Techical catalogue

RCAH heat recovery unit

Thank you for trust in Hitecsa product. From our company we are offering to the market, for more than
30 years, an extended range of specialized units for air conditioning installations. Our approach is based
in efficiency, flexibility, manageability and practical solutions. It has built a hallmark of our product
catalogue.

The versatility of our factory allows us to contribute solutions almost customitzables in each project,
searching a solution for every problem that arises in design and implementation of air conditioning
installations.

From Hiplus Aire Acondicionado’s team, once more thank you very much

07.13 Ref. 207375 rev.100 1

INDEX

General specifications ................................................................................................ pag. 3

Techincal specifications............................................................................................... pag. 4

Dimensions.................................................................................................................. pag. 6

Sound levels ................................................................................................................ pag. 8

Air flows and efficency filters...................................................................................... pag. 9

Accesories.................................................................................................................... pag. 16

07.13 Ref. 207375 rev.100 2

GENERAL SPECIFICATIONS

Fully removable 20 mm of thickness of sandwich pannels.They are compose of galvanized steel inside or
outside sandwich panels, easy to open. Units are precoated galvanized sheet metal frame RAL 9002.

The unit is equipped with crossed air-to-air heat recovery with aluminum heat exchanger plates and
supplementary sealing. It has aluminum condensate tray with 2 outlet tubes that covers all of
heating/cooling components.
3
Contain mineral wool heat and sound insulation with 20 mm of thickness, density 40 kg/m and fire
reaction A1.

Supply and exhaust fans are centrifugal double inlet forward curved and a multispeed electric motor
directly coupled to the turbine . The unit is completed with electric box IP 56 for electrical connection of
each fans.

It has some filters of efficiency G4, easily removable.

07.13 Ref. 207375 rev.100 3

TECHNICAL SPECIFICATIONS
5 10 20 30
Capacities
Max 0.50 0.90 1.60 2.90
Recovery cooling
Med kW 0.30 0.80 1.30 2.40
capacity
Min 0.20 0.80 1.00 2.00
Max 50.8 48.9 43.5 48.2
Recovery cooling
Med % 53.2 49.5 44.8 49.5
efficiency (2)
Min 55.4 50.2 46.3 50.9
Supply temperature. Min 29.0 29.1 29.4 29.1
Cooling (2) Med ºC 28.8 29.0 29.3 29.0
Min 28.7 29.0 29.2 28.9
Max 2.40 4.70 8.30 14.3
Recovery heating
Med kW 1.70 4.30 6.40 12.0
capacity
Min 1.20 3.90 4.90 10.0
Max 58.7 56.4 50.0 53.8
Recovery heating
Med % 61.6 57.2 51.7 55.5
efficiency (1)
Min 64.3 58.0 53.5 57.1
Supply temperature. Max 8.3 7.8 6.3 7.2
Heating (1) Med ºC 9.0 8.0 6.7 7.6
Min 9.6 8.2 7.1 8.0

Fan
Speed fan nº 3 3 3 3
3
Fan supply W/(m /s) 1019 986 1166 1143
Max 500 1000 2000 3200
3
Air flow Med m /h 330 900 1500 2600
Min 220 800 1100 2100
Max 155 125 130 160
External Static
Med Pa 100 105 115 150
Pressure
Min 45 80 80 105

Electric Data
Electric Supply V-Ph-Hz 230-1-50
Power supply kW 0.17 x 2 0.36 x 2 0.90 x 2 1.40 x 2
Maximum current A 0.70 x 2 1.50 x 2 3.90 x 2 5.70 x 2

Sound Levels
Max 51 52 58 59
Sound pressure Med dB(A) 50 49 54 53
Min 44 45 42 51

(1) Outside air temperature –5°C (80% RH), room air temperature 20°C (50% RH)
(2) Outside air temperature 32°C (50% RH), room air temperature 26°C (50% RH)

07.13 Ref. 207375 rev.100 4

TECHNICAL SPECIFICATIONS

40 50 60
Capacities
Max 4.00 4.40 5.20
Recovery cooling
Med kW - - -
capacity
Min 3.10 3.60 4.50
Max 48.8 46.7 46.1
Recovery cooling
Med % - - -
efficiency (2)
Min 50.8 47.9 47.1
Min 29.1 29.2 29.2
Supply temperature.
Med ºC - - -
Cooling (2)
Min 29.0 29.1 29.2
Max 19.5 22.4 26.5
Recovery heating
Med kW - - -
capacity
Min 15.1 18.4 22.6
Max 54.6 53.8 53.1
Recovery heating
Med % - - -
efficiency (1)
Min 56.9 55.3 54.3
Max 7.4 7.2 7.1
Supply temperature.
Med ºC - - -
Heating (1)
Min 7.9 7.5 7.3

Fan
Speed fan nº 2 2 2
3
Fan supply W/(m /s) 1213 1428 1594
Max 4300 5000 6000
3
Air flow Med m /h - - -
Min 3200 4000 5000
Max 180 99 188
External Static
Med Pa - - -
Pressure
Min 110 139 208

Electric Data
Power supply V-Ph-Hz 400-3+N-50
Maximum power
kW 1.89 x 2 7.23 7.73
input
Maximum current A 3.30 x 2 11.2 10.8

Sound Levels
Max 62 64 64
Sound pressure Med dB(A) - - -
Min 55 59 62

(1) Outside air temperature –5°C (80% RH), room air temperature 20°C (50% RH)
(2) Outside air temperature 32°C (50% RH), room air temperature 26°C (50% RH)

07.13 Ref. 207375 rev.100 5

 DIMENSIONS

Electrical connection
E Condensate discharge

M
E90 M90

Electrical connection

R
A

A90 R90

Model 5 10 20 30 40
A mm 750 900 1000 1300 1400
B mm 750 900 1000 1300 1400
C mm 295 410 470 530 705
D mm 200 315 355 450 500
E mm 145 205 235 265 352
F mm 202 240 265 340 365
Weight kg 41 68 99 155 235

Condensate discharge Inch 2 x 1/2" F 2 x 1/2" F 2 x 1/2" F 2 x 1/2" F 2 x 1/2" F

07.13 Ref. 207375 rev.100 6

 DIMENSIONS
By-pass

BY-PASS

Model 50 60

A (mm) 1700 1900

B (mm) 1350 1450

C (mm) 705 750

D (mm) 480 530

Ø (inch) 1” F 1” F

E (mm) 353 (278) 379 (334)

F (mm) 427 (353) 419 (379)

G (mm) 353 379

H (mm) 297 (339) 350 (403)

H1 (mm) 555 615

L (mm) 339 (297) 403 (350)

L1 (mm) 555 615

M (mm) - (101) - (101)

S (mm) 175 200

Weight (kg) 235 273

07.13 Ref. 207375 rev.100 7

 SOUND LEVELS

The following table shows the sound power level (SWL) per octave band and total; It also shows the
sound pressure level (SPL) at 1 m, 5 m and 10 m on supply/exhaust air, return/fresh air and outside the
unit.

Supply./Exhaust. SPL Return / Fresh air SPL Outside SPL

SWL [dB] per octave band [Hz] SWL
Model 1m 5m 10 m 1m 5m 10 m 1m 5m 10 m
63 125 250 500 1000 2000 4000 8000 dB dB(A) dB(A) dB(A) dB(A) dB(A) dB(A) dB(A) dB(A) dB(A) dB(A)
5 78.6 79.4 77.6 69.0 70.4 71.4 66.9 62.2 84 77 63 52 46 60 49 43 51 40 34
10 72.4 78.9 75.9 71.1 72.8 73.7 71.7 69.0 83 79 65 53 48 62 50 45 52 40 35
20 90.7 82.9 90.1 79.4 78.6 79.5 79.3 75.5 94 87 72 61 56 69 58 53 58 47 42
30 103.4 83.2 88.7 78.6 80.0 79.9 77.6 72.6 104 87 72 61 56 69 58 53 59 48 43
40 95.4 89.0 92.5 87.7 81.5 82.6 83.5 79.0 99 91 76 65 60 72 61 56 62 51 46
50 110.0 89.9 93.6 84.2 84.1 84.5 82.8 78.5 110 92 76 66 61 73 63 58 64 54 49

60 111.0 90.9 94.6 85.2 85.1 85.5 83.8 79.5 111 93 77 67 62 74 64 59 65 55 50

07.13 Ref. 207375 rev.100 8

 AIR FLOWS AND HIGH EFFICENCY FILTERS

Units come with filters G4. Filters F6, F7, F8 can be mounted together to increase the filtering efficiency.
The following table shows the filter pressure drop at nominal airflow.

Filter Pressure Drop Thickness Efficiency class 5 10 20 30 40 50 60

F6 Pa 48 M6 78 108 149 191 127 175 179

F7 Pa 48 F7 117 162 224 287 190 205 185

F8 Pa 48 F8 143 198 274 350 232 248 225

07.13 Ref. 207375 rev.100 9

 AIR FLOWS AND HIGH EFFICIENCY FILTERS

RCAH 5
Pressure drop [Pa]

3
Air flow [m /h]

400

350

300
Available pressure [Pa]

250

200

150

100

50
MIN MED MAX
0
0 100 200 300 400 500 600 700 800
3
Airflow [m /h]

07.13 Ref. 207375 rev.100 10

 AIR FLOWS AND HIGH EFFICIENCY FILTERS

RCAH 10
Pressure drop [Pa]

3
Air flow [m /h]

300

250
Available Pressure [Pa]

200

150

100

50
MED MAX
MIN
0
400 600 800 1000 1200 1400 1600 1800

Air flow [m3/h]

07.13 Ref. 207375 rev.100 11

 AIR FLOWS AND HIGH EFFICIENCY FILTERS

RCAH 20
carga
Pressurededrop
Pérdida [Pa]
[Pa]

3
Airflow [m /h]

400

350

300
Available pressure [Pa]

250

200

150

100

50
MIN MED MAX
0
500 1000 1500 2000 2500 3000
3
Airflow [m /h]

07.13 Ref. 207375 rev.100 12

 AIR FLOWS AND HIGH EFFICENCY FILTERS

RCAH 30
Pressure drop [Pa]

3
Airflow [m /h]

600

500
Available pressure [Pa]

400

300

200

100
MIN MED MAX
0
800 1300 1800 2300 2800 3300 3800 4300 4800

Air flow [m3/h]

07.13 Ref. 207375 rev.100 13

 AIR FLOWS AND HIGH EFFICIENCY FILTERS

RCAH 40
Pressure Drop [Pa]

3
Air flow [m /h]

450
400
350
Available Pressure[Pa]

300
250
200
150
100
50
MIN MAX
0
2000 2500 3000 3500 4000 4500 5000 5500
Airflow [m3/h]

07.13 Ref. 207375 rev.100 14

 AIR FLOWS AND HIGH EFFICIENCY FILTERS

RCAH 50
Available Pressure [Pa]

3
Airflow [m /h]

RCAH 60
Available Pressure [Pa]

Airflow [m3/h]

07.13 Ref. 207375 rev.100 15

ACCESORIES

ELECTRIC HEATER

It is an external module situated in the water inlet duct, as preheating or postheating or extraction
circuit as antifreeze system.

It is created of resistive elements combined to provide the power that you can see in the table below.
Electrical heater is completed with a thermical relay and a security thermostat. Power supply and line
protection has to be carried out by an installer.

Specification table

Model Speed fan 5 10 20 30 40 50 60

Heating capacity kW 2.00 4.50 9.00 12.0 18.0 18 24

Pressure drop Max Pa 5 5 13 12 9 11 13

Power supply V-Ph-Hz 230-1-50 400-3-50

Current input A 8.70 6.50 13.0 17.3 26.0 26.0 34.6

07.13 Ref. 207375 rev.100 16

 ACCESORIES

COOLING MODULE / OUTDOOR HEATING

Cooling module / Outdoor heating is a separate module, internally insulated, in which is located the
water coil with which heat exchange occurs fresh air. It can be use as cooling or heating. The condensed
outlet, ½ “ of gaz, is located at the bottom and through the stainless steel tray.

RCAH 5-40 RCAH 50-60

Model 5 10 20 30 40 50 60

Total cooling capacity (1) kW 3.10 6.00 11.2 19.2 25.4 21.6 21.9

Sensible cooling capacity (1) kW 1.86 3.60 6.72 11.5 15.2 - -

Supply temperature (1) °C 17.9 18.4 19.4 18.7 18.8 - -

Heating capacity (2) kW 6.30 12.2 23.7 37.9 53.9 - -

Supply temperature (2) °C 44.5 43.0 40.1 41.2 43.4 - -

Water flow rate m3/h 0.53 1.03 1.91 3.29 4.37 - -

Water pressure drop kPa 11 17 11 29 22 16 15

Air pressure drop Pa 63 45 87 84 50 66 69

P mm 375 450 450 615 675 675 725

L mm 400 700 700 700 850 850 900

H mm 270 410 470 490 630 630 755

D mm 200 315 355 450 500 - -

Weight kg 9 20 21 25 40 - -

(1) Outdoor air temperature –5°C (80% RH), room air temperature 20°C (50% RH)
(2) Outdoor air temperature 32°C (50% RH), room air temperature 26°C (50% RH)

07.13 Ref. 207375 rev.100 17

ACCESORIES

WATER HEATING COIL

For models RCAH 50 and RCAH 60, water heating coil can be located inside unit, after cross-flow heat
exchanger, allowing raising the temperature of air supply. This accessory is not valid for cooling mode.

3 WAY VALVE WITH ACTUATOR

It consists of a 3-way valve with actuator 230V-1ph-50Hz with 3 point modulation.

BY-PASS

It allows create an alternative duct for channeling the air does not pass through the cross-flow
exchanger providing a flow for free-cooling and free-heating. This optional is supplied with spring return
actuator and powered 230V.1.50 Hz.

Model 5 10 20 30 40 50 60
High mm 75 75 100 150 175 175 200

CIRCULAR DUCT CONNECTION

It allows the connection between the unit and duct network with circular joints or ducts; it can be
installed both on the air inlets and outlets. Only for units RCAH 50 and RCAH 60

Model 50 60

A mm 354 378

B mm 652 694

C mm 352.5 377.5

D mm 556 626

07.13 Ref. 207375 rev.100 18

ACCESORIOS
FLEXIBLE CONNECTION

It allows flexible connection between unit and air duct, to reduce to cut off the transmission of the
mechanical vibrations due to the mobile parts of the unit.

OUTDOOR KIT INSTALLATION

It is indispensable when unit will be installed outdoor. Nevertheless, is recommended install the unit in a
sheltered, inside building and easy access.

STEP FAN SPEED CONTROL

Suitable for wall installation, it allows to select one of the possible fan speeds.
On the control panel there are :

- ON/OFF switch
- 3 position speed switch.

BASIC ELECTRONIC CONTROL

Suitable to wall installation, it allows control local temperature (on/off control) both summer and winter
and select ventilation speed. The temperature sensor can be located remotely, if is necessary.

- ON-OFF and summer/winter change

- Fan speed selector
- Temperature selector
- ON-OFF electric heater

MULTIFUNCTION ELECTRONIC CONTROL

Suitable to units equipped with by-pass system for free-cooling or free-heating.

- Automatic / Manual speed fan selection

- Cooling valve management
- Heating valve management
- On-Off Electric heater management
- Post ventilation
- Free-cooling damper management
- Alarm management

Probe error

Overheating in electrical resistance

Clogged filter
- Weekly schedule
- Remote ON-OFF
- Remote Display with indoor probe
- MODBUS

07.13 Ref. 207375 rev.100 19

ACCESORIES

ANTIFREEZE THERMOSTAT

It can be used in all the applications where is needed check temperature in a determinate point of the
system it does not fall down below a predeterminate security value.

FILTERS F6-F7-F8

The unit is provided with filters G4. These filters can combine with filters F (F6, F7 or F8). All of them are
removables.

07.13 Ref. 207375 rev.100 20
