Contents :
• Six Sigma : An Overview
• What is Six Sigma?
• Why Six Sigma?
• Six Sigma Phases : Define, Measure, Analyze,
Improve and Control
• Tools and Key Roles for Six Sigma
www.exploreHR.org 3
Why Six Sigma?
www.exploreHR.org 4
What is Sigma ?
www.exploreHR.org 5
What is Six Sigma?
www.exploreHR.org 6
Sigma Level
Sigma Level Defects per Million
(Process Opportunities
Capability)
2 308,537
3 66,807
4 6,210
5 233
6 3.4
www.exploreHR.org 7
Sigma Level
Six Sigma =
99,9997%
www.exploreHR.org 8
Sigma Level
• Every hour the postal service
Why not Four would lose 20,000 pieces of mail
Sigma or • Every day our drinking water would
99.379% ? be unsafe for almost 15 minutes
• Every week there would be 5,000
surgical operations that go wrong
in some way
• Every month we would be without
electricity for almost seven hours
www.exploreHR.org 9
Why Six Sigma?
Money Quality
Customer Competitive
Satisfaction Advantage
www.exploreHR.org 10
Why Six Sigma?
www.exploreHR.org 11
Why Six Sigma?
www.exploreHR.org 12
Cost of Poor Quality
www.exploreHR.org 13
Cost of Poor Quality
What is cost of business lost because
customers are dissatisfied with your
products or services?
www.exploreHR.org 14
Critical-to-Quality (CTQ)
Elements of a process that significantly affect
the output of that process. Identifying these
elements is figuring out how to make
improvements that can dramatically reduce
costs and enhance quality.
www.exploreHR.org 15
Six Sigma Phases
www.exploreHR.org 16
Six Sigma Phases
Improve
DMAIC Control
www.exploreHR.org 17
Six Sigma Phases
Define the project goals and customer
Define (internal and external) deliverables
www.exploreHR.org 19
Six Sigma Phases
• Define Customers and Requirements (CTQs)
Define • Develop Problem Statement, Goals and
Benefits
• Identify Champion, Process Owner and Team
• Define Resources
• Evaluate Key Organizational Support
• Develop Project Plan and Milestones
• Develop High Level Process Map
www.exploreHR.org 20
Six Sigma Phases
• Define Defect, Opportunity, Unit and Metrics
Measure • Detailed Process Map of Appropriate Areas
• Develop Data Collection Plan
• Validate the Measurement System
• Collect the Data
• Begin Developing Y=f(x) Relationship
• Determine Process Capability and Sigma
Baseline
www.exploreHR.org 21
Six Sigma Phases
• Define Performance Objectives
Analyze • Identify Value/Non-Value Added Process
Steps
• Identify Sources of Variation
• Determine Root Cause(s)
• Determine Vital Few x's, Y=f(x)
Relationship
www.exploreHR.org 22
Six Sigma Phases
• Perform Design of Experiments
Improve • Develop Potential Solutions
• Define Operating Tolerances of Potential
System
• Assess Failure Modes of Potential
Solutions
• Validate Potential Improvement by Pilot
Studies
• Correct/Re-Evaluate Potential Solution
www.exploreHR.org 23
Six Sigma Phases
• Define and Validate Monitoring and Control
System
Control
• Develop Standards and Procedures
• Implement Statistical Process Control
• Determine Process Capability
• Develop Transfer Plan, Handoff to Process
Owner
• Verify Benefits, Cost Savings/Avoidance, Profit
Growth
• Close Project, Finalize Documentation
• Communicate to Business, Celebrate
www.exploreHR.org 24
Define Measure Analyze Improve Control
Deliverables :
• Fully trained team is formed, supported, and
committed to work on improvement project.
• Team charter developed, customers identified and
high impact characteristics (CTQs) defined, business
process mapped.
www.exploreHR.org 25
Define Measure Analyze Improve Control
Team Charter :
• Completed project management charter, including business case,
problem and goal statements, project scope, milestones, roles and
responsibilities, communication plan.
www.exploreHR.org 26
Define Measure Analyze Improve Control
Deliverables :
• Key measures identified, data collection planned and
executed, process variation displayed and communicated,
performance baselined, sigma level calculated.
www.exploreHR.org 28
Define Measure Analyze Improve Control
www.exploreHR.org 29
Define Measure Analyze Improve Control
www.exploreHR.org 30
Define Measure Analyze Improve Control
Deliverables :
• Data and process analysis, root cause analysis,
quantifying the gap/opportunity.
www.exploreHR.org 31
Define Measure Analyze Improve Control
www.exploreHR.org 33
Define Measure Analyze Improve Control
Deliverables :
• Generate (and test) possible solutions, select the best
solutions, design implementation plan.
www.exploreHR.org 34
Define Measure Analyze Improve Control
www.exploreHR.org 35
Define Measure Analyze Improve Control
www.exploreHR.org 37
Define Measure Analyze Improve Control
Deliverables :
• Documented and implemented monitoring plan,
standardized process, documented procedures, response
plan established and deployed, transfer of ownership
(project closure).
www.exploreHR.org 38
Define Measure Analyze Improve Control
Process Standardization
• New process steps, standards, and documentation are ingrained into
normal operations.
Documented Procedures
• Operating procedures are consistent.
• Knowledge gained on process is shared and institutionalized.
www.exploreHR.org 39
Define Measure Analyze Improve Control
www.exploreHR.org 40
Tools and Roles for
Six Sigma
www.exploreHR.org 41
Tools for Six Sigma
• Creating flowcharts of the step in a process
Process
– operations, decision points, delays,
Mapping
movements, handoffs, rework, loops, and
controls or inspections.
• A process map is illustrated description of
how a process work.
www.exploreHR.org 42
Tools for Six Sigma
• DOE is a structured, organized method for
Design of
determining the relationship between
Experiments
factors (Xs) affecting a process and the
or DOE
output of that process (Y).
www.exploreHR.org 43
Tools for Six Sigma
• A group of rows and columns, with one set
XY Matrix
of increments marked along the X
(horizontal) axis and another set of
increments marked along the Y (vertical)
axis.
• The purpose of using XY matrix is to study
and understand the relationship between
what you are putting into a process and
what your customer is getting out of it.
• The XY matrix allows the team to identify
gaps, areas for improvement.
www.exploreHR.org 44
Tools for Six Sigma
• The goal of this tool is to ensure that your
Measurement
measurement system is statically confident System
– that it’s both accurate and precise each Analysis
and every time it is used.
• Undertaken during Measure phase, your
MSA determines whether or not you can
take a certain measurement and repeat or
reproduce it among different people who
take the same measurement.
www.exploreHR.org 45
Tools for Six Sigma
• Process capability tool is the measure of a
Process
process being able to meet specification Capability
requirements and fulfill customer CTQ Tool
needs on a long term basis.
www.exploreHR.org 46
Tools for Six Sigma
• Investigating a theory about the suspected
Hypothesis
cause (s) of a particular effect in a process
Testing
to determine if it is correct.
• It’s a compass that points you directly to
the vital few factors that are most affecting
your process.
www.exploreHR.org 47
Tools for Six Sigma
• The manner in which a part or process can
Failure
fail to meet a specification, creating a
Mode Effect
defect or non-conformance, and the impact
Analysis
on the customer if that failure mode is not
prevented or corrected.
www.exploreHR.org 48
Tools for Six Sigma
• A detailed assessment and guide for
Control
maintaining all the positive changes you,
Plan
your black belt, and the project team have
made.
• It ensures that all your analysis and efforts
stay in effect and that you have information
at your disposal to prevent backsliding or a
return to less than optimal performance
standard.
www.exploreHR.org 49
Key Roles for Six Sigma
Executive Includes CEO and other key top management
Leadership team members. They are responsible for setting
up a vision for Six Sigma implementation.
www.exploreHR.org 50
Key Roles for Six Sigma
Master Identified by champions, act as in-house expert
Black Belts coach for the organization on Six Sigma. They
devote 100% of their time to Six Sigma.
www.exploreHR.org 51
Key Roles for Six Sigma
Green Belts Are the employees who take up Six Sigma
implementation along with their other job
responsibilities. They operate under the guidance
of Black Belts and support them in achieving the
overall results.
www.exploreHR.org 52
Six Sigma Do’s
www.exploreHR.org 53
Six Sigma Do’s
• Do benchmark
www.exploreHR.org 54
Recommended Further Readings:
2. George Eckes, Six Sigma for Everyone, John Wiley and Sons
