Outdoor lighting control

system
Based on the technologies
LoRaWAN/NB-loT

AIRBIT Light
Smart city lighting

Automated outer lighting control system AIRBIT LIGHT is a

software and hardware complex allowing to monitor the outdoor
lighting network state, perform diagnostics of the lighting
equipment, and reduce operation costs.

The use of the modern system allows you to make city lighting
operatively controlled and cost effective.
 Main functions of the
system AIRBIT Light

Reduction in Reduction in energy Use Increase of service life of

operating costs consumption in energy servicing the lighting equipment
contracts
Main functions of the system
AIRBIT Light
● Automatic mode of lighting control -
work on schedule with the ability to make necessary corrections;

● Individual or group control of lights: change of luminous power based on:

➔ coordinates of the place of installation with the automatic determination of

the time of sunset and sunrise;
➔ illumination level;
➔ real time;

● Automatic control and diagnostics of the condition of lighting equipment;

● Capability of remote metering of electric power consumption;

● The use of the lighting network for the continual power supply of other
informational systems (advertising structures, video surveillance system,
Wi-Fi network, etc.).

Architecture of AIRBIT Light
Lights with the AIRBIT
lighting controller
Street lights with light AIRBIT
controllers installed maintain
communication with base stations via
wireless networks
How its works
Wireless network LoRaWAN/NB-loT
LoRaWAN/NB-IoT
base station
Base stations provide
communication between light
controllers and cloud service
commands to controllers, and, on the other
Cloud service AIRBIT
Network Server
The link between lights and controlling
application AIRBIT Workspace Light. On
the one hand, the server transmits user's
hand, it, having received data on the state
of lights, displays this state in the
application
Controlling application
AIRBIT Workspace Light
The application is accessible from
any device of the user connected to
the Internet
Housing
Street light control
module AIRBIT Lighting
controller
Backup power
Module supply-
GPS/GLONASS ionistor ● This device is designed for control of
(optionally) luminous flux of lights using
wireless network LoRaWAN/NB-loT
Acsip Compact radio
 module LoRa  ● Control is carried out automatically
combining processo (by schedule/sensor) or manually
r and transceiver by the dispatcher's command;
SX1276
● Ability for lights status tracking
from Semtech
in case of emergency;
Corporation
● The use of any kind of lights,
equipped with drivers with control protocols
Illuminance
DALI;
sensor Zhaga Book 18
standard ● Automatic detection of geographic
coordinates using the GPS/GLONASS system;
 Flexible installation
on the controller

Zhaga book18 specification describes the interface

between LED outdoor lights and control modules
on the light Plug in

Turn
 DATASHEET
AIRBIT Lighting controller

Power supply Sensors

● Supply voltage 24 V;
● Current consumption in active mode -
no more than 60 mA;
● Current consumption in sleep mode -
50 μA;
● Backup power supply - ionistor;
Interfaces
● DALI 1, 2 interface support (up to 64 DALI
lines per controller);
● Connector according to zhaga book 18
Sensors
● Built-in GNSS/GLONASS receiver for automatic
time correction and automatic control of the
light based on the installation site;
● Built-in accelerometer (determination of the
deviation from the vertical of the light pole,
detection of shocks);
● Built-in luminance sensor
 DATASHEET
AIRBIT Lighting controller

Configuring LoRaWAN radio communication

● By commands through the network
LoRaWAN/NB-IoT;
● Via a radio channel using a special
USB dongle and Windows application
(for LoRaWAN version)
● and using a mobile application via Bluetooth for
NB-IoT version
● Data transmission standard - LoRaWAN v 1.0.3/LTE Cat NB1;
● Antenna type - built-in;
● Device class -  LoRaWAN - C;
● LoRaWAN frequency plans supported - EU868, RU864, AU915, CN 779,
KR 920, IN865, US915;
● Frequency plans NB-IoT supported -
B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/ /B28/B66;
● ADR adaptive data transmission rate support (for LoRaWAN version);
● Transmission rate for NB-IoT - Max. 25.5 kbps (DL)/16.7 kbps (UL)
● Support for multicast, remote multicast in accordance with
the LoRaWAN Alliance specification;
● Support for automatic time synchronization in accordance with
the LoRaWAN Alliance specification;
● Public/private network support
 Page of configuration of AIRBIT
Lighting controller
Dashboard

Adding devices: input of Display of packet exchange via Display of current

DevEUI and controller names. Selecting a the LoRaWAN/NB-IoT network controller state parameters: coordinates,
controller for configuring. in CBOR format in real time. time, dimming profile, etc.
 Page of configuration of AIRBIT
Lighting controller
Changing the current settings

Requesting the current parameters from the controller and

sending a packet with new settings:

● Geographical coordinates;

● The interval for sending regular packets;

● Time synchronization interval;

● The interval for sending a data packet with a request

for confirmations in the network;

● The interval of DALI line scanning, etc;

 Page of configuration of AIRBIT
Lighting controller
Dimming profiles

By time of day By sunset/sunrise By illumination level

Linking lighting operation
to a fixed time interval.
For example, switching lights to standby lighting
at night.
For such purposes, it is possible to specify an
arbitrary time interval and brightness level that
the lights must maintain during this interval.
Each controller (light) knows its The operating mode of the lights, depending
coordinates and can calculate the on the level of natural sunlight outside.
calendar of sunrises and sunsets from Ability to specify what brightness the lights
them. should maintain at different intensities of
The only thing then to be done is to to sunlight
indicate at what moment the light should
begin to increase its brightness and when
this brightness should reach its maximum
value. For sunrise, on the contrary, the
order of dimming must be set until the
light is completely turned off.
 Application AIRBIT Workspace
Light
Control interface

The dispatcher interface contains the following main

screens in accordance with the system hierarchy:

● Monitoring of the entire lighting system;

● State of the lighting system of district importance;
● The state of the selected lighting line (group of
lights);
● State of individual light

The dispatcher's workstation allows you to quickly and

conveniently:

● assess the condition of the lighting system;

● identify the places of the accident;
● to carry out operational control;
● configure the system
 Application AIRBIT Workspace
Light
Control interface

Basic data on a light

Group membership, date of installation, warranty

period, power, etc.
 Application AIRBIT Workspace
Light
Control interface

Diagnostics of lights and emergencies

Monitoring of the state of a light

controller and the light itself.
This allows you to detect the problem in time and quickly fix
it.
In this case, the system message not only informs the user
about the presence of a failure, but also indicates its cause.
 Application AIRBIT Workspace
Light
Control interface

Configuring the operating mode of a light/group of

lights

Individual or group control

Changing the power level of the light:

● based on coordinates of the place of installation

with the automatic determination of the time of
sunset and sunrise;
● based on the illuminance level;
● based on real time

Using the control application, the user has the ability to

switch between modes “Auto” and “Manual”
 Application AIRBIT Workspace
Light
Control interface

● Monitoring on the map of the current state of

the lights, their mode of operation, the presence
of errors or accidents makes it possible to
simplify the operation of lighting networks, and
facilitate the work of dispatchers and service
teams

● Lights can be controlled directly from the city

map, without having to go to the pages of
individual facilities

● Smart clustering allows you to assess the

presence of problems at the level of the street,
district, and city
The effects of the introduction of the
system AIRBIT Workspace Light
Control interface

Real savings Safety

● Reducing energy costs by optimizing the ● Increasing the level of safety of the
operating time of lighting sources; population and road users;
● Possibility of effective control and metering ● Reduced light pollution
of electricity consumption

Service improvement
● Reduced operating and maintenance costs Increased service life
for outdoor lighting lines of lighting equipment
● Effective planning of emergency teams and reducing the frequency of its replacement
