RBS 6000 Series – Vfe DE

marc heynen
19.11.2012
RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 1
AGENDA

› RBS 6000 Overview

› RADIO UNITS
› baseband UNITS
› GSM MC-BTS with RRUS12
› HW Activation Codes

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 2
AGENDA

› RBS 6000 Overview

› RADIO UNITS
› baseband UNITS
› GSM MC-BTS with RRUS12
› HW Activation Codes

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 3
 RBS 6000 Overview

› Multi standard
› High capacity
› Superior Radio performance
› Complete site
› Full flexibility
RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 4
FULL FREEDOM

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 5
HYBRID CONFIGURATIONS

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 6
RBS 6601 – 19” Main Remote

› Deployment scenarios

Installation in any 19 inch rack

Connection of up to 12 remote radios
RRU or AIR
DC (–48 V DC)
66 x 483 x 350 mm (H x W x D)
Temperature range +5 to +50 °C

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 7
RBS 6202 – 19” small Macro indoor

Installation in any 19 inch rack

One radio shelf
Up to 6 radio units
DC (–48 V DC)
490 x 500 x 525 mm (H x W x D)
65 – 70 kg (fully equipped)
Temperature range +5 to +50 °C

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 8
RBS 6201 – Large Macro Indoor

THE HIGH CAPACITY INDOOR BASE STATION

Complete site
Two radio shelves
Up to 12 radio units
AC or DC (–48/+24 V DC)
Transmission space up to 6U
(3U for AC cabinet version)
1435 x 600 x 483 mm (H x W x D)
Weight, fully equipped 215 kg
Temperature range +5 to +50 °C

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 9
RBS 6102 – Large Macro Outdoor

THE HIGH CAPACITY OUTDOOR BASE STATION

Complete site
Two radio shelves
Up to 12 radio units
AC or DC (–48 V DC)
Transmission space up to 6U
(3U with two battery strings)
1450 x 1300 x 700 mm (H x W x D)
Weight, fully equipped 390 kg
(excluding batteries)
Temperature range -33 to +50 °C

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 10
AGENDA

› RBS 6000 Overview

› RADIO UNITS
› baseband UNITS
› GSM MC-BTS with RRUS12
› HW Activation CodeS

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 11
REMOTE RADIO UNIT (RRUS 12 B8)
CHARACTERISTICS for GSM (preliminary)
› Multi standard radio
– GSM, WCDMA & LTE
– Band 8 - 900 MHz Extended
– Exceeds 3GPP MSR / MC-BTS Class 2 requirements
› RF
– Dual PA, up to 2x60 W
– Up to 8 Carriers GSM
– Typical GSM RX sensitivity (2W-RXD – No TMA):
› -116.7 dBm (TCH/FS static)
› -118.0 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 35 MHz
› Dimensions (with solar shield & handle)
– Size: 518 x 470 x 186 mm (HxWxD)
– Weight: ~25 kg
› Temperature
– -40° C to +55° C
› Cooling
– Self convection / no fans
› Alarms
– 6 (potential-free)
› Power
– -48 V DC (standard) or ~230 V AC (optional)
– Recommended fuse sizes (min/mid/max):
› 16/25/32 A
– Recommended DC cable (shield & ground):
› 6 mm2 up to 60 meters
› 10 mm2 over 60 meters
› Typical Power Consumption*
– 2x40W mode: ~200-400 W (Vodafone DE operation)
– 2x60W mode: ~210-600 W
› Product Number *Note: Preliminary values. Subject to pending local lab tests.
– KRC 161 262/2

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 12
REMOTE RADIO UNIT (RRUS 02 B0)
CHARACTERISTICS for GSM (preliminary)
› Multi standard radio
– GSM, WCDMA & LTE
– Band 0 - 900 MHz
– Exceeds 3GPP MSR / MC-BTS Class 2 requirements
› RF
– Single PA, up to 1x100 W
– Up to 8 Carriers GSM
– Typical GSM RX sensitivity (2W-RXD – No TMA):
› -116.7 dBm (TCH/FS static)
› -118.0 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 25 MHz
› Dimensions (with solar shield & handle)
– Size: 518 x 470 x 156 mm (HxWxD)
– Weight: ~24 kg
› Temperature
– -40° C to +55° C
› Cooling
– Self convection / no fans
› Alarms
– 6 (potential-free)
› Power
– -48 V DC (standard) or ~230 V AC (optional)
– Recommended fuse sizes (min/mid/max):
› 16/25/32 A
– Recommended DC cable (shield & ground):
› 6 mm2 up to 60 meters
› 10 mm2 over 60 meters
› Typical Power Consumption*
– 1x80 W mode: ~180-385 W (Vodafone DE operation)
– 1x100 W mode: ~180-450 W
› Product Number *Note: Preliminary values. Subject to pending local lab tests.
– KRC 161 264/1

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 13
REMOTE RADIO UNIT (RRUS 12 B3)
CHARACTERISTICS for GSM (preliminary)
› Multi standard radio
– GSM, WCDMA & LTE
– Band 3 - 1800 MHz
– Exceeds 3GPP MSR / MC-BTS Class 2 requirements
› RF
– Dual PA, up to 2x60 W
– Up to 8 Carriers GSM
– Typical GSM RX sensitivity (2W-RXD – No TMA):
› -116.9 dBm (TCH/FS static)
› -118.2 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 40 MHz
› Dimensions (with solar shield & handle)
– Size: 518 x 470 x 186 mm (HxWxD)
– Weight: ~25 kg
› Temperature
– -40° C to +55° C
› Cooling
– Self convection / no fans
› Alarms
– 6 (potential-free)
› Power
– -48 V DC (standard) or ~230 V AC (optional)
– Recommended fuse sizes (min/mid/max):
› 16/25/32 A
– Recommended DC cable (shield & ground)
› 6 mm2 up to 60 meters
› 10 mm2 over 60 meters
› Typical Power Consumption*
– 2x40W mode: ~200-400 W (Vodafone DE operation)
– 2x60W mode: ~210-600 W
› Product Number *Note: Preliminary values. Subject to pending local lab tests.
– KRC 161 282/2

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 14
REMOTE RADIO UNIT (RRUS 01 B3)
CHARACTERISTICS for GSM (Preliminary)
› Multi standard radio
– GSM, WCDMA & LTE
– Band 3 - 1800 MHz
– Exceeds 3GPP MSR / MC-BTS Class 2 requirements
› RF
– Single PA, up to 1x80 W
– Up to 4 Carriers GSM
– Typical GSM RX sensitivity (2W-RXD – No TMA):
› -116.9 dBm (TCH/FS static)
› -118.2 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 20 MHz
› Dimensions (with solar shield)
– Size: 636 x 383 x 169 mm (HxWxD)
– Weight: ~20 kg
› Temperature
– -40° C to +55° C (+45° C in 80W / high load)
› Cooling
– Self convection / no fans
› Alarms
– 2 (potential-free)
› Power
– -48 V DC (standard) or ~230 V AC (optional)
– Recommended fuse sizes (min/mid/max):
› 16/25/32 A
– Recommended DC cable (shield & ground)
› 6 mm2 up to 60 meters
› 10 mm2 over 60 meters
› Typical Power Consumption*
– 1x40 W mode: ~145-340 W (Vodafone DE operation)
– 1x80 W mode: ~145-430 W
› Product Number *Note: Preliminary values. Subject to pending local lab tests.
– KRC 161 73/2

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 15
REMOTE RADIO UNIT (RRUS 11 B1)
CHARACTERISTICS for WCDMA
› Multi standard radio
– WCDMA & LTE
– Band 1 - 2100 MHz
› RF
– Dual PA, up to 2x30 W
– Typical WCDMA RX sensitivity (2W-RXD – No TMA)
› -128.3 dBm (TCH/FS static)
› -128.6 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 20 MHz
› Dimensions (with solar shield & handle)
– Size: 500 x 431 x 182 mm (HxWxD)
– Weight: ~22 kg
› Temperature
– -40° C to +55° C
› Cooling
– Self convection / no fans
› Alarms
– 2 (potential-free)
› Power
– -48 V DC (standard) or ~230 V AC (optional)
– Recommended fuse sizes (min/mid/max):
› 16/25/32 A
– Recommended DC cable:
› 6 mm2 up to 60 meters
› 10 mm2 over 60 meters
› Shield & ground
› Typical Power Consumption*
– 2x20W mode: ~180-300 W (Vodafone DE operation)
– 3x20W mode: ~180-350 W
› Product Number
– KRC 161 255/1
*Note: Verified values from jointly executed local lab tests.

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 16
REMOTE RADIO UNIT (RRUS 11 B1)
CHARACTERISTICS for WCDMA
› Multi standard radio
– WCDMA & LTE
– Band 1 - 2100 MHz
› RF
– Dual PA, up to 2x40 W
– Typical WCDMA RX sensitivity (2W-RXD – No TMA)
› -128.3 dBm (TCH/FS static)
› -128.6 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 20 MHz
› Dimensions (with solar shield & handle)
– Size: 500 x 431 x 182 mm (HxWxD)
– Weight: ~22 kg
› Temperature
– -40° C to +55° C
› Cooling
– Self convection / no fans
› Alarms
– 2 (potential-free)
› Power
– -48 V DC (standard) or ~230 V AC (optional)
– Recommended fuse sizes (min/mid/max):
› 16/25/32 A
– Recommended DC cable:
› 6 mm2 up to 60 meters
› 10 mm2 over 60 meters
› Shield & ground
› Typical Power Consumption*
– 2x20W mode: ~180-300 W (Vodafone DE operation)
– 3x20W mode: ~180-350 W
– 2x40W mode: ~180-400 W (Full output power)
› Product Number
*Note: Verified values from jointly executed local lab tests.
– KRC 161 255/2

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 17
REMOTE RADIO UNIT (RRUS 11 B20)
CHARACTERISTICS for LTE
› Multi standard radio
– WCDMA & LTE
– Band 20 - 800 MHz Digital Dividend
› RF
– Dual PA, up to 2x30 W
– Typical LTE RX sensitivity (2W-RXD – No TMA)
according to 3GPP TS36.104
› -109.6 dBm (TCH/FS static)
› -109.6 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 20 MHz
› Dimensions (with solar shield & handle)
– Size: 500 x 431 x 182 mm (HxWxD)
– Weight: ~22 kg
› Temperature
– -40° C to +55° C
› Cooling
– Self convection / no fans
› Alarms
– 2 (potential-free)
› Power
– -48 V DC (standard) or ~230 V AC (optional)
– Recommended fuse sizes (min/mid/max):
› 16/25/32 A
– Recommended DC cable:
› 6 mm2 up to 60 meters
› 10 mm2 over 60 meters
› Shield & ground
› Typical Power Consumption*
– 2x20W mode: ~170-285 W (Vodafone DE operation)
– 2x30W mode: ~170-350 W
› Product Number
– KRC 118 91/1 *Note: Verified values from jointly executed local lab tests.

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 18
REMOTE RADIO UNIT (RRUS 11 B20)
CHARACTERISTICS for LTE
› Multi standard radio
– WCDMA & LTE
– Band 20 - 800 MHz Digital Dividend
› RF
– Dual PA, up to 2x40 W
– Typical LTE RX sensitivity (2W-RXD – No TMA)
according to 3GPP TS36.104
› -109.6 dBm (TCH/FS static)
› -109.6 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 20 MHz
› Dimensions (with solar shield & handle)
– Size: 500 x 431 x 182 mm (HxWxD)
– Weight: ~22 kg
› Temperature
– -40° C to +55° C
› Cooling
– Self convection / no fans
› Alarms
– 2 (potential-free)
› Power
– -48 V DC (standard) or ~230 V AC (optional)
– Recommended fuse sizes (min/mid/max):
› 16/25/32 A
– Recommended DC cable:
› 6 mm2 up to 60 meters
› 10 mm2 over 60 meters
› Shield & ground
› Typical Power Consumption*
– 2x20W mode: ~175-270 W (Vodafone DE operation)
– 2x30W mode: ~175-335 W
› Product Number
– KRC 118 91/2 *Note: Verified values from jointly executed local lab tests.

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 19
REMOTE RADIO UNIT (RRUS 11 B7)
CHARACTERISTICS for LTE
› Multi standard radio
– WCDMA & LTE
– Band 7 - 2600 MHz
› RF
– Dual PA, up to 2x30 W
– Typical LTE RX sensitivity (2W-RXD – No TMA)
according to 3GPP TS36.104
› -109.3 dBm (TCH/FS static)
› -109.3 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 20 MHz
› Dimensions (with solar shield & handle)
– Size: 500 x 431 x 182 mm (HxWxD)
– Weight: ~22 kg
› Temperature
– -40° C to +55° C (+50° C in 2x30W / high load)
› Cooling
– Self convection / no fans
› Alarms
– 2 (potential-free)
› Power
– -48 V DC (standard) or ~230 V AC (optional)
– Recommended fuse sizes (min/mid/max):
› 16/25/32 A
– Recommended DC cable:
› 6 mm² up to 60 meters
› 10 mm² over 60 meters
› Shield & ground
› Typical Power Consumption
– 2x20W mode: ~180-300 W (Vodafone DE operation)
– 2x30W mode: ~180-350 W
› Product Number
– KRC 161 253/1

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 20
REMOTE RADIO UNIT (RRUS A2 B7)
CHARACTERISTICS for LTE (preliminary)

Functionality
Antenna 1 & 2 Antenna 3 & 4
› 4-wax RX diversity feature to improve uplink cell throughput
› Optional 2 RX expansion module for RRUS
› Eases deployment for 4-way RX diversity
› Works with RRUS 01, 11 and 12
› No terminal dependencies

Multi standard radio

› WCDMA & LTE
› Band 7 - 2600 MHz

Dimensions
› Size: 331 x 384 x 85 mm (HxWxD)
› Weight: < 10 kg

Temperature
› -40° C to +55° C

Product Number
› KRC 161 291/1

CPRI Power

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 21
antenna integrated radio (AIR-11)
characteristics 2.0m version
› Radio
– Frequency bands: 800 MHz (B20) active and 900 MHz (B8) passive
– Active part with 2 TX, supporting e.g. 2x2 MIMO, IBW = 20 MHz
› UL: >1 dB better than best in class RRU/TMA + antenna + jumpers
› DL: Equivalent to 2x40 W RRU + 800 10668 antenna + jumpers
(EIRP: 2 x 61 dbm, with 65° nominal beam-width)
– Best in class 65° passive antenna
(Similar to Kathrein 800 10668)
– Integrated AISG2.0 RET, individual per frequency band

› Dimensions
– Size: 1982 x 307 x 239 mm (HxWxD)
– Weight: 39 kg

› Wind load
– Less than for a passive antenna: <1,100 N
(Similar to Kathrein 800 10668)
– Worst direction, static @ 150 km/h wind speed

› Typical Power Consumption*

– 2x20W mode: ~170-260 W (Vodafone DE operation)

› Interfaces
– Two optical fiber ports (CPRI) for active antenna/radio
– One power connector, -48 V DC
– Two 7/16 female connectors for passive antenna, with RET support

› Product Number
– KRC 118 93/3

*Note: Preliminary values. Subject to pending local lab tests.

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 22
Macro RADIO UNIT (RUS 01 B1)
CHARACTERISTICS for WCDMA (Preliminary)
› Multi standard radio
– WCDMA & LTE
– Band 1 - 2100 MHz
› RF
– Single PA, up to 1x80 W
– Typical WCDMA RX sensitivity (2W-RXD – No TMA)
according to 3GPP TS36.104
› -128.4 dBm (TCH/FS static)
› -128.4 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 20 MHz
› Dimensions
– Size: 350 x 61 x 310 mm (HxWxD)
– Weight: 7.6 kg
› Temperature
– +5° C to +50° C
› Configuration
– 4 carriers over 20 MHz IBW
– 4 carriers GSM
– 4 carriers WCDMA or LTE
› Typical Power Consumption*
– 1x40W mode: ~150-240 W (2 carriers)
– 1x60W mode: ~180-320 W (3 carriers)
› Product Number
– KRC 118 75/1 – R2

*Note: Preliminary values. Subject to pending local lab tests.

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 23
Macro RADIO UNIT (RUS 01 B20)
CHARACTERISTICS for LTE (Preliminary)
› Multi standard radio
– WCDMA & LTE
– Band 20 - 800 MHz Digital Dividend
› RF
– Single PA, up to 1x80 W
– Typical LTE RX sensitivity (2W-RXD – No TMA)
according to 3GPP Receiver Sensitivity (for 5 MHz and above)
› -109.6 dBm
› -109.1 dBm
› Carrier bandwidth (IBW)
– 20 MHz
› Dimensions (with solar shield)
– Size: 350 x 61 x 310 mm (HxWxD)
– Weight: 7.6 kg
› Temperature
– +5° C to +50° C
› Configuration
– 4 carriers over 20 MHz IBW
– 4 carriers WCDMA or LTE
› Typical Power Consumption*
– 1x40W mode: ~150-240 W (2 carriers)
– 1x60W mode: ~180-320 W (3 carriers)
› Product Number
– KRC 118 90/2

*Note: Preliminary values. Subject to pending local lab tests.

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 24
Macro RADIO UNIT (RUS 01 B7)
CHARACTERISTICS for LTE (Preliminary)
› Multi standard radio
– LTE
– Band 20 - 2600 MHz Digital Dividend
› RF
– Single PA, up to 1x60 W
– Typical LTE RX sensitivity (2W-RXD – No TMA)
according to 3GPP Receiver Sensitivity (for 5 MHz and above)
› -109.5 dBm
› -108.7 dBm
› Carrier bandwidth (IBW)
– 20 MHz
› Dimensions
– Size: 350 x 61 x 310 mm (HxWxD)
– Weight: 7.5kg
› Temperature
– +5° C to +50° C
› Configuration
– 4 carriers over 20 MHz IBW
– 4 carriers WCDMA or LTE
› Typical Power Consumption*
– 1x40W mode: ~150-240 W (2 carriers)
– 1x60W mode: ~180-320 W (3 carriers)
› Product Number
– KRC 118 30/1

*Note: Preliminary values. Subject to pending local lab tests.

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 25
Macro RADIO UNIT (RUS 02 B3)
CHARACTERISTICS for GSM (Preliminary)
› Multi standard radio
– GSM, WCDMA & LTE
– Band 3 - 1800 MHz
› RF
– Single PA, up to 1x80 W
– Typical LTE RX sensitivity (2W-RXD – No TMA)
according to 3GPP Receiver Sensitivity (for 5 MHz and above)
› -116.7 dBm
› -118.0 dBm
› Carrier bandwidth (IBW)
– 40 MHz
› Dimensions
– Size: 350 x 61 x 310 mm (HxWxD)
– Weight: 7.5kg
› Temperature
– +5° C to +50° C
› Configuration
– 4 carriers over 40 MHz IBW
– 4 carriers WCDMA or LTE
› Typical Power Consumption*
– 1x40W mode: ~170-XXX W (2 carriers @ 20W)
– 1x60W mode: ~180-XXX W (3 carriers @ 20W)
– 1x80W mode: ~190-XXX W (4 carriers @ 20W)
› Product Number
– KRC 161 280/1

*Note: Preliminary values. Subject to pending local lab tests.

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 26
Macro RADIO UNIT (RUS 02 B8)
CHARACTERISTICS for GSM (Preliminary)
› Multi standard radio
– GSM, WCDMA & LTE
– Band 8 – 900 MHz (Enhanced)
› RF
– Single PA, up to 1x100 W
– Typical GSM RX sensitivity (2W-RXD – No TMA):
› -116.9 dBm (TCH/FS static)
› -118.2 dBm (TCH/FS TU50)
› Carrier bandwidth (IBW)
– 35 MHz
› Dimensions
– Size: 350 x 61 x 310 mm (HxWxD)
– Weight: 7.6 kg
› Temperature
– +5° C to +50° C
› Configuration
– 8 carriers over 35 MHz IBW
– 8 carriers GSM
– 4 carriers WCDMA or LTE
› Typical Power Consumption*
– 1x40W mode: ~150-XXX W (2 carriers @ 20W)
– 1x60W mode: ~160-XXX W (3 carriers @ 20W)
– 1x80W mode: ~170-XXX W (4 carriers @ 20W)
› Product Number
– KRC 161 260/1

*Note: Preliminary values. Subject to pending local lab tests.

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 27
AGENDA

› RBS 6000 Overview

› RADIO UNITS
› baseband UNITS
› GSM MC-BTS with RRUS12
› HW Activation Codes

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 28
RBS 6601 MAIN REMOTE
CHaracteristics

› Dimensions › External Alarms

– 66 x 483 x 350 mm (H x W x D) – 8 integrated
– 1.5 height units – 32 alarms via separate support alarm unit (SAU)
– 19” mounting (ETSI) › Deployment Variants
› Weight – Indoor 19” ETSI rack or AIO
– < 10 kg (maximum / fully equipped) – Delta Microcabinet or RBS/SSC 6101
› Climate Control › Power Consumption
– 3 Fans (12 V / max. 0.86 A each) – < 20 W (typical, without DU)
– Temperature range +5° C to +50° C › Product Number
› Power – 1/BFL 901 009/1
– -48 VDC (16/20 A circuit breaker) RBS 6601 Support Shelf
– DC cable size 4 mm² - 2/5/10m length

RBS 6601 with DUG 20 & DUL 20

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 29
Digital Unit GSM (DUG 20)
characteristics

› Transmission
– 4x E1/T1/J1 Interfaces (electrical)

› Dimensions
– Height: 350 mm
– Width: 30 mm
– Depth: 280 mm
– Weight: < 2 kg

› Power Consumption
– Typical: 45 W
– Max: 80 W

› Functionality
– Up to 12 TRX
– Multiple digital units (TG-sync)
– 256 MB Flash ATA (replaceable)

› Product Number
– KDU 137 569/1

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 30
Digital Unit GSM (DUG 20)
Interfaces

6x CPRI ESB E1 1+2 Equipment Power

SFP* HSIO RJ45 Control Bus -48V DC

To Radio E1 3+4 OMT GPS

Units RJ45 RJ45 / RS232 Serial / PPS

* Typical SFP: CPRI, optical, Single Mode, 614.4-2457.6 Mbit/s, 8km, 1310nm, LC Duplex (RDH 102 47/2)

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 31
Digital Unit LTE (DUL 20)
characteristics

› Transmission
– Gigabit Ethernet Interface (electrical, or optical via SFP)

› Capacity per DUL

– 173/56 Mbps (DL/UL)
– Up to 1000 users (HW prepared)
– 3 x 20 MHz with MIMO
– 64 QAM DL & UL support

› Functionality
– S1, X2 and O&M Interfaces
– Sync from GPS, NTP or external clock
– QoS mapping / QCI to DSCP
– IPSec and IPv6 prepared

› Futureproof
– LTE System Architecture Evolution
– Multiple digital units & redundancy

› Product Number
– KDU 137 533/3

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 32
Digital Unit LTE (DUL 20)
Interfaces

6x CPRI GigE GigE Equipment Power

SFP* SFP** RJ45 Control Bus -48V DC

O&M GPS
To Radio Inter DU Link
ETH / RS232 Serial / PPS
Units SFP***

* Typical SFP: CPRI, optical, Single Mode, 614.4-2457.6 Mbit/s, 8km, 1310nm, LC Duplex (RDH 102 47/2)
CPRI cable, 10GBase-KR, electrical, 10 Gbit/s, RI F, if two DUs are used (large configurations) (RPM 777 279/xxxxx)
** Typical SFP: 1000Base-SX, optical, Multimode, 0.55km, 850nm, LC Duplex (1400421-0010)
1000Base-LX, optical, Singlemode, 10km, 1310nm, LC Duplex (1400422-0019)
*** SFP cable: IDL cable, 10GBase-CX4, electrical, 10 Gbit/s, if two DUs are used (large configurations) (RPM 777 263/xxxxx)

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 33
Digital Unit WCDMA (DUW 30)
characteristics

› Transmission
– 4 E1/T1/J1
– STM-1 or GigE

› Capacity per DUW30

– 768/512 CE (DL/UL)
– 252/88 Mbit/s peak through put (DL/UL)
– 84/168 Mbit/s peak data rate (2x/4x MC)
– 90 HSDPA codes
– Up to 512 users

› Functionality
– Optimized for 10 MHz 3x2
– Sync from GPS, NTP or external clock
– Support for TxD, MIMO, 64 QAM, Multicarrier (10 MHz)

› Futureproof
– UL: Multi-Carrier, 16QAM, Interference Suppression
UL: EUL on FACH, TTI based HW allocation
– DL: MIMO+64QAM, MIMO+MC, MIMO+64QAM+MC

› Product Number
– KDU 127 161/3

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 34
Digital Unit WCDMA (DUW 30)
Interfaces

6x CPRI GigE E1 1+2 GigE Equipment Power

SFP* SFP** RJ45 RJ45 Control Bus -48V DC

To Radio Units Inter DU Link E1 3+4 O&M GPS

SFP*** RJ45 ETH & RS232 Serial / PPS

* Typical SFP: CPRI, optical, Single Mode, 614.4-2457.6 Mbit/s, 8km, 1310nm, LC Duplex (RDH 102 47/2)
CPRI cable, 10GBase-KR, electrical, 10 Gbit/s, RI F, if two DUs are used (large configurations) (RPM 777 279/xxxxx)
** Typical SFP: 1000Base-SX, optical, Multimode, 0.55km, 850nm, LC Duplex (1400421-0010)
1000Base-LX, optical, Singlemode, 10km, 1310nm, LC Duplex (1400422-0019)
*** SFP cable: IDL cable, 10GBase-CX4, electrical, 10 Gbit/s, if two DUs are used (large configurations) (RPM 777 263/xxxxx)

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 35
AGENDA

› RBS 6000 Overview

› RADIO UNITS
› baseband UNITS
› GSM MC-BTS with RRUS12
› HW Activation Codes

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 36
RBS6000 2nd generation radio
CHARACTERISTICS PER PRODUCT

GSM RF
Frequency RF
3GPP BW Product IBW Output Power
Band Output Power
IPM*

B0 - 900P 25 MHz RUS 02 B0 25 MHz 100 W 160 W

B0 - 900P 25 MHz RRUS 02 B0 25 MHz 100 W 160 W

B3 – 1800 75 MHz RUS 02 B3 40 MHz 80 W 160 W

B8 – 900E 35 MHz RUS 02 B8 35 MHz 100 W 160 W

B3 – 1800 75 MHz RRUS 12 B3 40 MHz 2 x 60 W 160 W

B8 – 900E 35 MHz RRUS 12 B8 35 MHz 2 x 60 W 160 W

*IPM: Intelligent Power Management / Power Overbooking

CPI Reference: MCPA Handling Guideline - 225/100 56-HSC 103 12

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 37
RBS6000 2nd generation radio
Multi standard mIXED MODE (MSMM)

CAPABILITY OF ONE R/RUS x2

10/15/20 MHz
LTE uses the
capacity of 2,
1 2 3 4 5 6 7 8 3 or 4 carriers
of 5 MHz

4 carriers can only be 4 carriers can be configured as GSM

configured as one carrier or 1.4, 3.0 or 5.0 MHz LTE
GSM carrier each carrier or 1 WCMDA carrier each

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 38
RRUS12 Radio Configurations (G12B)
Radio Building blocks – RBB 22 XX Concept

› RBB22_1B: 2xTX / 2xRX / 1 CPRI

– Configuration Examples
› SCC 1x8
› SCC 2x6
› SCC 3x4
› SCC 8+4
– 12 TRX maximum per DUG
– Up to 48 TRX with TG Synch

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 40
RRUS12 Radio Configurations (G12B)
Radio Building blocks – RBB 42 XX Concept

› RBB42_2D: 4xTX / 2xRX / 2 CPRI / Analog RX Cross Connect

– Configuration Examples
› SCC 1x9 to 1x12
– 12 TRX maximum per DUG
– Up to 48 TRX with TG Synch

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 41
RRUS12 Radio Configurations (G12B)
Radio Building blocks – RBB 44 XX Concept

› RBB44_2C: 4xTX / 4xRX / 2 CPRI / Digital RX Cross Connect

– Configuration Examples
› SCC 1x9 to 1x12
– 4-way RXD
– 12 TRX maximum per DUG
– Up to 48 TRX with TG Synch

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 42
AGENDA

› RBS 6000 Overview

› RADIO UNITS
› baseband UNITS
› GSM MC-BTS with RRUS12
› HW Activation CodeS

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 50
HW activation codes (HWAC)
compared to the traditional way of hw sales

Option 1 – Full Option 2 –Flexible

Instead of purchasing all …buy only what you …and pay when
HW capacity upfront… need today… you need to grow

Non activated HW - opened

Full Capacity with HW Activation Codes

All HW delivered All HW is delivered together Additional capacity is delivered

with an initial HWAC instantly and remotely as HWAC

Traditional example: Traditional example: Expanding capacity

Additional TRX cards

Full Capacity (TRXs) HW is delivered with few TRXs are physically added

HWAC is just like a traditional capacity expansion, but smarter!

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 51
RBS6000 Multi Standard
SALES Model overview
HW HW Activation Codes SW

Business as usual

LTE Bandwidth (Carrier)

RBS 6000 units Throughput UL
LTE (DUL/RRU) Throughput DL
Connected Users

Common HW Activation Codes

WCDMA Carrier
RBS 6000 cabinet

Channel element UL

Output Power
Common HW

RBS 6000 units

WCDMA (DUW/RRU) Channel element DL
HS Codes
IP/Ethernnet

GSM Carrier (TRX)

RBS 6000 units
GSM (DUG/RRU)

RBS 6000

RBS 6000 and HWAC span across the technology standards

RBS6000 for LTE/SRAN Vfe DE | Legally privileged and confidential | EDD-12:001637 Uen, Rev H | 2012-11-16 | Page 52
