RIVERTRACE ENGINEERING MARINE PRODUCTS

SMART ODME

Rivertrace Engineering is a market leader with over 25 years experience of Oil in Water Monitoring. RTE manufacture oil content monitors for the marine, offshore and industrial markets with up to date engineering solutions incorporating PFM technology. Our client list includes most of the worlds separator OEMs, shipyards and vessel operators. We have IMO type approvals for both Bilge and Ballast monitors. Our global network of agents ensures local service at most ports. S M A R T C E L L 15ppm OCM MEPC 107 (49) Smart ODME Pump - Measuring Cell Smart ODME Computer Module

The Oil Discharge Monitoring Equipment (Smart ODME) has been designed to provide means of monitoring, recording and controlling the ballast discharge in accordance with the requirements of MEPC 108(49). Discharge limits are set at 30 Litres per nautical mile and a total discharge expressed as a proportion of the previous S M A R T S A F E - Bilge Overboard Security System O C D 5 0 M - Boiler Condensate/Cooling water monitor cargo for dirty ballast. The requirements of the MARPOL Convention are that all oiltankers with a gross tonnage of 150 GRT and above must have an oil discharge monitoring and control system

installed, incorporating an approved oil content meter, with a starting interlock and an automatic overboard valve control system. The Smart ODME includes all components required to meet MEPC 108(49) and is designed for ease of operation, installation and maintenance. Incorporates a simulation operating mode to aid system demonstration to PSC surveyors. The requirements in IMO Resolution MEPC 108(49) apply to tankers with a date of keel laying or equivalent stage of construction of 1st of January 2005 or later.

S P E C I A L I S T

I N

W A T E R

Q U A L I T Y

M O N I T O R I N G

For more detailed technical specification, please see over:

ISO 9001 FM 40958

Rivertrace Engineering Limited Unit P, Kingsfield Business Centre Philanthropic Road Redhill Surrey RH1 4DP England Tel: +44 (0)1737 775500 Fax: +44 (0)1737 775501 Email: sales@rivertrace.com www.rivertrace.com
PubNo: 1/0710/0

1 Smart ODME 4pp.qxd:Rivertrace Data sheet 2

18/7/10

07:56

Page 3

SMART ODME

O D M E L AY O U T

Measurement Oil types: Clean water calibration: Oil measurement range: Resolution: Accuracy oil + solids: User Interface Display: Control + Setup: Input / Output Output: USB and RS232 Log Input: GPS: Data Storage and Retrieval Calibration data: Storage data: Data retrieval: Environmental & Sample Ambient temperature: Sample / clean water flow rate: Sample / Inlet pressure: System and Supply Supply voltage: Zenner Barrier/Computer Module: Motor: Supply voltage Consumption: Approvals: Mounting options: 115 / 230V ac, 50 - 60Hz (Switchable) 380-440V ac, 50-60Hz, 3 phase < 50 VA including solenoid valve IMO MEPC 108 (49) and GL + USCG 3U 19 Rack or Cabinet (Computer Module) -10 to +50C 0.5 - 4.0 litres / min 1 bar 200 Contact Closures per nautical mile NMEA 0183 As Per MEPC 108(49) Requirements Automatic 0 - 1000 ppm all types 1 ppm As Per MEPC 108(49) Requirements

4 line x 20 alphanumeric back lit LCD display 3 button keypad incorporating real time system display

Stored onboard microcontroller Stored onboard mounted memory media via LCD display or download to PC with Hyperterminal
