GOVERNMENT POLYTECHNIC GONDIA

Department Of Civil Engineering

Micro Project PPT

The Power of
Orthogonal Lemi's
and Theorem: Illustrated
non orthogonal force ON
Examples
‘Application Of Principle
Transmissibility Force’

Under The Guidance Of

Submitted By: Dr. R. Gawande
Maharashtra State Board of Technical Education,
 Sudhir Shende - 13 Mumbai (Autonomous) (ISO-9001-2008) (ISO/IEC 27001:2013)
 Bhuvan Bisane - 14 Academic Year 2022-2023
 Index

• R E S U LT A N T O F F O R C E S Y S T E M :
1. R e s u l t a n t o f C o n c u r r e n t F o r c e s
2. R e s u l t a n t o f N o n - C o n c u r r e n t F o r c e s
• PA R A L L E L F O R C E S Y S T E M :
1. C h a r a c t e r i s t i c o f a F o r c e
• MOMENT OF A FORCES:
1. M o m e n t o f C o p l a n a r F o r c e s
2. M o m e n t o f a F o r c e a b o u t a P o i n t a n d a n
Axis
 The Principle oF Transmissibility

F F If we concerns only about the

?
external resultant effects on rigid
= body
.

We can slide the force along its

line of action.
(force can be considered as sliding
vector)

“A force may be applied at any point on its given line of

action without altering the resultant effects external to the
rigid body on which it acts.”
 PARALLEL FORCES
SYSTEM
Forces whose line of action are parallel to each
other & all of them act in same direction.
 FORCE
An agent which produces or tends to produce ,
destroy or tends to destroy motion of a body is called
force.
Unit of force is Newton.
It is a vector quantity.
 RESULTANT OF CONCURRENT FORCE
SYSTEM
1. Resultant of Concurrent Forces:
The resultant of a concurrent force system can be defined as the
simplest single force which can replace the original system
without changing its external effect on a rigid body.

2. Resultant of Non-Concurrent Forces:

The resultant will not necessarily be a single force but a force
system comprising a force or a couple or a force and a couple.
RESULTANT OF FORCE SYSTEM
 Types of Force System
 RESULTANT OF FORCE SYSTEM

1. Resultant of Concurrent Forces:

The resultant of a concurrent force system can be defined as the
simplest single force which can replace the original system
without changing its external effect on a rigid body.
 Coplanar Concurrent Force
 Non-Coplanar Concurrent Force

2. Resultant of Non-Concurrent Forces:

The resultant will not necessarily be a single force but a force
system comprising a force or a couple or a force and a couple.
 CoplanarNon-Concurrent Force
 Non-Coplanar and Non-Concurrent Force
 Resultant of Coplanar Concurrent
Forces:
 CONTACT FORCES
Force produced by direct contact of bodies is
known as contact force.
It may be of pull type or push type.
