Silver Oak Group of Institutes

Silver Oak College of Computer Application

Chapter 2: Relational Data Model

Topics:
Structure of relational databases, Domains
Relations, Relational algebra-fundamental operators and syntax, relational algebra queries
Entity Relationship Diagram
Components of E-R Diagram (Entities, Attributes, Relationship)
Mapping cardinalities
Keys
Extended E-R Features: Specialization, Generalization and Aggregation.

Structure of relational databases

Relations:
Relation is sometimes used to refer to a table in a relational database but is more commonly used to describe
the relationships that can be created between those tables in a relational database.

❖ Relational algebra-fundamental operators and syntax

Relational algebra is a procedural query language, which takes instances of relations as input and yields
instances of relations as output. It uses operators to perform queries. An operator can be either unary or binary.
They accept relations as their input and yield relations as their output. Relational algebra is performed
recursively on a relation and intermediate results are also considered relations.
The fundamental operations of relational algebra are as follows −
• Select
• Project
• Union
• Set different
• Cartesian product
• Rename
We will discuss all these operations in the following sections.
Select Operation (σ)
It selects tuples that satisfy the given predicate from a relation.
Notation − σp(r)
Where σ stands for selection predicate and r stands for relation. p is prepositional logic formula which may use
connectors like and, or, and not. These terms may use relational operators like − =, ≠, ≥, <, >, ≤.
For example −
σsubject = "database"(Books)
Output − Selects tuples from books where subject is 'database'.
σsubject = "database" and price = "450"(Books)
Output − Selects tuples from books where subject is 'database' and 'price' is 450.
σsubject = "database" and price = "450" or year > "2010"(Books)
Output − Selects tuples from books where subject is 'database' and 'price' is 450 or those books published after
2010.
Project Operation (∏)
It projects column(s) that satisfy a given predicate.
Notation − ∏A1, A2, An (r)
Where A1, A2, An are attribute names of relation r.
Duplicate rows are automatically eliminated, as relation is a set.
For example −
∏subject, author (Books)
Selects and projects columns named as subject and author from the relation Books.
Union Operation (∪)
It performs binary union between two given relations and is defined as −
r ∪ s = { t | t ∈ r or t ∈ s}
Notation − r U s
Where r and s are either database relations or relation result set (temporary relation).
For a union operation to be valid, the following conditions must hold −
• r, and s must have the same number of attributes.
• Attribute domains must be compatible.
• Duplicate tuples are automatically eliminated.
∏ author (Books) ∪ ∏ author (Articles)
Output − Projects the names of the authors who have either written a book or an article or both.

Set Difference (−)

The result of set difference operation is tuples, which are present in one relation but are not in the second
relation.
Notation − r − s
Finds all the tuples that are present in r but not in s.
∏ author (Books) − ∏ author (Articles)
Output − Provides the name of authors who have written books but not articles.
Cartesian Product (Χ)
Combines information of two different relations into one.
Notation − r Χ s
Where r and s are relations and their output will be defined as −
r Χ s = { q t | q ∈ r and t ∈ s}
σauthor = 'xyz'(Books Χ Articles)
Output − Yields a relation, which shows all the books and articles written by xyz.
Rename Operation (ρ)
The results of relational algebra are also relations but without any name. The rename operation allows us to
rename the output relation. 'Rename' operation is denoted with small Greek letter rho ρ.
Notation − ρ x (E)
Where the result of expression E is saved with name of x.
Additional operations are −
• Set intersection
• Assignment
• Natural join
Relational Calculus
In contrast to Relational Algebra, Relational Calculus is a non-procedural query language, that is, it tells what to
do but never explains how to do it.
Relational calculus exists in two forms −
Tuple Relational Calculus (TRC)
Filtering variable ranges over tuples
Notation − {T | Condition}
Returns all tuples T that satisfies a condition.
For example −
{ T.name | Author(T) AND T.article = 'database' }
Output − Returns tuples with 'name' from Author who has written article on 'database'.
TRC can be quantified. We can use Existential (∃) and Universal Quantifiers (∀).
For example −
{ R| ∃T ∈ Authors(T.article='database' AND R.name=T.name)}
Output − The above query will yield the same result as the previous one.
❖ Entity Relationship Diagram
• The E-R model cannot express relationships among relationships.
• When would we need such a thing at that time aggregation is used?
• Consider a database with information about employees who work on a particularproject and use a
number of machines doing that work.

hours hours
name id number name id number

emp work project emp project

work

uses uses
work

machinery

uses
id

machinery
Fig. A Fig. B

• Relationship sets work and uses could be combined into a single set. We can combinethem by
using aggregation.
• Aggregation is an abstraction through which relationships are treated as higher-level entities.
• For our example, we treat the relationship set work and the entity sets employee and project as a
higher-level entity set called work.
• Transforming an E-R diagram with aggregation into tabular form is easy. We create a table for
each entity and relationship set as before.
• The table for relationship set uses contains a column for each attribute in the primary key of
machinery and work.

Step 1: Entities and Simple Attributes:

• An entity type within ER diagram is turned into a table. You may preferably keep the same name
for the entity or give it a sensible name but avoid DBMS reserved words as well as avoid the use of
special characters.
• Each attribute turns into a column (attribute) in the table. The key attribute of the entity is the
primary key of the table which is usually underlined. It can be composite if required but can never
be null.
• It is highly recommended that every table should start with its primary key attribute
conventionally named as TablenameID.
• Consider the following simple ER diagram:
 PersonID Person
Phone

Name
Address Emai
l
• The initial relational schema is expressed in the following format writing the tablenames with the
attributes list inside a parentheses as shown below

✓ Persons( personid, name, address, email )

Person
personid name address Email

• Persons and Phones are Tables and personid, name, address and email are Columns
(Attributes).
• personid is the primary key for the table : Person

Step 2: Multi-Valued Attributes

• A multi-valued attribute is usually represented with a double-line oval.

PersonID Person
Phone

• If you have a multi-valued attribute, take that multi-valued attribute and turn it into a new entity
or table of its own.
• Then make a 1:N relationship between the new entity and the existing one.
• In simple words.
➢ 1. Create a table for that multi-valued attribute.
➢ 2. Add the primary (id) column of the parent entity as a foreign key within the new
table as shown below:
✓ First table is Persons ( personid, name, address, email )
✓ Second table is Phones ( phoneid , personid, phone )

• personid within the table Phones is a foreign key referring to the personid of Persons

Phone
phoneid personid phone

Step 3: 1:1 Relationship

 WifeID Wife Name

Have

PersonID Person
Phone

Name
Address Emai
l

• Let us consider the case where the Person has one wife. You can place the primary key of the wife
table wifeid in the table Persons which we call in this case foreign key as shown below.
✓ Persons( personid, name, address, email , wifeid )
✓ Wife ( wifeid , name )
• Or vice versa to put the personid as a foreign key within the wife table as shown below:
✓ Persons( personid, name, address, email )
✓ Wife ( wifeid , name , personid)
• For cases when the Person is not married i.e. has no wifeID, the attribute can set to NULL
Persons Wife
personid name address email wifeid wifeid name

OR

Persons Wife
personid name address email wifeid name personid

Step 4: 1:N Relationships

HouseID House Name

Address
Has

PersonID Person
Phone

Name
Address Emai
l

• For instance, the Person can have a House from zero to many, but a House can haveonly one
Person.
• In such relationship place the primary key attribute of table having 1 mapping in to the table
having many cardinality as a foreign key.
• To represent such relationship the personid as the Parent table must be placed within the Child
 table as a foreign key.
• It should convert to :
✓ Persons( personid, name, address, email )
✓ House ( houseid, name , address, personid)
Persons House
personid name address email houseid name address personid

Step 5: N:N Relationships

CountryID Country Name

Has

PersonID Person
Phone

Name
Address Email

• For instance, The Person can live or work in many countries. Also, a country can have many
people. To express this relationship within a relational schema we use a separate table as shown
below:
• It should convert into :
✓ Persons( personid, name, address, email )
✓ Countries ( countryid, name)
✓ HasRelat ( hasrelatid, personid , countryid)
Persons Countries
personid name address email countryid name

HasRelat
hasrelatid personid countryid
 ❖ E-R model
• Entity-relationship (ER) model/diagram is a graphical representation of entities and their
relationships to each other with their attributes.

❖ Mapping cardinalities

In database management, cardinality plays an important role. Here cardinality represents the number of times an
entity of an entity set participates in a relationship set. Or we can say that the cardinality of a relationship is the
number of tuples (rows) in a relationship. Types of cardinality in between tables are:
1. one-to-one
2. one-to-many
3. many-to-one
4. many-to-many
1) One-to-One Cardinalities:

One to one cardinality is represented by a 1:1 symbol. In this, there is at most one relationship from one entity
to another entity. There are a lot of examples of one-to-one cardinality in real life databases.

For example, one student can have only one student id, and one student id can belong to only one student. So,
the relationship mapping between student and student id will be one to one cardinality mapping.

2) One-to-Many Cardinalities:

In One-to-many cardinality mapping, from set 1, there can be a maximum single set that can make relationships
with a single or more than one entity of set 2. Or we can also describe it as from set 2, more than one entity can
make a relationship with only one entity of set 1.

One to one cardinality is the subset of One-to-many Cardinality. It can be represented by 1: M.

For Example, in a hospital, there can be various compounders, so the relationship between the hospital and
compounders can be mapped through One-to-many Cardinality.

3) Many-to-One Cardinality:

In many to one cardinality mapping, from set 1, there can be multiple sets that can make relationships with a
single entity of set 2. Or we can also describe it as from set 2, and one entity can make a relationship with more
than one entity of set 1.
One to one Cardinality is the subset of many to one Cardinality. It can be represented by M:1.

For example, there are multiple patients in a hospital who are served by a single doctor, so the relationship
between patients and doctors can be represented by many to one Cardinality.

4) Many-to-Many Cardinalities:

In many, many cardinalities mapping, there can be one or more than one entity that can associate with one or
more than one entity of set 2. In the same way from the end of set 2, one or more than one entity can make a
relation with one or more than one entity of set 1.

It is represented by M: N or N: M.

❖ Keys
Keys play an important role in the relational database.
It is used to uniquely identify any record or row of data from the table. It is also used to establish and identify
relationships between tables.
For example, ID is used as a key in the Student table because it is unique for each student. In the PERSON
table, passport_number, license_number, SSN are keys since they are unique for each person.

Types of keys:
1. Primary key
o It is the first key used to identify one and only one instance of an entity uniquely. An entity can contain
multiple keys, as we saw in the PERSON table. The key which is most suitable from those lists becomes
a primary key.
o In the EMPLOYEE table, ID can be the primary key since it is unique for each employee. In the
EMPLOYEE table, we can even select License_Number and Passport_Number as primary keys since
they are also unique.
o For each entity, the primary key selection is based on requirements and developers.
2. Candidate key
o A candidate key is an attribute or set of attributes that can uniquely identify a tuple.
o Except for the primary key, the remaining attributes are considered a candidate key. The candidate keys
are as strong as the primary key.

For example: In the EMPLOYEE table, id is best suited for the primary key. The rest of the attributes, like
SSN, Passport_Number, License_Number, etc., are considered a candidate key.

3. Super Key
Super key is an attribute set that can uniquely identify a tuple. A super key is a superset of a candidate key.

For example: In the above EMPLOYEE table, for(EMPLOEE_ID, EMPLOYEE_NAME), the name of two
employees can be the same, but their EMPLYEE_ID can't be the same. Hence, this combination can also be a
key.
4. Foreign key
o Foreign keys are the column of the table used to point to the primary key of another table.
o Every employee works in a specific department in a company, and employee and department are two
different entities. So we can't store the department's information in the employee table. That's why we
link these two tables through the primary key of one table.
o We add the primary key of the DEPARTMENT table, Department_Id, as a new attribute in the
EMPLOYEE table.
o In the EMPLOYEE table, Department_Id is the foreign key, and both the tables are related.

5. Alternate key

There may be one or more attributes or a combination of attributes that uniquely identify each tuple in a
relation. These attributes or combinations of the attributes are called the candidate keys. One key is chosen as
the primary key from these candidate keys, and the remaining candidate key, if it exists, is termed the alternate
key. In other words, the total number of the alternate keys is the total number of candidate keys minus the
primary key. The alternate key may or may not exist. If there is only one candidate key in a relation, it does not
have an alternate key.

For example, employee relation has two attributes, Employee_Id and PAN_No, that act as candidate keys. In
this relation, Employee_Id is chosen as the primary key, so the other candidate key, PAN_No, acts as the
Alternate key.

6. Composite key

Whenever a primary key consists of more than one attribute, it is known as a composite key. This key is also
known as Concatenated Key.
For example, in employee relations, we assume that an employee may be assigned multiple roles, and an
employee may work on multiple projects simultaneously. So the primary key will be composed of all three
attributes, namely Emp_ID, Emp_role, and Proj_ID in combination. So these attributes act as a composite key
since the primary key comprises more than one attribute.

❖ Extended E-R Features: Specialization, Generalization and Aggregation

❖ Generalization
o Generalization is like a bottom-up approach in which two or more entities of lower level combine to
form a higher level entity if they have some attributes in common.
o In generalization, an entity of a higher level can also combine with the entities of the lower level to form
a further higher level entity.
o Generalization is more like subclass and super class system, but the only difference is the approach.
Generalization uses the bottom-up approach.
o In generalization, entities are combined to form a more generalized entity, i.e., subclasses are combined
to make a super class.

For example, Faculty and Student entities can be generalized and create a higher level entity Person.

❖ Specialization
o Specialization is a top-down approach, and it is opposite to Generalization. In specialization, one higher
level entity can be broken down into two lower level entities.
o Specialization is used to identify the subset of an entity set that shares some distinguishing
characteristics.
o Normally, the superclass is defined first, the subclass and its related attributes are defined next, and
relationship set are then added.

For example: In an Employee management system, EMPLOYEE entity can be specialized as TESTER or
DEVELOPER based on what role they play in the company.
 ❖ Aggregation

In aggregation, the relation between two entities is treated as a single entity. In aggregation, relationship with its
corresponding entities is aggregated into a higher level entity.

For example: Center entity offers the Course entity act as a single entity in the relationship which is in a
relationship with another entity visitor. In the real world, if a visitor visits a coaching center then he will never
enquiry about the Course only or just about the Center instead he will ask the enquiry about both.
