Become a Rapid Developer

Module 7
Automating Processes within an App
7. Automating Processes within
an App
7.1 Automating Processes
You might have experienced that filling out long forms can be quite a tiresome process. Manually entering
names, addresses, postcodes, and dates can take some time, and therefore make the experience of the user
less pleasant.

As a Mendix Developer, you always want to keep your users’ needs a top priority. Microflows are your number
one tool in the quest to make the user’s journey as pleasant as possible. They allow you to build custom
functionality based on the specific needs of your users.

Do most of your users use the app on their phone while travelling? Do they need to fill out the same
information multiple times? Can some information be filled in automatically based on data that you already
have? These are all questions you need to ask yourself when thinking of how you can make your app more
effective.

If the answer to one or more of these questions is yes, then Mendix has a solution for you! By using microflows
you can automatically fill in data in the app. For example, in the LearnNow app, when you know the start date
of a training event and the duration of the course, you can automatically fill out the end date of the training
event. You can also automatically calculate the total number of registrations, or pre-fill certain fields when you
create something new from a certain page. That will definitely save Jimmy some time and allow him to focus
on improving his business.

In this module you will learn how to use Mendix Studio Pro to make your app more efficient by adding custom
logic using microflows. In detail, you will learn how to:
• Set up a widget event to trigger a microflow
• Create a microflow to change objects and values
• Solve errors to ensure your microflows work as intended
• Give indications to the users on what information they still need to fill out

Go ahead to the next lecture to learn how to automatically calculate the end date of a training event!

7.2 Automatically Fill out End Date

Currently, when Jimmy wants to schedule a training event, he has to fill out all the details manually. However,
he could save time and keep his data consistent by having the end date calculated automatically, based on the
start date of the training event and the duration of the course. This will save Jimmy some work, but it also
eliminates the chance of Jimmy accidentally selecting the wrong end date!

2
In the image below, you can see that, when Jimmy selects a Course and Start Date for a Training Event he is
about to create, the End Date is automatically calculated. Note that European date format is used in the
images of this course.

Let's formulate a plan for building this functionality. You will need a couple of steps:

1. The first step is to make sure the microflow is triggered. As the start date or the course type determines
the end date, a trigger should be set there. You can create this trigger by using a widget event. You
will need to add a widget event to the start date input widget and the course selector. The widget event
will trigger a microflow that calculates the end date. Obviously, you will need to create the microflow
itself as well.
2. The second step is to fill out the calculated end date. For this you will need to change the
TrainingEvent (Change Object activity) and set the new EndDate value. You are going to use
a microflow expression for this, the addDays function to be specific. This function adds a number of
days (the duration of the course) to a date (the start date).
3. After that, you deploy the app and test the functionality by entering data in the detail page in every way
possible and see if you can cause errors.
4. The next step is to learn how to analyze any errors that may have occurred, and adjust the microflow to
prevent these errors from happening again.
5. Finally, you will commit your work.

All these steps will be explained in more detail as you go through the assignments in this module.

3
7.3 Triggering a Microflow from an Input Widget
Let's start with the first step: making sure the microflow is triggered when the user changes the course or the
start date of a training event.

As mentioned in the previous lecture, input widgets are typically used to show data to the user and allow them
to edit data. Some examples of input widgets are the check box, date picker, radio buttons, drop down, and
text box. As you can see in the image below, the Course can be selected in the Training Event detail page
using a drop down. Also, the Start Date of the training event is selected using a date picker.

In the same way that buttons can trigger events when the user clicks on them (for example open a page, or call
a microflow), input widgets can do the same! The difference with input widgets is that the events can be
triggered at three different points:
• On enter: when the user enters (clicks on) the input widget
• On change: when the user leaves the input widget after making a change
• On leave: when the user leaves (closes) the input widget (no matter whether they changed the value of
the widget or not)
When using an input widget, one of the events you can select on enter, change, or leave, is “Call a microflow”.
You can use microflows to immediately check the value of a field and give immediate feedback to the end user.
You can also use input widgets to calculate values based on input changes and give this back to the end user
immediately.

4
For example, the input widget that changes the StartDate value can trigger a microflow:
• On enter: The microflow will be triggered once the user clicks on the agenda icon
• On change: The microflow will be triggered once the user changes the start date of the training event.
This could also mean that they change the value of the StartDate from “no selection” to a specific date.
• On leave: The microflow will be triggered once the user opens the date picker and then closes it again,
whether they changed the date or not.

Can you guess when you want to trigger the microflow that you will use to automatically calculate the end date
of the training event? Go to the next lecture to see how you can do it!

7.3.1 Set up the Input Widgets

In this assignment you will see how you can call a microflow from an input widget to fill out the end date of a
training event automatically. The microflow will calculate the following: EndDate = StartDate + Duration.

The StartDate is selected in the date picker input widget, and the Duration depends on the Course that is
selected in the drop down input widget. Therefore, as the user can change both the course and the start
date, you will need to set up both those input widgets to trigger the microflow! Let’s start with the first one.

Start Date Input Widget (Date Picker)

1. Open the TrainingEvent_NewEdit page. Double-click on the start date input widget to open its
properties. A pop-up window opens. There are four tabs in this window: General, Common, Events, and
Appearance. Open the Events tab. In this case you want to calculate the end date when the start date
has changed, so you need an On change event.
2. Set the On change event to Call a microflow. A selection window opens which allows you to select
one of the existing microflows or create a new one. The microflow to calculate the end date doesn't
exist yet. Click New to create a new microflow.
3. Remember the naming convention for microflows? Prefix_Entity_Operation. The prefix for an On
Change event is OCH. Give the microflow a clear name, according to the naming convention. This way
it will be easier for another developer to interpret what it is and what it does, should the need arise. A
good name is: OCH_TrainingEvent_CalculateEndDate.

5
Course Input Widget (Drop Down widget)
As each course has a different duration, the end date also changes when a (different) course is selected. This
means the course selector also needs to trigger the same microflow.
1. Go back to the view of TrainingEvent_NewEdit add an On Change event to the course selector and
connect the OCH_TrainingEvent_CalculateEndDate microflow to it.

6
2. Open the newly created microflow. See how it has a TrainingEvent parameter? This represents the
TrainingEvent the end user is currently creating or editing.

7
7.3.2 Build the Microflow
Let’s dive into the microflow. If you want to refresh your knowledge about microflows, check Module 5 of this
learning path.

The goal of this microflow is to use the start date of the training event and the duration of the course to
calculate the end date of the training event. For this you will need to change the TrainingEvent (Change
object activity) and set the new EndDate value. You are going to use a microflow expression to calculate the
new end date: the addDays function. Microflow expressions are where you get to write a little bit of code, to
add even more custom logic to your app. The addDays function adds a number of days (the duration of the
course) to a date (the start date).

1. The first thing you need to do is add an Action activity to the microflow and then convert it to a Change
object. Do this by clicking the activity icon in the microflow toolbar and then clicking on the flow. You
can also get specific activities and microflow elements from the toolbox.

2. Place the Action activity close to the end event. Remember you always start with the end result! Now,
to convert to a Change object you right click the Action activity and set the action type to Change
object. After doing this, double-click the activity again to open its Properties. The object you are about
to change is the TrainingEvent object, so select that as the input variable.

8
You want Jimmy to be able to make changes to an event, see it, and have it displayed so that his teachers and
trainees can view it. So now you need to think about what this means in terms of committing changes to the
database immediately, and whether the client should be refreshed. The training event should only be stored in
the database (committed) when the end user clicks the save button in the app. The desired end result is to
show the calculated end date immediately in the app, so we need to refresh the client. This means you don't
have to commit the training event now. You do have to refresh the client so that it shows the changed
information. If you don't refresh the client, the information will be changed in the runtime, but the change won't
be visible to the end user.

You will learn more about the database and client in lecture 7.6 of this learning path.

3. Underneath Refresh in client, click New to add a change. The Edit Change Item pop-up will open. First
you have to select which Member you will change. A member is either an attribute or an association. In
this case you want to change the EndDate attribute, so select that in the dropdown. Immediately, the
expression editor (the big text area) becomes editable.

9
The expression editor is where you are going to write some code to add custom logic to your app. In the next
lectures you are going to learn how you can do that!

10
7.4 Microflow Expressions
To calculate the number of days, you need to make some calculations in your Microflow. To do that, you
will need to make use of expressions. Expressions are the closest you will get in Mendix Studio Pro to
writing code. With them you can create functions, build checks and change values.

Your biggest friend when writing microflow expressions is the keyboard shortcut ctrl + space. When you
use this shortcut, you will get a list of all the elements you have available to you to create your microflow
expression.

The following types of element are available:

• Functions: there are many functions available to change or compare values or to extract information
from values. An exhaustive list can be found in the Microflow Expressions. You can also access that list
by pressing F1 while in the expression editor. Functions always need parentheses () after them to
work. Inside the parentheses you place the ingredients the function needs to work its magic! So it's
functionName(Ingredient 1, Ingredient 2).
• Variables contain a single object, a list of objects, or a primitive (single) value. A variable always starts
with a $ (dollar sign) and the name of the variable. Every piece of data in a microflow is stored in a
variable and has a unique name.
o For example, the Trainee object is stored in the $Trainee variable. Attributes of an object are
added behind the variable: $Trainee/EmailAddress.
• Tokens are DateTime related, except the Current User token. Get a list of suggestions by typing [.
o For example, to use the current date and time, use [%CurrentDateTime%].
These are some general expressions:
Type Expressions
Arithmetic * : + -
Relational < > <= >= = !=
Special checks empty isNew
Boolean and or not
If expressions If then else

Examples of Microflow Expressions

• You can use the round function to round a number. If the value of the variable Number is 0.99, then the
outcome of the function round($Number) will be 1.

11
• You can use the toLowerCase function to transform text to lowercase. For example, if the variable Name
has ‘BeStName3veR’ as the value, then the toLowerCase($Trainee/Name) function will set the value of
Name to ‘bestname3ver’.

7.4.1 Create an Expression to Calculate the End Date

From the previous assignment, the Expression Editor is open. That will allow you to enter the function which
will calculate the End Date of the Training Event. You will need the addDays function. In this case, the
addDays function will add the duration of a course to the start date.

1. Click inside the microflow expression editor and press ctrl + space. Start typing addDays and, once
you see it in the list of options, select it by pressing Enter or double-clicking it.
2. Now add the parentheses after the addDays function. The function becomes red. This is because
Mendix Studio Pro now recognizes it as a function and is telling you there are ingredients missing.
Mendix Studio Pro even tells you which ingredients are missing and in what order they should be
placed between the parentheses. In this case the first ingredient is a Date and time value and the
second ingredient an Integer or Long.

12
3. So the function will be addDays(Date and time, Integer/Long) or, if you relate that to your Domain
Model and the calculation you are creating: addDays([start date], [duration]).
4. Go ahead and see if you can place both attributes between the parentheses. A couple of important
things to remember:
• Always use ctrl + space, don't just start typing blindly.
• Attributes of an object are always written after the variable representing that object (so start from
the variable, not directly with the attribute). Notation: $[VariableName]/[AttributeName].
• Separate the ingredients by placing a comma in between them.

5. Could you add the Duration ingredient? Most probably not! This isn't your fault though! You can access
the StartDate from within the TrainingEvent variable that is available in the microflow
($TrainingEvent/StartDate). You can even see which Course was selected
($TrainingEvent/MyFirstModule.TrainingEvent_Course). You can't however then go into Course by
typing / again to get to the Duration. Learn more about how you can tackle that in the next lecture!

13
7.5 In the Microflow’s Scope
When you have an object available to you in a microflow (this is also called in the microflow’s scope), you
have access to all the information inside the object (the attributes) and the objects it is connected to (the
associations), as you can see in the image below. You don't have access to the information inside those
objects though.

So, the TrainingEvent object is in the microflow’s scope and the StartDate is inside that object so it's also in
scope. Because the Duration is in the Course object, it is not in scope yet. You will need to get it into your
microflow: you need to do a retrieve. You will learn what a retrieve is and how to do a retrieve in the following
lectures.

14
7.6 Retrieving Data
As we have seen, sometimes data you need for your microflow isn’t in scope when you start building the
microflow. The way to bring it into scope is by using a retrieve. A retrieve is an activity in a microflow, just like
the Change object and Create object activities. Specifically, a retrieve looks for a specific object in a list of
objects and makes it available in the microflow.

When you do a retrieve, you need to decide where you want to get your information: from memory or from the
database. First let's take a look at where your data is at what point.

15
Let’s start with an example. When you start writing a text document, you boot up your computer, start your text
editor, and open a new document. At that moment you see your text document on your screen (1), and the
document is loaded in memory (2). When you make changes, they are visible on the screen (1), and are
recorded in the device’s memory (2). If you close the document without saving it, the document that’s in
memory will be deleted (4) and the document won’t exist in memory or on the hard drive anymore.

However, if you save the document, it is stored on the hard drive (3) and, when you close the document, the
document that was in memory will be deleted (4) but will remain on the hard drive (3). When you reopen the
document (3), it will be loaded into memory (2) and will be visible on the screen. When you make changes to
the document, they’ll be stored in memory (2). When you save the document, the saved file on the hard drive
(3) will be updated with the changes that are in memory (2). But, if you cancel the changes, the changes in
memory will be deleted (4), and the document copy on the hard drive will remain as the original saved
document.

So, you might be wondering, what does this have to do with a Mendix application?

16
Let’s look at another example. When you add a new location to the application, the user clicks the new button,
which results in the creation of a new empty Location object in memory (2). The object is then sent to the client
(1), where you can edit it. When you make changes, they are visible in the client (1) and will be recorded in
memory (2). If you don’t save it, and cancel the Location object, you will close the page. The Location object as
stored in memory will be sent to the garbage bin (4). The Location object won’t exist anymore in memory (and
there was never a Location record in the database).

However, if you save the Location object, it will be stored in the database (3) as a new record, and the Location
object held in memory will be sent to the garbage bin (4). Once you reopen the Location details, the Location
record stored in the database (3) will be loaded into memory (2) as the Location object and will be visible in the
client. When you make changes to the Location object, these changes will be recorded in memory (2). Once
you save the changed Location object, the database record (3) will be updated according to the changes in
memory (2). Or, if you cancel the changes, the Location object as recorded in memory will be sent to the
garbage bin (4), and the Location record in the Database will remain as the original saved object.

It is important to see the similarity of the interactions here in the following ways:

17
 • client <–> memory <-> database
• editor <-> memory <-> hard drive

7.7 By Association Retrieve

Doing a retrieve from memory in Mendix is called a “By Association Retrieve”. This means the app will look in
memory for the requested information first. If it isn't in memory yet or if the information could be outdated
(because the information is older than a certain threshold), the app will get its information from the database.
When the information is already in memory, the By Association retrieve is faster than a Database retrieve. This
is because no connection to the database is needed. This is one of the benefits of using a By Association
retrieve.

Another reason to use the By Association retrieve is when you want to retrieve information that isn't in the
database yet. Remember the jam example? Let's say you are making a new type of jam. The director wants to
sample the new flavor. This jam isn't available in the warehouse (the database) yet, so you'll have to get the
sample straight from the production line (memory).

An object that has been created in memory is called a transient object. Retrieving by association will include all
information in the database, as well as transient objects that are available in memory. This can be useful, like
in the example above with the new jam flavor, but it can also be a risk.

Let's go back to the jam factory. The director wants an overview of all jam types that are currently being sold.
The new jam flavor which is being produced and tested now, but hasn't been approved for sale yet, shouldn't
be in this list. This means you will have to ask the warehouse employee for the list (the database) and not the
production line employee (memory).

So, transient objects are always included in a By Association Retrieve. If you don’t want transient objects to be
included, use a From Database Retrieve.

7.7.1 Retrieve your Data

Time to get that Course object into the scope of your microflow! As microflows work sequentially, from left to
right, the Course object needs to be retrieved before the Change object activity. Otherwise it won’t be in
scope for the microflow expression in the Change object activity.

1. Place a new activity on the microflow line (to the left of the Change object activity) and double-click the
new activity to set the type of action. Select Retrieve.

You now need to decide what your data source is going to be: By association or From database. In
this case it needs to be By assocation. There are two reasons for this:
• You may create a new TrainingEvent, where the information isn't in the database yet. The
Course object is, but the connection to the Course isn't and that is the starting point of the
retrieve.
• You may be editing an existing TrainingEvent and have changed the Course type. If you would
look up the connection in the database, you would get the old Course type, not the one you just
selected.
18
2. Click Select to select the association you want to use for this retrieve, in other words: which object you
want to retrieve. Select the TrainingEvent_Course association. Click Select and in the next screen click
Ok.

3. Open the Change object activity and go back to the addDays function. You now have the Course
object in scope as the $Course variable, so you have access to the Duration attribute. Complete the
microflow expression as shown below:

19
7.7.2 Run, Test, Crash
Time to test your app! Run Locally and play around with it. Remember the goal is to try and break the
application, so be creative and try scheduling a training event in every possible way.

20
 Yeah you did it! Usually an app crashing isn't something to celebrate. In this case however it was the goal
of the assignment and now you will learn how to debug your app to figure out what is wrong. The minute
you select the course or StartData your app will crash!

7.7.3 Analyze Errors

The next step is to analyze the errors.
1. In Mendix Studio Pro open the Console. This is the local log of your app and this is where error
messages will appear if your app crashes.

2. The two red lines at the bottom represent the error that you just triggered. Double-click on the line that
has the paperclip icon to investigate it further. When errors like this occur, Mendix tries to give you a
very clear log message, to give you a good starting point of how and where to fix the error.

21
 3. In the message you can see the name of the microflow that the error occurred in (highlighted in red in
the following image). It's the OCH_TrainingEvent_CalculateEndDate microflow that you are currently
building! Let's do some debugging do see what is causing the error.

Tip: If you want to know more about creating log messages within Mendix, take a look at the Advanced module
Error Handling.

4. Open the OCH_TrainingEvent_CalculateEndDate microflow and right click on the first activity. Click
Add breakpoint. A red dot should appear at the bottom right corner of the activity. This breakpoint will
pause the microflow when it passes this activity, allowing you to investigate the microflow step by step.

5. Go back to your app, refresh the browser and repeat the steps you took to make the app crash (select
the Course or Start Date). The Mendix icon in your taskbar will start flashing when the microflow is
paused.

6. Go back to Mendix Studio Pro. Make sure you have the Debugger and Variables windows visible (if you
don’t go to View, then Debug windows click on those options). Setting up your Mendix Studio Pro like

22
 the following image, with the Debugger and Variables windows displayed side by side, is
recommended.

7. The activity with the red border around it, is the activity that the microflow is currently paused on. It
pauses before the execution of the activity, so the retrieve hasn't been done yet at this point. Click Step
over in the Debugger window to go to the next activity. Investigate the Variables window to see if you
can figure out what's going wrong.

23
 8. The Course was retrieved successfully, but the StartDate is empty. This will cause the addDays
function to crash, because one of the two ingredients is still missing. This makes sense though,
because when filling out the details of the new training event you can't select both the Course type and
the start date at the same time. If you had chosen a start date first, you would get the exact same
crash, only then the Course object would be missing instead of the start date. How can you prevent this
from happening? By building in checks to see whether all necessary ingredients are there, before
executing the addDays function.
9. Click Continue in the Debugger window to finish the debugging process.

7.7.4 Using Decisions

You build checks into a microflow with decisions, the yellow diamond-shaped component. In this case you can
use it to check whether both a start date and a course have been selected, before allowing the microflow to
continue.

You will need two decisions in this microflow, one to check the start date and one to check the course.

1. Place a decision on the microflow line, in between the two existing activities. Double-click it to open its
properties. The first thing you should decide on is the Caption. This will be displayed on the decision. A
24
 good caption will allow you to understand what the decision checks, without having to open it. This
decision will check whether the start date has been selected, so a good caption would be: Start date
selected?
2. The next thing you need is the microflow expression. This is where you define what needs to be
checked. Checking whether the selection has been made will result in a true or false outcome. The
true value should always represent the positive outcome, in other words when the check results in a
true, the microflow continues. When the result is false, the execution is canceled. To make sure that
the true value represents the 'everything is ok' outcome, you need to write the check (or question) in a
way which may feel counterintuitive at first. Instead of asking whether start date is empty (this is the
value if no selection has been made), you are going to ask whether it is NOT empty. Is not is written as
!=. The expression in this case is $TrainingEvent/StartDate != empty.
3. Click OK to go back to the microflow.
4. The arrow coming out of the decision is now red. This is because the flow doesn't know which value
from the decision it represents. It's basically having a bit of an identity crisis! Right click the arrow and
then set the condition value to true. This flow now represents the everything is ok outcome and
continues to calculate the end date. The decision also needs a flow for the false path. Click the bottom
corner of the decision and draw a line downwards. On release select End event. This path
automatically becomes the false path because this decision only has two possible outcomes. So if one
path is true, the other one is automatically false.

5. Repeat these steps to build the decision that checks whether the Course has been selected.
Remember that the Course object is stored in the $Course variable. You need to check whether that
variable is empty or not.
6. Use the following image to check your solution.

25
7. Full microflow should now look like this:

26
7.7.5 Finish the Microflow
The final steps are to finish the microflow, to save your work, and commit it.
1. Right click the first activity and click Remove breakpoint to remove the breakpoint. This way the app
will no longer pause and go into the debugger when the microflow is triggered.
2. Run the app again (Run Locally) and try scheduling a training event. There is one error left, but this is
a different kind of error. The app won't crash any longer, so what could it be? Take a look at the date
that is being calculated and see if you notice the problem. If you don't see it, create a course with a
duration of one day and schedule that course. The end date is one day later than the start date, but a
course that lasts one day starts and finishes on the same day! The addDays function basically adds 24
hours, so the function is correct but not completely what you need here. Let's change the logic a little
bit!
3. Go back to the microflow and open the Change object activity. Edit the addDays function so it adds the
duration of the course, minus one day. This way a course that lasts one day will now start and finish on
the same day. Simple add “– 1” after $Course/Duration to achieve this.

4. Do one last round of testing and then continue with the last step!

27
7.7.6 Commit Your Work
Congratulations! You have automatically calculated the end date and have now made the scheduling of
training events more efficient in three different ways! Time to commit your work and update the status of the
user story.

5. Open the Changes pane, you will find it at the bottom of Mendix Studio Pro.

There are currently two changes.

6. Click Commit to start the commit process. Mendix Studio Pro first does an automated check for
updates and after that the commit window will open.
7. In the Commit dialog box in Mendix Studio Pro, click the Changes in model tab. Here you can also
see the changes you are about to commit to the Team Server.

28
 8. Next, open the Related stories tab again and select the task for automatically calculating the end date.
You’ll find it in the fourth user story.
9. The text area above the tabs is where you have to enter a commit message. This is required to go
through with the commit. It is of course always a good idea to make this commit message a descriptive
one. How about: “Added two on change events to the TrainingEvent_NewEdit page, on the Course and
StartDate input widgets. Added a microflow that calculates and shows the correct EndDate based on
the Course and the Startdate”.
10. Click OK. The commit will take a couple of seconds. Once it's done, there will be 0 changes left in the
Changes pane.
11. Now, go to the Developer Portal to check out your commit! On your app project page in the Developer
Portal, click Team Server to see all the commits. Your commit is all the way at the top, because it is the
last commit.
12. Click Details for your commit to go to the View Revision page where you can read more about the
details of the revision.
13. Go back to Mendix Studio Pro and open the Stories pane. Set the current user story to Done.

7.8 Automatically Calculating the Total Number of

Registrations
Jimmy has one last request for custom logic, as described in the next user story: As a teacher, I want to be
able to see the number of trainees attending a training event at any time, so that I know what resources
I need.

Each training event can host a maximum of 12 trainees. However, it would be a waste of money if the teacher
always ordered lunch or prepared handouts for 12 people, if there are only 6 trainees coming to a training
event. It would therefore be very useful if the teachers could easily see how many people are registered for
each training event.

To build this functionality, you need to take a couple of steps:

1. Make sure you can see the information in the app
2. Determine when the number of registrations should be calculated.
3. Build the microflow that calculates the total number of registrations.
4. Deploy and test your work.
5. Commit your changes to the team server.

Check the next lecture to learn more about the difference between stored and calculated attributes!

7.9 Stored vs Calculated Attributes

You want to show a new piece of dynamic information in your app: the total number of registrations per training
29
event. If you want to show dynamic information in your app, it needs to be represented in the Domain Model as
an attribute. In this case the total number of registrations says something about the training event, so you add
the new attribute to the TrainingEvent entity. A good name for this new attribute is TotalNumberOfRegistrations
and the type is Integer. You can have one or seven or twelve registrations, but never one and a half
registration or eight and three quarters registrations.

You also need to decide whether this attribute will be a stored or calculated attribute. The value of a stored
attribute is saved in the database. The value of a calculated attribute is calculated when it needs to be shown
in the app. The calculation is done by a microflow. Note that this microflow will be triggered every time the
value is shown or used in the app.

The rule of thumb when it comes to deciding between a calculated or a stored attribute is the following: if a
value changes more often than you look at it, make it a calculated attribute. If you look at it more often than it
changes, store it in the database.

A good example for a calculated attribute is if you want to show the latest exchange rates in an app. These are
values that change all the time. That is why it is a good idea to make this a calculated attribute. Now let’s see
how that plays out for the TotalNumberOfRegistrations attribute.

30
As stated earlier a maximum of 12 people can attend a training event. For a fully booked training event that
means the total number of registrations changes 12 times. Now let’s say some of the trainees cancel their
registrations and other trainees register in their place. That would mean the total number of registrations
changes 16 to 20 times at most. This won’t happen all that often and most likely the teachers using the app will
look at the information more often than this takes place. So in this case, the total number of registrations
should be a stored attribute.

7.9.1 Add a New Attribute

1. Go ahead and add the attribute TotalNumberOfRegistrations to the TrainingEvent entity. As explained
in the previous lecture, it should be a stored attribute of the type Integer. This attribute also needs to be
shown to the teachers in the app. A good spot for that would be on the TrainingEvent_Overview page.
This way, when the teacher looks at his schedule, he immediately sees how many people are
registered for each training event.
2. Open the TrainingEvent_Overview page and add the attribute to the list view. From the Toolbox, add
the text widget underneath At {…/Name}. Double-click it to open its properties. Click the topmost Edit
button to edit the caption.
3. Add a new parameter (dynamic text) by clicking New. Select the TotalNumberOfRegistrations attribute.
4. The caption is the text that will be shown to the teacher. Replace Text with Number of registrations: {1}.
The {1} will be replaced by the TotalNumberOfRegistrations parameter.

31
Here’s what it should look like at the end:

7.10 Object Event Handlers

You have decided that you are going to store the total number of registrations in the database. Now you need
to determine when this number changes, in other words when you are going to (re)calculate and store it in the
database. When does the total number of registrations for a training event change? Exactly! When a new
registration is added to the system or when an existing registration is deleted. And not just in some cases, no,
every time a registration is added or deleted the total number of registrations needs to be recalculated.

You already know how to create buttons that trigger a microflow. You could add the logic for this user story to a
custom save and a custom delete button. Every time a teacher adds or deletes a registration the total number
32
would be recalculated. However, if an automated process were to delete a registration (for example when the
trainee that the registration belongs to is deleted), the recalculation wouldn’t happen, because those specific
buttons aren’t clicked. This means the custom buttons aren’t the answer to the problem. You need object event
handlers!

Object event handlers “listen” to the app, waiting for events to occur. Events are when an object is created,
committed, deleted or rolled back (canceling of changes). You can then select a microflow that can be
triggered before or after the event is executed. In the case of your current user story you need an after commit
and after delete object event handler. You add object event handlers to the Domain Model, on the entity that
the event occurs on. In this case that is the Registration entity. Let’s add them now!

You need two object event handlers: one for after commit and one for after delete of a registration. Both
object event handlers will use the same microflow (this microflow doesn’t exist yet). It is a best practice to
reuse logic when possible, because this makes your app easier to maintain later on. By making both event
handlers trigger the same microflow, you reuse logic!

Follow the instructions in the next lecture to see how you can add object event handlers in your app!

7.10.1 Add Object Event Handlers

You need two object event handlers: one for after commit and one for after delete of a registration. Both
object event handlers will use the same microflow (which you will also need to create).

1. Open the Domain Model and double-click on the Registration entity. The fourth tab is the Event
handlers tab. Open this tab and click New to add a new event handler.

33
 2. First you will set up the after commit object event handler. Set the Moment to After and the Event to
Commit. Click Select to select the microflow that should be triggered.
3. Click New to create a new microflow. You now need to come up with a good name for this microflow.
Remember the naming convention Prefix_Entity_Operation?

These are the prefixes for the object event handlers:

Before After
Create BCR ACR
Commit BCO ACO
Rollback BRO ARO
Delete BDE ADE

34
4. Because this microflow will be for both the After Commit and After Delete, you have to add both
prefixes to the name of the microflow. Like this:
ACO_ADE_Registration_SetTotalNumberOfRegistrations.

5. Click OK in this screen and in the next screen to finish the process.
6. Now repeat these steps to add the After Delete object event handler, but instead of creating a new
microflow, select the ACO_ADE_Registration_SetTotalNumberOfRegistrations microflow you just
created.
7. Close the properties window of the Registration entity and look at the entity in the Domain Model. See
how there is a lightning bolt to the left of the entity name? This tells you that this entity has one or more
object event handlers.

35
7.10.2 Create a Registration List
1. Open the ACO_ADE_Registration_SetTotalNumberOfRegistrations microflow. It is an empty microflow with
an input parameter of type Registration. This is the registration that was just committed or deleted. Let’s
formulate a plan for building this microflow:
• The end result of this microflow is to store the total number of registrations in the TrainingEvent object
owning the registration that was just committed or deleted. You also want to show the updated value in
the client (in that case, in the Training Event Overview Page).
• This TrainingEvent object isn’t in scope of the microflow yet, so you need to retrieve it. This retrieve
needs to be by association. It is by association and not from database because if the Registration
object was just deleted from the database, the connection to a TrainingEvent also won’t exist in the
database anymore. It does however still exist in the input parameter of this microflow.

2. To get the TrainingEvent in scope, add a new activity just after the start event of the microflow. Set the
type to Retrieve, the source to By association and from the Registration entity select the
Registration_TrainingEvent association.
3. To store the number of registrations for each training event, add a new activity just before the end
event. Set the type to Change Object and from the variable list, select the TrainingEvent. Click New
and select the TotalNumberOfRegistrations attribute. Set the value to $Count (this won’t work at this
moment, but don’t worry – you’ll create this variable in a later step). Also, change the Commit to Yes.
Otherwise the registrations go away, and the count is zero when the app is closed and opened up
again.

36
Now you have the beginning and the end of the microflow. But the microflow doesn’t really do anything yet.
What you need to do next, is to determine the total number of registrations and set this as the new value
(change it) of the TrainingEvent object.

Since the microflow doesn’t know whether the After Commit or After Delete object event handler was triggered,
you can’t use a +1 or -1 solution. Instead, you need to count all Registrations that belong to this
TrainingEvent. But you don’t have all Registrations in scope of the microflow yet, only the one that was just
committed or deleted. This means you have to do another retrieve!

As a reminder: An object that has been created in memory but isn't in the database (yet) is called a transient
object. Doing a by association retrieve will include all information in the database, plus the transient objects
that are available in memory. In this case you don’t want transient objects to be counted, because you only
want those registrations that have been stored in the database. If you have registrations that exist in work
memory, but not in the database yet, you don’t want to count them in this microflow. You need to do a from
database retrieve!

4. Add a new activity to the microflow, directly after the first retrieve activity. Set the type of action to
retrieve and the source to From database. Click Select to select which entity should be retrieved.
5. In the following image you can see that there are two options to select the Registration entity. One at
the bottom of the select window (underneath MyFirstModule) and one that is nested in the
TrainingEvent variable at the top of the window. If you were to use the bottom option, you would get all
Registrations in your microflow. That’s not what you want here, you only want those Registrations that
belong to this TrainingEvent. That is why you should use the nested option at the top of the screen, so
you use the TrainingEvent as a constraint.

37
6. The Name will automatically be set to RegistrationList, because it is a list of registrations. The last
step is to count the registrations and set the value of the TotalNumberOfRegistrations attribute to this in
the Change object activity. Counting is done with an activity (what a surprise!), the Aggregate list
activity. Add a new activity to the microflow, directly after the second retrieve. Set the type of action to
Aggregate list. Use the following settings to configure the activity:

7. Your microflow should now look like this:

38
Run and Test the App
8. Congratulations, you have built the functionality! Time to see it in action! Run your app and add a
couple of registrations to a training event to see it work.
9. You might be asked to synchronize your database due to the changes we did to the Domain Model.

Commit your Work

10. Once you have added a couple of registrations to your app, go ahead and commit your new
functionality to the team server. Also set the user story to Done. You are doing great!

39
7.11 Summary
In this module you have learned how to automate certain processes within your app. Specifically, you have
learned:

• How to automatically fill out fields, such as the end date of a training event, when the course and start
date are given
• How to trigger a microflow from an input widget
• What microflow expressions consist of
• How to write microflow expressions
• What it means for an object to be in scope of a microflow
• What retrieving data is
• How to do a retrieve by association
• How to analyze errors
• How to use decisions
• How to automatically count objects, such as the total number of registrations
• The difference between stored and calculated attributes
• What object event handlers are and how you can add them to your app
• How to retrieve a list of objects, such as a registration list

Congratulations! Your users are going to be happy with the improvements you made! Move to the next module
to learn how you can make sure that all the data that your users can add is consistent and valid!

40
7.12 Knowledge Check
1. When do you use in the retrieve action the option “by association”?
a. Always when you want to retrieve an associated object.
b. When you want to retrieve the associated object from memory.
c. When you want to retrieve the association of an object.
d. Only when you want to retrieve an associated list.

2. Which statement is true?

a. Microflow expressions are used to change, check and extract data from available values.
b. Microflow expressions are used to define a query on the database.
c. Microflow expressions are used to express the flow of a microflow.
d. Microflow expressions are used to document the microflow actions.

3. Which activity is used to change the value of an attribute?

a. Change attribute
b. Change object
c. Change variable
d. Change value

4. Within a given expression addDays(Date and time, Integer/Long), what do you call the 'Date and time'
parameter?
a. Fuction
b. Data type
c. Token
d. Variable

5. Which of the key combinations provides you with a set of available variables, functions and tokens
within the expression editor?
a. CTRL+Space
b. Shift+Space
c. Alt+Space
d. Tab+Space

6. Which members of an object available in a microflow are considered to be in the scope of that
microflow?

41
 a. Attributes of the entity
b. Associations of the entity
c. Attributes and associations of the entity (correct)
d. Attributes and all entities accessible via association

7. You would like to add 2 new attributes to an entity. The attribute A will be changed more often than
viewed and the attribute B will be viewed more often than changed. How should you create the
attributes A and B?
a. Both calculated
b. Both stored
c. A - calculated, B – stored
d. B – stored, A – calculated

Answers:

1-b, 2-a, 3-b, 4-b, 5-a, 6-c, 7-c;

42
 Mendix is the fastest and easiest platform to build and
continuously improve mobile and web applications at scale.
Recognized as a market leader by leading analysts, we help our
customers digitally transform their organizations and industries by
building, managing, and improving apps at unprecedented speed
and scale. More than 4,000 forward-thinking enterprises, including
Kuehne + Nagel, KLM, Philips and North Carolina State University
use our platform to build business applications to delight their
customers and improve operational efficiency.

Learn more at Mendix.com

43
