Service Manual Guide for 16/8 Track Digital Recorders

Service Manual
Model
&
MODEL 8345 TC/SYNC CARD
MODEL 5042 / 5043 BALANCE I/O CARD
MODEL 8350 AES/EBU CARD
16TRACK DIGITAL RECORDER

8TRACK DIGITAL RECORDER
CAUTION:
CAUTION TO PREVENT ELECTRIC SHOCK, MATCH
RISK OF ELECTRIC SHOCK
WIDE BLADE OF PLUG TO WIDE SLOT,
DO NOT OPEN
FULLY INSERT.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, ATTENTION:

DO NOT REMOVE COVER (OR BACK). POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE
NO USER-SERVICEABLE PARTS INSIDE.
LA FICHE DANS LA BORNE CORRE-
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. SPONDANTE DE LA PRISE ET POUSSER
JUSQU' AU FOND.
The lightening flash with arrowhead symbol, The exclamation point within an equilateral
within an equilateral triangle, is intended to triangle is intended to alert the user to the
alert the user to the presence of uninsulated presence of important operating and mainte-
“dangerous voltage” within the product's en- nance (servicing) instructions in the literature
closure that may be of sufficient magnitude to accompanying the appliance.
constitute a risk of electric shock to persons.
“WARNING”
“TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOIS-
TURE.”
SAFETY INSTRUCTIONS
1. Read instructions - All the safety and operating instruc- 9. Heat - The appliance should be situated away from heat
tions should be read before the appliance is operated. sources such as radiators, heat registers, stoves, or other
2. Retain instructions - The safety and operating instructions appliances (including amplifiers) that produce heat.
should be retained for future reference. 10. Power Sources - The appliance should be connected to a
3. Heed warnings - All warnings on the appliance and in the power supply only of the type described in the operating
operating instructions should be adhered to. instructions or as marked on the appliance.
4. Follow instructions - All operating and use instructions 11. Grounding or Polarization - The precautions that should
should be followed. be taken so that the grounding or polarization means of
5. Water and Moisture - The appliance should not be used an appliance is not defeated.
near water - for example, near a bathtub, washbowl, 12. Power Cord Protection - Power supply cords should be
kitchen sink, laundry tub, in a wet basement, or near a routed so that they are not likely to be walked on or
swimming pool, and the like. pinched by items placed upon or against them, paying
6. Carts and Stands - The appliance should be used only particular attention to cords at plugs, convenience recep-
with a cart or stand that is recommended by the manufac- tacles, and the point where they exit from the appliance.
turer. 13. Cleaning - The appliance should be cleaned only as rec-
ommended by the manufacturer.
14. Nonuse Periods - The power cord of the appliance should
be unplugged from the outlet when left unused for a long
period of time.
15. Object and Liquid Entry - Care should be taken so that
objects do not fall and liquids are not spilled into the en-
closure through openings.
16. Damage requiring Service - The appliance should be ser-
An appliance and cart combination should be moved with
viced by qualified service personnel when:
care. Quick stops, excessive force, and uneven surfaces
A. The power supply cord or the plug has been damaged;
may cause the appliance and cart combination to over-
or
turn.
B. Objects have fallen, or liquid has been spilled into the
7. Wall or Ceiling Mounting - The appliance should be
appliance; or
mounted to a wall or ceiling only as recommended by the
C. The appliance has been exposed to rain; or
manufacturer.
D. The appliance does not appear to operate normally or
8. Ventilation - The appliance should be situated so that its
exhibits a marked changed in performance; or
location or position does not interfere with its proper ven-
E. The appliance has been dropped, or the enclosure
tilation. For example, the appliance should not be situ-
damaged.
ated on a bed, sofa, rug, or similar surface that may block
17. Servicing - The user should not attempt to service the ap-
the ventilation openings; or, placed in a built-in installa-
pliance beyond that described in the operating instruc-
tion, such as a bookcase or cabinet that may impede the
tions. All other servicing should be referred to qualified
flow of air through the ventilation openings.
service personnel.
D1624 / D824
TABLE OF CONTENTS
1. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. CONTROLS, INDICATORS & CONNECTORS . . . . . . . . . . . . . . . 8
3. SOFTWARE UPDATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. SERVICE MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5. ERROR CODE LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6. MODEL 8345/5042/5043/8350 INSTALLING PROCEDURES . . . . . 23
7. EXPLODED VIEW, PCB ASSEMBLY & PARTS LIST . . . . . . . . . . 30
8. CIRCUIT & BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . 58
NOTES
* Service mode, exploded view, PCB assembly, parts list and circuit diagrams are given in this manual
to assist the service technician in maintaining the Model D1624 / D824.
* The following accessories are supplied with D1624 / D824 as the standard accessories.
D1624 / D824 English owner's manual : 8288461000
D1624 / D824 Japanese owner's manual : 8288462000
D1624 / D824 English quick guide : 8288463000
D1624 / D824 Japanese quick guide : 8288464000
* Following is the packing material for the Model D1624 / D824.

Carton, inner, D1624 : 8228731000
Carton, outer, D1624 : 8228910000
Carton, inner, D824 : 8228736000
Carton, outer, D824 : 8228914000
Packing, side, L, D1624 / D824 : 8228430001
Packing, side, R, D1624 / D824 : 8228430002
Packing, case, D1624 / D824 : 8228435000
CAUTION
! Parts marked with this sign are safety critical components. They must always be replaced with identical
components. Refer to the Fostex Parts List and ensure exact replacement.
3
D1624 / D824
1. SPECIFICATIONS
D824 / D1624
INPUT & OUTPUT
INPUT (1 ~ 8)
Connector RCA pin jack (x 8)
Input Level -10 dBV
Input Impedance 10 kΩ or more
OUTPUT (D824: 1 ~ 8, D1624: 1 ~ 16)
Connector RCA pin jack (x 8: D824, x 16: D1624)
Output Level -10 dBV
Load Impedance 10 kΩ or more
DATA IN / OUT (D824: 1 ~ 8, D1624: 1 ~ 8 & 9 ~ 16)
Connector Square shape optical
Format IEC consumer optical standard (IEC 60958 Part 3)
Alesis Proprietary Multichannel Optical Digital Interface
(ADAT format does not comply to 96 kHz sampling frequency.)
MIDI IN / OUT / THRU
Connector DIN 5-pin
Format Comply to MIDI standard
WORD IN / OUT
Connector BNC
Level TTL level
REMOTE IN / THRU
Connector D-SUB 9-pin
Transfer Format RS-422
Protocol Sony 9-pin (P2) protocol, ES bus
SCSI
Connector D-SUB 50-pin (half pitch)
Protocol SCSI-2, unbalanced transfer method
Transfer Type Asynchronous
Number of Unit Connected 1
PUNCH IN / OUT
Connector Ø6 mm phone jack
Level CMOS (HIGH: 3.5 ~ 5 V, LOW: 0 ~ 1.5 V)
RECORD & PLAYBACK
Recording Medium Internal 3.5” E-IDE hard disk drive (optional)
Backup Medium External fixed / removable SCSI-2 SCSI device (backup only)
Standard SCSI-2 or better
Sampling Frequency 44.1 kHz, 48 kHz, 96 kHz (Switchable by Disk Format)
Quantization 16-bit linear, 24-bit linear (Switchable by Disk Format)
A-to-D Converter 24-bit delta-sigma 128 times over sampling
D-to-A Converter 24-bit delta-sigma 128 times over sampling
Recording Format FDMS-3 Version 2
Emphasis Not available
Recording Time (mono track min.) About 18 min. / 100 MB at maximum (at 44.1 kHz)
Number of Tracks 24 tracks (D824: 8 + 16 additional tracks, D1624: 16 + 8 additional tracks)
Number of Recording Tracks at a Time
D824 8
D1624 16 (when using DATA IN), 8 (Analog only or at 24-bit / 96 kHz)
4
D1624 / D824
Number of playback tracks at a time

D824 8
D1624 16, 8 (at 24-bit / 96 kHz)
No. of Programs 99
Pitch Control ± 6.0 % (0.1 % step)
Crossfade 10 msec (at 44.1 / 48 kHz), 5 msec (at 96 kHz)
Overall Frequency Response 20 ~ 20 kHz ± 1 dB (at 44.1 / 48 kHz)
20 ~ 43 kHz ± 2 dB (at 96 kHz)
Signal to Noise Ratio 100 dB or more (between ADC and DAC, 24-bit)
Dynamic Range 100 dB or more (between ADC and DAC, 24-bit)
T.H.D. 0.01 % or less (at 1 kHz, -10 dBV, 24-bit)
Channel Separation 80 dB or more (at 1 kHz, 0 dB, 24-bit)
Phase difference between channels 20 º or less (at 20 kHz)
OPERATION
Shuttle Speed 8 steps (7 steps for FWD direction)
CUE ON ± 1 ~ 8 times (FWD: ± 1 ~ 7 times)
CUE OFF ± 1 ~ 64 times
FFWD / REW Speed
CUE ON ± 3 times
CUE OFF ± 32 times
Digital Scrubbing (JOG) 0 ~ 1 times (Envelope can be displayed when selecting only one track.)
Locate Memory 6 (7 including [LOCATE] key temporary memory) + 99
Level Indication
Type FL Bargraph
Number of Indicated Levels 11 dots (-∞, -42, -30, -24, -18, -12, -9, -6, -3, 0, OVER)
Reference Level (-10 dBV) Indication - 12 dB
Full Scale Output Level + 2 dBV ± 1 dB
GENERAL
Dimensions 482 (W) x 148 (H) x 381 (D) mm
Weight 7.0 kg
Power Supply
JPN 100 V AC
USA / CND 120 V AC
EUR / UK 230 V AC
Power Consumption
D824 Approx. 30 W
D1624 Approx. 35 W
Standard Environment
Standard Temperature 20 ± 2 ºC
Standard Humidity 65 ± 5 %
ENVIRONMENT CONDITION (W/O HD)
Characteristics Guaranteed
Temperature + 5 ~ + 40 ºC
Humidity 30 ~ 70 %
AC voltage deviation ± 5 % or less
Operation Guaranteed
Temperature 0 ~ + 45 ºC
Humidity 85 % or less
AC voltage deviation ± 10 % or less
5
D1624 / D824
8345
INPUT & OUTPUT
TIME CODE INPUT
Format SMPTE/EBU
Connector XLR-3-31 type (Pin 1: GND, Pin 2: HOT, Pin 3: COLD)
Standard Input Level 2 V p-p
Minimum Input Level 0.25 V p-p
TIME CODE OUTPUT
Format SMPTE/EBU
Connector XLR-3-32 type (Pin 1: GND, Pin 2: HOT, Pin 3: COLD)
Standard Output Level 2 V p-p
Minimum Output Level 0.25 V p-p
Load Impedance 20 kΩ or more
VIDEO INPUT
Format Composite (Applied video signal must comply to PAL or NTSC
standard and be interlace type.)
Connector BNC
Frame Pulse 24, 25, 29.97, 30 Hz (± 1000 ppm)
Field Pulse 48, 50, 59.94, 60 Hz (± 1000 ppm)
Standard Input Level 1 V p-p
Input Impedance 75 Ω (ON / OFF by terminator SW)
VIDEO THRU
Connector BNC
Output Level Direct output of signal fed to Video Input connector
WORD INPUT
Connector BNC
Frequency 44.1 kHz, 48 kHz
Standard Input Level TTL level
Input Impedance 75 Ω (ON / OFF by terminator SW)
WORD OUTPUT
Connector BNC
Standard Output Level TTL level
Load Impedance 75 Ω
GENERAL
Dimensions 215 (W) x 80 (D) mm
Power Supply Supplied from main unit
Digital DC + 5 V
Analog DC + 19 V / - 15 V
6
D1624 / D824
5042 / 5043
INPUT & OUTPUT
INPUT (1 ~ 8)
Standard Input Level + 4 dBu
OUTPUT (1 ~ 8)
Output Level + 4 dBu
Load Impedance 600 Ω or more
OUTPUT (9 ~ 16, Model 5043 only)
Output Level + 4 dBu
Load Impedance 600 Ω or more
GENERAL
DIMENSIONS 270 (W) x 70 (D) mm
POWER SUPPLY DC + 15 V (Supplied from main unit)
8350
Format IEC958 PART 3 (AES/EBU)
Pin assignment Indicated below
Recommended cable AES/EBU digital audio transfer cable from Hosa Technology Inc.
DBK-258 (DB-25 (male) ↔ 4 x XLR (male) & 4 x XLR (female))
[ D-SUB 25-pin Assignment ]

(Seen from rear panel side)
SIGNAL HOT COLD
13 1
Input 1/2 1 14
Input 3/4 2 15
Input 5/6 3 16
25 14
Input 7/8 4 17
Output 1/2 5 18
Output 3/4 6 19
Output 5/6 7 20
Output 7/8 8 21
10, 12, 13, 22,
Frame GND
23, 24, 25
Open 9, 11
7
D1624 / D824
2. CONTROLS, INDICATORS & CONNECTORS

Front Panel Section: Main Unit (D1624 / D824)
1 2 3 4 2
7 6 5
1. Detachable Controller connector 5. Hard disk power LED
2. Controller mounter 6. Access LED
3. Removable hard disk cartridge slot 7. Power switch
4. Lock/Unlock key
Front Panel Section: Controller (D1624 / D824)

11 13
1 2 26 4 5 6 7 8 9 10 12 14 15 16
17
36 18
19
35
3 31 29 27 25 23 21
34 33 32 30 28 24 22 20
1. Controller Connection Cable 19. Jog/Shuttle dial
2. Record Track Select / Envelope key 20. Vari-pitch / Pitch Edit key
3. Track Shift / All Input key 21. Fast Forward key
4. Auto Play/Auto Return key 22. Locate key
5. Clipboard In / Preview key 23. Rewind key
6. Clipboard Out / Preview key 24. Undo/Redo / Multi Undo key
7. Auto Return Start / Preview key 25. Play key
8. Auto Punch In / Preview key 26. Setup / TC Generator Setup key
9. Auto Punch Out / Preview key 27. Stop key
10. Auto Return End / Preview key 28. Edit / TC Ready key
11. Display Select key 29. Record / All Ready key
12. Program select key 30. Auto Punch Mode On/Off key
13. Store key 31. Shift key
14. Exit/No / Eject key 32. TC ready LED
15. Execute/Yes / Chase key 33. Access LED
16. Recall key 34. All Input LED
17. NEXT key 35. Punch In/Out jack
18. Previous key 36. Meter display
8
D1624 / D824
Rear Panel Section (D1624)

1 2 3 4 5 2 6
MIDI
INPUT OUTPUT THRU
REMOTE
INPUT THRU
WORD 100
INPUT OUTPUT
75Ω
ON OFF
ON OFF
CAUTION WARNING:
RISK OF ELECTRIC SHOCK TO REDUCE THE RISK OF FIRE OR ELECTRIC
DO NOT OPEN SHOCK, DO NOT EXPOSE THIS EQUIPMENT
AVIS: RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR TO RAIN OR MOISTURE.
ANALOG INPUT ANALOG OUTPUT DIGITAL/DATA SCSI AC IN

INPUT OUTPUT
4 3 2 1 8 7 6 5 4 3 2 1
16 - 9 8-1 16 - 9 8-1
OPTICAL
8 7 6 5 16 15 14 13 12 11 10 9
15 14 13 12 11 10 9 8 7
Rear Panel Section (D824)

1 2 3 4 5 2 6
MIDI
INPUT OUTPUT THRU
REMOTE
THRU
WORD 100
INPUT OUTPUT
75Ω
ON OFF
ON OFF
CAUTION WARNING:
AC IN
ANALOG INPUT ANALOG OUTPUT DIGITAL/DATA SCSI
4 3 2 1 4 3 2 1 INPUT OUTPUT
OPTICAL
8 7 6 5 8 7 6 5
15 14 13 12 11 10 9 8 7
1. Panel A for an optional card 9. REMOTE INPUT terminating switch

2. Panel B for an optional card 10. REMOTE INPUT connector
3. WORD IN terminating switch 11. SCSI connector [half-pitch 50-pin]
4. WORD INPUT connector [BNC] 12. Digital/Data Output connector [OPTICAL]
5. WORD OUTPUT connector [BNC] 13. Digital/Data Input connector [OPTICAL]
6. MIDI Input/Output/Thru connector 14. Analog Output jack [RCA pin]
7. AC IN connector 15. Analog Input jack [RCA pin]
8. REMOTE THRU connector
9
D1624 / D824
Rear Panel Section (D1624 with Model 5043 and 8345)

451 6 78 2 9 10 11 3
MIDI
ANALOG BALANCE I/O
INPUT OUTPUT THRU
+4dBu INPUT 8-1 +4dBu OUTPUT 16-9 +4dBu OUTPUT 8-1
REMOTE
INPUT THRU
VIDEO WORD TIME CODE 100
INPUT THRU INPUT OUTPUT OUTPUT
75Ω 75Ω
1 GND
ON OFF
2 HOT
ON OFF ON OFF 3 COLD
CAUTION WARNING:
INPUT RISK OF ELECTRIC SHOCK TO REDUCE THE RISK OF FIRE OR ELECTRIC

INPUT OUTPUT
4 3 2 1 8 7 6 5 4 3 2 1
16 - 9 8-1 16 - 9 8-1
OPTICAL
8 7 6 5 16 15 14 13 12 11 10 9
[ MODEL 5043 ] 7. Word input terminating switch

1. Balanced input connector 8. Word input connector
2. Balanced output connector (9 - 16) 9. Word output connector
3. Balanced output connector (1 - 8) 10. Time code input connector
[ MODEL 8345] 11. Time code output connector
4. Video input terminating switch
5. Video input connector
6. Video thru connector
Rear Panel Section (D824 with Model 5042, 8345 and 8350)
451 6 78 2 9 10 11 3
MIDI
ANALOG BALANCE I/O INPUT OUTPUT THRU
+4dBu INPUT +4dBu OUTPUT
8-1 I/O
AES/EBU
REMOTE
THRU
VIDEO WORD TIME CODE 100
INPUT THRU INPUT OUTPUT OUTPUT
75Ω 75Ω
1 GND
ON OFF
2 HOT
ON OFF ON OFF 3 COLD
CAUTION WARNING:
INPUT
AC IN
4 3 2 1 4 3 2 1 INPUT OUTPUT
OPTICAL
8 7 6 5 8 7 6 5
[ MODEL 5042 ] 5. Video input connector

1. Balanced input connector 6. Video thru connector
2. Balanced output connector 7. Word input terminating switch
[ MODEL 8350 ] 8. Word input connector
3. Digital input & output connector 9. Word output connector
[ MODEL 8345 ] 10. Time code input connector
4. Video input terminating switch 11. Time code output connector
10
D1624 / D824
3. SOFTWARE UPDATE
Since the 8Mbit flash ROM is mounted on the MAIN PCB assy, the D1624/D824 software can be updated through the
SCSI port. Please refer to the following explanation for correct software updating procedures.
3-1. Required Tools

The following tools/equipment are required to update the D1624/D824 software.
1. IBM PC/AT compatible computer with SCSI board
2. Removable type SCSI drive
3. Cable between the removable type SCSI drive and the SCSI board
4. Cable between the removable type SCSI drive and the D1624/D824 (D-SUB half-pitch 50-pin)
5. A Utility software to extract the WinZip compressed file
3-2. Software Updating Procedures

Presuming that the updated software is correctly sent to you via email and is copied into your computer.
1. Connect the removable type SCSI drive to the IBM PC/AT compatible computer SCSI port.
2. Insert the diskette to the removable type SCSI drive and format it by the computer on which Windows 95/98 is
running.
3. Using the utility software, extract the WinZip compressed software file. The extracted file name is “d1624mvX.XX”.
(X.XX indicates the version number. For example, if the software version number is V1.06, the file name is
d1624mv1.06.)
3. Copy the updated software file “d1624mvX.XX” to the removable type SCSI drive (diskette).
4. Set the removable type SCSI drive ID to 6 and connect to the D1624/D824 SCSI port (D-SUB half-pitch 50-pin).
5. Turn on the power of removable drive and then D1624/D824.
6. Insert the diskette with updated software file.
7. The D1624/D824 automatically finds the software update file in the SCSI drive/disk and is put into the software
update mode. In this condition, “SystemUp” is displayed and “SURE?” is blinking on the FL display.
OL
0
3
6
9 44.1kHz
12
18
24
30 SURE?
42
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
8. Press the [EXECUTE/YES] key to start updating the software.

9. The D1624/D824 FL display shows “Loading !”, “Writing !”, etc and after a while, “SystemUp” appears on the
FL display again. This indicates that the software is correctly updated. Press the [STOP] key or [EXIT/NO] key to
eject the disk.
10. Turn off the D1624/D824 and the connected SCSI drive.
11. Disconnect the SCSI drive from the D1624/D824 and power on the D1624/D824 again.
12. Confirm the software version number and the programming date while in the boot up procedures. For your
information, they can also be checked by the Service Mode explained later.
[CAUTION]
In case the D1624/D824 does not find the software update file in the external SCSI drive by itself, please follow the
procedures below.
1..6. Same as the before mentioned procedures.
7. Press the [SETUP] key.
8. Rotate the jog wheel, select the “Drive Sel?” menu and press the [EXECUTE/YES] key.
: Blinking
SETUP
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
11
D1624 / D824
9. Select “SCSI-6” and press the [EXECUTE/YES] key.

: Blinking
SETUP
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
10. The D1624/D824 recognizes the software file in the connected SCSI drive/diskette and is automatically put into
the software update mode.
11. Press the [EXECUTE/YES] key to start updating the software.
12. The D1624/D824 FL display shows “Initial...”, name of the drive, “Loading...” and “Writing...” in order and after
a while, “SURE?” will start blinking again. This indicates that the software is correctly updated. Press the [STOP]
key or [EXIT/NO] key to eject the disk.
13. Turn off the D1624/D824 and the connected SCSI drive.
14. Disconnect the SCSI drive from the D1624/D824 and power on the D1624/D824 again.
15. Confirm the software version number and the programming date while in the boot up procedures. They can also
be checked by the Service Mode explained later.
4. SERVICE MODE
There are various optional modes available in the D1624/D824 Service Mode. Please utilize them when servicing the unit.
4-1. Putting D1624/D824 into Service Mode

The way of putting the D1624/D824 into Service Mode is as follow.
1. Plug a 3.5” E-IDE HDD caddy into the D1624/D824 HD bay and lock it using the HD key.
2. Power on the D1624/D824.
3. While holding down the [STOP] key and [TRACK SHIFT/ALL INPUT] key, press the [SETUP] key.
As shown below, by rotating the jog dial C.W. or C.C.W., various optional modes will be displayed in addition to the
general SETUP menus. In order to select a certain optional mode, press the [EXECUTE/YES] key while the menu is
displayed.
: Blinking
SETUP
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Tempo Map Set? Delete PGM? Preroll Time? Frame Rate? Offset Mode? Slave Type?
Signature Set? Title Edit? Click ? Midi Sync Out? MTC offset? Ref. TC?
Disk Format? Rec Protect?
Reserved Digital In?

Disk Optimize? Digital Out?
Reserved Freeblock Check? Resolution?
Date & Time set? Version? Standby Disk? Self Check? Initial Disk? Device ID?
Save PGM? DA Test? Display Test? Offset Disp? Flash ROM? Clock Sel?
Load pGM? Sync Preset?
Drive Sel? NOs Of Event?
Virtual LTC?
Drive Info?
Reserved Offset Disp?
4-2. Flash ROM (software) version

This mode is used to check the Flash ROM (software) versions currently installed in the unit.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
12
D1624 / D824
In order to check the version number, press the [EXECUTE/YES] key while “?” is blinking.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
The example on the above indicates that the Flash ROM version is V1.05 and its programming date is April 3, 2000.
4-3. DA Test
This mode tests the signal flow from the DATA INPUT jack to the D/A converter. A S/P DIF digital signal (Fs:
44.1kHz) must be input to the DATA INPUT jack to execute this test. Then, press the [EXECUTE/YES] key while “?”
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
is blinking. If the D1624/D824 is in a normal condition, “44.1kHz” and “DIGITAL” will be lit solid. The odd (1, 3, 5,
7, 9, 11, 13, 15) and even (2, 4, 6, 8, 10, 12, 14, 16) channels indicate the left and right input level of S/P DIF digital
signal fed to the DATA INPUT jack respectively.
If the D1624/D824 is not in a normal condition, “DIGITAL” and “EXT SYNC” on the display will blink and the
bargraph meter will not indicate any level.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 EXT SYNC
DIGITAL
4-4. Standby Disk

This mode stops spinning the internal hard disk for purposes such as “shock” test. If the [EXECUTE/YES] key is
pressed when “?” is blinking, “SURE?” will start blinking. If you would like to go on, press the [EXECUTE/YES] key
once again. The internal hard disk will stop spinning.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
4-4. Display/Key Test

This mode tests if all the segments on the FL display, LEDs and keys (switches) on the D1624/D824 controller are
correctly working or not. To execute this test, press the [EXECUTE/YES] key while “?” is blinking.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
13
D1624 / D824
If the D1624/D824 is in a normal condition, all the segments on the FL display will be lit solid, dot matrix and bargraph
meter sections on the FL display and all the LEDs on the top panel will start blinking. If the D1624/D824 is not in a
normal condition, faulty segments on the LCD display, dot matrix and/or LEDs on the top panel will remain unlit.
TC MTC IN OFFSET
ABS SETUP CHASE
LOCATE
REMAIN PGM
OL FORMAT
0 SIGNATURE
3
6 TEMPO
9 44.1kHz 48kHz
12 -0.1%
18
24 COMPLETED!
30 SURE?
42
∞ MIDI CHASE
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
SAVE LOAD
EXT SYNC
DIGITAL
In this condition, if the [EXECUTE/YES] key is pressed one more time, the Key Test can be executed. The Key Test
checks if each key and jog dial are working properly or not. The display below indicates that the [PLAY] key is pressed
and held down.
OL
0
3
6
9
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
The table below shows the relationship between the key/button/jog dial and the corresponding numbers appear on the
FL display.
In order to quit the Button Test, turn the jog dial C.W. or C.C.W. further after “51” or “49” is displayed respectively.
Key/Button No. Key/Button No. Key/Button No.

AUTO RTN/PLAY 01 ERASE 14 RECORD TRACK 5 27
CLIPBOARD IN 02 UNDO 15 RECORD TRACK 6 28
CLIPBOARD OUT 03 REDO 16 RECORD TRACK 7 29
AUTO RTN START 04 HOLD/ 17 RECORD TRACK 8 30
AUTO PUNCH IN 05 STORE 18 SHIFT 31
AUTO PUNCH OUT 06 RECALL 19 RECORD 32
AUTO RTN END 07 AUTO PUNCH 20 STOP 33
DISP SEL 08 LOCATE 21 PLAY 34
EXECUTE/YES 09 VARI PITCH 22 REWIND 35
EXIT/NO 10 RECORD TRACK 1 23 F. FWD 36
COPY 11 RECORD TRACK 2 24 SHUTTLE 00~07
MOVE 12 RECORD TRACK 3 25 JOG (C.W.) 51
PASTE 13 RECORD TRACK 4 26 JOG (C.C.W.) 49
4-5. Self Check

This mode automatically tests the following points in order.
1. SCSI port → 2. ATA (E-IDE) bus → 3. Option (Model 8345) bus → 4. MIDI in/out circuit
→ 5. S/P DIF digital signal in/out → 6. ADAT digital signal in/out → 7. 8345 vari-pitch circuit
→ 8. Vari-pitch circuit → 9. External Time Clock Check → 10. Internal Time Clock Check →
11. Remote in/out circuit → 12. Word In/Out circuit → 13. A/D and D/A circuit (Input Monitor)
MIDI
Cable connection in “Self Check” mode : D824
MIDI
INPUT OUTPUT THRU
REMOTE
THRU
WORD 100Ω
INPUT OUTPUT
75Ω
ON OFF
ON OFF
CAUTION WARNING:
AC IN
4 3 2 1 4 3 2 1 INPUT OUTPUT
OPTICAL
8 7 6 5 8 7 6 5
WORD DIGITAL REMOTE

External SCSI Device
14
D1624 / D824
MIDI
Cable connection in “Self Check” mode : D1624
MIDI
INPUT OUTPUT THRU
REMOTE
INPUT THRU
WORD 100Ω
INPUT OUTPUT
75Ω
ON OFF
ON OFF
CAUTION WARNING:

INPUT OUTPUT
4 3 2 1 8 7 6 5 4 3 2 1
16 - 9 8-1 16 - 9 8-1
OPTICAL
8 7 6 5 16 15 14 13 12 11 10 9
WORD REMOTE
DIGITAL
External SCSI Device
CAUTION: In order not to form a MIDI signal loop, connect the MIDI cable after putting the D1624/D824 into the
Service Mode.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
4-5-1. SCSI Port Check

If the D1624/D824 does not recognize a connected SCSI device, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
The following is considered to be the cause of problem.

• Bad cable connection, bad cable contact and / or the power of SCSI device is being turned off.
• SCSI device ID is not set to 6.
• U9, U64, J16, etc and / or surrounding circuit are defective.
• If a removable type SCSI drive is connected and in case a disk is not inserted into the drive, the following prompt
will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Fs, DIGITAL IN, DIGITAL OUT and SLAVE MODE settings on the internal hard disk to be used when the Self Check
test is executed should be as follow.
* Fs: 44.1kHz
* DIGITAL IN: OFF (L: -, R: -)
* DIGITAL OUT: ADAT
* SLAVE MODE: OFF
Even if the before mentioned prompt is displayed, pressing the [EXECUTE/YES] key would reach the next test.
15
D1624 / D824
4-5-2. ATA (E-IDE) Bus Check

This test checks if data can be properly read out from the preformatted internal hard disk.
If the “ALTERNATE STATUS” which indicates the hard disk condition cannot be read out, the prompt below will be
displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
If the data (SYSTEM ID) written by formatting the disk cannot read out correctly, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

• Breaking, shortage and / or bad contact of flat cable W12.
• U1, U9, etc and / or surrounding circuit are defective.
Fs, DIGITAL IN, DIGITAL OUT and SLAVE MODE settings on the internal hard disk to be used when the Self Check
test is executed should be as follow.
* Fs: 44.1kHz
* DIGITAL IN: OFF (L: -, R: -)
* DIGITAL OUT: ADAT
* SLAVE MODE: OFF
Even if the before mentioned prompt is displayed, pressing the [EXECUTE/YES] key would reach the next test. If the
[EXECUTE/YES] key is pressed with the “ATA Bus Check” message displayed, checking the SYSTEM ID on the
SCSI device will be executed. The current drive setting after the Self Check test will become “SCSI”.
4-5-3. Option (Model 8345) Bus Check

This test checks if the option bus (J18 on the MAIN PCB) to which the Model 8345 is connected is working properly
or not. If reading out and / or writing in data are not correctly executed, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

• Bad connection and / or wrongly connected J18.
• J18, U67, U75, etc and / or surrounding circuit are defective.
16
D1624 / D824
4-5-4. MIDI In/Out Check

By connecting the MIDI IN and OUT ports, this test checks if the replyagainst the ID inquiry is correctly received. If
not, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

• J7, U28, U29 (MAIN PCB), J201, J202 (MIDI PCB), J301, J304 (RS422 PCB), etc and / or surrounding circuit are
defective.
4-5-5. S/P DIF In/Out Check

By connecting the DATA IN and OUT terminals, this test checks if the S/P DIF signal output by itself is correctly
received. If the PLL circuit is not in a “LOCKED” condition, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

• No oscillation of resonator X1.
• J11, J12, J20, J21, U4, U5, U17, U19, U24, U62, etc and / or surrounding circuit are defective.
4-5-6. Adat In/Out Check

By connecting the DATA IN and OUT terminals, this test checks if the ADAT digital signal output by itself is correctly
received. If the PLL circuit is not in a “LOCKED” condition, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

• No oscillation of resonator X2.
• J11, J12, J20, J21, U4, U5, U17, U19, U24, U62, etc and / or surrounding circuit are defective.
17
D1624 / D824
4-5-7. 8345 Vari-Pitch Circuit Check

The master clock is generated using the Model 8345 LRCK (J1 pin-24: EXT_LRCK). In the meantime, the adat digital
signal is generated based on this master clock. This test checks if the adat digital signal output by itself is correctly
received. If not, it means that the vari-pitch circuit does not work correctly. As a result, the prompt below will be
displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
If “adat error” is displayed in the before mentioned Adat In/Out Check test, the above error prompt will be displayed.
If the Model 8345 is not installed in the D1624/D824, this test will be skipped.
• Wrongly connected flat cable to J18 on the MAIN PCB.
• J18, U67, U75, etc and / or surrounding circuit are defective.
4-5-8. D1624/D824 Vari-Pitch Circuit Check

Using the master clock generated through the D1624/D824 vari-pitch circuit on the MAIN PCB, the adat digital signal
is output. This test checks if the adat digital signal output by itself is correctly received. If not, it means that the vari-
pitch circuit does not work correctly. As a result, the prompt below will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
If “adat error” is displayed in the before mentioned Adat In/Out Check test, the above error prompt will be displayed.
If the Model 8345 is not installed in the D1624/D824, this test will be skipped.
• U1, U2, U17, etc and / or surrounding circuit are defective.
4-5-9. External Time Clock Check

This mode checks the internal RTC (Real Time Clock) controlling circuit when the power is at OFF condition.
• Defects on the U86.
4-5-10. Internal Time Clock Check

This mode checks the internal RTC (Real Time Clock) controlling circuit when the power is at ON condition.
18
D1624 / D824
4-5-11. Remote
This mode checks the remote circuit.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
4-5-12. Word In/Out

This mode can be checked only when the Model 8345 is not installed. In other words, if this test is executed with the
Model 8345 installed, the following error message will be displayed.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
4-5-13. A/D and D/A Circuit Check (Input Monitoring)

The D1624/D824 automatically checks the before mentioned points in the Self Check mode. If the D1624/D824 is
working properly, the following appears on the display with REC LED blinking.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
In order to go back to the normal display, press the [EXIT/NO] key or STOP button.
4-6. Offset Display

This mode determines if the offset value against a master machine should be displayed when the D1624/D824 is
working as a slave machine. If you would like to turn ON the offset display, press the [EXECUTE/YES] key while “?”
is blinking. (The default setting is “off”.) Then, turn the jog dial C.W. to change the display to “ON” and press the
[EXECUTE/YES] key.
: Blinking
SETUP
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
19
D1624 / D824
In order to check the offset value, select the “MTC” time base and the “REMAINING TIME” display. The display
below is an example of offset display. This mode is identical to the one when the normal SETUP menu “Offset Disp?”
is selected.
OFFSET
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
4-7. Initializing Disk

This is the mode to initializes a 3.5” internal E-IDE hard disk drive or an external SCSI device connected to the SCSI
port.
CAUTION: If both the external SCSI drive and the internal 3.5” E-IDE hard disk drive are connected at the same time,
currently selected drive by the SETUP menu “Drive_Sel?” will be initialized.
After pressing the [EXECUTE/YES] key, “SURE?” will start blinking on the FL display. In this condition, pressing
the [EXECUTE/YES] key one more time would initialize the recognized disk drive. This mode puts the disk back to
the condition originally formatted. This mode is exclusively designed for our manufacturer. To initialize the disk, use
the ERASE function in the Format SETUP menu.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
4-8. Flash ROM

This mode is used when copying the system software from EPROMs to Flash ROM. As mentioned in the section “3.
SOFTWARE UPDATE” (page 11), the D1624/D824 software inside the Flash ROM can be updated through the SCSI
port. However, if something wrong happens when updating the software (e.g. A blackout occurred while updating the
software.), the D1624/D824 might not be able to boot up using the system software inside the Flash ROM.
In this case, the following procedures must be taken.
1. Turn off the power of D1624/D824 and disconnect the AC cable from the AC IN socket.
2. Plug the D1624/D824 EPROMs into the ROM CARD PCB assy sockets (U1 and U2). The SW on the ROM
CARD PCB assy must be set to “EPROM” side.
3. Open up the top cover, loosen 4 screws fixing the HD bay to the HD bracket and move the bay to the front side,
so that the ROM CARD PCB assy can be plugged into the 50-pin connector J5 on the MAIN PCB assy vertically.
4. Connect the AC cable and turn on the power of D1624/D824.
In this condition, the D1624/D824 is booted up using the system software inside the EPROMs. The next procedures to
take are as follows.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
20
D1624 / D824
5. Put the D1624/D824 into the Service Mode, rotate the jog dial, select “FlashROM” menu and press [EXECUTE/
YES] key. (“SURE?” is blinking in this condition.)
6. Change the SW setting on the ROM CARD PCB assy from “EPROM” side to “FLASH” side while “SURE?”
is blinking and then press the [EXECUTE/YES] key to copy the system software from EPROMs to Flash ROM.
The display shows “Erase ROM”, “Write ROM” and then “COMPLETED!” in order.
7. In order to confirm that the D1624/D824 is correctly booted up using the system software inside the Flash ROM,
turn off the power, disconnect the ROM CARD PCB assy and turn the power back on again.
8. After the boot up confirmation, referring to the section “3. SOFTWARE UPDATE” (page 11), update the
system software inside the Flash ROM through SCSI port again.
4-9. Free Block Check

This mode is used to check the condition of the diskette inserted into an external SCSI drive connected to the D1624/
D824 or the internal E-IDE hard disk drive. The drive to be checked is the one currently selected drive by the SETUP
menu “Drive_Sel?”.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Press the [EXECUTE/YES] key when “?” is blinking. The display indicates the free audio file numbers.
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
If the Free Block indicates a large number even after formatting and no signal is recorded or recorded signal on the E-
IDE HDD is frequently skipped, the diskette / hard disk drive can be judged to be in a bad condition.
4-10. MIDI Date Set

This mode is mainly designed for our manufacturer. When this menu is selected, pressing the [EXECUTE/YES] key
would output the current time information in the shape of FEX (Fostex System Exclusive message) from MIDI OUT
port. The internal RTC on the D1624/D824 which receives the information can be set to the current time.
: Blinking
OL
0
3
6
9 44.1kHz
12
18
24
30
42
∞
_ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
21
D1624 / D824
5. ERROR CODE LIST

The chart below indicates the error code number and corresponding description. Since the error code list is basically
designed for our engineers to improve the software, the description is quite technical. If you find the D1624/D824 with
one of the error codes displayed, we encourage you to update the software first. In case updating the software does not
solve the problem, we would like you to inform us about details.
D1624/D824 ERROR CODE LIST

ERROR
DESCRIPTION
CODE
1 D-108 tries to access the address which does not exist.
When saving system region sector, its address is registered in Free_block File during Free block File checking
9
procedure.
Link_pointer which links Audio File indicates smaller address (out of region) than Link_File address region in
10
RAM.
11 Link_pointer indicates larger address (out of region) than Link_File address region in RAM.
12 “Pointer_addre” calculation of Link_Pointer is not correct.
Link_Pointer during recording/reproducing indicates smaller address (out of region) than actual Link_File
14
address region.
Link_Pointer during recording/reproducing indicates larger address (out of region) than actual Link_File address
15
region.
16 “Pointer_addre” calculation of Link_Pointer during recording/reproducing is not correct.
20 src_cash_load: Improper access of link address occurred while PASTE editing.
21 bak_cash_load: Program link during PASTE/MOVE editing is incorrect.
22 bak_cash_load: Incompatibility problem occurred on program link during PASTE/MOVE editing.
30 Error when executing MOVE editing. Improper Link Pointer. Error in “bak_cash_load” function.
35 Backup_Save:Error occurred when saving data to SCSI device.
36 Backup_Load: Error occurred when loading data from SCSI device.
40 dis_cah_load: Improper access occurred when recording/reproducing.
45 get_non_des_block: Remaining disk capacity is insufficient.
52 non_des_cash_save_sub: Improper access occurred when recording/reproducing.
60 remake_free_block: There was improper access to program management region.
62 remake_free_block: Number of manageable events exceeds limit.
64 remake_free_block: There is an overlapping section in program management region.
71 There is no enough region to accommodate history of multiple undo file list.
73 File cannot be correctly read when optimizing disk.
96 There was improper access to program management region.
97 There was improper access to program management region when saving System File.
99 There was improper access when fading in/out.
22
J106 J107 J108 J109 J101 J102
J2 J21 J11 J20

OUT1 OUT2 IN1 IN2
L102
L202
L902
L302
L402
L1102
L1202
L502
L602
L1302
L1402
L702
L802
L1502
L1602
J9 TO INT SCSI
L1002
R47
R52
U112
U212
U912
U1012
U312
U412
U1112
U1212
U512
U612
U1312
U1412
U712
U812
U1512
U1612
L801
L101
L501
L201
L601
L301
L701
L401
C13 C12 2 16
R418
R3040 R118 R218 R918 R1018 R318 R1218 R518 R618 R1318 R1418 R718 R818 R1518 R1618 1 17
R3040 W603 R1118 J103
W503
1 2
C16
TO 5041
W13
D17 J104 2 16
U64 C77 TO 5041
1 17
W703
C84 C114 C214 C914 C1014 C314 C414 C1114 C1214 W803 C714 C814 C1514 C1614
C101
C105
C301
C305
C501
C505
C701
C705
2 13 13
C39
C201
C205
C401
C405
C601
C605
C801
C805
U66 U48 C514 C614 C1314 C1414
C35
1 1
C3106 C3107
C115 C915 C315 C1115 C515 C1315 C715 C1515
C33 C104 C204 C304 C404 C504 C604 C704 C804
U9
C54
U102
U902
U302
U502
U302
U702
U101
U201
U301
U401
U501
U601
U701
U801
U1502
U1102
13 13
C116 C916 C316 C1116 C516 C1316 C716 C1516 From
C1611
C38
W5
W4
C111 C211 C911 C1011 C311 C411 C1111 C1211 C511 C611 C1311 C1411 C711 C811 C1511
W12
U47 U65
TO IDE
X5 C60 C103 C203 C303 MODEL5042 C403
C503 C603 C703 C803
8 8 1 1
From
C36
8
C3104 C3105
R111
R112
R211
R212
R911
R912
R311
R312
R411
R412
R511
R512
R611
R612
R711
R712
R811
R812
R1011
R1012
R1111
R1112
R1211
R1212
R1311
R1312
R1411
R1412
R1511
R1512
R1611
U10 U69 C99 C133 C139 C233 C339 C433 C439
U43 J4
C239(for
C233 D824)
8 MODEL5042
R1612
1 1 1
U80 C141 C143 C541 C543 C241 C243 C641 C643 C341 C343 C741 C743 C441 C443 C841 C843
From or
C134
C140
C234
C240
C334
C340
C434
C440
8 11 1 C3043
J6 (for D824, 8-pin)
25 C142 C144 C542 C544 15 C242 C244 C642 C644 C342 C344
15 15 15 15 15 15 15
U53
MODEL8345 U71 MODEL5043
C3111
or C742 C744 C442 C444 C842 C844
C147
C547
C147
C147
C347
C747
C447
C847
C132
C232
C332
C432
1 1 U131 U231 U331 U431
C138
C238
C338
C438
U141 U541 U241 U641 U341 U741 U441 U841

J1 U6 C131 (for D1624)
J4 C231 C331 C431
R27
8 8 MODEL5043
C3113 C3108
1 1 1 1 1 1 1 1
C53
C137
U13 U56
C3110
1 C146 C546 C246 C646 J5 C346
(for D1624, C746 17-pin) C446 C846
C3117 1 1 C237 C337 C437
6-1. Connector Location on MAIN PCB
R136
R236
R336
R436
R99
W302
W301
W702
W701
W402
W401
W802
W801
8 8 8
C3114
C52
U23 U57 U55 49 1
C18
C3116
50 2
C9
1 1 1
8 C49 C50
R25
J5
R79
8 8
U70 8 8 8
C3101
C3072
X1
C3
R6
R9
C2
9
U83 U27
1 R61 U36 U79 U37
25
25
R80
R76
24
24
1 1 L2
U13
28 28 1 1
C95
1 8 8 8 From
C3090
C3102
C3095
1
8
R85
From U21 9 U44 U60 U45
11
W11
1 8 9
C3070
U7 U8 8 U15 MODEL8350
R24 1 1 1 PCB. MAIN.
FromD1624
1
1 U11
C34
U13
WORD I/OX2 PCB U63 U19 U42 C17
J2 WORD I/O
From C9 R3002
1
1 1 1 1 1 1 R3003
W1
C3091
8
C3092
8
C3094
8 U35 MODEL5042
C3045
C3047
C3002
C3109 R3004 C3001
13
MODEL8350 U72 U62 U46 R3001
R84
R4
R3006
R3005
R60
&L5
L3
1 1 1 W1 (for D824)
J18 TO 8345
U67
J4 TO AES/EBU
C88
J2 R68 U17
L8
R62
MODEL8345
100
90
100
90
81
81
1
or
R3
R69
R11
1 1
80
From From R3007 TP1
C3008
100
R3004
90
100
90
80
81
81
C3003
C3028
104
53
R8
C40 C37 8 9 80 80 R56 R3010 C98 W3
2
2
105 52 1 1 MODEL5043
R58
MODEL8350 MODEL8350
1
1
8
U87 U59 D15
C3058
10 10
C3057
70 70 R3009
C44
U34
1 1
1
W1C3060 (for D1624)

L9
(TRK1 ~ 8) (TRK9 ~ 16) C79

L4
1
U2 U3 70 70
R67
C69 U18
20 60 20 60 J1 U3 J1 U3
U20
W3 2 1
R59
R3011 R3016 TP2 U38
U1 60 60 R54
C3129 C23
R3019 C3059
C90 C78
30 30
/RESET
TDO
TMS
/ASEBRK
TDI
/TRST
TCK
51 51
R55
R71 R72
1
C3034
C3033
X6
31
40
31
40 R3018 C3085
C3082
50
50
51 51
C3035
C57
C3130 C5 C7
5
5
C98 C3055
31
40
31
40
50
50
C3083
1
J8 R94 C3080 U61

7 1 9
C10 C3050 C3079 9
L10
14 8 GND 156 1 X4 L1
C3009 U84 U89
J105
L7
208
157
C3015 C3075 C3084
TO 5041
C3054
C3039 1
4
TP7 TP4 C3024 C3021 1 R3020

J12 OPTION
J22 OPTION
TP8
1
1
X3 C58 TP9
5
R34 TP11
C6
R14 C3038
5
R13 TP10 2 16 2 16
6. MODEL 8345/5042/5043/8350 INSTALLING PROCEDURES
U32 C95
8 8 TP9 R100 8 1 17 1 17 U41
C46
8 8 9
1
W1 TO POWER
C80
C83
1
1
U52 U22 J13 J14 C5

TP5 C61 U12 U26 U82 U49 TO AES/EBU TO AES/EBU
R96 C48
C70 1 1
J3
R22 1 1 1 C86
1
4
C82
C51
TP6
TO HDD2
J10
R18
W2 HDD1
R92
4
D3 D4 D5
12
U28 8 8 8 8 8
SELF C45
C14
C3122
CHECK D11 U58 U51 U25 U54 U31
1 9 1 1 1 7 1 1 1
J7 C91 TP12
R21 R19 R15 R20 J6 C11
B1
C100
D1624 / D824
23
D1624 / D824
6-2. Removing Top Cover & Blank Panels

1) Open up the top panel by loosening the following screws.
• 4 x BBT 3 x 8 screws on both sides of top panel
• 2 x BBT 3 x 8 screws on the top of top panel
• 2 x B 3 x 6 screws on the rear side of top panel
2) Remove the 2 x small blank panels by loosening 4 x BBT 3 x 6 screws.
3) Remove the large blank panel by loosening 2 x BBT 3 x 6 screws.
4) Remove the WORD I/O bracket by loosening 2 x BBT 3 x 8 screws and the 4-pin cable connected to the J2 on the
MAIN PCB assy.
BBT 3 x 8 BZn
BBT 3 x 8 BZn
B 3 x 6 BZn
TO
P
P
A
N
E
L
BBT 3 x 8 BZn
BBT 3 x 6 BZn
BBT 3 x 6 BZn
BPT 3 x 8 BZn
BLANK PANEL, L
BLANK PANEL, S
M CB
A
P
IN
W P bra
O CB ck
R
w
D et
ith
I/O
24
D1624 / D824
6-3. Installing MODEL 8345

CAUTION: When retrofitting both the MODEL 8345 and MODEL 5042/5043 to the D1624/D824, make sure that the
MODEL 8345 will be the one to retrofit first. However, flat cables for MODEL 5042 / 5043 (MODEL
5043: 2 x 17-pin flat cables, MODEL 5042: 1 x 17-pin and 1 x 8-pin flat cables) must be plugged into the
connector J103 and J104 on the MAIN PCB assy before the MODEL 8345 is fixed at the rear panel.
1) Fix the MODEL 8345 to the D1624/D824 rear panel by the following screws.
• 3 x B 3 x 6 BZn screws included in the MODEL 8345 package - Bracket section
• 4 x BBT 3 x 8 BZn screws included in the MODEL 8345 package - XLR connector section
2) Connect the following cables.
• 25-pin flat cable from the connector J18 on the D1624/D824 MAIN PCB assy to the connector J1 on the
MODEL 8345 PCB assy
• 5-pin connector cable W3 on the MODEL 8345 PCB assy to the connector J12 or J22 on the D1624/D824
MAIN PCB assy
To MAIN PCB J12 or J22

W
3
J1
M
O PC
D B
E
L
83
To MAIN PCB J18

45
BBT 3 x 8 BZn
B 3 x 6 BZn
M CB
A
P
IN
25
D1624 / D824

1) Before fixing the MODEL 5042 to the D824 rear panel, plug in the 8-pin and 17-pin flat cables to the D824 MAIN
PCB assy connector J104 and J103 respectively.
2) Remove 4 x hex screws originally attached to the MODEL 5042 D-SUB connectors.
3) Fix the bracket, B, 5041 (P/N: 8221206000) included in the MODEL 5042 package to the MODEL 5042 PCB assy
using 2 x BBT 3 x 6 CZn screws.
4) Fix the MODEL 5042 to the D824 rear panel by the following screws.
• 1 x B 3 x 6 BZn screws included in the MODEL 5042 package - Bracket section
• 4 x hex screws originally attached to the D-SUB connector - D-SUB connector section
• 17-pin flat cable from the connector J103 on the D824 MAIN PCB assy to the connector J4 on the MODEL
5042 PCB assy
5042 PCB assy
• 4-pin connector cable W1 on the MODEL 5042 PCB assy to the connector J105 on the D824 MAIN PCB assy
5) Fix the Panel, Blank, S (P/N: 8221209100) to the rear panel to hide the D-SUB connector hole using 2 x BBT 3 x 8
BZn screws.
To MAIN PCB J105

Bracket, B, 5041
(included in the MODEL 5042,
P/N: 8221206000)
M 04 B
O 2
D
5 C
EL
P
W
1
J6
BBT 3 x 6 CZn
To MAIN PCB J104

J4
To MAIN PCB J103

Panel, blanks, S
P/N: 8221209100)
BBT 3 x 8 BZn
BBT 3 x 8 BZn
Hex screw
(attached to the D-SUB 25-pin connector)
M CB
A
P
IN
26
D1624 / D824

1) Before fixing the MODEL 5043 to the D1624 rear panel, plug in the 2 x 17-pin flat cables to the D1624 MAIN PCB
assy connector J104 and J103 respectively.
5043 PCB assy
5043 PCB assy
• 4-pin connector cable W1 on the MODEL 5043 PCB assy to the connector J105 on the D824 MAIN PCB assy
M 04 B To MAIN PCB J105

O 3
D
5 C
EL
P
W
1
J5
To MAIN PCB J104
J4
To MAIN PCB J103
Hex screw
(attached to the D-SUB 25-pin connector)
M CB
A
P
IN
27
D1624 / D824
6-6. Installing 1 x MODEL 8350

1) Before fixing the MODEL 8350 to the D1624/D824 rear panel, loosen 4 x screws fixing the HD bay to the HD
bracket and move the HD bay to the front side, so that the flat cables can be plugged into the connector J13 on the
D1624/D824 PCB assy.
MODEL 8350 PCB assy
MODEL 8350 PCB assy
• 5-pin connector cable W1 on the MODEL 8350 PCB assy to the connector J12 or J22 on the D1624/D824
MAIN PCB assy
6) Fix the Panel, Blank, 8350 (P/N: 8221327000) to the rear panel to hide the D-SUB connector hole using 3 x BBT 3
x 8 BZn screws.
S1 & S2 SETTING
D-SUB 25-pin connector
To MAIN PCB J12 or J22 S2

To MAIN PCB J13
S1 8350 PCB
To MAIN PCB J4
J2 J3
W1
J2 J1
J3
M 83 CB
O 50
D
EL
P
J1
Panel, blanks, 8350

P/N: 8221327000)
Hex screw
(attached to the D-SUB 25-pin connector) BBT 3 x 8 BZn
M CB
A
P
IN
28
D1624 / D824
6-7. Installing 2 x MODEL 8350s

CAUTION: The MODEL 5043 and MODEL 8350 cannot be installed into the D1624 together. You need to select
either the MODEL 5043 or 2 x MODEL 8350.
1) Before fixing the MODEL 8350s to the D1624 rear panel, loosen 4 x screws fixing the HD bay to the HD bracket
and move the HD bay to the front side, so that the flat cables can be plugged into the connector J13 on the D1624
PCB assy.
2) Remove 2 of each hex screws originally attached to the MODEL 8350 D-SUB connectors.
3) Fix the MODEL 8350s to the D1624 rear panel by the following screws.
• 2 of each hex screws originally attached to the D-SUB connector - D-SUB connector section
8350 PCB assy No.1 (TRK1 ~ 8)
8350 PCB assy No.2 (TRK9 ~ 16)
8350 PCB assy No.1
• 25-pin flat cable from the connector J3 on the MODEL 8350 PCB assy No.1 to the connector J2 on the
MODEL 8350 PCB assy No.2
• 5-pin connector cable W1 on the MODEL 8350 PCB assy No.1 to the connector J12 or J22 on the D1624
MAIN PCB assy
• 5-pin connector cable W1 on the MODEL 8350 PCB assy No.2 to the connector J4 on the MODEL 8350 PCB
assy No.1
6) Fix the Panel, Blank, S (P/N: 8221209100) to the rear panel to hide the D-SUB connector hole using 2 x BBT 3 x 8
BZn screws.
S1 & S2 SETTING (TRK1 ~ 8) S1 & S2 SETTING (TRK9 ~ 16)
D-SUB 25-pin connector D-SUB 25-pin connector
To 8350 PCB No.1 J4 S2 S2

To MAIN PCB J14
S1 8350 PCB S1 8350 PCB
To 8350 PCB No.1 J3
J2 J3 J2 J3
To MAIN PCB J13 W1 W1
J2 J1 J1
J3
M 83 B
O 50
D
EL
PC
J1
To 8350 PCB No.2 J2

MODEL 8350 No.2 (TRK9 ~ 16)
To MAIN PCB J12 or J22
To MAIN PCB J4
J2 Hex screw
Panel, blank, S
J3
M 83 B
(attached to the
O 50
D

EL
PC
D-SUB 25-pin connector)

J1
P/N: 8221327000)
MODEL 8350 No.1 (TRK1 ~ 8)
BBT 3 x 8 BZn
M CB
A
P
IN
29
D1624 / D824
5. EXPLODED VIEW, PCB ASSEMBLY & PARTS LIST

D1624 / D824 OVERALL EXPLODED VIEW & PARTS LIST
Ref. No. Part No. Description Ref. No. Part No. Description
1 8212 5811 04 Panel, controller, D1624/D824 45 8226 0191 00 Escutcheon, B
2 8226 1852 07 Button, 11 x 5, N3 46 8226 0130 04 Button, push, B, N8
3 8226 1842 09 Button, 6 x 6, N3 47 8221 1730 00 Angle, back, 133
4 N/A 48 8221 2140 00 Panel, top, D-series
5 N/A 49 8260 5650 00 Controller assy, D1624
6 8226 1831 05 Button, 11 x 11, E 8260 5720 00 Controller assy, D824
7 8226 1831 08 Button, 11 x 11, N3 50 8207 0116 00 Key, HD, D-series
8 8214 2700 00 Spring, 8 x 3, 0.2 51 8239 1200 00 Battery, 3V, CR2032 (Included in
9 8212 5830 03 Window, FL, D1624 the Main PCB assy)
8212 5830 04 Window, FL, D824 ! 52 8274 2240 00 PCB assy, Power SW, D1624/D824
10 N/A Both-sided tape, 10mm x 40mm ! 53 8276 8010 00 Cord, power, UL/CSA,
11 8221 1740 01 Panel, rear, remote, D1624/D824 VM0033-0089, USA/CSA/CND
12 8212 5820 00 Lock, controller, D-series 8276 8021 00 Cord, power, CEE, 0309B-0310B,
13 8277 3530 10 Cable assy, earth lug, D3-D3, #20, EUR
L100 8276 8000 00 Cord, power, DM, VM1292-1298,
14 8216 6281 00 Pad, controller, D-series JPN
15 8277 4092 01 Cable assy, remote, D1624/D824 8276 9170 00 Cord, power, BS, 3C,
16 8274 2260 00 PCB assy, Display, D1624/D824 KP610-KS31A, UK
17 8216 6290 00 Sheet, remote controller, D-series 54 8218 7760 02 Label, caution, HD, N3
18 8216 6310 00 Sheet, remote controller, B, 55 8218 2630 00 Sticker, GND
D-series 56 8277 4790 40 Cable assy, earthlug, D4, L400
19 8226 1702 01 Knob, shuttle, N3, D1624/D824
20 8226 1711 03 Knob, jog, N3, D1624/D824
21 8221 2980 00 Panel, rear, D1624
8221 3180 00 Panel, rear, D824
22 8221 2101 00 Panel, blank, L
23 8221 2091 00 Panel, blank, S
24 8221 3200 00 Bracket, word, D1624/D824
25 8274 2580 00 PCB assy, Word I/O, D1624/D824
26 8221 3020 00 Chassis, D1624/D824
27 8274 2200 00 PCB assy, Main, D1624
8274 2590 00 PCB assy, Main, D824
28 8207 0117 01 Holder, cord, CS-1
29 8207 0130 00 Foot, FF1011
! 30 8274 2230 00 PCB assy, Power, D1624/D824
31 8221 3320 00 Shield, power, D1624/D824
32 8274 2250 00 PCB assy, Regulator, D1624/D824
33 8274 2210 00 PCB assy, Connect, D1624/D824
34 8221 1710 00 Bracket, D-SUB, D-series
35 N/A (Included in the D-SUB connector)
36 8274 2570 00 PCB assy, RS422, D1624/D824
37 8274 2220 00 PCB assy, MIDI, D1624/D824
38 8260 5240 00 Bay assy, HDD
39 8221 2130 00 Bracket, HD, D1624/D824
40 8221 3210 00 Bracket, fan, D1624/D824
41 8249 0440 00 Motor, fan, DC12V, 40 x 40
42 8216 6561 00 Belt, HD, D-series
43 8221 1671 05 Panel, dress, D1624
8221 1671 06 Panel, dress, D824
44 8223 2942 00 Hook, controller, D-series
30
D1624 / D824
P 3x4 CZn
BBT 3x8 BZn
42
BBT 3x25 BZn

B 3x6 BZn
BBT 3x8 BZn

50 P 3x4 CZn
41
48
BBT 3x8 BZn
40 38
53
B 3x6 CZn
33
31 BBT 3x8 BZn 39
56
B 3x6 CZn
34
35
52
B 3x6 CZn
30
B 4x8 BZn
29
32
47
BBT 3x6 BZn
22
BBT 3x8 BZn 23
46 35
B 3x6 CZn 21
55 37 P 2.6 x 5 BBT 3x6
29 BZn BZn
BBT 3 x 6 B 3x6 CZn BPT3x8
BZn BZn
B 3x6 CZn B 4x8 51 23
BZn
45 BBT 3x8 BZn 36
BPT 3x8
26 BZn
44 24
47 BBT 3x8
25 BZn
B3x6
CZn
43
28
54 BBT 3x8 BZn
27
BTT 3x6 BZn
14
W3 BZn
AZ-3
49
15 N3 Ni CZn
13 BBT 3x6 BZn
10
BPT 3x8 BZn
9 18 BPT 3x8 BZn
11
1 12
17
8
3
16
2 8
6
7
8
4 2
19
20
31
32
/RESET
J16
TO
SCSI
J9
EXT
TDO TO IDE W12

C3116 C3117
TMS
J8
TP5
7
J18 24
TP6
TO 8345
14
/ASEBRK 2
SELF
R3040
TDI
CHECK
/TRST 1
TCK 25 C52
X6
1
U23
C3111
C3130
C3129
2 24 C3110
8
2
1
1
1
1
1 W5
25 C3114
U53
W13
W4
1
J4 TO AES/EBU
8 13 11 C84
W3
U9
9
B1
8
8
C69
U13
C40
2
U57
8
U86
U10
8
1
C3113 C3108
C23
1
1
1
U64
1 1
1
DGND
C37
R59 1 U34
C3109
1
8
8
U67 U50
U69
U55
U75
8
1
U56
C14
11
1
U71
C10
50
49
J7
U87
C3045
X5
C70
8
U28
8
U80
C89 C16
1 5 C3104 C3105 C35 C39
1
1
1
1
D11
U32
C77
C88
U47
C61
U59
C90 C3043
U66
25
C3122 R96 C48

X3
• Parts Side of MAIN PCB
9 1
1
C3034
R94
C44 R8
105
C3033
13
13
U7
D17
TP7
104 C36 C38 C3106 C3107

8
8
R21 R19
J5
OUT1 J12
157
1
U58
U6
R22
U52
1
1
28
U51
R14
U48
TO
U65
C3047
R99
R15
1
8
OUT2 J21
1
13
13
8
INT SCSI
R20
1
U22
C58
1
D3
R27 C13
U1
8
R92 C46
U43
D1624 / D824 PCB ASSEMBLIES
J6
U8
D4
R13
R47
D5
04
C3038 C146
53
R18
J11
IN1
C141 R111
208
C147
7
1
C100 C51 U102

C142
52
1
1
U12
C3035 C114 C12

2
1
C115
C116
C57
28
TP4
R112
TP10
C111
1 U25
C143
U141
R211
8
8
C144
R52
1
C214
1
X4
15
C211
TP9
J20
1
1
IN2
R212
U33
R34
U70
C546
U54
C541 R911
C3039
C547 U902
C542
C91
C914
8
TP11
C916
8
8
C915
U26
R912
C911
C543
1
R1011
1
U541
C3008
C544
30 20 10 1
C1014
X1
U82
C11
15
X2
R1012
C1011
C246
8
C241
100
C3015
C59 R311
9
C247 U302
C242
U31
1
1
R100
TP12
J106
C314
C316
C315
TP8
R84
40
R60 R312 U112

C311
C243
C45
R411
U241
C244
R4
R118
U2
U21
R3006 C414
8 R61
U49
R24
50
R3005
15
C80 R412 L102

C411
C34 C646 C641 R1111

1
C647 U1102
C642
R218
1
1
U212
60 70 80
C3009
R68
U83
C1114
L202
C1116
C1115
1
R1112
8
30 20 10 C3028
U11
C643
C1111
R1211
U641
R6
C644
U912
R918
C1214
R85
L902
TO 5041
15
100
J104
R1212
U27
C1211
C3024
C346
U3
C514
9
8
C341 R511
C347
C342
1
U502
1
R25
U1012
R1018
2
40
L1002
90
C516
C515
1 4 R9 W302
R512
C511
J2 WORD I/O W301 C343 R611

1
1
C3021
U312
C344
W803
U341
50
L302
R318 W603
C614
15
C611
R612
U63
U36
C746 C1314
W503
C741
8
8
R1311
W703
60 70
U412
C747
R418
R69
C742
C3054 U1302
1
C3101
1
L402
1
J107
W702
C1316
C1315
U4
C3055
30 20 10
16
1
W701
2
U79
R1312
17
U19
R1118
C743
1
C1311
R1411
U1112
C744
L1102
U741
C1414
100
C3070 C3072
1
1
15
R1412
C1411
C446
R1218
J13
C441
U1212
R62 C447 R711
U42
U702
C442
L1202
9 40
U84
1
90
8
8
C714
TO AES/EBU
C715
C716
C3050 W402
U37
R518
W401 R712
U512
C3091
C711
C3090 C443 R811
50
1
C444
L502
17
U441
C814
16
R3
15
C811
U72
U44
60 80 R812
U612
R618
C846
2
R67
8
8
C841
R71
C847 R1511
1
C842
C3079 R11 C3092 C3102 U1502 L602

1
1
1
J108
C1514
U5
30 20 10
C3080
1
C1515
W802
C1516
U62
U60
W801 R1512
R1318
C843
U1312
R1611 L1302
C1511
8
C844
100
9
9
U841
C3095 C1614
C3094
U85
1
1
J14
15
U1412
R1418
R1612
40
L1402
U45
90
C1611
TO AES/EBU
U46
C60 C54
8
8
R718
U712
16
C33
50
17
C137 C99 L702
U101
U35
U15
C18 C101
U812
C138 C134 +
R818
60 70 80
R72
C95
C105 L802
C3075
C103
J109
C104
R55 C2 +
R58 C133
R3011
R3018
R3009
C3004
R3004
R3003
R1518
U61
U18
U17
C8
U1512
U131 C201
U201 L1502
R56
L2
U41 +
C139 C205
R3020
U1612
C203
C204
C132 +
C86
R3002
R133 C140
R54 R3016 R3019

R3007 R3010
R1618
TP2
TP3
C3
TP1
C3060 R3001 C131
1 5 C3085 C237 C234 U301 C301 L1602
C3084 C3083 C3059 C3058 C3003 C3002 C238 + J101
L7 L4 L3
C305
C303
C304
C83 C233 +
L9 C3001
C3082 L8
C6 L10 L101
C3057
U231
TO 5041
C19
U401
C82
+ L501
C239 C401
1
C4
C5
C403
C404
PCB,MAIN,D1624
C405
L1
2
C232
C240
+
R233
C231
12 1 C334 U501
C337 C501
U38
C338 + L201
J103
C503
C504
C333 + C505
W1 TO POWER
C79
W11
R76 U331
C78
W2 L601
U601 +
C98
4 TO 5041 1 C601
16
4 TO HDD1 1 C339
17
C603
R80 R79
C604
J105 C605 L301
C332
1 C340 +
D15 R333
C331
TO HDD2 J3 C437 C434 U701
U20
C49
C438 + C701 L701
J1
C703
C704
C433 + C705
4 1 1 OPTION1 5
U431 L401
4 1
C50
C439 C801
C17
+
J10
C803
C804
1
5 C432
L5
J22 R433 C440 C805 +
OPTION2 U801 J102
C9 C53
8251988 101 C431 L801
C7
D1624 / D824
33
W12 R37 C3117
C3117 C3116
C3116 J18
TP6
24
TP5
7
14
2
D1
1 /RESET R3050
D2
2
1
14
R49 R31 TDO R3049

TMS R3048
R50 R36 R95 2 R3047 C47
/ASEBRK R81
DGND
C28 R3051 R38

W13
C84 C3118
C3118 25 1 TDI R3046 R97
J4 R73
/TRST
J8
J16
2
D9
D10
C66 R86 R3045

B1
C65
W3
R3044
R87 C3120 TCK
8
1
C25
C3112
C3112
J9
C63
1
C3098 C3100 R17

C64 C24
C10
R10 C87
X5
R30 R32
C3099 R29 R33
R5
50
J7
R23
R40
U29
49
C77 C3123
R3025
C88
C89
C3043
U30
C61
C3046 C90
X3
• Foil Side of MAIN PCB
C3032
40
39
C3044
C21 C3031
D17
C3126
C22 TP7
J12
C3065
C43
30
R7 C27
R70 C3121
R63
J5
C3115
C3115 C3125 R16
C30
19
20
1
J21
C3074
D6
C3048
C13 C3040
D7
C3041
J6
C3042
9
10
R48 C3124 R93

R141 C41
R46
D8
C42 C15
J11
J1
7
C96
1
2
R115
R115 R114
R114 C146
R116
R116 C3036
C114
C114 C112
C112 C141
C3037
C12 C113
C113 R113
R113
R117
R117 C3119
C3119
C212
R53 C213 R213 TP4 TP10
C68
R51 C214 R216 C143
R541 R64
R215 R214 C67
J20
R217
C97
R915 C546 TP9 C26
C29
C914 R916 R914 C541
C912
C913 R913 TP11
R917
C1012
C1013 R1013
C1014 C3014 C92
R1016 R1014 C543 C56
R1015 R241 C3013
R1017
C3016
C3015
TP12
R315 C246 C3018

C314 R316 R314 C241 R77 R78 C3010
C312
C313 R313 C3017 C3019
TP8
R317
C412
C413 R413 C3007
C414 R414 C243
R416
R415 R641 C3020
R417 C3103 R12
9
C3011
C301 C3012
J106
R1116
R1 16 R1115
R1 15 C646
C3009
R1114
R1 14 R89
C1114
C1 14 C1112
C1 12 C641 R88
C1113
C1 13 R1 13
R1113
R1117
R1 17
C1212
C1213 R1213 C32
C1214 R1214 C643
U24
R1216 R1215 R341

1
R1217 C3029
C3025
C3024
C31
1
C514 R515 C346
2
R516 R514 C341 C3022
C512 C3023
C513 R513 4 1
R517
C612
R39
D12
C614 C613 R613 C3073 C3026 C3030 C3027

C3021
J104
C3067 R3012
R614 C343
R616 R615 R741 C3066
R617
R3013
R1316
J107
C1314 R1315 C746
C3068
R1314 C741
C1312
1
C1313 R1313
16
R1317
2
C1412 C3056 C3054
17
C1413 R1413 C3071 C3064
C1414 C3069
R1416 R1414 C743 C3127
R1415 R441
D13
R1417
J13
R715 C446
U14
U16
C714 R716 R714 C441 C3053

C712
C713 R713 R3015 C3051
R3021
R717 C812 R3014
C3052 C3050
C813 R813
17
16
C814 R814 C443 C3097 R3041

R817 R816 R815 R841 R3022 C3079
1
J108
R1516 R1515 C846 C3128
2
C1514 R1514 C841

C1513 C1512 R1513
R1517 C1612
C3089
C1613 R1613 C3093 C3096 C3081
C1614 C843
J14
R1614
R1616 R1615
R1617
C54 C60
R3042
R3023 C3077
C33 C3078
16
R107 R75 R74 C3076

17
R132 R57
C3075
C62 C106 R104 R105 R3024

C133 C18
C137 R28
R108 R101 R26
J109
R103 R43
C135 C2 R44 C95
C102
R109 R106 R42 R45
R207 C107 R102
R3008 R3017
C206 R205 C3005
C3088
C3063
C202
R204
R208 R201 R203 R206 C136 C3062 C3087
C3006
R209 C3061 C3086
C139
TP3
R307 C207 R202 R232

TP2
TP1
R305 R131 C131
C306
R301 R304 C237 L7
R303 C233
R308 C235 L4
C3001 L3 C3057 C3082
R306
C302
R309 C83
R407 C307 R302
C19
C406 R405
C402
R404
1
C236
R408 R401 R403 R406
J101
C82
C239 R332
R409 C407 R402
R507
J103
R505 R231 C231 1 W1 12
C506
R501 R504 C337
C333
C79
R503
R508 C335
D14
U73
C502
R506 4
R509 C507 R502
R607 W2
D25
C606 R605
C98
C78
1
U39
C1
16
R604 J105
C602
17
R603 R606 C336
R608 R601 1 4
U74
R609 R432
C339
U40
C607 R602 U20
R331 C331
D15
R707 C706 R705 C49
J1 J3
R701 R704 C437 R83
R703 C433 R2 5 1
C435 R1
J102
R708 R702
R706
1 4
C702
C17
R709 C707 R82
R807 R805 L5 J22 1 4
C806 C50
C802
R804
R803 C436 5 1 J10
R801 R806
R808
R809 C439
C807 R802
R431 C431
D1624 / D824
34
U3
U4
U3
L5
U5
U6
U7
U7
U5
U6
L5
R65
R53
R65
C22
1
R49
R52
U4 R50
R51
C20
D95
D95
2
C20
C21
C22
C21
C15
R51
R49
3
R50
R52
DGND
R53
4
U13
J2
140
1
C15 1
140
DGND
J2
U13
D81
D81
64 49
D94 D94
L4
6
L4
6
1
48
R44
R47 R48 R44
R48 R47
D88 D89 C23 D89 D88
D90 D91 C23
D91 D90
1/9
S1
SPACER
R45 R45
S1
D82 D83
33
16
D83 D82
R12
R41 17 32 R10
R12 1/9
R10 R41
D92 D93 D1 D93 D92
2/10
S2
D1
U14
R9
R46 R9
LC75710
R8 R46
D84D85
S2
R8
R13
R13
D85 D84
2/10
R7 R7
R42 R6 D2 R42
D86 D87 D2 R6
R5 D87 D86
3/11
S3
R5
R14
D63
R14
R4 D63
R4 R43
S3
R43
R3 D3
3/11
D3 R3
R2
LOCKED
R2
15
J1
114
114
R1 R1
15
4/12
S4
R68 R68
R15
S4
R15
D4
31
4/12
31
U17
D4
33
33
U17
R67
D62
J1
D62
U16
U16
R67
5/13
S5
U15
HD ACCESS
U15
S5
5/13
R16 R66
1
R16
R66
• Parts & Foil Side of KEY & DISPLAY PCB
1
100 98
98
R17
R17
R18
6/14
S6
R18
C1 C2
R19
C2 C1
D61 D5
D61 R19
S6
6/14
D5
MTC IN
R20 D6 R20
50 48
7/15
D6
S7
L3
L2
W1
W1
C14
DGND
S7
7/15
C14
L2
L3
D7 D7
55
U1
C4
H8/3B
SPACER
C4
64 41
S8
D9
D9
C6
D8
8/16
S8
8/16
40
C6
65
D8
L1
DGND
62
62
78
78
D64
D64
L1
W11
W10
W10
25
80
S9
73
W11
S9
1 24 C3
C3
SHIFT
SHIFT
71
70
70
C5 C5
NJM2103
U2
5
U8 U8
R40 R57
R56 R56
C7
C8
C7
C9
C9
R57
C10
C10
X1
R38
R38
U9
X1
R39 C11
C1 U9
D73
Q4
C8
R40
R39
Q1
Q4
Q1
R54
R55
Q2
R55
R54
Q3
D65
R36 C11 D65
D76
R36
A.RTN
R37
Q2
R37
Q3
D76 D73
A.PLAY
A.RTN
A.PLAY
D20
D10 D10
S15
S10
REC
S20
S20
S19
S19
S15
COPY
S10
REC
A.PUNCH
C13 COPY
AUTO PUNCH
D71 D69 D69 D71 D15 C13

D68 D19
D20
D19 C12
D15
C12 R21 R21 D68
R35
R35
R22
REH
REH
R22
TAKE
IN
TAKE
IN
S21
S21
R23 R23
C19
C19
S11
R34
S11
STOP
R24
S43
R34
R24
MOVE
STOP
D21 D21
S43
CLIPBOARD
D43
CLIPBOARD
MOVE
D11 D67 D67 D43

D11
D1
S22
OUT
S22
OUT
DGND
D22 D22
D12
S12
S12
S44
D12
PLAY
PLAY
PASTE
S44
DGND S45
D44
S45
D44
START
START
R33
R25
PASTE
D66 R25 D66

R33
R26 R26
R29
D45
R32
D45 R27 R27

S33
LOC
R28 R28
D33
R29
R30
R31
R32
R31
R30
S13 D33
S13
REW
S32
S33
IN
D13
REW
S46
IN
D32 D13
ERASE
S46
LOCATE
D32
DIP
DIP
S32
D74 D70 D70

ERASE
D46 D74 D46
AUTO PUNCH
AUTO PUNCH
S47
OUT
OUT
S36
S47
V.PITCH
D47 D47
S34
UNDO
FF
FF
D36 D14
S14
S14
S36
V.PITCH
S34
D34 D34
UNDO
D14 D36
D51
D50
D49
D52
S31
END
S31
S35
END
REDO
D31 D31
D49
D51
D52
S35
REDO
1 100
D50
D35 D35
DGND
8251511 100
DISPLA
DGND
D-160 DISPLAY
8251511
825151
C18
C18 D37
S37
D37
S39
D-160 DISPLAY
HOLD
S37
R61
R61
DISP SEL
R62 R62
DISP SEL
C16
C16 C17
S39
D39 C17
HOLD
D39
U12 1
1
D75 R59 R58 R58 R59
D75
R63
R63
R60
R60
D38
S38
U12
D38
S40
S38
STORE
EXECU/YES
EXECU/YES
S40
D40
D40
STORE
8
D72 D72
D41
S41
D41 D42
DGND
S41
S42
EXIT/NO
RECALL
EXIT/NO
D42
S42
RECALL
4 3 2 1 1 2 3 4
D1624 / D824
D1624 / D824
• Parts & Foil Side of CONNECT PCB
L1010 L1009 L1008
L1011 L1007
J1001
L1006
J1001
L1013
L1012
L1003
L1002
L1001
8251988 005
L1004
PCB,CONNECT,D1624
1 7 7 1
1 W1001 7 W1002 7 1
W1002 W1001
POWER MAIN
• Parts & Foil Side of MIDI PCB
1
THRU
J201
OUT
6
J202 IN OUT
8251988 002 PCB,MIDI,D1624
R201
R205
R206
R203
L101
L105
L106
L103
L104
J201
R202
L102
6
J202
• Parts & Foil Side of RS422 PCB
S301 ON
L304
L303
L302
L301
THRU J303
C302
J302 U301 REMOTE

9
1 9
W301 TO MAIN
C306
C305
C304
C303
8251988 003 1
C301
R307
PCB,RS422,D1624 R302 R301 1 6

J304 TO MIDI
J304
R303
R304
1 6
C301
W301
1 9
R305
R306
1 5 1 5
S301
6 J302 9 6 J303 9
35
D1624 / D824
• Parts & Foil Side of POWER/REGULATOR/POWER SW PCBs

AC5.4A TO DISPLAY
C20
DGND
DGND
C23
DGND
DGND
Vdisp
F1 800mA 250V AC5.4B
D+5
U10
PCB,POWER,D-108
D+5
C5 L7
D9 J4
8251974 101 R13 1 TO FAN
+
7
TO SWITCH U9 1 2
R3 J1
U4
C4 C30
6
R4
R16
W1
J2
12
3 2 D8
U8
U7
C21
R2 C22 DGND
C24
U2 R5 R14
L1 1 D+5
1
D4 D7 R15
C28
C6 DGND
D+12
4 1 R8
C31 C8 N.C.
J3 T1 8251974 103
D+5
T2 PCB,REGULATOR,D-108
DGND
Q1
A-15
C7
C1 C2 AGND
C15
L3 AGND
ER2810
D6 R12 D10 N.C.
R11
D S C
C32 C27 A+15
3 2 D3 C10
1
L
D1
R10 C29
L2 C17 C12
C9 C16
1
U1 4049
D2 C14
S1
4 U5 R6
C13
N
R7
L6 C3 R1 R9 D5
C26
C18 1
3 TO REGULATOR
2
C19 C11
L5 U3 1 6
L4
J5 U6
4
CAUTION :FOR CONTINUED PROTECTION AGAINST RISK OF FIRE,

REPLACE ONLY WITH SAME TYPE FUSE.
PRECAUTION :EN VUE DE LA PROTECTION CONTINUELLE CONTRE LES 8251974 102
PCB,POWER SWITCH,D-108
RISQUES D'INCENDIE,REPLACER LE MEME TYPE DE FUSIBLE
J5
L5
U3
1 6 U6
PQ1CF2
L4
C3 R1 R9 C18 C19 C26
D5 R7 R6
N
C11 C13
L6 C14
4 1 C17
D2 C10 U1
C16 C9
L2 C12
U5
L
D1 AGND R10 C29

D3
1
3 2
C32 C27
T1 R11
R12 D10
J3
C1 C2 DGND
C7 L3
D6
T2 Q1
C15
C6
U7
J2
C28
C22
4 1 R8
C21
D7 C31
D4 R15 C8
1
L1
C24
R5
R2 U8
U2
3 2
12
U10
C5 R14 D8
D9 R3 R16
R4
6
C4 C30
U4
C20
U9
C23
1 2
1
+
8251974 101 7
L7 J1 J4
F1 PCB,POWER,D-108 R13
• Parts & Foil Side of WORD I/O PCB

C404
L402
R402
C403
L401
U401 1 8251988 004

W401 C401 R401
PCB,WORD I/O D1624
R403
R405
1 4
S401 J403 J402
S401
1 4
R406
C402
C401
W401
R404
D401 D402 J402

J403
36
D1624 / D824
D1624 Parts List

• Main PCB assy
8274 2200 00 PCB Assy, Main, D1624 U060 8236 5450 00 ST, TSSOP, 74VHC00
8251 9881 01 Plain PCB, Main, D1624/D824 U061 8236 5034 00 ST, DG, VCO, TC9246F
U062 8236 5451 61 ST, TSSOP, 74VHC161
ICs U063 8236 5450 86 ST, TSSOP, 74VHC86
Ref. No. Part No. Description U064 8236 0829 00 SOP, DG, SCSI terminate,
U001 8236 0848 10 QFP, DG, CPU, SH7709A, BH9595FP-Y
HD6417709A U065 8236 5641 00 ST, SS0P, 74LVXC3245FS
U002, 003 8236 0851 00 QFP, DG, gate array, SPPS U066 8236 5641 00 ST, SS0P, 74LVXC3245FS
U004, 005 8236 0850 00 QFP, DG, gate array, DIF U067 8236 5641 00 ST, SS0P, 74LVXC3245FS
U006 8236 0847 00 TSOP, DG, FROM, M29W800AT U069 8236 5440 04 ST, TSSOP, 74VHCT04
U007, 008 8236 0866 00 TSOP, DG, SDRAM, U070 8236 5440 08 ST, TSSOP, 74VHCT08
MB81F641642D-102 U071 8236 5445 41 ST, TSSOP, 74VHCT541
U009 8236 0828 00 QFP, DG, SCSI, MB86604L U072 8236 5450 86 ST, TSSOP, 74VHC86
U010 8236 5450 10 ST, TSSOP, 74VHC10 U073 8236 5701 01 ST, DG, driver, DTC114EK
U011 8236 5601 51 ST, DG, 74HC151 U074 8236 5708 03 ST, DG, driver, DTB114EK
U012, 013 8236 5450 00 ST, TSSOP, 74VHC00 U075 8236 5445 41 ST, TSSOP, 74VHCT541
U014, 015 8236 5704 01 ST, DG, driver, DTA114EK U079 8236 5450 00 ST, TSSOP, 74VHC00
U016 8236 5701 01 ST, DG, driver, DTC114EK U080 8236 5459 04 ST, TSSOP, 74VHCU04
U017, 018 8236 5034 00 ST, DG, VCO, TC9246 U082 8236 5451 61 ST, TSSOP, 74VHC161
U019 8236 5451 61 ST, TSSOP, 74VHC161 U083 8236 5450 04 ST, TSSOP, 74VHC04
U020 8236 0853 00 V, AN, DC-DC, PQ1CF2 U084, 085 8236 5451 57 ST, TSSOP, 74VHC157
U021 8236 5459 04 ST, TSSOP, 74VHCU04 U086 8236 5642 00 ST, DG, TIMER, NJU6350R
U022 8236 5440 32 ST, TSSOP, 74VHCT32 U087 8236 5440 32 ST, TSSOP, 74VHCT32
U023 8236 5450 11 ST, TSSOP, 74VHC11 U1..801 8236 5050 11 ST, AN, op amp, NJM2115M (TEI)
U024 8236 5601 51 ST, DG, 74HC151 U102 8236 5405 00 ST, AN, NJM2068MD (TEI)
U025 8236 5450 14 ST, TSSOP, 74VHC14 U1..1612 8236 5702 01 ST, DG, driver, DTC314TK
U026 8236 5450 32 ST, TSSOP, 74VHC32 U1..431 8236 5424 00 ST, DG, AD, AK5393VS-E2
U027 8236 5450 00 ST, TSSOP, 74VHC00 U1..841 8236 5422 00 ST, DG, DA, AK4393VF-E2
U028 8234 5047 00 OPT, ST, photo, PC410T U302 8236 5405 00 ST, AN, NJM2068MD (TEI)
U029, 030 8236 5701 01 ST, DG, driver, DTC114EK U502 8236 5405 00 ST, AN, NJM2068MD (TEI)
U031 8236 5450 74 ST, TSSOP, 74VHC74 U702 8236 5405 00 ST, AN, NJM2068MD (TEI)
U032 8236 5419 00 ST, AN, regulator, PQ7VZ5U U902 8236 5405 00 ST, AN, NJM2068MD (TEI)
U033, 034 8236 5440 08 ST, TSSOP, 74VHCT08 U1102 8236 5405 00 ST, AN, NJM2068MD (TEI)
U035 8236 5701 01 ST, DG, driver, DTC114EK U1302 8236 5405 00 ST, AN, NJM2068MD (TEI)
U036, 037 8236 5450 74 ST, TSSOP, 74VHC74 U1502 8236 5405 00 ST, AN, NJM2068MD (TEI)
U038 8236 5403 01 ST, AN, regulator, L78M05T-TL
U039 8236 5701 01 ST, DG, driver, DTC114EK DIODEs
U040 8236 5708 03 ST, DG, driver, DTB114EK Ref. No. Part No. Description
U041 8236 5414 00 PT, AN, REG, PQ3DZ53U D001~005 8234 5028 00 ST, DAN202K
U042 8236 5450 74 ST, TSSOP, 74VHC74 D006~008 8234 5029 00 ST, DAP202K-T146
U043 8236 5450 00 ST, TSSOP, 74VHC00 D009, 010 8234 5021 00 ST, SCHOTTKY, SB05-05CP
U044~046 8236 5450 74 ST, TSSOP, 74VHC74 D011~014 8234 5028 00 ST, DAN202K
U047, 048 8236 5641 00 ST, SS0P, 74LVXC3245FS D015 8234 1084 00 VT, SCHOTTKY, EK03W
U049 8236 5025 00 ST, AN, RESET, NJM2103M D017 8234 1050 00 VF, SCHOTTKY, EK13
U050 8236 5441 38 ST, TSSOP, 74VHCT138 D025 8234 7506 00 ST, RB400D
U051 8236 5440 08 ST, TSSOP, 74VHCT08
U052, 053 8236 5450 04 ST, TSSOP, 74VHC04 RESISTORs
U054 8236 5450 74 ST, TSSOP, 74VHC74 Ref. No. Part No. Description
U055 8236 5450 08 ST, TSSOP, 74VHC08 R001 8230 5103 02 ST, carbon, 1/15W, 3kΩ, 5%
U056, 057 8236 5450 04 ST, TSSOP, 74VHC04 R002 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5%
U058 8236 5450 08 ST, TSSOP, 74VHC08 R003, 004 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5%
U059 8236 5451 57 ST, TSSOP, 74VHC157 R005 N/A
37
D1624 / D824
R006 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R086, 087 8230 5104 72 ST, carbon, 1/15W, 4.7kΩ, 5%
R007 8242 5041 21 Filter, ST, EMI, EXC3BP, 121 R088, 089 8230 5104 73 ST, carbon, 1/15W, 47kΩ, 5%
R008 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R092, 093 8230 5104 73 ST, carbon, 1/15W, 47kΩ, 5%
R009 8242 5041 21 Filter, ST, EMI, EXC3BP, 121 R094 8230 5100 00 ST, carbon, 1/15W, 0Ω, 5%
R010 8230 5101 05 ST, carbon, 1/15W, 1MΩ, 5% R095 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5%
R011 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R096 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R012 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 R097 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5%
R013~022 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R099 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R023, 024 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 R1..801 8230 5101 33 ST, carbon, 1/15W, 13kΩ, 5%
R025 8242 5041 21 Filter, ST, EMI, EXC3BP, 121 R1..802 8230 5109 12 ST, carbon, 1/15W, 9.1kΩ, 5%
R026 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R1..803 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R027 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R1..804 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R028 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R1..805 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5%
R029 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5% R1..806 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5%
R032, 033 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% R1..809 8230 5101 33 ST, carbon, 1/15W, 13kΩ, 5%
R034 N/A R1..1611 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5%
R036 8230 5100 00 ST, carbon, 1/15W, 0Ω, 5% R1..1612 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5%
R037 N/A R1..1613 8230 5108 21 ST, carbon, 1/15W, 820Ω, 5%
R039 N/A R1..1615 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5%
R042~045 N/A R1..1617 8230 5104 73 ST, carbon, 1/15W, 47kΩ, 5%
R047 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 R1..431 8230 5101 00 ST, carbon, 1/15W, 10Ω, 5%
R049 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% R1..433 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5%
R051 8230 5103 32 ST, carbon, 1/15W, 3.3kΩ, 5% R3001 8230 5101 52 ST, carbon, 1/15W, 1.5kΩ, 5%
R052 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 R3002 8230 5102 24 ST, carbon, 1/15W, 220kΩ, 5%
R053 8230 5102 22 ST, carbon, 1/15W, 2.2kΩ, 5% R3003 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5%
R054 8230 5104 72 ST, carbon, 1/15W, 4.7kΩ, 5% R3004 8242 5051 02 Filter, ST, EMI, EXC3BB, 102
R055 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R3005 8230 5100 00 ST, carbon, 1/15W, 0Ω, 5%
R056 8230 5104 72 ST, carbon, 1/15W, 4.7kΩ, 5% R3006 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5%
R057 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R3007 8230 5105 62 ST, carbon, 1/15W, 5.6kΩ, 5%
R059 8230 5102 23 ST, carbon, 1/15W, 22kΩ, 5% R3009, 10 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5%
R060, 061 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 R3011 8242 5051 02 Filter, ST, EMI, EXC3BB, 102
R063 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% R3013 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5%
R064 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R3014, 15 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R067 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R3016 8230 5105 62 ST, carbon, 1/15W, 5.6kΩ, 5%
R068, 069 8230 5081 01 ST, array, 100Ω x 4, 5%, CN1J4 R3017 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5%
R070 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R3018, 19 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5%
R071, 072 8230 5081 01 ST, array, 100Ω x 4, 5%, CN1J4 R3020 8242 5051 02 Filter, ST, EMI, EXC3BB, 102
R073 8230 5101 03 ST, carbon, 1/15W, 10kΩ 5% R3021 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R074, 075 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% R3022 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5%
R076 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R3023, 24 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R077, 078 8230 5101 05 ST, carbon, 1/15W, 1MΩ, 5% R3025 8230 5100 00 ST, carbon, 1/15W, 0Ω, 5%
R079, 080 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R3040 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R081 8230 5101 52 ST, carbon, 1/15W, 1.5kΩ, 5% R3041, 42 8230 5104 73 ST, carbon, 1/15W, 47kΩ, 5%
R082, 083 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R3043, 44 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R085 N/A
38
D1624 / D824
CAPACITORs Ref. No. Part No. Description

ALU = Electrolytic type C1..1613 8233 5131 02 ST, CER,50V, 0.001µF, 15%, CC11R
CER = Ceramic type C1..1614 8232 1431 07 VT, ALU, 16V, 100µF, 20%, SME-VB
Ref. No. Part No. Description C115, 116 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C001~009 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C1..431 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C010 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C1..432 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
C011 8233 5131 01 ST, CER, 50V, 100µF, 15%, CC11R C1..433 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C012, 013 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C1..434 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
C014~016 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C1..435 8233 5172 24 ST, CER, 16V, 0.22µF, 20%, KC11E
C017 8232 3574 77 VT, ALU, 16V, 470µF, 20%, LXV, D10 C1..436 8233 5172 24 ST, CER, 16V, 0.22µF, 20%, KC11E
C018 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C1..437 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C019 8232 3631 27 VT, ALU, 6.3V, 120µF, 20%, LXV, DS C1..438 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C021~027 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C1..439 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C028 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R C1..440 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
C033 8232 1424 77 VT, ALU, 10V, 470µF, 20%, SME-VB C1..842 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
C045 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C1..844 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
C046 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R C1..846 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C047, 048 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C1..847 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C049, 050 8232 1441 07 VT, ALU, 25V, 100µF, 20%, SME-VB C315, 316 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C051, 052 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C515, 516 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C053 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C715, 716 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C054 8232 3711 87 VT, ALU, 16V, 180µF, 20%, LXV, D6.3 C915, 916 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C056 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C1115, 16 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C057, 058 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R C1315, 16 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C060 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB C3001 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C061 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C3002~04 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C062~069 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C3005 8233 5164 74 ST, CER, 16V, 0.47µF, 20%, KC20E
C070 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C3006 8233 5121 50 ST, CER, 50V, 15pF, 5%, CC11SL
C077 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C3007, 08 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C078 8232 3574 77 VT, ALU, 16V, 470µF, 20%, LXV, D10 C3009 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C079 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C3010~14 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C080 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C3015 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C082, 083 8232 1421 07 VT, ALU, 10V, 100µF, 20%, SME-VB C3016~19 8233 5122 20 ST, CER, 50V, 22pF, 5%, CC11SL
C084 8232 1431 07 VT, ALU, 16V, 100µF, 20%, SME-VB C3020 N/A
C086 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C3021 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C088 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C3024 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C089, 090 8232 3631 27 VT, ALU, 6.3V, 120µF, 20%, LXV, DS C3025~29 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C091, 092 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C3030 N/A
C095 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C3031, 32 8233 5123 30 ST, CER, 50V, 33pF, 5%, CC11SL
C096, 097 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C3033~35 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R
C098 8232 3574 77 VT, ALU, 16V, 470µF, 20%, LXV, D10 C3036, 37 8233 5121 80 ST, CER, 50V, 18pF, 5%, CC11SL
C099 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB C3038 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C100 N/A C3039~42 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R
C101~801 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV C3043 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C102~802 8233 5132 22 ST, CER, 50V, 0.0022µF, 5%, CC11R C3044~48 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C103~803 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C3050 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C104~804 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C3051~53 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C105~805 8233 0491 06 ST, ALU, 16V, 10µF, 15%, MV C3054 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C106~806 N/A C3055, 56 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C107~807 N/A C3057 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C1..1611 8233 5133 32 ST, CER, 50V, 0.0033µF, 15%, CC11R C3058~60 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C1..1612 8233 5131 02 ST, CER,50V, 0.001µF, 15%, CC11R C3061 8233 5164 74 ST, CER, 16V, 0.47µF, 20%, KC20E
39
D1624 / D824
C3062 8233 5121 50 ST, CER, 50V, 15pF, 5%, CC11SL J008, 009 N/A
C3063 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R J010 8245 5470 02 Connector, PI, jack, PH, 2P
C3064 8233 5131 01 ST, CER, 50V, 100pF, 15%, CC11R J011 8245 5530 10 Connector, opt, GPIF37R1
C3065 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F J012 8245 5520 10 Connector, opt, GPIF38T2
C3066~68 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R J013, 014 8245 2720 17 Connector, PI, jack, FPC 17P
C3069 8233 5131 01 ST, CER, 50V, 100pF, 15%, CC11R J016 8245 3290 50 Connector, PL, D-SUB, 50P, P1.27,
C3070 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R ECI2
C3071 8233 5131 01 ST, CER, 50V, 100pF, 15%, CC11R J018 8245 2720 25 Connector, PI, jack, FPC, 25P
C3072 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R J020 8245 5530 10 Connector, opt, GPIF37R1
C3073 8233 5124 70 ST, CER, 50V, 47pF, 5%, CC11SL J021 8245 5520 10 Connector, opt, GPIF38T2
C3074 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F J022 8245 0530 05 Connector, PI, jack, 8263, 5P, WHT
C3075 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J101, 102 8245 2860 00 Connector, PL, jack, RCA, 4P,
C3076~78 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R YKC21-3077
C3079 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J103, 104 8245 2720 17 Connector, PI, jack, FPC 17P
C3080, 81 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R J105 8245 0530 04 Connector, PI, jack, 8263, 4P, WHT
C3082 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J106~109 8245 2860 00 Connector, PL , jack, RCA, 4P,
C3083~85 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R YKC21-3077
C3086 8233 5164 74 ST, CER,16V, 0.47µF, 20%, KC20E L001, 002 8242 5025 60 Core, ST, CDRH104, 56µH
C3087 8233 5121 50 ST, CER, 50V, 15pF, 5%, CC11SL L003, 004 N/A
C3088 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R L005 8242 2640 01 Coil, DC-DC, R17, 256µH
C3089 8233 5131 01 ST, CER, 50V, 100pF, 15%, CC11R L007 N/A
C3090~92 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R L008~010 8242 5000 21 Coil, ST, 22µH, LFC32
C3093 8233 5131 01 ST, CER, 50V, 100pF, 15%, CC11R L1..801 8242 5041 21 Filter, ST, EMI, EXC3BP, 121
C3094, 95 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R L1..1602 8242 5041 21 Filter, ST, EMI, EXC3BP, 121
C3096 8233 5131 01 ST, CER, 50V, 100pF, 15%, CC11R W001 8276 7360 40 Cable assy, 12P, 8263,
C3097 8233 5124 70 ST, CER, 50V, 47pF, 5%, CC11SL WHT-5395, #22, L400
C3098, 99 8233 5123 30 ST, CER, 50V, 33pF, 5%, CC11SL W002 8277 3184 30 Cable assy, 4P, 5395-CNC, L300
C3100~15 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R W003 8245 3590 02 Pin header, 2P, P2.0, 9210B-1
C3116, 17 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB W004 N/A
C3118~28 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R W005 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5%
C3129, 30 N/A W011 N/A
W012 8277 4771 22 Cable assy, FC, 40P, /B-/F, L220,
MISCELLANEOUS core, reverse
Ref. No. Part No. Description W013 8245 3590 02 Pin header, 2P, P2.0, 9210B-1
E2301 N/A (TP001) W301 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5%
E2302 N/A (TP002) W302 N/A
E2304 N/A (TP004) W402 N/A
E2305, 06 8276 0010 00 Pin, header (TP005) W503, 603 N/A
E2306 8276 0010 00 Pin, header (TP006) W701 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5%
E2307 N/A (TP007) W702, 703 N/A
E2309 N/A (TP009) W802, 803 N/A
E2310 N/A (TP010) X001 8256 1700 01 Resonator, ST, XTL, 22.579MHz,
E2311 N/A (TP011) FUP-FBB3A
E2312 N/A (TP012) JX002 8256 1700 02 Resonator, ST, XTL, 24.576MHz,
E2315 8239 1200 00 Battery, 3V, CR2032 FUP-FBB3A
E2316 8239 1210 00 Holder, battery, BCR20H4 X003 8256 1790 04 Resonator, PT, CER, 11.00MHz, F5,
J001 8245 0530 05 Connector, PI, jack, 8263, 5P, WHT EF0EN
J002 8245 1711 04 Connector, PI, jack, 8283, 4P, WHT X004 8256 1850 00 Resonator, ST, XTL, 32.768KHz,
J003 8245 0530 04 Connector, PI, jack, 8263, 4P, WHT DMX-26
J004 8245 2720 25 Connector, PI, jack, FPC, 25P X005 8256 1710 01 Resonator, PT, CER, 20.00MHz, KBR
J005 8245 3220 50 Connector, PI, header, 50P, P2.0, 9210B X006 8256 1850 00 Resonator, ST, XTL, 32.768KHz,
J006 8245 1711 07 Connector, PI, jack, 8283, 7P, WHT DMX-26
J007 8245 1711 09 Connector, PI, jack, 8283, 9P, WHT
40
D1624 / D824
• Connect PCB assy Ref. No. Part No. Description

D006 8234 1078 00 HT, 600V, 1.0A, D1N60-4084
Ref. No. Part No. Description
D007 8234 1085 00 HT, fast recovery, D1NL40
8274 2210 00 PCB Assy, Connect, D1624/D824
D008 8234 5039 34 HT, zener, MTZ J 6.8
8251 9880 05 Plain PCB, Connect, D1624/D824
D009 8234 1077 00 Stack, 600VAC, 1.5A, D2SBA60
D010 8234 5052 00 V, 600V, 1.7A, S2V60-4002
D011 8234 5007 00 HT, 1SS136
J1001 8245 2960 00 Connector, PL, jack, D-SUB/F, 15P-HD
D012 8234 5039 27 HT, zener, MTZ J 5.6B
L1001~13 8242 5041 21 Filter, ST, EMI, EXC3BP, 121
W1001 8276 7310 20 Cable assy, 7P, 8263, WHT-5395,
RESISTORs
#22, L200
W1002 8276777035 Cable assy, 7P, WHTMT/F-MT/BS,
R001 8230 1386 29 HT, carbon, 1/4W, 6.2Ω, 5%
L350
R002 8230 1383 31 HT, carbon, 1/4W, 330Ω, 5%
R003 8230 1381 01 HT, carbon, 1/4W, 100Ω, 5%
R004 8230 1388 22 HT, carbon, 1/4W, 8.2kΩ, 5%
• MIDI PCB assy R005 8230 1382 02 HT, carbon, 1/4W, 2kΩ, 5%
Ref. No. Part No. Description R006 8230 1484 72 HT, metal, 1/4W, 4.7kΩ, 1%
8274 2220 00 PCB Assy, MIDI, D1624/D824 R007 8230 1481 52 HT, metal, 1/4W, 1.5kΩ,1%
8251 9880 02 Plain PCB, MIDI, D1624/D824 R008 8230 1251 04 H, metal, 2W, 100kΩ, 5%, F20, RSS
R009 8230 1386 29 HT, carbon, 1/4W, 6.2Ω, 5%
Ref. No. Part No. Description R010 8230 1381 03 HT, carbon, 1/4W, 10kΩ, 5%
J201 8276 7760 15 Cable assy, 6P, WHTMT/F-MT/BS, R011 8230 1384 72 HT, carbon, 1/4W, 4.7kΩ, 5%
L150 R012 8230 5094 72 HT, non-flammable, 1/4W, 4.7kΩ,
J202 8245 2970 00 Connector, PL , jack, DIN, 5P, 5%, MHT
YKF51-5040 R013 8230 1382 02 HT, carbon, 1/4W, 2kΩ, 5%
L101~106 8242 5041 21 Filter, ST, EMI, EXC3BP, 121 R014 8230 1251 01 H, metal, 2W, 100Ω, 5%, F20, RSS
R201~206 8230 5102 21 Resistor, ST, carbon, 1/15W, 220Ω, 5% R015 8230 1384 73 HT, carbon, 1/4W, 47kΩ, 5%
R016 8230 1382 23 HT, carbon, 1/4W, 22kΩ, 5%
R017 8230 1381 03 HT, carbon, 1/4W, 10kΩ, 5%
• Power PCB assy

CAPACITORs
ALU = Electrolytic type
8274 2230 00 PCB Assy, Power, D1624/D824
CER = Ceramic type
8251 9744 01 Plain PCB, Power, D1624/D824
PES = Mylar type
ICs
C001, 002 8232 3542 22 VT, CER, 250V, 0.0022µF, 20%,
ECK-ZNS
U001 8236 0028 01 DIP, DG, CMOS, 4049UB
C003 8232 3521 04 V, PES, 250VAC, 0.1µF, 20%,
U002 8236 5409 00 VT, AN, regulator, AN1431T
ECQ-UMV
U003 8234 1081 00 OPT, H, photo coupler, ON3171
C004 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF
U004 N/A
C005 8232 3241 07 V, ALU, 400V, 100µF, 20%,
U005 8236 5410 06 V, AN, power, MIP166
SMH-VNSN, D2
U006 8236 0859 00 V, AN, DC-DC, PQ1CF1
C006~008 8232 3584 77 VT, ALU, 25V, 470µF, 20%, LXV, D10
U007, 009 N/A
C009 8232 0964 76 V, ALU, 25V, 47µF, 20%, SME
U010 8236 0853 00 V, AN, DC-DC, PQ1CF2
C010~013 8232 3584 77 VT, ALU, 25V, 470µF, 20%, LXV, D10
C014 8232 1441 07 VT, ALU, 25V, 100µF, 20%, SME-VB
TRANSISTORs
C015 8232 3584 77 VT, ALU, 25V, 470µF, 20%, LXV, D10
C016, 017 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF
Q001 8234 1094 03 V, FET, 2SK2661, TO-22ONIS
C018, 019 8232 3542 22 VT, CER, 250V, 0.0022µF, 20%,
Q002 8234 1034 00 V, PNP, 2SA1606, A/E
ECK-ZNS
C022 8232 8031 03 VT, CER, 50V, 0.01 F, +80-20%, YF
DIODEs
C025 8232 3491 03 VT, PES, SEMKO, TLAG, 0.8A,
250V, TR5-T
D001 8234 1079 00 HT, 80V, 0.2A, MA171
D002, 003 8234 1085 00 HT, fast recovery, D1NL40
D004 8234 1080 00 V, 200V, 5.0A, MA649
D005 8234 1084 00 VT, SCHOTTKEY, EK03W
41
D1624 / D824
MISCELLANEOUS • Display PCB assy

J001 8245 0530 07 Connector, PI, jack, 8263, 7P, WHT 8274 2260 00 PCB Assy, Display, D1624/D824
J002 8245 0530 12 Connector, PI, jack, 8263, 12P, WHT 8251 5111 00 Plain PCB, Display, D1624/D824
J003 8245 3210 00 Connector, PL, jack, AC INLET, 3P,
0714-FR7
J004 8245 0530 02 Connector, PI, jack, 8263, 2P, WHT ICs
J005 8245 0530 06 Connector, PI, jack, 8263, 6P, WHT Ref. No. Part No. Description
L001 8242 2491 93 Filter, line, 19mH, 0.5A, ELFI5NOO5A U001 8236 0704 03 QFP, DG, CPU, HD6433723, DISP,
L002 8242 2491 02 Filter, line, 1mH, 2.2A, ELFI5NO22A FL-CTRL
L003 8242 2501 03 Coil, PV, 10µH, 2A, ELC U002 8236 5025 00 ST, AN, reset, NJM2103M
L004 8242 2640 01 Coil, DC-DC, R17, 256µH U003~006 8236 0781 01 PT, DG, driver, DTC114ES
L005, 006 8242 1340 01 Filter, EMI, 6HOLE U008, 009 8236 0782 01 PT, DG, driver, DTA114ESA
L007 8242 2620 00 Coil, DC-DC, RCH110, 180µH U012 8256 1090 01 Module, shuttle, SRGPHJ-A-3-2
T001 8242 2580 00 Transformer, SW, POWER, ER2810, U013 8256 1730 00 Module, display, FL, CM1538D
12-18 U014 8236 0830 01 QFP, DG, VFD, driver, LC75710NE
T002 8242 2600 00 Transformer, DC-DC, EE1605, U015~017 8236 0782 01 PT, DG, driver, DTA114ESA
AC5CT-30
Y501 8207 0126 02 Heat sink, 17PB23, L25, B TRANSISTORs
Y502~504 8207 0015 00 Heat sink, OSH-1625-SP Ref. No. Part No. Description
Q001~004 8234 1008 02 VT, PNP, 2SA1150Y
DIODEs
• Power SW PCB assy Ref. No. Part No. Description
D001~015 8234 5007 00
HT, 1SS136
D019~022 8234 5007 00
HT, 1SS136
8274 2240 00 PCB Assy, Power SW, D1624/D824
D031~047 8234 5007 00
HT, 1SS136
8251 9743 02 Plain PCB, Power SW, D1624/D824
D049~052 8234 5007 00
HT, 1SS136
D061 8234 0100 00
OPT, V, LED, org, GL-2HD6
D062~064 8234 0191 00
OPT, V, LED, grn, GL-2EG6
S1001 8253 4610 02 SW, P, push, power, SDDLB1-B1-F2
D065 8234 0100 00
W1001, 02 8277 1620 40 Cable assy, SIN1.8-SIN1.8, 400
D066~068 8234 0191 00
OPT, V, LED, org, GL-2EG6
D069 8234 0100 00
D070~076 8234 0191 00
OPT, V, LED, grn, GL-2EG6
D081~083 N/A
D084~095 8234 5007 00 HT, 1SS136
• Regulator PCB assy
Ref. No. Part No. Description RESISTORs
8274 2250 00 PCB Assy, Regulator, D1624/D824 Ref. No. Part No. Description
8251 9743 03 Plain PCB, Regulator, D1624/D824 R001~010 8230 1381 54 HT, carbon, 1/4W, 150kΩ, 5%
R012~037 8230 1381 54 HT, carbon, 1/4W, 150kΩ, 5%
Ref. No. Part No. Description R038, 039 8230 1381 54 HT, carbon, 1/4W, 150kΩ, 5%
U001 8236 0321 06 IC, 220, AN, regulator, 7815FA R040 8230 1381 05 HT, carbon, 1/4W, 1MΩ, 5%
U002 8236 0348 06 IC, 220, AN, regulator, 7915FA R042~046 8230 1381 01 HT, carbon, 1/4W, 100Ω, 5%
C001~004 8232 8031 03 Capacitor, VT, CER, 50V, 0.01µF, R047 8230 1481 52 HT, carbon, 1/4W, 1.5kΩ, 1%
+80-20%, YF R048 8230 1381 01 HT, carbon, 1/4W, 100Ω, 5%
C005, 006 8232 1431 06 Capacitor, VT, ALU, 16V, 10µF, R049~052 8230 1383 90 HT, carbon, 1/4W, 39Ω, 5%
20%, SME-VB R054~057 8230 1381 02 HT, carbon, 1/4W, 1kΩ, 5%
W001 8276 7300 20 Cable assy, 6P, 8263WHT-5395, L200 R058, 061 8230 1382 23 HT, carbon, 1/4W, 22kΩ, 5%
R059, 062 8230 1381 03 HT, carbon, 1/4W, 10kΩ, 5%
R060, 063 8230 1381 04 HT, carbon, 1/4W, 100kΩ, 5%
R065 8230 1381 03 HT, carbon, 1/4W, 10kΩ, 5%
R066~068 8230 1381 54 HT, carbon, 1/4W, 150kΩ, 5%
42
D1624 / D824

ALU = Electrolytic type C302 8233 5131 03 Capacitor, ST, CER, 50V, 0.01µF,
CER = Ceramic type 15%, CC11R
Ref. No. Part No. Description C303~306 N/A
C001, 003 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF J301 8276 7790 30 Cable assy, 9P, WHTMT/F-MT/BS,
C002, 004 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF L300
C005, 006 8232 1461 06 VT, ALU, 50V, 10µF, 20%, SME-VB J302, 303 8245 5460 11 Connector, PL, jack, D-SUB, 9P, #4-40
C007, 008 8232 8013 00 VT, CER, 50V, 30pF, 5%, SL J304 8245 1711 06 Connector, PI, jack, 8283, 6P, WHT
C009 8232 8031 03 VT, CER, 50V, 0.01µF, +80-20%, YF L301~304 8242 5041 21 Filter, ST, EMI, EXC3BP, 121
C010, 011 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF S301 8253 6550 04 SW, PI, slide, 1-2, non-shortening,
C012, 013 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF SSSF1
C014 8232 8031 04 VT, CER, 50V, 0.1µF, +80-20%, YF W301 8276 7790 25 Cable assy, 9P, WHTMT/F-MT/BS,
C015 8232 8031 03 VT, CER, 50V, 0.01µF, +80-20%, YF L250
C016 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF
C017, 018 8232 8031 03 VT, CER, 50V, 0.01µF, +80-20%, YF
C019 8232 8014 71 VT, CER, 50V, 470pF, 5%, SL
C020 8232 8181 04 VT, CER, 25V, 0.1µF, +80-20%, YF • WORD I/O PCB assy
C021 8232 8013 00 VT, CER, 50V, 30pF, 5%, SL
C022 8232 8031 04 VT, CER, 50V, 0.1µF, +80-20%, YF
8274 2580 00 PCB Assy, WORD I/O, D1624/D824
C023 8232 8014 71 VT, CER, 50V, 470pF, 5%, SL
8251 9880 04 Plain PCB, WORD I/O, D1624/D824
MISCELLANEOUS
U401 8236544004 IC, ST, TSSOP, 74VHCT04
J001 8245 1721 15 Connector, PL, jack, 8283, 15P, WHT
D401 8234 5028 00 Diode, ST, DAN202K
J002 8245 2980 00 Connector, PL, jack, phone,
D402 8234 5029 00 Diode, ST, DAP202K-T146
LGR4609-7000
R401 8230 5031 00 Resistor, ST, carbon, 1/2W, 10Ω, 5%
L001~003 8242 1340 01 Filter, EMI, 6HOLE
R402 8230 5101 02 Resistor, ST, carbon, 1/15W, 1kΩ, 5%
L004, 005 8242 1860 13 Filter, T, EMI, LFW7B-M3R2T
R403 8230510750 Resistor, ST, carbon, 1/15W, 75Ω, 5%
S000~015 8253 1350 02 SW, PT, tact, SKQNAB
R404, 405 8230510101 Resistor, ST, carbon, 1/15W, 100Ω, 5%
R406 8230510105 Resistor, ST, carbon, 1/15W, 1MΩ, 5%
C401 8232 1431 06 Capacitor, VT, ALU, 16V, 10µF,
X001 8256 1340 03 Resonator, PF, CER, 8.00MHz, F5,
20%, SME-VB
EFOEN
C402 8233 5131 03 Capacitor, ST, CER, 50V, 0.01µF,
Y701 8207 0100 11 Spacer, LED, 11
15%, CC11R
Y702 8207 0100 09 Spacer, LED, 9
C403, 404 8233 5124 70 Capacitor, ST, CER, 50V, 47pF, 5%,
Y703 8216 5910 00 Spacer, FL, DMT-8/D1624/D824
CC11SL
J401 8276 7741 25 Cable assy, 4P, red, 8283/F-9073/BS,
L250
J402, 403 8245 3000 00 Connector, PL, jack, BNC, 01K0083
• RS422 PCB assy L401, 402 8242 5041 21 Filter, ST, EMI, EXC3BP, 121
S401 8253655004 SW, PI, slide, 1-2, non-shortening,
SSSF1
8274 2570 00 PCB Assy, RS422, D1624/D824
W401 8276774020 Cable assy, 4P, WHTMT/F-MT/BS,
8251 9880 03 Plain PCB, RS422, D1624/D824
L200

U301 8236 5426 00 IC, ST, transceiver, SN75C1168
R301 8230 5101 01 Resistor, ST, carbon, 1/15W, 100Ω,
5%
R302 8230 5101 03 Resistor, ST, carbon, 1/15W, 10kΩ,
5%
R303, 304 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5%
R305, 306 8230 5104 70 Resistor, ST, carbon, 1/15W, 47Ω, 5%
R307 8230 5101 01 Resistor, ST, carbon, 1/15W, 100Ω,
5%
C301 8232 1431 06 Capacitor, VT, ALU, 16V, 10µF,
20%, SME-VB
43
D1624 / D824
D824 Parts List

• Main PCB assy
8274 2590 00 PCB Assy, Main, D824 U056, 057 8236 5450 04 ST, TSSOP, 74VHC04
8251 9881 01 Plain PCB, Main, D1624/D824 U058 8236 5450 08 ST, TSSOP, 74VHC08
U059 8236 5451 57 ST, TSSOP, 74VHC157
ICs U060~62 N/A
Ref. No. Part No. Description U063 8236 5450 86 ST, TSSOP, 74VHC86
U001 8236 0848 10 QFP, DG, CPU, SH7709A, U064 8236 0829 00 SOP, DG, SCSI terminate,
HD6417709A BH9595FP-Y
U002 8236 0851 00 QFP, DG, gate array, SPPS U065 8236 5641 00 ST, SS0P, 74LVXC3245FS
U003 N/A U066 8236 5641 00 ST, SS0P, 74LVXC3245FS
U004 8236 0850 00 QFP, DG, gate array, DIF U067 8236 5641 00 ST, SS0P, 74LVXC3245FS
U005 N/A U069 8236 5440 04 ST, TSSOP, 74VHCT04
U006 8236 0847 00 TSOP, DG, FROM, M29W800AT U070 8236 5440 08 ST, TSSOP, 74VHCT08
U007, 008 8236 0866 00 TSOP, DG, SDRAM, U071 8236 5445 41 ST, TSSOP, 74VHCT541
MB81F641642D-102 U072 N/A
U009 8236 0828 00 QFP, DG, SCSI, MB86604L U073 8236 5701 01 ST, DG, driver, DTC114EK
U010 8236 5450 10 ST, TSSOP, 74VHC10 U074 8236 5708 03 ST, DG, driver, DTB114EK
U011 8236 5601 51 ST, DG, 74HC151 U075 8236 5445 41 ST, TSSOP, 74VHCT541
U012, 013 8236 5450 00 ST, TSSOP, 74VHC00 U079 8236 5450 00 ST, TSSOP, 74VHC00
U014 8236 5704 01 ST, DG, driver, DTA114EK U080 8236 5459 04 ST, TSSOP, 74VHCU04
U015 N/A U082 8236 5451 61 ST, TSSOP, 74VHC161
U016 8236 5701 01 ST, DG, driver, DTC114EK U083 8236 5450 04 ST, TSSOP, 74VHC04
U017, 018 8236 5034 00 ST, DG, VCO, TC9246 U084 8236 5451 57 ST, TSSOP, 74VHC157
U019 8236 5451 61 ST, TSSOP, 74VHC161 U085 N/A
U020 8236 0853 00 V, AN, DC-DC, PQ1CF2 U086 8236 5642 00 ST, DG, TIMER, NJU6350R
U021 8236 5459 04 ST, TSSOP, 74VHCU04 U087 8236 5440 32 ST, TSSOP, 74VHCT32
U022 8236 5440 32 ST, TSSOP, 74VHCT32 U101~801 8236 5050 11 ST, AN, op amp, NJM2115M (TEI)
U023 8236 5450 11 ST, TSSOP, 74VHC11 U102 N/A
U024 8236 5601 51 ST, DG, 74HC151 U112~412 N/A
U025 8236 5450 14 ST, TSSOP, 74VHC14 U512~812 8236 5702 01 ST, DG, driver, DTC314TK
U026 8236 5450 32 ST, TSSOP, 74VHC32 U912~1212 N/A
U027 8236 5450 00 ST, TSSOP, 74VHC00 U13..1612 8236 5702 01 ST, DG, driver, DTC314TK
U028 8234 5047 00 OPT, ST, photo, PC410T U1..431 8236 5424 00 ST, DG, AD, AK5393VS-E2
U029, 030 8236 5701 01 ST, DG, driver, DTC114EK U141, 241 N/A
U031 8236 5450 74 ST, TSSOP, 74VHC74 U341, 441 8236 5422 00 ST, DG, DA, AK4393VF-E2
U032 8236 5419 00 ST, AN, regulator, PQ7VZ5U U541, 641 N/A
U033, 034 8236 5440 08 ST, TSSOP, 74VHCT08 U741, 841 8236 5422 00 ST, DG, DA, AK4393VF-E2
U035 N/A U302 N/A
U036, 037 8236 5450 74 ST, TSSOP, 74VHC74 U502 8236 5405 00 ST, AN, NJM2068MD (TEI)
U038 8236 5403 01 ST, AN, regulator, L78M05T-TL U702 8236 5405 00 ST, AN, NJM2068MD (TEI)
U039 8236 5701 01 ST, DG, driver, DTC114EK U902 N/A
U040 8236 5708 03 ST, DG, driver, DTB114EK U1102 N/A
U041 8236 5414 00 PT, AN, REG, PQ3DZ53U U1302 8236 5405 00 ST, AN, NJM2068MD (TEI)
U042 8236 5450 74 ST, TSSOP, 74VHC74 U1502 8236 5405 00 ST, AN, NJM2068MD (TEI)
U043 8236 5450 00 ST, TSSOP, 74VHC00
U044~046 N/A DIODEs
U047, 048 8236 5641 00 ST, SS0P, 74LVXC3245FS Ref. No. Part No. Description
U049 8236 5025 00 ST, AN, RESET, NJM2103M D001~005 8234 5028 00
ST, DAN202K
U050 8236 5441 38 ST, TSSOP, 74VHCT138 D006~008 8234 5029 00
ST, DAP202K-T146
U051 8236 5440 08 ST, TSSOP, 74VHCT08 D009, 010 8234 5021 00
ST, SCHOTTKY, SB05-05CP
U052, 053 8236 5450 04 ST, TSSOP, 74VHC04 D011, 012 8234 5028 00
ST, DAN202K
U054 8236 5450 74 ST, TSSOP, 74VHC74 D013 N/A
U055 8236 5450 08 ST, TSSOP, 74VHC08 D011~014 8234 5028 00 ST, DAN202K
44
D1624 / D824
D015 8234 1084 00 VT, SCHOTTKY, EK03W R074, 075 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5%
D017 8234 1050 00 VF, SCHOTTKY, EK13 R076 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
D025 8234 7506 00 ST, RB400D R077, 078 8230 5101 05 ST, carbon, 1/15W, 1MΩ, 5%
R079, 080 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
RESISTORs R081 8230 5101 52 ST, carbon, 1/15W, 1.5kΩ, 5%
Ref. No. Part No. Description R082, 083 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R003, 004 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R086, 087 8230 5104 72 ST, carbon, 1/15W, 4.7kΩ, 5%
R005 N/A R088, 089 8230 5104 73 ST, carbon, 1/15W, 47kΩ, 5%
R007 8242 5041 21 Filter, ST, EMI, EXC3BP, 121 R094 8230 5100 00 ST, carbon, 1/15W, 0Ω, 5%
R009 8242 5041 21 Filter, ST, EMI, EXC3BP, 121 R096 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R010 8230 5101 05 ST, carbon, 1/15W, 1MΩ, 5% R097 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5%
R012 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 R1..801 8230 5101 33 ST, carbon, 1/15W, 13kΩ, 5%
R013~022 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R1..802 8230 5109 12 ST, carbon, 1/15W, 9.1kΩ, 5%
R025 8242 5041 21 Filter, ST, EMI, EXC3BP, 121 R1..804 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5%
R026 N/A R1..805 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5%
R027 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R1..806 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5%
R028 N/A R1..807 8230 5101 04 ST, carbon, 1/15W, 100kΩ, 5%
R029 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5% R1..808 8230 5101 04 ST, carbon, 1/15W, 100kΩ, 5%
R031 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R111~411 N/A
R032, 033 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% R511~811 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5%
R034 N/A R911~1211 N/A
R036 8230 5100 00 ST, carbon, 1/15W, 0Ω, 5% R13..1611 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5%
R037 N/A R112~412 N/A
R038 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R512~812 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5%
R039 N/A R912~1212 N/A
R040 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5% R13..1612 8230 5101 12 ST, carbon, 1/15W, 1.1kΩ, 5%
R042~045 N/A R113~413 N/A
R046 8230 5103 32 ST, carbon, 1/15W, 3.3kΩ, 5% R513~813 8230 5108 21 ST, carbon, 1/15W, 820Ω, 5%
R047 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 R913~1213 N/A
R050 8230 5105 62 ST, carbon, 1/15W, 5.6kΩ, 5% R514~814 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5%
R051~055 N/A R914~1214 N/A
R056 8230 5104 72 ST, carbon, 1/15W, 4.7kΩ, 5% R13..1614 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5%
R057 N/A R115~415 N/A
R058 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% R515~815 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5%
R062 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R116~416 N/A
R063 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% R516~816 8230 5108 21 ST, carbon, 1/15W, 820Ω, 5%
R067 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% R13..1616 8230 5108 21 ST, carbon, 1/15W, 820Ω, 5%
R068 8230 5081 01 ST, array, 100Ω x 4, 5%, CN1J4 R117~417 N/A
R069 N/A R517~817 8230 5104 73 ST, carbon, 1/15W, 47kΩ, 5%
R071 8230 5081 01 ST, array, 100Ω x 4, 5%, CN1J4 R13..1617 8230 5104 73 ST, carbon, 1/15W, 47kΩ, 5%
R072 N/A R118~418 N/A
R073 8230 5101 03 ST, carbon, 1/15W, 10kΩ 5% R518~818 8230 5001 01 ST, carbon, 1/15W, 100Ω, 5%
45
D1624 / D824
R918~1218 N/A C056 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
R13..1618 8230 5001 01 ST, carbon, 1/15W, 100Ω, 5% C057, 058 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R
R1..431 8230 5101 00 ST, carbon, 1/15W, 10Ω, 5% C059 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
R1..432 8230 5101 00 ST, carbon, 1/15W, 10Ω, 5% C060 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
R1..433 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C061 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R141, 241 N/A C062~069 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
R341, 441 8230 5101 00 ST, carbon, 1/15W, 10Ω, 5% C070 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R541, 641 N/A C077 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R741, 841 8230 5101 00 ST, carbon, 1/15W, 10Ω, 5% C078 8232 3574 77 VT, ALU, 16V, 470µF, 20%, LXV, D10
R3001 8230 5101 52 ST, carbon, 1/15W, 1.5kΩ, 5% C079 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R3002 8230 5102 24 ST, carbon, 1/15W, 220kΩ, 5% C080 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
R3003 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C082, 083 8232 1421 07 VT, ALU, 10V, 100µF, 20%, SME-VB
R3004 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 C084 8232 1431 07 VT, ALU, 16V, 100µF, 20%, SME-VB
R3005 8230 5100 00 ST, carbon, 1/15W, 0Ω, 5% C086 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
R3006 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C087 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
R3007 8230 5105 62 ST, carbon, 1/15W, 5.6kΩ, 5% C088 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R3008 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5% C089, 090 8232 3631 27 VT, ALU, 6.3V, 120µF, 20%, LXV, DS
R3009, 10 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C091, 092 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
R3011 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 C095 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
R3012 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% C096 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
R3013 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% C097 N/A
R3014, 15 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% C098 8232 3574 77 VT, ALU, 16V, 470µF, 20%, LXV, D10
R3016~24 N/A C099 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
R3025 8230 5100 00 ST, carbon, 1/15W, 0Ω, 5% C100 N/A
R3040 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% C101~801 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV
R3041 8230 5104 73 ST, carbon, 1/15W, 47kΩ, 5% C102~802 8233 5132 22 ST, CER, 50V, 0.0022µF, 5%, CC11R
R3042 N/A C103~803 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
R3043, 44 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% C104~804 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C106~806 N/A
CAPACITORs C107~807 N/A
ALU = Electrolytic type C111~411 N/A
CER = Ceramic type C511~811 8233 5133 32 ST, CER, 50V, 0.0033µF, 15%, CC11R
C001~009 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C13..1611 8233 5133 32 ST, CER, 50V, 0.0033µF, 15%, CC11R
C010 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C112~412 N/A
C011 8233 5131 01 ST, CER, 50V, 100µF, 15%, CC11R C512~812 8233 5131 02 ST, CER,50V, 0.001µF, 15%, CC11R
C013 N/A C13..1612 8233 5131 02 ST, CER,50V, 0.001µF, 15%, CC11R
C014~016 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C113~413 N/A
C017 8232 3574 77 VT, ALU, 16V, 470µF, 20%, LXV, D10 C513~813 8233 5131 02 ST, CER,50V, 0.001µF, 15%, CC11R
C019 8232 3631 27 VT, ALU, 6.3V, 120µF, 20%, LXV, DS C13..1613 8233 5131 02 ST, CER,50V, 0.001µF, 15%, CC11R
C028 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R C514~814 8232 1431 07 VT, ALU, 16V, 100µF, 20%, SME-VB
C033 8232 1424 77 VT, ALU, 10V, 470µF, 20%, SME-VB C13..1614 8232 1431 07 VT, ALU, 16V, 100µF, 20%, SME-VB
C034~044 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C115, 116 N/A
C045 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C1..431 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C046 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R C1..432 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
C047, 048 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C1..433 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C049, 050 8232 1441 07 VT, ALU, 25V, 100µF, 20%, SME-VB C1..434 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
C051, 052 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C1..435 8233 5172 24 ST, CER, 16V, 0.22µF, 20%, KC11E
C053 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C1..436 8233 5172 24 ST, CER, 16V, 0.22µF, 20%, KC11E
C054 8232 3711 87 VT, ALU, 16V, 180µF, 20%, LXV, D6.3 C1..437 8232 1431 06 VT, ALU, 16V, 10µF, 20%,SME-VB
46
D1624 / D824
C1..438 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R C3057 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C1..439 8232 1431 06 VT, ALU, 16V, 10µF, 20%,SME-VB C3058~60 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C1..440 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C3061 8233 5164 74 ST, CER, 16V, 0.47µF, 20%, KC20E
C141, 241 N/A C3062 8233 5121 50 ST, CER, 50V, 15pF, 5%, CC11SL
C341, 441 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C3063 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C541, 641 N/A C3064 8233 5131 01 ST, CER, 50V, 100pF, 15%, CC11R
C741, 841 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C3065 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
C142, 242 N/A C3066~68 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C342, 442 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C3069 8233 5131 01 ST, CER, 50V, 100pF, 15%, CC11R
C542, 642 N/A C3070 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C742, 842 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C3071 8233 5131 01 ST, CER, 50V, 100pF, 15%, CC11R
C143, 243 N/A C3072 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C343, 443 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB C3073 8233 5124 70 ST, CER, 50V, 47pF, 5%, CC11SL
C543, 643 N/A C3074~97 N/A
C743, 843 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB C3098, 99 8233 5123 30 ST, CER, 50V, 33pF, 5%, CC11SL
C144, 244 N/A C3100, 01 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R
C344, 444 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C3102 N/A
C744, 844 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F C3116, 17 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C346, 446 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB C3129, 30 N/A
C546, 646 N/A
C746, 846 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB MISCELLANEOUS
C147, 247 N/A Ref. No. Part No. Description
C347, 447 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R E2501 N/A (TP001)
C547, 647 N/A E2502 N/A (TP002)
C315, 316 N/A E2504 N/A (TP004)
C515, 516 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R E2505 8276 0010 00 Pin, header (TP005)
C715, 716 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R E2506 8276 0010 00 Pin, header (TP006)
C915, 916 N/A E2507 N/A (TP007)
C1115, 16 N/A E2508 N/A (TP008)
C3001 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB E2511 N/A (TP011)
C3002~04 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R E2512 N/A (TP012)
C3005 8233 5164 74 ST, CER, 16V, 0.47µF, 20%, KC20E E2515 8239 1200 00 Battery, 3V, CR2032
C3006 8233 5121 50 ST, CER, 50V, 15pF, 5%, CC11SL E2516 8239 1210 00 Holder, battery, BCR20H4
C3007, 08 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R J001 8245 0530 05 Connector, PI, jack, 8263, 5P, WHT
C3009 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J002 8245 1711 04 Connector, PI, jack, 8283, 4P, WHT
C3010~14 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R J003 N/A
C3015 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J004 8245 2720 25 Connector, PI, jack, FPC, 25P
C3016~19 8233 5122 20 ST, CER, 50V, 22pF, 5%, CC11SL J005 8245 3220 50 Connecotr, PI, header, 50P, P2.0, 9210B
C3020..30 N/A J006 8245 1711 07 Connector, PI, jack, 8283, 7P, WHT
C3031, 32 8233 5123 30 ST, CER, 50V, 33pF, 5%, CC11SL J007 8245 1711 09 Connector, PI, jack, 8283, 9P, WHT
C3033~35 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R J008, 009 N/A
C3036, 37 8233 5121 80 ST, CER, 50V, 18pF, 5%, CC11SL J010 8245 5470 02 Connector, PI, jack, PH, 2P
C3038 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R J011 8245 5530 10 Connector, opt, GPIF37R1
C3039~42 8233 5134 71 ST, CER, 50V, 470pF, 15%, CC11R J012 8245 5520 10 Connector, opt, GPIF38T2
C3043 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J013 8245 2720 17 Connector, PI, jack, FPC 17P
C3044~48 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R J014 N/A
C3050 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J016 8245 3290 50 Connector, PL, D-SUB, 50P, P1.27,
C3051~53 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R ECI2
C3054 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J018 8245 2720 25 Connector, PI, jack, FPC, 25P
C3055, 56 8233 5131 03 ST, CER, 50V, 0.01µF, 15%, CC11R J020, 021 N/A
47
D1624 / D824
Ref. No. Part No. Description • Connect PCB assy (P/N: 8274221000)
Refer to the D1624 Parts List page 41.
J101, 102 8245 2860 00 Connector, PL, jack, RCA, 4P,
YKC21-3077
J103 8245 2720 17 Connector, PI, jack, FPC 17P
J104 8245 2720 08 Connector, PI, jack, FPC 8P • MIDI PCB assy (P/N: 8274222000)
J106, 107 N/A
J108, 109 8245 2860 00 Connector, PL , jack, RCA, 4P,
YKC21-3077
L001, 002 8242 5025 60 Core, ST, CDRH104, 56µH • Power PCB assy (P/N: 8274223000)
L003, 004 N/A Refer to the D1624 Parts List page 41 ~ 42.
L005 8242 2640 01 Coil, DC-DC, R17, 256µH
L007 N/A
L008, 009 8242 5000 21 Coil, ST, 22µH, LFC32
L010 N/A • Power SW PCB assy (P/N: 8274224000)
L1..801 8242 5041 21 Filter, ST, EMI, EXC3BP, 121
L102~402 N/A Refer to the D1624 Parts List page 42.
L502~802 8242 5041 21 Filter, ST, EMI, EXC3BP, 121
L902~1202 N/A
L13..1602 8242 5041 21 Filter, ST, EMI, EXC3BP, 121 • Regulator PCB assy (P/N: 8274225000)
W001 8276 7360 40 Cable assy, 12P, 8263,
WHT-5395, #22, L400
W002 8277 3184 30 Cable assy, 4P, 5395-CNC, L300
W003 8245 3590 02 Pin header, 2P, P2.0, 9210B-1
W004 N/A
• Display PCB assy (P/N: 8274226000)
W005 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5%
Refer to the D1624 Parts List page 42 ~ 43.
W011 N/A
W012 8277 4771 22 Cable assy, FC, 40P, /B-/F, L220,
core, reverse
W013 8245 3590 02 Pin header, 2P, P2.0, 9210B-1
• RS422 assy (P/N: 8274257000)
W301 N/A
W302 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5% Refer to the D1624 Parts List page 43.
W401 N/A
W402 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5%
W503, 603 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5%
W701 N/A • WORD I/O assy (P/N: 8274258000)
W702, 703 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5% Refer to the D1624 Parts List page 43.
W801 N/A
W802, 803 8230 5100 00 Resistor, ST, carbon, 1/15W, 0Ω, 5%
X001 8256 1700 01 Resonator, ST, XTL, 22.579MHz,
Abbreviation
FUP-FBB3A
S: Surface mount
X002 8256 1700 02 Resonator, ST, XTL, 24.576MHz,
V: Vertical mount
FUP-FBB3A
P: Penetrate mount
X003 8256 1790 04 Resonator, PT, CER, 11.00MHz, F5,
T: Taping device
EF0EN
X004 8256 1850 00 Resonator, ST, XTL, 32.768KHz, F: Forming device
DMX-26 L: L form
X005 8256 1710 01 Resonator, PT, CER, 20.00MHz, KBR I: I form
X006 8256 1850 00 Resonator, ST, XTL, 32.768KHz, QFP: Quad Flat Package
DMX-26 TSOP: Thin Small Outline Package
TSSOP: Thin Shrink Small Outlint Package
DIP: Dual In-line Package
220: TO-220 type
DG: Digital
AN: Analog
48
TC OUT TC IN OFF ON OFF ON
L8 VIDEO VIDEO
TC OUT R70 J4 J3 THRU IN
R32 J6 J5 S1
L9 WORD
R18
R19
S1
R26
R21
R16
OUT IN 1
C30
R3 1
R9
C86
L1
D7
C18
C22
C59 U8 U13 C19
C21
R2 C17
R4 SN75124 HC04
C32
3 R17 D5
C16 1 R20 R22
R75 C85 D3 C31 9 8 1 1 C23
U9
R51
C60
D4
5
C24
C42 U11
L10
R27
C34
R69 SN75123 C25
D8
C84 C29 U10
R5
U5
D6
R23
C9 D2 D1 NJM2207
L4
R31
R30
C62 C61 C46
1
R28 9 1 8 5 NJM592
C7 D14 D15 D12 A+5 C12
C26
R10 R12 R11 C15
R50
22 12 U20 C44 C43
L3
C47 C48
R8
R6
TC9246
C20
1 23 11
C11
C8 R25 C63 R24
R15
U4 C45
R52
R53
R1 U24 U27 U26 9
C93 1 19 1 8 1
L5
2 TCR
R41
L2
HC04 50 R55 R43 TP3 C91 R65 C65
EXT
R33
C49
20 64 U12 R54 3130

28MHz U21
U3 8 51 R56 C64 TC9246
C90
HC74
C76
C27
C78 R48 R49R59 R58 C68
C77
33 1
C40
TCG
C79
5 C83 R42 U15 9
34 44 1 1
C50
L6
U6 VCO
C94
C52
U29 U28
C35
R57
C41
R34
NJM4580
C28
C89 R61 C88R63 R64 C92 31
U16
C95
R73 U19 50 30 R44
CLK GR 5 NJM2115 51 C51
R74
C81
32
C33
C36
R72 52
R47
31
R76
C80
U22 U23
33 51 TP1:28MHz R67
C14 C57 8
R66
R68
U1
R13
D11
C10
U14 TP2
R46
R71 C5 78M05 C37 R45
U18
C38 R60 R35 1
C55
U17
C82
R38 1 HCU04 4.8MHz
R29 80 81 100 U25 CLK GR
D10
C69 C58 D3
R14
R39 C4 1 HCU04
D9
C2
R36
R37
C73
5
C6 8
C72
R40
C87
W1 8
C71
C66 C56
C53
U7
C54
HC00 X1 W2 R62 1
MODEL 8345 PCB ASSEMBLIES
2 24
C1
W3
C7 J1 80
1 1 1 25 C75 C74 81 100
C70 X2 C67 C13
C3 U2 C39
1
79M05 PCB. TC/SYNC. CARD. 8345
L7 D+5
A B C 8251961 201 D E F G
A B C D E F G
1
1 25
A–5
C3
C70
L7
1 16MHz
C7
C13
W3
J1
C6 2 24 X2
AGND
5
X1
C4
R39
A+5
D10
C38
28MHz D+5
R38
D9
TP1
C5
C14
D11
D13
28MHz
C51
GND OUT
EXT
28MHz U15 4.8MHz
L6
EXT
TP3 TP2
VIN VCC
L2
L5
2
A+5
L3
4.8MHz
C45
C48
A+5
C15
AGND 9
C12
L4
A–5
C46
C9
L10
C84
C25
9
A–5
C16
H J8 C S J7
L1
3 C 1
C59
C19
G G H WORD VIDEO
1
OUT L9 S1 IN S2
S OUT IN THRU IN
OUT TC OUT
TC TC L8 J4 J3 J6 J5
D1624 / D824
49
D1624 / D824
8345 Parts List

• 8345 PCB assy
N/A PCB assy, 8345 R010 8230 5001 51 ST, carbon, 1/10W, 150Ω, 5%
B101 8251 9612 01 Plain PCB, 8345 R011, 012 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5%
R013, 014 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5%
ICs R015, 016 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
Ref. No. Part No. Description R017 8230 5007 50 ST, carbon, 1/10W, 75Ω, 5%
U001 8236 5403 01 ST, AN, regulator, NJM78M05DLA R018 8230 5001 00 ST, carbon, 1/10W, 10Ω, 5%
U002 8236 5404 01 ST, AN, regulator, NJM78M05DLA R019, 020 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5%
U003 8236 0619 00 QFP, DG, gate array, TCG R021 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5%
U004 8236 0762 00 QFP, DG, gate array, TCR R022, 023 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
U005 8236 5055 00 ST, AN, comparator, NJM311M R024 8230 5003 32 ST, carbon, 1/10W, 3.3kΩ, 5%
U006 8236 5031 00 ST, AN, op amp, NJM4580E R025 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U007 8236 5600 00 ST, DG, 74HC00 R026 8230 5007 50 ST, carbon, 1/10W, 75Ω, 5%
U008 8236 0185 00 DIP, DG, TTL, SN75124 R027, 028 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
U009 8236 0793 00 DG, line IF, SN75123 R029~032 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U010 8236 7210 00 ST, AN, NJM592M R033 8230 5002 22 ST, carbon, 1/10W, 2.2kΩ, 5%
U011 8234 7211 00 ST, AN, NJM2207M R034 8230 5006 81 ST, carbon, 1/10W, 680Ω, 5%
U012 8236 5600 74 ST, DG, 74HC74 R035 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
U013 8236 5600 14 ST, DG, 74HC14 R036 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U014 8236 5610 04 ST, DG, 74HCU04 R037 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
U015 8236 1780 00 Module, VCO, 28.224MHz, F100 R038, 039 8230 4001 00 H, metal, 1W, 10Ω, 5%
U016, 017 8236 8200 00 QFP, DG, gate array, µPD65640GF- R040 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
215-3BNEC, NEWCLK R041 8230 5001 02 ST, carbon, 1/10W, 1kΩ, 5%
U018 8236 5701 01 ST, DG, driver, DTC114EK R042 8230 5001 52 ST, carbon, 1/10W, 1.5kΩ, 5%
U019 8236 5050 11 ST, AN, op amp, NJM2115M (TEI) R043, 044 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U020, 021 8236 5034 00 ST, DG, VCO, TC9246F R045, 046 8230 5002 71 ST, carbon, 1/10W, 270Ω, 5%
U023 8236 5701 01 ST, DG, driver, DTC114EK R047 N/A
U024 8236 5600 04 ST, DG, 74HC04 R048, 049 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U025 8236 5610 04 ST, DG, 74HCU04 R050~053 8230 5001 52 ST, carbon, 1/10W, 1.5kΩ, 5%
U026 8236 5701 01 ST, DG, driver, DTC114EK R054 8230 5002 24 ST, carbon, 1/10W, 220kΩ, 5%
U027 8236 5704 01 ST, DG, driver, DTA114EK R055 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
U028 8236 5701 01 ST, DG, driver, DTC114EK R056 8230 5002 24 ST, carbon, 1/10W, 220kΩ, 5%
U029 8236 5704 01 ST, DG, driver, DTA114EK R057 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
R058, 059 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5%
DIODEs R060 8230 5003 31 ST, carbon, 1/10W, 330Ω, 5%
Ref. No. Part No. Description R061 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
D001~008 8234 5028 00 ST, DAN202K R062 N/A
D009, 010 8234 2024 01 Opt., LED, red, SLR-40VR R063 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
D011~013 N/A R064 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5%
D014, 015 8234 5028 00 ST, DAN202K R065 N/A
R066, 067 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
RESISTORs R068 8230 5001 01 ST, carbon, 1/10W, 100Ω, 5%
Ref. No. Part No. Description R069 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
R001 8230 5002 72 ST, carbon, 1/10W, 2.7kΩ, 5% R070 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5%
R004 8230 5001 05 ST, carbon, 1/10W, 1MΩ, 5% R073 8230 5002 02 ST, carbon, 1/10W, 2kΩ, 5%
R005, 006 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% R074 8230 5001 51 ST, carbon, 1/10W, 150Ω, 5%
R009 8230 5004 73 ST, carbon, 1/10W, 47kΩ, 5%
50
D1624 / D824

ALU = Electrolytic type C090 8233 5041 03 ST, CER, 25V, 0.01µF, 10%,
CER = Ceramic type CC20R
C001, 002 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R C095 8233 5002 22 ST, CER, 50V, 0.0022µF, 5%,
C003 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB CC20SL
C004 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C005, 006 8232 1461 05 VT, ALU, 50V, 1µF, 20%, SME-VB MISCELLANEOUS
C007 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB Ref. No. Part No. Description
C008 8233 5105 62 ST, CER, 50V, 5600pF, 10%, CC20B J001 8245 2720 25 Connector, PI, jack, FPC, 25P
C009 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB J002 N/A
C010, 011 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R J003~006 8245 3000 00 Connector, jack, BNC, 01K0083
C012~016 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J007 8245 2680 02 Connector, PL, jack, XLR31,
C017, 018 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL NC3FAH2
C019 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB J008 8245 2670 02 Connector, PL, jack, XLR31,
C020 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R NC3MAH
C021, 022 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL L001 8242 1860 13 Filter, T, EMI, LFW7B-M3R2T
C023, 024 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R L002~006 8242 1962 23 Coil, PVT, 22µH, 5%, LF5.0F
C025 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB L007 8242 1350 01 Coil, 50µH, SKP-2-30
C026~033 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R L008~010 8242 1860 13 Filter, T, EMI, LFW7B-M3R2T
C034 8233 5002 21 ST, CER, 50V, 220pF, 5%, CC20SL S001, 002 8253 6550 04 SW, slide, 1-2, non shortening,
C035, 036 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL SSSF1
C037 8233 5005 60 ST, CER, 50V, 56pF, 5%, CC20SL TP001~003 N/A
C038 8233 5003 00 ST, CER, 50V, 30pF, 5%, CC20SL
C039 8233 5002 20 ST, CER, 50V, 22pF, 5%, CC20SL
C040~044 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C045, 046 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB ACCESSORIES
C047 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R Ref. No. Part No. Description
C048 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB Y101 8221 2150 00 Bracket, 8345
C049, 050 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R Y102 8288 4010 00 Owner’s manual, 8345, multi
C051 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB Y103 8216 6510 00 Shield, EMI, 8345
C052 8233 5021 04 ST, CER, 50V, 0.1µF, +80-20, CC20R Y104 8218 7610 00 Label, TC IN, 8345
C053~058 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R W101 8276 8404 30 Cable, flat, FFC, 25P, L300
C059 8232 1431 06 VT, ALU, 16V, 10µF, 20%, SME-VB
C060 8233 5001 50 ST, CER, 50V, 15pF, 5%, CC20SL
C061 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
Abbreviation
C062 8233 5094 74 ST, CER, 25V, 0.47µF, 20%, KC30E
S: Surface mount
C063 8233 5001 50 ST, CER, 50V, 15pF, 5%, CC20SL
P: Penetrate mount
C064 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
T: Taping device
C065 8233 5094 74 ST, CER, 25V, 0.47µF, 20%, KC30E
F: Forming device
C066, 067 8233 5004 71 ST, CER, 50V, 470pF, 5%, CC20SL
L: L form
C068 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
I: I form
C069 8233 5002 20 ST, CER, 50V, 22pF, 5%, CC20SL
V: Vertical mount
C070 8232 1431 07 VT, ALU, 16V, 100µF, 20%, SME-
QFP: Quad Flat Package
VB
DIP: Dual In-line Package
C071, 072 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
220: TO-220 type
C073~075 N/A
DG: Digital
C076~082 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
AN: Analog
C083 8233 5105 62 ST, CER, 50V, 5600pF, 10%, CC20B
C084 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
C085, 086 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL
C087 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C088, 089 8233 5004 71 ST, CER, 50V, 470pF, 5%, CC20SL
51
D1624 / D824
MODEL 5042/5043 PCB ASSEMBLIES

C106 W101 R104 R103
R102
C105
C105 C103
C104 C204 R206 R304 C304 C404 R406 R504 C504 C604 R606 R704 C704
C102
1
R101
C102
U1 R107 R106 R105
C1
C2
C101
R207 R204 R205 R202
C205 W201 W301 C305

5 C101
C203
C205
C202
17
R201
16
17
L101
16
R203
C202
I
L101 C206
C801
I
C306 R302 L102
13
L102
R303
C201
13
25
C305
TO MAIN
25
L201
C302
TO MAIN
L201 R301
C303
1
J4
J4
C302 L202
C301
L202
R402
U2 R307 R306 R305
C3
C4
L301 C301 L301
R407 R404 R405
C403
C405 W401
C402
5 R401
L302
C405
L302
C402
R403
C401
L401
BAL IN 1-8CH
2
L401 C406 R502
1
C401
R503 C503 C603 R603

L402 C506 L402
J1
W501
C502
R501
C505
L501
L501 C505 C502
1
C501
L502 R602 L502

U3 C507 R506 R505 C501
C5
C6
L601
C602
L601
R607 R604 R605 R601
H
5
C602 L602
H
C605
L602
C801
C605 R702
L701 L701
C606 W601 C601
C702
L702 C706 R701 L702

14
W701
14
C702
1
C703
C705
L801
C701
L801
C705
1
1 R802
C701 L802
L802 R707
C802
R801
C803
U4 C707 R706 R705
C7
C8
R807 R804 R805 C802

C801
5
J1
BAL IN
1-8CH
5040 & 5041
C805
C9 C805
C801
C9
C806 W801
C804
C10 R806 R803
1
C10
1
G
F
TO MAIN
TO MAIN
R916
U903
W1
W1
C46 R909
C46
L903
C29
C913
5 R912 L903
R914
R910 C911 R915

C913
C30
U902
C909
U901
C45 C907
C907
4
4
L904
C45
C912
C908 C910
R913 1 L904
R908 R911
U1003
R1016 C912
C31
L1003 5 R1009 R1012

R914
C1013
L1003
R1010 C1011
C32
C1009
U1002
U1001
R1015
C1007
C1007 C1013
(50401 only)
L1004 C1010
C1008
C1012
TO MAIN
R1013
R1008 R1011 L1004
W1
U1103
C36
R1116 C1012
5 R1109 R1112
1 J6
R1114
L1103
C1113
R1110 C1111 L1103

C1109
C34
U1101
C1107
C1107 R1115
U1102
2
13
1
13
C1110 C1113
TO MAIN
C1108
2
25
L1104 1
25
C1112
R1113
R1108 R1111 L1104
C35
R1216
U1203
TO MAIN
5 R1209 R1212 C1112

7
C1213
R1214
J5
L1203
7
R1210 C1211
C36
C1209
U1201
C1207
L1203
8
C1207
C1210 C1213 R1215
U1202
1 C1208
BAL OUT 9-13CH

R1208
C1212
L1204
R1213 R1211
17
L1204
16
17
C37
R1309 R1312 R1316

16
5
C1212
U1303
J2
R1314
R1310 C1311
C1309
C38
C1313
L1303 U1301
C1307
C1307
L1303
TO MAIN
C1308 C1310 C1313 R1315
U1302
TO MAIN
1
R1308 R1311
J5
L1304 R1313
C1312
C39
5 R1409 R1412 R1416 L1304

C1312
U1403
R1414
R1410 C1411
C1409
C40
U1401
C1413
C1407
C1407
E
L1403
E
C1410 R1415 L1403

1 C1408
C1413
2
U1402
R1408 R1411
2
14
14
C1412
R1413
1
L404
C41
R1509 R1512
1
5
R1516 L1404
J5
(5041 only)
C1412
U1503
R1510 C1511
R1514
C1509
C42
U801
C1507
C1507
C1513
L1503
C1508 C1510 R1515
1 L1503
R1508 R1511 C1513
J2
U1502
5041 9-16CH
5040 1-8CH
C1512
R813
C43
L1504
5 R1609 R1612
R1616 L1504
BAL OUT
C1512
C1609
R1610 C1611
C44
R1614
U1603
U801
C1607
C1507
C1613
L1603
1 C1608 C1610
R1608 R1615 L1603
D
R1611 C1613
D
U1602
R1613
C1612
C27 C28
PCB BALANCE I/O. 5040/5041
C28
C27
L1604
L1604
C1612
R116
C11
U103
L104 5 R109 R112

R114
C113
R110 C111 L103

C12
C109
U101
C107
C107
R115
U102
1 C108 C110 C113

L104 R113 R108 R111
C112
L104
C13
R209 R212 R216

U203
5
L203 C112
R214
R210 C211
C14
C213
C209
U201
C207 L203
C207
R215
C210
U202
1 C208 C213
R213 R208 R211
C212
L204
L204
C15
R316
C
5 R309 R312
13
C212
U303
PCB BALANCE I/O. 5040/5041
13
R314
25
L303 R310 C311

C313
25
C309
C16
U301
C307
C307
R315 L303
1 C308 C310 C313
U302
R313 R308 R311

C312
L304
C17
5 R409 R412 R416 L304

C312
U403
R410 C411
R414
C413
C18
C409
L403
BAL OUT 1-8CH
U401
C407
C407
C410 R415 L403

1 C408 C413
U402
R813 R408 R411

J3
C412
L404
C19
5 R509 R512 R516 L404

5251958 101
C412
U503
R514
R510 C511
C509
C20
C513
L504 U501
C507
C507
R515 L503
1 C508 C510 C513
U502
R508 R511
B
R513
C512
L504
R616
C21
R609 R612 L504

B
5
C512
U603
R614
R610 C611
C609
C613
C22
L603 U601
C607
C607
14
R615 L603
14
C610 C613
1
C608
U602
1
1
R613 R708 R611

C612
L604
C23
5 R709 R712 R716 L604

C612
U703
R714
R710 C711
C709
C24
L703 U701
C707
C713
C707
BAL OUT 1-8CH
J3
C710 R715 L703

1 C708 C613
U702
R708 R711
5041 only
C712
L704 R713
R816
C25
5 R809 R812 L704

C712
U803
R810 C811
R814
C809
C813
A
C26
L803 U801
C807
C807
R815 L803
C808 C810 C813
U802
1
R808 R811
C812
L804 R813
L804
C812
52
D1624 / D824
5043 Parts List

• BALANCE I/O PCB assy
N/A PCB assy, Balance I/O, 5040 C0111~1611 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
B101 8251 9581 01 Plain PCB, Balance I/O, 5040 C0112~1612 8232 1422 27 VT, ALU, 10V, 220µF, 20%, SME-VB
C0113~1613 8232 1422 27 VT, ALU, 10V, 220µF, 20%, SME-VB
ICs
Ref. No. Part No. Description MISCELLANEOUS
U0001~0004 8236 5412 00 ST, AN, op amp, NJM4565M Ref. No. Part No. Description
U0101~1601 8236 5031 00 ST, AN, op amp, NJM4580E J0001~0003 8245 3120 05 Connector, PL, jack, D-SUB, 25P,
U0102~1602 8236 5702 01 ST, DG, driver, DTC314TK 70057-025, EMIFIL
U0103~1603 8236 5702 01 ST, DG, driver, DTC314TK J0004, 0005 8245 2720 17 Connector, PI, jack, FPC, 17P
L0101~0801 N/A
RESISTORs L0102~0802 N/A
Ref. No. Part No. Description L0103~1603 N/A
R0101~0801 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% L0104~1604 N/A
R0102~0802 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% W0001 8276 7280 30 Cable assy, 4P, 8263WHT-5395,
R0103~0803 8230 5002 23 ST, carbon, 1/10W, 22kΩ, 5% #22, L300
R0104~0804 8230 5002 23 ST, carbon, 1/10W, 22kΩ, 5% W0002~0007 N/A
R0105~0805 8230 5005 62 ST, carbon, 1/10W, 5.6kΩ, 5% W0101~0801 8230 5000 00 Resistor, ST, carbon, 1/10W, 0Ω
R0106~0806 8230 5005 62 ST, carbon, 1/10W, 5.6kΩ, 5%
R0107~0807 N/A
R0108~1608 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5%
ACCESSORIES
R0109~1609 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5%
R0110~1610 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5%
Y103 8288 3941 00 Owner’s manual, 5040/5041, multi
R0111~1611 8230 5009 12 ST, carbon, 1/10W, 9.1kΩ, 5%
W001 8276 8387 25 Cable, flat, FFC, 8P, L250
R0112~1612 8230 5009 12 ST, carbon, 1/10W, 9.1kΩ, 5%
R0113~1613 8230 5021 01 ST, carbon, 1/4W, 100Ω, 5%
R0114~1614 8230 5021 01 ST, carbon, 1/4W, 100Ω, 5%
R0115~1615 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5%
R0116~1616 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5%
5042 Parts List

CAPACITORs
• BALANCE I/O PCB assy
CER = Ceramic type Ref. No. Part No. Description
PES = Mylar type N/A PCB assy, Balance I/O, 5040
Ref. No. Part No. Description B101 8251 9581 01 Plain PCB, Balance I/O, 5040
C0001~0008 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C0009, 0010 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB ICs
C0011~0026 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R Ref. No. Part No. Description
C0027, 0028 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB U0001~0004 8236 5412 00 ST, AN, op amp, NJM4565M
C0029~0044 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R U0101~0801 N/A
C0045, 0046 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB U0102~0802 N/A
C0101~0801 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB U0103~0803 N/A
C0102~0802 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB U0901~1601 8236 5031 00 ST, AN, op amp, NJM4580E
C0103~0803 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL U0902~1602 8236 5702 01 ST, DG, driver, DTC314TK
C0104~0804 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL U0903~1603 8236 5702 01 ST, DG, driver, DTC314TK
C0105~0805 N/A
C0106~0806 N/A RESISTORs
C0107~1607 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB Ref. No. Part No. Description
C0108~1608 N/A R0101~0801 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5%
C0109~1609 N/A R0102~0802 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5%
C0110~1610 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL R0103~0803 8230 5002 23 ST, carbon, 1/10W, 22kΩ, 5%
53
D1624 / D824
R0104~0804 8230 5002 23 ST, carbon, 1/10W, 22kΩ, 5% C0912~1612 8232 1422 27 VT, ALU, 10V, 220µF, 20%, SME-VB
R0105~0805 8230 5005 62 ST, carbon, 1/10W, 5.6kΩ, 5% C0913~1613 8232 1422 27 VT, ALU, 10V, 220µF, 20%, SME-VB
R0106~0806 8230 5005 62 ST, carbon, 1/10W, 5.6kΩ, 5% C0110~1610 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
R0107~0807 N/A C0111~1611 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
R0108~0808 N/A C0112~1612 8232 1422 27 VT, ALU, 10V, 220µF, 20%, SME-VB
R0109~0809 N/A C0113~1613 8232 1422 27 VT, ALU, 10V, 220µF, 20%, SME-VB
R0110~0810 N/A
R0111~0811 N/A MISCELLANEOUS
R0112~0812 N/A Ref. No. Part No. Description
R0113~0813 N/A J0001, 0002 8245 3120 05 Connector, PL, jack, D-SUB, 25P,
R0114~0814 N/A 70057-025, EMIFIL
R0115~0815 N/A J0003 N/A
R0116~0816 N/A J0004 8245 2720 17 Connector, PI, jack, FPC, 17P
R0908~1608 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5% J0005 8245 2720 08 Connector, PI, jack, FPC, 8P
R0909~1609 8230 5004 72 ST, carbon, 1/10W, 4.7kΩ, 5% L0101~0801 N/A
R0910~1610 8230 5001 03 ST, carbon, 1/10W, 10kΩ, 5% L0102~0802 N/A
R0913~1613 8230 5021 01 ST, carbon, 1/4W, 100Ω, 5% W0001 8276 7280 30 Cable assy, 4P, 8263WHT-5395,
R0914~1614 8230 5021 01 ST, carbon, 1/4W, 100Ω, 5% #22, L300
R0915~1615 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% W0002~0007 N/A
R0916~1616 8230 5001 04 ST, carbon, 1/10W, 100kΩ, 5% W0101~0801 8230 5000 00 Resistor, ST, carbon, 1/10W, 0Ω
CAPACITORs ACCESSORIES
ALU = Electrolytic type Ref. No. Part No. Description
CER = Ceramic type Y102 8221 2060 00 Bracket, B, 5041
Ref. No. Part No. Description Y103 8288 3941 00 Owner’s manual, 5040/5041, multi
C0001~0008 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, Y209 8221 2091 00 Panel, blank, S
CC20R W001 8276 8387 25 Cable, flat, FFC, 8P, L250
C0009, 0010 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB W002 8276 8396 15 Cable, flat, FFC, 17P, L150
C0011~0026 N/A
C0027, 0028 N/A
C0029~0044 8233 5041 03 ST, CER, 25V, 0.01µF, 10%, CC20R
C0045, 0046 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
C0101~0801 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
C0102~0802 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
C0103~0803 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL
C0104~0804 8233 5004 70 ST, CER, 50V, 47pF, 5%, CC20SL
C0105~0805 N/A
C0106~0806 N/A
Abbreviation
C0107~0807 N/A
S: Surface mount
C0108~0808 N/A
P: Penetrate mount
C0109~0809 N/A
T: Taping device
C0110~0810 N/A
F: Forming device
C0111~0811 N/A
L: L form
C0112~0812 N/A
I: I form
C0113~0813 N/A
V: Vertical mount
C0907~1607 8232 1434 76 VT, ALU, 16V, 47µF, 20%, SME-VB
DG: Digital
C0108~1608 N/A
AN: Analog
C0109~1609 N/A
C0910~1610 8233 5001 01 ST, CER, 50V, 100pF, 5%,
CC20SL
C0911~1611 8233 5001 01 ST, CER, 50V, 100pF, 5%, CC20SL
54
J2
24 2 2
3 1 3 1 J2
25 1 1
9
1 2 3 4
S2 S1
1
S1 S2
D203
D201
C1 C2
U7
24 2 2
D202
J3
D204
1 R251
25 1
9
J3
U2
U1
R8
D103
R151
25
D102
D101
C8
+
D104
50 C101 50
C301
C102 + C302
50 50 C19 +
R310
C404 C204
C207
C153
J1
R155
1
1
1
C251 C151 C154
R210
14
2
C205
30
2
30
C253
30
R253 R153
R255 C252 C152
U401
R254 R154
C303
C254
C451 C351
U201 30
C353
R410
J1
R353
60
R453
60
20
20
C453 R110
C407 C405
20
20
C452 R355
R455 R309 C352
C454 C103
R454 R354 C354
C403
C307
C257 C157 C159

C259 R256
R209
70
R156 R158
70
10
10
C107
R258
10
10
C258
R109 C305 C158
C260 R257 R157 C160
C203
C457 C357
R409
C359
16
R456 C105 R356 R358
17
C459
17
16
1
1
80
80
1
1
80
80
R458 C458 R7 C358
TP401
C460 + C360
R6
R457 C11 R357
MODEL 8350 PCB ASSEMBLIES
C26 + C20
U301
1
TP101
C402 C202 C104 100 100 C7
TP201 TP301
U101
100 100
C304
D301
D304
D302
303D J4
• Foil side of AES/EBU & PLL PCB assys

J4 C3 C23
L2
• Parts side of AES/EBU & PLL PCB assys
C24
U8
1
1
U10
8
1
8
U5
5 1
C12
R351 R451
C4
5
J5
R5
U9
U6
25
+
13
C25 5 1
1
9
1
1 R201 R301 R304
D401
D403
D402
5 R101R104 R204 R305
C6 W1
9 D404
R404
R202
U402 U202 W1 TP1

R401
C208
U302 U102 R4 U3
R105 R205
C14 + R302 R402 R405
R408
R102
C5 C108 C308 C408
C211 C411
C111
R303 C311R403
R108
C10 C18 R103 R203

C309
J5
C109 C209 C409
R308
R208
R2 C110 C210 C310 C410
C17 R206 R306 R406
R1 R3R106 R407
C15 R107 R207 R307
+ C21 C113 C115 C213 C215 C313 C315 C413 C415
+ + + + +
U4
+ + + + +
1
1
1
C22
C13
C414 C314 C214 C114 C16 C9 C112 C212 C312 C412
8251704000
L1 L101 L201 L301 L401

PCB,AES/EBU,8350
TP1
C31
C33
TP4
1
1
C34
TP3
TP5
R11
TP2
8
8
U11 U12
C32
1
1
C35 C36
U16
R12
8251998001
PCB,PLL,SUB
8
8
U13 U14
U15
D1624 / D824
55
D1624 / D824
8350 Parts List

• AES/EBU PCB assy
Ref. No. Part No. Description CAPACITORs
N/A PCB assy, AES/EBU, 8350 ALU = Electrolytic type
B101 8251 7040 00 Plain PCB, AES/EBU, 8350 CER = Ceramic type
ICs C001, 002 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
Ref. No. Part No. Description C003~005 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
U001 8236 5451 38 ST, TSSOP, 74VHC138 C006~008 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
U002 8236 5450 04 ST, TSSOP, 74VHC04 C009 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV
U003 8236 5034 00 ST, DG, VCO, TC9246F C010 8233 5121 50 ST, CER, 50V, 15pF, 5%, CC11SL
U004 8236 5403 01 ST, AN, regulator, L78M05T-TL C011, 012 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV
U005 8236 5450 32 ST, TSSOP, 74VHC32 C013, 014 8233 3221 07 ST, ALU, 100µF, 20%, MVY
U006, 007 8236 5426 00 ST, transceiver, SN75C1168NSR C015, 016 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
U008, 009 8236 5450 74 ST, TSSOP, 74VHC74 C017 8233 5164 74 ST, CER, 0.47µF, 20%, KC20E
U010 8236 5459 04 ST, TSSOP, 74VHCU04 C018 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
U101~401 8236 0850 00 QFP, DG, gate array, DIF C019~021 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV
U102~402 8236 5034 00 ST, DG, VCO, TC9246F C022 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
C023~025 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
DIODEs C026 8233 5123 90 ST, CER, 50V, 39pF, 5%, CC11SL
Ref. No. Part No. Description C101, 301 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV
D101~401 8234 5028 00 ST, DAN202K C102~402 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
D102~402 8234 5029 00 ST, DAP202K C103~403 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
D103~403 8234 5028 00 ST, DAN202K C104~404 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
D104~404 8234 5029 00 ST, DAP202K C105~405 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
C107~407 8233 5131 01 ST, CER, 50V, 100pF, 10%, CC11R
RESISTORs C108~408 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
Ref. No. Part No. Description C109~409 8233 5121 50 ST, CER, 50V, 15pF, 5%, CC11SL
R001 N/A C110~410 8233 5164 74 ST, CER, 16V, 0.47µF, 20%, KC20E
R002 8230 5102 24 ST, carbon, 1/15W, 220kΩ, 5% C111~411 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
R003 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C112~412 8233 0491 06 ST, ALU, 16V, 10µF, 20%, MV
R004 8242 5051 02 Filter, ST, EMI, EXC3BB, 102 C113~413 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
R005~007 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C114~414 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
R101~401 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C151~451 8233 5124 70 ST, CER, 50V, 47pF, 5%, CC11SL
R102~402 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5% C152~452 8233 5124 70 ST, CER, 50V, 47pF, 5%, CC11SL
R103~403 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C153~453 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
R104~404 8230 5104 72 ST, carbon, 1/15W, 4.7kΩ, 5% C154~454 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
R105~405 8230 5101 03 ST, carbon, 1/15W, 10kΩ, 5% C157~457 8233 5124 70 ST, CER, 50V, 47pF, 5%, CC11SL
R106~406 8230 5105 62 ST, carbon, 1/15W, 5.6kΩ, 5% C158~458 8233 5124 70 ST, CER, 50V, 47pF, 5%, CC11SL
R107~407 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% C159~459 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
R108~408 8230 5101 02 ST, carbon, 1/15W, 1kΩ, 5% C160~460 8233 5151 04 ST, CER, 25V, 0.1µF, +80, CC11F
R109~409 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5%
R110~410 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% MISCELLANEOUS
R151~451 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% Ref. No. Part No. Description
R153~453 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% J001 8245 2720 17 Connector, PI, jack, FPC, 17P
R154~454 8230 5101 01 ST, carbon, 1/15W, 100Ω, 5% J002, 003 8245 2720 25 Connector, PI, jack, FPC, 25P
R155~455 8230 5101 11 ST, carbon, 1/15W, 110Ω, 5% J004 8245 0530 05 Connector, PI, jack, 8263, 5P, WHT
R156~456 8230 5102 20 ST, carbon, 1/15W, 22Ω, 5% J005 8245 3120 05 Connector, PL, jack, D-SUB, 25P,
R157~457 8230 5102 20 ST, carbon, 1/15W, 22Ω, 5% 70057-025, EMIFIL
R158~458 8230 5103 31 ST, carbon, 1/15W, 330Ω, 5% L001 8242 5000 21 Coil, SVT, 22µH, LEC32
L002 8242 5025 60 Core, ST, CDRH104, 56µH
56
D1624 / D824

L101~401 8242 5000 21 Coil, SVT, 22µH, LEC32
S001, 002 8253 4570 02 SW, ST, slide, 1-3, non-shortening,
SSSS91, L4
W001 8276 7290 30 Cable assy, 5P, 8263WHT-5395,
#22, L300
• PLL SUB PCB assy

N/A PCB assy, PLL Sub, 8350
B101 8251 9980 01 Plain PCB, PLL Sub, 8350
ICs
U011 8236 5450 04 ST, TSSOP, 74VHC04
U012~014 8236 5450 00 ST, TSSOP, 74VHC00
U015 8236 5701 01 ST, DG, driver, DTC114EK
U016 8236 5704 01 ST, DG, driver, DTA114EK
RESISTORs
R011, 012 8230 5101 52 ST, carbon, 1/15W, 1.5kΩ, 5%
R012 8230 5102 24 ST, carbon, 1/15W, 220kΩ, 5%
CAPACITORs
CER = Ceramic type
C033~036 8233 5131 03 ST, CER, 50V, 0.01µF, 10%, CC11R
ACCESSORIES
Y104 8221 2091 00 Panel, blank, S
Y105 8221 3270 00 Panel, blank, 8350
Y205 8288 4650 00 Owner’s manual, 8350, mlt
Abbreviation
S: Surface mount
P: Penetrate mount
T: Taping device
F: Forming device
L: L form
I: I form
V: Vertical mount
DG: Digital
AN: Analog
57
58
DISPLAY, ROOT, DISPLAY, D1624 / D824 FRNT\KEY.SCH
D1624 / D824
FRNT\MPUKEY.SCH
FS[2..27]
DIG0
DIG1
DIG0
DIG1 J1
J2
J1 D+5
J2 DGND
KEY.SCH
LEDA[0..3] FRNT\LED.SCH
LEDA[0..3]
LEDK[0..4]
LEDK[0..4]
LEDA[0..3]
FS[2..27]
FS[2..27] LEDK[0..4]
5. CIRCUIT & BLOCK DIAGRAMS
FD[6..15]
FD[6..15]
D+5 LED.SCH
D+5
DGND FRNT\FL.SCH
DGND
FS[2..27]
FD[6..15]
SCK_FL D+5
SO_FL DGND
CE_FL
SCK_FL
AC6.2A
AC6.2A SO_FL
AC6.2B
AC6.2B CE_FL
Vdisp
Vdisp
AC6.2A
AC6.2B
Vdisp
/S27 /S27
/S28 /S28
/S29 /S29
/RST2 /RST2
MPUKEY.SCH FL.SCH
MPUKEY, DISPLAY, D1624 / D824 D+5 D+5
L1 D+5
C1 C3 C5 LGR4609-7000 L4 R47
6HOLE 2 1
0.1 0.1 10/50 J2 BEAD D94 3 2
1.5K 1%
D+5 DIG1
2 1 2 1
4 2 U9 R39
L3 3 D95 A114ES 150K
1 1 2 1 1
DGND
6HOLE C15 3 2
AC6.2B DIG0
BEAD 0.01
L2 DGND L5 DGND U8 R38
AC6.2A R48 A114ES 150K
Vdisp
C2 6HOLE C4 C6 100
0.1/50 0.1/50 10/50 P P
Vdisp A A
1 0 Vdisp
J1
SO_FL
1 AC6.2A
J2 CE_FL LEDK[0..4]
2 AC6.2B
SCK_FL
3 VdispF D+5
D92 D88 D84
4 GND U3 LEDK[0..4]
D90 D86 D82 /S29
5 D+5F C114ES
/S28 R49
6 D+5F 2 2 2 2 2 2 NON 3 2 LEDK0
/S27
7 GND 39
8 GND 1 1 1 1 1 1 1
9 GND C12 0.1 U4
R42 R41
10 /RST NON 100 C114ES R50
11 /ATN1 3 2 LEDK1
12 /ATN2 R43
13 TXD R44 1 39
14 RXD 8 7 7 7 7 7 7 7 7 7 7 6 6 6 6 6 U1
0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5
15 SCK U5
R45 C114ES R51
8283M15P R46 P P P P AP P P S P S SS S P P LEDK2
0 0 0 0 VA A 9 O 9 C O I C 9 8 3 2
Vdisp=-29.5V 2 2 2 2 2 2 100x5 3 2 1 0 C 1 0 7 2 5 K 1 1 K 0 7 39
/ / / / C (O)(O)(O) (O) 2 1 (O)(O) 1
1 1 1 1 1 1 NON 2 A A A A / U6
N N N N C
D91 D87 D83 D81 3 2 1 0 E C114ES R52
NON D LEAD 1 1 64 3 2 LEDK3
D93 D89 D85 P04/AN4 P86(O)
DGND 2 63
P05/AN5 P85(O) 39
3 62 1
P06/AN6 P84(O)
X1 4 61
8MHz P07/AN7 P83(O) U7
5 60
/RST2 AVSS P82(O) NON C114ES
D+5 C7 R40 6 59
30p 1M TEST P81(O) R53
7 58 3 2 LEDK4
X2(O) P80(O)
8 57 NON 39
X1(I) VCC
9 56 FD15 1
C8 VSS FD15
C10 NJM2103 10 55 FD14 D+5
30p OSC1(I) FD14
U2 11 54 FD13
0.1 5 OSC2(O) FD13
/RST2 12 53 FD12
RES FD12
2 13 52 FD11
VSC V J1 IRQ0 FD11
C 3 14 51 FD10
OC P11(O) FD10
6 C 15 50 FD9 C13
VSB P12(O) FD9
C19 16 49 FD8 0.1
P13(O) FD8
7 470p 17 48 FD7
VSA P14(O) FD7
G 8 18 47 FD6
N RST P15(O) FD6
1 19 46 FS2
CT D P16(I) FS2
C9 20 45 FS3
FS27 FS3
C11 0.01 21 44 FS4 DGND
FS26 FS4
0.1 4 22 43 FS5
FS25 FS5
23 42 FS6
FS24 FS6
24 41 FS7
FS23 FS7
DGND
DGND
V
F F F F F F F F F F F F F F F F F F D
D+5 S S S S S S S S S S S S S S S S S S F F I
2 2 2 2 2 2 2 2 1 1 1 1 1 1 1 1 1 1 S S S
1 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8 P
R54
/LEDA0 3 Q1 H8/3B
A1150 2 2 2 2 2 3 3 3 3 3 3 3 3 3 3 4
1K 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0
2 LEDA0
FS22 FS8
R55 1 FS21 FS9
/LEDA1 3 Q2 FS23 FS20 FS10
A1150 FS24 FS19 FS11 FD[6..15]
1K 2 LEDA1 FD[6..15]
FS25 FS18 FS12
FS26 FS17 FS13
R56 1 FS27 FS16 FS14
/LEDA2 3 Q3 FS15
A1150 LEDA[0..3]
1K 2 LEDA2 FS[2..27]
FS[2..27]
R57 1 W1
/LEDA3 3 Q4 JUMPER C14
A1150 0.1/50
1K 2 LEDA3
LEDA[0..3] Vdisp DGND

D1624 / D824
59
60
KEY, DISPLAY, D1624 / D824
D1624 / D824
DIG1 U12
JOG/SHUTTLE
DIG0
TRACK SHIFT REWIND A/P_IN

S9 D9 S13 D13 S46 D46
2 1 2 1 2 1
FS10 FS19 FS19

S S S C S J C J
1 2 3 1 4 2 2 1
1 2 3 4 5 6 7 8
SR_8/16 F.FWD AUTO PUNCH A/P_OUT SHIFT

D8 D14 D20 D47 D19 D+5
S8 S14 S20 S47 S19
2 1 2 1 2 1 2 1 2 1
C16
FS9 FS18 FS27 FS18 FS27 R58
22K 0.1
R59 R60
J1
10K 100K
AUTO PLAY R61
SR_7/15 PITCH PREV C17
22K
S7 D7 S36 D36 S34 D34 S15 D15 0.01
2 1 2 1 2 1 2 1 R62 R63
J2
10K 100K
FS8 FS17 FS17 FS26
C18
0.01
NEXT EDIT DGND

SR_6/14
S6 D6 D49 S35 D35 S43 D43
2 1 2 1 2 1 2 1
FS7 FS16 FS16 FS25
SR_5/13 END CLIP IN

S5 D5 D50 S31 D31 S21 D21
2 1 2 1 2 1 2 1
FS6 FS15 FS15 FS24
SR_4/12 RECORD DISP SEL CLIP OUT

S4 D4 D51 S10 D10 S39 D39 S22 D22
2 1 2 1 2 1 2 1 2 1
FS5 FS14 FS23 FS14 FS23
SR_3/11 STOP PGM SEL SETUP

S3 D3 D52 S11 D11 S37 D37 S44 D44
2 1 2 1 2 1 2 1 2 1
SR_2/10 EXECUTE/YES PLAY STORE START

S2 D2 S41 D41 S12 D12 S40 D40 S45 D45
2 1 2 1 2 1 2 1 2 1
SR_1/9 RECALL LOCATE EXIT/NO UNDO/REDO

S1 D1 S42 D42 S33 D33 S38 D38 S32 D32
2 1 2 1 2 1 2 1 2 1
FS[2..27]
FS[2..27]
26X2=52MAX
LED, DISPLAY, D1624 / D824
LEDA[0..3]
LEDA[0..3]
LEDK[0..4] LEDA0 LEDA1 LEDA2 LEDA3

LEDK[0..4]
LED(GRN)
AUTO LED(GRN) LED(RED) LED(GRN)
RETURN REHEARSAL REC TRACK SHIFT
D73 D71 D65 D64
LEDK0
LED(GRN) LED(RED) LED(GRN) LED(GRN)

A.PLAY TAKE STOP TC READY
D76 D69 D68 D61
LEDK1
LED(GRN) LED(GRN) LED(GRN) LED(GRN)

STORE PITCH PLAY HD ACCESS
D75 D74 D67 D62
LEDK2
LED(GRN) LED(GRN) LED(GRN) LED(GRN)

RECALL FF REW ALL INPUT
D72 D70 D66 D63
LEDK3
D1624 / D824
61
62
D+5 C21 30p
R64, C19: REMOVE
FL, DISPLAY, D1624 / D824
/RST2 R65 C22
10K 0.1/50
C20 C23
DGND
D1624 / D824
0.1 470p Vdisp G1

G2
G3
G4
CE_FL
DGND G5
SCK_FL
G6
SO_FL
6 6 6 6 6 5 5 5 5 5 5 5 5 5 5 4
4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 U14
1 D C C / V O OV T V GG GGGG 48 G7
D+5 AM1 I L E R D S S S E F 1 2 3 4 5 6 G7
2 47 G8
AM2 E D C C S S L G8
3 S I O T 46 G9
AM3 G9
D+5 4 45 G10
D+5 AM4 G10
5 44 G11
AM5 G11
Vdisp 6 43 G12
Vdisp AM6 AA8/G12
7 42 G13
AM7 AA7/G13
DGND 8 41 G14
DGND AM8 AA6/G14
Vdisp 9 40 G15
AM9 AA5/G15
10 39 G16
AM10 AA4/G16
DGND 11 38
AM11 AA3
12 37
AM12 AA2
13 36
AM13 AA1
14 35
AM14 AM35
15 A A A A A A A A A A A A A A A A 34
AM15 M M M M M M M M M M M M M M M M AM34
16 33
AM16 1 1 1 2 2 2 2 2 2 2 2 2 2 3 3 3 AM33
7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2
1 1 1 2 2 2 2 2 2 2 2 2 2 3 3 3
7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2
LC75710/1/2 FS[2..27]
FS[2..27]
R12 ~ R37: NON
FS2
R12
FS3
R13
FS4
R14
FS5 R15
FS6
R16
FS7
R17
FS8
R18
FS9 R19
FS10
R20
FS11
R21
FS12
R22
FS13 R23
FS14
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 R24
FS15 R25
4 3 3 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 9 9 9 9 9 9 9 9 9 8 8 8 8 8 8 8 8 8 8 7 7 7 7 FS16
0 9 8 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 3 2 1 R26
FS17 R27
U13 FS18
F F F D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D D F F F R28
1 1 1 3 2 2 2 2 2 2 2 2 2 3 3 3 3 3 1 2 3 4 5 6 7 8 9 1 1 1 1 1 1 1 1 1 1 2 2 2 2 FL_D160 FS19 R29
0 9 8 7 6 5 4 3 2 1 1 2 3 4 5 0 1 2 3 4 5 6 7 8 9 0 FS20
R30
FS21
R31
FS22
R32
FS23 R33
FS24
R34
FS25
R35
FS26
R36
FS27 R37
GG GGGGG GGGG GGGGGG S S S S S S S S S S S S S S S S S S S S
F F F GGG GGGG G 1 1 G 1 1 1 1 1 2 2 2 2 2 2 2 1 1 1 2 2 2 S S S S S S S S S 1 1 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 F F F
1 1 1 1 2 3 4 5 6 7 8 5 6 9 0 1 2 3 4 6 5 4 3 2 1 0 9 8 7 9 8 7 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 2 2 2 FD6
R1
FD7 R2
1 1 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 2 2 3 3 3 3 3 3 3 3 3 4 4 4 4 4 4 4 4 4 5 5 5 5 5 5 5 5 5 5 6 6 6 6 6 7 FD8
1 2 3 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 0 1 2 3 4 5 6 7 8 9 0 1 2 8 9 0 R3
FD9 R4
AC6.2A FD10
AC6.2A R5
F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F F FD11 R6
AC6.2B D D D D D D D D D D S S S S S S S S S S S S S S S S S S S S S S S S S S FD12
AC6.2B 1 1 1 1 1 1 9 8 7 6 2 3 4 5 6 7 8 9 1 1 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 R7
FD13 R8
5 4 3 2 1 0 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 FD14
R9
G G G G G G GG G G G G G G G G FD15
R10
D+5 1 2 3 4 5 6 7 8 1 1 9 1 1 1 1 1
5 6 0 1 2 3 4
FD[6..15] Vdisp
R1 ~ R10: NON
1 G[1..16]
FD[6..15]
3 2
/S27
U15
1
A114ES
3 2 R66 R67 R68
/S28
U16
1 150K 150K 150K
A114ES
3 2
/S29
U17
A114ES Vdisp
4
POWER, D1624 / D824 U10 L7
Vout
2 DGND
1
Vin
Oadj
180uH DGND
5 D1NL40 C30
GND
on/off R15
D7 R16
PQ1CF2 47K
330u/50
3
J2 22K
+12V C31
1 A+15 T2 C28
10
2 47/50 0.01
1
3 AGND
2 D8
4 AGND R13
R12
5 A-15 Q2
9 2K
DGND C32 4.7K
6 2SA1606
0.01
to MAIN 7 D+5 D12
8
8
9 D+12 D10 6.8V
S2V60 -30V
10 DGND 5.6V 7
11 D+5 6 Vdisp
4
12 DGND
3
1
U1C U1B U1A 5
8263-12P
R12
7 6 5 4 3 2
J1 DC-DCTRANS AC5.6-1
470 8242261000
1 AC5.6-1 4049 Q1
2 AC5.6-2 4049 4049 R14
8
C29
3 Vdisp 2SK2661 100/2W
R11
to DISPLAY 4 DGND R10
5 D+5 10K 470p AC5.6-2
PCB, POWER SW, D-108 6 DGND 4.7K
7 DGND
TP3 TP4 DGND
4
PIN PIN 8263M7P
OSC U6
S1
2 D+5
Vout
J4 1 L4
Vin
Oadj
POWER-SW 4P 1 D+5 180u R6
EK13
to FAN 2 DGND 5 4.7K(1%)
GND
C14 on/off D5
8263M2P 100/25 PQ1CF2
C15 C27
3
470/25 0.1
R7
1.5K(1%)
F1
FUSE2 T1 D4
U9 1
ano1 3.0A(MAX)
10 2 D+12
to SW D9 kath
THERMISTER 3 L3
TP1 BRIDGE1 ano2
1 10uH
MA649
TP2 2 9
R8
to SW 100K/2W R17 R2
C5 3
C25
C7 C6 10K 330
4 470/25 470/25
R4
100U/400V 0.01/630
U3B 8.2K
1
D3
C8
8
470/25
19mH
5 D1NL40
D6
L1 MA171 7
D1N60 ON3171 C22
2
D11 0.01
C1 C2 R 3 100 C4
D1 6
0.0022 / 250 0.0022 / 250
TRANS
1SS136 0.1
MIP166 D2 D1NL40
FGND U5 U2 R5
C16 AN1431
3 2K
drain 0.1
L2 C33
2 10/16
1mH souce 47/25
1
control U3A
C9
C3 ON3171 DGND
0.1/250
DGND
C17 A+15 +15V
0.1 R1 R9 PCB,POWER REGULATOR,D-108
FGND U1
L6
6.2 6.2 500mA(MAX) 7815
L5
3 1
J5 C12 Vin Vout
6hole C10
8263M6P 470/25 C1 C3
6hole 470/25
GND
0.01 C5 0.01
6 10/16
W1
5
2
4 AGND 6
3 5
2 C26 4
J3 1 0.1 3
C18 C19 C11 2
AC-IN 470/25 DGND AGND
3
0.0022 0.0022 to REGULATOR 1 U2

C13 7915
GND C6
IN 85V-265V AC 470/25 10/16 C4
BIN6P C2 0.01
A-15 0.01
GND
-15V 2 1
Vin Vout
500mA(MAX)
D1624 / D824
63
64
ROOT, MAIN, D1624 / D824
D1624 / D824
R_ADDA ADDA m_spps SPPS

A+15
256FS_1
A+15 256FS_2
AGND WORD_DIF1 DIGTAL I/F
WORD_DIF2
AGND D[0..31] m_dif.sch
A-15 MSCK WORD_AES/EBU1
A[0..19] D+5
BCK WORD_AES/EBU2 LRCK
A-15 CPU SCSI.SCH
LRCK EXT_LRCK BCK D+5
CPU MSCK
A+5_ADDA D+3.3
/RD /RD D[0..31] MLRCK
A+5_ADDA /LRCK /LRCK /WE0 /WE0 LRCK LRCK D+3.3
AGND BCK_ADDA BCK_ADDA /CS_SPPS1 /CS_SPPS1 MLRCK EXT_LRCK A[0..19] 256FS_1
MSCK_DA MSCK_DA /CS_SPPS2 /CS_SPPS2 256FS_2 DGND
AGND /CS_IDE D+3.3
MSCK_AD MSCK_AD /CS_IDE /CS_IDE WORD_DIF1
DGND
D[0..31] D[0..31] RST_3.3 RST_3.3 D+3.3 WORD_DIF2
D+5
AD_DATA[0..3] /RST_5 /RST_5 WORD_AES/EBU1
A[0..19] A[0..19] /RD/WR /RD/WR D+5 WORD_AES/EBU2
SCSI_CS
DA_DATA[0..7] DA_DATA[0..7] SCSI_CS SCSI_CS DGND
FS96/48 FS96/48 IDE_DMACK IDE_DMACK D[0..31]
D+5_ADDA A+5_PLL DGND A+5_PLL
WORD_SEL0 WORD_SEL0 /IDE_DREQ /IDE_DREQ A[0..19]
D+5_ADDA A+5_PLL WORD_SEL1 WORD_SEL1SCSI_DMACK SCSI_DMACK A+5_PLL
DGND_ADDA AGND_PLL WORD_SEL2 WORD_SEL2 /SCSI_DREQ /SCSI_DREQ /WE0 /WE0
DQMUL /ATA_RST /ATA_RST /RD /RD AGND_PLL
DGND_ADDA AGND_PLL D+3.3
DFS_5V IORDY_I IORDY_I DI[0..7]
AGND_PLL
D+3.3 /INTRQ /INTRQ AD_DATA[0..3]
D+5
DI[0..7] OP_IRQ OP_IRQ DA_DATA[0..7]
D+5
D+5 SCSI_INT SCSI_INT
D+5 SCSI_TMOUT SCSI_TMOUT /CS_DIF1
D+3.3
DGND DMA_SEL DMA_SEL SCSI /CS_DIF2
D+12
D+3.3 /RST_3.3 BSSEL BSSEL /RST_3.3
DGND
D+12 DGND WORD_IN /OP_CS1 /OP_CS1
DGND /OP_CS2 /OP_CS2 WORD_IN
DGND m_spps.SCH
/MUTE /MUTE /OP_CS3 /OP_CS3
DGND
DFS_5V DFS_5V /OP_CS4 /OP_CS4
SMUTE SMUTE /AESEBU /AESEBU
/RST_5 /RST_5
/RST_3.3 DQMLU
DQMLU DQMLU
R_ADDA.SCH DQMUL DQMUL
DQMUU DQMUU
SCSI m_dif
/CS_DIF1
/CS_DIF2
CPU.SCH DI[0..7]
AD_DATA[0..3]
DA_DATA[0..7]
/RST_3.3
WORD_IN
4
W1 A+15 C98 U20 A+5_ADDA D+5_ADDA
C78 C1 L5 470/16LXV
1 470/16LXV 2
2
A+15 470/16LXV 0.1 Vout
2 1 256uH C17 C3 L2 C18
Oadj
NC Vin R1
3 D15 0.1 56uH C2 10/16
AGND
4 5 EK03 3K
1
0.1
GND
AGND on/off R2
5
A-15
TO POWER 6 1K
3
6
7
DGND C79
7 AGND C7
D+5 10/16
8 PQ1CF2 H-SINK
NC
9 AD-DA POWER AGND DGND_ADDA
D+12
10 A-15 DGND 0.1
DGND
11 78M05 A+5_PLL
D+5 C19
12 U38
DGND 120/6.3LXV
3 1 PLL POWER
I O
BOARDIN 12P D+12 C4
G
0.1 C8
2
W2
1
D+12 0.1
2 JUMPER
DGND
TO HD 3 AGND_PLL DGND
DGND
4
D+5
C82 C5 C6 C83 D+5 U41 D+3.3
BOARDIN-4P 100/10 0.1 L1 0.1 100/10 PQ3DZ53
1 3
J10 J3 I O
2 G
C C86 C95
1 1 56uH
D+12
5
TO FAN 2 2 0.1 10/16
DGND
3
DGND
8283M2P 4
D+5
DGND DGND
8263M4P A+15
J1
A+15 5
AGND 4
A-15 3
TO 8345 D+5 2
DGND 1 AGND
A-15
8263M5P A+15
J22
A+15 5
AGND 4
TO AES/EBU A-15 3
D+5 2
DGND 1 AGND
A-15
8263M5P DGND
CPU, MAIN, D1624 / D824
D+5 C3121 D+5
14
D+5 C68
0.01 WORD_SEL0 [SPPS]
3
U51A 74VHCT08(5V)
3
3
DGND 0.01 1
14
74VHC08(3.3V) U33A 74VHCT08(5V) WORD_SEL1 [SPPS] D+5
9 D5 D4 D3 3 DGND 1
8 DAN202K x 9 [5<<3] 2 /RST_DISP [3>>5] 3 4 U33B 74VHCT08(5V)
U33C WORD_SEL2 [SPPS] D+1.9
10 2 [3>>5] 6 9 U86 D+5
U58C C3129 D+3.3
1
2
1
2
1
2
D+3.3 74VHCT08(5V) 5 [3>>5] 8 12 8 1
C3122 U51B VDD Fout U32 D+5
4 10 11 7 2 NON
2
1
2
1
2
1
1
3
FS96/48 [SPPS] DATA XT PQ7VZ5U
DGND 6 13 [3>>5] 6 3 R29 R40 D+3.3
U33D CLK /XT 3 1
D8 D7 D6 DGND 0.01 [5<<3] 5 /ATN1 4 5 4 X6 1.1K 1.1K OUT IN
74VHCT08(5V) CE VSS
D+5 6 32.768kHz
14
U58A DFS_5V [AD,DA,SPPS] C10 4 2
74VHCT08(5V)
GND
1 5 [3>>5] 10 NJU6350R C24 ADJ C DGND
1
U70C
3
3
3
2
4
3 R21 /ATN2 8 10/16 0.01 R30 C70
DMA_SEL [SCSI] B1
5
TO R92 2 [5>>3] U70B 9 [3>>5] C23
100 74VHCT08(5V) 74VHCT08(5V) U70D 74VHCT08(5V) CR2032 C3130 1K 10/16 GND DGND
DISPLAY 47K DGND 13 0.01
R15 100 74VHC08(3.3V) PTD0 U26-1pin [3>>5} 11 DGND NON
U51C /MUTE [AD,DA]
J6 9 R63 12 DGND
R20 100 /ATA_RST 1K U83F
1 /RST_DISP 8 DGND
2 /ATN1 [5<<3] 10 TXD0 13 12 U58D D+3.3
SMUTE [AD,DA]
3 /ATN2 U58B 13
4 TXD0 74VHC08(3.3V) 74VHCT08(5V) DGND 74VHC04(5V) RXD2 R22 11
R16 R17 100
5 RXD0 4 D+3.3 U22D [3>>5] 100 [3<<5] 12 U1-102pin
R19 100 R70
6 SCK0 U51D D+5 [5>>3] 6 RXD0 TXD2 13 /CS_IDE 4 U87B
100 74VHC08(3.3V)
7 DGND 13 5 J7-5p 10K 11 6
R18 SCSI_CS
11 SCPT3 12 R14 100 5
8283M7P [5<<3] 12 SCK0 U25C [3<<5] D+5 U1-167pin 74VHCT32(5V)
100
D+3.3 R93 74VHCT32(5V) SCPT3 D+5
74VHCT08(5V) R38 U25B R32 U28
C14
3
47K [SCSI] 74VHC14(3.3V) 1K
DAN202K NON 74VHC14(3.3V) 5 1
3
PUNCH IN VCC J7
D1 DGND TP7 6 5 D11
R81 SCSI_TMOUT R33 0.01
TP5 R7 TEST 4 3 4 DAN202K 1 DGND D+5
VO
TP 1.5K 100 2 D+5
1
2
R39 1K C67
PTD1 /DMAREQ_RST2 3 2 3 RXD422
1
2
1
R97 GND
/PUNCH_I/O U31-1pin IRQ_LRCK/8 U29 4 TXD422
1
0
14
C114EK 0.01
3
330 IRQ_LRCK DGND PC410 5 DGND
TP6 C47 DGND 2 3 6 MIDI_OUT 1
TP 0.01 C57 D+1.9 D+3.3 7 MIDI_IN2 3
C3035 R13 U30 8 MIDI_IN1 2
1
2
1
470P 470P C114EK 9 MIDI THRU
1
100 U70A
D2 C15 C3038 9 8 2 3
DAN202K DGND 0.01 0.01 C58 8283M9P 74VHCT08(5V)
1
DGND 470P U25D DGND DGND

D+3.3 DGND DGND 74VHC14(3.3V) 9P-REMOTE, MIDI
208
207
206
205
204
203
202
201
200
199
198
197
196
195
194
193
192
191
190
189
188
187
186
185
184
183
182
181
180
179
178
177
176
175
174
173
172
171
170
169
168
167
166
165
164
163
162
161
160
159
158
157
DGND
R64
TP4 [DA] DGND
10K
CA
NON D+5
VSS
VSS
VSS
VCC
VCC
VCC
MD5
MD4
MD3
R34 /RST_5
CKIO
AVSS
AVSS
AVCC
NMI
C3031 [SCSI]
RESETP
IRQOUT
C3039 NON
AN5/PTL5
AN4/PTL4
AN3/PTL3
AN2/PTL2
AN1/PTL1
AN0/PTL0
X4 33P R100
TCLK/PTH7
RST_3.3
PTC0/PINT0
PTC1/PINT1
PTC2/PINT2
PTC2/PINT3
PTC4/PINT4
PTC5/PINT5
PTC6/PINT6
PTC7/PINT7
470P 18p X3 10k
RTS2/SCPT6
TXD2/SCPT4
TXD1/SCPT2
TXD0/SCPT0
32.768kHz DGND
SCK2/SCPT5
SCK1/SCPT3
SCK0/SCPT1
RXD2/SCPT4
RXD1/SCPT2
RXD0/SCPT0
DRAK1/PTD0
DRAK0/PTD1
5
DREQ1/PTD6
DREQ0/PTD4
C3036
AN7/DA0/PTL7
AN6/DA1/PTL6
8MHz C80
STATUS1/PTJ7
STATUS0/PTJ6
1 156 D+1.9 [DIF,SPPS] U49 TP8
WAKEUP/PTD3
MD1 EXTAL C3032
3
1
R94 0.01
PTD2/RESETOUT
DGND 2 155 2 RESET
CTS2/IRQ5/SCPT7
MD2 AVSS /RST_3.3 VSC
3 XTAL 154 0 33P 3
VCC
VCC(RTC) OC
4 VCC 153 6
1
XTAL2 VSB
4
2
DGND 5 VSS 152
EXTAL3
C3037 6 VSS 151 [3<<5] 7
18p VSS(RTC) AUDCK/PTH6 VSA
7 150 120/6.3LXV 10 11 12 13 8
MNI VCC(PLL2) RST
[SCSI] 8 149 U25E U25F 1
GND
/INTRQ IRQ0/PTH0 CAP2 C21 C46 CT

[SCSI] 9 148 C89 74VHC14(3.3V) 74VHC14(3.3V) C45
SCSI_INT IRQ1/PTH1 VSS(PLL2) 0.01 470P
10 147 NJM2103M
4
[SCSI] OP_IRQ IRQ2/PTH2 VSS(PLL1)

11 146 C3033C3034 0.1
C3042 IRQ3/PTH3 CAP1
12 145 DGND C3119 U25A
IRQ4/PTH4 VCC(PLL1) 470p 470p 74VHC14(3.3V)
470P D31 13 144 D+3.3
D31/PTB7 MD0 0.01
D30 14 143 C48 D+3.3 DGND
D30/PTB6 PTF0/PINT8
14
D29 15 142 0.01

C3040 C3041 D29/PTB5 PTF1/PINT9 C22 C90
D28 16 141 DGND IRQ_LRCK/8
MEMORY D28/PTB4 PTF2/PINT10 0.01
DGND 470P 470P D27 17 140 IRQ_LRCK DGND 2 1 [SPPS]
D27/PTB3 PTF3/PINT11 120/6.3LXV LRCK
memory D26 18 139 LRCK_MSK_EN
D26/PTB2 TCK/PTF4/PINT12 C100
19 138 /DMAREQ_RST1 TP9
VSS TDI/PTF5/PINT13 non
D25 20 137 TP
10
NMI D25/PTB1 TMS/PTF6/PINT14

14
/EPROM 21 136 TP10 U54B

/EPROM VCC TRSTN/PTF7/PINT15 U26D
D24 22 135 RTC_IN TP 1 DGND
S
FM_RDY D24/PTB0 AUDATA0/PTG0

D23 23 134 9 3 13 9 12
D23/PTA7 VCC Q D
D22 24 133 8 2 11 8 11
1
D22/PTA6 AUDATA1/PTG1 Q C
D[0..31] D21 25 132 10 12
R
D[0..31] D21/PTA5 VSS U12A

D20 26 131
D20/PTA4 AUDATA2/PTG2 U12C 74VHC00(3.3V)
27 130 74VHC32(3.3V) 74VHC74(3.3V)
VSS AUDATA3/PTG3 R73 74VHC00(3.3V)
13
A[0..19] D19 28 U1 129 D+3.3

A[0..19] D19/PTA3 PTG4 J8
29 128 10K C92
VCC SH7709A ASEBRKAK/PTG5
D18 30 127 1
D18/PTA2 ASEMD0/PTG6 0.01
D17 31 126 8
CKE D17/PTA1 IOIS16/PTG7 R59 22K
D16 32 125 2
CLK D16/PTA0 PTH5/ADTRG W3
33 124 9 TP12 DGND
14
4
VSS RESETM
D15 34 123 1 3 TP
D15 WAIT
35 122 2 10
S
VCC BREQ
D+3.3 D14 36 121 4 U12B 5 2 U31A
1
VCC
D14 BACK Q D
D13 37 120 PIN HEADER 2P 11 H-UDI 4 6 3 74VHC74(3.3V)
D+3.3 D13 TDO/PTE0 Q C
D12 38 119 5 6
R
DGND D12 RAS2U/PTE1

D11 39 118 12 5 D+3.3
D11 RAS3U/PTE2
DGND D10 40 117 6
1
D10 CAS2H/PTE3 74VHC00(3.3V) C11

D9 41 116 13
D9 CAS2L/PTE6 100p
D8 42 115 7 TP11
14
4
/CS0 D8 DACK1/PDT7
D7 43 114 14 PTD1 TP U54A
/CS2 D7 DACK0/PDT5
D6 44 113 U1-189pin DGND
S
/CS3 D6 CASHH/PTJ5
45 112 DGND FC 14P 5 2
1
VCC
WE0/DQMLL VSS CASHL/PTJ4 R8 Q D

D5 46 111 6 3
DQMLU D5 VCC 100 Q C
47 110
R
DQMUL VCC CASLH/PTJ3 C26

D4 48 109
DQMUU D4 VSS 74VHC74(3.3V) 0.01
D3 49 108
1
D+3.3C29
/CAS D3 CASLL/CAS/PTJ2 0.01
D2 50 107
/RAS3L D2 RAS2L/PTJ1
D1 51 106 C91
14
D1 RAS3L/PTJ0 100p
D0 52 105 DGND U1-190pin
RD/WR D0 CKE/PTK5
[SCSI] 1 PTD0 DGND
/RD IORDY_I
3 12
/RST_3.3 /SCSI_DREQ
[SCSI] 2 11 [SCSI] D+3.3
IDE_DMACK
13
/IDE_DREQ
m_mem.sch U26A
D+3.3 74VHC32(3.3V) U12D U82
A0
A1
A2
A3
VSS
A4
VCC
A5
A6
A7
A8
A9
A10
A11
A12
A13
VSS
A14
VCC
A15
A16
A17
A18
A19
A20
A21
VSS
A22
VCC
A23
VSS
A24
VCC
A25
BS/PTK4
RD
WE0/DQMLL
WE1/DQMLU/WE
WE2/DQMUL/ICIORD/PTK6
WE3/DQMUU/ICIOWR/PTK7
RD/WR
AUDSYNC/PTE7
VSS
/CS0
VCC
CS2/PTK0
CS3/PTK1
CS4/PTK2
CS5/CE1A/PTK3
CS6/CE1B
CE2A/PTE4
CE2B/PTE5
74VHC00(3.3V) 14 3
QA A
D[0..31] D+3.3 13 4
[DIF,SPPS,SCSI] D[0..31] QB B
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
14
12 5
100
101
102
103
104
QC C
A[0..19] C51 11 6
[DIF,SPPS,SCSI] A[0..19] QD D
C44 C43 C42 C41 C61 1 2
0.01
D+3.3 15 7
0.01 0.01 0.01 0.01 10/16 DGND U52A RCO ENP
10
74VHC04(3.3V) ENT
/CS_IDE U70-1pin [SCSI] DGND 2
/CS_IDE C3126 CK
A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
[SCSI] 5 6 9
10
BSSEL U52C LOAD

[DIF12,DIF34,SCSI] 0.01 D+1.9 U31B 16 1
/RD 74VHC04(3.3V) VCC CLR
[DIF12,DIF34,SCSI]
S
DQMLU U52E C56

12 9 74VHC161(3.3V)
D Q 0.01
11 8 11 10
C Q
[SPPS] [3>>5]
R
[SCSI] 74VHC04(3.3V) U22C

DQMUL C30
D+3.3 [SCSI] C3124 C3125 DGND 74VHC74(3.3V) 9 DGND
DQMUU 0.01 0.01
13
12 0.01 13 12 8
MLRCK [DIF]
11 U52F 10
13 74VHC04(3.3V)
U52B DGND 74VHCT32(5V)
U55D RD/WR 3 4 [SCSI,AESEBU]
74VHC08(3.3V) /RD/WR
D+3.3 C3120 /RD
74VHC04(3.3V)
14
0.01 DGND U50 [5<<3] /CS4
A17
A18
1 15 1 A16
Y0 A
3 [3<<5] 14 2 4
[DIF1] /CS_DIF1 Y1 B
2 13 3 6
U55A Y2 C /CS_SPPS1 [SPPS1]
4 12 D+5 5 U26B
74VHC08(3.3V) Y3
6 11 74VHC32(3.3V)
[DIF2] /CS_DIF2 Y4
9 [3<<5] 5 10 6
U55B Y5 G1
8 9 4
74VHC08(3.3V) Y6 G2A
[3<<5] 10 7 5 /CS5 10
74VHC08(3.3V)U55C Y7 G2B U52D 8
[SCSI] /OP_CS1 /CS_SPPS2 [SPPS2]
16 9 8 9
[SCSI] /OP_CS2 VCC
C25 U26C
[SCSI] /OP_CS3 74VHC04(3.3V)
74VHCT138(5V) 0.01 74VHC32(3.3V)
[SCSI] /OP_CS4
[SCSI] /AESEBU
DGND
D1624 / D824
65
66
MEMORY, CPU, MAIN, D1624 / D824
FLASH ROM ( 4M or 8M ) SDRAM(64Mx2)
A[0..19] [CPU]
A[0..19]
D1624 / D824
D[0..31]
D[0..31] [CPU]
D+3.3
U6
J5A A1 25 29 D0 U7
A0 DQ0
A2 24 DQ1 31 D1 1 54
A1 VCC VSS
1 A0 A3 23 DQ2 33 D2 D0 2 53 D15
A2 DQ0 DQ15
2 A1 A4 22 DQ3 35 D3 3 52
A3 VCCQ VSSQ
3 A2 A5 21 DQ4 38 D4 D1 4 51 D14
A4 DQ1 DQ14
4 A3 A6 20 DQ5 40 D5 D2 5 50 D13
A5 DQ2 DQ13
5 A4 A7 19 DQ6 42 D6 6 49
A6 VSSQ VCCQ
6 A5 A8 18 44 D7 D3 7 48 D12
A7 DQ7 DQ3 DQ12
7 A6 A9 8 DQ8 30 D8 D4 8 47 D11
A8 DQ4 DQ11
8 A7 A10 7 DQ9 32 D9 9 46
A9 VCCQ VSSQ
9 A8 A11 6 DQ10 34 D10 D5 10 45 D10
A10 DQ5 DQ10
10 A9 A12 5 DQ11 36 D11 D6 11 44 D9
A11 DQ6 DQ9
11 A13 4 39 D12 12 43
A12 DQ12 VSSQ VCCQ
12 A10 A14 3 DQ13 41 D13 D7 13 42 D8
A13 DQ7 DQ8
13 A11 A15 2 DQ14 43 D14 14 41
A14 VCC VSS
14 A12 A16 1 DQ15 45 D15 15 40
A15 DQML NC
15 A13 A17 48 [CPU] RD/WR 16 39 DQMLU
A16 WE DQMU DQMLU [CPU]
16 A14 A18 17 28 /RD /CAS 17 38 CLK
A17 OE /RD CAS CLK CLK [CPU]
17 A15 A19 16 CE 26 D+3.3 /RAS3L 18 37 CKE
A18 RAS CKE CKE [CPU]
18 A16 D+3.3 WE 11 /CS3 19 36
CS NC
19 A17 37 D+3.3 A15 20 35 A13
C3044 VCC A13 A11
20 A18 D+3.3 D+5 12 R27 A14 21 34 A11
RESET A12 A9
21 A19 10K A12 22 33 A10
0.01 A10 A8
22 /CS_EPROMC 27 RY/BG 15 [CPU] A2 23 32 A9
VSS FM_RDY A0 A7
23 46 BYTE 47 A3 24 31 A8
VSS A1 A6
24 A4 25 30 A7
A2 A5
25 NC DGND MBM29LV800T/M29W800T A5 26 29 A6
A3 A4
26 /EPROM 27 28
VCC VSS
27 NC
28 WE0/DQMLL WE0/DQMLL MB811641642A
29 /RD
30
/RST_3.3 [CPU]
31 NMI U8
NMI [CPU]
32 D+3.3 [CPU] 1 54
RD/WR VCC VSS
33 D0 [CPU] D16 2 53 D31
/CAS DQ0 DQ15
34 D1 [CPU] 3 52
R96 /RAS3L VCCQ VSSQ
35 D2 D17 4 51 D30
10K [CPU] /CS3 DQ1 DQ14
36 D3 D18 5 50 D29
DQ2 DQ13
37 D4 6 49
VSSQ VCCQ
38 D5 D19 7 48 D28
DQ3 DQ12
39 D6 D20 8 47 D27
DQ4 DQ11
40 D7 9 46
VCCQ VSSQ
41 D21 10 45 D26
DQ5 DQ10
42 D8 D22 11 44 D25
DQ6 DQ9
43 D9 12 43
VSSQ VCCQ
44 D10 D23 13 42 D24
DQ7 DQ8
45 D11 14 41
VCC VSS
46 D12 DQMUL 15 40
[CPU] DQMUL DQML NC
47 D13 16 39 DQMUU
WE DQMU DQMUU [CPU]
48 D14 17 38
CAS CLK
49 D15 U59 18 37
RAS CKE
50 4 2 /CS0 19 36
1Y 1A /CS0 [CPU] CS NC
3 /CS2 A15 20 35 A13
1B /CS2 [CPU] A13 A11
FC 50P /CS_FLASHC 7 5 A14 21 34 A11
2Y 2A A12 A9
6 A12 22 33 A10
2B A10 A8
DGND 9 11 A2 23 32 A9
3Y 3A WE0/DQMLL [CPU] A0 A7
10 A3 24 31 A8
3B A1 A6
12 14 D+3.3 A4 25 30 A7
4Y 4A A2 A5
13 A5 26 29 A6
4B A3 A4
27 28
VCC VSS
D+3.3 1
A/B MB811641642A
D+3.3 16 15 D+3.3
VCC G
C3048
D+3.3
C3123 74VHC157 0.01
C88 0.01 DGND R99 C3045 C3046 C3047
10/16 10K 0.01 0.01 0.01
DGND
DGND /EPROM
/EPROM [CPU]
DGND GND
DGND
ROOT, SPPS (Serial-Parallel, Parallel-Serial), MAIN
DA_DATA[0..7]
[DA,DIF34] DA_DATA[0..7]
spps1 spps2 D824 NON

DA_DATA[0..7]256FS_1 256FS_1 [DIF1] DA_DATA[0..7]
256FS_2 256FS_2 [DIF2]
EXT_LRCK EXT_LRCK [SCSI]
WORD_AES/EBU1 WORD_AES/EBU1 [AES/EBU]
[DIF12,DIF34] MSCK MSCK WORD_AES/EBU2 WORD_AES/EBU2 [AES/EBU] MSCK
[DIF12,DIF34] BCK BCK WORD_DIF1 WORD_DIF1 [DIF1] BCK
[DIF12,DIF34,CPU,SCSI,CPU] LRCK LRCK WORD_DIF2 WORD_DIF2 [DIF2] LRCK
[AD,DA] /LRCK /LRCK WORD_IN WORD_IN [DIF1]
/RD /RD
DQMUL DQMUL
[CPU]
[AD,DA] BCK_ADDA BCK_ADDA /CS_SPPS1 /CS_SPPS1 /CS_SPPS2 /CS_SPPS2 [CPU]
[AD] MSCK_AD MSCK_AD
[DA] MSCK_DA MSCK_DA D[0..31] D[0..31]
[CPU] WORD_SEL0 WORD_SEL0 A[0..19] A[0..19]

[CPU] WORD_SEL1 WORD_SEL1
[CPU]
[CPU] WORD_SEL2 WORD_SEL2 FS96/48 FS96/48
A+5_PLL A+5_PLL
A+5_PLL A+5_PLL
AGND_PLL AGND_PLL
AGND_PLL AGND_PLL
D+5 [CPU] D+5

DFS_5V DFS_5V DI[0..7]
D+5 D+5
DI[0..7]
D+3.3 D+3.3
D+3.3 /RST_3.3 D+3.3 /RST_3.3
DGND DGND
DGND DGND
spps1.SCH spps2.SCH
DI[0..7]
DI[0..7] [DIF12]
[CPU] A[0..19]
A[0..19]
[CPU] D[0..31]
D[0..31]
/RST_3.3 [CPU]
[CPU] /RD
/RD
[CPU] DQMUL
DQMUL
A+5_PLL
A+5_PLL
AGND_PLL
AGND_PLL
D+5
D+5
D+3.3
D+3.3
DGND
GND DGND
D1624 / D824
67
68
L8
SPPS1, MAIN, D1624 / D824 22uH/LFC32
A+5_PLL non L3 (LOCK_LRCK) D+5

C34 D+5 C3103
D1624 / D824
(INT,EXT PLL) C3001 C3002

0.01 0.01 C3003 0.01
DGND 10/16 DGND
14
0.01
U11 U17 TP1
4 16 1 16 2 1 [CPU]
D0 VCC R3001 REF VDD TEST PIN FS96/48 U83C
3 5 2 15
[SCSI] EXT_LRCK D1 Y PD LOCK U83A
2 6 3 14 5 6
[AES/EBU] WORD_AES/EBU1 D2 W R3002 1.5K VDDA S2 74VHC04(5V)
1 11 4 13 D+5
[AES/EBU] WORD_AES/EBU2 D3 A AMPI S1 74VHC04(5V)
15 10 220K 5 12
WORD_IN D4 B R3003 AMPO M2 R3004 U83D
14 9 6 11
[DIF1] WORD_DIF1 D5 C VSSA M1
13 7 100 7 10 330 U24 9 8
[DIF2] WORD_DIF2 D6 G XI CKO
12 8 C3006 0.01 8 9 16 4
D7 GND 15P XO VSS R12 VCC D0 74VHC04(5V)
C3005 5 3
D1624 : non R85 R88 R89 0.47 Y D1 U83E
74HC151 TC9246F 330 6 2
D824 : 47k 47k 47k C3004 W D2
DGND DGND 11 1 11 10
A D3
10 15
B D4 74VHC04(5V)
AGND_PLL 9 14 256FS_1 [DIF1]
C31 C D5 256FS_1
WORD_SEL DGND 7 13 256FS_2 [DIF2]
WORD_SEL0 0.01 G D6 256FS_2
0, 1, 2, 8 12
[CPU] WORD_SEL1 GND D7
------ WORD_SEL2
L L L : INTERNAL 74HC151
H L L : EXTERNAL 512FS-2 DGND
L H L : AES/EBU 512FS-1 DGND DGND
R60 560
H H L :WORD IN MSCK [DIF]
R4
L L H : DIF 1 [AD,DA] BCK_ADDA
H L H : DIF 2 100 R3006 R3005
L H H : DIF 3 [DIF] BCK LRCK [DIF,DIF34,CPU,SCSI,CPU]
R84 U83B
100 100 100 R6
3 4
>
>
U21D /LRCK [AD,DA]
100
99
98
97
96
95
94
93
92
91
90
89 >
88
87 >
86 >
85
84
83 >
82
81 >
100
U21E 74VHCU04(5V) 74VHC04(5V) D+5
R61 C32
11 10 9 8
PI
PO
560
VSS
SCK
VDD
74VHCU04(5V) 0.01
BCKI
DGND
/B16B
BCKO
LRCKI
/SCSB
R77
SDATA
14
FS256I
M_SEL
LRCKO
R9
FS256O
FS128O
FS512I1
FS512I2
VLRCKO
[AD]
SOUT_89
1M 1 80 > R68 1 MSCK_AD
VDD SOUT_67 BEAD-3BP
2 79 > 1 2 DA_DATA3 U27D 3
VSS SOUT_45
X1 3 78 3 4 DA_DATA2 13 2
UVDD VSS
D0 4 77 > 5 6 DA_DATA1 11 4
D0 SOUT_23 U27A R25
D1 5 76 > 7 8 DA_DATA0 12 6 [DA]
D1 SOUT_01 > 74VHC00(5V) MSCK_DA
22.5792MHz D2 6 75 5 BEAD-3BP
D2 SIN_89 100x4 74VHC00(5V)
D3 7 74 DI3 9
C3016 C3017 D3 SIN_67 U27B
8 73 8
22P 22P VSS VDD 74VHC00(5V)
D4 9 72 DI2 10
D4 SIN_45 U27C
DGND DGND D5 10 71 DI1
D5 SIN_23 74VHC00(5V)
D6 11 70> DI0 DFS_5V [CPU]
D6 SIN_01 DFS_5V
D7 12 69
U21B U21C D7 /MUTEB
D8 13 68
R24 D8 /TRPB
3 4 5 6 D9 14 67 DA_DATA[0..7]
D9 PCMBW1 DA_DATA[0..7] [DA,DIF]
560 15 U2 66
74VHCU04(5V) 74VHCU04(5V) VSS VSS
D10 16 GA_SPPS1 65 DI[0..7]
R78 D10 PCMBW1 DI[0..7] [DIF]
D11 17 64
D11 C5VOUT2
1M D12 18 63
D12 C5VOUT1
D13 19 62
D13 C3VIN1
X2 24.576MHz D14 20 61
D14 UVDD
D15 21 60
D15 CTL_PIN
D16 22 59
D16 /RESETB
D17 23 58
C3018 C3019 D17 C3VOUT1
D18 24 57
22P 22P D18 C5VIN2
D19 25 56
D19 C5VIN1
D20 26 55 A0
D20 A0 /RST_3.3 [CPU]
DGND DGND 27 54 A1
UVDD A1 C3020
28 53
VSS UVDD NON
D+5 29 52
UVDD UVDD
D21 30 51 A2
D21 A2 A+5_PLL
DGND
14
A+5_PLL
U21A D+5
C59 1 2 AGND_PLL
D22
D23
D24
D25
D26
D27
D28
D29
D30
VSS
VDD
D31
/CSB
/RDB
/WRB
A7
A6
A5
A4
A3
0.01
74VHCU04(5V) C3009 AGND_PLL
31
32
33
34
35
36
37
38
39
40
41
42
46
47
48
49
50
DGND 10/16
> 43
> 44
> 45
U21F C3011 C3010 C3007 C3008

74VHCU04(5V) 0.01 0.01 0.01 0.01 DGND D+5
13 12 D+3.3 D+5
D+3.3
D+3.3
D22
D23
D24
D25
D26
D27
D28
D29
D30
D31
A7
A6
A5
A4
A3
C3015
[CPU] D[0..31] 10/16
D[0..31] DGND
C3012 C3013 C3014
[CPU] A[0..19] 0.01 0.01 0.01 DGND GND DGND
A[0..19]
[CPU] /CS_SPPS1
/CS_SPPS1
[CPU] /RD
/RD
[CPU] DQMUL
DQMUL
SPPS2, MAIN, D1624 / D824
[SPPS1] LRCK
[SPPS1] BCK
[SPPS1] MSCK
D824 NON
D+5
C3021
>
>
10/16
100
99
98
97
96
95
94
93
92
91
90
89 >
88
87 >
86 >
85
84
83 >
82
81 >
C3022 C3023 C3025 C3026
D+3.3 DGND 0.01 0.01 0.01 0.01
PI
PO
VSS
SCK
VDD
BCKI
/B16B
BCKO
LRCKI
/SCSB
SDATA
FS256I
M_SEL
LRCKO
FS256O
FS128O
FS512I1
FS512I2
C3024
VLRCKO
SOUT_89
10/16 1 80 >
VDD SOUT_67 R69
C3027 C3028 C3029 2 79 > 1 2 DA_DATA7
VSS SOUT_45
DGND 0.01 0.01 0.01 3 78 3 4 DA_DATA6
UVDD VSS
D0 4 77 > 5 6 DA_DATA5
D0 SOUT_23
D1 5 76 > 7 8 DA_DATA4
D1 SOUT_01 >
D2 6 75
D2 SIN_89
D3 7 74 100x4 DI7
D3 SIN_67
8 73
VSS VDD
D4 9 72 DI6 DA_DATA[0..7]
D4 SIN_45 DA_DATA[0..7] [DA,DIF]
D5 10 71 DI5
D5 SIN_23 >
D6 11 70 DI4
D6 SIN_01
D7 12 69
D7 /MUTEB
D8 13 68
D8 /TRPB
D9 14 67
D9 PCMBW1
15 U3 66 DI[0..7]
VSS VSS DI[0..7] [DIF]
D10 16 GA_SPPS2 65
D10 PCMBW1
D11 17 64
D11 C5VOUT2
D12 18 63
D12 C5VOUT1
D13 19 62
D13 C3VIN1
D14 20 61
D14 UVDD
D15 21 60 C3030
D15 CTL_PIN
D16 22 59
D16 /RESETB
D17 23 58
D17 C3VOUT1 NON
D18 24 57 DGND
D18 C5VIN2
D19 25 56
D19 C5VIN1
D20 26 55 A0
D20 A0 /RST_3.3 [CPU]
27 54 A1
UVDD A1
28 53
VSS UVDD
29 52
UVDD UVDD
D21 30 51 A2
D21 A2
A+5_PLL
D22
D23
D24
D25
D26
D27
D28
D29
D30
VSS
VDD
D31
/CSB
/RDB
/WRB
A7
A6
A5
A4
A3
A+5_PLL
31
32
33
34
35
36
37
38
39
40
41
42
46
47
48
49
50
AGND_PLL
> 43
> 44
> 45
AGND_PLL
D+5
D22
D23
D24
D25
D26
D27
D28
D29
D30
D31
A7
A6
A5
A4
A3
D+5
[CPU] D[0..31] D+3.3
D[0..31]
D+3.3
[CPU] A[0..19]
A[0..19]
DGND
[CPU] /CS_SPPS2
/CS_SPPS2
GND DGND
[CPU] /RD
/RD
[CPU] DQMUL
DQMUL
[CPU]
D1624 / D824
69
70
ROOT, DIF, MAIN, D1624 / D824
[CPU] MLRCK
D1624 / D824
[SPPS] LRCK D824 NON

[SPPS] BCK
[SPPS] MSCK
dif1.sch dif2.sch
D+5 D+5
MLRCK MLRCK
LRCK D+5 LRCK D+5
BCK BCK
D+3.3 D+3.3
MSCK MSCK
D+3.3 D+3.3
256FS_1 256FS_1 [SPPS] 256FS_2 256FS_2
WORD_DIF1 WORD_DIF1 DGND [SPPS] WORD_DIF2 WORD_DIF2 DGND
WORD_AES/EBU1 WORD_AES/EBU1 [SPPS] WORD_AES/EBU2 WORD_AES/EBU2
[SPPS] DGND DGND
WORD_IN WORD_IN
D[0..31] D[0..31]
A[0..19] A[0..19]
/RD /RD
DQMLU DQMLU
A+5_PLL A+5_PLL
[CPU] /CS_DIF1 /CS_DIF1 A+5_PLL [CPU] /CS_DIF2 /CS_DIF2 A+5_PLL
/RST_3.3 /RST_3.3
AGND_PLL AGND_PLL
AGND_PLL AGND_PLL
DI[0..7] DI[0..7]
AD_DATA[0..3] AD_DATA[0..3]
DA_DATA[0..7] SPDIF DA_DATA[0..7] SPDIF
dif1 dif2
D[0..31]
[CPU] D[0..31]
A[0..19]
[CPU] A[0..19]
[CPU] /RD
[CPU] DQMLU
/RST_3.3
[CPU] /RST_3.3
DI[0..7]
[SPPS] DI[0..7]
AD_DATA[0..3]
[AD] AD_DATA[0..3]
DA_DATA[0..7]
[SPPS] DA_DATA[0..7]
D+5
A+5_PLL
D+5
A+5_PLL
D+3.3
D+3.3 AGND_PLL
AGND_PLL
DGND
DGND
DIF1, MAIN, D1624 / D824 FCONT1.SCH
[DIF2] SPDIF SPDIF 256FS_1

DATA_IN_1
[CPU] MLRCK MLRCK FCONT2_2
/LOCK2B
D+5
MSCK
[SPPS] MSCK
BCK
[SPPS] BCK D+5 (DIGITAL1,2 PLL)
LRCK
[SPPS] LRCK DGND
L9 22uH/LFC32
[SPPS] WORD_DIF1
DGND A+5_PLL
R62 L4 non
R42 NON
100
D+5 C3051 C3052 C3053 C3057 C3058
0.01 0.01 0.01 0.01 C3059
R43 NON 10/16 0.01
C3050
10/16 R56 4.7K AGND_PLL
(LOCK SPDIF)
1 16
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
R58 REF VDD TP2
10K 2 15
PD LOCK TEST PIN
D+3.3 3 14
R3009 VDDA S2
R3007 5.6K 4 13
AMPI S1 256FS_1 [SPPS1]
VSS
VDD
BCKI
100 5 12
BCKO
LRCKI
AMPO M2
W_IN2
W_IN1
FS256I
R3010
LRCKO
C3054 6 11
W_OUT
FS256O
FCONT2
TDO_FS1O
VSSA M1
/LOCK2B
R3 R3011
PCMBW0
PCMBW1
CK_SEL0
CK_SEL1
CK_SEL2
10/16 1 80 R3008 7 10
TDO_FS0O PD2 C3062 100 XI CKO
C3055 C3056 2 79 100 330 8 9 560
0.01 0.01 TDO_EMPO MCK2 15P C3060 XO VSS
/PLL2_CONTB
DGND 3 78
PI VSS C3063 0.01
4 77 C3061 U18 TC9246F
PO /PLL1_CONTB 0.01
5 76 0.47
TEST1 /LOCK1B
A[0..4] 6 75
[CPU] A[0..19] TEST2 FCONT1 R11
7 74
VDD PD1
A4 8 73 100 AGND_PLL 256FS_1
A4 MCK1
A3 9 72
A3 DO_SEL0
A2 10 71 D+5
A2 DO_SEL1 J2
A1 11 70
A1 ADAT_MD
A0 12 69 4
A0 DO2 R67
DQMLU 13 68 3
[CPU] DQMLU /WRB DO1
/RD 14 67 100 2 WORD I/O
[CPU] /RD /RDB DO_EMPI WORD_IN
15 U4 66 1
VSS VSS
/CS_DIF1 16 GA_DIF1 65
[CPU] /CS_DIF1 /CSB VDD
/RST_3.3 17 64 8283M4P
[CPU] /RST_3.3 /RESETB DO_FS0I
D0 18 63
C3064 D0 DO_FS1I
D1 19 62 DGND
100P D1 SOUT_DI
D2 20 61
D2 SOUT2_78
D3 21 60 >
D3 SOUT2_56
DGND D4 22 59 >
D4 SOUT2_34
D5 23 58 >
D5 SOUT2_12
D6 24 57 R71
D6 VSS
D7 25 56 > 1 2 DI3
D7 SOUT1_78
26 55 > 3 4 DI2
CTL_PIN SOUT1_56
[CPU] D[0..7] 27 54 5 6 DI1
D[0..31] VDD SOUT1_34
28 53 7 8 DI0
VSS SOUT1_12
29 52 D+5
/EN_IFB DI_EMPO 100x4
30 51 C12
SINA_MD DI_FS0O 10/16
C3065
DI[0..7] 0.1 J12
SOUT1_MD
SOUT2_MD
TDI_FS1I
TDI_FS0I
TDI_EMPI
SINA_12
SINA_34
SINA_56
SINA_78
VSS
VDD
SINB_12
SINB_34
SINB_56
SINB_78
SIN_DIF
DI1
DI2
DI_SEL
DI_FS1O
DI[0..7] [SPPS1]
[AD] 2 4
AD_DATA[0..3]
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
DATA_OUT_1 1 5 DATA OUT_1
AD_DATA[0..3]
3 6
TO AES/EBU
DATA_IN_1
J13 GPIF32T
FC 17P
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
C96 J11
[SPPS1] R46 0.1 1 4
WORD_AES/EBU1 3.3K
D+5 R47
LRCK
[SPPS1] 3 5 DATA IN_1
BCK D+5
[SPPS1] D+3.3 A+5_PLL
DGND DA_DATA0 330 R48 2 6
D+3.3 A+5_PLL 2.2K
AD_DATA0 DA_DATA1
AD_DATA1 DA_DATA2 GPIF32R
DGND AGND_PLL
AD_DATA2 DA_DATA3
AD_DATA3 U84 DGND AGND_PLL
2 4 DGND
1A 1Y DA_DATA[0..7] [SPPS1]
3 DA_DATA[0..7]
1B
5 7
2A 2Y
D+5 6
2B
11 9
3A 3Y
10
R3041 3B
14 12
47k 4A 4Y
13 D+5
4B
1
A/B
15 16
G VCC
C3127
74VHC157 0.01
DGND
DGND
D1624 / D824
71
72
FCONT1, DIF1, MAIN, D1624 / D824
D+5
D1624 / D824
12
C3066 D+5
11
0.01 13
D+5 D+5
C3067 U79D
0.01 74VHC00
C3101
DGND 0.01
U63B
U63A 5 U19
4
14
14
U79C D+5
DGND 1 6 3 14 DGND 10
A QA
OPT_IN 3 4 4 13 8 11T
S
B QB U79B
14
2 5 2 5 12 5 9
VCC
DATA_IN_1 D Q 74VHC86 C QC C3069 C3072
3 6 6 11 1 6
10
4
14
C Q 74VHC86 D QD 74VHC00 100p U37B U37A 0.01
D+5 3 4
R
U36A 7 15 2
S
S
ENP RCO 74VHC00
74VHC74 10 12 9 2 5 DGND D+5
1
VCC
ENT 74VHC00 D Q D Q
2 11 8 3 6
1
CK U79A
D+5 9 D+5 C Q C Q VCO
R
R
LOAD R3014
1 16 2 3
CLR VCC FCONT2_2
10K
1
74VHC74 74VHC74
13
74VHC161 C3068 DGND U14
DIF-GR 0.01 DTA114EK
256FS_1 D+5
DGND DGND D+5
C3070 U16
10
4
14
U42B U42A 0.01 DTC114EK

2 3 R3015
S
S
12 9 2 5 DGND 10K
VCC
D Q D Q
11 8 3 6
1
C Q C Q
R
R
DGND
1
74VHC74 74VHC74
DGND 13
10T
C3071
100p
D+5
U63D DGND
13
11
12 D+5
MLRCK
74VHC86
10
U36B
S
12 9
D Q R3013
11 8
C Q
1K
R
C3073
74VHC74
47p
13
DGND
DGND GND
D+5
U63C
9
8
R3012 10
DIF-GR /LOCK2B
10k 74VHC86
3
D12
1
SPDIF
DIF2, MAIN, D1624 / D824 FCONT2.SCH
[DIF1] SPDIF SPDIF 256FS_2

DATA_IN_2
[CPU] MLRCK MLRCK FCONT2_2
/LOCK2B
D+5
MSCK
[SPPS] MSCK
BCK
[SPPS] BCK D+5 (DIGITAL1, 2 PLL)
LRCK
[SPPS] LRCK DGND
L10 22uH/LFC32
DGND A+5_PLL
L7 non
[SPPS] WORD_DIF2 R44 NON
D+5 C3076 C3077 C3078 C3082 C3083
0.01 0.01 0.01 0.01 C3084
R45 NON 10/16 0.01
C3075
10/16 R54 4.7K AGND_PLL
(LOCK SPDIF)
1 16
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
R55 REF VDD TP3
10K 2 15
PD LOCK TEST PIN
D+3.3 3 14
R3018 VDDA S2
R3016 5.6K 4 13 [SPPS1]
AMPI S1 256FS_2
VSS
VDD
BCKI
100 5 12
BCKO
AMPO M2
LRCKI
W_IN2
W_IN1
R3019
FS256I
LRCKO
C3079 6 11
W_OUT
FS256O
FCONT2
VSSA M1
TDO_FS1O
/LOCK2B
10/16 R26 R3020
PCMBW0
PCMBW1
CK_SEL0
CK_SEL1
CK_SEL2
1 80 R3017 100 7 10
TDO_FS0O PD2 330 C3087 XI CKO
C3080 C3081 2 79 100 8 9 560
0.01 0.01 TDO_EMPO MCK2 15P C3085 XO VSS
/PLL2_CONTB
DGND 3 78
PI VSS C3088 C3086 0.01
4 77 U61 TC9246F
PO /PLL1_CONTB 0.01 0.47
5 76
TEST1 /LOCK1B 100
A[0..4] 6 75
[CPU] A[0..19] TEST2 FCONT1 R28
7 74
VDD PD1
A4 8 73 AGND_PLL 256FS_2
A4 MCK1
A3 9 72
A3 DO_SEL0
A2 10 71
A2 DO_SEL1
A1 11 70
A1 ADAT_MD
A0 12 69
A0 DO2 R57
DQMLU 13 68 DATA_OUT_2
[CPU] DQMLU /WRB DO1
/RD 14 67 100
[CPU] /RD /RDB DO_EMPI
15 U5 66
VSS VSS
[CPU] /CS_DIF2 /CSB VDD
/RST_3.3 17 64
[CPU] /RST_3.3 /RESETB DO_FS0I
D0 18 63 D+5
D0 DO_FS1I
C3089 D1 19 62 C13
D1 SOUT_DI 10/16
100P D2 20 61
D2 SOUT2_78
D3 21 60 >
D3 SOUT2_56
DGND D4 22 59 > C3074
D4 SOUT2_34 J21
D5 23 58 > 0.1
D5 SOUT2_12
D6 24 57 R72 2 4
D6 VSS
D7 25 56 > 1 2 DI7
D7 SOUT1_78
26 55 > 3 4 DI6 1 5 DATA OUT_2
CTL_PIN SOUT1_56
D[0..7] 27 54 5 6 DI5
[CPU] D[0..31] VDD SOUT1_34
28 53 7 8 DI4 3 6
VSS SOUT1_12
29 52
/EN_IFB DI_EMPO 100x4
30 51 GPIF32T
SINA_MD DI_FS0O
DI[0..7] [SPPS2]
SOUT1_MD
SOUT2_MD
TDI_FS1I
TDI_FS0I
TDI_EMPI
SINA_12
SINA_34
SINA_56
SINA_78
VSS
VDD
SINB_12
SINB_34
SINB_56
SINB_78
SIN_DIF
DI1
DI2
DI_SEL
DI_FS1O
DI[0..7]
[AD] AD_DATA[0..3]
C97
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
J20
AD_DATA[0..3] R51 0.1 1 4
TO AES/EBU R52 3.3K
J14 DATA_IN_2 3 5 DATA IN_2
FC 17P
330 R53 2 6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
2.2K
GPIF32R
[SPPS1]
WORD_AES/EBU2
LRCK
[SPPS1] D+5 DGND
BCK
[SPPS1]
D+5
DGND DA_DATA4 D+3.3
AD_DATA0 DA_DATA5 A+5_PLL
D+3.3
AD_DATA1 DA_DATA6
A+5_PLL
AD_DATA2 DA_DATA7
DGND
AD_DATA3 DA_DATA1
AGND_PLL
U85 DGND
2 4 AGND_PLL
1A 1Y
3 DA_DATA[0..7] [SPPS1]
1B DA_DATA[0..7]
5 7 D824 NON
2A 2Y
6
D+5 2B
11 9
3A 3Y
10
3B
R3042 14 12
47k 4A 4Y
13 D+5
4B
1
A/B
15 16
G VCC
C3128
74VHC157 0.01
DGND
DGND
D1624 / D824
73
74
FCONT2, DIF2, MAIN, D1624 / D824
D+5
D1624 / D824
12
11
C3090 D+5 13
0.01 D824 NON
D+5 D+5 U60D
C3091 74VHC00
0.01
C3102
DGND 0.01
U72B
U72A 5 U62
4
14
U60C
14
DGND 1 6 3 14 DGND 10 D+5
OPT_IN 3 4 4 A QA 13 8 11T
S
B QB U60B
14
2 5 2 5 12 U60A 5 9
VCC
DATA_IN_2 D Q 74VHC86 C QC C3093 C3095
3 6 6 11 1 6
10
4
14
C Q 74VHC86 D+5 D QD 3 4 74VHC00 100p U45B U45A 0.01
R
U44A 7 15 2
S
S
74VHC74 10 ENP RCO 74VHC00 12 9 2 5 DGND D+5
1
VCC
ENT 74VHC00 D Q D Q
2 11 8 3 6
1
D+5 9 CK D+5 C Q C Q VCO
R
R
1 LOAD 16 2 3 R3023
CLR VCC FCONT2_2
74VHC74 74VHC74 10K
13
74VHC161 C3092 DGND U15
DIF-GR 0.01 DTA114EK
256FS_2 D+5
DGND DGND D+5
C3094 U35
10
4
14
U46B U46A 0.01 DTC114EK

2 3 R3024
S
S
12 9 2 5 DGND 10K
VCC
D Q D Q
11 8 3 6
1
C Q C Q
R
R
DGND
74VHC74 74VHC74
1
13
DGND
10T
C3096
100p
D+5
U72D DGND
13
11
12 D+5
MLRCK
74VHC86
10
U44B
S
12 9
D Q R3022
11 8
C Q 1K
R
C3097
74VHC74 47p
13
DGND
DGND GND
D+5
U72C
9
DIF-GR 8
R3021 10
/LOCK2B
10k 74VHC86
3
D13
1
SPDIF
SCSI I/F, MAIN, D1624 / D824
D+3.3
D+5
D[0..31]
[CPU] D[0..31] C40
U47 U65 U67 [3<<>>5]
1 24 1 24 1 24 0.01 /OP_RST_5V
VA VB VA VB VA VB
2 23 2 23 2 23
DIR NC DIR NC DIR NC
D+3.3 D0 3 22 D8 3 22 D0 3 22 DGND
A1 G A1 G A1 G DQMLU U34C
D1 4 21 5V_D0 D9 4 21 5V_D0 D1 4 21 OP_D0 [CPU] 9
A2 B1 A2 B1 A2 B1 DQMLU
D2 5 20 5V_D1 D10 5 20 5V_D1 D2 5 20 OP_D1 [3>>5] 8
C3043 C3106 A3 B2 A3 B2 A3 B2
D3 6 19 5V_D2 D11 6 19 5V_D2 D3 6 19 OP_D2 10
10/16 A4 B3 A4 B3 A4 B3 74VHCT08(5V)
0.01 D4 7 18 5V_D3 D12 7 18 5V_D3 D4 7 18 OP_D3 TO AES/EBU
A5 B4 A5 B4 A5 B4 U34D
D5 8 17 5V_D4 D13 8 17 5V_D4 D5 8 17 OP_D4 [CPU] /RD 12 TO 8345
A6 B5 A6 B5 A6 B5 /RD
DGND C3104 D6 9 16 5V_D5 D14 9 16 5V_D5 D6 9 16 OP_D5 [3>>5] 11 J18 J4
0.01 A7 B6 A7 B6 A7 B6
D7 10 15 5V_D6 D15 10 15 5V_D6 D7 10 15 OP_D6 C69 D+5 13 1 1
A8 B7 A8 B7 A8 B7 74VHCT08(5V)
11 14 5V_D7 11 14 5V_D7 11 14 OP_D7 D+3.3 C52 2 2
GND B8 GND B8 C37 GND B8 0.01
12 13 12 13 12 13 OP_D0 3 OP_D0 3
GND GND GND GND GND GND
14
OP_D1 4 OP_D1 4
14
74LVXC3245FS 74LVXC3245FS 0.01 74LVXC3245FS 0.01 1 U34A OP_D2 5 OP_D2 5
/RD/WR C39 C38 U23C 1 DGND 3 OP_D3 6 OP_D3 6
[CPU] /RD/WR
U48 [3<<>>5] 0.01 U66 [3<<>>5] 0.01 DGND 11 12 [3<<5] 2 2 OP_D4 7 OP_D4 7
74VHCT08(5V)
1 24 1 24 D+5 8 10 13 OP_D5 8 OP_D5 8
VA VB VA VB
2 23 DGND 2 23 DGND 9 OP_D6 9 OP_D6 9
DIR NC DIR NC U23A U34B
D8 3 22 D0 3 22 4 OP_D7 10 OP_D7 10
A1 G A1 G C3105 C3107 74VHC11(3.3V) 74VHC11(3.3V)
D9 4 21 5V_D8 D1 4 21 5V_D8 6 OP_A0 11 OP_A0 11
A2 B1 A2 B1
D10 5 20 5V_D9 D2 5 20 5V_D9 0.01 0.01 3 5 OP_A1 12 OP_A1 12
A3 B2 A3 B2 74VHCT08(5V)
D11 6 19 5V_D10 D3 6 19 5V_D10 6 [3<<5] 4 OP_A2 13 OP_A2 13
A4 B3 A4 B3
D+3.3 D12 7 18 5V_D11 D4 7 18 5V_D11 DGND 5 DGND OP_A3 14 OP_A3 14
A5 B4 A5 B4
D13 8 17 5V_D12 D5 8 17 5V_D12 D+5 OP_A4 15 OP_A4 15
A6 B5 A6 B5 U23B
4 D14 9 16 5V_D13 D6 9 16 5V_D13 [CPU] OP_IRQ 4 3 16 16
A7 B6 A7 B6 74VHC11(3.3V) OP_IRQ
6 D15 10 15 5V_D14 D7 10 15 5V_D14 [3<<5] /OP_WE 17 /OP_WE 17
A8 B7 A8 B7 U57B
5 11 14 5V_D15 11 14 5V_D15 R86 /OP_RD 18 /OP_RD 18
GND B8 GND B8 74VHC04(3.3V)
C35 12 13 12 13 4.7K [CPU] /OP_CS1 19 /AESEBU 19
U43B GND GND C36 GND GND /OP_CS1
/OP_CS2 20 OP_A13 20
74VHC00(3.3V) /OP_CS2
0.01 74LVXC3245FS 0.01 74LVXC3245FS /OP_CS3 21 OP_A14 21
/OP_CS3
5V_D15
5V_D14
5V_D13
5V_D12
5V_D11
5V_D10
5V_D9
5V_D8
5V_D7
5V_D6
5V_D5
5V_D4
5V_D3
5V_D2
5V_D1
5V_D0
/OP_CS4 22 OP_A15 22
/OP_CS4
D+3.3 DGND DGND D+5 9 23 23
/AESEBU
U43D [SPPS] LRCK 8 U13C 24 24
LRCK
13 U43C 10 U53F 25 25
11 10 [SPPS] EXT_LRCK 74VHC00(5V) 12 13
EXT_LRCK
[CPU] 12 8 FC 25P FC 25P
BSSEL 74VHC04(5V)
9 [5>>3] 5V_A4 DGND
74VHC00(3.3V) DGND
74VHC00(3.3V) C3115
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
J16 R3051 D+5
10K
14
0.01 DGND 51
A4
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
BSSEL 1
D11
D15
D14
D13
D12
D10
LDP
CS1
CS0
VSS
VSS
BHE
UDP
VCC
3 1 26 /DB0 S10
D+5 2 [5>>3] 2 27 /DB1 S11
1 75 5V_A3 3 28 /DB2 S12
U43A WR A3
2 74 5V_A2 4 29 /DB3 S13
14
74VHC00(3.3V) RD A2
C87 3 73 5V_A10 5 30 /DB4 S14
VCC A1
0.01 1 U87A 4 72 5V_A9 6 31 /DB5 S15
VSS A0
3 5 71 /ATN S5 7 32 /DB6 S16
CLK ATN
2 [3<<5] 6 70 8 33 /DB7 S17
RESET VSS
[CPU] [CPU] SCSI_INT 12 13 7 69 /BSY S7 9 34 /DBP S9
SCSI_INT INT BSY
U56F 8 68 /ACK S6 10 35
74VHCT32(5V) /ATA_RST MODE ACK
74VHC04(3.3V) S9 9 67 /RES S4 11 36
DBP RES
10 66 reserved12 37 reserved
R23 VSS VSS
S17 11 65 open 13 38 /TPWR
DGND W12A 560 DB7 U9 VSS
S16 12 64 reserved14 39 reserved
U80F DB6 VCC
S15 13 MB86604L 63 /MSG S1 15 40
74VHCU04(5V) DB5 MSG
1 14 62 /SEL S8 16 41 /ATN S5 EXT SCSI
D+5 VCC SEL
2 DGND 13 12 11 10 15 61 /C/D S2 17 42
VSS C/D
3 5V_D7 16 60 /REQ S0 18 43 /BSY S7
3 4 U80E VSS REQ
4 5V_D8 S14 17 59 19 44 /ACK S6
74VHCU04(5V) DB4 VSS
U69B 5 5V_D6 R10 1M S13 18 58 /I/O S3 20 45 /RES S4
DB3 I/O
74VHCT04(5V) 6 5V_D9 S12 19 57 21 46 /MSG S1
5 6 X5 DB2 TEST2
7 5V_D5 S11 20 56 22 47 /SEL S8
DB1 (OPEN)
U69C 8 5V_D10 21 55 23 48 /C/D S2
20MHz VSS TP
74VHCT04(5V) 9 5V_D4 S10 22 54 24 49 /REQ S0
9 8 DB0 VSS
10 5V_D11 23 53 25 50 /I/O S3
U69D TEST1 VCC
11 5V_D3 24 52
74VHCT04(5V) TMOUT DREQ
12 5V_D12 C3098 C3099 25 51 52
11 10 (OPEN) DMACK
13 5V_D2 DGND
33P 33P
U69E 14 5V_D13 D+5 DGND DGND
74VHCT04(5V) D-SUB 50P J9A
15 5V_D1
12 16 5V_D14
DMA WR
DMA RD
VCC
VSS
DMA 0
LDMDP
DMD 0
DMD 1
DMD 2
DMD 3
DMD 4
DMD 5
DMD 6
DMD 7
VSS
DMD 8
DMD 9
DMD10
DMD11
DMD12
DMD13
DMD14
DMD15
UDMDP
DMBHE
11 17 5V_D0 C3100 1
13 18 5V_D15 0.01 S10 /DB0 2
14
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
19 DGND 3
U13D
20 KEYPIN 1 2 DGND W13 S11 /DB1 4
74VHC00(5V)
TO IDE HD 21 DMARQ U80A PIN HEADER 2P 5
11 10 22 DGND 74VHCU04(5V) SCSI TERM S12 /DB2 6
U53E 23 /DIOW 3 4 U80B OUT : enable 7
74VHC04(5V) 24 DGND 74VHCU04(5V) D+5 IN : disable S13 /DB3 8
2
1
9 8
5V_D0
5V_D1
5V_D2
5V_D3
5V_D4
5V_D5
5V_D6
5V_D7
5V_D8
5V_D9
5V_D10
5V_D11
5V_D12
5V_D13
5V_D14
5V_D15
25 /DIOR DGND 9
26 DGND 5 6 U80C R3040 S14 /DB4 10
U57D 27 IORDY D+5 74VHCU04(5V) 10k 11
74VHC04(3.3V) 28 S[0..16] DGND S15 /DB5 12
5 6 29 9 8 U80D U64 13
30 DGND R95 74VHCU04(5V) D+5 1 25 S16 /DB6 14
U57C 1K N.C. TSD
31 INTRQ 2 24 15
74VHC04(3.3V) EN VM
32 /IOCS16 /DBP S9 3 23 S8 /SEL S17 /DB7 16
11 10 SCSI15 SCSI14
33 5V_A10 R87 4.7K /DB0 S10 4 22 S7 /BSY 17
SCSI16 SCSI13
34 /PDIAG /DB1 S11 5 21 S6 /ACK S9 /DBP 18
U57E SCSI17 SCSI12
35 5V_A9 /DB2 S12 6 20 S5 /ATN 19
74VHC04(3.3V) SCSI18 SCSI11
36 5V_A2 20
13 12 37 /CS1FX D+5 21
38 /CS3FX U75 [5<<3] 22
U57F 39 /DASP 20 1 7 23
74VHC04(3.3V) V VSS
40 DGND 19 2 A0 /DB3 S13 8 19 S4 /RES 24
DGND U87C SCSI1 SCSI10
OP_A0 18 3 A1 /DB4 S14 9 18 S3 /I/O 25
SCSI2 SCSI9
FC 40P-R D+5 9 OP_A1 17 4 A2 /DB5 S15 10 17 S2 /C/D /TPWR 26
U56C SCSI3 SCSI8
DGND 8 OP_A2 16 5 A3 /DB6 S16 11 16 S1 /MSG 27
SCSI4 SCSI7
/INTERQ 6 5 10 OP_A3 15 6 A4 /DB7 S17 12 15 S0 /REQ 28 INT SCSI
[CPU] /INTRQ R37 U87D SCSI5 SCSI6
[3<<5] OP_A4 14 7 A13 13 14 29
74VHC04(3.3V) C28 NON VCC VCC
74VHCT32(5V) 12 OP_A13 13 8 A14 30
C3112 D+5 R31 470P 11 OP_A14 12 9 A15 D+5 DGND BH9595FP 31
10K 13 D+5 OP_A15 11 10 D17 S5 /ATN 32
G
1 2 33
14
DGND 0.01 DGND R36 74VHCT32(5V) 74VHCT541 34
IDE_DMACK 1 2 0 C3114 D+3.3 EK13 C16 35
[CPU] IDE_DMACK
[3>>5] U69A C3109 S7 /BSY 36
74VHCT04(5V) D+5 0.01 D+5 DGND 0.01 37
C77
R49 1K DGND 0.01 U71 [5<<3] S6 /ACK 38
14
10/16
IORDY_I 8 9 10 11 [CPU] C3108 20 1 DGND 39
[CPU] IORDY_I V
U56D U56E [3<<5] SCSI_TMOUT 2 1 DGND 0.01 19 2 A9 C3113 D+3.3 S4 /RES 40
74VHC04(3.3V) 74VHC04(3.3V) SCSI_TMOUT U57A
[3<<5] R3025 5V_A9 18 3 A10 41
[CPU] 74VHC04(3.3V) 0 5V_A10 17 4 A2 S1 /MSG 42
14
/IDE_DREQ 4 3 DMA_SEL 5V_A2 16 5 A3 DGND 0.01 43

[CPU] /IDE_DREQ DMA_SEL
D+5 U56B [3<<5] 5V_A3 15 6 A4 1 2 /SCSI_DREQ S8 /SEL 44
74VHC04(3.3V) R50 /SCSI_DREQ
C27 R5 5V_A4 14 7 A6 [5>>3] [CPU] 45
0.01 NON 5V_A6 13 8 A7 U56A S2 /C/D 46
14
5.6K 74VHC04(3.3V)
[3>>5] DGND D+5 5V_A7 12 9 47
DQMUU 1 C3110 11 10 S0 /REQ 48
[CPU] DQMUU G
3 DGND 49
2 U22B 0.01 D+5 74VHCT541 S3 /I/O 50
4 [3>>5] [CPU]
/RST_5
14
DGND U22A 6
DQMUL 74VHCT32(5V) 5 1 DGND C3111 DGND DGND
[CPU] DQMUL 0.01
/CS3FX 3 [CPU] A[0..19]
A[0..19]
74VHCT32(5V) 2 C3118
14
/CS_IDE 2 1 DGND 5V_A3

D+3.3 U13A
74VHC00(5V) U53A
D+3.3
14
4 DGND 0.01 74VHC04(5V)

C3116 /CS1FX 6 U53D 1 4 3 5V_A6
10/16 5 8 9 12 2
D+5 13 U53B
DGND U13B 74VHC00(5V) 74VHC04(5V) 74VHC04(5V)
SCSI_CSB U10A 74VHC10(5V)
SCSI_CS
D+5
9 W5 W4 [CPU] 6 5 5V_A7
POWER C3117
8 10 0 non 3
10/16 U53C 74VHC04(5V)
DGND 11 6 4 U69F [5<<3]
C84 C65 C66 C64 C63 5 12 13 /CS_IDE [CPU]
U10C 74VHC10(5V) U10B 74VHC10(5V) /CS_IDE
100/16 0.01 0.01 0.01 0.01 DGND GND 74VHCT04(5V)
D1624 / D824
75
76
ROOT, AD-DA, MAIN, D1624 / D824
A+5_ADDA
R74
1K
VBIAS
D1624 / D824
J101 ADDA_IN ADDA ADDA_OUT

R75 C62 C33
YKC21-3077
1K 0.01 470/10
ADDA_IN ADDA_DG ADDA_OUT
7
7
AGND R118
D824 NON
L101 BEAD-3BP L102 BEAD-3BP
100
4 1 2 AIN1 AIN1+ AOUT1 1 2 4 AOUT1
AIN1 AIN1+ AIN1+ AOUT1+ AOUT1+ AOUT1
AIN1- AOUT2
AIN2 AIN1- AIN1- AOUT1- AOUT1- AOUT2
6 AOUT3 2 3 6
AIN3 AOUT2+ AOUT2+ AOUT3
L501 BEAD-3BP AOUT4 L902 BEAD-3BP
AIN4 AOUT2- AOUT2- AOUT4 DTC314TK
3 1 2 AIN5 AIN2+ AOUT5 1 2 3 AOUT9
1
AIN2+ AIN2+ AOUT3+ AOUT3+ AOUT5 U112
AIN2- AOUT6
AIN2- AIN2- AOUT3- AOUT3- AOUT6 R918
INPUT AOUT7 AGND
AIN5 AOUT4+ AOUT4+ AOUT7 100
L201 BEAD-3BP AOUT8 L202 BEAD-3BP
AIN6 AOUT4- AOUT4- AOUT8
2 1 2 AIN2 AIN3+ 1 2 2 AOUT2
AIN7 AIN3+ AIN3+ AOUT5+ AOUT5+
AIN3- 2 3
AIN8 AIN3- AIN3- AOUT5- AOUT5-
5 AOUT9 5
AOUT6+ AOUT6+ AOUT9 DTC314TK
L601 BEAD-3BP AOUT10 L1002
1
AOUT6- AOUT6- AOUT10 U912
1 1 2 AIN6 AIN4+ AOUT11 1 2 1 AOUT10
A+5_ADDA AIN4+ AIN4+ AOUT7+ AOUT7+ AOUT11 R218
AIN4- AOUT12 AGND
AIN4- AIN4- AOUT7- AOUT7- AOUT12 100
AOUT13 BEAD-3BP
A+5_ADDA AOUT8+ AOUT8+ AOUT13
AOUT14 J106
AOUT8- AOUT8- AOUT14
AIN5+ AOUT15 2 3 YKC21-3077
AGND AIN5+ AIN5+ AOUT15
AIN5- AOUT16
AIN5- AIN5- AOUT16 DTC314TK
FRAME AGND AGND
1
U212
VBIAS R1018
AIN6+ AGND AGND FRAME
AIN6+ AIN6+ AOUT9+ AOUT9+ 100
AIN6-
J102 AIN6- AIN6- AOUT9- AOUT9-
AOUT10+ AOUT10+
7
YKC21-3077 2 3
BAL_IN1 AOUT10- AOUT10-
L301 BEAD-3BP AIN7+
BAL_IN2 AIN7+ AIN7+ AOUT11+ AOUT11+ DTC314TK
AIN7-
7
4 1 2 AIN3 BAL_IN3 AIN7- AIN7- AOUT11- AOUT11- U1012

BAL_IN4 AOUT12+ AOUT12+ R318
6 AGND L302 BEAD-3BP
AOUT12- AOUT12- 100
L701 BEAD-3BP AIN8+ 1 2 4 AOUT3
AIN8+ AIN8+ AOUT13+ AOUT13+
3 1 2 AIN7 AIN8-
AIN8- AIN8- AOUT13- AOUT13-
2 3 6
AOUT14+ AOUT14+ L1102 BEAD-3BP
AOUT14- AOUT14- DTC314TK
1 2 3 AOUT11
1
INPUT L401 BEAD-3BP BAL_IN5 AOUT15+ AOUT15+ U312

2 1 2 AIN4 A+5_ADDA
BAL_IN6 AOUT15- AOUT15- R1118
AGND
BAL_IN7 A+5_ADDA AOUT16+ AOUT16+ 100
5 L402 BEAD-3BP
BAL_IN8 AOUT16- AOUT16-
L801 BEAD-3BP 1 2 2 AOUT4
AGND
1 1 2 AIN8 2 3
AGND 5
DTC314TK L1202
1
U1112
ADDA_IN.SCH D+5_ADDA 1 2 1 AOUT12
R418
AGND
D+5_ADDA 100
BEAD-3BP
J107
DGND_ADDA
FRAME AGND A+15 2 3 YKC21-3077
DGND_ADDA
A+15 DTC314TK
1
U412
AD_DATA[0..3]
GR AD_DATA[0..3] AD_DATA[0..3] R1218
AGND AGND FRAME
AGND 100
DA_DATA[0..7] J104
GR DA_DATA[0..7] DA_DATA[0..7]
J103 AGND AOUT1 1
1 AOUT2 2 2 3
/RST_5 A-15
2 BAL_IN1 AOUT3 3
DFS_5V DTC314TK
1
3 A-15 AOUT4 4
7
U1212 AGND
4 BAL_IN2 AOUT5 5
MSCK_AD TO
5 AOUT6 6 L502 BEAD-3BP
MSCK_DA BALANCE R518
6 BAL_IN3 AOUT7 7 1 2 4 AOUT5
7 AOUT8 8
/LRCK 100
8 BAL_IN4 AOUT9 9 2 3 6
BCK_ADDA
TO 9 ADDA_OUT.SCH AOUT10 10 L1302 BEAD-3BP
SMUTE DTC314TK
10 BAL_IN5 AOUT11 11 1 2 3 AOUT13
1
BALANCE /MUTE U512

11 AOUT12 12 D824
R1318
12 BAL_IN6 AOUT13 13 FC 8P AGND
100
13 ADDA_DG.SCH AOUT14 14 L602 BEAD-3BP
14 BAL_IN7 AOUT15 15 1 2 2 AOUT6
15 AOUT16 16 2 3
16 BAL_IN8 17 5
17 N.C. N.C. DTC314TK L1402
1
U1312
FC 17P 1 2 1 AOUT14
R618
FC 17P AGND /RST_5 AGND
CPU /RST_5 100
BEAD-3BP
DFS_5V J108
CPU DFS_5V
2 3 YKC21-3077
MSCK_AD A+15
CPU MSCK_AD DTC314TK
J105
1
U612
MSCK_DA 1
CPU MSCK_DA R1418
R82 2 TO AGND AGND FRAME
100
/LRCK 10K 3
SPPS /LRCK BALANCE
A+15 D+12 D25 4
BCK_ADDA AGND 2 3
SPPS BCK_ADDA RB400D C50 8263M4P
SMUTE W11 2 3 100/25 A-15 DTC314TK
7
CPU SMUTE U1412

non
1
R718
D14 A-15 AGND L702 BEAD-3BP
100
A+5_ADDA D+5_ADDA 1 2 3 BAL_MUTE 1 2 4 AOUT7
3
A+5_ADDA D+5_ADDA 2 U74 2 3 6
DTB114EK L1502 BEAD-3BP
AGND DGND_ADDA DAN202K R80 DTC314TK 1 2 3 AOUT15
1
10K R1518 U712

AGND DGND_ADDA 100
R83 AGND
POWER
R76 10K A-15 L802 BEAD-3BP
10K 2 3 1 2 2 AOUT8
A+15 D+12 C49
DTC114EK DTC114EK 100/25 DTC314TK 5
1
1
A+15 D+12 R818 U1512

U73 U39 L1602
100
/MUTE 2 3 2 3 2 3 MUTE AGND 1 2 1 AOUT16
/MUTE
AGND U40 2 3
1
1
BEAD-3BP
AGND DTB114EK J109
DGND R79 DTC314TK YKC21-3077
1
A-15 10K U812

DGND GND DGND
R1618
A-15 AGND
100
A-15
AGND FRAME
2 3
DTC314TK
1
U1612
AGND
ANALOG IN, MAIN, D1624 / D824
A+5_ADDA C503 A+5_ADDA
C103 0.01
G=-3.0dB
0.01
C101 R101 C501 R501
10/16 R102 R104 10/16 R502 R504
13K AGND 9.1K 10K 13K AGND 9.1K 10K
-10dBV
AIN1 AIN5
8
8
R103
0
0
R503
-10dBV 2 10K R105 -13dBV 2 R505
BAL_IN1 BAL_IN5 10K
1 6 330 1 6 330
C105 R109 3 7 C505 R509 3 7
AIN1+ AIN5+
10/16 13K U101A 5 10/16 13K U501A 5
R107 U101B R507 U501B
4
4
100K R108 C107 NJM2115 100K R508 C507 NJM2115
NJM2115 NJM2115
0
0
100K NON C106 C102 100K NON C506 C502
NON 2200P NON 2200P
R106 R506
330 -13dBV 330
C104 C504
AIN1- AIN5-
0.01 0.01
AGND AGND
VBIAS
C203 A+5_ADDA C603 A+5_ADDA
0.01 0.01
C201 R201 C601 R601

R202 R204 R602 R604
10/16 13K AGND 10/16 13K AGND
9.1K 10K 9.1K 10K
AIN2 AIN6
8
8
0
0
R203 R603
2 R205 2 10K R605
BAL_IN2 10K BAL_IN6
1 6 330 1 6 330
C205 R209 3 7 C605 R609 3 7
AIN2+ AIN6+
10/16 13K U201A 5 10/16 13K U601A 5
R207 U201B R607 U601B
4
4
100K R208 C207 NJM2115 100K R608 C607 NJM2115
NJM2115 NJM2115
0
0
100K NON C206 C202 100K NON C606 C602

NON 2200P NON 2200P
R206 R606
330 330
C204 C604
AIN2- AIN6-
0.01 0.01
AGND AGND

0.01 0.01
C301 R301 C701 R701

10/16 R302 R304 10/16 R702 R704
13K AGND 9.1K 10K 13K AGND 9.1K 10K
AIN3 AIN7
8
8
0
0
R303 R703
2 R305 2 R705
BAL_IN3 10K BAL_IN7 10K
1 6 330 1 6 330
C305 R309 3 7 C705 R709 3 7
AIN3+ AIN7+
10/16 13K U301A 5 10/16 13K U701A 5
R307 R707
U301B U701B
4
4
100K R308 C307 NJM2115 100K R708 C707 NJM2115

NJM2115 NJM2115
0
0
100K NON C306 C302 100K NON C706 C702

NON 2200P NON 2200P
R306 R706
330 330
C304 C704
AIN3- AIN7-
0.01 0.01
AGND
AGND

0.01 0.01
C401 VBIAS C801

R401 R402 R404 R801 R802 R804
10/16 13K AGND 10/16 13K AGND
9.1K 10K 9.1K 10K
AIN4 AIN8
8
8
0
0
R403 R803
2 R405 2 R805
BAL_IN4 10K BAL_IN8 10K
1 6 330 1 6 330
C405 R409 3 7 C805 R809 3 7
AIN4+ AIN8+
10/16 13K U401A 5 10/16 13K U801A 5
R407 R807
U801B
4
4
100K R408 C407 NJM2115 100K R808 C807 NJM2115

U401B NJM2115
0
0
100K NON C406 NJM2115 C402 100K NON C806 C802

NON 2200P NON 2200P
R406 R806
330 330
C404 C804
AIN4- AIN8-
0.01 0.01
AGND AGND
A+5_ADDA
VBIAS
A+5_ADDA
C99
47/16
AGND
AGND
D1624 / D824
77
78
/RST_5 D+5_ADDA
AD-DA, MAIN, D1624 / D824 MSCK_DA
SMUTE R141
DFS_5V 10 C147
/MUTE
/LRCK C146 0.01 U141
BCK_ADDA 10/16
A+5_ADDA 1 28
VDSS CKS2 D824 NON
C140 C139 2 27
C133 C134 MSCK_AD DVDD CKS1
D1624 / D824
0.1 10/16 DGND_ADDA 3 26

10/16 0.1 MCLK CKS0 C142 C141
U131 R131 4 25
PD P/S 0.1 10/16
1 28 10 MSCK_DA 5 24
VREFL VREFR BICK VCOM
AGND C135 2 27 C136 /RST 6 23
0.22 GNDL GNDR 0.22 SDATA AOUTL+ AOUT1+
3 26 BCK_ADDA 7 22 D+5_ADDA
VCOML VCOMR LRCK AOUTL- AOUT1-
4 25 DA_DATA0 8 21
AIN1+ AINL+ AINR+ AIN2+ SMUTE AOUTR+ AOUT2+
D+5_ADDA 5 24 9 20
AIN1- AINL- AINR- AIN2- C132 C131 DFS AOUTR- AOUT2-
6 23 LRCK 10 19 R541
R132 ZCAL VA 0.1 10/16 DEM0 AVSS
7 22 11 18 10
VD AGND DEM1 AVDD C547
10 8 21 12 17 A+5_ADDA
DGND BGND DIF0 VREFH
9 20 13 16
CAL TEST DIF1 VREFL C546 0.01
10 19 AGND 14 15 10/16 U541 FULL SCALE:2.5Vp-p
RST HPFE DIF2 BVSS
11 18 C144 C143 1 28
C137 C138 SMODE2 DFS VDSS CKS2 REF:-13dBV
12 17 MSCK AK4393 0.1 47/16 2 27
10/16 0.01 SMODE1 MCLK DVDD CKS1
13 16 DGND_ADDA 3 26
LRCK FSYNC MCLK CKS0 C542 C541
14 15 AD_DATA0 AGND 4 25
SCLK SDATA PD P/S 0.1 10/16
MSCK_DA 5 24
R133 100 BICK VCOM
DGND_ADDA AK5383 BCK /RST 6 23
SDATA AOUTL+ AOUT9+
LRCK BCK_ADDA 7 22
LRCK AOUTL- AOUT9-
RST_AD DA_DATA4 8 21
SMUTE AOUTR+ AOUT10+
9 20
DFS AOUTR- AOUT10-
D+5_ADDA LRCK 10 19
DEM0 AVSS
11 18
DEM1 AVDD
DGND_ADDA A+5_ADDA 12 17 A+5_ADDA
DIF0 VREFH
C240 C239 R241 13 16
C233 C234 DIF1 VREFL
0.1 10/16 10 C247 14 15
10/16 0.1 DIF2 BVSS
U231 R231 C246 C544 C543
1 28 10 0.01 AK4393 0.1 47/16
VREFL VREFR
AGND C235 2 27 C236 U241
0.22 GNDL GNDR 0.22
3 26 10/16 1 28 AGND
VCOML VCOMR VDSS CKS2
4 25 2 27
AIN3+ AINL+ AINR+ AIN4+ DVDD CKS1
D+5_ADDA 5 24 DGND_ADDA 3 26
AIN3- AINL- AINR- AIN4- C232 C231 MCLK CKS0 C242 C241
6 23 4 25
R232 ZCAL VA 0.1 10/16 PD P/S 0.1 10/16
7 22 MSCK_DA 5 24
VD AGND BICK VCOM
10 8 21 /RST 6 23
DGND BGND SDATA AOUTL+ AOUT3+
CAL TEST LRCK AOUTL- AOUT3-
10 19 AGND DA_DATA1 8 21
RST HPFE SMUTE AOUTR+ AOUT4+
11 18 DFS 9 20
C237 C238 SMODE2 DFS DFS AOUTR- AOUT4-
12 17 MSCK LRCK 10 19 R641
10/16 0.01 SMODE1 MCLK DEM0 AVSS
13 16 11 18 10
LRCK FSYNC DEM1 AVDD C647
14 15 AD_DATA1 12 17 A+5_ADDA
SCLK SDATA DIF0 VREFH
13 16
R233 100 DIF1 VREFL C646 0.01
DGND_ADDA AK5383 BCK 14 15 10/16 U641
DIF2 BVSS
LRCK C244 C243 1 28
VDSS CKS2
RST_AD AK4393 0.1 47/16 2 27
DVDD CKS1
DGND_ADDA 3 26
MCLK CKS0 C642 C641
AGND 4 25
PD P/S 0.1 10/16
MSCK_DA 5 24
BICK VCOM
DGND_ADDA /RST 6 23
SDATA AOUTL+ AOUT11+
BCK_ADDA 7 22
LRCK AOUTL- AOUT11-
A+5_ADDA DA_DATA5 8 21
C340 C339 9 20
C333 C334 DFS AOUTR- AOUT12-
0.1 10/16 D+5_ADDA LRCK 10 19
10/16 0.1 DEM0 AVSS
U331 R331 11 18
DEM1 AVDD
1 28 10 12 17 A+5_ADDA
VREFL VREFR DIF0 VREFH
AGND C335 2 27 C336 R341 13 16
0.22 GNDL GNDR 0.22 DIF1 VREFL
3 26 10 14 15
VCOML VCOMR C347 DIF2 BVSS
4 25 C346 C644 C643
AIN5+ AINL+ AINR+ AIN6+
D+5_ADDA 5 24 AK4393 0.1 47/16
AIN5- AINL- AINR- AIN6- C332 C331 0.01
6 23 U341
R332 ZCAL VA 0.1 10/16 10/16
7 22 1 28 AGND
VD AGND VDSS CKS2
10 8 21 2 27
DGND BGND DVDD CKS1
9 20 DGND_ADDA 3 26
CAL TEST MCLK CKS0 C342 C341
10 19 AGND 4 25
RST HPFE PD P/S 0.1 10/16
11 18 DFS MSCK_DA 5 24
C337 C338 SMODE2 DFS BICK VCOM
12 17 MSCK /RST 6 23
10/16 0.01 SMODE1 MCLK SDATA AOUTL+ AOUT5+
LRCK FSYNC LRCK AOUTL- AOUT5-
14 15 AD_DATA2 DA_DATA2 W301 8 21
SCLK SDATA SMUTE AOUTR+ AOUT6+
JUMPER 9 20
R333 100 DFS AOUTR- AOUT6-
DGND_ADDA AK5383 BCK LRCK 10 19 R741
DEM0 AVSS
LRCK 11 18 10
DEM1 AVDD C747
RST_AD 12 17 A+5_ADDA
DIF0 VREFH
DA_DATA0 W302 13 16 C746 0.01
DIF1 VREFL
JUMPER 14 15 10/16 U741
DIF2 BVSS
C344 C343 1 28
VDSS CKS2
DGND_ADDA AK4393 0.1 47/16 2 27
DVDD CKS1
DGND_ADDA 3 26
MCLK CKS0 C742 C741
AGND 4 25
PD P/S 0.1 10/16
MSCK_DA 5 24
BICK VCOM
A+5_ADDA /RST 6 23
C440 C439 BCK_ADDA 7 22
C433 C434 LRCK AOUTL- AOUT13-
0.1 10/16 DA_DATA6 W701 8 21
10/16 0.1 SMUTE AOUTR+ AOUT14+
U431 R431 LRCK JUMPER 9 20
DFS AOUTR- AOUT14-
1 28 10 D+5_ADDA 10 19
C435 VREFL VREFR C436 R441 DEM0 AVSS
AGND 2 27 11 18
0.22 GNDL GNDR 0.22 DEM1 AVDD
3 26 10 12 17 A+5_ADDA
VCOML VCOMR DIF0 VREFH
4 25 C446 13 16
AIN7+ AINL+ AINR+ AIN8+ DIF1 VREFL
D+5_ADDA 5 24 DA_DATA2 W702 14 15
AIN7- AINL- AINR- AIN8- C432 C431 C447 DIF2 BVSS
6 23 0.01 U441 JUMPER C744 C743
R432 ZCAL VA 0.1 10/16 10/16
7 22 1 28 AK4393 0.1 47/16
VD AGND VDSS CKS2
10 8 21 2 27
DGND BGND DVDD CKS1
9 20 DGND_ADDA 3 26 AGND
CAL TEST MCLK CKS0 C442 C441
10 19 AGND 4 25
RST HPFE PD P/S 0.1 10/16
11 18 DFS MSCK_DA 5 24
C437 C438 SMODE2 DFS BICK VCOM
12 17 MSCK /RST 6 23
10/16 0.01 SMODE1 MCLK SDATA AOUTL+ AOUT7+
LRCK FSYNC LRCK AOUTL- AOUT7-
14 15 AD_DATA3 DA_DATA3 W401 8 21
SCLK SDATA SMUTE AOUTR+ AOUT8+
JUMPER 9 20
R433 100 DFS AOUTR- AOUT8-
DGND_ADDA AK5383 BCK LRCK 10 19 R841
DEM0 AVSS
LRCK 11 18 10 C847
DEM1 AVDD
RST_AD 12 17 A+5_ADDA
DIF0 VREFH
13 16 C846 0.01
DIF1 VREFL
DA_DATA1 W402 14 15 U841
DIF2 BVSS 10/16
JUMPER C444 C443 1 28
VDSS CKS2
DGND_ADDA AK4393 0.1 47/16 2 27
DVDD CKS1
DGND_ADDA 3 26
MCLK CKS0 C842 C841
AGND 4 25
PD P/S 0.1 10/16
MSCK_DA 5 24
BICK VCOM
/RST 6 23
BCK_ADDA 7 22
LRCK AOUTL- AOUT15-
DA_DATA7 W801 8 21
JUMPER 9 20
DFS AOUTR- AOUT16-
LRCK 10 19
A+5_1 D+5_1 DEM0 AVSS
11 18
DEM1 AVDD
A+5_1 D+5_1 12 17 A+5_ADDA
DIF0 VREFH
DA_DATA3 W802 13 16
DIF1 VREFL
AGND DGND_ADDA 14 15
JUMPER DIF2 BVSS
C844 C843
AGND C53 DGND_ADDA DA_DATA[0..7] AK4393 0.1 47/16
C9 DA_DATA[0..7]
0.1 0.1 AD_DATA[0..3]
AD_DATA[0..3]
AGND
DGND DGND D1624 --- W301, 401, 701, 801 ON
D824 --- W302, 402, 702, 802 ON
ANALOG OUT, MAIN, D1624 / D824
C115 A+15
0.01 C915 A+15
0.01
C112
R113 C912
AGND 820 1000p U102A R913
8
NJM4565M -10.01dBv AGND 820 1000p U902A
8
R111 R114 3 NJM4565M
AOUT1+ 1 R911 R914
1.1K 1K 3
AOUT1 AOUT9+ 1
2 C114 1.1K 1K
C515 A+15 AOUT9
C111 2 C914 C1315 A+15
C113 100/16 0.01 C911 0.01
4
R112 3300p R115 R117 C913 100/16
4
AOUT1- R912 3300p R915
1.1K 1K 1000p 47K C512 R917 C1312
R513 AOUT9- R1313
1.1K 1K 1000p 47K
AGND 820 1000p U502A AGND 820 1000p U1302A
8
8
R116 820 C116 NJM4565M NJM4565M

R511 R916 820 C916 R1311
R514 3 R1314 3
0.01 AOUT5+ 1 AOUT13+ 1
1.1K 1K AOUT5 0.01 1.1K 1K AOUT13
A-15 AGND 2 C514 2 C1314
C511 A-15 AGND C1311
C513 100/16 C1313 100/16
4
4
R512 3300p R515 R1312 3300p R1315

R517 R1317
AOUT5- AOUT13-
1.1K 1K 1000p 47K 1.1K 1K 1000p 47K
C212
R213 C516 C1012 C1316
1000p U102B R516 820 R1316 820
AGND 820 R1013
NJM4565M AGND 820 1000p U902B
R214 0.01 0.01
R211 5 NJM4565M
AOUT2+ 7 R1011 R1014
1.1K 1K A-15 AGND 5 A-15 AGND
AOUT2 AOUT10+ 7
6 1.1K 1K
C214 AOUT10
C211 6 C1014
C213 100/16 C1011
R212 3300p R215 R217 3300p C1013 100/16
AOUT2- R1012 R1015
1.1K 1K 1000p 47K C612 R1017 C1412
AOUT10-
R613 1.1K 1K 47K R1413
U502B 1000p U1302B
AGND 820 1000p AGND 820 1000p
R216 820 NJM4565M NJM4565M
R611 R614 R1016 820 R1411 R1414
5 5
AOUT6+ 7 AOUT14+ 7
AGND 1.1K 1K 1.1K 1K
AOUT6 AOUT14
6 C614 AGND 6 C1414
C611 C1411
C315 A+15
3300p C613 100/16 C1413 100/16
0.01 R612 R615 R617 C1115A+15 R1412 3300p R1415 R1417
AOUT6- 0.01 AOUT14-
1.1K 1K 1000p 47K 1.1K 1K 1000p 47K
C312
R313 C1112
1000p U302A R616 820 R1416 820
AGND 820 R1113
8
NJM4565M AGND 820 1000p U1102A
8
R311 R314 3 AGND NJM4565M AGND
AOUT3+ 1 R1111 R1114
1.1K 1K 3
AOUT3 AOUT11+ 1
2 C314 1.1K 1K
C715 A+15 AOUT11
C311 2 C1114 C1515 A+15
C313 100/16 0.01 0.01
C1111
4
R312 3300p R315 R317 3300p C1113 100/16
4
AOUT3- R1112 R1115

1.1K 1K 1000p 47K C712 R1117 C1512
AOUT11-
R713 1.1K 1K 47K R1513
1000p U702A 1000p 1000p U1502A
AGND 820 AGND 820
8
8
R316 820 C316 NJM4565M NJM4565M

R1116 820 C1116
R711 R714 3 R1511 R1514 3
0.01 AOUT7+ AOUT15+ 1
1.1K 1K 1 0.01 1.1K 1K
AOUT7 AOUT15
A-15 AGND 2
C714
2
C1514
C711 A-15 AGND C1511
C713 100/16 C1513 100/16
4
4
R712 3300p R715 R1512 3300p R1515

R717 R1517
AOUT7- AOUT15-
1.1K 1K 47K 1.1K 1K 1000p 47K
1000p
C412
R413 C716 C1212 C1516
1000p U302B R716 820 R1516 820
AGND 820 R1213
NJM4565M AGND 820 1000p U1102B
R411 R414 0.01 NJM4565M 0.01
5
AOUT4+ 7 R1211 R1214
1.1K 1K A-15 AGND 5 A-15 AGND
AOUT4 AOUT12+ 7
6 C414 1.1K 1K AOUT12
C411 6 C1214
C413 100/16 C1211
R412 3300p R415 R417 3300p C1213 100/16
AOUT4- R1212 R1215
1.1K 1K 1000p 47K C812 R1217 C1612
AOUT12-
R813 1.1K 1K 47K R1613
1000p U702B 1000p 1000p U1502B
AGND 820 AGND 820
R416 820 NJM4565M NJM4565M
R811 R814 R1216 820 R1611 R1614
5 5
AOUT8+ AOUT16+ 7
AGND 1.1K 1K 7 1.1K 1K
AOUT8 AOUT16
6 C814 AGND 6 C1614
C811 C1611
C813 100/16 C1613 100/16
R812 3300p R815 R817 R1612 3300p R1615 R1617
AOUT8- AOUT16-
1.1K 1K 47K 1.1K 1K 1000p 47K
1000p
R816 820 R1616 820
D824 NON AGND AGND

D824 NON
A+15
A+15
C54
180/16LXV
AGND
AGND
A-15
C60
47/16 A-15
D1624 / D824
79
80
RS-422 & CONNECT, D1624 / D824
RS422
D1624 / D824
J304
6
5
4
TO MIDI 3
2 D+5
1 DGND D+5
8283M6P
D+5
DGND
J301 U301
9 THRU_OUT R302
16
8 MIDI_IN1 75C1168 10k R303 0 J302
R301 L301
7 MIDI_IN2 100 1 1 2 11
6 MIDI_OUT 3 2 5
5 CONT 4 9
TO MAIN 4 TXD422 15 14 R304 0 L302 4
3 RXD422 13 1 2 8
2 3
1 D+5 10 7
9 11 R305 47 L303 2
BOADIN-9P 12 1 2 6
5 6 1
DGND 7 10
R306 47 L304
1 2 DSUB-9P
8
C301 C302 C303 C304 C305 C306 J303
0.01 non non non non 11
10/16
5
4
R307 9
100 1 S301 4
2 SW SLIDE 1-2 FRAME 8
3 3
7
2
5
6
1
DGND
CONNECT 10
L1001
1 2 DSUB-9P
W1001 DGND
1 AC6.2A BEAD-3BP 1 L1002 2
2 AC6.2B L1003 J1001
3 VDISP 1 2 BEAD-3BP 16
4 DGND L1004 AC6.2A 1
5 D+5 BEAD-3BP 1 2 AC6.2B 11
6 DGND VDISP 6
7 DGND BEAD-3BP 2
L1006 D+5 12
B.IN7P 1 2 D+5 7
L1007 3
1 2 BEAD-3BP 13
8
BEAD-3BP 1 L1008 2 /RST_DISP 4
L1009 /ATN1 14
1 2 BEAD-3BP /ATN2 9
L1010 TXD1 5
W1002 BEAD-3BP 1 2 RXD1 15
1 /RST_DISP L1011 10
2 /ATN1 1 2 BEAD-3BP SCK1 17
3 /ATN2
4 TXD1 BEAD-3BP DSUB15P
L1012
5 RXD1 1 2 DGND
6 SCK1 L1013
7 DGND 1 2 BEAD-3BP
B.IN7P BEAD-3BP
D1624 / D824
MIDI & WORD I/O, D1624 / D824
MIDI
D+5
J202C
21
R201 L101
1 2 24 27
220 BEAD-3BP
1
4
22
2
THRU OUT
5
3
J201 L102
6 THRU_OUT R202 1 2 25 26
5 MIDI_IN1 220
23
4 MIDI_IN2 BEAD-3BP
TO RS422 3 MIDI_OUT DIN5-3 YKF51-5046
2
1 D+5
L103 J202A
1
BOADIN-6P R203 1 2 4 7
220 BEAD-3BP
1
4
2 MIDI IN
2
DGND
5
3
L104
1 2 5 6
31
32
3
BEAD-3BP
DIN5-3 YKF51-5046
D+5
J202B
11
R205 L105
1 2 14 17
220 BEAD-3BP
1
4
12
2
MIDI OUT
5
3
R206 L106
1 2 15 16
220
13
33
34
BEAD-3BP
DIN5-3 YKF51-5046
DGND
WORD I/O
D+5
D+5 U401A
C401 74VHCT04
14
J401 10/16
3
4 WORD OUT 1 2
3 D401 L401
MAIN 2 WORD IN 3 4 DAN202K J402
1 C402 U401B BEAD-3BP BNC
1
74VHCT04 5 6 R401 1 2 2
BOADIN-4P 0.01 U401C 10,1/2W
9 8 74VHCT04 C403
1
DGND U401D R402 47P

74VHCT04 1K
R405
100
U401E U401F
10 11 12 13 R404
100
2
74VHCT04 74VHCT04 C404

D402 R403 47p
R406 DAP202K 75
1M
3
J403
L402 BNC
DGND 1 2 2
BEAD-3BP
1
5
DGND
3
S401 2
SW SLIDE 1-2 FRAME 1
4
DGND
81
82
ROOT, 8345
TO
D1624 / D824
MAIN
J1
1
/OP_RST 2
NEWCLKD OP_D0 3
OP_D1 4 A+5 C4 78M05 R38 C71
OP_D2 5 C2 U1 C5 TO
10/16 0.01 10 0.01
OP_D3 6 1 O I 31/50 POWER
OP_D4 7
G
OP_D5 8 1W
NEWCLOCK OP_D6 9 W3
2
OP_D7 10 A+19 5
OP_A0 11 AGND 4
OP_A1 12 A-15 3
3
OP_D[0..7] OP_A2 13 D+5 2
OP_D[0..7] OP_A3 14 AGND C72 DGND 1
OP_A4 15 0.01
G
/OP_IRQ 16 1 2 B-IN5P
/OP_WR 17 O I
C7 C1 C6 R39
OP_A[0..4] /OP_RD 18 U2
OP_A[0..4] /OP_CS1 19 A-5
10/16 0.01 79M05 1/50 10 1W
/OP_CS2 20
/OP _RST /OP_CS3 21
D+5 /OP _IRQ /OP_CS4 22
/OP_WR /LRCK 23
/OP_RD EXT_LRCK 24 D+5 L7
D+5 25 50uH
DGND /OP _CS3
/OP _CS4
EDGE EDGE FC-25P
DGND WORD_IN
WORD_IN
16M DGND C3 C70
A+5 16M 100/16
EXT_LRCK 47/16
/LRCK 4R8M
A+5 4R8M LTCF_N D+5
AGND LTCF_N V_FIN
A-5 V_FIN C87 DGND GND
WORD_OUT
AGND A-5
14
OPTION\EXTSYNC\MCLK.SCH 0.01
DGND
1
TC & I/O 3 4
2 6
LTCF_N 5
V_FIN U7A
16M 74HC00 U7B
TC 4R8M 74HC00
WORD_IN D+5
WORD_OUT WORD_OUT 74HC00
& EDGE U7D
D+5 13
/OP
_RST /OP
_RST 11
D+5 I/O OP_A4 12 9
DGND OP_D[0..7]
OP_D[0..7] 8
DGND 10
0
OP_A[0..4] OP_A[0..4]
U7C
/OP _IRQ /OP_IRQ 74HC00
A+5 /OP_WR /OP_WR
/OP_RD /OP_RD
A+5 CS_TCG
AGND CS_TCG
CS_TCR CS_TCR
A-5
AGND A-5 12 13
OPTION\EXTSYNC\TC_IO.SCH
U24F
74HC04
10 11
U24E
74HC04 DGND
MCLK, 8345
OP_A[0..4] OP_A[0..4]
CONNECT
OP_D[0..7] OP_D[0..7]
OP_A4
OP_A3
OP_A2
OP_A1
OP_A0
OP_A4
OP_A3
OP_A2
OP_A1
OP_A0
OP_D7
OP_D6
OP_D5
OP_D4
OP_D3
OP_D2
OP_D1
OP_D0
OP_D7
OP_D6
OP_D5
OP_D4
OP_D3
OP_D2
OP_D1
OP_D0
/OP_RD
CONNECT /OP_WR
/OP_CS3 CONNECT /OP_CS4
TC /OP_IRQ
CONNECT /OP_RST
TC 16M 16M
D+5
C67
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
C57 D+5 C66 D+5 D+5 470p D+5
0.01 470p
DGND
U14B
D7
D6
D5
D4
D3
D2
D1
D0
A4
A3
A2
A1
A0
D7
D6
D5
D4
D3
D2
D1
D0
A4
A3
A2
A1
A0
DGND
CSB
CSB
DGND R40
14
C56 C55 C53 C54
RDB
RDB
RSTB
WRB
GND
GND
RSTB
WRB
GND
GND
IRQB
IRQB
74HCU04 100
3 4 1 2 0.01 1 80 0.01 0.01 1 80 0.01
2 GND GND 79 2 GND GND 79
VDD VDD VDD VDD
3 78 3 78
U14A 4 16M TST4 77 4 16M TST4 77
74HCU04 LTCF_N LTCF TST3 LTCF TST3
TC V_FIN
5
FRMP TST2
76 5
FRMP TST2
76
R37 R68 6 75 6 75
7 AUXF TST1 74 7 AUXF TST1 74
1M FRMR TST0 FRMR TST0
8 73 8 73
R36 100 9 FW VITC 72 9 FW VITC 72
X1 100 EDGE FWM CSYB FWM CSYB
10 71 10 71
16MHz 11 FWO VCKI 70 11 FWO VCKI 70
C89 12 C1RB VITI 69 12 C1RB VITI 69
C69 EDGB MCK2 EDGB MCK2
470P 13 NEWCLK1 68 13 NEWCLK2 68
NON UM-1 14 28M MCK1 67 14 28M MCK1 67
GND HXCK WORD_OUT GND HXCK
DGND 15 66 15 66
16 FRMM LRCK 65 16 FRMM LRCK 65
FRMS U16 MPX2 FRMS U17 MPX2
C39 17
C1SB MPX1
64 17
C1SB MPX1
64 D+5
22p 18 UPD65640 63 D+5 18 UPD65640 63
19 TCFM FSYN 62 19 TCFM FSYN 62
C38 20 TCFP NJCK 61 20 TCFP NJCK 61
INTW GND INTW GND DTC114EK D9
DGND 30p 21 60 DTC114EK D10 21 60 U18 LED
EXT_IO /LRCK 22 C3R LTFI 59 C3R LTFI
WORD_IN EXTW TCFI U22 LED 22
EXTW TCFI
59 2 3
CONNECT 23 58 2 3 23 58
R61 24 DIGW Q 57 24 DIGW Q 57
AUXW B R46 AUXW B R45
1
1
CONNECT 25 56 D+5 25 56
26 WREF A 55 270 26 WREF A 55 270
TCCK C3UL TCCK C3UL DGND
R64 100 27
C2R C2UL
54 C79 DGND 27
C2R C2UL
54
28 53 D11 28 53 C81
GND GND 0.01 U23 GND GND
C88 29 52 NON NON 29 52 0.01
0
0
VDD VDD 2 3 VDD VDD
1M 470P 30
C2CK C1UL
51 30
C2CK C1UL
51
R63
R47
1
10 11
12 13
EXT_LRCK C78
DGND NON C80
100 U14E U14F DGND
GND
256F
128F
FS
GND
C3CK
C3S
C1PT
C1NT
GND
C1HB
C1LI
C2PT
C2NT
C2HB
C2LI
C3PT
C3NT
C3HB
C3LI
GND
256F
128F
FS
GND
C3CK
C3S
C1PT
C1NT
GND
C1HB
C1LI
C2PT
C2NT
C2HB
C2LI
C3PT
C3NT
C3HB
C3LI
0.01 0.01
74HCU04 74HCU04
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
A+5 L3 C45 C44

22uH 10/16 0.01 A+5 L6 C51 C50
DGND DTC114EK 22uH
C43 U28 10/16 0.01
DGND 0.01 R53 3 2
L4 1.5k
22uH C49 TP
1
A+5 U20 A+5 0.01 TP2

1
L5
U27 1 16
1
REF VDD 22uH
2 15 AGND U21
1
DTA114EK PD LOCK
D+5 2 3 3 14 TP 3 2 1 16
C61 4 VDDA S2 13 REF VDD 4R8M
AMPI S1 TP3 2
PD LOCK
15
R50 0.01 5 12 R52 U29 3 14 R44 TC
U12A AMPO M2 1.5k VDDA S2
DTC114EK 1.5k R54 6 11 DTA114EK 4 13 100
4
14
C27 74HC74 VSSA M1 AMPI S1
1
U26 220k 7 10 C64 0.01 5 12

0.01 2 3 8 XI CKO 9 R56 6 AMPO M2 11
XO VSS R43 7 VSSA M1 10
S
220k XI CKO
R55 C62
1
2 5 R51 TC9246F 100 8 9
VCC
D Q 100 0.47 XO VSS
3 6 1.5k C60 R57
C Q C65
DGND AGND 15p TC9246F
R
C46 C42 100 0.47
C63
10/16 0.01 15p C48 C47
1
R76 A+5 C58
10/16 0.01
0.01
AGND
C95 10K A+5
0.0022 AGND AGND
R65
DGND NON L2 A+5
R49 C41 C40 22uH C82
100 0.01
0.01
C52 R34 R35
R41
0.1 R67 0.01 D+5
1k
D+5 R48 10k AGND
2
100 AGND 680 1M TP

R42
8
R66 TP1
D+5 1.5k 2 10k
14
1 6 R33
VCC
DGND 3 5 6 U14C
1
A+5 3 7 1 3 1 2 U25B 4
5 VIN OUT R60 74HCU04
74HCU04
3
4
GND DGND U19A 2.2K C37 330
7
R59 C91 U19B U25A

56p
GND
NON NJM2115M C92 U15 U25C 9 8 U14D

A+5 4.7k NJM2115M 74HCU04 5 6
NON 74HCU04 74HCU04
4
VCO
1
AGND AGND
A+5
R58 D12 W2
4.7k NON U25E 11 10
AGND C68 NON
AGND 74HCU04
0.01
A-5 AGND 28M AGND
U25F 13 12
A-5 9 8 U25D 74HCU04
74HCU04
W1
AGND 0 R62
NON
C73 AGND
NON
2
D13
NON C75
NON
1
3
AGND C74 AGND

NON
D1624 / D824
83
84
A+5
XLR-3-31
3
TC-I/O, 8345 L8
C59 J7
D14 R69 10/16 BEAD
A+5 DAN202K 1 2 2 1
1
D15 10k R70
R4 1M DAN202K
3
4
100K
1
R29
D1624 / D824
R28 1M
R71 AGND A+5
6
5
8
R1 U5 AGND
3
100 2.7K
CS_TCG 100 2 D2 C16
OP_A3
OP_A2
OP_A1
OP_A0
CONNECT CS_TCG + R2
/OP_WR 6 5 4 3 7 DAN202K 10/16 L9
1
10K
/OP_RD - 3 1 2
U24C U24B A+5 TC IN
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
3
74HC04 74HC04 NJM311M BEAD
1
4
C29 R5 R6
0.01 10K R11 D1 R3
10K
FSI
A3
A2
A1
A0
NJ
CSB
FSO
TCR
LTC
1K
RDB
WRB
LTCF
NJGT
LTCB
LTCO
TNRZ
1
TGEN
PORT
DAN202K 100K
OP_D[0..7] OP_D[0..7]
CONNECT
OP_A[0..4] OP_D0 52 32
OP_A[0..4] D0 EMPT
OP_D1 53
D1 FRCI
31
OP_D2 54
D2 FRCO
30
C11 R12
OP_D3 55 29 D+5 C15
D3 SFMI 0.01 10/16 1K
OP_D4 56
D4 U3 SFMO
28 AGND AGND
/OP_WR OP_D5 57 27 A+5 R7
/OP_WR D5 VDD C76
CONNECT /OP_RD /OP_RD 58
GND TCG GND
26 2K
59 25 C28 0.01
TEST NTM
OP_D6 60 24 0.01
D6 FSYN
OP_D7 61
D7 TRGI
23 C8
/OP_IRQ 62 22 XLR-3-32
8
/OP_IRQ IRQB TRGO R8 5600P
CONNECT /OP_RST 63 21 DGND C9 L1 J8
/OP_RST RSTB NCKI 10K BEAD
64 20 2 47/16
SBYB NCKO
D+5 A+5 1 1 2 2 1
C93 3 TC OUT
NON R10
150
R9
4
R14 U6A
3
4
C35 47K C86
FSL0
FSL1
DF
CDWN
STIL
RVRS
SYNC
EDGE
4R8M
256F
2BCO
2BCI
BCO
BCI
SFTR
SFTO
SFTI
RPEO
RPEI
100p 4.7k NJM4580 47p
AGND C90 A-5
0.01
1
2
3
4
5
6
7
8
9
R73
10
11
12
13
14
15
16
17
18
19
2K
DGND R13
4.7k C10 R75 AGND
0.01 C83 47K
4R8M
NEWCLK EDGE 5600P C85
C14 R72 C84 47p
AGND 10/16 6 47/16
10K 7 1 2
5
R74 L10
150
C94 U6B BEAD
D+5
OP_A3
OP_A2
OP_A1
OP_A0
NON NJM4580
C30
NEWCLK LTCF_N
LTCF_N
CONNECT CS_TCR /OP_WR 0.01
/OP_RD
3
D+5 U8 WORD
1 16 D4 BNC
33
32
31
30
29
28
27
26
25
24
23
C33 1A VCC
2 15 R16 J3
1
0.01 D+5 1B 1S
3 14 2
2R 1R
4 13 IN
2S 1Y
A3
A2
A1
A0
X1I
5 12 100
CSB
1
LTC
X1O
3
RDB
2A 3A
WRB
R17
LTCF
6 11 C17
OP_D0 2B 3S 75
34 22 7 10 47p
10
5
IO0 LDTI 2Y 3R D5
DGND OP_D1 35 21 8 9
3
OP_D2 IO1 LDTO GND 3Y

36 20 R32 1
IO2 LCKI
1
OP_D3 37 19 R15 NEWCLK SN75124 2
S
IO3 LCKO 100 S1
OP_D4 38 U4 18 9 12 NEWCLK 6 5 D6 3 DGND
VCC
IO4 8M Q D WORD_IN SSSF1
39 17 8 11
VDD TCR GND Q C 16M
1
OP_D5 40 16 100 U13C BNC
R
IO5 VITC
4
OP_D6 41 15 74HC04 R18 J4

OP_D7 42 IO6 CSYB 14 U12B DGND 2 OUT
IO7 SYNC
43 13 74HC74 C31
13
44 IRQB VCKO 12 10
1
RSTB VCKI
C18
3
0.01 47p
C36 DGND
B1M
XOUT
FRMP
VDDT
FLMK
NTSB
SMPB
VSBO
VSYB
X0O
X0I
100p U9 D3
1 16
1A VCC R19
1
2
3
4
5
6
7
8
9
1
2 15
10
11
1B 2F
DGND 3
1C 2E
14 1k
R31 4 13
1D 2D
NEWCLK V_FIN NEWCLK 100 5
1E 2C
12
WORD_OUT 9 8 6 1F 2B 11
DGND 7 10
U13D 8 1Y 2A 9
GND 2Y
D+5 A+5 74HC04
COMP_SYNC SN75123
A+5
D+5 A+5
C13 C12 C26
10/16 10/16 DGND
DGND AGND 0.01
A+5
GND DGND AGND
A-5
2
4
6
8
10
12
14
C25 C23
10/16
3
A-5 U11
S1
2Y
0.01
NC
SIN
NJM2207M
VIN
-VSY
-CSY
C32 D+5 C77 D+5

R24 D8
6
7
0.01 0.01 3.3k BNC VIDEO
14
14
1
C20 C19 R20 J5

5 8 2
IN
VHI
VCC
VOUT
S2
Y1
VEE
CSY
1 2 1 2
0.01 4 1 10/16 1k
1
0
0
U13A U24A R26 C21
1
3
5
7
9
75 47p
11
13
5
74HC04 74HC04
3
2
3
3 4 9 8
BNC
U10
0
U13B U24D R23 R22 R21 1 J6
74HC04 74HC04 C24 NJM592M 10k 10k D7 100k 2 2
11 10 R30 R25 C34 3
1
12 13 R27 THRU
1
220p 1M 0.01 C22

U13E
4
74HC04 100 100 47p

U13F DGND
DGND DGND
74HC04 S2
SSSF1 FRAME
AGND A-5
ROOT, 5042 / 5043
BALANCE IN
BALANCE IN TO MAIN
J1 J4
26 L802 N.C. 17
1 L801 1 2 HOT_IN8 16 BALANCE OUT 9..16CH 5042(D824) & 5043(D1624)
HOT_IN8 BAL_IN8
14 1 2 COLD_IN8 15 J2
COLD_IN8 GNDI8
2 L702 GND_IN8 14 L1604 26
GND_IN8 BAL_IN7 L1603
15 L701 1 2 HOT_IN7 13 HOT_OUT16 1 2 1
HOT_IN7 GNDI7 AOUT16+ HOT_OUT16
3 1 2 COLD_IN7 12 COLD_OUT16 1 2 14
COLD_IN7 BAL_IN6 COLD_OUT16
16 L602 GND_IN7 11 GND_OUT16 L1504 2
GND_IN7 GNDI6 AOUT15+ GND_OUT16
4 L601 1 2 HOT_IN6 10 HOT_OUT15 L1503 1 2 15
HOT_IN6 BAL_IN5 HOT_OUT15
17 1 2 COLD_IN6 9 COLD_OUT15 1 2 3
COLD_IN6 GNDI5 AOUT14+ COLD_OUT15
5 L502 GND_IN6 8 GND_OUT15 L1404 16
GND_IN6 BAL_IN4 GND_OUT15
18 L501 1 2 HOT_IN5 7 HOT_OUT14 L1403 1 2 4
6 1 2 COLD_IN5 6 COLD_OUT14 1 2 17
COLD_IN5 BAL_IN3 COLD_OUT14
19 L402 GND_IN5 5 GND_OUT14 L1304 5 BALANCE
GND_IN5 GNDI3 AOUT12+ GND_OUT14
7 L401 1 2 HOT_IN4 4 HOT_OUT13 L1303 1 2 18 OUTPUT
HOT_IN4 BAL_IN2 HOT_OUT13
20 1 2 COLD_IN4 3 COLD_OUT13 1 2 6
COLD_IN4 GNDI2 AOUT11+ COLD_OUT13
8 L302 GND_IN4 2 GND_OUT13 L1204 19 9--16CH
GND_IN4 BAL_IN1 GND_OUT13
21 L301 1 2 HOT_IN3 1 HOT_OUT12 L1203 1 2 7
9 1 2 COLD_IN3 COLD_OUT12 1 2 20 5042(D824)
COLD_IN3 COLD_OUT12
22 L202 GND_IN3 FC 17P GND_OUT12 L1104 8 &
GND_IN3 AOUT9+ GND_OUT12
10 L201 1 2 HOT_IN2 HOT_OUT11 L1103 1 2 21 5043(D1624)
HOT_IN2 HOT_OUT11
23 1 2 COLD_IN2 COLD_OUT11 1 2 9
COLD_IN2 COLD_OUT11
11 L102 GND_IN2 GND_OUT11 L1004 22
GND_IN2 GND_OUT11 L1003
24 L101 1 2 HOT_IN1 HOT_OUT10 1 2 10
HOT_IN1 HOT_OUT10
12 1 2 COLD_IN1 A+15 COLD_OUT10 1 2 23
COLD_IN1 MUTE COLD_OUT10
25 GND_IN1 GND_OUT10 L904 11
GND_IN1 A+15 GND_OUT10
13 N.C. A+15 HOT_OUT9 L903 1 2 24
AGND1 HOT_OUT9
27 COLD_OUT9 1 2 12
A-15 A+15 COLD_OUT9
GND_OUT9 25
AGND1 GND_OUT9
DSUB-25P A-15 13
A-15
AGND1 27
AGND1 BAL_IN.SCH AGND1 A-15 BLO_9_16.SCH
DSUB-25P
AGND1 J3
J5 L804 26
J6 17 HOT_OUT8 L803 1 2 1
AOUT8+ HOT_OUT8
8 16 COLD_OUT8 1 2 14
COLD_OUT8
7 15 GND_OUT8 L704 2
AOUT7+ GND_OUT8
6 14 HOT_OUT7 L703 1 2 15
HOT_OUT7
5 13 COLD_OUT7 1 2 3
AOUT6+ COLD_OUT7
4 12 GND_OUT7 L604 16
GND_OUT7
3 11 HOT_OUT6 L603 1 2 4
AOUT5+ HOT_OUT6
2 10 COLD_OUT6 1 2 17
COLD_OUT6
1 9 GND_OUT6 L504 5
AOUT4+ GND_OUT6
8 HOT_OUT5 L503 1 2 18
non HOT_OUT5
7 COLD_OUT5 1 2 6 BALANCE
AOUT3+ COLD_OUT5
TO MAIN 6 GND_OUT5 L404 19 OUTPUT
GND_OUT5
5 HOT_OUT4 L403 1 2 7
AOUT2+ HOT_OUT4
4 COLD_OUT4 1 2 20 1--8CH
COLD_OUT4
3 GND_OUT4 L304 8
AOUT1+ GND_OUT4
2 HOT_OUT3 L303 1 2 21 5043(D1624) ONLY
HOT_OUT3
1 COLD_OUT3 1 2 9
COLD_OUT3
5042(D824) : FC 8P GND_OUT3 L204 22
GND_OUT3
5043(D1624) : FC17P HOT_OUT2 L203 1 2 10
HOT_OUT2
COLD_OUT2 1 2 23
MUTE COLD_OUT2
GND_OUT2 L104 11
GND_OUT2
A+15 A+15 HOT_OUT1 L103 1 2 24
W1 HOT_OUT1
COLD_OUT1 1 2 12
A+15 COLD_OUT1
1 GND_OUT1 25
AGND1 GND_OUT1
2 13
A-15
TO MAIN 3 27
4 MUTE AGND1 A-15 BLO_1_8.SCH
DSUB-25P
BOADIN-4P BALANCE OUT 1..8CH 5043(D1624) ONLY
AGND1
A-15 AGND1
D1624 / D824
85
86
BALANCE IN, 5042 / 5043
A+15 A+15
C1 G=-5.8dB C5 G=-5.8dB
0.01 0.01
D1624 / D824
R106 R506
5.6k 5.6k
C102 C502
R104 C106 C104 W101 R504 C506 C504 W501
47/16 47/16
8
8
22k NON JUMPER 22k NON JUMPER
COLD_IN1 47p COLD_IN5 47p
2 -10dBv 2 -10dBv
1 1
BAL_IN1 BAL_IN5
3 3
HOT_IN1 HOT_IN5
U1A C105 U3A C505
R103 R503
C101 4565 NON C501 4565 NON
4
4
47/16 22k R107 47/16 22k R507
R102 R101 R105 C103 NON R502 R501 R505 C503 NON
100k 100k 5.6k 47p 100k 100k 5.6k 47p
C2 C6
GND_IN1 GNDI1 GND_IN5 GNDI5
0.01 0.01
A-15 G=-5.8dB A-15 G=-5.8dB
R206 R606
5.6k 5.6k
C202 C602
R204 C206 C204 W201 R604 C606 C604 W601
47/16 47/16
0
0

6 -10dBv 6 -10dBv
7 7
BAL_IN2 BAL_IN6
5 5
HOT_IN2 HOT_IN6
U1B C205 U3B C605
R203 R603
C201 4565 NON C601 4565 NON
0
0
47/16 22k R207 47/16 22k R607

R202 R201 R205 C203 NON R602 R601 R605 C603 NON
100k 100k 5.6k 47p 100k 100k 5.6k 47p
A+15
A+15
C9
47/16
AGND1
C10 A+15 A+15
47/16 C3 G=-5.8dB C7 G=-5.8dB
A-15 0.01 0.01
A-15 AGND R306 R706
5.6k 5.6k
C302 C702
R304 C306 C304 W301 R704 C706 C704 W701
47/16 47/16
8
8

2 -10dBv 2 -10dBv
1 1
BAL_IN3 BAL_IN7
3 3
HOT_IN3 HOT_IN7
U2A C305 U4A C705
R303 R703
C301 4565 NON C701 4565 NON
4
4
47/16 22k R307 47/16 22k R707

R302 R301 R305 C303 NON R702 R701 R705 C703 NON
100k 100k 5.6k 47p 100k 100k 5.6k 47p
C4 C8
0.01 0.01
A-15 A-15
G=-5.8dB
R406 G=-5.8dB R806

5.6k 5.6k
C402 C802
R404 C406 C404 W401 R804 C806 C804 W801
47/16 47/16
0
0

6 -10dBv 6 -10dBv
7 7
BAL_IN4 BAL_IN8
5 5
HOT_IN4 HOT_IN8
U2B C405 U4B C805
R403 R803
C401 4565 NON C801 4565 NON
0
0
47/16 22k R407 47/16 22k R807

R402 R401 R405 C403 NON R802 R801 R805 C803 NON
100k 100k 5.6k 47p 100k 100k 5.6k 47p
BALANCE OUT 1 - 8CH, 5042 / 5043
A+15 A+15
C25 C17
0.01 0.01 5043(D1624) ONLY
R811
G=5.8dB
R411
1..8CH
9.1k 9.1k
8
8
C810 C812 C410 C412
C807 2 100p 220/10 C407 2 100p 220/10
R808 R408
47/16 4.7k 1 47/16 4.7k 1
HOT_OUT8 HOT_OUT4
3 DTC314TK 3 DTC314TK
AOUT8+ U801A R813 AOUT4+ U401A R413
C808 U802 C408 U402
4580 100 2 3 4580 100 2 3
NON NON
4
4
R810 1/4W R410 1/4W
R815 R415
10k 10k
1
1
C26 100k C18 100k
GND_OUT8 GND_OUT4
0.01 0.01
1
1
R816 R416
A-15 100k 2 3 A-15 100k 2 3
U801B U401B
R809 5 4580 U803 R409 5 4580 U403
R814 R414
4.7k COLD_OUT8 4.7k COLD_OUT4
6 6
100 100
C809 1/4W C813 C409 1/4W C413
NON 100p 220/10 NON 100p 220/10
C811 C411
R812 9.1k R412 9.1k

A+15 A+15
C23 C15
0.01 0.01
R711 R311
9.1k 9.1k
8
8
C710 C712 C310 C312
C707 2 100p 220/10 C307 2 100p 220/10
R708 R308
47/16 4.7k 1 47/16 4.7k 1
HOT_OUT7 HOT_OUT3
C708 U702 C308 U302
4580 100 2 3 4580 100 2 3
4
4
NON 1/4W NON 1/4W
R710 R715 R310 R315
10k 10k
1
1
C24 100k C16 100k

GND_OUT7 GND_OUT3
0.01 0.01
1
1
R716 R316
A-15 100k 2 3 A-15 100k 2 3
U701B U301B
5 4580 U703 5 4580 U303
R709 R714 R309 R314
4.7k COLD_OUT7 A+15 4.7k COLD_OUT3
6 6
100 100
C709 1/4W C713 C309 1/4W C313
NON 100p 220/10 A+15 NON 100p 220/10
C711 C311
C27
R712 9.1k 47/16 R312 9.1k
AGND1
A+15 A+15
C21 C28 C13
0.01 47/16 0.01
A-15
R611 R211
9.1k A-15 AGND1 9.1k
8
8
C610 C612 C210 C212

C607 2 100p 220/10 C207 2 100p 220/10
R608 R208
47/16 4.7k 1 47/16 4.7k 1
HOT_OUT6 HOT_OUT2
C608 U602 C208 U202
4580 100 2 3 4580 100 2 3
4
4
NON 1/4W NON 1/4W

R610 R615 R210 R215
10k 10k
1
1
C22 100k C14 100k

GND_OUT6 GND_OUT2
0.01 0.01
1
1
R616 R216
A-15 100k 2 3 A-15 100k 2 3
U601B U201B
R609 5 4580 U603 R209 5 4580 U203
R614 R214
6 6
100 100
C609 1/4W C613 C209 1/4W C213
NON 100p 220/10 NON 100p 220/10
C611 C211
R612 9.1k R212 9.1k

A+15 A+15
C19 C11
0.01 0.01
R511 R111
9.1k 9.1k
8
8
C510 C512 C110 C112

C507 R508 2 100p 220/10 C107 R108 2 100p 220/10
47/16 1 47/16 1
4.7k HOT_OUT5 4.7k HOT_OUT1
C508 U502 C108 U102
4580 100 2 3 4580 100 2 3
4
4
NON 1/4W NON 1/4W

R510 R515 R110 R115
10k 10k
1
1
C20 100k C12 100k

GND_OUT5 GND_OUT1
1
1
0.01 0.01
R516 R116
A-15 100k 2 3 A-15 100k 2 3
U501B U101B
5 4580 U503 5 4580 U103
R509 R514 R109 R114
6 6
100 100
C509 C513 C109 C113
1/4W 1/4W
NON C511 100p 220/10 NON C111 100p 220/10
R512 9.1k R112 9.1k

MUTE
D1624 / D824
87
88
BALANCE OUT 9 - 16CH, 5042 / 5043
A+15 A+15
C43 C35
0.01 0.01 G=5.8dB
R1611 R1211
9..16CH
D1624 / D824
9.1k 9.1k 5042(D824) & 5043(D1624)
8
8
C1610 C1210 C1212
C1612
C1607 2 100p C1207 2 100p 220/10
R1608 220/10 R1208
47/16 4.7k 1 47/16 4.7k 1
HOT_OUT16 HOT_OUT12
AOUT16+ U1601A R1613 R1615 AOUT12+ U1201A R1213
C1608 U1602 C1208 U1202
4580 100 100k 2 3 4580 100 2 3
4
4
NON 1/4W NON 1/4W
R1210 R1215
R1610 10k
1
1
C44 C36 100k
10k
GND_OUT16 GND_OUT12
0.01 0.01
1
1
R1616 R1216
A-15 100k 2 3 A-15 100k 2 3
U1601B U1201B
R1609 5 4580 U1603 R1209 5 4580 U1203
R1614 R1214
6 100 6
100
C1609 1/4W C1613 C1209 1/4W C1213
NON C1611 100p 220/10 NON C1211 100p 220/10
R1612 9.1k R1212 9.1k

A+15 A+15
C41 C33
0.01 0.01
R1511 R1111
9.1k 9.1k
8
8
C1510 C1110
C1512 C1112
100p
C1507 2 C1107 2 100p 220/10
R1508 220/10 R1108
47/16 4.7k 1 47/16 4.7k 1
HOT_OUT15 HOT_OUT11
AOUT15+ R1513 AOUT11+ U1101A R1113
C1508 U1501A U1502 C1108 U1102
100 4580 100
4580 2 3 2 3
4
4
NON 1/4W NON 1/4W
R1510 R1515 R1110 R1115
10k
1
1
10k C42 100k C34 100k

GND_OUT15 GND_OUT11
0.01 0.01
1
1
R1516 R1116
A-15 100k 2 3 A-15 100k 2 3
U1501B U1101B
5 4580 U1503 A+15 5 4580 U1103
R1509 R1514 R1109 R1114
6 6
100 100
C1509 1/4W C1513 A+15 C1109 1/4W C1113
NON 220/10 NON 220/10
C1511 100p C45 C1111 100p
47/16
R1512 9.1k AGND1 R1112 9.1k
A+15 C46 A+15
C39 C31
47/16
0.01 A-15 0.01
R1411 R1011
A-15 AGND1
9.1k 9.1k
8
8
C1410 C1010
100p C1412 C1012
C1407 2 220/10 C1007 2 100p 220/10
R1408 R1008
47/16 4.7k 1 47/16 4.7k 1
HOT_OUT14 HOT_OUT10
AOUT14+ R1413 AOUT10+ U1001A R1013
C1408 U1401A U1402 C1008 U1002
100 4580 100
4580 2 3 2 3
4
4
NON 1/4W NON 1/4W

R1410 R1415 R1010 R1015
10k 10k
1
1
C40 100k C32 100k

GND_OUT14 GND_OUT10
0.01 0.01
1
1
R1416 R1016
A-15 100k A-15 100k
2 3 2 3
U1401B U1001B
R1409 5 4580 U1403 R1009 5 4580 U1003
R1414 R1014
6 100 6
C1413 100
C1409 1/4W C1009 1/4W C1013
NON 220/10 NON 220/10
C1411 100p C1011 100p
R1412 9.1k R1012 9.1k

A+15 A+15
C37 C29
0.01 0.01
R1311 R911
9.1k 9.1k
8
8
C1310
C1312 C910 C912
C1307 2 100p C907 2 100p
R1308 220/10 R908 220/10
47/16 1 47/16 1
4.7k HOT_OUT13 4.7k HOT_OUT9
3 R1313 DTC314TK 3 DTC314TK
AOUT13+ U1301A AOUT9+ U901A R913
C1308 U1302 C908 U902
4580 100 2 3 4580 100 2 3
4
4
NON 1/4W NON 1/4W

R1310 R1315 R910 R915
10k 10k
1
1
C38 100k C30 100k

GND_OUT13 GND_OUT9
1
1
0.01 0.01
R1316 R916
A-15 100k 2 3 A-15 100k 2 3
U1301B U901B C913
5 U1303 5 4580 220/10 U903
R1309 4580 R1314 R909 R914
6 6
100 100
C1309 C1313 C909
1/4W 1/4W
NON 220/10 NON
C1311 100p C911 100p
R1312 9.1k R912 9.1k
MUTE
ROOT, 8350
5 A+15 A+5_PLL D+5 D+5 D+5
U4 78M05 C24
4 AGND 3 1
(MSCK PLL)
3 A-15 I O C13 A+5_PLL C21
G
W1 2 D+5 100/16MVY
L1 22uH/LFC32 10/16MV
D+5 0.01 DGND
10
10
4
14
BOARDIN 5P 1 C5 C23 U8B U9B U9A
C22
2
0.1 C15 C16
0.1 C9
S
S
S
0.01 0.01
5 C14 10/16MV 12 9 12 9 2 5
4 AGND_PLL DGND DGND GND U3
0.01 DGND
11
D Q
8 128 11
D Q
8 3
D VCC Q
6
100/16MVY TP1 C Q
3 D+5 D+5 R1 1 16 C Q C R Q
L2 REF VDD
R
non
R
2 2 15 D+5 C25
1
J4 PD LOCK 74VHC74 74VHC74 74VHC74
1 56uH PD 3 14
4
14
1
R2 VDDA S2
13
13
8263M5P C11 C3 C4 DGND 4 13 (LOCK_LRCK) R5
AMPI S1 100
1
10/16MV 0.1 0.1 5 12 0.01 DGND
S
220K
1
J1 C12 R3 AMPO M2
6 11 2 5 BCK
VCC
10/16MV VSSA M1 R4 D Q U5C
1 DGND AD0 7 10 3 6
14
100 XI CKO C Q
2 SOUT_DI0 0.01 8 9 EXC3BB102 10 BCK
1
R
C10 XO VSS
3 AD1 C6 D+5 C17 1 2 8
4 SOUT_DI1 15p 0.47 TC9246F U8A 9 io.sch
1
C18 U10A
5 AD2 D+5 74VHC74
6 SOUT_DI2 DGND 0.01 74VHCU04 74VHC32
MSCK
U5A
14
7 AD3 74VHC32 AGND_PLL U5B LRCK
8 SOUT_DI3 1 LRCK1 4
9 3 6 DATA_OUT[1..4]
DATA_OUT[1..4]
10 DA_DATA0 DGND 2 5 D+5
11 DA_DATA1 DATA_IN[1..4]
DATA_IN[1..4] D+5
12 DA_DATA2 74VHC32 DGND
13 DA_DATA3 SOUT_DI[0..3]
14 1 AES/EBU I/O DGND
15 DA_DATA[0..7]
INT_BCK
16 LRCK_RST
17 R6 100 BCK
LRCK
FC 17P
DGND R7 100 dif1.sch dif2.sch dif3.sch dif4.sch

C26
39p
MSCK MSCK MSCK MSCK
DATA_OUT1
DATA_IN1
DATA_OUT2
DATA_IN2
DATA_OUT3
DATA_IN3
DATA_OUT4
DATA_IN4
J2 BCK BCK BCK BCK

DGND
LRCK DATA_OUT1 LRCK DATA_OUT2 LRCK DATA_OUT3 LRCK DATA_OUT4
1 AD0 AD1 AD2 AD3
AD0 DATA_IN1 AD1 DATA_IN2 AD2 DATA_IN3 AD3 DATA_IN4
2 /RST SOUT_DI0 SOUT_DI1 SOUT_DI2 SOUT_DI3
SOUT_DI0 SOUT_DI1 SOUT_DI2 SOUT_DI3
3 OP_D0 DA_DATA0 DA_DATA1 DA_DATA2 DA_DATA3
DA_DATA0 DA_DATA1 DA_DATA2 DA_DATA3
4 OP_D1
5 OP_D2 WORD_DIF1
WORD_DIF1 WORD_DIF2 WORD_DIF2 WORD_DIF3 WORD_DIF3 WORD_DIF4 WORD_DIF4
6 OP_D3 /AES_ON
/AES_ON LRCK_RST
7 OP_D4
8 OP_D5
9 OP_D6
/OP_RD /OP_RD /OP_RD /OP_RD
10 OP_D7
/OP_WE /OP_WE /OP_WE /OP_WE
11 OP_A0 /CS_DIF1 /CS_DIF2 /CS_DIF3 /CS_DIF4
/CS_DIF1 /CS_DIF2 /CS_DIF3 /CS_DIF4
12 OP_A1
/RST /RST /RST /RST
13 OP_A2 D+5 D+5 D+5 D+5
14 OP_A3
OP_D[0..31] D+5 OP_D[0..31] D+5 OP_D[0..31] D+5 OP_D[0..31] D+5
15 OP_A4
OP_A[0..19] DGND OP_A[0..19] DGND OP_A[0..19] DGND OP_A[0..19] DGND
16
OP_D[0..31]
17 /OP_WE DGND DGND DGND DGND
18 /OP_RD
19 /AESEBU A+5_PLL A+5_PLL A+5_PLL A+5_PLL
20 OP_A13
A+5_PLL A+5_PLL A+5_PLL A+5_PLL
21 OP_A14
AGND_PLL AGND_PLL AGND_PLL AGND_PLL
22 OP_A15
23 DIF1 AGND_PLL DIF2 AGND_PLL DIF 3 AGND_PLL DIF 4 AGND_PLL
24 OP_A16
25 OP_D[0..31]
OP_A[0..19]
FC 25P OP_A[0..19]
J3 DGND /OP_RD
1 /OP_WE
2 /RST /RST
3 OP_D0
4 OP_D1 U5D
5 OP_D2 /CS_DIF[1..4] 12 74VHC32
6 OP_D3 11
7 OP_D4 13
8 OP_D5 D+5
9 OP_D6
10 OP_D7
11 OP_A0 U1 U2C U2D U2E U2F U10B U10C U10D U10E U10F
12 OP_A1 74VHC138 5 6 9 8 11 10 13 12 3 4 5 6 9 8 11 10 13 12
13 OP_A2 OP_A13 1 15 /CS_DIF1
A Y0 74VHC04 74VHC04 74VHC04 74VHC04 74VHCU04 74VHCU04 74VHCU04 74VHCU04 74VHCU04
14 OP_A3 OP_A14 2 14 /CS_DIF2
B Y1
15 OP_A4 D+5 C2 3 13 /CS_DIF3
0.01 C Y2 DGND
16 12 /CS_DIF4
Y3
17 /OP_WE DGND 11 DGND
Y4
18 /OP_RD DGND 6 10
G1 Y5
19 /AESEBU 4 9
G2A Y6
20 OP_A13 OP_A15 D+5 5 7
G2B Y7
21 OP_A14
14
1 2 16
22 OP_A15
VCC
1
2
3
23
U2A 74VHC04
24 OP_A16 C1
25 S1 0.01
OP_A16 SSSS91
DGND
FC 25P R8 3 4
DGND 47k S1(A15) 1-2 2-3 1-2 2-3
1
2
3
U2B 74VHC04 S2 S2(A16) 1-2 1-2 2-3 2-3
#1 #2 #3 #4
DGND SSSS91
D1624 / D824
89
90
DIF1, 8350
TP3 TP2
non SMD non SMD
D1624 / D824
1
1
MSCK
MSCK
BCK
BCK
LRCK
LRCK
WORD_DIF2
WORD_DIF2
WORD_DIF1 C112
WORD_DIF1 L101
A+5_PLL 10/16MV C115
22uH/LFC32 10/16MV
TP101
D+5 C101 C102 C103 C104 C105 non C113
10/16MV 0.01 0.01 0.01 0.01 (LOCK AES/EBU) 0.01 C114
0.01
Hi : LOCK
R104 4.7K AGND_PLL
1 16
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
R105 REF VDD
10K 2 15
PD LOCK
DGND 3 14
R103 R106 VDDA S2
5.6K 4 13
AMPI S1
VSS
VDD
BCKI
100 5 12
BCKO
LRCKI
AMPO M2
W_IN2
W_IN1
R107
FS256I
LRCKO
6 11
W_OUT
FS256O
FCONT2
VSSA M1
/LOCK2B
TDO_FS1O
PCMBW0
PCMBW1
CK_SEL0
CK_SEL1
CK_SEL2
1 80 R102 100 C111 7 10
2 79 8 9
TDO_EMPO MCK2 15P C110 0.01 XO VSS R108
/PLL2_CONTB
3 78
PI VSS C108 0.47 EXC3BB102
4 77 U102 TC9246F
/AES_ON PO /PLL1_CONTB 0.01
5 76
TEST1 /LOCK1B R101
OP_A[0..19] 6 75 100
OP_A[0..19] TEST2 FCONT1
7 74
VDD PD1
OP_A4 8 73 AGND_PLL 256FS_1
A4 MCK1
OP_A3 9 72
A3 DO_SEL0
OP_A2 10 71
A2 DO_SEL1
OP_A1 11 70
A1 ADAT_MD
OP_A0 12 69
A0 DO2 R109
/OP_WE 13 68 DATA_OUT1
/OP_WE /WRB DO1 DATA_OUT1
/OP_RD 14 67 100
/OP_RD /RDB DO_EMPI
15 U101 66
VSS VSS
/CS_DIF1 /CSB VDD
/RST 17 64
/RST /RESETB DO_FS0I
OP_D0 18 63
C107 D0 DO_FS1I
OP_D1 19 62
100P D1 SOUT_DI
OP_D2 20 61
D2 SOUT2_78
OP_D3 21 60 >
D3 SOUT2_56
DGND OP_D4 22 59 >
D4 SOUT2_34 R110
OP_D5 23 58 >
D5 SOUT2_12
OP_D6 24 57 100
D6 VSS
OP_D7 25 56 >
D7 SOUT1_78
26 55 >
CTL_PIN SOUT1_56
OP_D[0..7] 27 54
OP_D[0..7] VDD SOUT1_34
28 53
VSS SOUT1_12
29 52
/EN_IFB DI_EMPO
30 51
SINA_MD DI_FS0O
SOUT1_MD
SOUT2_MD
TDI_FS1I
TDI_FS0I
TDI_EMPI
SINA_12
SINA_34
SINA_56
SINA_78
VSS
VDD
SINB_12
SINB_34
SINB_56
SINB_78
SIN_DIF
DI1
DI2
DI_SEL
DI_FS1O
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
AD0 DATA_IN1
AD0 DATA_IN1
DA_DATA0
DA_DATA0
SOUT_DI0
SOUT_DI0
D+5 A+5_PLL
D+5 A+5_PLL
DGND AGND_PLL
DGND AGND_PLL
DIF2, 8350
MSCK
MSCK
BCK
BCK
LRCK
LRCK
WORD_DIF3
WORD_DIF3
WORD_DIF2 C212
WORD_DIF2 L201
A+5_PLL 10/16MV C215
22uH/LFC3210/16MV
TP201
D+5 C202 C203 C204 C205 non C213
0.01 0.01 0.01 0.01 (LOCK AES/EBU) 0.01 C214
0.01
Hi : LOCK
R204 4.7K AGND_PLL
1 16
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
R205 REF VDD
10K 2 15
PD LOCK
DGND 3 14
R203 R206 VDDA S2
5.6K 4 13
VSS
AMPI S1
VDD
BCKI
5 12
BCKO
100
LRCKI
W_IN2
W_IN1
AMPO M2
FS256I
R207
LRCKO
W_OUT
6 11
FS256O
FCONT2
VSSA M1
/LOCK2B
TDO_FS1O
PCMBW0
PCMBW1
CK_SEL0
CK_SEL1
CK_SEL2
1 80 R202 100 C211 7 10
2 79 8 9 R208
TDO_EMPO MCK2 15P C210 0.01 XO VSS
/PLL2_CONTB
3 78 EXC3BB102
PI VSS C208 0.47
LRCK_RST 4 77 U202 TC9246F
LRCK_RST PO /PLL1_CONTB 0.01
5 76
TEST1 /LOCK1B R201
OP_A[0..19] 6 75 100
7 74
VDD PD1
A4 MCK1
OP_A3 9 72
A3 DO_SEL0
OP_A2 10 71
A2 DO_SEL1
OP_A1 11 70
A1 ADAT_MD
OP_A0 12 69
A0 DO2 R209
/OP_RD 14 67 100
/OP_RD /RDB DO_EMPI
15 U201 66
VSS VSS
/CS_DIF2 /CSB VDD
/RST 17 64
OP_D0 18 63
C207 D0 DO_FS1I
OP_D1 19 62
100P D1 SOUT_DI
OP_D2 20 61
D2 SOUT2_78
OP_D3 21 60 >
D3 SOUT2_56
DGND OP_D4 22 59 >
D4 SOUT2_34 R210
OP_D5 23 58 >
D5 SOUT2_12
OP_D6 24 57 100
D6 VSS
OP_D7 25 56 >
D7 SOUT1_78
26 55 >
CTL_PIN SOUT1_56
OP_D[0..7] 27 54
28 53
VSS SOUT1_12
29 52
/EN_IFB DI_EMPO
30 51
SINA_MD DI_FS0O
SOUT1_MD
SOUT2_MD
TDI_FS1I
TDI_FS0I
TDI_EMPI
SINA_12
SINA_34
SINA_56
SINA_78
VSS
VDD
SINB_12
SINB_34
SINB_56
SINB_78
SIN_DIF
DI1
DI2
DI_SEL
DI_FS1O
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
AD1 DATA_IN2
AD1 DATA_IN2
DA_DATA1
DA_DATA1
SOUT_DI1
SOUT_DI1
D+5 A+5_PLL
D+5 A+5_PLL
DGND AGND_PLL
DGND AGND_PLL
D1624 / D824
91
92
DIF3, 8350
MSCK
MSCK
BCK
D1624 / D824
BCK
LRCK
LRCK
WORD_DIF4
WORD_DIF4
WORD_DIF3
WORD_DIF3 L301
A+5_PLL C312 C315
22uH/LFC32 10/16MV
10/16MV
TP301
D+5 C301 C302 C303 C304 C305 non C313
10/16MV 0.01 0.01 0.01 0.01 (LOCK AES/EBU) 0.01 C314
0.01
Hi : LOCK
R304 4.7K AGND_PLL
1 16
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
R305 REF VDD
10K 2 15
PD LOCK
DGND 3 14
R303 R306 VDDA S2
5.6K 4 13
VSS
AMPI S1
VDD
BCKI
5 12
BCKO
100
LRCKI
W_IN2
W_IN1
AMPO M2
FS256I
R307
LRCKO
W_OUT
6 11
FS256O
FCONT2
VSSA M1
/LOCK2B
TDO_FS1O
PCMBW0
PCMBW1
CK_SEL0
CK_SEL1
CK_SEL2
1 80 R302 100 C311 7 10
2 79 8 9
/PLL2_CONTB
3 78
PI VSS C308 0.47 EXC3BB102
4 77 U302 TC9246F
PO /PLL1_CONTB 0.01
5 76
TEST1 /LOCK1B R301
OP_A[0..19] 6 75 100
7 74
VDD PD1
A4 MCK1
OP_A3 9 72
A3 DO_SEL0
OP_A2 10 71
A2 DO_SEL1
OP_A1 11 70
A1 ADAT_MD
OP_A0 12 69
A0 DO2 R309
/OP_RD 14 67 100
/OP_RD /RDB DO_EMPI
15 U301 66
VSS VSS
/CS_DIF3 /CSB VDD
/RST 17 64
OP_D0 18 63
C307 D0 DO_FS1I
OP_D1 19 62
100P D1 SOUT_DI
OP_D2 20 61
D2 SOUT2_78
OP_D3 21 60 >
D3 SOUT2_56
DGND OP_D4 22 59 >
D4 SOUT2_34 R310
OP_D5 23 58 >
D5 SOUT2_12
OP_D6 24 57 100
D6 VSS
OP_D7 25 56 >
D7 SOUT1_78
26 55 >
CTL_PIN SOUT1_56
OP_D[0..7] 27 54
28 53
VSS SOUT1_12
29 52
/EN_IFB DI_EMPO
30 51
SINA_MD DI_FS0O
SOUT1_MD
SOUT2_MD
TDI_FS1I
TDI_FS0I
TDI_EMPI
SINA_12
SINA_34
SINA_56
SINA_78
VSS
VDD
SINB_12
SINB_34
SINB_56
SINB_78
SIN_DIF
DI1
DI2
DI_SEL
DI_FS1O
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
AD2 DATA_IN3
AD2 DATA_IN3
DA_DATA2
DA_DATA2
SOUT_DI2
SOUT_DI2
D+5 A+5_PLL
D+5 A+5_PLL
DGND AGND_PLL
DGND AGND_PLL
DIF4, 8350
MSCK
MSCK
BCK
BCK
LRCK
LRCK
WORD_DIF4 C412
WORD_DIF4 L401
A+5_PLL 10/16MV C415
22uH/LFC32 10/16MV
TP401
D+5 C402 C403 C404 C405 non C413
0.01 0.01 0.01 0.01 (LOCK AES/EBU) 0.01 C414
0.01
Hi : LOCK
R404 4.7K AGND_PLL
1 16
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
R405 REF VDD
10K 2 15
PD LOCK
DGND 3 14
R403 R406 VDDA S2
5.6K 4 13
VSS
AMPI S1
VDD
BCKI
5 12
BCKO
LRCKI
100
W_IN2
W_IN1
AMPO M2
FS256I
LRCKO
R407
W_OUT
FS256O
6 11
FCONT2
/LOCK2B
TDO_FS1O
VSSA M1
PCMBW0
PCMBW1
CK_SEL0
CK_SEL1
CK_SEL2
1 80 R402 100 C411 7 10
2 79 8 9
/PLL2_CONTB
3 78 EXC3BB102
PI VSS C408 0.47
4 77 U402 TC9246F
PO /PLL1_CONTB 0.01
5 76
TEST1 /LOCK1B R401
OP_A[0..19] 6 75 100
7 74
VDD PD1
A4 MCK1
OP_A3 9 72
A3 DO_SEL0
OP_A2 10 71
A2 DO_SEL1
OP_A1 11 70
A1 ADAT_MD
OP_A0 12 69
A0 DO2 R409
/OP_RD 14 67 100
/OP_RD /RDB DO_EMPI
15 U401 66
VSS VSS
/CS_DIF4 /CSB VDD
/RST 17 64
OP_D0 18 63
C407 D0 DO_FS1I
OP_D1 19 62
100P D1 SOUT_DI
OP_D2 20 61
D2 SOUT2_78
OP_D3 21 60 >
D3 SOUT2_56
DGND OP_D4 22 59 >
D4 SOUT2_34 R410
OP_D5 23 58 >
D5 SOUT2_12
OP_D6 24 57 100
D6 VSS
OP_D7 25 56 >
D7 SOUT1_78
26 55 >
CTL_PIN SOUT1_56
OP_D[0..7] 27 54
28 53
VSS SOUT1_12
29 52
/EN_IFB DI_EMPO
30 51
SINA_MD DI_FS0O
SOUT1_MD
SOUT2_MD
TDI_FS1I
TDI_FS0I
TDI_EMPI
SINA_12
SINA_34
SINA_56
SINA_78
VSS
VDD
SINB_12
SINB_34
SINB_56
SINB_78
SIN_DIF
DI1
DI2
DI_SEL
DI_FS1O
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
AD3 DATA_IN4
AD3 DATA_IN4
DA_DATA3
DA_DATA3
SOUT_DI3
SOUT_DI3
D+5 A+5_PLL
D+5 A+5_PLL
DGND AGND_PLL
DGND AGND_PLL
D1624 / D824
93
94
I/O, 8350
D+5
3
D1624 / D824
D103
DAN202K
R153 C153
1
2
IN_H1
100
C151 0.1 R155
47P 110
R154 C154
C19 D+5 IN_C1
10/16MV 100
2
1
3
C152 0.1
47P
C8 D101
D102 DAN202K DGND C159
3
1
2
DATA_IN[1..4] DAP202K R156 OUT_H1
16
DATA_IN[1..4]
DGND 0.01 U7 22
DATA_OUT[1..4] 1 IN_C1B C157 0.1 R158
DATA_OUT[1..4] R151 47p 330
DATA_IN1 3 2 IN_H1B C160
4 R157 OUT_C1
100
DATA_OUT1 15 14 OUT_H1B 22
2
1
13 OUT_C1B C158 0.1
47p
10 OUT_H2B
DATA_OUT2 9 11 OUT_C2B
3
12 D104
DATA_IN2 5 6 IN_H2B DAP202K DGND
7 IN_C2B D203 D+5
R251 DAN202K
100
D+5 75C1168
8
DGND
3
D303 C253
1
2
DAN202K R253 IN_H2
C353 100
1
2
R353 IN_H3 C251 0.1 R255
47P 110
100 C254
C351 0.1 R355 R254 IN_C2
47P 110
100
2
1
3
R354 C354 0.1
C20 IN_C3 C252
10/16MV D+5 47P
100
2
1
3
C352 0.1 D201
D202
47P DAP202K DAN202K DGND C259
1
2
R256
3
C7 D302 D301 OUT_H2
DAP202K DAN202K DGND C359 22
3
1
2
R356 OUT_H3 C257 0.1 R258
16
DGND 0.01 U6 47p 330
22 0.1 C260
1 IN_C3B C357 R358 R257 OUT_C2
DATA_IN3 R351 100 3 2 IN_H3B 47p 330
C360 22
2
1
4 R357 OUT_C3 C258 0.1

DATA_OUT3 15 14 OUT_H3B 47p
22
2
1
13 OUT_C3B C358 0.1
47p
3
J5
D204 DGND
10 OUT_H4B 26
3
DATA_OUT4 9 11 OUT_C4B DAP202K DGND IN_H1 1
12 D304 IN_C1 14
DATA_IN4 5 6 IN_H4B DAP202K DGND IN_H2 2
R451 100 7 IN_C4B D403 D+5 IN_C2 15
DAN202K IN_H3 3
75C1168 IN_C3 16
8
IN_H4 4
DGND IN_C4 17
OUT_H1 5
C453 OUT_C1 18
1
2
R453 IN_H4 OUT_H2 6
100 OUT_C2 19
C451 0.1 R455 OUT_H3 7
47P 110 OUT_C3 20
R454 C454
IN_C4 OUT_H4 8
100 OUT_C4 21
2
1
3
C452 0.1 Not Used 9
47P 22
D401 10
DAN202K DGND C459 23
3
1
2
R456 OUT_H4
Not Used 11
D402 22 0.1 R458 24
DAP202K C457 330
47p C460 12
R457 OUT_C4 25
2
1
22 13
D404 0.1 27
DAP202K C458
47p
3
DSUB-25P
DGND
DGND
PLL, 8350
D+5 C34 D+5 TP3

D+5 TP
1
0.01
R11
1
2 3 PD
DGND C36 1.5K
C33 U16
D+5 0.01 DTA114EK
14
14
TP1 0.01 D+5 DGND
U12A
BCK 1 1
14
U12B
DGND 3 4 3
BCK 1 2 2 6 2
1
5 U14A
C31 U11A 74VHC00
NON 74VHC04 74VHC00 74VHC00
U14B
DGND U12C 4
U12D 9 U11C 6
12 8 5 6 5
11 10
13 74VHC04 74VHC00
74VHC00
74VHC00
D+5 C35
0.01
14
TP2 DGND D+5 U14D U15
INT_BCK 1 U13B 13 DTC114EK
U11B 3 4 11 2 3 R12
INT_BCK 3 4 2 6 12 1.5K
1
U13A 5
1
C32 74VHC04 74VHC00

NON 74VHC00 74VHC00 DGND
DGND U13C TP5

U13D 9 U11D D+5
12 8 9 8 D+5
1
11 10
13 74VHC04
74VHC00 U11E TP4
74VHC00 11 10 DGND
1
74VHC04 U14C
9
U11F 8 GND DGND
13 12 10
74VHC04 74VHC00
DGND DGND
D1624 / D824
95
FOSTEX CORPORATION 3-2-35 Musashino, Akishima, Tokyo, Japan 196-0021
FOSTEX CORPORATION OF AMERICA 15431 Blackburn Ave., Norwalk, CA 90650, U.S.A.

Service Manual Guide for 16/8 Track Digital Recorders

Uploaded by

Document Information

Original Description:

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Service Manual Guide for 16/8 Track Digital Recorders

Uploaded by

Copyright:

Available Formats

Service Manual

16TRACK DIGITAL RECORDER

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, ATTENTION:

* Following is the packing material for the Model D1624 / D824.

Number of playback tracks at a time

[ D-SUB 25-pin Assignment ]

2. CONTROLS, INDICATORS & CONNECTORS

Front Panel Section: Controller (D1624 / D824)

Rear Panel Section (D1624)

ANALOG INPUT ANALOG OUTPUT DIGITAL/DATA SCSI AC IN

Rear Panel Section (D824)

1. Panel A for an optional card 9. REMOTE INPUT terminating switch

Rear Panel Section (D1624 with Model 5043 and 8345)

ANALOG INPUT ANALOG OUTPUT DIGITAL/DATA SCSI AC IN

[ MODEL 5043 ] 7. Word input terminating switch

[ MODEL 5042 ] 5. Video input connector

3-1. Required Tools

3-2. Software Updating Procedures

8. Press the [EXECUTE/YES] key to start updating the software.

9. Select “SCSI-6” and press the [EXECUTE/YES] key.

4-1. Putting D1624/D824 into Service Mode

Reserved Digital In?

4-2. Flash ROM (software) version

4-4. Standby Disk

4-4. Display/Key Test

Key/Button No. Key/Button No. Key/Button No.

4-5. Self Check

WORD DIGITAL REMOTE

ANALOG INPUT ANALOG OUTPUT DIGITAL/DATA SCSI AC IN

4-5-1. SCSI Port Check

The following is considered to be the cause of problem.

4-5-2. ATA (E-IDE) Bus Check

The following is considered to be the cause of problem.

4-5-3. Option (Model 8345) Bus Check

The following is considered to be the cause of problem.

4-5-4. MIDI In/Out Check

The following is considered to be the cause of problem.

4-5-5. S/P DIF In/Out Check

The following is considered to be the cause of problem.

4-5-6. Adat In/Out Check

The following is considered to be the cause of problem.

4-5-7. 8345 Vari-Pitch Circuit Check

4-5-8. D1624/D824 Vari-Pitch Circuit Check

4-5-9. External Time Clock Check

4-5-10. Internal Time Clock Check

4-5-12. Word In/Out

4-5-13. A/D and D/A Circuit Check (Input Monitoring)

4-6. Offset Display

4-7. Initializing Disk

4-8. Flash ROM

4-9. Free Block Check

4-10. MIDI Date Set

5. ERROR CODE LIST

D1624/D824 ERROR CODE LIST

J2 J21 J11 J20

U66 U48 C514 C614 C1314 C1414

1 1 U131 U231 U331 U431

U141 U541 U241 U641 U341 U741 U441 U841

C3109 R3004 C3001

W1C3060 (for D1624)

(TRK1 ~ 8) (TRK9 ~ 16) C79

J8 R94 C3080 U61
