Technical Sales Guide – 60Hz

DEH STELLAR MICRO SERIES

Air Cooled Packaged Air Conditioners

7.5 to 10TR - (R-410a)

MICRO SERIES
“Include YORK Simplicity Controller”
YORK STELLAR DEH MICRO SERIES

Table of Contents

DESCRIPTION ....................................................................................................................................................... 3
TYPICAL UNIT CONFIGURATION ...................................................................................................................... 3
FEATURES ........................................................................................................................................................ 4
OPTIONS AVAILABLE ....................................................................................................................................... 4
SELECTION METHOD ....................................................................................................................................... 6
PIN NUMBER GUILDLINES ............................................................................................................................. 7
PRODUCT DATA ............................................................................................................................................... 8
COOLING PERFORMANCE DATA ..................................................................................................................... 9
FAN PERFORMANCE DATA ............................................................................................................................ 18
DRIVE AND PULLEY DATA .............................................................................................................................. 19
ELECTRICAL DATA .......................................................................................................................................... 20
DIMENSIONAL DATA ..................................................................................................................................... 22
TYPICAL WIRING DIAGRAM ........................................................................................................................... 25

GUIDE SPECIFICATION ....................................................................................................................................... 26

DESCRIPTION ................................................................................................................................................ 26
UNIT CABINET AND FRAME ........................................................................................................................ 26
INDOOR (EVAPORATOR) FAN ASSEMBLY ...................................................................................................... 26
OUTDOOR (CONDENSER) FAN ASSEMBLY .................................................................................................... 26
REFRIGERANT COMPONENTS ....................................................................................................................... 26

MAINTENANCE .................................................................................................................................................. 27
EVERY MONTH .............................................................................................................................................. 27
EVERY 3 MONTHS ......................................................................................................................................... 27
EVERY SIX MONTHS ....................................................................................................................................... 27
EVERY 12 MONTHS ....................................................................................................................................... 27

TEH-7.510R2-60-0920 2
YORK STELLAR DEH MICRO SERIES

DESCRIPTION
Models DEH 90,100,120 (7.5,8.3 &10 Nominal Tons).

YORK STELLAR Units are single package energy efficient high ambient rooftops air conditioner. All Models have one refrigerant circuit that operates
efficiently. STELLAR units are designed for roof top slab mounted at ground level or on steel platform installation above floor or roof.
A wide range of factory mounted options and field installed accessories make the STELLAR units suitable for almost every application.

YORK STELLAR units are designed to operate satisfactorily in wide range of ambient temperatures from 131°F (55°C) down to 50°F (10°C) as standard.

YORK STELLAR packaged air conditioners are rated in accordance with ARI 340/360.

All standard units include:

• Powder paint finish that meets ASTM B 117, 750 hour salt spray standard.
• Single stage cooling with expansion valves, filter drier, high and low pressure switches and
freezestats.
• High efficiency hermetic scroll compressors.
• Side air discharge configuration.
• Belt drive blower motor with variable pitch pulley.
• Totally Enclosed Fan Cooled (TEFC) IP55 Evaporator fan motors with Class F Insulation.
• Totally Enclosed Air over (TEAO) IP55 Condenser fan motors with Class F Insulation.
• Microprocessor based Simplicity TM control board.
• Fresh air intake panel.
• Copper tubes / Aluminum fins evaporator coil.
• Microchannel condenser coil.
• 2 inch disposable filter with easy access.
• Rigging holes in base rails for overhead lifting.
• Single point power connection.
• Complete factory package-tested, charged and wired.
`TYPICAL UNIT CONFIGURATION

Typical unit configuration.

TEH-7.510R2-60-0920 3
YORK STELLAR DEH MICRO SERIES
FEATURES
Stellar units are self-contained and assembled on full perimeter base
rails with rigging holes in the four corners for overhead rigging. Every
unit is completely piped, wired, charged and tested at the factory to
simplify the field installation and to provide years of dependable
operation. All models are suitable for horizontal duct connections.The
power supply can be routed into the control box through a gland in the
wiring panel on the front of the unit.
Compressors are scroll type of an advanced design ensuring high
Energy Efficiency Ratio, less noise, less vibration and outstanding
endurance. Crankcase heaters, internal pressure relief valve, internal
compressor motor protection.
Every refrigerant circuit includes an expansion valve, a liquid line filter
drier, a discharge line high pressure switch and suction line freezestat
and low pressure switch to protect all system components.Each supply
air blower is equipped with a belt drive that can be adjusted to meet the
exact requirements of the application.A high or low static drive option is
available for applications with a higher or lower airflow and / or static
pressure requirement. All evaporator blower motors are weatherproof
TEFC IP55 with Class F insulation.
A fixed outdoor air intake connection that is designed for 25% fresh air
is available as standard.
Fresh air dampers are optional for field / factory installation.
Condenser fans are propeller type of heavy duty construction,
dynamically balanced and suitable for operate up to 80°C ambient.
Fans are driven by TEAO IP55 motors with Class F insulation. The fan
blade pitch Angle is designed for maximum airflow and minimum
noise.
The evaporator coils are constructed of seamless internally
enhanced copper tubes which are mechanically bonded to
aluminum fins. Heat Exchangers are tested up to a pressure of
250 psig (evaporator) .
A nonmetallic drain pan with bottom condensate removal ensures
zero water retention and no corrosion that ensures indoor air quality
(IAQ).
All units have long lasting powder paint cabinets with a robust
40 microns thick paint coating that meets ASTM- B-117
standards and suitable for 750 hour salt spray test, ensuring
excellent resistance to corrosion in the harshest conditions.
The cabinet of all Stellar is internally lined by 13mm
Elastomeric insulation that minimize heat gain and improves IAQ.
All Stellar units are equipped with a control panel that includes all
the necessary operating and safety controls that are needed for
reliable operation. Compressors are protected with internal
thermal overload and fan motors with external overload.
Transformers and control circuits are protected with fuses.
TEH-7.510R2-60-0920
The operation of the package units is masterminded by the
microprocessor based Simplicity™ control board which provides both
intelligent monitoring and easy Diagnostics, as featured below:
Anti-Short Cycle Protection: To aid compressor life, an anti-short cycle
delay is incorporated into the standard controls. Compressor reliability
is further ensured by programmable minimum run times.
Fan Delays: Fan on and fan off delays are fully Programmable. All units
are programmed with default values based upon their configuration of
cooling and heating.
Safety Monitoring: High flow pressure switches and suction line
freezestats are supplied on all units to protect against loss of charge and
the occurrence of coil frosting. The control board monitors the high and
low pressure switches and the freezestats. The unit control board will
alarm on compressor lockouts and repeated limit switch trips on electric
heat units.
Nuisance Trip Protection: To prevent nuisance Trouble calls.The high
and low-pressure switches and the freeze stats must trip three times
with- in two hours before the unit control board will lock out the
associated compressor.
On Board Diagnostics: Each alarm will energize an error on UCB LCD,
Each high and low-pressure switch alarm as well as each freezestat
alarm has its own error code. The control board saves the five most
recent alarms in memory, and these alarms can be reviewed at any
time.
OPTIONS AVAILABLE
• Heresite Coated Evaporator and Condenser Coils (factory
installed): Coating is applied by spray for maximum
corrosion protection.
• Copper Tube and Copper Fin Evaporator Coils (factory
installed).
• E-Coating Condenser Coils (factory installed).
• Filter Options: Standard units are shipped, installed with 2”
throw away filters. 2” washable aluminum filters are offered
as a factory installed option.
• Bag Filters (factory installed): Units can be supplied with
standard size bag filters, depth 22” and efficiency 65%, 85%
& 95%. For this option, add 800 mm in unit length.
• High And Low Speed Drive (factory installed) : Includes a
belt and blower pulley to upgrade or down-grade the blower
performance.
• Fresh Air Dampers: Manual or motorized
4
YORK STELLAR DEH MICRO SERIES
• Electric Heaters: All electric heat models (heater factory/field
installed only) are wired for a single power source and
include a bank of nickel chromium elements to be mounted
at the discharge of the supply air blower to provide a high
velocity and uniform distribution of air across the heating
elements. Every element is fully protected against excessive
current and temperature by high temperature thermal cut-
out (HTIC).
• Phase Monitors (factory installed): Design to prevent unit
damage, the phase monitor will shut the unit down in an out
of phase condition.
• Main Disconnect Switch (factory installed): Suitably sized in
accordance with the applicable electrical codes.
• Thermostat (field installed): For single stage cooling and a
single stage heating.
TEH-7.510R2-60-0920
• BMS Controls: York’s stellar series units offer factory
mounted BMS controls-consult your local sales office for
details.
• Low Ambient Kit (factory installed): For unit to work
satisfactorily down to 32°F (0°C).
• Smoke Detectors for supply air & return air (factory
installed): The smoke detectors stop operation of the unit by
interrupting power to the control board if smokes detected
within the air compartment.
• Ultra violet Lamps: Factory Installed.
• Economizer (factory installed): Stellar units offer an optional
factory installed economizer with low leak dampers, single
enthalpy and double enthalpy controls. When selecting this
option, add 1100mm in unit length.
5
YORK STELLAR DEH MICRO SERIES

SELECTION METHOD
Step 2: For the sensible capacity read the value at the Intersection of
The following steps illustrate the selection of a DEH Package Unit for a
the same row (as the WB in step1 and the 80° DB column on the right.
Total Capacity requirement of 105MBh and an Airflow rate of 3000cfm.
The Sensible capacity for the unit in this example is 72.4MBh
The unit operating Parameters are:
Entering Air Temperature: 80/67°F (DB/WB)
Step 3: Refer “Fan Performance Data” on page 18 to check the motor
Ambient Temperature: 95°F Fan External
size and fan rpm. Scroll down the “1.0 inch wg ESP” column to the 3000
Static Pressure: 1.0 inch wg.
cfm row for DEH100. The fan speed is 781rpm and fan power input
0.83Kw.In this example standard 1.1 Kw motor will be required.
Step 1: Select the unit model by referring to “Cooling Performance data”
table for 95°F ambient on Page12 Scroll down the “Total capacity” and
Step 4: To arrive at the correct drive set to be ordered the unit, refer
“Entering Air WBT” columns until 105 MBH with (or a value close to it)
“Drive & Pulley Data” on page 19 the fan rpm from step 3 to select the
is found at 67°F WB For an airflow 3000 cfm The selected model is
correct drive set. The package unit in this example will required a
DEH-100 giving total Capacity 104.7 MBH with the actual compressor
standard drive set.
power input being 7.3Kw.

TEH-7.510R2-60-0920 6
YORK STELLAR DEH MICRO SERIES

PIN NUMBER GUILDLINES

D E H 120 C02 A 2 A 1 1

Series Name Product Generation

D = A/C,Single Package, 1 = First generation
R‐410a

E = Energy Efficient Field Installed Options

(SASO Compliant) 1 = No option installed
2 = 9 Kw electric heater
3 = 18 Kw electric heater
H = High Ambient Operation 4 = Fresh air damper
HD = High Amb.Operation Double Skin

Nominal Cooling Capacity Factory Installed Options

090 = 7.5 Tons A = No option installed
100 = 8.5Tons B = Heresite Coating on Condenser coil
120 = 10 Tons C = Heresite Coating on Evaporator Coil
D = 2" Aluminum Washable Filter
E =E-Coating on Condenser Coil
F = Cu / Cu on Evaporator Coil
G = Disconnect Switch
H = Phase Monitor
I = BMS
Mode J = High Speed Drive
C02 = Cooling only [R410a] K = Low Speed Drive
L = UV Lamp(Double Skin)
M = Dirty Filter Switch
Motor Options N = Low Ambient Kit
A = Standard motor P = Smoke Detector(Double Skin)
B = Over size motor Q = 9 KW Heater
R = 18 KW Heater
S = Mixing Box(Double skin)
Power Supply T = Temperature Economizer (Double Skin)
1 = 230V /3Ph / 60Hz U = Enthalpy Economizer (Double Skin)
2 = 400V /3Ph / 60Hz V = Bag Filter 85% Effcy.(Double Skin)
3 = 460V /3Ph / 60Hz W = Moisture Eliminator(Double Skin)
X = VFC for comp. (status on/off)
Z = Fresh Air Damper

TEH-7.510R2-60-0920 7
YORK STELLAR DEH MICRO SERIES

PRODUCT DATA
Model DEH 90 100 120
Gross Capacity MBH(KW) 94.88 (27.81) 106.22 (31.13) 124.82 (36.58)
Net EER MBH/KW 11.35 11.37 11.35
Rating @ ARI Conditions Capacity (NET) MBH(KW) 92.84 (27.21) 103.42 (30.31) 121.34 (35.56)
Compressor Power
HP(KW) 8.94 (6.67) 9.87 (7.36) 11.22 (8.37)
Input
Capacity (Gross) MBH(KW) 94.00 (27.55) 105.00 (30.77) 123.00 (36.05)
(T1 Condition) 95°F (35°C)
Outdoor Ambient Capacity (Net) MBH(KW) 92.00 (26.96) 102.00 (29.89) 120.00 (35.17)
Temperature @
80.6°F DB / 66.2°F WB Total Power Input HP(KW) 10.97 (8.18) 12.16 (9.07) 14.36 (10.71)
(27°C DB /
19°C WB) Indoor air EER (Gross) MBH/KW 11.49 11.58 11.48
Temperature
EER (Net) MBH/KW 11.25 11.25 11.2

Capacity (Gross) MBH(KW) 83.96 (24.61) 93.39 (27.53) 109.29 (32.03)

(T3 Condition) 115°F
(46.1°C)
Capacity (Net) MBH(KW) 81.81 (24.00) 90.49 (26.52) 105.70 (30.98)
Outdoor Ambient
Temperature @
Total Power Input HP(KW) 13.10 (9.77) 14.67 (10.94) 17.21 (12.83)
84.2°F DB / 66.2°F WB
(29°C DB /
EER (Gross) MBH/KW 8.59 8.54 8.52
19°C WB) Indoor air
Temperature MBH/KW
EER (Net) 8.37 8.27 8.24
Option 1 (KW) 9 9 9
Heating Capacities
Option 2 (KW) 18 18 18
Tube/Fins 3/8" copper Tube / Aluminum Fins
Evaporator Coil Fins fpi 14 12 12
2
Area ft 12.25 12.25 13.42
Tube/Fins 2pass - MCHE
Condenser Coil Fins fpi 23 23 23
2
Area ft 25.36 25.36 25.36
Fan Type Forward Curved Centrifugal - Belt Drive
Fan QTY NOS. 1 1 1
Blower Fan & Motor Motor Type 4 Pole, Class F insulation, Totally Enclosed Fan Cooled, IP55, 1725 rpm
std 1.1 1.1 1.5
Motor Size KW
xtd 2.2 2.2 2.2
Type 3 & 4 Blades heavy duty Propeller Fan
Quantity NOS. 2 2 2
Condenser Fan & Motor Motor Type 6 Pole, Class F insulation, Totally Enclosed Air Over, IP55
Motor Size KW 0.55 0.55 0.55
Quantity NOS. 2 2 2
Type Hermatic Scroll
Compressor
Quantity NOS. 1 1 1
Type R410a
Refrigerant No of Circuits NOS. 1 1 1
Charge lbs(kgs) 8.96 (4.1) 10.93 (5.0) 12.06 (5.5)
Height inches(mm) 48 (1225) 48 (1225) 48 (1225)
Dimensions Width inches(mm) 68 (1729) 68 (1729) 70 (1778)
Length inches(mm) 70 (1799) 70 (1799) 74 (1872)
Type Washable Disposable Filters
H X L X D- Qty Inches 24X24X2" -1 24X24X2" - 2
Filters
H X L X D- Qty Inches 20X24X2" -2 20X24X2" - 2
H X L X D- Qty Inches 20X20X2" -1 \
Weights Basic Unit lbs(kgs) 1175 (533) 1230 (558) 1310 (594)

TEH-7.510R2-60-0920 8
YORK STELLAR DEH MICRO SERIES

COOLING PERFORMANCE DATA

DEH090
Ambient 85°F (29.4°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 90.3 6.0 67.8 72.9 77.5 81.5 84.8 87.4
64.5 93.8 6.0 60.4 66.3 71.7 76.6 80.9 84.7
2600 67 97.6 6.0 52.5 58.9 64.8 70.4 75.5 80.1
69.5 101.4 6.0 44.4 51.1 57.4 63.4 69.0 74.3
72 105.1 6.0 36.3 43.2 49.8 56.1 62.1 67.8
62 91.3 6.0 70.9 76.1 80.6 84.4 87.5 89.8
64.5 94.9 6.0 63.3 69.4 74.9 79.8 84.1 87.8
2800 67 98.7 6.0 55.0 61.6 67.9 73.6 78.8 83.5
69.5 102.4 6.0 46.3 53.4 60.1 66.4 72.2 77.6
DEH090 72 106.1 6.0 37.6 45.0 52.0 58.7 65.0 70.9
60Hz 62 92.2 6.0 73.7 79.0 83.4 87.1 89.8 91.7
64.5 95.9 6.0 66.0 72.3 77.9 82.9 87.1 90.6
3000 67 99.6 6.0 57.3 64.3 70.7 76.6 81.9 86.6
69.5 103.3 6.0 48.2 55.6 62.7 69.2 75.3 80.8
72 107.1 6.0 38.9 46.7 54.2 61.2 67.8 74.0
62 93.0 6.0 76.5 81.7 86.0 89.4 91.8 93.0
64.5 96.8 6.0 68.7 75.1 80.8 85.7 89.8 93.0
3200 67 100.5 6.0 59.6 66.9 73.5 79.5 84.9 89.5
69.5 104.2 6.0 50.0 57.9 65.2 72.0 78.2 83.8
72 108.0 6.0 40.1 48.4 56.3 63.7 70.5 76.9
Ambient 95°F (35°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 86.2 6.6 66.3 71.3 75.6 79.2 82.2 84.4
64.5 89.6 6.6 59.2 64.9 70.1 74.7 78.8 82.4
2600 67 93.1 6.7 51.4 57.6 63.4 68.8 73.7 78.2
69.5 96.5 6.7 43.3 49.9 56.2 62.0 67.5 72.6
72 100.0 6.7 35.2 42.1 48.7 54.9 60.8 66.3
62 87.1 6.6 69.2 74.2 78.4 81.9 84.6 86.4
64.5 90.6 6.6 62.0 67.8 73.2 77.8 81.9 85.2
2800 67 94.0 6.7 53.8 60.3 66.4 71.9 76.9 81.3
69.5 97.5 6.7 45.2 52.2 58.8 64.9 70.6 75.8
DEH090 72 100.9 6.7 36.5 43.8 50.8 57.4 63.6 69.3
60Hz 62 87.8 6.6 72.0 76.9 81.0 84.3 86.6 87.8
64.5 91.4 6.6 64.6 70.6 76.0 80.7 84.6 87.7
3000 67 94.9 6.7 56.1 62.9 69.2 74.8 79.9 84.3
69.5 98.3 6.7 47.0 54.4 61.3 67.7 73.5 78.8
72 101.8 6.7 37.7 45.6 52.9 59.8 66.3 72.3
62 88.5 6.6 74.5 79.4 83.3 86.2 88.1 88.5
64.5 92.1 6.7 67.1 73.3 78.7 83.3 87.0 89.8
3200 67 95.6 6.7 58.3 65.4 71.8 77.6 82.6 86.9
69.5 99.1 6.7 48.8 56.6 63.7 70.3 76.3 81.7
72 102.6 6.7 39.0 47.2 55.0 62.2 68.9 75.1

TEH-7.510R2-60-0920 9
YORK STELLAR DEH MICRO SERIES

Ambient 105°F (40.6°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 81.3 7.4 64.5 69.1 73.1 76.3 78.9 80.6
64.5 84.5 7.4 57.7 63.2 68.1 72.5 76.2 79.4
2600 67 87.7 7.4 50.0 56.1 61.8 66.9 71.6 75.7
69.5 91.0 7.4 42.1 48.6 54.7 60.4 65.7 70.6
72 94.1 7.5 34.0 40.8 47.3 53.4 59.1 64.5
62 82.0 7.4 67.2 71.8 75.6 78.7 80.8 82.0
64.5 85.3 7.4 60.3 65.9 71.0 75.3 78.9 81.8
2800 67 88.6 7.4 52.4 58.7 64.6 69.9 74.6 78.7
69.5 91.8 7.5 43.9 50.8 57.2 63.2 68.6 73.6
DEH090 72 95.0 7.5 35.2 42.5 49.4 55.8 61.9 67.5
60Hz 62 82.7 7.4 69.7 74.3 77.9 80.6 82.4 82.7
64.5 86.1 7.4 62.8 68.6 73.6 77.9 81.4 84.0
3000 67 89.3 7.4 54.6 61.2 67.2 72.6 77.3 81.3
69.5 92.5 7.5 45.7 52.9 59.6 65.8 71.4 76.5
72 95.8 7.5 36.5 44.2 51.5 58.2 64.5 70.3
62 83.4 7.4 72.2 76.6 80.0 82.4 83.4 83.4
64.5 86.7 7.4 65.2 71.1 76.1 80.3 83.5 85.7
3200 67 90.0 7.4 56.7 63.6 69.8 75.2 79.9 83.7
69.5 93.2 7.5 47.4 55.0 62.0 68.4 74.1 79.1
72 96.4 7.5 37.7 45.8 53.4 60.5 67.0 72.9
Ambient 115°F (46.1°C)
Air Flow Entering Air Total Comp. Gross Sensible Capacity
Model
Rate WBT Capacity Power Input 76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 76.8 8.1 62.6 67.0 70.6 73.5 75.6 76.8
64.5 80.0 8.2 56.2 61.5 66.2 70.3 73.7 76.5
2600 67 83.1 8.2 48.8 54.8 60.2 65.2 69.6 73.4
69.5 86.2 8.2 41.0 47.4 53.4 58.9 64.1 68.7
72 89.1 8.2 32.9 39.7 46.1 52.1 57.7 62.9
62 77.5 8.1 65.2 69.5 73.0 75.5 77.2 77.5
64.5 80.7 8.2 58.8 64.2 68.9 72.9 76.2 78.7
2800 67 83.8 8.2 51.1 57.3 62.9 68.0 72.4 76.2
69.5 86.8 8.2 42.7 49.5 55.8 61.6 66.8 71.5
DEH090 72 89.9 8.2 34.1 41.4 48.1 54.5 60.3 65.7
60Hz 62 78.2 8.1 67.7 71.8 75.0 77.2 78.2 78.2
64.5 81.4 8.2 61.2 66.7 71.4 75.3 78.3 80.4
3000 67 84.4 8.2 53.2 59.6 65.4 70.5 74.9 78.5
69.5 87.5 8.2 44.5 51.6 58.2 64.1 69.5 74.2
72 90.6 8.2 35.3 43.0 50.1 56.8 62.9 68.4
62 78.7 8.1 69.9 73.9 76.8 78.5 78.7 78.7
64.5 82.0 8.2 63.5 69.1 73.7 77.4 80.1 81.8
3200 67 85.1 8.2 55.3 62.0 67.9 73.0 77.3 80.7
69.5 88.1 8.2 46.2 53.6 60.4 66.6 72.0 76.8
72 91.1 8.2 36.5 44.6 52.1 59.0 65.3 71.0

TEH-7.510R2-60-0920 10
YORK STELLAR DEH MICRO SERIES

Ambient 125°F (51.7°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 71.4 9.0 60.3 64.3 67.4 69.7 71.2 71.4
64.5 74.4 9.0 54.4 59.4 63.7 67.4 70.4 72.7
2600 67 77.4 9.1 47.3 53.0 58.2 62.9 67.0 70.5
69.5 80.3 9.1 39.6 45.9 51.7 57.1 61.9 66.3
72 83.0 9.1 31.6 38.3 44.6 50.5 55.9 60.9
62 71.9 9.0 62.6 66.4 69.3 71.2 71.9 71.9
64.5 75.1 9.1 56.8 61.9 66.2 69.8 72.5 74.4
2800 67 78.0 9.1 49.4 55.4 60.8 65.5 69.5 72.8
69.5 80.9 9.1 41.3 48.0 54.0 59.6 64.6 68.9
DEH090 72 83.7 9.1 32.8 40.0 46.6 52.8 58.4 63.6
60Hz 62 72.9 9.0 65.0 68.7 71.3 72.8 72.9 72.9
64.5 75.6 9.1 59.1 64.2 68.4 71.8 74.2 75.6
3000 67 78.6 9.1 51.5 57.7 63.2 67.9 71.8 74.9
69.5 81.5 9.1 43.0 50.0 56.3 62.0 67.0 71.4
72 84.3 9.1 34.0 41.5 48.5 55.0 60.8 66.1
62 73.9 9.0 67.3 70.8 73.1 73.9 73.9 73.9
64.5 76.1 9.1 61.2 66.3 70.4 73.5 75.5 76.1
3200 67 79.2 9.1 53.6 59.9 65.5 70.1 73.9 76.8
69.5 82.1 9.1 44.7 52.0 58.5 64.3 69.4 73.7
72 84.8 9.1 35.2 43.1 50.4 57.1 63.1 68.5

TEH-7.510R2-60-0920 11
YORK STELLAR DEH MICRO SERIES

DEH100
Ambient 85°F (29.4°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 98.3 6.5 70.6 76.1 81.1 85.5 89.4 92.7
64.5 102.6 6.5 62.9 69.1 74.8 80.0 84.8 89.2
2600 67 107.0 6.6 54.8 61.4 67.6 73.4 78.8 83.9
69.5 111.4 6.6 46.6 53.4 60.0 66.2 72.1 77.6
72 116.1 6.6 38.5 45.6 52.3 58.8 65.0 70.9
62 100.9 6.5 77.1 82.8 87.9 92.2 95.8 98.5
64.5 105.3 6.5 68.9 75.5 81.6 87.1 91.9 96.1
3000 67 109.6 6.6 59.9 67.1 73.9 80.2 85.9 91.2
69.5 114.2 6.6 50.6 58.3 65.5 72.4 78.8 84.8
DEH100 72 118.7 6.6 41.3 49.3 56.9 64.2 71.0 77.5
60Hz 62 102.5 6.5 81.6 87.4 92.4 96.5 99.6 101.8
64.5 106.9 6.5 73.1 80.0 86.3 91.8 96.6 100.5
3300 67 111.2 6.6 63.5 71.2 78.3 84.9 90.8 96.0
69.5 115.8 6.6 53.5 61.7 69.5 76.8 83.5 89.7
72 120.4 6.6 43.3 52.0 60.2 68.0 75.3 82.2
62 104.3 6.5 88.1 93.9 98.5 101.9 104.0 104.3
64.5 109.0 6.6 79.6 86.9 93.2 98.6 103.0 106.3
3800 67 113.4 6.6 69.2 77.6 85.2 92.1 98.1 103.2
69.5 117.9 6.6 58.0 67.2 75.8 83.6 90.7 97.2
72 122.5 6.6 46.4 56.2 65.5 74.1 82.0 89.4
Ambient 95°F (35°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 94.1 7.2 69.1 74.5 79.2 83.4 87.0 90.0
64.5 98.2 7.3 61.7 67.7 73.2 78.3 82.9 87.0
2600 67 102.4 7.3 53.7 60.2 66.2 71.9 77.2 82.1
69.5 106.6 7.4 45.6 52.3 58.8 64.9 70.6 76.0
72 111.1 7.4 37.5 44.5 51.2 57.6 63.7 69.5
62 96.5 7.3 75.4 80.9 85.7 89.7 92.9 95.2
64.5 100.7 7.3 67.5 74.0 79.8 85.1 89.6 93.5
3000 67 104.7 7.3 58.6 65.8 72.4 78.5 84.0 89.0
69.5 109.1 7.4 49.5 57.1 64.2 70.9 77.2 82.9
DEH100 72 113.4 7.4 40.2 48.1 55.7 62.8 69.6 75.9
60Hz 62 97.7 7.3 79.6 85.1 89.7 93.4 96.1 97.6
64.5 102.1 7.3 71.6 78.3 84.3 89.5 93.9 97.5
3300 67 106.2 7.4 62.2 69.7 76.7 83.0 88.7 93.6
69.5 110.5 7.4 52.3 60.4 68.1 75.2 81.7 87.6
72 114.9 7.4 42.1 50.8 58.9 66.6 73.8 80.5
62 99.3 7.3 85.8 91.1 95.2 98.0 99.3 99.3
64.5 103.8 7.3 77.8 84.8 90.8 95.8 99.7 102.4
3800 67 108.2 7.4 67.8 76.0 83.3 89.9 95.5 100.2
69.5 112.5 7.4 56.7 65.8 74.2 81.8 88.7 94.8
72 116.8 7.5 45.2 54.9 64.0 72.5 80.3 87.4

TEH-7.510R2-60-0920 12
YORK STELLAR DEH MICRO SERIES

Ambient 105°F (40.6°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 88.8 8.1 67.3 72.3 76.8 80.7 83.8 86.3
64.5 92.7 8.2 60.1 65.9 71.3 76.1 80.4 84.1
2600 67 96.6 8.2 52.3 58.6 64.5 70.0 75.1 79.7
69.5 100.6 8.3 44.2 50.9 57.2 63.2 68.8 74.0
72 104.6 8.3 36.2 43.1 49.7 56.0 62.0 67.7
62 90.8 8.1 73.2 78.3 82.7 86.2 88.8 90.5
64.5 94.8 8.2 65.7 71.9 77.5 82.4 86.5 89.9
3000 67 98.7 8.2 57.1 64.0 70.5 76.3 81.6 86.2
69.5 102.8 8.3 48.0 55.5 62.5 69.0 75.1 80.6
DEH100 72 106.8 8.4 38.8 46.7 54.1 61.2 67.7 73.9
60Hz 62 91.8 8.1 77.1 82.1 86.2 89.3 91.3 91.8
64.5 96.2 8.2 69.6 76.1 81.7 86.5 90.4 93.5
3300 67 100.0 8.3 60.5 67.9 74.6 80.6 85.9 90.4
69.5 104.0 8.3 50.8 58.8 66.3 73.1 79.4 85.0
72 108.1 8.4 40.7 49.2 57.3 64.8 71.8 78.2
62 94.0 8.2 83.2 88.0 91.5 93.7 94.0 94.0
64.5 97.7 8.2 75.5 82.1 87.7 92.1 95.4 97.4
3800 67 101.7 8.3 65.9 73.8 80.9 87.0 92.2 96.3
69.5 105.7 8.3 55.1 64.0 72.1 79.4 86.0 91.7
72 109.8 8.4 43.7 53.3 62.3 70.5 78.1 84.9
Ambient 115°F (46.1°C)
Air Flow Entering Air Total Comp. Gross Sensible Capacity
Model
Rate WBT Capacity Power Input 76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 84.0 9.0 65.5 70.3 74.5 78.0 80.8 82.8
64.5 87.8 9.0 58.7 64.3 69.4 74.0 78.0 81.3
2600 67 91.5 9.1 51.0 57.2 62.9 68.3 73.1 77.5
69.5 95.2 9.2 43.0 49.6 55.8 61.7 67.1 72.1
72 99.0 9.2 35.0 41.9 48.4 54.6 60.5 66.0
62 85.6 9.0 71.0 75.8 79.7 82.8 84.8 85.6
64.5 89.7 9.1 64.0 70.0 75.3 79.8 83.6 86.5
3000 67 93.4 9.1 55.7 62.5 68.7 74.3 79.2 83.5
69.5 97.1 9.2 46.7 54.1 61.0 67.3 73.1 78.4
DEH100 72 100.9 9.3 37.6 45.4 52.7 59.6 66.0 72.0
60Hz 62 86.7 9.0 74.7 79.4 83.0 85.5 86.7 86.7
64.5 90.8 9.1 67.8 73.9 79.2 83.6 87.0 89.5
3300 67 94.5 9.2 59.0 66.1 72.6 78.3 83.2 87.3
69.5 98.4 9.2 49.4 57.3 64.6 71.3 77.3 82.6
72 102.0 9.3 39.4 47.8 55.8 63.1 69.9 76.1
62 89.6 9.1 80.9 85.3 88.3 89.6 89.6 89.6
64.5 92.1 9.1 73.4 79.6 84.6 88.5 91.1 92.1
3800 67 96.0 9.2 64.2 71.9 78.6 84.3 88.9 92.5
69.5 99.8 9.2 53.7 62.4 70.2 77.3 83.5 88.7
72 103.6 9.3 42.4 51.9 60.7 68.7 76.0 82.5

TEH-7.510R2-60-0920 13
YORK STELLAR DEH MICRO SERIES

Ambient 125°F (51.7°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 78.2 10.0 63.2 67.7 71.4 74.4 76.6 78.1
64.5 82.0 10.1 56.9 62.2 67.1 71.3 74.9 77.8
2600 67 85.4 10.2 49.4 55.5 61.0 66.1 70.6 74.6
69.5 89.0 10.3 41.6 48.1 54.1 59.8 65.0 69.8
72 92.4 10.3 33.6 40.4 46.9 53.0 58.7 64.0
62 79.8 10.1 68.4 72.7 76.1 78.5 79.8 79.8
64.5 83.6 10.1 62.0 67.6 72.5 76.6 79.8 82.1
3000 67 87.1 10.2 54.0 60.5 66.4 71.7 76.3 80.1
69.5 90.6 10.3 45.2 52.4 59.1 65.2 70.7 75.6
DEH100 72 94.2 10.3 36.1 43.8 51.1 57.8 64.0 69.7
60Hz 62 81.7 10.1 72.3 76.5 79.6 81.5 81.7 81.7
64.5 84.4 10.2 65.4 71.2 75.9 79.8 82.5 84.2
3300 67 88.0 10.2 57.1 64.0 70.1 75.4 79.9 83.4
69.5 91.5 10.3 47.8 55.5 62.5 68.9 74.6 79.5
72 94.9 10.4 37.9 46.2 54.0 61.1 67.7 73.6
62 84.4 10.2 78.0 81.8 84.0 84.4 84.4 84.4
64.5 85.5 10.2 70.7 76.3 80.7 83.8 85.5 85.5
3800 67 89.4 10.3 62.2 69.5 75.7 80.9 84.9 87.8
69.5 92.9 10.3 51.9 60.4 67.9 74.6 80.3 85.0
72 96.3 10.4 40.8 50.1 58.7 66.5 73.4 79.5

TEH-7.510R2-60-0920 14
YORK STELLAR DEH MICRO SERIES

DEH120
Ambient 85°F (29.4°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 115.4 7.4 82.1 88.5 94.4 99.6 104.2 108.1
64.5 120.6 7.4 73.2 80.3 87.0 93.2 98.8 103.9
3000 67 125.8 7.4 63.8 71.4 78.6 85.4 91.8 97.7
69.5 131.2 7.5 54.4 62.3 69.8 77.1 83.9 90.4
72 137.0 7.5 45.1 53.3 61.1 68.6 75.8 82.7
62 118.2 7.4 88.7 95.4 101.4 106.6 110.9 114.3
64.5 125.6 7.4 79.9 87.6 94.8 101.3 107.2 112.3
3400 67 128.6 7.5 68.9 77.3 85.1 92.3 99.1 105.2
69.5 134.2 7.5 58.4 67.2 75.5 83.4 90.8 97.7
DEH120 72 140.1 7.5 48.0 57.1 65.8 74.1 82.0 89.4
60Hz 62 120.2 7.4 94.1 101.0 106.9 111.8 115.8 118.6
64.5 125.4 7.4 84.2 92.3 99.6 106.1 111.8 116.6
3750 67 130.7 7.5 73.3 82.1 90.4 98.0 105.0 111.2
69.5 136.3 7.5 61.8 71.3 80.3 88.6 96.5 103.7
72 142.1 7.5 50.3 60.2 69.7 78.6 87.1 95.0
62 122.0 7.4 100.3 107.2 112.9 117.3 120.4 122.0
64.5 127.5 7.5 90.3 98.7 106.2 112.7 118.1 122.4
4200 67 132.9 7.5 78.5 88.1 96.9 104.8 111.9 118.0
69.5 138.6 7.5 66.0 76.4 86.1 95.0 103.3 110.7
72 144.3 7.6 53.2 64.2 74.5 84.2 93.3 101.8
Ambient 95°F (35°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 110.3 8.2 80.4 86.6 92.2 97.2 101.4 104.9
64.5 115.3 8.3 71.7 78.7 85.2 91.2 96.6 101.4
3000 67 120.4 8.3 62.5 70.0 77.1 83.7 89.9 95.6
69.5 125.5 8.4 53.1 61.0 68.4 75.5 82.3 88.6
72 131.1 8.4 43.9 52.0 59.8 67.2 74.3 81.0
62 112.8 8.2 86.8 93.2 98.9 103.7 107.5 110.5
64.5 117.9 8.3 77.6 85.1 91.9 98.1 103.5 108.1
3400 67 122.9 8.4 67.5 75.7 83.3 90.4 96.9 102.7
69.5 128.2 8.4 57.1 65.8 74.0 81.7 88.9 95.6
DEH120 72 133.7 8.5 46.6 55.7 64.3 72.5 80.3 87.6
60Hz 62 114.6 8.3 91.9 98.4 103.9 108.4 111.8 114.0
64.5 119.8 8.3 82.5 90.3 97.4 103.5 108.8 113.2
3750 67 124.8 8.4 71.7 80.5 88.5 95.9 102.5 108.4
69.5 130.1 8.4 60.4 69.8 78.6 86.8 94.4 101.4
72 135.7 8.5 49.0 58.8 68.2 77.0 85.3 93.0
62 116.1 8.3 97.8 104.2 109.4 113.2 115.7 116.1
64.5 121.5 8.3 88.3 96.4 103.6 109.6 114.5 118.3
4200 67 126.7 8.4 76.9 86.2 94.7 102.3 109.0 114.8
69.5 132.1 8.4 64.5 74.7 84.2 93.0 100.9 108.1
72 137.6 8.5 51.8 62.7 72.9 82.5 91.4 99.6

TEH-7.510R2-60-0920 15
YORK STELLAR DEH MICRO SERIES

Ambient 105°F (40.6°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 104.0 9.2 78.2 84.1 89.3 93.9 97.7 100.7
64.5 108.8 9.3 69.9 76.7 82.9 88.5 93.6 98.0
3000 67 113.5 9.4 60.8 68.2 75.1 81.5 87.4 92.8
69.5 118.4 9.4 51.5 59.3 66.6 73.6 80.1 86.2
72 123.6 9.5 42.3 50.4 58.0 65.4 72.3 78.9
62 106.2 9.2 84.2 90.3 95.5 99.7 103.0 105.3
64.5 111.0 9.3 75.6 82.8 89.2 95.0 100.0 104.1
3400 67 115.7 9.4 65.7 73.7 81.1 87.9 94.0 99.5
69.5 120.8 9.5 55.4 64.0 72.0 79.5 86.5 93.0
DEH120 72 125.9 9.5 45.0 54.0 62.5 70.6 78.1 85.3
60Hz 62 107.6 9.3 89.0 95.0 100.0 103.8 106.5 107.6
64.5 112.7 9.3 80.2 87.7 94.3 100.1 104.8 108.6
3750 67 117.4 9.4 69.8 78.3 86.0 93.1 99.3 104.7
69.5 122.5 9.5 58.7 67.9 76.5 84.5 91.8 98.4
72 127.6 9.5 47.3 57.0 66.2 74.9 83.0 90.5
62 108.9 9.3 94.4 100.2 104.7 107.7 108.9 108.9
64.5 114.2 9.4 85.7 93.5 100.1 105.5 109.8 112.7
4200 67 119.2 9.4 74.8 83.8 92.0 99.2 105.4 110.5
69.5 124.2 9.5 62.7 72.7 81.9 90.4 98.0 104.7
72 129.4 9.6 50.0 60.8 70.9 80.2 88.9 96.7
Ambient 115°F (46.1°C)
Air Flow Entering Air Total Comp. Gross Sensible Capacity
Model
Rate WBT Capacity Power Input 76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 98.4 10.2 76.1 81.7 86.6 90.8 94.1 96.6
64.5 102.8 10.3 68.1 74.7 80.6 86.0 90.7 94.7
3000 67 107.4 10.4 59.3 66.5 73.2 79.4 85.1 90.2
69.5 112.0 10.5 50.1 57.8 65.0 71.8 78.1 84.0
72 116.8 10.5 40.9 48.9 56.5 63.7 70.5 76.9
62 100.1 10.3 81.8 87.4 92.2 95.9 98.6 100.1
64.5 104.9 10.4 73.6 80.6 86.7 92.1 96.6 100.3
3400 67 109.4 10.4 64.0 71.8 79.0 85.5 91.3 96.4
69.5 114.1 10.5 53.9 62.3 70.2 77.5 84.3 90.4
DEH120 72 119.0 10.6 43.5 52.4 60.8 68.8 76.2 83.1
60Hz 62 101.1 10.3 86.2 91.7 96.0 99.2 101.1 101.1
64.5 106.3 10.4 78.1 85.2 91.4 96.7 100.9 104.0
3750 67 110.8 10.5 68.0 76.2 83.7 90.4 96.2 101.2
69.5 115.5 10.5 57.1 66.1 74.5 82.2 89.2 95.5
72 120.3 10.6 45.7 55.4 64.5 72.9 80.8 88.0
62 103.7 10.3 91.9 97.2 101.0 103.4 103.7 103.7
64.5 107.7 10.4 83.4 90.7 96.8 101.7 105.2 107.4
4200 67 112.3 10.5 72.8 81.6 89.3 96.1 101.8 106.4
69.5 117.1 10.6 61.0 70.8 79.8 87.9 95.1 101.4
72 122.0 10.6 48.5 59.1 69.0 78.1 86.5 94.1

TEH-7.510R2-60-0920 16
YORK STELLAR DEH MICRO SERIES

Ambient 125°F (51.7°C)

Air Flow Entering Air Total Comp. Gross Sensible Capacity

Model
Rate WBT Capacity Power Input
76°F (24.4°C) 78°F (25.6°C) 80°F (26.7°C) 82°F (27.8°C) 84°F (28.9°C) 86°F (30°C)
cfm °F MBh kW MBh MBh MBh MBh MBh MBh
62 91.4 11.5 73.4 78.6 83.0 86.6 89.2 91.0
64.5 95.8 11.6 66.0 72.3 77.9 82.8 87.1 90.6
3000 67 100.0 11.7 57.4 64.4 70.9 76.8 82.1 86.8
69.5 104.4 11.8 48.4 55.9 63.0 69.5 75.6 81.2
72 108.8 11.9 39.2 47.1 54.6 61.7 68.3 74.5
62 92.6 11.5 78.6 83.6 87.7 90.6 92.5 92.6
64.5 97.5 11.6 71.2 77.7 83.4 88.3 92.2 95.1
3400 67 101.8 11.7 62.0 69.5 76.4 82.5 87.9 92.5
69.5 106.2 11.8 52.1 60.3 68.0 75.0 81.4 87.2
DEH120 72 110.7 11.9 41.8 50.6 58.9 66.6 73.8 80.4
60Hz 62 94.9 11.6 83.2 88.2 91.9 94.3 94.9 94.9
64.5 98.6 11.7 75.4 82.0 87.7 92.3 95.7 98.0
3750 67 103.0 11.7 65.8 73.7 80.8 87.0 92.3 96.6
69.5 107.4 11.8 55.1 64.0 72.1 79.5 86.1 91.9
72 111.9 11.9 43.9 53.5 62.4 70.6 78.2 85.1
62 97.6 11.6 88.7 93.3 96.4 97.6 97.6 97.6
64.5 99.8 11.7 80.3 87.0 92.4 96.5 99.1 99.8
4200 67 104.3 11.8 70.4 78.8 86.1 92.2 97.3 101.0
69.5 108.8 11.8 58.9 68.5 77.2 84.9 91.6 97.3
72 113.4 11.9 46.6 57.1 66.7 75.6 83.6 90.7

TEH-7.510R2-60-0920 17
YORK STELLAR DEH MICRO SERIES

FAN PERFORMANCE DATA

DEH90-EXTERNAL STATIC PRESSURE( Pa )

Air flow rate
50.00 100.00 150.00 200.00 250.00 300.00 350.00 400.00 450.00 500.00
cfm l/s RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW
2600 1225 459 0.27 542 0.36 619 0.46 690 0.56 757 0.66 820 0.78 880 0.90 935 1.01 988 1.13 1038 1.26
2800 1319 478 0.32 557 0.41 630 0.52 698 0.62 763 0.73 825 0.85 883 0.97 938 1.10 991 1.22 1041 1.36
3000 1413 496 0.37 571 0.47 641 0.57 707 0.69 770 0.81 830 0.93 887 1.05 941 1.19 993 1.32 1043 1.45
3200 1507 514 0.43 586 0.54 654 0.65 717 0.76 778 0.88 836 1.01 891 1.14 945 1.28 996 1.42 1045 1.56
Motor 1.1KW Motor 2.2KW

DEH100-EXTERNAL STATIC PRESSURE( Pa )

Air flow rate
50.00 100.00 150.00 200.00 250.00 300.00 350.00 400.00 450.00 500.00
cfm l/s RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW
2600 1225 473 0.28 555 0.37 631 0.47 701 0.57 768 0.69 830 0.798 889 0.92 944 1.04 996 1.16 1046 1.28
3000 1413 510 0.40 584 0.49 653 0.60 719 0.71 781 0.83 840 0.95 897 1.07 951 1.21 1002 1.34 1052 1.48
3300 1554 539 0.49 609 0.60 674 0.71 735 0.83 794 0.95 851 1.08 905 1.22 958 1.36 1008 1.50 1057 1.64
3800 1790 588 0.69 651 0.81 711 0.93 767 1.06 821 1.19 874 1.33 924 1.48 973 1.63 1021 1.78
Motor 1.1KW Motor 2.2KW

DEH120-EXTERNAL STATIC PRESSURE( Pa )

Air flow rate
50.00 100.00 150.00 200.00 250.00 300.00 350.00 400.00 450.00 500.00
cfm l/s RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW RPM KW
3000 1413 493 0.37 569 0.47 639 0.57 705 0.69 768 0.80 828 0.93 885 1.05 939 1.18 991 1.31 1041 1.45
3400 1601 529 0.50 599 0.60 664 0.72 725 0.84 783 0.96 840 1.09 894 1.23 946 1.37 997 1.51 1045 1.66
3750 1766 561 0.63 627 0.75 688 0.87 745 0.99 801 1.13 854 1.26 906 1.40 955 1.55 1004 1.70 1051 1.86
4200 1978 602 0.83 663 0.95 720 1.09 774 1.22 826 1.37 876 1.51 924 1.67 971 1.83
Motor 1.5KW Motor 2.2KW

TEH-7.510R2-60-0920 18
YORK STELLAR DEH MICRO SERIES

DRIVE AND PULLEY DATA

Low Static Drive Set

Motor Drive Package Pitch Fan Drive Package RPM Range Belt
Unit Model Pitch Dia.
Pulley Bush Min Max Pulley Bush Min Max Center Dist. Length
DEH090 1VL40 - 58.4 78.7 AK89 - 207.3 486 655 545 1532
DEH100 1VL40 - 58.4 78.7 AK84 - 207.3 518 698 545 1510
DEH120 1VL40 - 58.4 78.7 AK84 - 207.3 518 698 545 1510

Medium Static Drive Set

Motor Drive Package Pitch Fan Drive Package RPM Range Belt
Unit Model Pitch Dia.
Pulley Bush Min Max Pulley Bush Min Max Center Dist. Size
DEH090 1VL40 - 58.4 78.7 AK99 - 148.8 677 913 545 1656
DEH100 1VL40 - 58.4 78.7 AK99 - 148.8 677 913 545 1656
DEH120 1VL40 - 58.4 78.7 AK84 - 148.8 677 913 545 1554

High Static Drive Set

Motor Drive Package Pitch Fan Drive Package RPM Range Belt
Unit Model Pitch Dia.
Pulley Bush Min Max Pulley Bush Min Max Center Dist. Size
DEH090 1VM50 - 83.8 104.1 AK74 - 169.2 855 1062 545 1506
DEH100 1VM50 - 83.8 104.1 AK74 - 169.2 855 1062 545 1506
DEH120 1VM50 - 83.8 104.1 AK74 - 169.2 855 1062 545 1506

Drive and Pulley data

TEH-7.510R2-60-0920 19
YORK STELLAR DEH MICRO SERIES

ELECTRICAL DATA
Minimum Maximum Minimum Maximum
Standard oversized
Condenser Circuit Fuse / Circuit Fuse /
Compressor Blower Blower Electrical Heater
Motor Amperes Breaker Amperes Breaker
Model Power Qty Qty Motor (1) motor (2)
(1) Size (1) (2) Size (2)

RLA Each LRA Each FLA Each FLA FLA KW FLA STG Amps Amp Amps Amp

26 190 1 3.03 2 3.87 7.7 - 0 - 42.43 70 46.26 70

DEH 90 26 190 1 3.03 2 3.87 7.7 9K 22.6 1 42.43 70 46.26 70

26 190 1 3.03 2 3.87 7.7 18K 45 2 61.0875 70 65.875 70

31 250 1 3.03 2 3.87 7.7 - 0 - 48.68 80 52.51 80

DEH 100 230/3/60 31 250 1 3.03 2 3.87 7.7 9K 22.6 1 48.68 80 52.51 80

31 250 1 3.03 2 3.87 7.7 18K 45 2 61.0875 70 65.875 70

32 250 1 3.03 2 5.64 7.7 - 0 - 51.7 80 53.76 85

DEH 120 32 250 1 3.03 2 5.64 7.7 9K 22.6 1 51.7 80 53.76 85

32 250 1 3.03 2 5.64 7.7 18K 45 2 63.3 70 65.875 70

Minimum Maximum Minimum Maximum

Standard oversized
Condenser Circuit Fuse / Circuit Fuse /
Compressor Blower Blower Electrical Heater
Motor Amperes Breaker Amperes Breaker
Model Power Qty Qty Motor (1) motor (2)
(1) Size (1) (2) Size (2)

RLA Each LRA Each FLA Each FLA FLA KW FLA STG Amps Amp Amps Amp

14.4 110 1 1.1 2 2.6 5.1 - 0 - 22.8 35 25.3 40

DEH 90 14.4 110 1 1.1 2 2.6 5.1 9K 13 1 22.8 35 25.3 40

14.4 110 1 1.1 2 2.6 5.1 18K 26 2 35.75 40 38.875 40

17.5 155 1 1.1 2 2.6 5.1 - 0 - 26.675 45 29.175 45

DEH 100 400/3/60 17.5 155 1 1.1 2 2.6 5.1 9K 13 1 26.675 45 29.175 45

17.5 155 1 1.1 2 2.6 5.1 18K 26 2 35.75 40 38.875 40

19.2 155 1 1.1 2 3.2 5.1 - 0 - 29.4 45 31.3 50

DEH 120 19.2 155 1 1.1 2 3.2 5.1 9K 13 1 29.4 45 31.3 50

19.2 155 1 1.1 2 3.2 5.1 18K 26 2 36.5 40 38.875 40

TEH-7.510R2-60-0920 20
YORK STELLAR DEH MICRO SERIES

Minimum Maximum Minimum Maximum

Standard oversized
Condenser Circuit Fuse / Circuit Fuse /
Compressor Blower Blower Electrical Heater
Motor Amperes Breaker Amperes Breaker
Model Power Qty Qty Motor (1) motor (2)
(1) Size (1) (2) Size (2)

RLA Each LRA Each FLA Each FLA FLA KW FLA STG Amps Amp Amps Amp

13 100 1 1.8 2 2.05 4.3 - 0 - 21.9 35 24.15 35

DEH 90 13 100 1 1.8 2 2.05 4.3 9K 11.3 1 21.9 35 24.15 35

13 100 1 1.8 2 2.05 4.3 18K 22.6 2 30.8125 35 33.625 35

18 125 1 1.8 2 2.05 4.3 - 0 - 28.15 45 30.4 45

DEH 100 460/3/60 18 125 1 1.8 2 2.05 4.3 9K 11.3 1 28.15 45 30.4 45

18 125 1 1.8 2 2.05 4.3 18K 22.6 2 30.8125 35 33.625 35

18.5 125 1 1.8 2 3 4.3 - 0 - 29.725 45 31.025 50

DEH 120 18.5 125 1 1.8 2 3 4.3 9K 11.3 1 29.725 45 31.025 50

18.5 125 1 1.8 2 3 4.3 18K 22.6 2 32 35 33.625 35

Electrical Data

TEH-7.510R2-60-0920 21
YORK STELLAR DEH MICRO SERIES

DIMENSIONAL DATA
DEH90-100 (Single Skin)

TEH-7.510R2-60-0920 22
YORK STELLAR DEH MICRO SERIES

DEH120 (Single Skin)

TEH-7.510R2-60-0920 23
YORK STELLAR DEH MICRO SERIES

DEHD90-120 (Double Skin)

TEH-7.510R2-60-0920 24
YORK STELLAR DEH MICRO SERIES

TYPICAL WIRING DIAGRAM

DEH90-120

TEH-7.510R2-60-0920 25
YORK STELLAR DEH MICRO SERIES
GUIDE SPECIFICATION
DESCRIPTION
Standard Units shall be factory assembled, single packaged, cool only,
and designed for outdoor mounted installation. They shall have built-in
side duct connections for discharge supply and return. The units shall be
factory wired, piped, charged with R-410a refrigerant and factory tested
prior to shipment. All unit wiring shall be both numbered and color coded.
UNIT CABINET AND FRAME
Unit cabinet shall be constructed of G90 galvanized steel, with exterior
surfaces coated with a non-chalking, powdered paint finish, to meet
ASTM B117 Standards suitable for 750 hours salt spray test. The indoor
blower and air supply section shall be insulated with 13mm Elastomeric
insulation. Cabinet panels shall be easily removable for servicing and
maintenance. Full perimeter base rails shall be provided to assure
reliable transit of equipment, overhead rigging and fork lifting. Disposable
2” filters shall be furnished and be accessible through a removable
access door, sealed airtight. Condensate connection shall be minimum
of 1.0” FPT connection
INDOOR (EVAPORATOR) FAN ASSEMBLY
Fan shall be a belt drive assembly and include an adjustable pitch motor
pulley. Fan wheel shall be DIDW type with forward curved High static
blades, dynamically balanced to operate smoothly throughout the entire
range of operation. Airflow design shall be constant air volume. Bearings
shall be lubricated for life. The evaporator motor shall be TEFC IP55
class F insulation.
OUTDOOR (CONDENSER) FAN ASSEMBLY
Each unit shall have two condenser fans / motors. The outdoor fans shall
be of direct driven propeller type, discharge air vertically and shall be
dynamically balanced for smooth operation. The outdoor fan motors shall
be TEAO with class F insulation. Motors shall have permanently
lubricated bearings and shall have external overload protection.
REFRIGERANT COMPONENTS
Compressors:
a. Compressors for all models shall be Hermetic Scroll. All compressors
shall be internally protected with internal high pressure relief and over
temperature protection. The compressors shall be mounted on neoprene
mounts to eliminate vibration from being transmitted to the unit structure
and cabinet.
Coils:
a. Evaporator coils shall have aluminum fins mechanically bonded to
seamless internally enhanced copper tubes with all joints brazed
Condenser coils are microchannel coils made of a single material to
avoid galvanic corrosion due to dissimilar metals. The microchannel
maximizes condenser heat transfer, resulting in a smaller footprint, and
reduces refrigerant charge while fin spacing shall be limited to minimize
blockage and high pressure operating condition.
b. Evaporator and Condenser coils shall be of the direct expansion,
draw-thru, design. Coils shall be tested up to a pressure of 250 psig
(evaporator) and 630 psig (condenser).
TEH-7.510R2-60-0920
Refrigerant Circuit and Refrigerant Safety components shall include:
a) Thermostatic expansion valve with external equalizing line.
b) Filter drier to eliminate any moisture or foreign matter.
c) Accessible service gauge connections on both suction and
discharge lines to charge, evacuate, and measure
refrigerant pressure during any necessary servicing or
troubleshooting, without losing charge.
d) The refrigeration system shall provide at least 15°F of sub-
cooling at design conditions.
e) All models shall have 1 independent refrigerant circuits.
f) Unit shall operate with conventional thermostat designs and
have a low voltage terminal strip for easy hookup.
g) Unit control board shall have on-board diagnostics and fault
code display.
h) Standard controls shall include anti-short cycle and low
voltage protection, and permit cooling operation down to
50°F.
i) Control board shall monitor each refrigerant safety switch
independently.
j) Control board shall retain last 5 fault codes in non-volatile
memory, which will not be lost in the event of a power loss.
ELECTRIC HEATING-OPTIONAL:
Nickel chromium electric heating elements shall be provided
as required by the application with 2 stage control for 18 kW
or 36 kW capacities. The heating section shall have a primary
limit control(s) and automatic reset to prevent the heating
element system from operating at an excessive temperature.
Units with Electric Heating shall be wired for a single point
power supply.
UNIT OPERATING CHARACTERISTICS:
Unit shall be capable of starting and running at 131°F outdoor
temperature. The compressor, with standard controls, shall
be capable of operation down to 50°F outdoor temperature.
ELECTRICAL REQUIREMENTS:
All unit power wiring shall enter unit cabinet at a single factory
provided gland be capable of side entry.
26
YORK STELLAR DEH MICRO SERIES

MAINTENANCE
The DEH Stellar Packaged Air Conditioners are premium quality machines with very low maintenance requirements.
Compressors used in Packaged Units are of Scroll type and are charged with the correct amount of refrigerant and lubricating oil.
Unless there is a leak in the system, no topping up is generally required.

EVERY MONTH
• Remove the filters and blow compressed air over them to get rid of loose dust. Visually inspect the filter conditions, replace them with new ones
of same sizes if required.
• DEH Stellar Air Conditioners are provided with a specially designed drain pan, for proper maintenance check and clean blockages at drain
connections if any.

EVERY 3 MONTHS
• In addition to the monthly maintenance above, check the belt tension of evaporator fan. A correct tension is indicated when the belt has a
relaxation of approximately 10 mm to 13 mm when pressed lightly with a finger.

EVERY SIX MONTHS

In addition to the maintenance done every three months :

• The condenser coils should be cleaned by spraying water over it at low pressure or with a brush while ensuring that the fins are not damaged.
• Check all electrical connections and tighten them if required.
• Clean all accessible electrical panels of dirt and dust. Before cleaning the control panels , ENSURE that the electrical power to the unit is
switched off.

EVERY 12 MONTHS
In addition to the maintenance done every six months :

• Use a proper cleaning cloth to clean fan blades and motors.

• Ensure that the unit is working properly by checking, current, voltages, pressures and temperatures.
• Check the earthing or grounding of the unit.
• Check the exterior of the unit for any signs of corrosion. Even though it is highly unlikely, if any corrosion that is seen, should be removed by
proper sanding the surface. Repaint the unit with proper touch up paint, available from YORK®.
• Check the unit for any unusual vibrations or noise, locate the cause and rectify it by changing mounts, base.

TEH-7.510R2-60-0920 27
YORK STELLAR DEH MICRO SERIES

Johnson Controls provides comfortable environments wherever you

Live, Work or Travel

Whether you’re at home, in a car, or in an office or workplace, chances are there’s a Johnson
Controls product or service nearby, helping to make your environment more comfortable, safe and
sustainable.
Johnson Controls creates smart environments that improve the places where people spend most of
their time – their homes, workplaces and vehicles. We anticipate consumer needs, and then
integrate technologies, products and services to make life better and easier.
For Johnson Controls, sustain ability matters at every level and through our products, service
operations and community involvement, we promote the efficient use of resources to benefit all
people and the world. Our triple bottom line of sustain ability that is, economic prosperity,
environmental stewardship and social responsibility impacts each and every aspect of our business.
York products are now a premier brand manufactured by Johnson Controls. The acquisition of York,
gives us a unique insight into designing HVAC products that match your exact requirements. We
provide solutions for today's most critical concerns - energy efficiency, refrigerant alternatives and
indoor air quality.
Johnson Controls has a wide range of York products for residential, light commercial and
commercial applications. Our offering includes package & split air conditioners and heat pumps. In
addition, Johnson Controls offers chillers, air handling units, ventilation equipment and controls for
larger projects.
Our advanced technology is leading the way in developing efficient and environment friendly
solutions for your homes, offices and places of leisure.

Let us create the ideal environment for you

Technical Sales Guide # TEH-7.510R2-60-0920

We reserve the right to change in part or in whole the specifications without prior notice.

Al Salem Johnson Controls (Head Office)

P.O. Box 15019 Jeddah 21444
Kingdom of Saudi Arabia
Tel.: +966 12 690 0999
Fax: +966 12 690 0909

TEH-7.510R2-60-0920 28
