vrc terofire

Products

product catalogue

fire detection accessories lighting

Manufacturers & Worldwide Exporters of Quality Assured Fire Panels

VRC Terofire Products have been in the manufacturing Lion House, Lion Street Congleton,
business since 1978, producing reliable quality Cheshire
CW12 4BH
products for the fire alarm and emergency lighting United Kingdom
industry.
Tel: +44(0)1260 297578
Fax: +44(0)1260 290078
Based in Cheshire for almost 30 years we have
enjoyed success not only in the UK but also worldwide www.terofire.com
- exporting our quality British made products A Division of VRTL (Holdings) Ltd
throughout the globe. Registered Number 1516961

To download any of our

Our full range of Fire Alarm Control Panels are designed to BS EN Quality Systems Certificates
54 parts 2&4. We have several products which carry full LPCB please go to:
approval certification. www.terofire.com
We have been working to ISO9001:2008 with both LPCB/BRE and
Isoqar for over 10 years, ensuring that our customers recieve the Product Certificates can be
best level of service we can offer. downloaded from our
on-line data sheets

To arrange a visit from our

Sales Rep please call us on
At VRC customer care is paramount. We offer you 01260 297578

far more than fire products, we offer you a full after Information and Prices on
sales care package which may include; badging your own fire panels
can be downloaded from
www.terofire.com
- Regional Sales Representitive, on the road support
- Corporate badging of fire panels to maximise your To book in for product training
company profile please call our Technical Dept.
- Full product training on a purpose built demonstration on 01260 297578
wall
For more information on our
- Technical back up via telephone or email Commissioning Pack please
- We offer our services on site visits call or email us at the
- Our BFPSA/FIA trained staff can recommend which Sales Office
range of products may suit your installation best
- Assist you to get your installation fully commissioned
- Recommend your fire system maintenance
Assessed to ISO 9001 Assessed to ISO 9001
Certificate Number 1454/97 Certificate Number 799 Issue 1
 Saffire 24-48 Zone Panel Data Sheet
at a glance
Open Protocol

675mm
Passive Repeater Available

Requires 2 x 12Ah Batteries

10
Kg

480mm
specification

Microprocessor based conventional fire alarm control panel

approved to EN54-2 & 4

24, 32, 40 or 48 detection zones

Expansion available in 8z cards

Surface fitting

Epoxy painted steel enclosure

Passive Repeater available

Zonal alarm circuits not supported

Codes

05-0035 Saffire 24 Zone Panel

05-0036 Saffire 32 Zone Panel
05-0037 Saffire 40 Zone Panel
05-0038 Saffire 48 Zone Panel
05-0039 Saffire 24-48 Repeater Panel

SUPPLY VOLTAGE 230V AC +10%/-15% @ 50/60 Hz

SYSTEM VOLTAGE 29V DC (Nominal)
technical data

DETECTION ZONES 24, 32, 40 or 48

ZONE VOLTAGE 21V DC
ZONE END OF LINE 100¼F capacitor
ZONE CAPACITY Up to 32 Devices
SOUNDER OUTPUT 4 X 400mA @ 24V DC
SOUNDER EOL 10K Resistor
SOUNDER DELAY 0 TO 9 Minutes
FIRE RELAY 1 Relay, SELV @ 1A
FAULT RELAY 1 Relay, SELV @ 1A (Normally Energised)
OTHER CONNECTIONS Class Change Input (N/O Contact)/ F.A.R.E. Output / Serial Repeater Output(4 Wire)
CHARGER SIZE 3 Amp
CHARGER VOLTAGE 28.4V DC (Batteries disconnected)
IP RATING IP43
OPERATING TEMP. -0°C to 50°C
ENCLOSURE SIZE 675 x 480 x 135 mm
WEIGHT 13 kg

10
 Conventional Fire Panel Overview

05-0011 Saffire 2 Zone EN54 Control Panel

05-0013 Saffire 4 Zone EN54 Control Panel

05-0014 Saffire 6 Zone EN54 Control Panel

05-0015 Saffire 8 Zone EN54 Control Panel

05-0017 Saffire 12 Zone EN54 Control Panel

05-0000 Saffire 8-12 Zone Repeater Panel

01-0054 Saffire Approved 2 Zone LPCB Control Panel

01-0055 Saffire Approved 4 Zone LPCB Control Panel
01-0056 Saffire Approved 6 Zone LPCB Control Panel
01-0057 Saffire Approved 8 Zone LPCB Control Panel

05-0030 Saffire 16 Zone EN54 Control Panel

05-0031 Saffire 20 Zone EN54 Control Panel
05-0032 Saffire 24 Zone EN54 Control Panel
05-0033 Saffire 16-24 Zone Repeater Panel

05-0035 Saffire 24 Zone EN54 Control Panel

05-0036 Saffire 32 Zone EN54 Control Panel
05-0037 Saffire 40 Zone EN54 Control Panel
05-0038 Saffire 48 Zone EN54 Control Panel
05-0039 Saffire 24-48 Zone Repeater Panel

11
Conventional Fire Panel Overview

Key2-8 Saffire 2-12 Zone Spare Key

KeyAP Saffire AP Spare Key
KeySw16-48 Saffire 16-48 Spare Operating Key
Key16-48 Saffire 16-48 Spare Door Lock Key

06-0010 Small Auxillary Box 285 x 230 x 85mm

06-0011 Large Auxillary Box 335 x 265 x 85mm

14-0013 End Of Line Unit

04-0004 Heavy Duty Relay

04-0006 4 Zone Alarm Extender Card

04-0010 Power Supply Unit Excluding Batteries

06-0001 2 Ah 12V Sealed Lead Acid Battery

06-0002 3 Ah 12V Sealed Lead Acid Battery
06-0003 7Ah 12V Sealed Lead Acid Battery
06-0004 12Ah 12V Sealed Lead Acid Battery

12
 accessories supported by

vrc terofire
Products

13
 10-0001 Optical Detector & Base Data Sheet
at a glance 10-0003 Heat Detector & Base

LPCB Certified

Open Protocol

Individually boxed complete

with base
wiring info

Requires pair of cables from sense or detection zones

Interlink detectors observing correct polarity

Terminate last devise with 3k3 resistor (supplied in panel)

for basic install, or use Active End of Line Unit (purchase
separately 14-0013) for head removal.

Locate 3k3 or EOL between +OUT (2) and -OUT (5).

Remote output wired via POS(6) & NEG(3) for LED’s.

Features and Benefits Simple, clear and easy replace and removal feature
features

Advanced photoelectric smoke sensing

Durable sensor head
Excellent smoke access
Dual LEDs for 360° visibility
Easy installation and maintenance
Modern design for any décor

LPCB Approval Number: 512a/02 Step 2 Step 1

Twist to long alignment Line alignment mark on
LPCB Approval Number: 512d/03 mark to lock in place, to detector to short
remove twist back to short alignment mark on base
LPCB Approval Number: 512b/02 alignment mark
technical data

Smoke Sensitivity EN 54-5/7:2000 standard

Detection Range 100 square m rating for smoke sensor; 50 square m rating for heat sensor
Start-Up Current 70 µA Maximum
Alarm Impedance 560R+3V max (red LED open circuit)
Reset Voltage Less than 1 volt
Reset Time Less than 1 sec
Alarm Indicator LED Continuously emitting red light
Temperature range -10°C to 50°C
Remote Output 15 mA max, diode gate
Humidity 0 to 95% RH, noncondensing
Dimensions 100mm (dia) x 46mm (ht) with base
Weight 130g/set with base

14
Conventional Detector Range

10-0001 Terofire EA LPCB Optical Detector c/w Base

10-0003 Terofire EA LPCB Heat Detector c/w Base

07-0000 Nittan ST-P-OM Optical Detector

07-0002 Nittan NHD-G2 66 Degree Heat Detector
07-0003 Nittan NHD-GH1 80 Degree Heat Detector

07-0004 STB-4RD 470 Ohm Diode Base

07-0005 STB-4R 470 Ohm Common Base

11-0000 Apollo Series 65 Optical Detector

11-0001 Apollo Series 65 Ionisation Detector
11-0002 Apollo Series 65 A1R 57 Deg RoR Heat Detector
11-0003 Apollo Series 65 BR 75 Deg RoR Heat Detector
11-0004 Apollo Series 65 CR 90 Deg RoR Heat Detector
11-0005 Apollo Series 65 CS 90 Deg Fixed Heat Detector

11-0006 Apollo Series 65 Diode Base

11-0007 Apollo Series 65

15
Conventional Accessory Range

12-0001 Fulleon Roshni Shallow Base

12-0002 Fulleon Roshni Deep Base
12-0003 Fulleon 6" Fire Bell
12-0005 Fulleon White Sounder Base
12-0006 Fulleon White Sounder Strobe Combi Base
12-0007 Fulleon Flasni Combined Sounder Strobe

14-0001 Cranford Remote Indicator Square

12-0033 Cranford Red Vantage Sounder
12-0034 Cranford Vector Sounder Base
12-0037 Cranford Vector Cover Plate
12-0024 Cranford Vantage Deep Base Combined Sounder Strobe
12-0035 Cranford Flashing Beacon Only

14-0018 VRC Surface Mount Resettable Call Point with Hinged Cover
14-0002 Fulleon Universal Call Point

14-0005 Cranford 24V Magnetic Door Holder

14-0006 Cranford 230V Mangentic Door Holder

14-0008 Dorgard Wireless Door Retainer

16
 Wedging open fire doors is illegal and
dangerous. Dorgard is the safe, legal and cost
effective solution.

Dorgard provides a wireless solution for legally

holding open fire doors in any position.

Acoustic Door Retainer Features

• Installs in under 5 minutes

• Automatically releases fire doors when

fire alarms sound

• Automatic night-time release facility

• Improves access for wheelchair users in

line with the Disability Discrimination Act

• Complieswith BS EN 1155 and approved

by the Fire Brigade

Dimensions and weight Material and operating specifications

• Overall height: 205mm • Casing: ABS
• Main casing height: 150mm • Power: 2 x 1.5v C size alkaline batteries
• Width: 195mm (do not use rechargeable batteries)
• Depth: 45mm • Expected battery life: 12 months
• Packed kit weight: 950g • Trigger: by alarms compliant with BS 5839-3
• Product only (including batteries): 700g

Approvals and standards Dorgard Acoustic Retainer

• BS EN 1155: 1997 building hardware. Electrically
powered hold-open devices for swing doors.
(Manufacturer’s classification number 357113).
• EN61000-6-1:2001 Electromagnetic compatibility
(EMC). Generic standards. Immunity for
residential, commercial and light industrial
environments.
• EN61000-6-3:2001+A11:2004. Electromagnetic
compatibility (EMC). Generic standards.
Emission standard for residential, commercial
and light industrial environments.
• BS 7273-4 category C. Code of practice for the
operation of fire protection measures. Activation
of release mechanisms for doors.
• USA patent number: 5525963
• European patent number: 0635092

Fireco reserves the right to alter specifications without prior notification.

17
Solo 330 Aerosol Smoke Dispenser

Fundamental to functional smoke checking for many professionals around the world the
Solo 330 contains the test aerosol and ensures that it is applied correctly and contained
only where required. Used with the access poles it enables safe testing at heights but is
equally valued at low level.

* Lightweight and simple to use

* Universal design suits widest range of detectors (up to 100mm / 4" in diameter)
* Spring-loaded solution for suspended ceilings
* Transparent test cup for clear view of detector LED
* Swing frame for use at / from angles
* Outstanding quality backed by lifetime warranty
* Detector manufacturer approved
* Solo 332 suitable for detectors up to 177mm / 7" in diameter

Solo 461 Cordless Heat Detector Tester (battery powered)

Using the unique IR activation and Cross Air Technology, the Solo 460 heat generation process takes place only
when the detector under test is within the cup with hot air blown horizontally in a focussed beam directly toward
the sensor for optimum energy use and results. Interchangeable NiMH battery batons and a fast battery recharger
enable testing all day with a cable free professional device.
* Detector manufacturer endorsed
* No cables, trailing leads or hanging wires
* Battery powered (includes 2 Battery Batons and
UL listed fast charger)
* Suits fixed temperature, RoR and combination
detectors up to 194°F / 90°C
* Lightweight and simple to use
* Universal design suits widest range of detectors
* Transparent test cup for clear view of detector LED
* Designed for use at height, angles or low level

Solo 423 / 424 Heat Detector Tester (110 -> 240V)

Available in both 110 / 120 and 220 / 240 volt versions the Solo 423 and 424 are the professionals’ choice where
cables and leads are acceptable. Unconstrained by energy availability they provide the quickest of test times and
are, perhaps, most suitable for the highest temperature detectors.

* Suit fixed temperature, RoR and combination detectors up to 194°F / 90°C

* Quickest activation times
* Lightweight and simple to use
* Universal design suits widest range of detectors
* Designed for use at height, at angles and low level
* Supplied with 5m / 16ft cable (additional 5m / 16ft cable available)

18
 Smoke Test Kits 14-0030 810-001 Smoke Starter Kit: 2.5m Inc. Arm Reach
1 x Pole to 1.13m, 1 x Smoke Dispenser, 1 x Canned Smoke
14-0031 808-001 Smoke Starter Kit: 4m Inc. Arm Reach
1 x Pole to 2.5m, 1 x Smoke Dispenser, 1 x Canned Smoke
14-0032 809-001 Smoke Starter Kit: 6m Inc. Arm Reach
1 x Pole to 1.13m, 1 x Smoke Dispenser, 1 x Canned Smoke
14-0033 811-001 Smoke Test & Removal Kit: 6m Inc. Reach
1 x Telescopic Pole to 4.5m, Removal Tool, 1 x Smoke Dispenser,
1 x Canned Smoke, Protective Carry/Storage Bag

Heat & Smoke Test Kits

14-0035 814-001 Smoke & Mains Heat Kit: 6m inc Reach
1 x Telescopic Pole to 4.5m, Removal Tool, 1 x Smoke Dispenser, 1 x
240v Heat Tester 1 x Canned Smoke, Protective Carry Bag

14-0036 822-001 Smoke & Cordless Heat Kit: 6m inc Reach

1 x Telescopic Pole to 4.5m, Removal Tool, 1 x Smoke Dispenser,
1 x Cordless Heat Tester inc. Battery 1 x Canned Smoke, Protective
Carry Bag

14-0034 330-001 Aerosol Smoke & CO Dispenser Head

14-0037 424-001 240v Heat Detector Tester c/w 5m Cable

14-0038 461-001 Cordless Heat Detector Tester Set: Includes 1 x Cordless

Head Unit, 2 x Battery Baton, 1 x Fast Mains & Car Charger

14-0040 100-001 Fiberglass 4 Section Telescopic Pole 4.5m

Reach of 6m including height of man
x12 108-001 Fiberglass 2 Section Telescopic Pole 2.5m
14-0041
Reach of 4m including height of man
14-0042 101-001 Fiberglass Extension Pole 1.13m
Reach of 2.5m including height of man

14-0045 A3-00 Smoke Detectcor Test Spray Pack 12

14-0046 C3-001 CO Detector Test Spray Pack 12
14-0047 A7-001 Detector Cleaning Spray Pack 12

14-0050 220-001 Universal Detector Removal Tool

Pole Not Included

14-0051 1002-001 Additional Spare Transparent Grips

For use with removal tool

14-0052 610-001 Protective Carry / Storage Bag

Designed to fit all product range
Separate pole bag included

19
 conventional
Saffire Control Panel Range 1-12 Zones....3-8

Saffire Control Panel 16-48 Zones....9-10

Conventional Panel & Accessory Overview....11-12

Conventional Detectors....13-15

Conventional Sounders, Beacons, Call Points....16

Fireco Dorgard ....17

Solo Detector Tester Range....18-19

emergency lighting
Emergency Bulkhead Range....21

Metal Exit Boxes & Twinspots....22

addressable
Simplicity Addressable Range 1 Loop....24-25

EA Pro-Line Range 1-4 Loops....26

Addressable Panel & Accessory Overview....27

EA Addressable Detectors, Sounders, Call Points....28

Apollo XP95 Detectors, Sounders & Call Points....29

emergency
lighting
vrc terofire
Products

20
 Emergency Lighting Bulkhead Range

Standard Style 8W Bulkead for Indoor or Outdoor Applications.

Measures: 250 x 118 x 72mm

18-0006 Toplite 8W Non Maintained IP65 Bulkhead

18-0007 Toplite 8W Maintained IP65 Bulkhead

Fully Recessable 8W Bulkhead for Indoor Applications Only

Measures:

25-0001 Slimline 8W NM Recessed Indoor Bulkhead

25-0002 Slimline 8W MTD Recessed Indoor Bulkhead

16W or 28W 2D Emergency Fitting for Indoor Applications

Measures: 260mm Diameter x 85mm depth

15-0035 16W Indoor Kandel Maintained Emergency Fitting

15-0036 28W Indoor Kandel Maintained Emergency Fitting

16W or 28W 2D Emergency Fitting for Indoor or Outdoor Applications

Measures: 225 x 225 x 90mm

15-0018 16W IP65 Square Maintained Emergency Fitting

15-0019 28W IP65 Square Maintained Emergency Fitting

Self Adhesive Legend Pack, can be fitted in any combination

18-0009 Multi-Position Legend Pack for Bulkheads

21
Emergency Lighting Alternative Range

8W illuminated exit sign with a selection of screen printed legends available

21-0001 Metal Exit Box 8W Mainatined

Please specify legend requirement when ordering

Powerful twin flood luminaire complete with IP65 rated 21W lamps in an IP55 rated
strong plastic enclosure

24-0002 IP55 Rated 2 x 21W Twinspot Excluding Battery

06-0002 7Ah Sealed Lead Acid Battery

1 Hour Rating Requires 1 x 7Ah Battery

3 Hour Rating Requires 2 x 7Ah Battery

Powerful twin flood luminaire complete with IP65 rated 21W lamps in a powder
coated steel enclosure

24-0004 2 x 21W 3 Hour Twinspot Including Batteries

Self contained low energy gear tray ideal for converting non emergency
lighting enclosures to 16W or 28W Maintained emergency units

15-0040 16W Maintained Module Gear Tray Excluding Lamp

15-0041 28W Maintained Module Gear Tray Excluding Lamp

Lighting replacement accessories

33-0004 Replacement 8W Lamps

22
 control range supported by

vrc terofire
Products

23
Analogue Addressable Fire Alarm Systems /

Simplicity Micro Analogue Addressable

Fire Alarm Panel (SP-M)

The Simplicity Micro is a unique concept

that provides the best possible entry
level solution for addressable Àre alarm
systems. It is directed primarily towards
small installations, where traditionally the
use of addressable systems would have been
considered cost prohibitive.
The Micro is based upon the successful Simplicity 64
& 126 Àre alarm panels and incorporates many of the
larger systems features. These include single loop
connection, minimal commissioning & conÀguration, 20
character label for each connected device and a 2,046
history event log.

Features
Complies fully to EN54 parts 2 & 4
CE marked
Slimline enclosure
Model SP-M Flame retardant ABS plastic
Supply Voltage 230V AC +/- 10%
Set of changeover relay output in fault condition
System Voltage 24V DC (nominal)
Set of changeover relay output in relay condition
Number of Loops 1
Loop Capacity 32 devices Each detector can have a sounder or combined
sounder & Áasher base
Number of Zones 4
2,046 event log (Àre & fault)
Sounder Output Addressable sounder only
Fault Output 28 V repeat output to drive Zone or device disablement
relay (normally energised) One man test mode
Fire Output 28 V repeat output to drive Plug & play, no need for any special tools or
relay laptop for commissioning
Operating Temperature -0°C to 50°C
Fully integrated keypad
Enclosure Size (mm) 355 x 275 x TBC
All associated devices are loop powered
Weight TBC

Compatible with conventional detectors to save money Range of standalone addressable detectors

Securetone Micro Addressable Securetone Micro Addressable Addressable Addressable Addressable Addressable
Sounder Base Sounder & Flasher Base Optical Detector Opto-Heat Detector Rate of Rise Heat Detector Fixed Heat Detector
(SM-ASB) (SM-ASFIB) (FEAOE2000) (FEAOH2000) (FEAHE2000) (FEAHHE2000)

Range of Addressable Maxitone Addressable Maxitone Sounder Addressable Securetone 2 Addressable Addressable
input/output Sounder & Flasher available in Red (ZAMT/R) Sounder Flasher c/w Isolator Securetone 2 Sounder Manual Call Point
Simplicity Micro modules (ZAMTF/R) or White (ZAMT/W) available in Red (ZAS2/RFI) available in Red (ZAS2/R) (ZT-CP2/AD)
(SP-M) or White (ZAS2/WFI) or White (ZAS2/W)

24
Analogue Addressable Fire Alarm Systems /

Simplicity Micro Analogue Addressable

Fire Alarm Panel (SP-M)

The Simplicity Micro is a unique concept

that provides the best possible entry
level solution for addressable Àre alarm
systems. It is directed primarily towards
small installations, where traditionally the
use of addressable systems would have been
considered cost prohibitive.
The Micro is based upon the successful Simplicity 64
& 126 Àre alarm panels and incorporates many of the
larger systems features. These include single loop
connection, minimal commissioning & conÀguration, 20
character label for each connected device and a 2,046
history event log.

Features
Complies fully to EN54 parts 2 & 4
CE marked
Slimline enclosure
Model SP-M Flame retardant ABS plastic
Supply Voltage 230V AC +/- 10%
Set of changeover relay output in fault condition
System Voltage 24V DC (nominal)
Set of changeover relay output in relay condition
Number of Loops 1
Loop Capacity 32 devices Each detector can have a sounder or combined
sounder & Áasher base
Number of Zones 4
2,046 event log (Àre & fault)
Sounder Output Addressable sounder only
Fault Output 28 V repeat output to drive Zone or device disablement
relay (normally energised) One man test mode
Fire Output 28 V repeat output to drive Plug & play, no need for any special tools or
relay laptop for commissioning
Operating Temperature -0°C to 50°C
Fully integrated keypad
Enclosure Size (mm) 355 x 275 x TBC
All associated devices are loop powered
Weight TBC

Compatible with conventional detectors to save money Range of standalone addressable detectors

Securetone Micro Addressable Securetone Micro Addressable Addressable Addressable Addressable Addressable
Sounder Base Sounder & Flasher Base Optical Detector Opto-Heat Detector Rate of Rise Heat Detector Fixed Heat Detector
(SM-ASB) (SM-ASFIB) (FEAOE2000) (FEAOH2000) (FEAHE2000) (FEAHHE2000)

Range of Addressable Maxitone Addressable Maxitone Sounder Addressable Securetone 2 Addressable Addressable
input/output Sounder & Flasher available in Red (ZAMT/R) Sounder Flasher c/w Isolator Securetone 2 Sounder Manual Call Point
Simplicity Micro modules (ZAMTF/R) or White (ZAMT/W) available in Red (ZAS2/RFI) available in Red (ZAS2/R) (ZT-CP2/AD)
(SP-M) or White (ZAS2/WFI) or White (ZAS2/W)

24
EA Pro Line Addressable Data Sheet
The EA Pro-Line 1-2 Loop provides a powerful yet user friendly solution to installations which require cause and
effect programming. Events may be logged on the optional printer and the addition of an optional network card
allows monitoring, indication and control of the functions of a networked installation.

- From 1-2 loops

- 126 Addresses per Loop
- Compliant with EN54 parts 2 and 4, BS EN 60950 and BS EN
50130 part 4
- Full Saffire Addressable detector compatibility
- Extensive cause & effect capability
- Windows-based, full upload/download PC software package
- 500mA output per loop with highly stable voltage platform,
even under mains-failed conditions
- Fully networkable with other EA Pro-Line panels, graphics
package and network repeaters
- Powerful processing and extensive panel and loop I/O
capability
- User-friendly controls and a clear, unambiguous screen
10-0020 EA Pro-Line 1 Loop Panel
- Membrane fascia with tactile switches
10-0022 EA Pro-Line 2 Loop Panel

Mains voltage 230V AC +10% -6%

Max. battery charging current 1.5A
Alarm circuits 2 @ 1A per circuit
Auxiliary supply 20V-28V @ 500mA
Weight (excluding batteries) 8kg
Dimensions 370mm high x 325mm wide x 139mm deep

Continuing from the EA Pro-Line 1-2 Loop panel, the 3-4 Loop offers the same comprehensive features, fully
approved by the LPCB.

- From 3-4 loops

- 126 Address per Loop
- LPCB approved to EN54 parts 2 and 4
- Full EA Pro-Line & Saffire Addressable compatibility
- Extensive cause & effect capability
- Windows-based, full upload/download PC software
package
- 500mA output per loop with highly stable voltage platform,
even under mains-failed conditions
- Fully networkable with other EA Pro-Line panels, graphics
package and network repeaters
- Powerful processing and extensive panel and loop I/O
capability
- User-friendly controls and a clear, unambiguous screen
- Membrane fascia with tactile switches 10-0020 EA Pro-Line 1 Loop Panel
10-0022 EA Pro-Line 2 Loop Panel

Mains voltage 230V AC +10% -6%

Max. battery charging current 1.5A
Alarm circuits 2 @ 1A per circuit
Auxiliary supply 20V-28V @ 500mA
Weight (excluding batteries) 15kg
Dimensions 480mm high x 410mm wide x 144mm deep

26
 Addressable Panel Overview

09-0000 Simplicity Micro Addressable Panel

09-0001 Simplicity 64 1 Loop Addressable 4 Zone Panel
09-0002 Simplicity 126 1 Loop Addressable 8 Zone Panel

10-0020 EA Pro-Line 1 Loop Analogue Addressable Panel

10-0022 EA Pro-Line 2 Loop Analogue Addressable Panel

Please specify protocol when ordering

10-0023 EA Pro-Line 3 Loop Analogue Addressable Panel

10-0024 EA Pro-Line 4 Loop Analogue Addressable Panel

Please specify protocol when ordering

10-0025 EA Pro-Line Repeater c/w Power Supply Unit

10-0026 EA Pro-Line Repeater Card

10-0027 EA Pro-Line Printer

10-0028 EA Pro-Line 1-2 Loop Bezel

10-0029 EA Pro-Line 3-4 Loop Bezel

27
Addressable EA Detector & Accessory Overview
09-0004 LPCB Addressable Dual Optical/Heat Detector
09-0005 LPCB Addressable Optical Detector
09-0006 LPCB 57 Degree Addressable Detector
09-0007 LPCB 90 Degree Addressable Detector
09-0008 European Approved Optical Detector
09-0009 European Approved Heat Detector

09-0010 Common Detector Base

09-0011 Isolator Base
09-0012 Stand Alone Isolator
09-0013 Base Mounted Sounder Strobe
09-0014 Base mounted Sounder

09-0015 Addressable Remote LED

09-0016 Addressable Call Point
09-0017 Loop Powered Sounder Strobe 80dB (Midi)
09-0018 Addressable Midi Sounder 88dB
09-0019 Addressable Wall Mounted Sounder (Maxi)
09-0025 Addressable Wall Sounder Strobe (Maxi)

09-0028 Loop Powered Sounder 100dB

09-0029 Loop Powered Sounder Strobe 100dB

09-0020 Loop Powered Input Module

09-0021 Loop Powered Input/Output Module
09-0022 Addressable Sounder Circuit Controller
09-0023 Addressable Zone Monitor Unit

14-0010 Refective Beam 40m Auto Aligning

14-0011 40-80m Reflective Beam Addition Kit
14-0012 80-100m Reflective Beam Addition Kit
09-0024 Beam Interface Unit

28
Apollo XP95 Overview for use with Apollo Protocol Voyager or Discovery Panels

11-0020 Apollo XP95 Optical Smoke Detector

11-0021 Apollo XP95 Ionisation Detector
11-0022 Apollo XP95 55 Deg Heat Detector
11-0023 Apollo XP95 90 Deg Heat Detector

11-0024 Apollo XP95 Base c/w XPERT Card

11-0025 Apollo XP95 Isolator Base
11-0028 Apollo XP95 Stand Alone Isolator c/w Base
11-0029 Apollo XP95 Base Sounder 55-91dB
11-0030 Apollo XP95 Base Sounder 55-91dB c/w Isolator
11-0031 Apollo XP95 Sounder Beacon Base 55-91 dB
11-0032 Apollo XP95 Sounder Beacon Base 55-91 dB c/w Isolator

11-0033 Apollo XP95 Loop Powered Sounder 100/92dB

11-0034 Apollo XP95 Loop Powered Sounder Beacon 100/92dB

11-0026 Apollo XP95 Surface Resettable Call Point

11-0027 Apollo XP95 Surface Resettable Call Point c/w Isolator

11-0035 Apollo XP95 Input/Output Unit

11-0036 Apollo XP95 Output Unit
11-0037 Apollo XP95 Switch Monitor Plus
11-0038 Apollo XP95 Zone Monitor
11-0039 Apollo XP95 Sounder Control Unit

11-0040 Apollo XP95 Beam Kit

29
 one range
multiple solutions
vrc terofire
Products

3
Contact Details

Our Sales Office is still based in the heart of

Cheshire, only 15 minutes from the M6 motorway.

For full directions on how to reach us please see our

website www.terofire.com

At VRC Terofire Products we are a close working team,

aiming to give our customers the best service and
the best products we can offer.
From inhouse technical support to Regional ‘On The Road’ Sales Care
we pride ourselves on offering a personal level of service, which you can rely upon.

Product Training & Demonstrations

To arrange a product training session please contact our Technical

Manager.

Your training session can be completely tailored to suit your own

requirements or we can offer a broad
demonstration across all of our extensive panel ranges.

useful email contacts:

Sales : sales@terofire.com
Technical : technical@terofire.com
Quality : quality@terofire.com
Accounts : accounts@terofire.com

VRC Terofire Products

Lion House, Lion Street
Congleton, Cheshire, CW12 4BH
United Kingdom

Tel: +44 (0) 1260 297578

Fax: +44 (0) 1260 290078
www.terofire.com

call us. fax us. email us.

you order. we supply.
 vrc terofire
Products
Lion House Lion Street Congleton Cheshire CW12 4BH
United Kingdom

t:+44 (0)1260 297578 f:+44(0)1260 290078

e: sales@terofire.com
www.terofire.com
the saffire range
The Saffire Range offers affordable quality in a
contemporary styled enclosure. The microprocessor
based conventional control panels are designed to
EN54 2&4 using surface mount technology, providing
reliable and durable cover from 2 through to 12
zones. The Saffire Range is made by VRC in the UK
supporting British Manufacturing.

The cream steel enclosures with tactile touch buttons

are subtle enough to grace any public area, with
discreet colour the panel range has a modern
appearance.

Recently added to the Saffire Range are the Saffire AP

- an LPCB Approved 2-8 zone panel and the Saffire
16-24 and 24-48 Zone Panels. The larger panels are
ideally suited to larger installations where
addressable systems are not favourable.

Installation itself could not be more simple, with fully

open protocol almost every detector on the market is
compatible, along with call points, sounders and
strobes. The 2 alarm zones as standard can be
optionally increased to 4 circuits if required using an
additional card.

The small 5cm x 3cm aperture allows for cost

effective branding which can be used over the full
panel range. Free of charge artwork is offered
inhouse and your Saffire Panel will be delivered fully
branded – an idea option for maintenance
companies wanting to provide service numbers and
advertise

c
conventional
en
ntio
nt
contemporary
mpo
porary
competitive
4
 05-0011 Saffire 2 Zone Panel Data Sheet

Open Protocol
at a glance

225mm
470 Ohm Firing Resistor

2 x Sounder Circuits
Kg
4.5

Requires 2 x 2Ah Batteries

87m
m MADE IN UK
234m

m
specification

Microprocessor based conventional fire alarm control panel

complies with EN54-2 & 4

2 detection zones

One set of volt free changeover contacts operable on fire

Head removal via zener clamp or active end of line unit

Open collector fault output

Zone and alarm disablement

Tactile Touch Buttons

features

Keyswitch Operation

Affordable Branding

2 Zone 4 Zone 6 Zone

Mains Voltage (VAC) 240 240 240
technical data

System Voltage (VDC) 28.4 28.4 28.4

Quiescent Current Unsilenced Fault (mA) 76 89 102
Minimum Battery Size (Ah) 2 x 12V Required 2.2 3 3
Detector Voltage (VDC) 20 20 20
No. of Sense Zones 2 4 6
Max No. of Detectors per Zone 30 30 30
Firing Resistance (Ohms) 510 ± 200 510 ± 200 510 ± 200
Sense Zone EOL (Ohms) 3k3 3k3 3k3
Alarm Voltage (VDC) 28.4 28.4 28.4
No. of Alarm Zones 2 2 2
Max. Alarm Current per Zone (mA) 200 300 300
Max. No. of Sounders per Zone 10 16 16
Alarm Zone EOL (Ohms) 10k 10k 10k
Max. Aux. Supply Current (mA) In Fire Condition N/A 50 50
Max. Permanent 28V Supply Current (mA) N/A N/A N/A
Panel Weight Inc. Batts. (kg) 4.5 5 5
5 Panel Dimensions (mm) 234x225x85 285x230x85
 05-0013 Saffire 4 Zone Panel
Data Sheet
05-0014 Saffire 6 Zone Panel

Open Protocol
at a glance

230mm
470 Ohm Firing Resistor

2 x Sounder Circuits 5
Kg

285m
m
Requires 2 x 3Ah Batteries m MADE IN UK
87m

Microprocessor based conventional fire alarm control panel

complies with EN54-2 & 4

4 or 6 detection zones
specification

Two set of volt free changeover contacts operable on fire

Head removal via zener clamp or active end of line unit

Open collector fault output

Zone and alarm disablement

Class change input

Non-latching zones facility

One man test facility

28V 50mA fused supply available on fire

Tactile Touch Buttons

features

Keyswitch Operation

Affordable Branding

2 Zone 4 Zone 6 Zone

Mains Voltage (VAC) 240 240 240
technical data

System Voltage (VDC) 28.4 28.4 28.4

Quiescent Current Unsilenced Fault (mA) 76 89 102
Minimum Battery Size (Ah) 2 x 12V Required 2.2 3 3
Detector Voltage (VDC) 20 20 20
No. of Sense Zones 2 4 6
Max No. of Detectors per Zone 30 30 30
Firing Resistance (Ohms) 510 ± 200 510 ± 200 510 ± 200
Sense Zone EOL (Ohms) 3k3 3k3 3k3
Alarm Voltage (VDC) 28.4 28.4 28.4
No. of Alarm Zones 2 2 2
Max. Alarm Current per Zone (mA) 200 300 300
Max. No. of Sounders per Zone 10 16 16
Alarm Zone EOL (Ohms) 10k 10k 10k
Max. Aux. Supply Current (mA) In Fire Condition N/A 50 50
Max. Permanent 28V Supply Current (mA) N/A N/A N/A
Panel Weight Inc. Batts. (kg) 4.5 5 5 6
Panel Dimensions (mm) 234x225x85 285x230x85
 05-0015 Saffire 8 Zone Panel
Data Sheet
05-0017 Saffire 12 Zone Panel

Open Protocol
at a glance

265mm
470 Ohm Firing Resistor

2 x Sounder Circuits 10
Kg

Requires 2 x 7Ah Batteries m MADE IN UK

335m

87m
m
Microprocessor based conventional fire alarm control panel
complies with EN54-2 & 4
specification

8 10 or 12 detection zones

Two set of volt free changeover contacts operable on fire

One set of volt free changeover contacts operable on fault

Head removal via zener clamp or active end of line unit

None latching zones facilirty

Zone and alarm disablement , Class change input

28V 125mA fused supply permanently available

28V 50mA fused supply available on fire

Passive repeater available (3 core connection)

Tactile Touch Buttons

features

Keyswitch Operation

Affordable Branding

8 Zone 12 Zone
Mains Voltage (VAC) 240 240
technical data

System Voltage (VDC) 28.4 28.4

Quiescent Current Unsilenced Fault (mA) 115 135
Minimum Battery Size (Ah) 2 x 12V Required 7 7
Detector Voltage (VDC) 20 20
No. of Sense Zones 8 12
Max No. of Detectors per Zone 30 30
Firing Resistance (Ohms) 510 ± 200 510 ± 200
Sense Zone EOL (Ohms) 3k3 3k3
Alarm Voltage (VDC) 28.4 28.4
No. of Alarm Zones 2 2
Max. Alarm Current per Zone (mA) 300 300
Max. No. of Sounders per Zone 16 16
Alarm Zone EOL (Ohms) 10k 10k
Max. Aux. Supply Current In Fire Condition 50 50
Max. Permanent 28V Supply Current (mA) 125 125
7 Panel Weight Inc. Batts. (kg) 10 10
Panel Dimensions (mm) 335x265x87
 Saffire AP, LPCB Approved Panel Data Sheet
at a glance
LPCB Certified

275mm
Open Protocol

Passive Repeater Available

335mm 10
Kg

Microprocessor based conventional fire alarm control panel

approved to EN54-2 & 4
specification

2, 4, 6 or 8 detection zones

One man test facility

One set of volt free changeover contacts operable on fire

One set of volt free changeover contacts operable on fault

Class change input

Zone isolate facilities

Sounder activation delay (up to 9 minutes)

Zone and alarm disablement

Codes

01-0054 Saffire AP 2 Zone Panel

01-0055 Saffire AP 4 Zone Panel
01-0057 Saffire AP 6 Zone Panel
01-0058 Saffire AP 8 Zone Panel

2 Zone 4 Zone 6 Zone 8 Zone

technical data

Mains Voltage (VAC) 240 240 240 240

System Voltage (VDC) 24 24 24 24
Quiescent Current Unsilenced Fault (mA) 48 48 48 48
Minimum Battery Size (Ah) 2 x 12V Required 7 7 7 7
Detector Voltage (VDC) 21 21 21 21
No. of Sense Zones 2 4 6 8
Max No. of Detectors per Zone 32 32 32 32
Firing Resistance (Ohms) 510 ± 200 510 ± 200 510 ± 200 510 ± 200
Sense Zone EOL (Ohms) Diode Diode Diode Diode
Alarm Voltage (VDC) 24 24 24 24
No. of Alarm Zones 2 2 2 2
Max. Alarm Current per Zone (mA) 400 400 400 400
Max. No. of Sounders per Zone 20 20 20 20
Alarm Zone EOL (Ohms) 10k 10k 10k 10k
Panel Weight Inc. Batts. (kg) 10 10 10 10
Panel Dimensions (mm) 335x275

8
 Saffire 16-24 Zone Panel Data Sheet
at a glance
Open Protocol

395 mm
Passive Repeater Available

Requires 2 x 7Ah Batteries

10
Kg

480mm

Microprocessor based conventional fire alarm control panel

specification

approved to EN54-2 & 4

16, 20 or 24 detection zones

Expansion available in 8z cards

Surface or semi flush fitting

Lightweight IP 43 enclosure

Passive Repeater available

Zonal alarm circuits can be added using cards

Codes

05-0030 Saffire 16 Zone Panel

05-0031 Saffire 20 Zone Panel
05-0032 Saffire 24 Zone Panel
05-0033 Saffire 16-24 Repeater Panel
technical data

No. OF SENSE ZONES 16, 20 OR 24

MAINS VOLTAGE 230 VAC± 10% / -15% @ 50/60 Hz
SYSTEM VOLTAGE 24 Vdc (Nominal)
ZONE VOLTAGE 21 Vdc
SOUNDER ALARM O/P 4 x 250 mA @ 24 Vdc
FAULT RELAY O/P 1 x relay SELV @ 1 A Maximum
FIRE RELAY O/P 1 x relay SELV @ 1 A Maximum
ZONE CAPACITY 32 Devices
ZONE E.O.L 100¼F Capacitor
CHARGER VOLTAGE 28.4 Vdc (batteries disconnected)
CHARGER SIZE 3.0 Amp
ENCLOSURE 480L x 395H x 100D mm
WEIGHT 14.00 Kg
IP RATING IP 43
