Document number

FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147

Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 1 of 16

OBAGI FGRS PROJECT (FEED)

FIRE AND GAS SPECIFICATIONS

This document has been generated by an Electronic Document Management System. When printed it is considered as "For information
only”. The control copy is the screen version, and it is the holder's responsibility that he/she holds the latest valid version.

Rev. Status Date Revision memo Issued by Checked by Approved by

02 AFD 15-DEC-2025 Approved for Design Testimony Aina Afees Olajide Yomi Obaoye

01 AFD 28-NOV-2025 Approved for Design Testimony Aina Afees Olajide Yomi Obaoye

00 IFR 10-NOV-2025 Issued for Review Afees Olajide Testimony Aina Yomi Obaoye

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 1 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 2 of 16

TABLE OF CONTENTS
1.0 INTRODUCTION........................................................................................................................ 4
1.1 Project Overview ................................................................................................................. 4
1.2 Purpose............................................................................................................................... 5
1.3 Scope .................................................................................................................................. 5
1.4 Abbreviations and Definitions ............................................................................................. 6
1.5 Environmental Conditions ................................................................................................... 7
2.0 REFERENCES........................................................................................................................... 8
2.1 Project Documents.............................................................................................................. 8
2.2 Company Documents ......................................................................................................... 8
2.3 Applicable Company’s General Specifications (GS) – 2022 ............................................... 8
2.4 International Standards ....................................................................................................... 9
3.0 SYSTEM OVERVIEW .............................................................................................................. 10
4.0 SYSTEM DESIGN REQUIREMENTS ...................................................................................... 10
4.1 General ............................................................................................................................. 10
4.2 Safety Integrity Level (SIL)................................................................................................ 11
4.3 Fire Zones and Tagging Philosophy ................................................................................. 11
5.0 DETECTION AND ALARM DEVICES ...................................................................................... 12
5.1 Gas Detectors ................................................................................................................... 12
5.2 Flame Detectors................................................................................................................ 12
5.3 Manual Call Points (MACs) ............................................................................................... 12
5.4 Sounders and Beacons..................................................................................................... 12
6.0 FIELD INSTALLATION AND CABLING ................................................................................... 13
6.1 Junction Boxes (JBs) ........................................................................................................ 13
6.2 Cables ............................................................................................................................... 13
6.3 Earthing and Bonding ....................................................................................................... 13
6.4 Cable Routing and Protection ........................................................................................... 13
7.0 INTERFACE WITH ICSS ......................................................................................................... 14

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 2 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 3 of 16

8.0 PASSIVE FIRE AND CORROSION PROTECTION ................................................................ 14

9.0 TESTING AND COMMISSIONING .......................................................................................... 14
10.0 DOCUMENTATION AND DELIVERABLES ............................................................................. 15
11.0 CYBERSECURITY AND SYSTEM RELIABILITY .................................................................... 15
12.0 SPARES AND MAINTENANCE ............................................................................................... 15
13.0 PACKING, STORAGE AND TRANSPORTATION ................................................................... 15
14.0 TRAINING AND HANDOVER .................................................................................................. 16

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 3 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 4 of 16

1.0 INTRODUCTION

1.1 Project Overview

The OML58 is an onshore producing oil and gas asset located approximately 70 km northwest of
Port Harcourt in the eastern Niger Delta, Nigeria. The field was discovered in 1964 near Obagi,
with three appraisal wells drilled in 1972, 1979, and 1984. OML58 currently produces oil and gas
from two fields, Obagi (Ogbogu Flow Station) and Ibewa, with an average oil production of 16
kbopd and average gas production of 10 MSm³/d.
Produced fluids are treated and exported through five facilities:
• Ogbogu Flow Station (3 flares)
• Obite Treatment Center (3 flares)
• Ibewa (2 cold vents)
• Rumuji (1 flare)
• Owaza (1 flare)
At present, the total flaring rate is 90 kSm³/d, with 85% of flaring attributed to Ogbogu Flow
Station (Obagi).
A pre-project study conducted between September 2023 and March 2024 identified early tie-in
and full FGRS tie-in scopes for HP and LLP flares. While the LP flare was initially excluded due
to process stability concerns, the current FEED scope now covers all three flare systems (HP,
LLP, and LP), ensuring a comprehensive solution.
The primary objective of this FEED project is to develop a Closed Flare Gas Recovery System
(FGRS) for OML58, with a focus on the Ogbogu Flow Station. The project shall address the HP,
LLP, and LP flare systems to ensure significant reduction in routine flaring and associated
methane emissions, while enabling compliance with Company and regulatory commitments. The
project business drivers are:
• Reduce routine flaring to <0.1 MSm³/d by 2025
• Achieve zero routine flaring by 2030
• Reduce methane emissions by 50% by 2025 (vs. 2020 baseline)
• Prevent potential shut-in of the fields’ production
• Reduce methane emissions by 80% by 2030 (vs. 2020 baseline)

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 4 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 5 of 16

1.2 Purpose
This specifications defines the technical, design, and functional requirements for the Fire and
Gas System (FGS) associated with the Obagi Flare Gas Recovery System (FGRS) Project at the
Ogbogu Flow Station.
It establishes the design, installation, and integration criteria for all new FGS field devices,
junction boxes, cables, and interfaces, ensuring complete fire and gas protection coverage for the
new FGRS package units (P3 type) and associated piping and tie-ins.
The specification ensures compliance with the TotalEnergies General Specifications (GS, 2022
Edition) and relevant international standards, while ensuring seamless integration with the
existing Integrated Control and Safety System (ICSS), which comprises the PCS, PSS/ESD, and
FGS subsystems.

1.3 Scope
This specifications covers the following:
• Design, engineering, supply, installation, configuration, and testing of Fire and Gas detection
devices and associated equipment for the new FGRS process areas.
• Integration of new FGS field devices and junction boxes with the existing Ogbogu FGS
architecture.
• Specification for flame detectors, gas detectors, manual call points, beacons, sounders,
junction boxes, cables, and earthing systems.
• Interface requirements with PCS, PSS/ESD, and FGS subsystems, in accordance with the
stored ICSS Integration Philosophy – NG-OBA-OGBOGU 81-DORI-070001.
• Testing, commissioning, and functional verification of all new FGS components prior to
handover.
This document does not redefine the existing FGS system architecture except where expansion
is necessary for integration of the new FGRS facilities.

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 5 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 6 of 16

1.4 Abbreviations and Definitions

Table 1.0 Abbreviations and Definitions
CCTV Closed-Circuit Television
C&E Cause and Effect
DED Detailed Engineering Design
DMZ Demilitarized Zone
ESD Emergency Shutdown
FAT Factory Acceptance Test
FCM Flare Closure Mechanism
FEED Front-End Engineering Design
FGRS Flare Gas Recovery System
FGS Fire and Gas System
F&G Fire and Gas
HP High Pressure
ICSS Integrated Control Safety System
IEC International Electrotechnical Commission
I/O Input / Output
JB Junction Box
IP Ingress Protection
IR Infrared
ISA International Society of Automation
ISO International Organization for Standardization
LP Low Pressure
LLP Low-Low Pressure
LSZH Low Smoke Zero Halogen
MAC Manual Call Point
PAGA Public Address and General Alarm
PCS Process Control System
PLC Programmable Logic Controller
PSS Process Safety System

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 6 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 7 of 16

UCP Unit Control Panel

UV/IR Ultraviolet and Infrared
SAT Site Acceptance Test
SIL Safety Integrity Level
SIS Safety Instrumented System
TCP/IP Transmission Control Protocol / Internet Protocol

1.5 Environmental Conditions

The environmental design parameters for the Ogbogu Flow Station are as follows:
Table 2.0 Environmental Conditions
Parameter Design Basis
Ambient Temperature 15°C to 45°C

Relative Humidity Up to 100%

Wind Speed 45 m/s (gusts)

Altitude <100 m above sea level

Hazardous Area Classification Zone 1 and Zone 2

Corrosion Environment Severe (C5-M)

Protection IP65 minimum

Materials Corrosion-resistant, UV-stable, suitable for tropical

onshore environment

All F&G field devices shall be suitable for outdoor, corrosive, and hazardous environments,
compliant with GS EP INS 106, and relevant ATEX/IECEx certification requirements.

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 7 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 8 of 16

2.0 REFERENCES
Reference is made to the following documents and drawings in the respective actual version:

2.1 Project Documents

Table 3.0 Project Documents

S/N Document No Title

Overall Instrumentation & Control System
1 NG-OBG-40-ARSH-400117
Philosophy
2 NG-OBG-40-ARSH-400119 General Instrumentation Specifications
3 NG-OBG-40-ARSH-400118 ICSS Modifications Specifications
4 NG-OBG-40-ARSH-400146 Fire and Gas Detection Philosophy

2.2 Company Documents

Table 4.1 Company Documents

S/N Document No Title

ICSS Integration Philosophy – Impact on Existing
1 NG-OBA-OGBOGU 81-DORI-070001
ICSS Assessment

2.3 Applicable Company’s General Specifications (GS) – 2022

Table 5.3 General Specifications - 2022

S/N Document No Title

1 GS EP INS 106 Instrument Installation
2 GS EP INS 115 Instrument Earthing
4 GS EP INS 116 Instrument Cables
5 GS EP INS 134 Design and Supply of Integrated Control and Safety Systems (ICSS)
6 GS EP INS 135 Cybersecurity Requirements for Industrial Information Systems
7 GS EP INS 143 Fire and Gas Detectors and Associated Detection Systems
8 GS EP SAF 312 Fire and Gas Detection Systems
9 GS GR HSE 303 Area Classification of Potentially Explosive Atmospheres
Design of earthing and bonding systems and lightning protection for
10 GS EP ELE 032
Onshore Installations

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 8 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 9 of 16

11 GS EP ELE 311 Cable Trays Ladder

12 GS GR HSE 306 Safety Integrity Level (SIL) Assignment
13 GS GR HSE 314 Fire and Gas Detection – Design Requirements
14 GS GR HSE 315 Passive Fire Protection – Design Requirements
15 GS EP COR 354 External Protection of Onshore Structures and Equipment by Painting
16 GS EP COR 771 Thermal Insulation (Hot and Dual Services)

2.4 International Standards

Table 6.4 International Standards

S/N Document No Title

1 IEC 60079 Series Electrical Equipment in Hazardous Areas
Functional safety of electrical / electronic / programmable
2 IEC 61508
electronic safety-related systems
Functional safety - Safety instrumented systems for the
3 IEC 61511
process industry sector
4 NFPA 72 National Fire Alarm and Signalling Code
5 ISO 7240 Fire Detection and Alarm Systems

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 9 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 10 of 16

3.0 SYSTEM OVERVIEW

The FGS is an integral subsystem of the existing ICSS at Ogbogu FS.
It provides detection, alarm, and mitigation functions for fire and gas hazards across process
areas.
For the Obagi FGRS Project, the FGS scope covers the new HP, LP, and LLP Flare Gas
Recovery Packages (P3 type) and associated Flare Closure Mechanism (FCM), tie-in piping, and
open process areas.
Each FGRS package includes a Unit Control Panel (UCP) for local control and safety
management, interfacing with the FGS and ICSS subsystems as follows:

Subsystem Interface Type Description

Alarm annunciation, status monitoring, and

PCS Modbus TCP/IP
FGRS equipment status

PSS/ESD Hardwired Shutdown, isolation, and permissive signals

FGS Hardwired / Ethernet Detector inputs, alarm loops, and alarm initiation

Deluge initiation, firewater valve actuation, and

Firewater System Hardwired / Modbus
pump start

Security / CCTV Ethernet Camera activation upon fire/gas alarm

Integration philosophy shall conform to the ICSS Integration Philosophy – NG-OBA-OGBOGU

81-DORI-070001.

4.0 SYSTEM DESIGN REQUIREMENTS

4.1 General
• The FGS design shall conform to GS GR HSE 314 and GS EP INS 143 for detection
coverage, zoning, and functional performance.
• The design shall ensure no single point of failure results in loss of fire and gas protection.
• Detection layout and coverage shall be based on Fire Zone risk assessment, consistent with
the existing Ogbogu FS Fire Zone Philosophy.
• The FGS extension shall utilize existing FGS logic solvers and marshalling panels, with
additional I/O only where required.

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 10 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 11 of 16

• Equipment shall comply with GS GR HSE 303 and IEC 60079 for hazardous area
classification and certification.

4.2 Safety Integrity Level (SIL)

• FGS detection and mitigation loops shall meet minimum SIL 2 reliability as per GS GR HSE
306 and IEC 61511.
• SIL classification, validation, and proof-test intervals shall be defined and recorded within the
SIL demonstration documentation and associated Performance Standards for each Safety
Instrumented Function (SIF).
• Safety lifecycle documentation, including reliability analysis and verification results, shall be
maintained and made available for Company review.

4.3 Fire Zones and Tagging Philosophy

• The new FGRS process units (HP, LP, and LLP compressor packages, Flare Closure
Mechanism, and associated piping manifolds) shall each be assigned dedicated Fire Zones,
except where equipment is located in close proximity or falls entirely within an existing Fire
Zone.
• Fire Zone classification and boundary definition shall be carried out during FEED in
accordance with GS GR HSE 314 and GS GR HSE 303, ensuring each zone reflects the
specific fire and gas risk potential of the covered area.
• Where Fire Zones are newly created or extended, their numbering and identification shall
follow the existing Ogbogu FS Fire Zone Tagging Philosophy, maintaining continuity with the
facility’s FGS database and cause-and-effect logic.
• All new detectors, alarm devices, and FGS field equipment shall be tagged according to the
existing site tagging convention.
• Fire Zone boundary updates shall be validated jointly by the Contractor and Company during
FEED and recorded in the updated Fire and Gas Detection Layouts, Zoning Drawings, and
Cause & Effect Matrix.

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 11 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 12 of 16

5.0 DETECTION AND ALARM DEVICES

5.1 Gas Detectors

• Gas detectors shall comply with GS EP INS 143 and GS GR HSE 314.
• Detectors shall be infrared or catalytic type, suitable for hydrocarbon gas monitoring in open
process environments.
• Each detector shall provide 4–20 mA with HART output, local indication, and fault
supervision.
• Installation areas: compressor skids, manifolds, flare closure assemblies, and vent piping.
• Detectors shall be Ex d / Ex e certified and IP65 minimum.

5.2 Flame Detectors

• Flame detectors shall be multi-spectrum IR or UV/IR type, certified for SIL 2 applications, self-
testing, and compliant with GS EP INS 143.
• Locations: compressor discharge, flare valve area, and gas-handling equipment.
• Devices shall be immune to false alarms from sunlight and welding.

5.3 Manual Call Points (MACs)

• Explosion-proof, non-addressable type.
• Installed at all FGRS unit entry points and accessible locations along escape routes.
• MACs shall be installed on large plates located on instrument stands. Plates shall be painted
diagonally red/white to clearly identify the call point.

5.4 Sounders and Beacons

• Sounders and beacons shall be installed to ensure acoustic and visual coverage across the
FGRS Fire Zones.
• Additional outdoor sirens/beacons shall be installed only where existing alarms do not provide
full coverage.
• Minimum sound level: 85 dB(A) above ambient; beacons shall be visible up to 30 meters.
• Each device shall be linked to the relevant Fire Zone alarm logic.

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 12 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 13 of 16

6.0 FIELD INSTALLATION AND CABLING

6.1 Junction Boxes (JBs)

• JBs shall be 316L stainless steel, IP66-rated, Ex e/Ex d certified, in accordance with GS EP
INS 106.
• Dedicated JBs shall be provided for FGS signals and labeled per existing facility tagging
philosophy.
• Terminal identification and glanding per GS EP INS 106.
• Junction boxes shall be installed on adequately fabricated supports and shall be at a
maximum height of 1.80 meters from the top of the Junction Box to grade or platform.

6.2 Cables
• All cables shall comply with GS EP INS 116.
• Use low smoke, zero halogen (LSZH), fire-rated cables.
• Minimum conductor size: 1.5 mm² for signal circuits, 2.5 mm² for power.
• Use twisted, shielded pairs for detector loops.

6.3 Earthing and Bonding

• Earthing shall comply with GS EP INS 115 and GS EP ELE 032.
• Provide separate instrument and safety earths.
• Cable screens to be grounded at marshalling end only.

6.4 Cable Routing and Protection

• Cable routing shall follow GS EP ELE 311.
• Existing routing systems shall be reused wherever technically and physically feasible,
provided they comply with project design, integrity, and safety requirements.
• Where reuse is not feasible, new routing systems shall be installed in accordance with GS EP
ELE 311 and project standards.
• Cable trays and supports shall have anti-corrosion coating per GS EP COR 354 and thermal
protection per GS EP COR 771.

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 13 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 14 of 16

7.0 INTERFACE WITH ICSS

• All new FGS signals shall terminate in existing FGS marshalling panels.
• Alarm and trip signals exchanged with PCS (Modbus TCP/IP) and PSS/ESD (hardwired).
• Firewater System interface shall trigger deluge valves and fire pump start where applicable.
• Communication security shall follow GS EP INS 135 cybersecurity architecture and DMZ
segregation.
• All interfaces shall conform to GS EP INS 134 ICSS integration requirements.

8.0 PASSIVE FIRE AND CORROSION PROTECTION

• Structural supports, instrument racks, and trays within Fire Zones shall have PFP coatings as
per GS GR HSE 315.
• Metallic equipment and junction boxes shall receive anti-corrosion coatings as per GS EP
COR 354.
• Thermal insulation for nearby hot surfaces shall comply with GS EP COR 771, ensuring non-
flammable and low-toxicity materials.

9.0 TESTING AND COMMISSIONING

• Factory Acceptance Test (FAT): Validate detector function, output, and alarm logic per GS
EP INS 143.
• Site Acceptance Test (SAT): Confirm proper field installation, address configuration, and
integration with existing FGS.
• Loop and Continuity Testing: Verify continuity, polarity, and insulation resistance for all
circuits.
• Cause and Effect Verification: Perform full FGS logic validation as per approved C&E
Matrix.
• All testing shall align with IEC 61511 safety validation standards.

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 14 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 15 of 16

10.0 DOCUMENTATION AND DELIVERABLES

Contractor shall provide:
• FGS layout and Fire Zone drawings.
• Detector and alarm device lists with tag numbers.
• Updated zoning diagrams and cause & effect charts.
• JB wiring and loop diagrams.
• FAT/SAT procedures and reports.
• Calibration certificates and as-built documentation.

11.0 CYBERSECURITY AND SYSTEM RELIABILITY

• All FGS interfaces shall conform to GS EP INS 135.
• Implement role-based access control, audit trails, and patch management.
• Minimum system availability: 99.9% with redundancy for logic solvers and power supplies.

12.0 SPARES AND MAINTENANCE

• Provide 10% spare detectors of each type.
• Minimum 20% spare I/O capacity in FGS marshalling panels, if new I/O card required.
• 10% spare terminals in each JB.
• Detectors shall include self-testing capability.
• Provide spare calibration kits and consumables.

13.0 PACKING, STORAGE AND TRANSPORTATION

• All Fire and Gas detection devices, junction boxes, cables, and accessories shall be packed,
handled, and stored in accordance with the manufacturer’s recommendations and GS EP INS
143, section 10 and GS EP INS 106.
• Equipment shall be vacuum-sealed or moisture-proof packed to prevent condensation and
corrosion during transport and long-term storage.
• Packing shall be designed to protect against vibration, impact, and mechanical damage,
ensuring full preservation of IP rating during shipping and handling.

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 15 of 16
 Document number
FIRE AND GAS SPECIFICATIONS NG-OBG-40-ARSH-400147
Revision: 02 Rev Date : 15-DEC-25
Document Type: SPE System / Subsystem: NN Discipline: INS Doc Class: 1 Status: AFD
Phase: FE NG-OBG-40-ARSH-400147 Page 16 of 16

• Temporary electrical or cable entry points shall be sealed or plugged to maintain enclosure
protection integrity.
• Each package shall include a detailed packing list, clearly stating tag number, item
description, gross/net weight, handling instructions, and storage conditions.
• Sensitive electronic components, such as flame and gas detectors, shall be individually
wrapped in anti-static, shock-absorbing material, with protective dust caps installed on sensor
heads.
• Spare parts shall be separately packed and clearly labeled.
• All items shall be suitable for storage in tropical humid environments for at least 12 months
without degradation.
• During construction, unpacked instruments shall be protected from dust, moisture, and
contamination, using approved covers or greasing where applicable.
• Transportation and handling shall comply with GS EP INS 106 to avoid damage or
misalignment.
• Any equipment found damaged upon receipt or during storage shall be quarantined,
inspected jointly with Company, and replaced at no cost to the project.

14.0 TRAINING AND HANDOVER

• Provide detailed training to operators and maintenance staff covering operation,
troubleshooting, and C&E logic interpretation.
• Handover documentation shall include training records, calibration data, FAT/SAT reports,
and all as-built documentation.

“This document is the property of TEPNG. It must not be reproduced or transmitted to others without written authorization
from the Company”

Page 16 of 16
