How to Program a PIC Microcontroller to Build a

Project
PIC 32 COMMENTS

The recent trends in the advanced technology are helpful in developing most advanced electronic gadgets. Most of  these
electronic devices are developed using microcontrollers. The microcontroller is an electronic component, which is programmed
to perform various control operations. There are various kinds of microcontrollers available, such as 8051, AVR, ARM, and PIC
microcontrollers, etc., which are programmed by using the integrated development tools.
SEARCH

SPONSORED SEARCHES

rubber vape rings

vape smoke change color

python offline tutorial

PIC Microcontroller Programming Steps
fine wooden boxes

PIC Microcontroller study of arduino

The PIC is a family of the microcontroller, which is manufactured by the di erent companies such as NXP, microchip, etc. The
PIC stands for “peripheral interface controller”, which contains memories, timers/counters, serial communication, interrupts
and ADC converters built into a single integrated chip.

RECENT POSTS

Labview Projects for Engineering

Students
Need electronics ICM-20608-G Specifications and
solutions? Applications

APDS-9960 Specifications and

We can provide the most Applications
suitable solutions from TDK
Group's wide range of products MATLAB Projects for Engineering
TDK Corporation
Students

What is Attenuation : Different Types & Its

Causes
The PIC microcontrollers are found in most electronic devices such as alarm systems, tra ic control systems and RFID based
security systems, etc. The PIC microcontroller programming can be carried out to perform the huge range of tasks. Even though AT Commands Tutorial
there are many types of PIC microcontrollers , the best and basic microcontroller is PIC16f877a. Electromagnetic Spectrum (EM
Spectrum) Working & Its Applications
PIC Microcontroller Programming Procedure Color Sensor – Working and Applications
The PIC microcontrollers is programmed by the  embedded C language or assembly language by using appropriate dedicated Satellite Communication System
so ware. Before going to build a PIC microcontroller project, we must become aware of developing a basic microcontroller (like
Electronic Communication and Its Types
8051) based project. Once you get the idea, this controller based project building becomes easy, so let us  look at the basic steps
to build a PIC microcontroller based project.

Before going to program the PIC microcontroller, first we have to select the right project that you are going program the
microcontroller. As of now, consider the LEDs flash light system.

Theory:
SPONSORED SEARCHES

PIC16F84A Price in India

The LEDs flashlight  uses a set of light emitting diodes, and these are advanced to the
Colorful Smoke Vape Juice
traditional incandescent lights which consumes more energy and have very less life time. The
LED lights on the other hand, consume less energy and have longer life.

Basic Idea of this Project Behind the Design:

The microcontroller generates the output logic pulses so that the LED light is switched ON and OFF at certain intervals. It is a 40
pin microcontroller. The Crystal interfaced to the input pins of the microcontroller  provides  accurate clock signals at the crystal
frequency.

Circuit Designing
The PIC microcontroller transmit and receive the data with respect to clock pulses, the PIC microcontroller operates with 4MHz
crystal frequency. Two capacitors are connected to the crystal oscillator with range of 20pf to 40pf which is used to stabilize the
clock signals. At some times, the PIC microcontroller goes to block state or missing time calculation,at that time we need to
reset the microcontroller. If a microcontroller is reset for 3sec time delay, 10k resistor and 10uf capacitor are connected to the
respective pins.

Circuit Components

MOST READ POSTS

Hardware Components
Half Adder and Full Adder with Truth
Yellow LEDs Table
Crystal
MOSFET Basics, Working Principle and
Reset
Applications
PIC Microcontroller
Capacitors Latest Electronics Project Ideas
Resistors
How Does a PID Controller Work? -
Structure & Tuning Methods
So ware Components
New 100+ Top Electrical Projects Ideas
MPLAB Compiler
Proteus software
Embedded C language

Circuit Connections

The 5v DC supply is given to the 11 pin of the microcontroller which  drives  the circuit. The crystal  is connected to the 13 and 14
pins of the microcontroller. The reset circuit is interfaced at 1 pins of the microcontroller. The Yellow LEDs is connected to the
PORTB of the microcontroller.

Circuit Diagram
This circuit is designed with the help of Proteus so ware. The Proteus is a circuit designing so ware that contains a database of
components, which we can use to build the circuit. Each and every component is available in the component library. X

PIC Microcontroller Project Circuit Diagram

Open the Proteus software. A window with a menu bar appears.

Click the file menu.
Select ‘new design’ from the drop-down menu.
Click the library menu.
Select ‘pick devices/symbol’ from the drop-down menu.
Select the relevant comment by double clicking it, so that the electronic components list appear on the window.
Add all the components and draw the circuit with the proper connections as shown above.

Program the PIC Microcontroller

The PIC microcontroller programming is performed through  ‘MP-Lab’ so ware. First instal the MP-Lab so ware, then select and
install the compiler like CCS, GCC compiler, etc. Here ‘CCS C compiler’ is used for building the program.

Controllers for DC brushless motors. 24

- 48VDC, up to 50 A. RS-485 or 0-5V…
Ad Manufacturer. Fast shipping. Technical support.
Ad Analog 0-5V or RS485 speed control.
Smart Motor Devices

Learn more

First open the MPLAB software. This shows the menu bar with file, edit, view, project and tools option.
Select the project option and select the ‘project wired option’ from the drop-down menu. This will show the project
wired window.
Select a microcontroller for your project. Here ‘PIC16f877A’ microcontroller is selected.
Select the compiler and path location for your project. Here ‘CCS C compiler’ is selected for the PIC microcontroller,
then select the ‘browse’ option from the project wired window to select the ‘ccsloader’ in the PICC folder from the
program files. A folder with the name ‘source group’ is created in the ‘target’ folder.
Give a name to the project and click on ‘NEXT’ button to save the project. A folder with the name ‘source group’ is
created in the ‘target’ folder.. Click on the ‘file’ menu on the menu bar. Select ‘new file’ from the drop- down menu.

PIC Microcontroller Programming Code

The LED Flash Program:

#include<pic16f877x.h>
void delay(int);
sbit a=PB^2;
sbit b=PB^3;
sbit c=PB^4;
sbit d=PB^5;
void main()
{

TRISB=0x00;
a=b=c=d=0x00;
delay(10);
a=b=c=d=0xFF;
}
void delay(int a )
{
unsigned char c;
for(c=0;c<a;c++)
for(c=0;c<250;c++);
}

Load the Code to PIC Microcontroller

The code loading process of microcontroller is called dumping. The microcontrollers understand only the machine level
language, which contains ‘0 or 1s’. So we need to load the hex code into the microcontroller. There are many so wares available
in the market for loading the code to the microcontroller. Here we have used ‘PICFLSH’ programmer so ware to dump the code
to the PIC  microcontroller. The programmer kit comes with the hardware kit along with the so ware.

This so ware needs to be installed into the computer. The microcontroller placed in the hardware kit, which comes  with the
socket. Here are the steps to load the code onto the microcontroller.

Code Dumping Device

Interface the hardware (programmer kit) to the computer through a serial cable
Place the microcontroller in the socket of the hardware kit. Press the lock button to ensure the microcontroller is
connected to the board.
Open the software installed in the computer. This shows the menu bar with file, functions, open, save and setting
options.
Select the ‘open’ option from the drop-down menu and select the ‘load file’ .
Click on the ‘load’ button so that the hex file is loaded into the microcontroller.

Code Loading to PIC Microcontroller

Simulating the Circuit

The simulation is a decision analysis and support tool, which is used to know the performance of the circuit. The hardware is the
cost-e ective  equipment, so the  proposed action cannot be directly observed by the hardware. The simulation so ware allows
you to know the circuit performance and find & rectify the errors of the program. There are di erent types of simulating
so wares available in the market for checking the circuit performance.  Here Proteous so ware is used to check the circuit
performance.

Open the project in the Proteus software.

Click on the ‘Debug’ menu.
Select the ‘start debugging’ option. The LED starts blinking, which indicates the circuit is running.
After some time, select the ‘stop debugging’ option. The LED will now stop blinking.

These are the necessary steps for PIC microcontroller programming to develop simple project. Hope that you might have got a
basic idea on this topic. Any further assistance to build the PIC based projects or any microcontroller based projects you can
contact us by commenting below.
