Encoder Quick Reference guide

www.encoder.com | 1-800-366-5412
 www.encoder.com | 1-800-366-5412

The Accu-Coder™ Advantage

Company History­
Encoder Products Company, Inc. (EPC) is a leading designer and
world-wide manufacturer of motion sensing devices. Founded in
1969 by William Watt, EPC began operations with a small line
of custom encoders. Now, almost 50 years later, EPC's popular
Accu-Coders™ are recognized for their exceptional quality. Our
core philosophy is that each and every customer deserves quality
products, superior customer service, and expert support.
Business Partnerships
Fostering long-term business partnerships with satisfied customers
is what we do best, and it’s the heart of our mission. We take pride
in providing superior customer service and supplying you encoders
that function precisely, dependably, and flawlessly. Listening to our
customers’ needs, and designing products that provide solutions for
you, is a key to our success.
Solving Problems
At EPC, we believe that an encoder supplier should solve problems,
not cause them. For almost 50 years, we have been solving encoder
problems with custom designs, faster delivery, and reliable products.
Custom Encoders ARE Our Specialty
Through years of experience, we understand each industrial
environment is different; you need an encoder that fits your specific
situation. This ultimately means not having to make do with
someone else’s specifications or configurations, but having your own
custom-designed unit. Many of our customers have come to depend
on us for this specialty. We can design and deliver custom encoders
faster than most suppliers standard products – often shipping
your unique encoder in 2 to 6 days. Some models can even ship
overnight.

ISO 9001 Quality Systems

Innovative Design Team
At EPC, quality is designed into every product. Before it's offered for
At EPC, we concentrate on encoders, and we’ve been responsible
sale, each Accu-Coder™ model is developed and fully tested against
for many “firsts” in encoder innovation:
EPC's exacting quality standards. But quality control does not stop
at design; during the manufacturing process, each Accu-Coder™ is
First to design the cube style encoder, now an industry standard.
subjected to a series of stringent quality control tests to ensure you
 irst to resolve mounting installation problems by providing
F
are receiving the best encoder available. Our quality system has
flexible-mounting systems.
successfully been audited to the requirements of ISO 9001:2008,
First to include Opto-ASIC technology, which virtually eliminates
an internationally recognized standard for comprehensive Quality
miscounts by eliminating electrical noise, and enhancing signal
Systems. Because we pay close attention to detail, our Accu-
quality.
Coder™ brand is known throughout the industry for quality and
First to provide encoders that operate at 120° C.
reliability.
First to provide 6000 CPR in a 1.5" diameter encoder.
First to provide a 3-year standard warranty, demonstrating that
we proudly stand behind the reliability of each of our products.

EPC’s North American manufacturing facility and world headquarters in Sagle, Idaho.

For Complete Product Information And Details Visit www.encoder.com

 Incremental Thru-Bore & Motor Mount Encoders
Model 15T/H Ø1.5”
• High performance economical encoder
• Low profile – 1.0” (25.4 mm) height
and 1.5” (38 mm) diameter
• Resolutions to 10,000 CPR
• Simple, innovative flex mounting system
• Bore sizes to 0.375” or 10 mm
• Up to 12 pole commutation available
• Operating temps: -40° to 120° C
• Sealing up to IP64
Model 260 Ø2.0”
• Low profile – 1.19”
• Resolutions to 10,000 CPR
• Bore sizes to 0.625” or 15 mm
• Thru-bore and hollow bore (blind) styles
• Operating Temps: -40° to 120° C
• Up to 12 pole commutation
• Incorporates Opto-ASIC technology
• CE marking available
• Simple, innovative flexible mounting system
• Sealing up to IP64
Model 225A/Q Ø2.25”
• Single channel and quadrature
• Economical tachometer/motor feedback
• Bore sizes to 0.875” or 22 mm
• A variety of connector options
• Available with flexible mounting arm
Model 775  Ø4.3”
• Available with a variety of bore sizes,
resolutions, and connector types
• Bore options to 1.375”
• Incorporates Opto-ASIC technology
• CE marking available
• Easy over-shaft installation
• High temp option 0° to 100° C
Model 770 Ø6.5”
• Fits NEMA frame size 56C thru 184C motors
• Slim profile – 1” deep
• Resolutions to 4096 CPR
• Bore sizes to 1.00” or 24 mm
• Incorporates Opto-ASIC technology
• Large selection of connector options
• Operating temps: 0° to 100° C
1 S u p e r i o r De s i g n
Model 755A Ø1.5”
• Miniature size (1.5” diameter)
• Resolutions to 30,000 CPR
• Bore sizes to 0.750”, or 14 mm
• Frequencies to 1 MHz
• Flexible mounting brackets
• Operating temps: -40° to 100° C
Model 121 Ø2.1”
• Patented auto-aligning mounting
• Resolutions to 2500 CPR
• Bore sizes to 0.625” or 15 mm
• Up to 12 pole commutation available
• Operating temps: 0° to 100° C
• Includes IP50 dust seal kit
Model 25T/H Ø2.5”
• Single replacement solution for 2.0” to 3.5”
encoders
• Resolutions to 10,000 CPR
• Standard bore sizes ranging from 0.250” to 1.125”
• Metric bore sizes ranging from 6 mm to 28 mm
• Frequencies to 1 MHz
• A variety of flexible mounting options
• 2.5” Opto-ASIC encoder with a low profile (2.0”)
• Corrosion-resistant option
• Operating Temps: -20° to 105° C
• Sealing up to IP66
Model 776 Ø4.3”
• Fits directly on shaft where position, direction,
or velocity information is needed.
• Slim profile – only 1.36” deep
• Bore options to 1.875”
• Thru-bore design for easy mounting
• Incorporates Opto-ASIC technology
• High temp option 0° to 100° C
Model 771 Ø9.0”
• Standard double C-Face
• Fits NEMA frame size 182TC thru 256TC
• Resolutions to 4096 CPR
• Bore sizes to 1.875” or 43 mm
• Incorporates Opto-ASIC technology
• Operating temps: 0° to 100° C
• Optional protective cover provides IP65 Seal
 Incremental Shaft Encoders
Model 15S Ø1.5”
• Wide variety of mounting options
• Resolutions to 10,000 CPR
• Up to 12 pole commutation available
• Operating temps: -40° to 120° C
• Sealing up to IP64

Model 702 Ø2.0”

• NEMA motor mount options available
• Resolutions to 30,000 CPR
• Shaft sizes to 0.375” or 10 mm
• 80 lb. max. radial and axial load
• Operating temps: 0° to 100° C
• Sealing up to IP67
Model 758 Ø58 mm
Model 15 Incremental Encoder in use for inline labeling
Model 755A Ø1.5”
• Variety of servo and flange mounts available
• Resolutions to 30,000 CPR
• Available with in-line M12 connectors
• NEMA motor mount options available
• Frequencies to 1 MHz
• Operating temps: -40° to 100° C

• Clamping or synchro flange options

• Resolutions to 30,000 CPR
• 80 lb. max. radial and axial load
• Operating temps: 0° to 100° C
• Sealing up to IP67
Model 725 Ø2.5”
• Industrial isolated flex housing available
• Resolutions to 30,000 CPR
• Frequencies to 1 MHz
• Operating temps: 0° to 100° C
• Sealing up to IP67

Classic Cube Encoders - MODELS 711, 715 & 716

• The original Cube Encoders
• Compatible with most:
Programmable controllers
Electronic counters
Motion controllers
Motor drives
• Single channel, quadrature, and timed pulse
• Versatile housing styles, from Standard to
Ultra-Heavy Duty
• Resolutions to 10,000 CPR
• Single and double shaft options
• Unidirectional or bidirectional output
• Single chip design Industrial Housing (IND12) Heavy Duty Housing (HD12) Ultra Heavy Duty Housing (HD10)

For Complete Product Information And Details Visit www.encoder.com

2 Quick Delivery
 Absolute Encoders See encoder.com for more information on configurations and options.

multi-turn
Model MA36S Ø36 mm Model MA36H Ø36 mm
• Standard Size 36 mm package (1.42”) • Standard Size 36 mm package (1.42”)
• Multi-turn absolute encoder (12 Bit/39 Bit) • Multi-turn absolute encoder (14 bit/39 bit)
• Shaft sizes to 0.250”, or 6 mm • Shaft sizes to 0.250”, or 6 mm
• SSI and CANopen communications • Durable magnetic technology
• Durable magnetic technology • SSI and CANopen communications
• Proven new turns counting technology – no • Proven turns counting technology – no gears
gears or batteries or batteries
• Can record position information without • Flex mount eliminates couplings and is ideal
external power for motors or shafts
• Shaft sealed to IP65 • Can record position information without
external power
Model MA63S Ø2.5” • Sealed to IP65
• Standard Size 25 package (2.5” x 2.5”)
• Multi-turn absolute encoder (14 Bit/39 Bit)
Durable magnetic technology – no gears or
batteries
• Shaft sizes to 0.375”, or 10 mm
• Servo and flange mounting
• SSI and CANopen Communications
• Can record position information without
external power
• IP67 sealing available

Single turn
Model 925 Ø2.5”
• Flange and servo mounts
• Industrial housed 2.5” single turn absolute
• Shaft sizes to 0.375”, or 10 mm
• Gray, natural binary, and excess gray codes
• Parallel output Model 725 Incremental Shaft Encoder installed on a large motor
• Sealing up to IP67

Model 958 Ø58 mm Model 960 Ø2.0”

• Industrial housed European Size 58 mm • Low profile - 1.55” single turn absolute
• Shaft sizes to 0.375” or 10 mm • Resolutions to 11 Bits
• Gray, natural binary, and excess gray codes • Bore sizes to 0.375” or 10 mm
• Clamping or synchro flange options • Opto-ASIC circuitry in an all metal housing
• Sealing up to IP66 • A variety of flexible mounting brackets
• Sealed to IP50

Model SA36H Ø36 mm Model SA36S Ø36 mm

• Flex mount eliminates couplings and is ideal • Standard Size 36 mm package (1.42”)
for motors or shafts • Up to 14 bits of single turn resolution
• Standard Size 36 mm package (1.42”) • Shaft sizes to 0.250”, or 6 mm
• Up to 14 bits of single turn resolution • Durable magnetic technology
• Bore sizes to 0.250”, or 6 mm • SSI and CANopen communications
• SSI and CANopen Communications • Shaft sealed to IP65
• Durable magnetic technology
• Sealed to IP65

3 E x c e pti o n a l Va l u e
 Stainless Steel Encoders
Model 802S Ø2.0”
• Industry standard
Size 20 (2” diameter)
• Flange and servo
mounting
• Up to 30,000 CPR
• 80 lb maximum axial
and radial shaft loading
• Up to IP67 sealing
available
• 0° to 100° C Operating
temp option
Model 858S Ø58 mm Model 865T Ø6.5”
• Industry standard • C-Face thru-bore encoder
Size 58 (58mm • Fits NEMA Size 56C thru
diameter) 184C motor faces (4.5” AK)
• Up to 30,000 CPR • Slim profile – only 1.00”
• 80 lb maximum axial deep
and radial shaft • Incorporates Opto-ASIC
loading technology
• Temp options from • Resolutions to 4096 CPR
-40° to 100° C • 0° to 100° C Operating
• Up to IP67 sealing temp option

Linear Encoder Solutions

Model TR1
• Encoder and measuring wheel solution
integrated into one compact unit
• Spring-loaded torsion arm makes wheel
pressure adjustments a snap
• Easily installed in a vertical, horizontal or
upside down orientation
• Operates over a variety of surfaces at speeds
up to 3000 feet per minute
• Temp options from -40° to 100° C
• Up to IP66 sealing
Model TR2
• Encoder with rack-and-pinion gear
integrated into one compact unit
• Easily installed in a vertical, horizontal or
upside down orientation
• Operates at speeds up to 400 feet per
minute
• Spring-loaded torsion arm eliminates gear
backlash
• Temp options from -40° to 100° C
• Up to IP66 sealing

Model TR3 Model LCE

• Integrated heavy duty encoder and measuring • Low cost linear solution
wheel in one • Resolutions from 2 - 500 cycles per inch
• Available in single or dual wheel configuration. • IP65 sealing available
• Spring-loaded torsion arm for quick wheel • Cable measurement from 0 to 50”
pressure adjustments
• Easily installed in a vertical, horizontal or
upside down orientation
• Operates over a variety of surfaces at speeds
up to 3000 feet per minute
• Temp options from -40° to 100° C
• Up to IP67 sealing

Encoder modules
Model 30M Ø30 mm
• Magnetic incremental encoder module
• Compact 30 mm (1”) size
• Available with 8-pin Molex, 16-Pin Molex, or 8-pin M12 connector
• Large air gap and tolerance to misalignment 30M 8-Pin Molex
• Both 5 VDC and 5 to 28 VDC supply voltage input options
• Up to 1024 CPR (4096 PPR with Quadrature Counting)
• Optional 2, 4 or 8 pole commutation
• Sealing options to IP69K 30M 16-Pin Molex
• Temperature range -40° to 120° C
• Easy alignment and installation
• Advanced magnetic sensing and signal processing technology
• Can be configured for a wide range of industrial, commercial, and consumer feedback applications
30M 8-Pin M12

For Complete Product Information And Details Visit www.encoder.com

4 expert support
 Cross-Reference Chart
In the chart below, encoder models are referenced by Model Number. See each model for more information.

Incremental Absolute
Hollow or Incremental Hollow or Absolute Magnetic Stainless
Thru-Bore Shaft Thru-Bore Shaft Linear Incremental Steel
Low Temp 15S, 755A, 702,
15T/H, 755A, MA36H, TR1, TR2,
Option 725, 758, TR1, MA63S 30M 802S, 858S
260, 25T/H SA36H TR3
(≤ -20° C) TR2, TR3
High Temp 15T/H, 755A, 15S, 755A,
TR1, TR2, 802S, 858S,
Option 260, 121, 775, 702, 725, 758, 30M
TR3 865T
(≥ 100° C ) 776, 770, 771 Cubes

702,725, 758, 925, 958, 802S, 858S,

Heavy-Duty* 702, 770, 771 TR3, LCE
Cubes MA63S 865T

925, 958, 802S, 858S,

Harsh Duty** 25T/H TR3 30M
MA63S 865T

15S, 755A,
15T/H, 755A, TR1, TR2,
≥ 10,000 CPR 702, 725, 758, 802S, 858S
260, 25T/H TR3
Cubes

≥ IP67 Seal 702, 725, 758 MA63S TR3 30M 802S

25T/H, 775,
≥ 1-inch bore 865T
776, 770, 771

Slim Profile 15T/H, 260,

30M 865T
≤ 1.5 inch 776, 770, 775

NEMA C-Face 25T, 260, 770,

865T
Mount Option 771

Integrated
TR1, TR2,
Measuring
TR3
Wheel

925, 958,
Single Turn 960, SA36H
SA36S

MA36S,
Multi-turn MA36H
MA63S

*Heavy Duty – Heavy-duty encoders offer various options that allow them to operate in heavy-duty industrial conditions. Various options include:
heavy-duty housing options; high and/or low temperature options; and heavy-duty bearing options, to handle heavier loads.

**Harsh Duty – Harsh-duty encoders can tolerate caustic environments. Various options include: high and/or low temperature options; corrosion-
resistant features and options; and higher IP seal options.

5 3 y e a r wa r r a n t y
World Wide Manufacturing Locations
World Headquarters
Americas Division
Encoder Products Company
464276 Highway 95
PO Box 249
Sagle, Idaho 83860
USA
Phone: 800.366.5412
208.263.8541
Fax: 208.263.0541
Email: sales@encoder.com
Web: www.encoder.com

Europe Division
British Encoder Products Company
Whitegate Industrial Estate, Unit 33
Wrexham, Clwyd
Wales LL138UG
United Kingdom
Phone: +44.1978.262100
Fax: +44.1978.262101
Email: sales@encoder.co.uk
Web: www.encoder.co.uk

Asia Division
Zhuhai Precision Encoder Co., LTD
RM. 308C, 3/F
Zhongdian Building
No. 1082 JiuZhou Ave.
Ji Da District, Zhuhai City
Guangdong Province, PRC
Phone: +86.756.3363470
Fax: +86.756.3363573
Email: EPC-Asia@163.com
Web: www.asiaencoder.com

Encoder Quick Reference guide rev 3/16 © 2016 Encoder Products Company. All rights reserved.
