1 The chitosan hydrogels: From structure to function

2
3 Jing Fu 1,2, Fuchao Yang 1, Zhiguang Guo1,3*
New Journal of Chemistry Accepted Manuscript

1
4 Hubei Collaborative Innovation Centre for Advanced Organic Chemical Materials and Ministry
Published on 17 September 2018. Downloaded by Freie Universitaet Berlin on 9/21/2018 8:43:25 AM.
5 of Education Key Laboratory for the Green Preparation and Application of Functional Materials,
6 Hubei University, Wuhan 430062, P. R. China.
2
7 School of Chemistry and Environment Engineering, Wuhan Institute of Technology, Wuhan
8 430205, P. R. China.
3
9 State Key Laboratory of Solid Lubrication, Lanzhou Institute of Chemical Physics, Chinese
10 Academy of Sciences, Lanzhou 730000, P. R. China.
11 *Address correspondence to E-mail: zguo@licp.cas.cn
12 Abstract
13 Knowledge of the structure of the hydrogels and the gelation mechanism of intelligent
14 hydrogels is essential to designing bioinspired hydrogels. As one of the raw materials
15 in hydrogels, chitosan has been highly pursued due to the polymer's biocompatibility,
16 biodegradability and low toxicity. Following the biomimetic principles to prepare
17 chitosan intelligent hydrogel has drawn great research interests in materials science
18 and engineering. In this paper, we present the recent progress in fabricating intelligent
19 chitosan hydrogels. Starting from the features of the hydrogels and the advantage of
20 the chitosan, the several development of the chitosan intelligent hydrogels have been
21 introduced. With constructed the hydrogels network, diversified physical interactions
22 and chemical covalent bonds have been used, this review focuses on the interactions
23 formed the hydrogels which based on the chitosan. The stimuli responsive
24 characteristics, bio-inspired functions and high mechanical strength properties of the
25 chitosan hydrogels have been detailed in the review. The emphasis of this paper was
26 on the relationship between the structural characters and the corresponding functions
27 of above intelligent hydrogels. Finally, a perspective on challenges facing the field
28 and prospects for future development are given.
29 Keywords: Chitosan; Hydrogels; Formation; Intelligent
30 1. Introduction
31 Hydrogel is a kind of hydrophilic polymer network which can swell but not dissolve
1 / 43
New Journal of Chemistry Page 2 of 44
View Article Online
DOI: 10.1039/C8NJ03482F
32 in water, and it has character like both liquid and solid [1]. Despite the water in the
33 hydrogel is bound with the gel network, it is still a certain activity. The fully swollen
34 hydrogel shows some characteristic properties similar to the organism, including a

35 soft and rubbery consistency common to living tissues, higher permeability to
36 undersized molecules and release of entrapped molecules in a controlled manner [2-4].

37 In addition, the hydrogel can be prepared with many different physical forms, from
38 solid molded forms to membranes or sheets, and even to microparticles or coatings [5].
39 The dimensions of hydrogel can also vary from nanometers to centimeters in width,
40 and it is also relatively deformable and readily conform to the shape of any confined
41 space [6,7]. These features have made hydrogel applied on biomedical, medicine,
42 industry, agriculture and other fields [8]. Recently, new ideas on the design of
43 hydrogels with the response to stimulate of external environment [9,10] (such as
44 temperature, pH value, electricity, light, magnetic field, specific biological molecules,
45 etc.), self-repair characteristic like the organism and substantially enhanced
46 mechanical properties have broadened their applicability, these novel hydrogels which
47 different with the traditional hydrogels can termed intelligent hydrogels [11,12]. As
48 the first biomaterials designed for use in the human body, intelligent hydrogels have
49 revitalized biomaterials research field [13].
50 Comparing with the synthetic polymer hydrogels, the natural polymer hydrogels
51 have acquired increasing attention due to their properties of low toxicity, good
52 biocompatibility, easy degradation, rich source and low price [14]. Chitin is a natural
53 biopolymer with the most abundant polymer after cellulose. Chitosan (CS) derived
54 from deacetylated chitin (Fig. 1), is a natural amino homogeneous linear
55 polysaccharide composed of glucosamine and N-acetyl glucosamine units linked by
56 β-(1-4) glycosidic bond [15]. This material with free amino groups has no pollution to
57 the environment, owning to stronger reactivity and solubility than chitin [16]. Chitin
58 and chitosan can be easily processed into hydrogel [17,18]. Madhumathi et al.
59 synthesized chitin/nanosilver composite scaffolds with incorporation silver
60 nanoparticles into chitin hydrogel, and the scaffolds will function as ideal wound
61 dressings [19]. Jayakumar group developed α- and β-chitin membranes using α- and
2 / 43
View Article Online
DOI: 10.1039/C8NJ03482F
62 β-chitin hydrogels [20]. The bioactivity and cell adhesion studies of these membranes
63 indicated that it could be used for tissue-engineering applications. Chitin hydrogel is
64 usually prepared through a two-step process involving dissolution followed by

65 cross-linking, and specific solvent systems are required to dissolve chitin, which
66 possess poor solubility characteristic due to the numerous inter- and intra-molecular
67 hydrogen bonds between polymeric chains. Only a few solvents have been used for
68 the dissolution of native chitin, such as lithium chloride/dimethylacetamide [21],
69 calcium chloride dihydrate/methanol [22] etc. However, these polar solvents has
70 somewhat alleviated the issues with the biopolymer’s intractability, and the toxicity or
71 corrosivity of these organic components can inhibit batch production and potential
72 applications of the resulting gels. In recent years, people began to use chitosan as raw
73 material to prepare intelligent hydrogels and achieved some interesting results.
74
75 Fig. 1 Chemical structure of chitin and chitosan. Reproduced from ref. 15 with permission from
76 Elsevier, copyright 2004.
77 Today, the chitosan intelligent hydrogels have been widely used in separation and
78 cell culture, tissue engineering, enzyme immobilization, drug-controlled release and
79 targeted drug etc. [23,24]. For this purpose, many new strategies were applied in
80 fabricating hydrogels, such as Layer-by-Layer (LbL) assembly, soft-nanoimprint and
81 electrodeposition [26-28], and various structure with desirable functionalities chitosan
82 hydrogels have been developed. Ladet et al. developed a complex chitosan hydrogels
83 with multi-membrane ‘onion-like’ architectures which formation force were hydrogen
84 bonds, hydrophobic interactions and chitosan crystallites [29]. This physical hydrogel
85 could be used to encapsulate drugs for the co-delivery of multiple therapeutics or
86 pulse-like delivery of a given payload [30]. Encapsulation of chondrocytes and the
3 / 43
View Article Online
DOI: 10.1039/C8NJ03482F
87 delivery of biological therapeutics with thermo-setting chitosan hydrogel was reported

88 by Chenite's group [31], who designed thermally sensitive chitosan/glucose-phosphate
89 salts system which formed monolithic gels at body temperature, several driving forces

90 including hydrogen bonding, electrostatic interactions and hydrophobic interactions
