Utilities Mapping

plowmancraven.co.uk

t h e t r u s t e d n a m e i n m e a s u r e m e n t
Welcome to Plowman Craven
Plowman Craven is WHY CHOOSE
a leading Chartered PLOWMAN CRAVEN?
Surveying company n Honesty, Integrity and Trust – This is integral to every practice and
decision in the business. Our reputation depends on it.
offering a broad range of
n Client Orientation – Developing great relationships with our clients is key
professional measurement to our success. We work closely with our clients so we can fully understand
and respond to their individual needs.
services. We have built our
n Innovation – Our innovation is what sets us apart, whether we are offering a
reputation through reliable unique product or challenging our methodology to become more effective.
performance and continued n Quality – We are committed to quality at every level of the business.
We understand there is no compromise on this and we continually invest in
investment in both people
technology, staff development and health and safety to ensure we achieve
and technology to become the highest standard of service.

the trusted name in n Professional Approach – We operate worldwide and our access to skilled
and specialist resource allows us to respond effectively no matter the size of
measurement. the project or how challenging.

Head Office London Office


141 Lower Luton Road 33A Clerkenwell Green
Harpenden, Hertfordshire AL5 5EQ London EC1R 0DU
Tel: +44 (0)1582 765566 Tel: +44 (0)20 7490 7700
Email: post@plowmancraven.co.uk Web: www.plowmancraven.co.uk

ELECTRODETECTION Plowman Craven’s specialist in-house utilities division,
ElectroDetection, offers a range of utilities mapping solutions.
Using state-of-the-art technology, ElectroDetection is able to trace,
identify and map underground utilities and service routes including
gas, water, telecommunications, electricity and drainage.

ElectroDetection
The ElectroDetection division offers services which meet
any requirement - from early planning stage through to post-
construction as-built surveys.

WHAT IS UTILITIES MAPPING?


The diversification of the utilities sector in recent years has led
to increasing difficulties in unifying utilities asset information.
This lack of understanding, coupled with incomplete and
inaccurate statutory records, leads to many unknowns and risks.
Pinpointing the exact location of utilities is vital when planning
and undertaking both design and construction work.

A utilities mapping survey by ElectroDetection provides a


comprehensive understanding of infrastructure below ground.

Utilities Mapping enables the client to:

n Have an accurate record of existing and as-built services


n Minimise site disruption and potential delays
n Improve compliance
n Identify potential problems and avoid the risk of costly
asset failures and emergency repairs
n Reduce health and safety risks
n Comply with HSE guidelines
n Mitigate the risk of utility strikes

At ElectroDetection, a dedicated Project Manager is


assigned to each individual project and is responsible
for ensuring all project requirements are met.
All output is checked as part of ElectroDetection’s
standard works procedures in accordance with
the company’s British Standard EN ISO 9001:2008
certification. ElectroDetection is Utilities Vendor
Database Supplier Management Service (UVDB)
verified, a demonstration of our compliance to health,
safety, environment and quality.
TECHNOLOGY
TECHNOLOGY ElectroDetection always uses the latest innovative technology when
undertaking a utilities mapping survey. A variety of tracing methods are
available and each requirement warrants its own unique methodology.

Ground Penetrating Radar (GPR) Surveys


The very latest ground identified as services by
penetrating radar systems are relating the captured data
used to locate buried services to record information and
which cannot be traced by surface features.
other methods such as RFL. By processing our radar
GPR is also used to detect survey through the latest
other buried features such as dedicated software, the
chambers and voids. captured data is filtered
ElectroDetection uses the and enhanced to enable
better data analysis and
Detector Duo (IDS Duo) and
improved service detection.
Mala Easy Locator GPR
The processing software also
systems to locate non-metallic
improves detection of sub-
services and re-confirm the
surface voids and non-service
position of services traced by
features. These features can
RFL methods. be processed straight from
By carrying out a targeted grid the software into AutoCAD as Example of GPR scan in good
of scans, linear below-ground a 3D model compatible with ground conditions
features can be located and Revit models and BIM.

3D Surveys
and BIM
With the rise of Building Information Modelling
(BIM) and other modelling environments, there is
an ever greater demand for survey deliverables
Any Environment Mala Easy Locator in 3D. Using buried service techniques, we have
the ability to present service survey information
in a variety of 3D formats, including REVIT®.
These deliverables enable the user to gain a
significantly enhanced understanding of the
layout and location of buried services when
compared to 2D data.

IDS Duo

GROUND PENETRATING RADAR AND RADIO FREQENCY LOCATION -


COMMON MISCONCEPTIONS AND LIMITATIONS
There is a perception that all buried pipes, cables and ducts can be According to the American Society of Civil Engineers;
detected and mapped irrespective of their size, duty, depth, location, “In good ground conditions and within the depth range
material type, geology and proximity to other utilities. of two metres, the ability to detect a utility will reduce in
A well designed and executed survey should detect up to around diameter by 1mm for each 10mm of depth. i.e. a 200mm
95% of utilities, but it may not be possible to achieve 100% detection pipe can be detected at 2m and a 50mm pipe at 0.5m,
rate. Often, the situation is not ideal for GPR due to the soil or ground but a 25mm plastic water service pipe to a house cannot
conditions being unsuitable. In addition, some services are too small be detected at 1.2m with radar”.
and buried too deep for the GPR to identify them.
TECHNOLOGY

Radio Frequency
Location (RFL)
RFL technology works by As the RFL signal can be drawn to other
connecting directly onto a pipe at services, this technology works at its best when
a valve pit and tracing the radio the concentration of services are less dense.
signal along the route of the pipe. Although the exact location of a service cannot
always be pinpointed, the presence of a service
Low voltage electricity routes are
is noted and should be taken into consideration
traced by connecting to a surface
for any future planned works.
feature such as a lamp-post, or
by clamping the cable within an n Accurately map routes of underground
inspection chamber and tracing the metallic, water and gas pipes, cable
signal along the route of the cable. ducts and other metallic services
Once all known services have been n Identify cable services such as
located, the site is then scanned to telecoms, cable television and CCTV
check for any unrecorded services. n Where services cannot be directly
These unrecorded services are connected, the transmitter can be placed
then identified and added in order on the ground directly above and a signal
to complete the survey. induced into the cable

Laser Scanning
Depending on the requirements and specifications of a project, ElectroDetection may
use state-of-the-art laser scanning instrumentation. 3D laser scanning and advances
in high-dynamic range photography have led to quicker surveys, greater accuracy and
easier interpretation of complex underground locations.
3D laser scanning provides:
n Rapid site date collection – 1,000,000 points per second – and particularly
valuable where site access is limited
n Non-contact measurement – reduces risk and safety constraints using
inverted scanning techniques
n Completeness of data – all information in the scan view is collected –
eliminating the need for return visits
n Permanent point in time archive for condition monitoring
n Collaborative and virtual site visits with TruView™ imagery

TruView™ combines scan data with 360° high dynamic range photography
in order to create the ultimate in virtual environments. It enables a user to
move around easily within a visual tour of the scanned site and its real-time
measurement tools allow every user to pan, zoom and investigate the area
from the comfort of a desk.
TECHNOLOGY After construction of a new site, utility owners often require a non-biased
investigation of the location and condition of all utility components before
accepting ownership.

Adoption Surveys
ElectroDetection provides independent survey advice and specialises in providing the following types of Adoption Surveys.

DRAINAGE ADOPTION SURVEY AS-BUILT SURVEY


A Drainage Adoption survey will confirm the manhole positions, An As-Built survey provides detailed information on utilities to
pipe levels and condition prior to the utility provider taking over determine exact routes of all services as-built rather than as-
ownership of newly constructed sewers: designed.

n Position Inspection covers onto Ordnance Survey (OS) Benefits


mapping data using GPS
n Accurate record of actual construction
n Provide levels to covers related to OS datum
n Independent confirmation of construction specification
n Full cover/chamber details (size/type/chamber material/
n Protection for ground workers from utility strikes
invert depth/pipe material and sizes/flow direction)
n Risk mitigation should a clash occur with other planned
n Manhole data cards for each manhole to include location or future works
sketch and chamber sketch

CASE STUDY

As-Built Survey
The survey below was carried out on a new housing development where subsidence had
occurred and where the foundations of each property needed to be reinforced.
The underground utilities were fully traced and mapped, including every service connection,
to reduce the risk of service strikes.
The results enabled the remedial works to be carried out without damage to the services.
CASE STUDY

Road Mapping
In conjunction with a major minimum, ElectroDetection
redevelopment around adopted the innovative
Earls Court in West London, approach of using a multi-
ElectroDetection was channel radar array towed
commissioned to carry behind a vehicle. Using the
out underground services specialist vehicle meant the
surveys at each of the fieldwork could be carried out
major road junctions around over four nights rather than
the complex. The roads the original estimate of four
concerned were some of weeks, and approval from the
most congested in the area Local Authority was obtained
and included North End Road within minutes.
and Warwick Road.
The reduced timeframe
In order to carry out these on site appealed to the
surveys a comprehensive Local Authority which was
traffic management plan naturally concerned about
was devised and extensive the disruption to residents,
approvals were sought from particularly at night. The
the Highways Department, quality and quantity of the
Transport for London, Bus survey data collected proved
operating companies, and to be more than satisfactory
other relevant organisations. and some unknown structural
data was also obtained
In order to keep traffic
alongside the service routes.
management requirements
and congestion to a Vehicle based GPR system

Underground services using Underground services at busy


mobile mapping road junction
TECHNOLOGY

Example of TruView™ model and ‘unwrapped’ panoramic image

Using the latest Leica total station surveying equipment, a specialist


ElectroDetection team can accurately survey the line and level of
man-entry sewers and pipes.

Line and Level Surveys


ElectroDetection has many years of Profiles of pipes can be measured at
experience in carrying out line and level specified intervals and at locations where
surveys in sewers, river culverts, cable the pipe size or shape changes.
tunnels and on Rail and Underground
Large diameter pipes and tunnels can also
infrastructure. Results of survey
be scanned and photographed to create
measurement can be processed to create
a fully measurable TruView™ model and
2D drawings with level information, a 3D
panoramic images.
wireframe model showing pipes in correct
x,y,z position, or as a full 3D CAD surface n Accurate position of deep level
model. pipes which cannot be located
A photographic record can also be using surface techniques
compiled to show the internal condition of n Photographic record of condition
the pipe and relevant features. n 3D model enables detailed design
All line and level surveys are carried for new connections
out in accordance with confined space
regulations using industry leading safety
and rescue equipment.
CASE STUDY

Inverted Scanning
The manhole chambers were surveyed
using an innovative solution whereby
the Leica 6000 3D laser scanner was
lowered into each chamber using an
inverted tripod.
Data was collected at several levels
including at the surface, that when stitched
together, created a 3D scan cloud of the
whole chamber.
The 3D data captured enabled the
accurate plotting of each manhole
chamber and associated pipes without
having to access the chamber. The scans
even managed to help determine the
direction of the pipes entering and leaving
the chambers.
As part of large topographical and
underground services survey at Three n No confined space entry necessary
Bridges Rail Depot in Sussex, the route of
n Rapid data collection reduces
a large diameter, deep level Thames Water
site time
sewer was identified. The pipe depth meant
that it was not possible to accurately survey n 3D chamber and localised pipe
the route without confined space access model created
and this was not permitted.

CASE STUDY

Wall Scanning
In 2012, London Underground (LU) in two directions on a pre-set grid.
commissioned ElectroDetection to The data from these scans was then
undertake radar scans of the walls merged, thus obtaining a ‘cloud’ of data.
and floors of St Mary Abchurch, a The software then allowed the user to
Christopher Wren designed church in the pan through the various levels and view
City of London. The huge redevelopment elevation data through the wall.
of Bank Station beneath the streets
The delivered 3D data enabled London
of London posed a serious risk to the
Underground’s engineers to understand
historic buildings above and LU needed
how the walls of the church were
to establish whether the structure of the
Church could withstand excavations constructed. The survey data allowed
planned below. the team to identify weak points and
formulate a methodology to monitor
The original plan was to carry out
and protect the church during the
core-sampling through the walls, but
excavation and construction phases.
this was rejected by the Diocese. As a
result, ElectroDetection developed an The number of core samples required
alternative methodology. Using the IDS to be drilled was reduced significantly
DUO ground penetrating radar unit, and potential damage was limited.
ElectroDetection scanned the floors of n Void detection – Chimney flues,
the Church to locate both known and poor construction, structural
previously unknown crypts. The walls
changes
were then scanned using the hand-held
MALA CX Imaging System. n Reinforcing detection – rebar,

3D scans were undertaken and a series tension cables


of closed-centred grid scans were taken n Hidden services – cable trunking
TECHNOLOGY
TECHNOLOGY ElectroDetection can trace interior below ground drainage routes and locate
service in-takes and meters.

Building Services Tracing


By lifting all inspection to scan building slabs to
covers, ElectroDetection check for the existence of LIMITATIONS
will accurately trace all main other buried services. Often, internal drainage systems penetrate through metallic
drainage routes and prove are sealed by metal plates objects.
GPR can also be used
connections from WC’s, (hatch-boxes) within inspection
to identify below ground Another limitation to internal
sinks and down pipes by dye chambers to eliminate the
structures and voids. GPR drainage surveys is that
testing and/or electronically release of odour into the building.
scans can only be carried out inspection covers are often
tracing pipe work. Although these can be removed,
on flat, open areas and, to be designed to fit in with the
Positions of all service able to identify below ground no guarantee can be given that surrounding floor. Tiled covers
intakes and meter points are structures, a number of scans the seal will be replaced tightly. that are not loose often cannot
surveyed and photographed are required to create a grid. Also, pipework beneath buildings be lifted without the specific
with meter numbers recorded. is usually cast iron to avoid the manhole keys for each type of
Scans are then post-
risk of collapse. In this case, cover. ElectroDetection’s survey
Using Radio Frequency processed in the office to
pipes cannot be electronically vehicles carry a large variety of
Locators (RFL) and Ground identify linear features and
traced as the signal from the manhole keys suitable for the
Penetrating Radar (GPR), marked changes in the
ElectroDetection is also able underlying structure. transmitting probe cannot majority of cover types.

Internal below ground drainage survey Internal heating survey Internal services can also be surveyed in
3D for incorporation into BIM/Revit models

CCTV
Using the latest high specification and written report highlighting quality video capture.
equipment and industry standard faults, if any, in the system and Reports are fully coordinated
software, ElectroDetection can provide recommendations for with a utility mapping survey to
deliver detailed pipe condition rehabilitation and repair. provide accurate information
surveys. ElectroDetection will also arrange on all routes including ‘blind’
ElectroDetection will present the cleaning of the sewer system connections.
the client with a colour DVD prior to survey to ensure best

Still image showing pipe in good condition Still image showing pipe with corrosion
FURTHER INFORMATION

Health and Safety Executive The Survey Association


The Health and Safety Executive has published a booklet The UK’s Survey Association has published a useful guide to
which outlines unseen dangers arising from working utility surveys which specifies differing levels of survey.
near underground services. It provides guidance on risk Typically, a utilities survey would be to level 4, where all covers
reduction, especially concerning ground penetration or are lifted, contents detailed and service routes traced using
below surface operations. A copy can be downloaded from RFL and GPR techniques. The GPR is used in “mark out”
the Health and Safety Executive website: Booklet HSG47 - mode with results viewed on-site.
‘Avoiding danger from underground services’
Survey levels 5 and 6 are enhanced versions of level 4. Here,
the GPR data is recorded on-site and post-processed for
For more information click here further analysis. The difference between levels 5 and 6 is the
density of the scan grids that are undertaken. The more dense
the grids, the more comprehensive the survey is likely to be.

For more information click here

Plowman Craven
Offices, Industrial and Residential n Area Measurement Surveys n Engineering Surveys

Urban Regeneration n Measured Building Surveys n Deformation Monitoring


Transport n Rail Surveys
n Heritage Recording Services
Retail n Underground Utilities Surveys
n Lease Plan and Boundary Surveys
Police and Security n Laser Scanning Services
n Rights of Light Surveys
Utilities n 3D and Building Information Modelling
n Estate Management Services Services
Government and Public Bodies

Film and Entertainment n Infrastructure Surveys n Film and Entertainment Scanning

Heritage, Arts and Leisure n Topographical Surveys n Police and Security Services

Head Office London Office


141 Lower Luton Road 33A Clerkenwell Green
Harpenden, Hertfordshire AL5 5EQ London EC1R 0DU
Tel: +44 (0)1582 765566 Tel: +44 (0)20 7490 7700
Email: post@plowmancraven.co.uk Web: www.plowmancraven.co.uk

You might also like
