IBM MQ With Weblogic Using SSL Connectivity

IB M M Q wi t h
W EBLOGIC u si n g S SL
c o n n e c tivity
R22
IB M M Q w i t h W EBLOGI C u s i n g S SL c o n n e c tivi ty
Amendement History:
Revisio
Date Amended Name Description
n
1 20th October 2019 M. Siranjeevi Content Prepared
2 20th October 2019 Ram Content Reviewed
3 24th March 2020 Immanuel KJ R20 AMR Review
4 12th April 2021 Halith MY R21 AMR Review
5 25th March 2022 Dhanya J R22 AMR Review
Page 2
Copyri g h t
Copyright © Temenos Headquarters SA 2009-2022.
All rights reserved.
This document contains proprietary information that is protected by copyright. No part of this document may
be reproduced, transmitted, or made available directly or indirectly to a third party without the express
written agreement of TEMENOS UK Limited. Receipt of this material directly TEMENOS UK Limited
constitutes its express permission to copy. Permission to use or copy this document expressly excludes
modifying it for any purpose, or using it to create a derivative therefrom.
Errat a and Com m e n t s

If you have any comments regarding this manual or wish to report any errors in the
documentation, please document them and send them to the address below:
Technology Department
Temenos Headquarters SA
2 Rue de l’Ecole-de-Chimie,
CH - 1205 Geneva,
Switzerland
Tel SB: +41 (0) 22 708 1150

Fax: +41 (0) 22 708 1160
Please include your name, company, address, and telephone and fax numbers, and email
address if applicable. TAFJdev@temenos.com
Page 3
Table of Contents
Copyright................................................................................................................................................ 3
Errata and Comments............................................................................................................................ 3
Creation of queues manager and queue................................................................................................5
Queue creation.................................................................................................................... 8
Binding the Queues.............................................................................................................................. 10
Creating Keystore and Truststore......................................................................................................... 12
Setup at Websphere MQ level.............................................................................................................. 14
Setup at Weblogic level........................................................................................................................ 17
Creating a Foreign JMS server............................................................................................................. 19
Creating Connection Factory................................................................................................................ 27
Limitations with IBM MQ:...................................................................................................................... 30
Page 4
Creat i o n of qu e u e s ma n a g e r and qu e u e
Queu e man a g e r crea tio n
Start Websphere MQ manager and you will see the home page as given below,
Queue Managers > New > Queue Manager
Name the queue manager as "T24MQ" and then click "Next"
Page 5
Click "Next"
"Select type of queue manager startup" as Automatic
Make sure the option "Create listener configured for TCP / IP" is selected and define the
PORT Number as 1414 (If it’s already used you can define another one) and "Next"
Page 6
Click "Next"
Page 7
Queue manager T24MQ created as below
Check the listener is created and running
Que u e cre a t i o n
Creating of MQClearingQueue
Page 8
Click "Finish"
Likewise, we have create MQClearingReplyQueue, T24.BROWSER.QUEUE and

T24.BROWSER.REPLY.QUEUE only.
Page 9
Once done it like below
Bin d i n g the Que u e s

Creati n g JNDI Cont ext and Conn e c tio n factorie s:
Create a simple file-based JNDI context and configure the JMS objects in that JNDI
namespace. These JNDI objects are used by applications running in WebLogic Application
Server to connect to the WebSphere MQ queue manager. For this integration, WebLogic and
WebSphere MQ should be on the same machine.
The setting is for file-based JNDI. Create the directory

C:\LocalArea\Dev\TAFJ\appserver\MQ\MQ-JNDI before continuing with the next step.
U
nder new folder C:\LocalArea\Dev\TAFJ\appserver\MQ\MQ-JNDI create a file
MyAdmin.Config with the following contents:
INITIAL_CONTEXT_FACTORY=com.sun.jndi.fscontext.RefFSContextFactory
PROVIDER_URL=file://C:/LocalArea/Dev/TAFJ/appserver/MQ/MQ-JNDI
SECURITY_AUTHENTICATION=none
Open a command prompt as Administrator and set the following CLASSPATH as shown
below
Page 10
C:\LocalArea\Dev\TAFJ\appserver\MQ\MQ-JNDI>set
MQ_JAVA_INSTALL_PATH="C:\Program Files\IBM\MQ\java"
C:\LocalArea\Dev\TAFJ\appserver\MQ\MQ-JNDI>set classpath=
%MQ_JAVA_INSTALL_PATH%\*;%classpath%
C:\LocalArea\Dev\TAFJ\appserver\MQ\MQ-JNDI>set path=%MQ_JAVA_INSTALL_PATH%;
%path%
Next open a command prompt, cd to C:\JNDI-Directory, create the QueueConnectionFactory

and Queue objects by executing the command:
C:\LocalArea\Dev\TAFJ\appserver\MQ\MQ-JNDI>"C:\Program
Files\IBM\MQ\java\bin\JMSAdmin.bat" -cfg MyAdmin.config
def xaqcf(MQConnectionFactory) qmgr(T24MQ)

def q(MQClearingQueue) qmgr(T24MQ) queue(MQClearingQueue)
def q(MQClearingReplyQueue) qmgr(T24MQ) queue(MQClearingReplyQueue)
def q(t24BROWSERQueue) qmgr(T24MQ) queue(T24.BROWSER.QUEUE)
def q(t24BROWSERReplyQueue) qmgr(T24MQ) queue(T24.BROWSER.REPLY.QUEUE)
end
We should see a message like “Stopping Websphere MQ classes for Java(tm) Message
Service Administration” after we press Enter after the last line “end”.
After Successful, binding of Queues a file with the name .bindings will be created at
C:\LocalArea\Dev\TAFJ\appserver\MQ\MQ-JNDI.
Page 11
Creat i n g Keys t o r e and Trus t s t o r e

Truststore and Keystore file is used to provide secured transaction between the client and
server. The keytool command used to create the keystore file, which contains the
public/private keys, and then using keystore, create a truststore file that contains only public
keys. Follow the below steps to create Truststore and Keystore file,
 Generate a keystore file

 Verify the newly created keystore file
 Export the certificate
 Import the certificate in to the truststore file
 Verify the newly created trust store file
Step 1 - Gene r a t e a keystor e file

Java Keytool stores the keys and certificates in the keystore file. If you are a "Windows" user,
the keytool command should be executed in the Java bin directory. The following command
should be executed from bin path and in this case, java is present in the path
'C:\LocalArea\Dev\java\jdk1.8.0_121'
keytool -genkey -keyalg RSA -validity 1925 -alias ibmwebspheremqMQT24 -keypass

temenos -storepass temenos -dname "cn=TAFJ, ou=TEMENOS, o=TEMENOS, c=INDIA"
-keystore temntafj.jks
Next we should verify the newly created key store file.
Step 2 – Verifiy the newly crea t e d keysto r e file

Use the following command,
Page 12
keytool -list -v -keystore <name>.jks
After executing the above command, you will get the details as specified in the image below.
Make sure to input the password 'temenos' which we given for creating the keystore.
Step 3 – Expor t the cer tifica t e

Either a self signed certificate or a commercial certificate or other certificate authority should
be exported. For exporting verisign certificates, execute the following command,
keytool -export -alias ibmwebspheremqMQT24 -file ingadapter.cer -storepass temenos

-keystore temntafj.jks
After executing the above command, you will be asked for the password, Give the same
password "temenos" and you will get the details as specified in the image below,
Step 4 – Impor t the cer tifica t e in to the trus t s t o r e file

Import the certificate by executing the below command,
keytool -import -noprompt -alias ibmwebspheremqMQT24 -file ingadapter.cer -storepass

temenos -keystore temntafjtrust.jks
After executing the preceding command, you will get the details as specified in the image
below
Page 13
Step 5 – Verify the newly cre a t e d trus t stor e file:

Verify the newly created trust store file by executing the following command,
keytool -list -v -keystore <name>.jks
After executing the preceding command, you will get the details as specified in the image
below,
Se t u p at Web s p h e r e MQ leve l
Right click IBM MQManage SSL certificates
Page 14
Enter the password 'temenos', which we used to create keystore and check 'stash password
to a file’
Page 15
From personal Certificates, import the keystore (temntafj.jks) from the path where we have
generated
Page 16
Now click View/Edit button and check the check box 'set the certificate as default'.
Se t u p at Webl o g i c lev el
Weblogic star t u p script s at setDo m ai n E n v.c m d
set JAVA_PROPERTIES=-Dwls.home=%WLS_HOME% -Dweblogic.home=%WLS_HOME%
- Djavax.net.ssl.keyStore=C:\keystore\temntafj.jks
-Djavax.net.ssl.keyStorePassword=temenos
-Djavax.net.ssl.trustStore=C:\keystore\temntafjtrust.jks
-Djavax.net.ssl.trustStorePassword=temenos
-Doracle.net.ssl_cipher_suites=TLS_RSA_WITH_AES_128_CBC_SHA
-Dcom.ibm.mq.cfg.useIBMCipherMappings=false -Dcom.ibm.mq.cfg.preferTLS=true
set
DOM_HOME=C:\\Oracle\\Middleware\\Oracle_Home\\user_projects\\domains\\base_domain\
\lib
set CLASSPATH=%DOM_HOME%\\com.ibm.mq.jar;%DOM_HOME%\\com.ibm.mqjms.jar;
%DOM_HOME%\\com.ibm.mq.commonservices.jar;%DOM_HOME%\\com.ibm.mqetclient;
%DOM_HOME%\\fscontext.jar;%DOM_HOME%\\dhbcore.jar;%DOM_HOME
%\\com.ibm.mq.headers.jar;%DOM_HOME%\\com.ibm.mq.jmqi.jar;%CLASSPATH%
Copy the jars file from the MQ lib to the created domain server(<<Oracle_home>>
user_projects\domains\base_domain\lib) lib.
Page 17
Map the generated generated keystore and trust keystore files in the Keystore tab.
From the left pane in the weblogic home EnvironmentserversAdminserver
Enter the Private Key Alias and respective credentials of the keystore.
From the left pane in the weblogic home EnvironmentserversAdminserver
Page 18
Tick the SSL Listen Port Enabled
Indicates whether the server can be reached through the default SSL listen port
Then restart the ssl to take effect

From the left pane in the weblogic home Environmentservers  go to the control tab
Then select the adminserver and select the Restart SSL
Creat i n g a Forei g n JMS serv e r

Create a JMS Module using SystemModule-MQ Services>Messaging>JMS Modules>New
Page 19
Click Next
Click finish
Page 20
Click on SystemModule-MQ and then click New
Page 21
Select “Foreign Server” radio button and click “Next” Foreign Server
Page 22
In this page we can see that the target server is selected already. Click Finish.
Open the newly created Foreign JMS server by clicking Services -> Messaging -> JMS
Modules -> SystemModule-T24 -> ForeignServer-MQ
Under the General tab under Configuration, type in following details:
Page 23
JNDI Initial Context Factory: com.sun.jndi.fscontext.RefFSContextFactory
JNDI Connection URL: (This path must contain the .bindings file generated on the MQ
server) file://C:/LocalArea/Dev/TAFJ/appserver/MQ/MQ-JNDI
Page 24
Creating Destinations
Click on “Destinations tab” at the top and click “New”
Name: OFSClearingQueue
Local JNDI Name: jms/t24OFSClearingQueue
Remote JNDI Name: MQClearingQue
Note that the Remote JNDI Name must match the name of the queue we created in
WebSphere MQ and click "OK".
Page 25
Repeat the same steps for Reply queue with the following naming
Name: OFSClearingReplyQueue
Local JNDI Name: jms/t24OFSClearingReplyQueue
Remote JNDI Name: MQClearingReplyQueue
Likewise, we have create another two queues.
Page 26
Creat i n g Con n e c t i o n Fact o ry

After creating Destinations, create a Connection Factory for above queues. Click on (next
tab to Destinations) and Connection Factories
click "New"
Give the naming as shown below
Name: ConnectionFactory
Local JNDI Name: jms/ConnectionFactoryMQ
Remote JNDI Name: MQConnectionFactory
Configuring ejb-jar.xml and weblogic-ejb-jar.xml in TAFJEEE.ear
Page 27
Take the TAFJJEE_MDB.jar present in the TAFJJEE_EAR.ear. Under the

TAFJJEE_MDB.jar we need to edit the ejb-jar.xml and weblogic-ejb-jar.xml as per the queue
creation done in the foreign JMS server
Add the below section in ejb-jar.xml below the OFSTransactedMDB section
<message-driven>
<display-name>Transacted Listener MDB for OFS</display-name>
<ejb-name>MQTransactedMDB</ejb-name>
<ejb-class>com.temenos.tafj.mdb.TransactedMDB</ejb-class>
<messaging-type>javax.jms.MessageListener</messaging-type>
<transaction-type>Container</transaction-type>
<message-destination-type>javax.jms.Queue</message-destination-type>
<ejb-local-ref>
<ejb-ref-name>ejb/OFSProcessingBeanLocal</ejb-ref-name>
<ejb-ref-type>Session</ejb-ref-type>
<local>com.temenos.tafj.sb.OFSProcessingBeanLocal</local>
<ejb-link>OFSProcessingBean</ejb-link>
</ejb-local-ref>
<resource-ref>
<description>Used to get connections to JMS for OFS queues</description>
<res-ref-name>jms/TAFJQueueConnectionFactory</res-ref-name>
<res-type>javax.jms.ConnectionFactory</res-type>
<res-auth>Container</res-auth>
</resource-ref>
<message-destination-ref>
<description>OFS queue</description>
<message-destination-ref-name>jms/ReplyQueue</message-destination-ref-name>
<message-destination-type>javax.jms.Queue</message-destination-type>
<message-destination-usage>Produces</message-destination-usage>
<message-destination-link>jms/OFSClearingReplyQueue</message-destination-link>
</message-destination-ref>
</message-driven>
Add the below section in weblogic-ejb-jar.xml below the OFSTransactedMDB section
<wls:weblogic-enterprise-bean>
<wls:ejb-name>MQTransactedMDB</wls:ejb-name>
<wls:message-driven-descriptor>
<wls:pool>
<wls:max-beans-in-free-pool>20</wls:max-beans-in-free-pool>
<wls:initial-beans-in-free-pool>4</wls:initial-beans-in-free-pool>
</wls:pool>
<wls:destination-jndi-name>jms/t24OFSClearingQueue</wls:destination-jndi-name>
<wls:connection-factory-jndi-name>jms/ConnectionFactoryMQ</wls:connection-factory-
jndi-name>
</wls:message-driven-descriptor>
Page 28
<wls:resource-description>
<wls:res-ref-name>jms/TAFJQueueConnectionFactory</wls:res-ref-name>
<wls:jndi-name>jms/ConnectionFactoryMQ</wls:jndi-name>
</wls:resource-description>

<wls:dispatch-policy>OFSWorkManager</wls:dispatch-policy>
</wls:weblogic-enterprise-bean>
Also add the below in message-destination-descriptor section
<wls:message-destination-descriptor>
<wls:message-destination-name> </wls:message-destination-name>
jms/OFSClearingReplyQueue
<wls:destination-jndi-name> </wls:destination-jndi-name>
jms/t24OFSClearingReplyQueue
</wls:message-destination-descriptor>
After the above changes, redeploy TAFJEEE.ear file in Weblogic.
After login into T24.
Page 29
Limit a t i o n s with IBM MQ:

When MQ recovers from an unexpected shutdown, only in case of Enterprise Application
servers like Websphere and JBoss, MQ is unable to perform an automatic reconnection.
https://www.ibm.com/docs/en/ibm-mq/8.0?topic=application-automatic-jms-client-
reconnection
reconnection
reconnection
reconnection
Page 30

IBM MQ With Weblogic Using SSL Connectivity

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

IBM MQ With Weblogic Using SSL Connectivity

Uploaded by

Copyright:

Available Formats

IB M M Q wi t h

Errat a and Com m e n t s

Tel SB: +41 (0) 22 708 1150

Queue Managers > New > Queue Manager

Name the queue manager as "T24MQ" and then click "Next"

"Select type of queue manager startup" as Automatic

Queue manager T24MQ created as below

Check the listener is created and running

Likewise, we have create MQClearingReplyQueue, T24.BROWSER.QUEUE and

Once done it like below

Bin d i n g the Que u e s

The setting is for file-based JNDI. Create the directory

Next open a command prompt, cd to C:\JNDI-Directory, create the QueueConnectionFactory

def xaqcf(MQConnectionFactory) qmgr(T24MQ)

Creat i n g Keys t o r e and Trus t s t o r e

 Generate a keystore file

Step 1 - Gene r a t e a keystor e file

keytool -genkey -keyalg RSA -validity 1925 -alias ibmwebspheremqMQT24 -keypass

Next we should verify the newly created key store file.

Step 2 – Verifiy the newly crea t e d keysto r e file

keytool -list -v -keystore <name>.jks

Step 3 – Expor t the cer tifica t e

keytool -export -alias ibmwebspheremqMQT24 -file ingadapter.cer -storepass temenos

Step 4 – Impor t the cer tifica t e in to the trus t s t o r e file

keytool -import -noprompt -alias ibmwebspheremqMQT24 -file ingadapter.cer -storepass

Step 5 – Verify the newly cre a t e d trus t stor e file:

keytool -list -v -keystore <name>.jks

Tick the SSL Listen Port Enabled

Then restart the ssl to take effect

Creat i n g a Forei g n JMS serv e r

Click on SystemModule-MQ and then click New

Under the General tab under Configuration, type in following details:

JNDI Initial Context Factory: com.sun.jndi.fscontext.RefFSContextFactory

Click on “Destinations tab” at the top and click “New”

Local JNDI Name: jms/t24OFSClearingQueue

Remote JNDI Name: MQClearingQue

Likewise, we have create another two queues.

Creat i n g Con n e c t i o n Fact o ry

Give the naming as shown below

Local JNDI Name: jms/ConnectionFactoryMQ

Remote JNDI Name: MQConnectionFactory

Configuring ejb-jar.xml and weblogic-ejb-jar.xml in TAFJEEE.ear

Take the TAFJJEE_MDB.jar present in the TAFJJEE_EAR.ear. Under the

Add the below section in ejb-jar.xml below the OFSTransactedMDB section

Add the below section in weblogic-ejb-jar.xml below the OFSTransactedMDB section

Also add the below in message-destination-descriptor section

After the above changes, redeploy TAFJEEE.ear file in Weblogic.

After login into T24.

Limit a t i o n s with IBM MQ:

You might also like
