Fuel Oxygen
FIRE
Heat
Figure 1.1 Fire Triangle
(Redsicker and O’connor, 1997)
Traditionally, fire has been described as having three components: heat, oxygen, and fuel.
This triad was illustrated by the fire triangle, which symbolized, in the most basic terms, a
chemical relationship that would have required hours to explain. We now realized, however,
that the fire triangle falls short of integrating all the components involved in producing flaming
combustion. Today, the fire triangle is used to technically explain glowing combustion, which
occurs when a fuel mass glows (burns) without flaming. This is called solid-to-gas reaction (fuel
being solid, and the oxidizing agent a gas.
The additional component that is needed to explain flaming combustion is a chemical
chain reaction. Such a reaction yields energy or products that cause further reactions of the
same kind, and this process is self-sustaining.
Fuel Oxygen
FIRE
Chemical Chain
Reaction
Heat Figure 1.2. Fire Tetrahedron
(Redsicker and O’connor, 1997)
In flaming combustion, fuel and the oxidizing agent are both in the gaseous state; hence
this is referred to as gas-to gas-reaction.
Two kinds of Combustion
1. Glowing combustion – represented by the Fire Triangle
2. Flaming Combustion – represented by the Fire Tetrahedron
IV. FUEL AND ITS PHYSICAL STATES
Fuel. Any materials or substances capable of burning can be considered as Fuel. Fuels are
characterized as: (P.S.B.R.C.)
a. Solid Fuels. The principal component is carbon.
b. Liquid Fuels. The principal component is hydrocarbon.
c.Gaseous Fuels. The principal component is hydrocarbon.
A. Solid Fuels. The most obvious solids fuels are woods, fibers and plastics (Abis, 1986).
(1) Wood and wood-based products.
Pyrolysis of Wood
Before solid fuel will burn, it must be changed to the vapor state. In a fire situation,
this change usually results from the initial application of heat.
Pyrolysis is generally defined as “chemical decomposition of matter by the action of
heat”. (Aguado, 2000). It involves the following process:
1. Heat is absorbed by the fuel
2. Molecules are driven off
3. Molecules are broken into pieces
4. They give off combustible vapors.
FACTORS AFFECTING IGNITION AND BURNING OF WOOD
2. Boiling point. The constant temperature at which the vapor pressure of the liquid is
equal or above to the atmospheric pressure .
3. Ignition temperature. The temperature at which a flammable material will ignite,
whether it be gas, liquid, or solid; for example :
4. Flash point. The temperature at which the vapors given off (gas) is not sufficient in
quantity to burn. For example, the fire point of gasoline, this is –50 *F, for kerosene,
110 *F.
5. Fire Point. The temperature at which the material will give off vapors in sufficient
quantity to sustain combustion (burning).
VI. CHEMICAL PROPERTIES OF FIRE
Abis (1986) enumerates the following chemical properties of fire.
1. Endothermic Reactions. These are changes whereby energy (heat) is absorbed or
is added before the reaction takes place.
2. Exothermic Reactions. Are those that release or give off energy (heat) thus they
produced substances with less energy than the reactants .
3. Oxidation. It is a chemical change that is exothermic. It is actually the deterioration
or aging of materials.
4. Flames. It refers to incandescent gases. In order to be sustained, it should maintain a
high temperature and a concentration of short-lived intermediate chemical reactions
between fuel and oxidizer. There are different types of flames, categorized as :
a. Based on color and completeness of combustibility of fuel:
(1) Luminous flame is orange-red, will deposit soot at the bottom of a vessel
being heated due to incomplete combustion of fuel and has a lower
temperature.
(2) Non-luminous flame is blue, will not deposit soot due to almost complete
combustion of the fuel and has relatively high temperature.
b. Based on fuel and air mixture:
(1) Premixed flame is exemplified by the Bunsen-type laboratory burner
where the hydrocarbon is thoroughly mixed with air before reaching the
flame zone.
(2) Diffusion flame is observed when gas (fuel) alone is forced through the
nozzle into the atmosphere, which diffuses, in the surrounding atmosphere in
order to form a flammable mixture. The rate at which the fuel and oxidizer
are brought together determines the characteristics of a diffusion flame.
c. Based on smoothness:
(1) Laminar flames are flames that follow a smooth path through a gaseous
flame.
(2) Turbulent flames are those having unsteady, irregular swirls and eddy. As
physical size, gas density or velocity is increased, all laminar gas flows tend
to become turbulent.
VII. WHAT IS HEAT?
This source of heat is generated as the result of some type of chemical reactions.
The four types of chemical reactions that result in heat production are heat of
combustion, spontaneous heating, heat of decomposition and heat of solution (Abis,
1986).
a. Heat of combustion. It is the amount of heat released during the complete
oxidation where the organic fuel is converted to water and carbon dioxide.
b. Spontaneous heating. It is the process of increase in temperature of a
material as a result of slow oxidation, that is, without drawing heat from its
surrounding, until the ignition temperature results into combustion .
c. Heat of decomposition. It is the heat produced by the decomposition of
compounds requiring the addition of heat for their formation.
d. Heat of solution. It is the heat released by the solution of matter in a liquid.
Some acids, when dissolved in water, can produce violent reactions, spewing
(emitting) hot water and acid with explosive force.
2. Mechanical heat energy. Mechanical heat is the product of friction. Our ancestors
rubbed sticks together to generate heat to start a fire. Internal metal components of
machinery can overheat, due to lubricant breakdown or ball-bearing failures, and
cause ignition of available combustibles.
The following the examples of mechanical heat energy: (Abis, 1986)
a. Frictional heat. It results when mechanical energy is used in overcoming the
resistance to motion when two solids are rubbed together.
b. Overheating of machinery. It may cause fire from the heat accumulated from
the rolling, sliding or friction in machinery or between two hard surfaces, at least
one of which is usually a metal. Ignition sources in this category are heated
bearings or rotating machinery and belts, which becomes over heated due to the
pulley slippage.
c. Heat of compression. The heat that is released when gas is compressed.
3. Electrical heat energy. Electrical heat is the product of arcing, shorting or other
electrical malfunction. Poor wire connections, too much resistance, a loose ground,
and too much current flowing through an improperly sized wire are other sources of
electrical heat.
The following the examples of electrical heat energy:
a. Resistant heating. Refers to the heat generated by passing an electrical current
through a conductor such as wire or an appliance. Resistant heating is increased if
the wire is not large enough in diameter for the amount of current. Fires are
caused when a simple extension cord is overloaded with too many appliances
plugged into it.
b. Leakage current heating. It occurs when a wire is not property insulated well
enough to contain all the current. Some current leaks out into the surrounding
material such as inside the wall of a structure. This current causes heat and can
cause a fire.
c. Heat from arcing. A type of electrical heating that occurs when the current flows is
interrupted. Interruption may be from an open switch or a loose connection. Arc
temperatures are extremely high and may even melt the conductor.
d. Inductive heating. Whenever atoms are subjected to electric potential gradients
from external sources, the arrangement of the atoms (or molecules of several
atoms) is distorted with a tendency for electrons to move in the direction of
opposite direction.
4. Nuclear heat energy. Nuclear energy is the product of the splitting or fusing of
atomic particles (fission or fusion, respectively). The tremendous heat energy in a
nuclear power plant produces steam to turn steam turbines. When more heat is
produced than is lost (transferred), there is a positive heat balance. When more
heat is lost than is produced, there is a negative heat balance.
a. Nuclear fission. It occurs when a subatomic particle called neutron bombards
an appropriate type of nucleus. The nucleus then splits into two lighter nuclei
and at the same time releases tremendous amount of energy in the form of
kinetic energy of the fission fragments (Abis, 1986).
b. Nuclear Fusion. It includes all nuclear reactions in which two lighter nuclei
combined to form heavier nucleus with the emission of other particles or
gamma rays.
5. Solar heat energy. The energy transmitted from the sun in the form of
electromagnetic radiation is called solar heat energy.
Heat Transfer
Law of Heat Flow – specifies that heat tends to flow from a hot substance to a cold
substance. The colder of two bodies in contact will absorb heat until both objects are at
the same temperature. Heat can travel throughout a building by one or more of the
three methods, conduction, convection and radiation.
1. Conduction. It is the transfer of heat from a region of higher temperature to a
region of lower temperature by increased kinetic energy. This increased kinetic energy
is passed from molecule to molecule. Conductors are materials that heat can pass
through. Not all materials are good conductors .
Poor conductors are called insulators, since heat flows through them slowly.
Joseph Fourier formulated the theory of heat conduction in the early 1800s,
(Quintiere, 1998).
2. Radiation. In the early 1900s, German physicist Max Planck formulated this form of
heat transfer.
He wrote that all substances emit radiant energy simply because they have a
positive absolute temperature.
Radiation is the process of heat transfer by means of infrared radiation, a form
of electromagnetic wave.
Electromagnetic waves do not need any material medium for their propagation.
Space is almost completely empty, so the sun’s heat cannot reach us by
conduction or convection. Because electromagnetic waves don’t need a medium
they are able to travel through space.
Anything above the temperature of absolute zero is absorbed by darker surfaces
and reflected by lighter surfaces. This is why people wearing darker clothing in
the summer are hotter than those people wearing white or light clothing. Those
wearing black will absorb the radiations; therefore their temperature will rise.
(Stay Cool, Wear White)
3. Convection. It is the transfer of heat through a circulating medium, usually air or
liquid (see Ideal Gas Law).
Heat transfer in convection is cheaply responsible for the spread of fire in the
structure.
The super-heated gases evolved from a fire are lighter than air and consequently
rise; they can and do initiate additional damage.
Warm Air
Heater
Heat Measurement
Heat of a given material is measured by its temperature. A material is made up of minute
particles called molecules that are in constant motion. The temperature of the material is the
condition that determines whether it will transfer heat to or from another materials (Abis,
1986).
Temperature Units
Celsius degree (also called Centigrade)
Fahrenheit
Kelvin or Absolute
What is the international symbol of Temperature?
VIII. CLASSIFICATION OF FIRE
The class of fire determines the type of fire extinguishers to be used. The action of the
fire extinguisher is either to cool the burning substance to below its ignition temperature, or to
exclude air supply or a combination of both. These are quenching, cooling and blanketing
effects. Fires are generally classified as: (Abaygar, 2000)
1. Class A fires. These are fires involving ordinary combustible materials such as, wood,
cloth, paper, rubber, and many plastics. Water is used in cooling or quenching effect
to reduce the temperature of the burning material below its ignition temperature.
2. Class B fires. It involves flammable and combustible liquids, greases and gases such
as gasoline, oil, lacquers, paints, mineral spirits, and alcohols.
3. Class C fires. These are fires involving energized electrical equipment. A non-
conducting extinguishing agent such as halon, dry chemical, or carbon dioxide can
sometimes control these fires.
4. Class D fires. It involves combustible metals such as aluminum, magnesium,
titanium, zirconium, sodium, lithium, calcium, zirconium, zinc and potassium. These
materials are particularly hazardous in their powdered formed and require careful fire
attack with special extinguishing agents.
5. Class E fires. These are fires involving liquefied petroleum gases.
6. Class F fires. These are fires involving the burning of spontaneously combustible
materials.
Phases of Fire and Its Behavior
As a fire progresses, it normally passes through three phases: incipient, free burning and
smoldering. No two fires are exactly the same. They vary in many ways from incident to
accident (P.S.B.R.C).
1. The Incipient Phase. It is the earliest phase of fire with the actual ignition.
The fire is limited to the original materials of ignition. In the
incipient phase, the oxygen content in the air has not been significantly reduced,
and the fire is producing water vapor (H2O), carbon dioxide (CO2), a small
quantity of sulfur dioxide (SO2), carbon monoxide (CO) and other gases.
The behavior of fire during the incipient phase is “rollover”,
sometimes referred to as “flameover”. It takes place when unburned combustible
gases released during the incipient phase accumulate at the ceiling level. These
superheated gases are pushed, under pressure, away from the fire area and into
uninvolved areas where they mix with oxygen.
2. Steady – state Burning Phase or Free Burning Phase. It is the phase of fire
where sufficient oxygen and fuel are available for fire growth and open burning to a
point where total involvement is possible.
During this phase of fire, the rate and intensity of open burning increases
geometrically.
Heat, rapidly evolving from the original point of the fire, is convected and collects
in the uppermost areas of the structure or room.
The additional heat is transferred through conduction and radiation.
The convected (super-heated) gases themselves become a source of radiated
heat, radiating heat energy downward onto all the surface areas directly below
them.
This heat is absorbed by conduction into the mass of those items whose surfaces
are struck, causing surface pyrolysis.
When the temperature reaches the ignition temperature of these items, a
flashover occurs: flames instantly “flashover” the entire area.
Flashover is defined as “a stage in the development of a continued fire in which
all exposed surfaces reach ignition temperature, more or less simultaneously,
and fire spreads rapidly.
3. Hot Smoldering Phase. After the steady-state burning phase, flames may cease to
exist if the area of confinement is airtight.
In this state, burning is reduced to glowing embers.
As the flames die down, the room becomes completely filled with dense smoke and
gases.
The resulting superheated mixture of gases needs only a fresh supply of oxygen to
resume free burning at an explosive rate.
This type of explosive is referred to as a backdraft or smoke explosion.
Backdraft is an explosion resulting from the sudden introduction of air (oxygen)
into a confined space containing oxygen-deficient superheated products of
incomplete combustion.
A backdraft may result if someone opens a ‘hot door”. This is why firefighters are
trained to touch a door with their bare hands and feel its temperature before
opening it.
This situation can be made less dangerous by proper ventilation. If the room or
building is opened at the highest point involved, the heated gases and smoke will
be released, reducing the possibility of an explosion.
The other behaviors of fire are flash fire and bite back. Bite back occurs when the fire
resists extinguishments operation and become stronger and bigger instead. It occurs when
firefighters used the wrong fire fighting tools in extinguishing fires.
Products of Combustion
When a fire occurs, certain by-products of fire dangerous to human being will appear
(P.S.B.R.C.).
1. Heat. It is a form of energy that is measured in degrees of temperature to signify its
intensity. The following are the dangers of heat:
Heat is the product of combustion that is responsible for the spread of fire.
It is also the direct cause of burns, dehydration, heat exhaustion and injury to
the respiratory tract and destruction of property.
