ELECTRIC FIRE PUMP MOTOR

FIRE PUMP
MOTORS

BUILT TO SERVE

Open Drip Proof

FIRE PUMP MOTORS
National Motors' NMCM series consists of motors designed
for fire pump applications as specified in NFPA 20
(Standard for the Installation of Stationary Pumps for Fire
Protection). They are certified by UL as per the requirement
of UL 1004-5 'Standard for Fire Pump Motors'. These
three phase horizontal low-voltage squirrel-cage medium
induction motors are constructed and manufactured as
per the requirements of NEMA MG 1 standard Design B.
With Open Drip Proof enclosures, they provide best
possible ventilation suitable for environments having
minimal airborne contaminants and better cooling that
contribute to the most e cient performance available from
these motors. These certified motors are fully complaint
with the motor e ciency requirements as given in the
EISA (Energy Independence and Security Act of 2007 - US
federal act).

Features:
15 to 350 horse power rating
400 – 415 voltage rating at 50 hertz
NEMA Energy e cient design
1.15 Service Factor
Class F insulation
50 °C Ambient Temperature rating*
Regreasable Ball Bearing
Cast Iron construction frame
Frame size from 254T to 449TS
UL File No. EX26863
Stainless Steel name plate
RAL 3000 Standard red painted
IP23 Degree of Protection
Altitude rating of 1000 meters above sea level*
F1 foot mounting
2 Pole, 2920 - 2945 rpm speed**
Temperature Rise below Class B (80 K)
Suitable for various standard starters such as across the line, wye-delta, soft starter etc.

Note:
* Derating may be required for higher values.
** Rated speed of the motor varies depending on motor size and it is mentioned on the next page.
PERFORMANCE DATA
Rated Output Frequency Rated Voltage Full Load Service Number of Speed
Model No. Frame Size
(hp) (Hz) (v) Current (A) Factor Poles (rpm)
NMCM50152PO 15 254T 50 400-415 19.7 1.15 2 2920
NMCM50202PO 20 256T 50 400-415 25.9 1.15 2 2920
NMCM50252PO 25 284TS 50 400-415 31.9 1.15 2 2930
NMCM50302PO 30 286TS 50 400-415 38.8 1.15 2 2930
NMCM50402PO 40 286TS 50 400-415 50.5 1.15 2 2925
40 324TS 50 400-415 50.6 1.15 2 2930
NMCM50502PO 50 324TS 50 400-415 61.3 1.15 2 2930
50 326TS 50 400-415 63 1.15 2 2930
NMCM50602PO 60 364TS 50 400-415 75.4 1.15 2 2930
60 326TS 50 400-415 75.8 1.15 2 2935
NMCM50752PO 75 364TS 50 400-415 92.2 1.15 2 2940
75 365TS 50 400-415 93.6 1.15 2 2940
NMCM501002PO 100 365TS 50 400-415 119.8 1.15 2 2940
100 405TS 50 400-415 124.5 1.15 2 2940
NMCM501252PO 125 404TS 50 400-415 143.5 1.15 2 2940
125 444TS 50 400-415 155.3 1.15 2 2940
NMCM501502PO 150 405TS 50 400-415 178.6 1.15 2 2940
150 445TS 50 400-415 182.9 1.15 2 2940
NMCM502002PO 200 447TS 50 400-415 243 1.15 2 2940
200 444TS 50 400-415 258.2 1.15 2 2945
NMCM502502PO 250 449TS 50 400-415 302 1.15 2 2940
NMCM503002PO 300 447TS 50 400-415 355 1.15 2 2945
300 449TS 50 400-415 355 1.15 2 2945
NMCM503502PO 350 447TS 50 400-415 451.5 1.15 2 2945
350 449TS 50 400-415 451.5 1.15 2 2945

Locked Rotor Insulation Rated Ambient Power Temperature

Model No. Phases Duty Enclosure
Current (A) Class Temperature (°C) Factor Rise (K)
NMCM50152PO 141 3 F 50 Continuous 0.91 55 ODP
NMCM50202PO 177 3 F 50 Continuous 0.91 78 ODP
NMCM50252PO 222 3 F 50 Continuous 0.91 70 ODP
NMCM50302PO 264 3 F 50 Continuous 0.91 70 ODP
NMCM50402PO 354 3 F 50 Continuous 0.91 70 ODP
354 3 F 50 Continuous 0.91 65 ODP
NMCM50502PO 441 3 F 50 Continuous 0.91 76 ODP
441 3 F 50 Continuous 0.91 75 ODP
NMCM50602PO 529 3 F 50 Continuous 0.91 63 ODP
529 3 F 50 Continuous 0.91 75 ODP
NMCM50752PO 661 3 F 50 Continuous 0.92 78 ODP
661 3 F 50 Continuous 0.92 75 ODP
NMCM501002PO 883 3 F 50 Continuous 0.92 80 ODP
883 3 F 50 Continuous 0.92 78 ODP
NMCM501252PO 1105 3 F 50 Continuous 0.92 80 ODP
1105 3 F 50 Continuous 0.92 78 ODP
NMCM501502PO 1319 3 F 50 Continuous 0.93 80 ODP
1319 3 F 50 Continuous 0.93 80 ODP
NMCM502002PO 1764 3 F 50 Continuous 0.93 80 ODP
1764 3 F 50 Continuous 0.93 80 ODP
NMCM502502PO 2320 3 F 50 Continuous 0.93 80 ODP
NMCM503002PO 2770 3 F 50 Continuous 0.93 80 ODP
2770 3 F 50 Continuous 0.93 80 ODP
NMCM503502PO 3243 3 F 50 Continuous 0.93 80 ODP
3243 3 F 50 Continuous 0.93 80 ODP
DESIGNED AS PER NEMA MG 1

TESTED AS PER UL 1004-5

INSTALLED AS PER NFPA 20

CAT. NO. NF/NAT-UL/01/15

NAFFCO
E-mail: info@naffco.com
www.naffco.com | www.national-motors.com

In line with NAFFCO policy for continous product development, NAFFCO has right to change specifications without prior notice.
 Micro
Processor
Based
Fire Pump
Controllers
1-1/2” BS 336 male
ELECTRIC FIRE PUMP CONTROLLER
 Micro
Processor
Based
Fire Pump
Controllers
1-1/2” BS 336 male
 , U F 1 )) 2

1 )) 2 ) 2 D Z UO O D re ghting technology and re safety solutions, NAFFCO

manufacturers and suppliers of top-tier re ghting D Z UN E U D D U F U
equipment, re protection systems, re alarms, security D Z OO D D IDF U OD DO D
and safety engineering systems worldwide. Since malls and other organizational projects, delivering
EO E 1 )) 2 D U Z IU comprehensive re safety and engineering solutions.
D T DU U ED D U U
100 countries around the world. NAFFCO is associated with globally renowned
international companies in the re protection industry
such as Esser, Secutron, Megalights, Evax, Fike, Central,
S SS OO Shield, Mueller, Giacomini, RB Pumps, Bombas, Ideal
F Pumps, Joslyn Pumps, Peerless Pumps.

1 )) 2 Z DU D D DE D
Today’s companies recognize the importance and upgrading and improving any means of safety, by having
convenience of having multiple safety services available U OO T DU I I D IDF U DF U
under one roof, a “one-stop shopping” source for all types 450 engineers, and following all the latest technology
of re protection systems. As the undisputed leader in available. We live by our passion, the passion to protect.
 / / 67( (/( 7 272
23 2 (662 6( 217 2//(
2 (/ 1) 6 ( ( 2/7 (
67 (/7 23(1 7 16 7 21
2 (/ 1) 2 ( 7 21 / 1(
NAFFCO Electric Motor Controllers for re pumps are Power ratings vary from 40 to 400 horsepower, 230 /
listed by Underwriters Laboratories (UL le number 380 / 415 VAC, 50/60 Hz.
EX15064), in accordance with UL218 (Standard for Fire
Pump Controller), UL508a (Standard for Industrial Control 2 Oy high quality UL listed or UL recognized components
Panel), NFPA20 (National Fire Protection Association DU D O DUD E EO
Pamphlet 20- Standard for Centrifugal Fire Pumps), reliability. Also high quality UL listed enclosures are
NFPA70 (National Electric Code) and NEMA. used.
F ntroller is completely wired, assembled,
programmed and tested at the factory before shipment,
and ready for immediate installation.

67 1 )( 7 (6
• 230 / 380 / 415 VAC, 50/60 Hz main 3 phase system
power.
• Voltage Surge Protector.
• Main disconnecting switch with rotary handle sized for
disconnecting motor horsepower and voltage.
• Circuit breaker with shunt trip coil and rotary handle.
• Rated motor contactors.
• Emergency run mechanism to mechanically close motor
contactor contacts to start motor in case of emergency.
• Manual start and stop push buttons.
• 20x4 LCD display showing all system parameters and
variables.
• User friendly software enables user to program all related
parameters like timers, pressure, inputs, outputs … etc.
• Shows 3 phase line voltages.
• Shows 3 phase line motor currents.
• Shows real value of discharge pressure.
• Shows motor running hours.
• Shows ambient temperature.
• Starting delay timer (programmable) for sequence multi
ple pumps starting.
• Automatic or manual shutdown after automatic start (se
lectable).
• Automatic shutdown mode enabled/disabled indicator.
• Power ON/Healthy indicator.
• Automatic mode indicator.
• Manual mode indicator.
67 1 )( 7 (6
• Motor Run indicator/free contact.
• Phase Loss/Failure alarm / indicator / free contact.
• Phase sequence error alarm/indicator / free contact.
• System error alarm / indicator / free contact.
• Fail to start alarm / indicator.
• System error alarm / indicator.
• Pump lockout indicator / free contact.
• Push button for alarm silence
(only for additional alarms).
• Motor locked rotor trip at 600% of FLA, after
programmable time delay.
• Programmable automatic test, which can be
programmed to start at any desired day, hour and
minute in the week.
• Manual test push button.
• Motor overload alarm/ indicator / free contact
(programmable).
• Over voltage alarm/indicator / free contact
(programmable).
• Under voltage alarm/ indicator / free contact
(programmable).
• Low discharge pressure alarm / indicator / free
contact (programmable).
• Deluge valve on alarm / indicator / free contact
(programmable).
)LJ
272 67 71 7( 67
• Remote start on alarm / indicator / free contact
(programmable).
• Manual local start on alarm/ indicator / free
contact (programmable).
• Fail while run alarm / indicator / free contact
(programmable).
• Emergency start on alarm / indicator / free contact
(programmable).
• Test on alarm/ indicator / free contact
(programmable).
• 10 additional programmable indicators (LED’s).
• 10 additional programmable auxiliary digital inputs.
• 7 additional programmable output relays (free
contacts).
• Pressure transducer with analog voltage output.
• Data logging system for pressure and events.
• USB port for saving recorded pressure and
events on USB memory, and can be viewed
with MS word and Excel.
• Electrically actuated built in discharge solenoid
valve.
• Electrical alarm bell.
• UL listed enclosure.
6 2/ 1 67 (/7
6( (1 ( 2) 23( 7 21 72 7 2 (
F U OO U Z UN U E D D F D •, I U U Z OO F
D DO Z D DO U D D F Z pressure point then motor will start automatically.
(automatic shut down is possible only after automatic • If the N/C contact of the deluge valve is opened, this
start). will cause the pump to start automatically exactly as if
the pressure goes down to starting pressure.
1 / 2 ( • In case of multiple pumps, it may be necessary to delay
•, U Z OO E II F I U U U DU I DF U U OD
and deluge valve. starting of all motors. Sequential starting can be
• Manual start of motor can be done by pressing start P.B. adjusted by a programmable timer. User has to
• Manual start can also be done by pushing specify if the pump is connected as single/parallel
emergency start mechanical handle. Z U U I F F
• D O U U F O F DU series with other pumps (programmable). In the rst
• In this mode motor can be stopped only manually by case (single or parallel), system may delay starting in
pressing Stop P.B. automatic mode only, but starting in manual mode
• All alarm signals are operational in this mode. will not be delayed. In the second case (series),
system may delay starting in automatic mode and
in manual mode, and this is to avoid dry running of
pump (see table 1) Notice that in case no time delay is
required before starting (for example when pump is
single), then time delay can be programmed to zero.
 7 ( (/ ()2 ( 67 71 7 () (3 3

REASON OF STARTING SINGLE PUMP OR PARALLEL PUMPS SERIES JUMPS

U U U With delay With delay

O DO With delay With delay

Remote start No delay With delay

Manual start No delay With delay

7DEOH

• If remote start switch was momentarily actuated, • Two ways of shutdown are possible in this mode
motor will start directly and automatically, and it will (operator have to select one of them by software):
O UD U U E
the panel’s door. In this mode (remote start mode) there 1. Manual shutdown: After automatic start, motor can
Z OO E II F I O DO DO D O Z U U be stopped in this mode only by pressing manual
stop push button. If the pump was on demand (low
signal. U U U O DO DF D D
• Motor automatic start by pressure sensor and deluge then pump cannot be stop manually, unless it is not on
valve can be disabled by pump lockout contact (external demand any more.
contact) which can be connected with controller (this 2. Automatic shutdown: After automatic start, controller
will keep motor running for a period (programmable).
option can be used in case of having a stand-by pump, After that, if the pump was not any more on
where it is not desired both pumps to start automatically demand, then controller will automatically shutdown
at the same time). the motor. If within this period, the pump became not
on demand, operator can shut it down manually by
pressing manual stop push button.

(7 2 6 2) 67233 1 7 () (3 3

REASON OF STARTING AUTOMATIC STOP MANUAL STOP

YES - selectable
U U U YES - selectable
(After running hold time)
YES - selectable
O DO YES - selectable
(After running hold time)
Remote start 12 YES
Manual start 12 YES

7DEOH

• All alarm signals are operational in auto mode. • Manual test is operational in auto mode only, and it
• Automatic weekly test is only operational at auto can be applied by pressing test ON/OFF push button.
mode and can be enabled or disabled (operator Test can be terminated by pressing Test ON/OFF push
selection). If enabled, then user has to program the delay button again.
time before starting the test. Also to program the day,
hour and minute where the weekly automatic test is
desired to start. Test can be terminated by pressing Test
ON/OFF push button.
) 1 7 21 / 7
• During operation of the system, controller will be • ,I F U OO U FO F DF U DU U
reading voltages, currents, pressure, and sensing many (due to auto or manual start), but the motor didn’t
input signals. These reading can be monitored on the start after some delay (programmable time delay),
LCD display. then controller will give alarm (fail to start alarm).
• ,I F U OO U F O I D U U Controller will sense if motor started or not by sensing
Z OO D DODU D Z OO U U IU DU the motor current.
E I O I D D Z O U ZD • ,I F U OO U FO F DF U DU U
U F U OO U Z OO DODU E Z OO (due to auto or manual start), but the motor didn’t
the motor. start after some delay (programmable time delay),
• ,I F U OO U F D U U DO Z OO DODU because of LOCKED ROTOR, then controller will
and will not start the motor. activate the shunt trip coil of the MCCB and shut it
• U OO U Z OO F U OD U OD D down. Controller will sense if motor is in locked rotor
overload (over current), and will give alarms showing situation or not by sensing the motor current.
these errors.

71
RATED SHORT CIRCUIT
POWER RATED VOLTAGE FREQUENCY ENCLOSED SIZE
21 1 CURRENT
(HP) (VAC) (Hz) (mm)
(A) (kA)

380 - 415 U N 1100(L) x 750(W) x 300(D)

380 - 415 U 83 N 1100(L) x 750(W) x 300(D)

380 - 415 U N 1100(L) x 750(W) x 300(D)

75 380 - 415 U 128 N 1200(L) x 800(W) x 300(D)

380 - 415 U N 1200(L) x 800(W) x 300(D)

380 - 415 U 208 N 1200(L) x 800(W) x 300(D)

380 - 415 U N 1500(L) x 800(W) x 350(D)

380 - 415 U N 1500(L) x 800(W) x 350(D)

380 - 415 U N 1500(L) x 800(W) x 350(D)

380 - 415 U 482 N 1500(L) x 800(W) x 350(D)

380 - 415 U N 1700(L) x 950(W) x 400(D)

380 - 415 U N 1700(L) x 950(W) x 400(D)

7DEOH

7
301
