Service Manual for D-108 Digital Multitrack Recorder

Service Manual
Model
D-108
&
8345/5040
DIGITAL MULTITRACK RECORDER
CAUTION:
CAUTION TO PREVENT ELECTRIC SHOCK, MATCH
RISK OF ELECTRIC SHOCK
WIDE BLADE OF PLUG TO WIDE SLOT,
DO NOT OPEN
FULLY INSERT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, ATTENTION:

DO NOT REMOVE COVER (OR BACK). POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE
NO USER-SERVICEABLE PARTS INSIDE.
LA FICHE DANS LA BORNE CORRE-
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. SPONDANTE DE LA PRISE ET POUSSER
JUSQU' AU FOND.
The lightening flash with arrowhead symbol, The exclamation point within an equilateral
within an equilateral triangle, is intended to triangle is intended to alert the user to the
alert the user to the presence of uninsulated presence of important operating and mainte-
“dangerous voltage” within the product's en- nance (servicing) instructions in the literature
closure that may be of sufficient magnitude to accompanying the appliance.
constitute a risk of electric shock to persons.
“WARNING”
“TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOIS-
TURE.”
SAFETY INSTRUCTIONS
1. Read instructions - All the safety and operating instruc- 9. Heat - The appliance should be situated away from heat
tions should be read before the appliance is operated. sources such as radiators, heat registers, stoves, or other
2. Retain instructions - The safety and operating instructions appliances (including amplifiers) that produce heat.
should be retained for future reference. 10. Power Sources - The appliance should be connected to a
3. Heed warnings - All warnings on the appliance and in the power supply only of the type described in the operating
operating instructions should be adhered to. instructions or as marked on the appliance.
4. Follow instructions - All operating and use instructions 11. Grounding or Polarization - The precautions that should
should be followed. be taken so that the grounding or polarization means of
5. Water and Moisture - The appliance should not be used an appliance is not defeated.
near water - for example, near a bathtub, washbowl, 12. Power Cord Protection - Power supply cords should be
kitchen sink, laundry tub, in a wet basement, or near a routed so that they are not likely to be walked on or
swimming pool, and the like. pinched by items placed upon or against them, paying
6. Carts and Stands - The appliance should be used only particular attention to cords at plugs, convenience recep-
with a cart or stand that is recommended by the manufac- tacles, and the point where they exit from the appliance.
turer. 13. Cleaning - The appliance should be cleaned only as rec-
ommended by the manufacturer.
14. Nonuse Periods - The power cord of the appliance should
be unplugged from the outlet when left unused for a long
period of time.
15. Object and Liquid Entry - Care should be taken so that
objects do not fall and liquids are not spilled into the en-
closure through openings.
16. Damage requiring Service - The appliance should be ser-
An appliance and cart combination should be moved with
viced by qualified service personnel when:
care. Quick stops, excessive force, and uneven surfaces
A. The power supply cord or the plug has been damaged;
may cause the appliance and cart combination to over-
or
turn.
B. Objects have fallen, or liquid has been spilled into the
7. Wall or Ceiling Mounting - The appliance should be
appliance; or
mounted to a wall or ceiling only as recommended by the
C. The appliance has been exposed to rain; or
manufacturer.
D. The appliance does not appear to operate normally or
8. Ventilation - The appliance should be situated so that its
exhibits a marked changed in performance; or
location or position does not interfere with its proper ven-
E. The appliance has been dropped, or the enclosure
tilation. For example, the appliance should not be situ-
damaged.
ated on a bed, sofa, rug, or similar surface that may block
17. Servicing - The user should not attempt to service the ap-
the ventilation openings; or, placed in a built-in installa-
pliance beyond that described in the operating instruc-
tion, such as a bookcase or cabinet that may impede the
tions. All other servicing should be referred to qualified
flow of air through the ventilation openings.
service personnel.
D-108
TABLE OF CONTENTS
1. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. CONTROLS, INDICATORS & CONNECTORS . . . . . . . . . . . . 7
3. SOFTWARE UPDATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4. SERVICE MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5. ERROR CODE LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6. MODEL 8345/5040 INSTALLING PROCEDURES . . . . . . . . . 23
7. EXPLODED VIEW, PCB ASSEMBLY & PARTS LIST . . . . . . 26
8. CIRCUIT DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
NOTES
* Service mode, error code list, exploded view, PCB assembly, parts list and circuit diagrams are given in this
manual to assist the service technician in maintaining the Model D-108.
* The following accessories are supplied with D-108 as the standard accessories.
Owner's manual : 8288421000 (for export model)
: 8288422000 (for domestic model)
Quick manual : 8288435000 (for export model)
: 8288436000 (for domestic model)
* Following is the packing material for the Model D-108.

Carton, inner, D-108 : 8228720000
Carton, outer, D-108 : 8228899000
Packing, side, L, D-108/160 : 8228430001
Packing, side, R, D-108/160 : 8228430002
Packing, case, D-108/160 : 8228435000
Inner carton, 9040 : 8228698000
Packing, side, 9040/9041 : 8228414000
CAUTION
Parts marked with this sign are safety critical components. They must always be replaced with identical
components. Refer to the Fostex Parts List and ensure exact replacement.
3
D-108
1. SPECIFICATIONS
D-108
INPUT & OUTPUT
INPUT (1 ~ 8)
Connector RCA pin jack (x 8)
Input Level -10 dBV
Input Impedance 10 kΩ or more
OUTPUT (1 ~ 8)
Connector RCA pin jack (x 8)
Output Level -10 dBV
Load Impedance 10 kΩ or more
DATA IN / OUT
Connector Square shape optical
Format IEC consumer optical standard IEC 958 Part 3
ALESIS Proprietary Multi Channel Optical Digital Interface
MIDI IN / OUT / THRU
Connector DIN 5-pin
Format Comply to MIDI standard
PUNCH IN / OUT
Connector Ø6 mm phone jack (CMOS level)
SCSI
Connector D-SUB 25-pin
Protocol SCSI-2, unbalanced transfer method
Transfer Type Asynchronous
Number of Units Connected 2
RECORD & PLAYBACK
Recording Medium Internal 3.5” E-IDE hard disk drive (optional)
External fixed / removable SCSI-2 hard disk drive
Standard SCSI-2 or better
Sampling Frequency 44.1 kHz, 48kHz (Switchable by SETUP mode)
Quantization 16-bit linear
Emphasis Not available
Recording Time (mono track min.) About 18 min. / 100 MB at maximum (at Fs: 44.1 kHz)
Recording time will be limited up to 24 hours.
Number of Tracks 24 tracks (8 + 16 additional tracks)
Number of recording tracks at a time 8
Number of playback tracks at a time 8
Recording Format FDMS-3
Pitch Control ± 6.0 %
Crossfade 10 msec
OPERATION
Shuttle Speed 8 steps (7 steps for FWD direction)
CUE ON ± 1 ~ 8 times (FWD: ± 1 ~ 7 times)
CUE OFF ± 1 ~ 64 times
FFWD / REW Speed
CUE ON ± 3 times
CUE OFF ± 32 times
4
D-108
OPERATION (continued)
Digital Scrubbing (JOG) 0 ~ 1 times (Envelope can be displayed when selecting only
one track.)
Locate Memory 6 (7 including [LOCATE] key temporary memory) + 99
LEVEL INDICATION
Type FL Bargraph
Number of Indicated Levels 11 dots (-∞, -42, -30, -24, -18, -12, -9, -6, -3, 0, OVER)
Reference Level (-10 dBV) Indication -12 dB
DIMENSIONS 148 (H) x 482 (W) x 381 (D) mm
WEIGHT 8 kg
POWER REQUIREMENT
JPN 100 V AC
USA / CND 120 V AC
EUR / UK 230 V AC
POWER CONSUMPTION Approx. 33 W
STANDARD ENVIRONMENT
Standard Temperature 20 ± 2 ºC
Standard Humidity 65 ± 5 %
ENVIRONMENT CONDITION (W/O HD)
Characteristics Guaranteed
Temperature + 5 ~ + 40 ºC
Humidity 30 ~ 70 %
AC voltage deviation ± 5 % or less
Operation Guaranteed
Temperature - 5 ~ + 45 ºC
Humidity 85 % or less
AC voltage deviation ± 10 % or less
CHARACTERISTICS
Overall Frequency Response 20 ~ 20 kHz +1, -2 dB
Signal to Noise Ratio 88 dB or more (between ADC and DAC)
Dynamic Range 88 dB or more (between ADC and DAC)
T.H.D. 0.008 % or less (at 1 kHz, -1 dBV)
Channel Separation 80 dB or more (at 1 kHz)
Phase Difference between Channels 20 º or less
8345
INPUT & OUTPUT
TIME CODE INPUT
Format SMPTE
Connector XLR-3-31 type (Pin 1: GND, Pin 2: HOT, Pin 3: COLD)
Standard Input Level 2 V p-p
Minimum Input Level 0.25 V p-p
5
D-108
TIME CODE OUTPUT

Format SMPTE
Connector XLR-3-32 type (Pin 1: GND, Pin 2: HOT, Pin 3: COLD)
Standard Output Level 2 V p-p
Minimum Output Level 0.25 V p-p
Load Impedance 20 kΩ or more
VIDEO INPUT
Format Composite (Applied video signal must comply to PAL or
NTSC standard and be interlace type)
Connector BNC
Frame Pulse 24, 25, 29.97, 30 Hz (± 1000 ppm)
Field Pulse 48, 50, 59.94, 60 Hz (± 1000 ppm)
Standard Input Level 1 V p-p
Input Impedance 75 Ω (ON / OFF by terminator SW)
VIDEO THRU
Connector BNC
Output Level Direct output of signal fed to Video Input connector
WORD INPUT
Connector BNC
Frequency 44.1, 48 kHz
Standard Input Level TTL level
Input Impedance 75 Ω (ON / OFF by terminator SW)
WORD OUTPUT
Connector BNC
Standard Output Level TTL level
Load Impedance 75 Ω (ON / OFF by terminator SW)
DIMENSIONS 215 (W) x 80 (D) mm
POWER SUPPLY Supplied from D-108
Digital DC + 5 V
Analog DC + 19 V / - 15 V
5040
INPUT (1 ~ 8)
Standard Input Level + 4 dBu
OUTPUT (1 ~ 8)
Output Level + 4 dBu
Load Impedance 600 Ω or more
DIMENSIONS 270 (W) x 70 (D) mm
POWER SUPPLY DC + 15 V (Supplied from D-160)
Specifications and appearance are subject to change without notice for product improvement.
6
D-108
2. CONTROLS, INDICATORS & CONNECTORS
< Front Panel Section with Detachable Controller >
AUTO RTN
CLIPBOARD AUTO PUNCH EXECUTE EXIT
AUTO PLAY IN OUT START IN OUT END DISP SEL /YES /NO
8TRACK DIGITAL RECORDER D-108

AUTO RTN TIME BASE SEL
COPY MOVE PASTE ERASE UNDO REDO HOLD/ STORE RECALL
POWER PGM SEL PREVIEW

AUTO
PUNCH REHEARSAL LOCATE VARI PITCH
TAKE
OPTICAL
ENVELOPE
RECORD STOP PLAY REWIND F FWD
RECORD TRACK
1/9 2/10 3/11 4/12 5/13 6/14 7/15 8/16 SHIFT
PUNCH
IN / OUT
LOCKED HD ACCESS TC IN CLIPBOARD PLAY

LOCATE ABS 0
LOCATE REC END
< Front Panel Section without Detachable Controller >
POWER
< Rear Panel Section >
ANALOG IN ANALOG OUT MIDI DATA OPTICAL SCSI

AC IN
4 3 2 1 4 3 2 1
INPUT OUTPUT THRU INPUT OUTPUT
8 7 6 5 8 7 6 5
7
D-108
< Front Panel Section without Detachable Controller >
POWER
1 2 3 6 4 7 5
1. Detachable remote controller connector (DSUB 15-pin) 5. Hard disk power LED (Green)
2. Power switch [POWER] 6. Removable hard disk cartridge slot
3. Controller mount 7. Lock / Unlock key
4. Hard disk access LED (Red)
< Detachable Controller Section >

12 13 14 15 16 19 23
8 9 10 32 31 30 17 18 24 20 21 22
AUTO RTN
CLIPBOARD AUTO PUNCH EXECUTE EXIT
AUTO PLAY IN OUT START IN OUT END DISP SEL /YES /NO

AUTO RTN TIME BASE SEL
COPY MOVE PASTE ERASE UNDO REDO HOLD/ STORE RECALL
PGM SEL PREVIEW

AUTO
PUNCH REHEARSAL LOCATE VARI PITCH
TAKE
OPTICAL
ENVELOPE
RECORD STOP PLAY REWIND F FWD
RECORD TRACK
1/9 2/10 3/11 4/12 5/13 6/14 7/15 8/16 SHIFT
43 PUNCH
IN / OUT
LOCKED HD ACCESS TC IN CLIPBOARD PLAY

LOCATE ABS 0
LOCATE REC END
40 41 42 11 35 36 34 28 29 26 25
33 37 38 39 27
8. Controller connection cable 20. Execute / Yes key [EXECUTE/YES]
9. Meter display 21. Exit / No key [EXIT/NO]
10. Record track select key [RECORD TRACK 1 ~ 8] 22. Recall key [RECALL]
11. Shift key [SHIFT] 23. Store key [STORE]
12. Auto play / Auto return key [AUTO PLAY/AUTO RTN] 24. Hold / Digit move key [HOLD/ ]
13. Clipboard in key [CLIPBOARD IN] 25. Jog / Shuttle dial
14. Clipboard out key [CLIPBOARD OUT] 26. Redo key [REDO]
15. Auto return start key [AUTO RTN START] 27. Undo key [UNDO]
16. Auto return end key [AUTO RTN END] 28. Erase key [ERASE]
17. Auto punch in key [AUTO PUNCH IN] 29. Vari pitch key [VARI PITCH]
18. Auto punch out key [AUTO PUNCH OUT] 30. Paste key [PASTE]
19. Display select key [DISP SEL] 31. Move key [MOVE]
8
D-108
32. Copy key [COPY] 38. Rewind button [REWIND]

33. Auto punch mode on / off key 39. Fast forward button [F FWD]
[AUTO PUNCH (REHEARSAL/TAKE )] 40. Locked LED [LED] (Green)
34. Locate key [LOCATE] 41. Hard disk access LED [HD ACCESS] (Green)
35. Record button [RECORD] 42. MIDI time code in LED [TC IN] (Green)
36. Stop button [STOP] 43. Punch in / out jack [PUNCH IN/OUT] (Phone)
37. Play button [PLAY]
< Rear Panel Section >

AC IN
4 3 2 1 3 2 1
8 7 6 5 8 7 6 5
50 44 45 51 49 46 47 48 52
44. Input jack [ANALOG IN 1 ~ 8] (RCA) 49. MIDI input / output / thru connector
45. Output jack [ANALOG OUT 1 ~ 8] (RCA) [MIDI INPUT/OUTPUT/THRU] (DIN 5-pin)
46. Data input connector [DATA INPUT] (Optical) 50. Panel A for optional card (Model 5041)
47. Data output connector [DATA OUTPUT] (Optical) 51. Panel B for optional card (Model 8345)
48. SCSI connector [SCSI] (D-SUB 25-pin) 52. AC IN connector [AC IN]
< Rear Panel Section with Model 8345 and 5041 >
61 53 54 55 62 56 57 58 59 60
VIDEO WORD TIME CODE

75Ω INPUT THRU 75Ω INPUT OUTPUT INPUT OUTPUT
ON OFF ON OFF
1 GND
2 HOT
3 COLD
BALANCE I/O
+4dBu INPUT +4dBu OUTPUT

AC IN
4 3 2 1 4 3 2 1
8 7 6 5 8 7 6 5
53. Video input terminating switch [75Ω ON/OFF] 58. Word output connector [WORD OUTPUT] (BNC)
54. Video input connector [VIDEO INPUT] (BNC) 59. Time code input connector [TIME CODE INPUT] (XLR)
55. Video thru connector [VIDEO THRU] (BNC) 60. Time code output connector [TIME CODE OUTPUT] (XLR)
56. Word input terminating switch [75Ω ON/OFF] 61. Balanced input connector [+4dBu INPUT] (XLR)
57. Word input connector [WORD INPUT] (BNC) 62. Balanced output connector [+4dBu OUTPUT] (XLR)
9
D-108
3. SOFTWARE UPDATE
Like the FD-4 and FD-8, the D-108 software can be updated through the SCSI port. This means that unscrewing and opening
up the D-108 top cover is not necessary to change the EPROMs. Please refer to the following explanation for correct software
updating procedures.
3-1. Method of Sending Software from Fostex Japan

There are two ways of sending the D-108 updated software.
1. Updated software in a removable medium (e.g. floppy disk, zip disk, etc.) to be sent via airmail
2. Updated software as an attachment file to be sent via Email
3-2. Required Tools

The following tools/equipment are required to update the D-108 software.
1. IBM PC/AT compatible computer with SCSI board
2. Removable type SCSI drive
3. Cable between the removable type SCSI drive and the SCSI board
4. Cable between the removable type SCSI drive and the D-108 (D-SUB 25-pin)
3-3. Software Updating Procedures

Presuming that the updated software is correctly sent and is copied into your computer.
1. Connect the removable type SCSI drive to the IBM PC/AT compatible computer SCSI port.
2. Insert the diskette to the removable type SCSI drive and format it by the computer on which Windows 95/98 is running.
3. Copy the updated software file to the removable type SCSI drive (diskette).
4. Set the removable type SCSI drive ID to 0 ~ 5 and connect to the D-108 SCSI port.
5. Turn on the power of removable drive and then D-108. While the system is booted up, do not forget to check the software
version as well as the programming date.
6. Select “SCSI” by the Drive Select SETUP menu (Drive_Sel.?) and press the EXECUTE/YES key.
7. After confirming that the D-108 recognizes the connected SCSI drive, insert the diskette with updated software file. The
D-108 is automatically put into the software updating mode and comes to a standstill at the display below.
SURE?
8. Pressing the EXECUTE/YES key will start updating the software. The display shows “Loading!”, “Writing!” and “Initial..”
in order and automatically returns to the above condition again. Check the displayed ROM version and date if the
software is correctly updated by the optional mode “4-2. Flash ROM & CPU Version” (page 11).
9. Eject the diskette with updated software file by the press of STOP or EXIT/NO key and insert the diskette formatted by
the D-108.
CAUTION:
1. The diskette in which the updated software file is copied must be formatted by IBM PC/AT computer, not by Macintosh.
2. If something wrong happens while updating the software (e.g. A blackout occurred while updating the software.), the D-
108 might not be able to boot up the system software inside the Flash ROM. In such a case, please refer to the section “4-
8. Flash ROM” (page 21).
3. The SCSI ID to be connected to the D-108 must be selected to 0 ~ 5. The SCSI ID “6” is used for backing up purpose
exclusively. The SCSI ID “7” cannot be used on the D-108 by technical reasons.
10
D-108
4. SERVICE MODE
There are various optional modes available in the D-108 Service Mode. Please utilize them when servicing the unit.
4-1. Putting D-108 into Service Mode
The way of putting the D-108 into Service Mode is as follow.
1) Insert a 3.5” E-IDE internal HDD into the HDD cartridge slot or connect an external SCSI recording/playback device
(SCSI ID: 0 ~ 5) to the D-108 SCSI connector.
2) Turn on the power of D-108.
3) While holding down the STOP button, press the DISP SEL key to select the SETUP menu and then press the EXECUTE/
YES key.
As shown below, by rotating the jog dial C.W. or C.C.W., various optional modes will be displayed in addition to the
general SETUP menus. In order to select a certain optional mode, press the EXECUTE/YES key while its menu is
displayed.
SETUP
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
*: Model 8345 is required.

: Optional Mode
Load_PGM? DiskFormat_? CW
NOs_Of_Event?
Drive_Sel.? Save_PGM?
Sync_Preset* Track_Exchange? Signature_Set?
DA_Test?
Not_Used? Tempo_Map_Set ?
Clock_Sel? Version? Standby_Disk? DisplayTest? TitleEdit_PGM01?
SampleRate? Self_Check? Delete_PGM01?
Device_ID? Flash_ROM? OffsetDisp? Click_ ?
Resolution? PrerollTime?
Digi.out? Freeblock_Check? InitialDisk? MidiSyncOut?
Digi.in? Rec_Protect? Ref._TC* OffsetMode? Frame_Rate?
SlaveType? Slave_Mode? 00h59m57s00f00sf

(MTC Offset)
4-2. Flash ROM & CPU Version

This mode is used to check the Flash ROM and CPU versions currently installed in the unit.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
11
D-108
In order to check the version number, press the “EXECUTE/YES” key while “?” is blinking.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
The example on the above indicates that the Flash ROM version is V1.01 and its programming date is December 25,
1998. In this condition, by turning the jog dial C.W. or C.C. W., the CPU version can be checked. The example below
indicates that the CPU version is V2.00 and its programming date is August 4, 1998.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
4-3. DA Test
This mode tests the signal flow from the DATA INPUT jack to the D/A converter. A S/P DIF digital signal (Fs: 44.1kHz)
must be input to the DATA INPUT jack to execute this test. Then, press the EXECUTE/YES key while “?” is blinking.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
If the D-108 is in a normal condition, “44.1kHz” and “DIGITAL” will be lit solid. The odd (1, 3, 5, 7 and L) and even (2,
4, 6, 8 and R) channels indicate the left and right input level of S/P DIF digital signal fed to the DATA INPUT jack
respectively.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
If the D-108 is not in a normal condition, “DIGITAL” and “EXT SYNC” on the display will blink and the bargraph meter
will not indicate any level.
12
D-108
4-4. Standby Disk

This mode makes the internal hard disk stop spinning for purposes such as “shock” test.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
If the EXECUTE/YES key is pressed when “?” is blinking, the “SURE” prompt will start blinking. If you would like to go
on, press the EXECUTE/YES key once again. The internal hard disk will stop spinning.
4-4. Display/Button Test

This mode tests if all the segments on the FL display, LEDs and buttons (switches) on the D-108 controller are correctly
working or not. To execute this test, press the EXECUTE/YES key while “?” is blinking.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
If the D-108 is in a normal condition, all the segments on the FL display will be lit solid (Dot matrix and bargraph meter
sections on the FL display will blink.) and all the LEDs on the top panel will start blinking.
: Blinking
MTC IN OFFSET
ABS SETUP CHASE
LOCATE
REMAIN PGM
OL FORMAT
0
3 SIGNATURE
6 TEMPO
9 L 44.1kHz 48kHz
12
18 -0.1%
24 COMPLETED!
30 R SURE?
42
MIDI CHASE
SAVE LOAD
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 EXT SYNC
60 50 40 32 26 20 15 12 10 8 6 4 2 1 0 OL DIGITAL
If the D-108 is not in a normal condition, faulty segments on the LCD display and/or LEDs on the top panel will remain
unlit.
In this condition, if the EXECUTE/YES key is pressed one more time, the Button Test can be executed. The Button Test
checks if each key/button and jog dial are working properly or not. The display below indicates that the PLAY button is
pressed and held down.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
13
D-108
The table below shows the relationship between the key/button/jog dial and the corresponding numbers appear on the
LCD display.
Key/Button No. Key/Button No. Key/Button No.

AUTO RTN/PLAY 01 ERASE 14 RECORD TRACK 5 27
CLIPBOARD IN 02 UNDO 15 RECORD TRACK 6 28
CLIPBOARD OUT 03 REDO 16 RECORD TRACK 7 29
AUTO RTN START 04 HOLD/ 17 RECORD TRACK 8 30
AUTO PUNCH IN 05 STORE 18 SHIFT 31
AUTO PUNCH OUT 06 RECALL 19 RECORD 32
AUTO RTN END 07 AUTO PUNCH 20 STOP 33
DISP SEL 08 LOCATE 21 PLAY 34
EXECUTE/YES 09 VARI PITCH 22 REWIND 35
EXIT/NO 10 RECORD TRACK 1 23 F. FWD 36
COPY 11 RECORD TRACK 2 24 SHUTTLE 00~07
MOVE 12 RECORD TRACK 3 25 JOG (C.W.) 51
PASTE 13 RECORD TRACK 4 26 JOG (C.C.W.) 49
In order to quit the Button Test, turn the jog dial C.W. or C.C.W. further after “51” or “49” is displayed respectively.
4-5. Self Check

This mode automatically tests the following points in order.
• SCSI port
• ATA (E-IDE) bus
• Option (Model 8345) bus
• MIDI in/out circuit
• S/P DIF digital signal in/out (44.1kHz)
• ADAT digital signal in/out (48kHz)
• 8345 vari-pitch circuit
• D-108 vari-pitch circuit
• A/D and D/A circuit (Input Monitor)
< Cable connection in “Self Check” mode >

AC IN
4 3 2 1 4 3 2 1
8 7 6 5 8 7 6 5
External SCSI Device
CAUTION: In order not to form a MIDI signal loop, connect the MIDI cable after putting the D-108 into the Service Mode.
14
D-108
To start the Self Check mode, press the EXECUTE/YES key when “?” is blinking.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
The D-108 automatically checks the before mentioned points. If the D-108 is working properly, the following appears on
the display with REC LED blinking.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
In order to go back to the normal display, press the EXIT/NO key or STOP button.
4-5-1. SCSI Port Check

If the D-108 does not recognize a SCSI device connected to the D-108 SCSI port, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
The following is considered to be the cause of problem.

• Bad cable connection, bad cable contact and / or the power of SCSI device is being turned off.
• SCSI device ID is not set to 0 ~ 5.
• MAIN PCB is defective. (bad soldering of U7, U8, J6, etc.)
If a removable type SCSI drive is connected and in case a disk is not inserted into the drive, the following prompt will be
displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
15
D-108
In the case that the inserted disk is not FDMS-3 formatted, the following prompt will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
Fs, DIGITAL IN, DIGITAL OUT and SLAVE MODE settings on the disk to be used when the Self Check test is executed
should be as follow.
• Fs: 44.1kHz
• DIGITAL IN: OFF (L: - R: -)
• DIGITAL OUT: ADAT
• SLAVE MODE: OFF
Even if the before mentioned prompt is displayed, pressing the EXECUTE/YES key would reach the next test.
4-5-2. ATA (E-IDE) Bus Check

This test checks if data can be properly read out from the preformatted internal hard disk .
If the “ALTERNATE STATUS” which indicates the hard disk condition cannot be read out, the prompt below will be
displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
If the data (SYSTEM ID) written by formatting the disk cannot be read out correctly, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8

• Breaking, shortage and / or bad contact of flat cable J12.
• Bad soldering of gate array U5 on the MAIN PCB.
16
D-108
Fs, DIGITAL IN, DIGITAL OUT and SLAVE MODE settings on the internal disk to be used when the Self Check test is
executed should be as follow.
• Fs: 44.1kHz
• DIGITAL IN: OFF (L: - R: -)
• DIGITAL OUT: ADAT
• SLAVE MODE: OFF
Even if the before mentioned prompt is displayed, pressing the EXECUTE/YES key would reach the next test. If the
EXECUTE/YES key is pressed with the “ATA Bus Check” prompt displayed, checking the SYSTEM ID on the SCSI
device will be executed. The current drive setting after the Self Check test will become “SCSI”.
4-5-3. Option (Model 8345) Bus Check

This test checks if the option bus (J9 on the MAIN PCB) to which the Model 8345 is connected is working properly or not.
If reading out and / or writing in data are not correctly executed, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8

• Bad connection and / or wrongly connected J9.
• Bad soldering of J9, U16, U17, U34, etc. on the MAIN PCB
4-5-4. MIDI In/Out Check

By connecting the MIDI IN and OUT ports, this test checks if the reply against the ID inquiry is correctly received. If not,
the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8

• Bad soldering of J2, U11, U19 and surrounding circuit on the MAIN PCB
17
D-108
4-5-5. S/P DIF In/Out (44.1kHz) Check

By connecting the DATA IN and OUT terminals, this tests checks if the S/P DIF signal output by itself is correctly
received. If the PLL circuit is not in a “LOCKED” condition, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8

* Defect on DIGITAL OUT
- No oscillation of resonator X1.
- Connector J4, gate array U5, U20 and / or surrounding circuit are defective.
* Defect on DIGITAL IN
- PLL circuit (U10 and surrounding circuit) are defective.
* The SETUP “DIGITAL IN” is set other than “L: - R: -”.
4-5-6. Adat In/Out (48kHz) Check

By connecting the DATA IN and OUT terminals, this tests checks if the ADAT digital signal output by itself is correctly
received. If the PLL circuit is not in a “LOCKED” condition, the prompt below will be displayed.
OL
0
3
6
9 48kHz
12
18
24
30
42
1 2 3 4 5 6 7 8

* Defect on DIGITAL OUT
- No oscillation of resonator X2.
- Connector J4, gate array U5, U20 and / or surrodunding circuit are defective.
* Defect on DIGITAL IN
- PLL circuit (U22, 23, 35, 36, 37, 38, 39 and / or surrounding circuit) are defective.
* The SETUP “DIGITAL IN” is set other than “L: - R: -”.
18
D-108
4-5-7. 8345 Vari-Pitch Circuit (48kHz) Check

The master clock is generated using the Model 8345 LRCK (J9 pin-24: EXT_LRCK). In the meantime, the adat digital
signal is generated based on this master clock. This test checks if the adat digital signal output by itself is correctly
received. If not, it means that the vari-pitch circuit does not work correctly. As a result, the prompt below will be displayed.
OL
0
3
6
9 48kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
If “adat error” is displayed in the before mentioned test, the above error prompt will be naturally displayed.
If the Model 8345 test is not installed in the D-108, this test will be skipped.

• Wrongly connected flat cable to J9 on the MAIN PCB.
• Bad soldering of J9, U9, U3 and / or surrounding circuit
4-5-8. D-108 Vari-Pitch Circuit (48kHz) Check

Using the master clock generated through the D-108 vari-pitch circuit on the MAIN PCB, the adat digital signal is output.
This test checks if the adat digital signal output by itself is correctly received. If not, it means that the vari-pitch circuit
does not work correctly. As a result, the prompt below will be displayed.
OL
0
3
6
9 48kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
If “adat error” is displayed in the before mentioned test, the above error prompt will also be naturally displayed.

• Defects on the vari-pitch circuit (U3, U9), gate array (U5) and / or surrounding circuit.
19
D-108
4-6. Offset Display

This mode determines if the offset value against a master machine should be displayed when the D-108 is working as a
slave machine. If you would like to turn ON the offset display, press the EXECUTE/YES key while “?” is blinking. (The
default setting is “off”.) Then, turn the jog dial C.W. to change the display to “ON” and press the EXECUTE/YES key.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
In order to check the offset value, select the “MTC” time base and the “REMAINING TIME” display. The display below
is an example of offset display.
OFFSET
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
CAUTION: There might be a case that the percentage value does not indicate “0.0%” exactly. This is caused by the
difference of internal clocks between master and slave machines, which are running independently.
4-7. Initializing Disk

This mode initializes a 3.5" internal E-IDE hard disk drive or an external SCSI device connected to the SCSI port.
CAUTION: 1. If both the external SCSI drive and the internal 3.5” E-IDE hard disk drive are connected at the same
time, currently selected drive by the SETUP menu “Drive_Sel?” will be initialized.
2. Up to 2 x SCSI drives can be connected to the D-108 at a time. One is for recording / reproducing (SCSI
ID: 0 ~ 5) and the other for exclusive backing up (SCSI ID: 6). Initializing is possible on the SCSI drive
(ID: 0 ~ 5) used for recording / reproducing only.
After pressing the EXECUTE/YES key, “SURE?” will start blinking in the FL display. In this condition, pressing the
EXECUTE/YES key one more time would initialize the recognized disk drive. This mode puts the disk back to the
condition originally formatted.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
20
D-108
4-8. Flash ROM

This mode is used when copying the system software from EPROMs to Flash ROM. As mentioned in the section “3.
SOFTWARE UPDATE” (page 10), the D-108 software inside the Flash ROM can be updated through the SCSI port.
However, if something wrong happens when updating the software (e.g. A blackout occurred while updating the software.),
the D-108 might not be able to boot up by the system software inside the Flash ROM.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
In this case, the following procedures must be taken.

1. Turn off the power of D-108 and turn the switch on the ROM CARD PCB assy to “EPROM” side.
2. Plug the EPROMs into the sockets on the ROM CARD PCB assy which will be supplied to you separately.
3. Connect the ROM CARD PCB assy to J10 (50-pin connector) on the MAIN PCB assy.
4. Turn on the power of D-108.
In this condition, the D-108 is booted up by the system software inside the EPROMs. The next procedures to take are as
follows.
1. Put the D-108 into the Service Mode, select “FlashROM” and press EXECUTE/YES key. (“SURE?” is blinking.)
2. Press the EXECUTE/YES key one more time to copy the system software from EPROMs to Flash ROM.
3. After the completion, turn the switch on the ROM CARD PCB assy to “FLMEM” side.
4. In order to confirm that the D-108 is correctly booted up using the system software inside the Flash ROM, turn off
the power, disconnect the cable connected to the J10 on the MAIN PCB assy and turn the power back on again.
5. After the confirmation, referring to the section “3. SOFTWARE UPDATE” (page 10), update the system software
inside the Flash ROM through SCSI port again.
4-9. Free Block Check

This mode is used to check the condition of the diskette inserted into an external SCSI drive connected to the D-108 or the
internal E-IDE hard disk drive. The drive to be checked is the one currently selected drive by the SETUP menu “Drive_Sel?”.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
Press the EXECUTE/YES key when “?” is blinking. The display indicates the free audio file numbers.
21
D-108
OL
0
3
6
9 44.1kHz
12
18
24
30
42
1 2 3 4 5 6 7 8
If the Free Block indicates a large number even after formatting and no signal is recorded or recorded signals are frequently
skipped, the diskette / hard disk drive can be judged to be in a bad condition.
5. ERROR CODE LIST

The chart below indicates the error code number and corresponding description. Since the error code list is basically
designed for our engineers to improve the software, the description is quite technical. If you find the D-108 with one of
the error codes displayed, we encourage you to update the software first. In case updating the software does not solve the
problem, we would like you to inform us about details.
D-108 ERROR CODE LIST

ERROR
DESCRIPTION
CODE
1 D-108 tries to access the address which does not exist.
3 SCSI drive does not boot up correctly when in SCSI access operation.
When saving system region sector, its address is registered in Free_block File during Free block File
9
checking procedure.
Link_pointer which links Audio File indicates smaller address (out of region) than Link_File address region
10
in RAM.
11 Link_pointer indicates larger address (out of region) than Link_File address region in RAM.
12 “Pointer_addre” calculation of Link_Pointer is not correct.
Link_Pointer during recording/reproducing indicates smaller address (out of region) than actual Link_File
14
address region.
Link_Pointer during recording/reproducing indicates larger address (out of region) than actual Link_File
15
address region.
16 “Pointer_addre” calculation of Link_Pointer during recording/reproducing is not correct.
20 src_cash_load: Improper access of link address occurred while PASTE editing.
21 bak_cash_load: Program link during PASTE/MOVE editing is incorrect.
22 bak_cash_load: Imcompatibility problem occurred on program link during PASTE/MOVE editing.
30 Error when executing MOVE editing. Improper Link Pointer. Error in “bak_cash_load” function.
35 Backup_Save:Error occurred when saving data to SCSI device.
36 Backup_Load: Error occurred when loading data from SCSI device.
38 Displayed in Test Mode only. SCSI device cannot be recognized during initial test.
40 dis_cah_load: Improper access occurred when recording/reproducing.
45 get_non_des_block: Remaining disk capacity is insufficient.
52 non_des_cash_save_sub: Improper access occurred when recording/reproducing.
60 remake_free_block: There was improper access to program management region.
62 remake_free_block: Number of manageable events exceeds limit.
64 remake_free_block: There is an overlapping section in program management region.
96 There was improper access to program management region.
97 There was improper access to program management region when saving System File.
99 There was improper access when fading in/out.
22
D-108
6. MODEL 8345/5040 INSTALLING PROCEDURES

CAUTION: When retrofitting both the MODEL 8345 and 5040 to the D-108, please make sure that the MODEL 5040 will
be the one to retrofit first.
1) Open up the top panel by loosening the following screws.

• 4 x BBT 3 x 8 BZN screws on both sides of top panel
• 2 x BBT 3 x 8 BZn screws on the top of top panel
• 2 x B 3 x 6 BZn screws on the rear side of top panel
2) Remove the blank panels by loosening 4 x BPT 3 x 8 BZn screws.
BBT 3 x 8 BZn
B 3 x 6 BZn
Top Panel
BBT 3 x 8 BZn
BBT 3 x 8 BZn
BBT 3 x 8 BZn
Blank Panel
PO PC
W B
ER
M
AI
N
PC
B
23
D-108
3) Loosen 4 x PWH 3 x 6 Ni scerws which fix the hard disk bay assy to the HD bracket. In this condition, the hard disk bay
can be moved towards the front panel so that the cable can be easily connected / disconnected.
4) Before fixing the MODEL 5040 to the D-108 rear panel, insert the 17-pin and 8-pin flat cables included in the MODEL
5040 package into the connector J13 and J14 on the D-108 MAIN PCB assy respectively.
5) Remove 4 x hex screws originally attached to the MODEL 5040 D-SUB connectors.
6) Fix the Bracket, B, 5041 (P/N: 8221206000) to the MODEL 5040 PCB assy.
7) Fix the MODEL 5040 to the D-108 rear panel by the following screws.
• 1 x B 3 x 6 BZn screws included in the MODEL 5041 package
• 4 x hex screws originally attached to the D-SUB connectors
8) Connect the following cables.
• 17-pin flat cable from the connector J13 on the D-108 MAIN PCB assy to the connector J4 on the MODEL 5040
PCB assy
PCB assy
• 4-pin connector cable W1 on the MODEL 5040 PCB assy to the connector J8 on the MODEL 5040 PCB assy
CAUTION: On the MODEL 5040 PCB assy, if the 8-pin connector to be connected to the J14 on the D-108 MAIN PCB assy
is mounted on the J5 location, the flat cable does not have to be twisted around. However, if the 8-pin connector
is mounted on the J6 location, the flat cable has to be twisted around to match the pin numbers.
To
MAIN PCB
J8
Bracket, B, 5041
(P/N: 8221206000)
MO
DE
L5
040
W1
J5
To
BBT 3 x 6 CZn MAIN PCB J4
J14
To
MAIN PCB
J13
BBT 3 x 8 BZn
Hex screw
(attached to D-SUB 25-pin connector)
PO PC
W B
ER
M
AI
N
PC
B
J1
4
J8
J1
3
24
D-108
9) Before fixing the MODEL 8345 to the D-108 rear panel, insert the 25-pin flat cable included in the MODEL 8345 package
into the connector J9 on the D-108 MAIN PCB assy .
10) Fix the MODEL 5040 to the D-108 rear panel by the following screws.
• 3 x B 3 x 6 BZn screws included in the MODEL 8345 package - Bracket section
• 4 x BBT 3 x 8 BZn screws included in the MODEL 8345 package - XLR connector section
11) Connect the following cables.
PCB assy
• 5-pin connector cable W3 on the MODEL 5040 PCB assy to the connector J1 on the MODEL 5040 PCB assy
To
MAIN PCB
J1
5
1 W3
J1
1
25 MO
DE
L8
345
BBT 3 x 8 BZn
BBT 3 x 8 BZn
25
PO PC
W B
J9
ER
1
M
AI
N
PC
B
1
J1
25
D-108
7. EXPLODED VIEW, PCB ASSEMBLY & PARTS LIST

D-108 OVERALL EXPLODED VIEW
Ref. No. Part No. Description
1 8212 5811 03 Panel, controller, D-series
2 8226 1852 05 Button, 11 x 5, E
3 8226 1842 08 Button, 6 x 6, H
4 8226 1842 02 Button, 6 x 6, B
5 8226 1852 04 Button, 11 x 5, D
6 8226 1831 05 Button, 11 x 11, E
7 8226 1831 04 Button, 11 x 11, D
8 8214 2700 00 Spring, 8 x 3, 0.2
9 8212 5830 01 Window, FL, D-108
10 N/A Both-sided tape, 10 mm (w) x 40 mm (H)
11 8221 1740 00 Panel, rear, remote, D-108
12 8212 5820 00 Lock, controller, D-series
13 8216 6281 00 Pad, controller, D-series
14 8277 3530 10 Cable assy, earth lug, D3-D3, L100
15 8277 4092 00 Cable assy, remote, D-series
16 8274 1700 00 PCB assy, Display, D-108
17 8216 6290 00 Sheet, remote controller, B, D-series
18 8216 6310 00 Sheet, remote controller, B, D-80
19 8226 1702 00 Knob, shuttle, D-10, D-series
20 8226 1711 01 Knob, jog, D-10, D-series
21 8221 2600 00 Panel, rear, D-108
22 8221 2101 00 Panel, blank, L
23 8221 2091 00 Panel, blank, S
24 8221 2591 00 Chassis, D-108
25 8274 1690 00 PCB assy, Main, D-108
26 8207 0130 00 Foot, FF1011
27 8274 1710 00 PCB assy, Power Supply, D-108
28 8274 2020 00 PCB assy, Regulator, D-108
29 8221 2610 00 Bracket, AC IN, D-108
30 8274 1720 00 PCB assy, Connect, D-108
31 8221 1710 00 Bracket, D-SUB, D-series
32 8274 1730 00 PCB assy, Power SW, D-108
33 8260 5240 00 Bay assy, HD
34 8221 2130 00 Bracket, HD, D-160/D-108
35 8216 6561 00 Belt, HD, D-series
36 8207 0117 01 Cord holder, CS-1
37 8221 1670 03 Panel, dress, D-108
38 8223 2942 00 Hook, controller, D-series
39 8226 0191 01 Escutcheon, B, No. 8
40 N/A Both-sided tape, 5 mm (W) x 20 mm (H)
41 8226 0130 04 Button, push, B, No. 8
42 8221 1730 00 Angle, back, 133
43 8221 2140 00 Panel, top, D-160/D-108
44 8276 8010 00 Cord, power, UL/CSA, VM0033-0089,
USA/CND
8276 8021 00 Cord, power, CEE, 0309B-0310B, EUR
8276 8000 00 Cord, power, DM, VM1292-1298
45 8360 5580 00 Controller assy, D-108
46 8218 7760 00 Label, caution, HD
47 8207 0116 00 Key, HD, D-series
26
D-108
D-108 OVERALL EXPLODED VIEW

BBT 3x8 BZn
35
P 3x5 CZn
B 3x6 BZn
BBT 3x8 BZn

33
P 3x5 CZn
47
43
BBT 3x8 BZn

30 B 3x6 CZn
31 36
32 34
B 3x6
CZn 23 BBT 3x6 BZn
44
28
21
BBT 3x8 BZn
BBT 3x6
29 BZn
BPT 3x8 BZn
B 3x6 CZn BPT 3x8

BZn
BPT 3x8 22
BZn
BBT 3x8
B 4x8 BZn 36 BZn
42
BTT 3x6 BZn
27 B 3x6
CZn W3 BZn 13
25 AZ-3
B 3x6
CZn
N3 Ni CZn
41 BTT 3x6 BZn
BBT 3x6 14
BZn
BPT 3x8 BZn
26
BBT 3x6 CZn
11
12
BBT 3x8
39 BZn
B 4x8 BZn
24
40 B 3x6 CZn 15
42
46 10
BPT 3x8 BZn
9 18
38
45
1
37
17
BBT 3x8 BZn
3
16
2
8
6
7
8
4 5
19
20
27
28
D-108
D-108 PCB PATTERN DRAWING
• Parts Side of MAIN / CONNECT PCB
J17 J18 J15 J16
J6
THRU
OUT
SCSI R914 J2
R916
J4 OUT J5 IN
IN
U257
U557
U657
U357
U457
U757
U857
MIDI
TP2 LOCK
U157
L101
L501
L201
L601
L301
L701
L401
L801
TP1 C60 L11 L12 L9 L10
C68
C50
R918 R919 R920 C62
C47
LOCK R913 L7 L8
14
C81
L3
C59
L6
R41
L4
VARI R33
L102
L502
L602
L302
L402
L702
L202
9 9 9 C9
4 4
BH9595
U22 R156 R256 R556 R656 R356 R456 R756 R856

U8
U9 U10 J13 16
TP8
9246 U2 2
9246 9246
LOCK2
C48 C26 C63 C80 5040
C57
1 17
C55
C116 C216 C316 C416 C516 C616 C716 C816 C801 C805
1 1 1
C56
C201 C205
C66
C51 C19 C7
U40 R924
D1
1
W12 C113 C213 C313 C413

R99 C923 C14
1
2
1 D5
50 26 1 1 1 1 1 1
1
C101 C105 C301 C305 C401 C405 C601 C605 C601 C605 C701 C705
C928
U153
U253
U353
U453
C99
51 U3 U4 U23 U37 U38 U39
4565
4565
4565
4565
25
00 00 74 86 74 74
R50
C916
5
8 8 8 8 8 8
C927
C71
C98
C929
U41 3
C82
R925
U7
C924
MB86604 R923 U11 C114 C214 J14 C314 C414 C104 C204 C304 C404 C504 C604 C704 C804
C922 PC410 5040
C46 9
2 C917
C918
8 5
IDE HDD
100 90 U19
5
U101
U201
U301
U401
U501
U601
U701
U801
2115
2115
2115
2115
2115
2115
2115
2115
TP9
C93
U24 157 1 7
J12
75 1 LOCK2B 32
76 100 1
3
1
80
C21 C111 C211 C311 C411 C511 C611 C711 C811
1
1
TP10 C161 C163 C261 C263 C361 C363 C461 C463 3
1
R917
R915
LOCK1B C103 C203 C303 C403 C503 C603 C703 C803
10
70
R9
36 1 R71
R7
RS422
37 144 U20
J3
C164
C264
C364
C464
DIG IF R904 C251 C253 C351 C353 C451 C453
C151 C153
C162
C262
C362
C462
20
C915
60
C77 13 13 13 13 C152 C252 C352 C452
R28
R95
8
R27
C909
5
U21 U14 U152 U252 U352 U452
U5 4320 4320 4320 4320
30
GA2 C157 C154 1 C257 C254 1 C357 C354 1 C457 C454 1

1 U12 1 1 1 1
C74 IC14 U151 U251 U351 U451
40 50 C167 C267 C367 C467
C906
5351 5351 5351 5351
R47
C75
C255
C355
C455
C155
C30
C166 C266 C366 C466

13 13 13 13
TP5
R96
R8
X3 C156 C256 C356 C456

72
2 73
109 C91 2
C94
108 R152 R252 R352 R452

40
57
39
85 56 8254973 201 PCB. MAIN D-108

R49 48 25 L1
22.5792
25
24.576
11
C76 C13 L2 C904

X1
X2
U18
245
R66 C3
TP4
C73
R48
U904 C6
U33
U15 5
1
D3 X4 9 14 8
C70
U30
C905
C97
U29 U13 C10
2103 5040
157 J8
D4 1 1 U1
1 C913 C914
TP3
1
R62
R63
C78
R64
R43
R65
112 4 1
OPTION
TP6 C87 29 1 POWER C1

R100
R45
J1001
11
W3
R93
J9
C96
R44
1 24 1 28 L1002
22
SELF L1005
U17
541
CHECK E C72 12 1
U16
139
U905 U903
L1001
8251973 002
L1003
L1004
EPROM C79 U53 PCB. CONNECT.D-108
1
TP7 HDD
9
49 J10 1 DGND W1
D8 D9 D10 D11 D12 D13 U902
C89 1
2
4 1 1 5 U54
1
1 7 1 7 1 7
R92 W9
J1 U901
J7 FRONT C18 W1001 W1002
8345
A B 50 C 2 D E F G H I POWER J MAIN
29
L1014
1
2
3
4
L1015
R807
7
L1013
L1012 R804 C808
L1011 C453 R805
C805
R803
L1010
C802 R809
L1006 R808
R806
R801
W1002
R704 R802
C708 C801
C702 C808 C705
R705
C451 R708
1
R707 R701
L1005
J
C456 R706
L1004 C701 R607
7
R703 R702 C608 C707 R609
J16
C353 R604 R709
R451 R603 C605
L1003 R605
17
L1009
16
R608
L1008 C602 R606
L1002 L1007 R601
R602 C601
W1001
R504 C607
L1001 C502 R505 C608 C505
C351 R508
R507
1
J1001
C356 R506 C501
R407
J13
R503 R501
R502 C408
C253 R404 C507 R509
C405
2
R351 R403 R409
1
R405
C914 R408
C402 R406
R401
D7
C401
I
R402 R304 C407
C907 C302
J15
R305 C308 C305
C904
R911 C251 R308 R307
C913 C256 R306 C301
C903 R207
R906 R912 R303 R301
D6
C2 R910 R909 R204 R302 C208 C307
C253 R309
R908 R251 R403 C205
R205
C4 C5 R208 R209
C202 R206
C1 R201
R202 R204 C207 C105 C201
C102 C108
R105 R108
C6 R151 C151 R107
C101
R53
R54
H
R106
• Foil Side of MAIN / CONNECT PCB
C3 R101
C156 R102 C107
J18
C915 R109
R103
1
C917 C916
5
1
R814
C465
J8
C463 C711 C815 C816
J1
R714
4
R811 C812
C461 C711 R813
1
R451 R812 C716
W3
R713 R614
C611R712
C11 C12 R711 C712
C365
1
C466
C363 C615 C715 C616
C511 R514
R611 C612
W1
R613
C361
J17
C10 C13
G
C516
4
R351
12
8
R612 R513
7
R512 R414
R511 C512
C265
J14
C415
TP3
TP4
C366
W9
C72 R411 C515 C416
2
C412 R314
1
C263 R413
R412
R251 C411 C316
R312 R313
7
C261 R214
D19 D18
R311 C312
C311
C266 C165
C163 C315 C216
C212 R114
J7
C211 R213
C161 C116
R151
F
C111 R113
1
C112
C166 C115
D17 D16 D15 D14

J3 C7
PCB. MAIN. D-108

C21
5 1
C8 C9
R52
C930 L3
R51 C54
C88 R94
J2
C80
C95
E
R73
C69 R74 C53
R72
R75
C28
R69 R12 R61 C16
R68 R58 R76
C29
X3
R70 R78 R60 C15

R59 TP8
C92
R39 L6
TP10
R46 R36 C61

TP5
R37R
R77 R35
9
R90 R84
C901 C86 C63
R42
C67
R3
R901 C83
U35
R57 C902
R56
2
1
C65
1
R2
R902
C919 C926 R40
R55
8
C64
C91 C84
9
TP2
10
U36
R38L4
C85 C49 C33
1
TP9
C925 C59 R10

20
19
R16
C100 C58 R11
TP1
J10
R31
C
C25 C20
R32
30
29
R30 R34
J4
C22 C52
R13
40
39
C35 C32 R6
8
R14 R5 C26
R18 D1
R17 R15 R89
U04
C46
C36 C31 C25 C912
1
50
49
R91 C48
R1
C34
R920
C911
R97 C39 C37
C23 C24
X4
C910
B
R26
W2 R20
C40
W14
J6
R29 R19
8
R921
R25 C41 C38
R919
C921
U34
R24 C42
R922
R23 C43
1
C920 R22 C44

25 R21 C45
1
A
40 30 20 10 2
2 24 39 29 19 9 1
R918
J9
TP7
TP6
1
2
3
4
D-108
30
D-108
• Parts side of DISPLAY PCB
D89 D89
D91 D90
D83 D82
D93 D92
D85 D84
D87 D86
J1 DGND
L3
R44
R45
R41
R46
R42
R43
C13
C12
L1
C3
U8
U9
C5 D73
C2 C1 C6 A.RTN CLIPBOARD AUTO PUNCH
15 1 L2
C4 R38 S15 DISP SEL EXECU/YES EXIT/NO
IN OUT START IN OUT END
DGND 140 114 100 98 78 W10 73 D76 S21 S22 S45 S46 S47 S31 DGND S37 S38 S41
R39
4
A.PLAY DGND
C20 W11
D15
C7
D21
D31
D22
D45
D46
D47
SPACER
D38
D37
D41
C19
D44
D34
D32
D75
D72
C21 SPACER
D35
D39
D40
S42
D43
3
X1 S34
RECALL
R40
UNDO
R37
D19
C22
R36
R65 C8 S44 S32
S43 S35 S39 S40
MOVE PASTE ERASE HOLD STORE
U3 Q1 S19 REDO
R29
COPY
D42
R49 R54 R35
C18
R62
C17
R59
R30 R63
U4 R55 DGND
R31 R60
D74
R50 D71 R34 S33
Q2 AUTO PUNCH
R56
REH R32 LOC
U5 R33
R61
C16
R58
Q3
R57
R51 D69 S36
TAKE V.PITCH
U6 D51 DGND
Q4 S20 D20
R52 D50
D36
D49
D33
U7
2
U13 1 6 31 33 55 62 70
R53 C15 D52
R10
R168
R16
R17
R18
R19
R20
C9
C11
D10
D14
R9
R8
R7
D13
D12
D11
R4
R3
R2
R1
W1
DGND
R6
R5
C81
R47
D95
U17
L5
C10
D64
D94
S8 S9
J2 9/16 SHIFT
D66
D70
U12
D68
D67
R67 DGND
S1 S2 S3 S4 S5 S6 S7
D65
1/9 2/10 3/11 4/12 5/13 6/14 7/15 S10 S11 S12 S13 S14
R21
C23
REC STOP PLAY REW FF
1
R48
D5
R15
D8
L4
R12 R13 R14 U16
D6
D3
R21
R22
R23
R24
U15
D4
D1
D2
8251511 100
D7
R66
R25
R26
R27
R28
D63 D62 D61 DGND D9 D-160 DISPLAY 1 8
LOCKED HD ACCESS MTC IN
• Foil side of DISPLAY PCB

L3
A.RTN
D86
D84
D92
D82
D90
D88
D73 L1
C2
C1
C5
C3
U8
U9
1 J1 15
C6
C4
L2
AUTO PUNCH CLIPBOARD
R43
C12
C13
A.PLAY
S41 S38 S37 S31 OUT IN S45 OUT IN D76 R38
D87
R42
D85
R46
D93
R41
D83
R45
D91
D89
R44
4
EXIT/NO EXECU/YES DISP SEL END S47 S46 START S22 S21 S15 R39 W10
71 78 98 114 140
W11 C20
17
D15
C19
D31
D47
D46
D45
D22
D21
C7
D41
D38
D37
80 65
D72
U14 C21
64LC75710 16 1
D35
D34
D32
D44
D43
D39
D75
R40
1
D40
3
X1
S42 S40 S39 S35 S34 S32 S44 S43 17 64 C22
D19
PASTE
R37
RECALL STORE HOLD REDO UNDO ERASE MOVE C8

R36
U1 U14 R65
S19
COPY Q1 H8/3B LC75710 U3
R29
D42
R63 R30 R35 R54 R49

R55 32 49
R60 R31 R34 U4
D74
33
R59
C17
R62
C18
S36 S33 R32 D71 Q2 24 41 48 R50

R56
V.PITCH LOCATE REH U5

R33 25 40
R57
D69 R51
TAKE S20 Q3
R58
C16
D51 A.PUNCH U6
D20
D36
D50 R52
R61
Q4
D49
D33
70 62 50 348 33 31 6 1 U7
2
C9
NJM2103
R53
5 U2
D52
1
R10
R20
R19
R18
R17
R16
D14
D10
D19
D12
R66
C11
U13
R7
R8
R9
R1
R2
R3
R4
D11
R5
R6
C15
D95
L5
D81
W1
D64
C23 R47
D94
U17
U12 C10 S9 S8 S7 S6 S5 J2
D70
D66
D67
D68
SHIFT 8/16 7/15 6/14 5/13

S14 S13 S12 S11 S10 R67
S4
D65
4 3 1
R48
FF REW PLAY STOP REC S3 S2 S1
L4
4/12
R28
R27
R26
R25
3/11 2/10 1/9

1
R15
D5
R14 2
R66
D8
R13 R12
C14
U16
D7
D6
R24
R23
R22
R21
D3
D4
D2
D1
8251511 100
U15
D61
D62
D63
D-160 DISPLAY D9
8 1
• Parts side of POWER / POWER SW / REGULATOR PCB
DGND
DGND
DGND
DGND
AC5.4A
T800mA 250V
Vdisp
AC5.4B
D+5
U1
D+5
PCB. POWER. D-108 L7
C1
D9 R13 J4
8251974301 7 TO FAN
1 J1
C5
F1 1 2
TO SWITCH U9
TO DISPLAY
C3
R3
D8
6
C4
R4 R16
C5 C30
PCB. REGULATOR. D-108
W1
J2
12
3 2
R5 Q2
U2 DGND
C22
D7 1 R14
C2
L1 R2 R15 D+5
1
D4 U10
8251974 303
C8 DGND
C4
C6
1 R8 D+12
4 C28 C31
C6 N.C.
U2
D+5
C25 T2 DGND
U5 L3 Q1
C15 A–15
C1 C2 AGND
C7 AGND
D6 R12
N.C.
D T1 C32 A+15
D10 C27
3 2 S ER2810
1
R10
L
C D1
D3 R11
L2 C29
C17 C12
C9 C10 U1
4049
1 D2
4 C16 R7 C14
N
L6
R1 R9 C13
C3 C18 C26 C11 TO REGULATOR L4
J5 D5
3 2 1
C19
L5 U3 1 6
U6
4 1
S1
CAUTION : FOR CONTINUED PROTECTION AGAINST RISK OF FIRE.
J3 REPLACE ONLY WITH SAME TYPE FUSE.
PRECAUTION : EN VUE DE LA PROTECTION CONTINUELLE CONTRE LES 8251974 302
RISQUES D’INCENDIE. REMPLACER AVEC LE MEME TYPE DE FUSIBLE. PCB. POWER SWITCH. D-108
D-108
31
32
D-108
• Foil side of POWER / POWER SW / REGULATOR PCB
R13 L7 PCB. POWER. D-108

C1
F1
J4 J1 8251974 301
7 1
C5 2 1
U9
U1 C3
6
C4
R16 D8 R14 R4 R3 D9
C30 C5
12 U10
R5 U2 2 3
U2 Q2 R15 R2
C2 D7 L1
C22 C8 C31 D4
1
C28
C4 C6
C6 R8 1 4
J2
C15
Q1 T2 L3
C25
C7 DGND
R12 C2 C1
C27 U5 J3
D10
R3 C32 T1 D6
R11 C29 D3 2 3
1
R10 AGND L
D1
C12 C10 L2
U1 L6
C17
C9
1 4
C16
C14 D2
C13
R6 R7 D5
C11
C26
C3 N
L4 C18 R1
PQ1CF2 J5 C19 R9
U6 L5
6 1 U3
D-108
D-108 Parts List

• MAIN PCB assy
Ref. No. Part No. Description DIODEs
8274 1690 00 PCB assy, Main, D-108 Ref. No. Part No. Description
B101 8251 9731 01 Plain PCB, Main, D-108 D001 8234 1050 00 VF, schottky, EK13
D002 N/A
ICs D003~006 8234 5028 00 ST, DAN202K
Ref. No. Part No. Description D007 8234 7506 00 ST, RB400D
U001, 002 8236 5403 01 ST, AN, regulator, NJM78M05DLA D008~019 8234 5028 00 ST, DAN202K
U003, 004 8236 5450 00 ST, TSSOP, 74VHC00
U005 8236 0818 00 QFP, DG, gate array, ASPI RESISTORs
U006 8236 5610 04 ST, DG, 74HCU04 Ref. No. Part No. Description
U007 8236 0828 00 QFP, DG, SCSI, MB86604L R001~003 8230 5081 01 ST, resistor array, 100Ω x 4, 5%, CN1J4
U008 8236 0829 00 SOP, DG, SCSI, terminator, R004 N/A
BH9595FP-Y R005~007 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U009, 010 8236 5034 00 ST, DG, VCO, TC9246F R008 8230 5001 03 ST, carbon, 1/10W, 1kΩ, 5%
U011 8234 5047 00 Opt., Photo, PC410 R009 8230 5005 62 ST, carbon, 1/10W, 5.6kΩ, 5%
U012 8236 5450 14 ST, TSSOP, 74VHC14 R010 8230 5003 32 ST, carbon, 1/10W, 3.3kΩ, 5%
U013 8236 5025 00 ST, AN, reset, NJM2103M R011 8230 5002 22 ST, carbon, 1/10W, 2.2kΩ, 5%
U014 8236 5701 01 ST, DG, driver, DTC114EK R012 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U015 8236 0838 02 QFP, DG, CPU, main, FD-8/D-108, R013 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5%
mask, SH7042, F28 R014 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
U016 8236 5451 39 ST, TSSOP, 74VHC139 R015 8230 5000 00 ST, carbon, 1/10W, 0Ω, 5%
U018 8236 5452 45 ST, TSSOP, 74VHC245 R017 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
U020 8236 0850 00 QFP, DG, gate array, DIF R019 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5%
U021 8236 5701 01 ST, DG, driver, DTC114EK R020 N/A
U022 8236 5034 00 ST, DG, vco, TC9246F R021~025 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U023 8236 5450 74 ST, TSSOP, 74VHC74 R026, 027 8230 5000 00 ST, carbon, 1/10W, 0Ω, 5%
U024 8236 5450 32 ST, TSSOP, 74VHC32 R028 N/A
U025~028 N/A R029 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5%
U030 8236 0840 11 TSOP, DG, from, M29F400T-400 R031 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U031~033 N/A R032 8230 5002 24 ST, carbon, 1/10W, 220kΩ, 5%
U034 N/A (14P) R033 8230 5005 61 ST, carbon, 1/10W, 560Ω, 5%
U035 8236 5600 86 ST, TSSOP, 74HC86 R034 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5%
U036 8236 5601 61 ST, DG, 74HC161 R035 8230 5007 51 ST, carbon, 1/10W, 750Ω, 5%
U038, 039 8236 5450 74 ST, TSSOP, 74VHC74 R037 N/A
U040 8236 5704 01 ST, DG, driver, DTA114EK R038 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5%
U041 8236 5701 01 ST, DG, driver, DTC114EK R039 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
U101~801 8236 5407 00 ST, AN, op amp, NJM2115M R040 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U151~451 8236 5407 00 ST, DG, ADC, AK5351 R041 8230 5005 61 ST, carbon, 1/10W, 560Ω, 5%
U152~452 8236 5053 00 ST, DG, DAC, AK4320 R042 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5%
U153~453 8236 5412 00 ST, AN, NJM4565M R043, 044 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U157~857 8236 5702 01 ST, DG, driver, DTC314TK R045~048 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
U901, 902 8236 5701 01 ST, DG, driver, DTC114EK R049 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5%
U903 8236 5708 01 ST, DG, driver, DTB114EK R050 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5%
U904 8236 5450 04 ST, TSSOP, 74VHC04 R051 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
U905 8236 5708 01 ST, DG, driver, DTB114EK
33
D-108
Ref. No. Part No. Description Ref. No. Part No. Description
R052 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5% R142~452 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
R053, 054 8230 5001 00 ST, carbon, 1/10W, 10Ω, 5% R156~856 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
R055, 056 8230 5005 61 ST, carbon, 1/10W, 560Ω, 5% R161~461 8230 5001 00 ST, carbon, 1/10W, 10Ω, 5%
R057 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5% R901 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
R058 N/A R902 8230 5005 61 ST, carbon, 1/10W, 560Ω, 5%
R059 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5% R903 N/A
R060 8230 5007 51 ST, carbon, 1/10W, 750Ω, 5% R904 8230 5005 61 ST, carbon, 1/10W, 560Ω, 5%
R061 8230 5008 22 ST, carbon, 1/10W, 8.2kΩ, 5% R905 N/A
R062~065 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5% R906, 907 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
R066 8230 5001 52 ST, carbon, 1/10W, 1.5kΩ, 5% R908, 909 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5%
R067 N/A R910~912 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
R068 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5% R913~917 8230 5002 21 ST, carbon, 1/10W, 220Ω, 5%
R069 8230 5002 22 ST, carbon, 1/10W, 2.2kΩ, 5% R918~922 N/A
R070 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5% R923 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5%
R071 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% R924, 925 8230 5002 23 ST, carbon, 1/10W, 22kΩ, 5%
R072 N/A R926, 927 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
R073 8230 5000 00 ST, carbon, 1/10W, 0Ω, 5%
R074 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5% CAPACITORs
R075 N/A ALU = Electrolytic type
R076 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5% CER = Ceramic type
R077 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% Ref. No. Part No. Description
R078 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5% C001 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R079~088 N/A C002 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F
R089 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5% C003 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R090 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% C004, 005 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F
R091 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5% C006, 007 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R092 8230 5004 73 ST, carbon, 1/10W, 47kΩ, 5% C008 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F
R093 8230 5004 73 ST, carbon, 1/10W, 47kΩ, 5% C009, 010 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R094 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% C011, 012 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F
R095 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5% C013 8232 1421 07 VT, ALU, 10V, 100µF, 20%, SME-VB
R096 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5% C014 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
R097 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5% C015 8233 5001 50 ST, CER, 50V, 15pF, 5%, CC20SL
R098 N/A C016 8233 5094 74 ST, CER, 25V, 0.47µF, 20%, KC30E
R099 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5% C017 N/A
R100 N/A C018 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F
R101~801 8230 5002 03 ST, carbon, 1/10W, 20kΩ, 5% C019, 020 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
R102~802 8230 5001 23 ST, carbon, 1/10W, 12kΩ, 5% C021 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R103~803 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% C022~025 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
R105~805 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5% C027 8233 5004 71 ST, CER, 50V, 470pF, 5%, CC20SL
R106~806 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5% C028 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
R107~807 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% C029 N/A
R108~808 8230 5002 03 ST, carbon, 1/10W, 20kΩ, 5% C030 8233 5004 71 ST, CER, 50V, 470pF, 5%, CC20SL
R109~809 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% C031, 032 8233 5002 20 ST, CER, 50V, 22pF, 5%, CC20SL
R110~810 N/A C033, 034 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
R111~811 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% C035, 036 8233 5002 20 ST, CER, 50V, 22pF, 5%, CC20SL
R112~812 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% C037~040 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
R113~813 8230 5002 72 ST, carbon, 1/10W, 2.7kΩ, 5% C041~045 N/A
R141~451 8230 5001 00 ST, carbon, 1/10W, 10Ω, 5% C047 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F
34
D-108
C048 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C153~453 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C049~051 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C154~454 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C052 8233 5001 50 ST, CER, 50V, 15pF, 5%, CC20SL C155~455 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F
C053~057 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C156~456 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C058 8233 5094 74 ST, CER, 25V, 0.47µF, 20%, KC30E C157~457 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C059 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C161~461 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C060 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F C162~462 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C061, 062 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C163~463 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
C063 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C164~464 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C064 8233 5001 50 ST, CER, 50V, 15pF, 10%, CC20SL C165~465 N/A
C065 8233 5094 74 ST, CER, 25V, 0.47µF, 20%, KC30E C166~466 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C066, 067 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C167~467 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C068~070 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F C901 8233 5004 71 ST, CER, 50V, 470pF, 5%, CC20SL
C071 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C902 N/A
C072 8232 1461 05 VT, ALU, 50V, 1µF, 20%, SME-VB C903 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C073 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C904 8232 1421 07 VT, ALU, 10V, 100µF, 20%, SME-VB
C074, 075 8233 5003 30 ST, CER, 50V, 33pF, 5%, CC20SL C905 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C076 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C906 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F
C077 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL C907, 908 N/A
C078 8233 5004 71 ST, CER, 50V, 470pF, 5%, CC20SL C909 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C079 N/A C910 N/A
C080 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C911 8230 5000 00 Resistor, carbon, 1/10W, 0Ω, 5%
C081 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F C912 8233 5003 30 ST, CER, 50V, 33pF, 5%, CC20SL
C082~087 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C913, 914 8232 1441 07 VT, ALU, 25V, 100µF, 20%, SME-VB
C088 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20%, CC20F C915 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C089, 090 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C916, 917 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
C091 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C918 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C092 N/A C919 8233 5004 71 ST, CER, 50V, 470pF, 5%, CC20SL
C093, 094 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C920, 921 N/A
C095 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL C922 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL
C096~099 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C923, 924 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
C100 N/A C925~929 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C101~801 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C930 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
C102~802 8233 5001 52 ST, CER, 50V, 0.0015µF, 5%, CC20SL
C103~803 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R MISCELLANEOUS
C104~804 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R Ref. No. Part No. Description
C105~805 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB E1301 8276 0010 00 Pin, header
C106~806 N/A J001 8245 0530 05 Connector, PI, jack, 8263, 5P, WHT
C107~807 N/A J002 8245 2970 00 Connector, PL, DIN, 5P, YKF51-5040
C108~808 N/A J003 8245 1711 05 Connector, PI, jack, 8283, 5P, WHT
C109~809 N/A J004 8245 5520 00 Connector, opt., GPIF32T
C110~810 N/A J005 8245 5530 00 Connector, opt., GPIF32R
C111~811 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J006 8245 3120 05 Connector, PL, jack, D-SUB, 25P,
C112~812 8233 5006 81 ST, CER, 50V, 680pF, 5%, CC20SL 70057-025, EMIFIL
C113~413 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R J007 8276 7770 35 Cable assy, 7P, WHT MT/F-MT/BS, L350
C114~414 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R J008 8245 0530 04 Connector, PI, jack, 8263, 4P, WHT
C115~815 N/A J009 8245 2720 25 Connector, PI, jack, FPC, 25P
C116~816 8232 1431 07 VT, ALU, 16V, 100µF, 20%, SME-VB J010 8245 3220 50 Connector, PI, jack, AMPMOD, 2mm,
C151~451 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB 50P, 176264
C152~452 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
35
D-108
Ref. No. Part No. Description DIODEs

J011 N/A Ref. No. Part No. Description
J012 8277 4771 22 Cable assy, FC, 40P/F-/B, core, L220, D001~015 8234 5007 00 HT, 1SS136
reverse D019~022 8234 5007 00 HT, 1SS136
J013 8245 2720 17 Connector, PI, jack, FPC, 17P D031~047 8234 5007 00 HT, 1SS136
J014 8245 2720 08 Connector, PI, jack, FPC, 8P D049~052 8234 5007 00 HT, 1SS136
J015~018 8245 2860 00 Connector, RCA, 4P, UKC21-3077 D061~064 8234 0191 00 Opt., V, LED, green, GL-2EG6
L001, 002 8242 5025 60 Core, ST, CDHR104, 56µH D065 8234 0100 00 Opt., V, LED, orange, GL-2HD6
L003, 004 8242 1962 23 Coil, PVT, 22µH, LF5.0S D066~068 8234 0191 00 Opt., V, LED, green, GL-2EG6
L005 N/A D069 8234 0100 00 Opt., V, LED, orange, GL-2HD6
L006 8242 1962 23 Coil, PVT, 22µH, LF5.0S D070~076 8234 0191 00 Opt., V, LED, green, GL-2EG6
L007~012 8242 5011 21 Filter, ST, EMI, MMZ2012, 121 D081~083 N/A
L101~801 8242 5011 21 Filter, ST, EMI, MMZ2012, 121 D084~095 8234 5007 00 HT, 1SS136
L102~802 8242 5011 21 Filter, ST, EMI, MMZ2012, 121
W001 8277 3184 20 Cable assy, 4P, 5395-CNC, L200 RESISTORs
W002 N/A Ref. No. Part No. Description
W003 8276 7360 35 Cable assy, 12P, 8263WHT-5395, #22, R001~010 N/A
L350 R012~037 N/A
W004~013 N/A R038, 039 8230 1381 54 HT, carbon, 1/4W, 150kΩ, 5%
W014 8230 5000 00 Resistor, carbon, 1/10W, 0Ω, 5% R040 8230 1381 05 HT, carbon, 1/4W, 1MΩ, 5%
X001 8256 1700 01 Resonator, ST, XTL, 22.579MHz, R041 N/A
FUP-FBB3A R042~046 8230 1381 01 HT, carbon, 1/4W, 100Ω, 5%
X002 8256 1700 02 Resonator, ST, XTL, 24.576MHz, R047 8230 1481 52 HT, metal, 1/4W, 1.5kΩ, 1%
FUP-FBB3A R048 8230 1381 01 HT, carbon, 1/4W, 100Ω, 5%
X003 8256 1790 01 Resonator, PT, CER, 7.00MHz, F5, R049~052 8230 1383 90 HT, carbon, 1/4W, 39Ω, 5%
EFOEN R053 N/A
X004 N/A R054~057 8230 1381 02 HT, carbon, 1/4W, 1kΩ, 5%
R058, 061 8230 1382 23 HT, carbon, 1/4W, 22kΩ, 5%
R059, 062 8230 1381 03 HT, carbon, 1/4W, 10kΩ, 5%
R060, 063 8230 1381 04 HT, carbon, 1/4W, 100kΩ, 5%
• DISPLAY PCB assy
R065 8230 1381 03 HT, carbon, 1/4W, 10kΩ, 5%
Ref. No. Part No. Description R066~068 8230 1381 54 HT, carbon, 1/4W, 150kΩ, 5%
8274 1700 00 PCB assy, Display, D-108
B101 8251 5111 00 Plain PCB, Main, D-108 CAPACITORs
ALU = Electrolytic type
ICs CER = Ceramic type
U001 8236 0704 03 QFP, DG, CPU, HD6433723, DISP, C001, 003 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF
FL_CTRL C002, 004 8232 8031 04 VT, CER, 50V, 0.1µF, +80-20%, YF
U002 8236 5025 00 ST, AN, reset, NJM2103M C005, 006 8232 1461 06 VT, ALU, 50V, 10µF, 20%, SME-VB
U003~006 8236 0781 01 PT, DG, driver, DTC114ES C007, 008 8232 8013 00 VT, CER, 50V, 30pF, 5%, SL
U007 N/A C009 8232 8031 03 VT, CER, 50V, 0.01µF, +80-20%, YF
U008, 009 8236 0782 01 PT, DG, driver, DTA114ES C010~013 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF
U012 8256 1090 01 Module, shuttle, SRGPHJ-A-3-2 C014 8232 8031 04 VT, CER, 50V, 0.1µF, +80-20%, YF
U013 8256 1730 00 Module, display, FL, CND1538D C015 8232 8031 03 VT, CER, 50V, 0.01µF, +80-20%, YF
U014 8236 0830 01 QFP, DG, VFD driver, LC75710NE C016 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF
U015~17 8236 0782 01 PT, DG, driver, DTA114ES C017, 018 8232 8031 03 VT, CER, 50V, 0.01µF, +80-20%, YF
C019 8232 8014 71 VT, CER, 50V, 470pF, 5%, SL
TRANSISTORs C020 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF
Ref. No. Part No. Description C021 8232 8013 00 VT, CER, 50V, 30pF, 5%, SL
Q001~004 8234 1008 02 VT, PNP, 2SA1150Y C022 8232 8031 04 VT, CER, 50V, 0.1µF, +80-20%, YF
C023 8232 8014 71 VT, CER, 50V, 470pF, 5%, SL
36
D-108
MISCELLANEOUS TRANSISTORs
E401 Jumper, F5.0 Q001 8234 1094 03 V, FET, 2SK2661, TO-220NIS
E402 Jumper, F7.5 Q002 8234 1034 00 V, PNP, 2SA1606
E403 Jumper, F10.0
E404 Jumper, F12.5 DIODEs
E405 Jumper, F20.0 Ref. No. Part No. Description
E406 Jumper, F30.0 D001 8234 1079 00 HT, 80V, 0.2A, MA171
J001 8245 1721 15 Connector, jack, 8283, horizontal, 15P, D002, 003 8234 1085 00 HT, fast recovery, D1NL40
WHT D004 8234 1080 00 V, 200V, 5.0A, MA649
J002 8245 2980 00 Connector, jack, phone, LGR4609-7000 D005 8234 1084 00 VT, schottkey, EK03W
L001~003 8242 1340 01 Filter, EMI, 6 hole D006 8234 1078 00 HT, 600V, 1.0A, D1N60-4084
L004, 005 8242 1860 13 Filter, T, EMI, LF7W-M3R2T D007 8234 1085 00 HT, fast recovery, D1NL40
S001~015 8253 1350 02 SW, PT, tact, SOR-112HS D008 8234 5039 34 HT, zener, MTXJ6.8
S019~022 8253 1350 02 SW, PT, tact, SOR-112HS D009 8234 1077 00 Stack, 500VAC, 1.5A, D2SBA60
S031~047 8253 1350 02 SW, PT, tact, SOR-112HS D010 8234 5052 00 VT, 600V, 1.7A, S2V60-4002
W001 Jumper, F10.0
X001 8256 1340 03 Resonator, PF, CER, 8.00MHz, F5, RESISTORs
EFOEN Ref. No. Part No. Description
Y701 8207 0100 11 Spacer, LED, 11 R001 8230 1386 29 HT, carbon, 1/4W, 6.2Ω, 5%
Y702 8207 0100 09 Spacer, LED, 9 R002 8230 1383 31 HT, carbon, 1/4W, 330Ω, 5%
Y703 8216 5910 00 Spacer, FL, DMT-8 R003 8230 1381 01 HT, carbon, 1/4W, 100Ω, 5%
R004 8230 1388 22 HT, carbon, 1/4W, 8.2kΩ, 5%
R005 8230 1382 02 HT, carbon, 1/4W, 2kΩ, 5%
R006 8230 1484 72 HT, metal, 1/4W, 4.7kΩ, 1%
• POWER SW PCB assy
R007 8230 1481 52 HT, metal, 1/4W, 1.5kΩ, 1%
R008 8230 1251 04 H, metal, 2W, 100kΩ, 5%, F20, RSS
8274 1730 00 PCB assy, Power SW, D-108
R009 8230 1386 89 HT, carbon, 1/4W, 6.8Ω, 5%
B101 8251 9743 02 Plain PCB, Power SW, D-108
R010 8230 1381 03 HT, carbon, 1/4W, 10kΩ, 5%
R011 8230 1384 72 HT, carbon, 1/4W, 4.7kΩ, 5%
R012 8230 5094 72 HT, nflame, 1/4W, 4.7kΩ, 5%, MHT
S1001 8253 4610 02 Switch, push, power, SDDLB1-B1-F2
R013 8230 1382 02 HT, carbon, 1/4W, 2kΩ, 5%
W1001 8277 1620 40 Cable assy, SIN1.8-SIN1.8, 400
R014 8230 1251 01 H, metal, 2W, 100Ω, 5%, F20, RSS
W1002 8277 1620 40 Cable assy, SIN1.8-SIN1.8, 400
R015 8230 1384 73 HT, carbon, 1/4W, 47kΩ, 5%
CAPACITORs
ALU = Electrolytic type
• POWER PCB assy
CER = Ceramic type
PES = Mylar type
8274 1710 00 PCB assy, Power, D-108
B101 8251 9743 01 Plain PCB, Power, D-108
C001, 002 8232 3542 22 VT, CER, 250V, 0.0022µF, 20%,
ECK-ZNS
ICs
C003 8232 3521 04 VT, PES, 250V, 0.1µF, 10%, ECQ-EKF
C004 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF
U001 8236 0028 01 DIP, DG, CMOS, 4049UB
C005 8232 3241 07 V, ALU, 400V, 100µF, 20%,
U002 8236 5409 00 VT, AN, regulator, AN1431T
SMH-VNSN, D2
U003 8234 1081 00 Opt., H, photo coupler, ON3171
C006~008 8232 3584 77 VT, ALU, 25V, 470µF, 20%, LXV, D10
U004 N/A
C009 8232 1444 76 VT, ALU, 25V, 47µF, 20%, SME-VB
U005 8236 5410 06 V, AN, power, MIP166
C010~013 8232 3584 77 VT, ALU, 25V, 470µF, 20%, LXV, D10
U006 8236 0853 00 V, AN, DC-DC, PQ1CF2
C014 8232 1441 07 VT, ALU, 24V, 100µF, 20%, SME-VB
U007 N/A
C015 8232 3584 77 VT, ALU, 25V, 470µF, 20%, LXV, D10
U009 8234 1095 00 V, thermistor, NTH18D8R0LA
U010 8236 0853 00 V, AN, DC-DC, PQ1CF2
37
D-108
Ref. No. Part No. Description • REGULATOR PCB assy

C016, 017 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF Ref. No. Part No. Description
C018, 019 8232 3542 22 VT, CER, 250V, 0.0022µF, 20%, 8274 2020 00 PCB assy, Regulator, D-108
ECK-ZNS B101 8251 9743 03 Plain PCB, Regulator, D-108
C020, 021 N/A
C022 8232 8031 03 VT, CER, 50V, 0.01µF, +80-20%, YF Ref. No. Part No. Description
C023, 024 N/A U001 8236 0321 06 IC, 220, AN, regulator, NJM7815FA
C025 8232 3491 03 VT, PES, 630V, 0.01µF, 10%, U002 8236 0348 06 IC, 220, AN, regulator, NJM7915FA
ECQ-EKF C001~004 8232 8031 03 Capacitor, VT, CER, 50V, 0.01µF,
C026, 027 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF +80-20%, YF
C028 8232 8031 03 VT, CER, 50V, 0.01µF, +80-20%, YF C005, 006 8232 1431 06 Capacitor, VT, ALU, 16V, 10µF, 20%,
C029 8232 8014 71 VT, CER, 50V, 470pF, 5%, SL SME-VB
C030 8232 4383 37 V, ALU, 50V, 330µF, 20%, LXV W001 8276 7300 20 Cable assy, 6P, 8263WH-5395, L200
C031 8232 1464 76 VT, ALU, 50V, 47µF, 20%, SME-VB
C032 8232 8031 03 VT, CER, 50V, 0.01µF, +80-20%, YF
MISCELLANEOUS • CONNECT PCB assy

E301 8239 0002 00 Holder, PI, fuse, S-N5057 8274 1720 00 PCB assy, Connect, D-108
F001 8239 0007 08 Fuse, SEMKO, timelag, 0.8A B101 8251 9730 02 Plain PCB, Connect, D-108
J001 8245 0530 07 Connector, PI, jack, 8263, 7P, WHT
J002 8245 0530 12 Connector, PI, jack, 8263, 12P, WHT Ref. No. Part No. Description
J003 8245 3210 00 Connector, PL, jack, AC INLET, 3P, J1001 8245 2960 00 Connector, PL, jack, D-SUB/F, 15P-HD
AP-320V L1001~05 8242 1860 13 Filter, T, EMI, LFW7B-M3R2T
J004 8245 0530 02 Connector, PI, jack, 8263, 2P, WHT L1006~15 8242 5011 21 Filter, ST, EMI, MMZ2012, 121
J005 8245 0530 06 Connector, PI, jack, 8263, 6P, WHT W1001 8276 7310 20 Cable assy, 7P, 8263WHT-5395, #22,
L001 8242 2491 93 Filter, line, 19MH, 0.5A, ELFI5N005A L200
L002 8242 2491 02 Filter, line, 1MH, 2.2A, ELFI5N022A W1002 8245 1711 07 Connector, PI, jack, 8283, 7P, WHT
L003 8242 2501 03 Coil, pvt, 10µH, 2A, ELC
L004 8242 2640 01 Coil, DC-DC, R17, 256µH
L005, 006 8242 1340 01 Filter, EMI, 6 hole
L007 8242 2620 00 Coil, DC-DC, RCH110, 180µH
T001 8242 2580 00 Transformer, sw power, ER2810, 12-18
T002 8242 2600 00 Transformer, DC-DC, EE1605, AC5CT
Y501 8207 0126 02 Heat sink, 17PB23, L25, B
Abbreviation
Y502~504 8207 0015 00 Heat sink, OSH-1625-SP S: Surface mount
Y505 Screw, P3 x 6 CZn T: Taping device
F: Forming device
P: Penetrate mount
V: Vertical mount
H: Horizontal mount
I: I form
L: L form
QFP: Quad Flat Package
SOP: Small Outline Package
TSSOP: Thin Shrink Small Outline Package
DIP: Dual In-line Package
220: TO-220 type
DG: Digital
AN: Analog
38
8345 PCB PATTERN DRAWING
• Parts Side of 8345 PCB
TC OUT TC IN OFF ON OFF ON
L8 VIDEO VIDEO
TC OUT R70 J4 J3 THRU IN
R32 J6 J5
R18
R19
S1
R26
L9 WORD
R16
S1
C30
R21
C86
OUT IN 1 1
C18
R3
C22
R9
L1
D7
C21
C59 U8 U13 C19
C32
R2 C17
3 R4 R17 D5 SN75124 HC04
C16 1 R20 R22
R51
C60
R75 C85 D3 8 1 1 C23
C24
C31 9
R27
C34
L10
U9 D4
5
C42
D8
U11
R23
R69 C25
R5
C29 SN75123
U5
C84 U10
R31
R30
C9 D2 D1 D6 NJM2207
L4
R28 9 C62 C61 C46
C26
1 8 5 NJM592
R50
C7 R10 R12 R11 C15 D14 D15 D12 A+5 C12
22 12 U20
L3
C43
C20
C44 C48
C11
C47
R8
R6
R15
1 23 11 TC9246
R52
R53
C8 R25 C63 R24
U4 C45
R41
R1 U24 U27 U26 9
2
L5
C93 1 19 1 8 R55 R43 TP3 1
R33
L2
TCR
C49
HC04 50 C91 R65 C65
U12 R54 3130 EXT U21
C90
C76
C27
20 64 28MHz
C77
U3 8 51 R56 C64
C40
HC74 TC9246
C79
33 1 C78 R48 R49R59 R58 C68
TCG
C50
5 C83 1 R42 U15 9
34 44
L6
1
C52
C35
C41
U6 VCO
R34
C28
C94 U29 U28 R57
C95
NJM4580
U22 U23
C89 R61 C88R63 R64 C92 31
R73 U16 U19 50 30 R44
CLK GR 51
C81
C33
C36
C51
R47
R74 5 NJM2115
R76
32
C37 R45
R72 52
C80
C69 C58 D3
31
33 51 TP1:28MHz R67
R66
R68
R13
D11
C10
C14 C57
R46
U1
U18
C55
C82
R71 C5 78M05 U14 TP2
R38 1 C38 R60 R35 1 U17 4.8MHz
HCU04
C66 C56
D10
80 81
R14
R29 100 U25 CLK GR
R37
1
D9
C2
C73
R39 C4 HCU04
C72
R40
C87
R36
C71
C6 8
5
W1 8
C53
C54
U7
R62
W3
X1
C1
HC00 J1 2 24 W2 1
C7 80 100
1 C70 1 1 25 C75 X2 C74 81
C67 C13
C3 U2 C39
PCB. TC/SYNC. CARD. 8345
1
79M05
L7
A B C 8251961 201 D E D+5
F G
• Foil Side of 8345 PCB

J5 J6 J3 J4 L8 TC TC
OUT OUT TC
IN THRU IN OUT S
S2 IN S1 L9 OUT
1
VIDEO WORD H G G
C19
C59
1 C 3
L1
J7 S C H J8
C16
A–5
9
C25
C84
L10
C9
C46
A–5
L4
C12
9 AGND
C15
A+5
C48
C45
4.8MHz
L3
A+5
2
L5
L2
VCC VIN
TP2 TP3
EXT
L6
4.8MHz U15 28MHz

EXT
OUT GND
C51
28MHz
D13
D11
C14
C5
TP1
D9
R38
D+5 28MHz
C38
D10
A+5
R39
C4
X1
5
24 2 AGND C6
X2
J1
W3
C13
C7
16MHz 1
L7
C70
C3
A–5
25 1
1
G F E D C B A
D-108
39
40
W101 R104 R103

R102
C105 C103
R101 R813 L804
C812
C102 1
R107 R106 R105
R202
C807
R207 R204 R205 U801 L803
C26
C813
A
R814
C101
R201 5
17
C203
C25
C202 L101
16
R713 L704
I
C712
5041 only
R203
R302 L102 1
13
C201
J3
25
L201
BAL OUT 1-8CH
C707
R303
R301
C713
U701 L703
C24
R714
J4
C302 L202
R402 5
C303
C23
C205 W201 W301 C305
TO MAIN
R307 R306 R305 L604
L301
C612
R407 R404 R405 C301 R613
R401 1
L302
1
C403
C402
14
C607
U601 L603
2
L401
C22
C613
R614
1
R403
R502
C401
C405 W401
L402 5
C21
W501
J1
R501 L504
C512
L501 R513
B
C505 C502 1
R602 L502
BAL IN 1-8CH
C507
U501 L504
C513
C20
C507 R506 R505 C501 L601
R514
• Foil Side of 5040 PCB

5251958 101
R607 R604 R605 R601 5
C19
C602 L602
• Parts Side of 5040 PCB
L404
H
C412
C605 R702 R813
R503 C503 C603 R603

L701 1
W601 C601
C407
R701 L702 U401 L403
C18
C413
R414
W701 C702
14
L801
1
C705 R802 5
C703
C701 L802 C17 L304
C312
R707 R313
C104 C204 R206 R304 C304 C404 R406 R504 C504 C604 R606 R704 C704
C707 R706 R705 R801 1
R807 R804 R805 C802
C803
C307
U301
C16
25
L303
C313
C9
R314
13
C805
C801 5
C
C15
W801
5040 PCB PATTERN DRAWING
L204
C212
R806 R803 R213

1
C804
C10
1
C207
U201
C213
C14
G
R214
R916 L203
C46 R909 5
C13
W1
U903
R912
C112
L903
TO MAIN
R113 L104
R910 C911 R915 1
C913
C45 C907
4
C107
U902
C909
C910 U101
C12
C908
C113
L904
R114
R908 R911 C912 5 L104

R1016
C11
U1003
R1009 R1012
L1003 L1604
R1010 C1011
C27
C28
PCB BALANCE I/O. 5040/5041
R1015
C1612
C1007 C1013 R1613

C1010
U1002
C1009
C1008
D
R1008 R1011 L1004 1

L1603
R1116 C1012
W1
C1613
R1109 R1112
C1607
U801
R1614
C44
U1103
TO MAIN
BAL OUT
R1110 C1111 L1103 5

C1107 R1115 L1504
C43
1
R813
C1512
5040 1-8CH
13
C1110 C1113
C1109
2
5041 9-16CH
C1108
J2
25
U1102
F
R1108 R1111 1
L1104
R1216 L1503
C1513
C1112
C1507
R1209 R1212 U801

C42
R1514
7
U1203
(5041 only)
J5
8
J5
R1210 C1211
L1203 5
C41
C1207 L404
1
TO MAIN
R1413
1
C1412
C1210 C1213 R1215
C1209
14
C1208
2
R1208 R1211 1
U1202
L1204
E
L1403
17
R1309 R1312 R1316
C1407
C1413
C1212 U1401
16
C40
R1414
J2
R1310 C1311
U1303
C1307 5
C39
L1303
C1310
C1312
R1313
C1309
C1308 C1313 R1315 L1304
BAL OUT 9-13CH
R1308 R1311 1
TO MAIN
J5
U1302
L1304
TO MAIN
C1307
R1409 R1412 R1416 U1301 L1303

C1313
C38
R1314
C1312
R1410 C1411
C1407 5
U1403
C37
E
16
C1410 L1403
17
R1213
C1409
C1408 R1415
2
L1204
C1212
R1408 C1413
1
1
R1411
14
U1402
1
8
R1509 R1512
C1207
L1404 U1201
C36
R1516
7
L1203
R1214
C1213
R1510 C1511 C1412

C1507 5
C35
U1503
C1510
C1509
C1508 R1515 L1503 R1113
C1112
R1508 C1513
25
R1511 1 L1104
TO MAIN
13
U1502
R1609 R1612
C1107
U1101
C34
C1113
R1616 L1504 L1103

C1512
F
R1610 C1611
R1114
1 J6
C1507 5
C36
C1609
C1610
U1603
C1608 R1013
R1608 R1615 L1603 1
C1012
R1611 C1613 L1004
D
(50401 only)
C1007
C27 C28 U1001

C32
U1602
C1013
R914
L1604 5 L1003
C1612
C31
R116
R109 R112
R913
U103
1
R110 C111 L103
C912
C45
C107 L904
4
C907
R115 U901
C109
C30
C108 C110 C113

U102
R914
R108 R111 5
C913
L104
C29
L903
C46
R209 R212 R216

W1
C112
TO MAIN
U203
F
R210 C211
C207 L203
R215
C10
C209
1
C208 C210 C213

R208 R211
U202
L204 C806
R316
C9
R309 R312
C
C212
13
C805
5040 & 5041
1-8CH
BAL IN
J1
R310 C311 5
25
C801
U303
C307 R315 L303

C309
C310 C313
C8
C7
C308 U4
C802
R308 R311 L802

1
U302
R409 R412 R416 L304 L801

C701
C312
C705
1
14
R410 C411 C706 L702

C407
C702
U403
R415 C606
C409
C410 C413 L403 L701

C408
R408 R411
C801
L602
J3
C605
U402
5
H
R509 R512 R516 L404

L601
C602
C412
C6
C5
R510 C511 U3
BAL OUT 1-8CH
C507 L502
U503
R515
C501
C509
C510 L503 1
C508 C513 L501
R508
C505
R511
C502
U502
R616 C506 L402

R609 R612 L504
1
C512
2
C406 L401
R610 C611
C401
C607
U603
R615 L302
C405
C609
C610 L603
14
C608 C613 5
C402
R708 R611 L301

C4
C3
U2
U602
R709 R716 L604 L202

C301
R712
PCB BALANCE I/O. 5040/5041
C612
J4
1
R710 C711 L201
TO MAIN
C302
C707
U703
25
C305
R715
C709
L703
13
C708 C710 C613 C306 L102

R708
C801
R711 C206 L101

I
U702
R816
16
R809 R812 L704

17
C202
C205
C712 5
R810 C811
A
U803
C807 R815
C101
C2
C1
L803 U1
C809
C808 C810 C813

R808 R811 1
C102
U802
L804
C105
C812
C106
D-108
D-108
8345 Parts List

• 8345 PCB assy
N/A PCB assy, 8345 R005, 006 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
B101 8251 9612 01 Plain PCB, 8345 R007 8230 5002 02 ST, carbon, 1/10W, 2kΩ, 5%
R008 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
ICs R009 8230 5004 73 ST, carbon, 1/10W, 47kΩ, 5%
Ref. No. Part No. Description R010 8230 5001 51 ST, carbon, 1/10W, 150Ω, 5%
U001 8236 5403 01 ST, AN, regulator, NJM78M05DLA R011, 012 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5%
U002 8236 5404 01 ST, AN, regulator, NJM78M05DLA R013, 014 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5%
U003 8236 0619 00 QFP, DG, gate array, TCG R015, 016 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U004 8236 0762 00 QFP, DG, gate array, TCR R017 8230 5007 50 ST, carbon, 1/10W, 75Ω, 5%
U005 8236 5055 00 ST, AN, comparator, NJM311M R018 8230 5001 00 ST, carbon, 1/10W, 10Ω, 5%
U006 8236 5031 00 ST, AN, op amp, NJM4580E R019, 020 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5%
U007 8236 5600 00 ST, DG, 74HC00 R021 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5%
U008 8236 0185 00 DIP, DG, TTL, SN75124 R022, 023 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
U009 8236 0793 00 DG, line IF, SN75123 R024 8230 5003 32 ST, carbon, 1/10W, 3.3kΩ, 5%
U010 8236 7210 00 ST, AN, NJM592M R025 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U011 8234 7211 00 ST, AN, NJM2207M R026 8230 5007 50 ST, carbon, 1/10W, 75Ω, 5%
U012 8236 5600 74 ST, DG, 74HC74 R027, 028 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
U013 8236 5600 14 ST, DG, 74HC14 R029~032 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U014 8236 5610 04 ST, DG, 74HCU04 R033 8230 5002 22 ST, carbon, 1/10W, 2.2kΩ, 5%
U015 8236 1780 00 Module, VCO, 28.224MHz, F100 R034 8230 5006 81 ST, carbon, 1/10W, 680Ω, 5%
U016, 017 8236 8200 00 QFP, DG, gate array, µPD65640GF- R035 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
215-3BNEC, NEWCLK R036 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U018 8236 5701 01 ST, DG, driver, DTC114EK R037 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
U019 8236 5050 11 ST, AN, op amp, NJM2115M (TEI) R038, 039 8230 4001 00 H, metal, 1W, 10Ω, 5%
U020, 021 8236 5034 00 ST, DG, VCO, TC9246F R040 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U023 8236 5701 01 ST, DG, driver, DTC114EK R041 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5%
U024 8236 5600 04 ST, DG, 74HC04 R042 8230 5001 52 ST, carbon, 1/10W, 1.5kΩ, 5%
U025 8236 5610 04 ST, DG, 74HCU04 R043, 044 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U026 8236 5701 01 ST, DG, driver, DTC114EK R045, 046 8230 5002 71 ST, carbon, 1/10W, 270Ω, 5%
U027 8236 5704 01 ST, DG, driver, DTA114EK R047 N/A
U028 8236 5701 01 ST, DG, driver, DTC114EK R048, 049 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U029 8236 5704 01 ST, DG, driver, DTA114EK R050~053 8230 5001 52 ST, carbon, 1/10W, 1.5kΩ, 5%
R054 8230 5002 24 ST, carbon, 1/10W, 220kΩ, 5%
DIODEs R055 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
Ref. No. Part No. Description R056 8230 5002 24 ST, carbon, 1/10W, 220kΩ, 5%
D001~008 8234 5028 00 ST, DAN202K R057 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
D009, 010 8234 2024 01 Opt., LED, red, SLR-40VR R058, 059 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5%
D011~013 N/A R060 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5%
D014, 015 8234 5028 00 ST, DAN202K R061 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
R062 N/A
RESISTORs R063 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
Ref. No. Part No. Description R064 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
R001 8230 5002 72 ST, carbon, 1/10W, 2.7kΩ, 5% R065 N/A
R002 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% R066, 067 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
R003 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% R068 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
R004 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5% R069 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
41
D-108
R070 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% C068 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
R071 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5% C069 8233 5002 20 ST, CER, 50V, 22pF, 5%, CC20SL
R072 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% C070 8232 1431 07 VT, ALU, 16V, 100µF, 20%, SME-VB
R073 8230 5002 02 ST, carbon, 1/10W, 2kΩ, 5% C071, 072 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
R074 8230 5001 51 ST, carbon, 1/10W, 150Ω, 5% C073~075 N/A
R075 8230 5004 73 ST, carbon, 1/10W, 47kΩ, 5% C076~082 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
R076 230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% C083 8233 5105 62 ST, CER, 50V, 5600pF, 10%, CC20B
C084 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
CAPACITORs C085, 086 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL
ALU = Electrolytic type C087 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
CER = Ceramic type C088, 089 8233 5004 71 ST, CER, 50V, 470pF, 5%, CC20SL
PES = Mylar type C090 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
Ref. No. Part No. Description C091~094 N/A
C001, 002 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C095 8233 5002 22 ST, CER, 50V, 0.0022µF, 5%, CC20SL
C003 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
C004 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB MISCELLANEOUS
C005, 006 8232 1461 05 VT, ALU, 50V, 1µF, 20%, SME-VB Ref. No. Part No. Description
C007 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J001 8245 2720 25 Connector, PI, jack, FPC, 25P
C008 8233 5105 62 ST, CER, 50V, 5600pF, 10%, CC20B J002 N/A
C009 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB J003~006 8245 3000 00 Connector, jack, BNC, 01K0083
C010, 011 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R J007 8245 2680 02 Connector, PL, jack, XLR31,
C012~016 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB NC3FAH2
C017, 018 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL J008 8245 2670 02 Connector, PL, jack, XLR31,
C019 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB NC3MAH
C020 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R L001 8242 1860 13 Filter, T, EMI, LFW7B-M3R2T
C021, 022 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL L002~006 8242 1962 23 Coil, PVT, 22µH, 5%, LF5.0F
C023, 024 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R L007 8242 1350 01 Coil, 50µH, SKP-2-30
C025 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB L008~010 8242 1860 13 Filter, T, EMI, LFW7B-M3R2T
C026~033 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R S001, 002 8253 6550 04 SW, slide, 1-2, non shortening, SSSF1
C034 8233 5002 21 ST, CER, 50V, 220pF, 5%, CC20SL TP001~003 N/A
C035, 036 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
C037 8233 5005 60 ST, CER, 50V, 56pF, 5%, CC20SL ACCESSORIES
C038 8233 5003 00 ST, CER, 50V, 30pF, 5%, CC20SL Ref. No. Part No. Description
C039 8233 5002 20 ST, CER, 50V, 22pF, 5%, CC20SL Y101 8221 2150 00 Bracket, 8345
C040~044 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R Y102 8288 4010 00 Owner’s manual, 8345, multi
C045, 046 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB Y103 8216 6510 00 Shield, EMI, 8345
C047 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R Y104 8218 7610 00 Label, TC IN, 8345
C048 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB W101 8276 8404 30 Cable, flat, FFC, 25P, L300
C049, 050 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C051 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C052 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20, CC20R
Abbreviation
C053~058 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R S: Surface mount
C059 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB T: Taping device
C060 8233 5001 50 ST, CER, 50V, 15pF, 5%, CC20SL V: Vertical mount
C061 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R QFP: Quad Flat Package
C062 8233 5094 74 ST, CER, 25V, 0.47µF, 20%, KC30E DIP: Dual In-line Package
C063 8233 5001 50 ST, CER, 50V, 15pF, 5%, CC20SL 220: TO-220 type
C064 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R DG: Digital
C065 8233 5094 74 ST, CER, 25V, 0.47µF, 20%, KC30E AN: Analog
C066, 067 8233 5004 71 ST, CER, 50V, 470pF, 5%, CC20SL
42
D-108
5040 Parts List

• BALANCE I/O PCB assy
Ref. No. Part No. Description CAPACITORs
N/A PCB assy, Balance I/O, 5040 ALU = Electrolytic type
B101 8251 9581 00 Plain PCB, Balance I/O, 5040 CER = Ceramic type
PES = Mylar type
ICs Ref. No. Part No. Description
Ref. No. Part No. Description C0001~0008 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
U0001~0004 8236 7207 00 ST, AN, NJM4560M C0009, 0010 8232 1434 76 VT, ALU, 16V, 47µF, 20%,
U0101~0801 N/A SME-VB
U0102~0802 N/A C0011~0028 N/A
U0103~0803 N/A C0029~0044 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
U0901~1601 8236 5031 00 ST, AN, op amp, NJM4580E C0045, 0046 8232 1434 76 VT, ALU, 16V, 47µF, 20%,
U0902~1602 8236 5702 01 ST, DG, driver, DTC314TK SME-VB
U0903~1603 8236 5702 01 ST, DG, driver, DTC314TK C0101~0801 8232 1434 76 VT, ALU, 16V, 47µF, 20%,
SME-VB
RESISTORs C0102~0802 8232 1434 76 VT, ALU, 16V, 47µF, 20%,
Ref. No. Part No. Description SME-VB
R0108~0808 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% C0103~0803 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL
R0102~0802 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% C0104~0804 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL
R0103~0803 8230 5002 23 ST, carbon, 1/10W, 22kΩ, 5% C0105~0805 N/A
R0104~0804 8230 5002 23 ST, carbon, 1/10W, 22kΩ, 5% C0106~0806 N/A
R0107~0807 N/A C0109~0809 N/A
R0108~0808 N/A C0110~0810 N/A
R0109~0809 N/A C0111~0811 N/A
R0110~0810 N/A C0112~0812 N/A
R0111~0811 N/A C0113~0813 N/A
R0112~0812 N/A C0907~1607 8232 1434 76 VT, ALU, 16V, 47µF, 20%,
R0113~0813 N/A SME-VB
R0114~0814 N/A C0908~1608 N/A
R0115~0815 N/A C0909~1609 N/A
R0116~0816 N/A C0910~1610 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
R0908~1608 8230 5003 32 ST, carbon, 1/10W, 3.3kΩ, 5% C0911~1611 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
R0909~1609 8230 5003 32 ST, carbon, 1/10W, 3.3kΩ, 5% C0912~1612 8232 1422 27 VT, ALU, 10V, 220µF, 20%,
R0910~1610 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% SME-VB
R0911~1611 8230 5001 53 ST, carbon, 1/10W, 15kΩ, 5% C0913~1613 8232 1422 27 VT, ALU, 10V, 220µF, 20%,
R0912~1612 8230 5008 22 ST, carbon, 1/10W, 8.2kΩ, 5% SME-VB
R0913~1613 8230 5021 01 ST, carbon, 1/4W, 100Ω, 5%
R0914~1614 8230 5021 01 ST, carbon, 1/4W, 100Ω, 5%
R0915~1615 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5%
R0916~1616 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5%
43
D-108
MISCELLANEOUS
J0001 8245 3120 05 Connector, PL, jack, D-SUB, 25P,
70057-025, EMIFIL
J0002 8245 3120 05 Connector, PL, jack, D-SUB, 25P,
70057-025, EMIFIL
J0003 N/A
J0004 8245 2720 17 Connector, PI, jack, FPC, 17P
J0005 8245 2720 08 Connector, PI, jack, FPC, 8P
L0101~0801 N/A
L0102~0802 N/A
L0103~0803 N/A
L0104~0804 N/A
L0903~1603 N/A
L0904~1604 N/A
W0001 8276 7280 30 Cable assy, 4P, 8263WHT-5395,
#22, L300
W0002 N/A
W0003 N/A
W0004 N/A
W0005 N/A
W0006 N/A
W0007 N/A
W0101~0801 8230 5000 00 Resistor, ST, carbon, 1/10W, 0Ω
ACCESSORIES
Y102 8221 2060 00 Bracket, B, 5041
Y103 8288 3940 00 Owner’s manual, 5040/5041, multi
W001 8276 8387 25 Cable, flat, FFC, 8P, L250
W002 8276 8396 15 Cable, flat, FFC, 17P, L150
Abbreviation
S: Surface mount
T: Taping device
V: Vertical mount
DG: Digital
AN: Analog
44
8. CIRCUIT DIAGRAMS
ROOT, MAIN D-108 (1/11)
AD-DA GATE ARRAY CPU

AD-DA AUDIO_IF CPU
AD_D[1..4] D[0..15]
AD_D[1..4] AD_D[1..4] D[0..15] D[0..15]
DA_D[1..4] A[0..18]
DA_D[1..4] DA_D[1..4] A[0..18] A[0..18]
LRCK
LRCK LRCK
BCK_ADDA /RD
BCK_ADDA BCK_ADDA /RD /RD
MSCK_ADDA /WR
MSCK_ADDA MSCK_ADDA /WR /WR
MSCK_AD
MSCK_AD MSCK_AD
VCO+5 SCSI_TMOUT
SCSI_TMOUT SCSI_TMOUT
SC_INT7I
VCO+5 SC_INT7I SC_INT7I
A+15 28MHZ
VCOGND 28MHZ 28MHZ
A+15
VCOGND /OP_IRQ
A-15 /OP_IRQ /OP_IRQ
/CS1
/CS1 /CS1
A-15 /CS_IDE
/CS_IDE /CS_IDE
A+5
/DACK1
A+5 /DACK1 /DACK1
/AIRQ1
AGND /AIRQ1 /AIRQ1
IORDY1
IORDY1 IORDY1
AGND /DREQ1
/DREQ1 /DREQ1
/ATA_INT1
/ATA_INT1 /ATA_INT1
D+5_1
D+5
D+5_1
/RST
DGND1 D+5 /RST /RST
SCSI_CS
DGND SCSI_CS SCSI_CS
DGND1 DMA_SEL
DMA_SEL DMA_SEL
DGND VARI/EXT
VARI/EXT VARI/EXT
D+5
AUDIO_IF.SCH
D+5
/RST_ADDA
DGND /RST_ADDA /RST_ADDA
TP /MUTE D+5
/MUTE /MUTE
W9 DGND /RST
/RST D+5
TO DISPLAY
POWER_SEL
DGND
R_ADDA.SCH POWER_SEL
1
78M05 A+5 D+5_1 DGND

DGND A+15 U1 L1
R53 R54 3 1 CPU.SCH
I O
10,1W 10,1W
G
W3 56uH
+15V 1 C6
C2 C4
+15V 2 10/16
2
GND2 3 0.1 0.1 CONNECT

GND2 4 C1 C3
TO DCDC -15V 5 C5
10/16 10/16 C18 0.1
GND1 6 AGND DGND1
+5V 7 0.1
POWER_SEL 8 A-15 78M05 VCO+5
D+12 9 U2 DGND
GND1 10 3 1
I O
+5V 11
G
GND1 12
C9
C8
BOADIN 12P 10/16
2
CONNECT 0.1
C7
10/16
D+12 VCOGND
W1 D+5
1 L2
2 D+5
3
TO HDD 4 56uH C13
C11 100/10
BOARDIN 4P
DGND 0.1
C10 C12
10/16 0.1
D+5 A+15 DGND
J1
5
4
3
2
1
A-15 VCOGND
8263M5P
DGND
D-108
45
46
D-108
CPU, MAIN, D-108 (2/11)
D+5
U12E
14
74HC14 C905
U904A
0.01
10 11 2 1
74HC04
DGND
U904B
4 3
D+5
74HC04
R901 POWER U904C

10K POWER_SEL
D+5 6 5
3
OPTION
/OP_IRQ 74HC04
TP
C901 /422ON R66 D3 TP6 SELF CHECK
470p R49 1.5K U904D
D+5
330
3
SELF_CHECK 8 9
1
DGND
1
D+5 C76 74HC04
D+5 D4
VARI/EXT 0.01
GR DGND
1
DGND DMA_SEL TP DGND
R45 D+5
21
TP7 J2C
10K SCSI_TMOUT /RST GR L11
/RST
DGND GND /EPROM 1 224 27
FM_RDY /RST_DISP
U13 R916
5
MEMORY C73
1
/DREQ1 NJM2103M 220
4
GR R48 22
/DACK1 0.01
2
U904E U904F 2 10K THRU OUT
5
VCC
/EPROM VSC
3
10 11
12 13 3 L12
FM_RDY /RST_ADDA OC
ADDA 6 DGND 1 225 26
/MUTE 74HC04 74HC04 VSB
112
111
110
109
108
107
106
105
104
103
102
101
100
/RST R77
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
/RST R917
R46 10K 7
23
VSA 220
D[0..15] 8 TP4 DIN5-3 YKF51-5046
GND
D[0..15] 10K RST
C94 D+5 C909 1 (TP)
P E13/MRE S
VCC
AVSS
P E9
P E8
P E7
P E6
P E5
P F7/AN7
P F6/AN6
P F5/AN5
P F4/AN4
P F3/AN3
P F2/AN2
P F1/AN1
P F0/AN0
P E4
P E3/DRAK1
P E1/DRAK0
CT
AVCC
VSS
VSS
VSS
P E12
P E11
P E10
P E2/DREQ1
P E0/DREQ0
DGND 0.01 0.01 13027
1
A[0..18] DGND L7 J2A
A[0..18]
A0 1 24 7
4
D+5 TP3
A1 (TP) R913
1
MEMORY R69 C72 220
4
13027 2 MIDI IN
14
2
A2 DGND 2.2k R68 DGND 1/50
5
3
1 84 330 D+5 L8
PE14/AH RES/(VPP)
A3 2 83 1 2 GR 1 25 6
PE15/IRQOUT PA15/CK 28MHZ
3 82
VSS PLLVSS R70 C93
D+5 A4 4 81 U12A D+5
31
32
3
PC0/A0 PLLCAP 0.01
5 80 330 74HC14 U24A
14
D+5 PC1/A1 PLLVCC
A5 6 79 R47 DIN5-3 YKF51-5046
PC2/A2 MD0 74HC32
7 78 10K MD=2 DGND
DGND PC3/A3 MD1
A6 8 77 CLOCK= x4 1
11
PC4/A4 VCC J2B
DGND 9 76 TP5 3 L9
PC5/A5 NMI
A7 10 75 (TP) 2 1 214 17
PC6/A6 MD2 C74
11 74 13027
PC7/A7 EXTAL R914
RDWR A8 12 U15 73 33p
1
RDWR PC8/A8 MD3 220
4
/CS0 A9 13 72 X3 U24B D+5 12
/CS0 PC9/A9 XTAL
2
/CS2 A10 14 71 7MHz 74HC32 MIDI OUT
5
/CS2 PC10/A10 SH7042 VSS C75
3
/RAS A11 15 70 D0 DGND 4 L10
/RAS PC11/A11 PD0/D0
/LCAS A12 16 69 D1 33p 6 1 215 16
/LCAS PC12/A12 PD1/D1
/UCAS A13 17 68 D2 5
/UCAS PC13/A13 PD2/D2 R915
/RD A14 18 67 D3
13
33
34
/RD PC14/A14 PD3/D3 220
/WR A15 19 66 D4
/WR PC15/A15 PD4/D4
A16 20 65 DIN5-3 YKF51-5046
PB0/A16 VCC
MEMORY.SCH 21 64 D5
VCC PD5/D5
D[0..15] A17 22 63 D6 DGND
D[0..15] PB1/A17 PD6/D6
A18 23 62 D7 DGND
VSS PD7/D7
24 61
PB2/RAS VSS
GR A[0..18] 25 60 D8
A[0..18] PB3/CASL PD8/D8
26 59 D9
PB4/CASH PD9/D9
A0 27 58 D10 DTC114EK
VSS PD10/D10 U12B
28 57 D11 U21
PB5/RDWR PD11/D11
C88 C91 3 42 3 THRU_OUT
D+5
P B9/A21/ADTRG
C79 0.1 10/16
P B6/A18/BACK
P B7/A19/BREQ
P B8/A20/WAIT
74HC14
(CHIP C)
1
P A13/WRH
P A12/WRL
P A3/RXD1
P A0/RXD0
P A5/SCK1
P A4/TXD1
P A2/SCK0
P A1/TXD0
P D15/D15
P D14/D14
P D13/D13
P D12/D12
DGND DGND
P A11/CS1
P A10/CS0
P A9/IRQ3
P A8/IRQ2
WDTOVF
P A14/RD
P A7/CS3
P A6/CS2
/WR C71 D+5
/WR 0.01
GR /RD C70 C69
VCC
/RD
VSS
VSS
VSS
0.1 0.1 DGND
D[0..15] R50
1K U11
3
5 1
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
VCC
RXD0 4 D5
VO
3 2
1
GND
PC410
D+5 U19
2 4 DGND
D15
D14
D13
D12
1A 1Y
3
1B
5 7 DTC114EK
2A 2Y
6 U14
2B
11 9 TXD0 5 6 2 3
3A 3Y
10
/AIRQ1 3B
R94 14 12 U12C
/ATA_INT1 4A 4Y
GR D+5 10K 13 74HC14
1
IORDY1 4B J3
DGND
C95 C930 /422ON 1 D+5 RXD422 1
A/B
1 R51 15 16 TXD422 2 TO
100p 100p G VCC
10K R52 100 /422ON 3
74HC157 4 DSUB 9P
DGND U24D D+5 5
13
SCSI_CS 11 8283M5P
SCSI_CS C918
R78 GR 12 DGND
0.01 DGND
100
/CS_IDE 74HC32
/CS_IDE
DGND
C92 GR /CS1 U24C
/CS1
D+5 (CHIP C) 10 SC_INT7I
SC_INT7I
8 9 8
DGND R62 9 GR
R93 100 SCSI_TMOUT
/RST_DISP C77 U12D
47K 100p 74HC14 74HC32 R73 R72 SCSI_TMOUT
R63 /ATN1 (CHIP R)
J7 0
1 /RST_DISP R71
100 R64
2 /ATN1 /ATN2
10k
TO 3 /ATN2 100 R43 100 DGND DGND
4 TXD1 TXD1
DISPLAY 5 RXD1
R65
6 SCK1 RXD1
7 DGND 100 R44 100
SCK1
D+5
8283M7P
3
DGND
D8 D9 D10 D11 D12 D13
31
31
31
31
31
31
C78
470P
D14 D15 D16 D17 D18 D19
DGND
1
R92
47K
MEMORY, MAIN, D-108 (3/11)
1 A0
2 A1
3 A2
4 A3
5 A4
6
7
A5
A6 FLASH MEMORY DRAM
8 A7
9 A8 D[0..15]
D[0..15]
10 A9
11
12 A10 A[0..18]
A[0..18]
13 A11
14 A12
15 A13 U33
16 A14 U30 1 42
VCC VSS
17 A15 A1 25 29 D0 D0 2 41 D15
A0 DQ0 I/O0 I/O15
18 A16 A2 24 31 D1 D1 3 40 D14
A1 DQ1 I/O1 I/O14
19 A17 A3 23 33 D2 D2 4 39 D13
A2 DQ2 I/O2 I/O13
20 A18 A4 22 35 D3 D3 5 38 D12
A3 DQ3 I/O3 I/O12
21 A5 21 38 D4 6 37
A4 DQ4 VCC VSS
22 A6 20 40 D5 D4 7 36 D11
A5 DQ5 I/O4 I/O11
23 D+5 A7 19 42 D6 D5 8 35 D10
A6 DQ6 I/O5 I/O10
24 A8 18 44 D7 D6 9 34 D9
A7 DQ7 I/O6 I/O9
25 NC A9 8 30 D8 D7 10 33 D8
A8 DQ8 I/O7 I/O8
26 A10 7 32 D9 11 32
A9 DQ9 NC NC /LCAS
27 A11 6 34 D10 12 31
J10A A10 DQ10 NC LCAS /UCAS
28 /WR A12 5 36 D11 13 30
A11 DQ11 WE UCAS
29 /RD A13 4 39 D12 14 29
A12 DQ12 RAS OE
ROM CARD 30 /RST A14 3 41 D13 15 28 A10
A13 DQ13 NC A9
31 NC D[0..15] A15 2 43 D14 16 27 A9
A14 DQ14 NC A8
32 A16 1 45 D15 A1 17 26 A8
A15 DQ15 A0 A7
33 D0 A17 48 A2 18 25 A7
A16 A1 A6
34 D1 A18 17 28 A3 19 24 A6
A17 OE A2 A5
35 D2 D+5 16 26 A4 20 23 A5
A18 CE A3 A4
36 D3 11 21 22
WE VCC VSS
37 D4 37 D+5 D+5
VCC
38 D5 12 HM51W18160J/ALJ
C100 RESET
39 D6
40 D7 (CHIP C) 27 15
VSS RY/BG
41 46 47
VSS BYTE
42 D8
43 D9 DGND M29F400T-400
44 D10 C96
45 D11 DGND 0.01
46 D12
47 D13 D+5
48 D14
49 D15
50 R90
10K
FC 50P DGND
FM_RDY
R100
/RST (CHIP R)
U29
/CS0 2 4 /CS_EPROM
/CS0 1A 1Y
/CS2 3
/CS2 1B
/CS2 5 7 /CS_FLMEM
2A 2Y
/CS0 6
2B
11 9 /RD
3A 3Y /RD
10
3B
14 12 /WR
4A 4Y /WR
13
4B
D+5 /RAS
/RAS
1
/EPROM A/B
15 16 RDWR
G VCC RDWR
C97
74HC157
DGND 0.01
DGND
D+5
D+5
DGND
DGND GND
D-108
47
48
D-108
GATE ARRAY, MAIN, D-108 (4/11)
D+5
U34C C920
9 non
/CS_OP[1..4] 8 U34B
OP_A[1..5] 10 5 R922 DGND
OP_D[0..7] 6 1M
non 4
14
J9 U34D non
11 /OP _RST
12 /OP _WR
13 /OP _RD
R921
11 OP _D7
12 OP _D6
13 OP _D5
14 OP _D4
15 OP _D3
16 OP _D2
17 OP _D1
18 OP _D0
14 OP _A5
15 OP _A4
16 OP _A3
17 OP _A2
18 OP _A1
1 D+5 D+5 12 1
2 /OP_RST 11 3 non
3 OP_D0 13 2 C921
C90 C89 non
20
4 OP_D1 D+5
5 OP_D2 0.01 0.01 non U34A
6 OP_D3 non
U18 U17 C87
7 OP_D4 DGND DGND DGND DGND
DIR VCC
G2 VCC
B8
B7
B6
B5
B4
B3
B2
B1
Y8
Y7
Y6
Y5
Y4
Y3
Y2
Y1
74HC245 74HC541 0.01
8 OP_D5
9 OP_D6 U16A U16B
OE
A8
A7
A6
A5
A4
A3
A2
A1
G1
A8
A7
A6
A5
A4
A3
A2
A1
10 OP_D7 /CS_OP1 4 2 DGND /CS_GA 12 14
Y0 A Y0 A
11 OP_A1 /CS_OP2 5 3 11 13
Y1 B Y1 B
12 OP_A2 /CS_OP3 6 /CS_DIG 10
Y2 Y2
19
19
1
9
8
7
6
5
4
3
2
9
8
7
6
5
4
3
2
13 OP_A3 /CS_OP4 7 1 9 15 /CS1 CPU
Y3 G Y3 G /CS1
14 OP_A4
D7
D6
D5
D4
D3
D2
D1
D0
A5
A4
A3
A2
A1
15 OP_A5 DGND 16 W14 74HC139
A11
A10
VCC
16 /OP_IRQ 0
/OP_IRQ
17 /OP_WR 74HC139
A9
A8
18 /OP_RD /CS_OP
19 /CS_OP1
20 /CS_OP2 D[0..15]
D[0..15]
21 /CS_OP3 CPU
22 /CS_OP4 A[0..18]
A[0..18]
23 /LRCK /CS_OP[1..4]
D10
D11
D12
D13
D14
D15
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
A5
A4
A3
A2
A1
D0
D1
D2
D3
D4
D5
D6
D7
24 EXT_LRCK
A9
A1
A2
A3
A4
A5
A6
A7
A8
25 D+5 C22 C24 /CS_IDE CPU
/CS_IDE
0.01 IORDY1
0.01 IORDY1
FC 25P
C21 /WR
/WR
10/16 /RD CPU
/RD
DGND C912 /RST
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
/RST
9
8
7
6
5
4
3
2
1
C23 C25 33p R902 560
0.01 0.01 MSCK_ADDA
DGND
VSS
VSS
VSS
VSS
NC
IORDY_O
CS
CS_IDE
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D13
D14
D15
A0
A1
A2
A3
A4
A5
A6
A7
A8
VDD
VDD
VDD
R55
MSCK_AD C919
ADDA 560
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
R56
1
2
3
4
5
6
7
8
9
SCSI 37 144 470P
NC VDD BCK_ADDA
38 143 560 U20
VSS VSS R57
/ATA_RST 39 142
VSS
VSS
RDB
TDO_EMP O
PO
SINA_MD
CSB
RESETB
EN_IFB
CTL_P IN
PI
WRB
TEST1
TEST2
/ATA_RST ATA_RES WR LRCK
TDO_FS0O
VDD
VDD
A4
A3
A2
A1
A0
D0
D1
D2
D3
D4
D5
D6
D7
DD7 40 141 100
ATA_D7 RD
DD8 41 140
ATA_D8 NC
DD6 42 139
ATA_D6 ATA_INT /ATA_INT1
DD9 43 138 100 31
ATA_D9 MLRCK /AIRQ1 TDO_FS1O SOUT1_MD
44 137 CPU 99 32
VSS DACK_I /DACK1 W_OUT SOUT2_MD
DD5 45 136 98 33
ATA_D5 VSS W_IN2 TDI_FS1I
DD10 46 135 97 34
ATA_D10 ATA_DREQ /DREQ1 W_IN1 TDI_FS0I
DD4 47 134 96 35
ATA_D4 RST 256FSO TDI_EMPI
DD[0..17] DD11 48 133 95 36 AD_D1
DD[0..17] ATA_D11 SLAVE VARI/EXT BCKO SINA_12
DD3 49 132 C27 94 37 AD_D2
ATA_D3 TCRC LRCKO SINA_34
DD12 50 U5 131 470p 93 38 AD_D3
ATA_D12 TST2 LRCKI SINA_56
D+5 DD2 51 GA2 130 92 39 AD_D4
ATA_D2 TCK2 BCKI SINA_78
DD13 52 129 DGND 91 40
ATA_D13 VDD VDD VSS
DD1 53 128 90 41
ATA_D1 DIGITAL_OUT_2 VSS VDD
54 127 89 42 DA2_D1 AD_D[1..4]
VDD DIGITAL_IN_2 FS256I SINB_12 AD_D[1..4]
55 126 88 43 DA2_D2
R95 VDD DIGITAL_OUT_1 PCMBW0 SINB_34
R96 DD14 56 125 87 44 DA2_D3
1K ATA_D14 DIGITAL_IN_1 PCMBW1 SINB_56
1K DD0 57 124 86 45 DA2_D4
ATA_D0 TEST CK_SEL0 SINB_78
DD15 58 123 VCO 85 46 DA2_D5
ATA_D15 EXT_MCLK2 CK_SEL1 SIN_DIF
DMARQ 59 122 84 47
DMARQ DMARQ FCONT2 VARI/EXT CK_SEL2 DI1
/DIOW 60 121 83 48
/DIOW DIOW PD2 PLL2_CONT PLL2_CONT DI2
/DIOR 61 120 82 49
/DIOR DIOR PLL_SEL LOCK2B DI_SEL
P LL1_CONT
IORDY_I 62 119 81 50
IORDY_I IORDY_I FCONT1 FCONT2 FCONT2 DI_FS1O
ADAT_MD
SOUT2_78
SOUT2_56
SOUT2_34
SOUT2_12
SOUT1_78
SOUT1_56
SOUT1_34
SOUT1_12
/DMACK 63 118
DO_EMP I
DI_EMP O
DO_SEL0
DO_SEL1
SOUT_DI
/DMACK DMACK PD1 /LOCK2B
LOCK1B
DO_FS0I
DO_FS1I
DI_FS0O
FCONT1
64 117
VSS EXT_MCLK1
MCK2
MCK1
/PDIAG 65 116 TP9
VDD
DO2
DO1
P D2
P D1
/PDIAG VSS VSS
VSS
VSS
VSS
INTRQ 66 115 TP
INTRQ INTRQ VDD
67 114 VARI_256FS
ATA_A1 VARI_256FS VARI_256FS
68 113 VARI_FS DIFGA D+5
ATA_A0 VARI_FS VARI_FS
69 112 S_MSCK
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
1
ATA_A2 SLAVE_MSCK
/CS1FX 70 111 PD2
/CS1FX CS1FX SLAVE_MLRCK PD2
71 110
AD_DATA_LR
DA_DATA_LR
AD_DATA_12
AD_DATA_34
AD_DATA_56
AD_DATA_78
DA_DATA_12
DA_DATA_34
DA_DATA_56
DA_DATA_78
VSS NC
/CS3FX 72 109
SCSI_DREQ
/CS3FX VDD NC
MCK2
DMA_WR
SCSI_INT
DMA_RD
MCK2
SCSI_A3
SCSI_A4
SCSI_A5
SCSI_CS
C83 C84 C85 C86 DGND

MLRCK PLL1_CONT
CS3FX
MCLK
0.01 0.01 0.01 0.01
LRCK
VDD
VDD
VDD
VDD
BCK
FCONT1
XO1
XO2
R9
VSS
VSS
VSS
VSS
VSS
XI1
XI2
NC
PD1 TP10
C30 PD1
5.6K MCK1 TP
EXT_LRCK MCK1
ATA1
ATA0
ATA2
470P R7
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
R8 100
101
102
103
104
105
106
107
108
ADAT_IN 100
1
10K
DGND vco.sch
ATA[0..4] R1 DA2_D[1..5]
ATA[0..4]
2 1 DA2_D1
/DMA_RD 4 3 DA2_D2 SOUT[1..5] R84
/DMA_RD 100
/DMA_WR 6 5 DA2_D3 SOUT5 D+5
/DMA_WR
/SCSI_CS 8 7 DA2_D4 D+5
/SCSI_CS SCSI_CS C26
DMA_SEL SOUT4 8 7
DMA_SEL DMA_SEL W12 10/16
/SCSI_DREQ 100x4 R89 DA2_D5 SOUT3 6 5
/SCSI_DREQ
C29 R12 100 SOUT5 NON SOUT2 4 3 J5
ATA3 SOUT4 D+5 SOUT1 2 1 R10 C33 1 4
(CHIP C) 100 ATA4 SOUT3 R99 0.01
330 3.3K
SC_INT7I SOUT2 3 5
SC_INT7I R6 C98
SOUT1 R2
SCSI_TMOUT SC_INT7I R97 100 0.01 R16
14
28MHZ CPU 100x4 2 6
28MHz SCSI_TMOUT 1M R11
D+5 330
28MHZ 2.2K
D+5 DGND 1 GPIF32R
D+5
DA2_D[1..5]
12 13 U6F 4 3
R14 R17 R5 R13
GND 74HCU04 6 2 DATA IN(OPT)
DGND 1M 1M 100 330
C28 5 DGND
100p W2 X4 U4A D+5
(CHIP R) U4B 74HC00
(XTAL) 20MHz U4D
C910 U6D 74HC00
SCSI.SCH DGND C911 12 J4
DGND (CHIP C) 0 6 5 8 9 74HCU04 11 C20 2 4
13 U4C D+5 0.01
DGND U6C 9 1 5
74HCU04 74HC00 8
10 R3 3 6
R15 R18 DA_D1 8 7 DA2_D1
74HC00 DA_D2 6 5 DA2_D2 DGND GPIF32T
0 0
X1 X2 DA_D3 4 3 DA2_D3
U6B 22.5792MHz 24.576MHz DA_D4 2 1 DA2_D4 DATA OUT(OPT)
R91 4 3
100 C31 C32 C35 C36 100x4
74HCU04 22P 22P 22P 22P
DA_D[1..4]
DA_D[1..4]
DGND DGND
U6E D+5 VCO+5

11 10 POWER
D+5 VCO+5
74HCU04 POWER
DGND VCOGND
DGND
DGND GND VCOGND
SCSI I/F, MAIN, D-108 (5/11)
/ATA_RST
GA
DMARQ
D+5
IORDY_I R29
INTRQ
4.7K
DD[0..17]
ATAD4
DD 16
DD 15
DD 14
DD 13
DD 12
DD 11
DD 10
DD 9
DD 8
DD 7
DD 6
DD 5
DD 4
DD 3
DD 2
DD 1
DD 0
DD 17
D+5 R918 R919 R920
RA221/331 RA221/331 RA221/331
J12
1 /ATA_RST
100
2 DGND
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
3 DD7 DGND
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
4 DD8
5 DD6
VCC
VSS
VSS
D1 5
D1 4
D1 3
D1 2
D1 1
D1 0
BHE
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
CS1
CS0
A4
UD P
LDP
6 DD9
7 DD5
8 DD10 DGND
9 DD4 1 75 ATAD3 J6
WR A3
10 DD11 2 74 ATAD2 26
RD A2
11 DD3 3 73 ATAD1 S0 /REQ 1
VCC A1
12 DD12 4 72 ATAD0 14
VSS A0
13 DD2 5 71 /ATN S5 S1 /MSG 2
CLK ATN
14 DD13 6 70 S2 /C/D 15
RESET VSS
15 DD1 7 69 /BSY S7 S3 /I/O 3
INT BSY
TO IDE HD 16 DD14 8 68 /ACK S6 16
MODE ACK
17 DD0 S9 9 67 /RES S4 S4 /RES 4
DBP RES
18 DD15 10 66 S5 /ATN 17
/DIOW VSS VSS
19 DGND GA S17 11 65 S6 /ACK 5
/DIOR DB7 U7 VSS
20 KEYPIN S16 12 64 18
/DMACK DB6 VCC
21 DMARQ S15 13 MB86604L 63 /MSG S1 S7 /BSY 6
DB5 MSG
22 DGND 14 62 /SEL S8 S8 /SEL 19
VCC SEL
23 /DIOW 15 61 /C/D S2 7
VSS C/D
24 DGND 16 60 /REQ S0 S9 /DBP 20 SCSI
VSS REQ
25 /DIOR S14 17 59 S10 /DB0 8
DB4 VSS
26 DGND S13 18 58 /I/O S3 S11 /DB1 21
DB3 I/O
27 IORDY D+5 S12 19 57 9
DB2 TEST2
28 S11 20 56 S12 /DB2 22
DB1 (OPEN)
29 DMACK R28 21 55 S13 /DB3 10
VSS TP
30 DGND (CHIP R) S10 22 54 S14 /DB4 23
DB0 VSS
31 INTRQ 23 53 S15 /DB5 11
TEST1 VCC
32 /IOCS16 24 52 24
TMOUT DREQ
33 ATA1 25 51 S16 /DB6 12
R27 (OPEN) DMACK
34 /PDIAG /TPWR 25
DMA WR
DMA RD
UD MD P
DMBH E
LDMD P
35 ATA0 S17 /DB7 13
DMD10
DMD11
DMD12
DMD13
DMD14
DMD15
0
DMA 0
DMD 0
DMD 1
DMD 2
DMD 3
DMD 4
DMD 5
DMD 6
DMD 7
DMD 8
DMD 9
36 ATA2 27
VCC
VSS
VSS
37 /CS1FX
38 /CS3FX DSUB-25P
39 /DASP DGND
40 DGND
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
S[0..17]
DD 17
DD 0
DD 1
DD 2
DD 3
DD 4
DD 5
DD 6
DD 7
DD 8
DD 9
DD 10
DD 11
DD 12
DD 13
DD 14
DD 15
DD 16
DGND
/PDIAG
GA S[0..17] D+5
/CS1FX
U8
/CS3FX
D+5 1 25
N.C. TSD
2 24
EN VM
DD[0..17] /DBP S9 3 23 S8 /SEL
DD[0..17] SCSI15 SCSI14
R19 4.7K /DB0 S10 4 22 S7 /BSY
SCSI16 SCSI13
GA /DB1 S11 5 21 S6 /ACK
SCSI17 SCSI12
ATA[0..4] ATAD[0..4] /DB2 S12 6 20 S5 /ATN
ATA[0..4] SCSI18 SCSI11
/DMACK
DMA_RDB 7
/DMA_RD VSS
GA DMA_WRB /DB3 S13 8 19 S4 /RES
/DMA_WR SCSI1 SCSI10
SCSI_CSB /DB4 S14 9 18 S3 /I/O
/SCSI_CS SCSI2 SCSI9
D+5 /DB5 S15 10 17 S2 /C/D
SCSI3 SCSI8
/DB6 S16 11 16 S1 /MSG
SCSI4 SCSI7
/DB7 S17 12 15 S0 /REQ
C34 SCSI5 SCSI6
GA 13 14
14
0.01 VCC VCC

SC_INT7I
SC_INT7I
DGND BH9595FP
SC_DREQB 2 1DGND D+5
/SCSI_DREQ
D1
GA 28MHZ U6A R26 1 2
28MHZ 74HCU04 CPU
DMA_SEL
CPU EK13 C47
SCSI_TMOUT
0
R20 0.1
C48
(CHIP R) 10/16
R21 100
ATA0 ATAD0 DGND
R22 100
ATA1 ATAD1 DGND
R23 100
ATA2 ATAD2
R24 100
ATA3 ATAD3
D+5
R25 100
ATA4 ATAD4
D+5
POWER
C41
C45
(CHIP C) DGND
(CHIP C)
C46 C39 C40 C38 C37
10/16 0.01 0.01 0.01 0.01 DGND GND
C43
(CHIP C)
DGND
C42 C44
(CHIP C) (CHIP C)
D-108
49
50
D-108
VCO, MAIN, D-108 (6/11)
L6
VCO+5
22uH
R42
PLL1_CONT
DIF_GR 4.7k C61 C62 C63
FCONT1 0.01 0.01 10/16
R39 10K
ADAT FCONT VCO+5 TEST PIN
VCOGND TP2
U10 13027
R37 1 16
REF VDD
(CHIP R) R35 R36 2 15
PD LOCK
750 8.2K 3 14
VDDA S2
DIF_GR 4 13
PD1 AMPI S1
5 12
C65 AMPO M2 R41
6 11
R40 0.47 VSSA M1 560
R38 7 10 DIF_GR
100 XI CKO MCK1
330 8 9
C64 XO VSS
15p
OPT_IN C66 TC9246F C68
C19 0.01
ADAT_IN ADAT_IN 0.1
GA2 0.01 VCOGND
/AIRQ1 /AIRQ1 C902
VCOGND DGND
/LOCK2B /LOCK2B (CHIP C)
VCOGND
DIF-GR
D+5 C67
D+5 MCK2 0.01
DGND L3
VCO+5
FCONT2_2 22uH
DGND
fcont.sch DIF_GR R74
PLL2_CONT
4.7k C55 C56 C80
FCONT2 0.01 0.01 10/16
R75 non
VCO+5 TEST PIN
VCOGND TP8
U22 13027
R58 1 16
REF VDD
(CHIP R) R60 R61 2 15
PD LOCK
750 8.2K 3 14
VDDA S2
DIF_GR 4 13
PD2 AMPI S1
5 12
C16 AMPO M2 R33
6 11
R76 0.47 VSSA M1 560
R59 7 10 DIF_GR
100 XI CKO MCK2
330 8 9
C15 XO VSS
15p
C54 TC9246F C81
C14 0.01 0.1
0.01 VCOGND
VCOGND C53 DGND
VCOGND 0.01
D+5
14
C82
0.01 VCO+5 L4
GR 1 22uH C59
VARI_FS 10/16
DGND
3 4
2 6
5 C49 C50 TEST PIN
U3A 0.01 0.01 TP1
74HC00 U3C U3B
OPTION 9 13027
EXT_LRCK 74HC00
8
D+5 U3D 10 VCOGND
12
74HC00 R30
11 U9
1.5K
CPU 13 1 16
VARI/EXT REF VDD
2 15
74HC00 PD LOCK
3 14
VDDA S2
4 13
AMPI S1
5 12
R32 AMPO M2
C52 6 11
220K VSSA M1
15P 7 10 GR
XI CKO VARI_256FS
R31 8 9
XO VSS R34
100 330
VCOGND C57 TC9246F C60
0.01 0.1
VCOGND DGND
C51
0.01
DGND GND C58

0.47
13002
FCONT, MAIN, D-108 (7/11)
D+5
D+5
C926
0.01
C99
0.01 14 DGND U35B D+5
14
4
U35A 5 U36 U37B

DGND 1 6 3 14 4 D+5 D+5
A QA
OPT_IN 3 4 4 13 U37C 6 11T
S
VCC
B QB
2 5 2 5 12 U37D 9 5
14
14
ADAT_IN D Q 74HC86 C QC C923 C928 C929
4
3 6 6 11 12 8
C Q 74HC86 D QD 74HC00 100p 0.01 0.01
D+5 11 10 U38A U39A
R
U23A 7 15 13
VCC
VCC
S
S
ENP RCO 74HC00
74HC74 10 2 5DGND 2 5DGND D+5
ENT 74HC00 D Q D Q
1
2 3 6 3 6
1
CK C Q C Q
D+5 9 D+5 VCO
LOAD
R
1 16 2 3 R924
CLR VCC FCONT2_2
74HC74 74HC74 22K
74HC161 C925 DGND U40
1
0.01 DTA114EK
DIF-GR
MCK2
DGND DGND D+5
10
10
U41
U38B U39B DTC114EK
2 3 R925
S
12 9 12 9 22K
D Q D Q
11 8 11 8
C Q C Q
1
R
R
DGND
74HC74 74HC74
DGND
13
13
D+5 10T
C924
100p
U35D DGND
13
11
GR2 12 D+5
/AIRQ1
74HC86 D+5
10
U23B
C927
14
S
12 9 0.01
D Q R923
11 8 1
C Q
1K DGND 3
R
C922 2
74HC74 47P
U37A
13
DGND 74HC00
DGND GND
D+5 DGND
U35C
9
8
DIF-GR 10
/LOCK2B
74HC86
D-108
51
52
D-108
ROOT, AD-DA, MAIN, D-108 (8/11)
ADDA_IN ADDA ADDA_OUT

ADDA IN ADDA_DG ADDA_OUT
7
7
AIN[1. .8] AI N+ [1..8] AOUT+ [1..8] AOUT[1. .8]

AIN[1. .8] AI N+ [1..8] AI N+ [1..8] AOUT+ [1..8] AOUT+ [1..8] AOUT[1. .8]
L102
BAL_IN[1..8] AIN-[1. .8] AOUT1 R156 1 2 4
L101 BAL_IN[1..8] AIN-[1. .8] AIN-[1. .8]
4 1 2 AIN1 AOUT5 100
AOUT2 6
6 AOUT6 L502
AOUT+ [1..8] R556 1 2 3
L501
3 1 2 AIN5 J13 100
1
2 BAL_IN1 L202
3 J14 R256 1 2 2
L201
2 1 2 AIN2 4 BAL_IN2 AOUT+1 1 100
5 AOUT+2 2 5
5 6 BAL_IN3 AOUT+3 3
R656 L602
L601 7 AOUT+4 4 1 2 1
1 1 2 AIN6 8 BAL_IN4 AOUT+5 5 100
9 AOUT+6 6
10 BAL_IN5 AOUT+7 7 2 3 J17
J15 11 AOUT+8 8 YKC21-3077
YKC21-3077 12 BAL_IN6 U157
13 FC 8P U557 DTC314TK
1
14 BAL_IN7 DTC314TK
15 To 5040 2 3 AGND
7
16 BAL_IN8
17
L301 U257
1
4 1 2 AIN3 FC 17P DTC314TK
2 3
6
L701 AGND
3 1 2 AIN7 U657
1
DTC314TK
2 3
L401 A+15
7
2 1 2 AIN4
A+15
A+5
1
VBIAS A-15
5 L302
A+5 AGND R356
L801 AOUT3 1 2 4
1 1 2 AIN8 adda_in.sch A-15 AGND AOUT7 100
AGND
AOUT4 6
AGND AOUT8 L702
J16 R756 1 2 3
YKC21-3077 D+5_1 ADDA_OUT.SCH 100
D+5_1 L402
R456 1 2 2
DGND1
100
AGND DGND1 5
R856 L802
AD_D[1. .4] 1 2 1
AD_D[1. .4] AD_D[1. .4]
GR 100
DA_D[1. .4] U357
DA_D[1. .4] DA_D[1. .4] DTC314TK
A+15 J18
CPU 2 3 YKC21-3077
/RST /RST J8
A+5
RST_ADDA
/RST_ADDA 1
/RST_ADDA MSCK_ADDA
2 U757
1
LRCK_ADDA
R908 3 TO 5040 DTC314TK
BCK_ADDA
1K 4 2 3 AGND
MSCK_AD
VBIAS MSCK_AD
MSCK_AD
8263M4P
ADDA_DG.SCH AGND A-15 U457
1
R909
GR MSCK_ADDA DTC314TK
1K MSCK_ADDA
C903 C904 2 3
0.01 100/10
R904
U12F U857
1
560
AGND GR 13 12 LRCK_ADDA DTC314TK
LRCK
2 3
74HC14
R911
10K
1
GR BCK_ADDA
BCK_ADDA
C914
100/25
1
AGND
2 3 BAL_MUTE
U905
DTB114EK R910
10K
A+15
D7 A-15
A+15 2 3
A+15 RB400D R912
C916 D6 10K
47/16 D+5_1 3 1
C913
C917 D+5_1 R906
AGND U901 100/25
1
47/16 10K U902
A-15 DGND1 DTC114EK
DTC114EK
A-15 DGND1 CPU 2 3 2 3 2 3 MUTE
/MUTE
U903
A+5 D+5 DTB114EK R907
1
10K
A+5 C915 D+5
10/16
DGND
AGND
DGND GND DGND A-15
AGND
ADDA IN, D-108 (9/11)
+2dBv
5040 BAL_IN[1..8] BAL_IN[1..8]
BAL_IN[1..8]
UNBAL IN AIN[1..8] AIN[1..8]

AIN[1..8]
+2dBv G=-4.5dB C103 A+5 G=-4.5dB C503 A+5

0.01 0.01
C101 R101 C501 R501
10/16 R102 R104 10/16 R502 R504
20k 12k 10K 20k 12k 10K
AIN1 AGND AIN5 AGND
R108 R508
8
BAL_IN1 R103 BAL_IN5 R503
20k 6 10K R105 20k 6 10K R505
C105 7 2 C505 7 2
R107 330 R507 330
10/16 5 1 AIN+1 10/16 5 1 AIN+5
100K U101B 3 100K U501B 3
R109 R509
NJM2115M U101A NJM2115M U501A
100K C107 100K C507
(CHIP C) C108 NJM2115M (CHIP C) C508 NJM2115M
C102 C502
4
(CHIP C) (CHIP C)
R106 1500P R506 1500P
330 330
C104 AIN-1 C504 AIN-5
0.01 0.01
AGND AGND
C203 A+5 C603 A+5
0.01 0.01
C201 R201 C601 R601
10/16 R202 R204 10/16 R602 R604
20k 12k 10K 20k 12k 10K
AIN2 AGND AIN6 AGND
R208 R608
8
20k 6 R205 20k 6 R605
C205 7 10K 2 C605 7 10K 2
R207 330 R607 330
10/16 5 1 AIN+2 10/16 5 1 AIN+6
100K U201B 3 100K U601B 3
R209 R609
100K C207 100K C607
C202 C602
4
(CHIP C) 1500P (CHIP C) 1500P
R206 R606
330 330
C204 AIN-2 C604 AIN-6
0.01 0.01
AGND AGND
C303 A+5 C703 A+5

0.01 0.01
C301 R301 C701 R701
10/16 R302 R304 10/16 R702 R704
20k 12k 10K 20k 12k 10K
AIN3 AGND AIN7 AGND
R308 R708
8
8
20k 6 10K R305 20k 6 10K R705
C305 7 2 C705 7 2
R307 330 R707 330
10/16 5 1 AIN+3 10/16 5 1 AIN+7
100K U301B 3 100K U701B 3
R309 R709
100K C307 100K C707
C302 C702
4
4
(CHIP C) (CHIP C)
R306 1500P R706 1500P
330 330
C304 AIN-3 C704 AIN-7
0.01 0.01
AGND AGND
C403 A+5 C803 A+5
0.01 0.01
C401 R401 C801 R801
10/16 R402 R404 10/16 R802 R804
20k 12k 10K 20k 12k 10K
AIN4 AGND AIN8 AGND
R408 R808
8
8
20k 6 R405 20k 6 R805
C405 7 10K 2 C805 7 10K 2
R407 330 R807 330
10/16 5 1 AIN+4 10/16 5 1 AIN+8
100K U401B 3 100K U801B 3
R409 R809
100K C407 100K C807
C402 C802
4
4
(CHIP C) 1500P (CHIP C) 1500P
R406 R806
330 330
C404 AIN-4 C804 AIN-8
0.01 0.01
AGND AGND
VBIAS
VBIAS
Full Scale : 2.1V/P-P
-2.587dBv
AIN+[1..8] AIN+[1..8] AIN+[1..8]
AIN-[1..8] AIN-[1..8]
AIN-[1..8]
Full Scale : 2.1V/P-P

-2.587dBv
D-108
53
54
D-108
ADDA, MAIN, D-108 (10/11)
AIN+[1..8]
AIN+[1..8]
AIN-[1..8] AIN+2
AIN-[1..8]
AIN-2 DA_D[1..4]
DA_D[1..4]
GR
AIN+1
AIN-1
RST_ADDA
A+5 C155 D+5_1
/RST
0.1 A+5
MSCK_ADDA C162
LRCK_ADDA 0.01
R161 U152
BCK_ADDA
10 1 24
MSCK_AD CKS ZMUTE
2 23
DVDD DZF C161
U151 C166 3 22
DVSS VREF 10/16
C153 C154 1 24 AGND AD_D[1..4] 10/16 4 21
AINR+ VB AD_D[1..4] XTO AVSS
10/16 0.01 2 23 5 20
AINR- SMODE XTI AVDD
3 22 C167 6 19
VREF CMODE R152 100 PD VCOM
4 21 AD_D1 DGND1 0.01 7 18 AOUT+1
VA SDATA BICK AOUTL
5 20 MSCK 8 17
AGND FSYNC SDATA AOUTR
6 19 LRCK 9 16 AOUT+2
AINL+ LRCK LRCK VCNT
7 18 BCK /RST 10 15
AIN- SCLK SMUTE DIF1
8 17 MSCK BCK 11 14 C165
C151 C152 TST1 MCLK HOLD DIF0
9 16 RST_ADDA 12 13 (CHIP C) C164 C163
10/16 0.01 HPFE PD DEM0 DEM1
AGND 10 15 DA_D1 0.01 47/16
TST2 SMODE2
11 14 AK4320 DGND1
TST3 TST4
D+5_1 12 13 LRCK
VD DGND
AGND
AK5351 D+5_1
R151 R261 A+5
C262
10 10
U252 0.01
C266 1 24
C156 C157 10/16 CKS ZMUTE
2 23
10/16 0.01 DVDD DZF C261
3 22
DVSS VREF 10/16
4 21
XTO AVSS
AIN+4 DGND1 5 20
XTI AVDD
AIN-4 C267 6 19
PD VCOM
DGND1 0.01 7 18 AOUT+3
BICK AOUTL
AIN+3 MSCK 8 17
SDATA AOUTR
AIN-3 /RST 9 16 AOUT+4
LRCK VCNT
A+5 C255 BCK 10 15
SMUTE DIF1
0.1 11 14 C265
HOLD DIF0
DA_D2 12 13 (CHIP C) C264 C263
DEM0 DEM1
0.01 47/16
LRCK AK4320 DGND1
U251
C253 C254 1 24 AGND AGND
AINR+ VB
10/16 0.01 2 23
AINR- SMODE
3 22
VREF CMODE R252 100
4 21 AD_D2
VA SDATA
5 20
AGND FSYNC
6 19 LRCK
AINL+ LRCK
7 18 BCK D+5_1
AIN- SCLK R361
8 17 MSCK A+5
C251 C252 TST1 MCLK 10
9 16 RST_ADDA
10/16 0.01 HPFE PD
AGND 10 15 U352
TST2 SMODE2 C366
11 14 1 24
TST3 TST4 10/16 CKS ZMUTE
D+5_1 12 13 2 23
VD DGND DVDD DZF C362 C361
3 22
DVSS VREF 0.01 10/16
AK5351 4 21
XTO AVSS
R251 5 20
XTI AVDD
10 C367 6 19
PD VCOM
0.01 7 18 AOUT+5
BICK AOUTL
DGND1 8 17
C256 C257 SDATA AOUTR
MSCK 9 16 AOUT+6
10/16 0.01 LRCK VCNT
/RST 10 15
SMUTE DIF1
BCK 11 14 C365
HOLD DIF0
AIN+6 DGND1 12 13 (CHIP C) C364 C363
DEM0 DEM1
AIN-6 DA_D3 0.01 47/16
AK4320 DGND1
AIN+5 LRCK
AIN-5 AGND
A+5 C355 D+5_1
R461 A+5
0.1
10
U452
C466 1 24
10/16 CKS ZMUTE
2 23
DVDD DZF C462 C461
U351 3 22
DVSS VREF 0.01 10/16
C353 C354 1 24 AGND 4 21
AINR+ VB XTO AVSS
10/16 0.01 2 23 5 20
AINR- SMODE XTI AVDD
3 22 C467 6 19
VREF CMODE R352 100 PD VCOM
4 21 AD_D3 DGND1 0.01 7 18 AOUT+7
VA SDATA BICK AOUTL
5 20 MSCK 8 17
AGND FSYNC SDATA AOUTR
6 19 LRCK /RST 9 16 AOUT+8
AINL+ LRCK LRCK VCNT
7 18 BCK 10 15
AIN- SCLK SMUTE DIF1
8 17 MSCK BCK 11 14 C465
C351 C352 TST1 MCLK HOLD DIF0
9 16 RST_ADDA 12 13 (CHIP C) C464 C463
10/16 0.01 HPFE PD DEM0 DEM1
AGND 10 15 DA_D4 0.01 47/16
TST2 SMODE2 AK4320
11 14 DGND1
TST3 TST4
D+5_1 12 13 LRCK
VD DGND
AK5351 AGND
R351 AOUT+[1..8]
10
C356 C357
10/16 0.01
AIN+8 DGND1
AOUT+[1..8]
AIN-8
AIN+7
AIN-7
A+5 C455
0.1
D+5_1 A+5
D+5_1 A+5
U451
DGND1 AGND
C453 C454 1 24 AGND
AINR+ VB
10/16 0.01 2 23 DGND1 AGND C906
AINR- SMODE
3 22 0.1
VREF CMODE R452 100
4 21 AD_D4
VA SDATA
5 20 DGND
AGND FSYNC
6 19 LRCK
AINL+ LRCK
7 18 BCK
AIN- SCLK
8 17 MSCK
C451 C452 TST1 MCLK
9 16 RST_ADDA
10/16 0.01 HPFE PD
AGND 10 15
TST2 SMODE2
11 14
TST3 TST4
D+5_1 12 13
VD DGND
AK5351
R451
10
C456 C457
10/16 0.01
DGND1
ANALOG OUT, MAIN, D-108 (11/11)
AOUT+[1..8] AOUT+[1..8]
AOUT+[1..8]
A+15
A+15
G=+2.08dB C113
0.01 G=+2.08dB C313
0.01
U153A
8
NJM4565M C116 U353A
8
C111 AGND C516
AOUT+1 3 100/16 C511 NJM4565M AGND
1 AOUT1 AOUT+5 3 100/16
10/16 2 1 AOUT5
R111 10/16 2
R113
10K R511
2.7K R513
C115 R114 10K
4
2.7K
(CHIP C) 100K C515 R514
4
R112 C112 (CHIP C) 100K
10K 680P R512 C512
10K 680P
AGND
AGND
A-15 C114
U153B A-15
NJM4565M 0.01 C216 U353B C314
C211 C616
AOUT+2 5 100/16 NJM4565M 0.01
C611
7 AOUT2 AOUT+6 5 100/16
10/16 6 7 AOUT6
R211 10/16 6
R213
10K R611
2.7K R613
C215 R214 10K
2.7K
(CHIP C) 100K C615 R614
C212 (CHIP C) 100K
R212 680P C612
10K R612 680P
10K
A+15 AGND
A+15 AGND
C213
0.01 C413
0.01
U253A
8
NJM4565M C316 U453A
8
C311 AGND C716
AOUT+3 3 100/16 C711 NJM4565M AGND
1 AOUT3 AOUT+7 3 100/16
10/16 2 1 AOUT7
R311 10/16 2
R313
10K R711
2.7K R713
C315 R314 10K
4
2.7K
(CHIP C) 100K C715 R714
4
R312 C312 (CHIP C) 100K
10K 680P R712 C712
10K 680P
AGND
AGND
A-15
C214
A-15
U253B 0.01 C414
NJM4565M C416 U453B 0.01
C411 C816
AOUT+4 5 100/16 C811 NJM4565M
7 AOUT4 AOUT+8 5 100/16
10/16 6 7 AOUT8
R411 10/16 6
R413
10K R811
2.7K R813
C415 R414 10K
2.7K
(CHIP C) 100K C815 R814
C412 (CHIP C) 100K
R412 680P C812
10K R812 680P
10K
AGND
AGND Full Scale = +2dBv
Ref = -10dBv
AOUT[1..8] AOUT[1..8]
AOUT[1..8]
D-108
55
56
D-108
ROOT, DISPLAY, D-108 / D-160 (1/5)
FRNT\KEY.SCH
FRNT\MPUKEY.SCH
FS[2..27]
DIG0
DIG1
DIG0
DIG1 J1
J2
J1 D+5
J2 DGND
KEY.SCH
LEDA[0..3] FRNT\LED.SCH
LEDA[0..3]
LEDK[0..4]
LEDK[0..4]
LEDA[0..3]
FS[2..27]
FS[2..27] LEDK[0..4]
FD[6..15]
FD[6..15]
D+5 LED.SCH
D+5
DGND FRNT\FL.SCH
DGND
FS[2..27]
FD[6..15]
SCK_FL D+5
SO_FL DGND
CE_FL
SCK_FL
AC6.2A
AC6.2A SO_FL
AC6.2B
AC6.2B CE_FL
Vdisp
Vdisp
AC6.2A
AC6.2B
Vdisp
/S27 /S27
/S28 /S28
/S29 /S29
/RST2 /RST2
MPUKEY.SCH FL.SCH
MPUKEY, DISPLAY, D-108 / D-160 (2/5)
D+5
D+5
L1 D+5 R47
C1 C3 C5 LGR4609-7000 L4
6HOLE 2 1.5K 1% 1
0.1 0.1 10/50 J2 BEAD D94 3 2
D+5 DIG1
2 1 2 1
4 2 U9 R39
L3 3 D95 A114ES 150K
1 1 2 1 1
DGND
6HOLE C15 3 2
AC6.2B DIG0
BEAD 0.01
L2 DGND L5 DGND U8 R38
AC6.2A R48 A114ES 150K
Vdisp
C2 6HOLE C4 C6 100
0.1/50 0.1/50 10/50 P P
Vdisp A A
J1 1 0
SO_FL
1 AC6.2A Vdisp
J2 CE_FL LEDK[0..4]
2 AC6.2B
SCK_FL
3 VdispF D+5
D92 D88 D84
4 GND U3 LEDK[0..4]
D90 D86 D82 /S29
5 D+5F C114ES
/S28 R49
6 D+5F 2 2 2 2 2 2 NON 3 2 LEDK0
/S27
7 GND 39
8 GND 1 1 1 1 1 1 1
9 GND C12 0.1 U4
R42 R41
10 /RST NON 100 C114ES R50
11 /ATN1 3 2 LEDK1
12 /ATN2 R43
13 TXD R44 1 39
14 RXD 8 7 7 7 7 7 7 7 7 7 7 6 6 6 6 6 U1
0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5
15 SCK U5
R45 C114ES R51
8283M15P R46 P P P P AP P P S P S SS S P P LEDK2
0 0 0 0 VA A 9 O 9 C O I C 9 8 3 2
Vdisp=-29.5V 2 2 2 2 2 2 100x5 3 2 1 0 C 1 0 7 2 5 K 1 1 K 0 7 39
/ / / / C (O)(O)(O) (O) 2 1 (O)(O) 1
1 1 1 1 1 1 NON 2 A A A A / U6
N N N N C
D91 D87 D83 D81 3 2 1 0 E C114ES R52
NON D LEAD 1 1 64 3 2 LEDK3
D93 D89 D85 P04/AN4 P86(O)
DGND 2 63
P05/AN5 P85(O) 39
3 62 1
P06/AN6 P84(O)
X1 4 61
8MHz P07/AN7 P83(O) U7
5 60
/RST2 AVSS P82(O) NON C114ES
D+5 C7 R40 6 59
30p 1M TEST P81(O) R53
7 58 3 2 LEDK4
X2(O) P80(O)
8 57 NON 39
X1(I) VCC
9 56 FD15 1
C8 VSS FD15
C10 NJM2103 10 55 FD14 D+5
30p OSC1(I) FD14
U2 11 54 FD13
0.1 5 OSC2(O) FD13
/RST2 12 53 FD12
RES FD12
2 13 52 FD11
VSC V J1 IRQ0 FD11
C 3 14 51 FD10
OC P11(O) FD10
6 C 15 50 FD9 C13
VSB P12(O) FD9
C19 16 49 FD8 0.1
P13(O) FD8
7 470p 17 48 FD7
VSA P14(O) FD7
G 8 18 47 FD6
1 N RST 19
P15(O) FD6
46 FS2
CT D P16(I) FS2
C9 20 45 FS3
FS27 FS3
C11 0.01 21 44 FS4 DGND
FS26 FS4
0.1 4 22 43 FS5
FS25 FS5
23 42 FS6
FS24 FS6
24 41 FS7
FS23 FS7
DGND
DGND
V
F F F F F F F F F F F F F F F F F F D
S S S S S S S S S S S S S S S S S S F F I
2 2 2 2 2 2 2 2 1 1 1 1 1 1 1 1 1 1 S S S
7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8 P
H8/3B
2 2 2 2 2 3 3 3 3 3 3 3 3 3 3 4
5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0
D+5 FS22 FS8
FS21 FS9
FS23 FS20 FS10
1 FS24 FS19 FS11 FD[6..15]
R54 FD[6..15]
/LEDA0 3 Q1 FS25 FS18 FS12
A1150 FS26 FS17 FS13
1K 2 LEDA0 FS27 FS16 FS14
FS15
R55 1
/LEDA1 3 Q2
A1150 FS[2..27]
1K FS[2..27]
2 LEDA1
R56 1 NON
/LEDA2 3 Q3 W1 C14
A1150 LEDA[0..3] 0.1/50
1K 2 LEDA2
R57 1
/LEDA3 3 Q4 Vdisp
A1150
1K 2 LEDA3 DGND
LEDA[0..3]
D-108
57
58
D-108
KEY, DISPLAY, D-108 / D-160 (3/5)
DIG1
U12
JOG/SHUTTLE
DIG0
SHIFT REWIND A/P_IN

S9 D9 S13 D13 S46 D46
2 1 2 1 2 1
FS10 FS19 FS19

S S S C S J C J
1 2 3 1 4 2 2 1
1 2 3 4 5 6 7 8
SR_8/16 F.FWD AUTO PUNCH A/P_OUT COPY

D8 D14 D20 D47 D19 D+5
S8 S14 S20 S47 S19
2 1 2 1 2 1 2 1 2 1
C16
FS9 FS18 FS27 FS18 FS27 R58
22K 0.1
R59 R60
J1
10K 100K
AUTO PLAY R61
SR_7/15 PITCH UNDO C17
22K
S7 D7 S36 D36 S34 D34 S15 D15 0.01
2 1 2 1 2 1 2 1 R62 R63
J2
10K 100K
FS8 FS17 FS17 FS26
C18
0.01
REDO MOVE DGND

SR_6/14
S6 D6 D49 S35 D35 S43 D43
2 1 2 1 2 1 2 1
FS7 FS16 FS16 FS25
SR_5/13 END CLIP IN

S5 D5 D50 S31 D31 S21 D21
2 1 2 1 2 1 2 1
FS6 FS15 FS15 FS24
SR_4/12 RECORD HOLD/> CLIP OUT

S4 D4 D51 S10 D10 S39 D39 S22 D22
2 1 2 1 2 1 2 1 2 1
FS5 FS14 FS23 FS14 FS23
SR_3/11 STOP DISP SEL PASTE

S3 D3 D52 S11 D11 S37 D37 S44 D44
2 1 2 1 2 1 2 1 2 1
SR_2/10 EXIT/NO PLAY STORE START

S2 D2 S41 D41 S12 D12 S40 D40 S45 D45
2 1 2 1 2 1 2 1 2 1
SR_1/9 RECALL LOCATE EXEC/YES ERASE

S1 D1 S42 D42 S33 D33 S38 D38 S32 D32
2 1 2 1 2 1 2 1 2 1
FS[2..27] 26X2=52MAX
FS[2..27]
LED, DISPLAY, D-108 / D-160 (4/5)
LEDA[0..3]
LEDA[0..3]
LEDK[0..4] LEDA0 LEDA1 LEDA2 LEDA3

LEDK[0..4]
LED(GRN)
AUTO LED(GRN) LED(RED) LED(GRN)
RETURN REHEARSAL REC SHIFT
D73 D71 D65 D64
LEDK0
LED(GRN) LED(RED) LED(GRN) LED(GRN)

A.PLAY TAKE STOP MTC IN
D76 D69 D68 D61
LEDK1
LED(GRN) LED(GRN) LED(GRN) LED(GRN)

STORE PITCH PLAY HD ACCESS
D75 D74 D67 D62
LEDK2
LED(GRN) LED(GRN) LED(GRN) LED(GRN)

RECALL FF REW LOCKED
D72 D70 D66 D63
LEDK3
D-108
59
60
D-108
FL, DISPLAY, D-108 / D-160 (5/5)
C21 30p
D+5
R64,C19:REMOVE 0.1/50
C22
R65
10K
/RST2
C20 C23 DGND
Vdisp
0.1 470p G1
G2
G3
G4
CE_FL
DGND G5
SCK_FL
G6
SO_FL
6 6 6 6 6 5 5 5 5 5 5 5 5 5 5 4
4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 U14
D C C / V OOV T V GG GGGG
I L E R D S S S E F 1 2 3 4 5 6
E D C C S S L
1 S I O T 48 G7
AM1 G7
2 47 G8
AM2 G8
3 46 G9
AM3 G9
4 45 G10
AM4 G10
D+5 5 44 G11
AM5 G11
6 43 G12
AM6 AA8/G12
D+5 7 42 G13
D+5 AM7 AA7/G13
8 41 G14
AM8 AA6/G14
Vdisp 9 40 G15
Vdisp AM9 AA5/G15
10 39 G16
AM10 AA4/G16
DGND 11 38
DGND AM11 AA3
Vdisp 12 37
AM12 AA2
13 36
AM13 AA1
DGND 14 35
AM14 AM35
15 34
AM15 AM34
16 33
AM16 AM33
A A A A A A A A A A A A A A A A
MMMMMMMM MMMMMMMM
1 1 1 2 2 2 2 2 2 2 2 2 2 3 3 3
7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2
1 1 1 2 2 2 2 2 2 2 2 2 2 3 3 3
7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2
LC75710/1/2 FS[2..27]
FS[2..27]
FS2
R12
FS3
R13
FS4
R14
FS5 R15
FS6
R16
FS7
R17
FS8
R18
FS9
R19
FS10
R20
FS11
R21
FS12
R22
FS13
R23
FS14
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 R24
FS15 R25
4 3 3 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 9 9 9 9 9 9 9 9 9 8 8 8 8 8 8 8 8 8 8 7 7 7 7 FS16
0 9 8 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 3 2 1 R26
FS17
R27
U13 FS18
F F F D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D F F F R28
1 1 1 3 2 2 2 2 2 2 2 2 2 3 3 3 3 3 1 2 3 4 5 6 7 8 9 1 1 1 1 1 1 1 1 1 1 2 2 2 2 FL_D160 FS19 R29
0 9 8 7 6 5 4 3 2 1 1 2 3 4 5 0 1 2 3 4 5 6 7 8 9 0 FS20
R30
FS21
R31
FS22
R32
FS23 R33
FS24
R34
FS25
R35
FS26
R36
FS27 R37
GG GGGGG GGGG GGGGGG S S S S S S S S S S S S S S S S S S S S
F F F GGG GGGG G 1 1 G 1 1 1 1 1 2 2 2 2 2 2 2 1 1 1 2 2 2 S S S S S S S S S 1 1 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 F F F
1 1 1 1 2 3 4 5 6 7 8 5 6 9 0 1 2 3 4 6 5 4 3 2 1 0 9 8 7 9 8 7 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 2 2 2 FD6
R1
FD7 R2
1 1 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 2 2 3 3 3 3 3 3 3 3 3 4 4 4 4 4 4 4 4 4 5 5 5 5 5 5 5 5 5 5 6 6 6 6 6 7 FD8
1 2 3 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 0 1 2 3 4 5 6 7 8 9 0 1 2 8 9 0 R3
FD9
R4
AC6.2A FD10
AC6.2A R5
F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F FD11
R6
AC6.2B D D D D D D D D D D S S S S S S S S S S S S S S S S S S S S S S S S S S FD12
AC6.2B 1 1 1 1 1 1 9 8 7 6 2 3 4 5 6 7 8 9 1 1 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 R7
FD13 R8
5 4 3 2 1 0 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 FD14
R9
G G G G G G GG G G G G G G G G FD15
R10
D+5 1 2 3 4 5 6 7 8 1 1 9 1 1 1 1 1
5 6 0 1 2 3 4
150kx9
FD[6..15] Vdisp
U15
1 G[1..16]
FD[6..15]
3 2
/S27
A114ES 1
3 2
/S28
U16 R66 R67 R68
A114ES 1
3 2 150K 150K 150K
/S29
U17
A114ES
Vdisp
POWER / POWER SW / REGULATOR, D-108
4
U10 L7
2 DGND
Oadj
Vout
1
Vin 180uH DGND
GND
5 D1NL40 C30
on/off R15
D7 47K R16
PQ1CF2 330u/50
J2 22K
+12V C31
3
1 A+15 T2 10 C28
2 47/50 0.01
1
3 AGND 2
4 AGND R13 D8
R12
5 A-15 2K Q2
C32 9
6 DGND 4.7K 2SA1606
0.01
to MAIN 7 D+5 8
8
9 D+12 D+5 D10 6.8V
10 DGND S2V60 -30V
7 Vdisp
11 D+5 6
4
12 DGND
3
1
8263-12P U1C U1B U1A 5
7 6 5 4 3 2 R12
J1 DC-DCTRANS AC5.6-1
470
1 AC5.6-1 4049 Q1
2 AC5.6-2 4049 4049 R14
C29
8
3 Vdisp 2SK2661 100/2W
R11
to DISPLAY 4 DGND R10
5 D+5 10K 470p AC5.6-2
6 DGND 4.7K
7 DGND
DGND
8263M7P
4
OSC
U6
2 D+5
Oadj
J4 Vout
PCB,POWER SW,D-108 1
Vin
L4
1 D+5 180u R6
GND
EK13
to FAN 2 DGND 5 4.7K(1%)
C14 on/off D5
TP3 TP4
PIN PIN 8263M2P 100/25 PQ1CF2
C15 C27
S1
3
470/25 0.1
R7
POWER-SW 4P 1.5K(1%)
F1
FUSE2 T1 D4
U9 1
10
ano1
2 3.0A(MAX) D+12
to SW D9 kath
THERMISTER 3 L3
TP1 BRIDGE1 ano2
1 10uH
MA649
TP2 2 9
R8
to SW 100K/2W R2
C5 3 C7 C6
C25 330
4 470/25 470/25
R4
100U/400V 0.01/630
U3B 8.2K
D3
1
C8
8 470/25
19mH 5
D6 D1NL40
L1 MA171 7
D1N60 ON3171 C22
2
R3 0.01
6 C4
C1 C2 D1
TRANS 100 0.1
0.0022 / 250 0.0022 / 250 D1NL40 U2
MIP166 D2
FGND U5 R5
3 C16 2K
drain 0.1 AN1431
L2 2
1mH souce 47/25
1
control U3A
C9
C3 ON3171 DGND
0.1/250
DGND
C17
0.1 R1 R9
FGND
6.2 6.2 PCB,POWER REGULATOR,D-108
L6 L5 U1
A+15 +15V 7815 C5
6hole C3
3 1
6hole Vin Vout
GND
500mA(MAX) C1
0.01 0.01
J5 C12 10/16
C10 8263M6P 470/25 W1
470/25
2
6 6
J3
C18 C19 5 5
AC-IN 0.0022 0.0022 4 AGND 4
3 3
GND 2 C26 2
IN 85V-265V AC 1 0.1 1
C11 C6
3
470/25 to REGULATOR DGND AGND U2
C13 BIN6P 10/16
C4
GND
470/25 C2 0.01
0.01 2 1
Vin Vout
A-15 -15V
7915
500mA(MAX)
D-108
61
62
D-108
CONNECT, D-108
L1001
1 2
W1001 L1002
1 AC6.2A BEAD 1 2
2 AC6.2B L1003 J1001
3 VDISP 1 2 BEAD 16
4 DGND L1004 AC6.2A 1
5 D+5 BEAD 1 2 AC6.2B 11
6 DGND L1005 VDISP 6
7 DGND 1 2 BEAD 2
L1006 D+5 12
B.IN7P BEAD 1 2 D+5 7
L1007 3
1 2 BEAD-MMZ 13
L1008 8
BEAD-MMZ1 2 /RST_DISP 4
L1009 /ATN1 14
1 2 BEAD-MMZ /ATN2 9
L1010 TXD1 5
W1002 BEAD-MMZ1 2 RXD1 15
1 /RST_DISP L1011 10
2 /ATN1 1 2 BEAD-MMZ SCK1 17
3 /ATN2 L1012
4 TXD1 BEAD-MMZ1 2 DGND DSUB15P
5 RXD1 L1013
6 SCK1 1 2 BEAD-MMZ
7 DGND L1014
BEAD-MMZ1 2
B.IN7P L1015
1 2 BEAD-MMZ
BEAD-MMZ
ROOT, 8345 (1/3)
TO
MAIN
J1
1
/OP_RST 2
NEWCLKD OP_D0 3
OP_D1 4 A+5 C4 78M05 R38 C71
OP_D2 5 C2 U1 C5 TO
10/16 0.01 10 0.01
OP_D3 6 1 31/50 POWER
O I
OP_D4 7
NEWCLOCK
G
OP_D5 8 1W
OP_D6 9 W3
OP_D7 10 A+19 5
2
OP_A0 11 AGND 4
OP_A1 12 A-15 3
3
OP_D[0..7] OP_A2 13 D+5 2
OP_D[0..7]
OP_A3 14 AGND C72 DGND 1
OP_A4 15 0.01
G
/OP_IRQ 16 1 2 B-IN5P
O I
/OP_WR 17 C7 C1 C6 R39
OP_A[0..4] /OP_RD 18 U2
OP_A[0..4] 10/16 0.01 1/50 10 1W
/OP_CS1 19 A-5 79M05
/OP_CS2 20
/OP_RST
/OP_CS3 21
/OP_IRQ
D+5 /OP_CS4 22
/OP_WR
/LRCK 23
/OP_RD L7
EXT_LRCK 24 D+5
D+5 50uH
25
DGND /OP_CS3
/OP_CS4
EDGE FC-25P
EDGE
DGND WORD_IN
WORD_IN
16M DGND C3 C70
16M
A+5 47/16 100/16
EXT_LRCK
/LRCK
4R8M
A+5 4R8M
LTCF_N D+5
AGND LTCF_N
V_FIN C87 DGND GND
A-5 V_FIN
WORD_OUT
AGND A-5
14
OPTION\EXTSYNC\MCLK.SCH 0.01
0
DGND
1
TC & I/O 3 4
2 6
5
LTCF_N
U7A
TC V_FIN
16M
4R8M
74HC00 U7B
74HC00
D+5
& WORD_IN
WORD_OUT
EDGE
WORD_OUT 74HC00
U7D
0
D+5 13
D+5
DGND
I/O /OP_RST
/OP_RST
OP_A4 12
11
9
OP_D[0..7] 8
OP_D[0..7]
DGND 10
OP_A[0..4]
0
OP_A[0..4]
U7C
/OP_IRQ 74HC00
/OP_IRQ
A+5 /OP_WR
/OP_WR
/OP_RD
A+5 /OP_RD
CS_TCG
AGND CS_TCG
CS_TCR
A-5 CS_TCR
0
AGND A-5
OPTION\EXTSYNC\TC_IO.SCH 12 13
0
U24F
74HC04
10 11
U24E
74HC04
DGND
D-108
63
64
D-108
MCLK, 8345 (2/3)
OP_A[0..4]
OP_A[0..4]
CONNECT
OP_D[0..7]
OP_D[0..7]
OP _D7
OP _D6
OP _D5
OP _D4
OP _D3
OP _D2
OP _D1
OP _D0
OP _A4
OP _A3
OP _A2
OP _A1
OP _A0
OP _D7
OP _D6
OP _D5
OP _D4
OP _D3
OP _D2
OP _D1
OP _D0
OP _A4
OP _A3
OP _A2
OP _A1
OP _A0
/OP_RD
CONNECT
/OP_WR
CONNECT
/OP_CS3 /OP_CS4
TC
/OP_IRQ
CONNECT
/OP_RST
TC 16M
16M
D+5
100
100
C67
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
C57 D+5 C66 D+5 D+5 470p D+5
0.01 470p
DGND
14
RDB
RDB
RSTB
IRQB
CSB
WRB
RSTB
IRQB
CSB
WRB
D7
D6
D5
D4
D3
D2
D1
D0
A4
A3
A2
A1
A0
D7
D6
D5
D4
D3
D2
D1
D0
A4
A3
A2
A1
A0
GND
GND
GND
GND
U14B
0
DGND R40 C56 DGND C55 C53 C54

74HCU04 100
3 4 1 2 0.01 1 80 0.01 0.01 1 80 0.01
GND GND GND GND
2 79 2 79
VDD VDD VDD VDD
3 78 3 78
U14A 16M TST4 16M TST4
4 77 4 77
74HCU04 LTCF_N LTCF TST3 LTCF TST3
TC 5 76 5 76
V_FIN FRMP TST2 FRMP TST2
R37 R68 6 75 6 75
AUXF TST1 AUXF TST1
1M 7 74 7 74
FRMR TST0 FRMR TST0
8 73 8 73
FW VITC FW VITC
R36 100 9 72 9 72
X1 EDGE FWM CSYB FWM CSYB
100 10 71 10 71
16MHz FWO VCKI FWO VCKI
11 70 11 70
C69
NON UM-1
C89
470P
12
13
C1RB
EDGB
28M
NEWCLK1 VITI
MCK2
MCK1
69
68
12
13
C1RB
EDGB
28M
NEWCLK2 VITI
MCK2
MCK1
69
68
14 67 14 67
GND HXCK WORD_OUT GND HXCK
DGND 15 66 15 66
FRMM LRCK FRMM LRCK
16 65 16 65
FRMS U16 MPX2 FRMS U17 MPX2
C39 17 64 17 64 D+5
C1SB MPX1 C1SB MPX1
22p 18 UPD65640 63 D+5 18 UPD65640 63
TCFM FSYN TCFM FSYN
19 62 19 62
C38 TCFP NJCK TCFP NJCK
20 61 20 61 DTC114EK D9
30p INTW GND INTW GND
DGND 21 60 DTC114EK D10 21 60 U18 LED
/LRCK C3R LTFI C3R LTFI
EXT_IO 22 59 U22 LED 22 59 2 3
WORD_IN EXTW TCFI EXTW TCFI
CONNECT 23 58 2 3 23 58
DIGW Q DIGW Q
R61 24 57 24 57 R45
AUXW B R46 AUXW B
CONNECT 25 56 D+5 25 56
1
WREF A 270 WREF A 270
26 55 26 55 DGND
1
TCCK C3UL TCCK C3UL
R64 100 27 54 C79 DGND 27 54
C2R C2UL C2R C2UL C81
28 53 0.01 DTC114EK D11 28 53
GND GND GND GND
C88 29 52 U23 LED 29 52 0.01
VDD VDD VDD VDD
0
1M 470P 30 51 2 3 C80 30 51
C2CK C1UL C2CK C1UL
R63
10 11
12 13 R47 0.01
EXT_LRCK
C1HB
C2HB
C3HB
C1HB
C2HB
C3HB
C1NT
C2NT
C3NT
C1NT
C2NT
C3NT
C3CK
C3CK
DGND C78
C1PT
C2PT
C3PT
270
C1PT
C2PT
C3PT
GND
GND
GND
GND
GND
GND
C1LI
C2LI
C3LI
C1LI
C2LI
C3LI
256F
128F
256F
128F
1
C3S
C3S
100 U14E U14F DGND
FS
FS
0.01
74HCU04 74HCU04
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
A+5 L3 C45 C44
22uH
10/16 0.01 A+5 L6 C51 C50
DGND DTC114EK 22uH
C43 U28 10/16 0.01
R53
DGND L4 0.01 3 2
1.5k C49 TP
22uH
A+5 U20 A+5 L5 0.01 TP2
1
U27 1 16
1
REF VDD 22uH
DTA114EK 2 15 AGND U21
PD LOCK
D+5 2 3 3 14 TP 3 2 1 16
1
C61 VDDA S2 REF VDD 4R8M
4 13 TP3 2 15
AMPI S1 R52 PD LOCK R44
U12A R50 0.01 5 12 U29 3 14 TC
AMPO M2 1.5k VDDA S2
DTC114EK 1.5k R54 6 11 DTA114EK 4 13 100
14
C27 74HC74 VSSA M1 AMPI S1

4
U26 220k 7 10 C64 0.01 5 12
1
0.01 XI CKO AMPO M2
2 3 8 9 R56 6 11
XO VSS R43 VSSA M1
220k 7 10
S
VCC
R55 C62 XI CKO

2 5 R51 TC9246F 100 8 9
D Q 100 0.47 XO VSS
3 6 1.5k C60 R57
1
C Q C65
DGND AGND 15p C46 TC9246F
R
C42 C63 100 0.47

10/16 0.01 15p C48 C47
R76 A+5 C58
1
10/16 0.01
0.01
AGND
C95 10K A+5
0.0022 AGND AGND
R65
DGND NON L2 A+5
R49 C41 C40 22uH C82
100 0.01
0.01
C52 R34 R35
R41
0.1 R67 0.01 D+5
1k
D+5 R48 10k AGND
8
2
100 AGND 680 1M TP
R42 R66 0 TP1
14
D+5 1.5k
0
2 10k
VCC
1 6 R33
DGND U25B U14C
A+5 3 7 1 3 1 2 3 4 5 6
1
VIN OUT R60 74HCU04
5 74HCU04
0
GND DGND 2.2K 330
GND
C91 U19A C37 U25A
R59 U19B 56p
NJM2115M
4
0
NON C92 U15 U25C
A+5 4.7k NJM2115M 74HCU04 5 6 9 8 U14D
0
NON VCO 74HCU04 74HCU04
0
AGND AGND
1
4
A+5
R58 D12 W2
0
4.7k NON NON U25E 11 10
AGND C68 AGND 74HCU04
0.01
0
A-5
0
AGND 28M AGND
0
U25F 13 12
A-5 9 8 U25D 74HCU04
74HCU04
W1
0
AGND 0 R62
0
NON
C73 AGND
NON
2
D13
NON C75
NON
1
AGND C74 AGND

NON
TC I/O, 8345 (3/3)
A+5
3
L8 XLR-3-31
C59 J7
D14 R69 10/16 BEAD
DAN202K
3
A+5 1 22 1
1
D15 10k R70
R4 1M DAN202K
100K
R29
4
R71 AGND A+5
OP _A3
OP _A2
OP _A1
OP _A0
6
5
8
3
R28 1M R1 U5 AGND
0
100 2.7K
CONNECT CS_TCG 100 2 D2 C16
CS_TCG + R2
/OP_WR 6 54 3 7 DAN202K 10/16 L9
10K
/OP_RD 3 1 2
TC IN
1
-
U24C U24B A+5
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
3
74HC04 74HC04 NJM311M BEAD
C29 R5 R6
1
4
0.01 10K R11 D1 R3
TNRZ
10K
NJ
NJGT
P ORT
FSI
RDB
WRB
CSB
LTCB
TCR
LTC
LTCF
FSO
TGEN
A3
A2
A1
A0
LTCO
1K
DAN202K
1
100K
OP_D[0..7]
OP_D[0..7]
CONNECT
OP_A[0..4] OP_D0 52 32
OP_A[0..4] D0 EMPT
OP_D1 53 31
D1 FRCI
OP_D2 54 30
D2 FRCO C11 C15 R12
OP_D3 55 29 D+5
D3 SFMI 0.01 10/16 1K
OP_D4 56 U3 28 AGND AGND
D4 SFMO
/OP_WR OP_D5 57 27 A+5 R7
/OP_WR D5 VDD C76
CONNECT /OP_RD 58 TCG 26 2K
/OP_RD GND GND 0.01
59 25 C28
TEST NTM
OP_D6 60 24 0.01
D6 FSYN
OP_D7 61 23 C8
D7 TRGI
8
/OP_IRQ 62 22 R8 5600P XLR-3-32
/OP_IRQ IRQB TRGO C9 L1
CONNECT /OP_RST 63 21 DGND 10K J8
/OP_RST RSTB NCKI 47/16 BEAD
64 20 2
SBYB NCKO
D+5 A+5 1 1 22 1
C93
NON
3
R10
TC OUT
CDW N
150
EDGE
SYNC
RP EO
4R8M
2BCO
RVRS
SFTO
R9
RP EI
SFTR
FSL0
FSL1
2BCI
256F
BCO
STIL
U6A
SFTI
R14
BCI
C35 C86
DF
47K
4
100p 4.7k NJM4580 47p
AGND C90 A-5
0.01
R73
1
2
3
4
5
6
7
8
9
2K
10
11
12
13
14
15
16
17
18
19
DGND R13
4.7k C10 R75 AGND
0.01 C83 47K
4R8M
0
NEWCLK 5600P C85
EDGE C14 C84
R72 47p
AGND 10/16 6 47/16
7 1 2
10K
5
R74
OP _A3
OP _A2
OP _A1
OP _A0
L10
150
C94 U6B BEAD
NON D+5
0
C30 NJM4580
NEWCLK LTCF_N
LTCF_N
CONNECT
CS_TCR
/OP_WR 0.01
3
/OP_RD
D+5 U8 WORD
1 16 D4 BNC
33
32
31
30
29
28
27
26
25
24
23
C33 1A VCC
2 15 R16 J3
0.01 1B 1S
D+5 3 14 2
IN
1
2R 1R
4 13
RDB
WRB
CSB
LTC
X1I
LTCF
2S 1Y
A3
A2
A1
A0
X1O
5 12 100
2A 3A
3
6 11 R17 C17
1
2B 3S
5
OP_D0 34 22 7 10 75 47p
10
IO0 LDTI 2Y 3R D5
0
DGND OP_D1 35 21 8 9
IO1 LDTO GND 3Y
3
OP_D2 36 20 R32 1
IO2 LCKI
OP_D3 37 19 R15 NEWCLK 100 SN75124 2 S1
1
VCC
S
IO3 U4 LCKO
OP_D4 38 18 9 12 NEWCLK 6 5 D6 3 SSSF1 DGND
IO4 8M Q D WORD_IN
39 17 8 11
VDD TCR GND Q C 16M
OP_D5 40 16 100 U13C BNC
1
IO5 VITC
R
OP_D6 41 15 74HC04 R18 J4
OUT
4
IO6 CSYB U12B
OP_D7 42 14 DGND 2
IO7 SYNC
43 13 74HC74 C31
13
IRQB VCKO
44 12 10
RSTB VCKI
C18
1
XOUT
VDDT
FLMK
SMP B
VSYB
FRMP
3
VSBO
NTSB
0.01 47p
B1M
X0O
X0I
C36 DGND
100p U9 D3
1 16
1A VCC R19
2 15
1
2
3
4
5
6
7
8
9
10
11
1
1B 2F
DGND 3 14 1k
1C 2E
0
R31 4 13
1D 2D
NEWCLK NEWCLK 100 5 12
V_FIN 1E 2C
9 8 6 11
WORD_OUT 1F 2B
DGND 7 10
1Y 2A
U13D 8 9
GND 2Y
74HC04
COMP_SYNC SN75123
D+5 A+5 A+5
D+5 A+5 C26 DGND

C13 C12 0.01
10/16 10/16 A+5
DGND AGND
10
12
14
2
GND DGND AGND C23

A-5
C25
U11
3
10/16
NC
S1
-VSY
2Y
VIN
SIN
-CSY
A-5 NJM2207M 0.01

R24 D8
VIDEO
6
7
C32 D+5 C77 D+5 3.3k BNC
0.01 0.01 C20 C19 R20 J5
1
VOUT
5 8 2
IN
14
14
VCC
VEE
CSY
VHI
Y1
S2
0.01 4 1 10/16 1k
1 2 1 2 R26 C21
1
75 47p
1
11
13
0
5
U13A U24A
3
2
3
74HC04 74HC04 BNC
3 4 9 8 U10 R23 R22 R21 1 J6
0
C24 NJM592M 10k 10k D7 100k 2 2

0
U13B U24D R30 R25 C34 3

74HC04 74HC04 12 13 R27 THRU
1
11 10 220p 1M 0.01 C22
1
100 100 47p
4
U13E U13F DGND
74HC04 74HC04 S2
DGND DGND
SSSF1 FRAME
AGND A-5
D-108
65
66
D-108
BALANCE I/O, ROOT, 5040 (1/3)
BALANCE IN BALANCE IND BALANCE OUT

(5040 & 5041) TO MAIN
J1 J4
26 L802 N.C. 17 9..16CH (5040 & 5041)
1 L801 1 2 HOT_IN8 16
HOT_IN8 BAL_IN8
14 1 2 COLD_IN8 15 BALANCE OUT 9..16CHD12D10 J2
COLD_IN8 GNDI8
2 L702 GND_IN8 14 L1604 26
GND_IN8 BAL_IN7 L1603
15 L701 1 2 HOT_IN7 13 HOT_OUT16 1 2 1
HOT_IN7 GNDI7 AOUT16+ HOT_OUT16
3 1 2 COLD_IN7 12 COLD_OUT16 1 2 14
COLD_IN7 BAL_IN6 COLD_OUT16
16 L602 GND_IN7 11 GND_OUT16 L1504 2
GND_IN7 GNDI6 AOUT15+ GND_OUT16
4 L601 1 2 HOT_IN6 10 HOT_OUT15 L1503 1 2 15
HOT_IN6 BAL_IN5 HOT_OUT15
17 1 2 COLD_IN6 9 COLD_OUT15 1 2 3
COLD_IN6 GNDI5 AOUT14+ COLD_OUT15
5 L502 GND_IN6 8 GND_OUT15 L1404 16
GND_IN6 BAL_IN4 GND_OUT15
18 L501 1 2 HOT_IN5 7 HOT_OUT14 L1403 1 2 4
6 1 2 COLD_IN5 6 COLD_OUT14 1 2 17
COLD_IN5 BAL_IN3 COLD_OUT14
19 L402 GND_IN5 5 GND_OUT14 L1304 5
GND_IN5 GNDI3 AOUT12+ GND_OUT14
7 L401 1 2 HOT_IN4 4 HOT_OUT13 L1303 1 2 18
HOT_IN4 BAL_IN2 HOT_OUT13
20 1 2 COLD_IN4 3 COLD_OUT13 1 2 6
COLD_IN4 GNDI2 AOUT11+ COLD_OUT13
8 L302 GND_IN4 2 GND_OUT13 L1204 19 BALANCE
GND_IN4 BAL_IN1 GND_OUT13
21 L301 1 2 HOT_IN3 1 HOT_OUT12 L1203 1 2 7 OUTPUT
9 1 2 COLD_IN3 COLD_OUT12 1 2 20
COLD_IN3 COLD_OUT12
22 L202 GND_IN3 FC 17P GND_OUT12 L1104 8 9--16CH
GND_IN3 AOUT9+ GND_OUT12
10 L201 1 2 HOT_IN2 HOT_OUT11 L1103 1 2 21
HOT_IN2 HOT_OUT11
23 1 2 COLD_IN2 COLD_OUT11 1 2 9 (5040 & 5041)
COLD_IN2 COLD_OUT11
11 L102 GND_IN2 GND_OUT11 L1004 22
GND_IN2 GND_OUT11 L1003
24 L101 1 2 HOT_IN1 HOT_OUT10 1 2 10
HOT_IN1 HOT_OUT10
12 1 2 COLD_IN1 A+15 COLD_OUT10 1 2 23
COLD_IN1 MUTE COLD_OUT10
25 GND_IN1 GND_OUT10 L904 11
GND_IN1 A+15 GND_OUT10
13 N.C. A+15 HOT_OUT9 L903 1 2 24
J6 (5040 & 5041) AGND1 HOT_OUT9
27 COLD_OUT9 1 2 12
A-15 A+15 COLD_OUT9
GND_OUT9 25
DSUB-25P
BAL IN A-15 AGND1
AGND1
A-15
GND_OUT9
13
27
AGND1 OPTION\BAL_IO\BAL_IN.SCH AGND1 A-15 OPTION\BAL_IO\BLO_9_16.SCH
DSUB-25P
BALANCE OUT 1..8CH AGND1 J3

J5 L804 26
17 HOT_OUT8 L803 1 2 1
FC 8P AOUT8+ HOT_OUT8
8 16 COLD_OUT8 1 2 14
COLD_OUT8
7 15 GND_OUT8 L704 2
AOUT7+ GND_OUT8
6 14 HOT_OUT7 L703 1 2 15
HOT_OUT7
TO MAIN 5 13 COLD_OUT7 1 2 3
AOUT6+ COLD_OUT7
4 12 GND_OUT7 L604 16
GND_OUT7
D-80EX 3 11 HOT_OUT6 L603 1 2 4
AOUT5+ HOT_OUT6
2 10 COLD_OUT6 1 2 17
COLD_OUT6
(5040 ONLY) 1 9 GND_OUT6 L504 5
AOUT4+ GND_OUT6
8 HOT_OUT5 L503 1 2 18
HOT_OUT5
7 COLD_OUT5 1 2 6 BALANCE
AOUT3+ COLD_OUT5
6 GND_OUT5 L404 19 OUTPUT
GND_OUT5
5 HOT_OUT4 L403 1 2 7
AOUT2+ HOT_OUT4
4 COLD_OUT4 1 2 20 1--8CH
COLD_OUT4
TO MAIN 3 GND_OUT4 L304 8
AOUT1+ GND_OUT4
2 HOT_OUT3 L303 1 2 21 (5041 ONLY)
HOT_OUT3
D-160 1 COLD_OUT3 1 2 9
COLD_OUT3
GND_OUT3 L204 22
GND_OUT3
(5041 ONLY) FC 17P HOT_OUT2 L203 1 2 10
HOT_OUT2
COLD_OUT2 1 2 23
MUTE COLD_OUT2
GND_OUT2 L104 11
GND_OUT2
A+15 A+15 HOT_OUT1 L103 1 2 24
W1 HOT_OUT1
COLD_OUT1 1 2 12
A+15 COLD_OUT1
1 GND_OUT1 25
AGND1 GND_OUT1
2 13
A-15
TO MAIN 3 27
4 MUTE AGND1 A-15 OPTION\BAL_IO\BLO_1_8.SCH
DSUB-25P
BOADIN-4P
BALANCE OUT 1..8CH (5041 ONLY) AGND1
A-15 AGND1
BALANCE I/O, INPUT, 5040 (2/3)
A+15 A+15
C1 G=-5.8dB C5 G=-5.8dB
0.01 0.01
R106 R506
5.6k 5.6k
C102 C502
R104 C106 C104 W101 R504 C506 C504 W501
8
47/16 47/16
22k NON JUMPER 22k NON JUMPER
COLD_IN1 47p COLD_IN5 47p
2 -10dBv 2 -10dBv
1 1
BAL_IN1 BAL_IN5
3 3
HOT_IN1 HOT_IN5
U1A C105 U3A C505
R103 R503
C101 4560 NON C501 4560 NON
47/16 22k R107 47/16 22k R507
4
R102 R101 R105 C103 NON R502 R501 R505 C503 NON
100k 100k 5.6k 47p 100k 100k 5.6k 47p
C2 C6
GND_IN1 GNDI1 GND_IN5 GNDI5
0.01 0.01
A-15 G=-5.8dB A-15 G=-5.8dB
R206 R606
5.6k 5.6k
C202 C602
R204 C206 C204 W201 R604 C606 C604 W601
0
47/16 47/16
6 -10dBv 6 -10dBv
7 7
BAL_IN2 BAL_IN6
5 5
HOT_IN2 HOT_IN6
U1B C205 U3B C605
R203 R603
C201 4560 NON C601 4560 NON
47/16 22k R207 47/16 22k R607
0
0
R202 R201 R205 C203 NON R602 R601 R605 C603 NON
100k 100k 5.6k 47p 100k 100k 5.6k 47p
A+15
A+15
C9
47/16
AGND1
C10 A+15 A+15
47/16 C3 G=-5.8dB C7 G=-5.8dB
A-15 0.01 0.01
A-15 AGND R306 R706
5.6k 5.6k
C302 C702
R304 C306 C304 W301 R704 C706 C704 W701
8
8
47/16 47/16
2 -10dBv 2 -10dBv
1 1
BAL_IN3 BAL_IN7
3 3
HOT_IN3 HOT_IN7
U2A C305 U4A C705
R303 R703
C301 4560 NON C701 4560 NON
47/16 22k R307 47/16 22k R707
4
4
R302 R301 R305 C303 NON R702 R701 R705 C703 NON
100k 100k 5.6k 47p 100k 100k 5.6k 47p
C4 C8
0.01 0.01
A-15 A-15
G=-5.8dB
R406 G=-5.8dB R806

5.6k 5.6k
C402 C802
R404 C406 C404 W401 R804 C806 C804 W801
0
0
47/16 47/16
6 -10dBv 6 -10dBv
7 7
BAL_IN4 BAL_IN8
5 5
HOT_IN4 HOT_IN8
U2B C405 U4B C805
R403 R803
C401 4560 NON C801 4560 NON
47/16 22k R407 47/16 22k R807
0
0
R402 R401 R405 C403 NON R802 R801 R805 C803 NON
100k 100k 5.6k 47p 100k 100k 5.6k 47p
D-108
67
68
D-108
BALANCE I/O, OUTPUT 9 - 16, 5040 (3/3)
A+15 A+15
R1611
C43
0.01
R1211
C35
0.01
9..16CH
15k 15k
8
C1610 C1210 C1212
C1612
C1607 2 100p C1207 2 100p 220/10
R1608 220/10 R1208
47/16 3.3k 1 47/16 3.3k 1
HOT_OUT16 HOT_OUT12
3 DTC314TK 3 DTC314TK
AOUT16+ U1601A R1613 R1615 AOUT12+ U1201A R1213
C1608 U1602 C1208 U1202
4580 100 100k 2 3 4580 100 2 3
NON 1/4W NON 1/4W
R1210
4
R1610 R1215
C44 10k C36 100k
10k
1
GND_OUT16 GND_OUT12
1
0.01 R1616 0.01
R1216
A-15 100k 2 3 A-15 100k 2 3
U1601B
4580 U1201B
4580
R1609 5 U1603 R1209 5 U1203
R1614 R1214
3.3k COLD_OUT16 3.3k COLD_OUT12
6 100 6
100
C1609 1/4W C1613 C1209 1/4W C1213
NON 220/10 NON C1211 100p 220/10
C1611
R1612 R1212
100p
8.2k 8.2k
A+15 A+15
C41 C33
0.01 0.01
R1511 R1111
15k 15k
8
C1510 C1110
C1512 C1112
100p
C1507 R1508 2 220/10 C1107 R1108 2 100p 220/10
47/16 3.3k 1 47/16 3.3k 1
HOT_OUT15 HOT_OUT11
3 R1513 DTC314TK 3 DTC314TK
AOUT15+ U1501A AOUT11+ U1101A R1113
C1508 U1502 C1108 U1102
100 4580 100
NON 4580 2 3 NON 2 3
1/4W 1/4W
R1510 R1515 R1110
4
4
R1115
10k C42 100k 10k C34 100k
1
GND_OUT15 GND_OUT11
1
0.01 0.01
R1516 R1116
A-15 100k 2 3 A-15 100k 2 3
U1501B
4580 U1101B
4580
R1509 5 U1503 R1109 5 U1103
R1514 R1114
6 100 6
100
C1509 1/4W C1513 C1109 1/4W C1113
NON 220/10 NON 220/10
C1511 A+15 C1111 100p
100p
R1512 R1112
A+15
8.2k 8.2k
C45
47/16
AGND1
A+15 A+15
C39 C46 C31
0.01 47/16 0.01
A-15
R1411 R1011
15k A-15 AGND1 15k
8
8
C1410 C1010
100p C1412 C1012
C1407 2 220/10 C1007 2 100p 220/10
R1408 R1008
47/16 3.3k 1 47/16 3.3k 1
HOT_OUT14 HOT_OUT10
AOUT14+ U1401A AOUT10+ U1001A R1013
C1408 U1402 C1008 U1002
100 4580 100
NON 4580 2 3 NON 2 3
1/4W 1/4W
R1410 R1010
4
4
R1415 R1015
10k C40 100k 10k C32 100k
1
1
GND_OUT14 GND_OUT10
1
1
0.01 R1416 0.01
R1016
A-15 100k 2 3 A-15 100k 2 3
U1401B
4580 U1001B
4580
R1409 5 U1403 R1009 5 U1003
R1414 R1014
6 100 6
C1413 100
C1409 1/4W C1009 1/4W C1013
NON 220/10 NON 220/10
C1411 100p C1011 100p
R1412 R1012
8.2k 8.2k
A+15 A+15
C37 C29
0.01 0.01
R1311 R911
15k 15k
8
8
C1310 C1312 C910 C912
C1307 2 100p 220/10 C907 2 100p 220/10
R1308 R908
47/16 3.3k 1 47/16 3.3k 1
HOT_OUT13 HOT_OUT9
AOUT13+ U1301A AOUT9+ U901A R913
C1308 U1302 C908 U902
4580 100 2 3 4580 100 2 3
NON 1/4W NON 1/4W
R1310 R910
4
R1315
4
R915
10k C38 100k 10k C30 100k
1
1
GND_OUT13 GND_OUT9
1
1
0.01 0.01
R1316 R916
A-15 100k 2 3 A-15 100k 2 3
U1301B
4580 U901B
4580 C913
R1309 5 U1303 R909 5 220/10 U903
7 R1314 DTC314TK 7 R914 DTC314TK
6 100 6 100
C1309 C1313 C909
1/4W 1/4W
NON 220/10 NON
C1311 100p C911 100p
R1312 R912
8.2k 8.2k
MUTE
D-108
<NOTE>
69
FOSTEX CORPORATION 3-2-35 Musashino, Akishima, Tokyo, Japan 196-0021
FOSTEX CORPORATION OF AMERICA 15431 Blackburn Ave., Norwalk, CA 90650, U.S.A.

Service Manual for D-108 Digital Multitrack Recorder

Uploaded by

Document Information

Original Description:

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Service Manual for D-108 Digital Multitrack Recorder

Uploaded by

Copyright:

Available Formats

Service Manual

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, ATTENTION:

* Following is the packing material for the Model D-108.

TIME CODE OUTPUT

2. CONTROLS, INDICATORS & CONNECTORS

< Front Panel Section with Detachable Controller >

8TRACK DIGITAL RECORDER D-108

COPY MOVE PASTE ERASE UNDO REDO HOLD/ STORE RECALL

POWER PGM SEL PREVIEW

LOCKED HD ACCESS TC IN CLIPBOARD PLAY

< Front Panel Section without Detachable Controller >

8TRACK DIGITAL RECORDER D-108

< Rear Panel Section >

ANALOG IN ANALOG OUT MIDI DATA OPTICAL SCSI

< Front Panel Section without Detachable Controller >

8TRACK DIGITAL RECORDER D-108

< Detachable Controller Section >

8TRACK DIGITAL RECORDER D-108

PGM SEL PREVIEW

LOCKED HD ACCESS TC IN CLIPBOARD PLAY

32. Copy key [COPY] 38. Rewind button [REWIND]

< Rear Panel Section >

ANALOG IN ANALOG OUT MIDI DATA OPTICAL SCSI

VIDEO WORD TIME CODE

ANALOG IN ANALOG OUT MIDI DATA OPTICAL SCSI

3-1. Method of Sending Software from Fostex Japan

3-2. Required Tools

3-3. Software Updating Procedures

*: Model 8345 is required.

SlaveType? Slave_Mode? 00h59m57s00f00sf

4-2. Flash ROM & CPU Version

4-4. Standby Disk

4-4. Display/Button Test

Key/Button No. Key/Button No. Key/Button No.

4-5. Self Check

< Cable connection in “Self Check” mode >

ANALOG IN ANALOG OUT MIDI DATA OPTICAL SCSI

External SCSI Device

4-5-1. SCSI Port Check

The following is considered to be the cause of problem.

4-5-2. ATA (E-IDE) Bus Check

The following is considered to be the cause of problem.

4-5-3. Option (Model 8345) Bus Check

The following is considered to be the cause of problem.

4-5-4. MIDI In/Out Check

The following is considered to be the cause of problem.

4-5-5. S/P DIF In/Out (44.1kHz) Check

The following is considered to be the cause of problem.

4-5-6. Adat In/Out (48kHz) Check

The following is considered to be the cause of problem.

4-5-7. 8345 Vari-Pitch Circuit (48kHz) Check

The following is considered to be the cause of problem.

4-5-8. D-108 Vari-Pitch Circuit (48kHz) Check

The following is considered to be the cause of problem.

4-6. Offset Display

4-7. Initializing Disk

4-8. Flash ROM

In this case, the following procedures must be taken.

4-9. Free Block Check

5. ERROR CODE LIST

D-108 ERROR CODE LIST

6. MODEL 8345/5040 INSTALLING PROCEDURES
