Light
Fun Experiments
with Optics
MARÍA VIÑAS PEÑA
Editor
ISBN: 978-84-00-10789-5
e-ISBN: 978-84-00-10790-1
NIPO: 833-21-043-3
e-NIPO: 833-21-044-9
DL: M-11258-2021
Published by
SPIE
P.O. Box 10
Bellingham, Washington 98227-0010 USA
Phone: +1 360.676.3290
Fax: +1 360.647.1445
Email: books@spie.org
Web: http://spie.org
All rights reserved. No part of this publication may be reproduced or distributed in any form or by any means
without written permission of the publisher.
The content of this book reflects the work and thought of the authors. Every effort has been made
to publish reliable and accurate information herein, but the publisher is not responsible for the validity of
the information or for any outcomes resulting from reliance thereon.
SAFETY NOTE: All of the experiments in this book are intended to be performed under adult supervision.
Appropriate and reasonable caution is required at all times, and the recommendations in the activities in
this book cannot replace sound judgment. The authors and publisher disclaim all liability for any damage,
mishap, or injury that may occur from engaging in the activities featured in this book.
Introduction ix
Acknowledgments xi
1. What is light? 1
3. Optical instruments 61
Glossary 225
Index 233
I
t is my great pleasure to write these lines as the preface for the book Discovering Light:
Fun Experiments with Optics, by Maria Viñas, project coordinator, with the collabora-
tion of 14 co-authors. The book was written first in Spanish with the title Descubriendo
la luz: Experimentos divertidos de óptica and published in 2018 by the CSIC (Consejo
Superior de Investigaciones Cientificas, Spanish National Research Council) and the
publisher Catarata Books. This book has had a great success in Spain, and I hope that this
edition in English will also be very successful worldwide. The group of co-authors had
more than ten years of experience working together before the publication of this book.
The authors met as young researchers at the Institute of Optics (IO-CSIC), and they were
members at some point of the IO-CSIC OSA student chapter. They organized very valuable
activities and experiments for students and also for the public in general.
The book that you have in your hands will help you to love optics, to understand what
light is, and to play with light. It is organised by topics of great interest, going from the fun-
damental concept of light, as wave and as particle (photon), to light-based technologies.
Some chapters in this book are indeed new and necessary for broadening the field that the
teachers show to students, such as the human eye: a biological photographic camera, light
in nature, and many easy and original experiments included in the book. All chapters have
the same structure: first, an introduction to the fundamentals of optics that teachers and
students should review for the specific topic under study; secondly, a description of the
experiments with questions about what the students have learned. At the end of the book,
the authors give the answers to these questions in an extended and open way that will
help teachers and students to deepen their knowledge of a particular field.
There is a need for books and courses that might help teachers to introduce experi-
ments in optics in their laboratories with students. The experiments in this book are very
inspiring and amusing; they open the way to discuss with the students the things that they
see in real life, and the students can be drawn to study more deeply the fundamentals. For
young people, experiments playing with light are magical. It is important in the education
process to open the world to students for exploration and to help children to find their
passion for discovering things.
The collaboration of the two major optics societies—SPIE (The international Society
for Optics and Photonics) and OSA (The Optical Society)—with the CSIC in this English
version of this book makes this project very attractive because it will reach a very wide
audience. This book can inspire the members of the student chapters of both societies to
organise outreach activities with students and adults for learning optics in an amusing way.
vii
María J. Yzuel1
1
SPIE 2009 President
Fellow Member of OSA, SPIE, IOP, and EOS
Honorary Member of SEDOPTICA and RSEF
Professor Emeritus, Universitat Autònoma de Barcelona, Spain
Chair of the Spanish Committee for the International Day of Light
viii Preface
L
ight is an element that draws together many areas of human knowledge (physics,
chemistry, biology, astronomy, engineering, art, etc.); moreover, optical phenomena
and the technologies based on them are widespread in our daily lives. However, it can
be difficult to understand or explain these phenomena.
What is light? Where are optics and photonics present in our lives? What lies behind
different optical phenomena? What is an optical instrument? How does the eye resem-
ble an optical instrument? How can we explain human vision? What are everyday optical
technologies based on? Where is optics found in nature? The book you are holding, written
by a group of young scientists, attempts to answer these questions and many more, and
help you to get to know the exciting world of optics and photonics.
Our aim is to look at optics from all sides, covering both basic phenomena occurring in
nature and the very latest applications and technologies. Although we want to reach out
to anyone interested in science, we have taken care to include experiments and explana-
tions covering the light-related topics on the syllabus for high school level. Our experience
in performing demonstrations at primary and secondary schools, as well as the general
public, has taught us that the best way to reach our goals is through experimentation and
interpretation of results. We have developed a set of exercise cards to help you complete
the different experiments step by step (color-coded by level of complexity), after which
the challenge is to show what you have learned. We provide help to fully understand the
experiments, with an introduction to all the necessary concepts at the beginning of each
chapter, as well as plenty of interesting facts.
Chapter 1 looks at the physical properties of light, how it is described, how it travels
and how it behaves on interaction with different materials. Some of the key words in this
chapter are wave, photon, reflection, refraction, diffraction and interference.
In Chapter 2, we explore the different sources and detectors of light that are so com-
monplace in our daily lives. It includes experiments using extraordinary light emitters like
lasers and building “invisible” light detectors.
Chapter 3 shows how you can use simple optical elements such as lenses, mirrors and
prisms to build different optical instruments. We will focus on understanding how light
travels and images are formed using these items and how we can manipulate light using
optical instruments such as cameras, microscopes and telescopes.
ix
The Authors
x Introduction
T
he project “Discovering Light” and the book you are holding in your hands would
have never been possible without the generous support of a large group of collabora-
tors and institutions.
The original edition of the book in Spanish, Descubriendo la luz: Experimentos divertidos
de Óptica, was published in 2018 by the Spanish National Research Council (CSIC). It was
an immediate success among both the general public and high-school teachers. The project
was the result of the collaborative work of former and current members that were part of the
young researchers association IOSA, an OSA student chapter of the Institute of Optics of the
CSIC (IO-CSIC). This team of tireless scientific disseminators has more than ten years of expe-
rience in outreach of science and optics. It is also worth mentioning all the feedback received
from students, teachers and scientific disseminators we have met over the years who were the
main reason for writing this book. We wanted to create and share with them a tool to make
optics fun at class, hoping it will help you approach optics in a more natural way.
We give thanks to our friends, collaborators, IO-CSIC peers, our families (young and
old) and all the members of the public we have met. In particular, Daniel Pascual, IO-CSIC
engineer, and the person we have always been able to turn to whenever one of our projects
comes up against a technical hitch. Carmen Guerrero, from the CSIC Scientific Culture
department, who always supports the challenging ideas we put before her and with whom
we have been working for more than five years on our dissemination projects, such as
Ciudad Ciencia. Dr. Lourdes Llorente, founding member of IOSA and reviewer of many
chapters of this book. Prof. Susana Marcos, Professor of Research at CSIC and IOSA super-
visor, our institutional and motivational support. We have learned a lot from you all.
The English version of the project is the result of a fruitful collaboration between the
International Society for Optics and Photonics (SPIE), the Optical Society (OSA) and the
Spanish National Research Council (CSIC). These three institutions are willing to expand
knowledge in optics and photonics among the youngest audience. Thank you for trusting
that our project might be able to accomplish that goal. No doubt, Prof. María Yzuel and
Prof. Susana Marcos have been significant promoters of this English version, looking at the
international audience of the optics and photonics community. We cannot forget the input
from Jennifer Mehltretter (OSA) and Patrick Franzen (SPIE), whose invaluable feedback
helped navigate the negotiation process between institutions. Finally, we want to thank
Pura Fernández, head of the CSIC Publications Office, for her generous support and help
through the publication process, which has allowed the international jump of our book.
xi
T
he safe use of a laser requires the knowledge and enforcement of a series of rules
that go beyond the usual precautions to be used for any electrical or mechanical
equipment. Low-power lasers (pointers) are used for the experiments in this book.
These are designed to be safe, provided that the laser light does not directly illuminate
the eyes. In general, pointers are labeled with the maximum output power and can con-
sequently be classified into four types. The recommended laser pointers for our experi-
ments are in classes 1 and 2 (low power), regardless of color.
• Find the label showing the operating power of the laser pointer you are going to use,
to assess the potential risk. Avoid using lasers with a power of more than 5 mW.
• Never look directly at the laser beam.
• Before switching on the laser pointer, calculate the approximate route of the beam to
prevent any reflections into the eyes.
• Never open the casing of the laser pointer. This can transform a Class-2 laser into a
higher-category one, increasing the risk of accident.
A warning label about the risk of working with laser radiation is included along-
side all experiments requiring the use of a laser source.
xiii
What is light?
H
ave you ever tried to define light? If so, your definition is probably related to
vision, the ability to see things. The Merriam-Webster English dictionary defines
light as “something that makes vision possible”. However, the definition of the
“nature of light” is a complex term already discussed by philosophers of Ancient Greece.
In the 17th century, the debate on the matter focused on whether light was a particle or a
wave, based on the different properties of light that had been gradually discovered over
time. Isaac Newton (1642−1727) was a defender of the corpuscular theory of light, which
considered light to be formed by particles, i.e., small pieces of matter, like dust or grains
of sand. He was the author of Opticks (1706), the front cover of which appears in Fig. 1.1.
Christian Huygens (1629–1695), on the other hand, supported the theory that light is a
wave. These are two completely different definitions of the same physical concept.
A range of experiments were developed to attempt to clarify this dilemma, but it was only
until 1900 when Max Planck (1858-1947) introduced the basis of a theory that would go on to
revolutionize scientific thinking, marking the beginning of modern physics: quantum theory.
Developed during the 20th century thanks to advances made by scientists such as Niels
Bohr, Born, Heisenberg, Schrödinger, Pauli, Dirac, Einstein or de Broglie, quantum theory
clarified that light is neither a particle nor a wave, but that it has a dual nature: it behaves
like a wave as it spreads but like a particle in its interactions with matter. In this book, we
will specify where necessary whether light behaves as a particle or as a wave, although in
most cases we refer to rays of light, which always represent the direction of propagation of
light.
What is a wave?
A wave is a disturbance that transmits energy from one point of a medium to another,
without the medium itself moving noticeably. We have all seen how throwing a stone into
a pond causes ripples on the flat surface of the water, which spreads in all directions in the
form of waves. The wave moves via small oscillations or vibrations of the particles mak-
ing up the medium, which always return to the same position they were in when the wave
reached them: just as water in a pond rises and falls as a wave moves across it but does not
move along with it.
Light is a specific kind of wave known as an electromagnetic wave because of the type of
energy it carries. Figure 1.2 shows a wave in relation to distance. In other words, it shows
the wave as if taking a photograph as it spreads along the horizontal axis, observing mini-
mum values (“valleys”) and maximum values (“peaks”) on the vertical axis. The vertical
distance from the horizontal axis to the top of the crest is known as the amplitude of the
c = λ/Τ=λ· ν.
One of the reasons why doubt was cast over the wave nature of light was precisely because
of the way it behaves in a vacuum: if a wave requires the oscillation of material particles
in order to propagate, like water in a pond when you throw in a stone, or molecules of
air in the case of sound waves, how then could light waves propagate in vacuum? The
answer is that electromagnetic waves propagate via the oscillation of their electrical and
magnetic fields, hence their name, rather than via a mechanical oscillation, which requires
the movement of matter. A static electrical charge (an electron) creates an electrical field
around itself that “repels” charges of the same sign and “attracts” charges of a different
sign. The electrical field created by that electrical charge does not require matter in order
to propagate. When the charge oscillates, the electrical field also oscillates. That variation
(disturbance) of the electrical field also affects the charges around it, i.e., that disturbance
will propagate through space. This is the reason why we can perceive the light emanating
from the stars, as it can travel through the vacuum of outer space, but their sounds cannot
reach us, as sound waves require material particles in order to propagate.
Finally, since the early 19th century, thanks to the discoveries of Ørsted, Ampère,
Biot and Savart, we know that the variation in the electrical field causes a change in the
magnetic field, and vice versa. The propagation of electromagnetic waves, with their
corresponding electrical and magnetic fields, was described by James Clerk Maxwell
(1831-1879) through his four famous equations.
Figure 1.3 EM light spectrum. On the left, waves with shorter frequency (longer wavelengths), and on the right, waves
with greater frequencies (shorter wavelengths).
Source: Adapted from Wikimedia Commons.
Figure 1.4 Rays of sunlight travelling in straight lines through the leaves of trees.
Photograph: in house.
What is reflection?
When a ray of light meets the boundary between two different media, part of that light
changes direction, returning to the first medium, at the same angle (angle of reflection) as
the incident light (angle of incidence), as shown in Figure 1.5. This phenomenon is known
as reflection. Not all materials behave in the same way: for example, metals reflect practi-
cally all the incident light (which is why they are used to make mirrors), while transparent
materials reflect a lot less light (e.g., the glass in a shop window).
Figure. 1.5 Example of reflection in nature. The River Tormes flowing through Salamanca.
Photograph: Warein Holgado.
What is refraction?
Refraction is the change in the speed of light
that occurs when it travels through a medium
other than a vacuum. A consequence of this
change in speed is seen when light meets a
surface at an angle other than zero (i.e., in
a direction other than the normal). In these
conditions, the light changes direction when
it meets the second medium. An effect of
this diversion of refracted rays is that the
image of an object submerged in two differ-
ent media will have different characteristics
depending on the medium in which each Figure 1.6 Example of how a difference in the
part of the object is submerged. One exam- refraction index causes a diversion of light.
ple of this phenomenon is a pencil in a glass Photograph: in house.
of water; it looks like the pencil is broken
because the rays complete the image in a different position, depending on the refractive
index of the medium they are passing through—air or water—as shown in Figure 1.6.
Refraction also occurs when light passes through layers of air at different temperatures,
which affects the refractive index (the cause of mirages, for example).
The phenomenon of refraction, illustrated in Figure 1.7, is described mathematically
using a trigonometric equation known as Snell’s law, which relates the refractive index of
the material through which the ray of light is travelling (n1) and the angle of incidence (θ1)
to the index (n2) and angle (θ2) of the material where the ray is refracted:
sin (θ1) n2
n1 sin (θ1) = n2 sin (θ2) ↔ = =
sin (θ2) n1
Snell’s law tells us that refracted light bends in proportion to the difference between the
indices of refraction that it encounters along the way (see Experiment 1.1):
• When light passes from a material with a lower refractive index to one with a higher
refractive index, such as, for example, from air to water, the ray of light is refracted
at a smaller angle than the angle of incidence (Figure 1.7, left), i.e., the refracted light
bends away from the normal.
• However, when light passes from a larger index to a smaller one, e.g., from water to
air, the ray of light bends at a greater angle than the angle of incidence (Figure 1.7,
center), i.e., the refracted light bends towards the normal.
• In this case, as the angle of incidence increases, a point is reached in which the light is
not refracted, but travels parallel to the surface (angle of refraction = 90°). This angle of
incidence, the point at which for the first time there is no refracted beam, is called the
critical angle, θ1 and it depends on the index of refraction of the media: sin(θcrit) = n2/n1.
For example, the value of the critical angle for water and air is
(
θcrit = arcsin
1
(= 37°
1.33
For incident light with an angle greater than the critical angle, there is total reflection
on the surface of the material: there is no refracted light; it is all reflected. For smaller
angles of incidence, only part of the light is reflected (and part is refracted).
• As we have already mentioned, where light is travelling perpendicular (normal) to the
surface (zero angle of incidence), it will not bend.
c
cmaterial =
nmaterial
What is dispersion?
We have seen how the refractive index depends on the properties of the material. However, we
have not yet mentioned that it also depends on the wavelength of the incident light: the shorter
the wavelength is, the greater the refraction. So, the index of refraction increases as wavelength
decreases, which, if we apply Snell’s law, means that shorter wavelengths (such as those cor-
responding to blue light) are refracted at a greater angle than longer wavelengths (the color red
at the opposite end of the visible spectrum). This phenomenon is known as chromatic disper-
sion, and it is responsible for the rainbow effect we see when white light (the combination of
all wavelengths on the visible spectrum) diagonally passes through drops of water or when a
beam of white light passes through a prism, as shown in Figure 1.8 (see Experiment 1.2).
Interference
Although you may not have realized, you are bound to have seen at one time or another an
interference pattern: typically, this is a series of stripes, sometimes colored (illuminated with
white light) or in a single color (illuminated with a laser), alternating bright and dark stripes.
Does that sound familiar? You have surely seen something similar on the surface of soap
bubbles or patches of oil on a wet road. These stripes are caused by light wave interference.
Interference takes place when two or more electromagnetic waves overlap (are at the
same place at the same time), giving rise to a new wave, which is the algebraic sum (con-
sidering the sign) of the overlapping wave. However, we do not see stripes every time
light hits the surface, because specific conditions also need to be met, e.g., the overlapping
waves must have the same wavelength and vibrate in the same direction.
The brightest stripes seen in the pattern, regardless of color, are called interference
maxima and appear when the two overlapping waves coincide at their highest (crests) and
lowest points (troughs), forming a new wave with an amplitude equal to the sum of the
amplitudes of the initial waves. In this case, the two waves are said to be in phase, and
they give rise to a constructive interference (Figure 1.10, left).
Figure 1.11 Aerial view of the Virgo interferometer near Pisa, Italy, showing the Mode Cleaner, the main building, the 3-km
western arm and the beginning of the northern arm.
Source: The Virgo Collaboration, Wikimedia Commons.
Diffraction
So far, we have talked about how light travels in straight lines. However, in certain circum-
stances, light can “go around” the edge of objects, travelling beyond obstacles in its path.
This property is called diffraction, and it is an exclusive property of waves that allow us,
for example, in the case of sound waves, to hear people in another room despite not being
right outside the door; it is also the reason why in photographs taken at night, spots of
light (street lamps, stars) appear with spikes of light, generated by diffraction through the
slits in the camera shutter.
Huygens explained this phenomenon in the 17th century, considering that each of the
points making up a wavefront (points in phase) acts as a small emitter of secondary waves
with the same wavelength as the initial wave, forming part of the same wavefront. As the
wave advances, the new wavefronts are formed by the wave envelope.
When a wavefront meets an obstacle, part of the light is blocked (absorbed or reflected),
and part has its propagation altered as it passes along the edges of that object. It is like
a crowd of people that can only pass through a single door. Once everyone has passed
through that door one by one, they can then freely move forward in all directions. This is
known as diffraction, and it occurs in any type of wave (light, sound, etc.) As this wave-
front passes close to the edge of the object, new wavefronts are formed. In the early 18th
century, Fresnel adapted Huygens’ principle to explain that if the waves are coherent, they
overlap after passing the obstacle, creating a pattern of interference that is characteristic of
diffraction. This is what is known as a diffraction pattern, and it is made up of a set of light
and dark stripes, as shown in Figure 1.12 in the case of a small gap. You can see this effect
for yourself by forming a small slit with your fingers and looking at a light background
through them (see Experiment 1.5).
Figure 1.12 Diffraction of a wavefront through a small aperture. On the right, the diffraction pattern (distribution of light
intensity) is formed after passing through the aperture.
Source: Internally created.
Polarization
As we have already mentioned, EM waves are transversal, i.e., the magnetic and electri-
cal fields created by the wave oscillate perpendicular to the direction in which they are
travelling. For simplicity, we will only represent the oscillations of the electric field (E).
Depending on the direction in which the electrical field oscillate, we can define:
• Polarized light: we say that an EM wave is polarized when its electrical vector oscil-
lates in an “orderly” fashion, i.e., not at random. Depending on the shape formed by
the oscillations of the electrical field as the wave moves, we can define different types
of polarized light: in the case of linear polarized light, the electrical field oscillates
along a line, hence the name. To get the idea, it is as if we—representing the oscilla-
tions of the electrical field—were to jump up and down while moving somewhere;
then we could say that “our wave” is vertically polarized. If, however, the person next
to us jumps left to right as they move forward, “their wave” is horizontally polar-
ized. The oscillation (up-down or right-left in this example) is known as the plane
of polarization. The wave that we normally represent, like in Figures 1.2 or 1.3, is
a linear polarized wave that oscillates vertically (at 90°), although in reality there
are linear polarized waves at all possible angles (at 180° (horizontal), at 30°, etc.). In
addition to the linear polarized light, we find other types of polarized light, circular
and elliptic, where the electrical field oscillations change direction as the wave pro-
gresses, creating a circle and an ellipse, respectively. In this book, we are only going to
look at linear polarized light, so where we refer to polarized light, this refers to linear
polarized light.
• Non-polarized light or natural light: the majority of the light around us, coming from
the sun or artificial sources, such as lightbulbs, is non-polarized. This means that
the oscillations of the electrical field are in random directions (although they always
remain perpendicular to the direction of travel) and change as the wave progresses. In
the above example, it is as if we were jumping up, to the right, to the left to the right,
diagonally, downwards, etc., in random order.
Although most of the light around us is non-polarized, there are different physical phe-
nomena that can polarize it:
• Polarization by absorption: just as we can use color filters to select a single wavelength
by absorbing the other wavelengths in white light, we can also use linear polarized fil-
ters (Figure 1.13) that only allow through waves vibrating in a certain direction, what
is known as the transmission axis of the polarizer, absorbing the waves that vibrate in
any other direction. In Experiment 1.7, we will block or let through light using linear
polarizers.
• Polarization by reflection: light reflected on a non-metallic surface, such as water or
glass, is at least partially polarized in the parallel direction to the reflective surface.
Figure 1.14 Polarized sunglasses against a screen. Depending on the angle of the lenses, the polarized light from the screen
can pass through or it is blocked.
Photograph: in house.
Only when light meets the reflective surface at a certain angle, known as Brewster’s
angle (θB) and which depends solely on the refractive indices of the media on either
side of that surface, is polarization total. Because the reflected light is polarized, we
can block it using a polarizer on the axis perpendicular to the reflective surface, so
that we can only see the light that is transmitted (rather than reflected). This is the
optical principle that allows us to see the bottom of a shallow pool using polarized
glasses.
O
n partially cloudy days we can
see how sunlight passes more eas-
ily through the spaces where there
are no clouds or where the clouds are less
dense. In these cases we can see beautiful
scenes where the light streams through dif-
ferent areas in straight lines that we call
rays of light.
In this experiment, we will learn the
importance of the optical properties of
materials in the propagation of light.
You can repeat the experiment with a different initial angle θ1 and use these same equa-
tions to obtain the corresponding θ2, θ3, θ4
Tips
• You can do a similar invisibility experiment by filling the bowl with sunflower oil and
then adding something made from Pyrex glass. The refractive indices are very similar,
so we can make the Pyrex “disappear” by placing it in the oil.
• To see the path of the laser beam more clearly through the alcohol and the water, add
a drop of milk to the water and a drop of ink to the alcohol before pouring them into
the jar.
Related experiments
Experiment 3.4 Micro-lenses: beyond a magnifying glass
Experiment 5.1 Is everything we see real?
MATERIAL
Refraction, electromagnetic • Glass microscope slides (x4) • Black and white card
50 min (+) spectrum, frequency, speed • Hot glue gun or Superglue. • Cylindrical converging lens
of propagation
• Water
• Source of white light
I
n an era of great, revolutionary scientific
discoveries, Isaac Newton was one of the
first to understand why white light broke
down into colours.
In his experiment, Newton used triangu-
lar glass prisms and passed a beam of white
light through one of them. The result was the
formation of a continuous spectrum contain-
ing all the colors from red to violet. Once Figure 1.2.1 Isaac Newton completes his prism
the spectrum of colors had formed, Newton experiment (experimentum crucis) in his room at
proved that a second prism could “join” them Woolsthorpe Manor.
back together to form white light again. This Illustration : Sascha Grushe.
simple experiment proved that prisms do not
add color to light, as many people believed,
but rather broke white light down. In this
experiment, we will reproduce Newton’s
experiment with our own prism, and using a
cylindrical converging lens, we will blend all
the colors back into white, so let’s get to it!
Procedure
1. Using the adhesive (hot glue or super-
glue), join the longest edges of three glass
slides. This should form a triangular
shape from the short end (Figure 1.2.2).
2. To make the base of our prism, use a
fourth slide and stick the triangular
structure to it. It is important that the
base is firmly glued along all its edges. Figure 1.2.2 Image of the four glass slides form-
Apply enough glue and allow to dry for ing a prism.
10 to 20 minutes. Photograph: Eliezer Sánchez González/Cultura Científica (CSIC)/IOSA.
3. Next, fill the prism structure with water.
IMPORTANT: Keep an eye out for leaks! If any water is leaking, the best thing to do
is empty the prism, let it air dry and go over all the edges again with glue. If the water
doesn’t leak out from anywhere, your home-made prism is ready! Now try it out.
Figure 1.2.3 Obtaining the color spectrum with a prism and a source of white light (left), and the colors joined
back together to form white light using a converging lens (right).
Photograph: Eliezer Sánchez González/CulturaCientífica (CSIC)/IOSA.
4. Use a source of white light, preferably in the form of a beam. This can be done by mak-
ing a screen from a black card with a small slit in the center to let the light through.
If you move the screen away from the source of the light, the beam will pass more
evenly through the slit, although it will be less intense. At this point, it is best to do
this experiment in a darkened room.
5. Next, place the prism in the path of the beam and turn it until the light is refracted
into the colors of the rainbow (Figure 1.2.3, left).
6. Use another screen from a white card to see the rainbow. Try different distances until
you achieve a wide, uniform rainbow.
Once you have it, can we turn it back into white light? Let’s try using a converging lens by
placing it between the prism and the screen (Figure 1.2.3, right). Is it possible or not?
Explanation
The amount of light refracted is generally
expressed in terms of its angle of devia-
tion. This angle is the difference between
the angle of incidence of the light on the
prism and the emerging beam. In our case,
when the light passes from air to glass and
then into the water, its speed drops and, as
it leaves the prism, returns to its original Figure 1.2.4 Diagram of the breakdown of light in a prism.
speed. This is mainly due to the difference Source: Internally created.
in refractive index of the material making
up the prism and the medium around it (in this case, air).
Depending on the wavelength travelling through the material, there will be a character-
istic refractive index associated to that wavelength, meaning that colors with shorter wave-
lengths (blue) have a greater refractive index and, therefore, “bend” the angle of incidence
more than colors with a longer wavelength (such as yellow, orange and red). A converging
lens is one where parallel rays hitting one of its sides will converge towards a single point.
When we focus the rays of color emerging from a prism to a single point, the opposite
effect to that of the prism is achieved: the colors are joined together again in one, produc-
ing a ray of white light.
Related experiments
Experiment 2.1 Build your own spectroscope
Experiment 2.5 Beyond the visible: IR radiation
Experiment 5.6 Artificial sunset: the scattering of light in our atmosphere
T
he solar spectrum does not have a spe-
cific color and is called “white light”;
however, it is made up of a combina-
tion of different colors: seven visible colors
(red, orange, yellow, green blue, indigo and
violet) and two ranges of colors invisible
to the human eye, infrared and ultraviolet.
Exposure to ultraviolet light (UV) can have
a harmful effect on our skin. One of form of
protection is sunscreen, which, depending
on its composition, can absorb or reflect the
harmful radiation. Figure 1.3.1 Types of ultraviolet radiation and their
In this experiment, we use UV-sensitive penetration into the skin.
beads to check the efficacy of different sun- Source: Internally created.
screens and understand how they work.
Procedure
1. Start this experiment in a room where
there is no direct exposure to sunlight
and divide the UV-sensitive beads into
different bags.
2. Separate some of the beads to use as
an example and then compare them
with the ones under the use of different
sunscreens.
3. Label the other bags with the different
SPFs you are using, e.g., Bag 1 = SPF Figure 1.3.2 Lighting the beads with an ultraviolet
30, Bag 2 = SPF 50, Bag 3 = 90 SPF. lamp, without sunscreen (not placed inside a bag).
4. Now apply a layer of sunscreen to each Photograph: Eliezer Sánchez González/CulturaCientífica (CSIC)/IOSA.
of the labelled bags. Make sure that the
edges of the bag are also covered, as
radiation could get in through any exposed areas, and the desired effect would not be
achieved.
5. Wait a few minutes for the solvents in the sunscreen to evaporate.
6. Use the camera on your phone to take a picture of the labelled bags and the blank
beads (as they have not yet been exposed to sunlight or the UV lamp).
Tips
• If you have two types of sunscreen (min-
eral and organic) with the same SPF, you
can do a further experiment to see if one
works better than the other (Figure 1.3.4).
• To increase the effect of the experiment,
you can remove the violet, blue and pink
beads, as they will change color with the
visible part of the solar spectrum.
• Dilute a cream with a certain SPF (50, for Figure 1.3.4 Two different types of sunscreen,
oil-based and mineral.
example) by half. Check to see if it has the
same protective effect as a cream with SPF 25. Photograph: Eliezer Sánchez González/Cultura Científica (CSIC)/IOSA.
MATERIAL
Interference, thin film,
20 min (+) iridescence • Glass microscope slides (x2) • Transparent circular lid (e.g.,
• Flashlight from a tub of candy or chips)
• Colored transparent paper • Double-sided adhesive tape
(red cellophane, for example) • Liquid soap
• Plastic straw
L
ight is a fundamental element in our daily life;
however, it is difficult to explain the wave−par-
ticle duality that defines it and even more dif-
ficult to see it. So, how can we really see how light
behaves like a wave?
In this experiment, we will discover the wave-
like nature of light by observing the phenomenon of
interference and the different patterns it creates.
Procedure
Interferences with two pieces of glass Figure 1.4.1 Procedure for observing
interferences with two glass slides and white light.
1. Place the two slides on a dark surface, one on Photograph: Eliezer Sánchez González/Cultura Científica
top of the other, taking care not to leave finger- (CSIC)/IOSA.
prints on the surface of the glass (Figure 1.4.1).
2. Place the colored cellophane over the flashlight.
Switch on the flashlight and position it half a meter over the glass slides. Switch off all
other lights.
3. Press down on one end of the top slide.
4. Repeat the experiment without the cellophane, i.e., using white light (Figure 1.4.1).
Tips
Try using different light sources (halogen lamp or fluorescent lamp). We will see different
colors, as the emission spectrum for each bulb is different, even though together they both
emit white light.
Related experiments
Experiment 5.3 Where do those colors come from?
Diffraction,
MATERIAL
30 min (+) interference • Card • Ruler
• Scissors • Measuring tape
• Laser pointer • Adhesive tape
• A long hair
O
ne of the most interesting behaviors of waves is
that they can cause constructive or destructive
interference. There are countless uses for this
property. For example, sound-cancelling earphones
use destructive interference on unwanted sound
waves to isolate the user.
Another example is the use of electromagnetic wave
interference to help us to measure very small distances
with high precision. This is the characteristic we are
going to use during this experiment to measure the
thickness of a hair. The image shows an opaque object
Figure 1.5.1 Frame for holding the hair.
under a laser beam. The light diffracts on the edges of
the object, creating two isolated sources that interfere at Source: Internally created.
a certain distance. This pattern of interference depends
on the size of the object, and this is what we will use
during this experiment to measure the thickness of hair.
Procedure
1. Make the frame by cutting a large “H” from
a piece of card using the suggested template
(Figure 1.5.1). The frame should measure
approximately 20 x 10 cm. Fold the frame in
half to make a “C” shape measuring 10 x 10 cm.
Lay it down on its side.
2. Using adhesive tape, stick the ends of the hair to
the prongs of the “C” shape, keeping it as verti-
cal and tight as possible.
3. Switch off the light and shine the laser over the
hair (remember not to look directly at the beam).
4. In order to gain a better measurement of the hair,
it is advisable to do the experiment some dis- Figure 1.5.2 Setup of the experiment
tance from the wall where the laser will be pro- with the laser incident on the hair positioned over
jected. If you look at the spot on the wall, you the card frame (top) and the interference pattern
will see a dotted line, the diffraction pattern. formed (bottom).
5. Use the measuring tape to measure the distance Photograph: Eliezer Sánchez González/Cultura Científica
between the frame holding the hair and the wall (CSIC)/IOSA.
Tips
• Try the experiment with naturally curly and straight hair to see if the thickness mea-
surement changes depending on the angle of incidence. Straight hair is normally more
homogeneous, while curly hair has a more oval-shaped section, which means the
thickness will be different at different angles.
• You can also try using other material (e.g., dental floss).
Related experiments
Experiment 2.1 Build your own spectroscope
Experiment 2.4 Extraordinary light: laser
I
n 1678, Christian Huygens put forward the theory
that light was a wave phenomenon transmitted
through a medium called ether. This theory was
largely ignored until the first half of the 19th cen-
tury, when Thomas Young resurrected it to explain
the phenomenon of interference.
This research, together with the development of
quantum physics in the 20th century, led to the dis-
covery of the dual nature of light: wave and particle.
Procedure
Experiment with aluminum sheets
Figure 1.6.1 One single reality can be
1. Take the aluminum sheet and make two slits observed from two different viewpoints.
in it, less than 1 mm thick and less than 1 mm Source: Jean-Christophz Benoist, Wikimedia Commons.
apart; if not, the pattern will form too close to
the slits (Figure 1.6.2).
2. Take a shoe box and cut a hole in the lid a
little smaller than the aluminum sheet
(Figure 6.2). Similarly, cut a hole in the side
of about 5 × 5 cm.
3. Place the aluminum over the lid of the box,
lining it up with the hole.
4. Position the source of light (laser or lightbulb)
at less than 5 cm from the aluminum across the
slits so that both are illuminated by the beam.
5. Observe the strip pattern created though the
side hole (Figure 1.6.3). Figure 1.6.2 Two slits made in the
aluminum sheet. The light is coming from a source of
white light.
Experiment with cardboard box Photograph: Eliezer Sánchez González/Cultura Científica
1. Punch two holes in the top of the box. The (CSIC)/IOSA.
holes should be a few mm in diameter and
positioned about 10 cm apart.
2. Line up one of the holes with the double slit aluminum sheet used in Procedure 1.
3. Turn the face of the box towards the sun. Look through the other hole in the box to
observe the pattern formed by sunlight as it passes through the slits.
Explanation
As the light from the two slits meets a screen, a series of stripes are created where you
can see peaks and valleys in a regular pattern. This pattern originates from the wave-like
nature of light. The waves reaching the slit are in phase. Based on the Huygens principle,
each of these slits becomes a temporary source of waves that emit from them in the same
phase, but the rays from each slit do not follow the same path until they reach the screen.
A connection can be made between the distance between the slits s, the wavelength λ,
the distance of the slits from the screen D, and the width of the bands of interference (the
distance between successive stripes) x:
λ x
=
s D
Tips
You will need two rubber balls and some wire to make two “maracas”. Find a swimming
pool, fountain or bathtub, i.e., somewhere with calm water. Gently tap the surface of the
water with the balls at two points close to each other. Observe the undulations formed on
the surface of the water and how the waves caused by each ball interfere with each other.
T
here are many substances (calcite,
sugar) in which the speed of light
depends both on the direction of travel
of the light and on its state of polarization;
it is said that such materials present aniso-
tropic properties. In these materials, an
electromagnetic wave breaks down into two
waves, each affected by a different refrac-
tive index (ordinary no and extraordinary
ne). Among other effects, the division of the
light, depending on polarization, into two
beams can form a dual image. The polariza-
tion of the output light can also vary com-
pared to the input light, which is why they Figure 1.7.1 Ordinary and extraordinary component
are called optical dephasers. of light while passing through an anisotropic material. Dual
image effect.
Photograph: APN MJM, Wikimedia Commons.
Procedure
Observation of light polarization using polarizing filters
1. Take two polarizing filters, one in each
hand. Hold one in front of the other
between your eyes and a source of light
(e.g., a fluorescent ceiling light).
2. Keeping one of them still, turn the
other through 90°. There will be a posi-
tion where the intensity of the light
you can see will be minimal; we’ll call
this the total extinction position.
Observation of birefringence
1. Place the filters in total extinction posi-
tion and hold an object between them
(e.g. plastic fork). Figure 1.7.2 The two polarizing filters; one placed at
2. Hold one of the filters in the same 90° to the other blocks the light from behind.
position and rotate the other. You will Photograph: Eliezer Sánchez González/Cultura Científica (CSIC)/IOSA.
Figure 1.7.3 Glasses between two polarizing filters in parallel (you may see colored interferences
due to tensions inside the material of the lenses) (left) and with the filters crossed at 90°, blocking the light
from behind (as the light passes through the plastic folder with tape across it, we can see colors associated to
different tensions inside the tape) (right).
Photograph: Eliezer Sánchez González/Cultura Científica (CSIC)/IOSA.
see how the intensity of the light passing through both filters varies as you rotate
(Figure 1.7.2).
3. Pay special attention to the object you placed between the filters and note down your
observations, as what is happening is a birefringence effect due to possible tensions
inside the material (Figure 1.7.3).
Explanation
In the first experiment, depending on the relative position between the filters, a greater or
lesser amount of light will pass through. If you place both filters in the same direction, the
maximum amount of light will pass through, as the first filter transforms natural light into
linear polarized light and the second allows it all through as it is in the same position. If
you turn the second polarizer 90°, the light will be completely blocked.
By placing glasses or another clear plastic item between the filters, you can see how
some materials become birefringent as they have been subjected to tension or force during
manufacturing. This is known as photoelasticity (Figure 1.7.3). This means that the polar-
ization of the light is changed as it passes through the glasses. As the tension or force is
not applied evenly, the birefringence caused by the photoelastic effect will also be uneven.
Tips
• Try the same experiment using different people’s glasses and different kinds of frames
(or frameless glasses). You will see greater or lesser tension depending on the manu-
facturer or the type of frame/lens.
T
he photoelectric effect consists of
the emission of electrons by a mate-
rial when electromagnetic radiation
meets it (generally visible light or ultra-
violet light). Photons have a characteristic
energy, determined by the frequency of the
light wave. If an atom absorbs energy from
a photon, has more energy than needed to
expel an electron from the material, and Figure 1.8.1 Diagram of the photoelectric effect.
is also following a trajectory towards the Source: Internally created.
surface, then the electron may be expelled
from the material. If the photon energy is too low, the electron cannot escape from the sur-
face of the material.
The photoelectric effect was discovered and described by Heinrich Hertz in 1887, who
saw the arc between two electrodes connected to high-voltage currents covered greater
distances when illuminated with ultraviolet light than when left in darkness. The theory
was explained by Albert Einstein in 1905; he received the Nobel Prize for Physics for this
theory in 1921.
Procedure
Experiment with balloons
1. Blow up two balloons and tie each one to a different string.
2. Rub one of the balloons on your hair. Next, hold this balloon close to the other one;
you will see that they are attracted (Figure 1.8.2, left).
3. Now rub both balloons on your hair and bring them together again. This time, you will
see how the balloons repel (Figure 1.8.2, right).
Figure 1.8.2 Balloons hanging from a string, one not rubbed (left) and both rubbed and therefore electrically charged
with the same charge (right).
Photograph: Eliezer Sánchez González/Cultura Científica (CSIC)/IOSA.
3. Touch the metal frame to discharge the aluminum curtain with your body.
4. Charge the curtain in the same way as in Step 2.
5. Now shine an ultraviolet light on the curtain. Does it also discharge?
Explanation
Matter is made of atoms, in turn consist-
ing of protons (positive charge), electrons
(negative charge) and neutrons (no charge).
Atoms normally contain more protons than
electrons, and so the positive and negative
charges cancel each other out. The balloons
are fundamentally in this state. When you
rub a balloon against your hair, your hair
gives up electrons to the balloon, which
becomes negatively charged: it has more
electrons than protons. This is how the
attraction effect occurs: when one balloon
is negatively charged and the other one is
neutral; repulsion occurs when both bal- Figure 1.8.3 Charged curtain made from aluminum
loons are negatively charged. foil using a charged PVC tube.
In the case of the aluminum strips, Photograph: Eliezer Sánchez González/Cultura Científica (CSIC)/IOSA.
which are negatively charged by the PVC
object, i.e., they have more electrons than
protons, we see how they repel each other.
Under ultraviolet light, the energy of the photons is absorbed by the electrons of the
aluminum strip so that they take on the necessary energy in order to escape the material,
i.e. the photoelectric effect takes place. This process discharged the aluminum strips.
They then have the same number of electrons as protons, and the strips therefore do not
repel each other.
Tips
• If you want to make it more fun, rub the balloon against your shirt, or another cotton
garment. Hold the balloon to the strips and see how they are attracted to it. In the same
way, if you hold the negatively charged balloon near to your hair, you will see how it
stands on end.
• If you shine an ultraviolet light on the balloon, it will be discharged and no longer
have the same effect on the strips or your hair.
Related experiments
Experiment 6.6 Obtaining electricity from the sun: build a photovoltaic cell
N
ow that we know what light is and its properties, in this chapter we will focus on
understanding how we have learned to generate and detect it, as all artificial light
sources of light require the conversion of some kind of energy into electromagnetic
radiation. The main thread of this chapter is understanding how this conversion takes
place, identifying the part of the electromagnetic spectrum where the different types of
light sources have the best properties and discovering which are the most efficient of them.
At the end of the chapter, we will focus on the optical systems that can detect light and
their recent application to artificial vision.
37
between orbits = photon energy = h · u, where h is the Planck constant (6.6 × 10−34 joules/
sec), and u is the frequency of the photon.
Each atom interacting with light releases or absorbs electromagnetic radiation when
there is a transition between energy levels. When an atom absorbs energy equal to the
difference between two of its energy levels, its electrons move to higher-energy orbitals,
which is why we say it is in an excited state. While returning to its ground state, the atom
must release energy. In this case, the energy is released in the form of a photon whose
energy sums to the difference between the two orbitals.
The emission spectrum of a material is the set of wavelengths emitted when excited (ther-
mally, electrically or luminously). For example, when exciting hydrogen in a gaseous state
while analyzing the light emitted by separating it into each of its different components, we
can see stripes of very specific colors: red (656 nm), green-blue (486 nm) and two lines of
violet (434 nm and 410 nm). So, the emission spectrum is different depending on the mate-
rial in question and is therefore a kind of “ID card”.
vacuum has been made or filled with an inert gas to prolong its life (Figure 2.8). As
electric current travels through the filament, this heats up and emits visible and invis-
ible light, but mainly infrared, which we cannot see but feel in the form of heat when
close to the lamp. These light sources have a continuous emission spectrum, which is
equivalent to a black body at 2,800 K (orange tones); see Experiment 2.2.
• Halogen lamps. These work in the same way as incandescent lamps, but they reach
higher temperatures (3,000−3,100 K). This is possible because the bulb contains a pres-
surized halogen gas (e.g., iodine or bromine). This higher temperature generates a whiter
form of light (less yellow).
• Arc discharge lamps. The classic example of this type of lamp is fluorescent strip light-
ing. A fluorescent tube, which is filled with a gas, sits between two electrodes. When
these electrodes produce a discharge, the electrons in the gas atoms contained in the
tube (generally mercury vapor) become excited and emit UV light. The fluorescent mate-
rial lining the inside of the tube absorbs the ultraviolet and emits visible light.
Depending on the type of gas and its pressure, the material will emit different wave-
lengths from the visible spectrum, and therefore the tone (color temperature) will vary
accordingly.
• LEDs (Light-Emitting Diodes): These are semiconductor diodes that emit radiation via
electroluminescence, where the electric current is transformed into radiation without
significantly increasing the temperature of the material (Figure 2.9). A semiconductor
is an electronic component with two terminals that allow electricity to flow only in one
direction through it. Depending on the characteristics of the material used in the LED,
the diode will emit this energy in the form of IR, UV or visible radiation. The emission
spectrum of LEDs is related to energy differences between the levels of its main compo-
nent material and its electronic structure. Electromagnetic emission therefore consists
of a range of wavelengths concentrated into a part of the spectrum (see Experiment 2.3).
In order to obtain white light, it is necessary to combine red, green and blue LEDs (red,
blue and yellow) or use LEDs that emit UV with a cover lined with fluorescent material,
as we saw in the case of fluorescence strips.
• Lasers are light sources with such special characteristics (described in Figure 2.10) that
they stand out among them (see Experiment 2.4). First, they have such a narrow emis-
sion spectrum that they are considered to emit practically one single wavelength and are
therefore called monochromatic (emitting a single color). Furthermore, the laser beams
are highly directional and concentrated, a property known as collimated. Finally, they are
highly coherent, which facilitates the observation of wave phenomena such as interfer-
ence or diffraction, as seen in Chapter 1.
Figure 2.12 Image of the first ruby laser system developed by T. Maiman in 1960.
Photograph: Guy Immega, Wikimedia Commons.
Artificial vision
The purpose of artificial vision is to replicate the sense of human vision to record what is
happening in the outside world, process information numerically and extract key visual
elements. These machines cannot replace the human brain, yet they have a series of advan-
tages over human vision, as they are better at determining physical dimensions and per-
forming low-processing routine tasks.
The basic systems used for artificial vision are a light source, a sensor and a proces-
sor. Once the signal has been captured, it is processed and transformed into high-level
information. This information can be used for visual representation or as a data source for
machine programming. The light sources used can range from any kind of lamp or LED to
a laser, although due to characteristics and cost, the most common light source used is an
infrared LED. The sensors used are mainly photodiodes for simple tasks (e.g., a rain sensor
on a car windscreen) and a CMOS for complex tasks such as detecting objects using night
vision.
There are many examples of the use of artificial vision (Figure 2.15) in a range of fields,
such as rain sensors in the motor industry. They consist of an infrared LED and a photo-
diode that detects how much of the light emitted is reflected by the glass. The infrared
light is emitted through the body of the sensor at an exact angle, and it is reflected inside
the glass of the windscreen and returns to the photodiode. If the microcontroller detects
changes in this signal, the sensor activates the wipers and adjusts their speed.
Bibliography
Fundación española para la Ciencia y la Tecnología (2015): “Unidad Didáctica. Ciencia con luz propia.
Aplicaciones tecnológicas de la luz”, Madrid, Editorial SM.
Guffey, J. S. and Wilborn, J. (2006): “In vitro bactericidal effects of 405-nm and 470-nm blue l light”,
Photomed Laser Surg, 24 (6), pp. 684-688.
Sarkar, M. (2012): “Vision sensors in automobiles”, Optics and Photonics News, 23, 7-8, pp. 25-29.
MATERIAL
Electromagnetic spectrum, • A cardboard box • Different light sources:
30 min (+) colors, diffraction
(e.g., cereal box) incandescent bulb, energy-saving
• An old CD or DVD bulb, halogen lamp, colored
• Craft knife or scissors flashlights, LED, etc.
• Protractor • Ruler (optional)
• Dark adhesive tape • Pen or pencil (optional)
Y
ou already know that white light is the sum of all colors, but are all light sources
the same? It may look like it by just looking at an incandescent bulb or fluorescent
strip, but with the help of our homemade spectroscope you will see how this isn’t
actually the case. The secret is in the spectrum: in the colors that make it up and make its
“fingerprint”.
Procedure
1. Seal up the box, taping over all flaps and
holes using adhesive tape so that no light
can get in through any slits or gaps.
2. Make the opening for the CD: cut two
5−6-cm slits in the sides of the box at an
angle of around 60° off vertical, as shown
in Figure 2.1.2. If you want, you can use
a protractor and ruler to do this, marking
the necessary slits using a pen or pencil. Figure 2.1.1 Fragment of a CD (our homemade
3. You will be placing the CD into the diago- diffraction grating) breaking down light.
nal slits; you will probably need to make Photograph: Eliezer Sánchez González/Cultura Científica (CSIC)/
them a bit wider using scissors or a knife IOSA.
to make the disc fit.
4. Insert the CD into the slits with the reflec-
tive side upwards (towards the shorter
end of the box). Secure the disc in place
using adhesive tape if necessary.
5. Next, cut a small window in the short
side of the box so that you can see the CD.
6. On the opposite side of the box (long
side), cut a slit a few mm long and as
straight as possible at the same height as
the CD to let light into the spectroscope.
7. Make sure you can see the CD properly
from the window in the short side of the Figure 2.1.2 Assembling the spectroscope.
box. Make it a bit larger if necessary. You Photograph: Eliezer Sánchez González/Cultura Científica (CSIC)/
IOSA
will make your observations from this
point.
48 Discovering Light: Fun Experiments with Optics
Explanation
Our spectroscope allows us to see the electro-
magnetic spectrum of visible light.
The CD or DVD acts as a diffraction grating,
as it has 650 or 1250 lines per mm engraved
on its surface. As the light meets the surface, it
is diverted, with each wavelength (each color)
at a slightly different angle. By looking at the
spectrum, we can see the differences between
light sources, even though to the naked eye
they look the same (Figure 2.1.3). Figure 2.1.3 simple spectroscope and the spec-
If you have ever observed sunlight reflected trum of a light source observed through it.
onto a white wall (or an incandescent lightbulb) Photograph: in house.
and compared it with an energy-saving bulb,
you may have seen how the spectrum of sunlight is continuous: all the colors can be seen in a
constant stream. However, in the case of the energy-saving bulb, you can only see lines: there
are dark areas between the colors. Their spectra are different because they have a different
chemical composition. By observing emission spectra and the absorption of different elements
and molecules, we can identify the composition of an unknown or out-of-reach materials.
TIPS
• If you prefer, you can make your spectroscope using a cardboard tube, closing off the
ends to stop any light from getting in. Cut a slit in one end to let light in. Cut diagonal
slits close to the other end for the CD and a small observation window.
• You can easily remove the reflective part of the CD by sticking strong adhesive tape
(e.g., gaffer tape) and then peeling it off gently. What is left behind is just the trans-
parent part of the disc, which is the true diffraction grating that you can then use in
transmission rather than reflection. Look through the “transparent CD” at a lightbulb
or fluorescent strip. The light still breaks down!
Related experiments
Experiment 1.2 Breaking light: Newton’s prism
Experiment 2.5 Beyond the visible: IR radiation
A Lightbulb MATERIAL
• Glass jar with lid (airtight) • 2 screws, 4 washers and
• 1.4-mm graphite pencil leads 8 nuts (4 for “security”).
and aluminum foil Diameter ≥ 4 mm
Light sources, continuous • 2 4R25-type 6V batteries or a • Plastic adhesive / hot
>1 hour spectrum, incandescence 12V, 8Ah lead-acid battery glue gun
• Switch, wire and crocodile clips • Safety gloves
• 2 pliers • Manual drill and metal
• Metal paper clips (not coated) drill bits
• Bathroom sealant • 1 cork
• Small candle or small piece of a
large candle
H
ave you ever looked at an old incan-
descent lightbulb and thought it
didn’t seem too complicated? The
truth is you are right! In this experiment,
we’ll show you how to make your own
lightbulb with a graphite filament. The
principle is simple: passing electricity
through a material to heat it up and make it
emit visible light.
Procedure
1. Find an airtight glass jar. Check that it
is airtight by heating it (in a warm oven
or with steam) without the lid. Next, Figure 2.2.1 Materials.
place the lid, taking care not to burn Photograph: in house.
yourself, and then leave it to cool. If
once the jar is cold the lid has been sucked downwards and does not go “plop” when
you press it, the jar is airtight. If not, you need to find another one.
2. Start by marking and drilling the holes in the lid for the pieces of cork, as shown in
the image (Figure 2.2.2). Try to ensure that they are far enough apart and not too large.
3. Next, cut the cork in half and drill a hole in the center of each half to feed the screws
through. It is important to drill a hole slightly smaller in diameter than the screws so
that they are firmly held in place. Now you can insert them into the holes in the lid of
the jar and seal them with hot glue or bathroom sealant.
4. Strip, braid and wind a piece of wire around the head of each screw. If you or anyone
you know can solder, you can solder the wire onto the screw for a stronger connection
(as shown in the images). If not, just leave them wound around the head. Now you can
screw them into the cork pieces in the lid of the jar.
5. Next, take the pencil lead, being careful not to snap it or damage it. You must use
gloves for this stage to protect the lead and prevent it from becoming greasy. Now
Explanation
The graphite filament acts as a resistor as
the electricity flows through it and starts
to heat up. As the temperature of the fila-
ment starts to rise, the spectrum emitted
also starts changing from infrared towards
higher frequencies of visible light.
Tips
You can fit a dimmer switch to change
how the bulb behaves.
Related experiments
Experiment 2.3 Detecting light with semiconductors
Light with Objective 2: Use the presence of both phenomena in LEDs for
them to act as both light sources and light sensors.
Semiconductors
MATERIAL • Connection board
• Arduino Uno (breadboard)
• Sensors: 3 × 5 mm infrared, red or • Connector wires
LED, photodetectors, yellow LEDs • USB cable
45 min (+) electroluminescence
• Indicators: 3 visible-light LEDs • Computer running
• 3 x 300−350-Ohm resistors Arduino IDE software
A
n LED operates based on a com-
bination of electrons and empty
spaces; where there is no electron,
we have a positive charge. The electromag-
netic energy released during this process is
converted into a photon capable of emit-
ting light on three wavelengths (red, green
and blue; blue received the Nobel Prize for
Physics in 2014, finally creating the sought-
after white light in combination with the
other two).
However, LEDs can be used for more
than just a source of light, as they also have
the wonderful property of transmitting
electricity—consuming very little energy
in both processes. Let’s explore these two Figure 2.3.1 p-n junction diagram in a diode.
properties. Source: Internally created.
Procedure
Before we begin, and to help with the experiment, it is important to make some technical
observations. We will be using a total of six LEDs. Three of them will act as sensors, and
the other three as indicators. The Arduino and its program will help us to pair up “sensor”
LEDs and “indicator” LEDs.
1. First, connect the negative rail on the breadboard to the GND pin on the Arduino
(Figure 2.3.2).
2. Connect the short pin (cathode) to each of the LED indicators of the negative rail on the
breadboard and a connector wire to the other end of each one. Fit a resistor between
one of these connections. In this case, it doesn’t matter which one.
3. Connect the wires from the previous step to pins 9, 10, 11 on the Arduino Uno board.
4. Next, connect the sensor LEDs directly to pins 2 to 7 of the Arduino: Connect the
cathodes (short) to the Arduino’s pin number 3, 4 and 7 and anodes (long) to number
2, 5 and 6 (2.3.3).
5. Now the Arduino can be programmed using the script provided at the end of these
instructions.
Figure 2.3.2 LED function diagram (left) and circuit diagram (right).
Source: Adapted from SPARKFUN (left). Internally created using Fritzing (right).
Explanation
LEDs change their electrical properties depending on the amount and type of light they
receive, part of a phenomenon known as photoconductivity. We are making use of this
feature to use them as sensors.
Tips
• Try shining light directly over the LEDs using a lamp. This improves the sensor func-
tion as it creates a greater contrast between light levels.
• If the device stops working correctly due to sudden changes in the surrounding light
levels, press the reset button on the Arduino.
Related experiments
Experiment 2.2 Reinventing Edison: build a lightbulb
MATERIAL
• A white LED flashlight • A sheet of matte black or
Laser, light source, • Red or green laser pointer white paper
10 min (+) diffraction • An LED flashlight, the same • Graph paper
color as the laser
• A cheap diffraction grating
A
laser is a truly extraordinary light source.
In this experiment, we will delve into
what makes it unique compared to other
sources.
The beam generated by a laser is monochro-
matic (just one color, or just one wavelength),
collimated (it consists of parallel “rays”) and
coherent (its light waves have a constant phase
relation).
In this experiment, we will see these three
main characteristics of lasers.
Figure 2.4.1 Laser emission at 480-nm
wavelength (blue).
Procedure Photograph: in house.
1. Monochromatic: Hold the diffraction grating
up close to your eye and look through at the
sheet of paper. Shine the different lights onto
the paper (white flashlight, red/green and
laser). Observe the different patterns created
(Figure 2.4.2).
2. Collimated: Stick the graph paper to a wall.
Shine the different light sources onto it
from several different distances (e.g., 10 cm,
50 cm and 1 m), ensuring that the beam is
perpendicular to the wall. Notice how the
light spots on the wall change as you get Figure 2.4.2 Procedure for seeing diffraction
further away: you can mark them on the patterns.
paper, if you like, or see how they move by Photograph: Eliezer Sánchez González/Cultura Científica
holding the flashlights at the same time as (CSIC)/IOSA.
you move farther away.
3. Coherent: Hold the laser and the colored flashlight close to a piece of paper, with a
small angle between them. Turn the flashlight on and observe the light.
Explanation
Monochromatic: A diffraction grating consists of a large number of lines too small to be
seen by the naked eye and that can diffract light, i.e., separate its components depending
Figure 2.4.3 Diffraction of white light (left), a green laser pointer (middle) and red LED (right).
Photograph: Eliezer Sánchez González/Cultura Científica (CSIC)/IOSA.
Collimated: You will have noticed that as you move further away from the wall, the
areas lit by the flashlights get much wider than the one for the laser. Light from a flashlight
diverges from its source, while collimated laser light does not diverge or converge: its rays
travel in parallel, in a single direction. Laser light is produced in a cavity lined by two
mirrors, so that only the light travelling in a well-defined direction will leave it, creating a
collimated beam.
Coherent: Looking closely at the light projected, you will have noticed that the spots
caused by the laser pointer and the LED are different, despite being the same color. Laser
light is characterised by its shiny, well-defined spot. The projection from the LED is
brighter in the center and less so around the edge. You already know that light travels in
wave form. These waves are said to be coherent when they have the same frequency and
a constant phase. Think of a wave with peaks (maximum levels) and troughs (minimum
levels): if two or more waves overlap perfectly so that all the peaks and troughs are in the
same position as they travel, then they are coherent waves. This also increases their power,
whereas if the peaks and troughs are not in synch they can cancel each other out. Lasers
emit coherent radiation. This is why it doesn’t seem to emit “brighter, more defined light”.
LEDs are not coherent, and therefore the edges of the projection on the paper are duller.
Tips
Would you like to create a starry sky? Place two or more diffraction gratings over each
other with the lines in different directions (this will also work using a very fine woven silk
handkerchief) and point a laser beam through it towards the ceiling.
Related experiments
Experiment 1.5 What is the thickness of my hair?
Experiment 2.1 Build your own spectroscope
MATERIAL
Infrared light, • Glass prism • Carboard box (or
30 min (+) Herschel’s experiment • 3 alcohol thermometers (for something similar to use
measuring air temperature) under the prism)
• Permanent black ink or marker, • Adhesive tape
or black insulating tape. • Scissors
I
n the year 1800, William Herschel realized, while observing the spectrum of sunlight
through different filters, that depending on their color, the amount of heat transmit-
ted was different. It was while he was trying to understand this phenomenon that, by
chance, he discovered infrared radiation, a type of radiation on the electromagnetic spec-
trum located “beyond red”, which cannot be seen with the naked eye.
Herschel managed to detect it because it is associated with thermal radiation: part of the
radiation is emitted in the form of heat, which can be measured using a thermometer, as
we will do in this experiment.
Procedure
1. This experiment should be completed outside or
close to a window on a sunny day without clouds
or mist, as this might reduce the chances of seeing
the phenomenon.
2. Color or paint the thermometer bulbs or cover
them with black tape so that they absorb more
heat. Stick them together with adhesive tape, with
all the temperature gauges lined up.
3. You will need to create a support for the prism
on the side of the box nearest the sun. Cut out a
piece from the top edge, slightly shorter than the
largest axis of the prism and quite deep to allow
the prism to spin. You can create a different kind
of frame for the prism if you prefer.
4. Place the prism on its support frame. Adjust its
position to obtain the widest possible spectrum (you
already know how a prism works): you can direct
the spectrum into the shadows inside the box, but
it is easier to get a wider spectrum if you project
it a bit further, e.g., onto the floor or a table. Make Figure 2.5.1 Sir William Herschel
sure that the prism is not moving. and Caroline Herschel. William is polishing a
5. Place the thermometers in the shade to measure telescopic instrument, probably a mirror, while
the ambient temperature. Caroline Herschel adds lubricant.
6. Next position the thermometers where the Source: Color lithograph by A. Diethe, c 1896.
R. Burgess, Portraits of Doctors & Scientists in the
spectrum spreads out, so that the first bulb
Wellcome Institute, London, 1973, no. 1379.10.
lines up with blue, the middle one with yellow
Tips
If you have more precise thermometers, you can try using four instead of three. This means
you can take a more accurate temperature reading of the absorption of the different color
light. You could also try using adhesive thermometers (usually designed for fish tanks).
Related experiments
Experiment 1.2 Breaking light: Newton’s prism
Experiment 2.1 Build your own spectroscope
Optical instruments
I
n this chapter, we will find out how rays of light behave when they pass through the
different elements that make up an optical system: lenses, mirrors and prisms. In other
words, we will look at the deviation of the rays of light as they pass through different
items. This examination helps us to predict the characteristics of an image formed by the
combination of certain optical elements, e.g., in the case of a microscope, where the image
is inverted and larger than the real size object we are looking at.
This means that we will not be looking at phenomena related to the behavior of light
as a wave, although they may actually be present (interference, diffraction, etc.). Nor are
we going to take into consideration the intensity of light; we will concentrate on describ-
ing these properties based solely on the path followed by the rays of light. We will do this
using what is known as geometrical optics, with calculations, or graphs, to work out the
path of light through certain optical elements or a combination of these (optical systems).
Using geometrical optics, we will discover the key characteristics of basic optical ele-
ments and systems, as well as more complex systems made from a combination of differ-
ent simple ones, such as cameras, telescopes and microscopes.
Basic concepts
It is very important to know what type of image an optical element will form of an object,
as it helps us understand how the world will look through that instrument.
An object either emits light (light source) or reflects light from a separate light source
in the form of rays. These rays travel in a straight line through a homogeneous and isotro-
pic medium, which is most common, until they reach a medium with a different index of
refraction. As we saw in Chapter 1, the surface between the two media with differing indi-
ces of refraction will refract or reflect the rays of light that have not been absorbed; they
will change direction according to the law of refraction (Snell’s law) or the law of reflec-
tion (angle of reflection = angle of incidence), respectively.
When we study the image formed of an object by an optical element, it is not enough to
examine a single ray of light. We need to study at least two rays as the image will form at
the point where two rays leaving the same point on the original object cross over, having
passed through all the elements making up the optical system in question. In reality, not
only two rays leave each point on the object but also what is known as a stroke of light,
i.e., many rays of light from the same point on the object that fill up the optical element as
they pass through it and then reflect or refract to form the corresponding image. Studying
the propagation of these strokes of light, made up of rays, allows us to predict that the
61
Figure 3.1 Path of light through a convergent optical element that forms the image of an object. The image and object
planes are perpendicular to the optical axis and parallel to the surface of the lens (left). Magnified virtual image of an object using
a convergent lens. In this case, the observer is on the left of the image (right).
Source: Camilo Florian Baron.
Figure 3.2 When we look into a mirror, what we see is always a virtual image. In the picture on the left, with a flat mirror,
it looks like the pencil is on the other side of the mirror at the same distance. In the middle and on the right, we can see how the
image of the same object is formed using a concave and convex mirror, respectively.
Source: Camilo Florian Baron.
F = (n'− n)/R
The greater the difference between the refraction indices, or the smaller the radius of
curvature of the surface, the greater the refractive power, i.e., a convergent interface (posi-
tive power) will converge rays more strongly, while a divergent one (negative power) will
diverge them more.
A spherical interface is convergent (positive power) if the convex side of the sphere is
in contact with the lower refraction index and divergent (negative power) if it is the con-
cave side of the sphere.
• The focal point (or focus) of an image is the point on the optical axis where the rays
meeting the interface parallel to its optical axis converge (or appear to come from)
after refraction
• The focal point (or focus) of an object is the point on the axis where the rays that pass
(or point in that direction) as they meet the lens will emerge in parallel, after refraction.
In the case of a convergent lens, the focal points are real (Figure 3.5, left). This means that
the object focal point is in the object space and the image focal point is in the image space.
However, in the case of a divergent lens, the focal points are virtual: parallel incident rays
diverge after refraction, and to find a focal point we need to extend them backwards into the
image space (Figure 3.5, right). In the case of the object focal point, in order to obtain paral-
lel refracted rays we need them to be convergent as they meet the lens, and when we extend
them beyond the surface of the lens they must converge in the image space.
The distances from the apex of the interface (intersection with its optical axis) to the
object focal point and the image focal point are the object focal length (f) and the image
focal length (f'), respectively. These distances can be calculated using the refractive power
of the interface (F) and the refractive indices for the object space, in front of the interface
(n) and the image space, situated behind the interface (n') thus:
respectively. The object and image focal distances are therefore not the same, as the refrac-
tive indices are different: F = −n/f = n'/f' . The shorter the focal length is, the greater the
power of the lens.
As for the image formed by a convergent interface, when the object is placed farther
away from the interface than the object focus, the image formed is real, inverted and larger,
the same or smaller than the object, depending on its position. If the object is closer to the
mirror than its focal point, the resulting image is virtual, non-inverted and augmented.
Convex mirrors form a virtual image that is smaller than the real object the reflect.
A lens is an optical element formed by two interfaces, generally curved, which separate
the material from which the lens is made from the exterior. The effect of a lens on the ver-
gence of light, i.e., its refractive power depends on the refractive index of its two interfaces,
Figure 3.5 Refraction of a beam of light through a converging spherical lens (left) and a diverging spherical lens (right).
Source: Camilo Florian Baron.
Figure 3.6 Rays of light passing through a converging lens (left) and a diverging lens (right).
Source: Camilo Florian Baron.
• A ray inciding on the optical surface parallel to the optical axis, which travels towards
(divergent) or through (convergent) the image focal point.
• A ray that, when it meets an optical element, crosses (convergent) or travels towards
(divergent) the object focal point, parallel to the optical axis.
• The nodal ray is one that passes through the system without changing course. In the
case of a curved mirror or lens, this is the ray that travels towards or crosses the center
of curvature (normal ray). In the case of a lens, this is the ray that travels towards the
yi
m=
y
i.e., indicating if the image is larger (m > 1), the same size (m = 1) or smaller than the
corresponding object (m < 1 in absolute figures). The magnification sign also indicates the
orientation of the image in comparison to the object: m > 0 if they are the same, and m < 0,
i.e., if it is inverted (m < 0) or straight (m > 1).
The field of view of an optical system is the extension of the object that appears
in the image produced by the system. The optical system acts as a window through
which we see the object, and depending on the characteristics of that window (size,
distance, position), we will see more or less of the object. In general, the more magni-
fication an optical system has, the smaller its visual field. It can be measured in mm
on the object or in degrees (the subtended angle of the object and the optical system)
(Figure 3.9).
Figure 3.10 Diagram showing the rays of light passing through the aperture of the camera obscura. The image forms
inside the camera, and the result is an inverted image (left). Image of the camera obscura in the Duke’s Palace in Béjar (Spain) (right).
Source: Adapted from www.scratchpixel.com (left).
Photograph: Manuel Garrote Prieto, department of Tourism at the Local Council of Béjar (right).
A picture of the
outside world: how
does a photographic
camera work?
Once of the best-known optical
systems is the photographic cam-
era (Figure 3.12). The purpose of
cameras is to form an image of an
object over a light sensor through
an optical system. This optical
system is made up of a set of con-
vergent lenses, known collectively
as the objective, and a diaphragm
located either in the lens or the
body of the camera.
Until a few years ago, the “sen-
Figure 3.11 Diagram of different types of illumination. Köhler sor” used was photographic film
illumination uses two different kinds of diaphragms: one field diaphragm (35 mm), made from a photosensi-
and one aperture diaphragm, positioned in different places along the path tive material on which the image
of the light from light source to object. Critical illumination also uses two was recorded when it came into
apertures but fewer optical elements. contact with light. This process
Source: Camilo Florian Baron. required subsequent chemical
Figure 3.13 Inside of a photographic camera, showing the path of light. The sensor that receives the light from the
object of interest is marked with a red box.
Source: Camilo Florian Baron.
f1ob
M=
f1oc
Bibliography
Casas, J. (1985): Óptica, Zaragoza, J. Casas, Librería Pons.
Donnelly, J. and Massa, N. (2007): Light: Introduction to Optics and Photonics. Boston, New England
Board of Higher Education.
Hecht, E. (2019): Optics, Pearson; 5th edition.
Tippler, P. A. and Mosca, G. (2007): Physics for Scientists and Engineers, WH Freeman; 6th edition.
A
1948 science-fiction work, where a
magnified face appeared in a scene
in front of a transparent plate pre-
senting great realism and three dimen-
sions, inspired physicist Yuri Denisyuk to
research deeper into the optical procedure
that caused this phenomenon. In this way,
what we know today as reflection holo-
grams, widely used in photography and
with major variations in technique, were
perfected. The pseudo-holographic pyra-
Figure 3.1.1 Materials.
mid is an innovative system used by com-
panies to display products, logos, objects or Source: in house.
3D animations, amongst other things.
Procedure
1. Take the pen, ruler and graph paper.
Start by making the template of one of
the faces of the pyramid as indicated
in Figure 3.1.2.
2. Place the template on the overhead
projector sheet. Draw it four times, and
cut out all four sides.
3. Paste the sides with sticky tape or
transparent glue forming a pyramid.
4. Search YouTube for “videos to project
holograms.” Figure 3.1.2 Diagram for creating the pyramids.
5. Place the pyramid in the center of Source: In-house.
the mobile phone screen and play
the video. You have created a virtual
image. Try to catch it!
Explanation
What takes place in this experiment is that an image is reflected on a reflective surface
with an angle equal to that of incidence. As the reflective surface is in turn translucent, it
causes the sensation that the image comes from the other side of the surface, that is, from
Tricks
You can create your own videos to cre-
ate the images you want. You can use a
PowerPoint and add the GIF you like the
most four times. Think about which direc-
tion each one has to go. Save it as a video,
and there you have it!
Related experiments
Experiment 3.2 There is nothing beyond my reach!
Experiment 3.5 Nothing here, nothing there: invisibility with mirrors and lenses
MATERIALS
Mirrors, reflection • A large, empty rectangular • Two flat mirrors of
45 min (+) container (e.g., milk or juice) similar size
• A box of cookies (alternative) (preferably rectangular)
• Corrugated cardboard • Frame and conveyor belt
(alternative) • Adhesive tape and glue
• Kitchen paper cardboard tubes • Aluminum foil (optional)
(alternative)
T
he periscope is an optical instrument
that is used to observe the outside
world from areas inaccessible to our
vision in a direct way, extending the field
of vision. This is the case of the first peri-
scopes in submarines or in World War I,
with military purposes on the ground to
monitor the enemy from the trenches. Also,
it is the basis of certain medical instru-
ments that serve to observe internal organs.
The one you build may be used to get closer
to the edge of a wall and look at the other side
of it, where you cannot reach because of your
Figure 3.2.1 A periscope inside an American navy
height and without stretching.
submarine.
Photography: US Navy, Wikimedia Commons.
Procedure
1. Take the empty milk carton (or any of
the alternatives) and cut a rectangle near
one end, as wide as the width of the
cardboard allows. This will be one of the
viewers through which you can look.
2. On the opposite side, make a similar
hole so that if one is at the front and
top, the other is at the back and bot-
tom, as in Figure 3.2.2.
3. With a few pieces of adhesive tape,
glue one of the mirrors inside the box
in front of one of the openings, but
place it at a 45° inclination. Similarly, Figure 3.2.2 Mirror placement diagram (left).
place the other mirror in the other Diagram of how the periscope should look (right).
opening, also at 45°. For this step, you Source: Camilo Florian Baron.
can cut a piece of cardboard on which
to support the mirror, this will have as a section an angle of 90° and two of 45°. One
of the sides will have the sizing of the mirror, and the other two a somewhat smaller
height. This way you can make sure the angles are correct and the mirror is well
aligned (Figure 3.2.2).
4. You already have your periscope. Now all you have to do is try it. Hold the periscope
with the upper opening just above the edge of a wall or wall and look through the
lower opening.
You can see over the edge! If you want it to resemble a professional periscope, wrap it
with aluminum foil (Figure 3.2.3).
Explanation
The operation of mirrors can be explained by following the law of light reflection. In a
common flat mirror, a beam of parallel rays of light that strikes the surface is reflected
in such a way that each reflected beam remains in the same plane as its corresponding
incident beam, so the beam of reflected rays continues to be of parallel rays, even if they
change direction.
The second law of reflection indicates that the reflected ray will have the same angle
as the incident ray. This phenomenon is observed when we look in front of the mirror, in
which case the incident rays project our image on it. The reflected rays return this same
image but inverted (the image is right, symmetric and virtual).
In the mirror of the upper end of the periscope that we have built, the rays coming from
objects located outside our area of vision will be reflected. When this is affected at 45º and,
following the second law of reflection of light, the objects will be reflected at 45º as well,
so that the incident rays and the reflected rays will form a right angle to each other. This is
what allows the rays reflected in the upper mirror to accompany the path of the tube and
be directed vertically downwards, although projecting the inverted image. These reflected
rays, in turn, will affect the mirror located at the lower end, repeating this phenomenon
that will reverse the image, so the final rays perceived by the eye of the observer will cor-
respond exactly to the original image.
Tricks
• You can build the periscope in two halves that fit inside one another, so you can
“extend” or “shrink” it according to your needs. In this case, you should use two sepa-
rate boxes in its construction.
Chapter 3 Optical instruments 81
Related experiments
Experiment 3.1 Catch me if you can!
Experiment 3.7 Become a top-notch astronomer at home!
What Happens
MATERIALS
For lenses and jelly prisms • 3 laser pointers
• Transparent jelly (flavorless) • Meter
Lenses, prisms, • Flat tray with walls at least
3 h (+) micro-lenses, imaging, For silicone micro-lenses
focal length 2 cm high • Hot melt silicone bar
• Glass or cup • Tweezers
• Craft knife • Craft knife
• Pot • Heat source (candle or lighter)
• Kitchen
B
uilding a homemade lens is not a
simple task. Pay attention to the size
of the lens, its angles and the shape
of its sides. To make our lenses and prisms
we will use jelly and silicone. The jelly is
transparent and solidifies at room tempera-
ture, it is also easy to cut. Silicone is also
transparent and easy to handle.
In this experiment we will learn the dif-
ference between convergent and divergent
lenses. To do this we will use lasers, whose
beam will be deflected and refracted,
depending on the type of lens it passes
through. After seeing how the beams are Figure 3.3.1 View through a thick convergent lens.
refracted with each lens, we will apply this Photography: in house.
knowledge to the formation of the image,
putting it behind the convergent and divergent lens. We will also calculate the focal length
in order to see the image clearly.
Procedure
Manufacture of lenses and jelly prisms
1. The first step is the construction of the lenses. You have to prepare the jelly as
instructed by the manufacturer, put it inside the tray and make sure it covers at least 1
cm of the tray.
2. Once the jelly is solid, use a glass or cup to cut the silicone on curved surfaces and a
knife to create the straight surfaces (Figure 3.3.2). See the shapes in Figure 3.3.3.
3. Remove the lenses from the tray, being careful not to break them, and leave the rest of
the jelly on the tray.
4. In order to see if the lenses you have made deflect light, the light must pass from the
laser pointers. You must join the three pointers with adhesive tape so that the rays are
parallel and then pass them through the jelly lenses to see how they deviate.
Figure 3.3.2 Trimming and separation of solid jelly according to the lens molds: convergent lens (left), divergent lens
(center) and flat convex lens (right).
Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Explanation
When light passes through any transparent medium, depending on its index of refraction
and the level of polishing of its surface, the light will be diverted to a greater or lesser
extent. In the specific case of lenses, the convergent ones will divert the light to a specific
point known as the focal length, measured from the side of the lens where the light comes
out. A very simple way to measure the focal length of a lens is to pass parallel rays through
it that strike the lens at different points. Once these pass through the lens, they will con-
verge at a point that can be measured with a tape measure. You can do the same with the
other types of convergent lenses.
Figure 3.3.4 Beam tracing with the lenses produced for the experiment (from left to right): flat convex lens, convergent
lens, composite system, and divergent lens.
Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Figure 3.3.5 Templates of different optical systems on which you can place the lenses you have manufactured. Print
them to a larger size so you can see well what happens with the rays when crossing different surfaces.
Source: Laser ray box kit. Laser Ray Scale PDF.
Tricks
• Until now, the jelly lenses you have made are transparent. You can try using different
colored jelly and see what happens when it has the same color as the light of the laser
pointers.
• You can place the silicone lenses on the templates (A - F figures) to see how different
optical instruments work.
• You can play with the size of the silicone micro-lenses you have made and check if
the size of the object you are viewing alters. Since these lenses are very small, you can
use your mobile phone screen to magnify the light-emitting pixels.
Related experiments:
Experiment 3.4 Micro-lenses: beyond a magnifying glass
a Magnifying Glass Objective 2: Use dried and hydrated hydrogel beads to produce a
higher resolution than with liquid drops.
MATERIALS
Refraction, convergent • Water
30 min (+) lenses, thick lenses, • Water sprayer
magnification • Mobile phone or tablet
• Hydrogel beads
• Micro-lenses manufactured in Experiment 3.3 (optional)
H
ave you ever seen the screen of your
computer or mobile phone with water
droplets on its surface? If so and you
have looked carefully, you will surely have
seen blue, red and green dots. In reality, the
small drops of water are acting as a lens that
allows us to solve/view the light emitting
pixels of our screens. To give you an idea,
a high-resolution mobile screen is made up
of 1,920 pixels high and 1,800 wide. That
makes, if the screen is 5.5 inches (diagonal),
the pixel size is less than 10 microns on the
side (a hair is 100 microns).
Figure 3.4.1 Hydrogel pearl without hydration.
In this experiment, you will manufac-
Photography: in house.
ture liquid water lenses to view the pixels
of your mobile phone screen. Furthermore,
we will also use dried hydrogel beads and
see how their optical behavior is affected
by hydrating them. Finally, we will show
how hydrated hydrogel balls can be used as
convergent lenses.
Procedure
Water droplet experiment
Before you start, bear in mind that water
can damage the electronic device you are
going to use. Therefore, you must use small Figure 3.4.2 Hydrogel beads without hydration on a
amounts of water; you can use a sprayer, for screen.
example, and try to avoid wetting the head- Photography: in house.
set. If the drops are too large, quickly move
the mobile phone horizontally while blowing on the screen.
Spray a little water on the unlocked screen and with luminous wallpaper. Notice that in
the places where the small droplets are, the colors green, blue and red appear. If the drop-
let is small enough, you will distinguish that these colors are grouped into small squares,
each occupying a third part with a rectangular shape.
Explanation
Water droplets, like small spheres, have
two fundamental properties to be consid-
ered as lenses: a material with a refractive
index greater than air and a surface with
curvature. Since the curvature of the sur-
face is convex, both of the droplets and of
the spheres, they behave like convergent Figure 3.4.4 The object is at a distance from the
lenses. The difference between them is that lens less than its focal length, so the image that is observed is
the droplet can be considered as a flat con- straight and enlarged.
vex lens and the sphere as a biconvex lens. Source: Camilo Florian Baron.
When the object is located at a distance
from the sphere smaller than the focal length, it is magnified and not inverted (Figure 3.4.4).
Tricks
• You can use a spray bottle to spray the drops of water on the mobile phone screen,
such as those used for perfumes. In this way, the water droplets will be more even and
much smaller than if you do it with your hand.
• You can look for other spherical objects that can help you magnify objects. For exam-
ple, you can use a crystal marble.
Related experiments
Experiment 3.3 Make your own lenses and see what happens
MATERIALS
Setup I: mirrors Setup II: lenses
Mirrors, reflection, lenses, • 4 flat mirrors • 4 convergent lenses (200-mm focal)
30 min (+) divergence, convergence
• Mounts • 4 divergent lenses (focal 75−100 mm)
• Conveyor • Mounts
• Ruler
I
nvisibility is one of the most recurring
fantasies in science fiction works. Having
a cape that allows you to go unnoticed
to the rest of the world is a dream that has
appealed to not only writers and film direc-
tors but also many renowned scientists. At
present, a certain type of invisibility is pos-
sible, although it is limited to objects on
a very small scale made of a new class of
materials that are not found in nature and
that present unusual electromagnetic prop-
erties. These are known as meta-materials,
which allow deflecting or attenuating the
incident light rays on an object, making
them imperceptible. Despite this, on a larger Figure 3.5.1 Materials.
scale, it is possible to achieve an invisibility Photography: in house.
effect used by illusionists and prestidigi-
tators by way of mirrors or lenses. In this
experiment, we will show you their tricks.
Procedure
Invisibility with mirrors
1. Place the four mirrors as indicated in
Figure 3.5.2. Reflective sides should
be on the inside, facing each other.
2. Make sure they form a 90º angle. To
do this, you can use a conveyor or a
square. Figure 3.5.2 Assembly diagram of invisibility with mirrors.
3. Position an object of appropriate size Source: Camilo Florian Baron.
in the invisibility area indicated in the
figure. To prove that it works, scroll it
up and down, and enjoy the effect of appearance and disappearance.
Explanation
The secret of this experiment is to deflect the light around the object that we want to dis-
appear. In the first case, the first mirror (mirror 1 in the figure) reflects the light away from
the invisible area towards the second pair of mirrors (mirrors 2 and 3) to return it at the
end to the mirror behind the hidden area (mirror 4). In the second case, the convergent
lenses concentrate the light on the divergent lenses, avoiding the hidden object. Divergent
lenses are important in the proposed design because they prevent the background of the
image from being inverted.
Tricks
• The larger the mirrors or lenses are, the larger the objects you can hide.
• Perpendicular mirrors can be separated (so long as you keep the angle 90º) to cover
elongated objects.
• If you don’t want them to discover your secret, hide the second pair of mirrors (2 and 3)
behind a wall (for example, at the end of a corridor) or place the mirrors in a box, leav-
ing the observer a single point from which to observe the phenomenon.
Related experiments
Experiment 3.1 Catch me if you can!
Experiment 3.3 Make your own lenses and see what happens
to a Camera camera.
Objective 2: Understand how a camera works.
MATERIALS
Photography, lenses, • A lens with a focal length of 12 to • Glue for cardboard and a
1 h (+) imaging 17 cm (equivalent to between paint brush
6 and 8 diopters) • Translucent paper or a
• A shoebox thin sheet
• Pieces of cardboard or cardboard • Photographic film
• A pair of scissors, craft knife, ruler • Photo development liquid
and stapler
T
he camera is possibly one of the
most popular optical instruments
of our time. The first forefather of
the cameras is the dark cameras, already
described by some Greek philosophers,
such as Aristotle. These cameras simply
consisted of a chamber with a small hole
in one of the walls, projecting the image
on the opposite wall of the chamber. From
this classic instrument, the introduction of
lenses and a diaphragm (a hole with vari-
able diameter) made it possible to create
a modern camera. To record the images, Figure 3.6.1 Set-up of the camera equipment to be
analog cameras require physical support: mounted.
photographic films created from photosen- Source: In-house.
sitive materials where the image is immor-
talized. In this experiment, you will see how to build your analog camera.
Procedure
Simple camera
1. Cut the shoe box without cutting the lid. To do this, draw two lines parallel to the nar-
rowest walls of the box. The first will be at a distance equal to the focal length of the
lens from one end, and the second will be two centimeters longer from the opposite
end. Cut along these lines to obtain sections 1 and 2, respectively.
2. Take section 2 and slightly reduce its height to fit the fixed part.
3. Make a hole, a little smaller than the lens, in the wall of section 1.
4. Place the lens on a piece of cardboard and fix it with glue or staples on the hole.
5. Now glue or staple section 1 to the shoe box’s lid.
6. Take section 2 and cut out a small window at the back. In this window you must place
the translucent paper.
7. Place the object you want to photograph and illuminate it. Point the camera and focus
on the subject by moving section 2. Observe how the image is formed on translucent
paper (Figure 3.6.2).
Figure 3.6.2 Backlit object and camera taken image. Photo camera operation.
Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Explanation
In the camera we have built, we can identify the basic parts of an analog camera. Basically,
a traditional camera consists of at least a first objective lens; then a diaphragm, which is
responsible for regulating the amount of light that will reach the film; a shutter, which will
define the moment in which we want to capture and, finally (depending on our objective
lens), a second lens that will send the image to the film at a suitable size.
The shutter speed is what defines the exposure time of the film to the incoming light.
The diaphragm is fixed, or we can build it additionally, as we have previously suggested.
The cover that we put on the lens acts as a shutter, regulating the exposure time by the
camera’s aperture time.
If we want to take pictures in low-light conditions (where we need an open diaphragm and
more exposure time), the simplest solution is to use a roll of film that is more sensitive to light.
Tricks
An alternative to build a diaphragm is to use your hand or a bottle cap to increase or
reduce the amount of light that reaches our camera.
Related experiments
Experiment 3.2 There is nothing beyond my reach!
Experiment 3.7 Become a top-notch astronomer at home!
MATERIALS
For the Galileo telescope For the Kepler telescope (in
• A small concave lens addition to the above):
• A large convex lens • Two convex lenses: one
• Recycling cardboard tubes small for the eyepiece and
• Glue one larger for the lens
• Filter strips
• Ruler
• Scissors and craft knife
T
he telescope is an optical instru-
ment that allows distant objects to be
observed in much more detail than
the naked eye. It is a fundamental tool in
astronomy: each development or improve-
ment of this instrument has allowed for
advances in our understanding of the uni-
verse. There are two types of telescopes,
refractors and reflectors, depending on
whether they are constituted only by
lenses, which refract light, or also incor-
porate mirrors, which reflect it. Within
the refracting mirrors, we can find those of Figure 3.7.1 Materials.
Galileo and those of Kepler, with different
Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
characteristics due to their different lens
combinations.
In this experiment, a telescope of each type will be built. In this way we will better
understand the differences between the two, and we can begin to observe the beauty that a
starry sky hides.
Procedure
1. The first thing you need to know is the
diameter and focal length of your lenses.
If you cannot remember how to measure
the focal length of a lens, don’t worry!
Go back to Experiment 3.3 to look it up.
2. Paste both lenses on each end of a tube.
Remember that the diameter of the tubes
must be similar to that of the lenses. If the
lens is larger, you can glue it carefully as
not to dirty it, and if it is small, you can
fill the hole with felt, for example.
3. Place one tube inside the other, so
that the lenses are at opposite ends of
the two tubes. It is necessary that the Figure 3.7.4 Right image produced by the Galileo
smaller tube can slide smoothly in and telescope.
out of the larger tube. Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
4. Glue the felt strips around the out-
side of the smaller tube to fill the gap
between the tubes. Put enough layers
so that it is more or less tight but can
slide to carry out the approach.
5. To calculate the length of your telescope,
remember: the sum of the focal points
of both lenses is equal to the distance
between them, this being so when the
telescope is focused infinitely, theo-
retically. The tube of greater diameter,
for aesthetics, is longer than the one of Figure 3.7.5 Inverted image produced by the Kepler
smaller diameter. The tube of smaller telescope.
diameter must be in the middle position Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
according to the total length. Thus, we
will have enough travel to increase or reduce the distance when focusing (Figures 3.7.4
and 3.7.5).
Chapter 3 Optical instruments 97
Explanation
In the Galileo telescope, parallel rays of light from a distant object are brought to a point
in the focal plane of the objective lens using a convergent lens. The eyepiece is a divergent
lens that intercepts these rays and makes them parallel once again.
The final image is a virtual image, right, located in the infinite and with the same shape
as the object. In contrast, both the eyepiece and the objective lens are convergent lenses in
the Kepler telescope. The objective lens provides a real and inverted image and, through the
eyepiece, the observer sees a virtual image of the same meaning, that is, inverted with respect
to the object. The Newtonian telescope uses mirrors instead of lenses. Light from the observed
object propagates along the tube until it reaches the primary mirror, located at the rear. The
mirror reflects the rays forward and, thanks to its concave shape, concentrates them in a very
small space. Next, a flat mirror directs the light towards a hole in the side of the tube, and with
the help of an eyepiece that is nothing more than a lens, the desired star can be observed.
The Galileo telescope is a very bright telescope, and the final image is right without
the need for an inverter system. However, it has a very small field of vision. The Kepler
telescope, when using a convex lens in the eyepiece instead of the concave of the Galileo
model, has the advantage of allowing a much wider field of vision and in greater detail,
but the image for the viewer is reversed. The Newtonian telescope, when using mirrors,
avoids the chromatic aberration of the lenses; however, the disadvantage of Newtonians
Tricks
• Try different combinations of lenses and tube materials. You can use the lenses of old
cameras, magnifiers or other optical items.
• Paint the inside of your telescopes slate black to avoid reflections of parasitic light.
Outside, you can be as creative as you want.
• Try not to touch the front of your lenses and optical mirrors with your hands (wear latex
gloves), and before incorporating them into your telescope, clean them with a cloth.
• When you go to make the observation, choose a day of clear sky and an area with little
artificial light pollution.
Related experiments
Experiment 3.2 There is nothing beyond my reach!
Experiment 3.3 Make your own lenses and see what happens
Experiment 3.6 From a shoebox to a camera
See the Tiniest Things Objective 2: Optimize the system to obtain measurements with
real scale, align the optical elements (smartphone,
lens, sample and lighting) and calculate the magnifi-
cation of the system.
Lenses, imaging, focal
60 min (+) length, lens combination MATERIALS
• Two convergent lenses of a • 2 wooden or plastic bases
disposable camera (usually • 4 LEGO pieces
with 25-mm and 45-mm • Lighting source (or
focal lengths) continuous flash of
• PVC tube ~ 3 cm in diameter or another mobile phone)
cardboard (to form a tube) • Adhesive tape
A
microscope is an optical instrument
that produces a magnified image of
small objects (or microscopic, that
is, of the size of microns) thanks to the
help of convex lenses. A magnifying glass
would be a simple microscope composed
of a single lens, but if we wish to view
tiny details, we need to combine different
optical elements.
Mainly, a basic microscope consists of
(1) a plate, or transparent sheet where we
place the sample we want to observe; (2)
a lighting and diaphragm system, which
illuminates the sample (lights below); (3)
an objective lens, which is the lens closest
to the sample (usually with great power)
and (4) an eyepiece, which is the lens
located near our eye. The combination
of the power of the objective and ocular
lenses determines the magnification of our Figure 3.8.1 Magnifying glass and simple microscope
microscope (for example, the 40× nota- (two lenses, two diaphragms and one lighting source).
tion indicates that we see the object a ver- Source: Camilo Florian Baron.
sion scaled 40 times larger). The observed
image is created in our retina, if we are the ones who observe, or in the camera sensor, in
case we want to register that image.
Today, we can build a microscope and take the images with the help of our smartphone.
Would you like one?
Procedure
Microscope construction
1. Identify the two lenses to construct the microscope: one with a short focal length (used as
lens 1, objective), and one with a longer lens (which we will use as an eyepiece, lens 2).
Explanation
Curiosity regarding small things has allowed us to develop and implement many improve-
ments to the different optical instruments that are within our reach today. In the specific
case of the microscope, its origins go back to the use of a simple magnifying glass that
allows us to magnify objects in the simplest possible way, even the most modern high-
resolution optical microscopes with which research is currently being performed.
The microscope you just built is the result of combining two convergent lenses to view
the world of small things without having to use a single, giant convergent lens. Basically, it
incorporates an objective lens (which is the one that is closest to the object to be studied)
and an ocular lens (which allows us to form the enlarged image).
Over the years, different elements have been incorporated to obtain sharper images,
with more magnifications and exceptional spatial resolutions. Two basic elements are the
Tricks
• To optimize your system, you can also play with the distances between the light
source and the sample, in order to obtain a more even lighting system. In the case of
samples that are not translucent, you can illuminate the sample from the top, so that it
reflects on its surface and goes to the lens.
• If you want to further increase the resolution of your system, use a micro-lens.
Experiment 3.4 Micro-lenses: beyond a magnifying glass is suitable for this case.
Related experiments
Experiment 3.3 Make your own lenses and see what happens
Experiment 3.4 Micro-lenses: beyond a magnifying glass
Experiment 3.9 A micro-world in a droplet
Refraction, lenses,
20 min (+) microscopes, MATERIALS
magnification • Green (or red) laser pointer • White screen (or a wall)
• Syringe or toothpick • Water (from the tap, a
• 2 toilet-paper cardboard rolls puddle, a river, the sea,
• Plastic flange saliva)
T
he microscopic world within a droplet
can be fascinating. Paramecia, amoebas
and different micro-organisms can be
observed in a simple way. We will be able to see
their movements, their shapes and sizes, since
a suspended drop, due to its shape and differ-
ent index of refraction with respect to the air,
can behave like a spherical lens. Thus, with the
help of a laser pointer we will manufacture a
simple microscope where we will see the shad-
ows of the micro-organisms inside the droplet,
getting up to 100 magnifications!
Figure 3.9.1 Materials.
Procedure Photography: in house.
1. Fill the syringe with water that you have taken from the tap or a natural source and
place it between two supports, for example, the two rolls of toilet paper cardboard, so
that it is held between them. Press the plunger of the syringe so that a droplet hangs
without falling.
2. Hold the laser pointer with the plastic flange so that the power button is pressed. Then
carefully place the pointer so that it is at the same height as the water droplet and its light
is aimed towards the white wall. To reach the same height and so that the light strikes the
droplet, you can use a notebook or book. Try opening sheets until you get the right height.
Explanation
Here, the droplet behaves like a spherical lens. The beam of light penetrates the drop-
let through the air/water interfaces twice. Therefore, the tools produce two refractions,
as shown in Figure 3.9.3, producing a focus on the back of the droplet and subsequently
reaching the screen located at a distance (d). Note that the image of the projected shadow
of the object will be inverted.
The system works like an image projector. The linear increase produced by the system
is directly related to the distance (d) between the projection lens (in our case, the drop-
let) and the screen and inversely proportional to the focal length of the droplet (f), since
the object is very close to the focal plane of the lens:
A = d/f
Chapter 3 Optical instruments 103
Figure 3.9.2 Assembly of the complete experiment (left) and detail of the assembly in which the suspended droplet
(right) is observed.
Photography: in house.
Tricks
• If you do not have a syringe, you can
use a stick by wetting it and allowing
the droplet to hang without falling;
finally, place the toothpick carefully
on a support with adhesive tape so
that it is suspended. The smaller the Figure 3.9.3 Projection onto a white surface of a back-
droplet is, the more magnification lit droplet using a green laser (you can see the wing of a wasp
you will have in your microscope. located between the laser and droplet.
• Add water from the sea, river or pud-
dles to see the micro-organisms move, although this water must not be too cloudy.
• You can put a transparent sheet, such as an insect wing or onion skin, between the
laser and the droplet, and you will also see it enlarged, as if it were a projector.
Related experiments
Experiment 3.3 Make your own lenses and see what happens
Experiment 3.4 Micro-lenses: beyond a magnifying glass
Experiment 3.8 Microscope: how to see the tiniest things
T
he human eye is an optical instrument offering incredible performance: not only is it
capable of forming an image focused on its sensor (the retina) but it also has the abil-
ity to focus at different distances and work under a wide range of light levels boasting
optical quality that is optimized for its functions. This is why for years it was the weak
point of Darwin’s theory of evolution, as he himself acknowledged:
How is it possible that simply through the process of natural selection, such a perfect
biological optical instrument had been created?
Yet the ability to see does not belong solely to the eyes; rather, it is a complex process
(Figure 4.1) that occurs throughout differentiated phases where visual information is per-
ceived, recognized, transformed and processed, over three stages: optic, retinal and neuro-
nal. Our eyes form the image of the outside world, the brain interprets the image from each
eye “in real time” and vision is the incredible result of highly coordinated teamwork.
105
index between the air and the cornea (with water-like value); it is the first medium (together
with the tear film) with which the light is found at its entry into the eye. The lens is the
second lens that forms the optical system; it is a converging biconvex lens that contributes
the remaining third to the refractive power of the eye (about 20 diopters in the unattended
state; later, we will delve into greater detail on the accommodation, the eye’s autofocus).
Both the cornea and the lens act to transmit and focus light optimally on the retina, where
transparency in both tissues is a critical requirement. For this, the cornea has a highly
organized structure, while the crystalline lens has different interfaces and proteins (called
crystalline proteins) distributed regularly as in onion layers, meaning that simple optical
systems cannot be considered. This will be seen more closely in Experiment 4.1.
The iris is found between the cornea and
the lens and is a diaphragm that, thanks to
its dilator and sphincter muscles, modulates
the entry of light into the eye. The size of
the aperture delimited by the iris, which we
call the pupil, varies automatically depend-
ing on the intensity of light that reaches the
eye (acting as the variable diaphragm of a
photo camera).
These are the optical elements of the eye;
they are not artificial lenses or the mechani-
cal structure of a camera, but they are tis-
sues that need support, protection and
nutrition. Alongside this, we have three dif-
ferent types of transparent fluids through
which light propagates (tear film, aqueous
humour and vitreous humour) and support
tissues rich in collagen, fibers and blood
vessels that are out of the light’s path (the
sclera, the eyelids, the conjunctiva, the cili-
Figure 4.2 The eye as a biological photo camera. ary muscle and the choroid), vital for the
Photography: Tinypic. maintenance of the visual system.
it means that the eye has certain imperfections. Furthermore, these imperfections are dif-
ferent between the two eyes.
Indeed, the eye is not a perfect optical system. The differences between the images of
the real point of the LED and the one that you have seen with each of your eyes are called
aberrations, and they can be measured, quantified and their influence studied, although
today it is not possible to correct them with glasses. In addition, it must be kept in mind
that there are other phenomena such as diffraction or dispersion that greatly affect the
final quality of the image.
Helmholtz (1821−1894) was a famous 19th-century scientist, with studies in numerous
fields, who developed important knowledge in optics. His phrase was famous, saying, “It
is not an exaggeration to say that if an optician wanted to sell me an instrument that had
as many defects as those of the eye, it would be justified to reprimand his lack of care in
the most energetic way and return it.” However, Helmholtz knew very well that the defects
that the eye has are not as noticeable as in any other instrument. Why? As you have been
told in this chapter, the visual process does not depend only on the eye or end at the ret-
ina. It is the brain that is responsible for interpreting all the information it receives through
the retina and is responsible for compensating some of these imperfections or adapting to
them, so that in everyday life we are not fully aware of them. The brain is adapted to the
visual quality of each one and, when that quality changes, as when we wear new glasses,
for example, it must re-adapt to the new quality of the images it receives.
relevant. That is, our brain selects the information it wants to process and frees us from the
rest; this is an effective strategy in terms of neural resources. Imagine the energy resources we
would consume if we had to process all the information coming from each of our senses.
This active process of the reconstruction of our visual perception is very similar to our
reality, but not completely. And when there is a lack of correspondence between percep-
tion and reality, optical illusions come into play. The basis of optical illusions is psychol-
ogy, and they can be classified into several groups: on the one hand, we have those that
are due to physiological phenomena, which depend on the physical response of the eye
to a stimulus (for example, the bleaching of flash photoreceptors of a photo camera, or
the disappearance of an object whose image falls on the blind spot of the retina or the few
details that our objects that are on the periphery of the scene have) and on the other hand,
we have the optical illusions that are due to psychological phenomena, which are based
on the geometric perspective and are related to the association of ideas during learning.
Optical illusions are a combination of physiology and psychology that involve the entire
visual process (from the eye to the brain), and its final result is deception. Wizards learned
their use centuries ago. We will explore this in Experiments 4.3 and 4.7.
refractive power to form the image on the retina, and we need to contribute more conver-
gent refractive power. Therefore, when we say that an eye has hypermetropy of +3.0 D,
we know that this is the lens that corrects its refractive error, focusing the image on the
retina. This will be seen in Experiment 4.4.
The near-sighted or hypermetropic have the focal point in front of or behind the retina
because the power of the eye or its length are not correct. However, if there is some kind
of irregularity or decentralisation in the cornea or lens, then a single focal point is not
formed, but different foci are presented for different orientations. This is known as astig-
matism, and its correction would be done with cylindrical or toric lenses (Figure 4.9).
the term depth perception. However, these are totally different concepts, since there are
patients with monocular vision who can perceive relative distances between objects in
space and, nevertheless, do not have stereopsis. Binocular vision, together with retinal dis-
parity, that is, the difference between two images in the retina (because the two retinas do
not have the same vision stimuli given the location of the eyes) is the basis for the creation
of images in three dimensions (3D) on flat surfaces, used in different space exploration
projects (Figure 4.11).
The binocular field of vision contains the visual field of the two eyes, without moving
the head, and this extends through a region that exceeds 180º horizontally, but there are
regions that are invisible to each of the two eyes due to the nose.
obtain a concave figure called an eye in a glass. If we continue folding gradually, the cup
closes on itself leaving only a hole at the top, which provides the eye with a mechanism
similar to that of a pinhole camera. The nautilus, a genus of cephalopod molluscs, has eyes
of this type (Figure 4.14), simple, that furnish it with blurred vision of the environment
and with scant details, but it allows them to determine certain simple forms.
The key to obtaining a clearer image that provides good vision is found in the lenses.
The better the lens is, the better the image obtained will be. Natural selection has
continued working generation after generation, imposing in each phase small improve-
ments on different characteristics, such as the curvature, the transparency of the lenses
and ocular medium, until finally a degree of evolution like that of the human eye was
reached.
However, we find in nature many examples of animals with more surprising eyes than
ours; for example, we can highlight the primate called the tarsier. Its huge eyes are fixed
on the skull and cannot rotate in its orbits, a disadvantage that this animal compensates
with a neck that rotates 360º. As its eyes are heavier and bigger than its brain, the tarsier
has very sharp sight and excellent night vision. Also interesting is the case of the goblin
fish, which incorporates in its vision system a mirror that allows it to see up and down at
the same time.
Bibliography
Atchison, D.A. and Smith, G. (2000): Optics of the Human Eye, Oxford, Butterworth-Heinemann.
Diaz, R. (2013): Art, magic and illusion: optical illusions in art and other visual productions, Madrid,
CSIC.
Kahle, W. and Fortscher, M. (2015): Anatomy Atlas with Clinical Correlation, Thieme Medical Pub;
7th edition.
Macknik, S., Martinez-Conde, S. and Blakeslee, S. (2011): Sleights of Mind: What the neuroscience of
magic reveals about our brains, Profile Books.
Puell, M.C. (2006): Óptica Fisiológica: el sistema óptico del ojo y la visión binocular. Universidad
Complutense de Madrid, Madrid.
Schwartz, S.H. (2013): Geometrical and Visual Optics, New York, McGraw Hill Professional.
Stratton, G.M. (1986): “Some Preliminary Experiments on Vision without Inversion of the Retinal
Image,” Psychological Review, 3 (6), pp. 611-617.
Valenzuela , M. (2008): Anomalías en la visión del color. Publicatuslibros. https://docplayer.
es/19554919-Anomalias-en-la-vision-del-color.html.
Eye Work? And that compare them with the parts of a camera.
T
he sight process is complex and needs three basic elements: eye, brain and light.
Without light, we are unable to see. However, in many cases it is the optics of the eye
that determines the type of vision.
In this experiment, you can mount two different eye models, in which various opti-
cal elements are involved: a pinhole and a lens. Of course, the quality of the image that
reaches the retina is not the same.
Try for yourself!
Procedure
The nautilus
The nautilus has the simplest visual system you can imagine: a simple pinhole that regu-
lates the amount of light that enters, and no lens.
1. Make a small hole in some cardboard. You can draw the animal on the cardboard!
2. Illuminate a slide so that the image passes through the pinhole. Place a white card-
board behind the nautilus to see how the image is formed.
Figure 4.1.2 Nautilus eye diagram (left) and assembly of the experiment (right).
Source: in house. Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Figure 4.1.3 How to use the model eye (left). Looking through the model eye (right).
Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
3. Cut the plastic ball in half, with the help of the craft knife, remember not to cut yourself!
4. Make a hole in the centre of each of the halves. The PVC pipe will pass through one
of the holes and the lens (magnifying glass) will be placed in the other. This lens will
represent the cornea and lens ensemble.
5. Insert the PVC tube so that the plastic and onion paper are inside the ball.
6. Adjust the distance between the magnifying glass and the paper until a focused image
is obtained.
7. Join the two halves of the ball and fix them with sticky tape.
Explanation
Light enters the eye through the cornea (the magnifying glass in our experiment). The iris
controls the muscles that alter the size of the pupil in order to adjust the amount of light
entering the eye (in this case, the hole that simulates the pupil is of fixed size). After pass-
ing through the pupil, the light reaches the lens (the magnifying glass), which focuses the
light on the retina (the transparent circle covered with onion paper). The retina contains
thousands of cells that are sensitive to light and help transform this into a neural message
for the brain to interpret as an image. The eye is optically equivalent to the current camera:
it has a lens system, a variable aperture system (the pupil) and a retina that corresponds to
the photographic plate on which the images are projected.
The jumping spider (Salticidae) has one of the finest visual systems in the world of
invertebrates. In total, it has eight eyes, six lateral and two in the front of its head, so that
they provide a kind of peripheral vision. The main eyes are located in the front and allow
it to locate prey and hunt them. These eyes have two lenses like our cornea, which make
a first filtering of the light, but then they have two tubular structures that reach a second
lens. The two-lens system makes jumping spiders see the world through two small tele-
scopes that can move and adjust. Just as we accommodate by changing the shape of our
lens to change the focal length, the spider focuses with different layers of its retina. It has
a succession of photoreceptors arranged in a kind of staircase, which allows the spider to
clearly perceive objects at different distances depending on where you direct the stimulus,
that is, one layer receives the focused images and the other receives them blurred. The
more out of focus the image appears in this layer, the closer the eye is to the object. This
detail allows the spider to calculate the exact distance it has to jump to catch its prey. The
second, third and fourth layers are responsible for color vision, and the first layer works in
high sharpness and shape perception. Combining the four layers, the spider has 3D vision.
Tricks
You can paint the ball white so that it looks more like an eye, as well as the iris around the
magnifying glass.
Related experiments
Experiment 3.6 From a shoebox to a camera
T
he functioning of our body is based on numerous chemical reactions. For example,
in the process of transforming the light signal that reaches the retina into a nerve
impulse, a chemical reaction also occurs. With this experiment you can verify and
alter these processes.
The retina is the part of the eye that receives the image information being viewed, just
like the sensor in a camera. So that all this information can be sent to the brain, the optic
nerve is used, the “cable” that communicates between both organs. The junction zone
between the optic nerve and the retina lacks photoreceptors, light-sensitive cells, making
it a blind zone. You don’t believe it? Check it out for yourself!
Procedure
Experiment with the light of a flashlight
1. With the help of the craft knife, cut
a simple figure on the cardboard (a
square or a triangle).
2. Get into a dark room.
3. Place the flashlight behind the hole so
that the light passes through the cut-
out area, without protruding from the
sides of the cardboard. Keep the card-
board upright by placing books on both
sides, for example.
4. Keep the cardboard and flashlight an
arm’s length from you.
5. Look at the bright hole for 30 seconds.
6. Next, look at a blank wall and blink Figure 4.2.1 Assembly of the experiment. The flash-
a few times. What did you see? What light is placed behind the cardboard.
color is it? Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
7. Now look at the palm of your hand and
again the wall. What’s the difference
between the two?
Explanation
What is happening in the first part of this experiment is that, by observing a bright light
for a long time, the retinal sticks become saturated. The rods contain a protein called rho-
dopsin, which is sensitive to light stimulation. When it receives light, it breaks, and in the
dark it forms again. By stimulating the protein with such light intensity, the regeneration
process takes longer, which becomes a few seconds of “blindness.” The saturation that
produced in the experiment is localized, and that is why the shape (the triangle or the
square) of the figure we have made in the cardboard is maintained. The image you see is
called a post-image.
In the second experiment, as long as you keep your eyes fixed on the cross, it will be
projected on the fovea, the point of maximum visual acuity, and everything around (in
α = arctan 12 or 15cm/d
In the third experiment, the distance (d) is an approximation, since it can be measured
from the vertex of the eye and not from the center of rotation, so keep in mind that this
value is always going to be somewhat greater. In this experiment, what is known as visual
persistence is tested. The eye and the brain both retain images for a small fraction of a sec-
ond. When you move the tube quickly, the brain retains the fractions of the images long
enough to form a complete picture of what you are seeing.
Tricks
• You can do even more with the post-images. Cover your eyes for 10 minutes. After
that time, uncover them, open your eyes and observe a well-lit scene for half a second.
Then close your eyes again. It will seem like even with your eyes closed, you can still
see the scene.
• You can complicate the post-image experiment a bit by playing with both eyes. Repeat
the same process, but this time observe the illuminated figure with only one of them,
keeping the other closed. Try looking again at the wall, first with one eye and then with
the other. You will see that this effect only occurs in the eye that has been exposed to
the great intensity of light.
• In the second experiment, to make it easier for you to measure the distance from your
eye to the paper, place positioning marks and place the paper on some support so that
the displacement is more uniform.
T
he perception of colors plays an important role in our life. In February 2015, the
photo of a dress began to circulate on social networks and caused a stir on the inter-
net. What was special about the dress? Apparently, it was a normal dress, but half of
the world’s population saw it as golden and white, and the other half saw it as black and
blue. You can search for the photo of the dress on the internet.
In this experiment, we will see how certain factors affect how we perceive colors and
how our brain can deceive us.
Procedure
Experiment with colored cards
1. Cut one of the orange cards and one of the blue cards in half. Do it so that you
take the blue of the darkest shade and the orange of the lightest shade. Glue two
of the halves of different color with
sticky tape and leave the part that is
not taped upside down. This will be
our new backdrop.
2. From the rest of the colors (except
grey, black, white and those you used
to make the background), cut out equal
squares of each color and a rectangular
strip (of the same colors).
3. Take two squares of the same color and
paste them at the same distance in the
background that you prepared in step 1.
Each square must be of a different
color. Repeat this step with all squares.
4. Ask a friend which color they think is
lighter or darker. Join the squares with
the rectangular strip of the same color
and show that, despite the background, Figure 4.3.1 Experiment with colored cards.
the color is the same! Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Explanation
Cones are responsible for processing color sight. We have three different types of cones
and each of them is sensitive to a different color. This makes us distinguish many colors,
but it also means we can confuse them. Therefore, if we place a light blue color on a dark
blue background, it will appear brighter, since the cones that process this color are centred
on the dark blue color that is in the background, and the rest of the cones are not that sen-
sitive to that color. Something similar is what happens in the experiment using grey with
black and white card. When changing the grey strips’ position, it can be seen that at some
point they appear to be the same shade of grey (when the two strips are parallel on black or
Tricks
• Try changing the backgrounds, put darker or lighter colors to see which background
causes what you place on top is perceived as lighter or darker. The contrast also works
in reverse: different colors may look the same.
• Try to take two similar but differentiable colors with the naked eye and find a back-
ground where both look the same.
MATERIALS
Image formation, refractive • A fish tank with water • Flashlight
1 h (+) defects, retina • A magnifying glass (if you • A letter printed on
don’t have one, you can place acetate paper, which will
a converging lens inside a leave an image
cardboard roll) • DIN A4 black-and-white
• A converging lens and a cardboard
divergent lens • Plasticine (optional)
T
he size of the eyeball and the shape of
the cornea have parameters that allow
the parallel rays that reach our eyes to
focus on the retina with sharpness.
When one or more of these parameters do
not comply with the rule, the images that
form on the retina are blurred. This is what
is known as refractive defects, as was seen
in Figure 4.9. Let’s experiment with myopia
and farsightedness!
Procedure
1. Cut a hole in the middle of the bottom
of the black cardboard. Paste the image
of the letter into this hole.
2. Place the magnifying glass behind the Figure 4.4.1 Materials.
black cardboard at a distance not far Photography: in house.
away.
3. In the same line of sight, place the fish-
bowl full of water and glue the white
cardboard on the side opposite to the one
closest to the magnifying glass. This will
be the retina of our experimental eye.
4. Once all the elements are located in a
straight line, light up the image with
the flashlight to form the image on the
retina (the screen). Move the magnifying
glass to form a sharp image of the letter.
5. You have created an emmetropic eye,
that is, an eye without refractive defects.
6. To simulate an eye with myopia, the Figure 4.4.2 Image formation in one eye.
retina will be removed from its initial Photography: in house.
position. In other words, the image will
be formed before the screen. You can check it with the help of an extra white cardboard.
Explanation
The refractive defect can be considered as a power error due to a mismatch between the
equivalent power (cornea, lens power) and eye length. For example, if the equivalent
power is too high for a certain eye length, the image is formed in front of the retina, and
this results in a myopic refractive error. If the power is too low in relation to the length of
the eye, the image is formed behind the retina and results in a hypermetropic refractive
error. To correct a myopic eye, a divergent (negative) lens is interposed, instead a hyper-
metropic or farsighted eye is corrected with a convergent (positive) lens (Figure 4.4.4).
Related experiments
Experiment 4.1 How does the human eye work? And that of other animals?
Both Eyes? Objective 2: Experience the third degree that gives rise to binocu-
lar vision: stereopsis.
MATERIALS
• A sheet of paper • 2 drinking straws
Binocular vision,
30 min (+) simultaneous vision, • Two pieces of cardboard • Two coins or cardboard circles
fusion, stereopsis, • Template for glasses of different sizes
distance perception • Red and blue tissue paper • Sheet of paper or cardboard of
• A shoe box with lid a color that contrasts with the
• Scissors inside of the shoe box
• Sticky tape or masking tape
I
f we have two eyes, it is not simply nature’s whim. Having binocular vision (Figure 4.10)
gives us an in-depth vision, but to reach this, it is necessary to fulfil a series of previous
degrees: simultaneous vision (first grade), fusion (second grade) and finally stereopsis,
that is, insight into depth (third grade). When a person does not have deep vision (it hap-
pens to 8% of the population) and, for example, is not able to watch 3D movies, it may be
because they fail any of the three degrees of binocular vision, but how can you know if you
have binocular vision?
Procedure
Simultaneous vision and fusion
1. Take the sheet of paper and roll it up.
2. Place it in front of your right eye (it will be easier on the left if you are left-handed)
and look through it as if it were a spyglass. You must keep the other eye open.
3. Tilt the tube slightly towards the nose.
4. In the middle of the tube place your open hand, with the palm facing you.
5. Move it along the sheet of paper. What happens? Figure 4.5.1.
Figure 4.5.1 Position and result of the experiment when you have binocular vision: a hand with a hole.
Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Correct distance?
1. Take the shoebox and remove the lid.
2. Cut an 8 x 13-cm window on one of the short sides of the box and make a hole in the
center of the cropped rectangle. The hole should be 0.5 cm in diameter, so you can see
through it with one eye.
3. Cover the window you made in the box with the rectangle. To do this, put sticky tape
at the bottom of the rectangle and paste it to the bottom of the window. The window
must be covered by the rectangle.
4. On the opposite side of the box (in front of where the window is), make a hole for each
straw. Make them the same height, with a little separation between them so the straws
are held in place.
Figure 4.5.3 Description of the assembly (left) and experimental assembly (right).
Sources: in house.
Explanation
In the first experiment, we are forcing each eye to see a different thing, with one the hole
and with the other the hand. If there is simultaneous vision, you will see both images.
If your brain also has the ability to merge, it will appear as if your hand has a hole (both
images overlap). The position of the hole on the hand depends on the distance at which
you have your hand with respect to yourself.
In the second experiment, your eye is again receiving two different images (anaglyphs),
one bluish and one reddish, but from the same scene. Also, if you look at the scene, the
images are laterally shifted with regard to each other. As the images are different, your
brain can merge them and give them depth. The more you move between them, the more
different they will appear, and the brain will give them greater depth. In the third experi-
ment, it is seen that, when looking only with one eye, depth perception is affected. It is
difficult to know which circle is farther away and how much. When checking with both
eyes, we see two different images (one for each eye), and that provides enough information
for our brain to analyze and discriminate the size, shape and distance of objects.
Tricks
On the internet, there are web pages to generate anaglyphs from your own images. You can
try it with a funny picture of yourself!
Related experiments
Experiment 4.1 How does the human eye work? And that of other animals?
D
ue to the extraordinary characteristics of vision, optical illusion games can be cre-
ated by using the underlying physical principle. As early as 1824, John Ayrton
Paris was aware of this and invented the thaumotrope, an apparatus with which
he intended to demonstrate retinal persistence but which eventually became a popular
game in Victorian England. The same happened with the zoetrope, created in 1834 by
William George Horner, after which the
same concept is hidden and which, in
this case, was the precursor of the begin-
nings of cinema. You can also build both
devices and see for yourself what John
and William already knew.
Procedure
Building a thaumotrope
1. Take a sheet of paper and fold it in
half.
2. Draw a fish on one side and a fish
tank on the other. Both drawings
must face the same way. Check that
the fish is smaller than the fish tank.
3. Paste the sheet, placing the straw
between both sides.
4. Spin the straw around quickly and
look at the paper. The fish is inside Figure 4.6.1 Thaumotrope on both sides.
the fish tank! Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Building a zoetrope
1. Glue the two ends of the cardboard.
2. Glue the cardboard rectangle on the
other side of the cardboard, so that a
cylinder (drum) is formed. With the
triangles on one of the edges, it will
be easier to give it the circular shape.
So that eyelashes are not visible, you
can cover it with the other circle of
black cardboard. Figure 4.6.2 Template to make the zoetrope.
Source: in house.
Explanation
Behind both experiments is the same principle: an image projected on the retina remains
in it a very small time, 0.1 seconds, before disappearing completely. If after this image
another one is presented, then the brain will interpret them as being together. In the first
case, the fish seemed to be inside the fishbowl, as the two images overlapped, and that is
why we can also build an illusion of movement through static drawings using the zoetrope.
Figure 4.6.4 Final result of the experimental setup and the moving image strip.
Photography: in house.
Tricks
For the first part, you can use infinite pairs of images: a bird and a cage, a fried egg and a
pan, a window and a face, a bouquet and a vase, the two sides of a coin...it’s up to your
imagination! The same happens in the second part: a balloon that flies, a person running,
someone putting a basket or a trapeze artist. You set the limits! On the internet, you have a
lot of options available that you can print and use.
What You See! Objective 2: Understand the illusion of Helmholtz, in its usual
format with squares of vertical lines and in its three-
dimensional human form.
O
ptical illusions are quite simple
phenomena that deceive our brain.
For example, a circle with a black
half and the other half white and black
lines drawn is a very simple structure that,
turning it quickly, will make you see dif-
ferent colors. This phenomenon is called
“Benham’s disk”, and there are people
who see red, green, blue, brown...And you,
what colors do you see?
Surely you have heard that vertical
striped shirts flatter the figure because
they make you look taller and thinner,
while horizontal striped shirts have just
the opposite effect, but is this true? With
only one piece of paper and a pen, you can
check this out. It is as easy as that!
Explanation
In Benham’s disk, there are only two colors, black and white. In order to see the color
white, the three types of cones must respond equally, however, in each person they have
different response times. As in this template, both colors, black and white, are alternating
rapidly, and each person sees different shades, as the color receptors respond. If we vary
the speed of rotation of the disk, we will see how the saturation of the colors we perceive
varies and, furthermore, if we vary the direction of rotation of the disc we will observe
how the colors are reversed.
Helmholtz (1867) found that a square composed of horizontal lines seems to be too
tall, and one composed of vertical lines seems too wide. This effect is observed in situa-
tions of everyday life, such as an empty
room that looks smaller than one that
is furnished, and a wall covered with
a paper pattern that looks larger than
an evenly painted one color. The exact
explanation is still unknown, but stud-
ies have been conducted, the last led by
the expert perception psychologist Peter
Thomson, in which this theory was con-
firmed. In human figures, this effect of
thinness or width is observed especially
in the hips; the vertically striped pattern
makes the hips appear wider, the outline
of the silhouette being the same, so it can
be denied that the vertical stripes have a
slimming effect.
Figure 4.7.4 shows an optical illusion Figure 4.7.4 Optical illusion of rotating snakes.
known as rotating snakes, created by Source: Wikimedia Commons.
Tricks
• Not everyone sees the same thing when the disc spins; try it with your friends.
• Search for optical illusions on the internet and discover how to cheat your brain in a
fascinating way!
Related experiments
Experiment 4.6 How do we see movement?
Light in nature
O
ptical phenomena in nature are generally caused by interactions between sun-
light and the atmosphere, clouds, water, dust and other particles and materials,
animals and plants, and even objects, both natural and man-made. From sunsets
to the rainbows, passing through the blues and green of the oceans and the astound-
ing variety of colors of animals and plants, nature unveils many examples of optical
phenomena.
Some are a consequence of the dual behavior of light as a particle and wave. Some
are easily observable, such as rainbows, and others can only be observed and measured
by precise scientific instrumentation, such as the curvature of a star by the sun dur-
ing a solar eclipse, demonstrating the curvature of space as predicted in the theory of
relativity.
139
be seen. In the pool, caustics are formed when the light passes through the waves of the
pool water. In optics, a caustic or caustic network is the envelope of light rays reflected or
refracted by a curved surface or object, or the projection of that envelope of rays on another
surface.
Is there natural
polarized light?
Standard light sources in nature emit
non-polarized light; however, there are
quite a few examples of the polarization
effect (which we discussed in Chapter 1)
around us. The usual way to polarize
light is through dichroism (Figure 5.3).
This phenomenon consists of the pref-
erential selective absorption of all the
components of the electric field, except
those parallel to the axis of the material.
Therefore, only the component paral- Figure 5.3 Dichroism diagram: the vertical component is
lel to its axis is transmitted through the transmitted, and the rest is absorbed.
dichroic material. The phenomenon of Source: Internal creation.
dichroism occurs naturally in some crys-
tals, such as tourmaline, which is highly
dependent on wavelength, or herapa-
Did you know...?
thite, in the form of very small crystals. Fishermen can go unnoticed by fish if they
The polarization of light can be eas- calculate the angle at which there will be total
ily detected by observing its reflection reflection. In this way, the fish will be unable to
through a linear polarizer that we place see them.
before our eyes. It is very interesting to
use polarized glasses to observe the rainbow, since the light that forms features a high
degree of polarization. The reason is that the angle of reflection that occurs inside the
drops of water that remain after the rain is very close to the Brewster angle, as was seen
in Chapter 1. The drops also produce a dispersive effect, giving rise to the colors of the
rainbow. In this way, in the rainbow, in addition to the chromatic separation, polarization
of light naturally occurs as well.
Areas of the blue sky can be seen that have a significant degree of polarization, caused
by diffusion into the atmosphere, which will be explained later. Photography enthusiasts
know that contrasting images can be obtained between the blue sky, clouds and landscape
by properly placing a polarizer in front of the camera lens.
Plants’ coloring
The color that each plant presents depends on the predominance of a pigment or the
combination of several. The green of the leaves is due to the presence of chlorophyll
(see Experiment 5.5), which is essential for photosynthesis, the process by which plants
Figure 5.6 The Aequorea Victoria jellyfish produces the green fluorescent protein (GFP) (left). The brightness visible in this
image is due to the reflection of the flash used to take the photo. Pyridinium bahamense is a type of unicellular micro-organism that
has the capacity to produce light in highly favorable environmental conditions and when its population has a high rate of growth. At
that time, when the water is moved, the light reaction occurs, as would be the case with the famous star beaches (right).
Photography: Adapted from the exhibition “A universe of light”, CSIC, 2015 (left). Bruce Anderson (University of Stellenbosch), BMC Ecology, 2013,
13: 6, doi: 10.1186 / 1472-6785-13 -6 (right).
convert sunlight into chemical energy. Most healthy plants are green since they contain
chlorophyll, a pigment that reflects the green component of light and absorbs the blue
and red components. Although a small part of this absorbed light dissipates in the form
of fluorescence, most is used to activate photosynthesis. The majority of the fruits and
vegetables are green, and as they ripen, metabolic changes occur that alter the color.
Chlorophyll degrades and other pigments appear, such as carotenes and anthocyanins,
which provide colors from pale yellow to orange and dark red. These pigments are vital
not only for the self-protection of the plant but also for the health of humans owing to
their antioxidant effects. Sick plants may undergo changes in the composition of their
pigments, causing color changes or light emission at different wavelengths than healthy
plants (Figure 5.9).
Figure 5.9 In ripe bananas, dead blackhead cells light up in fluorescent chlorophyll catabolites.
Photo: “Fluorescent chlorophyll catabolites in bananas light up blue halos of cell death”, Simone Moser, Thomas Muller, Andreas
Holzinger, Cornelius Lutz, Steffen Jockusch, Nicholas J. Turro and Bernhard Kräutler. Proc Natl Acad Sci U S A. 2009 Sep 15;
106(37):15538-43. doi: 10.1073/pnas.0908060106. Epub 2009 Sep 8.
Figure 5.11 White light passing through a drop of water and decomposing in the different colors that compose it and
bring about the rainbow.
Source: Camilo Florian Baron.
A green flash is more likely to be seen in stable, clear air, when more of the light from
the setting sun reaches the observer without being scattered. The possible “blue flash”
occurs because the light of that color is not seen, as blue colors disperse more in the air
and only the green light remains. To see the green ray, you must have a perfect view of
the horizon, that is, being on a beach during sunset. Even so, you must be patient to see
it, as it does not occur every day and is difficult to see.
Figure 5.17 Example of light pollution: aerial view of the large city of Madrid (left) and the much smaller town Santiago
de Compostela (right).
Photography: in house.
MATERIALS
• Pencil • 1 kg sugar
Refraction • Glass • 2 L of water
15 min (+)
• Transparent rectangular • Laser pointer
beaker as long as possible
M
irages are optical phenomena that
occur under particular conditions
and that cause us to see things
where there are none. Who has not seen
in a movie someone in the desert run to
drink water and, when they reach where
the water should be, there is only sand?
Formerly, it was believed that mirages such
as the fata morgana were works of witch-
craft to attract sailors to their death.
Procedure
Figure 5.1.1 Example of mirages.
Does light travel in a straight line? Photography: Adapted from the exhibition “A universe of light”,
CSIC, 2015.
1. Put a liter of water in the beaker.
2. From one end of the beaker, turn on the laser pointer.
3. You can verify that the laser light travels in a straight line through a homogeneous
medium.
Explanation
As we have seen in previous chapters, light
travels in a straight line within the same
medium. As a result of this, our brain inter-
prets that light always travels in a straight
line and that is why we see mirages. Figure 5.1.3 Laser beam going through a beaker
However, when we can differentiate two with sugar dissolved in water.
media, such as water and air, we no longer Photography: in house.
associate that light travels in a straight line,
because we are able to see the difference in medium and we know that the speed of light
changes with the index of refraction, as we have seen in Chapter 1.
The mechanism by which we have been able to bend a laser beam is similar to the one
that causes the appearance of mirages. In our experiment, the different refractive indices of
fresh water and sugar-saturated water create the laser beam curve. This is similar to what
happens with mirages, where the density of the different layers of air is different, caus-
ing the rays to refract, although visually the difference between the different layers is not
noticed.
Tricks
• Try turning off the light: you will see how the laser beam bends more clearly.
Furthermore, you can try different laser colors!
• Take a longer rectangular beaker to better see how the laser beam curves.
Related experiments
Experiment 3.9 A micro-world in a droplet
A
s we have seen throughout this book,
optics are present in many of our
daily activities, even in summer,
when we go to the pool or when we drink
a glass of water. Have you ever wondered
why sometimes it seems that the water is
“cracked”? Surely, once, while diving in
a pool or at sea, you have noticed that the
surface became a mirror. In this experi-
ment, you will learn why.
Procedure
Figure 5.2.1 Caustics observed on the bottom of
Making homemade caustics a pool.
1. Fill the bottom of the glass with water. Photography: Pixabay.
2. Light up the glass with white light and
watch what happens when the light passes through the glass.
3. Move the glass and observe the changes that occur in the light that passes through the
water.
Water observation
1. Dive into the pool, preferably with div-
ing goggles, and, from a few cm below
the surface of the water, look up at dif-
ferent angles; do you see something
different according to your angle of
vision?
2. Dive to different depths and see what
happens.
Tricks
• If the day is cloudy or you are in a room
with low light, you can use a flashlight
to observe the caustics in the cup more
easily!
• If you want to see another effect on Figure 5.2.3 Total reflection underwater.
caustics, add some milk to the water!
Photography: Jean-Marc Kuffer, WiKimedia Commons.
• If instead of diving in the pool, you can
do it in the sea; you can observe the
phenomenon of total reflection in the
fish or algae that you have around you.
You can use it to take some amazing
photos! You can search the internet for
how a fish sees underwater due to total
reflection.
M
any times, we observe bright and
changing colors in everyday phe-
nomena, such as soap bubbles, an
oil stain on the road or in some animals.
The thin layers suffer the effect of interfer-
ence: depending on the angle of incidence
of light, we will see different colors.
Procedure
1. Fill a beaker with water and dip the
black cardboard to the bottom; keep it
submerged at the bottom of the bucket.
In the subsequent steps, you have to
be fast so that the cardboard does not Figure 5.3.1 Formation of giant soap bubbles.
soften too much. Photography: Xoana Barcala Gosende.
2. Put two or three drops of clear enamel
on the surface of the water.
3. Wait for the enamel drops to expand onto the largest possible surface of water.
4. Collect the enamel film with the black cardboard on the bottom, being careful to keep
it as even as possible.
5. Wait for the cardboard to dry.
Explanation
When a beam of light strikes the outer
layer of the soap bubble, part of the light is
reflected by going to the eye of the observer,
and another part is refracted through the
water layer to its innermost part. In that
innermost part we find another process
of refraction and reflection, The beam
reflected from the last layer of the soap bub-
ble has to pass through the first layer again Figure 5.3.2 Manufacturing process of the thin
and reaches the eye of the observer paral- sheet in a black cardboard.
lel to the first reflected beam. The different Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Tricks
• Write letters on the black cardboard, glu-
ing pieces of tissue paper. Dip it in the
water. When collecting the enamel drop
with the cardboard, it will only stay in
areas where there is no heat. This way
you can write an iridescent message.
• Make soap bubbles and observe the dif- Figure 5.3.4 Diagram of refraction on each of the
ferent colors depending on how the light surfaces of the soap bubble.
affects them. Photography: Camilo Florian Baron.
Related experiments
Experiment 1.4 Is light really a wave?
I
n nature there are multiple examples
of fluorescent organisms. The jelly-
fish Aequorea victoria produces a fluo-
rescent protein called green fluorescent
protein (GFP) because it emits green
light. Researchers Martin Chalfie, Osamu
Shimomura and Roger Y. Tsien were
awarded the 2008 Nobel Prize in Chemistry
for the discovery and development of GFP,
which is used to mark other proteins in
vivo.
Quinine, which is also fluorescent, was
used as a remedy for malaria. This is a mol-
ecule that comes from the red cinchona
tree and is bitter to the taste. Nowadays, it
is used to give tonic its characteristic bitter
taste. Minerals also contain many fluores-
cent specimens. The phenomenon of lumi-
nescence allows us to introduce apparently
invisible marks in banknotes and other
official documents that appear only under
ultraviolet light.
1. Serve tonic in a glass and illuminate it with ultraviolet light. You will see the tonic
fluorescence.
2. While illuminating the tonic with ultraviolet light, add a little ammonia to the tonic.
What has happened?
3. Illuminate minerals with ultraviolet light. You will see that they change color. If you
don’t have this material, take a look at the pictures.
4. Take one of the sticks and fold it in half. Light! You will see that little by little, the
whole stick lights up and shines. Hence the name “glow stick”.
Tricks
Now you know why in some supermarkets
they illuminate with a purple lamp the
banknotes you use to pay. The purple lamp
is ultraviolet and...they are checking that
the notes are not fake! If you do not have an
ultraviolet lamp and you cannot buy one,
take advantage when you go to the super-
market and ask them to let you see it in
action.
Related experiments
Experiment 5.5 Chlorophyll, green?
Experiment 6.4 Does my olive oil have
antioxidants?
MATERIALS
• Plant with large green leaves • Fresh spinach leaves
• Tin foil • Strainer
Photosynthesis, • Iodine for wounds • Mixer
30 min (+) fluorescence • Pot • Transparent glass
• Ethyl alcohol • UV light flashlight
C
hlorophyll is found in the chloroplasts
of plants. During the day, when plants
receive light, oxygen is produced
through photosynthesis. In this experiment,
we will see what happens when a plant
does not receive light, and what the chloro-
phyll hides.
Procedure
Observe degraded chlorophyll
1. Make an envelope with the foil in
which one of the leaves of the plant
fits. You can make more than one enve-
lope and thus cover more than one leaf.
2. Wait a week and uncover the leaves of
the plant. What has happened? If the
leaves remain green, leave the enve-
lopes in place until the leaves wilt.
Figure 5.5.1 Leaves covered with tinfoil.
3. After observing the differences between
Photography: in house.
the leaves you covered and those that
you did not, boil one of the leaves that
you covered and another one that wasn’t covered for 30 seconds. Mark them to distin-
guish between them. You can remove the petiole from one of the two, for example.
4. Put them in a jar with alcohol overnight.
5. Check that there is no chlorophyll in any of the leaves (when they have lost the green-
ish color) and immerse them in a solution that has the same proportion of water and
iodine. Do both leaves have the same color?
Explanation
In the absence of light, chlorophyll is not
Figure 5.5.2 On the left and in the center tubes
synthesized, it degrades, and the leaf turns
with fluorescent paint dissolved, and on the right the extract
brown. This happens when you put the of chlorophyll, under ultraviolet lighting.
leaves in the tin foil.
Photography: in house.
Starch is the sugar that is produced dur-
ing photosynthesis. Iodine reacts with
it, resulting in a bluish compound. Therefore, it indicates whether photosynthesis has
occurred in the leaves or not. When mixing with iodine the leaf that was covered with
tin foil, it simply stains and becomes brown, but does not react because it has no starch.
However, the leaf that was not covered and had its chlorophyll in perfect condition, did
photosynthesis and therefore had starch, which reacts with iodine.
When illuminated with sunlight, chlorophyll looks green, as it absorbs all wavelengths
except that corresponding to the color green. However, with ultraviolet light, part of the
absorbed light is emitted in the form of heat, meaning that the energy of the emitted light is
less than that absorbed. For this reason, chlorophyll looks red.
Tricks
• Make a small hole in the foil envelope. You can make different shapes. In this way, the
leaf will have a green part with the shape that you have made in the hole.
• Remove the tin foil envelope from one of the covered leaves. Does chlorophyll reoccur
on that leaf?
Related experiments
Experiment 5.4 The light hidden by nature
Experiment 6.4 Does my olive oil have antioxidants?
A
s we explained in Chapter 1, light
travels in a straight line unless the
materials in its path modify its tra-
jectory. In the case of sunlight, which we
could call white light (it contains all colors,
including red, yellow, green, blue), when
it enters the atmosphere it undergoes color
changes, giving the violet-blue color to the
sky in a clear day and the typical reddish
color at sunset. What happens is that the
light interacts with the gas molecules in
our atmosphere and they scatter the light.
Figure 5.6.1 The dispersion of the rays of light
Because the wavelengths of the violet-blue
coming from the sun in the particles of the atmosphere pro-
colors are the shortest (400 nm), they scat-
duces the typical reddish color of the sunset.
ter about ten times more than the yellow-
Photography: Pexels.
red light (in addition to a resonance effect
with the molecules of the atmosphere that
favors the blue light emission).
On the other hand, when the sun is on
the horizon, at sunrise or sunset, light trav-
els a longer way through our atmosphere,
so most of the light of other colors is scat-
tered, leaving mainly red, orange and yel-
low colors found at sunrise and sunset.
In this experiment we will try to simu-
late the particles of the atmosphere to get
the effect of a blue sky and a reddish sun-
set. So let’s start!
Procedure
1. You must do the experiment in a dark
and closed space, with the lights off.
2. Put enough water in the transparent
container, but do not fill it to the brim Figure 5.6.2 Experimental setup.
because then you must shake it, and Source: Camilo Florian Baron.
you must avoid it spilling.
Figure 5.6.3 Container with the water displayed in profile (top left) and aligned with the light source (top right). After
adding a little milk and dissolving it homogeneously, the profile image turns white-bluish due to the scattering of the blue
light (bottom left) and the light that is aligned turns reddish yellow, just like at sunset (bottom right).
Photography: in house.
3. Place the white light source at one end, as shown in Figure 5.6.2. The points where
you will observe the effects of milk on the water are located laterally to the axis of illu-
mination and in line with the source.
4. Slowly, add a few drops of milk. Use the spoon to stir the water and homogenize the
solution.
5. Now, you will have a mixture of water and milk with grey color. Add a little more
milk until you see on the sides that the white light disperses, giving the mixture a blu-
ish color.
6. Once you manage to adjust this color, look towards the light through the container,
and you will see that the white light turns yellow or somewhat reddish. What you
are viewing laterally is the analog to the color that the sky has during the day. On the
other hand, when you look at the light source through the mixture that you have cre-
ated, you are simulating the conditions that occur during the sunset, since the sun’s
rays pass through the atmosphere, scattering mostly the red and orange wavelengths
in that direction. That’s why we see that color.
Tricks
• Be careful when you are mixing the milk in the water. If you add too much, the whole
solution will become too dark to appreciate the effect, and you will have to reduce it
by adding more clean water.
• You can use the flash of your phone as a source of white light.
Related experiments
Experiment 1.2 Breaking light: Newton’s prism
Experiment 5.3 Where do those colors come from?
S
ince the beginning of the last century,
lighting has been damaging our skies.
The glow of artificial light, caused by
improper use of lamps or streetlights, sends
light directly and indirectly to the sky,
which is known as light pollution.
Procedure
1. Cover all slats in the box with dark
masking tape.
2. Make small holes with a sharp ele- Figure 5.7.1 Night photo of the Madrid skyline.
ment at the top of the box to create the Photography: Maxpixel.
planetarium.
3. On the opposite side of these holes,
that is, at the bottom of the box, make a small hole to insert the flashlight.
4. Switch on one of the flashlights and insert it into the hole you have just made. You
now have a small planetarium that you can project on a low ceiling or on the shelves
of a bookcase in a dark room.
5. Place the other flashlight near your
planetarium. This must be on and
pointed towards the starry sky that you
formed in the previous step. This flash-
light will simulate a lamppost.
6. Place a soft drink cap or a small “hat”
made of aluminum foil on top of the
flashlight. Do you notice any difference?
Explanation
Light pollution takes place when you see
a glow of light in the sky produced by the
reflection of artificial light in the gases and
very light particles that are suspended in Figure 5.7.2 Holed box to simulate a planetarium.
the air. That same glow makes the night less Photography: Eliezer Sánchez González / Scientific Culture (CSIC) /
IOSA.
dark, and then the starlight “disappears”
progressively from our sky. We say that they “disappear”, since we cannot perceive the
stars that shine with less intensity. The upper screen that is put on the streetlamps pre-
vents much of the light they emit illuminate the sky. In this way, light pollution decreases.
Tricks
If you want it to look even cooler, you can use a celestial planisphere to place the holes in
your planetary box.
T
he light of the stars and, in particular,
that of the sun have always captivated
mankind. From the origins of astron-
omy, starry nights became the perfect labo-
ratory where it was sought not only to find
our place in the universe, but also informa-
tion about its origin.
During the day, when the sun is just
above our heads, its light causes curious
scenarios: the shadows it produces hardly
change size when an object is placed in
its path, contrary to what happens with
candlelight or that of a flashlight, for exam- Figure 5.8.1 Projection of the shadow of four
ple, whose shadow increases in size as it people at the foot of a mountain. Despite the distance, the
approaches the light source. This type of shadows remain the same size as the people.
light, coming from the sun and the stars, Photography: in house.
both located at very far distances, can be
understood for practical purposes as collimated light. In this case, the light rays are paral-
lel to each other due to the great distances from their origin (the stars). This means that
the projection of a shadow produced by an object that opposes its path remains virtually
unchanged over great distances.
Procedure
As mentioned, the shadow produced by the tree when sunlight falls on it does not change
size when projected at a certain distance. Therefore, we can use it to estimate its height.
What we must do is simply measure some distances and relate them to the known distance
of the cardboard tube.
1. It is essential to try this on a clear day, with the tree’s shade as clearly defined as pos-
sible. Place the vertical cardboard tube on the ground, so that the tree’s shade barely
touches the top of the cardboard tube, as seen in Figure 5.8.2.
2. Now, let’s measure! With the help of the measuring tape, you must measure the dis-
tance between the cardboard tube and the end of the shade of the tree that forms on
the ground (Figure 5.8.2, B') and also measure the tube (Figure 5.8.2, A').
3. You have formed a right-angle triangle. Therefore, using trigonometric identities you
can make a very simple calculation to find the angle that is formed between the shade
Tricks
At first, compare the values obtained in
your calculations with the height of a
known object, such as your height. In this Figure 5.8.2 Diagram of the triangles formed with
way, you can validate your procedure and the shade produced by the tree, the pencil (in our case, a
move on to measuring things that you cardboard tube) and the distance to the base of the tree.
really do not have information about, such Source: in house.
as the height of a lighting pole, a tree or a
building. Why not?
Related experiments
Experiment 1.1 Does light travel in a straight line?
Light-based technologies
M
any times scientists hear the comment: “Very interesting, but what is it for?” Well,
if thus far we have not managed to convince you of the importance of optics and
photonics, we hope that after this chapter you will be in no doubt, since both in
our everyday lives and in the most avant-garde research there are infinite applications and
technologies based on light that improve our quality of life and enrich our world.
In Chapter 1, we described how light is a form of energy and that it can behave as a
wave and particle. Furthermore, in Chapter 2 we have seen its different forms in the EM
spectrum, where only a small portion is visible to the human eye. From the use of the vis-
ible spectrum we can give numerous examples that range from television or any other type
of screens to lighting, but it has also been possible to develop numerous applications for
the benefit of society that use the spectrum of light that humans cannot see, such as X-rays
or ultraviolet rays.
Thus, the knowledge of the properties of light by scientists has led us to develop
different applications in fields as diverse as communications, agriculture, energy, secu-
rity, health, the environment or art, amongst others. Amongst the simplest and everyday
applications of optics and photonics, the lighting and sensors of smartphones stand out
(see Chapter 2) or the construction of different optical instruments (see Chapter 3). In
addition, it should be noted that in optical discs (CD, DVD or Blu Ray) the information
is saved and read thanks to a laser, and there are other technologies that also use elec-
tromagnetic radiation, although at frequencies outside the visible one, for communica-
tions applications (Wi-Fi or remote controls) or energy (microwave oven, as is used in
Experiment 6.1). Therefore, in this chapter we will try to give some examples of how
light improves and enriches our world in different applications and its potential use in
the future.
Light in telecommunications
How does the internet work?
Light-based technologies, especially those related to fiber-optic communications, are
essential for the exchange of information. Following the legacy of the telegraph and tele-
phone, fiber optic cables have replaced copper cables since they can carry a greater amount
of data and faster than their electronic counterpart.
In optical communications, information encoded in a beam of light is sent through a
glass or plastic wire known as optical fiber. This system was originally devised for endo-
scopes in the 1950s, with the goal of helping doctors see the inside of the human body
175
Figure 6.1 Diagram of an optical fiber (left). Light traveling through optical fibers (right).
Photography: Groman123, Flickr
system and the Chinese BeiDou are the satellite network systems that tell you your posi-
tion in real time if you have a signal receiver. These systems are based, among other fea-
tures, on precise optical clocks that use the fundamental properties of the decay of the
caesium or rubidium atoms. The future European Galileo system will use lasers (micro-
wave lasers) that will improve its accuracy (Figure 6.2).
The satellites emit signals constantly, marking their position at every moment
throughout the day. The corresponding receivers on Earth, for example, your mobile
phone, configure these signals to determine the exact location of at least four of these satel-
lites. With this information, the system is capable of calculating your specific longitude,
latitude and altitude on the Earth’s surface.
Light is energy!
Solar technology, a great source of energy
available to everyone. How can we use it?
On Earth, life in all its forms ultimately depends on the light and energy radiated by the sun.
Recently, humanity has made important advances in the understanding of how to acquire
and store the enormous energy of the sun to power our infrastructure, homes and industries.
There are two ways to collect solar energy:
• Indirect: an intermediate step is used before obtaining usable energy. This example
is found in solar thermal energy, where sunlight is used to heat a liquid that moves a
turbine.
The first reference of the use of solar thermal energy is due to Archimedes (3rd century BCE),
who during the battle of Syracuse would have used parabolic mirrors to concentrate the solar
rays on the sails of Roman ships, with the aim of making them burn. Currently, cylindrical-
parabolic collector mirrors are used that concentrate the light in a tube that passes through
the focus of these mirrors, which contains a liquid that, when heated, is taken to a tank that
evaporates water and moves a turbine, producing electricity. In Experiment 6.5, you will
have the chance to make a solar oven.
• Direct: for example, solar cells that convert light directly into electrons. This type of
energy is called photovoltaic energy.
New materials
New materials are also being developed that interact with light in exotic ways, such as, for
example, the so-called metamaterials, which, as indicated by their suffix, are artificially
created materials (they do not exist in nature), as shown in Figure 6.4. They consist mainly
of very small metal structures compared to the wavelength of light. And it is the geom-
etry of these structures that governs their electromagnetic properties, that is, the material’s
interaction with light.
What at first glance might seem like a simple trick of the light led to an important amal-
gam of new physical phenomena and a number of applications, such as the construction of
flat lenses or the possibility of obtaining super-resolution, that is, exceeding the diffraction
limit, which could mean increasing the capacity of information storage systems. But per-
haps one of the most striking properties is the possibility of obtaining invisibility more
effectively than we learned in Experiment 3.5.
Thus, a group from Duke University in the United States explored the possibility of
creating a metamaterial layer around an object in such a way that it transformed the path
of light to surround it and continue as if there had been no such object, which would
remain invisible to an outside observer. This first tasks were performed in two dimen-
sions and for microwaves; new studies are being carried out in the visible spectrum and in
three-dimensional situations. While much remains to be obtained for a cloak like the one
that made Harry Potter invisible, the door to science fiction has been once again opened,
and the chimera of invisibility may be a little closer.
LED light (see Chapter 2). During harvest times, laser-guided machinery maximizes crop
harvesting.
Remote sensors from different sources such as satellites or drones can produce more spe-
cialist information. Thus, the hyperspectral image, the one that captures the light beyond the
optical range by increasing the bandwidth, provides us with useful information regarding
areas with different crops, risk of fire or floods or even illegal drug crops (Figure 6.5).
• Endoscopy typically uses a camera with a lens and white light that is inserted into
the body with a cable (endoscope) through a natural orifice (such as the mouth, anus
or genitals) or through a surgical incision. The organs that are often viewed with this
technique are the stomach, intestine and gallbladder. In recent years, the use of the
so-called endoscopic capsule is also being disseminated, which incorporates a tiny
camera that patients can swallow and transmits images to doctors.
• Optical coherence tomography (OCT) is an imaging technique that allows for the view-
ing and quantifying of three-dimensional tissues of the human body with microscopic
Another commonly used and non-invasive technique to monitor the amount of blood
oxygen uses a device called an oximeter that rests on the tip of the patient’s finger. The
oximeter uses two LEDs (see Chapter 2) of different wavelengths that send pulses of light
capable of crossing the patient’s skin. The measurement of the absorbed light allows us to
determine the level of oxygen in the blood.
Alongside the techniques described above, commonly used in hospitals, there are oth-
ers that are still in the research phase, such as optical biopsy. Unlike traditional biopsies,
where a tissue sample is sectioned and then analyzed if the tissue shows any signs of a
tumor, an optical biopsy aims to analyze the tissue in the body itself by direct skin imaging
paint. For example, X-rays (shorter wavelength) reach the deepest layer of the painting, as
far as the frame that supports it. Visible light (VIS) only manages to penetrate the surface
layer of the paint, while infrared (IR) wavelengths get through the surface layers until they
reach the drawing on the canvas.
What is more, thermal cameras (which detect the infrared wavelength) are used to ana-
lyze historic buildings and works of art instead of traditional cameras since they can detect
water damage or cracks below the surface.
Figure 6.13 A half-scale version of the ExoMars rover, called the ExoMars Testing Rover (ExoTeR), seen maneuvering
itself carefully through the red rocks and sand of the 9x9-m Planetary Utilization Testbed, part of ESA's Planetary Robotics
Laboratory at its ESTEC technical center in the Netherlands, as a test of autonomous navigation software destined for ESA's
ExoMars 2020 mission to the Red Planet.
Photography: European Space Agency
M
icrowave ovens are one of the most common optical technology applications that
we use in our daily lives. Water molecules stand out for the absorption power of
photons present in microwave energy. Therefore, the food’s water is heated, and,
as a consequence, all the food becomes evenly hot. In this experiment, you can check the
operation of the microwave oven thanks to the microwaves and even calculate with it the
speed of light.
Procedure
1. Remove the rotating device from the
microwave. It is important that the
plate and the chocolate bar do not
move.
2. Place the chocolate bar on the plate
and place it in the microwave so that
the longest side of the bar is parallel
to the door. In some microwaves it is
necessary to place the chocolate at a
Figure 6.1.1 Operation scheme.
certain height so that the experiment
Source: in house.
works properly (Figure 6.1.2). This is
because microwave waves do not reach
all points of the microwave oven.
3. Heat at maximum power for 20-40 sec-
onds or until you see that the chocolate
begins to melt at certain points. Make
sure the dish and chocolate do not
rotate during microwave operation.
4. Remove the dish from the microwave
and measure the distance between the
center of the two melted points with
the ruler. If you do not see well where
it has melted, you can prick it a little
with a toothpick, so you will notice
the consistency differences more
clearly (Figure 6.1.3). The first image Figure 6.1.2 Microwave with chocolate over the bowl.
shows how the chocolate should look Photography: in house.
Explanation
This type of oven generates electromag-
netic waves in the range of microwaves
that heat food. These waves cause a vibra-
tion in the water that can be more or less
energetic following a periodic pattern. If
we eliminate the mechanism that allows Figure 6.1.3 Chocolate melted after heating in the
the food to rotate inside the microwave, we microwave.
will produce a non-uniform heating in the Photography: in house.
food. The chocolate points that have melted
correspond to the nodes of the wave, which
are one-half wavelength apart. By knowing that the speed of light (c) corresponds to the
multiplication of the frequency (v, known) and the wavelength (λ, measured), we can cal-
culate the speed of light: c = λ · v
In a microwave oven, the magnetron generates electromagnetic waves in the microwave
range, usually at a frequency of 2.45 GHz. Every electromagnetic wave transfers part of its
energy to the medium in which it propagates. Water is a polar molecule, that is, it has a
slightly negative charge near its oxygen atom and a slightly positive charge near its hydro-
gen atoms. This causes the water molecules to vibrate with the EM field and, therefore,
suffer a greater transfer of energy.
By eliminating the rotating part of the microwave, this transfer is not constant through-
out the entire food but rather follows a periodic pattern. The maximum, minimum and
nodes of this pattern are repeated at a distance that depends on the microwave’s wave-
length and, indirectly, on its frequency and the speed of light by means of the formula:
c = λ · v.
Related experiments
Experiment 2.5 Beyond the visible: IR radiation
Experiment 1.4 Is light really a wave?
MATERIALS
Total reflection, • Clear plastic bottle
30 min (+) Snell's law, light • Laser pointer
transmission • Scissors, cutter or similar
• Cube
I
n optical communications, light travels through optical fibers thanks to the process of total
internal reflection. Water acts similarly to fibers, and if a beam of light strikes a water jet at a
certain angle; we can see how the light is confined within the jet traveling with its same curva-
ture. An example where we can observe this phenomenon is the source of colladon, also known
as Tyndall’s experiment. With this experiment, you can make your own Colladon source.
Procedure
1. Take the clear plastic bottle and make a
small hole near the bottom.
2. Place the laser pointer at the point
opposite the side where the hole is.
Make sure that the laser light beam
goes out through the hole we made in
the bottle.
3. Cover the hole with your finger or a
piece of masking tape.
4. Fill the water bottle, turn on the laser
and uncover the hole. You can already
see a beautiful light source (Figure 6.2.2).
5. Make sure the water falls on the bucket
to be able to reuse it.
Explanation
The water-air surface acts as a mirror in
which the light is reflected and therefore
follows the path of the water. At the point
where the water jet falls into the bucket,
a point of light is observed. As the bottle
empties, the point of light will move with
the water until there comes a time when the
jet has excessive curvature and the light is
no longer confined, continuing its path in a Figure 6.2.1 Colladon fountain.
straight line. In an optical fiber, light travels
Source: Jean-Daniel Colladon, reproduced in the journal The Nature
in a similar way. (1884).
Related experiments
Experiment 1.1 Does light travel in a straight line?
Experiment 6.3 Listening to light: optical communications system
MATERIALS
• LED • 470-Ω resistor
• Photovoltaic cell • Speaker
Communications,
30 min (+) modulation, light • Jack–jack cable • Sound transmitter
transmission • Cable and wire stripper, (radio, smartphone or
or scissors and pliers microphone)
• 9V DC battery • Audio amplifier (optional)
J
ust like a microphone transforms our voice (a vibration) into electricity, we can use
this electricity to modulate the light and transmit that information. In this experi-
ment, we will design an optical communications system in which the information is
transmitted by an LED (light-emitting diode). Similarly, with lasers in free space, certain
satellites communicate. An example of this is ESA’s ESRS system (Figure 6.3.1).
Procedure
1. Connect the LED in parallel to the bat-
tery and the resistor. Make sure the
polarity of the LED is suitable (the long
pin is the positive pole) (Figure 6.3.3).
2. Use the jack–jack cable to connect the
radio in parallel. The jack connector
has three different parts (two if not ste-
reo). The part closest to the cable is the
ground, which you must connect to the
negative output of the LED. The other
two parts carry the sound, meaning you
can connect either to the positive side.
3. Connect the photovoltaic cell to the
speaker. Figure 6.3.1 The European EDRS (European Data
4. You may hear the sound very faintly. In Relay System) system developed by the European Space Agency
that case, connect an audio amplifier (ESA) and Airbus.
between the photovoltaic board and the Source: ESA.
speaker to increase the volume.
Explanation
Every communication system contains a sender and a receiver. The emitter of our sys-
tem, the LED, generates a beam of light that contains the information of our voice or the
music that we are playing. On the other hand, the detector, the photovoltaic cell, detects
that information and transforms it back into electricity, which will be transformed into
sound through the loudspeaker. If we put an object between the LED and the photovol-
taic cell, we will observe that the communication is interrupted, and therefore the music
can no longer be heard.
Tricks
• We can replace the LED diode with a laser pointer. Due to the characteristics of the
lasers, we will have a much higher sound quality.
• If you have an optical fiber, you can try to couple the LED or laser light and take it to
the photovoltaic cell. In this way, you will avoid obstacles and get better sound qual-
ity in the speaker.
Related experiments
Experiment 6.2 A stream of light: Tyndall–Colladon experiment
MATERIALS
• Extra virgin olive oil
• Sunflower oil
Fluorescence, power, • Glass containers or beakers
30 min (+) optical technology
• Green laser pointer
O
live oil is unique compared to other
oils, since it is the product of a fruit
and not of a seed. Thus, it has a dif-
ferent constitution, particularly with respect
to its flavor, but also due to the major pres-
ence of antioxidants and natural pigments.
It is the central product of Mediterranean
cuisine and is treated as a “healthy oil”.
In this experiment, we will analyze the
presence of antioxidants in our olive oil
by fluorescence. As previously mentioned,
fluorescence can be applied as food control
technology, since it does not imply a dete- Figure 6.4.1 Olive grove.
rioration of the food product, as there is no Photography: Stocksnap, Pixabay.
contact and possible degradation.
Procedure
1. Place olive and sunflower oils in separate containers. Add another container with
water.
2. Pass the green laser beam through the
different oils.
3. View how the fluorescence changes
from one oil to another.
4. As an additional study, you can see
how it affects extra virgin olive oil left
in the sun for a week or that has been
heated several times (always heat the
oil with adult supervision, since you
can burn yourself).
Explanation
Some olive oils may contain chlorophyll. Figure 6.4.2 From left to right: water, sunflower oil
These oils are usually greener than those and olive oil with green light.
that do not contain it. Although chlorophyll Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Tricks
• Find a dark place to observe the effect more closely.
• Change the order of the oil containers. If you put olive oil in front of sunflower oil,
you will notice that olive oil absorbs more than sunflower oil.
Related experiments
Experiment 5.5 Chlorophyll, green?
T
o cook food, electricity or fuels such as natural gas or firewood are required, which
in some countries or remote places are often not available. An alternative to cook-
ing with cheap and renewable energy is solar energy, which you can also use almost
anywhere. In addition to solar energy, you need a solar oven to boost the calorific value
of the sun. The diffusion of solar ovens for cooking food took place in rural areas of India
during the fifties of the last century. The United Nations has also promoted the use of solar
furnaces in refugee camps, as a result of military conflicts in different parts of the planet.
Next, we will describe the process of building a solar oven with low-cost and affordable
materials.
Procedure
1. Cut the ends of the flaps of the large box so that they are trapezoid shaped and line
them with the foil, as shown in Figure 6.5.2. Try to avoid creases or wrinkles in the tin
foil for better operation of the solar oven.
2. Cut out the flaps of the small box.
3. Cover the inside of the small box with black cardboard.
Figure 6.5.1 Diagram of the experiment. Figure 6.5.2 Final assembly of the solar oven.
Source: in house. Photography: Eliezer Sánchez González / Scientific Culture (CSIC) / IOSA.
Explanation
The solar oven uses sunlight to heat the air in a thermally insulated space. The air temper-
ature in the oven increases by reducing the possibility of heat loss. This same effect hap-
pens inside a car when left closed and in the sun for a long time. The temperature inside
the oven can exceed 100°C.
Out of all the energy of the sun that reaches the Earth, the one that has a wavelength
in the infrared can manage to heat the objects. In particular, infrared radiation can be
absorbed, reflected or transmitted according to the type of material it passes through.
In general, transparent glasses and plastics largely allow almost all the solar radiation
that passes through them to not be absorbed. Instead, the rest of the bodies absorb a part
of the radiation that reaches them and reflect the remaining part. Black objects absorb
all solar radiation and become warmer than other objects. The solar oven we have made
bases its principle on the accumulation of heat generated by the sun’s rays. The rays that
pass through the glass or plastic lid are absorbed by the oven walls, which are black. This
causes the air inside the oven to heat up, and when there is a lid covering it, the heat can-
not escape. This effect is called the greenhouse effect. Furthermore, the presence of the
reflective exterior surfaces increases the area of sunlight capture, reflecting many of them
inside the oven.
Tricks
• With the solar oven, you can prepare the same recipes that are made in a conven-
tional oven, although in some cases you can reduce the cooking time by making cer-
tain tweaks. For example, it is advisable to reduce the amount of water in the recipe
and cut the food into small pieces.
• You can put a kitchen thermometer inside the solar oven to know what the tempera-
ture is and thus have a more precise idea about the time needed for cooking food.
Related experiments
Experiment 6.6 Obtaining electricity from the sun: build a photovoltaic cell
Experiment 6.7 Desalinate water for free
from the Sun: Build a Objective 2: Understand what mechanism occurs inside the pho-
tovoltaic cell.
Photovoltaic Cell MATERIALS
• Two strips of copper or • A spoon
aluminum or copper wire • A cup or glass
Solar energy, electricity (uncoated) • A filter for coffee or similar
2 h (+) • Two pieces of flat glass of • Sunscreen with high protection
the same size (microscope factor (check that the
slides) ingredients contain
• Glue titanium dioxide, TiO2)
• Adhesive tape • A tea candle or lighter
• A bowl or deep dish • Iodine for wounds (pharmacy)
• Blueberries or blackberries • A multi-meter
O
ne of the most important challenges
of our day is to obtain sources of
clean, cheap and abundant energy
that allow us to end the dependence we
have on fossil fuels. Photovoltaic energy is
an excellent candidate. In this experiment,
we will develop a photovoltaic cell with
homemade elements. We will create a dye-
sensitized cell that will allow us to produce
electricity through a photoelectrochemical
phenomenon. This type of solar cell is very
promising compared to the classic ones
based on silicon, because although they are Figure 6.6.1 Solar panels.
less efficient, they have a lower production Photography: Blickpixel, Pixabay.
cost.
Procedure
1. Glue the copper or aluminum strips
along the glass pieces.
2. Place masking tape on the edges of one
of the glasses (on the side of the strip).
3. Cover the surface abundantly with sun-
screen. Wait 15 minutes for the protec-
tor to dry. Remove the adhesive tape.
4. Put the blueberries in a bowl and
squeeze them with a spoon, so that
the juice is released. Now use the fil-
ter to separate the juice and store it in
Figure 6.6.2 Materials.
the bowl. If you do not get much juice,
Photography: in house.
do not worry, save the puree you have
obtained.
Figure 6.6.3 Different steps of the procedure: glue the metal strips, cover the first one with sunscreen and then leave it
to soak in the juice, smoke the other with a candle or lighter, finally join the two plates and measure the voltage.
Photography: in house.
5. Place the glass in the juice or puree and leave it for 15 minutes to soak.
6. Meanwhile, prepare the other glass. Light the candle and be careful! (you can use a
clothespin) smoke the surface of the glass on which you have glued the copper. You
have to wait until enough soot is deposited (the surface will be black).
7. After the necessary time has elapsed, remove the glass from the juice and, if necessary,
dry it with a cotton cloth. It is not necessary to remove everything. Deposit a few drop-
lets of iodine on the surface.
8. Place the soot-covered glass on top of the other. Fix them with small strips of masking
tape. Be careful that the copper strips do not touch either.
9. Your solar cell is ready: just put it in the sun and check the voltage with a multi-meter.
Prevent the copper strips from touching when measuring voltage.
Explanation
The cell we have built transforms light energy into electricity through a photoelectrochem-
ical process. Sunlight interacts with the photosensitive dye contained in the juice of blue-
berries or blackberries, a pigment called anthocyanin, abundant in these fruits. Anthocy-
anin is absorbed by a semiconductor material (titanium dioxide, TiO2, from the sunscreen).
Sunlight allows the electrons in the dye to absorb enough energy to move in the cell. These
204 Discovering Light: Fun Experiments with Optics
Tricks
• If you wish to obtain higher voltages,
you can play with the size of the cells:
the larger the surface, the higher the
voltage. You can also connect different
cells in series or parallel.
• Although our system does not yield
high energy, you can try to connect an Figure 6.6.4 Diagram of the components of our solar cell.
LED or a small motor. A cell the size of
Source: in house.
a microscope slide should produce a
current around 0.5 volts.
Related experiments
Experiment 6.5 Cooking for free: build a solar oven
W
e all know that without fresh water
there would be no life for many
animals or plants on our planet,
including humans. But this resource is
highly limited, since about 97% of the water
present on Earth is salty and therefore can-
not be used for agriculture or food. However,
this water can be desalinated by various
techniques, which allows for it to be used.
In this experiment, we will see how it is pos-
sible to build a desalination plant without
Figure 6.7.1 Beach.
spending money, using the sun energy and
Photography: Joe de Sousa, Flickr.
materials available in any household.
Procedure
1. Put the glass in the center of the bowl.
2. Deposit the seawater into the bowl so
that it surrounds the glass.
3. Cover the bowl with the film, being
careful not to leave any holes.
4. Place the stones in the center of the
film paper so that it sinks into the inte-
rior of the bowl. This sinking should
coincide with the center of the glass.
5. Leave the bowl in the sun until there is
no water left in the bowl and the glass
is full. Figure 6.7.2 Diagram of the experiment.
6. Now you have drinking water! You can Source: in house.
use it to water plants and even drink to
check that it has no salt.
Explanation
In our experiment, we have simulated the water cycle to convert salt water into fresh
water. The sun’s energy absorbed by salt water causes it to transform into steam, which
rises and collides with the plastic film. The presence of plastic also makes the tempera-
ture inside the bowl higher than the temperature outside, since the heat cannot escape.
Tricks
The described method to desalinate seawater can also be used to purify fresh water from
any toxic or microbial substances and thus make it drinkable. You can check it by staining
the water placed in the bowl with a coloring substance and seeing that it is not present in
the water that is deposited in the glass.
Related experiments
Experiment 6.5 Cooking for free: build a solar oven.
How can it be observed that the refractive index of ethyl alcohol is lower than that of
sunflower oil?
A very simple way to verify differences in the refractive index of different liquids is to put
them in the same container and then introduce a pencil or a straw, for example. When you
look at the sides, you will see that the light is refracted differently in each liquid, making
the pencil appear discontinuous. If you see that the image of the pencil does not change
when the two liquids pass through, then they have the same refractive index; but if you
notice a discontinuity (as if the pencil were broken), then its index of refraction is differ-
ent. Image 1.1.3 illustrates three liquids with different refractive indices. The most drastic
change in index can be observed between air and water, since the straw seems wholly
broken (Figure 1.6).
209
What happens to wavelengths that our eyes cannot perceive? Does the same effect occur
with ultraviolet and infrared?
If you have a white light source that goes through a prism, in fact, even if your eyes cannot
perceive it, beyond the red is the infrared component that contains the light and, beyond
the violet or violet blue, is the ultraviolet, although both in low quantity. To be able to
visualise it more easily, use a white light and the prism that you have built in the experi-
ment, and with a camera that has the “night vision” mode you will be able to observe an
additional color of the spectrum next to the red that corresponds to the close infrared. Try
it and impress yourself!
Is it true that if I wear sunscreen, my skin does not synthesize vitamin D, which is neces-
sary for my body?
No. Even if you wear the highest-protection sunscreen, a very small percentage of ultravio-
let radiation (around 3% using a 50-SPF sunscreen) manages to reach our skin. If exposure
to the sun is not prolonged, this amount of radiation is harmless to our skin, and further-
more, with that radiation it is perfectly possible to synthesize vitamin D.
Why do we observe different colors when there is a spot of gasoline on the asphalt?
In this case, we also have a system of a thin layer of gasoline on water. Between the inci-
dent light that is reflected and the one that is transmitted and reflected again at the inter-
face between water and gasoline there is a 180° offset. This leads to destructive interference
that lets only a dependent wavelength pass through the layer’s thickness. For this reason,
too, in the central parts of the stain (where there is more gasoline and this form a thicker
layer) visible interference does not occur, but, as we move away from the center and the
layer becomes thinner, we see the colors.
What size should the slits be so that the waves generated are spherical point sources and
the effects of diffraction are reduced by a single slit?
The size of the slits must be somewhat smaller than the wavelength of the light used to
generate intermittent spherical waves.
Why do glasses between polarizers show different colors and not just one?
In general, one way to view the tension within an organic material, such as plastics, is
to place it between cross polarizers. The tensions that are within the material product
of forces, such as the force that makes the frame of our glasses on the lenses, cause the
polymer molecules to modify their position with each other, acting as local polarizers and
rotating the direction of the plane of oscillation of the light that crosses one of the polar-
izers. As the tensions are gradual, the plastic behaves as a polarizer gradually, producing
the effect of multiple colors.
If you look through a spectroscope, what do you think the spectrum you see would be?
What do you think would be the spectrum you would observe?
The spectroscope is a device that allows you to view the different wavelengths wave
(colors) that come from a light source by either emission or absorption. The different dis-
tributions of color lines indicate the elementary materials that are present in said emitter.
In the case of an incandescent bulb, since it comes from a high-density material, the spec-
trum we would see would be a mainly continuous spectrum.
Do you think it is essential to use a microcontroller like the one we used to observe this
property of LEDs? Why do you think we have used it?
It is not essential, since the experiment is based on a characteristic inherent to the operating
mechanism of the LEDs. However, a microcontroller allows us to continuously and simul-
taneously sample several of them at the same time, as well as calculate a “base” value and
execute actions when it is exceeded up or down (turn on or off the indicator LEDs).
What is the relationship between temperature and color (or, rather, electromagnetic spec-
trum, since we cannot see it completely)?
Each color of the light (or part of the EM spectrum) has its own wavelength (or frequency)
and each frequency (𝜈) corresponds to a certain energy (E) according to the Planck equa-
tion E = h · 𝜈, where h is a constant (Planck’s constant). Color is only one type of energy.
What would happen if there were only one image on the tablet or mobile?
We would not achieve the same effect. In that case, the image is reflected only in the side
that is facing the image, and therefore, we would only see the “hologram” from the side.
Turning the phone or tablet would have no three-dimensional effect.
Why is the use of lenses not essential in this experiment? Are you able to relate it in some
way with your daily life?
The use of lenses is not necessary, since we do not need to focus the light beams to form an
image on a specific plane. By using flat mirrors, the direction of all light beams is changed
equally, meaning that the beams that come parallel from infinity to the periscope entrance
will continue to be at the exit of the periscope. Our eye, assuming it is emmetropic or
properly corrected, will be the one that will focus the beams so that they form the image
on the plane of the retina, just as it does when we look at the world around us or see our
image reflected in the mirror of the bath in the morning.
The reflection of light in a mirror is possible thanks to a property of light that we have
already learned before. This is also the one that allows imaging in a dark chamber
(through a hole). Do you know the one we’re talking about?
Specifically, the rectilinear propagation of light.
Experiment 3.3 Make your own lenses and see what happens
What would happen if the lens surface were not completely smooth?
If the lens surface were not completely smooth, part of the light would diffract in all direc-
tions and therefore would not propagate parallel to the optical axis. This would result in a
loss of brightness in the image formed with respect to the one that would be visible using
a perfectly smooth lens.
What happens to the focal length if you squeeze the lens and increase its curvature?
By squeezing the converging lens, its curvature increases. This causes the focal length of
the lens to decrease since it increases the ability of the lens to deflect light beams.
What would happen if we used sparkling water to make the ice magnifier? Do you think it
would improve?
No. Ice, created from this water, would not be uniform because it would contain gas bub-
bles. The light passing through a non-uniform medium would be diffracted differently by
ice and gas. A lens with these characteristics would lead to distorted images.
Why are objects magnified that are very close to the micro-lens support point?
Because the micro-lenses, being very small spheres, have a large curvature that results in
a very small focal length. Therefore, by leaning on a surface the micro-lens magnifies the
objects that are in it.
Why does such a large magnification occur when the spheres (or hemispheres) are getting
smaller and smaller?
The magnification depends on the curvature of the surface of the spherical lens; smaller
size means greater curvature and, therefore, greater magnification.
Why with the hydrated hydrogel ball do we see the image without inverting when the
object is near and inverted when the object is far away?
Inversion occurs when the object is located further from the focus. This is because the focus
is the point where all beams converge and intersect. Thus, if the object is before the focus, the
beams do not cross and, therefore, there will be no image inversion, simply a magnification.
Instead, the beams that originate beyond the focus cross in it, and therefore, the image is inverted.
How would we see an object located in the area marked out between the mirrors?
Objects outside the invisibility area will be visible to the observer. In the case of a mirrored
configuration, the object positioned in the area delimited between the objects will appear
to be displaced, apparently, within the invisibility zone.
What is the main difference between the Galileo and Kepler telescopes?
In the Galileo telescope, the eyepiece is a divergent lens, and the lens is a converging lens.
In contrast, both the eyepiece and the objective are converging lenses in the Kepler tele-
scope. In the Galileo telescope, the image is upwards. However, in the Kepler telescope we
obtain an inverted image.
What are the advantages and disadvantages of each type of telescope (Galileo, Kepler and
Newton)?
The Galileo telescope is a very bright telescope, and the final image is right without the
need for an inverter system. However, it has a very small field of vision. The Kepler tele-
scope, however, by using a convex lens in the eyepiece (instead of the concave of the
Galileo model) has the advantage of allowing a much wider and more detailed field of
vision, but the image for the viewer is reversed. The Newtonian telescope, when using
mirrors, prevents chromatic aberration of the lenses. The disadvantage of Newtonian
telescopes compared to those that use lenses (refracting telescopes) is the shading of the
incoming light. This is because refracting telescopes have no element in the optical path
that causes an obstruction, thus being capable of providing more light and contrast to
images with the same aperture as reflector telescopes.
What would be needed to view an atom? Would it be possible with a similar system?
We would need to use some radiation of wavelength similar to the size of atoms, such as
X-rays. However, X-rays are quickly absorbed by the system’s lenses. To see atoms, an elec-
tron microscope is used, which features an electron beam instead of a light beam.
The part of the retina we are observing, what would it be and why?
The part of the retina corresponds to the end of the tube where the onion skin paper is. By
adjusting the magnifying glass, what would be our cornea and lens, we do it so that the
image is formed exactly on the retina, on the onion skin paper. And what is more, we can
verify that it is our retina because the image that is formed is back-to-front!
If a person’s vision is corrected with divergent or negative glasses or contact lenses, what
refractive defect do they have?
That person has myopia. The eyeball is larger than it should be, which makes it more
powerful, and therefore the image is formed in front of the retina. Myopia is corrected with
divergent lenses to compensate for the extra power that the eye has and to focus the image
on the retina.
If you want to recommend someone a type of pattern to stylize your figure, what would
you recommend, vertical or horizontal stripes?
The horizontal pattern. In human figures, this effect of thinness or width is observed
mainly in the hips; the vertically striped pattern makes the hips appear wider, the outline
of the silhouette being the same. So, it can be denied that vertical stripes have a slimming
effect.
How is it possible that we observe yellow or red figures on our banknotes and passports
with ultraviolet light?
Both elements, tickets and identity documents (ID, passports, driver’s license), have lumi-
nescent marks to prevent counterfeiting of documents. These marks can only be seen when
they are illuminated with UV light, since it causes the luminescence to be activated.
Would the experiment work if instead of milk we used sugar or salt, for example?
No, since we need a large particle size for this type of scattering. Milk is composed of fatty
acids and proteins, which facilitate the scattering of light. The ions present in the sugar or
salt solutions are not large enough for light to scatter.
Why can the moon have a reddish or orange tinge when a lunar eclipse occurs?
The Earth’s atmosphere disperses the blue and green light that comes from the sun’s spec-
trum. The red light passes without dispersing. During the lunar eclipse, the light that reaches
our satellite is the red of our atmosphere. That is why the moon looks red during an eclipse.
If we could measure those values in another area of the EM spectrum, would we get the
same result?
Yes. The speed of light is a constant. It only changes if it is transmitted by a different
medium, for example, light is slower in water or glass than in air.
When you bend a fiber that transmits a visible beam, we can see how the point of maxi-
mum curvature is illuminated. What causes this phenomenon?
As we have seen with our experiment, when the curvature of the water (and by extension
of the fiber) is very high, the phenomenon of total internal reflection does not occur, and
part of the light continues its path in a straight line.
Should you reuse many times the oil you used to fry some foods?
When you heat the oil, it loses its properties. If we repeat our experiment with an over-
heated oil, we will observe a less reddish color.
If we use colored LEDs to illuminate our system, which LED color generates a greater elec-
trical current?
Blue or green light has an energy greater than red light; for this reason, if we illuminate our
system with an LED of these colors, a greater amount of electrical current will be noted.
What characteristics must the outer container have to favor the experiment?
Ideally, the outer container should be dark and large in size to absorb a greater amount of
solar energy and thus facilitate water evaporation.
225
226 Glossary
Glossary 227
228 Glossary
Glossary 229
230 Glossary
Glossary 231
233
234 Index
235
