 S E R I E S DM G A T E V A L V E S DEMCO

The premier design in the oil
and gas drilling market, Demco
Series DM Gate Valves are
specifically engineered for the
rigorous requirements of oilfield
applications.
Designed for dependable, heavy duty per-
formance in abrasive service conditions,
Demco DM gate valves are commonly
selected for a number of oilfield applica-
tions, including:
• Pump manifold block valves
• High pressure mud mixing lines
• Standpipe manifolds
• High pressure drilling system
block valves
• Wellheads
• Well treating and frac service
• Production manifolds
• Production gathering systems
• Production flow lines
The Demco series DM gate valve is
offered in two basic pressure classes:
The ANSI series valves conform
to the standard flange dimension and
pressure requirements for ANSI classes
400, 600, 900 and 1500. Except for the
4" class 1500, these valves are designed
with economical, double acting threaded
stem & gate. The 4" 1500 use the same
rising stem design used in the 4" 3000
API series valve.
The API series valves conform to the
standard flange and pressure require-
ments for API classes 2000, 3000 and
5000. Except for the 4" and larger API
5000, these valves are designed with
heavy duty, double acting rising stems.
Both series are offered with threaded,
weld and flanged end connections. End
connection availability varies by size and
pressure based on market requirements.
Some sizes in the ANSI series are offered
with grooved end connections.

Sight lens for open/close indication

(4" 5000 psi and larger).

Heavy duty, rising

stem design with
thrust bearings.
Stem seal assembly prevents
leakage into the stem area
for protection and long life.

Bonnet is easily removed

for in-line service.

Unique seat design

provides drop tight
shut-off, easy
maintenance.

4" and larger API 5000 Series DM Gate Valve

(12 bolt bonnet design shown - 10,000 psi test)

F E A T U R E S A N D B E N E F I T S p1
 S E R I E S DM G A T E V A L V E S DEMCO

Features/Benefits thread protection is provided by a special

stem seal assembly.
A In-line field repairability
The 4" and larger 5000 psi DM gate
The bonnet is easily removed for internal
valve includes a sight lens to view the
parts inspection and/or replacement with-
stem for determining gate position.
out removing the valve from the line.
This design simplicity permits fast and Exclusive seat design for drop
easy service without the need for special tight sealing
tools. The Demco Series DM gate valve seat
uses a unique design to provide a drop tight
Flexible trim offerings
shut off in abrasive and erosive service.
3" ANSI 900/1500
Optional materials for stems, gates, seat
inserts and seat elastomers make it easier The seat consists of two identical
to trim valves for a wide range of service metal wear rings encapsulated in elas-
conditions. Three internal plastic coatings tomer to form a cylindrical shape with a
for the body and bonnet are offered to gate slot and two round ports. The closed
improve resistance to wear and corrosion. gate bears on the downstream wear ring
B
while the elastomer provides a drop-tight,
Double acting thread design for
pressure responsive seal around the port.
C fast operation
The cylindrical seat assembly fits
The ANSI series double acting
into the matched body cavity and is
thread design uses a threaded stem into
expanded outward toward the valve ports
the gate working with threads in the bon-
by the bonnet and spread ring in the
net and handle assembly. Stems are pol-
bottom of the seat. The expansion occurs
ished and include a dependable o-ring
when the bonnet is tightened onto the
and anti-extrusion seal. This unique
body while engaging the seat pin
design is economical and effective.
extensions from both wear rings. The
(note: 4” 1500 valve is a double acting,
spread ring ensures the seat elastomer
4" API 3000
rising stem design, similar to the 4” 3000
presses uniformly against the body bore.
valve.
This design ensures a tight seat seal
The API series double acting threads against the body and around each valve
D
work together in a specially designed port and has proven to be effective even
stem screw, screw housing and stem if the gate and seat ring become scored
arrangement (except 4" and larger 5000 is or abraded during service.
C
a single thread, heavy duty rising stem When it comes time for maintenance,
B design with bearings). the seat's single piece design makes it easy
The rising stem design protects the to pull out of the body for replacement.
stem threads from the lading. Further

SPECIFICATIONS See page 7 for technical specifications.

F
Sizes Stem, gate and seat inserts:
E ANSI Series: 1-1/2" - 8"x 6" Steel and Stainless Steel
API Series: 2" - 6"x 5" Seats: Buna N, Viton

4"API 5000 (4 bolt design shown) Pressure Class Optional Materials

ANSI Series: 400, 600, 900 & 1500 Gate: Monel, Aluminum Bronze
API Series: 2000, 3000, 5000 Seat: Hypalon
Standard End Connections Industry Standards Compliance*
Threaded,Weld and Flanged Ability to comply with NACE, ABS,
Standard Materials DNV, Lloyds and other stringent
Body & Bonnet: Steel industry standards.

E * Valves not monogrammed to 6D or 6A

F E A T U R E S A N D B E N E F I T S p2
 S E R I E S DM 7500 G A T E V A L V E S DEMCO

Meeting the tough, 7,500 psi
working pressure demands of
deep well drilling is the Demco
DM 7500 gate valve. The DM
7500 comes to this market with
proven technology from the
industry leader.
When the market demanded a 7,500 psi
drilling mud valve, the Demco DM 7500
gate valve was introduced to meet the
challenge. This is fitting since Demco
DM API gate valves (2,000 to 5,000 psi)
continue to be the premium drilling mud
valves of choice, as they have been for
more than 30 years.
The Demco DM 7500 is available
in sizes 2" to 6" with butt weld end or
flanged end connections.
Engineered specifically for the high
pressure requirements of deep well
drilling, the Demco DM 7500 gate
valve is chosen for the following drilling
applications:
• Standpipe manifolds
• Pump manifold block valves
• High pressure drilling system block
valves
• High pressure frac service
Features/Benefits
Floating slab gate design
A slab gate with “T” slot stem connection
allows the gate to float to the seat provid-
ing a tighter pressure responsive seal.

Sight lens allows operator

to determine gate position.

Rising stem design — threads

protected from line medium.

Replaceable stem packing

without removing bonnet.

Flow cleansed design.

F E A T U R E S A N D B E N E F I T S p3
 S E R I E S DM 7500 G A T E V A L V E S DEMCO

In-line field repairability

The bonnet is easily removed for internal E
parts inspection and/or replacement with-
out removing the valve from the line. D

This design simplicity permits fast and

easy service without the need for special
tools.
Heavy duty roller bearings F
Large, heavy duty stem roller bearings
reduces torque. G

Unique, abrasion-resistant, one

piece seat design.
The seat assembly consists of two stain-
less steel insert/support rings to which a
resilient elastomer is permanently bonded.
The elastomer provides tight shut off
after long use in abrasive service. The
stainless steel rings are corrosion and ero-
sion resistant. The rings are specially
designed to ensure maximum bonding
strength for the elastomer. The one piece
design makes field replacement easier.
Locking seat alignment
The seat assembly is engineered with a
metal “lock shell” that anchors the seat in
the bottom of the valve. This design
ensures accurate seat alignment with min-
imum resistance to flow.
Body wear rings
Surface hardened alloy body wear rings
back up both sides of the seat. These
rings extend the service life of the valve
by absorbing erosive wear that can dam-
age the body around the seat bore area.
Rising stem design
The Demco DM 7500 uses a rising stem
C
A B
C
Replaceable stem packing
The stem packing can be replaced with-
out removing the bonnet from the valve
(3" - 6") saving time when this mainte-
nance may be required (note: line and
valve pressure must be relieved before
performing this maintenance).
Flow-cleansed design
The body cavity area is designed to
allow continuous “flushing” by the
fluid flow. This action prevents the valve
from “sanding up”, even in standpipe
installations.
A
B

design which isolates and protects the

threads from the line medium. The rising SPECIFICATIONS See page 19 for technical specifications.

stem also indicates gate position. Sizes
2" to 6"x 5"
Visual position indicator lens
Pressure
A clear position indicator lens allows the
7,500 psi WP, 11,250 Test
operator to easily determine whether the
valve is open or closed. The indicator Standard End Connections
lens also helps to protect the stem threads Butt Weld and Flanged
from the weather. Standard Materials
Body and Bonnet: Alloy Steel
Gate: Alloy Steel & Stainless Steel
Stems: 410SS & 17-4SS
Seat/seals: Buna-N & Viton
Body wear rings & seat rings: Carbon
Steel & 410SS
Optional Materials
Stems & Gates: Duplex SS
Industry Standards Compliance
Ability to comply with NACE, ABS, DNV,
and other stringent industry standards.

F E A T U R E S A N D B E N E F I T S p4
 S E R I E S DT/DB G A T E V A L V E S DEMCO

Known throughout the industry
for their quality design and
rugged dependability, Demco
corrosion-resistant gate valves
and accessories are made
especially for waterflood and
CO2 applications.
Demco Aluminum Bronze and Stainless
Steel Products are designed especially for
the demanding requirements of corrosive
CO2 injection and waterflood applica-
tions in the enhanced oil recovery market.
Demco Series DT gate valves are
available in sizes 1" to 4". Demco Series
DB gate valves are available for 6" and
8" size applications.
Features/Benefits
In-line field repairability
The bonnet is easily removed for internal
parts inspection and/or replacement with-
out removing the valve from the line.This
design simplicity permits fast and easy
service without the need for special tools.
Corrosion resistant materials
are standard.
Body and bonnet materials as well as all
internal wetted parts comply with NACE
RP-0475.
Stem back-seat capability
Demco’s DT design allows the stem to
back-seat providing a backup stem seal
capability when the valve is in the open
position.
Rising stem design
A rising stem moves the handle up and
down providing a visible aid for deter-
mining whether the valve is in the open
or closed position.
Pressure responsive drop-tight
sealing.
Standard seats consist of 316SS seat rings
encapsulated with 90 Durometer, perox-
ide cured Buna N elastomer to provide
reliable, drop tight sealing for extended
service life.

Stem threads isolated

from line media.

Four ring packing set.

Full through
conduit design.

Flanged DT Gate Valve

F E A T U R E S A N D B E N E F I T S p5
 S E R I E S DT/DB G A T E V A L V E S DEMCO

Superior Abrasion Resistance

E
Buna N elastomer encapsulated seats also
provide an excellent deterrent to abrasion,
further enhancing extended service life.
Four ring stem packing set.
C
The DEMCO DT stem seal design uses
four packing rings preventing leakage
A into the stem journal and outside the valve.
Through conduit gate design
Full through conduit design assures non-
turbulent flow and gate alignment for
D
improved valve performance and longer Series DB Gate Valve
B service life.
SD-016080
SD016080
The DEMCO Series DB gate valve is
Series DT Gate Valve
Non-wetted stem thread design available for the larger 6" and 8" pipe
DEMCO’s stem design isolates corrosive sizes in the enhanced oil recovery market.
lading from contacting stem threads pre- These valves also feature aluminum
venting stem seizure and assuring long bronze body and bonnet as standard.
trouble free valve performance. Internal parts are 316SS.
The exclusive seat design of the
Accessories DEMCO DB gate valve is the same
proven design found in the DEMCO
Ball check valves, flow tees, strainers and
Ball Check Valves F DM series gate valves. The seat consists
chokes are available to complete require-
of two identical metal wear rings encap-
ments for an entire injection assembly.
sulated in elastomer to form a cylindrical
Aluminum Bronze Ball Valves are also
shape with a gate slot and two round
offered for additional requirements found
ports. The closed gate bears on the
in this market.
downstream wear ring while the elas-
Ball Check Valves tomer provides a drop-tight, pressure
Flow Tees responsive seal around the port. This
design provides an effective seal even if
Strainers the gate and seat ring become scored or
Flow Tees G
abraded during service.
Bronze Ball Valves
The Demco Series DB is also field
repairable while the valve is in line.

SPECIFICATIONS See page 21 for technical specifications.

Strainers H Sizes Standard Materials

Series DT 1" - 4" Body & Bonnet: Aluminum Bronze
Series DB 6"x 4", 6" & 8"x 6" Stem, gate and seat inserts: Stainless
Pressure Class Steel
1" - 4" DT: Class 600, 900 & 1500: Optional Materials
6" DB: Class 600, 900 & 1500 DT: Stainless Steel Body and Bonnet
8" DB: Class 600 & 900 Viton or P-10 seats
End Connection DB: Viton seat elastomer
Threaded and Flanged, see product
specification section for sizes.

Series A Bronze Ball Valve I

F E A T U R E S A N D B E N E F I T S p6
DM G A T E V A L V E S , C L A S S E S 400, 600 DEMCO

Parts Detail Base Part Numbers, Class 400, Full Port

(985 psi WP –1500 psi test)
Valve Size (in)/Type
2" 21/2" 3" 4" 41/16" 6"
Screwed End1 1071 1073 1075 1077 24969 1079
Weld End2 1091 1093 1095 1097 — 1099
Grooved End3 1081 1083 1085 1087 — 1089
Flanged End
1061 1063 1065 — — 1069
(RF or RTJ)4

Base Part Numbers, Class 400, Regular Port

Valve Size (in)/Type
3" x 2" 4" x 3"
Screwed End LP 3934 3935

Base Part Numbers, Class 600, Full Port

(1480 psi WP –2225 psi test)
Valve Size (in)/ Type
11/2" 2" 21/2" 3" 4" 6"
Screwed End1 3938 1072 1074 1076 1078 1080
Weld End2 — 1092 1094 1096 1098 1100
Grooved End3 — 1082 1084 1086 1088 1090
Flanged End
— 1062 1064 1066 1068 1070
(RF or RTJ)4

Base Part Numbers, Class 600, Regular Port

Valve Size (in)/Type
2" x 11/2" 3" x 2" 4" x 3" 6" x 4" 8" x 6"
Screwed End LP 3939 3942 3943 — —
Flanged End
3939 3942 3943 3944 3945
(RF or RTJ)
1
Screwed End valves furnished for line pipe unless otherwise specified.
TBG and UPTBG 10 round threads on 1-1/2"; UPTBG 8 round on 2" and
2-1/2" valves; TBG 10 round on 3"; TBG 8 round on 4"; LP only on 6".
2
Weld End valves furnished for Sch. 40 pipe. See page 18 for more information.
3
Grooved End valves furnished for Sch. 80 pipe.
4
Raised Face flanges furnished unless otherwise specified.

Parts List – Class 400 and 600 (2"- 8" x 6")

Ref. Description Material
1 Handle Ductile Iron
2 Pin Stem Spring Steel
3 Lube Fitting Steel
4 Back Up Ring Chrome Leather
5 Stem Seal As specified (Buna N or Viton)
6 Stem As specified, see page 8
7 Bonnet Class 400: all sizes except
2-1/2" FP, ASTM A395 Ductile Iron
All others, ASTM A216 Carbon Steel
8 Body Stud (4) ASTM A193 Gr B7 Steel
9 Body Stud Nut (4) A194 Gr 2H Stl
10 Bonnet Seal As specified (Buna N or Viton)
11 Body* Class 400: all except weld end and
size 2-1/2" FP, ASTM A395 Ductile Iron
All others, ASTM A216 Carbon Steel
or equivalent
12 Seat As specified, see page 8
13 Gate As specified, see page 8
* Orders for replacement bodies must include 4 body studs.

P R O D U C T S P E C I F I C A T I O N S p7
DM G A T E V A L V E S , C L A S S E S 400, 600 DEMCO

How to Order (example: 2" 600, line pipe, std trim: 1072-0422110)
XXXX - X X X X X X X

Body Stem Gate Seat Seat

Base Part Number End Connection Coating*
Config. Material Material Inserts Elastomer

See previous page. Configuration Code Material Code Material Code

Screwed 4 Steel, Nickel Plated 2 Buna N 1

End Connection Code Weld 5 Monel 3 Viton 2
LP 0
Screwed TBG 1 Grooved 6 Alum. Bronze 4 Hypalon 3
UPTBG 2
Flanged 7 316 SS 8
Short
Casing 4*

Weld, Sch. 40 0 Material Code Material Code Material Code

Grooved Sch. 80 0 303 SS 2 Duct. Iron Uncoated 0
(Steel 4" Bore Only) 1
400 RTJ 0 DEMCO 10 1
316 SS 8
400 RF 1 Monel 3
Flanged
600 RTJ 2 DEMCO 11 4
600 RF 3 Alum. Bronze 4
DEMCO 12 5
*Avail. 4” 400 only.
316 SS 8
*On Weld End valves, only
the Bonnet is coated.
See page 18 for coating
descriptions.

Dimensional Data (inches)

Dimension
A B (Open) C (Seat Bore) D F
Nom.
Size Screwed, Flange
Screwed- Ring
Grooved & Flanged- Flanged- Regular Regular Regular Flange Bolts
Regular Full Port Full Port Full Port Number
Weld- RF RTJ Port Port Port Diameter (No.,
Port (RTJ)
Full Port Size)

Class 400
2" 87/8 73/4 111/2 115/8 83/4 73/4 2 15/8 11 91/2 61/2 8 - 5/8 R23
21/2" 10 — 13 131/8 105/8 — 21/2 — 125/8 — 71/2 8 - 3/4 R26
3" 101/4 121/2 14 141/8 113/8 83/4 3 2 125/8 11 81/4 8 - 3/4 R31
4" 117/8 15 — — 137/8 113/8 4 3 141/4 125/8 — — —
6" 151/2 — 191/2 195/8 191/4 137/8 6 4 24 141/4 121/2 12 - 7/8 R45
Class 600
11/2" 73/4 — — — 73/4 — 15/8 — 91/2 — — — —
2" 87/8 73/4 111/2 115/8 83/4 73/4 2 15/8 11 91/2 61/2 8 - 5/8 R23
21/2" 10 — 13 131/8 105/8 — 21/2 — 125/8 — 71/2 8 - 3/4 R26
3" 101/4 121/2 14 141/8 113/8 83/4 3 2 125/8 11 81/4 8 - 3/4 R31
4" 117/8 15 17 171/8 137/8 113/8 4 3 141/4 125/8 103/4 8 - 7/8 R37
6" 151/2 — 22 221/8 191/4 137/8 6 4 24 141/4 14 12 -1 R45
8" — — 26 261/8 — 191/4 — 6 — 24 161/2 12-11/8 R49

P R O D U C T S P E C I F I C A T I O N S p8
DM G A T E V A L V E S , C L A S S E S 900, 1500 DEMCO

Parts Detail Base Part Numbers, Class 900, Full Port

(2220 psi WP –3350 psi test)
Valve Size (in)/ Type
2" 21/2" 3" 4" 6"
Screwed and
3947 3951 3953 3955 —
Grooved End1
Weld End 2 3947 3951 3953 3955 3999
Flanged End
3947 3951 3953 3955 3999
(RF or RTJ) 3

Base Part Numbers, Class 1500, Full Port (4" see page 172)
(3705 psi WP –5575 psi test)
Valve Size (in)/Type
2" 21/2" 3"
Screwed and
Grooved End1
Weld End2 3948 3952 3957
Flanged End
(RF or RTJ)3
1
Screwed End valves furnished for line pipe unless otherwise specified.
UPTBG 8 round threads on 2" and 2 1/2" valves; TBG 10 round on 3";
TBG 8 round on 4"; Grooved Ends in Class 900 only.
2
Weld End valves furnished for Sch. 40 and Sch. 80 – Class 900; Sch. 40,
Sch. 80 and Sch. 160 – Class 1500. See page 18 for more information.
3
Raised Face flanges furnished unless otherwise specified.

Parts List – Class 900 (2"- 6") and 1500 (2"- 3")
Ref. Component Material
1 Handle Ductile Iron
2 Pin Stem Spring Steel
3 Lube Fitting Steel
4 Back Up Ring Chrome Leather
5 Stem Seal As specified (Buna N or Viton)
6 Stem As specified, see page 10
7 Bonnet ASTM A487 CL 4N Carbon Steel or
equivalent.
2" valves, AISI 4140 Normalized Steel
8 Body Stud (4) ASTM A193 GR B7 Steel
(6" valve AISI 4140)
9 Body Stud Nut (4) A194 GR 2H Stl*
10 Bonnet Seal As specified (Buna N or Viton)
11 Body** ASTM A487 CL 4N Carbon Steel or
equivalent.
2" screwed and weld end, AISI 1029
Normalized Steel
12 Seat As specified, see page 10
13 Gate As specified, see page 10
14 Screw Seal Buna N
15 Relief Fitting Steel

* AISI 4140-4145 6" only.

** Orders for replacement bodies must include 4 body studs.

P R O D U C T S P E C I F I C A T I O N S p9
DM G A T E V A L V E S , C L A S S E S 900, 1500 DEMCO

How to Order (example: 2" 900, RTJ, std trim: 3947-4722110)

XXXX - X X X X X X X

Body Stem Gate Seat Seat

Base Part Number End Connection Coating*
Config. Material Material Inserts Elastomer

See previous page. Material Code Material Code

Configuration Code Steel, Nickel Plated 2 Buna N 1
End Connection Code Screwed 4 Monel 3 Viton 2
LP 0
Weld 5 Alum. Bronze 4 Hypalon 3
Screwed TBG 1
UPTBG 2 Grooved 6 316 SS 8
Sch. 40 0
Weld Sch. 80 1 Flanged 7
Sch. 160 5 Material Code Material Code
Grooved Sch. 801 0 Material Code Duct. Iron Uncoated 0
900 RTJ 4 (Steel 4" Bore Only) 1
900 RF 5 303 SS 2 DEMCO 10 1
Flanged
1500 RTJ 6 Monel 3
316 SS 8 DEMCO 11 4
1500 RF 7
Alum. Bronze 4
1
Class 900 only. DEMCO 12 5
316 SS 8
*On Weld End valves, only
the Bonnet is coated.
See page 18 for coating
descriptions.

Dimensional Data (inches)

Dimension
A B (Open) C (Seat Bore) D F
Nom.
Size Screwed,
Flange Bolts Ring
Grooved & Flanged- Flanged- Flange
Full Port Full Port Full Port (No., Number
Weld- RF RTJ Diameter
Size) (RTJ)
Full Port

Class 900
2" 9 141/2 14 5/8 97/8 2 141/2 81/2 8 - 7/8 R24
21/2" 93/4 161/2 165/8 117/8 21/2 19 95/8 8 -1 R27
3" 11 15 151/8 12 3/4 3 19 91/2 8 - 7/8 R31
4" 13 18 181/8 15 4 23 111/2 8 -11/8 R37
6" 20 24 241/8 191/4 6 24 15 12 -11/8 R45
Class 1500
2" 9 141/2 145/8 97/8 2 141/2 81/2 8 - 7/8 R24
21/2" 93/4 161/2 165/8 117/8 21/2 19 95/8 8 -1 R27
3" 11 181/2 185/8 12 3/4 3 19 101/2 8 -11/8 R35

P R O D U C T S P E C I F I C A T I O N S p10
 DM G A T E V A L V E S , C L A S S 1500, 4" DEMCO

Parts Detail

How to Order (example: 4" 1500, RTJ, std trim: 3010-6722110)

XXXX - X X X X X X X

Body Stem Gate Seat Seat

Base Part Number End Connection Coating*
Config. Material Material Inserts Elastomer

Configuration Code Material Code Material Code

Screwed 4 Steel, Nickel Plated 2 Buna N 1

End Connection Code Weld 5 Monel 3 Viton 2
LP 0
Screwed Flanged 7 Alum. Bronze 4 Hypalon 3
TBG 1
Sch. 40 0
316 SS 8
Weld Sch. 80 1 Material Code
Sch. 160 5
303 SS 2 Material Code Material Code
Flanged 1500 RTJ 6
1500 RF 7 316 SS 8 Steel 1 Uncoated 0

Monel 3 DEMCO 10 1
Base Part Number, 4" Class 1500
(3705 psi WP – 5575 test) Alum. Bronze 4 DEMCO 11 4

Valve Size (in.) 316 SS 8 DEMCO 12 5

4" *On Weld End valves, only
Screwed End1 the Bonnet is coated.

Weld End2 3010

Flanged End
(RF or RTJ)3
1
Screwed End valves furnished for line pipe unless otherwise specified.
TBG 8 round threads on 4".
2
Weld End valves furnished for Sch. 40, Sch. 80 and Sch. 160 – Class 1500.
See page 18 for more information.
3
Raised face flanges furnished unless otherwise specified.

P R O D U C T S P E C I F I C A T I O N S p11
 DM G A T E V A L V E S , C L A S S 1500, 4" DEMCO

Parts List – Class 1500 (4")

Ref. Component Material
1 Hub Assembly Steel or Ductile Iron
3 Lube Fitting Steel
5 Stem Seal Ass’y. As specified (Buna N or Viton)
Includes Brz. bushing
6 Stem As specified, see page 13
and chart
7 Bonnet ASTM A487 CL 4N Carbon Steel
8 Body Stud (4) ASTM A193 Gr B7 Steel
9 Body Stud Nut (4) A194 Gr 2H Stl
10 Bonnet Seal As specified (Buna N or Viton)
11 Body* ASTM A487 CL 4N Carbon Steel
12 Seat As specified, see page 13
and chart
13 Gate As specified, see page 13
and chart
14 Screw Seal Buna N
16 Lock Handle Steel
18 Stem Screw Steel
19 Screw Housing Steel
20 Secondary Seal Buna N
21 Retainer Steel
22 Pin, Lock Handle Steel
23 Bonnet Stud (2) ASTM A193 Gr B7 Steel
24 Bonnet Stud Nut (2) A194 Gr 2H Stl
* Orders for replacement bodies must include 4 body studs.

Dimensional Data (inches)

Dimension
A B (Open) C (Seat Bore) D F
Nom.
Size Flange
Screwed Ring
Flanged- Flanged- Flange Bolts
& Weld- Full Port Full Port Full Port Number
RF RTJ Diameter (No.,
Full Port (RTJ)
Size)

4" 13 211/2 215/8 211/4 4 23 121/4 8-11/4 R39

P R O D U C T S P E C I F I C A T I O N S p12
DM G A T E V A L V E S , 2000, 3000, 5000 WP DEMCO

Parts Detail Base Part Numbers, 2000 WP 4000 psi Test

Valve Size (in)
2" 21/2" x 2" 21/2" 3" 4"
Screwed End1 1026 — 1042 1045 1048
Weld End2 1029 1115 1051 1054 1057
Grooved End3 11920 — 11921 11922 11923
Flanged End
1023 — 1033 1036 1039
(RTJ)4

Base Part Numbers, 3000 WP 6000 psi Test – Full Port

Valve Size (in)
2" 21/2" 3" 4" 41/16"
Screwed End 1
1027 1043 1046 1049 24968
Weld End2 1030 1052 1055 1058 —
Flanged End
1024 1034 1037 1040 —
(RTJ)4

Base Part Numbers, 3000 WP 6000 psi Test – Regular Port

Valve Size (in)
21/2" x 2" 4" x 3" 5" x 4"
Weld End 1114 1113 1111
(See ordering information on page 14.)

Base Part Numbers, 5000 WP 10,000 psi Test

Valve Size (in)
2" 21/2" x 2" 3" 4" x 3”
Screwed End1 1028 — 1047 —
Weld End2 1031 1109 1056 1110
Flanged End
1025 — 1038 —
(RTJ)4

2" Full, 2-1/2" Regular

1
Screwed End valves furnished for line pipe unless otherwise
specified. UPTBG 8 round on 2" and 21/2" valves; TBG 10
round on 3"; TBG 8 round on 4". 2-1/2" Full – 5" Regular
2
Weld End valves furnished for Sch. 40 and Sch. 80 on 2000 WP
valves; Sch. 80 and Sch. 160 on 3000 WP; Sch. 80, XXH and
Sch. 160 on 5000 WP. See page 18 for more information.
3
Grooved End valves furnished for Sch. 80 pipe.
4
RTJ flanges comply with API Std. 6A, 1974.

P R O D U C T S P E C I F I C A T I O N S p13
DM G A T E V A L V E S , 2000, 3000, 5000 WP DEMCO

How to Order (example: 2" 5000, Line Pipe, std trim: 1028-0422110)
XXXX - X X X X X X X
Body Stem Gate Seat Seat
Base Part Number End Connection Config. Material Material Inserts Elastomer Coating*

End Connection Code Configuration Code Material Code Material Code

LP 0 Screwed 4 Steel, Nickel Plated 2 Buna N 1
Screwed TBG 1
Weld 5 Monel 3 Viton 2
UPTBG 2
Grooved 6 Alum. Bronze 4 Hypalon 3
Sch. 80 1
Flanged 7 316 SS 8
Weld XXH 2
Material Code
Sch. 160 5
Material Code
Grooved Sch. 80 0 Uncoated 0
2000 RTJ 0 Duct. Iron DEMCO 10 1
(Steel 4" Bore Only) 1
Flanged 3000 RTJ 1 DEMCO 11 4
Material Code
5000 RTJ 2 Monel 3
DEMCO 12 5
303 SS 2 Alum. Bronze 4
See previous page. 316 SS 8 316 SS 8 *On Weld End valves, only
the Bonnet is coated.

Parts List
Ref. Component Material Ref. Component Material
1 Lube Fitting Steel 17 Index Pin Steel (2" bore only)
2 Hub Assembly Steel or Ductile Iron 18 Bonnet Seal As specified (Buna N or Viton)
4 Lock Handle Steel 19 Gate As specified, see How to Order
6 Stem Screw Steel 20 Body* 2" bore: AISI 1029, or A105 Steel
7 Stem Screw Seal Buna N Other sizes: ASTM A487 Steel
8 Screw Housing Steel (CL 4N or 2Q)
9 Stem As specified, see How to Order 21 Seat As specified, see How to Order
10 Secondary Seal Buna N 22 Pin, Lock Handle Steel
11 Retainer Steel 23 Bonnet Stud ASTM A193, GR B7
(2-1/2"– 4" bore)
12 Stem Seal Assembly As specified (Buna N or Viton)
24 Bonnet Stud Nut (2) A194 Gr 2H Stl
13 Lock Screw Steel (2" bore only)
(2-1/2"– 4" bore)
15 Coupling (2" bore only) 2000/3000 WP: A216 WCB Steel
25 Body Stud (4) ASTM A193, GR B7
5000 WP: A487 4NSteel (2-1/2"– 4" bore)
16 Bonnet 2" bore: AISI 1029, or A105 Steel 26 Body Stud Nut (4) A194 Gr 2H Stl
Other sizes: ASTM A487 Steel (2-1/2"– 4" bore)
(CL 4N or 2Q)
* Orders for replacement bodies must include 4 body studs
(except 2" bore valves).
Dimensional Data (inches)
A B (Open) C (Seat Bore) D F

Nom. Screwed, Flange

Weld Ring
Size Grooved & Flanged- Regular Regular Regular Flange Bolts
Regular Full Port Full Port Full Port Number
Weld- RTJ Port Port Port Diameter (No.-
Port (RTJ)
Full Port Size)

2000 psi WP, 4000 psi Test

2" 9 — 115/8 13 — 2 — 14 — 61/2 8 -5/8 R23
21/2" 93/4 9 165/8 17 13 21/2 2 19 14 71/2 8 -3/4 R26
3" 11 — 141/8 18 — 3 — 19 — 81/4 8 -3/4 R31
4" 13 — 163/8 211/4 — 4 — 23 — 103/4 8 -7/8 R37
3000 psi WP, 6000 psi Test
2" 9 — 115/8 13 — 2 — 14 — 81/2 8 -7/8 R24
21/2" 93/4 9 165/8 17 13 21/2 2 19 14 95/8 8-1 R27
3" 11 — 141/8 18 — 3 — 19 — 91/2 8 -7/8 R31
4" 13 11 163/8 211/4 18 4 3 23 19 111/2 8 -11/8 R37
5" — 13 — — 211/4 — 4 — 23 — — —
5000 psi WP, 10,000 psi Test
2" 9 — 121/8 13 — 2 — 14 — 81/2 8 -7/8 R24
21/2" — 9 — — 13 — 2 — 14 — — —
3" 11 — 155/8 18 — 3 — 19 — 101/2 8 -11/8 R35
4” — 11 — — 18 — 3 — 19 — — —

P R O D U C T S P E C I F I C A T I O N S p14
 D E M C O 4 ", 5 ", 6"- 5000 WP DEMCO

4" 5000 psi 4" 5000 WP Full Port

(12 bolt bonnet) (4 bolt bonnet)

Dimensional Data (inches) – Both Bonnet Designs

F
A B C D
Nom. Flange
(End to (Open (Seat (Handle Flange Bolts RTJ Ring
Size End) Height) Bore) Diameter) Diameter (No., Number
Size)
4"
Screwed/ 13 245/8 4 223/4 — — —
Weld End

4"
Flanged 18 245/8 4 223/4 121/4 8-11/4 R39

5" x 4"
Weld End 13 245/8 4 223/4 (1)
— —

6" x 4"
Weld End 13 245/8 4 223/4 (1)
— —

5”1000 (2)
Casing 16 247/8 5.12 20 — — —
Thread
5” 3000 (2)
5000
Casing 16 31 5.12 23 — — —
Thread
6”x5”(2) 16 31 5.12 23 — — —
Weld

(1)
Flanged end connection available by special order, consult factory.
(2)
Consult factory for 5” casing thread and 6”x5” weld end valve data sheet
(graphic not shown here).

Test Pressure
Test Pressure for 4" x 4", 5" x 4" and 6” x 4” 4-bolt design
valves is 7500 psi. 12-bolt bonnet design valves are shell tested
to 10,000 psi. All 5” casing thread valves shell tested to 2 times
working pressure.

P R O D U C T S P E C I F I C A T I O N S p15
 D E M C O 4 ", 5 ", 6"- 5000 WP DEMCO

How to Order (example: 5" x 4", 4 bolt, weld XXH, std trim: 7421-2522110)
XXXX - X X X X X X X

Body Stem Gate Seat Seat

Base Part Number End Connection Coating*
Config. Material Material Inserts Elastomer

Size 4 Bolt 12 Bolt Configuration Code Material Code Material Code

4"x 3" 1110 —
Screwed 4 Steel, Nickel Plated 2 Buna N 1
4"x 4" 7420 17263
5"x 4" 7421 17264 Weld 5 Monel 3 Viton 2
6"x 4" — 17265
3
Flanged 7 Alum. Bronze 4 Hypalon 3
6"x 5" — CF
3
Consult factory for order # 316 SS 8
information on 6”x5”
3000/5000 weld end gate
valves (ref. data sheet G-34).
Material Code Material Code Material Code

303 SS 2 Steel 1 Uncoated 0

End Connection Code
LP 0 316 SS 8 Monel 3 DEMCO 10 1
Screwed
TBG 1
Sch. 80 1 316 SS 8 DEMCO 11 4
Weld2 XXH 2 DEMCO 12 5
Sch. 160 5
Flanged 5000 RTJ1 2 *On Weld End valves, only
the Bonnet is coated.
1
4" x 4" 12 bolt design only, RTJ flanges See page 18 for coating
comply with API Std 6A, 1974.
descriptions.
2
See page 18 for more information.

DM Gate Valves with Casing Threads **

Parts List – Class 5000 (4", 5" x 4", 6" x 4")
We offer 4” and 5” Full Port
Ref. Component Material
DM Gate Valves with Casing Threads
1 Lube Fitting Steel
2 Handle Assembly Steel or Ductile Iron Size
Pressure Rating (PSIG)
(Full Port)
3 Tube Clear Acrylic
4 Stem Cap Ductile Iron 4” 985, 3000
5 Key Steel (41/16” bore) (all 4” are short casing thread)
6 Stem Screw Steel
5” 1000, 3000, 5000
7 Stem Screw Seal Buna N
(51/8” bore) (all 5” are long casing thread)
8 Screw Housing Steel
9 Stem As specified, see How to Order
10 Secondary seal Buna N
11 Retainer Steel ** 4” 400 (985 psi WP) valve design same as on
12 Stem Seal Assembly As specified (Buna N or Viton) page 7.
(Includes BRZ Bushing)
13 Bearing (2) Teflon/Phenolic
4” 3000 valve design same as on page 12.
14 Down Stop Ring 303 SS Std trim order #s for 4” valves:
16 Bonnet ASTM A487 steel (CL 4N or 2Q) 4” class 400 (985 psi WP): 24969-4422110
18 Bonnet Seal As specified (Buna N or Viton) 4” 3000: 24968-4422110
19 Gate As specified, see How to Order 5” is a round bonnet design, consult factory
20 Body* ASTM A487 steel (CL 4N or 2Q) for technical information and data sheet
21 Seat As specified, see How to Order (1000-G-35, 3000/5000 G-34).
23 Bonnet Stud (2) ASTM A193, GR B7 Steel Std trim order #s for 5” valves:
24 Bonnet Stud Nut (2) A194 Gr 2H Steel 5” 1000: 22401-3422110
25 Body Stud (4) AISI 4140 Steel
5” 3000: 23925-3422110
25 Body Stud (12) ASTM A193 GR B7
26 Body Stud Nut (4) AISI 4140-4145 Steel
5” 5000: 23925-3482210
26 Body Stud Nut (12) ASTM A194 GR 2H

* Orders for replacement bodies must include 4 body studs.

P R O D U C T S P E C I F I C A T I O N S p16
 G E N E R A L T E C H N I C A L I N F O R M A T I O N DEMCO

Standard Weights (pounds)

Working Pressure
Size (in.) 400 600 900 1500 2000 3000 5000
S, G, W* FL* S, G, W* FL* S, G, W* FL* S, G, W* FL* S, G, W* FL* S, G, W* FL* S, G, W* FL*
11/2" — — 20 — — — — — — — — — — —

2" x 11/2" — — 20 40 — — — — — — — — — —
‡ ‡
2" 24 42 26 44 48 100 48 100 48 70 53 100 61 110
† † †
21/2" x 2" — — — — — — — — 48 — 53 — 61 —

21/2" 48 70 50 74 87 170 87 170 74 141 87‡ 170 — —

3" x 2" 32 — 34 65 — — — — — — — — — —
‡ ‡
3" 58 90 60 96 95 160 113 205 95 131 113 175 140 241
† †
4" x 3" 72 — 74 145 — — — — — — 113 — 140 —

4" 93 — 98 176 140 230 162‡ 320 140 200 162‡ 265 210‡1 330

5" x 4" — — — — — — — — — — 162† — 210†1 —

2 3 3
5" — — — — 208 — — — — — 317 — 317 —
†
6" x 4" — — — 270 — — — — — — — — 255 —
†
6" 300 411 310 428 325 540 — — — — — — — —

8" x 6" — — — 590 — — — — — — — — — —

* S = Screwed End † Weld End only

G = Grooved End ‡ Grooved End not included
W = Butt Weld End
FL = Flanged End 1 Weight shown is for the 4 bolt design, the 12 bolt design is 246lbs
2 Weight shown is for a 5” 1000# DM GV with casing threads.
3 Casing thread only (weight will be the same for a 5” 4000# valve)

P R O D U C T S P E C I F I C A T I O N S p17
 G E N E R A L T E C H N I C A L I N F O R M A T I O N DEMCO

Valve Size Designations and Weld End Plastic Coatings

Dimensional Information Internally plastic-coated body and bonnet are offered with three
1. All references to pipe size in this catalog is the nominal size. coatings. Demco 10 is a catalyst-cured epoxy with excellent
The actual OD and ID for various nominal sizes and schedules adhesion and resistance to wear, chipping and abrasion, is unaf-
is tabulated below. Weld End bodies are machined at each end fected by most acids, alkalis, brines and petroleum products up
to match the pipe OD and ID. to 150˚ F. Demco 11 is a baked-on phenolic serviceable to 200˚
F and resistant to organic and mineral acids, hydrocarbons and
corrodents encountered in oil and gas production (not recom-
Nominal ID
OD mended for caustics). Demco 12 is a baked-on phenolic-epoxy,
Size Sch. 40 Sch. 80 Sch. 160 XXH
tougher and more abrasion resistant, for excellent service in
11/2" 1.900 1.610 1.500 — —
2" 2.375 2.067 1.939 1.687 1.503 caustics and salt water up to 200˚ F. All coatings are applied 5
21/2" 2.875 2.469 2.323 2.125 1.771 to 6 mil thickness.
3" 3.500 3.068 2.900 2.624 2.300 For applications in high pressure gas above 3000 psi or
4" 4.500 4.026 3.826 3.438 3.152
5" 5.563 — 4.813 4.313 4.063 involving concentrations of H2S or CO2 consult factory for
6" 6.625 6.065 5.761 5.187 — recommendations.
8" 8.625 7.981 7.625 6.813 —
Pressure Ratings
Demco® Gate Valves are designed for the maximum working
2. Regular port valve size descriptions are designated by two
pressures and test pressures tabulated below:
numbers. The first number is the nominal size of the end con-
nection. The second number is the ID of the valve seat (dimen- Pressure Ratings
sion “C” in the tables).
Class Class Class Class 2000 3000 5000*
400 600 900 1500 WP WP WP
Special Order Accessories 990 WP 1480 WP 2220 WP 3705 WP 2000 WP 3000 WP 5000 WP
Square Operating Nuts are offered to replace handles, for 1500 Test 2225 Test 3350 Test 5575 Test 4000 Test 6000 Test 10,000 Test
wrench operation. Nuts are sized for 2-inch square sockets. * 4"-5000, 5" & 6" regular port-5000 valves of the 4 bolt design are tested
at 7,500 psi; 10,000 psi on the 12 bolt design.
Locking devices for tamper-proof valve settings of standard
handles are also available. Gate valve rating must be selected to match the piping system
Special Stem Extensions are available on all gate valves, in which the valve will be installed. Tabulated below are work-
for buried service. Extended stems are housed from the valve ing pressures at 100˚ F for ASTM A-106 Grade B pipe in sizes
bonnet to the handle; operation of the valve is identical to nor- corresponding to Demco gate valves.
mal assembly.
Actuators for automated or remote-controlled applications Pressure Ratings
may be furnished on special order. Prices for pneumatic or
Size Sch. 40 Sch. 80 Sch. 160 XXH
hydraulic actuators can be given on request.
11/2" 1340 2430 — —
Testing 2" 1210 2220 4300 5970
Demco® Gate Valves are hydrostatically tested at assembly. 21/2" 1620 2590 3950 6590
3" 1460 2370 3930 5880
Stem seal, body and seat are inspected for zero leakage under
4" 1300 2130 3830 5150
pressure, before acceptance. 5" — 1970 3730 4650
6" 1110 1970 3650 —
Seat Elastomers 8" 1030 1790 3620 —
Buna N (nitrile) is the basic seat elastomer. It is excellent for
petroleum oil and gases, fuel oils and alcohols from –10˚ F to Ordering Information
+200˚ F. Hypalon is optionally offered compounded for maxi- Give size, pressure class and end connection. Specify pressure
mum chemical resistance. Particularly suited for oxidizing class of flanged ends and raised face or RTJ. For threaded ends,
acids, it resists hydrocarbon oils and fuels from –10˚ F to give line pipe, TBG (non upset tubing) or UPTBG (external
+250˚ F. Viton is highly resistant to mineral acids and hydrocar- upset tubing). For weld or grooved ends, give schedule of
bons and resists moderate concentrations of hydrogen sulfide. mating pipe.
Serviceable from –10˚ F to +400˚ F. (Not suitable for steam).

P R O D U C T S P E C I F I C A T I O N S p18
 DM 7500 G A T E V A L V E S DEMCO

Parts Detail No. Component Material Description

ASTM A536
1 Handwheel Ductile Iron Grade 65-45-12
Seat
Size 2 Lock Screw Carbon Steel ANSI 1213
Skt. Hd.
3 Alloy Steel ASTM B18.3
23
Cap Screw
4 Gate Clip Stainless Steel ANSI 302
1
24 5 Stem Packing Elastomeric Buna-N
ANSI 410
6 Stem Stainless Steel HRC 22 Max
ASTM A487
7 Bonnet Alloy Steel
18 Grade 4 Class C
2
8 Bonnet Stud Alloy Steel ASTM A193 Grade B7
14 9 Bonnet Nut Alloy Steel ASTM A194 Grade 2H
22
19 18A 10 Bonnet Seal Elastomeric Buna-N
25
ASTM A487
26 11 Body Alloy Steel
3 Grade 4 Class C
17 Stainless Steel/
21 12 Seat ANSI 410/Buna-N
5
Elastomeric
20
13 Gate Alloy Steel ANSI 4130
8
14 Weather Seal Elastomeric Buna-N
9
6 15 Wear Ring Alloy Steel ANSI 4142
4 16 Wear Ring Seal Elastomeric Buna-N
7
12 Packing
10 17 Bronze ASTM B271 Grade 955
Adapter
16
13 Stem Screw
18 Carbon Steel ANSI 1022
Assy.
11
15 18* Bearing Steel Roller Thrust
19 Bonnet Cap Carbon Steel ANSI 1022
20 Secondary Seal Elastomeric Buna-N
Packing
21 Carbon Steel ANSI 1022
Retainer
22 Hex Cap Screw Alloy Steel ASTM A307 Grade 2
23 Stem Protector Plastic Clear Acrylic
SD-016418
ASTM A536
24 Stem Cap Ductile Iron Grade 65-45-12
25 Grease Fitting Commercial —
26 Grease Vent Commercial —

How to Order* (Part number example: Std 5" Butt Weld 24994-2572110)
X X X X X – X X X X X X 0
Base Part End Body Stem Gate/ Seat Seat/Seal
Number Connection* Configuration Material Wear Ring Insert Elastomer

10,000 RTJ 3 Weld 5 410 SS 7 Steel/Steel 2 410 SS 1 Buna-N / Buna-N 1

Weld end size Flanged 7 17- 4 SS 8 410 SS/410 SS 7 Viton / Viton 2
(see table)
17- 4 SS/410 SS 8 HNBR / Viton 4

Seat Size Weld End Table for First Digit of Part No. Suffix
2" 3" 4" 5" 6 × 5" Seat Seat
Weld End Size Weld End Size
Size Size
24993 25051 24967 24994 24981
4” XXH (4.50OD X 3.15 ID) 2
2” XXH (2.38 OD x 1.50 ID) 2
5” XXH (5.56 OD X 4.06 ID) 4
2 3.00 OD x 2.00 ID 4 4
5.56 OD X 3.95 ID 5
3.25 OD X 2.00 ID 6
6.00 OD X 4.00 ID 6
*Consult factory for other end connections or trims. 3” XXH (3.50 OD x 2.30 ID) 2 5 5” XXH (5.56 OD x 4.06 ID) 2
3 4” XXH (4.50 OD x 3.15 ID) 4 6x5 6” XXH (6.62 OD x 4.90 ID) 4
4.50 OD x 2.96 ID 5 7.00 OD x 5.12 ID 6

P R O D U C T S P E C I F I C A T I O N S p19
 DM 7500 G A T E V A L V E S DEMCO

Dimensional Data (inches)

2" 3" 4" 5" 6"

Description
Weld Flange Weld Flange Weld Flange Weld Flange Weld Flange
A 9.00 18.38 13.00 24.38 16.00 26.38 17.88 29.00 17.88 N/A

B 13.04 13.04 24.60 24.60 31.00 31.00 31.81 31.81 31.81 N/A

C 2.6 3.94 4.69 5.31 3.90 6.2 5.00 7.03 5.00 N/A

D 6.38 6.38 10.50 10.50 11.75 11.75 14.88 14.88 14.88 N/A

E 13.88 13.88 22.81 22.81 20.00 20.00 26.75 26.75 26.75 N/A

Weight (lb) 76 124 256 372 310* 475* 506 761 506 N/A

Wear Ring I.D., Min (in) 1.97 1.97 2.98 2.98 3.97 3.97 5.17 5.17 5.17 N/A

End Conn. Option 6 ID 2.075 N/A 3.075 N/A 4.075 N/A 5.135 N/A Option

End Conn. Option 6 OD 3.00 N/A 4.40 N/A 5.81 N/A 7.25 N/A Option

*Estimated weights.

P R O D U C T S P E C I F I C A T I O N S p20
 S E R I E S DT G A T E V A L V E S DEMCO

How to Order ( X X X X X - X X X X X X X ) - Example: 2" Bronze 1500, UPTBG 24753-2488816

XXXXX – X X X X X X X

Base Part End Body Stem Gate Seat Seat/Seals Body/

Number Configuration Configuration Material Material Ring Bonnet

Aluminum
6
Size ANSI Base Flanged 316 SS 8 316 SS 8 Bronze
(in) Class Part No. 600 RTJ 2 Stainless
8
600 17275 Steel
600 RF 3 316 SS 8 Buna N/Buna N 1
Threaded 4 (Peroxide
1* 900 17276 900 RTJ 4 Cured Buna)
Flanged 7
1500 14044 900 RF 5 Viton/Viton 2
600 24726 1500 RTJ 6 P-10/Hytrel 4
2 900 24727 1500 RF 7 P-10/90 Duro
6
1500 24753 Threaded Buna-N P.C.

600 24728 API LP 0

D

21/2 900 24729 UPTBG 2 40

80

1500 24754
120
130
600 24730

3 900 24731
180
1500 24732 21

90 60

600 24733 70
B (OPEN)
110
100
4 900 24734
20

1500 24735 10
160

* 1’ design not shown ( consult factory )

Dimensional Data E

Size/ A A A SEE SEAT DETAIL

B C D E
Class THD’D RF RTJ
30

1”600 6.75 — — 11.00 1.06 5.00 3.00 A

900/500 6.75 10.00 10.00 11.00 1.06 5.00 3.00

2" 600 8.50 11.50 11.63 14.63 2.06 14.50 5.00
Seat Assembly Detail
2" 8.50 14.50 14.63 14.63 2.06 14.50 5.25 SEAT SPRING
900/1500 SEAT SEAL
SEAT SEAL

21/2" 600 8.75 13.00 13.13 16.71 2.56 14.75 6.13

21/2" 8.75 16.50 16.63 16.71 2.56 14.75 6.38
900/1500
3" 600 — 14.00 14.13 18.00 3.13 14.75 6.81
3" 900 9.69 15.00 15.13 18.00 3.13 14.75 6.94
50 50
3" 1500 — 18.50 18.63 18.82 3.13 18.00 7.15
4" 600 — 17.00 17.13 22.25 4.06 23.00 9.00
Peroxide Cured BUNA or Viton P-10
4" 900 — 18.00 18.13 22.25 4.06 23.00 9.13 (Seat/seal option 6)
(Seat/seal option 1 or 2)
4" 1500 — 21.50 21.63 22.54 4.06 23.00 9.41 Seat seal part of seat assembly Seat spring and seal
part of seat assembly

P R O D U C T S P E C I F I C A T I O N S p21
 S E R I E S DT G A T E V A L V E S DEMCO

Body Style and Material Optional Availability*

2" 21/2" 3" 4"
Index Reqd. Description Material/Option Specifications
900 900
600 1500 600 1500 600 900 1500 600 900 1500
Body—API LP Aluminum Bronze X
(6) N/A X N/A X N/A N/A N/A N/A N/A
Body—UPTBG ASTM B148 Alloy 955 CF
Body—ANSI RF Aluminum Bronze
(6) X X X X X X X X X X
Body—ANSI RTJ ASTM B148 Alloy 955
10 1
Body—API LP
(8) Stainless Steel CF8M N/A X N/A CF N/A N/A N/A N/A N/A N/A
Body—UPTBG
Body—ANSI RF
(8) Stainless Steel CF8M CF X CF CF CF CF CF CF CF CF
Body—ANSI RTJ
Aluminum Bronze
(6) X X X X X X X X X X
20 1 Bonnet ASTM B148 Alloy 955
(8) Stainless Steel CF8M CF X CF CF CF CF CF CF CF CF
Stem Bushing
21 1 Bronze
( f / SS Bonnet)
Gate—Elastomer Seat Stainless Steel CF8M
30 1
Gate—P-10 Seat Stainless Steel CF8M, Chromium Plated
40 1 Stem (8) 316 SS
(1) Ring: CF8M; Elastomer: Buna-N Peroxide Cured, 90 Durometer
(2) Ring: CF8M; Elastomer: Viton, 75 Durometer
Ring: CF8M; Insert: Peek; Seal: Hytrel/Elgiloy
50 2 Seat Assembly (4)
Spring: Inconel X-750
(6) Ring: CF8M; Insert: Peek; Seal: Buna-N Peroxide Cured, 90 Durometer
Spring: Inconel X-750
60 1 Handle Ductile Iron ASTM A536 Grade 65-45-12
Stem Packing
70 1 316 SS
Retainer
80 1 Cap Steel
90 1 Stem Seal (1)or(6) Buna-N, Peroxide Cured, 90 Durometer
Assembly
(2) Viton, 90 Durometer
(Matched w/
Seat Option) (4) Teflon/ Elgiloy

100 1 Retainer Snap Ring PH 15-7 Mo

110 4 Cap Screw Alloy Steel
120 1 Lube Fitting Steel
130 1 Relief Fitting Steel
(1)or(6) Buna-N, Peroxide Cured, 90 Durometer
160 1 Body Seal (2) Viton, 90 Durometer
(4) Teflon/Elgiloy
180 1 Handle Seal Buna-N
* X = Available; CF = Consult Factory; N/A = Not Available. For 1” size consult factory
Part number reference for material option is shown ( ) description column if applicable.

Working Pressure/ Test Pressure Data

End Connection Material Class 600 Class 900 Class 1500
Bronze
Threaded 1480 WP 2225 Test 2220 WP 3350 Test 3705 WP 5575 Test
Stainless Steel
Bronze 1480 WP 2225 Test 2220 WP 3350 Test 3705 WP 5575 Test
Flanged
Stainless Steel 1440 WP 2175 Test 2160 WP 3250 Test 3600 WP 5400 Test

P R O D U C T S P E C I F I C A T I O N S p22
 S E R I E S DB G A T E V A L V E S DEMCO

6" x 4", 6" x 6", 8" x 6" 600 6" x 4" 900

How to Order ( X X X X X - X 7 8 X X X 6 ) Example: 6" x 6" 900 RF 19163-5788896

XXXXX – X 7 8 X X X 6

Base Part End Body Stem Gate Insert Seat/Seals Body/Bonnet

Number Connection Configuration Material Material Material Material

Size 600 RTJ 2 Flanged Class 600 – all 316 Stainless Aluminum
Part No.
(in) Class 1500 – 6 x 4 Steel Bronze
600 RF 3 ASTM B148
ASTM A479
Class 600 Alloy 955
900 RTJ 4 Class 900 – all Type XM-19
6x4 18993 Class 1500 – 6 x 6 Stainless
900 RF 5 Steel
6x6 19108 Buna-N 1
1500 RTJ 6
8x6 19977 Viton 2
1500 RF 7
Class 900 Buna-N, 90 Duro
(Except 6 x 6 1500) 9*
Peroxide Cured
6x4 18756
Aluminum Bronze 4 *Most common option.
6x6 19163 ASTM B148 Alloy 953
(Except 6 x 6 1500)
8x6 19785
316 Stainless Steel 8*
Class 1500 ASTM A351 CF8M
6x4 19791 (6 x 6 1500 only)

6x6 18418 Duplex Stainless Steel 9*

UN5 831803 (Gate)
UN5 551803 (Insert)
*Most common option.

P R O D U C T S P E C I F I C A T I O N S p23
 S E R I E S DB G A T E V A L V E S DEMCO

6" x 4" 1500 6" x 6" 900/1500, 8" x 6" 900

Dimensional Data (inches)

Class 600 Class 900 Class 1500
Description
6" x 4" 6"x 6" 8" x 6" 6" x 4" 6" x 6" 8" x 6" 6" x 4" 6" x 6"
Wt. Lbs. 270 400 570 350 540 775 540 610
Flanged–RF 22 22 26 24 24 29 273/4 273/4
A
Flanged–RTJ 221/8 221/8 261/8 241/8 241/8 291/8 28 28
B (Open) 135/8 191/8 191/8 1415/16 34 34 215/16 34
C (Seat Bore) 4 6 6 4 6 6 4 6
D 141/4 24 24 23 20 20 23 24
E 43/16 51/2 51/2 43/8 57/8 57/8 411/16 61/8
(Flange Diameter) 14 14 161/2 15 15 181/2 151/2 151/2
F Flange Bolts (No.-Size) 12 -1 12 -1 12 -11/8 12 -11/8 12 -11/8 12 -13/8 12 -13/8 12 -13/8
Ring Number (RTJ) R45 R45 R49 R45 R45 R49 R46 R46

Parts List
Ind Req Description/Matl* Ind Req Description/Matl* Ind Req Description/Matl*
Class 600 (all), 6" x 4" 900 7 1 Bonnet* 22 1 Pin, Lock Handle (Steel)
1 1 Handle (Ductile) 8 † Body Stud (A193 B7) 23 2 Bonnet Stud (A193 B7)
2 1 Stem Pin (SS) 9 † Body Stud Nut (A194 2H) 24 2 Bonnet Stud Nut (A194 2H)
3 1 Lube Fitting (Steel) 10 1 Bonnet Seal* 6" x 6" 900/1500, 8" x 6" 900
4 1 Back-up Ring (Chrm/Lthr) 11 1 Body* 15 2 Roller & Cage Assy (Steel)
6" x 4" 1500 12 1 Seat Assembly* 16 4 Thrust Washer (Steel)
1 1 Hub Assy (Steel or Ductile) 13 1 Gate* 18 1 Stem Screw (Steel)
3 1 Lube Fitting (Steel) 14 1 Screw Seal (n/r Class 600) 19 1 Housing (Steel)
6" x 6" 900/1500, 8"x 6" 900 6" x 4" 900 20 1 Secondary Seal*
1 1 Handwheel (Ductile) 15 1 Relief Fitting (Steel) 21 1 Retainer (Steel)
2 1 Set Screw (Steel) 6" x 4" 1500 (next 16-24) 22 4 Housing Screw (Steel)
3 1 Retainer Screw (Alloy Stl) 16 1 Lock Handle (Steel) 23 1 Sight Tube (Clear Acrylic)
4 1 Down Stop Ring (316SS) 18 1 Stem Screw (Steel) 24 1 Stem Cap (Ductile)
Index 5-14 same for all valves 19 1 Screw Housing (Steel) 25 1 Lube Fitting (Steel)
5 1 Stem Seal* 20 1 Secondary Seal* 26 1 Relief Fitting (Steel)
6 1 Stem* 21 1 Retainer (Steel)
*See How to Order table for materials not shown (Body, bonnet, seat insert, seat and seals).
†Class 600(4); 6 x 4 900(8); 6 x 4 1500 (10); 6 x 6 900/1500 & 8 x 6 900 (12).

P R O D U C T S P E C I F I C A T I O N S p24
 T E R M S A N D C O N D I T I O N S
1. CONTRACT ACCEPTANCE:
Any written or oral purchase order received
from Buyer by Cooper Cameron Corporation,
Cameron Division and Cooper Cameron Valves
(“Seller”) shall be construed as a written
acceptance of Seller’s offer to sell and shall
be filled in accordance with the terms and
conditions of sale set forth herein. SELLER’S
ACCEPTANCE OF THIS ORDER IS EXPRESSLY
CONDITIONED ON BUYER’S ASSENT TO THE
TERMS CONTAINED HEREIN. The terms and
conditions of Seller’s proposal (if any) and
acknowledgement shall prevail over any
conflicting or different terms in Buyer’s order
unless Buyer notifies Seller in writing of its
objections thereto within fifteen (15) days
from receipt of Seller’s acknowledgement.
Buyer’s standard terms of purchase will not
be considered a counteroffer to Seller’s terms
and conditions of sale. The failure of Seller to
object to any provision in conflict herewith
whether contained on Buyer’s purchase order
or otherwise shall not be construed as a
waiver of the provisions hereof nor as an
acceptance thereof.
2. QUOTATIONS AND PRICES:
All quotations are made for prompt acceptance
and any terms quoted therein are subject to
change without notice after thirty (30) days
from the date quoted unless specifically stated
otherwise on the quotation. Any product,
service capability or manufacturing capability
which may be available at the time a quotation
is made is subject to prior sale. Prices quoted
are valid for thirty (30) days unless specifically
stated otherwise on the quotation and are
subject to change without notice. The price in
effect at the time of shipment including any
escalation formula will apply, unless a valid
quotation or written agreement to the contrary
exists between Buyer and Seller. All prices
shown are in U.S. dollars and are F.O.B. Seller s
shipping point. Any documentation pertaining
to traceability requirements for raw materials
or products or documentation required for any
routine or special processes must be identified
by the Buyer at the time of quotation (if any)
or at the time of order placement.
3. TAXES:
Any tax or other charge imposed by law on
the sale or production of goods or the per-
formance of services shall be paid by the
Buyer, unless the law specifically provides that
such payment must be made by Seller, in
which case Buyer shall reimburse Seller for
such payment as part of the purchase price.
Custom duties, consular fees, insurance
charges and other comparable charges will be
borne by Buyer.
4. SHIPPING SCHEDULE AND
DELIVERY:
Shipment schedules are given as accurately
as conditions permit and every effort will be
made to make shipments as scheduled. Seller
will not be responsible for deviations in meet-
ing shipping schedules nor for any losses or
damages to Buyer (or any third party) occa-
sioned by deviations in the shipping schedule,
whether due to Acts of God, orders bearing
T E R M S A N D C O
priority ratings established pursuant to law,
differences with workmen, local labor short-
ages, fire, flood, shortages or failure of raw
materials, supplies, fuel, power or transporta-
tion, breakdown of equipment or any other
causes beyond Seller’s reasonable control,
whether of similar or dissimilar nature than
those enumerated. Seller shall have additional
time within which to perform as may be rea-
sonably necessary under the circumstances and
shall have the right to apportion its produc-
tion among its customers in such a manner as
it may consider to be equitable. Seller reserves
the right to furnish commercially equivalent or
better substitutes for materials or to subcon-
tract the Buyer’s order or portions thereof as
Seller deems necessary. In no event shall Seller
be liable for any consequential damages for
labor resulting from failure or delay in ship-
ment. If Buyer requires drawings, procedures,
standards or similar material for approval,
shipping schedules will be calculated from
the time such approvals are received by Seller,
since shipping schedules are based on Seller
having all required information and a firm
order from Buyer which is enterable into pro-
duction. Any hold points, witness points or the
need for inspection by Buyer’s representatives
must be identified by Buyer at the time of
quotation (if any) and/or order placement in
order that the effect on the prices or shipping
schedules (if any) can be taken into account.
Additional inspection or testing required by
Buyer which affects normal production
sequence will be considered as extending
the shipping dates accordingly.
5. MINIMUM BILLING:
Seller reserves the right to impose a minimum
billing charge on all sales, change orders or
order supplements.
6. TERMS OF PAYMENT:
Terms of payment for all materials and service
are 30 days from invoice date, at net price,
provided satisfactory credit has been estab-
lished. All unpaid invoices are subject to the
maximum legal interest rate per annum
commencing with the due date.
7. CANCELLATIONS AND RETURNS:
Purchase orders once placed by Buyer and
accepted by Seller can be canceled only with
Seller’s written consent and upon terms which
will save Seller from loss. No products may
be returned for credit or adjustment without
written permission from Seller’s office author-
ized to issue such permission.
8. WARRANTIES:
All products of Seller’s manufacture are war-
ranted against defects of material and work-
manship for a period of twelve (12) months
from the date of installation or eighteen (18)
months from date of shipment, whichever
period first expires, when such products are
used in the service and within the pressure
range for which they were manufactured. In
the case of products or parts not wholly of
Seller’s manufacture, Seller’s liability shall be
limited to the extent of its recovery from the
manufacturer of such products or parts under
N D I T I O N S
its liability to Seller.
Any repair work performed by Seller is war-
ranted for one year from completion of such
repairs and applies only to work performed.
If, within these specified periods, Seller
receives notice from Buyer of any alleged
defect in or nonconformance of any product
or repair and if in the Seller’s sole judgment
the product or repair does not conform or
is found to be defective in material or work-
manship, then, Buyer shall, at Seller’s request,
return the part or product F.O.B. to Seller’s
designated plant or service location. Seller,
at its option and expense, shall repair or
replace the defective part or product, or
repay to Buyer the full price paid by Buyer
for such defective part, repair or product.
Any repayment of purchase price shall be
without interest.
Seller’s warranty liability, including defects
caused by Seller’s negligence, shall be limited
to such repair, replacement or refund, and
shall not include claims for labor costs, expens-
es of Buyer resulting from such defects, recov-
ery under general tort law or strict liability or
for damages resulting from delays, loss of use,
or other direct, indirect, incidental or conse-
quential damages of any kind. Seller will not
be responsible for failures of products which
have been in any way tampered with or
altered by anyone other than an authorized
representative of Seller, failures due to lack of
compliance with recommended maintenance
procedures or products which have been
repaired or altered in such a way (in Seller’s
judgment) as to affect the products adversely.
THIS WARRANTY IS EXPRESSLY IN LIEU OF
ALL OTHER WARRANTIES, EXPRESS, STATUTO-
RY OR IMPLIED, INCLUDING THE WARRANTY
OF MERCHANTABILITY AND FITNESS FOR
PARTICULAR PURPOSE WHICH EXCEED THE
FOREGOING WARRANTY.
9. NUCLEAR SALES:
The products sold hereunder are not designed
or manufactured for use in or with any atomic
installation or activity. If the Buyer or ultimate
user of these products intends to use them in
such an installation or activity, Seller’s Nuclear
Terms of Sale shall be part of and control this
contract. Seller will furnish Buyer with a copy
of its Nuclear Terms of Sale upon request.
10. PATENT INFRINGEMENT:
Seller warrants that the use or sale of material
or apparatus sold or rented by it to Buyer
hereunder will not infringe United States’
patents of others covering such material or
apparatus by itself, and hereby agrees to
indemnify Buyer against judgment for dam-
ages for such infringement of any such patent,
provided that Buyer shall, upon receipt of any
claim for infringement of any such patent or
threat of suit for such infringement or upon
the filing of any suit for infringement,
whichever comes first, promptly notify Seller
in writing and afford Seller full opportunity, at
its option and its own expense, to answer such
claim or threat of suit, assume the control of
the defense of said suit, and settle or compro-
mise same in any way Seller sees fit. Other
p25
 T E R M S A N D C O N D I T I O N S
than court-awarded judgments as aforesaid
Seller shall not be liable for any delays, loss of
use or for other direct, indirect, incidental or
consequential damages incurred by reason of
any such judgment. Seller does not warrant
that such material or apparatus (a) will not
infringe any such patent when not manufac-
tured by or for Seller or when specially made
in whole or in part to the Buyer’s design speci-
fication and such infringement arises from
the inclusion of such specified design or (b),
if used or sold in combination with other
material or apparatus, or if used in the
practice of a process, will not, as a result of
such combination or use, infringe any patent
covering such combination or process; and
Seller shall not be liable for and does not
indemnify Buyer for damages or losses of any
nature whatsoever resulting from actual or
alleged patent infringement arising pursuant
to (a) or (b) above.
11. SELLER’S RIGHT TO
MANUFACTURE:
Seller in its sole discretion shall have the right
to manufacture the products provided hereun-
der as far in advance of its estimated shipping
schedule as it deems appropriate. Seller
expressly reserves the right to change or modi-
fy the design and construction of any product
in due course of Seller’s manufacturing proce-
dure without incurring any obligation or liabil-
ity to furnish or install such changes, modifica-
tions or improvements to products previously
or subsequently sold.
12. ENGINEERING AND SERVICE:
Upon request, Seller will provide engineering
and/or technical information regarding its
products and their uses and, if feasible, will
provide personnel to assist Buyer in effecting
field installations and/or field service. Any such
information, service or assistance so provided,
whether with or without charge, shall be
advisory only. In that regard, neither Seller
nor Buyer assumes any liability for the acts or
omissions of the other party except as may be
provided in these terms.
13. LABOR STANDARDS:
Seller hereby certifies that these products were
produced in accordance with all applicable
requirements of Section 6, 7 and 12 of the
Fair Labor Standards Act as amended and of
regulations and orders of the United States
Department of Labor issued under Section 14
thereof.
14. INSPECTION:
Unless otherwise agreed in writing, final
inspection and acceptance of products must
be made at Seller’s plant or other shipping or
receiving point designated by Seller and shall
be conclusive except as regards latent defects.
Buyer’s representatives may inspect at the
Seller’s plant or shipping point during working
hours prior to shipment in such manner as will
not interfere with operations.
15. TITLE:
Title to the products sold hereunder passes
to Buyer upon payment of the full purchase
T E R M S A N D C O
price.
16. TRANSPORTATION CHARGES,
ALLOWANCES, CLAIMS:
All prices are F.O.B. Seller’s plant or other
designated shipping point.
No freight is allowed unless stated in
Seller’s quotation (if any) or in a written
contract which may exist between Seller and
Buyer at the time of shipment. If Seller’s quo-
tation or a written contract states that all or a
portion of freight is allowed, all prices are
F.O.B. Seller’s plant or other designated ship-
ping point, with most economical surface
transportation allowed. If the quoted or con-
tractual price includes transportation, Seller
reserves the right to designate the common
carrier and to ship in the manner it deems
most economical. Added costs due to special
routing requested by the Buyer are chargeable
to the Buyer. Under no circumstances is any
freight allowance which is absorbed by Seller
to be deducted from the selling price. If the
quoted price or contract includes transporta-
tion, no deduction will be made in lieu thereof
whether Buyer accepts shipment at plant,
warehouse, freight station, or otherwise
supplies its own transportation. When sales
are made from the Seller’s warehouse, Seller
reserves the right to charge either actual or
pro-rated freight from Seller’s principle point
of manufacture to Seller’s warehouse. Buyer
assumes risk of loss upon delivery to the carri-
er, regardless of who pays shipping costs.
Seller endeavors to pack or prepare all
shipments so that they will not break, rust or
deteriorate in transit, but does not guarantee
against such damage. Unless requested in
writing by the Buyer, no shipments are insured
by Seller against damage or loss in transit.
Seller will place insurance as nearly as possible
in accordance with Buyer’s written instructions
but in such case Seller acts only as agent
between the insurance company and the
Buyer and assumes no liability whatsoever.
Any claims for shipping loss, breakage or
damage (obvious or concealed) are Buyer’s
responsibility and should be made to the
carrier. All claims regarding shortages must be
made within thirty (30) days from receipt of
shipment and must be accompanied by the
packing list(s) covering the shipment.
17. CONSULAR INVOICES:
Consular fees for legalizing invoices, stamping
bills of lading, or other documents required
by the laws of any country or destination are
not included in quotations or selling prices. If
instructed in writing, Seller will make arrange-
ments for consular documents and declarations
as agent of the Buyer, but Seller assumes no
liability whatsoever as a result of making such
arrangements. Seller assumes no responsibility
for any fines or other charges imposed due to
errors or incorrect declarations.
18. INDEMNIFICATION AND
LIMITATION OF LIABILITY:
A. INDEMNIFICATION:
Seller agrees to indemnify Buyer and hold
Buyer harmless against any claims, demands
N D I T I O N S
or causes of action for property damage or
personal injury (including death) caused by
the negligent act or omission of any employ-
ee, agent or subcontractor of Seller and not
contributed to by the negligence of Buyer,
its employees, its agents or any third party.
Seller shall not be responsible for the acts and
workmanship of employees, agents, contractors
or subcontractors of Buyer or any third party,
nor for failure or malfunction of any tools,
materials, equipment, products, supplies,
facilities or devices not manufactured and
supplied by Seller. Buyer agrees to hold Seller
harmless from any and all losses, claims, or
damages arising from subsurface damage,
surface damage caused by subsurface damage,
loss of hydrocarbons and from pollution,
regardless of whether such damages, losses or
claims were caused by the negligence or sole
negligence of Seller, it being the intent of the
parties that this indemnity shall apply to prop-
erty of Buyer or to that of any third party.
B. LIMITATION OF LIABILITY:
UNDER NO CIRCUMSTANCES SHALL SELLER BE
LIABLE FOR ANY SPECIAL, CONSEQUENTIAL OR
INCIDENTAL DAMAGES, INCLUDING, BUT NOT
LIMITED TO LOSS OF ANTICIPATED PROFITS,
LOSS OF USE OF EQUIPMENT OR OF ANY
INSTALLATION, SYSTEM OR FACILITY INTO
WHICH SELLER’S EQUIPMENT MAY BE LOCAT-
ED OR AT WHICH SELLER, ITS AGENT OR SUB-
CONTRACTOR MAY BE PERFORMING WORK.
Seller’s total responsibility for any claims,
damages, losses or liabilities arising out of or
related to its performance of this contract or
the products or services covered hereunder
shall not exceed the purchase price.
19. MODIFICATION, RESCISSION
& WAIVER:
The terms herein may not be modified or
rescinded nor any of its provisions waived
unless such modification, rescission or waiver
is in writing and signed by an authorized
employee of Seller at its office in Houston,
Texas.
Failure of Seller to insist in any one or
more instances upon the performance of any
of the terms and conditions of the contract or
the failure of Seller to exercise any of its rights
hereunder shall not be construed as a waiver
or relinquishment of any such term, condition,
or right hereunder and shall not affect Seller’s
right to insist upon strict performance and
compliance with regard to any unexecuted
portions of this contract or future perform-
ance of these terms and conditions.
All orders must be accepted by an
authorized employee of Seller. The rights
and duties of the parties and construction
and effect of all provisions hereof shall be
governed by and construed according to the
internal laws of the State of Texas. Any disputes
which arise under this agreement shall be
venued in the District Court of Harris County,
Texas or in the Southern District of Texas.
p26
 T R A D E M A R K I N F O R M A T I O N

References in this catalog to registered trademarks or product

designations, which are owned by Cooper Cameron Corporation
are as follows:

Cameron®
Demco®
DynaCentric®
DynaSeal®
Foster®
Pow-R-Seal®
Saf-T-Seal®
Thornhill Craver ™
Unibolt ™
W-K-M®

References in this catalog to registered trademarks or product

designations, which are not owned by Cooper Cameron
Corporation are as follows:

Celcon Hoechst Celanese Corporation

Delrin E. I. Dupont De Nemours & Company
Fluorel Minnesota Mining and Manufacturing Company
Hastelloy Haynes International, Inc.
Hycar Hydrocarbon Chemical and Rubber Company
Hydrin Zeon Chemicals USA, Inc.
Hypalon E. I. Dupont De Nemours & Company
Inconel INCO Nickel Sales, Inc.
Monel INCO Alloys International, Inc.
Nordel E. I. Dupont De Nemours & Company
Stellite Stoody Deloro Stellite, Inc.
Teflon E. I. Dupont De Nemours & Company
Viton E. I. Dupont De Nemours & Company

T R A D E M A R K I N F O R M A T I O N p27
USA Argentina Other Locations
Cooper Cameron Valves Cameron Argentina S.A.I.C. Austria
16500 South Main Street Av. Antartida Argentina 2711 Australia
Missouri City, TX 77489-1300 CC No. 2 Brazil
Phone: 281-499-8511 2800 Zarate, Pica Buenos Aires Brunei
Fax: 281-499-6965 Phone: 54-487-22297 Chile
Fax: 54-487-23404 Congo
UK Egypt
Cooper Cameron Valves Singapore England
Houstoun road Cooper Cameron (Singapore) Gabon
Livingston, West Lothian Pte. Ltd. Germany
Scotland, EH545BZ No. 2 Gul Circle Hungary
Phone: 441-506-444-000 Jurong Industrial Estate Indonesia
Fax: 441-506-441-320 Locked Bag Service No. 3 Ireland
Jurong Town Post Office Japan
Canada Singapore 2262 Malaysia
Cooper Cameron Corporation Republic of Singapore Netherlands
715-5th Ave. S.W. #600 Phone: 65-861-3355 New Zealand
Calgary, Alberta T2P 2X6 Fax: 65-861-6197 Nigeria
Canada Norway
Phone: 403-261-2800 France Oman
Fax: 403-262-5181 Cameron France, S.A. Poland
Plaine Sainte-Pierre Qatar
Mexico CS 620 Russia
Cooper Cameron de Mexico 34535 Beziers Cedex Saudi Arabia
S.A. de C.V. Beziers, France UAE
Avenida Homero 1804, Phone: 33-467-111500 Venezuela
Suite 403 Fax: 33-467-111600
Col. Chapultepec Morales,
11510 Mexico, D.F. Mexico.
Phone: 52-5-580-0296
Fax: 52-5-395-8669

COOPER CAMERON
VA LV E S

16500 South Main Street

Missouri City, TX 77489
281 499 8511
800 323 9160
www.ccvalve.com

©Cooper Cameron Corporation, Cooper Cameron Valves Division Printed in USA 1/01 TC1466
