Slot diffusers and round duct diffusers

04
Slot diffusers, Round duct diffusers
Slot diffusers Round duct diffusers
176
VENTILATING GRILLES,
VENTILATING VALVES
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
VARIABLE SWIRL DIFFUSERS
SWIRL DIFFUSERS,
ROUND DUCT DIFFUSERS
SLOT DIFFUSERS,
AIR DISPLACEMENT UNITS
Slot diffusers,
Round duct diffusers
SUPPLY AIR NOZZLES

Slot diffusers are designed for air supply in rooms with
floor to ceiling heights of 2.5 to 4 m. They are suitable
for supplying either cold or warm air, in particular in
EXTERNAL ELEMENTS
applications where air conditioning comfort demands
are stringent. Due to their high induction rate and rapid
decrease of temperature difference, these diffusers are
also suitable for variable systems.
CONTROL UNITS
Round duct diffusers can be installed at various

AIR FLOW
locations within the duct network. They are suitable for

supplying either cold or warm air.
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
177
Overview
■■ Slot diffusers ■■ Round duct diffusers Slot diffusers
Slot diffusers are designed for air supply Round duct diffusers can be installed at
in rooms with floor to ceiling heights of various locations within the duct network.
2.5 to 4 m. They are suitable for supplying They are suitable for supplying either cold
either cold or warm air, in particular in or warm air. LD-13 LD-14
applications where air conditioning com-
fort demands are stringent. Due to their
high induction rate and rapid decrease of ■■ Software: KLIMA ADE
temperature difference, these diffusers
are also suitable for variable systems. LD and SKD Software:
• available calculation and graphical LD-15 LD-18
display of air supply for slot diffusers
■■ Nozzle diffusers LD-13, LD-14 and LD-15
• available calculation of technical speci- Nozzle diffusers
Nozzle diffusers LD-19 are designed for fications for the application of wall- or
supply of warm or cold air and can be ceiling-mounted slot diffusers
mounted in the wall or in the ceiling. Adju- • available calculation of ceiling-moun-
stable deflectors allow us to set different ted multiple-diffuser configuration air
directions of air discharge. supply
Nozzle diffusers LD-20 are designed to • application of vertical or horizontal LD-19 LD-20
supply low quantities of air on big window slot diffuser air supply into the room,
surfaces to prevent condensation (ceiling depending on the mode of operation –
installation near windows) or for big heating or cooling Floor slot diffusers
throws for cooling when wall installation • the package supports basic air supply
(Coanda effect). mode models for the SKD-13 round
duct diffuser
• available calculation of SKD-13 round
■■ Panel design slot diffusers duct diffusers cooling mode: single-si-
de and two-side horizontal supply and LD-16N
A panel design slot diffuser consists of a alternating horizontal supply heating
face plate and a plenum box. Cylindrical mode: vertical air supply
air deflectors, equal to those in LD-13 and Panel design slot diffusers
LD-14 diffusers, are installed in the slots,
to allow continuous adjustment of dischar- Software: Klima ADE
ged air direction within the 360° range.
On order, diverse plate designs and slot
patterns are available.
■■ Floor slot diffusers

LDP-14
LD-16N floor slot diffusers are a suitable
solution for swimming pools and similar
rooms with large glass surfaces and
windows. They are designed for installati-
on in the floor. Warm air is supplied in the
upwards direction, towards the window.
SKD-13D
178
VENTILATING VALVES
Content
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
Page
Slot diffusers 180

Slot diffusers LD-13, LD-14 180
Slot diffusers LD-15 195
Slot diffusers LD-17, LD-18 199

Nozzle diffusers LD-19 213
SWIRL DIFFUSERS,
Nozzle diffusers LD-20 219
Floor slot diffusers LD-16N 230
Panel design slot diffusers LDP-13, LDP-14 232
Round duct diffusers 234

Round duct diffusers SKD-13 234
SLOT DIFFUSERS,
SUPPLY AIR NOZZLES
■■ Legend of symbols
EXTERNAL ELEMENTS
Element is made of aluminium Element is intended to be built in Element is suitable for the supply
AI
profiles, aluminium sheet or the wall. of cool air (cooling).
aluminium casting.
Element is made of steel sheet. Element is intended to be built in Element allows regulation by electric
St M
the ceiling or in the wall. motor (Belimo electric motors).
CONTROL UNITS
AIR FLOW
RAL Element is powder painted in stan- Element for air conditioning of rooms F Element is intended for air filtration.
9010 EU...
dard RAL 9010 colour. Other desired with floor to ceiling heights room up The filter of class … is built in.
colour is to be specified in the order. to 4 m.
Shady symbol means possibility of Element for air conditioning of rooms CD The possibility of the automatic selec-
optional material, surface protection, with floor to ceiling heights from 6 to tion and calculation of the technical
SOUND ATTENUATORS,
SOUND ATTENUATING
motor version, … 15 m. characteristics of grilles and difusers in

LOUVRES
regard to the given conditions with the

assistance of the Klima ADE program.
Element is intended to be built in the Element is suitable for the supply of INOX
The element is made of stainless
floor. warm air (heating). sheet steel AISI 304.
179
Slot diffusers
Slot diffusers
■■ Slot diffusers LD-13, LD-14
Application
LD-13 and LD-14 slot diffusers are
designed for the supply of air in rooms
with floor to ceiling heights of 2.5 to 4 m
for supplying either cold or warm air, in AI
particular in applications where air
conditioning comfort demands are
stringent. Due to their high induction
rate and rapid decrease of temperature
difference, these diffusers are also
suitable for variable systems.
RAL
9010
Description
LD-13 and LD-14 slot diffusers are CD
designed in 1, 2, 3 and 4-slot versions.
Diffuser face plate consists of anodised
aluminium sections with built-in cylindrical
deflectors made of plastics. Deflectors
allow continuos adjustment of discharged
air direction within the 360° range
as well as control of supply air flow rate.
The cylindrical deflectors also allow full LD-13
shutting of the diffuser. The slot diffuser F

9.4
plenum box is made of galvanised sheet 4
steel and has a flow rate control damper B 60 LD-13

8.5
built in its inlet spigot, to allow fine adjust- F 5

41
ment of the desired air flow rate. 1 9.4 46

2
8.5
3
15 7 5
Control schematic of the spigot
41
A
fD
6
H
volume control damper E

H1
15 7
A
E
a
LD-14
F
9.4 4
8
LD-14
8.5
F
5
53
9.4 4
6
8.5
5
53
26 7 6
A
E
26 7
1 Plenum boxA
E
2 Inlet spigot
3 Volume control damper
4 Main section
5 Cylindrical deflector
6 Side lateral section
7 Connecting section
8 Outside insulation
180
Slot diffusers
VENTILATING VALVES
LD-13/1 LD-13/2 LD-13/3 LD-13/4
Slot diffuser types
• Single-slot (designation LD-13,14/1)
• Two slots (designation LD-13,14/2)
• Three-slots (designation LD-13,14/3) LD-14/1 LD-14/2 LD-14/3 LD-14/4
• Four-slots (designation LD-13,14/4)
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
Slot diffusers LD-13 O/ 1
41.5
LD-14 O/ 1
53.5

LD-13 O, LD-14 O
SWIRL DIFFUSERS,
37.5
50
Narrow version
The narrow slot diffuser differs from the
conventional slot diffuser construction as LD-13 O/ 2 LD-14 O/ 2
53.5
41.5
regards its mounting to the ceiling or wall.

The conventional slot diffuser has a 72.5 96.5
L-cross-section mounting sleeve which

remains visible and may, in certain appli-
SLOT DIFFUSERS,
cations, interfere with aesthetic require- LD-14 O/ 3
53.5
LD-13 O/ 3
41.5
ments. The narrow design has eliminated

this deficiency as well as introduced 107 142
improved structural rigidity due to its
reinforced sleeve. The product is thus sui-
table for installation in cooling suspended LD-14 O/ 4
53.5
LD-13 O/ 4
41.5
ceilings as well.

142 187.5
LD-13 O, LD-14 O LD-13, LD-14
SUPPLY AIR NOZZLES

Standard lenghts L
LD-13 and LD-14 slot diffusers are avai-
lable in standard lengths ranging from
EXTERNAL ELEMENTS
L=300 to L=2000 mm, with a 100 mm
LD-13
step. In cases where longer diffusers are
required, they can be joint together by
No. of slots H H1 B A E F
means of (rail-type) connecting plates.
Plenum boxes are also available in 1 220 261 95 33 57.5 24.4
standard lengths ranging from 300 mm to
2 230 271 129 67 92 58.2
2000 mm.
3 250 291 162 101 126.5 92.0
CONTROL UNITS
AIR FLOW
4 290 331 196 135 161.5 125.8

Special orders
On customer’s request slot diffusers can
LD-13
be made in other dimensions. End seals
and longitudinal sections are painted in No. of slots H H1 B A E F
any RAL scale colour according to the
SOUND ATTENUATORS,
SOUND ATTENUATING
customer’s request. As standard, cylindri- 1 233.5 287 106 44 69 35.3

cal deflectors are black or white, on the
LOUVRES
2 253.5 307 150 89 115 80

customer’s request, they can be coloured
in any RAL scale colour. Non-standard 3 293.5 347 195 133 161.5 124.7
colours and extra components are to be
ordered separately. 4 318.5 372 240 178 206.5 169.4
181
Slot diffusers
Number and diameter of inlet L 300 do 1000 1100 do 1500 1600 do 2000
spigots Number and diameter of inlet spigots
No. of slots
LD-13 LD-14 LD-13 LD-14 LD-13 LD-14
1 1 x 98 1 x 123 2 x 98 2 x 123 2 x 123 2 x 138
2 1 x 138 1 x 158 2 x 123 2 x 138 2 x 138 2 x 158
3 1 x 158 1 x 198 2 x 138 2 x 158 2 x 158 2 x 198
4 1 x 198 1 x 223 2 x 158 2 x 198 2 x 198 2 x 223
L/2 L/2
Position of inlet spigots Number of Standard Position of J J
inlet spigots length spigots
1 300 – 1000 L/2
2 1100 – 1500 J = 300
2 1600 – 2000 J = 400
Slot diffuser face plate designs

Slot diffuser face plates are made of
linear or angular ended sections, which
300
angle 90˚
allow the diffusers to be joined at different
angles. Angular ended sections are not
fitted with air direction controls.
300
Cylindrical deflectors
Cylindrical deflectors are an important
components of a slot diffuser. They allow
adjustment of both air flow rate and
direction. Cylindrical deflectors are made of
plastics. As standard, they are black or
white.
End seals
End seals are components of the diffuser
face plate. They are available in two
designs:
• a
s an angle piece (E – on both ends,
ET – on one end only) or
• plates (F – on both ends, FT – on one
end only).
The connecting strip-section has no end
angle pieces or plates seals (designation T).
Joining diffusers together in

length and width
Joining in width (into diffusers with
multiple slots) requires special strip
sections, while joining in length requires
connecting plates (the total length of
combined diffusers is not limited).
182
Slot diffusers
VENTILATING VALVES
Fixing of the plenum box onto
LD-13, LD-14 diffusers
• With self-tapping screws (designation U)
• With spring clamps (designation S)
• With a cross-member (designation Z)
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
Fixing with self-tapping Fixing with spring clamps (S) Fixing with a cross-member (Z)
screws (U)

SWIRL DIFFUSERS,
Installation methods
• With a threaded bar (designation R)
• With a wire (designation R)
• With suspension brackets on the
plenum box (designation P)

• With special fixing elements
SLOT DIFFUSERS,
(designation R)
• With springs (designation N)

Installation with Installation with wire (R) Installation with
a threaded bar (R) suspension bracket (P)
SUPPLY AIR NOZZLES

EXTERNAL ELEMENTS
Installation with special Installation with springs into ducts (N)

fastening elements (R)
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
183
Slot diffusers
Types of air discharge

a b
LD-13
Max. air flow rate

Min. air flow rate
Standard Standard
Discharge direction (left, right) (right)
c d
101˚
Discharge angle
LD-14
Standard Standard
(left) (vertical)
Max. air flow rate
Min. air flow rate
e f g
Discharge direction
Air jet angle 60° Air jet angle 60° Air jet angle 60°
(left, right) (right) (left)
Discharge angle
Slot diffuser with actuator controlled

discharge direction
3
Slot diffusers with actuator controlled
discharge direction are suitable for
summer-winter air supply applications.
The desired direction of air jet is achieved
by means of an electric actuator which
moves a slider. Manual adjustment is 2
therefore not necessary. Compared with Top view
Pogled z vrha
standard slot diffusers, air flow rate is

reduced by 50 %. There are two options
for the Belimo electric motors: 1
LH 24A-SR100 and LH-24A-MP100. The

first operates at 24V AC/DC, the second
within the range of 0-10V or 0-32V. Their
travel distance is 100 mm, for which 150
s is required.
Component Parts
1. Slot diffuser
2. Deflector
3. Electric actuator
In case the discharge angle is to be
adjustable by means of an electric Every second row Every second row
actuator (winter-summer application), 1 Adjustment of deflectors for 2 Adjustment of deflectors for
this requirement shall be specified warm air supply cold air supply
in the ordering form.
*
Motor version on customer’s request.
184
Slot diffusers
VENTILATING VALVES
Ordering key
LD-13/1/B/E/K/M/S/P/I/g L=1700
Length L=300, 400, 500, …, 2000 (single piece)
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
Type of air discharge (a, b, c, d, e, f, g)
I5 Thermal insulation (polyethylene), 5 mm thick, on the outside of the plenum box

I9 Sound and thermal insulation (from -40 °C to 105 °C), 9 mm thick, on the outside of the
plenum box (synthetic rubber based material)

SWIRL DIFFUSERS,
N Installation with spring clamps – without plenum box (LD-13 and LD-14 only)
P Installation of the plenum box with hangers
R Installation with brackets built in the basic section
Z Fixing of the diffuser to the plenum box with a cross-member

S Fixing of the diffuser to the plenum box with spring clamps

SLOT DIFFUSERS,
U Fixing of the diffuser to the plenum box with self-tapping screws
M Volume control damper
K Plenum box
E End sealing on both ends

ET End sealing on one end
F End plate on both ends
FT End plate on one end
T Rail-type without end sealings and plates
B Black deflectors
W White deflectors
SUPPLY AIR NOZZLES

1 Number of slots
2
3
4
LD-13 Slot diffuser

LD-14
EXTERNAL ELEMENTS
LD-13 O Narrow slot diffuser
LD-14 O
Note:
• Please specify the deflector colour in your order.
• Standard eloxal colour of the aluminium section is the original aluminium colour. Other colours shall be specified in the order.
• For the LD-13 0 and LD-14 0 type, the following end seals are available: F, FT and T.
• When installing in cooling ceilings, consult the manufacturer.
• In the case the slot diffuser is ordered complete with plenum box, the air jet configuration is set as shown on the drawing on page 184.
CONTROL UNITS
AIR FLOW
• Versions with insulation on the inside of the plenum box are also available.
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
185
Slot diffusers
Wall mounted slot diffusers 4

LD-13S and LD-14S
Application 1’
Designed for installation in plasterboard walls with a thickness of

100 mm or more. These are used for the supply of air in rooms
with ceiling heights of 2.5 to 4m. Suitable for cooling as well as
for heating, especially in rooms with elevated comfort requi-
rements. They may also be used to discharge the air from the 1
room, and enable a high level of induction.
Description
Inlet or outlet connection may be in the plenum box above the
ventilated room or on the other side of the wall. On the diffuser
side, the plenum box is sound-insulated, lowering the level of 3
2
noise emissions in the ventilated room.
Component parts
1. front chamber connection (KF)
1’. rear chamber connection (KB)
2. slot diffuser LD-13S or LD-14S Installation in the plasterboard
3. sound insulation
4. plenum box
Plenum box
Despite its low height, it assures sufficient air distribution in
the direction from the plenum box connection to LD-13 or D-14
across the entire length of the diffuser. It can be installed in
plasterboard walls with a minimum thickness of 100 mm. Design
allows installation and placement on metal profile brackets of
internal plasterboard walls.
Front plenum box connection

Front plenum box connection allows air inlet and outlet above the
suspended ceiling of the ventilated room. This assures a certain
competitive advantage, as there is no need to adjust the duct
network to the diffuser placement.
Dimensions
Rear plenum box connection
Rear side connection allows air inlet and outlet through the
neighboring room. Due to the height of the connector according B1 B2
to LD-13 o LD-14, the duct network can be placed above the
L
suspended ceiling.
Sound insulation
Sound insulation has enhanced absorption properties and
prevents the spreading of emissions from the duct network into
H
the ventilated room. The insulation placement effectively reduces

internal noise generation in the entire plenum box, particularly
M1
on the location of the inlet jet through the connection.

H2
H H1 H2 B B1 B2 L ΦD
(mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
LD-13S/1 289 203 40 75 58 45 1000 98
LD-14S/1 289 203 74 75 58 45 1000 123
LD-13S/2 289 203 51 75 58 45 1000 138
LD-14S/2 289 203 96 75 58 45 1000 158
186
Slot diffusers
VENTILATING VALVES
Ordering key
LD-13S/1/B/E/K/I5 L =1000
Length
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
I9 Sound and thermal insulation (from -40 °C to 105 °C), 9 mm thick, on the outside of
the plenum box (synthetic rubber based material)
KF Plenum box, front side connection

KB Plenum box, back side connection
SWIRL DIFFUSERS,
F End plate on both ends

SLOT DIFFUSERS,
B Black deflectors
W White deflectors
1 Number of slots
2
S For wall installation

LD-13 Slot diffuser type
LD-14
Note:
SUPPLY AIR NOZZLES

EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
187
Slot diffusers
Fast selection diagram:

LWA < 35 dB(A)
4
Technical specifications for one-slot
diffuser, per meter of lenght,
at horizontal discharge
3
A(m²) Q(m³/h) LWA (dB)
LD-13 0.0092 135 34
of slots
rež
LD-14 0.0136 210 28
Število
2
Nr.
1
LD-13
LD-14
100 300 500 1000 1200

Q(m3/hm)
L
Definition of symbols L
A
x
L
x
A
L x
Q (m³/hm) Air flow rate to length

x (m) Horizontal distance to the wall
H (m) Room height
V H1
L (m) Throw distance (L=H1+x)
H1
H1
ΔtH V L
VL (m/s) Air velocity at the throw ΔtL VL V H1 VL
distance L ΔtL ΔtH ΔtL
Δtz (K) Temperature difference betwe-

en the supply and room air
ΔtL (K) Difference between the core
and room air temperature
Δp (Pa) Pressure drop
LWA (dB(A)) Sound power level
vH1 (m/s) Air velocity at the distance H1
A, B (m) Distance between diffusers, in
length and in width
H1 (m) Throw distance
188
Slot diffusers
VENTILATING VALVES
Air velocity diagrams for LD-13, at different throw distances
One or two sided horizontal discharge
H1 (m)
1 1.2 1.6 2
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
(m³/hm) 2.5
LD-13 / 1 160 125 110 90 70 55 45 LD-13 / 1 160 125 110 90 70 55 45
LD-13 / 2 230 180 155 125 100 LD-13 / 2 230 180 155 125 100
LD-13 / 3 280 220 185 155 LD-13 / 3 280 220 185 155
LD-13 / 4 325 250 215 180 LD-13 / 4 325 250 215 180
0.8

0.6
SWIRL DIFFUSERS,
0.5
0.4
VL (m/s)
0.4
VH1(m/s)
0.3 0.3
0.25 0.25
0.2 0.2

0.15
SLOT DIFFUSERS,
0.15
0.1
2 2.5 3 4 5 7 10 2 2.5 3 4 5 7 10
A (m) L (m)

Alternate sided horizontal discharge
H1 (m)
1 1.2 1.6 2
(m³/hm) 2.5
LD-13 / 1 160 125 110 90 70 55 45 LD-13 / 1 160 125 110 90 70 55 45
LD-13 / 2 230 180 155 125 100 LD-13 / 2 230 180 155 125 100
LD-13 / 3 340 280 220 185 155 LD-13 / 3 340 280 220 185 155
LD-13 / 4 395 325 250 215 180 LD-13 / 4 395 325 250 215 180
SUPPLY AIR NOZZLES

0.7
0.5
0.3
0.25 0.4
0.2 0.3
VH1 (m/s)
0.25
0.15
0.2
VL (m/s)
0.1
EXTERNAL ELEMENTS
0.15
0.1
0.05
2 2.5 3 4 5 7 10 2 2.5 3 4 5 7 10
A (m) L (m)
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
189
Slot diffusers
Air velocity diagrams for LD-14, at different throw distances
One or two sided horizontal discharge
H1 (m)
1.6 2 1.2
1 (m) 1.6 2 (m³/hm) (m³/hm)
H1 2.5 2.5
1.6 2 1.2
-14 / 1 1 LD-14 1.6
/1 2 2.5 2.5
-14 / 2 LD-14 / 2
4/1 LD-14 / 1
4/2 LD-14 / 2
0.8 0.8
0.8 0.8
0.6 0.6
0.5
0.6 0.5
0.6
0. 4
VH1(m/s)
0.4
0.5 0.4
0.5
V L (m/s)
V L (m/s)
0. 4
VH1(m/s)
0.3 0.4
0.3 0.4
0.3
V L (m/s)
V L (m/s)
0.25
0.3 0.30.25 0.25
0.3
0.25 0.25
0.2 0.2
0.25
0. 2
0.2 0.2
0. 2 0.15 0.15
0.15
0.15 0.15
0.15 0.1 0.1
2 2.5 3 4 5 2 2.57 3 10 4 5 7 10 2 2.5 3 4 2 5 2.5 3 7 4 10 5 7
A (m) A (m) 0.1 0.1
L (m) L (m)
2 2.5 3 4 5 2 7
2.5 3 10 4 5 7 10 2 2.5 3 4 2 5 2.5 3 7 4 10 5 7
A (m) A (m) L (m) L (m)
AlternateH1sided
(m)
horizontal discharge
m)
1.6 2 1H11.2
(m) 1.6 2
2.5 2.5
1.6 2 1 1.2 1.6 2 LD-14 / 1
2.5 LD-14 / 1
(m³/hm) LD-14 / 2 2.5 LD-14 / 2 (m³/hm)
LD-14 / 1 LD-14 / 1
LD-14 / 2 LD-14 / 2
0.7 0.7
0.7
0.5 0.7
0.5
0.3
0.25 0.4
0.5 0.4
0.3 0.5
0.2 0.4
0.3 0.3
0.4
0.25
VH1(m/s)
0.15 0.25 0.25

VL (m/s)
VL (m/s)
0.2 0.3 0.3

VH1 (m/s)
0.1 0.2
0.25 0.2
0.25
VL (m/s)
0.15
VL (m/s)
0.1 0.2
0.15 0.15
0.2
0.15 0.15
0.1 0.1
0.1 0.1
0.05 0.05
2 2.5 3 4 5 2 2.57 3 10 4 5 7 10 2 2.5 3 4 2 5 2.5 3 7 4 10 5 7
A (m) A (m) 0.05 L (m)
0.05 L (m)
2 2.5 3 4 5 2 7
2.5 3 10 4 5 7 10 2 2.5 3 4 2 5 2.5 3 7 4 10 5 7
A (m) A (m) L (m) L (m)
190
Slot diffusers
VENTILATING VALVES
Sound power level and pressure drop
LD 13/1 LD 13/2
0
00
00 00 00
00
00
50
0
20
20 15 10
50
10
200
15
200
55
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
100 50 100 60
55
45 50
50 50
)
45
A)
40
B(
(d
40
A
Lw
35
20 35 20
p t (Pa)
pt (Pa)
15 30

30
))
A
B(
10 25
SWIRL DIFFUSERS,
10
(d
A
8
Lw
25 8
6 6 20
20
4 4
15
3 3
2 2 10
1.5 1.5

1 1
SLOT DIFFUSERS,
100 150 200 300 400 500 700 1000 100 150 200 300 400 500 700 1000
Q (m3/h) Q (m 3/h)
Correction factors applicable to LD-13/1 Correction factors applicable to LD-13/2

Type of Type of
Vertical Horizontal Vertical Horizontal
discharge discharge
Flow rate Flow rate
control Open Closed Open Closed control Open Closed Open Closed
damper damper
L=500 x1 x 1.44 x 0.87 x 1.34 L=500 x1 x 1.91 x 0.86 x 1.79
L=1000 x1 x 3.30 x 0.85 x 3.02 L=1000 x1 x 5.91 x 0.70 x 5.31
L=1500 x1 x 5.26 x 0.84 x 4.47 L=1500 x1 x 9.88 x 0.58 x 8.67
SUPPLY AIR NOZZLES

L=2000 x1 x 7.37 x 0.81 x 5.68 L=2000 x1 x 14.10 x 0.47 x 11.99
Example Example
Q = 150 m³/h Q = 150 m³/h
L = 1000 mm L = 500 mm
EXTERNAL ELEMENTS
Δpt = 14 Pa (vertical; damper opened) Δpt = 22 Pa (vertical; damper opened)
Δpt = 14 x 3.30 = 46.2 Pa (vertical; damper closed) Δpt = 22 x 1.91 = 42.0 Pa (vertical; damper closed)
Δpt = 14 x 0.85 = 11.9 Pa (horizontal; damper opened) Δpt = 22 x 0.86 = 18.9 Pa (horizontal; damper opened)
Δpt = 14 x 3.02 = 42.3 Pa (horizontal; damper closed) Δpt = 22 x 1.79 = 39.4 Pa (horizontal; damper closed)
LWA = 32 dB(A) LWA = 30 dB(A)

CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
191
Slot diffusers
LD 13/3 LD 13/4
0
50
0
50
200
00
200
10
55
00
75
10
50
00 00
20 15
100 100
00 00
70 45
20 15
60
50 50 40
50
45 35
40
)
A)
B(
)
35 30
A)
(d
B(
20 20
A
(d
Lw
30
A
Lw
p t (Pa)
25
p t (Pa)
10 25 10
8 8 20
6 20 6
4 4 15
15
3 3
10 2 10
2
1.5
1.5
1
1 100 150 200 300 400 500 700 1000
100 150 200 300 400 500 700 1000
Q (m 3/h) Q (m 3/h)
Type of Type of
discharge discharge
Flow rate Flow rate
damper damper
L=500 x1 x 2.37 x 0.84 x 2.24 L=500 x1 x 3.08 x 0.70 x 2.91
L=1000 x1 x 8.52 x 0.56 x7.59 L=1000 x1 x 11.07 x 0.47 x 9.87
L=1500 x1 x 14.50 x 0.32 x 12.86 L=1500 x1 x 18.85 x 0.27 x 16.72
L=2000 x1 x 20.82 x 0.18 x 18.29 L=2000 x1 x 27.07 x 0.15 x 23.78
Example Example
Q = 300 m³/h Q = 300 m³/h
L = 1000 mm L = 500 mm
192
Slot diffusers
VENTILATING VALVES
LD 14/1 LD 14/2
00
0
5 00
50
200 10 200
00
CIRCULAR DIFFUSERS,
15
SQUARE DIFFUSERS
100 00 100
2 0 00
10
(A )) 50
50
50 50
(dB 00
45 15
A
Lw 45 )
40 B( A) 40 00
(d 20
35 Lw
A
35
20 20
p t (Pa)
p t (Pa)
30

30
25
SWIRL DIFFUSERS,
10 10
8 25 8
6 20 6 20
4 4 15
15
3 3
2 2
1.5 1.5

1
SLOT DIFFUSERS,
1
100 150 200 300 400 500 700 1000 100 150 200 300 400 500 700 1000
Q (m 3/h) Q (m 3/h)

Type of Type of
discharge discharge
Flow rate Flow rate
damper damper
L=500 x1 x 1.81 x 0.76 x 1.31 L=500 x1 x 2.11 x 0.53 x 1.59
L=1000 x1 x 3.83 x 0.42 x 3.23 L=1000 x1 x 8.84 x 0.29 x 7.96
L=1500 x1 x 5.80 x 0.28 x 5.11 L=1500 x1 x 15.36 x 0.20 x 14.14
SUPPLY AIR NOZZLES

L=2000 x1 x 7.87 x 0.19 x 7.07 L=2000 x1 x 22.32 x 0.14 x 20.70
Example Example
Q = 300 m³/h Q = 300 m³/h
L = 1000 mm L = 500 mm
EXTERNAL ELEMENTS

CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
193
Slot diffusers

LD 14/3 LD 14/4
0
50
0
50
200 200
100
100
00
50 50 10 50 40
45 00
)) 40 ) 10
A
B( (A
) 35
(d
Lw
A 35
00 (dB
p t (Pa)
20 15 20
p t (Pa)
A
Lw 30
30 00
00 15
25 20
10 10 25 00
8 8 20
20
6 6 20
5
4 4
3 3
15
2 2
1.5 15
1.5
1 1
100 150 200 300 400 500 700 1000 100 150 200 300 400 500 700 1000
Q (m 3/h) Q (m 3/h)
Type of Type of
discharge discharge
Flow rate Flow rate
damper damper
L=500 x1 x 2.41 x 0.33 x 1.87 L=500 x1 x 3.14 x 0.28 x 2.43
L=1000 x1 x 13.86 x 0.19 x 12.69 L=1000 x1 x 18.02 x 0.15 x 16.50
L=1500 x1 x 24.92 x 0.16 x 23.17 L=1500 x1 x 32.34 x 0.13 x 28.12
L=2000 x1 x 36.76 x 0.13 x 31.33 L=2000 x1 x 47.79 x 0.10 x 39.63
Example Example
Q = 600 m³/h Q = 600 m³/h
L = 1000 mm L = 500 mm
194
Slot diffusers
VENTILATING VALVES
■■ Slot diffuser LD-15
Application
Slot diffuser LD-15 is designed to supply
air in rooms with floor to ceiling heights AI
from 2.5 to 4 m. They are primarily desi-
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
gned for the supply of cold air in applicati-
ons with high comfort demands.
Description RAL
9010
LD-15 slot diffuser is of a one-slot con-
struction. The diffuser face plate consi- CD
sts of aluminium sections with built-in

cylindrical deflectors made of recycled
SWIRL DIFFUSERS,
plastics. Individually adjustable
deflectors allow continuous adjustment of 80 60
discharge angle within the 360° range,

as well as adjustment of air flow rate. The
diffuser air flow can be completely shut
by means of the cylindrical deflectors. The
plenum box is made of galvanised sheet

steel.
SLOT DIFFUSERS,
No. of spigots Standard lengths (L)
f78
147
300, 400, 500, 600, 700, 800,

1 900, 1000
1100, 1200, 1300, 1400, 1500,
205

2 1600, 1700, 1800, 1900, 2000
2
Position of inlet spigots

The positions of inlet spigots are equal to
those of LD-13 and LD-14 slot diffusers. 1
See drawing and table on page 182.
SUPPLY AIR NOZZLES

41
3
Slot diffuser face plate designs 1 Plenum box
Slot diffuser face plates are made of line- 2 Inlet spigot
4
ar or angular ended sections, which allow 7.5 3 Main section
the diffusers to be joined at different 4 Cylindrical air deflector
angles. Angular ended sections are not 15
fitted with air direction controls.

Installation openings: 15 x L (diffuser length)
Cylindrical air deflectors
Cylindrical deflectors are the most impor- EXTERNAL ELEMENTS
tant components of a slot diffuser. They
allow free adjustment of the air flow rate.
Joining slot diffusers together in length

Sections can be joint together by means
of connecting plates. Total length of so
joint sections is not limited.
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
Joining slot diffusers

together in length
LOUVRES
195
Slot diffusers
Fixing of the plenum box onto a

LD-15 slot diffuser
• W
ith self-tapping screws (designation U)
• With spring clamps (designation S)
• I nstallation with suspension brackets on
the plenum box (designation P)
• Instalaltion with suspension brackets
on the main section (designation R) Fixing of the diffuser to the plenum box
with self-tapping screws (U) Fixing of the diffuser to the plenum box
with a spring clamps (S)
Installation with suspension brackets Installations with suspension bracket on the main section (R)
on the plenum box (P)
Ordering key
LD-15/B/K/M/S/P/I L=1500
Length L=300, 400, 500, 600 …, 2000 (single piece)
I5 Thermal insulation (polyethylene), 5 mm thick, on the outside of

the plenum box.
I9 Sound and thermal insulation (from -40 °C to 105 °C), 9 mm thick,
on the outside of the plenum box (synthetic rubber based material).
I19 Sound and thermal insulation (from -40 °C to 105 °C), 19 mm
thick, on the outside of the plenum box (synthetic rubber based
material).
P Installation of the diffuser with suspension brackets on the plenum

box
R Installation with suspension brackets on the main section
S Fixing of the diffuser to the plenum box with a spring clamp

K Plenum box
B Black deflectors
W White deflectors
Note:
• Standard eloxal colour of the aluminium section is the original aluminium colour. Other colours
shall be specified in the order.
196
Slot diffusers
VENTILATING VALVES
Technical data Fast selection diagram
Free surface, per 1 m of length:
Aef=0.004559 m². L=2000
Air flow rate per 1 m of length:

Q=20-70 m³/hm. L=1500
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
L WA<35 dB(A)
L=1000
L WA35-45 dB(A)
L= 500
50 100 150 200 250
Q (m³/hm)
Q (m3/h)

SWIRL DIFFUSERS,
Air velocity diagrams, at different throw distances
One or two sided horizontal discharge:
H1 (m)
1 1.2 1.6 2
2.5

(m³/hm) (m³/hm)
LD-15 / 1 160 125 110 90 70 55 45 LD-15 / 1 160 125 110 90 70 55 45
SLOT DIFFUSERS,
0.8
0.6

0.4 0.5
0.4
0.3
VH1(m/s)
VL (m/s)
0.25 0.3
0.2 0.25
0.2
0.15
0.15
SUPPLY AIR NOZZLES

0.1
2 2.5 3 4 5 7 10 2 2.5 3 4 5 7 10
A (m) L (m)
Alternate sided horizontal discharge:
H1 (m)
EXTERNAL ELEMENTS
1 1.2 1.6 2
2.5
(m³/hm) (m³/hm)
LD-15 / 1 160 125 110 90 70 55 45 LD-15 / 1 160 125 110 90 70 55 45
0.7
0.5
CONTROL UNITS
0.25 0.4
AIR FLOW
0.2 0.3
0.15 0.25
VL (m/s)
0.2
VH1(m/s)
0.1
0.15
0.1
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
0.05
2 2.5 3 4 5 7 10 2 2.5 3 4 5 7 10
A (m) L (m)
197
Slot diffusers
0 00
50 10
200 00
15
55 00
100 10
50
50
) 45
(A )
( dB 40
L wa
20 35
p t ( P a)
30
25
10
20
6
15
4
3
2
1.5
10
1
10 20 30 40 50 60 80 100 150 200 250
Q (m3/hm)
ΔPt correction (in Pa) in cases of

vertical discharge
α=0˚ α=45˚ α=90˚
Q (m³/h) 100 150 200 100 150 200 100 150 200
L=500 Data in the diagram +5 +7 +10 +15 +32 +35
α
α = 0˚ Control damper in the inlet spigot is fully opened

α = 45˚ Control damper in the inlet spigot is half opened
α = 90˚ Control damper in the inlet spigot is fully closed
ΔPt correction (in Pa) in cases of

inclined discharge
α=0˚ α=45˚ α=90˚
Q (m³/h) 100 150 200 100 150 200 100 150 200
α
α = 0˚ Control damper in the inlet spigot is fully opened

198
Slot diffusers
VENTILATING VALVES
■■ Slot diffusers LD-17, LD-18
Application
Slot diffusers LD-17 and LD-18 are
designed for supply of cold or warm air in
rooms with a height between 2.5 m and 4
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
m. They allow easy setting of air deflectors
for different modes of operation and can
be mounted to ceiling or wall.
Description
LD-17 and LD-18 slot diffusers are desi-
gned in 1, 2, 3 and 4-slot versions. The

unit’s front consists of anodised alumini-
SWIRL DIFFUSERS,
um profiles (on customer’s request, these
can be powder painted in RAL 9010 or
another colour). The individually adjusta-
ble air deflectors are made of plastic in
white (RAL 9010) or black (RAL 9005)
colour). Plenum box is made of galvani-
sed sheet steel. Slot diffusers LD-17 and

LD-18 are made in standard lengths: from
SLOT DIFFUSERS,
200 up to 2000 mm with a 100 mm step
(any length available upon request).
Nominal air volume per 1 m of slot:
LD-17 – 150 m³/h
LD-18 – 200 m³/h
(Δpt = 30 Pa, NR = 35 dB)

1. Plenum box B 60
2. Inlet spigot 2
8 6 7
3. Volume control damper
4. Side section A
1 4
SUPPLY AIR NOZZLES

F
5. Cylindrical deflector
6. Intermediate section
3
7. Connecting bar 5
ØD
H2
8. Insulation (entire outside surface of

H
43
H1
the plenum box)
25 b 18
E
EXTERNAL ELEMENTS
43
LD-17 b=15
No. of slots A F E B H H1 H2
1 45.5 34.5 65 107 220 263 203.5
CONTROL UNITS
2 78.5 67.5 98 139 230 273 213.5

AIR FLOW
3 111.5 100.5 131 172 250 293 233.5

4 144.5 133.5 164 205 290 333 273.5
LD-18 b=26.5
SOUND ATTENUATORS,
SOUND ATTENUATING
No. of slots A F E B H H1 H2
1 57.0 46.0 76.5 118 233 276 216.5
LOUVRES
2 101.0 90.5 121.0 162 253 296 236.5

3 146.0 135.0 165.5 207 293 336 276.5
4 190.5 179.5 210.0 251 318 361 301.5
199
Slot diffusers
Number and diameter of inlet L 300 to 1000 1100 to1500 1600 to 2000
spigots Number Number and diameter of inlet spigots
of slots
LD-17 LD-18 LD-17 LD-18 LD-17 LD-18
1 1x98 1x123 2x98 2x123 2x123 2x138
2 1x138 1x158 2x123 2x138 2x138 2x158
3 1x158 1x198 2x138 2x158 2x158 2x198
4 1x198 1x223 2x158 2x198 2x198 2x223
Position of inlet spigots L/2 L/2

J J B 60
Number Position of inlet

Standard length
of spigots spigots
φD
H2
1 300-1000 L/2
H
H1
2 1100-1500 J=300
2 1600-2000 J=400
43
Slot diffuser face plate designs 300
Slot diffuser face plates are made of

linear or angular ended sections, which
allow the diffusers to be joined at
different angles.
300
90
°
Joining diffusers together

in length
Joining in length requires connecting pla-
tes (the total length of combined diffusers
is not limited).
End seals
End seals are components of the diffuser
face plate. They are available in two
designs:
• as an angle piece (E – on both ends,
ET – on one end only) or
• plates (F – on both ends, FT – on one
end only).
The connecting strip-section has no end
anglepieces or plates seals (designation T).
200
Slot diffusers
VENTILATING VALVES
Fixing of the plenum box onto
LD-17, LD-18 diffusers
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
Fixing with self-tapping screws (U) Fixing with spring clamps (S) Fixing with a cross-member (Z)

SWIRL DIFFUSERS,
SLOT DIFFUSERS,
Installation with hangers (P) Installation with a cross member without plenum box (N)

Types of air discharges
SUPPLY AIR NOZZLES

Vertical – heating Horizontal – cooling
EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
Different settings of the two slot model (similar combinations are possible also for diffusers with more slots).
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
201
Slot diffusers
Ordering key
LD-17/1/B/E/K/M/S/P I5 L=1000 (length L=200, 300, …, 2000)

I9 Sound and thermal insulation (from -40 °C to 105 °C), 9 mm thick, on the outside of the plenum box
(synthetic rubber based material)
N Diffuser installation with a cross-member without plenum box

S Fixing of the diffuser to the plenum box with spring clamps
K Plenum box

F End plate on both end
B Black deflectors
W White deflectors
1 Number of slots
2
3
4
LD-17 Slot diffuser type

LD-18
Note:
Quick selection diagram: LWA < 35 dB(A)
LD-18
4
LD-17
3
of slots
število
Nr. rež
100 300 500 1000
Q (m3/hm)
202
Slot diffusers
VENTILATING VALVES
Sound power level, pressure drop and throw distances
LD-17 horizontal discharge
[l/s] 13.9 27.8 41.7 55.6 83.3 111.1 138.9 166.7 194.4 222.2 250.0 277.8 333.3
Type Q
[m³/h) 50 100 150 200 300 400 500 600 700 800 900 1000 1200
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
LWA [dB (A)] 32 47
Δpt [Pa] 13 42
LD-17/1 L=500 mm
L0.2 [m] 5.6 6.6
Lmin [m] 12.5 >15
LWA [dB (A)] 27 35 43 50
Δpt [Pa] 8 27 56 95

LD-17/1 L=1000 mm
L0.2 [m] 6 6.5 6.7 6.8
SWIRL DIFFUSERS,
Lmin [m] 12 >15 >15 >15
LWA [dB (A)] <25 29 34 40 50
Δpt [Pa] 5 16 32 52 99
LD-17/1 L=1500 mm
L0.2 [m] 5.5 6.1 6.5 6.6 6.8
Lmin [m] 4 12.5 >15 >15 >15

LWA [dB (A)] <25 32 36 43 49
SLOT DIFFUSERS,
Δpt [Pa] 2 3 6 11 19
LD-17/1 L=2000 mm
L0.2 [m] 5.8 6.1 6.5 6.7 6.8
Lmin [m] 6.5 12.5 13 >15 >15
LWA [dB (A)] <25 34 42 50
Δpt [Pa] 3 11 22 36
LD-17/2 L=500 mm

L0.2 [m] 5 5.4 5.7 5.8
Lmin [m] 11.5 14 >15 >15
LWA [dB (A)] 27 30 36 45 50
Δpt [Pa] 7 14 22 48 80
LD-17/2 L=1000 mm
L0.2 [m] 5.3 5.4 5.5 5.7 5.8
Lmin [m] 8 13.2 13.4 >15 >15
LWA [dB (A)] 26 30 36 42 46 52
SUPPLY AIR NOZZLES

Δpt [Pa] 8 13 28 44 65 84
LD-17/2 L=1500 mm
L0.2 [m] 5.1 5.4 5.5 5.6 5.8 5.8
Lmin [m] 5.7 13.3 13.5 >15 >15 >15
LWA [dB (A)] 26 32 36 41 44 48 51
Δpt [Pa] 2 4 7 10 13 18 22
LD-17/2 L=2000 mm
L0.2 [m] 5.2 5.4 5.5 5.6 5.7 5.7 5.8
EXTERNAL ELEMENTS
Lmin [m] 7.5 13.2 13.4 >15 >15 >15 >15
LWA [dB (A)] 30 37 45 54
Δpt [Pa] 5 12 20 50
LD-17/3 L=500 mm
L0.2 [m] 8 8.5 8.7 9
Lmin [m] 9 10.5 11.2 13.5
LWA [dB (A)] <25 29 34 42 50
Δpt [Pa] 3 8 14 32 54
CONTROL UNITS
LD-17/3 L=1000 mm
AIR FLOW
L0.2 [m] 7.7 7.9 8 8.5 8.8

Lmin [m] 6.4 6.9 9 11 12
LWA [dB (A)] 28 35 42 48 53
Δpt [Pa] 8 19 34 52 79
LD-17/3 L=1500 mm
L0.2 [m] 7.8 8.2 8.5 8.7 8.7
SOUND ATTENUATORS,
SOUND ATTENUATING
Lmin [m] 7.5 9.5 10.8 11.7 12.3

LWA [dB (A)] 31 36 41 46 50 54
LOUVRES
Δpt [Pa] 2 4 6 8 12 17
LD-17/3 L=2000 mm
L0.2 [m] 7.9 8.1 8.4 8.5 8.6 9
Lmin [m] 7.7 9.6 10.5 11 11.9 12
203
Slot diffusers
[l/s] 13.9 27.8 41.7 55.6 83.3 111.1 138.9 166.7 194.4 222.2 250.0 277.8 333.3
Type Q
[m³/h) 50 100 150 200 300 400 500 600 700 800 900 1000 1200
LWA [dB (A)] 25 32 40 51 55
Δpt [Pa] 3 7 12 29 50
LD-17/4 L=500 mm
L0.2 [m] 7.2 7.5 7.6 8 8.1
Lmin [m] 8.2 9 9.5 10.5 11.2
LWA [dB (A)] 35 38 46 53 60
Δpt [Pa] 9 21 38 56 90
LD-17/4 L=1000 mm
L0.2 [m] 7.5 7.6 7.7 7.9 8
Lmin [m] 8.3 9 9.5 10.5 10.5
LWA [dB (A)] 32 38 44 48 52 60
Δpt [Pa] 10 19 30 44 60 80
LD-17/4 L=1500 mm
L0.2 [m] 7.2 7.5 7.6 7.8 7.9 8
Lmin [m] 7.5 8.7 9.5 9.8 10.2 10.4
LWA [dB (A)] 34 38 42 45 49 52 56 60
Δpt [Pa] 3 5 7 9 12 17 23 33
LD-17/4 L=2000 mm
L0.2 [m] 7.4 7.5 7.6 7.8 7.8 7.8 7.9 8.3
Lmin [m] 8.2 8.6 9.2 9.5 9.7 10.2 10.5 11.3
Definition of symbols Conditions for Lmin:

LWA A-weighted sound power level Q=600 m³/h
Dpt Total pressure drop calculated to normal conditions L=1000 mm
L0.2 Isothermal throw distance of supply air jet, when its velocity drops down to 0.2 m/s Room height: H=2.8 m
Lmin Minimum distance between diffusers, that the jet velocity is less than or equal to 0.2 m/s Occupied zone height: 1.8 m
Room temperature: 24 °C
Supply temperature: DT= -6 K
LD-17 vertical discharge
[l/s] 13.9 27.8 41.7 55.6 83.3 111.1 138.9 166.7 194.4 222.2 250.0 277.8 333.3
Type Q
[m³/h) 50 100 150 200 300 400 500 600 700 800 900 1000 1200
LWA [dB (A)] 32 47
LD-17/1 L=500 mm Δpt [Pa] 17 68
L0.2 (+10K) [m] 2.4 4.8
LWA [dB (A)] 27 35 43 50
LD-17/1 L=1000 mm Δpt [Pa] 4 17 39 68
L0.2 (+10K) [m] 1 2.4 3.5 5
LWA [dB (A)] <25 29 34 40 50
LD-17/1 L=1500 mm Δpt [Pa] 2 8 17 30 68
L0.2 (+10K) [m] 0.9 1.5 2.3 3.3 4.7
LWA [dB (A)] <25 32 36 43 49
LD-17/1 L=2000 mm Δpt [Pa] 4 10 17 39 68
L0.2 (+10K) [m] 0.8 1.8 2.4 3.8 4.8
LWA [dB (A)] 25 35 43 51
LD-17/2 L=500 mm Δpt [Pa] 4 17 39 68
L0.2 (+10K) [m] 1.6 3 4 4.5
LWA [dB (A)] 28 31 37 46 51
LD-17/2 L=1000 mm Δpt [Pa] 4 10 17 39 68
L0.2 (+10K) [m] 1.6 2.6 3 4.2 4.5
204
Slot diffusers
VENTILATING VALVES
[l/s] 13.9 27.8 41.7 55.6 83.3 111.1 138.9 166.7 194.4 222.2 250.0 277.8 333.3
Type Q
[m³/h) 50 100 150 200 300 400 500 600 700 800 900 1000 1200
LWA [dB (A)] 26 30 36 42 46 52
LD-17/2 L=1500 mm Δpt [Pa] 4 8 17 30 48 68
L0.2 (+10K) [m] 1.6 2.5 3.2 3.6 4 4.5
CIRCULAR DIFFUSERS,
LWA [dB (A)] 26 32 36 41 44 48 51
SQUARE DIFFUSERS
LD-17/2 L=2000 mm Δpt [Pa] 4 10 17 27 39 52 68
L0.2 (+10K) [m] 1.8 2.5 3.1 3.5 3.8 4.3 4.5
LWA [dB (A)] 31 38 46 55
LD-17/3 L=500 mm Δpt [Pa] 8 17 30 68
L0.2 (+10K) [m] 3.1 4.2 5.5 7.5
LWA [dB (A)] 31 36 44 52

LD-17/3 L=1000 mm Δpt [Pa] 4 8 17 30
SWIRL DIFFUSERS,
L0.2 (+10K) [m] 1.9 3.1 4.2 5.5
LWA [dB (A)] 30 37 44 50 55
LD-17/3 L=1500 mm Δpt [Pa] 3 8 14 21 30
L0.2 (+10K) [m] 1.5 2.9 3.8 4.8 5.5
LWA [dB (A)] 32 37 42 47 51 55

LD-17/3 L=2000 mm Δpt [Pa] 4 8 12 17 23 30
SLOT DIFFUSERS,
L0.2 (+10K) [m] 1.9 3.1 3.8 4.3 5 5.5
LWA [dB (A)] 27 34 42 53 57
LD-17/4 L=500 mm Δpt [Pa] 4 10 17 39 68
L0.2 (+10K) [m] 3.1 4.3 5.2 6.8 7.7
LWA [dB (A)] 36 39 47 54 61
LD-17/4 L=1000 mm Δpt [Pa] 4 10 17 27 39

L0.2 (+10K) [m] 3 4.4 5.2 6.1 6.7
LWA [dB (A)] 33 39 45 49 53 61
LD-17/4 L=1500 mm Δpt [Pa] 4 8 12 17 23 30
L0.2 (+10K) [m] 2.9 4.1 4.8 5.2 5.8 6.2
LWA [dB (A)] 35 39 43 46 50 53 57 61
LD-17/4 L=2000 mm Δpt [Pa] 4 7 10 13 17 22 27 39
L0.2 (+10K) [m] 3.1 4 4.3 4.8 5.3 5.8 6.1 6.8
SUPPLY AIR NOZZLES

Definition of symbols
LWA A-weighted sound power level
Dpt Total pressure drop calculated to normal conditions
L0.2 (+10 °C) Isothermal throw distance of supply air jet with temperature +10K,
EXTERNAL ELEMENTS
when its velocity drops down to 0.2 m/s
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
205
Slot diffusers
LD-18 horizontal discharge
[l/s] 27.8 41.7 55.6 83.3 111.1 138.9 166.7 194.4 222.2 250.0 277.8 333.3 388.9
Type Q
[m³/h) 100 150 200 300 400 500 600 700 800 900 1000 1200 1400
LWA [dB (A)] 41 51
Δpt [Pa] 24 53
LD-18/1 L=500 mm
L0.2 [m] 6.6 6.9
Lmin [m] >15 >15
LWA [dB (A)] 29 37 44
Δpt [Pa] 16 36 64
LD-18/1 L=1000 mm
L0.2 [m] 6.2 6.5 6.7
Lmin [m] 12.8 >15 >15
LWA [dB (A)] 25 31 36 46
Δpt [Pa] 9 19 34 77
LD-18/1 L=1500 mm
L0.2 [m] 5.8 6.2 6.4 6.6
Lmin [m] 4.2 12.8 >15 >15
LWA [dB (A)] <25 28 32 40 47 53 58 62
Δpt [Pa] 1 2 4 9 15 24 35 47
LD-18/1 L=2000 mm
L0.2 [m] 5.2 5.9 6.2 6.5 6.7 6.8 6.9 6.9
Lmin [m] 2 6.6 12.8 >15 >15 >15 >15 >15
LWA [dB (A)] 29 37 45 56
Δpt [Pa] 6 13 24 53
LD-18/2 L=500 mm
L0.2 [m] 5.4 5.6 5.7 5.8
Lmin [m] 14 >15 >15 >15
LWA [dB (A)] <25 27 32 40 48
Δpt [Pa] 4 9 16 37 65
LD-18/2 L=1000 mm
L0.2 [m] 5 5.3 5.5 5.6 5.7
Lmin [m] 2 8 13.4 >15 >15
LWA [dB (A)] <25 27 34 40 45 50
Δpt [Pa] 5 9 20 35 55 80
LD-18/2 L=1500 mm
L0.2 [m] 5 5.2 5.4 5.6 5.7 5.7
Lmin [m] 2 5.8 13.4 >15 >15 >15
LWA [dB (A)] 25 30 35 39 44 47 51 54 57 62 67
Δpt [Pa] 1 3 6 9 13 18 23 29 36 52 71
LD-18/2 L=2000 mm
L0.2 [m] 5 5.3 5.4 5.5 5.6 5.7 5.7 5.7 5.8 5.8 5.8
Lmin [m] 2 8 13.4 >15 >15 >15 >15 >15 >15 >15 >15
LWA [dB (A)] <25 31 37 48 56 63
Δpt [Pa] 3 6 11 24 42 66
LD-18/3 L=500 mm
L0.2 [m] 8 8.3 8.6 8.8 9 9.1
Lmin [m] 8 10 11.2 12.6 13.4 13.8
LWA [dB (A)] <25 27 34 40 46 51 55
Δpt [Pa] 4 7 16 29 45 65 88
LD-18/3 L=1000 mm
L0.2 [m] 7.7 8 8.3 8.6 8.7 8.8 8.9
Lmin [m] 6.4 8 10 11.2 12 12.6 13
LWA [dB (A)] <25 29 34 38 42 46 50 53 56
Δpt [Pa] 4 9 15 24 34 47 61 77 96
LD-18/3 L=1500 mm
L0.2 [m] 7.6 8 8.2 8.4 8.6 8.7 8.7 8.8 8.9
Lmin [m] 5.8 8.2 9.6 10.6 11.2 11.8 12.2 12.6 12.8
LWA [dB (A)] 26 30 34 37 40 44 46 49 54 58
Δpt [Pa] 1 2 3 4 6 8 10 12 17 23
LD-18/3 L=2000 mm
L0.2 [m] 7.7 8 8.2 8.4 8.5 8.6 8.6 8.7 8.8 8.9
Lmin [m] 6.4 8 9.2 10 10.8 11.2 11.8 12 12.6 13
206
Slot diffusers
VENTILATING VALVES
[l/s] 27.8 41.7 55.6 83.3 111.1 138.9 166.7 194.4 222.2 250.0 277.8 333.3 388.9
Type Q
[m³/h) 100 150 200 300 400 500 600 700 800 900 1000 1200 1400
CIRCULAR DIFFUSERS,
LWA [dB (A)] 28 34 44 52 58 64 68
SQUARE DIFFUSERS
Δpt [Pa] 3 6 13 24 37 53 72
LD-18/4 L=500 mm
L0.2 [m] 7.4 7.6 7.8 8 8.1 8.2 8.3
Lmin [m] 8.2 9 10.2 10.6 11 11.2 11.4
LWA [dB (A)] <25 31 37 42 47 51 55 58
Δpt [Pa] 4 9 16 26 37 50 65 83
LD-18/4 L=1000 mm

L0.2 [m] 7 7.4 7.6 7.7 7.8 7.9 8 8
SWIRL DIFFUSERS,
Lmin [m] 6.2 8.2 9 9.6 10.2 10.4 10.6 10.8
LWA [dB (A)] 26 31 35 38 42 45 48 51 56
Δpt [Pa] 5 9 14 20 28 36 46 57 82
LD-18/4 L=1500 mm
L0.2 [m] 7 7.3 7.4 7.6 7.7 7.8 7.8 7.9 8
Lmin [m] 6.2 7.6 8.4 9 9.6 9.8 10 10.4 10.6

LWA [dB (A)] 28 31 34 37 40 42 45 50 54
SLOT DIFFUSERS,
Δpt [Pa] 2 3 4 6 7 9 11 16 22
LD-18/4 L=2000 mm
L0.2 [m] 7 7.2 7.4 7.5 7.6 7.7 7.7 7.8 7.9
Lmin [m] 6.2 7.4 8.2 8.6 9.2 9.4 9.8 10.2 10.4

LWA A-weighted sound power level Q=600 m³/h
Dpt Total pressure drop calculated to normal conditions L=1000 mm
L0.2 Isothermal throw distance of supply air jet, when its velocity Room height: H=2.8 m
drops down to 0.2 m/s Occupied zone height: 1.8 m
Lmin Minimum distance between diffusers, that the jet velocity is Room temperature: 24 °C
less than or equal to 0.2 m/s Supply temperature: DT= -6 K
SUPPLY AIR NOZZLES

EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
207
Slot diffusers
LD-18 vertical discharge
[l/s] 27.8 41.7 55.6 83.3 111.1 138.9 166.7 194.4 222.2 250.0 277.8 333.3 388.9
Type Q
[m³/h) 100 150 200 300 400 500 600 700 800 900 1000 1200 1400
LWA [dB (A)] 40 51
LD-18/1 L=500 mm Δpt [Pa] 25 56
L0.2 (+10K) [m] 3.4 5.1
LWA [dB (A)] 29 36 43
LD-18/1 L=1000 mm Δpt [Pa] 17 39 69
L0.2 (+10K) [m] 1.5 2.5 3.4
LWA [dB (A)] 25 31 36 45
LD-18/1 L=1500 mm Δpt [Pa] 10 21 38 86
L0.2 (+10K) [m] 0.7 1.5 2.2 3.5
LWA [dB (A)] 28 32 39 46 52 57
LD-18/1 L=2000 mm Δpt [Pa] 4 7 17 30 47 67
L0.2 (+10K) [m] 0.9 2 2.5 3.5 4.4 5.2
LWA [dB (A)] 29 37 44 55
LD-18/2 L=500 mm Δpt [Pa] 6 14 25 56
L0.2 (+10K) [m] 2.4 3.2 3.8 4.6
LWA [dB (A)] <25 27 32 40 47
LD-18/2 L=1000 mm Δpt [Pa] 4 10 17 39 69
L0.2 (+10K) [m] 1 1.9 2.4 3.2 3.8
LWA [dB (A)] <25 27 33 39 44 49
LD-18/2 L=1500 mm Δpt [Pa] 6 10 22 39 61 88
L0.2 (+10K) [m] 1.1 1.7 2.4 3 3.4 3.8
LWA [dB (A)] 25 30 35 39 43 47 50 53 56 61
LD-18/2 L=2000 mm Δpt [Pa] 2 5 9 15 21 29 38 48 59 85
L0.2 (+10K) [m] 1 1.9 2.4 2.9 3.2 3.5 3.8 4 4.3 4.6
LWA [dB (A)] 23 30 36 46 54 60
LD-18/3 L=500 mm Δpt [Pa] 3 6 11 25 44 69
L0.2 (+10K) [m] 1.9 3.1 4 5.7 7.1 8.2
LWA [dB (A)] <25 26 33 39 44 49 53
LD-18/3 L=1000 mm Δpt [Pa] 4 8 17 31 49 70 95
L0.2 (+10K) [m] 1.3 1.9 3.1 4 5 5.8 6.5
LWA [dB (A)] 23 28 33 37 41 45 48 51
LD-18/3 L=1500 mm Δpt [Pa] 5 10 18 28 41 56 73 92
L0.2 (+10K) [m] 1 1.9 2.7 3.4 4 4.7 5.2 5.8
LWA [dB (A)] 26 29 33 36 39 42 45 47 52 56
LD-18/3 L=2000 mm Δpt [Pa] 3 5 8 12 16 21 27 34 48 66
L0.2 (+10K) [m] 1.3 1.9 2.5 3.1 3.6 4 4.5 5 5.8 6.5
LWA [dB (A)] 21 27 33 42 50 56 61
LD-18/4 L=500 mm Δpt [Pa] 2 3 6 14 25 39 56
L0.2 (+10K) [m] 2.1 3.3 4.1 5.4 6.4 7.2 7.9
LWA A-weighted sound power level
Dpt Total pressure drop calculated to normal conditions
L0.2 (+10 °C) Isothermal throw distance of supply air jet with temperature
+10K, when its velocity drops down to 0.2 m/s
208
Slot diffusers
VENTILATING VALVES
[l/s] 27.8 41.7 55.6 83.3 111.1 138.9 166.7 194.4 222.2 250.0 277.8 333.3 388.9
Type Q
[m³/h) 100 150 200 300 400 500 600 700 800 900 1000 1200 1400
LWA [dB (A)] <25 30 36 41 45 49 53 56
LD-18/4 L=1000 mm Δpt [Pa] 4 10 18 27 39 54 70 89
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
L0.2 (+10K) [m] 2.1 3.3 4.1 4.8 5.4 6 6.5 6.9
LWA [dB (A)] 26 30 34 37 41 44 47 50 54
LD-18/4 L=1500 mm Δpt [Pa] 6 10 16 23 32 41 52 65 93
L0.2 (+10K) [m] 2.1 2.9 3.6 4.1 4.6 5 5.5 5.8 6.5
LWA [dB (A)] 27 30 33 36 39 41 44 48 52
LD-18/4 L=2000 mm Δpt [Pa] 3 5 7 10 13 16 20 29 39
L0.2 (+10K) [m] 2.1 2.8 3.3 3.8 4.2 4.5 4.8 5.5 6

SWIRL DIFFUSERS,
Pressure drop

(valid for horizontal discharge and plenum box with 100 % opened volume control damper)
SLOT DIFFUSERS,
LD-17/1 LD-17/2
L=500 mm 1000 1500 L=500 mm 1000
200 200 1500
100 100

50 2000 50
40 40
30 30
2000
20 20
50 50
45 45
10 10
Δpt (Pa)
Δpt (Pa)
40 40
))
5 (A 5 35 ))
35 (dB (A
LWA
(dB
SUPPLY AIR NOZZLES

30 L WA
30
2 2
3 3
Q (m /h) Q (m /h)
50 100 150 200 300 500 700 50 100 150 200 300 500 700 900
LD-17/3 LD-17/4
L=500 mm 1000 L=500 mm 1000 EXTERNAL ELEMENTS
200 200
1500
100 100 1500
50 50
40 40
30 30
20 2000 20
2000
CONTROL UNITS
AIR FLOW
50 50
10
Δpt (Pa)
10
Δpt (Pa)
45
45
5 5 40
40
))
(A
35
( A)
) 35 (dB
(dB L WA
2 2
30 L WA 30
SOUND ATTENUATORS,
SOUND ATTENUATING
3 3
Q (m /h) Q (m /h)
100 150 200 300 500 700 900 100 150 200 300 500 700 900
LOUVRES
209
Slot diffusers
Correction factors
LD-17/1 Type of discharge Horizontal Vertical LD-17/2 Type of discharge Horizontal Vertical
Volume control Volume control
Length Open Closed Open Closed Length Open Closed Open Closed
damper damper
∆pt x1 x 1.1 x 1.1 x 1.5 ∆pt x1 x2 x 1.0 x 2.2
L=500 L=500
LWA - +1 - +2 LWA - +4 +1 +2
∆pt x1 x 1.2 x 1.2 x 1.5 ∆pt x1 x 2.3 x 1.2 x 2.2
L=1000 L=1000
LWA - +2 - +1 LWA - +4 +1 +2
∆pt x1 x 1.3 x 1.2 x 1.6 ∆pt x1 x 2.3 x 1.2 x 2.3
L=1500 L=1500
LWA - +2 - +1 LWA - +3 - +1
∆pt x1 x 2.9 x 2.0 x 2.7 ∆pt x1 x3 x 1.6 x 3.4
L=2000 L=2000
LWA - +2 - - LWA - +3 - +1
damper damper
∆pt x1 x 2.5 x 1.1 x 2.4 ∆pt x1 x 2.2 x 1.2 x 2.4
L=500 L=500
LWA - +5 +1 +4 LWA - +6 +2 +3
∆pt x1 x 2.6 x 1.2 x 2.5 ∆pt x1 x 2.4 x 1.2 x 2.4
L=1000 L=1000
LWA - +6 +2 +4 LWA - +5 +1 +3
∆pt x1 x 2.7 x 1.2 x 2.8 ∆pt x1 x 2.7 x 1.2 x 2.7
L=1500 L=1500
LWA - +6 +2 +3 LWA - +6 +1 +2
∆pt x1 x 3.2 x 2.5 x6 ∆pt x1 x5 x 1.9 x 4.3
L=2000 L=2000
LWA - +5 +1 +2 LWA - +6 +1 +2
210
Slot diffusers
VENTILATING VALVES
Pressure drop
(valid for horizontal discharge and plenum box with 100 % opened volume control damper)
LD-18/1 LD-18/2
L=500 mm 1000 1500 L=500 mm 1000 1500
200 200
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
100 2000 100
50 50
40 40
2000
30 30
20 20
50 50

45 45
10 10
Δpt (Pa)
Δpt (Pa)
SWIRL DIFFUSERS,
40 40
)
( A)
5 (dB 5 35 ))
35 LW A (A
A
(dB
30 LW
30
2 2
3 3
Q (m /h) Q (m /h)
100 150 200 300 500 700 1000 100 150 200 300 500 700 1000

SLOT DIFFUSERS,
LD-18/3 LD-18/4
L=500 mm 1000 L=500 mm 1000
200 200
1500
1500

100 100
50 50
40 40
30 30
20 20
2000 2000
50 50
10 10
Δpt (Pa)
Δpt (Pa)
45
45
SUPPLY AIR NOZZLES

5 40 5 40
))
(A
(dB
35 35
) )
(A L WA
2 (dB 2
30 L WA 30
3 3
Q (m /h) Q (m /h)
100 150 200 300 500 700 1000 1200 100 150 200 300 500 700 1000 1400
EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
211
Slot diffusers
Correction factors
damper damper
∆pt x1 x1 x1 x 1.4 ∆pt x1 x 2.1 x1 x 2.1
L=500 L=500
LWA - +1 - - LWA - +3 - +1
∆pt x1 x 1.1 x 1.1 x 1.4 ∆pt x1 x 2.2 x 1.1 x 2.1
L=1000 L=1000
LWA - +1 - - LWA - +3 - +1
∆pt x1 x 1.2 x 1.1 x 1.5 ∆pt x1 x 2.2 x 1.1 x 2.2
L=1500 L=1500
LWA - +1 - - LWA - +3 - +1
∆pt x1 x 2.8 x 1.9 x 2.6 ∆pt x1 x3 x 1.6 x 3.3
L=2000 L=2000
LWA - +1 - - LWA - +3 - +1
damper damper
∆pt x1 x 2.5 x 1.0 x 2.4 ∆pt x1 x 2.2 x1 x 2.4
L=500 L=500
LWA - +6 - +3 LWA - +5 +1 +2
∆pt x1 x 2.5 x 1.1 x 2.5 ∆pt x1 x 2.3 x 1.1 x 2.5
L=1000 L=1000
LWA - +6 - +3 LWA - +5 - +2
∆pt x1 x 2.5 x 1.2 x 2.7 ∆pt x1 x 2.6 x 1.1 x 2.6
L=1500 L=1500
LWA - +6 - +2 LWA - +5 - +2
∆pt x1 x 3.1 x 2.8 x 6.5 ∆pt x1 x5 x 1.8 x 4.3
L=2000 L=2000
LWA - +6 - +3 LWA - +4 - +2
212
Slot diffusers
VENTILATING VALVES
■■ Nozzle diffuser LD-19
Application
Nozzle diffuser LD-19 is designed for
supply of warm or cold air and can be
mounted in the wall or in the ceiling.
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
Adjustable deflectors allow us to set
different directions of air discharge.
Description
Front plate is made of sheet steel and
powder painted in white (RAL 9010) or any
other RAL colour (on customer’s request).

Individually adjustable nozzles are made
SWIRL DIFFUSERS,
of plastics in white (RAL 9010) or black
125
H1
85
A
(RAL 9005) colour.
Plenum box is made of sheet steel. Nozzle L1 L1 8
diffusers are made in standard lenghts L
(one section) from 600 up to 2000 mm
with 100 mm step.

SLOT DIFFUSERS,
L/2
J 60 B
2 7 1. Plenum box
2. Spigot
3 1
3. Volume control damper (M)
4. Nozzle
φD

6 5. Cross bar
H
5 6. Fixing screw
125
H1
85
A
A
7. Insulation (entire outside surface
of the plenum box)
L1 L1 8
32
L
4
A
SUPPLY AIR NOZZLES

Dimensions
L 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000
L1 552 652 752 852 476 526 576 626 676 726 776 826 876 926 976
No. of 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40
nozzles*
EXTERNAL ELEMENTS
*
Up to length L=900mm: fixing with 4 screws. Other sizes: fixing with 6 screws.
No. of rows A H1 B H
1 85 65 117 216.5
2 125 105 162 236.5
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
213
Slot diffusers
Number and dimensions of L 600 – 1000 1100 – 1500 1600 – 2000

spigots No. of Number and dimensions of spigots fD
rows
1 1x123 2x123 2x138
2 1x158 2x138 2x158
Position of inlet spigots

L/2 L/2
J J 60 B
No. of inlet Standard Position of inlet

spigots length spigots
φD
1 600-1000 L/2
2 1100-1500 J=300
2 1600-2000 J=400 A
Front plate installation
With screws (V)
Installation with a cross-member (Z)

Installation on a cross bar can be made Installation of a plenum box with
through the hole, in which is mounted a suspension bracket (P)
nozzle.
Types of air discharge
Possible angle settings

Cooling
Heating
Nastavitve kota šobe Hlajenje Gretje

Nastavitve kota šobe Hlajenje Gretje
214
Slot diffusers
VENTILATING VALVES
Ordering key
LD-19/1/B/K/M/Z/P/I5 L=1000 (length L=600, 700, …, 2000)
I5 T hermal insulation (polyethylene), 5 mm thick, on the outside of the plenum box
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS

V Visible installation (front plate without plenum box)
SWIRL DIFFUSERS,
K Plenum box
B Black deflectors

W White deflectors
SLOT DIFFUSERS,
1 Number of rows with nozzles
2
LD-19 Nozzle diffuser

Note:
Standard colour is RAL 9010. Other colours on customer’s request.
SUPPLY AIR NOZZLES

EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
215
Slot diffusers
Quick selection
Horizontal discharge DT= 0K

Type Q (l/s) 13.9 27.8 41.7 55.6 69.4 83.3 111.1
(m³/h) 50 100 150 200 250 300 400
LWA (dB(A)) 27 40 46.8 / / / /
∆pt (Pa) 12.8 47 101.2 / / / /
LD-19/1 L=600 mm
L0.2 (m) 2.7 3.5 4.1 / / / /
Lmin (m) 4.3 5.9 7.1 / / / /
LWA (dB(A)) 21.4 33.7 40.8 44.8 / / /
∆pt (Pa) 5 17.7 37.7 64.6 / / /
LD-19/1 L=1000 mm
L0.2 (m) 2.2 2.8 3.6 4.4 / / /
Lmin (m) 3.2 4.4 6.0 7.6 / / /
LWA (dB(A)) 16.4 27.4 34.8 39.7 43.1 / /
∆pt (Pa) 2.3 7.9 16.9 28.9 43.8 / /
LD-19/1 L=1500 mm
L0.2 (m) 2 2.5 2.8 3.3 3.9 / /
Lmin (m) 2.7 3.7 4.4 5.4 6.6 / /
LWA (dB(A)) 13.1 22.8 30 35.2 39.1 41.9 45.5
∆pt (Pa) 1.4 4.6 9.7 16.5 25 35.2 60.4
LD-19/1 L=2000 mm
L0.2 (m) 1.9 2.2 2.6 2.9 3.2 3.6 3.9
Lmin (m) 2.5 3.1 3.9 4.5 5.1 5.9 6.6
LWA (dB(A)) 19.1 30.9 38.2 / / / /
∆pt (Pa) 3.4 12.2 26 / / / /
LD-19/2 L=600 mm
L0.2 (m) 3.2 4.6 6.8 / / / /
Lmin (m) 5.4 8.2 12.6 / / / /
LWA (dB(A)) 13.1 22.8 30 35.2 / / /
∆pt (Pa) 1.5 4.9 10.1 17.1 / / /
LD-19/2 L=1000 mm
L0.2 (m) 2.7 3.5 4.3 5.4 / / /
Lmin (m) 4.3 5.9 7.6 9.8 / / /
LWA (dB(A)) 10.3 18.4 24.9 30.1 34.2 / /
∆pt (Pa) 0.7 2.4 4.8 7.9 11.9 / /
LD-19/2 L=1500 mm
L0.2 (m) 2.4 3 3.4 4.2 4.8 / /
Lmin (m) 3.7 4.9 5.7 7.3 8.5 / /
LWA (dB(A)) 9.1 16.6 22.8 27.8 31.9 35.3 40.3
∆pt (Pa) 0.5 1.4 2.8 4.7 6.9 9.6 16.2
LD-19/2 L=2000 mm
L0.2 (m) 2.4 2.8 3.1 3.6 4 4.4 5.6
Lmin (m) 3.6 4.4 5.1 6.1 6.9 7.7 10.1

LWA (dB(A)) Sound power level Room height: H=2.8 m
Dpt (Pa) Total pressure drop Occupied zone height: 1.8 m
L0.2 (m) Isothermal throw length of supply air jet, when its speed drops down to 0.2 m/s Room temperature: 24 °C
Lmin (m) Minimum distance between diffusers, that the jet velocity is less than or equal to 0.2 m/s Supply temperature by cooling: ΔT= - 6 K
L02 (m) L02 (m) L02 (m) L02 (m)
216
Slot diffusers
VENTILATING VALVES
Vertical discharge DT= 0K

Type Q (l/s) 13.9 27.8 41.7 55.6 69.4 83.3 111.1
(m³/h) 50 100 150 200 250 300 400
LWA (dB(A)) 19.1 30.9 38.2 / / / /
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
LD-19/2 L=600 mm ∆pt (Pa) 3.4 12.2 26 / / / /
L0.2 (m) 1.8 2.6 3.9 / / / /
LWA (dB(A)) 13.1 22.8 30 35.2 / / /
LD-19/2 L=1000 mm ∆pt (Pa) 1.5 4.9 10.1 17.1 / / /
L0.2 (m) 1.6 2.0 2.3 2.8 / / /
LWA (dB(A)) 10.3 18.4 24.9 30.1 34.2 / /
LD-19/2 L=1500 mm ∆pt (Pa) 0.7 2.4 4.8 7.9 11.9 / /

L0.2 (m) 1.4 1.7 1.9 2.4 2.7 / /
SWIRL DIFFUSERS,
LWA (dB(A)) 9.1 16.6 22.8 27.8 31.9 35.3 40.3
LD-19/2 L=2000 mm ∆pt (Pa) 0.5 1.4 2.8 4.7 6.9 9.6 16.2
L0.2 (m) 1.3 1.6 1.8 2.1 2.3 2.5 3.2
Vertical discharge DT= +5K

Type Q (l/s) 13.89 27.78 41.67 55.56 69.44 83.33 111.11

SLOT DIFFUSERS,
(m³/h) 50.00 100.00 150.00 200.00 250.00 300.00 400.00
LWA (dB(A)) 19.1 30.9 38.2 / / / /
LD-19/2 L=600 mm ∆pt (Pa) 3.4 12.2 26 / / / /
L0.2 (m) 1.20 1.72 2.55 / / / /
LWA (dB(A)) 13.1 22.8 30 35.2 / / /
LD-19/2 L=1000 mm ∆pt (Pa) 1.5 4.9 10.1 17.1 / / /
L0.2 (m) 1.16 1.45 1.64 2.03 / / /

LWA (dB(A)) 10.3 18.4 24.9 30.1 34.2 / /
LD-19/2 L=1500 mm ∆pt (Pa) 0.7 2.4 4.8 7.9 11.9 / /
L0.2 (m) 1.07 1.33 1.51 1.87 2.14 / /
LWA (dB(A)) 9.1 16.6 22.8 27.8 31.9 35.3 40.3
LD-19/2 L=2000 mm ∆pt (Pa) 0.5 1.4 2.8 4.7 6.9 9.6 16.2
L0.2 (m) 1.03 1.26 1.40 1.62 1.80 1.98 2.52
SUPPLY AIR NOZZLES

Vertical discharge DT= +10K
Type Q (l/s) 13.89 27.78 41.67 55.56 69.44 83.33 111.11
(m³/h) 50.00 100.00 150.00 200.00 250.00 300.00 400.00
LWA (dB(A)) 19.1 30.9 38.2 / / / /
LD-19/2 L=600 mm ∆pt (Pa) 3.4 12.2 26 / / / /
L0.2 (m) 0.85 1.22 1.81 / / / /
LWA (dB(A)) 13.1 22.8 30 35.2 / / /
LD-19/2 L=1000 mm ∆pt (Pa) 1.5 4.9 10.1 17.1 / / / EXTERNAL ELEMENTS
L0.2 (m) 0.86 1.07 1.22 1.50 / / /
LWA (dB(A)) 10.3 18.4 24.9 30.1 34.2 / /
LD-19/2 L=1500 mm ∆pt (Pa) 0.7 2.4 4.8 7.9 11.9 / /
L0.2 (m) 0.74 0.92 1.04 1.29 1.47 / /
LWA (dB(A)) 9.1 16.6 22.8 27.8 31.9 35.3 40.3
LD-19/2 L=2000 mm ∆pt (Pa) 0.5 1.4 2.8 4.7 6.9 9.6 16.2
L0.2 (m) 0.69 0.85 0.94 1.09 1.21 1.33 1.69
CONTROL UNITS
AIR FLOW
Definitions of symbols
Dpt (Pa) Total pressure drop
SOUND ATTENUATORS,
SOUND ATTENUATING
L0.2 (m) Isothermal throw length of supply air jet, when its speed drops down to 0.2 m/s
LOUVRES
L02 (m)
217
Slot diffusers

Pressure drop by horizontal discharge and 100 % opened volume
control damper.
LD 19/1 LD 19/2 LD-20/1 LD-20/1

LD-19/1 LD-19/1 LD-19/2 LD-19/2
L=600mm 1000
L=600mm 15001000
2000 1500 2000 L=600mm L=600mm
1000 1000 L=600mm 1000L=
200 200 200 200 200 200
1500 1500
100 100 100 100 2000 2000 100 100
50 50 45 45
40
50 50 50 50 50 50
40 40 45 45 40 40 40 40 35
) ) 30 30 )
30 30 (A ) (A ) 30 30 40 40
30 (A ) 3
40 (dB 40 (dB 20 20 20 20 (dB
20 20 L WA L WA
L
25 WA
25
35 ) 35 )
10
35
10
35
10 10 (A ) (A ) 10 10
(dB (dB
Δp t (Pa)
Δp t (Pa)
Δp t (Pa)
Δp t (Pa)
Δp t (Pa)
Δp t (Pa)
LW A
LW A
5 5 5 5 30 30 5 5
2 2 2 2 2 2
3 3 3 3
Q (m /h) Q (m /h) Q (m /h) Q (m /h)
100 150 100
200 150
300 200 500300 700 1000 700
500 1000 100 150 100
200 150
300 200 500300 700 500
1000 700 1000 100 150 100
200 150
300 200
Correction factors applicable to LD-19
LD-19/1 LD-19/2
Volume control damper Volume control damper
Length
open closed open closed
L=600 X1 X 1.3 X1 X 1.8
L=1000 X1 X 1.4 X1 X2
L=1500 X1 X 1.5 X1 X 2.2
L=2000 X1 X2 X1 X 2.5
218
Slot diffusers
VENTILATING VALVES
■■ Nozzle diffuser LD-20
125
Application
H1
85
A
Nozzle diffuser LD-20 is designed to
supply low quantities of air on big window L1 L1 8
surfaces to prevent condensation (ceiling
CIRCULAR DIFFUSERS,
L
SQUARE DIFFUSERS
installation near windows) or for big
throws for cooling when wall installation
(Coanda effect).
Description
The front plate is made of sheet steel
powder painted in white (RAL 9010) or any

other RAL colour (on customer’s request).
SWIRL DIFFUSERS,
Individually adjustable nozzles are made
from plastic in white (RAL 9010) or black
(RAL 9005) colour. Plenum box is made
125
H1
85
A
A
of sheet steel. Nozzle diffuser LD-20 can
be made in standard lenghts (one section)
from 600 up to 2000 mm with 100 mm L1 L1 8
L
step.

SLOT DIFFUSERS,
J
2 60 B

7
1 Plenum box
3 1 2 Inlet spigot
3 Volume control damper (M)
4 Nozzle
φD
6
5 Cross-bar
H
5 6 Fixing screw
7 Insulation (entire outside surface of the
plenum box)
SUPPLY AIR NOZZLES

32
8
φ20 4
A
L 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000
L1 552 652 752 852 476 526 576 626 676 726 776 826 876 926 976 EXTERNAL ELEMENTS
No. of nozzles 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40
No. of rows H1 B H A
1 65 117 216.5 85
CONTROL UNITS
2 105 162 236.5 125

AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
219
Slot diffusers
Number and dimensions L 600 – 1000 1100 – 1500 1600 – 2000

of spigots No. of rows Number and dimensions of spigots fD
1 1x123 2x123 2x138
2 1x158 2x138 2x158
Position of inlet spigots No. of inlet Standard Position of

J
L/2 L/2
J
60
spigots length inlet spigots
1 600-1000 L/2
φD
2 1100-1500 J=300
2 1600-2000 J=400
8
φ20
Front plate installation
With screws(V)
Installation of a plenum box with

Installation with a cross-member (Z) suspension bracket (P)
Installation on a cross bar can be made through the
hole, in which is mounted a nozzle.
Possible angle settings

150
150
150
150
220
Slot diffusers
VENTILATING VALVES
Ordering key
LD-20/1/B/K/M/Z/P/I5 L=1000 (lenght L=600, 700, …, 2000)
I5 T hermal insulation (polyethylene), 5 mm thick, on the outside of the plenum box
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
I9 Sound and thermal insulation (from -40 °C to 105 °C), 9 mm thick, on the outside of the plenum
I19 Sound and thermal insulation (from -40 °C to 105 °C), 19 mm thick, on the outside of the plenum
box (synthetic rubber based material)

V Visible installation (front plate without plenum box)
SWIRL DIFFUSERS,
K Plenum box
B Black nozzles
W White nozzles

SLOT DIFFUSERS,
1 Number of rows with nozzles
2
LD-20 Nozzle diffuser

Note:
Sandard colour is RAL 9010. Other colours on customer’s request.
SUPPLY AIR NOZZLES

EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
221
Slot diffusers
Quick selection
Horizontal discharge DT=0K

Type Q (l/s) 13.9 27.8 41.7 55.6 69.4 83.3 111.1
(m³/h) 50 100 150 200 250 300 400
LWA (dB(A)) 20 33.8 41 / / / /
LD-20/1 L=600 mm ∆pt (Pa) 13.5 35.6 74.8 / / / /
L0.2 (m) 6.6 > 10 > 10 / / / /
LWA (dB(A)) 11 23.2 30 36 / / /
LD-20/1 L=1000 mm ∆pt (Pa) 12 22 43 76 / / /
L0.2 (m) 3.8 6.6 9.3 > 10 / / /
LWA (dB(A)) 8 14.5 25 31 35 37.5 43
LD-20/1 L=1500 mm ∆pt (Pa) 5.5 12.5 25 39.6 55 86.4 136.8
L0.2 (m) 2.1 3.5 5 6.4 7.9 9.3 > 10
LWA (dB(A)) / 11 21 26.5 31 34.7 40
LD-20/1 L=2000 mm ∆pt (Pa) / 7.5 15 23.7 33 45.5 75.2
L0.2 (m) / 2.5 3.6 4.6 5.7 6.7 7.5
LWA (dB(A)) 14 25 31 / / / /
LD-20/2 L=600 mm ∆pt (Pa) 2 8.3 18.3 / / / /
L0.2 (m) 4.2 9.1 > 10 / / / /
LWA (dB(A)) / 19 24 27.8 31 / /
LD-20/2 L=1000 mm ∆pt (Pa) / 4 8 15 22 / /
L0.2 (m) / 7.1 8.9 > 10 > 10 / /
LWA (dB(A)) / 14.6 20.4 24 27 28.5 32.5
LD-20/2 L=1500 mm ∆pt (Pa) / 2.4 4.7 7.6 13 17 28.5
L0.2 (m) / 4.3 5.3 6.2 7.3 8.1 8.9
LWA (dB(A)) / 11 17 21.5 24 26.3 30.3
LD-20/2 L=2000 mm ∆pt (Pa) / 1.4 2.7 4.2 6.5 8.2 14.4
L0.2 (m) / 2.8 3.5 4.0 4.7 5.3 5.8
222
Slot diffusers
VENTILATING VALVES
Horizontal discharge DT=-5K

Type Q (l/s) 13.9 27.8 41.7 55.6 69.4 83.3 111.1
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
(m³/h) 50 100 150 200 250 300 400
LWA (dB(A)) 20 33.8 41 / / / /
LD-20/1 L=600 mm ∆pt (Pa) 13.5 35.6 74.8 / / / /
L0.2 (m) 5.1 > 10 > 10 / / / /
LWA (dB(A)) 11 23.2 30 36 / / /
LD-20/1 L=1000 mm ∆pt (Pa) 12 22 43 76 / / /

L0.2 (m) 2.9 6.9 8.8 > 10 / / /
SWIRL DIFFUSERS,
LWA (dB(A)) 8 14.5 25 31 35 37.5 43
LD-20/1 L=1500 mm ∆pt (Pa) 5.5 12.5 25 39.6 55 86.4 136.8
L0.2 (m) 1.6 3.8 4.8 6.6 8.2 9.8 > 10
LWA (dB(A)) / 11 21 26.5 31 34.7 40
LD-20/1 L=2000 mm ∆pt (Pa) / 7.5 15 23.7 33 45.5 75.2

L0.2 (m) / 2.7 3.4 4.7 5.8 7.0 8.1
SLOT DIFFUSERS,
LWA (dB(A)) 14 25 31 / / / /
LD-20/2 L=600 mm ∆pt (Pa) 2 8.3 18.3 / / / /
L0.2 (m) 7.3 9.1 > 10 / / / /
LWA (dB(A)) / 19 24 27.8 31 / /
LD-20/2 L=1000 mm ∆pt (Pa) / 4 8 15 22 / /

L0.2 (m) / 4.7 7.1 9.3 > 10 / /
LWA (dB(A)) / 14.6 20.4 24 27 28.5 32.5
LD-20/2 L=1500 mm ∆pt (Pa) / 2.4 4.7 7.6 13 17 28.5
L0.2 (m) / 2.8 4.3 5.6 7.0 8.2 9.3
LWA (dB(A)) / 11 17 21.5 24 26.3 30.3
LD-20/2 L=2000 mm ∆pt (Pa) / 1.4 2.7 4.2 6.5 8.2 14.4
L0.2 (m) / 1.8 2.8 3.6 4.5 5.3 6.0
SUPPLY AIR NOZZLES

EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
223
Slot diffusers
Horizontal discharge DT=-10K

Type Q (l/s) 13.9 27.8 41.7 55.6 69.4 83.3 111.1
(m³/h) 50 100 150 200 250 300 400
LWA (dB(A)) 20 33.8 41 / / / /
LD-20/1 L=600 mm ∆pt (Pa) 13.5 35.6 74.8 / / / /
L0.2 (m) 3.5 8.5 > 10 / / / /
LWA (dB(A)) 11 23.2 30 36 / / /
LD-20/1 L=1000 mm ∆pt (Pa) 12 22 43 76 / / /
L0.2 (m) 2 4.9 8.1 > 10 / / /
LWA (dB(A)) 8 14.5 25 31 35 37.5 43
LD-20/1 L=1500 mm ∆pt (Pa) 5.5 12.5 25 39.6 55 86.4 136.8
L0.2 (m) 1.1 2.6 4.4 5.9 7.3 9.1 > 10
LWA (dB(A)) / 11 21 26.5 31 34.7 40
LD-20/1 L=2000 mm ∆pt (Pa) / 7.5 15 23.7 33 45.5 75.2
L0.2 (m) / 1.9 3.1 4.2 5.3 6.6 7.5
LWA (dB(A)) 14 25 31 / / / /
LD-20/2 L=600 mm ∆pt (Pa) 2 8.3 18.3 / / / /
L0.2 (m) 3.4 4.3 7.74 / / / /
LWA (dB(A)) / 19 24 27.8 31 / /
LD-20/2 L=1000 mm ∆pt (Pa) / 4 8 15 22 / /
L0.2 (m) / 2.5 4.5 6.7 9.7 / /
LWA (dB(A)) / 14.6 20.4 24 27 28.5 32.5
LD-20/2 L=1500 mm ∆pt (Pa) / 2.4 4.7 7.6 13 17 28.5
L0.2 (m) / 1.5 2.7 4.0 5.8 6.9 8.3
LWA (dB(A)) / 11 17 21.5 24 26.3 30.3
LD-20/2 L=2000 mm ∆pt (Pa) / 1.4 2.7 4.2 6.5 8.2 14.4
L0.2 (m) / 1.0 1.8 2.6 3.8 4.5 5.4
L0.2 (m) Isothermal throw length of supply air jet, when its speed drops down to 0.2 /s
L02 (m)
L02 (m)
L02 (m)
L02 (m)
224
Slot diffusers
VENTILATING VALVES
Vertical discharge DT=0K

Type Q (l/s) 13.9 27.8 41.7 55.6 69.4 83.3 111.1
(m³/h) 50 100 150 200 250 300 400
LWA (dB(A)) 20 33.8 41 / / / /
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
LD-20/1 L=600 mm ∆pt (Pa) 13.5 35.6 74.8 / / / /
L0.2 (m) 5.2 > 10 > 10 / / / /
LWA (dB(A)) 11 23.2 30 36 / / /
LD-20/1 L=1000 mm ∆pt (Pa) 12 22 43 76 / / /
L0.2 (m) 3.2 7.4 9.4 > 10 / / /
LWA (dB(A)) 8 14.5 25 31 35 37.5 43

LD-20/1 L=1500 mm ∆pt (Pa) 5.5 12.5 25 39.6 55 86.4 136.8
SWIRL DIFFUSERS,
L0.2 (m) 1.5 3.9 6.6 9.8 > 10 > 10 > 10
LWA (dB(A)) / 11 21 26.5 31 34.7 40
LD-20/1 L=2000 mm ∆pt (Pa) / 7.5 15 23.7 33 45.5 75.2
L0.2 (m) / 2.6 4.6 6.6 9 > 10 > 10
LWA (dB(A)) 14 25 31 / / / /

LD-20/2 L=600 mm ∆pt (Pa) 2 8.3 18.3 / / / /
SLOT DIFFUSERS,
L0.2 (m) 2.7 5.4 8.8 / / / /
LWA (dB(A)) / 19 24 27.8 31 / /
LD-20/2 L=1000 mm ∆pt (Pa) / 4 8 15 22 / /
L0.2 (m) / 3 5.4 7.2 8.9 / /
LWA (dB(A)) / 14.6 20.4 24 27 28.5 32.5

LD-20/2 L=1500 mm ∆pt (Pa) / 2.4 4.7 7.6 13 17 28.5
L0.2 (m) / 3.3 4.6 6.1 7.7 9.4 > 10
LWA (dB(A)) / 11 17 21.5 24 26.3 30.3
LD-20/2 L=2000 mm ∆pt (Pa) / 1.4 2.7 4.2 6.5 8.2 14.4
L0.2 (m) / 1.9 2.6 3.4 4.2 5.1 7.1
SUPPLY AIR NOZZLES

EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
225
Slot diffusers
Vertical discharge DT=+5K

Type Q (l/s) 13.9 27.8 41.7 55.6 69.4 83.3 111.1
(m³/h) 50 100 150 200 250 300 400
LWA (dB(A)) 20 33.8 41 / / / /
LD-20/1 L=600 mm ∆pt (Pa) 13.5 35.6 74.8 / / / /
L0.2 (m) 3.9 > 10 > 10
LWA (dB(A)) 11 23.2 30 36 / / /
LD-20/1 L=1000 mm ∆pt (Pa) 12 22 43 76 / / /
L0.2 (m) 2 5.1 8.6 > 10 / / /
LWA (dB(A)) 8 14.5 25 31 35 37.5 43
LD-20/1 L=1500 mm ∆pt (Pa) 5.5 12.5 25 39.6 55 86.4 136.8
L0.2 (m) 1.2 3 5.1 7.5 > 10
LWA (dB(A)) / 11 21 26.5 31 34.7 40
LD-20/1 L=2000 mm ∆pt (Pa) / 7.5 15 23.7 33 45.5 75.2
L0.2 (m) / 2.1 3.6 5.2 7 9.1 > 10
LWA (dB(A)) 14 25 31 / / / /
LD-20/2 L=600 mm ∆pt (Pa) 2 8.3 18.3 / / / /
L0.2 (m) 2.3 5.9 > 10 / / / /
LWA (dB(A)) / 19 24 27.8 31 / /
LD-20/2 L=1000 mm ∆pt (Pa) / 4 8 15 22 / /
L0.2 (m) / 3 5.4 7.2 8.4 / /
LWA (dB(A)) / 14.6 20.4 24 27 28.5 32.5
LD-20/2 L=1500 mm ∆pt (Pa) / 2.4 4.7 7.6 13 17 28.5
L0.2 (m) / 1.85 3.1 4.5 6.2 7.9 > 10
LWA (dB(A)) / 11 17 21.5 24 26.3 30.3
LD-20/2 L=2000 mm ∆pt (Pa) / 1.4 2.7 4.2 6.5 8.2 14.4
L0.2 (m) / 1.6 2.2 3.2 4.3 5.4 8
226
Slot diffusers
VENTILATING VALVES

Type Q (l/s) 13.9 27.8 41.7 55.6 69.4 83.3 111.1
(m³/h) 50 100 150 200 250 300 400
LWA (dB(A)) 20 33.8 41 / / / /
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
LD-20/1 L=600 mm ∆pt (Pa) 13.5 35.6 74.8 / / / /
L0.2 (m) 2.6 6.3 > 10 / / / /
LWA (dB(A)) 11 23.2 30 36 / / /
LD-20/1 L=1000 mm ∆pt (Pa) 12 22 43 76 / / /
L0.2 (m) 1.5 3.6 6.2 8.8 / / /
LWA (dB(A)) 8 14.5 25 31 35 37.5 43

LD-20/1 L=1500 mm ∆pt (Pa) 5.5 12.5 25 39.6 55 86.4 136.8
SWIRL DIFFUSERS,
L0.2 (m) 1.5 2 3.3 4.8 6.5 8.3 > 10
LWA (dB(A)) / 11 21 26.5 31 34.7 40
LD-20/1 L=2000 mm ∆pt (Pa) / 7.5 15 23.7 33 45.5 75.2
L0.2 (m) / 1.4 2.4 3.4 4.6 5.8 8.5
LWA (dB(A)) 14 25 31 / / / /

LD-20/2 L=600 mm ∆pt (Pa) 2 8.3 18.3 / / / /
SLOT DIFFUSERS,
L0.2 (m) 1.5 4.5 8.2 / / / /
LWA (dB(A)) / 19 24 27.8 31 / /
LD-20/2 L=1000 mm ∆pt (Pa) / 4 8 15 22 / /
L0.2 (m) / 2 3.6 5.3 7.4 / /
LWA (dB(A)) / 14.6 20.4 24 27 28.5 32.5

LD-20/2 L=1500 mm ∆pt (Pa) / 2.4 4.7 7.6 13 17 28.5
L0.2 (m) / 1.1 2.1 3.3 4.6 6.1 9.2
LWA (dB(A)) / 11 17 21.5 24 26.3 30.3
LD-20/2 L=2000 mm ∆pt (Pa) / 1.4 2.7 4.2 6.5 8.2 14.4
L0.2 (m) / 0.7 1.3 2.1 3 3.9 6.1
SUPPLY AIR NOZZLES

EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
227
Slot diffusers

Type Q (l/s) 13.9 27.8 41.7 55.6 69.4 83.3 111.1
(m³/h) 50 100 150 200 250 300 400
LWA (dB(A)) 20 33.8 41 / / / /
LD-20/1 L=600 mm ∆pt (Pa) 13.5 35.6 74.8 / / / /
L0.2 (m) 1.8 4.5 7.9 / / / /
LWA (dB(A)) 11 23.2 30 36 / / /
LD-20/1 L=1000 mm ∆pt (Pa) 12 22 43 76 / / /
L0.2 (m) 1.1 2.6 4.3 5.1 / / /
LWA (dB(A)) 8 14.5 25 31 35 37.5 43
LD-20/1 L=1500 mm ∆pt (Pa) 5.5 12.5 25 39.6 55 86.4 136.8
L0.2 (m) 1.1 1.4 2.4 3.5 4.6 6 8.8
LWA (dB(A)) / 11 21 26.5 31 34.7 40
LD-20/1 L=2000 mm ∆pt (Pa) / 7.5 15 23.7 33 45.5 75.2
L0.2 (m) / 1 1.6 2.4 3.3 4.2 6.1
LWA (dB(A)) 14 25 31 / / / /
LD-20/2 L=600 mm ∆pt (Pa) 2 8.3 18.3 / / / /
L0.2 (m) 1.2 3.1 5.6 / / / /
LWA (dB(A)) / 19 24 27.8 31 / /
LD-20/2 L=1000 mm ∆pt (Pa) / 4 8 15 22 / /
L0.2 (m) / 1.6 2.4 3.7 5.3 / /
LWA (dB(A)) / 14.6 20.4 24 27 28.5 32.5
LD-20/2 L=1500 mm ∆pt (Pa) / 2.4 4.7 7.6 13 17 28.5
L0.2 (m) / 1 1.5 2.3 3.2 4.2 6.3
LWA (dB(A)) / 11 17 21.5 24 26.3 30.3
LD-20/2 L=2000 mm ∆pt (Pa) / 1.4 2.7 4.2 6.5 8.2 14.4
L0.2 (m) / 0.6 0.9 1.5 2.1 2.8 4.2
L0.2 (m) Isothermal throw length of supply air jet, when its speed drops down to 0.2 m/s
L02 (m)
L02 (m)
228
Slot diffusers
VENTILATING VALVES
Pressure drop by horizontal discharge and 100 % opened volume control damper
LD-20/1
LD-20/1 LD-20/2
LD-20/2
L=600mm 1000 1000
L=600mm 1500 1500
2000 2000 L=600mm 1000 1000
L=600mm
CIRCULAR DIFFUSERS,
200 200 200 200
SQUARE DIFFUSERS
1500
1500 1500
2000 100 100 100 100
5
40 40 2000 2000
50 50 50 50
40 40 35 35 40 40
30 30 ) ) (A ) ) 30 30
30 30(A
20 20 (dB A (dB 20 20
35 35
25 25 L WA LW
10 10 30 30
10 10

Δp t (Pa)
Δp t (Pa)
) )
Δp t (Pa)
Δp t (Pa)
A) A)
B( B(
SWIRL DIFFUSERS,
5 5 25 25(d (d
5 5 L WA L WA
20 20
2 2 2 2
3 3
3
/h)
3
Q (m /h) Q (m /h)
Q (m /h) 3
Q (m /h)
3
Q (m /h)
0 100 100
150 150
200 200300 300 500 500
700 700
1000 1000 100 100
150 150
200 200300 300 500 500
700 700
1000 1000

SLOT DIFFUSERS,
Correction factors applicable to LD-20
LD-20/1 LD-20/2
Volume control damper Volume control damper
Length
open closed open closed
L=600 X1 X 1.25 X1 X 1.6

L=1000 X1 X 1.3 X1 X 1.8
L=1500 X1 X 1.4 X1 X2
L=2000 X1 X 1.8 X1 X 2.3
SUPPLY AIR NOZZLES

EXTERNAL ELEMENTS
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
229
Slot diffusers
■■ Floor Slot Diffusers LD-16N

AI
Application
LD-16N floor slot diffusers are a suitable
solution for swimming pools and similar
rooms with large glass surfaces and RAL
windows. They are designed for installati- 9010
on in the floor. Warm air is supplied in the

CD
upwards direction, towards the window.
With appropriate dimensions, proper air
supply is guaranteed, free of excessive
draught or noise (LWA<35 dB(A)).
Description
LD-16N slot diffusers are designed in 1,
2, 3, 4, 5 and 6 slot versions. They are
made of fixed aluminium sections and an
aluminium structural frame.
18.5
The diffusers are available in single piece
8.5
lengths 200 mm to 2000 mm. Painting
according to the customer’s specification
is available on order.
100
57
Advantages
• No glass misting 18.5 15 130 15
• Optimal ventilation 8.5
32
• No heat losses
• Low pressure drop 18.5
• Prevents the descent of cold air along 8.5
100
windows
57
• Does not cause heating of air near the

windows even in 18.5
the sunshine 15 130 15 150
100
• Easy installation 8.5
57
32 45.5
18.5
15 130 15
8.5
100
32
57
Versions
15 130 15 150 180
100
57
32 45.5 59
single slot LD-16N/1 two slots LD-16N/2 three slots LD-16N/3
18.5 15 130 15 150
8.5
32 45.5
150 180 230

100
57
45.5 59 72.5
15 130 15 150 180
32 45.5 59
four slots LD-16N/4 180 five slots LD-16N/5 230 six slots LD-16N/6 280
59 72.5 86
150 180 230
45.5 59 72.5
230 280 330
72.5 86
180 230 280
59 72.5 86
280 330
230 86
230 280 330

Slot diffusers
VENTILATING VALVES
Installation method max 0.2m
1 glass
2 LD-16N slot diffuser
1 3 air supply channel
2
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
SWIRL DIFFUSERS,
3
Fast selection diagram
LwA < 35 dB(A); Vef =2,5 m/s; Δpt = 16 Pa
v ef

25
SLOT DIFFUSERS,
/1
4
/2
N/
-1 6 N
- 16
/3
-16
6N
LD N /5
LD
-1
LD
-16
LD
LD
20
N/
6 Example
-16
LD
The available floor area next to the glass surface

is 15 m in length. The calculated supplied air
15
flow rate is 4000 m³/h. From the diagram, the
type:
LD-16N/3 L=15m is selected.
L (m)
10 Q (m³/h) Air flow rate

Δpt (Pa) Pressure drop
L (m) Slot diffuser length
SUPPLY AIR NOZZLES

5 vef (m/s) Effective air velocity
1000 2000 3000 4000 5000 6000 7000 8000

Q (m 3/h)
Ordering key EXTERNAL ELEMENTS
LD-16N /v 1= 2.5/ m/s

ef
L/n L WA < 35 dB(A) Δpt = 80 Pa/m
Number of longitudinal sections (pieces)
Single piece length (L = 200, 300, …, 2000)

CONTROL UNITS
AIR FLOW
1 Number of slots
2
3
4
5
6
SOUND ATTENUATORS,
SOUND ATTENUATING
LD-16N Floor slot diffuser

LOUVRES
Note:
Standard colour is RAL 9010.
231
Slot diffusers
■■ Panel design slot diffusers

LDP-13, LDP-14
Application
Panel design slot diffusers are designed
for the supply of air in rooms with floor to St
ceiling heights from 2.4 m to 4 m. They
are suitable for supplying either cold or
warm air. RAL
9010
Description
LDP-13 and LDP-14 consists of a diffuser
face plate and a plenum box. The diffuser
face plate is commonly made of sheet
steel and its design can be suited to the
customer’s requirements. Longitudinal
guides, fitting tight to the sheet steel, are
inserted in the diffuser face plate. Cylindri-
cal deflectors, made of recycled plastics A
(ABS-antistatic) are installed in the guides,

to allow free adjustment of both air jet
discharge direction and flow rate. The
number of slots per unit depends on the 1
size of the unit. Diffuser face plate is pow- 3
der painted in a RAL 9010 scale colour,
or, on special orders, in other colours.
φD
The deflectors, equal to those of LD-13 or
LD-14 slot diffusers, are white or black as 2
H
standard.
The plenum box is made of galvanised
4
sheet steel. It is fitted with a flow rate
control damper, designed for fine air flow
rate adjustment.
Type
9
• LDP-13 m = 12 mm 5 φ C3
• LDP-14 m = 22 mm
1 Plenum box
8 2 Volume control damper
3 Inlet spigot
7 4 Cross member
5 Diffuser face plate
6 6 Guide
7 Air deflector
8 Spring clamp
m
LDP-13 LDP-14
7
Size фC3 Slot length фA фD H No. of slots h No. of slots h
400 395 300 370 198 320 8 6 6
500 495 400 470 198 320 10 6
25 40
600 595 500 570 248 380 12 8
625 620 500 570 248 380 12 8
232
Slot diffusers
VENTILATING VALVES
Special orders
On special order, we can deliver
diffuser face plates of any design. The
shape and dimensions are specified
in agreement with the designer or
customer.
CIRCULAR DIFFUSERS,
SQUARE DIFFUSERS
Technical data
Tecnical data are determined upon the
definition of the shape, design, number
of discharge slots and other factors.

Fast flow rate determination
SWIRL DIFFUSERS,
(at LWA < 35 dB(A))
LPD-13: flow rate per 1 meter length
≈100 m³/h
LPD-14: flow rate per 1 meter length
≈150 m³/h

SLOT DIFFUSERS,
Ordering key
LDP-13/B/K/M/I Size 400
Size (400, 500, 600, 625)

SUPPLY AIR NOZZLES

K Plenum box
B Black deflectors
W White deflectors
LDP-13
LDP-14
EXTERNAL ELEMENTS
Note:
CONTROL UNITS
AIR FLOW
SOUND ATTENUATORS,
SOUND ATTENUATING
LOUVRES
233

■■ Round Duct Diffuser SKD-13
Application
Round duct diffusers SKD-13 are designed for supplying air to
the rooms with large floor to ceiling heights, e.g. conference halls, St
gyms, industrial halls etc. They can be installed at any location wi- RAL
9010
thin the duct network, which renders them suitable for supplying
of either hot or cold air.
The T register model is designed to control the supply air flow-rate
at the individual diffuser level. The T register design is recom-
mended for installations with several round duct diffusers in one
line. In such cases, the flow-rates of the diffusers near the line
beginning should be slightly reduced, in order to supply adequate
amounts of air to the diffusers farther along the line.
Description
The duct diffuser consists of galvanised round cross-section tubes
with inserted longitudinal guides, fitting tight into the tubes. Cylindri-
cal deflectors made of recycled plastics are inserted into the guides,
to allow continuous adjustment of discharged air direction within
the 360o range. Diffusers are available with different number of
slots. The tube is painted in a RAL 9010 scale colour, or, on special
orders, in other colours. The deflectors, equal to those of LD-13 slot
diffusers, are white or black as standard.
A T register, made of galvanised sheet steel, is inserted in the SKD-
-13D/T. The T register The setting piece is adjusted with a gear mo-
ved using a straight screwdriver. The gear can be accessed through
3 2 1
a hole in the cover.
1. SKD-13D
2. T-register
3. Gear
LD L LV
/ 1000 800
1505 750 2 X 500
1755 875 2 X 600
2005 1000 2 X 800
Diffuser structure for lengths exceeding 1000 mm

D
φ
60 Lv 60 60 Lv Lv 60
L L L
5
Note: фD is the diffuser internal diameter. Ld
234
L

VENTILATING VALVES
Accessories
Size d L,r 7 40
End cover Elbow 900 L L
150 148.7-149.3 150 r
40
160 158.7-159.3 160
CIRCULAR DIFFUSERS,
40 20
SQUARE DIFFUSERS
180 178.6-179.3 180
40
200 198.6-199.3 200 Ød Ød
Ød
224 222.5-223.3 224
250 248.5-249.3 250
280 278.4-279.3 280
Joining piece
300 298.4-299.3 300
7 40

7 40
315 313.4-314.3 315 r r
SWIRL DIFFUSERS,
355 353.3-354.3 355
40
40
40 20
400 398.3-399.3 400 40 20
7
40
40
450 448.2-449.3 450
Ød Ød Ød Ød Ød Ød
500 498.2-499.3 500
560 558.1-559.3 560

630 628.1-629.3 630
SLOT DIFFUSERS,
710 708.0-709.3 710
800 798.1-799.3 800
900 897.0-899.3 900
Note: фd is the external diameter.

Installation of SKD-13/D
SKD-13/D Joining piece Tube Joining piece SKD-13/D
φD
SUPPLY AIR NOZZLES

L 40 40 L 87 L
7
SKD-13/R
EXTERNAL ELEMENTS
60
SKD-13/R is constructed for installations into round ducts with
square openings.
No. of ΦD of Openings
L LV H slots tube L-35 H-35
580 500 100 1 150-355 545 65
H
680 600 150 2 355-900 645 115

CONTROL UNITS
600-
AIR FLOW
880 800 200 3 845 165

2400
600-
880 800 250 4 845 215 Lv
2400
L
SOUND ATTENUATORS,
Installation of SKD-13/R:
SOUND ATTENUATING
LOUVRES
235
Ordering key Ordering key

SKD-13D SKD-13R
SKD-13D /B /T /ф355 /2 L=1000 mm SKD-13R /B /T /ф355 /2 L=680 mm, H=150 mm
Length Length
Number of slots Number of slots
Tube diameter Tube diameter
T-register T-register
B Black deflectors B Black deflectors

W White deflectors W White deflectors
Tube R Diffuser designed

for installation into
round ducts
Note:
• Please specify the deflector colour in your order. Other colours on customer's
request.
Example accessory specification:

Accessory: Elbow 900
Colour: RAL 9010
Quantity: 1 piece
Types of discharge
Cooling – two-sided horizontal discharge Cooling – alternate sided horizontal

discharge
Cooling – one sided left (horizontal) Cooling – one sided – right (horizontal) Heating – vertical 90°
For determination of air velocity data at different throw distances

and temperature differences, please use software for air
distribution elements calculation KLIMA ADE.
236
VENTILATING VALVES
Pipe length Ld [mm] No. of Recommended air flow volume [m³/h]
Lwa[dB(a)]
(Slot length Lv [mm]) slots 150, 160, 180 200, 224, 250 280, 300, 315, 355 400, 450 500, 560 630, 710, 800, 900
2 26 128 128 128 128 128 128
4 30 256 256 256 256 256 256
6 34 384 384 384 384
CIRCULAR DIFFUSERS,
1000
SQUARE DIFFUSERS
8 35 512 512 512
(800)
10 36 640 640 640
12 37 768 768
14 38 896 896
2 35 160 160 160 160 160 160
4 38 320 320 320 320 320 320

6 40 480 480 480 480
SWIRL DIFFUSERS,
1505
8 41 640 640 640
(2 x 500)
10 46 800 800 800
12 46 960 960
14 47 1120
2 30 192 192 192

4 32 384 384 384
SLOT DIFFUSERS,
1755
6 33 576 576
(2 x 600)
8 35 768
10 38 960
2 30 256 256 256
4 32 512 512 512
2005

6 34 768 768
(2 x 800)
8 37 1024
10 40 1280
Other dimensions are available on request.

The recommended air flow is 80 m³/h m per meter of active slot length.
SUPPLY AIR NOZZLES

Pressure drop determination diagram
160
140
120 gister
ut T re
witho with T registe
r
100
90
EXTERNAL ELEMENTS
80
70
V [m 3/hm slot]
60
50
40
30
CONTROL UNITS
1
AIR FLOW
vduct [m/s]
5 10 15 20 25 30
2
5 10 15 20 25 30 40
3
10 15 20 25 30 35 40
4
SOUND ATTENUATORS,
SOUND ATTENUATING
15 20 25 30 35 40
5
LOUVRES
25 30 35 40 45 50
6
35 40 45 50 55 60
Total pressure p [Pa] at the SKD-13 diffuser
v air jet velocity in the duct

237

Slot diffusers and round duct diffusers

Uploaded by

Document Information

Original Description:

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Slot diffusers and round duct diffusers

Uploaded by

Copyright:

Available Formats

04

Slot diffusers, Round duct diffusers

Slot diffusers Round duct diffusers

SUPPLY AIR NOZZLES

Round duct diffusers can be installed at various

locations within the duct network. They are suitable for

■■ Floor slot diffusers

Slot diffusers 180

VARIABLE SWIRL DIFFUSERS

ROUND DUCT DIFFUSERS

motor version, … 15 m. characteristics of grilles and difusers in

regard to the given conditions with the

shutting of the diffuser. The slot diffuser F

steel and has a flow rate control damper B 60 LD-13

built in its inlet spigot, to allow fine adjust- F 5

ment of the desired air flow rate. 1 9.4 46

volume control damper E

VARIABLE SWIRL DIFFUSERS

regards its mounting to the ceiling or wall.

ROUND DUCT DIFFUSERS

ments. The narrow design has eliminated

AIR DISPLACEMENT UNITS

LD-13 O, LD-14 O LD-13, LD-14

SUPPLY AIR NOZZLES

4 290 331 196 135 161.5 125.8

customer’s request. As standard, cylindri- 1 233.5 287 106 44 69 35.3

2 253.5 307 150 89 115 80

Slot diffuser face plate designs

Joining diffusers together in

VARIABLE SWIRL DIFFUSERS

ROUND DUCT DIFFUSERS

AIR DISPLACEMENT UNITS

SUPPLY AIR NOZZLES

Installation with special Installation with springs into ducts (N)

Types of air discharge

Max. air flow rate

Slot diffuser with actuator controlled

standard slot diffusers, air flow rate is

LH 24A-SR100 and LH-24A-MP100. The

Length L=300, 400, 500, …, 2000 (single piece)

I5 Thermal insulation (polyethylene), 5 mm thick, on the outside of the plenum box

VARIABLE SWIRL DIFFUSERS

Z Fixing of the diffuser to the plenum box with a cross-member

ROUND DUCT DIFFUSERS

M Volume control damper

E End sealing on both ends

AIR DISPLACEMENT UNITS

SUPPLY AIR NOZZLES

LD-13 Slot diffuser

Wall mounted slot diffusers 4

Designed for installation in plasterboard walls with a thickness of

Front plenum box connection

the ventilated room. The insulation placement effectively reduces

on the location of the inlet jet through the connection.

KF Plenum box, front side connection

VARIABLE SWIRL DIFFUSERS

ROUND DUCT DIFFUSERS

S For wall installation

AIR DISPLACEMENT UNITS

SUPPLY AIR NOZZLES

Fast selection diagram:

100 300 500 1000 1200
