The Irrigation Innovators

Multi-stream technology maximizes the water-efficiency of your irrigation systems

eaturing a unique, multi-trajectory rotating stream delivery system that achieves water-conserving results, the MP Rotator is a revolutionary product, unlike anything else in the field of irrigation. A multi-stream rotor the size of a spray nozzle, the MP Rotator features only one moving parttechnology that assures proven reliability. It fits any conventional spray head body or shrub adapter, transforming one into a high uniformity, low precipitation rate sprinkler that boasts an industry first: true matched precipitation at any arc and any radius. The MP Rotator is ideal for new systems, with ultimate design flexibility (from 1.2 m strip to 9.1 m radius), as well as lower installation costs and better system efficiency. Its also perfect for revitalizing older systemsa retrofit can solve both low pressure and poor coverage problems. Plus, its the solution for slopes and tight soils, as the low precipitation rate radically reduces runoff. To save water, solve problems, and simply do a better job of irrigating, make the switch to the MP Rotator.

MP 1000

MP 2000

MP 3000

MP Strips

MP Corner

Features & Benefits

Revitalize Old Systems

With so many models to choose from, the MP Rotator has the perfect solution for rejuvenating an older spray system without requiring a new point of connection, new lateral lines, or new valves. Some models even make it possible to eliminate existing heads, saving additional labor and material costs. Even better, independent water audits have shown potential water savings of up to 30% when systems are retrofitted with MP Rotators.

Superior Efficiency Multiple rotating streams provide excellent uniformity Matched Precipitation Automatic matched precipitation even after arc and radius adjustment Minimal Runoff Low precipitation rate reduces runoff on slopes and tight soils Rotator Technology Proven in demanding agricultural conditions since 1987 Superior Dirt Tolerance Double-pop flushes on start-up and shut-down Simple and quick adjustments Easy arc adjustment, easy radius adjustment up to 25%, no nozzle to change

Setting a New Standard for Water Efficiency in the Turf and Landscape Industry
The MP Rotators multi-trajectory, revolving streams apply water much more slowly and uniformly than conventional spraysespecially after adjustment has been made to both the radius and the arc. On slopes and clay-like soils, this allows water to soak into the landscape instead of running off and being wasted. In fact, independent audits have shown that water usage can be reduced by up to nearly one-third of current levels when conventional sprays are replaced with MP Rotator sprinklers. Additional watersaving advantages include better windresistance, less misting, and the ability to handle reclaimed water.

NEW
Say hello to the MPR40!
Until now MP Rotator has been seen on many different spray bodies, but never has a spray body been created just for the MP Rotator. Introducing the MPR 40, a spray body that optimizes the performance of the MP Rotator. It provides the perfect combination of Hunter's famous Pro-Spray body with a specially calibrated pressure regulator. This gives the MP Rotator a consistent 2.6 Bars output, meaning even coverage and optimal performance. Pressure regulated to 2.6 Bars for optimum efficiency with the MP Rotator. The extra tough co-molded wiper seal prevents leaks even at higher pressures.

Rotating Multiple Streams: Actually a Powerful Conservation Tool

The MP Rotators multiple, rotating streams are fascinating to watch. But form follows function in a quality irrigation product, so each MP Rotator stream is designed to complement its partners. The MP Rotators wind-resistant, multi-trajectory streams apply water much more slowly and uniformly than conventional misters and sprays especially after adjustments. This prevents unwanted wet spots and ugly brown spots from appearing during the heat of the summer.

Hunters Line of Proven Water Saver Products: Because Every Drop Counts
As our population grows, but our sources of water do not, there will be less of the wet stuff to go around. Never before has water conservation seemed so important. To that end, Hunter has assembled a family of products that makes it possible for you to create a more efficient system. In fact, no other manufacturer offers such a wide array of water-saving components that covers all aspects of irrigation. Visit www.HunterIndustries.com to see all our Proven Water Savers.

Two-piece ratchet design makes head adjustment quicker and more precise. Heavy-duty body and cap construction with multithread buttress design withstands the harshest environments.

Maintain Matched Precipitation Any Model, Any Arc, Any Radius

Adjustable Radius
All models of the MP Rotator allow for easy radius adjustment of up to 25% while maintaining automatic matched precipitation. 90 to 210 210 to 270 360 MP1000 -360

Adjustable Arc

MP1000
Stream Height @ 2 bar = 0.4 m

MP1000-90-210

Not Available
2.5 m 4.6 m
Radius Reduction

Maroon MP2000-90-210 MP2000-210-270

Olive MP2000-360

MP2000
Stream Height @ 2 bar = 1 m

4m
Radius Reduction

6.4 m

Black MP3000-90-210

Green MP3000-210-270

Red MP3000-360

MP3000

Stream Height @ 2.8 bar = 2 m

6.7 m

Radius Reduction

9.1 m

Blue

Yellow

Gray

MP Corner
Stream Height @ 2 bar = 0.25 m

MPC

45 to 105
MP1000 radius reduced to 2.7 m
3.7 m 45

6.7 m

4.5 m
Radius Reduction

The MP Corner is designed for tight corners that are difficult to irrigate properly with conventional sprinklers. It has an adjustable arc from 45 to 105, maintains MPR at any arc, any radius and can be placed on the same zone with any other MP Rotator model.

Turquoise

MP Corner at full radius

MP1000 radius reduced to 2.7 m

MP Strip
Example with triangular spacing.
MP Side Strip 1.5 m MP Left Strip 4.6 m 4.6 m MP Side Strip 4.6 m MP Side Strip MP Right Strip 4.6 m

MPLS (Left Strip)

MPCS (Center Strip)

MPRS (Right Strip)

The three MP Strip models of the MP Rotator family offer an exciting alternative to irrigate strip areas. Strip models offer improved uniformity and excellent wind-fighting ability. The reduced flow rate compared to conventional sprays makes longer runs and/or fewer zones possible.

Ivory

Brown

Copper

Models
MP1000 (Female Thread) & MP1000T (Male Thread)
Radius Range 2.4 -4.6 m including all pressure and radius adjustment influence Pressure Range 2.1 - 3.8 Bars Application Notes Low trajectory, perfect for smaller areas For minimum radius, recommended install on a 2.1 Bars regulated Institutional Spray body Not available in a 210-270 model Radius Range 4.0 - 6.4 m including all pressure and radius adjustment influence Pressure Range 1.7 - 3.8 Bars Application Notes Flow rate is about 1/3 of a 4.6 m spray head; and yet has greater radius and higher uniformity For minimum radius, recommended install on a 2.1 Bars regulated Institutional Spray body Radius Range 6.7 - 9.1 m including all pressure and radius adjustment influence Pressure Range 2.1 - 3.8 Bars Application Notes Flow rate is about the same as a 4.6 m spray head; and yet has greater radius and higher uniformity For minimum radius, provide adjustable zone pressure regulation; Installation on a 2.1 Bars pressure regulated Institutional Spray body is not recommended if radius reduction is needed For maximum radius, provide pressures over 2.8 Bars Radius Range 2.4 - 4.6 m; Pressure Range 2.1 - 3.8 Bars Application Notes Designed for application in areas with less than 90 degrees of arc area necessary Does not require adjacent sprinklers to reach into the first 0.9 - 1.5 m of coverage Flow Range 0.5 l/min (0.03 m3/hr) @ 2.1 Bars (Min. radius) 1.0 l/min (0.06 m3/hr) @ 55 PSI (Max. radius) Pressure Range 2.1 - 3.8 Bars Application Notes Matched precipitation even after radius reduction with head to head spacing Can be used on the same zone with the MP1000, MP2000 or MP3000 and still maintain matched precipitation Adjustable right edge Flow Range 1.0 l/min (0.06 m3/hr) @ 2.1 Bars (Min. radius) 1.9 l/min (0.12 m3/hr) @ 3.8 Bars (Max. radius) Pressure Range 2.1 - 3.8 Bars Application Notes Matched precipitation even after radius reduction with head to head spacing Can be used on the same zone with the MP1000, MP2000 or MP3000 and still maintain matched precipitation Adjustable right edge to fit curved strips Flow Range 0.5 l/min (0.03 m3/hr) @ 2.1 Bars (Min. radius) 1.0 l/min (0.06 m3/hr) @ 55 PSI (Max. radius) Pressure Range 2.1 - 3.8 Bars Application Notes Matched precipitation even after radius reduction with head to head spacing Can be used on the same zone with the MP1000, MP2000 or MP3000 and still maintain matched precipitation Edges are fixed

A Closer Look at the MP Rotator

Color Coded Identification Ring Model number and arc clearly visible whether the system is on or off! Left Edge Indicator Arc is clockwise from this mark. Inlet Screen CAUTION: Do not run the MP Rotator without the inlet screen provided!.
* While water is on, use orange tool to engage built-in ratchet; move past the left or right stop until edge is aligned

Radius Adjustment Screw Turn clockwise to decrease radius, builtin slip clutch prevents damage from over adjustment. Arc Adjustment Ring* Turn clockwise to increase the radius.
The MP Rotator can be adjusted with just a screwdriver and your hand, but the MPR Tool makes adjustments even easier!

MP2000 (Female Thread) & MP2000T (Male Thread)

MP-3000 (Female Thread) & MP-3000T (Male Thread)

MP Corner

MP Left Strip

MP Side Strip

Versatility of MP Side Strips

Yet another technological breakthrough, the MP Rotator Strip. You are now able to take all the benefits of the MP Rotator into spaces you never thought possible. The MP Rotator strip is the perfect solution for small areas of turf or plants. As the name suggests, you have total control in watering strips and still maintain unsurpassed uniformity SPECIFICATION GUIDE and performance. A new dimension in EXAMPLE: MP2000* - 90-210 watering flexibility is available now.
MODEL MP1000 MP2000 MP3000 MP CORNER MP STRIP ADJUSTABLE ARC 90-210 = 90 to 210 210-270 = 210 to 270 (Not available for MP1000) 360 = 360 45-105 = 45 to 105 LEFT SIDE RIGHT

MP Right Strip

* Note: Add T to to specify male thread.

Hunter Industries Incorporated The Irrigation Innovators 1940 Diamond Street San Marcos, California 92078 TEL: (1) 760-744-5240 FAX: (1) 760-744-7461 www.HunterIndustries.com

2007 Hunter Industries Incorporated INT-620 10/07

MP Rotator Performance Data Metric MP1000

Radius: 2.5 to 4.6 m Adjustable Arc and Full Circle Color Code: Maroon or Olive Radius m Color LPH Flow LPM Precip mm/hr

MP2000

Radius: 4 to 6.4 m Adjustable Arc and Full Circle Color Code: Black, Green, or Red Radius m Color LPH Flow LPM Precip mm/hr

MP3000

Radius: 6.7 to 9.1 m Adjustable Arc and Full Circle Color Code: Blue, Yellow, or Gray Radius m Color LPH Flow LPM Precip mm/hr

Arc

Pressure Bars kPa

90

Black = 90 to 210

180

1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75 1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75

175 200 225 250 275 300 325 350 375 175 200 225 250 275 300 325 350 375

--3.7 3.8 4.0 4.1 4.3 4.3 4.4 4.6 --3.7 3.8 4.0 4.1 4.3 4.3 4.4 4.6

--72 76 81 84 88 91 94 97 --85 89 95 98 102 106 109 113

--1.20 1.27 1.35 1.40 1.46 1.51 1.56 1.62 --1.41 1.48 1.58 1.63 1.71 1.76 1.82 1.89

--11 10 10 10 10 10 10 9 --11 10 10 10 10 10 10 9

--12 12 12 11 11 11 11 11 --13 12 12 11 11 11 11 11

4.9 5.2 5.3 5.5 5.8 6.1 6.2 6.4 6.4 4.9 5.2 5.3 5.5 5.8 6.1 6.2 6.4 6.4 4.9 5.2 5.3 5.5 5.8 6.1 6.2 6.4 6.4 4.9 5.2 5.3 5.5 5.8 6.1 6.2 6.4 6.4

133 141 150 160 168 174 182 189 193 155 165 175 185 195 205 214 222 228 199 212 225 238 249 261 272 282 293 265 283 300 317 333 348 362 375 384

2.22 2.35 2.50 2.67 2.80 2.90 3.03 3.15 3.22 2.58 2.75 2.92 3.08 3.25 3.42 3.57 3.70 3.80 3.32 3.53 3.75 3.97 4.15 4.35 4.53 4.70 4.88 4.42 4.72 5.00 5.28 5.55 5.80 6.03 6.25 6.40

11 11 11 11 10 10 9 9 9 11 11 11 10 10 10 9 9 10 11 11 11 10 10 10 9 9 9 11 11 11 10 10 10 9 9 9

12 13 13 12 12 11 11 10 11 12 13 13 12 12 11 11 10 11 12 13 13 12 12 11 11 10 11 12 13 13 12 12 11 11 10 10

Blue = 90 to 210

1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75

175 200 225 250 275 300 325 350 375 Maroon = 90 to 210

--3.7 3.8 4.0 4.1 4.3 4.3 4.4 4.6

--36 38 41 42 44 45 47 49

--0.61 0.63 0.68 0.70 0.73 0.75 0.78 0.81

--11 10 10 10 10 10 10 9

--12 12 12 11 11 11 11 11

5.2 5.5 5.6 5.8 6.1 6.4 6.6 6.7 6.7

71 74 80 86 91 94 97 101 106

1.18 1.23 1.33 1.43 1.52 1.57 1.62 1.68 1.77

11 10 10 10 10 9 9 9 9

12 11 12 12 11 11 10 10 11

7.6 8.2 8.4 8.5 9.1 9.1 9.1 9.1 9.1 7.6 8.2 8.4 8.5 9.1 9.1 9.1 9.1 9.1 7.6 8.2 8.4 8.5 9.1 9.1 9.1 9.1 9.1 7.6 8.2 8.4 8.5 9.1 9.1 9.1 9.1 9.1 7.6 8.2 8.4 8.5 9.1 9.1 9.1 9.1 9.1

158 166 175 185 195 203 212 220 228 329 353 373 393 413 431 449 466 481 384 411 436 459 481 502 523 542 562 501 530 560 589 619 646 673 701 727 659 703 745 786 825 862 897 931 964

2.63 2.77 2.92 3.08 3.25 3.38 3.53 3.67 3.80 5.48 5.88 6.22 6.55 6.88 7.18 7.48 7.77 8.02 6.40 6.85 7.27 7.65 8.02 8.37 8.72 9.03 9.37 8.35 8.83 9.33 9.82 10.32 10.77 11.22 11.68 12.12 10.98 11.72 12.42 13.10 13.75 14.37 14.95 15.52 16.07

11 10 10 10 9 10 10 11 11 11 10 11 11 10 10 11 11 12 11 10 11 11 10 10 11 11 12 12 10 11 11 10 10 11 11 12 11 10 11 11 10 10 11 11 12

13 11 12 12 11 11 12 12 13 13 12 12 12 11 12 12 13 13 13 12 12 12 11 12 12 13 13 13 12 12 12 11 12 12 13 13 13 12 12 12 11 12 12 13 13

210

270

Olive = 360

* To obtain full radius reduction for the MP1000 and MP2000, operate at a maximum of 2.1 Bars (207 kPa). ** When operating the MP3000 at full radius reduction maintain a minimum pressure of 2.8 Bars (276 kPa) to assure reliable operation. *** Lower end radius is achieved by using radius adjustment screw. Flow adjusts with radius to maintain matched precipitation. Note: Precipitation rates are based on head-to-head throw coverage.

MP Rotator Performance Data Metric MP Corner

Radius: 2.4 to 4.6 m Adjustable Arc Color Code: Turquoise Radius m Color

MP Rotator Performance Data Metric MPLCS515 MPRCS515 MPSS530

LPM 0.61 0.63 0.68 0.70 0.73 0.75 0.78 0.81 1.15 1.27 1.31 1.40 1.44 1.57 1.63 1.67 1.73 1.34 1.48 1.53 1.63 1.70 1.83 1.88 1.94 2.00 Nozzle Model Pressure Bars kPa 200 225 250 275 300 325 350 375 200 225 250 275 300 325 350 375 200 225 250 275 300 325 350 375 Color Unadjusted Reduced Precip Rate Radius LPH Radius LPH mm/hr 43 45 48 50 52 54 56 58 85 90 95 100 104 108 113 117 43 45 48 50 52 54 56 58 30 33 35 36 38 40 41 43 60 66 69 73 76 79 83 86 30 33 35 36 38 40 41 43 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12 12

Arc

Pressure Bars kPa

Flow LPH

45

Brown

105

2.00 2.25 2.50 2.75 MP Side Strip 3.00 3.25 3.50 3.75

Copper

90

1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75 1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75 1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75

175 200 225 250 275 300 325 350 375 175 200 225 250 275 300 325 350 375 175 200 225 250 275 300 325 350 375

--3.5 3.8 4.0 4.1 4.3 4.3 4.4 4.5 3.2 3.5 3.8 4.0 4.1 4.3 4.3 4.4 4.5 3.2 3.5 3.8 4.0 4.1 4.3 4.3 4.4 4.5

--36 38 41 42 44 45 47 49 69 76 79 84 86 94 98 100 104 80 89 92 98 10 2 110 113 117 120

2.00 2.25 2.50 2.75 MP Left Strip 3.00 3.25 3.50 3.75 2.00 2.25 2.50 2.75 MP Right Strip 3.00 3.25 3.50 3.75

Turquoise = 45 to 105

Ivory

Gray = 360

Red = 360

360

1.75 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.75

175 200 225 250 275 300 325 350 375

--3.5 3.8 4.0 4.1 4.3 4.3 4.4 4.5

--144 153 161 169 177 183 190 195

--2.40 2.55 2.69 2.81 2.94 3.05 3.17 3.25

--12 11 10 10 10 10 10 10

--14 13 12 12 11 11 11 11

Yellow = 210 to 270

Green = 210 to 270
