Program/Course : COMPUTER SYSTEM SERVCING NCII
Unit of Competency : SET-UP COMPUTER SERVER
Module : SETTING-UP SERVER

INTRODUCTION: This module covers the knowledge, skills and attitudes

needed to set-up computer servers for LANs and SOHO systems. It consists
of competencies to set-up user access and configures network services as
well as to perform testing, documentation and pre-deployment procedures.

SUMMARY OF LEARNING OUTCOME

LO 1. Set-up user access LO

2. Configure network services LO
3. Perform testing, documentation and pre-deployment procedures

7
 Information Sheet 1.2-1
Computer Server

Learning Objectives: After reading this information sheet, the

students/trainees must be able to familiarize computer server and its
components.

Installing Active Directory and DNS

 The first step is to assign a ip to the server that you going to deploy
the AD. Its nessary to install it as DNS server too. So its better to have
fixed ip it doesn't mean you cannot install AD without fixed ip address
but it will solve lot of issues if you used fixed ip.

In here the server ip is 10.0.0.14. Since we going to make it as DNS server

too you should use the same ip as the preferred DNS server.

8
  Next step is to install the Active directory roles. Unlikely the older
version of windows servers Microsoft highly recommend to use server
manager option to install roles before you run dcpromo.

 Click on start menu and select the Server Manager

 Select the roles from the right hand panel and click on add roles
option.

9
 From the roles list select the "Active Directory Domain Services" role
and Click "Next"

 Review the confirmation and click on "Next"

10
 Review the installation confirmation and click on "Next"

 It will take few minutes to complete and when its done you will get
this confirmation. And then click on "Close"

11
After that you will need to do a reboot.
 After reboot please open up the "server Manager" again. And then click
on "Roles" there you will see the "Active Directory Domain Services" is
successfully installed in there. click on it then you will get a window
like below.

 In their please pay attention to the message

12
 So please click on that link and it will start the DCPROMO wizard.
 So next step to go through the DC promo wizard.
 To start the installation click on "Next"

 Click on "Next"

Since we going to install New domain Controller in new forest please select
the option "Create a new domain in new forest" option and click on "Next"

13
 Now we have to provide the name for our domain controller. It must
be FQDN. In our case I used rebeladmin.com as the domain. Please
click "Next" after it.

 In this window it will ask to select forest function level. If you going to
add server 2003 domain controller to your forest later don't select the
function level as server 2008. If you going to use full features of 2008
Ad you must select forest function level as server 2008. In my case I
used server 2008. Click on "Next" after the select.

14
 In next window since it's the first DC we should make it as DNS server
too. Leave the default selection and click on "Next"

 If the wizard cannot create a delegation for the DNS server, it displays
a message to indicate that you can create the delegation manually. To
continue, click "Yes"

15
 next window it will show up the database location. It its going to be bigger
AD its good if you can keep NTDS database in different partition. Click on
"Next" after changes.

16
 In next window its asking to define a restore mode password. Its more
important if you had to do a restore from backup in a server crash.
Click on "Next" after filling it.

 Next window is giving you a brief of the installation. Click on "Next"

 Then it will start the installation of the AD. It will take some time to
complete. After complete of the installation perform a server reboot.

17
  After the reboot now you can login to the domain. Please use the login
as following example
User name : your domain\administrator
Password : XXXXXXXX

 Now its done and you can view the active directory options on
administrative tools menu

18
How to Create Users and User Templates in Windows Server 2008
Active Directory
You probably already know that a User Account in Active Directory is
an Active Directory Object, or simply said, a record in an AD database. Most
of the time we create user accounts for people, however user accounts can
also be created for applications or processes.
User accounts allow a person to access resources on a network. But
we can just as easily deny access to certain resources on the network
through the user account. That’s why, User Account Objects are quite
important and very useful.
Today I’ll show you how easy it is to create a new user account, create
a user template and how to use a template in Server 2008 Active Directory.
Next week we’ll discuss User Groups and Organizational Units. Now, let’s
get started with creating a user account.
How To Create a New User Account in Active Directory
1. To start let’s go ahead and open up Server Manager

2. Next we will open up the Roles section, next to Active Directory Users

and Computers section and finally the Active Directory Users and
Computers. You should now see your domain name.

19
3. We are going to click on our Users section where we are going to create a
new User Account. To do so, right-click on the blank section, point
to New and select User.

4. In this window you need to type in the user’s first name, middle initial
and last name. Next you will need to create a user’s logon name.

20
In our example we are going to create a user account for Billy Miles and his
logon name will be bmiles. When done, click on the Next button.

5. In the next window you will need to create a password for your new user
and select appropriate options.
In our example we are going to have the user change his password at his
next logon. You can also prevent a user from changing his password, set the
password so that it will never expire or completely disable the account.
When you are done making your selections, click the Next button.

21
6. And finally, click on the Finish button to complete the creation of new
User Account.

Setting Up DHCP in Windows Server 2008 R2

To get started, fire up the Server Manager, right click on roles, and then
select add roles.

22
You will be prompted with the normal “Before You Begin” screen, and after
clicking Next you’ll be able to choose DHCP Server.

Next you’ll want to select the network connection to bind the DHCP protocol
to.

23
Put in the IP address of your DNS Server, which in this case is the same
machine–but be careful not to put the loopback address (127.0.0.1) as this
will be the address your clients will go to for name resolution.

24
Click next again to skip the WINS setup, this will bring you to creating a
DHCP Scope, where you can click the Add button.

Now you need to:

 Give your scope a name
 Enter the first address that you want available to clients to use
 Enter the last address that you want available to clients to use
 Enter the subnet mask (usually 255.255.255.0)
 Enter the IP address of your default gateway (usually your router IP
at .1)

25
26
Once you have clicked on OK, you can click next 4 times to get to the
confirmation screen where you can finally click install.

Once the installation is complete your DHCP will be functioning, and you
can start managing your DHCP server right away.

27
File Sharing
To install the File Services role, perform the following steps:
1. Launch the Server Manager, scroll down to the roles summary, and Click
Add Roles.
2. When the Add Roles Wizard appears, choose the File Services role and
click Next.
3. On the next page, which includes Introduction to Files services, Things to
Note, and Additional Information sections, take note of the information
and check out a few of the links. When you are ready to proceed, click
Next.
4. Next, you see the role services you can install (see Figure 1), depending
on what you want to accomplish with your file server. You can really pick
and choose the components you would like to install. Just choose File
Server for file/folder sharing.

After installing the file server role. Create a folder in drive C or where you
want to put the folder

28
29
After selecting the drive where you want to create your folder, right click on
the space on your drive (make sure that you do not select any file or folder
when you press the right mouse button) then select new>folder and left
click.

Then name your folder the desired name you want

30
After Creating a folder, press right click on your folder and select properties

Then select the sharing tab and under the sharing tab select share and
choose who you want to share your folder with

31
Folder Redirection GPO Settings
Since Folder Redirection is in the User Configuration portion of a GPO, one
can create multiple different policies and apply one to each distinct user
population by filtering the security settings in the properties of the
GPO. This allows administrators to redirect some users' folders to pre-
configured directories, that the users do not have sufficient NTFS
Permission to alter, and to redirect other users to folders that are self
maintained.
Folder Redirection settings are located in User Configuration-> Windows
Settings -> Folder Redirections.  In that node one will find:

To configure an item, right-click and select “Properties”.  This exposes the

configuration UI for the specified folder.  In a single GPO one can either
configure the folder to redirect to a specified location for all users to which
the GPO applies, or one can configure the folder to redirect to a specified
location based upon group membership.

32
Enabling Remote Desktop Using Group Policy

You can also use Group Policy to enable Remote Desktop on host
computers. To enable Remote Desktop on all computers in a specified
organizational unit (OU), open the Group Policy object (GPO) linked to the
OU using Group Policy Object Editor, enable the following policy setting and
add users to the Remote Desktop Users group:

Computer Configuration\Policies\Administrative Templates\Windows

Components \Remote Desktop Services\Remote Desktop Session Host\
Connections\Allow Users To Connect Remotely Using Remote Desktop
Services

Enabling Remote Desktop on computers using Group Policy also enables the
Allow Connections From Computers Running Any Version Of Remote
Desktop (Less Secure) option on the computers targeted by the GPO. To
enable Remote Desktop using the Allow Connections Only From Computers
Running Remote Desktop With Network Level Authentication (More Secure)
option instead, you must enable the following policy setting in addition to
the preceding one:

33
Computer Configuration\Policies\Administrative Templates\Windows
Components \Remote Desktop Services\Remote Desktop Session Host\
Security\Require User Authentication For Remote Connections By Using
Network Level Authentication

Note By default, when the first policy setting is enabled but the second
setting is not configured, local administrators on the targeted computers
have the ability to change the Remote Desktop security level on their
computers to Allow Connections Only From Computers Running Remote
Desktop With Network Level Authentication (More Secure) if desired. When
the second policy setting is enabled, the option Allow Connections From
Computers Running Any Version Of Remote Desktop (Less Secure) on the
Remote tab is unavailable and appears dimmed.

Deploy Printers via Group Policy on Windows Server 2008 R2

Every office has printers, and they all need to be connected.  If you have an
office with a Windows Server domain, you can easily connect your printers
using Group Policy.   Your printers and print drivers for your various
operating systems must be installed and shared on the server before you
begin.
This example is shown using Windows Server 2008 R2. To deploy your
printers using Group Policy, you first need to install the Print and Document
Services Role.  Open Server Manager, right click Roles, and choose Add
Roles.  Select the Print and Document Services role. When installing the
role, you need only choose Print server.

After you have installed the Role services, go back into Server Manager and
browse to Roles\Print and Document Services\Print Management\Print

34
Server\<Servername>\Printers.  Right-click on the printer you want to
deploy, and choose Deploy with Group Policy

After you have chosen Deploy with Group Policy, Click Browse to select the
Group Policy you want to use, then select it.  After choosing the policy, click
the check boxes to assign the printer on a user or computer basis (either per
user or per machine).  Then click Add

After you click Add, you can see the Printer name, the GPO that you
assigned it to, and the Connection Type (per user or per machine).  You can
add the printer to as many policies as you want.


Your users should not be administrators of their machines, which means
that when your printers attempt to install themselves, it won’t work.  There
are some changes that need to be made to the GPO assigning the printers so

35
that non-administrator users can install them.  Open the GPMC (Group
Policy Management Console) in Administrative Tools and browse to:
Computer Configuration | Policies | Administrative Templates |
Printers
Right-Click Point and Print Restrictions and choose Properties.  Click
Enabled.  Clear the checkboxes (if checked) that say “Users can Only point
and print to these servers” and “Users can only point and print to machines
in their forest”.  In the “When installing drivers for a new connection” box,
select “Do not show warning or elevation prompt”.  These settings only apply
to Vista and later.  If you are running Windows XP, hang your head in
shame, because it’s no longer supported.

36
 Self-Check 1.3-1
Computer Server

Abbreviation: these words stands for?

1. DNS
2. DHCP
3. FTP
4. GPO
5. TCP/IP

Identification: Identify the following

__________1. is a standard network protocol used to transfer computer files
from one host to another host over a TCP-based network, such as the
Internet.
__________2. is the consecutive range of possible IP addresses that
the DHCP server can lease to clients on a subnet.
__________3. an Internet service that translates domain names into IP
addresses.
__________4. is a client/server protocol that automatically provides an
Internet Protocol (IP) host with its IP address and other related configuration
information such as the subnet mask and default gateway.
__________5.  is an amount of time that an IP address is offered to a device.

37
 Answer-key 1.3-1
Computer Server

Abbreviation:
1. Domain Name System
2. Dynamic Host Configuration Protocol
3. File Transfer Protocol
4. Group Policy Object
5. Transmission Control Protocol/Internet Protocol

Identification:
1. FTP
2. DHCP Scope
3. DNS
4. DHCP
5. DHCP Lease

38
 TASK SHEET 1.3-1
Title: Installing and configuring computer servers

Learning Objective: Given the supplies/materials and equipment to

work on you must be able to install and configure computer servers in
each device
Supplies/Materials : Patch panel, network cable, wireless router,
wireless access point, driver installer
Equipment : Desktop Computer, laptop computer, tables and chairs

Steps/Procedure:
1. Prepare the materials and equipment needed in performing this
task
2. Apply occupational health and safety policies and procedures
before working on a computer
3. Configure the wireless router and wireless access point
4. Reserve the IP address XXX.XXX.XXX.1 for the server
5. Check if the 3 computers are within the subnet and are
communicating with each other by using cmd to ping one another
6. Install and configure Active Directory Domain Services role
7. Install and configure DNS role
8. Install and configure DHCP role
9. Install and configure File Services role
10.Install and configure Print and Document Services role
11.Create a GPO for folder redirection
12.Create a GPO for remote desktop
13.Create a GPO for deploying printer
Assessment Method:
Checking procedure with detailed checklist

39
 Performance Criteria Checklist 1.3-1

CRITERIA
YES NO
Did you….
Prepare the materials and equipment needed in
performing this task in accordance to the requirement?
Apply occupational health and safety policies and
procedures before working on a computer in
accordance to the requirement?
Configure the wireless router and wireless access point
in accordance to the requirement?
Reserve the IP address XXX.XXX.XXX.1 for the server
in accordance to the requirement?
Check if the 3 computers are within the subnet and are
communicating with each other by using cmd to ping
one another in accordance to the requirement?
Install and configure Active Directory Domain Services
role in accordance to the requirement?
Install and configure DNS role in accordance to the
requirement?
Install and configure DHCP role in accordance to the
requirement?
Install and configure File Services role in accordance to
the requirement?
Install and configure Print and Document Services role
in accordance to the requirement?
Create a GPO for folder redirection in accordance to the
requirement?
Create a GPO for remote desktop in accordance to the
requirement?
Create a GPO for deploying printer in accordance to the
requirement?
6.

40
For inquiries or feedback, please write or call:

Department of Education - Bureau of Learning Resources

(DepEd-BLR)

Ground Floor, Bonifacio Bldg., DepEd Complex

Meralco Avenue, Pasig City, Philippines 1600

Telefax: (632) 8634-1072; 8634-1054; 8631-4985

Email Address: blr.lrqad@deped.gov.ph *

blr.lrpd@deped.gov.ph

41
