January 2013
Revision 1
Notice: This Beechjet 400A Cockpit Reference Handbook is to be used
for aircraft familiarization and training purposes only. It is not to be used
as, nor considered a substitute for, the manufacturer’s Pilot or
Maintenance Manuals.
SimuFlite
Our best wishes are with you for a most successful and
rewarding training experience.
Introduction
CAE SimuFlite created this reference handbook for cockpit use.
It is an abbreviated version of the CAE SimuFlite Technical
Manual and includes international flight planning information.
Please refer to the front of each chapter for a table of contents.
The Procedures chapter contains four elements: Preflight
Inspection, Expanded Normal Procedures, a sample Standard
Operating Procedure (SOP), and Maneuvers.
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2A-5
Cockpit Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2A-6
Checklist Usage
Tasks are executed in one of two ways:
as a sequence that uses the layout of the cockpit controls
and indicators as cues (i.e., "flow pattern")
as a sequence of tasks organized by event rather than panel
location (e.g., After Takeoff; Landing Gear – UP, Flaps –
UP).
Placing items in a flow pattern or series provides organization
and serves as a memory aid.
A challenge-response review of the checklist follows execution
of the tasks; the pilot not flying (PNF) calls the item, and the
appropriate pilot responds by verifying its condition (e.g., "Cowl
Anti-Ice" [challenge] – "ON" [response]).
Two elements are inherent in the execution of normal
procedures:
use of either the cockpit layout or event cues to prompt the
correct switch and/or control positions
use of normal checklists as "done" lists.
B4CRH-PF002i
General
Carry out a normal preflight inspection. During inspection,
make a general check for security, condition, and cleanliness of
the airplane and components. Check particularly for damage,
condition of tires, flight controls, fuel, oil, hydraulic fluid leak-
age, security of access panels, and blockage of ventilation
inlets and drain ports. Ensure all ground safety pins, control
locks, covers, tie-downs, and chocks are removed and stowed.
Before starting the exterior inspection, obtain the following:
flashlight
standard screwdriver
step stool
sump drain wrench
container for fuel drain disposal.
All Surfaces . . . . . . . . . . . . . FREE FROM SNOW/ICE/FROST
Protective Covers/Plugs . . . . . . . . . . . . . . . . REMOVE/STOW
Remove safety covers from the engines, static ports, pitot
probes.
All Intakes/Exhausts. . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Fasteners/Panels. . . . . . . . . . . . . . . . . . . . . . . . . ALL SECURE
Verify that all fasteners and panels are secure. Remove
keys from locks.
General Condition . . . . . . . . . . . . . . . . . . . . . . . UNDAMAGED
Cabin Inspection
Pins, Plugs, and Covers . . . . . . . . . . . . . . . . . . . . . . . . .STOW
Ensure the nose gear pin, pitot and static covers, and other
external plugs are on board and stowed.
First Aid Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Check that the kit is sealed and stowed. If the kit is not
sealed, check that it contains all required materials.
Cabin Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Check that the windows are secure and in good condition.
The windows should be clean and free from cracks and
crazing.
Cabin Fire Extinguisher . . . . . . . . . . . . . . . . . . . . . . SERVICED
Verify the cabin fire extinguisher is charged and stowed.
Emergency Exit . . . . . . . . . . . . . . . . . . .CLEAR AND SECURE
Ensure the emergency exit is closed and lock pin is
removed and stowed. Make sure the emergency exit is clear
of any obstructions.
Safety Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Check that the life jackets are in good condition and stowed
appropriately.
Passenger Seats and Tables . . . . . . . . . . . . . . . . . CONDITION
Ensure all seats and tables are in good condition and
secure. All seats should be upright: swivel seats should be
locked facing forward or aft. Stow all retractable tables.
Galley (if installed) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Confirm that the galley is stocked and that all equipment is
in good repair.
A Cabin Door
Cabin Entry Door Seal/Frame . . . . . . . . . . . . . . . . CONDITION
Inspect the door seal for cuts or abrasions. A damaged door
seal can cause pressurization loss. Check for general condi-
tion of the door frame for damage and foreign objects. A
damaged door frame or a foreign object will prevent normal
door seal operation.
Exterior Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . STOWED
B Left Nose
Static Ports (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Verify the upper and lower static ports are clear and
undamaged.
Angle-of-Attack Transmitter . . . . . . . . . . . . . CLEAR, ROTATES
Remove the probe cover and retain for later stowage.
Ensure the probe is undamaged and moves freely.
Windshield Wiper (if installed) . . . . . . . . . . . . . . . . CONDITION
SECURE
Ice Detector (if installed) . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Avionics Compartment Door . . . . . . . . . . . . . . . . . . . SECURE
Pitot and Static Drain Ports (2). . . . . . . . . . . . . . . . . . .CLOSED
Nose Gear, Doors, Tire, Torque Link . . . . . . . . . . . CONDITION
SECURE
Check the nose gear, doors and torque link for damage and
alignment. Examine the nosewheel tire and tread for signs
of damage or excessive wear. Check for correct tire pres-
sure (120 ±5 PSI). Service tire with nitrogen only.
Cabin Air Discharge Duct . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Landing Light Door . . . . . . . . . . . . . . . . . . . . . . . . . . SECURE
Check landing light for security and signs of a burnt out bulb.
For night flight, verify operation.
Pitot Mast. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Verify the pitot probe is is clear, secure and undamaged.
C Right Nose
Pitot Mast. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Remove the pitot probe cover and retain for later stowage.
Verify the pitot probe is clear, secure and undamaged.
Landing Light Door . . . . . . . . . . . . . . . . . . . . . . . . . . SECURE
Check landing light for security and signs of a burnt out bulb.
For night flight, verify operation.
Cabin Air Discharge Duct . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Ensure the duct is clear and free from any damage.
Pitot and Static Drain Ports (2) . . . . . . . . . . . . . . . . . .CLOSED
Ensure the drain ports are closed and undamaged.
Oxygen Blowout Disc. . . . . . . . . . . . . . . . . . . . . . . . . . .GREEN
Ensure the green blowout disc is in place and intact. If the
disc is missing, check to see if the oxygen bottle is empty
and determine the cause; service is required before flight.
Avionics Compartment Door . . . . . . . . . . . . . . . . . . . SECURE
Windshield Wiper (if installed) . . . . . . . . . . . . . . . CONDITION/
SECURE
Angle-of-Attack Transmitter . . . . . . . . . . . . . CLEAR, ROTATES
Remove the probe cover and retain for later stowage.
Ensure the probe is undamaged and moves freely.
Static Ports (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Verify the upper and lower static ports are clear and
undamaged.
D Right Wing
Emergency Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SECURE
The emergency exit should be closed and flush with the
fuselage. Ensure the locking pin has been removed and
stowed.
Dorsal Fin Inlet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Check that the inlet is clear and free from damage.
Wing Inspection Light . . . . . . . . . . . . . . . . . . . . . . CONDITION
Check the wing inspection light for security and signs of a
burnt out bulb. For night flight, verify operation.
Wing Leading Edge Inlet . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Check that the inlet is clear and free from damage.
Center Fuselage Tank Drain (daily) . . . . . . . . DRAIN, SECURE
Inspect the center fuselage tank drain for damage. Use a
sump drain wrench to drain any water accumulation.
Fuel Quick Drains (3) (daily) . . . . . . . . . . . . . DRAIN, SECURE
Inspect the quick drains for damage. Use a sump drain
wrench to drain any water accumulation.
Fuel Filler Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SECURE
Ensure the filler cap is on and secure.
Fuel Tank Vent Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Check that the inlet is clear and free from damage.
Sniffle Valves (2) (daily) . . . . . . . . . . . . . . . . . . . . PUSH, PULL,
CHECK FOR LEAKS
Check for freedom of movement and signs of fuel leakage.
Wing Tip Vent Inlet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Check that the inlet is clear and free from damage.
E Right Nacelle
Engine Fan Duct and Fan . . . . . . . . . . . . . . . . . . . CONDITION
Check the fan duct for any obstruction. Check the fan blades
for any signs of damage. Ensure the fan rotates freely.
Engine Inlet Screws . . . . . . . . . . . . . . . . CHECK SLIP MARKS
Generator Inlet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Check that the generator inlet is clear and free from
damage.
Oil Level and Filler Door . . . . . . . . . . . . . . . CHECK, SECURE
Check the engine oil level; replenish oil before flight if nec-
essary. Visually check the oil level by the dipstick. Check
the oil level within 10 to 30 minutes of engine shutdown.
Install filler cap and dipstick assembly in filler tube. Ensure
cap is correctly installed and locked securely.
NOTE: Oil will blow out if cap is not installed and locked
correctly.
F Empennage
Fuselage Fuel Filler and
Sniffle Valve (daily) . . . . . . . . . . . . . . . . . . . . . . . PUSH, PULL,
CHECK FOR LEAKS
Ensure the sniffle valve is undamaged and there is freedom
of movement. Check for signs of fuel leakage.
Fuselage Fuel Filler Door . . . . . . . . . . . . . . . . . . . . . SECURE
Ensure the filler cap is on and secure.
Upper Aft Fuselage Vent Outlet (right). . . . . . . . . . . . . . CLEAR
Ensure that the aft fuselage vent outlet is clear and free from
damage.
Cooling Air Discharge Duct . . . . . . . . . . . . . . . . . . . . . . CLEAR
Ensure that the cooling air discharge duct is clear and free
from damage.
Aft Fuselage Vent Inlet (right) . . . . . . . . . . . . . . . . . . . . CLEAR
Ensure that the aft fuselage vent inlet is clear and free from
damage.
Fuel Vent Ports (2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Ensure that the fuel vent ports are clear and free from
damage.
Stabilizer Trim, Elevator, Static Wicks (4) . . . . . . . CONDITION
Check the stabilizer trim and elevator for security and condi-
tion. Verify the static wicks are secure and undamaged.
Check MEL for flight with missing static wicks.
Rudder, Trim Tab, Static Wicks (2). . . . . . . . . . . . . CONDITION
Check the rudder, and trim tab for security and condition.
Verify the static wicks are secure and undamaged. Check
MEL for flight with missing static wicks.
H Left Nacelle
Engine Exhaust and Bypass Duct . . . . . . . . . . . . . CONDITION
Ensure the engine exhaust and bypass duct are clear and
free from obstructions and there is no sign of damage.
Thrust Reverser . . . . . . . . . . . . . . . . . . . . . . . . . . . CONDITION
Ensure the thrust reverser is undamaged and stowed.
Drain Lines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Ensure that the drain lines are clear and free from damage.
Oil Level and Filler Door . . . . . . . . . . . . . . . CHECK, SECURE
Check the engine oil level; replenish oil before flight if nec-
essary. Visually check the oil level by the dipstick. Check
the oil level within 10 to 30 minutes of engine shutdown.
Install filler cap and dipstick assembly in filler tube. Ensure
cap is correctly installed and locked securely.
NOTE: Oil will blow out if cap is not installed and locked
correctly.
I Left Wing
Brake System Accumulator Pressure . . . . . . . . . . . . . .CHECK
Ensure the brake system accumulator pressure reads 900
±50 PSIG. If the pressure reads below 900 ±50 PSIG,
charge the accumulator with nitrogen.
Fuel Filter Drain (daily) . . . . . . . . . . . . . . . . . DRAIN, SECURE
Inspect the fuel filter drain for damage. Use a sump drain
wrench to drain any water accumulation.
Main Gear, Doors, Tire, Brake . . . . . . . . . . . . . . . . CONDITION
Inspect the right main landing gear wheel well for general
condition and cleanliness. Ensure there are no loose articles
or fluid leaks. Verify that all cable, hydraulic and electrical
lines are secure. Inspect the doors for security and any
signs of damage. Check the wheels for signs of tread wear
or damage. Verify the correct tire pressure (125 ±5 PSI). If
required, service with nitrogen only.
Flaps, Spoilers, Static Wicks (3), Roll Trim Tab . . . CONDITION
Check the roll trim tab, spoilers and flaps for security and
condition. Inspect the lower surfaces of the roll trim tab and
flaps for any damage. Verify the static wicks are secure and
undamaged. Check MEL for flight with missing static wicks.
Wing Anti-Ice Exhaust Port . . . . . . . . . . . . . . . . . . . . . . CLEAR
Check that the exhaust port is clear and free from damage.
Navigation and Strobe Lights . . . . . . . . . . . . . . . . . CONDITION
Check the navigation and strobe lights for security. For night
operation, perform a functional check of the light.
Wing Tip Vent Inlet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Check that the inlet is clear and free from damage.
Sniffle Valves (2) (daily) . . . . . . . . . . . . . . . . . . . . PUSH, PULL,
CHECK FOR LEAKS
Line Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-30
Takeoff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-30
Descent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-36
Approach . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-37
Before Landing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-39
Landing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-40
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-42
Turnaround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-43
Towing/Taxiing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-45
Taxiing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-51
Parking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-53
Mooring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-55
Taxi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-65
Before Takeoff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-65
Takeoff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-66
Climb/Cruise/Descent . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-67
Landing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-68
Taxi-In/Park . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2B-68
Normal Procedures
Passenger Briefing
According to Far Part 91.519 and 135.117 requirements, the
pilot-in-command or a crewmember briefs the passengers on
smoking, use of safety belts, location and operation of the pas-
senger entry door and emergency exits, location and use of
survival equipment, and normal and emergency use of oxygen
equipment. For flights over water, the briefing should include
ditching procedures and use of flotation equipment.
FAR 91.519 states that an exception to the oral briefing rule is if
the pilot-in-command determines that passengers are familiar
with the briefing content.
FAR 91.519 states that a printed card with the above informa-
tion should be available to each passenger to supplement the
oral briefing.
FAR 135.117 states that a printed card with the above informa-
tion must be available to each passenger to supplement the
oral briefing.
The Before Starting Engines procedures may be accomplished
somewhat prior to the planned departure time.
Checklist Usage
Tasks are executed in one of two ways:
as a sequence that uses the layout of the cockpit controls
and indicators as cues (i.e., “flow pattern”)
as a sequence of tasks organized by event rather than panel
location (e.g., After Takeoff; Landing Gear – UP, Flaps –
UP).
Placing items in a flow pattern or series provides organization
and serves as a memory aid.
A challenge-response review of the checklist follows execution
of the tasks; the pilot not flying (PNF) calls the item, and the
appropriate pilot responds by verifying its condition (e.g., “Cowl
Anti-Ice” [challenge] – “ON” [response]).
Two elements are inherent in the execution of normal
procedures:
use of either the cockpit layout or event cues to prompt the
correct switch and/or control positions
use of normal checklists as “done” lists.
Starting Engines
NOTE: A GPU start is recommended at ambient tempera-
tures below approximately 5°F (-15°C) External power
requirements are 28V DC, 1,000-1,500 amperes output.
Standby Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
SPKR Switches . . . . . . . . . . . . . . . . . ON or DON HEADSET
INTPH Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
DC Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Check that there is 22V minimum for battery start or 28V for
GPU start.
Navigation Lights. . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Rotating Beacon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Emergency Lights . . . . . (GUARD DOWN). . . . . . . . . . . . . ARM
Generator Reset Switches . . . . . . . . . . . . . . SET FOR GPU/
BAT START
Refrigeration Air Conditioning . . . . . . . . . . . . . . . . . . . . OFF
Engine EFCs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Engine Start Select . . . . . . . . . . . . . . . . . . . SELECT L OR R
EFC AUX PWR ON Annunciator . . . . . . . . . . . ILLUMINATED
Engine Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DEPRESS
a. Start Button. . . . . . . . . . . . . . . . . . . . . . . . ILLUMINATED
b. DISENGAGE Button . . . . . . . . . . . . . . . . ILLUMINATED
c. N2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ROTATION
Starter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DISENGAGE
Ensure starter disengages prior to 45% N2.
Engine Instruments. . . . . . (52-54% N2) . . . . . . . . . . MONITOR
Engine Start Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OFF
Ignition and Boost Pump Lights. . . . . . . . . EXTINGUISHED
Hydraulic Pressure . . . . . . . . . . . . . . . . . . . . . . . . . NORMAL
FUEL/H PMP PRESS LO Annunciators . . . EXTINGUISHED
Cabin Pressure Source . . . . . . . . . . . . OPERATING ENGINE
Operating Generator (if battery start) . . . . . . . . . . . .CHECK
Ensure current is less than 150 amps.
Engine Start Select . . . . . . . . . . . .SELECT OTHER ENGINE
FUEL PRESS LO
Annunciator (other engine). . . . . . . . . . . . . . . ILLUMINATED
Before Taxi
NOTE: Do not taxi until AHRS ALIGNING - DO NOT TAXI
annunciators extinguish on both pilot's and copilot's panels.
Taxi
Wheel Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Speedbrakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CHECK
a. Speedbrake Emer
Retract . . . . . . . . . . .(GUARD UP) . . . . . . . . . EMER RET
b. Speedbrakes . . . . . . . . . . . . . . . . . . . . . . . . . . . EXTEND
Ensure there is no movement.
c. Speedbrake Emer
Retract. . . . . . . . . . (GUARD DOWN). . . . . . . . . . . . NORM
d. Speedbrakes . . . . . . . . . . . . . . . . . . NOTE EXTENSION
e. SPD BRAKE EXT Annunciator. . . . . . . . . ILLUMINATED
f. Speedbrakes . . . . . . . . . . . . . . . . . . . . . . . . . RETRACT
Flight Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Anti-Skid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
a. Wheel Brakes . . . . . . . . . . . . . . APPLY WHILE ROLLING
b. Anti-Skid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TEST
Check for brake release, then switch OFF. Recover brake
effectiveness. Check that the ANTI-SKID FAIL annuncia-
tor illuminates.
c. Anti-Skid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Check that the ANTI-SKID FAIL annunciator extinguishes
and there is normal braking.
Thrust Reversers . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
a. Thrust Reversers . . . . . . . . . . . . . . . . . . . . . . . .DEPLOY
b. Check ARM, UNLOCK, and
DEPLOY Annunciators. . . . . . . . . . . . . . . ILLUMINATED
c. EMER STOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PUSH
d. Check:
EMER STOW Lights. . . . . . . . . . . . . . . . . ILLUMINATED
UNLOCK and DEPLOY
Annunciators . . . . . . . . . . . . . . . . . . . . EXTINGUISHED
e. EMER STOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PUSH
f. Check:
EMER STOW Lights. . . . . . . . . . . . . . . EXTINGUISHED
ARM, UNLOCK and DEPLOY
Annunciators . . . . . . . . . . . . . . . . . . . . . . ILLUMINATED
g. Thrust Reversers . . . . . . . . . . . . . . . . . . . . . . . . . .STOW
h. Check all Thrust Reverser Lights
and Annunciators . . . . . . . . . . . . . . . . . EXTINGUISHED
a. Autopilot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ENGAGE
Verify that the pilot's PFD displays the following
messages:
ROLL (Green)
PTCH (Green)
ALTS (White)
AP (Green)
b. Center button on pilot's
Manual Trim Switch . . . . . . . . . . . . . . . . . . . . .ACTUATE
Verify AP disconnect with YD remaining engaged then
re-engage the autopilot.
c. Pilot's A/P DISENG pushbutton . . . . . . . . . . . DEPRESS
Verify that AP and YD disconnect then re-engage the
autopilot.
d. Center button on copilot's
Manual Trim switch. . . . . . . . . . . . . . . . . . . . . .ACTUATE
Verify AP disconnect with YD remaining engaged then
re-engage the autopilot.
e. Copilot's A/P DISENG pushbutton . . . . . . . . . DEPRESS
Verify that AP and YD disconnect, then engage the auto-
pilot.
f. Go-around Button. . . . . . . . . . . . . . . . . . . . . . DEPRESS
Verify the AP disengages with the YD remaining engaged
Avionics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SET
FMS Programming
Pertinent information (station identifier, waypoint, bearing,
and waypoint distance) is entered into the flight plan from
either CDU. Programming may be accomplished before
takeoff or during flight. To enter RNAV approach waypoints:
a. Flight Plan Page . . . . . . . . . . . . . . . . . . . . . . . . . . ENTER
Enter the flight plan page on the CDU.
b. ADD WPTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . SELECT
c. Associated Navaids . . . . . . . . . . . . . . . . . . . . . . . ENTER
Enter the navaid associated with the RNAV approach and
verify the navaid position.
d. ADD RAD/DIS OFFSET . . . . . . . . . . . . . . . . . . . SELECT
e. Radial and Distance Offset. . . . . . . . . . . . . . . . . . KEY IN
Key in the radial and distance offset of the initial
approach fix and select OFFSET COMPLETE.
The CDU will display the initial approach fix position and
offers the select RNAV APCH. Verify the initial approach
position and select RNAV APCH.
f. Waypoint Name . . . . . . . . . . . . . . . . . . . . . . . . . . ENTER
Enter a waypoint name of up to 5 alphanumeric charac-
ters and select NAME COMPLETE.
g. Radial and Distance Offset. . . . . . . . . . . . . . . . . . ENTER
Enter the radial and distance offset of the next RNAV
approach fix.
h. Waypoint Name . . . . . . . . . . . . . . . . . . . . . . . . . . ENTER
Enter the waypoint name for the next RNAV approach fix.
i. Repeat the last two steps for as many waypoints as
required.
Ground Operation
TCAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . STBY
Maintain the TCAS in the STBY mode until just prior to
takeoff, then select the TCAS mode as desired.
Select the TCAS STBY mode immediately after clear-
ing the runway following a landing.
Before Takeoff
Engine EFCs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Anti-Collision Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Landing Lights . . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Engine Anti-Ice. . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Radar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
If ECS OFF takeoff is planned:
Cabin Pressure Source . . . . . . . . . . . . . . . . . . . . . . . . . . OFF
Rate Control . . . . . . . . . . . . . . . . . . . 11 O'CLOCK POSITION
Manual Pressure Control . . . . . . . . . . . . . FULL DECREASE
Vent Blower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Before Takeoff Checklist . . . . . . . . . . . . . . . . . . . COMPLETE
Line Up
Windshield Anti-Ice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . LOW
AOA Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Pitot Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Static Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Ignition Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Transponder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Refrigeration Air Conditioning . . . . . . . . . . . AS REQUIRED
Recognition Lights . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Annunciators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Line Up Check . . . . . . . . . . . . . . . . . . . . . . . . . . . COMPLETE
Takeoff
Thrust . . . . . . . . . . . . . . . . . . . . . . APPROXIMATELY 90% N1
Engine Instruments . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Wheel Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RELEASE
Thrust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TAKEOFF
Set thrust to TAKEOFF prior to 60 KIAS.
Nose-up Pitch Attitude
at Rotation (VR) . . . . . . . . (AS DESIRED) . . . . . . . . . . . .13º-15º
After Takeoff
Landing Gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . UP
While the gear retracts, watch for proper indication. Monitor
the hydraulic pressure gage to detect a hydraulic failure.
Yaw Damp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Landing Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RET/OFF
Flaps. . . . . . . . . . . . . . . . . . . . . (UP). . . . . . . . . . . . . . . . . . . . . 0º
Thrust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SET MCT
Engine Sync . . . . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Ignition Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . STBY
Anti-Ice/Deice Systems
(above 400 ft AGL) . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
d. Thrust . . . . . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Refer to the Takeoff Thrust Setting or Maximum Continu-
ous Thrust setting graphs.
e. ENG ICE TEMP LO
Annunciators . . . . . . . . . ILLUMINATED MOMENTARILY
f. Engine Anti-Ice Lights . . . . . . . . . . . . . . . ILLUMINATED
g. Ignition Lights . . . . . . . . . . . . . . . . . . . . . . ILLUMINATED
Wing Anti-Ice System Operation
a. Thrust . . . . . . . . . . . . . . . . . . . . . . . 90% N1 OR LOWER
b. Wing Anti-Ice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
c. Engine ITT . . . . . . . . . . . . . . . . . . . . CHECK INCREASE
d. Thrust . . . . . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Refer to the Takeoff Thrust Setting or Maximum Continu-
ous Thrust Setting graphs.
e. Wing Anti-Ice Light . . . . . . . . . . . . . . . . EXTINGUISHED,
THEN ILLUMINATED
Horizontal Stabilizer Anti-Ice System Operation
RK-1 thru RK-107 not modified by KIT 128-4014-1,
128-4014-3, 128-4014-5 or 128-4016-1
a. H Stab Anti-Ice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
b. H Stab Anti-Ice Light. . . . . . . . . . . . . . . . . ILLUMINATED
Horizontal Stabilizer Deice System Operation
RK-1 thru RK-107 not modified by KIT 128-4014-1,
128-4014-3, 128-4014-5 or 128-4016-1
a. H Stab Deice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
b. H Stab Deice Light . . . . . . . . . . . . . . . . . . . . . . FLASHES
There will be as many as 6 short flashes followed by
cycling of approximately 15 seconds on and 1 second off.
10,000 100.2 102.4 102.0 100.5 99.2 97.9 96.7 95.6 94.5 93.4
6,000 91.5 93.4 95.4 97.3 99.2 98.0 96.8 95.6 94.5 93.4
2,000 86.7 88.5 90.3 92.3 94.0 95.9 96.8 95.6 94.5 93.4
10,000 100.2 102.4 102.6 101.2 99.8 98.6 97.4 96.3 95.2 94.1
6,000 91.5 93.5 95.4 97.4 99.2 98.6 97.4 96.3 95.2 94.1
2,000 86.7 88.5 90.5 92.3 94.1 95.9 97.4 96.3 95.2 94.1
Descent
Seat Belts/Shoulder Harnesses . . . . . . . . . . . . . FASTENED
Cabin Sign . . . . . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Recognition Light . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Anti-Ice/Deice Systems . . . . . . . . . . . . . . . . . AS REQUIRED
Approach
Crew Briefing . . . . . . . . . . . . . . . . . . . . . . . . . . . . COMPLETE
FMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VERIFY
Prior to commencing the approach, verify that the flight plan
is properly loaded. The NAV tuning mode will change to
MAN mode prior to using an RNAV waypoint. The Navigator
mode will change to MAN LEG advance if using AUTO LEG
or SEL CRS.
Prior to the first RNAV waypoint:
Verify that either NAV is tuned to RNAV reference facility.
Manually advance the waypoint when over the existing
TO waypoint (DME = 0.0).
Due to the earth's magnetic field drift, the course dis-
played on the PFD may differ from the published course
slightly. Manually changing the course to match the pub-
lished course is not approved.
The airplane course will be direct to the initial approach fix
from the previous waypoint. It may be necessary to intercept
the final approach course outside the initial approach fix or
to hold outside the initial approach fix. To accomplish this:
Enter the SYSTEM CONTROL page and select SEL CRS.
Rotate the CRS knob to the desired course.
Re-select MAN LEG advance on the SYS CTRL page.
Fuel Management . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
VREF, VAC, N1, AOA, LDG DIST . . . . . . . . . . . . . . . .CONFIRM
Cabin Sign . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SAFETY
Windshield Anti-Ice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . LOW
Hydraulic/Nitrogen Pressure . . . . . . . . . . . . . . . . . . .CHECK
Engine Sync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OFF
Flaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10º
Before Landing
Landing Gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DOWN
Extend the landing gear when the glideslope indicator
shows the airplane two dots above the glideslope. Extend
the flaps to 20 degrees when one dot above glideslope.
Extend flaps to 30 degrees when glideslope is captured.
Smoothly decrease airspeed from initial approach speed
(VREF + 30 KIAS) to final approach speed (VREF + 10 KIAS).
Cross threshold at VREF - 5 to10 KIAS.
Flaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30º
Yaw Damp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OFF
Landing
Thrust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IDLE
Brakes (after touchdown) . . . . . . . . . . . . . . . . . . . . . . APPLY
Speedbrakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EXTEND
Thrust Reversers . . . . . . . . . . . . . . . . . . . . . . . . . . . .DEPLOY
Reverser Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VERIFY
Reverse Power . . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Balked Landing
Thrust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TAKEOFF N1
Climb Airspeed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VREF
When positive climb is established:
Flaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10º
Landing Gear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . UP
Yaw Damp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Flaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0º
Landing Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RET/OFF
After Landing
Engine EFCs. . . . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Anti-Collision Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . OFF
Anti-Ice/Deice Systems:
Wing, Engine and H Stab . . . . . . . . . . . . . . . . . . . . . . . OFF
Windshield. . . . . . . . . . . . . . . . . . . . . . . . . . . . .OFF or LOW
Shutdown
Parking Brake. . . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Turnaround
Prior to Boarding or Deplaning:
L Thrust Lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CUTOFF
Cabin Pressure Source . . . . . . . . . . . . . . . . . . . . . . . . . . OFF
Brake Energy and
Turnaround Charts. . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
See Approach and Landing Performance in AFM.
Restarting L Engine:
Radio Masters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OFF
Left Engine EFC . . . . . . . . . . . . . . . . . . . . . . OFF, THEN ON
Refrigeration Air Conditioning . . . . . . . . . . . . . . . . . . . . OFF
Perform STARTING ENGINE Procedures
Before Taxi:
Refrigeration Air Conditioning . . . . . . . . . . . AS REQUIRED
Radio Masters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ON
Cabin Pressure Source . . . . . . . . . . . . . . . . . . . . . . . SELECT
Select either BOTH HIGH or BOTH NORM.
Engine EFCs. . . . . . . . . . . . . . . . . . . . . . . . . . . . AS DESIRED
Engine Anti-Ice. . . . . . . . . . . . . . . . . . . . . . . . AS REQUIRED
Taxi:
Wheel Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Flight Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Fuel Crossfeed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NORM
Fuel Quantity and Balance . . . . . . . . . . . . . . . . . . . . .CHECK
Engine Instruments . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Flight Instruments . . . . . . . . . . . . . . . . . . . . . . . . . . . .CHECK
Cabin Pressure Control. . . . . . . . . . SET CRUISE ALTITUDE
Flaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . SET FOR TAKEOFF
Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SET FOR TAKEOFF
Avionics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SET
V1, VR, V2, AOA, N1, Flap Setting . . . . . . . . . . . . . .CONFIRM
Crew Briefing . . . . . . . . . . . . . . . . . . . . . . . . . . . . COMPLETE
Perform Before Takeoff and Line Up Procedures.
Turnaround Check . . . . . . . . . . . . . . . . . . . . . . . . COMPLETE
Towing/Taxiing
On hard surfaces, the aircraft can be towed or pushed back-
wards using a tow bar (P/N 45A91715-1) attached to the nose-
wheel. Turning angle of the nosewheel with tow bar is 90
degrees either side of center. When the aircraft is on a soft sur-
face (such as sand, soft ground, or mud), towing adapter belts
(P/N 45A99601-1) and tow cables must be attached to each
main gear for towing.
For taxi operations, accomplish directional control with the
nosewheel steering system. To prevent landing gear or engine
damage, taxi the airplane on a smooth, hard surface that is free
of loose gravel or debris. The maximum turning radius for the
nosewheel steering system is 45 degrees either side of center.
19.2 FT 22.2 FT
4.65 FT
25.37 FT
CURB TO CURB
23.68 FT
B4CRH-EXPN002i
Aircraft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TOWED
Observe the aircraft turning distances depicted in Mini-
mum Turning Radii.
Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CHOCKED
Tow Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . REMOVED
Torque Link Upper Pin . . . . . . . . . . . . . . . . . . . INSTALLED
Insert the disconnect pin through the torque link sleeve
and nose gear shock strut.
Aircraft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TOWED
Observe the aircraft turning distances depicted in Minimum
Turning Radii.
Taxiing
Pretaxi Procedure
Area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLEAR
Torque Link . . . . . . . . . . . . . . . . . . . . . . . . . . .CONNECTED
Static Ground Cable . . . . . . . . . . . . . . . . . . . . . . REMOVED
Taxi Procedure
Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SET
Engines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . START
Refer to the Normal Procedures section of the Airplane
Flight Manual for engine starting procedures.
Wheel Chocks . . . . . . . . . . . . . . . . . . . . . . . . . . . REMOVED
Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . . RELEASED
Taxi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BEGIN
Apply only sufficient thrust to start roll.
23.0 FT
17.13 FT
8.0 FT
B4CRH-EXPN003i
Parking
Under normal weather conditions, the aircraft may be parked
and headed in a direction to facilitate servicing without regard
to prevailing winds. For extended parking, head aircraft into the
wind.
Aircraft . . . . . . . . . . . . . . . . . . . . . . . . . . PARKED ON HARD,
LEVEL SURFACE
Nosewheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CENTERED
Control Gust Locks . . . . . . . . . . . . . . . . . . . . . . . INSTALLED
Mooring
No mooring is necessary in wind speeds up to 40 kt if the air-
craft is headed into the wind, the parking brake is engaged, and
main gear front and rear chocks are installed.
If extended parking plans or impending weather necessitates
mooring the aircraft, 3/4-inch ropes are attached to the nose
gear and main gear struts. This procedure requires that tie-
down eyelets be set into the apron; there is no procedure for
mooring at unprepared facilities.
Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NEUTRAL
Flaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . UP
Gust Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . INSTALLED
Emergency Exit Locking Pin . . . . . . . . . . . . . . . INSTALLED
Wheel Chocks . . . . . . . . . . . . . . . . . . . . . . . . . . . INSTALLED
Aircraft . . . . . . . . . . . . . . . . . . . . . . . . STATICALLY GROUND
Removing Snow
Use a brush to remove dry snow from aircraft surfaces, or
employ cold air blast. In either case, exercise care to prevent
“trapping snow” in control surface gaps and hinges. If ambient
conditions are above freezing, dry snow may be removed by
applying a hot blast, then spraying the cleared surface with
deicing fluid.
Use rubber squeegees to remove wet snow. Again, exercise
care to prevent trapping snow in control surface gaps and
hinges. If ice formed under the snow, apply deicing fluid.
For frozen snow and ice films, first clear loose snow, then apply
deicing fluid. Brush the snow as fluid is applied to assist in
breaking up deposits and to keep the fluid on the deposit. After
all frozen deposits are removed, apply a light coating of fluid to
keep the surface clear. Brush off or mop up any water resulting
from melted ice as soon as possible.
After clearing snow, make sure the following are free of frost,
ice, or frozen deposits:
static vents pitot heads
angle-of-attack probe (if installed)
drain mast
all intakes
all control surfaces airbrakes
landing gear.
Removing Hoar Frost
To remove hoar frost, spray deicing fluid according to the fluid
manufacturer's instructions. If the frost-forming conditions are
severe, apply a light coat of concentrated fluid after defrosting
to maximize the holdover period.
Removing Sleet and Freezing Rain
To remove sleet or freezing rain, spray undiluted deicing fluid
according to the fluid manufacturers’ instructions. Use hot fluid
when possible.
Preflight Inspection
In ground icing conditions, conduct a pre-takeoff contamination
check within five minutes of takeoff, preferably just prior to taxi-
ing onto the active runway. Critical areas of the aircraft (e.g.,
empennage, wing, windshield, control surfaces) must be
checked to ensure they are free of ice, slush, and snow or that
the deicing/anti-icing treatment is still effective.
During preflight inspection, inspect areas where surface snow
or frost could change or affect normal system operations. The
following are supplemental preflight checks.
All Protective Covers/Blanks . . . . . . . . . . . . . . . . REMOVED
All Surfaces . . . . . . . . . . . . . . . FREE OF FROST/ICE/SNOW
The wing leading edges, all control surfaces, tab surfaces,
flap jacks and balance panel cavities must be free of ice or
snow. Check control balance cavities and drain holes for
drainage after snow removal; puddled water may refreeze in
flight.
Engine Inlets. . . . . . . . . . .CLEAR OF INTERNAL ICE/SNOW
Check that the inlet cowling is free of ice or snow and that
the engine is free to rotate.
Fuel Tank Vents . . . . . . . . . . . . . . . . . . .FREE OF ICE/SNOW
Check accessible fuel tank vents; remove all traces of ice or
snow.
Pitot Heads and Static Ports . . . . . . . . . . . . . CLEAR OF ICE
Water rundown from snow removal may refreeze immedi-
ately forward of static ports and cause an ice build-up. This
build-up results in disturbed airflow over the static ports,
which causes erroneous static readings, even though the
static ports themselves are clear.
As snow on the windshield melts, it may also form sheet ice
over a large area of the forward fuselage and obstruct the
static ports.
Engine Start
Preheating engines exposed to cold soaking in temperatures
below -19ºF (-29ºC) is recommended, with particular attention
to accessory gearbox and fuel system components.
Taxi/Before Takeoff
When significant quantities of precipitation in the form of snow,
slush, or water are on the runway, takeoff performance may
vary considerably; refer to the AFM.
Taxi
Nosewheel Steering. . . . . . . . . . . . . . . . . . . . . . . . EXERCISE
Brakes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . APPLY
When taxiing in snow or slush, the manufacturer recom-
mends that brake applications be made to enable the resid-
ual heat in the brake friction discs to dispose of any slush
accumulation in the brake units.
Before Takeoff
Flaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TAKEOFF
Extend the flaps to the takeoff setting at this time if they
have been held due to slush or wet snow. Consider using a
zero flap (0 degrees) takeoff configuration.
Engine Oil Temperature. . . . . . . . . . . . . . . . . . . . . . . .CHECK
Ensure the oil temperature gage needle is in the green arc.
Before Takeoff Check . . . . . . . . . . . . . . . . . . . . . COMPLETE
To ensure the aircraft is configured for takeoff, complete the
before takeoff checklist before releasing brakes.
Takeoff
In icing conditions, ensure wing anti-ice, engine ignition, and
engine anti-ice are on for takeoff.
If the aircraft starts to slide on ice or snow during the engine
power check, release the brakes and begin the takeoff roll.
Continue the engine check during the early part of the takeoff
roll. A forward pressure on the control column increases nose-
wheel steering effectiveness.
Climb/Cruise/Descent
When engine anti-ice is selected on, engine idle RPM is higher
(i.e., raised idle) to ensure adequate engine and intake ice pro-
tection. The thrust at a given RPM decreases; fuel flow and ITT
increase. The penalties on sector fuel are large.
The following is the recommended procedure.
Climb at 220 KIAS with normal climb power.
If it is necessary to cruise into an icing layer, use long
range cruise performance; it is more economical to cruise
below an icing layer than in it.
Thrust levers may be closed. Full airbrakes give a rate of
descent of about 3,000 fpm. Higher airspeeds (up to VMo/
MMo) may be used if required for a higher rate of descent.
Hold at recommended holding speed.
Landing
Select engine ignition ON prior to landing; switch engine igni-
tion OFF after landing.
If reverse thrust is not used, shutting down either engine after
selecting speedbrakes helps deceleration. In a crosswind, shut
down the downwind engine.
If available, use reverse thrust; however, select forward idle if
directional control becomes difficult.
Ground clearance with flaps lowered is relatively small; when
operating on a runway with deep puddles, slush, snow or ice,
observe the following:
Taxi-In/Park
If severe icing conditions are present, utilize engine anti-icing.
Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2C-3
Checklists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2C-4
Climb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2C-14
Cruise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2C-16
Descent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2C-17
Landing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2C-36
General Information
CAE SimuFlite strongly supports the premise that the disci-
plined use of well-developed Standard Operating Procedures
(SOP) is central to safe, professional aircraft operations, espe-
cially in multi-crew, complex, high performance aircraft.
If your flight department has an SOP, we encourage you to use
it during your training. If your flight department does not already
have one, we welcome your use of the CAE SimuFlite SOP.
Corporate pilots carefully developed this SOP. A product of their
experience, it is the way CAE SimuFlite conducts its flight
operations.
The procedures described herein are specific to the Beechjet
400A and apply to specified phases of flight. The flight crew
member designated for each step accomplishes it as indicated.
Definitions
PF – Pilot Flying. The pilot responsible for controlling the flight
of the aircraft.
PIC – Pilot-in-Command. The pilot responsible for the opera-
tion and safety of an aircraft during flight time.
PM – Pilot Monitoring. The pilot who is not controlling the flight
of the aircraft.
LH/RH – Pilot Station. Designation of seat position for accom-
plishing a given task because of proximity to the respective
control/indicator. Regardless of PF or PM role, the pilot in that
seat performs tasks and responds to checklist challenges
accordingly.
CAE SimuFlite
Flow Patterns
Flow patterns are an integral part of the SOP. Accomplish the
cockpit setup for each phase of flight with a flow pattern, then
refer to the checklist to verify the setup. Use normal checklists
as “done lists” instead of “do lists.”
Flow patterns are disciplined procedures; they require pilots
who understand the aircraft systems/controls and who method-
ically accomplish the flow pattern.
Checklists
Use a challenge-response method to execute any checklist.
After the PF initiates the checklist, the PM challenges by read-
ing the checklist item aloud. The PF is responsible for verifying
that the items designated as PF or his seat position (i.e., LH or
RH) are accomplished and for responding orally to the chal-
lenge. Items designated on the checklist as PM or by his seat
position are the PM's responsibility. The PM confirms the
accomplishment of the item, then responds orally to his own
challenge. In all cases, the response by either pilot is confirmed
by the other and any disagreement is resolved prior to contin-
uing the checklist.
After the completion of any checklist, the PM states “_______
checklist is complete.” This allows the PF to maintain situa-
tional awareness during checklist phases and prompts the PF
to continue to the next checklist, if required.
Effective checklists are pertinent and concise. Use them the
way they are written: verbatim, smartly, and professionally.
Omission of Checklists
While the PF is responsible for initiating checklists, the PM
should ask the PF whether a checklist should be started if, in
his opinion, a checklist is overlooked. As an expression of good
crew resource management, such prompting is appropriate for
any flight situation: training, operations, or check rides.
Challenge/No Response
If the PM observes and challenges a flight deviation or critical
situation, the PF should respond immediately. If the PF does
not respond by oral communication or action, the PM must
issue a second challenge that is loud and clear. If the PF does
not respond after the second challenge, the PM must ensure
the safety of the aircraft. The PM must announce that he is
assuming control and then take the necessary actions to return
the aircraft to a safe operating envelope.
Abnormal/Emergency Procedures
When any crewmember recognizes an abnormal or emergency
condition, the PIC designates who controls the aircraft, who
performs the tasks, and any items to be monitored. Following
these designations, the PIC calls for the appropriate checklist.
The crewmember designated on the checklist accomplishes
the checklist items with the appropriate challenge/response.
The pilot designated to fly the aircraft (i.e. PF) does not perform
tasks that compromise this primary responsibility, regardless of
whether he uses the autopilot or flies manually.
Both pilots must be able to respond to an emergency situation
that requires immediate corrective action without reference to a
checklist. The elements of an emergency procedure that must be
performed without reference to the appropriate checklist are
called memory or recall items. Accomplish all other abnormal and
emergency procedures while referring to the printed checklist.
Accomplishing abnormal and emergency checklists differs from
accomplishing normal procedure checklists in that the pilot
reading the checklist states both the challenge and the
response when challenging each item.
CAE SimuFlite
CAE SimuFlite
CAE SimuFlite
for takeoff
Q initial heading/
course
Q initial altitude
Q airspeed limit
(if applicable)
Q clearance limit
Q emergency return
plan
Q SOP deviations.
Consider the
following:
Q impaired runway
conditions
Q weather
Q obstacle clearance
Q instrument
departure
procedures
Q abort
Holding Short(continued)l
PF PM
Takeoff Roll
PF PM
At V1
CALL “V1.”
ACTION Move hand from
throttles to yoke.
Push and hold F/D
TCS.
At VR
CALL “Rotate.”
ACTION Rotate to
approximately 13-15
degrees pitch
attitude for takeoff.
Climb
PF PM
angles are
acceptable.
CALL “Attitudes check.”
Or, if a fault exists,
give a concise
statement of the
discrepancy.
400 ft. Above Airport Surface (Minimum)
CALL “400 feet”
NOTE:
V2 +10 KIAS (10
degree flaps) or V2
+20 KIAS (20 degree
flaps).
Climb (continued)
PF PM
Cruise
PF PM
Descent
PF PM
Descent (continued)
PF PM
Q field elevation
Q timing required
Q DA/MDA
Q MAP (non-precision)
Q VDP
procedures, if required)
Q missed approach procedures
Q approach speed
Q approach course
Q FAF altitude
Q DA/MDA altitude
Q field elevation
Q VDP
Q missed approach
Q heading
Q
altitude
Q
intentions
Q
abnormal implications.
Accomplish as many checklist items as possible. The Approach
checklist must be completed prior to the initial approach fix.
Precision Approach
PF PM
approach altitude in
altitude alerter.
Q Check PF and PM
instruments.
Q Call FAF inbound.
CAE SimuFlite
CAE SimuFlite
Non-Precision Approach
PF PM
Prior to FAF
CALL “_____ (number)
miles/minutes from
FAF.”
CALL “Gear down.”
“Before Landing
checklist.”
CALL “Gear selected
down.” When gear
extension is
complete,
“Gear indicates
down.”
ACTION Complete Before
Landing Checklist.
CAE SimuFlite
At FAF
CALL “Final Approach fix.”
ACTION Q Start timing.
Q
Visually crosscheck
that both altimeters
agree.
Q Set MDA (or
nearest 100 ft
above) in altitude
alerter.
Q Check PF and PM
instruments.
Q
Call FAF inbound.
CALL “Flaps 30.”
CALL “Flaps selected 30.”
When flaps indicate
30 degrees,
“Flaps indicate 30.
Before Landing
checklist complete.”
At 1,000 ft Above MDA
CALL “1,000 ft to
minimums.”
CALL “Check.”
CAE SimuFlite
At MDA
CALL “Minimums. _____
(time) to go.” or
“Minimums. _____
(distance) to go.”
CALL “Check.”
At Point Where PM Sights Runway or Visual References
CALL “Runway (or visual
reference) _____
o’clock.”
CALL “Going visual. Land.”
or “Missed approach.”
At MAP
CALL “Missed approach
point. Missed
approach.”
CALL “Missed approach.”
ACTION Apply power firmly ACTION Assist PF in setting
and positively. power for go-around.
Activate go-around
mode and initially
rotate the nose to the
flight director go-
around attitude.
CALL “Flaps 10.” CALL “Flaps selected 10.”
When flaps indicate
10 degrees,
“Flaps indicate 10.”
At Positive Rate of Climb
CALL “Positive rate.”
CALL “Gear up.”
CALL “Gear selected up.”
When gear retraction
is compete,
“Gear indicates up.”
ACTION Announce heading
and altitude for
missed approach.
CAE SimuFlite
CAE SimuFlite
CAE SimuFlite
Landing
PF PM
check
Q callouts
Q
gear down
verification
Q flap verification.
CALL “Autopilot/yaw
damper off.”
CALL “Final gear and flaps
recheck.”
At 100 ft Above Touchdown
CALL “100 ft.”
At 50 ft Above Touchdown
CALL “50 ft.”
Landing (continued)
PF PM
At Touchdown
ACTION Apply brakes. ACTION Extend speedbrake.
CALL “Speedbrake
extended.”
ACTION Deploy thrust
reversers
CALL “Two DEPLOY lights”
CALL As airspeed
decreases through
60 KIAS,
“60 Knots.”
ACTION Stow thrust
reversers.
CAE SimuFlite
Maneuvers
Table of Contents
Approach Speed Explanation . . . . . . . . . . . . . . . . . . . . . . 2D-2
CAE SimuFlite
MFG.’S
FLAP CORRECTION CALCULATED ACTUAL
PUBLISHED
CONFIG. FACTOR VREF VREF
VREF
(DURING (FOR OTHER (ESTIMATED (COMPUTED
(14,000 lbs)
APPROACH) THAN FLAPS 1.3 AOA) 1.3 AOA)
30°)
Most of the time approaches are flown in the landing configuration (Flaps
30°), and consequently the calculated VREF will be the same as the pub-
lished VREF. But if the approach configuration is other than Flaps 30 °, the
published VREF must be adjusted with a correction factor to estimate 1.3
AOA. This will result in a higher calculated VREF than the published VREF.
For example, if an approach is flown at flaps 0°, then 20 KIAS must be
added to the published VREF to determine calculated VREF.
In the Beechjet 400A, the AOA system can compute an actual VREF by
using the AOA vanes. The actual VREF is displayed on the PFD (in the form
of a Greenline). Flying the Greenline always assures the appropriate speed
(regardless of configuration) for 1.3 AOA. Most pilots can avoid the “mental
gymnastics” of VREF simply by using the Greenline all the time. However, it
is important to remember that the Greenline changes every time your con-
figuration changes.
The CAE SimuFlite SOP recommends crossing the FAF at VREF +10 kts (for
maneuvering), and then crossing the threshold at VREF. In order to observe
the PTS tolerances of desired airspeed (±5 kts) on final approach, plan a
target approach speed of Greenline -0 / +10 kts. But be sure to always use
the calculated VREF -0 / +10 kts to estimate and verify the accuracy of your
Greenline.
Normal Takeoff
NOTE:
PRIOR TO TAKING ACTIVE RUNWAY:
HEADING BUG – SET RWY HEADING
LINE-UP CHECK COMPLETE
8 CLIMB
ı (AT 1500 FT AGL, MIN)
ı AIRSPEED – ACCELERATE TO 220/250
KIAS CLIMB PROFILE
CLIMB POWER – SET MCT
AFTER TAKEOFF CHECKLIST COMPLETED
TAKEOFF
1 BRAKES – HOLD
POWER – SET TO 90% N1
ENGINE INSTRUMENTS – CHECK
BRAKES – RELEASE 7 ı FT AGL
400
POWER – ADVANCE TO TARGET N1
PM – "400 FEET"
MAX POWER – OBTAINED BY 60 KTS PF – LOWERS NOSE TO 10° NOSE-UP
3 AT 80 KTS PF – "FLAPS UP, AFTER TAKEOFF CHECKLIST"
PM – "80 KTS CROSSCHECK"
4 AT V1
PM – "V1"
PF – BOTH HANDS ON YOKE
2 PM – "AIRSPEED ALIVE"
(BOTH SIDES)
5 AT VR
PM – "ROTATE"
*
PF – ROTATE 13-15° NOSE UP
F/D TCS – PITCH SYNC
PM – "V "
2 AT POSITIVE RATE OF CLIMB
6 PM – "POSITIVE RATE"
PF – "GEAR UP, LIGHTS – IN,
YD – ON"
* (FOR
NOTE:
NOISE ABATEMENT TAKEOFF)
MAINTAIN 15° PITCH UP TO 1,500 FT
FLAPS – UP
AIRSPEED – ACCELERATE TO CLIMB SPEED
AFTER TAKEOFF CHECKLIST – COMPLETE
B4CRH-MV001i
Rejected Takeoff
TAKEOFF
1 BRAKES – HOLD
POWER – SET TO 90% N1
ENGINE INSTRUMENTS – CHECK
BRAKES – RELEASE
POWER – ADVANCE TO TARGET N1
MAX POWER – OBTAINED BY 60 KTS
2 PM – "AIRSPEED A L I V E "
(BOTH SIDES)
AT 80 KTS
3 PM – "80 KTS CROSSCHECK"
ABORT
5 WHEEL BRAKES – MAX EFFORT
THRUST LEVERS – IDLE *
SPEEDBRAKES – EXTEND
THRUST REVERSER(S) – DEPLOY
SAFE SPEED ADVISE TOWER – ABORTING
B4CRH-MV002i
Steep Turns
5 ROLLOUT
PM – "30°/20°/10°"
START ROLLOUT 10°
CLEAN CONFIGURATION
1 MANEUVER SETUP BEFORE ROLLOUT
ATTITUDE – TRIM AIRPLANE FOR HEADING 6 EXIT
200 KTS LEVEL FLIGHT ROLLOUT – ON HEADING AND ALTITUDE
POWER – APPROXIMATELY 70% N1 POWER – REDUCE BY 8% N TO MAINTAIN
1
PITCH – 5° 200 KTS
B4CRH-MV003i
Stall Series
1 CLEAN/CRUISE CONFIGURATION
2 ▪ GEAR – UP
TAKEOFF/APPROACH CONFIGURATION ▪ FLAPS – UP
▪ GEAR – DOWN ▪ AUTOPILOT – ON
▪ FLAPS – 10° ▪ THROTTLES – 50% N1
▪ AUTOPILOT – OFF ▪ PITCH – MAINTAIN LEVEL FLIGHT (AUTOPILOT)
▪ THROTTLES – 50% N1 ▪ BANK – WINGS LEVEL
▪ PITCH – MAINTAIN LEVEL FLIGHT ▪ TRIM – AUTOPILOT CONTROLLED
▪ BANK – 15 to 30° ▪ SLOW TO FIRST INDICATION OF STICK SHAKER
▪ TRIM – TRIM TO 140 KTS ▪ RECOVERY
▪ SLOW TO FIRST INDICATION OF STICK SHAKER AT THE FIRST INDICATION OF STALL, SIMULTANEOUSLY ACCOMPLISH THE FOLLOWING:
▪ RECOVERY ▪ AUTOPILOT – OFF
AT THE FIRST INDICATION OF STALL, SIMULTANEOUSLY ACCOMPLISH THE FOLLOWING: ▪ PITCH – REDUCE ANGLE OF ATTACK (TRIM AS NECESSARY)
▪ AUTOPILOT – OFF ▪ BANK – LEVEL THE WINGS
▪ PITCH – REDUCE ANGLE OF ATTACK (TRIM AS NECESSARY) ▪ THROTTLES – INCREASE POWER AS NECESSARY
▪ BANK – LEVEL THE WINGS ▪ SPEEDBRAKES – RETRACT
▪ THROTTLES – INCREASE POWER AS NECESSARY ▪ REGAIN CONTROL OF AIRCRAFT AND RECOVER TO MANEUVERING SPEED
▪ SPEEDBRAKES – RETRACT AND FLIGHT PATH APPROPRIATE FOR THE AIRPLANE’S CONFIGURATION.
▪ REGAIN CONTROL OF AIRCRAFT AND RECOVER TO MANEUVERING SPEED ▪ DO NOT EXCEED ANY LIMITATIONS
AND FLIGHT PATH APPROPRIATE FOR THE AIRPLANE’S CONFIGURATION.
▪ DO NOT EXCEED ANY LIMITATIONS
NOTE:
EVALUATION CRITERIA FOR A RECOVERY FROM AN APPROACH TO STALL SHOULD NOT
MANDATE A PREDETERMINED VALUE FOR ALTITUDE LOSS AND SHOULD NOT MANDATE
MAINTAINING ALTITUDE DURING RECOVERY.
LANDING CONFIGURATION
3 ▪ GEAR – DOWN
▪ FLAPS – 30°
▪ AUTOPILOT – OFF
▪ THROTTLES – 60% N1
▪ PITCH – MAINTAIN LEVEL FLIGHT
▪ BANK – WINGS LEVEL
▪ TRIM – TRIM TO 140 KTS
▪ SLOW TO FIRST INDICATION OF STICK SHAKER
▪ RECOVERY
AT THE FIRST INDICATION OF STALL, SIMULTANEOUSLY ACCOMPLISH THE FOLLOWING:
▪ AUTOPILOT – OFF
▪ PITCH – REDUCE ANGLE OF ATTACK (TRIM AS NECESSARY)
▪ BANK – LEVEL THE WINGS
▪ THROTTLES – INCREASE POWER AS NECESSARY
▪ SPEEDBRAKES – RETRACT
▪ EXAMPLE: RECOVER TO VREF, THEN EXECUTE A NORMAL GO-AROUND AND ACCELEREATE TO 250 KTS.
▪ DO NOT EXCEED ANY LIMITATIONS
8 LANDING
THRUST LEVERS – IDLE
WHEEL BRAKES – APPLY
SPEEDBRAKES – EXTEND
THRUST REVERSERS – DEPLOY
B4CRH-MV005i
I A F OUTBOUND
2 AIRSPEED – 170 KTS
POWER – 60% N1 (APPROX.)
FLAPS – 10º 1 PRIOR TO INITIATING APPROACH, SLOW
THE AIRPLANE TO 200 KTS IN THE
CLEAN CONFIGURATION
5 AT FAF
FLAPS – 30º
AIRSPEED – VREF + 10
POWER – 60% N1 (APPROX.)
BEFORE LANDING CHECKLIST – COMPLETE
6 AT MDA
ATTITUDE – LEVEL OFF
POWER – 75% N1 (APPROX.)
9 LANDING
THRUST LEVERS – IDLE
WHEEL BRAKES – APPLY
SPEEDBRAKES – EXTEND
THRUST REVERSERS – DEPLOY
B4CRH-MV006i
Circling Approach
1 ENTER BASIC PATTERN AS
APPROPRIATE FOR AIRCRAFT POSITION.
FLY OVER RUNWAY
NOTE: APPROACH CHECKLIST WHEN ESTABLISHED ON CENTERLINE,
SHOULD BE COMPLETE PRIOR TO ENTER BASIC PATTERN AS MAXIMUM 30° BANK TURN TO DOWNWIND
ENTERING THE TRAFFIC AREA. APPROPRIATE FOR AIRCRAFT POSITION. FLAPS – 20°
FLY 90° TO RUNWAY GEAR – DOWN
VREF SHOULD BE CALCULATED
1 START TIMING CROSSING 1
AND AIRSPEED BUG SHOULD BE SET. 4 WITH RUNWAY IN SIGHT AND IN
RUNWAY CENTERLINE POSITION TO MAKE A NORMAL
AFTER 15 SECONDS, TURN
DESCENT TO LANDING
TO DOWNWIND
FLAPS – 20° DESCENT FROM MDA – BEGIN
GEAR – DOWN FLAPS – 30°
AIRSPEED – VREF + 10
BEFORE LANDING CHECKLIST – COMPLETE
IF NOT IN A POSITION TO MAKE A NORMAL
LANDING, GO-AROUND – EXECUTE
5 THRESHOLD
AIRSPEED – VREF
50 FT - THRUST LEVERS TO IDLE
45°
15 SEC
ABEAM POINT
30° BANK
30
SE
C
NOTES:
VISUAL REFERENCE IS THE PRIMARY MEANS
FOR CIRCLING APPROACHES
TIMING IS THE SECONDARY MEANS FOR CIRC- ENTER BASIC PATTERN AS
1
LING APPROACHES (LISTED TIMES ARE BASED APPROPRIATE FOR AIRCRAFT POSITION.
ON VREF + 20, NO WINDS) TURN OVER RUNWAY
AT RUNWAY END, MAXIMUM 30°
BANKED TURN TO DOWNWIND
FLAPS – 20°
GEAR – DOWN
B4CRH-MV008i
1 PATTERN ENTRY
15 SE AIRSPEED – SLOW TO 170 KTS
CON
DS POWER – 60% N1 (APPROX.)
FLAPS – 10°
1,500 FT AGL
900 FT AGL
(IF POSSIBLE) 4 THRESHOLD
AIRSPEED – VREF
50 FT – THRUST LEVERS TO IDLE
M
5N
1.
TO
1
APPR
OX. 3
NM
5 LANDING
THRUST LEVERS – IDLE
WHEEL BRAKES – APPLY
SPEEDBRAKES – EXTEND
THRUST REVERSERS – DEPLOY
B4CRH-MV013i
NOTE:
PRIOR TO TAKING ACTIVE RUNWAY:
HEADING BUG – SET RWY HEADING
LINEUP CHECK COMPLETE
10 1,500 FT AGL
AIRSPEED – ACCELERATE TO 170 KTS
ENGINE SHUTDOWN OR FAILURE IN FLIGHT
CHECKLIST– COMPLETE
1 TAKEOFF
BRAKES – HOLD
POWER – SET TO 90% N 1 8 AT 400 FT AGL (OR OBSTACLES CLEARED)
ENGINE INSTRUMENTS – CHECK ı PITCH – 10°
BRAKES – RELEASE
ı AIRSPEED
IF FLAPS AT 10°
POWER – ADVANCE TO TARGET N1
ACCELERATE TO V2 + 10 KTS
9 CLIMB
MAX POWER – OBTAINED BY 60 KTS AIRSPEED – MAINTAIN 140 KTS
IF FLAPS AT 20°,
ENGINE FAILURE DURING T/O
ACCELERATE TO V2 + 20 KTS
(ABOVE V1 - T/O CONT.) CHECKLIST - COMPLETE
3 AT 80 KTS
PM – "80 KTS CROSSCHECK"
ı AT V2 + 10 (OR V2 + 20) – FLAPS UP
5 ENGINE FAILURE
CALL – "ENGINE FAILURE"
4 AT V1
PM – "V1"
PF – BOTH HANDS ON YOKE
6 AT VR
PM – "ROTATE"
PF – ROTATE (13-15°)
F/D TCS – PITCH SYNC 7 AT POSITIVE RATE OF CLIMB
PM – "V " PM – "POSITIVE RATE"
2
AIRSPEED – MAINTAIN V2
*
PF – "GEAR UP, LIGHTS – IN
Y/D – ON"
B4CRH-MV010i
4 PRIOR TO FAF
AIRSPEED – VREF +20
POWER – 80% N1 (APPROX.)
ONE DOT FLY UP – GEAR DOWN
ONE ENG. INOP APPROACH /
LANDING CHECKLIST – COMPLETE 7 THRESHOLD
AIRSPEED - V REF
5 AT GLIDESLOPE INTERCEPT 50 FT - THRUST LEVERS TO IDLE
AIRSPEED – VREF +10 KTS
POWER – 75% N (APPROX.)
1
8 LANDING
THRUST LEVERS – IDLE
WHEEL BRAKES – APPLY
6 LANDING ASSURED SPEEDBRAKES – EXTEND
B4CRH-MV011i
2 IAF OUTBOUND
AIRSPEED – 170 KTS
POWER – 80% (APPROX.)
5 AT MDA
ATTITUDE – LEVEL OFF
POWER – 80% N1 (APPROX.)
6 LANDING ASSURED
*
FLAPS – 30° (IF REQUIRED)
AIRSPEED – SLOW TO VREF
4 AT FAF
ı AIRSPEED – VREF +10
ı GEAR – DOWN
ONE ENG. INOP. APPROACH / LANDING
CHECKLIST – COMPLETE
7 THRESHOLD
ı AIRSPEED – VREF
NOTE: APPROACH CHECKLIST SHOULD BE 50 FT – THRUST LEVERS TO IDLE
COMPLETE PRIOR TO INITIATING THE
APPROACH. VREF SHOULD BE CALCULATED
AND THE AIRSPEED BUG SHOULD BE SET.
THE APPROACH CHART SHOULD BE 8 LANDING
REVIEWED, AND THE APPROACH BRIEFING THRUST LEVERS – IDLE
SHOULD BE COMPLETE. WHEEL BRAKES – APPLY
SPEEDBRAKES – EXTEND
THRUST REVERSERS – DEPLOY
B4CRH-MV015i
1,500 FT AGL
APPROX.
900 FT AGL
(IF POSSIBLE)
5 THRESHOLD
AIRSPEED – VREF
M
N
50 FT – THRUST LEVERS TO IDLE
5
1.
1-
APPR
OX. 3
NM
B4CRH-MV009i
Emergency Descent
EXPLOSIVE/RAPID DECOMPRESSION
OXYGEN MASKS – DON
MIC SELECTORS – OXY MASK
SPKR SWITCH – ON OR DON HEADSETS
INTPH SWITCH – ON
THRUST LEVERS – IDLE
SPEEDBRAKES – EXTEND
*
AUTO PILOT – OFF DESCENT LEVEL-OFF (MINIMUM SAFE ALTITUDE)
INITIATE – MODERATE BANK NOT TO CABIN SIGN – SAFETY INITIATE LEVEL-OFF AT APPROX. 1,000 FT ABOVE
EXCEED 45º AIRSPEED – ACCELERATE TO VMO/MMO
PITCH – INITIALLY 15º NOSEDOWN DESIRED ALTITUDE
TRANSPONDER 7700 OR PER ATC SPEEDBRAKES – RETRACT
HEADING – MAINTAIN OR AS
REQUIRED BY ATC
CHECKLISTS:
1. RAPID DECOMPRESSION – COMPLETE
2. EMERGENCY DESCENT – COMPLETE
B4CRH-MV019i
4 AT 1500 FT
SET MCT
3 AT 400 FT
LOWER NOSE – TO 10° PITCH
140 KTS – FLAPS UP
ACCELERATE – TO DESIRED CLIMB SPEED
1 MISSED APPROACH BALKED LANDING CHECKLIST – COMPLETE
THRUST – TAKEOFF N1
FLAPS – 10
PITCH UP – 13° TO 15°
AIRSPEED – V
REF
B4CRH-MV007i
* CLEARANCE,
NOTE: IF NEEDED FOR OBSTRUCTION
REMAIN @ VAC UNTIL
CLEAR OF OBSTACLE. CONSULT
APPROACH CLIMB GRADIENT CHART.
*
AIRSPEED – MAINTAIN VAC
B4CRH-MV012i
Limitations
Table of Contents
General Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Enroute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Landing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Kinds of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
CAE SimuFlite
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27
Limitations
General Limitations
Cabin Emergency Exit
Q The internal cabin emergency exit locking pin, if fitted, must
be removed and stowed before the commencement of each
flight.
Cockpit Placards
Q The flight compartment placards illustrate typical flight com-
partment placards pertinent to operations and safety of
flight. For location and description of the placards, refer to
Section II of the Pilot’s Operating Manual.
Cabin Placards
Q The passenger compartment placards illustrate typical plac-
ards which are of a limiting nature. For location and descrip-
tion of the placards, refer to Section II of the Pilot’s
Operating Manual.
Ground Handling
Q
Always ensure the tow pin has been removed before any
towing procedures are carried out.
CAE SimuFlite
Q Always pull or push the towbar horizontally to keep the
weight on the nose wheel for positive steering action. Do not
lift the towbar.
Q The minimum towing radius is approximately 15% less than
the braked taxi-turning radius. For further details, refer to the
Beechjet 400A Maintenance Manual.
Servicing
The following servicing procedures will help maintain the
airplane.
Tires
Q Maintain tire pressure to 125 ±5 PSI for the main landing
gear tires and 120 ±5 PSI for the nose tire.
Window Cleaning
Q Never attempt to clean windows when dry. Flush the surface
with clean water or a mild soap solution, then rub lightly with
a grit-free soft cloth, sponge or chamois and dry. To remove
stubborn grease and oil deposits, use Naptha TT-N-95A
Type II as a detergent and rinse with clean water; avoid pro-
longed rubbing.
Limitations
Operational Limitations
Airspeed Limitations
This airplane complies with FAR 25 and FAR 36. Operations in
compliance with the limitations presented in this section and in
the applicable supplements in Section 7 are required by
Federal Aviation Regulations.
Speeds shown are Knots of Indicated Airspeed (KIAS) or Indi-
cated Mach (MI) as appropriate:
VMO (S.L. to 8,000 ft) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
VMO (8,000 to 11,000 ft). . . . . . . . . . . . . . . . . . . . 264 to 320 (1)
VMO (11,000 to 26,000 ft). . . . . . . . . . . . . . . . . . . . . . . . . . . 320
MMO (above 26,000 ft) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.78
VA . . . . . . . . . . . . . . . . SEE AIRSPEED LIMITATIONS GRAPH
VFE/VFO (Flaps 10 Degrees and 20 Degrees) . . . . . . . . . . . 200
VFO (Flaps 30 Degrees). . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
VFE (Flaps 30 Degrees) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
VLE/VLO (Normal Operation) . . . . . . . . . . . . . . . . . . . . . . . . 200
VLO (Emergency Operation) . . . . . . . . . . . . . . . . . . . . . . . . 150
VSB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NO LIMIT
MSB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . NO LIMIT
VMCA (Flaps 0 Degrees) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
VMCA (Flaps 10 Degrees and 20 Degrees) . . . . . . . . . . . . . . 89
VMCG (Flaps 0 Degrees, 10 Degrees and 20 Degrees). . . . . 88
VWW (if installed) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
CAE SimuFlite
45,000
38,000 FT
40,000 246 KIAS
M
35,000 MO
=0
.78
30,000
ALTITUDE ~ FEET
A
V
26,000 FT
25,000 320 KIAS
20,000
213 KIAS
15,000
FT. 11,000 FT
8000
IAS 320 KIAS
10,000 2 64 K
VA
5000
210 KIAS
S.L.
160 180 200 220 240 260 280 300 320 340
150 170 190 210 230 250 270 290 310 330 350
IAS ~ KNOTS
B4CRH-LM001i
Limitations
Number of Occupants
Flight Crew
Q
The minimum crew is one pilot and one copilot.
Passengers
Q
The total number of passengers carried shall not exceed
nine (9), nor that for which approved seating accommoda-
tion is provided.
Weight/Balance Limitations
Center of Gravity Limitations
Q The airplane weight and center of gravity (CG) for all flight
and ground operations must be maintained within the appli-
cable limits. The flight limits (gear up or down) are automati-
cally complied with when the airplane, loaded to Zero Fuel
Weight (ZFW), is within the zero fuel envelope with the land-
ing gear down.
Compartment Loading Limitations
Q The aircraft must be loaded in accordance with the Aircraft
Weight and Balance Manual and as placarded in the bag-
gage/stowage compartments.
CAE SimuFlite
15000
14000
WEIGHT (POUNDS)
300
400 MAX ZERO FUEL
500 WT. 13000 LBS
13000
600
700
ZONE 800 ZONE
C 900 B ZONE
12000
C
11388
11000
ZONE
2000
A
10000
ULL)
1456
2049 (F
1500
1600
1700
1900
1800
9000
10 15 20 25 30 35
13.3
CENTER OF GRAVITY % MAC
Limitations
Weight Limitations
For aircraft modified by Raytheon Aircraft Company Kit
128-5052 and Hawker 400XP:
Maximum Taxiing (Ramp) Weight . 16,500 LB (7,484.40 KG)
Maximum Takeoff Weight . . . . . . . 16,300 LB (7,393.68 KG)
For aircraft NOT modified by Raytheon Aircraft Company
Kit 128-5052:
Maximum Taxiing (Ramp) Weight . 16,300 LB (7,393.68 KG)
Maximum Takeoff Weight . . . . . . . 16,100 LB (7,302.96 KG)
All aircraft:
Maximum Landing Weight. . . . . . . 15,700 LB (7,121.52 KG)
Maximum Zero Fuel Weight . . . . . 13,000 LB (5,869.80 KG)
Cabin Floor Loading . . . . . . . . . . . . . . . . . . . . 65 LB/SQ FT
Cabin Baggage Compartment (without galley) . . . . . 150 LB
Cabin Baggage Compartment (with galley) . . . . . . . 100 LB
Aft Cabin Baggage Compartment . . . . . . . . . . . . . . . 350 LB
Aft Cabin Baggage Compartment
Floor Loading . . . . . . . . . . . . . . . . . . . . . . . . 125 LB/SQ FT
External Aft Baggage Compartment . . . . . . . . . . . . 450 LB
External Aft Baggage
Compartment Floor Loading . . . . . . . . . . . . . 100 LB/SQ FT
CAE SimuFlite
Takeoff
Q Maximum Takeoff Weight is limited by the most restrictive of
the following:
– 16,300 lbs for aircraft modified by Raytheon Aircraft
Company Kit 128-5052 and Hawker 400XP;
16,100 lbs for aircraft NOT modified by Raytheon Aircraft
Company Kit 128-5052.
– Maximum Takeoff Weight to Achieve Takeoff Climb
requirements in Section 5 of the AFM.
– Maximum Takeoff Weight Limited by Maximum Brake
Energy in Section 5 of the AFM.
– Maximum Takeoff Weight for the runway available and
ambient conditions shown on the Takeoff Speeds and
Field Length tables and Correction graphs in Section 5 of
the AFM.
Q Performance data is provided in the AFM for the three differ-
ent takeoff flap settings: 0 degrees, 10 degrees, and 20
degrees. Each setting provides performance advantages
under different circumstances. In situations where the maxi-
mum takeoff weight is being limited by climb requirements,
brake energy limits, or available runway length, use of a dif-
ferent takeoff flap setting may allow a higher takeoff weight.
Q The Environmental Control System (ECS) can be turned
OFF to increase available thrust during takeoff, thereby
sometimes permitting higher takeoff weights. If ECS OFF
takeoff procedures are used, it is mandatory that ECS OFF
be used for approach and landing in the event of an emer-
gency return to the departure airport. The combined selec-
tion of ECS OFF and Engine Anti-Ice ON is not permissible
operation.
Q Takeoffs under icing conditions shall be conducted with an
airplane free of ice, frost, and wet snow that is adhering to
the airframe. The presence of such accumulations may
result in significant changes in the aerodynamic characteris-
tics, drag, and stalling speed of the airplane, which would
invalidate published performance data.
Q Maximum fuel imbalance . . . . . . (T/O) . . . . . . . . . . 100 lbs.
Limitations
Enroute
Maximum Operating Altitude . . . . . . . . . . . . . . . . . . . 45,000 FT
Ambient Air Temperature . . . . . . . . . . . . . . -65°C to ISA +35°C
Extension of gear, flaps or landing lights is prohibited above
20,000 feet.
Yaw Damper . . . . . . . . . . .OPERABLE AND ON FOR FLIGHT
IN ICING CONDITIONS, OR
FLIGHT ABOVE 28,000 FT
Maximum fuel imbalance . . . . . . . (ENROUTE). . . . . . .300 lbs.
Refrigeration Air
Conditioning Operation . . . . .PROHIBITED ABOVE 18,000 FT
Landing
Q Maximum Landing Weight is limited by the most restrictive
of the following:
– 15,700 lb.
– Maximum Landing Weight to Achieve Approach Climb
Requirements.
– Maximum Landing Weight Limited by Maximum Brake
Energy.
– Maximum Landing Weight for the runway available and
ambient conditions shown on the Landing Distance
Graph.
Q If ECS OFF procedures have been utilized for takeoff, it is
mandatory that ECS OFF thrust settings be used for
approach and landing climb in the event of an emergency
return to the airport of departure.
Q
The landing weight limits under icing conditions consider the
effects of a typical icing encounter on the airplane drag and
flying capabilities. Selection of the ECS OFF thrust setting
combined with Anti-Ice ON is prohibited.
Q Maximum fuel imbalance . . . (LANDING) . . . . . . . .300 lbs.
CAE SimuFlite
Kinds of Operation
Q This aircraft is certified in the Transport Category and is eli-
gible for the following kinds of operation when the appropri-
ate instruments and equipment required by the
airworthiness and/or operating certificate are installed and
approved and are in operable condition:
– Day
– Night
– VFR
– IFR
– Known Icing Conditions.
The following operations are not authorized:
– Acrobatic Maneuvers
– Spins
– Takeoffs and landings from unprepared surfaces
– Not approved for ditching under FAR 25.801.
All Operations
Q The trim system must be checked and operable prior to
flight in accordance with the procedure in Section 4 of the
AFM. The Trim System check may be omitted for turn-
around operations where only the left engine has been shut
down.
Q The stall warning system must be checked and operable
prior to flight in accordance with the procedure in Section 4
of the AFM.
Q The speed brakes must be operable prior to flight in accor-
dance with the procedure in Section 4 of the AFM.
Q
Rudder Boost must be operable and armed for all
operations.
Limitations
CAE SimuFlite
Limitations
CAE SimuFlite
Limitations
System Limitations
Avionics System
Q This avionics system is intended for use with Collins FMS
Program Number:
– RK-1 thru RK-64, except RK-52: 613-5470-017.
– RK-52, RK-65 thru RK-77, and RK-79 thru RK-98:
613-5470-025.
– RK-78, RK-99 and after: 613-5470-028.
Q The following Beechjet Pilot's Operating Manual must be
immediately available to the flight crew:
– RK-1 thru RK-64, except RK-52: P/N 128-590001-97 or
later revision,
– RK-52, RK-65 thru RK-117, RK-119 thru RK-139: P/N
128-590001-149 or later revision.
– RK-118, RK-140 and after: P/N 128-590001-205 or later
revision.
Autopilot
Q Approved for Category 1 ILS approaches only.
Q The autopilot and yaw damper must be disengaged for take-
off and landing.
Q Do not manually override the autopilot in flight.
Q Do not operate the autopilot during airplane trim malfunction.
Q Maximum speed limit for autopilot operation is unchanged
from the airplane maximum airspeed limit (VMO/MMO).
Q
Do not use autopilot below 200 feet above terrain.
Q
A pilot must be seated at the controls with the seat belt and
shoulder harness fastened during autopilot operations.
CAE SimuFlite
Q Autopilot preflight check must be conducted and found satis-
factory prior to each flight on which the autopilot is to be
used.
Q Both AHRS are required for autopilot operation.
Q
Nav captures, including localizer captures, must be accom-
plished with an intercept angle of 90 degrees or less.
Q Increase final approach speed to VREF + 5 knots for autopi-
lot coupled approaches.
Q Localizer back course captures must be accomplished with
an intercept angle of 70 degrees or less.
Q Do not use 1/2 Bank mode when conducting FMS based
approaches.
Q RK-1 thru RK-91, except RK-78.
– Use of speed brakes with autopilot engaged is prohibited.
(When Kit P/N 128-3023 is installed, this limitation no
longer applies).
EFIS
Q The third attitude indicator and the standby power supply
must be operative for takeoff.
Q The MAP mode of navigation and checklist data on the
Multi-function Display (MFD) are provided only as an aid
and are not approved as primary information.
Q The pilot’s and copilot's PFDs (three and four tube systems)
must be operative in the normal mode for takeoff.
Q The pilot's and copilot's Air Data Computers must be opera-
tive for takeoff.
Q After applying power to the AHRS, the aircraft must not be
moved until the altitude and heading warnings have cleared.
Limitations
CAE SimuFlite
Limitations
CAE SimuFlite
Q If the GPS sensor is unavailable, and following a period of
CHK POS, dead reckoning or when a cross-check with other
onboard approved navigation equipment reveals an error
greater than 3 nm, the aircraft position should be verified by
visually sighting ground reference points and/or by using
other navigation equipment such as VOR, DME, NDB, and/
or radar fix.
Q
Instrument approaches must be accomplished in accor-
dance with approved instrument approach procedures that
are retrieved from the AMS-5000 database. The AMS-5000
database must incorporate the current update cycle.
– Instrument approaches must be conducted in the
approach mode and GPS integrity monitoring (for system
incorporating a GPS sensor) must be available at the
Final Approach Fix.
– Accomplishment of ILS, LOC, LOC-BC, LDA, and SDF
approaches are not authorized utilizing the AMS-5000
system.
– When an alternate airport is required by the applicable
operating rules, it must be served by an approach based
on other than GPS navigation, the aircraft must have
operational equipment capable of using that navigation
aid, and the required navigation aid must be operational.
Q The FMS is approved for RNAV approaches under the fol-
lowing conditions:
– Either VHF navigation receiver must be tuned to the
reference VOR.
– The FMS must be programmed with data from current
published instrument approach procedures only.
Q
Fuel management parameters are advisory only, and do not
replace the primary fuel quantity and fuel flow indicators.
Limitations
CAE SimuFlite
Limitations
Electrical System
General
Q
External power requirements are 28V DC and 1,000 to
1,500 amps.
Q The maximum permitted starter operating time is 30 sec-
onds. After an aborted start, a minimum of five minutes cool-
ing time must be allowed before making another attempt to
start, A further fifteen minutes are required before making a
third attempt. The cycle may be repeated after a further
period of 60 minutes.
Q Do not attempt a battery start if battery voltage is below 22
volts.
Q No takeoff is permitted if battery temperature is above 120°F
and continues to rise on airplanes RK-1 thru RK-48 except
RK-45.
Q No takeoff is permitted if battery temperature is above 135°F
and continues to rise on airplanes RK-45, RK-49 thru
RK-97.
Starter/Generator Limitation
Q Maximum ground operation is 280 amps each generator.
Generator Assisted Start
Q Do not attempt to start the second engine until the generator
load is below 150 amps.
Q Inflight operation (maximum) on RK-1 thru RK-107 not
modified by Kit 128-4014-1, 128-4014-3, 128-4014-5 or
128-4016-1.
Both generators operating
up to 41,000 ft . . . . . . . . . . 280 AMPS EACH GENERATOR
Both generators operating
above 41,000 ft . . . . . . . . . 260 AMPS EACH GENERATOR
CAE SimuFlite
Red Arc/Red
Instrument Green Arc Yellow Arc
Line Maximum
Ammeter 0 to 400 amps 260 to 400 amps 400 amps
Voltmeter – – 32 to 35 volts
Battery Temp Up to 120°F 120 to 150°F 150 to 190°F
Limitations
Environmental
Q The maximum differential pressure (pressure relief valve
setting) is 9.1 PSI.
Q
The cabin must be unpressurized for landing.
Q Combined selection of ECS OFF and engine anti-ice ON is
prohibited.
CAE SimuFlite
Fuel System
Wing Fuselage
Total
Tanks Tanks
(US gal)
(US gal) (US gal)
UNUSABLE FUEL 7.16 1.19 8.35
Limitations
Q
Ground operation of engine anti-ice is not permitted at tem-
peratures above 10°C, except for preflight check.
Q If either pitot heat system fails, the inoperative system
should be identified.
Q Combined operation of ECS OFF and Engine Anti-Ice ON is
prohibited.
CAE SimuFlite
Limitations
Maximum
––– 680 96 104 (2) 60-83 (3) 10-121
Continuous
-40
Idle ––– ––– (4) ––– 40 (Min)
121
-40
Starting ––– (1) ––– ––– (3)
(Min)
135
Transient (Max)
(Except ––– 700 96 104 ––– (15 Min
Starting) over
121)
1
Engine starting conditions only. If starting ITT exceeds 550°C, the following time
limitations apply:
550°C to 600°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Seconds Maximum
600°C to 700°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Seconds Maximum
If the above time limitations are exceeded, refer to the JT15D-5 Maintenance
Manual for inspection procedures.
2
Refer to Takeoff Thrust and Maximum Continuous Thrust Setting charts in Section
5 of the AFM for maximum allowable N1 for ambient conditions.
3
Normal oil pressure is 60 to 83 PSI at N2 speeds above 60%. Oil pressure below
60 PSI is undesirable and should be tolerated only for the completion of the flight,
preferably at reduced power setting. Under cold conditions, oil pressure may
exceed 83 PSI.
4
Engine idle conditions
In icing conditions:
Engine EFC ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52% N2 (Min)
In non-icing conditions
Engine EFC ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52% N2 (Min)
Engine EFC OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46% N2 (Min)
CAE SimuFlite
Limitations
Oil Limitations
Q Approved Oils:
– Use Synthetic Oil Type II per Pratt & Whitney Service
Bulletin 7001.
– Check oil level before each flight and service as required.
An accurate oil level can only be obtained 10 to 30 min-
utes after engine shutdown. Service with an oil recom-
mended in Pratt & Whitney Service Bulletin 7001.
– If the same brand of oil is unavailable for replenishment,
Synthetic Oil Type II per Pratt & Whitney Service Bulletin
7001 may be used provided the total quantity added does
not exceed 2 US quarts per engine in any 400 hour
period.
Q Oil Temperature:
– The normal oil temperature operating range is 10°C to
121°C.
– Minimum oil temperature for engine starting is -40°C.
Q Oil Consumption:
– The maximum permissible oil consumption rate of an
engine during any flight is 0.5 lb/hr over a 10 hour period
or approximately 1 qt in 4 hours.
Engine Icing
Q The ENGINE switches on the ANTI/DEICE portion of the
overhead panel (engine intake ice protection system) may
be ON at any engine speed, including the use of maximum
takeoff thrust for takeoff and balked landing.
Q
Engine anti-Ice systems must be on for taxi and takeoff
when in visible moisture at 5°C or colder.
CAE SimuFlite
Engine Synchronizer
Q
Engine synchronizer must be turned off during takeoff, land-
ing and single engine operation.
Q Engine synchronizer is inoperable when the electronic fuel
control (EFC) is off.
Engine Fuel Control
Q Except during taxi conditions in visible moisture at 5°C or
colder, the engine EFC system may be selected OFF during
ground operation provided the engine speed is manually
maintained at a minimum of 46% N2.
Q With the EFC system selected OFF, a potential exists for the
generators to fall off-line with the thrust levers at idle.
Thrust Reverser Limits
Q Deployment of either thrust reverser is restricted to ground
operations only.
Q Reverse thrust must not be used to back the aircraft.
Q Engine starts with thrust reversers deployed are prohibited.
Q The maximum time for continuous reverse thrust above
reverse idle is 30 seconds.
Q The full reverse cutoff speed is 55 KIAS or above.
Q
The maximum deployed time for reverse idle during taxi
operations is 5 seconds.
Q The restow envelope is 30,000 ft or below and 135 KIAS or
below.
Limitations
Instrument Markings
CAE SimuFlite
( 32
0 ºc
E
TUR )
RA 6 ºf
1500 PE ( -7
M -6 0 ºc
TE
LE
TT
BO
1000
500
0
0 25 50 75 100
PERCENT OF USEABLE CAPACITY B4CRH-LM003i
Figure 3-3; Oxygen Available with Partially Full Bottle
Limitations
Psgrs
207 209 182 136 150 186 211
1
4 89 90 86 75 80 89 95
5 74 76 72 65 69 75 80
6 64 65 63 57 61 66 69
7 56 57 56 51 54 58 61
8 50 51 50 47 49 52 55
9 45 46 45 45 45 47 49
Stall Warning
Q The AOA indicator is divided into three areas:
Green Arc (normal operating area) . . . . . . . . . . . . . . 0 to 0.6
Yellow Arc (caution area) . . . . . . . . . . . . . . . . . . 0.6 to 0.85
Red Arc (warning area) . . . . . . . . . . . . . . . . . . . . 0.85 to 1.0
Q Prior to flight, the Stall Warning system must be checked
and operable in accordance with the procedure in section 4
of the AFM.
CAE SimuFlite
Systems
Table of Contents
Avionics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4A-1
Powerplant. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4K-1
CAE SimuFlite
Avionics
Pitot/Static System
LH PITOT RH PITOT
DRAIN DRAIN
STATIC
PORT
RH STATIC
DRAIN
LH STATIC FRONT PRESSURE BULKHEAD
DRAIN
STBY ALT
100 0 CAB
FT AL I N
0 0 T
35
30 MACH 9 1
40
50 PSI
5
AIRSPEED 6 1 00
COPILOT'S
0 1
A/S
8 8 2 10 2
10 9 3
30
STATIC TEST
KNOTS 12 8 DIFF
4
7 3 10
IND
X 10 7
PRESS
5
14
20 18 16 ALT
25
6 4
CONNECTION
hpa
2992
20 15
CABIN
DIFF
PRES
IND
LH STATIC RH STATIC
PORTS PORTS
B4CRH-AV001I
CAE SimuFlite
Avionics
This chapter provides an overview of the various avionics sys-
tems installed on the Beechjet 400A aircraft. Please refer to the
applicable Aircraft Flight Manual supplements and Pilot’s Manu-
als for operating procedures and complete system descriptions.
Pitot/Static Systems
The pitot/static system supplies dynamic and static pressure
from pitot heads and static vents to the flight instruments and
avionics equipment. The system consists of two pitot tubes,
one for each subsystem, and five static ports, four of which are
used for the two static systems. The fifth static port, located on
the forward pressure bulkhead venting to the unpressurized
nose compartment, is used for the cabin altitude/differential
pressure indicator.
Two pitot tubes on the left and right sides of the aircraft nose
supply ram air pressure. The left pitot tube supplies air pres-
sure to the No. 1 air data computer (ADC) and the computer
generates electric signals to operate the pilots airspeed indica-
tor. The right pitot tube supplies air pressure for the No. 2 ADC,
and the standby Mach/airspeed indicator.
Sources of static air are two dual static ports on either side of
the aircraft fuselage. One static port on each side is for the
pilot’s system and the other on each side is for the copilot’s
system. By having a port on each side for each system, they
will receive a balanced static pressure.
The pilot’s system uses the upper left and lower right static
ports. The pilot’s static system provides static air for the ADC
only, as the computer generates electrical signals to operate
the airspeed and attitude displays on the primary flight display
(PFD).
The copilot’s system uses the upper right and lower left static
ports. It provides static pressure for the No. 2 ADC, standby air-
speed indicator and a standby altimeter.
Avionics
The four power modules independently power the left and right
flight control computers and the left and right flight manage-
ment computers. Each PWR module also powers one data
concentrator. The roll trim coupler receives both left and right
side power from two PWR modules.
There are two CSU-4000 configuration strapping units (CSU) on
the IAPS. Both contain a strapping matrix that sets the left and
right IAPS configurations for the Beechjet 400A installation. The
number 1 CSU provides configuration strapping for the DCMs 1A
and 1B, the number 1 FCC, number 1 FMC and the MDC. The
number 2 CSU provides configuration strapping for the IOC 2A
and 2B modules, the number 2 FCC, number 2 FMC and the ATC.
The MDC-4000 maintenance diagnostic computer (MDC) pro-
vides computation and storage of maintenance parameters for
the avionic LRUs. Additional storage is available for engine
trend/exceedance data and maintenance data from other air-
plane systems. The MDC also interfaces with the DBU-4100
data loader to download maintenance data to a diskette or
upload maintenance diagnostic equations from a diskette.
The MFD performs a built-in test (BIT) upon initial power appli-
cation and then displays the MFD index. If the BIT fails, the dis-
play remains blank.
The MFD has six line-keys on the left bezel, six line-keys on the
right bezel, and six line-keys on the bottom bezel to select the
display or function desired. To display any item, depress the
line-key on the bezel adjacent to the corresponding label on the
MFD index. Some line-keys will have nothing adjacent to them
on the screen, which means they have no function in that
display.
Checklist line items are displayed in three colors as follows:
Green . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Completed items
Magenta . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Current items
Cyan . . . . . . . . . . . . . . . . . . . . . . . . . . . Unaccomplished items
Navigation Display (ND)
On airplanes with the four-tube display only, an ND is installed
on the pilot side of the instrument panel and the MFD is
installed on the copilot side of the instrument panel. It provides
display map data, weather radar and HSI formats. It is also a
reversion backup for the left PFD.
The following features are available:
Q
The formats horizontal situation indicator (HSI), MAP DATA,
and RDR are selected on the Display Control Panel (DCP).
Q
The status line is displayed with all three formats.
Q
The DATA window is selectable with any of the three
formats.
Normal control inputs come from the CDU, DCP and the CHP.
The CDU and DCP are used to set display modes, NAV and
bearing pointer source, and radar mode. The CHP has dual
course set knobs, allowing separate courses, and a single
heading selector.
Navigation signals come from the FMS, left and right attitude
heading computers (AHC), left and right ADCs and the TCAS.
This is done with the NAV SRC and BRG SRC push buttons on
the DCP and the appropriate line key on the CDU.
In all three formats, the radar mode line, status line, and data
window are common. When the HSI format is selected, naviga-
tion information is displayed in the traditional 360 degree com-
pass rose format. The MAP format displays a dynamic
navigational picture of the flight as it occurs. The radar targets
may be superimposed onto the map display. The radar overlay
updates with each antenna sweep. Terrain can also be over-
layed.
Sensor Display Units (SDU)
The SDU-640A sensor displays are identical, high resolution,
monochrome cathoid ray tubes (CRT) that replace conven-
tional RMIs. They incorporate four selectable formats: RMI,
VLF, VOR and DME. The format is selected by rotation of the
FORMAT knob. The selected format is annunciated above the
left index mark. A circular arrow above the right index mark
indicates the direction to turn the FORMAT knob to select a dif-
ferent format.
NOTE: Loss of the No. 1 AHRS will cause the radar stabili-
zation to turn OFF.
Q Heading Select
Q Navigation
Q
Approach
Q Altitude Hold
Q Altitude Preselect
Q
LVL Change
Q Speed
Q Vertical Speed
Q
Go-around
The autopilot panel is located at the bottom of the control ped-
estal. The autopilot is engaged when the A/P Lever is raised. A
green AP ← at the upper left corner of each PFD annunciates
autopilot engagement. To disengage the autopilot:
Q Depress the red autopilot disconnect switch on either control
wheel (the yaw damper is also disengaged).
Q Depress the GO AROUND switch on the left thrust lever
(yaw damper remains engaged).
Q Actuate the center button on the control wheel trim switch
(yaw damper remains engaged).
Q
Move the AP engage lever to the disengaged position (yaw
damper remains engaged).
The yaw damper (YD) is engaged when the YD lever is raised.
When engaged, if the FCC detects a yaw damper failure, it dis-
engages the YD. If the condition causing the disengagement
was momentary, the pilot can reengage the YD after the condi-
tion passes. To disengage the yaw damper:
Q
Depress the red autopilot disconnect switch on either control
wheel.
Q Move the YD engage lever to the disengaged position.
The A/P XFR push button transfers control of the mode select
panel and flight director between the pilot and the copilot.
The TURB push button adapts the autopilot pitch and roll
responses to compensate for turbulence. It is automatically
cleared if a localizer is captured or if the autopilot is
disengaged.
The pitch knob commands AFCS pitch changes. Displacing the
switch clears any vertical mode except glideslope capture and
returns the AFCS to the pitch mode.
The turn knob commands AFCS turns. Moving it clears any lat-
eral mode except approach or localizer capture, returns the
AFCS to roll mode, and commands a roll angle (up to 30
degrees), proportional to the knob position. Localizer capture
disables the turn knob.
The mode select panel (MSP) contains the autopilot mode
select switches. All switches toggle their functions on and off
with indicator lights above them to verify switch selection sta-
tus. Also, mode selections and transitions (i.e. armed to cap-
ture) are displayed on the PFD by flashing the mode for 5
seconds before becoming steady. Lateral and vertical modes
are independent of each other. The lateral mode selections are:
Q HDG
Q
APPR
Q 1/2 BANK
Q NAV
Indicating/Recording Systems
Flight Hour Meter
The flight hour meter, located on the right side panel, records
operating time of the airplane, from takeoff to touchdown, and
displays the operating time in hours and tenths. It operates
whenever the battery switch is ON, the applicable circuit break-
ers are engaged and the main gear strut is extended.
Clock
Digital clocks with two displays are installed on the pilot’s and
copilot’s instrument panels. The left display presents universal
time in hours, minutes and seconds. The right display shows
flight time (FT), elapsed time (ET), local time (LT) and universal
time (UT).
Electrical System
DC Electrical System Diagram
MASTER
ENG START L GEN R GEN AHRS AUX BATT STBY BUS
GEN RESET STBY
NORM PWR
NORM
AHRS 1 STBY PWR STBY ATT IND ARM ON
L GEN
O LEFT LOAD BUS AHRS 2 STBY PWR STBY ALT VIB
F L BUS
OFF SELECT FDR FAIL
F COPLT (STBY INST) LT
R L ITT
RESET L START/GEN ANTI SKID
OFF NO. 1 INV PWR LDG GR POS AHRS AUX BATT ENG EFC START
L DEFOG BLOWER RUD TRIM POS COMM 1
L WSHLD ANTI- ROLL TRIM STBY
RTU 1
EMER ICE CONT L THRUST REV PWR
PUSH TO
DISENG L WSHLD ANTI- CONT SUPPLY
LEFT GENERATOR ICE PWR L ENG EFC
CONTROL UNIT LH STAB
DEICE L ENG ANTI-ICE L VIB
L TAIL FLOOD H STAB DEICE L FUEL FLOW
BATT LT PWR MONITOR L OIL TEMP
CUT OFF RECOG LT PWR L LDG LT CONT L FIRE DETECT
LEFT L GAP DEICE PWR 3 PLT WARN LT L WG FUEL QTY INVERTER
STARTER PLT INST LT XFEED VALVE LEFT RADIO BUS NO. 1
GENERATOR HF POWER INST LT CONT FUSLG FUEL QTY
CABIN PRESS L TRANS PUMP SDU 2 ADF 1 PROC 1 HEAT ON
SHUNT LEFT L BLEED VALVE L FUEL TRANS MFD ** RAD ALTM CDU 1 NUMBER 1
MAIN HYD PRESS IND L JET PUMP FCS 1 GPS 1 ATC 1 INVERTER
BUS VENT BLOWER L AUTO BOOST PFD 1 FMS 1 DME 1 OFF HOT BATTERY BUS
EXTERNAL MASTER TEST L BOOST PUMP
POWER L STARTER L GENERATOR
RELAY L BUS ICE DETECTOR A/P TRIM LEFT OVHD BUS BATT VOLT
RELAY LINE CONTACTOR 4 AHRS AUX BATT ROOM LTS
FEED
1 2
3 4
5 RCCB L WIPER 5 AVIONICS ANN/DIM L AOA HEATER ANTI COLL LT GND AUDIO/RTU
EXTERNAL BATTERY
0 X 100 6
DAU A L PITOT HEAT WING INSP LT GND COMM
POWER TIE IN AMPS L BUS PLT CLOCK PILOT STATIC HEAT
2 TIE RCCB ADC 1
RELAY
BATTERY BATTERY LEFT NON-ESSENTIAL BUS EMERGENCY BUS
BATTERY START BUS CHARGE RECOG LT CONT TCAS
RELAY LH BATT RH BUS L LDG LT PWR GALLEY CONT EMERGENCY BUS STBY BATT
GEN GEN HF CONT TIE RELAY BATT FDR PROT
COMPR 0
10 20 30
NO. 2 INV EMER PWR
EMER FEED LOAD EMER WARN LT
FEED RCCB VOLTS BUS FLOOD INST LT
RCCB
VOLT SEL 2 TIE CABIN SIGN
EMER LT
BATTERY EMERGENCY EMER LDG GR POS
RELAY FIRE BELL
BATT FDR FAIL PASS OXYGEN CONT
R STARTER R BUS RIGHT NON-ESSENTIAL BUS
OVHT RIGHT LOAD BUS DOOR SEAL
1 ON
RELAY TIE RCCB R DEFOG BLOWER RADIO PHONE
O EMER BUS L HYD VALVE
F R START/GEN FLAP R WSHLD ANTI- CABIN DISPLAY FDR FAIL R HYD VALVE
F
NO. 2 INV PWR NORM PITCH TRIM ICE CONT L ENG FIRE EXT
EMER PASS READ LT
H STAB DEICE CONT RUD TRIM R ENG FIRE EXT
1 2
3 4
5 R BUS R WSHLD ANTI- ROLL TRIM POS ROTAT BCN CONT L GND SAFE
REFRIG 0 X 100 6
TAIL FLOOD LT CONT
COMPR R GENERATOR FEED ICE PWR R THRUST REV EMER PITCH TRIM
LINE CONTACTOR AMPS RCCB R ENG ANTI-ICE CONT CABIN TEMP IND TRIM WARN
PWR 2 REFRIG AIRCOND CONT
WING ANTI-ICE R ENG EFC L THRUST REV POS
R LDG LT PWR R VIB R WIPER 5 R THRUST REV POS
RIGHT R LDR LT CONT R FUEL FLOW
MAIN L TR EMER STOW
COPLT WARN LT R OIL TEMP R TR EMER STOW
SHUNT BUS CTR INST AND O/H R TURBINE RPM L TURBINE RPM
RIGHT PANEL LT R ITT RIGHT OVHD BUS L FAN RPM
STARTER RH STAB CTR PED LT R FAN RPM L IGN
GENERATOR DEICE C/B PANEL LT R IGN R AOA HEAT NAV LT L FUEL VALVE
R TAIL FLOOD MAP LT R FIRE DETECT R PITOT HEAT ROTAT BCN PWR INVERTER
R FUEL VALVE
LT PWR AIR COND R WG FUEL QTY COPLT STATIC HEAT NO. 2 L STALL WARN
FLT HOUR METER R BLEED VALVE FUEL TEMP
HYD PRESS CONT R TRANS PUMP ON SDU 1
GALLEY PWR COPLT CLOCK
TOILET SPEED BRAKE R FUEL TRANS RIGHT RADIO BUS
LDG GR R JET PUMP AHRS 1
CABIN LT MFD * CDU 2 OFF NAV 1
MASTER
VANITY R GND SAFE R AUTO BOOST
L GEN R GEN GAP DEICE R BOOST PUMP FCS 2 ATC 2 FLT DATA REC
ENG START NORM REFRIG BLOWERS PFD 2 DME 2 AURAL WARN
R GAP DEICE PWR 3 CONT (H STAB CABIN AUDIO
R GEN 3 DEICE BACK UP) DAU B ADC 2 NAV 2 CKPT VOICE REC
OFF
AHRS 2 ADF 2 COMM 2 PLT AUDIO
SELECT R STALL WARN RADAR RTU 2 COPLT STBY AUDIO
GEN RESET
L NORM COPLT AUDIO FMS 2 GPS 2
CABIN SPKRS PROC 2 HEAT ND **
RIGHT GENERATOR OFF O R BUS
CONTROL UNIT F FDR FAIL
F
RESET
* THREE-TUBE SYSTEM
NOTES: EMER
B4CRH-EL001I
PUSH TO ** FOUR-TUBE SYSTEM
DISENG
1 AIRPLANES RK-52, RK-65 THRU RK-97. 3 AIRPLANES RK-52, RK-65 THRU RK-107.
2 AIRPLANES RK-108 AND AFTER, RK-52, RK-65 THRU RK-107. 4 AIRPLANES RK-108 AND AFTER. NUMBER 2
MODIFIED BY KIT 128-4014-3 OR 128-4014-5. INVERTER
5 AIRPLANES NOT MODIFIED BY KIT 128-5405.
CAE SimuFlite
PRIMARY
PRIMARY 26 V AC SHED BUS
115 V AC SHED BUS
• FLAP POS
• LH OIL PRESS
• RH OIL PRESS SECONDARY SECONDARY
• FLAP ASYM 26 VAC BUS 115 VAC BUS
AC BUS SHED
(SHROUD PANEL)
PRIMARY PRIMARY
115 V AC BUS 26 V AC BUS
• EGPWS • PITCH TRIM POS
• AC SHED IND LT
2 2 INV SEL 2 2
NO 1
NO 2 (ANNUNCIATOR
PANEL)
INV 2
(ANNUNCIATOR FAIL
PANEL)
INV 1 115V
FAIL 115V 115V 115V 26V
15
26V AC VOLTS
0
NO. 2
NO. 1 INVERTER INVERTER
NO. 2 INVERTER SWITCH
PRIMARY 115 V AC AND VOLTAGE AC VOLT
BLOCKING
26 V AC BUSES SELECTOR METER DIODE (2)
SECONDARY BUSES AND SW
PRIMARY SHED BUSES
SECONDARY BUSES NO. 2
NO. 1 INVERTER
INVERTER BATTERY POWER
RELAY
SWITCH NO. 1 GENERATOR POWER EMER BUS
NO. 2 GENERATOR POWER
EMER EMERGENCY
BUS TIE RELAY
RELAY
LH LOAD BUS RH LOAD BUS
B4CRH-EL002i
4B-2 For Training Purposes Only Beechjet 400A
January 2004
Electrical System
DC Electrical System
Electrical power to the airplane is normally supplied by two 28.5
V DC, 400-ampere engine-driven starter-generators. A 24-volt,
40-ampere-hour lead-acid battery or a 24-volt, 36-ampere-hour
nickel-cadmium battery (on airplanes RK-1 thru RK-97) sup-
plies electrical power for engine starting and emergency
requirements. A 28 V DC external power receptacle located on
the right side of the aft fuselage is provided for connection of an
external power unit.
Lead-Acid Batteries
One 24-volt, 40-ampere-hour lead-acid battery is used as a
secondary source of DC electrical power in the airplane. It also
supplies power for engine start or the emergency buses.
The battery power components are the battery relay, battery
switch, battery feeder protection unit, current transformers,
control relays, and indicating lights. A battery feeder protection
subsystem is provided to detect a ground fault that may occur
in the secondary power (battery and external power) feeder line
between the main junction box and secondary power sources.
If a ground fault occurs, the battery feeder protection unit illumi-
nates the BATTERY FDR FAIL light, located on the overhead
switch panel, and drops off the battery and battery tie-in relays.
The BATT CUT OFF annunciator, located on the annunciator
panel, will illuminate when the bus connecting the battery relay
and external power relay loses DC electrical power.
The BATTERY switch, located on the overhead panel, is a tog-
gle-type with three positions: ON, OFF, and EMER. During nor-
mal operation, the BATTERY switch is in the ON position and
the battery relay and battery tie-in relay remain energized.
Placing the BATTERY switch to the EMER position will drop off
the battery relay and battery tie-in relay, isolating the battery
from the start bus. The battery will supply DC power only to the
emergency bus and the BATT CUT OFF annunciator, located
on the annunciator panel, will illuminate.
DC Generation
Primary electrical power is generated by two 28.5 V DC 400-
ampere engine-driven starter-generators. These generators
are also used as starter motors for engine starting. The genera-
tor power is distributed by two main buses that are paralleled
through two remote control circuit breakers (RCCBs) and the
battery charge bus. A generator control unit for each generator
utilizes solid state, integrated circuits and amplifiers to provide
control in both starting and generating modes.
A function of the generator control unit is to monitor for a gener-
ator feeder wire ground fault. Should this occur, generator field
excitation is disconnected by the generator control unit, result-
ing in generator output voltage decay to zero. The generator is
also disconnected from the main bus. The system may be
tested during engine ground run by selecting the L or R GEN
GND FAIL position of the master test switch on the overhead
switch panel. This simulated ground fault will cause the illumi-
nation of the L or R GEN OFF annunciator and GO light, while
the DC voltmeter will indicate zero. Upon completion of the sys-
tem test, reset the appropriate generator by placing the GEN
RESET switch to the RESET position for approximately one
second.
The L and R MASTER GEN switches on the overhead panel,
have a NORM position and an EMER position. When the guard
is closed, the toggle lever is in the NORM position. Placing both
switches to the EMER position removes all electrical power.
The GEN RESET switches have a NORM, OFF or RESET
position. With the switches in the NORM position, generator
control is automatic. Placing the switches to the OFF position
will isolate the generators from the main buses. The RESET
position is momentary and resets a generator that has tripped
as a result of an over voltage, feeder fault, or activation of
either ENG FIRE PUSH switch.
AC Power System
Two static inverters mounted in the nose electronic compartment
supply AC power. These inverters are designated No. 1 and No.
2 and are controlled by INVERTER switches located on the over-
head switch panel. The inverters are designed to produce 115
volts and 26 volts 400 Hz AC, with apparent power rating of 50
volt-amperes each. The inverter operates when its respective
INVERTER switch is placed to the ON position. DC power from
the left load bus is applied directly to the No. 1 inverter. Normally,
the No. 2 inverter is powered from the right load bus through the
No. 2 inverter relay. If DC power on the right load bus fails, the
No. 2 inverter relay is automatically de-energized and the No. 2
inverter is powered from the emergency bus.
Four bus-tie circuit breakers are also located on the main circuit
breaker panel. Two of the circuit breakers, labelled LH BUS TIE
and RH BUS TIE, are the push-pull type. They control their
respective bus-tie RCCBs that connect their respective bus to
the battery charge bus, thus tying the two main buses together.
The other two circuit breakers are also the push-pull type. One
is labelled LOAD BUS TIE, and it ties the left and right load
buses together. The last one is labelled EMER BUS TIE and is
left in the closed position during normal operation. In the closed
position, the EMER BUS TIE circuit breaker supplies power
from the left load bus to the emergency bus via the emergency
bus-tie relay when the emergency relay opens.
Lighting System
The aircraft incorporates three lighting systems: exterior light-
ing, interior lighting and emergency lighting. The exterior light-
ing system includes landing, navigation and recognition lights.
The interior lights include lights used in the cockpit and cabin
areas as well as the cargo and service areas. The emergency
lighting system includes all emergency lighting inside the air-
planes as well as emergency cabin lights.
Interior Lighting
The interior lighting system consists of various combinations of
lighting throughout the cockpit, cabin, and aft fuselage baggage
compartment. Ceiling mounted fluorescent lights installed in the
cabin provide general area lighting controlled by the cabin light
switch in the cockpit and the entrance light switch near the
door. A switch inside the compartment door controls an aft
fuselage baggage compartment light. Individually controlled
reading lights are installed above each passenger seat and
above the card tables in the cabin.
Cabin passenger sign lights are installed in the cabin where
they can be easily seen from all seating locations. A three-posi-
tion CABIN SIGN switch on the overhead panel controls them.
The switch's SAFETY position illuminates the NO SMOKING
and FASTEN SEAT BELT legends while the FSB position illu-
minates only the FASTEN SEAT BELT legend.
Instrument/circuit breaker panel lighting is divided into five
groups: pilot's instrument panel, copilot's instrument panel,
center instrument and overhead panels, center pedestal, and
circuit breaker panels. Each group is powered by an individual
power supply that provides 5 V DC for instrument lights and
115 V AC for the electroluminescent panels. The INTEG switch
located in the INST LIGHT group on the overhead panel con-
trols lighting. Light intensity may be varied for individual prefer-
ence using the PLT INST LT, COPLT INST LT, CTR INST and
O/H PNL, and CENTER PED LT rheostats located on the over-
head panel, and the C/B PNL rheostat located on the aft circuit
breaker panel.
Exterior Lighting
The exterior lighting system consists of navigation lights, anti-
collision lights, a wing inspection light (right light optional), land-
ing lights, rotating beacon, forward recognition light, and
optional tail floodlights. Switches located on the overhead
switch panel individually control all the exterior lights.
Navigation lights are installed on the wing tips and the top rear-
most section of the vertical stabilizer. Anti-collision lights are
installed on the left and right wing tips and on the rearmost sec-
tion of the fuselage. These lights generate white flashes at 50
to 60 cycles per minute.
The wing inspection light is installed on the left side of the fuse-
lage, just aft of the entrance door. An optional second light is
mounted directly opposite on the right side of the fuselage.
These lights are used to inspect for ice formation on the leading
edge of the wings during night flight.
Emergency Lighting
The emergency lighting system consists of an emergency exit
sign light, emergency exit outside lights, and emergency cabin
lights. An emergency exit sign light is installed above the
entrance and escape hatch doors in the cabin. In addition to
the lighted exit sign, an emergency outside light is mounted in
the escape hatch doorframe to illuminate the outside area
around the escape hatch. There is also an emergency outside
light mounted near the cabin doorframe to illuminate the out-
side area around the cabin door.
Two power supplies, one installed under the floor in the forward
right hand cabin and one installed in the right hand aft cabin
sidewall, contain batteries and supply power to the emergency
lights. A guarded EMER LT switch located on the overhead
panel controls all emergency lights. This switch, placarded
TEST/ON, ARM, and OFF, is positioned to ARM when the
guard is closed. When all power is lost, 6 V DC power is sup-
plied to the emergency lights. The power supplies are charged
by generator power when the emergency light switch is set in
the OFF or ARM position. Charging is stopped and the emer-
gency lights are illuminated by their power supply when the
EMER LT switch is set to the TEST/ON position. When the
EMER LT switch is placed in the OFF or TEST/ON position, the
EMER LT NOT ARM annunciator on the shroud panel
illuminates.
With the EMER LT switch positioned to TEST/ON and the BAT-
TERY switch in the ON position, a green light adjacent to the
switch will illuminate when the power supply batteries are fully
charged.
ENG ANTI-ICE
VALVE
LEGEND
UNREGULATED AIR
CABIN
CEILING
15-PSI AIR OUTLET
EMERGENCY
PRESSURIZATION
30-PSI AIR VALVE
30 PSI
VACUUM PRSOV
CHECK
VALVES
AIR
CONDITIONING
WING
ANTI-ICE
SHUTOFF
VALVE
CHECK
VALVES
30 PSI
PRSOV
CABIN
TEMPERATURE
CONTROL
CABIN
PRESSURIZATION
CONTROL SYSTEM CHECK
VALVE
HYDRAULIC
PACKAGE
15 PSI
PRESSURE RESTRICTOR
REGULATOR VALVE
EJECTOR
ENTRANCE
DOOR SEAL
ENG ANTI-ICE
B4CRH-PN001I
EJECTOR
DISCHARGE VALVE
DOOR SEAL
VALVE
RK110
VENT CABIN
BLOWER CEILING
ON/OFF OUTLET
BOTH NORM
L ENG BOTH HIGH
B4CRH-PN003i
TEMPERATURE TO ENTRANCE
TEMPERATURE DOOR SEAL
SENSOR CONTROL VALVES
LEFT ENGINE
BLEED AIR
0 20
BL AIR TO CEO CONTROL
DCT FAIL CABIN CABIN CONTROL
DEFOG -20 50
AIR OV HT
TEMPERATURE °C (IN COCKPIT)
CABIN
TO REFRIG INDICATOR TEMP
COCKPIT CONTROL
AIRCOND TO FAN
CONTROL BUTTON
COCKPIT CABIN
TM
Air Distribution
MIXING
CAE SimuFlite
CHAMBER
COLD AC
VERY COLD
CONTROL
CABIN
PRESSURE
WS
TEMP
COCKPIT SENSOR
WARM TEMP
Developed for Training Purposes
SENSOR
ELECTRICAL
WS
AC
DUCT HIGH TEMP
TEMP LIMIT CONTROL
SENSOR SENSOR VALVES
MIXING
CABIN AIR CHAMBER
OV HT
ANTISKID
FAIL
TM
VACUUM
B4CRH-PN004I
TO DOOR SEAL
Beechjet 400A
March 2002
Environmental Systems
TO RIGHT
WING
L ENG ICE BL AIR
TEMP LO DCT FAIL
AIR COND DEFOG
FAIL AIR OV HT FROM RIGHT
ENGINE
BLEED AIR
TO LAV
3.5 PSI
CEILING OUTLET
EMERGENCY 30 PSI
PRESS VALVE PRESS
TO CABIN REG
PRESSURIZATION SOV
CONTROL
TO TEMP
CONTROL
VALVES
BULK
HEAD
EJECTOR VALVE (OPEN ON GROUND)
TEMP
SW (350°F)
LEGEND
TO TEMP COLD
TM
CONTROL 30 PSI
VALVES PRESS COOL
REG
SOV
ENGINE BLEED
15 PSI FROM LEFT
PRESSURE ENGINE TEMPERED
TO CABIN / DUCT REGULATORS BLEED AIR
SENSOR TEMPERED BLEED
REGULATED
B4CRH-PN005I
PRESSURE
TO DOOR SEAL / VACCUM
TO HYDRAULIC SYSTEM
MOTOR CONDENSER
RECEIVER FAN
DRYER
BELT
DRIVE
PRESSURE
SUCTION
COMPRESSOR
HIGH LOW
PRESSURE PRESSURE
SWITCH SWITCH
SERVICE
VALVE SERVICE
(DISCHARGE) VALVE
(SUCTION)
SIGHT
GLASS
AFT
PRESSURE EVAPORATOR LEGEND
BULKHEAD BLOWER
LOW PRESSURE
LIQUID
LOW PRESSURE
GAS
HIGH PRESSURE
LIQUID
HIGH PRESSURE
EVAPORATOR GAS
CABIN
COCKPIT EVAPORATOR
BLOWER
QUICK
DISCONNECT
REFRI AIR COND CONTROL
AIR COND BLOWER
+ ON FWD HI AFT +
AIR COND
O O ON
EXPANSION F
F
F
F
VALVE
+ BLOWER LOW +
EVAPORATOR OPERATION PROHIBITED BELOW 5ºC OAT
B4CRH-PN006i
Pneumatic Systems
The pneumatic system extracts hot engine bleed air and then
controls, regulates and distributes it. Regulated air is supplied
to the air-conditioning, wing anti-ice, hydraulic reservoir, cabin
temperature control, jet pump and door seal systems. Vacuum
generated by a jet pump is supplied to the pressurization sys-
tem controls. Pneumatics, air-conditioning, ventilation and
pressurization are closely tied together. The pneumatic system
bleed air is supplied to the air-conditioning system, which intro-
duces conditioned air into the fuselage for the passenger’s
comfort. The cabin is pressurized by controlling the rate at
which the air-conditioned bleed air is allowed to escape from
the pressure vessel.
System Operation
High compressor discharge air from the engine is tapped off
from two extraction pads, located respectively at 5 and 7
o’clock on the bypass duct. This gas generator case air pres-
sure is manifolded and provided for airplane services.
The air is routed from the engines to a manifold in such a way
that air from each engine feeds all systems but does not feed
into the opposite engine. The use of check valves allows this
arrangement, and each system that is fed uses some form of
pressure or flow regulation.
An ejector-type air pump is mounted in the wall of the cabin just
forward of the entrance door. The ejector uses regulated bleed
air to produce a vacuum for the pressurization control units.
The vacuum serves as a reference pressure for the system.
The vacuum is ported to the vacuum regulator in the cabin
pressurization control module.
Wing Anti-Ice
Engine bleed air is tapped from the bleed air manifold and
routed to the wing anti-ice pressure regulator and shutoff valve.
The valve is controlled by the anti-ice system, which uses the
air for preventing ice buildup on the wing leading edges. A
more detailed discussion on wing anti-ice can be found in the
Ice and Rain Protection section of this manual.
Hydraulics
Engine bleed air tapped from the bleed air manifold is used to
pressurize the hydraulic system reservoir. This bleed air is regu-
lated to 15 PSI and assures a constant head of pressure on the
hydraulic reservoir. A more detailed discussion on hydraulics can
be found in the Hydraulic Power Systems section of this manual.
Environmental System
The pressurization and air-conditioning systems utilize bleed
air to pressurize and air-condition the cabin, and defog the
cockpit windows. During normal operation, most functions are
automatic. The only manual adjustments required are for indi-
vidual comfort, such as cabin rate of climb and temperature.
Ram air for cabin ventilation is available when the pressuriza-
tion system is not in use.
Air Distribution
Cabin air distribution lines are composed of cold air lines and
conditioned air lines. Cold air is delivered to the cockpit and
cabin overhead eyeball outlets. Conditioned air is fed through
check valves at the aft pressure bulkhead to the cabin floor out-
lets on both sides and to the armrest. The cockpit has a sepa-
rate but similar system. These bulkhead check valves are used
to prevent cabin depressurization in the event of a duct rupture
upstream. The cockpit system includes floor outlets and a wind-
shield and side window defogger. DEFOG SELECT levers are
provided for the pilot and copilot to select defog, floor outlets, or
a combination of both. Thermal switches, installed in the cock-
pit side window defog ducts, illuminate the DEFOG AIR OVHT
annunciator if duct temperatures above 200°F (93°C) are
encountered. This is to prevent the side windows from being
damaged by heat. Manually controlled air outlets are provided
in the upper area of the cockpit to supply cold air to the pilots.
The ventilation blower introduces outside fresh air into the
cockpit depending on whether environmental control system
OFF or ON operation is selected. An illuminated push button-
type switch, located adjacent to the cockpit mode select switch,
controls the ventilation blower operation.
Pressurization
The cabin is pressurized by flow of air from the cockpit and cabin
air outlets. Cabin pressurization control is accomplished by mod-
ulating discharge air from the cabin. The system's major compo-
nents are the outflow safety valves, cabin air pressure controller,
manual control valve, pneumatic relay, altitude pressure regula-
tor, air filters, solenoid valves, and a quick dump valve. This sys-
tem uses a variable isobaric controller to drive two outflow safety
valves through a pneumatic relay. Both outflow safety valves
modulate flow of air discharged from the cabin during normal
operation. Either or both valves open automatically, as required,
to provide positive or negative pressure relief protection. Both
valves are connected to cabin altitude pressure regulators that
automatically override a valve failure and prevent the cabin alti-
tude from exceeding 12,500 ± 1,500 feet.
The CABIN PRESS switch determines the source of air for
cabin pressurization. It is a six-position rotary-type switch with
positions placarded OFF, L ENG, BOTH NORM, BOTH HIGH,
R ENG, and EMER:
OFF – No bleed air is supplied. Ram air is supplied to the
cabin in flight. No temperature control is provided.
L ENG – Bleed air is supplied by the left engine. The right
bleed air is shut off. Normal temperature control is provided.
BOTH NORM – Bleed air is supplied by both engines. Nor-
mal temperature control is provided.
BOTH HIGH – Bleed air is supplied by both engines at a
greater rate than in the BOTH NORM position.
NORM – Position by opening the flow increasing valve. Nor-
mal temperature control is provided.
R ENG – Bleed air is supplied by the right engine. The left
bleed air is shut off. Normal temperature control is provided.
EMER – Bleed air is supplied to the cabin for emergency
pressurization. No temperature control is provided.
Pneumatic Relay
The pneumatic relay is mounted in the cabin pressure control
module that is installed on the cabin side of the forward pres-
sure bulkhead. The pneumatic relay is a high gain device that
operates by a signal from the cabin air pressure controller and
from cabin pressure to regulate the outflow safety valve control
pressure to the desired level.
Altitude Pressure Regulator
The altitude pressure regulator directly senses cabin pressure.
When the cabin altitude pressure reaches 12,500 ±1,500 feet,
the poppet valve in the regulator opens to direct cabin pressure
to both outflow safety valve control chambers. The outflow
safety valves will close to a modulating position, thus prevent-
ing excessive exhaust of cabin air.
Outflow Safety Valves
The two outflow safety valves are installed on the forward pres-
sure bulkhead. The outflow safety valves regulate cabin airflow
through the pressure bulkhead. The valves are controlled by an
air pressure signal from the cabin air pressure controller
through the pneumatic relay. The valve contains a positive dif-
ferential pressure relief (9.1 PSI) and a negative relief.
Manual Control Valve
The MAN PRESS CONT valve, mounted on the instrument
panel, is used to manually depressurize the cabin. This valve is
connected to a vacuum source and the outflow safety valve
control line. The cabin can be depressurized in an emergency
by turning the knob counter-clockwise. This action proportion-
ately vents the control chambers of both outflow safety valves
to vacuum, resulting in opening of the outflow safety valves.
The cabin may be depressurized to an altitude of 12,500
±1,500 feet.
CAE SimuFlite
Environmental Systems
Air Conditioning
Engine bleed air is used to heat, cool, and pressurize the cabin.
Hot compressed air is tapped off the gas generator case of
each engine. Bleed air coming from the engine will not normally
exceed 600°F (315°C) and 150 PSI at takeoff rated power. The
bleed air is routed into the air cycle machine located in the aft
fuselage. Prior to reaching the air cycle machine, bleed air
passes through a pressure regulator/shutoff valve, a venturi,
and a check valve. The pressure regulator/shutoff valve
reduces bleed air pressure to 30 PSI and serves as a system
shutoff. The inlet venturi is installed to restrict the volume of air
that can be extracted from the engine. At low power settings
(below 60% N1 during ground operations) the volume of air
flowing through the venturi is inadequate; therefore, a flow-
increasing valve is used to increase the airflow. Switches
located on the thrust lever quadrant and the squat switch auto-
matically control the flow-increasing valve.
CAE SimuFlite
Temperature Control
The temperature control system is a pneumatically operated
system that manually or automatically regulates the tempera-
ture of air delivered to the cabin from the air cycle machine.
The Beechjet 400A is equipped with a two zone/two mode tem-
perature control system which permits independent control of
cabin and cockpit temperatures.
TEST
AS HORN
IND LTS
ANNUNCIATOR PANEL
GO NO GO
L FIRE R FIRE
LG HORN DET FAIL DET FAIL
OFF
L GEN R GEN
GND FAIL GND FAIL
R STALL FLAP
ASYM
STBY L FIRE SHROUD
BATT DET INDICATION
R FIRE PANEL
DET
L STALL
BOT 1
L H/V L F/V LH ENG RH ENG R F/V R H/V
BOT 2
OPEN OPEN OPEN OPEN
MASTER TEST SWITCH ARMED
L H/V L F/V
FIRE FIRE R F/V R H/V
ARMED
PUSH PUSH
(OVERHEAD PANEL) CLOSE CLOSE PUSH PUSH CLOSE CLOSE
BOTTLE BOTTLE
NO. 1 NO. 2
IN
EXT GUIS
E
HE
FIR
R
D I SC
PRESSURE PRESSURE
OR
GAUGE GAUGE
AT
HA
RG
E IN D I C
OVERBOARD
DISCHARGE L/H ENGINE POD R/H ENGINE POD
INDICATOR
LEGEND
EXTINGUISHER AND DISCHARGE NOZZLES
OVERBOARD DISCHARGE
B4CRH-FR001i
L/H ENGINE FIRE DETECT
DISCHARGE PATH FIRE DETECTOR CONTROL BOX
LOOP
R/H ENGINE
DISCHARGE PATH
The rotary test switch on the overhead switch panel has L FIRE
DET and R FIRE DET positions. These positions are used to
perform integrity checks of the detection circuits, to test the fire
bell and to illuminate the GO/NO GO lights, according to the
condition of the system.
Selection of one of these positions completes a circuit through
the sensing element and detector control unit, simulating a fire
condition. If a fault exists in the detector control or the sensor
element is shorted or open-circuited, the fire warning light will
not illuminate. In this case, the respective red FIRE DET FAIL
light on the annunciator panel will illuminate. The respective
FIRE DET FAIL light will also illuminate any time a sensor ele-
ment is shorted or open, as the sensor is continuously
monitored.
ELEVATOR
VARIABLE
HORIZONTAL
STABILIZER
TRIM
DOT
RH ROLL
TRIM
RUDDER
RUDDER
TRIM TAB
OUTBOARD
SPOILER
LH ROLL
TRIM
B4CRH-FC001I
Speedbrake System
CONTROL VALVE
VALVE PACKAGE
TO CONTROL
UP WHEEL
LEGEND
RETRACT LINE
EXTEND LINE
PRESSURE LINE
RETURN LINE RETRACT
ELECTRICAL LINE EXTEND
FIXED POINT SPEED
MOVABLE POINT BRAKE
CHECK VALVE RET
SPEED
B4CRH-FC002I.AI
BRAKE SHROUD
CONTROL SPOILER
ANNUNCIATOR SPD BRAKE EXTEND MIXER
SWITCH
PANEL
EXT
TO AUTO PILOT SERVO
Flap System
UP
FLAP MASTER
F
FLAP 10º
ASYM
L FUEL
RH LOAD BUS FLAP ASYMMETRY
L
POSITION FEED
- GO / NO GO -
INDICATOR A 20º
P 30º
FLAP ASYMMETRY
DETECTOR
PRIMARY
FLAP ASYMMETRY SHED BUS
DETECTOR
LOCK
VALVE
THERMAL
RELIEF
VALVE
R
H
L
O
SYSTEM PRESSURE A
B4CRH-FC003I
THRUST CONTROL FLAP CONTROL D
SYSTEM RETURN
B
U
S
Speedbrake
The spoilers are used as a speedbrake, as well as for roll con-
trol. The SPEED BRAKE switch on the center pedestal electri-
cally controls the speedbrake. The speedbrake is hydraulically
operated. See Tables 4-1 through 4-3 for the Speed Brake
Deflection Charts.
When the SPEED BRAKE switch is positioned to EXT, electri-
cal power is applied to the extend solenoid of the speedbrake
control valve. This valve supplies hydraulic pressure to the
speedbrake actuator which deploys the spoilers up to a maxi-
mum of 36 degrees on both wings. This creates drag and
reduces lift. The speedbrake actuator uses the same mechani-
cal linkage as the spoiler system to deploy the speedbrakes;
therefore, the pilot can still move the spoiler, using the control
wheel to maintain lateral control. By setting the SPEED BRAKE
switch to the RET position, electrical power is applied to the
retract solenoid of the speedbrake control valve, hydraulic
pressure is supplied to the speedbrake actuator retract port,
and the spoiler surfaces are retracted.
When the SPEED BRAKE switch is set to the EXT position,
advancing either thrust lever to the T.O. position or setting flaps
beyond 10 degrees de-energizes the SPEED BRAKE control
switch holding coil. The switch springs to the retract position
and the spoilers retract automatically.
If the spoilers will not retract normally, emergency retraction
can be accomplished by placing the pedestal mounted and
guarded SPEED BRAKE EMER RET switch to the EMER RET
position. This deactivates the solenoids and dumps hydraulic
pressure. The speedbrakes are blown down by aerodynamic
force.
The SPD BRAKE EXT annunciator, located on the shroud indi-
cator panel, illuminates when the SPEED BRAKE switch is
positioned to EXT and the speedbrake retract limit switch,
installed in the spoiler mixer box, is de-energized.
Flaps
The fowler-type flaps run approximately the full wingspan. The
flaps on each wing consist of a main flap and an aft flap. The
main flap moves along tracks, actuated by push-pull rods in the
drive mechanism on the wing rear spar. The main flap mechan-
ically extends the aft flap as it extends. The wing flaps are
hydraulically actuated with one actuator per side and are inter-
connected by a cable system to ensure symmetrical operation.
The flap system is controlled by a flap control lever located on
the center pedestal to the right of the thrust levers. The flap
control lever has four positions: 0°, 10°, 20° and 30°.
Flap position transmitters, located on the flap operating mecha-
nism, send a signal to the AC-powered flap-position indicator.
The transmitters also send signals to the flap asymmetry detec-
tor unit that, in turn, will stop flap operation if a 5 -7 degree dis-
crepancy occurs between the two outboard sections or the two
inboard sections. When this occurs, the FLAP ASYM annuncia-
tor will illuminate and the flap asymmetry detector will operate
the asymmetry cutout relay. A selector valve in the flap valve
module is de-energized to shut off system pressure to the flap
actuators and flap movement will stop. The flaps cannot be
moved from the position where the asymmetry occurred.
F TRANSFER F
PRESSURE
LOW LEGEND
LOW LEVEL SWITCH
CROSS
DEFUEL SNIFFLE VALVE FLOW DIRECTION
FEED VENT
VALVE (PRESSURE & VACUUM ACCELERATION
SURGE CHECK VALVE
RELIEF) TANK
FLAPPER VALVE
FLAME
FEED CHECK VALVE
ARRESTOR
FUEL
SHUTOFF VALVE
SOV
ELECTRIC PUMP
AFT MOTIVE FUEL
FUSELAGE SHUTOFF VALVE JET PUMP
TANK DEFUEL DRAIN VALVE
FILTER WITH
F
FEED FUEL BYPASS
B4CRH-FU001i
FLAME (PRES. & VACUUM RELIEF) BYPASS
ARRESTOR DRAIN BOX
PRESSURIZED OVERBOARD PRESSURIZED
AIR VENT DRAINS AIR
Fuel System
LEGEND
FUEL TEMP
°C LOW LEVEL SWITCH
-60
-40-20 20 40
0
60
FLOW DIRECTION
6
8
10 ACCELERATION
CHECK VALVE
4 12
R
10 12 14 2 14
COLLECTOR TANK
8
16
6 0 16
FLAPPER VALVE
18 WING
4 FUEL QTY
20
CHECK VALVE
FUEL QTY
LBS X 100
F
LEVEL LO LEVEL LO BYPASS
FUEL PROBE
SUMP DRAIN
F FUEL FILLER CAP
FLOAT CHECK VALVE
BOOST PUMP PRESSURE SWITCH
AUTO
L R
O
F
F F F
R WG TK
ON OV PRESS
FUEL XFEED
ON
FUEL TRANS L R F
NORM
F F JET PUMP
ON
L R OFF
A L R
U NORM
T
O FUEL XFEED OFF
RESET
NORM
L TANK R TANK
B4CRH-FU002i
L F FLTR JET PUMP XFEED JET PUMP R F FLTR
BYPASS BYPASS
FUSELAGE TANK
DRAIN VALVE
B4CRH-FU003i
4F-4 Developed for Training Purposes Beechjet 400A
September 2001
Fuel System
Fuel System
The fuel system provides an independent fuel supply for each
engine and is designed for safe operation between sea level
and 45,000 ft. within a temperature range of -40ºC (-40ºF) to
50°C (122ºF). All components in the fuel system are compatible
with jet fuel grades Jet A, Jet A-1, JP-4, JP-5, JP-8, JP-8 +100
or RP-3 (Chinese). This system is not designed for use of any
grade of avgas. Total usable fuel capacity is 733 US gallons.
Fuel Tanks
Fuel storage is provided in two independent wing tanks, two
aux (forward) fuselage tanks, two mid-fuselage tanks, and one
aft filler tank. A collector tank is internally mounted in the
inboard portion of each wing tank. Refer to Table 4E-A for fuel
tank quantities.
WING FUSELAGE
TOTAL
TANKS TANKS
(US GAL)
(US GAL) (US GAL)
Fuel Feed
Each fuel feed system includes a main jet pump and a standby
electric boost pump, both located in the collector tank at the
inboard end of each wing tank. The pumps are interconnected
by tubing and supply fuel under pressure to the engine and
crossfeed lines. The outboard lower surfaces of the collector
tank are equipped with flapper valves that allow fuel to gravity
flow into the tank. The outboard upper surface of the collector
tank is open to the wing tank to allow fuel to flow outboard dur-
ing fuselage-to-wing transfer and to vent the collector tank. In
addition to the gravity feed, two transfer jet pumps serve to
transfer fuel from the wing into the collector tank. During normal
operation, the main jet pump provides fuel feed to the engine
with motive flow provided by the engine-driven fuel pump. The
boost pump is used during engine starting, crossfeed, wing-to-
collector-tank transfer and as a backup for the main jet pump.
The boost pump is automatically energized during the starting
procedure and, once the engine is started, is shut down by
selecting the OFF position on start select switch.
A fuel shutoff valve is installed in the fuel feed line to stop fuel
flow to the engine in case of engine fire or fuel leakage down-
stream of the valve.
Each fuel filter incorporates a pressure switch and a bypass
valve. If the filter element becomes clogged, the filter pressure
switch actuates and the L or R F FLTR BYPASS annunciator
illuminates. If the pressure difference exceeds 2.3 PSI, the
bypass valve opens and most of the fuel is supplied to the
engine without passing through the filter element.
Fuel Crossfeed
The crossfeed function is used primarily to equalize the fuel
quantities in the left and right wing tanks by operating both
engines from either of the tanks. If crossfeed becomes neces-
sary, placing the crossfeed switch to the L or R TANK position
will turn ON the boost pump on the side supplying fuel, open
the crossfeed valve, and then close the motive fuel shutoff
valve, securing the jet pump on the side being crossfed. Plac-
ing the crossfeed switch back to NORM will open the motive
fuel shutoff valve, shut off the boost pump, and then close the
crossfeed valve. The L or R BOOST PUMP light indicates oper-
ation of the boost pump. The FUEL X FEED light indicates that
crossfeed has been selected and the crossfeed valve is open.
The LH JET PUMP, RH JET PUMP, and X FEED lights illumi-
nate when the respective valves are not yet in the position
required by the crossfeed switch.
CAE SimuFlite
Fuel Transfer
Fuel in the mid-fuselage tanks is transferred to the right or left
wing tanks by electric transfer pumps. During normal operation,
the transfer pump switches, placarded FUEL TRANS-L-R-ON-
AUTO-RESET is set to the AUTO position. With the switches in
this position, fuel transfer is initiated when the generator is
turned on after engine start. Fuel transfer is terminated auto-
matically by the combination of a float switch in the mid-fuse-
lage tank and a pressure switch in the transfer line. When fuel
in the mid-fuselage tank reaches a level just above empty, the
float switch is activated. The pump will continue to run until
pressure in the transfer line drops below 1.3 PSI, at which time
the pump shuts off.
The switch may be moved to the ON position to check transfer
pump operation on the ground and as a backup to the auto-
matic system. When the switch is moved to the ON position, an
indicator light adjacent to the switch will illuminate, indicating
that the pump is operating. If fuel is exhausted in the center
fuselage tank the L or R F XFR PRESS LO annunciator will illu-
minate. The pilot must manually select AUTO to prevent the
pump from running dry.
Fuel level in the wing is controlled by a pilot float valve in the
outboard wing that operates a fill valve in the collector tank.
When the fill valve closes, the transfer pump continues to run,
but at a zero flow.
A wing over-pressure condition, caused by a malfunction of the
wing fuel level control valves, will automatically shut down the
transfer pump with the switches in the AUTO or ON positions,
causing the L or R WNG TK OV PRESS annunciator to illumi-
nate. The momentary RESET position may be used to reacti-
vate the system.
Refueling
A filler port is provided on each wing upper surface and is cov-
ered by a cap assembly. The wing filler adapter assembly is
provided with a flapper check valve to avoid fuel discharge in
the event of cap seal failure. The aft filler tank filler port is
located on the aft fuselage surface above the right engine
pylon. This port is covered by a cap assembly and an access
panel. The access panel is provided with a ground point for
refueling and a provision that does not allow the panel to close
if the aft filler tank filler cap is not completely secured.
Tank Vent
The vent system provides continuous ram air pressure to all
tanks and the vent surge tank during flight. This allows the tank
differential air pressure to remain within limits during maximum
rate climbs or descents. Each fuel tank is vented separately
through independent vent systems. The ram air scoop for each
wing tank is located on the underside of the outboard wing
area. The aft fuselage and filler tanks are vented to the vent
surge tank that is, in turn, vented to the vent ports at the bottom
of the fuselage.
LEVEL
LOW SWITCH
CASE DRAIN RH
VDP
LH <750
VDP FILTER PSI
WITH BYPASS
PCB
<750 GROUND
15 SEC 15 SEC CONNECTOR
PSI
DRAIN VALVE
10 PRESSURE
5
PSI X 100
15 TRANSDUCER
20
HYD
PRESS
HYD
PRESS
REL REL
NORM
NORM
BRAKES AND
THRUST REVERSERS
5A 5A 5A 2A SAFETY
FLAP SELECTOR DUMP CHECK VALVE
LH LOAD EMERGENCY RH LOAD VALVE VALVE VALVE
SAFETY
LEGEND VALVE
PRESSURE
RETURN LANDING GEAR DOOR SELECTOR SPEED BRAKE
SELECTOR VALVE VALVE CONTROL VALVE
STATIC
BLEED AIR
ELECTRICAL
FLAP CONTROL LANDING GEAR SPEED BRAKES
Hydraulic System
The airplane is equipped with a closed-center hydraulic power
system which has two engine-driven pumps, a hydraulic pack-
age, ground connectors and associated electrical components.
It operates at 1,500 PSI and is monitored by a pressure gage
and caution lights. The system supplies hydraulic power to the
flaps, speedbrakes, power brakes/anti-skid, thrust reversers
and the landing gear.
Hydraulic Pumps
A variable displacement, rotary-plunger-type hydraulic pump is
installed on, and driven by, each engine accessory gearbox.
The displacement varies from zero at an output pressure of
1,500 PSI to 3.9 GPM at about 1,400 PSI. This pump not only
varies the volume of fluid pumped, but also regulates the sys-
tem pressure. There is no need for a pressure regulator.
Hydraulic Package
The hydraulic package consists of a reservoir, air filter, vacuum
and air pressure relief valves, check valves, fluid filters, shutoff
valves, a hydraulic relief valve, a bypass valve, low-pressure
switches, a high-pressure switch, a pressure transducer, and
lines. The reservoir provides hydraulic fluid for system opera-
tion. Its capacity is approximately 1.1 US gallons of MIL-H-5606
hydraulic fluid. The reservoir is pressurized by filtered engine
bleed air that is regulated to 15 PSI. Air pressure in the reser-
voir is controlled by an air supply check valve, a vacuum relief
valve and a pressure relief valve. The reservoir is equipped
with a sight gage (window) that is used to check proper fluid
level. A float-type switch installed inside the reservoir warns the
flight crew when the reservoir fluid quantity reaches 0.6 US gal-
lons or less. Activation of this switch will illuminate the HYD
LEVEL LO annunciator.
Shutoff valves are mounted at the fluid supply ports of the res-
ervoir to stop fluid flow to the engine-driven pumps. These
valves are normally open and are closed in case of an engine
fire or overheat condition. During an engine fire procedure,
depressing the LH or RH ENG FIRE PUSH button electrically
closes the fuel and hydraulic shutoff valves.
Three filters extract foreign particles from the fluid to prevent
damage to moving parts in the system. One filter assembly is
installed in each pressure passage from the pumps and one is
in the fluid return passage to the reservoir. Should a filter ele-
ment become clogged, a bypass valve will allow fluid to bypass
the element for continued system operation. After passing
through the filters, fluid passes through a check valve that pre-
vents reverse flow of pressure in case of engine shutdown.
The system relief valve relieves abnormally high pressure to
the return side when system pressure rises excessively. The
system can be depressurized through the bypass valve that is
electrically energized by the HYD PRESS REL switch to pre-
vent excessive fluid temperature rise caused by the sustained
flow through the system relief valve. The switch should be set
in the NORMAL position. When moved to the HYD PRESS
REL position, the bypass valve is opened to bypass the
hydraulic fluid to the reservoir.
The low-pressure switches sense a low-pressure condition in
the pump outlet lines. If one or both pumps fail (pressure below
750 ±100 PSI for 15 seconds or more), the LH or RH PMP
PRESS LO annunciator illuminates. The same indication is pro-
vided for excessive leakage due to any hydraulic component
failure. The hydraulic pressure indicator can monitor the sys-
tem pressure. After fluid passes through all the indicating and
controlling devices, it is ported through the hydraulic valve to
the systems utilizing hydraulic pressure for actuation. Systems
utilizing hydraulic pressure for activation are the landing gear,
flaps, speedbrakes, power brakes/anti-skid and thrust
reversers.
BL AIR
DCT FAIL
ICE
DEFOG DETECTOR
AIR OV HT
L ENG ICE
TEMP LO
AIR COND ICING
FAIL
RH SHROUD
INDICATOR
PANEL
OAT OAT
SENSOR BIAS R ENG ICE
TEMP LO
FLAP ACM ICE DET
CONTROL FAIL
L R
ENG. 30 PSI 30 PSI ENG.
LDG FLAP DELAY PRSOV
PRSOV
RH SHROUD
FLAPS
INDICATOR
PANEL
DE-ICE
CONTROLLER
ANTI/DEICE
B4CRH-IR001I
BLEED AIR
STATOR VALVE
AIR INLET
ASSEMBLY
BLEED AIR
INLET VALVE
LEGEND
EJECTOR
BLEED AIR SUPPLY
B4CRH-IR002I
4H-2 Developed for Training Purposes Beechjet 400A
September 2001
Ice and Rain Protection
Deice Operation
Deicing of the horizontal stabilizer leading edges and elevator
horns is accomplished by a cyclic supply of 28V DC power to
the heater elements. When the H STAB DEICE switch on the
overhead switch panel is turned ON, a white light adjacent to
the switch illuminates and 28V DC power is directed from the H
STAB CONT circuit breaker (ICE RAIN) to a controller located
in the aft fuselage. The controller will not supply power to the
heater elements if the RAT is greater than approximately 21°C,
or if the aircraft is on the ground. With the system turned ON
and the RAT below approximately 21°C, the controller pro-
cesses RAT, airspeed and flap position from the temperature
sensor, Q-switches and flap lever respectively and follows a
predetermined cyclic sequence of powering the heating
elements.
Ice Detector
The ice detector, mounted on the upper left side of the nose,
senses ice accretion and causes the ICING annunciator in the
copilot's shroud panel to illuminate. The illumination of the
annunciator is the ice detector's only function. If the ice detec-
tor fails, an ICE DETECT FAIL caution annunciator illuminates
and the glareshield-mounted MASTER CAUTION RESET
switches will flash.
Engine Anti-Ice
Each engine has two anti-ice systems installed to prevent the
buildup of ice in the engine intake. One system circulates high
pressure compressor bleed air in a jacket around the nacelle
air inlet duct leading edge and the other system extracts high
pressure compressor bleed air and routes it into the engine low
pressure compressor inner stators. Additional high-pressure
compressor air is tapped off and supplies a small amount of air
for anti-ice protection for the T1 temperature probe and the inlet
cone. The nacelle inlet anti-ice control valve is located on the
lower part of the engine inlet case and the inner stator anti-ice
control valve is located at the 10 o'clock position on the engine
intermediate case.
The L or R ENGINE ANTI-ICE switches located on the over-
head switch panel, control the engine anti-ice systems. When
the ENGINE ANTI-ICE switch is ON, the pressure regulator
shutoff valve opens to regulate the bleed air pressure for the
engine anti-ice system at 16 PSI. At the same time, the L or R
ENGINE ANTI-ICE operation light will illuminate. When the
engine inlet bleed air temperature is below 120°F the L or R
ENG ICE TEMP LO annunciator will illuminate.
Heated Windshield
Heating the windshield not only prevents the formation of ice,
but also aids its bird strike resistance. For this reason, wind-
shield low heat should always be used during flight. Electrical
power is applied to the windshield by the L or R WINDSHIELD
ANTI-ICE switch through the respective temperature controller
which uses a sensing element to monitor the heating element
temperature. The control unit incorporates overheat warning
circuitry which supplies a signal to the L or R WSHLD OVHT
light annunciator. The windshield heat system has two separate
modes of operation: high and low. Electrical power is supplied
to the heating elements through the windshield anti-ice (high
power relays or windshield anti-ice low power relays. The tem-
perature controller automatically regulates the heating cycle to
maintain the temperature between 95°F and 104°F (35°C and
40°C) by utilizing the sensing element embedded in the
windshield.
The high and low relays and temperature controller are located
in the left junction box. When the windshield anti-ice system is
placed in operation by placing the WINDSHIELD ANTI-ICE
switch in the HIGH or LOW position, the operation light incorpo-
rated near the switch will illuminate and remain on until the con-
troller cycles or the switch is turned OFF. Should a malfunction
occur in the system, such as an open sensor or windshield
overheat condition, the L or R WSHLD OVHT annunciator will
illuminate.
EMERGENCY GEAR
VALVE PACKAGE DOWN HANDLE
LEGEND
VENT LINE
EMERGENCY
PRESSURE LINE DOOR CLOSE
DUMP CHECK
RETURN LINE VALVE VALVE
NITROGEN
SHUTTLE
VALVE
SHUTTLE
VALVE
DOOR SELECTOR LEFT & RIGHT
VALVE
DOOR OPEN
SWITCH
UPLOCK
RELEASE NOSE LEFT & RIGHT GEAR GEAR
CYLINDER UPLOCK UPLOCK
GEAR UP- GEAR UP- RELEASE RELEASE
LOCK SWITCH LOCK SWITCH CYLINDER CYLINDER
OFF R ENG
DN BEECHJET
B4CRH-LG001I
CONTROL SWITCH
UNIT
SILENCE FLAP FOLLOW-UP
(AIRPLANES RK-98 SWITCH UNIT
CABIN DUMP
AND RK-110 AND AFTER) LANDING GEAR
GEAR SELECTOR AURAL WARNING
VALVE
Normal Retraction
LEGEND
VENT LINE
EMERGENCY GEAR PRESSURE LINE
VALVE PACKAGE DOWN HANDLE
RETURN LINE EMERGENCY
DOOR CLOSE
NITROGEN
GEAR DROP TO
EXTEND POSITION NITROGEN
LANDING BOTTLE
GEAR DOOR
SELECTOR SELECTOR
VALVE DOOR CLOSE SWITCH
VALVE
DOOR OPEN SWITCH EMERGENCY
CONTROL VENT
SHUTTLE VALVE
VALVE
SHUTTLE
VALVE
UPLOCK
RELEASE GEAR GEAR
CYLINDER UPLOCK UPLOCK
RELEASE RELEASE
CYLINDER CYLINDER
LEFT GEAR DOOR LEFT DOOR RIGHT DOOR DOOR RIGHT GEAR
DOWNLOCK CLOSELOCK ACTUATING ACTUATING CLOSELOCK
RELEASE DOWNLOCK DOWNLOCK
RELEASE RELEASE CYLINDER CYLINDER RELEASE RELEASE
CYLINDER CYLINDER CYLINDER
CYLINDER CYLINDER
B4CRH-LG002I
NOSE LANDING GEAR MAIN LANDING GEAR
LH RH
Normal Extension
LEGEND
VENT LINE
EMERGENCY GEAR PRESSURE LINE
VALVE PACKAGE DOWN HANDLE
RETURN LINE EMERGENCY
DOOR CLOSE
NITROGEN
DUMP CHECK
VALVE VALVE ELECTRICAL CIRCUIT
CABLE LINE
GEAR DROP TO
EXTEND POSITION NITROGEN
LANDING BOTTLE
GEAR DOOR
SELECTOR SELECTOR
VALVE DOOR CLOSE SWITCH
VALVE
DOOR OPEN SWITCH EMERGENCY
CONTROL VENT
VALVE
SHUTTLE
VALVE
SHUTTLE
VALVE
UPLOCK
RELEASE GEAR GEAR
CYLINDER UPLOCK UPLOCK
RELEASE RELEASE
CYLINDER CYLINDER
LEFT GEAR DOOR LEFT DOOR RIGHT DOOR DOOR RIGHT GEAR
DOWNLOCK CLOSELOCK ACTUATING ACTUATING CLOSELOCK
RELEASE DOWNLOCK DOWNLOCK
RELEASE RELEASE CYLINDER CYLINDER RELEASE RELEASE
CYLINDER CYLINDER CYLINDER
CYLINDER CYLINDER
B4CRH-LG003I
NOSE LANDING GEAR MAIN LANDING GEAR
LH RH
Emergency Extension
LEGEND
EMERGENCY GEAR
VALVE PACKAGE DOWN HANDLE RETURN LINE
NITROGEN EMERGENCY
DOOR CLOSE
ELECTRICAL CIRCUIT
DUMP CABLE LINE
VALVE
GEAR DROP TO
EXTEND POSITION NITROGEN
LANDING BOTTLE
GEAR DOOR
SELECTOR SELECTOR
VALVE DOOR CLOSE SWITCH
VALVE
DOOR OPEN SWITCH EMERGENCY
CONTROL VENT
VALVE
SHUTTLE
VALVE
SHUTTLE
VALVE
UPLOCK
RELEASE GEAR GEAR
CYLINDER UPLOCK UPLOCK
RELEASE RELEASE
CYLINDER CYLINDER
LEFT GEAR DOOR LEFT DOOR RIGHT DOOR DOOR RIGHT GEAR
DOWNLOCK CLOSELOCK ACTUATING ACTUATING CLOSELOCK
RELEASE DOWNLOCK DOWNLOCK
RELEASE RELEASE CYLINDER CYLINDER RELEASE RELEASE
CYLINDER
B4CRH-LG004I
CYLINDER CYLINDER CYLINDER CYLINDER
Brake System
BRAKE FLUID
RESERVOIR
COPILOT'S
PILOT'S PILOT'S COPILOT'S
RUDDER
RUDDER MASTER MASTER
PEDALS
PEDALS CYLINDERS CYLINDERS
1 2 3 4
ACCUMULATOR NITROGEN
BOTTLE
HYDRAULIC 1500 / 1650 PSI
PACKAGE 900 PSI EMERGENCY BRAKE
± 50 CONTROL VALVE
MIXING VALVES POWER BRAKE
VALVE
1500
PSI VENT
CONTROL
VALVE
PARKING BRAKE
HANDLE
EMERGENCY
PARKING VALVES BRAKE
LEVER
LH MLG RH MLG
BRAKE BRAKE
ASSEMBLY ASSEMBLY
LEGEND
RETURN
B4CRH-LG005I
CONTROLED PRESSURE
TEST
BRAKING PRESSURE
ANTI SKID SWITCH
EMERGENCY EMERGENCY
DOOR LEFT/RIGHT
CHECK CLOSE
THRUST DOWN
VALVE
LEVER
DUMP
VALVE
GEAR DOOR VENT
SELECTOR SELECTOR
VALVE VALVE
SHUTTLE
VALVE PACKAGE VALVE
DOWN
LOCK NOSE LH GEAR GEAR UPLOCK GEAR UPLOCK RH GEAR
GEAR ACTUATOR RELEASE RELEASE ACTUATOR
UP
ACTUATOR
LOCK LH RH
DOOR DOOR
ACTU- ACTU-
ATOR ATOR
LEGEND
VENT LINE
PRESSURE LINE
RETURN LINE
NITROGEN
B4TM-LG001i
Emergency Extension
The EMER L/G DOWN handle and the EMER DOOR CLOSE
handle are installed under the pilot's instrument panel. Pulling
the EMER L/G DOWN handle all the way out (approximately 10
inches), releases the fuselage MLG door uplocks, MLG
uplocks, and NLG uplock. The gear doors open and the landing
gear free falls to the down-and-locked position, assisted by
extension springs on each landing gear downlock. At the initial
opening motion of the doors, the red warning light will illumi-
nate. As the landing gear extends to the down-and-locked posi-
tion, their respective green indicator lights will illuminate. After
the three green indicator lights illuminate, the EMER L/G
DOWN handle is pushed to the stowed position and the EMER
DOOR CLOSE handle is operated to close the fuselage MLG
doors by nitrogen pressure. After the doors are closed, the red
warning light will extinguish. The nitrogen pressure is supplied
from a nitrogen bottle mounted in the left nose electronic
compartment.
Antiskid System
The airplane is equipped with an electrically controlled antiskid
system. The system detects the start of a skid condition at the
wheels and automatically releases the brake pressure for both
wheels in proportion to the severity of the skid. Use of the anti-
skid system offers protection from skids and can provide con-
sistently shorter landing rolls for all runway conditions. Placing
the ANTI SKID switch in the ON position activates the system.
A stationary wheel speed transducer, mounted inside each
main gear axle, electrically senses any change in wheel rota-
tion speed. As a skid is detected, an electrical signal is supplied
to the system, which releases hydraulic pressure from the
brakes. With brake pressure released, the wheel speed will
increase and hydraulic pressure will be restored to the brakes.
The antiskid system continues this control cycling as long as
Parking Brake
The parking brake is a part of the normal brake system and
employs check valves that prevent the return of fluid after the
brake pedals have been released. Parking brakes are set by
pulling out the PARKING BRAKE HANDLE, located under the
lower left side of the instrument panel, and depressing the toe
brakes two or three times. Do not set the parking brake with the
copilot's pedals if the engines are not running. Without power
boost (i.e. engines not running) the copilot's pedals require sev-
eral pumps to set brakes. This may cause the first or second
subsequent application of brakes from the pilot's pedals to be
ineffective. The parking brake is released by pushing in the
handle.
The parking brake should not be set if the brakes are very hot.
This increases brake cool-down time due to decreased airflow.
This may result in sufficient heat transfer from the brakes to
cause the parking brake hydraulic pressure to rise excessively,
or to melt the thermal relief plugs in the wheel.
Emergency Brake
In the event of normal hydraulic brake system failure, the pilot
or copilot can continue braking operation by using the spring-
loaded emergency brake lever mounted on the upper right side
of the pedestal. The nitrogen bottle, mounted in the lower por-
tion of the left electronics bay in the nose, contains sufficient
pressure for 7 to 10 full brake applications when fully charged.
For the most efficient use of the system, use steady and
smooth application, gradually increasing force until desired
braking action is attained. Maintain that pressure until the air-
plane is stopped. When the lever is released, residual nitrogen
pressure from the brakes is vented overboard. Normal braking
should not be applied while using the emergency brakes.
OVERBOARD
XY
GEN VE DISCHARGE
INDICATOR
NT
OXYGEN
O
CYLINDER
RE
HI G
H
PRESS
U
FWD
PRESSURE FILLER
BULKHEAD VALVE
OXYGEN
PRESSURE
GAGE
1000
500 1500
0 2000
PSI
OXYGEN
BAROMETRIC
SUPPLY PRESSURE
MADE IN USA
20
PRESSURE PASS
OXYGEN
SYS
READY SYS READY
SWITCH PULL-ON
PUSH/PULL
ON/OFF
PUSH/PULL
ON/OFF
CONTROL KNOB
PASS OXYGEN
PULL-ON
CONTROL KNOB
CREW OXYGEN
RECEPTACLE
OXYGEN MASK
MIC RECEPTACLE
SHROUD
INDICATOR OXYGEN MASK
PANEL AND CONTAINER
(CONTINUOUS
PASS OXY ON FLOW)
LEGEND
PASS OXYGEN ON
CYLINDER PRESSURE SWITCH
SUPPLY LINE
PRESSURE CABIN AREA
CREW CONTROL -
INDICATOR
B4CRH-OXY001I
PASSENGER OXYGEN
SUPPLY
ELECTRICAL CIRCUIT
MECHANICAL CONNECTION
Oxygen System
The system consists of an oxygen-cylinder-regulator assembly
mounted in the right electronics bay compartment. The 77-
cubic-foot cylinder is of composite construction and stores oxy-
gen at a maximum pressure of 2,000 PSI. Normal oxygen pres-
sure is 1,850 PSI. The oxygen duration chart (Table 4I-B) is
based on a flow rate of 3.7 LPM per passenger mask and on an
altitude schedule for the diluter demand crew masks. The sup-
ply pressure regulator, installed on the cylinder, is capable of
delivering up to 300 Liters Per Minute-Normal Temperature and
Pressure Dry (LPM-NTPD) regulated oxygen at 70 ±10 PSI
with cylinder pressure from 200 to 2,000 PSI (see Table 4I-A
for the Average Time of Useful Consciousness). The regulator
incorporates an ON-OFF valve which vents low side pressure
when in the OFF position. It is actuated by a push-pull SYS
READY control located adjacent to the lower right corner of the
copilot's instrument panel. A high-pressure rupture fitting
relieves high side cylinder pressure and dumps oxygen over-
board should it exceed 2,775 PSI. When this occurs, the vent
line receives pressure in excess of 60 PSI and ruptures a green
indicator disk located on the right side nose skin, indicating that
an overpressure condition has occurred and oxygen was
routed overboard.
Cabin Altitude Average Time of Useful Consciousness
45,000 feet 9 to 15 seconds
40,000 feet 15 to 20 seconds
35,000 feet ½ to 1 minute
30,000 feet 1 to 2 minutes
28,000 feet 2½ to 3 minutes
25,000 feet 3 to 5 minutes
22,000 feet 5 to 10 minutes
12,000 – 18,000 feet 30 minutes or more
Table 4I-A; Average Time of Useful Consciousness
Crew
373 373 292 188 214 292 359
(2)
Pass
207 209 182 136 150 186 211
1
System Operation
The oxygen system should be armed prior to takeoff by pulling
out the SYS READY control. This opens the oxygen regulator
at the cylinder, charges the lines to the crew masks and pro-
vides oxygen immediately to the crew upon donning the masks.
The cabin oxygen shutoff valve controls oxygen supply to the
passenger masks. Normally closed, it may be opened either
electrically or manually. Electrically, the cabin barometric switch
opens the shutoff valve when the cabin altitude exceeds
12,500 ±500 feet. Manually, it is opened from the cockpit at any
cabin altitude by pulling out on the PASS OXYGEN control
knob located adjacent to the lower right corner of the copilot's
instrument panel.
Access to the filler valve is gained by opening the right elec-
tronics bay compartment door. When the oxygen supply line is
connected to the filler valve and supplying oxygen, the poppet
is unseated to allow oxygen to flow to the storage cylinder.
Loss of oxygen is prevented when the supply line is removed
due to the reseating of the poppet.
The oxygen pressure gage is located adjacent to the lower right
corner of the copilot's instrument panel. The gage is illuminated
and is a direct-pressure reading instrument. The range mark-
ings are yellow arc (0 to 200 PSI), green arc (1,600 to 1,850
PSI) and red line (2,000 PSI).
Two identical outlet receptacles are provided for the crew oxy-
gen system. When the oxygen mask supply tube plug is
inserted into the outlet, the poppet unseats, allowing oxygen
flow to the mask. When the plug is removed, the poppet
reseats and shuts off the oxygen flow.
B4CRH-PP001i
Beechjet 400A Developed for Training Purposes 4K-1
September 2001
CAE SimuFlite
FILLER NECK
STRAINERS
LEGEND
OIL JET STRAINER
PRESSURE OIL NO. 1 BEARING
NO. 4 BEARING
BYPASS OIL
SCAVENGE OIL
SCREEN
TRAINER NO. 3 BEARING
NO.3 1/2
BEARING
CHECK VALVE
TYPICAL STRAINER
PRESSURE BYBASS
OIL TANK
PRESSURE
REGULATOR
VALVE
OIL FILT
BYPASS GEARBOX SCAVENGE
SW
ACCESSORY GEARBOX
OIL PUMP STRAINER ELEMENT
ASSEMBLY TYPICAL RETURN TO TANK
BJ4CRH-PP002I
OIL PRESS SW 10
FILTER 5
5 R OIL
0
OIL TEMP TRANSMITTER -5 0 PRESS LO
T P R FUEL
PRESS LO
TO BEARING NO.4 & NO.3 1/2
Fuel System
ENGINE ELECTRICAL
CONTROL
PRIMARY
IGNITER
SECONDARY
EXCITER
PRIMARY LINE
AUTO SECONDARY LINE
STARTER GENERATOR SHUTOFF
VALVE
LEGEND
OIL COOLER P3 FUEL FLOW
INDICATORS FUEL
OIL IN FLOW (LBS/HOUR)
DIVIDER SIGNAL FROM THE RETURN
CONDITIONER OTHER ENGINE
OIL OUT
HI PRESSURE FUEL
CONSUMED SECONDARY FUEL
FUEL
P3 AIR
FUEL FLOW
TRANSMITTER
LF/V
OPEN
LF/V
CLOSE
FILTER VENT
DRAIN
MIN PRESS
VALVE
BOOST PUMP
HP
RELIEF
HP PUMP
MOTIVE
FLOW
B4CRH-PP003i
L WG TK
OV PRESS
L OIL
PRESS LO
LH ENG
HMU FIRE
L F FLTR L FUEL
BYPASS PRESS LO PUSH
Ignition System
NOTES:
1 AIRPLANES NOT MODIFIED
BY KIT 128-3055-3
2 AIRPLANES MODIFIED
BY KIT 128-3055-3
IGNITER PLUGS
IGNITION
EXCITER
IGNITION
LIGHT
LEGEND
STANDBY CIRCUIT
THRUST LEVER 2 START CIRCUIT
SWITCH
28 V DC PATH
IGNITION HIGH VOLTAGE
CONTROL PATH
START
CONTROL
STALL
ANTI-ICE WARN
IGNITION IGNITION
IGNITION ON
SWITCH
OFF
STBY
B4CRH-PP004i
Engine Synchronization
14 0 14 0
12 2 12 2
10 4 10 4
8 6 8 6
RIGHT
ENGINE EXCITER
ENG SYNC ON
X1 X1
OFF
11 0 11 0
10 TURB 10 TURB FAN TURBINE
9 % RPM 2 9 % RPM 2
8 X 10 3 8 X 10 3 GEAR OIL FUEL FLOW
7 6 5 4 7 6 5 4 BOX FUEL COOLER DIVIDER VALVE
ENG
SYNC PUMP
SWITCH FROM
FUEL FLOW STARTING
TRANSMITTER SYSTEM
HYDROMECHANICAL
METERING UNIT
X1 X1
11 0 11 0
10 FAN 1 10 FAN 1
9 % RPM 2 9 % RPM 2
8 X 10 3 8 X 10 3
7 6 5 4 7 6 5 4
LEFT
ENGINE
LEGEND
ELECTRICAL LINE
MECHANICAL LINE
RIGHT LEFT
THRUST THRUST
LEVER LEVER
B4CRH-PP005i
Engine Start
TO BATTERY TO LEFT
SWITCH ENGINE START ENGINE START
DISENGAGE SELECT
BUTTON SWITCH TO IGNITION
SWITCH
EMERGENCY BUS
RIGHT LOAD BUS
BATTERY ENGINE
STANDBY ANTI-ICE
START
BUTTON IGNITION
2 AIRPLANES MODIFIED
BY KIT 128-3055-3. LEGEND
FUEL
TO THRUST RETURN
LEVER
HI PRESSURE FUEL
B4CRH-PP006I
HYDROMECHANICAL FUEL PUMP
METERING UNIT
FUEL MOTIVE LINE
JET PUMP
Thrust Reverser
LEGEND
L TR ARM R TR ARM PRESSURE LINE
LEFT L TR PUSH R TR PUSH RIGHT UNLOCK UNLOCK
EMERGENCY EMERGENCY RETURN LINE
STOW EMER STOW EMER STOW STOW DEPLOY DEPLOY
SWITCH SWITCH MECHANICALLY LINKED LINE
ELECTRICAL CIRCUIT
LEFT RIGHT
REVERSER REVERSER
LEVER LEFT RIGHT LEVER
CONTROL CONTROL
VALVE VALVE
TO HYDRAULIC
LEFT PACKAGE
STOW
THRUST
INTERLOCK RIGHT
SOLENOID THRUST
INTERLOCK
SOLENOID
LEFT RIGHT
ENGINE ENGINE
STOW STOW STOW STOW
PORT PORT PORT PORT
LEFT RIGHT
DEPLOY ISOLATION ISOLATION DEPLOY
VALVE VALVE
DEPLOY
DEPLOY DEPLOY PORT DEPLOY
PORT PORT PORT
LEFT RIGHT
GROUND GROUND
SAFETY SAFETY
SWITCH SWITCH
LEFT THRUST
B4CRH-PP007i
REVERSER RIGHT THRUST
STOW LIMIT REVERSER
SWITCH STOW LIMIT
SWITCH
Engines
The Beechjet 400A is powered by two aft pod-mounted
JT15D-5 turbofan engines manufactured by Pratt & Whitney
Aircraft of Canada, Limited. The engines are lightweight, twin
spool, front turbofan jets having a full-length annular bypass
duct.
The low compressor consists of a low compressor fan followed
by a primary gas path booster stage. A concentric shaft system
supports the high and low rotors. The inner shaft supports the
low compressor fan and booster stage and is driven by a two-
stage turbine supported at the rear. The speed of this assembly
is designated as N1 RPM. The outer shaft supports the high-
pressure centrifugal compressor impeller and is driven by a sin-
gle-stage high-pressure turbine. This speed is designated as
N2 RPM.
The JT15D-5 will produce 2,965 pounds of static thrust on a
standard day at sea level and a maximum continuous thrust of
2,900 pounds. All intake air passes through the low compressor
fan. Immediately aft of the fan, the airflow is divided by concen-
tric ducts. Most of the total airflow is bypassed around the
engine through the outer annular bypass duct and is exhausted
at the rear. Air entering the inner duct passes through a booster
stage and is compressed by the impeller. The high-pressure air
then passes through a diffuser assembly and moves back to
the combustion section. The combustion chamber is a reverse
flow design to save space and reduce engine size. Most of the
air entering the chamber is mixed with fuel and ignited while the
remainder streams down the chamber liner for cooling. Fuel is
introduced by twelve dual orifice nozzles supplied by a dual
manifold. Spark igniters that extend into the combustion cham-
ber at the 5 and 7 o'clock positions initially ignite the mixture
and after start, the combustion becomes self-sustaining. The
hot gases expand in the reverse direction and pass through a
set of turbine guide vanes to the high-pressure turbine. As the
expanding gases move rearward, they pass through another
Engine Indicators
The engine monitoring system consists of the fan RPM (N1)
inter-turbine temperature (ITT), turbine RPM (N2), fuel flow, oil
pressure and temperature, fuel consumed totalizer, and engine
vibration indicators.
The fan RPM (N1) indicator displays engine fan speed RPM in
percentage. A fan speed of 15,900 RPM equals 100% RPM. The
indicator receives a signal from its respective N1 speed sensor.
The turbine RPM (N2) indicating system operates on the same
principle as the fan RPM indicator. A turbine speed of 32,760
RPM equals 100% RPM. Turbine RPM red line is 96%.
The scale range on the ITT indicator is from 0 to 10 with read-
ings multiplied by 100 in degrees centigrade (100°C). The ITT
(T5) receives voltage from thermocouples that measure fan
inlet air temperature (T1) and turbine exhaust temperature (T6).
The engine vibration monitoring system consists of two piezo-
electric accelerometers, a signal conditioner and an indicator.
The accelerometers, mounted on the top of each engine, convert
the vibratory acceleration into an electric charge. The signal con-
ditioner, mounted on the baggage compartment wall, receives
the electric charge from the accelerometers. A single indicator
with dual pointers is mounted on the instrument panel. The scale
range on the indicator is from 0 to 10 and corresponds to engine
vibration velocity. The engine vibration indicator is used as a
trend instrument. A significant change in the engine vibration
level over a period of time may indicate a problem.
Separate oil and pressure indicators for each engine are located
on the instrument panel. Their functions are described under the
Oil System section.
Two engine fuel flow indicators are located on the main instru-
ment panel. Their functions are described under the Fuel Control
System section.
Oil System
The system supplies cooled, pressurized oil for lubrication and
cooling of engine bearings and accessory drive gears and bear-
ings. An integral oil tank on each engine has a capacity of 2.03
U.S. gallons of which 1.34 US gallons are drainable. Recom-
mended oils are listed in Pratt & Whitney Service Bulletin 7001.
Oil drawn from the oil tank by the pressure oil pump is ducted
through a check valve to the pressure relief valve for oil pressure
regulation. The oil is also passed through the oil cooler and oil fil-
ter. Excess oil pressure at the oil filter outlet opens the pressure-
regulating valve and some of the oil is bypassed and ducted
externally through a second check valve to the oil pressure
pump inlet. From the filter, oil is routed to the engine bearings
and accessory gearbox. If the filter becomes clogged, a bypass
valve opens allowing lubrication to continue and the L or R O
FLTR BYPASS annunciator will illuminate. Circulated oil from the
No. 4 bearing area and accessory gearbox is returned to the
tank by two scavenge pump elements in the oil pump assembly.
Oil pressure is sensed by a transmitter and is displayed on two
AC powered indicators with dual pointers (pressure and temper-
ature) on the instrument panel. The scale ranges on the dual
indicators are 0 to 150 PSI for oil pressure and -50 to 150°C for
oil temperature. The minimum oil pressure at idle RPM is 40
PSI. The L or R OIL PRESS LO annunciator will illuminate when
the system pressure decreases below 40 PSI. The acceptable
operating pressure range is 40 to 60 PSI when the power is
below 60% N2. The normal operating range is 60 to 83 PSI
when the power is over 60% N2. Oil pressure below 60 PSI is
undesirable and should be tolerated only for the completion of
the flight, preferably at reduced power settings. In cold starting
conditions, oil pressure may exceed 83 PSI, but may not
exceed 150 PSI. Oil temperature is sensed by a resistance bulb
and transmitted to the dual DC powered indicators. Minimum oil
temperature for engine start is -40°C and normal operating
range is 10 to 121°C.
The engine fuel flow indicating systems for both engines con-
sist of transmitters, DC-powered fuel flow indicators, a fuel flow
signal conditioner, and a fuel consumed totalizer indicator. The
fuel flow transmitter is on the outlet side of the HMU and mea-
sures the frequency signals proportional to the fuel flow rate
that passes through it. The flow rate is converted into an electri-
cal current by the signal conditioner and is sent to the fuel flow
indicator. The fuel flow indicators on the instrument panel dis-
play engine fuel consumption in pounds per hour. The scale
range of the indicator is 0 to 2,000 pounds per hour. The fuel-
consumed totalizer receives the current from the signal condi-
tioner and provides a digital display of the fuel consumed.
Engine Control
Power Controls
During normal operation, the engine power may be adjusted to
any setting between idle and Takeoff Rated Thrust (TRT). TRT
can be used for a maximum of 5 minutes. The ITT should not
exceed 700°C; the N1 should not exceed 104%; N2 should not
exceed 96%; and oil temperature and pressure should be in the
normal operating range of 10 to 121°C and 60 to 83 PSI,
respectively. Maximum continuous thrust has no time limit, but
the ITT is limited to 680°C. Oil temperature should be within 10
to 121°C. All other limits are the same as TRT. The minimum
idle speed with engine EFC ON is 52% N2; with engine EFC
OFF, it is 46% N2. In either case the CABIN PRESS switch is in
the BOTH position with the generator load below 50 amps. The
ITT should not exceed 580°C. During any acceleration, the ITT
should not exceed 700°C.
The thrust levers control engine thrust. Angular displacement of
the thrust lever is transformed into stroke displacement of the
cable connected to the engine fuel control. The thrust lever has
four detent positions: CUT OFF, IDLE, NORM TAKE OFF
(NORM T.O.) and TAKE OFF (T.O.). To move the thrust lever
from CUT OFF to IDLE or from IDLE back into CUT OFF, it is
necessary to pull up and move the levers over the detent on
airplanes without thrust reversers; or to pull up the detent
release lever and move the thrust levers over the detents on
airplanes with thrust reversers.
A friction lever is mounted on the left side of the pedestal adja-
cent to the thrust levers. The thrust levers may be fixed in any
position by moving the friction lever forward.
Engine Synchronizer
Engine Starting
Engine starts may be made using the airplane battery, external
power, generator assist, or by air starting. The starter-generator
operates as a starter until engine speed (N2) reaches approxi-
mately 35 to 40% RPM. At this time, the starter ceases to turn
the engine and the solenoid held ENG START button is auto-
matically released. As engine RPM increases, the starter-gen-
erator begins to function as a generator. The generator output
is automatically connected to the DC bus system when the
ENG START SELECT switch, located on the pedestal, is
placed to the OFF position.
Battery Start
RK-118, RK-140 Thru RK-220 Not Modified by
Kit 128-3055-3
During a battery start, the BATTERY switch must be ON with
the battery supplying a minimum of 22 volts. Turn the ENG
EFC switch ON and select the engine (left or right) to be started
with the ENG START SELECT switch. Momentarily press the
respective ENG START button, then release. Verify illumination
of the ENG START button and the BOOST PUMP light and
monitor N2 RPM. At 8% N2 RPM, move the thrust lever to IDLE
and check that the IGNITION operation light illuminates. Moni-
tor N1, N2, ITT, and oil pressure during start.
RK-221 and After or RK-118, RK-140 Thru RK-220 Modified
by Kit 128-3055-3
The battery start for airplanes RK-221 and After or RK-118,
RK-140 Thru RK-220 Modified By Kit 128-3055-3 is identical to
airplanes RK-118, RK-140 Thru RK-220 Not Modified By Kit
128-3055-3. The only difference is the illumination of the IGNI-
TION operation light when the ENG START button is pressed.
External Power Start
An external power start may be accomplished by plugging in an
external power source capable of supplying 28V DC, 1,000-
1,500 amperes output. If both engines are to be started with
external power, the GEN RESET switches must be OFF during
start.
Air Start
Should a system failure actuate the deploy cycle with the thrust
levers set above the IDLE position, a thrust reverser feedback
subsystem will force the thrust linkage to the IDLE position. In
such a failure condition, the reverser lever is restrained in the
IDLE position by the thrust interlock.
To initiate the stow cycle, the reverser levers are pushed back
to their stow positions. This reverses the mechanism actuation,
returning the reverser doors to their stowed and locked posi-
tion. The DEPLOY, UNLOCK, and TR ARM annunciators will
sequentially extinguish during the stow cycle.
Takeoff Profile
(One Engine Inoperative) . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Landing Weight Determination. . . . . . . . . . . . . . . . . . . . . . . 5-8
Airport Ident.
FBO Freq. Tel: ( )
Fax: ( )
Hotel Tel: ( )
Fax: ( )
Catering Tel: ( )
FSS Tel: ( )
Airport Ident.
FBO Freq. Tel: ( )
Fax: ( )
Hotel Tel: ( )
Fax: ( )
Catering Tel: ( )
FSS Tel: ( )
Notes
Airport Ident.
FBO Freq. Tel: ( )
Fax: ( )
Hotel Tel: ( )
Fax: ( )
Catering Tel: ( )
FSS Tel: ( )
Airport Ident.
FBO Freq. Tel: ( )
Fax: ( )
Hotel Tel: ( )
Fax: ( )
Catering Tel: ( )
FSS Tel: ( )
Airport Ident.
FBO Freq. Tel: ( )
Fax: ( )
Hotel Tel: ( )
Fax: ( )
Catering Tel: ( )
FSS Tel: ( )
Notes
FINISHED
NO ANTI-ICE/
RUNWAY GRADIENT
YES
TAKEOFF CORRECTION
FACTORS
ADJUSTED V1
ADJUSTED TAKEOFF
FIELD LENGTH
TAKEOFF/GO-AROUND
THRUST SETTING
MAXIMUM CONTINOUS
THRUST SETTING
ANTI-ICE ON OR OFF?
5-1 FINISHED
B4CRH-FP001i
Takeoff Profile
One Engine Inoperative
1st
SEGMENT
2nd 3rd
TAKEOFF DISTANCE SEGMENT SEGMENT FINAL
(TRANSITION) SEGMENT
REFERENCE
ZERO 400 FT 1,500 FT
MINIMUM MINIMUM
GROUND ROLL
BRAKE GEAR UP
RELEASE V1 VR VLOF V2
35 FT
MAX CONT.
THRUST TAKEOFF THRUST THRUST
RETRACTION
LANDING
DOWN RETRACTED
GEAR
RETRACTION RETRACTED
FLAPS TAKEOFF SETTING
5-2
CLIMB
BALKED LANDING
(ALL ENGINE)
CLIMB ONE
ENGINE
VREF = 1.3VSO INOPERATIVE
50 FT
LANDING DISTANCE
BRAKE
THRESHOLD ENERGY
5-3 B4CRH-FP003i
AIRCRAFT WEIGHT
RUNWAY CONDITION/LENGTH
ATMOSPHERIC CONDITIONS
ANTI-ICE ON OR OFF?
NO
RUNWAY GRADIENT
YES
APPLY LANDING
DISTANCE CORRECTION
FACTOR
TAKEOFF/GO-AROUND
THRUST SETTING
ANTI-ICE ON OR OFF?
FINISHED
5-4
B4CRH-FP004i
Pilot
Copilot
Passenger 1
Passenger 2
Passenger 3
Passenger 4
Passenger 5
Passenger 6
Passenger 7
Subtotal
Baggage
Baggage
Galley Cabinet
Aft Fuselage
Subtotal
Galley
Map Case
Phone/Ice Chest/
Storage
Vanity
Subtotal
Total
AIRCRAFT
Airworthiness certificate
Registration
Radio licenses
MNPS certification
Aircraft flight manual
Maintenance records
Certificates of insurance (US military and foreign)
Import papers (for aircraft of foreign manufacture)
II. OPERATIONS
PERMITS
Flight authorization letter
Overflights
Landing
Advance notice
Export licenses (navigation equipment)
Military
Customs overflight
Customs landing rights
SERVICES
Inspection
Customs forms
Immigrations
Agricultural (disinfectant)
Ground
Handling agents
FBOs
Fuel (credit cards, carnets)
Maintenance
Flyaway kit (spares)
Fuel contamination check
Financial
Credit cards
Carnets
Letters of credit
Banks
Servicing air carriers
Handling
Fuelers
Traveler's checks
Cash
COMMUNICATIONS
Equipment
VHF
UHF
HF SSB
Headphones
Portables (ELTs, etc.)
Spares
Agreements
ARINC
BERNA (Switzerland)
SITA
Stockholm
NAVIGATION
Equipment
VOR
DME
ADF
Inertial
VLF/OMEGA
LORAN
GPS
Publications
Onboard computer (update)
En route charts (VFR, IFR)
Plotting charts
Approach charts (area, terminal)
NAT message (current)
Flight plans
Blank flight plans
III. OTHER PUBLICATIONS
Operations manual
International Flight Information Manual
Maintenance manuals
Manufacturer's sources
World Aviation Directory
Interavia ABC
Airports International Directory
MNPS/NOPAC
Customs Guide
B4CRH-FP005i
5-20
Flight Planning
12. FUEL ON BOARD 13. ALTERNATE AIRPORT(S) 14. PILOTS NAME, ADDRESS & TELEPHONE NUMBER & AIRCRAFT HOME BASE 15. NUMBER
18. COLOR OF AIRCRAFT CIVIL AIRCRAFT PILOTS. FAR Part 91 requires you to file an IFR flight plan to operate under instrument flight rules in
controlled airspace. Failure to file could result in civil penality not to exceed $1,000 for each violation (Section 901 of the
Federal Aviation Act of 1956, as amended). Filing of a VFR flight plan is recomended as a good operating practice. See also
Part 99 for requirements concerning DVFR flight plans.
FAA Form 7233-1 (8-82) CLOSE VFR FLIGHT PLAN WITH_________________FSS ON ARRIVAL
B4CRH-FP006i
September 2001
Beechjet 400A
Flight Planning
Block 17 Record the FSS name for closing the flight plan. If
the flight plan is closed with a different FSS or
facility, state the recorded FSS name that would
normally have closed your flight plan. Information
transmitted to the destination FSS consists only of
that in Blocks 3, 9, and 10. Estimated time en route
(ETE) will be converted to the correct estimated
time of arrival (ETA).
Optional Record a destination telephone number to assist
search and rescue contact should you fail to report
or cancel your flight plan within ½ hour after your
estimated time of arrival (ETA).
In-runway Lighting
Runway Centerline Lighting System (RCLS). Runway cen-
terline lights are installed on some precision approach runways
to facilitate landing under adverse visibility conditions. They are
located along the runway centerline and are spaced at 50-foot
intervals. When viewed from the landing threshold, the runway
centerline lights are white until the last 3,000 feet of the runway.
The white lights begin to alternate with red for the next 2,000
feet, and for the last 1,000 feet of the runway, all centerline
lights are red.
Touchdown Zone Lights (TDZL). Touchdown zone lights are
installed on some precision approach runways to indicate the
touchdown zone when landing under adverse visibility condi-
tions. They consist of two rows of transverse light bars dis-
posed symmetrically about the runway centerline. The system
consists of steady-burning white lights which start 100 feet
beyond the landing threshold and extend to 3,000 feet beyond
the landing threshold or to the midpoint of the runway, which-
ever is less.
Taxiway Lead-Off Lights. Taxiway lead-off lights extend from
the runway centerline to a point on an exit taxiway to expedite
movement of aircraft from the runway. These lights alternate
green and yellow from the runway centerline to the runway
holding position or the ILS/MLS critical area, as appropriate.
Land and Hold Short Lights. Land and hold short lights are
used to indicate the hold short point on certain runways which
are approved for Land and Hold Short Operations (LAHSO).
Land and hold short lights consist of a row of pulsing white
lights installed across the runway at the hold short point. Where
installed, the lights will be on anytime that LAHSO is in effect.
These lights will be off when LAHSO is not in effect.
Taxiway Lights
Taxiway Edge Lights. Taxiway edge lights are used to outline
the edges of taxiways during periods of darkness or restricted
visibility conditions. These fixtures emit blue light.
Stop Bar Lights. Stop bar lights, when installed, are used to
confirm the ATC clearance to enter or cross the active runway
in low visibility conditions (below 1,200 feet Runway Visual
Range). A stop bar consists of a row of red, unidirectional,
steady-burning in-pavement lights installed across the entire
taxiway at the runway holding position, and elevated steady-
burning red lights on each side. A controlled stop bar is oper-
ated in conjunction with the taxiway centerline lead-on lights
which extend from the stop bar toward the runway. Following
the ATC clearance to proceed, the stop bar is turned off and the
lead-on lights are turned on. The stop bar and lead-on lights
are automatically reset by a sensor or backup timer.
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Approved Fuels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Refueling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Hydraulics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
Engine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-25
Oxygen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27
General
Fire Extinguishers
The fire extinguishers are located in the cockpit and the aft
fuselage compartment. Check the indication on the pressure
gage and ensure it reads between 580 and 600 PSIG. If the
gage reads below 580 PSIG, exchange the bottle.
Windshield
Windshield Cleaning (Airplanes Not Modified By Kit
128-5405)
Window Cleaning
Never attempt to clean windows when dry. Flush the surface
with clean water or a mild soap solution, then rub lightly with a
grit-free soft cloth, sponge, or chamois and dry. Windex and
similar commercial cleaners containing ammonia must not be
used. To remove stubborn grease and oil deposits, use Naptha
TT-N-95A Type II as a detergent and rinse with clean water;
avoid prolonged rubbing.
Polishing Windows
Lights
For night flights, verify operation of all external lighting.
Fuel
Approved Fuels
The approved fuels for the Beechjet 400A are commercial Ker-
osene Jet A, Jet A-1, Jet B, JP-4, JP-5, JP-8, JP-8+100 and
RP-3 (Chinese) as per the Pratt & Whitney Service Bulletin
7144.
Fuel Capacities
WING FUSELAGE
TOTAL
TANKS TANKS
(US GAL)
(US GAL) (US GAL)
Refueling
The left and right wing fuel tanks are gravity filled through the
fillers located inboard of each wing tip. The aft fuselage fuel
tank is filled through the filler located on the right side of the
upper fuselage at FS 390.0. Procedures for filling all tanks are
identical. The fuel tanks can be serviced in any sequence.
Electrical Grounding
Prior to refueling the airplane, the following electrical grounding
operations must be performed:
1. Connect a grounding cable from the fuel truck to the ramp
ground.
2. Connect a grounding cable from the ramp ground to the
airplane.
Pressure Defueling
Anti-Icing Inhibitors
For fuels used in this airplane, refer to the Consumable Mate-
rial Table. Fuels not containing icing inhibitor must have MIL-I-
27686 or MIL-I-85470 fuel system icing inhibitor added in
amounts of not less than 0.10% or more than 0.15% by
volume.
Using HI-FLO Prist blender (Model PHF-2024) manufactured
by Houston Chemical Corp, Pittsburgh, PA., remove cap con-
taining tube and clip assembly. Attach the piston grip onto the
collar and press the tube into button. Clip the tube end to the
fuel nozzle and pull the trigger firmly to assure full flow and lock
in place.
Start the flow of additive when the refueling begins. Refueling
should be at 30 gal/min minimum, 60 gal/min maximum. A rate
of less than 30 gal/min may be used when topping off tanks.
Hydraulics
Approved Hydraulic Fluids
Service the hydraulic system using MIL-I-5606 hydraulic fluid.
System Servicing
Servicing the hydraulic package consists of maintaining the
proper fluid level in the reservoir. Refer to Table 6-B for the
hydraulic package reservoir capacity.
QUANTITY QUANTITY
SYSTEM US GAL IMPERIAL SPECIFICATION
(LITERS) GAL
Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . LOWER
Lower the pressure in the accumulator to the correct value
by slowly cracking the bleed valve.
Charging Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CLOSE
Turn the swivel nut clockwise past the free-play area and
torque the nut to 50 to 70 inch-pounds (60 to 80 kg-cm).
Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BLEED
Bleed pressure from the pressure gage assembly and
remove it from the charging valve.
Valve Cap . . . . . . . . . . . . . . . . . . . . .INSTALL FINGER-TIGHT
Access Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . INSTALL
Engine
Approved Engine Oils
Use only approved jet engine oil when servicing the engine oil
system. Refer to the latest revision of Pratt & Whitney Service
Bulletin No. 7001 for approved oils.
Quantity
Quantity US Name, Number
System Imperial
Gallons (Liters) or Type
Gallons
Engine Oil Refer to the latest
revision of the Pratt
& Whitney Service
Bulletin No. 7001.
Oil Tank (Total
2.03 (7.68) 1.69
Capacity)
Usable
1.20 (4.54) 1.00
Quantity
Oxygen
Approved Materials
Service the oxygen system using MIL-O-27210 aviator’s
breathing oxygen.
Oxygen System Servicing
Toilet
Alamo Toilet Servicing
NOTE: During cold weather operation, add toilet antifreeze
to the waste container and the flushing liquid reservoir as
instructed on the antifreeze container.
The initial charge of the flushing liquid reservoir is approxi-
mately two quarts of water mixed with 2 oz. of toilet chemi-
cals per each quart of water. The reservoir should be filled to
the line marked “Fill To Here” on the inner wall of the
reservoir.
Choking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-23
Emergency Equipment Record . . . . . . . . . . . . . . . . . . . . . 7-24
Emergency Information
Pilot Responsibility and Authority
The pilot in command of an aircraft is directly responsible for
and is the final authority as to the operation of that aircraft. In
an emergency requiring immediate action, the pilot in com-
mand may deviate from any rule in 14 CFR Part 91, Subpart A,
General, and Subpart B, Flight Rules, to the extent required to
meet that emergency.
REFERENCE-14 CFR Section 91.3(b).
If the emergency authority of 14 CFR Section 91.3(b) is used to
deviate from the provisions of an ATC clearance, the pilot in
command must notify ATC as soon as possible and obtain an
amended clearance.
Unless deviation is necessary under the emergency authority
of 14 CFR Section 91.3, pilots of IFR flights experiencing two-
way radio communications failure are expected to adhere to
the procedures prescribed under “IFR operations, two-way
radio communications failure”.
REFERENCE-14 CFR Section 91.185.
Emergency Conditions
An emergency can be either a distress or urgency condition as
defined in the Pilot/Controller Glossary. Pilots do not hesitate to
declare an emergency when they are faced with distress condi-
tions such as fire, mechanical failure, or structural damage.
However, some are reluctant to report an urgency condition
when they encounter situations which may not be immediately
perilous, but are potentially catastrophic. An aircraft is in at
least an urgency condition the moment the pilot becomes
doubtful about position, fuel endurance, weather, or any other
condition that could adversely affect flight safety. This is the
time to ask for help, not after the situation has developed into a
distress condition.
Pilots who become apprehensive for their safety for any reason
should request assistance immediately. Ready and willing help
is available in the form of radio, radar, direction finding stations,
and other aircraft. Delay has caused accidents and cost lives.
Safety is not a luxury! Take action!
• Visible landmarks.
• Aircraft color.
• Number of persons on board.
• Emergency equipment on board.
Actuate your ELT if the installation permits.
For bailout, and for crash landing or ditching if risk of fire is not
a consideration, set your radio for continuous transmission.
If it becomes necessary to ditch, make every effort to ditch
near a surface vessel. If time permits, an FAA facility should
be able to get the position of the nearest commercial or
Coast Guard vessel from a Coast Guard Rescue Coordina-
tion Center.
After a crash landing, unless you have good reason to
believe that you will not be located by search aircraft or
ground teams, it is best to remain with your aircraft and pre-
pare means of signaling search aircraft.
Circulation
Locate carotid artery pulse; hold 10 seconds. If no pulse:
Begin external chest compressions by locating hand posi-
tion two fingers above notch and placing heel of hand on
breastbone.
Perform 15 compressions of 1½ to 2 inches at a rate of 80 to
100 compressions per minute. (Count, “One and two and
three and...,” etc.) Come up smoothly, keeping hand contact
with victim’s chest at all times.
Repeat the cycle of two breaths, 15 compressions, until
victim’s pulse and breathing return. If only the pulse is present,
continue rescue breathing until medical assistance is available.
Reproduced with permission. © MedAire, Inc.
Airway
Breathing
Circulation B4CRH-EM001i
Heart Attack
Signals
Pressure, squeezing, fullness, or pain in center of chest
behind breastbone.
Sweating.
Nausea.
Shortness of breath.
Feeling of weakness.
Actions for Survival
Recognize signals.
Stop activity and lie or sit down.
Provide oxygen if available.
If signals persist longer than two minutes, get victim to
medical assistance.
Choking
If victim can cough or speak:
Encourage continued coughing.
Provide oxygen if available.
If victim cannot cough or speak:
Perform Heimlich maneuver (abdominal thrusts):
1. Stand behind victim; wrap arms around victim’s waist.
2. Place fist of one hand (knuckles up) in upper abdomen*.
3. Grasp fist with opposite hand.
4. Press fist into upper abdomen* with quick, inward and
upward thrusts.
5. Perform maneuver until foreign body is expelled.
Provide supplemental oxygen if available.
* If victim is pregnant or obese, perform chest thrusts
instead of abdominal thrusts.
B4CRH-EM002i
Fire Extinguisher(s)
Fire Axe
Life Raft
Life Vests
Therapeutic
Oxygen
Overwater
Survival Kit
Other
Meters/Feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Statute Miles/Kilometers/Nautical Miles . . . . . . . . . . . . . . . . 8-4
Distance Conversion
Meters/Feet
Meters Feet Meters Feet
0.3048 1 3.2908
0.61 2 6.58
0.91 3 9.87
1.22 4 13.16
1.52 5 16.45
1.83 6 19.74
2.13 7 23.04
2.44 8 26.33
2.74 9 29.62
3.1 10 32.9
6.1 20 65.8
9.1 30 98.7
12.2 40 131.6
15.2 50 165.5
18.3 60 197.4
21.3 70 230.4
24.4 80 263.3
27.4 90 296.2
31 100 329
61 200 658
91 300 987
122 400 1316
152 500 1645
183 600 1974
213 700 2304
244 800 2633
274 900 2962
305 1000 3291
Weight Conversion
lb./kg
lb. kg lb. kg
2.2046 1 0.4536
4.40 2 0.91
6.61 3 1.36
8.82 4 1.81
11.02 5 2.27
13.23 6 2.72
15.43 7 3.18
17.64 8 3.63
19.84 9 4.08
22.0 10 4.5
44.1 20 9.1
66.1 30 13.6
88.2 40 18.1
110.2 50 22.7
132.3 60 27.2
154.3 70 31.8
176.4 80 36.3
198.4 90 40.8
220 100 45
441 200 91
661 300 136
882 400 181
1102 500 227
1323 600 272
1543 700 318
1764 800 363
1984 900 408
2205 1000 454
Volume Conversion
Imp Gal/US Gal; US Gal/Liter; Imp Gal/Liter
Imp US Imp US US US Imp Imp
Ltr Ltr Ltr Ltr
Gal Gal Gal Gal Gal Gal Gal Gal
0.83267 1 1.2010 0.26418 1 3.7853 0.21997 1 4.5460
1.67 2 2.40 0.52 2 7.57 0.44 2 9.09
2.49 3 3.60 0.79 3 11.35 0.66 3 13.64
3.33 4 4.80 1.06 4 15.14 0.88 4 18.18
4.16 5 6.01 1.32 5 18.92 1.10 5 23.73
5.00 6 7.21 1.59 6 22.71 1.32 6 27.28
5.83 7 8.41 1.85 7 26.50 1.54 7 31.82
6.66 8 9.61 2.11 8 30.28 1.76 8 36.37
7.49 9 10.81 2.38 9 34.07 1.98 9 40.91
8.3 10 12.0 2.6 10 37.9 2.2 10 45.6
16.7 20 24.0 5.3 20 75.7 4.4 20 91.0
24.9 30 36.0 7.9 30 113.5 6.6 30 136.4
33.3 40 48.0 10.6 40 151.4 8.8 40 181.8
41.6 50 60.1 13.2 50 189.2 11.0 50 227.3
50.0 60 72.1 15.9 60 227.1 13.2 60 272.8
58.3 70 84.1 18.5 70 265.0 15.4 70 318.2
66.6 80 96.1 21.1 80 302.8 17.6 80 363.7
74.9 90 108.1 23.8 90 340.7 19.8 90 409.1
83 100 120 26.4 100 379 22 100 455
167 200 240 53 200 757 44 200 909
249 300 360 79 300 1136 66 300 1364
333 400 480 106 400 1514 88 400 1818
416 500 601 132 500 1893 110 500 2273
500 600 721 159 600 2271 132 600 2728
583 700 841 185 700 2650 154 700 3182
666 800 961 211 800 3028 176 800 3637
749 900 1081 238 900 3407 198 900 4091
833 1000 1201 264 1000 3785 220 1000 4546
Temperature Conversion
°C °F °C °F °C °F °C °F °C °F
-54 -65 -32 -26 -10 14 12 54 34 93
-53 -63 -31 -24 -9 16 13 55 35 95
-52 -62 -30 -22 -8 18 14 57 36 97
-51 -60 -29 -20 -7 19 15 59 37 99
-50 -58 -28 -18 -6 21 16 61 38 100
-49 -56 -27 -17 -5 23 17 63 39 102
-48 -54 -26 -15 -4 25 18 64 40 104
-47 -53 -25 -13 -3 27 19 66 41 106
-46 -51 -24 -11 -2 28 20 68 42 108
-45 -49 -23 -9 -1 30 21 70 43 109
-44 -47 -22 -8 0 32 22 72 44 111
-43 -45 -21 -6 1 34 23 73 45 113
-42 -44 -20 -4 2 36 24 75 46 115
-41 -42 -19 -2 3 37 25 77 47 117
-40 -40 -18 0 4 39 26 79 48 118
-39 -38 -17 1 5 41 27 81 49 120
-38 -36 -16 3 6 43 28 82 50 122
-37 -35 -15 5 7 45 29 84 51 124
-36 -33 -14 7 8 46 30 86 52 126
-35 -31 -13 9 9 48 31 88 53 127
-34 -29 -12 10 10 50 32 90 54 129
-33 -27 -11 12 11 52 33 91 55 131
International Standard
Atmosphere (ISA)
Altitude/Temperature
Altitude ISA Altitude ISA Altitude ISA Altitude ISA
(ft.) (°C) (ft.) (°C) (ft.) (°C) (ft.) (°C)
S.L. 15.0 11,000 -6.8 22,000 -28.5 33,000 -50.3
1,000 13.0 12,000 -8.8 23,000 -30.5 34,000 -52.3
2,000 11.0 13,000 -10.7 24,000 -32.5 35,000 -54.2
3,000 9.1 14,000 -12.7 25,000 -34.5 36,000 -56.2
4,000 7.1 15,000 -14.7 26,000 -36.5 37,000 -56.5
5,000 5.1 16,000 -16.7 27,000 -38.4 38,000 -56.5
6,000 3.1 17,000 -18.7 28,000 -40.4 39,000 -56.5
7,000 1.1 18,000 -20.6 29,000 -42.4 40,000 -56.5
8,000 -0.8 19,000 -22.6 30,000 -44.4 41,000 -56.5
9,000 -2.8 20,000 -24.6 31,000 -46.3 42,000 -56.5
10,000 -4.8 21,000 -26.6 32,000 -48.3 43,000 -56.5
0 1 2 3 4 5 6 7 8 9
Hectopascals
or Millibars
Inches of Mercury
880 25.99 26.02 26.05 26.07 26.10 26.13 26.16 26.19 26.22 26.25
890 26.28 26.31 26.34 26.37 26.40 26.43 26.46 26.49 26.52 26.55
900 26.58 26.61 26.64 26.67 26.70 26.72 26.75 26.78 26.81 26.84
910 26.87 26.90 26.93 26.96 26.99 27.02 27.05 27.08 27.11 27.14
920 27.17 27.20 27.23 27.26 27.29 27.32 27.34 27.37 27.40 27.43
930 27.46 27.49 27.52 27.55 27.58 27.61 27.64 27.67 27.70 27.73
940 27.76 27.79 27.82 27.85 27.88 27.91 27.94 27.96 27.99 28.02
950 28.05 28.08 28.11 28.14 28.17 28.20 28.23 28.26 28.29 28.32
960 28.35 28.38 28.41 28.44 28.47 28.50 28.53 28.56 28.58 28.61
970 28.64 28.67 28.70 28.73 28.76 28.79 28.82 28.85 28.88 28.91
980 28.94 28.97 29.00 29.03 29.06 29.09 29.12 29.15 29.18 29.21
990 29.23 29.26 29.29 29.32 29.35 29.38 29.14 29.44 29.47 29.50
1000 29.53 29.56 29.59 29.62 29.65 29.68 29.71 29.74 29.77 29.80
1010 29.83 29.85 29.88 29.91 29.94 29.97 30.00 30.03 30.06 30.09
1020 30.12 30.15 30.18 30.21 30.24 30.27 30.30 30.33 30.36 30.39
1030 30.42 30.45 30.47 30.50 30.53 30.56 30.59 30.62 30.65 30.68
1040 30.71 30.74 30.77 30.80 30.83 30.86 30.89 30.92 30.95 30.98
1050 31.01 31.04 31.07 31.10 31.12 31.15 31.18 31.21 31.24 31.27
40
35 40,000
35,000
30
30,000
25
25,000
ET
FE
CAE SimuFlite
–
Cabin Altitude
20
DE 20,000
TU .
TI M 1
AL . AT
N 2
BI STD
15
CA 15,000 US 3
4
5
10
10,000
MAXIMUM PRESSURE SCHEDULE 6
CABIN ALTITUDE – 1000 FT
7
Developed for Training Purposes
8
R E
5
9 SU
5,000
RES
P
10 L
A
TI
R EN SIG
E P
FF
DI
MAXIMUM PRESSURE SCHEDULE
0
5
15
10
20
35
25
30
50
40
60
S.L.
September 2001
Beechjet 400A
