SSC2802-TM

Quick Installation Guide

Issue: 01
Date: 2017-09-07

HUAWEI TECHNOLOGIES CO., LTD.

Precautions
General Safety Precautions
To ensure human and equipment safety, observe all the safety precautions marked on the equipment and provided in this
document. The WARNING, CAUTION, and NOTE marks in this document do not cover all the safety precautions that
must be followed; they only supplement general safety precautions as a whole. Huawei is not liable for any consequence
that results from customers' violation of universal operation requirements or equipment design, manufacturing, and usage
safety standards.
Local Laws and Regulations
When operating a device, obey local laws and regulations.

Personnel Requirements
Engineers that are responsible for installing and maintaining Huawei equipment must be trained, and have a thorough
understanding of the proper operation methods and safety precautions.

Symbol Conventions

Alerts you to a medium or low risk hazard that could, if not avoided, result in moderate or minor injury.

Alerts you to a potentially hazardous situation that could, if not avoided, result in equipment damage,
performance deterioration, or unanticipated results.

Provides additional information to emphasize or supplement important points in the main text.

Human Safety
Do not look into the optical port without eye protection.
When drilling holes, take proper protection measures to avoid inhaling dust and prevent dust from hurting your eyes.
When working at heights, take proper measures to prevent objects from falling down.

Appearance and Structure

a Appearance

SSC2802-TM-12

Copyright © 2017 Huawei Technologies Co. Ltd. All Rights Reserved.

2
Appearance and Structure

b Structure Diagrams

Shell SC/APC
hardened adapter

Velcro strap

Splicing tray

Blind plug for straight-through cable

Buckle

All the blind plugs are one-off.

Kit Content
NO. Item Quantity

1 Closure 1 pcs

2 FP-S01(FastPlug for straight- 1 pcs

through optical cable)
Pole-mounting plate 2 pcs
3
M6x12 screw 4 pcs
Plastic plug 4 pcs
4
Wall-mounting screw 4 pcs
5 Cable tie 5 pcs

6 Splicing protection tube 5 packets

7 Grease lubricant 1 packet

• The kits and quantity are different according to different

configurations.
• You need order other installation accessories separately
according to different installation scenario. In aerial-mounting
scenario, you need to order aerial mounting brackets. In
pole-mounting scenario, you need to order hose clamp.

Aerial mounting brackets Hose clamp

3
Tools

Marker 3-m measuring tape Scissors Phillips screwdriver Flat-head screwdriver

(M3–M6) (M3-M6)

Splicing tool kits Optical cable/fiber Diagonal pliers M6-Socket wrench Pliers
(fusion splicer, cutter, stripper
detergent)

Hammer drill Ø10-mm drill bit Protective gloves Hex key

Installation Process
Start

Installing the drop cable

Opening the Closure

Stripping, Leading in and Securing End

Optical Cables

Splicing and Terminating Optical

Fibers and Routing Pigtails

Checking after the Installation

Sealing the Closure

Installing the Closure

1. Put away materials that are not used during the installation for future use.
2. Put away components that are removed during the installation and protect them against contamination.
3. Clean the required parts or components before the installation.

4
1 Opening the Closure
1 Open the closure. a) Use the Phillips screwdriver to loosen the sealing screw. b) Pry the 4 buckles using the flat-head
screwdriver. c) Turn over the closure cover

2 Stripping, Leading in and Securing Optical Cables

a Stripping the Straight-through Optical Cable

The FP-S01 is suitable for Φ6-18 mm optical cable. Check whether the diameter of the
straight-through cable matches the FastPlug
Mark the position where the optical cable will be stripped.
Handle the strength members
Determine the length to be stripped for each section of the optical cable, and strip carefully as they are sharp and may
the optical cable. cause body injuries.
Strip the branching part by 1500 mm.

1500 Unit: mm

Straight-through part
35 35
Strength member Strength member

Loose tube
Branching part

5
2 Stripping, Leading in and Securing Optical Cables (Continued)

b Leading in and Securing the Straight-through Optical Cable

a) Release the support bar from the FastPlug. b) Loosen the fixing screw and separate the FastPlug for straight-through
optical cable. c) Loosen the fixing screws for the cable fixing.
Support bar

a) Route the straight-through optical cable into the shell of FastPlug. b) Fix the strength member using the fixing plate. Adjust
the cables to prevent the loose tube from being held down by the strength member.

When leading Before fixing the

the optical strength member,
cable into the adjust the cable
FastPlug, to keep the
ensure a cable stripping endface
bending and the
diameter of boundary of the
about 65 mm shell at the same
to avoid surface.
Bending breaking or
diameter damaging the
optical cable.

6
2 Stripping, Leading in and Securing Optical Cables (Continued)

b Leading in and Securing the Straight-through Optical Cable

a) Select a proper rubber plug and pressure plate from the accessory package based on the diameter of the optical cable. b
) Install the rubber plug to the straight-through optical cables. c) Install the pressure plate to the straight-through optical
cables
Diameter 6-13 mm 13-18 mm
range
Item 6-9 mm 9-13 mm 13-16 mm 16-18 mm

Rubber plug

(Blue) (Gray) (Black) (Pink)

Pressure plate

When installing the pressure

plate, the side with convex
point must be outward.

a) If the diameter of the optical cable is greater than 8 mm, remove the adjustment plate from the support. b) Push the
support into the shell of FastPlug. c) Insert the screw into the installation hole on the top of the FastPlug. Press down the
fixing screw.

Support

Adjustment
plate

7
 2 Stripping, Leading in and Securing Optical Cables (Continued)

b Leading in and Securing the Straight-through Optical Cable

d) Tighten the fixing screw using the Phillips screwdriver and then use the socket wrench to tighten the screw finally.

Phillips
screwdriver

When installing the support into the

shell of FastPlug, the boundary of the
shell must be between line 1 and line 2.

Line 2
Line 2 Line 1
Line 1

Socket wrench

Secure the fixing plate for the straight-through optical cable.

a) Pinch the clip using hand and pry the plug using Flat-head screwdriver at the same time. b) Push the blind plug out of the
hole.

8
2 Stripping, Leading in and Securing Optical Cables (Continued)

b Leading in and Securing the Straight-through Optical Cable

a) Remove the Velcro tape and turn up the splicing tray. b) Remove the support for adapters: press the broadside of the
support with one figure and pull the support upward. c) Lead the straight-through cable into the closure. d) Fasten the support
bar to the clip.

• When leading the straight-through
optical into the closure, confirm that
the FastPlug is installed into the
closure with the side where the
strength member is secured as the
front side 。
• You are advised to daub grease lubricant
to the O-ring of FastPlug before pushing it
into the closure for quicker operation.
Before daubing grease lubricant, please
clean the O-ring.

Grease
lubricant

Front Back

Clip
• Push the FastPlug into the closure
until the clip completely opens.

9
2 Stripping, Leading in and Securing Optical Cables (Continued)

b Leading in and Securing the Straight-through Optical Cable

a) Coil the straight-through cable and secure the cables using cable ties. b) Strip the branching part of straight-through cable
to bare fiber at the position of TUBE END line as shown in the figure b. c) Pull out the rubber plate. d) Pass the branching
part through the channel and install the rubber plate.

Cable tie TUBE END

a) Install the support for adapters. b) Coin the branching part of the straight-through optical cable into the splicing tray.

When installing the support for adapters,

place the side with gap facing the direction
of cable inlets as shown in the following
figure.

Support for Gap

adapters

3 Splicing and Terminating Optical Fibers and Routing Pigtails

a) Remove the block at the slot for optical splitter. b) Install the optical splitter.

When installing the

splitter, you must keep
it flat as shown in left
figure.
OUT IN

10
3 Splicing and Terminating Optical Fibers and Routing Pigtails (Continued)

c) Cut the connector of the input pigtail. d) Coil the input pigtail. e) Remove the dustproof caps from the closure. f) Route
the output pigtail through the corresponding channel and insert the connectors into the adapters.

Input Pigtail

Output
Pigtail

a) Splice the branching part of the straight-through optical cable and input pigtails. b) Coil branching part of straight-through
optical cable and pigtails.

branching part of straight-through optical cable

Φ0.125 fiber core

50 mm
Input
pigtails

Branching part fiber of straight-

through optical cable
Input pigtail of the SPL

Output pigtail of the SPL

Splicing protection tube

SPL

Bundle up the splicing tray with the Velcro strap.

11
4. Checking after the Installation
No. Description

1 Check whether the diameter of the optical cable matches the FastPlug.

2 Check whether the screws are tightened.

3 Check whether optical cables and fibers are reliably secured.

4 Check whether the gasket on the shell is flat (press down the gasket if it bulges) and the closure is properly sealed.

5 Check whether the bending radius of optical fibers meets the requirement. Adjust the optical fiber coiling if
necessary.

6 Check whether the unoccupied cable holes are equipped with plugs.

5. Sealing the Closure

a) Install buckles using the flat-head screwdriver. b) Tighten the sealing screw using the Phillips screwdriver.

6. Installing the Closure

a Pole-mounting
Install the pole-mounting plates. Install the hose clamps to the plates.

12
6. Installing the Closure
a Pole-mounting
Secure the hose clamps on the pole, and tighten the screws.

b Wall-mounting
Mark installation positions by using the closure and Drill holes and install Plastic plugs in the specified
a marker. area on the wall.

Level

Marker

52-55 mm

Installation Φ10 mm
holes drill bit

Wall-mounting screw
Wall
Plastic plug
Fasten the closure to the wall by tightening the screws.

13
6. Installing the Closure

c Aerial-Mounting
a Install the bracket to the closure.

It is advised to keep two

brackets at the same height.

a) Remove the screws. b) Hang the closure onto the cable, and then fasten the screws.

7. Installing the drop cable

a) Remove the dustproof cap from the adapter by rotating the dustproof cap of the adapter from the 1 position to the 0
position. b) Remove the dust cap from the drop cable connector. c) Remove the shroud for ferrule protection.

0 1

Dust cap Shroud for ferrule protection

14
7. Installing the drop cable

a) Connect the drop cable to the closure, and rotate the connector from the 0 position to the 1 position. b) Connect the
dustproof caps of the drop cable connector and adapter.

0 1

15
Appendix 1

This appendix shows the method to maintain the closure.

a Fixing the shell of closure to 120°

When maintaining the closure mounted on a pole or on the wall, take out the metallic wedge(on the back of the splicing
tray) and fix the shell to 120°.
Take out the metallic pressure plate.

Wedge Wedge

Insert the short side of metallic spacing piece to the hole.

120°

b Removing the FastPlug

Remove the FastPlug using the same method of removing the corresponding blind plug.
