1.
For the type 1 compound truss shown in
Figure 1, determine the force in each member
and state if the members are in tension or
compression. The internal angle between any
two members is 60°. The truss is pin supported
at A and roller supported at F.
2. For the type 2 compound truss shown in
Figure 2, determine the force in each member
and state if the members are in tension or
compression. Trusses ACE and BDF are connected
by three bars, BE, CD, and DE. Dimensions in
meters.
3. Determine the forces in all the members of
the lattice (complex) truss shown in Figure 3
and state if the members are in tension or
compression. Hint: Substitute member JE by one
placed between K and F. Dimensions in meters.
4. For the space truss shown in Figure 4,
determine the force in each member and state
if the members are in tension or compression.
THEORY OF STRUCTURES
Problem Set No. 1b Analysis of Determinate Trusses
Figure 1:
C D
B J K E
A F
I H G
1X.YY kN 1Y.XX kN 7.XY kN
Figure 2:
6X.YY kN 6Y.XX kN
B C
1.XY
D E
45° 45°
A F
1.XY 1.XY 1.XY 1.XY 1.XY
THEORY OF STRUCTURES
Problem Set No. 1b Analysis of Determinate Trusses
Figure 3: L K J
I H 2 x 1.XY
E
G F
1.XY
D
A
B C
1.XY 2 x 1.XY 1.XY
1X.YY kN
Figure 4: y
x
z
THEORY OF STRUCTURES
Problem Set No. 1b Analysis of Determinate Trusses
