Engine Assembly

ENGINE ASSEMBLY
109A13451-1
TABLE OF CONTENTS Sandvik DL430-7 090805
10. ENGINE ASSEMBLY

* 550 796 61 ENGINE ASSEMBLY, MB OM904LA 110KW, TIER 3................................................................................................... 2
** 550 440 06 SURGE TANK ASSEMBLY......................................................................................................................................... 7
** 550 368 85 GEARBOX + CONVERTER......................................................................................................................................... 8
*** 550 768 37 NSS CONVERTER HOUSING ASSEMBLY............................................................................................................ 10
*** 550 768 39 NSS TRANSMISSION CASE & COVER................................................................................................................. 12
*** 550 768 40 NSS TURBINE SHAFT ASSEMBLY........................................................................................................................ 14
*** 550 478 77 FLEX PLATE............................................................................................................................................................ 16
*** 550 768 44 NSS TORQUE CONVERTER ASSY....................................................................................................................... 18
*** 550 768 45 NSS GEAR KIT........................................................................................................................................................ 20
*** 550 768 51 NSS PUMP DRIVE GROUP.................................................................................................................................... 22
*** 550 768 53 NSS PUMP DRIVE GROUP.................................................................................................................................... 24
*** 550 768 54 NSS SHAFT ASSEMBLY......................................................................................................................................... 26
*** 550 768 60 NSS GEAR............................................................................................................................................................... 30
*** 550 768 61 NSS LOW SPEED SHAFT GROUP........................................................................................................................ 32
*** 550 768 69 NSS PUMP ASSEMBLY.......................................................................................................................................... 40
*** 550 768 73 NSS GEAR CONTROL VALVE............................................................................................................................... 42
**** 550 768 74 VALVE ASSEMBLY.............................................................................................................................................. 44
** 550 429 23 CONNECTING PIECE, TRANSMISSION.................................................................................................................... 45
** 550 429 20 CONNECTING PIECE................................................................................................................................................. 46
** 550 472 41 PUMP ASSEMBLY....................................................................................................................................................... 47
* ENGINE MB OM 904 LA, TIER3, SEE SEPARATE CATALOGUE..................................................................................................
Sandvik Mining and Construction Oy, Drills Tampere © 2009

550 796 61 bDh
1 (47) ENGINE ASSEMBLY / MB OM904LA 110KW, TIER 3 090805

550 796 61 bDh
090805 ENGINE ASSEMBLY / MB OM904LA 110KW, TIER 3 2 (47)
Ref. Part no. Description EN Standard designation Qty

e
3 550 782 35 COOLER 1
4 550 856 74 MOUNTING PLATE 2
5 550 855 67 BRACKET 1
7 550 417 54 BRACKET 1
23 550 422 00 PLATE 1
. . . . .
25 550 751 45 DAMPER D40/h30/M10 55shore 4
26 550 414 91 RUBBER PAD SET 6
29 550 429 20 CONNECTING PIECE SECTION 10 PAGE 46 1
40 550 422 13 BRACKET 1
41 550 440 06 SURGE TANK ASSEMBLY SECTION 10 PAGE 7 1
. . . . .
55 550 508 73 RUBBER SHEET 1
56 871 942 19 CABLE ENTRY 1
89 867 163 79 STRAIGHT THREAD ADAPTER 9/16-18JIC 1
102 800 466 09 HEXAGON HEAD BOLT M10x60 m8.8 4
103 800 467 39 HEXAGON HEAD BOLT M12X120 DIN931 88ZN 6
. . . . .
104 808 997 79 HEXAGON HEAD SCREW M12X50 m8.8 SFS 2064 4
106 800 460 49 HEXAGON HEAD SCREW M10X25-8.8 SFS-ISO 4017 6
121 284 773 10 LOCK NUT M10 DIN985 8.8ZN 15
122 811 260 29 LOCK NUT M12 m8 BH8 12
. . . . .
131 851 281 89 DOUBLE LOCK WASHER M8 2
135 421 181 30 WASHER 10,5 8
. . . . .
150 550 472 41 PUMP ASSEMBLY SECTION 10 PAGE 47 1

550 796 61 bDh

550 796 61 bDh

e
6 550 834 35 GUARD 1
10 550 957 96 GUARD for radiator fan, D=678 1
11 550 802 00 INTAKE PIPE 1
12 550 421 79 INTAKE PIPE 1
13 550 423 28 RUBBER HOSE 1
. . . . .
14 550 423 00 RUBBER HOSE 1
15 550 413 54 RUBBER HOSE 1
16 093 700 70 O-RING 85,09X5,33, NBR, 70 SHORE A 1
20 550 422 47 HOSE CLAMP Hose Clamp, 90-110mm 6
21 550 421 90 PLATE 1
. . . . .
24 883 203 69 DAMPER 2
38 550 444 36 ELBOW 1
60 551 615 74 GUARD For alternator, MB 1
71 817 098 79 STRAIGHT THREAD ELBOW 3/4-16 JIC 2
72 865 407 99 ADAPTER (HYDRAULIC) JIC 3/4-16 1
. . . . .
73 817 094 69 ADAPTOR JIC 3/4-16 1
74 800 156 19 BALL VALVE R1/2IN 1
75 817 097 49 PLUG 3/4-16 JIC 2
79 817 094 69 ADAPTOR JIC 3/4-16 1
90 592 009 27 HYDRAULIC HOSE ASSEMBLY 2SC08MS AB-600-JIC 1
. . . . .
91 592 009 25 HYDRAULIC HOSE ASSEMBLY 2SC08MS AA-900-JIC 1
92 817 099 09 ADAPTER (HYDRAULIC) 3/4-16JIC 2
93 864 095 09 STRAIGHT THREAD ELBOW C40X-S12-3/8" (3/4-16JIC) 1
94 550 562 40 ADAPTER (HYDRAULIC) 1
97 283 356 60 CU-SEAL A27X32X2 DIN 7603-CU 1
. . . . .
106 800 460 49 HEXAGON HEAD SCREW M10X25-8.8 SFS-ISO 4017 6
123 801 779 99 LOCK NUT M8 DIN985 88ZN 2
126 550 444 02 HEXAGON NUT M10 MS, DIN934, SFS 2067 4
. . . . .
141 800 916 09 HEXAGON HEAD SCREW M8x25 m8.8 SFS 6
142 884 293 59 WASHER M8 DIN 9021 6

550 796 61 bDh

550 796 61 bDh

e
1 550 794 98 ENGINE MB OM904LA 110kW, Tier3, Thermamax 1
2 550 368 85 GEARBOX + CONVERTER SECTION 10 PAGE 8 1
8 550 417 68 BRACKET 1
9 550 418 32 BRACKET 2
17 550 431 57 COVER PLATE 1
. . . . .
22 550 421 89 PLATE 1
27 449 697 70 LIFTING EYE M16 C15 DIN 580 2
28 550 429 23 CONNECTING PIECE SECTION 10 PAGE 45 1
31 550 672 95 COOLER PIPING 1
36 550 667 23 RUBBER CURVE 1
. . . . .
37 550 204 53 CLAMP 6
42 592 009 53 HOSE ASSY 1SN16MS AD-1800-JIC 1
43 592 009 55 HYDRAULIC HOSE ASSEMBLY 1SN16MS AA-1150-JIC 1
45 550 477 65 HOSE 1.5
46 550 473 55 SLEEVE PIPE 1
. . . . .
47 550 473 84 FILLING CAP 1
48 280 678 90 CLAMP Ø 50 2
50 550 801 21 WATER HOSE 1
51 550 667 24 RUBBER CURVE 1
54 550 492 66 CONNECTOR 1
. . . . .
61 551 526 30 SIGN Finger cover, Engine's blower 2
76 816 735 19 STRAIGHT THREAD ADAPTER 136-12 (R3/4XR3/4) 1
77 811 281 79 PLUG 1
78 816 708 79 SWIVEL NUT ELBOW 90 1,5/16-12 JIC 1
80 816 700 59 STRAIGHT THREAD ADAPTER 1,5/16-12 JIC 2
. . . . .
81 864 270 09 SWIVEL NUT ELBOW 45 V6X-S25 (1,5/16-12JIC) 1
87 816 767 09 STRAIGHT THREAD ADAPTER 1,5/16-12JIC 2
88 550 442 96 STRAIGHT THREAD ADAPTER M16x1,5 / JIC 3/4-16 2
98 550 442 96 STRAIGHT THREAD ADAPTER M16x1,5 / JIC 3/4-16 2
101 800 461 79 HEXAGON HEAD SCREW M10x35 m8.8 SFS 2064 7
. . . . .
109 550 473 44 STUD M10X35 m8.8 DIN 939 12
110 550 473 45 HEXAGON SOCKET HEAD SCREW UNF 3/8x1 - 1 1/4 (32mm) - 10.9 8
111 065 355 03 HEXAGON HEAD SCREW 3/4 UNC X 1 3/4 GRADE 5 8
121 284 773 10 LOCK NUT M10 DIN985 8.8ZN 15
125 284 773 10 LOCK NUT M10 DIN985 8.8ZN 15
. . . . .
140 065 814 22 WASHER 10,5/18X1,6 8
600 455 332 90 SCREW N:O 2 X 5 SMS 1549 8
*49 550 478 77 FLEX PLATE SECTION 10 PAGE 16 1
. . . . .

550 440 06 cA
7 (47) SURGE TANK ASSEMBLY 090805

e
1 550 395 18 SURGE TANK 1
7 280 675 00 CLAMP 32 SMS 2298 2
8 280 672 20 CLAMP 20 SMS 2298 5
9 550 463 07 LEVEL SWITCH DC 9-36V, M14x1.5 1
10 816 702 09 STRAIGHT THREAD ADAPTER JIC 9/16-18 1
. . . . .
11 818 891 09 FITTING 4HE 254A-6 1
12 550 448 70 HOSE 1
13 550 448 71 HOSE 1
14 550 448 72 HOSE 1
15 550 448 72 HOSE 1
. . . . .
16 800 923 29 WASHER 15 SFS 2041 1

550 368 85 b
090805 GEARBOX + CONVERTER 8 (47)

e
1 550 768 37 NSS CONVERTER HOUSING ASSEMBLY SECTION 10 PAGE 10 1
2 550 768 39 NSS TRANSMISSION CASE & COVER SECTION 10 PAGE 12 1
3 550 768 40 NSS TURBINE SHAFT ASSEMBLY SECTION 10 PAGE 14 1
4 550 478 77 FLEX PLATE SECTION 10 PAGE 16 1
5 550 768 44 NSS TORQUE CONVERTER ASSY SECTION 10 PAGE 18 1
. . . . .
6 550 768 45 NSS GEAR KIT SECTION 10 PAGE 20 1
7 550 768 51 NSS PUMP DRIVE GROUP SECTION 10 PAGE 22 1
8 550 768 53 NSS PUMP DRIVE GROUP SECTION 10 PAGE 24 1
9 550 768 54 NSS SHAFT ASSEMBLY SECTION 10 PAGE 26 1
. . . . .
11 550 768 60 NSS GEAR SECTION 10 PAGE 30 1
12 550 768 61 NSS LOW SPEED SHAFT GROUP SECTION 10 PAGE 32 1
. . . . .
16 550 768 69 NSS PUMP ASSEMBLY SECTION 10 PAGE 40 1
17 550 768 73 NSS GEAR CONTROL VALVE SECTION 10 PAGE 42 1
18 550 268 55 SEAL KIT 1

550 768 37 NSS
9 (47) CONVERTER HOUSING ASSEMBLY 090805

550 768 37 NSS
090805 CONVERTER HOUSING ASSEMBLY 10 (47)

e
1 560 079 99 CONVERTER HOUSING 1
2 046 913 90 BUSHING 2
3 046 952 90 PLUG 1
4 046 995 73 PLUG 1
5 046 912 67 SEAL 1
. . . . .
6 046 991 81 SCREW 18
7 046 991 82 WASHER 18
8 046 913 86 PIN 1
9 046 990 51 LOCK 2
10 046 991 75 SCREW 2
. . . . .
11 046 943 01 WASHER 2
12 046 995 56 BREATHER 1
13 046 971 54 PLUG INCL. PARTS 14 5
14 046 998 07 O-RING 5
15 046 913 87 PLUG 1
. . . . .
16 046 913 88 O-RING 1
17 046 913 89 SCREW 1

550 768 39 NSS
11 (47) TRANSMISSION CASE & COVER 090805

550 768 39 NSS
090805 TRANSMISSION CASE & COVER 12 (47)

e
1 560 092 63 TRANSMISSION CASE INCL. PARTS 2-9 1
2 046 913 79 PIPE 1
3 046 913 80 O-RING 1
4 046 995 81 PIPE 1
5 047 005 32 BUSHING 4
. . . . .
6 046 913 81 PIPE 1
7 046 913 82 CLAMP 1
8 046 995 92 SCREW 1
9 046 991 82 WASHER 1
10 046 971 54 PLUG INCL. PARTS 11 1
. . . . .
11 046 998 07 O-RING 1
12 046 985 92 PLUG INCL. PARTS 13 2
13 046 997 00 O-RING 2
14 046 913 83 REAR COVER INCL. PARTS 15 1
15 046 971 54 PLUG INCL. PARTS 16 1
. . . . .
16 046 998 07 O-RING 1
17 046 913 84 PLATE 1
18 046 913 85 SEAL 1
19 046 995 80 O-RING 4
20 046 993 77 O-RING 1
. . . . .
21 046 913 86 PIN 2
22 046 912 53 SCREW 20
23 046 991 82 WASHER 20
24 047 007 08 PLUG 2
25 047 008 28 PLUG 1
. . . . .
26 046 913 87 PLUG 2
27 046 913 88 O-RING 2
28 046 913 89 SCREW 2
30 046 952 19 COVER 1
31 046 998 30 GASKET 1
. . . . .
32 046 951 37 SCREW 2
33 047 004 89 WASHER 2
34 046 995 94 DIPSTICK TUBE 1
35 046 987 08 DIPSTICK 1

550 768 40 NSS
13 (47) TURBINE SHAFT ASSEMBLY 090805

550 768 40 NSS
090805 TURBINE SHAFT ASSEMBLY 14 (47)

e
1 560 080 00 TURBINE SHAFT ASSEMBLY INCL. PARTS 2 1
2 046 987 04 CIRCLIP 1
3 046 914 20 BEARING 1
4 046 957 96 SNAP RING 1
5 046 996 33 THRUST WASHER 1
. . . . .
6 047 009 05 CIRCLIP 1
7 560 010 42 PISTON RING 1
8 560 092 66 SUPPORT 1
9 046 910 93 SCREW 6
10 046 967 52 PISTON RING 1
. . . . .
11 887 828 19 BAFFLE INCL. PARTS 12 1
12 046 993 67 SEAL 1
13 884 148 19 SEAL RING 1
14 046 982 42 CIRCLIP 1

550 478 77 b
15 (47) FLEX PLATE 090805

550 478 77 b
090805 FLEX PLATE 16 (47)

e
3 550 278 70 RING 1
4 550 768 43 SCREW 6
5 550 174 91 WASHER 6

550 768 44 NSS
17 (47) TORQUE CONVERTER ASSY 090805

550 768 44 NSS
090805 TORQUE CONVERTER ASSY 18 (47)

e
1 615 088 35 TORQUE CONVERTER 1
2 046 977 03 BEARING 1
3 560 092 68 BACK UP RING 1
4 046 995 45 PLUG 1
5 046 995 44 O-RING 1
. . . . .
6 046 995 46 CIRCLIP 1
7 560 056 16 RETAINING RING 2

550 768 45 NSS
19 (47) GEAR KIT 090805

550 768 45 NSS
090805 GEAR KIT 20 (47)

e
1 046 913 94 GEAR WHEEL 1
2 550 768 46 GEAR WHEEL 1
3 550 768 47 GEAR WHEEL 1
4 560 080 14 WHEEL 1
5 550 768 49 GEAR WHEEL 1
. . . . .
6 550 768 50 GEAR WHEEL 1

550 768 51 NSS
21 (47) PUMP DRIVE GROUP 090805

550 768 51 NSS
090805 PUMP DRIVE GROUP 22 (47)

e
1 560 092 70 BEARING RETAINER 1
2 560 092 71 SCREW 1
3 560 092 72 PIN 1
4 560 092 74 BALL 1
5 046 979 64 BACKING RING 1
. . . . .
6 560 092 75 GEAR WHEEL 1
7 046 985 36 COVER 1
8 560 085 95 GASKET 1
9 046 988 65 SCREW 2
10 047 003 11 WASHER 2
. . . . .

550 768 53 NSS
23 (47) PUMP DRIVE GROUP 090805

550 768 53 NSS
090805 PUMP DRIVE GROUP 24 (47)

e
1 560 092 70 BEARING RETAINER 1
2 560 092 72 PIN 1
3 560 092 71 SCREW 1
4 560 092 74 BALL 1
5 046 979 64 BACKING RING 1
. . . . .
6 560 092 77 GEAR WHEEL 1
7 560 092 78 GEAR WHEEL 1
8 560 085 98 SHAFT 1
9 046 994 97 BALL 1
10 047 006 65 BEARING 1
. . . . .
11 046 979 62 CIRCLIP 2
12 046 996 15 RING 2

550 768 54 NSS
25 (47) SHAFT ASSEMBLY 090805

550 768 54 NSS
090805 SHAFT ASSEMBLY 26 (47)

e
1 550 768 55 SHAFT & DRUM ASSEMBLY 1
2 615 096 47 CLUTCH PISTON INCL. PARTS 3-4 1
3 046 996 62 PISTON RING 1
4 046 996 63 SEAL 1
5 046 996 65 CLUTCH DISC 8
. . . . .
6 046 996 60 CLUTCH DISC 8
7 046 996 01 BUSHING 1
8 550 768 56 END PLATE 1
9 046 996 58 RING 1
10 046 976 61 DISC SPRING KIT 1
. . . . .
11 046 995 99 RING 1
12 560 086 02 PISTON RING 2
13 046 996 11 BEARING 1
14 046 914 01 BEARING 1
15 046 996 09 RING 1
. . . . .
16 046 914 02 RETAINING RING 1
17 550 768 46 GEAR WHEEL 1

550 768 57 NSS

550 768 57 NSS

e
3 046 996 62 PISTON RING 1
4 046 996 63 SEAL 1
5 046 914 10 CLUTCH INCL. PARTS 6-7 1
. . . . .
6 046 996 62 PISTON RING 1
7 046 996 63 SEAL 1
8 046 996 65 CLUTCH DISC 8
9 046 996 65 CLUTCH DISC 6
10 046 996 60 CLUTCH DISC 8
. . . . .
11 046 996 60 CLUTCH DISC 6
12 046 996 01 BUSHING 1
13 550 768 56 END PLATE 2
14 046 996 58 RING 2
15 046 996 02 SPRING 1
. . . . .
16 046 996 03 SPRING RETAINER 1
17 046 976 61 DISC SPRING KIT 1
18 046 996 04 CIRCLIP 1
19 047 006 81 BEARING 1
20 047 006 79 BEARING 1
. . . . .
21 046 995 96 RING 2
22 046 978 95 BEARING 1
23 046 967 75 CIRCLIP 1
24 047 007 92 CIRCLIP 1
25 560 086 02 PISTON RING 3
. . . . .
26 046 995 99 RING 1
27 046 914 11 HUB 1
28 046 996 04 CIRCLIP 1
29 046 914 12 BEARING 1
30 046 914 13 STOPPER 1
. . . . .
31 046 914 14 STOPPER 1
32 046 914 15 BUSHING 1
33 046 913 94 GEAR WHEEL 1

550 768 60 NSS
29 (47) GEAR 090805

550 768 60 NSS
090805 GEAR 30 (47)

e
1 560 080 05 SHAFT 1
2 046 995 66 BEARING 1
3 046 914 04 WASHER 1
4 046 914 05 NUT 1
5 046 914 06 LOCK DEVICE 1
. . . . .
6 046 987 15 BALL 1
7 046 914 07 GEAR WHEEL 1
8 046 914 08 O-RING 1

550 768 61 NSS
31 (47) LOW SPEED SHAFT GROUP 090805

550 768 61 NSS
090805 LOW SPEED SHAFT GROUP 32 (47)

e
1 560 080 08 SHAFT ASSEMBLY 1
2 046 914 17 CLUTCH INCL. PARTS 3-4 1
3 046 996 62 PISTON RING 1
4 046 996 63 SEAL 1
5 046 996 59 CLUTCH DISC 8
. . . . .
6 046 996 60 CLUTCH DISC 8
7 550 768 56 END PLATE 1
8 046 996 58 RING 1
9 046 914 18 SPRING 1
10 046 996 04 CIRCLIP 1
. . . . .
11 046 914 19 BUSHING 1
12 886 878 59 BEARING 1
13 046 956 20 BEARING 1
14 046 981 35 CIRCLIP 2
15 046 992 38 PISTON RING 1
. . . . .
16 046 914 20 BEARING 1
17 046 914 21 BUSHING 1
18 046 914 22 BEARING 1
19 046 957 96 SNAP RING 1
20 046 914 23 SPRING 1
. . . . .
21 550 768 47 GEAR WHEEL 1

550 768 63 NSS

550 768 63 NSS

e
3 046 996 62 PISTON RING 1
4 046 996 63 SEAL 1
5 046 996 65 CLUTCH DISC 6
. . . . .
6 046 996 60 CLUTCH DISC 6
7 550 768 56 END PLATE 1
8 046 996 58 RING 1
9 046 996 02 SPRING 1
10 046 996 03 SPRING RETAINER 1
. . . . .
11 046 996 04 CIRCLIP 1
12 046 967 75 CIRCLIP 1
13 046 978 95 BEARING 1
14 047 007 92 CIRCLIP 1
15 560 086 02 PISTON RING 2
. . . . .
16 046 987 19 GEAR 1
17 046 996 06 RING 1
18 046 914 12 BEARING 1

550 768 65 NSS

550 768 65 NSS

e
1 550 768 66 GEAR SHAFT 1
2 046 914 20 BEARING 1
3 046 957 96 SNAP RING 1
4 046 914 26 BEARING 1
5 047 007 41 NUT 1
. . . . .
6 047 005 09 WASHER 1
7 046 996 56 SPACER 1
8 046 991 17 CIRCLIP 1
9 550 768 49 GEAR WHEEL 1
10 560 080 14 WHEEL 1
. . . . .

550 768 67 NSS

550 768 67 NSS

e
1 550 768 68 GEAR SHAFT 1
2 046 914 28 BEARING 1
3 046 986 43 BEARING 1
4 046 969 98 LOCK RING 1
5 047 006 64 CIRCLIP 2
. . . . .
6 046 914 29 SEAL 2
7 046 987 22 STUD 4
8 046 992 06 WASHER 4
9 046 996 46 NUT 4
10 046 914 30 BEARING 1
. . . . .
11 046 996 51 GASKET 1
12 615 096 49 SPACER RING 1
13 046 996 56 SPACER 1
14 886 881 79 O-RING 2
15 047 005 09 WASHER 2
. . . . .
16 047 007 41 NUT 2
17 550 768 50 GEAR WHEEL 1
18 046 983 12 FLANGE 1
19 046 983 12 FLANGE 1

550 768 69 NSS
39 (47) PUMP ASSEMBLY 090805

550 768 69 NSS
090805 PUMP ASSEMBLY 40 (47)

e
1 550 768 70 CHARGING PUMP 1
2 046 975 05 FILTER 1
3 852 033 49 GASKET 1
4 046 993 77 O-RING 1
5.1 550 768 71 SCREW 1
. . . . .
5.2 550 768 72 SCREW 4
6 046 991 82 WASHER 5

550 768 73 NSS
41 (47) GEAR CONTROL VALVE 090805

550 768 73 NSS
090805 GEAR CONTROL VALVE 42 (47)

e
1 550 768 74 VALVE ASSEMBLY SECTION 10 PAGE 44 1
2 550 768 75 GASKET 1
3 047 005 24 SCREW 4
4 047 004 88 SCREW 3
5 046 999 97 SCREW 2
. . . . .
6 047 004 89 WASHER 9

550 768 74
43 (47) VALVE ASSEMBLY 090805

550 768 74
090805 VALVE ASSEMBLY 44 (47)

e
1 550 770 74 SOLENOID 4
2 046 995 73 PLUG 8
3 550 770 75 VALVE BODY 1
4 550 770 76 COVER PLATE 1
5 550 770 77 SCREW 10
. . . . .
6 550 770 78 PLUG 9

550 429 23 bC
45 (47) CONNECTING PIECE / TRANSMISSION 090805

e
1 550 428 53 CONNECTING PIECE 1
2 816 703 39 SWIVEL NUT MALE ADAPTER 1,5/16-12 JIC 1
4 816 885 99 QUICK DISCONNECT FITTING 1
5 869 054 89 TEMPERATURE TRANSDUCER 1
. . . . .
6 800 987 99 CU-SEAL A14X18 CU DIN 7603 1
7 550 299 75 PLUG M14x1,5 1

550 429 20 eE
090805 CONNECTING PIECE 46 (47)

e
1 550 428 67 CONNECTING PIECE 1
2 550 431 51 SENSOR TRANSMISSION OIL PRESSURE 1
3 813 912 49 BREATHER M12X1,5 1
4 816 705 99 SWIVEL NUT MALE ADAPTER 1/4" 1
5 817 180 79 SWIVEL NUT ELBOW 90 9/16-18 JIC 1
. . . . .
7 819 561 09 SWIVEL NUT ELBOW 90 C6X-S6 (7/16-20JIC) 2
8 800 987 99 CU-SEAL A14X18 CU DIN 7603 1
9 550 299 75 PLUG M14x1,5 1

550 472 41 cC
47 (47) PUMP ASSEMBLY 090805

e
1 550 394 71 GEAR PUMP 1
1.1 550 394 60 SEAL KIT 2
4 817 163 39 ADAPTER TEE 3/4-16 JIC 2
. . . . .
5 850 778 99 PRESSURE GAUGE CONNECTOR TT4XS10 1/4" 2
6 816 885 99 QUICK DISCONNECT FITTING 2
7 818 001 09 NUT JIC 3/4-16 2
8 853 780 09 TUBE END REDUCER 9/16JIC ,3/4X 2
9 550 443 93 GASKET 1,5 mm. 1
. . . . .
10 451 335 30 HEXAGON HEAD SCREW 1/2 UNCX32 M8.8 SMS 1943 2

Engine Assembly

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Engine Assembly

Uploaded by

Copyright:

Available Formats

ENGINE ASSEMBLY

10. ENGINE ASSEMBLY

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Sandvik Mining and Construction Oy, Drills Tampere © 2009

Ref. Part no. Description EN Standard designation Qty
