No.

Date :

DATA SHEET
Three-phase induction motor - Squirrel Cage Motor
Customer : XXX
Product Type : Cast Iron Frame - Standard Efficiency - B3 Mounting

Frame : EM80B-4
Output (kW) : 0.75
Pole : 4
Voltage (V) : 380
Frequency (Hz) : 50
Full Load Speed (RPM) : 1390
Efficiency Class : IE1
Efficiency (%) : 72.1
Design : TEFC
Full Load Rated current (A) : 2.08
Locked rotor current (A) : 12.48
Power factor : 0.76
Full load torque (Nm) : 5.2
Locked rotor torque (Nm) : 11.96
Breakdown torque (Nm) : 11.96
Insulation class : H (300oC in 2 hours)
Temperature rise : B
Max Allowable Starting (secs) : 26
Service factor : 1.00
Duty cycle : S1
Ambient temperature : -20oC-+40oC
Altitude : Up to 1000
Degree of Protection : IP55
Approximate weight (Kg) : 16
Moment of inertia (Kgm2) : 0.003
Noise level (dB) : 56
Cooling : IC411 : Self External Fan, Surface Cooling

Drive End Non Drive End MATERIAL LIST


Bearings 6204 C3 6204 C3 Bearing Brand : DARM
Regreasing interval NA NA Paint Colour : RAL 3028, Pure Red
Grease amount NA NA

Notes :

This is a preliminary technical data sheet for reference purposes.

Prepared by Checked
IE1 TEFC
EM80B-4

Dimension *All dimensions in mm Mounting Type: B3


FOOT MOUNTED DIMENSION

A AA AB AC AD AG B BA BB C D DH E EB ED F G GA H HA K KK L LA LB LD LL M N P S T

125 34 160 155.4 131 94 100 0 130 50 19 M6X16 40 30 5 6 15.5 21.5 80 10 4-Φ10 M20*1.5 284 112 94
