MiCOM P211
Three-phase Motor
Protection Relay

T&D
Energy Automation & Information
MiCOM P211
Three-phase Motor Protection Relay
with Communication Facility
Main features
· Motor protection for MV motors
and larger LV units against:
- thermal overload [49],
- loss of load (undercurrent) [37],
- loss of phase,
- unbalance [46],
- excessive temperature inside
the motor [38],
- earthfault (option) [50N/51N],
- short-circuit fault [50/51]
- prolonged starting [38] (including
inertia motor criteria),
- stalled rotor / mechanical jam
[51LR],
- number of startings [66].
· Optional communication
facility via Modbus RTU
protocol, through halfduplex
communication port RS485 (2 wires:
"+", "-"), enabling:
- readout of phase current values,
motor thermal state and earthfault
current value, the relay inputs and
outputs state, the max. current and
duration of the most recent starting,
- remote reset of warning signals
and latched output relays,
- remote control of circuit-breaker
or contactor via RS485,
- readout of protection trigger
and trip state.
· Local control of CB/contactor through
the relay’s binary input
· Flush or DIN rail mounted case
· Star / delta logic control
· Reaccelleration logic (emergency
restart). Binary input may be
configured to enable a motor
selfstarting, when automatic standby-
switching scheme operates or voltage
interruption takes place
· Control logic in case of motor power
supply failure. User selectable time
period for motor selfstarting up to
3s for 230V AC.
· True RMS measurement of phase
currents from 10Hz to 1000Hz
· Measurement of earthfault current
from 40 to 70Hz (MV application)
· Record of last motor starting
parameters (max. current, duration)
· Immunity to transient voltage dips or
interruptions, which benefits
specifically when stand by-switching
scheme operates
· Connection of motor phase wires to
the relay:
- through terminals IL1, IL2, IL3.
This applies to MV and LV high
power motor applications,
- by their interleaving through guiding
channels in the housing (L1, L2, L3).
This applies to motor applications of
LV low power motors
· Connection of residual current
transformer to the relay's screw
terminals
· Optional control of voltage presence
on the busbar (LV applications)
2
· 6 LEDs indicating trip or trigger state
of the relay
· 5 button keypad to configure the
relay
· Up to 4 programmable output relays
(3 N/O +1 C/O)
· Programmable contact input S1-S2
which enable blocking, resetting of
trip latching, instantaneous tripping
of the motor, activating of inertia
motor logic and trigerring of motor
reaccelleration , blocking of remote
command via RS485
· Programmable contact input T1-T2
which enable blocking, resetting of
trip latching or connection of PTC
sensors
· Programmable voltage input V1-C
(options) which enable instantaneous
tripping of the relay, closing of
CB/contactor, or activating outputs in
maintenance state
· Programmable voltage inputs V2-C
(option) which enable blocking,
reseting of latch or warning signals,
instantaneous tripping of the relay,
monitoring of CB/contactor,
activating of trigerring of motor
reaccelleration
· Overload pre-warning if a set
threshold is exceeded
(flashing LED “I>" )
· Setting tamper-proof feature (seal of
the front panel cover and user
defined password)
Protection features
Overload (49)
The protection feature is based on
mathematical model of motor thermal
image. The model utilises a heating

constant time values. It is input to the relay
by means of T parameter, which
describes the maximum period of time
when actual motor current value is allowed
to reach a sixfold increase of its nominal
value. Cooling constant time value is
calculated on the basis of the heating
constant. Configuring procedure of the
model includes setting of the motor base
current (nominal motor current) and T .  core balanced transformer or filter of
There are 2 thresholds. The first one for
alarm and the second one for trip.
It is possible to set a separate threshold
("theta forbid start") which is activated after
trip command and up to this threshold the
trip signal is present. This feature prevents
from close command.
Undercurrent (37)
It is based on undercurrent protection
with time delay tI<. Configuring
procedure of this protection facility
includes setting of the triggering
threshold at which undercurrent state is
detected, and time delay. This feature
benefits specifically when detecting drive
failures or no-load running of a pomp.
Unbalance (46)
Running motors at unbalance or loss of
phase conditions results in overheating,
even at current values below the
nominal. Principle of operation is based
on monitoring of the percentage of the
current unbalance in the three
subsequent phases L1, L2, L3 (A,B,C):
where:
LX is L1, L2, L3 respectively.
Configuring procedure of this protection
facility includes setting of the max. value
of current unbalance, and DT delay.
Loss of phase
This feature monitors phase current
values. Any phase current of a value
below 0.1xIB (where I is motor nominal
current) is recognised by the relay as
a lost phase. The relay trips a motor after
a set DT delay.
Over-temperature (38)
The relay may co-operate with motors
fitted with PTC sensors. PTC’s may be
linked in a serial loop of max 6 sensors.
This feature protects motor against slow
variations of temperature, taking into
account ambient and cooling conditions
(direct measurement of motor
temperature).
Since PTC sensors represent some
thermal inertia, dynamic changes of
motor temperature shall be detected by
motor thermal image feature.
Opening the loop (increase of the
circuit's resistance) is registered by the
relay as the result of PTC sensors
operation.
Earthfault (50N/51N) (option)
Earthfault protection is performed thanks
to the relay's connection to an external
current zero sequence component,
based on CT’s Holmgreen arrangement.
Zero sequence component is applied to
separate current terminals of the relay.
Setting parameters of this protection are
current threshold, and DT delay.
Short circuit fault (50/51)
If current threshold is set above current
value of motor starting, then a short-
circuit feature is enabled. This feature is
used exclusively in applications where a
circuit-breaker exists as a switching
device and is capable to trip short-circuit
current.
In applications where a contactor is used
the short-circuit protection must not be
enabled. Protection against short-circuit
faults is then performed by external fuses.
Excessive long start (38)
If the motor is subject to heavy load, this
function allows monitoring of the duration
of the motor's start-up phase. The detection
of the start-up is based on current criteria
only. If start-up phase is too long (greater
than time delay tIstart) there is trip
command or alarm signal.
Blocked rotor while running
or at start-up (50S/51LR)
During normal motor opertation, an
overcurrent threshold detects rotor stalling,
and the time delay setting (tIstall) is
calculated.
During motor start-up, a locked rotor is
detected with the help of a speed switch
signal, connected via the logic input S1-S2
(if set to this function). If during start-up
phase S1-S2 input is not shorted (it means
that the motor is stopped) the time delay
setting (tIstall) is calculated.
This protection can be set to trip or alarm.
Number of startings (66)
The max. number of motor's startings can
be defined, within a user-defined period
of time.
3
Emergency start-up
When required by security conditions or
startup process, a logic input can be
used to allow motor start-up. If the input
is energised, then the thermal image
function will be disabled (set to 0%).
Reaccelleration function
This function is used for the motors'
selfstarting. If there is no voltage on the
busbar (controlled via binary input: S1-
S2 or V2-C) this function is trigerred.
Calculation of the time delay
(authorization time of reaccelleration) is
commenced . If voltage returns again to
the busbar before the timing is
completed, the reaccelleration time
delay for close command is calculated.
After that time motor is started.
If P211 is supplied from AC auxiliary
voltage of the busbar, the maximum
authorization time of reacceleration is
limited down to 3s for 230VAC (after
switching the auxiliary voltage off, P211
works correctly for not less than 3s).
Such feature is very useful for contactor
LV application.
Technical Data
Analogue inputs
· Setting range of base current (IB )
(options)
0.37-0.75A; step: 0.01A
0.75-1.5A; step: 0.01A
1.5-3A; step: 0.1A
3-6A; step: 0.1A
5-10A; step: 0.1A
10-20A; step: 0.1A (rail only)
20-40A; step: 0.1A (rail only)
40-80A; step: 0.1A (rail only)
For DIN rail mounted version of the
relay it is possible to widen the relay
current range downwards, by multiple
interleaves of motor phase feeders
through the guiding channels in the
relay housing. These guiding channels
constitute primary side of internal
CTs'. E.g. fivefold interleaves of motor
phase feeders through the channels
will change the measuring range of
the relay from 3-6A down to 0.6-
1.2A.
It is also possible to widen the relay
current range upwards, by using
external CTs'. In such the case it is
recommended to use the relay version
of 3-6A setting range. The CTs’ should
have rated over-current factor of at
least 10 (they should transform
current up to 10 In).
Should you need any assistance with
purchasing the proper CTs', please
contact the relay manufacturer.
· Frequency range: · Time delay setting range Earthfault Io>T:
- phase current measurement (0.00 - 2.50)s in steps of 0.01s · current threshold range Io>
(10 - 1000)Hz - for Ion=1A
· Operation: trip or alarm
- earthfault current measurement (0.01A - 0.5)A; step: 0.01A
(40 - 70)Hz Unbalance tI<: - for Ion=5A
· Current threshold range (0.05 - 2.5)A; step: 0.01A
Protection features
(15 - 50)% in steps of 1% · Time delay setting range
Overload (thermal replica): · Time delay setting range (0.02 - 99.9)s in steps of 0.01s
· Tripping time range at 6xIB (0.02 - 99.9)s in steps of 0.01s
(0.2 - 50)s; step: 0.1s · Operation: trip or alarm
· Operation: trip or alarm
· Threshold for alarm:
Excessive long start Number of start-up
(50-120)%; step: 1%
· Time delay setting range for · allowed start-up number
· Threshold for trip: 100% (fixed) prolonged starting tIstart 1-5
(0.02 - 99.9)s in steps of 0.01s
· Threshold for forbid start: · The time for start-up calculation
Blocked rotor Treference
(30-99)%; step: 1%
· Current threshold range (10-7200)s; step: 10s
· trip: latched or not latched (1.0 - 12.0)xIB; step: 1xIB
· The blocking time after operation
Undercurrent tI<: · Time delay setting range
number of start-up (lock time)
for stalled rotor tIstall
· Current threshold range I< (0.02 - 99.9)s in steps of 0.01s (10-7200)s; step: 10s
(30 - 90)% in steps of 1% · Operation: trip or alarm · Operation: trip or alarm
· Time delay setting range
(0.02 - 99.9)s in steps of 0.01s Loss of phase: Accuracy
· Operation: trip or alarm · Time delay setting range
· Current and time accuracy: 10%
(0.02 - 99.9)s in steps of 0.01s
Short-circuit tI>>:
· Current threshold range I>> Burden for current input
(2 -12)xI in steps of 1xI
Phase: <0.3VA for In=5A
Earth: <0.5VA for Ion=5A
<0.1VA for Ion=1A

Dimensions

111.0
32.5

100.0 5.0 103.0

10.5
P211

L1 [%]
23.0 23.0
L2
I> L3 [S]

I>>
75.0

I<
Io

PTC

Vx PTC
A1 A2 13 14 21 22 T1 T2 S2 S1 / 01 2 /

Fig. 1: 35 mm DIN rail housing Fig. 2: Flush mounted housing

and panel cut-out details
& ' ( )* !!" # + , + -.

P211

L1 [%]
L2
I> L3 [S]

I>>
I<
Io

PTC

3 45 6 3
$%
4
Auxiliary supply voltage Connections Insulation
· Auxiliary supply voltage (options) Threaded terminal ends M3, with wire Voltage test
(24 - 48)V AC/DC 7
protection for conductor cross-sections Between independent circuits
(60 - 240)V AC/DC 7
- up to 4mm single-core or 2 kV AC, 50Hz, 60s
· Reset time of output relays - up to 2.5mm finely stranded Between contact circuits
on supply voltage interruption 1 kV AC, 50Hz, 60s
5.2s at 230V AC Environmental Conditions Insulation resistance
2.95s at 230V DC · Degree of device protection >100MW
1.2s at 110V AC - Case: IP 40 Impulse voltage withstand test between
0.75s at 110V DC - Terminals: IP 20 independent circuits
0.065s at 24V AC - Front panel 5 kV
0.06s at 24V DC for flush mounted case: IP54
· Supply voltage tolerance
· Ambient temperature: Mechanical Robustness
(0.8 - 1.1)Vx
Operating temp. (-20 ¸ +60)°C Vibration test:
· Burden
Storage temp. (-25 ¸ 70)°C Acc. to IEC 255-21-1 class 1
4.5VA
Relay outputs · Ambient humidity range Frequency range during operation:
Relative humidity to preclude any 10 to 60Hz, 0.035mm
· Up to 4 output relays (3 NO, 1CO) condensation: 95% at 40°C 60 to 150Hz, 0.5g
· Contact capacity: Frequency range during transport:
Making, continuously: 5 A Conformity statement 10 to 150Hz, 1g
Breaking: EC EMC Directive 89/336/EEC Shock response and withstand test,
5A (220V AC, cosj=0.4) EC Low Voltage Directive bump test:
0.1A (220V DC, L/R=40ms) 73/23/EEC Acc. to IEC 255-21-2 class 1
Acceleration 5g/15g
10
8
· Mechanical durability International Standard
EN 60255-6

9
· Switching capacity
Electromagnetic Compatibility External CTs’ specification
10
(EMC) P211 may co-operate with external CTs',
Inputs designed for protection applications.
· Binary inputs S1-S2 and T1-T2: Interface suppression
The accuracy limit factor should be at
- controlled by an external contact According to EN 55011, level A least P10 (eg. 5VA 5P10 or 30VA
· Binary inputs V1-C and V2-C 10P10, etc.).
- controlled by Vx voltage Creepage distances CT's power should be greater than a sum
· PTC sensor input (if T1-T2 configured and clearances of power of analogue inputs and burden
as PTC input) Per IEC 255-5 group C of current circuit at the relay's terminals
- max resistance in cold state: (resistance of wires, terminals, etc.).
1500 Ohm If a range greater than 10xIn is used,
- trip resistance: Immunity
then a CT of rated power greater than
(3700 - 4000) Ohm Electrostatic discharge calculated should be matched, in order
- reset resistance: EN 61000-4-2 level 3 for the accuracy limit factor at real load
(1900 - 2100) Ohm Radiated electromagnetic energy to be sufficient (that is greater than
EN 61000-4-3 level 2 maximum setting).
Radiotelephone radiated Recommended CTs’ may be ordered
Weight electromagnetic energy with the relay from the relay
~0.6kg EN 50204 level 3 manufacturer.
Electrical fast transient/burst
Housing EN 61000-4-4 level 3
35mm DIN rail or flush mounted Surge test
EN 61000-4-5 level 3
1 MHz burst disturbance test
Communication Acc. to IEC 255-22-1 level 3
· RS485 halfduplex link Voltage dips and interruptions
(2 wires "+", "-") Acc. to EN 61000-4-11
· Protocol Modbus RTU Conducted disturbance inducted by
· Data rate (1200-19200) bps radio frequency fields
Acc. to EN 61000-4-6 level 3

5
Connection diagram

Fig. 3. Connection diagram

Ordering information
Ordering No.
806 0 0 1

Housing version
35 mm DIN rail 0
flush mounted 1
Relay hardware version
A, standard 1
B, standard plus additional input Io>, RS485 2
C, standard plus additional input Io>, RS485 and I/O card (2xBI: V1-C, V2-C and 2xBO: P3, P4) 3
Auxiliary supply Vx
60 ¸ 230V AC/DC 0
24 ¸ 48V AC/DC 1
Rated earthfault current Ion
1A (only version B or C) 0
5A (only version B or C) 1
no Ion input (only version A) 2
Voltage 230VAC presence control (only version C) 6
Measuring range I (setting of a nominal current of the motor)
1.5 ¸ 3A 0
3 ¸ 6A 1
5 ¸ 10A 2
10 ¸ 20A (only DIN rail housing) 3
20 ¸ 40A (only DIN rail housing) 4
40 ¸ 80A (only DIN rail housing) 5
0.75 ¸ 1.5A 6
0.37 ¸ 0.75A 7
Note: It is possible to modify the current range of relay if external current transformers are used.
Should you require any assistance with choosing the proper CTs', please contact the relay manufacturer.
Details concerning the recommended CTs' may be found in an individual publication.
Please contact: pcb-gee.poland@areva-td.com

6
 L1 L2 L3 N

rs

^ _ ` _ acb d e f d J K
m npo q F G NN kl [[ B C
:; LM YZ
MiCOM P211
HI OP \] DE
>?
M
3 phase
ST WX
<= QR UV
@A

Fig. 4: Example of application - MiCOM P211, version C, DIN rail mounted case -
(star / delta arrangement of motor starting)
Fig. 5: Example of application - MiCOM P211, version A, DIN rail mounted case
(star / delta arrangement of motor starting)
L1 L2 L3 N

xyzy{

MiCOM P211

M
3 phase

t uv w u
ghi j
RTx-153

K2

7
 L1 L2 L3 N

STOP
START

Trip Alarm

13 14 23 24 42 41 V2 V1 C

P1 P2 P3 P4

MiCOM P211
k K L S1 S2 T1 T2 TR+ TR- A2 A1
l
RS 485

RESET

PTC

M
3 phase

Fig. 6: Example of application - MiCOM P211, version C,

DIN rail mounted case, control via RS 485 link
Fig. 7: Example of application - MiCOM P211, version A,
flush mounted case

L1 L2 L3 N

STOP

IZ K S1

IZ K S2 START
S1
Trip
IZ K S2
S1
1 3 5 13 14 21 22 A1 A2
S2

P1 P2

MiCOM P211
2 4 6 S1 S2 T1 T2
RESET

PTC

M
3 phase

Your contact:

8
9
 Printed in Poland
Publication: P211EnBr_V6F

Transmission & Distribution Energy Automation & Information, Le Sextant, 3 avenue Andr é Malraux, 92300 Levallois-Perret. France
Tel: +33 (0) 1 41 49 20 00 Fax: +33 (0) 1 41 49 24 85 energy-automation.information@tde.alstom.com www.tde.alstom.com
Contact Centre on line 24 hours a day: +44 (0) 1785 25 00 70

Ð Ñ Ò Ó Ð Ô Õ Ö | × }Ø ~ Ù  Ú €Û Ü Ø  × Ø ‚ Ý ƒ „Þ ߅ à ᆠ⠇ ˆã ‰ à Š ß ä ‹ å æ Œ  ç Ž è é ê ë  ì ‘ í ’ î “ ”ï ð ñ• ò– — ˜ó ô ™ õ š › ö œ÷  ž øŸ ù   ú¡ û ¢ü £ý ¤ ¥ú ù ¦ þ §ÿ ¨ © ª © « ¬ ­ ® ¯ ° ± ² ³ ´ µ ² ± ¶ · ¸ ¹ º » ¼ ½ ¾ ¿ À Á Â Ã Ä Å Æ Ç È É Ê Ë Ì Í Î Ï



                      ! " # ! $ % & ' ! ( ) * + , - . / 0 1

2 3 4 5 6 7 8 9 : ; < = > ? @ A B C D E F D G C G H I J K J L M N O J P Q R S T T U V W X Y Z [ \ ] ^ _ ` a b c d e f g h i j k l m n o p q r s t u v w x y z { | } ~  €  ‚ ƒ „ … † ‡ ˆ ‰ Š ‹ Œ  Œ Ž   ‘ ‘ ’ “ ” • – — ˜ ™ š › œ  ž Ÿ   ¡ ¢ £ ¤ ¥ ¦ § ¨ © ª « ¬ ­ ® ¯ ° ± ® ² ° ¯ ³ ´ µ ¶ ·

¸ ¹ º » ¼ ½ ¹ ¾ ¿ À Á Â Ã Ä Å Æ Ç È É Ê Ë Ì Í Î Ë Ï Ì Ï Ð Ñ Ò Ó Ô Õ Ö × Ø Ù Ú Û Ü Ý Þ ß à Þ á à á â ã ä å æ ç è é ê ë ì í î ï ð ñ ò ð ó ô õ ô ö ÷ ø ù ú û ü ý þ ÿ


                    ! " # $ % & ' ( ) * + , - - . / 0 , 1 / 2 3 4 5 6 7 8 9 : ; < = > ?

@ A B A @ @ A C D E F G H I J K L M N O O P Q R S T U V W X Y Z [ \ ] Z ^ _ ` Y a b c d e f g h i j k l m h n o p q r s t u v w v x y w z { | } ~  €  ‚ ƒ „ … † ‡ ˆ † ‡ ‰ Š ‹ Œ  Ž  Œ  ‘ ’ “ ” • ” “ – — ˜ ™ š › œ
