MODEL V30, 50, 100
START UP CHECKS
• Your eyes may be injured by the processing solution.
Be sure to wear safety goggles.
• Your skin may be injured by the processing solution.
Be sure to wear chemical resistant gloves and working clothes.
1 Press the TIMER key. 3 ATTACH UPPER TURN GUIDES
PROPERLY
EXECUTE START CHECK
After grime has been removed from
each upper turn guide and inlet guide,
YES attach them to the processing racks.
2 CHECK LEVELS OF
Upper turn guides
PROCESSING SOLUTION TANKS
Open the upper cover and check that
the level of each of the processing
solutions reaches the upper end of the
overflow pipe.
Inlet guide
YES
Upper end of the overflow pipe
YES
8 Leader card
2, 3, 4, 5
6
7
4 ATTACH SQUEEGEE RACK 7 EXECUTE AUTO
PROPERLY WATER REFILLING
After the squeegee rack has been
YES
washed, attach and secure it to the
processor with two knob screws.
REFILLING
Roller If the water level in the tank is low:
REFILL WATER INTO
REFILLING WATER TANK
Wash the rollers
Refill water into the refilling water tank.
while rubbing them.
Refilling water tank
Squeegee rack
Knob screws 8 OPEN LOADING COVER
YES Open the loading cover.
5 CHECK IF RACK STOPPER
INSERT LEADER CARD
IS SET PROPERLY Insert the leader card and
close the loading cover.
LEADER CARD TEST
Rack stopper Rack stopper
FINISHED?
YES
9 PROCESS CONTROL STRIP?
YES or NO
YES Process the control strip.
6 CLOSE UPPER COVER
Close the upper cover.
KS
EC
H
C
P
U
T
AR
ST
CLOSE DOWN CHECKS
• Your eyes may be injured by the processing solution.
Be sure to wear safety goggles.
• Your skin may be injured by the processing solution.
Be sure to wear chemical resistant gloves and working clothes.
1 Press the TIMER key. 5 REMOVE SQUEEGEE RACK
AND CLEAN IT
EXECUTE CLOSE CHECK
Remove the squeegee rack and wash it.
YES Squeegee rack
2 CHECK TIMER SETTING
If the setting time is to be changed,
carry out setting on the
PROGRAM TIMER display.
YES
Knob screws
3 If the DRIVE switch is turned on:
YES
TURN OFF DRIVE SWITCH
6 CLEAN ROLLERS AND REMOVE
CRYSTALS FROM PROC. RACKS
4 REMOVE UPPER TURN GUIDES
Wash the upper part of the processing
racks.
AND CLEAN THEM Processing rack
Open the upper cover, remove the
upper turn guides and inlet guide,
and clean them.
After the inlet guide has been washed,
wipe the guide and attach it as it was.
Upper turn guides
YES
Inlet guide
YES
7 CHECK LEVELS OF 9 EXECUTE AUTO
PROCESSING SOLUTION TANKS WATER REFILLING
Check that the level of each of the
YES
processing solutions reaches the
upper end of the overflow pipe.
Upper end of the over flow pipe REFILLING
If the water level in the tank is low:
REFILL WATER INTO
REFILLING WATER TANK
Refill water into the refilling water tank.
Refilling water tank
YES
8 CLOSE UPPER COVER
Close the upper cover.
If the program timer is not being used, keep
the cover half open.
10 PROGRAM TIMER OPERATING
4, 5, 6, 7 8
KS
EC
H
C
3
N
W
O
D
SE
LO
C
SPLICING
Splicing is the operation where the film is spliced to the leader card.
For information on how to splice film other than 135 film, refer to the Operator’s Manual - Basic Operations -.
• Your hand may be cut with the cutter. Do not bring your hand close to the cutter.
1 Pull the film tongue. 3 Lift the film holder of the splicing
gauge and raise the cutter.
Film tongue
Cutter
Film holder
2 Check that the leader card is not
soiled.
Remove glue from the leader card, if any.
Leader card
Splicing gauge
4 Place the film on the splicing gauge
and lower the film holder.
Never use the leader cards under
the following conditions.
Damage at the Damaged
leader card edge perforations 4th perforation on the short
side of the film
Film tongue
10 mm
5 mm
Horizontal curl with Vertical curl with
5 mm or more 10 mm or more 5 Lower the cutter and cut the film
tongue.
6 Position the leader card. 8 Remove any bubbles from the
splicing tape.
Guide pins
Splicing tape
9 Lift the film holder and remove the
film cartridge and leader card from
the splicing gauge.
Remove the film while holding
both the film cartridge and leader
card.
Overlap the film
on the leader card.
Film cartridge
7 Splice the film to the leader card
using splicing tape.
Do not use splicing tape which has any
perspiration or hand cream or which has
Leader card
been exposed to the air more than 5 hours.
3-5
mm
A=B
10 Rewind the film into its cartridge
A using the take-up roller.
B
Take-up roller
Splicing tape
Stop rewinding before the splicing tape.
G
IN
C
LI
SP
LIST OF MODES
DEVELOPMENT
MAIN MENU SWITCHES REPLENISHMENT SWITCH
DISPLAY CONTRAST
BUZZER VOLUME
TEMPERATURE TEMPERATURE DISPLAY
SOLUTION TEMP. SETTING
THERMOSENSOR CALIBRATION
TOTALING TODAY’S ROLLS
TOTAL ROLLS
FILM POSITION
CHECK INPUT CHECK LOADING
VERSION CHECK PROCESSOR
DIGITAL FLOWMETER ∗
TIMER DATE & TIME DISPLAY
DATE & TIME SETTING
PROGRAM TIMER SETTING
MAINTENANCE DAY SETTING
REPLENISH. REPLENISHMENT TOTAL REPLENISH. AMOUNT
/ REFIL. WATER
REFILLING WATER MANUAL REPLENISHMENT
BASIC AMOUNT SETTING
PUMP AMOUNT SETTING
PUMP AMOUNT MEASUREMENT
REPLENISHMENT LACK TIME
FLOPPY FLOPPY DISK READING / WRITING
SOFTWARE UPGRADE
FORMAT
is a display requiring the password.
*This mode can be selected only when the digital flowmeter (option) is installed.
These modes may be changed without notice. Check according to the Operator’s Manual - Additional Operations -.
