Atlas Copco: Simba H1354 Spare Parts Catalogue

Atlas Copco
Simba H1354
Spare Parts Catalogue
8991 9808 00
PM No. 8991980800
Use Atlas Copco genuine parts only. Använd alltid Atlas Copco originaldelar.
Any damage or mailfunction caused by the Skador och driftstörningar orsakade av ej
use of unauthorized parts is not covered by godkända reservdelar täcks ej av garanti
warranty or product liability. och produktsäkerhetsåtaganden.
This publication refers only to the mentioned Denna publikation gäller endast för
product. nämnda produkt.
When ordering spare parts, please state part Vid beställning av reservdelar, var god ange
number (not the ref no) and the quantity. detaljnummer (ej ref nr) samt antal.
© Copyright 2012, Atlas Copco Rock Drills AB, Sweden

Any unauthorized use or copying of the contents or any part thereof is prohibited.
This applies in particular to trademarks, model denominations, part numbers and drawings.
Obehörigt utnyttjande eller kopiering av innehållet eller del därav är förbjudet.
Detta gäller speciellt varumärken, modellbeteckningar, reservdelsnummer och ritningar.
Atlas Copco Rock Drills AB

SE-70191 Örebro, Sweden
Table of Content / Innehållsförteckning
1. ROCK DRILL / BERGBORRMASKIN .................................................... 5
2. FEED / MATARE ................................................................................... 55
3. POS. EQUIPMENT / POS.UTRUSTNING .......................................... 191
4. CARRIER / UNDERREDE .................................................................. 243
5. CABLE REEL / KABELVINDA ........................................................... 471
6. HYDR. SYSTEM / HYDRAULSYSTEM .............................................. 505
7. ELECTR. SYSTEM / ELSYSTEM ....................................................... 663
8. ANGLE IND.COMPL / RIKTINSTR.KOMPL ....................................... 763
9. AIR/WATERSYSTEM / LUFT/VATTENSYST ..................................... 785
10. HOSE CONNECTION / SLANGANSLUTNING ................................. 859
11. HOSES / SLANGAR ........................................................................... 879
12.CROSS REFERENCE LIST .................................................................. 891
3
4
ROCK DRILL / BERGBORRMASKIN
LIST OF CONTENTS
Part no Description Benämning See page Remarks
Detaljnr Se sida Anmärkning
– ROCK DRILL BERGBORRMASKIN 11
3115 3451 81 – ACCUMULATOR – ACKUMULATOR 19
3115 3511 81 – ACCUMULATOR – ACKUMULATOR 21
3115 2615 91 – RETURN ACCUM. – RETURACKUMULAT. 23
3115 3473 81 – HYDRAULIC MOTOR – HYDRAULMOTOR 25 MSQ 100 SH (05)
– – OPTIONAL SET – OPTIONGRUPP 31
– – – ASSEMBLY TOOL – – MONTERINGSVERKT 33
3115 9153 90 – – O-RING SET – – O-RINGSSATS 35 COP 1638-2560
3115 2887 80 – – CONNECT. PLATE – – ANSLUTN.PLATTA 37 OMS
3115 9156 93 – – SEAL KIT – – TÄTNINGSSATS 39 SEAL KIT COP 1838MUX/HUX
3115 9153 90 – – – O-RING SET – – – O-RINGSSATS 35 COP 1638-2560
3115 9156 94 – – SEAL KIT – – TÄTNINGSSATS 41 SEAL KIT EXTRACTOR
COP 1838MUX/HUX
3115 9156 95 – – OVERHAUL KIT – – RENOVERINGSSATS 43 400 IMPACT HOURS KIT
COP 1838MUX/HUX
3115 9156 93 – – – SEAL KIT – – – TÄTNINGSSATS 39 SEAL KIT COP 1838MUX/HUX
3115 9153 90 – – – – O-RING SET – – – – O-RINGSSATS 35 COP 1638-2560
3115 9156 96 – – OVERHAUL KIT – – RENOVERINGSSATS 47 800 IMPACT HOURS - 1838MUX
3115 9156 95 – – – OVERHAUL KIT – – – RENOVERINGSSATS 43 400 IMPACT HOURS KIT
COP 1838MUX/HUX
3115 9156 93 – – – – SEAL KIT – – – – TÄTNINGSSATS 39 SEAL KIT COP 1838MUX/HUX
3115 9153 90 – – – – – O-RING SET – – – – – O-RINGSSATS 35 COP 1638-2560
3115 9156 98 – – OVERHAUL KIT – – RENOVERINGSSATS 49 800 IMPACT HOURS - 1838HUX
3115 9156 95 – – – OVERHAUL KIT – – – RENOVERINGSSATS 43 400 IMPACT HOURS KIT
COP 1838MUX/HUX
3115 9156 93 – – – – SEAL KIT – – – – TÄTNINGSSATS 39 SEAL KIT COP 1838MUX/HUX
5
3115 9153 90 – – – – – O-RING SET – – – – – O-RINGSSATS 35 COP 1638-2560
3115 9156 97 – – OVERHAUL KIT – – RENOVERINGSSATS 51 OVERHAUL KIT EXTRACTOR
COP 1838MUX/HUX
3115 9156 94 – – – SEAL KIT – – – TÄTNINGSSATS 41 SEAL KIT EXTRACTOR
COP 1838MUX/HUX
3115 3425 80 – CHARGIN DEVICE – LADDN.UTRUSTN. 53 FOR ACCUMULATORS
6
7
ROCK DRILL / BERGBORRMASKIN COP 1838MUX
ROCK DRILLBERGBORRMASKIN
Fig. 1 of 3
B0054183
8
ROCK DRILL / BERGBORRMASKIN COP 1838MUX
Fig. 2 of 3
8311 1249 90 010D

9
Fig. 3 of 3
B0040575
10
(Sheet 1 of 6)
Ref Part no Qty Description Benämning See page Remarks
no Detaljnr Antal Se sida Anmärkning
2 3115 1944 80 1 CYLINDER CYLINDER COMPLETE INCL.POS 3-12
3 – 1 CYLINDER CYLINDER NOT DELIVERY SEPARATELY
5 0259 0311 00 1 THREAD INSERT GÄNGINSATS HELI-COIL M 20X2 X 1,5 D
6 0259 0011 00 4 THREAD INSERT GÄNGINSATS HELI-COIL M 14 X 1,5 D
8 3115 1825 00 1 PLUG RÖRPROPP
9 0686 6447 04 2 PLUG PROPP M 22X1,5 - STEEL 5.8
10 0661 1034 00 2 SEAL WASHER TÄTNINGSBRICKA 22,7 / 30 X 2 TREDO
11 3115 1165 00 4 STUD PINNSKRUV
12 3115 2112 00 1 GUIDE STYRNING
14 3115 2766 80 1 SEAL HOUSE COMP TÄTN. HUS KOMPL INCL. POS 15-17
15 – 1 SEAL HOUSING TÄTNINGSHUS NOT DELIVERY SEPARATELY
16 3115 0970 00 2 SEAL KIT TÄTNINGSSATS
17 0663 6136 00 1 O-RING O-RING 59,5 X 3 70 SHORE
19 3115 1671 00 1 PISTON GUIDE KOLVSTYRNING
21 3115 2129 00 1 PISTON KOLV
24 3115 2772 80 1 SEAL HOUSE COMP TÄTN. HUS KOMPL REAR INCL.POS 25-27
25 – 1 SEAL HOUSING TÄTNINGSHUS NOT DELIVERY SEPARATELY
31 3115 1765 00 1 VALVE PISTON VENTILKOLV
32 3115 2077 03 1 VALVE COVER VENTILGAVEL
33 3115 2076 05 1 VALVE COVER VENTILGAVEL
34 0147 1438 03 4 SCREW, HEX HEAD SKRUV, SEXKANT M 14 X 30 - 8.8 FZB
35 3115 3291 00 1 REG. PLUG REGLERPROPP
36 3115 3214 00 1 NUT BOTTENMUTTER
37 3115 1697 00 2 SEAL WASHER TÄTNINGSBRICKA GM 1000
38 3115 3245 00 1 SEAL RING TÄTNINGSRING
8311 1249 90 010D

11
(Sheet 2 of 6)
52 3115 2583 86 1 INTERM. COMPL. MELLANDEL,KOMPL
53 3115 2583 45 1 INTERMED. PART MELLANDEL INCL. POS 54-60
54 – 1 INTERMED. PART MELLANDEL NOT DELIVERY SEPARATELY
55 0686 6442 00 1 PLUG PROPP G 1/4 TYPE B - STEEL 5.8
56 0661 1020 00 1 SEAL WASHER TÄTNINGSBRICKA 13,7 / 20,6 X 2,1 - FZ ST
TREDO 1/4
59 3115 1746 06 1 NOZZLE MUNSTYCKE M8X8, D=1,7
60 3115 2401 00 1 PLUG RÖRPROPP
66 3115 3474 00 1 LINER FODER
67 3115 3744 00 1 BUSHING BUSSNING
68 0335 3500 10 1 LOCK RING LÅSRING 80 X 3,2 DIN 7993 B
71 3115 1746 06 2 NOZZLE MUNSTYCKE M8X8, D=1,7
72 0196 1318 00 1 SET SCREW STOPPSKRUV M 8 X 8 SK6SS DIN 916
76 3115 2384 00 1 VALVE SEAT VENTILSÄTE
77 3115 2383 00 1 VALVE CONE VENTILKÄGLA
79 3115 3455 00 1 CONNECT. PLATE ANSLUTN.PLATTA
80 0211 1960 84 2 SCREW SKRUV MC6S M 12 X 35 -12.9
86 3115 2971 00 1 DAMPING PISTON DÄMPKOLV
87 0686 9110 00 1 PROTECTION PLUG SKYDDSPROPP 9,3 / 10,9 X 9
92 3115 3481 00 1 BACK HEAD BAKSTYCKE
B0040575
12
(Sheet 3 of 6)
102 3115 2340 80 1 GEAR HOUSING VÄXELHUS COMPLETE INCL ITEM 103-109
103 – 1 GEAR HOUSING VÄXELHUS NOT SOLD SEPARATELY
SEE REF.NO.102
104 0686 4201 03 1 PLUG PROPP
105 0653 9038 00 1 GASKET PACKNING 10 / 13,5 X 1 -11 4010 14
106 0544 2162 00 1 GREASE NIPPLE SMÖRJNIPPEL ISO 7 - R 1/8 TYPE AH
107 0666 7188 01 1 RADIAL LIP SEAL RADIALTÄTNING 80 / 100 X 7
108 0335 2169 00 1 CIRCLIP SPÅRRING SGH 100 X 3 DIN 472
109 3115 0273 00 1 WASHER BRICKA
116 3115 1732 81 1 ROT.CHUCK BORRHYLSA INCL.POS 117,118
117 – 1 ROT.CHUCK BORRHYLSA NOT DELIVERY SEPARATELY
121 0509 0221 00 1 ROLLER BEARING RULLAGER 32016
122 0509 0223 00 1 ROLLER BEARING RULLAGER 90 / 140 X 32
123 3115 0274 00 1 GEAR WHEEL KUGGHJUL
124 0516 1504 01 1 NEEDLE BEARING NÅLLAGER 22 / 34 X 16
125 3115 0823 00 1 WASHER BRICKA
127 3115 0824 00 1 SLEEVE HYLSA
128 0667 1206 00 1 SEAL TÄTNING 28 / 44 X 8 90 NBR/108
129 3115 2742 00 1 GUIDE SLEEVE STYRHYLSA
130 3115 0821 00 1 SHAFT AXEL
131 3115 1582 00 1 DRIVER MEDBRINGARE
132 3115 2968 00 1 ROT.CH.BUSHING BORRBUSSNING
133 3115 1457 00 1 SIDE BOLT SIDOBULT
136 0663 2120 00 2 O-RING O-RING 13,3 X 2,4 70 SHORE
137 3115 0297 01 1 SHIM SHIMS 0,10 MM
138 3115 0297 02 1 SHIM SHIMS 0,15 MM
139 3115 0297 03 1 SHIM SHIMS 0,5 MM
152 3115 3609 10 1 COVER LOCK
8311 1249 90 010D

13
(Sheet 4 of 6)
154 0666 7190 01 1 RADIAL LIP SEAL RADIALTÄTNING SIMRIT 90 / 110 X 7
155 3115 3610 00 1 SPACER DISTANS
156 0102 0460 00 2 PIN PINNE CP 12 X 30
158 3115 3612 00 2 STUD PINNBULT
159 3115 3613 00 1 STUD PINNBULT
161 3115 3608 81 1 FRONT PART COMP FRONTDEL KOMPL.
162 – 1 FRONT PART FRONTDEL
163 3115 2223 02 1 GUIDE STYRNING D=52
181 3115 3165 00 1 EXTRACTORPISTON UPPSLAGARKOLV
182 3115 3528 00 1 SEAL RETAINER TÄTNINGSHÅLLARE
183 3115 2386 00 1 CUP SEAL U-MANSCHETT
184 0347 6200 21 1 HOSE CLIP SLANGKLÄMMA A 149 - 161
185 3115 3200 00 2 SLEEVE HYLSA
186 3115 3201 00 1 ATTACHMENT FÄSTE
188 3115 3061 00 1 PIN TAPP
189 3115 3062 00 1 WASHER BRICKA
195 3115 3190 81 1 FLUSH HEAD COMP SPOLHUVUD KOMPL
196 – 1 FLUSHING HEAD SPOLHUVUD NOT DELIVERY SEPARATELY
B0040575
14
(Sheet 5 of 6)
197 3115 3195 01 2 COVER LOCK
198 3115 3196 02 2 GUIDE STYRNING
199 3115 3197 02 2 GUIDE STYRNING
201 3115 3236 00 2 WIPER AVSTRYKARE
204 0266 2112 00 3 NUT MUTTER M 12 - 8 FZB
211 3115 3451 81 1 ACCUMULATOR ACKUMULATOR Page 19
221 3115 3511 81 1 ACCUMULATOR ACKUMULATOR Page 21
231 3115 2615 91 1 RETURN ACCUM. RETURACKUMULAT. Page 23
241 3115 3473 81 1 HYDRAULIC MOTOR HYDRAULMOTOR Page 25 MSQ 100 SH (05)
246 3115 3548 00 4 NUT MUTTER
247 3115 0327 00 1 GASKET PACKNING
248 3115 0277 00 1 COUPLING KOPPLING
249 0335 2130 00 1 CIRCLIP SPÅRRING SGH 28 X 1,2 DIN 472
251 3115 0286 00 5 DOME NUT KUPOLMUTTER
252 3115 0287 00 5 WASHER BRICKA
261 0570 5005 00 1 STRAIGHT NIPPLE RAK NIPPEL B2 12 16 UNF 7/8 -14 G 3/
262 3176 6512 00 4 NIPPLE NIPPEL UNF 3/4 - G 3/8
291 3115 3164 00 1 LABEL DEKAL ATLAS COPCO
292 3115 3308 00 1 LABEL DEKAL
300 7490 5164 74 1 SHANK ADAPTER NACKADAPTER T38E (SECOROC 90516474)
300 7490 5164 75 1 SHANK ADAPTER NACKADAPTER T45E (SECOROC 90516475)
300 7490 5165 59 1 SHANK ADAPTER NACKADAPTER TC35E, L=730
301 3115 2232 00 1 DRILL COLLAR BORRMANSCHETT T45 ADAPTER
0686 9250 26 2 PLUG PROPP SKRUVPLUGG G 1/2'
0686 9250 27 2 PLUG PROPP SKRUVPLUGG G 3/4'
– 1 OPTIONAL SET OPTIONGRUPP Page 31
0909 1071 00 1 LUBRICAT.GUN SMÖRJSPRUTA VOL 525 D 56
3115 3425 80 1 CHARGIN DEVICE LADDN.UTRUSTN. Page 53 FOR ACCUMULATORS
8311 1249 90 010D

15
(Sheet 6 of 6)
3363 0345 67 1 GREASE PUMP FETTPUMP
9106 1015 40 1 TORQUE KEY MOMENTNYCKEL 1/2' 10-100NM
9106 1015 41 1 TORQUE KEY MOMENTNYCKEL 1/2' 75-400NM
B0040575
16
8311 1249 90 010D

17
ACCUMULATOR / ACKUMULATOR 3115 3451 81
ACCUMULATORACKUMULATOR
B0049708
18

3115 1870 00 1 PROTECTION PLUG SKYDDSPROPP
1 – 1 DIAPHRAGM COVER MEMBRANLOCK
2 – 1 DIAPHRA.HOUSING MEMBRANHUS
3 3115 1822 01 1 DIAPHRAGM MEMBRAN
4 3115 0262 00 1 VALVE VENTIL COMPLETE INCL. POS 621,622
5 3115 2196 81 1 TEST VALVE KONTROLLVENTIL COMPLETE
9 3115 2714 90 1 LABEL SET DEKALSATS
10 3115 2702 10 2 SCREW SKRUV
11 3310 4076 00 1 CAP HUV
12 0663 9056 00 1 O-RING O-RING 14 X 1,78 70 SHORE
3115 3451 81 001K

19
ACCUMULATORACKUMULATOR
B0049703
20

3115 1870 00 1 PROTECTION PLUG SKYDDSPROPP
1 – 1 DIAPHRAGM COVER MEMBRANLOCK
2 – 1 DIAPHRA.HOUSING MEMBRANHUS
5 3115 2196 81 1 TEST VALVE KONTROLLVENTIL COMPLETE
9 3115 2715 90 1 LABEL SET DEKALSATS
10 3115 2702 10 2 SCREW SKRUV
11 3310 4076 00 1 CAP HUV
3115 3511 81 001K

21
RETURN ACCUM. / RETURACKUMULAT. 3115 2615 91
RETURN ACCUM.RETURACKUMULAT.
B0054144
22
RETURN ACCUM. / RETURACKUMULAT. 3115 2615 91

0686 9010 54 1 PROTECTING PLUG PROPP, SKYDD 26,4 29,5 19 27,7 24,7 45
2 3115 2615 20 1 TUBE RÖR
3 3115 2885 00 1 TUBE COVER RÖRGAVEL
4 3115 2886 00 1 PIPE RÖR
5 3115 2889 00 1 PRESSURE SCREW TRYCKSKRUV
6 0663 2109 37 1 O-RING O-RING 25 X 2 90 SHORE
8 3115 2618 00 1 END PIECE GAVEL
11 3115 2617 20 1 PLUG PROPP
13 0661 1038 00 1 SEAL WASHER TÄTNINGSBRICKA 27 / 35 X 2,5 FZ ST.
14 3176 6528 00 1 NIPPLE NIPPEL UNF 1 1/16 - G 3/4
21 3115 2275 00 1 CLAMP KLAMMA
22 3115 2276 00 1 HOLDER HÅLLARE
24 0291 1128 19 2 LOCK NUT LÅSMUTTER M 8 - 8 FZB / ISO 7043
3115 2615 91 006D

23
HYDRAULIC MOTOR / HYDRAULMOTOR 3115 3473 81 MSQ 100 SH (05)
HYDRAULIC MOTORHYDRAULMOTOR
B0040501
24

3115 3473 90 1 SEAL KIT TÄTNINGSSATS INCL. POS 2,4,5,10,18,19,25
3115 3473 81 002K

25
B0040501
26

3115 3473 90 1 SEAL KIT TÄTNINGSSATS INCL. POS 2,4,5,10,18,19,25
3115 3473 83 003K

27
B0040501
28

3115 3473 90 1 SEAL KIT TÄTNINGSSATS POS. 2,5,10,18,19,25
3115 3473 85 003K

29
OPTIONAL SET / OPTIONGRUPP
OPTIONAL SETOPTIONGRUPP
B0040518
30
OPTIONAL SET / OPTIONGRUPP

11 – 1 ASSEMBLY TOOL MONTERINGSVERKT Page 33
20 3115 2163 00 1 MANDREL DORN FOR ASSY OF ITEM 67
25 3115 2724 80 1 DISASSEMB.TOOLS DEMONT.VERKTYG FOR THE DRIVER
26 3115 2736 00 1 SPACER TUBE DISTANSRÖR COPROD
27 3115 2737 00 1 MANDREL DORN COPROD
40 3115 9153 90 1 O-RING SET O-RINGSSATS Page 35 COP 1638-2560
45 3115 9156 92 1 O-RING SET O-RINGSSATS EXTRACTOR UNIT
50 0371 1100 02 1 LIFTING EYE LYFTÖGLA SS 1899 - M 12
70 3115 3473 90 1 SEAL KIT TÄTNINGSSATS INCL. POS 2,4,5,10,18,19,25
90 3115 3292 00 1 REG. PLUG REGLERPROPP STROKE POSITION 3
100 3115 2231 00 1 DRILL COLLAR BORRMANSCHETT R28/R32/R38/T38 ADAPTER
110 3115 2232 00 1 DRILL COLLAR BORRMANSCHETT T45 ADAPTER
120 3115 2233 00 1 DRILL COLLAR BORRMANSCHETT T51,R32/38F ADAPTER
160 3115 2519 00 1 TIGHTENING TOOL SPÄNNVERKTYG FOR ACCUMULATOR
200 3115 2887 80 1 CONNECT. PLATE ANSLUTN.PLATTA Page 37 OMS
210 3115 2115 01 1 REG. PLUG REGLERPROPP COP1850
220 3115 2915 00 1 PRESSING TOOL PRESSVERKTYG COP 1850EX-TAC
230 3115 9156 93 1 SEAL KIT TÄTNINGSSATS Page 39 SEAL KIT COP 1838MUX/HUX
240 3115 9156 94 1 SEAL KIT TÄTNINGSSATS Page 41 SEAL KIT EXTRACTOR
COP 1838MUX/HUX
250 3115 9156 95 1 OVERHAUL KIT RENOVERINGSSATS Page 43 400 IMPACT HOURS KIT
COP 1838MUX/HUX
260 3115 9156 96 1 OVERHAUL KIT RENOVERINGSSATS Page 47 800 IMPACT HOURS - 1838MUX
270 3115 9156 98 1 OVERHAUL KIT RENOVERINGSSATS Page 49 800 IMPACT HOURS - 1838HUX
280 3115 9156 97 1 OVERHAUL KIT RENOVERINGSSATS Page 51 OVERHAUL KIT EXTRACTOR
COP 1838MUX/HUX
360 3115 3478 00 1 PLATE SKYLT
370 3115 3479 00 1 PLATE SKYLT
3115 0315 59 003K

31
ASSEMBLY TOOL / MONTERINGSVERKT
ASSEMBLY TOOLMONTERINGSVERKT
B0040518
32
ASSEMBLY TOOL / MONTERINGSVERKT

1 3115 2420 00 1 SCREW SKRUV
2 3115 0318 00 1 EXTENSION FÖRLÄNGNING FOR 3115190280
3 3115 2409 80 1 PRESSING TOOL PRESSVERKTYG FOR BUSHING
6 3115 2412 00 1 PRESSING TOOL PRESSVERKTYG FOR GUIDE
7 3115 2422 00 1 PRESSING TOOL PRESSVERKTYG
8 3115 2423 00 1 GUIDE RING STYRRING
3115 2420 60 001D

33
O-RING SET / O-RINGSSATS 3115 9153 90 COP 1638-2560
O-RING SETO-RINGSSATS
B0040518
34
O-RING SET / O-RINGSSATS 3115 9153 90 COP 1638-2560

0663 2100 62 2 O-RING O-RING 24,2 X 3 90 SHORE
0663 2109 37 1 O-RING O-RING 25 X 2 90 SHORE
0663 2110 00 2 O-RING O-RING 10,3 X 2,4 70 SHORE
0663 9056 00 3 O-RING O-RING 14 X 1,78 70 SHORE
0663 9104 01 2 O-RING O-RING 23,47X 2,62 90 SHORE
3115 2988 00 2 SEAL RING TÄTNINGSRING
3115 3245 00 5 SEAL RING TÄTNINGSRING
9900 0003 00 1 PLASTIC BAG PLASTPÅSE
3115 9153 90 018K

35
CONNECT. PLATE / ANSLUTN.PLATTA 3115 2887 80 OMS
CONNECT. PLATEANSLUTN.PLATTA
B0034710
36
CONNECT. PLATE / ANSLUTN.PLATTA 3115 2887 80 OMS

1 – 1 CONNECT. PLATE ANSLUTN.PLATTA
3115 2887 80 003K

37
SEAL KIT / TÄTNINGSSATS 3115 9156 93 SEAL KIT COP 1838MUX/HUX
SEAL KITTÄTNINGSSATS
B0040518
38
SEAL KIT / TÄTNINGSSATS 3115 9156 93 SEAL KIT COP 1838MUX/HUX

1 3115 3473 90 1 SEAL KIT TÄTNINGSSATS INCL. POS 2,4,5,10,18,19,25
2 3115 1880 90 1 SEAL KIT TÄTNINGSSATS FOR DAMPING PISTON
3 3115 9153 90 1 O-RING SET O-RINGSSATS Page 35 COP 1638-2560
5 0686 4201 03 1 PLUG PROPP
6 0653 9038 00 1 GASKET PACKNING 10 / 13,5 X 1 -11 4010 14
8 0666 7188 01 1 RADIAL LIP SEAL RADIALTÄTNING 80 / 100 X 7
9 0667 1206 00 1 SEAL TÄTNING 28 / 44 X 8 90 NBR/108
TREDO 1/4
12 3115 1697 00 2 SEAL WASHER TÄTNINGSBRICKA GM 1000
13 0661 1034 00 2 SEAL WASHER TÄTNINGSBRICKA 22,7 / 30 X 2 TREDO
17 3115 3236 00 2 WIPER AVSTRYKARE
3115 9156 93 001K

39
SEAL KIT / TÄTNINGSSATS 3115 9156 94 SEAL KIT EXTRACTOR %% COP 1838MUX/HUX
B0040518
40
SEAL KIT / TÄTNINGSSATS 3115 9156 94 SEAL KIT EXTRACTOR %% COP 1838MUX/HUX

1 3115 9156 92 1 O-RING SET O-RINGSSATS EXTRACTOR UNIT
5 3176 6514 00 1 NIPPLE NIPPEL UNF 7/8 - R 3/8
7 3115 3528 00 1 SEAL RETAINER TÄTNINGSHÅLLARE
3115 9156 94 005K

41
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 95 400 IMPACT HOURS KIT %% COP 1838MUX/HUX
OVERHAUL KITRENOVERINGSSATS
B0040518
42
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 95 400 IMPACT HOURS KIT %% COP 1838MUX/HUX
(Sheet 1 of 2)
1 3115 9156 93 1 SEAL KIT TÄTNINGSSATS Page 39 SEAL KIT COP 1838MUX/HUX
6 3115 0297 01 3 SHIM SHIMS 0,10 MM
7 3115 0297 02 3 SHIM SHIMS 0,15 MM
8 3115 0297 03 1 SHIM SHIMS 0,5 MM
10 0509 0223 00 1 ROLLER BEARING RULLAGER 90 / 140 X 32
11 0509 0221 00 1 ROLLER BEARING RULLAGER 32016
15 0335 3500 10 1 LOCK RING LÅSRING 80 X 3,2 DIN 7993 B
18 3115 3548 00 4 NUT MUTTER
20 3115 2702 10 4 SCREW SKRUV
21 3115 2703 00 2 SCREW SKRUV
22 3115 2617 10 1 PLUG PROPP
26 3115 0287 00 4 WASHER BRICKA
27 3115 3308 00 1 LABEL DEKAL
28 3115 3164 00 1 LABEL DEKAL ATLAS COPCO
29 3315 0195 08 4 LOCK WASHER LÅSBRICKA 13,0/19,5 X 2,6 HRC50 FZB
32 9853 6685 20 1 SPARE PART.LIST RESERVDELSLISTA
3115 9156 95 003K

43
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 95
(Sheet 2 of 2)
33 9853 6684 20 1 SPARE PART.LIST RESERVDELSLISTA
34 9853 1170 01 1 REPAIR.INSTR RENOVERINGSINST
B0040518
44
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 95
3115 9156 95 003K

45
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 96 800 IMPACT HOURS - 1838MUX
B0040518
46
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 96 800 IMPACT HOURS - 1838MUX

COP 1838MUX/HUX
6 3115 3474 00 1 LINER FODER
10 3115 2129 00 1 PISTON KOLV
3115 9156 96 002K

47
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 98 800 IMPACT HOURS - 1838HUX
B0040518
48
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 98 800 IMPACT HOURS - 1838HUX

COP 1838MUX/HUX
6 3115 3474 00 1 LINER FODER
10 3115 2126 00 1 PISTON KOLV
3115 9156 98 002K

49
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 97 OVERHAUL KIT EXTRACTOR %% COP 1838MUX/HUX
B0040518
50
OVERHAUL KIT / RENOVERINGSSATS 3115 9156 97 OVERHAUL KIT EXTRACTOR %% COP 1838MUX/HUX

1 3115 9156 94 1 SEAL KIT TÄTNINGSSATS Page 41 SEAL KIT EXTRACTOR
COP 1838MUX/HUX
3 3115 2223 02 1 GUIDE STYRNING D=52
6 3115 3165 00 1 EXTRACTORPISTON UPPSLAGARKOLV
7 0102 0460 00 2 PIN PINNE CP 12 X 30
8 3115 3613 00 3 STUD PINNBULT
9 3115 0287 00 3 WASHER BRICKA
3115 9156 97 001K

51
CHARGIN DEVICE / LADDN.UTRUSTN. 3115 3425 80 FOR ACCUMULATORS
CHARGIN DEVICELADDN.UTRUSTN.
B0039310
52
CHARGIN DEVICE / LADDN.UTRUSTN. 3115 3425 80 FOR ACCUMULATORS

– 1 PICTURE BILD
9851 2518 01 1 DESCRIPTION BESKRIVNING
9852 1797 01 1 INSTRUCTIONS INSTRUKTION
1 3115 3425 01 1 O-RING O-RING FÖR FLASKANSLUTNING
2 3115 3425 02 1 BOTTLE CONNECT FLASKANSLUTNING TO NITROGEN DIN10
3 3115 3425 03 1 HOSE SLANG 1/8' L=2000MM
4 3115 3425 04 1 MANOMETER MANOMETER 63MM SS 0-400BAR
7 3115 3425 07 1 REGULATOR REGULATOR RS200/1 200BAR
8 3115 3425 08 1 NEEDLE VALVE NÅLVENTIL FÖR EVAKUERING
9 3115 3425 09 1 HOSE SLANG COMPLETE WITH CONNECTIONS
1/8' L=2500MM
10 3115 3425 10 1 CONNECTION ANSLUTNING TILL MEMBRAN I SS
11 – 1 LABEL SET DEKALSATS
12 – 1 HOSE SLANG
14 3115 3425 18 1 SET SCREW STOPPSKRUV
15 3115 3425 19 1 HEX.SOCKET KEY HÅLNYCKEL 6KANT
17 3310 4076 00 2 CAP HUV
3115 3425 80 007K

53
54
FEED / MATARE
LIST OF CONTENTS
– FEED MATARE 59
– – FEED – MATARE 61
3128 3097 89 – – FEED BEAM – – MATARBALK 63
3128 3232 36 – – DRILL STEEL SUP – – BORRSTÖD 67
3128 0030 51 – – – HYDR. CYLINDER – – – HYDRAULCYLINDER 69
3128 3232 37 – – – CONNECTION SET – – – ANSLUTNINGSSATS 71
– – – – – HOSE SET – – – – SLANGSATS 73
3128 0031 05 – – CUTTINGS CAP – – KAXKÅPA 75
– – – – CHOOSE SEAL – – – VÄLJ TÄTNING 77
9121 7221 01 – – HYDR. CYLINDER – – HYDRAULCYLINDER 79
9126 2770 50 – – – COVER COMPL. – – – LOCK KOMPL. 83
9122 4332 50 – – – COVER COMPL. – – – LOCK KOMPL. 85
– – FEED COMPONENTS – MATARDETALJER 87
3128 0016 31 – – CRADLE COMPL – – SLÄDE KOMPL 89 COP 1838MEX
3128 3095 62 – – – CRADLE – – – SLÄDE 91
3128 3123 07 – – – HOLDER SET – – – HÅLLARE KOMPL. 93 RIGHT
3128 3123 08 – – – HOLDER SET – – – HÅLLARE KOMPL. 95 LEFT
– – HOSE SET – SLANGSATS 97 DRILL UNIT
– – ROD HANDLING – STÅNGHANTERING 99
– – – MAGAZINE – – MAGASIN 102 RHS 27D
– – – – MAGAZINE SHAFT – – – MAGASINAXEL 107 RHS27D
3128 3103 50 – – – PLUNGER – – – PLUNGE 109
– – – – ROD HANDL. ARM – – – RAS ARM 111
3128 3097 33 – – – – ARM – – – – ARM 113 RHS 17/27 - COMPLETE
3128 3105 98 – – – – – EXPANDING SHAFT – – – – – EXP.AXEL 115
3128 3106 12 – – – – – HYDR. CYLINDER – – – – – HYDRAULCYLINDER 117
3128 3104 72 – – – EXPANDING SHAFT – – – EXP.AXEL 119
55
– – – SENSOR SET – – GIVARSATS 127
3128 3107 32 – – GUARD – – SKYDD 129
– – – SHAFT SET – – AXELSATS 131 6 FEET
– – – HOLDER SET – – HÅLLARSATS 133 27 X D38
3128 2378 31 – – HYDRAULIC SET – – HYDRAULSATS 136 RHS 17D/27D EDS
3128 2378 29 – – – HOSE SET – – – SLANGSATS 139 EDS
3177 3092 84 – – – DIRECTION VALVE – – – RIKTNINGSVENTIL 141
3177 3092 83 – – – DIRECTION VALVE – – – RIKTNINGSVENTIL 143 TRACKOSCILLATION
3222 3268 96 – – – DOUBLE CH.VALVE – – – HYDRAULLÅS 145
3214 8712 80 – – – PRESS.RED.VALVE – – – TRYCKRED.VENTIL 153 ZDR 6DP2-40/210 YM
9106 0652 00 – – – PRESS.REL.VALVE – – – TRYCKBEG.VENTIL 155
3217 9341 60 – – – PRESS.RED.VALVE – – – TRYCKRED.VENTIL 157
– – – SPACER SET – – DISTANS SATS 159
– – STINGER – STINGER 161 STINGER FORWARD
9111 4063 64 – – STINGER – – STINGER 163 BSJ8-115 KPL
9111 4064 07 – STINGER – STINGER 165 BSJ 8-200
– – STINGER SET – STINGERSATS 167
9111 4064 07 – – STINGER – – STINGER 165 BSJ 8-200
9111 3471 01 – – HYDR. SET – – HYDR.SATS 169 STINGER REAR
– – GREASING DEVICE – GÄNGSMÖRJNING 171
56
– – – LUBRICATOR – – SMÖRJANORDNING 173
9111 4017 18 – – – GREASING DEVICE – – – GÄNGSMÖRJNING 175
3217 9766 01 – – DRUM PUMP – – FATPUMP 177
– – – HOSE SET – – SLANGSATS 181
– – – ELECTRIC SET – – ELSATS 183 THREAD LUBRICATION
9111 3760 04 – – – CONTROL BOX – – – MANÖVERLÅDA 185 THREAD LUBRICATION
3217 0012 73 – – – – PALM GRIP – – – – VRED 187
9111 3760 13 – – – SIGN SET – – – SKYLTSATS 189
57
FEED / MATARE
FEEDMATARE
B0049856
58
FEED / MATARE

12 3115 2231 00 1 DRILL COLLAR BORRMANSCHETT R28/R32/R38/T38 ADAPTER
21 – 1 FEED MATARE Page 61
22 – 1 FEED COMPONENTS MATARDETALJER Page 87
23 – 1 HOSE SET SLANGSATS Page 97 DRILL UNIT
31 – 1 ROD HANDLING STÅNGHANTERING Page 99
33 3128 0618 07 2 SEAL TÄTNING T38
41 – 1 STINGER STINGER Page 161 STINGER FORWARD
42 9111 4064 07 1 STINGER STINGER Page 165 BSJ 8-200
43 – 1 STINGER SET STINGERSATS Page 167
62 – 1 GREASING DEVICE GÄNGSMÖRJNING Page 171
1260 5001 33 001K

59
FEED / MATARE
FEEDMATARE
B0023397
60
FEED / MATARE

1 3128 3097 89 1 FEED BEAM MATARBALK Page 63
2 3128 3105 16 1 FRONT PLATE FRONTPLÅT
3 3128 3232 36 1 DRILL STEEL SUP BORRSTÖD Page 67
4 3128 0031 05 1 CUTTINGS CAP KAXKÅPA Page 75
5 9121 7221 01 1 HYDR. CYLINDER HYDRAULCYLINDER Page 79
6 3128 3097 88 1 END PLATE ÄNDPLÅT
7 3128 3097 93 1 INTERM.PLATE MELLANPLATTA
22 3128 0037 00 1 DAMPING DÄMPNING
23 0301 2378 00 38 PLAIN WASHER RUNDBRICKA 17 / 30 X 3 - HB 200 FZB
25 0129 3104 00 8 BLIND RIVET BLINDNIT 2,4 X 7,4 TAP / D 48 BS
26 3222 3168 52 1 SIGN SKYLT
28 0384 3546 00 16 DISK SPRING TALLRIKSFJÄDER A 71 36 4
29 3128 3097 90 4 WASHER BRICKA
30 3128 3097 91 4 SLEEVE HYLSA
33 3128 3022 32 2 PIN PINNE
35 0211 1963 42 6 SCREW SKRUV MC6S M 16 X 110 - 12.9
37 0301 2358 00 2 WASHER BRICKA 13 / 24 X 2,5 -HB 200 FZB
39 3128 3039 21 1 INTERM.PLATE MELLANPLATTA
40 9236 2002 69 2 SHIM SHIMS
41 0147 1959 28 1 SCREW, HEX HEAD SKRUV, SEXKANT M 30X2 X 150 - 8.8 FZB
42 0333 5200 06 1 LOCK WASHER LÅSBRICKA 30,5 / 47 X 4,8 FZB
45 3128 0782 73 1 DATA PLATE DATASKYLT
3128 0017 10 010K

61
FEED BEAM / MATARBALK 3128 3097 89
FEED BEAMMATARBALK
B0028582
62
FEED BEAM / MATARBALK 3128 3097 89

1 – 1 FEED BEAM MATARBALK
2 0259 2062 00 16 THREAD INSERT GÄNGINSATS HELI-COIL M 16 X 2 D
M16 MID-GRIP
6 3128 0034 01 2 SLIDE BAR GLIDSKENA
3128 3097 89 017K

63
DRILL STEEL SUP / BORRSTÖD 3128 3232 36
DRILL STEEL SUPBORRSTÖD
Fig. 1 of 3
B0037083
64
Fig. 2 of 3
3128 3232 36 001K

65
Fig. 3 of 3
B0057420
66

A 3128 0672 02 1 ADJUSTMENT TOOL JUSTERVERKTYG
1 3128 3013 06 1 DR.ST.SU.HOUSE BORRSTÖDSHUS
2 0102 0423 00 2 PIN PINNE CP 10M6 X 60 - 11 1922 04
4 3128 3013 89 2 PISTON ROD END KOLVSTÅNGSÄNDE TAC 64
BSH 55
6 3315 0195 12 8 LOCK WASHER LÅSBRICKA 21/30.7 X 3.7 - HRC50 FZB
9 0690 3181 00 1 PLATE SKYLT 55 X 27 11 2333 56
10 0244 4143 00 4 SCREW, DRIVE SKRUV, DRIV KDS 2,5 X 5 SMS 1549 FZB
12 3128 3232 37 1 CONNECTION SET ANSLUTNINGSSATS Page 71
3128 3232 36 001K

67
HYDR. CYLINDER / HYDRAULCYLINDER 3128 0030 51
HYDR. CYLINDERHYDRAULCYLINDER
B0027499
68

3128 0030 77 1 SEAL KIT TÄTNINGSSATS INCL. POS 8, 10-13, 17-23,
25, 26, 28, 29, 31, 32
1 3128 3141 51 4 SCREW SKRUV
2 0301 2318 00 4 PLAIN WASHER RUNDBRICKA 5,3 / 10 X 1 - HB 200 FZB
3 3128 3141 34 2 SCREW SKRUV
7 3128 3141 35 1 COVER LOCK
9 3128 0030 76 1 GUIDE SPINDLE STYRTAPP
14 3128 0030 75 1 PISTON ROD KOLVSTÅNG
16 – 1 MANTLE MANTEL
24 9122 3838 00 1 COVER LOCK
27 9126 1956 00 1 COVER LOCK
30 9126 1960 00 1 GUIDE SLEEVE STYRHYLSA
33 9126 1959 00 1 PISTON KOLV
3128 0030 51 002K

69
CONNECTION SET / ANSLUTNINGSSATS 3128 3232 37
CONNECTION SETANSLUTNINGSSATS
X0000000
70
CONNECTION SET / ANSLUTNINGSSATS 3128 3232 37

1 – 1 HOSE SET SLANGSATS Page 73
3128 3232 37 002K

71
HOSE SET / SLANGSATS
HOSE SETSLANGSATS
B0015365
72

BS10 0574 0063 64 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 750 R9R
BS20 0574 0073 76 1 HOSE ASSEMBLY SLANGLEDNING 12,5 X 450 R9R
9106 2102 92 001K

73
CUTTINGS CAP / KAXKÅPA 3128 0031 05
CUTTINGS CAPKAXKÅPA
B0057658
74
CUTTINGS CAP / KAXKÅPA 3128 0031 05

– 1 CHOOSE SEAL VÄLJ TÄTNING Page 77
2 3128 0094 00 1 RUBBER CLOTH GUMMIDUK
3 3128 0090 00 1 COLLARING PART ANSÄTTNINGSDEL
5 3128 3047 81 1 CUTTINGS GUIDE KAXAVLEDARE
6 3128 0616 00 2 RING RING
9 3128 0683 00 2 SHIM MELLANLÄGG
11 0690 3181 00 1 PLATE SKYLT 55 X 27 11 2333 56
14 0301 2335 00 11 PLAIN WASHER RUNDBRICKA 8,4 / 16 X 1,6 -HB200 FZB
16 0301 2344 00 6 PLAIN WASHER RUNDBRICKA 10,5 / 20 X 2 -HB 200 FZB
3128 0031 05 005K

75
CHOOSE SEAL / VÄLJ TÄTNING
CHOOSE SEALVÄLJ TÄTNING
B0051315
76
CHOOSE SEAL / VÄLJ TÄTNING

1 3128 0618 00 2 SEAL TÄTNING 64-76MM DRILL TUBE
2 3128 0618 01 2 SEAL TÄTNING 89MM DRILL TUBE
3 3128 0618 02 2 SEAL TÄTNING 102MM DRILL TUBE
4 3128 0618 05 2 SEAL TÄTNING S51
5 3128 0618 06 2 SEAL TÄTNING T45
6 3128 0618 07 2 SEAL TÄTNING T38
7 3128 0618 08 2 SEAL TÄTNING R32
3128 3016 92 003K

77
B0052696
78
(Sheet 1 of 2)
9121 6526 50 1 SEAL KIT TÄTNINGSSATS INCL.POS.2-3(2X),5-7(2X),8,
9-11(2X),13-14(2X),15-17,
19(2X),20,25-26(2X)
1 – 1 CYL.BARREL CYLINDERRÖR NOT SOLD SEPARATELY
2 – 2 WIPER AVSTRYKARE NOT SOLD SEPARATELY
3 – 2 SEAL TÄTNING NOT SOLD SEPARATELY
4 9126 2770 50 2 COVER COMPL. LOCK KOMPL. Page 83
5 – 2 GUIDE RING STYRRING NOT SOLD SEPARATELY
6 – 2 BACK-UP RING STÖDRING NOT SOLD SEPARATELY
7 – 2 O-RING O-RING NOT SOLD SEPARATELY
8 0665 0800 14 1 PISTON SEAL KOLVTÄTNING 105 / 125 X 25 NBR
11 – 2 GUIDE RING STYRRING NOT SOLD SEPARATELY
12 9122 4332 50 2 COVER COMPL. LOCK KOMPL. Page 85
15 9125 6739 00 1 PISTON ROD SEAL KOLVSTÅNGSTÄTN.
16 0661 1526 00 1 BACK-UP RING STÖDRING 35 / 40 X 1,3
18 9122 3653 00 1 COVER LOCK
15,3 X 2,4 70 SHORE
21 0302 1274 01 1 PLAIN WASHER RUNDBRICKA 10,5 / 22 X 4 - 11 1370
23 9126 2714 00 1 PIPE RÖR
27 9126 1783 00 1 INNER TUBE INNERRÖR
9121 7221 01 008K

79
(Sheet 2 of 2)
29 9127 2523 00 1 PLAIN BEARING GLIDLAGER
B0052696
80
9121 7221 01 008K

81
COVER COMPL. / LOCK KOMPL. 9126 2770 50
COVER COMPL.LOCK KOMPL.
B0003099
82

2 0661 1539 00 1 BACK-UP RING STÖDRING 90 95 2,5 1,3
3 – 1 COVER LOCK
5 0665 1000 17 1 SEAL TÄTNING F1 63 75 INT
6 0665 9099 12 1 WIPER AVSTRYKARE B 63 75
9126 2770 50 001K

83
COVER COMPL.LOCK KOMPL.
B0003098
84

3 – 1 COVER LOCK
4 0665 9300 67 1 GUIDE RING STYRRING RWR 105 / 111 X 18
5 0665 1000 16 1 SEAL TÄTNING 105 / 115 X 11 94 AU
6 0665 9099 13 1 WIPER AVSTRYKARE 105 / 115 X 10 PU
9122 4332 50 001K

85
FEED COMPONENTS / MATARDETALJER
FEED COMPONENTSMATARDETALJER
X0000000
86
FEED COMPONENTS / MATARDETALJER

1 3128 0016 31 1 CRADLE COMPL SLÄDE KOMPL Page 89 COP 1838MEX
2 – 1 HOSE ATTACHMENT SLANGFÄSTE
13 – 1 HOSE YOKE SLANGBYGEL
15 3176 7341 00 1 NIPPLE NIPPEL UN 1 1/16 - UN 1 5/16
16 – 1 MARKING SET MÄRKSATS
9111 4064 14 009K

87
CRADLE COMPL / SLÄDE KOMPL 3128 0016 31 COP 1838MEX
CRADLE COMPLSLÄDE KOMPL
B0030356
88
CRADLE COMPL / SLÄDE KOMPL 3128 0016 31 COP 1838MEX

1 3128 3095 62 1 CRADLE SLÄDE Page 91
6 3315 0195 10 6 LOCK WASHER LÅSBRICKA 17/25,4 X 3,7 HRC50 FZB
7 0333 0500 03 12 CONICAL WASHER KONISK BRICKA C 16 17
10 0686 9252 27 1 PROTECTION CAP SKYDDSHUV 12 X 12 PELD / RED
13 3128 3123 07 4 HOLDER SET HÅLLARE KOMPL. Page 93 RIGHT
14 3128 3123 08 4 HOLDER SET HÅLLARE KOMPL. Page 95 LEFT
15 3128 0314 00 1 BEARING,SP.PL. LEDLAGER
18 3128 3105 22 1 SPACER DISTANS
21 3128 2174 00 1 COVER LOCK
3128 0016 31 007K

89
CRADLE / SLÄDE 3128 3095 62
CRADLESLÄDE
B0023398
90
CRADLE / SLÄDE 3128 3095 62

1 – 1 CRADLE SLÄDE
3128 3095 62 004K

91
HOLDER SET / HÅLLARE KOMPL. 3128 3123 07 RIGHT
HOLDER SETHÅLLARE KOMPL.
B0030071
92
HOLDER SET / HÅLLARE KOMPL. 3128 3123 07 RIGHT

2 3128 3043 55 1 SLIDING PIECE GLIDSTYCKE
3 3128 0646 00 2 KEY KIL
3128 3123 07 004K

93
HOLDER SET / HÅLLARE KOMPL. 3128 3123 08 LEFT
HOLDER SETHÅLLARE KOMPL.
B0030072
94
HOLDER SET / HÅLLARE KOMPL. 3128 3123 08 LEFT

3 3128 0646 00 2 KEY KIL
3128 3123 08 004K

95
HOSE SET / SLANGSATS DRILL UNIT
HOSE SETSLANGSATS
B0015365
96
HOSE SET / SLANGSATS DRILL UNIT

BU1 0574 1566 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2500 R9R
DP1 0574 1527 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2000 R9R
DS1 0574 0000 93 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 3700 R9R
F1 0574 2531 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 2800 R9R
LU1 0574 1527 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2000 R9R
RHA1 0574 0065 21 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 1250 R2AT
R1 0574 1252 36 1 HOSE ASSEMBLY SLANGLEDNING 12,5 X 3450 R9R
S1 0574 3527 11 1 HOSE ASSEMBLY SLANGLEDNING 19 X 2000 R9R
TBU1 0574 1566 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2500 R9R
TS1 0574 4524 11 1 HOSE ASSEMBLY SLANGLEDNING 25 X 1700 R9R
WSB1 0574 0564 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 2900 R9R
W1 0574 3260 48 1 HOSE ASSEMBLY SLANGLEDNING 25X2550 R9R
9106 1953 41 006K

97
ROD HANDLING / STÅNGHANTERING
ROD HANDLINGSTÅNGHANTERING
B0042928
98
ROD HANDLING / STÅNGHANTERING

1 – 1 MAGAZINE MAGASIN Page 102 RHS 27D
2 – 1 SENSOR SET GIVARSATS Page 127
3 3128 3107 32 1 GUARD SKYDD Page 129
4 – 1 SHAFT SET AXELSATS Page 131 6 FEET
5 – 1 HOLDER SET HÅLLARSATS Page 133 27 X D38
6 3128 2378 31 1 HYDRAULIC SET HYDRAULSATS Page 136 RHS 17D/27D EDS
11 – 1 SPACER SET DISTANS SATS Page 159
9111 3002 76 001K

99
MAGAZINE / MAGASIN RHS 27D
MAGAZINEMAGASIN
Fig. 1 of 2
B0042829
100
MAGAZINE / MAGASIN RHS 27D
Fig. 2 of 2
3128 0031 44 010K

101
MAGAZINE / MAGASIN
(Sheet 1 of 3)
1 3128 3101 97 1 END PIECE GAVEL
2 3128 3102 00 1 END PIECE GAVEL FRONT
3 – 1 MAGAZINE SHAFT MAGASINAXEL Page 107 RHS27D
4 3128 3102 06 1 ARM ARM
5 3128 3102 08 1 COVER LOCK
6 3128 3102 09 1 DISTANS DISTANS
7 9111 4088 50 1 LINK ARM LÄNKARM RHS
10 3128 3102 14 1 COVER LOCK
11 3128 3102 17 1 COVER LOCK
13 3214 7790 00 1 DISK LAMELL
15 3128 2288 00 1 COVER LOCK
16 3128 3102 15 1 COVER LOCK
17 3128 3103 50 1 PLUNGER PLUNGE Page 109
19 3128 3102 16 1 COVER LOCK
20 3128 3115 79 4 SHIM SHIMS
25 0502 1091 94 2 BALL BEARING KULLAGER C1 130 165 18 1,1
26 0501 0000 72 2 BEARING,SP.PL. LEDLAGER E1 60 23 21 95 88,5 1 1 3
27 0501 0019 01 1 BEARING,SP.PL. LEDLAGER 60 / 90 X 44
29 0335 1151 00 1 CIRCLIP SPÅRRING SGA 60 X 2 DIN 471
31 0665 9170 01 1 WIPER AVSTRYKARE 40 / 50 X 7 NBR 90
32 0666 8000 24 2 AXIAL SEAL AXIALTÄTNING 67 -79 X 11 VA
33 0666 8097 02 2 AXIAL SEAL AXIALTÄTNING 144 / 157 X 10,5
39 0663 2158 00 1 O-RING O-RING 149,1 8,4 13 3930 90
44 3128 3102 93 2 PROTECTION ARCH SKYDDSBÅGE
45 – 1 ROD HANDL. ARM RAS ARM Page 111
B0042830
102
MAGAZINE / MAGASIN
(Sheet 2 of 3)
46 3128 3104 72 6 EXPANDING SHAFT EXP.AXEL Page 119
51 0147 1961 80 1 SCREW, HEX HEAD SKRUV, SEXKANT M16X60 - 8.8FZB
54 0266 2114 00 1 NUT MUTTER M 16 - 8 FZB
56 0300 0276 27 8 PLAIN WASHER RUNDBRICKA C 16 17 33 4 1 1,2 - - DA
61 0211 1402 03 10 SCREW SKRUV MC6S M 12 X 35 - 8.8 FZB
75 0544 2362 00 4 GREASE NIPPLE SMÖRJNIPPEL BH KR 1/8 SMS 1568
77 9000 0241 00 1 HOSE NIPPLE SLANGNIPPEL 6,3 KR 1/4
78 3176 1878 01 1M AIR HOSE LUFTSLANG PVC 06 6,3 500
79 0347 6103 00 1 HOSE CLIP SLANGKLÄMMA 12,7 - 16 FZB
84 0661 1000 13 1 SEAL WASHER TÄTNINGSBRICKA 18,7 26,0
88 3128 3022 32 2 PIN PINNE
3128 0031 44 010K

103
MAGAZINE / MAGASIN
(Sheet 3 of 3)
91 0665 9100 83 1 WIPER AVSTRYKARE 85 95 7 10 94 AU 925 1 -
92 – 1 HOSE GUIDE SLANGFÖRARE
B0042830
104
MAGAZINE / MAGASIN
3128 0031 44 010K

105
MAGAZINE SHAFT / MAGASINAXEL RHS27D
MAGAZINE SHAFTMAGASINAXEL
B0057680
106
MAGAZINE SHAFT / MAGASINAXEL RHS27D

2 – 1 GABLE PLATE GAVELPLÅT
6 3128 3102 73 1 GABLE PLATE GAVELPLÅT
7 3128 3102 75 1 SHAFT AXEL
12 3128 0032 05 1 FLAT KEY PLATTKIL
3128 3102 62 012K

107
PLUNGER / PLUNGE 3128 3103 50
PLUNGERPLUNGE
B0010704
108
PLUNGER / PLUNGE 3128 3103 50

1 3128 2262 00 1 COVER LOCK
3 3128 2250 01 1 PISTON KOLV
4 0665 1000 73 2 SEAL TÄTNING 60 / 70 X 10 94 AU/925
5 0665 9300 85 2 GUIDE RING, EXT STYRRING, UTV. RWR/S 60 / 66 X 13
6 0665 9193 00 2 WIPER AVSTRYKARE 60 / 70 X 10 AU 92
8 3128 3083 72 1 SPRING FJÄDER
10 0665 0700 72 1 SEAL TÄTNING X - SIMKO 300 70 - 57 - 6
12 3128 3103 51 1 HOUSE HUS
13 0803 5012 04 1 FILTER PLUG FILTERPROPP G 1/2 - DN 15 - TYPE B
G 1/2 - DN 15 - TYPE B
15 3128 3097 40 3 SHIM SHIMS
16 3128 3212 35 1 PLUNGER PLUNGE
3128 3103 50 003K

109
ROD HANDL. ARM / RAS ARM
ROD HANDL. ARMRAS ARM
B0044211
110
ROD HANDL. ARM / RAS ARM

1 3128 3103 98 1 ARM ARM
2 3128 3097 33 2 ARM ARM Page 113 RHS 17/27 - COMPLETE
3 0666 8000 24 1 AXIAL SEAL AXIALTÄTNING 67 -79 X 11 VA
4 3128 3115 78 5 SHIM SHIMS
5 0501 0000 72 2 BEARING,SP.PL. LEDLAGER E1 60 23 21 95 88,5 1 1 3
7 0248 9979 54 2 THREADED ROD GÄNGAD STÅNG M 16 150 2 8.8 FZB 20 -
8 3128 0031 14 1 BEARING HOUSING LAGERHUS
9 3128 0031 15 1 BEARING HOUSING LAGERHUS
10 3128 0031 19 1 COVER LOCK
12 3128 0031 16 1 SPACER RING DISTANSRING
13 3128 2288 00 1 COVER LOCK
15 0333 0500 08 10 CONICAL WASHER KONISK BRICKA C 20 21
16 3315 0195 12 10 LOCK WASHER LÅSBRICKA 21/30.7 X 3.7 - HRC50 FZB
18 0665 9100 86 3 WIPER AVSTRYKARE 70 80 - 7 94 AU 925 5 - 9
19 0661 1000 13 1 SEAL WASHER TÄTNINGSBRICKA 18,7 26,0
23 0266 2114 00 4 NUT MUTTER M 16 - 8 FZB
27 0335 1151 00 1 CIRCLIP SPÅRRING SGA 60 X 2 DIN 471
29 3217 9735 03 0.20M HOSE SLANG DIA 5X8 MM PVC
30 5112 3061 39 1 HOSE NIPPLE SLANGNIPPEL
3128 0031 39 002K

111
ARM / ARM 3128 3097 33 RHS 17/27 - COMPLETE
ARMARM
B0047071
112
ARM / ARM 3128 3097 33 RHS 17/27 - COMPLETE

1 3128 3097 34 1 ARM ARM
2 3128 3097 36 1 CLAMP ÖVERFALL
3 3128 3103 78 1 JAW KLO
5 3128 3063 83 1 EXPANDING SHAFT EXP.AXEL
9 3128 2353 00 4 DAMPING ELEMENT DÄMPELEMENT
14 5530 8966 00 8 SCREW, HEX HEAD SKRUV, SEXKANT M12X60 - 10.9
15 5530 8108 00 8 PLAIN WASHER RUNDBRICKA WASHER-FLAT M12 HT PLTD
16 0291 1128 45 8 LOCK NUT LÅSMUTTER M 12 1,75 2 16,1 11,6 1,8
21 3128 3107 02 2 PIN TAPP
23 3128 0031 55 1 EXPANDING SHAFT EXP.AXEL
3128 3097 33 012K

113
EXPANDING SHAFT / EXP.AXEL 3128 3105 98
EXPANDING SHAFTEXP.AXEL
B0047099
114

1 3128 3105 99 1 SHAFT AXEL
3 0295 3105 00 2 LOCK NUT LÅSMUTTER M 20X1 - KM 4 - 11 0727
3128 3105 98 001K

115
B0026465
116

9120 0993 09 1 SEAL KIT TÄTNINGSSATS INCL. ITEMS 3-5,7-12,14
2 3222 2900 30 1 PISTON KOLV
13 9126 3959 00 1 COVER LOCK
15 9128 8383 00 1 MARKING PLATE MÄRKSKYLT
3128 3106 12 007K

117
B0023140
118

2 – 1 SHAFT AXEL
3 0663 2111 90 2 O-RING O-RING 38 2,5 13 3930 90
3128 3104 72 006K

119
B0045104
120

9120 0993 05 1 SEAL KIT TÄTNINGSSATS INCL.POS.3-5,6,7,9-12
2 9126 3948 00 1 PISTON KOLV
3 – 1 PISTON SEAL KOLVTÄTNING NOT SOLD SEPARATELY
5 – 1 SCREW SKRUV NOT SOLD SEPARATELY
8 9126 3943 00 1 COVER LOCK
9 – 1 PISTON ROD SEAL KOLVSTÅNGSTÄTN. NOT SOLD SEPARATELY
10 9127 2274 00 1 WASHER BRICKA
13 – 1 PISTON ROD KOLVSTÅNG NOT SOLD SEPARATELY
16 – 1 HOLDER HÅLLARE NOT SOLD SEPARATELY
3128 3134 03 003K

121
B0045103
122

9120 0993 05 1 SEAL KIT TÄTNINGSSATS INCL.POS.2-4,6-10,13
1 9126 3948 00 1 PISTON KOLV
9 – 1 WASHER BRICKA NOT SOLD SEPARATELY
10 – 1 CIRCLIP SPÅRRING NOT SOLD SEPARATELY
11 3128 3116 41 1 LOCK RING LÅSRING
12 3128 3116 40 1 COVER LOCK
3128 3134 02 002K

123
B0045105
124

9120 0993 05 1 SEAL KIT TÄTNINGSSATS INCL.POS.3-5,6,7,9-12.
2 9126 3948 00 1 PISTON KOLV
8 9126 3943 00 1 COVER LOCK
10 9127 2274 00 1 WASHER BRICKA
11 – 1 CIRCLIP SPÅRRING NOT SOLD SEPARATELY
3128 3134 04 003K

125
SENSOR SET / GIVARSATS
SENSOR SETGIVARSATS
B0059886
126

8 3128 3039 44 1 COVER LOCK
29 3128 3103 95 1 COVER LOCK
33 3128 3117 14 1 PROTECTION SKYDD
3128 0030 55 004K

127
GUARD / SKYDD 3128 3107 32
GUARDSKYDD
B0024797
128
GUARD / SKYDD 3128 3107 32

1 3128 3107 34 1 PLATE PLÅT
2 3128 3107 35 1 GUARD SKYDD
3 3128 3107 37 8 FLAT BAR PLATTSTÅNG
3128 3107 32 003K

129
SHAFT SET / AXELSATS 6 FEET
SHAFT SETAXELSATS
B0044576
130
SHAFT SET / AXELSATS 6 FEET

1 3128 3102 67 1 SHAFT AXEL
2 3128 0031 13 1 SHAFT AXEL
3 3128 3102 92 2 STAY STAG
4 3128 3102 84 1 STAY STAG
5 3128 3233 90 1 STAY STAG
3128 0031 43 003K

131
HOLDER SET / HÅLLARSATS 27 X D38
HOLDER SETHÅLLARSATS
B0024708
132
HOLDER SET / HÅLLARSATS 27 X D38

1 3128 3069 04 8 SEGMENT SEGMENT D 38
2 3128 3104 21 4 BUSHING HALF BUSSNINGSHALVA T 38
3128 3104 56 002K

133
HYDRAULIC SET / HYDRAULSATS 3128 2378 31 RHS 17D/27D EDS
HYDRAULIC SETHYDRAULSATS
Fig. 1 of 2
B0054960
134
HYDRAULIC SET / HYDRAULSATS 3128 2378 31 RHS 17D/27D EDS
Fig. 2 of 2
3128 2378 31 026K

135
HYDRAULIC SET / HYDRAULSATS 3128 2378 31
(Sheet 1 of 2)
3128 2378 29 1 HOSE SET SLANGSATS Page 139 EDS
1 3217 9060 07 1 CONNECT. PLATE ANSLUTN.PLATTA RX 7 HSR 06-21/01D
2 3177 3092 84 2 DIRECTION VALVE RIKTNINGSVENTIL Page 141
3 3177 3092 83 3 DIRECTION VALVE RIKTNINGSVENTIL Page 143 TRACKOSCILLATION
4 3222 3268 96 2 DOUBLE CH.VALVE HYDRAULLÅS Page 145
16 3214 8712 80 1 PRESS.RED.VALVE TRYCKRED.VENTIL Page 153 ZDR 6DP2-40/210 YM
19 3217 9882 04 13 VALVE PLUG VENTILKONTAKT 3M
5MM 2X0,5 IP67 LED+Z-DIOD
UNF 9/16-G 3/8 STRAIGHT
22 3715 0584 00 14 ELBOW NIPPLE VINKELNIPPEL UNF 9/16 - UNF 9/16
24 3176 6497 00 1 NIPPLE NIPPEL UNF 3/4
27 3176 5429 00 1 CAP HUV UNF 9/16
29 0661 1026 00 2 SEAL WASHER TÄTNINGSBRICKA TREDO G 3/8
30 0686 3716 30 2 PLUG PLUGG G 3/8 A A
31 0661 1033 00 2 SEAL WASHER TÄTNINGSBRICKA 21,5 / 28,6 X 2,5 FZ ST.
32 0686 6444 03 2 PLUG PROPP
34 3176 5313 00 1 CAP HUV UNF 3/4
36 3715 0597 00 1 CAP HUV UNF 7/8
38 3217 6513 02 1 RESTRICTION STRYPNING D=0,8; 9/16-18 UN
B0054961
136
HYDRAULIC SET / HYDRAULSATS 3128 2378 31
(Sheet 2 of 2)
39 3176 6496 00 10 NIPPLE NIPPEL UNF 9/16=WTXNS10
UNF 9/16
50 3128 0225 00 1 PROTECTION COIL SKYDDSSPIRAL 48 X 800 MM
52 0346 1002 42 6 PIPE CLAMP RÖRKLÄMMA D=15 NORMA TYP RSGU
54 9106 0652 00 1 PRESS.REL.VALVE TRYCKBEG.VENTIL Page 155
56 3176 8264 00 1 FLOW CONT.VALVE STRYPBACKVENTIL PH 9F-600-S
60 3217 9341 60 1 PRESS.RED.VALVE TRYCKRED.VENTIL Page 157
61 3176 8505 00 1 RESTRICTION STRYPNING D=1,2 ; 9/16-18 UN
3128 2378 31 026K

137
HOSE SET / SLANGSATS 3128 2378 29 EDS
HOSE SETSLANGSATS
B0015365
138
HOSE SET / SLANGSATS 3128 2378 29 EDS

RHC1 0574 0274 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 1700 R2AT
RHD1 3176 6336 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 700 R2AT
RHE1 3176 5679 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 500 R2AT
RHF1 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
RHG1 0574 1256 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 450 R2AT
RHG2 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
3128 2378 29 008K

139
DIRECTION VALVE / RIKTNINGSVENTIL 3177 3092 84
DIRECTION VALVERIKTNINGSVENTIL
B0032237
140

3177 3092 53 1 SEAL KIT TÄTNINGSSATS POS. 2,4,5
3177 3092 54 2 NUT SET MUTTERSATS POS. 1,2
2 3177 3092 52 2 COIL SPOLE
3177 3092 84 003K

141
DIRECTION VALVE / RIKTNINGSVENTIL 3177 3092 83 TRACKOSCILLATION
B0042530
142

3177 3092 57 2 NUT MUTTER POS. 1,2
1 5507 8719 00 2 WAGNER PART WAGNER ARTIKEL NOT SOLD SEPRETLY
3 3177 3092 55 2 COIL SPOLE
3177 3092 83 005K

143
DOUBLE CH.VALVE / HYDRAULLÅS 3222 3268 96
DOUBLE CH.VALVEHYDRAULLÅS
B0041070
144

3222 3308 22 1 SEAL KIT TÄTNINGSSATS INCL. ITEM 1-2
3222 3268 96 002K

145
B0042529
146

1 3177 3092 57 1 NUT MUTTER
2 3177 3092 55 1 COIL SPOLE
3177 3092 88 002K

147
B0042530
148

3177 3092 56 1 SEAL KIT TÄTNINGSSATS INCL. REF 2, 4, 5
1 3177 3092 57 2 NUT MUTTER
3 3177 3092 55 2 COIL SPOLE
3177 3092 80 004K

149
B0014698
150

1 9106 0631 24 2 SEAL KIT TÄTNINGSSATS POS.1
2 9106 0631 23 2 CARTRIDGE PATRON
9106 0630 10 003K

151
PRESS.RED.VALVE / TRYCKRED.VENTIL 3214 8712 80
PRESS.RED.VALVETRYCKRED.VENTIL
B0042534
152

3 3214 8712 82 1 PLUG PLUGG
6 – 1 PRESS.RED.VALVE TRYCKRED.VENTIL NOT SOLD SEPARATELY
10 3214 8712 87 1 SEAL KIT TÄTNINGSSATS POS. 10
3214 8712 80 004K

153
PRESS.REL.VALVE / TRYCKBEG.VENTIL 9106 0652 00
PRESS.REL.VALVETRYCKBEG.VENTIL
B0002493
154
PRESS.REL.VALVE / TRYCKBEG.VENTIL 9106 0652 00

- 9106 0652 03 1 SEAL KIT TÄTNINGSSATS FOR REF. 2.
1 0663 9050 00 4 O-RING O-RING 9,25X 1,78 70 SHORE
2 9106 0652 01 1 PRESS.REL.VALVE TRYCKBEG.VENTIL 315 BAR
3 – 1 PLATE PLATTA
9106 0652 00 003K

155
B0042533
156

3214 8712 87 1 SEAL KIT TÄTNINGSSATS POS. 1-5,7-10
6 3214 8712 86 1 REGULATING UNIT REGLERENHET
3217 9341 60 004K

157
SPACER SET / DISTANS SATS
SPACER SETDISTANS SATS
B0043485
158
SPACER SET / DISTANS SATS

3128 3108 71 001K

159
STINGER / STINGER STINGER FORWARD
STINGERSTINGER
X0000000
160
STINGER / STINGER STINGER FORWARD

1 9111 4063 64 1 STINGER STINGER Page 163 BSJ8-115 KPL
2 9111 4063 63 1 ATTACHM.COMPLET FÄSTE KOMPLETT STINGER FRONT
9111 4225 07 001K

161
STINGER / STINGER 9111 4063 64 BSJ8-115 KPL
STINGERSTINGER
B0058915
162
STINGER / STINGER 9111 4063 64 BSJ8-115 KPL

1 3128 0023 12 1 STINGER STINGER
2 3128 0015 02 1 DOWEL DUBB RUBBER
3 0108 1494 00 1 SPRING PIN RÖRPINNE 14 X 90 DIN 1481
9111 4063 64 004K

163
STINGER / STINGER 9111 4064 07 BSJ 8-200
STINGERSTINGER
B0058948
164
STINGER / STINGER 9111 4064 07 BSJ 8-200

1 3128 0023 10 1 STINGER STINGER
3 3128 0015 02 1 DOWEL DUBB RUBBER
9111 4064 07 005K

165
STINGER SET / STINGERSATS
STINGER SETSTINGERSATS
X0000000
166
STINGER SET / STINGERSATS

1 9111 4064 07 1 STINGER STINGER Page 165 BSJ 8-200
3 3128 3098 12 1 CLAMP KLAMMA
4 9111 3471 01 1 HYDR. SET HYDR.SATS Page 169 STINGER REAR
5 3128 0018 74 1 PIPE RÖR
9111 4225 08 002D

167
HYDR. SET / HYDR.SATS 9111 3471 01 STINGER REAR
HYDR. SETHYDR.SATS
B0025268
168

4 – 4 HEX SOCK. SCREW SEXKANTHÅLSKRUV M 5 130 8,72 22 5 - 4 8.8
6 3177 3016 00 1 COUPLING KOPPLING 2101-01-18.00
9111 3471 01 011K

169
GREASING DEVICE / GÄNGSMÖRJNING
GREASING DEVICEGÄNGSMÖRJNING
B0058949
170
GREASING DEVICE / GÄNGSMÖRJNING

A 9111 4192 42 1 COMPON. LAYOUT PLACERINGSRITN.
1 – 1 LUBRICATOR SMÖRJANORDNING Page 173
12 3217 9766 01 1 DRUM PUMP FATPUMP Page 177
13 3217 9766 03 1 COVER LOCK
14 3217 9766 15 1 ADAPTER FÖRSKRUVNING
15 3217 9766 16 1 COVER LOCK
17 3217 9766 25 1 GREASE FETT
22 3217 9882 06 1 VALVE PLUG VENTILKONTAKT
24 – 1 ELECTRIC SET ELSATS Page 183 THREAD LUBRICATION
25 3217 9996 00 1 SOLENOID VALVE MAGNETVENTIL
26 8202 0301 05 1 BALL VALVE KULVENTIL BAL 08
27 8204 0942 16 1 THROTTLE VALVE STRYPVENTIL
28 9111 4095 50 1 BOX LÅDA
9111 4064 64 003K

171
LUBRICATOR / SMÖRJANORDNING
LUBRICATORSMÖRJANORDNING
B0059880
172
LUBRICATOR / SMÖRJANORDNING

2 9111 4017 18 1 GREASING DEVICE GÄNGSMÖRJNING Page 175
3128 0016 94 001K

173
GREASING DEVICE / GÄNGSMÖRJNING 9111 4017 18
GREASING DEVICEGÄNGSMÖRJNING
B0058493
174
GREASING DEVICE / GÄNGSMÖRJNING 9111 4017 18

2 9030 1100 00 0.30M AIR HOSE LUFTSLANG 80 X 8
3 9111 4017 20 2 FLAT IRON PLATTJÄRN
4 0216 1100 34 2 HEX SOCK. SCREW SEXKANTHÅLSKRUV M 8 70 16 22 4,4 3,5 5 0,
9111 4017 18 004K

175
DRUM PUMP / FATPUMP 3217 9766 01
DRUM PUMPFATPUMP
B0039854
176
(Sheet 1 of 3)
3217 9766 13 1 VALVE VENTIL INCL.POS.38(3X),41-43,46,54-56
3217 9766 14 1 VALVE VENTIL INCL.POS.38,41-45,49-52
9106 1331 00 1 SEALING SET PACKNINGSSATS INCL.POS.6,7,11,12,26,31,32,
33(2X),34,35
9106 1331 01 1 REPAIR KIT RENOVERINGSSATS INCL.POS.3(2X),4,6,7,9,11,12,
16-26,30,31
1 – 1 COVER LOCK NOT SOLD SEPARATELY
6 – 1 SEAL RING TÄTNINGSRING NOT SOLD SEPARATELY
8 – 1 PIN TAPP NOT SOLD SEPARATELY
9 – 1 RING RING NOT SOLD SEPARATELY
10 – 1 TUBE RÖR NOT SOLD SEPARATELY
14 – 1 LOCK RING LÅSRING NOT SOLD SEPARATELY
15 – 1 HOUSE HUS NOT SOLD SEPARATELY
16 – 1 SHIM SHIMS NOT SOLD SEPARATELY
17 – 1 PLATE PLATTA NOT SOLD SEPARATELY
18 – 1 MANIFOLD ANSLUTN.BLOCK NOT SOLD SEPARATELY
19 – 1 ADAPTER ADAPTER NOT SOLD SEPARATELY
20 – 1 HOLDER HÅLLARE NOT SOLD SEPARATELY
23 – 1 PIN PINNE NOT SOLD SEPARATELY
24 – 1 SLEEVE HYLSA NOT SOLD SEPARATELY
25 – 1 SPRING FJÄDER NOT SOLD SEPARATELY
3217 9766 01 008K

177
(Sheet 2 of 3)
27 – 1 PLUG PLUGG NOT SOLD SEPARATELY
28 – 1 VALVE VENTIL NOT SOLD SEPARATELY
30 – 1 GUIDE SLEEVE STYRHYLSA NOT SOLD SEPARATELY
34 – 1 NUT MUTTER NOT SOLD SEPARATELY
35 – 1 ATTACHMENT LUG FÄSTÖRA NOT SOLD SEPARATELY
36 – 1 SHAFT AXEL NOT SOLD SEPARATELY
38 – 1 LOCKING CLIP LÅSSPRINT NOT SOLD SEPARATELY
42 – 1 PIN PINNE NOT SOLD SEPARATELY
43 – 1 BALL KULA NOT SOLD SEPARATELY
48 3217 9766 15 1 ADAPTER FÖRSKRUVNING
51 – 1 CYLINDER CYLINDER NOT SOLD SEPARATELY
55 – 1 VALVE UNIT VENTILENHET NOT SOLD SEPARATELY
56 – 1 VALVE SEAT VENTILSÄTE NOT SOLD SEPARATELY
57 – 1 INLET UNIT INLOPPSENHET NOT SOLD SEPARATELY
B0039854
178
(Sheet 3 of 3)
3217 9766 01 008K

179
HOSE SETSLANGSATS
B0015365
180

AP10 3176 6859 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 3800 R2AT
GRT 3176 6486 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 1000 R2AT
GRT1 0574 0315 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 2300 R2AT
9111 3959 40 002K

181
ELECTRIC SET / ELSATS THREAD LUBRICATION
ELECTRIC SETELSATS
B0033623
182

1 9111 3760 04 1 CONTROL BOX MANÖVERLÅDA Page 185 THREAD LUBRICATION
2 3176 4643 54 1 CABLE COMPLETE KABEL KOMPLETT
3 9111 3760 13 1 SIGN SET SKYLTSATS Page 189
4 – 1 ELBOW LEADING VINKELINFÖRING
9111 3760 06 001K

183
CONTROL BOX / MANÖVERLÅDA 9111 3760 04 THREAD LUBRICATION
CONTROL BOXMANÖVERLÅDA
B0059214
184
CONTROL BOX / MANÖVERLÅDA 9111 3760 04 THREAD LUBRICATION

1 3176 0027 04 1 DRILLED BOX HÅLAD LÅDA
2 3217 0012 73 1 PALM GRIP VRED Page 187
3 3217 8486 03 1 PLATE SKYLT
4 5112 2909 00 1 COVER TÄCKLOCK
5 0698 5140 61 1 CABLE GLAND KABELFÖRSKRUVN. M20X1,5 7-13 B1
M20X1,5 7-13 B1
6 0697 9810 19 2 END PLUG AVSLUTN.PROPP M20X1,5 A3
7 0697 9809 14 3 LOCK NUT LÅSMUTTER M20X1,5 A3
9111 3760 04 007K

185
PALM GRIP / VRED 3217 0012 73
PALM GRIPVRED
B0036919
186
PALM GRIP / VRED 3217 0012 73

1 3217 0010 15 1 PALM GRIP VRED
2 3217 0010 72 1 INTERMED. PART MELLANDEL
3 3217 0010 73 2 CONTACT BLOCK KONTAKTBLOCK NORMALLY OPEN
3217 0012 73 002K

187
SIGN SET / SKYLTSATS 9111 3760 13
SIGN SETSKYLTSATS
B0008507
188
SIGN SET / SKYLTSATS 9111 3760 13

1 9111 3760 14 1 PLATE SKYLT
2 9111 3760 15 1 PLATE SKYLT
9111 3760 13 002K

189
190
POS. EQUIPMENT / POS.UTRUSTNING
LIST OF CONTENTS
– POS. EQUIPMENT POS.UTRUSTNING 193
– – ASSEMBLY SET – MONTERINGSSATS 195
3128 2099 55 – – – CHECK VALVE – – – BACKVENTIL 199
– – TRAVERSE – TRAVERS 201
3128 0560 80 – – CYLINDER – – CYLINDER 205
3128 3090 42 – – ROLLER PATH – – SVÄNGKRANS 207
– – – HOSE ATTACHMENT – – SLANGFÄSTE 209
– – TURNING DEVICE – VRIDDON 211
3128 3093 81 – – GEAR – – VÄXEL 213
3128 3093 76 – – – GEAR – – – VÄXEL 215
3128 3093 77 – – – BRAKE – – – BROMS 219
3128 3093 78 – – – HYDRAULIC MOTOR – – – HYDRAULMOTOR 221
– – – HOSE SET – – SLANGSATS 223 HYD.MOTOR
9111 4064 62 – POSITIONING – POSITIONERING 225
9111 4020 29 – – FEED HOLDER – – MATARHÅLLARE 227
3128 3093 96 – – EXPANDING SHAFT – – EXP.AXEL 233
3155 2367 80 – – EXPANDING SHAFT – – EXP.AXEL 235
– – HOSE HOLDER SET – SLANGHÅLLARSATS 237
– – – HOSE FRAME SET – – SLANGHÅLLARSATS 239
– – – – ATTACHMENT – – – FÄSTE 241
191
POS. EQUIPMENTPOS.UTRUSTNING
B0049856
192

100 – 1 ASSEMBLY SET MONTERINGSSATS Page 195
101 – 1 TRAVERSE TRAVERS Page 201
102 – 1 TURNING DEVICE VRIDDON Page 211
103 9111 4064 62 1 POSITIONING POSITIONERING Page 225
104 – 1 HOSE HOLDER SET SLANGHÅLLARSATS Page 237
1260 5016 90 001K

193
ASSEMBLY SET / MONTERINGSSATS
ASSEMBLY SETMONTERINGSSATS
B0051504
194

2 9111 3231 07 2 SHAFT AXEL
3 9111 1922 00 2 SHAFT AXEL
4 3217 6359 00 4 LOCK SHEET LÅSBLECK 35X6 L=80
5 9110 4758 00 2 LOCK SHEET LÅSBLECK DIA 70-80 X 40 X 90 X 60
8 0500 4500 28 4 FLANGE BEARING FLÄNSLAGER B1T 80 85 40 95
9 9106 2328 60 1 BRACKET KONSOL
13 9106 2328 21 2 SHAFT AXEL
9106 2328 18 006K

195
B0027926
196

3128 2099 65 1 SEALING SET PACKNINGSSATS INCL ITEMS 2,4,5,7,10-11,13-14
9120 0990 20 1 SEAL KIT TÄTNINGSSATS
3 9128 5034 00 2 PLUG PLUGG
6 9124 9568 00 1 PISTON KOLV
12 9123 6507 13 1 CYLINDER COVER CYLINDERLOCK
15 3128 2099 55 2 CHECK VALVE BACKVENTIL Page 199
16 9128 6998 00 1 SLIDE SLID
3128 3060 24 004K

197
CHECK VALVE / BACKVENTIL 3128 2099 55
CHECK VALVEBACKVENTIL
B0001976
198

3 0661 1500 95 1 BACK-UP RING STÖDRING 12 16 2 1,3
3128 2099 55 002K

199
TRAVERSE / TRAVERS
TRAVERSETRAVERS
B0055721
200
TRAVERSE / TRAVERS
(Sheet 1 of 2)
1 3128 3093 60 1 CRADLE SLÄDE
2 3128 0569 02 1 SUPPORT STATIV
3 3128 0427 00 1 PIPE RÖR
4 3128 0560 80 1 CYLINDER CYLINDER Page 205
5 3128 0428 02 1 GUIDE STRIP STYRLIST
9 3128 0631 00 1 RING RING
10 3128 0314 00 1 BEARING,SP.PL. LEDLAGER
18 0339 1000 10 1 RING SPRING RINGFJÄDER
21 3128 0010 00 4 WASHER BRICKA
22 0384 3508 00 16 DISK SPRING TALLRIKSFJÄDER 63 / 31 - 3,5 - 1,4
23 3128 0011 00 4 WASHER BRICKA
27 3128 0463 00 2 GUIDE RING, EXT STYRRING, UTV.
28 0690 3181 00 1 PLATE SKYLT 55 X 27 11 2333 56
30 3128 0603 00 1 CAP HUV
33 3176 5429 00 2 CAP HUV UNF 9/16
9111 4020 10 015K

201
TRAVERSE / TRAVERS
(Sheet 2 of 2)
34 0147 1400 09 4 SCREW, HEX HEAD SKRUV, SEXKANT M 12 X 25 - 8.8 FZV
42 3128 3090 42 1 ROLLER PATH SVÄNGKRANS Page 207
44 0147 1962 43 56 HEX. HEAD SCREW 6-KANT SKRUV A M20 110
50 – 1 HOSE ATTACHMENT SLANGFÄSTE Page 209
B0055721
202
TRAVERSE / TRAVERS
9111 4020 10 015K

203
CYLINDER / CYLINDER 3128 0560 80
CYLINDERCYLINDER
B0000912
204
CYLINDER / CYLINDER 3128 0560 80

9121 6526 50 1 SEAL KIT TÄTNINGSSATS REF 3-8, 10-20
9122 4332 50 2 COVER COMPL. LOCK KOMPL. REF 2-4
9126 2770 50 1 COVER COMPL. LOCK KOMPL. REF 9-11
1 9122 3892 00 1 MANTLE MANTEL
2 – 2 COVER LOCK
5 0665 1000 16 2 SEAL TÄTNING 105 / 115 X 11 94 AU
6 0665 9099 13 2 WIPER AVSTRYKARE 105 / 115 X 10 PU
7 0665 9300 67 2 GUIDE RING STYRRING RWR 105 / 111 X 18
8 0665 0800 14 1 PISTON SEAL KOLVTÄTNING 105 / 125 X 25 NBR
9 – 2 COVER LOCK
12 0665 1000 17 2 SEAL TÄTNING F1 63 75 INT
13 0665 9099 12 2 WIPER AVSTRYKARE B 63 75
15 9125 6739 00 1 PISTON ROD SEAL KOLVSTÅNGSTÄTN.
18 9122 3893 00 1 END COVER ÄNDLOCK
15,3 X 2,4 70 SHORE
3128 0560 80 004K

205
ROLLER PATH / SVÄNGKRANS 3128 3090 42
ROLLER PATHSVÄNGKRANS
X0000000
206
ROLLER PATH / SVÄNGKRANS 3128 3090 42

1 3128 3158 57 1 SEAL TÄTNING INNER AND OUTER SEAL
3128 3090 42 004K

207
HOSE ATTACHMENT / SLANGFÄSTE
HOSE ATTACHMENTSLANGFÄSTE
B0011331
208
HOSE ATTACHMENT / SLANGFÄSTE

2 3128 0968 00 2 YOKE BYGEL
9111 4020 13 001K

209
TURNING DEVICE / VRIDDON
TURNING DEVICEVRIDDON
B0034367
210
TURNING DEVICE / VRIDDON

1 3128 3093 81 2 GEAR VÄXEL Page 213
2 3128 3087 17 2 ECCENTER EXCENTER
6 0301 2371 00 24 PLAIN WASHER RUNDBRICKA 15 / 28 X 2,5 -HB 200 FZB
10 – 1 HOSE SET SLANGSATS Page 223 HYD.MOTOR
11 – 1 GEAR GREASE KUGGVÄXELFETT MALLEUS GL500
3128 0016 03 016K

211
GEAR / VÄXEL 3128 3093 81
GEARVÄXEL
B0012528
212
GEAR / VÄXEL 3128 3093 81

1 3128 3093 76 1 GEAR VÄXEL Page 215
2 3128 3093 77 1 BRAKE BROMS Page 219
3 3128 3093 78 1 HYDRAULIC MOTOR HYDRAULMOTOR Page 221
4 3128 3098 79 1 PINION PINJONG
6 3128 3095 11 1 VALVE BLOCK VENTILBLOCK
3128 3093 81 003K

213
GEAR / VÄXEL 3128 3093 76
GEARVÄXEL
B0031188
214
GEAR / VÄXEL 3128 3093 76
(Sheet 1 of 2)
3128 3170 03 1 SEAL KIT TÄTNINGSSATS INCL. POS 9,19,35,37
1 3128 3094 51 1 SUPPORT STÖD
2 3128 3094 52 1 COVER LOCK
3 3128 3094 53 1 SHAFT AXEL
4 3128 3170 04 1 KIT SATS
5 3128 3170 05 1 GEAR RING KUGGKRANS
6 3128 3170 06 1 FLANGE FLÄNS
7 3128 3170 07 1 KIT SATS
10 3128 3170 08 1 GEAR RING KUGGKRANS
11 3128 3170 09 1 PINION PINJONG
12 3128 3094 56 1 BEARING LAGER
13 3128 3094 57 1 BEARING LAGER
15 3128 3170 10 1 CIRCLIP SPÅRRING
16 3128 3094 60 1 SHIM SHIMS
17 3128 3094 61 1 LOCK NUT LÅSMUTTER
18 3128 3170 11 1 BEARING LAGER
20 3128 3170 12 1 FLANGE FLÄNS
21 3128 3094 63 4 SPRING PIN RÖRPINNE
22 3128 3170 13 12 SCREW SKRUV
23 3128 3170 14 5 SCREW SKRUV
24 3128 3170 15 8 NUT MUTTER
25 3128 3170 16 8 WASHER BRICKA
26 3128 3094 59 5 WASHER BRICKA
27 3128 3170 17 1 SPUR PINION KUGGDREV
28 3128 3094 62 1 PLUG PLUGG
29 3128 3094 64 1 PLUG PLUGG
30 3128 3094 65 1 PLUG PLUGG
31 3177 0001 86 1 PLUG PLUGG
32 3128 3170 19 1 DISK LAMELL
33 3177 0001 91 1 WASHER BRICKA
3128 3093 76 003K

215
GEAR / VÄXEL 3128 3093 76
(Sheet 2 of 2)
34 3128 3170 20 1 WASHER BRICKA
36 3128 3170 20 3 WASHER BRICKA
38 3128 3170 22 3 PLUG PLUGG
B0031188
216
GEAR / VÄXEL 3128 3093 76
3128 3093 76 003K

217
BRAKE / BROMS 3128 3093 77
BRAKEBROMS
B0031187
218
BRAKE / BROMS 3128 3093 77

3128 3170 24 1 SEAL KIT TÄTNINGSSATS INCL. POS 21,22,24,25,26
1 3177 0001 61 1 BRAKE HOUSING BROMSHUS
2 3177 0001 62 1 FLANGE FLÄNS
3 3177 0001 63 1 SHAFT AXEL
5 3177 0001 64 1 PISTON KOLV
7 3177 0001 66 1 RING RING
8 3177 0001 67 12 SPRING FJÄDER
10 3177 0001 68 7 DISK SKIVA
11 3177 0001 69 8 STEEL DISK STÅLSKIVA
13 3177 0001 70 1 BEARING BÄRLAGER
17 3177 0001 73 1 RETAINING RING STOPPRING
19 3177 0001 74 1 RETAINING RING STOPPRING
28 3177 0001 80 1 RING RING
29 3177 0001 81 1 RING RING
30 3177 0001 82 1 BEND RÖRBÖJ
31 3177 0001 83 4 SCREW SKRUV
32 3177 0001 84 6 SCREW SKRUV
37 3177 0001 86 3 PLUG PLUGG
38 3177 0001 87 1 PLUG PLUGG
39 3177 0001 88 1 PLUG PLUGG
40 3177 0001 89 6 WASHER BRICKA
41 3177 0001 90 1 WASHER BRICKA
42 3177 0001 91 4 WASHER BRICKA
3128 3093 77 004K

219
HYDRAULIC MOTOR / HYDRAULMOTOR 3128 3093 78
B0031189
220

3128 3170 03 1 SEAL KIT TÄTNINGSSATS INCL. POS 14,15,20,21
3128 3093 78 003K

221
HOSE SET / SLANGSATS HYD.MOTOR
HOSE SETSLANGSATS
B0015365
222
HOSE SET / SLANGSATS HYD.MOTOR

FRB1 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
OFR1 3176 5681 00 1 HOSE ASSEMBLY SLANGLEDNING 10 X 600 R2AT
3128 0016 46 005K

223
POSITIONING / POSITIONERING 9111 4064 62
POSITIONINGPOSITIONERING
B0049857
224
POSITIONING / POSITIONERING 9111 4064 62

1 9111 4020 29 1 FEED HOLDER MATARHÅLLARE Page 227
2 9111 4064 60 1 PENDULUM PENDEL
5 3128 0559 00 1 CYLIND.BRACKET CYLINDERFÄSTE
7 3128 3093 65 1 COVER LOCK
12 3128 3088 19 1 SEAL TÄTNING
13 3128 0554 01 4 WEAR PLATE SLITPLÅT
15 3128 0557 00 8 SHIM MELLANLÄGG T=1,5 MM
16 3128 0558 00 12 SHIM MELLANLÄGG T=0,5 MM
17 3128 0555 00 4 GUIDE LIST LINJAL
19 3128 0518 00 1 SHAFT AXEL
20 0690 3181 00 1 PLATE SKYLT 55 X 27 11 2333 56
25 3128 0530 00 1 WASHER BRICKA
34 3128 3175 30 1 YOKE BYGEL
9111 4064 62 003K

225
FEED HOLDER / MATARHÅLLARE 9111 4020 29
FEED HOLDERMATARHÅLLARE
B0013378
226
FEED HOLDER / MATARHÅLLARE 9111 4020 29

1 9111 4020 28 1 FEED HOLDER MATARHÅLLARE
2 3128 3175 30 1 YOKE BYGEL
3 3128 0968 00 1 YOKE BYGEL
5 – 1 PLATE PLÅT
9111 4020 29 003K

227
B0027919
228

9120 0993 13 1 SEAL KIT TÄTNINGSSATS INCL.ITEMS.4-5,10-16
3 3128 2191 36 1 PISTON KOLV
6 3222 3176 18 1 LOCK SCREW LÅSSKRUV
9 9122 4880 00 1 COVER LOCK
22 8231 1203 07 2 OVERCENT.VALVE LASTHÅLL.VENTIL
23 9127 3366 00 2 PLUG PLUGG
3128 3060 89 006K

229
B0001255
230

- 9120 0990 10 1 SEAL KIT TÄTNINGSSATS REF 4-7, 21-23
- 9120 0990 20 2 SEAL KIT TÄTNINGSSATS REF 17-20
2 9124 9566 00 1 PISTON KOLV
3 9123 6507 09 1 COVER LOCK
4 0665 0010 14 1 SEAL RING TÄTNINGSRING STEFA 40/50 X 10,5 S11EI
11 0544 2251 00 2 GREASE NIPPLE SMÖRJNIPPEL AH G 1/8
13 0686 6443 00 2 PLUG PROPP G 3/8 - STEEL 5.8 BLACK
14 0661 1026 00 2 SEAL WASHER TÄTNINGSBRICKA TREDO G 3/8
21 0665 0020 22 1 PISTON SEAL KOLVTÄTNING SKEGA 80 /60 / 51 7046
3128 3060 15 002K

231
B0002902
232

1 3128 3093 97 1 SHAFT AXEL
3128 3093 96 002K

233
B0000559
234

1 3155 2367 00 1 SHAFT AXEL
4 0291 1112 00 1 LOCK NUT LÅSMUTTER M 12 - 8 FZB
3155 2367 80 002D

235
HOSE HOLDER SET / SLANGHÅLLARSATS
HOSE HOLDER SETSLANGHÅLLARSATS
X0000000
236
HOSE HOLDER SET / SLANGHÅLLARSATS

1 – 1 HOSE FRAME SET SLANGHÅLLARSATS Page 239
2 9110 9748 75 3 HOSE HOLDER SLANGHÅLLARE
9111 4064 11 003K

237
HOSE FRAME SET / SLANGHÅLLARSATS
HOSE FRAME SETSLANGHÅLLARSATS
B0039839
238
HOSE FRAME SET / SLANGHÅLLARSATS

10 3125 1997 00 1 PIPE RÖR
11 3125 2049 00 1 PIPE RÖR
18 9111 3622 45 1 HOSE HOLDER SLANGHÅLLARE
28 – 1 ATTACHMENT FÄSTE Page 241
30 9111 4115 75 1 HOSE GUIDE SLANGFÖRARE
42 0226 9915 12 24 SCREW SKRUV M 6 X 20 - STEEL FZB
44 0266 2108 00 24 NUT MUTTER M 6 - 8 FZB
45 3128 2098 00 4 ATTACHM. PLATE FÄSTPLÅT
46 3128 0289 01 8 ELBOW PLATE VINKELPLÅT
9111 4064 12 002K

239
ATTACHMENT / FÄSTE
ATTACHMENTFÄSTE
B0015575
240
ATTACHMENT / FÄSTE

2 9111 3530 15 1 CLAMP ÖVERFALL
6 0347 6120 00 4 HOSE CLIP SLANGKLÄMMA 140 - 159 FZB
7 9030 0300 00 2M AIR HOSE LUFTSLANG 12,5 X 5
9111 3530 16 004K

241
242
CARRIER / UNDERREDE
LIST OF CONTENTS
– CARRIER UNDERREDE 249
3217 9952 00 – LASER – LASER 251 RAL 650 LAZER
3217 9952 02 – – CONVERTER – – OMVANDLARE 253
– – ATTACHMENT SET – FÄSTDETALJER 255
– – – ATTACHMENT – – FÄSTE 259
9111 3748 00 – PANEL HOLDER – PANELFÄSTE 261
– – CARRIER – UNDERREDE 263
5112 2877 37 – – HYDR. SYSTEM – – HYDRAULSYSTEM 265 CARRIER
– – – – HOSE SET – – – SLANGSATS 269 DC 15 C
5112 3021 12 – – – HYDRAULIC PUMP – – – HYDRAULPUMP 271
3128 2020 15 – – – PRESS.RED.VALVE – – – TRYCKRED.VENTIL 275 R 1/4
5112 1933 80 – – – HYDR. CYLINDER – – – HYDRAULCYLINDER 277 STEERING CYL.
125/63/385
5112 2347 80 – – – PILOT VALVE – – – STYRVENTIL 279
5112 2348 80 – – – VALVE BLOCK – – – VENTILBLOCK 281
– – – FRAME MOTOR P. – – RAM MOTORDEL 283
5112 2331 80 – – – FUEL TANK – – – BRÄNSLETANK 285
5112 2331 81 – – – – FUEL TANK – – – – BRÄNSLETANK 287
5112 3021 15 – – – DRIVE AXLE – – – DRIVAXEL 289
5112 3024 66 – – – – BRAKE DISC KIT – – – – BROMSLAMELLSATS 291 COMPLETE KIT ONLY
5112 3024 68 – – – – CROWN WHEEL KIT – – – – KRONHJULSATS 293 COMPLETE KIT ONLY
5112 3024 71 – – – – PLANET GEAR KIT – – – – PLANETHJULSSATS 295 COMPLETE KIT ONLY
5112 3197 44 – – – – DIFF.KIT – – – – DIFF.SATS 297 COMPLETE KIT ONLY
– – – FRAME MOTOR P. – – RAM MOTORDEL 299
5112 3133 74 – – – HYDR. RESERVOIR – – – HYDRAULTANK 303
5112 2931 00 – – – – LEVEL-TEMP.IND. – – – – NIVÅ-TEMP.MÄT. 305
243
8234 0200 36 – – – – FILTER, COMPL. – – – – FILTER, KOMPL. 307
– – – – BATTERY BOX – – – BATTERILÅDA 309
– – – EL.EQUIPMENT – – ELUTRUSTNING 311 CARRIER
5112 0104 01 – – – JUNCTION BOX – – – KOPPLINGSLÅDA 313 X2
5112 0020 41 – – – – JUNCTION BOX – – – – KOPPLINGSLÅDA 317 X2
5112 0104 04 – – – SWITCH PANEL – – – INSTRUMENTPANEL 319
3217 0012 05 – – – – INDICATION LAMP – – – – SIGNALLAMPA 323
– – – – – HOUR METER – – – – TIMRÄKNARE 325 COMPLETE
3217 0012 35 – – – – MUSHROOM PUSHB. – – – – SVAMPTRYCKKNAPP 327
5112 3046 92 – – – – IGNITION LOCK – – – – TÄNDNINGSLÅS 329
3217 0012 58 – – – – PUSH BUTTON – – – – TRYCKKNAPP 331
5112 0104 17 – – – EL EQUIPM.MOTOR – – – ELUTRUSTN.MOTOR 339
5112 0104 09 – – – DRIVING LIGHT. – – – ÅKBELYSNING 343 8 X 70W
5112 3043 40 – – – – HEADLIGHT – – – – STRÅLKASTARE 345
5112 3043 40 – – – – HEADLIGHT – – – – STRÅLKASTARE 345
5112 3134 81 – – – – HEADLIGHT – – – – STRÅLKASTARE 347 NORDIC 100 24V
5112 3134 81 – – – – HEADLIGHT – – – – STRÅLKASTARE 347 NORDIC 100 24V
5112 3217 81 – – – – JUNCTION BOX – – – – KOPPLINGSLÅDA 349
244
– – – – REVERSE ALARM – – – BACKALARM 351
5112 3126 05 – – – BRAKE LIGHT – – – BROMSLJUS 353
– – – DIESEL ENG.UNIT – – DIESELMOT.ENHET 355
– – – – DIESEL ENG.UNIT – – – DIESELMOT.ENHET 357
5112 3238 04 – – – – DIESEL ENGINE – – – – DIESELMOTOR 359
5112 3231 95 – – – – AIR FILTER SET – – – – LUFTFILTERSATS 361
5112 3052 41 – – – – – AIR FILTER – – – – – LUFTFILTER 363
5112 3231 60 – – – – AIR INLET – – – – LUFTINTAG 365
5112 3231 45 – – – – THROTTLE CONTR. – – – – GASREGLAGE 367
– – – – – – THROTTLE CONTR. – – – – – GASREGLAGE 369
5112 3228 68 – – – – CABLE HOLDER – – – – KABELHÅLLARE 371
5112 3231 71 – – – – DRAINAGE – – – – AVTAPPNING 373
5112 3020 94 – – – CARDAN SHAFT – – – KARDANAXEL 375
5112 3216 64 – – – HYDR.TRANSMISS. – – – HYDR.TRANSMISS 377
5112 3041 80 – – – FILLER SET – – – PÅFYLLNINGSSATS 381 CLARK 12000
5112 3102 99 – – – LEVEL GLASS – – – NIVÅGLAS 383
– – – FUEL SYSTEM – – BRÄNSLESYSTEM 385
– – – PLATFORM COMPL. – – PLATTFORM KOMPL 387
– – – LUBR. SYSTEM – – SMÖRJSYSTEM 389
5112 2163 80 – – – LUBR. VALVE – – – SMÖRJVENTIL 391
– – – FRAME BOOM PART – – RAM BOMDEL 393
5112 3021 84 – – – DRIVE AXLE – – – DRIVAXEL 399
5112 3024 66 – – – – BRAKE DISC KIT – – – – BROMSLAMELLSATS 291 COMPLETE KIT ONLY
5112 3024 68 – – – – CROWN WHEEL KIT – – – – KRONHJULSATS 293 COMPLETE KIT ONLY
5112 3024 71 – – – – PLANET GEAR KIT – – – – PLANETHJULSSATS 295 COMPLETE KIT ONLY
5112 3190 18 – – – – DIFF.KIT – – – – DIFF.SATS 401 COMPLETE KIT ONLY
5112 2360 80 – – – HYDR. CYLINDER – – – HYDRAULCYLINDER 403 HC09-K63-32K-400-A37
245
3128 2099 55 – – – – CHECK VALVE – – – – BACKVENTIL 405
5112 3134 38 – – DRIVERS PLATF. – – FÖRARPLATTFORM 407
– – – CHAIR COMPL. – – STOL KOMPL. 409
5112 0007 80 – – – CHAIR COMPL. – – – STOL KOMPL. 411
5112 2877 19 – – HYDR. SYSTEM – – HYDRAULSYSTEM 413 OIL COOLER
– – – HOSE SET – – SLANGSATS 269 DC 15 C
5112 3231 28 – – EXHAUST SYSTEM – – AVGASSYSTEM 415
5112 3232 52 – – – CATALYSER – – – KATALYSATOR 417
– – – – SILENCER – – – LJUDDÄMPARE 419
5112 3235 27 – – SET OF WHEELS – – HJULSATS 421
5112 3223 56 – – – WHEEL COMPL. – – – HJUL KOMPL. 423 SOLIDEAL 12.0X20/20 LAGER
5112 2335 80 – – – – RIM COMPL. – – – – FÄLG KOMPL. 425
5112 3302 52 – – – ASSEMBLY SET – – – MONTERINGSSATS 427 WHEEL NUT AND WASHER
– – – GUIDE UNIT – – STYRENHET 429
5112 3025 20 – – – CONTROL PANEL – – – MANÖVERPULPET 431
5112 3025 14 – – – STEERING SYSTEM – – – STYRSYSTEM 433
5112 3024 99 – – – ANGLE POINTER – – – VINKELVISARE 435
9110 8551 00 – SUPPORT LEG – STÖDBEN 437
9121 5913 01 – – HYDR. CYLINDER – – HYDRAULCYLINDER 439 SUPPORT LEG
BSJ 10-40
– – PROTECTION ROOF – SKYDDSTAK 441
– – WARNING SIGNS – VARNINGSSKYLTAR 445
– – LABEL LIST – DEKALLISTA 447
– – DRILL BIT BOX – KRONLÅDA 449
9111 4225 12 – FIRE SUPPR.SYST – ELDBEKÄMPN.SYST 451
– – – FIRE SUPPR.SYST – – ELDBEKÄMPN.SYST 453 ANSUL
5112 3049 30 – – – FIRE EXTING.SET – – – ELDSLÄCKN.SATS 455 ANSUL SYSTEM
246
3217 9316 11 – – – – NOZZLE – – – – MUNSTYCKE 457
– – – – – SEAL – – – – PLOMB 459
– – – – CONNECTION SET – – – ANSLUTNINGSSATS 461 ANSUL
– – – – HOSE SET – – – SLANGSATS 463 ANSUL
– – – COVER, CPL. – – SKYDD KOMPL. 465
5112 0107 27 – – FIRE EXTING.SET – – ELDSLÄCKN.SATS 467
5112 0107 30 – – – HOSE SET – – – SLANGSATS 469
– – – – SEAL – – – PLOMB 459
247
CARRIER / UNDERREDE
CARRIERUNDERREDE
B0049856
248
CARRIER / UNDERREDE

52 3217 9952 00 1 LASER LASER Page 251 RAL 650 LAZER
105 – 1 ATTACHMENT SET FÄSTDETALJER Page 255
106 9111 3748 00 1 PANEL HOLDER PANELFÄSTE Page 261
107 9111 3752 00 1 BRACKET KONSOL
200 – 1 CARRIER UNDERREDE Page 263
215 – 1 REAR FRAME EFTERRAM
230 9110 8551 00 4 SUPPORT LEG STÖDBEN Page 437
235 – 1 PROTECTION ROOF SKYDDSTAK Page 441
265 9106 1072 21 2 LASER RADIATION LASERSTRÅLNING ENGLISH TEXT
266 – 1 WARNING SIGNS VARNINGSSKYLTAR Page 445
267 – 1 LABEL LIST DEKALLISTA Page 447
861 – 1 DRILL BIT BOX KRONLÅDA Page 449
900 9111 4225 12 1 FIRE SUPPR.SYST ELDBEKÄMPN.SYST Page 451
1260 5001 31 001K

249
LASER / LASER 3217 9952 00 RAL 650 LAZER
LASERLASER
B0024704
250
LASER / LASER 3217 9952 00 RAL 650 LAZER

1 3217 9952 01 2 LASER LASER
2 3217 9952 02 1 CONVERTER OMVANDLARE Page 253
4 9111 3891 06 0.50M CABLE, 3-CORE KABEL, 3-LEDARE 3X1,5
5 0697 9745 31 1 ADAPTER ADAPTER PG 11 - M 20X1,5
M20X1,5 7-13 B1
6 3217 9952 03 1 PLATE SKYLT
10 3217 0010 20 1 PALM GRIP VRED
3217 9952 00 011K

251
CONVERTER / OMVANDLARE 3217 9952 02
CONVERTEROMVANDLARE
B0006793
252
CONVERTER / OMVANDLARE 3217 9952 02

3217 9952 09 1 CONVERTER OMVANDLARE DC CONVERTER 5V
3217 9952 02 003K

253
ATTACHMENT SET / FÄSTDETALJER
ATTACHMENT SETFÄSTDETALJER
B0063322
254
(Sheet 1 of 2)
1 – 1 ATTACHMENT FÄSTE
4 3176 3604 00 2 U-BOLT U-BULT
5 0291 1128 21 4 LOCK NUT LÅSMUTTER M 10 - 8 FZB /7 ISO 7043
6 9106 1610 20 1 COOLER SUPPORT KYLARFÄSTE
16 0291 1128 15 2 LOCK NUT LÅSMUTTER M6 - 8 FZB / ISO 7040
24 0301 2394 04 8 PLAIN WASHER RUNDBRICKA 21 / 37 X 3 - HB 200 FZV
27 0147 1323 03 4 SCREW, HEX HEAD SKRUV, SEXKANT M 8 X 20 -8.8 FZB
37 9110 8539 00 1 FLAT BAR PLATTSTÅNG
40 0291 1128 03 5 LOCK NUT LÅSMUTTER M 5 - ISO A4
42 – 1 ATTACHMENT FÄSTE Page 259
43 9111 3714 62 1 HANDLE HANDTAG LEFT
44 9111 3714 63 1 HANDLE HANDTAG RIGHT
51 – 1 HOSE HOOK SLANGKROK
9111 3565 93 007K

255
(Sheet 2 of 2)
52 9111 3714 86 1 HOSE FENDER SLANGAVVISARE
B0063322
256
9111 3565 93 007K

257
ATTACHMENT / FÄSTE
ATTACHMENTFÄSTE
B0007649
258
ATTACHMENT / FÄSTE

9111 3647 15 001K

259
PANEL HOLDER / PANELFÄSTE 9111 3748 00
PANEL HOLDERPANELFÄSTE
B0052227
260
PANEL HOLDER / PANELFÄSTE 9111 3748 00

2 – 1 BRACKET KONSOL
3 9111 3748 30 2 WHEEL COMPL. HJUL KOMPL.
4 – 2 GUIDE STYRNING
5 3128 2097 00 4 SLEEVE HYLSA
6 3177 0055 00 4 BUFFER BUFFERT BUFFERT 15/3458
7 0335 1122 00 2 CIRCLIP SPÅRRING SGA 20 X 1,2 DIN 471
10 0266 2110 00 8 NUT MUTTER M 8 - 8 FZB
9111 3748 00 003K

261
CARRIER / UNDERREDE
CARRIERUNDERREDE
B0000845
262
CARRIER / UNDERREDE

1 5112 2877 37 1 HYDR. SYSTEM HYDRAULSYSTEM Page 265 CARRIER
2 – 1 FRAME MOTOR P. RAM MOTORDEL Page 283
3 – 1 FRAME MOTOR P. RAM MOTORDEL Page 299
4 – 1 EL.EQUIPMENT ELUTRUSTNING Page 311 CARRIER
5 – 1 DIESEL ENG.UNIT DIESELMOT.ENHET Page 355
7 – 1 FUEL SYSTEM BRÄNSLESYSTEM Page 385
8 – 1 PLATFORM COMPL. PLATTFORM KOMPL Page 387
9 – 1 LUBR. SYSTEM SMÖRJSYSTEM Page 389
10 – 1 FRAME BOOM PART RAM BOMDEL Page 393
11 5112 3134 38 1 DRIVERS PLATF. FÖRARPLATTFORM Page 407
12 – 1 CHAIR COMPL. STOL KOMPL. Page 409
13 5112 2877 19 1 HYDR. SYSTEM HYDRAULSYSTEM Page 413 OIL COOLER
14 – 1 HOSE SET SLANGSATS Page 269 DC 15 C
15 5112 3231 28 1 EXHAUST SYSTEM AVGASSYSTEM Page 415
16 5112 3235 27 2 SET OF WHEELS HJULSATS Page 421
17 – 1 GUIDE UNIT STYRENHET Page 429
32 9721 0800 00 30L FUEL BRÄNSLE DF DIESEL
5112 3238 19 001K

263
HYDR. SYSTEM / HYDRAULSYSTEM 5112 2877 37 CARRIER
HYDR. SYSTEMHYDRAULSYSTEM
B0056342
264
HYDR. SYSTEM / HYDRAULSYSTEM 5112 2877 37 CARRIER
(Sheet 1 of 3)
A – 1 HOSE SET SLANGSATS Page 269 DC 15 C
1 5107 1534 00 1 NIPPLE NIPPEL
4 0144 3363 03 2 SCREW, HEX HEAD SKRUV, SEXKANT UNC 1/2 X 32 - 8.8 FZB
6 5112 2921 01 1 PRESSURE SWITCH TRYCKVAKT
7 5112 2949 00 1 PROTECT. COVER SKYDDSHUV
TREDO 1/4
9 5112 2595 00 1 PRESSURE SWITCH TRYCKVAKT SUCO 0166412031047
10 0653 1055 00 1 GASKET PACKNING 12 / 15,5 X 1,5-11 501312
11 3176 7707 00 1 NIPPLE NIPPEL UNF 9/16 - M12 X 1,5
T- /SVIVELNUT
16 0570 5191 06 1 TEST CONNECTION TESTANSLUTNING UNF 7/8 - GR 1/4
18 5112 3021 12 1 HYDRAULIC PUMP HYDRAULPUMP Page 271
23 0570 5191 05 2 TEST CONNECTION TESTANSLUTNING UNF 3/4 - G 1/4
27 3128 2020 15 1 PRESS.RED.VALVE TRYCKRED.VENTIL Page 275 R 1/4
5112 2877 37 022K

265
HYDR. SYSTEM / HYDRAULSYSTEM 5112 2877 37
(Sheet 2 of 3)
32 5112 2878 05 1 BRAKE VALVE BROMSVENTIL
33 3176 6615 00 2 CAP NUT ÖVERFALLSMUTTER UNF 3/4
34 3176 6501 00 3 NIPPLE NIPPEL UNF 3/4 - UNF 9/16
40 0603 4225 00 2 HEXAGON NIPPLE SEXKANTNIPPEL R 1/2 - R 1/2 - 11 1914
41 5112 2915 00 2 ACCUMULATOR ACKUMULATOR 65 BAR
42 5112 3024 50 1 ACCUMULAT.BLOCK ACKUMULAT.BLOCK
UNF 9/16-M14X1,5 STRAIGHT
T- /SVIVELNUT
49 3715 0597 00 1 CAP HUV UNF 7/8
50 3176 6646 00 1 NIPPLE NIPPEL UN 1 7/8 - G 1 1/2
51 3176 6788 00 1 CAP NUT ÖVERFALLSMUTTER UN 1 7/8
53 3176 6505 00 1 NIPPLE NIPPEL UN 1 1/16 - UNF 7/8
54 5112 1933 80 1 HYDR. CYLINDER HYDRAULCYLINDER Page 277 STEERING CYL.
125/63/385
55 3217 6512 01 1 RESTRICTION STRYPNING D=3,4
SU1 5107 1536 00 1 HOSE ASSEMBLY SLANGLEDNING
75 3176 6517 00 1 NIPPLE NIPPEL UN 1 1/16 - G 3/4
B0056342
266
(Sheet 3 of 3)
84 0638 0527 00 2 FLANGE HALF FLÄNSHALVA 32 X 51,59 SAE 1 1/4 P276
ZINC PLATED
88 5112 2347 80 1 PILOT VALVE STYRVENTIL Page 279
89 5112 2348 80 1 VALVE BLOCK VENTILBLOCK Page 281
90 0347 4344 00 2 HOSE CLIP SLANGKLÄMMA D=47 NORMA TYP SKZ
5112 2877 37 022K

267
HOSE SET / SLANGSATS DC 15 C
HOSE SETSLANGSATS
B0015365
268
HOSE SET / SLANGSATS DC 15 C

ABR1 0574 1316 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2700 R2AT
STT1 0574 2284 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 3400 R2AT
BD1 3176 6975 00 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2400 R2AT
BD3 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
BR3 0574 0260 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 650 R2AT
CV1 0574 3261 11 1 HOSE ASSEMBLY SLANGLEDNING 19 X 700 R2AT
P13 0574 2280 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 2600 R2AT
ST1 0574 2273 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X1600 R2AT
ST2 0574 0000 39 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 850 R2AT
TRF 0574 3261 11 1 HOSE ASSEMBLY SLANGLEDNING 19 X 700 R2AT
1BR1 0574 0064 71 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2900 R2AT
1BR2 0574 0328 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 220 R2AT
3128 2020 90 002K

269
HYDRAULIC PUMP / HYDRAULPUMP 5112 3021 12
HYDRAULIC PUMPHYDRAULPUMP
B0000169
270

5112 3100 56 1 SEAL KIT TÄTNINGSSATS REF 1-2
5112 3021 12 004K

271
B0047201
272

1 3222 3106 10 1 SOLENOID MAGNETSPOLE
2 3128 3087 31 1 SEAL KIT TÄTNINGSSATS INCL.POS.3-8
9106 0630 14 002K

273
PRESS.RED.VALVE / TRYCKRED.VENTIL 3128 2020 15 R 1/4
B0004672
274
PRESS.RED.VALVE / TRYCKRED.VENTIL 3128 2020 15 R 1/4

3128 3023 72 1 SEAL KIT TÄTNINGSSATS INCL.POS.12-16
1 3128 3023 71 1 INSERT INSATS INCL.SEALS
3128 2020 15 006K

275
HYDR. CYLINDER / HYDRAULCYLINDER 5112 1933 80 STEERING CYL. %% 125/63/385
B0000876
276
HYDR. CYLINDER / HYDRAULCYLINDER 5112 1933 80 STEERING CYL. %% 125/63/385

9120 0990 14 1 SEALING SET PACKNINGSSATS REF. NO. 5-9,11,12.
4 9123 6507 13 1 CYLINDER COVER CYLINDERLOCK INCLUDES REF. NO. 5-8.
7 0665 0010 18 1 PISTON ROD SEAL KOLVSTÅNGSTÄTN. A1 63 83
10 9124 9568 00 1 PISTON KOLV
12 0665 0800 35 1 PISTON SEAL KOLVTÄTNING E1X 100 125
5112 1933 80 004K

277
PILOT VALVE / STYRVENTIL 5112 2347 80
PILOT VALVESTYRVENTIL
B0038350
278

5112 2347 92 1 SEALING SET PACKNINGSSATS INCL.POS.1-5
5112 2347 80 002K

279
VALVE BLOCK / VENTILBLOCK 5112 2348 80
VALVE BLOCKVENTILBLOCK
B0024629
280

5112 2348 91 1 SEAL KIT TÄTNINGSSATS INCL.POS: 3,9,11
5112 3120 19 1 SHOCK VALVE CHOCKVENTIL INCL.POS: 8-14
5112 3217 56 1 RELIEF VALVE AVLASTN.VENTIL INCL.POS: 2-7
5112 2348 80 004K

281
FRAME MOTOR P. / RAM MOTORDEL
FRAME MOTOR P.RAM MOTORDEL
B0044363
282

1 5112 3020 70 1 MOTOR FRAME MOTORRAM
4 5112 2331 80 1 FUEL TANK BRÄNSLETANK Page 285
11 5112 3021 15 1 DRIVE AXLE DRIVAXEL Page 289
21 5112 2524 00 1 COVER LOCK
26 5112 2523 00 1 CUSHION KUTS
30 0303 1274 01 4 PLAIN WASHER RUNDBRICKA 8,4 / 26 X 5 - 5.8 FZB
5112 3230 67 003D

283
FUEL TANK / BRÄNSLETANK 5112 2331 80
FUEL TANKBRÄNSLETANK
B0061288
284

1 5112 2331 81 1 FUEL TANK BRÄNSLETANK Page 287
6 5112 2340 00 1 COVER LOCK
7 5054 0140 00 0.33M PLASTIC TUBING PLASTSLANG
8 1088 1301 01 3 ASSEMBLY STRIP MONTERINGSBAND 2,4 X 92 1,6-15,8 T.-23M
11 5112 1423 00 1 SUCT.-RETURN P. SUG-RETURLEDN.
13 5112 2083 81 1 LEVEL SENSOR NIVÅGIVARE
15 5118 1159 00 1 PLUG PROPP
16 5112 3022 18 0.70M HOSE SLANG
18 5112 2338 07 1 FILLER PIPE PÅFYLLNINGSRÖR
19 5112 2646 00 1 U-BOLT U-BULT P 69,9 M 8 77
23 5112 3231 94 1 LEVEL GLASS NIVÅGLAS
5112 2331 80 006K

285
FUEL TANKBRÄNSLETANK
B0001274
286

2 – 1 FUEL TANK BRÄNSLETANK
3 5112 2338 00 1 TANK COVER TANKLOCK
5112 2331 81 004K

287
DRIVE AXLE / DRIVAXEL 5112 3021 15
DRIVE AXLEDRIVAXEL
B0004959
288

5112 3024 66 1 BRAKE DISC KIT BROMSLAMELLSATS Page 291 COMPLETE KIT ONLY
5112 3024 68 1 CROWN WHEEL KIT KRONHJULSATS Page 293 COMPLETE KIT ONLY
5112 3024 71 2 PLANET GEAR KIT PLANETHJULSSATS Page 295 COMPLETE KIT ONLY
5112 3197 44 1 DIFF.KIT DIFF.SATS Page 297 COMPLETE KIT ONLY
1 5112 3003 35 20 WHEEL BOLT HJULBULT
2 0299 1000 06 20 WHEEL NUT HJULMUTTER M 22X1,5 - 10 FOSF. TYP A
3 0653 1128 00 2 GASKET PACKNING 22 / 27 X 1,5 -11 5013 12
4 5112 3003 37 2 PLUG PLUGG
5 5112 3104 74 2 PLANET GEAR HO. PLANETVÄXELHUS
6 5112 3120 40 1 FLANGE FLÄNS
5112 3021 15 008K

289
BRAKE DISC KIT / BROMSLAMELLSATS 5112 3024 66 COMPLETE KIT ONLY
BRAKE DISC KITBROMSLAMELLSATS
B0000501
290
BRAKE DISC KIT / BROMSLAMELLSATS 5112 3024 66 COMPLETE KIT ONLY

1 5112 3032 14 2 O-RING O-RING
2 5112 3003 59 12 DISK LAMELL
3 5112 3005 03 2 O-RING O-RING
4 5112 3003 60 12 DISK LAMELL
5112 3024 66 003K

291
CROWN WHEEL KIT / KRONHJULSATS 5112 3024 68 COMPLETE KIT ONLY
CROWN WHEEL KITKRONHJULSATS
B0024394
292
CROWN WHEEL KIT / KRONHJULSATS 5112 3024 68 COMPLETE KIT ONLY

3 5112 3003 07 2 LOCK SHEET LÅSBLECK
4 5112 3032 14 6 O-RING O-RING
5 5112 3003 75 1 BEARING LAGER
5 5112 3003 78 2 BEARING LAGER
7 5112 3187 75 16 BOLT BULT
8 5112 3133 08 1 O-RING O-RING
10 – 1 GEAR SET DREVSATS
20 5112 3187 77 16 SPRING WASHER FJÄDERBRICKA
23 5112 3133 17 1 O-RING O-RING
24 5112 3187 85 1 SHIM SHIMS 0,40 MM
24 – 4 SHIM SHIMS
27 5112 3003 79 1 BEARING LAGER
28 5112 3193 84 1 COVER PLATE TÄCKPLATTA
29 5112 3187 87 1 O-RING O-RING
30 5112 3003 23 1 NUT MUTTER
32 5112 3133 49 1 SEAL TÄTNING
34 – 1 SHIM SHIMS
34 – 1 SHIM SHIMS
34 – 1 SHIM SHIMS
34 – 1 SHIM SHIMS
35 5112 3003 80 1 BEARING LAGER
5112 3024 68 002K

293
PLANET GEAR KIT / PLANETHJULSSATS 5112 3024 71 COMPLETE KIT ONLY
PLANET GEAR KITPLANETHJULSSATS
B0000044
294
PLANET GEAR KIT / PLANETHJULSSATS 5112 3024 71 COMPLETE KIT ONLY

1 – 2 SEAL TÄTNING
2 – 1 RING RING
3 – 1 SHAFT AXEL
4 – 5 SCREW SKRUV
5 – 1 RING RING
6 – 1 WASHER BRICKA
7 – 1 SEAL WASHER TÄTNINGSBRICKA
8 – 1 PLUG PLUGG
9 – 3 O-RING O-RING
10 – 3 PIN PINNE
11 – 5 BOLT BULT
12 – 3 BEARING LAGER
13 – 3 GEAR WHEEL KUGGHJUL
14 – 3 BOLT BULT
15 – 1 PLATE PLATTA
16 – 5 PIN STIFT
17 – 1 HOLDER HÅLLARE
18 – 1 RING RING
19 – 1 WHEEL HJUL
22 – 1 RING RING
5112 3024 71 001D

295
DIFF.KIT / DIFF.SATS 5112 3197 44 COMPLETE KIT ONLY
DIFF.KITDIFF.SATS
B0025874
296

6 5112 3190 15 8 BOLT BULT
8 5112 3003 10 2 FRICTION RING FRIKTIONSRING
9 5112 3190 14 2 SIDE WHEEL SIDOHJUL
10 5580 0110 80 4 WASHER BRICKA
11 5112 3188 03 4 DIFFERENT.WHEEL DIFFERENT. HJUL
12 5112 3188 09 1 SHAFT AXEL
13 5112 3003 77 3 PIN PINNE
14 5112 3188 08 1 DIFF.SPIDER DIFF.KORS
15 5112 3188 04 2 SHAFT AXEL
17 5112 3190 17 1 DIFF.CASE DIFF.HUS
19 5112 3190 16 1 COVER LOCK
5112 3197 44 003K

297
FRAME MOTOR P.RAM MOTORDEL
B0056755
298
(Sheet 1 of 2)
1 5112 3133 74 1 HYDR. RESERVOIR HYDRAULTANK Page 303
11 5112 3020 91 1 HOOK HAKE
15 5112 3231 82 1 CAP HUV
26 5112 3231 74 1 BACK HEAD BAKSTYCKE
32 – 1 BATTERY BOX BATTERILÅDA Page 309
33 5112 3064 25 1 MUDGUARD STÄNKSKÄRM
46 0500 0324 00 1 PLAIN BEARING GLIDLAGER 60 F7 X 75 P6 X 60 TYPE A
47 5112 2093 00 2 RING PIN RINGSPRINT DANOPRODUKTER NR 11060
48 5112 2387 00 1 STAY STAG
49 5112 2405 06 1 RUBBER PROTEC GUMMISKYDD
50 3176 3681 00 15 STRAP BAGAGEBAND L=500,B=25 TYG
BLACK YELLOW TEXT
51 0500 1296 00 2 PLAIN BEARING GLIDLAGER 60 F7 X 75 P6 X 35
5112 3231 26 005K

299
(Sheet 2 of 2)
54 5112 3021 08 1 SUPPORT BEAM STÖDBALK
57 0226 0351 01 3 TAPPING SCREW GÄNGANDE SKRUV MC6S M 5 X 20 - 5.8 FZB
MC6S M5X20-5.8 FZB
58 5112 2946 01 3 RUBBER BUFFER GUMMIBUFFERT
B0056755
300
5112 3231 26 005K

301
HYDR. RESERVOIR / HYDRAULTANK 5112 3133 74
HYDR. RESERVOIRHYDRAULTANK
B0056761
302
HYDR. RESERVOIR / HYDRAULTANK 5112 3133 74

2 0266 2111 00 8 NUT MUTTER M 10 - 8 FZB
4 0653 1055 00 1 GASKET PACKNING 12 / 15,5 X 1,5-11 501312
6 0686 3710 00 1 PLUG PROPP R 1 1/2 - 11 1550
8 5112 2931 00 1 LEVEL-TEMP.IND. NIVÅ-TEMP.MÄT. Page 305
9 8231 0854 84 1 MANOMETER MANOMETER
10 8234 0200 36 2 FILTER, COMPL. FILTER, KOMPL. Page 307
11 8231 0854 19 1 BREATHER FILTER ANDNINGSFILTER CONNECTION. G3/4'
12 5112 3133 75 1 HYDR.OIL TANK HYDRAULOLJETANK
13 8202 0304 02 1 BALL VALVE KULVENTIL BAL 20 - G 3/4 - TYP A
AIR
SPARE PARTS SET 9090 1154 00
5112 3133 74 006K

303
LEVEL-TEMP.IND. / NIVÅ-TEMP.MÄT. 5112 2931 00
LEVEL-TEMP.IND.NIVÅ-TEMP.MÄT.
B0058817
304
LEVEL-TEMP.IND. / NIVÅ-TEMP.MÄT. 5112 2931 00

3 5112 2931 02 1 THERMOMETER TERMOMETER
5 5112 2931 90 1 SPARE PARTS SET RESERVDELSSATS
5112 2931 00 006K

305
FILTER, COMPL. / FILTER, KOMPL. 8234 0200 36
FILTER, COMPL.FILTER, KOMPL.
B0038355
306
FILTER, COMPL. / FILTER, KOMPL. 8234 0200 36

1 8231 1018 04 2 FILTER INSERT FILTERINSATS
2 0266 2111 00 4 NUT MUTTER M 10 - 8 FZB
4 8231 0853 45 1 O-RING O-RING
5 8231 0853 46 1 O-RING O-RING
7 8231 0858 23 1 COVER COMPL. LOCK KOMPL.
8 5112 3102 60 1 BY PASS VALVE ÖVERSTR.VENTIL
8234 0200 36 006K

307
BATTERY BOX / BATTERILÅDA
BATTERY BOXBATTERILÅDA
B0000839
308
BATTERY BOX / BATTERILÅDA

7 5112 2607 00 4 KNOB KNOPP
8 5112 2608 00 2 RUBBER STROP GUMMISTROPP
9 5112 2610 00 1 BATTERY COVER BATTERILOCK
10 5112 2731 24 1 BATTERY SHELF BATTERIHYLLA
5112 3021 53 005K

309
EL.EQUIPMENT / ELUTRUSTNING CARRIER
EL.EQUIPMENTELUTRUSTNING
X0000000
310
EL.EQUIPMENT / ELUTRUSTNING CARRIER

B350 9111 3891 44 3M CABLE, 2-CORE KABEL, 2-LEDARE 2X1.5 D2=7.4
H121 3176 0001 56 1 REVERSE ALARM BACKALARM 97DB
H121 5112 0127 90 1 CABLE KABEL
H186 3176 0000 90 1 LOUDWHISTLEHORN STARKTONHORN
H186 9111 3891 44 3M CABLE, 2-CORE KABEL, 2-LEDARE 2X1.5 D2=7.4
H215 9111 3891 44 3M CABLE, 2-CORE KABEL, 2-LEDARE 2X1.5 D2=7.4
Y216 3217 9882 04 1 VALVE PLUG VENTILKONTAKT 3M
W51 9111 3891 13 3M CABLE, 7-CORE KABEL, 7-LEDARE 7X1,5MM2
W52 9111 3891 10 3M CABLE, 5-CORE KABEL, 5-LEDARE 150 5G1.5 D2=9.8
X2 5112 0104 01 1 JUNCTION BOX KOPPLINGSLÅDA Page 313 X2
X5 5112 0104 04 1 SWITCH PANEL INSTRUMENTPANEL Page 319
1 5112 0104 17 1 EL EQUIPM.MOTOR ELUTRUSTN.MOTOR Page 339
2 5112 0104 09 1 DRIVING LIGHT. ÅKBELYSNING Page 343 8 X 70W
MC6S M5X20-5.8 FZB
10 – 1 REVERSE ALARM BACKALARM Page 351
11 5112 3126 05 1 BRAKE LIGHT BROMSLJUS Page 353
5112 0103 90 007K

311
JUNCTION BOX / KOPPLINGSLÅDA 5112 0104 01 X2
JUNCTION BOXKOPPLINGSLÅDA
B0044364
312
(Sheet 1 of 2)
K101 5118 0899 00 1 RELAY RELÄ BOSCH 0 332 204 203
W182 5112 3217 13 1 WIRING KABLAGE
W187 0017 2060 70 6M CABLE, 1-CORE KABEL, 1-LEDARE RK 6MM2 BLACK D2=4.8
6MM BLACK
W187 3176 0050 31 2M PROTECTION HOSE SKYDDSSLANG
W188 0017 2060 40 20M CABLE, 1-CORE KABEL, 1-LEDARE RK 1,5MM2 BLACK D1=3.5
W188 0017 2060 50 6M CABLE, 1-CORE KABEL, 1-LEDARE RK 2,5 MM2 BLACK D1=4.2
2,5MM BLACK
6MM BLACK
W188 5112 1579 00 5M PROTECTION COIL SKYDDSSPIRAL
2,5MM BLACK
W189 3176 0050 35 3.50M PROTECTION HOSE SKYDDSSLANG
W189 3176 0050 44 1 ADAPTER FÖRSKRUVNING BVAD-M329GT
W189 5112 1758 00 1 SLEEVE INSERT HYLSINSATS
W189 9111 0020 30 1 CABLE GEAR KABELDON SIDE-ENTRY,M32,WITHOUT STEM
2,5MM BLACK
6MM BLACK
W51 9111 3891 13 5M CABLE, 7-CORE KABEL, 7-LEDARE 7X1,5MM2
1 0160 6061 00 2 SCREW, SLOTTED SPÅRSKRUV M 5 X 14 - 4.8 FZB
3 9139 6004 56 4 FLAT PIN SLEEVE FLATSTIFTSHYLSA D 6,3- 0,5-1,5 MM2
4 1088 0004 09 1 FLAT PIN SLEEVE FLATSTIFTSHYLSA C 6,3- 1 T 70
5112 0104 01 012K

313
JUNCTION BOX / KOPPLINGSLÅDA 5112 0104 01
(Sheet 2 of 2)
5 – 1 ADAPTER FÖRSKRUVNING BVWD-M329GT
M32X1,5 A3
7 – 3 ELBOW LEADING VINKELINFÖRING
M20X1,5 7-13 B1
9 3176 0050 43 4 ADAPTER FÖRSKRUVNING BVWD-M207GT
10 3176 0050 42 3 ADAPTER FÖRSKRUVNING BVND-M207GT
13 0226 0326 00 4 TAPPING SCREW GÄNGANDE SKRUV M6SF M 5 X 10 - 8.8 FZB
M6SF M 5 X 10 - 8.8 FZB
14 0346 1002 03 4 PIPE CLAMP RÖRKLAMMA D=12 NORMA TYP RSGU
D=12 NORMA TYP RSGU
B0044364
314
5112 0104 01 012K

315
B0037051
316

2 3176 4363 08 0.26M MOUNTING RAIL MONTERINGSSKENA TS35 X 7.5 E29 208 07
3 0160 1244 00 2 SCREW, SLOTTED SPÅRSKRUV M 6 X 12 - 4.8
7 3176 4049 51 2 END SUPPORT ÄNDSTÖD TERMINAL MODULE
8 3176 4049 00 20 TERMINAL BLOCK KOPPLINGSPLINT ZDU 2.5/4AN
9 3176 4049 01 1 END PLATE ÄNDPLATTA FOR ZDU 2,5/4A
10 3176 4049 11 12 TERMINAL BLOCK KOPPLINGSPLINT
11 3176 4049 12 4 END PLATE ÄNDPLATTA
12 3176 4049 13 4 BRIDGE CONN. ÖVERKOPPL.BLECK
13 3176 4491 01 1 MARKING PLATE MÄRKSKYLT 5FW 1-50
1-50
TERMINAL MARKERS
14 3176 4049 61 1 MARKING PLATE MÄRKSKYLT HORIZSONTAL PLINTH 5X5MM
15 5112 3043 10 1 FUSE CON. TERM. SÄKRINGSPLINT
17 5112 3043 16 1 FUSE SÄKRING 15A FLAT PIN
18 0017 2060 70 0.25M CABLE, 1-CORE KABEL, 1-LEDARE RK 6MM2 BLACK D2=4.8
6MM BLACK
19 0017 2060 40 0.25M CABLE, 1-CORE KABEL, 1-LEDARE RK 1,5MM2 BLACK D1=3.5
20 5112 2216 04 1 EARTH TERMINAL JORDPLINT
21 0226 0351 07 1 TAPPING SCREW GÄNGANDE SKRUV C M 5 12
22 – 1 PLATE SKYLT
23 0129 3207 00 2 BLIND RIVET BLINDNIT 3,2 X 9 TAP / D 48 BS
24 3217 9897 01 1 DIODE UNIT DIODENHET 3A
5112 0020 41 003K

317
SWITCH PANEL / INSTRUMENTPANEL 5112 0104 04
SWITCH PANELINSTRUMENTPANEL
B0053354
318
(Sheet 1 of 3)
F111 5112 3043 15 1 FUSE SÄKRING 10A
F112 5112 3043 15 1 FUSE SÄKRING 10A
F113 5112 3043 15 1 FUSE SÄKRING 10A
F114 5112 3043 15 1 FUSE SÄKRING 10A
F115 5112 3043 15 1 FUSE SÄKRING 10A
F116 5112 3043 16 1 FUSE SÄKRING 15A FLAT PIN
F117 5112 3043 15 1 FUSE SÄKRING 10A
H201 3217 0012 05 1 INDICATION LAMP SIGNALLAMPA Page 323
K102 3217 9583 01 1 RELAY RELÄ IK 8701.12 24V DC D & S
24 VOLT 16A
K104 3176 0007 55 1 RELAY RELÄ RELAY 50A CONT 200A INRUSH
24 VOLT 16A
24 VOLT 16A
24 VOLT 16A
K148 3176 0035 27 1 TIMING RELAY TIDRELÄ
P110 – 1 HOUR METER TIMRÄKNARE Page 325 COMPLETE
P111 5112 3137 68 1 FUEL GAUGE BRÄNSLEMÄTARE COMPLETE
S137 5112 2865 00 1 GEAR CONTROL VÄXELREGLAGE
S138 3217 0012 35 1 MUSHROOM PUSHB. SVAMPTRYCKKNAPP Page 327
S139 5112 3046 92 1 IGNITION LOCK TÄNDNINGSLÅS Page 329
S157 3217 0012 58 1 PUSH BUTTON TRYCKKNAPP Page 331
5112 0104 04 009K

319
(Sheet 2 of 3)
S307 5112 3138 08 1 SWITCH STRÖMSTÄLLARE
S308 5112 3138 08 1 SWITCH STRÖMSTÄLLARE
V100 5112 3043 33 1 DIODE UNIT DIODENHET LAMPTEST MAX 7 LAMPS
U2 3176 0001 45 1 WARNING BUZZER VARNINGSSUMMER
1 – 1 PANEL PLATE PANELPLÅT
2 3176 4158 00 1 BULB GLÖDLAMPA TYP.13913.ART.1378.
4 0301 2315 00 4 PLAIN WASHER RUNDBRICKA 4,3 / 9 X 0,8 -HB 200 FZB
10 5112 2863 00 1 RELAY SHELF RELÄHYLLA
11 5112 2879 00 2 CUSHION UNDERLÄGG
13 1088 0003 01 2 FLAT PIN SLEEVE FLATSTIFTSHYLSA A 6,3-1 T 70
18 0266 2111 00 1 NUT MUTTER M 10 - 8 FZB
22 3176 4049 02 1 BRIDGE CONN. ÖVERKOPPL.BLECK 10-POL
29 5112 3043 10 7 FUSE CON. TERM. SÄKRINGSPLINT
30 5112 3043 13 1 BRIDGE CONN. ÖVERKOPPL.BLECK FUSE CON. TERM.
31 3176 4344 02 1 PIN INSERT STIFTINSATS 24-TERMINALS (1-24)
32 5112 2215 00 1 SEAL TÄTNING
B0053354
320
(Sheet 3 of 3)
34 3176 4343 01 1 HOUSING PANELBRUNN
37 0698 5140 60 5 CABLE GLAND KABELFÖRSKRUVN. M16X1,5 4,5-10 B1
38 0697 9745 71 2 REDUCER REDUCERING A3 M 20X1,5 M 16X1,5 6 15
M20X1,5 7-13 B1
42 5112 2493 00 1 PLATE SKYLT
43 5112 3045 99 1 PLATE SKYLT
44 – 1 READ INSTR.BOOK LÄS INSTR.BOK SYMBOL
50 0017 2060 70 4M CABLE, 1-CORE KABEL, 1-LEDARE RK 6MM2 BLACK D2=4.8
6MM BLACK
51 0017 2060 50 4M CABLE, 1-CORE KABEL, 1-LEDARE RK 2,5 MM2 BLACK D1=4.2
2,5MM BLACK
52 0017 2060 40 40M CABLE, 1-CORE KABEL, 1-LEDARE RK 1,5MM2 BLACK D1=3.5
5112 0104 04 009K

321
INDICATION LAMP / SIGNALLAMPA 3217 0012 05
INDICATION LAMPSIGNALLAMPA
B0025322
322
INDICATION LAMP / SIGNALLAMPA 3217 0012 05

1 3217 0010 47 1 LAMP CALOTTE LAMPKALOTT
3 3217 0010 59 1 LAMP INSERT LAMPINSATS
3217 0012 05 002K

323
HOUR METER / TIMRÄKNARE COMPLETE
HOUR METERTIMRÄKNARE
X0000000
324
HOUR METER / TIMRÄKNARE COMPLETE

1 3176 0026 14 1 HOUR METER TIMRÄKNARE
5112 3137 79 005K

325
MUSHROOM PUSHB. / SVAMPTRYCKKNAPP 3217 0012 35
MUSHROOM PUSHB.SVAMPTRYCKKNAPP
B0025617
326
MUSHROOM PUSHB. / SVAMPTRYCKKNAPP 3217 0012 35

1 3217 0011 07 1 MUSHROOM PUSHB. SVAMPTRYCKE PULL-REL.MUSHROOM BUTTON
4 3217 0010 74 1 CONTACT BLOCK KONTAKTBLOCK NORMALLY CLOSED
3217 0012 35 002K

327
IGNITION LOCK / TÄNDNINGSLÅS 5112 3046 92
IGNITION LOCKTÄNDNINGSLÅS
B0028131
328
IGNITION LOCK / TÄNDNINGSLÅS 5112 3046 92

1 5112 3046 72 1 IGNITION LOCK TÄNDNINGSLÅS INCL.2 KEYS
2 5112 3046 73 2 IGNITON KEY STARTNYCKEL
3 5112 3046 91 4 FLAT PIN SLEEVE FLATSTIFTSHYLSA
5112 3046 92 002K

329
PUSH BUTTON / TRYCKKNAPP 3217 0012 58
PUSH BUTTONTRYCKKNAPP
B0025809
330

1 3217 0010 06 1 TRIGGER TRYCKE
4 3217 0010 75 1 SEALING COVER TÄTNINGSKÅPA
3217 0012 58 002K

331
PUSH BUTTONTRYCKKNAPP
B0025807
332

1 3217 0010 02 1 TRIGGER TRYCKE ZB5-AA2
3217 0012 00 002K

333
B0057625
334

8 3214 0181 00 0.15M MOUNTING RAIL MONTERINGSSKENA
14 3176 4049 52 2 END SUPPORT ÄNDSTÖD
16 0697 9810 54 1 END PLUG AVSLUTN.PROPP M 20X1,5 BLACK A5
5112 0105 48 006K

335
B0052269
336

16 0697 9810 54 2 END PLUG AVSLUTN.PROPP M 20X1,5 BLACK A5
5112 0105 50 005K

337
EL EQUIPM.MOTOR / ELUTRUSTN.MOTOR 5112 0104 17
EL EQUIPM.MOTORELUTRUSTN.MOTOR
B0041735
338
(Sheet 1 of 2)
B355 5112 3021 88 1 PRESSURE SWITCH TRYCKVAKT 1/8'THREAD CLOSES AT 12BAR
B356 5112 3022 93 1 PRESSURE SWITCH TRYCKVAKT CUT-OFF AT 4.2 BAR 1/8'THREAD
B357 5112 3021 86 1 THERMOSTAT TEMPERATURVAKT
F100 3216 1531 00 1 FUSE SÄKRING 25A
F101 3176 4394 00 2 FUSE SÄKRING 50A
G100 0926 5051 00 2 BATTERY BATTERI 12V 70AH TERMINAL
12V 70AH TERMINAL
G100 5112 2368 00 1 CABLE COMPLETE KABEL KOMPLETT G100
S300 3176 0026 97 1 BATTERY SWITCH BATTERIFR.SKILJ
W501 5112 0105 41 1 CABLE COMPLETE KABEL KOMPLETT
W502 5112 3030 99 1 CABLE COMPLETE KABEL KOMPLETT
W533 5112 2088 00 1 CABLE COMPLETE KABEL KOMPLETT W533
W534 5112 3021 78 1 CABLE COMPLETE KABEL KOMPLETT W534
A37 5112 3177 03 1 FUSE BOX SÄKRINGSLÅDA
2 3176 1942 00 1 NIPPLE NIPPEL UNF 9/16 - NPTF 1/8
UNF 9/16-NPTF 1/8 STRAIGHT
5 0653 1174 00 1 GASKET PACKNING 30 / 38 X 2 - 11 5013 12
MC6S M5X20-5.8 FZB
9 4310 0464 00 1M PLAST.,ST.CABLE PLAST,STÅLLINA
10 4330 1016 00 2 BULLDOG GRIP LINLÅS
11 5118 0904 00 1 RUBBER PROTEC GUMMISKYDD RUBBER PROTEC.4N
16 0333 3137 00 2 LOCK WASHER LÅSBRICKA 13 / 20,5 X 1 DIN 6798
5112 0104 17 009K

339
(Sheet 2 of 2)
21 3176 0050 42 2 ADAPTER FÖRSKRUVNING BVND-M207GT
22 5112 2216 00 1 GROUND BRAID JORDFLÄTA
25 0333 3132 00 2 LOCK WASHER LÅSBRICKA 10,5 / 18 X 0,9 DIN 6798
B0041735
340
5112 0104 17 009K

341
DRIVING LIGHT. / ÅKBELYSNING 5112 0104 09 8 X 70W
DRIVING LIGHT.ÅKBELYSNING
B0044370
342
DRIVING LIGHT. / ÅKBELYSNING 5112 0104 09 8 X 70W

E101 5112 3043 40 2 HEADLIGHT STRÅLKASTARE Page 345
E101 9111 3891 44 10M CABLE, 2-CORE KABEL, 2-LEDARE 2X1.5 D2=7.4
E103 5112 3134 78 2 WIRING KABLAGE DT06-2S-E008+5M CABLE
E103 5112 3134 81 2 HEADLIGHT STRÅLKASTARE Page 347 NORDIC 100 24V
E104 5112 3134 78 2 WIRING KABLAGE DT06-2S-E008+5M CABLE
E104 5112 3134 81 2 HEADLIGHT STRÅLKASTARE Page 347 NORDIC 100 24V
X12 5112 3217 81 1 JUNCTION BOX KOPPLINGSLÅDA Page 349
RUBBER-COVERED
D=12 NORMA TYP RSGU
5112 0104 09 001K

343
HEADLIGHT / STRÅLKASTARE 5112 3043 40
HEADLIGHTSTRÅLKASTARE
B0048346
344

1 3176 4494 00 1 BULB GLÖDLAMPA H3 70W 24V
3 0300 8005 00 1 PLAIN WASHER RUNDBRICKA 9 / 25 X 1,5 - FZB
5112 3043 40 004K

345
HEADLIGHT / STRÅLKASTARE 5112 3134 81 NORDIC 100 24V
B0048346
346
HEADLIGHT / STRÅLKASTARE 5112 3134 81 NORDIC 100 24V

5112 3134 81 003K

347
B0040032
348

1-50
TERMINAL MARKERS
5112 3217 81 003K

349
REVERSE ALARM / BACKALARM
REVERSE ALARMBACKALARM
B0029729
350
REVERSE ALARM / BACKALARM

1 3176 0001 45 1 WARNING BUZZER VARNINGSSUMMER
M20X1,5 7-13 B1
9110 9994 69 007K

351
BRAKE LIGHT / BROMSLJUS 5112 3126 05
BRAKE LIGHTBROMSLJUS
B0043320
352
BRAKE LIGHT / BROMSLJUS 5112 3126 05

1 5112 3124 73 2 BRAKE LIGHT BROMSLJUS
2 5112 3125 40 2 BULB GLÖDLAMPA 24V 21W BA15S
3 9111 3891 44 10M CABLE, 2-CORE KABEL, 2-LEDARE 2X1.5 D2=7.4
4 0698 5205 00 1 JUNCTION BOX KOPPLINGSDOSA 3XPG11-PR18,6 77X90MM
9 5112 2877 71 1 PRESSURE SWITCH TRYCKVAKT 5BAR M12X1,5/M16X1,5
5112 3126 05 005K

353
DIESEL ENG.UNIT / DIESELMOT.ENHET
DIESEL ENG.UNITDIESELMOT.ENHET
B0044371
354

1 – 1 DIESEL ENG.UNIT DIESELMOT.ENHET Page 357
5 0147 1403 09 8 SCREW, HEX HEAD SKRUV, SEXKANT M 12 X 40 - 8.8 FZV
8 0144 4000 32 12 SCREW, HEX HEAD SKRUV, SEXKANT UNF 3/8 X 45 - 10.9
9 5112 3020 94 1 CARDAN SHAFT KARDANAXEL Page 375
10 5112 3001 59 1 FLANGE SCR.SET FLÄNS.SKRUVSATS
11 5112 3216 64 1 HYDR.TRANSMISS. HYDR.TRANSMISS Page 377
15 5112 3041 80 1 FILLER SET PÅFYLLNINGSSATS Page 381 CLARK 12000
16 5112 3102 99 1 LEVEL GLASS NIVÅGLAS Page 383
5112 3238 22 001K

355
DIESEL ENG.UNITDIESELMOT.ENHET
B0061231
356

1 5112 3238 04 1 DIESEL ENGINE DIESELMOTOR Page 359
2 5112 3231 95 1 AIR FILTER SET LUFTFILTERSATS Page 361
3 5112 3231 60 1 AIR INLET LUFTINTAG Page 365
4 5112 3231 45 1 THROTTLE CONTR. GASREGLAGE Page 367
5 5112 3228 68 1 CABLE HOLDER KABELHÅLLARE Page 371
6 5112 3231 71 1 DRAINAGE AVTAPPNING Page 373
7 5112 3231 73 1 SPACER SLEEVE DISTANSHYLSA
5112 3238 23 001K

357
DIESEL ENGINE / DIESELMOTOR 5112 3238 04
DIESEL ENGINEDIESELMOTOR
B0045110
358
DIESEL ENGINE / DIESELMOTOR 5112 3238 04

1 3177 0002 17 1 OIL PLUG OLJEPLUGG
2 5500 3057 00 1 SEAL WASHER TÄTNINGSBRICKA
3 5112 3007 59 1 OIL FILTER OLJEFILTER
4 5580 0041 28 1 FUEL FILTER BRÄNSLEFILTER
6 5112 3007 09 1 FAN BELT FLÄKTREM
7 5112 3226 17 1 V-BELT KILREM
8 3177 0002 19 1 GENERATOR GENERATOR
9 5112 3101 59 1 STARTER STARTMOTOR STARTER
10 5112 3226 16 1 FILTER FILTER SET OF PARTS
11 9106 3207 43 4 MOTOR BRACKET MOTORFÄSTE NOT SHOWN
5112 3238 04 002K

359
AIR FILTER SET / LUFTFILTERSATS 5112 3231 95
AIR FILTER SETLUFTFILTERSATS
B0044538
360
AIR FILTER SET / LUFTFILTERSATS 5112 3231 95

1 5112 3052 41 1 AIR FILTER LUFTFILTER Page 363
3 5112 3052 46 1 FILT.INDICATOR FILTERINDIKATOR
4 5112 3231 96 1 INTAKE HOSE INSUGNINGSSLANG
5 5112 3231 93 1 INLET PORT INSUGNINGSRÖR
6 0347 6100 22 2 HOSE CLIP SLANGKLÄMMA B 82 105 15,8 - - - -
7 0347 6100 21 1 HOSE CLIP SLANGKLÄMMA B 70 92 15,8 - - - -
B 70 92 15,8
5112 3231 95 001K

361
AIR FILTER / LUFTFILTER 5112 3052 41
AIR FILTERLUFTFILTER
B0050454
362
AIR FILTER / LUFTFILTER 5112 3052 41

1 5112 3052 43 1 SAFETY CARTR. SÄKERHETSPATRON
2 5112 3052 42 1 FILTER ELEMENT FILTERELEMENT
5112 3052 41 004K

363
AIR INLET / LUFTINTAG 5112 3231 60
AIR INLETLUFTINTAG
B0044376
364
AIR INLET / LUFTINTAG 5112 3231 60

2 5112 3231 50 1 AIR INLET LUFTINTAG
5 1030 1005 03 4 HOSE CLIP SLANGKLÄMMA A 254 280 12,2 - STEEL FZ
5112 3231 60 002K

365
THROTTLE CONTR. / GASREGLAGE 5112 3231 45
THROTTLE CONTR.GASREGLAGE
B0044377
366
THROTTLE CONTR. / GASREGLAGE 5112 3231 45

1 – 1 THROTTLE CONTR. GASREGLAGE Page 369
2 5112 2943 00 1 PEDAL PEDAL
5112 3231 45 002K

367
THROTTLE CONTR. / GASREGLAGE
THROTTLE CONTR.GASREGLAGE
B0044378
368
THROTTLE CONTR. / GASREGLAGE

1 5112 3040 69 1 THROTTLE WIRE GASWIRE
2 5112 3217 46 1 CONTROL ATTM. REGLAGEFÄSTE
3 5112 1886 00 1 BOLT SET BULTSATS
4 5112 3217 49 1 ACCELERATOR GASPÅDRAG
6 5118 0910 00 1 LINK ROD HEAD LÄNKSTÅNGSHUVUD ROD TO HOOD RELEASE
5112 3231 88 002K

369
CABLE HOLDER / KABELHÅLLARE 5112 3228 68
CABLE HOLDERKABELHÅLLARE
B0047060
370
CABLE HOLDER / KABELHÅLLARE 5112 3228 68

5112 3228 68 001K

371
DRAINAGE / AVTAPPNING 5112 3231 71
DRAINAGEAVTAPPNING
B0044379
372
DRAINAGE / AVTAPPNING 5112 3231 71

1 0627 4224 03 1 PRESSURE SCREW TRYCKSKRUV 28 M 30 X 1,5 13 A 58 51
3 5112 3231 69 1 HOSE SLANG
5 3455 0543 06 1 NIPPLE NIPPEL UN 1 1/16
6 3715 0820 00 1 CAP HUV UN 1 1/16
5112 3231 71 001K

373
CARDAN SHAFT / KARDANAXEL 5112 3020 94
CARDAN SHAFTKARDANAXEL
B0052675
374

2 5112 3102 71 1 TRUNNION BLOCK KNUTKORS
4 5112 3102 81 1 FLANGE FORK FLÄNSGAFFEL
5 5112 3102 86 1 SPAT DAMASK
6 5112 3102 85 1 CLAMP KLAMMER
7 5112 3102 84 1 BALL KULA
9 5112 3149 72 1 SET SATS
5112 3020 94 003K

375
HYDR.TRANSMISS. / HYDR.TRANSMISS 5112 3216 64
HYDR.TRANSMISS.HYDR.TRANSMISS
B0032653
376
HYDR.TRANSMISS. / HYDR.TRANSMISS 5112 3216 64

1 5112 3024 98 1 FILTER FILTER
5112 3216 64 006K

377
B0001671
378

2 5112 3102 77 2 GREASE NIPPLE SMÖRJNIPPEL
4 5112 3102 78 1 GREASE NIPPLE SMÖRJNIPPEL
5112 3020 93 002K

379
FILLER SET / PÅFYLLNINGSSATS 5112 3041 80 CLARK 12000
FILLER SETPÅFYLLNINGSSATS
B0004951
380
FILLER SET / PÅFYLLNINGSSATS 5112 3041 80 CLARK 12000

1 5112 3111 75 1 CONNECTION ANSLUTNING
3 3176 6550 00 1 ELBOW RÖRVINKEL UN 1 1/16
4 3176 6499 00 1 NIPPLE NIPPEL UN 1 1/16
6 3715 0820 00 1 CAP HUV UN 1 1/16
5112 3041 80 003K

381
LEVEL GLASS / NIVÅGLAS 5112 3102 99
LEVEL GLASSNIVÅGLAS
B0003047
382
LEVEL GLASS / NIVÅGLAS 5112 3102 99

1 5112 3038 12 1 HOUSE HUS
2 5112 3038 13 2 SCREW SKRUV
3 0653 1057 00 5 GASKET PACKNING 12 17 1,5 A
4 5112 3103 12 1 OIL LEVEL GLASS OLJESTÅNDSGLAS
5112 3102 99 002K

383
FUEL SYSTEM / BRÄNSLESYSTEM
FUEL SYSTEMBRÄNSLESYSTEM
B0044380
384
FUEL SYSTEM / BRÄNSLESYSTEM

1 0627 4209 00 1 PRESSURE SCREW TRYCKSKRUV M14 X 1,5 OXSV
3 5112 3231 86 1 FUEL HOSE BRÄNSLESLANG
9 5112 3231 87 1 FUEL HOSE BRÄNSLESLANG
5112 3231 14 003K

385
PLATFORM COMPL. / PLATTFORM KOMPL
PLATFORM COMPL.PLATTFORM KOMPL
B0003448
386
PLATFORM COMPL. / PLATTFORM KOMPL

1 5112 2425 00 1M EDGE LIST KANTLIST
2 – 1 PROTECT. SHIELD SKYDDSPLÅT
3 5112 2021 00 1 FLOOR RACK GOLVTRALL
6 5112 2447 00 1 YOKE BYGEL
9 5112 2320 00 1 PLATFORM PLATTFORM
11 5112 2322 00 4 DAMPER DÄMPARE NOVIBRA RA125EM-HARDN. A
12 9110 8336 00 2 STEP TRAPPSTEG
13 9110 8818 01 4 STRINGER VANGSTYCKE
14 9110 8351 00 4 WASHER BRICKA
15 9110 8352 00 4 WASHER BRICKA
5112 3021 59 005K

387
LUBR. SYSTEM / SMÖRJSYSTEM
LUBR. SYSTEMSMÖRJSYSTEM
B0000847
388
LUBR. SYSTEM / SMÖRJSYSTEM

1 5112 2163 80 1 LUBR. VALVE SMÖRJVENTIL Page 391
2 0544 2562 00 1 GREASE NIPPLE SMÖRJNIPPEL CH KR 1/8 SMS 1586
5 0580 2202 00 6 PIPE COUPLING RÖRKOPPLING D=6; ISO 7-R 1/8; 90 DEG.
PR.WORK 250 BA
8 5112 2164 00 8M HIGH POWER PIPE HÖGTR.PLASTRÖR D= 6/3 MM
5112 3021 66 002K

389
LUBR. VALVE / SMÖRJVENTIL 5112 2163 80
LUBR. VALVESMÖRJVENTIL
B0000157
390
LUBR. VALVE / SMÖRJVENTIL 5112 2163 80

1 3128 3005 38 6 CUTTING RING SKÄRRING
2 0580 0013 11 6 PIPE COUPLING RÖRKOPPLING 6 - M 10X1 GE 6 - LLM
4 3128 3005 37 1 PLUG PROPP
5 5112 2163 00 1 VALVE HOUSING VENTILHUS
5112 2163 80 003K

391
FRAME BOOM PART / RAM BOMDEL
FRAME BOOM PARTRAM BOMDEL
B0025396
392
(Sheet 1 of 2)
1 5112 3021 00 1 FRAME RAM
2 5112 2325 00 2 WAIST SHAFT MIDJEAXEL
3 0333 6113 00 2 LOCK WASHER LÅSBRICKA 60 / 73 X 1,5
4 0295 3113 00 2 LOCK NUT LÅSMUTTER M 60X2 - KM 12 - 11 0727
8 5112 2326 00 2 SHAFT AXEL
15 5112 2404 00 2 DAMPER BIT MOTLÄGG
19 5112 2403 00 2 FENDER STÄNKSKYDD
26 5112 3000 38 1 CARDAN PROTECT. KARDANSKYDD
36 5112 3021 84 1 DRIVE AXLE DRIVAXEL Page 399
5112 3230 68 003K

393
(Sheet 2 of 2)
48 3217 6814 00 2 SHAFT AXEL
50 5112 2363 00 2 SHAFT AXEL
51 5112 2360 80 2 HYDR. CYLINDER HYDRAULCYLINDER Page 403 HC09-K63-32K-400-A37
52 5112 3022 87 2 JACK TUBE DOMKRAFTRÖR
B0025396
394
5112 3230 68 003K

395
B0001672
396

1 0502 8010 21 1 BEARING HOUSING LAGERHUS SNH 209 TA
2 0503 2109 00 1 BALL BEARING KULLAGER 2209 ETN9
3 5112 3109 23 1 COUNTER FLANGE MOTFLÄNS
5 5112 3102 80 1 NUT MUTTER
5112 3020 95 002K

397
DRIVE AXLEDRIVAXEL
B0024996
398

5112 3024 66 1 BRAKE DISC KIT BROMSLAMELLSATS Page 291 COMPLETE KIT ONLY
5112 3024 68 1 CROWN WHEEL KIT KRONHJULSATS Page 293 COMPLETE KIT ONLY
5112 3024 71 2 PLANET GEAR KIT PLANETHJULSSATS Page 295 COMPLETE KIT ONLY
5112 3190 18 1 DIFF.KIT DIFF.SATS Page 401 COMPLETE KIT ONLY
1 5112 3003 35 20 WHEEL BOLT HJULBULT
2 0299 1000 06 20 WHEEL NUT HJULMUTTER M 22X1,5 - 10 FOSF. TYP A
4 5112 3003 37 2 PLUG PLUGG
5 5112 3104 74 2 PLANET GEAR HO. PLANETVÄXELHUS
5112 3021 84 006K

399
DIFF.KITDIFF.SATS
B0023616
400

6 5112 3003 15 2 PIN PINNE
7 5112 3188 03 4 DIFFERENT.WHEEL DIFFERENT. HJUL
9 5112 3188 08 1 DIFF.SPIDER DIFF.KORS
10 5112 3003 77 3 PIN PINNE
11 5112 3188 09 1 SHAFT AXEL
12 5112 3190 14 2 SIDE WHEEL SIDOHJUL
13 5112 3003 10 2 FRICTION RING FRIKTIONSRING
14 5112 3190 15 8 BOLT BULT
31 5112 3190 16 1 COVER LOCK
32 5112 3190 17 1 DIFF.CASE DIFF.HUS
5112 3190 18 004K

401
B0001037
402

9120 0990 08 1 SEAL KIT TÄTNINGSSATS INCL.2,7-12
9120 0990 20 1 SEAL KIT TÄTNINGSSATS INCL.17,18
3 9124 9565 00 1 PISTON KOLV
4 9123 3553 00 1 CYLINDER COVER CYLINDERLOCK
6 0501 0014 00 2 BEARING,SP.PL. LEDLAGER 30 / 47 X 40,7
7 0665 0020 18 1 PISTON SEAL KOLVTÄTNING SKEGA 63 / 47 / 51 7045
11 0665 0010 12 1 SEAL RING TÄTNINGSRING A1 32 40
13 0686 6442 00 2 PLUG PROPP G 1/4 TYPE B - STEEL 5.8
TREDO 1/4
16 0686 3103 00 2 PLUG PROPP KR 3/8 - 11 0815 00
18 9128 6998 00 1 SLIDE SLID
5112 2360 80 004K

403
CHECK VALVEBACKVENTIL
B0001976
404

3128 2099 55 002K

405
DRIVERS PLATF. / FÖRARPLATTFORM 5112 3134 38
DRIVERS PLATF.FÖRARPLATTFORM
B0000260
406
DRIVERS PLATF. / FÖRARPLATTFORM 5112 3134 38

1 5112 3133 98 1 DRIVERS PLATF. FÖRARPLATTFORM
5 5112 3152 91 1 COVER LOCK
5112 3134 38 002K

407
CHAIR COMPL. / STOL KOMPL.
CHAIR COMPL.STOL KOMPL.
B0042936
408
CHAIR COMPL. / STOL KOMPL.

5 5112 0007 80 1 CHAIR COMPL. STOL KOMPL. Page 411
6 5112 3021 20 1 CHAIR SUPPORT STOLSTATIV
5112 3025 85 005K

409
CHAIR COMPL. / STOL KOMPL. 5112 0007 80
CHAIR COMPL.STOL KOMPL.
B0038276
410
CHAIR COMPL. / STOL KOMPL. 5112 0007 80

1 5112 0105 24 1 DRIVERS CHAIR FÖRARSTOL
2 5112 0007 77 1 SAFETY BELT SÄKERHETSBÄLTE
5112 0007 80 002K

411
HYDR. SYSTEM / HYDRAULSYSTEM 5112 2877 19 OIL COOLER
B0001214
412
HYDR. SYSTEM / HYDRAULSYSTEM 5112 2877 19 OIL COOLER

5112 2877 19 003K

413
EXHAUST SYSTEM / AVGASSYSTEM 5112 3231 28
EXHAUST SYSTEMAVGASSYSTEM
B0044381
414
EXHAUST SYSTEM / AVGASSYSTEM 5112 3231 28

1 5112 3232 52 1 CATALYSER KATALYSATOR Page 417
2 – 1 SILENCER LJUDDÄMPARE Page 419
3 5112 3231 35 1 EXHAUST HOSE AVGASSLANG
4 0347 4676 00 2 HOSE CLIP SLANGKLÄMMA D=80 NORMA TYP SK
6 0211 1964 35 3 HEX SOCK. SCREW SEXKANTHÅLSKRUV SKRUV
7 5112 3231 37 3 LOCK NUT LÅSMUTTER
5112 3231 28 003K

415
CATALYSER / KATALYSATOR 5112 3232 52
CATALYSERKATALYSATOR
B0046528
416
CATALYSER / KATALYSATOR 5112 3232 52

1 5112 3231 32 1 OUTLET UTLOPP
2 5112 3202 38 2 CLAMP KLAMMA
4 5112 3202 39 1 CATALYSER KATALYSATOR
5 5112 3231 31 1 INLET INLOPP
6 5112 3232 48 1 RESTR. WASHER STRYPBRICKA
5112 3232 52 001K

417
SILENCER / LJUDDÄMPARE
SILENCERLJUDDÄMPARE
B0002205
418
SILENCER / LJUDDÄMPARE

1 5112 2051 00 1 SILENCER LJUDDÄMPARE
2 5112 3231 33 1 INLET INLOPP
6 5112 2579 00 2 BAND BAND
9 5112 3102 48 1 EXHAUST BEND AVGASKRÖK
5112 3231 30 001K

419
SET OF WHEELS / HJULSATS 5112 3235 27
SET OF WHEELSHJULSATS
B0050481
420
SET OF WHEELS / HJULSATS 5112 3235 27

1 5112 3223 56 2 WHEEL COMPL. HJUL KOMPL. Page 423 SOLIDEAL 12.0X20/20 LAGER
2 5112 3302 52 2 ASSEMBLY SET MONTERINGSSATS Page 427 WHEEL NUT AND WASHER
5112 3235 27 001K

421
WHEEL COMPL. / HJUL KOMPL. 5112 3223 56
WHEEL COMPL.HJUL KOMPL.
B0025808
422
WHEEL COMPL. / HJUL KOMPL. 5112 3223 56

1 5112 2335 80 1 RIM COMPL. FÄLG KOMPL. Page 425
5112 3223 56 001K

423
RIM COMPL. / FÄLG KOMPL. 5112 2335 80
RIM COMPL.FÄLG KOMPL.
B0002326
424
RIM COMPL. / FÄLG KOMPL. 5112 2335 80

1 – 1 RIM FÄLG
2 5112 2335 08 1 RIM COLLAR FÄLGHORN
3 5112 2335 10 1 RING RING
5112 2335 80 007K

425
ASSEMBLY SET / MONTERINGSSATS 5112 3302 52 WHEEL NUT AND WASHER
B0050482
426
ASSEMBLY SET / MONTERINGSSATS 5112 3302 52 WHEEL NUT AND WASHER

1 0333 0500 24 10 SPERIC WASHER SFÄRISK BRICKA D - 22,5 34 24 18 - 8 - S
2 0299 1000 10 10 WHEEL NUT HJULMUTTER B M22X1,5 36 22 6 30 10 G
5112 3302 52 003K

427
GUIDE UNIT / STYRENHET
GUIDE UNITSTYRENHET
B0044383
428
GUIDE UNIT / STYRENHET

1 5112 3025 20 1 CONTROL PANEL MANÖVERPULPET Page 431
2 5112 3025 14 1 STEERING SYSTEM STYRSYSTEM Page 433
10 0147 1252 03 2 SCREW, HEX HEAD SKRUV, SEXKANT
11 5112 3024 99 1 ANGLE POINTER VINKELVISARE Page 435
5112 3231 27 002K

429
CONTROL PANEL / MANÖVERPULPET 5112 3025 20
CONTROL PANELMANÖVERPULPET
B0001049
430
CONTROL PANEL / MANÖVERPULPET 5112 3025 20

1 5112 3024 33 1 CONTROL PANEL MANÖVERPULPET
3 – 1 VALVE ATTM. VENTILFÄSTE
4 5112 3021 07 1 COVER LOCK
5 0296 1110 00 2 WING NUT VINGMUTTER M 8-4
5112 3025 20 009K

431
STEERING SYSTEM / STYRSYSTEM 5112 3025 14
STEERING SYSTEMSTYRSYSTEM
B0001047
432
STEERING SYSTEM / STYRSYSTEM 5112 3025 14

1 5112 2350 15 1 STEERING KPL RATT KPL
3 0266 1115 04 1 NUT MUTTER M 18X1,5 - 12 (DIN 934)
4 5112 2336 00 1 CLAMP KLAMMER
5 5112 2349 80 1 STEERING SHANK RATTSTAM
7 5112 2337 00 1 ANGLE BRACKET FÄSTVINKEL
8 5112 2185 00 1 CUSHION UNDERLÄGG
9 5112 2348 93 1 ASSEMBLY SET MONTERINGSSATS
5112 3025 14 005K

433
ANGLE POINTER / VINKELVISARE 5112 3024 99
ANGLE POINTERVINKELVISARE
B0009454
434
ANGLE POINTER / VINKELVISARE 5112 3024 99

4 – 1 HOLDER HÅLLARE
5 5112 3102 43 2 ANGLE POINTER VINKELVISARE
6 – 1 READ INSTR.BOOK LÄS INSTR.BOK SYMBOL
7 9106 1073 21 1 TIPP. HAZ. DOWN TIPPRISK NEDFÖR
5112 3024 99 003K

435
SUPPORT LEG / STÖDBEN 9110 8551 00
SUPPORT LEGSTÖDBEN
B0047796
436
SUPPORT LEG / STÖDBEN 9110 8551 00

1 9121 5913 01 1 HYDR. CYLINDER HYDRAULCYLINDER Page 439 SUPPORT LEG
BSJ 10-40
2 9106 1804 77 2 COVER PLUG TÄCKPLUGG 055 0143 000 03
5 9110 8967 00 1 FOOT PLATE FOTPLATTA
9110 8551 00 003K

437
HYDR. CYLINDER / HYDRAULCYLINDER 9121 5913 01 SUPPORT LEG %% BSJ 10-40
B0035372
438
HYDR. CYLINDER / HYDRAULCYLINDER 9121 5913 01 SUPPORT LEG %% BSJ 10-40

9120 0990 20 1 SEAL KIT TÄTNINGSSATS REF. 9-12
9121 5913 50 1 SEAL KIT TÄTNINGSSATS REF. 1-8
2 0665 1000 46 1 SEAL TÄTNING 80 / 90 X 12 94 AU/925
6 0665 0800 21 1 PISTON SEAL KOLVTÄTNING 85 / 100 X 19,5 NBR
7 0665 9300 46 1 GUIDE RING, EXT STYRRING, UTV. PWR 100 / 94 X 25
8 0194 1320 00 1 SET SCREW STOPPSKRUV M 8 X 12 S6SS DIN 914
9 9128 7076 00 1 PISTON KOLV
14 – 1 CYLINDER CYLINDER
16 9126 2012 00 1 PISTON KOLV
17 9126 2011 00 1 COVER LOCK
9121 5913 01 004K

439
PROTECTION ROOF / SKYDDSTAK
PROTECTION ROOFSKYDDSTAK
B0060979
440
PROTECTION ROOF / SKYDDSTAK

1 9110 6736 00 2 INNER TUBE INNERRÖR
3 – 1 PROTECTION ROOF SKYDDSTAK
4 0108 3392 00 2 SPRING PIN SPÄNNSTIFT 10 X 40 DIN 7343
6 0304 1012 00 4 SPERIC WASHER SFÄRISK BRICKA 23,2 / 36 X 7,5 -DIN 6319
7 0304 1062 00 4 SPERIC WASHER SFÄRISK BRICKA 21 / 36 X 6,3 - DIN 6319
11 3217 6993 00 4 SCREW SKRUV
12 9110 8324 00 4 NIPPLE NIPPEL UNF 9/16-R 1/4
TREDO 1/4
14 9110 8772 00 2 HATCH LUCKA
9110 7438 85 004K

441
B0046923
442

9120 0990 09 1 SEALING SET PACKNINGSSATS REF.1,3,4,7-9,11
2 9123 3554 00 1 COVER LOCK
3 0665 0010 14 1 SEAL RING TÄTNINGSRING STEFA 40/50 X 10,5 S11EI
5 9126 1581 00 1 PISTON ROD KOLVSTÅNG STROKE LENGTH 700
6 9124 9565 00 1 PISTON KOLV
8 0665 0020 18 1 PISTON SEAL KOLVTÄTNING SKEGA 63 / 47 / 51 7045
9126 1580 00 003D

443
WARNING SIGNS / VARNINGSSKYLTAR
WARNING SIGNSVARNINGSSKYLTAR
B0063324
444
WARNING SIGNS / VARNINGSSKYLTAR

1 9106 1071 94 1 DATA PLATE CE DATASKYLT CE
1 9106 1071 95 1 DATA PLATE DATASKYLT DATA PLATE
3 9106 1073 02 1 ELECTRIC. SHOCK ELEKTRISK STÖT
4 9106 1073 02 1 ELECTRIC. SHOCK ELEKTRISK STÖT
5 – 1 HIGH SOUND LEV. HÖG LJUDNIVÅ
6 9106 1073 21 1 TIPP. HAZ. DOWN TIPPRISK NEDFÖR
8 9106 1073 11 2 TIPPING HAZ. DR TIPPRISK BORRN.
12 9106 1073 05 6 RISK OF CRUSH. KLÄMRISK
15 9106 1073 14 2 WARNING SIGN VARNINGSSKYLT
25 9106 1072 20 2 LASER RADIATION LASERSTRÅLNING SWEDISH TEXT
25 9106 1072 21 2 LASER RADIATION LASERSTRÅLNING ENGLISH TEXT
25 – 2 LASER RADIATION LASERSTRÅLNING SPANISH TEXT
25 – 2 LASER RADIATION LASERSTRÅLNING
25 9106 1072 33 2 LASER RADIATION LASERSTRÅLNING
31 9106 1071 01 2 READ INSTR.BOOK LÄS INSTR.BOK
33 9106 1071 03 2 NO ADMITTANCE TILLTRÄDE FÖRB.
35 9106 1071 06 4 SIGN SKYLT
38 9106 1071 13 1 LABEL DEKAL HYD.OLJA/INSTR.BOK
39 9106 1071 15 1 FUEL BRÄNSLE SYMBOL 57 X 57
40 9106 1071 12 1 BATTERY SWITCH BATTERIFR.SKILJ
41 9106 1071 11 2 WELDING INSTR. SVETSINSTRUKT.
42 9106 1071 07 1 SYMBOL PLATE SYMBOLSKYLT
44 9106 1071 09 1 SYMBOL PLATE SYMBOLSKYLT
46 9106 1071 14 1 PLC CABINET PLC SKÅP
67 9106 1071 27 1 LUBRICATING OIL SMÖRJOLJA
71 9106 1071 31 2 PLATE SKYLT
72 9106 1071 32 1 PLATE SKYLT
74 8915 0021 08 1 INSTRUCTION SIG INSTRUKTIONSSKY I WATER PRESSURE WASH CON
75 8915 0026 62 1 PLATE SKYLT - FLUSHING WATER 50 50 -
9111 3982 50 008K

445
LABEL LIST / DEKALLISTA
LABEL LISTDEKALLISTA
B0007648
446
LABEL LIST / DEKALLISTA

80 9850 5009 00 2 LABEL DEKAL
81 – 2 SIGN SKYLT
82 – 2 SIGN SKYLT
83 9106 1427 01 2 SIGN SKYLT
84 9106 1427 03 2 SIGN SKYLT
85 9106 1427 05 2 SIGN SKYLT
86 9106 1427 02 2 SIGN SKYLT
87 9106 1427 03 2 SIGN SKYLT
88 9106 1427 04 2 SIGN SKYLT
89 9850 5005 00 3 LABEL DEKAL
9111 3982 51 001K

447
DRILL BIT BOX / KRONLÅDA
DRILL BIT BOXKRONLÅDA
B0046964
448
DRILL BIT BOX / KRONLÅDA

1 9106 2328 83 1 DRILL BIT BOX KRONLÅDA
6 0324 1000 14 4 SPACER SLEEVE DISTANSHYLSA 18 X 9 X 2 ZINC PLATED
7 9106 2369 04 1 PLATE PLÅT
9106 2328 84 002K

449
FIRE SUPPR.SYST / ELDBEKÄMPN.SYST 9111 4225 12
FIRE SUPPR.SYSTELDBEKÄMPN.SYST
X0000000
450
FIRE SUPPR.SYST / ELDBEKÄMPN.SYST 9111 4225 12

1 – 1 FIRE SUPPR.SYST ELDBEKÄMPN.SYST Page 453 ANSUL
2 – 1 COVER, CPL. SKYDD KOMPL. Page 465
3 5112 0107 27 1 FIRE EXTING.SET ELDSLÄCKN.SATS Page 467
9111 4225 12 001K

451
FIRE SUPPR.SYST / ELDBEKÄMPN.SYST ANSUL
FIRE SUPPR.SYSTELDBEKÄMPN.SYST
X0000000
452
FIRE SUPPR.SYST / ELDBEKÄMPN.SYST ANSUL

1 5112 3049 30 1 FIRE EXTING.SET ELDSLÄCKN.SATS Page 455 ANSUL SYSTEM
2 – 1 CONNECTION SET ANSLUTNINGSSATS Page 461 ANSUL
3 – 1 HOSE SET SLANGSATS Page 463 ANSUL
5112 3152 95 003K

453
FIRE EXTING.SET / ELDSLÄCKN.SATS 5112 3049 30 ANSUL SYSTEM
FIRE EXTING.SETELDSLÄCKN.SATS
B0054552
454
FIRE EXTING.SET / ELDSLÄCKN.SATS 5112 3049 30 ANSUL SYSTEM

1 3218 2008 28 1 TANK TANK INCL. ATTACHMENT
2 3217 9316 42 1 ATTACHMENT FÄSTE LT-A-101-30
3 5112 3171 40 1 TRIGGER UTLÖSARE
4 – 1 GAS CARTRIDGE GASPATRON
7 3217 9316 19 2 GAS CARTRIDGE GASPATRON
9 3217 9316 02 1 SAFETY VALVE SÄKERHETSVENTIL
10 3217 9316 24 2 CHECK VALVE BACKVENTIL
11 3217 9316 30 1 BRANCH BLOCK FÖRGREN.BLOCK
13 3217 9316 11 6 NOZZLE MUNSTYCKE Page 457
14 3217 9316 14 12 LOCK WASHER LÅSBRICKA
15 – 2 SEAL PLOMB Page 459
16 5112 3049 08 6 GUIDE DISC RIKTSKIVA T V-MUNSTYCKE
5112 3049 30 013K

455
NOZZLE / MUNSTYCKE 3217 9316 11
NOZZLEMUNSTYCKE
B0060308
456
NOZZLE / MUNSTYCKE 3217 9316 11

1 5112 3049 06 1 CAP HUV
3217 9316 11 003K

457
SEAL / PLOMB
SEALPLOMB
X0000000
458
SEAL / PLOMB

1 3218 2008 31 1M SEAL PLOMB
2 3218 2008 32 0.20M STEEL WIRE STÅLTRÅD
3218 2008 30 003K

459
CONNECTION SET / ANSLUTNINGSSATS ANSUL
CONNECTION SETANSLUTNINGSSATS
B0041310
460
CONNECTION SET / ANSLUTNINGSSATS ANSUL

53 3176 6562 00 1 NIPPLE NIPPEL UN 1 1/16 - NPTF 3/4
58 3177 0074 13 2 CROSSING NIPPLE ÖVERGÅNGSNIPPEL UNF 9/16 - NPTF 1/4
64 0226 0307 00 14 TAPPING SCREW GÄNGANDE SKRUV M6SF M 6 X 20 STEEL FZB
66 5500 5110 00 1 PIPE CONNECTION RÖRANSLUTNING CONNECTOR (PIPE/JIC)BULKH
T- /SVIVELNUT
5112 3152 98 005K

461
HOSE SET / SLANGSATS ANSUL
HOSE SETSLANGSATS
B0042983
462
HOSE SET / SLANGSATS ANSUL

AS1 0574 0068 08 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 5500 R1T RÖD
AS4 0574 0068 36 1 HOSE ASSEMBLY SLANGLEDNING 19 X 3400 R1T RÖD
5112 3152 94 007K

463
COVER, CPL. / SKYDD KOMPL.
COVER, CPL.SKYDD KOMPL.
B0035371
464
COVER, CPL. / SKYDD KOMPL.

9106 1923 88 001K

465
FIRE EXTING.SET / ELDSLÄCKN.SATS 5112 0107 27
FIRE EXTING.SETELDSLÄCKN.SATS
B0049691
466
FIRE EXTING.SET / ELDSLÄCKN.SATS 5112 0107 27

1 5112 0107 30 1 HOSE SET SLANGSATS Page 469
3 3217 9316 19 2 GAS CARTRIDGE GASPATRON
6 – 2 SEAL PLOMB Page 459
30 3125 2525 00 1 COLLECT. BLOCK SAMLINGSBLOCK
32 0147 1252 03 2 SCREW, HEX HEAD SKRUV, SEXKANT
34 3177 0074 13 2 CROSSING NIPPLE ÖVERGÅNGSNIPPEL UNF 9/16 - NPTF 1/4
TREDO 1/4
37 0686 6442 03 1 PLUG PROPP G 1/4 A B
42 8915 0025 73 2 INFORMATION LAB INFORMATIONSSKY I FIRE EXTINGUISHER READ
5112 0107 27 005K

467
HOSE SET / SLANGSATS 5112 0107 30
HOSE SETSLANGSATS
B0042983
468
HOSE SET / SLANGSATS 5112 0107 30

5112 0107 30 001K

469
470
CABLE REEL / KABELVINDA
LIST OF CONTENTS
– CABLE REEL KABELVINDA 473
3217 9978 19 – PLUG CONNECTOR – STICKPROPP 475
3217 9978 17 – SOCKET COUPLER – SKARVUTTAG 477 MAX 160A
3217 7835 20 – CABLE REEL – KABELVINDA 479
3217 3913 81 – – HYDRAULIC UNIT – – HYDRAULENHET 481 CABLE REEL
3217 9034 20 – – – HYDRAULIC MOTOR – – – HYDRAULMOTOR 483 INCL. POS 2, 3
3217 3909 80 – – GEAR HOUSING – – VÄXELHUS 485
9110 9554 00 – SWING ARM – SVÄNGARM 489
9110 9555 00 – – LOCKING – – LÅSNING 491
9106 1165 00 – – HASP – – HASP 493 FOR SWINGARM, EL CABINETT
9106 1165 01 – – – HASP – – – HASP 495 ARM
MOUNTED ON REAR FRAME
9110 9560 00 – CABLE STEERING – KABELSTYRNING 497
5112 3045 87 – BRAKING CHOPPER – BROMSSTYRENHET 499
5112 0000 30 – – APPARATUS PANEL – – APPARATLÅDA 501 X15
9106 1065 25 – ELECTRIC SET – ELSATS 503 PILOT CIRCUIT
471
CABLE REELKABELVINDA
B0049856
472

705 3217 9978 19 1 PLUG CONNECTOR STICKPROPP Page 475
708 3217 9978 17 1 SOCKET COUPLER SKARVUTTAG Page 477 MAX 160A
800 3217 7835 20 1 CABLE REEL KABELVINDA Page 479
805 9110 9554 00 1 SWING ARM SVÄNGARM Page 489
806 9110 9560 00 1 CABLE STEERING KABELSTYRNING Page 497
820 3217 9294 83 1 COMMUTATOR KOLLEKTOR
822 5112 3045 87 1 BRAKING CHOPPER BROMSSTYRENHET Page 499
823 9106 1065 25 1 ELECTRIC SET ELSATS Page 503 PILOT CIRCUIT
1260 5002 96 001K

473
PLUG CONNECTOR / STICKPROPP 3217 9978 19
PLUG CONNECTORSTICKPROPP
B0036828
474
PLUG CONNECTOR / STICKPROPP 3217 9978 19

14 3217 9978 24 1 INSULATOR ISOLATOR
15 3217 9978 25 4 PIN STIFT
16 3217 9978 70 4 SLEEVE HYLSA +=35MM2 PC4
17 3217 9978 27 2 PIN STIFT
18 3217 9978 67 1 SLEEVE HYLSA
3217 9978 19 003K

475
SOCKET COUPLER / SKARVUTTAG 3217 9978 17 MAX 160A
SOCKET COUPLERSKARVUTTAG
B0012627
476
SOCKET COUPLER / SKARVUTTAG 3217 9978 17 MAX 160A

16 3217 9978 13 1 INSULATOR ISOLATOR
17 3217 9978 14 3 SOCKET HYLSA
18 3217 9978 14 1 SOCKET HYLSA
19 3217 9978 70 4 SLEEVE HYLSA +=35MM2 PC4
20 3217 9978 16 2 SOCKET HYLSA
21 3217 9978 67 1 SLEEVE HYLSA
3217 9978 17 003K

477
CABLE REEL / KABELVINDA 3217 7835 20
CABLE REELKABELVINDA
B0003385
478
CABLE REEL / KABELVINDA 3217 7835 20

1 3217 5598 80 1 DRUM TRUMMA RAC 614-201
2 3217 3913 81 1 HYDRAULIC UNIT HYDRAULENHET Page 481 CABLE REEL
3 3217 3909 80 1 GEAR HOUSING VÄXELHUS Page 485
4 3176 8266 00 1 WIRE MESH HOSE KABELSTRUMPA
5 3163 1854 00 1 SHACKLE SCHACKEL
3217 7835 20 001K

479
HYDRAULIC UNIT / HYDRAULENHET 3217 3913 81 CABLE REEL
HYDRAULIC UNITHYDRAULENHET
B0003436
480
HYDRAULIC UNIT / HYDRAULENHET 3217 3913 81 CABLE REEL

1 3217 9034 20 1 HYDRAULIC MOTOR HYDRAULMOTOR Page 483 INCL. POS 2, 3
2 0666 6000 39 1 RADIAL LIP SEAL RADIALTÄTNING 20 X 35 X 8 NBR
3 3128 3061 24 1 KEY KIL
4 3217 5599 01 1 INTERMED.FLANGE MELLANFLÄNS
5 9106 1438 80 1 SET SATS INCL. POS 6, 7
7 3217 3917 02 1 KEY KIL
3217 3913 81 006K

481
B0038965
482

3218 2006 65 1 SEAL KIT TÄTNINGSSATS POS.21,26-29
3217 9034 20 004K

483
GEAR HOUSING / VÄXELHUS 3217 3909 80
GEAR HOUSINGVÄXELHUS
B0056826
484
(Sheet 1 of 2)
3217 3909 82 1 SEALING SET PACKNINGSSATS INCL.ITEM 3,6,20,21,23,25,27
AND 37
3217 3909 83 1 FRICTION KIT FRIKTIONSSATS INCL.ITEM 8,10,12,13,31
3217 3909 84 1 STAND FRAME STATIVRAM INCL.ITEM 2,22
3217 3909 85 1 BEARING SET LAGERSATS INCL.ITEM 4,16,30,32
2 – 1 END PIECE GAVEL NOT SOLD SEPARATELY
4 – 1 BEARING LAGER NOT SOLD SEPARATELY
6 – 1 GASKET PACKNING NOT SOLD SEPARATELY
8 – 1 COUPLING KOPPLING NOT SOLD SEPARATELY
9 – 1 INNER RING INNERRING NOT SOLD SEPARATELY
10 – 1 GEAR RING KUGGKRANS NOT SOLD SEPARATELY
12 – 1 SPRING HOLDER FJÄDERHÅLLARE NOT SOLD SEPARATELY
15 3217 3909 14 1 NUT MUTTER
21 – 1 GASKET PACKNING NOT SOLD SEPARATELY
26 3217 3909 22 1 SETTING KEY STÄLLNYCKEL
28 5112 0105 93 1 OIL LEVEL PLUG OLJENIVÅPLUGG
29 3217 3909 19 1 OIL PLUG OLJEPLUGG
3217 3909 80 008K

485
(Sheet 2 of 2)
33 – 1 LOCK WASHER LÅSBRICKA NOT SOLD SEPARATELY
35 3217 3909 29 1 COVER LOCK
B0056826
486
3217 3909 80 008K

487
SWING ARM / SVÄNGARM 9110 9554 00
SWING ARMSVÄNGARM
B0001278
488
SWING ARM / SVÄNGARM 9110 9554 00

1 9110 9554 10 1 SWING ARM SVÄNGARM
2 9110 9555 00 1 LOCKING LÅSNING Page 491
3 9110 6753 00 1 SHAFT AXEL
4 3217 6359 00 1 LOCK SHEET LÅSBLECK 35X6 L=80
5 0500 4500 11 2 BUSHING BUSSNING 50 / 55 X 40 WB802
14 9106 1165 00 1 HASP HASP Page 493 FOR SWINGARM, EL CABINETT
15 9106 1272 34 1 LAMP PROTECTION LAMPSKYDD
9110 9554 00 013K

489
LOCKING / LÅSNING 9110 9555 00
LOCKINGLÅSNING
B0001985
490
LOCKING / LÅSNING 9110 9555 00

2 9110 9555 02 1 CATCH SPÄRR
8 9110 9555 12 1 COMPRESS.SPRING TRYCKFJÄDER L0 61,D 2.0,DI 23,DO 27
9110 9555 00 009K

491
HASP / HASP 9106 1165 00 FOR SWINGARM, EL CABINETT
HASPHASP
B0002017
492
HASP / HASP 9106 1165 00 FOR SWINGARM, EL CABINETT

1 9106 1165 01 1 HASP HASP Page 495 ARM
MOUNTED ON REAR FRAME
9106 1165 00 002K

493
HASP / HASP 9106 1165 01 ARM %% MOUNTED ON REAR FRAME
HASPHASP
B0002012
494
HASP / HASP 9106 1165 01 ARM %% MOUNTED ON REAR FRAME

1 0111 1307 00 2 SPLIT PIN SAXPINNE 4 X 25 SP 1325 - 00
2 9106 1165 04 1 ARM ARM
4 9106 1165 03 1 SHAFT AXEL
9106 1165 01 002K

495
CABLE STEERING / KABELSTYRNING 9110 9560 00
CABLE STEERINGKABELSTYRNING
B0001605
496
CABLE STEERING / KABELSTYRNING 9110 9560 00

1 9110 6731 00 1 ROLLER HOLDER RULLHÅLLARE
2 3177 0060 01 4 ROLLER RULLE
9110 9560 00 003K

497
BRAKING CHOPPER / BROMSSTYRENHET 5112 3045 87
BRAKING CHOPPERBROMSSTYRENHET
B0012814
498
BRAKING CHOPPER / BROMSSTYRENHET 5112 3045 87

2 5112 0000 30 1 APPARATUS PANEL APPARATLÅDA Page 501 X15
4 9111 3891 13 10M CABLE, 7-CORE KABEL, 7-LEDARE 7X1,5MM2
5 9111 3891 10 10M CABLE, 5-CORE KABEL, 5-LEDARE 150 5G1.5 D2=9.8
5112 3045 87 003K

499
APPARATUS PANEL / APPARATLÅDA 5112 0000 30 X15
APPARATUS PANELAPPARATLÅDA
B0055415
500
APPARATUS PANEL / APPARATLÅDA 5112 0000 30 X15

1 5112 0000 29 1 JUNCTION BOX KOPPLINGSLÅDA
1-50
TERMINAL MARKERS
10 – 1 SIGN SKYLT
15 – 1 SIGN SKYLT
19 5112 3170 82 1 PLATE SKYLT
5112 0000 30 007K

501
ELECTRIC SET / ELSATS 9106 1065 25 PILOT CIRCUIT
ELECTRIC SETELSATS
B0030339
502
ELECTRIC SET / ELSATS 9106 1065 25 PILOT CIRCUIT

S56 3217 0010 03 1 TRIGGER TRYCKE
S56 3217 0010 72 1 INTERMED. PART MELLANDEL
S56 3217 0010 73 1 CONTACT BLOCK KONTAKTBLOCK NORMALLY OPEN
S56 3217 0010 74 1 CONTACT BLOCK KONTAKTBLOCK NORMALLY CLOSED
S59 3217 0010 72 1 INTERMED. PART MELLANDEL
S59 3217 0010 74 2 CONTACT BLOCK KONTAKTBLOCK NORMALLY CLOSED
S59 3217 0010 87 1 MUSHROOM PUSHB. SVAMPTRYCKE
V58 3217 9897 00 1 DIODE UNIT DIODENHET
Q7 9106 1125 13 1 CONTACT BLOCK KONTAKTBLOCK
9106 1065 25 006K

503
504
HYDR. SYSTEM / HYDRAULSYSTEM
LIST OF CONTENTS
– HYDR. SYSTEM HYDRAULSYSTEM 511
– – HYDRAULIC SET – HYDRAULSATS 513 EXTRACTOR
3177 3092 88 – – DIRECTION VALVE – – RIKTNINGSVENTIL 515
3177 3092 88 – – DIRECTION VALVE – – RIKTNINGSVENTIL 515
9110 8969 12 – COUPLING SET – KOPPLINGSSATS 517
3176 8502 90 – – COUPLING HALF – – KOPPLINGSHALVA 519
– – – COVER SET – – TÄCKLOCKSATS 521
9111 4213 00 – HYDR. SYSTEM – HYDRAULSYSTEM 526 HYDRAULIC SYSTEM
9106 0658 85 – – SUCT.CONNECTION – – SUGANSLUTNING 529
– – – SUCT.CONNECTION – – SUGANSLUTNING 533
9111 3469 00 – – HYDR. SET – – HYDR.SATS 535 DAMPING PISTON
– – – HYDRAULIC PUMP – – HYDRAULPUMP 537
3217 8762 00 – – – HYDRAULIC PUMP – – – HYDRAULPUMP 539 A10VO 100 CC
– – – – – PUMP – – – – PUMP 541
3217 9203 02 – – – – PILOT VALVE – – – – STYRVENTIL 543
3217 8525 00 – – – HYDRAULIC PUMP – – – HYDRAULPUMP 545
3217 9203 01 – – – – PUMP – – – – PUMP 547
3217 9203 11 – – – – – PUMP UNIT – – – – – PUMPENHET 549
3217 9203 02 – – – – PILOT VALVE – – – – STYRVENTIL 543
9111 3731 00 – – HYDRAULIC UNIT – – HYDRAULENHET 552 DRILLING ,EDS
9111 3770 00 – – – VALVE BLOCK – – – VENTILBLOCK 555
3177 3092 81 – – – – DIRECTION VALVE – – – – RIKTNINGSVENTIL 557
3217 7864 01 – – – – DIRECTION VALVE – – – – RIKTNINGSVENTIL 561 RX 4WE10E
505
– – – – – INLET SECTION – – – – INLOPPSSEKTION 565
– – – – – CONTROL UNIT – – – – MANÖVERENHET 567
– – – – – END PIECE – – – – GAVEL 569
– – – – – CONTROL UNIT – – – – MANÖVERENHET 567
– – – – – END PIECE – – – – GAVEL 569
– – – – – INLET SECTION – – – – INLOPPSSEKTION 573
9111 4213 01 – – HYDRAULIC UNIT – – HYDRAULENHET 576 POSITIONING
3217 9193 01 – – – REGULATOR – – – REGULATOR 579
3217 9773 00 – – – FLOW CONT.VALVE – – – STRYPBACKVENTIL 587 RX Z2FS6-2-4X-2Q
3176 8149 93 – – – RESTRICTION SET – – – STRYPNINGSSATS 589
3217 9341 60 – – – PRESS.RED.VALVE – – – TRYCKRED.VENTIL 591
– – – HYDRAULIC UNIT – – HYDRAULENHET 593
– – – PRES. GAUGE SET – – MANOMETERSATS 595
9111 3470 01 – – HYDR. SET – – HYDR.SATS 597 STINGER FRONT
9111 3471 01 – – HYDR. SET – – HYDR.SATS 601 STINGER REAR
9111 3516 02 – – HYDRAULIC SET – – HYDRAULSATS 603 DRILL STEEL SUPPORT,BSH 55
506
9111 3600 03 – – HYDRAULIC SET – – HYDRAULSATS 605 DIESEL POS.
9111 3603 00 – – HYDRAULIC SET – – HYDRAULSATS 607 PUMP UNLOADING
9111 3335 20 – – HYDRAULIC SET – – HYDRAULSATS 609 ROTATION DIVICE
9111 3333 01 – – HYDR. SET – – HYDR.SATS 611 TRAVERSE
9106 1609 60 – – HYDRAULIC SET – – HYDRAULSATS 613 PROTECTION ROOF
3128 2091 22 – – – – INLET SECTION – – – – INLOPPSSEKTION 619
3128 2091 02 – – – – VALVE SECTION – – – – VENTILSEKTION 621
3128 2091 24 – – – – OUTLET SECTION – – – – UTLOPPSSEKTION 623
9111 3337 00 – – HYDR. SET – – HYDR.SATS 625 JACK EXTENSION
9111 3468 00 – – HYDR. SET – – HYDR.SATS 627 FEED SWING
3176 2935 10 – – RETURN BLOCK – – RETURBLOCK 629 INCL. CHECK VALVE
507
3176 8149 93 – – RESTRICTION SET – – STRYPNINGSSATS 589
– – HOSE SET COMPL. – SLANGSATS KOMPL 631
– – – HOSE SET – – SLANGSATS 633 RIGHYDRAULIC
– – – HOSE SET – – SLANGSATS 635 HYDR.UNIT
– – – HOSE SET – – SLANGSATS 639 JACKS
9106 2486 00 – EL.OIL FILLER – EL.OLJEPÅFYLLN. 655
9106 0796 62 – – HYDRAULIC PUMP – – HYDRAULPUMP 657 WITH EL.MOTOR 0,2KW/24VOLT
9106 1434 46 – – HOSE SET – – SLANGSATS 659 ELECTR.OIL FILLER
5112 3162 07 – – ELECTRIC SET – – ELSATS 661 EL. OILREFILL
508
509
B0049856
510

13 – 1 HYDRAULIC SET HYDRAULSATS Page 513 EXTRACTOR
255 9110 8969 12 1 COUPLING SET KOPPLINGSSATS Page 517
300 9111 4213 00 1 HYDR. SYSTEM HYDRAULSYSTEM Page 526 HYDRAULIC SYSTEM
301 – 1 HOSE SET COMPL. SLANGSATS KOMPL Page 631
315 9106 2486 00 1 EL.OIL FILLER EL.OLJEPÅFYLLN. Page 655
1260 5001 30 001K

511
HYDRAULIC SET / HYDRAULSATS EXTRACTOR
B0010550
512
HYDRAULIC SET / HYDRAULSATS EXTRACTOR

1 3214 7494 03 1 REDUCT. NIPPLE STRYPNIPPEL
5 3217 2682 00 1 PLUG PLUGG
9111 4005 32 008K

513
B0042529
514

1 3177 3092 57 1 NUT MUTTER
2 3177 3092 55 1 COIL SPOLE
3177 3092 88 002K

515
COUPLING SET / KOPPLINGSSATS 9110 8969 12
COUPLING SETKOPPLINGSSATS
B0049626
516
COUPLING SET / KOPPLINGSSATS 9110 8969 12

1 9110 8969 05 1 CLUTCH CASE KOPPLINGSHUS
2 3176 8502 90 1 COUPLING HALF KOPPLINGSHALVA Page 519
3 9110 9484 01 1 COUPLING HALF KOPPLINGSHALVA
4 9110 8060 04 1 WASHER BRICKA DIA 50/12 X 6
8 0144 3326 03 1 SCREW, HEX HEAD SKRUV, SEXKANT UNC 7/16 X 32 - 8.8 FZB
10 – 1 COVER SET TÄCKLOCKSATS Page 521
9110 8969 12 009K

517
COUPLING HALF / KOPPLINGSHALVA 3176 8502 90
COUPLING HALFKOPPLINGSHALVA
B0000001
518
COUPLING HALF / KOPPLINGSHALVA 3176 8502 90

- 3715 0889 90 5 BOLT SET BULTSATS REF.NO. 3-6
1 – 1 COUPLING HALF KOPPLINGSHALVA
2 3715 0889 03 5 RUBBER SLEEVE GUMMIHYLSA
3176 8502 90 001D

519
COVER SET / TÄCKLOCKSATS
COVER SETTÄCKLOCKSATS
B0049629
520
COVER SET / TÄCKLOCKSATS

1 9111 4169 71 2 PLASTIC SHEET PLASTSKIVA
M6SF M 5 X 16 - 8.8 FZB
9111 4169 70 002K

521
HYDR. SYSTEM / HYDRAULSYSTEM 9111 4213 00 HYDRAULIC SYSTEM
Fig. 1 of 4
B0055754
522
HYDR. SYSTEM / HYDRAULSYSTEM 9111 4213 00 HYDRAULIC SYSTEM
Fig. 2 of 4
9111 4213 00 001K

523
Fig. 3 of 4
B0055756
524
Fig. 4 of 4
9111 4213 00 001K

525

L10 9106 0658 85 1 SUCT.CONNECTION SUGANSLUTNING Page 529
L12 3217 9504 01 1.50M HOSE SLANG 2 INCH HOSE
L20 – 1 SUCT.CONNECTION SUGANSLUTNING Page 533
L22 3217 9504 00 1M HOSE SLANG
M10 9111 3469 00 1 HYDR. SET HYDR.SATS Page 535 DAMPING PISTON
M15 – 1 HYDRAULIC PUMP HYDRAULPUMP Page 537
M17 9111 3731 00 1 HYDRAULIC UNIT HYDRAULENHET Page 552 DRILLING ,EDS
M18 9111 4213 01 1 HYDRAULIC UNIT HYDRAULENHET Page 576 POSITIONING
M19 – 1 HYDRAULIC UNIT HYDRAULENHET Page 593
M30 – 1 PRES. GAUGE SET MANOMETERSATS Page 595
A1 – 6 COVER LOCK
B1 9111 3470 01 1 HYDR. SET HYDR.SATS Page 597 STINGER FRONT
C1 9111 3471 01 1 HYDR. SET HYDR.SATS Page 601 STINGER REAR
E1 9111 3516 02 1 HYDRAULIC SET HYDRAULSATS Page 603 DRILL STEEL SUPPORT,BSH 55
F1 9111 3600 03 1 HYDRAULIC SET HYDRAULSATS Page 605 DIESEL POS.
I1 9111 3603 00 1 HYDRAULIC SET HYDRAULSATS Page 607 PUMP UNLOADING
M3 9111 3335 20 1 HYDRAULIC SET HYDRAULSATS Page 609 ROTATION DIVICE
M4 9111 3333 01 1 HYDR. SET HYDR.SATS Page 611 TRAVERSE
M5 9106 1609 60 1 HYDRAULIC SET HYDRAULSATS Page 613 PROTECTION ROOF
M6 9111 3337 00 1 HYDR. SET HYDR.SATS Page 625 JACK EXTENSION
M9 9111 3468 00 1 HYDR. SET HYDR.SATS Page 627 FEED SWING
1 9106 1608 62 1 OIL COOLER OLJEKYLARE
3 3216 8883 00 1 THROTTLE VALVE STRYPVENTIL DV20-1.1/0-P-S
8 3176 2935 10 1 RETURN BLOCK RETURBLOCK Page 629 INCL. CHECK VALVE
9 3176 8149 93 4 RESTRICTION SET STRYPNINGSSATS Page 589
10 9106 1264 09 1 CONNECTING PIPE ANSLUTNINGSRÖR
B0055757
526
9111 4213 00 001K

527
SUCT.CONNECTION / SUGANSLUTNING 9106 0658 85
SUCT.CONNECTIONSUGANSLUTNING
B0048300
528

2 0638 0547 00 2 FLANGE HALF FLÄNSHALVA 63 X 84,94 SAE 2 1/2 P172
ZINC PLATED
3 0211 5365 00 4 SCREW SKRUV UNC 1/2 X 38 - 12.9
5 0347 6100 04 2 HOSE CLIP SLANGKLÄMMA 70 - 89
9106 0658 85 002K

529
B0048184
530

2 0638 0545 00 2 FLANGE HALF FLÄNSHALVA 51 72,24
3 0211 5363 00 4 SCREW SKRUV UNC 1/2 X 32 - 12.9
9106 0658 72 003K

531
SUCT.CONNECTION / SUGANSLUTNING
B0048303
532
SUCT.CONNECTION / SUGANSLUTNING

2 0638 0545 00 2 FLANGE HALF FLÄNSHALVA 51 72,24
3 0211 5365 00 4 SCREW SKRUV UNC 1/2 X 38 - 12.9
9106 0658 94 002K

533
HYDR. SET / HYDR.SATS 9111 3469 00 DAMPING PISTON
HYDR. SETHYDR.SATS
B0059893
534
HYDR. SET / HYDR.SATS 9111 3469 00 DAMPING PISTON

2 3217 9193 02 1 REGULATOR REGULATOR
3 3177 3032 00 1 PRESSURE GAUGE TRYCKMÄTARE WIKA 2748/63 0-250 BAR
4 3217 9882 11 1 SIGNAL CABLE SIGNALKABEL
5 – 1 PLATE PLÅT
9111 3469 00 009K

535
HYDRAULIC PUMP / HYDRAULPUMP
B0014845
536
HYDRAULIC PUMP / HYDRAULPUMP

1 3217 8762 00 1 HYDRAULIC PUMP HYDRAULPUMP Page 539 A10VO 100 CC
2 3217 8525 00 1 HYDRAULIC PUMP HYDRAULPUMP Page 545
3 3217 8762 01 1 SHAFT COUPLING AXELKOPPLING
4 3217 8524 02 1 COVER LOCK
3217 9553 75 002K

537
HYDRAULIC PUMP / HYDRAULPUMP 3217 8762 00 A10VO 100 CC
B0000141
538
HYDRAULIC PUMP / HYDRAULPUMP 3217 8762 00 A10VO 100 CC

1 – 1 PUMP PUMP Page 541
3217 8762 00 007K

539
PUMP / PUMP
PUMPPUMP
B0007788
540
PUMP / PUMP

- 3217 9206 82 1 SEAL KIT TÄTNINGSSATS INCL. REF 20, 22-24 +
SEALING SET FOR PILOT VALVE
1 3217 9206 11 1 PUMP UNIT PUMPENHET
2 3217 9206 12 1 REG PISTON REGLERKOLV
3 – 1 PISTON GUIDE KOLVSTYRNING
4 3217 9206 14 1 PISTON KOLV
5 3217 9206 15 1 PUMP HOUSING PUMPHUS
7 3217 9206 48 1 CRADLE VAGGA
8 3217 9206 18 1 SHAFT AXEL
12 3217 9206 22 1 WASHER BRICKA
13 3217 9206 23 1 SPRING FJÄDER
15 3217 9206 25 1 ROLLER BEARING RULLAGER
17 3217 9206 27 2 BEARING PLATE LAGERPLATTA
20 3217 9206 49 1 SEAL TÄTNING
22 3217 9206 30 1 O-RING O-RING
30 0686 9250 63 1 CAP HUV UN 1 1/6-12 PEHD
33 0101 2316 00 1 PIN PINNE CP 6M6 X 18 - 11 1650 06
3217 9206 04 001K

541
PILOT VALVESTYRVENTIL
B0030981
542

1 3218 2007 58 1 CONTROL VALVE MANÖVERVENTIL
2 3217 9203 59 3 O-RING O-RING
3 3218 2007 60 4 SCREW SKRUV
4 3217 9203 58 1 PLUG PROPP RX 705454-90542000716
3217 9203 02 006K

543
B0000141
544

1 3217 9203 01 1 PUMP PUMP Page 547
3 3217 9203 58 1 PLUG PROPP RX 705454-90542000716
3217 8525 00 002K

545
PUMP / PUMP 3217 9203 01
PUMPPUMP
B0000137
546
PUMP / PUMP 3217 9203 01

- 3128 3093 45 1 BEARING SET LAGERSATS INCL POS 11-12,15-17,27,33
- 3128 3095 02 1 GUIDE UNIT STYRENHET INCL POS 2-4,9,13
- 3217 9203 82 1 SEAL KIT TÄTNINGSSATS RX 913856-97202020640
INCL. REF.20,22-24,30 PUMP +
REF.19-21,23 PILOT VALVE
1 3217 9203 11 1 PUMP UNIT PUMPENHET Page 549
2 3217 9203 12 1 REG PISTON REGLERKOLV
4 3217 9203 14 1 PISTON KOLV
7 3217 9204 54 1 CRADLE VAGGA
8 3217 9203 18 1 SHAFT AXEL
11 3217 9203 21 1 WASHER BRICKA
12 3217 9203 22 1 WASHER BRICKA
13 3217 9203 23 1 SPRING FJÄDER
17 3217 9203 27 2 BEARING PLATE LAGERPLATTA
20 3217 9204 44 1 SEAL TÄTNING
25 5112 2878 46 1 LOCKING RING LÅSRING
30 3176 7868 07 1 PLUG PROPP
33 0101 2316 00 1 PIN PINNE CP 6M6 X 18 - 11 1650 06
3217 9203 01 007K

547
PUMP UNIT / PUMPENHET 3217 9203 11
PUMP UNITPUMPENHET
B0038192
548
PUMP UNIT / PUMPENHET 3217 9203 11

– 1 EXPLODED VIEW SPRÄNGBILD
1 – 1 ROTATION UNIT ROTATIONSENHET
2 3217 9203 94 1 CONTROL PLATE MANÖVERPLÅT
3217 9203 11 004K

549
HYDRAULIC UNIT / HYDRAULENHET 9111 3731 00 DRILLING ,EDS
Fig. 1 of 2
B0013840
550
HYDRAULIC UNIT / HYDRAULENHET 9111 3731 00 DRILLING ,EDS
Fig. 2 of 2
9111 3731 00 017K

551
HYDRAULIC UNIT / HYDRAULENHET 9111 3731 00

1 – 1 SIGN SET SKYLTSATS
2 9111 3729 03 1 PANEL PANEL
3 9111 3729 01 1 SLIDE LIST
7 9111 3770 00 1 VALVE BLOCK VENTILBLOCK Page 555
10 3177 3077 00 1 ASSEMBLY PLATE MONT.PLATTA
20 0823 0050 24 2 CHECK VALVE BACKVENTIL A G 1 0 18 98 46 WITHOUT
21 3216 8883 00 1 THROTTLE VALVE STRYPVENTIL DV20-1.1/0-P-S
23 3176 8377 00 1 SHUTTLE VALVE VÄXELVENTIL RS 417-00-04 / R 1/4
24 3177 5031 00 1 PRESSURE GAUGE TRYCKMÄTARE 63 0-60 4113
0-60 BAR
28 3217 9337 40 1 PRESS.REL.VALVE TRYCKBEG.VENTIL
B0033758
552
9111 3731 00 017K

553
VALVE BLOCKVENTILBLOCK
B0002474
554

C1 9111 3770 01 1 FLOW REGULATOR FLÖDESREGULATOR
C2 9111 3770 01 1 FLOW REGULATOR FLÖDESREGULATOR
C3 9111 3770 02 1 PRESS.REL.VALVE TRYCKBEG.VENTIL
C6 9111 3770 04 1 PRESS.REGULATOR TRYCKREGULATOR
C7 3177 3092 81 1 DIRECTION VALVE RIKTNINGSVENTIL Page 557
C10 3217 7864 01 1 DIRECTION VALVE RIKTNINGSVENTIL Page 561 RX 4WE10E
C11 9111 3770 03 1 CARTRIDGE VALVE PATRONVENTIL
- 3214 7675 92 1 SEAL KIT TÄTNINGSSATS REF. NO. C11.
- 3217 9963 04 1 SEAL KIT TÄTNINGSSATS REF. NO. C6.
- 9106 1492 04 3 SEAL KIT TÄTNINGSSATS REF. NO. C3,C4,C5.
- 9111 3770 11 2 SEAL KIT TÄTNINGSSATS REF. NO. C1,C2.
9111 3770 00 010K

555
B0032237
556

3177 3092 54 2 NUT SET MUTTERSATS POS. 1,2
2 3177 3092 52 2 COIL SPOLE
3177 3092 81 003K

557
B0042530
558

3177 3092 56 1 SEAL KIT TÄTNINGSSATS INCL. REF 2, 4, 5
1 3177 3092 57 2 NUT MUTTER
3 3177 3092 55 2 COIL SPOLE
3177 3092 80 004K

559
B0061521
560

- 3217 7864 22 1 SEAL KIT TÄTNINGSSATS REF.NO.104,105,113
1 3217 7864 11 1 HOUSE HUS
7 3217 7864 12 2 COVER LOCK
19 3217 7864 13 1 PISTON KOLV
60 3217 7864 14 2 WASHER BRICKA
63 3217 7864 15 2 SPRING HOLDER FJÄDERHÅLLARE
68 3217 7864 16 2 PIN STIFT
71 3217 7864 17 2 SPRING FJÄDER
104 3217 7864 18 2 BACK-UP RING STÖDRING
152 3176 1882 02 2 MAGNET MAGNET
169 3176 2037 00 1 ELECTR.PLUG STICKKONTAKT
170 3176 2038 00 1 ELECTR.PLUG STICKKONTAKT
182 3217 7864 24 2 PLUG PLUGG
3217 7864 01 002K

561
B0001243
562

– 1 INLET SECTION INLOPPSSEKTION Page 565
– 1 CONTROL UNIT MANÖVERENHET Page 567
– 1 END PIECE GAVEL Page 569
3217 9966 02 002K

563
INLET SECTION / INLOPPSSEKTION
INLET SECTIONINLOPPSSEKTION
B0001246
564

1 9120 0920 01 1 PILOT VALVE PILOTVENTIL REF.NO. 7-10,18-21.
2 9120 0920 02 1 PRESS.REL.VALVE TRYCKBEG.VENTIL REF.NO. 15,17.
3 9120 0920 04 1 FILTER SET FILTERSATS REF.NO. 22-26.
4 9120 0920 06 1 PLUG PLUGG REF.NO. 33,34.
5 0686 6442 07 3 PLUG PROPP VSTI G 1/4-ED
6 9120 0292 63 1 PRESS.REL.VALVE TRYCKBEG.VENTIL REF.NO. 44.
7 9120 0920 41 1 SPOOL SLID REF.NO. 11-14.
1261 0000 05 003K

565
CONTROL UNIT / MANÖVERENHET
CONTROL UNITMANÖVERENHET
B0001248
566
CONTROL UNIT / MANÖVERENHET

- 9120 0920 37 1 SEAL KIT TÄTNINGSSATS INCL. ITEM 55,56,59
- 9120 0920 39 1 SEAL KIT TÄTNINGSSATS INCL. ITEM 23,32,47,69,104,106
,120,139
- 9120 0920 40 1 SEAL KIT TÄTNINGSSATS INCL. ITEM 46-48
1 9120 0920 15 1 SPRING SET FJÄDERSATS INCL. ITEM 131-136,138
2 9120 0920 16 1 COVER LOCK INCL. ITEM 23,30-32,64,65,101,
137,139,140
3 9120 0920 20 1 COVER LOCK INCL. ITEM 23,30-32,69,101
4 9120 0792 46 2 SOLENOID VALVE MAGNETVENTIL ITEM 111
5 9125 9551 00 2 ELECTR.PLUG STICKKONTAKT ITEM 112
6 9128 8434 00 2 SHOCK SCREW DÄMPSKRUV ITEM 114
7 9120 0924 74 1 PLUG PLUGG INCL. ITEM 52,55-57,59,60,66-6
8
8 9120 0920 31 1 PLUG PLUGG INCL. ITEM 46-48,88
10 9120 0920 21 1 VALVE HOLDER VENTILHÅLLARE INCL. ITEM 23,30,101-103,107
1261 0000 07 005K

567
END PIECE / GAVEL
END PIECEGAVEL
B0001253
568
END PIECE / GAVEL

- 9120 0920 36 2 SEAL KIT TÄTNINGSSATS INCL. REF. 69,70,71.
1 9120 0920 34 1 PLUG PLUGG INCL. REF. 94,95.
2 9120 0920 35 2 ATTACHM. PLATE FÄSTPLATTA
3 – 3 PULL ROD DRAGSTÅNG
1261 0000 12 001K

569
B0001245
570

– 1 CONTROL UNIT MANÖVERENHET Page 567
– 1 END PIECE GAVEL Page 569
– 1 INLET SECTION INLOPPSSEKTION Page 573
3217 9966 03 002K

571
B0001254
572

1 9120 0920 06 1 PLUG PLUGG
5 9120 0920 41 1 SPOOL SLID
1261 0000 13 003K

573
HYDRAULIC UNIT / HYDRAULENHET 9111 4213 01 POSITIONING
Fig. 1 of 2
B0055758
574
HYDRAULIC UNIT / HYDRAULENHET 9111 4213 01 POSITIONING
Fig. 2 of 2
9111 4213 01 001K

575

2 9111 3728 05 1 PANEL PANEL
4 – 1 RUBBER CLOTH GUMMIDUK
9 3217 9193 01 1 REGULATOR REGULATOR Page 579
19 3217 9773 00 1 FLOW CONT.VALVE STRYPBACKVENTIL Page 587 RX Z2FS6-2-4X-2Q
20 4090 0630 00 4 HEX SOCK. SCREW SEXKANTHÅLSKRUV M 5 88 8,5 30 5 2,5 4 8.8
21 3176 8149 93 4 RESTRICTION SET STRYPNINGSSATS Page 589
22 – 0.50M EDGE LIST KANTLIST S1L
23 3217 9341 60 1 PRESS.RED.VALVE TRYCKRED.VENTIL Page 591
B0055759
576
9111 4213 01 001K

577
REGULATOR / REGULATOR 3217 9193 01
REGULATORREGULATOR
B0031877
578
REGULATOR / REGULATOR 3217 9193 01

2 3217 9194 02 1 PISTON KOLV
3 3217 9194 03 1 SEAT SÄTE
6 3217 9194 06 1 SCREW SKRUV
7 3217 9194 07 1 CONE KONA
8 3217 9194 08 1 O-RING O-RING
9 3217 9194 09 1 BACK-UP RING STÖDRING
10 3217 9194 10 1 KNOB KNOPP
3217 9193 01 003K

579
B0042530
580

3177 3092 57 2 NUT MUTTER POS. 1,2
3 3177 3092 55 2 COIL SPOLE
3177 3092 83 005K

581
B0042534
582

3 3214 8712 82 1 PLUG PLUGG
6 – 1 PRESS.RED.VALVE TRYCKRED.VENTIL NOT SOLD SEPARATELY
10 3214 8712 87 1 SEAL KIT TÄTNINGSSATS POS. 10
3214 8712 80 004K

583
B0032236
584

1 3177 3092 57 1 NUT MUTTER
2 3177 3092 55 1 COIL SPOLE
3 3177 3092 56 1 SEAL KIT TÄTNINGSSATS POS 3
3177 3092 89 002K

585
FLOW CONT.VALVE / STRYPBACKVENTIL 3217 9773 00 RX Z2FS6-2-4X-2Q
FLOW CONT.VALVESTRYPBACKVENTIL
B0045114
586
FLOW CONT.VALVE / STRYPBACKVENTIL 3217 9773 00 RX Z2FS6-2-4X-2Q

– 1 EXPLODED VIEW SPRÄNGBILD
3217 9773 19 1 SEAL KIT TÄTNINGSSATS INCL.POS.9-13.
2 – 2 PISTON KOLV NOT SOLD SEPARATELY
3 – 2 BUSHING BUSSNING NOT SOLD SEPARATELY
4 – 2 REGULATOR REGULATOR NOT SOLD SEPARATELY
5 – 2 CAP HUV NOT SOLD SEPARATELY
14 3217 9773 23 1 SEAL DISC TÄTNINGSSKIVA
3217 9773 00 002K

587
RESTRICTION SET / STRYPNINGSSATS 3176 8149 93
RESTRICTION SETSTRYPNINGSSATS
B0000012
588
RESTRICTION SET / STRYPNINGSSATS 3176 8149 93

2 3176 8153 00 1 VALVE CONE VENTILKÄGLA D=1,0
3176 8149 93 002K

589
B0042533
590

3214 8712 87 1 SEAL KIT TÄTNINGSSATS POS. 1-5,7-10
6 3214 8712 86 1 REGULATING UNIT REGLERENHET
3217 9341 60 004K

591
HYDRAULIC UNIT / HYDRAULENHET
B0015007
592
HYDRAULIC UNIT / HYDRAULENHET

1 9111 3730 10 1 SIGN SET SKYLTSATS
2 9111 3472 06 1 PANEL PANEL
6 9106 0746 01 1 SLIDE LIST
11 3217 6047 01 2 DAMPER DÄMPARE
12 3217 6047 02 2 DAMPER DÄMPARE VT NEDRE
9111 3730 00 004K

593
PRES. GAUGE SET / MANOMETERSATS
PRES. GAUGE SETMANOMETERSATS
B0058096
594
PRES. GAUGE SET / MANOMETERSATS

4 3217 3839 00 1 PALM GRIP VRED
6 3176 6020 00 1 PRESSURE GAUGE TRYCKMÄTARE 100 0- 60 R3/8
7 3176 6022 00 2 PRESSURE GAUGE TRYCKMÄTARE 0-250 BAR
0-250 BAR
8 0653 0905 11 3 GASKET PACKNING 6,5 / 14,8 X 2-11 5013 12
9111 3714 37 005K

595
HYDR. SET / HYDR.SATS 9111 3470 01 STINGER FRONT
HYDR. SETHYDR.SATS
B0025267
596
HYDR. SET / HYDR.SATS 9111 3470 01 STINGER FRONT

9111 3470 01 011K

597
B0041070
598

3222 3308 22 1 SEAL KIT TÄTNINGSSATS INCL. ITEM 1-2
3222 3268 96 002K

599
HYDR. SETHYDR.SATS
B0025268
600

9111 3471 01 011K

601
HYDRAULIC SET / HYDRAULSATS 9111 3516 02 DRILL STEEL SUPPORT,BSH 55
B0025269
602
HYDRAULIC SET / HYDRAULSATS 9111 3516 02 DRILL STEEL SUPPORT,BSH 55

11 – 4 COVER LOCK
9111 3516 02 019K

603
HYDRAULIC SET / HYDRAULSATS 9111 3600 03 DIESEL POS.
B0006168
604
HYDRAULIC SET / HYDRAULSATS 9111 3600 03 DIESEL POS.

6 0823 0050 18 1 CHECK VALVE BACKVENTIL A G 1/2 0,5 14 72 30 -
7 3176 2711 00 1 PRESS.REL.VALVE TRYCKBEG.VENTIL HW SV 28
9111 3600 03 011K

605
HYDRAULIC SET / HYDRAULSATS 9111 3603 00 PUMP UNLOADING
B0002466
606
HYDRAULIC SET / HYDRAULSATS 9111 3603 00 PUMP UNLOADING

9111 3603 00 005K

607
HYDRAULIC SET / HYDRAULSATS 9111 3335 20 ROTATION DIVICE
B0039281
608
HYDRAULIC SET / HYDRAULSATS 9111 3335 20 ROTATION DIVICE

9111 3335 20 003K

609
HYDR. SET / HYDR.SATS 9111 3333 01 TRAVERSE
HYDR. SETHYDR.SATS
B0007351
610
HYDR. SET / HYDR.SATS 9111 3333 01 TRAVERSE

9111 3333 01 009K

611
HYDRAULIC SET / HYDRAULSATS 9106 1609 60 PROTECTION ROOF
B0027631
612
HYDRAULIC SET / HYDRAULSATS 9106 1609 60 PROTECTION ROOF

74 3176 8505 00 2 RESTRICTION STRYPNING D=1,2 ; 9/16-18 UN
76 3128 2091 69 2 LEVER SET SPAKSATS
77 9121 5500 08 1 CONNECT.ADAPTER ANSLUTN.NIPPEL
78 3176 7574 00 1 PLATE SKYLT
9106 1609 60 004K

613
B0014698
614

1 9106 0631 24 2 SEAL KIT TÄTNINGSSATS POS.1
9106 0630 10 003K

615
B0032256
616

1 3128 2091 22 1 INLET SECTION INLOPPSSEKTION Page 619
2 3128 2091 02 2 VALVE SECTION VENTILSEKTION Page 621
3 3128 2091 24 1 OUTLET SECTION UTLOPPSSEKTION Page 623
3128 2090 72 004K

617
INLET SECTION / INLOPPSSEKTION 3128 2091 22
B0032252
618
INLET SECTION / INLOPPSSEKTION 3128 2091 22

3222 3264 90 1 VALVE VENTIL
10 3222 3264 94 1 RESTRICTION STRYPNING
3128 2091 22 002K

619
VALVE SECTION / VENTILSEKTION 3128 2091 02
VALVE SECTIONVENTILSEKTION
B0032230
620
VALVE SECTION / VENTILSEKTION 3128 2091 02

3222 3264 95 1 SEAL KIT TÄTNINGSSATS POS. 10,11
3222 3264 98 1 LEVER HOLDER SPAKHÅLLARE POS. 1,2,3,4
3222 3264 99 1 ACTUATOR STÄLLDON POS. 5,6,8,9
3128 2091 02 003K

621
OUTLET SECTION / UTLOPPSSEKTION 3128 2091 24
OUTLET SECTIONUTLOPPSSEKTION
B0032233
622
OUTLET SECTION / UTLOPPSSEKTION 3128 2091 24

3128 2091 26 1 PULL ROD SET DRAGSTÅNGSSATS POS.1,2
3128 2091 24 003K

623
HYDR. SET / HYDR.SATS 9111 3337 00 JACK EXTENSION
HYDR. SETHYDR.SATS
B0001865
624
HYDR. SET / HYDR.SATS 9111 3337 00 JACK EXTENSION

9111 3337 00 008K

625
HYDR. SET / HYDR.SATS 9111 3468 00 FEED SWING
HYDR. SETHYDR.SATS
B0006814
626
HYDR. SET / HYDR.SATS 9111 3468 00 FEED SWING

9111 3468 00 007K

627
RETURN BLOCK / RETURBLOCK 3176 2935 10 INCL. CHECK VALVE
RETURN BLOCKRETURBLOCK
B0059819
628
RETURN BLOCK / RETURBLOCK 3176 2935 10 INCL. CHECK VALVE

9106 1312 00 1 SPARE PARTS SET RESERVDELSSATS
1 – 1 RETAINER FASTHÅLLARE PART OF SPARE PARTS SET
2 – 1 SPRING FJÄDER PART OF SPARE PARTS SET
3 – 1 POPPET VALVE SÄTESVENTIL
3176 2935 10 004K

629
HOSE SET COMPL. / SLANGSATS KOMPL
HOSE SET COMPL.SLANGSATS KOMPL
B0015365
630
HOSE SET COMPL. / SLANGSATS KOMPL

1 – 1 HOSE SET SLANGSATS Page 633 RIGHYDRAULIC
2 – 1 HOSE SET SLANGSATS Page 635 HYDR.UNIT
3 – 1 HOSE SET SLANGSATS Page 639 JACKS
9111 3959 30 002K

631
HOSE SET / SLANGSATS RIGHYDRAULIC
HOSE SETSLANGSATS
B0015365
632
HOSE SET / SLANGSATS RIGHYDRAULIC

DF 0574 4319 11 1 HOSE ASSEMBLY SLANGLEDNING 25 X 670 R2AT
DKV 0574 0320 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 5700 R2AT
DR 3176 7665 00 1 HOSE ASSEMBLY SLANGLEDNING 19 X 600 R2AT
DS9 3176 7099 00 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 4000 R2AT
KV1 0574 1292 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 5000 R2AT
LU11 0574 2255 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 400 R2AT
PF1 0574 0063 90 1 HOSE ASSEMBLY SLANGLEDNING 25 X 5000 R9R
PR1 0574 0064 37 1 HOSE ASSEMBLY SLANGLEDNING 25 X 4400 R9R
TF 3176 5672 00 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 1500 R2AT
T10 0574 2284 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 3400 R2AT
T41 0574 0000 66 1 HOSE ASSEMBLY SLANGLEDNING 38 X 3500 R1T
WG 0574 0278 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 2200 R2AT
WR1 3176 6861 00 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 500 R2AT
W11 0574 0068 86 1 HOSE ASSEMBLY SLANGLEDNING 38 X 2500 R1T
38*1500 R1T
XFS1 0574 0321 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 4500 R2AT
XR1 0574 0289 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 4400 R2AT
9111 3959 17 004K

633
HOSE SET / SLANGSATS HYDR.UNIT
HOSE SETSLANGSATS
B0015365
634
HOSE SET / SLANGSATS HYDR.UNIT
(Sheet 1 of 2)
BS30 0574 2255 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 400 R2AT
DP 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
DP9 3176 6974 00 1 HOSE ASSEMBLY SLANGLEDNING 10 X 1400 R2AT
E1 3176 5220 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 1200 R2AT
GF 0574 0253 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 300 R2AT
GGF 3176 6856 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 3000 R2AT
GGR 3176 6856 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 3000 R2AT
GGW 3176 6856 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 3000 R2AT
GR1 0574 0253 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 300 R2AT
GR3 3176 5680 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3 X 800 R2AT
LG 0574 0253 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 300 R2AT
PG 3176 6854 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 600 R2AT
PR11 0574 1256 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 450 R2AT
PS1 0574 4509 11 1 HOSE ASSEMBLY SLANGLEDNING 25 X 600 R9R
P3 0574 2270 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X1300 R2AT
P5 3176 5681 00 1 HOSE ASSEMBLY SLANGLEDNING 10 X 600 R2AT
TF10 0574 4259 11 1 HOSE ASSEMBLY SLANGLEDNING 25 X 600 R2AT
TF12 3176 7449 00 1 HOSE ASSEMBLY SLANGLEDNING D6,3X1100 R2AT
TR1 0574 0000 17 1 HOSE ASSEMBLY SLANGLEDNING 25 X 1500 R2AT
TS1 0574 0000 17 1 HOSE ASSEMBLY SLANGLEDNING 25 X 1500 R2AT
XDP 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
XFP 3176 6854 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 600 R2AT
9111 3959 16 002K

635
(Sheet 2 of 2)
XFT 0574 0272 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 1500 R2AT
XP 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
XS 3176 6486 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 1000 R2AT
XT1 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
B0015365
636
9111 3959 16 002K

637
HOSE SET / SLANGSATS JACKS
HOSE SETSLANGSATS
B0015365
638
HOSE SET / SLANGSATS JACKS

J11 3176 6859 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 3800 R2AT
9111 3958 75 002K

639
HOSE SETSLANGSATS
B0015365
640

BU7 0574 1323 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 5400 R2AT
10*5400 R2AT
C5 0574 0291 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 4800 R2AT
10*5400 R2AT
FE5 0574 1291 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 4800 R2AT
F10 0574 3569 11 1 HOSE ASSEMBLY SLANGLEDNING 19 X 5300 R9R
JS11 0574 2291 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 4800 R2AT
K3 0574 1314 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 5700 R2AT
R7 0574 3569 11 1 HOSE ASSEMBLY SLANGLEDNING 19 X 5300 R9R
TBU7 0574 1323 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 5400 R2AT
10*5400 R2AT
W7 0574 4287 11 1 HOSE ASSEMBLY SLANGLEDNING 25 X 4000 R2AT
25*4000 R2AT
9111 3959 21 002K

641
HOSE SETSLANGSATS
X0000000
642

HB11 3176 5679 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 500 R2AT
9111 3958 76 001K

643
HOSE SETSLANGSATS
B0015365
644

9111 3959 25 002K

645
HOSE SETSLANGSATS
B0015365
646
(Sheet 1 of 2)
9111 3959 24 003K

647
(Sheet 2 of 2)
B0015365
648
9111 3959 24 003K

649
HOSE SETSLANGSATS
B0015365
650

9111 3959 23 002K

651
HOSE SETSLANGSATS
B0015365
652

SH1 3176 7645 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 3400 R2AT
9111 3959 22 001K

653
EL.OIL FILLER / EL.OLJEPÅFYLLN. 9106 2486 00
EL.OIL FILLEREL.OLJEPÅFYLLN.
B0052228
654
EL.OIL FILLER / EL.OLJEPÅFYLLN. 9106 2486 00

1 9106 0796 62 1 HYDRAULIC PUMP HYDRAULPUMP Page 657 WITH EL.MOTOR 0,2KW/24VOLT
2 9106 0833 01 1 CHECK VALVE BACKVENTIL IA 2290-15
3 0823 0090 06 1 CHECK VALVE BACKVENTIL 25 G 1
5 9106 1434 46 1 HOSE SET SLANGSATS Page 659 ELECTR.OIL FILLER
6 5112 3162 07 1 ELECTRIC SET ELSATS Page 661 EL. OILREFILL
9106 2486 00 001K

655
HYDRAULIC PUMP / HYDRAULPUMP 9106 0796 62 WITH EL.MOTOR 0,2KW/24VOLT
B0055959
656
HYDRAULIC PUMP / HYDRAULPUMP 9106 0796 62 WITH EL.MOTOR 0,2KW/24VOLT

9106 1080 07 1 REPAIR SET REPARATIONSSATS INCL.POS 1,3,8,9,16
9106 1080 12 1 REPAIR SET REPARATIONSSATS INCL.POS.19,20,21
8 – 7 PLATE PLATTA NOT SOLD SEPARATELY
17 9106 1080 05 1 MOTOR MOTOR
18 9106 1080 06 1 PUMP PUMP
19 9106 1080 09 1 CONE KÄGLA
20 9106 1080 10 1 SPRING FJÄDER
21 9106 1080 11 1 SCREW SKRUV
9106 0796 62 006K

657
HOSE SET / SLANGSATS 9106 1434 46 ELECTR.OIL FILLER
HOSE SETSLANGSATS
B0015365
658
HOSE SET / SLANGSATS 9106 1434 46 ELECTR.OIL FILLER

TF1 3176 6862 00 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 700 R2AT
9106 1434 46 002K

659
ELECTRIC SET / ELSATS 5112 3162 07 EL. OILREFILL
ELECTRIC SETELSATS
B0034609
660
ELECTRIC SET / ELSATS 5112 3162 07 EL. OILREFILL

1 3176 0006 14 1 PUSH-BUTTON-BOX TRYCKKNAPPSLÅDA A81
M20X1,5 7-13 B1
7 9111 3891 59 3M CABLE, 2-CORE KABEL, 2-LEDARE
5112 3162 07 005K

661
662
ELECTR. SYSTEM / ELSYSTEM
LIST OF CONTENTS
– ELECTR. SYSTEM ELSYSTEM 667
– – CONTROLSYST EL. – STYRSYSTEM EL. 671
9111 2027 25 – – SENSOR SET – – GIVARSATS 673
9111 3733 03 – – E-BOX – – E-LÅDA 675
– – – – ELECTRIC SET – – – ELSATS 679 THREAD LUBRICATION
3217 8977 08 – – CABLE – – KABEL 681
3217 8438 04 – – OPERATING CABLE – – MANÖVERKABEL 683
9111 4012 12 – – CABLE – – KABEL 685
3217 8975 10 – – CABLE – – KABEL 687
9111 3758 04 – – CABLE – – KABEL 689
9111 3610 82 – – ELECTRIC SET – – ELSATS 691 DUAL CONTROL
– – – – CONTROL BOX – – – MANÖVERLÅDA 693
– – – – CONTROL BOX – – – MANÖVERLÅDA 695
9111 2023 84 – – CONTROL DEVICE – – MANÖVERDON 697
9111 3420 12 – – CABLE – – KABEL 699
3217 8957 42 – – CONTROL PANEL – – MANÖVERPANEL 701
9111 3703 08 – – – CONTROL PANEL – – – MANÖVERPANEL 705
5112 3158 44 – – – EMERG.SET – – – NÖDSTOPPSATS 707
3176 4341 20 – – – CONTROLER – – – KONTROLLER 709
9111 3671 80 – – JUNCTION BOX – – KOPPLINGSLÅDA 711
9111 3671 10 – – – JUNCTION BOX – – – KOPPLINGSLÅDA 713
– – – JUNCTION BOX – – KOPPLINGSLÅDA 715
– – – – CABLE SET – – – KABELSATS 718
9111 3688 10 – – ELECTRIC SET – – ELSATS 721 EMERGENCY STOP
3217 0011 09 – – – EMERG. STOP BOX – – – NÖDSTOPPSLÅDA 723
– – BASIC EL.CAB. – GRUNDELSKÅP 725
9106 1287 61 – – ELECTR.CABINET – – ELSKÅP 727 380-690V 50/60HZ
663
9106 1286 31 – – – ELECTR.CABINET – – – ELSKÅP 731
9106 1286 42 – – – – DOOR – – – – DÖRR 733
9106 1286 41 – – – – DOOR – – – – DÖRR 735
9106 1125 00 – – – MAIN SWITCH – – – HUVUDBRYTARE 737
– – THERMAL RELAYS – TERMISKA RELÄER 739
– – ELECTRIC SET – ELSATS 741
9111 3229 00 – LIGHT SET – BELYSNINGSSATS 743 1 X 200W - 24V
3217 3841 80 – – HOLDER – – HÅLLARE 745
3217 9687 01 – – HEADLIGHT – – STRÅLKASTARE 747 200W 24V
3176 0001 27 – – OUTLET KIT – – UTTAGSSATS 749 TRIPOD
– – FLASHING BEACON – VARNINGSFYR 751
5112 3214 17 – CONTACT – KONTAKT 753
– – STAIR LIGHTING – TRAPPBELYSNING 755 2X70W
5112 3043 40 – – HEADLIGHT – – STRÅLKASTARE 757
5112 3043 40 – – HEADLIGHT – – STRÅLKASTARE 757
3217 0012 11 – – SWITCH – – VRED 759
5112 3217 81 – – JUNCTION BOX – – KOPPLINGSLÅDA 761
664
665
ELECTR. SYSTEMELSYSTEM
B0049856
666

600 – 1 CONTROLSYST EL. STYRSYSTEM EL. Page 671
630 3217 9970 63 1 ELECTRIC MOTOR ELMOTOR
650 – 1 BASIC EL.CAB. GRUNDELSKÅP Page 725
660 – 1 THERMAL RELAYS TERMISKA RELÄER Page 739
671 – 1 ELECTRIC SET ELSATS Page 741
672 0017 2307 21 7M CABLE, 3-CORE KABEL, 3-LEDARE CAVOTEC
BUFLEX 3X35+3G6+4X1,5+2X1
680 9111 3229 00 2 LIGHT SET BELYSNINGSSATS Page 743 1 X 200W - 24V
681 – 1 FLASHING BEACON VARNINGSFYR Page 751
682 5112 3214 17 1 CONTACT KONTAKT Page 753
686 – 1 STAIR LIGHTING TRAPPBELYSNING Page 755 2X70W
1260 5001 34 001K

667
CONTROLSYST EL. / STYRSYSTEM EL.
CONTROLSYST EL.STYRSYSTEM EL.
Fig. 1 of 3
B0063325
668
Fig. 2 of 3
9111 3738 20 003K

669
Fig. 3 of 3
B0063327
670

E1 9111 2027 25 1 SENSOR SET GIVARSATS Page 673
F3 9111 3733 03 1 E-BOX E-LÅDA Page 675
I1 3217 8977 08 1 CABLE KABEL Page 681
J2 3217 8438 04 1 OPERATING CABLE MANÖVERKABEL Page 683
J5 9111 4012 12 1 CABLE KABEL Page 685
K1 3217 8975 10 1 CABLE KABEL Page 687
L1 9111 3758 04 1 CABLE KABEL Page 689
N4 9111 3610 82 1 ELECTRIC SET ELSATS Page 691 DUAL CONTROL
2 9111 2023 84 1 CONTROL DEVICE MANÖVERDON Page 697
3 9111 3420 12 1 CABLE KABEL Page 699
4 3217 8957 42 1 CONTROL PANEL MANÖVERPANEL Page 701
7 9111 3671 80 1 JUNCTION BOX KOPPLINGSLÅDA Page 711
8 3176 0050 32 5M PROTECTION HOSE SKYDDSSLANG
9 3176 0050 32 7M PROTECTION HOSE SKYDDSSLANG
14 3217 7992 02 1 THERMOSTAT TERMOSTAT 55 DEGREE CELSIUS
15 3217 7992 01 1 THERMOSTAT TERMOSTAT 70 DEGREE CELSIUS
16 8231 1085 75 1 PRESS. SWITCH TRYCKSTRÖMSTÄLL RETURN FILTER
20 – 1 JUNCTION BOX KOPPLINGSLÅDA Page 715
21 8231 1086 09 1 PROTECTION HOOD SKYDDSKÅPA
28 9111 3688 10 1 ELECTRIC SET ELSATS Page 721 EMERGENCY STOP
9111 3738 20 003K

671
SENSOR SET / GIVARSATS 9111 2027 25
SENSOR SETGIVARSATS
B0056375
672

1 9111 2027 20 1 SENSOR FLAG GIVARFLAGGA
2 9111 2027 22 1 PLATE PLÅT
4 9111 2027 24 1 PLATE PLÅT
5 9111 2027 23 1 PLATE PLÅT
7 3222 1488 03 1 SENSOR GIVARE
9 0698 5205 00 1 JUNCTION BOX KOPPLINGSDOSA 3XPG11-PR18,6 77X90MM
13 3176 0050 38 2.50M PROTECTION HOSE SKYDDSSLANG
D=12 NORMA TYP RSGU
M6SF M 5 X 10 - 8.8 FZB
9111 2027 25 005K

673
E-BOX / E-LÅDA 9111 3733 03
E-BOXE-LÅDA
B0050407
674
E-BOX / E-LÅDA 9111 3733 03
(Sheet 1 of 3)
1 3217 8923 31 1 PLC CABINET PLC SKÅP
2 9111 3734 10 7 RELAY RELÄ CA3KN40BD 24VDC
3 9111 3734 11 10 RELAY RELÄ CA3KN22BD 24VDC
4 3176 0035 28 2 TIMING RELAY TIDRELÄ
5 3176 4492 01 4 MIN CIRC BREAK AUTOMATSÄKRING 1-POL 6A
6 3217 9823 01 1 INNER LIGHT INNERBELYSNING
7 3176 4160 00 2 BULB GLÖDLAMPA 24V 5W SV8,5 L=36MM(39MM)
8 3217 8816 00 1 HEATER ELEMENT VÄRMEELEMENT
9 3217 9865 01 1 FAN FLÄKT
12 9111 3707 32 1 COVER LOCK
14 3177 7024 13 1 HOUSING PANELBRUNN HARTING:09 30 016 0302
15 3177 7024 12 1 SLEEVE INSERT HYLSINSATS HARTING:09 33 016 2716
16 3217 8278 00 16 SLEEVE HYLSA
18 3217 8277 11 8 GUIDE PIN STYRPINNE GUIDE PIN
19 3217 8277 10 8 GUIDE SLEEVE STYRHYLSA GUIDE BUSH
22 3176 4343 03 2 COVER LOCK
23 3176 4344 02 1 PIN INSERT STIFTINSATS 24-TERMINALS (1-24)
24 – 1 ELECTRIC SET ELSATS Page 679 THREAD LUBRICATION
25 3217 8402 00 1 FRAME RAM
26 3217 8400 00 2 SLEEVE INSERT HYLSINSATS
27 3217 8403 00 100 SLEEVE HYLSA
9111 3733 03 017K

675
E-BOX / E-LÅDA 9111 3733 03
(Sheet 2 of 3)
35 – 3M CABLE TRAY KABELKANAL EL-AUTOMATIK
36 1088 1501 01 0.50 SHRINKING TUB. KRYMPSLANG KRYMPSLANG
38 4142 4045 00 1 CONNECTOR KONTAKTDON A01 10 6X20
40 9111 3760 30 1 COVER LOCK
41 – 1 PLATE PLÅT
42 3217 9897 01 1 DIODE UNIT DIODENHET 3A
43 3217 9825 01 1 AMPLIFIER FÖRSTÄRKARE
44 3217 9784 01 1 REGULATOR REGULATOR
45 – 1 HOUSING PANELBRUNN
49 9106 1616 03 1 COVER LOCK
90 3217 9583 01 2 RELAY RELÄ IK 8701.12 24V DC D & S
24 VOLT 16A
50 0017 2100 20 25M CABLE, 1-CORE KABEL, 1-LEDARE RK 0,75MM2 BLUE
51 0017 2010 20 25M CABLE, 1-CORE KABEL, 1-LEDARE RK 0,75MM2 RED
52 0017 2100 40 5M CABLE, 1-CORE KABEL, 1-LEDARE RK 1,5 MM2 BLUE
53 0017 2010 40 10M CABLE, 1-CORE KABEL, 1-LEDARE RK 1,5 MM2 RED
54 0017 2016 02 60M CABLE, 1-CORE KABEL, 1-LEDARE RK 0.75MM2 WHITE
55 0017 2010 50 3M CABLE, 1-CORE KABEL, 1-LEDARE RK 2,5 MM2 RED
60 0694 4990 24 1 WIRE MARKER KABELMÄRKNING FLEXIPART ' 24'
64 9138 5000 84 1 WIRE MARKER KABELMÄRKNING FLEXIPART ' 0'-' 29'
66 9138 5000 85 1 WIRE MARKER KABELMÄRKNING FLEXIPART '100'-'129'
B0050407
676
E-BOX / E-LÅDA 9111 3733 03
(Sheet 3 of 3)
71 3176 4049 90 1 MARKING PLATE MÄRKSKYLT 0
1-50
81 0694 5610 01 16 END SOCKET ÄNDHYLSA 0,4 1,0 1,4
82 1088 0008 01 60 END SOCKET ÄNDHYLSA 1,6/1,9 X 22 0,25 - 1,5
83 1088 0008 02 4 END SOCKET ÄNDHYLSA 2,3/1,9 X 23 1,1 - 2,6
84 1088 0003 06 4 FLAT PIN SLEEVE FLATSTIFTSHYLSA A 6,3- 6 T 70
9111 3733 03 017K

677
ELECTRIC SETELSATS
X0000000
678

X5 9106 1616 06 1 HOUSING PANELBRUNN
9111 3760 07 001K

679
CABLE / KABEL 3217 8977 08
CABLEKABEL
B0057606
680
CABLE / KABEL 3217 8977 08

1 9111 3891 15 12M CABLE,18-CORE KABEL,18-LEDARE
3 9111 0020 35 1 CABLE GEAR KABELDON
4 3177 7023 13 1 COVER LOCK FOR CONNECTOR
3217 8977 08 007K

681
OPERATING CABLE / MANÖVERKABEL 3217 8438 04
OPERATING CABLEMANÖVERKABEL
B0057608
682
OPERATING CABLE / MANÖVERKABEL 3217 8438 04

1 3217 8440 00 1.50M CABLE KABEL ÖLFLEX 100 X 0,5
2 9111 0020 30 2 CABLE GEAR KABELDON SIDE-ENTRY,M32,WITHOUT STEM
3 0697 9745 80 2 ENLARGER FÖRSTORING C2 M 32X1,5 M 40X1,5 16 7
4 3217 8403 00 200 SLEEVE HYLSA
5 3217 8402 00 2 FRAME RAM
7 3217 8399 00 2 PIN INSERT STIFTINSATS
10 3176 4344 03 2 COVER LOCK
3217 8438 04 005K

683
CABLE / KABEL 9111 4012 12
CABLEKABEL
B0008727
684
CABLE / KABEL 9111 4012 12

4 9111 3707 30 2 COVER LOCK
9111 4012 12 001K

685
CABLE / KABEL 3217 8975 10
CABLEKABEL
B0057609
686
CABLE / KABEL 3217 8975 10

2 3176 4343 02 1 SLEEVE INSERT HYLSINSATS WITH 24-POLES
3 9111 0020 30 1 CABLE GEAR KABELDON SIDE-ENTRY,M32,WITHOUT STEM
4 3176 4344 03 1 COVER LOCK
3217 8975 10 007K

687
CABLE / KABEL 9111 3758 04
CABLEKABEL
B0007662
688
CABLE / KABEL 9111 3758 04

1 9139 6001 00 1 PLUG CONNECTOR STICKPROPP CANNON KPT 06 F10-6P
9111 3758 04 003K

689
ELECTRIC SET / ELSATS 9111 3610 82 DUAL CONTROL
ELECTRIC SETELSATS
B0058401
690
ELECTRIC SET / ELSATS 9111 3610 82 DUAL CONTROL

1 – 1 CONTROL BOX MANÖVERLÅDA Page 693
2 9111 3610 10 4 SIGN SET SKYLTSATS
8 – 1 CONTROL BOX MANÖVERLÅDA Page 695
10 9111 3891 09 25M CABLE,12-CORE KABEL,12-LEDARE ÖLFLEX 150 12X1.5 D2=14.5
9111 3610 82 009K

691
CONTROL BOX / MANÖVERLÅDA
B0030007
692

9 5112 3139 18 1 PLATE SKYLT
3217 6514 77 003K

693
B0029795
694

3 3217 0010 90 1 LAMPPUSHBUTTON LAMPTRYCKKNAPP
9 5112 3139 18 1 PLATE SKYLT
3217 6514 78 003K

695
CONTROL DEVICE / MANÖVERDON 9111 2023 84
CONTROL DEVICEMANÖVERDON
B0056788
696
CONTROL DEVICE / MANÖVERDON 9111 2023 84

1 9111 2030 01 1 CONTROL DEVICE MANÖVERDON
3 9111 2190 04 1 PLATE SKYLT
4 3176 4576 02 2 PLATE PLÅT
8 3217 0010 14 11 PALM GRIP VRED 3 L BRAKE TEST
10 – 1 PLATE SKYLT
13 0333 3114 00 4 LOCK WASHER LÅSBRICKA 4,3 / 8 X 0,5 DIN 6798
4,3 / 8 X 0,5 DIN 6798
14 0261 2106 00 4 NUT MUTTER M 4 - 4 FZB
15 3217 8277 00 40 PIN STIFT CRIMP CONTACTS-SILVER-PLATED
21 3217 0010 76 12 PROTECTION RING SKYDDSRING
22 3217 0010 76 12 PROTECTION RING SKYDDSRING
9111 2023 84 007K

697
CABLE / KABEL 9111 3420 12
CABLEKABEL
B0056780
698
CABLE / KABEL 9111 3420 12

1 0017 2307 06 12M CABLE,41-CORE KABEL,41-LEDARE NUMMERKABEL
4 3217 8278 00 40 SLEEVE HYLSA
6 3217 8277 00 40 PIN STIFT CRIMP CONTACTS-SILVER-PLATED
10 3177 7023 13 2 COVER LOCK FOR CONNECTOR
9111 3420 12 003K

699
CONTROL PANEL / MANÖVERPANEL 3217 8957 42
CONTROL PANELMANÖVERPANEL
B0023763
700
(Sheet 1 of 2)
1 9111 3703 08 1 CONTROL PANEL MANÖVERPANEL Page 705
2 9111 3703 48 1 PLATE SKYLT
8 3217 0010 81 1 MUSHROOM PUSHB. SVAMPTRYCKE
18 9111 3703 50 1 POTENTIOMETER POTENTIOMETER
26 3217 9837 02 1 SWITCH OMKOPPLARE
28 3217 9837 07 1 SWITCH OMKOPPLARE
30 3177 7017 00 1 JOYSTICK MANIPULATOR TELEM.XD2-CC1111
31 – 1 INSTRUCTION INSTRUKTION
33 5112 3158 44 1 EMERG.SET NÖDSTOPPSATS Page 707
35 3176 4341 20 2 CONTROLER KONTROLLER Page 709
40 3176 4342 10 1 SWITCH STRÖMSTÄLLARE
45 9111 3707 30 1 COVER LOCK
50 9111 3703 28 1 PLATE PLÅT
51 3217 9592 10 1 TERMINAL BLOCK KOPPLINGSPLINT UK 4-TG
BASIC TERMINAL BLOCK/SCREWS
52 3217 9592 20 1 DIODE UNIT DIODENHET ELEKTROPHÖNIX ST-1N4007
55 3217 8816 00 1 HEATER ELEMENT VÄRMEELEMENT
3217 8957 42 010K

701
(Sheet 2 of 2)
57 3217 9865 10 1 FAN FLÄKT
1-50
78 – 2 SCREW, SLOTTED SPÅRSKRUV M 5 X 6 - 4.8 FZB
82 0333 2212 00 16 SPRING WASHER FJÄDERBRICKA 4,1 / 7,6 X 1,0 FZB
84 0333 2215 00 2 SPRING WASHER FJÄDERBRICKA 5,1 / 9,2 X 1,3 FZB
86 0266 2106 00 12 NUT MUTTER M 4 - 8 FZB
100 0017 2010 20 15M CABLE, 1-CORE KABEL, 1-LEDARE RK 0,75MM2 RED
101 0017 2100 20 15M CABLE, 1-CORE KABEL, 1-LEDARE RK 0,75MM2 BLUE
106 9139 6002 38 130 END SOCKET ÄNDHYLSA SIZE 0,5 - 8 0,5 MM2
B0023763
702
3217 8957 42 010K

703
CONTROL PANELMANÖVERPANEL
B0009369
704

1 9111 3703 18 1 COVER LOCK
2 9111 3703 15 1 BOX LÅDA
3 9111 3703 20 1 YOKE BYGEL
4 9111 3703 25 1 COVER KÅPA
5 9110 9591 12 1 ARM REST ARMSTÖD
6 9111 3703 30 1 HINGE GÅNGJÄRN
7 1088 0401 05 1 FLANGE FLÄNS TÄCKFLÄNS FLT21 E2631007
8 9111 3707 62 1 FLANGE FLÄNS
10 1088 0498 05 2 GASKET PACKNING FL 21 STOHNE NR. 503162
12 0266 1110 00 8 NUT MUTTER M 8-8
13 0298 1000 19 16 BLIND RIVET NUT BLINDNITMUTTER M 6 - STEEL FZB
16 0266 2108 00 12 NUT MUTTER M 6 - 8 FZB
9111 3703 08 002K

705
EMERG.SET / NÖDSTOPPSATS 5112 3158 44
EMERG.SETNÖDSTOPPSATS
X0000000
706
EMERG.SET / NÖDSTOPPSATS 5112 3158 44

1 3217 0010 79 1 MUSHROOM PUSHB. SVAMPTRYCKE TRIGGER ACTION/TURN RESET
5112 3158 44 001K

707
CONTROLER / KONTROLLER 3176 4341 20
CONTROLERKONTROLLER
B0006811
708
CONTROLER / KONTROLLER 3176 4341 20

1 3176 4341 23 1 PROTECT.BELLOWS SKYDDSBÄLG
2 3176 4341 02 1 BELLOW BÄLG
3 3176 4341 03 1 RUBBER PACKING GUMMIPACKNING
4 3176 4341 04 2 MICRO SWITCH MICROBRYTARE
5 3176 4341 05 1 HANDLE HANDTAG
6 3176 4341 06 1 ROCKER VIPPA
7 3176 4341 07 9 CONTACT BLOCK KONTAKTBLOCK
3176 4341 20 005K

709
B0032447
710

1-50
TERMINAL MARKERS
9111 3671 80 010K

711
B0032448
712

9111 3671 01 1 JUNCTION BOX KOPPLINGSLÅDA
9111 3671 10 009K

713
JUNCTION BOX / KOPPLINGSLÅDA
B0059889
714
JUNCTION BOX / KOPPLINGSLÅDA

– 1 CABLE SET KABELSATS Page 718
9 3217 8402 00 1 FRAME RAM
11 3217 8403 00 100 SLEEVE HYLSA
14 3217 8278 00 36 SLEEVE HYLSA
19 3176 4049 07 55 TERMINAL BLOCK KOPPLINGSPLINT ZDU 2.5/2X2AN
26 3217 8265 00 2 FUSE HOLDER SÄKRINGSHÅLLARE
27 3176 4156 00 1 FUSE SÄKRING 8A 25MM
8A 25MM
28 1089 9037 10 1 FUSE SÄKRING 0,8A SNABB 5X20
9111 3676 06 002K

715
CABLE SET / KABELSATS
CABLE SETKABELSATS
Fig. 1 of 2
B0059890
716
Fig. 2 of 2
9111 3555 42 004K

717

1A 3217 9882 51 5 VALVE PLUG VENTILKONTAKT
1B 3217 9882 51 2 VALVE PLUG VENTILKONTAKT
5A 3217 9882 11 2 SIGNAL CABLE SIGNALKABEL
B0059892
718
9111 3555 42 004K

719
ELECTRIC SET / ELSATS 9111 3688 10 EMERGENCY STOP
ELECTRIC SETELSATS
B0024566
720
ELECTRIC SET / ELSATS 9111 3688 10 EMERGENCY STOP

1 3217 0011 09 3 EMERG. STOP BOX NÖDSTOPPSLÅDA Page 723
M20X1,5 7-13 B1
9111 3688 10 008K

721
EMERG. STOP BOX / NÖDSTOPPSLÅDA 3217 0011 09
EMERG. STOP BOXNÖDSTOPPSLÅDA
X0000000
722
EMERG. STOP BOX / NÖDSTOPPSLÅDA 3217 0011 09

1 3176 0001 14 1 LIGHT EMIT. DIO LYSDIOD
M20X1,5 7-13 B1
3217 0011 09 001K

723
BASIC EL.CAB. / GRUNDELSKÅP
BASIC EL.CAB.GRUNDELSKÅP
B0026392
724
BASIC EL.CAB. / GRUNDELSKÅP

1 9106 1287 61 1 ELECTR.CABINET ELSKÅP Page 727 380-690V 50/60HZ
2 0392 1110 02 4 DAMPER DÄMPARE 50 / 36 60 IRH 1800
9111 3855 81 003K

725
ELECTR.CABINET / ELSKÅP 9106 1287 61 380-690V 50/60HZ
ELECTR.CABINETELSKÅP
B0055416
726
ELECTR.CABINET / ELSKÅP 9106 1287 61 380-690V 50/60HZ
(Sheet 1 of 3)
1 9106 1286 31 1 ELECTR.CABINET ELSKÅP Page 731
5 9106 1286 44 1 TOUCH GUARD BERÖRINGSSKYDD
C 69 3176 4325 03 1 CAPACITOR KONDENSATOR
ECL 3217 9871 00 1 PULSE UNIT PULSAGGREGAT
F 6 3217 9311 55 1 MOTORPROTECTOR MOTORSKYDDSBRYT
F 17 3176 4492 01 1 MIN CIRC BREAK AUTOMATSÄKRING 1-POL 6A
10A
F 66 3176 4258 01 1 MIN CIRC BREAK AUTOMATSÄKRING 2-POL. 6A G/U-CHARACT. *
F 91 3217 9873 02 1 EARTHFAULTRELAY JORDFELSRELÄ
H 35 3217 0010 47 1 LAMP CALOTTE LAMPKALOTT
H 35 3217 0010 59 5 LAMP INSERT LAMPINSATS
H 35 3217 0010 72 6 INTERMED. PART MELLANDEL
H 53 3217 0010 61 1 LAMP INSERT LAMPINSATS
K 10 3217 9666 02 1 EARTHFAULTRELAY JORDFELSRELÄ CONTREL ELR-3C 110V 0.3A
K 26 3217 9708 06 1 PHASE SEQ.RELAY FASFÖLJDSVAKT 3*200-500VAC
CSA APPROVED
K 28 3035 3313 73 1 AUX. CONTACT HJÄLPBLOCK
K 28 3217 9787 53 1 RELAY RELÄ
K 28 9111 3734 31 1 TRANSIENT PROT. TRANSIENTSKYDD
9106 1287 61 014K

727
ELECTR.CABINET / ELSKÅP 9106 1287 61
(Sheet 2 of 3)
K 29 3176 4108 00 1 DIODE DIOD
K 29 3176 4261 01 1 RELAY RELÄ INSTICKS- 11-POL
K 29 3176 4324 02 1 RELAY SOCKET RELÄSOCKEL SR3P-05 11-POLIG
K 30 3217 9787 53 1 RELAY RELÄ
K 30T 3217 9788 51 1 TIMING RELAY TIDRELÄ
K 31 3217 9583 01 1 RELAY RELÄ IK 8701.12 24V DC D & S
24 VOLT 16A
K 32 3176 0035 27 1 TIMING RELAY TIDRELÄ
K 61 9106 1157 62 1 CONTACTOR KONTAKTOR
K 61 9111 3734 32 1 TRANSIENT PROT. TRANSIENTSKYDD 110-250V VARISTOR
K 61D 9106 1157 62 1 CONTACTOR KONTAKTOR
K 61D 9111 3734 32 1 TRANSIENT PROT. TRANSIENTSKYDD 110-250V VARISTOR
K 61DT 3217 9788 51 1 TIMING RELAY TIDRELÄ
K 61T 3217 9788 51 1 TIMING RELAY TIDRELÄ
K 61Y 9106 1157 61 1 CONTACTOR KONTAKTOR
K 61Y 9111 3734 32 1 TRANSIENT PROT. TRANSIENTSKYDD 110-250V VARISTOR
K 64 3035 3313 73 1 AUX. CONTACT HJÄLPBLOCK
K 64 3217 9787 53 1 RELAY RELÄ
K127 9106 1157 02 1 CONTACTOR KONTAKTOR
K127 9111 3734 31 1 TRANSIENT PROT. TRANSIENTSKYDD
K128 9111 3734 10 1 RELAY RELÄ CA3KN40BD 24VDC
K132 9106 1157 02 1 CONTACTOR KONTAKTOR
24 VOLT 16A
24 VOLT 16A
P 12 3217 9277 37 1 VOLT METER VOLTMETER 500V/5A
P 66 3217 9658 02 1 HOUR METER TIMRÄKNARE 12-24V DC SKENMONT. *)
B0055416
728
(Sheet 3 of 3)
Q 7 9106 1125 00 1 MAIN SWITCH HUVUDBRYTARE Page 737
S 32 3217 0010 02 1 TRIGGER TRYCKE ZB5-AA2
S 32 3217 0010 72 1 INTERMED. PART MELLANDEL
S 32 3217 0010 73 1 CONTACT BLOCK KONTAKTBLOCK NORMALLY OPEN
S 51 3217 9841 12 1 SWITCH STRÖMSTÄLLARE
T 10 3217 9655 22 1 TRANSFORMER TRANSFORMATOR
T 11 3217 9512 02 1 TRANSFORMER TRANSFORMATOR 400-690/110V 50VA
U 68 3176 4329 05 1 RECTIFIER LIKRIKTARE
U 68 3176 4329 30 1 COOLING FLANGE KYLFLÄNS
U158 3217 9674 07 1 BATTERY CHARGER BATTERILADDARE
U180 9106 0713 01 1 POWER UNIT STRÖMFÖRS.ENHET
V 33 3176 4326 01 1 DIODE UNIT DIODENHET
X1 3176 4049 00 2 TERMINAL BLOCK KOPPLINGSPLINT ZDU 2.5/4AN
X1 3176 4049 03 1 TERMINAL BLOCK KOPPLINGSPLINT
9106 1287 61 014K

729
ELECTR.CABINETELSKÅP
B0003573
730

1 9106 1286 40 1 CABINET SKÅP
2 9106 1286 44 1 TOUCH GUARD BERÖRINGSSKYDD
3 9106 1286 47 1 SLIDE LIST
4 – 1 MOUNTING PLATE MONTERINGSPLÅT
5 9106 1286 42 1 DOOR DÖRR Page 733
6 9106 1286 41 1 DOOR DÖRR Page 735
7 9106 1286 63 1 MOUNTING PLATE MONTERINGSPLÅT
8 9106 1286 64 1 MOUNTING PLATE MONTERINGSPLÅT
11 0266 2110 00 6 NUT MUTTER M 8 - 8 FZB
12 0266 2107 00 2 NUT MUTTER M 5 - 8 FZB
15 0226 0350 05 8 TAPPING SCREW GÄNGANDE SKRUV A M5 8
9106 1286 31 002K

731
DOOR / DÖRR 9106 1286 42
DOORDÖRR
B0012955
732
DOOR / DÖRR 9106 1286 42

1 – 1 DOOR DÖRR
2 – 2 ROD STÅNG
3 9106 1120 13 2 ADAPTER ADAPTER
4 9106 1120 09 1 LATCH REGEL
6 0090 7005 01 2.10M RUBBERMOULDING GUMMILIST 15 X 10 MTRL. = EPDM
9106 1286 42 002K

733
DOOR / DÖRR 9106 1286 41
DOORDÖRR
B0012954
734
DOOR / DÖRR 9106 1286 41

1 9106 1286 55 1 DOOR DÖRR
2 – 2 ROD STÅNG
3 9106 1120 13 2 ADAPTER ADAPTER
4 9106 1120 09 1 LATCH REGEL
6 0090 7005 01 2.80M RUBBERMOULDING GUMMILIST 15 X 10 MTRL. = EPDM
9106 1286 41 002K

735
MAIN SWITCH / HUVUDBRYTARE 9106 1125 00
MAIN SWITCHHUVUDBRYTARE
B0001868
736
MAIN SWITCH / HUVUDBRYTARE 9106 1125 00

1 9106 1125 10 1 CONTACT BREAKER BRYTARE
2 9106 1125 11 1 OVERLOAD RELAY ÖVERSTRÖMSRELÄ
4 9106 1125 13 1 CONTACT BLOCK KONTAKTBLOCK
5 9106 1125 15 1 COIL SPOLE
6 9106 1125 16 1 PALM GRIP VRED
9106 1125 00 001K

737
THERMAL RELAYS / TERMISKA RELÄER
THERMAL RELAYSTERMISKA RELÄER
X0000000
738
THERMAL RELAYS / TERMISKA RELÄER

F 60 3217 9904 97 1 OVERLOAD RELAY ÖVERSTRÖMSRELÄ
F126 3217 9311 61 1 MOTORPROTECTOR MOTORSKYDDSBRYT GV2M16 9-14AMP
F126 3217 9311 70 1 AUX. CONTACTS HJÄLPKONTAKTER
F131 3217 9311 59 1 MOTORPROTECTOR MOTORSKYDDSBRYT
F131 3217 9311 70 1 AUX. CONTACTS HJÄLPKONTAKTER
9111 3855 60 003K

739
ELECTRIC SET / ELSATS
ELECTRIC SETELSATS
B0004139
740
ELECTRIC SET / ELSATS

1 – 1 CABLE SET KABELSATS
4 9106 1752 07 1 FLANGE FLÄNS
M20X1,5 7-13 B1
30 0694 5110 22 2 CABLE LUG KABELSKO RAK 50/M10
31 0694 5110 12 6 CABLE LUG KABELSKO RAK 25/M10
D=12 NORMA TYP RSGU
53 0346 3000 99 4 PIPE CLAMP RÖRKLAMMA D=35 SPAL5035-PP-DPAL-AS
MC6S M5X20-5.8 FZB
61 3217 9876 15 6 FLANGE FLÄNS
62 9106 1752 00 1 FLANGE FLÄNS
63 9106 1752 01 1 FLANGE FLÄNS
9111 3684 06 008K

741
LIGHT SET / BELYSNINGSSATS 9111 3229 00 1 X 200W - 24V
LIGHT SETBELYSNINGSSATS
B0058936
742
LIGHT SET / BELYSNINGSSATS 9111 3229 00 1 X 200W - 24V

2 3217 3841 80 1 HOLDER HÅLLARE Page 745
3 3217 9687 01 1 HEADLIGHT STRÅLKASTARE Page 747 200W 24V
M20X1,5 7-13 B1
7 3176 0001 27 1 OUTLET KIT UTTAGSSATS Page 749 TRIPOD
RUBBER-COVERED
9111 3229 00 006K

743
HOLDER / HÅLLARE 3217 3841 80
HOLDERHÅLLARE
B0000114
744
HOLDER / HÅLLARE 3217 3841 80

2 3217 3838 00 1 LOCK LEVER LÅSSPAK
3 3217 3839 00 1 PALM GRIP VRED
4 3217 4501 01 1 SPACER SLEEVE DISTANSHYLSA
3217 3841 80 001K

745
B0028990
746

1 3176 4303 01 1 HALOGEN LAMP HALOGENLAMPA 30V 200W R7S 63,6MM
3217 9687 01 002K

747
OUTLET KIT / UTTAGSSATS 3176 0001 27 TRIPOD
OUTLET KITUTTAGSSATS
X0000000
748
OUTLET KIT / UTTAGSSATS 3176 0001 27 TRIPOD

1 3176 0001 25 1 PLUG CONNECTOR STICKPROPP
2 3176 0001 26 1 SOCKET OUTLET STICKDOSA
3176 0001 27 001K

749
FLASHING BEACON / VARNINGSFYR
FLASHING BEACONVARNINGSFYR
B0007812
750
FLASHING BEACON / VARNINGSFYR

1 5112 3139 02 1 FLASH LIGHT BLIXTLJUS COMPLETE WHIT ATTACHMENTS
3 9111 3891 06 10M CABLE, 3-CORE KABEL, 3-LEDARE 3X1,5
4 0698 5140 06 1 CABLE GLAND KABELFÖRSKRUVN. PG11 5-9MM
5 9106 0649 55 1 PROTECTION CAP SKYDDSHUV
5112 3135 13 001D

751
CONTACT / KONTAKT 5112 3214 17
CONTACTKONTAKT
B0030323
752
CONTACT / KONTAKT 5112 3214 17

T102 5112 3166 53 1 VOLTAGE CONVERT SPÄNNINGSOMV. 24VDC->12VDC
X131 5112 0011 41 1 SOCKET OUTLET STICKDOSA 2-POL M LOCK,FLAT CONNECTORS
X131 5112 0011 42 1 PLUG CONNECTOR STICKPROPP 2 POL 18AMP
F8 5112 3043 10 1 FUSE CON. TERM. SÄKRINGSPLINT
F8 5112 3043 15 1 FUSE SÄKRING 10A
5112 3214 17 001K

753
STAIR LIGHTING / TRAPPBELYSNING 2X70W
STAIR LIGHTINGTRAPPBELYSNING
B0052264
754
STAIR LIGHTING / TRAPPBELYSNING 2X70W

S147 3217 0012 11 1 SWITCH VRED Page 759
W53 9111 3891 44 5M CABLE, 2-CORE KABEL, 2-LEDARE 2X1.5 D2=7.4
W71 9111 3891 44 10M CABLE, 2-CORE KABEL, 2-LEDARE 2X1.5 D2=7.4
K8 3217 9583 04 1 RELAY RELÄ
X7 5112 3217 81 1 JUNCTION BOX KOPPLINGSLÅDA Page 761
1 5112 3172 29 1 PLATE SKYLT
3217 8072 49 009K

755
B0048346
756

5112 3043 40 004K

757
SWITCH / VRED 3217 0012 11
SWITCHVRED
B0025274
758
SWITCH / VRED 3217 0012 11

1 3217 0010 11 1 CONTROL SWITCH MANÖVERSTÄLLARE 2 POSITION/STAY PUT
3217 0012 11 002K

759
B0040032
760

1-50
TERMINAL MARKERS
5112 3217 81 003K

761
762
ANGLE IND.COMPL / RIKTINSTR.KOMPL
LIST OF CONTENTS
9111 4066 18 ANGLE IND.COMPL RIKTINSTR.KOMPL 765
– – SYSTEM KIT RCS – SYSTEMSATS RCS 767 1 OPERATOR PANEL
9106 2257 25 – SENSOR SET – GIVARSATS 769
9106 2192 16 – – LINEAR SENSOR – – LÄNGDGIVARE 771
3128 3090 30 – SENSOR SET – GIVARSATS 773
9106 2192 04 – – INCLINOMETER – – LODGIVARE 775
– – SENSOR SET – GIVARSATS 777
9106 2192 04 – – INCLINOMETER – – LODGIVARE 775
– – CABLE SET RCS – KABELSATS RCS 779 ANGLE READING INSTRUMENT
– – CABLE SET RCS – KABELSATS RCS 781 HOLE DEPTH
– – ASSEMBLY SET – MONTERINGSSATS 783
763
ANGLE IND.COMPL / RIKTINSTR.KOMPL 9111 4066 18 ANGLE READING INSTRUMENT
ANGLE IND.COMPLRIKTINSTR.KOMPL
X0000000
764
ANGLE IND.COMPL / RIKTINSTR.KOMPL 9111 4066 18 ANGLE READING INSTRUMENT

10 – 1 SYSTEM KIT RCS SYSTEMSATS RCS Page 767 1 OPERATOR PANEL
11 – 1 PROGRAM PACKAGE PROGRAMPAKET ARI/FAM RCS4 REL. 4.53
20 9106 2257 25 1 SENSOR SET GIVARSATS Page 769
21 3128 3090 30 1 SENSOR SET GIVARSATS Page 773
22 – 1 SENSOR SET GIVARSATS Page 777
30 – 1 CABLE SET RCS KABELSATS RCS Page 779 ANGLE READING INSTRUMENT
31 – 1 CABLE SET RCS KABELSATS RCS Page 781 HOLE DEPTH
40 – 1 ASSEMBLY SET MONTERINGSSATS Page 783
41 9106 1914 10 1 ATTACHM.COMPLET FÄSTE KOMPLETT FAM DISPLAY
9111 4066 18 010K

765
SYSTEM KIT RCS / SYSTEMSATS RCS 1 OPERATOR PANEL
SYSTEM KIT RCSSYSTEMSATS RCS
X0000000
766
SYSTEM KIT RCS / SYSTEMSATS RCS 1 OPERATOR PANEL

D120 9106 0140 80 1 RESOLVER MODUL RESOLVERMODUL
D501 9106 2335 62 1 DISPLAY DISPLAY
9106 2468 12 003K

767
SENSOR SETGIVARSATS
B0042815
768

1 9106 2192 16 1 LINEAR SENSOR LÄNGDGIVARE Page 771
8 3128 3079 15 1 CHAIN CATCH KARBINHAKE L=60, D=6
9 3138 5051 23 1 BULLDOG GRIP LINLÅS
10 9106 2257 26 1 PLATE PLÅT
M6SF M 5 X 10 - 8.8 FZB
9106 2257 25 006K

769
LINEAR SENSOR / LÄNGDGIVARE 9106 2192 16
LINEAR SENSORLÄNGDGIVARE
B0047200
770
LINEAR SENSOR / LÄNGDGIVARE 9106 2192 16

43 9106 2192 20 1 WIRE ASSY WIRE KPL
48 9106 2192 21 1 POTENTIOMETER POTENTIOMETER
9106 2192 16 003K

771
SENSOR SETGIVARSATS
B0037085
772

1 9106 2192 04 1 INCLINOMETER LODGIVARE Page 775
3128 3090 30 004K

773
INCLINOMETER / LODGIVARE 9106 2192 04
INCLINOMETERLODGIVARE
B0050418
774
INCLINOMETER / LODGIVARE 9106 2192 04

1 – 1 HOUSING HUS
2 – 1 COVER LOCK
3 – 1 SENSOR SENSOR
4 – 1 PENDULUM PENDEL
5 0502 0105 00 2 BALL BEARING KULLAGER A 5 16 5 0,
7 – 1 SHAFT AXEL
8 3128 3062 45 1 CONNECTOR KONTAKTDON
11 0190 1242 00 1 SET SCREW STOPPSKRUV M 6 X 8 P6S DIN 913
12 3128 3081 47 1L OIL OLJA
13 – 1 PLUG PLUGG
14 0211 1105 01 3 HEX SOCK. SCREW SEXKANTHÅLSKRUV MC6S M 3 X 8 - ISO A4-50
9106 2192 04 001K

775
SENSOR SETGIVARSATS
B0009065
776

1 9106 2192 04 1 INCLINOMETER LODGIVARE Page 775
3128 3090 31 004K

777
CABLE SET RCS / KABELSATS RCS ANGLE READING INSTRUMENT
CABLE SET RCSKABELSATS RCS
B0054544
778
CABLE SET RCS / KABELSATS RCS ANGLE READING INSTRUMENT

1 9106 1593 33 1 MAIN CABLE MATNINGSKABEL
2 9106 1629 17 1 MAIN CABLE MATNINGSKABEL
3 3222 3323 38 1 CAN-OPEN CABLE CAN-OPEN KABEL
4 9106 1898 25 1 CAN-OPEN CABLE CAN-OPEN KABEL
5 9106 1447 65 1 SENSOR CABLE GIVARKABEL
6 9106 1725 43 1 SENSOR CABLE GIVARKABEL
7 9106 1902 51 1 CABLE KABEL
50 9106 2207 00 2 ADDRESS PLUG ADRESSPLUGG 5P M12 ADDRESS 0.250 KBIT BOOT
ADRESSPLUGG 0
51 9106 2066 78 1 TERMINATION AVSLUT (F)CANOPEN M12 TERM. 120R
52 9106 1828 34 1 TERMINATION AVSLUT CAN TERMINATION. MALE
END PLUGG
9106 2468 13 003K

779
CABLE SET RCS / KABELSATS RCS HOLE DEPTH
CABLE SET RCSKABELSATS RCS
B0050408
780
CABLE SET RCS / KABELSATS RCS HOLE DEPTH

10 9106 1629 16 1 CAN-CABLE CAN-KABEL
9106 1918 84 001K

781
B0013844
782

9111 3991 03 003K

783
784
AIR/WATERSYSTEM / LUFT/VATTENSYST
LIST OF CONTENTS
– AIR/WATERSYSTEM LUFT/VATTENSYST 789
9111 3592 31 – AIR/WATERSYSTEM – LUFT/VATTENSYST 791 SIMBA H-RIGS
3217 8667 52 – – LUBRICAT.PUMP – – SMÖRJPUMP 793 ECL-PUMP
3217 7403 80 – – OIL RESERVOIR – – OLJEBEHÅLLARE 795
3217 9997 00 – – SOLENOID VALVE – – MAGNETVENTIL 797 G1',40BAR
9111 4061 78 – – STRAINER – – SIL 799
3217 9192 50 – WATER PUMP UNIT – VATTENPUMPENHET 801
3217 9175 20 – – WATER PUMP SET – – VATTENPUMPSATS 803
3217 9255 50 – – – WATER PUMP – – – VATTENPUMP 805
– – WATER MIST COMP – WATERMIST KOMPL 809
9111 3615 00 – – AIR SYSTEM – – LUFTSYSTEM 812 AIR DRILLING SYSTEM
– – – – ELECTRIC SET – – – ELSATS 815 TOP HAMMER
9111 2699 00 – – – WATER PUMP – – – VATTENPUMP 817 WATERMIST
9111 2699 02 – – – – SEAL KIT – – – – TÄTNINGSSATS 821 INCL. 48-56
3176 8641 00 – – – PRESS.REGULATOR – – – TRYCKREGULATOR 827
3217 9339 00 – – – DIRECTION VALVE – – – RIKTNINGSVENTIL 829 133 K05 AXEL LARSSON
3217 9997 00 – – – SOLENOID VALVE – – – MAGNETVENTIL 797 G1',40BAR
3176 1856 00 – – – PRESS.REGULATOR – – – TRYCKREGULATOR 831 R17-801-RNLD R1
3163 0427 80 – – – STRAINER – – – SIL 833 FIG 12SG 2'BSP
3216 3466 80 – – – PRESS.REGULATOR – – – TRYCKREGULATOR 835
9111 3633 00 – – – JUNCTION BOX – – – KOPPLINGSLÅDA 837
3214 8520 80 – – – FLOW METER – – – FLÖDESMÄTARE 839
9106 1160 10 – ASSEMBLY SET – MONTERINGSSATS 843 COMPRESSOR
– – LAMP HOUSING – LAMPHUS 845 70W
785
– – ECL WARNING KIT – ECL-VARNING 847
– – – ELECTRIC SET – – ELSATS 849 WARNING KIT ECL
9106 2486 05 – CLEANING UNIT – TVÄTTUTRUSTNING 851
– – – WATER SET – – VATTENSATS 853 RIG WASHING KIT
– – – ELECTRIC SET – – ELSATS 855 RIG WASHING SET
3217 6514 83 – – – CONTROL BOX – – – MANÖVERLÅDA 857 STAINLESS
786
787
AIR/WATERSYSTEMLUFT/VATTENSYST
B0049856
788

500 9111 3592 31 1 AIR/WATERSYSTEM LUFT/VATTENSYST Page 791 SIMBA H-RIGS
502 3217 9192 50 1 WATER PUMP UNIT VATTENPUMPENHET Page 801
503 1080 2340 09 1 ELECTRIC MOTOR ELMOTOR 4KW 380-420/660V 50HZ
510 – 1 WATER MIST COMP WATERMIST KOMPL Page 809
520 8115 9018 06 1 COMPRESSOR KOMPRESSOR LE 7
ASL 2930140100
521 9106 1160 10 1 ASSEMBLY SET MONTERINGSSATS Page 843 COMPRESSOR
556 – 1 LAMP HOUSING LAMPHUS Page 845 70W
560 – 1 ECL WARNING KIT ECL-VARNING Page 847
910 9106 2486 05 1 CLEANING UNIT TVÄTTUTRUSTNING Page 851
1260 5001 36 001K

789
AIR/WATERSYSTEM / LUFT/VATTENSYST 9111 3592 31 SIMBA H-RIGS
AIR/WATERSYSTEMLUFT/VATTENSYST
B0060904
790
AIR/WATERSYSTEM / LUFT/VATTENSYST 9111 3592 31 SIMBA H-RIGS

A1 3222 3292 27 1 AIR VALVE LUFTVENTIL
1 3217 8667 52 1 LUBRICAT.PUMP SMÖRJPUMP Page 793 ECL-PUMP
3 3217 7403 80 1 OIL RESERVOIR OLJEBEHÅLLARE Page 795
4 3176 8695 00 1 PRESSURE GAUGE TRYCKMÄTARE G 1/8'
5 9093 0009 61 1 PRESS.REGULATOR TRYCKREGULATOR
8 0830 1008 44 1 SAFETY VALVE SÄKERHETSVENTIL 7,5 BAR ISO7-R 1/4 B14
9 9090 1172 00 1 PRESSURE GAUGE TRYCKMÄTARE 0-10 BAR G 1/8'
10 3177 7001 05 1 PRESSURE SWITCH TRYCKVAKT SUCO 7032-3 2BAR R1/4'
11 3217 9997 00 3 SOLENOID VALVE MAGNETVENTIL Page 797 G1',40BAR
12 3176 7208 00 1 NEEDLE VALVE NÅLVENTIL
13 0834 1194 05 1 SAFETY VALVE SÄKERHETSVENTIL HM - 72 RSK 5003421
AIR
16 9111 4061 78 1 STRAINER SIL Page 799
17 3176 5233 00 1 VALVE VENTIL
18 0823 0090 06 1 CHECK VALVE BACKVENTIL 25 G 1
19 – 5L COP OIL ECL OLJA
20 3115 3124 01 1 LABEL DEKAL
30 3217 9955 40 1 FLOW GUARD FLÖDESVAKT
32 3176 3152 00 1 BUSHING BUSSNING A G 1/2A G 1/4
TREDO 1/4
9111 3592 31 019K

791
LUBRICAT.PUMP / SMÖRJPUMP 3217 8667 52 ECL-PUMP
LUBRICAT.PUMPSMÖRJPUMP
B0032563
792
LUBRICAT.PUMP / SMÖRJPUMP 3217 8667 52 ECL-PUMP

4 3115 1648 01 1 COIL SPOLE 37W/24V
10 3115 1684 00 1 COUPLING KOPPLING INCL.CUTTING RING
11 3217 9273 00 1M POLYAMIDE HOSE POLYAMIDSLANG 13 9 ,1.8 X 3.2
SOLD BY THE METER
12 9090 1423 00 1 CONNECTION ANSLUTNING 1,8
3217 8667 52 009K

793
OIL RESERVOIR / OLJEBEHÅLLARE 3217 7403 80
OIL RESERVOIROLJEBEHÅLLARE
B0036558
794
OIL RESERVOIR / OLJEBEHÅLLARE 3217 7403 80

1 3217 7403 00 1 RESERVOIR BEHÅLLARE
2 0686 3716 02 2 PLUG PROPP G 1/2 A 5.8 FZB
3 0803 5012 04 1 FILTER PLUG FILTERPROPP G 1/2 - DN 15 - TYPE B
G 1/2 - DN 15 - TYPE B
4 0560 1305 03 1 ELBOW RÖRVINKEL RP 1/2 X ISO7-R 1/2 - 90
RP 1/2 X ISO7-R 1/2 - 90
5 3115 0212 00 1 STRAP BAGAGEBAND
6 3217 7403 01 1 COVER LOCK
3217 7403 80 007K

795
SOLENOID VALVE / MAGNETVENTIL 3217 9997 00 G1',40BAR
SOLENOID VALVEMAGNETVENTIL
B0043068
796
SOLENOID VALVE / MAGNETVENTIL 3217 9997 00 G1',40BAR

– 1 EXPLODED VIEW SPRÄNGBILD DRAWING
3222 3135 14 1 REPAIR SET REPARATIONSSATS POS. 1-8
1 – 1 COMPRESS.SPRING TRYCKFJÄDER NOT SOLD SEPARATELY
2 – 1 PISTON KOLV NOT SOLD SEPARATELY
3 – 1 FJÄDERRING FJÄDERRING NOT SOLD SEPARATELY
7 – 1 COIL SPOLE NOT SOLD SEPARATELY
8 – 1 COMPRESS.SPRING TRYCKFJÄDER NOT SOLD SEPARATELY
3217 9997 00 005K

797
STRAINER / SIL 9111 4061 78
STRAINERSIL
B0047277
798

9111 4061 93 1 SPARE PARTS SET RESERVDELSSATS INCL.POS.2,3,5
2 – 1 STRAINER SIL NOT SOLD SEPARATELY
9111 4061 78 002K

799
WATER PUMP UNIT / VATTENPUMPENHET 3217 9192 50
WATER PUMP UNITVATTENPUMPENHET
B0024326
800
WATER PUMP UNIT / VATTENPUMPENHET 3217 9192 50

1 3217 9175 20 1 WATER PUMP SET VATTENPUMPSATS Page 803
2 0633 3307 00 2 FLANGE FLÄNS 16 42,4 32 4
3 0650 0101 14 2 GASKET PACKNING 1 38 82 2
3217 9192 50 002K

801
WATER PUMP SET / VATTENPUMPSATS 3217 9175 20
WATER PUMP SETVATTENPUMPSATS
X0000000
802
WATER PUMP SET / VATTENPUMPSATS 3217 9175 20

1 3217 9255 50 1 WATER PUMP VATTENPUMP Page 805
2 5112 3082 99 1 HUB NAV
3217 9175 20 002K

803
WATER PUMP / VATTENPUMP 3217 9255 50
WATER PUMPVATTENPUMP
B0056871
804
(Sheet 1 of 2)
3217 9174 01 1 SHAFT SEAL AXELTÄTNING INCL.POS.22(2X),28.
3217 9174 12 1 SEAL KIT TÄTNINGSSATS INCL.POS.6,7,22(2X),38.
9 – 4 PULL ROD DRAGSTÅNG NOT SOLD SEPARATELY
10 – 1 DIFFUSOR DIFFUSOR NOT SOLD SEPARATELY
16 – 1 IMPELLER PUMPHJUL NOT SOLD SEPARATELY
19 – 1 SPACER DISTANS NOT SOLD SEPARATELY
29 – 1 DISK SKIVA NOT SOLD SEPARATELY
31 – 2 COUPLING HALF KOPPLINGSHALVA NOT SOLD SEPARATELY
3217 9255 50 004K

805
(Sheet 2 of 2)
35 – 2 PROTECTION SKYDD NOT SOLD SEPARATELY
B0056871
806
3217 9255 50 004K

807
WATER MIST COMP / WATERMIST KOMPL
WATER MIST COMPWATERMIST KOMPL
X0000000
808
WATER MIST COMP / WATERMIST KOMPL

1 9111 3615 00 1 AIR SYSTEM LUFTSYSTEM Page 812 AIR DRILLING SYSTEM
9111 4225 15 001K

809
AIR SYSTEM / LUFTSYSTEM 9111 3615 00 AIR DRILLING SYSTEM
AIR SYSTEMLUFTSYSTEM
Fig. 1 of 2
B0032491
810
AIR SYSTEM / LUFTSYSTEM 9111 3615 00 AIR DRILLING SYSTEM
Fig. 2 of 2
9111 3615 00 011K

811
AIR SYSTEM / LUFTSYSTEM 9111 3615 00

– 1 ELECTRIC SET ELSATS Page 815 TOP HAMMER
1 9111 2699 00 1 WATER PUMP VATTENPUMP Page 817 WATERMIST
2 3176 8641 00 1 PRESS.REGULATOR TRYCKREGULATOR Page 827
3 3217 9339 00 2 DIRECTION VALVE RIKTNINGSVENTIL Page 829 133 K05 AXEL LARSSON
4 3217 9997 00 2 SOLENOID VALVE MAGNETVENTIL Page 797 G1',40BAR
5 3176 1856 00 1 PRESS.REGULATOR TRYCKREGULATOR Page 831 R17-801-RNLD R1
6 9090 2052 00 1 MANOMETER MANOMETER 0-10BAR -50MM
7 3176 7208 00 1 NEEDLE VALVE NÅLVENTIL
8 3217 8943 02 1 CHECK VALVE BACKVENTIL IT-104-2' NORGREN PNEUMAT
9 3217 8943 01 1 CHECK VALVE BACKVENTIL IT-100-1.1/2' NORGREN PNE
10 3163 0427 80 1 STRAINER SIL Page 833 FIG 12SG 2'BSP
11 8202 0311 78 1 BALL VALVE KULVENTIL BAL-1A 50 G2'
12 3216 3466 80 1 PRESS.REGULATOR TRYCKREGULATOR Page 835
16 9090 1172 00 1 PRESSURE GAUGE TRYCKMÄTARE 0-10 BAR G 1/8'
AIR
30 3214 8520 80 1 FLOW METER FLÖDESMÄTARE Page 839
B0032490
812
AIR SYSTEM / LUFTSYSTEM 9111 3615 00
9111 3615 00 011K

813
ELECTRIC SET / ELSATS TOP HAMMER
ELECTRIC SETELSATS
X0000000
814
ELECTRIC SET / ELSATS TOP HAMMER

9111 3615 01 012K

815
WATER PUMP / VATTENPUMP 9111 2699 00 WATERMIST
WATER PUMPVATTENPUMP
B0006678
816
WATER PUMP / VATTENPUMP 9111 2699 00 WATERMIST
(Sheet 1 of 3)
9111 2699 02 1 SEAL KIT TÄTNINGSSATS Page 821 INCL. 48-56
4 9111 2699 04 1 PISTON KOLV
5 9111 2699 05 1 COVER LOCK
6 9111 2699 06 2 SCREW SKRUV
8 9111 2699 08 4 NUT MUTTER
10 9111 2699 10 8 WASHER BRICKA
11 9111 2699 11 1 CYLINDER CYLINDER
13 9111 2699 13 2 SCREW SKRUV
14 9111 2699 14 1 COVER LOCK
15 9111 2699 15 1 NIPPLE NIPPEL
16 9111 2699 16 1 PLUG PROPP HASKEL 17568-2
18 9111 2699 18 1 PISTON KOLV
19 9111 2699 19 2 PLUG PROPP HASKEL 16510
20 9111 2699 20 2 SPRING FJÄDER
21 9111 2699 21 1 HOUSE HUS
23 9111 2699 23 1 SLEEVE HYLSA
24 9111 2699 24 1 PISTON KOLV
26 9111 2699 26 1 NUT MUTTER
29 9111 2699 29 1 COVER LOCK
30 9111 2699 30 6 SCREW SKRUV
32 9111 2699 32 2 PISTON KOLV
33 9111 2699 33 2 SPRING FJÄDER
34 9111 2699 34 2 FITTING BLINDFÖRSKRUVN.
35 9111 2699 35 2 SEAT SÄTE
9111 2699 00 004K

817
(Sheet 2 of 3)
37 9111 2699 37 1 SLEEVE HYLSA
38 9111 2699 38 1 SLIDE SLID
39 9111 2699 39 1 PIPE RÖR
40 9111 2699 40 1 PIPE RÖR
43 9111 3928 00 1 POPPET VALVE SÄTESVENTIL
44 9111 3927 00 1 PISTON KOLV
45 9111 3928 01 1 PLUG PLUGG
47 9111 3929 00 1 RETAINER FASTHÅLLARE
52 – 2 SPACER DISTANS
53 – 2 RETAINING RING STOPPRING
60 – 1 RETAINER FASTHÅLLARE
64 – 1 PIN PINNE
65 9106 1462 17 2 SEAL TÄTNING
B0006678
818
(Sheet 3 of 3)
72 – 1 PISTON RING KOLVRING
9111 2699 00 004K

819
SEAL KIT / TÄTNINGSSATS 9111 2699 02
B0006678
820

53 – 2 RETAINING RING STOPPRING
9111 2699 02 002K

821
B0006678
822

60 – 1 RETAINER FASTHÅLLARE
9111 2699 03 002K

823
B0006678
824

64 – 1 PIN PINNE
65 9106 1462 17 2 SEAL TÄTNING
72 – 1 PISTON RING KOLVRING
9111 2699 01 002K

825
PRESS.REGULATOR / TRYCKREGULATOR 3176 8641 00
PRESS.REGULATORTRYCKREGULATOR
B0008018
826

3176 8641 00 002K

827
B0034201
828

1 3217 9339 01 1 COIL SPOLE
3217 9339 00 003K

829
X0000000
830

3177 0000 64 1 KIT SATS SERVICE KIT CONTAINS:
DIAPHRAM, ALL O-RINGS,
VALVE & VALVE SPRING.
3176 1856 00 002K

831
STRAINERSIL
B0000322
832

1 3163 0427 00 1 STRAINER DRUM SILTRUMMA
3163 0427 80 002K

833
B0000497
834

- 3216 3719 00 1 DIAPHRAGM MEMBRAN
- 3222 3098 17 1 REPAIR KIT RENOVERINGSSATS INCL.ITEMS 3,4A,5,7-13
3216 3466 80 004K

835
B0048821
836

1 3217 9927 00 1 JUNCTION BOX KOPPLINGSLÅDA
2 3176 4261 02 4 RELAY RELÄ INSTICKS- 11-POL.
3 3176 4324 02 4 RELAY SOCKET RELÄSOCKEL SR3P-05 11-POLIG
29 0333 2119 00 4 SPRING WASHER FJÄDERBRICKA 6,1 / 11,8 X 1,7
9111 3633 00 007K

837
FLOW METER / FLÖDESMÄTARE 3214 8520 80
FLOW METERFLÖDESMÄTARE
B0012459
838
FLOW METER / FLÖDESMÄTARE 3214 8520 80

1 3214 8399 00 1 VENTURI PIPE VENTURIRÖR
3 3176 6486 00 2 HOSE ASSEMBLY SLANGLEDNING 6,3X 1000 R2AT
4 3222 3289 42 1 FLOW GUARD FLÖDESVAKT
3214 8520 80 006K

839
HOSE SETSLANGSATS
B0015365
840

AP1 0574 6029 11 1 HOSE ASSEMBLY SLANGLEDNING 38 X 2400 R1T
AP10 0574 0000 18 1 HOSE ASSEMBLY SLANGLEDNING 25 X 1300 R2AT
HP 0574 0064 49 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 850 R2AT
LP 3176 5687 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 900 R2AT
9111 3959 26 001K

841
ASSEMBLY SET / MONTERINGSSATS 9106 1160 10 COMPRESSOR
B0011424
842
ASSEMBLY SET / MONTERINGSSATS 9106 1160 10 COMPRESSOR

2 9106 1215 09 1 SHIM SHIMS
5 9106 1215 14 1 STOP LUG STOPPKLACK
6 9106 1215 15 2 SLEEVE HYLSA
10 3176 5409 00 2 DAMPER DÄMPARE
9106 1160 10 009K

843
LAMP HOUSING / LAMPHUS 70W
LAMP HOUSINGLAMPHUS
B0004731
844
LAMP HOUSING / LAMPHUS 70W

1 9110 9557 00 1 LAMP HOLDER LAMPHÅLLARE
10 9106 1272 34 1 LAMP PROTECTION LAMPSKYDD
9106 1332 00 003K

845
ECL WARNING KIT / ECL-VARNING
ECL WARNING KITECL-VARNING
B0045078
846
ECL WARNING KIT / ECL-VARNING

1 – 1 ELECTRIC SET ELSATS Page 849 WARNING KIT ECL
2 9106 2192 15 1 SENSOR GIVARE
11 9111 3891 44 6M CABLE, 2-CORE KABEL, 2-LEDARE 2X1.5 D2=7.4
T- /SVIVELNUT
13 0570 5191 06 1 TEST CONNECTION TESTANSLUTNING UNF 7/8 - GR 1/4
TREDO 1/4
9111 4065 44 003K

847
ELECTRIC SET / ELSATS WARNING KIT ECL
ELECTRIC SETELSATS
B0036768
848
ELECTRIC SET / ELSATS WARNING KIT ECL

– 1 PLATE SKYLT SKYLT A-SKÅP
F89 3176 0015 33 1 FUSE HOLDER SÄKRINGSHÅLLARE FUSE SE 511
F89 5112 3214 43 1 FUSE SÄKRING
H40 3217 0010 47 1 LAMP CALOTTE LAMPKALOTT
H40 3217 0010 59 1 LAMP INSERT LAMPINSATS
H40 3217 0010 72 1 INTERMED. PART MELLANDEL
H41 3217 0010 47 1 LAMP CALOTTE LAMPKALOTT
H41 3217 0010 59 1 LAMP INSERT LAMPINSATS
H41 3217 0010 72 1 INTERMED. PART MELLANDEL
V34 3176 4326 01 1 DIODE UNIT DIODENHET
24 VOLT 16A
24 VOLT 16A
9111 4061 04 006K

849
CLEANING UNIT / TVÄTTUTRUSTNING 9106 2486 05
CLEANING UNITTVÄTTUTRUSTNING
B0055489
850
CLEANING UNIT / TVÄTTUTRUSTNING 9106 2486 05

1 – 1 WATER SET VATTENSATS Page 853 RIG WASHING KIT
2 – 1 ELECTRIC SET ELSATS Page 855 RIG WASHING SET
3 9106 2472 30 1 PLATE PLÅT
9106 2486 05 002K

851
WATER SET / VATTENSATS RIG WASHING KIT
WATER SETVATTENSATS
B0038223
852
WATER SET / VATTENSATS RIG WASHING KIT

1 3217 9390 01 1 NOZZLE MUNSTYCKE
2 3217 9783 02 1 HOSE REEL SLANGVINDA
4 3177 5048 01 1 BALL VALVE KULVENTIL
5 3177 5048 02 1 LEVER SPAK
6 0605 8823 00 1 BUSHING BUSSNING R 3/4 - R 3/8 STEEL
7 0607 2155 00 1 SOCKET RÖRMUFF G 3/4 33,5 36 B
8 3176 5588 10 2 U-BOLT U-BULT
9 8915 0026 62 1 PLATE SKYLT - FLUSHING WATER 50 50 -
10 8915 0021 08 1 INSTRUCTION SIG INSTRUKTIONSSKY I WATER PRESSURE WASH CON
9111 3893 10 008K

853
ELECTRIC SET / ELSATS RIG WASHING SET
ELECTRIC SETELSATS
B0035774
854
ELECTRIC SET / ELSATS RIG WASHING SET

1 3217 6514 83 1 CONTROL BOX MANÖVERLÅDA Page 857 STAINLESS
6 9111 3891 13 6M CABLE, 7-CORE KABEL, 7-LEDARE 7X1,5MM2
9111 3901 03 002K

855
CONTROL BOX / MANÖVERLÅDA 3217 6514 83 STAINLESS
B0045076
856
CONTROL BOX / MANÖVERLÅDA 3217 6514 83 STAINLESS

1 3217 9891 02 1 PUSH-BUTTON-BOX TRYCKKNAPPSLÅDA
2 3217 0010 22 1 PALM GRIP VRED
M20X1,5 7-13 B1
10 – 1 SIGN HOLDER SKYLTHÅLLARE
3217 6514 83 006K

857
858
HOSE CONNECTION / SLANGANSLUTNING
LIST OF CONTENTS
– HOSE CONNECTION SLANGANSLUTNING 862
859
HOSE CONNECTIONSLANGANSLUTNING
Fig. 1 of 2
B0054217
860
Fig. 2 of 2
1260 1001 23 051K

861
(Sheet 1 of 17)
1 3176 3556 00 1 NIPPLE NIPPEL UNF 9/16=HTXS10
1 3176 6495 00 1 NIPPLE NIPPEL UN 1 5/16
1 3176 6633 00 1 NIPPLE NIPPEL UN 1 5/8
1 3176 6634 00 1 NIPPLE NIPPEL UN 1 7/8
1 3176 6635 00 1 NIPPLE NIPPEL UN 2 1/2
1 3715 0581 00 1 NIPPLE NIPPEL UN 1 1/16
3A 3176 6501 00 1 NIPPLE NIPPEL UNF 3/4 - UNF 9/16
3A 3176 6503 00 1 NIPPLE NIPPEL UN 1 1/16 - UNF 9/16
3A 3176 6509 00 1 NIPPLE NIPPEL UN 1 5/16 - UN 1 1/16
UNF 3/4-UNF 7/16
3B 3176 6505 00 1 NIPPLE NIPPEL UN 1 1/16 - UNF 7/8
3B 3176 7336 00 1 NIPPLE NIPPEL UNF 7/8 - UNF 3/4
B0054218
862
(Sheet 2 of 17)
4 3176 7340 00 1 NIPPLE NIPPEL UNF 7/8 - UN 1 1/16
5 0570 5010 01 1 NIPPLE NIPPEL UN 1 5/16 - M27 X 2
5 0570 5010 12 1 NIPPLE NIPPEL UNF 7/16 - M10 X 1
5 3176 2929 00 1 NIPPLE NIPPEL UN 1 1/16 - M26 X 1,5
6 3176 8076 00 1 NIPPLE NIPPEL UN 1 1/16 - M33 X 2
1260 1001 23 051K

863
(Sheet 3 of 17)
7 3176 6514 00 1 NIPPLE NIPPEL UNF 7/8 - R 3/8
7 3176 6518 00 1 NIPPLE NIPPEL UN 1 1/16 - G 1
B0054218
864
(Sheet 4 of 17)
9 3176 6534 00 1 NIPPLE NIPPEL UNF 7/8 - UN 1 1/16
10 0570 5010 06 1 NIPPLE NIPPEL UN 1 1/16 - NPTF 1
10 0570 5010 10 1 NIPPLE NIPPEL UN 1 5/16 - NPTF 1 1/4
1260 1001 23 051K

865
(Sheet 5 of 17)
UNF 9/16-NPTF 1/8 STRAIGHT
11 3176 8711 00 1 NIPPLE NIPPEL UN 2 1/2 - RD 65-6
11 3176 8872 00 1 NIPPLE NIPPEL UN 1 7/8 - RG 65-6
12 0570 5011 06 1 STRAIGHT COUPL. RAK KOPPLING UN 1 1/16 - ISO 7-R 1/2
13 0570 5011 05 1 STRAIGHT COUPL. RAK KOPPLING UNF 7/16 - M10 X 1
UNF 9/16-G 1/4 INV.STRAIGHT
14 3176 6528 00 1 NIPPLE NIPPEL UNF 1 1/16 - G 3/4
B0054218
866
(Sheet 6 of 17)
17 3176 3045 80 1 PIPE COUPLING RÖRKOPPLING UNF 9/16
17 3176 3046 80 1 PIPE COUPLING RÖRKOPPLING UNF 3/4
17 3176 3048 80 1 PIPE COUPLING RÖRKOPPLING UN 1 1/16
17 3176 3049 80 1 PIPE COUPLING RÖRKOPPLING UN 1 5/16
18 3176 2821 00 1 NIPPLE NIPPEL UNF 3/4 - 15
18 3176 3053 00 1 NIPPLE NIPPEL UN 1 1/16 - 20
1260 1001 23 051K

867
(Sheet 7 of 17)
18 3217 7310 00 1 NIPPLE NIPPEL UN 1 5/16 - 22
19 0570 5040 15 1 STRAIGHT NIPPLE RAK NIPPEL UN 1 7/8 - G 1 1/4
22 0570 5080 05 1 NIPPLE NIPPEL UN 1 5/8
23 3176 1947 00 1 NIPPLE NIPPEL UN 1 3/16
23 3176 6039 00 1 NIPPLE NIPPEL UN 1 5/16
23 3176 6668 00 1 NIPPLE NIPPEL UN 1 5/8
23 3176 6669 00 1 NIPPLE NIPPEL UN 1 7/8
23 3176 6670 00 1 NIPPLE NIPPEL UN 2 1/2
23 3176 7872 00 1 ELBOW NIPPLE VINKELNIPPEL UNF 7/16
B0054218
868
(Sheet 8 of 17)
24 3176 6660 00 1 NIPPLE NIPPEL UN 1 5/8
24 3176 6661 00 1 NIPPLE NIPPEL UN 1 7/8
24 3176 6662 00 1 NIPPLE NIPPEL UN 2 1/2
90 DEGREE
1260 1001 23 051K

869
(Sheet 9 of 17)
28 3176 6571 00 1 ELBOW RÖRVINKEL UN 1 1/16 - UN 1 1/16
B0054218
870
(Sheet 10 of 17)
UNF 3/4-NPTF 3/8 90 DEGREE
30A 0570 5090 13 1 NIPPLE NIPPEL UNF 7/16 - NPTF 1/4
30A 0570 5090 14 1 NIPPLE NIPPEL UN 1 1/16 - NPTF 3/4
30A 0570 5090 37 1 NIPPLE NIPPEL UN 1 5/16 - NPTF 1
30A 0570 5090 38 1 NIPPLE NIPPEL UN 1 5/8 - NPTF 1 1/4
30B 0570 5090 15 1 NIPPLE NIPPEL UNF 7/16 - NPTF 1/4
30B 0570 5090 30 1 NIPPLE NIPPEL UN 1 1/16 - NPTF 3/4
30B 0570 5090 31 1 NIPPLE NIPPEL UN 1 5/16 - NPTF 1
30B 0570 5090 32 1 NIPPLE NIPPEL UN 1 5/8 - NPTF 1 1/4
UN 1 5/16-NPTF 1 45GRAD
1260 1001 23 051K

871
(Sheet 11 of 17)
33 3176 6574 00 1 NIPPLE NIPPEL UN 1 1/16
33 3176 6575 00 1 NIPPLE NIPPEL UN 1 5/16
33 3176 6679 00 1 NIPPLE NIPPEL UN 1 5/8
33 3176 6680 00 1 NIPPLE NIPPEL UN 1 7/8
33 3176 6681 00 1 NIPPLE NIPPEL UN 2 1/2
34 3176 6577 00 1 NIPPLE NIPPEL UN 1 1/16
34 3176 6578 00 1 NIPPLE NIPPEL UN 1 5/16
34 3176 6682 00 1 NIPPLE NIPPEL UN 1 5/8
34 3176 6683 00 1 NIPPLE NIPPEL UN 1 7/8
34 3176 6684 00 1 NIPPLE NIPPEL UN 2 1/2
T- /SVIVELNUT
35 3176 6591 00 1 NIPPLE NIPPEL UN 1 1/16
35 3176 6592 00 1 NIPPLE NIPPEL UN 1 5/16
35 3176 6690 00 1 NIPPLE NIPPEL UN 1 5/8
35 3176 6691 00 1 NIPPLE NIPPEL UN 1 7/8
35 3176 6692 00 1 NIPPLE NIPPEL UN 2 1/2
B0054218
872
(Sheet 12 of 17)
UNF 7/8-G 1/2
1260 1001 23 051K

873
(Sheet 13 of 17)
43 0570 5140 05 1 NIPPLE NIPPEL UN 1 1/16
B0054218
874
(Sheet 14 of 17)
44 3176 6496 00 1 NIPPLE NIPPEL UNF 9/16=WTXNS10
UNF 9/16
44 3176 6499 00 1 NIPPLE NIPPEL UN 1 1/16
44 3176 6500 00 1 NIPPLE NIPPEL UN 1 5/16
44 3176 6636 00 1 NIPPLE NIPPEL UN 1 5/8
44 3176 6637 00 1 NIPPLE NIPPEL UN 1 7/8
44 3176 6638 00 1 NIPPLE NIPPEL UN 2 1/2
46 3455 0543 06 1 NIPPLE NIPPEL UN 1 1/16
46 3455 0543 07 1 NIPPLE NIPPEL UN 1 5/16
46 3455 0543 08 1 NIPPLE NIPPEL UN 1 5/8
47A 3176 8927 00 1 NIPPLE NIPPEL UNF 7/8
49A 0570 5190 11 1 ADAPTER SLEEVE KLÄMHYLSA FÖR RÖR D=32
1260 1001 23 051K

875
(Sheet 15 of 17)
49B 0570 5190 02 1 ADAPTER SLEEVE KLÄMHYLSA FÖR RÖR D=1/4
49B 0570 5190 06 1 ADAPTER SLEEVE KLÄMHYLSA FÖR RÖR D=1
49B 0570 5190 07 1 ADAPTER SLEEVE KLÄMHYLSA FÖR RÖR D=1 1/4
49B 0570 5190 08 1 ADAPTER SLEEVE KLÄMHYLSA FÖR RÖR D=1 1/2
50 3176 5563 00 1 PLUG PLUGG UNF 3/4
50 3176 6698 00 1 PLUG PLUGG UN 1 5/8
50 3176 6699 00 1 PLUG PLUGG UN 1 7/8
50 3176 6700 00 1 PLUG PLUGG UN 2 1/2
50 3176 8289 00 1 PLUG PLUGG UNF 7/16
50 3715 0598 00 1 PLUG PLUGG UN 1 1/16
50 3715 0599 00 1 PLUG PLUGG UNF 7/8
50 3715 0600 00 1 PLUG PLUGG UNF 9/16
50 3715 0821 00 1 PLUG PLUGG UN 1 5/16
51 3176 5313 00 1 CAP HUV UNF 3/4
51 3176 5429 00 1 CAP HUV UNF 9/16
51 3176 6701 00 1 CAP HUV UN 1 5/8
51 3176 6702 00 1 CAP HUV UN 1 7/8
51 3176 6703 00 1 CAP HUV UN 2 1/2
51 3176 8029 00 1 CAP HUV UNF 7/16
51 3177 3197 00 1 CAP HUV UNF 1/2
51 3715 0597 00 1 CAP HUV UNF 7/8
51 3715 0819 00 1 CAP HUV UN 1 5/16
51 3715 0820 00 1 CAP HUV UN 1 1/16
B0054218
876
(Sheet 16 of 17)
52A 0570 5191 05 1 TEST CONNECTION TESTANSLUTNING UNF 3/4 - G 1/4
52A 0570 5191 06 1 TEST CONNECTION TESTANSLUTNING UNF 7/8 - GR 1/4
52A 0570 5191 07 1 TEST CONNECTION TESTANSLUTNING UNF 9/16 - G 1/4
52B 0570 5191 08 1 TEST CONNECTION TESTANSLUTNING UN 1 1/16 - G 1/4
52B 0570 5191 09 1 TEST CONNECTION TESTANSLUTNING UN 1 5/16 - G 1/4
53 0584 0004 00 1 CUTTING RING SKÄRRING 6 - PRESS.WORK 100 BAR
53 0584 0027 00 1 CUTTING RING SKÄRRING Y 1 - 15
53 0584 0064 00 1 CUTTING RING SKÄRRING Y1-8
54 0584 2004 00 1 NUT MUTTER M 10X1 - 6-LL DIN 3870
54 0584 2022 00 1 NUT MUTTER M 12X1,5 - 6-L DIN 3870
54 0584 2062 00 1 NUT MUTTER M 14X1,5 - 6-S DIN 3870
54 0584 2074 00 1 NUT MUTTER M 36X2 - 25-S DIN 3870
EXTRA LONG, FOR FEED BULKHEAD
1260 1001 23 051K

877
(Sheet 17 of 17)
878
HOSES / SLANGAR
LIST OF CONTENTS
– HOSES SLANGAR 881
879
HOSES / SLANGAR
HOSESSLANGAR
B0015365
880
HOSES / SLANGAR
(Sheet 1 of 10)
AP1 0574 6029 11 1 HOSE ASSEMBLY SLANGLEDNING 38 X 2400 R1T
AP10 0574 0000 18 1 HOSE ASSEMBLY SLANGLEDNING 25 X 1300 R2AT
8991 9808 00 003K

881
HOSES / SLANGAR
(Sheet 2 of 10)
BD3 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
BR3 0574 0260 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 650 R2AT
BS20 0574 0073 76 1 HOSE ASSEMBLY SLANGLEDNING 12,5 X 450 R9R
BU1 0574 1566 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2500 R9R
DF 0574 4319 11 1 HOSE ASSEMBLY SLANGLEDNING 25 X 670 R2AT
DKV 0574 0320 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 5700 R2AT
B0015365
882
HOSES / SLANGAR
(Sheet 3 of 10)
DP 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
DP1 0574 1527 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2000 R9R
DR 3176 7665 00 1 HOSE ASSEMBLY SLANGLEDNING 19 X 600 R2AT
DS1 0574 0000 93 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 3700 R9R
8991 9808 00 003K

883
HOSES / SLANGAR
(Sheet 4 of 10)
GF 0574 0253 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 300 R2AT
GGF 3176 6856 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 3000 R2AT
GGR 3176 6856 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 3000 R2AT
GGW 3176 6856 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 3000 R2AT
GRT 3176 6486 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 1000 R2AT
GR3 3176 5680 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3 X 800 R2AT
HP 0574 0064 49 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 850 R2AT
B0015365
884
HOSES / SLANGAR
(Sheet 5 of 10)
LG 0574 0253 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 300 R2AT
LP 3176 5687 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 900 R2AT
LU1 0574 1527 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2000 R9R
8991 9808 00 003K

885
HOSES / SLANGAR
(Sheet 6 of 10)
PF1 0574 0063 90 1 HOSE ASSEMBLY SLANGLEDNING 25 X 5000 R9R
PG 3176 6854 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 600 R2AT
PR1 0574 0064 37 1 HOSE ASSEMBLY SLANGLEDNING 25 X 4400 R9R
PS1 0574 4509 11 1 HOSE ASSEMBLY SLANGLEDNING 25 X 600 R9R
P3 0574 2270 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X1300 R2AT
P5 3176 5681 00 1 HOSE ASSEMBLY SLANGLEDNING 10 X 600 R2AT
B0015365
886
HOSES / SLANGAR
(Sheet 7 of 10)
8991 9808 00 003K

887
HOSES / SLANGAR
(Sheet 8 of 10)
STT1 0574 2284 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 3400 R2AT
ST1 0574 2273 11 1 HOSE ASSEMBLY SLANGLEDNING 12,5X1600 R2AT
SU1 5107 1536 00 1 HOSE ASSEMBLY SLANGLEDNING
B0015365
888
HOSES / SLANGAR
(Sheet 9 of 10)
TBU1 0574 1566 11 1 HOSE ASSEMBLY SLANGLEDNING 10 X 2500 R9R
TF 3176 5672 00 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 1500 R2AT
TF1 3176 6862 00 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 700 R2AT
TF12 3176 7449 00 1 HOSE ASSEMBLY SLANGLEDNING D6,3X1100 R2AT
TRF 0574 3261 11 1 HOSE ASSEMBLY SLANGLEDNING 19 X 700 R2AT
TR1 0574 0000 17 1 HOSE ASSEMBLY SLANGLEDNING 25 X 1500 R2AT
TS1 0574 0000 17 1 HOSE ASSEMBLY SLANGLEDNING 25 X 1500 R2AT
WG 0574 0278 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 2200 R2AT
WR1 3176 6861 00 1 HOSE ASSEMBLY SLANGLEDNING 12,5X 500 R2AT
WSB1 0574 0564 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 2900 R9R
W1 0574 3260 48 1 HOSE ASSEMBLY SLANGLEDNING 25X2550 R9R
8991 9808 00 003K

889
(Sheet 10 of 10)
XDP 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
XFP 3176 6854 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 600 R2AT
XFS1 0574 0321 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 4500 R2AT
XFT 0574 0272 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 1500 R2AT
XP 0574 0255 11 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 400 R2AT
XS 3176 6486 00 1 HOSE ASSEMBLY SLANGLEDNING 6,3X 1000 R2AT
13 9030 0600 00 2 AIR HOSE LUFTSLANG 25 X 5
2 9030 1100 00 .30 AIR HOSE LUFTSLANG 80 X 8
3 3176 6486 00 2 HOSE ASSEMBLY SLANGLEDNING 6,3X 1000 R2AT
7 9030 0300 00 2 AIR HOSE LUFTSLANG 12,5 X 5
78 3176 1878 01 1 AIR HOSE LUFTSLANG PVC 06 6,3 500
890
CROSS REFERENCE LIST
Part no Description Ref See page Part no Description Ref See page
Detaljnr no Se sida Detaljnr no Se sida
0017 2010 20 CABLE, 1-CORE 100 702 0101 2316 00 PIN 33 541
0017 2010 20 CABLE, 1-CORE 51 676 0102 0423 00 PIN 2 67
0017 2010 40 CABLE, 1-CORE 53 676 0102 0460 00 PIN 156 14
0017 2010 50 CABLE, 1-CORE 55 676 0102 0460 00 PIN 7 51
0017 2016 02 CABLE, 1-CORE 54 676 0108 1200 00 SPRING PIN 3 491
0017 2060 40 CABLE, 1-CORE W189 313 0108 1400 00 SPRING PIN 9 393
0017 2060 40 CABLE, 1-CORE W188 313 0108 3392 00 SPRING PIN 4 441
0017 2060 40 CABLE, 1-CORE 1 753 0111 1307 00 SPLIT PIN 1 495
0017 2060 40 CABLE, 1-CORE 52 321 0129 3101 00 BLIND RIVET 15 715
0017 2060 40 CABLE, 1-CORE W10 313 0129 3104 00 BLIND RIVET 10 75
0017 2060 50 CABLE, 1-CORE 51 321 0129 3104 00 BLIND RIVET 45 321
0017 2060 70 CABLE, 1-CORE W188 313 0144 3326 03 SCREW, HEX HEAD 8 517
0017 2060 70 CABLE, 1-CORE 50 321 0144 3363 03 SCREW, HEX HEAD 4 265
0017 2060 70 CABLE, 1-CORE W187 313 0144 4000 32 SCREW, HEX HEAD 8 355
0017 2307 06 CABLE,41-CORE 1 699 0147 1170 03 SCREW, HEX HEAD 10 775
0090 7005 01 RUBBERMOULDING 6 735 0147 1244 03 SCREW, HEX HEAD 7 381
0090 7005 01 RUBBERMOULDING 6 733 0147 1244 03 SCREW, HEX HEAD 40 467
0101 2316 00 PIN 33 547 0147 1244 03 SCREW, HEX HEAD 14 320
891
0147 1246 03 SCREW, HEX HEAD 12 320 0147 1323 03 SCREW, HEX HEAD 11 843
892
893
894
0147 1484 03 SCREW, HEX HEAD 24 201 0160 1242 00 SCREW, SLOTTED 28 837
0147 1638 03 SCREW, HEX HEAD 10 195 0190 1242 00 SET SCREW 11 775
0147 1962 43 HEX. HEAD SCREW 44 202 0196 1552 09 SET SCREW 25 79
895
0196 1552 10 SET SCREW 11 277 0211 1440 00 SCREW 27 547
0196 1552 24 SET SCREW 2 403 0211 1477 03 SCREW 28 541
0211 1105 01 HEX SOCK. SCREW 14 775 0211 1960 78 SCREW 7 109
0211 1177 03 SCREW 14 743 0211 1960 79 SCREW 2 109
0211 1205 03 SCREW 13 731 0211 1960 82 SCREW 85 267
0211 1207 00 SCREW 9 285 0211 1960 84 SCREW 80 12
0211 1209 03 SCREW 20 673 0211 1960 84 SCREW 16 43
0211 1211 03 SCREW 30 552 0211 1960 84 SCREW 28 547
0211 1215 00 SCREW 7 136 0211 1960 86 SCREW 27 541
0211 1215 00 SCREW 3 389 0211 1962 79 SCREW 3 89
0211 1215 03 SCREW 2 625 0211 1962 80 SCREW 14 299
0211 1215 03 SCREW 3 607 0211 1962 88 SCREW 19 485
0211 1215 03 SCREW 17 576 0211 1962 91 SCREW 9 251
0211 1215 03 SCREW 6 513 0211 1962 92 SCREW 27 283
0211 1215 03 SCREW 3 605 0211 1962 93 SCREW 22 79
0211 1215 03 SCREW 11 552 0211 1962 94 SCREW 22 89
0211 1223 00 SCREW 8 136 0211 1962 95 SCREW 23 89
0211 1229 00 SCREW 4 609 0211 1962 99 SCREW 6 201
0211 1229 00 SCREW 53 137 0211 1963 02 SCREW 25 201
0211 1246 03 SCREW 14 705 0211 1963 02 SCREW 5 67
0211 1252 00 SCREW 13 593 0211 1963 18 SCREW 17 109
0211 1260 00 SCREW 15 255 0211 1963 34 SCREW 70 103
0211 1322 03 SCREW 72 103 0211 1963 35 SCREW 7 67
0211 1325 03 SCREW 2 409 0211 1963 42 SCREW 35 61
0211 1357 03 SCREW 71 103 0211 1963 42 SCREW 14 201
0211 1362 03 SCREW 30 127 0211 1963 51 SCREW 47 394
0211 1362 03 SCREW 20 111 0211 1963 91 SCREW 38 486
0211 1402 03 SCREW 61 103 0211 1964 35 HEX SOCK. SCREW 6 415
0211 1404 03 SCREW 4 211 0211 5363 00 SCREW 3 531
0211 1405 03 SCREW 8 225 0211 5365 00 SCREW 3 533
896
0211 5365 00 SCREW 3 529 0259 2044 00 THREAD INSERT 4 63
0216 1100 34 HEX SOCK. SCREW 4 175 0259 2044 00 THREAD INSERT 2 91
0226 0306 00 TAPPING SCREW 2 521 0259 2061 00 THREAD INSERT 7 11
0226 0326 00 TAPPING SCREW 11 769 0261 2106 00 NUT 14 697
0226 9915 12 SCREW 42 239 0266 2114 00 NUT 23 111
0244 4143 00 SCREW, DRIVE 29 201 0291 1112 00 LOCK NUT 4 235
0248 9979 54 THREADED ROD 7 111 0291 1128 13 LOCK NUT 16 743
0259 0011 00 THREAD INSERT 6 11 0291 1128 13 LOCK NUT 3 435
897
0291 1128 14 LOCK NUT 17 715 0291 1128 18 LOCK NUT 7 593
0291 1128 14 LOCK NUT 2 313 0291 1128 18 LOCK NUT 15 75
0291 1128 14 LOCK NUT 4 389 0291 1128 18 LOCK NUT 31 283
0291 1128 15 LOCK NUT 12 845 0291 1128 18 LOCK NUT 4 429
0291 1128 15 LOCK NUT 3 309 0291 1128 18 LOCK NUT 4 345
0291 1128 15 LOCK NUT 7 371 0291 1128 18 LOCK NUT 4 347
0291 1128 15 LOCK NUT 77 461 0291 1128 18 LOCK NUT 3 409
0291 1128 15 LOCK NUT 16 255 0291 1128 19 LOCK NUT 11 433
0291 1128 15 LOCK NUT 17 489 0291 1128 19 LOCK NUT 24 23
0291 1128 15 LOCK NUT 8 339 0291 1128 20 LOCK NUT 5 387
0291 1128 15 LOCK NUT 5 367 0291 1128 20 LOCK NUT 5 119
0291 1128 15 LOCK NUT 5 369 0291 1128 20 LOCK NUT 20 113
0291 1128 16 LOCK NUT 15 320 0291 1128 20 LOCK NUT 8 255
0291 1128 18 LOCK NUT 22 299 0291 1128 20 LOCK NUT 3 259
0291 1128 18 LOCK NUT 19 320 0291 1128 20 LOCK NUT 7 129
0291 1128 18 LOCK NUT 6 552 0291 1128 20 LOCK NUT 21 299
0291 1128 18 LOCK NUT 5 237 0291 1128 20 LOCK NUT 7 419
0291 1128 18 LOCK NUT 23 501 0291 1128 20 LOCK NUT 9 449
0291 1128 18 LOCK NUT 8 843 0291 1128 20 LOCK NUT 5 769
0291 1128 18 LOCK NUT 6 365 0291 1128 20 LOCK NUT 63 461
0291 1128 18 LOCK NUT 22 285 0291 1128 20 LOCK NUT 20 393
0291 1128 18 LOCK NUT 4 757 0291 1128 21 LOCK NUT 4 309
0291 1128 18 LOCK NUT 10 361 0291 1128 21 LOCK NUT 22 387
0291 1128 18 LOCK NUT 13 339 0291 1128 21 LOCK NUT 5 255
0291 1128 18 LOCK NUT 75 461 0291 1128 22 LOCK NUT 62 103
0291 1128 18 LOCK NUT 6 175 0291 1128 22 LOCK NUT 5 491
0291 1128 18 LOCK NUT 5 349 0291 1128 22 LOCK NUT 35 127
0291 1128 18 LOCK NUT 5 761 0291 1128 22 LOCK NUT 4 449
0291 1128 18 LOCK NUT 6 576 0291 1128 22 LOCK NUT 16 107
0291 1128 18 LOCK NUT 7 845 0291 1128 22 LOCK NUT 7 355
898
0291 1128 22 LOCK NUT 24 299 0295 3105 00 LOCK NUT 3 115
0291 1128 22 LOCK NUT 5 173 0295 3113 00 LOCK NUT 4 393
0291 1128 22 LOCK NUT 3 255 0296 1110 00 WING NUT 5 431
0291 1128 22 LOCK NUT 5 419 0298 1000 19 BLIND RIVET NUT 13 705
0291 1128 22 LOCK NUT 17 387 0299 1000 06 WHEEL NUT 2 399
0291 1128 25 LOCK NUT 53 103 0300 0276 27 PLAIN WASHER 56 103
899
0301 2321 00 PLAIN WASHER 5 309 0301 2335 00 PLAIN WASHER 4 365
0301 2335 00 PLAIN WASHER 28 255 0301 2358 00 WASHER 20 340
900
0301 2358 00 WASHER 6 491 0301 2378 00 PLAIN WASHER 3 299
0301 2358 00 WASHER 4 845 0304 1012 00 SPERIC WASHER 6 441
0301 2358 00 WASHER 6 745 0304 1062 00 SPERIC WASHER 7 441
0301 2358 00 WASHER 35 202 0324 1000 14 SPACER SLEEVE 6 449
0301 2371 00 PLAIN WASHER 6 211 0333 0500 03 CONICAL WASHER 7 89
0301 2378 00 PLAIN WASHER 11 595 0333 0500 08 CONICAL WASHER 15 111
0301 2378 00 PLAIN WASHER 55 103 0333 0500 24 SPERIC WASHER 1 427
0301 2378 00 PLAIN WASHER 6 517 0333 2119 00 SPRING WASHER 29 837
0301 2378 00 PLAIN WASHER 7 173 0333 3114 00 LOCK WASHER 13 697
901
0333 3132 00 LOCK WASHER 25 340 0346 1002 03 PIPE CLAMP 14 314
0335 1122 00 CIRCLIP 7 261 0346 1002 42 PIPE CLAMP 52 137
0335 1158 00 CIRCLIP 17 485 0347 4344 00 HOSE CLIP 90 267
0335 2173 00 CIRCLIP 9 43 0371 1100 02 LIFTING EYE 50 31
0335 2177 00 CIRCLIP 166 14 0384 3508 00 DISK SPRING 22 201
0335 2177 00 CIRCLIP 2 51 0384 3546 00 DISK SPRING 28 61
0335 2178 00 CIRCLIP 5 485 0392 1110 02 DAMPER 2 725
0335 3500 10 LOCK RING 15 43 0500 0324 00 PLAIN BEARING 46 299
0335 3500 10 LOCK RING 68 12 0500 1296 00 PLAIN BEARING 51 299
0339 1000 10 RING SPRING 18 201 0500 4500 11 BUSHING 5 489
0346 1000 07 PIPE CLAMP 16 320 0500 4500 28 FLANGE BEARING 8 195
0346 1002 01 PIPE CLAMP 3 343 0501 0000 72 BEARING,SP.PL. 26 102
902
0501 0019 00 BEARING,SP.PL. 20 229 0544 2362 00 GREASE NIPPLE 75 103
0501 0019 01 BEARING,SP.PL. 2 277 0544 2562 00 GREASE NIPPLE 2 389
0501 0019 01 BEARING,SP.PL. 27 102 0560 1305 03 ELBOW 4 795
0501 0019 01 BEARING,SP.PL. 6 111 0570 5000 06 NIPPLE 1 862
0502 0105 00 BALL BEARING 5 775 0570 5005 00 STRAIGHT NIPPLE 261 15
0502 1091 94 BALL BEARING 25 102 0570 5010 01 NIPPLE 5 863
0502 8010 21 BEARING HOUSING 1 397 0570 5010 06 NIPPLE 10 865
0503 2109 00 BALL BEARING 2 397 0570 5010 07 NIPPLE 9 864
0509 0221 00 ROLLER BEARING 121 13 0570 5010 09 NIPPLE 10 865
0516 1504 01 NEEDLE BEARING 124 13 0570 5010 13 NIPPLE 7 863
0544 2162 00 GREASE NIPPLE 106 13 0570 5010 17 NIPPLE 5 863
0544 2162 00 GREASE NIPPLE 7 39 0570 5011 05 STRAIGHT COUPL. 13 866
0544 2162 00 GREASE NIPPLE 6 195 0570 5011 06 STRAIGHT COUPL. 12 866
903
0570 5020 08 NIPPLE 16 867 0570 5090 26 NIPPLE 30 871
0570 5040 02 NIPPLE 19 868 0570 5090 27 NIPPLE 30 871
0570 5040 03 NIPPLE 37 136 0570 5090 28 NIPPLE 30B 871
0570 5040 03 NIPPLE 19 868 0570 5090 29 NIPPLE 30B 871
0570 5040 04 NIPPLE 20 868 0570 5090 30 NIPPLE 30B 871
0570 5040 05 NIPPLE 19 868 0570 5090 31 NIPPLE 30B 871
0570 5040 06 NIPPLE 19 868 0570 5090 32 NIPPLE 30B 871
0570 5040 07 NIPPLE 19 868 0570 5090 33 NIPPLE 30B 871
0570 5040 15 STRAIGHT NIPPLE 19 868 0570 5090 34 NIPPLE 30A 871
0570 5041 05 NIPPLE 21 868 0570 5090 35 NIPPLE 30A 871
0570 5041 06 NIPPLE 21 868 0570 5090 36 NIPPLE 30A 871
0570 5080 05 NIPPLE 22 868 0570 5090 37 NIPPLE 30A 871
0570 5090 01 NIPPLE 30 870 0570 5090 38 NIPPLE 30A 871
0570 5090 02 NIPPLE 25 869 0570 5090 45 NIPPLE 26 869
0570 5090 03 NIPPLE 32 872 0570 5110 01 NIPPLE 35 872
0570 5090 04 NIPPLE 32 872 0570 5110 03 NIPPLE 34 872
0570 5090 08 NIPPLE 30 870 0570 5120 01 NIPPLE 37 873
0570 5090 12 NIPPLE 31 871 0570 5120 03 NIPPLE 36 873
0570 5090 13 NIPPLE 30A 871 0570 5120 04 NIPPLE 36 873
0570 5090 14 NIPPLE 30A 871 0570 5120 05 NIPPLE 37 873
0570 5090 15 NIPPLE 30B 871 0570 5120 07 NIPPLE 41 874
0570 5090 16 NIPPLE 30 870 0570 5120 08 NIPPLE 41 874
0570 5090 18 NIPPLE 27 870 0570 5120 09 NIPPLE 41 874
0570 5090 19 NIPPLE 25 869 0570 5120 10 NIPPLE 41 874
0570 5090 20 NIPPLE 25 869 0570 5120 11 NIPPLE 41 874
0570 5090 21 NIPPLE 30 870 0570 5120 12 NIPPLE 41 874
0570 5090 22 NIPPLE 30 871 0570 5120 13 NIPPLE 41 874
0570 5090 23 NIPPLE 30 871 0570 5140 05 NIPPLE 43 874
0570 5090 24 NIPPLE 30 871 0570 5160 05 NIPPLE 47 875
0570 5090 25 NIPPLE 30 870 0570 5190 02 ADAPTER SLEEVE 49B 876
904
0570 5190 03 ADAPTER SLEEVE 49B 876 0574 0000 70 HOSE ASSEMBLY C1 645
0570 5190 04 ADAPTER SLEEVE 49B 876 0574 0000 74 HOSE ASSEMBLY TS7 641
0570 5190 05 ADAPTER SLEEVE 49B 876 0574 0000 74 HOSE ASSEMBLY TS7 889
0570 5190 06 ADAPTER SLEEVE 49B 876 0574 0000 87 HOSE ASSEMBLY W9 633
0570 5190 07 ADAPTER SLEEVE 49B 876 0574 0000 87 HOSE ASSEMBLY W9 890
0570 5190 08 ADAPTER SLEEVE 49B 876 0574 0000 93 HOSE ASSEMBLY DS1 97
0570 5190 11 ADAPTER SLEEVE 49A 875 0574 0000 93 HOSE ASSEMBLY DS1 883
0570 5191 05 TEST CONNECTION 23 265 0574 0063 64 HOSE ASSEMBLY BS10 73
0570 5191 05 TEST CONNECTION 52A 877 0574 0063 64 HOSE ASSEMBLY BS10 882
0570 5191 06 TEST CONNECTION 16 265 0574 0063 70 HOSE ASSEMBLY RHA5 139
0570 5191 06 TEST CONNECTION 52A 877 0574 0063 70 HOSE ASSEMBLY RHA5 886
0570 5191 07 TEST CONNECTION 29 266 0574 0063 90 HOSE ASSEMBLY PF1 886
0570 5191 07 TEST CONNECTION 52A 877 0574 0063 90 HOSE ASSEMBLY S7 888
0570 5191 08 TEST CONNECTION 52B 877 0574 0063 90 HOSE ASSEMBLY S7 641
0570 5191 09 TEST CONNECTION 52B 877 0574 0063 90 HOSE ASSEMBLY PF1 633
0574 0000 17 HOSE ASSEMBLY TR1 889 0574 0064 37 HOSE ASSEMBLY PR1 886
0574 0000 17 HOSE ASSEMBLY TS1 635 0574 0064 37 HOSE ASSEMBLY PR1 633
0574 0000 17 HOSE ASSEMBLY TS1 889 0574 0064 49 HOSE ASSEMBLY HP 841
0574 0000 17 HOSE ASSEMBLY TR1 635 0574 0064 49 HOSE ASSEMBLY HP 884
0574 0000 18 HOSE ASSEMBLY AP10 881 0574 0064 54 HOSE ASSEMBLY AP6 841
0574 0000 18 HOSE ASSEMBLY AP10 841 0574 0064 54 HOSE ASSEMBLY AP6 881
0574 0000 39 HOSE ASSEMBLY ST2 888 0574 0064 65 HOSE ASSEMBLY LU5 885
0574 0000 39 HOSE ASSEMBLY ST2 269 0574 0064 65 HOSE ASSEMBLY JS9 885
0574 0000 66 HOSE ASSEMBLY T41 633 0574 0064 65 HOSE ASSEMBLY DS5 651
0574 0000 66 HOSE ASSEMBLY T41 889 0574 0064 65 HOSE ASSEMBLY JS10 651
0574 0000 70 HOSE ASSEMBLY C2 882 0574 0064 65 HOSE ASSEMBLY JS9 651
0574 0000 70 HOSE ASSEMBLY C1 882 0574 0064 65 HOSE ASSEMBLY LU5 651
0574 0000 70 HOSE ASSEMBLY C2 645 0574 0064 65 HOSE ASSEMBLY DS5 883
905
0574 0064 65 HOSE ASSEMBLY JS10 884 0574 0068 17 HOSE ASSEMBLY AS62 463
0574 0064 71 HOSE ASSEMBLY 1BR1 890 0574 0068 17 HOSE ASSEMBLY AS60 463
0574 0065 21 HOSE ASSEMBLY RHA1 886 0574 0068 18 HOSE ASSEMBLY AS61 881
0574 0065 85 HOSE ASSEMBLY BU5 882 0574 0068 29 HOSE ASSEMBLY AS41 881
0574 0065 85 HOSE ASSEMBLY DP5 651 0574 0068 36 HOSE ASSEMBLY AS4 881
0574 0065 85 HOSE ASSEMBLY TBU5 889 0574 0068 36 HOSE ASSEMBLY AS4 463
0574 0065 85 HOSE ASSEMBLY DP5 883 0574 0068 38 HOSE ASSEMBLY AS8 881
0574 0065 85 HOSE ASSEMBLY BU5 651 0574 0068 38 HOSE ASSEMBLY AS8 469
0574 0065 85 HOSE ASSEMBLY TBU5 651 0574 0068 42 HOSE ASSEMBLY AS2 881
0574 0065 91 HOSE ASSEMBLY 2BR1 890 0574 0068 86 HOSE ASSEMBLY W11 889
0574 0068 03 HOSE ASSEMBLY AS6 469 0574 0068 86 HOSE ASSEMBLY W9 841
0574 0068 03 HOSE ASSEMBLY AS3 463 0574 0069 39 HOSE ASSEMBLY AS5 881
0574 0068 13 HOSE ASSEMBLY AS51 881 0574 0073 76 HOSE ASSEMBLY BS20 73
0574 0068 13 HOSE ASSEMBLY AS52 463 0574 0073 76 HOSE ASSEMBLY BS20 882
0574 0068 13 HOSE ASSEMBLY AS52 881 0574 0074 07 HOSE ASSEMBLY S5 888
0574 0068 13 HOSE ASSEMBLY AS51 463 0574 0074 07 HOSE ASSEMBLY S5 651
906
0574 0074 07 HOSE ASSEMBLY TS5 651 0574 0255 11 HOSE ASSEMBLY XP 890
0574 0074 07 HOSE ASSEMBLY TS5 889 0574 0255 11 HOSE ASSEMBLY RHG2 139
0574 0253 11 HOSE ASSEMBLY LG 885 0574 0255 11 HOSE ASSEMBLY DP 883
0574 0253 11 HOSE ASSEMBLY GF 884 0574 0255 11 HOSE ASSEMBLY RHF1 887
0574 0253 11 HOSE ASSEMBLY LG 635 0574 0255 11 HOSE ASSEMBLY AP13 841
0574 0253 11 HOSE ASSEMBLY 3BR3 269 0574 0255 11 HOSE ASSEMBLY RHF1 139
0574 0253 11 HOSE ASSEMBLY GR1 635 0574 0255 11 HOSE ASSEMBLY J53 885
0574 0253 11 HOSE ASSEMBLY GR1 884 0574 0255 11 HOSE ASSEMBLY J54 885
0574 0253 11 HOSE ASSEMBLY GF 635 0574 0260 11 HOSE ASSEMBLY AP7 841
0574 0253 11 HOSE ASSEMBLY 3BR3 890 0574 0260 11 HOSE ASSEMBLY BR3 269
0574 0255 11 HOSE ASSEMBLY J54 639 0574 0260 11 HOSE ASSEMBLY BR3 882
0574 0255 11 HOSE ASSEMBLY XT5 636 0574 0260 11 HOSE ASSEMBLY AP7 881
0574 0255 11 HOSE ASSEMBLY AP13 881 0574 0272 11 HOSE ASSEMBLY XFT 636
0574 0255 11 HOSE ASSEMBLY XT5 890 0574 0272 11 HOSE ASSEMBLY XFT 890
0574 0255 11 HOSE ASSEMBLY BD3 269 0574 0274 11 HOSE ASSEMBLY HB23 643
0574 0255 11 HOSE ASSEMBLY 3BR5 269 0574 0274 11 HOSE ASSEMBLY HB24 643
0574 0255 11 HOSE ASSEMBLY XDP 890 0574 0274 11 HOSE ASSEMBLY HB24 884
0574 0255 11 HOSE ASSEMBLY RHG2 888 0574 0274 11 HOSE ASSEMBLY HB23 884
0574 0255 11 HOSE ASSEMBLY FRB1 883 0574 0274 11 HOSE ASSEMBLY RHC1 886
0574 0255 11 HOSE ASSEMBLY DP 635 0574 0274 11 HOSE ASSEMBLY RHC1 139
0574 0255 11 HOSE ASSEMBLY XT1 636 0574 0278 11 HOSE ASSEMBLY WG 889
0574 0255 11 HOSE ASSEMBLY XT1 890 0574 0278 11 HOSE ASSEMBLY WG 633
0574 0255 11 HOSE ASSEMBLY FRB2 223 0574 0289 11 HOSE ASSEMBLY XR1 890
0574 0255 11 HOSE ASSEMBLY FRB1 223 0574 0289 11 HOSE ASSEMBLY XR1 633
0574 0255 11 HOSE ASSEMBLY FRB2 883 0574 0291 11 HOSE ASSEMBLY C6 882
0574 0255 11 HOSE ASSEMBLY J53 639 0574 0291 11 HOSE ASSEMBLY C5 882
0574 0255 11 HOSE ASSEMBLY XDP 635 0574 0291 11 HOSE ASSEMBLY RHC10 886
0574 0255 11 HOSE ASSEMBLY XP 636 0574 0291 11 HOSE ASSEMBLY C6 641
0574 0255 11 HOSE ASSEMBLY 3BR5 890 0574 0291 11 HOSE ASSEMBLY C5 641
0574 0255 11 HOSE ASSEMBLY BD3 882 0574 0291 11 HOSE ASSEMBLY RHE10 647
907
0574 0291 11 HOSE ASSEMBLY RHE9 647 0574 0316 11 HOSE ASSEMBLY RHC4 887
0574 0291 11 HOSE ASSEMBLY RHC9 887 0574 0316 11 HOSE ASSEMBLY RHA6 886
0574 0291 11 HOSE ASSEMBLY RHD10 887 0574 0316 11 HOSE ASSEMBLY J63 885
0574 0291 11 HOSE ASSEMBLY RHG10 648 0574 0316 11 HOSE ASSEMBLY RHA6 139
0574 0291 11 HOSE ASSEMBLY RHG10 887 0574 0316 11 HOSE ASSEMBLY RHF3 648
0574 0291 11 HOSE ASSEMBLY RHD10 647 0574 0316 11 HOSE ASSEMBLY RHE3 647
0574 0291 11 HOSE ASSEMBLY RHD9 647 0574 0316 11 HOSE ASSEMBLY RHE4 887
0574 0291 11 HOSE ASSEMBLY RHD9 887 0574 0316 11 HOSE ASSEMBLY RHA6 647
0574 0291 11 HOSE ASSEMBLY RHE10 887 0574 0316 11 HOSE ASSEMBLY J63 639
0574 0291 11 HOSE ASSEMBLY RHA11 886 0574 0316 11 HOSE ASSEMBLY RHE3 887
0574 0291 11 HOSE ASSEMBLY RHA12 886 0574 0316 11 HOSE ASSEMBLY RHD4 647
0574 0291 11 HOSE ASSEMBLY RHA12 647 0574 0316 11 HOSE ASSEMBLY RHG4 648
0574 0291 11 HOSE ASSEMBLY RHA11 647 0574 0316 11 HOSE ASSEMBLY RHG4 888
0574 0291 11 HOSE ASSEMBLY RHF9 648 0574 0316 11 HOSE ASSEMBLY RHC3 647
0574 0291 11 HOSE ASSEMBLY RHF9 887 0574 0316 11 HOSE ASSEMBLY RHD3 887
0574 0291 11 HOSE ASSEMBLY RHE9 887 0574 0316 11 HOSE ASSEMBLY RHC4 647
0574 0293 11 HOSE ASSEMBLY GRT7 181 0574 0316 11 HOSE ASSEMBLY RHF3 887
0574 0293 11 HOSE ASSEMBLY GRT7 884 0574 0316 11 HOSE ASSEMBLY RHD4 887
0574 0294 11 HOSE ASSEMBLY GRT9 181 0574 0316 11 HOSE ASSEMBLY RHE4 647
0574 0294 11 HOSE ASSEMBLY GRT9 884 0574 0316 11 HOSE ASSEMBLY RHD3 647
0574 0294 11 HOSE ASSEMBLY J43 885 0574 0316 11 HOSE ASSEMBLY J64 639
0574 0315 11 HOSE ASSEMBLY GRT1 181 0574 0318 11 HOSE ASSEMBLY J21 885
0574 0315 11 HOSE ASSEMBLY GRT1 884 0574 0320 11 HOSE ASSEMBLY DKV 882
0574 0316 11 HOSE ASSEMBLY RHC3 886 0574 0320 11 HOSE ASSEMBLY DKV 633
0574 0316 11 HOSE ASSEMBLY J64 885 0574 0321 11 HOSE ASSEMBLY XFS1 890
908
0574 0321 11 HOSE ASSEMBLY XFS1 633 0574 0328 11 HOSE ASSEMBLY RHA3 886
0574 0323 11 HOSE ASSEMBLY SH2 653 0574 0328 11 HOSE ASSEMBLY RHA4 886
0574 0323 11 HOSE ASSEMBLY SH2 888 0574 0328 11 HOSE ASSEMBLY RHA3 139
0574 0323 11 HOSE ASSEMBLY SH3 888 0574 0564 11 HOSE ASSEMBLY WSB1 889
0574 0323 11 HOSE ASSEMBLY SH3 653 0574 0564 11 HOSE ASSEMBLY WSB1 97
0574 0326 11 HOSE ASSEMBLY RHA9 647 0574 1252 36 HOSE ASSEMBLY R1 97
0574 0326 11 HOSE ASSEMBLY RHD8 647 0574 1252 36 HOSE ASSEMBLY R1 888
0574 0326 11 HOSE ASSEMBLY RHC8 887 0574 1252 36 HOSE ASSEMBLY R2 97
0574 0326 11 HOSE ASSEMBLY RHC7 887 0574 1252 36 HOSE ASSEMBLY R2 888
0574 0326 11 HOSE ASSEMBLY RHD8 887 0574 1253 11 HOSE ASSEMBLY PR13 635
0574 0326 11 HOSE ASSEMBLY RHA10 886 0574 1253 11 HOSE ASSEMBLY PR13 886
0574 0326 11 HOSE ASSEMBLY RHG8 648 0574 1256 11 HOSE ASSEMBLY RHG1 887
0574 0326 11 HOSE ASSEMBLY GRT5 181 0574 1256 11 HOSE ASSEMBLY PR11 635
0574 0326 11 HOSE ASSEMBLY RHG8 888 0574 1256 11 HOSE ASSEMBLY RHG1 139
0574 0326 11 HOSE ASSEMBLY RHE7 887 0574 1256 11 HOSE ASSEMBLY PR11 886
0574 0326 11 HOSE ASSEMBLY RHA10 647 0574 1281 11 HOSE ASSEMBLY ABR2 269
0574 0326 11 HOSE ASSEMBLY RHE7 647 0574 1281 11 HOSE ASSEMBLY ABR2 881
0574 0326 11 HOSE ASSEMBLY RHE8 647 0574 1285 11 HOSE ASSEMBLY BU3 645
0574 0326 11 HOSE ASSEMBLY RHA9 886 0574 1285 11 HOSE ASSEMBLY DP3 883
0574 0326 11 HOSE ASSEMBLY RHC7 647 0574 1285 11 HOSE ASSEMBLY TBU3 889
0574 0326 11 HOSE ASSEMBLY GRT5 884 0574 1285 11 HOSE ASSEMBLY TBU3 645
0574 0326 11 HOSE ASSEMBLY RHF7 648 0574 1285 11 HOSE ASSEMBLY DP3 645
0574 0326 11 HOSE ASSEMBLY RHE8 887 0574 1285 11 HOSE ASSEMBLY BU3 882
0574 0326 11 HOSE ASSEMBLY RHC8 647 0574 1290 11 HOSE ASSEMBLY FE3 651
0574 0326 11 HOSE ASSEMBLY RHD7 647 0574 1290 11 HOSE ASSEMBLY RHG7 888
0574 0326 11 HOSE ASSEMBLY RHF7 887 0574 1290 11 HOSE ASSEMBLY FE4 651
0574 0326 11 HOSE ASSEMBLY RHD7 887 0574 1290 11 HOSE ASSEMBLY FE3 883
0574 0328 11 HOSE ASSEMBLY 1BR2 890 0574 1290 11 HOSE ASSEMBLY FE4 883
0574 0328 11 HOSE ASSEMBLY 1BR2 269 0574 1290 11 HOSE ASSEMBLY RHG7 648
0574 0328 11 HOSE ASSEMBLY RHA4 139 0574 1291 11 HOSE ASSEMBLY FE5 641
909
0574 1291 11 HOSE ASSEMBLY FE5 883 0574 1527 11 HOSE ASSEMBLY DP1 883
0574 1291 11 HOSE ASSEMBLY FE6 641 0574 1527 11 HOSE ASSEMBLY LU1 97
0574 1291 11 HOSE ASSEMBLY FE6 883 0574 1527 11 HOSE ASSEMBLY DP1 97
0574 1291 11 HOSE ASSEMBLY RHG9 888 0574 1566 11 HOSE ASSEMBLY BU1 882
0574 1291 11 HOSE ASSEMBLY RHG9 648 0574 1566 11 HOSE ASSEMBLY TBU1 889
0574 1292 11 HOSE ASSEMBLY KV2 633 0574 1566 11 HOSE ASSEMBLY TBU1 97
0574 1292 11 HOSE ASSEMBLY KV1 633 0574 1566 11 HOSE ASSEMBLY BU1 97
0574 1292 11 HOSE ASSEMBLY KV2 885 0574 2254 11 HOSE ASSEMBLY AP3 841
0574 1292 11 HOSE ASSEMBLY KV1 885 0574 2254 11 HOSE ASSEMBLY AP3 881
0574 1314 11 HOSE ASSEMBLY K3 641 0574 2255 11 HOSE ASSEMBLY AP9 841
0574 1314 11 HOSE ASSEMBLY K4 885 0574 2255 11 HOSE ASSEMBLY T12 633
0574 1316 11 HOSE ASSEMBLY ABR1 881 0574 2255 11 HOSE ASSEMBLY BS30 882
0574 1316 11 HOSE ASSEMBLY ABR1 269 0574 2255 11 HOSE ASSEMBLY T12 889
0574 1316 11 HOSE ASSEMBLY FE1 645 0574 2255 11 HOSE ASSEMBLY BS30 635
0574 1316 11 HOSE ASSEMBLY FE2 883 0574 2255 11 HOSE ASSEMBLY AP9 881
0574 1321 11 HOSE ASSEMBLY 3BR4 890 0574 2267 11 HOSE ASSEMBLY P13 886
0574 1321 11 HOSE ASSEMBLY 3BR4 269 0574 2267 11 HOSE ASSEMBLY P13 633
0574 1321 11 HOSE ASSEMBLY RHG3 648 0574 2270 11 HOSE ASSEMBLY P3 635
0574 1321 11 HOSE ASSEMBLY RHG3 888 0574 2270 11 HOSE ASSEMBLY P3 886
0574 1323 11 HOSE ASSEMBLY TBU7 889 0574 2273 11 HOSE ASSEMBLY ST1 269
0574 1323 11 HOSE ASSEMBLY BU7 882 0574 2273 11 HOSE ASSEMBLY ST1 888
0574 1323 11 HOSE ASSEMBLY DP7 641 0574 2277 11 HOSE ASSEMBLY BS22 882
0574 1323 11 HOSE ASSEMBLY BU7 641 0574 2277 11 HOSE ASSEMBLY BS22 645
0574 1323 11 HOSE ASSEMBLY TBU7 641 0574 2277 11 HOSE ASSEMBLY BS3 882
0574 1323 11 HOSE ASSEMBLY DP7 883 0574 2277 11 HOSE ASSEMBLY BS3 645
0574 1527 11 HOSE ASSEMBLY LU1 885 0574 2280 11 HOSE ASSEMBLY ST4 888
910
0574 2280 11 HOSE ASSEMBLY P13 269 0574 2290 11 HOSE ASSEMBLY BS26 651
0574 2280 11 HOSE ASSEMBLY ST3 269 0574 2290 11 HOSE ASSEMBLY BS7 882
0574 2280 11 HOSE ASSEMBLY P13 886 0574 2290 11 HOSE ASSEMBLY BS16 882
0574 2284 11 HOSE ASSEMBLY BS5 645 0574 2290 11 HOSE ASSEMBLY JS12 651
0574 2284 11 HOSE ASSEMBLY BS5 882 0574 2290 11 HOSE ASSEMBLY BS7 651
0574 2284 11 HOSE ASSEMBLY BS24 645 0574 2291 11 HOSE ASSEMBLY LU7 641
0574 2284 11 HOSE ASSEMBLY STT1 888 0574 2291 11 HOSE ASSEMBLY JS14 884
0574 2284 11 HOSE ASSEMBLY STT1 269 0574 2291 11 HOSE ASSEMBLY JS15 884
0574 2284 11 HOSE ASSEMBLY T10 889 0574 2291 11 HOSE ASSEMBLY LU7 885
0574 2284 11 HOSE ASSEMBLY T10 633 0574 2291 11 HOSE ASSEMBLY JS15 641
0574 2285 11 HOSE ASSEMBLY JS6 645 0574 2291 11 HOSE ASSEMBLY JS14 641
0574 2285 11 HOSE ASSEMBLY DS3 883 0574 2316 11 HOSE ASSEMBLY BS9 882
0574 2285 11 HOSE ASSEMBLY JS5 885 0574 2316 11 HOSE ASSEMBLY BS18 882
0574 2285 11 HOSE ASSEMBLY JS6 885 0574 2318 11 HOSE ASSEMBLY LU9 885
0574 2285 11 HOSE ASSEMBLY DS3 645 0574 2318 11 HOSE ASSEMBLY JS10 884
0574 2285 11 HOSE ASSEMBLY LU3 885 0574 2318 11 HOSE ASSEMBLY P10 633
0574 2285 11 HOSE ASSEMBLY LU3 645 0574 2318 11 HOSE ASSEMBLY P10 886
0574 2290 11 HOSE ASSEMBLY JS13 651 0574 2318 11 HOSE ASSEMBLY LU9 633
0574 2290 11 HOSE ASSEMBLY BS16 651 0574 2324 11 HOSE ASSEMBLY P31 886
911
0574 2324 11 HOSE ASSEMBLY T31 889 0574 3527 11 HOSE ASSEMBLY S1 97
0574 2324 11 HOSE ASSEMBLY T31 633 0574 3535 11 HOSE ASSEMBLY F6 645
0574 2324 11 HOSE ASSEMBLY P31 633 0574 3535 11 HOSE ASSEMBLY F6 883
0574 2327 11 HOSE ASSEMBLY JS3 645 0574 3535 11 HOSE ASSEMBLY R4 888
0574 2529 11 HOSE ASSEMBLY F2 883 0574 3535 11 HOSE ASSEMBLY F5 645
0574 2531 11 HOSE ASSEMBLY F1 97 0574 3565 11 HOSE ASSEMBLY R5 888
0574 3260 48 HOSE ASSEMBLY W1 97 0574 3565 11 HOSE ASSEMBLY R6 651
0574 3260 48 HOSE ASSEMBLY W1 889 0574 3565 11 HOSE ASSEMBLY F8 651
0574 3261 11 HOSE ASSEMBLY TRF 269 0574 3569 11 HOSE ASSEMBLY R8 888
0574 3261 11 HOSE ASSEMBLY TRF 889 0574 3569 11 HOSE ASSEMBLY F9 641
0574 3261 11 HOSE ASSEMBLY CV1 882 0574 3569 11 HOSE ASSEMBLY F10 883
0574 3261 11 HOSE ASSEMBLY CV1 269 0574 3569 11 HOSE ASSEMBLY F9 884
0574 3264 11 HOSE ASSEMBLY CV2 882 0574 3569 11 HOSE ASSEMBLY R7 888
0574 3264 11 HOSE ASSEMBLY CV2 269 0574 3569 11 HOSE ASSEMBLY R8 641
0574 3277 11 HOSE ASSEMBLY TF2 889 0574 3569 11 HOSE ASSEMBLY R7 641
0574 3277 11 HOSE ASSEMBLY TF2 659 0574 3569 11 HOSE ASSEMBLY F10 641
0574 3505 11 HOSE ASSEMBLY S7 888 0574 4259 11 HOSE ASSEMBLY TF10 889
0574 3505 11 HOSE ASSEMBLY S7 635 0574 4259 11 HOSE ASSEMBLY TF10 635
0574 3511 11 HOSE ASSEMBLY S9 635 0574 4285 11 HOSE ASSEMBLY W3 889
912
0574 4287 11 HOSE ASSEMBLY W7 890 0584 0064 00 CUTTING RING 53 877
0574 4319 11 HOSE ASSEMBLY DF 633 0584 0065 00 CUTTING RING 53 877
0574 4319 11 HOSE ASSEMBLY DF 882 0584 0066 00 CUTTING RING 53 877
0574 4509 11 HOSE ASSEMBLY PS1 635 0584 0067 00 CUTTING RING 53 877
0574 4509 11 HOSE ASSEMBLY PS1 886 0584 0068 00 CUTTING RING 53 877
0574 4524 11 HOSE ASSEMBLY TS1 97 0584 0071 00 CUTTING RING 53 877
0574 4524 11 HOSE ASSEMBLY TS1 889 0584 0074 00 CUTTING RING 53 877
0574 4535 11 HOSE ASSEMBLY S3 888 0584 2004 00 NUT 54 877
0574 4535 11 HOSE ASSEMBLY TS3 645 0584 2022 00 NUT 54 877
0574 4535 11 HOSE ASSEMBLY TS3 889 0584 2024 00 NUT 54 877
0574 4535 11 HOSE ASSEMBLY S3 645 0584 2025 00 NUT 54 877
0574 6013 11 HOSE ASSEMBLY T43 633 0584 2026 00 NUT 54 877
0574 6022 11 HOSE ASSEMBLY W13 889 0584 2065 00 NUT 54 877
0574 6028 11 HOSE ASSEMBLY W11 889 0603 4225 00 HEXAGON NIPPLE 40 266
0574 6029 11 HOSE ASSEMBLY AP1 881 0605 8823 00 BUSHING 6 853
0574 6029 11 HOSE ASSEMBLY AP1 841 0607 2155 00 SOCKET 7 853
0580 0013 11 PIPE COUPLING 2 391 0627 4209 00 PRESSURE SCREW 1 385
0580 2202 00 PIPE COUPLING 5 389 0627 4224 03 PRESSURE SCREW 1 373
0584 0004 00 CUTTING RING 53 877 0633 3307 00 FLANGE 2 801
0584 0024 00 CUTTING RING 53 877 0638 0527 00 FLANGE HALF 84 267
913
0650 0101 14 GASKET 3 801 0661 1034 00 SEAL WASHER 10 11
0653 1070 00 GASKET 2 385 0661 1500 49 BACK-UP RING 19 205
0661 1000 13 SEAL WASHER 84 103 0661 1510 00 BACK-UP RING 10 439
0661 1020 00 SEAL WASHER 10 39 0663 2100 60 O-RING 113 561
0661 1026 00 SEAL WASHER 14 231 0663 2100 62 O-RING 35
914
0663 2101 66 O-RING 153 14 0663 2122 00 O-RING 20 205
0663 2101 78 O-RING 23 547 0663 2127 00 O-RING 35 266
0663 2102 09 O-RING 31 61 0663 2128 00 O-RING 22 231
0663 2103 63 O-RING 22 547 0663 2128 00 O-RING 35
0663 2103 64 O-RING 24 547 0663 2128 00 O-RING 9 23
0663 2103 64 O-RING 24 541 0663 2129 01 O-RING 7 23
0663 2103 67 O-RING 43 61 0663 2129 01 O-RING 35
0663 2103 90 O-RING 10 225 0663 2129 01 O-RING 78 12
0663 2104 94 O-RING 70 12 0663 2131 00 O-RING 17 79
0663 2104 94 O-RING 202 15 0663 2131 00 O-RING 17 205
0663 2104 94 O-RING 35 0663 2133 01 O-RING 135 13
0663 2105 31 O-RING 23 541 0663 2133 01 O-RING 35
0663 2105 96 O-RING 69 12 0663 2133 01 O-RING 48 12
0663 2105 96 O-RING 35 0663 2133 01 O-RING 47 11
0663 2106 33 O-RING 160 14 0663 2134 00 O-RING 5 439
0663 2109 36 O-RING 4 37 0663 2134 00 O-RING 35
0663 2109 37 O-RING 6 23 0663 2135 00 O-RING 9 277
0663 2109 37 O-RING 35 0663 2142 00 O-RING 11 109
0663 2110 00 O-RING 35 0663 2143 00 O-RING 35
0663 2110 00 O-RING 14 19 0663 2144 00 O-RING 35
0663 2110 00 O-RING 14 21 0663 2145 01 O-RING 35
0663 2111 90 O-RING 3 119 0663 2150 00 O-RING 6 277
0663 2115 00 O-RING 35 0663 2158 00 O-RING 39 102
0663 2118 01 O-RING 11 439 0663 3120 00 O-RING 2 381
0663 2118 01 O-RING 2 199 0663 6121 00 O-RING 35
0663 2118 01 O-RING 2 405 0663 6121 00 O-RING 13 19
0663 2119 00 O-RING 1 305 0663 6121 00 O-RING 13 21
0663 2120 00 O-RING 35 0663 6127 00 O-RING 8 403
0663 2120 00 O-RING 136 13 0663 6127 00 O-RING 7 443
0663 2122 00 O-RING 20 79 0663 6131 00 O-RING 32 61
915
0663 6134 01 O-RING 46 11 0663 9056 00 O-RING 35
0663 6134 01 O-RING 45 11 0663 9078 00 O-RING 6 793
0663 6134 01 O-RING 35 0663 9099 00 O-RING 1 199
0663 6135 00 O-RING 4 443 0663 9099 00 O-RING 1 405
0663 6135 00 O-RING 27 11 0663 9099 00 O-RING 12 439
0663 6135 00 O-RING 35 0663 9104 01 O-RING 35
0663 6135 00 O-RING 9 403 0663 9158 00 O-RING 35
0663 6135 01 O-RING 35 0663 9191 01 O-RING 86 267
0663 6136 00 O-RING 35 0663 9203 00 O-RING 4 529
0663 6136 00 O-RING 17 11 0663 9205 00 O-RING 4 531
0663 6137 00 O-RING 34 102 0663 9205 00 O-RING 4 533
0663 6137 00 O-RING 17 111 0665 0010 12 SEAL RING 11 403
0663 6138 00 O-RING 35 0665 0010 14 SEAL RING 3 443
0663 6138 00 O-RING 93 12 0665 0010 14 SEAL RING 4 231
0663 6139 00 O-RING 6 231 0665 0010 18 PISTON ROD SEAL 7 277
0663 6142 00 O-RING 1 83 0665 0020 18 PISTON SEAL 8 443
0663 6143 00 O-RING 6 775 0665 0700 72 SEAL 10 109
0663 6143 00 O-RING 35 0665 0800 14 PISTON SEAL 8 79
0663 6144 00 O-RING 35 0665 0800 21 PISTON SEAL 6 439
0663 6148 00 O-RING 3 205 0665 1000 16 SEAL 5 85
0663 6148 00 O-RING 9 89 0665 1000 16 SEAL 5 205
0663 6151 00 O-RING 35 0665 1000 17 SEAL 12 205
0663 7148 00 O-RING 1 85 0665 1000 17 SEAL 5 83
0663 9050 00 O-RING 1 155 0665 1000 46 SEAL 2 439
0663 9056 00 O-RING 12 19 0665 1000 73 SEAL 4 109
0663 9056 00 O-RING 12 21 0665 9099 12 WIPER 6 83
916
0665 9099 12 WIPER 13 205 0686 3716 02 PLUG 2 795
0665 9099 13 WIPER 6 85 0686 3716 30 PLUG 30 136
0665 9099 13 WIPER 6 205 0686 4201 03 PLUG 5 39
0665 9100 16 WIPER 8 277 0686 4201 03 PLUG 104 13
0665 9100 17 WIPER 12 403 0686 6442 00 PLUG 13 403
0665 9100 83 WIPER 91 104 0686 6442 00 PLUG 55 12
0665 9100 86 WIPER 18 111 0686 6442 03 PLUG 37 467
0665 9170 01 WIPER 31 102 0686 6442 07 PLUG 9 619
0665 9170 01 WIPER 5 231 0686 6442 07 PLUG 7 619
0665 9170 01 WIPER 1 443 0686 6442 07 PLUG 3 623
0665 9193 00 WIPER 6 109 0686 6442 07 PLUG 2 573
0665 9214 00 WIPER 1 439 0686 6442 07 PLUG 5 565
0665 9258 01 WIPER 26 201 0686 6443 00 PLUG 13 231
0665 9300 46 GUIDE RING, EXT 7 439 0686 6444 03 PLUG 32 136
0665 9300 67 GUIDE RING 7 205 0686 6447 04 PLUG 9 11
0665 9300 67 GUIDE RING 4 85 0686 9010 54 PROTECTING PLUG 23
0665 9300 85 GUIDE RING, EXT 5 109 0686 9110 00 PROTECTION PLUG 87 12
0666 6000 39 RADIAL LIP SEAL 2 481 0686 9250 26 PLUG 15
0666 7188 01 RADIAL LIP SEAL 107 13 0686 9250 27 PLUG 15
0666 7188 01 RADIAL LIP SEAL 8 39 0686 9250 63 CAP 30 541
0666 7190 01 RADIAL LIP SEAL 154 14 0686 9252 27 PROTECTION CAP 26 111
0666 8000 24 AXIAL SEAL 3 111 0686 9252 27 PROTECTION CAP 30 225
0667 1206 00 SEAL 128 13 0690 3181 00 PLATE 9 67
0667 1206 00 SEAL 9 39 0690 3181 00 PLATE 11 75
0686 3103 00 PLUG 16 403 0690 3181 00 PLATE 28 201
0686 3710 00 PLUG 6 303 0690 3181 00 PLATE 20 225
917
0694 4990 17 WIRE MARKER 62 676 0697 9810 18 END PLUG 6 691
0694 5110 12 CABLE LUG 31 741 0697 9810 19 END PLUG 8 431
0694 5110 22 CABLE LUG 30 741 0697 9810 19 END PLUG 6 185
0694 5610 01 END SOCKET 17 837 0697 9810 19 END PLUG 11 314
0697 9745 31 ADAPTER 6 743 0697 9810 19 END PLUG 17 349
0697 9745 31 ADAPTER 5 251 0697 9810 19 END PLUG 17 761
0697 9745 66 ADAPTER 16 673 0697 9810 19 END PLUG 36 321
0697 9745 66 ADAPTER 5 353 0697 9810 21 END PLUG 17 741
0697 9745 71 REDUCER 38 321 0697 9810 54 END PLUG 16 337
0697 9745 80 ENLARGER 3 683 0697 9810 54 END PLUG 16 335
0697 9809 13 LOCK NUT 7 431 0698 5140 06 CABLE GLAND 4 751
0697 9810 18 END PLUG 6 431 0698 5140 61 CABLE GLAND 39 321
918
0698 5140 61 CABLE GLAND 11 741 0698 5141 70 CABLE GLAND 15 335
0698 5140 61 CABLE GLAND 4 721 0698 5205 00 JUNCTION BOX 9 673
0698 5140 62 CABLE GLAND 8 741 0698 5205 00 JUNCTION BOX 4 353
0698 5140 62 CABLE GLAND 5 711 0803 5012 04 FILTER PLUG 13 109
0698 5140 62 CABLE GLAND 4 691 0803 5012 04 FILTER PLUG 3 795
0698 5140 62 CABLE GLAND 8 695 0823 0050 18 CHECK VALVE 6 605
0698 5140 63 CABLE GLAND 7 699 0830 1008 44 SAFETY VALVE 8 791
0698 5140 63 CABLE GLAND 7 741 0834 1194 05 SAFETY VALVE 13 791
0698 5140 63 CABLE GLAND 14 837 0909 1071 00 LUBRICAT.GUN 15
0698 5140 63 CABLE GLAND 3 711 0926 5051 00 BATTERY G100 339
0698 5140 63 CABLE GLAND 7 681 1030 1005 03 HOSE CLIP 5 365
0698 5140 63 CABLE GLAND 7 687 1079 9697 03 ADAPTER 4 815
0698 5140 64 CABLE GLAND 6 741 1080 2340 09 ELECTRIC MOTOR 503 789
0698 5140 64 CABLE GLAND 3 683 1088 0003 01 FLAT PIN SLEEVE 10 353
0698 5141 41 CABLE GLAND 3 715 1088 0008 01 END SOCKET 82 677
0698 5141 41 CABLE GLAND 15 761 1088 0008 02 END SOCKET 83 677
0698 5141 62 CABLE GLAND 18 501 1088 0401 05 FLANGE 7 705
919
1088 0498 05 GASKET 10 705 3115 0823 00 WASHER 125 13
1088 1301 01 ASSEMBLY STRIP 8 285 3115 0824 00 SLEEVE 127 13
1088 1501 01 SHRINKING TUB. 36 676 3115 0970 00 SEAL KIT 11 39
1089 9037 10 FUSE 28 715 3115 0970 00 SEAL KIT 16 11
3035 3313 73 AUX. CONTACT K 28 727 3115 1156 00 SEAL KIT 26 11
3035 3313 73 AUX. CONTACT K 64 728 3115 1156 00 SEAL KIT 14 39
3115 0212 00 STRAP 5 795 3115 1165 00 STUD 11 11
3115 0262 00 VALVE 16 53 3115 1457 00 SIDE BOLT 133 13
3115 0262 00 VALVE 4 21 3115 1457 00 SIDE BOLT 23 43
3115 0262 00 VALVE 4 19 3115 1582 00 DRIVER 131 13
3115 0262 00 VALVE 4 43 3115 1582 00 DRIVER 4 47
3115 0273 00 WASHER 109 13 3115 1582 00 DRIVER 4 49
3115 0274 00 GEAR WHEEL 123 13 3115 1648 00 CARTRIDGE 3 793
3115 0277 00 COUPLING 248 15 3115 1648 01 COIL 4 793
3115 0286 00 DOME NUT 10 51 3115 1648 02 SEAL KIT 8 793
3115 0286 00 DOME NUT 25 43 3115 1671 00 PISTON GUIDE 19 11
3115 0286 00 DOME NUT 251 15 3115 1671 00 PISTON GUIDE 8 49
3115 0287 00 WASHER 252 15 3115 1671 00 PISTON GUIDE 8 47
3115 0297 01 SHIM 137 13 3115 1684 00 COUPLING 10 793
3115 0297 01 SHIM 6 43 3115 1697 00 SEAL WASHER 37 11
3115 0297 02 SHIM 7 43 3115 1697 00 SEAL WASHER 12 39
3115 0297 02 SHIM 138 13 3115 1732 81 ROT.CHUCK 116 13
3115 0297 03 SHIM 8 43 3115 1746 06 NOZZLE 71 12
3115 0297 03 SHIM 139 13 3115 1746 06 NOZZLE 59 12
3115 0318 00 EXTENSION 2 33 3115 1765 00 VALVE PISTON 31 11
3115 0327 00 GASKET 247 15 3115 1822 01 DIAPHRAGM 3 21
3115 0327 00 GASKET 16 39 3115 1822 01 DIAPHRAGM 3 19
3115 0821 00 SHAFT 130 13 3115 1822 01 DIAPHRAGM 2 43
920
3115 1825 00 PLUG 8 11 3115 2231 00 DRILL COLLAR 12 59
3115 1870 00 PROTECTION PLUG 19 3115 2232 00 DRILL COLLAR 301 15
3115 1870 00 PROTECTION PLUG 21 3115 2232 00 DRILL COLLAR 110 31
3115 1879 00 SEAL KIT 84 12 3115 2233 00 DRILL COLLAR 120 31
3115 1880 00 SEAL KIT 85 12 3115 2275 00 CLAMP 21 23
3115 1880 90 SEAL KIT 2 39 3115 2276 00 HOLDER 22 23
3115 1881 00 BUSHING 118 13 3115 2340 80 GEAR HOUSING 102 13
3115 1881 00 BUSHING 3 49 3115 2383 00 VALVE CONE 77 12
3115 1881 00 BUSHING 3 47 3115 2384 00 VALVE SEAT 76 12
3115 1926 02 DIAPHRAGM 10 23 3115 2386 00 CUP SEAL 18 39
3115 1926 02 DIAPHRAGM 5 43 3115 2386 00 CUP SEAL 183 14
3115 1944 80 CYLINDER 2 11 3115 2386 00 CUP SEAL 200 15
3115 2055 00 SEAL KIT 3 41 3115 2401 00 PLUG 60 12
3115 2055 00 SEAL KIT 167 14 3115 2409 80 PRESSING TOOL 3 33
3115 2076 05 VALVE COVER 33 11 3115 2410 80 PRESSING TOOL 4 33
3115 2077 03 VALVE COVER 32 11 3115 2411 00 PRESSING TOOL 5 33
3115 2112 00 GUIDE 12 11 3115 2412 00 PRESSING TOOL 6 33
3115 2115 01 REG. PLUG 210 31 3115 2420 00 SCREW 1 33
3115 2116 00 SEAL KIT 4 41 3115 2422 00 PRESSING TOOL 7 33
3115 2116 00 SEAL KIT 168 14 3115 2423 00 GUIDE RING 8 33
3115 2124 00 PISTON GUIDE 9 49 3115 2472 00 DIAPHRAGM 3 43
3115 2126 00 PISTON 10 49 3115 2519 00 TIGHTENING TOOL 160 31
3115 2129 00 PISTON 10 47 3115 2554 00 SEAL KIT 15 39
3115 2129 00 PISTON 21 11 3115 2583 45 INTERMED. PART 53 12
3115 2163 00 MANDREL 20 31 3115 2583 86 INTERM. COMPL. 52 12
3115 2196 81 TEST VALVE 5 21 3115 2615 20 TUBE 2 23
3115 2196 81 TEST VALVE 5 19 3115 2615 91 RETURN ACCUM. 231 15
3115 2223 02 GUIDE 3 51 3115 2617 10 PLUG 22 43
3115 2223 02 GUIDE 163 14 3115 2617 20 PLUG 11 23
3115 2231 00 DRILL COLLAR 100 31 3115 2618 00 END PIECE 8 23
921
3115 2702 10 SCREW 10 21 3115 3164 00 LABEL 28 43
3115 2702 10 SCREW 20 43 3115 3164 00 LABEL 291 15
3115 2702 10 SCREW 10 19 3115 3165 00 EXTRACTORPISTON 6 51
3115 2703 00 SCREW 21 43 3115 3165 00 EXTRACTORPISTON 181 14
3115 2714 90 LABEL SET 9 19 3115 3190 81 FLUSH HEAD COMP 195 14
3115 2715 90 LABEL SET 9 21 3115 3195 01 COVER 197 15
3115 2724 80 DISASSEMB.TOOLS 25 31 3115 3196 02 GUIDE 198 15
3115 2736 00 SPACER TUBE 26 31 3115 3197 02 GUIDE 199 15
3115 2737 00 MANDREL 27 31 3115 3200 00 SLEEVE 185 14
3115 2742 00 GUIDE SLEEVE 129 13 3115 3201 00 ATTACHMENT 186 14
3115 2766 80 SEAL HOUSE COMP 14 11 3115 3214 00 NUT 36 11
3115 2772 80 SEAL HOUSE COMP 24 11 3115 3236 00 WIPER 17 39
3115 2885 00 TUBE COVER 3 23 3115 3236 00 WIPER 201 15
3115 2886 00 PIPE 4 23 3115 3245 00 SEAL RING 38 11
3115 2887 80 CONNECT. PLATE 200 31 3115 3245 00 SEAL RING 35
3115 2888 00 PRESSURE SCREW 2 37 3115 3245 00 SEAL RING 134 13
3115 2889 00 PRESSURE SCREW 5 23 3115 3291 00 REG. PLUG 35 11
3115 2915 00 PRESSING TOOL 220 31 3115 3292 00 REG. PLUG 90 31
3115 2968 00 ROT.CH.BUSHING 2 47 3115 3308 00 LABEL 292 15
3115 2968 00 ROT.CH.BUSHING 132 13 3115 3308 00 LABEL 27 43
3115 2968 00 ROT.CH.BUSHING 2 49 3115 3425 01 O-RING 1 53
3115 2971 00 DAMPING PISTON 5 49 3115 3425 02 BOTTLE CONNECT 2 53
3115 2971 00 DAMPING PISTON 5 47 3115 3425 03 HOSE 3 53
3115 2971 00 DAMPING PISTON 86 12 3115 3425 04 MANOMETER 4 53
3115 2988 00 SEAL RING 35 3115 3425 05 MANOMETER 5 53
3115 2988 00 SEAL RING 82 12 3115 3425 06 MANOMETER 6 53
3115 3061 00 PIN 188 14 3115 3425 07 REGULATOR 7 53
3115 3062 00 WASHER 189 14 3115 3425 08 NEEDLE VALVE 8 53
3115 3063 00 BUSHING 187 14 3115 3425 09 HOSE 9 53
3115 3124 01 LABEL 20 791 3115 3425 10 CONNECTION 10 53
922
3115 3425 17 GASKET 13 53 3115 3609 10 COVER 152 13
3115 3425 18 SET SCREW 14 53 3115 3610 00 SPACER 155 14
3115 3425 19 HEX.SOCKET KEY 15 53 3115 3611 00 SIDE BOLT 24 43
3115 3425 80 CHARGIN DEVICE 15 3115 3611 00 SIDE BOLT 157 14
3115 3451 81 ACCUMULATOR 211 15 3115 3612 00 STUD 158 14
3115 3455 00 CONNECT. PLATE 79 12 3115 3613 00 STUD 8 51
3115 3473 81 HYDRAULIC MOTOR 241 15 3115 3613 00 STUD 159 14
3115 3473 83 HYDRAULIC MOTOR 241 15 3115 3744 00 BUSHING 7 49
3115 3473 85 HYDRAULIC MOTOR 241 15 3115 3744 00 BUSHING 7 47
3115 3473 90 SEAL KIT 27 3115 3744 00 BUSHING 67 12
3115 3473 90 SEAL KIT 29 3115 9153 90 O-RING SET 3 39
3115 3473 90 SEAL KIT 70 31 3115 9153 90 O-RING SET 40 31
3115 3473 90 SEAL KIT 25 3115 9156 92 O-RING SET 1 41
3115 3473 90 SEAL KIT 1 39 3115 9156 92 O-RING SET 45 31
3115 3474 00 LINER 6 47 3115 9156 93 SEAL KIT 1 43
3115 3474 00 LINER 6 49 3115 9156 93 SEAL KIT 230 31
3115 3474 00 LINER 66 12 3115 9156 94 SEAL KIT 1 51
3115 3475 00 BUSHING 165 14 3115 9156 94 SEAL KIT 240 31
3115 3475 00 BUSHING 4 51 3115 9156 95 OVERHAUL KIT 1 47
3115 3478 00 PLATE 360 31 3115 9156 95 OVERHAUL KIT 250 31
3115 3479 00 PLATE 370 31 3115 9156 95 OVERHAUL KIT 1 49
3115 3481 00 BACK HEAD 92 12 3115 9156 96 OVERHAUL KIT 260 31
3115 3511 81 ACCUMULATOR 221 15 3125 1997 00 PIPE 10 239
3115 3528 00 SEAL RETAINER 182 14 3125 2049 00 PIPE 11 239
3115 3528 00 SEAL RETAINER 7 41 3125 2178 00 BUSHING 2 233
3115 3548 00 NUT 246 15 3125 2525 00 COLLECT. BLOCK 30 467
3115 3548 00 NUT 18 43 3125 2794 03 PRESS.REL.VALVE 2 603
3115 3608 81 FRONT PART COMP 161 14 3128 0003 00 BUSHING 19 201
923
3128 0009 00 BUSHING 20 201 3128 0224 00 PROTECTION COIL 40 237
3128 0010 00 WASHER 21 201 3128 0225 00 PROTECTION COIL 50 137
3128 0011 00 WASHER 23 201 3128 0225 01 PROTECTION COIL 41 239
3128 0015 02 DOWEL 3 165 3128 0289 01 ELBOW PLATE 46 239
3128 0015 02 DOWEL 2 163 3128 0314 00 BEARING,SP.PL. 10 201
3128 0016 31 CRADLE COMPL 1 87 3128 0314 00 BEARING,SP.PL. 15 89
3128 0018 74 PIPE 5 167 3128 0427 00 PIPE 3 201
3128 0023 10 STINGER 1 165 3128 0428 02 GUIDE STRIP 5 201
3128 0023 12 STINGER 1 163 3128 0429 00 HOLDER 11 201
3128 0030 51 HYDR. CYLINDER 3 67 3128 0430 00 SLIDING PIECE 12 201
3128 0030 75 PISTON ROD 14 69 3128 0431 00 SPACER 13 201
3128 0030 76 GUIDE SPINDLE 9 69 3128 0432 00 SHIM 15 201
3128 0030 77 SEAL KIT 69 3128 0446 00 BUSHING 17 201
3128 0031 05 CUTTINGS CAP 4 61 3128 0463 00 GUIDE RING, EXT 27 201
3128 0031 13 SHAFT 2 131 3128 0518 00 SHAFT 19 225
3128 0031 14 BEARING HOUSING 8 111 3128 0530 00 WASHER 25 225
3128 0031 15 BEARING HOUSING 9 111 3128 0553 00 GUIDE STRIP 27 225
3128 0031 16 SPACER RING 12 111 3128 0554 01 WEAR PLATE 13 225
3128 0031 19 COVER 10 111 3128 0555 00 GUIDE LIST 17 225
3128 0031 55 EXPANDING SHAFT 23 113 3128 0556 00 GUIDE STRIP 14 225
3128 0031 70 HOLDER 4 107 3128 0557 00 SHIM 15 225
3128 0031 73 HOLDER 5 107 3128 0558 00 SHIM 16 225
3128 0032 05 FLAT KEY 12 107 3128 0559 00 CYLIND.BRACKET 5 225
3128 0034 01 SLIDE BAR 6 63 3128 0560 80 CYLINDER 4 201
3128 0037 00 DAMPING 22 61 3128 0569 02 SUPPORT 2 201
3128 0082 00 HOLDER 1 93 3128 0603 00 CAP 30 201
3128 0083 00 HOLDER 1 95 3128 0616 00 RING 6 75
3128 0090 00 COLLARING PART 3 75 3128 0618 00 SEAL 1 77
3128 0094 00 RUBBER CLOTH 2 75 3128 0618 01 SEAL 2 77
3128 0224 00 PROTECTION COIL 40 239 3128 0618 02 SEAL 3 77
924
3128 0618 05 SEAL 4 77 3128 2099 65 SEALING SET 197
3128 0618 06 SEAL 5 77 3128 2174 00 COVER 21 89
3128 0618 07 SEAL 33 59 3128 2191 36 PISTON 3 229
3128 0618 07 SEAL 6 77 3128 2192 00 SPACER 18 102
3128 0618 08 SEAL 7 77 3128 2206 00 PISTON ROD 14 102
3128 0631 00 RING 9 201 3128 2250 01 PISTON 3 109
3128 0646 00 KEY 3 95 3128 2262 00 COVER 1 109
3128 0646 00 KEY 3 93 3128 2288 00 COVER 13 111
3128 0672 02 ADJUSTMENT TOOL A 67 3128 2288 00 COVER 15 102
3128 0682 00 SHIM 12 75 3128 2353 00 DAMPING ELEMENT 9 113
3128 0683 00 SHIM 9 75 3128 2376 00 SPACER 1 159
3128 0782 73 DATA PLATE 45 61 3128 2378 29 HOSE SET 136
3128 0968 00 YOKE 2 209 3128 2378 31 HYDRAULIC SET 6 99
3128 0968 00 YOKE 3 227 3128 2419 00 WASHER 9 129
3128 2019 54 HOSE NIPPLE 83 267 3128 2428 00 GASKET 14 109
3128 2020 15 PRESS.RED.VALVE 27 265 3128 2435 00 GASKET 9 127
3128 2090 72 DIRECTION VALVE 75 613 3128 2597 50 ATTACHMENT 90 103
3128 2091 02 VALVE SECTION 2 617 3128 3005 37 PLUG 4 391
3128 2091 05 CHECK VALVE 12 621 3128 3005 38 CUTTING RING 1 391
3128 2091 22 INLET SECTION 1 617 3128 3013 06 DR.ST.SU.HOUSE 1 67
3128 2091 24 OUTLET SECTION 3 617 3128 3013 89 PISTON ROD END 4 67
3128 2091 25 PRESS.REL.VALVE 8 619 3128 3022 32 PIN 88 103
3128 2091 26 PULL ROD SET 623 3128 3022 32 PIN 33 61
3128 2091 69 LEVER SET 76 613 3128 3023 71 INSERT 1 275
3128 2097 00 SLEEVE 5 261 3128 3023 72 SEAL KIT 275
3128 2098 00 ATTACHM. PLATE 45 239 3128 3029 54 BUSHING 1 119
3128 2099 55 CHECK VALVE 13 439 3128 3039 21 INTERM.PLATE 39 61
3128 2099 55 CHECK VALVE 15 197 3128 3039 44 COVER 8 127
3128 2099 55 CHECK VALVE 17 403 3128 3043 55 SLIDING PIECE 2 93
3128 2099 55 CHECK VALVE 15 231 3128 3043 55 SLIDING PIECE 2 95
925
3128 3047 81 CUTTINGS GUIDE 5 75 3128 3094 51 SUPPORT 1 215
3128 3060 15 HYDR. CYLINDER 4 225 3128 3094 52 COVER 2 215
3128 3060 24 HYDR. CYLINDER 1 195 3128 3094 53 SHAFT 3 215
3128 3060 89 HYDR. CYLINDER 3 225 3128 3094 54 WASHER 8 215
3128 3061 01 PISTON ROD 9 197 3128 3094 56 BEARING 12 215
3128 3061 24 KEY 3 481 3128 3094 57 BEARING 13 215
3128 3062 45 CONNECTOR 8 775 3128 3094 58 SPACER 14 215
3128 3063 83 EXPANDING SHAFT 5 113 3128 3094 59 WASHER 26 215
3128 3069 04 SEGMENT 1 133 3128 3094 60 SHIM 16 215
3128 3074 03 HOUSING 8 715 3128 3094 61 LOCK NUT 17 215
3128 3079 15 CHAIN CATCH 8 769 3128 3094 62 PLUG 28 215
3128 3081 47 OIL 12 775 3128 3094 63 SPRING PIN 21 215
3128 3083 72 SPRING 8 109 3128 3094 64 PLUG 29 215
3128 3086 41 HOLDER 1 175 3128 3094 65 PLUG 30 215
3128 3087 17 ECCENTER 2 211 3128 3095 02 GUIDE UNIT - 547
3128 3087 31 SEAL KIT 2 273 3128 3095 11 VALVE BLOCK 6 213
3128 3088 19 SEAL 12 225 3128 3095 62 CRADLE 1 89
3128 3090 30 SENSOR SET 21 765 3128 3097 33 ARM 2 111
3128 3090 42 ROLLER PATH 42 202 3128 3097 34 ARM 1 113
3128 3093 45 BEARING SET - 547 3128 3097 36 CLAMP 2 113
3128 3093 60 CRADLE 1 201 3128 3097 40 SHIM 15 109
3128 3093 65 COVER 7 225 3128 3097 88 END PLATE 6 61
3128 3093 69 SHIM 9 225 3128 3097 89 FEED BEAM 1 61
3128 3093 76 GEAR 1 213 3128 3097 90 WASHER 29 61
3128 3093 77 BRAKE 2 213 3128 3097 91 SLEEVE 30 61
3128 3093 78 HYDRAULIC MOTOR 3 213 3128 3097 93 INTERM.PLATE 7 61
3128 3093 80 WASHER 5 213 3128 3098 07 DRIVER 17 89
3128 3093 81 GEAR 1 211 3128 3098 12 CLAMP 3 167
3128 3093 96 EXPANDING SHAFT 6 225 3128 3098 13 ATTACHMENT 2 167
3128 3093 97 SHAFT 1 233 3128 3098 37 PROTECTION 36 202
926
3128 3098 79 PINION 4 213 3128 3105 20 SPACER 19 89
3128 3101 97 END PIECE 1 102 3128 3105 22 SPACER 18 89
3128 3102 00 END PIECE 2 102 3128 3105 98 EXPANDING SHAFT 4 113
3128 3102 06 ARM 4 102 3128 3105 99 SHAFT 1 115
3128 3102 08 COVER 5 102 3128 3106 01 BUSHING 2 115
3128 3102 09 DISTANS 6 102 3128 3106 12 HYDR. CYLINDER 6 113
3128 3102 12 DISTANS 8 102 3128 3106 13 BUSHING 16 117
3128 3102 13 DISTANS 11 111 3128 3107 02 PIN 21 113
3128 3102 13 DISTANS 9 102 3128 3107 32 GUARD 3 99
3128 3102 14 COVER 10 102 3128 3107 34 PLATE 1 129
3128 3102 15 COVER 16 102 3128 3107 35 GUARD 2 129
3128 3102 16 COVER 19 102 3128 3107 37 FLAT BAR 3 129
3128 3102 17 COVER 11 102 3128 3115 78 SHIM 4 111
3128 3102 18 PLAIN BEARING 12 102 3128 3115 79 SHIM 20 102
3128 3102 67 SHAFT 1 131 3128 3116 40 COVER 12 123
3128 3102 73 GABLE PLATE 6 107 3128 3116 41 LOCK RING 11 123
3128 3102 75 SHAFT 7 107 3128 3117 14 PROTECTION 33 127
3128 3102 84 STAY 4 131 3128 3123 07 HOLDER SET 13 89
3128 3102 92 STAY 3 131 3128 3123 08 HOLDER SET 14 89
3128 3102 93 PROTECTION ARCH 44 102 3128 3134 02 HYDR. CYLINDER 82 103
3128 3103 50 PLUNGER 17 102 3128 3134 03 HYDR. CYLINDER 81 103
3128 3103 51 HOUSE 12 109 3128 3134 04 HYDR. CYLINDER 83 103
3128 3103 52 PISTON ROD 9 109 3128 3134 05 BUSHING 16 123
3128 3103 78 JAW 3 113 3128 3134 05 BUSHING 14 121
3128 3103 95 COVER 29 127 3128 3134 05 BUSHING 13 125
3128 3103 98 ARM 1 111 3128 3139 34 WASHER 6 119
3128 3104 21 BUSHING HALF 2 133 3128 3141 34 SCREW 3 69
3128 3104 53 BUSHING 13 113 3128 3141 35 COVER 7 69
3128 3104 72 EXPANDING SHAFT 46 103 3128 3141 36 WASHER 6 69
3128 3105 16 FRONT PLATE 2 61 3128 3141 37 WASHER 5 69
927
3128 3141 51 SCREW 1 69 3128 3232 37 CONNECTION SET 12 67
3128 3154 56 PISTON ROD 6 117 3128 3233 90 STAY 5 131
3128 3158 57 SEAL 1 207 3138 5051 23 BULLDOG GRIP 9 769
3128 3170 03 SEAL KIT 221 3155 2367 00 SHAFT 1 235
3128 3170 03 SEAL KIT 215 3155 2367 80 EXPANDING SHAFT 24 225
3128 3170 04 KIT 4 215 3155 2368 00 BUSHING 2 235
3128 3170 05 GEAR RING 5 215 3163 0427 00 STRAINER DRUM 1 833
3128 3170 06 FLANGE 6 215 3163 0427 01 GASKET 2 833
3128 3170 07 KIT 7 215 3163 0427 80 STRAINER 10 812
3128 3170 08 GEAR RING 10 215 3163 1854 00 SHACKLE 5 479
3128 3170 09 PINION 11 215 3176 0000 90 LOUDWHISTLEHORN H186 311
3128 3170 10 CIRCLIP 15 215 3176 0001 14 LIGHT EMIT. DIO 1 723
3128 3170 11 BEARING 18 215 3176 0001 25 PLUG CONNECTOR 1 749
3128 3170 12 FLANGE 20 215 3176 0001 26 SOCKET OUTLET 2 749
3128 3170 13 SCREW 22 215 3176 0001 27 OUTLET KIT 7 743
3128 3170 14 SCREW 23 215 3176 0001 45 WARNING BUZZER 1 351
3128 3170 15 NUT 24 215 3176 0001 45 WARNING BUZZER U2 320
3128 3170 16 WASHER 25 215 3176 0001 56 REVERSE ALARM H121 311
3128 3170 17 SPUR PINION 27 215 3176 0006 14 PUSH-BUTTON-BOX 1 661
3128 3170 19 DISK 32 215 3176 0007 55 RELAY K104 319
3128 3170 20 WASHER 34 216 3176 0015 33 FUSE HOLDER F89 849
3128 3170 20 WASHER 36 216 3176 0026 14 HOUR METER 1 325
3128 3170 22 PLUG 38 216 3176 0026 97 BATTERY SWITCH S300 339
3128 3170 23 CIRCLIP 41 216 3176 0027 02 DRILLED BOX 1 335
3128 3170 24 SEAL KIT 219 3176 0027 02 DRILLED BOX 1 337
3128 3175 30 YOKE 2 227 3176 0027 02 DRILLED BOX 1 761
3128 3175 30 YOKE 34 225 3176 0027 02 DRILLED BOX 1 349
3128 3212 35 PLUNGER 16 109 3176 0027 04 DRILLED BOX 1 185
3128 3230 59 PROTECTION 40 202 3176 0035 27 TIMING RELAY K3 849
3128 3232 36 DRILL STEEL SUP 3 61 3176 0035 27 TIMING RELAY K 32 728
928
3176 0035 27 TIMING RELAY 37 676 3176 1426 00 NIPPLE 28 870
3176 0035 27 TIMING RELAY K4 849 3176 1472 00 NIPPLE 1 862
3176 0050 31 PROTECTION HOSE W10 313 3176 1522 00 NIPPLE 10 866
3176 0050 32 PROTECTION HOSE 9 671 3176 1524 00 NIPPLE 33 872
3176 0050 42 ADAPTER 21 340 3176 1856 00 PRESS.REGULATOR 5 812
3176 0050 42 ADAPTER 10 314 3176 1878 01 AIR HOSE 78 103
3176 0050 43 ADAPTER 9 314 3176 1878 01 AIR HOSE 78 890
3176 0050 44 ADAPTER W189 313 3176 1882 02 MAGNET 152 561
3176 0062 00 NIPPLE 30 871 3176 1900 00 NIPPLE 6 863
3176 0063 00 NIPPLE 57 461 3176 1901 00 NIPPLE 6 863
3176 0063 00 NIPPLE 41 467 3176 1942 00 NIPPLE 2 339
3176 0063 00 NIPPLE 30 871 3176 1942 00 NIPPLE 10 866
3176 0064 00 NIPPLE 54 461 3176 1943 00 NIPPLE 10 866
3176 0064 00 NIPPLE 10 865 3176 1944 00 NIPPLE 24 869
3176 0064 00 NIPPLE 35 467 3176 1945 00 NIPPLE 31 872
3176 0065 00 NIPPLE 10 865 3176 1946 00 NIPPLE 31 872
3176 0166 00 NIPPLE 31 871 3176 1947 00 NIPPLE 23 868
3176 0167 00 NIPPLE 31 871 3176 1948 00 NIPPLE 30 871
3176 0529 00 NIPPLE 31 871 3176 1949 00 NIPPLE 30 871
3176 1271 00 NIPPLE 9 864 3176 2037 00 ELECTR.PLUG 169 561
3176 1300 00 NIPPLE 40 874 3176 2038 00 ELECTR.PLUG 170 561
929
3176 2053 00 CONNECT. PLATE 2 607 3176 3048 80 PIPE COUPLING 17 867
3176 2053 00 CONNECT. PLATE 29 552 3176 3049 80 PIPE COUPLING 17 867
3176 2053 00 CONNECT. PLATE 16 576 3176 3050 00 NIPPLE 18 867
3176 2131 00 NIPPLE 13 265 3176 3051 00 NIPPLE 18 867
3176 2131 00 NIPPLE 7 863 3176 3052 00 NIPPLE 18 867
3176 2279 00 NIPPLE 1 862 3176 3053 00 NIPPLE 18 867
3176 2644 00 NIPPLE 33 872 3176 3060 00 NIPPLE 23 868
3176 2645 00 NIPPLE 10 866 3176 3060 00 NIPPLE 40 137
3176 2710 00 NIPPLE 41 874 3176 3060 00 NIPPLE 93 267
3176 2711 00 PRESS.REL.VALVE 7 605 3176 3060 00 NIPPLE 5 265
3176 2786 00 NIPPLE 10 866 3176 3152 00 BUSHING 32 791
3176 2809 00 NIPPLE 41 874 3176 3555 00 NIPPLE 26 136
3176 2821 00 NIPPLE 18 867 3176 3555 00 NIPPLE 33 872
3176 2904 00 NIPPLE 7 863 3176 3556 00 NIPPLE 1 862
3176 2905 00 ADAPTER SLEEVE 49A 875 3176 3604 00 U-BOLT 4 255
3176 2929 00 NIPPLE 5 863 3176 3681 00 STRAP 50 299
3176 2930 00 CAP NUT 77 267 3176 3737 00 HOSE ASSEMBLY RHG5 648
3176 2930 00 CAP NUT 48 875 3176 3737 00 HOSE ASSEMBLY RHG5 888
3176 2932 00 NIPPLE 5 863 3176 3828 00 NIPPLE 30 871
3176 2935 10 RETURN BLOCK 8 526 3176 3829 00 NIPPLE 10 866
3176 3031 00 NIPPLE 8 864 3176 4049 00 TERMINAL BLOCK 21 320
3176 3036 00 NIPPLE 8 864 3176 4049 00 TERMINAL BLOCK X1 729
3176 3045 80 PIPE COUPLING 17 867 3176 4049 00 TERMINAL BLOCK 12 729
3176 3046 80 PIPE COUPLING 17 867 3176 4049 01 END PLATE 3 713
930
3176 4049 01 END PLATE 23 320 3176 4049 20 TERMINAL BLOCK 10 337
3176 4049 01 END PLATE 20 715 3176 4049 21 END PLATE 23 715
3176 4049 01 END PLATE 69 702 3176 4049 25 BRIDGE CONN. 12 349
3176 4049 02 BRIDGE CONN. 33 675 3176 4049 25 BRIDGE CONN. 25 715
3176 4049 02 BRIDGE CONN. 22 320 3176 4049 26 TERMINAL BLOCK 6 335
3176 4049 02 BRIDGE CONN. 14 729 3176 4049 26 TERMINAL BLOCK 20 349
3176 4049 03 TERMINAL BLOCK X1 729 3176 4049 26 TERMINAL BLOCK 6 337
3176 4049 04 TERMINAL BLOCK 15 729 3176 4049 26 TERMINAL BLOCK 20 761
3176 4049 11 TERMINAL BLOCK 10 317 3176 4049 50 END SUPPORT 12 837
3176 4049 12 END PLATE 20 729 3176 4049 51 END SUPPORT 30 675
3176 4049 13 BRIDGE CONN. 25 320 3176 4049 51 END SUPPORT 7 317
3176 4049 13 BRIDGE CONN. 12 317 3176 4049 51 END SUPPORT 18 729
931
3176 4049 52 END SUPPORT 21 715 3176 4341 02 BELLOW 2 709
3176 4049 52 END SUPPORT 14 335 3176 4341 03 RUBBER PACKING 3 709
3176 4049 52 END SUPPORT 14 337 3176 4341 04 MICRO SWITCH 4 709
3176 4049 52 END SUPPORT 14 761 3176 4341 05 HANDLE 5 709
3176 4049 61 MARKING PLATE 14 317 3176 4341 06 ROCKER 6 709
3176 4049 61 MARKING PLATE 13 335 3176 4341 07 CONTACT BLOCK 7 709
3176 4049 61 MARKING PLATE 13 337 3176 4341 20 CONTROLER 35 701
3176 4049 62 MARKING PLATE 13 335 3176 4341 23 PROTECT.BELLOWS 1 709
3176 4049 65 MARKING PLATE 13 337 3176 4342 10 SWITCH 40 701
3176 4049 67 MARKING PLATE 13 353 3176 4343 01 HOUSING 34 321
3176 4049 90 MARKING PLATE 75 702 3176 4343 01 HOUSING 20 675
3176 4049 90 MARKING PLATE 71 677 3176 4343 02 SLEEVE INSERT 2 687
3176 4049 90 MARKING PLATE 11 711 3176 4343 03 COVER 22 675
3176 4049 94 MARKING PLATE 70 677 3176 4344 02 PIN INSERT 23 675
3176 4049 94 MARKING PLATE 74 702 3176 4344 02 PIN INSERT 31 320
3176 4108 00 DIODE K 29 728 3176 4344 03 COVER 10 683
3176 4156 00 FUSE 27 715 3176 4344 03 COVER 4 687
3176 4158 00 BULB 2 320 3176 4362 01 TERMINAL BLOCK 1 679
3176 4160 00 BULB 7 675 3176 4363 08 MOUNTING RAIL 6 837
3176 4258 01 MIN CIRC BREAK F 66 727 3176 4363 08 MOUNTING RAIL 5 713
3176 4261 01 RELAY K 29 728 3176 4363 08 MOUNTING RAIL 7 715
3176 4261 02 RELAY 2 837 3176 4363 08 MOUNTING RAIL 34 675
3176 4303 01 HALOGEN LAMP 1 747 3176 4363 08 MOUNTING RAIL 77 702
3176 4324 02 RELAY SOCKET 3 837 3176 4363 08 MOUNTING RAIL 2 317
3176 4324 02 RELAY SOCKET K 29 728 3176 4394 00 FUSE F101 339
3176 4325 03 CAPACITOR C 69 727 3176 4402 52 DRILLED BOX 1 695
3176 4326 01 DIODE UNIT V 33 729 3176 4402 52 DRILLED BOX 1 693
3176 4326 01 DIODE UNIT V34 849 3176 4491 01 MARKING PLATE 6 501
3176 4329 05 RECTIFIER U 68 729 3176 4491 01 MARKING PLATE 76 702
3176 4329 30 COOLING FLANGE U 68 729 3176 4491 01 MARKING PLATE 72 677
932
3176 4491 01 MARKING PLATE 13 349 3176 5220 00 HOSE ASSEMBLY E2 635
3176 4491 01 MARKING PLATE 13 317 3176 5220 00 HOSE ASSEMBLY E2 883
3176 4491 01 MARKING PLATE 13 761 3176 5221 00 HOSE ASSEMBLY HB14 643
3176 4491 02 MARKING PLATE 13 761 3176 5233 00 VALVE 17 791
3176 4491 02 MARKING PLATE 13 349 3176 5313 00 CAP 34 136
3176 4491 02 MARKING PLATE 7 501 3176 5313 00 CAP 51 876
3176 4491 03 MARKING PLATE 21 729 3176 5409 00 DAMPER 10 843
3176 4491 03 MARKING PLATE 33 503 3176 5427 00 NIPPLE 35 872
3176 4491 04 MARKING PLATE 22 729 3176 5427 00 NIPPLE 71 266
3176 4492 01 MIN CIRC BREAK 5 675 3176 5427 00 NIPPLE 56 461
3176 4492 01 MIN CIRC BREAK F 17 727 3176 5428 00 NIPPLE 45 266
3176 4492 03 MIN CIRC BREAK F 48 727 3176 5429 00 CAP 51 876
3176 4494 00 BULB 1 345 3176 5535 00 NIPPLE 35 872
3176 4494 00 BULB 1 347 3176 5563 00 PLUG 50 876
3176 4494 00 BULB 1 757 3176 5588 10 U-BOLT 8 853
3176 4576 02 PLATE 4 697 3176 5670 00 HOSE ASSEMBLY T9 889
3176 4576 03 GASKET 17 675 3176 5670 00 HOSE ASSEMBLY T9 635
3176 4576 03 GASKET 11 697 3176 5670 00 HOSE ASSEMBLY T8 889
3176 4643 54 CABLE COMPLETE 2 183 3176 5670 00 HOSE ASSEMBLY T8 635
3176 5000 00 NIPPLE 9 865 3176 5672 00 HOSE ASSEMBLY TF 889
3176 5018 00 NIPPLE 40 874 3176 5672 00 HOSE ASSEMBLY TF 633
3176 5220 00 HOSE ASSEMBLY E1 883 3176 5679 00 HOSE ASSEMBLY J41 639
3176 5220 00 HOSE ASSEMBLY E1 635 3176 5679 00 HOSE ASSEMBLY HB11 884
933
3176 5679 00 HOSE ASSEMBLY J32 639 3176 5687 00 HOSE ASSEMBLY GR5 884
3176 5679 00 HOSE ASSEMBLY J31 885 3176 5687 00 HOSE ASSEMBLY XT3 890
3176 5679 00 HOSE ASSEMBLY HB22 643 3176 5687 00 HOSE ASSEMBLY LP 885
3176 5679 00 HOSE ASSEMBLY HB21 643 3176 5687 00 HOSE ASSEMBLY GR5 635
3176 5679 00 HOSE ASSEMBLY J42 885 3176 6020 00 PRESSURE GAUGE 6 595
3176 5679 00 HOSE ASSEMBLY HB12 884 3176 6022 00 PRESSURE GAUGE 7 595
3176 5679 00 HOSE ASSEMBLY HB21 884 3176 6036 00 NIPPLE 80 461
3176 5679 00 HOSE ASSEMBLY RHE2 139 3176 6301 00 NIPPLE 9 865
3176 5679 00 HOSE ASSEMBLY J32 885 3176 6336 00 HOSE ASSEMBLY RHD1 139
3176 5679 00 HOSE ASSEMBLY RHE2 887 3176 6336 00 HOSE ASSEMBLY AP14 841
3176 5679 00 HOSE ASSEMBLY J42 639 3176 6336 00 HOSE ASSEMBLY AP14 881
3176 5679 00 HOSE ASSEMBLY RHE1 887 3176 6336 00 HOSE ASSEMBLY RHD1 887
3176 5679 00 HOSE ASSEMBLY J41 885 3176 6344 00 NIPPLE 26 869
3176 5679 00 HOSE ASSEMBLY J31 639 3176 6344 00 NIPPLE 7 863
3176 5680 00 HOSE ASSEMBLY GR3 884 3176 6348 00 NIPPLE 7 175
3176 5680 00 HOSE ASSEMBLY GR3 635 3176 6348 00 NIPPLE 89 103
3176 5681 00 HOSE ASSEMBLY P5 886 3176 6348 00 NIPPLE 2 839
3176 5681 00 HOSE ASSEMBLY OFR2 223 3176 6348 00 NIPPLE 25 265
3176 5681 00 HOSE ASSEMBLY P5 635 3176 6349 00 NIPPLE 20 136
3176 5685 00 HOSE ASSEMBLY BD2 269 3176 6351 00 NIPPLE 38 467
3176 5685 00 HOSE ASSEMBLY BD2 881 3176 6351 00 NIPPLE 8 385
3176 5687 00 HOSE ASSEMBLY LP 841 3176 6351 00 NIPPLE 25 136
3176 5687 00 HOSE ASSEMBLY XT3 636 3176 6351 00 NIPPLE 28 265
934
3176 6351 00 NIPPLE 26 869 3176 6505 00 NIPPLE 3B 862
3176 6352 00 NIPPLE 26 869 3176 6505 00 NIPPLE 53 266
3176 6353 00 NIPPLE 18 867 3176 6506 00 NIPPLE 3A 862
3176 6483 00 NIPPLE 9 865 3176 6507 00 NIPPLE 3A 862
3176 6486 00 HOSE ASSEMBLY 3 890 3176 6508 00 NIPPLE 3A 862
3176 6486 00 HOSE ASSEMBLY E3 635 3176 6509 00 NIPPLE 3A 862
3176 6486 00 HOSE ASSEMBLY E3 883 3176 6510 00 NIPPLE 7 864
3176 6486 00 HOSE ASSEMBLY GRT 181 3176 6511 00 NIPPLE 7 864
3176 6486 00 HOSE ASSEMBLY 3 839 3176 6511 00 NIPPLE 23 136
3176 6486 00 HOSE ASSEMBLY XS 636 3176 6511 00 NIPPLE 47 266
3176 6486 00 HOSE ASSEMBLY XS 890 3176 6512 00 NIPPLE 6 41
3176 6486 00 HOSE ASSEMBLY GRT 884 3176 6512 00 NIPPLE 41 137
3176 6495 00 NIPPLE 1 862 3176 6513 00 NIPPLE 33 136
3176 6496 00 NIPPLE 44 875 3176 6513 00 NIPPLE 7 864
3176 6496 00 NIPPLE 39 137 3176 6514 00 NIPPLE 7 864
3176 6497 00 NIPPLE 24 136 3176 6514 00 NIPPLE 5 41
3176 6497 00 NIPPLE 44 875 3176 6515 00 NIPPLE 24 79
3176 6498 00 NIPPLE 79 461 3176 6515 00 NIPPLE 7 864
3176 6498 00 NIPPLE 44 875 3176 6515 00 NIPPLE 82 267
3176 6499 00 NIPPLE 44 875 3176 6515 00 NIPPLE 35 136
3176 6499 00 NIPPLE 4 381 3176 6516 00 NIPPLE 7 864
3176 6500 00 NIPPLE 44 875 3176 6517 00 NIPPLE 75 266
3176 6501 00 NIPPLE 3A 862 3176 6517 00 NIPPLE 7 864
3176 6501 00 NIPPLE 34 266 3176 6518 00 NIPPLE 7 864
3176 6502 00 NIPPLE 3A 862 3176 6519 00 NIPPLE 7 864
3176 6503 00 NIPPLE 3A 862 3176 6520 00 NIPPLE 7 864
3176 6504 00 NIPPLE 3A 862 3176 6521 00 NIPPLE 7 864
3176 6504 00 NIPPLE 76 266 3176 6522 00 NIPPLE 14 866
935
3176 6523 00 NIPPLE 14 866 3176 6549 00 NIPPLE 78 461
3176 6524 00 NIPPLE 14 866 3176 6550 00 ELBOW 24 869
3176 6525 00 NIPPLE 14 866 3176 6550 00 ELBOW 52 461
3176 6526 00 NIPPLE 14 866 3176 6550 00 ELBOW 3 381
3176 6527 00 NIPPLE 14 866 3176 6551 00 ELBOW 24 869
3176 6527 00 NIPPLE 51 461 3176 6552 00 NIPPLE 27 870
3176 6528 00 NIPPLE 14 23 3176 6553 00 NIPPLE 27 870
3176 6528 00 NIPPLE 14 866 3176 6554 00 NIPPLE 27 870
3176 6529 00 NIPPLE 14 866 3176 6555 00 NIPPLE 27 870
3176 6530 00 NIPPLE 9 865 3176 6556 00 NIPPLE 27 870
3176 6531 00 NIPPLE 9 865 3176 6557 00 NIPPLE 29 870
3176 6532 00 NIPPLE 9 865 3176 6558 00 NIPPLE 29 870
3176 6533 00 NIPPLE 9 865 3176 6559 00 NIPPLE 29 870
3176 6534 00 NIPPLE 9 865 3176 6560 00 NIPPLE 4 413
3176 6535 00 NIPPLE 5 413 3176 6560 00 NIPPLE 29 870
3176 6535 00 NIPPLE 9 865 3176 6561 00 NIPPLE 29 870
3176 6536 00 NIPPLE 9 865 3176 6562 00 NIPPLE 31 872
3176 6537 00 NIPPLE 9 865 3176 6562 00 NIPPLE 53 461
3176 6538 00 NIPPLE 9 865 3176 6563 00 NIPPLE 26 869
3176 6539 00 NIPPLE 70 461 3176 6564 00 NIPPLE 26 869
3176 6539 00 NIPPLE 10 866 3176 6564 00 NIPPLE 39 266
3176 6540 00 NIPPLE 10 866 3176 6565 00 NIPPLE 26 869
3176 6542 00 NIPPLE 18 867 3176 6566 00 NIPPLE 26 869
3176 6543 00 NIPPLE 18 867 3176 6566 00 NIPPLE 3 413
3176 6544 00 NIPPLE 18 868 3176 6567 00 NIPPLE 26 869
3176 6547 00 NIPPLE 24 869 3176 6568 00 NIPPLE 26 869
3176 6547 00 NIPPLE 42 137 3176 6569 00 NIPPLE 26 869
3176 6548 00 NIPPLE 24 869 3176 6570 00 NIPPLE 28 870
3176 6549 00 NIPPLE 24 869 3176 6571 00 ELBOW 28 870
3176 6549 00 NIPPLE 14 265 3176 6572 00 NIPPLE 28 870
936
3176 6574 00 NIPPLE 33 872 3176 6597 00 NIPPLE 37 873
3176 6575 00 NIPPLE 33 872 3176 6598 00 NIPPLE 39 873
3176 6576 00 NIPPLE 34 872 3176 6599 00 NIPPLE 39 873
3176 6576 00 NIPPLE 30 266 3176 6600 00 NIPPLE 39 873
3176 6577 00 NIPPLE 34 872 3176 6601 00 NIPPLE 39 873
3176 6578 00 NIPPLE 34 872 3176 6602 00 NIPPLE 39 873
3176 6579 00 NIPPLE 36 873 3176 6603 00 NIPPLE 41 874
3176 6580 00 NIPPLE 36 873 3176 6604 00 NIPPLE 41 874
3176 6581 00 NIPPLE 36 873 3176 6605 00 NIPPLE 41 874
3176 6582 00 NIPPLE 36 873 3176 6612 00 NIPPLE 26 869
3176 6583 00 NIPPLE 36 873 3176 6613 00 CAP NUT 48 875
3176 6584 00 NIPPLE 38 873 3176 6614 00 CAP NUT 48 875
3176 6585 00 NIPPLE 38 873 3176 6615 00 CAP NUT 33 266
3176 6585 00 NIPPLE 36 873 3176 6615 00 CAP NUT 48 875
3176 6586 00 NIPPLE 36 873 3176 6616 00 CAP NUT 48 875
3176 6586 00 NIPPLE 38 873 3176 6618 00 CAP NUT 48 875
3176 6587 00 NIPPLE 38 873 3176 6619 00 NIPPLE 7 863
3176 6588 00 NIPPLE 38 873 3176 6620 00 NIPPLE 7 863
3176 6589 00 NIPPLE 40 874 3176 6633 00 NIPPLE 1 862
3176 6590 00 NIPPLE 48 266 3176 6634 00 NIPPLE 1 862
3176 6590 00 NIPPLE 82 461 3176 6635 00 NIPPLE 1 862
3176 6590 00 NIPPLE 12 847 3176 6636 00 NIPPLE 44 875
3176 6590 00 NIPPLE 35 872 3176 6637 00 NIPPLE 44 875
3176 6590 00 NIPPLE 15 265 3176 6638 00 NIPPLE 44 875
3176 6591 00 NIPPLE 35 872 3176 6639 00 NIPPLE 3A 862
3176 6592 00 NIPPLE 35 872 3176 6640 00 NIPPLE 3A 862
3176 6593 00 NIPPLE 37 873 3176 6641 00 NIPPLE 3A 862
3176 6594 00 NIPPLE 37 873 3176 6642 00 NIPPLE 7 864
3176 6595 00 NIPPLE 37 873 3176 6643 00 NIPPLE 7 864
3176 6596 00 NIPPLE 37 873 3176 6644 00 NIPPLE 7 864
937
3176 6645 00 NIPPLE 7 864 3176 6674 00 NIPPLE 26 869
3176 6646 00 NIPPLE 7 864 3176 6675 00 NIPPLE 26 869
3176 6646 00 NIPPLE 50 266 3176 6676 00 NIPPLE 28 870
3176 6647 00 NIPPLE 14 866 3176 6677 00 NIPPLE 28 870
3176 6648 00 NIPPLE 14 866 3176 6678 00 NIPPLE 28 870
3176 6649 00 NIPPLE 14 866 3176 6679 00 NIPPLE 33 872
3176 6650 00 NIPPLE 14 866 3176 6680 00 NIPPLE 33 872
3176 6651 00 NIPPLE 9 865 3176 6681 00 NIPPLE 33 872
3176 6652 00 NIPPLE 9 865 3176 6682 00 NIPPLE 34 872
3176 6653 00 NIPPLE 9 865 3176 6683 00 NIPPLE 34 872
3176 6654 00 NIPPLE 9 865 3176 6684 00 NIPPLE 34 872
3176 6655 00 NIPPLE 9 865 3176 6687 00 NIPPLE 38 873
3176 6656 00 NIPPLE 9 865 3176 6688 00 NIPPLE 38 873
3176 6657 00 NIPPLE 10 866 3176 6689 00 NIPPLE 38 873
3176 6658 00 NIPPLE 10 866 3176 6690 00 NIPPLE 35 872
3176 6659 00 NIPPLE 10 866 3176 6691 00 NIPPLE 35 872
3176 6660 00 NIPPLE 24 869 3176 6692 00 NIPPLE 35 872
3176 6661 00 NIPPLE 24 869 3176 6693 00 NIPPLE 37 873
3176 6662 00 NIPPLE 24 869 3176 6694 00 NIPPLE 37 873
3176 6663 00 NIPPLE 27 870 3176 6695 00 NIPPLE 39 874
3176 6664 00 NIPPLE 27 870 3176 6696 00 NIPPLE 39 874
3176 6665 00 NIPPLE 29 870 3176 6697 00 NIPPLE 39 874
3176 6666 00 NIPPLE 29 870 3176 6698 00 PLUG 50 876
3176 6667 00 NIPPLE 29 870 3176 6699 00 PLUG 50 876
3176 6668 00 NIPPLE 23 868 3176 6700 00 PLUG 50 876
3176 6669 00 NIPPLE 23 868 3176 6701 00 CAP 51 876
3176 6670 00 NIPPLE 23 868 3176 6702 00 CAP 51 876
3176 6671 00 NIPPLE 26 869 3176 6703 00 CAP 51 876
3176 6672 00 NIPPLE 26 869 3176 6708 00 NIPPLE 6 863
3176 6673 00 NIPPLE 26 869 3176 6787 00 CAP NUT 48 875
938
3176 6788 00 CAP NUT 51 266 3176 6861 00 HOSE ASSEMBLY WR1 889
3176 6788 00 CAP NUT 48 875 3176 6862 00 HOSE ASSEMBLY TF1 889
3176 6789 00 CAP NUT 48 875 3176 6862 00 HOSE ASSEMBLY P8 635
3176 6854 00 HOSE ASSEMBLY PG 635 3176 6862 00 HOSE ASSEMBLY AP4 881
3176 6854 00 HOSE ASSEMBLY RHD2 887 3176 6862 00 HOSE ASSEMBLY TF1 659
3176 6854 00 HOSE ASSEMBLY XR3 890 3176 6862 00 HOSE ASSEMBLY AP4 841
3176 6854 00 HOSE ASSEMBLY XR3 636 3176 6862 00 HOSE ASSEMBLY P8 886
3176 6854 00 HOSE ASSEMBLY XFP 890 3176 6972 00 HOSE ASSEMBLY BS12 645
3176 6854 00 HOSE ASSEMBLY PG 886 3176 6972 00 HOSE ASSEMBLY AP2 881
3176 6854 00 HOSE ASSEMBLY RHD2 139 3176 6972 00 HOSE ASSEMBLY AP2 841
3176 6854 00 HOSE ASSEMBLY XFP 635 3176 6972 00 HOSE ASSEMBLY BS12 882
3176 6856 00 HOSE ASSEMBLY GGF 635 3176 6974 00 HOSE ASSEMBLY DP9 635
3176 6856 00 HOSE ASSEMBLY GGW 635 3176 6974 00 HOSE ASSEMBLY DP9 883
3176 6856 00 HOSE ASSEMBLY GGR 635 3176 6975 00 HOSE ASSEMBLY BD1 881
3176 6856 00 HOSE ASSEMBLY GGF 884 3176 6975 00 HOSE ASSEMBLY BD1 269
3176 6856 00 HOSE ASSEMBLY GGW 884 3176 6981 00 NIPPLE 4 862
3176 6856 00 HOSE ASSEMBLY GGR 884 3176 6983 00 NIPPLE 6 863
3176 6858 00 HOSE ASSEMBLY GRT3 884 3176 7058 00 NIPPLE 10 866
3176 6858 00 HOSE ASSEMBLY GRT3 181 3176 7071 00 NIPPLE 43 874
3176 6859 00 HOSE ASSEMBLY J11 885 3176 7099 00 HOSE ASSEMBLY DS9 633
3176 6859 00 HOSE ASSEMBLY J11 639 3176 7099 00 HOSE ASSEMBLY DS9 883
3176 6859 00 HOSE ASSEMBLY AP10 881 3176 7099 00 HOSE ASSEMBLY DS7 883
3176 6859 00 HOSE ASSEMBLY AP10 181 3176 7099 00 HOSE ASSEMBLY DS7 641
3176 6859 00 HOSE ASSEMBLY J12 639 3176 7186 00 HOSE ASSEMBLY RHC2 139
3176 6859 00 HOSE ASSEMBLY J12 885 3176 7186 00 HOSE ASSEMBLY RHC2 886
3176 6860 00 HOSE ASSEMBLY C4 651 3176 7208 00 NEEDLE VALVE 12 791
3176 6860 00 HOSE ASSEMBLY C3 651 3176 7208 00 NEEDLE VALVE 7 812
3176 6860 00 HOSE ASSEMBLY C4 882 3176 7304 00 NIPPLE 7 864
3176 6860 00 HOSE ASSEMBLY C3 882 3176 7319 00 NIPPLE 5 863
3176 6861 00 HOSE ASSEMBLY WR1 633 3176 7319 00 NIPPLE 4 385
939
3176 7336 00 NIPPLE 3B 862 3176 7644 00 HOSE ASSEMBLY RHE6 647
3176 7337 00 NIPPLE 3A 862 3176 7644 00 HOSE ASSEMBLY RHF5 648
3176 7337 00 NIPPLE 52 266 3176 7644 00 HOSE ASSEMBLY RHA8 647
3176 7338 00 NIPPLE 3A 862 3176 7644 00 HOSE ASSEMBLY RHA7 647
3176 7339 00 NIPPLE 3A 862 3176 7645 00 HOSE ASSEMBLY SH1 888
3176 7340 00 NIPPLE 4 863 3176 7645 00 HOSE ASSEMBLY SH4 653
3176 7342 00 NIPPLE 14 866 3176 7665 00 HOSE ASSEMBLY DR 883
3176 7449 00 HOSE ASSEMBLY TF12 889 3176 7665 00 HOSE ASSEMBLY DR 633
3176 7449 00 HOSE ASSEMBLY TF12 635 3176 7703 00 NIPPLE 6 863
3176 7457 00 HOSE ASSEMBLY 2BR2 890 3176 7707 00 NIPPLE 6 863
3176 7457 00 HOSE ASSEMBLY 2BR2 269 3176 7707 00 NIPPLE 11 265
3176 7574 00 PLATE 78 613 3176 7757 00 NIPPLE 19 868
3176 7644 00 HOSE ASSEMBLY RHA8 886 3176 7851 00 NIPPLE 9 595
3176 7644 00 HOSE ASSEMBLY RHC5 647 3176 7868 07 PLUG 30 547
3176 7644 00 HOSE ASSEMBLY RHF5 887 3176 7872 00 ELBOW NIPPLE 23 868
3176 7644 00 HOSE ASSEMBLY RHG6 888 3176 7873 00 NIPPLE 23 868
3176 7644 00 HOSE ASSEMBLY RHA7 886 3176 7937 00 RESTRICTION 15 791
3176 7644 00 HOSE ASSEMBLY RHD5 647 3176 7968 00 NIPPLE 55 877
3176 7644 00 HOSE ASSEMBLY RHD5 887 3176 8026 00 NIPPLE 3A 862
3176 7644 00 HOSE ASSEMBLY RHC5 887 3176 8027 00 NIPPLE 3A 862
3176 7644 00 HOSE ASSEMBLY RHC6 887 3176 8029 00 CAP 51 876
3176 7644 00 HOSE ASSEMBLY RHC6 647 3176 8043 00 NIPPLE 14 867
3176 7644 00 HOSE ASSEMBLY RHG6 648 3176 8076 00 NIPPLE 6 863
940
3176 8077 00 NIPPLE 6 863 3176 8927 00 NIPPLE 47A 875
3176 8078 00 NIPPLE 6 863 3176 8972 00 NIPPLE 22 868
3176 8120 00 NIPPLE 18 868 3176 8973 00 NIPPLE 22 868
3176 8149 93 RESTRICTION SET 21 576 3177 0000 64 KIT 831
3176 8149 93 RESTRICTION SET 9 526 3177 0001 61 BRAKE HOUSING 1 219
3176 8153 00 VALVE CONE 2 589 3177 0001 62 FLANGE 2 219
3176 8251 00 NIPPLE 3A 862 3177 0001 63 SHAFT 3 219
3176 8264 00 FLOW CONT.VALVE 56 137 3177 0001 64 PISTON 5 219
3176 8266 00 WIRE MESH HOSE 4 479 3177 0001 65 SPACER 6 219
3176 8270 00 NIPPLE 19 868 3177 0001 66 RING 7 219
3176 8271 00 NIPPLE 9 865 3177 0001 67 SPRING 8 219
3176 8289 00 PLUG 50 876 3177 0001 68 DISK 10 219
3176 8292 00 NIPPLE 15 867 3177 0001 69 STEEL DISK 11 219
3176 8377 00 SHUTTLE VALVE 23 552 3177 0001 70 BEARING 13 219
3176 8402 00 NIPPLE 8 864 3177 0001 71 CIRCLIP 15 219
3176 8424 00 NIPPLE 45 875 3177 0001 72 CIRCLIP 16 219
3176 8489 00 NIPPLE 26 265 3177 0001 73 RETAINING RING 17 219
3176 8489 00 NIPPLE 19 868 3177 0001 74 RETAINING RING 19 219
3176 8489 00 NIPPLE 6 385 3177 0001 80 RING 28 219
3176 8490 00 NIPPLE 19 868 3177 0001 81 RING 29 219
3176 8502 90 COUPLING HALF 2 517 3177 0001 82 BEND 30 219
3176 8505 00 RESTRICTION 74 613 3177 0001 83 SCREW 31 219
3176 8505 00 RESTRICTION 61 137 3177 0001 84 SCREW 32 219
3176 8641 00 PRESS.REGULATOR 2 812 3177 0001 85 STUD 35 219
3176 8641 01 SEAL KIT 827 3177 0001 86 PLUG 31 215
3176 8695 00 PRESSURE GAUGE 4 791 3177 0001 86 PLUG 37 219
3176 8711 00 NIPPLE 11 866 3177 0001 87 PLUG 38 219
3176 8872 00 NIPPLE 11 866 3177 0001 88 PLUG 39 219
3176 8880 00 HOSE ASSEMBLY BS28 641 3177 0001 89 WASHER 40 219
3176 8880 00 HOSE ASSEMBLY BS28 882 3177 0001 90 WASHER 41 219
941
3177 0001 91 WASHER 42 219 3177 3068 00 NIPPLE 20 265
3177 0001 91 WASHER 33 215 3177 3070 00 NIPPLE 15 867
3177 0002 17 OIL PLUG 1 359 3177 3070 00 NIPPLE 31 552
3177 0002 18 GASKET 5 359 3177 3077 00 ASSEMBLY PLATE 10 552
3177 0002 19 GENERATOR 8 359 3177 3092 52 COIL 2 557
3177 0055 00 BUFFER 6 261 3177 3092 52 COIL 2 141
3177 0060 01 ROLLER 2 497 3177 3092 53 SEAL KIT 141
3177 0074 13 CROSSING NIPPLE 58 461 3177 3092 53 SEAL KIT 557
3177 0074 13 CROSSING NIPPLE 34 467 3177 3092 54 NUT SET 141
3177 3012 00 NIPPLE 15 867 3177 3092 54 NUT SET 557
3177 3016 00 COUPLING 17 265 3177 3092 55 COIL 3 559
3177 3016 00 COUPLING 24 576 3177 3092 55 COIL 2 515
3177 3016 00 COUPLING 6 601 3177 3092 55 COIL 3 149
3177 3016 00 COUPLING 2 526 3177 3092 55 COIL 2 585
3177 3016 00 COUPLING 6 169 3177 3092 55 COIL 2 147
3177 3016 00 COUPLING 7 535 3177 3092 55 COIL 3 143
3177 3016 00 COUPLING 6 597 3177 3092 55 COIL 3 581
3177 3016 00 COUPLING 1 603 3177 3092 56 SEAL KIT 559
3177 3016 00 COUPLING 2 609 3177 3092 56 SEAL KIT 3 147
3177 3025 00 NIPPLE 19 868 3177 3092 56 SEAL KIT 149
3177 3032 00 PRESSURE GAUGE 16 552 3177 3092 56 SEAL KIT 143
3177 3032 00 PRESSURE GAUGE 3 535 3177 3092 56 SEAL KIT 581
3177 3045 00 NIPPLE 26 869 3177 3092 56 SEAL KIT 3 515
3177 3046 00 NIPPLE 21 265 3177 3092 56 SEAL KIT 3 585
3177 3046 00 NIPPLE 26 870 3177 3092 57 NUT 1 149
3177 3047 00 ADAPTER SLEEVE 49A 875 3177 3092 57 NUT 143
3177 3054 00 NIPPLE 5 863 3177 3092 57 NUT 1 559
3177 3063 00 NIPPLE 10 866 3177 3092 57 NUT 1 147
3177 3064 00 NIPPLE 3A 862 3177 3092 57 NUT 1 585
3177 3068 00 NIPPLE 5 863 3177 3092 57 NUT 1 515
942
3177 3092 57 NUT 581 3177 3178 00 NIPPLE 2 862
3177 3092 80 DIRECTION VALVE 6 136 3177 3190 00 NIPPLE 28 870
3177 3092 80 DIRECTION VALVE C9 555 3177 3195 00 NIPPLE 27 870
3177 3092 80 DIRECTION VALVE C8 555 3177 3197 00 CAP 51 876
3177 3092 81 DIRECTION VALVE C7 555 3177 5031 00 PRESSURE GAUGE 24 552
3177 3092 83 DIRECTION VALVE 3 601 3177 5048 01 BALL VALVE 4 853
3177 3092 83 DIRECTION VALVE 1 611 3177 5048 02 LEVER 5 853
3177 3092 83 DIRECTION VALVE 1 625 3177 7001 05 PRESSURE SWITCH 13 812
3177 3092 83 DIRECTION VALVE 4 603 3177 7017 00 JOYSTICK 30 701
3177 3092 83 DIRECTION VALVE 2 605 3177 7023 13 COVER 4 681
3177 3092 83 DIRECTION VALVE 3 597 3177 7023 13 COVER 10 699
3177 3092 83 DIRECTION VALVE 2 627 3177 7024 12 SLEEVE INSERT 15 675
3177 3092 83 DIRECTION VALVE 3 136 3177 7024 13 HOUSING 5 697
3177 3092 88 DIRECTION VALVE 3 513 3214 0181 00 MOUNTING RAIL 8 349
3177 3092 89 DIRECTION VALVE 12 576 3214 6056 00 HOSE NIPPLE 1 533
3177 3095 00 NIPPLE 35 873 3214 7494 03 REDUCT. NIPPLE 1 513
3177 3107 00 NIPPLE 19 868 3214 7675 92 SEAL KIT - 555
3177 3108 00 ADAPTER SLEEVE 49A 876 3214 7790 00 DISK 13 102
3177 3132 00 NIPPLE 19 868 3214 8399 00 VENTURI PIPE 1 839
3177 3136 00 NIPPLE 15 867 3214 8520 80 FLOW METER 30 812
3177 3147 00 PRESSURE GAUGE 18 552 3214 8712 80 PRESS.RED.VALVE 2 169
943
3214 8712 80 PRESS.RED.VALVE 2 601 3217 0010 06 TRIGGER 1 331
3214 8712 80 PRESS.RED.VALVE 16 136 3217 0010 11 CONTROL SWITCH 1 759
3214 8712 80 PRESS.RED.VALVE 2 597 3217 0010 14 PALM GRIP 8 697
3214 8712 82 PLUG 3 583 3217 0010 45 LAMP CALOTTE H 53 727
3214 8712 82 PLUG 3 153 3217 0010 47 LAMP CALOTTE H 38 727
3214 8712 83 SPRING 7 153 3217 0010 47 LAMP CALOTTE H40 849
3214 8712 83 SPRING 7 583 3217 0010 47 LAMP CALOTTE 4 701
3214 8712 86 REGULATING UNIT 6 157 3217 0010 47 LAMP CALOTTE H 39 727
3214 8712 86 REGULATING UNIT 6 591 3217 0010 47 LAMP CALOTTE H 35 727
3214 8712 87 SEAL KIT 591 3217 0010 47 LAMP CALOTTE H41 849
3214 8712 87 SEAL KIT 10 153 3217 0010 47 LAMP CALOTTE H 36 727
3214 8712 87 SEAL KIT 157 3217 0010 47 LAMP CALOTTE 8 501
3214 8712 87 SEAL KIT 10 583 3217 0010 47 LAMP CALOTTE 1 323
3216 1531 00 FUSE F100 339 3217 0010 47 LAMP CALOTTE H 65 727
3216 3466 80 PRESS.REGULATOR 12 812 3217 0010 57 LAMP INSERT 5 695
3216 3719 00 DIAPHRAGM - 835 3217 0010 59 LAMP INSERT H 35 727
3216 5295 00 GASKET 6 307 3217 0010 59 LAMP INSERT 9 501
3216 7882 00 NIPPLE 5 839 3217 0010 59 LAMP INSERT 6 701
3216 8883 00 THROTTLE VALVE 21 552 3217 0010 59 LAMP INSERT 3 323
3216 8883 00 THROTTLE VALVE 3 526 3217 0010 59 LAMP INSERT H41 849
3217 0010 02 TRIGGER 11 501 3217 0010 59 LAMP INSERT H40 849
3217 0010 02 TRIGGER S 32 729 3217 0010 61 LAMP INSERT H 53 727
3217 0010 02 TRIGGER 1 333 3217 0010 72 INTERMED. PART S56 503
3217 0010 02 TRIGGER 9 697 3217 0010 72 INTERMED. PART 20 697
3217 0010 02 TRIGGER 2 695 3217 0010 72 INTERMED. PART S59 503
3217 0010 02 TRIGGER 2 693 3217 0010 72 INTERMED. PART 12 501
3217 0010 03 TRIGGER S56 503 3217 0010 72 INTERMED. PART H40 849
944
3217 0010 72 INTERMED. PART 2 331 3217 0010 74 CONTACT BLOCK 3 331
3217 0010 72 INTERMED. PART H41 849 3217 0010 74 CONTACT BLOCK 3 707
3217 0010 72 INTERMED. PART 2 759 3217 0010 74 CONTACT BLOCK S56 503
3217 0010 72 INTERMED. PART 6 695 3217 0010 75 SEALING COVER 7 693
3217 0010 72 INTERMED. PART H 35 727 3217 0010 75 SEALING COVER 4 331
3217 0010 72 INTERMED. PART S 32 729 3217 0010 75 SEALING COVER 4 333
3217 0010 72 INTERMED. PART 3 857 3217 0010 76 PROTECTION RING 22 697
3217 0010 72 INTERMED. PART 4 701 3217 0010 76 PROTECTION RING 21 697
3217 0010 72 INTERMED. PART 10 251 3217 0010 79 MUSHROOM PUSHB. 1 707
3217 0010 72 INTERMED. PART 8 701 3217 0010 81 MUSHROOM PUSHB. 8 701
3217 0010 72 INTERMED. PART 2 707 3217 0010 87 MUSHROOM PUSHB. S59 503
3217 0010 72 INTERMED. PART 2 327 3217 0010 90 LAMPPUSHBUTTON 3 695
3217 0010 73 CONTACT BLOCK 10 701 3217 0011 07 MUSHROOM PUSHB. 1 327
3217 0010 73 CONTACT BLOCK 3 333 3217 0011 09 EMERG. STOP BOX 1 721
3217 0010 73 CONTACT BLOCK 11 251 3217 0012 00 PUSH BUTTON S178 319
3217 0010 73 CONTACT BLOCK S 32 729 3217 0012 05 INDICATION LAMP H239 319
3217 0010 73 CONTACT BLOCK 3 759 3217 0012 05 INDICATION LAMP H219 319
3217 0010 73 CONTACT BLOCK S56 503 3217 0012 05 INDICATION LAMP H206 319
3217 0010 73 CONTACT BLOCK 3 327 3217 0012 11 SWITCH S147 755
3217 0010 73 CONTACT BLOCK 4 695 3217 0012 35 MUSHROOM PUSHB. S138 319
3217 0010 74 CONTACT BLOCK S59 503 3217 0012 58 PUSH BUTTON S157 319
945
3217 0012 58 PUSH BUTTON S186 319 3217 6047 02 DAMPER 12 593
3217 0012 73 PALM GRIP 2 185 3217 6148 00 NIPPLE 6 863
3217 0347 00 HOLDER 1 595 3217 6218 00 NIPPLE 4 863
3217 2682 00 PLUG 5 513 3217 6246 40 PISTON ROD 8 231
3217 3838 00 LOCK LEVER 2 745 3217 6246 47 PISTON ROD 15 69
3217 3839 00 PALM GRIP 4 595 3217 6359 00 LOCK SHEET 4 489
3217 3839 00 PALM GRIP 3 745 3217 6359 00 LOCK SHEET 4 195
3217 3841 00 HOLDER 1 745 3217 6512 01 RESTRICTION 55 266
3217 3909 14 NUT 15 485 3217 6513 02 RESTRICTION 4 607
3217 3909 19 OIL PLUG 29 485 3217 6513 02 RESTRICTION 38 136
3217 3909 21 BUSHING 24 485 3217 6514 83 CONTROL BOX 1 855
3217 3909 22 SETTING KEY 26 485 3217 6814 00 SHAFT 48 394
3217 3909 23 SEAL RING 25 485 3217 6993 00 SCREW 11 441
3217 3909 29 COVER 35 486 3217 7310 00 NIPPLE 18 868
3217 3909 80 GEAR HOUSING 3 479 3217 7403 00 RESERVOIR 1 795
3217 3909 82 SEALING SET 485 3217 7403 01 COVER 6 795
3217 3909 83 FRICTION KIT 485 3217 7403 80 OIL RESERVOIR 3 791
3217 3909 84 STAND FRAME 485 3217 7471 10 HOSE NIPPLE 1 531
3217 3909 85 BEARING SET 485 3217 7835 20 CABLE REEL 800 473
3217 3910 24 SEAL RING 27 485 3217 7864 01 DIRECTION VALVE C10 555
3217 3913 81 HYDRAULIC UNIT 2 479 3217 7864 11 HOUSE 1 561
3217 3917 01 BUSHING 6 481 3217 7864 12 COVER 7 561
3217 3917 02 KEY 7 481 3217 7864 13 PISTON 19 561
3217 4501 01 SPACER SLEEVE 4 745 3217 7864 14 WASHER 60 561
3217 5598 80 DRUM 1 479 3217 7864 15 SPRING HOLDER 63 561
3217 5599 01 INTERMED.FLANGE 4 481 3217 7864 16 PIN 68 561
3217 5608 00 GASKET 21 675 3217 7864 17 SPRING 71 561
3217 6047 01 DAMPER 11 593 3217 7864 18 BACK-UP RING 104 561
946
3217 7864 20 CIRCLIP 148 561 3217 8403 00 SLEEVE 11 715
3217 7864 21 CIRCLIP 149 561 3217 8438 04 OPERATING CABLE J2 671
3217 7864 22 SEAL KIT - 561 3217 8440 00 CABLE 1 683
3217 7864 24 PLUG 182 561 3217 8486 03 PLATE 3 185
3217 7992 01 THERMOSTAT 15 671 3217 8524 02 COVER 4 537
3217 7992 02 THERMOSTAT 14 671 3217 8525 00 HYDRAULIC PUMP 2 537
3217 8049 30 NIPPLE 2 793 3217 8667 52 LUBRICAT.PUMP 1 791
3217 8180 00 HOSE NIPPLE 1 529 3217 8762 00 HYDRAULIC PUMP 1 537
3217 8265 00 FUSE HOLDER 26 715 3217 8762 01 SHAFT COUPLING 3 537
3217 8266 00 PIN INSERT 6 697 3217 8816 00 HEATER ELEMENT 8 675
3217 8266 00 PIN INSERT 5 699 3217 8816 00 HEATER ELEMENT 55 701
3217 8267 00 SLEEVE INSERT 13 715 3217 8923 31 PLC CABINET 1 675
3217 8267 00 SLEEVE INSERT 3 699 3217 8943 01 CHECK VALVE 9 812
3217 8277 00 PIN 15 697 3217 8943 02 CHECK VALVE 8 812
3217 8277 00 PIN 6 699 3217 8957 42 CONTROL PANEL 4 671
3217 8277 10 GUIDE SLEEVE 19 675 3217 8975 10 CABLE K1 671
3217 8277 11 GUIDE PIN 18 675 3217 8977 08 CABLE I1 671
3217 8278 00 SLEEVE 14 715 3217 9034 20 HYDRAULIC MOTOR 1 481
3217 8278 00 SLEEVE 4 699 3217 9060 02 CONNECT. PLATE 1 605
3217 8278 00 SLEEVE 16 675 3217 9060 06 CONNECT. PLATE 8 576
3217 8308 05 CABLE, 1-CORE 102 702 3217 9060 06 CONNECT. PLATE 6 603
3217 8399 00 PIN INSERT 10 715 3217 9060 07 CONNECT. PLATE 1 136
3217 8399 00 PIN INSERT 7 683 3217 9060 07 CONNECT. PLATE 7 576
3217 8400 00 SLEEVE INSERT 26 675 3217 9174 01 SHAFT SEAL 805
3217 8400 00 SLEEVE INSERT 6 683 3217 9174 12 SEAL KIT 805
3217 8402 00 FRAME 5 683 3217 9175 20 WATER PUMP SET 1 801
3217 8402 00 FRAME 9 715 3217 9192 50 WATER PUMP UNIT 502 789
3217 8402 00 FRAME 25 675 3217 9193 01 REGULATOR 9 576
3217 8403 00 SLEEVE 27 675 3217 9193 02 REGULATOR 2 535
3217 8403 00 SLEEVE 4 683 3217 9194 02 PISTON 2 579
947
3217 9194 03 SEAT 3 579 3217 9206 11 PUMP UNIT 1 541
3217 9194 04 SPRING 4 579 3217 9206 12 REG PISTON 2 541
3217 9194 05 SET SCREW 5 579 3217 9206 14 PISTON 4 541
3217 9194 06 SCREW 6 579 3217 9206 15 PUMP HOUSING 5 541
3217 9194 07 CONE 7 579 3217 9206 18 SHAFT 8 541
3217 9194 08 O-RING 8 579 3217 9206 19 PISTON GUIDE 9 541
3217 9194 09 BACK-UP RING 9 579 3217 9206 22 WASHER 12 541
3217 9194 10 KNOB 10 579 3217 9206 23 SPRING 13 541
3217 9203 01 PUMP 1 545 3217 9206 25 ROLLER BEARING 15 541
3217 9203 02 PILOT VALVE 2 539 3217 9206 26 ROLLER BEARING 16 541
3217 9203 02 PILOT VALVE 2 545 3217 9206 27 BEARING PLATE 17 541
3217 9203 11 PUMP UNIT 1 547 3217 9206 30 O-RING 22 541
3217 9203 12 REG PISTON 2 547 3217 9206 48 CRADLE 7 541
3217 9203 13 PISTON GUIDE 3 547 3217 9206 49 SEAL 20 541
3217 9203 14 PISTON 4 547 3217 9206 50 LOCK RING 25 541
3217 9203 18 SHAFT 8 547 3217 9206 82 SEAL KIT - 541
3217 9203 19 PISTON GUIDE 9 547 3217 9255 50 WATER PUMP 1 803
3217 9203 21 WASHER 11 547 3217 9273 00 POLYAMIDE HOSE 11 793
3217 9203 22 WASHER 12 547 3217 9277 37 VOLT METER P 12 728
3217 9203 23 SPRING 13 547 3217 9294 83 COMMUTATOR 820 473
3217 9203 25 ROLLER BEARING 15 547 3217 9299 09 TIMING RELAY K303 679
3217 9203 26 ROLLER BEARING 16 547 3217 9311 55 MOTORPROTECTOR F 6 727
3217 9203 27 BEARING PLATE 17 547 3217 9311 59 MOTORPROTECTOR F131 739
3217 9203 58 PLUG 3 545 3217 9311 61 MOTORPROTECTOR F126 739
3217 9203 58 PLUG 4 543 3217 9311 65 MOTORPROTECTOR F 18 727
3217 9203 59 O-RING 2 543 3217 9311 66 MOTORPROTECTOR F 19 727
3217 9203 82 SEAL KIT - 547 3217 9311 70 AUX. CONTACTS F126 739
3217 9203 94 CONTROL PLATE 2 549 3217 9311 70 AUX. CONTACTS F131 739
3217 9204 44 SEAL 20 547 3217 9311 80 MOTORPROTECTOR F 20 727
3217 9204 54 CRADLE 7 547 3217 9316 02 SAFETY VALVE 9 455
948
3217 9316 11 NOZZLE 13 455 3217 9583 01 RELAY K1 849
3217 9316 14 LOCK WASHER 14 455 3217 9583 01 RELAY 90 676
3217 9316 18 TRIGGER 6 455 3217 9583 04 RELAY K8 755
3217 9316 18 TRIGGER 5 467 3217 9592 10 TERMINAL BLOCK 51 701
3217 9316 19 GAS CARTRIDGE 7 455 3217 9592 20 DIODE UNIT 52 701
3217 9316 19 GAS CARTRIDGE 3 467 3217 9592 21 HOLDER 53 701
3217 9316 24 CHECK VALVE 10 455 3217 9655 10 TRANSFORMER T 62 729
3217 9316 24 CHECK VALVE 2 467 3217 9655 22 TRANSFORMER T 10 729
3217 9316 28 ATTACHMENT 4 467 3217 9656 15 TRANSFORMER T 16 729
3217 9316 28 ATTACHMENT 8 455 3217 9658 02 HOUR METER P 66 728
3217 9316 30 BRANCH BLOCK 11 455 3217 9666 02 EARTHFAULTRELAY K 10 727
3217 9316 42 ATTACHMENT 2 455 3217 9674 07 BATTERY CHARGER U158 729
3217 9316 44 ATTACHMENT 5 455 3217 9687 01 HEADLIGHT 3 743
3217 9337 40 PRESS.REL.VALVE 28 552 3217 9708 06 PHASE SEQ.RELAY K 26 727
3217 9339 00 DIRECTION VALVE 3 812 3217 9735 03 HOSE 29 111
3217 9339 01 COIL 1 829 3217 9766 01 DRUM PUMP 12 171
3217 9341 60 PRESS.RED.VALVE 23 576 3217 9766 03 COVER 13 171
3217 9341 60 PRESS.RED.VALVE 60 137 3217 9766 13 VALVE 177
3217 9390 01 NOZZLE 1 853 3217 9766 14 VALVE 177
3217 9504 00 HOSE L22 526 3217 9766 15 ADAPTER 48 178
3217 9504 01 HOSE L12 526 3217 9766 15 ADAPTER 14 171
3217 9512 02 TRANSFORMER T 11 729 3217 9766 16 COVER 15 171
3217 9583 01 RELAY K 31 728 3217 9766 25 GREASE 17 171
3217 9583 01 RELAY K2 849 3217 9773 00 FLOW CONT.VALVE 5 609
3217 9583 01 RELAY K164 728 3217 9773 19 SEAL KIT 587
3217 9583 01 RELAY K102 319 3217 9773 23 SEAL DISC 14 587
949
3217 9783 02 HOSE REEL 2 853 3217 9882 04 VALVE PLUG Y216 311
3217 9784 01 REGULATOR 44 676 3217 9882 05 VALVE PLUG 5 605
3217 9787 53 RELAY K 30 728 3217 9882 06 VALVE PLUG 22 171
3217 9787 53 RELAY K 64 728 3217 9882 09 VALVE PLUG 26 671
3217 9787 53 RELAY K 28 727 3217 9882 09 VALVE PLUG 4B 718
3217 9788 51 TIMING RELAY K 61DT 728 3217 9882 11 SIGNAL CABLE 4 535
3217 9788 51 TIMING RELAY K 61T 728 3217 9882 11 SIGNAL CABLE 25 671
3217 9788 51 TIMING RELAY K 30T 728 3217 9882 11 SIGNAL CABLE 5A 718
3217 9789 03 TRANSFORMER T 50 729 3217 9882 14 CABLE COMPLETE 31 791
3217 9823 01 INNER LIGHT 6 675 3217 9882 15 CABLE COMPLETE 3 847
3217 9825 01 AMPLIFIER 43 676 3217 9882 45 VALVE PLUG 2B 718
3217 9837 02 SWITCH 26 701 3217 9882 45 VALVE PLUG 2A 718
3217 9837 07 SWITCH 28 701 3217 9882 49 VALVE PLUG 3A 718
3217 9841 12 SWITCH S 51 729 3217 9882 51 VALVE PLUG 1A 718
3217 9865 01 FAN 9 675 3217 9882 51 VALVE PLUG 1B 718
3217 9865 10 FAN 57 702 3217 9891 02 PUSH-BUTTON-BOX 1 857
3217 9871 00 PULSE UNIT ECL 727 3217 9897 00 DIODE UNIT V58 503
3217 9873 02 EARTHFAULTRELAY F 91 727 3217 9897 01 DIODE UNIT 42 676
3217 9876 15 FLANGE 61 741 3217 9897 01 DIODE UNIT 24 317
3217 9882 04 VALVE PLUG 19 136 3217 9904 97 OVERLOAD RELAY F 60 739
3217 9882 04 VALVE PLUG 5 597 3217 9926 00 ATTACHMENT 3 593
3217 9882 04 VALVE PLUG 3 625 3217 9926 02 RUBBER CLOTH 4 593
3217 9882 04 VALVE PLUG 5 815 3217 9927 00 JUNCTION BOX 1 837
3217 9882 04 VALVE PLUG 4 627 3217 9946 00 PRESSURE SWITCH 4 526
3217 9882 04 VALVE PLUG 5 611 3217 9946 00 PRESSURE SWITCH 1 535
3217 9882 04 VALVE PLUG 5 601 3217 9952 00 LASER 52 249
3217 9882 04 VALVE PLUG 5 169 3217 9952 01 LASER 1 251
3217 9882 04 VALVE PLUG 27 671 3217 9952 02 CONVERTER 2 251
3217 9882 04 VALVE PLUG 5 793 3217 9952 03 PLATE 6 251
3217 9882 04 VALVE PLUG 8 603 3217 9952 09 CONVERTER 253
950
3217 9955 40 FLOW GUARD 30 791 3222 3048 20 GROUND BRAID 20 501
3217 9963 04 SEAL KIT - 555 3222 3048 77 GROUND BRAID 2 349
3217 9964 21 PRESS.REL.VALVE 18 576 3222 3048 77 GROUND BRAID 2 761
3217 9966 02 DIRECTION VALVE 17 552 3222 3098 17 REPAIR KIT - 835
3217 9966 03 DIRECTION VALVE 22 552 3222 3106 10 SOLENOID 1 273
3217 9970 63 ELECTRIC MOTOR 630 667 3222 3135 14 REPAIR SET 797
3217 9978 13 INSULATOR 16 477 3222 3168 52 SIGN 26 61
3217 9978 14 SOCKET 18 477 3222 3176 18 LOCK SCREW 6 229
3217 9978 14 SOCKET 17 477 3222 3264 90 VALVE 619
3217 9978 16 SOCKET 20 477 3222 3264 94 RESTRICTION 10 619
3217 9978 17 SOCKET COUPLER 708 473 3222 3264 95 SEAL KIT 619
3217 9978 19 PLUG CONNECTOR 705 473 3222 3264 95 SEAL KIT 621
3217 9978 24 INSULATOR 14 475 3222 3264 98 LEVER HOLDER 621
3217 9978 25 PIN 15 475 3222 3264 99 ACTUATOR 621
3217 9978 27 PIN 17 475 3222 3265 01 SPRING 7 621
3217 9978 67 SLEEVE 21 477 3222 3268 96 DOUBLE CH.VALVE 1 601
3217 9996 00 SOLENOID VALVE 25 171 3222 3268 96 DOUBLE CH.VALVE 4 136
3217 9997 00 SOLENOID VALVE 11 791 3222 3268 96 DOUBLE CH.VALVE 1 597
3217 9997 00 SOLENOID VALVE 4 812 3222 3289 42 FLOW GUARD 4 839
3218 2006 65 SEAL KIT 483 3222 3292 27 AIR VALVE A1 791
3218 2007 58 CONTROL VALVE 1 543 3222 3308 22 SEAL KIT 145
3218 2007 60 SCREW 3 543 3222 3308 22 SEAL KIT 599
3218 2008 28 TANK 1 455 3222 3322 44 SOLENOID 9 797
3218 2008 31 SEAL 1 459 3222 3323 38 CAN-OPEN CABLE 3 779
3218 2008 32 STEEL WIRE 2 459 3310 4076 00 CAP 11 21
3222 1488 03 SENSOR 7 673 3310 4076 00 CAP 17 53
3222 2900 30 PISTON 2 117 3310 4076 00 CAP 11 19
951
3315 0195 08 LOCK WASHER 29 43 3455 0766 04 NIPPLE 42 874
3363 0345 67 GREASE PUMP 16 3455 0766 08 NIPPLE 42 874
3455 0402 01 NIPPLE 16 867 3455 0766 09 NIPPLE 42 874
3455 0402 02 NIPPLE 16 867 3715 0581 00 NIPPLE 1 862
3455 0402 03 NIPPLE 16 867 3715 0584 00 ELBOW NIPPLE 23 868
3455 0402 11 NIPPLE 16 867 3715 0585 00 NIPPLE 92 267
3455 0402 12 NIPPLE 16 867 3715 0585 00 NIPPLE 23 869
3455 0402 13 NIPPLE 16 867 3715 0587 00 NIPPLE 9 865
3455 0543 01 NIPPLE 46 875 3715 0588 00 NIPPLE 28 870
3455 0543 02 NIPPLE 46 875 3715 0589 00 ELBOW 23 869
3455 0543 03 NIPPLE 46 875 3715 0597 00 CAP 51 876
3455 0543 04 NIPPLE 46 875 3715 0597 00 CAP 49 266
3455 0543 05 NIPPLE 46 875 3715 0597 00 CAP 36 136
3455 0543 06 NIPPLE 46 875 3715 0598 00 PLUG 50 876
3455 0543 06 NIPPLE 5 373 3715 0599 00 PLUG 50 876
3455 0543 07 NIPPLE 46 875 3715 0600 00 PLUG 50 876
3455 0543 08 NIPPLE 46 875 3715 0819 00 CAP 51 876
3455 0766 01 NIPPLE 42 874 3715 0820 00 CAP 6 381
3455 0766 02 NIPPLE 42 874 3715 0820 00 CAP 51 876
3455 0766 03 NIPPLE 42 874 3715 0820 00 CAP 6 373
952
3715 0821 00 PLUG 50 876 5112 0020 42 DRILLED BOX 1 317
3715 0889 03 RUBBER SLEEVE 2 519 5112 0104 01 JUNCTION BOX X2 311
3715 0889 90 BOLT SET - 519 5112 0104 04 SWITCH PANEL X5 311
3715 1505 00 ADAPTER SLEEVE 49A 876 5112 0104 09 DRIVING LIGHT. 2 311
3715 3020 00 ADAPTER SLEEVE 49A 876 5112 0104 17 EL EQUIPM.MOTOR 1 311
3715 3021 00 ADAPTER SLEEVE 49A 876 5112 0105 24 DRIVERS CHAIR 1 411
3715 3022 00 ADAPTER SLEEVE 49A 876 5112 0105 41 CABLE COMPLETE W501 339
3715 3030 00 ADAPTER SLEEVE 49A 876 5112 0105 48 JUNCTION BOX X8 311
3715 6344 00 NIPPLE 21 136 5112 0105 50 JUNCTION BOX X9 311
3715 6344 00 NIPPLE 32 201 5112 0105 93 OIL LEVEL PLUG 28 485
3980 1979 00 HOLDER 19 701 5112 0107 19 ATTACHMENT 69 461
4090 0630 00 HEX SOCK. SCREW 10 605 5112 0107 27 FIRE EXTING.SET 3 451
4090 0630 00 HEX SOCK. SCREW 20 576 5112 0107 30 HOSE SET 1 467
4090 0630 00 HEX SOCK. SCREW 3 627 5112 0115 67 CABLE COMPLETE 7 351
4090 0630 00 HEX SOCK. SCREW 7 603 5112 0127 90 CABLE H121 311
4142 4045 00 CONNECTOR 38 676 5112 1423 00 SUCT.-RETURN P. 11 285
4310 0464 00 PLAST.,ST.CABLE 9 339 5112 1579 00 PROTECTION COIL W188 313
4330 1016 00 BULLDOG GRIP 10 339 5112 1758 00 SLEEVE INSERT W189 313
5054 0140 00 PLASTIC TUBING 7 285 5112 1886 00 BOLT SET 3 369
5107 1534 00 NIPPLE 1 265 5112 1933 80 HYDR. CYLINDER 54 266
5107 1536 00 HOSE ASSEMBLY SU1 266 5112 2021 00 FLOOR RACK 3 387
5107 1536 00 HOSE ASSEMBLY SU1 888 5112 2051 00 SILENCER 1 419
5112 0000 29 JUNCTION BOX 1 501 5112 2083 81 LEVEL SENSOR 13 285
5112 0000 30 APPARATUS PANEL 2 499 5112 2086 00 HOLDER 18 340
5112 0001 83 GASKET 5 415 5112 2088 00 CABLE COMPLETE W533 339
5112 0007 77 SAFETY BELT 2 411 5112 2093 00 RING PIN 47 299
5112 0007 80 CHAIR COMPL. 5 409 5112 2163 00 VALVE HOUSING 5 391
5112 0011 41 SOCKET OUTLET X131 753 5112 2163 80 LUBR. VALVE 1 389
5112 0011 42 PLUG CONNECTOR X131 753 5112 2164 00 HIGH POWER PIPE 8 389
5112 0020 41 JUNCTION BOX X2 313 5112 2185 00 CUSHION 8 433
953
5112 2215 00 SEAL 32 320 5112 2349 80 STEERING SHANK 5 433
5112 2216 00 GROUND BRAID 22 340 5112 2350 15 STEERING KPL 1 433
5112 2216 04 EARTH TERMINAL 20 317 5112 2360 06 PISTON ROD 5 403
5112 2216 04 EARTH TERMINAL 6 349 5112 2360 80 HYDR. CYLINDER 51 394
5112 2216 04 EARTH TERMINAL 6 761 5112 2363 00 SHAFT 50 394
5112 2216 04 EARTH TERMINAL 27 320 5112 2368 00 CABLE COMPLETE G100 339
5112 2216 04 EARTH TERMINAL 29 715 5112 2387 00 STAY 48 299
5112 2320 00 PLATFORM 9 387 5112 2396 84 TRUNNION BLOCK 3 375
5112 2322 00 DAMPER 11 387 5112 2403 00 FENDER 19 393
5112 2325 00 WAIST SHAFT 2 393 5112 2404 00 DAMPER BIT 15 393
5112 2326 00 SHAFT 8 393 5112 2405 06 RUBBER PROTEC 49 299
5112 2328 00 BUSHING 1 413 5112 2405 08 RUBBER PROTEC 14 393
5112 2331 80 FUEL TANK 4 283 5112 2425 00 EDGE LIST 1 387
5112 2331 81 FUEL TANK 1 285 5112 2447 00 YOKE 6 387
5112 2335 08 RIM COLLAR 2 425 5112 2479 00 NIPPLE 7 303
5112 2335 09 LOCK RING 4 425 5112 2493 00 PLATE 42 321
5112 2335 10 RING 3 425 5112 2523 00 CUSHION 26 283
5112 2335 80 RIM COMPL. 1 423 5112 2524 00 COVER 21 283
5112 2336 00 CLAMP 4 433 5112 2525 00 BUSHING 22 283
5112 2337 00 ANGLE BRACKET 7 433 5112 2531 04 PROTECTION 14 303
5112 2338 00 TANK COVER 3 287 5112 2579 00 BAND 6 419
5112 2338 07 FILLER PIPE 18 285 5112 2595 00 PRESSURE SWITCH 9 265
5112 2339 00 GASKET 4 287 5112 2607 00 KNOB 7 309
5112 2340 00 COVER 6 285 5112 2608 00 RUBBER STROP 8 309
5112 2341 00 GASKET 5 285 5112 2610 00 BATTERY COVER 9 309
5112 2347 80 PILOT VALVE 88 267 5112 2646 00 U-BOLT 19 285
5112 2347 92 SEALING SET 279 5112 2710 00 ATTACHM. PLATE 17 283
5112 2348 80 VALVE BLOCK 89 267 5112 2710 00 ATTACHM. PLATE 53 394
5112 2348 91 SEAL KIT 281 5112 2731 24 BATTERY SHELF 10 309
5112 2348 93 ASSEMBLY SET 9 433 5112 2863 00 RELAY SHELF 10 320
954
5112 2865 00 GEAR CONTROL S137 319 5112 3001 71 PROTECTION 13 393
5112 2877 19 HYDR. SYSTEM 13 263 5112 3003 07 LOCK SHEET 3 293
5112 2877 37 HYDR. SYSTEM 1 263 5112 3003 10 FRICTION RING 8 297
5112 2877 71 PRESSURE SWITCH 9 353 5112 3003 10 FRICTION RING 13 401
5112 2878 05 BRAKE VALVE 32 266 5112 3003 15 PIN 6 401
5112 2878 46 LOCKING RING 25 547 5112 3003 23 NUT 30 293
5112 2879 00 CUSHION 11 320 5112 3003 35 WHEEL BOLT 1 289
5112 2909 00 COVER 4 185 5112 3003 35 WHEEL BOLT 1 399
5112 2909 00 COVER 6 857 5112 3003 37 PLUG 4 399
5112 2909 00 COVER 11 691 5112 3003 37 PLUG 4 289
5112 2909 00 COVER 46 321 5112 3003 59 DISK 2 291
5112 2915 00 ACCUMULATOR 41 266 5112 3003 60 DISK 4 291
5112 2921 01 PRESSURE SWITCH 6 265 5112 3003 75 BEARING 5 293
5112 2931 00 LEVEL-TEMP.IND. 8 303 5112 3003 77 PIN 10 401
5112 2931 01 PRESSURE SCREW 2 305 5112 3003 77 PIN 13 297
5112 2931 02 THERMOMETER 3 305 5112 3003 78 BEARING 5 293
5112 2931 03 PRESSURE SCREW 4 305 5112 3003 79 BEARING 27 293
5112 2931 90 SPARE PARTS SET 5 305 5112 3003 80 BEARING 35 293
5112 2943 00 PEDAL 2 367 5112 3005 03 O-RING 3 291
5112 2946 01 RUBBER BUFFER 58 300 5112 3007 09 FAN BELT 6 359
5112 2949 00 PROTECT. COVER 7 265 5112 3007 59 OIL FILTER 3 359
5112 2949 01 PROTECT. COVER 31 266 5112 3010 18 SPACER 5 293
5112 2949 01 PROTECT. COVER 11 353 5112 3012 00 BUSHING 37 266
5112 3000 35 ATTACHM. PLATE 25 393 5112 3020 43 STUD 6 309
5112 3000 38 CARDAN PROTECT. 26 393 5112 3020 69 SPACER 6 355
5112 3000 85 BRACKET 32 283 5112 3020 70 MOTOR FRAME 1 283
5112 3000 86 BRACKET 24 283 5112 3020 91 HOOK 11 299
5112 3000 90 BUSHING 25 283 5112 3020 92 SPACER 12 299
5112 3001 59 FLANGE SCR.SET 10 355 5112 3020 93 CARDAN SHAFT 14 355
5112 3001 70 PROTECTION 11 393 5112 3020 94 CARDAN SHAFT 9 355
955
5112 3020 95 CARDAN SHAFT 29 393 5112 3030 99 CABLE COMPLETE W502 339
5112 3021 00 FRAME 1 393 5112 3032 14 O-RING 1 291
5112 3021 07 COVER 4 431 5112 3032 14 O-RING 4 293
5112 3021 08 SUPPORT BEAM 54 300 5112 3032 73 HOLDER 4 373
5112 3021 12 HYDRAULIC PUMP 18 265 5112 3038 12 HOUSE 1 383
5112 3021 15 DRIVE AXLE 11 283 5112 3038 13 SCREW 2 383
5112 3021 20 CHAIR SUPPORT 6 409 5112 3040 69 THROTTLE WIRE 1 369
5112 3021 33 PROTECTION 1 365 5112 3041 80 FILLER SET 15 355
5112 3021 78 CABLE COMPLETE W534 339 5112 3043 10 FUSE CON. TERM. 15 317
5112 3021 81 NIPPLE 4 339 5112 3043 10 FUSE CON. TERM. F8 753
5112 3021 84 DRIVE AXLE 36 393 5112 3043 10 FUSE CON. TERM. 29 320
5112 3021 86 THERMOSTAT B357 339 5112 3043 12 MARKING PLATE 16 317
5112 3021 88 PRESSURE SWITCH B355 339 5112 3043 13 BRIDGE CONN. 30 320
5112 3022 18 HOSE 16 285 5112 3043 15 FUSE F8 753
5112 3022 87 JACK TUBE 52 394 5112 3043 15 FUSE F111 319
5112 3022 93 PRESSURE SWITCH B356 339 5112 3043 15 FUSE F112 319
5112 3023 43 PRESSURE SWITCH 91 267 5112 3043 15 FUSE F114 319
5112 3024 33 CONTROL PANEL 1 431 5112 3043 15 FUSE F113 319
5112 3024 50 ACCUMULAT.BLOCK 42 266 5112 3043 15 FUSE F115 319
5112 3024 66 BRAKE DISC KIT 289 5112 3043 15 FUSE F117 319
5112 3024 66 BRAKE DISC KIT 399 5112 3043 16 FUSE 17 317
5112 3024 68 CROWN WHEEL KIT 399 5112 3043 16 FUSE F116 319
5112 3024 68 CROWN WHEEL KIT 289 5112 3043 33 DIODE UNIT V100 320
5112 3024 71 PLANET GEAR KIT 399 5112 3043 40 HEADLIGHT E102 343
5112 3024 71 PLANET GEAR KIT 289 5112 3043 40 HEADLIGHT E105 755
5112 3024 73 ATTACHMENT 20 285 5112 3043 40 HEADLIGHT E101 343
5112 3024 98 FILTER 1 377 5112 3043 40 HEADLIGHT E106 755
5112 3024 99 ANGLE POINTER 11 429 5112 3044 36 NIPPLE 1 339
5112 3025 14 STEERING SYSTEM 2 429 5112 3045 87 BRAKING CHOPPER 822 473
5112 3025 20 CONTROL PANEL 1 429 5112 3045 99 PLATE 43 321
956
5112 3046 72 IGNITION LOCK 1 329 5112 3102 79 WASHER 4 397
5112 3046 73 IGNITON KEY 2 329 5112 3102 80 NUT 5 397
5112 3046 91 FLAT PIN SLEEVE 3 329 5112 3102 81 FLANGE FORK 4 375
5112 3046 92 IGNITION LOCK S139 319 5112 3102 84 BALL 7 375
5112 3049 06 CAP 1 457 5112 3102 85 CLAMP 6 375
5112 3049 08 GUIDE DISC 16 455 5112 3102 86 SPAT 5 375
5112 3049 11 ATTACHMENT 67 461 5112 3102 99 LEVEL GLASS 16 355
5112 3049 30 FIRE EXTING.SET 1 453 5112 3103 12 OIL LEVEL GLASS 4 383
5112 3052 41 AIR FILTER 1 361 5112 3104 74 PLANET GEAR HO. 5 289
5112 3052 42 FILTER ELEMENT 2 363 5112 3104 74 PLANET GEAR HO. 5 399
5112 3052 43 SAFETY CARTR. 1 363 5112 3109 18 SEAL KIT 397
5112 3052 44 HOLDER 2 361 5112 3109 23 COUNTER FLANGE 3 397
5112 3052 46 FILT.INDICATOR 3 361 5112 3111 75 CONNECTION 1 381
5112 3061 39 HOSE NIPPLE 30 111 5112 3120 19 SHOCK VALVE 281
5112 3064 12 MUDGUARD 21 393 5112 3120 40 FLANGE 6 289
5112 3064 13 MUDGUARD 7 393 5112 3124 73 BRAKE LIGHT 1 353
5112 3064 24 MUDGUARD 36 299 5112 3125 40 BULB 2 353
5112 3064 25 MUDGUARD 33 299 5112 3126 05 BRAKE LIGHT 11 311
5112 3064 41 BRACKET 38 299 5112 3133 08 O-RING 8 293
5112 3082 99 HUB 2 803 5112 3133 17 O-RING 23 293
5112 3100 56 SEAL KIT 271 5112 3133 49 SEAL 32 293
5112 3101 59 STARTER 9 359 5112 3133 74 HYDR. RESERVOIR 1 299
5112 3102 43 ANGLE POINTER 5 435 5112 3133 75 HYDR.OIL TANK 12 303
5112 3102 48 EXHAUST BEND 9 419 5112 3133 98 DRIVERS PLATF. 1 407
5112 3102 60 BY PASS VALVE 8 307 5112 3134 38 DRIVERS PLATF. 11 263
5112 3102 71 TRUNNION BLOCK 7 397 5112 3134 78 WIRING E103 343
5112 3102 71 TRUNNION BLOCK 2 375 5112 3134 78 WIRING E104 343
5112 3102 71 TRUNNION BLOCK 1 379 5112 3134 81 HEADLIGHT E104 343
5112 3102 77 GREASE NIPPLE 2 379 5112 3134 81 HEADLIGHT E103 343
5112 3102 78 GREASE NIPPLE 4 379 5112 3137 68 FUEL GAUGE P111 319
957
5112 3138 08 SWITCH S307 320 5112 3190 14 SIDE WHEEL 12 401
5112 3138 08 SWITCH S308 320 5112 3190 15 BOLT 6 297
5112 3139 02 FLASH LIGHT 1 751 5112 3190 15 BOLT 14 401
5112 3139 18 PLATE 9 695 5112 3190 16 COVER 19 297
5112 3139 18 PLATE 9 693 5112 3190 16 COVER 31 401
5112 3145 55 ATTACHMENT 55 256 5112 3190 17 DIFF.CASE 17 297
5112 3149 72 SET 9 375 5112 3190 17 DIFF.CASE 32 401
5112 3152 90 WASHER 4 407 5112 3190 18 DIFF.KIT 399
5112 3152 91 COVER 5 407 5112 3193 84 COVER PLATE 28 293
5112 3158 44 EMERG.SET 33 701 5112 3197 44 DIFF.KIT 289
5112 3162 07 ELECTRIC SET 6 655 5112 3202 37 GASKET 3 417
5112 3166 53 VOLTAGE CONVERT T102 753 5112 3202 38 CLAMP 2 417
5112 3170 82 PLATE 19 501 5112 3202 39 CATALYSER 4 417
5112 3171 40 TRIGGER 3 455 5112 3214 17 CONTACT 682 667
5112 3172 29 PLATE 1 755 5112 3214 43 FUSE F89 849
5112 3177 03 FUSE BOX A37 339 5112 3216 64 HYDR.TRANSMISS. 11 355
5112 3187 75 BOLT 7 293 5112 3217 13 WIRING W182 313
5112 3187 77 SPRING WASHER 7 297 5112 3217 29 SOLENOID 2 377
5112 3187 77 SPRING WASHER 20 293 5112 3217 46 CONTROL ATTM. 2 369
5112 3187 77 SPRING WASHER 5 401 5112 3217 49 ACCELERATOR 4 369
5112 3187 85 SHIM 24 293 5112 3217 56 RELIEF VALVE 281
5112 3187 87 O-RING 29 293 5112 3217 81 JUNCTION BOX X7 755
5112 3188 03 DIFFERENT.WHEEL 11 297 5112 3217 81 JUNCTION BOX X12 343
5112 3188 03 DIFFERENT.WHEEL 7 401 5112 3223 56 WHEEL COMPL. 1 421
5112 3188 04 SHAFT 15 297 5112 3226 16 FILTER 10 359
5112 3188 08 DIFF.SPIDER 14 297 5112 3226 17 V-BELT 7 359
5112 3188 08 DIFF.SPIDER 9 401 5112 3228 66 HOLDER 1 371
5112 3188 09 SHAFT 12 297 5112 3228 67 HOLDER 2 371
5112 3188 09 SHAFT 11 401 5112 3228 68 CABLE HOLDER 5 357
5112 3190 14 SIDE WHEEL 9 297 5112 3231 28 EXHAUST SYSTEM 15 263
958
5112 3231 31 INLET 5 417 5500 3057 00 SEAL WASHER 2 359
5112 3231 32 OUTLET 1 417 5500 5110 00 PIPE CONNECTION 66 461
5112 3231 33 INLET 2 419 5507 8719 00 WAGNER PART 16 483
5112 3231 35 EXHAUST HOSE 3 415 5507 8719 00 WAGNER PART 15 483
5112 3231 37 LOCK NUT 7 415 5507 8719 00 WAGNER PART 22 483
5112 3231 45 THROTTLE CONTR. 4 357 5507 8719 00 WAGNER PART 25 483
5112 3231 50 AIR INLET 2 365 5507 8719 00 WAGNER PART 4 581
5112 3231 60 AIR INLET 3 357 5507 8719 00 WAGNER PART 2 581
5112 3231 69 HOSE 3 373 5507 8719 00 WAGNER PART 9 483
5112 3231 71 DRAINAGE 6 357 5507 8719 00 WAGNER PART 10 483
5112 3231 73 SPACER SLEEVE 7 357 5507 8719 00 WAGNER PART 3 483
5112 3231 74 BACK HEAD 26 299 5507 8719 00 WAGNER PART 2 143
5112 3231 82 CAP 15 299 5507 8719 00 WAGNER PART 1 143
5112 3231 86 FUEL HOSE 3 385 5507 8719 00 WAGNER PART 5 143
5112 3231 87 FUEL HOSE 9 385 5507 8719 00 WAGNER PART 2 483
5112 3231 93 INLET PORT 5 361 5507 8719 00 WAGNER PART 1 483
5112 3231 94 LEVEL GLASS 23 285 5507 8719 00 WAGNER PART 11 483
5112 3231 95 AIR FILTER SET 2 357 5507 8719 00 WAGNER PART 4 143
5112 3231 96 INTAKE HOSE 4 361 5507 8719 00 WAGNER PART 30 483
5112 3232 48 RESTR. WASHER 6 417 5507 8719 00 WAGNER PART 5 581
5112 3232 52 CATALYSER 1 415 5507 8719 00 WAGNER PART 1 581
5112 3235 27 SET OF WHEELS 16 263 5530 8108 00 PLAIN WASHER 15 113
5112 3238 04 DIESEL ENGINE 1 357 5530 8966 00 SCREW, HEX HEAD 14 113
5112 3302 52 ASSEMBLY SET 2 421 5580 0041 28 FUEL FILTER 4 359
5118 0188 00 GASKET 12 285 5580 0110 80 WASHER 10 297
5118 0899 00 RELAY K101 313 5580 0110 80 WASHER 8 401
5118 0904 00 RUBBER PROTEC 11 339 7490 5164 74 SHANK ADAPTER 300 15
5118 0905 00 RUBBER PROTEC 17 339 7490 5164 75 SHANK ADAPTER 300 15
5118 0910 00 LINK ROD HEAD 6 369 7490 5165 59 SHANK ADAPTER 300 15
5118 1159 00 PLUG 15 285 8115 9018 06 COMPRESSOR 520 789
959
8202 0301 05 BALL VALVE 15 812 9090 1172 00 PRESSURE GAUGE 16 812
8202 0301 05 BALL VALVE 7 385 9090 1172 00 PRESSURE GAUGE 9 791
8202 0301 05 BALL VALVE 26 171 9090 1423 00 CONNECTION 12 793
8202 0302 04 BALL VALVE 6 791 9090 2052 00 MANOMETER 6 812
8202 0304 02 BALL VALVE 14 791 9093 0009 61 PRESS.REGULATOR 5 791
8202 0304 02 BALL VALVE 17 812 9106 0110 81 HOSE GUIDE 59 394
8202 0304 02 BALL VALVE 13 303 9106 0140 80 RESOLVER MODUL D120 767
8202 0311 78 BALL VALVE 11 812 9106 0630 10 DOUBLE CH.VALVE 4 625
8204 0942 16 THROTTLE VALVE 27 171 9106 0630 10 DOUBLE CH.VALVE 73 613
8231 0853 45 O-RING 4 307 9106 0630 10 DOUBLE CH.VALVE 12 136
8231 0853 46 O-RING 5 307 9106 0630 14 DIRECTION VALVE 24 265
8231 0854 19 BREATHER FILTER 11 303 9106 0631 23 CARTRIDGE 2 615
8231 0854 84 MANOMETER 9 303 9106 0631 23 CARTRIDGE 2 151
8231 0858 23 COVER COMPL. 7 307 9106 0631 24 SEAL KIT 1 615
8231 1018 04 FILTER INSERT 1 307 9106 0631 24 SEAL KIT 1 151
8231 1085 75 PRESS. SWITCH 16 671 9106 0649 55 PROTECTION CAP 5 751
8231 1086 09 PROTECTION HOOD 21 671 9106 0652 00 PRESS.REL.VALVE 54 137
8231 1203 07 OVERCENT.VALVE 22 229 9106 0652 01 PRESS.REL.VALVE 2 155
8234 0200 36 FILTER, COMPL. 10 303 9106 0652 03 SEAL KIT - 155
8915 0021 08 INSTRUCTION SIG 74 445 9106 0658 72 SUCT.CONNECTION L11 526
8915 0021 08 INSTRUCTION SIG 10 853 9106 0658 85 SUCT.CONNECTION L21 526
8915 0025 73 INFORMATION LAB 42 467 9106 0658 85 SUCT.CONNECTION L10 526
8915 0026 62 PLATE 75 445 9106 0713 01 POWER UNIT U180 729
8915 0026 62 PLATE 9 853 9106 0746 00 RUBBER CLOTH 5 593
9000 0241 00 HOSE NIPPLE 77 103 9106 0746 01 SLIDE 6 593
9030 0300 00 AIR HOSE 7 241 9106 0790 12 RUBBER CLOTH 16 171
9030 0300 00 AIR HOSE 7 890 9106 0796 62 HYDRAULIC PUMP 1 655
9030 0600 00 AIR HOSE 13 890 9106 0833 01 CHECK VALVE 2 655
9030 1100 00 AIR HOSE 2 890 9106 1015 40 TORQUE KEY 16
9030 1100 00 AIR HOSE 2 175 9106 1015 41 TORQUE KEY 16
960
9106 1065 25 ELECTRIC SET 823 473 9106 1080 09 CONE 19 657
9106 1071 01 READ INSTR.BOOK 31 445 9106 1080 10 SPRING 20 657
9106 1071 03 NO ADMITTANCE 33 445 9106 1080 11 SCREW 21 657
9106 1071 06 SIGN 35 445 9106 1080 12 REPAIR SET 657
9106 1071 07 SYMBOL PLATE 42 445 9106 1120 09 LATCH 4 733
9106 1071 09 SYMBOL PLATE 44 445 9106 1120 09 LATCH 4 735
9106 1071 11 WELDING INSTR. 41 445 9106 1120 13 ADAPTER 3 733
9106 1071 12 BATTERY SWITCH 40 445 9106 1120 13 ADAPTER 3 735
9106 1071 13 LABEL 38 445 9106 1120 50 HANDLE 5 735
9106 1071 14 PLC CABINET 46 445 9106 1120 50 HANDLE 5 733
9106 1071 15 FUEL 39 445 9106 1125 00 MAIN SWITCH Q 7 729
9106 1071 27 LUBRICATING OIL 67 445 9106 1125 10 CONTACT BREAKER 1 737
9106 1071 31 PLATE 71 445 9106 1125 11 OVERLOAD RELAY 2 737
9106 1071 32 PLATE 72 445 9106 1125 12 PROTECTION 3 737
9106 1071 94 DATA PLATE CE 1 445 9106 1125 13 CONTACT BLOCK Q7 503
9106 1071 95 DATA PLATE 1 445 9106 1125 13 CONTACT BLOCK 4 737
9106 1072 20 LASER RADIATION 25 445 9106 1125 15 COIL 5 737
9106 1072 21 LASER RADIATION 25 445 9106 1125 16 PALM GRIP 6 737
9106 1072 21 LASER RADIATION 265 249 9106 1157 02 CONTACTOR K132 728
9106 1072 33 LASER RADIATION 25 445 9106 1157 02 CONTACTOR K127 728
9106 1073 02 ELECTRIC. SHOCK 4 445 9106 1157 61 CONTACTOR K 61Y 728
9106 1073 02 ELECTRIC. SHOCK 3 445 9106 1157 62 CONTACTOR K 61 728
9106 1073 05 RISK OF CRUSH. 12 445 9106 1157 62 CONTACTOR K 61D 728
9106 1073 11 TIPPING HAZ. DR 8 445 9106 1160 10 ASSEMBLY SET 521 789
9106 1073 14 WARNING SIGN 15 445 9106 1165 00 HASP 14 489
9106 1073 21 TIPP. HAZ. DOWN 6 445 9106 1165 01 HASP 1 493
9106 1073 21 TIPP. HAZ. DOWN 7 435 9106 1165 02 ATTACHMENT 3 495
9106 1080 05 MOTOR 17 657 9106 1165 03 SHAFT 4 495
9106 1080 06 PUMP 18 657 9106 1165 04 ARM 2 495
9106 1080 07 REPAIR SET 657 9106 1165 05 ATTACHMENT 3 493
961
9106 1165 06 ATTACHMENT 2 493 9106 1427 05 SIGN 85 447
9106 1215 09 SHIM 2 843 9106 1434 46 HOSE SET 5 655
9106 1215 13 SPACER 1 843 9106 1438 80 SET 5 481
9106 1215 14 STOP LUG 5 843 9106 1447 65 SENSOR CABLE 5 779
9106 1215 15 SLEEVE 6 843 9106 1462 17 SEAL 65 818
9106 1264 09 CONNECTING PIPE 10 526 9106 1462 17 SEAL 65 825
9106 1272 34 LAMP PROTECTION 15 489 9106 1492 04 SEAL KIT - 555
9106 1272 34 LAMP PROTECTION 10 845 9106 1593 33 MAIN CABLE 1 779
9106 1286 31 ELECTR.CABINET 1 727 9106 1608 62 OIL COOLER 1 526
9106 1286 40 CABINET 1 731 9106 1609 60 HYDRAULIC SET M5 526
9106 1286 41 DOOR 6 731 9106 1610 20 COOLER SUPPORT 6 255
9106 1286 42 DOOR 5 731 9106 1616 00 HOUSING 47 701
9106 1286 44 TOUCH GUARD 5 727 9106 1616 02 HOUSING 48 676
9106 1286 44 TOUCH GUARD 2 731 9106 1616 03 COVER 49 676
9106 1286 47 SLIDE 3 731 9106 1616 06 HOUSING X5 679
9106 1286 55 DOOR 1 735 9106 1629 16 CAN-CABLE 10 781
9106 1286 63 MOUNTING PLATE 7 731 9106 1629 17 MAIN CABLE 2 779
9106 1286 64 MOUNTING PLATE 8 731 9106 1725 43 SENSOR CABLE 6 779
9106 1287 61 ELECTR.CABINET 1 725 9106 1752 00 FLANGE 62 741
9106 1312 00 SPARE PARTS SET 629 9106 1752 01 FLANGE 63 741
9106 1331 00 SEALING SET 177 9106 1752 07 FLANGE 4 741
9106 1331 01 REPAIR KIT 177 9106 1804 77 COVER PLUG 2 437
9106 1332 01 ATTACHMENT 2 845 9106 1828 34 TERMINATION 52 779
9106 1418 50 COVER 47 676 9106 1898 25 CAN-OPEN CABLE 4 779
9106 1418 50 COVER 49 701 9106 1902 51 CABLE 7 779
9106 1427 01 SIGN 83 447 9106 1914 10 ATTACHM.COMPLET 41 765
9106 1427 02 SIGN 86 447 9106 1923 87 PROTECTION 1 465
9106 1427 03 SIGN 87 447 9106 2021 80 ATTACHMENT 1 173
9106 1427 03 SIGN 84 447 9106 2066 78 TERMINATION 51 779
9106 1427 04 SIGN 88 447 9106 2192 04 INCLINOMETER 1 773
962
9106 2192 04 INCLINOMETER 1 777 9110 8352 00 WASHER 15 387
9106 2192 15 SENSOR 2 847 9110 8538 00 RUBBER CLOTH 36 255
9106 2192 16 LINEAR SENSOR 1 769 9110 8539 00 FLAT BAR 37 255
9106 2192 20 WIRE ASSY 43 771 9110 8551 00 SUPPORT LEG 230 249
9106 2192 21 POTENTIOMETER 48 771 9110 8772 00 HATCH 14 441
9106 2207 00 ADDRESS PLUG 50 779 9110 8818 01 STRINGER 13 387
9106 2219 72 SIGNAL CABLE 15 781 9110 8957 00 LOCK RING 13 793
9106 2257 20 ATTACHMENT 2 769 9110 8967 00 FOOT PLATE 5 437
9106 2257 25 SENSOR SET 20 765 9110 8969 05 CLUTCH CASE 1 517
9106 2257 26 PLATE 10 769 9110 8969 12 COUPLING SET 255 511
9106 2328 21 SHAFT 13 195 9110 9407 41 ATTACHMENT 12 255
9106 2328 60 BRACKET 9 195 9110 9484 01 COUPLING HALF 3 517
9106 2328 83 DRILL BIT BOX 1 449 9110 9554 00 SWING ARM 805 473
9106 2328 85 RUBBER CLOTH 5 449 9110 9554 10 SWING ARM 1 489
9106 2335 62 DISPLAY D501 767 9110 9555 00 LOCKING 2 489
9106 2369 04 PLATE 7 449 9110 9555 02 CATCH 2 491
9106 2472 30 PLATE 3 851 9110 9555 12 COMPRESS.SPRING 8 491
9106 2486 00 EL.OIL FILLER 315 511 9110 9557 00 LAMP HOLDER 1 845
9106 2486 01 ATTACHMENT 7 655 9110 9560 00 CABLE STEERING 806 473
9106 2486 05 CLEANING UNIT 910 789 9110 9591 12 ARM REST 5 705
9106 2486 06 HOLDER 4 851 9110 9748 75 HOSE HOLDER 2 237
9106 3207 43 MOTOR BRACKET 11 359 9110 9986 50 ATTACHMENT 12 353
9110 4758 00 LOCK SHEET 5 195 9111 0020 30 CABLE GEAR 3 687
9110 6731 00 ROLLER HOLDER 1 497 9111 0020 30 CABLE GEAR 2 683
9110 6736 00 INNER TUBE 1 441 9111 0020 30 CABLE GEAR W189 313
9110 6753 00 SHAFT 3 489 9111 0020 35 CABLE GEAR 3 681
9110 8060 04 WASHER 4 517 9111 0020 35 CABLE GEAR 2 699
9110 8324 00 NIPPLE 12 441 9111 1922 00 SHAFT 3 195
9110 8336 00 STEP 12 387 9111 2023 84 CONTROL DEVICE 2 671
9110 8351 00 WASHER 14 387 9111 2027 20 SENSOR FLAG 1 673
963
9111 2027 22 PLATE 2 673 9111 2699 24 PISTON 24 817
9111 2027 23 PLATE 5 673 9111 2699 25 SPACER 25 817
9111 2027 24 PLATE 4 673 9111 2699 26 NUT 26 817
9111 2027 25 SENSOR SET E1 671 9111 2699 29 COVER 29 817
9111 2030 01 CONTROL DEVICE 1 697 9111 2699 30 SCREW 30 817
9111 2190 04 PLATE 3 697 9111 2699 31 LOCK WASHER 31 817
9111 2502 00 SUPPORT 1 743 9111 2699 32 PISTON 32 817
9111 2699 00 WATER PUMP 1 812 9111 2699 33 SPRING 33 817
9111 2699 01 SEAL KIT 817 9111 2699 34 FITTING 34 817
9111 2699 02 SEAL KIT 817 9111 2699 35 SEAT 35 817
9111 2699 03 SEAL KIT 817 9111 2699 37 SLEEVE 37 818
9111 2699 04 PISTON 4 817 9111 2699 38 SLIDE 38 818
9111 2699 05 COVER 5 817 9111 2699 39 PIPE 39 818
9111 2699 06 SCREW 6 817 9111 2699 40 PIPE 40 818
9111 2699 07 HANDLE 7 817 9111 2699 41 PLUG 41 818
9111 2699 08 NUT 8 817 9111 2699 42 PLUG 42 818
9111 2699 09 LOCK WASHER 9 817 9111 3229 00 LIGHT SET 680 667
9111 2699 10 WASHER 10 817 9111 3231 07 SHAFT 2 195
9111 2699 11 CYLINDER 11 817 9111 3333 01 HYDR. SET M4 526
9111 2699 12 HOLDER 12 817 9111 3335 20 HYDRAULIC SET M3 526
9111 2699 13 SCREW 13 817 9111 3337 00 HYDR. SET M6 526
9111 2699 14 COVER 14 817 9111 3420 12 CABLE 3 671
9111 2699 15 NIPPLE 15 817 9111 3468 00 HYDR. SET M9 526
9111 2699 16 PLUG 16 817 9111 3469 00 HYDR. SET M10 526
9111 2699 17 ATTACHMENT 17 817 9111 3470 01 HYDR. SET B1 526
9111 2699 18 PISTON 18 817 9111 3471 01 HYDR. SET C1 526
9111 2699 19 PLUG 19 817 9111 3471 01 HYDR. SET 4 167
9111 2699 20 SPRING 20 817 9111 3472 06 PANEL 2 593
9111 2699 21 HOUSE 21 817 9111 3516 02 HYDRAULIC SET E1 526
9111 2699 23 SLEEVE 23 817 9111 3530 14 ATTACHMENT 1 241
964
9111 3530 15 CLAMP 2 241 9111 3707 22 HOUSING 11 675
9111 3592 31 AIR/WATERSYSTEM 500 789 9111 3707 30 COVER 45 701
9111 3600 03 HYDRAULIC SET F1 526 9111 3707 30 COVER 4 685
9111 3603 00 HYDRAULIC SET I1 526 9111 3707 32 COVER 12 675
9111 3610 10 SIGN SET 2 691 9111 3707 40 GASKET 46 701
9111 3610 82 ELECTRIC SET N4 671 9111 3707 40 GASKET 13 675
9111 3615 00 AIR SYSTEM 1 809 9111 3707 50 BUSHING 5 685
9111 3622 45 HOSE HOLDER 18 239 9111 3707 62 FLANGE 8 705
9111 3633 00 JUNCTION BOX 20 812 9111 3714 18 PROTECTION 18 255
9111 3647 10 ATTACHMENT 1 259 9111 3714 35 ATTACHMENT 3 595
9111 3671 01 JUNCTION BOX 713 9111 3714 62 HANDLE 43 255
9111 3671 10 JUNCTION BOX 1 711 9111 3714 63 HANDLE 44 255
9111 3671 80 JUNCTION BOX 7 671 9111 3714 68 PROTECTION 58 256
9111 3688 10 ELECTRIC SET 28 671 9111 3714 86 HOSE FENDER 52 256
9111 3703 08 CONTROL PANEL 1 701 9111 3728 05 PANEL 2 576
9111 3703 15 BOX 2 705 9111 3729 01 SLIDE 3 552
9111 3703 18 COVER 1 705 9111 3729 02 RUBBER CLOTH 4 552
9111 3703 20 YOKE 3 705 9111 3729 03 PANEL 2 552
9111 3703 25 COVER 4 705 9111 3730 10 SIGN SET 1 593
9111 3703 28 PLATE 50 701 9111 3731 00 HYDRAULIC UNIT M17 526
9111 3703 30 HINGE 6 705 9111 3733 03 E-BOX F3 671
9111 3703 35 GASKET 19 705 9111 3734 10 RELAY 2 675
9111 3703 48 PLATE 2 701 9111 3734 10 RELAY K128 728
9111 3703 50 POTENTIOMETER 18 701 9111 3734 11 RELAY 3 675
9111 3703 60 HOLDER 10 675 9111 3734 30 TRANSIENT PROT. K128 728
9111 3707 05 SIGNAL CABLE 2 689 9111 3734 31 TRANSIENT PROT. K 28 727
9111 3707 09 CABLE,50-CORE 1 685 9111 3734 31 TRANSIENT PROT. K 30 728
9111 3707 10 CABLE GEAR 2 685 9111 3734 31 TRANSIENT PROT. K132 728
9111 3707 12 CABLE GEAR 3 685 9111 3734 31 TRANSIENT PROT. K127 728
9111 3707 20 HOUSING 43 701 9111 3734 31 TRANSIENT PROT. K 64 728
965
9111 3734 32 TRANSIENT PROT. K 61 728 9111 3891 10 CABLE, 5-CORE W77 343
9111 3734 32 TRANSIENT PROT. K 61D 728 9111 3891 10 CABLE, 5-CORE W511 313
9111 3734 32 TRANSIENT PROT. K 61Y 728 9111 3891 10 CABLE, 5-CORE W52 311
9111 3748 00 PANEL HOLDER 106 249 9111 3891 10 CABLE, 5-CORE 2 721
9111 3748 10 SUPPORT 1 261 9111 3891 10 CABLE, 5-CORE 3 721
9111 3748 30 WHEEL COMPL. 3 261 9111 3891 10 CABLE, 5-CORE 5 499
9111 3748 60 ATTACHMENT 25 255 9111 3891 13 CABLE, 7-CORE W51 311
9111 3751 00 CHECK VALVE 14 812 9111 3891 13 CABLE, 7-CORE W51 313
9111 3752 00 BRACKET 107 249 9111 3891 13 CABLE, 7-CORE 4 499
9111 3758 04 CABLE L1 671 9111 3891 13 CABLE, 7-CORE 6 855
9111 3760 04 CONTROL BOX 1 183 9111 3891 15 CABLE,18-CORE 1 681
9111 3760 13 SIGN SET 3 183 9111 3891 15 CABLE,18-CORE 2 815
9111 3760 14 PLATE 1 189 9111 3891 19 CABLE,25-CORE 1 687
9111 3760 15 PLATE 2 189 9111 3891 44 CABLE, 2-CORE E102 343
9111 3760 21 GASKET 39 676 9111 3891 44 CABLE, 2-CORE W71 755
9111 3760 30 COVER 40 676 9111 3891 44 CABLE, 2-CORE W53 755
9111 3770 00 VALVE BLOCK 7 552 9111 3891 44 CABLE, 2-CORE 11 847
9111 3770 01 FLOW REGULATOR C2 555 9111 3891 44 CABLE, 2-CORE B143 313
9111 3770 01 FLOW REGULATOR C1 555 9111 3891 44 CABLE, 2-CORE E106 755
9111 3770 02 PRESS.REL.VALVE C4 555 9111 3891 44 CABLE, 2-CORE H215 311
9111 3770 02 PRESS.REL.VALVE C3 555 9111 3891 44 CABLE, 2-CORE H186 311
9111 3770 02 PRESS.REL.VALVE C5 555 9111 3891 44 CABLE, 2-CORE B359 311
9111 3770 03 CARTRIDGE VALVE C11 555 9111 3891 44 CABLE, 2-CORE B352 311
9111 3770 04 PRESS.REGULATOR C6 555 9111 3891 44 CABLE, 2-CORE B351 311
9111 3770 11 SEAL KIT - 555 9111 3891 44 CABLE, 2-CORE E101 343
9111 3891 06 CABLE, 3-CORE 3 751 9111 3891 44 CABLE, 2-CORE B350 311
9111 3891 06 CABLE, 3-CORE 4 251 9111 3891 44 CABLE, 2-CORE 3 353
9111 3891 07 CABLE, 3-CORE 13 743 9111 3891 44 CABLE, 2-CORE E105 755
9111 3891 07 CABLE, 3-CORE 12 743 9111 3891 59 CABLE, 2-CORE 8 661
9111 3891 09 CABLE,12-CORE 10 691 9111 3891 59 CABLE, 2-CORE 7 661
966
9111 3927 00 PISTON 44 818 9111 4225 12 FIRE SUPPR.SYST 900 249
9111 3928 00 POPPET VALVE 43 818 9120 0292 60 PRESS.REL.VALVE 3 573
9111 3928 01 PLUG 45 818 9120 0292 63 PRESS.REL.VALVE 6 565
9111 3928 02 SHIM 46 818 9120 0792 46 SOLENOID VALVE 4 567
9111 3929 00 RETAINER 47 818 9120 0920 01 PILOT VALVE 1 565
9111 3991 27 ATTACHMENT 42 765 9120 0920 02 PRESS.REL.VALVE 2 565
9111 4012 12 CABLE J5 671 9120 0920 04 FILTER SET 3 565
9111 4017 18 GREASING DEVICE 2 173 9120 0920 06 PLUG 1 573
9111 4017 20 FLAT IRON 3 175 9120 0920 06 PLUG 4 565
9111 4020 12 ATTACHMENT 1 209 9120 0920 15 SPRING SET 1 567
9111 4020 28 FEED HOLDER 1 227 9120 0920 16 COVER 2 567
9111 4020 29 FEED HOLDER 1 225 9120 0920 20 COVER 3 567
9111 4061 78 STRAINER 16 791 9120 0920 21 VALVE HOLDER 10 567
9111 4061 93 SPARE PARTS SET 799 9120 0920 31 PLUG 8 567
9111 4063 45 ATTACHMENT 7 691 9120 0920 34 PLUG 1 569
9111 4063 63 ATTACHM.COMPLET 2 161 9120 0920 35 ATTACHM. PLATE 2 569
9111 4063 64 STINGER 1 161 9120 0920 36 SEAL KIT - 569
9111 4064 07 STINGER 42 59 9120 0920 37 SEAL KIT - 567
9111 4064 07 STINGER 1 167 9120 0920 39 SEAL KIT - 567
9111 4064 60 PENDULUM 2 225 9120 0920 40 SEAL KIT - 567
9111 4064 62 POSITIONING 103 193 9120 0920 41 SPOOL 7 565
9111 4088 50 LINK ARM 7 102 9120 0920 41 SPOOL 5 573
9111 4095 50 BOX 28 171 9120 0924 74 PLUG 7 567
9111 4115 75 HOSE GUIDE 30 239 9120 0990 08 SEAL KIT 403
9111 4115 78 HOSE GUIDE 31 239 9120 0990 09 SEALING SET 443
9111 4169 71 PLASTIC SHEET 1 521 9120 0990 10 SEAL KIT - 231
9111 4192 41 ATTACHMENT 11 171 9120 0990 14 SEALING SET 277
9111 4192 42 COMPON. LAYOUT A 171 9120 0990 20 SEAL KIT - 231
9111 4213 00 HYDR. SYSTEM 300 511 9120 0990 20 SEAL KIT 439
9111 4213 01 HYDRAULIC UNIT M18 526 9120 0990 20 SEAL KIT 403
967
9120 0990 20 SEAL KIT 197 9124 9568 00 PISTON 10 277
9120 0993 05 SEAL KIT 121 9125 6191 00 O-RING 35
9120 0993 05 SEAL KIT 123 9125 6191 00 O-RING 20 39
9120 0993 05 SEAL KIT 125 9125 6191 00 O-RING 12 23
9120 0993 09 SEAL KIT 117 9125 6739 00 PISTON ROD SEAL 15 205
9120 0993 13 SEAL KIT 229 9125 6739 00 PISTON ROD SEAL 15 79
9121 5500 08 CONNECT.ADAPTER 77 613 9125 6889 00 O-RING 8 565
9121 5913 01 HYDR. CYLINDER 1 437 9125 6889 00 O-RING 4 573
9121 5913 50 SEAL KIT 439 9125 6896 00 SET SCREW 26 79
9121 6526 50 SEAL KIT 205 9125 9551 00 ELECTR.PLUG 5 567
9121 6526 50 SEAL KIT 79 9126 1580 00 HYDR. CYLINDER 5 441
9121 7221 01 HYDR. CYLINDER 5 61 9126 1581 00 PISTON ROD 5 443
9122 3653 00 COVER 18 79 9126 1783 00 INNER TUBE 27 79
9122 3838 00 COVER 24 69 9126 1956 00 COVER 27 69
9122 3892 00 MANTLE 1 205 9126 1959 00 PISTON 33 69
9122 3893 00 END COVER 18 205 9126 1960 00 GUIDE SLEEVE 30 69
9122 4332 50 COVER COMPL. 205 9126 2010 01 PISTON ROD 15 439
9122 4332 50 COVER COMPL. 12 79 9126 2011 00 COVER 17 439
9122 4811 00 PISTON ROD 2 229 9126 2012 00 PISTON 16 439
9122 4880 00 COVER 9 229 9126 2094 01 PISTON ROD 24 205
9123 3553 00 CYLINDER COVER 4 403 9126 2714 00 PIPE 23 79
9123 3554 00 COVER 2 443 9126 2770 50 COVER COMPL. 205
9123 6507 09 COVER 3 231 9126 2770 50 COVER COMPL. 4 79
9123 6507 13 CYLINDER COVER 12 197 9126 2771 01 PISTON ROD 28 79
9123 6507 13 CYLINDER COVER 4 277 9126 3943 00 COVER 8 125
9123 6624 00 PISTON ROD 3 277 9126 3943 00 COVER 8 121
9124 9565 00 PISTON 6 443 9126 3948 00 PISTON 1 123
9124 9565 00 PISTON 3 403 9126 3948 00 PISTON 2 121
9124 9566 00 PISTON 2 231 9126 3948 00 PISTON 2 125
9124 9568 00 PISTON 6 197 9126 3959 00 COVER 13 117
968
9127 2154 00 SPRING 1 589 9852 1797 01 INSTRUCTIONS 53
9127 2274 00 WASHER 10 121 9853 1170 01 REPAIR.INSTR 34 44
9127 2274 00 WASHER 10 125 9853 6684 20 SPARE PART.LIST 33 44
9127 2523 00 PLAIN BEARING 21 205 9853 6685 20 SPARE PART.LIST 32 43
9127 2523 00 PLAIN BEARING 29 80 9900 0003 00 PLASTIC BAG 35
9127 3366 00 PLUG 23 229
9128 5034 00 PLUG 3 197
9128 6173 00 BUSHING 1 197
9128 6998 00 SLIDE 16 197
9128 6998 00 SLIDE 18 403
9128 7076 00 PISTON 9 439
9128 7343 00 BUSHING 12 231
9128 8383 00 MARKING PLATE 15 117
9128 8434 00 SHOCK SCREW 6 567
9138 5000 84 WIRE MARKER 90 702
9138 5000 84 WIRE MARKER 64 676
9138 5000 85 WIRE MARKER 66 676
9138 5000 86 WIRE MARKER 67 676
9138 5000 88 WIRE MARKER 68 676
9138 5000 89 WIRE MARKER 69 677
9138 5001 41 WIRE MARKER 65 676
9138 5001 41 WIRE MARKER 91 702
9139 6001 00 PLUG CONNECTOR 1 689
9139 6002 38 END SOCKET 106 702
9139 6004 56 FLAT PIN SLEEVE 3 313
9236 2002 69 SHIM 40 61
9721 0800 00 FUEL 32 263
9850 5005 00 LABEL 89 447
9850 5009 00 LABEL 80 447
9851 2518 01 DESCRIPTION 53
969

Atlas Copco: Simba H1354 Spare Parts Catalogue

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Atlas Copco: Simba H1354 Spare Parts Catalogue

Uploaded by

Copyright:

Available Formats

Atlas Copco

© Copyright 2012, Atlas Copco Rock Drills AB, Sweden

Atlas Copco Rock Drills AB

1. ROCK DRILL / BERGBORRMASKIN .................................................... 5

2. FEED / MATARE ................................................................................... 55

3. POS. EQUIPMENT / POS.UTRUSTNING .......................................... 191

4. CARRIER / UNDERREDE .................................................................. 243

5. CABLE REEL / KABELVINDA ........................................................... 471

6. HYDR. SYSTEM / HYDRAULSYSTEM .............................................. 505

7. ELECTR. SYSTEM / ELSYSTEM ....................................................... 663

8. ANGLE IND.COMPL / RIKTINSTR.KOMPL ....................................... 763

9. AIR/WATERSYSTEM / LUFT/VATTENSYST ..................................... 785

10. HOSE CONNECTION / SLANGANSLUTNING ................................. 859

11. HOSES / SLANGAR ........................................................................... 879

12.CROSS REFERENCE LIST .................................................................. 891

8311 1249 90 010D

8311 1249 90 010D

8311 1249 90 010D

8311 1249 90 010D

8311 1249 90 010D

Ref Part no Qty Description Benämning See page Remarks

3115 3451 81 001K

Ref Part no Qty Description Benämning See page Remarks

3115 3511 81 001K

Ref Part no Qty Description Benämning See page Remarks

3115 2615 91 006D

Ref Part no Qty Description Benämning See page Remarks

3115 3473 81 002K

Ref Part no Qty Description Benämning See page Remarks

3115 3473 83 003K

Ref Part no Qty Description Benämning See page Remarks

3115 3473 85 003K

Ref Part no Qty Description Benämning See page Remarks

3115 0315 59 003K

Ref Part no Qty Description Benämning See page Remarks

3115 2420 60 001D

Ref Part no Qty Description Benämning See page Remarks

3115 9153 90 018K

Ref Part no Qty Description Benämning See page Remarks

3115 2887 80 003K

Ref Part no Qty Description Benämning See page Remarks

3115 9156 93 001K

Ref Part no Qty Description Benämning See page Remarks

3115 9156 94 005K

3115 9156 95 003K

3115 9156 95 003K

Ref Part no Qty Description Benämning See page Remarks

3115 9156 96 002K

Ref Part no Qty Description Benämning See page Remarks

3115 9156 98 002K

Ref Part no Qty Description Benämning See page Remarks

3115 9156 97 001K

Ref Part no Qty Description Benämning See page Remarks

3115 3425 80 007K

Ref Part no Qty Description Benämning See page Remarks

1260 5001 33 001K

Ref Part no Qty Description Benämning See page Remarks

3128 0017 10 010K

Ref Part no Qty Description Benämning See page Remarks

3128 3097 89 017K

3128 3232 36 001K

Ref Part no Qty Description Benämning See page Remarks

3128 3232 36 001K
