Group Members:

PATHIRAGE P.A.L
RANAWEERA R.A.I.E
WELLAARACHCHI W.A.P.K
WELLALA S.R.G
Table of Contents

INTRODUCTION ....................................................................................................................................... 3
THEORY ................................................................................................................................................... 4
LEGEND ............................................................................................................................................... 4
LOGIC .................................................................................................................................................. 4
CIRCUIT DIAGRAM .............................................................................................................................. 4
LAYOUT OF THE SYSTEM ..................................................................................................................... 5
FUNCTIONALITY OF THE SYSTEM ........................................................................................................ 5
PROCEDURE OF THE IMPLEMENTATION ................................................................................................ 7
BUDGET ................................................................................................................................................... 9
LIST OF FIGURES

Figure 1: Sensors after connecting to the relay .......................................................................... 7

Figure 2: Testing circuit ............................................................................................................. 7
Figure 3: Cutting the conduit pipe to the required height .......................................................... 7
Figure 4: Fixing the sensors to the pipe ..................................................................................... 7
Figure 5: Finishing ..................................................................................................................... 7
Figure 6: C10 MCB ................................................................................................................... 8
Figure 7: Installing the MCB to the distribution board.............................................................. 8
Figure 9: Installing conduit pipes .............................................................................................. 8
Figure 8: Wired the connection of the motor ............................................................................. 8
Figure 10: Installing the socket outlets ...................................................................................... 8
Figure 11: Installing the 24DC power supply, Motor Controller and the relay ......................... 8
Figure 12: Finalized control box and socket outlets .................................................................. 9
Figure 13: Tank and the installed sensors .................................................................................. 9
INTRODUCTION
In this project an automatic water pump controller was implemented to control two tanks which
are parallel connected in Deduru Oya Mini Hydro Power Plant. All the regular works of the
plant is done with that water supply. It was operated manually, and that switch was located in
the storeroom, separate from the plant. Requirement of an automatically controlling motor was
occurred because of some difficulties faced by the workers. In order to automate the process,
it is designed to sense the water level and to control the pump according to that.
After studying the logic behind the sensor functioning, which is suitable for the tank water
level operation, suitable relay which is related to our required logic is found. Then all the
required components were listed and budgeted. Finally, after six working days the automatic
water pump controller system was installed, with the help of SLE officials.
This report includes the objectives, components, all the implementation steps with circuit
diagrams and the budget.

OBJECTIVES
• To minimize the difficulties faced by the workers.
• To utilize the manpower while making the motor operation more efficient and user
friendly.
• Two switches to function the manual and the auto operation
 THEORY

LEGEND
S1 MCPLS-041-A-6 Upper Float Sensor-Magnetic
S2 MCPLS-041-A-6 Lower Float Sensor-Magnetic

LOGIC
S2=0 & S1=0 Motor On
S2=1 & S1=0 Motor keeps On
S2=1 & S1=1 Motor Off
S2=1 & S1=0 Motor keeps Off
S1=0 & S2=0 Motor On

COMPONENTS
1. 230V/24V AC/DC converter
2. 2 Sensors
3. 24V DC relay
4. Wires
5. PVC pipe
6. Conduit pipe
7. 2 socket outlets
8. C10 MCB
9. Enclosure box

CIRCUIT DIAGRAM

Relay
-62K1
5
L
9
A1(13) 1

8
A2(14) 12 4
C10
MCB
E
L N Always ON

S2(Lower) S1(Upper)

0V 24V

DC Supply MOTOR
XST4
LAYOUT OF THE SYSTEM

S1

S2
230V/24V AC/ DC Converter

14 1 4

13 9 8

L N E 5 12

24V DC Relay

L N L N

Manual Switch Auto Switch

L C10 MCB

FUNCTIONALITY OF THE SYSTEM

Case 1: S2=0 & S1=0

S2
S1
Above mentioned circuit is related to this position where neither S1 no
S2 is closed. Therefore, motor is in on situation.

S1
S2

Case 2: S2=1 & S1=0

S2
S1
When water is filling S2 become 1 position and S1 keep in 0
position. Therefore, motor is in keep on situation.

S1
S2
Case 3: S2=1 & S1=1
When both sensors reach to 1 motor off.
S1
S2

S2
S1

Case 4: S2=1 & S1=0

S2
S1
In this system the requirement is to keep the motor off when the water
level is falling and S1 become disconnected. (Latch operation) Therefore,
motor keeps off until the water level reaches to the S2 position.

S1
S2

Case 5: S1=0 & S2=0

S2
S1
After water level goes down and S2 loss their connections S2 become
open and again motor on.

S1
S2
 PROCEDURE OF THE IMPLEMENTATION
Step 1: Prepared the circuit diagram, connected all the components, and tested the working
principal of the relay.

Figure 1: Sensors after connecting to the relay

Figure 2: Testing circuit

Step 2: Implementation of the sensor part.

Figure 3: Cutting the conduit pipe to the Figure 4: Fixing the sensors to the pipe Figure 5: Finishing
required height
Step 03: Installed the MCB in the distribution board and wired the connection of the motor.

Figure 6: C10 MCB Figure 7: Installing the MCB to the

distribution board

Figure 9: Installing conduit pipes

Figure 8: Wired the connection of the motor

Step 04: Installed the socket outlets, 24DC power supply, Motor Controller, and the relay by
using an enclosure box.

Figure 10: Installing the socket outlets Figure 11: Installing the 24DC power supply, Motor Controller, and
the relay
Step 05: Fixed the sensors to the tank and did the finishing of the system.

Figure 12: Finalized control box and socket

outlets Figure 13: Tank and the installed sensors

BUDGET
ITEM NAME PRICE (Rs.)
220V MY2 Relay 260.00
24V Relay 8 pin 620.00
Silicon Gun 950.00
Floating Sensor Magnetic 2000.00
Silicon Gum 1175.00
230V/24V AC/DC converter 4200.00
Conduit pipes + casing 2000.00
Enclosure box + nails 600.00
Socket outlets 1500.00
Total 13,305.00
