Product Catalog

Remote Terminal Units

RTU560/RTU211

Remote control products

2012/2013

New remote control product catalog

Dear Madam and Sir,
this Catalog will give you an overview of our remote terminal units (RTU) product portfolio. The products are divided into the
categories rack RTU and DIN rail RTU. The catalog will inform you about each single module and its possible additional
material.
ABB ist working for more than 40 years successful in the area of remote control applications and offers the security of a strong
and experienced partner. Worldwide presence with local partners in almost all regions allows quick access to support and
service.
With more than 50.000 installed remote terminal units (RTUs) at around 2.000 customers in more than 100 countries, ABB is
world market leader for medium and large RTU applications.
For more information please ask your local sales and service contact or visit us at www.abb.com/substationautomation.
Yours sincerly,
RTU-Team

Dr. Ditmar Heinz

Global product line manager RTU

2 Welcome | ABB remote control products

Sigbert Reimann
Global product manager RTU

Helmut Weber
Global sales manager RTU

Remote control products

Content

Remote terminal units

Overview
The products ............................................................................................................................. 4
Applications ............................................................................................................................... 6
Trends in remote control ........................................................................................................... 7

Rack RTUs
RTU560 for rack mounting ........................................................................................................ 8
Racks .................................................................................................................................... 10
Power supply units .............................................................................................................. 14
Communication units (CMUs) ............................................................................................. 15
Rack inputs/outputs (I/Os) ................................................................................................... 16
Serial communication ........................................................................................................... 19
Ethernet communication ...................................................................................................... 22
Real time clocks ................................................................................................................... 24

DIN rail RTUs

Compact RTUs ........................................................................................................................ 26
RTU560 CMUs with xed housing ....................................................................................... 28
RTU211 CMUs with exible housing ................................................................................... 31
Power supply exible housing ............................................................................................. 32
Power supply xed housing ................................................................................................. 33
I/Os with xed housing......................................................................................................... 35
I/Os with exible housing ..................................................................................................... 39
Multi meters .......................................................................................................................... 42
Multi meters with fault current detection (FCD) .................................................................. 43
Serial communication ........................................................................................................... 44
Ethernet communication ...................................................................................................... 45
I/O adapter for exible housing ........................................................................................... 46

Licences
Basic License........................................................................................................................ 47
PLC/Archive License ............................................................................................................ 47
HMI License .......................................................................................................................... 47

PC Tools
COMPROTware Tool ........................................................................................................... 48
ITT600 SA Explorer ............................................................................................................... 48
RTUtil560............................................................................................................................... 48
RTUtil61850........................................................................................................................... 48
MULTIPTOGwt ...................................................................................................................... 48
IET600 ................................................................................................................................... 48

ABB remote control products | Content 3

Remote control products

Overview

The products
The flexible and modular designed RTU provides a complete solution with a wide variety of integrated functions. Thanks to the
multiplicity of possible combinations in terms of modules, the RTU presents a high degree of scalability. This allows perfect
adaptation not only for station reinforcement, but also for retrofit and new installations.
The open architecture of the RTU supports the use in different applications. Future functional and quantitative extensions are
easy to realize at anytime through hardware or software upgrade for various applications which makes the RTU offer a cost
saving investment. The RTU560/RTU211 family offers an integrated Human Machine Interface (HMI) functionality, PLC functions
and network components in one RTU system which makes it unbeatable in terms of competitiveness.
Functional elements
Flexible footprint: 19 rack, half size rack or DIN rail design, in combination with different communication modules, provide
the perfect fit for your application.
Advanced communication: Communication racks with multi-processor architecture, integrated modems and network
modules.
Scalable in- and outputs: Solutions for small feeder RTUs up to complex and large substation RTUs
Integrated cyber security features
Superior redundancy concept adaptable to different availability requirements
Efficient data engineering: Easy use of MS-Excel sheets for data engineering and for data import and export
Time synchronization
Rugged design for substations and harsh environmental conditions
Applicable for electrical applications from medium to extra- high voltage
Including support of non electrical application like gas, oil, water, waste water and district heating
Supports a lot of modern international and third party tele-control communication protocols
Solution using IEC 61850 station bus for new business, retrofit and/or partial upgrades

4 Overview | ABB remote control products

Remote control products

Overview

Product lines
Rack
RTU solution for huge and medium applications for transmission/sub transmission and distribution
The swing frame and mounting plate rack expand the flexibility of the RTU560 rack based solution
Fully flexible sub racks for communication units (CMUs)
and I/Os with redundancy support
19 and short versions
Sub racks for cost efficient solutions
Wide abilities to interface with host systems and sub devices

DIN rail
Excellent solution for smart grid applications and feeder
RTUs
Compact RTU560 DIN rail and remarkable cost-effective
RTU211 DIN rail solution
Minimized installation efforts
Directional fault current detection (optional)
Extendable with different I/O modules

ABB remote control products | Overview 5

Remote control products

Applications
One solution suitable for various applications
The open architecture of the RTU supports adaptation to different applications. Future functional and quantitative extensions
are easy to realize at anytime through hardware or software upgrade for various applications:

Transmission / sub transmission

Distribution automation
Smart grids
Feeder automation
Oil, gas and petrochemicals
Railways
As well as other non-electrical applications

6 Applications | ABB remote control products

Remote control products

Trends in remote control
Constant change of technology
Smart meters
The large deployment of smart meters and its required communication infrastructure open the possibility to apply smart
meters for the operation of the grid. Traditionally energy metering and network control have been separated. Its integration
provides several opportunities of optimization, e.g. the usage
of the same communication infrastructure to use meter data
for grid optimization and control.
Process bus IEC 61850
The wide acceptance of the IEC 61850 station bus in the industry points the direction towards the future. IEC 61850 will
be deployed towards the process bus. Primary equipment will
be enabled with even more intelligent technology and provide
TCP/IP based process information. Secondary equipment will
be interfaced directly to the IEC 61850 process bus.

Automated grid balancing

In the future the grid needs to be operated closer to its limits
since decentralized generation creates local bottle necks in
the distribution. Grid enforcements will not be possible due to
environmental and economic reasons. Grid automation is inevitable as operators and service technicians have larger areas
to deal with. Therefore a higher degree of automated actions
is required to ensure grid stability. The automation of these
actions in a peer to peer architecture is necessary to unburden the operators and unload communication networks.

E-mobility
E-mobility projects are constantly announced throughout the
world. Consequently the impact towards grid operation is
inescapable. The management of the charging stations, the
demand management and the energy storage will be a future
task of the grid operation. Providing technology for monitoring and control of the charging stations poses technical and
economical challenges to the grid operators and technology
provider.

ABB remote control products | Trends in remote control 7

Rack RTUs
RTU560 for rack mounting
RTU solution for huge and medium applications for transmission/sub transmission and distribution automation
In order to achieve a cost efficient solution for requirements of different applications, swing frame or mounting plate rack solutions can be used. They can be realized as pure communication racks, pure I/O racks or a combination of both. Higher system
availability can be achieved by using redundant power supply, redundant communication and redundant CMUs for each rack.
The RTU560 rack based solution with its scalable platform and its highly advanced communication capabilities allows ABBs
RTU to communicate to various sub RTUs, IEDs and control centers at the same time.
The RTU560 short rack together with a wide range of communication interfaces, e.g. fiber and copper solutions as well as
radio, GSM/GPRS etc. meets the requirements for distribution applications. The compact dimension makes it an adequate
solution for applications with space restrictions.

RTU solution for huge and medium applications for transmission/sub transmission and distribution
The swing frame and mounting plate rack expand the flexibility of the RTU560 rack based solution
Fully flexible sub racks for communication units (CMUs) and I/Os
With redundancy support
19 and short versions of racks
Sub racks for cost efficient solutions
Wide abilities to interface with host systems and sub devices

8 RTU rack family | ABB remote control products

Rack RTUs
RTU560 for rack mounting
Product family

Racks
560MPR01 p.10

560MPR03 p.11

560SFR02 p.12

Power
supply units
560PSU01 p.14

560PSU02 p.14

560CMU02 p.15

560CMU05 p.15

Rack CMUs

Rack I/Os

23BE23 p.16

23BA20 p.16

23BA23 p.17

23AE23 p.17

23AA21 p.18

23WT24 p.20

23WT25 p.21

Serial
communication
23OK24 p.19

23WT23 p.19

25LU40 p.20

560NUS04 p.22

560NUS12 p.22

560NMS24 p.23

560RTC01 p.24

560RTC02 p.24

560RTC03 p.25

Ethernet
communication
560NMS34 p.23

Real time
clocks

ABB remote control products | RTU rack family 9

Rack RTUs
Racks
Rack with 9 slots, wall mounted
Application
The Mounting Plate Rack 560MPR01 accommodates up to two
communication units 560CMU02 or 560CMU05 and up to 8 peripheral modules in a RTU560 substation. One additional (extension) mounting plate rack can be connected to the 560MPR01 via
the serial RTU560 system bus.

560MPR01
1KGT012500R0001

Description
Mounting panel for RTU with plug for serial peripheral bus 8/7 slots for peripheral modules, 1/2slots for
560CMU02/05 (23XS20 not included).

Additional material:

Bus connection unit for 23TP22 / 560MPR01

560BCU02
R0001

Alarm and warning contacts

Minute pulse in- and output

1KGT007900R0001

Process-connector 2-/17-/19-pole 23TP22/ 560MPR03/01

23XS20R0019
19-pole connector with screw-terminals AWG12 for process
connections to the I/O modules on 23TP22/ 560MPR03/01
(one connector per module); 100 pcs per package

1KGN000556R0019

23XS20 R0017
1KGN000556R0017

17-pole connector with screw-terminals AWG12 for process
1KGN000556R0002

connections to the I/O modules on 23TP22/ 560MPR03/01

(one connector per module); 100 pcs per package
23XS20
R0002

2-pole connector with screw-terminals AWG12 for process

connections to the I/O modules on 23TP22/ 560MPR03/01

100 pcs per package
Blanking front plate

1KGT007700R0001

10 Racks | ABB remote control products

23VF2R0001
Frontplate: light beige, plastic
Blanking front plate to cover free slots within a module
subrack (1slot; with ABB LOGO grip)
Incl. screws
100 pcs per package

Rack RTUs
Racks
Mounting panel for redundant power supply
Application
The 560MPR03 rack is designed to be used with or without
redundant power supply. Therefore, it has 2 slots for redundant
power supply units (PSU) and 17 slots that can be used for I/O
boards, communication units (CMU) or a mixture of both. It is interfaced to other racks via the RTU560s serial peripheral bus. Up
to 7 560MPR03 racks can be connected to a I/O Bus segment.
By using the bus connection unit 560BCU04, the 560MPR03 becomes a rack with up to eight communication units (560CMU05/
560CMU02R2).
560MPR03
1KGT022100R0001

Description
With flexible configuration for I/O, CMU and power
supply (23XS20 not included).

Also for applications with only one communication unit the usage
of 560BCU04 is required. The rack 560MPR03 is mounted on a
mounting plate in a cubicle.
Only in slot 19 the second PSU can be inserted and will be
operated. It is not allowed to put in other modules. Slot 18 is
available, when the option of the second PSU is not used.

Additional material:
Bus connection unit for 560MPR03 (Basic and Extension)

560BCU04R0001 (Basic)

Alarm and warning contacts

Minute pulse in- and output

For 2 units 560CMU0x (one basic unit, one extension unit)

1KGT022300R0001
1KGT022300R0002

560BCU04R0002 (Extension)

Extension kit for 10 additional 560CMU0x

Process-connector 2-/17-/19-pole 23TP22/ 560MPR03/01

23XS20R0019
19-pole connector with screw-terminals AWG12 for process
connections to the I/O modules on 23TP22/ 560MPR03/01
(one connector per module); 100 pcs per package

1KGN000556R0019

23XS20
R0017
1KGN000556R0017

17-pole connector with screw-terminals AWG12 for process
1KGN000556R0002

connections to the I/O modules on 23TP22/ 560MPR03/01

(one connector per module); 100 pcs per package

23XS20
R0002

2-pole connector with screw-terminals AWG12 for process

connections to the I/O modules on 23TP22/ 560MPR03/01

100 pcs per package
Blanking front plate

1KGT007700R0001

23VF21R0001
Frontplate: light beige, plastic
Blanking front plate to cover free slots within a module
subrack (1slot; with ABB LOGO grip)
Incl. screws
100 pcs per package

ABB remote control products | Racks 11

Rack RTUs
Racks
19 Swing frame rack for optional redundant power supply
Application
The 560SFR02 rack is designed to be used with or without
redundant power supply. Therefore, it has 2 slots for redundant
power supply units (PSU) and 17 slots that can be used for I/O
boards, communication units (CMU) or a mixture of both.
It is interfaced to other racks via the RTU560s serial peripheral
bus. Up to 7 560SFR02 racks can be connected to a system. By
using the bus connection unit 560BCU05, the 560SFR02 becomes a rack with up to eight communication units (560CMU05/
560CMU02R2). Also for applications with only one communication unit the usage of 560BCU05 is required. It is installed in a
swing frame cabinet or in a frame.

560SFR02
1KGT022200R0001

Description
With flexible configuration for I/O, CMU and power
supply

Additional material:

Only in slot 19 the second PSU can be inserted and will be

operated. It is not allowed to put in other modules. Slot 18 is
available, when the option of the second PSU is not used.

Bus connection unit for 560SFR02 (Basic and Extension)

560BCU05R0001 (Basic)
Alarm and warning contacts
Minute pulse in- and output

For 2 units 560CMU0x (one basic unit, one extension unit)

1KGT022400R0001
1KGT022400R0002

560BCU05R0002 (Extension)

Extension kit for 10 additional 560CMU0x

Process-connector-housing 23ET24 / 560SFR02

23XS40R1001
18-pole plug for connectors of 23ET24/ 560SFR02
(housing only, without snap-in-contacts)

100 pcs per package

1KGN000758R1001

Snap-in-contacts for 23XS40R1001

23XS40R2001

Snap-in-contacts for 23XS40R1001 (18 contacts per plug required)

500 pcs per package

1KGN000758R2001

12 Racks | ABB remote control products

Rack RTUs
Racks

Additional material:

Crimp-Tool for 23XS40R2001

23XS41R0001

Tool to connect wires to snap-in-contacts (23XS40R2001)

1KGN000797R0001

Removal Tool for Snap-In contacts

23XS42R0001

Tool to extract snap-in-contacts (23XS40R2001)

1KGN000798R0001

Removal Tool for Process connector 23XS40R1001

23XS43R0001

Tool to remove connector housing 23XS40R1001 from subrack

23ET24/ 560SFR02

1KGN000799R0001

Blanking front plate

23VF21R0001
Frontplate: light beige, plastic
Blanking front plate to cover free slots within a module

subrack (1slot; with ABB LOGO grip)
Incl. screws

1KGT007700R0001
100 pcs per package

ABB remote control products | Racks 13

Rack RTUs
Power supply units

560PSU01
1KGT006600R0001
1KGT006600R0002

Description
Power supply unit for RTU560 racks
Input voltage 24...60 V DC or 110...220 V DC
Output voltage: 5 and 24 V DC

Power supply unit for RTU560, 24...60 V DC, 44,3W (R0001) /

110...220 V DC, 44,3W (R0002)
Application
The power supply unit 560PSU01 generates the two supply voltages (5 V DC and 24 V DC ) for the RTU560 subracks
560MPR03 and 560SFR02. The output power is sufficient to
supply a subrack with up to 4 communication units.
It is possible to configure redundant power supplies for project
configurations with higher requirements to availability. In this
configuration two power supply units 560PSU01 are operating in
parallel mode. They are able to take over the load, if one power
supply fails.
The power supply unit 560PSU01 is available in two versions
(Rubriken) for different input voltage ranges:
R0001: Input range 24...60 V DC
R0002: Input range 110220 V DC

Power supply unit for RTU560, 48...220 V DC, 85W

Application
The power supply unit 560PSU02 generates the two supply
voltages (5 V DC and 24 V DC ) for the RTU560 communication
units within the subrack. The output power is sufficient to supply
the whole communication subrack with up to 8 CMU modules.

560PSU02
1KGT011900R0001

Description
Power supply unit for RTU560 racks
Input voltage: 48...220 V DC
Output voltage: 5 and 24 V DC
Suitable for redundant power supply in
560CSR01/ 560MPR03/ 560SFR02

14 Power supply units | ABB remote control products

It is possible to configure redundant power supplies for project

configurations with higher requirements for availability. In this
configuration two power supply units 560PSU02 are operating
in parallel mode. They are able to take over the full load, if one
power supply fails.
The power supply unit 560PSU02 is available in one version
(Rubrik):
R0001: Input range 48...220 V DC

Rack RTUs
Communication units (CMUs)

560CMU02
1KGT012600R0002

Description
Central module of the RTU560 with 32 bit CPU
Two serial communication interfaces (RS232 or
RS485) for local/remote communication
2x Ethernet interface (10/100BaseT)
Licences for protocol, functions and compact flash
are not included.

560CMU05
1KGT012700R0002

Description
Central module of the RTU560 with 32 bit CPU
4x serial communication interfaces (RS232/485)
for local/remote communication
2x Ethernet interface (10/100BaseT)
Licences for protocol, functions and compact flash
are not included.

CMU for RTU560, 2 serial ports, 2 Ethernet ports

Application
The 560CMU02R0002 communication unit is one of the CMU
boards (CMU = communication unit) of the remote terminal unit
RTU560.
The essential tasks are:
Managing and controlling of the I/O boards via the interfaces to
the RTU peripheral bus.
Reading process events from the input boards.
Send commands to the output boards.
Communication with control centers and local HMI systems via
the integrated serial line interfaces and the implemented
Ethernet 10/100 BaseT LAN interface.
Managing the time base for the RTU560 station and
synchronizing the I/O boards.
Within the RTU560 racks the board occupies one slot. It contacts itself via a DIN F socket connector to the rack. The Communication Unit 560CMU02 R0002 is able to handle Ethernetand UART-character based communication protocols, and the
serial peripheral bus.

CMU for RTU560, 4 serial ports, 2 Ethernet ports

Application
The 560CMU05 communication unit is one of the CMU boards
(CMU=communication unit) of the remote terminal unit RTU560.
The essential tasks are:
Managing and controlling of the I/O boards via the interfaces to
the RTU peripheral bus.
Reading process events from the input boards.
Send commands to the output boards.
Communications with control centers and local HMI systems
via the integrated serial line interfaces and the implemented
Ethernet 10/100BaseT LAN interfaces.
Managing the time base for the RTU560 station and
synchronizing the I/O boards.
Within the RTU560 racks the board occupies two slots. It contacts itself via a DIN F socket connector to the rack. The Communication Unit 560CMU05R0002 is able to handle Ethernet-,
UART-character based bitprotocols and the serial peripheral bus.

ABB remote control products | Communication units 15

Rack RTUs
Rack I/Os

23BE23
1KGT012100R5001

Binary input, 16 channels, LEDs

Application
Isolated input of up to 16 binary process signals. Scanning and
processing of the inputs are executed with the high time resolution of 1ms. Allocation of an input to a processing function can be
done according to the rules of configuration.
The board 23BE23 can process the following types of signals:
16 single indications with time stamp
8 double indications with time stamp
2 digital measured values with 8 bit
1 digital measured value with 16 bit
16 pulse counters

Description
To be used for single indications, double indications,
digital measurands and pulse counters.
Resolution: 1ms
Process voltage: 24...60 VDC
LED signal for each input

23BA20
GSNE000700R5312

Description
16 single commands 1-pole or with 23BA23 1.5-pole
or 8 single commands 2-pole
Max. operating voltage: 60VDC, 60W
Imax.=2A with 24VDC (ohmic load)

16 Rack I/Os | ABB remote control products

Binary output, 16 channels

Application
The binary output board 23BA20 can be used for the potentially
isolated output of up to 16 binary signals to the process. The assignment of an output to a number of processing functions can
be freely undertaken within the scope of the configuration rules.
The 23BA20 can be used for the following types of signal:
Object commands with 1 or 2 pole output without
(1 out of n) check
Set-point messages
General output messages

Rack RTUs
Rack I/Os
Command output monitoring (1 out of n test)
Application
The 23BA23 board is intended for the use in the remote terminal
unit RTU560. The 23BA23 board should be installed if the output
circuit of an object command has to be checked before the
actual command is given. The 23BA23 board executes a 1 out of
n check. It checks if only one interposing relay will be activated
in the output circuit. This is feasible only if all interposing relays
connected to one check circuit have the same resistance value.
23BA23
1KGT020800R0001

Description
2 test and switching circuits
Auxiliary test voltage 24...60 V DC

The 23BA23 board allows to check two different interposing relay

types by using two separated check circuits. The permissible
tolerance range is defined by means of parameters. Up to 16
23BA23 boards can be used in one RTU560.
Galvanic isolation of the check circuit
Suppression of line frequency during measuring characteristics

Analog input, 8 channels

Application
The 23AE23 board records up to 8 analog measured values. The
23AE23 board allows it to connect all typical measured value
ranges.

23AE23
1KGT012200R5001

Description
Resolution 12bit + sign
Measuring ranges: +/- 2 mA; +/- 5mA; +/- 10mA;
+/-20mA; +/-40mA; +/- 2VDC; 0...20VDC

It can be configured for the following measurement ranges by

simple switches and jumpers:
2mA
5mA
10mA
20mA
40mA
2VDC
0... +20VDC
Other effective ranges and live zero signals become generated
out of these ranges through conversion of the communication
unit CMU.

ABB remote control products | Rack I/Os 17

Rack RTUs
Rack I/Os
Analog output; 2 channels with potential isolation
Application
Via the analog output board 23AA21, analog control outputs for
sequential or closed loop control, display instruments, measurand recorders etc. can be connected to the RTU560. The
23AA21 board has two output channels which are isolated and
can be configured to different output current ranges. The output
format, unipolar or bipolar resp. Live-Zero (4...20mA), can be
configured by software parameters.
23AA21
1KGT020700R0001

Description
Analog signal represented digitally by 11bit + sign
Selectable current outputs: +/-2.5 mA; +/-5mA;
+/-10mA;+/-20mA; +4..20mA

18 Rack I/Os | ABB remote control products

The following output current ranges can be configured independently per channel via plug-in jumpers:
2.5mA
5mA
10 mA
20 mA (4...20mA)

Rack RTUs
Serial communication
Fibre optic coupler (BFOC/2.5) for 2xglass-fibre
Application
The fiber optic coupler 23OK24 is intended for the use in the
remote terminal unit RTU560 or in other foreign devices. The
module is used to transmit data via two independent optical links
(receive and transmit).

23OK24
1KGT011800R5001

Description
Fibre optic coupler for glass-fibre optic cable with
emission wave length of 820nm max.
Fibre optic-connection with bayonet socket BFOC/2.5
(IEC-SC86B).
Suitable as star coupler for RS485 bus.
Making condition Light ON or Light OFF can be
configured
Connector for 2 optical cables on frontplate

Optical fiber cables are not sensitive to inductive and capacitive

interferences, as well for potential differences between the two
data communication equipments. Fiber optic cables will be used
to bridge over distances in critical environments, or if a potential
isolation is required. The maximum distance can be up to 2600 m.
The board can be used for signal conversion of the received and
transmitted data for the following electrical interface standards:
RTU560 I/O-bus
RS485 bus
RS232 C

Modem V.23, power supply 5/24 V DC

Application
The 23WT23 board is a modem which converts the serial data
according to CCITT V.23 standard. Therefore it can be used for
the transmission via leased PTT-lines, private networks or for
radio transmission.

23WT23
1KGT008200R0001
1KGT008200R0002

The modem 23WT23 is available in two versions (Rubriken):

R0001: V.23 modem power supply +5VDC
R0002: V.23 modem power supply +24VDC
Two- or four-wire operation mode is selectable by jumper. The VF
output has a high impedance which allows that up to 10 remote
stations can be connected to a multi-drop line.

Description
Voice frequency telegraphy device (VFT) according
CCITT V.23 standard

ABB remote control products | Serial communication 19

Rack RTUs
Serial communication

25LU40
1KGN000865R0001

Line transformer 600/600 + lightning protection

Application
The DIN rail mountable voice frequency line transformer 25LU40
is intended to isolate the RTU560 FSK modems (frequently shift
keying) from the pilot line and to protect the RTU560 equipment
from high voltage disturbances. The 25LU40 operates with very
low transmission loss in the working frequency range from 300 to
3400Hz applies to line impedances of 600Ohms and to the ABB
modems 23WT23 and 23WT25. The test voltage is 2.5kV at
50 Hz. Protection is guaranteed through the integrated sparking
gap, fuses and 10 kA arrestors.
A high-resistance staggering is possible with both types of modems on e.g. party lines and multidrop lines. This is because the
line transformer has no additional load at the line.

Description
Isolated line transformer, test voltage 2.5kV/ 50Hz,
600/600Ohm, required for surge voltage protection on
transmission line and/or galvanic isolation of transmission line.
Lightning protection is included.
Snap locked

Modem 9600Bd, power supply 5VDC

Application
The 23WT24 board is a modem with 9,6kBps transmission
speed. Therefore it can be used for the transmission via private
networks.
The modem 23WT24 is available in one version:
R0001: 9,6 kBps modem
power supply +5 VDC
23WT24
1KGT010500R0001

Description
Voice frequency telegraphy device (VFT) with
9600 baud transmission speed

20 Serial communication | ABB remote control products

The board operates on the frequency shift keying principle (FSK).

Two- or four-wire operation mode is selectable by jumper. The VF
output has a high impedance which allows that up to 10 remote
stations can be connected to a multi-drop line.

Rack RTUs
Serial communication
Modem 50-2400Bd, power supply 5/24VDC
Application
The 23WT25 modem is designed for the operation on telecontrol
lines together with the RTU560. However it can also be connected to other data terminal equipments because it operates at the
interfaces like a universal FSK-modem in the voice-band range
(300-3400Hz) according to CCITT.

23WT25
1KGT012400R0001
1KGT012400R0002

The 23WT25 modem allows the assignment of a two- or fourwire line with communication channels in the CCITT raster for
50 to 2400 bit/s.
There are two versions (Rubrik) available:
23WT25R0001: 5VDC Supply
23WT25R0002: 24VDC Supply

Description
Voice frequency telegraphy device (VFT)
Channel-frequencies and -bandwidth are selectable
according to CCITT frequency tables (R35...R38)
or V.23

Additional material:

Programming cable 23WT25

23PK31

For download of project specific firmware version

1KGT013200R0001

ABB remote control products | Serial communication 21

Rack RTUs
Ethernet communication
Integrated unmanaged switch with 4 ports
Application
The RTU component 560NUS04 is an unmanaged plug and play
10/100Mbps Ethernet switch providing four fast Ethernet autonegotiating.

560NUS04
1KHW001891R0001

RJ45-Ports with auto MDI/X (automatic crossover detection and

correction). The switch is intended for distributing Ethernet within
a station and supplying a local area network (LAN) with additional
ports and can be used with rack types 560MPR01, 560MPR03,
560SFR02.

Description
4 x10/100 BaseT ports (electrical)
Only linear structure
No ring configuration possible

Integrated unmanaged switch with 2 FX ports

Application
The RTU component 560NUS12 is an unmanaged plug and play
10/100 Mbps Ethernet switch providing two fast Ethernet autonegotiating RJ45-Ports with auto MDI/X (automatic crossover
detection and correction) and two fiber optic 100Mbps slots for
use with SFP modules.
560NUS12
1KHW001892R0001

Description
2 x100 FX ports, without optical transmitter/receiver.
Additional SFP modules are required (see 560NFOxx)
2 x10/100 BaseT ports (electrical)
Only linear structure No ring configuration possible

The switch is intended for distributing Ethernet within a station

through the RJ45-Ports. The fiber optic ports can be used for
interconnecting stations with a maximum distance of 40 km. The
switch is not applicable for providing fault tolerant topologies like
ring or mesh networks.

Additional material:

SFP S-1.1 for optical switch

560NFO13

For 560NUS12 board; monomode, distance of typically 15km

1KHW001893R0001

1KHW001894R0001
1KHW001895R0001

560NFO15
For 560NUS12 board; monomode, distance of typically 40km

560NFO85

For 560NUS12 board; multimode, distance of typically 2km

22 Ethernet communication | ABB remote control products

Rack RTUs
Ethernet communication
Integrated managed switch with 2 DSL ports and
4 Ethernet ports
Application
The RTU component 560NMS24 is a managed plug and play
Layer2-switch providing four Fast Ethernet auto-negotiating
RJ45-ports with auto MDI/X (Automatic Crossover Detection and
Correction) and two 2-wire SDSL-ports for use with private copper cables. It can be used with rack types 560MPR01,
560MPR03 and 560SFR02.
560NMS24
1KHW002108R0001

Description
Integrated managed Layer 2-Switch
4x10/100 BaseT ports (RJ45, electrical, autonegotiating)
2xSDSL port for copper wire
Provides redundant topologies by the (Rapid)
Spanning Tree Protocol (RSTP)

The switch is intended for distributing Ethernet within a station through the RJ45-ports. The SDSL ports can be used for
interconnecting stations with a maximum distance of 20km
(copper cable with diameter of 0.8 mm). Longer distances can be
achieved by cascading multiple 560NMS24. The switch is able
to provide redundant topologies by the (Rapid) Spanning Tree
Protocol.

Integrated managed switch with 1 DSL port and

4 Ethernet ports
Application
The RTU component 560NMS34 is a managed plug and play
Layer 2-switch providing four Fast Ethernet auto-negotiating
RJ45-ports with auto MDI/X (automatic crossover detection and
correction) and one 2-wire SDSL-port for use with private copper
cables.
560NMS34
1KHW023538R0001

Description
Integrated managed Layer 2-Switch
4x10/100 BaseT ports (RJ45, electrical, autonegotiating)
1xSDSL port for copper wire
Provides (Rapid) Spanning Tree Protocol (RSTP)
support

It can be used with rack types 560MPR01, 560MPR03 and

560SFR02. The switch is intended for distributing Ethernet within
a station through the RJ45-ports. The SDSL port can be used for
interconnecting stations with a maximum distance of 20km
(copper cable with diameter of 0.8mm). The switch is able to
provide redundant topologies by the (Rapid) Spanning Tree Protocol.

ABB remote control products | Ethernet communication 23

Rack RTUs
Real time clocks
Real time clock GPS for RTU560
Application
A remote terminal unit RTU560 can be synchronized with the
time information received from the global positioning system
(GPS) satellites using the module 560RTC01. The RTU560 reads
the time and date from the module 560RTC01 and synchronizes
its internal time to the standard time by the means of a minute
pulse. The use of the module 560RTC01 ensures that process
information from several terminal units are synchronized, when
they include time information.
560RTC01
1KGT006700R0001

Description
Real time clock for synchronisation of the RTU560
with the standard time of the GPS satellite including
configuration tool.
Antenna and cable has to be ordered separately

Real time clock DCF 77 for RTU560

Application
A remote terminal unit RTU560 can be synchronized with the
standard time of the long-wave transmitter DCF 77 using the
module 560RTC02. The RTU560 reads the time and date from
the module 560RTC02 and synchronizes its internal clock to the
standard time by means of a minute pulse. The use of the module 560RTC02 ensures that indications from several terminal units
are synchronized, when they include time information.
560RTC02
1KGT007800R0001

Description
For synchronisation of the RTU560 with the standard
time of the long-wave transmitter DCF77.
Antenna and cable has to be ordered separately

24 Real time clocks | ABB remote control products

Rack RTUs
Real time clocks
Real time clock IRIG-B for RTU560
Application
A remote terminal unit RTU560 can be synchronized with the
standard time of the IRIG-B signal using the module 560RTC03.
The RTU560 reads the time and date from the module
560RTC03 and synchronizes its internal clock to the standard time by means of a minute pulse. The use of the module
560RTC03 ensures that indications from several terminal units
are synchronized, when they include time information.
560RTC03
1KGT012000R0001

Description
For synchronization of the RTU560 with the standard
time of the IRIG-B signal.
Receiver and cable has to be ordered separately

Additional material:

Connection cable 20m/50m for the real time clock

23AC02R0020

Cable to connect real time clock module 560RTC01 with 23AN02

1KGT006900R0020

or 560RTC02 with 25AN01

Length 20 meters

1KGT006900R0050

23AC02R0050

Cable to connect real time clock module 560RTC01 with 23AN02

or 560RTC02 with 25AN01

Length 50 meters

Ferrite antenna for outside installation

25AN01R0003
Ferrite antenna for the real time clock module 560RTC02 incl. wall
mounting kit, 360 rotatable

GSNP812601R0003

GPS Antenna

23AN02R0001

Active antenna for the real time clock module 560RTC01

1KGT006800R0001

ABB remote control products | Real time clocks 25

DIN rail RTUs

Compact RTUs
One solution for various applications
The open architecture of the RTU family supports different applications:
Remote control, substation automation, communication gateway, distribution and feeder RTU as well as smart grid applications. All RTU560 functions are available as DIN rail solution.
The scalability of our RTU DIN rail product line allows perfect adaptation for all types of small applications.

Product family

DIN rail RTU560

CMUs with fixed
housing
560CMG10 p.28

560CMD11 p.28

560MDD10 p.29

560CIG10 p.30

DIN rail RTU211

CMUs with flexible housing
560CMU01 p.31

RTU DIN rail calculation tool (EUR/USD)

Power
supply
flexible housing

For ordering extension modules

23PU63 p.32
560PSU10 p.32

Power
supply
fixed housing

I/Os with fixed

housing

560PSU40 - p.33

560PSU41 p.33

23VG23 p.34

23VG24 p.34

23BE40 p.35

23BE50 p.35

23BA40 p.36

560FOC40 p.36

211BID51 p.37

211BOD52 p.37

26 RTU DIN rail family | ABB remote control products

211AID50 p.38

211ADD52 p.34

DIN rail RTUs

Compact RTUs

RTU560 in a fixed rugged metal housing

With 560CMG10 as communication gateway
With 560CIG10 and integrated multi-I/O-board
RTU211 in a scalable housing
With 560CMU01 and up to 4 integrated I/O modules
With 23CM61 and integrated multi-I/O-board

All versions can be extended with different I/O modules from the RTU family.
Product family
RTU DIN rail calculation tool (EUR/USD)
For ordering extension modules

I/Os with flexible

housing

23BO61 p.39

23AI60 p.40

23BI61 p.39

23AD63 p.40

23BO62 p.39

23PT60 p.40

23AO60 p.39

23AD64 p.40

23BO63 p.39

23IO96 p.40

23AD62 p.40

Multi meters

560CVD03 - p.42

560CVD03 - p.42

Multi meters with

FCD

560CVT10- p.43

Serial communication
560FSM10 - p.44

560FSM11 - p.44

Ethernet communication
560NMD01 - p.45

I/Os adapter for

flexile housing

23SC60 - p.46

ABB remote control products | RTU DIN rail family 27

DIN rail RTUs

RTU560 CMUs with fixed housing
560CMG10 base module
Application
The 560CMG10 is a communication unit (CMU) of the DIN rail
RTU560. The 560CMG10 consists of a metal DIN rail housing,
which includes a CPU and a power supply.

560CMG10
1KGT017600R0001

Description
DIN rail mounted base module RTU560
Metal housing
Three serial ports (2xRS-232, 1xRS-485)
1xEthernet port
Power supply 24 VDC
With connection interface to RTU211 I/O-extension
modules

The essential tasks of the 560CMG10 are:

Managing and controlling of the I/O boards via the interface to
the RTU560 serial peripheral bus (I/O-Interface/Wired-OR-Bus)
Reading process events from the input boards
Writing commands to the output boards
Communications with control centers and local HMI systems
via the integrated serial line interfaces and the implemented
Ethernet 10/100BaseT LAN interface
Managing the time base for the RTU560 station and
synchronizing the I/O boards
Handling the dialogue between RTU560 and Web-Browser
via LAN interface

560CMD11, 24VDC, optionally with internal GPRS modem

Application
The 560CMD11 is a communication unit (CMU) of the remote
terminal unit RTU560. The 560CMD11 consists of a metal DIN
rail housing, which includes a CPU and a power supply.

560CMD11
1KGT023400R0001
1KGT023400R0011

Description
DIN rail mounted base module RTU560
Metal housing
Four serial ports (RS-232, RS-485), one used
for GPRS
2xEthernet port
Power supply 24 VDC
No SIM-Card or antenna included
With connection interface to RTU211 I/O-extension
modules

28 RTU560 CMUs with fixed housing | ABB remote control products

The essential tasks of the 560CMD11 are:

Managing and controlling of the I/O boards via the interface to
the RTU560 serial peripheral bus (I/O-Interface/Wired- OR-Bus)
Reading process events from the input boards
Writing commands to the output boards
Communications with control centers and local HMI systems
via the integrated serial line interfaces and the implemented
Ethernet 10/100BaseT LAN interface
Managing the time base for the RTU560 station and
synchronizing the I/O boards
Handling the dialogue between RTU560 and Web-Browser
via LAN interface
Communication via integrated GPRS-Modem (only R0011)

DIN rail RTUs

RTU560 CMUs with fixed housing
GSM/GPRS modem for DIN rail
Application
The 560MDD10 is a GSM/GPRS modem that provides Ethernet
communication via serial interface with Point-to-Point Protocol
(PPP). The modem consists of a plastic DIN rail housing.

560MDD10
1KGT030100R0001

Description
Ethernet communication via serial interface with
Point-to-Point Protocol (PPP)
Plastic DIN rail housing
Quad-Band GSM/GPRS
No SIM-Card or antenna included

Additional material:

Bar antenna for 560CMD11 and 560MDD10

560ANA01R0001

Bar Antenna for 560CMD11 and 560MDD10

10pcs per package
1KGT023600R0001

Wall mounted antenna for 560CMD11 and 560MDD10

560ANA02R0005

Wall mounted antenna for 560CMD11 and 560MDD10,

5m cable

1KGT023700R0005

560ANA02R0020
1KGT023700R0020

Wall mounted antenna for 560CMD11 and 560MDD10,

20m cable

ABB remote control products | RTU560 CMUs with fixed housing 29

DIN rail RTUs

RTU560 CMUs with fixed housing

560CIG10
1KGT021600R0001
1KGT021600R0002

Description
DIN rail mounted base module
Metal housing
Three serial ports (2x RS-232, 1x RS-485)
1x Ethernet port
Power supply 24VDC
Integrated I/O 16 BI, 8BO, 8AI (mA Signals),
1 out of n check
With connection interface to RTU211 I/O-extension
modules

30 RTU560 CMUs with fixed housing | ABB remote control products

560CIG10 base module

Application
The 560CIG10 is a RTU560 unit consisting of a communication
unit, a multi I/O-board and a power supply in a metal DIN rail
housing.
The essential tasks of the 560CIG10 are:
Capturing of 8 analog input signals (mA/V signals)
Capturing of 16 digital input signals
Output of 8 binary commands (by relay)
1-of-n test function
Managing and controlling of the RTU211 I/O boards via the
serial interface (Wired-OR-Bus).
Reading process events from the input boards.
Writing commands to the output boards.
Communications with control centers and local HMI systems
via the integrated serial line interfaces and the implemented
Ethernet 10/100BaseT LAN interface.
Managing the time base for the RTU560 station and
synchronizing the I/O boards.
Handling the dialogue between RTU560 and Web-Browser
via LAN interface.
Process voltage:
R0001: 24...60 VDC
R0002: 110...125 VDC

DIN rail RTUs

RTU211 CMUs with flexible housing

560CMU01
1KGT013100R0001

Description
CMU board for housing type 23HS60R000x for
RTU560
Three serial ports
1x Ethernet port
With connection interface to RTU211 I/O-extension
modules

560CMU01 board, spare part

Application
The 560CMU01 is the Communication unit (CMU) of the remote
terminal unit RTU560 for DIN rail mounting. It is designed to be
used together with DIN rail I/O devices (e.g. 23BI61, 23BO62 or
23AI60).
The essential tasks of the 560CMU01 are:
Managing and controlling of the I/O boards via the interface to
the RTU560 serial I/O bus (local I/O-Interface/ Wired-OR-Bus).
Reading process events from the input boards.
Writing commands to the output boards.
Communications with control centers and local HMI systems
via the integrated serial line interfaces and the implemented
Ethernet 10/100BaseT LAN interface.
Managing the time base for the RTU560 station and
synchronizing the I/O boards.
Handling the dialogue between RTU560 and Web-Browser
via LAN interface.
The communication unit 560CMU01 will be mounted in a DIN rail
housing, together with the power module 560PSU10, and the
DIN rail I/O modules.
The communication unit 560CMU01 is able to handle Ethernetand UART-character based communication protocols and the
serial I/O bus.

ABB remote control products | RTU560 CMUs with flexible housing 31

DIN rail RTUs

Power supply flexible housing
RTU DIN rail calculation tool (EUR/USD)
The RTU DIN rail calculation tool is used for ordering
RTU560/211 DIN rail RTUs and extension modules. In case of an
extension module failure you can order the spare parts separately.
Please always use the latest version which is send to all RTU
price list recipients.

Additional information:

23PU63, power supply 24...110VDC, spare part

23PU63

Power supply unit

Input voltage: 24...110VDC

Output power: 25W

Module length: 175mm

1KGT017900R0001

560PSU10 board, spare part

1KGT013400R0001

32 Power supply flexible housing | ABB remote control products

560PSU10
Power supply board for DIN rail mounting in combination with 560CMU01
Input voltage: 24VDC
Output power: 38W

DIN rail RTUs

Power supply fixed housing
DIN rail power supply unit for 110...220 V DC, 230 V AC
Application
The power supply unit 560PSU40 is a galvanic isolated DIN rail
power supply. It is designed to supply the RTU560 DIN rail I/Omodules and communication modules.
In order to increase the availability two power supplies can be
operated in parallel. External diodes are not necessary.

560PSU40
1KGT011600R0001

Description
Power supply module for DIN rail mounting
Input voltage: 85...264 V AC or 85...375 V DC
Output voltage: 24 V DC, max. 2.5 A, 60 W
Suitable for the supply of up to 8 interposing
modules 23BEx0 / 23BA40 / 560CVTxx /
RTU560 DIN rail

DIN rail power supply unit for 24...60 V DC

Application
The power supply unit 560PSU41 is a galvanic isolated DIN rail
power supply. It is designed to supply the RTU560 DIN rail I/Omodules and communication modules.

560PSU41
1KGT017700R0001

Description
Power supply module for DIN rail mounting
Input voltage: 24...60 V DC
Output voltage: 24 V DC, max. 2.5 A, 60 W
Suitable for the supply of up to 8 interposing
modules 23BEx0 / 23BA40 / 560CVTxx /
RTU560 DIN rail

ABB remote control products | Power supply fixed housing 33

DIN rail RTUs

Power supply fixed housing
Mains adapter 230...115VAC -> 24VDC, 48W
Application
The mains adapter 23VG23 is an AC/DC converter in combination with an external back up battery for the use as an uninterruptible power system (UPS). It contains a switch-mode power
supply of 92 VAC to 265VAC without switch over the input
voltage. The mains adapter supplies an output voltage of
24VDC with an output current of min. 0.2A and max. 2A.
Charge current: max. 0,35A

23VG23
1KGT005500R0001

Description
Mains adapter AC/DC converter for 230 or 115VAC
input, output 24VDC, 2A max.
Designed for use with back-up battery 24VDC
nominal for maximum 1.5 hours full operation

Mains adapter 230...115VAC -> 24VDC, 240W

Application
The mains adapter 23VG24 is an AC/DC converter for an input
voltage of 115 or 230 VAC. It supplies an output voltage of
24VDC with an output current of max. 10A.
It can supply the module racks, the mounting panels and the I/O
modules of a RTU560 station with a power output of approx.
240W.

23VG24
1KGT005600R0001

Description
Mains adapter AC/DC converter for 230 or 115VAC
input, output 24VDC, 10 A max.

34 Power supply fixed housing | ABB remote control products

DIN rail RTUs

I/Os with fixed housing
Binary Input, 16 channels 110...125 V DC (R0011) and
220/250 V DC (R0012)
Application
The binary input board 23BE40 is used for the isolated input of
up to 16 binary process signals. Scanning and processing of the
inputs are executed with the high time resolution of 1 ms.
The board is available in two versions (Rubriken):
23BE40 R0011 for 110...125 V DC
23BE40 R0012 for 220...250 V DC
23BE40
1KGT011100R0011
1KGT011100R0012

Description
16 channel potential isolated inputs, without common
return.
Process voltage: 110/125 V DC and 220/250 V DC

Allocation of an input to a processing function can be done

according to the rules of configuration. The 23BE40 can process
the following types of signals:
16 single indications with time stamp
8 double indications with time stamp
2 step position information each with 8 bit
8/16 bit digital measured value(s)
8/16 bit String Information
16 pulse counters (max. 25 Hz)
Power supply 560PSU40/41 is needed to feed this modules.

Binary Input, 64 channels, LEDs

Application
The binary input board 23BE50 is used for the isolated input of
64 process signals in 4 groups with each up to 16 binary signals.
Scanning and processing of the inputs are executed with the
high time resolution of 1ms.

23BE50
1KGT020900R0001

Description
To be used for single indications, double indications,
digital measurands and pulse counters.
Resolution: 1ms
Process voltage: 24...60 VDC
LED signal for each input

Allocation of an input to a processing function can be done

according to the rules of configuration. The board 23BE50 can
process the following types of signals:
64 single indications with time stamp
32 double indications with time stamp
8 step position information each with 8 bit
8/16 bit digital measured value(s)
8/16 bit string information
64 pulse counters (max. 120 Hz)
Power supply 560PSU40/41 is needed to feed these modules.

ABB remote control products | I/Os with fixed housing 35

DIN rail RTUs

I/Os with fixed housing
Command output module 110...220VDC
Application
The binary output board 23BA40 can be used for the potentially
isolated output of up to 16 binary signals to the process. The assignment of an output to a number of processing functions can
be freely undertaken within the scope of the configuration rules.

23BA40
1KGT011200R0011

Description
16 relays for 16 outputs. single pole:
Max. switching voltage: 220 V DC / 250 V AC
Max. switching capacity : 120 W (DC)
Max. switching current: 300 mA at 110 V DC,
200 mA at 220 V DC (L/R = 40 ms)
Isolated relay outputs, no common return

The 23BA40 can be used for the following types of signal:

Object commands with 1- or 2-pole output without
(1 out of n) check
Regulation commands
Digital setpoints
Bitstring output, 1, 2 or 16 bit (see note)
The board is available in one version (Rubrik):
23BA40R0011 for 24 up to 220VDC and up to 250VAC note:
The number of simultaneous active relays may not exceed 8 at
heavy conditions (220 VDC, 8A, at 70C).
Power supply 560PSU40/41 is needed to feed these modules.

560FOC40 optical coupler (24VDC)

Application
The 560FOC40 module is intended for use in RTU560 configurations with binary I/O modules 23BA40/23BE40. The module
560FOC40 is used to transmit data via fiber optical cables. Fiberoptic cables are not sensitive to inductive and capacitive interference as well as to differences in potential between two data
communication units/systems.

560FOC40
1KGT011500R0001

Description
Direct Connection to Serial Peripheral Bus (SPB)
For potential isolation of SPB
Emission wave length: 850nm
Input optical power:
Min. - 24.0 dBm
Max. -10.0 dBm
Transmission rate: 1 Mbit max.
Connects in star or multipoint-T configuration

36 I/Os with fixed housing | ABB remote control products

Fiber-optic links will be used to cover large distances in critical

environments or if potential isolation is required. Available version
is 820 nm multimode glass fiber optic.
RTU560 I/O Bus
RS485 (inactive signal =light off)
The board 560FOC40 is snap mounted.

DIN rail RTUs

I/Os with fixed housing

211BID51
1KGT024100R0001
1KGT024100R0002

Description
To be used for single indications, double indications,
digital measurands and pulse counters.
Resolution: 1 ms
Process Voltage: 24...60 V DC / 110...125 V DC
LED signal for each intput
Common return per 8 inputs

211BOD52
1KGT024200R0002

Description
8 single commands 1-pole (high capacity relays)
Max. switching voltage 150 V DC
Max. load=110VDC / 3A

211BID51 R0001: 16 binary inputs, 24...60 V DC /

R0002: 110...125 V DC
Application
The binary input device 211BID51 provides 16 galvanic insolated
inputs for 16 binary process signals. Scanning and processing
of the inputs are executed with the high time resolution of 1 ms.
The allocation of an input signal to the functional processing can
be done according to the rules of configuration.
The module 211BID51 is able to process the following types of
signals:
16 single indications with time stamp
8 dual indications with time stamp
2 digital status messages with 8 bit
1 digital status message with 16 bit
16 pulse counters
The board is available in two versions (Rubriken):
R0001: process voltage 24...60 V DC, LED signal
for each inpu,t common return per 8 inputs
R0002: process voltage 110...125 V DC, LED signal
for each input, common return per 8 inputs

211BOD52R0002: 8 binary outputs, relays

Application
The binary output device 211BOD52 can be used for the control
of 8 binary process signals using relay contacts. The assignment
of an output to a specific processing function can be chosen by
the user according the configuration rules.
The 211BOD52 can be used for the following types of signal:
Object commands with 1 or 2 pole output without
(1 out of n)-check
Object commands with 2 pole output including
(1 out of n)-check
Control switch commands, 1 and 2 pole
Digital set point commands (8 bit)
String output commands, 1or 8 bit
Regulation commands

ABB remote control products | I/Os with fixed housing 37

DIN rail RTUs

I/Os with fixed housing
211AID50R0001: 6 analog inputs, mA signals /
R0002: 6 analog inputs, V signals
Application
The 211AID50 board records up to six analog measurement
values. Various sensitivity ranges for voltage and current measurement are available.
The device 211AID50 is available in two versions (Rubriken):
R0001: Current measurement version
R0002: Voltage measurement version
211AID50
1KGT024000R0001
1KGT024000R0002

Description
R0001:
Resolution 11bit + sign; accuracy class 0,25
+/- 5 mA; +/- 10mA; +/- 20mA; 4...20mA
Resolution 10bit + sign; accuracy class 0,5
Measuring range: +/- 2,5 mA
R0002:
Resolution 11 bit + sign; accuracy class 0,25
+/- 1 VDC; +/- 10VDC

211ADD52 I/O adapter board

Application
The adapter 211ADD52 is the standard adapter to connect
RTU211 I/O-modules within an RTU211.

211ADD52
1KGT023900R0001

Description
Standard adapter board for I/O modules 211BIDxx,
211BODxx, 211AIDxx

38 I/Os with fixed housing | ABB remote control products

DIN rail RTUs

I/Os with flexible housing
RTU DIN rail calculation tool (EUR/USD)
The RTU DIN rail calculation tool is used for ordering
RTU560/211 DIN rail RTUs and extension modules. In case of an
extension module failure you can order the spare parts separately.
Please always use the latest version which is send to all RTU
price list recipients.

Additional information:

23BO61: 8 binary outputs, transistor, spare part

23BO61

8 single commands 1-pole (transistor)

Max. operating voltage = 50 V DC / 0,2 A

Length 70 mm

Incl. label for plastic housing 23HS60

Incl. connectors

23BO62: 8 binary outputs, relays, spare part

1KGT014600R0001

23BO62
8 single commands 1-pole (high capacity relays)
Max. load = 110VDC / 3A
Length 140mm
Incl. label for plastic housing 23HS60
Incl. connectors

1KGT014400R0001

ABB remote control products | I/Os with flexible housing 39

DIN rail RTUs

I/Os with flexible housing

Additional information:

23BI61: 16 binary inputs, 24...48VDC / 60...110VDC,

23BI61

spare part

To be used for single indications, double indications, digital measurands

and pulse counters.

Resolution: 1 ms; Process voltage: R0001: 24...48VDC /

1KGT014300R0001

1KGT014300R0002

R0002: 60110VDC
LED signal for each input common return per 8 inputs

Length 105mm

Incl. label for plastic housing 23HS60

Incl. connectors

23AI60: 6 analog inputs, spare part

1KGT014700R0001

23AI60
Resolution 11 bit + sign; accuracy class 0,25
Ranges: +/-5mA; +/-10mA; +/-20 mA; 4...20mA; +/- 1VDC;
+/-10VDC
Resolution 10bit + sign; accuracy class 0,5
Measuring range: +/-2,5mA
Length 70mm
Incl. label for plastic housing 23HS60
Incl. connectors

23AO60: 2 analog outputs, spare part

23AO60

Resolution 11bit + sign; accuracy class 0,25

Ranges: +/-2,5mA; +/-5mA; +/-10mA; +/-20mA; 4...20mA;



1KGT014800R0001

+/- 1VDC;
+/- 10VDC

Length 105mm

Incl. label for plastic housing 23HS60

Incl. connectors

23PT60: 6 PT100 inputs, spare part

1KGT014900R0001

23PT60
2...4 wires per channel
Resolution: 11 bit + sign; accuracy class: +/-1C (-25C...125C)
Measuring range: -25C150C
Overrange: -200C200C,
Measuring current: 6mA
Length 140mm
Incl. label for plastic housing 23HS60

Incl. connectors

40 I/Os with flexible housing | ABB remote control products

DIN rail RTUs

I/Os with flexible housing

Additional information:

23AD62 I/O adapter board, spare part

23AD62

Standard adapter board for I/O modules (23BIxx, 23BOxx, 23AIxx,

23AOxx, 23PTxx)
Module length 35mm

Incl. 20 pole ribbon cables, cable length 200mm

Incl. label for plastic housing 23HS60

23AD63 I/O adapter board (RS485 and plastic/ glass fibre),

spare part





1KGT018500R0001

1KGT018500R0002

23AD63
Adapter board for interface to further I/O racks
Plastic fibre: 50m, 650nm / glass fibre,
multimode: ST connector, 820nm
Distance up to 2000m, 62,5/125m
HCS fibre: 500m, 650nm
RS485: 19,2kbaud, 200m
Module length 35mm
Incl. 20 pole ribbon cables, cable length 200mm

Incl. label for plastic housing 23HS60

23AD64 I/O adapter board remote I/O with plastic fibre/ glass fibre,

23AD64

spare part

Adapter board with connection for 23PU63

Plastic fibre: 50m, 650nm HCS fibre: 500m, 650nm

1KGT018400R0001

1KGT018600R0002

1KGT018600R0003

RS485: 19,2kbaud, 200m

Glass fibre, multimode: ST connector, 820nm distance up to 2000m,
62,5/125m

Module length 175mm

Incl. label for plastic housing 23HS60

ABB remote control products | I/Os with flexible housing 41

DIN rail RTUs

Multi meters
560CVD03 Transducer, LO/HI, 1A/5A, 3U3I
Application
The current/voltage-transformer interface 560CVD03 is used
for monitoring input signals from three independent phases with
3 or 4 wire connections. For each phase voltage, current and
power are measured directly, and a number of other parameters
derived from these in software. The results are transmitted to the
RTU560.
560CVD03
1KGT028000R0021
1KGT028000R0025
1KGT028000R0041
1KGT028000R0045

Versions

Type

LO

560CVD03 R0021

3U3I

HI

560CVD03 R0025

3U3I

560CVD03 R0041

3U3I

560CVD03 R0045

3U3I

1A

5A

x
x
x
x

Description
CT/VT interface with 3 voltage and 3 current inputs for
direct monitoring of 3 wire 10300 V AC, 1 A/5 A signals without mA transducers with MODBUS interface
to RTU560 (RS485).

560CVD03 transducer, LO/HI, Display, 1 A/5 A

Application
The Current/Voltage-Transformer Interface 560CVD03 is used
for monitoring input signals from three independent phases with
3 or 4 wire connections. For each phase voltage, current and
power are measured directly, and a number of other parameters
derived from these in software. The results are transmitted to the
RTU560.
560CVD03
1KGT028000R0031
1KGT028000R0035
1KGT028000R0051
1KGT028000R0055

Description
CT/VT interface with 3 voltage and 3 current inputs
for direct monitoring of 3 wire 10300 V AC, 1 A /
5 A signals without mA transducers with MODBUS
interface to RTU560 (RS485).
With display on front

42 Multi meters | ABB remote control products

It automatically changes the screen of measurement page and

each screen display for six seconds.
If you change it to button push mode, each screen will automatically display for 240 seconds. The scroll mode can be set up by
RTUtil560.
Versions

Type

LO

560CVD03 R0031

3U3I

HI

560CVD03 R0035

3U3I

560CVD03 R0051

3U3I

560CVD03 R0055

3U3I

1A

5A

x
x
x
x

DIN rail RTUs

Multi meters with FCD
CT/VT Interface 560CVT10
Application
The Current/Voltage Transducer Interface (CT/VT interface) is
used for measuring analog AC input signals from three independent phases with 3 or 4 wire connections. For each phase
voltage, current and power are measured directly, and a number
of other parameters derived from these in software. The results
are transmitted to the RTU560.
560CVT10
1KGT018900R0021
1KGT018900R0025
1KGT018900R0041
1KGT018900R0045

Description
Fault current detection (FCD)
LO 20...60VDC / HI: 80...330VDC, 80...260VAC
CT/VT interface with 4 voltage and 4 current inputs
for direct monitoring of 3/4 wire 10300 VAC,
1A/5A signals without mA transducers with
MODBUS interface to RTU560 (RS485)

There are several versions available:

Auxiliary Voltage (LO):
4 current-, 4 voltage inputs (In 1A)
4 current-, 4 voltage inputs (In 5A)
Auxiliary Voltage (HI):
4 current-, 4 voltage inputs (In 1A)
4 current-, 4 voltage inputs (In 5A)

ABB remote control products | Multi meters with FCD 43

DIN rail RTUs

Serial communication
Modem V.23, DIN rail, 24...60VDC
Application
The 560FSM10 is a modem which converts the serial data according to CCITT V.23 standard. It operates on the frequency shift
keying principle (FSK).
Two- or four-wire operation mode is selectable by DIP-switch.
The line output is capable to drive up to 10 remote stations
connected in a multi-drop line. It is functionally compatible with
the 23WT23 modem for subrack mounting and can be used as a
self-contained counterpart of it.
560FSM10
1KGT019200R0001

Description
Voice frequency telegraphy device (VFT) according
CCITT V.23 standard.
Compatible with 23WT23
DIN rail mounted

Modem 9600 baud, DIN rail, 24...60VDC

Application
The 560FSM11 is a modem for transmitting serial data at rates
up to 9600 bps. It operates on the frequency shift keying principle (FSK). Two- or four wire operation mode is selectable by
DIP-switch.
The line output is capable to drive up to 10 remote stations
connected in a multi-drop line. It is functionally compatible with
the 23WT24 modem for subrack mounting and can be used as a
self-contained counterpart of it.
560FSM11
1KGT019300R0001

Description
Voice frequency telegraphy device (VFT) with
9600 baud transmission speed.
Compatible with 23WT24
DIN rail mounted

44 Serial communication | ABB Remote Control Products

DIN rail RTUs

Ethernet communication

560NMD01
1KHW025096R0001

DIN rail integrated managed switch with 1 DSL port and

4 Ethernet ports
Application
The DIN rail mountable 560NMD01 is a managed plug and play
Layer2-switch providing four Fast Ethernet auto-negotiating
RJ45-ports with auto MDI/X (Automatic Crossover Detection and
Correction) and one 2-wire SDSL-port for use with private copper cables. The switch is intended for distributing Ethernet within
a station through the RJ45-ports. The SDSL port can be used for
interconnecting stations with a maximum distance of 20 km (copper cable with diameter of 0.8 mm). The switch is able to provide
redundant topologies by the (Rapid) Spanning Tree Protocol.

Description
Integrated managed Layer 2-Switch
4 x 10/100 BaseT ports (RJ45, electrical,
autonegotiating)
1 x SDSL port for copper wire
Provides (Rapid) Spanning Tree Protocoll (RSTP)
support

ABB Remote Control Products | Ethernet communication 45

DIN rail RTUs

I/O adapter for flexible housing
23SC60R0081: star coupler 1 glass fibre interfaces /
23SC60 R0091: star coupler 1 plastic fibre interfaces
Application
The star coupler 23SC60 is used to connect decentralized I/O
modules of the RTU560/RTU211. It is used to extend the serial
peripheral bus (Wired- OR-Bus) over distances of more than app.
50 cm.

23SC60
1KGT015800R0081
1KGT015800R0091

Description
Adapter board to remote I/O using glass fibre
1x 23AD63R0002 / plastic or HCS fibre
1x 23AD63 R0001
Including plastic housing
Incl. 20 pole ribbon cable

46 I/O adapter for flexible housing | ABB remote control products

The 23SC60 can also be used for converting the serial peripheral bus (Wired- OR-Bus) via a 20 pole connector to the RS485
peripheral bus. With this converter, I/O modules like 23BE40,
23BA40 or 23BE50 are connected to the RTU560 communication modules (CMU) 560CMG10, 560CIG10 and 560CMU01.
The star coupler 23SC60 is available in 8 versions (Rubriken):
23SC60 R009n plastic fibre max. 500 m
23SC60 R008n glass fibre max. 2000 m
Where n is the number of modules within one plastic enclosure
(1 n 5).

Licences
Basic License
1KGT201446R0001 (50 DP)
1KGT201443R0001 (250 DP)
1KGT201440R0001 (750 DP)
1KGT201437R0001 (5000 DP)

PLC/Archives License (incl. Basic)

1KGT201447R0001 (50 DP)
1KGT201444R0001 (250 DP)
1KGT201441R0001 (750 DP)
1KGT201438R0001 (5000 DP)

HMI License (incl. Basic and PLC/Archives)

1KGT201448R0001 (50 DP)
1KGT201445R0001 (250 DP)
1KGT201442R0001 (750 DP)
1KGT201439R0001 (5000 DP)

Licences:
Basic License

All CMUs

50/250/750/5000 DP

Incl. IEC 61850 Server and Client

(DP = data points)

Max. 50 DP/ 250 DP/ 750 DP (560CMU01/02/05, 560CMG10,

560CMD11, 560CIG10)
All protocols

PLC/Archives License
50/250/750/5000 DP

All CMUs
Max. 50 DP/ 250 DP/ 750 DP (560CMU01/02/05, 560CMG10,
560CIG10, 560CMD11)
Incl. Basic licence

HMI License

All CMUs

50/250/750/5000 DP

Max. 50 DP/ 250 DP/ 750 DP (560CMU01/02/05, 560CMG10,

560CIG10, 560CMD11)
Incl. Basic and PLC/Archives

48 Licences | ABB Remote Control Products

PC tools

Additional material:

COMPROTware Tool

Integrated testtool for telecontrol protocols

The following protocols are available:

1KG0000000R0003

IEC870-5-101, IEC870-5-102, IEC870-5-103, IEC870-5-104,

MODBUS, SPABUS, RP570, DNP3.0 (serial), DNP3.0 on LAN/WAN
Scope of supply: installation CD and hardlock

ITT600 SA Explorer






1KGT210239R0001

IEC 61850 test tool box (single license) with following functions:
Explore IEDs
Explore data models
Explore Ethernet
Explore GOOSE
Scope of supply: CD

RTUtil560

Software package utilities RTU560

Utility software for industrial standard-PC containing the program

modules running under Windows XP (single license)

Configuration of RTU560 (signal tree, network tree, hardware tree)

1KGT210203R0001

Creation of download files for RTU560

EXCEL-Import/Export function

Scope of supply: one CD

RTUtil61850





1KGT210238R0001

RTUtil61850 system configuration tool

IEC 61850 system engineering tool (CCT600) for overall station
engineering (single license)
For configuration of system-wide parameters, such as communication
addresses, horizontal communication data and its priorities and
client/server (system level/ IED) connections.
GOOSE engineering
Scope of supply: CD

MULTIPROGwt

Software package utilities RTU560 for PLC

Utility software for industrial standard-PC containing the program

modules running under Windows XP (single license)

PLC programming according to IEC1131-3, function-block-diagram

(FBD), instruction list (IL), structured text (ST), sequential function

1KGT210204R0001

chart (SFC), ladder diagram (LD)

Scope of supply: dongle (hardlock USB), software is part of
RTUtil560 CD

IET600

Intergrated Engineering Toolbox IET600

IET600 acts as a system tool which is used to define and share the

system-wide 61850 parameters, such as communication addresses,

horizontal communication data and its priorities and client/server

1KGT030900R0001

(system level/IED) connections. The actual configuration of the IED and

the down loading of configuration changes are done with PCM600.

ABB remote control products | PC tools 49

ABB AG
Power Systems Division
P.O. Box 10 03 51
68128 Mannheim, Germany
Phone: +49 621 381 3000
Fax:
+49 621 381 7622
E-Mail: rtu-sales-support@de.abb.com
www.abb.com/substationautomation

Note:
We reserve the right to make technical changes or
modify the contents of this document without prior
notice. With regard to purchase orders, the agreed
particulars shall prevail. ABB AG does not accept
any responsibility whatsoever for potential errors or
possible lack of information in this document.
We reserve all rights in this document and in the
subject matter and illustrations contained therein.
Any reproduction, disclosure to third parties or
utilization of its contents - in whole or in parts - is
forbidden without prior written consent of ABB AG.
Copyright 2012 ABB
All rights reserved

DEABB 1746 12 en printed in Germany (04.12-500-DI)

Contact us
