Neteco

ECC500(Data center)
V300R001C02
User Mannual

Issue Draft C
Date 20130226
HUAWEI TECHNOLOGIES CO., LTD.

Issue Draft C (20130226)
Huawei Proprietary and Confidential
Copyright Huawei Technologies Co., Ltd.
i

Copyright Huawei Technologies Co., Ltd. 2013. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.

Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: support@huawei.com

ECC500(Data center)
User Mannual About This Document

Issue Draft C (20130226) Huawei Proprietary and Confidential
ii

About This Document
This document describes the energy control center 500 (ECC500) in terms of overview,
architecture, installation and commissioning, user interface (UI), and maintenance and
troubleshooting. The document will guide onsite installation personnel through the ECC500
installation and provides support for Huawei technical support engineers.
Product Version
The following table lists the product version related to this document.
Product Name Version
ECC500 V300R001C02

Intended Audience
This document is intended for:
Sales Engineer
Technical Support Engineer
System Engineer
Hardware Installation Engineer
Commissioning Engineer
Data Configuration Engineer
Maintenance Engineer
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description

Alerts you to a high risk hazard that could,
if not avoided, result in serious injury or
death.
ECC500(Data center)
User Mannual About This Document

iii

Symbol Description

Alerts you to a medium or low risk hazard
that could, if not avoided, result in moderate
or minor injury.

Alerts you to a potentially hazardous
situation that could, if not avoided, result in
equipment damage, data loss, performance
deterioration, or unanticipated results.

Provides a tip that may help you solve a
problem or save time.

Provides additional information to
emphasize or supplement important points
in the main text.

Change History
Issue Description Date
Draft A This issue is the first official
release.
2012-05-30
Draft B This document incorporates the
following changes:

Added SNMP northbound
interfaces, supports the
third-party network
management system.

Added descriptions for
configuring monitoring
interface of Emerson UPS.
20120920
Draft C This document incorporates the
following changes:

The prompt logs in the system
default user name and
password.

After prompting first time logs
in the Web system, must
change the default password.
20130226
ECC500(Data center)
User Mannual Contents

iv

Contents
About This Document .................................................................................................................... ii
1 ECC500 Overview ......................................................................................................................... 1
1.1 Positioning ....................................................................................................................................................... 1
1.2 Benefits ............................................................................................................................................................ 1
1.3 Typical Application Scenario ........................................................................................................................... 3
2 Architecture .................................................................................................................................... 5
2.1 Components...................................................................................................................................................... 5
2.2 Panel and Ports ................................................................................................................................................. 6
2.2.1 Main Control Module.............................................................................................................................. 6
2.2.2 Basic I/O module .................................................................................................................................... 9
2.2.3 GPRS module........................................................................................................................................ 11
3 Installation and Commissioning.............................................................................................. 14
3.1 Installation Preparation .................................................................................................................................. 14
3.2 Installation ...................................................................................................................................................... 14
3.3 Cable Connection ........................................................................................................................................... 15
3.3.1 Overview ............................................................................................................................................... 15
3.3.2 Connecting the Communication Cable ................................................................................................. 17
3.4 Commissioning .............................................................................................................................................. 19
4 User Interface Description ........................................................................................................ 21
4.1 LUI Description ............................................................................................................................................. 21
4.1.1 LCD Usage............................................................................................................................................ 21
4.1.2 LCD Menu Hierarchy ........................................................................................................................... 23
4.2 WebUI Description ......................................................................................................................................... 24
4.2.1 Login Preparation .................................................................................................................................. 24
4.2.2 WebUI Description ................................................................................................................................ 29
5 Maintenance and Troubleshooting ......................................................................................... 43
5.1 Common Faults and Solutions ....................................................................................................................... 43
5.2 Parts Replacement .......................................................................................................................................... 43
5.3 Software Upgrade ........................................................................................................................................... 45
6 Appendix ...................................................................................................................................... 47
ECC500(Data center)
User Mannual Contents

v

6.1 Technical Specifications ................................................................................................................................. 47
6.2 LUI Menu ....................................................................................................................................................... 48
6.3 Acronyms and Abbreviations ......................................................................................................................... 53
ECC500(Data center)
User Mannual 1 ECC500 Overview

1

1 ECC500 Overview
1.1 Positioning
The ECC500 is a cross-platform monitoring product, in which a main control module works
with several expansion boards to monitor the environment, uninterruptible power supply
(UPS), natural-ventilation units in real time. In addition, the GPRS module on the ECC500
can send short messages to prompt related personnel to handle alarms. The ECC500 can
collect and analyze statistics on feedback information and automatically control system
components. This ensures the system reliability and security and meets all monitoring
requirements of a mini data center. Figure 1-1 shows an ECC500.
Figure 1-1 ECC500

1.2 Benefits
In a mini data center, the ECC500 can automatically detect the connection equipment
(southbound equipment) and allows you to configure, control, monitor, and collect statistics
on the equipment. The ECC500 also connects to a web client through the IP network for
presenting a web management interface, and provides the alarm notification function using
the GPRS module.
The ECC500 allows you to perform remote maintenance on the web user interface (WebUI)
or local maintenance on the LCD. Maintenance data is synchronized between the WebUI and
the LCD.
UPS Monitoring
The ECC500 obtains real-time data and alarms by running UPS status query commands
periodically (the period is shorter than 15s), and reports and clears alarms.
If the UPS does not respond the UPS status query commands for three consecutive times,
the ECC500 reports alarms indicating interrupted communication with the UPS. The
ECC500(Data center)

2

ECC500 clears the alarms only after detecting a UPS with the same type as the original
one.
The ECC500 collects the real-time performance data (rated values) every 60s and other
data by running commands, and saves all data to its memory.
The ECC500 can query real-time status data by running testing commands during
equipment deployment, scheduled preventive maintenance, and corrective maintenance.
UPS monitoring alarms are reported indicating mains voltage exceptions, low voltage of
batteries, UPS faults, and UPS communication interruption.
Natural-ventilation monitoring
The ECC500 can connect to and manage the fan control system and use the speed
adjustment curve and temperature sensor in the fan controller to control the fan rotational
speed for the natural-ventilation equipment.
The ECC500 can monitor the fan controller, temperature sensor, and four connected fans.
Natural-ventilation monitoring alarms are reported indicating the failure of temperature
sensor at the air exhaust vent, high and low ventilation temperatures, control board and
fan faults, and communication interruption.
Alarm Notification by Sending Messages
The ECC500 allows the GPRS module to send alarm notification messages to the mobile
phones of maintenance engineers.
A maximum of five field application engineer (FAE) phone numbers can be set on the
ECC500 over the LCD or WebUI. When major or critical alarms are generated, the
GPRS module sends the alarm information to these phones.
Data Collection and Processing
The ECC500 reports the data collected by the water sensor, smoke sensor, door status
sensor, camera, and ambient temperature and humidity sensor, and reports alarms over
dry contacts.
The ECC500 can back up its own data and that of the monitored equipment. For example,
the ECC500 backs up the alarm information that is downloadable from the WebUI.
When failing to communicate with a web client, the ECC500 still works properly and
stores alarms. After communication is restored, the stored alarm information can be
downloaded by using the WebUI.
Centralized Management of Intelligent Equipment
The ECC500 remotely or locally manages intelligent equipment, such as the
natural-ventilation unit and UPS, in a centralized manner. The ECC500 communicates
with the natural-ventilation unit and UPS over the RS485 serial port, and communicates
with a web client using 10 Mbit/s or 100 Mbit/s autonegotiation Ethernet port.
The ECC500 provides ports for receiving signals from sensors and sending control
signals to meet requirements for data collection and control.
Alarm Detection and Management
The ECC500 monitors analog and digital parameters and reported data and alarms to
detect alarm generation and clearance in real time. The ECC500 manages alarms in the
following manner:
ECC500(Data center)

3

Display all alarms on the LCD or on the WebUI, and turn on the alarm indicator to
indicate major or critical alarms.
When the major or critical alarms are cleared, turn off the LED alarm indicator and
clear these alarms on the LCD or WebUI.
The ECC500 saves a maximum of 800 historical alarms, among which you can view
cleared alarms on the LCD or on the WebUI.
User-Friendly Interface
The ECC500 displays all operation parameters for the monitored equipment on the LCD.
The ECC500 allows you to set site-deployment and network-connection parameters for
sites and the NMS, such as IP addresses and access point names (APNs), on the LCD to
implement laptop-free deployment.
The ECC500 provides the WebUI that transmits data after encrpting it over SSL to help
obtain real-time information, alarms, and statistics from tab pages and issue control
commands through the data exchange interface.
A web client of the ECC500 supports SNMP northbound interfaces, data query, alarm
reporting, access to third-party network management system.
A web client of the ECC500 supports a maximum of 15 accounts in three levels
(administrator, engineer, and operator). Each level can be assigned a maximum of five
accounts.
The ECC500 allows the access of a maximum of three web clients running on three
separate computers. A user can log in to the ECC500 from only one client at a time.
Communication
A web client can obtain ECC500-reported equipment information, such as UPS and
natural-ventilation information, by communicating with the ECC500 through the IP
network with encrypted transmission. In addition, the ECC500 performs operations (for
example, open or close dry contacts and control southbound equipment) after receiving
control and configuration information from the WebUI.
The ECC500 communicates with southbound equipment over Huawei temperature
control protocol and the Modbus protocol to collect the data required for other modules.
The ECC500 also sends control and configuration commands to southbound equipment
to perform operations, such as battery connection and disconnection.
By communicating with northbound equipment, the ECC500 allows you to load its
applications and those of southbound equipment online and view the electronic labels.
1.3 Typical Application Scenario
Figure 1-2 shows a typical application scenario of the ECC500 in a mini data center.
ECC500(Data center)

4

Figure 1-2 Application scenario of the ECC500 in a mini data center

A web client of the ECC500 supports SNMP northbound interfaces, data query, alarm reporting,
access to third-party network management system.
Temperature control units include natural-ventilation devices.
You can select devices based on ECC500 site requirements for the ECC500 to monitor them.
ECC500(Data center)
User Mannual 2 Architecture

5

2 Architecture
2.1 Components
The ECC500 consists of a main control module, a basic input/output (I/O) module, a GPRS
module, and reserved slots, as shown in Figure 2-1.
The main control module and basic I/O module are mandatory, and other modules are
optional.
Figure 2-1 ECC500

(1) Main control module (2) Reserved slots (3) GPRS module (4) Basic I/O module
Table 2-1 lists ECC500 component functions.
Table 2-1 ECC500 component functions
Module Silk
screen
Configur
ation
Function
Main
control
module
SMU03A Mandator
y

Provides an LCD to query and set local
parameters.

Provides an operation indicator.

Provides FE and RS485 ports for
communication with northbound equipment.

Provides RS485 ports for communication with
southbound equipment.

Records active and historical alarms.
ECC500(Data center)

6

Module Silk
screen
Configur
ation
Function

Manages intelligent units.

Monitors the natural-ventilation system.

Monitors and manages a mini data center.
Basic I/O
module
MUS01A Mandator
y

Monitors UPS components over serial ports.

Receives alarms generated by dry contacts and
sensors for detecting water, smoke, door status,
lightning, camera and ambient temperature and
humidity.
GPRS
module
MUC01A Optional

Sends alarm notification messages through a
network independent of the IP network.

Provides six digital parameter input ports and
two dry contact outputs.

A reserved slot can house an extension communications module, an extension I/O module, or a TCU.
2.2 Panel and Ports
2.2.1 Main Control Module
The main control module provides an LCD to query and set local parameters. Figure 2-2
shows the front panel of the main control module.
Figure 2-2 Front panel of the main control module

(1) Indicators (2) LCD (3) Buttons (4) FE port
(5) RS485/RS232 (6) COM1 (7) COM2 (8) Universal serial bus (USB)
ECC500(Data center)

7

port port port port
Indicators
Table 2-2 lists the indicators on the main control module.
Table 2-2 Indicators on the main control module
Silk
screen
Color Name Status Description

Green Operation
indicator
Steady off The main control module
is faulty or has no DC
input.
Blinking (1s on and
1s off)
The main control module
runs properly and
communicates a web client
properly.
Blinking (0.125s on
and 0.125s off)
The main control module
runs properly but fails to
communicate with the
NetEco.

Red Alarm
indicator
Off There is no major or
critical alarm.
On A critical or major alarm is
generated.

LCD and Buttons
You can view information and set parameters on the LCD by using four buttons. Table 2-3
describes the buttons on the front panel.
Table 2-3 Button description
Button Name Description
or
Arrow button Allows you to select menu items and set
parameters.

Return button Returns to the upper-level menu without saving
parameter settings.

Confirm button Enters the main menu from the standby screen,
enters a submenu from the main menu, or confirms
or saves parameter settings.

ECC500(Data center)

8

If you press no button within 8 minutes after a menu is displayed, the standby screen is displayed.
If you press no button within 8 minutes after a menu is displayed, the LCD screen becomes dark.
Ports
Table 2-4 describes the ports on the main control module.
Table 2-4 Port description
Silk screen Description
FE Ethernet port connecting to the northbound equipment and transmitting
data after encrpting it, allowing client access over the local network or
a remote network and access to third-party network management
system

Transmits data.
1: TX+
2: TX-

Receives data.
3: RX+
6: RX-
RS485/RS232 Reserved northbound port

Transmits data.
1: 485_TX+
2: 485_TX-
7: RS232_TXD sharing the UART with
RS485 within the same RJ45 port

Receives data.
3: RS232_RXD sharing the UART with
RS485 within the same RJ45 interface
4: 485_RX+
5: 485_RX-

GND: 6, 8
COM1 Reserved southbound RS485 port

Receives data.
1: RX+
2: RX-

Transmits data.
4: TX+
5: TX-

GND: 6
COM2 Southbound RS485 port connecting to the natural-ventilation
equipment

Receives data.
ECC500(Data center)

9

1: RX+
2: RX-

Transmits data.
4: TX+
5: TX-
USB port Reserved port for connecting to hardware

2.2.2 Basic I/O module
Figure 2-3 shows the front panel of the basic I/O module.
Figure 2-3 Front panel of the basic I/O module

(1) ELU (2) SMOKE (3) DI_1 (4) DI_2 (5) DI_3
(6) AI_1 (7) AI_2 (8) TEM_HUM (9) WATER (10) CAN
(11) 12 V (12) COM1 (13) GATE (14) COM2 (15) COM3
(16) DC input terminals (17) Indicators - - -
Table 2-5 describes indicators on the front panel of the basic I/O module.
Table 2-5 Indicator description
Silk screen Color Name Status Description
PWR Green Power indicator On The power
system runs
properly.
Off The I/O module
is faulty or has
ECC500(Data center)

10

Silk screen Color Name Status Description
no DC input.
RUN Green Operation
indicator
Blinking (1s on
and 1s off)
The I/O module
communicates
properly with
the main control
module.
Blinking
(0.125s on and
0.125s off)
Communication
fails between
the I/O module
and the main
control module.
ALM Red Alarm indicator Off No alarm is
generated.

Table 2-6 describes ports on the front panel of the basic I/O module.
ELU Reserved for future use

1: supplies 5 V power for the electronic label.

3, 6: GND

4: I2C data line

5: I2C clock signal line

7: supplies 5 V power for 1-WIRE extension module.

8: 1-WIRE signal line
DI_1 Dry contact for receiving alarms reported by the lightning arrestor.
Default setting:

If the dry contact is closed, an alarm is generated.

If the dry contact is open, no alarm is generated.
DI_2 Reserved for future use ( connects to a camera)
DI_3 Reserved for future use ( connects to a indoor smoke sensor)
AI_1 Reserved for future use
AI_2 Reserved for future use
TEM_HUM Connects to an ambient temperature and humidity sensor.
WATER Connects to a water sensor.
SMOKE Connects to a smoke sensor.
CAN CAN communication port
ECC500(Data center)

11

12 V Outputs power between 10.5 V and 13.5 V, Connects to a indoor smoke
sensor.
COM1 Two-wire RS485 port reserved for southbound communication
GATE Dry contact for receiving door status alarms. Default setting:

If the dry contact is open, no alarm is generated.

If the dry contact is closed, an alarm is generated.
COM2 Southbound RS485 port for monitoring UPS 1

Receives data.
1: RX+
2: RX-

Transmits data.
4: TX+
5: TX-

CAN differential signals
7: CANH
8: CANL
COM3 Southbound RS485 port for monitoring UPS 2

Receives data.
1: RX+
2: RX-

Transmits data.
4: TX+
5: TX-

7, 8: DO+, DO-
DC input
terminals
-48 V DC input port

RTN+: positive DC input terminal

NEG-: negative DC input terminal

If the system has one Emerson UPS, connect the monitor signal lines to COM1.
If the system has two Emerson UPSs, connect all monitor signal lines to COM1 and switch the DIP2 on.
2.2.3 GPRS module
Figure 2-4 shows the front panel of the GPRS module.
ECC500(Data center)

12

Figure 2-4 Front panel of the GPRS module

(1) DO_1 (2) DO_2 (3) DI_1 (4) DI_2
(5) DI_3 (6) DI_4 (7) DI_5 (8) DI_6
(9) ANT (10) Indicators - -
Figure 2-5 shows the SIM card slot on the GPRS module.
Figure 2-5 SIM card slot in the GPRS module

(1) SIM card slot
Indicators
Table 2-7 lists the indicators on the GPRS module.
Table 2-7 Indicator description
Silkscreen Color Status Description
PWR1 Yellow On Power is properly
supplied for the
GPRS board.
Off The power supply
system is faulty or
has no DC input.
ECC500(Data center)

13

Silkscreen Color Status Description
PWR2 Yellow On The GPRS module
functions properly.
Off The GPRS module
is faulty or has no
DC input.
GPRS Green Off The GPRS module
is not powered on.
On The GPRS is
attempting to
connect to the server
of the operator.
Blinking (0.1s on
and 0.025s off)
The GPRS data is
being transmitted.
Blinking (0.1s on
and 2.9s off)
The GPRS module
has registered with
the network but is
not transmitting or
receiving data.
Blinking (0.1s on
and 0.9s off)
The ECC500 is
searching for a
network, no SIM
card is available, or
no PIN is obtained.

Ports
Table 2-8 lists the ports on the GPRS module.
Silkscreen Description
DO_1 Dry contact output
The dry contact is open for connecting to
audible and visual alarm reporters.
DO_2
DI_1 Dry contact input
Default setting:

If the dry contact is closed, no alarm is
generated.

If the dry contact is open, an alarm is
generated.
DI_2
DI_3
DI_4
DI_5
DI_6
ECC500(Data center)
User Mannual 3 Installation and Commissioning

14

3 Installation and Commissioning
3.1 Installation Preparation
Safety Precautions
Wear ESD gloves to move equipment. This prevents electrostatic shock and damage to hands.
Protect yourself from falling-down objects.
Tools
Table 3-1 lists the required tools.
Table 3-1 Tool requirements
Appearance Item Description

Phillips
screwdriver
Tightens screws.
Screwdriver specifications: M3 x 100 mm or
M6 x 200 mm

Flat-head
screwdriver
Tightens screws.
Screwdriver specification: M2 x 100 mm or
M6 x 200 mm

3.2 Installation
Prerequisite
All tools are obtained.
The location of the equipment is determined in the rack.
ECC500 installation
Figure 3-1 shows how to install the ECC500 in the standard 19-inch rack.
ECC500(Data center)

15

Figure 3-1 ECC500 installation

Procedure
Step 1 Install floating nuts on the rack.
Step 2 Install mounting ears on the ECC500.
Step 3 Hold the mounting ears of the ECC500, and place it on the guide rails in the rack.
Step 4 Push the ECC500 inside the rack to ensure that the mounting ears are level with the columns
in the rack.
Step 5 Partially tighten each screw in the four mounting holes of the mounting ears using an M6
Phillips screwdriver.
----End
3.3 Cable Connection
3.3.1 Overview
The following cables need to be connected for the ECC500:
Ground cable
RJ45 communication cable
Dry contact signal cable
DC power cable
Sensor signal cable

Cables are connected to the ECC500 based on site requirements.
Connecting the Ground Cable
After you install the ECC500, connect the ground cable first, as shown in Figure 3-2.
ECC500(Data center)

16

Figure 3-2 Ground cable connection

Connecting the RJ45 Communication Cable
Connect the ECC500 and the required equipment using the RJ45 communication cable. The
RS485/232 and Ethernet serial ports use RJ45 terminals. Figure 3-3 shows how to connect the
RJ45 communication cable.
Figure 3-3 RJ45 communication cable connection

Cores in the RJ45 communication cable terminal are ranged by following the sequence (orange-white,
orange, green-white, blue, blue-white, green, brown-white, and brown) specified by 586B.
The pinouts of FE port and RS485 port are defined as 2.2 Panel and Ports
Connecting Signal Cables to Dry Contacts
Figure 3-4 shows how to connect signal cables to dry contacts.
ECC500(Data center)

17

Figure 3-4 Connection of signal cables to dry contacts

Connecting the DC Power Cable
Connect the terminals of the power cable to the socket with the silkscreen RTN (+) NEG (-)
as shown in Figure 3-5.
Figure 3-5 DC power cable connection

Connecting Sensor Signal Cables
For the ports to which the sensor signal cables are connected, see 2.2.2 Basic I/O module.
3.3.2 Connecting the Communication Cable
The ECC500 connects to a web client through the IP network for presenting the web
management interface, and provides alarm notification function using the GPRS module.
Connecting the ECC500 to the IP Network
Figure 3-6 shows how to connect the ECC500 to the IP network.
ECC500(Data center)

18

Figure 3-6 Connection between the ECC500 and the IP network

The port supports security protocols.
Connecting the GSM Antenna and Installing the SIM Card

The GSM antenna connector is fastened to the RF port on the GPRS module.
The antenna is installed in an unshielded place to ensure proper signal reception.
If the GPRS antenna is longer than 3 meters, take surge protection measures.
If the mounting bracket of the GSM antenna has a plastic shell, remove the plastic shell
before installing the GSM antenna. This ensures sufficient magnetic force.
Figure 3-7 shows how to connect the GSM antenna.
Figure 3-7 GSM antenna connection

To enable the GPRS function on the ECC500, remove the GPRS module, insert an SIM card
to it, and reinstall the GPRS module properly. Figure 3-8 shows how to insert and remove an
SIM card.
ECC500(Data center)

19

Figure 3-8 SIM card insertion and removal

Users should provide an SIM card by themselves.
3.4 Commissioning
After installing the ECC500, verify the connection of all cables, power on the ECC500, check
the status of all indicators, and set communication parameters for the ECC500 on the LCD.
Checking Cable Connection and Powering on the ECC500
Power on the ECC500 after verifying that the DC power cable, communication cable, and
signal cable are properly connected to the main control module, basic I/O module, and GPRS
module.
Checking Indicator Status
Verify the indicator status for the main control module, basic I/O module, and GPRS module.
Table 3-2 lists the ECC500 indicators in normal state.
Table 3-2 ECC500 indicators in normal state
Module Normal State
Main control
module

The operation indicator keeps blinking (1s on and 1s off).

The alarm indicator is always off.
Basic I/O module

The power indicator is always on.

The operation indicator keeps blinking (1s on and 1s off).

The alarm indicator is always off.
ECC500(Data center)

20

Module Normal State
GPRS module

The PWR1 indicator is always on.

The PWR2 indicator is always on.

The GPRS indicator keeps blinking (0.1s on and 0.025s off).

Setting ECC500 Communication Parameters on the LCD
Table 3-3 lists the IP network parameters.
Table 3-3 IP network parameters
Parameter Description
IP Address Set according to the network plan
Subnet Mask Set according to the network plan
Gateway Set according to the network plan

Figure 3-9 shows how to set the IP network parameters on the LCD.
Figure 3-9 IP network parameter settings on the LCD

ECC500(Data center)
User Mannual 4 User Interface Description

21

4 User Interface Description
4.1 LUI Description
The ECC500 provides an LCD for you to locally perform the following operations:
View active and historical alarms.
View the system running status.
Set system and communication parameters.
Control the system status.
Set parameters efficiently, such as date, time, and communication addresses.
4.1.1 LCD Usage
This section describes how to select a display language, view historical alarms, and set and
modify parameters on the LCD. For details about how to use the buttons on the ECC500 main
control module, see LCD and Buttons.
Selecting a Display Language
After powering on the ECC500, the screen for selecting a display language is displayed. You
can press or to select a display language, as shown in Figure 4-1. To display the
standby screen, press .
Figure 4-1 Screen for selecting a display language

After entering the system, you can change the display language by performing the steps
shown in Figure 4-2.
ECC500(Data center)

22

Figure 4-2 Display language selection

Viewing Historical Alarms
This section describes how to view historical alarms on the LCD, as shown in Figure 4-3. The
parameter values in the figures in this section are for reference only.
Figure 4-3 Procedure for viewing historical alarms

The value 111018 indicates 2011-10-18. The value 1/22 indicates that a total of 22 alarms are
generated and the first one is displayed.
The value 111018 07:53:50 indicates the time the alarm is generated. The value 111018 08:29:12
indicates the time the alarm is cleared.

Modifying Parameters
This section describes how to modify parameters on the LCD, as shown in Figure 4-4.
ECC500(Data center)

23

Figure 4-4 Procedure for modifying parameters

To enter the settings screen, quick-setting screen, and control screen, you need to enter the password.

4.1.2 LCD Menu Hierarchy
Figure 4-5 the LCD menu hierarchy.
Figure 4-5 LCD menu hierarchy

The data that is displayed on the LCD in this section is for reference only.
Menus specific to monitored devices are displayed only after the devices (natural-ventilation device)
are connected to the ECC500.

ECC500(Data center)

24

4.2 WebUI Description
To ensure the security of data transmission, the ECC500 transmits data after encrpting it over
SSL. You can perform the following operations on the WebUI:
View the system information, such as the UPS status, natural-ventilation system status,
and active alarms.
Set system parameters.
Configure network parameters, IP addresses, and FAE phone numbers.
Control the system, such as the UPS and natural-ventilation monitoring units.
Manage user information. For example, add, delete, and modify user information.
Upgrade software online.
Query and export historical logs and alarms.
Collect the performance statistics on the main control module and the monitored
equipment.
Set the system date and time and site name, and save, download, and upload
configuration files.
Query electronic label information.
4.2.1 Login Preparation
Set the IP address, gateway, and subnet mask of the ECC500 before logging in to the WebUI.
You also need to set the network and Internet Explorer.

Configurations:
Operating system: Windows XP or Windows 7
Browser: Internet Explorer 6.0 or a later version
Connecting Cables
Connect the FE port on the ECC500 and a communication device using a network cable, and
the port together with security protocols.
Setting the IP Address
Set the IP address, subnet mask, and gateway on the LCD based on the assigned ones.
Setting the LAN

If the ECC500 is connected to a local area network(LAN) and a proxy server has been selected, cancel
the proxy server settings.
If the ECC500 is connected to the Internet while the computer (where a client runs) is connected to the
LAN, retain the proxy server settings. Otherwise, you cannot connect the computer to the ECC500.
1. Open Internet Explorer.
2. Choose Tools > Internet Options.
3. On the Connections tab, click LAN settings, as shown in Figure 4-6.
ECC500(Data center)

25

Figure 4-6 Internet options

4. Select or clear Use a proxy server for your LAN (These settings will not apply to
dial-up or VPN connections). as required, as shown in Figure 4-7.
ECC500(Data center)

26

Figure 4-7 LAN settings

5. Click OK. The proxy server setting is complete.
Setting Internet Explorer
If Internet Explorer 8.0 is used, open Internet Explorer 8.0 and choose Tools >
Compatibility View from the main menu to set the browser, as shown in Figure 4-8.
This ensures proper use of the WebUI.
Figure 4-8 Compatibility View

ECC500(Data center)

27

Specify the IP address of the ECC500 as trusted, enable the download function, and set
the security level of the trusted IP address as the lowest.
1. Open Internet Explorer.
2. Choose Tools > Internet Options from the main menu.
3. On the Security tab, select Trusted sites and click Sites, as shown in Figure 4-9.
Figure 4-9 Trusted-site addition

4. Enter the IP address of the ECC500 and click Add and Close.
5. Click Custom level. In the dialog box that is displayed, choose Downloads >
Automatic prompting for file downloads, File download, and Font download from
the navigation tree and enable them. Then, click OK, as shown in Figure 4-10.
ECC500(Data center)

28

Figure 4-10 Download function setting

6. Drag the slider label to the medium level and click OK, as shown in Figure 4-11.
ECC500(Data center)

29

Figure 4-11 Security level setting

4.2.2 WebUI Description
The parameter values in the figures in this section are for reference only.
Logging in to the WebUI
Enter the IP address of the ECC500 in the Internet Explorer address box and press Enter. On
the page that is displayed, enter the user name and password, select the display language, and
click Login, as shown in Figure 4-12.
ECC500(Data center)

30

Figure 4-12 Login page

The default user name is admin and default password is a00001.
Change the the system default password after you logining in at the first time.
System Status
On System Status tab, you can view information about active alarms and monitored
equipment, as shown in Figure 4-13.
ECC500(Data center)

31

Figure 4-13 System status

The data that is displayed on the LCD in this section is for reference only.
Menus specific to monitored devices are displayed only after the devices (natural-ventilation device)
are connected to the ECC500.
System Configuration
On the System Configuration tab, you can configure parameters for the monitored
equipment. Specifically, click Site Summary to expand all options, click the desired option,
set the parameter, and click Submit, as shown in Figure 4-14.
ECC500(Data center)

32

Figure 4-14 System configuration

You can submit the modification only to one parameter at a time.
Network Configuration
On the Network Configuration tab, you can set network parameters, phone number of the
maintenance staffSNMP northbound control and interface of alarms reported as shown in
Figure 4-15.
ECC500(Data center)

33

Figure 4-15 Network configuration

When networking modes is IP networking, you can set the ECC's IP address, subnet mask and
default gateway. you can set five phone numbers in the system to send alarm reminded
messages.
Configure SNMP northbound interface can be connected to the third-party network
management, parameters description show as inTable 4-1.
Table 4-1 SNMP configuration parameters
parameters Description
SNMP Version

In SNMPv1&SNMPv2c system, you can set read and write
permissions of network management software to connect ECC.

In SNMPv3 system, you can set specific users of the network
management software to connect to ECC

ALLThe above two are supported
SNMP Port Set data port of network management software to connect the
ECC , the default value is 161.
ECC500(Data center)

34

parameters Description
Value range: 065535
Read Community Set read permissions of network management software to
connect the ECC , the default value is read.
Value rangea-zA-Z0v9you can input up to 15 character
Write Community Set write permissions of network management software to connect
the ECC , the default value is write
Value rangea-zA-Z0-9you can input up to 15 character
User Name Set a specific user to connect ECC
Value rangea-zA-Z09you can input up to 15 character
Password Connect ECC passwords
Value rangea-zA-Z0-9 The character length is more than
8 and less than 15.
Trap IP Trap IP is the IP address of PC, which is report SNMP alarm
information. And the IP address is planing by carrier.
Trap Port Trap port is the PC port, which is report SNMP alarm
information, the default value is 162.
Value range: 065535

Select Disable other configure optionto prevent SNMP configuration has been modified and protect
the configured information.
Alarm Configuration
On the Alarm Configurationtabyou can set the alarm severity of the site, the alarm name
and severity of ECC500 dry contact,as shown in Figure 4-16.
ECC500(Data center)

35

Figure 4-16 Alarm Configuration

User Management
On the User Management tab, you can create, modify, and delete user information, as shown
in Figure 4-17.
You can add a user to the admin, engineer, or operator group. The operation rights vary with
groups.
ECC500(Data center)

36

Figure 4-17 User management

Upgrade
On the Upgrade tab, you can upgrade the ECC500 as shown in Figure 4-18.
Figure 4-18 Upgrade

For details about how to upgrade the ECC500 on the WebUI, see 5.3 Software Upgrade.

Log History
On the Log History tab, you can click Download to export logs to pack files as shown in
Figure 4-19.
ECC500(Data center)

37

Figure 4-19 Log history

If the downloading user interface is not displayed after packing during the download, the Internet
Explorer setting may be faulty. To resolve this issue, see Figure 4-20. Choose Information Bar
Help > Windows Help and Support > To stop the Information bar from blocking file and
software downloads.
Click the Log History tab and retry the download. If the downloading user interface is not displayed,
perform operations as shown in Figure 4-21. Click Default level and Reset at zones to default level
and click OK.
Click the Log History tab and retry the download.
Figure 4-20 Information Bar Help

ECC500(Data center)

38

Figure 4-21 Internet options

Alarm History
On the Alarm History tab, you can click Export to export historical alarms to an .html or .xls
file, as shown in Figure 4-22.
ECC500(Data center)

39

Figure 4-22 Historical alarms

Site Configuration
On the Site Configuration tab, you can set the system date and time and site information, and
perform operations on configuration files, as shown in Figure 4-23.
ECC500(Data center)

40

Figure 4-23 Site configuration

You must save configuration files before downloading them.
If you fail to download configuration files, see Log History for handling methods.
The system automatically restarts after you upload configuration files.
Statistics
On the Statistics tab, you can query the statistical items recored by the ECC500, and clear one
or all items, as shown in Figure 4-24.
ECC500(Data center)

41

Figure 4-24 Statistics

Electronic Label
On the Electronic Label tab, you can view and export electronic label information about the
ECC500, monitored equipment, and equipment main control boards, as shown in Figure 4-25.
ECC500(Data center)

42

Figure 4-25 Electronic label information

ECC500(Data center)
User Mannual 5 Maintenance and Troubleshooting

43

5 Maintenance and Troubleshooting
5.1 Common Faults and Solutions
This chapter describes common faults of the ECC500 and how to troubleshoot them. Table
5-1 lists common faults and troubleshooting measures.
Table 5-1 Common ECC500 faults and troubleshooting measures
Module Symptom Troubleshooting
measure
Main control module The operation indicator is
off or blinks at 4 Hz.
Check the power supply and
communication with the
host.
The alarm indicator is on. View the alarm information
and rectify the fault.
Basic I/O module The power indicator is off. Check the power supply.
The alarm indicator is on. View the alarm information
and rectify the fault.
GPRS module The PWR1 indicator is off. Check the power supply.
The PWR2 indicator is off.
The GPRS indicator is off or
blinks (0.1s on and 0.9s off).
Check the power supply or
search for the network.

For details about how to view alarm information, see Viewing Historical Alarms.
5.2 Parts Replacement
Context
This section describes how to replace faulty ECC500 modules.
ECC500(Data center)

44

Before replacing faulty modules, verify that no power is supplied for the ECC500 and
disconnect the DC power cable terminals.
Only trained and qualified personnel are allowed to perform operations.
Operation personnel must wear ESD gloves.
The ECC500 monitoring platform consists of the main control module, basic I/O module, and
GPRS module (optional). To replace a faulty GPRS module, perform the following steps:

Replace the ECC500 if the main control module or basic I/O module is faulty. For details, see 3.2
Installation.
Procedure
Step 1 Remove the cables from a faulty module one by one. During the removal, insulate the cables
and stamp labels on them in a timely manner.
Step 2 Loosen the captive screws on the faulty module anti-clockwise using the M3 screwdriver.
Step 3 Pull out the faulty module by the handle, as shown in Figure 5-1.
Figure 5-1 Procedure for pulling out a faulty module

Step 4 Hold the handle of a new module, and insert the module into its slot in the ECC500 subrack.
Step 5 Push the new module until its front panel is level with that of the ECC500 subrack.
Step 6 Fold the handle.
Step 7 Tighten the captive screws clockwise using the M3 screwdriver, as shown in Figure 5-2.
ECC500(Data center)

45

Figure 5-2 Procedure for installing a new module

Step 8 Connect the cables to the module according to their labels.
----End
5.3 Software Upgrade
Context

During software upgrade, ensure an uninterrupted power supply for the ECC500 and EMS
and proper communication between them.
Obtain the latest software version before the software upgrade. If the software upgrade
fails, the ECC500 runs based on the original software version.
To upgrade ECC500 software, log in to the WebUI by referring to Upgrade.
Procedure
Step 1 Click Browse to select the software to be upgraded, as shown in Figure 5-3.
Figure 5-3 Software upgrade (1)

ECC500(Data center)

46

Step 2 Click Send to send the software to be upgraded to the main control module of the ECC500.
Step 3 After the software is uploaded successfully, it is displayed under Packages to be activated.
Select the software to be upgraded and then click Activate. After the upgrade is successful,
the Selected package has been activated successfully message is displayed, as shown in
Figure 5-4.
Figure 5-4 Software upgrade (2)

----End
ECC500(Data center)
User Mannual 6 Appendix

47

6 Appendix
6.1 Technical Specifications
Table 6-1 lists ECC500 technical specifications.
Table 6-1 ECC technical specifications
Category Item Description
Environment Operating temperature
-40+70
Storage temperature
-45+70
Humidity 5% to 95% RH (non-condensing)
Atmospheric pressure 70-106 kPa
Altitude When the altitude is less than or
equal to 3000 m, the ECC500
works properly.
When the altitude is greater than
3000 m, the temperature
decreases by 1C for each
additional 300 m.
Moisture resistance Damp heat, cyclic: 25-65, 95%
RH, 48 hours
Others Free from explosives, conductive
dust, and corrosive air
Power supply
input
Operating voltage Operating voltage: -40 V DC to
-60 V DC
Rated voltage: -48 V DC
Operating power Rated power: 30 W
EMC Conducted interference Class B
Radiated interference Class B
Electrostatic interference

For the shell: contact
ECC500(Data center)

48

Category Item Description
discharge: 6 kV; air
discharge: 8 kV (criterion
B); the shell has been
powered on before the test

For the conductor in the
signal port: contact discharge:
2 kV (criterion R); the
conductor has been powered
on before the test
Conducted susceptibility 3 V, 0.15-80 MHz (criterion A)
Radiated susceptibility 10 V/m, 80 MHz to 2 GHz
(criterion A)
Surge protection Digital parameter Differential mode: 3 kA ;
common mode: 5 kA
Analog parameter Differential mode: 3 kA ;
common mode: 5 kA
Communication signal Differential mode: 3 kA ;
common mode: 5 kA
DC port -48 V; differential mode: 2 kA;
common mode: 4 kA
Safety - ECC500 components and the
PCB comply with IEC60950-1,
EN60950-1, and GB4943.
Reliability MTBF 100,000 hours
Annual return repair rate < 1%
Life cycle > 10 years (at least three years
promised in actual application)
Water resistance and dustproof
level
Cabinet: IP45 or IP55
Mechanical
parameters
Dimensions (H x W x D) 44.5 mm x 220 mm x 440 mm
Weight 5 kg

6.2 LUI Menu
Table 6-2 describes LUI menu hierarchy and parameters.
ECC500(Data center)

49

Table 6-2 LUI Menu
Main Menu Level-2 Menu Level-3 Menu Level-4
Menu
Default Value
Active Alarm - - - -
Operating
status
Site Summary Neteco Comm
stat
- -
Amb T 1 - -
Amb T 1 - -
Ambient
temperature 2
- -
Amb T 2 - -
Amb T 3 - -
Amb T 3 - -
ECC500 MUS01A_AI_
12
- -
MUS01A_DI_
13
- -
MUS01B-1_AI
_12
- -
MUS01B-1_DI
_13
- -
MUS01B-2_AI
_12
- -
MUS01B-2_DI
_13
- -
MUE03A_DI_
16
- -
MUE03A_AI_
12
- -
FAN Device Address - -
SW Version - -
Device Type - -
Device Status - -
Fan speed - -
Air Outlet T - -
Alarm History - - -
ECC500(Data center)

50

Menu
Default Value
Inventory ECC500 - -
FAN - -
Settings Site Summary U Thres Amb T - 80 degC
L Thres Amb T - -20 degC
U Thres Amb
H
- 100%
L Thres Amb H - 0%
Amb HT 1-3
Thres
- 50 degC
Amb LT 1-3
Thres
- 0 degC
Amb HH 1-3
Thres
- 80%
Amb LH 1-3
Thres
- 10%
LCD Contrast - 5
ECC500 En-MUS01A_
AI_12
- Enable
UMT-MUS01
A_AI_12
- 80
LMT-MUS01A
_AI_12
- -20
UAT-MUS01A
_AI_12
- 50
LAT-MUS01A
_AI_12
- 0
En-MUS01A_
DI_13
- Disable
MUS01A_DI_
13
- Normal Open
En-MUS01B1
2_AI_12
- Disable
UMT-MUS01B
12_AI_12
- 80
LMT-MUS01B
12_AI_12
- -20
ECC500(Data center)

51

Menu
Default Value
UAT-MUS01B
12_AI_1
2UA
- 50
LAT-MUS01B
12_AI_1
2LA
- 0
En-MUS01B-1
2_DI_13
- Disable
MUS01B-1
2_DI_13
- Normal Open
En-MUE03A_
DI_16
- Disable
MUE03A_DI_
16
- Normal Open
En-MUE03A_
DO_12
- Disable
MUE03A_DO_
12
- Normal Open
Door
Alm->DO12
- NO
MUS01A_DI1-
>DO12
- NO
MUS01B1_ID1
2->DO1
- NO
MUS01B2_ID1
->DO2
- NO
MUE03A_DI1-
>DO2
- NO
FAN HT ALM Thres - 68 degC
LT ALM Thres - -20 degC
Comm Para Net Para Network
Mode
IP
IP Address -
Subnet
Mask
-
Gateway -
ECC500(Data center)

52

Menu
Default Value
Server Para NetEco
Main IP
-
NetEco
Backup IP
-
Host Para Host Comm
Addr
-
System Para LCD Language - ENGLISH
Set Date -
Set Time -
Set Time Zone - GMT +08:00
Save As Def
Cfg
- Yes
Restore Def
Cfg
- Yes
Restore Manu
Cfg
- Yes
Logout - Yes
Set Site Name - ECC500
LCD Contrast - 5
Control Site Summary Smoke 1-3
Reset
- -
FAN FAN Reset - -
Quick Setting System Para Set Date - -
Set Time - -
LCD Contrast - -
Comm Para IP Address - -
Subnet Mask - -
Gateway - -
Host Comm
Addr
- -

The LUI menu varies based on configurations. The preceding table is for reference only.
ECC500(Data center)

53

6.3 Acronyms and Abbreviations
A
APN Access point name
C
CAN Controller area network
D
DIP switch Dual in-line package switch
E
ECC Energy control center
ESD Electrostatic discharge
F
FE Fast ethernet
G
GPRS General packet radio service
I
IP Internet Protocol
L
LUI LCD user interface
LCD Liquid Crystal Display
S
SD Secure digital card
SNMP Simple network management protocol

Neteco

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Neteco

Uploaded by

Copyright:

Available Formats

ECC500(Data center)

You might also like
