INSTALLATION SUBMITTAL

FCU&FANS

Project Name: King Abdullah International Gardens

Contractor: Zaid Alhussain

Date:19/2/2024

Sa.tso@hilti.com
 FCU&FAN INSTALLATION SUMMARY TABLE

total Weight S.F total Load Point Load Threaded rod type & Size Threaded rod Capacity Utilization Anchor type&size Anchor Capacity Utilization
Supporting type
KG % KN KN KN % KN %

Ceilling support 52 250% 1.30 0.33 AM-M8-4.6 7.8 7.80% HKD- drop-in anchor -M8 6.1 6.10%

Ceilling support 42 250% 1.05 0.26 AM-M8-4.6 7.8 7.80% HKD- drop-in anchor -M8 6.1 6.10%

Ceilling support 65 250% 1.63 0.41 AM-M8-4.6 7.8 7.80% HKD- drop-in anchor -M8 6.1 6.10%
 Hilti. Outperform. Outlast.

+,/7,7KUHDGHG5RGDQG)DVWHQHUV

www.hilti.sa Costumer Service | 8001200013

 Threaded rods – technical information

Mechanical properties
Material class Yield strength Tensile strength
fyk fuk
4.8. 240 Mpa 400 MPa
5.8. 400 Mpa 500 MPa
8.8. 640 Mpa 800 MPa

Recommended tensile load – threaded rods ( kN )

Threaded Characteristic NRec ( kN )
rod cross section
size As ( mm2) 4.6. 5.8. 8.8.
M8 32,8 4,7 7,8 12,5
M 10 52,3 7,5 12,5 19,9
M 12 76,2 10,9 18,1 29,0
M 16 144,0 20,6 34,3 54,9
M 20 225,0 32,1 53,6 85,7
M 24 324,0 46,3 77,1 123,4
M 27 427,0 61,0 101,7 162,7
M 30 519,0 74,1 123,6 197,7
M 33 647,0 92,4 154,0 246,5
M 36 759,0 108,4 180,7 289,1
M 39 913,0 130,4 217,4 347,8

Note :
Recommended global safety factor v 2,8 2,1 2,1

Tensile strength ( N/mm 2) 400 500 800

Calculation used: NRec ( N ) = As (mm2 ) x fuk (MPa ) / v()

 Installation Systems

Threaded rod

Technical data

Surface Finish Galvanized

Material composition Steel grade 4.8
Additional product information According DIN 976-1 / Form A

Ordering
Thread diameter Length Order designation Sales Quantity Item Number

M4 1m Threaded rod AM4x1000 4.8 zinced 50 pc 00409382

M6 1m Threaded rod AM6x1000 4.8 zinced 20 pc 00339792
M6 2m Threaded rod AM6x2000 4.8 zinced 20 pc 00216411
M6 3m Threaded rod AM6x3000 4.8 zinced 20 pc 00216412
M8 1m Threaded rod AM8x1000 4.8 zinced 20 pc 00339793
M8 2m Threaded rod AM8x2000 4.8 zinced 20 pc 00339794
M8 3m Threaded rod AM8x3000 4.8 zinced 20 pc 00216415
M10 1m Threaded rod AM10x1000 4.8 zinced 20 pc 00339795
M10 2m Threaded rod AM10x2000 4.8 zinced 20 pc 00339796
M10 3m Threaded rod AM10x3000 4.8 zinced 20 pc 00216418
M12 1m Threaded rod AM12x1000 4.8 zinced 15 pc 00339797
M12 2m Threaded rod AM12x2000 4.8 zinced 15 pc 00216420
M12 3m Threaded rod AM12x3000 4.8 zinced 15 pc 00216421
M16 1m Threaded rod AM16x1000 4.8 zinced 5 pc 00216422
M16 2m Threaded rod AM16x2000 4.8 zinced 5 pc 00216423
M16 3m Threaded rod AM16x3000 4.8 zinced 5 pc 00216424
M20 1m Threaded rod AM20x1000 4.8 zinced 5 pc 00216425
M20 2m Threaded rod AM20x2000 4.8 zinced 5 pc 00212632
M24 1m Threaded rod AM24x1000 4.8 zinced 5 pc 00216426
M24 2m Threaded rod AM24x2000 4.8 zinced 5 pc 00212633

10

www.hilti.com | 0800-123 123456 10 Installation Systems 1

 Installation Systems

Threaded rod

Technical data

Surface Finish Galvanized

Material composition Steel grade 4.6
Additional product information According DIN 976-1 / Form A

Ordering
Thread diameter Length Order designation Sales Quantity Item Number

M8 30 mm Threaded stud AM8x30 4.6 zinced 100 pc 00216379

M8 40 mm Threaded stud AM8x40 4.6 zinced 100 pc 00216380
M8 50 mm Threaded stud AM8x50 4.6 zinced 100 pc 00216381
M8 60 mm Threaded stud AM8x60 4.6 zinced 100 pc 00216382
M8 70 mm Threaded stud AM8x70 4.6 zinced 100 pc 00216383
M8 80 mm Threaded stud AM8x80 4.6 zinced 100 pc 00216384
M8 100 mm Threaded stud AM8x100 4.6 zinced 100 pc 00216385
M8 120 mm Threaded stud AM8x120 4.6 zinced 100 pc 00216386
M8 150 mm Threaded stud AM8x150 4.6 zinced 100 pc 00216387
M8 180 mm Threaded stud AM8x180 4.6 zinced 100 pc 00216388
M10 30 mm Threaded stud AM10x30 4.6 zinced 100 pc 00216389
M10 40 mm Threaded stud AM10x40 4.6 zinced 50 pc 00216390
M10 60 mm Threaded stud AM10x60 4.6 zinced 50 pc 00216391
M10 80 mm Threaded stud AM10x80 4.6 zinced 50 pc 00216392
M10 100 mm Threaded stud AM10x100 4.6 zinced 50 pc 00216393
M10 120 mm Threaded stud AM10x120 4.6 zinced 50 pc 00216394
M10 150 mm Threaded stud AM10x150 4.6 zinced 50 pc 00216395
M10 180 mm Threaded stud AM10x180 4.6 zinced 50 pc 00216396
M12 50 mm Threaded stud AM12x50 4.6 zinced 50 pc 00216397
M12 80 mm Threaded stud AM12x80 4.6 zinced 50 pc 00216398
M12 100 mm Threaded stud AM12x100 4.6 zinced 50 pc 00216399
M12 120 mm Threaded stud AM12x120 4.6 zinced 50 pc 00216400
M12 150 mm Threaded stud AM12x150 4.6 zinced 25 pc 00216401
M12 200 mm Threaded stud AM12x200 4.6 zinced 25 pc 00216402
M16 60 mm Threaded stud AM16x60 4.6 zinced 25 pc 00212634
M16 80 mm Threaded stud AM16x80 4.6 zinced 25 pc 00216403
M16 100 mm Threaded stud AM16x100 4.6 zinced 25 pc 00212635
M16 150 mm Threaded stud AM16x150 4.6 zinced 25 pc 00212636

Threaded pipe
GR-G

Technical data
GR-G
Surface Finish Galvanized
Material composition Steel grade 4.6

Ordering
Thread diameter Length Order designation Sales Quantity Item Number

3/8 in 2m Threaded pipe GR-G 3/8”x2000 4.6 Zn 10 pc 00056427

1/2 in 2m Threaded pipe GR-G 1/2”x2000 4.6 Zn 10 pc 00056428
3/4 in 2m Threaded pipe GR-G 3/4”x2000 4.6 Zn 5 pc 00056429
1 in 2m Threaded pipe GR-G 1”x2000 4.6 Zn 5 pc 00056430
1-1/4 in 2m Threaded pipe GR-G 1 1/4”x2000 4.6 Zn 3 pc 00248532

2 10 Installation Systems www.hilti.com | 0800-123 123456

 Installation Systems

Hexagon screw

Technical data

Surface Finish Galvanized

Material composition Steel grade 8.8
Additional product information According DIN 933

Ordering
Thread diameter Thread length Wrench size Order designation Sales Quantity Item Number

M6 16 mm 10 mm Hexagon screw M6x16 zinced 100 pc 00216443

M6 25 mm 10 mm Hexagon screw M6x25 zinced 100 pc 00216444
M6 40 mm 10 mm Hexagon screw M6x40 zinced 100 pc 00216445
M8 16 mm 13 mm Hexagon screw M8x16 zinced 100 pc 00216446
M8 20 mm 13 mm Hexagon screw M8x20 zinced 100 pc 00216447
M8 25 mm 13 mm Hexagon screw M8x25 zinced 100 pc 00216448
M8 30 mm 13 mm Hexagon screw M8x30 zinced 100 pc 00047425
M8 35 mm 13 mm Hexagon screw M8x35 zinced 100 pc 00216449
M8 45 mm 13 mm Hexagon screw M8x45 zinced 100 pc 00212631
M8 55 mm 13 mm Hexagon screw M8x55 zinced 100 pc 00216450
M10 16 mm 17 mm Hexagon screw M10x16 zinced 100 pc 00216452
M10 20 mm 17 mm Hexagon screw M10x20 zinced 100 pc 00216453
M10 25 mm 17 mm Hexagon screw M10x25 zinced 100 pc 00216454
M10 30 mm 17 mm Hexagon screw M10x30 zinced 100 pc 00047426
M10 35 mm 17 mm Hexagon screw M10x35 zinced 100 pc 00216455
M10 55 mm 17 mm Hexagon screw M10x55 zinced 100 pc 00216456
M12 22 mm 19 mm Hexagon screw M12x22 zinced 50 pc 00216457
M12 25 mm 19 mm Hexagon screw M12x25 zinced 50 pc 00216458
M12 35 mm 19 mm Hexagon screw M12x35 zinced 50 pc 00216459
M12 40 mm 19 mm Hexagon screw M12x40 zinced 50 pc 00047398
M12 50 mm 19 mm Hexagon screw M12x50 zinced 50 pc 00084618
M12 60 mm 19 mm Hexagon screw M12x60 zinced 50 pc 00216460
M16 30 mm 24 mm Hexagon screw M16x30 zinced 50 pc 00216461
M16 35 mm 24 mm Hexagon screw M16x35 zinced 50 pc 00084793
M16 40 mm 24 mm Hexagon screw M16x40 zinced 50 pc 00047427
M16 50 mm 24 mm Hexagon screw M16x50 zinced 50 pc 00084718
M16 70 mm 24 mm Hexagon screw M16x70 zinced 50 pc 00387994
M20 40 mm 30 mm Hexagon screw M20x40 zinced 50 pc 00216462

10

www.hilti.com | 0800-123 123456 10 Installation Systems 3

 Installation Systems

Hex head wood screw

Technical data

Surface Finish Galvanized

Material composition Steel grade 8
Additional product information According DIN 571

Ordering
Thread diameter Thread length Wrench size Order designation Sales Quantity Item Number

M5 50 mm 8 mm Hex head wood screw M5x50 zinced 200 pc 00409390

M7 60 mm 12 mm Hex head wood screw M7x60 zinced 100 pc 00409391
M8 50 mm 13 mm Hex head wood screw M8x50 zinced 100 pc 00047429
M8 60 mm 13 mm Hex head wood screw M8x60 zinced 100 pc 00047430
M8 80 mm 13 mm Hex head wood screw M8x80 zinced 50 pc 00047431
M8 100 mm 13 mm Hex head wood screw M8x100 zinced 50 pc 00047432

Interior hexagon head screw

Technical data

Surface Finish Galvanized

Material composition Steel grade 8.8
Additional product information According DIN 912
Screw head type Hexagon socket

Ordering
Thread diameter Thread length Order designation Sales Quantity Item Number

M8 16 mm Hex skt hd cap screw M8x16 zinced 50 pc 00216471

M8 25 mm Hex skt hd cap screw M8x25 zinced 50 pc 00216472
M10 16 mm Hex skt hd cap screw M10x16 zinced 50 pc 00216474
M12 20 mm Hex skt hd cap screw M12x20 zinced 50 pc 00216476

4 10 Installation Systems www.hilti.com | 0800-123 123456

 Installation Systems

Hanger bolt

Technical data

Surface Finish Galvanized

Material composition Steel grade 4.6
Additional product information HUD anchors should be one size
above screw diameter

Ordering
Thread Length A B Screw head Order designation Sales Item Number
diameter type Quantity

M6 60 mm 20 mm 30 mm TX 15 Hanger bolt M6x60 4.6 zinced 100 pc 00216357

M6 80 mm 30 mm 30 mm TX 15 Hanger bolt M6x80 4.6 zinced 100 pc 00216358
M8 50 mm 15 mm 30 mm TX 25 Hanger bolt M8x50 4.6 zinced 100 pc 00216360
M8 60 mm 20 mm 30 mm TX 25 Hanger bolt M8x60 4.6 zinced 100 pc 00216361
M8 80 mm 30 mm 40 mm TX 25 Hanger bolt M8x80 4.6 zinced 100 pc 00216362
M8 100 mm 40 mm 40 mm TX 25 Hanger bolt M8x100 4.6 zinced 100 pc 00216363
M8 120 mm 50 mm 50 mm TX 25 Hanger bolt M8x120 4.6 zinced 100 pc 00216364
M8 130 mm 50 mm 50 mm TX 25 Hanger bolt M8x130 4.6 zinced 50 pc 00216365
M8 150 mm 50 mm 50 mm TX 25 Hanger bolt M8x150 4.6 zinced 50 pc 00216366
M10 80 mm 30 mm 40 mm TX 25 Hanger bolt M10x80 4.6 zinced 50 pc 00216367
M10 100 mm 30 mm 60 mm TX 25 Hanger bolt M10x100 4.6 zinced 50 pc 00216368
M10 120 mm 50 mm 60 mm TX 25 Hanger bolt M10x120 4.6 zinced 50 pc 00216369
M10 130 mm 50 mm 60 mm TX 25 Hanger bolt M10x130 4.6 zinced 50 pc 00216370
M10 150 mm 50 mm 60 mm TX 25 Hanger bolt M10x150 4.6 zinced 50 pc 00216371
M10 180 mm 50 mm 60 mm TX 25 Hanger bolt M10x180 4.6 zinced 50 pc 00216372
M12 100 mm 30 mm 50 mm TX 30 Hanger bolt M12x100 4.6 zinced 50 pc 00216374
M12 150 mm 60 mm 60 mm TX 30 Hanger bolt M12x150 4.6 zinced 25 pc 00216376

10

www.hilti.com | 0800-123 123456 10 Installation Systems 5

 Installation Systems

Spurt screw
ESS
Technical data
ESS
Surface Finish Galvanized
Material composition Steel, 290 - 435 HV
Screw head type Cross recess (POZI)
Additional product information To use with HUD anchor
Ordering
Thread diameter Thread length Order designation Sales Quantity Item Number

3.5 mm 30 mm Spurt screw ESS-3,5x30 200 pc 00418018

4 mm 25 mm Spurt screw ESS-4,0x25 200 pc 00418019
4 mm 30 mm Spurt screw ESS-4,0x30 200 pc 00418020
4 mm 35 mm Spurt screw ESS-4,0x35 200 pc 00418021
4 mm 40 mm Spurt screw ESS-4,0x40 200 pc 00418022
4 mm 45 mm Spurt screw ESS-4,0x45 200 pc 00418023
4 mm 50 mm Spurt screw ESS-4,0x50 200 pc 00418024
4.5 mm 30 mm Spurt screw ESS-4,5x30 200 pc 00418025
4.5 mm 35 mm Spurt screw ESS-4,5x35 200 pc 00418026
4.5 mm 40 mm Spurt screw ESS-4,5x40 200 pc 00418027
4.5 mm 45 mm Spurt screw ESS-4,5x45 200 pc 00418028
4.5 mm 50 mm Spurt screw ESS-4,5x50 200 pc 00418029
5 mm 30 mm Spurt screw ESS-5,0x30 200 pc 00418030
5 mm 35 mm Spurt screw ESS-5,0x35 200 pc 00418031
5 mm 40 mm Spurt screw ESS-5,0x40 200 pc 00418032
5 mm 45 mm Spurt screw ESS-5,0x45 200 pc 00418033
5 mm 50 mm Spurt screw ESS-5,0x50 200 pc 00418034

Flat leaf screw

BS
Technical data
BS
Surface Finish Galvanized
Material composition S235JR as per DIN EN 10025
Additional product information Centric tensile load related to
the single component

Ordering
Thread diam- Length Hole diameter Max. recom- Order designation Sales Quantity Item Number
eter mended
tensile load

M6 40 mm 8.5 mm 1500 N Flat leaf screw BS M6x40 50 pc 00058522

M8 20 mm 10.5 mm 2000 N Flat leaf screw BS M8x20 50 pc 00058531
M8 40 mm 10.5 mm 2000 N Flat leaf screw BS M8x40 50 pc 00058532
M10 20 mm 12.5 mm 3000 N Flat leaf screw BS M10x20 50 pc 00058541
M10 40 mm 12.5 mm 3000 N Flat leaf screw BS M10x40 50 pc 00058542

6 10 Installation Systems www.hilti.com | 0800-123 123456

 Installation Systems

Hexagon nut
Technical data

Surface Finish Galvanized

Material composition Steel grade 8
Additional product information According DIN 934

Ordering
Thread diameter Wrench size Order designation Sales Quantity Item Number

M6 10 mm Hexagon nut M6 zinced 100 pc 00216464

M8 13 mm Hexagon nut M8 zinced 100 pc 00216465
M10 17 mm Hexagon nut M10 zinced 100 pc 00216466
M12 19 mm Hexagon nut M12 zinced 100 pc 00216467
M16 24 mm Hexagon nut M16 zinced 50 pc 00216468
M20 30 mm Hexagon nut M20 zinced 50 pc 00216469
M24 36 mm Hexagon nut M24 zinced 50 pc 00216470

Flange nut
Technical data

Surface Finish Galvanized

Material composition Steel grade 8
Additional product information According EN 1661

Ordering
Thread diameter Wrench size Order designation Sales Quantity Item Number

M8 13 mm Hex nut with flange M8 250 pc 00271508

M10 16 mm Hex nut with flange M10 250 pc 00271509
M12 18 mm Hex nut with flange M12 150 pc 00052288

10

www.hilti.com | 0800-123 123456 10 Installation Systems 7

 Installation Systems

Flat washer
Technical data

Surface Finish Galvanized

Material composition Steel 140 HV

Ordering
Inside diameter Outside Thickness Additional product information Order designation Sales Quantity Item Number
diameter

6.4 mm 12 mm 1.6 mm According DIN 125 / Form A Flat washer A 6,4/12 zinced 500 pc 00282849
8.4 mm 16 mm 1.6 mm According DIN 125 / Form A Flat washer A 8,4/16 zinced 200 pc 00282850
10.5 mm 20 mm 2 mm According DIN 125 / Form A Flat washer A 10,5/20 zinced 100 pc 00282851
13 mm 24 mm 2.5 mm According DIN 125 / Form A Flat washer A 13/24 zinced 100 pc 00282852
17 mm 30 mm 3 mm According DIN 125 / Form A Flat washer A 17/30 zinced 100 pc 00282853
21 mm 37 mm 3 mm According DIN 125 / Form A Flat washer A 21/37 zinced 50 pc 00282854
25 mm 44 mm 4 mm According DIN 125 / Form A Flat washer A 25/44 zinced 50 pc 00282855
8.4 mm 40 mm 3 mm Similar to DIN 125 / Form A Flat washer A 8,4/40 zinced 100 pc 00282856
10.5 mm 40 mm 3 mm Similar to DIN 125 / Form A Flat washer A 10,5/40 zinced 100 pc 00282857
13 mm 40 mm 3 mm Similar to DIN 125 / Form A Flat washer A 13/40 zinced 100 pc 00282858
17 mm 40 mm 3 mm Similar to DIN 125 / Form A Flat washer A 17/40 zinced 100 pc 00282859
6.4 mm 28 mm 2 mm Similar to DIN 125 / Form A Flat washer A 6,4/28 zinced 200 pc 00282860
8.4 mm 28 mm 2 mm Similar to DIN 125 / Form A Flat washer A 8,4/28 zinced 200 pc 00282861
10.5 mm 28 mm 2 mm Similar to DIN 125 / Form A Flat washer A 10,5/28 zinced 100 pc 00282862
6.4 mm 18 mm 1.6 mm According DIN 9021 / Form A Flat washer A 6,4/18 zinced 200 pc 00409392
8.4 mm 24 mm 2 mm According DIN 9021 / Form A Flat washer A 8,4/24 zinced 100 pc 00409393
10.5 mm 30 mm 2.5 mm According DIN 9021 / Form A Flat washer A 10,5/30 zinced 100 pc 00409394
13 mm 37 mm 3 mm According DIN 9021 / Form A Flat washer A 13/37 zinced 100 pc 00409395
17 mm 50 mm 3 mm According DIN 9021 / Form A Flat washer A 17/50 zinced 50 pc 00409396
22 mm 60 mm 4 mm According DIN 9021 / Form A Flat washer A 22/60 zinced 50 pc 00409398

Thread adapter
GA
Technical data
GA
Surface Finish Galvanized
Material composition Steel 9 SMnPb 28 U

Ordering
Internal Outside Length Wrench size A B Order designation Sales Item Number
thread size thread Quantity

1/2 in M10 29 mm 24 mm 19 mm 8 mm Thread adapter GA M10-1/2” 50 pc 00067584

1/2 in M12 29 mm 24 mm 18 mm 8.5 mm Thread adapter GA M12-1/2” 50 pc 00067692
1/2 in M16 35 mm 30 mm 19 mm 13 mm Thread adapter GA M16-1/2” 25 pc 00067693
3/4 in M16 38 mm 30 mm 21.5 mm 13 mm Thread adapter GA M16-3/4” 25 pc 00067728
M6 M8 20 mm 13 mm 12 mm 6 mm Thread adapter GA M8-M6 100 pc 00067572
M8 M6 19 mm 13 mm 12 mm 5.5 mm Thread adapter GA M6-M8 100 pc 00067583
M8 M10 21 mm 13 mm 13 mm 6 mm Thread adapter GA M10-M8 100 pc 00067575
M10 M12 23 mm 13 mm 13 mm 7.5 mm Thread adapter GA M12-M10 100 pc 00067577
M10 M8 23 mm 13 mm 15 mm 6 mm Thread adapter GA M8-M10 100 pc 00047389
M10 M16 30 mm 24 mm 15 mm 13 mm Thread adapter GA M16-M10 50 pc 00067581
M12 M8 23 mm 17 mm 15 mm 6 mm Thread adapter GA M8-M12 100 pc 00047390
M12 M10 25 mm 17 mm 15 mm 8 mm Thread adapter GA M10-M12 100 pc 00047391
M12 M16 32 mm 19 mm 18 mm 11 mm Thread adapter GA M16-M12 50 pc 00047399
M16 M8 28 mm 19 mm 19 mm 6 mm Thread adapter GA M8 - M16 50 pc 00267022
M16 M10 29 mm 24 mm 19 mm 8 mm Thread adapter GA M10 - M16 50 pc 00267813

8 10 Installation Systems www.hilti.com | 0800-123 123456

 Installation Systems

Threaded coupling round

Technical data

Surface Finish Galvanized

Material composition Steel grade 4.6

Ordering
Thread diameter Length Order designation Sales Quantity Item Number

M6 20 mm Spacer coupling M6x20 round 100 pc 00216432

M6 30 mm Spacer coupling M6x30 round 100 pc 00216433
M6 40 mm Spacer coupling M6x40 round 100 pc 00216434
M8 30 mm Spacer coupling M8x30 round 50 pc 00216435
M8 40 mm Spacer coupling M8x40 round 50 pc 00216436
M10 30 mm Spacer coupling M10x30 round 50 pc 00216437
M10 40 mm Spacer coupling M10x40 round 50 pc 00216438
M12 30 mm Spacer coupling M12x30 round 50 pc 00216439
M12 40 mm Spacer coupling M12x40 round 50 pc 00216440
M16 60 mm Spacer coupling M16x60 round 20 pc 00216441

Threaded coupling
Technical data

Surface Finish Galvanized

Material composition Steel grade 4.6

Ordering
Thread diameter Length Wrench size Order designation Sales Quantity Item Number

M6 18 mm 10 mm Spacer coupling M6x18 50 pc 00070063

M8 25 mm 13 mm Spacer coupling M8x25 50 pc 00216703
M8 40 mm 13 mm Spacer coupling M8x40 50 pc 00432188
M10 30 mm 17 mm Spacer coupling M10x30 50 pc 00216704
M12 40 mm 19 mm Spacer coupling M12x40 50 pc 00216705
M16 40 mm 24 mm Spacer coupling M16x40 25 pc 00216706

Reduction sleeve
SR-RM
Technical data
SR-RM
Surface Finish Galvanized
Material composition Steel 9 SMnPb 28 U
10
Ordering
Inside thread Outside thread Length Order designation Sales Quantity Item Number

1/2 in 3/4 in 20 mm Reduction sleeve SR-RM 3/4”-1/2” 50 pc 00230963

M8 M12 8 mm Reduction sleeve SR-RM M12-M8 100 pc 00067729
M8 1/2 in 10 mm Reduction sleeve SR-RM 1/2” - M8 50 pc 00372844
M10 1/2 in 10 mm Reduction sleeve SR-RM 1/2”-M10 50 pc 00230964
M10 3/4 in 10 mm Reduction sleeve SR-RM 3/4” - M10 50 pc 00372845
M10 M16 10 mm Reduction sleeve SR-RM M16-M10 100 pc 00058146
M12 1/2 in 10 mm Reduction sleeve SR-RM 1/2”-M12 50 pc 00047394
M12 M16 10 mm Reduction sleeve SR-RM M16-M12 100 pc 00047428
M16 1/2 in 17 mm Reduction sleeve SR-RM 1/2”-M16 50 pc 00230987
M16 3/4 in 17 mm Reduction sleeve SR-RM 3/4”-M16 50 pc 00230988

www.hilti.com | 0800-123 123456 10 Installation Systems 9

 Installation Systems

Screw-in coupling
ESM

Technical data
ESM
Surface Finish Galvanized
Material composition Steel 9 SMnPb 28 U

Ordering
Thread diameter Length Order designation Sales Quantity Item Number

1/2” - M8 29.5 mm Screw-in coupling ESM 1/2” - M8 20 pc 00251877

1/2” - M10 30.5 mm Screw-in coupling ESM 1/2” - M10 20 pc 00251878

Eye nut

Technical data

Surface Finish Galvanized

Material composition Steel C15E
Additional product information According DIN 582

Ordering
Thread diameter Order designation Sales Quantity Item Number

M8 Eye nut M8 zinced 40 pc 00365873

M10 Eye nut M10 zinced 20 pc 00365808
M12 Eye nut M12 zinced 10 pc 00365811
M16 Eye nut M16 zinced 10 pc 00365809
M20 Eye nut M20 zinced 6 pc 00365810
M24 Eye nut M24 zinced 4 pc 00365874

Eyelet
AG

Technical data
AG
Surface Finish Galvanized
Material composition Malleable cast iron
Additional product information Centric tensile load related to
the single component

Ordering
Thread diam- Length Hole diameter Max. recom- Order designation Sales Quantity Item Number
eter mended
tensile load

M8 52 mm 26 mm 1000 N Eyelet AG M8 50 pc 00058230

M10 52 mm 26 mm 1000 N Eyelet AG M10 50 pc 00058240

10 10 Installation Systems www.hilti.com | 0800-123 123456

 Installation Systems

Hook
AH
Technical data
AH
Surface Finish Galvanized
Material composition Malleable cast iron
Additional product information Centric tensile load related to
the single component

Ordering
Thread diameter Length Max. recommended Order designation Sales Quantity Item Number
tensile load

M6 28 mm 250 N Hook AH M6 100 pc 00058121

Lifting eye bolt

Technical data

Surface Finish Galvanized

Material composition S235JR as per DIN EN 10025

Ordering
Thread diam- Length Hole diameter Max. recom- Order designation Sales Quantity Item Number
eter mended
tensile load

M8 25 mm 8.5 mm 2000 N Lifting eye bolt M8x25 100 pc 00058455

Pipe hanger
RA
Technical data
RA
Surface Finish Galvanized
Material composition Malleable cast iron
Additional product information Centric tensile load related to
the single component

Ordering
Thread diam- Length Hole diameter Max. recom- Order designation Sales Quantity Item Number
eter mended
tensile load

M6 39 mm 10 mm 2000 N Pipe hanger RA M6 100 pc 00058225

M8 44 mm 12 mm 2000 N Pipe hanger RA M8 50 pc 00058235
Pipe hanger RA M10
M10 44 mm 12 mm 2000 N 50 pc 00058245
10

www.hilti.com | 0800-123 123456 10 Installation Systems 11

Installation Systems

Suspension clip


Y


Applications Technical data

nn Single-point suspension of pipes from ceilings or channels

Surface Finish Galvanized

Advantages
Material composition S235JR as per DIN EN 10025
nn Height continuously adjustable up to 30 mm
Additional product - M8 rod has to be used with M10
nn Two slots for convenient installation information washer. Washer as per DIN 125
nn Adjustment after installation possible - Connection to channel with hex.
nn Suitable for use with M8 / M10 / M12 head screw as per DIN 933

Max. recommended Order designation Sales Quantity Item Number

tensile load

1500 N Suspension clip M8-M12 zinced 25 pc 00041220

12 10 Installation Systems www.hilti.com | 0800-123 123456

HILTI HKD
FLUSH ANCHOR
Technical Datasheet
Update: Jan-23
HKD Flush anchor
Everyday standard manual set flush anchor for single anchor applications

Anchor version Benefits

- Simple and well proven
HKD - Approved, tested and confirmed
(M8-M20) by everyday jobsite experience
- Reliable setting thanks to simple
visual check
- Versatile
HKD-S(R) - For medium-duty fastening with
(M6-M20) bolts or threaded rods
- Available in various materials and
sizes for maximized coverage of
possible applications
HKD-E(R)
(M6-M20)

Base material Load conditions

Concrete Static/
(non-cracked) quasi-static

Installation conditions Other information

European CE PROFIS Corrosion

Hammer Technical conformity Engineering resistance
drilled holes Assessment design
software

Approvals / certificates
Description Authority / Laboratory No. / date of issue
European Technical Assessment a) CSTB, Marne-la-Vallèe ETA-02/0032 / 2020-11-04
Hilti technical data Hilti
a) All data given in this section according to ETA-02/0032, issue 2015-01-07.
Static resistance

All data in this section applies to:

- Correct setting (See setting instruction)
- No edge distance and spacing influence
- Concrete as specified in the table
- Steel failure
- Minimum base material thickness
- Concrete C 20/25, fck,cube = 25 N/mm²
- Screw or rod with steel grade 5.8 (carboon steel) and / or A4-70 (stainless steel)

Effective anchorage depth for static

Anchor size M6 M8 M10 M12 M16 M8 M8 M10 M10 M12 M16 M20
Effective anchorage depth hef [mm] 25 25 25 25 30 30 40 30 40 50 65 80

Characteristic resistance
Hilti technical data
M10x25 ETA-02/0032, issued 2020-11-04

M12x25

M10x30

M10x40

M12x50

M16x65

M20x80
M6x25

M8x25

M6x30

M8x30

M8x40
Anchor size
HKD 6,1 6,1 6,1 6,1 - 8,1 9,0 8,1 12,4 17,4 25,8 35,2
Tension HKD-S, HKD-E NRk [kN] 6,1 - - - 8,1 8,1 9,0 8,1 12,4 17,4 25,8 35,2
HKD-SR, HKD-ER 6,1 - - - 8,1 8,1 - - 12,4 17,4 25,8 35,2
HKD 5,0 6,1 6,1 6,1 - 8,6 9,2 10,0 11,0 18,3 33,8 49,5
Shear HKD-S, HKD-E VRk [kN] 5,0 - - - 5,0 7,0 7,0 7,4 8,0 14,1 21,9 34,7
HKD-SR, HKD-ER 6,2 - - - 6,4 8,4 - - 10,5 18,7 32,1 51,0

Design resistance
Hilti technical data ETA-02/0032, issued 2020-11-04
M10x25

M12x25

M10x30

M10x40

M12x50

M16x65

M20x80
M6x25

M8x25

M6x30

M8x30

M8x40

Anchor size
HKD 4,1 4,1 4,1 4,1 - 5,4 6,0 5,4 8,3 11,6 17,2 23,5
Tension HKD-S, HKD-E NRd [kN] 4,1 - - - 5,4 5,4 5,0 5,4 8,3 11,6 17,2 23,5
HKD-SR, HKD-ER 4,1 - - - 5,4 5,4 - - 8,3 11,6 17,2 23,5
HKD 4,0 4,1 4,1 4,1 - 6,9 7,3 8,0 8,8 14,6 27,0 39,6
Shear HKD-S, HKD-E VRd [kN] 3,9 - - - 3,9 5,5 5,5 5,9 6,4 11,3 17,5 27,8
HKD-SR, HKD-ER 4,1 - - - 4,2 5,5 - - 6,9 12,3 21,1 33,6
Recommended loads a)
Hilti technical data ETA-02/0032, issued 2020-11-04

M10x25

M12x25

M10x30

M10x40

M12x50

M16x65

M20x80
M6x25

M8x25

M6x30

M8x30

M8x40
Anchor size
HKD 2,9 2,9 2,9 2,9 - 3,8 3,6 3,8 5,9 8,3 12,3 16,8
Tension HKD-S, HKD-E NRec [kN] 2,9 - - - 3,8 3,8 3,6 3,8 5,9 8,3 12,3 16,8
HKD-SR, HKD-ER 2,9 - - - 3,8 3,8 - - 5,9 8,3 12,3 16,8
HKD 2,9 2,9 2,9 2,9 - 4,9 5,2 5,7 6,3 10,5 19,3 28,3
Shear HKD-S, HKD-E VRec [kN] 2,8 - - - 2,8 3,9 4,2 3,9 4,6 8,1 12,5 19,8
HKD-SR, HKD-ER 2,9 - - - 3,0 3,9 - - 4,9 8,8 15,1 24,0
a) With overall partial safety factor for action  = 1,4. The partial safety factors for action depend on the type of loading and shall be
taken from national regulations.

Materials

Mechanical properties
Anchor size M6 M8 M10 M12 M16 M20
HKD 570 570 570 570 640 590
Nominal tensile
HKD-S, HKD-E fuk [N/mm²] 560 560 510 510 - 460
strength
HKD-SR, HKD-ER 540 540 540 540 - 540
HKD 460 460 460 480 510 470
Yield strength HKD-S, HKD-E fyk [N/mm²] 440 440 410 410 - 375
HKD-SR, HKD-ER 355 355 355 355 - 355
HKD 20,7 26,7 32,7 60,1 105 167
Stressed
HKD-S, HKD-E As [mm²]
cross-section 20,9 26,1 28,8 58,7 - 163
HKD-SR, HKD-ER
HKD 32,3 54,6 82,9 184 431 850
Moment of
HKD-S, HKD-E W [mm³]
resistance 50 79 110 264 602 1191
HKD-SR, HKD-ER
Char. bending With 5.8 Gr. Steel 7,6 18,7 37,4 65,5 167 325
resistance for HKD-SR M0Rk,s [Nm]
rod or bolt 11 26 52 92 187 454
HKD-ER with A4-70

Material quality
Part Material
HKD Cold formed steel / galvanised to min. 5 µm
Anchor body HKD-S, HKD-E Steel Fe/Zn5 galvanised to min. 5 µm
HKD-SR, HKD-ER Stainless steel, 1.4401, 1.4404, 1.4571
HKD Cold formed steel
Expansion plug HKD-S, HKD-E Cold formed steel
HKD-SR, HKD-ER Stainless steel, 1.4401, 1.4404, 1.4571
Anchor dimensions of HKD, HKD-S, HKD-E, HKD-SR, HKD-ER
Hilti technical data ETA-02/0032, issued 2015-01-07

M10x25

M12x25

M10x30

M10x40

M12x50

M16x65

M20x80
M6x25

M8x25

M6x30

M8x30

M8x40
Anchor size
Eff. anchorage depth hef [mm] 25 25 25 25 30 30 40 30 40 50 65 80
Anchor diameter d1 [mm] 7,9 9,95 11,9 14,9 8 9,95 9,95 11,8 11,95 14,9 19,75 24,75
Plug diameter d2 [mm] 5,1 6,35 8,1 9,7 5 6,5 6,35 8,2 8,2 10,3 13,8 16,4
Plug length l1 [mm] 10 7 7 7,2 15 12 16 12 16 20 29 30

Anchor body Expansion plugs

Setting information

Setting details
Hilti technical data ETA-02/0032, issued 2015-01-07
M10x30a)
M10x25

M12x25

M10x40

M12x50

M16x65

M20x80
M6x25

M8x25

M6x30

M8x30

M8x40

Anchor size
Effective embedment
hef [mm] 25 25 25 25 30 30 40 30 40 50 65 80
depth
Nominal diameter of
do [mm] 8 10 12 15 8 10 10 12 12 15 20 25
drill bit
Cutting diameter of
dcut ≤ [mm] 8,45 10,5 12,5 15,5 8,45 10,5 10,5 12,5 12,5 15,5 20,5 25,5
drill bit
Depth of drill hole h1 ≥ [mm] 27 27 27 27 32 33 43 33 43 54 70 85
Screwing depth ls,min [mm] 6 8 10 12 6 8 8 10 10 12 16 20
Thread engagement
ls,max [mm] 12 11,5 12 12 12,5 14,5 17,5 12,7 18 23,5 30,5 42
depth
Diameter of clearance
df ≤ [mm] 7 9 12 14 7 9 9 12 12 14 18 22
hole in the fixture
Max. torque moment Tinst [Nm] 4 8 15 35 4 8 8 15 15 35 60 100
a) With anchor size M10x30 only threaded rod is to be used.
Installation equipment
Anchor size M6 M8 M10 M10 M12 M16
Rotary hammer for setting TE 1 – TE 3 TE 16 – TE 50
Machine setting tool HSD-M 6x25/30 8x25/30 10x25/30 10x40 12x50 16x65
HSD-G
Hand setting tool 6x25/30 8x25/30 10x25/30 10x40 12x50 16x65
HSD-M
Other tools hammer, torque wrench, blow out pump

Setting paramaters
Hilti technical data ETA-02/0032, issued 2015-01-07
M10x25

M12x25

M10x30

M10x40

M12x50

M16x65

M20x80
M6x25

M8x25

M6x30

M8x30

Anchor size M8x40

Minimum base material
hmin [mm] 100 100 100 100 100 100 100 100 100 100 130 160
thickness

Minimum spacing and smin [mm] 60 60 60 60 60 60 80 60 80 125 130 160

minimum edge distance
HKD-S (R) / HKD-E (R) cmin [mm] 88 88 88 88 105 105 140 105 140 175 230 280

Minimum spacing smin [mm] 80 80 80 80 60 60 80 60 80 125 130 160

HKD c ≥ [mm] 140 140 140 140 105 105 140 105 140 175 230 280
Minimum edge distance cmin [mm] 100 100 100 100 80 80 140 80 140 175 230 280
HKD s ≥ [mm] 150 150 150 150 120 120 80 120 80 125 130 160
Critical spacing and scr,sp [mm] 200 200 200 200 210 210 280 210 280 350 455 560
edge distance for
splitting failure HKD ccr,N [mm] 100 100 100 100 105 105 140 105 140 175 227 280
Critical spacing and
edge distance for scr,N [mm] 80 80 80 80 90 90 120 90 120 150 195 240
concrete cone failure
HKD / HKDS-(R) / ccr,N [mm] 40 40 40 40 45 45 60 45 60 75 97 120
HKD-E(R)
Critical spacing and
scr,sp [mm] 176 176 176 176 210 210 280 210 280 350 455 560
edge distance for
splitting failure
ccr,N [mm] 88 88 88 88 105 105 140 105 140 175 227 280
HKD-S(R) / HKD-E(R)
For spacing (edge distance) smaller than critical spacing (critical edge distance) the design loads have to be
reduced.
Setting instruction

*For detailed information on installation see instruction for use given with the package of the product.
Setting instruction
1. Drilling 2. Cleaning

3. Inserting the anchor 4. Setting tools

5. Inserting the tools 6. Inserting the tools

7. Attaching the belonging washer

 92 4554 912)
1*3 4 912
+
,492 324203
,4245

0120345360895536 4 3 42019529
6 3 93
!"#$%&'!(
 :;<=>
01234235 6784
9



!  "
! "#
$  "#
%#
&#
' (
)   (
& *
+ , -
. /0,1
234 56
'56
.7   8 55,5
!5
9 5
9 5
% 3"5#

?@ABCADCAEFGHIHJG?KFGHIDLBIFCAFIBHJMNFCOPG@QHOHABIR
BKHGHS@GHTFBKHIHFIPH?CSC?JBC@AIFJGHFIDUVH?BFB@F?KJAEHFWCBK@DBFA@BC?HR
5
 30J67J680J34(
789:; ?:@ E i g c 7C 77 79 7;
< 538=569365> 53A6 67682938 7 6 269 8865509365 D34 8037 D37269 012304
=B7CC8D3>5F1176=&G1HGI> 8037 8044682304
JKLM.NOPPQ0 XY 8MYX[]Y-X!\!ZX M-SVR.NOPPQ0 4MUVNQ) QS 4M^ )U0)S0 M)PW_OUW_ 9MSN^O0Q+ 4MUVUQ 4M^ )U0)S0
R) QS R) QS JMY$R TOU ^ )U0)S0 WUO
T)U.VOP XX-1 fM-SVR.NOPPQ0 6M-$R M -
.d)PdQb).5)aQ ,T).OUa)OS M)PW_OUW_
WUO XZ R) QSj\SVR ,.VVPVUPe2 <M.V) Q0 0O^! ,\]Y`NO.52
NQ) (Mh$R )PW_OUW_ .N)SaQ2
X[ <M-0d)PdQb).5)aQ TOU
\X 4MUVNQ) QS ,.VVPVUPe2 8M.VbbQSTOU 7MVb PN^O0Q+
OVU)P
\Y 6M-$R fM1.d)PdQb).5)aQ ,T).OUa)OS
\1 <M1SVR.NOPPQ0 (Mh$R ,NQ) /.VVP2 0O^!
\Z R) QS fMk$R .N)SaQ2
\[ 'M1SVR.NOPPQ0 'M10d)PdQb).5)aQ
YX R) QSj\SVR 3M\X$R ,NQ) /.VVP2
NQ)

0123045
67682938 6 2695
! "#$"" !
%%#"#"#%

& 7&61 8' (65
)$*+#,-./-0%"1./10
2""
2 693052 2
)% "%4 """
%#"*/*#" *5 #

26138 72 693052 2

Y
 0123 4526 829214  93 1 4 9
 !!"!#$%&'()##*&)
%#+,-+ !!'
-)*.))#&++&##!#/&)##&
 !&##)./#'
/&0!!)+&&##&## !
#.&!'
1411492 21 3
$##4(5&#6#&7*&/&&)!+
!&'8#&/#!##&)!#
"!#*'
93025 9 01 529:123
!!*.++*/#&!+&!&!&#+'
;&!+###"!#*'
$.!*/#&!+/&'%&*
8!'<##/#))#!+#'
;&*4(5++)##&=
>4(5%#&?%@ AB
>8*<# AB

($CB;BD=
E#F&&,G!+#!!&#+&
*+'H###&&&#&!##+&*+'
%$@;HB=
;!&#+&+&!+&*#+'
I#&##!#/+'

J
 012345543061896 92
450
 !!"#$%&!'()*+((,(!-+. *+/('0
!"1+(&-*(*2-(+"+-3-+4*.,+".-! *.*! +"+
5".+--&&.!.-*(( 5+."/*/*2-!-.*!
*&+&,6
7!&*.*!.#$%*+5+,.!+4!*!)&."'-.*!.!".'"
+*"1(!58&'//(,+*"8(-."*-+(-+)(-!-.*!&8
-! &+."+*/*/+ -*(( 5+."/*/*26
"9'*" -(+"+-&+"&!5*1*2'":;6<=((
*0&*!&+"*-0>6
?2@8@A H0I 9 JK
&*.1!".#$%*&.+((+.*!&!'()1"1"!0+, 9 L 09 01 6691035 4941 2
!)&.+-(.+.-+)+B+"!'&.!.*&.+((+.*!
/"&!(+ 3!"+0+2*2.!.'*.6
7"!/"(,*.*1,+((C*&.*2)'*(*2'.*(*.*&<&'-+&
(-."*-+(-+)(&8/('0)*2/*/&8&+*.+",+"5+"8.-6>6
D+E&'".+.(*4(-."*-+(-+)(&+"!.+2*2!"
"'*2+".#$%/"!/!& (!-+.*!!"!)&."'-.*2
*+,5+,.0!40.!1.*&.+((+.*!/"&!(6
$(+".1(!!"1"!0+((!)F-.&5*.&+"/ 2&6
G0!4(*9'*!"&(*//",0+."*+(1"!0.*&.+((+.*!
&*.)1!"/"!- *26
0OO
$'...!/-+".!/+(+ 0+"E*.5*.+&E.-&*0'(+.*2
.#$%6%&*.+&+.0/(+.1!"/!&*.*!*2.'*.+ .
-!""&/! *20!'.*2)"+-E.&!(3&(!.6
:7'...0/(+.+2+*&..-*(*2+ 0+"E.
-!""&6D+E&'".+.,!'(+4+.(+&.PQ-06
-(+"+-1"!0."+"+ +."RQ-061"!0.
"*2.+ &*!1.'*.<5(!!E*2+..'*. H0I 9 JN
1"!0.&'//(,&*>+&&!5*1*2'":;6
:D+"E.S!(&6
:T"*((.!&S!(&6&"..."+  "! &'&*2
+-!")!(.&<U00>6
: #*.+ .*2..'.&+..(!!& !1+-."+
"! +&/".+""+20.&!5*1*2'":V6
: W*1..#$%'*.+ *&"..."+  "! &*.!.
0!'.*2)"+-E.&(!.&6W.*."&.!.(!5"'.35+&"6
: =1.",!'-!0/(..(-."*-+(-!-.*!&<&
-!""&/! *2&-.*!&<X(-."*-+(Y*"*2+
"0!&.+.&.+(+.*!+ $!-.*!>>8(4(.#$%
+ /"&&*.+2+*&..-*(*2<&'"*2.!&/+"+.*.
1"!0.-*(*2),*&".*2"'))"-!"E/*-&>),1'"."
.*2.*2+-.*!!1.(!5"'.<&>6#!"+  &-'"*.,
-!'.".*2..'//"'.+&&!5*1*2'":P6$'.
.C."+(2.!1.."+  "! + "!' . 2&6
1@Z=(5+,&(+4[.!U-0C."+(2.*. H0I 9 JM
."+  "! )(!5.(!5"'.35+&"6
S
013454678966 8496

0  !" #$"
)*+' %&'( %&'(
)*+, %&'( %&'(
)*+- %&'( %&'(
)*+. %&'( %&'(
)*+/ %&'( %&'(
)*%+ %&'( %&'(
)*%' %&'( %&'(
)*%- %&'( %&'(
)*%. %&'( %&'(
)*%/ %&'( %&'(
)*'+ %&'( %&'(
9 VF:T?A:B>CH:9@O9AS:CH9A?>>:I>:Q:>CHSEAFAF:FEBCWEHA?>XQ:BACG?>J>?H:P
65YZ64969[545 5
%PF:JCJ:CH9O>?ACEH9FEO>IGEQ:BSEAFCH>:AXEOA>:AJCJ:9?99FETHS:>ETP
'P$9:AF:CH9O>?ACEHEDJE>R:AFR>:H:DE?@@CHC@O@ED.@@CHAFCG\H:99P
kbclmn]^ kbclmnd`c kbclmnd`c kbclmnd`c

]^_`abc]d^ kbclmn]^ kbclmn]^

]^_`abc]d^
ghij ef ef
1964 656 076468966 8496
8$9:;<==>?99,@?A:BC?>DEBAF:GEHI:H9?A:IB?CHJCJCHKL,&-MN?9J:BDCKOB:8-P
8;BEQCI:?M;MAB?JC@@:IC?A:>R?AAF:GEHI:H9?A:IB?CHGEHH:GACEHP
8OHREOBJCJCHK?QECICHKS:HI9?HI:>SET9P
8;CAGFAF:JCJCHK?T?RDBE@AF:OHCATCAF'&%++9>EJ:P
8 DAF:JCJ:C9BEOA:IAFUEOKF?BEE@LEB?HOHGEHICACEH:I9J?G:NCH9O>?A:AE?QECIGEHI:H9?ACEHEHCA9EOA:BT?>>9P

0123
o
 0123451645
26037580 0
Y
[ Z `l[bihmjn^[jm\o
\ YgZ\hijkefa
W X

RSTU
]
f
e

_
^

VSRU
c
NIPKLMNOK JHQKLMNO NIPKLMNOK

d `aWb
`
q
r

pSRU
FGHIJKLMNO

46)38*++,-./01-20134/-0..,-./01-201-054367/8134/-0-069/1
0123451645 :+2;/4<.2824311/.5+=
26037    0 3     >22+-0?62-+
0    !"# "! !!! "#"!  "#  >20842+52@
0 $    !"# "! !!! "#"!  "#  !A-+8/44367
0 %    !"# "! !!! "#"!  "#  B0-8.2C08-0?54367/81
0 & #!" "! !!#" #"   "#  ! " "D4-E+-E
0 ' #!" "! !!#" #"   "#  ! " DC686200/6824
0 ( # "    "!  "!  !# #! #
0 ( # "    "!  "!  !# #! #
0 (% # "    "!  "!  !# #! #
0 (& #!! "  "!  !!# " !" #! "" ! #
0 (' #!! "  "!  !!# " !" #! "" ! #
0 #!! "  "!  !!# " !" #! "" !#

"
 0123451647807 7 618 6443 1645
260385 0
N N
L L
O O
M M

Q Q
P P

DEFGHIJ KEFGHIJ


260385 0 0
N N
L L
O O
M M
Q

Q
P

DEFGHIJ KEFGHIJ



26038 188307 3 618 6 7 3 618

7 0 0 4126365 3 3 4126365
0 !"#$%&' ()"#&%(' ("#*%(' *)+""#+%&' ( +,"#*-%,' )!"#*-%$' *
0 !"#$%&' ()"#&%(' ("#*%(' *)+""#+%&' ( +,"#*-%,' )!"#*-%$' *
0 !"#$%&' ()"#&%(' ("#*%(' *)+""#+%&' ( +,"#*-%,' )!"#*-%$' *
0 (*("#*%(' (,"#*%$' ("#*%(' *)$"#)' ( (!*"#*(%$' (+"#*,%(' *
0. (*("#*%(' (,"#*%$' ("#*%(' *)$"#)' ( (!*"#*(%$' (+"#*,%(' *
0/ (*("#*%(' (,"#*%$' $("#(%(' )"#$%&' ( (!*"#*(%$' (+"#*,%(' *
0/ (*("#*%(' (,"#*%$' $("#(%(' )"#$%&' ( (!*"#*(%$' (+"#*,%(' *
0/ (*&"#*%+' ((-"#*(' $("#(%(' )"#$%&' , (!)"#*,' (+$"#*,%!' *
0/ ()+"#*,%$' ($&"#*!%(' *&"#!' )("#*-%$' , ,*,"#*+%(' ,)"#*+%$' *
0/. ()+"#*,%$' ($&"#*!%(' *&"#!' )("#*-%$' , ,*,"#*+%(' ,)"#*+%$' *
0 ()+"#*,%$' ($&"#*!%(' *&"#!' )("#*-%$' , ,*,"#*+%(' ,)"#*+%$' *
46 3"455"6789:;7<:;"=>9"7:"88"#6789:;7<:;"7:"?>=@A9B;"=>9"7:"7:@C9;'%

)
!"#$%&0'(%)1*&!$%'+$,$32'4$&2,&*
)1&!-%..0'*.410('/'101%!,$%')1&!1,
012134
567 589 5 6  5 7
5 556
 6   5
  6 5
 56
 8 8
 56 656
6 56
67  656  5 7

  86 5
6  566 656

56
3.!1(
0  8 1 6865 560
06 6 5  660
2067638  56  0
40856 5 638 05
56 5 56 65 1 5
55 5688 0

6
0123456849 5034 3335 5
9 5046  6890 50
6
 !"#
"$ "$"!
" "! !
% ""%%
%& ""%%'()*
+ + !!
), ))! ,
(% ()(%!)!"#
-& !&
.- .!
/// +,0)
+"!0)
0 8
&1$!02$$3+! $1
.1!!2($!",1
412"!$$"! ,"!02! 1
51+%6%&+"!2,3$2
,,2(,2"! !21

7
 0120351671839
012035167183"#6$%&'(#)*)+, 012035167183/#6$%&'/#)*)+,
 -.

! !

012035167183"#2$%&'(#)*)+, 012035167183/#2$%&'/#)*)+,
0.11 -.0.11

! !

7 6
>8? @
89:;;<=
 6

!
513492594
AB232CDAE33
239635545BC 2FGH(IH"IH/ 2FGHJIHK 2FGLHIL(IL/ 2FGLJILK 2FG(H
-MNOPQRMSSPTUVW XYYYXZ[\ XYYYXZ[ XYYYXZ[ XYYYXZ[[ XYYYXZ[[
UV]P^T ^ XYY\_[\\ XYY\_[\ XYY\_[\ XYY\_[\[ XYY\_[\[
UV]P^]`PPV XYY[ \Y XYY[ \ XYY[ \ XYY[ \ XYY[ \
abMVbPcMQRMdPeQf [YY g \ [YY g \ [YY g \ [YY g \ [YY g \
bMVbPcMQRMdPeOf [YY g_X [YY g_X [YY g_X [YY g_X [YY g_X
^P h^NMi^-iV P^S XYY _Z_ XYY _Z Z XYY _Z X XYY _Z g XYY _Z g
`P^TS M XYYg_g XYYg_g XYYg_g XYYg_g XYYg_g
CB43j-_Qk_O!lmnoQkoOlp
Y
 23456782927 45927 8 4927 929

0
S1
T

7 4592 9 825:27 8
6718" 4$!'3$

!"
#$
%&#'
0 '()*(+* ,()-.
1 '()*(+* ,()-.
"/0)
1&23410)
%35%0)
7 4592 9 574:54
6/3'!%<63'3$ 4$!'3$
!"3$512&
0 ;< 6=!"0*  >
1 ;6(()*(-+?(-,@.(,;.+* ()(()
A)B*B)? "!20()>
;) ) +B+? -6CD
"/
1&2341
%35%
%&#'3$512&
0 ;< 6=%&#'0*  >
1 ;6(()*(-+?(-,@.(,;.+* ()(()
A)B*B)? "!20()>
;) ) +B+? -6CD
"/
1&2341
%35%
#$12&
;< 6=#$0*  >
;) ) +B+? -6CD
"/
1&2341
%35%
4$3'
;< 6= *(00* >
EFGHI
=>6)(;*B)?D/ (*B()J"!2))0B)-B)?0) )(A)B*><(,@.K,;.
+* ))) -B)?)+ ()*(>
C>6)L* D/ ,@.(,;.+* (J())*()*(-) (
B)?>'B)?) +)L*M>NO(P*(A)B*>#0(Q ,)(R>.)*)B()*(BB
 +B)?>
==
01234563868
9
 ! " #$%&$&'(
) &! "&*(('&+,,
+# )
*(('
! " #$%&$&'(
-"# .( "( /(#(" '0
6152345853868
+# "%6('% 789:;<*=&)>
+# "% " * (*
?#  "% =* ( 7*
'6@(,  6' A=B
C#'@ "%/ '6'0 AAA9*
'6@(,  '6' AB
)@   DA=B
"% " =8<* 7/0<
E F ," " /70<
"( @  ?*/"("%0
+#(" '.("( G7H
 ) &+,,&*(('&! "
7! "#$
-"$ ( '# *(('&)
02IJ45853868
*('( 9('
E ' <K#'
9(("' -979'
L% 7%
< ( K #' "$
+#(" ? "# "  ''("$("%M'(N'6"'(" 'A
34r13J423J Tqmom
TWp nm
OP
QPRS
TUV
TVm
TXV
nq

WX

jg\d`ahgcd YZ[\]^_`abZcdec]Z^`fZac]Z^ghi

TXl XnoU
lm

UV

cYdbkZ\cgc 3261<''$"(" "A


 012345543061
789 998 98 999 9 99  998 99 9 9
9 8999  9 9 8989
!9  "9989978  999 9#
989 "98 99 89
$5$%3&0%45
!9999 '9()!8*+, 899 999-9 9
%./0123459 89 9 '9'9 9 89
6.731384999 9'7:;<5== '9 897899 9 98
9 9'8>989 99
?&6@1ABCBD66$&B60&$2
E 9 '9'99' E 9'9 89989  F
G4013$141%$
%605
E  9 999 89'99'8'98988 9'9
9'8 99789   9 998899 999
9H8 9 9 89999 9989 ' 9 9
9 9
A&401BD0D$
I98 9 89"999 9 9 H 998 9"9 9899
 8 99'' 99 99JKLMHI9 99!9 89" 89
98 9"9 9 9899  9  9'8
N053$&BB%5$4101?
;9 9 9999  9" 9'O
79 9 9899P899 8 '9H9899 9F9
99  ## 7#  !8 89  89 9999#99
9'8 9 ''88' =98 8 89999
&$D54%$G$13BD4&32
P89'99 999 9 99 9 89 99 89
&6@301$QD&$R$130R$BG4013$141%$
E98989  F'88
;9 9899989O
,#''89""9  899"89899 89'9"
,#''89""9  899"898999'
,E9899S9 8999999
,H989 999
24N$3TB0123&@%30612
BBBBB6.7313849999 9 99 "9988999 '9 99
- 8989
''J L 99999
JU
 01234546746092 59460

;
5 9:9B
A?BK5M
L
595
BI@967
DD?KK O35
J
7
N456

8@9A?B5C?DE5F9@CG>H5I9@:
3456
7
7
3456
8@9A?B5C?DE

89::9;5<=>?@

6
!"!!#
$%&!'&'()!')(!()&*+&*!'",)-#
./&*0
)&!')1#
'/11!'"-"!"*!2'"-!*''*"!'"-#
2


234356789
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-01 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

400.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

6.300 26.70 16.70 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX12

Cooling Performance Data

Total Cooling Capacity 6.657 kW
Total Sensible Capacity 6.150 kW
SHR 0.9
Air Flowrate 418.0 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.2649 LPS
Water Pressure Drop 4.03 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 26.70 °C Dry Bulb 12.10 °C

Wet Bulb 16.70 °C Wet Bulb 11.14 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 4
Fins Per Inch 12

Electrical Data General Data

Blower Motor 353 W Weight 52 kg
Blower Motor FLA 2.35 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 2.94 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 69 64 62 66 60 58 56
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-02 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

400.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

6.000 26.60 17.00 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX12

Cooling Performance Data

Total Cooling Capacity 7.033 kW
Total Sensible Capacity 5.915 kW
SHR 0.8
Air Flowrate 418.0 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.2798 LPS
Water Pressure Drop 4.44 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 26.60 °C Dry Bulb 13.00 °C

Wet Bulb 17.00 °C Wet Bulb 11.19 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 4
Fins Per Inch 12

Electrical Data General Data

Blower Motor 353 W Weight 52 kg
Blower Motor FLA 2.35 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 2.94 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 69 64 62 66 60 58 56
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-03 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

283.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

2.550 21.40 16.10 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX10

Cooling Performance Data

Total Cooling Capacity 3.011 kW
Total Sensible Capacity 2.322 kW
SHR 0.8
Air Flowrate 352.9 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.1198 LPS
Water Pressure Drop 0.74 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 21.40 °C Dry Bulb 13.83 °C

Wet Bulb 16.10 °C Wet Bulb 13.08 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 3
Fins Per Inch 12

Electrical Data General Data

Blower Motor 353 W Weight 52 kg
Blower Motor FLA 2.35 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 2.94 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 69 64 62 66 60 58 56
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-04 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

283.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

2.550 21.40 16.10 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX10

Cooling Performance Data

Total Cooling Capacity 3.011 kW
Total Sensible Capacity 2.322 kW
SHR 0.8
Air Flowrate 352.9 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.1198 LPS
Water Pressure Drop 0.74 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 21.40 °C Dry Bulb 13.80 °C

Wet Bulb 16.10 °C Wet Bulb 13.08 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 3
Fins Per Inch 12

Electrical Data General Data

Blower Motor 353 W Weight 52 kg
Blower Motor FLA 2.35 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 2.94 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 69 64 62 66 60 58 56
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-05 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

380.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

5.100 24.90 16.40 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX12

Cooling Performance Data

Total Cooling Capacity 6.265 kW
Total Sensible Capacity 5.244 kW
SHR 0.8
Air Flowrate 418.0 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.2493 LPS
Water Pressure Drop 3.63 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 24.90 °C Dry Bulb 12.72 °C

Wet Bulb 16.40 °C Wet Bulb 11.15 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 4
Fins Per Inch 12

Electrical Data General Data

Blower Motor 353 W Weight 52 kg
Blower Motor FLA 2.35 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 2.94 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 69 64 62 66 60 58 56
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-06 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

380.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

5.100 24.90 16.40 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX12

Cooling Performance Data

Total Cooling Capacity 6.265 kW
Total Sensible Capacity 5.244 kW
SHR 0.8
Air Flowrate 418.0 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.2493 LPS
Water Pressure Drop 3.63 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 24.90 °C Dry Bulb 12.72 °C

Wet Bulb 16.40 °C Wet Bulb 11.15 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 4
Fins Per Inch 12

Electrical Data General Data

Blower Motor 353 W Weight 52 kg
Blower Motor FLA 2.35 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 2.94 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 69 64 62 66 60 58 56
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-07 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

380.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

5.100 24.90 16.40 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX12

Cooling Performance Data

Total Cooling Capacity 6.265 kW
Total Sensible Capacity 5.244 kW
SHR 0.8
Air Flowrate 418.0 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.2493 LPS
Water Pressure Drop 3.63 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 24.90 °C Dry Bulb 12.72 °C

Wet Bulb 16.40 °C Wet Bulb 11.15 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 4
Fins Per Inch 12

Electrical Data General Data

Blower Motor 353 W Weight 52 kg
Blower Motor FLA 2.35 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 2.94 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 69 64 62 66 60 58 56
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-08 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

550.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

9.500 27.20 16.60 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX16

Cooling Performance Data

Total Cooling Capacity 10.06 kW
Total Sensible Capacity 9.546 kW
SHR 0.9
Air Flowrate 565.5 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.4003 LPS
Water Pressure Drop 2.51 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 27.20 °C Dry Bulb 12.00 °C

Wet Bulb 16.60 °C Wet Bulb 10.32 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 5
Fins Per Inch 14

Electrical Data General Data

Blower Motor 520 W Weight 65 kg
Blower Motor FLA 3.58 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 4.48 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 71 64 62 63 61 56 54
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-09 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

225.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

3.300 26.60 17.30 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX08

Cooling Performance Data

Total Cooling Capacity 3.448 kW
Total Sensible Capacity 3.214 kW
SHR 0.9
Air Flowrate 255.5 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.1372 LPS
Water Pressure Drop 1.62 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 26.60 °C Dry Bulb 13.67 °C

Wet Bulb 17.30 °C Wet Bulb 12.40 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 3
Fins Per Inch 12

Electrical Data General Data

Blower Motor 153 W Weight 40 kg
Blower Motor FLA 1.16 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 1.45 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 64 59 58 53 52 49 46
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: - Zaid Al Hussain Done By: ASIF

General Info

Project: KAFD Location: RIYADH

Ref/Tag: FCU-EC2-10 Quantity: 1

Revision: 0 Date: 2022-06-21 11:03

External
Air Flow Static Pressure Altitude
Input Conditions

225.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

3.200 26.60 17.30 0.0000 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX08

Cooling Performance Data

Total Cooling Capacity 3.448 kW
Total Sensible Capacity 3.214 kW
SHR 0.9
Air Flowrate 255.5 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.1372 LPS
Water Pressure Drop 1.62 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 26.60 °C Dry Bulb 13.67 °C

Wet Bulb 17.30 °C Wet Bulb 12.40 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 3
Fins Per Inch 12

Electrical Data General Data

Blower Motor 153 W Weight 40 kg
Blower Motor FLA 1.16 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 1.45 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 64 59 58 53 52 49 46
Products Certifications

of
 Chilled Water Fan Coil Unit
fcZAC

Customer: Zaid Alhussain Done By: MKH

General Info

Project: King Abdullah International Gardens Location: Central

Ref/Tag: FCU-1-3-1-(A-B) Quantity: 2

Revision: 00 Date: 2022-07-26 17:21

External
Air Flow Static Pressure Altitude
Input Conditions

708.0 50.00 2,034.12 Total Entering Entering Water Entering Delta

Cooling Data
LPS Pa ft Capacity Dry Bulb Wet Bulb Flowrate Water Temp

7.520 29.00 17.63 0.2998 6.00 6.00

Voltage Phases Frequency kW °C °C LPS °C °C
Volts Phase Hertz
230V 1 60Hz

Selected Unit Model

DWX18

Cooling Performance Data

Total Cooling Capacity 12.57 kW
Total Sensible Capacity 11.49 kW
SHR 0.9
Air Flowrate 710.0 LPS
Fan Speed MED
Entering Water Temp 6.00 °C
Leaving Water Temp 12.00 °C
Water Flowrate 0.5003 LPS
Water Pressure Drop 2.93 kPa

Psychrometric Data
Entering (On Coil) Leaving (Off Coil)
Output Performance

Dry Bulb 29.00 °C Dry Bulb 18.36 °C

Wet Bulb 17.63 °C Wet Bulb 14.58 °C

Cooling Coil Data

Coil Tube Diameter 3/8 Inch
Rows 4
Fins Per Inch 14

Electrical Data General Data

Blower Motor 520 W Weight 65 kg
Blower Motor FLA 3.58 A Pipe Connection In/Out - Cooling 5 / 8 - 5 / 8 in
MCA 4.48 A Unit Length See Drawings
MOCP 15 A Unit Width See Drawings
Unit Height See Drawings

Sound Power Data

Frequency (Hz) 125 250 500 1000 2000 4000 8000

dB 74 69 64 66 64 61 60
Products Certifications

of
