DigiTRON e

DigiTRON
DigiTRON + and DigiTRON e Controls & Instrumentation Connectors
Siemens Subsea Connectors (Tronic Products)
www.siemens.com/energy/subsea
DigiTRON Brochure (March 2015).indd 1 31/03/2015 16:07

Design Test Manufacture Qualification Installation

DigiTRON + & e Catalogue (13.10.2014)_- 31/03/2015 10:13 Page 3
The DigiTRON Evolution
Siemens Subsea has an established global reputation for the manufacture and delivery
of market-leading subsea connector and measurement technology.
The enhanced next generation of DigiTRON connectors has arrived. Introducing DigiTRON + and DigiTRON e from Siemens Subsea.
Backward compatability, refined enhancements and increased reliability make DigiTRON + and DigiTRON e the most technically advanced
and reliable subsea connectors on the market.
The Siemens Subsea product name is recognised throughout the global subsea oil and gas industry as a leader in the design, manufacture
and installation of reliable subsea mateable electrical and optical connection systems.
Siemens Subsea products are market-leading, high integrity, subsea power and data connection systems. Combined with our sensors
they offer a convenient integrated scope of supply with our customers benefitting from a single source of supply for complete jumper
assemblies and flying leads. This gives the advantage of a simplified supply chain coupled with a single warranty.
11 Way ROV REDU (Retrievable

Electrical Distribution Unit) 4000
metres depth rating
Contents
Technical Specification ..................................................7
Termination Methods ....................................................8
DigiTRON Range Product Selection ..............................10
Type Numbering System..............................................12
ROV Connectors.........................................................14
Stab Plate Connectors ...............................................25
Diver Connectors .......................................................35
Subsea Cable...............................................................45
Junction Boxes ............................................................46
ROV Retrievable EDU ...................................................47
AquaTRON Oil Tube .....................................................48
AquaTRON Junction Boxes...........................................49
AquaTRON Isolated Chamber Junction Boxes ...............50
Harness Assemblies .....................................................51
Interface Drawings ......................................................52
Common Modular Diagram .........................................54
Junction Boxes, Penetrators & Splices ..........................56
Glossary of Terms........................................................57
Siemens Subsea Services - Life Cycle Management ......58
3
The DigiTRON range of subsea

instrumentation connectors combines the
many field proven features of the Mini CE
connector with the latest in design
technology.
DigiTRON benefits include faster lead times

and improved flexibility. This is achieved by
DigiTRON’s modular design specification
using fewer components.
Technically, DigiTRON retains the high-density

pin configurations for more compact 7 and
12 way connectors. PEEK™ and Ultem
moulded inserts and pins eliminate potential
leak paths around the termination area, while
new louvred contacts minimise contact
resistance.
DigiTRON connectors for ROV operation are

considerably simpler, stronger and more
compliant to avoid damage while mating. A
new debris seal gives positive indication of
successful mating.
High integrity is ensured by pressure

compensation, two completely independent
oil chambers and built-in redundancy.
DigiTRON connectors are rated at 1000V ac

(pin to earth) and up to 40A. They are
primarily used for instrumentation and low
power distribution.
DigiTRON Range Highlights

• 4, 7 & 12 ways for deployment by ROV,
stab plate or diver
• 1000 mate / de-mates (750 dry followed by
250 turbid at 4000 metres depth pressure)
• 30 year design life
• In-house testing to 4000 metres
DigiTRON Continuous Improvements

• Partial de-mate ability
• Sulphamic compatible Cutaway model of a 4 way plug assembly
• Oceanic CW compatible
• EMC screening available (oil tube only)
• Best practices document Qualified to:
NHT-152-00073 Rev 04H (Norsk Hydro)
RA-SNØ-00182 Rev 01 (Statoil)
TD0153 (Statoil)
TR1233 (Statoil)
TR2390 (Statoil)
GP EP SPS 021 (Total)
BP Compliant
4

– Technology Overview
Controlled Environment (CE) Principle
DigiTRON connectors are based around the unique and patented Controlled
Environment (CE) Principle.
This arrangement ensures the highest level of integrity for long life and repeated
subsea mating capability.
• The CE plug features an oil-filled primary diaphragm to prevent water ingress.

Each electrical socket is further protected within an individual secondary oil-filled
diaphragm
• Both diaphragms have individual seals, failure of either seal would not
compromise the connector’s integrity
• Shuttle pins prevent water ingress or loss of oil when the connector is not mated
• Insulated pins on the receptacle connector displace the shuttle pins during the
mating process. The conductive tips of the pins are wiped twice before making
contact with the electrical socket 7 way pin & socket insert assemblies
• The whole assembly is pressure balanced to minimise stress within the sealing areas
4 way plug front end 7 way plug front end 12 way plug front end 7 way socket insert assembly
Technical Philosophy
CE Principle - Sequence of Operations
1 Use pressure balancing to
minimise material stress.
2 Use modular systems to
achieve maximum
flexibility whilst utilising
proven components.
3 Include at least one level
of redundancy on high
integrity connectors.
4 Mechanical gland sealing
1 Receptacle & plug prior to mating 2 Receptacle pin engages with shuttle pin of plug assembly
avoids many problems
associated with moulding
to cable sheaths.
5 Ensure material
compatibility and
traceability - the majority
of Siemens Subsea
subsea connectors have a
30 year design life with
no requirement for
servicing. 3 Receptacle pin enters first oil chamber of the primary 4 Receptacle pin enters secondary diaphragm and makes
diaphragm and pushes back the shuttle pin full contact with plug socket
5
DigiTRON Evolution
The enhanced, next generation of DigiTRON connectors has arrived. Introducing DigiTRON +
and DigiTRON e from Siemens Subsea. Backward compatability, refined enhancements and
increased reliability make DigiTRON + and DigiTRON e the most technically advanced and
reliable subsea connectors on the market.
We have a history of providing reliability where you need it most - subsea. With over 110,000 connectors in service on over 400 projects
worldwide, the DigiTRON range of connectors provides trusted quality and long lasting reliability. We strive for reliability in everything we
do. DigiTRON + and DigiTRON e low voltage subsea connectors now redefine not only Siemens Subsea but also the subsea connector
market. These two pinnacle products are manufactured and tested at our headquarters in Great Britain where cutting edge technology and
advanced proven testing methods come together to provide the level of service and reliability you would expect from a world leader in
subsea connectors.
When reliability counts, count on our experience.
DigiTRON +
The refined and enhanced DigiTRON connector
What is a DigiTRON + connector? A DigiTRON + connector is a DigiTRON connector with enhanced capabilities.
• Backward compatible with the existing DigiTRON range

• Fully qualified to operate at 4000 metres (13,123 feet) depth pressure at full differential
• Glanded connectors depth rating is cable dependant
• Fully qualified for 30 years design life
• PD (Partial Discharge) free @ 1.73Uo & 2.50Uo giving long-term integrity
• 1000 mate / de-mates (750 dry followed by 250 turbid at 4000 metres depth pressure)
• Fully machined connector body which removes the need for welding
• Paddle handle with increased versatility
DigiTRON e Ethernet Connector

The market’s first ethernet connector with all the functionality of DigiTRON +
What is a DigiTRON e connector? A DigiTRON e connector is a DigiTRON + connector with ethernet capability.
When would there be a need for a DigiTRON e connector? Where there is a requirement for higher data rates for real time control.
The benefit of a DigiTRON e connector is that it allows you to react quickly to real time subsea situations.
• Fully qualified to operate at 4000 metres (13,123 feet) depth pressure

• Qualified in compliance with IEEE 802.3 and the SIIS level 3 document which includes traffic generator and cable analyser tests
• Harnesses up to 160 metres in length (including test harness) capable of handling 100 Mbps full duplex data rate @ 4000
metres (13,123 feet) depth pressure
• Multiple harnesses mated together to create a total length of up to 160 metres (including test harness), capable of
handling 100 Mbps full duplex data rate @ 4000 metres (13,123 feet) depth pressure
• Available for 12 way connectors only.
6
DigiTRON + and DigiTRON e

Technical Specification
Electrical Specification 4 way connector 7 way connector 12 way connector
Maximum working voltage (pin to earth) 1000V rms (1414V peak) 1000V rms (1414V peak) 1000V rms (1414V peak)
Maximum working voltage (pin to pin) 2000V rms (2828V peak) 2000V rms (2828V peak) 2000V rms (2828V peak)
Maximum working current 35-40 Amps 22-32 Amps 20-28 Amps
Working current in air 18 Amps 14 Amps 11 Amps
Typical contact resistance <4 milliohms <4 milliohms <4 milliohms
Typical pin to pin resistance (connectors only) >100 Gigaohms >100 Gigaohms >100 Gigaohms
Ethernet Specification DigiTRON e 4 way connector 7 way connector 12 way connector
Typical pin to pin resistance (harness) - - >10 Gigaohms
Maximum data rate <100 metres (including test harness) - - 100 Mbps Full duplex
IEEE Cable analyser - - CAT 5E
Mechanical Specification 4 way connector 7 way connector 12 way connector
4000 metres 4000 metres 4000 metres

Depth rating
(13,123 feet) (13,123 feet) (13,123 feet)
440 bar 440 bar 440 bar
Test pressure
(6382 psi) (6382 psi) (6382 psi)
4 mm2 4 mm2 4 mm2

Maximum conductor size (standard)
(12 awg) (12 awg) (12 awg)
Maximum conductor size (with crimps and 25 mm2 25 mm2 25 mm2

extended cable gland) (4 awg) (4 awg) (4 awg)
Storage temperature range -40°C to 70°C -40°C to 70°C -40°C to 70°C
Working temperature range -5°C to 60°C -5°C to 60°C -5°C to 60°C
Onshore testing temperature range -20°C to 50°C -20°C to 50°C -20°C to 50°C
Oil Tube Specification 4 way connector 7 way connector 12 way connector
Standard conductors within the oil tube Raychem Spec 44, 1000V, ø2.06 mm (0.08 inch), 16awg
Ethernet cable - - CAT 5E
Oil type Dow Corning 200/ 1000 (silicone oil)
ROV Mating 4 way connector 7 way connector 12 way connector
<30 kgf <30 kgf <50 kgf

Mating force
(<66 lbf) (<66 lbf) (<110 lbf)
24 - 36 kgf 24 - 36 kgf 48 - 80 kgf

Demating force
(53 - 79 lbf) (53 - 79 lbf) (105 - 176 lbf)
±20 mm ±20 mm ±20 mm

Maximum radial misalignment
(±0.79 inch) (±0.79 inch) (±0.79 inch)
Maximum angular misalignment ±20° ±20° ±20°
Maximum rotational misalignment ±15° ±15° ±15°
7
Termination Methods
Cable Termination
(Field Installable Termination Assembly)
• After termination and helium pressure testing, the gland

housing is filled with hydrophobic dielectric gel. When
deployed, a diaphragm subjects the gel to ambient seawater
pressure, preventing water ingress and minimising material
stress.
• Termination sleeves over the solder cups provide the
conductors with a continuous insulating layer
• A cable-to-conductor boot seals the gland cavity from the
cable. This prevents water ingress from the spaces between
the conductors in the event of cable sheath damage
• The compression cable seal performs consistently – even
when assembled in difficult conditions Cable gland
• Tolerance of jumpers is:

Jumper length 10 to 20 metres -0 / +0.50 metres
Jumper length >20 metres -0 / +3% of nominal length
Gland Size / Cable Sheath Capacity
Gland Minimum Maximum

size sheath Ø sheath Ø
G10 8 mm 22.9 mm
G20 23 mm 35 mm
Gland Options
Cable sealing / gripping components
• Gland extension modules can be used to
accommodate crimps and tailing wire
where the cable conductors are larger than
the solder cups (4 mm2). For details see
page 27.
• Some configurations of armoured cables
can be terminated using armour
termination modules.
Please contact our Customer Support

Department for more details.
Series 10 DigiTRON connectors with standard cable glands
8
Termination Methods
Oil Tube Termination
Oil-filled AquaTRON hose containing a number of sheathed

conductors can be used as an alternative to cable and
glands. Connectors and oil tube are supplied as a complete
harness.
• Pressure compensation is provided by the flexibility of

the tube
• Short oil tube jumpers are significantly simpler and less
expensive than cable equivalents
• Jumpers are available from a minimum length of 1.5
Oil tube termination metres to a maximum length of 240 metres*
(excluding ethernet)
• Complex AquaTRON hose harnesses can be constructed
from connectors, tee pieces and junction boxes
• Tolerance of jumpers is:
Jumper length 10 to 20 metres -0 / +0.50 metres
Jumper length >20 metres -0 / +3% of nominal length
Bulkhead Termination
Bulkhead mounted connectors are used where a

disconnectable interface is required at the boundary of
an environmentally sealed enclosure.
Example applications include: subsea control modules,

junction boxes and subsea power distribution modules.
* For longer lengths please contact Siemens Subsea

Connectors
DigiTRON connectors for AquaTRON oil tube
Rear view of a bulkhead connector with termination sleeves
9

- Product Selection
This catalogue describes the standard connectors within the In-line Plug Connector (A)
DigiTRON + and DigiTRON e range.
In-line plug connectors are fitted with socket contacts within
Standard connectors are generally available at shorter lead an oil-filled environment and are terminated to a segment of
times than less common or bespoke connectors. cable or oil tube.
Non-standard configurations include: In-line Receptacle Connector (B)
• Angled cable / hose entry In-line receptacle connectors are fitted with male pin contacts
• Extended glands to accommodate crimps facilitating and are terminated to a segment of cable or oil tube.
2
termination to conductors bigger than 4 mm When mated, the receptacle's pins are protected by the plug's
• Multi cable / hose entry dielectric fluid.
The use of dummy connectors is advised if the pins on

Plug or Receptacle? receptacles are likely to be exposed to seawater for any
significant period. The advised maximum cumulative exposure
DigiTRON + and DigiTRON e plug connectors contain electrical over the life of the system is 28 days, although some pin
sockets (female) protected by pressure balanced dielectric deterioration may occur in a shorter period.
fluid. Receptacle connectors contain pin inserts (male). Plugs
are inserted into receptacles - hence their respective names.
The choice between plug and receptacle is usually dictated by Bulkhead Connectors (G&H)
system configuration. There are three primary considerations: Bulkhead connectors are used where a disconnectable
1 If a voltage is to be applied to the connector whilst interface is required at the boundary of an environmentally
unmated, then a plug must be used. Receptacles must sealed enclosure. Applications include oil-filled subsea control
NEVER be live whilst unmated. modules, junction boxes and instrument housings.
2 Receptacle connector pins must not be left exposed to The environmental seal is achieved by face and barrel 'O' rings.
seawater. The advised maximum cumulative exposure over Solder cups are provided at the inboard side of the connector
the life of the system is 28 days, although some pin for end-user termination. Inboard tails and / or termination
deterioration may occur in a shorter period. A dummy plug sleeves can be specified at time of order.
connector should be used wherever practical.
3 Some system designers prefer to use plug connectors (the

more complicated component) on recoverable equipment.
Connector End Views
4 way Plug 7 way Plug 12 way Plug
7 2 12 4
1
6 1 3 11 5
4 1 3 2
3 2
5 4 10 6
8
9 7
10

- Product Selection
Dummy Connectors Dummy / Shorting / Parking Receptacle (M)
Full-function dummy connectors are similar to in-line The three principal uses for dummy / shorting / parking
connectors with a blank backshell replacing the cable gland or receptacles are:
oil tube adaptor.
1 To provide a loop across the sockets of a plug connector for
Dummies can be supplied with three distinct wiring subsea testing – e.g. monitoring the condition of an
configurations: umbilical during deployment.
1 Open circuit. 2 Somewhere to fix (park) a spare plug on a subsea

installation.
2 Specified contacts shorted.
3 To prevent marine growth and sand / silt deposits on an
3 Specified contacts wired together with resistors. Wiring and
unmated plug.
resistor requirements are specified at time of order.
Protective Caps (P&R)

Dummy / Shorting / Parking Plug (L)
The use of black acetal caps is recommended to protect
There are four principal uses for dummy plugs: connectors during transport and storage prior to subsea
1 To mechanically and electrically protect the pins on a deployment.
receptacle that might otherwise be exposed to seawater.
2 To provide a loop across the pins of a receptacle connector Test Plugs and Receptacles (T)
for subsea test purposes - e.g. monitoring the condition of
Test plugs and receptacles are used for cost-effective factory
an umbilical during deployment.
testing of a system without risk of damage to the gold-plated
3 To prevent marine growth and sand / silt deposits on an connector contacts.
unmated receptacle.
Notes: Please note letter in brackets e.g. (A) refers to the type
4 Somewhere to fix (park) a spare receptacle on a subsea of connector (item 3) on pages 12 & 13.
installation.
Wiring and resistor requirements are specified at time of order.
Connector End Views
4 way Receptacle 7 way Receptacle 12 way Receptacle
4 12
1
2 7
3 1 6 5 11
1 4 2 3
2 3
4 5 6 10
8
7 9
11
DigiTRON + Type Numbering System
BROV-10-A001-BQ-G10-MC04S-VT
1 2 3 4 5 6 7 8 9
CONNECTOR FAMILY TERMINATION

1 5
Indicates the DigiTRON + connector family: Indicates the type of termination:
BROV: DigiTRON + ROV mated G10: Series 10 gland

BDIV: DigiTRON + Diver mated G20: Series 20 gland
BSTA: DigiTRON + Stab Plate mated EGxx: Extended gland
GxxA: Gland with armour termination
GxxB: Bend restrictor
SERIES DB: AquaTRON (0.5" NB) Oil Tube
2 DC: AquaTRON (0.75" NB) Oil Tube
Indicates the size (series) within the DigiTRON
AF: 0.5" NB 34" - 16 JIC fitting
range and which insert they can accommodate:
AH: 0.75" NB 1 116"- 12 JIC fitting
10: 4 way Mini CE compatible inserts
& 7 way high density inserts
20: 12 way high density inserts CONTACT INSERT DENSITY
6
Indicates the contact insert density:
TYPE of CONNECTOR MC: Mini CE compatible
3 HD: High density pin configuration
Indicates the type of connector as follows:
A: Plug connector (socket contacts)
B: Receptacle connector NUMBER of WAYS
(pin contacts)
7
Indicates the number of ways:
G: Flange mounted bulkhead receptacle
connector (pin contacts) 04: 4 Way
H: Flange mounted bulkhead plug 07: 7 Way
connector (socket contacts) 12: 12 Way
L: Dummy plug connector
(socket contacts)
M: Dummy receptacle connector CONTACT
(pin contacts)
8
Indicates the type of contact:
P: Protective cap for plug
R: Protective cap for receptacle S: Socket
T: Test connector P: Pin
The number immediately following the connector type

distinguishes different variations. A001..A999 ROV HANDLES
9
represent different configurations of plug connector for Suffix indicates ROV handle:
a particular shell size (series).
HP: Horizontal Paddle
VT: Vertical T Bar
MATERIAL HT: Horizontal T Bar
4 VF: Vertical Fishtail
Indicates the material: HF: Horizontal Fishtail
AA: Stainless Steel (UNS S31603) XY: XYZ Handle
BQ: Super Duplex Stainless Steel (UNS S32550)
AC: Black Acetal
CD: White Acetal
12
DigiTRON e Type Numbering System
EROV-20-A001-BQ-G10-HD12S-VT
1 2 3 4 5 6 7 8 9
8 9
CONNECTOR FAMILY TERMINATION

1 5
Indicates the DigiTRON e connector family: Indicates the type of termination:
EROV: DigiTRON e ROV mated G10: Series 10 gland

EDIV: DigiTRON e Diver mated G20: Series 20 gland
ESTA: DigiTRON e Stab Plate mated DC: AquaTRON (0.75" NB) Oil Tube
AH: 0.75" NB 1116"- 12 JIC fitting
SERIES
2
CONTACT INSERT DENSITY
Indicates the size (series) within the DigiTRON 6
range and which insert they can accommodate: Indicates the contact insert density:
20: 12 way high density inserts HD: High density pin configuration
TYPE of CONNECTOR
3 7 NUMBER of WAYS
Indicates the type of connector as follows:
Indicates the number of ways:
A: Plug connector (socket contacts)
12: 12 Way
B: Receptacle connector
(pin contacts)
G: Flange mounted bulkhead receptacle CONTACT
connector (pin contacts) 8
H: Flange mounted bulkhead plug Indicates the type of contact:
connector (socket contacts)
S: Socket
L: Dummy plug connector (socket contacts)
P: Pin
- refer to DigiTRON +
M: Dummy receptacle connector
- refer to DigiTRON + ROV HANDLES
P: Protective cap for plug 9
R: Protective cap for receptacle Suffix indicates ROV handle:
T: Test connector HP: Horizontal Paddle
The number immediately following the connector type VT: Vertical T Bar
distinguishes different variations. A001..A999 represent HT: Horizontal T Bar
different configurations of plug connector for a particular VF: Vertical Fishtail
shell size (series). HF: Horizontal Fishtail
XY: XYZ Handle
MATERIAL
4
Indicates the material:
AA: Stainless Steel (UNS S31603)

BQ: Super Duplex Stainless Steel (UNS S32550)
13
ROV Connectors
ROV (Remotely Operated Vehicle) Deployment
• Large primary catchment area and built in compliance facilitate mating

in difficult conditions
• ROV Connectors can cope with considerable misalignment during the
initial stages of mating but alignment is ensured before the pins meet
the seals (Please refer to page 7 - ROV Mating in the Technical
Specification)
• Straight push / pull operation facilitated by the snap ring
• Manufactured from Super Duplex Stainless Steel (UNS S32550) for
improved strength and corrosion resistance and giving a 30 year
design life
ROV Notes
1 4 way DigiTRON ROV connectors are compatible with 4 way Mini CE DigiTRON ROV Size 10/20 connector de-mate tool
ROV connectors.
2 7 and 12 way DigiTRON ROV connectors utilise high-density inserts

and are NOT Mini CE compatible.
3 Siemens Subsea strongly recommend that ROV connectors are isolated

from CP systems to minimise calcareous growth.
4 The use of dummy connectors is advised if the pins on receptacles are

likely to be exposed to seawater. The advised maximum cumulative
exposure over the life of the connector is 28 days, although some pin
deterioration may occur in a shorter period.
5 DigiTRON ROV connector de-mating tool available (Top-side use only).

ROV bulkhead mounted plug & receptacle
Two views of ROV flying plug with machined backshell and enhanced paddle handle for AquaTRON oil tube
14
ROV Connectors
Page PLUG RECEPTACLE Page
ROV Connectors
Number ROV FLYING PLUG ROV FLYING RECEPTACLE Number
FOR CABLE (A001) FOR CABLE (B001)
17 17
ROV Connectors
ROV COMPLIANTLY MOUNTED PLUG ROV COMPLIANTLY MOUNTED RECEPTACLE
17 17
90° ROV COMPLIANTLY MOUNTED PLUG 90° ROV COMPLIANTLY MOUNTED RECEPTACLE
ROV Connectors
18 18
ROV Connectors
ROV FLYING PLUG FOR ROV FLYING RECEPTACLE FOR
AQUATRON OIL TUBE (A003) AQUATRON OIL TUBE (B003)
19 19
ROV COMPLIANTLY MOUNTED PLUG ROV COMPLIANTLY MOUNTED RECEPTACLE

ROV Connectors
FOR AQUATRON OIL TUBE (A004) FOR AQUATRON OIL TUBE (B004)
19 19
90° ROV COMPLIANTLY MOUNTED PLUG 90° ROV COMPLIANTLY MOUNTED RECEPTACLE
20 20
ROV Connectors
15
ROV Connectors

ROV Connectors
Number ROV BULKHEAD MOUNTED PLUG ROV BULKHEAD MOUNTED RECEPTACLE Number
(H001) (G001)
20 20
ROV BULKHEAD MOUNTED PLUG ROV BULKHEAD MOUNTED RECEPTACLE

4000m Full Differential (H003) (G003) 4000m Full Differential
21 21
ROV Connectors
ROV FLYING DUMMY PLUG ROV FLYING DUMMY RECEPTACLE

(L001) (M002)
21 21
ROV FIXED DUMMY PLUG ROV FIXED DUMMY RECEPTACLE

(L002) (M004)
ROV Connectors
22 22
ROV COMPLIANTLY MOUNTED ROV COMPLIANTLY MOUNTED

DUMMY PLUG (L003) DUMMY RECEPTACLE (M003)
22 22
ROV Connectors
ROV PARKING PLUG ROV PARKING RECEPTACLE

(L004) (M001)
23 23
MANUALLY OPERATED PROTECTIVE CAP FOR MANUALLY OPERATED PROTECTIVE CAP FOR
ROV RECEPTACLE (R001) ROV PLUG (P001)
ROV Connectors
23 23
ROV OPERATED PROTECTIVE CAP FOR RECEPTACLE ROV OPERATED PROTECTIVE CAP FOR PLUG
(R002) (P002)
24 24
ROV TEST PLUG ROV TEST RECEPTACLE

ROV Connectors
(T001) (T002)
24 24
16
ROV Connectors
ROV FLYING CONNECTORS FOR CABLE

A A
Plug Receptacle
Series Number Gland Cable Nominal DigiTRON + DigiTRON e

of Series Ø A Weight Type Type
Ways mm mm kg Number Number
10 4 G10 8 to 22.9 325 3.64 BROV-10-A001-BQ-G10-MC04S -
PLUG
10 7 G10 8 to 22.9 325 3.64 BROV-10-A001-BQ-G10-HD07S -

20 12 G20 23 to 35 363 4.82 BROV-20-A001-BQ-G20-HD12S EROV-20-A001-BQ-G20-HD12S
RECEPTACLE
10 4 G10 8 to 22.9 334 3.64 BROV-10-B001-BQ-G10-MC04P -

10 7 G10 8 to 22.9 334 3.64 BROV-10-B001-BQ-G10-HD07P -
20 12 G20 23 to 35 372 4.82 BROV-20-B001-BQ-G20-HD12P EROV-20-B001-BQ-G20-HD12P
DigiTRON + ROV series [10 / 20] flying plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON e ROV series 20 flying plug /receptacle with 12 pins/sockets and size [10 / 20] cable gland.
ROV COMPLIANTLY MOUNTED CONNECTORS FOR CABLE

A A
Compliant Mount Compliant Mount

Plug Receptacle
Series Number Gland Cable Flange Interface Nominal DigiTRON + DigiTRON e

of Series Ø A Ø Drg No. Weight Type Type
Ways mm mm mm kg Number Number
10 4 G10 8 to 22.9 331 108 T16813 2.94 BROV-10-A002-BQ-G10-MC04S -
10 7 G10 8 to 22.9 331 108 T16813 2.94 BROV-10-A002-BQ-G10-HD07S -
PLUG
10 4 G20 23 to 35 369 108 T16813 3.45 BROV-10-A002-BQ-G20-MC04S -

10 7 G20 23 to 35 369 108 T16813 3.45 BROV-10-A002-BQ-G20-HD07S -
20 12 G20 23 to 35 370 122 T16561 4.81 BROV-20-A002-BQ-G20-HD12S EROV-20-A002-BQ-G20-HD12S
10 4 G10 8 to 22.9 300 108 T16813 2.88
RECEPTACLE
BROV-10-B002-BQ-G10-MC04P -
10 7 G10 8 to 22.9 300 108 T16813 2.88 BROV-10-B002-BQ-G10-HD07P -
10 4 G20 23 to 35 363 108 T16813 3.39 BROV-10-B002-BQ-G20-MC04P -
10 7 G20 23 to 35 363 108 T16813 3.39 BROV-10-B002-BQ-G20-HD07P -
20 12 G20 23 to 35 338 122 T16561 3.47 BROV-20-B002-BQ-G20-HD12P EROV-20-B002-BQ-G20-HD12P
DigiTRON + ROV series [10 / 20] compliantly mounted plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON e ROV series 20 compliantly mounted plug/receptacle with 12 pins/sockets and size [10 / 20] cable gland.
17
ROV Connectors
90° ROV COMPLIANTLY MOUNTED CONNECTORS FOR CABLE

A A
Plug Receptacle
Series Number Gland Cable Flange Interface Nominal DigiTRON + DigiTRON e

of Series Ø A Ø Drg No. Weight Type Type
10 4 G10 8 to 22.9 226 108 T16813 4.12 BROV-10-A005-BQ-G10-MC04S -
10 7 G10 8 to 22.9 226 108 T16813 4.12 BROV-10-A005-BQ-G10-HD07S -
PLUG
20 12 G10 8 to 22.9 238 122 T16561 6.08 BROV-20-A005-BQ-G10-HD12S EROV-20-A005-BQ-G20-HD12S

10 4 G20 23 to 35 226 108 T16813 4.63 BROV-10-A005-BQ-G20-MC04S -
10 7 G20 23 to 35 226 108 T16813 4.63 BROV-10-A005-BQ-G20-HD07S -
20 12 G20 23 to 35 238 122 T16561 6.20 BROV-20-A005-BQ-G20-HD12S EROV-20-A006-BQ-G20-HD12S
10 4 G10 8 to 22.9 192 108 T16813 4.06 BROV-10-B005-BQ-G10-MC04P -
RECEPTACLE
10 7 G10 8 to 22.9 192 108 T16813 4.06 BROV-10-B005-BQ-G10-HD07P -

20 12 G10 8 to 22.9 206 122 T16561 5.53 BROV-20-B005-BQ-G10-HD12P EROV-20-B005-BQ-G20-HD12P
10 4 G20 23 to 35 192 108 T16813 4.57 BROV-10-B005-BQ-G20-MC04P -
10 7 G20 23 to 35 192 108 T16813 4.57 BROV-10-B005-BQ-G20-HD07P -
20 12 G20 23 to 35 206 122 T16561 5.65 BROV-20-B005-BQ-G20-HD12P EROV-20-B005-BQ-G20-HD12P
DigiTRON + ROV series [10 / 20] 90° flying plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON e ROV series 20 - 90° flying plug/receptacle with 12 pins/sockets and size [10 / 20] cable gland.
18
ROV Connectors
ROV FLYING CONNECTORS FOR AQUATRON OIL TUBE

A A
Plug Receptacle
Please Note: DigiTRON + connectors shown
Series Number Hose Hose Hose Nominal DigiTRON + DigiTRON e

of internal Ø outside Ø Code A Weight Type Type
10 4 12.7 25.2 DB 325 2.44 BROV-10-A003-BQ-DB-MC04S -
RECEPTACLE PLUG
10 7 12.7 25.2 DB 325 2.44 BROV-10-A003-BQ-DB-HD07S -

20 12 12.7 25.2 DB 363 3.10 BROV-20-A003-BQ-DB-HD12S EROV-20-A003-BQ-DC-HD12S
10 4 12.7 25.2 DB 334 2.58 BROV-10-B003-BQ-DB-MC04P -
10 7 12.7 25.2 DB 334 2.58 BROV-10-B003-BQ-DB-HD07P -
20 12 12.7 25.2 DB 372 3.10 BROV-20-B003-BQ-DB-HD12P EROV-20-B003-BQ-DC-HD12P
DigiTRON + ROV series [10 / 20] flying plug/receptacle with [4 / 7 / 12] pins/sockets and AquaTRON oil tube fitting.
DigiTRON e ROV series 20 flying plug /receptacle with 12 pins/sockets and AquaTRON oil tube fitting.
ROV COMPLIANTLY MOUNTED CONNECTORS FOR AQUATRON OIL TUBE

A A
Plug Receptacle
Series Number Hose Hose Flange Interface Nominal DigiTRON + DigiTRON e

of internal Ø outside Ø A Ø Drg No. Weight Type Type
Ways mm mm mm mm kg Number Number
10 4 12.7 25.2 377 108 T16813 2.35 BROV-10-A004-BQ-DB-MC04S -
PLUG
10 7 12.7 25.2 377 108 T16813 2.35 BROV-10-A004-BQ-DB-HD07S -

20 12 12.7 25.2 413 122 T16561 3.37 BROV-20-A004-BQ-DB-HD12S EROV-20-A004-BQ-DC-HD12S
RECEPTACLE
10 4 12.7 25.2 345 108 T16813 2.29 BROV-10-B004-BQ-DB-MC04P -

10 7 12.7 25.2 345 108 T16813 2.29 BROV-10-B004-BQ-DB-HD07P -
20 12 12.7 25.2 383 122 T16561 2.82 BROV-20-B004-BQ-DB-HD12P EROV-20-B004-BQ-DC-HD12P
DigiTRON + ROV series [10 / 20] flying plug/receptacle with [4 / 7 / 12] pins/sockets and AquaTRON oil tube fitting.
DigiTRON e ROV series 20 flying plug/receptacle with 12 pins/sockets and AquaTRON oil tube fitting.
19
ROV Connectors
A A
Plug Receptacle

10 4 12.7 25.2 226 108 T16813 3.53 BROV-10-A006-BQ-DB-MC04S -
PLUG
10 7 12.7 25.2 226 108 T16813 3.53 BROV-10-A006-BQ-DB-HD07S -

20 12 12.7 25.2 264 122 T16561 4.45 BROV-20-A006-BQ-DB-HD12S EROV-20-A006-BQ-DC-HD12S
RECEPTACLE
10 4 12.7 25.2 192 108 T16813 3.47 BROV-10-B006-BQ-DB-MC04P -

10 7 12.7 25.2 192 108 T16813 3.47 BROV-10-B006-BQ-DB-HD07P -
20 12 12.7 25.2 206 122 T16561 4.94 BROV-20-B006-BQ-DB-HD12P EROV-20-B006-BQ-DC-HD12P
DigiTRON + ROV series [10 / 20] compliantly mounted 90° plug/receptacle with [4 / 7 / 12] pins/sockets and AquaTRON oil tube fitting.
DigiTRON e ROV series 20 compliantly mounted 90° plug/receptacle with 12 pins/sockets and AquaTRON oil tube fitting.
ROV BULKHEAD MOUNTED CONNECTORS

A A
Plug Receptacle
Series Number Flange Interface Nominal DigiTRON + DigiTRON e

of A Ø Drg No. Weight Type Type
10 4 126 88 T8346 1.20 BROV-10-H001-BQ-MC04S -
RECEPTACLE PLUG
10 7 126 88 T8346 1.20 BROV-10-H001-BQ-HD07S -

20 12 126 93 T11685 1.30 BROV-20-H001-BQ-HD12S EROV-20-H001-BQ-HD12S
10 4 135 88 T8346 1.30 BROV-10-G001-BQ-MC04P -
10 7 135 88 T8346 1.30 BROV-10-G001-BQ-HD07P -
20 12 135 93 T11685 1.60 BROV-20-G001-BQ-HD12P EROV-20-G001-BQ-HD12P
DigiTRON + ROV series [10 / 20] bulkhead plug/receptacle with [4 / 7 / 12] pins/sockets.
DigiTRON e ROV series 20 bulkhead plug/receptacle with 12 pins/sockets.
Depth rating 4 / 7 / 12 is 4000m compensated.
20
ROV Connectors
ROV BULKHEAD MOUNTED CONNECTORS (4000m Full Differential)

A A
Plug Receptacle
Series Number Flange Interface Nominal DigiTRON +

of A Ø Drg No. Weight Type
Ways mm mm kg Number
- - - - - - -
RECEPTACLE PLUG
- - - - - - -
20 12 152 93 T17162 1.88 BROV-20-H003-BQ-HD12S
- - - - - - -
10 7 161 93 T17162 2.17 BROV-10-G003-BQ-HD07P
20 12 161 93 T17162 2.31 BROV-20-G003-BQ-HD12P
DigiTRON + ROV series [10 / 20] bulkhead plug/receptacle with [7 / 12] pins/sockets.
DigiTRON e ROV series 20 bulkhead plug/receptacle with 12 pins/sockets.
ROV FLYING DUMMY CONNECTORS

A A
Plug Receptacle
Series Number Nominal DigiTRON + DigiTRON e

of A Weight Type Type
Ways mm kg Number Number
10 4 325 2.23 BROV-10-L001-BQ-MC04S -
RECEPTACLE PLUG
10 7 325 2.23 BROV-10-L001-BQ-HD07S -

20 12 363 2.90 BROV-20-L001-BQ-HD12S EROV-20-L001-BQ-HD12S
10 4 334 2.38 BROV-10-M002-BQ-MC04P -
10 7 334 2.38 BROV-10-M002-BQ-HD07P -
20 12 372 2.89 BROV-20-M002-BQ-HD12P EROV-20-M002-BQ-HD12P
DigiTRON + ROV series [10 / 20] dummy plug/receptacle with [4 / 7 / 12] pins/sockets.
DigiTRON e ROV series 20 dummy plug plug/receptacle with 12 pins/sockets.
Please specify internal shorting requirements if required for continuity testing.
21
ROV Connectors
ROV FIXED DUMMY CONNECTORS

A A
Plug Receptacle

10 4 176 88 & 120 T13234 1.66 BROV-10-L002-BQ-MC04S -
RECEPTACLE PLUG
10 7 176 88 & 120 T13234 1.66 BROV-10-L002-BQ-HD07S -

20 12 176 98 & 120 T11161 2.24 BROV-20-L002-BQ-HD12S Use DigiTRON+ Type Number
10 4 184 88 & 120 T13234 1.81 BROV-10-M004-BQ-MC04P -
10 7 184 88 & 120 T13234 1.81 BROV-10-M004-BQ-HD07P -
20 12 184 98 & 120 T11161 2.23 BROV-20-M004-BQ-HD12P Use DigiTRON+ Type Number
ROV COMPLIANTLY MOUNTED DUMMY CONNECTORS

A A
Compliant Compliant
Mount Mount
Plug Receptacle
Please Note: DigiTRON+ connectors shown

10 4 220 108 T16813 2.62 BROV-10-L003-BQ-MC04S -
RECEPTACLE PLUG
10 7 220 108 T16813 2.62 BROV-10-L003-BQ-HD07S -

20 12 258 122 T16561 3.64 BROV-20-L003-BQ-HD12S Use DigiTRON+ Type Number
10 4 188 108 T16813 2.57 BROV-10-M003-BQ-MC04P -
10 7 188 108 T16813 2.57 BROV-10-M003-BQ-HD07P -
20 12 225 122 T16561 3.10 BROV-20-M003-BQ-HD12P Use DigiTRON+ Type Number
22
ROV Connectors
ROV PARKING CONNECTORS

A A
Plug Receptacle
Series Number Flange Nominal Interface DigiTRON + DigiTRON e

of A Ø Weight Drawing Type Type
Ways mm mm kg Number Number Number
10 not applicable 110 89 0.34 T13234 BROV-10-L004-AC -
RECEPTACLE PLUG
20 not applicable 110 100 0.34 T11161 BROV-20-L004-AC Use DigiTRON+ Type Number
- - - - - - - -
10 not applicable 100 89 1.56 T13234 BROV-10-M001-CD -
20 not applicable 100 94 1.61 T11161 BROV-20-M001-CD Use DigiTRON+ Type Number
- - - - - - - -
DigiTRON + & e ROV series [10 / 20] parking plug - used for very short term parking of flying receptacle.
DigiTRON + & e ROV series 20 parking receptacle - used for long term parking of flying plug.
MANUALLY OPERATED PROTECTIVE CAPS FOR ROV CONNECTORS

A A
Cap for Receptacle Cap for Plug

PLUG RECEPTACLE
10 not applicable 65 0.15 BROV-10-R001-AC -

CAP FOR CAP FOR
20 not applicable 65 0.15 BROV-20-R001-AC Use DigiTRON+ Type Number

- - - - - -
10 not applicable 102 0.25 BROV-10-P001-AC -
20 not applicable 102 0.25 BROV-20-P001-AC Use DigiTRON+ Type Number
- - - - - -
Cap for DigiTRON + ROV series [10 / 20] plug/receptacle - used for marine growth / transport protection.
Cap for DigiTRON e ROV series 20 plug/receptacle - used for marine growth / transport protection.
23
ROV Connectors
ROV OPERATED PROTECTIVE CAPS

A A
Cap for Receptacle Cap for Plug

PLUG RECEPTACLE
10 not applicable 255 1.16 BROV-10-R002-AC -

CAP FOR CAP FOR
20 not applicable 255 1.16 BROV-20-R002-AC Use DigiTRON+ Type Number

- - - - - -
10 not applicable 275 2.25 BROV-10-P002-AC -
20 not applicable 286 1.21 BROV-20-P002-AC Use DigiTRON+ Type Number
- - - - - -
Cap for DigiTRON + ROV series [10 / 20] receptacle - used for very short term subsea protection.
Cap for DigiTRON e ROV series 20 plug - used to protect against marine growth.
ROV TEST CONNECTORS

A A
Plug Receptacle

10 4 118 0.28 BROV-10-T001-CD-MC04S -
RECEPTACLE PLUG
10 7 118 0.32 BROV-10-T001-CD-HD07S -

20 12 118 0.43 BROV-20-T001-CD-HD12S EROV-20-T001-BQ-HD12S
10 4 125 0.27 BROV-10-T002-AC-MC04P -
10 7 125 0.27 BROV-10-T002-AC-HD07P -
20 12 125 0.38 BROV-20-T002-AC-HD12P EROV-20-T002-BQ-HD12P
DigiTRON + ROV series [10 / 20] test plug/receptacle with [4 / 7 / 12] pins/sockets - used for factory testing in air.
DigiTRON e ROV series 20 test plug/receptacle with 12 pins/sockets - used for factory testing in air.
Standard wiring convention to SIIS level 3 unless specified by customer.
24
Stab Plate Connectors
Stab Plate Deployment
• The stab plates provide movement and clamping force

for mate / demate
• Floating mounts on one connector accommodate
misalignment
• Standard connectors suit popular hydraulic coupler stab
plate stack up distances
Stab Plate Notes
1 Stab plate connectors are manufactured from 316L

stainless steel (UNS S31603), and must be connected to
a cathodic protection system (UNS S32550 available).
2 Due to the number of different stab plate connector

configurations, Siemens Subsea recommend that stab
plate connectors are specified and purchased in pairs.
7 way 90° Stab Plate plug for cable
For this reason, DigiTRON stab plate connectors are not
always compatible with Mini CE.
3 The use of dummy connectors is advised if the pins on

receptacles are likely to be exposed to seawater. The
advised maximum cumulative exposure over the life of
the connector is 28 days, although some pin
deterioration may occur in a shorter period.
7 way Stab Plate plug &
receptacle for oil tube
4 way Stab Plate receptacle
25

Number STAB PLATE PLUG FOR CABLE STAB PLATE RECEPTACLE FOR CABLE Number
(A001/A002) (B001/B002)
29 29
STAB PLATE PLUG FOR AQUATRON OIL TUBE STAB PLATE RECEPTACLE FOR AQUATRON OIL TUBE
(A003/A004) (B003/B004)
30 30
90° STAB PLATE PLUG FOR CABLE 90° STAB PLATE RECEPTACLE FOR CABLE
(A005/A006) (B005/B006)
31 31
90° STAB PLATE PLUG 90° STAB PLATE RECEPTACLE

FOR AQUATRON OIL TUBE (A007/A008) FOR AQUATRON OIL TUBE (B007/B008)
32 32
STAB PLATE BULKHEAD MOUNTED PLUG STAB PLATE BULKHEAD MOUNTED RECEPTACLE
(H001) (G001)
33 33
STAB PLATE DUMMY PLUG STAB PLATE DUMMY RECEPTACLE

(L001/L002) (M001/M002)
33 33
PROTECTIVE CAP FOR STAB PLATE PLUG PROTECTIVE CAP FOR STAB PLATE RECEPTACLE
(P001) (R001)
34 34
STAB PLATE TEST PLUG STAB PLATE TEST RECEPTACLE

(T001) (T002)
34 34
STAB PLATE PARKING RECEPTACLE

(M006/M007)
30
26
Fixed & Floating Mounts

Fixed Flange Floating Flange
One connector in a stab plate pair is normally fitted with
floating mounts, the other is fixed. Floating mounts
allow approximately ±1 mm movement laterally. The
following tables include a reference to fixed or floating
to differentiate the two types of mounting.
Split Flanges
Split flanges can be provided so that pre-terminated

harnesses can be passed through the hole in the stab
plate and then fixed from the other side. Split Flange
Large Conductors
DigiTRON solder cups can accommodate conductors up

to 4 mm2 (12 awg). Termination to a cable with larger
conductors is achieved by using crimps and tailing wires.
A gland extension piece is used to accommodate this
arrangement.
Please contact our Customer Support Department for

more details.
Solid Flange
Sleeve Crimp
CRIMP ADAPTOR
Large Conductors - Gland Extension / Crimps

Extension Pieces Crimp Adaptor
27
Stab Plate Distances

Inside Faces
DigiTRON™ Stab Plate connectors are designed to be
compatible with common hydraulic couplers. Flanges on
stab plate connectors are 10 mm thick.
If both connectors are mounted on the inside face of the

plates, the closed distance between the inside of the
plates must be 100 to 101 mm.
If both connectors are mounted on the outside face of the

plates, the closed distance between the outside of the
plates must be 80 to 81 mm.
100 / 101 mm
If one connector is mounted on an outside face, and the
other on the inside face, the distance between the two
faces to which the connectors are fitted must be 90 to 91
mm.
Outside Faces
80 / 81 mm
One / Other Faces
90 / 91 mm
28
STAB PLATE CONNECTORS FOR CABLE

A A
Plug Receptacle
Series Number Gland Cable Flange Flange Interface Nominal DigiTRON + DigiTRON e
of Series Ø A Size Type Drg No. Weight Type Type
10 4 G10 8 to 22.9 287 70 x 70 Fixed T11164 1.77 BSTA-10-A001-AA-G10-MC04S -
10 7 G10 8 to 22.9 287 70 x 70 Fixed T11164 1.77 BSTA-10-A001-AA-G10-HD07S -
10 4 G10 8 to 22.9 287 70 x 70 Floating T11164 1.77 BSTA-10-A002-AA-G10-MC04S -
10 7 G10 8 to 22.9 287 70 x 70 Floating T11164 1.77 BSTA-10-A002-AA-G10-HD07S -
PLUG
10 4 G20 23 to 35 347 70 x 70 Fixed T11164 2.28 BSTA-10-A001-AA-G20-MC04S -

10 7 G20 23 to 35 347 70 x 70 Fixed T11164 2.28 BSTA-10-A001-AA-G20-HD07S -
10 4 G20 23 to 35 347 70 x 70 Floating T11164 2.28 BSTA-10-A002-AA-G20-MC04S -
10 7 G20 23 to 35 347 70 x 70 Floating T11164 2.28 BSTA-10-A002-AA-G20-HD07S -
20 12 G20 23 to 35 345 74 x 74 Fixed T11127 2.47 BSTA-20-A001-AA-G20-HD12S ESTA-20-A001-AA-G20-HD12S
20 12 G20 23 to 35 345 74 x 74 Floating T11127 2.47 BSTA-20-A002-AA-G20-HD12S ESTA-20-A002-AA-G20-HD12S
10 4 G10 8 to 22.9 287 70 x 70 Fixed T11164 2.98 BSTA-10-B001-AA-G10-MC04P -
10 7 G10 8 to 22.9 287 70 x 70 Fixed T11164 2.98 BSTA-10-B001-AA-G10-HD07P -
10 4 G10 8 to 22.9 287 70 x 70 Floating T11164 2.05 BSTA-10-B002-AA-G10-MC04P -
RECEPTACLE
10 7 G10 8 to 22.9 287 70 x 70 Floating T11164 2.05 BSTA-10-B002-AA-G10-HD07P -

10 4 G20 23 to 35 347 70 x 70 Fixed T11164 2.57 BSTA-10-B001-AA-G20-MC04P -
10 7 G20 23 to 35 347 70 x 70 Fixed T11164 2.57 BSTA-10-B001-AA-G20-HD07P -
10 4 G20 23 to 35 347 70 x 70 Floating T11164 2.56 BSTA-10-B002-AA-G20-MC04P -
10 7 G20 23 to 35 347 70 x 70 Floating T11164 2.56 BSTA-10-B002-AA-G20-HD07P -
20 12 G20 23 to 35 345 74 x 74 Fixed T11127 2.94 BSTA-20-B001-AA-G20-HD12P ESTA-20-B001-AA-G20-HD12P
20 12 G20 23 to 35 345 74 x 74 Floating T11127 2.94 BSTA-20-B002-AA-G20-HD12P ESTA-20-B002-AA-G20-HD12P
DigiTRON + Stab Plate series [10 / 20] plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON e Stab Plate series 20 plug/receptacle with12 pins/sockets and size [10 / 20] cable gland.
29
STAB PLATE CONNECTORS FOR AQUATRON OIL TUBE

A A
Plug Receptacle
Series Number Hose Hose Flange Flange Interface Nominal DigiTRON + DigiTRON e
of internal external A Size Type Drg No. Weight Type Type
Ways Ø mm Ø mm mm mm kg Number Number
10 4 12.7 25.2 329 70 x 70 Fixed T11164 1.19 BSTA-10-A003-AA-DB-MC04S -
10 7 12.7 25.2 329 70 x 70 Fixed T11164 1.19 BSTA-10-A003-AA-DB-HD07S -
PLUG
10 4 12.7 25.2 329 70 x 70 Floating T11164 1.19 BSTA-10-A004-AA-DB-MC04S -

10 7 12.7 25.2 329 70 x 70 Floating T11164 1.19 BSTA-10-A004-AA-DB-HD07S -
20 12 12.7 25.2 367 74 x 74 Fixed T11127 1.83 BSTA-20-A003-AA-DB-HD12S ESTA-20-A003-AA-DC-HD12S
20 12 12.7 25.2 367 74 x 74 Floating T11127 1.83 BSTA-20-A004-AA-DB-HD12S ESTA-20-A004-AA-DC-HD12S
10 4 12.7 25.2 329 70 x 70 Fixed T11164 1.47 BSTA-10-B003-AA-DB-MC04P -
RECEPTACLE
10 7 12.7 25.2 329 70 x 70 Fixed T11164 1.47 BSTA-10-B003-AA-DB-HD07P -

10 4 12.7 25.2 329 70 x 70 Floating T11164 1.47 BSTA-10-B004-AA-DB-MC04P -
10 7 12.7 25.2 329 70 x 70 Floating T11164 1.47 BSTA-10-B004-AA-DB-HD07P -
20 12 12.7 25.2 367 74 x 74 Fixed T11127 2.10 BSTA-20-B003-AA-DB-HD12P ESTA-20-B003-AA-DC-HD12P
20 4 12.7 25.2 367 74 x 74 Floating T11127 2.10 BSTA-20-B004-AA-DB-HD12P ESTA-20-B004-AA-DC-HD12P
DigiTRON + Stab Plate series [10 / 20] plug/receptacle with [4 / 7 / 12] pins/sockets and AquaTRON oil tube fitting.
DigiTRON e Stab Plate series 20 plug/receptacle with 12 pins/sockets and AquaTRON oil tube fitting.
STAB PLATE PARKING RECEPTACLE

A
Receptacle
Series Number Flange Flange Interface Nominal DigiTRON + DigiTRON e

of A Size Type Drg No. Weight Type Type
RECEPTACLE
10 not applicable 87 70 x 70 Fixed T11164 0.75 BSTA-10-M006-AA -

10 not applicable 87 70 x 70 Floating T11164 0.75 BSTA-10-M007-AA -
20 not applicable 87 70 x 70 Fixed T11127 0.99 BSTA-20-M006-AA Use DigiTRON+ Type Number
20 not applicable 87 70 x 70 Floating T11127 0.99 BSTA-20-M007-AA Use DigiTRON+ Type Number
DigiTRON + Stab Plate series [10 / 20] flange mounted parking receptacle.
DigiTRON e Stab Plate series 20 flange mounted parking receptacle.
30
A A
Plug Receptacle
Series Number Gland Cable Flange Flange Interface Nominal DigiTRON + DigiTRON e
of Series Ø A Size Type Drg No. Weight Type Type
10 4 G10 8 to 22.9 178 70 x 70 Fixed T11164 2.95 BSTA-10-A005-AA-G10-MC04S -
10 7 G10 8 to 22.9 178 70 x 70 Fixed T11164 2.95 BSTA-10-A005-AA-G10-HD07S -
10 4 G10 8 to 22.9 178 70 x 70 Floating T11164 2.95 BSTA-10-A006-AA-G10-MC04S -
10 7 G10 8 to 22.9 178 70 x 70 Floating T11164 2.95 BSTA-10-A006-AA-G10-HD07S -
10 4 G20 23 to 35 178 70 x 70 Fixed T11164 3.46 BSTA-10-A005-AA-G20-MC04S -
PLUG

10 4 G20 23 to 35 178 70 x 70 Floating T11164 3.46 BSTA-10-A006-AA-G20-MC04S -
20 12 G20 23 to 35 191 74 x 74 Fixed T11127 4.54 BSTA-20-A005-AA-G20-HD12S ESTA-20-A005-AA-G20-HD12S
20 12 G20 23 to 35 191 74 x 74 Floating T11127 4.53 BSTA-20-A006-AA-G20-HD12S ESTA-20-A006-AA-G20-HD12S
10 4 G10 8 to 22.9 178 70 x 70 Fixed T11164 2.24 BSTA-10-B005-AA-G10-MC04P -
10 7 G10 8 to 22.9 178 70 x 70 Fixed T11164 2.24 BSTA-10-B005-AA-G10-HD07P -
10 4 G10 8 to 22.9 178 70 x 70 Floating T11164 2.24 BSTA-10-B006-AA-G10-MC04P -
10 7 G10 8 to 22.9 178 70 x 70 Floating T11164 2.24 BSTA-10-B006-AA-G10-HD07P -
RECEPTACLE
10 4 G20 23 to 35 178 70 x 70 Fixed T11164 3.75 BSTA-10-B005-AA-G20-MC04P -

10 4 G20 23 to 35 178 70 x 70 Floating T11164 3.75 BSTA-10-B006-AA-G20-MC04P -
20 12 G20 23 to 35 190 74 x 74 Fixed T11127 4.54 BSTA-20-B005-AA-G20-HD12P ESTA-20-B005-AA-G20-HD12P
20 12 G20 23 to 35 190 74 x 74 Floating T11127 4.53 BSTA-20-B006-AA-G20-HD12P ESTA-20-B006-AA-G20-HD12P
90° DigiTRON + Stab Plate series [10 / 20] plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
90° DigiTRON e Stab Plate series 20 plug/receptacle with 12 pins/sockets and size [10 / 20] cable gland.
31
A A
Plug Receptacle
Series Number Hose Hose Flange Flange Interface Nominal DigiTRON + DigiTRON e
of internal external A Size Type Drg No. Weight Type Type
10 4 12.7 25.2 178 70 x 70 Fixed T11164 2.37 BSTA-10-A007-AA-DB-MC04S -
10 7 12.7 25.2 178 70 x 70 Fixed T11164 2.37 BSTA-10-A007-AA-DB-HD07S -
PLUG
10 4 12.7 25.2 178 70 x 70 Floating T11164 2.36 BSTA-10-A008-AA-DB-MC04S -

10 7 12.7 25.2 178 70 x 70 Floating T11164 2.36 BSTA-10-A008-AA-DB-HD07S -
20 12 12.7 25.2 216 74 x 74 Fixed T11127 3.00 BSTA-20-A007-AA-DB-HD12S ESTA-20-A007-AA-DC-HD12S
20 12 12.7 25.2 216 74 x 74 Floating T11127 3.00 BSTA-20-A008-AA-DB-HD12S ESTA-20-A008-AA-DC-HD12S
10 4 12.7 25.2 178 70 x 70 Fixed T11164 2.65 BSTA-10-B007-AA-DB-MC04P -
RECEPTACLE
10 7 12.7 25.2 178 70 x 70 Fixed T11164 2.65 BSTA-10-B007-AA-DB-HD07P -

10 4 12.7 25.2 178 70 x 70 Floating T11164 2.65 BSTA-10-B008-AA-DB-MC04P -
10 7 12.7 25.2 178 70 x 70 Floating T11164 2.65 BSTA-10-B008-AA-DB-HD07P -
20 12 12.7 25.2 216 74 x 74 Fixed T11127 3.00 BSTA-20-B007-AA-DB-HD12P ESTA-20-B007-AA-DC-HD12P
20 12 12.7 25.2 216 74 x 74 Floating T11127 3.00 BSTA-20-B008-AA-DB-HD12P ESTA-20-B008-AA-DC-HD12P
90° DigiTRON + Stab Plate series [10 / 20] plug/receptacle with [4 / 7 / 12] pins/sockets and AquaTRON oil tube fitting.
90° DigiTRON e Stab Plate series 20 plug/receptacle with 12 pins/sockets and AquaTRON oil tube fitting.
32
STAB PLATE BULKHEAD MOUNTED CONNECTORS

A A
Plug Receptacle

of A Size Drg No. Weight Type Type
10 4 88 70 x 70 T9584 0.56 BSTA-10-H001-AA-MC04S -
PLUG
10 7 88 70 x 70 T9584 0.56 BSTA-10-H001-AA-HD07S -

20 12 88 70 x 70 T11126 0.69 BSTA-20-H001-AA-HD12S ESTA-20-H001-AA-HD12S
- - - - - - - -
RECEPTACLE
10 4 88 70 x 70 T9584 0.52 BSTA-10-G001-AA-MC04P -

10 7 88 70 x 70 T9584 0.52 BSTA-10-G001-AA-HD07P -
20 12 88 70 x 70 T11126 1.60 BSTA-20-G001-AA-HD12P ESTA-20-G001-AA-HD12P
- - - - - - - -
DigiTRON + Stab Plate bulkhead mounted series [10 / 20] plug/receptacle with [4 / 7 / 12] pins/sockets.
DigiTRON e Stab Plate bulkhead mounted series [10 / 20] plug/receptacle with [7 / 12] pins/sockets.
STAB PLATE DUMMY CONNECTORS

A A
Plug Receptacle
Series Number Flange Flange Interface Nominal DigiTRON + DigiTRON e

of A Size Type Drg No. Weight Type Type
10 4 172 70 x 70 Fixed T11164 1.46 BSTA-10-L001-AA-MC04S -
10 7 172 70 x 70 Fixed T11164 1.46 BSTA-10-L001-AA-HD07S -
PLUG
10 4 172 70 x 70 Floating T11164 1.46 BSTA-10-L002-AA-MC04S -

10 7 172 70 x 70 Floating T11164 1.46 BSTA-10-L002-AA-HD07S -
20 12 209 74 x 74 Fixed T11127 2.10 BSTA-20-L001-AA-HD12S Use DigiTRON+ Type Number
20 12 209 74 x 74 Floating T11127 2.10 BSTA-20-L002-AA-HD12S Use DigiTRON+ Type Number
10 4 172 70 x 70 Fixed T11164 1.74 BSTA-10-M001-AA-MC04P -
RECEPTACLE
10 7 172 70 x 70 Fixed T11164 1.74 BSTA-10-M001-AA-HD07P -

10 4 172 70 x 70 Floating T11164 1.74 BSTA-10-M002-AA-MC04P -
10 7 172 70 x 70 Floating T11164 1.74 BSTA-10-M002-AA-HD07P -
20 12 209 74 x 74 Fixed T11127 2.10 BSTA-20-M001-AA-HD12P Use DigiTRON+ Type Number
20 12 209 74 x 74 Floating T11127 2.10 BSTA-20-M002-AA-HD12P Use DigiTRON+ Type Number
DigiTRON + Stab Plate series [10 / 20] dummy plug/receptacle with [4 / 7 / 12] pins/sockets.
DigiTRON e Stab Plate series 20 dummy plug/receptacle with 12 pins/sockets.
33
PROTECTIVE CAPS FOR STAB PLATE CONNECTORS

A A
Cap for plug Cap for receptacle

10 not applicable 89 0.12 BSTA-10-P001-AC -
CAP FOR CAP FOR
RECEPTACLE PLUG
20 not applicable 86 0.12 BSTA-20-P001-AC Use DigiTRON+ Type Number

- - - - - -
10 not applicable 97 0.14 BSTA-10-R001-AC -
20 not applicable 97 0.15 BSTA-20-R001-AC Use DigiTRON+ Type Number
- - - - - -
Manually operated cap for DigiTRON + & e Stab Plate series [10 / 20] plug
- used for transport / storage / subsea protection.
Manually operated cap for DigiTRON + & e Stab Plate series 20 receptacle
- used for transport and storage but NOT subsea protection.
STAB PLATE TEST CONNECTORS

A A
Plug Receptacle

10 4 118 0.28 BSTA-10-T001-CD-MC04S -
RECEPTACLE PLUG
10 7 118 0.28 BSTA-10-T001-CD-HD07S -

20 12 118 0.47 BSTA-20-T001-CD-HD12S ESTA-20-T001-AA-HD12S
10 4 115 0.22 BSTA-10-T002-AC-MC04P -
10 7 115 0.22 BSTA-10-T002-AC-HD07P -
20 12 115 0.27 BSTA-20-T002-AC-HD12P ESTA-20-T002-AA-HD12P
DigiTRON + Stab Plate series [10 / 20] test plug/receptacle with [4 / 7 / 12] pins/sockets - used for factory testing in air.
DigiTRON e Stab Plate series 20 test plug/receptacle with 12 pins/sockets - used for factory testing in air.
34
Diver Connectors
Diver Deployment
• A threaded clamp ring ensures secure, low-

force clamping of connector pairs without
galling
• Connectors are manufactured from UNS
S31603 stainless steel (also available in
UNS S32550) for a 30 year design life
when deployed in conjunction with a
cathodic protection system
Diver Notes
1 DigiTRON Diver connectors are not

compatible with the Mini CE Range. Mini
CE diver connectors were always
manufactured with dual keys whereas
DigiTRON have a single key. In
emergencies, it may be useful to note that
a 4 way DigiTRON diver plug will physically 4 way Diver plug & receptacle for cable
fit into a 4 way Mini CE receptacle. Severe damage to both
connectors will occur unless care is taken to ensure that the
single key on the DigiTRON plug is fitted into the 12 o'clock
keyway on the Mini CE receptacle.
2 7 and 12 way DigiTRON connectors are NOT Mini CE

compatible.
3 Diver connectors are manufactured from UNS S31603

stainless steel and must be connected to a corrosion
protection system (e.g. via internal earth ring, earth straps
etc.).
4 The use of dummy connectors is advised if the pins on

receptacles are likely to be exposed to seawater for any
significant period. The advised maximum cumulative
exposure over the life of the connector is 28 days, although
some pin deterioration may occur in a shorter period. 12 way Diver plug and receptacle for cable
Diver bulkhead receptacle
35
Diver Connectors

Number Number
Diver Connectors
DIVER PLUG DIVER RECEPTACLE

38 38
90° DIVER PLUG 90° DIVER RECEPTACLE

38 38
Diver Connectors
DIVER FLANGE MOUNTED PLUG DIVER FLANGE MOUNTED RECEPTACLE

39 39
90° DIVER FLANGE MOUNTED PLUG 90° DIVER FLANGE MOUNTED RECEPTACLE
39 39
Diver Connectors
DIVER PLUG DIVER RECEPTACLE

40 40
90° DIVER PLUG 90° DIVER RECEPTACLE

Diver Connectors
40 40
DIVER FLANGE MOUNTED PLUG DIVER FLANGE MOUNTED RECEPTACLE

Diver Connectors
41 41
36
Diver Connectors

Number Number
Diver Connectors
90° DIVER FLANGE MOUNTED PLUG 90° DIVER FLANGE MOUNTED RECEPTACLE
41 41
Diver Connectors
DIVER BULKHEAD MOUNTED PLUG DIVER BULKHEAD MOUNTED RECEPTACLE
(H001) (G001)
42 42
DIVER BULKHEAD MOUNTED PLUG DIVER BULKHEAD MOUNTED RECEPTACLE

4000m Full Differential (H006) (G003) 4000m Full Differential
42 42
DIVER FLYING DUMMY PLUG DIVER FLYING DUMMY RECEPTACLE

(L001) (M001)
Diver Connectors
43 43
DIVER FIXED DUMMY PLUG DIVER FIXED DUMMY RECEPTACLE

(L002) (M002)
43 43
PROTECTIVE CAP FOR DIVER PLUG PROTECTIVE CAP FOR DIVER RECEPTACLE
(P001) (R001)
44 44
Diver Connectors
DIVER TEST PLUG DIVER TEST RECEPTACLE
(T001) (T002)
44 44
DIVER PARKING RECEPTACLE

(M003)
44
Diver Connectors
37
Diver Connectors
DIVER CONNECTORS FOR CABLE

A A
Plug Receptacle

10 4 G10 8 to 22.9 280 1.57 BDIV-10-A001-AA-G10-MC04S -
10 7 G10 8 to 22.9 280 1.57 BDIV-10-A001-AA-G10-HD07S -
PLUG
10 4 G20 23 to 35 318 2.08 BDIV-10-A001-AA-G20-MC04S -

10 7 G20 23 to 35 318 2.08 BDIV-10-A001-AA-G20-HD07S -
20 12 G20 23 to 35 318 2.24 BDIV-20-A001-AA-G20-HD12S EDIV-20-A001-AA-G20-HD12S
10 4 G10 8 to 22.9 280 1.78
RECEPTACLE
BDIV-10-B001-AA-G10-MC04P -
10 7 G10 8 to 22.9 280 1.78 BDIV-10-B001-AA-G10-HD07P -
10 4 G20 23 to 35 318 2.28 BDIV-10-B001-AA-G20-MC04P -
10 7 G20 23 to 35 318 2.28 BDIV-10-B001-AA-G20-HD07P -
20 12 G20 23 to 35 318 2.33 BDIV-20-B001-AA-G20-HD12P EDIV-20-B001-AA-G20-HD12P
DigiTRON + Diver series [10 / 20] plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON e Diver series 20 plug/receptacle with 7 / 12 pins/sockets and size [10 / 20] cable gland.
A A
Plug Receptacle

10 4 G10 8 to 22.9 174 2.75 BDIV-10-A006-AA-G10-MC04S -
10 7 G10 8 to 22.9 174 2.75 BDIV-10-A006-AA-G10-HD07S -
PLUG
10 4 G20 23 to 35 174 3.26 BDIV-10-A006-AA-G20-MC04S -

10 7 G20 23 to 35 174 3.26 BDIV-10-A006-AA-G20-HD07S -
10 4 G10 8 to 22.9 174 2.95
RECEPTACLE
10 7 G10 8 to 22.9 174 2.95 BDIV-10-B006-AA-G10-HD07P -
10 4 G20 23 to 35 174 3.46 BDIV-10-B006-AA-G20-MC04P -
10 7 G20 23 to 35 174 3.46 BDIV-10-B006-AA-G20-HD07P -
20 12 G20 23 to 35 187 4.45 BDIV-20-B006-AA-G20-HD12P EDIV-20-B006-AA-G20-HD12P
DigiTRON + Diver series [10 / 20] 90° plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON e Diver series 20 - 90° plug/receptacle with 12 pins/sockets and size [10 / 20] cable gland.
38
Diver Connectors
DIVER
DIVER FLANGE CONNECTORS
DIVERMOUNTED
CONNECTORS FORCABLE
FOR CABLE
CONNECTORS FOR CABLE
AA
A A
A
B B
Plug
Plug Receptacle
Receptacle
Plug Receptacle
Series Number
Number Gland Cable Ø Nominal DigiTRON + + DigiTRON ee
Series of Gland Cable
Series A Nominal
Flange Weight Interface DigiTRON
Type DigiTRON
Type
of Series Ø A B Weight Type Type
ofWaysSeries Ø mm A mm Weight
Ø kg Drg No. NumberType NumberType
Ways
Ways mm mm mm mmmm mm kg
kg Number
Number Number
Number
10 4 G10 8 to 22.9 280 1.57 BDIV-10-A001-AA-G10-MC04S -
10 4 10 8 to 23 280 56 1.75 BDIV-10-A001-AA-G10-MC04S -
10 10 4 7 G10 G10 8 to 22.98 to315
22.9 88
280 2.12
1.57 T8399BDIV-10-A001-AA-G10-HD07S
BDIV-10-A002-AA-G10-MC04S - -
PLUG
10 7 10 8 to 23 280 56 1.75 BDIV-10-A001-AA-G10-HD07S EDIV-10-A001-AA-G10-HD07S

10 10 7 4 G10 G20 8 to 22.923 to315 88 2.12 T8399 BDIV-10-A002-AA-G10-HD07S -
PLUG
35 318 2.08 BDIV-10-A001-AA-G20-MC04S -

PLUG
10 4 20 23 to 35 318 63 2.25 BDIV-10-A001-AA-G20-MC04S -

10 10 4 7 G20 G20 23 to 35 23 to374
35 88
318 2.63 BDIV-10-A002-AA-G20-MC04S
2.08 T8399BDIV-10-A001-AA-G20-HD07S - -
10 7 20 23 to 35 318 63 2.25 BDIV-10-A001-AA-G10-HD07S EDIV-10-A001-AA-G10-HD07S
10 20 7 12 G20 G20 23 to 35 23 to374
35 88
318 2.63
2.24 T8399BDIV-20-A001-AA-G20-HD12S
BDIV-10-A002-AA-G20-HD07S EDIV-20-A001-AA-G20-HD12S -
20 12 20 23 to 35 318 69 2.75 BDIV-20-A001-AA-G20-HD12S DIV-20-A001-AA-G20-HD12S
20 10 12 4 G20 G10 23 to 358 to37222.9 93
280 2.91
1.78 T15470 BDIV-20-A002-AA-G20-HD12S EDIV-20-A002-AA-G20-HD12S
RECEPTACLE
10 4 10 8 to 23 280 51 2.00 BDIV-10-B001-AA-G10-MC04P -
RECEPTACLE
10 10 4 7 G10 G10 8 to 22.98 to285 88 1.78 T8399BDIV-10-B001-AA-G10-HD07P

2.31
RECEPTACLE
22.9 280 BDIV-10-B002-AA-G10-MC04P - -

10 7 10 8 to 23 280 51 2.00 BDIV-10-B001-AA-G10-HD07P DIV-10-B001-AA-G10-HD07P
10 10 7 4 G10 G20 8 to 22.9 23 to
285
35 88
318 2.28 T8399BDIV-10-B001-AA-G20-MC04P
2.31 BDIV-10-B002-AA-G10-HD07P - -
10 4 20 23 to 35 318 63 2.50 BDIV-10-B001-AA-G20-MC04P -
10 10 4 7 G20 G20 23 to 35 23 to344
35 88
318 2.28 T8399BDIV-10-B001-AA-G20-HD07P
2.61 BDIV-10-B002-AA-G20-MC04P - -
10 7 20 23 to 35 318 63 2.50 BDIV-10-B001-AA-G20-HD07P EDIV-10-B001-AA-G20-HD07P
10 20 7 12 G20 G20 23 to 35 23 to344
35 88
318 2.33 T8399BDIV-20-B001-AA-G20-HD12P
2.61 BDIV-10-B002-AA-G20-HD07P EDIV-20-B001-AA-G20-HD12P -
20 12 20 23 to 35 318 63? 3.00 BDIV-20-B001-AA-G20-HD12P EDIV-20-B001-AA-G20-HD12P
20
DigiTRON12 G20 [10 /23
+ Diver series 20]toplug/receptacle
35 342 93 [4 / 72.65
with / 12] pins/sockets size [10 / 20] cable gland.
T15470 andBDIV-20-B002-AA-G20-HD12P EDIV-20-B002-AA-G20-HD12P
DigiTRON + Diver series [10 / 20] plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON
DigiTRON e Diver
+ Diver series [10 /20
series plug/receptacle
20] flange mounted with 7 / 12 pins/sockets
plug/receptacle / 7size
and
with [4 / 12] / 20] cable and
[10pins/sockets size [10 / 20] cable gland.
gland.
DigiTRON e Diver series [10 / 20] plug/receptacle with [7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON e Diver series 20 flange mounted plug/receptacle with 12 pins/sockets and size [10 / 20] cable gland.
DIVER FLANGE MOUNTED CONNECTORS FOR CABLE

AA A
A
A A
Plug Receptacle
Series Number Gland Cable Flange Nominal Interface DigiTRON + DigiTRON e

of Series Ø A Ø Weight Drg No. Type Type
Plug Receptacle
10 4 10 8 to 23 310 88 2.00 T8399 BROV-10-A002-BQ-G10-MC04S -
10 7 10 8 to 23 310 88
Plug
2.00 T8399
Receptacle
BROV-10-A002-BQ-G10-HD07S EROV-10-A002-BQ-G10-HD07S
PLUG
10 4 20 23 to 35 348 88 2.50 T8399 BROV-10-A002-BQ-G20-MC04S -

Series
10 Number 7 Gland 20 Cable 23 to 35 348 88 Nominal
Flange 2.00 Interface
T8399 DigiTRON +
BROV-10-A002-BQ-G20-HD07S DigiTRON e
EROV-10-A002-BQ-G20-HD07S
20 of12Ways
Series 20 Ø 23 to 35 A 348
mm mm Weight
Ø
93 3.00
kg Drg No.
T15470
Number Type
BROV-20-A002-BQ-G20-HD12S
NumberType
EROV-20-A002-BQ-G20-HD12S
10 Ways 4 mm
G10 8mm
to 22.9 mm
174 kg2.75 Number
BDIV-10-A006-AA-G10-MC04S Number
-
10 4 10 8 to 23 280 88 2.00 T8399 BROV-10-B002-BQ-G10-MC04P -
RECEPTACLE
10 4 7 G10 8 G10 8 to 22.9 174 2.75 T8399BDIV-10-A006-AA-G10-HD07S -

PLUG
10
10 7 10 to 22.98 to 23 204280 88
88 3.30
2.00 T8399 BDIV-10-A008-AA-G10-MC04S
BROV-10-B002-BQ-G10-HD07P -
EROV-10-B002-BQ-G10-HD07P
10 7 4 G10 8 G20 23 to 35 174 3.26 T8399BDIV-10-A006-AA-G20-MC04S -
10
10 4 20 to 22.9
23 to 35 204318 88
88 3.30
2.50 T8399 BDIV-10-A008-AA-G10-HD07S
BROV-10-B002-BQ-G20-MC04P --
PLUG
10 4 7 G20 23G20 174

10
10 7 20 to 23 35 to 3523 to 35
204318 88
88 2.50
3.80
3.26
T8399BDIV-10-A006-AA-G20-HD07S
BDIV-10-A008-AA-G20-MC04S
BROV-10-B002-BQ-G20-HD07P
- -
10
20 712 G20 20 23 to 23
35 to 35 204318 88
93 3.80
3.00 T8399
T15470 BDIV-10-A008-AA-G20-HD07S
BROV-20-B002-BQ-G20-HD12P -
20 10 + 12
Diver 4series /G10 8 217 174
to 22.9plug/receptacle 2.95
RECEPTACLE
DigiTRON G20[1023 to 35
20] flange mounted 93 5.03
with 7 / 12]BDIV-10-B006-AA-G10-MC04P
[4 /T15470 BDIV-20-A008-AA-G20-HD12S
pins/sockets -
and size [10 / 20] cable gland. EDIV-20-A008-AA-G20-HD12S
10
DigiTRON e Diver 7series G10 8 to 22.9 174 2.95 BDIV-10-B006-AA-G10-HD07P -
10 4 G10[108/ to
20]22.9
flange mounted
174 plug/receptacle
88 with
3.76 [7 / 12] pins/sockets
T8399 and size [10 / 20] cable gland.
RECEPTACLE
10 4 G20 23 to 35 174 3.46 BDIV-10-B006-AA-G20-MC04P -
10 7 G10 8 to 22.9 174 88 3.76 T8399 BDIV-10-B008-AA-G10-HD07P -
174
10 10 4 7 G20 23G20 to 35 23 to 35
174 88 3.79
3.46
T8399
BDIV-10-B006-AA-G20-HD07P
BDIV-10-B008-AA-G20-MC04P - -
187
10 20 7 12 G20 23G20 to 35 23 to 35
174 88 3.794.45 T8399BDIV-20-B006-AA-G20-HD12P
BDIV-10-B008-AA-G20-HD07P EDIV-20-B006-AA-G20-HD12P -
DigiTRON12+ DiverG20
20 series [10 / 20]
23 to 35 90° plug/receptacle
187 / 7 / 12] T15470
93with [44.77 pins/sockets and size [10 / 20] cable gland.
BDIV-20-B008-AA-G20-HD12P EDIV-20-B008-AA-G20-HD12P
DigiTRON e Diver series 20 - 90° plug/receptacle with 12 pins/sockets and size [10 / 20] cable gland.
DigiTRON + Diver series [10 / 20] 90° flange mounted plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON e Diver series 20 - 90° flange mounted plug/receptacle with 12 pins/sockets and size [10 / 20] cable gland.
39
Diver Connectors
DIVER CONNECTORS FOR AQUATRON OIL TUBE

A A
Plug Receptacle
Series Number Hose Hose Hose Nominal DigiTRON + DigiTRON e

of internal Ø outside Ø Code A Weight Type Type
10 4 12.7 25.2 DB 325 0.98 BDIV-10-A003-AA-DB-MC04S -
PLUG
10 7 12.7 25.2 DB 325 0.98 BDIV-10-A003-AA-DB-HD07S -

20 12 12.7 25.2 DB 363 1.59 BDIV-20-A003-AA-DB-HD12S EDIV-20-A003-AA-DC-HD12S
RECEPTACLE
10 4 12.7 25.2 DB 325 1.18 BDIV-10-B003-AA-DB-MC04P -

10 7 12.7 25.2 DB 325 1.18 BDIV-10-B003-AA-DB-HD07P -
20 12 12.7 25.2 DB 363 1.68 BDIV-20-B003-AA-DB-HD12P EDIV-20-B003-AA-DC-HD12P
DigiTRON + Diver series [10 / 20] plug/receptacle with [4 / 7 / 12] pins/sockets and AquaTRON oil tube fitting.
DigiTRON e Diver series20 plug /receptacle with 12 pins/sockets and AquaTRON oil tube fitting.
A A
Plug Receptacle
Series Number Hose Hose Nominal DigiTRON + DigiTRON e

of internal Ø outside Ø A Weight Type Type
10 4 12.7 25.2 174 2.16 BDIV-10-A007-AA-DB-MC04S -
PLUG
10 7 12.7 25.2 174 2.16 BDIV-10-A007-AA-DB-HD07S -

20 12 12.7 25.2 187 3.71 BDIV-20-A007-AA-DB-HD12S EDIV-20-A007-AA-DC-HD12S
RECEPTACLE
10 4 12.7 25.2 174 2.36 BDIV-10-B007-AA-DB-MC04P -

10 7 12.7 25.2 174 2.36 BDIV-10-B007-AA-DB-HD07P -
20 12 12.7 25.2 185 3.80 BDIV-20-B007-AA-DB-HD12P EDIV-20-B007-AA-DC-HD12P
DigiTRON + Diver series [10 / 20] 90° flange mounted plug/receptacle with [4 / 7 / 12] pins/sockets and AquaTRON oil tube fitting.
DigiTRON e Diver series 20 - 90° flange mounted plug/receptacle with 12 pins/sockets and AquaTRON oil tube fitting.
40
Diver Connectors
DIVER FLANGE MOUNTED CONNECTORS FOR AQUATRON OIL TUBE

A A
Plug Receptacle

10 4 12.7 25.2 354 88 T8399 1.53 BDIV-10-A004-AA-DB-MC04S -
PLUG
10 7 12.7 25.2 354 88 T8399 1.53 BDIV-10-A004-AA-DB-HD07S -

20 12 12.7 25.2 393 93 T15470 2.36 BDIV-20-A004-AA-DB-HD12S EDIV-20-A004-AA-DC-HD12S
RECEPTACLE
10 4 12.7 25.2 354 88 T8399 1.52 BDIV-10-B004-AA-DB-MC04P -

10 7 12.7 25.2 354 88 T8399 1.52 BDIV-10-B004-AA-DB-HD07P -
20 12 12.7 25.2 393 93 T15470 2.00 BDIV-20-B004-AA-DB-HD12P EDIV-20-B004-AA-DC-HD12P
DigiTRON + Diver series [10 / 20] flange mounted plug/receptacle with [4 / 7 / 12] pins/sockets and AquaTRON oil tube fitting.
DigiTRON e Diver series 20 flange mounted plug/receptacle with 12 pins/sockets and AquaTRON oil tube fitting.
A A
Plug Receptacle
Series Number Hose Hose Flange Nominal Interface DigiTRON + DigiTRON e

of internal external A Ø Weight Drg No. Type Type
10 4 12.7 25.2 204 88 2.71 T8399 BDIV-10-A009-AA-DB-MC04S -
RECEPTACLE PLUG
10 7 12.7 25.2 204 88 2.71 T8399 BDIV-10-A009-AA-DB-HD07S -

20 12 12.7 25.2 217 93 4.38 T15470 BDIV-20-A009-AA-DB-HD12S EDIV-20-A009-AA-DC-HD12S
10 4 12.7 25.2 174 88 2.70 T8399 BDIV-10-B009-AA-DB-MC04P -
10 7 12.7 25.2 174 88 2.70 T8399 BDIV-10-B009-AA-DB-HD07P -
20 12 12.7 25.2 185 93 4.12 T15470 BDIV-20-B009-AA-DB-HD12P EDIV-20-B009-AA-DC-HD12P
DigiTRON + Diver series [10 / 20] 90° flange mounted plug/receptacle with [4 / 7 / 12] pins/sockets and AquaTRON oil tube fitting.
DigiTRON e Diver series 20 - 90° flange mounted plug/receptacle with 12 pins/sockets and AquaTRON oil tube fitting.
41
Diver Connectors
DIVER BULKHEAD MOUNTED CONNECTORS

A A
Plug Receptacle

10 4 108 88 T8346 0.93 BDIV-10-H001-AA-MC04S -
PLUG
10 7 108 88 T8346 0.93 BDIV-10-H001-AA-HD07S -

20 12 116 93 T11685 1.23 BDIV-20-H001-AA-HD12S EDIV-20-H001-AA-HD12S
- - - - - - - -
RECEPTACLE
10 4 108 88 T8346 1.13 BDIV-10-G001-AA-MC04P -

10 7 108 88 T8346 1.13 BDIV-10-G001-AA-HD07P -
20 12 116 93 T11685 1.32 BDIV-20-G001-AA-HD12P EDIV-20-G001-AA-HD12P
- - - - - - - -
DigiTRON + Diver series [10 / 20] bulkhead mounted plug/receptacle with [4 / 7 / 12] pins/sockets.
DigiTRON e Diver series 20 bulkhead mounted plug/receptacle with 12 pins/sockets.
Depth Rating 4 / 7 / 12 way 4000m compensated.
DIVER BULKHEAD MOUNTED CONNECTORS (4000m Full Differential)

A A
Plug Receptacle

20 12 122 93 T11685 1.46 BDIV-20-H006-BQ-HD12S EDIV-20-H006-BQ-HD12S
PLUG
- - - - - - - -
- - - - - - - -
- - - - - - - -
RECEPTACLE
10 7 83 88 T17162 1.50 BDIV-10-G003-AA-HD07P -

20 12 83 88 T17162 1.62 BDIV-20-G003-AA-HD12P EDIV-20-G003-AA-HD12P
20 12 83 88 T17162 1.54 BDIV-20-G003-BQ-HD12P EDIV-20-G003-BQ-HD12P
- - - - - - - -
DigiTRON + Diver series [10 / 20] bulkhead mounted plug/receptacle with [7 / 12] pins/sockets.
DigiTRON e Diver series 20 bulkhead mounted plug/receptacle with 12 pins/sockets.
12 way Diver Bulkhead Plug available in Super Duplex Stainless Steel (UNS S32550) only.
42
Diver Connectors
DIVER FLYING DUMMY CONNECTORS

A A
Plug Receptacle

10 4 168 1.26 BDIV-10-L001-AA-MC04S -
PLUG
10 7 168 1.26 BDIV-10-L001-AA-HD07S -

20 12 206 1.86 BDIV-20-L001-AA-HD12S Use DigiTRON+ Type Number
- - - - - -
RECEPTACLE
10 4 168 1.46 BDIV-10-M001-AA-MC04P -

10 7 168 1.46 BDIV-10-M001-AA-HD07P -
20 12 206 1.95 BDIV-20-M001-AA-HD12P Use DigiTRON+ Type Number
- - - - - -
DigiTRON + Diver series [10 / 20] dummy plug/receptacle with [4 / 7 / 12] pins/sockets.
DigiTRON e Diver series 20 dummy plug/receptacle with 12 pins/sockets.
DIVER FIXED DUMMY CONNECTORS

A A
Plug Receptacle

10 4 168 88 T13234 1.54 BDIV-10-L002-AA-MC04S -
PLUG
10 7 168 88 T13234 1.54 BDIV-10-L002-AA-HD07S -

20 12 205 93 T13234 2.15 BDIV-20-L002-AA-HD12S Use DigiTRON+ Type Number
- - - - - - - -
RECEPTACLE
10 4 168 88 T8399 1.79 BDIV-10-M002-AA-MC04P -

10 7 168 88 T8399 1.79 BDIV-10-M002-AA-HD07P -
20 12 206 93 T15470 2.27 BDIV-20-M002-AA-HD12P Use DigiTRON+ Type Number
- - - - - - - -
DigiTRON + Diver series [10 / 20] flange mounted dummy plug/receptacle with [4 / 7 / 12] pins/sockets.
DigiTRON e Diver series 20 flange mounted dummy plug plug/receptacle with 12 pins/sockets.
43
Diver Connectors
PROTECTIVE CAPS FOR DIVER CONNECTORS
A A
Cap for Plug Cap for Receptacle

Cap for Cap for
10 not applicable 86 0.74 BDIV-10-P001-AC -

RECEPTACLE PLUG
20 not applicable 92 1.08 BDIV-20-P001-AC Use DigiTRON+ Type Number

- - - - - -
10 not applicable 43 0.50 BDIV-10-R001-AC -
20 not applicable 43 0.70 BDIV-20-R001-AC Use DigiTRON+ Type Number
- - - - - -
Protective cap for DigiTRON + & e Diver series [10 / 20] plug.
Protective cap for DigiTRON + & e Diver series 20 receptacle.
DIVER TEST CONNECTORS

A A
Please Note: DigiTRON + connectors shown Plug Receptacle

10 4 118 0.79 BDIV-10-T001-CD-MC04S -
RECEPTACLE PLUG
10 7 118 0.79 BDIV-10-T001-CD-HD07S -

20 12 118 0.48 BDIV-20-T001-CD-HD12S EDIV-20-T001-AA-HD12S
10 4 108 0.18 BDIV-10-T002-AC-MC04P -
10 7 108 0.18 BDIV-10-T002-AC-HD07P -
20 12 108 0.48 BDIV-20-T002-AC-HD12P EDIV-20-T002-AA-HD12P
DigiTRON + Diver series [10 / 20] Test plug/receptacle with [4 / 7 / 12] pins/sockets and size [10 / 20] cable gland.
DigiTRON e Diver series 20 Test plug/receptacle with 12 pins/sockets and size 20 cable gland.
DIVER PARKING RECEPTACLE

A
Receptacle
Series Number A Flange Interface Nominal DigiTRON + DigiTRON e

of mm Ø Drg No. Weight Type Type
RECEPTACLE
10 not applicable 81 82 T13234 0.77 BDIV-10-M003-AA -

20 not applicable 81 93 T11161 1.07 BDIV-20-M003-AA Use DigiTRON+ Type Number
- - - - - - - -
DigiTRON + & e Diver series [10 / 20] flange mounted receptacle.
44
Subsea Cable
Siemens Subsea are pleased to offer complete harnesses made up from connectors and subsea cable.
Our standard screened cables are always available from stock and specifically designed for extended life subsea.
Other cable specifications are available on request.
4 way cable
Part Number 75-004-TR Sheath Drain Wire
Outside diameter 18.2 mm Screen

Filler
Sheath material Polyurethane
Minimum static bend radius 182 mm
Minimum dynamic bend radius 273 mm
Weight in air 371 kg/km
Weight in water 105 kg/km Conductor
Voltage rating 600/1000V ac
Resistance 13.3 ohms/km Bedding

Braid Sheath
Conductor size 1.5 mm 2
Depth rating 3000 metres
7 way cable
Part Number 75-007-TR Sheath Braid
Outside diameter 18.2 mm

Screen
Minimum static bend radius 200 mm Filler
Weight in water 132 kg/km

Conductor
Resistance 13.3 ohms/km Bedding

Drain Wire Sheath
Conductor size 1.5 mm 2
12 way cable
Sheath Braid
Part Number 75-012-TR
Outside diameter 22.3 mm Screen

Minimum static bend radius 300 mm Filler
Weight in water 164 kg/km Conductor

Resistance 13.3 ohms/km

Bedding
Conductor size 1.5 mm 2 Drain Wire Sheath
45
DigiTRON Junction Boxes

3000 metres depth rating
Junction Boxes for cable
Although not as simple as oil tube junction boxes, cable junction boxes
are available in a wide range of configurations.
Cable junction boxes are usually gel filled and pressure compensated. For
permanent fixtures, cables enter through penetrators fitted with pressure
compensated cable glands.
Disconnectable Junction Boxes
Disconnectable junction boxes can be provided through standard

DigiTRON bulkhead connectors fitted to a gel filled pressure compensated
acetal chamber. Connection is made via in-line DigiTRON connectors
terminated to cable or AquaTRON oil tube.
Please contact our Customer Support Department for specific

Junction Box requirements.
Connector Manifold
ROV Retrievable Electrical Distribution Units
Siemens Subsea can now offer various ROV Retrievable Electrical

Distribution Units (REDU’s). These can be base plate mounted on client
structure and are available in a range of connector configurations. The
units have cathodic protection through the mating connectors on the
Electrical Distribution Unit and base plate.
Disconnectable Junction Boxes (horizontally mounted only)
A typical example of an ROV Retrievable Electrical Distribution

Unit (REDU) - (horizontally mounted only)
46
DigiTRON + and DigiTRON e ROV REDU

(Retrievable Electrical Distribution Unit)
This is the evolution from our current standard REDU (see previous
page). This does not replace the existing REDU but offers 4000 metres
operation with a higher specification of up to 11 connections. The units
have full cathodic protection through the input connector on the base
plate which can be configured as the CP connection only
• Improved compensated design - rated to 4000 metres

• Common input connector
• Common guide posts
• Standard base plate for all variants
• Optional input connection on base plate
REDU Type Numbering System:

Please contact our Customer Support Department for specific REDU
requirements.
REDU-0001-AA-01-08
1 2 3 4 5
PRODUCT FAMILY
1
REDU: Retrievable Electrical Distribution Unit
Connector 2 TYPE OF REDU

Part Number ABCDE F 0001 - 9999 represents the different configurations
REDU-❖❖❖❖-AA-❖❖-02 ● ● Tronic Technical Department to advise on placement of order
REDU-❖❖❖❖-AA-❖❖-03 ● ● ● MATERIAL
3
REDU-❖❖❖❖-AA-❖❖-04 ● ● ● ● Indicates the type of material:
AA: Stainless Steel (UNS S31603) - standard
REDU-❖❖❖❖-AA-❖❖-05 ● ● ● ● ●
REDU-❖❖❖❖-AA-❖❖-06 ● ● ● ● ● ● BASE PLATE CONNECTOR REQUIRED

4
Connector configuration for REDU 6 way. 00: No Connector
Ghosted connectors C,D,E & F are the 01: 4 way Standard Dummy / CP
additional connector options available.
NUMBER OF CONNECTOR OUTPUTS
5
08: 8-off connector outputs
REDU Base Type Numbering System:

Connector
Base Plate Connector Type Part Number AB CD E F GH I J K
REDU-BASE-AA-00* No Connector REDU-❖❖❖❖-AA-❖❖-07 ● ● ● ● ● ● ●
REDU-BASE-AA-01 4 way Standard Dummy / CP REDU-❖❖❖❖-AA-❖❖-08 ● ● ● ● ● ● ● ●
* Please Note: Input connector is as standard 12 way, REDU-❖❖❖❖-AA-❖❖-09 ● ● ● ● ● ● ● ● ●
part of EFL assembly.
REDU-❖❖❖❖-AA-❖❖-10 ● ● ● ● ● ● ● ● ● ●
REDU-❖❖❖❖-AA-❖❖-11 ● ● ● ● ● ● ● ● ● ● ●
Connector configuration for REDU 11 way.
Ghosted connectors G, H, J & K are the
additional connector options available.
47
AquaTRON Oil Tube

Oil tube jumpers and harnesses are an alternative to cable. They are
formed by pulling conductors through the AquaTRON hose, cutting to
length, terminating the conductors to the solder cups, fixing the oil
tube to the connector backshells, leak testing and filling with oil.
AquaTRON is more flexible than cable and is often more convenient for
short jumpers and / or complex harnesses consisting of several oil tube
segments, connectors, sensors, actuators and marshalling or junction
boxes.
Complex harnesses and jumpers can be procured on a single purchase

order, factory assembled in ideal conditions and delivered with full
warranty. AquaTRON hose is available in two sizes; 12.7 mm (0.5”) and
19 mm (0.75”) diameter bore.
AquaTRON Technical Specification

Part Number AquaTRON 50 AquaTRON 75
Design life 25 years 25 years
Outside diameter (nominal) 25.2 mm 32 mm
Inside diameter (nominal) 12.7 mm 19 mm
Sheath material PVC / Nitrile PVC / Nitrile

Strain member material Aramid Aramid
Minimum bend radius 125 mm 180 mm
Depth pressure 0 - 400 bar 0 - 400 bar

-5°C to 60°C -5°C to 60°C
Operating temperature
(23°F to 140°F) (23°F to 140°F)
-40°C to 70°C -40°C to 70°C
Storage temperature
(-40°F to 158°F) (-40°F to 158°F)
Standard conductor voltage rating 1000V 1000V
Standard conductor size 16 awg 16 awg
Standard conductor type Raychem Spec 44 Raychem Spec 44
Ethernet cable - CAT 5E

-20°C to 50°C -20°C to 50°C
Onshore testing
(-4°F to 122°F) (-4°F to 122°F)
PVC / Nitrile cover
Polyester yarn braid
Aramid fibre longitudinal

strain member
Styrene Butadiene (SBR)

inner tube
AquaTRON 50 & 75 oil

tube size comparison
48

AquaTRON Junction Boxes
Junction Boxes for AquaTRON Oil Tube
A major advantage of AquaTRON oil tube is the ease with which complex
harnesses can be factory assembled. Harnesses can include connectors,
actuators, sensors and junction boxes. The junction box usually serves one
of two purposes:
1 Distribution
One input signal is distributed to several outputs.
An insert facilitates insulation around the conductor junctions.
2 Marshalling
One input connector has it’s conductors marshalled to several
output connectors. In this configuration, no inserts are required.
Part Number Description

JB-01DB-02DB-BQ 3 ports (1 to 2), to suit 12.7 mm (0.5”) hose
JB-01DC-02DB-BQ 1 x 19 mm (0,75”) hose to 2 x 12.7 mm (0.5”) hose
JB-01DC-02DC-BQ 1 x 19 mm (0,75”) hose to 2 x 19 mm (0.75”) hose
JB-02DC-02DC-BQ 2 x 19 mm (0,75”) hose to 2 x 19 mm (0.75”) hose

Please Note: Other options available.
AquaTRON Junction Box Harness Assembly with

sensor and receptacle connector.
AquaTRON Junction Box Harness Assembly

(1 x AquaTRON 50 to 4 x AquaTRON 50)
49

AquaTRON ‘Isolated Chamber’
Junction Boxes
ICJB (Isolated Chamber Junction Box)
This is the evolution from our current standard AquaTRON Junction Box.
This new product does not replace the existing design but offers an
alternative solution giving customers a higher specification design
which is pressure compensated, isolated and will work to a depth of
4000 metres. Currently available in Stainless Steel (UNS S31603) as
standard (cathodic protection required).
• Compensated design - Rated to 4000 metres

• Each leg has a penetrator separating the hoses from the internals of
the box
• JIC 3/4” and 1 1/16” interface fittings now available
• Standard DigiTRON connector block parts used internally
• Can operate in any orientation
Hose Interface Fittings
We can now offer JIC and the standard Omnitec / AquaTRON hose fittings in
two sizes. Below is a typical table for the number of variations available from
1 in and 1 out, to 4 in and 4 out for JIC fitting for 0.5” NB AquaTRON hose.
This option allows a customer to specify any of the hose fittings in a
combination to suit their requirements.
Please contact our Customer Support Department for part numbers and
specific Junction Box requirements.
Part Number Description

ICJB-01AF-01AF-AA 2 ports (1 to 1), to suit 12.7 mm (0.5”) hose

DB DC AF AH
AquaTRON AquaTRON AquaTRON AquaTRON
(0.5" NB) Oil Tube (0.75" NB) Oil Tube (0.5" NB) Oil Tube (0.75" NB) Oil Tube
(Omnitec M25 fitting) (Omnitec M32 fitting) ( 4" -16 JIC fitting)
3
(1 16" - 12 JIC fitting)
1
50

Harness Assemblies
Integrated Scope of Supply
Siemens Subsea can supply high quality, high reliability packages with a single
warranty. These can range from single legged harnesses to multi-legged harness
assemblies utilising pressure and temperature transducers designed to suit our
clients requirements. The harnesses in an integrated scope of supply will consist of
DigiTRON + and DigiTRON e Connectors, AquaTRON Hose and sensors.
Our hose facility has been purpose built for assembling oil filled harnesses in
controlled conditions. The length of the internal clean working area is ideal for the
longest of harness assemblies. The working environment is fully climate controlled
(temperature and humidity) with a full clean air filtration system.
The pictures shown on this page show typical examples of harness assemblies
supplied as integrated packages / scopes.
Please contact our Customer Support Department for specific harness

requirements.
51

Interface Drawings
Interface Drawing No: T8346 Interface Drawing No: T8399
A
24.76
B
4-off HOLES
SECTION A-A M6 x 1.0-6H Ø 0.13 4-off HOLES
TYP 24.76
12.00
SECTION B-B M6 x 1.0-6H Ø 0.13
TYP
0.8
15°
24.76
TYP
24.76
TYP
Ø 44.20
Ø 44.53
Ø 44.58
Ø 45.72
Ø 45.97
Ø 58.00 ±1.0
0.8
A
B
15.00 MIN 10.00 MIN
0.8 20.00 MAX
SURFACE FINISH TO BE
MAINTAINED OVER Ø90

C 1-off Ø6mm 4-off HOLES D 1-off Ø6mm
DOWEL SECTION D-D DOWEL
4-off HOLES 24.76 M6 x 1.0-6H
SECTION C-C M6 x 1.0-6H Ø 0.13
15.87 Ø 0.13 Ø 0.13
15.87 Ø 0.13
TYP 15.00
12.00 (OPTIONAL)
0.8
0.8 15°
15°
35.56
34.93
24.76
TYP
Ø 47.00
Ø 49.20
Ø 49.25
Ø 51.25
Ø 51.50
Ø 44.20
Ø 44.53
Ø 44.58
Ø 45.72
Ø 45.97
27.84
TYP
24.76
TYP
0.8 0.8
D
C
15.00 MIN 15.00 MIN

0.8 24.76 27.84 0.8
SURFACE FINISH TO BE SURFACE FINISH TO BE
TYP TYP MAINTAINED OVER Ø95
MAINTAINED OVER Ø90

E F 4-off HOLES M6 x 1.0-6H
Ø 0.13
15.87
1-off Ø6mm DOWEL SECTION F-F
SECTION E-E Ø 0.13
35.56
Ø65.00 ±0.50
27.84
TYP
27.84
TYP
F
E
27.84 4-off HOLES M6 x 1.0-6H

15.00 MIN 15.00 MIN 27.84
TYP Ø 0.13
TYP
DRAWINGS FOR INFORMATION ONLY

All dimensions in millimetres
52

G 15.00 H 4-off HOLES
15.88 1-off Ø6mm M6 x 1.0-6H
SECTION G-G DOWEL
4-off HOLES Ø 0.13
Ø 0.13
M6 x 1.0-6H 0.8
Ø 0.13 15°
34.93
Ø55.00 ±0.50
Ø 47.00
Ø 51.25
Ø 51.50
Ø 49.20
Ø 49.25
27.84
TYP
24.76
TYP
0.8
H
G
24.76 15.00 MIN 0.8

TYP 27.84 SURFACE FINISH TO BE
15.00 MIN
SECTION H-H TYP MAINTAINED OVER Ø 95.0

SECTION I-I I 24.76 SECTION J-J J 4-off THRO' HOLES M6 x 1.0-6H
Ø 0.13
TYP 4-off HOLES
M6 x 1.0-6H
Ø 0.13
Ø 70.00 ±0.5
24.76
TYP
27.84
TYP
J
I
10.00 MIN 27.84

15.00 MIN
20.00 MAX TYP

SECTION K-K K 38.20 38.00 SECTION L-L 4-off THRO' L 31.60 31.40
TYP HOLES Ø 7.0 TYP
38.20
38.00
TYP
31.60
31.40
TYP
Ø 76.20
Ø 85.10
L
K
4-off THRO'
10.00 ± 0.50 10.00 ± 0.50
HOLES Ø 7.0
Interface Drawing No: T17162

0.8 M 31.90
9.40 Extent of Finish 6-off HOLES
2.50 TYP M6 x 1.0-6H x 15 Minimum
Full Thread Depth,
20 maximum depth
0.8 to drill point
Minimum Depth to achieve 0.8 Finish
12° Ø 0.12
36.83
TYP
18.42
Ø 105.00 SF
TYP
Ø 53.98
Ø 54.03
0.8
SECTION M-M M
53

TEE PIECE
Common Modular Diagram
EXTENSION
RIGHT
ANGLE
EXTENSION
BULKHEAD
DIVER FLANGE
PLUG BODY
Diver
FLANGE
DUMMY
(For Plug)
DIVER BACKSHELL
RECEPTACLE
BODY
AQUATRON
BACKSHELL
FULL DIFFERENTIAL DIVER SPACER FLANGE
BULKHEAD CONNECTORS
(For Receptacle)
OMMITTED FOR CLARITY
Protective
Caps
FIXED FLANGE
STAB PLATE
BULKHEAD
PLUG
FLOATING GLANDED
STAB PLATE FLANGE BACKSHELL
PLUG BODY
Stab Plate
SPLIT FLANGE
FIXED
STAB PLATE
RECEPTACLE
BODY
SPLIT FLANGE
FLOATING
STAB PLATE
Protective BULKHEAD
RECEPTACLE
Caps COMPLIANT 3/4”JIC BACKSHELL
FLANGE FOR
PLUG
ROV 1 1/16”JIC
BULKHEAD
PLUG BACKSHELL
FRONT
RING
ROV
PLUG BODY
COMPLIANT STOP END FITTING
FLANGE FOR AQUATRON HOSE
RECEPTACLE
ROV
ROV
RECEPTACLE
BODY DUMMY/
PARKING
SPACER FLANGE STOP END FITTING
GLANDED BACK SHELL
ROV
BULKHEAD
Protective RECEPTACLE
Caps
PROTECTIVE CAP
FULL DIFFERENTIAL ROV FOR PLUG
BULKHEAD CONNECTORS
OMMITTED FOR CLARITY
PROTECTIVE CAP
FOR RECEPTACLE
54

Examples
AQUATRON HOSE FITTING
ROV PLUG CONNECTOR

WITH DUAL AQUATRON
HOSE EXITS
G10 CABLE GLAND
G20 CABLE GLAND
DUMMY BACKSHELL DIVER MATE PLUG

CONNECTOR WITH
EXTENDED G20 CABLE GLAND
FLANGED
DUMMY BACKSHELL
JIC HOSE
FITTING
OMNITEC HOSE
FITTING 1-IN, 3-OUT AQUATRON HOSE SPLITTER
FISH TAIL
HANDLE
G10 TO G10 CABLE SPLICE
STAB PLATE RECEPTACLE

T-BAR CONNECTOR WITH 90°
HANDLE AQUATRON HOSE FITTING
PADDLE ROV RECEPTACLE

HANDLE
CONNECTOR WITH COMPLIANT
FLANGE & G10 CABLE GLAND
XYZ
HANDLE
55

Junction Boxes, Penetrators & Splices
RIGHT ANGLE EXTENSION
Size 10
Connector
Front End
AQUATRON HOSE FITTING

JUNCTION BOX FITTING
20 - 10 ADAPTOR AQUATRON HOSE
Size 20
Connector
Front End
G10 CABLE GLAND

HALF ENDED G10 CABLE GLAND
(No diaphragm)
JUNCTION BOX FITTING G20 CABLE GLAND

GLANDED BACK SHELL FOR SIZE 10 CONNECTORS
BULKHEAD FLANGE
JIC HOSE
FITTING
PENETRATOR
AQUATRON HOSE FITTING BLOCK
OMNITEC HOSE
FITTING
STOP END JUNCTION BOX

G10 CABLE GLAND FITTING AQUATRON HOSE
G10 CABLE SPLICE G20 CABLE SPLICE
G20 CABLE GLAND FOR SIZE 10 CONNECTORS
STOP END JUNCTION BOX

FITTING GLANDED BACK SHELL
JIC HOSE FITTING
OMNITEC HOSE FITTING
56
Glossary of Terms
Term Description
AquaTRON.................................. The oil tube system used as an alternative to cable.
Bulkhead.................................... A boundary wall separating fluids on either side. There may be a pressure difference between the two sides.
Bulkhead mounted connector.... A connector that fits into, and seals against, a bulkhead. The mating end of the connector points to the external side, while the
internal side is fitted with tails to facilitate termination within the enclosure.
Note that a bulkhead connector is similar to a penetrator except that a connector is easily de-mated.
Cable to conductor boot............. An elastomeric component that seals over the cable sheath and the individual conductors. Usually located within a cable gland
where the individual conductors emerge from the cable.
Cathodic protection.................... An electrochemical method of controlling corrosion, achieved by making a metal cathodic by means of impressed current or
attachment to a sacrificial anode (usually magnesium, aluminium or zinc).
CE / Controlled Environment...... A patented fluid filled Siemens Subsea connector principle. The electrical sockets contained within the plug are protected within
oil chambers (the 'Controlled Environment'). During mating, the receptacle pins enter the controlled environment through seals,
before the electrical connection is made in the controlled environment.
Connector................................... Half a connector pair.
Dummy connector...................... Connector having a fully operating mating front end but a blank backshell at the termination end. Dummies have two main
uses:
1) Protecting contacts that might otherwise be exposed to seawater.
2) Creating a loop between a pair of conductors for test purposes e.g. when pulling through an umbilical.
Field assembled gland............... A cable gland that can be assembled on site / offshore (Field Installable Termination Assembly).
Flange mounted......................... A connector with a flange. Note: This is not the same as a bulkhead mounted connector.
Gel.............................................. A self repairing, hydrophobic gel used by Siemens Subsea to fill subsea glands. The gel allows pressure balancing and is
electrically inert.
Gland.......................................... The part of the connector / penetrator where a cable is terminated.
In-line connector........................ Connectors that terminate to a cable or oil tube segment.
Insert.......................................... The centre part of the connector / penetrator containing the electrical contacts.
Instrumentation......................... Typically the range catered for by the DigiTRON connector e.g: up to 1000V and 40A.
Junction box............................... A component used in subsea systems where several cables / conductors are joined together. A junction box contains an insert
which performs a multiple conductor joint whilst maintaining conductor sheath integrity.
Marshalling box......................... A component used in oil tube systems to collect the inputs from several 4 way connectors to a 7 or 12 way connector. Unlike a
junction box, signals are not duplicated.
Oil tube....................................... An alternative to cable for subsea jumpers. The conductors are contained within a pressure-balanced oil-filled hose rather than
within a cable.
Parking receptacle..................... Parking receptacles are very simple devices that allow a loose CE plug connector to be 'parked' or fixed. CE plug connectors do
not need dummy connectors as the sockets are protected from seawater by the oil chambers.
PEEK™ (Victrex Limited)............. PolyEtherEtherKetone. An engineering thermoplastic with excellent insulation properties.
Penetrator.................................. A permanent connection through a bulkhead.
Plug............................................ The connector half which fits inside the receptacle. In CE terminology, the plug contains electrical sockets within oil-filled
chambers.
Receptacle.................................. The connector half into which the plug is inserted. In CE terminology, the receptacle contains the electrical pins.
Redundancy............................... Achieved by supplying a back up to key system components so that failure of one component will not result in electrical failure.
ROV............................................. Subsea Remotely Operated Vehicle. Used to carry out tasks that are beyond economic diver depth, range or capability.
Shuttle pin.................................. The pin that seals the oil chambers within CE plug connectors when unmated.
The shuttle pin is displaced by the receptacle pin during mating.
Stab plates.................................. Two plates which contain hydraulic and/or electrical connectors. Enables remote mating of the connectors when the distance
between the plates is reduced.
Termination sleeve..................... A sleeve that fits over terminations, providing a continuous insulation path.
Test connectors.......................... Low cost connectors, specifically manufactured for system testing. They are not waterproof and are usually fitted with long tails for
connecting to test equipment. If a system terminates in a true subsea receptacle, a test plug is used to prevent damage to the pins.
UNS S31603................................ The standard grade of stainless steel used for most subsea connectors when a corrosion protection system is in operation.
UNS S32550................................ A superior specification of stainless steel (super duplex) used to achieve long life where protection systems are not
available/reliable.
57
Life Cycle Management
Installation, Commissioning, Refurbishment, Field Service and After Care
for the entire design life of all our products and systems
Siemens Subsea Services - Life Cycle Management
58

Subsea Services - Life Cycle Management
Siemens Subsea Services - Life Cycle Management group provides a range of post-sales support.
We have an extensive field service team of qualified and fully trained UK installation engineers
along with teams based in Brazil, USA, Norway and Malaysia, whose expertise is utilised around
the world, supporting our customers at both onshore and offshore locations.
Our Life Cycle Management Services l Paperless documentation system available to complement hard
l Connector installation and test copy project records
l Offshore deployment support
l Spares and inventory management Service Team Profile
l Investigation support Today, our installation engineers boast a combined experience of
l Condition reports / inspections over 200 man-years and we continue to grow in order to meet market
l Umbilical test demand. Only our Engineers are certified for the installation and test
l Test connector hire of the Siemens Subsea connector range, ensuring the highest possible
electrical performance throughout the connector life time.
Global Capabilities
Our UK based service team has extensive experience of installing the
full range of connectors at onshore and offshore locations around
the world. Additionally, we provide growing and dedicated in-country
support utilising locally based personnel. This not only provides
focused in-country resource but also offers indigenous workforces
where ‘local content’ is required. In country support is available in the
UK, Europe, USA, Brazil, West Africa and Malaysia.
Capabilities
l Termination, installation and test of the complete connector range
l 24 hour access to inventory for spares and emergency scenarios
l Priority Service Response mobilisation within 24 - 48 hours
l Fully equipped vehicles and installation containers for large
‘on site’ project requirements

l 24 hour 7 days a week telephone emergency response service
l Installations assured by warranty
59

Siemens Subsea Locations and Address details - TRONDHEIM - Brazil
SUBSEA SYSTEMS - RIO DE JANEIRO -
Siemens Subsea General email address: Siemens AS Siemens Ltda.
subsea.energy@siemens.com Bratsbergveien 5 Rua Geraldo Martins,
N-7037 Trondheim 54 - Sobreloja,
United Kingdom Postadresse: Santa Rosa, Niterói, RJ,
- ULVERSTON - N-7493 Trondheim CEP 24220-380
SUBSEA CONNECTORS Phone: +47 73 95 90 00 Phone: +55 21 3445 8000
Siemens Plc Fax: +47 73 95 90 70
Subsea Excellence Centre Malaysia
Ulverston, Cumbria LA12 9EE - KONGSBERG - - JOHOR -
SUBSEA DISTRIBUTION 41 Jalan Mega 1/6,
Phone: +44 1229 580 500
Siemens AS Taman Perindustrian Nusa Cemerlang,
Fax: +44 1229 586 604
Kirkegårdsveien 45 81550 Gelang Patah, Johor
E-Mail: connectorsales.gb@siemens.com
N-3616 Kongsberg Phone: +60 7556 3330
Postadresse: Fax: +60 7556 3321
- ABERDEEN -
P.O. Box 375
Siemens Plc. Oil & Gas
N-3604 Kongsberg
Unit D2 Abbotswell Road West Tullos
Phone: +47 22 63 30 00 Siemens Subsea Services -
Aberdeen,
Fax: +47 32 28 61 11 LIFE CYCLE MANAGEMENT
AB12 3AD
are based on all sites worldwide,
Phone: +44 0 1224 238800
- BØMLO - plus other sites including Macaé,
Fax: +44 0 1224 238801
SUBSEA SENSORS Rio de Janeiro (Brazil) and Angola.
Siemens AS
Norway
Ternetangen 65
- OSLO -
N-5420 Rubbestadneset
Siemens AS
Phone: +47 22 63 30 00
Østre Aker vei 88
Fax: +47 53 42 86 01
N-0596 Oslo
Postadresse:
United States of America
Postboks 1 Alnabru
- HOUSTON -
N-0613 Oslo
Siemens Inc
Phone: +47 22 63 30 00
10730 Telge Road,
Fax: +47 22 63 38 05
Houston, TX 77095
Phone: +1 281 856 4400
- STAVANGER -
Siemens AS
Gamle Forus vei 1
N-4033 Stavanger
Postadresse:
Postboks 8036 Forus,
4068 Stavanger
Phone: +47 51 82 70 70
Fax: +47 51 82 70 30
SpecTRON Brochure (March 2015) Cover.indd 6 07/05/2015 11:39

DigiTRON e

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

DigiTRON e

Uploaded by

Copyright:

Available Formats

DigiTRON

DigiTRON + and DigiTRON e Controls & Instrumentation Connectors

Siemens Subsea Connectors (Tronic Products)

DigiTRON Brochure (March 2015).indd 1 31/03/2015 16:07

DigiTRON Brochure (March 2015).indd 2 31/03/2015 16:07

The DigiTRON Evolution

11 Way ROV REDU (Retrievable

Technical Specification ..................................................7

Termination Methods ....................................................8

DigiTRON Range Product Selection ..............................10

Type Numbering System..............................................12

Stab Plate Connectors ...............................................25

Diver Connectors .......................................................35

Junction Boxes ............................................................46

ROV Retrievable EDU ...................................................47

AquaTRON Oil Tube .....................................................48

AquaTRON Junction Boxes...........................................49

AquaTRON Isolated Chamber Junction Boxes ...............50

Harness Assemblies .....................................................51

Interface Drawings ......................................................52

Common Modular Diagram .........................................54

Junction Boxes, Penetrators & Splices ..........................56

Siemens Subsea Services - Life Cycle Management ......58

The DigiTRON Evolution

The DigiTRON range of subsea

DigiTRON benefits include faster lead times

Technically, DigiTRON retains the high-density

DigiTRON connectors for ROV operation are

High integrity is ensured by pressure

DigiTRON connectors are rated at 1000V ac

DigiTRON Range Highlights

DigiTRON Continuous Improvements

The DigiTRON Evolution

• The CE plug features an oil-filled primary diaphragm to prevent water ingress.

When reliability counts, count on our experience.

• Backward compatible with the existing DigiTRON range

DigiTRON e Ethernet Connector

• Fully qualified to operate at 4000 metres (13,123 feet) depth pressure

DigiTRON + and DigiTRON e

Maximum working current 35-40 Amps 22-32 Amps 20-28 Amps

Working current in air 18 Amps 14 Amps 11 Amps

Typical contact resistance <4 milliohms <4 milliohms <4 milliohms

Ethernet Specification DigiTRON e 4 way connector 7 way connector 12 way connector

Typical pin to pin resistance (harness) - - >10 Gigaohms

IEEE Cable analyser - - CAT 5E

Mechanical Specification 4 way connector 7 way connector 12 way connector

4000 metres 4000 metres 4000 metres

4 mm2 4 mm2 4 mm2

Maximum conductor size (with crimps and 25 mm2 25 mm2 25 mm2

Storage temperature range -40°C to 70°C -40°C to 70°C -40°C to 70°C

Working temperature range -5°C to 60°C -5°C to 60°C -5°C to 60°C

Oil Tube Specification 4 way connector 7 way connector 12 way connector

Ethernet cable - - CAT 5E

Oil type Dow Corning 200/ 1000 (silicone oil)

ROV Mating 4 way connector 7 way connector 12 way connector

<30 kgf <30 kgf <50 kgf

24 - 36 kgf 24 - 36 kgf 48 - 80 kgf

±20 mm ±20 mm ±20 mm

Maximum angular misalignment ±20° ±20° ±20°

Maximum rotational misalignment ±15° ±15° ±15°

• After termination and helium pressure testing, the gland

• Tolerance of jumpers is:

Gland Size / Cable Sheath Capacity
