interrupt
By Rahul Awati

u
What is an interrupt?
c An interrupt is a signal emitted by a device attached to a computer or from a program within
o the computer. It requires the operating system (OS) to stop and figure out what to do next.
An interrupt temporarily stops or terminates a service or a current process. Most I/O devices
i
have a bus control line called Interrupt Service Routine (ISR) for this purpose.
n
An interrupt signal might be planned (i.e., specifically requested by a program) or it may be
unplanned (i.e., caused by an event that may not be related to a program that's currently
running on the system).

Today, almost all computing systems are interrupt-driven. What this means is that they
follow the list of computer instructions in a program and run the instructions until they get to
the end or until they sense an interrupt signal. If the latter event happens, the computer
either resumes running the current program or begins running another program. In either
case, it must stop operations while deciding on the next action. To do this and to work on
other programs, the OS uses pauses in operations.

When the device processor handles interrupts, it informs the device sending the signal that
the interrupt request (IRQ) has been recognized. Then the device stops sending the IRQ
signal.

An OS usually includes code called an interrupt handler to prioritize interrupts and save them
in a queue if more than one is waiting to be handled. It also has a scheduler program that
determines the next program that gets control.
When an interrupt occurs, the associated service may not start immediately. The time
interval between the time the interrupt occurs and the time when ISR execution starts is
called interrupt latency.

Three types of computer instruction formats

k Almost all computing today is interrupt-driven, which means they follow a list of
instructions in a program and run those until they get to the end or sense an interru
signal.

Types of interrupts
Interrupts are classified into two types:

I. Hardware interrupt
A hardware interrupt is an electronic signal from an external hardware device that indicates
it needs attention from the OS. One example of this is moving a mouse or pressing a
keyboard key. In these examples of interrupts, the processor must stop to read the mouse
position or keystroke at that instant.

In this type of interrupt, all devices are connected to the Interrupt Request Line (IRL).
Typically, a hardware IRQ has a value that associates it with a particular device. This makes
it possible for the processor to determine which device is requesting service by raising the
IRQ, and then provide service accordingly.

There are three types of hardware interrupts:

Maskable interrupts

In a processor, an internal interrupt mask register selectively enables and disables hardware
requests. When the mask bit is set, the interrupt is enabled. When it is clear, the interrupt is
disabled. Signals that are affected by the mask are maskable interrupts.

Non-maskable interrupts

In some cases, the interrupt mask cannot be disabled so it does not affect some interrupt
signals. These are non-maskable interrupts and are usually high-priority events that cannot
be ignored.

Spurious interrupts
Also known as a phantom interrupt or ghost interrupt, a spurious interrupt is a type of
hardware interrupt for which no source can be found. These interrupts are difficult to identify
if a system misbehaves. If the ISR does not account for the possibility of such interrupts, it
may result in a system deadlock.

II. Software interrupts

A software interrupt occurs when an application program terminates or requests certain
services from the OS. Usually, the processor requests a software interrupt when certain
conditions are met by executing a special instruction. This instruction invokes the interrupt
and functions like a subroutine call. Software interrupts are commonly used when the
system interacts with device drivers or when a program requests OS services.

In some cases, software interrupts may be triggered unexpectedly by program execution

errors rather than by design. These interrupts are known as exceptions or traps.

Interrupts vs. polling

Polling is a state of continuous monitoring where a microcontroller in a computing system
continuously checks the status of all devices. The first device encountered with the IRQ bit
is serviced first and the appropriate ISR is called to service that device. The system is easy
to implement and ensures that the component that needs service gets it.
However, because the microcontroller uses all its processing time for polling, it cannot carry
out simultaneous operation. Also, a lot of time is wasted by interrogating the IRQ bit of all
devices. Interrupts provide a solution to this problem. With interrupts, the controller does not
need to regularly monitor the status of devices. Instead, it responds only when an interrupt
occurs. So, when there is an interrupt, the controller is notified that it needs service.

What is an ISR?
An ISR is present for every interrupt. The address of each ISR is stored in a fixed location in
memory. An ISR can call for asynchronous interrupts and handle both maskable and non-
maskable interrupts.

When an interrupt occurs, the microcontroller runs the ISR. At the start of execution, the ISR
disables the interrupt services of all other devices, stopping the instruction that's currently
processing and saving its configuration in a register. Then it will load the interrupt's program
counter from a location given by the interrupt vector table. Once ISR execution is complete,
it will reinitialize all interrupt services.

The two main types of interrupt handlers:

First-level interrupt handler (FLIH). A hard or fast interrupt handler that handles
maskable interrupts and has jitter during process execution

Second-level interrupt handler (SLIH). A slow and soft interrupt handler with less jitter
than FLIH
 What is a Computer Program and How Does It Work?

Types of interrupt methods

There are two types of interrupt triggering methods or modules:

Level-triggered interrupts

This interrupt module generates an interrupt by holding the interrupt signal at a particular
active logic level. The signal gets negated once the processor commands it after the device
has been serviced. The processor samples the interrupt signal during each instruction cycle
and recognizes it when it's inserted during the sampling process. After servicing a device,
the processor may service other devices before exiting the ISR.

Level-triggered interrupts allow multiple devices to share a common signal using wired-OR
connections. However, it can be cumbersome for firmware to deal with them.

Edge-triggered interrupts

This module generates an interrupt only when it detects an asserting edge of the interrupt
source. Here, the device that wants to signal an interrupt creates a pulse which changes the
interrupt source level.

Edge-triggered interrupts provide a more flexible way to handle interrupts. They can be
serviced immediately, regardless of how the interrupt source behaves. Plus, they reduce the
complexity of firmware code and reduce the number of conditions required for the firmware.
The drawback is that if the pulse is too short to be detected, special hardware may be
required to detect and service the interruption.
See also: supervisor call, polled interrupt, embedded system
