Spare parts catalogue

AFT 500
Cummins

Book ID: 6-P07PV74010A002CU-EN

 AFT 500
Paver Finisher
Cummins BS III

Spare parts catalogue

Edition 06/2018 EN
From Serial No. A1N74102J18012022
Original Spare Part catalogue
Preface
 AFT 500 Preface

We congratulate you on your purchase of Ammann construction machine.

The quality of this equipment, which is characterized by its easy operation and maintenance, is
based on years of experience of Ammann in engineering. Please read the Operating manual carefully
in order to prevent any damages incurred by incorrect operation and maintenance, and keep it in
a safe place for future use.

Kind regards,
Ammann Schweiz AG
Table of contents
AFT 500 Table of contents

Article Description

001 1503923 AFT 500 Chassis Assembly

001-001 1503968 Steel Construction Assembly
001-001-001 1505062 Base Frame Assembly
001-001-001-001 1505063 Platform Back Side
001-001-001-002 1505073 Hopper Assembly
001-001-001-003 1505715 Cleaning System
001-001-001-004 1505951 Tool Box Assembly
001-001-001-005 1507436 Tractor Frame
001-001-001-006 1508182 Push Roller Assembly
001-001-001-007 1505359 Position Indicator Assy.
001-001-002 1505599 Conveyor Belt Assembly
001-001-002-001 1505287 Chain Guard Conveyor Assy.
001-001-002-002 1508185 Shaft Conveyor Assembly
001-001-002-003 1508201 Conveyor Drive Assembly
001-001-003 1505700 Feed Screw Assembly
001-001-004 1508175 Sensor Auger Assembly
001-002 1503969 Door Assembly
001-003 1503970 Engine Hood Assembly

002 1471462 AFT 500 Crawler Track Assy.

002-001 1471463 Crawler Track Assy. RH
002-002 1471464 Crawler Track Assy. LH

003 1502476 AFT 500 Engine Assembly

003-001 1471469 Fuel Tank Assy.
003-002 1507154 Engine Assembly

004 1503926 AFT 500 Hydraulic Pump Assy.

004-001 5-104032500 Hydraulic Pump Augers & Conveyor
004-002 1456170 Gear Pump
004-003 5-104032501 Hydraulic Pump Conveyor, Vibration &Tamper
004-004 1502752 Hydraulic Pump Traction Assy.
AFT 500 Table of contents

Article Description

005 1503928 AFT 500 Operating Platform

005-001 5-0270708 Hose
005-002 1508126 Driver's Seat Assy. RH
005-003 1508104 Instrument Panel Assy.
005-004 1508219 Floor Assembly
005-005 1508240 Driver's Seat Assy. LH
005-006 1469601 Rubber Pointer

006 1224314 AFT 500 Driver's Seat Assy.

007 1455172 AFT 500 Electrical kit

007-001 1456413 Console Dashboard
007-002 1456414 Electrical Panel
007-003 1518238 Harness

008 1508309 AFT 500 Hydraulic System

008-001 1505284 Hydraulic Block Assy.
008-001-001 1508004 Filter Element
008-001-002 1508007 Valve Block Assy.
008-001-003 1508021 Distributor Block Filter Assy.
008-001-004 5-104014522 Distributor Block Assy.
008-001-005 5-104014524 Hydraulic Block Reduction Assy.
008-001-006 1508057 Brake & Shaft Block Assy.
008-001-007 5-104014525 Valve Block Assy.
008-001-008 5-104014526 Valve Block Assy.
008-001-009 1508064 Valve Block Assy.
008-001-010 5-104014516 Hand Pump Assy.
008-002 1505363 Hydraulic Oil Tank Assy.
008-003 1509144 Hydraulic System Lines Assy.
008-003-001 1509104 Hydraulic Tube Assy.
008-003-002 5-104001503 Hydraulic System Rear Wall
008-003-003 1229924 Hydraulic Hose Assy.

009 5-105000000 AFT 500 Unit GP

AFT 500 Table of contents

Article Description

010 1505705 AFT 500 Filter Assy.

011 1505703 AFT 5000 Decal Assembly

012 1503930 AFT 500 Hydraulic Roof System

013 1505702 AFT 500 Auger Extension

013-001 1508162 Auger Extension

014 1519338 AFT 500 Safety Lock

015 1234862 AFT 500 Tool Kit

Spare parts catalogue
 AFT 500 Spare parts catalogue AFT 500
1450302

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Spare parts catalogue AFT 500
1450302

Pos Article Qty. Unit Description Note

1 1503923 1 ST AFT 500 Chassis Assy.
2 1471462 1 ST AFT 500 Crawler Track Assy.
3 1502476 1 ST AFT 500 Engine Assembly Assy.
4 1503926 1 ST AFT 500 Hydraulic pump Assy.
5 1503928 1 ST AFT 500 Operating platform Assy.
6 1224314 1 ST AFT 500 Driver's seat Assy.
7 1455172 1 ST AFT 500 Electrical kit Assy.
8 1508309 1 ST AFT 500 Hydraulic system Assy.
9 5-105000000 1 ST AFT 500 Unit GP Assy.
10 1505705 1 ST AFT 500 Operating material Assy.
11 1505703 1 ST AFT 500 Decal Assy.
12 1503930 1 ST AFT 500 Hydraulic roof Assy.
13 1505702 1 ST AFT 500 Auger extension Assy.
14 1519338 1 ST AFT 500 Safety lock for Screed Assy.
15 1234862 1 ST AFT 500 Tool Kit

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Chassis Assembly

001 1503923

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Chassis Assembly

001 1503923

Pos Article Qty. Unit Description Note

1 1503968 1 ST Steel construction assembly
2 1503969 1 ST Door assembly
3 1503970 1 ST Engine hood assembly

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Steel Construction assembly

001-001 1503968

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Steel Construction assembly

001-001 1503968

Pos Article Qty. Unit Description Note

0 1503968 1 ST Steel construction assembly
001-001-001 1505062 1 ST Base frame assembly
001-001-002 1505599 1 ST Conveyor belt assembly
001-001-003 1505700 1 ST Feed screw assembly
001-001-004 1508175 1 ST Sensor auger assembly

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Base frame assembly

001-001-001 1505062

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Base frame assembly

001-001-001 1505062

Pos Article Qty. Unit Description Note

0 1505062 1 ST Base frame assembly
1 5-104021000 1 ST Guide rod assy.
2 1183536 2 ST Hydraulic cylinder assy.
3 5-101009019 2 ST Hydraulic cylinder
4 5-0390006 4 ST Connector
5 5-101040012 8 ST Hex screw
6 1505084 1 ST Battery box assembly
7 1505085 1 ST Battery holder
8 1480931 22 ST Spring washer
9 1480660 4 ST Hex screw
10 1473757 1 ST Countersunk screw
11 1473859 9 ST Hexagon nut
12 1480658 17 ST Hex screw
13 1480922 21 ST Washer
14 1473836 7 ST Washer
15 1505950 2 ST Cover plate
16 5-101001035 3 ST Support oil motor drain
17 1481846 2 ST Hex screw
18 1313065 1 ST Rubber
19 1505132 2 ST Plate
20 1473608 12 ST Socket head screw
21 1505133 2 ST Plate
22 1508078 1 ST Mounting plate
23 1510713 2 ST Plate
24 1510712 1 ST Plate
25 5-104001502 2 ST Hydraulic cylinder assembly
26 5-104001002 2 ST Hydraulic cylinder
27 5-0390004 2 ST Connector
28 5-104001026 2 ST Connector
29 1480653 2 ST Hex Screw
30 1480921 2 ST Washer
31 1480903 2 ST Hex nut

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Platform back side assy.

001-001-001-001 1505063

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Platform back side assy.

001-001-001-001 1505063

Pos Article Qty. Unit Description Note

0 1505063 1 ST Platform back side assy.
1 1471468 1 ST Foot plate
2 1480932 4 ST Spring washer
3 1480717 6 ST Hex screw
4 1480936 6 ST Spring washer
5 5-104007016 1 ST Foot board
6 1480675 3 ST Hex screw
7 1480923 8 ST Washer
8 1480906 4 ST Hexagon nut
9 1510437 1 ST Plate
10 1510439 1 ST Bracket gas cylinder
11 1510462 1 ST Plate
12 1510464 1 ST Plate
13 1510465 1 ST Plate
14 1480658 2 ST Hex screw
15 1480922 6 ST Washer
16 1480904 2 ST Hexagon nut
17 1480660 2 ST Hex screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hopper assembly

001-001-001-002 1505073

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hopper assembly

001-001-001-002 1505073

Pos Article Qty. Unit Description Note

0 1505073 1 ST Hopper Assembly
1 1480935 6 ST Spring washer
2 5-104017005 4 ST Shoulder bolt
3 1480925 10 ST Plain washer
4 1473519 6 ST Hex screw
5 1480680 6 ST Hex screw
6 1480748 2 ST Hex screw
7 1480932 31 ST Spring washer
8 1480923 21 ST Washer
9 1480687 2 ST Hex screw
10 1480933 2 ST Spring washer
11 5-101003014 2 ST Fixing pin
12 5-101003015 2 ST Journal
13 1480931 4 ST Spring washer
14 1480658 4 ST Hex screw
15 1507385 1 ST Material bunker RH For RH
1507374 1 ST Material bunker LH For LH
16 5-105002002 4 ST Straight pin
17 1505081 1 ST Fixture hopper holder RH For RH
1505080 1 ST Fixture hopper holder LH For LH
18 5-104002006 2 ST Flat plate
19 5-104034001 1 ST Protection plate
20 5-104034005 2 ST Pintle bunker
21 5-104034011 1 ST Rod flap
22 1471452 2 ST Housing
23 5-105014001 8 ST Spacer element
24 5-104072503 1 ST Hydraulic cylinder assembly
25 5-104034006 2 ST Hydraulic cylinder bunker
26 5-0390003 2 ST Connector
27 5-104072502 1 ST Hydraulic cylinder assembly
28 5-0390535 2 ST Connector
29 5-105018502 2 ST Hydraulic cylinder assembly
30 5-105018001 2 ST Hydraulic cylinder
31 5-0390506 4 ST Connector

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cleaning system assy.

001-001-001-003 1505715

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cleaning system assy.

001-001-001-003 1505715

Pos Article Qty. Unit Description Note

0 1505715 1 ST Cleaning system assy.
1 5-0390086 1 ST Connector
2 1469604 1 ST Copper washer
3 1451567 1 ST Spray gun
4 1505100 1 ST Plate
5 1480922 16 ST Washer
6 1473859 8 ST Hexagon nut
7 1480661 4 ST Hex screw
8 5-0390554 1 ST Elbow
9 1473856 4 ST Spring washer
10 5-0390041 1 ST Connector
11 5-0520316 1 ST Hose
12 5-0521046 1 ST Hose
13 1473591 4 ST Head screw
14 1473830 4 ST Plain washer
15 1505713 1 ST Cleaning agent tank assembly
16 1475971 1 ST Diesel tank cap with lock
17 5-0490021 1 ST Screw plug
18 1469702 1 ST Copper washer
19 1480931 4 ST Spring washer
20 5-0490401 1 ST Filling level indicator transparent
21 1508112 1 ST Cleaning unit tank
22 1455527 1 ST Nipple
23 1456304 1 ST Suction strainer
24 1469597 1 ST Copper washer
25 1480660 4 ST Hex screw
26 1455435 1 ST Connector
27 1451331 1 ST Hose reel
28 1456171 1 ST Flow jet pump
29 1397519 1 ST Cover
30 1456605 1 ST O-ring
31 1-954070 1 ST Copper ring
32 1480673 4 ST Hex screw
33 1480932 4 ST Lock washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Tool box assy.

001-001-001-004 1505951

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Tool box assy.

001-001-001-004 1505951

Pos Article Qty. Unit Description Note

0 1505951 1 ST Tool box assy.
1 1473812 16 ST Hexagon nut
2 5-0190800 1 ST Lock
3 1480931 8 ST Spring washer
4 1480922 12 ST Washer
5 1481846 4 ST Hex screw
6 1480660 4 ST Hex screw
7 1473859 4 ST Hexagon nut
8 5-0190718 4 ST Hinge
9 1473834 16 ST Washer
10 1505107 1 ST Plate

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Frame tractor unit

001-001-001-005 1507436

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Frame tractor unit

001-001-001-005 1507436

Pos Article Qty. Unit Description Note

1 1507436 1 ST Frame tractor unit

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Push roller assembly

001-001-001-006 1508182

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Push roller assembly

001-001-001-006 1508182

Pos Article Qty. Unit Description Note

0 1508182 1 ST Push roller assembly
1 5-104051001 1 ST Compensation device
2 5-104051002 1 ST Pin
3 5-104050011 1 ST Serrated lock washer
4 1473517 2 ST Hex screw
5 1505813 1 ST Roller assembly RH
1505812 1 ST Roller assembly LH
6 5-104051007 4 ST Fixture Rolle
7 5-104051003 2 ST Drum
8 5-104051006 2 ST Scraper Rolle
9 5-104051004 2 ST Shaft
10 1480778 4 ST Set screw
11 1473530 4 ST Hex screw
12 1480926 8 ST Washer
13 1480946 8 ST Hexagon nut
14 1480669 4 ST Hex screw
15 1480923 4 ST Washer
16 1480854 4 ST Countersunk screw
17 5-101004005 4 ST Washer
18 5-0110007 4 ST Bearings
19 1415994 1 ST Fixture
20 1480739 6 ST Hex screw
21 1473846 6 ST Washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Position indicator assembly

001-001-001-007 1505359

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Position indicator assembly

001-001-001-007 1505359

Pos Article Qty. Unit Description Note

0 1505359 1 ST Position indicator assembly
1 5-104001027 2 ST Straight pin
2 1470291 4 ST Hexagon nut
3 1507316 1 ST Fixture displays fitting right
4 1507397 1 ST Fixture displays support RH
5 1223109 1 ST Blind rivet nut
6 1507398 1 ST Fixture displays fitting left
7 1507399 1 ST Fixture displays support LH
8 1480931 6 ST Spring washer
9 5-101001027 2 ST Plate scale
10 5-0110703 2 ST Pin
11 5-104001032 2 ST Spacer
12 5-104001501 2 ST Hydraulic cylinder assy.
13 5-104001001 2 ST Hydraulic cylinder
14 5-103001024 4 ST Connector
15 5-0390003 2 ST Connector
16 5-0150501 2 ST Hydraulic block
17 5-0390536 2 ST Connector
18 1508111 1 ST Connecting rod toe arm right
19 1508110 1 ST Connecting rod toe arm left
20 5-104001010 4 ST Washer
21 5-103001013 2 ST Round
22 1480650 2 ST Hex screw
23 1272961 2 ST Rod
24 1272939 2 ST Pipe
25 1272960 2 ST Round
26 1480675 2 ST Hex screw
27 1480942 2 ST Hexagon nut
28 1480660 6 ST Hex screw
29 5-0140100 6 ST Blind rivet

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Conveyor belt assembly

001-001-002 1505599

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Conveyor belt assembly

001-001-002 1505599

Pos Article Qty. Unit Description Note

0 1505599 1 ST Conveyor belt assembly
1 1505952 4 ST Carrier chain
2 1480933 16 ST Spring washer
3 1480689 16 ST Hex screw
4 1470304 2 ST Conveyor chain

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Chain guard Conveyor Assy.

001-001-002-001 1505287

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Chain guard Conveyor Assy.

001-001-002-001 1505287

Pos Article Qty. Unit Description Note

0 1505287 1 ST Chain guard conveyor assembly
1 1507472 2 ST Wear plate
2 1507473 2 ST Wear plate
3 5-104006026 1 ST Guard
4 5-104006027 1 ST Guard
5 5-104006028 1 ST Guard
6 5-104006029 1 ST Guard
7 5-104006030 1 ST Guard
8 5-104006031 1 ST Guard
9 1505135 2 ST Plate
10 1473767 36 ST Countersunk screw
11 1480923 36 ST Washer
12 1480932 36 ST Spring washer
13 1480906 36 ST Hexagon nut
14 1480924 26 ST Washer
15 1480689 12 ST Hex screw
16 1480695 14 ST Hex screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Shaft conveyor assembly

001-001-002-002 1508185

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Shaft conveyor assembly

001-001-002-002 1508185

Pos Article Qty. Unit Description Note

0 1508185 1 ST Shaft Conveyor Assembly
1 5-104006012 2 ST Shaft
2 1507471 4 ST Fixture Shaft Front
3 5-104006500 4 ST Toothed wheel
4 5-104006023 8 ST Washer
5 5-104006022 4 ST Toothed wheel
6 5-0110007 4 ST Grooved ball bearing
7 5-104006013 2 ST Spacer element intern
8 5-104006014 2 ST Spacer element extern
9 5-104006015 2 ST Serrated lock washer
10 5-104006034 1 ST Holding plate
11 5-104006036 4 ST Washer
12 1480933 4 ST Spring washer
13 1480689 1 ST Hex screw
14 1480702 1 ST Hex screw
15 1470291 4 ST Hexagon nut
16 1480687 2 ST Hex screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Conveyor drive assembly

001-001-002-003 1508201

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Conveyor drive assembly

001-001-002-003 1508201

Pos Article Qty. Unit Description Note

0 1508201 1 ST Conveyor drive assembly
1 5-104006001 2 ST Drive shaft
2 5-104006004 2 ST Rim
3 5-104009021 2 ST Fixture hydraulic motor
4 1222993 1 ST Bearing support gp conveyor
5 5-104006007 1 ST Holder
6 5-0110017 2 ST Ball bearing
7 5-104006008 2 ST Cap
8 5-0230003 2 ST Seal
9 1480932 8 ST Spring washer
10 1480671 8 ST Hex screw
11 1473518 12 ST Hex screw
12 1480910 4 ST Hexagon nut
13 1480925 12 ST Washer plain
14 5-104006024 1 ST Reduction
15 1469703 5 ST Washer copper
16 1508200 2 ST Fluid motor assembly
17 5-0330023 2 ST Fluid motor
18 5-0390013 4 ST Screwed connection
19 1480693 8 ST Hex screw
20 1480924 8 ST Washer
21 1480933 16 ST Spring washer
22 5-104006005 2 ST Pinion
23 5-0110026 3 ST Ball-bearing
24 5-0070009 2 ST Roller chain
25 5-0190006 2 ST Feather key
26 1473838 8 ST Washer
27 1480695 8 ST Hex screw
28 1480705 2 ST Hex screw
29 1480908 2 ST Hexagon nut
30 J903533 2 ST Circlip
31 1222980 2 ST Flange gp conveyor
32 5-0110504 2 ST Fixture
33 1471090 2 ST Hollow screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Conveyor drive assembly

001-001-002-003 1508201

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Conveyor drive assembly

001-001-002-003 1508201

Pos Article Qty. Unit Description Note

34 1480935 8 ST Spring washer
35 1470280 2 ST Circlip external
36 1470272 1 ST Circlip internal

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Feed screw assy.

001-001-003 1505700

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Feed screw assy.

001-001-003 1505700

Pos Article Qty. Unit Description Note

0 1505700 1 ST Feed screw assembly
1 5-104009001 1 ST Crosshead
2 1507294 1 ST Bracket external left feed screw
3 5-104009002 1 ST Gear housing assembly
4 1507295 1 ST Bracket external right feed screw
5 5-104033002 2 ST Fixture lager
6 5-104033001 2 ST Screw shaft
7 5-104033003 2 ST Guard lager
8 1-903861 2 ST Feather key
9 5-104009006 2 ST Rim
10 5-0230039 2 ST Seal
11 5-104009012 1 ST Auger element RH
12 5-104009014 1 ST End fitting rechts
13 5-104009015 1 ST End fitting links
14 5-104009018 2 ST Spacer element
15 5-104009013 1 ST Auger element
16 5-104009010 5 ST Auger element
17 5-104009011 5 ST Auger element
18 5-0230040 6 ST Laminar sealing ring
19 5-104009019 2 ST Cover
20 5-104009020 2 ST Cover frontal
21 5-0360401 2 ST Greasing nipple
22 5-104009026 1 ST Guard
23 5-104009027 1 ST Guard
24 1473522 28 ST Hex screw
25 1480739 4 ST Hex screw
26 1480799 20 ST Cyl head screw
27 5-104009024 2 ST Plate
28 1480908 2 ST Hexagon nut
29 1507296 2 ST Guide cross member
30 1507297 2 ST Guide traverse central screw
31 1480935 14 ST Spring washer
32 1480910 28 ST Hexagon nut
33 1480930 20 ST Spring washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Feed screw assy.

001-001-003 1505700

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Feed screw assy.

001-001-003 1505700

Pos Article Qty. Unit Description Note

34 1480651 20 St Hex screw
35 1473846 4 St Washer
36 1480925 32 St Washer plain
37 1480669 8 St Hex screw
38 1480932 28 St Spring washer
39 1480923 8 St Washer
40 1469885 4 St Blind rivet
41 1473520 6 St Hex screw
42 1473521 4 St Hex screw
43 1473506 2 St Hex screw
44 1480924 10 St Washer
45 1473518 4 St Hex screw
46 1223918 1 St Drive gp R augers
47 5-104009021 2 St Fixture hydraulic motor
48 5-0110025 2 St Ball-bearing
49 5-104009005 2 St Pinion
50 J903533 2 St Circlip
51 5-104033501 1 St Fluid motor gp R augers
52 5-0330053 2 St Fluid motor
53 1480933 8 St Spring washer
54 5-0390013 4 St Screwed connection
55 5-0390004 2 St Screwed connection
56 1480802 8 St Cyl head screw
57 1480693 8 St Hex screw
58 1480933 8 St Spring washer
59 1473838 8 St Washer
60 1470272 2 St Circlip internal
61 1223916 1 St Drive gp L augers
62 5-104033502 1 St Fluid motor gp L augers
63 5-0390549 1 St L-connection bar
64 5-0110037 2 St Ball-bearing
65 1508098 2 St Fixture
66 5-104033007 2 St Spacer element
67 5-104033004 2 St Holder

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Feed screw assy.

001-001-003 1505700

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Feed screw assy.

001-001-003 1505700

Pos Article Qty. Unit Description Note

68 5-104033005 2 ST Cap
69 5-104033006 2 ST Spacer element
70 1280817 2 ST Roller chain gp augers
71 5-0120024 2 ST Nut
72 1479467 2 ST Circlip external

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Sensor auger assembly

001-001-004 1508175

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Sensor auger assembly

001-001-004 1508175

Pos Article Qty. Unit Description Note

0 1508175 1 ST Sensor auger assembly
1 5-101025002 1 ST Holder for sensor left
2 5-101025001 1 ST Holder for sensor right
3 1508099 2 ST Lever
4 5-104024002 2 ST Shovel
5 1480658 4 ST Hex screw
6 1480922 2 ST Washer
7 1480651 2 ST Hex screw
8 1473590 8 ST Cyl head screw
9 1480903 2 ST Hexagon nut
10 1480931 4 ST Spring washer
11 1230476 2 ST Support for spring
12 1473481 2 ST Hex screw
13 1473830 8 ST Washer plain
14 1473836 6 ST Washer
15 1473859 2 ST Hexagon nut
16 5-104024003 1 ST Spring torsion right
17 5-104024004 1 ST Spring torsion left

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Door assembly

001-002 1503969

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Door assembly

001-002 1503969

Pos Article Qty. Unit Description Note

0 1503969 1 ST Door assembly
1 1507298 1 ST Door fix LH
2 1507320 1 ST Door fix RH
3 1505924 1 ST Flap plate LH
4 5-101001020 4 ST Hinge blank
5 1505925 1 ST Flap plate RH
6 5-104001018 1 ST End plate
7 2-80236353 2 ST Lock
8 5-104001035 1 ST End plate hinten rechts
9 1480847 4 ST Countersunk screw
10 1480922 24 ST Washer
11 1480931 42 ST Spring washer
12 1480658 24 ST Hex screw
13 1473481 6 ST Hex screw
14 1480668 2 ST Hex screw
15 1481846 8 ST Hex screw
16 1473836 8 ST Washer
17 5-101001047 2 ST Protection plate
18 1480904 2 ST Hexagon nut
19 5-104028013 1 ST Metal cover
20 5-105001004 2 ST Lateral rib
21 5-102020002 2 ST Plate
22 5-102020003 2 ST Plate
23 1480921 20 ST Washer
24 1480903 10 ST Hexagon nut
25 1480651 10 ST Hex screw
26 1469885 10 ST Blind rivet
27 1473859 2 ST Hexagon nut
28 1291669 1 ST Plate
29 1291664 1 ST Plate
30 1505364 1 ST Housing chain conveyor LH
31 1505858 1 ST Housing chain conveyor RH
32 1520878 1 ST Heat insulation right panel
33 1520879 1 ST Heat insulation left panel
34 1470353 1 ST Heat insulation

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine hood assy.

001-003 1503970_1

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine hood assy.

001-003 1503970_1

Pos Article Qty. Unit Description Note

0 1503970 1 ST Engine hood assy.
1 1505348 1 ST Bonnet top cover assly.
2 1508141 1 ST Engine hood
3 1480931 12 ST Spring washer
4 1480660 8 ST Hex screw
5 5-0190705 1 ST Lock
6 1473476 4 ST Hex screw
7 1480930 30 ST Spring washer
8 1473864 4 ST Hexagon nut
9 1480904 8 ST Hexagon nut
10 1480658 8 ST Hex screw
11 1509616 1 ST Perforated sheet assly.
12 1422826 1 ST Plate
13 1473857 48 ST Spring washer
14 1473469 48 ST Hex screw
15 1505882 1 ST Side cover assly.
16 1422824 1 ST Plate
17 1505881 1 ST Silencer mount bracket
18 1505214 1 ST Plate
19 1505215 1 ST Plate
20 1480922 6 ST Washer
21 1505880 1 ST Top cover with logo assly.
22 1480903 9 ST Hexagon nut
23 1178978 1 ST Company logo
24 5-0130983 3 ST Pan head forming screw
25 1481845 9 ST Hex screw
26 1505879 1 ST Top door assly.
27 1508142 1 ST Engine hood opening complete
28 1195797 2 ST Hinge extra strong
29 1309167 2 ST Heat insulation
30 1294626 1 ST Lock
31 5-0190708 4 ST Gasket
32 1480651 4 ST Hex screw
33 1313713 1 ST Ammann logo

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine hood assy.

001-003 1503970_1

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine hood assy.

001-003 1503970_1

Pos Article Qty. Unit Description Note

34 1308813 1 ST Heat insulation
35 1422682 1 ST Heat protection
36 1308661 2 ST Heat insulation

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine hood assy.

001-003 1503970_2

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine hood assy.

001-003 1503970_2

Pos Article Qty. Unit Description Note

1 1505289 1 ST Bonnet mount support assly.
2 1471437 1 ST Mounting plate
3 1473766 2 ST Countersunk screw
4 1480933 4 ST Spring washer
5 1480908 2 ST Hexagon nut
6 1480689 2 ST Hex screw
7 1480922 14 ST Washer
8 1513150 1 ST Connector plate
9 1512913 1 ST Plate
10 1480669 4 ST Hex screw
11 1480906 4 ST Hexagon nut
12 1480931 6 ST Spring washer
13 1480904 6 ST Hexagon nut
14 1505269 1 ST Back side door assly.
15 1422685 2 ST Cover rear
16 1308642 2 ST Heat protection
17 5-0190807 4 ST Lock
18 1197611 2 ST Handle
19 5-0190708 4 ST Gasket
20 1480651 8 ST Hex screw
21 1480921 16 ST Washer
22 1473864 8 ST Hexagon nut
23 1473830 4 ST Plain washer
24 1473813 4 ST Hexagon nut
25 1473754 4 ST Countersunk screw
26 1505877 1 ST Back side door assly.
27 1505859 1 ST Cover assly.
28 5-0190718 2 ST Hinge
29 1473833 8 ST Plain washer
30 5-0190800 1 ST Lock
31 1473812 8 ST Hexagon nut
32 1505347 1 ST Gas pressure spring assly.
33 1451464 2 ST Gas pressure spring

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine hood assy.

001-003 1503970_2

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine hood assy.

001-003 1503970_2

Pos Article Qty. Unit Description Note

34 1196028 4 ST Washer
35 1473859 4 ST Hexagon nut
36 1480664 2 ST Hex screw
37 1505876 1 ST Clamp assly.
38 1308687 1 ST Plate
39 1480658 6 ST Hex screw
40 1521755 1 ST Pre cleaner bracket
41 1308648 1 ST Heat insulation
42 1308645 2 ST Heat insulation

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Crawler Track Assy.

002 1471462

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Crawler Track Assy.

002 1471462

Pos Article Qty. Unit Description Note

1 1471463 1 ST Crawler track assy. RH
2 1471464 1 ST Crawler track assy. LH

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Crawler track assy. RH
002-001 1471463

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Crawler track assy. RH
002-001 1471463

Pos Article Qty. Unit Description Note

0 1471463 1 ST Crawler track assy. RH
1 5-0140900 2 ST Spring pin
2 5-102006009 1 ST Cover
3 5-103005012 1 ST Fixing device
4 5-102006013 2 ST Spacer element
5 5-102006014 2 ST Washer
6 5-102006008 2 ST Carrier
7 1480925 2 ST Washer plain
8 1480926 52 ST Washer
9 1480924 1 ST Washer
10 1480697 1 ST Hex screw
11 1473823 1 ST Hexagon nut
12 1480923 6 ST Washer
13 1480942 3 ST Hexagon nut
14 1480660 4 ST Hex screw
15 1473849 2 ST Washer
16 1473846 16 ST Washer
17 1471465 1 ST Crawler frame RH
18 5-105006002 1 ST Rim
19 5-105006003 1 ST Wheel
20 5-105006004 1 ST Bearing journal rad
21 5-105006005 2 ST Carrier
22 5-105006006 2 ST Spacer element
23 5-105006007 1 ST Pressure plate
24 5-0230031 2 ST Seal oil
25 1469611 1 ST Greasing nipple
26 5-0110027 2 ST Bearing
27 1471467 1 ST Stripper plate RH
28 5-105006010 1 ST Scraper
29 5-105006011 1 ST Flat
30 5-0070603 9 ST Drum
31 1473520 2 ST Hex screw
32 1480724 52 ST Hex screw
33 1473493 3 ST Hex screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Crawler track assy. RH
002-001 1471463

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Crawler track assy. RH
002-001 1471463

Pos Article Qty. Unit Description Note

34 1480939 2 ST Spring washer
35 1480757 2 ST Hex screw
36 1480742 16 ST Hex screw
37 1508144 1 ST Propulsion engine
38 5-0410520 1 ST Drive
39 5-0230038 1 ST O-ring
40 5-0420097 1 ST Sensor
41 5-0330026 1 ST Engine
42 5-0410012 1 ST Gearbox
43 1480675 8 ST Hex screw
44 1480932 8 ST Spring washer
45 1456592 2 ST O-ring
46 5-0390059 2 ST Connector
47 5-0390021 1 ST Connector
48 5-0390030 1 ST Connector
49 4-5160580016 4 ST Semi-flange
50 1480931 4 ST Spring washer
51 1480729 1 ST Hex screw
52 1273381 1 ST Crawler track
53 1451098 1 ST Accumulator
54 5-105006510 1 ST Piston
55 5-105006008 42 ST Rubber track
56 1403179 168 ST Screw
57 1403250 168 ST Nut
58 1469702 3 ST Copper washer
59 1455417 1 ST Connector
60 5-0390400 1 ST Adaptor
61 1267764 1 ST Grease valve
62 5-0070610 1 ST Copper washer

© Ammann Schweiz AG, www.ammann-group.com

1 Crawler track assy. LH
AFT 500

002-002 1471464

© Ammann Schweiz AG, www.ammann-group.com

1 Crawler track assy. LH
AFT 500

002-002 1471464

Pos Article Qty. Unit Description Note

0 1471464 1 ST Crawler track assy. RH
1 5-0140900 2 ST Spring pin
2 5-102006009 1 ST Cover
3 5-103005012 1 ST Fixing device
4 5-102006013 2 ST Spacer element
5 5-102006014 2 ST Washer
6 5-102006008 2 ST Carrier
7 1480925 2 ST Washer plain
8 1480926 52 ST Washer
9 1480924 1 ST Washer
10 1480697 1 ST Hex screw
11 1473823 1 ST Hexagon nut
12 1480923 6 ST Washer
13 1480942 3 ST Hexagon nut
14 1480660 4 ST Hex screw
15 1473849 2 ST Washer
16 1473846 16 ST Washer
17 1471466 1 ST Crawler frame LH
18 5-105006002 1 ST Rim
19 5-105006003 1 ST Wheel
20 5-105006004 1 ST Bearing journal rad
21 5-105006005 2 ST Carrier
22 5-105006006 2 ST Spacer element
23 5-105006007 1 ST Pressure plate
24 5-0230031 2 ST Seal oil
25 1469611 1 ST Greasing nipple
26 5-0110027 2 ST Bearing
27 1507247 1 ST Stripper plate LH
28 5-105006010 1 ST Scraper
29 5-105006011 1 ST Flat
30 5-0070603 9 ST Drum
31 1473520 2 ST Hex screw
32 1480724 52 ST Hex screw
33 1473493 3 ST Hex screw

© Ammann Schweiz AG, www.ammann-group.com

1 Crawler track assy. LH
AFT 500

002-002 1471464

© Ammann Schweiz AG, www.ammann-group.com

1 Crawler track assy. LH
AFT 500

002-002 1471464

Pos Article Qty. Unit Description Note

34 1480939 2 ST Spring washer
35 1480757 2 ST Hex screw
36 1480742 16 ST Hex screw
37 1508144 1 ST Propulsion engine
38 5-0410520 1 ST Drive
39 5-0230038 1 ST O-ring
40 5-0420097 1 ST Sensor
41 5-0330026 1 ST Engine
42 5-0410012 1 ST Gearbox
43 1480675 8 ST Hex screw
44 1480932 8 ST Spring washer
45 1456592 2 ST O-ring
46 5-0390059 2 ST Connector
47 5-0390021 1 ST Connector
48 5-0390030 1 ST Connector
49 4-5160580016 4 ST Semi-flange
50 1480931 4 ST Spring washer
51 1480729 1 ST Hex screw
52 1273381 1 ST Crawler track
53 1451098 1 ST Accumulator
54 5-105006510 1 ST Piston
55 5-105006008 42 ST Rubber track
56 1403179 168 ST Screw
57 1403250 168 ST Nut
58 1469702 3 ST Copper washer
59 1455417 1 ST Connector
60 5-0390400 1 ST Adaptor
61 1267764 1 ST Grease valve
62 5-0070610 1 ST Copper washer

© Ammann Schweiz AG, www.ammann-group.com

1 AFT 500 Engine Assy.
AFT 500

003 1502476

© Ammann Schweiz AG, www.ammann-group.com

1 AFT 500 Engine Assy.
AFT 500

003 1502476

Pos Article Qty. Unit Description Note

1 1471469 1 ST Fuel tank Assy.
2 1507154 1 ST Engine Assembly

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Fuel tank assy.

003-001 1471469

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Fuel tank assy.

003-001 1471469

Pos Article Qty. Unit Description Note

0 1471469 1 ST Fuel tank assly.
1 1518964 1 ST Filler neck fuel tank
2 5-0270400B 1 ST Hose
3 5-0160013 2 ST Hose clip
4 1475971 1 ST Tank cap
5 1480942 6 ST Hexagon nut
6 1480671 2 ST Hex screw
7 1480676 4 ST Hex screw
8 1480923 12 ST Washer
9 1471430 1 ST Fuel tank assy.
10 J906943 2 ST Sealing ring
11 5-0390041 1 ST Screwed connection
12 5-0390078 1 ST Screwed connection
13 5-0490402 1 ST Filling level indicator
14 5-0490003 1 ST Sealing plug
15 1456605 2 ST O-ring
16 1469836 2 ST Washer copper
17 5-0420464 1 ST Float
18 1473469 5 ST Hex screw
19 1471431 1 ST Fuel tank
20 1397519 2 ST Cover
21 1473767 8 ST Countersunk screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine assembly

003-002 1507154

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine assembly

003-002 1507154

Pos Article Qty. Unit Description Note

0 1507154 1 ST Engine Assly.
1 1508148 1 ST Pump Distribution Gearbox
2 1450978 1 ST Diesel Engine
3 1507156 1 ST Engine Mounting Skid
4 5-0030025 4 ST Oscillation Absorber
5 1471445 2 ST Bracket
6 1455768 1 ST Connection
7 1455769 1 ST Connection
8 1514199 1 ST Hydraulic Hose
9 4-5160680169 1 ST Hollow Screw
10 1327264 2 ST Sealing Ring
11 5-0390345 2 ST Screwed Connection
12 1480702 8 ST Hex Screw
13 1480673 12 ST Hex Screw
14 1473713 8 ST Hex Screw
15 1480932 28 ST Spring Washer
16 1480693 8 ST Hex Screw
17 1480739 1 ST Hex Screw
18 1480937 1 ST Spring Washer
19 1473846 1 ST Washer
20 1473503 4 ST Hex Screw
21 5-0390093 1 ST Screw-In Fitting
22 5-0520535 1 ST Hydraulic Hose
23 1480671 8 ST Hex Screw
24 1480933 21 ST Spring Washer
25 1473475 3 ST Hex Screw
26 1480930 5 ST Spring Washer
27 4-3170200130 5 ST Washer
28 1473878 5 ST Hexagon Nut
29 1480661 1 ST Hex Screw
30 1480931 1 ST Spring Washer
31 1480865 1 ST Hexagon Nut
32 1529991 1 ST Plate
33 1480815 4 ST Cyl Head Screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine assembly

003-002 1507154

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine assembly

003-002 1507154

Pos Article Qty. Unit Description Note

34 1481871 4 ST Spring Washer
35 1472031 2 ST Connectors
36 1530063 1 ST Support Plate
37 1530210 1 ST Throttle Cable Bracket
38 1480653 2 ST Hex Screw
39 1480921 2 ST Washer
40 1480687 1 ST Hex Screw
41 1480695 2 ST Hex Screw
42 1480933 2 ST Spring Washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine assembly

003-002 1507154_2

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine assembly

003-002 1507154_2

Pos Article Qty. Unit Description Note

1 1507155 1 ST Air Intake System
2 1471432 1 ST Bracket Air Filter
3 1450985 1 ST Hose Air Intake
4 1450958 1 ST Pre-Cleaner Connection Hose
5 1480669 4 ST Hex Screw
6 1480906 4 ST Hexagon Nut
7 1480932 4 ST Spring Washer
8 1473503 2 ST Hex Screw
9 1480933 2 ST Spring Washer
10 1457041 3 ST Tb Hose Clamp Spring Loaded
11 1450995 1 ST Tb Hose Clamp Spring Loaded
12 1505288 1 ST Exhaust System
13 1450981 1 ST Exhaust Connection Pipe
14 1450980 1 ST Silencer
15 1450982 1 ST Exhaust Pipe
16 1450957 1 ST Silencer Clamp
17 1475979 4 ST Rubber Foundation Pad
18 1480904 8 ST Hexagon Nut
19 1480931 8 ST Spring Washer
20 1473836 8 ST Washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine assembly

003-002 1507154_3

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Engine assembly

003-002 1507154_3

Pos Article Qty. Unit Description Note

1 1505290 1 ST Cooling System Assembly
2 1450979 1 ST Combi Cooler
3 1450988 3 ST Hose Coupling CAC
4 1450983 1 ST Hose Radiator Inlet
5 1450984 1 ST Hose Radiator Outlet
6 1450987 1 ST CAC Outlet Pipe
7 1450986 1 ST CAC Inlet Pipe
8 1450989 1 ST Hose CAC
9 1450956 1 ST Axial Flow Fan With Blex
10 1450959 1 ST Spacer Fan Mounting
11 1471450 1 ST Support Roc LH
12 1471429 1 ST Support Roc RH
13 1457031 8 ST Tb Hose Clamp Spring Loaded
14 1450994 1 ST Tb Hose Clamp Spring Loaded
15 1457033 1 ST Tb Hose Clamp Spring Loaded
16 1457036 2 ST Tb Hose Clamp Spring Loaded
17 1450997 2 ST Warm Drive Clamp
18 1450998 2 ST Warm Drive Clamp
19 1473715 4 ST Hex Screw
20 1480933 15 ST Spring Washer
21 1480924 15 ST Washer
22 1480695 4 ST Hex Screw
23 1480908 7 ST Hexagon Nut
24 1473508 3 ST Hex Screw
25 5-0030011 3 ST Rubber Cushion
26 1473498 4 ST Hex Screw
27 1450960 1 ST Hose
28 1450961 1 ST Hose
29 1480922 4 ST Washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Hydraulic pump assy.

004 1503926

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Hydraulic pump assy.

004 1503926

Pos Article Qty. Unit Description Note

1 5-104032500 1 ST Hydraulic pump augers & conveyor assy.
2 1456170 1 ST Gear pump
3 5-104032501 1 ST Hydraulic pump conveyor, vibrator & tamper assy.
4 1502752 1 ST Hydraulic pump traction assy.

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic pump augers & conveyor assy.

004-001 5-104032500

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic pump augers & conveyor assy.

004-001 5-104032500

Pos Article Qty. Unit Description Note

0 5-104032500 1 ST Hydraulic pump augers &conveyor afx500
1 5-0390010 3 ST Connector
2 1480923 2 ST Washer
3 5-0390033 3 ST Connector
4 5-0340064 1 ST Pump
5 1480932 2 ST Spring washer
6 5-0230619 1 ST Gasket
7 1473616 2 ST Head screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Gear pump

004-002 1456170

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Gear pump

004-002 1456170

Pos Article Qty. Unit Description Note

1 1456170 1 ST Gear Pump

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic pump conveyor, vibrator & tamper assy.

004-003 5-104032501

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic pump conveyor, vibrator & tamper assy.

004-003 5-104032501

Pos Article Qty. Unit Description Note

0 5-104032501 1 ST Hydraulic pump conveyor, vibrator & tamper
1 5-0340064 1 ST Pump
2 5-0390011 2 ST Connectors
3 5-0390010 1 ST Connector
4 5-0390534 3 ST Connectors
5 1473616 2 ST Head screw
6 1480923 2 ST Washer 1
7 5-0230619 1 ST Gasket
8 1480932 2 ST Spring washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic pump traction assy.

004-004 1502752

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic pump traction assy.

004-004 1502752

Pos Article Qty. Unit Description Note

0 1502752 1 ST Hydraulic pump traction assy.
1 5-0340031 1 ST Hydraulic pump
2 5-0490200 4 ST Pressure sensor
3 5-0390803 1 ST Screw-in fitting
4 5-0390328 1 ST Connector
5 5-0490201 2 ST Screw coupling
6 5-0390028 1 ST Connector
7 5-0390341 1 ST Holder manometer
8 5-0390342 1 ST Connector
9 5-0230008 4 ST O-ring
10 1480932 16 ST Spring washer
11 5-0390100 2 ST Connectors
12 5-0390024 4 ST Connectors
13 4-5160580016 8 ST Semi-flange
14 1480675 16 ST Hex screw
15 1480935 2 ST Spring washer
16 1473629 2 ST Head screw
17 1480924 2 ST Washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Operating platform Assy.

005 1503928

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Operating platform Assy.

005 1503928

Pos Article Qty. Unit Description Note

1 5-0270708 1 ST Hose
2 1508126 1 ST Driver's seat Assembly RH
3 1508104 1 ST Instrument panel Assembly
4 1508219 1 ST Floor Assembly
5 1508240 1 ST Driver's seat Assembly LH
6 1469601 1 ST Rubber pointer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hose

005-001 5-0270708

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hose

005-001 5-0270708

Pos Article Qty. Unit Description Note

1 5-0270708 1 ST Hose

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Driver's seat Assembly RH

005-002 1508126

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Driver's seat Assembly RH

005-002 1508126

Pos Article Qty. Unit Description Note

0 1508126 1 ST Driver's Seat Assembly RH
1 5-104007004 1 ST Fixture
2 5-101013009 1 ST Axle
3 5-107004010 1 ST Foot Plate
4 5-107004011 1 ST Metal Cover
5 5-104007008 1 ST Flat
6 1224006 1 ST Plate
7 5-107004012 1 ST Handle
8 5-101013031 1 ST Pipe
9 5-101013030 1 ST Compression Spring
10 5-0030026 1 ST Safety Plug Rubber
11 1480923 2 ST Washer
12 1480932 2 ST Spring Washer
13 1480671 3 ST Hex Screw
14 1473836 3 ST Washer
15 1480931 3 ST Spring Washer
16 1481846 3 ST Hex Screw
17 5-0190830 1 ST Lock
18 1473812 8 ST Hexagon Nut
19 5-0140910 1 ST Spring Pin
20 1480933 2 ST Spring Washer
21 1480689 2 ST Hex Screw
222 1473837 6 ST Washer
23 1480942 3 ST Hexagon Nut
24 1480680 2 ST Hex Screw
25 5-0190718 2 ST Hinge
26 1473834 8 ST Washer
27 1508128 1 ST Support Assembly Seat Right
28 1508127 1 ST Support
29 5-0050003 2 ST Flange Bushing

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Instrument panel Assembly

005-003 1508104

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Instrument panel Assembly

005-003 1508104

Pos Article Qty. Unit Description Note

0 1508104 1 ST Instrument Panel Assembly
1 5-104007006 1 ST Rod
2 5-104007003 1 ST Rod
3 5-104007001 1 ST Fixture
4 5-104007002 2 ST Bushing
5 5-101013007 1 ST Bearing Flange Exterior
6 5-101013006 1 ST Bearing Flange Interior
7 1471443 1 ST Instrument Panel
8 1505259 1 ST Plate
9 5-101013010 1 ST Round For Control Panel
10 5-101013020 1 ST Pin Rad
11 5-101013036 1 ST Fixing Device
12 5-101013024 2 ST Journal
13 1473823 4 ST Hexagon Nut
14 5-0250002 2 ST Clamping Lever
15 1473857 10 ST Spring Washer
16 1473774 12 ST Countersunk Screw
17 1480923 17 ST Washer
18 1480921 2 ST Washer
19 1480930 2 ST Spring Washer
20 1481845 2 ST Hex Screw
21 1480932 4 ST Spring Washer
22 1480671 4 ST Hex Screw
23 5-101013016 2 ST Washer
24 1480924 2 ST Washer
25 1480693 2 ST Hex Screw
26 1473469 10 ST Hex
27 1473836 2 ST Washer
28 1480661 2 ST Hex Screw
29 1480942 13 ST Hexagon Nut
30 5-0360003 1 ST Greasing Nipple
31 1471444 1 ST Guard
32 1510719 1 ST Cover Bottom Console
33 1512914 1 ST Connector Plate

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Floor Assembly

005-004 1508219

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Floor Assembly

005-004 1508219

Pos Article Qty. Unit Description Note

0 1508219 1 ST Floor Assembly
1 5-104029006 1 ST Foot Board
2 5-104029009 1 ST Foot Board
3 5-101001020 4 ST Hinge Blank
4 5-104029011 1 ST Foot Board Links
5 1508106 1 ST Foot Board Left Side
6 1473836 10 ST Washer
7 1480931 10 ST Spring Washer
8 1480658 18 ST Hex Screw
9 5-0190800 1 ST Lock
10 1480922 24 ST Washer
11 5-0110605 1 ST Angle Joint
12 5-104029012 1 ST Rod
13 5-0110603 1 ST Angle Joint
14 5-104016014 1 ST Rod
15 1473859 8 ST Hexagon Nut
16 1480660 8 ST Hex Screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Driver's seat Assembly LH

005-005 1508240

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Driver's seat Assembly LH

005-005 1508240

Pos Article Qty. Unit Description Note

0 1508240 1 ST Driver's Seat Assembly LH
1 5-101013009 1 ST Axle
2 5-107004011 1 ST Metal Cover
3 5-107004009 1 ST Foot Plate
4 5-107004012 1 ST Handle
5 5-101013031 1 ST Pipe
6 5-101013030 1 ST Compression Spring
7 5-0190800 1 ST Lock
8 5-0030026 1 ST Safety Plug Rubber
9 1480923 2 ST Washer
10 1480932 2 ST Spring Washer
11 1480671 2 ST Hex Screw
12 5-104007015 1 ST Fixing Plate
13 1473836 1 ST Washer
14 1480931 3 ST Spring Washer
15 1481846 1 ST Hex Screw
16 1480658 2 ST Hex Screw
17 5-104007005 1 ST Fixture
18 5-104007007 1 ST Flat
19 1224006 1 ST Plate
20 1480680 2 ST Hex Screw
21 5-0140910 1 ST Spring Pin
22 1480933 2 ST Spring Washer
23 1480689 2 ST Hex Screw
24 1473837 4 ST Washer
25 1480942 2 ST Hexagon Nut
26 1473812 8 ST Hexagon Nut
27 5-0190718 2 ST Hinge
28 1508160 1 ST Support Assembly
29 1508129 1 ST Support
30 5-0050003 2 ST Flange Bushing
31 1473834 8 ST Washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Rubber pointer

005-006 1469601

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Rubber pointer

005-006 1469601

Pos Article Qty. Unit Description Note

1 1469601 1 ST Rubber pointer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Driver's seat Assy.

006 1224314

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Driver's seat Assy.

006 1224314

Pos Article Qty. Unit Description Note

0 1224314 1 ST Driver's Seat Assy.
1 1473859 12 ST Hexagon Nut
2 1473609 12 ST Head Screw
3 1480931 12 ST Spring Washer
4 1451490 2 ST Driver's Seat

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Electrical kit

007 1455172_1

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Electrical kit

007 1455172_1

Pos Article Qty. Unit Description Note

0 1455172 1 ST Electrical Kit
1 1456417 1 ST Remote Control
2 4-5358010401 1 ST Ignition Lock
3 4-5358010402 1 ST Flap
4 1455258 1 ST Mobile Charger Socket
5 4-5358170091 1 ST Isolator
6 4-04152A 4 ST Pipe
7 1477868 2 ST Head Light Assy.
8 1455094 2 ST Rear Light
9 1455095 2 ST Lamp
10 1455096 2 ST Direction Indicator Lamp
11 1455076 1 ST Licence Plate Lighting
12 1508102 2 ST Work lamp
13 1455103 2 ST Signal Horn
14 1455100 1 ST Signal Horn Reverse
15 1454976 1 ST Engine Starter Relay
16 1477933 100 ST Cable Tie
17 1477934 50 ST Cable Tie
18 1477937 50 ST Cable Tie
19 1515113 2 ST Battery
20 1473864 2 ST Hexagon Nut
21 1473608 3 ST Head Screw
22 1480931 2 ST Spring Washer
23 1481846 2 ST Hex Screw
24 4-3113105055 4 ST Head Screw
25 1473812 4 ST Hexagon Nut
26 5-103015001 2 ST Wipe For Battery

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Electrical kit

007 1455172_2

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Electrical kit

007 1455172_2

Pos Article Qty. Unit Description Note

1 1454986 1 ST Battery Cable
2 1454987 1 ST Battery Cable
3 1454983 1 ST Battery Cable
4 1454981 1 ST Battery Cable
5 1454977 1 ST Ground Strap

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Console Dashboard

007-001 1456413_1

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Console Dashboard

007-001 1456413_1

Pos Article Qty. Unit Description Note

0 1456413 1 ST Console Dashboard
1 1529848 1 ST Display unit
2 1529440 1 ST Operating module top left
3 1529441 1 ST Operating module top right
4 1529442 1 ST Operating module bottom left
5 1529443 1 ST Operating module bottom right
6 1529444 1 ST Operating module centre
7 1529900 1 ST Panel Plate-Emblems & Plate
8 1521005 3 ST Knob
9 1521006 1 ST Emergency stop switch
10 1521007 1 ST Push button
11 1529909 1 ST Steering unit

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Console Dashboard

007-001 1456413_2

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Console Dashboard

007-001 1456413_2

Pos Article Qty. Unit Description Note

1 1529901 1 ST PCB Top
2 1529902 1 ST PCB Bottom
3 1521001 3 ST Pot Resistor
3 1529973 1 ST Cable Harness Dashboard Internal

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Electrical Panel

007-002 1456414

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Electrical Panel

007-002 1456414

Pos Article Qty. Unit Description Note

0 1456414 1 ST Electrical Panel
1 1529930 1 ST Controller
2 1529974 1 ST Cable Harness Controller
3 1529906 1 ST PCB
4 1529907 1 ST PCB
5 1529908 1 ST PCB
6 1529970 10 ST Relay
7 4-9200010006 2 ST Fuse Box
8 4-9200010001 2 ST Bunch Plug
9 4-9200010002 2 ST Bunch Plug
10 4-9200010003 2 ST Bunch Plug
11 4-9200010004 2 ST Bunch Plug
12 1529971 1 ST Flasher
13 1529931 1 ST Electrical Linear Actuator
14 1529998 1 ST Panel - Fasteners Kit
15 4-5422060016 9 ST Fuse 10A
16 4-5422060017 7 ST Fuse 20A

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cable harness Kit of Tractor Unit

007-003 1518238_1

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cable harness Kit of Tractor Unit

007-003 1518238_1

Pos Article Qty. Unit Description Note

0 1518238 1 ST Cable Harness Kit Of Tractor Unit
1 1455167 1 ST Cable Harness Screed Tractor Side
2 1515015 1 ST Cable Harness LH Speed Sensor
3 1515016 1 ST Cable Harness RH Speed Sensor

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cable harness Kit of Tractor Unit

007-003 1518238_2

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cable harness Kit of Tractor Unit

007-003 1518238_2

Pos Article Qty. Unit Description Note

1 1514998 1 ST Cable harness Dashboard to Junction
2 1515014 1 ST Cable harness Lighting

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cable harness Kit of Tractor Unit

007-003 1518238_3

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cable harness Kit of Tractor Unit

007-003 1518238_3

Pos Article Qty. Unit Description Note

1 1515011 1 ST Cable harness Hydraulic
2 1515013 2 ST Cable harness Limit S/W Sensor

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cable harness Kit of Tractor Unit

007-003 1518238_4

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Cable harness Kit of Tractor Unit

007-003 1518238_4

Pos Article Qty. Unit Description Note

1 1455165 1 ST Cable harness Engine

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Hydraulic System

008 1508309

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Hydraulic System

008 1508309

Pos Article Qty. Unit Description Note

1 1505284 1 ST Hydraulic Block Assy.
2 1505363 1 ST Hydraulic Oil Tank Assy.
3 1509144 1 ST Hydraulic System Lines Assy.

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic block Assembly

008-001 1505284

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic block Assembly

008-001 1505284

Pos Article Qty. Unit Description Note

0 1505284 1 ST Hydraulic block Assembly
1 5-0160077 2 ST Clamp body
2 5-0160079 2 ST Plate
3 1473496 2 ST Hex screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Filter element

008-001-001 1508004

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Filter element

008-001-001 1508004

Pos Article Qty. Unit Description Note

0 1508004 1 ST Filter element
1 5-0390019 1 ST Screwed connection
2 1480922 2 ST Washer
3 1480931 2 ST Spring washer
4 5-0390842 1 ST L-connection
5 1480660 2 ST Hex screw
6 5-0170006 1 ST Manometer
7 1456330 1 ST Oil filter
8 1176590 1 ST Pressure switch

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Valve block Assembly

008-001-002 1508007

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Valve block Assembly

008-001-002 1508007

Pos Article Qty. Unit Description Note

0 1508007 1 ST Valve block assembly
1 5-104014010 1 ST Block
2 5-0390006 6 ST Screwed connection
3 5-0390007 6 ST Screwed connection
4 1480930 2 ST Spring washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Distributor block filter assy.

008-001-003 1508021

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Distributor block filter assy.

008-001-003 1508021

Pos Article Qty. Unit Description Note

0 1508021 1 ST Distributor block filter assy.
1 5-104014017 1 ST Valve block
2 5-0390009 1 ST Screwed connection
3 5-0390007 1 ST Screwed connection
4 5-0390004 2 ST Screwed connection
5 5-0390558 1 ST Screwed connection
6 5-0490201 1 ST Screw coupling
7 5-0390026 2 ST Screwed connection
8 5-0390003 1 ST Screwed connection
9 5-0390006 1 ST Screwed connection
10 5-0390301 1 ST Screwed connection
11 5-0390555 1 ST Screwed connection
12 1469604 1 ST Washer copper
13 5-0390347 1 ST Plug
14 1480658 2 ST Hex screw
15 5-0390512 1 ST L-connection
16 1480660 2 ST Hex screw
17 1480669 2 ST Hex screw
18 1480932 2 ST Spring washer
19 1473837 2 ST Washer
20 5-104028011 1 ST Holder
21 1480931 4 ST Spring washer
22 1473836 4 ST Washer
23 5-0170027 1 ST Indicator
24 1456332 1 ST Oil filter

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Distributor block Assy.

008-001-004 5-104014522

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Distributor block Assy.

008-001-004 5-104014522

Pos Article Qty. Unit Description Note

0 5-104014522 1 ST Distributor block assy,
1 5-104014016 1 ST Distributor block
2 5-0390003 4 ST Screwed connection
3 1473597 4 ST Head screw
4 1473857 4 ST Spring washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic block Reduction Assy.

008-001-005 5-104014524

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic block Reduction Assy.

008-001-005 5-104014524

Pos Article Qty. Unit Description Note

0 5-104014524 1 ST Hydraulic block reduction assy.
1 5-101021007 1 ST Hydraulic block
2 5-0390026 2 ST Screwed connection
3 5-0390801 1 ST Screwed connection
4 5-0390517 1 ST Screwed connection
5 5-0490201 1 ST Screw coupling
6 1121409 1 ST Manometer
7 5-0190435 1 ST Indicator pipe
8 1473753 3 ST Countersunk screw
9 1473830 3 ST Washer plain
10 1473813 3 ST Hexagon nut
11 1473606 2 ST Head screw
12 1480921 2 ST Washer
13 1480930 2 ST Spring washer
14 1473864 2 ST Hexagon nut

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Brake & Shaft Block assy.

008-001-006 1508057

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Brake & Shaft Block assy.

008-001-006 1508057

Pos Article Qty. Unit Description Note

0 1508057 1 ST Brake & Shaft Block Assembly
1 5-105004002 1 ST Valve Block
2 5-0390038 2 ST Screwed Connection
3 5-0390518 2 ST Screwed Connection
4 5-0390009 2 ST Screwed Connection
5 1469604 2 ST Washer Copper
6 5-0190505 1 ST Screwed Connection
7 1480847 4 ST Countersunk Screw
8 1473766 4 ST Countersunk Screw
9 1473859 4 ST Hexagon Nut
10 1480922 4 ST Washer
11 5-105012001 1 ST Fixing Plate
12 5-0190502 2 ST Screwed Connection
13 1469597 1 ST Washer Copper

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Valve Block Assy.

008-001-007 , 5-104014525

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Valve Block Assy.

008-001-007 , 5-104014525

Pos Article Qty. Unit Description Note

0 5-104014525 1 ST Valve Block Assy.
1 5-104014011 1 ST Valve Block
2 5-0390010 14 ST Screwed Connection
3 5-0390011 4 ST Screwed Connection
4 5-0390019 1 ST Screwed Connection
5 5-0230602 1 ST Sealing Washer
6 5-0390098 1 ST Screw-In Fitting
7 5-0140403 1 ST Sealing Ring
8 5-0150636 1 ST Non Return Valve
9 5-0390014 1 ST Screw-In Fitting
10 5-0490201 6 ST Screw Coupling
11 1480931 4 ST Spring Washer
12 1480660 4 ST Hex Screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Valve Block assembly

008-001-008 5-104014526

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Valve Block assembly

008-001-008 5-104014526

Pos Article Qty. Unit Description Note

0 5-104014526 1 ST Valve Block Assy.
1 5-104014012 1 ST Valve Block
2 5-0390006 7 ST Screwed Connection
3 5-0390555 1 ST Screwed Connection
4 5-0390010 1 ST Screwed Connection
5 1469702 1 ST Washer Copper
6 5-0390007 3 ST Screwed Connection
7 5-0490201 1 ST Screw Coupling
8 1480922 2 ST Washer
9 1480931 2 ST Spring Washer
10 1481846 2 ST Hex Screw
11 5-0190504 1 ST Screwed Connection

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Valve Block assembly

008-001-009 1508064

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Valve Block assembly

008-001-009 1508064

Pos Article Qty. Unit Description Note

0 1508064 1 ST Valve Block Assembly
1 5-104014013 1 ST Valve Block
2 5-0390006 1 ST Screwed Connection
3 5-0390533 1 ST L-Connection
4 1480795 2 ST Head Screw
5 5-0390004 4 ST Screwed Connection
6 1480930 2 ST Spring Washer

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hand Pump Assy.

008-001-010 5-104014516

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hand Pump Assy.

008-001-010 5-104014516

Pos Article Qty. Unit Description Note

0 5-104014516 1 ST Hand Pump Assy.
1 5-0370001 1 ST Hand Pump
2 5-0390003 1 ST Screwed Connection
3 5-0390561 1 ST Screwed Connection
4 1480930 2 ST Spring Washer
5 1480654 2 ST Hex Screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Oil Tank Assy.

008-002 1505363

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Oil Tank Assy.

008-002 1505363

Pos Article Qty. Unit Description Note

0 1505363 1 ST Hydraulic oil tank Assy.
1 1473837 12 ST Washer
2 1480932 8 ST Spring washer
3 1480671 4 ST Hex screw
4 5-0390522 3 ST L-connection
5 5-0190515 1 ST Screw plug
6 5-0390018 1 ST Screwed connection
7 5-0390019 2 ST Screwed connection
8 5-0390010 5 ST Screwed connection
9 5-0390038 2 ST Screwed connection
10 5-0150634 1 ST Non return valve
11 5-0390545 1 ST Screwed connection
12 5-0190504 6 ST Screwed connection
13 1469702 6 ST Washer COPPER
14 5-0390009 2 ST Screwed connection
15 5-0390011 1 ST Screwed connection
16 5-0190507 1 ST Sealing plug
17 5-0390058 1 ST Screwed connection
18 5-0490003 1 ST Sealing plug
19 5-0140403 2 ST Sealing ring
20 1505929 1 ST Oil tank pre-mounting Assy.
21 5-0490402 1 ST Filling level indicator
22 5-0230015 1 ST O-ring
23 5-104004001 1 ST Tank cap
24 1456336 2 ST Oil filter
25 5-0140402 2 ST Sealing ring
26 1505283 1 ST Hydraulic oil tank
27 1480673 4 ST Hex screw
28 1505885 1 ST Oil filter Assy.
29 1477934 50 ST Cable Tie
30 1477937 50 ST Cable Tie
31 1477777 2 ST Insulating Tape
32 1515113 2 ST Battery

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic system Lines Assy.

008-003 1509144

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic system Lines Assy.

008-003 1509144

Pos Article Qty. Unit Description Note

0 1509144 1 ST Hydraulic System Lines Assy.
008-003-001 1509104 1 ST Hydraulic Tube Assy.
008-003-002 5-104001503 1 ST Hydraulic System Rear Wall
008-003-003 1229924 1 ST Hydraulic Hoses

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Tube Assembly

008-003-001 1509104

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Tube Assembly

008-003-001 1509104

Pos Article Qty. Unit Description Note

0 1509104 1 ST Hydraulic Tube Assembly
1 5-104020005 1 ST Hydraulic Tube
2 5-104020006 1 ST Hydraulic Tube
3 5-104020007 1 ST Hydraulic Tube
4 5-104020008 1 ST Hydraulic Tube
5 5-104020009 4 ST Hydraulic Tube
6 5-104020013 1 ST Hydraulic Tube
7 5-104020014 1 ST Hydraulic Tube
8 5-104020015 1 ST Hydraulic Tube
9 5-104020016 1 ST Hydraulic Tube
10 5-104020017 1 ST Hydraulic Tube
11 5-104020018 1 ST Hydraulic Tube
12 5-105007001 1 ST Hydraulic Tube
13 5-105007003 1 ST Hydraulic Tube
14 5-105007002 1 ST Hydraulic Tube
15 5-0160067 3 ST Clamp Body
16 5-105007004 1 ST Hydraulic Tube
17 5-105007005 1 ST Hydraulic Tube
18 5-0160019 3 ST Plate
19 1473603 18 ST Cyl Head Screw
20 1473481 2 ST Hex Screw
21 5-0160010 2 ST Hose Clip
22 1480666 3 ST Hex Screw
23 1156640 4 ST Hose Clip
24 1480921 4 ST Washer
25 1473605 4 ST Cyl Head Screw

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic System Rear Wall

008-003-002 5-104001503

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic System Rear Wall

008-003-002 5-104001503

Pos Article Qty. Unit Description Note

0 5-104001503 1 ST Hydraulic System Rear Wall
1 5-0390351 1 ST Screwed Connection
2 5-0390312 6 ST Screwed Connection
3 5-0390313 2 ST Screwed Connection
4 1469665 5 ST Nipple
5 5-0390324 5 ST Screwed Connection
6 5-0390326 4 ST Screwed Connection
7 5-0390311 1 ST Screwed Connection
8 5-0390310 2 ST Screwed Connection
9 5-0360402 5 ST Greasing Nipple
10 1469703 5 ST Washer Copper

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_1

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_1

Pos Article Qty. Unit Description Note

0 1229924 1 ST Hydraulic Hoses Assy.
1 5-0520474 1 ST Hydraulic Hose
2 5-0520485 2 ST Hydraulic Hoses
3 5-0520515 2 ST Hydraulic Hoses
4 5-0520514 2 ST Hydraulic Hoses
5 5-0520512 2 ST Hydraulic Hoses
6 5-0520511 2 ST Hydraulic Hoses
7 5-0520521 4 ST Hydraulic Hoses
8 5-0520196 1 ST Hydraulic Hose
9 5-0520179 1 ST Hydraulic Hose
10 5-0520517 2 ST Hydraulic Hoses
11 5-0520487 2 ST Hydraulic Hoses
12 5-0520486 3 ST Hydraulic Hoses
13 5-0520516 1 ST Hydraulic Hose
14 5-0520475 1 ST Hydraulic Hose
15 5-0520958 1 ST Hydraulic Hose
16 5-0520959 1 ST Hydraulic Hose
17 5-0520668 1 ST Hydraulic Hose

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_2

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_2

Pos Article Qty. Unit Description Note

1 5-0520538 1 ST Hydraulic Hose
2 5-0520520 1 ST Hydraulic Hose
3 5-0520539 1 ST Hydraulic Hose
4 5-0520519 1 ST Hydraulic Hose
5 5-0520721 4 ST Hydraulic Hoses
6 5-0520537 1 ST Hydraulic Hose
7 5-0520509 1 ST Hydraulic Hose
8 5-0520510 1 ST Hydraulic Hose
9 5-0520497 1 ST Hydraulic Hose
10 5-0520498 1 ST Hydraulic Hose
11 5-0520450 1 ST Hydraulic Hose
12 5-0520524 1 ST Hydraulic Hose
13 5-0520495 1 ST Hydraulic Hose

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_3

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_3

Pos Article Qty. Unit Description Note

1 5-0520707 1 ST Hydraulic Hose
2 5-0520713 1 ST Hydraulic Hose
3 5-0520007 1 ST Hydraulic Hose
4 5-0520697 1 ST Hydraulic Hose
5 5-0520698 1 ST Hydraulic Hose
6 5-0520712 1 ST Hydraulic Hose
7 5-0520710 1 ST Hydraulic Hose
8 5-0520022 1 ST Hydraulic Hose
9 5-0520696 1 ST Hydraulic Hose
10 5-0521020 1 ST Hydraulic Hose
11 5-0520701 1 ST Hydraulic Hose
12 5-0520700 1 ST Hydraulic Hose
13 5-0520699 1 ST Hydraulic Hose
14 5-0521018 1 ST Hydraulic Hose
15 5-0521019 1 ST Hydraulic Hose
16 5-0520708 1 ST Hydraulic Hose
17 5-0520709 1 ST Hydraulic Hose
18 5-0520702 1 ST Hydraulic Hose
19 5-0520703 1 ST Hydraulic Hose
20 5-0520704 1 ST Hydraulic Hose

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_4

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_4

Pos Article Qty. Unit Description Note

1 1504803 2 ST Hydraulic Hoses
2 1504805 2 ST Hydraulic Hoses
3 5-0520481 1 ST Hydraulic Hose
4 5-0520482 1 ST Hydraulic Hose
5 5-0520483 1 ST Hydraulic Hose
6 5-0520484 1 ST Hydraulic Hose
7 5-0520469 1 ST Hydraulic Hose
8 1512543 1 ST Hydraulic Hose
9 5-0520471 1 ST Hydraulic Hose
10 1526235 1 ST Hydraulic Hose
11 5-0520470 1 ST Hydraulic Hose
12 5-0520233 1 ST Hydraulic Hose
13 5-0520240 1 ST Hydraulic Hose
14 5-0520277 1 ST Hydraulic Hose
15 5-0521082 1 ST Hydraulic Hose
16 5-0520795 2 ST Hydraulic Hoses
17 5-0520542 2 ST Hydraulic Hoses
18 5-0520543 2 ST Hydraulic Hoses
19 5-0520544 1 ST Hydraulic Hose

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_5

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_5

Pos Article Qty. Unit Description Note

1 5-0520452 1 ST Hydraulic Hose
2 5-0520457 1 ST Hydraulic Hose
3 5-0520458 1 ST Hydraulic Hose
4 5-0520459 1 ST Hydraulic Hose
5 5-0520461 1 ST Hydraulic Hose
6 5-0521081 1 ST Hydraulic Hose
7 5-0520722 1 ST Hydraulic Hose
8 5-0520554 1 ST Hydraulic Hose

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_6

d
© Ammann Schweiz AG, www.ammann-group.com
 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_6

Pos Article Qty. Unit Description Note

1 5-0520330 1 ST Hydraulic Hose
2 1504807 1 ST Hydraulic Hose
3 5-0520614 1 ST Hydraulic Hose
4 5-0520525 1 ST Hydraulic Hose
5 5-0520522 1 ST Hydraulic Hose
6 5-0520173 1 ST Hydraulic Hose
7 5-0520492 1 ST Hydraulic Hose
8 5-0520494 1 ST Hydraulic Hose
9 5-0520711 1 ST Hydraulic Hose
10 5-0520714 1 ST Hydraulic Hose

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_7

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Hydraulic Hose Assy.

008-003-003 1229924_7

Pos Article Qty. Unit Description Note

1 5-0520479 1 ST Hydraulic Hose
2 5-0520535 1 ST Hydraulic Hose
3 1504809 1 ST Hydraulic Hose
4 1504808 1 ST Hydraulic Hose
5 5-0520541 1 ST Hydraulic Hose

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Unit GP

009 5-105000000

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Unit GP

009 5-105000000

Pos Article Qty. Unit Description Note

0 5-105000000 1 ST Unit Gp
1 1480758 18 ST Hex Screw
2 1473849 36 ST Washer
3 1473862 18 ST Hexagon Nut
4 1480928 4 ST Washer
5 5-205009007 2 ST Straight Pin
6 1479573 4 ST Pin

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Filter

010 Filter 1505705

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Filter

010 Filter 1505705

Pos Article Qty. Unit Description Note

1 1456331 1 ST Filter Element

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Decal Assembly

011 1505703_1

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Decal Assembly

011 1505703_1

Pos Article Qty. Unit Description Note

0 1505703 1 ST Decal Assembly
1 5-101030001 1 ST Decal
2 5-101030023 14 ST Decals
3 5-101030031 1 ST Decal
4 5-107016003 4 ST Decals
5 5-101030005 2 ST Decals
6 5-101030006 2 ST Decals
7 5-101030008 1 ST Decal
8 1-478679 1 ST Decal
9 5-101030012 1 ST Decal
10 5-101030013 1 ST Decal
11 5-101030014 4 ST Decals
12 1118436 1 ST Decal
13 5-101030016 1 ST Decal
14 1-494609 1 ST Plate
15 5-107016005 1 ST Decal
16 5-107016006 1 ST Decal
17 5-104030005 2 ST Decals
18 5-104030006 4 ST Decals
19 5-104030007 1 ST Decal

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Decal Assembly

011 1505703_2

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Decal Assembly

011 1505703_2

Pos Article Qty. Unit Description Note

1 5-107016010 2 ST Decals
2 1-413020 1 ST Decal
3 5-102030002 2 ST Decals
4 1276004 1 ST Decal
5 1272521 1 ST Reflective Decal
6 1272513 1 ST Reflective Decal
7 5-101030010 1 ST Decal
8 1246909 2 ST Decals
9 1227501 2 ST Decals
10 1414369 1 ST Decal

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Decal Assembly

011 1505703_3

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Decal Assembly

011 1505703_3

Pos Article Qty. Unit Description Note

1 5-0140100 4 ST Blind Rivet
2 1505238 1 ST Type Plate

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Roof Assembly

012 1503930_1

‘
© Ammann Schweiz AG, www.ammann-group.com
 AFT 500 AFT 500 Roof Assembly

012 1503930_1

Pos Article Qty. Unit Description Note

0 1503930 1 ST Roof Assy.
1 1508636 1 ST Strut Bottom RH Assy.
2 1508633 1 ST Strut RH
3 5-104017007 8 ST Flat
4 1480921 20 ST Washer
5 1473864 20 ST Hexagon Nut
6 1480846 16 ST Countersunk Screw
7 1505264 4 ST Plate
8 1519275 1 ST Strut Bottom LH Assy.
9 1519273 1 ST Strut Bottom LH
10 5-104017503 1 ST Ventilator Block
11 5-104014007 1 ST Block Brake Transmission
12 5-0390003 6 ST Nipple
13 1480930 4 ST Spring Washer
14 1480654 2 ST Hex Screw
15 5-104017502 1 ST Distributor
16 5-104017012 1 ST Valve Block
17 5-0390026 4 ST Nipple
18 1473605 4 ST Head Screw
19 5-104017009 1 ST Bracket
20 4-6531013291 2 ST Symbol
21 1470882 2 ST Hydraulic Cylinder
21.1 1518628 1 ST Sealing Kit
22 1509645 2 ST Canopy Top Lag
23 1480922 6 ST Washer
24 1480925 2 ST Plain Washer
25 5-104017004 2 ST Shoulder Bolt
26 1480948 4 ST Check Nut
27 1480926 24 ST Washer
28 1480733 4 ST Hex Screw
29 1480660 2 ST Hex Screw
30 1480904 2 ST Hexagon Nut
31 1518278 2 ST Pin
32 1456477 4 ST Circlip

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Roof Assembly

012 1503930_1

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Roof Assembly

012 1503930_1

Pos Article Qty. Unit Description Note

33 1516165 1 ST Hood
34 1480936 16 ST Spring Washer
35 1480946 16 ST Hexagon Nut
36 5-104073501 1 ST Crosshead
37 1473612 4 ST Socket Head Cap Screw
38 1526809 2 ST Bracket Mirror Mounting
39 1451563 2 ST Mirror Side Big

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Roof Assembly

012 1503930_2

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Roof Assembly

012 1503930_2

Pos Article Qty. Unit Description Note

1 5-0520161 1 ST Hydraulic Hose
2 5-0520607 1 ST Hydraulic Hose
3 5-0520608 2 ST Hydraulic Hose
4 5-0520005 2 ST Hydraulic Hose
5 5-0520609 2 ST Hydraulic Hose

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Auger Extension Assy.

013 AsseAmbly 1505702

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Auger Extension Assy.

013 AsseAmbly 1505702

Pos Article Qty. Unit Description Note

0 1505702 1 ST Auger Extension Assy.
1 1508275 2 ST Extension Material Coverage
2 5-205025001 1 ST Tunnel Extension
3 5-205025002 1 ST Tunnel Extension
4 5-205025003 2 ST Extension Tunnel
5 1508411 2 ST Strut
6 1508412 2 ST Strut Horizontal
7 1239245 2 ST Threaded Rod
8 1471423 2 ST Braces Collar
9 1469676 2 ST Bracket With Stud
10 1508163 2 ST Tension Tube
11 5-0110601 4 ST Rod End Bearing
12 5-0110602 4 ST Rod End Bearing
13 1473825 4 ST Hexagon Nut
14 1473826 4 ST Hexagon Nut
15 1239715 12 ST Linch Pin
16 1473872 2 ST Locknut
17 1473873 2 ST Locknut
18 1469918 2 ST Threaded Sleeve
19 1471425 2 ST Shaft
20 5-104009010 3 ST Auger Element RH
21 5-104009011 3 ST Auger Element LH
22 1480721 4 ST Hex Screw
23 1480936 4 ST Spring Washer
24 1480758 2 ST Hex Screw
25 1473849 2 ST Washer
26 1473862 2 ST Hexagon Nut
27 1473518 4 ST Hex Screw
28 1480910 18 ST Hexagon Nut
29 1480924 12 ST Washer
30 1480908 12 ST Hexagon Nut
31 1480695 12 ST Hex Screw
32 1473522 14 ST Hex Screw
33 5-104009012 1 ST Auger Element RH
34 5-0110601 4 ST Rod End Bearing
35 5-205025006 1 ST Bracket

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Auger Extension Assy.

013-001 AsseAmbly 1508162

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Auger Extension Assy.

013-001 AsseAmbly 1508162

Pos Article Qty. Unit Description Note

0 1508162 1 ST Auger Extension Assembly
1 1507294 1 ST Support Bracket Auger Left
2 1507295 1 ST Support Bracket Auger Right
3 5-104009010 8 ST Auger Element RH
4 5-104009011 8 ST Auger Element LH
5 5-104009012 1 ST Auger Element RH
6 1473522 42 ST Hex Screw
7 1480910 42 ST Hexagon Nut
8 5-0360401 2 ST Greasing Nipple
9 5-104009004 2 ST Guard
10 5-104009017 2 ST Guard
11 5-104009022 2 ST Holder
12 5-0110505 2 ST Holder
13 1480921 2 ST Washer
14 1473603 2 ST Head Screw
15 1471424 2 ST Screw Shaft Extending
16 5-104009013 1 ST Auger Element LH
17 5-0120024 2 ST Nut
18 5-104009014 1 ST End Fitting
19 5-104009018 2 ST Spacer Element
20 1480925 42 ST Washer Plain
21 5-104009015 1 ST End Fitting Links

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Safety lock Assy.

014 1519338

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 AFT 500 Safety lock Assy.

014 1519338

Pos Article Qty. Unit Description Note

0 1519338 1 ST Safety Lock Assy.
1 5-104046003 2 ST Flat
2 5-104046001 2 ST Pin
3 5-104046002 2 ST Spring
4 1473864 4 ST Hexagon Nut
5 1473609 2 ST Head Screw
6 1480653 4 ST Hex Screw
7 1480921 4 ST Washer
8 1480930 2 ST Spring Washer
9 1480903 2 ST Hexagon Nut
10 1518239 1 ST Screed Lock LH
11 1518233 1 ST Hand Lever LH
12 1518235 2 ST Cable Pull
13 1518236 1 ST Screed Lock RH
14 1518232 1 ST Hand Lever RH

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Tool Kit

015 1234862

© Ammann Schweiz AG, www.ammann-group.com

 AFT 500 Tool Kit

015 1234862

Pos Article Qty. Unit Description Note

0 1234862 1 ST Tool Kit
1 1481447 1 ST Pipe Wrench
2 1475211 1 ST Ring Wrench
3 1481450 1 ST Ring Wrench
4 1481451 1 ST Ring Wrench
5 1481452 1 ST Ring Wrench
6 1481453 1 ST Ring Wrench
7 1481458 1 ST Open-Ended Spanner
8 1475222 1 ST Open-Ended Spanner
9 1475249 1 ST Socket Wrench
10 1475250 1 ST Socket Wrench
11 1481469 1 ST Socket Wrench
12 1475276 1 ST Screwdriver
13 1475292 1 ST Hammer
14 1481493 1 ST Plier
15 1481497 1 ST Flat Chisel
16 1480418 1 ST Chain Tensioner
17 1451570 1 ST Grease Pump
18 4-5536900003 1 ST Hose
19 1475266 1 ST Hex Socket Key Set
20 1451572 1 ST Jack With Tommy
21 1522870 1 ST Grease Valve With Manometer
22 1520245 1 ST Screwed Connection
23 1456805 1 ST Wooden Box
24 1530625 1 ST Covering Hood

© Ammann Schweiz AG, www.ammann-group.com

Ammann Unternehmungen

Eisenbahnstrasse 25

CH-4901 Langenthal

Phone +41 62 916 61 61

www.ammann-group.com

© Ammann Schweiz AG, www.ammann-group.com
