THE TENDER . 14
DOCUMENTS AVAILABLE FOR THE BIDDERS
INDICATIVE TENDER STEPS
REFERENCE CONTACT
DISCLOSURE
2
THE PROJECT
The Government of Montenegro is seeking a private operator to construct and
operate a new cable car from Kotor to Cetinje over the Lovcen Mountain
in Montenegro on a DESIGN, BUILD, FINANCE, OPERATE, TRANSFER
(“DBFOT”) basis, with the Concessionaire to be selected through an open
international tender. The European Bank for Reconstruction and Development
(EBRD) is considering to contribute to the Project by financing the
concessionaire with a loan of up to €15 million Euro.
The main aim of the Project will be to foster tourism growth in the area of
south-western part of Montenegro and to collect those tourist flows from the
coastal area that today do not visit the Lovcen Par Mountain Park and the
historic Royal Capital of Montenegro: Cetinje.
The Project involves the construction of a cable car as an alternative to the
present bus and car based transport solutions. The route will run from Kotor to
Cetinje via the Lovcen Mountain National Park and close to the Njegos
Mausoleum, an important national monument erected in memory of the poet
and ruler of Montenegro, Njegos Petrovic II.
3
BACKGROUND
MONTENEGRO AND ITS TOURISM
TOURISM IN MONTENEGRO
The Tourism in Montenegro is fundamental for the Project as the new Cable Car
will primarily serve tourists, linking the bay of Kotor with the Lovcen National
Park and the Old Royal Capital of Cetinje. The two municipalities linked by the
new Cable Car, Kotor and Cetinje, recorded approximately 550,000 and 80,000
tourists in 2012, considering both daily visitors and visitors spending at least one
night in the municipality.
Moreover, one target of the project will also be to bring to the old Capital of
Cetinje tourists that currently remain in the coastal area. Only in the town of
Budva on the coast there have been 690,000 tourists in 2012.
Herceg Novi
Kotor
Tivat
Cetinje
S1
S2
S3
S4
Budva
4
The new cable car will improve the connection between those three important
touristic centers and will also be a tourist attraction in itself, being the longest
passenger cable car in the world, providing a spectacular view of the bay to
its passengers.
The expected result is an increase in domestic and foreign visitors to the area of
the project. This in turn will lead to direct and indirect benefits for the economy
of the area including increased tourist expenditure, development of new
commercial activities, increased employment possibilities for the local
population, etc.
The “idea design” (in Montenegrin: idejni projekat) is based on the original
spatial plan, by the Ministry for Sustainable Development and Tourism and the
Environmental Impact Assessment Study.
The route starts from Dub, on the outskirts of Kotor (close to the entrance of the
road tunnel linking Kotor to Tivat), it then reaches Kuk on top of the mountains
surrounding Kotor. From here a stretch reaches Ivanova Kurita before
descending to Cetinje as indicated in Figure 2 and Figure 3.
5
Figure 2: The route Altimetry (AG = altitude gap; LL = line length)
The cable car should use a modern design cable car with at least 8 place cabins
and automatic clamping. The total route will be divided into three sections and
would be characterized by high cabin speeds when in line (speed of 6m/s) and
by low speeds when in the stations (speed of 0.3m/s) to ease passengers
boarding and alighting operations.
6
The three sections should be mechanically independent, they would individually
be equipped with their own engines, but the terminal stations should be
connected to each other to ease passenger access.
The first two sections (from Dub to Kuk and from Kuk to Ivanova Korita) should
be connected through intermediate stations that should allow the automatic
transfer of the cabins from one rope ring to the next allowing, but of course not
requiring, passengers to remain in their cabin without them being required to
alight. The third stretch (from Ivanova Korita to Cetinje), instead, would not be
connected directly to the preceding ones and passengers would be obliged to
alight from the cabin.
The proposed system is extremely flexible and able to satisfy passenger needs in
both travel directions. In case of failure of one of the three sections the
remaining two will remain operational to ensure continuity and reduce
passenger disruption.
For each section a warehouse will be realized to shelter the cabins during non
operation periods or in bad weather conditions.
7
Horizontal length among the 3616.97 m / 3301.17 m / 7434.46 m
station entries:
Alternative way of rescue The gondolas can be set with redundant system, in
order to always grant the rescue of stopped vehicles on
the line, to avoid the operation of rescue of passengers
still on the line.
8
TERMINAL LOCATION
The locations of the terminals and intermediate stations will be in Dub, Kuk, Ivanova
Korita and the town of Cetinje:
Dub station and its surroundings are of fundamental importance as a
number of shuttle buses will arrive here from the port of Kotor and Budva,
for that reason a large parking area as well as a cabin storage facility are
provided for in the project.
The area at the Kuk station is on public land but has some environmental
constraints being inside the Lovcen Park. As the area immediately adjacent
to the mausoleum is not to be altered in any way, the station could not be
placed too close to the mausoleum. The intermediate station can also serve
as access point for other leisure activities such as hiking, hang-gliding etc.
Ivanova Korita is on public land with no development constraints. It has
already an access road but private transit in this area is to be forbidden. This
station could became the focal point of Lovcen National Park.
Cetinje station is on a public land within walking distance from the town
centre, thus allowing the visitors to enjoy the cultural and touristic offers of
the city. In the nearby there is a parking area that will need to be enlarged.
The design of the cable car will meet the requirements set out in Directive 2000/9/EC.
Safety components and subsystems shall be certified by Notified Bodies. Infrastructure
will be designed and approved according to harmonized CEN Norms.
OPERATION
Operation will take place at least over the period from April to October, 7 months in
total. The summer peak time will see all three sections operate at top capacity and the
system should be designed to reach a maximum transport capacity of 1,200Pax/h for the
first two sections, a speed of 6 m/s and a total transit time of 11.5 minutes for Section 1
and 10 minutes for section 2 and a transport capacity of 1,000Pax/h for the third section
with a speed of 6m/s and with a total transit time of 21.5 minutes.
The overall transit time for all three stretches, considering also passing through the
intermediate stations, will be about 45 minutes.
Considering the long transit times and the climatic conditions in Montenegro during the
summer, it will be recommended to equip the cabins with appropriate HVAC system.
During spring and autumn there will be the possibility to reduce the number of cabins
and hence reduced operating costs.
9
MAIN ASSUMPTIONS
Hereafter the main assumptions of the Project:
DEMAND
Assumption Comment
Cable car capture Two scenarios (Low and High The optimistic scenario
rate cases) based on the available takes into account
alternatives presented by tour higher capture rate for
operators Budva tourist
SCHEME CHARACTERISTICS
Assumption Comment
10
21.00)
COST ESTIMATES
CONSTRUCTION COSTS
The cost estimate are for all the equipment necessary to build an 8 person
automatic clamping cable car. Please note that these costs relate exclusively to
the equipment, construction of the Cable Car route and structural parts of the
station and they do not account for the civil works needed to build the station
buildings which are discussed separately.
Costs cover:
design
machinery at the engine stations at the bottom of the route
recirculation and tension systems in the station at the top of the route
electric and hydraulic drivers
cables
line pylons
roller conveyors
vehicles
emergency devices
structures in the stations
metallic carpentry for supporting and moving the vehicles to the storehouses
11
The total investment costs for all sections is € 36,700,000.
To the above mentioned total costs, additional costs might be considered for such
things as deforestation, for expropriation (estimates a specific cost of €30 per m2
and 15% of the terminal stations areas to be expropriated being the remaining
areas property of the Municipality or the Government), for roads and utilities
works as well as for the construction of high quality buildings at the terminal and
intermediate stations with attached services (ticket-office, personnel offices,
toilets, electric cabins, etc.)
These costs also exclude the connection to the electricity, drainage and water
networks.
The following table shows all the estimated costs, also for building the stations in
Dub, Kuk, Ivanova, Cetinje:
ITEM CAPEX
TOTAL € 46,550,000
The amounts above include all the works needed (e.g. architecture activities,
civil works and plants) to realise each station except for the Cable Car related
structural part of the stations that are already accounted for in the CapEx for the
Sections.
More specifically the amounts include the following tasks:
Excavations and embankments
12
Civil works (concrete foundations, walls and floors, steel structures, roofs,
windows, plastering, asphalting for the Dub parking area and finishing
works)
Electrical installation High Voltage (HV)
Electrical installation Low Voltage (LV)
Water and waste water (sewerage system)
HVAC (air conditioning system)
OPERATIONAL COSTS
This general cost includes costs for staff and monitoring, maintenance,
controls and revisions, electricity, insurance and contingencies.
This category excludes costs related to administrative and to marketing
aspects and depreciation.
Please note that all operating costs are estimated on the base of 7
months of opening p.a., estimated forecasts on tourist flow and a
standard maintenance.
13
payments to the private sector which reflect the services delivered:
The Montenegrin Government has decided to support the PPP
Company through availability payments.
The EBRD (European Bank for Reconstruction and Development) is
available to financially support the Project with a loan of up to €15
million to the Concessionaire.
DESIGN, BUILD, MAINTAIN AND OPERATE
THE TENDER
The tender is likely to be divided into two phases:
1. a Pre-Qualification Process to ensure potential bidders will meet
technical and financial criteria.
2. A Tender process for the selected bidders.
14
INDICATIVE TENDER STEPS
ACTIVITY
Selected Bidders
Publish Tender
DISCLOSURE
Please note that the information contained in this document are for information
purposes only and that neither the Government of Montenegro, nor the authors
of this document, nor Cetinje Municipality are assuming any kind of liability for
the contents of the document.
REFERENCE CONTACTS
15
