MAIN ELECTRIC MOTOR

119D57312-1
TABLE OF CONTENTS Sandvik DD422iE 190906

10. MAIN ELECTRIC MOTOR

* BG 009 156 34 MOTOR UNIT............................................................................................................................................................ 2
** BG 006 067 69 NSS MOUNTING, E-DRIVE MOTOR UNIT BEDROCK........................................................................................ 3

Sandvik Mining and Construction Oy Drills Tampere © 2019

 BG 009 156 34 aB
1 (3) MOTOR UNIT 190906

44

38 37 36

33

39 40 42 43

Sandvik Mining and Construction Oy Drills Tampere © 2019

 BG 009 156 34 aB
190906 MOTOR UNIT 2 (3)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 007 050 54 MOTOR, THREE PHASE 160kW/1500rpm, 400VD/690VY 1
33 AF0 120 0270 SCREW, SET, SOCKET, HEXAGON, CONE M12x20 2
POINT
36 AF0 190 0009 NUT, HEXAGON, PREVAILING TORQUE M20 4
37 AF0 010 1350 SCREW, HEXAGON HEAD, FULL THREAD M20x100 4
38 AF0 300 0126 WASHER, LOCK, PAIR NL20-sp 8
. . . . .
39 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 2
40 AF0 300 0031 WASHER, LOCK, PAIR NL10 2
42 550 531 21 CONNECTING PIECE 2
44 AF2 002 0060 CIRCLIP, INTERNAL 75.0x2.5 1
602 BG 006 067 69 NSS MOUNTING SECTION 10 PAGE 3 1
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2019

 BG 006 067 69 aA NSS
3 (3) MOUNTING / E-DRIVE MOTOR UNIT BEDROCK 190906

1
2

Ref. Part no. Description EN Standard designation Qty

e
1 AF0 010 1125 SCREW, HEXAGON HEAD, FULL THREAD M16x40 4
2 AF0 300 0124 WASHER, LOCK, PAIR NL16-sp 4

Sandvik Mining and Construction Oy Drills Tampere © 2019
