Balluff Object Sensing

Object Detection
Innovative sensor technology for all areas of automation

With over 50 years of sensor experience, Balluff is a leading global Benet from comprehensive
sensor specialist with its own line of connectivity products for every sensor expertise from a single
area of factory automation. Balluff is based in Germany and has a source. Achieve solutions
tight international network of 54 representatives and subsidiaries. suited to your requirements.
Balluff stands for comprehensive systems from a single source,

continuous innovation, state-of-the-art technology, highest
quality, and greatest reliability. That's not all: Balluff also stands
for exceptional customer orientation, customized solutions, fast
worldwide service, and outstanding application assistance.
High-quality, innovative products tested in our own accredited

laboratory and a quality management system certied according
to DIN ISO 9001 (EN 2008) form a secure foundation for optimized
added value for our customers.
Whether electronic and mechanical sensors, rotary and linear

transducers, identication systems or optimized connection
technology for high-performance automation, Balluff masters not
only the entire technological variety with all of the different operating
principles, but also provides technology that fullls regional quality
standards and is suitable for use worldwide. Wherever you are in
the world, Balluff technology is never far away. You won't have to
look far for you nearest Balluff expert.
Balluff products increase performance, quality and productivity

around the world every day. They satisfy prerequisites for meeting
demands for greater performance and cost reductions on the global
market. Including in the most demanding areas. No matter how
stringent your requirements may be, Balluff delivers state-of-the-art
solutions.
2 For more information, visit us online!

Object Detection
Innovative sensor technology for all areas of
automation
Photoelectric sensors 14
Inductive sensors 466
Capacitive sensors 768
Magnetic cylinder sensors 850
Industrial networking and connectivity A selection 912

You will nd many additional products in our total product line
catalog, "Industrial Networking and Connectivity
Basic information and denitions 952
Index 1010
www.balluff.com 3
Automobile, factory automation, metal processing,
energy, hydraulics and pneumatics,
lling and packaging, handling and automation,
plastics processing and many more.

Object Detection
automation
www.balluff.com 5
Identication, Networking and Connectivity
Rugged control components from network to sensor
Industrial Identication
Industrial Networking
and Connectivity
Industrial RFID systems BIS, Vision Sensors BVS, connectors and
connection cables BCC, valve connectors BCC, passive splitter boxes
BPI, active splitter boxes BNI, IO-Link, inductive couplers BIC, bus
systems (Probus, Pronet, CC-Link, Devicenet, Ethernet, IO-Link),
wireless systems BWT, power supplies BAE, electrical equipment BAE
HMI
Controller
Networking and
connectivity
Sensors
and
solutions
www.balluff.com 7
Object Detection Sensors
Linear Position Sensing
Fluid Sensors
Mechanical Accessories
Inductive sensors BES, magnetic eld cylinder sensors BMF, photoelectric sensors BOS, capacitive sensors BCS for
object detection, ultrasonic sensors BUS for object detection, ber optic devices BFB, through-beam fork sensors
BGL, optical window sensors BOW, light grids BLG, contrast sensors BKT, luminescence sensors BLT, color sensors
BFS, mechanical and inductive single and multiple position switches BNS, micropulse transducers BTL, magnetic
linear encoder system BML, incremental encoders BDG, absolute encoders BRG, inductive displacement system
BIW, inductive distance sensors BAW, magnetoinductive distance sensors BIL, capacitive distance sensors BCW,
photoelectric distance sensors BOD, ultrasonic sensors BUS for analog distance measurement, pressure sensors
BSP, capacitive sensors BCS for level detection, brackets and mountings, mounting system BMS

Sensors and Solutions
Rugged control components from network to sensor
HMI
Controller
Networking and
connectivity
Sensors
and
solutions
www.balluff.com 9
www.balluff.com
The most up-to-date information
Conveniently Use
the Most Current Data
Information available online Product overview 2D and 3D product data
all over the world
Data sheets
CAD drawings in 2D or 3D
Catalogs
Brochures
Manuals
Software descriptions
User's guides
FAQs
Worldwide addresses
News and events Company information
Service and support We are happy to help
www.balluff.com 11
Comprehensive
sensor expertise
from a single source
Photoelectric Inductive Capacitive

sensors sensors sensors
Photoelectric sensors check presence, Inductive sensors are used to control, Capacitive sensors detect objects and ll
size, color, distance and thickness. They position and check processes in levels of all liquids, granular materials and
are excellent specialists with different automation technology. The robust powders, including non-conductive mate-
focuses: sensors detect objects in the metal range. rials, directly or through a container wall.
Part recognition and counting Non-contact, wear-free, Non-contact, wear-free,

Stack height monitoring contamination-resistant, non-reactive, bounce-free output signal
Detection through glass short-circuit protected Simple sensor replacement,
Small parts alignment Available in designs from 3 mm container seal is unnecessary
Brand recognition to 8080 mm square dimensions
Fill level detection
and much more
Page 14 Page 466 Page 768

Object Detection
automation
Magnetic Industrial networking

cylinder sensors and connectivity
The primary application for magnetic Complete product line for quickly and
cylinder sensors is detecting piston easily connecting sensors and systems
positions on pneumatic and hydraulic to all networks. Usable anywhere in the
cylinders. world. For powerful performance
Can be used universally All bus systems shock and

Very precise, reliable switching behavior vibration-resistant. IP 67 guaranteed!
Long service life due to lack of contact Inductive coupler for contactless trans-
and wear mission of data and energy
Vibration-resistant Passive distributor for the best
Space-saving mounting thanks to integration
small sizes Comprehensive portfolio of plug
connectors and connection lines for all
areas of automation
The entire connection design is
also available in IO-Link versions
Page 850 Page 912

www.balluff.com 13
Photoelectric
Sensors
Photoelectric sensors for object detection
Photoelectric sensors check presence, size, color, distance
and thickness.
They are excellent specialists with completely different focuses:
Part recognition and counting
Stack height monitoring
Detection through glass
Small parts alignment
Brand recognition
Fill level detection and much more.
The wide Balluff portfolio offers every light type, whether red light,
infrared or laser technology. In different ranges. With and without
background suppression.
Various designs also in mini version ensure a wide variety of
possible applications. Our photoelectric sensors are optimized for
robotics, automation, installation and handling.

Photoelectric Sensors
Contents
Photoelectric sensors
Performance spectrum 16
Product overview 22
Photoelectric standard sensors

Cylinder designs 36
Block designs 140
Photoelectric special sensors

Optical ber basic devices BFB/BOS 246
Fiber optics BFO 272
Contrast sensors BKT 322
Luminescence sensors BLT 336
Color sensors BFS 342
Fork sensors BGL_A 348
Analog fork sensors BGL_C 368
Angle sensors BWL 372
Dynamic optical windows BOW 384
Light grids BLG 390
Photoelectric distance sensors

for analog distance measurement
Block designs 396
Special accessories for photoelectric sensors

Reectors 420
Fasteners 428
Optical accessories 452
Fiber optic accessories 462
Basic
information
and denitions
can be found
on page 952.
www.balluff.com 15
Performance spectrum
Checking stack height

Through-beam sensors that consist of a emitter and receiver can be
installed one on top of the other. Each through-beam sensor then
scans a specic stack height. The accuracy of the scan is within a
few millimeters, if apertures are used.
Querying the size and content of containers

The retroreective sensor (1) indicates the presence of the box.
The pulse duration can be used to count or measure box lengths.
The diffuse sensor (2) with background suppression checks the
contents of the box. Its range is adjustable.
Tracking a hoist
The through-beams are assigned so that the uppermost metal plate
interrupts the light beam. The beam path is open when the metal
plate is removed for processing. The through-beams provide a
switching signal, and the hoist is automatically reset to the height of
a metal plate.

Photoelectric
sensors
Scanning a read mark Performance
spectrum
In order to recognize a reading mark, a base device and plastic Product
ber optics are used. This way a mark such as a bright line can overview
be scanned on a dark background, as occur on belts, hoses or
containers. Photoelectric
standard
sensors
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Checking drill breakage

Using a through-beam sensor with double-slotted apertures, a drill
breakage check can be carried out from 2 m away. Drills larger than
approx. 2 mm diameter can be checked this way. If even smaller
drills (down to 1 mm ) have to be checked, then a laser through-
beam sensor can be used.
Detecting a groove Detecting small parts

To sense a groove on a bearing With an optical adapter such as the BOS 18-PK-1, small parts can
pillow, a diffuse sensor is be measured and the background simultaneously suppressed.
adjusted using a ber optic In this way, with a sensing distance of up to 13 mm, for example,
cable so that the bearing bers with a diameter of 0.05 mm can be queried, where the
pillow is reliably detected. The color plays a subordinate role. Diffuse sensors with background
groove interrupts the beam suppression enable larger ranges.
(no reection). And the switch
changes its output condition.
www.balluff.com 17
Querying packaging contents

A through-beam sensor is used in order to query the content of a
package (e.g., bandages). To do so, the emitter and receiver are
arranged so that the light beam goes through the packaging. If the
packaging is empty, the light is sufcient to light up the receiver. If
it is lled, the packaging contents interrupt the emitter's light beam.
And the sensor switches.
Querying ll level in transparent containers

During the ll level query in a transparent container (cylinder), a
diffuse sensor with ber optics is used as a through-beam sensor.
If no liquid is at the sensor height, the light beam is not broken, so
that it hits the receiver. If enough uid is available, the light beam
is deected away from the receiver. The switch changes its output
condition.
Recognizing different Checking sag

diameters Two through-beam sensors can be used to control the positioning
In order to be able to recognize of a roller conveyor. In addition, the through-beams are arranged
different shaft diameters, a above each other so that at optimum slack, the lower light beam is
diffuse sensor with background clear and the upper beam interrupted. If both light beams are clear,
suppression (HGA) is used in more roll tension is needed. If both are interrupted, there is too much
such a manner that it switches material (slack) present.
with large diameters. Small
diameters, on the other hand,
are suppressed as "background"
so that the sensor does not
switch.

Photoelectric
sensors
Positioning parts Performance
spectrum
In order to correctly position pivoted parts, its groove can be Product
scanned. A laser diffuse sensor with background suppression is overview
calibrated so that it recognizes the surface of the pivoted part. If the
light beam strikes the slot, the light is reected back to the sensor at Photoelectric
standard
a different angle. The switch recognizes this as a background signal sensors
and ignores it, i. e. changes its switching state.
Photoelectric
Checking ll level: Granular material in small packages special
Multiple sensors simultaneously check the content of a whole sensors
series of small packages on a conveyor belt.
Photoelectric
In addition, the user can shorten the plastic ber optics to the distance
desired length. Its standard length is 2 m. sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Detecting the bead of a camshaft

To detect whether a bead is present, a diffuse sensor with ber
optics is used. This ber optic is arranged on a level parallel to the
camshaft. If a bead is present on the camshaft, the light beam is
interrupted. With no bead, the beam path is free.
Checking the quality of workpieces

Multiple sensors with ber optic attachments simultaneously check
different features of a workpiece.
Only if all drill holes, screws, dimensional accuracies, surface
qualities etc. are present may the workpiece be processed further.
Later failures and downtime are thus avoided.
www.balluff.com 19
Sorting parts
In order to be able to sort parts of various heights, a through-beam
sensor is used. To do so, a teach-in process is used so that taller Checking threads
parts interrupt the light beam and can be sorted out. The quick and Prior to assembling nuts, a
secure teach-in enables quick adaptation to changed conditions. check needs to be made to
determine whether a thread is
present or not. If the thread is
present, they will reect the light
back to the ber optics and the
sensor will operate.
If the thread is missing, there will
be a total reection on the blank
wall of the drill hole, and as a
result, no light will be reected to
the ber optics. The sensor does
not switch.
Counting transparent bottles Checking packaging

Transparent objects absorb only In order to check whether a packaging is correctly closed, a through-
a little light. In order to measure beam sensor is congured so that the light beam runs just above the
them accurately, retroreective packaging. If it is not correctly closed, the obstructing lid interrupts
sensors with small hysteresis the light beam, and the through-beam sensor signals it.
are best suited. Through their
teach-in-buttons, the sensors
can additionally be set very
easily, and their conguration
can be changed even when the
process is running. Unnecessary
downtimes are thus prevented
easily.

Photoelectric
sensors
Checking completeness Performance
spectrum
Positioning and checking In order to be able to check an assembly process in detail, diffuse Product
equipment sensors with background suppression (HGA) are used. These sense overview
To bring the circuit board to a small objects with high precision and are not misled by different
colors. If details need to be measured even more accurately, we Photoelectric
particular inspection position, standard
a focused diffuse sensor (1) recommend laser sensors with background suppression. sensors
is used. The board crosses
the light beam of the sensor 2 Photoelectric
special
exactly in its focus. This enables sensors
maximum precision.
Through the small spot of light of Photoelectric
distance
the laser diffuse sensor (2) and sensors
its background suppression, it for analog
distance
can be checked whether even measurement
small components are present
on the board. 1 Special
accessories for
photoelectric
sensors
Final inspection of labels and caps Inspecting closing caps

For the nal inspection of dish detergent bottles, a check must Depending on installation
be made to determine whether the label and cap are attached. A circumstances and the required
contrast sensor is used for the label inspection. This distinguishes switching distance, a wide
between the relative reectivity of the label and the bottle. variety of diffuse sensors with
The cap is detected using a diffuse sensor with background background suppression can
suppression. The advantage of the background suppression is that if be employed. In this way, you
the cap is missing, the screw closure can be faded out. can choose excellent specialists
from the tightest installation
conditions, the maximum
resolution or high ranges.
Contact us.
www.balluff.com 21
Product overview
mini.s
Type BOS 08M BOS 12M BOS 12M BOS 18M BOS 18M
laser red light
Housing material Metal Metal Metal Metal Metal

Range/sensing distance
Through-beam sensor 0...1.1 m 0...5 m 0...3 m, 0...30 0...20 m, 0...20 m
emitter/receiver m 0...25 m
Retroreective sensor
Retroreective sensor 25...550 mm 0...1.5 m 4 m, 6 m 7m
with polarizing lter
with glass detection
Diffuse sensor 0...55 mm 0...100 mm, 1...400 mm, 1...300 mm,
0...200 mm, 1...600 mm 1...600 mm
0...400 mm
Diffuse sensor 0...24 mm, 30...150 mm,

with background suppression 10...60 mm 30...300 mm
Diffuse sensor with
foreground suppression
Technical data
Supply voltage 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
Output PNP PNP PNP PNP PNP

function NO/NC NO/NC NO/NC NO/NC NO/NC
Connection Connectors/ Connectors/ Connectors/ Connectors Connectors
cables cables cables
Ambient temperature 10...+60 C 5...+55 C, 10...+50 C 5...+55 C 5...+55 C
15...+55 C,
20...+60 C
Degree of protection as per IEC 60529 IP 67 IP 67 IP 67 IP 67 IP 67
Light Red light Infrared light/ Laser Infrared light/ Red light
red light red light
Special features
Page number 38 44 50 58 64

Product overview
Photoelectric
sensors
BOS 18M BOS 18M BOS 18M BOS 18M BOS 18M BOS 18E BOS 18KF BOS 18KF Performance
red light red light infrared laser laser with laser spectrum
Teach-in angle head angle head Product
overview
Metal Metal Metal Metal Metal Stainless steel Plastic Plastic Photoelectric
standard
sensors
0...20 m 0...16 m 0...50 m 0...50 m, 0...50 m 16 m 0...20 m 0...60 m
0...60 m
Photoelectric
10 m 4m 0.1...4.5 m special
5m 2m 7m 0.1...16 m 0.1...9 m 2m 0.1...5 m 0.1...16 m sensors
Photoelectric
0.1...1.7 m distance
sensors
for analog
1...500 mm 0...400 mm 1...800 mm 0...350 mm 0...250 mm 0...100 mm, 0...100 mm, 0...350 mm distance
0...200 mm, 0...400 mm, measurement
0...400 mm 0...700 mm
Special
accessories for
10...120 mm, 30...150 mm 0...40 mm 50...100 mm, photoelectric
sensors
40...120 mm 100 mm
40...100 mm
10...30 V DC 10...30 V DC, 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC

10...36 V DC
PNP PNP PNP PNP PNP PNP PNP PNP
NO/NC NO/NC NO/NC NO/NC NO/NC NO/NC NO/NC NO/NC
Connectors Connectors Connectors Connectors/ Connectors/ Connectors Connectors/ Connectors/
cables cables cables cables
5...+55 C 15...+55 C, 5...+55 C 5...+55 C, 5...+55 C 5...+75 C, 25...+55 C 10...+50 C
25...+55 C 10...+55 C, 20...+75 C
15...+55 C
IP 67 IP 67 IP 67 IP 65/IP 67 IP 67 IP 69K/IP 68 IP 67 IP 67
Red light Red light Infrared light Laser Laser Infrared light/ Infrared light/ Laser
red light red light
with DSC
72 74 78 82 86 98 106 114
www.balluff.com 23
Product overview
mini.s
Type BOS 18KW BOS 18KW BOS 30M BOS Q08M BOS Q08M BOS 2K
with laser with laser
angle head angle head
Housing material Plastic Plastic Metal Metal Metal Plastic

Through-beam sensor 0...15 m 0...50 m 0...2.2 m 0...3 m 0...1.2 m
transmitter/receiver
Retroreective sensor 0.1...3 m 0.1...9 m 25...550 mm 45...800 m
Retroreective sensor 0.1...1.7 m
with glass detection
with autocollimation
Diffuse sensor 0...80 mm, 0...250 mm 0...2 m 0...55 mm 1...55 mm
0...400 mm
Diffuse sensor 50...100 mm 5...50 mm 1...15 mm,
with background suppression 1...30 mm
Diffuse sensor with
foreground and background
suppression
Technical data
Supply voltage 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
Output function PNP PNP PNP/NPN PNP PNP PNP

NO/NC NO/NC NO/NC NO/NC NO/NC
Connection Connectors/ Connectors/ Connectors Connectors/ Connectors/ Connectors/
cables cables cables cables cables
Ambient temperature 25...+55 C 10...+50 C 20...+60 C 10...+60 C 0...+50 C 20...+50 C
Degree of protection as per IEC 60529 IP 67 IP 67 IP 65 IP 67 IP 67 IP 67

Light Infrared light/ Laser Infrared light Red light Laser Red light
red light
Special features
Page number 124 130 139 142 146 150

Product overview
Photoelectric
sensors
BOS 5K BOS 6K BOS 6K laser BOS 11K BOS 21M BOS 21M BOS 23K BOS 23K Performance
laser laser spectrum
Product
overview
Plastic Plastic Plastic Plastic Metal Metal Plastic Plastic Photoelectric

standard
sensors
0...10 m 0...6.5 m 0...20 m 0...20 m 0...60 m 0...25 m 0...30 m
Photoelectric
0.1...4 m 0.05...3 m 0...3.5 m, 0.1...8 m 0.1...20 m 0...14 m 0...14 m special
0...4 m sensors
0...500 mm, 0...2 m
Photoelectric
50...700 mm distance
0...500 mm 0...4 m 0...4 m sensors
for analog
distance
1...900 mm, 20...300 mm 10...450 mm 0.01...1 m, 0...600 mm 0...2 m 0...1.2 m measurement
50...200 m 0.05...2 m
Special
25...100 mm 20...60 mm, 10...50 70...200 mm 50...100 mm 70...800 mm 120...600 mm, accessories for
30...110 mm 150...800 mm photoelectric
sensors
70...200 mm
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC,

12...30 V DC
PNP PNP PNP PNP/NPN PNP PNP PNP PNP
NO/NC NO/NC NO/NC NO/NC NO/NC NO/NC NO/NC NO/NC
Connectors/ Connectors/ Connectors/ Connectors/ Connectors Connectors Connectors Connectors
cables cables cables cables
25...+55 C 20...+60 C 20...+60 C 20...+55 C 10...+50 C, 10...+50 C 20...+60 C 20...+60 C
25...+55 C
IP 67 IP 67 IP 67 IP 67 IP 67 IP 67 IP 67/IP 69K IP 67/IP 69K
Infrared light/ Red light Laser/red light Infrared light/ Infrared light/ Laser Red light Laser
red light red light red light
Teach-in Teach-in
160 170 176 184 194 200 208 210
www.balluff.com 25
Product overview
Type BOS 26K BOS 26K BOS 50K BOS 63M BOS 64K
laser laser
Housing material Plastic Plastic Plastic Metal Plastic

Through-beam sensor 0...60 m 0...50 m
transmitter/receiver
Retroreective sensor 0.1...18 m 0...10 m
Retroreective sensor 0...5.5 m 0...6 m,
with autocollimation 0...7 m,
0...20 m
Diffuse sensor 1...2000 mm 0.05...2 m
1...3500 mm
Diffuse sensor 30...300 mm, 30...150 mm, 200...2000 mm 0.2...6 m 0.2...2 m
with background suppression 150...600 mm 40...60 mm,
50...300 mm
Technical data
Supply voltage 10...30 V DC 10...30 V DC 10...30 V DC 15...30 V DC 24...60 V DC
24...240 V AC
Output function PNP PNP PNP 2 PNP Relay
NO/NC NO/NC NO/NC
Connection Connectors Connectors Connectors Connectors Wiring chamber
Ambient temperature 20...+60 C 15...+45 C, 5...+55 C, 10...+60 C 25...+50 C
20...+45 C 10...+60 C,
Light Infrared light/ Laser Red light Laser Infrared light/
red light red light
Special features Time function
Page number 218 220 228 236 240

Product overview
Photoelectric
sensors
BFB 75K BOS 73K BOS 6K BOS 18KF BOS18M
Performance
spectrum
Product
overview
Plastic Plastic Plastic Plastic Metal Photoelectric

standard
sensors
Depending on Depending on Depending on Depending on Depending on
fiber used fiber used fiber used fiber used fiber used
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
Depending on Depending on Depending on Depending on Depending on distance
fiber used fiber used fiber used fiber used fiber used measurement
Special
accessories for
photoelectric
sensors
10...30 V DC 11...26 V DC 10...30 V DC 10...30 V DC 10...30 V DC
PNP NPN PNP PNP NPN PNP NPN PNP NPN

NO/NC NO/NC NO/NC NO/NC NO/NC
Connectors/cables Connectors/cables Connectors Connectors Connectors
20...+60 C 25...+55 C 20...+60 C 25...+55 C 5...+60 C
IP 64 IP 54 IP 67 IP 67 IP 67
Red light Red light Red light Red light Infrared light
Teach-in Teach-in Teach-in Potentiometer Potentiometer

249 253 255 257 258
www.balluff.com 27
Product overview
Type BOS 16 K BOS 72 K BMOA BFO BMOA BKT 6K

Fiber optics Wired laser
ber optics
Housing material Plastic Plastic Plastic Glass, plastic Metal Plastic

Through-beam Depending on Depending on Depending on Depending on
fiber used fiber used fiber used fiber used
Diffuse sensor Depending on

with background suppression fiber used
Luminescence sensor 40...150 mm
Technical data
Supply voltage 11...26 V DC 10...24 V DC 10...30 V DC 10...30 V DC
22...250 V AC/V DC
Output function PNP/NPN PNP PNP/NPN PNP/NPN
NO/NC NO/NC NO/NC NO/NC
2-wire
Connection Connectors/ Connectors/ Analog Connectors/
cables cables Connectors/ cables
cables
Ambient temperature 20...+70 C 10...+55 C 10...+55 C 20...+85 C, -10...+55 C 20...+60 C
0...+170 C
Degree of protection as per IEC 60529 IP 67 IP 67 IP 65 45...+275 C IP 67 IP 67
Light Infrared light Red light Infrared light/ Various Infrared light Laser
red light
Special features with display Custom Focused light
lengths beam
possible
Page number 261 269 271 274 314 325

Product overview
Photoelectric
sensors
BKT 18KF BKT 21M BKT 67M BKT M BLT 18KF BLT 21M
Performance
spectrum
Product
overview
Plastic Metal Metal Plastic Plastic Metal Photoelectric

standard
sensors
Photoelectric
special
sensors
Photoelectric
10 mm2 mm 19 mm2 mm 9 mm3 mm 8...20 mm 0...40 mm distance
(18 mm) 4 mm sensors
for analog
distance
10...30 V DC 10...30 V DC, 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC measurement
PNP PNP/NPN PNP/NPN/ PNP/NPN PNP PNP Special

accessories for
NO/NC NO/NC Analog NO/NC NO/NC NO/NC photoelectric
sensors
NO/NC
Connectors/ Connectors Connectors Wiring chamber Connectors/ Connectors
cables cables
25...+55 C 25...+55 C 10...+55 C 10...+55 C 25...+55 C 10...+55 C
IP 67 IP 67 IP 67 IP 67 IP 67 IP 67
White light White light Red, green Red and green UV UV
and blue light light
Interchange- Teach-in
able optics
327 329 331 333 339 341
www.balluff.com 29
Product overview
Type BFS 26K BFS 33M BGL BGL BGL

true color red light pin point infrared
Housing material Plastic Metal Metal Metal Metal

Angle sensor
Color sensors 12...32 mm, up to 400 mm

15...30 mm,
18...22 mm,
Fork sensor 5, 10, 20, 30, 50, 5, 10, 20, 30, 50, 5, 10, 20, 30, 50,
80, 120, 180, 220 80, 120, 180, 220 80, 120, 180, 220
mm mm mm
Technical data
Supply voltage 12...28 V DC 24 V DC 10% 10...30 V DC 10...30 V DC 10...30 V DC
Output function 3 PNP 3 push-pull PNP PNP PNP
NO NO/RS 232 NO/NC NO/NC NO/NC
Connection Connectors Cables Connectors Connectors Connectors
Ambient temperature 10...+55 C +10...+55 C 10...+60 C 10...+60 C 10...+60 C

Light White light White light Red light Red light, Infrared
pin point
Special features various True color sensor Fluid
Light spot detection
sizes
Page number 345 347 350 354 358

Product overview
Photoelectric
sensors
BGL BGL 21 BGL_C BWL BWL BWL BWL
Performance
laser analog red light pin point infrared laser spectrum
Product
overview
Metal Metal Metal Metal Metal Metal Metal
Photoelectric
40, 54, 68, 90, 40, 54, 68, 90, 40, 54, 68, 90, 40, 54, 68, 90, standard
110 mm 110 mm 110 mm 110 mm sensors
Photoelectric
special
sensors
Photoelectric
distance
30, 50, 80, 2 mm 30 mm, sensors
for analog
120 mm 50 mm distance
measurement
10...30 V DC 10...30 V DC 18...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC Special

accessories for
PNP PNP/NPN PNP/analog PNP PNP PNP PNP photoelectric
NO/NC NO/NC NO/NC NO/NC NO/NC NO/NC NO/NC sensors
Connectors Connectors Connectors Connectors Connectors Connectors Connectors
10...+60 C 20...+60 C 5...+55 C 10...+60 C 10...+60 C 10...+60 C 10...+60 C

IP 67 IP 65 IP 65 IP 67 IP 67 IP 67 IP 67
Laser Infrared/ Red light Red light Red light, Infrared light Laser
red, green light Pin point
Transparent for stackable stackable stackable stackable
detection label sensing
362 367 370 374 376 378 380
www.balluff.com 31
Product overview
Type BWL BOW BLG BOD 6K BOD 21M BOD 26K

laser laser
Housing material Metal Metal Metal Plastic Metal Plastic

Angled light sensor 2222 mm, 20...80 mm 25...45 mm, 45...85 mm,
4343 mm, 20...200 mm, 30...100 mm,
4262 mm 20...500 mm 80...300 mm
Dynamic optical window 4080 mm, 20...80 mm 30...100 mm,
8080 mm, 80...300 mm
12080 mm
Light grid 0.15...2.1 m
Technical data
Supply voltage 10...30 V DC 10...30 V DC 24 V DC, 15...30 V DC 18...30 V DC 18...28 V DC,
18...30 V DC
Output function PNP PNP PNP/analog analog analog analog
NO NO NO PNP NO/NC PNP NO/NC PNP NO/NC
Connection Connectors Connectors Connectors Connectors/cables Connectors Connectors/cables
Ambient temperature 10...+60 C 10...+55 C 0...+55 C 20...+60 C 10...+50 C 0...+45 C,
10...+60 C
Degree of protection as per IEC 60529 IP 67 IP 65 IP 65 IP 67 IP 67 IP 67
Light Infrared light Infrared light Infrared light Red light Laser Laser
Special features Dynamic various Teach-in

measuring measurement
procedures eld heights
Page number 382 386 393 399 400 403

Product overview
Photoelectric
sensors
BOD 63M BOD 66M BOD 66M
Performance
laser laser spectrum
Product
overview
Metal Metal Metal
Photoelectric
200...2000 100...600 mm 200...2000 mm standard
mm,200...6000 sensors
mm
Photoelectric
200...2000 mm, 100...600 mm 200...2000 mm special
200...6000 mm sensors
Photoelectric
distance
sensors
for analog
15...30 V DC 18...30 V DC 18...30 V DC distance
measurement
analog analog analog
PNP NO PNP NO PNP NO Special
accessories for
Connectors Connectors Connectors photoelectric
10...+60 C 20...+50 C 20...+50 C sensors
IP 67 IP 65 IP 65
Laser Red light Laser
411 415 417
www.balluff.com 33
Photoelectric
Sensors
Photoelectric standard sensors
for object detection
Our broad portfolio of standard sensors provides the ideal solution
for every application, whether using through-beam, retroreective or
diffuse sensors. The sensors operate with visible red light, invisible
infrared light or incredibly precise laser light.
All of the sensors are robust and reliable even under harsh
ambient conditions or in complex applications.

Photoelectric Standard Sensors
Contents
Cylinder designs
BOS 08M 36
BOS 12M 42
BOS 18M 52
BOS 18E 97
BOS 18KF 104
BOS 18KW 122
BOS 30M 136
Block designs
BOS Q08M 140
BOS 2K 148
BOS 5K 158
BOS 6K 168
BOS 11K 182
BOS 21M 192
BOS 23K 206
BOS 26K 216
BOS 50K 226
BOS 63M 234
BOS 64K 238
www.balluff.com 35
Photoelectric Standard Sensors M8 Metal
BOS 08M
mini.s
Small size big performance

Diffuse, retroreective and through-beam sensors are available in a
cylindrical M8 housing. The sensors stand out with ease of installation
and xed sensing distances and ranges. They are small, robust,
exible and affordable.
Small photoelectric sensors open up possibilities in highly dynamic
applications such as robot arms. This is precisely where components
that have very low weight and small dimensions while retaining high
switching precision are in demand.

BOS 08M Product overview
Type Sensing Material Light Output Switching Switching US Connection Special Page
distance/ Housing type type frequency features
Range
Photoelectric
Nickel-plated CuZn
sensors
Light switching
Dark switching
M8 plug, 3-pin
Polarizing lter
10...30 V DC
Photoelectric
standard
Red light
Ordering code sensors
Cable
NPN
PNP
Part number Cylinder
designs
Diffuse sensor Block
designs
BOS0006 BOS 08M-PS-RD11-S49 0...55 mm 400 Hz 38
BOS0002 BOS 08M-NS-RD11-S49 0...55 mm 400 Hz 38 Photoelectric
BOS0004 BOS 08M-PO-RD11-S49 0...55 mm 400 Hz 38 special
sensors
BOS0001 BOS 08M-NO-RD11-S49 0...55 mm 400 Hz 38
BOS0005 BOS 08M-PS-RD11-02 0...55 mm 400 Hz 38 Photoelectric
BOS014N BOS 08M-NS-RD11-02 0...55 mm 400 Hz 38 distance
sensors
BOS0003 BOS 08M-PO-RD11-02 0...55 mm 400 Hz 38 for analog
BOS014M BOS 08M-NO-RD11-02 0...55 mm 400 Hz 38 distance
measurement
BOS00RC BOS 08M-PS-PR11-S49 25...550 mm 400 Hz 38 Special
accessories for
BOS00R7 BOS 08M-NS-PR11-S49 25...550 mm 400 Hz 38 photoelectric
BOS00R9 BOS 08M-PO-PR11-S49 25...550 mm 400 Hz 38 sensors
BOS00R6 BOS 08M-NO-PR11-S49 25...550 mm 400 Hz 38
BOS00RA BOS 08M-PS-PR11-02 25...550 mm 400 Hz 39
BOS014Z BOS 08M-NS-PR11-02 25...550 mm 400 Hz 39
BOS00R8 BOS 08M-PO-PR11-02 25...550 mm 400 Hz 39
BOS014Y BOS 08M-NO-PR11-02 25...550 mm 400 Hz 39
Through-beam sensor
Receiver
BOS00W9 BOS 08M-PS-RE11-S49 0...1.1 m 400 Hz 39
BOS0154 BOS 08M-NS-RE11-S49 0...1.1 m 400 Hz 39
BOS0153 BOS 08M-PO-RE11-S49 0...1.1 m 400 Hz 39
BOS0152 BOS 08M-NO-RE11-S49 0...1.1 m 400 Hz 39
BOS018F BOS 08M-PS-RE11-02 0...1.1 m 400 Hz 39
BOS018C BOS 08M-NS-RE11-02 0...1.1 m 400 Hz 39
BOS018E BOS 08M-PO-RE11-02 0...1.1 m 400 Hz 39
BOS018A BOS 08M-NO-RE11-02 0...1.1 m 400 Hz 39
Through-beam sensor
Emitter
BOS0151 BOS 08M-X-RS11-S49 0...1.1 m 39
BOS018H BOS 08M-X-RS11-02 0...1.1 m 39
www.balluff.com 37
BOS 08M
Sensing distance 55 mm, range 550 mm mini.s
Type Diffuse sensor Diffuse sensor Retroreective sensor

Detection range 0...55 mm 0...55 mm 25...550 mm
PNP NO Part number BOS 08M-PS-RD11-S49 @ BOS 08M-PS-RD11-02 !
NPN NO Part number BOS 08M-NS-RD11-S49 ^ BOS 08M-NS-RD11-02 %
PNP NC Part number BOS 08M-PO-RD11-S49 $ BOS 08M-PO-RD11-02 #
NPN NC Part number BOS 08M-NO-RD11-S49 * BOS 08M-NO-RD11-02 &
PNP NO Polarizing lter Part number BOS 08M-PS-PR11-S49 @
NPN NO Part number BOS 08M-NS-PR11-S49 ^
PNP NC Polarizing lter Part number BOS 08M-PO-PR11-S49 $
NPN NC Part number BOS 08M-NO-PR11-S49 *
PNP NO Receiver Part number
NPN NO Part number
PNP NC Receiver Part number
NPN NC Part number
Emitter Part number
Part number
Supply voltage UB 10...30 V DC 10...30 V DC 10...30 V DC
Output current 100 mA 100 mA 100 mA
No-load supply current I0 max. 20 mA 20 mA 20 mA
Switching type Light or dark switching Light or dark switching Light or dark switching
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes Yes/Yes
Settings Fixed Fixed Fixed
Emitter, light type LED, red light LED, red light LED, red light
Wavelength 640 nm 640 nm 640 nm
Received light indicator Yellow LED Yellow LED Yellow LED
Response time 1.25 ms 1.25 ms 1.25 ms
Switching frequency f 400 Hz 400 Hz 400 Hz
Degree of protection as per IEC 60529 IP 67 IP 67 IP 67
Ambient temperature Ta 10...+60 C 10...+60 C 10...+60 C
Permissible ambient light per EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Material Housing Nickel-plated CuZn Nickel-plated CuZn Nickel-plated CuZn
Optical surface PMMA PMMA PMMA
Connection M8 connector, 3-pin 2 m PUR cable, 326 AWG M8 connector, 3-pin
Diffuse sensor values referenced to 90% reective Kodak gray

card. Retroreective sensor values
referenced to BOS-R9 reector.
Wiring diagrams on page 40.
Ordering codes see page 37.

BOS 08M
Range 550 mm, 1.1 m
Receiver Emitter Receiver Emitter Photoelectric

sensors
Retroreective sensor Through-beam sensor Through-beam sensor Through-beam sensor Through-beam sensor
Photoelectric
25...550 mm 0...1.1 m 0...1.1 m 0...1.1 m 0...1.1 m standard
sensors
Cylinder
designs
Block
designs
BOS 08M-PS-PR11-02 !
Photoelectric
BOS 08M-NS-PR11-02 % special
BOS 08M-PO-PR11-02 # sensors
BOS 08M-NO-PR11-02 &
BOS 08M-PS-RE11-S49 @ BOS 08M-PS-RE11-02 ! Photoelectric
distance
BOS 08M-NS-RE11-S49 ^ BOS 08M-NS-RE11-02 % sensors
BOS 08M-PO-RE11-S49 $ BOS 08M-PO-RE11-02 # for analog
distance
BOS 08M-NO-RE11-S49 * BOS 08M-NO-RE11-02 & measurement
BOS 08M-X-RS11-S49 ) BOS 08M-X-RS11-02 ( Special

accessories for
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC photoelectric
100 mA 100 mA 100 mA sensors
20 mA 8 mA 15 mA 8 mA 15 mA
Light or dark switching Light or dark switching Light or dark switching
Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes
Fixed Fixed Fixed Fixed Fixed
LED, red light LED, red light LED, red light
640 nm 640 nm 640 nm
Yellow LED Yellow LED Yellow LED
1.25 ms 1.25 ms 1.25 ms
400 Hz 400 Hz 400 Hz
IP 67 IP 67 IP 67 IP 67 IP 67
10...+60 C 10...+60 C 10...+60 C 10...+60 C 10...+60 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Nickel-plated CuZn Nickel-plated CuZn Nickel-plated CuZn Nickel-plated CuZn Nickel-plated CuZn
PMMA PMMA PMMA PMMA PMMA
2 m PUR cable, 326 AWG M8 connector, 3-pin M8 connector, 3-pin 2 m PUR cable, 326 AWG 2 m PUR cable, 326 AWG
www.balluff.com 39
BOS 08M
Range 1.5 mm mini.s
Wiring diagrams
!
PS @
#
PO
$
%
NS
^
&
NO
*
( )
XX
Display elements
Yellow LED: received light indicator
The LED can show 3 different statuses:

LED off: no object detected
LED constantly lit: object detected
LED ashing: contamination indicator/signal not stable

BOS 08M
Connection, accessories
Photoelectric
sensors
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Recommended accessories Suitable connectors

(please order separately) (please order separately)
Description Ordering Size Design Cable Color Length Ordering

code material code
Reector BAM00WL M8, 3-pin Straight PUR Yellow 2m BCC050P
M8, 3-pin Straight PVC Yellow 2m BCC050Y
M8, 3-pin Angled PUR Yellow 2m BCC0558
M8, 3-pin Angled PVC Yellow 2m BCC055C
You can nd special accessories for photoelectric sensors, such as
reectors, apertures, lenses, lters and deection heads, in Connectors without LED are suitable for PNP and NPN sensors.
this catalog on page 420.
More electrical accessories: You can nd a large selection of plug
connectors and connector cables in a wide variety of cable materials, colors,
and lengths in our Industrial Networking and Connectivity catalog.
www.balluff.com 41
BOS 12M Global
Simplication with potential Features

Our BOS 12M series are in a fully potted metal housing with IP 67 Supply voltage 10...30 V DC, protected from polarity reversal
degree of protection have been optimized for typical applications. Output function indicator for the output
IP 67 degree of protection
Their installation also draws attention with its simplicity. This is Standard (M121) metal housing
because BOS 12M sensors are fastened in place simply by drilling Red and infrared light versions
holes. This provides the following benets: Fixed and adjustable sensitivity
Simplies the design of machines and systems. PNP or NPN, light or dark switching
Adapts sensor principles more quickly. Cable and connector versions (M12 connector)
Allows accessories to be used in multiple ways, thereby reducing
stock levels as well. Applications
General automation tasks
For long ranges or for detecting small parts, laser through-beam Assembly and handling technology
sensors are available in two different designs. Machine tool building
Packaging industry
Robots
Machine tool building

BOS 12M Global Product overview
Type Sensing Light type Output Switching Switching US Connection Special features Page
distance/range type frequency
M12 plug, 4-pin

Light switching
Dark switching
Polarizing lter
10...30 V DC
Laser Class
Cable, 3 m
Adjustable
Red light
Teach-in
Infrared
Ordering code
NPN
PNP
Part number
Diffuse sensor with
background suppression
BOS007R BOS 12M-PS-1N1I-S4-C 0...24 mm 1 kHz 44 Photoelectric
BOS007T BOS 12M-PU-1HA-S4-C 10...60 mm 1 kHz 44 sensors
Diffuse sensor Photoelectric

BOS0012 BOS 12M-PS-1YA-S4-C 1...100 mm 200 Hz 44 standard
sensors
BOS000H BOS 12M-NS-1YA-S4-C 1...100 mm 200 Hz 44
Cylinder
BOS000P BOS 12M-PO-1YA-S4-C 1...100 mm 200 Hz 44 designs
BOS0042 BOS 12M-NO-1YA-S4-C 1...100 mm 200 Hz 44 Block
BOS0010 BOS 12M-PS-1YA-BO-C-03 1...100 mm 200 Hz 45 designs
BOS000F BOS 12M-NS-1YA-BO-C-03 1...100 mm 200 Hz 45
Photoelectric
BOS000N BOS 12M-PO-1YA-BO-C-03 1...100 mm 200 Hz 45 special
BOS0008 BOS 12M-NO-1YA-BO-C-03 1...100 mm 200 Hz 45 sensors
BOS000W BOS 12M-PS-1PB-S4-C 1...200 mm 200 Hz 45
BOS000U BOS 12M-PS-1PB-BO-C-03 1...200 mm 200 Hz 45 Photoelectric
distance
BOS0043 BOS 12M-PS-1YB-S4-C 1...200 mm 200 Hz 45 sensors
BOS000K BOS 12M-NS-1YB-S4-C 1...200 mm 200 Hz 45 for analog
distance
BOS000T BOS 12M-PO-1YB-S4-C 1...200 mm 200 Hz 45 measurement
BOS000A BOS 12M-NO-1YB-S4-C 1...200 mm 200 Hz 45
BOS0013 BOS 12M-PS-1YB-BO-C-03 1...200 mm 200 Hz 45 Special
accessories for
BOS000J BOS 12M-NS-1YB-BO-C-03 1...200 mm 200 Hz 45 photoelectric
BOS000R BOS 12M-PO-1YB-BO-C-03 1...200 mm 200 Hz 45 sensors
BOS0009 BOS 12M-NO-1YB-BO-C-03 1...200 mm 200 Hz 45
BOS0045 BOS 12M-PS-1PD-S4-C 1...400 mm 200 Hz 46
BOS000E BOS 12M-NS-1PD-S4-C 1...400 mm 200 Hz 46
BOS0044 BOS 12M-PO-1PD-S4-C 1...400 mm 200 Hz 46
BOS0007 BOS 12M-NO-1PD-S4-C 1...400 mm 200 Hz 46
BOS000Y BOS 12M-PS-1PD-BO-C-03 1...400 mm 200 Hz 46
BOS000C BOS 12M-NS-1PD-BO-C-03 1...400 mm 200 Hz 46
BOS000L BOS 12M-PO-1PD-BO-C-03 1...400 mm 200 Hz 46
BOS00RE BOS 12M-PS-1QA-S4-C 0...1.5 m 200 Hz 46
BOS00RF BOS 12M-NS-1QA-S4-C 0...1.5 m 200 Hz 46
BOS00RJ BOS 12M-PO-1QA-S4-C 0...1.5 m 200 Hz 46
BOS00RK BOS 12M-PS-1QA-BO-C-03 0...1.5 m 200 Hz 47
BOS00RH BOS 12M-PO-1QA-BO-C-03 0...1.5 m 200 Hz 47
Through-beam sensor
Receiver
BOS00UE BLE 12M-PA-1PD-S4-C 0...5 m 500 Hz 47
BOS00UA BLE 12M-NA-1PD-S4-C 0...5 m 500 Hz 47
BOS00UC BLE 12M-PA-1PD-BO-C-03 0...5 m 500 Hz 47
Through-beam sensor
Emitter
BOS00W2 BLS 12M-XX-1RD-S4-L 0...5 m 47
BOS00UW BLS 12M-XX-1RD-BO-L-03 0...5 m 47
Laser through-beam sensor
Receiver
BOS00WF BOS 12M-PA-LE10-S4 0...3 m 1 1 kHz 51
BOS00WC BOS 12M-NA-LE10-S4 0...3 m 1 1 kHz 51
BOS00WE BOS 12M-PA-LE10-03 0...3 m 1 1 kHz 51
BOS00WA BOS 12M-NA-LE10-03 0...3 m 1 1 kHz 51
Emitter
BOS00WH BOS 12M-X-LS11-S4 0...3 m 1 51
BOS00WJ BOS 12M-X-LS12-S4 0...30 m 51
BOS00WL BOS 12M-XT-LS11-S4 0...3 m 1 51
BOS00WN BOS 12M-XT-LS12-S4 0...30 m 51
BOS00WK BOS 12M-XT-LS11-03 0...3 m 1 51
BOS00WM BOS 12M-XT-LS12-03 0...30 m 1 51
www.balluff.com 43
BOS 12M Global
Sensing distance 24, 60, 100 mm
Type Diffuse sensor with background suppression Diffuse sensor with background suppression Diffuse sensor
Detection range 0...24 mm 10...60 mm 1...100 mm
PNP NO Background Part number BOS 12M-PS-1N1I-S4-C @
suppression Part number
PNP NO/NC Background Part number BOS 12M-PU-1HA-S4-C 1
suppression, Teach-in Part number
PNP NO Part number BOS 12M-PS-1YA-S4-C @
NPN NO Part number BOS 12M-NS-1YA-S4-C *
PNP NC Part number BOS 12M-PO-1YA-S4-C $
NPN NC Part number BOS 12M-NO-1YA-S4-C 3
Switching type Light switching Light/dark switching (selectable) Light or dark switching
Settings Fixed Teach-in Fixed
Emitter, light type LED, red light LED, red light LED, red light
Light spot diameter 55 mm 55 mm at 50 mm
Distance hysteresis 5% 5%
Gray value shift (90%/18%) 5% 6%
Output function indicator Yellow LED Yellow LED Yellow LED
Stability indicator Green LED Green LED
Switching frequency f 1 kHz 1 kHz 200 Hz
Permissible ambient light 5 klx 5 klx 5 klx
Connection M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin
Diffuse sensor values referenced to 90% reective Kodak gray card. M12x1
Ordering codes on page 43. 17

40
74
10.5 Teach-in
key
11
M12x1

BOS 12M Global
Sensing distance 100, 200 mm
Photoelectric
sensors
Diffuse sensor Diffuse sensor Diffuse sensor Diffuse sensor Diffuse sensor
Photoelectric
1...100 mm 1...200 mm 1...200 mm 1...200 mm 1...200 mm standard
sensors
Cylinder
designs
Block
designs
BOS 12M-PS-1YA-BO-C-03 ! BOS 12M-PS-1PB-S4-C @ BOS 12M-PS-1PB-BO-C-03 ! BOS 12M-PS-1YB-S4-C ! BOS 12M-PS-1YB-BO-C-03 !
Photoelectric
BOS 12M-NS-1YA-BO-C-03 & BOS 12M-NS-1YB-S4-C & BOS 12M-NS-1YB-BO-C-03 & special
BOS 12M-PO-1YA-BO-C-03 # BOS 12M-PO-1YB-S4-C $ BOS 12M-PO-1YB-BO-C-03 # sensors
BOS 12M-NO-1YA-BO-C-03 2 BOS 12M-NO-1YB-S4-C 3 BOS 12M-NO-1YB-BO-C-03 2
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC Photoelectric
distance
200 mA 200 mA 200 mA 200 mA 200 mA sensors
20 mA 20 mA 20 mA 20 mA 20 mA for analog
distance
Light or dark switching Light switching Light switching Light or dark switching Light or dark switching measurement
Fixed Potentiometer, 270 Potentiometer, 270 Fixed Fixed Special
accessories for
LED, red light LED, infrared light LED, infrared light LED, red light LED, red light photoelectric
660 nm 880 nm 880 nm 660 nm 660 nm sensors
Yellow LED Yellow LED Yellow LED Yellow LED Yellow LED
2.5 ms 2.5 ms 2.5 ms 2.5 ms 2.5 ms

200 Hz 200 Hz 200 Hz 200 Hz 200 Hz
IP 67 IP 67 IP 67 IP 67 IP 67
5...+55 C 5...+55 C 5...+55 C 5...+55 C 5...+55 C
5 klx 5 klx 5 klx 5 klx 5 klx
3 m PVC cable, 22 AWG M12 connector, 4-pin 3 m PVC cable, 22 AWG M12 connector, 4-pin 3 m PVC cable, 22 AWG
M12x1
17
42
70
sn
LED
10.5
www.balluff.com 45
BOS 12M Global
Sensing distance 400 mm, range 1.5 m

Detection range 1...400 mm 1...400 mm 0...1.5 m
PNP NO Part number BOS 12M-PS-1PD-S4-C @ BOS 12M-PS-1PD-BO-C-03 !
NPN NO Part number BOS 12M-NS-1PD-S4-C * BOS 12M-NS-1PD-BO-C-03 &
PNP NC Part number BOS 12M-PO-1PD-S4-C $ BOS 12M-PO-1PD-BO-C-03 #
NPN NC Part number BOS 12M-NO-1PD-S4-C 3
PNP NO Polarizing Part number BOS 12M-PS-1QA-S4-C @
NPN NO lter Part number BOS 12M-NS-1QA-S4-C *
PNP NC Polarizing Part number BOS 12M-PO-1QA-S4-C $
lter Part number
PNP complementary Receiver Part number
NPN complementary Part number
Emitter Part number
Part number
Switching type Light or dark switching Light or dark switching Light or dark switching
Settings Potentiometer, 270 Potentiometer, 270 Potentiometer, 270
Emitter, light type LED, infrared light LED, infrared light LED, red light
Power-on indicator
Connection M12 connector, 4-pin 3 m PVC cable, 22 AWG M12 connector, 4-pin
Diffuse sensor values referenced to 90% reective Kodak M12x1 M12x1

gray card.
Retroreective sensor values referenced to R1 reector. 17 17

42
42
Ordering codes on page 43.

70
70
sn sn
LED LED
10.5 10.5

BOS 12M Global
Range 5 m
Receiver Emitter Receiver Emitter Photoelectric

sensors
Retroreective sensor Through-beam sensor Through-beam sensor Through-beam sensor Through-beam sensor
Photoelectric
0...1.5 m 0...5 m 0...5 m 0...5 m 0...5 m standard
sensors
Cylinder
designs
Block
designs
BOS 12M-PS-1QA-BO-C-03 !
Photoelectric
special
BOS 12M-PO-1QA-BO-C-03 # sensors
BLE 12M-PA-1PD-S4-C ^ BLE 12M-PA-1PD-BO-C-03 ^ Photoelectric

distance
BLE 12M-NA-1PD-S4-C 5 sensors
BLS 12M-XX-1RD-S4-L ) BLS 12M-XX-1RD-BO-L-03 ) for analog
distance
measurement
200 mA 200 mA 200 mA Special
accessories for
20 mA 20 mA 20 mA 20 mA 20 mA photoelectric
Light or dark switching Light and dark switching Light and dark switching sensors
Potentiometer, 270 Potentiometer, 270 Potentiometer, 270
LED, red light LED, red light LED, red light LED, red light LED, red light
660 nm 660 nm 660 nm 660 nm 660 nm
Green LED Green LED
2.5 ms 1 ms 1 ms
200 Hz 500 Hz 500 Hz
IP 67 IP 67 IP 67 IP 67 IP 67
5...+55 C 5...+55 C 5...+55 C 5...+55 C 5...+55 C
3 m PVC cable, 22 AWG M12 connector, 4-pin M12 connector, 4-pin 3 m PVC cable, 22 AWG 3 m PVC cable, 22 AWG
M12x1
17
42
70
sn
LED
10.5
www.balluff.com 47
BOS 12M Global
Function diagrams
Diffuse sensor BOS 12M-..-1YA/1YB/1PD-...
BOS 12M-..-1PD-...
BOS 12M-..-1YB-...
90% reective
BOS 12M-..-1YA-... Kodak gray card
Sensing distance measured with side approach of Kodak gray card.
Retroreective sensor BOS 12M-..-1QA-...
Reector
BOS R-1
Range measured with side approach of reector.
Through-beam sensor BLE/BLS 12M-...
Emitter/
Receiver
The maximum offset between the emitter and receiver is measured

for the through-beam sensor.

BOS 12M Global
Accessories, Connection
Orientation aid
The additional function indicator on the receiver of the through-beam
sensor enables fast and simple alignment between the emitter and
receiver.
First attach the receiver and then the emitter. As soon as the emitter Function indicator
is located within the active range of the receiver, the function Photoelectric
sensors
indicator on the front of the sensor goes out. This indicates an Potentiometer
optical connection between the emitter and receiver. It is also easily
Photoelectric
visible when the sensor is ush mounted. standard
sensors
Cylinder
designs
Block
designs
Photoelectric
special
sensors
Additional function indicator
as orientation aid
Photoelectric
Receiving element
distance
sensors
for analog
distance
measurement
Wiring diagrams
Special
accessories for
! PNP NO @ photoelectric
PS PS Recommended accessories sensors
(please order separately)
1
# PNP NC $ Description Ordering
PO PO
code 2
1 Reector BAM00WL
3
% PNP NO+NC ^ 2 Reector BAM00UK
PA PA 3 Diagonal mirror BAM00R0 4
4 Air shield BAM00PY
5 Slit aperture BAM00PW
& NPN NO * 5
6 Mounting cuff BAM01KM 6
NS NS
7 Cover nut BAM01Y6
7
( Emitter ) You can nd additional accessories for photoelectric sensors, such as

XX XX reectors, apertures, lenses, lters and deection heads,
in this catalog on page 420.
1 PNP NO/NC 3
PU NO
2 NPN NC 5
NO NA
Suitable connectors
4 NNP NO+NC 7
NA XT
Size Design Cable Color Length Ordering
material code
M12, 4-pin Straight PUR Yellow 5m BCC05FE
6 Emitter M12, 4-pin Straight PVC Yellow 2m BCC05FF
XT
M12, 4-pin Angled PUR Yellow 2m BCC05TA
M12, 4-pin Angled PVC Yellow 2m BCC05TF
Connectors without LED are suitable for PNP and NPN sensors.
www.balluff.com 49
BOS 12M
Connection Laser
The basis of the laser through-beam sensor BOS 12M is its two different
emitters. Emitter version LS11 is for small parts detection and offers a
resolution of 50 m at the focal point of 500 mm.
The LS12 version is not focused and is used for long ranges up to 30 m. The
receivers can be PNP or NPN, and any emitter can be combined with any
receiver. Laser Class 1
All sensors are Laser Class 1 and are available as a connector or with a cable.
Type
Small parts detection
Detection range
BOS 12M-XT-LS11-.. PNP NO/NC Part number
Reciever Part number
Detection at a distance of Emitter Part number
3 m between emitter and 50 m high resolution Part number
receiver.
Object size (mm)
Emitter Part number

Long range 30 m Part number
Supply voltage UB
Output current
No-load supply current I0 max.
Switching type
Polarity reversal/short-circuit protected
Object distance from emitter (m) Settings
Help function
BOS 12M-XT-LS12-.. Emitter, light type
Wavelength
Detection at a distance of Laser class
6 m between emitter and
Object size (mm)
receiver.
Output function indicator
Response time
Switching frequency f
Degree of protection as per IEC 60529
Ambient temperature Ta
Permissible ambient light per
Material Housing
Object distance from emitter (m)
Optical surface
Connection
BOS 12M-XT-LS12-..
Detection at a distance of
30 m between emitter and Wiring diagrams on page 49.
receiver.
Object size (mm)
Object distance from emitter (m)


code material code
Mounting cuff BAM00R2 M12, 4-pin Straight PUR Yellow 5m BCC05FE
M12, 4-pin Straight PVC Yellow 2m BCC05FF
reectors, apertures, lenses, lters and deection heads, in
this catalog on page 420. Connectors without LED are suitable for PNP and NPN sensors.

BOS 12M
Range 3 m, 30 m
Receiver Receiver Emitter Emitter Emitter Photoelectric

sensors
Laser through-beam Laser through-beam Laser through-beam Laser through-beam Laser through-beam
Photoelectric
sensor sensor sensor sensor sensor standard
0...3 m 0...3 m 0...3 m/0...30 m 0...3 m/0...30 m 0...3 m/0...30 m sensors
Cylinder
BOS 12M-PA-LE10-S4 ^ BOS 12M-PA-LE10-03 % designs
BOS 12M-NA-LE10-S4 5 BOS 12M-NA-LE10-03 4 Block
BOS 12M-X-LS11-S4 ) BOS 12M-XT-LS11-S4 7 BOS 12M-XT-LS11-03 6 designs
BOS 12M-X-LS12-S4 ) BOS 12M-XT-LS12-S4 7 BOS 12M-XT-LS12-03 6 Photoelectric

special
sensors
200 mA 200 mA Photoelectric
distance
Light/dark switching (complementary) Light/dark switching (complementary) for analog
distance
Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes measurement
Potentiometer, 270 Potentiometer, 270
Test input Test input Special
accessories for
Laser, red light Laser, red light Laser, red light photoelectric
655 nm 655 nm 655 nm sensors
1 1 1
Yellow LED Yellow LED
0.5 ms 0.5 ms
1 kHz 1 kHz
IP 67 IP 67 IP 67 IP 67 IP 67
10...+50 C 10...+50 C 10...+50 C 10...+50 C 10...+50 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PMMA PMMA Glass Glass Glass
M12 connector, 4-pin 3 m PVC cable, 22 AWG M12 connector, 4-pin M12 connector, 4-pin 3 m PVC cable, 22 AWG
M12x1 M12x1
17 17
42
42
70
70
10.5 10.5
www.balluff.com 51
BOS 18M
BOS 18M GlobalProx We often come across systems in which a sensor adjustment is
sound and cost
cost-effective
effective not required, not possible or is undesirable. Our BOS-18M diffuse
sensors and light barriers from the Global family are the correct
choice for these applications. All of these sensors have a xed
setting. This shortens the time required for system commissioning
and protects against tampering. Equipped with a sound basic range
of functions, these sensors also have the best possible
price/performance ratio.
Sound performance and reliable object detection

Ideal for standard applications, e.g. in automation
Cost-effective alternative for all types of light
Plug and play: All sensors with xed setting
Universal fastening thanks to wide range of assembly accessories
Red light sensors M18 Precise switching behavior excellent repeat accuracy
for the highest precision Cutting-edge LED technology and the latest Fresnel lenses are
combined in this unit to form an innovative and powerful photoelectric
sensor. What this means in practice: Improved repeat accuracy and
precise switching behavior even at large distances.
Long range
Rugged M18 metal housing
State-of-the-art LED technology with sharply contoured light spot
BOS 18M background suppression Balluff M18 laser diffuse sensors with background suppression are a
expertise with all kinds of light genuine highlight. They are available with different light types, allowing
you to simply select according to your requirements. The perfectly
focused light beam is able to detect the smallest of parts, grooves or
holes with maximum precision and reliability. The large light spot of
the red light variant with 300 mm is ideal for detecting objects with
notches, holes or openings, because breakthroughs and free areas
are simply bridged.
The 150 mm red light version is ideal for distinguishing between
foreground and background with high precision at extremely short
distances.
Exact, almost color-independent object detection

The correct light type for every application laser or red light
Precise setting with 10-turn potentiometer
Robust M18 metal housing with same design for all types
Universal fastening and alignment thanks to wide range of
assembly accessories

BOS 18M
BOS 18M Teach-in For users who prefer the teach-in procedure for sensor setting, Balluff
now offers its successful red light series BOS 18M, with long ranges,
precise switching behavior and very high levels of repeat accuracy.
The top sensor in its class is quickly set at the push of a button.
Further advantage: The BOS 18M Teach-in reports difculties
immediately by means of our patented Dynamic Sensor Control Photoelectric
sensors
diagnostic system, which is available as an option. The DSC allows
you to react immediately to contamination or malfunctions.
Photoelectric
Even users without DSC can make use of the contamination standard
detection as the sensors are also optionally available with a separate sensors
Cylinder
alarm output. designs
Block
Continuous sensor monitoring of contamination and malfunctions designs
Switchable output
Simple teach-in procedure Photoelectric
special
Standardized BOS-18M design for fast sensor change sensors
Photoelectric
BOS 18M infrared invisible power The successful BOS-18M series now also includes invisible infrared
distance
light. This type of light demonstrates its advantages particularly sensors
in heavily contaminated production environments: Objects are for analog
distance
reliably detected unimpeded by dust or dirt. With its range of over measurement
100 meters, the high-power version of the through-beam sensor
impresses particularly in this area. The standardized design of all BOS Special
accessories for
18Ms permits a simple change between the different types of light photoelectric
without assembly change. sensors
Reliable object detection even in a contaminated environment

Invisible light does not irritate personnel
Simple and fast setting with potentiometer
Through-beam sensor with test input for function check
Wide range of assembly accessories
BOS 18M Laser The BOS 18M(R) Laser series is characterized by long ranges and
absolute precision in small parts detection.
These sensors are Laser Class 1 and are available with axial or
radial light exit. Newly added is a diffuse version with background
suppression (Laser Class 2) and a sensing distance of 150 mm.
Long ranges (50 m)

High switching frequency (1.5 kHz)
Straight- and right-angle versions
Drill break monitoring
Precise parts positioning
Fast counting of objects
High precision
The BOS 18MR product family has a built-in angled mirror made of Standard M181 housing made of metal (nickel plated brass)
scratch-resistant glass which is attached to the housing. Since the All sensors use visible red light
optical head does not protrude over the side, installation from the IP 67 degree of protection
front is no problem. Supply voltage 10...30 V DC, polarity reversal protected
Output short circuit protected
Roller conveyors
Conveying lines
Packaging industry
www.balluff.com 53
BOS 18M
Product overview
Type Sensing Light Light type Output Switch- Switching US Connection Special features Page
distance/ exit ing frequency
range type
M12 plug, 4-pin

Light switching
Dark switching
Polarizing lter
Laser Class 1
10...30 V DC
Error output
Right-angle
Test input
Red light
Ordering code
Teach-in
Straight
Infrared
Cable
Laser
Fixed
Part number
NPN
PNP
Diffuse sensor with
BOS010J BOS 18MR-PS-1HA-E5-C-S4 10...120 mm 500 Hz 74
BOS0081 BOS 18MR-PA-1HA-S4-C 40...120 mm 600 Hz 74
BOS01J4 BOS 18M-PA-RH23-S4 30...150 mm 500 Hz 64
BOS01J3 BOS 18M-NA-RH23-S4 30...150 mm 500 Hz 64
BOS01J2 BOS 18M-PSV-RH23-S4 30...150 mm 500 Hz 64
BOS002H BOS 18M-PS-LH22-S4 30...150 mm 500 Hz 82
BOS002K BOS 18M-PSV-LH22-S4 30...150 mm 500 Hz 82
BOS001L BOS 18M-NSV-LH22-S4 30...150 mm 500 Hz 82
BOS001Z BOS 18M-POV-LH22-S4 30...150 mm 500 Hz 82
BOSOO1H BOS 18M-NOV-LH22-S4 30...150 mm 500 Hz 82
BOS01C5 BOS 18M-PA-LH23-S4 30...150 mm 500 Hz 83
BOS01C4 BOS 18M-PSV-LH23-S4 30...150 mm 500 Hz 83
BOS014W BOS 18M-PA-RH22-S4 30...300 mm 500 Hz 65
BOS019T BOS 18M-NA-RH22-S4 30...300 mm 500 Hz 65
BOS019P BOS 18M-PS-RH22-S4 30...300 mm 500 Hz 65
BOS019N BOS 18M-PSV-RH22-S4 30...300 mm 500 Hz 65
BOS019U BOS 18M-NSV-RH22-S4 30...300 mm 500 Hz 65
BOS019R BOS 18M-POV-RH22-S4 30...300 mm 500 Hz 65
BOS019W BOS 18M-NOV-RH22-S4 30...300 mm 500 Hz 65
Diffuse sensor
BOS0141 BOS 18MR-PA-LD10-02 250 mm 1.5 kHz 86
BOS013T BOS 18MR-NA-LD10-02 250 mm 1.5 kHz 86
BOS0142 BOS 18MR-PA-LD10-S4 250 mm 1.5 kHz 86
BOS013U BOS 18MR-NA-LD10-S4 250 mm 1.5 kHz 86
BOS01CA BOS 18M-PA-RD21-S4 300 mm 400 Hz 66
BOS01EC BOS 18M-NA-RD21-S4 300 mm 400 Hz 66
BOS01E7 BOS 18M-PS-RD21-S4 300 mm 400 Hz 66
BOS01E9 BOS 18M-NS-RD21-S4 300 mm 400 Hz 66
BOS01E8 BOS 18M-PO-RD21-S4 300 mm 400 Hz 67
BOS01EA BOS 18M-NO-RD21-S4 300 mm 400 Hz 67
BOS013H BOS 18M-PA-LD10-S4 350 mm 1.5 kHz 83
BOS0138 BOS 18M-NA-LD10-S4 350 mm 83
BOS013F BOS 18M-PA-LD10-02 350 mm 1.5 kHz 83
BOS0137 BOS 18M-NA-LD10-02 350 mm 83
BOS01FA BOS 18M-PS-RD23-S4 400 mm 400 Hz 58
BOS01FC BOS 18M-PO-RD23-S4 400 mm 400 Hz 58
BOS01HL BOS 18M-PS-ID23-S4 600 mm 400 Hz 58
BOS01J8 BOS 18M-PUV-RD30-S4 500 mm 1 kHz 72
BOS01CU BOS 18M-PUD-RD30-S4 500 mm 200 Hz 72
BOS01CF BOS 18M-PA-RD20-S4 600 mm 400 Hz 67
BOS01E6 BOS 18M-NA-RD20-S4 600 mm 400 Hz 67
BOS01C1 BOS 18M-PS-RD20-S4 600 mm 400 Hz 67
BOS01E4 BOS 18M-NS-RD20-S4 600 mm 400 Hz 67
BOS01E3 BOS 18M-PO-RD20-S4 600 mm 400 Hz 67
BOS01E5 BOS 18M-NO-RD20-S4 600 mm 400 Hz 67
BOS01J1 BOS 18M-PS-ID24-S4 80 mm 200 Hz 78
BOS01EY BOS 18M-PA-ID20-S4 800 mm 400 Hz 78
BOS01EZ BOS 18M-NA-ID20-S4 800 mm 400 Hz 78

BOS 18M
Product overview
Type Sensing Light exit Light type Output Switching Switching US Connection Special features Page
distance/ type frequency
range
M12 plug, 4-pin

Light switching
Dark switching
Polarizing lter
10...30 V DC
Photoelectric
Error output
Right-angle
Test input
sensors
Ordering code
Red light
Teach-in
Straight
Infrared
Cable
Laser
Fixed
Part number
NPN
PNP
Photoelectric
standard
Retroreective sensor sensors
BOS010L BOS 18MR-PS-1QB-E5-C-S4 2m 1 kHz 75 Cylinder
designs
BOS01F8 BOS 18M-PS-PR23-S4 4m 400 Hz 59
Block
BOS01F9 BOS 18M-P0-PR23-S4 4m 400 Hz 59 designs
BOS01J9 BOS 18M-PUV-PR30-S4 5m 1 kHz 73
BOS01CT BOS 18M-PUD-PR30-S4 5m 200 Hz 73 Photoelectric
special
BOS01HK BOS 18M-PS-IR23-S4 6m 400 Hz 59 sensors
BOS01CE BOS 18M-PA-PR20-S4 7m 400 Hz 68
BOS01E2 BOS 18M-NA-PR20-S4 7m 400 Hz 68 Photoelectric
distance
BOS01FJ BOS 18M-PA-PR20-S4S 7m 400 Hz 68 sensors
BOS01C3 BOS 18M-PS-PR20-S4 7m 400 Hz 69 for analog
distance
BOS01E0 BOS 18M-NS-PR20-S4 7m 400 Hz 69 measurement
BOS01CZ BOS 18M-PO-PR20-S4 7m 400 Hz 69
BOS01E1 BOS 18M-NO-PR20-S4 7m 400 Hz 69 Special
BOS01EM BOS 18M-PO-PR20-S4S 7m 400 Hz 69 accessories
for
BOS01EN BOS 18M-NO-PR20-S4S 7m 400 Hz 69 photoelectric
BOS01HR BOS 18M-PA-IR21-S4 7m 400 Hz 78 sensors
BOS01HW BOS 18M-NA-IR21-S4 7m 400 Hz 78
BOS0145 BOS 18MR-PA-LR10-02 9m 1.5 kHz 87
BOS0132 BOS 18MR-NA-LR10-02 9m 1.5 kHz 87
BOS0146 BOS 18MR-PA-LR10-S4 9m 1.5 kHz 87
BOS0140 BOS 18MR-NA-LR10-S4 9m 1.5 kHz 87
BOS01F0 BOS 18M-PA-IR20-S4 10 m 400 Hz 79
BOS01F2 BOS 18M-NA-IR20-S4 10 m 400 Hz 79
BOS01F1 BOS 18M-PS-IR20-S4 10 m 400 Hz 79
BOS013M BOS 18M-PA-LR10-S4 16 m 1.5 kHz 84
BOS013E BOS 18M-NA-LR10-S4 16 m 1.5 kHz 84
BOS013L BOS 18M-PA-LR10-02 16 m 1.5 kHz 84
BOS013C BOS 18M-NA-LR10-02 16 m 1.5 kHz 84
Through-beam sensor
Receiver
BOS010E BLE 18MR-PA-1PP-E5-C-S4 0...16 m 1 kHz 75
BOS01CC BOS 18M-PA-RE20-S4 0...20 m 400 Hz 70
BOS01EK BOS 18M-NA-RE20-S4 0...20 m 400 Hz 70
BOS01FK BOS 18M-PA-RE20-S4S 0...20 m 400 Hz 70
BOS01C2 BOS 18M-PS-RE20-S4 0...20 m 400 Hz 71
BOS01EH BOS 18M-NS-RE20-S4 0...20 m 400 Hz 71
BOS01EE BOS 18M-PO-RE20-S4 0...20 m 400 Hz 71
BOS01EJ BOS 18M-NO-RE20-S4 0...20 m 400 Hz 71
BOS01EF BOS 18M-PO-RE20-S4S 0...20 m 400 Hz 71
BOS01EL BOS 18M-NO-RE20-S4S 0...20 m 400 Hz 71
BOS01FF BOS 18M-PO-RE23-S4 0...20 m 400 Hz 60
BOS01FE BOS 18M-PS-RE23-S4 0...20 m 400 Hz 60
BOS01J7 BOS 18M-PUV-RE30-S4 0...20 m 1 kHz 73
BOS01CW BOS 18M-PUD-RE30-S4 0...20 m 200 Hz 73
BOS01HP BOS 18M-PS-IE23-S4 0...50 m 400 Hz 61
BOS01F3 BOS 18M-PA-IE20-S4 0...50 m 400 Hz 79
BOS01F4 BOS 18M-NA-IE20-S4 0...50 m 400 Hz 79
BOS0074 BLE 18M-BA-1LT-S4-C 0...50 m 6 kHz 93
BOS0076 BLE 18MR-BA-1LT-S4-C 0...50 m 6 kHz 93
www.balluff.com 55
BOS 18M
Product overview
Type Sensing Light Light type Output Switching Switching US Connection Special features Page
distance/ exit type frequency
range
M12 plug, 4-pin

Light switching
Dark switching
Polarizing lter
10...30 V DC
Error output
Right-angle
Test input
Ordering code
Red light
Teach-in
Straight
Infrared
Cable
Laser
Fixed
Part number
NPN
PNP
Through-beam sensor
Receiver
BOS0143 BOS 18MR-PA-LE10-02 0...50 m 1.5 kHz 88
BOS013W BOS 18MR-NA-LE10-02 0...50 m 1.5 kHz 88
BOS0144 BOS 18MR-PA-LE10-S4 0...50 m 1.5 kHz 88
BOS013Y BOS 18MR-NA-LE10-S4 0...50 m 1.5 kHz 88
BOS013K BOS 18M-PA-LE10-S4 0...60 m 1.5 kHz 85
BOS013A BOS 18M-NA-LE10-S4 0...60 m 1.5 kHz 85
BOS013J BOS 18M-PA-LE10-02 0...60 m 1.5 kHz 85
BOS0139 BOS 18M-NA-LE10-02 0...60 m 1.5 kHz 85
Through-beam sensor
Emitter
BOS010F BLS 18MR-XX-1P-E5-L-S4 0...16 m 75
BOS01C0 BOS 18M-X-RS20-S4 0...20 m 71
BOS01EP BOS 18M-XT-RS20-S4 0...20 m 71
BOS01FH BOS 18M-X-RS23-S4 0...20 m 60
BOS01CY BOS 18M-X-RS30-S4 0...20 m 73
BOS01HM BOS 18M-X-IS23-S4 0...50 m 61
BOS01F5 BOS 18M-X-IS20-S4 0...50 m 79
BOS01HN BOS 18M-XT-IS20-S4 0...50 m 79
BOSO1HT BOS 18M-X-IS24-S4 0...100 m 79
BOSO1HU BOS 18M-XT-IS24-S4 0...100 m 79
BOS00AW BLS 18M-XX-1LT-S4-C 0...50 m 93
BOS00AU BLS 18MR-XX-1LT-S4-C 0...50 m 93
BOS0147 BOS 18MR-XT-LS10-02 0...50 m 89
BOS0148 BOS 18MR-XT-LS10-S4 0...50 m 89
BOS013R BOS 18M-XT-LS10-S4 0...60 m 85
BOS013P BOS 18M-XT-LS10-02 0...60 m 85

BOS 18M
Product overview
Photoelectric
sensors
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 57
BOS 18M Global
Sensing distance 400 mm, 600 mm
Type Diffuse sensor Diffuse sensor

Detection range 1...400 mm 1...600 mm
PNP NO Part number BOS 18M-PS-RD23-S4 ! BOS 18M-PS-ID23-S4 !
NPN NO Part number
PNP NC Part number BOS 18M-PO-RD23-S4 @
NPN NC Part number
PNP NO Polarizing lter Part number
NPN NO Part number
PNP NC Polarizing lter Part number
NPN NC Part number
Supply voltage UB 10...30 V DC 10...30 V DC
Output current 100 mA 100 mA
No-load supply current I0 max. 30 mA 30 mA
Switching type Light or dark switching Light switching
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes
Settings Fixed Fixed
Emitter, light type LED, red light LED, infrared
Wavelength 620...670 nm 850 nm
Received light indicator Yellow LED Yellow LED
Response time 1.25 ms 1.25 ms
Switching frequency f 400 Hz 400 Hz
Degree of protection as per IEC 60529 IP 67 IP 67
Ambient temperature Ta 5...+55 C 5...+55 C
Permissible ambient light 10 klx 5 klx
Material Housing Nickel-plated brass Nickel-plated brass
Optical surface Glass Glass
Connection M12 connector, 4-pin M12 connector, 4-pin
Diffuse sensor values referenced to 90% reective Kodak gray card. M18x1 M18x1
Retroreective sensor values referenced to R1 reector.
wiring diagrams on page 95.
Ordering codes on pages 54-56.

48
48
75
75
LED LED
M12x1 M12x1

BOS 18M Global
Range 4 m, 6 m
Photoelectric
sensors
Retroreective sensor Retroreective sensor

Photoelectric
4m 6m standard
BOS 18M-PS-IR23-S4 ! sensors
Cylinder
designs
Block
designs
BOS 18M-PS-PR23-S4 !
Photoelectric
special
BOS 18M-PO-PR23-S4 @ sensors
10...30 V DC 10...30 V DC Photoelectric

distance
100 mA 100 mA sensors
30 mA 30 mA for analog
distance
Light or dark switching Dark switching measurement
Yes/Yes Yes/Yes
Fixed Fixed Special
accessories for
LED, red light LED, infrared photoelectric
620...670 nm 850 nm sensors
1.25 ms 1.25 ms
400 Hz 400 Hz
IP 67 IP 67
5...+55 C 5...+55 C
10 klx 5 klx
Nickel-plated brass Nickel-plated brass
Glass Glass
M12 connector, 4-pin M12 connector, 4-pin
M18x1 M18x1
48
48
75
75
LED LED
M12x1 M12x1
www.balluff.com 59
BOS 18M Global
Range 20 m
Receiver Emitter
Type Through-beam sensor Through-beam sensor

Detection range 0...20 m 0...20 m
PNP NO Receiver Part number BOS 18M-PS-RE23-S4 @
NPN NO Part number
PNP NC Receiver Part number BOS 18M-PO-RE23-S4 !
NPN NC Part number
Emitter Part number BOS 18M-X-RS23-S4 ^
Part number
Output current 100 mA
Switching type Light or dark switching
Emitter, light type LED, red light LED, red light
Wavelength 620...670 nm 620...670 nm
Received light indicator Yellow LED
Power-on indicator Green LED
Response time 1.25 ms
Switching frequency f 400 Hz
Wiring diagrams on page 95. M18x1 M18x1
48
48
75
75
LED LED
M12x1 M12x1

BOS 18M Global
Range 50 m
Receiver Emitter Photoelectric

sensors
Through-beam sensor Through-beam sensor

Photoelectric
0...50 m 0...50 m standard
sensors
BOS 18M-PS-IE23-S4 @
Cylinder
designs
Block
designs
BOS 18M-X-IS23-S4 ^
Photoelectric
special
10...30 V DC 10...30 V DC sensors
100 mA
Photoelectric
20 mA 30 mA distance
Dark switching sensors
for analog
Yes/Yes Yes/Yes distance
Fixed Fixed measurement
LED, infrared LED, infrared
850 nm 850 nm Special
accessories for
Yellow LED photoelectric
Green LED sensors
1.25 ms
400 Hz
IP 67 IP 67
5...+55 C 5...+55 C
5 klx 5 klx
Nickel-plated brass Nickel-plated brass
Glass Glass
M18x1 M18x1
48
48
75
75
LED LED
M12x1 M12x1
www.balluff.com 61
BOS 18M Global
Response curves, function diagram
Diffuse sensor BOS 18M...RD23 Diffuse sensor BOS 18M...RD23

Response curve Distance function reserve
mm
15 1000
10
Function reserve
5 100
Switching point
-5 10
-10
1
-15 mm
0 50 100 150 200 250 300 350 400 mm 0 50 100 150 200 250 300 350 400
Distance Distance
Retroreective sensor BOS 18M...PR23 Retroreective sensor BOS 18M...PR23

mm
200 250
150
Function reserve
100 150
50
Switching point
0 50
-50
-100
0 m
0 1 2 3 4
-150
Distance to reector
-200
mm
0 500 1000 1500 2000 2500 3000 3500 4000
Distance to reector
Through-beam sensor BOS 18M...RE/RS23 Through-beam sensor BOS 18M...RE/RS23

Response curve based on distance Emitter distance function reserve
400 10000
300
1000
200
Function reserve
Switching point
100
100
0
-100 10
-200
1
-300
0 1 2 3 4 5 6 7 8 9 10 m
-400 Emitterreceiver distance
0 5000 10000 15000 20000 25000
Distance

BOS 18M Global
Accessories
Photoelectric
sensors
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors

1
code 2 material code
1 Mounting clamp BAM00T3 M12, 4-pin Straight PUR Yellow 5m BCC05FE
2 Mounting bracket BAM00RY 3 M12, 4-pin Straight PVC Yellow 2m BCC0CAU
3 Reector BAM00UK M12, 4-pin Angled PUR Yellow 2m BCC05TA
M12, 4-pin Angled PVC Yellow 2m BCC0CAT
You can nd special accessories for photoelectric sensors, such as Connectors without LED are suitable for PNP and NPN sensors.

www.balluff.com 63
BOS 18M red light
Sensing distance 150 mm Red light
Type Diffuse sensor with background suppression Diffuse sensor with background suppression
PNP NO/NC Part number BOS 18M-PA-RH23-S4 #
NPN NO/NC Part number BOS 18M-NA-RH23-S4 $
PNP NO Part number
NPN NO Part number
PNP NO Error output Part number BOS 18M-PSV-RH23-S4 *
NPN NO Error output Part number
PNP NC Error output Part number
NPN NC Error output Part number
Switching type Light and dark switching Light switching
Settings 10-turn potentiometer 10-turn potentiometer
Wavelength 620...670 nm 620...670 nm
Response time 1ms 1ms
Material Housing Nickel-plated CuZn Nickel-plated CuZn

24 24
48
48
75
75
LED LED LED LED
M12x1 M12x1

BOS 18M red light
Sensing distance 300 mm
Photoelectric
sensors
Diffuse sensor with background suppression Diffuse sensor with background suppression Diffuse sensor with background suppression Diffuse sensor with background suppression
Photoelectric
30...300 mm 30...300 mm 30...300 mm 30...300 mm standard
BOS 18M-PA-RH22-S4 # sensors
Cylinder
BOS 18M-NA-RH22-S4 $ designs
BOS 18M-PS-RH22-S4 @ Block
designs
BOS 18M-PSV-RH22-S4 *
BOS 18M-NSV-RH22-S4 7 Photoelectric
special
BOS 18M-POV-RH22-S4 ( sensors
BOS 18M-NOV-RH22-S4 6
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC Photoelectric
distance
100 mA 100 mA 100 mA 100 mA sensors
50 mA 50 mA 50 mA 50 mA for analog
distance
Light and dark switching Light switching Light switching Dark switching measurement
Yes/Yes Yes/Yes Yes/Yes Yes/Yes
10-turn potentiometer 10-turn potentiometer 10-turn potentiometer 10-turn potentiometer Special
accessories for
LED, red light LED, red light LED, red light LED, red light photoelectric
620...670 nm 620...670 nm 620...670 nm 620...670 nm sensors
1ms 1ms 1ms 1ms
500 Hz 500 Hz 500 Hz 500 Hz
IP 67 IP 67 IP 67 IP 67
5...+55 C 5...+55 C 5...+55 C 5...+55 C
10 klx 10 klx 10 klx 10 klx
Nickel-plated CuZn Nickel-plated CuZn Nickel-plated CuZn Nickel-plated CuZn
Glass Glass Glass Glass
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin
M18x1 M18x1 M18x1 M18x1
24 24 24 24
48
48
48
48
75
75
75
75
LED LED LED LED LED LED LED LED
M12x1 M12x1 M12x1 M12x1
www.balluff.com 65
BOS 18M red light
Sensing distance 300 mm Red Light

PNP NO/NC Part number BOS 18M-PA-RD21-S4 #
NPN NO/NC Part number BOS 18M-NA-RD21-S4 $
PNP NO Part number BOS 18M-PS-RD21-S4 !
NPN NO Part number BOS 18M-NS-RD21-S4 8
PNP NC Part number
NPN NC Part number
Settings Potentiometer, 270 Potentiometer, 270
Wavelength 620...670 nm 620...670 nm
200200 mm
Ordering codes on pages 54-56. 24 24

48
48
75
75
LED LED LED LED
M12x1 M12x1

BOS 18M red light
Photoelectric
sensors
Diffuse sensor Diffuse sensor Diffuse sensor Diffuse sensor

Photoelectric
BOS 18M-PA-RD20-S4 # sensors
Cylinder
BOS 18M-NA-RD20-S4 $ designs
BOS 18M-PS-RD20-S4 ! Block
BOS 18M-NS-RD20-S4 8 designs
BOS 18M-PO-RD21-S4 @ BOS 18M-PO-RD20-S4 @
Photoelectric
BOS 18M-NO-RD21-S4 0 BOS 18M-NO-RD20-S4 0 special
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC sensors
100 mA 100 mA 100 mA 100 mA
50 mA 50 mA 50 mA 50 mA Photoelectric
distance
Dark switching Light and dark switching Light switching Dark switching sensors
Yes/Yes Yes/Yes Yes/Yes Yes/Yes for analog
distance
Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 measurement
LED, red light LED, red light LED, red light LED, red light
620...670 nm 620...670 nm 620...670 nm 620...670 nm Special
accessories for
1.25 ms 1.25 ms 1.25 ms 1.25 ms photoelectric
400 Hz 400 Hz 400 Hz 400 Hz sensors
IP 67 IP 67 IP 67 IP 67
5...+55 C 5...+55 C 5...+55 C 5...+55 C
M18x1 M18x1 M18x1 M18x1
24 24 24 24
48
48
48
48
75
75
75
75
LED LED LED LED LED LED LED LED
M12x1 M12x1 M12x1 M12x1
www.balluff.com 67
BOS 18M red light
Range 7 m Red Light
Type Retroreective sensor Retroreective sensor

Detection range 7m 7m
PNP NO/NC Part number BOS 18M-PA-PR20-S4 #
NPN NO/NC Part number BOS 18M-NA-PR20-S4 $
PNP NO/NC Part number BOS 18M-PA-PR20-S4S 2
NPN NO/NC Part number
PNP NO Part number
NPN NO Part number
PNP NC Part number
NPN NC Part number
PNP NC Special output Part number
NPN NC Special output Part number
Switching type Light and dark switching Light and dark switching
Wavelength 620...670 nm 620...670 nm
Retroreective sensor values referenced to R1 reector. M18x1 M18x1

24 24
48
48
75
75
LED LED LED LED
M12x1 M12x1

BOS 18M red light
Range 7 m
Photoelectric
sensors
Retroreective sensor Retroreective sensor Retroreective sensor

Photoelectric
7m 7m 7m standard
sensors
Cylinder
designs
Block
designs
BOS 18M-PS-PR20-S4 !
Photoelectric
BOS 18M-NS-PR20-S4 8 special
BOS 18M-PO-PR20-S4 @ sensors
BOS 18M-NO-PR20-S4 0
BOS 18M-PO-PR20-S4S 3 Photoelectric
distance
BOS 18M-NO-PR20-S4S o sensors
for analog
10...30 V DC 10...30 V DC 10...30 V DC distance
100 mA 100 mA 100 mA measurement
50 mA 50 mA 50 mA
Dark switching Light switching Light switching Special
accessories for
Yes/Yes Yes/Yes Yes/Yes photoelectric
Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 sensors
620...670 nm 620...670 nm 620...670 nm
1.25 ms 1.25 ms 1.25 ms
400 Hz 400 Hz 400 Hz
IP 67 IP 67 IP 67
5...+55 C 5...+55 C 5...+55 C
10 klx 10 klx 10 klx
Nickel-plated CuZn Nickel-plated CuZn Nickel-plated CuZn
Glass Glass Glass
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin
M18x1 M18x1 M18x1
24 24 24
48
48
48
75
75
75
LED LED LED LED LED LED
M12x1 M12x1 M12x1
www.balluff.com 69
BOS 18M red light
Range 20 m Red Light
Receiver Receiver

PNP NO/NC Receiver Part number BOS 18M-PA-RE20-S4 # BOS 18M-PA-RE20-S4S 2
NPN NO/NC Part number BOS 18M-NA-RE20-S4 $
NPN NO Part number
NPN NC Part number
Emitter Part number
Part number
Emitter Test input Part number
Part number
Settings
Wavelength 620...670 nm 620...670 nm
Wiring diagrams on page 95. M18x1 M18x1
24 24
48
48
75
75
LED LED
M12x1 M12x1

BOS 18M red light
Range 20 m
Receiver Receiver Emitter Emitter Photoelectric

sensors
Through-beam sensor Through-beam sensor Through-beam sensor Through-beam sensor

Photoelectric
0...20 m 0...20 m 0...20 m 0...20 m standard
sensors
Cylinder
designs
BOS 18M-PS-RE20-S4 @ Block
BOS 18M-NS-RE20-S4 8 designs
BOS 18M-PO-RE20-S4 @ BOS 18M-PO-RE20-S4S 3
BOS 18M-NO-RE20-S4 0 BOS 18M-NO-RE20-S4S o Photoelectric
special
BOS 18M-X-RS20-S4 2 sensors
BOS 18M-XT-RS20-S4 & Photoelectric

distance
sensors
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC for analog
distance
100 mA 100 mA measurement
35 mA 35 mA 50 mA 50 mA
Light or dark switching Light switching Special
accessories for
Yes/Yes Yes/Yes Yes/Yes Yes/Yes photoelectric
Potentiometer, 270 Potentiometer, 270 sensors
620...670 nm 620...670 nm 620...670 nm 620...670 nm
1.25 ms 1.25 ms
400 Hz 400 Hz
IP 67 IP 67 IP 67 IP 67
5...+55 C 5...+55 C 5...+55 C 5...+55 C
M18x1 M18x1 M18x1 M18x1
24 24 24 24
48
48
48
48
75
75
75
75
M12x1 M12x1 M12x1 M12x1
www.balluff.com 71
BOS 18M red light
Sensing distance 500 mm, range 5 m Red Light Teach-in

PNP NO/NC Error output Part number BOS 18M-PUV-RD30-S4 4
PNP NO/NC Part number BOS 18M-PUD-RD30-S4 5
PNP NO/NC Polarizing lter, Part number
NPN NO/NC Error output Part number
PNP NO/NC Polarizing lter Part number
Emitter Part number
Part number
Settings Teach-in Teach-in
Wavelength 626 nm 626 nm
Switching frequency f 1 kHz 200 Hz

24 24
48

48
75
75
LED LED LED LED
M12x1 M12x1

BOS 18M red light
Range 5 m, 20 m

sensors
Retroreective sensor Retroreective sensor Through-beam sensor Through-beam sensor

Photoelectric
5m 5m 0...20 m 0...20 m standard
BOS 18M-PUV-RE30-S4 4 sensors
Cylinder
designs
BOS 18M-PUD-RE30-S4 5 Block
designs
BOS 18M-PUV-PR30-S4 4
Photoelectric
special
BOS 18M-PUD-PR30-S4 5 sensors
BOS 18M-X-RS30-S4 ^ Photoelectric

distance
sensors
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC for analog
distance
40 mA 40 mA 25 mA 25 mA
Light and dark switching Light and dark switching Light and dark switching Special
accessories for
Yes/Yes Yes/Yes Yes/Yes Yes/Yes photoelectric
Teach-in Teach-in Teach-in sensors
626 nm 626 nm 626 nm
0.5 ms 2.5 ms 0.5 ms
1 kHz 200 Hz 1 kHz / 200 Hz
IP 67 IP 67 IP 67 IP 67
5...+55 C 5...+55 C 5...+55 C 5...+55 C
Nickel-plated brass Nickel-plated brass Nickel-plated brass Nickel-plated brass
M18x1 M18x1 M18x1 M18x1
24 24 24
48
48
48
48
75
75
75
75
LED
M12x1 M12x1 M12x1
M12x1
www.balluff.com 73
BOS 18M red light
Sensing distance 120 mm with Angle Head
PNP NO/NC Part number BOS 18MR-PA-1HA-S4-C #
PNP NO Part number BOS 18MR-PS-1HA-E5-C-S4 !
NPN NO Part number
PNP NO/NC Receiver Part number
Emitter Part number
Part number
Settings 18-turn potentiometer Potentiometer, 270
Response time 0.8 ms 1 ms
Diffuse sensor values referenced to 90% reective Kodak gray card.


28
19

BOS 18M red light
Sensing distance 2 m, 16 m

sensors
Retroreective sensor Through-beam sensor Through-beam sensor

Photoelectric
2m 0...16 m 0...16 m standard
sensors
Cylinder
designs
BOS 18MR-PS-1QB-E5-C-S4 ! Block
designs
BLE 18MR-PA-1PP-E5-C-S4 #
Photoelectric
special
BLS 18MR-XX-1P-E5-L-S4 ^ sensors
10...36 V DC 10...36 V DC 10...36 V DC Photoelectric

distance
20 mA 20 mA 20 mA for analog
distance
Dark switching Light and dark switching measurement
Yes/Yes Yes/Yes
Potentiometer, 270 Potentiometer, 270 Special
accessories for
LED, red light LED, red light LED, red light photoelectric
0.5 ms 0.5 ms
1 kHz 1 kHz
IP 67 IP 67 IP 67
25...+55 C 25...+55 C 25...+55 C
Nickel-plated CuZn Nickel-plated CuZn Nickel-plated CuZn
Glass Glass Glass
www.balluff.com 75
BOS 18M red light
Function diagrams Red Light
Diffuse sensor BOS 18M...RD Diffuse sensor BOS 18M...RD20

Distance function reserve Response curve
1000 30
20
RD20
Function reserve [mm]
100
Switching point [mm]

10
0
RD21
10 -10
-20
-30
1
0 100 200 300 400 500 600 700 800
0 100 200 300 400 500 600 700
Distance [mm] Distance [mm]
Diffuse sensor BOS 18M...RD21..

Response curve
15
10
5
-5
-10
-15
0 50 100 150 200 250 300 350 mm
Distance [mm]
Retroreective sensor BOS 18M...PR20... Retroreective sensor BOS 18M...PR20...

200 1000
150
100 100
50
0
10
-50
-100
1
m
0.5 2 3.5 5 6.5 8
-150
-200
0 1000 2000 3000 4000 5000 6000 7000 8000 mm
Through-beam sensor BOS 18M...RE/RS20 Through-beam sensor BOS 18M...RE/RS20

Response curve depending on distance Distance function reserve
400 0
300
0
200
Function reserve
100
0
0
-100 0
-200
1
-300
0 2 4 6 8 10 12 14 16 18 20 m
-400 Emitterreceiver distance
0 5000 10000 15000 20000 25000
Distance [m]

BOS 18M red light
Photoelectric
sensors
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Recommended accessories sories Suitable connectors

Description Ordering 1 Size Design Cable Color Length Ordering

2 Mounting bracket BAM00RY 3 M12, 4-pin Straight PVC Yellow 2m BCC05FF
www.balluff.com 77
BOS 18M infrared
Sensing distance 800 mm, Range 7 m Infrared

Detection range 80 mm Glass detection 1...800 mm 7m Polarizing lter
PNP NO/NC Part number BOS 18M-PA-ID20-S4 # BOS 18M-PA-IR21-S4 #
NPN NO/NC Part number BOS 18M-NA-ID20-S4 $ BOS 18M-NA-IR21-S4 $
PNP NO Part number BOS 18M-PS-ID24-S4 !
NPN NO Part number
Emitter Part number
Part number
Part number
Switching type Light switching Light and dark switching Light and dark switching
Settings None Potentiometer, 270 Potentiometer, 270
Emitter, light type LED, infrared LED, infrared LED, infrared
Material Housing Nickel-plated brass Nickel-plated brass Nickel-plated brass
Optical surface Glass Glass Glass
Diffuse sensor values referenced to 90% M18x1 M18x1 M18x1

reective Kodak gray card.
200200 mm retroreective sensor
values referenced to R1 reector.
24 24 24
48
48
48

75
75
75
LED LED LED
M12x1 M12x1 M12x1

BOS 18M infrared
Range 10 m, 50 m
Photoelectric
Receiver Emitter Emitter sensors
Retroreective sensor Retroreective sensor Through-beam sensor Through-beam sensor Through-beam sensor
Photoelectric
10 m 10 m 0...50 m 0...50 m 0...100 mm standard
BOS 18M-PA-IR20-S4 # sensors
Cylinder
BOS 18M-NA-IR20-S4 $ designs
BOS 18M-PS-IR20-S4 ! Block
designs
BOS 18M-PA-IE20-S4 #
Photoelectric
BOS 18M-NA-IE20-S4 $ special
BOS 18M-X-IS20-S4 ^ BOS 18M-X-IS24-S4 ^ sensors
BOS 18M-XT-IS20-S4 & BOS 18M-XT-IS24-S4 & Photoelectric

distance
sensors
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC for analog
distance
30 mA 30 mA 20 mA 30 mA 30 mA
Light and dark switching Dark switching Light and dark switching Special
accessories for
Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes photoelectric
Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 sensors
LED, infrared LED, infrared LED, infrared LED, infrared LED, infrared
850 nm 850 nm 850 nm
1.25 ms 1.25 ms 1.25 ms
400 Hz 400 Hz 400 Hz
IP 67 IP 67 IP 67 IP 67 IP 67
5...+55 C 5...+55 C 5...+55 C 5...+55 C 5...+55 C
Nickel-plated brass Nickel-plated brass Nickel-plated brass Nickel-plated brass Nickel-plated brass
Glass Glass Glass Glass Glass
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin
M18x1 M18x1 M18x1 M18x1 M18x1
24 24 24 24 24
48
48
48
48
48
75
75
75
75
75
LED LED LED
M12x1 M12x1 M12x1 M12x1 M12x1
www.balluff.com 79
BOS 18M infrared
Response curves, function diagram Infrared
Diffuse sensor BOS 18M...ID20-S4 response curve

mm
20
15
10
Switching point
-5
-10
-15
-30
0 200 400 600 800 1000 mm
Object distance
Retroreective sensor BOS 18M...IR20/IR21-S4
100
Function reserve
10
BOS R47
BOS R50
BOS R1,
BOS R9
BOS R46
1
0 1 2 3 4 5 6 7 8 9 10 11 12 m
Diffuse sensor BOS 18M...ID24-S4
100
Function reserve
10
1 mm
0 10 20 30 40 50 60 70 80
Object distance
white, 90% Remission

gray, 18% Remission
Glass (typ.)
Solar panel (typ.)

BOS 18M infrared
Accessories
Indicators and operating elements
270 potentiometer for precisely conguring

switching distance
Green LED power-on indicator
Photoelectric
Yellow LED: receiving light/stability indicator sensors
Photoelectric
Green LED power-on indicator standard
LED lit: supply voltage is applied. sensors
Cylinder
Yellow LED receiving light/stability indicator designs
LED lit: light at receiver. Block
LED ashes at function reserve < 1.5. Unreliable range. designs
Potentiometer
Used for precisely conguring the switching point Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors


code material code
1 Mounting clamp BAM00T3 1 M12, 4-pin Straight PUR Yellow 5m BCC05FE
2 Mounting bracket BAM00RY M12, 4-pin Straight PVC Yellow 2m BCC05FF
3 Reector BAM00UK 2 M12, 4-pin Angled PUR Yellow 2m BCC05TA
3

reectors, apertures, lenses, lters and deection heads, in More electrical accessories: You can nd a large selection of plug
this catalog on page 420. and lengths in our Industrial Networking and Connectivity catalog.
www.balluff.com 81
BOS 18M Laser
Sensing distance 150 mm Laser
PNP NO Part number BOS 18M-PS-LH22-S4 !
NPN NO Part number
PNP NO Error output Part number BOS 18M-PSV-LH22-S4 *
NPN NO Error output Part number BOS 18M-NSV-LH22-S4 7
PNP NC Error output Part number BOS 18M-POV-LH22-S4 (
NPN NC Error output Part number BOS 18M-NOV-LH22-S4 6
PNP NO/NC Part number
Switching type Light switching Dark switching
Emitter, light type Laser, red light Laser, red light
Laser class 2 2
Response time 1 ms 1 ms
Optical surface PMMA PMMA

BOS 18M Laser
Photoelectric
sensors
Diffuse sensor with background suppression Diffuse sensor with background suppression Diffuse sensor Diffuse sensor
Photoelectric
sensors
Cylinder
designs
BOS 18M-PSV-LH23-S4 * Block
designs
Photoelectric
special
BOS 18M-PA-LH23-S4 # BOS 18M-PA-LD10-S4 # BOS 18M-PA-LD10-02 p sensors
BOS 18M-NA-LD10-S4 $ BOS 18M-NA-LD10-02 [
distance
30 mA 30 mA 35 mA 35 mA for analog
distance
Light and dark switching Light switching Light and dark switching Light and dark switching measurement
10-turn potentiometer 10-turn potentiometer Potentiometer, 270 Potentiometer, 270 Special
accessories for
Laser, red light Laser, red light Laser, red light Laser, red light photoelectric
650 nm 650 nm 650 nm 650 nm sensors
1 1 1 1
1 ms 1 ms 333 s 333 s
500 Hz 500 Hz 1.5 kHz 1.5 kHz
IP 67 IP 67 IP 67 IP 67
5...+55 C 5...+55 C 5...+55 C 5...+55 C
Nickel-plated CuZn Nickel-plated CuZn Chrome-plated CuZn Chrome-plated CuZn
PMMA PMMA PMMA PMMA
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin 2 m PVC cable, 26 AWG
24
www.balluff.com 83
BOS 18M Laser
Range 16 m Laser

with polarizing lter with polarizing lter
Detection range 0.1...16 m 0.1...16 m
PNP NO/NC Part number BOS 18M-PA-LR10-S4 # BOS 18M-PA-LR10-02 p
NPN NO/NC Part number BOS 18M-NA-LR10-S4 $ BOS 18M-NA-LR10-02 [
Emitter Part number
Part number
Laser class 1 1
Response time 333 s 333 s
Switching frequency f 1.5 kHz 1.5 kHz
Material Housing Chrome-plated CuZn Chrome-plated CuZn
Connection M12 connector, 4-pin 2 m PVC cable, 26 AWG

24

BOS 18M Laser
Range 60 m
Receiver Receiver Emitter Emitter Photoelectric

sensors

Photoelectric
standard
0...60 m 0...60 m 0...60 m 0...60 m sensors
BOS 18M-PA-LE10-S4 # BOS 18M-PA-LE10-02 p Cylinder
designs
BOS 18M-NA-LE10-S4 $ BOS 18M-NA-LE10-02 [
Block
BOS 18M-XT-LS10-S4 & BOS 18M-XT-LS10-02 ] designs

special
35 mA 35 mA 30 mA 30 mA
Light and dark switching Light and dark switching Photoelectric
distance
Yes/Yes Yes/Yes Yes/Yes Yes/Yes sensors
Potentiometer, 270 Potentiometer, 270 for analog
distance
Laser, red light Laser, red light Laser, red light Laser, red light measurement
650 nm 650 nm 650 nm 650 nm
1 1 1 1 Special
accessories for
333 s 333 s photoelectric
1.5 kHz 1.5 kHz sensors
IP 67 IP 67 IP 67 IP 67
10...+55 C 10...+55 C 10...+55 C 10...+55 C
Chrome-plated CuZn Chrome-plated CuZn Chrome-plated CuZn Chrome-plated CuZn
PMMA PMMA PMMA PMMA
M12 connector, 4-pin 2 m PVC cable, 26 AWG M12 connector, 4-pin 2 m PVC cable, 26 AWG
M18x1
2.5
35.5
24 24 24 35.5
58
60
14.5
LED
M12x1
www.balluff.com 85
BOS 18M Laser
Sensing distance 250 mm Laser with Angle Head

PNP NO/NC Part number BOS 18MR-PA-LD10-02 p BOS 18MR-PA-LD10-S4 #
NPN NO/NC Part number BOS 18MR-NA-LD10-02 [ BOS 18MR-NA-LD10-S4 $
Laser class 1 1
Connection 2 m PVC cable, 26 AWG M12 connector, 4-pin


24 24

BOS 18M Laser
Range 9 m
Photoelectric
sensors

Photoelectric
with polarizing lter with polarizing lter standard
0.1...9 m 0.1...9 m sensors
Cylinder
BOS 18MR-PA-LR10-02 p BOS 18MR-PA-LR10-S4 # designs
BOS 18MR-NA-LR10-02 [ BOS 18MR-NA-LR10-S4 $ Block
10...30 V DC 10...30 V DC designs
100 mA 100 mA
special
Light and dark switching Light and dark switching sensors
Yes/Yes Yes/Yes
Potentiometer, 270 Potentiometer, 270 Photoelectric
distance
Laser, red light Laser, red light sensors
650 nm 650 nm for analog
distance
1 1 measurement
333 s 333 s
1.5 kHz 1.5 kHz Special
accessories for
IP 67 IP 67 photoelectric
10...+55 C 10...+55 C sensors
5 klx 5 klx
Chrome-plated CuZn Chrome-plated CuZn
PMMA PMMA
2 m PVC cable, M12 connector, 4-pin
26 AWG
24 24
www.balluff.com 87
BOS 18M Laser
Range 50 m Laser with Angle Head
Receiver Receiver

PNP NO/NC Reciever Part number BOS 18MR-PA-LE10-02 p BOS 18MR-PA-LE10-S4 #
NPN NO/NC Part number BOS 18MR-NA-LE10-02 [ BOS 18MR-NA-LE10-S4 $
Emitter Part number
Part number
Laser class 1 1
24 24

BOS 18M Laser
Range 50 m
Emitter Emitter Photoelectric

sensors

Photoelectric
0...50 m 0...50 m standard
sensors
Cylinder
designs
BOS 18MR-XT-LS10-02 ] BOS 18MR-XT-LS10-S4 & Block
designs
10...30 V DC 10...30 V DC
Photoelectric
special
30 mA 30 mA sensors
Yes/Yes Yes/Yes Photoelectric

distance
sensors
Laser, red light Laser, red light for analog
distance
650 nm 650 nm measurement
1 1
Special
accessories for
photoelectric
IP 67 IP 67 sensors
10...+55 C 10...+55 C
5 klx 5 klx
Chrome-plated CuZn Chrome-plated CuZn
PMMA PMMA
2 m PVC cable, M12 connector, 4-pin
26 AWG
24 24
www.balluff.com 89
BOS 18M Laser
Function diagrams Laser
Diffuse sensor with background suppression BOS 18M-...LH Diffuse sensor with background suppression BOS 18M-...LH
Gray value shift Light spot diameter at distance
Kodak white 90%
Laser spot (mm)

Kodak gray 18%
Sr max (%)
Kodak
black 6%
Object distance (mm)
Object distance (mm)
Diffuse sensor with background suppression BOS 18M-...LH Diffuse sensor with background suppression BOS 18M-...LH
Turn-on point for lateral approach Smallest detectable part
Switching point (mm)
Object size (mm)
Object distance (mm) Object distance (mm)
Diffuse sensor BOS 18M-..-LD10-... Diffuse sensor BOS 18MR-..-LD10-...
White 90% White 90%

Gray 18%
Gray 18%
Detection range Detection range
Resolution Resolution
Retroreective sensor BOS 18M-..-LR10-... Retroreective sensor BOS 18MR-..-LR10-...

With R1 reector With R1 reector
Detection range Detection range
Resolution Resolution

BOS 18M Laser
Function diagrams, connection, accessories
Through-beam sensor BOS 18M-..-LE/LS10-... Through-beam sensor BOS 18MR-..-LE/LS10-...
Photoelectric
sensors
Photoelectric
standard
Detection range sensors
Detection range Cylinder
designs
Block
designs
Photoelectric
special
sensors
Photoelectric
distance
Resolution Resolution sensors
for analog
distance
measurement
Special
10-turn- potentiometer for precisely conguring accessories for
switching distance photoelectric
Error indicator (green LED)
sensors
Output function indicator (yellow LED)
Green LED
The green LED turns on when the sensor is working in an unreliable
range. The green LED ashes when there is a short circuit on the
output.
Yellow LED
Output function indicator: The yellow LED comes on when the
output is active.
Error output
The error output is active when the sensor is working in an unreliable
range.
Potentiometer
Used for precisely conguring the switching point and background
suppression.

1
code material code
2
3
this catalog on page 420. connectors and connector cables in a wide variety of cable materials, colors,
www.balluff.com 91
BOS 18M
Laser through-beam sensor Laser
Through-beam Sensor
Accuracy diagram
Smallest detectable part size as
a function of range.
Type
Detection range
Part number
Minimum part size
Part number
PNP Emitter Part number
Part number
Supply voltage UB
Output current
Switching type
Range
Settings
Emitter, light type
Wavelength
Laser class
Response time
Minimum part size
Permissible ambient light
Material Housing
Optical surface
Connection
Range
Beam spot perpendicular to transport direction of the object.
Wiring diagrams
Recommended accessories ries Suitable connectors


code material code
Mounting cuff BAM00R2 M12, 4-pin Straight PUR Yellow 5m BCC05FE
More mechanical accessories: You can nd a large selection of mounting M12, 4-pin Angled PVC Yellow 2m BCC05TF
components of all types, such as clamping holders, mounting brackets, and
the Balluff mounting system BMS, in our Accessory Product Line catalog. Connectors without LED are suitable for PNP and NPN sensors.

BOS 18M
Range 50 m
0 Receiver Emitter Emitter Photoelectric

sensors

Photoelectric
0...50 m 0...50 m 0...50 m 0...50 m standard
BLE 18M-BA-1LT-S4-C BLE 18MR-BA-1LT-S4-C sensors
Cylinder
designs
Block
designs
BLS 18M-XX-1LT-S4-C BLS 18MR-XX-1LT-S4-C
Photoelectric
special
200 mA 200 mA
distance
Light/dark switching Light and dark switching sensors
distance
18-turn potentiometer 18-turn potentiometer measurement
Laser, red light Laser, red light
accessories for
2 2 photoelectric
0.08 ms 0.08 ms sensors
6 kHz 6 kHz
IP 65 IP 65 IP 65 IP 65
15...+55 C 15...+55 C 15...+55 C 15...+55 C
max.5
M18x1
37
24
74
16.5
27
M12x1
9
The beam can be focused on 9
a particular point using the

included focusing tool. Small
parts are then detected best at
this point.
Parts with a diameter of up to
0.03 mm can be detected at a
distance of 20...80 cm between
the emitter and receiver.
www.balluff.com 93
BOS 18M

Wiring diagrams
BOS 18M metal technical data
Wiring diagrams A. Diffuse with background suppression
! PS
Kodak gray card
90% Reection
Photoelectric
PO sensors
@
Photoelectric
standard
sensors
Cylinder
# PA designs
Block
designs
Sensing distance measured with lateral approach using Kodak gray card.
Photoelectric
$ NA
special
sensors
B. Diffuse Photoelectric
distance
% PU sensors
for analog
BOS 18M-..-1PA/XA-... BOS 18M-..-1PB/XB-... BOS 18M-..-1PD-...
distance
Kodak gray card measurement
90% Reection
Special
^ XX accessories for
photoelectric
sensors
Sensing distance measured with lateral approach using Kodak gray card.
& XT
* PSV
1
4 PUV
1
0 NO
+UB +U B
2 4
Error
4 2 Stab.
3 3 0V
0V
( POV 5 PUD o NO...S4S

1 +UB 1 +UB
2 4 DSC
Error
4 3 0V
3 0V
) X
1
6 NOV p PNP NO+NC
+U B PA
3 0V
1 XT 7 NSV [ NPN NO+NC

1 +UB NA
4
3 0V
2 PA-...S4S 8 NS ]
XT
3 PO-...S4S
1
9
+U B
4
3 0V
www.balluff.com 95
Photoelectric Standard Sensors M18E
BOS 18E
Product overview Stainless Steel
Photoelectric sensors from the Proxinox series are made of Features

corrosion-resistant stainless steel 1.4571 and therefore do not Supply voltage 10...30 V DC, polarity reversal protected
wear down. Their optical surface is made of 2 mm thick glass Output short circuit protected
(also available in plastic for the food industry), making it stable and Tough stainless steel housing without holes and with stainless
shockproof. The nightmare of lost name-plates is also over, because steel nuts
the photoelectric sensors are laser engraved. IP 68 degree of protection (BWN Pr. 27), can also withstand
steam cleaning
The housing design is identical for all the sensors in the BOS 18E Optical surface of tough 2 mm Borooat glass or scratch-
series. A special housing nose and optics construction provides resistant PMMA, secured in place by crimping.
optimum sealing and rigidity. In addition to the usual IP 68 protection,
steam cleaning is also permitted. Applications
Bottling equipment
In addition to retroreective and through-beam sensors with a ne- Food industry
tunable range, the BOS 18E series offers diffuse sensors whose Packaging industry
sensing distances of 100 mm, 200 mm to 400 mm have been ne- Laundry and dry-cleaning equipment
tuned. These diffuse sensors are manufactured with tight tolerances. Machine tools
This makes them ideal for rapid and simple assembly. Easily visible Heavy industry
red light (for 100 and 200 mm) also makes them easy to align. Wherever other sensors don't measure up
The through-beam model operates using infrared light. The high-
energy beam can penetrate ordinary paper. The through-beam
sensor is ideal for harsh environments, for example in the food
processing and machine tools industry, where a sensor with a large
function reserve is needed.

BOS 18E
Product overview
Type Sensing Light type Output Switching type Switching US Connection Special fea- Page
distance/ frequency tures
range
Photoelectric
sensors
M12 plug, 4-pin

Light switching
Dark switching
Polarizing lter
PNP transistor
10...30 V DC
Photoelectric
standard
Red light
Infrared
Cable
Part number Cylinder
designs
Diffuse sensor with Block
background suppression designs
BOS0016 BOS 18E-PS-1N2M-S4-D 0...40 mm 100 Hz 98
Photoelectric
Diffuse sensor special
BOS0047 BOS 18E-PS-1YA-E5-D-S4 0...100 mm 100 Hz 98 sensors
BOS0015 BOS 18E-PO-1YA-E5-D-S4 0...100 mm 100 Hz 98
Photoelectric
BOS0017 BOS 18E-PS-1XA-SA1-S4 0...100 mm 100 Hz 99 distance
sensors
for analog
BOS001A BOS 18E-PS-1YB-E5-D-S4 0...200 mm 100 Hz 99 distance
BOS0018 BOS 18E-PS-1XB-SA1-S4 0...200 mm 100 Hz 99 measurement
BOS001C BOS 18E-PS-1YD-E5-D-S4 0...400 mm 100 Hz 99 Special

accessories for
BOS0019 BOS 18E-PS-1XD-SA1-S4 0...400 mm 100 Hz 100 photoelectric
sensors
BOS00RN BOS 18E-PS-1UB-E5-D-S4 2m 100 Hz 100
BOS00RL BOS 18E-PO-1UB-E5-D-S4 2m 100 Hz 100
BOS00RP BOS 18E-PS-1UB-SA1-S4 2m 100 Hz 101
BOS0046 BOS 18E-PS-1WD-E5-D-S4 4m 100 Hz 101

Through-beam sensor
Receiver
BOS00UJ BLE 18E-PS-1P-E5-D-S4 16 m 100 Hz 101
BOS00UF BLE 18E-PO-1P-E5-D-S4 16 m 100 Hz 101
BOS00UH BLE 18E-PO-1P-E5-D-S4S 16 m 100 Hz 101
BOS00UK BLE 18E-PS-1P-SA1-S4 16 m 100 Hz 101
Through-beam sensor
Emitter
BOS00UY BLS 18E-XX-1P-E5-X-S4 16 m 101
BOS00UZ BLS 18E-XX-1P-SA1-S4 16 m 101
www.balluff.com 97
BOS 18E
Sensing distance 40, 100 mm Stainless Steel
Type Diffuse sensor with background suppression Diffuse sensor

PNP NO Part number BOS 18E-PS-1N2M-S4-D ! BOS 18E-PS-1YA-E5-D-S4 !
Part number
PNP NC Part number BOS 18E-PO-1YA-E5-D-S4 @
Part number
Switching type Light switching Light or dark switching
Degree of protection as per IEC 60529 IP 69K and IP 68 IP 69K and IP 68
Material Housing 316Ti Stainless steel 316Ti Stainless steel

BOS 18E
Sensing distance 100, 200, 400 mm,
Photoelectric
sensors

Photoelectric
BOS 18E-PS-1XA-SA1-S4 ! BOS 18E-PS-1YB-E5-D-S4 ! BOS 18E-PS-1XB-SA1-S4 ! BOS 18E-PS-1YD-E5-D-S4 ! sensors
Cylinder
designs
Block
designs
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
special
Light switching Light switching Light switching Light switching
Yes/Yes Yes/Yes Yes/Yes Yes/Yes Photoelectric
distance
Fixed Fixed Fixed Fixed sensors
LED, infrared LED, red light LED, infrared LED, red light for analog
distance
880 nm 660 nm 880 nm 660 nm measurement
5 ms 5 ms 5 ms 5 ms
100 Hz 100 Hz 100 Hz 100 Hz Special
accessories for
IP 69K and IP 68 IP 69K and IP 68 IP 69K and IP 68 IP 69K and IP 68 photoelectric
5...+75 C 20...+75 C 5...+75 C 20...+75 C sensors
316Ti Stainless steel 316Ti Stainless steel 316Ti Stainless steel 316Ti Stainless steel
PMMA scratch-resistant Glass PMMA scratch-resistant Glass
www.balluff.com 99
BOS 18E
Sensing distance 400 mm, 2 m Stainless Steel
Type Diffuse sensor Retroreective sensor

Detection range 0...400 mm 2 m with polarizing lter
PNP NO Part number BOS 18E-PS-1XD-SA1-S4 ! BOS 18E-PS-1UB-E5-D-S4 !
Part number
PNP NC Part number BOS 18E-PO-1UB-E5-D-S4 @
Part number
Part number
Part number
Output special assignment Part number
Emitter Part number
Part number
Emitter, light type LED, infrared LED, red light
Degree of protection as per IEC 60529 IP 69K and IP 68 as per BWN Pr. 27 IP 69K and IP 68 as per BWN Pr. 27
Material Housing 316Ti Stainless steel 316Ti Stainless steel
Optical surface PMMA scratch-resistant Glass


BOS 18E
Sensing distance 2, 4, 16 m
Photoelectric
sensors
Retroreective sensor Retroreective sensor Through-beam sensor Through-beam sensor

Photoelectric
2 m with polarizing lter 4m 16 m 16 m standard
BOS 18E-PS-1UB-SA1-S4 ! BOS 18E-PS-1WD-E5-D-S4 ! sensors
Cylinder
designs
Block
designs
BLE 18E-PS-1P-E5-D-S4 ! BLE 18E-PS-1P-SA1-S4 !
Photoelectric
special
BLE 18E-PO-1P-E5-D-S4 @ sensors
BLE 18E-PO-1P-E5-D-S4S $ Photoelectric

distance
sensors
for analog
BLS 18E-XX-1P-E5-X-S4 # BLS 18E-XX-1P-SA1-S4 # distance
measurement
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
200 mA 200 mA 200 mA 200 mA Special
accessories for
20 mA 20 mA 15 mA (BLS 40 mA) 15 mA (BLS 35 mA) photoelectric
Dark switching Dark switching Light or dark switching Dark switching sensors
Fixed Fixed Fixed Fixed
LED, red light LED, red light LED, infrared LED, infrared
660 nm 660 nm 880 nm 880 nm
5 ms 5 ms 5 ms 5 ms
100 Hz 100 Hz 100 Hz 100 Hz
IP 69K and IP 68 as per BWN Pr. 27 IP 69K and IP 68 as per BWN Pr. 27 IP 69K and IP 68 as per BWN Pr. 27 IP 69K and IP 68 as per BWN Pr. 27
20...+75 C 20...+75 C 5...+75 C 5...+75 C
316Ti Stainless steel 316Ti Stainless steel 316Ti Stainless steel 316Ti Stainless steel
PMMA scratch-resistant Glass Glass PMMA scratch-resistant
www.balluff.com 101
BOS 18E
Function diagrams Stainless Steel
Diffuse sensor BOS 18E-...-1YA-... Retroreective sensor BOS 18E-...-1UB-...
90% reective
Kodak Gray card
BOS R-1
reector
Sensing distance with side approach of Kodak gray card.
Diffuse sensor BOS 18E-...-1YB-... Retroreective sensor BOS 18E-...-1WD-...
90% reective
Kodak Gray card
BOS R-1
reector
Diffuse sensor BOS 18E-...-1YD-... Through-beam BLE/BLS 18E-...
Emitter/
90% reective Receiver
Kodak Gray card
For a through-beam sensor, the maximum possible offset

between the emitter and receiver is measured.

BOS 18E
Wiring diagrams
!
PS
@ Photoelectric
PO sensors
Photoelectric
standard
# sensors
XX Cylinder
designs
Block
designs
$
PO..S4S
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Recommended accessories ies Suitable connectors

(please order separately) 1 (please order separately)

code material code
1 Mounting clamp BAM00T3 M12, 4-pin Straight PVC Yellow 2m BCC0AHZ
2 Reector BAM00UK 2 M12, 4-pin Angled PVC Yellow 2m BCC0AHJ
3 Round aperture BAM00R6 3
4 Air shield BAM00R9 4 Connectors without LED are suitable for PNP and NPN sensors.
You can nd special accessories ffor photoelectric

h llectric
i sensors, such as
www.balluff.com 103
Photoelectric Standard Sensors M18
BOS 18KF Global
Plastic
BOS 18KF with expanded product line

BOS 18KF series sensors are available with red, infrared light or with
a Class 1 laser.
They are congured using a potentiometer or via teach-in.
The plastic housing with attened sides allows installation using the
included M18-nuts or screws through the sensor housing.
The sensors are available as cable or M12 connector styles with
PNP or NPN output.
Range
M12 plug, 4-pin
Glass detection
Light switching
Dark switching
Polarizing lter
10...30 V DC
Ordering code
Red light
Teach-in
Infrared
Part number
Cable
Laser
NPN
PNP
Diffuse sensor with

BOS00JM BOS 18KF-PA-1HA-S4-C 50...100 mm 500 Hz 106
BOS00HR BOS 18KF-NA-1HA-S4-C 50...100 mm 500 Hz 106
BOS00JL BOS 18KF-PA-1HA-C-02 50...100 mm 500 Hz 106
BOS00HP BOS 18KF-NA-1HA-C-02 50...100 mm 500 Hz 106
BOS00JW BOS 18KF-PA-1N1R-S4-C 100 mm 1 kHz 107
BOS00JO BOS 18KF-NA-1N1R-S4-C 100 mm 1 kHz 107
BOS00JU BOS 18KF-PA-1N1R-C-02 100 mm 1 kHz 107
BOS00HZ BOS 18KF-NA-1N1R-C-02 100 mm 1 kHz 107
Diffuse sensor with
foreground suppression
BOS00JK BOS 18KF-PA-1GA-S4-C 40...100 mm 250 Hz 107

BOS 18KF Global
Product overview
range
M12 plug, 4-pin
Glass detection
Light switching
Dark switching
Polarizing lter
10...30 V DC
Ordering code Photoelectric
Red light
Teach-in
Infrared
sensors
Part number
Cable
Laser
NPN
PNP
Photoelectric
Diffuse sensor standard
sensors
BOS00K9 BOS 18KF-PA-1XA-S4-C 0...100 mm 1 kHz 107 Cylinder
BOS00JF BOS 18KF-NA-1XA-S4-C 0...100 mm 1 kHz 107 designs
BOS00K8 BOS 18KF-PA-1XA-C-02 0...100 mm 1 kHz 108 Block
designs
BOS00JE BOS 18KF-NA-1XA-C-02 0...100 mm 1 kHz 108
BOS00JP BOS 18KF-PA-1LOC-S4-C 0...350 mm 1.5 kHz 114
Photoelectric
BOSOOHU BOS 18KF-NA-1LOC-S4-C 0...350 mm 1.5 kHz 114 special
BOS00JN BOS 18KF-PA-1LOC-C-02 0...350 mm 1.5 kHz 114 sensors
BOS00HT BOS 18KF-NA-1LOC-C-02 0...350 mm 1.5 kHz 114
Photoelectric
BOS00JZ BOS 18KF-PA-1PD-S4-C 0...400 mm 1 kHz 108 distance
BOS00J5 BOS 18KF-NA-1PD-S4-C 0...400 mm 1 kHz 108 sensors
for analog
BOS00JY BOS 18KF-PA-1PD-C-02 0...400 mm 1 kHz 109 distance
BOS00J1 BOS 18KF-NA-1PD-C-02 0...400 mm 1 kHz 109 measurement
BOS00K1 BOS 18KF-PA-1PE-S4-C 0...700 mm 1 kHz 109
Special
BOS00J5 BOS 18KF-NA-1PE-S4-C 0...700 mm 1 kHz 109 accessories for
BOS00K0 BOS 18KF-PA-1PE-C-02 0...700 mm 1 kHz 109 photoelectric
sensors
BOS00J4 BOS 18KF-NA-1PE-C-02 0...700 mm 1 kHz 109
BOS00K7 BOS 18KF-PA-1TB-S4-C 0.1...1.7 m 1 kHz 110
BOS00JC BOS 18KF-NA-1TB-S4-C 0.1...1.7 m 1 kHz 110
BOS00K6 BOS 18KF-PA-1TB-C-02 0.1...1.7 m 1 kHz 110
BOS00JA BOS 18KF-NA-1TB-C-02 0.1...1.7 m 1 kHz 110
BOS00K3 BOS 18KF-PA-1QD-S4-C 0.1...4.5 m 1 kHz 111
BOS00J7 BOS 18KF-NA-1QD-S4-C 0.1...4.5 m 1 kHz 111
BOS00K2 BOS 18KF-PA-1QD-C-02 0.1...4.5 m 1 kHz 111
BOS00J6 BOS 18KF-NA-1QD-C-02 0.1...4.5 m 1 kHz 111
BOS00K5 BOS 18KF-PA-1RE-S4-C 0.1...5 m 1 kHz 111
BOSOOJ9 BOS 18KF-NA-1RE-S4-C 0.1...5 m 1 kHz 111
BOS00K4 BOS 18KF-PA-1RE-C-02 0.1...5 m 1 kHz 111
BOS00J8 BOS 18KF-NA-1RE-C-02 0.1...5 m 1 kHz 111
BOS00JT BOS 18KF-PA-1LQP-S4-C 0.1...16 m 1.5 kHz 115
BOS00HY BOS 18KF-NA-1LQP-S4-C 0.1...16 m 1.5 kHz 115
BOS00JR BOS 18KF-PA-1LQP-C-02 0.1...16 m 1.5 kHz 115
BOS00HW BOS 18KF-NA-1LQP-C-02 0.1...16 m 1.5 kHz 115
Through-beam sensor
Receiver
BOS00CK BLE 18KF-PA-1PP-S4-C 0...20 m 250 Hz 112
BOS00CE BLE 18KF-NA-1PP-S4-C 0...20 m 250 Hz 112
BOS00CJ BLE 18KF-PA-1PP-C-02 0...20 m 250 Hz 113
BOS00CC BLE 18KF-NA-1PP-C-02 0...20 m 250 Hz 113
BOS00CH BLE 18KF-PA-1LT-S4-C 0...60 m 1.5 kHz 116
BOS00CA BLE 18KF-NA-1LT-S4-C 0...60 m 1.5 kHz 116
BOS00CF BLE 18KF-PA-1LT-C-02 0...60 m 1.5 kHz 117
BOS00C9 BLE 18KF-NA-1LT-C-02 0...60 m 1.5 kHz 117
Through-beam sensor
Emitter
BOS00EP BLS 18KF-XX-1P-S4-L 0...20 m 112
BOS00EN BLS 18KF-XX-1P-L-02 0...20 m 113
BOS00EM BLS 18KF-XX-1LT-S4-L 0...60 m 116
BOS00EL BLS 18KF-XX-1LT-L-02 0...60 m 117
www.balluff.com 105
BOS 18KF Global
Plastic
PNP NO/NC Teach-in Part number BOS 18KF-PA-1HA-S4-C ! BOS 18KF-PA-1HA-C-02 @
NPN NO/NC Teach-in Part number BOS 18KF-NA-1HA-S4-C # BOS 18KF-NA-1HA-C-02 $
Light spot diameter approx. 8 mm at 100 mm approx. 8 mm at 100 mm
Output function indicator Yellow LED Yellow LED
Stability indicator Green/red LED Green/red LED
Reference standard EN 60947-5-2 EN 60947-5-2
Material Housing PBT PBT
Diffuse sensor values referenced to 90% reective Kodak gray card. M18x1 14 M18x1 14
2.5
10

34
34
45
45
81.5
24
24 77
25
25
3.8
3.8
10
LED
M12x1 LED

BOS 18KF Global
Photoelectric
sensors
Diffuse sensor with background suppression Diffuse sensor with background suppression Diffuse sensor with foreground suppression Diffuse sensor
Photoelectric
100 mm 100 mm 40...100 mm 0...100 mm standard
BOS 18KF-PA-1N1R-S4-C ! BOS 18KF-PA-1N1R-C-02 @ BOS 18KF-PA-1XA-S4-C @ sensors
Cylinder
BOS 18KF-NA-1N1R-S4-C # BOS 18KF-NA-1N1R-C-02 $ BOS 18KF-NA-1XA-S4-C $ designs
BOS 18KF-PA-1GA-S4-C ! Block
designs
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
special
Light and dark switching Light and dark switching Light and dark switching Light and dark switching
distance
Fixed Fixed Teach-in Fixed sensors
LED, red light LED, red light LED, red light LED, infrared for analog
distance
approx. 20 mm at 100 mm approx. 20 mm at 100 mm approx. 8 mm at 100 mm approx. 80 mm at 100 mm
Yellow LED Yellow LED Yellow LED Yellow LED Special
accessories for
Green/red LED Green/red LED Green/red LED photoelectric
0.5 ms 0.5 ms 2 ms 0.5 ms sensors
1 kHz 1 kHz 250 Hz 1 kHz
IP 67 IP 67 IP 67 IP 67
25...+55 C 25...+55 C 25...+55 C 25...+55 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PBT PBT PBT PBT
PMMA PMMA PMMA PMMA
M12 connector, 4-pin 2 m PVC cable, 26 AWG M12 connector, 4-pin M12 connector, 4-pin
M18x1 14 M18x1 14 M18x1 14 M18x1 14

2.5
2.5
2.5
10
24
24
24
34
45
45
45
45
67
25
71.5
71.5
24
81.5
24 24
25
25
24
25
LED .8 LED
3
.8 .8
3 3.8 3
LED
10
10
10
LED
M12x1 M12x1
M12x1
www.balluff.com 107
BOS 18KF Global
Sensing distance 100, 400 mm Plastic

PNP NO/NC Part number BOS 18KF-PA-1XA-C-02 @ BOS 18KF-PA-1PD-S4-C !
NPN NO/NC Part number BOS 18KF-NA-1XA-C-02 $ BOS 18KF-NA-1PD-S4-C #
Switching type Light/dark (complementary) Light/dark (complementary)
Settings Fixed Potentiometer, 270
Emitter, light type LED, infrared LED, infrared
Stability indicator Green LED
Switching frequency f 1 kHz 1 kHz
2.5
2.5
24

34
45
45
67
25
24
81.5
25
.8
3 3.8
LED
10
LED
M12x1

BOS 18KF Global
Photoelectric
sensors
Diffuse sensor Diffuse sensor Diffuse sensor

Photoelectric
0...400 mm 0...700 mm 0...700 mm standard
BOS 18KF-PA-1PD-C-02 @ BOS 18KF-PA-1PE-S4-C ! BOS 18KF-PA-1PE-C-02 @ sensors
Cylinder
BOS 18KF-NA-1PD-C-02 $ BOS 18KF-NA-1PE-S4-C # BOS 18KF-NA-1PE-C-02 $ designs
10...30 V DC 10...30 V DC 10...30 V DC Block
100 mA 100 mA 100 mA designs
35 mA 35 mA 35 mA
Light/dark (complementary) Light/dark (complementary) Light/dark (complementary) Photoelectric
special
Yes/Yes Yes/Yes Yes/Yes sensors
LED, infrared LED, infrared LED, infrared Photoelectric
distance
approx. 100 mm at 300 mm approx. 200 mm at 600 mm approx. 200 mm at 600 mm for analog
distance
Yellow LED Yellow LED Yellow LED measurement
Green LED Green LED Green LED
0.5 ms 0.5 ms 0.5 ms Special
accessories for
1 kHz 1 kHz 1 kHz photoelectric
IP 67 IP 67 IP 67 sensors
25...+55 C 25...+55 C 25...+55 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PBT PBT PBT
PMMA PMMA PMMA
2 m PVC cable, 26 AWG M12 connector, 4-pin 2 m PVC cable, 26 AWG
M18x1 14 M18x1 14 M18x1 14

2.5
2.5
2.5
34
34
34
45
45
45
81.5
77
77
24 24
25
25
25
3.8
3.8
3.8
10
LED LED LED
M12x1
www.balluff.com 109
BOS 18KF Global
Range 1.7 m Plastic

Detection range 0.1...1.7 m 0.1...1.7 m
PNP NO/NC Polarizing lter, trans- Part number BOS 18KF-PA-1TB-S4-C ! BOS 18KF-PA-1TB-C-02 @
NPN NO/NC parency detection Part number BOS 18KF-NA-1TB-S4-C # BOS 18KF-NA-1TB-C-02 $
Switching type Light/dark (complementary) Light/dark (complementary)
Light spot diameter approx. 45 mm at 1 m approx. 45 mm at 1 m
Ambient temperature Ta 25...+55C 25...+55C
Retroreective sensor values referenced to R1 reector. M18x1 14 M18x1 14

2.5
2.5

34
34
45
45
77
81.5
24
24
25
25
8
3.
LED 3.8
10
LED
M12x1

BOS 18KF Global
Range 4.5 m, 5 m
Photoelectric
sensors
Retroreective sensor Retroreective sensor Retroreective sensor Retroreective sensor

Photoelectric
0.1...4.5 m 0.1...4.5 m 0.1...5 m 0.1...5 m standard
sensors
Cylinder
designs
BOS 18KF-PA-1QD-S4-C ! BOS 18KF-PA-1QD-C-02 @ Block
BOS 18KF-NA-1QD-S4-C # BOS 18KF-NA-1QD-C-02 $ designs
BOS 18KF-PA-1RE-S4-C ! BOS 18KF-PA-1RE-C-02 @
Photoelectric
BOS 18KF-NA-1RE-S4-C # BOS 18KF-NA-1RE-C-02 $ special
100 mA 100 mA 100 mA 100 mA
distance
Light/dark (complementary) Light/dark (complementary) Light/dark (complementary) Light/dark (complementary) sensors
distance
Potentiometer, 270 Potentiometer, 270 Fixed Fixed measurement
LED, red light LED, red light LED, infrared LED, infrared
660 nm 660 nm 880 nm 880 nm Special
accessories for
approx. 65 mm at 3 m approx. 65 mm at 3 m approx. 100 mm at 2 m approx. 100 mm at 2 m photoelectric
Yellow LED Yellow LED Yellow LED Yellow LED sensors
Green LED Green LED Green LED Green LED
0.5 ms 0.5 ms 0.5 ms 0.5 ms
1 kHz 1 kHz 1 kHz 1 kHz
IP 67 IP 67 IP 67 IP 67
25...+55C 25...+55C 25...+55C 25...+55C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PBT PBT PBT PBT
PMMA PMMA PMMA PMMA
M18x1 14 M18x1 14 M18x1 14 M18x1 14

2.5
2.5
2.5
2.5
24
24
34
34
45
45
45
45
67
25
24
71.5
24
25
81.5
77
24
25
25
LED .8
3.8 3
.8
3
LED
10
3.8
10
LED LED
M12x1
M12x1
www.balluff.com 111
BOS 18KF Global
Range 20 m Plastic
Receiver Emitter

PNP NO/NC Receiver Part number BLE 18KF-PA-1PP-S4-C !
NPN NO/NC Part number BLE 18KF-NA-1PP-S4-C #
Emitter Part number BLS 18KF-XX-1P-S4-L %
Part number
Switching type Light/dark (complementary)
Settings Potentiometer, 270
Help functions Test input
Emitter, light type LED, infrared
Wavelength 880 nm
Light spot diameter approx. 500 mm at 15 m
Power-on indicator Green LED Green LED
Output function indicator Yellow LED
Response time 2 ms
Wiring diagrams on page 121. M18x1 14 M18x1 14

2.5
2.5

24
34
45
45
71.5
24
25
81.5
24
25
.8
3.8 3
10
LED
M12x1
LED
M12x1

BOS 18KF Global
Range 20 m

sensors

Photoelectric
0...20 m 0...20 m standard
BLE 18KF-PA-1PP-C-02 @ sensors
Cylinder
BLE 18KF-NA-1PP-C-02 $ designs
BLS 18KF-XX-1P-L-02 ^ Block
designs
10...30 V DC 10...30 V DC
100 mA Photoelectric
special
30 mA 35 mA sensors
Light/dark (complementary)
distance
Potentiometer, 270 sensors
Test input for analog
distance
LED, infrared measurement
880 nm
approx. 500 mm at 15 m Special
accessories for
Green LED Green LED photoelectric
Yellow LED sensors
2 ms
250 Hz
IP 67 IP 67
25...+55C 25...+55C
EN 60947-5-2 EN 60947-5-2
PBT PBT
PMMA PMMA
2 m PVC cable, 2 m PVC cable,
26 AWG 26 AWG
M18x1 14 M18x1 14
2.5
2.5
24
34
45
45
67
77
24
25
25
24
3.8 3
.8
LED
LED
4
www.balluff.com 113
BOS 18KF Laser Global
Plastic Laser

PNP NO/NC Part number BOS 18KF-PA-1LOC-S4-C ! BOS 18KF-PA-1LOC-C-02 @
NPN NO/NC Part number BOS 18KF-NA-1LOC-S4-C # BOS 18KF-NA-1LOC-C-02 $
PNP NO/NC Polarizing Part number
NPN NO/NC lter Part number
Laser class 1 1
Resolution approx. 0.3 mm at 50 mm approx. 0.3 mm at 50 mm
approx. 0.3 mm at 100 mm approx. 0.3 mm at 100 mm
2.5
2.5

34
34

45
45
77
81.5
24
24
25
25
8
3.
LED 3.8
10
LED
M12x1

Range 16 m
Photoelectric
sensors

Photoelectric
0.1...16 m 0.1...16 m standard
sensors
Cylinder
designs
BOS 18KF-PA-1LQP-S4-C ! BOS 18KF-PA-1LQP-C-02 @ Block
BOS 18KF-NA-1LQP-S4-C # BOS 18KF-NA-1LQP-C-02 $ designs
10...30 V DC 10...30 V DC
special
35 mA 35 mA sensors
Light and dark switching Light and dark switching
distance
distance
1 1
approx. 0.9 mm at 1 m approx. 0.9 mm at 1 m Special
accessories for
approx. 2 mm at 3 m approx. 2 mm at 3 m photoelectric
sensors
Green LED Green LED
333 s 333 s
1.5 kHz 1.5 kHz
IP 67 IP 67
10...+50 C 10...+50 C
EN 60947-5-2 EN 60947-5-2
PBT PBT
PMMA PMMA
M12 connector, 4-pin 2 m PVC cable, 26 AWG
M18x1 14 M18x1 14
2.5
2.5
34
34
45
45
77
81.5
24 24
25
25
8
3.
LED 3.8
10
LED
M12x1
www.balluff.com 115
Range 60 m Plastic Laser
Receiver Emitter

PNP NO/NC Receiver Part number BLE 18KF-PA-1LT-S4-C ^
NPN NO/NC Part number BLE 18KF-NA-1LT-S4-C #
Emitter Part number BLS 18KF-XX-1LT-S4-L %
Part number
Switching type Light and dark switching
Emitter, light type Laser, red light
Wavelength 650 nm
Laser class 1
Resolution approx. 2.5 mm at 5 m
approx. 5 mm at 10 m
approx. 10 mm at 20 m
Response time 333 s
Switching frequency f 1.5 kHz
Wiring diagrams on page 121. M18x1 14 M18x1 14

2.5
2.5

24
34
45
45
71.5
24
81.5
25
24
25
3.8 .8
3
LED
10
LED
10
M12x1
M12x1

Range 60 m

sensors

Photoelectric
0...60 m 0...60 m standard
BLE 18KF-PA-1LT-C-02 @ sensors
Cylinder
BLE 18KF-NA-1LT-C-02 $ designs
BLS 18KF-XX-1LT-L-02 ^ Block
designs
10...30 V DC 10...30 V DC
special
30 mA 35 mA sensors
Light and dark switching
distance
Laser, red light for analog
distance
650 nm measurement
1
approx. 2.5 mm at 5 m Special
accessories for
approx. 5 mm at 10 m photoelectric
approx. 10 mm at 20 m sensors
Green LED Green LED
Yellow LED
333 s
1.5 kHz
IP 67 IP 67
10...+50 C 10...+50 C
EN 60947-5-2 EN 60947-5-2
PBT PBT
PMMA PMMA
2 m PVC cable, 26 AWG 2 m PVC cable, 26 AWG
M18x1 14 M18x1 14
2.5
2.5
24
34
45
45
67
24
25
77
24
25
3
.8
3.8
LED
LED
www.balluff.com 117
BOS 18KF Global
Function diagrams Plastic
Diffuse sensor BOS 18KF-..-1HA-...
Percent
difference
Percent
difference
Gray 18%
Gray 18%
White 90%
White 90%
Settings against 90% white background Settings against 90% white background
Tolerance with standard setting Tolerance with ne setting
Diffuse sensor BOS 18KF-..-1N1R-...
White 90%
Gray 18%
White 90%
Gray 18%
Detection range Function reserve
Diffuse sensor BOS 18KF-..-1XA-...
White 90%
Gray 18%
White 90%
Gray 18%
Diffuse sensor BOS 18KF-..-1GA-...
Sensing distance
rea
na
ressio
upp
nds g ran
ge
g rou Wor
kin
B ack
a
ion are
ppress
und su
Foregro
Sensing distance
Hysteresis with standard setting

BOS 18KF Global
Function diagrams
Diffuse sensor BOS 18KF-..-1PD-...
White 90%
Gray 18% Photoelectric

sensors
White 90%
Photoelectric
Gray 18%
standard
sensors
Cylinder
designs
Block
designs
Detection range Function reserve Photoelectric

special
sensors
Diffuse sensor BOS 18KF-..-1PE-...
White 90% Photoelectric

distance
Gray 18% sensors
for analog
distance
measurement
White 90%
Gray 18% Special

accessories for
photoelectric
sensors
Retroreective sensor BOS 18KF-..-1TB-...
With R1 reector
With R1 reector
Retroreective sensor BOS 18KF-..-1QD-...
With R1 reector
With R1 reector
www.balluff.com 119
BOS 18KF Global
Function diagrams Plastic
Retroreective sensor BOS 18KF-..-1RE-...
With R1 reector
With R1 reector
Detection range
Function reserve
Through-beam sensor BLE/BLS 18KF-..-1PP/1P-...
Diffuse sensor BOS 18KF-..-1LOC-...
White 90%
Gray 18%
Detection range Resolution
Retroreective sensor BOS 18KF-..-1LQP-...
With R1 reector

BOS 18KF Global
Through-beam sensor BLE/BLS 18KF-..-1LT-...
Photoelectric
sensors
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
Photoelectric
Detection range Resolution special
sensors
Photoelectric
distance
Wiring diagrams Connector orientation sensors
for analog
@ distance
! PNP NO+NC
1 BN measurement
PA +UB +UB
4 BK
2 WH
3 BU Special
0V 0V accessories for
photoelectric
sensors
# NPN NO+NC
1 $ BN
+UB +UB
NA 4 BK
2 WH
3 BU
0V 0V
% Emitter
1 ^ BN
+UB +UB
XX 4 BK
Test Test
2 WH
Test+ Test+
3 BU
0V 0V
BOS 18KF


3 Reector BAM00UK 3 M12, 4-pin Angled PUR Yellow 2m BCC05TA
4
4 Round aperture BAM00R6 M12, 4-pin Angled PVC Yellow 2m BCC05TF
5 Cover nut BAM00RL
5 6 Connectors without LED are suitable for PNP and NPN sensors.
C
6 Air shield BAM00R9
You can nd special accessories for photoelectric

hotoelectric sensors,
s, such as
reectors, apertures, lenses, lters and deection heads,, in More electrical accessories: You can nd a large selection of plug
www.balluff.com 121
Photoelectric Standard Sensors M18 Plastic
BOS 18KW Global
with Angle Head
BOS 18KF with expanded product line

BOS 18KF series sensors are available with red, infrared light or with
a Class 1 laser.
They are congured using a potentiometer or via teach-in.
The plastic housing with attened sides allows installation using the
included M18-nuts or screws through the sensor housing.
The sensors are available as cable or M12 connector styles with
PNP or NPN output.

BOS 18KW Global
Product overview
Type Sensing Light type Output Switching Switching US Connection Special Page
distance/ type frequency features
range
Photoelectric
sensors
M12 plug, 4-pin

Light switching
Dark switching
Polarizing lter
10...30 V DC
Photoelectric
standard
Red light
Teach-in
Infrared
Cable
Laser
NPN
PNP
Cylinder
Part number designs
BOS00LH BOS 18KW-PA-1HA-S4-C 50...100 mm 500 Hz 124
BOSOOKY BOS 18KW-NA-1HA-S4-C 50...100 mm 500 Hz 124 Photoelectric
BOS00LF BOS 18KW-PA-1HA-C-02 50...100 mm 500 Hz 124 special
sensors
Diffuse sensor
Photoelectric
BOS00M1 BOS 18KW-PA-1XA-S4-C 0...80 mm 1 kHz 125 distance
BOS00LE BOS 18KW-NA-1XA-S4-C 0...80 mm 1 kHz 125 sensors
for analog
BOS00M0 BOS 18KW-PA-1XA-C-02 0...80 mm 1 kHz 125 distance
BOSOOLC BOS 18KW-NA-1XA-C-02 0...80 mm 1 kHz 125 measurement
BOS00LK BOS 18KW-PA-1LOB-S4-C 0...250 mm 1.5 kHz 130
BOS00LO BOS 18KW-NA-1LOB-S4-C 0...250 mm 1.5 kHz 130 Special
accessories for
BOS00LJ BOS 18KW-PA-1LOB-C-02 0...250 mm 1.5 kHz 130 photoelectric
sensors
BOS00KZ BOS 18KW-NA-1LOB-C-02 0...250 mm 1.5 kHz 130
BOS00LT BOS 18KW-PA-1PD-S4-C 0...400 mm 1 kHz 125
BOS00L6 BOS 18KW-NA-1PD-S4-C 0...400 mm 1 kHz 125
BOS00LR BOS 18KW-PA-1PD-C-02 0...400 mm 1 kHz 125
BOS00L5 BOS 18KW-NA-1PD-C-02 0...400 mm 1 kHz 125
BOS00LZ BOS 18KW-PA-1TB-S4-C 0.1...1.7 m 1 kHz 126
BOS00LA BOS 18KW-NA-1TB-S4-C 0.1...1.7 m 1 kHz 126
BOS00LY BOS 18KW-PA-1TB-C-02 0.1...1.7 m 1 kHz 126
BOS00L9 BOS 18KW-NA-1TB-C-02 0.1...1.7 m 1 kHz 126
BOS00LW BOS 18KW-PA-1QC-S4-C 0.1...3 m 1 kHz 127
BOS00L8 BOS 18KW-NA-1QC-S4-C 0.1...3 m 1 kHz 127
BOS00LU BOS 18KW-PA-1QC-C-02 0.1...3 m 1 kHz 127
BOS00L7 BOS 18KW-NA-1QC-C-02 0.1...3 m 1 kHz 127
BOS00LM BOS 18KW-PA-1LQH-S4-C 0.1...9 m 1.5 kHz 131
BOS00L2 BOS 18KW-NA-1LQH-S4-C 0.1...9 m 1.5 kHz 131
BOS00LL BOS 18KW-PA-1LQH-C-02 0.1...9 m 1.5 kHz 131
BOS00LI BOS 18KW-NA-1LQH-C-02 0.1...9 m 1.5 kHz 131
Through-beam sensor
Receiver
BOS00CW BLE 18KW-PA-1PP-S4-C 0...15 m 250 Hz 128
BOS00CP BLE 18KW-NA-1PP-S4-C 0...15 m 250 Hz 128
BOS00CU BLE 18KW-PA-1PP-C-02 0...15 m 250 Hz 129
BOS00CN BLE 18KW-NA-1PP-C-02 0...15 m 250 Hz 129
BOS00CT BLE 18KW-PA-1LT-S4-C 0...50 m 1.5 kHz 133
BOS00CM BLE 18KW-NA-1LT-S4-C 0...50 m 1.5 kHz 133
Through-beam sensor
Emitter
BOS00EW BLS 18KW-XX-1P-S4-L 0...15 m 128
BOS00EU BLS 18KW-XX-1P-L-02 0...15 m 129
BOS00ET BLS 18KW-XX-1LT-S4-L 0...50 m 133
www.balluff.com 123
BOS 18KW Global
with Angle Head
PNP NO/NC Teach-in Part number BOS 18KW-PA-1HA-S4-C ! BOS 18KW-PA-1HA-C-02 @
NPN NO/NC Teach-in Part number BOS 18KW-NA-1HA-S4-C #
Stability indicator Green/red LED Green/red LED
Permissible ambient light EN 60947-5-2 EN 60947-5-2

BOS 18KW Global
Photoelectric
sensors

Photoelectric
BOS 18KW-PA-1XA-S4-C ! BOS 18KW-PA-1XA-C-02 @ BOS 18KW-PA-1PD-S4-C ! BOS 18KW-PA-1PD-C-02 @ sensors
Cylinder
BOS 18KW-NA-1XA-S4-C # BOS 18KW-NA-1XA-C-02 $ BOS 18KW-NA-1PD-S4-C # BOS 18KW-NA-1PD-C-02 $ designs
Block
designs
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
special
Light and dark switching Light and dark switching Light and dark switching Light and dark switching
distance
Fixed Fixed Potentiometer, 270 Potentiometer, 270 sensors
LED, infrared LED, infrared LED, infrared LED, infrared for analog
distance
approx. 55 mm at 100 mm approx. 55 mm at 100 mm approx. 35 mm at 400 mm approx. 35 mm at 400 mm
accessories for
0.5 ms 0.5 ms 0.5 ms 0.5 ms sensors
1 kHz 1 kHz 1 kHz 1 kHz
IP 67 IP 67 IP 67 IP 67
25...+55 C 25...+55 C 25...+55 C 25...+55 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PBT PBT PBT PBT
PMMA PMMA PMMA PMMA
M18x1
5.25 14
www.balluff.com 125
BOS 18KW Global
Range 1.7 m
with Angle Head

Detection range 0.1...1.7 m 0.1...1.7 m
PNP NO/NC Polarizing lter, Part number BOS 18KW-PA-1TB-S4-C ! BOS 18KW-PA-1TB-C-02 @
NPN NO/NC Transparency detection Part number BOS 18KW-NA-1TB-S4-C # BOS 18KW-NA-1TB-C-02 $
Light spot diameter approx. 60 mm at 1 m approx. 60 mm at 1 m

5.3 5.3

BOS 18KW Global
Range 3 m
Photoelectric
sensors

Photoelectric
0.1...3 m 0.1...3 m standard
sensors
Cylinder
designs
BOS 18KW-PA-1QC-S4-C ! BOS 18KW-PA-1QC-C-02 @ Block
BOS 18KW-NA-1QC-S4-C # BOS 18KW-NA-1QC-C-02 $ designs
Photoelectric
special
10...30 V DC 10...30 V DC sensors
100 mA 100 mA
distance
Light and dark switching Light and dark switching sensors
Yes/Yes Yes/Yes for analog
distance
Potentiometer, 270 Potentiometer, 270 measurement
LED, red light LED, red light
accessories for
Yellow LED Yellow LED sensors
Green LED Green LED
0.5 ms 0.5 ms
1 kHz 1 kHz
IP 67 IP 67
25...+55C 25...+55C
EN 60947-5-2 EN 60947-5-2
PBT PBT
PMMA PMMA
M18x1
5.25 14
www.balluff.com 127
BOS 18KW Global
Range 15 m
with Angle Head
Receiver Emitter

PNP NO/NC Receiver Part number BLE 18KW-PA-1PP-S4-C !
NPN NO/NC Part number BLE 18KW-NA-1PP-S4-C #
Emitter Part number BLS 18KW-XX-1P-S4-L %
Part number
Switching type Light and dark switching
Help functions Test input
Wavelength 880 nm
Light spot diameter approx. 470 mm at 10 m
Response time 2 ms

BOS 18KW Global
Range 15 m

sensors

Photoelectric
0...15 m 0...15 m standard
BLE 18KW-PA-1PP-C-02 @ sensors
Cylinder
BLE 18KW-NA-1PP-C-02 $ designs
BLS 18KW-XX-1P-L-02 ^ Block
designs
10...30 V DC 10...30 V DC
special
30 mA 35 mA sensors
distance
distance
LED, infrared measurement
880 nm
approx. 470 mm at 10 m Special
accessories for
Yellow LED sensors
2 ms
250 Hz
IP 67 IP 67
25...+55C 25...+55C
EN 60947-5-2 EN 60947-5-2
PBT PBT
PMMA PMMA
2 m PVC cable, 26 AWG 2 m PVC cable, 26 AWG
www.balluff.com 129
BOS 18KW Laser Global
Laser with Angle Head

PNP NO/NC Part number BOS 18KW-PA-1LOB-S4-C BOS 18KW-PA-1LOB-C-02
NPN NO/NC Part number BOS 18KW-NA-1LOB-S4-C BOS 18KW-NA-1LOB-C-02
Laser class 1 1
Resolution approx. 0.3 mm at 50 mm approx. 0.3 mm at 50 mm

Retroreective sensor values referenced to R1 reector. 5.3 5.3

Range 9 m
Photoelectric
sensors

Photoelectric
0.1...9 m 0.1...9 m standard
sensors
Cylinder
designs
BOS 18KW-PA-1LQH-S4-C BOS 18KW-PA-1LQH-C-02 Block
BOS 18KW-NA-1LQH-S4-C BOS 18KW-NA-1LQH-C-02 designs
10...30 V DC 10...30 V DC
special
35 mA 35 mA sensors
Light and dark switching Light and dark switching
distance
distance
1 1
approx. 0.9 mm at 1 m approx. 0.9 mm at 1 m Special
accessories for
sensors
Green LED Green LED
333 s 333 s
1.5 kHz 1.5 kHz
IP 67 IP 67
10...+50 C 10...+50 C
EN 60947-5-2 EN 60947-5-2
PBT PBT
PMMA PMMA
5.3 5.3
www.balluff.com 131
Range 50 m Laser with Angle Head
Type
Detection range
PNP NO/NC Emitter Part number
Supply voltage UB
Output current
Switching type
Settings
Help function
Emitter, light type
Wavelength
Laser class
Resolution
Power-on indicator
Response time
Reference standard
Material Housing
Optical surface
Connection

Range 50 m
Photoelectric
sensors

Photoelectric
0...50 m 0...50 m standard
BLS 18KW-XX-1LT-S4-L sensors
Cylinder
designs
BLE 18KW-PA-1LT-S4-C Block
BLE 18KW-NA-1LT-S4-C designs
10...30 V DC 10...30 V DC
special
30 mA 35 mA sensors
distance
distance
Laser, red light measurement
650 nm
1 Special
accessories for
approx. 2.5 mm at 5 m photoelectric
approx. 5 mm at 10 mm sensors
approx. 10 mm at 20 mm
Green LED Green LED
Yellow LED
333 s
1.5 kHz
IP 67 IP 67
10...+50 C 10...+50 C
EN 60947-5-2 EN 60947-5-2
PBT PBT
PMMA PMMA
www.balluff.com 133
BOS 18KW Global
Function diagrams with Angle Head
Diffuse BOS 18KW-..-1HA-... Through-beam BLE/BLS 18KW-..-1PP/1P-...
Percent
difference Percent
difference
Gray 18% Gray 18%
White 90% White 90%
Settings against 90% white background Settings against 90% white background
Tolerance with standard setting Tolerance with ne setting Detection range Function reserve
Diffuse sensor BOS 18KW-..-1XA-... Diffuse sensor BOS 18KW-..-1LOB-...
White 90%
Gray 18%
White 90%
Gray 18%
White 90%
Gray 18%
Detection range Function reserve Detection range Resolution
Diffuse sensor BOS 18KW-..-1PD-... Retroreective BOS 18KW-..-1LQH-...
With R1 reector
White 90%
Gray 18%
White 90%
Gray 18%
Retroreective sensor BOS 18KW-..-1TB-... Through-beam sensor BLE/BLS 18KW-..-1LT-...
With R1 reector
With R1 reector
Retroreective sensor BOS 18KW-..-1QC-...
With R1 reector
With R1 reector

BOS 18KW Global
Wiring diagrams Connector orientation
! PNP NO+NC
1 BN
@ BN
PA +UB +UB
4 BK BK
2 WH WH Photoelectric
3 BW BU sensors
0V 0V
Photoelectric
# NPN NO+NC $ standard
NA
1 BN +UB BN
+UB sensors
4 BK BK
Cylinder
2 WH WH
designs
3 BU BU
0V 0V Block
designs
% Emitter
1 BN
^ BN
XX +UB +UB Photoelectric
4 BK BK special
Test Test
2 WH WH sensors
Test+ Test+
3 BU BU
0V 0V
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Suitable connectors
Recommended accessories sories (please order separately)
1
2 Mounting bracket BAM00RY 3 M12, 4-pin Straight PVC Yellow 2m BCC05FF
www.balluff.com 135
Photoelectric Standard Sensors M30 metal
BOS 30M
The BOS 30M series combines the high optical performance of large Features
block-shaped sensors with the installation-friendly characteristics of Long sensing distance
cylindrical sensors. Tough design (metal housing and glass protective shield)
The long 2 m sensing distance provides great function reserve under 18-turn- potentiometer
less than favorable operating conditions. A tough glass disk protects NO-/NC- toggle
the optics from debris such as hot swarf, and the 18-turn- poten- Compatible with special glass optical ber
tiometer enables precise sensitivity conguration. In addition, the Automotive industry approved
integrated contamination indicator provides warning of contamination Contamination indicator
or external inuences in order to avoid impairing the optics.
The BOS 30M series provides a very high performance and robust Applications
design together with special glass optical ber BFO 18V-... A design Automotive industry
that is particularly well-suited to the automotive industry. Conveying and warehouse equipment
Construction machinery
Woodworking industry
In harsh environments

BOS 30M
Product overview
range
Photoelectric
sensors
M12 plug, 4-pin

Light switching
Dark switching
NPN transistor
PNP transistor
10...30 V DC
Photoelectric
standard
Infrared
Cylinder
Part number designs
Diffuse sensor Block
designs
BOS0134 BOS 30M-GA-1PH-S4-C 0...2 m 100 Hz 139
BOS008T BOS 30M-PU-1PH-SA3-C 0...2 m 100 Hz 139 Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 137
Photoelectric Standard Sensors M30 metal
BOS 30M
Function diagram, connection, accessories
Diffuse BOS 30M-..-1PH-...
90% reective
Kodak Gray card
Wiring diagrams
Switch for halving the switching distance.

The switching distance can be set more precisely. The
resolution of the 8-turn spindle- potentiometer is increased.
Inverting switch for toggling the nal stage version, thereby

converting normally closed to normally open.


code material code
Mounting clamp BAM00TN M12, 4-pin Straight PUR Yellow 5m BCC05FE
You can nd special accessories for photoelectric sensors, such as M12, 4-pin Angled PVC Yellow 2m BCC05TF
this catalog on page 420. Connectors without LED are suitable for PNP and NPN sensors.
More electrical accessories: You can nd a large selection of plug con-

nectors and connector cables in a wide variety of cable materials, colors, and
lengths in our Industrial Networking and Connectivity catalog.

BOS 30M
Sensing distance 2 m
Approval
for the
automotive industry Photoelectric
sensors

Photoelectric
Detection range 200...2000 mm 200...2000 mm standard
PNP Daylight lter Ordering code BOS008T sensors
Cylinder
Part number BOS 30M-PU-1PH-SA3-C designs
PNP/NPN Daylight lter Ordering code BOS0134 Block
Part number BOS 30M-GA-1PH-S4-C designs
Output current 200 mA 200 mA Photoelectric
special
No-load supply current I0 max. 50 mA 40 mA sensors
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes Photoelectric
distance
Settings Potentiometer, 18-turn Potentiometer, 18-turn sensors
Emitter, light type LED, infrared LED, infrared for analog
distance
Wavelength 880 nm 880 nm measurement
Output function indicator Yellow LED Yellow LED Special
accessories for
Stability indicator Red LED Red LED photoelectric
Response time 33 ms 5 ms sensors
Diffuse sensor values referenced to 90% reective

Kodak gray card, 400400 mm.
www.balluff.com 139
Photoelectric Standard Sensors mini.s
BOS Q08M
BOS Q08M
Diffuse sensor, reection and through-beam sensor are now also

available in the block-shaped housing with 8 mm edge length. They
provide the small sensors solutions in highly dynamic applications
such as robot arms. That is precisely where components that have
very low-weight and small dimensions while retaining high switching
precision are in demand.
Reliably detect the smallest parts

Balluff through-beam sensors BOS Q08M are innovative, compact
products that reach a high performance level. Nothing else produces
comparable results under similar conditions. These sensors are
therefore particularly recommended if there is little space available.
A focused light beam is able to detect even the smallest of parts,
grooves or holes reliably. In this way, they check things like heights
very reliably. And in cramped systems, the high-performance,
compact units are also characterized by the fact that their ne laser
beam (PinPoint laser/red light) can be aligned very precisely in the
middle of closely set parts to ensure reliable detection.
Small design for small spaces

Rugged metal housing
Reliable detection of small parts up to
0.4 mm (PinPoint red light) or 0.28 mm (laser)
Uses a patented mounting concept for Bosch
proles that allows quick, precise positioning
Type Sensing Light type Output Switching Switch- US Connection Special Page
distance/ type ing fre- features
Range quency
M8 connector, 3-pin
Red light pin point
Pigtail M8 plug,
Light switching
Dark switching
Polarizing lter
10...30 V DC
Cable, 2 m
Red light
Ordering code
Laser
3-pin
NPN
Part number
PNP
Diffuse sensor with

BOS0163 BOS Q08M-PS-KF20-00,2-S49 5...50 mm 400 Hz 142
BOS0169 BOS Q08M-NS-KF20-00,2-S49 5...50 mm 400 Hz 142
BOS0168 BOS Q08M-PO-KF20-00.2-S49 5...50 mm 400 Hz 142
BOS0162 BOS Q08M-NO-KF20-00.2-S49 5...50 mm 400 Hz 142
BOS0160 BOS Q08M-PS-KF20-S49 5...50 mm 400 Hz 142
BOS016C BOS Q08M-NS-KF20-S49 5...50 mm 400 Hz 142
BOS0164 BOS Q08M-PO-KF20-S49 5...50 mm 400 Hz 142
BOS0167 BOS Q08M-NO-KF20-S49 5...50 mm 400 Hz 142
BOS0161 BOS Q08M-PS-KF20-02 5...50 mm 400 Hz 143
BOS016A BOS Q08M-NS-KF20-02 5...50 mm 400 Hz 143
BOS0165 BOS Q08M-PO-KF20-02 5...50 mm 400 Hz 143
BOS0166 BOS Q08M-NO-KF20-02 5...50 mm 400 Hz 143
Diffuse sensor
BOS0041 BOS Q08M-PS-RD11-S49 0...55 mm 500 Hz 143
BOS003W BOS Q08M-NS-RD11-S49 0...55 mm 500 Hz 143
BOS003Z BOS Q08M-PO-RD11-S49 0...55 mm 500 Hz 143
BOS003T BOS Q08M-NO-RD11-S49 0...55 mm 500 Hz 143
BOS0040 BOS Q08M-PS-RD11-02 0...55 mm 500 Hz 143
BOS003U BOS Q08M-NS-RD11-02 0...55 mm 500 Hz 143
BOS003Y BOS Q08M-P0-RD11-02 0...55 mm 500 Hz 143
BOS003R BOS Q08M-N0-RD11-02 0...55 mm 500 Hz 143

BOS Q08M
Product overview
Range quency
M8 connector, 3-pin
Red light pin point
Pigtail M8 plug,
Light switching
Dark switching
Polarizing lter
10...30 V DC
Photoelectric
Cable, 2 m
sensors
Ordering code
Red light
Part number
Laser
3-pin
NPN
PNP
Photoelectric
standard
sensors
Cylinder
Retroreective sensor designs
BOS00U6 BOS Q08M-PS-PR11-S49 25...550 mm 500 Hz 144 Block
BOS0150 BOS Q08M-NS-PR11-S49 25...550 mm 500 Hz 144 designs
BOS00U4 BOS Q08M-PO-PR11-S49 25...550 mm 500 Hz 144
BOS00U1 BOS Q08M-NO-PR11-S49 25...550 mm 500 Hz 144 Photoelectric
special
BOS00U5 BOS Q08M-PS-PR11-02 25...550 mm 500 Hz 144 sensors
BOS00U2 BOS Q08M-NS-PR11-02 25...550 mm 500 Hz 144
BOS00U3 BOS Q08M-PO-PR11-02 25...550 mm 500 Hz 144 Photoelectric
distance
BOS00U0 BOS Q08M-NO-PR11-02 25...550 mm 500 Hz 144 sensors
Through-beam sensor for analog
distance
Receiver measurement
BOS00YC BOS Q08M-PS-KE20-00,2-S49 0...2.2 m 400 Hz 145
BOS00Y5 BOS Q08M-NS-KE20-00,2-S49 0...2.2 m 400 Hz 145 Special
accessories for
BOS00Y8 BOS Q08M-PO-KE20-00,2-S49 0...2.2 m 400 Hz 145 photoelectric
BOS00Y4 BOS Q08M-NO-KE20-00,2-S49 0...2.2 m 400 Hz 145 sensors
BOS00YF BOS Q08M-PS-KE20-S49 0...2.2 m 400 Hz 145
BOS00Y7 BOS Q08M-NS-KE20-S49 0...2.2 m 400 Hz 145
BOS00YA BOS Q08M-PO-KE20-S49 0...2.2 m 400 Hz 145
BOS00Y3 BOS Q08M-NO-KE20-S49 0...2.2 m 400 Hz 145
BOS00YE BOS Q08M-PS-KE20-02 0...2.2 m 400 Hz 145
BOS00Y6 BOS Q08M-NS-KE20-02 0...2.2 m 400 Hz 145
BOS00Y9 BOS Q08M-PO-KE20-02 0...2.2 m 400 Hz 145
BOS00Y2 BOS Q08M-NO-KE20-02 0...2.2 m 400 Hz 145
BOS0197 BOS Q08M-PS-LE20-00,2-S49 0...3 m 400 Hz 146

BOS0191 BOS Q08M-NS-LE20-00,2-S49 0...3 m 400 Hz 146
BOS0194 BOS Q08M-PO-LE20-00.2-S49 0...3 m 400 Hz 146
BOS0184 BOS Q08M-NO-LE20-00.2-S49 0...3 m 400 Hz 146
BOS0199 BOS Q08M-PS-LE20-S49 0...3 m 400 Hz 146
BOS0193 BOS Q08M-NS-LE20-S49 0...3 m 400 Hz 146
BOS0196 BOS Q08M-PO-LE20-S49 0...3 m 400 Hz 146
BOS0190 BOS Q08M-NO-LE20-S49 0...3 m 400 Hz 146
BOS0198 BOS Q08M-PS-LE20-02 0...3 m 400 Hz 147
BOS0192 BOS Q08M-NS-LE20-02 0...3 m 400 Hz 147
BOS0195 BOS Q08M-PO-LE20-02 0...3 m 400 Hz 147
BOS0182 BOS Q08M-NO-LE20-02 0...3 m 400 Hz 147
Through-beam sensor
Emitter
BOS00YH BOS Q08M-X-KS20-00,2-S49 0...2.2 m 145
BOS00YK BOS Q08M-X-KS20-S49 0...2.2 m 145
BOS00YJ BOS Q08M-X-KS20-02 0...2.2 m 145
BOS019M BOS Q08M-X-LS20-00,2-S49 0...3 m 146

BOS018K BOS Q08M-X-LS20-S49 0...3 m 146
BOS018M BOS Q08M-X-LS20-02 0...3 m 147
www.balluff.com 141
BOS Q08M
Sensing distance 50 mm BOS Q08M
PNP NO Part number BOS Q08M-PS-KF20-00,2-S49 @ BOS Q08M-PS-KF20-S49 @
NPN NO Part number BOS Q08M-NS-KF20-00,2-S49 ^ BOS Q08M-NS-KF20-S49 ^
PNP NC Part number BOS Q08M-PO-KF20-00.2-S49 $ BOS Q08M-PO-KF20-S49
NPN NC Part number BOS Q08M-NO-KF20-00.2-S49 * BOS Q08M-NO-KF20-S49 *
Switching type Light or dark switching Light or dark switching
Emitter, light type Pin point-LED, red light Pin point-LED, red light
Permissible ambient light per EN 60947-5-2 EN 60947-5-2
Material Housing Nickel-plated GD-Zn Nickel-plated GD-Zn
Optical surface PMMA, PC PMMA, PC
Connection Pigtail 20 cm, M8 plug, M8 connector,
3-pin 3-pin
Diffuse values referenced to 90% reective Kodak gray card. 8 8

3 3
5
5
10
10

15
15
M3
M3
40
20
20
44
50
59
LED
LED
M8x1
36.5
M8x1

BOS Q08M
Photoelectric
sensors
Diffuse sensor with background suppression Diffuse sensor Diffuse sensor

Photoelectric
5...50 mm 0...55 mm 0...55 mm standard
BOS Q08M-PS-KF20-02 ! BOS Q08M-PS-RD11-S49 @ BOS Q08M-PS-RD11-02 ! sensors
Cylinder
BOS Q08M-NS-KF20-02 % BOS Q08M-NS-RD11-S49 ^ BOS Q08M-NS-RD11-02 % designs
BOS Q08M-PO-KF20-02 # BOS Q08M-PO-RD11-S49 $ BOS Q08M-PO-RD11-02 # Block
BOS Q08M-NO-KF20-02 & BOS Q08M-NO-RD11-S49 * BOS Q08M-NO-RD11-02 & designs
10...30 V DC 10...30 V DC 10...30 V DC
100 mA 100 mA 100 mA Photoelectric
special
Light or dark switching Light or dark switching Light or dark switching
Yes/Yes Yes/Yes Yes/Yes Photoelectric
distance
Fixed Fixed Fixed sensors
Pin point-LED, red light LED, red light LED, red light for analog
distance
655 nm 640 nm 640 nm measurement
1.25 ms 1.25 ms 1.25 ms Special
accessories for
400 Hz 400 Hz 400 Hz photoelectric
10...+60 C 10...+60 C 10...+60 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Nickel-plated GD-Zn Nickel-plated GD-Zn Nickel-plated GD-Zn
PMMA, PC PMMA PMMA
2 m PUR cable, 26 AWG M8 connector, 2 m PUR cable, 26 AWG
3-pin
8 3 8
3

5

10
10
5
15
-
M3
40

20
40
20
44

,%$
M3(2x)
LED LED
4
-X
www.balluff.com 143
BOS Q08M
Range 550 mm BOS Q08M

PNP NO Polarizing lter Part number BOS Q08M-PS-PR11-S49 @ BOS Q08M-PS-PR11-02 !
NPN NO Part number BOS Q08M-NS-PR11-S49 ^ BOS Q08M-NS-PR11-02 %
PNP NC Polarizing lter Part number BOS Q08M-PO-PR11-S49 $ BOS Q08M-PO-PR11-02 #
NPN NC Part number BOS Q08M-NO-PR11-S49 * BOS Q08M-NO-PR11-02 &
NPN NO Part number
NPN NC Part number
Emitter Part number
Part number
Smallest detectable part
Connection M8 connector, 2 m PUR cable, 26 AWG
3-pin
Retroreective sensor values referenced to R9 reector. 3 8


10

5
-
40

20

,%$
M3(2x)
LED
4
-X

BOS Q08M
Range 2.2 m
Photoelectric
sensors
Through-beam sensor Through-beam sensor Through-beam sensor

Photoelectric
0...2.2 m 0...2.2 m 0...2.2 m standard
sensors
Cylinder
designs
Block
designs
BOS Q08M-PS-KE20-00,2-S49 @ BOS Q08M-PS-KE20-S49 @ BOS Q08M-PS-KE20-02 !
Photoelectric
BOS Q08M-NS-KE20-00,2-S49 ^ BOS Q08M-NS-KE20-S49 ^ BOS Q08M-NS-KE20-02 % special
BOS Q08M-PO-KE20-00,2-S49 $ BOS Q08M-PO-KE20-S49 $ BOS Q08M-PO-KE20-02 # sensors
BOS Q08M-NO-KE20-00,2-S49 * BOS Q08M-NO-KE20-S49 * BOS Q08M-NO-KE20-02 &
BOS Q08M-X-KS20-00,2-S49 ) BOS Q08M-X-KS20-S49 ) BOS Q08M-X-KS20-02 ( Photoelectric
distance
sensors
10...30 V DC 10...30 V DC 10...30 V DC for analog
distance
15 mA 15 mA 15 mA
Light or dark switching Light or dark switching Light or dark switching Special
accessories for
Yes/Yes Yes/Yes Yes/Yes photoelectric
Fixed Fixed Fixed sensors
Pin point-LED, red light Pin point-LED, red light Pin point-LED, red light
655 nm 655 nm 655 nm
0.4 mm 0.4 mm 0.4 mm
1.25 ms 1.25 ms 1.25 ms
400 Hz 400 Hz 400 Hz
IP 67 IP 67 IP 67
10...+60 C 10...+60 C 10...+60 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Nickel-plated GD-Zn Nickel-plated GD-Zn Nickel-plated GD-Zn
PMMA PMMA PMMA
Pigtail 20 cm, M8 plug, M8 connector, 2 m PUR cable,
3-pin 3-pin 26 AWG
8 8 8
3 3 3
5
5
10
10
10
M3
M3
40
20
M3
20
40
20
44
44
50
59
LED LED
LED
M8x1
36.5
M8x1
www.balluff.com 145
BOS Q08M Laser
Range 3 m BOS Q08M
Laser
Laser Class 1

PNP NO Receiver Part number BOS Q08M-PS-LE20-00,2-S49 @ BOS Q08M-PS-LE20-S49 @
NPN NO Part number BOS Q08M-NS-LE20-00,2-S49 ^ BOS Q08M-NS-LE20-S49 ^
PNP NC Receiver Part number BOS Q08M-PO-LE20-00.2-S49 $ BOS Q08M-PO-LE20-S49 $
NPN NC Part number BOS Q08M-NO-LE20-00.2-S49 * BOS Q08M-NO-LE20-S49 *
Emitter Part number BOS Q08M-X-LS20-00,2-S49 ) BOS Q08M-X-LS20-S49 )
Part number
Output current 100 mA (receiver) 100 mA (receiver)
Laser class 1 1
Smallest detectable part 0.28 mm 0.28 mm
Connection Pigtail 20 cm, M8 plug, 3-pin M8 connector, 3-pin
Ordering codes on page 141. 8 8

3 3
5
5
10
10
M3
M3
40
20
20
44
50
59
LED
LED
M8x1
36.5
Wiring diagrams M8x1
! PNP NO @ % NPN NO ^ ( Thru-beam emitter

PS
# PNP NC $ & NPN NC * )

BOS Q08M Laser
Range 3 m
Photoelectric
sensors
Through-beam sensor
Photoelectric
0...3 m standard
BOS Q08M-PS-LE20-02 ! sensors
Cylinder
BOS Q08M-NS-LE20-02 % designs
BOS Q08M-PO-LE20-02 # Block
BOS Q08M-NO-LE20-02 & designs
BOS Q08M-X-LS20-02 (
Photoelectric
special
10...30 V DC sensors
100 mA (receiver)
15 mA Photoelectric
distance
Light or dark switching sensors
Yes/Yes for analog
distance
Fixed measurement
Laser, red light
650 nm Special
accessories for
1 photoelectric
0.28 mm sensors
Yellow LED
1.25 ms
400 Hz
IP 67
0...+50 C
EN 60947-5-2
Nickel-plated GD-Zn
PMMA
2 m PUR cable, 26 AWG
8
3
5
10
Clamp holder
M3
40
20
44
For Bosch prole:BES Q08-KH-3
LED


code material code
Reector BAM00WL M8, 3-pin Straight PUR Yellow 2m BCC050P
M8, 3-pin angled PUR Yellow 2m BCC0558
You can nd special accessories for diffuse sensors, such as M8, 3-pin angled PVC Yellow 2m BCC055C
reectors, apertures, lenses, lters, and deection heads,
in this catalog starting on page 420. Connectors without LED are suitable for PNP and NPN sensors.
More electrical accessories: You can nd a large selection of plug connectors
and connector cables in a wide variety of cable materials, colors, and lengths in
our Industrial Networking and Connectivity catalog.
www.balluff.com 147
Photoelectric Standard Sensors BOS 2K
BOS 2K
Requirements such as extremely tight mounting spaces under

the most difcult of conditions are easily handled by the sub-mini
BOS 2K series.
The electronic circuitry is housed in a plastic enclosure just
20.612.57.6 mm. Metal sleeves in the housing ensure secure and
simple mounting.
The laser-like, visible light spot makes precise small-parts detection
possible. Unmatched ranges up to 1.2 m and fast response times
ensure compatibility with dynamic applications.
The BOS 2K series is a complete series with diffuse sensors,

retroreective sensors and through-beam sensor as well as diffuse
sensors with background suppression. That means this series offers
the complete functionality demanded of a modern sensor series.

BOS 2K
Product overview
Range quency
Photoelectric
M8 connector, 3-pin
M8 connector, 4-pin
sensors
Light switching
Dark switching
Polarizing lter
Ordering code
10...30 V DC
Photoelectric
Part number standard
Red light
sensors
Cable
NPN
PNP
Cylinder
designs
BOS0104 BOS 2K-PS-RH10-00,2-S75 1...15 mm 800 Hz 150
Photoelectric
BOS0103 BOS 2K-PS-RH10-00,2-S49 1...15 mm 800 Hz 150 special
BOS00ZN BOS 2K-PO-RH10-00,2-S49 1...15 mm 800 Hz 150 sensors
BOS0105 BOS 2K-PS-RH10-02 1...15 mm 800 Hz 151
BOS00ZH BOS 2K-NS-RH10-02 1...15 mm 800 Hz 151 Photoelectric
distance
BOS00ZA BOS 2K-NO-RH10-02 1...15 mm 800 Hz 151 sensors
for analog
distance
BOS0107 BOS 2K-PS-RH11-00,2-S75 1...30 mm 800 Hz 151 measurement
BOS0106 BOS 2K-PS-RH11-00,2-S49 1...30 mm 800 Hz 151
BOS0108 BOS 2K-PS-RH11-02 1...30 mm 800 Hz 151 Special
accessories for
BOS00ZJ BOS 2K-NS-RH11-02 1...30 mm 800 Hz 151 photoelectric
BOS00ZP BOS 2K-PO-RH11-02 1...30 mm 800 Hz 151 sensors
Diffuse sensor
BOS00ZY BOS 2K-PS-RD10-00,2-S75 1...55 mm 800 Hz 152
BOS00ZW BOS 2K-PS-RD10-00,2-S49 1...55 mm 800 Hz 152
BOS00ZZ BOS 2K-PS-RD10-02 1...55 mm 800 Hz 153
BOS00ZE BOS 2K-NS-RD10-02 1...55 mm 800 Hz 153
BOS00ZT BOS 2K-PS-PR10-00,2-S75 45...800 mm 800 Hz 153
BOS00ZR BOS 2K-PS-PR10-00,2-S49 45...800 mm 800 Hz 153
BOS00ZK BOS 2K-PO-PR10-00,2-S49 45...800 mm 800 Hz 153
BOS00ZU BOS 2K-PS-PR10-02 45...800 mm 800 Hz 153
BOS00ZC BOS 2K-NS-PR10-02 45...800 mm 800 Hz 153
BOS00ZL BOS 2K-PO-PR10-02 45...800 mm 800 Hz 153
BOS00Z9 BOS 2K-NO-PR10-02 45...800 mm 800 Hz 153
Through-beam sensor
Receiver
BOS0101 BOS 2K-PS-RE10-00,2-S75 0...1.2 m 200 Hz 154
BOS0100 BOS 2K-PS-RE10-00,2-S49 0...1.2 m 200 Hz 154
BOS0102 BOS 2K-PS-RE10-02 0...1.2 m 200 Hz 155
BOS00ZF BOS 2K-NS-RE10-02 0...1.2 m 200 Hz 155
BOS00ZM BOS 2K-PO-RE10-02 0...1.2 m 200 Hz 155
Through-beam sensor
Emitter
BOS010A BOS 2K-X-RS10-00,2-S75 0...1.2 m 155
BOS0109 BOS 2K-X-RS10-00,2-S49 0...1.2 m 155
BOS010C BOS 2K-X-RS10-02 0...1.2 m 155
www.balluff.com 149
BOS 2K
PNP NO Part number BOS 2K-PS-RH10-00,2-S75 # BOS 2K-PS-RH10-00,2-S49 @
NPN NO Part number
PNP NC Part number BOS 2K-PO-RH10-00,2-S49 $
NPN NC Part number
Supply voltage UB 10...30 V DC 1030 V DC
Light spot diameter approx. 1.2 mm at 8 mm approx. 1.2 mm at 8 mm
Output function indicator Red LED Red LED
Material Housing ABS ABS
Connection Pigtail 20 cm, M8 plug, Pigtail 20 cm, M8 plug,
4-pin 3-pin
Diffuse values referenced to 90% reective Kodak gray card.

9.5 9.5
Emitter Receiver
Emitter Receiver

BOS 2K
Photoelectric
sensors
Diffuse sensor with background suppression Diffuse sensor with background suppression Diffuse sensor with background suppression Diffuse sensor with background suppression
Photoelectric
BOS 2K-PS-RH10-02 ! BOS 2K-PS-RH11-00,2-S75 # BOS 2K-PS-RH11-00,2-S49 @ BOS 2K-PS-RH11-02 ! sensors
Cylinder
BOS 2K-NS-RH10-02 % BOS 2K-NS-RH11-02 % designs
BOS 2K-PO-RH11-02 $ Block
BOS 2K-NO-RH10-02 ^ designs
1030 V DC 1030 V DC 1030 V DC 1030 V DC
special
Light switching Light switching Light switching Light or dark switching
distance
Fixed Fixed Fixed Fixed sensors
Pin point-LED, red light Pin point-LED, red light Pin point-LED, red light Pin point-LED, red light for analog
distance
approx. 1.2 mm at 8 mm approx. 1.0 mm at 15 mm approx. 1.0 mm at 15 mm approx. 1.0 mm at 15 mm
approx. 2.5 mm at 15 mm approx. 4.5 mm at 30 mm approx. 4.5 mm at 30 mm approx. 4.5 mm at 30 mm Special
accessories for
Red LED Red LED Red LED Red LED photoelectric
800 Hz 800 Hz 800 Hz 800 Hz
IP 67 IP 67 IP 67 IP 67
20...+50 C 20...+50 C 20...+50 C 20...+50 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
ABS ABS ABS ABS
PMMA PMMA PMMA PMMA
2 m PVC cable, 28 AWG Pigtail 20 cm, M8 plug, Pigtail 20 cm, M8 plug, 2 m PVC cable, 28 AWG
4-pin 3-pin
9.5 9.5 9.5 9.5

Emitter Receiver
Emitter Receiver
Emitter Receiver
Emitter Receiver
www.balluff.com 151
BOS 2K

PNP NO Part number BOS 2K-PS-RD10-00,2-S75 # BOS 2K-PS-RD10-00,2-S49 @
NPN NO Part number
PNP NO Polarizing lter Part number
NPN NO Part number
PNP NC Polarizing lter Part number
NPN NC Part number
Switching type Light switching Light switching
Light spot diameter approx. 3.5 mm at 50 mm approx. 3.5 mm at 50 mm
4-pin 3-pin

Retroreective sensor values referenced to R9 reector. 9.5 9.5

Emitter Receiver
Emitter Receiver

BOS 2K
Sensing distance 55 mm, range 800 mm
Photoelectric
sensors
Diffuse sensor Retroreective sensor Retroreective sensor Retroreective sensor

Photoelectric
BOS 2K-PS-RD10-02 ! sensors
Cylinder
BOS 2K-NS-RD10-02 % designs
BOS 2K-PS-PR10-00,2-S75 # BOS 2K-PS-PR10-00,2-S49 @ BOS 2K-PS-PR10-02 ! Block
BOS 2K-NS-PR10-02 % designs
BOS 2K-PO-PR10-00,2-S49 $ BOS 2K-PO-PR10-02 $
Photoelectric
BOS 2K-NO-PR10-02 ^ special
50 mA 50 mA 50 mA 50 mA
distance
Light switching Dark switching Light or dark switching Light or dark switching sensors
distance
Fixed Fixed Fixed Fixed measurement
Pin point-LED, red light Pin point-LED, red light Pin point-LED, red light Pin point-LED, red light
accessories for
approx. 3.5 mm at 50 mm approx. 10 mm at 100 mm approx. 10 mm at 100 mm approx. 10 mm at 100 mm photoelectric
Red LED Red LED Red LED Red LED sensors
0.6 ms 0.6 ms 0.6 ms 0.6 ms
800 Hz 800 Hz 800 Hz 800 Hz
IP 67 IP 67 IP 67 IP 67
20...+50 C 20...+50 C 20...+50 C 20...+50 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
ABS ABS ABS ABS
PMMA PMMA PMMA PMMA
2 m PVC cable, 28 AWG Pigtail 20 cm, M8 plug, Pigtail 20 cm, M8 plug, 2 m PVC cable, 28 AWG
4-pin 3-pin
9.5 9.5 9.5

Emitter Receiver
Emitter Receiver
Emitter Receiver
Emitter Receiver
www.balluff.com 153
BOS 2K
Range 1.2 m

Detection range 0...1.2 m 0...1.2 m
PNP NO Receiver Part number BOS 2K-PS-RE10-00,2-S75 # BOS 2K-PS-RE10-00,2-S49 !
NPN NO Part number
NPN NC Part number
Emitter Part number
Part number
Switching type Dark switching Dark switching
Emitter, light type
Wavelength
4-pin 3-pin

9.5 9.5
Receiver
Receiver

BOS 2K
Range 1.2 m
Photoelectric
sensors

Photoelectric
0...1.2 m 0...1.2 m 0...1.2 m 0...1.2 m standard
sensors
BOS 2K-PS-RE10-02 !
Cylinder
BOS 2K-NS-RE10-02 % designs
BOS 2K-PO-RE10-02 & Block
designs
BOS 2K-X-RS10-00,2-S75 ) BOS 2K-X-RS10-00,2-S49 ( BOS 2K-X-RS10-02 *
Photoelectric
special
50 mA
distance
Light or dark switching sensors
distance
Fixed measurement
Pin point-LED, red light Pin point-LED, red light Pin point-LED, red light
660 nm 660 nm 660 nm Special
accessories for
Red LED photoelectric
2.5 ms sensors
200 Hz
IP 67 IP 67 IP 67 IP 67
20...+50 C 20...+50 C 20...+50 C 20...+50 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
ABS ABS ABS ABS
PMMA PMMA PMMA PMMA
2 m PVC cable, Pigtail 20 cm, M8 plug, Pigtail 20 cm, M8 plug, 2 m PVC cable,
28 AWG 4-pin 3-pin 28 AWG
12.5 12.5
9.5 9.5 9.5 9.5
7.6 9 7.6 9
3.9
3.9
6.4
6.4
Emitter
Emitter
Receiver
25.1
25.1
Emitter
15
15
2
2
3.
3.

www.balluff.com 155
BOS 2K
Function diagrams
Light spot diameter Diffuse sensor

Diffuse sensor, 50 mm
Sensing range on black, 6% remission

Sensing range on gray, 18% remission
Sensing range on white, 90% remission

Diffuse sensor with with background suppression
background suppression, 15 mm 15 mm


Diffuse sensor with with background suppression
background suppression, 30 mm 30 mm

Function reserve
Through-beam sensor
Operating range
Function reserve

BOS 2K
Connection, Accessories
Wiring diagrams
Diffuse sensor
PNP light switching
! @
PS
Photoelectric
sensors
# Photoelectric
PS
standard
sensors
Cylinder
designs
PNP dark switching Block
$ designs
PO
Photoelectric
special
sensors
Diffuse & Background Suppression

Photoelectric
NPN light-on distance
% sensors
for analog
NS
distance
measurement
NPN dark-on Special

accessories for
^ photoelectric
NO sensors
PNP dark-on
&
PO
Through-beam emitter
* ( )


1 Mounting bracket BAM00T4 3 M8, 3-pin Straight PUR Yellow 2m BCC050P
2 Mounting bracket BAM00T6 M8, 3-pin Straight PVC Yellow 2m BCC050Y
3 Mounting bracket BAM00T5 M8, 3-pin Angled PUR Yellow 2m BCC0558
Description Ordering
code Size Design Cable Color Length Ordering
1 Reector BAM00WL 1 material code
2 Reector BAM00W0 2 M8, 4-pin Straight PUR Yellow 2m BCC0532
3
3 Reective tape BAM00W5 M8, 4-pin Straight PVC Yellow 2m BCC0542
M8, 4-pin Angled PUR Yellow 2m BCC059R
M8, 4-pin Angled PVC Yellow 2m BCC059W
this catalog on page 420. More electrical accessories: You can nd a large selection of plug
www.balluff.com 157
BOS 5K Global
The advantage of miniature sensors is clearly seen: small size offers The new BOS 5K series features:
exibility and construction freedom. Not only are they easier to install, a small, compact design
many applications can be solved easily with a mini-sensor. Even the Concentration on the most important basic functions
photoelectric BOS 5K series stands out due to its optical power and Attractive price in the lower segment
its compact design. This series includes various diffuse sensors with Wide-ranging accessories for increased functionality
background suppression, diffuse sensors with narrow spot geometry,
energetic diffuse sensors, retroreective models with polarizing lter
and through-beam sensors. For electrical connection of the sensors,
plugs with a cable or M8-plugs are available.
Range quency
M8 connector, 3-pin
M8 connector, 4-pin
Light switching
Dark switching
Polarizing lter
10...30 V DC
Red light
Infrared
Cable
Ordering code
NPN
PNP
Part number
Diffuse sensor with
BOS012A BOS 5K-PS-RH12-S75 40...200 mm 500 Hz 160
BOS011F BOS 5K-NS-RH12-S75 40...200 mm 500 Hz 160
BOS011Z BOS 5K-PO-RH12-S75 40...200 mm 500 Hz 160
BOS0112 BOS 5K-NO-RH12-S75 40...200 mm 500 Hz 160
BOS015U BOS 5K-PS-RH12-S49 40...200 mm 500 Hz 160
BOS015Y BOS 5K-NS-RH12-S49 40...200 mm 500 Hz 160
BOS015W BOS 5K-PO-RH12-S49 40...200 mm 500 Hz 160
BOS015Z BOS 5K-NO-RH12-S49 40...200 mm 500 Hz 160
BOS0129 BOS 5K-PS-RH12-02 40...200 mm 500 Hz 161
BOS011E BOS 5K-NS-RH12-02 40...200 mm 500 Hz 161
BOS011Y BOS 5K-PO-RH12-02 40...200 mm 500 Hz 161
BOS0111 BOS 5K-NO-RH12-02 40...200 mm 500 Hz 161
Diffuse sensor
BOS0124 BOS 5K-PS-ID10-S75 0...900 mm 500 Hz 161
BOS0117 BOS 5K-NS-ID10-S75 0...900 mm 500 Hz 161
BOS011L BOS 5K-PO-ID10-S75 0...900 mm 500 Hz 161
BOS010R BOS 5K-NO-ID10-S75 0...900 mm 500 Hz 161
BOS015J BOS 5K-PS-ID10-S49 0...900 mm 500 Hz 161
BOS015L BOS 5K-NS-ID10-S49 0...900 mm 500 Hz 161
BOS015K BOS 5K-PO-ID10-S49 0...900 mm 500 Hz 161
BOS015M BOS 5K-NO-ID10-S49 0...900 mm 500 Hz 161
BOS0123 BOS 5K-PS-ID10-02 0...900 mm 500 Hz 161
BOS0116 BOS 5K-NS-ID10-02 0...900 mm 500 Hz 161
BOS011K BOS 5K-PO-ID10-02 0...900 mm 500 Hz 161
BOS010P BOS 5K-NO-ID10-02 0...900 mm 500 Hz 161

BOS 5K Global
Product overview
Range quency
M8 connector, 3-pin
M8 connector, 4-pin
Light switching
Dark switching
Polarizing lter
Special output
10...30 V DC
Photoelectric
assignment
sensors
Ordering code
Red light
Infrared
Part number
Cable
NPN
PNP
Photoelectric
standard
sensors
Cylinder
Diffuse small beam designs
BOS0128 BOS 5K-PS-RD11-S75 50...200 mm 500 Hz 162 Block
BOS011C BOS 5K-NS-RD11-S75 50...200 mm 500 Hz 162 designs
BOS011W BOS 5K-PO-RD11-S75 50...200 mm 500 Hz 162
BOS0110 BOS 5K-NO-RD11-S75 50...200 mm 500 Hz 162 Photoelectric
special
BOS015N BOS 5K-PS-RD11-S49 50...200 mm 500 Hz 162 sensors
BOS015R BOS 5K-NS-RD11-S49 50...200 mm 500 Hz 162
BOS015P BOS 5K-PO-RD11-S49 50...200 mm 500 Hz 162 Photoelectric
distance
BOS015T BOS 5K-NO-RD11-S49 50...200 mm 500 Hz 162 sensors
BOS0127 BOS 5K-PS-RD11-02 50...200 mm 500 Hz 163 for analog
distance
BOS011A BOS 5K-NS-RD11-02 50...200 mm 500 Hz 163 measurement
BOS011U BOS 5K-PO-RD11-02 50...200 mm 500 Hz 163
BOS010Z BOS 5K-NO-RD11-02 50...200 mm 500 Hz 163 Special
accessories for
photoelectric
BOS012E BOS 5K-PS-RR10-S75 0.1...4 m 500 Hz 163
BOS011J BOS 5K-NS-RR10-S75 0.1...4 m 500 Hz 163
BOS0121 BOS 5K-PO-RR10-S75 0.1...4 m 500 Hz 163
BOS0114 BOS 5K-NO-RR10-S75 0.1...4 m 500 Hz 163
BOS0122 BOS 5K-PO-RR10-S75-S 0.1...4 m 500 Hz 163
BOS0115 BOS 5K-NO-RR10-S75-S 0.1...4 m 500 Hz 163
BOS015E BOS 5K-PS-RR10-S49 0.1...4 m 500 Hz 163
BOS015H BOS 5K-NS-RR10-S49 0.1...4 m 500 Hz 163
BOS015C BOS 5K-PO-RR10-S49 0.1...4 m 500 Hz 163
BOS015F BOS 5K-NO-RR10-S49 0.1...4 m 500 Hz 163
BOS012C BOS 5K-PS-RR10-02 0.1...4 m 500 Hz 163
BOS011H BOS 5K-NS-RR10-02 0.1...4 m 500 Hz 163
BOS0120 BOS 5K-PO-RR10-02 0.1...4 m 500 Hz 163
BOS0113 BOS 5K-NO-RR10-02 0.1...4 m 500 Hz 163
Through-beam sensor
BOS0126 BOS 5K-PS-IX10-S75 0...10 m 500 Hz 164
BOS0119 BOS 5K-NS-IX10-S75 0...10 m 500 Hz 164
BOS011R BOS 5K-PO-IX10-S75 0...10 m 500 Hz 164
BOS010W BOS 5K-NO-IX10-S75 0...10 m 500 Hz 164
BOS011T BOS 5K-PO-IX10-S75-S 0...10 m 500 Hz 164
BOS010Y BOS 5K-NO-IX10-S75-S 0...10 m 500 Hz 164
BOS0158 BOS 5K-PS-IX10-S49 0...10 m 500 Hz 165
BOS015A BOS 5K-NS-IX10-S49 0...10 m 500 Hz 165
BOS0157 BOS 5K-PO-IX10-S49 0...10 m 500 Hz 165
BOS0159 BOS 5K-NO-IX10-S49 0...10 m 500 Hz 165
BOS0125 BOS 5K-PS-IX10-02 0...10 m 500 Hz 165
BOS0118 BOS 5K-NS-IX10-02 0...10 m 500 Hz 165
BOS011N BOS 5K-PO-IX10-02 0...10 m 500 Hz 165
BOS010U BOS 5K-NO-IX10-02 0...10 m 500 Hz 165
www.balluff.com 159
BOS 5K Global
PNP NO Part number BOS 5K-PS-RH12-S75 @ BOS 5K-PS-RH12-S49 !
NPN NO Part number BOS 5K-NS-RH12-S75 ( BOS 5K-NS-RH12-S49 *
PNP NC Part number BOS 5K-PO-RH12-S75 % BOS 5K-PO-RH12-S49 $
NPN NC Part number BOS 5K-NO-RH12-S75 2 BOS 5K-NO-RH12-S49 1
Settings Potentiometer, 6-turn Potentiometer, 6-turn
Stability indicator
Permitted ambient light per 5 klx (articial light)/10 klx (sunlight) 5 klx (articial light)/10 klx (sunlight)
Material Housing PC/PBT PC/PBT
Optical surface PC PC
Connection M8 connector, M8 connector,
4-pin 3-pin

Receiver
Receiver

9.8 10.5
9.8 10.5
Emitter
Emitter
LED LED
Potentiometer Potentiometer

BOS 5K Global
Photoelectric
sensors
Diffuse sensor with background suppression Diffuse sensor Diffuse sensor Diffuse sensor
Photoelectric
BOS 5K-PS-RH12-02 # BOS 5K-PS-ID10-S75 @ BOS 5K-PS-ID10-S49 ! BOS 5K-PS-ID10-02 # sensors
Cylinder
BOS 5K-NS-RH12-02 ) BOS 5K-NS-ID10-S75 ( BOS 5K-NS-ID10-S49 * BOS 5K-NS-ID10-02 ) designs
BOS 5K-PO-RH12-02 ^ BOS 5K-PO-ID10-S75 % BOS 5K-PO-ID10-S49 $ BOS 5K-PO-ID10-02 ^ Block
BOS 5K-NO-RH12-02 3 BOS 5K-NO-ID10-S75 2 BOS 5K-NO-ID10-S49 1 BOS 5K-NO-ID10-02 3 designs
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
special
Light or dark switching Light or dark switching Light or dark switching Light or dark switching
distance
Potentiometer, 6-turn Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 sensors
LED, red light LED, infrared LED, infrared LED, infrared for analog
distance
Yellow LED Yellow LED Yellow LED Yellow LED
Green LED Green LED Green LED Special
accessories for
1 ms 1 ms 1 ms 1 ms photoelectric
500 Hz 500 Hz 500 Hz 500 Hz sensors
IP 67 IP 67 IP 67 IP 67
25...+55 C 25...+55 C 25...+55 C 25...+55 C
5 klx (articial light)/10 klx (sunlight) 5 klx (articial light)/10 klx (sunlight) 5 klx (articial light)/10 klx (sunlight) 5 klx (articial light)/10 klx (sunlight)
PC/PBT PC/PBT PC/PBT PC/PBT
PC PC PC PC
2 m PVC cable, 24 AWG M8 connector, M8 connector, 2 m PVC cable, 24 AWG
4-pin 3-pin
Receiver
Receiver
Receiver
Receiver
9.8 10.5
11.4
11.4
11.4
Emitter
Emitter
Emitter
Emitter
LED LED LED LED

Potentiometer Potentiometer Potentiometer
Potentiometer
LED LED LED
www.balluff.com 161
BOS 5K Global
Type Diffuse small beam Diffuse small beam

PNP NO Part number BOS 5K-PS-RD11-S75 @ BOS 5K-PS-RD11-S49 !
NPN NO Part number BOS 5K-NS-RD11-S75 ( BOS 5K-NS-RD11-S49 *
PNP NC Part number BOS 5K-PO-RD11-S75 % BOS 5K-PO-RD11-S49 $
NPN NC Part number BOS 5K-NO-RD11-S75 2 BOS 5K-NO-RD11-S49 1
PNP NC Special assignment Part number
NPN NC Output Part number
Permitted ambient light per 5 klx (articial light)/10 klx (sunlight) 5 klx (articial light)/10 klx (sunlight)
Material Housing PC/PBT PC/PBT
Connection M8 connector, 4-pin M8 connector,
3-pin

Receiver
Receiver

11.4
11.4
Emitter
Emitter
LED LED
Potentiometer Potentiometer
LED LED

BOS 5K Global
Sensing distance 200 mm, range 4 m
Photoelectric
sensors
Diffuse small beam Retroreective sensor Retroreective sensor Retroreective sensor

Photoelectric
50...200 mm 0.1...4 m 0.1...4 m 0.1...4 m standard
BOS 5K-PS-RD11-02 # BOS 5K-PS-RR10-S75 @ BOS 5K-PS-RR10-S49 ! BOS 5K-PS-RR10-02 # sensors
Cylinder
BOS 5K-NS-RD11-02 ) BOS 5K-NS-RR10-S75 ( BOS 5K-NS-RR10-S49 * BOS 5K-NS-RR10-02 ) designs
BOS 5K-PO-RD11-02 ^ BOS 5K-PO-RR10-S75 % BOS 5K-PO-RR10-S49 $ BOS 5K-PO-RR10-02 ^ Block
BOS 5K-NO-RD11-02 3 BOS 5K-NO-RR10-S75 2 BOS 5K-NO-RR10-S49 1 BOS 5K-NO-RR10-02 3 designs
BOS 5K-PO-RR10-S75-S &
Photoelectric
BOS 5K-NO-RR10-S75-S 4 special
100 mA 100 mA 100 mA 100 mA
distance
Light or dark switching Light or dark switching Light or dark switching Light or dark switching sensors
distance
Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 measurement
accessories for
Yellow LED Yellow LED Yellow LED Yellow LED photoelectric
Green LED Green LED Green LED Green LED sensors
1 ms 1 ms 1 ms 1 ms
500 Hz 500 Hz 500 Hz 500 Hz
IP 67 IP 67 IP 67 IP 67
25...+55 C 25...+55 C 25...+55 C 25...+55 C
5 klx (articial light)/10 klx (sunlight) 5 klx (articial light)/10 klx (sunlight) 5 klx (articial light)/10 klx (sunlight) 5 klx (articial light)/10 klx (sunlight)
PC/PBT PC/PBT PC/PBT PC/PBT
PC PC PC PC
2 m PVC cable, 24 AWG M8 connector, 4-pin M8 connector, 2 m PVC cable, 24 AWG
3-pin
Receiver
Receiver
Receiver
Receiver
11.4
11.4
11.4
11.4
Emitter
Emitter
Emitter
Emitter
LED LED LED LED

Potentiometer Potentiometer Potentiometer Potentiometer
LED LED LED LED
www.balluff.com 163
BOS 5K Global
Range 10 m
Type Through-beam sensor

Detection range 0...10 m
PNP NO Part number BOS 5K-PS-IX10-S75 @5
NPN NO Part number BOS 5K-NS-IX10-S75 (5
PNP NC Part number BOS 5K-PO-IX10-S75 %5
NPN NC Part number BOS 5K-NO-IX10-S75 25
PNP NC Special assignment Part number BOS 5K-PO-IX10-S75-S &5
NPN NC Output Part number BOS 5K-NO-IX10-S75-S 45
Supply voltage UB 10...30 V DC
No-load supply current I0 max. 20 mA (receiver),
15mA (emitter)
Switching type Light or dark switching
Polarity reversal/short-circuit protected Yes/Yes
Wavelength 880 nm
Power-on indicator Green LED (emitter)
Output function indicator Yellow LED (receiver)
Stability indicator Green LED (receiver)
Response time 1 ms
Degree of protection as per IEC 60529 IP 67
Ambient temperature Ta 25...+55 C
Permitted ambient light per 5 klx (articial light)/10 klx (sunlight)
Material Housing PC/PBT
Optical surface PC
Connection M8 connector, 4-pin

Emitter or receiver
20.2
LED
LED
Potenti-
ometer
LED
Output sensor Emitter

BOS 5K Global
Range 10 m
Photoelectric
sensors

Photoelectric
0...10 m 0...10 m standard
BOS 5K-PS-IX10-S49 !5 BOS 5K-PS-IX10-02 #6 sensors
Cylinder
BOS 5K-NS-IX10-S49 *5 BOS 5K-NS-IX10-02 )6 designs
BOS 5K-PO-IX10-S49 $5 BOS 5K-PO-IX10-02 ^6 Block
BOS 5K-NO-IX10-S49 15 BOS 5K-NO-IX10-02 36 designs
Photoelectric
special
10...30 V DC 10...30 V DC sensors
100 mA 100 mA
20 mA (receiver), 20 mA (receiver), Photoelectric
distance
15mA (transmitter) 15mA (transmitter) sensors
Light or dark switching Light or dark switching for analog
distance
Yes/Yes Yes/Yes measurement
LED, infrared LED, infrared Special
accessories for
880 nm 880 nm photoelectric
Green LED (emitter) Green LED (emitter) sensors
Yellow LED (receiver) Yellow LED (receiver)
Green LED (receiver) Green LED (receiver)
1 ms 1 ms
500 Hz 500 Hz
IP 67 IP 67
25...+55 C 25...+55 C
5 klx (articial light)/10 klx (sunlight) 5 klx (articial light)/10 klx (sunlight)
PC/PBT PC/PBT
PC PC
M8 connector, 3-pin 2 m PVC cable, 24 AWG (emitter)
Transmitter or receiver
Transmitter or receiver
20.2
20.2
LED
LED
LED
LED
Potenti-
Potenti-
ometer
ometer
LED
LED
Output sensor Emitter Receiver Emitter
www.balluff.com 165
BOS 5K Global
Function diagrams
Diffuse sensor with background suppression BOS 5K-_ _-RH12-_ _

Light spot diameter Characteristic response curve (background Sensing distance vs. hysteresis
suppression 100 mm)
Light spot diameter (mm)
Kodak 90%
Lateral approach (mm)

Kodak 6%
Hysteresis
Kodak 6%
Kodak 18%
Kodak 90%
Object size 200200 mm
Sensing distance (mm) Sensing distance (mm) Sensing distance (mm)
Diffuse BOS 5K-_ _-ID10-_ _

Receiving characteristics Characteristic response curve Object size vs. hysteresis
Sensing distance (mm)

Kodak 90%
Function reserve
Kodak 90%
Sensing distance (mm) Sensing distance (mm) Object size (mm)
Diffuse sensor, small beam BOS 5K-_ _-RD11-_ _

Receiving characteristics Characteristic response curve Object size vs. hysteresis
Sensing distance (mm)
Kodak 90% Kodak 90%

Function reserve
Sensing distance (mm) Sensing distance (mm) Object size (mm)
Retroreective sensor BOS 5K-_ _-RR10-_ _

Receiving characteristics Characteristic response curve Angular offset
BOS-R9/R25
BOS-R9/R25
BOS-R26
BOS-R26
Function reserve
Angle reector
BOS-R9/R25
BOS-R30 BOS-R30
BOS-R27/28/29
BOS-R27/28/2a9
BOS-R30 BOS-R26 BOS-R27/28/29
Range (m) Range (m) Range (m)

Through-beam sensor BOS 5K-_ _-IX10-_ _
Receiving characteristics Characteristic response curve Angular offset
Function reserve
Angle receiver
Range (m) Range (m) Range (m)

BOS 5K Global
Wiring diagrams
! BOS 5K PS-...-S49 & BOS 5K PO-...-S75S 3 BOS 5K NO-...-02
Photoelectric
sensors
@ BOS 5K PS-...S75 * BOS 5K NS-...-S49 4 BOS 5K NO-...-S75S
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
# BOS 5K PS-...-02 ( BOS 5K NS-...S75 e Through-beam emitter
Photoelectric
special
sensors
Photoelectric
distance
$ BOS 5K PO-...-S49 ) BOS 5K NS-...-02 r Through-beam emitter
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
% BOS 5K PO-...S75 1 BOS 5K NO-...-S49
sensors
^ BOS 5K PO-...-02 2 BOS 5K NO-...S75


1 Mounting bracket BAM00T4 3 M8, 3-pin Straight PUR Yellow 2m BCC050P
2 Mounting bracket BAM00T6 M8, 3-pin Straight PVC Yellow 2m BCC050Y
3 Mounting bracket BAM00T5 M8, 3-pin Angled PUR Yellow 2m BCC0558
code Size Design Cable Color Length Ordering
1 Reector BAM00WL 1 material code
2 Reector BAM00W0 2 M8, 4-pin Straight PUR Yellow 2m BCC053Z
3
3 Reective tape BAM00W5 M8, 4-pin Straight PVC Yellow 2m BCC054Z
You can nd special accessories for photoelectric sensors, such as M8, 4-pin Angled PVC Yellow 2m BCC059W
www.balluff.com 167
BOS 6K
Due to its high performance, the BOS 6K can be used almost Features
anywhere. When space is at a premium, it is particularly Teach-in-button and control line
advantageous. This is because its small size allows better integration Dynamic teach-in possible (i. e., without stopping the machine)
of the sensors into the machine. Red light and background Multi-function display visible from any direction
suppression make the sensor extremely user-friendly. Disable buttons
Additionally, there are multiple varieties of lasers for an absolute Versions with 3- or 4-pin M8-plug
detection of small parts, so that even objects smaller than 1 mm can or with 2 m cable
be accurately measured. IP 67 protection
Calibration using the control lines means the sensor can be installed Red light and laser versions
at virtually inaccessible locations. Dynamic teach-in in running
operation means less attention needs to be paid to the sensors. Applications
Packaging machines
Handling and assembly
Specialty machines
Printing and paper machinery
Type Sensing Light type Output Switching Switch- US Connection Special features Page
distance/ type ing fre-
Range quency
M8 connector, 3-pin
M8 connector, 4-pin
Autocollimation
Light switching
Dark switching
Polarizing lter
Glass sensing
10...30 V DC
Laser class
Red light
Ordering code
Cable
NPN
PNP
Part number
Diffuse sensor with

BOS009Y BOS 6K-PU-1HA-S75-C 25...100 mm 1 kHz 170
BOS008Z BOS 6K-NU-1HA-S75-C 25...100 mm 1 kHz 170
BOS009U BOS 6K-PU-1HA-S49-C 25...100 mm 1 kHz 170
BOS009T BOS 6K-PU-1HA-C-02 25...100 mm 1 kHz 171
BOS008Y BOS 6K-NU-1HA-C-02 25...100 mm 1 kHz 171
BOS00A0 BOS 6K-PU-1LHA-S75-C 20...60 mm 1 1 kHz 176

BOS0091 BOS 6K-NU-1LHA-S75-C 20...60 mm 1 1 kHz 176
BOS009Z BOS 6K-PU-1LHA-C-02 20...60 mm 1 1 kHz 176
BOS0090 BOS 6K-NU-1LHA-C-02 20...60 mm 1 1 kHz 176
BOS00A2 BOS 6K-PU-1LHA-SA1-S75-C 30...110 mm 2 1 kHz 177

BOS0093 BOS 6K-NU-1LHA-SA1-S75-C 30...110 mm 2 1 kHz 177
BOS00A1 BOS 6K-PU-1LHA-SA1-C-02 30...110 mm 2 1 kHz 177
BOS0092 BOS 6K-NU-1LHA-SA1-C-02 30...110 mm 2 1 kHz 177

BOS 6K
Product overview
Type Sensing Light type Output Switching Switch- US Connection Special features Page
distance/ type ing fre-
Range quency
Photoelectric
M8 connector, 3-pin
M8 connector, 4-pin
sensors
Autocollimation
Light switching
Dark switching
Polarizing lter
Glass sensing
Photoelectric
10...30 V DC
Laser class
standard
Red light
Cable
Cylinder
NPN
Part number
PNP
designs
Block
designs
Diffuse sensor
BOS00A9 BOS 6K-PU-1OC-S75-C 20...300 mm 1 kHz 171 Photoelectric
BOS0099 BOS 6K-NU-1OC-S75-C 20...300 mm 1 kHz 171 special
sensors
BOS00A8 BOS 6K-PU-1OC-S49-C 20...300 mm 1 kHz 171
BOS00A7 BOS 6K-PU-1OC-C-02 20...300 mm 1 kHz 171 Photoelectric
BOS0098 BOS 6K-NU-1OC-C-02 20...300 mm 1 kHz 171 distance
sensors
for analog
Retroreective sensor distance
measurement
BOS00AE BOS 6K-PU-1QA-S75-C 50...700 mm 1 kHz 172
BOS009C BOS 6K-NU-1QA-S75-C 50...700 mm 1 kHz 172
Special
BOS00AC BOS 6K-PU-1QA-S49-C 50...700 mm 1 kHz 172 accessories for
BOS00AA BOS 6K-PU-1QA-C-02 50...700 mm 1 kHz 173 photoelectric
sensors
BOS009A BOS 6K-NU-1QA-C-02 50...700 mm 1 kHz 173
BOS00A4 BOS 6K-PU-1LQA-S75-C 0.05...3 m 1 4 kHz 177

BOS0095 BOS 6K-NU-1LQA-S75-C 0.05...3 m 1 4 kHz 177
BOS00A3 BOS 6K-PU-1LQA-C-02 0.05...3 m 1 4 kHz 177
BOS0094 BOS 6K-NU-1LQA-C-02 0.05...3 m 1 4 kHz 177
BOS00AJ BOS 6K-PU-1QC-S75-C 0.05...3 m 1 kHz 173

BOS009F BOS 6K-NU-1QC-S75-C 0.05...3 m 1 kHz 173
BOS00AH BOS 6K-PU-1QC-S49-C 0.05...3 m 1 kHz 173
BOS00AF BOS 6K-PU-1QC-C-02 0.05...3 m 1 kHz 173
BOS009E BOS 6K-NU-1QC-C-02 0.05...3 m 1 kHz 173
with autocollimation
BOS00AL BOS 6K-PU-1TA-S75-C 0...500 mm 1 kHz 174
BOS009J BOS 6K-NU-1TA-S75-C 0...500 mm 1 kHz 174
BOS00AK BOS 6K-PU-1TA-C-02 0...500 mm 1 kHz 174
BOS009H BOS 6K-NU-1TA-C-02 0...500 mm 1 kHz 174
BOS01CH BOS 6K-PU-1LQD-S75-C 0...4 m 1 4 kHz 178

BOS01JC BOS 6K-NU-1LQD-S75-C 0...4 m 1 4 kHz 178
BOS01HH BOS 6K-PU-1LQD-S49-C 0...4 m 1 4 kHz 178
Through-beam sensor
Receiver
BOS007J BLE 6K-PU-1E-S75-C 0...6.5 m 500 Hz 175
BOS007A BLE 6K-NU-1E-S75-C 0...6.5 m 500 Hz 175
BOS007H BLE 6K-PU-1E-S49-C 0...6.5 m 500 Hz 175
BOS007F BLE 6K-PU-1E-C-02 0...6.5 m 500 Hz 175
BOS0079 BLE 6K-NU-1E-C-02 0...6.5 m 500 Hz 175
Through-beam sensor
Emitter
BOS007P BLS 6K-XX-1E-S75 0...6.5 m 175
BOS007N BLS 6K-XX-1E-S49 0...6.5 m 175
BOS007M BLS 6K-XX-1E-02 0...6.5 m 175
www.balluff.com 169
BOS 6K
[
PNP NC/NO Part number BOS 6K-PU-1HA-S75-C @ BOS 6K-PU-1HA-S49-C #
NPN NC/NO Part number BOS 6K-NU-1HA-S75-C %
Switching type Light/dark switching (selectable) Light/dark switching (selectable)
Light spot diameter approx. 5x5 mm at 60 mm approx. 5x5 mm at 60 mm
Distance hysteresis 5% 5%
Switching state indicator Yellow LED Yellow LED
Switching frequency f 1 KHz 1 KHz
Permitted ambient light per 5 klx 5 klx
Material Housing Impact-resistant ABS Impact-resistant ABS
4-pin 3-pin
Diffuse values referenced to 90% reective Kodak gray card. 3.2 12 3.2 12

4 4.2
4 4.2

32
32
24
24
8
8
42
42
9
9
10
10
3.8
3.8
2.6 2.6
10.7 M8x1 10.7 M8x1
21 21

BOS 6K
Photoelectric
sensors
Diffuse sensor with background suppression Diffuse sensor Diffuse sensor Diffuse sensor
Photoelectric
BOS 6K-PU-1HA-C-02 ! BOS 6K-PU-1OC-S75-C @ BOS 6K-PU-1OC-S49-C # BOS 6K-PU-1OC-C-02 ! sensors
Cylinder
BOS 6K-NU-1HA-C-02 $ BOS 6K-NU-1OC-S75-C % BOS 6K-NU-1OC-C-02 $ designs
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC Block
100 mA 100 mA 100 mA 100 mA designs
35 mA 25 mA 25 mA 25 mA
Light/dark switching (selectable) Light/dark switching (selectable) Light/dark switching (selectable) Light/dark switching (selectable) Photoelectric
special
Yes/Yes Yes/Yes Yes/Yes Yes/Yes sensors
Teach-in Teach-in Teach-in Teach-in
LED, red light LED, red light LED, red light LED, red light Photoelectric
distance
660 nm 660 nm 660 nm 660 nm sensors
approx. 5x5 mm at 60 mm approx. 12x12 mm at 160 mm approx. 12x12 mm at 160 mm approx. 12x12 mm at 160 mm for analog
distance
10% measurement
5%
accessories for
Green LED Green LED Green LED Green LED photoelectric
1 KHz 1 KHz 1 KHz 1 KHz
IP 67 IP 67 IP 67 IP 67
20...+60 C 20...+60 C 20...+60 C 20...+60 C
Impact-resistant ABS Impact-resistant ABS Impact-resistant ABS Impact-resistant ABS
PMMA PMMA PMMA PMMA
4-pin 3-pin
3.2 12 3.2 12 3.2 12 3.2 12

4.2
4.2
4 4.2
4 4.2
24
24
32
32
24
24
32
32
8
8
42
42
17
17
9
9
9
9
5
5
10
10
4
4
3.8
3.8
2.6 2.6 2.6 2.6

10.7 10.7 M8x1 10.7 M8x1 10.7
21 21 21 21
www.balluff.com 171
BOS 6K
Range 700 mm
[
PNP NO/NC Polarizing lter, Part number BOS 6K-PU-1QA-S75-C @ BOS 6K-PU-1QA-S49-C #
NPN NO/NC Glass sensing Part number BOS 6K-NU-1QA-S75-C %
Light spot diameter 2020 mm up to 500 mm 2020 mm up to 500 mm
4-pin 3-pin
Retroreective sensor values referenced to R9 reector. 3.2 12 3.2 12

4 4.2
4 4.2
32
32
24
24
8
8
42
42
9
9
10
10
3.8
3.8
2.6 2.6
10.7 M8x1 10.7 M8x1
21 21

BOS 6K
Range 700 mm, 3 m
Photoelectric
sensors
Retroreective sensor Retroreective sensor Retroreective sensor Retroreective sensor

Photoelectric
50...700 mm 0.05...3 m 0.05...3 m 0.05...3 m standard
BOS 6K-PU-1QA-C-02 ! sensors
Cylinder
BOS 6K-NU-1QA-C-02 $ designs
BOS 6K-PU-1QC-S75-C @ BOS 6K-PU-1QC-S49-C # BOS 6K-PU-1QC-C-02 ! Block
BOS 6K-NU-1QC-S75-C % BOS 6K-NU-1QC-C-02 $ designs
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
special
Light/dark switching (selectable) Light/dark switching (selectable) Light/dark switching (selectable) Light/dark switching (selectable)
distance
Teach-in Teach-in Teach-in Teach-in sensors
LED, red light LED, red light LED, red light LED, red light for analog
distance
2020 mm up to 500 mm approx. 75x75 mm at 1.5 m approx. 75x75 mm at 1.5 m approx. 75x75 mm at 1.5 m
accessories for
Green LED Green LED Green LED Green LED photoelectric
1 KHz 1 KHz 1 KHz 1 KHz
IP 67 IP 67 IP 67 IP 67
20...+60 C 20...+60 C 20...+60 C 20...+60 C
5 klx EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PMMA PMMA PMMA PMMA
4-pin 3-pin
3.2 12 3.2 12 3.2 12 3.2 12

4.2
4 4.2
4.2
4 4.2
24
24
32
24
32
24
32
32
8
42
42
17
17
9
9
5
5
10
10
4
4
3.8
3.8
2.6 2.6 2.6 2.6

10.7 M8x1 10.7 M8x1
10.7 10.7
21 21 21 21
www.balluff.com 173
BOS 6K
Range 500 mm
[
with autocollimation with autocollimation
PNP NO/NC Polarizing lter, glass Part number BOS 6K-PU-1TA-S75-C @ BOS 6K-PU-1TA-C-02 !
NPN NO/NC detection, autocollimation Part number BOS 6K-NU-1TA-S75-C % BOS 6K-NU-1TA-C-02 $
Emitter Part number
Part number
Light spot diameter 2020 mm up to 500 mm 2020 mm up to 500 mm
Connection M8 connector, 2 m PVC cable, 26 AWG
4-pin
Only usable with R22 reector Only usable with R22 reector
Retroreective sensor values referenced to R9/R22 reector.
3.2 12 3.2 12
LED
4.2
LED
4.2

32
24
24
32
42
9
4
5
10
3.8
2.6 2.6
10.7 10.7
M8x1
21 21

BOS 6K
Range 6.5 m
Photoelectric
sensors
Through-beam sensor Through-beam sensor Through-beam sensor

Photoelectric
standard
0...6.5 m 0...6.5 m 0...6.5 m sensors
Cylinder
designs
Block
BLE 6K-PU-1E-S75-C @ BLE 6K-PU-1E-S49-C # BLE 6K-PU-1E-C-02 ! designs
BLE 6K-NU-1E-S75-C % BLE 6K-NU-1E-C-02 $
Photoelectric
BLS 6K-XX-1E-S75 * BLS 6K-XX-1E-S49 * BLS 6K-XX-1E-02 & special
sensors
10...30 V DC 10...30 V DC 10...30 V DC
distance
Light/dark switching (selectable) Light/dark switching (selectable) Light/dark switching (selectable) for analog
distance
Yes/Yes Yes/Yes Yes/Yes measurement
Teach-in Teach-in Teach-in
LED, red light LED, red light LED, red light Special
accessories for
660 nm 660 nm 660 nm photoelectric
sensors
1 ms 1 ms 1 ms
500 Hz 500 Hz 500 Hz
IP 67 IP 67 IP 67
20...+60 C 20...+60 C 20...+60 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Impact-resistant ABS Impact-resistant ABS Impact-resistant ABS
PMMA PMMA PMMA
M8 connector, M8 connector, 2 m PVC cable, 26 AWG
4-pin 3-pin
3.2 12 3.2 12 3.2 12

4.2
4.2
4.2
32
32
24
24
24
32
17
17
17
4
2.6 2.6
3.8
3.8
2.6
10.7 10.7
10.7
21 M8x1 21 M8x1
20
www.balluff.com 175
BOS 6K Laser
[
PNP NO/NC Part number BOS 6K-PU-1LHA-S75-C @ BOS 6K-PU-1LHA-C-02 !
NPN NO/NC Part number BOS 6K-NU-1LHA-S75-C % BOS 6K-NU-1LHA-C-02 $
Laser class 1 1
Light spot diameter 0.5 mm in focus (35 mm) 0.5 mm in focus (35 mm)
Distance hysteresis
Permitted ambient light per EN 60947-5-2 EN 60947-5-2
Connection M8 connector, 2 m PVC cable, 26 AWG
4-pin

3.2 12 3.2 12

4.2
4 4.2
24
32
24

32
8
42
17
9
9
5
10
4
3.8
2.6 2.6
10.7 M8x1 10.7
21 21

BOS 6K Laser
Sensing distance 110 mm, range 3 m
Photoelectric
sensors
Diffuse sensor with background suppression Diffuse sensor with background suppression Retroreective sensor Retroreective sensor
Photoelectric
30...110 mm 30...110 mm 0.05...3 m 0.05...3 m standard
BOS 6K-PU-1LHA-SA1-S75-C @ BOS 6K-PU-1LHA-SA1-C-02 ! sensors
Cylinder
BOS 6K-NU-1LHA-SA1-S75-C % BOS 6K-NU-1LHA-SA1-C-02 $ designs
BOS 6K-PU-1LQA-S75-C @ BOS 6K-PU-1LQA-C-02 ! Block
BOS 6K-NU-1LQA-S75-C % BOS 6K-NU-1LQA-C-02 $ designs
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
special
distance
Teach-in Teach-in Teach-in Teach-in sensors
Laser, red light Laser, red light Laser, red light Laser, red light for analog
distance
2 2 1 1
0.7 mm in focus (85 mm 5 mm) 0.7 mm in focus (85 mm 5 mm) 1 mm at 300 mm 1 mm at 300 mm Special
accessories for
photoelectric
7% 7% sensors
0.5 ms 0.5 ms 0.125 ms 0.125 ms
1 KHz 1 KHz 4KHz 4KHz
IP 67 IP 67 IP 67 IP 67
20...+60 C 20...+60 C 20...+60 C 20...+60 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PMMA PMMA PMMA PMMA
M8 connector, 2 m PVC cable, 26 AWG M8 connector, 2 m PVC cable, 26 AWG
4-pin 4-pin
3.2 12 3.2 12 3.2 3.2 12 12

4.2
4.2
4 4.2
4 4.2
24
24
32
32
24
24
32
32
8
17 8
42
42
17
9
9
9
9
5
5
10
10
4
4
3.8
3.8
2.6 2.6 2.6 2.6

10.7 M8x1 10.7 10.7 10.7 M8x1
21 21 21 21
www.balluff.com 177
BOS 6K Laser
Range 4 m Laser
[
with autocollimation with autocollimation
PNP NO/NC Polarizing Part number BOS 6K-PU-1LQD-S75-C @ BOS 6K-PU-1LQD-S49-C #
NPN NO/NC lter Part number BOS 6K-NU-1LQD-S75-C %
Laser class 1 1
Light spot diameter 2 mm at 2500 mm 2 mm at 2500 mm
Switching frequency f 4KHz 4KHz
Permitted ambient light per EN 60947-5-2 EN 60947-5-2
Retroreective sensor values depend on the 3.2 12 3.2 12

R22 reector. LED LED LED LED
4.2
4.2

24
24

32
32
42
42
9
9
4
4
10
10
3.8
3.8
2.6 2.6
10.7 M8x1 10.7 M8x1
20 20
Optical axis Optical axis

Photoelectric
sensors
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 179
BOS 6K
Function diagrams, connection
Diffuse BOS 6K-..-1HA-... Retroreective BOS 6K-..-1QA-...

BOS R-1
reector
90% reective
Kodak gray card
Sensing distance measured with side approach of Kodak gray card. Range measured with side approach of reector.
Diffuse BOS 6K-..-1OC-... Retroreective BOS 6K-..-1QC-...
BOS R-1
reector
90%
reective
Kodak
gray card
Diffuse BOS 6K-...-1LHA-... Retroreective BOS 6K-...-1LQA-...
BOS R22-
reector
90% reective
Kodak gray
card
Wiring diagrams
! BOS 6K-P.../BLE 6K-P $ BOS 6K-N.../BLE 6K-N & BLS 6K
Teach-in Teach-in
@ BOS 6K-P...-S75/BLE 6K-P....S75 % BOS 6K-N...-S75/BLE 6K-N....S75 * BLS 6K
Teach-in Teach-in
# BOS 6K-P...-S49/BLE 6K-P...S49 ^ BOS 6K-N..-S49/BLE 6K-N...S49

BOS 6K
Conguration notes, accessories
Diffuse sensor Retroreective/through-beam

Direct sensor at object. Direct sensor at reector/
receiver.
Photoelectric
sensors
Photoelectric
standard
sensors
Press button for approx. 3 sec. Press button for approx. 3 sec. Cylinder
until both LEDs blink at the until both LED's blink at the designs
Block
same time. same time. designs
Photoelectric
special
sensors
Remove object from beam path. Bring objects into detection Photoelectric
range. distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Hold down button for 1 sec. Hold down button for 1 sec.
Green LED blinks briey and Green LED blinks briey and then
then comes full on. The sensor is stays on. The sensor is ready.
ready. If both LEDs blink at the same
If both LEDs blink at the same time, recongure your settings.
time, recongure your settings.


code material code
1 Reector BAM00UK M8, 3-pin Straight PUR Yellow 2m BCC050P
1 2
2 Reector BAM00WL M8, 3-pin Straight PVC Yellow 2m BCC050Y
3 Laser reector BAM00UY M8, 3-pin Angled PUR Yellow 2m BCC0558
4 Mounting bracket BAM00UH M8, 3-pin Angled PVC Yellow 2m BCC055C
4
3 Connectors without LED are suitable for PNP and NPN sensors.

material code
M8, 4-pin Straight PUR Yellow 2m BCC053Z
M8, 4-pin Straight PVC Yellow 2m BCC0542
reectors, apertures, lenses, lters, and deection heads, in Connectors without LED are suitable for PNP and NPN sensors.
this catalog starting on page 420.
www.balluff.com 181
BOS 11K
BOS 11K
The photoelectric sensor BOS 11K is available in the most popular
form factor with the optimal size for the most frequent applications in
packaging machines and handling and assembly systems.
Features
Two mounting options
Infrared and red light versions
Pigtail with connector or cable out

BOS 11K
Product overview
Type Sensing Light Output Switching Switching US Connection Special Page

distance/ type type frequency features
Range
Photoelectric
sensors
Light switching
Dark switching
Polarizing lter
Ordering code
10...30 V DC
M12 Pigtail
Photoelectric
Cable, 2 m
Part number
Test input
standard
Red light
Infrared
sensors
NPN
PNP
Cylinder
designs
Block
Diffuse sensor designs
BOS014R BOS 11K-PA-RH10-00,15-S4 10...50 mm 500 Hz 184
Photoelectric
BOS014U BOS 11K-NA-RH10-00,15-S4 10...50 mm 500 Hz 184 special
BOS014P BOS 11K-PA-RH10-02 10...50 mm 500 Hz 185 sensors
BOS014T BOS 11K-NA-RH10-02 10...50 mm 500 Hz 185
Photoelectric
distance
BOS019A BOS 11K-PA-RH11-00,15-S4 10...100 mm 500 Hz 185 sensors
BOS019C BOS 11K-NA-RH11-00,15-S4 10...100 mm 500 Hz 185 for analog
distance
BOS019E BOS 11K-PA-RH11-02 10...100 mm 500 Hz 185 measurement
BOS019F BOS 11K-NA-RH11-02 10...100 mm 500 Hz 185
Special
accessories for
Diffuse sensor photoelectric
BOS012P BOS 11K-PA-ID10-00,15-S4 10...450 mm 500 Hz 186 sensors
BOS012F BOS 11K-NA-ID10-00,15-S4 10...450 mm 500 Hz 186
BOS012R BOS 11K-PA-ID10-02 10...450 mm 500 Hz 187
BOS012H BOS 11K-NA-ID10-02 10...450 mm 500 Hz 187
BOS012W BOS 11K-PA-PR10-00,15-S4 0...3.5 m 500 Hz 187
BOS012L BOS 11K-NA-PR10-00,15-S4 0...3.5 m 500 Hz 187
BOS012Y BOS 11K-PA-PR10-02 0...3.5 m 500 Hz 187
BOS012M BOS 11K-NA-PR10-02 0...3.5 m 500 Hz 187
BOS012Z BOS 11K-PA-RR10-02 0...4 m 500 Hz 188

BOS012N BOS 11K-NA-RR10-02 0...4 m 500 Hz 188
Through-beam sensor
Receiver
BOS012T BOS 11K-PA-IE11-00,15-S4 0...20 m 150 Hz 189
BOS012J BOS 11K-NA-IE11-00,15-S4 0...20 m 150 Hz 189
BOS012U BOS 11K-PA-IE11-02 0...20 m 150 Hz 189
BOS012K BOS 11K-NA-IE11-02 0...20 m 150 Hz 189
Through-beam sensor
Emitter
BOS0130 BOS 11K-X-IS11-00,15-S4 0...20 m 189
BOS0131 BOS 11K-X-IS11-02 0...20 m 189
www.balluff.com 183
BOS 11K
Type Diffuse wtih

tih
xed
dbbackground
k d suppression
i
Detection range 10...50 mm
PNP NO/NC Part number BOS 11K-PA-RH10-00,15-S4 !
NPN NO/NC Part number BOS 11K-NA-RH10-00,15-S4 #
No-load supply current I0 max. 25 mA
Switching type Light/dark switching (selectable)
Light exit Angle
Emitter, light type LED, red light
Wavelength 626 nm
Power indicator Green LED
Response time 1ms
Permitted ambient light per 10 klx sunlight
Material Housing ABS
Optical surface PMMA
Connection Pigtail 150 mm M12 plug, 4 pin
Diffuse values referenced to 90% reective Kodak gray card. 30.6

15 19.1
Wiring diagrams on page 190. 15.4
6.39
7.3 3.3
LED
Ordering codes on page 183. POT
if applicable
34.5
18
24
150 mm Length 8
6.5
32
48.2
M12x1
14.2

BOS 11K
Photoelectric
sensors
Diffuse wtih xed background suppression Diffuse wtih

tih
xed
dbbackground
k d suppression
i Diffuse wtih xed background suppression
Photoelectric
10...50 mm 10...100 mm 10...100 mm standard
sensors
BOS 11K-PA-RH10-02 @ BOS 11K-PA-RH11-00,15-S4 ! BOS 11K-PA-RH11-02 @
Cylinder
BOS 11K-NA-RH10-02 $ BOS 11K-NA-RH11-00,15-S4 # BOS 11K-NA-RH11-02 $ designs
10...30 V DC 10...30 V DC 10...30 V DC Block
100 mA 100 mA 100 mA designs
25 mA 25 mA 25 mA
Photoelectric
Light/dark switching (selectable) Light/dark switching (selectable) Light/dark switching (selectable) special
Angle Angle Angle sensors
Yes/Yes Yes/Yes Yes/Yes
LED, red light LED, red light LED, red light Photoelectric
distance
Yellow LED Yellow LED Yellow LED for analog
distance
Green LED Green LED Green LED measurement
1ms 1ms 1ms
500 Hz 500 Hz 500 Hz Special
accessories for
IP 67 IP 67 IP 67 photoelectric
20...+55 C 20...+55 C 20...+55 C sensors
10 klx sunlight 10 klx sunlight 3 klx/10 klx sunlight
ABS ABS ABS
PMMA PMMA PMMA
2 m PVC cable, 28 AWG Pigtail 150 mm M12 plug, 4 pin 2 m PVC cable, 28 AWG
30.6 30.6 30.6

15 19.1 15 19.1 15 19.1
15.4 15.4 15.4
6.39 6.39 6.39
7.3 3.3 7.3 3.3 7.3 3.3
LED LED LED
POT POT POT
if applicable if applicable if applicable
34.5
34.5
34.5
18
18
18
24
24
24
2m Length 8
150 mm Length 8
2m Length 8
6.5 6.5 6.5

32
48.2
M12x1
14.2
www.balluff.com 185
BOS 11K
Range 450 mm, 3.5 m
Type Diffuse
use sensor
PNP NO/NC Part number BOS 11K-PA-ID10-00,15-S4 !
NPN NO/NC Part number BOS 11K-NA-ID10-00,15-S4 #
Light exit Angle
Wavelength 950 nm
Response time 1ms
Connection Pigtail 150 mm M12 plug, 4 pin
Retroreective sensor values referenced to R1 reector. 30.6

15 19.1
15.4
7.3 3.3
LED
Ordering codes on page 183. POT
if applicable
34.5
18
24
150 mm Length 8
6.5
32
48.2
M12x1
14.2

BOS 11K
Range 450 mm
Photoelectric
sensors
Diffuse sensor Diffuse

use sensor Diffuse sensor
Photoelectric
10...450 mm 0...3.5 m 0...3.5 m standard
BOS 11K-PA-ID10-02 @ sensors
Cylinder
BOS 11K-NA-ID10-02 $ designs
BOS 11K-PA-PR10-00,15-S4 % BOS 11K-PA-PR10-02 ^ Block
BOS 11K-NA-PR10-00,15-S4 & BOS 11K-NA-PR10-02 * designs
10...30 V DC 10...30 V DC 10...30 V DC
special
Light/dark switching (selectable) Light/dark switching (selectable) Light/dark switching (selectable)
Angle Angle Angle Photoelectric
distance
Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 for analog
distance
LED, infrared LED, red light LED, red light measurement
950 nm 626 nm 626 nm
Yellow LED Yellow LED Yellow LED Special
accessories for
Green LED Green LED Green LED photoelectric
1ms 1ms 1ms sensors
500 Hz 500 Hz 500 Hz
IP 67 IP 67 IP 67
20...+55 C 20...+55 C 20...+55 C
10 klx sunlight 10 klx sunlight 10 klx sunlight
ABS ABS ABS
PMMA PMMA PMMA
2 m PVC cable, 28 AWG Pigtail 150 mm, M12 plug, 4 pin 2 m PVC cable, 28 AWG
30.6 30.6 30.6

15 19.1 15 19.1 15 19.1
15.4 15.4 15.4
6.39 6.39 6.39
7.3 3.3 7.3 3.3 7.3 3.3
LED LED LED
POT POT POT
if applicable if applicable if applicable
34.5
34.5
34.5
18
18
18
24
24
24
2m Length 8
150 mm Length 8
2m Length 8
6.5 6.5 6.5

32
48.2
M12x1
14.2
www.balluff.com 187
BOS 11K
Range 4 m, 20 m
Type Retroreective sensor

Detection range 4m
PNP NO/NC Polarizing lter Part number BOS 11K-PA-RR10-02 ^
NPN NO/NC Part number BOS 11K-NA-RR10-02 *
Emitter Part number
Part number
Light exit Angle
Wavelength 626 nm
Response time 1 ms
Connection 2 m PVC cable, 28 AWG

15 19.1
15.4
Ordering codes on page 183. 6.39
3.3
LED 7.3
POT
if applicable
34.5
18
24
2m Length 8
6.5

BOS 11K
Range 20 m
Photoelectric
sensors
Retroreective
roreective sensor Retroreective sensor
Photoelectric
20 m 20 m standard
sensors
Cylinder
designs
BOS 11K-PA-IE11-00,15-S4 ( BOS 11K-PA-IE11-02 ) Block
BOS 11K-NA-IE11-00,15-S4 1 BOS 11K-NA-IE11-02 2 designs
BOS 11K-X-IS11-00,15-S4 3 BOS 11K-X-IS11-02 4
Photoelectric
special
10...30 V DC 10...30 V DC sensors
100 mA 100 mA
distance
Light/dark switching (selectable) Light/dark switching (selectable) sensors
Angle Angle for analog
distance
Yes/Yes Yes/Yes measurement
LED, infrared LED, infrared Special
accessories for
950 nm 950 nm photoelectric
Green LED Green LED sensors
3 ms 3 ms
150 Hz 150 Hz
IP 67 IP 67
20...+55 C 20...+55 C
10 klx sunlight 10 klx sunlight
ABS ABS
PMMA PMMA
Pigtail 150 mm M12 plug 4 pin 2 m PVC cable, (2)/28 AWG (emitter)
30.6 30.6
15 19.1 15 19.1
15.4 15.4
6.39 6.39
7.3 3.3 7.3 3.3
LED LED
POT POT
if applicable if applicable
34.5
34.5
18
18
24
24
150 mm Length 8
2m Length 8
6.5 6.5
32
48.2
M12x1
14.2
www.balluff.com 189
BOS 11K
Wiring Diagrams
! PA ^ PA
BN
1 NA
1 BN
BN 8% +UB +U B
WH BK 2 WH
BK WH 4 BK
BU 3 BU
0V
9 BU
0V
@ PA
BN
& NA
1 BN
2 NA
BN
+UB +UB +U B
WH 4 BK WH
BK 2 WH BK
BU 3 BU BU 0V
0V 0V
# NA * NA
BN
3 X
1 BN
1 BN
+UB +UB +UB
2 WH BK
4 BK WH 3 BU
0V
3 BU
BU
0V 0V
$ NA
BN
( PA
1 BN
4 X
BN
+UB +U B +UB
WH 2 WH
BK 4 BK BU
0V
BU 3 BU
0V 0V
PA PA
% 1 BN ) BN
+UB +UB
4 BK WH
2 WH BK
3 BU BU
0V
0V
A Diffuse BOS 1 1K-...-ID10-... C Non-Polarized Retroreflective BOS 11K-...-RR10-...

BOS R-1
250 mm
20 mm 200
15 150
10 100
5 50
0 0 m
-5 10 100 200 300 400 500mm -50 1 2 3 4 5 6 7
-10 -100
-15 -150
-20 -200
-250
B Polarized Retroreflective BOS 11K-...-PR10-... D Thru-Beam BOS 11K-...-IE11-.../BOS 11K-X-IS11...
100 mm
80 mm BOS R-1 80
60 60
40 40
20 20
0 m 0 m
-20 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 -20 5 10 15 20 25
-40 -40
-60 -60
-80 -80
-100
Recommended Reectors
BOS R1 - High Efciency BOS R26 - Standard

BOS R9 - High Efciency

BOS 11K
Denitions, accessories
Photoelectric
sensors
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reector BOS R-10 Suitable connectors

(delivered with retroreective (please order separately)
sensor)
material code

You can nd special accessories for diffuse sensors, such as
reectors, apertures, lenses, lters, and deection heads, in
www.balluff.com 191
Photoelectric Standard Sensors BOS 21M
BOS 21M
BOS 21M the complete series in one compact, robust metal

housing with comprehensive functionality. State-of-the-art sensor
technology and innovative manufacturing technologies leave nothing
to be desired for versatile applications in robotics and automation,
packaging technology, installing, and handling technology, etc.
Teach-in switches and potentiometers assure fast startup as well as
simple and economical operation of the sensors.
A wide range of accessories such as mounting brackets, stands,
dovetail clamps, etc., enable adjustable mounting of the sensors in
any position.

BOS 21M
Product overview
range
Output special assignment

M12 connector, 4-pin
Autocollimation
Glass detection
Light switching
Dark switching
Polarizing lter
10...30 V DC
Photoelectric
Laser class
sensors
Red light
Teach-in
Ordering code
Infrared
Part number
NPN
PNP
Photoelectric
Diffuse sensor with standard
sensors
background suppression Cylinder
BOS0034 BOS 21M-PUS-LH12-S4 50...100 mm 1 1 kHz 200 designs
BOS0024 BOS 21M-NUS-LH12-S4 50...100 mm 1 1 kHz 200 Block
designs
BOS0035 BOS 21M-PUS-RH12-S4 70...200 mm 1 kHz 194 Photoelectric

BOS002Z BOS 21M-NUS-RH12-S4 70...200 mm 1 kHz 194 special
sensors
BOS0036 BOS 21M-PUS-RV13-S4 70...200 mm 1 kHz 195
BOS0030 BOS 21M-NUS-RV13-S4 70...200 mm 1 kHz 195
Photoelectric
distance
Diffuse sensor sensors
for analog
BOS0033 BOS 21M-PA-RD10-S4 0.01...1 m 500 Hz 195 distance
BOS002W BOS 21M-NA-RD10-S4 0.01...1 m 500 Hz 195 measurement
Special
BOS0031 BOS 21M-PA-ID10-S4 0.05...2 m 500 Hz 195 accessories for
BOS002T BOS 21M-NA-ID10-S4 0.05...2 m 500 Hz 195 photoelectric
sensors
BOS0032 BOS 21M-PA-LD10-S4 0...600 mm 1 2 kHz 201

BOS002U BOS 21M-NA-LD10-S4 0...600 mm 1 2 kHz 201
BOS00TR BOS 21M-PA-PR10-S4 0.1...8 m 1 kHz 196
BOS00TH BOS 21M-NA-PR10-S4 0.1...8 m 1 kHz 196
BOS00TT BOS 21M-PA-PR10-S4S 0.1...8 m 1 kHz 196
BOS00TL BOS 21M-PA-LR10-S4 0.1...20 m 1 2 kHz 201

BOS00TE BOS 21M-NA-LR10-S4 0.1...20 m 1 2 kHz 201
BOS00TM BOS 21M-PA-LR10-S4S 0.1...20 m 1 2 kHz 201
BOS00TN BOS 21M-PA-PK10-S4 0...4 m 1 kHz 197

BOS00TF BOS 21M-NA-PK10-S4 0...4 m 1 kHz 197
BOS00TP BOS 21M-PA-PK10-S4S 0...4 m 1 kHz 197
BOS00TU BOS 21M-PA-PT10-S4 0...2 m 1 kHz 197

BOS00TJ BOS 21M-NA-PT10-S4 0...2 m 1 kHz 197
BOS00TW BOS 21M-PA-PT10-S4S 0...2 m 1 kHz 197
BOS00TY BOS 21M-PA-PT14-S4 0...2 m 1 kHz 197
BOS00TK BOS 21M-NA-PT14-S4 0...2 m 1 kHz 197
Through-beam sensor
Receiver
BOS00WT BOS 21M-PA-IE10-S4 0...20 m 500 Hz 198
BOS00WP BOS 21M-NA-IE10-S4 0...20 m 500 Hz 198
BOS00WU BOS 21M-PA-IE10-S4S 0...20 m 500 Hz 198
BOS00WW BOS 21M-PA-LE10-S4 0...60 m 1 1.5 kHz 201

BOS00WR BOS 21M-NA-LE10-S4 0...60 m 1.5 kHz 201
BOS00WY BOS 21M-PA-LE10-S4S 0...60 m 1 1.5 kHz 201
Through-beam sensor
Emitter
BOS00WZ BOS 21M-XT-IS11-S4 0...20 m 199
BOS00Y0 BOS 21M-XT-LS11-S4 0...60 m 201
www.balluff.com 193
BOS 21M
Type Diffuse sensor with background suppression

PNP NO/NC Part number BOS 21M-PUS-RH12-S4 @
NPN NO/NC Part number BOS 21M-NUS-RH12-S4 $
Switching type Light/dark (switchable)
Settings Teach-in
Wavelength 670 nm
Stability indicator Green/red LED
Switching frequency f 1 kHz
Ambient temperature Ta 10...+50C
Permissible ambient light 10 klx
Material Housing GD-Zn/Al
Receiver
Emitter
0
27
s
te
ta
Ro

BOS 21M
Sensing distance 200 mm, 1 m, 2 m
Photoelectric
sensors
Diffuse sensor with foreground and background suppression Diffuse sensor Diffuse sensor
Photoelectric
70...200 mm 0.01...1 m 0.05...2 m standard
BOS 21M-PUS-RV13-S4 @ sensors
Cylinder
BOS 21M-NUS-RV13-S4 $ designs
BOS 21M-PA-RD10-S4 ! BOS 21M-PA-ID10-S4 ! Block
BOS 21M-NA-RD10-S4 # BOS 21M-NA-ID10-S4 # designs
10...30 V DC 10...30 V DC 10...30 V DC
Photoelectric
100 mA 100 mA 100 mA special
Light/dark (switchable) Light/dark (complementary) Light/dark (complementary)
Yes/Yes Yes/Yes Yes/Yes Photoelectric
distance
Teach-in Potentiometer, 270 Potentiometer, 270 sensors
LED, red light LED, red light LED, infrared for analog
distance
670 nm 650 nm 880 nm measurement
Green LED Green LED Green LED Special
accessories for
0.5 ms 1 ms 1 ms photoelectric
1 kHz 500 Hz 500 Hz sensors
IP 67 IP 67 IP 67
10...+50C 25...+55C 25...+55C
GD-Zn/Al GD-Zn/Al GD-Zn/Al
PMMA PMMA PMMA
Receiver
Receiver
Receiver
Emitter
Emitter
Emitter
0
0
27
27
27
s
s
te
te
te
ta
ta
ta
Ro
Ro
Ro
www.balluff.com 195
BOS 21M
Range 8 m

Detection range 0.1...8 m
PNP NO/NC Polarizing lter Part number BOS 21M-PA-PR10-S4 !
NPN NO/NC Part number BOS 21M-NA-PR10-S4 #
PNP NO/NC Polarizing lter Part number BOS 21M-PA-PR10-S4S %
NPN NO/NC Output special assignment Part number
PNP NO/NC Polarizing lter, autocollimation Part number
PNP NO/NC Polarizing lter, autocollimation Part number
PNP NO/NC Polarizing lter, glass detection, Part number
NPN NO/NC autocollimation Part number
PNP NO/NC Polarizing lter, glass detection, Part number
autocollimation, output special assignment Part number
Wavelength 650 nm
Retroreective sensor values referenced to reector R1.

Receiver

Emitter
0
27
s
te
ta
Ro

BOS 21M
Range 4 m, 2 m
Photoelectric
sensors
Retroreective sensor Retroreective sensor Retroreective sensor

Photoelectric
0...4 m 0...2 m 0...2 m standard
sensors
Cylinder
designs
Block
designs
BOS 21M-PA-PK10-S4 !
Photoelectric
BOS 21M-NA-PK10-S4 # special
BOS 21M-PA-PK10-S4S % sensors
BOS 21M-PA-PT10-S4 ! BOS 21M-PA-PT14-S4 ! Photoelectric

distance
BOS 21M-NA-PT10-S4 # BOS 21M-NA-PT14-S4 # sensors
BOS 21M-PA-PT10-S4S % for analog
distance
measurement
10...30 V DC 10...30 V DC 10...30 V DC
accessories for
35 mA 35 mA 35 mA photoelectric
Light/dark (complementary) Light/dark (complementary) Light/dark (complementary) sensors
650 nm 650 nm 650 nm
Green LED
0.5 ms 0.5 ms 0.5 ms
1 kHz 1 kHz 1 kHz
IP 67 IP 67 IP 67
25...+55C 25...+55C 25...+55C
Glass Glass PMMA
optical axis
optical axis
optical axis
0
0
27
27
27
s
s
te
te
te
ta
ta
ta
Ro
Ro
Ro
www.balluff.com 197
BOS 21M
Range 20 m
Type Through-beam sensor

PNP NO/NC Receiver Part number BOS 21M-PA-IE10-S4 !
NPN NO/NC Part number BOS 21M-NA-IE10-S4 #
PNP NO/NC Receiver Part number BOS 21M-PA-IE10-S4S %
Emitter Part number
Help functions
Wavelength 880 nm
Power-on indicator
Output function indicator Yellow LED (receiver)
Stability indicator Green LED (receiver)
Response time 1 ms
Receiver
0
27
s
te
ta
Ro

BOS 21M
Range 20 m
Photoelectric
sensors
Through-beam sensor
Photoelectric
0...20 m standard
sensors
Cylinder
designs
Block
designs
BOS 21M-XT-IS11-S4 ^
10...30 V DC Photoelectric
special
sensors
35 mA
Photoelectric
distance
Yes/Yes sensors
for analog
distance
Test input measurement
Special
accessories for
Green LED photoelectric
sensors
IP 67
25...+55C
10 klx
GD-Zn/Al
PMMA
Emitter
0
27
s
te
ta
Ro
www.balluff.com 199
BOS 21M Laser

PNP NO/NC Part number BOS 21M-PUS-LH12-S4 @
NPN NO/NC Part number BOS 21M-NUS-LH12-S4 $
Emitter Part number
Part number
Switching type Light/dark (switchable)
Settings Teach-in
Help functions
Wavelength 650 nm
Laser class 1
Power-on indicator
Stability indicator Green/red LED

Retroreective sensor values referenced to reector R1.
Receiver

Emitter
0
27
s
te
ta
Ro

BOS 21M Laser
Sensing distance 600 mm, range 20 m, 60 m
Photoelectric
sensors
Diffuse sensor Retroreective sensor Through-beam sensor

Photoelectric
0...600 mm 0.1...20 m 0...60 m standard
BOS 21M-PA-LD10-S4 ! sensors
Cylinder
BOS 21M-NA-LD10-S4 # designs
BOS 21M-PA-LR10-S4 ! Block
BOS 21M-NA-LR10-S4 # designs
BOS 21M-PA-LR10-S4S %
Photoelectric
special
BOS 21M-PA-LE10-S4 ! sensors
BOS 21M-NA-LE10-S4 #
BOS 21M-PA-LE10-S4S % Photoelectric
distance
sensors
BOS 21M-XT-LS11-S4 ^ for analog
distance
measurement
10...30 V DC 10...30 V DC 10...30 V DC
accessories for
35 mA 35 mA 35 mA photoelectric
Light/dark (complementary) Light/dark (complementary) Light/dark (complementary) sensors
Test input (emitter)
Laser, red light Laser, red light Laser, red light
650 nm 650 nm 650 nm
1 1 1
0.25 ms 0.25 ms 1 ms
2 kHz 2 kHz 500 Hz
IP 67 IP 67 IP 67
10...+50C 10...+50C 25...+55C
5 klx 5 klx 10 klx
PMMA PMMA PMMA
Receiver
Receiver
Receiver
Emitter
Emitter
Emitter
0
0
27
27
27
s
s
te
te
te
ta
ta
ta
Ro
Ro
Ro
www.balluff.com 201
BOS 21M
Function diagrams
Diffuse sensor with background suppression

BOS 21M-.US-RH12
Percent
difference (%)
Gray 18%
White 90%
Setting against white background 90%

Detection range
Diffuse sensor with fore- and background suppression

BOS 21M-.US-RV13
Sensing distance
a
are
ion e
ss ang
pre gr
u p rkin
ds W o
un rea
gro na
ck ssio
Ba pre
up
ds
oun
egr
For
Sensing distance
Detection range
Diffuse sensor
BOS 21M-.A-RD10 Gray 18%
White 90%
Gray 18%
White 90%
Gray 18%
Diffuse sensor, long range
BOS 21M-.A-ID10
Gray 18%
White 90% White 90%

BOS 21M
Function diagrams
R1
Retroreective sensor with polarization

BOS 21M-.A-PR10 Photoelectric
sensors
R1
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
Retroreective sensor with autocollimation distance
measurement
BOS 21M-.A-PK10
Special
accessories for
R1 photoelectric
sensors
R1
Retroreective sensor with glass detection

BOS 21M-.A-PT_-S4
R1
R1
Through-beam sensor
BOS 21M-.A-IE10
www.balluff.com 203
BOS 21M
Function diagrams
Laser diffuse sensor with background suppression

BOS 21M-.US-LH12-
Percent
difference (%)
Gray 18%
White 90%
Setting against white background 90%
Tolerance with standard setting
Laser diffuse sensor

BOS 21M-.A-LD10-
White 90%
Gray 18%
Laser retroreective sensor with polarization

BOS 21M-.A-LR10-
R1

BOS 21M-.A-LE10-

BOS 21M
Wiring diagrams
! BOS 21M-PA-...S4
Photoelectric
sensors
@ BOS 21M-PUS-...S4
Photoelectric
standard
sensors
Cylinder
designs
Block
# BOS 21M-NA-...S4 designs
Photoelectric
special
sensors
Photoelectric
$ BOS 21M-NUS-...S4 distance
sensors
for analog
distance
measurement
Special
accessories for
% BOS 21M-PA-...S4S photoelectric
sensors
^ BOS 21M-XT-...S4

1
2
code material code
1 Reector BAM00UK 3 4 5 M12, 4-pin Straight PUR Yellow 5m BCC05FE
2 Reector BAM00WL M12, 4-pin Straight PVC Yellow 2m BCC05FF
3 Clamp holder BAM00TF M12, 4-pin Angled PUR Yellow 2m BCC05TA
4 Clamping holder BAM00TH M12, 4-pin Angled PVC Yellow 2m BCC05TF
5 Adapter plate BAM00T7 6
7
6 Mounting bracket BAM00T9 Connectors without LED are suitable for PNP and NPN sensors.
7 Mounting bracket BAM00TA
www.balluff.com 205
BOS 23K
The new photoelectric series BOS 23K stands for precise switching
behavior with exact positioning tasks. Its high ranges and compact
design provide for great freedom in designing the system.
The laser versions are ideal for detecting small parts.
Additional Features
Highly visible red light/laser light for precision alignment
LEDs visible from all sides
Adjustable mounting options
Outstanding price/performance ratio

BOS 23K
Type Sensing Light type Output Switching Switch- US Connec- Special Page
distance/ type ing fre- tion features
Range quency

Photoelectric
sensors
Light switching
Dark switching
Polarizing lter
10...30 V DC
Photoelectric
Laser class
Ordering code standard
Red light
Teach-in
Part number sensors
NPN
PNP
Cylinder
designs
BOS01FL BOS 23K-PA-RH10-S4 70...800 mm 600 Hz 208
Photoelectric
BOS0178 BOS 23K-PU-RH10-S4 70...800 mm 600 Hz 208 special
BOS0179 BOS 23K-NU-RH10-S4 70...800 mm 600 Hz 208 sensors
BOS01FR BOS 23K-PA-LH10-S4 120...600 mm 1 1 kHz 210 Photoelectric

distance
BOS017C BOS 23K-PU-LH10-S4 120...600 mm 1 1 kHz 210 sensors
BOS017E BOS 23K-NU-LH10-S4 120...600 mm 1 1 kHz 210 for analog
distance
measurement
BOS01FT BOS 23K-PA-LH20-S4 150...800 mm 2 1 kHz 210
BOS017H BOS 23K-PU-LH20-S4 150...800 mm 2 1 kHz 210 Special
accessories for
BOS017J BOS 23K-NU-LH20-S4 150...800 mm 2 1 kHz 210 photoelectric
sensors
Diffuse sensor
BOS01FM BOS 23K-PA-RD10-S4 0...2 m 600 Hz 208
BOS016Z BOS 23K-PU-RD10-S4 0...2 m 600 Hz 208
BOS0170 BOS 23K-NU-RD10-S4 0...2 m 600 Hz 208
BOS0175 BOS 23K-PU-LD20-S4 0...1.2 m 2 600 Hz 211

BOS0176 BOS 23K-NU-LD20-S4 0...1.2 m 2 600 Hz 211
BOS01FN BOS 23K-PA-RR10-S4 0...14 m 600 Hz 209
BOS016P BOS 23K-PU-RR10-S4 0...14 m 600 Hz 209
BOS016R BOS 23K-NU-RR10-S4 0...14 m 600 Hz 209
BOS01HJ BOS 23K-PA-LR10-S4 0...14 m 1 2 kHz 211

BOS016U BOS 23K-PU-LR10-S4 0...14 m 1 2 kHz 211
BOS016W BOS 23K-NU-LR10-S4 0...14 m 1 2 kHz 211
Through-beam sensor
Receiver
BOS01FP BOS 23K-PA-RE10-S4 0...25 m 500 Hz 209
BOS016F BOS 23K-PU-RE10-S4 0...25 m 500 Hz 209
BOS016H BOS 23K-NU-RE10-S4 0...25 m 500 Hz 209
BOS01FU BOS 23K-PA-LE10-S4 0...30 m 1 3.5 kHz 211

BOS016L BOS 23K-PU-LE10-S4 0...30 m 1 3.5 kHz 211
BOS016M BOS 23K-NU-LE10-S4 0...30 m 1 3.5 kHz 211
Through-beam sensor
Emitter
BOS016E BOS 23K-XT-RS11-S4 0...25 m 209
BOS016K BOS 23K-XT-LS11-S4 0...30 m 1 211
www.balluff.com 207
BOS 23K
Sensing distance 800 mm, 2 m

Detection range 70...800 mm 0...2 m
PNP Complementary Part number BOS 23K-PA-RH10-S4 ! BOS 23K-PA-RD10-S4 !
PNP NO/NC Part number BOS 23K-PU-RH10-S4 @ BOS 23K-PU-RD10-S4 @
NPN switchable Part number BOS 23K-NU-RH10-S4 # BOS 23K-NU-RD10-S4 #
PNP Complementary Part number
switchable Part number
PNP Receiver Part number
PNP Receiver Part number
NPN Part number
Emitter Part number
Part number
Switching type Light/dark Light/dark
Settings 18-turn potentiometer Teach-in / control input
Stability indicator Flashing yellow LED Flashing yellow LED
Degree of protection as per IEC 60529 IP 67/IP 69K IP 67/IP 69K
Material Housing PC-ABS PC-ABS
Diffuse sensor values referenced to 90% reec- 52.4 52.4

tive Kodak gray card. Reection light barrier values 4.3 23 4.3 23
referenced to R1 reector.
2
1
1

13.1 13.1
50
50
5.8 5.8
44
44
16
16
M12x1
M12x1
14
14

BOS 23K
Range 14 m, 25 m
Photoelectric
sensors

Photoelectric
0...14 m 0...25 m 0...25 m standard
sensors
Cylinder
designs
Block
BOS 23K-PA-RR10-S4 ! designs
BOS 23K-PU-RR10-S4 @
BOS 23K-NU-RR10-S4 # Photoelectric
special
BOS 23K-PA-RE10-S4 ! sensors
BOS 23K-PU-RE10-S4 @
BOS 23K-NU-RE10-S4 # Photoelectric
distance
BOS 23K-XT-RS11-S4 $ sensors
for analog
distance
10...30 V DC 10...30 V DC 10...30 V DC measurement
100 mA 100 mA
accessories for
Light/dark Light/dark photoelectric
Yes/Yes Yes/Yes sensors
Teach-in / control input Teach-in / control input
640 nm 640 nm
Green LED Green LED
Flashing yellow LED Flashing yellow LED
0.833 ms 1 ms
600 Hz 500 Hz
IP 67/IP 69K IP 67/IP 69K IP 67/IP 69K
20...+60C 20...+60C 20...+60C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PC-ABS PC-ABS PC-ABS
PMMA PMMA PMMA
52.4 52.4 52.4

4.3 23 4.3 23 4.3 23
2
2
1
13.1
13.1 13.1
50
50
50
5.8
46
46
44
33.6
33.6
16
16
16
M12x1
M12x1
M12x1
13.9
13.9
14
www.balluff.com 209
BOS 23K Laser
Sensing distance 600 mm, 800 mm Laser
PNP Complementary Part number BOS 23K-PA-LH10-S4 ! BOS 23K-PA-LH20-S4 !
Part number
PNP NO/NC Part number BOS 23K-PU-LH10-S4 @ BOS 23K-PU-LH20-S4 @
NPN switchable Part number BOS 23K-NU-LH10-S4 # BOS 23K-NU-LH20-S4 #
PNP Complementary Part number
Part number
NPN switchable Part number
Receiver Part number
NPN Receiver Part number
Part number
Emitter Part number
Switching type Light/dark Light/dark
Laser class 1 2
Light spot diameter 2 mm at 600 mm 2.5x3.5 mm at 800 mm
Stability indicator Flashing yellow LED Flashing yellow LED
Degree of protection as per IEC 60529 IP 67/IP 69K IP 67/IP 69K
Material Housing PC-ABS PC-ABS
Diffuse sensor values referenced to 90% reec- 52.4 52.4

tive Kodak gray card. Reection light barrier values 4.3 23 4.3 23
referenced to R1 reector.
2
2
1

13.1 13.1
50
50
5.8 5.8
44
44
16
16
M12x1
M12x1
14
14

BOS 23K Laser
Sensing distance 1.2 m, range 14 m, 30 m
Photoelectric
sensors
Diffuse sensor Retroreective sensor Through-beam sensor

Photoelectric
0...1.2 m 0...14 m 0...30 m standard
sensors
Cylinder
designs
BOS 23K-PU-LD20-S4 @ Block
BOS 23K-NU-LD20-S4 # designs
BOS 23K-PA-LR10-S4 !
Photoelectric
special
BOS 23K-PU-LR10-S4 @ sensors
BOS 23K-NU-LR10-S4 #
BOS 23K-PA-LE10-S4 ! Photoelectric
distance
sensors
BOS 23K-PU-LE10-S4 @ for analog
distance
BOS 23K-NU-LE10-S4 # measurement
BOS 23K-XT-LS11-S4 $
Special
accessories for
10...30 V DC 10...30 V DC 10...30 V DC photoelectric
30 mA 30 mA 30 mA
Light/dark Light/dark Light/dark
Teach-in button / control input Teach-in button / control input Teach-in button / control input
655 nm 655 nm 655 nm
2 1 1
1.2x2.2 m at 1200 mm 17 mm at 14 m
Flashing yellow LED Flashing yellow LED Flashing yellow LED
0.833 ms 0.25 ms 0.14 ms
600 Hz 2 kHz 3.5 kHz
IP 67/IP 69K IP 67/IP 69K IP 67/IP 69K
20...+60C 20...+60C 20...+60C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PC-ABS PC-ABS PC-ABS
PMMA PMMA PMMA
52.4 52.4 52.4

4.3 23 4.3 23 4.3 23
2
2
1
13.1 13.1
13.1
50
50
50
5.8 5.8
46
44
44
33.6
16
16
16
M12x1
M12x1
M12x1
13.9
13.9
13.9
www.balluff.com 211
BOS 23K
Function diagrams
Diffuse sensor with background suppression BOS 23K-..-RH10-... Diffuse sensor with background suppression BOS 23K-..-RH10-...
Scanning features Light spot size
20
40
Gray/white
Black/white shift Hysteresis
shift 18%/90% 90%/90% 32
15
6%/90%
% from distance
Size [mm]
24
10
16
5
8
0 0
0 300 600 900 1200 1500 0 300 600 900 1200
Detection range BOS 23K-..-RH10-...

Reference material Detection range
White 90% 3...1200 mm
Gray 18% 5...800 mm
Black 6% 10...600 mm
Diffuse sensor BOS 23K-..-RD10-... Diffuse sensor BOS 23K-..-RD10-...

Function reserve Light spot size
100
50
40
Function reserve
Size [mm]
30
10
20
10
1 0
0 500 1000 1500 2000 2500 0 500 1000 1500 2000
Detection range BOS 23K-..-RD10-...

White 90% 5...2000 mm
Gray 18% 10...1200 mm
Black 6% 90...600 mm
Retroreective sensor BOS 23K-..-RR10-... Retroreective sensor BOS 23K-..-RR10-...

Function reserve Light spot diameter
100
300
250
Function reserve
200
BOS R-1
Size [mm]
10 150
100
50
1 0
0.1 1 10 100 0 3 6 9 12

BOS 23K
Function diagrams
Through-beam sensor BOS 23K-..-RS../RE Through-beam sensor BOS 23K-..-RS../RE

100
700
600 Photoelectric
sensors
Function reserve
500
Photoelectric
Size [mm]
400 standard
10
sensors
300
Cylinder
designs
200
Block
designs
100
1 0 Photoelectric
1 10 100 0 5 10 15 20 special
Distance [mm] Distance [mm] sensors
Laser diffuse sensor with background suppression BOS 23K-..-LH10-... Laser diffuse sensor with background suppression BOS 23K-..-LH10-... Photoelectric
distance
scanning features Light spot size sensors
for analog
30 distance
Gray/white measurement
shift
Black/white 18%/90% 3
24 shift
Special
6%/90%
accessories for
% from distance
photoelectric
18 sensors
Size [mm]
2
12
Hysteresis
90%/90%
6
0 1
0 200 400 600 800 1000 1200 1400 0 100 200 300 400 500 600 700 800
Detection range BOS 23K-..-LH10-...

White 90% 5...800 mm
Gray 18% 10...600 mm
Black 6% 30...500 mm
Laser diffuse sensor with background suppression BOS 23K-..-LH20-... Laser diffuse sensor with background suppression BOS 23K-..-LH20-...
Scanning features Light spot size
30
5
24
Black/white
4
shift Gray/white
% from distance
6%/90% shift Vertical y

18
Size [mm]
18%/90%
3
12
Horizontal x
Hysteresis
90%/90%
2
6
0 1
0 200 400 600 800 1000 1200 1400 0 500 1000 1500 2000
Detection range BOS 23K-..-LH20-...

White 90% 5...1000 mm
Gray 18% 10...800 mm
Black 6% 15...700 mm
www.balluff.com 213
BOS 23K
Function diagrams
Laser diffuse sensor BOS 23K-..-LD20-... Laser diffuse sensor BOS 23K-..-LD20-...
100
4
Function reserve
Vertical y
Size [mm]
10 3
2 Horizontal x
1 0
0 200 400 600 800 1000 1200 1400 0 400 800 1200 1600
Detection range BOS 23K-..-LD20-...

White 90% 5...1200 mm
Gray 18% 10...700 mm
Black 6% 100...400 mm
Laser retroreective sensor BOS 23K-..-LR10-...

Light spot size
20
16
Vertical y
12
Size [mm]
8
Horizontal x
0
0 3 6 9 12 15
Distance [mm]
Laser through-beam sensor BOS 23K-..-LE../LS..-... Laser through-beam sensor BOS 23K-..-LE../LS-...
100
32
24
Function reserve
10
Size [mm]
16
1 0
0.1 1 10 100 0 7 14 21 28

BOS 23K
Wiring diagrams
! BOS 23K-PA-...
1 +U B
2 Out
4 Out
3 0V
Photoelectric
sensors
@ BOS 23K-PU-...
1 +U B
2 Teach Photoelectric
4 Out standard
3 0V sensors
Cylinder
designs
# BOS 23K-NU-...
1 +U B Block
2 Teach designs
4 Out
3 0V
Photoelectric
special
sensors
$ BOS 23K-XT-...
1 +U B
2 Photoelectric
Test distance
4
3 sensors
0V for analog
distance
measurement
Special
accessories for
photoelectric
sensors


1 2 3
code material code
1 Reector BAM00UK M12, 4-pin Straight PUR Yellow 5m BCC05FE
3 Laser reector BAM00UY M12, 4-pin Angled PUR Yellow 2m BCC05TA
4 6
4 Reective tape BAM01JM 5 M12, 4-pin Angled PVC Yellow 2m BCC05TF
5 Clamping holder BAM00TF
7
6 Clamping holder BAM00TH 9 Connectors without LED are suitable for PNP and NPN sensors.
7 Weld protection BAM01L8 8
8 Mounting bracket BAM01FK connectors and connector cables in a wide variety of cable materials, colors,
9 Mounting bracket BAM01FM and lengths in our Industrial Networking and Connectivity catalog.

www.balluff.com 215
BOS 26K
The BOS 26K series is ideally suited wherever greater demands are Features
required in terms of precision, handling, high sensing distance or Rotatable M12 connector
range, and detection of small parts. Precise setting mechanism with two revolutions (720)
The retroreective sensors feature autocollimation, that is, the emitter Clear digital display for the sensitivity setting
and receiver beams coincide geometrically. Switching status and contamination indicator visible from any
Advantage: Exact switching points for any desired side-approaching direction
object in the entire beam path. Complementary PNP output
The diffuse sensor with background suppression BOS 26K-..-1LHB, High switching frequency for laser version
with its focused light beam, can accurately detect very small objects
in virtually any color between 30 and 150 mm. The focusing feature Applications
enables a spot size of just 0.1 mm at a distance of 80 mm. Precise detection of small parts
Positioning tasks
Detail checking
Conveyor inspection (background suppression)
Conveyor technology
Automation technology
Handling machines, robotics
Machine tool building
Specialty machines

BOS 26K
Product overview
Range

Photoelectric
sensors
Autocollimation
Light switching
Dark switching
Polarizing lter
10...30 V DC
Alarm output
Photoelectric
Laser class
Red light
Infrared
Part number sensors
NPN
PNP
Cylinder
designs
BOS008C BOS 26K-PA-1LHA-SA1-S4-C 40...60 mm 2 2.5 kHz 220
Photoelectric
BOS0084 BOS 26K-NA-1LHA-SA1-S4-C 40...60 mm 2 2.5 kHz 220 special
sensors
BOS008E BOS 26K-PA-1LHB-S4-C 30...150 mm 2 2.5 kHz 221
BOS0085 BOS 26K-NA-1LHB-S4-C 30...150 mm 2 2.5 kHz 221 Photoelectric
distance
sensors
BOS0089 BOS 26K-PA-1HC-S4-C 30...300 mm 1 kHz 218 for analog
distance
BOS008P BOS 26K-PS-1HC-S4-C 30...300 mm 1 kHz 218 measurement
BOS0082 BOS 26K-NA-1HC-S4-C 30...300 mm 1 kHz 218
Special
accessories for
BOS008F BOS 26K-PA-1LHC-S4-C 50...300 mm 2 2.5 kHz 221 photoelectric
BOS008R BOS 26K-PS-1LHC-S4-C 50...300 mm 2.5 kHz 221 sensors
BOS0086 BOS 26K-NA-1LHC-S4-C 50...300 mm 2 2.5 kHz 221
BOS008A BOS 26K-PA-1IE-S4-C 150...600 mm 800 Hz 219

BOS0083 BOS 26K-NA-1IE-S4-C 150...600 mm 800 Hz 219
BOS008M BOS 26K-PA-1QE-S4-C 0...5.5 mm 1 kHz 219
BOS0088 BOS 26K-NA-1QE-S4-C 0...5.5 mm 1 kHz 219
BOS008N BOS 26K-PO-1QE-SA1-C 0...5.5 mm 1 kHz 219
BOS008L BOS 26K-PA-1LQP-S4-C 0...20 m 1 2.5 kHz 222

BOS0087 BOS 26K-NA-1LQP-S4-C 0...20 m 1 2.5 kHz 222
BOS008J BOS 26K-PA-1LQE-SA1-S4-C 0...7 mm 1 2.5 kHz 223
BOS008K BOS 26K-PA-1LQE-SA2-S4-C 0...6 mm 1 2.5 kHz 223
www.balluff.com 217
BOS 26K

PNP NO/NC Part number BOS 26K-PA-1HC-S4-C !
NPN NO/NC Part number BOS 26K-NA-1HC-S4-C $
PNP NO/NC Polarizing lter, autocollimation, Part number
PNP NO Polarizing lter, autocollimation, Alarm output Part number BOS 26K-PS-1HC-S4-C #
Settings 2-turn potentiometer with indicator
Help function
Emitter, light type LED, red light, pulsed
Wavelength 660 nm
Light spot diameter approx. 8 mm at 200 mm
Gray value shift (90%/18%) 8%
Distance hysteresis <5%
Stability indicator Red LED
Permissible ambient light EN 60947-5-2
Material Housing ABS, impact-resistant


Emitter Receiver
Digital display
Rotates 270

BOS 26K
Sensing distance 600 mm, range 5.5 m
Photoelectric
sensors
Diffuse sensor with background suppression Retroreective sensor Retroreective sensor

Photoelectric
150...600 mm 0...5.5 m 0...5.5 m standard
BOS 26K-PA-1IE-S4-C ! sensors
Cylinder
BOS 26K-NA-1IE-S4-C $ designs
BOS 26K-PA-1QE-S4-C ! Block
BOS 26K-NA-1QE-S4-C $ designs
BOS 26K-PO-1QE-SA1-C @
10...30 V DC 10...30 V DC 10...30 V DC Photoelectric
special
70 mA 30 mA 30 mA
Light/dark (complementary) Light/dark (complementary) Light switching Photoelectric
distance
2-turn potentiometer with indicator 2-turn potentiometer with indicator 2-turn potentiometer with indicator for analog
distance
Contamination output measurement
LED, infrared, pulsed LED, red light, pulsed LED, red light, pulsed
880 nm 660 nm 660 nm Special
accessories for
approx. 20 mm at 400 mm 15 mm in 500 mm 15 mm in 500 mm photoelectric
12% sensors
<5%
Red LED Red LED Red LED
0.625 ms 0.5 ms 0.5 ms
800 Hz 1 kHz 1 kHz
IP 67 IP 67 IP 67
20...+60C 20...+60C 20...+60C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
ABS, impact-resistant ABS, impact-resistant ABS, impact-resistant
PMMA PMMA PMMA
Emitter Receiver
optical axis
optical axis
Digital display Digital display Digital display
Rotates 270 Rotates 270 Rotates 270
www.balluff.com 219
BOS 26K Laser

PNP NO/NC Part number BOS 26K-PA-1LHA-SA1-S4-C !
NPN NO/NC Part number BOS 26K-NA-1LHA-SA1-S4-C $
PNP NO Part number
Wavelength 670 nm
Laser class 2
Light spot diameter see table
Distance hysteresis 50 m
Permissible ambient light EN 60947-5-2

Emitter Receiver
Digital display
Rotates 270
Light spot diameter [mm]

Sensing distance 40 45 50 55 60
Light spot 0.25 0.7 1.1 1.5 1.8

BOS 26K Laser
Photoelectric
sensors
Diffuse sensor with background suppression Diffuse sensor with background suppression
Photoelectric
30...150 mm 50...300 mm standard
BOS 26K-PA-1LHB-S4-C ! BOS 26K-PA-1LHC-S4-C ! sensors
Cylinder
BOS 26K-NA-1LHB-S4-C $ BOS 26K-NA-1LHC-S4-C $ designs
BOS 26K-PS-1LHC-S4-C # Block
10...30 V DC 10...30 V DC designs
200 mA 200 mA
special
Light/dark (complementary) Light/dark (complementary) sensors
Yes/Yes Yes/Yes
2-turn potentiometer with indicator 2-turn potentiometer with indicator Photoelectric
distance
Laser, red light Laser, red light sensors
670 nm 670 nm for analog
distance
2 2 measurement
see table 31 mm at 300 mm
8% 5% Special
accessories for
5% 2% photoelectric
Red LED Red LED
0.2 ms 0.2 ms
2.5 kHz 2.5 kHz
IP 67 IP 67
15...+45C 20...+45C
5 klx 5 klx
ABS, impact-resistant ABS, impact-resistant
PMMA PMMA
Emitter Receiver
Emitter Receiver
Digital display Digital display
Rotates 270 Rotates 270
Light spot diameter [mm] Light spot diameter [mm]

Sensing distance 30 60 80 100 150 Sensing distance 50 100 200
Light spot 1.8 0.7 0.1 1.1 2.5 Light spot 51.8 41.5 3.81.2
www.balluff.com 221
BOS 26K Laser
Range 20 m Laser
Laser class 1

PNP NO/NC Polarizing lter, Part number BOS 26K-PA-1LQP-S4-C !
NPN NO/NC autocollimation, Part number BOS 26K-NA-1LQP-S4-C $
Wavelength 670 nm
Laser class 1
Light spot diameter 15 mm in 12 m


optical axis
Digital display
Rotates 270
Light spot diameter [mm]

Sensing distance 4 12 20
Light spot 5 15 24

BOS 26K Laser
Range 7 m, 6 m
Photoelectric
sensors

Photoelectric
0...7 m 0...6 m standard
BOS 26K-PA-1LQE-SA1-S4-C ! BOS 26K-PA-1LQE-SA2-S4-C ! sensors
Cylinder
designs
10...30 V DC 10...30 V DC Block
200 mA 200 mA designs
40 mA 40 mA
Light/dark (complementary) Light/dark (complementary) Photoelectric
special
Yes/Yes Yes/Yes sensors
2-turn potentiometer with indicator 2-turn potentiometer with indicator
Laser, red light Laser, red light Photoelectric
distance
670 nm 670 nm sensors
1 1 for analog
distance
1.5 mm in 150 mm 1.5 mm in 150 mm measurement
Green LED Green LED
Yellow LED Yellow LED Special
Red LED Red LED accessories for
photoelectric
0.2 ms 0.2 ms sensors
2.5 kHz 2.5 kHz
IP 67 IP 67
20...+45C 20...+45C
5 klx 5 klx
ABS, impact-resistant ABS, impact-resistant
PMMA PMMA
optical axis
optical axis
Digital display Digital display
www.balluff.com 223
BOS 26K
Function diagrams
Diffuse sensor BOS 26K-..-1HC-... Retroreective sensor BOS 26K-..-1QE-...

BOS R-1
reector
90% reective
Kodak Gray card

Diffuse sensor BOS 26K-..-1IE-...
90% reective
Kodak Gray card
Diffuse sensor BOS 26K-..-1LHB-...
90% reective
Kodak Gray card
Light beam geometry BOS 26K...1LHC
Light beam geometry BOS 26K...1LHB

BOS 26K
Contamination indicator Indicators and operating elements

The BOS 26K has 2 LED indicators: yellow for the function
Function indicator
indicator and green/red for the power and contamination indicator.
"Light at receiver"
Should the received light intensity drop below a certain level, this
yellow LED
will be indicated by the red LED. This allows contamination or
maladjustment to be detected early. Photoelectric
Power/contamination sensors
indicator, green/red dual LED
Photoelectric
standard
Switching distance indicator sensors
Cylinder
Sensitivity or designs
range setting Block
Wiring diagrams designs
potentiometer or spindle
! Photoelectric
special
sensors
Photoelectric
distance
@ sensors
for analog
distance
measurement
Special
# BOS 26K-.PA-... accessories for
photoelectric
sensors
$ BOS 26K-NA-...
Recommended accessories Suitable connector

Description Ordering 1 2 Size Design Cable Color Length Ordering

code material code
1 Reector BAM00UK M12, 4-pin Straight PUR Yellow 5m BCC05FE
3 4 5
3 Laser reector BAM00UY M12, 4-pin Angled PUR Yellow 2m BCC05TA
4 Laser reector BAM00UM M12, 4-pin Angled PVC Yellow 2m BCC05TF
5 Laser reector BAM00UN 7
6 Mounting bracket BAM00TK 6 Connectors without LED are suitable for PNP and NPN sensors.
7 Adapter plate BAM00T7
www.balluff.com 225
BOS 50K
The new light barriers and diffuse sensors in the BOS 50K series
combine top performance and compact dimensions. Thanks to
their long range, these all-rounders are suitable for use in numerous
sectors, ranging from the automotive industry to the woodwork-
ing industry. The background suppression is particularly impressive
with an almost color-independent detection of objects and that at
maximum sensing distance.
The most important features at a glance

Reliable object detection even at large distances
Real background suppression for a sensing distance of
up to 2 m even on dark objects
Simple alignment due to bright, clearly visible beam spot
Simple and fast setting with potentiometer
Through-beam sensor with test input for function check
Varied and time-saving assembly options

BOS 50K
Product overview
Type Sensing Light type Output Switching Switch- US Connec- Special Page
distance/ type ing fre- tion features
Range quency

Contamination output
Photoelectric
sensors
Light switching
Dark switching
Polarizing lter
10...30 V DC
Photoelectric
Red light
Teach-in
IO-Link
Part number sensors
NPN
PNP
Cylinder
designs
BOS018P BOS 50K-PA-RH12-S4 200...2000 mm 500 Hz 228
Photoelectric
BOS018R BOS 50K-NA-RH12-S4 200...2000 mm 500 Hz 228 special
BOS018N BOS 50K-PS-RH12-S4 200...2000 mm 500 Hz 228 sensors
BOS0156 BOS 50K-PSV-RH12-S4 200...2000 mm 500 Hz 228
BOS018T BOS 50K-NSV-RH12-S4 200...2000 mm 500 Hz 228 Photoelectric
distance
BOS018U BOS 50K-POV-RH12-S4 200...2000 mm 500 Hz 228 sensors
BOS018W BOS 50K-NOV-RH12-S4 200...2000 mm 500 Hz 228 for analog
distance
measurement
Diffuse sensor
BOS01CJ BOS 50K-PA-RD10-S4 1...2000 mm 400 Hz 229 Special
accessories for
BOS01N7 BOS 50K-NA-RD10-S4 1...2000 mm 400 Hz 229 photoelectric
BOS01CP BOS 50K-PS-RD10-S4 1...2000 mm 400 Hz 229 sensors
BOS01N9 BOS 50K-NS-RD10-S4 1...2000 mm 400 Hz 229
BOS01J0 BOS 50K-PO-RD10-S4 1...2000 mm 400 Hz 229
BOS01N8 BOS 50K-NO-RD10-S4 1...2000 mm 400 Hz 229
BOS01JA BOS 50K-PU-RD11-S4 1...3500 mm 200 Hz 229

BOS01JH BOS 50K-NU-RD11-S4 1...3500 mm 200 Hz 229
BOS01JJ BOS 50K-PI-RD11-S4 1...3500 mm 200 Hz 229
BOS01CR BOS 50K-PA-PR10-S4 0.1...18 m 400 Hz 230
BOS01N1 BOS 50K-NA-PR10-S4 0.1...18 m 400 Hz 230
BOS01CL BOS 50K-PS-PR10-S4 0.1...18 m 400 Hz 230
BOS01N3 BOS 50K-NS-PR10-S4 0.1...18 m 400 Hz 230
BOS01HY BOS 50K-PO-PR10-S4 0.1...18 m 400 Hz 230
BOS01N2 BOS 50K-NO-PR10-S4 0.1...18 m 400 Hz 230
Through-beam sensor
Receiver
BOS01CK BOS 50K-PA-RE10-S4 0...60 m 400 Hz 231
BOS01N4 BOS 50K-NA-RE10-S4 0...60 m 400 Hz 231
BOS01CM BOS 50K-PS-RE10-S4 0...60 m 400 Hz 231
BOS01N6 BOS 50K-NS-RE10-S4 0...60 m 400 Hz 231
BOS01HZ BOS 50K-PO-RE10-S4 0...60 m 400 Hz 231
BOS01N5 BOS 50K-NO-RE10-S4 0...60 m 400 Hz 231
Through-beam sensor
Emitter
BOS01EU BOS 50K-X-RS10-S4 231
BOS01CN BOS 50K-XT-RS10-S4 231
www.balluff.com 227
BOS 50K

PNP Complementary Part number BOS 50K-PA-RH12-S4 $
NPN Part number BOS 50K-NA-RH12-S4 )
NPN Switchable Part number
Switchable IO-Link Part number
PNP NO Part number BOS 50K-PS-RH12-S4 !
NPN NO Part number
PNP NC Part number
NPN NC Part number
PNP NO with Part number BOS 50K-PSV-RH12-S4 @
NPN Error output Part number BOS 50K-NSV-RH12-S4 *
PNP NC with Part number BOS 50K-POV-RH12-S4 ^
NPN Error output Part number BOS 50K-NOV-RH12-S4 1
Switching type Light/dark switching
Settings Potentiometer, 10-turn
Wavelength 630 nm
Light spot diameter 7575 mm at 1.5 m
Stability indicator
Error indicator Yellow LED (ashes)
Response time 1 ms
Material Housing ABS/PC
Optical surface Glass
Diffuse sensor values referenced to 90% reective Kodak gray card. 62

1.9
7.4
5 3
8.1
80.5
34.5
21.2
1.9
11.9
5
6.9
12.1
7.5 18.5

BOS 50K
Sensing distance 2 m, 3.5 m
Photoelectric
sensors
Diffuse sensor Diffuse sensor

Photoelectric
1...2000 mm 1...3500 mm standard
BOS 50K-PA-RD10-S4 $ sensors
Cylinder
BOS 50K-NA-RD10-S4 ) designs
BOS 50K-PU-RD11-S4 % Block
BOS 50K-NU-RD11-S4 2 designs
BOS 50K-PI-RD11-S4 3
Photoelectric
special
BOS 50K-PS-RD10-S4 ! sensors
BOS 50K-NS-RD10-S4 &
BOS 50K-PO-RD10-S4 # Photoelectric
distance
BOS 50K-NO-RD10-S4 ( sensors
for analog
distance
measurement
Special
accessories for
10...30 V DC 10...30 V DC photoelectric
50 mA 50 mA
Light/dark switching Light/dark switching
Yes/Yes Yes/Yes
Potentiometer, 270 Teach-in
630 nm 630 nm
5050 mm at 2 m 8080 mm at 3.5 m
Green LED Green LED

Yellow LED, ashes Yellow LED, ashes
1.25 ms 2.5 ms
400 Hz 200 Hz
IP 67 IP 67
5...+55C 5...+55C
5 klx 10 klx
ABS/PC ABS/PC
Glass Glass
62 62
1.9 1.9
7.4 7.4
5 3 5 3
8.1
8.1
80.5
80.5
34.5
34.5
21.2
21.2
1.9
1.9
11.9
11.9
5
5
6.9
6.9
12.1
12.1
7.5 18.5 7.5 18.5
www.balluff.com 229
BOS 50K
Range 18 m

PNP NO/NC Polarizing lter Part number BOS 50K-PA-PR10-S4 $
NPN NO/NC Part number BOS 50K-NA-PR10-S4 )
PNP NO Polarizing lter Part number BOS 50K-PS-PR10-S4 !
NPN NO Part number BOS 50K-NS-PR10-S4 &
PNP NC Polarizing lter Part number BOS 50K-PO-PR10-S4 #
NPN NC Part number BOS 50K-NO-PR10-S4 (
Emitter Part number
Switching type Light/dark
Wavelength 630 nm
Light spot diameter 200200 mm at 10 m
Stability indicator Yellow LED ashes
Material Housing ABS/PC
Retroreective sensor values referenced to R1 reector. 62

1.9

5 3
8.1
80.5
34.5
21.2
1.9
11.9
5
6.9
12.1
7.5 18.5

BOS 50K
Range 60 m

sensors

Photoelectric
0...60 m 0...60 m standard
BOS 50K-PA-RE10-S4 $ sensors
Cylinder
BOS 50K-NA-RE10-S4 ) designs
BOS 50K-PS-RE10-S4 ! Block
BOS 50K-NS-RE10-S4 & designs
BOS 50K-PO-RE10-S4 #
Photoelectric
BOS 50K-NO-RE10-S4 ( special
BOS 50K-XT-RS10-S4 4 sensors
BOS 50K-X-RS10-S4 4
10...30 V DC 10...30 V DC Photoelectric
distance
100 mA sensors
35 mA 50 mA for analog
distance
Light/dark measurement
Yes/Yes Yes/Yes
Fixed Potentiometer, 270 Special
accessories for
LED, red light photoelectric
630 nm sensors
180180 mm at 10 m
Green LED Green LED
Yellow LED
1.25 ms
400 Hz
IP 67 IP 67
5...+55C 5...+55C
10 klx 10 klx
ABS/PC ABS/PC
Glass Glass
62 62
1.9 1.9
7.4 7.4
5 3 5 3
8.1
8.1
80.5
80.5
34.5
34.5
21.2
21.2
1.9
1.9
11.9
11.9
5
5
6.9
6.9
12.1
12.1
7.5 18.5 7.5 18.5
www.balluff.com 231
BOS 50K
Function diagrams
Diffuse sensor with background suppression Diffuse sensor

BOS 50K-..-RH12-S4-... BOS 50K-..-RH12-S4-...
0 90% remission (white) 10
Hysteresis (% of Sr max.)
-5
18% remission (gray)
Sr max (%)
-10 1
-15
-20 0.1
6% remission (black)
-25
-30 0.01
500 1000 1500 2000 500 1000 1500 2000
Object distance Object distance
Switching distance deviation depending on object distance Switching hysteresis depending on object distance
With differing level of remission
Diffuse sensor with background suppression

BOS 50K-..-RH12-S4-...
Switching point relative to mechanical axis
20
Switching point at 2000 mm
15
10
5
-5
-10
-15
-20
500 1000 1500 2000

Object distance
Response curve with switch-on point from left and right side

BOS 50K-..-RD10-S4 BOS 50K-..-RD10-S4
20 100
15 Gray card 90%

Function reserve
10
Switching point
5 10
-5
Gray card 18%
-10 1
500 1000 1500 2000
-15 Object distance target 200200 mm
-20 Function reserve depending on distance
500 1000 1500 2000
Object distance
Response curve depending on distance

BOS 50K-..-RD11-S4 BOS 50K-..-RD11-S4
1000
20
Gray card 18%
15
Gray card 90% 100
Function reserve
10
5 Gray card 90%
-5 10
-10
Gray card 18%
-15
-20 500 1000 1500 2000 2500 3000 3500 mm
Object distance
500 1000 1500 2000 2500 3000 3500
Object distance Function reserve depending on object distance
Response curve depending on object distance
BOS 50K
Retroreective sensor Through-beam sensor

BOS 50K-..-PR10-S4 BOS 50K-..-RE/RS10-S4
100 10000
1000
Photoelectric
Function reserve
sensors
Function reserve
BOS R47 100

10 Photoelectric
standard
sensors
10 Cylinder
designs
BOS R1
Block
BOS R50 BOS R46 designs
BOS R9 0
1 0 10 20 30 40 50 60
0 2 4 6 8 10 12 14 16 18 20 22 Emitterreceiver distance (m) Photoelectric
Reector distance (m) special
sensors
Function reserve depending on distance between sensor and reector Function reserve depending on distance between emitter and receiver
Photoelectric
Indicators and operating elements Wiring diagrams distance
sensors
! BOS 50K-PS... * BOS 50K-NSV...
for analog
1 BN +U B 1 BN
2 WH
+UB distance
Error measurement
4 BK Out 4 BK
Green LED Yellow LED Green LED Yellow LED Out
3 BU 3 BU
0V 0V
Special
@ BOS 50K-PSV... ( BOS 50K-NO... accessories for
Teach key 1 BN 1 BN +U B
Potentiometer: WH
+UB photoelectric
2 Error
Conguring the 4 BK 4 WH sensors
Out Out
switching distance 3 BU 3 BU
0V 0V
# BOS 50K-PO... ) BOS 50K-NA...

1 BN +U B 1 BN +UB
2 WH
WH Out
4 Out 4 BK
BU BU Out
3 0V 3 0V
$ BOS 50K-PA... 1 BOS 50K-NOV...

1 BN +UB 1 BN +UB
2 WH 2 WH
Out Error
4 BK 4 BK
Out Out
3 BU 3 BU
0V 0V
% BOS 50K-PU... 2 BOS 50K-NU...

1 BN +UB 1 BN +UB
4 BK Test 4 BK Test
3 BU 3 BU
0V 0V
^ BOS 50K-POV... 3 BOS 50K-PI...

1 BN +UB
2 WH
Error
4 BK
Out
3 BU
0V
& BOS 50K-NS...

1 BN
Recommended accessories +U B
4 BK
(please order separately) BU
Out
3 0V
1 2
Suitable connector
code
1 Reector BAM00UK
2 Reector BAM00WL 3 4 5
3 Reector BAM01JN Size Design Cable Color Length Ordering
4 Reector BAM01JP material code
5 Reective tape BAM01JM 6 7 M12, 4-pin Straight PUR Yellow 5m BCC05FE
6 Mounting bracket BAM01E8 M12, 4-pin Straight PVC Yellow 2m BCC05FF
7 Weld protection BAM01U6 M12, 4-pin Angled PUR Yellow 2m BCC05TA
reectors, apertures, lenses, lters, and deection heads, in More electrical accessories: You can nd a large selection of plug
this catalog starting on page 420. connectors and connector cables in a wide variety of cable materials, colors,
www.balluff.com 233
BOS 63M
The BOS 63M is a specialist among the diffuse sensors with

regard to background suppression. The laser makes it ideally suited
for detecting objects from far away when they are right in front of a
background. The precise laser beam detects even small objects or
object details from great distances.
With two solid 4-turn potentiometers, the two switching outputs
can be congured independently and exactly. An integrated error
indicator informs you about the current sensor status.

BOS 63M
Product overview
Type Sensing Light type Output Switching Switching US Connec- Special Page
distance/ type frequency tion features
Range

Photoelectric
sensors
Light switching
15...30 V DC
Photoelectric
2 NPN
2 PNP
Part number sensors
Laser
Cylinder
designs
BOS019J BOS 63M-PS-LH13-S4 0.2...6 m 250 Hz 236
BOS019H BOS 63M-NS-LH13-S4 0.2...6 m 250 Hz 236 Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 235
BOS 63M

2 PNP Part number BOS 63M-PS-LH13-S4 !
2 NPN Part number BOS 63M-NS-LH13-S4 @
Supply voltage UB 1530 V DC
Switching type Light switching
Settings Potentiometer, 4-turn (2x)
Wavelength 660 nm
Laser class 2
Light spot size 10 mm
Gray value shift 1.5%
Switching hysteresis 15 mm
Repeat accuracy 4 mm
Output function indicator Yellow LED (2x)
Error indicator Red LED
Response time 2 ms
Ambient temperature T 10...+60C
Material Housing GD-AL
Diffuse sensor values referenced to 90% reective

Kodak gray card, 400400 mm.
19.5

BOS 63M Photoelectric Standard Sensors
BOS 63M
Function diagram, connection, accessories
Indicators and operating elements Working range as a function of object reectivity
R
1.
2.
100 %
3.
4. Photoelectric
90 %
sensors
5. 6. 72 %
Photoelectric
54 % standard
1. Power indicator (green) sensors
36 % Cylinder
2. Output function indicator Out 1 (yellow) designs
3. Output function indicator Out 2 (yellow) 18 %
Block
4. Error indicator (red) designs
6% Sa
5. 4-turn potentiometer for switching distance 1
6. 4-turn potentiometer for switching distance 2 m
Photoelectric
0 0.25 1 4 5 6 special
sensors
Wiring diagram Photoelectric

distance
! +U B sensors
PS
Out 1
for analog
distance
Out 2

0V
measurement
@ 1 +U B Special
NS 4
Out 1 accessories for
2
Out 2 photoelectric
3
0V sensors
Recommended accessories ories Suitable connector


code material code
Mounting bracket BAM00P6 M12, 8-pin Straight PUR Yellow 5m BCC0995
reectors, apertures, lenses, lters, and deection heads, in More electrical accessories: You can nd a large selection of plug
this catalog starting on page 420. and lengths in our Industrial Networking and Connectivity catalog.
www.balluff.com 237
BOS 64K (AC/DC)
(AC/DC)
High-performance sensors are particularly in demand for harsh Features

applications. This is why our BOS 64K has a 3 A output at 264 V AC Universal voltage model 24...240 V AC with relay output
and a very long sensing distance and range. Additionally, it provides Light/dark switching
an adjustment aid and time functions. Time functions
The following variants with a robust plastic housing and large Wiring compartment with cable gland
terminal compartment can be delivered:
Diffuse sensor Applications
Diffuse sensor with background suppression Conveyor technology
Retroreective sensor with polarizing lter Machine tool building
Through-beam sensor Packaging technology
Assembly and handling automation
The sensors have a relay output. Gate controls
The photoelectric sensors operate with alternating light in the visible Warehouse technology
red and infrared light range.

BOS 64K (AC/DC)
Product overview
Type Sensing Light type Out- Switching Switch- US Connection Features Page
distance/ put type ing fre-
Range quency
Photoelectric
sensors
Wiring chamber
Light switching
Dark switching
Polarizing lter
24...240 V AC
24...60 V DC
Photoelectric
Red light
Infrared
Part number sensors
Relay
Cylinder
designs
BOS01K1 BOS 64K-AA-IH12-TG 200...2000 mm 20 Hz 240
Photoelectric
special
Diffuse sensor sensors
BOS01K2 BOS 64K-AA-ID10-TG 50...2000 mm 20 Hz 240
Photoelectric
distance
BOS01K3 BOS 64K-AA-PR10-TG 0...10 m 20 Hz 241 for analog
distance
Through-beam sensor measurement
Receiver
BOS01K4 BOS 64K-AA-IE10-TG 0...50 m 20 Hz 241 Special
accessories for
Through-beam sensor photoelectric
Emitter sensors
BOS01K5 BOS 64K-AA-IS10-TG 0...50 m 241
www.balluff.com 239
BOS 64K (AC/DC)
Sensing distance 1.1 m, 2 m

Relay 3A, 250 V AC Time function Infrared Part number BOS 64K-AA-IH12-TG BOS 64K-AA-ID10-TG
Relay 3A, 250 V AC Time function Polarizing lter, red light Part number
Relay 3A, 250 V AC Time function Receiver, Infrared Part number
Relay 3A, 250 V AC Time function Emitter Part number
Supply voltage UB 24...60 V DC, 24...240 V AC 24...60 V DC, 24...240 V AC
Switching type Light and dark (switchable) Light and dark (switchable)
Settings Potentiometer, dip switch Potentiometer, dip switch
Power-on indicator
Connection Wiring chamber Wiring chamber
Cable diameter 8...10 mm 8...10 mm
Diffuse sensor values referenced to 90% reective Kodak gray card. 100.4
96.2 25.0
SW 22
69.7
67.5
42.0
31.15
5.2
5.0
5.0
6.8
16.9
27.0 40.0
50.0
55.0

BOS 64K (AC/DC)
Range 8 m, 50 m
Photoelectric
sensors

Photoelectric
0...10 m 0...50 m 0...50 m standard
sensors
BOS 64K-AA-PR10-TG Cylinder
designs
BOS 64K-AA-IE10-TG Block
BOS 64K-AA-IS10-TG designs
24...60 V DC, 24...240 V AC 24...60 V DC, 24...240 V AC 24...60 V DC, 24...240 V AC
Light and dark (switchable) Light and dark (switchable) Photoelectric
special
Potentiometer, dip switch Potentiometer, dip switch sensors
Green LED
Yellow LED Yellow LED Photoelectric
distance
25 ms 25 ms for analog
distance
20 Hz 20 Hz measurement
IP 67 IP 67 IP 67
25...+55C 25...+55C 25...+55C Special
5 klx 5 klx accessories for
photoelectric
PBT PBT PBT sensors
PC PC PC
Wiring chamber Wiring chamber Wiring chamber
8...10 mm 8...10 mm 8...10 mm
100.4
96.2 25.0
SW 22
69.7
67.5
42.0
31.15
5.2
5.0
5.0
6.8
16.9
27.0 40.0
50.0
55.0
www.balluff.com 241
BOS 64K (AC/DC)
Wiring diagrams
AC, screw terminals AC, screw terminals

L
N
NC
NO
6
C
5
Recommended accessories 2
Description Ordering 1
code
1 Reector BAM00UK
2 Mounting bracket BAM0125


Photoelectric
sensors
Photoelectric
standard
sensors
Cylinder
designs
Block
designs
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 243
Photoelectric
Sensors
for object detection
Special applications need special sensors. Our special photoelectric
sensors solve very special tasks with reliability and dependability. For
instance, color sensors reliably detect even the slightest color differ-
ences. The rst-class True Color Sensor is at home in quality control
as well as sorting systems. Contrast sensors and luminescence sen-
sors are perfectly suited for detection tasks, such as reading marks
on packaging and sensing ll levels, determining contours, measur-
ing thickness, etc.
Our broad selection of fork sensors with various widths and light
types allow optimal adaptation to many detection tasks. Angle sen-
sors or Dynamic optical windows are available as another alternative,
in addition to light grids for packaging larger objects involving longer
distances.
But even if it looks like there is no space for a photoelectric sensor,
Balluff provides a solution: ber optics in glass and plastic versions.

Photoelectric Special Sensors

Optical ber basic devices BFB/BOS 246
Fiber optics BFO 272
Contrast sensors BKT 322
Luminescence sensors BLT 336
Color sensors BFS 342
Fork sensors BGL_A 348
Analog fork sensors BGL_C 368
Angle sensors BWL 372
Dynamic optical windows BOW 384
Light grids BLG 390
www.balluff.com 245
Photoelectric Special Sensors Optical Fiber
Optical ber base units BFB/BOS
Base Units
Fiber optics are needed whenever there is not enough space for a Applications
photoelectric sensor. Small parts detection
Plastic ber optics are the right choice if the requirements for tough- Suitable for tight mounting conditions
ness, ambient temperature or chemical resistance are not very high. Inspecting parts features
There is a wide selection of special base units available with different Counting
outputs and various functions for using them: from simple models Precise parts positioning
with a potentiometer to high-end devices with a display. The base Assembly and handling technology
units generally operate using red light. Robotics
The base units for glass ber optics nd use in harsh environments
thanks to their powerful infrared light. Temperatures of up to 250 C
and oil mist are not a problem thanks to the various models of glass
ber optics.
Type Light type Output Switching Switching US Connection Special Page

type frequency features
M12 plug, 4-pin

Light switching
M8 plug, 3-pin
M8 plug, 4-pin
Dark switching
NPN transistor
PNP transistor
Analog output
10...30 V DC
11...26 V DC
Alarm output
Infrared light
Ordering code
Red light
Teach-in
Display
Cable
Part number
Base units
for plastic
optical bers
BFB0004 BFB 75K-001-P-S75 1.5 kHz 249
BFB0002 BFB 75K-001-N-S75 1.5 kHz 249
BFB0003 BFB 75K-001-P-02 1.5 kHz 249
BFB0001 BFB 75K-001-N-02 1.5 kHz 249
BFB0006 BFB 75K-002-P-S75 8 kHz 251

BFB0005 BFB 75K-002-N-S75 8 kHz 251
BFB0008 BFB 75K-003-P-02 8 kHz 251

BFB0007 BFB 75K-003-N-02 8 kHz 251
BOS003K BOS 73K-PU-1FR-C-02 1 kHz 253

BOS003L BOS 73K-PU-1FR-C-S75-00,1 1 kHz 253
BOS014L BOS 73K-PU-1FR-C-S49-00,3 1 kHz 253
BOS009R BOS 6K-PU-1FR-S75-C 1 kHz 255

BOS009P BOS 6K-PU-1FR-C-02 1 kHz 255
BOS008W BOS 6K-NU-1FR-S75-C 1 kHz 255
BOS008U BOS 6K-NU-1FR-C-02 1 kHz 255
BOS00JJ BOS 18KF-PA-1FR-S4-C 1 kHz 257

BOS00JH BOS 18KF-PA-1FR-C-02 1 kHz 257
BOS00HL BOS 18KF-NA-1FR-S4-C 1 kHz 257
BOS00HK BOS 18KF-NA-1FR-C-02 1 kHz 257

Optical ber base units BFB/BOS
Product overview
Type Light Output Switching Switching US Connection Special Page

type type frequency features
1/2 x 20 UNF for AC/DC sensors (S21)

M12 plug, 4-pin pigtail
Photoelectric
22...250 V AC/V DC
sensors
M12 plug, 4-pin

AC/DC 2 - wire
Light switching
M8 plug, 4-pin
Dark switching
NPN transistor
PNP transistor
Analog output
10...24 V DC
11...26 V DC
Alarm output
Infrared light
Photoelectric
Red light
Teach-in
Display
Part number sensors
Cable
Photoelectric
Base units for special
glass optical bers sensors
BOS0049 BOS 18M-PA-1PD-E5-C-S4 100 Hz 258 Optical ber
base units
BOS0080 BOS 18M-PU-1PD-SA5-C 1 kHz 258 Fiber optics
BOS001P BOS 18M-PA-1PF-E5-C-S4 200 Hz 259 Contrast sensor
BOS007U BOS 18M-GU-1PF-S4-Y 1 kHz 259 Luminescence
sensor
BOS0134 BOS 30M-GA-1PH-S4-C 100 Hz 259 Color sensors
Fork sensors
Angle sensors
BOS00P3 BOS 16K-UU-1FI-00.2-S4 500 Hz 261
Dynamic optical
BOS00PR BOS 16K-VU-1FI-00.2-S4 1.6 kHz 261 windows
BOS00P4 BOS 16K-UU-1FI-02 500 Hz 262 Light grids
BOS00PT BOS 16K-VU-1FI-02 1.6 kHz 262
BOS00NH BOS 16K-AU-0F1-00.2-S21 60 Hz 263 Photoelectric
distance
BOS00NJ BOS 16K-AU-0F1-02 60 Hz 263 sensors
BOS00P5 BOS 16K-UU-1FR-00.2-S4 500 Hz 264 for analog
distance
BOS00PU BOS 16K-VU-1FR-00.2-S4 1.6 kHz 264 measurement
BOS00P6 BOS 16K-UU-1FR-02 500 Hz 265
BOS00NK BOS 16K-AU-0FR-00.2-S21 60 Hz 265 Special
accessories for
BOS00NL BOS 16K-AU-0FR-02 60 Hz 266 photoelectric
sensors
BOS00Z0 BOS 72K-PU-RA10-S75 * 269
BOS00YZ BOS 72K-NU-RA10-S75 * 269
BOS00YU BOS 72K-PU-RA10-02 * 269
BOS00YT BOS 72K-NU-RA10-02 * 269
BOS00YY BOS 72K-PU-RA20-S75 * 269
BOS00YW BOS 72K-NU-RA20-S75 * 269
BOS00YR BOS 72K-PU-RA20-02 * 269
BOS00YP BOS 72K-NU-RA20-02 * 269
10...30 V DC
15...30 V DC
Base units for

wire optical bers
BAE00AL BMO A01-J-PU-C-S75 500 Hz 271
BAE00AK BMO A01-J-PU-C-02 500 Hz 271
BAE00AJ BMO A01-J-NU-C-02 500 Hz 271
BAE00AH BMO A01-I-PU-C-02 500 Hz 271
BAE00AF BMO A01-I-NU-C-02 500 Hz 271
BAE00AC BMO A01-H-C1-C-02 500 Hz 271
BAE00AE BMO A01-H-V1-C-02 500 Hz 271
* 1 kHz High Resolution

5 kHz Standard Resolution
www.balluff.com 247
Photoelectric Special Sensors Base Units for
Optical ber base units BFB 75K
Plastic Optical Fibers
The BFB 75K-001

is ideal for any kind of standard application. This affordable sensor
is installed on DIN rails and makes a great entry-level model. Ease of
setting using a teach-in procedure on the sensor or via an external
teach line make the sensor especially user-friendly.
Features
Red light
Teach-in
Connector and cable versions
Mounting notes for ber optics Operating panel

The resistance of the sealing ring must be overcome when connect-
ing the ber optics to the base unit.
Power-on indicator
Switching state indicator
Wiring diagrams
BFB 75K-001-P
Ext. teach-in Ext. teach-in
BFB 75K-001-N
Teach- button
Suitable connector

material code

nectors and connector cables in a wide variety of cable materials, colors and

Photoelectric
sensors
Photoelectric
standard
Series BFB 75K BFB 75K sensors
Plastic ber optic base unit for plastic ber optics for plastic ber optics
Photoelectric
with an outside diameter of 2.2 mm with an outside diameter of 2.2 mm special
PNP NC/NO Part number BFB 75K-001-P-S75 BFB 75K-001-P-02 sensors
NPN NC/NO Part number BFB 75K-001-N-S75 BFB 75K-001-N-02 Optical ber
base units
Fiber optics
Output current 100 mA 100 mA Contrast sensor
No-load supply current I0 max. 20 mA 20 mA Luminescence
Switching type Light/dark switching (selectable) Light/dark switching (selectable) sensor
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes Color sensors
Settings Teach-in Teach-in Fork sensors
Angle sensors
Dynamic optical
Wavelength 660 nm 660 nm windows
Light spot diameter Depends on the ber optics Depends on the ber optics Light grids
Switching state indicator Yellow LED Yellow LED Photoelectric
distance
Switching frequency f 1.5 kHz 1.5 kHz sensors
Degree of protection as per IEC 60529 IP 64 IP 64 for analog
distance
Ambient temperature Ta 20...+60 C 20...+60 C measurement
Material Housing ABS ABS Special
Optical surface Depends on ber optics Depends on ber optics accessories for
photoelectric
Connection M8 connector, 4-pin 2 m PVC cable, 26 AWG sensors
Connector orientation
Suitable ber optics can be found LED LED

starting on page 272.
84.1
Buttons Buttons
www.balluff.com 249
The BFB 75K-002 Mounting notes for ber optics

The high-end amplier offers perfect performance with 12-bit resolu- The resistance of the sealing ring must be overcome when connect-
tion, a 4-digit display and a switching frequency up to 8 kHz. ing the ber optics to the base unit.
Various operating modes such as Fine or High Distance allow the
sensor to be better adapted to the respective application.
Several sensors can be installed next to each other. Up to four
sensors installed adjacent to each other are synchronized to avoid
mutual interference in an application. They are synchronized auto-
matically after the supply voltage is turned on.
Adjustable time functions, window programming and ne-tuning for
the switching point expand its range of application options.
Operating mode Standard High High High
The BFB 75K-003... version provides an additional analog output. resolution switching Range
The output signal is in proportion to the remission or to the distance frequency
of the target object. All of the functions of the BFB 75K-02 variant Sensing distance* 150 mm 70 mm 70 mm 300 mm
are included. Switching frequency 1 kHz 125 Hz 8 kHz 125 Hz
*Depending on ber optics used
Features
Display
4 operating modes
No mutual interference
Variant with analog output
Wiring diagrams
BFB 75K-002-P Operating panel

Ext. teach-in
Yellow Green LED Power-on indicator
LED
Switching
BFB 75K-002-N state
indicator Red CONF LED Conguration is active
Red LOCK LED Keypad lock is active
Ext. teach-in Red NC LED Change switching output NO/NC
Red ADJ LED Adjust function is selected
Red DELAY LED Time function is selected
Red FUNC LED Function is selected
Display The display represents the reected energy

BFB 75K-003-P in the form of a numerical value (0-4095).
Ext. teach-in
Teach- buttons
Conguring various functions
BFB 75K-003-N
Ext. teach-in
Suitable connector

material code


Photoelectric
sensors
Photoelectric
standard
Series BFB 75K BFB 75K sensors
Photoelectric
PNP NC/NO Part number BFB 75K-002-P-S75 BFB 75K-003-P-02 sensors
NPN NC/NO Part number BFB 75K-002-N-S75 BFB 75K-003-N-02 Optical ber
base units
Fiber optics
Analog output 0...10 V (max. 2 mA) sensor
Switching type Light/dark switching (selectable) Light/dark switching (selectable) Color sensors
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes Fork sensors
Angle sensors
Dynamic optical
Emitter, light type LED, red light LED, red light windows
Wavelength 630 nm 630 nm Light grids
Light spot diameter Depends on the ber optics Depends on the ber optics
Power-on indicator Green LED Green LED Photoelectric
distance
Switching state indicator Yellow LED Yellow LED sensors
Status indicator 6 red LEDs 6 red LEDs for analog
distance
Display 4-digit 4-digit measurement
Switching frequency f Standard 1.5 kHz 1.5 kHz
Fast Mode 8 kHz 8 kHz Special
Adjustable 1...2000 ms delay for Adjustable 1...2000 ms delay for accessories for
Time function photoelectric
switching on and/or off switching on and/or off sensors
Optical surface Depends on ber optics Depends on ber optics
Suitable ber optics can be found

LED LED
Display Display
84.1
Buttons Buttons
www.balluff.com 251
Optical ber base units BOS 73K
The BOS 73K with display simplies sensor set up and provides a
precise overview of its settings.
The display shows sensitivity, signal strength as well as additional
functions.
The switching point and hysteresis can be acquired automatically or
set manually. The powerful red light emitter permits very long sens-
ing distances and ranges.
A switching and alarm output is also provided as an output and time
functions can also be set.
Two transmission channels allow multiple sensors to be used without Series
them interfering with each other. Plastic ber optic base unit
Wiring diagrams
Features BOS 73K...-02 PNP NC/NO Part number
LCD display with backlighting Supply voltage UB
PNP
Settings via teach-in Switching Switching output
Alarm
Powerful red light emitter for long ranges Ext. teach-in frequency f Alarm output
Contamination output No-load supply current I0 max.
All time functions can be set from 10...120 ms BOS 73K...-S75 Switching type
Two transmission channels Polarity reversal/short-circuit protected
PNP Settings
Alarm
Operating panel Emitter, light type
Clamp lever Stability indicator Teach-in Function selection BOS 73K...-S49 Wavelength
+ Light spot diameter
PNP Output function indicator
- Stability indicator
5XQ 0RGH Display
Response time
Output function indicator Display Operating mode
Switching Standard
Display frequency f
Mode Time function
L: Light switching Sensitivity range
D: Dark switching 8-level display (1, 2...8)
O: On-delay Amount of received
Transmission
F: Off-delay light frequency channel Ambient temperature Ta
Functions Material Housing

Sensor functions Additional functions
A: Automatic S: Manual sensitivity setting/switch-on point Optical surface
Detection H: Manual hysteresis setting (switch-off point) Connection
T: Teach-in V: Signal strength uctuation and absolute value display
L: Lock
Mounting hardware
are included!
Suitable connector Suitable connector

Size Design Cable Color Length Ordering Size Design Cable Color Length Ordering
material code material code
M8, 4-pin Straight PUR Yellow 2m BCC053Z M8, 3-pin Straight PUR Yellow 2m BCC050P
M8, 4-pin Straight PVC Yellow 2m BCC0542 M8, 3-pin Straight PVC Yellow 2m BCC050Y
M8, 4-pin Angled PUR Yellow 2m BCC059R M8, 3-pin Angled PUR Yellow 2m BCC0558
M8, 4-pin Angled PVC Yellow 2m BCC059W M8, 3-pin Angled PVC Yellow 2m BCC055C
Connectors without LED are suitable for PNP and NPN sensors. Connectors without LED are suitable for PNP and NPN sensors.
More electrical accessories: You can nd a large selection of plug con- More electrical accessories: You can nd a large selection of plug con-
nectors and connector cables in a wide variety of cable materials, colors and nectors and connector cables in a wide variety of cable materials, colors and
lengths in our Industrial Networking and Connectivity catalog. lengths in our Industrial Networking and Connectivity catalog.

Photoelectric
sensors
Photoelectric
standard
BOS 73K BOS 73K BOS 73K sensors
for plastic ber optics for plastic ber optics for plastic ber optics
Photoelectric
with an outside diameter of 2.2 mm with an outside diameter of 2.2 mm with an outside diameter of 2.2 mm special
BOS 73K-PU-1FR-C-02 BOS 73K-PU-1FR-C-S75-00,1 BOS 73K-PU-1FR-C-S49-00,3 sensors
11...26 V DC 11...26 V DC 11...26 V DC Optical ber
base units
100 mA 100 mA 100 mA
Fiber optics
50 mA 50 mA Contrast sensor
50 mA 50 mA 50 mA Luminescence
Light/dark switching (selectable) Light/dark switching (selectable) Light/dark switching (selectable) sensor
Yes/Yes Yes/Yes Yes/Yes Color sensors
Teach-in/Manually using buttons Teach-in/Manually using buttons Teach-in/Manually using buttons Fork sensors
Angle sensors
Dynamic optical
660 nm 660 nm 660 nm windows
Depends on the ber optics Depends on the ber optics Depends on the ber optics Light grids
Orange LED Orange LED Orange LED
Green LED Green LED Green LED Photoelectric
distance
Backlit LCD Backlit LCD Backlit LCD sensors
Channel 1: 0.5 ms Channel 1: 0.5 ms Channel 1: 0.5 ms for analog
distance
Channel 2: 0.6 ms Channel 2: 0.6 ms Channel 2: 0.6 ms measurement
Channel 1: 1kHz Channel 1: 1kHz Channel 1: 1kHz
Channel 2: 833 kHz Channel 2: 833 kHz Channel 2: 833 kHz Special
On/off delay On/off delay On/off delay accessories for
photoelectric
10120 ms selectable 10120 ms selectable 10120 ms selectable sensors
IP 54 IP 54 IP 54
25...+55 C 25...+55 C 25...+55 C
Articial light 10 klx, Articial light 10 klx, Articial light 10 klx,
Sunlight 20 klx Sunlight 20 klx Sunlight 20 klx
ABS ABS ABS
Depends on ber optics Depends on ber optics Depends on ber optics
2 m PVC cable, 24 AWG Pigtail 10 cm, Pigtail 30 cm,

68
www.balluff.com 253
The BOS 6K series also offers a optical ber base unit that is easy
to teach in externally using a button or control line. Together with the
BFO series of ber optics, an enclosure rating of IP 67 is provided.
Features
Teach-in
Contamination indicator
Control line for external teach-in
Disable buttons
Wiring diagrams
BOS 6K-PU-...
BOS 6K-NU-...


code material code
Mounting bracket BAM00UH M8, 4-pin Straight PUR Yellow 2m BCC053Z


Photoelectric
sensors
Photoelectric
standard
Series BOS 6K BOS 6K sensors
Photoelectric
PNP NC/NO Part number BOS 6K-PU-1FR-S75-C BOS 6K-PU-1FR-C-02 sensors
NPN NC/NO Part number BOS 6K-NU-1FR-S75-C BOS 6K-NU-1FR-C-02 Optical ber
base units
Fiber optics
Settings Teach-in Teach-in Fork sensors
Angle sensors
Dynamic optical
Light spot diameter Depends on range/sensing distance Depends on range/sensing distance Light grids
Stability indicator Green LED Green LED Photoelectric
distance
Response time 0.5 ms 0.5 ms sensors
Switching frequency f 1 kHz 1 kHz for analog
distance
No. of wires conductor cross-section 26 AWG measurement
Ambient temperature Ta 20...+60 C 20...+60 C Special
Permissible ambient light EN 60947-5-2 EN 60947-5-2 accessories for
photoelectric
Material Housing ABS ABS sensors
Connection M8 connector, 4-pin 2 m PVC cable


www.balluff.com 255
Optical ber base units BOS 18KF
The optical ber base unit BOS 18KF offers simple operation and
installation.
Features
Sensitivity setting using 270- potentiometer
Cap nut for adapting optical bers
Connector orientation Wiring diagrams
BOS 18KF-PA-...
BN
+UB
BK
WH
BU
0V
BOS 18KF-NA-...
BN
+UB
BK
WH
BU
0V


Description Ordering material code
code 1 2
2 Mounting clamp BAM00T3 M12, 4-pin Angled PUR Yellow 2m BCC05TA


Optical ber base units BOS 18KF
Photoelectric
sensors
Photoelectric
standard
Series BOS 18KF BOS 18KF sensors
Photoelectric
PNP NC/NO Part number BOS 18KF-PA-1FR-S4-C BOS 18KF-PA-1FR-C-02 sensors
NPN NC/NO Part number BOS 18KF-NA-1FR-S4-C BOS 18KF-NA-1FR-C-02 Optical ber
base units
Fiber optics
No-load supply current I0 max. 35 mA 35 mA Contrast sensor
Output current 100 mA 100 mA Luminescence
Switching type Light and dark switching Light and dark switching sensor
Settings Potentiometer, 270 Potentiometer, 270 Fork sensors
Angle sensors
Dynamic optical
Stability indicator Green LED Green LED Photoelectric
distance
Switching frequency f 1 kHz 1 kHz for analog
distance
Degree of protection as per IEC 60529 IP 67 IP 67 measurement
Permissible ambient light EN 60947-5-2 EN 60947-5-2 Special
Material Housing PBT PBT accessories for
photoelectric
Optical surface Depends on ber optics Depends on ber optics sensors

LED LED
www.balluff.com 257
Optical ber base units BOS 18M
Glass Optical Fibers
Type Diffuse sensor, energetic Diffuse sensor, energetic

PNP NC/NO Part number BOS 18M-PA-1PD-E5-C-S4 BOS 18M-PU-1PD-SA5-C
PNP/NPN NC/NO Part number
Switching type Light/dark switching (complementary) Light/dark switching (selectable)
Settings Potentiometer, 270 18-turn potentiometer
Switching frequency f 100 Hz 1 kHz
Optical surface PMMA Glass

Recommended accessories
ly) Suitable connector
code
Mounting clamp BAM00T3
material code
You can nd special accessories for diffuse sensors, such as M12, 4-pin Angled PUR Yellow 2m BCC05TA
reectors, apertures, lenses, lters and deection heads, in M12, 4-pin Angled PVC Yellow 2m BCC05TF

Optical ber base units BOS 18M, 30M
Photoelectric
sensors
Photoelectric
standard
Diffuse sensor Diffuse sensor Diffuse sensor sensors
0...1 m 0...1 m 0...2 m
Photoelectric
BOS 18M-PA-1PF-E5-C-S4 special
BOS 18M-GU-1PF-S4-Y BOS 30M-GA-1PH-S4-C sensors
base units
200 mA 200 mA 200 mA
Fiber optics
20 mA 25 mA 40 mA Contrast sensor
Light/dark switching (complementary) Light/dark switching (selectable) Light/dark switching (complementary) Luminescence
Yes/Yes Yes/Yes Yes/Yes sensor
Potentiometer, 270 18-turn potentiometer 18-turn potentiometer Color sensors
LED, infrared LED, infrared LED, infrared Fork sensors
Angle sensors
880 nm 880 nm 880 nm
Dynamic optical
2.5 ms 0.5 ms 5 ms windows
200 Hz 1 kHz 100 Hz Light grids
IP 67 IP 65 IP 65
5...+55 C 20...+60 C 20...+60 C Photoelectric
distance
5 klx 1 klx 1 klx sensors
Nickel-plated CuZn Nickel-plated CuZn Nickel-plated CuZn for analog
PMMA Glass Glass distance
measurement
Special
accessories for
photoelectric
sensors
56
Wiring diagrams
BOS 18M-PA-... BOS 30M-GA-1PH-S4-C-...
BOS 18M-PU-... BOS 18M-GU-...
www.balluff.com 259
The BOS 16K series also offers a optical ber base unit that offers
mounting versitality and easy set up.
Features
Mounting as block style or 18 mm tubular
Multiple indicators
AC/DC and DC versions
Potentiometer setup
PNP+NPN
Micro
! @
AC Wiring
# ~/+ $
Brown 3 Red/White
~/+ 3 2
Green Gnd
1
Blue Red/Black 1
2
~/- ~/-
Suitable connector
material code
Description Ordering M12, 4-pin Straight PUR Yellow 5m BCC05FE
code M12, 4-pin Straight PVC Yellow 2m BCC05FF
Mounting bracket BAM00UH M12, 4-pin Angled PUR Yellow 2m BCC05TA
1/2" Dual Keyway Straight PVC Yellow 12 ft BCC020C
1/2 Dual Keyway Angled PVC Yellow 15 ft BCC0200


Photoelectric
sensors
Photoelectric
standard
Plastic ber optic base unit for glass ber optics for glass ber optics
Photoelectric
PNP/NPN NO Part number BOS 16K-UU-1FI-00.2-S4 @ BOS 16K-VU-1FI-00.2-S4 @ sensors
Supply voltage UB 11...30 V DC 11...30 V DC Optical ber
base units
Fiber optics
No-load supply current I0 max. 35 mA 35 mA Contrast sensor
Switching type Light/dark switching (selectable) Light/dark switching (selectable) Luminescence
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes sensor
Settings Potentiometer 5 turn Potentiometer 5 turn Color sensors
Emitter, light type LED, infrared LED, infrared Fork sensors
Angle sensors
Dynamic optical
Light spot diameter Depends on range/sensing distance Depends on range/sensing distance windows
Power indicator Green LED Green LED Light grids
Stability indicator Orange LED Orange LED Photoelectric
distance
Response time 1 ms 0.3 ms sensors
Switching frequency f 500 Hz 1.6 kHz for analog
distance
No. of wires conductor cross-section measurement
Degree of protection as per IEC 60529 IP 67; 1200 PSI washdown IP 67; 1200 PSI washdown
Material Housing PPE-PS PPE-PS accessories for
photoelectric
Connection M12 connector, 4-pin, 6 inch pigtail M12 connector, 4-pin, 6 inch pigtail
Ordering codes on page 247. 20.5 20.5

Fiber Retaining Clip Fiber Retaining Clip
Connector orientation 16.5 Fiber Retaining Cap 16.5 Fiber Retaining Cap
12.7 12.7
25.3
25.3

12.2
12.2
24.1 24.1
39.6
39.6
3.5(x2) 3.5(x2)
30.7 30.7
152.4
152.4
www.balluff.com 261
Series BOS 16K BOS 16K

with an outside diameter of 4.8 mm with an outside diameter of 4.8 mm
PNP NO Part number BOS 16K-UU-1FI-02 ! BOS 16K-VU-1FI-02 !
Settings Potentiometer 5 turn Potentiometer 5 turn
Light spot diameter Depends on range/sensing distance Depends on range/sensing distance
Power indicator Green LED Green LED
Stability indicator Orange LED Orange LED
Response time 1 ms 0.3 ms
Switching frequency f 500 Hz 1.6 kHz
No. of wires conductor cross-section 4x22 AWG 4x22 AWG
Material Housing PPE-PS PPE-PS
Connection 2 m PVC cable 2 m PVC cable

Fiber Retaining Cap Fiber Retaining Cap
12.7 12.7
23
23

12.2
12.2

24.1 24.1
39.6
39.6
3.5(x2) 3.5(x2)
30.7 30.7

Photoelectric
sensors
Photoelectric
standard
Photoelectric
2-wire Part number BOS 16K-AU-0F1-00.2-S21 $ BOS 16K-AU-0F1-02 # sensors
Supply voltage UB 22...250 V AC 22...250 V AC Optical ber
base units
Fiber optics
Leakage 1.7 mA 1.7 mA Contrast sensor
Settings Potentiometer 5 turn Potentiometer 5 turn Color sensors
Emitter, light type LED, infrared LED, infrared Fork sensors
Angle sensors
Dynamic optical
Light spot diameter Depends on range/sensing distance Depends on range/sensing distance windows
Power indicator Green LED Green LED Light grids
Stability indicator Orange LED Orange LED Photoelectric
distance
Switching frequency f 60 Hz 60 Hz for analog
distance
No. of wires conductor cross-section 3x22 AWG measurement
Material Housing PPE-PS PPE-PS accessories for
photoelectric
Connection 1/2 x 20 UNF connector 3-pin, 6 inch pigtail 2 meter cable

Connector orientation Fiber Retaining Clip Fiber Retaining Clip
16.5 Fiber Retaining Cap 16.5 Fiber Retaining Cap
12.7 12.7
25.3
25.3
12.2
12.2
24.1 24.1
3.5(x2)
52.3
3.5(x2)
52.3
30.7
30.7
www.balluff.com 263
Series BOS 16K BOS 16K

with an outside diameter of 4.8 mm with an outside diameter of 4.8 mm
PNP/NPN NO Part number BOS 16K-UU-1FR-00.2-S4 @ BOS 16K-VU-1FR-00.2-S4 @
Settings Potentiometer 5 turn Potentiometer 5 turn
Light spot diameter Depends on range/sensing distance Depends on range/sensing distance
Stability indicator Orange LED Orange LED
Response time 1 ms 0.3 ms
Switching frequency f 500 Hz 1.6 kHz
No. of wires conductor cross-section 4x22 AWG 4x22 AWG
Material Housing PPE-PS PPE-PS
Connection M12 connector, 4-pin, 6 inch pigtail M12 connector, 4-pin, 6 inch pigtail

Fiber Retaining Cap Fiber Retaining Cap
12.7 12.7
23
23

12.2
12.2
starting on page 298. 24.1 24.1

39.6
39.6
3.5(x2) 3.5(x2)
30.7 30.7
152.4
152.4

Photoelectric
sensors
Photoelectric
standard
Photoelectric
PNP/NPN NO Part number BOS 16K-UU-1FR-02 ! sensors
2-wire Part number BOS 16K-AU-0FR-00.2-S21 $ Optical ber
base units
Supply voltage UB 11...30 V DC 22...250 V AC/V DC
Fiber optics
No-load supply current I0 max. 35 mA 1.7 mA (Leakage) Luminescence
Settings Potentiometer 5 turn Potentiometer 5 turn Fork sensors
Angle sensors
Dynamic optical
Output function indicator Yellow LED Yellow LED Photoelectric
distance
Stability indicator Orange LED Orange LED sensors
Response time 1 ms 8.3 ms for analog
distance
Switching frequency f 500 Hz 60 Hz measurement
No. of wires conductor cross-section 4x22 AWG
Degree of protection as per IEC 60529 IP 67; 1200 PSI washdown IP 67; 1200 PSI washdown Special
Ambient temperature Ta 20...+70 C 20...+70 C accessories for
photoelectric
Material Housing PPE-PS PPE-PS sensors
Connection 2 m PVC cable 1/2 x 20 UNF connector, 3-pin (2 keys), 6 inch pigtail
Ordering codes on page 247. 16.3 Fiber Retaining Cap

16.3 Fiber Retaining Cap
Connector orientation 12.7 12.7
23
23
12.2
12.2
24.1 24.1
39.6
3.5(x2) 3.5(x2)
52.3
30.7
30.7
www.balluff.com 265
Series BOS 16K

Plastic ber optic base unit for glass ber optics
with an outside diameter of 4.8 mm
2-wire Part number BOS 16K-AU-0FR-02 #
Supply voltage UB 22...250 V AC/V DC
Leakage 1.7 mA
Settings Potentiometer 5 turn
Wavelength 880 nm
Light spot diameter Depends on range/sensing distance
Stability indicator Orange LED
No. of wires conductor cross-section
Degree of protection as per IEC 60529 IP 67; 1200 PSI washdown
Material Housing PPS-PE
Optical surface Depends on ber optics
Connection 2 m PVC cable
Ordering codes on page 247. 16.3 Fiber Retaining Cap

12.7
23

12.2

24.1
3.5(x2)
52.3
30.7

Photoelectric
sensors
Photoelectric
standard
sensors
Photoelectric
special
sensors
Optical ber
base units
Fiber optics
Contrast sensor
Luminescence
sensor
Color sensors
Fork sensors
Angle sensors
Dynamic optical
windows
Light grids
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 267
Fiber Optic Amplier BOS 72K
BOS 72K Advanced Fiber Optic Amplier Features

The BOS 72K ber optic amplier uses the latest microprocessor- Accepts all 2.2 mm diameter ber optic cables
based technology to solve the most difcult applications. It is available Patented EASYtouch pushbutton teach-in process
in a standard style without display as well as a version with display. Remote teach for fast change over
The standard version without display has a 10-bit processor that of- Powerful economical standard version without display
fers over 1000 points of resolution and a fast operational speed up to Display version with over 4000 points of resolution
1000Hz. The version with display offers a 12-bit processor with over Din rail or panel mountable
4000 points of resolution, plus the convenience of a 4-digit display. M8 connector or cable out
The 4-digit display gives a clear indication of the received signal or
threshold value. Applications
Small object detection
Set-up has never been easier with the patented EASYtouchTM Limited mounting space restrictions
pushbutton teach-in process offered on the display version. It features Chemically aggressive environments
two modes of operation standard mode for 1kHz operation and fast High temperature environments
mode for 5kHz operation. Additionally, pushbuttons for + and allow
the user to tweak in the application.
Adjustment Indications
A
A OUTPUT status and READY/ERROR LED
B Teach-in button
C 4 digit display
D STATUS signaling LED
E OUTPUT signaling LED
G B F '+' e '-' buttons (adjust/menu)
D
G Fiber lock/unlock button
E
Wiring Diagrams
PNP PNP
1 1 +V 3 BN +V
2 Teach WH Teach
4 BK
3 BU
0V 0V
NPN NPN
2 1 +V 4 BN +V
2 WH
Teach Teach
4 BK
3 BU
0V 0V

Fiber Optic Amplier BOS 72K
Photoelectric
sensors
Photoelectric
standard
Fiber optic amplier
Photoelectric
special
*High resolution with display sensors
PNP Light-on/Dark-on Part number BOS 72K-PU-RA20-S75 BOS 72K-PU-RA20-02 Optical ber
base units
NPN Light-on/Dark-on Part number BOS 72K-NU-RA20-S75 BOS 72K-NU-RA20-02
Fiber optics
Std. resolution without display Contrast sensor
PNP Light-on/Dark-on Part number BOS 72K-PU-RA10-S75 BOS 72K-PU-RA10-02 Luminescence
NPN Light-on/Dark-on Part number BOS 72K-NU-RA10-S75 BOS 72K-NU-RA10-02 sensor
Supply voltage UB 10...24 V DC 10...24 V DC Color sensors
Output current 100 mA 100 mA Fork sensors
Emitter, light type Visible red 670 nm Visible red 670 nm Angle sensors
Dynamic optical
Operating temperature range 10...+55 C 10...+55 C windows
On/Off delay (standard) 100us High resolution 500us Standard resolution Light grids
Operating frequency (max.) 1Khz High resolution 5Khz standard resolution
Sensitivity adjustment EASY touch Teach-in Remote Teach-in Photoelectric
distance
Function indication Yellow Yellow sensors
Contamination indication 2 bicolor Red/Green LEDs (SET and ERROR) 2 bicolor Red/Green LEDs (SET and ERROR) for analog
distance
Environmental protection IP 67 IP 67 measurement
Housing material ABS ABS
Connection M8 4-pin connector 2 m cable 4x26 AWG Special
accessories for
photoelectric
Ordering codes on page 247. sensors
65

50
6.5
1.5 25.4 3.6

50
Suitable connector side view


material code

www.balluff.com 269
Miniature remote amplier sensors BMOA
BMOA Miniature Remote Amplier Sensors Features

Need the precision of a laser photoelectric sensor, but have no room to Smallest sensing head in the industry
mount something that big? Ultra miniature sensing heads down to 2 mm Laser-like precision to detect targets as small as 0.05 mm
can t into applications where most sensors wont. The BMOA compo- High speed swithching up to 5kHz
nent systems use an amplier to power and control the signals from the 50 ms pulse stretching delay
sensing head, making it a unique alternative to typical ber optic solutions. Simple pushbutton adjustment of dynamic teach function
The BMOA component systems offer maximum exibility with high ex Stability and Output Function LEDs
cable versions for moving applications like robotic arms. The systems can Discrete output versions 0...10 V DC and 4...20 mA
detect targets as small as 0.05 mm. The BMOA ampliers make set-up Din-rail or panel mountable
and operation easy, using a simple dynamic teach function, or a manual
push-button adjustment mode. Available in economical discrete or ad- Applications
vanced analog output versions to solve difcult applications. Thread detection
Small part proling
Robotic end-effectors
Semiconductor component detection
High performance alternative to ber optics
Wiring Diagrams
PNP NPN
! @ Sensitivity setting
AUT the amplier will determine the
( ) best setting for the application.
# MAN this allows you to ne-tune the
.
settings or manually adjust the sensor for
na g tp t ( . )
difcult applications.
na g . .
na g tp t
na g

Miniature remote amplier sensors BMOA
Photoelectric
sensors
Photoelectric
standard
Series BMOA BMOA BMOA sensors
Amplier High speed Standard Advanced Analog Amplier
Photoelectric
special
Discrete output sensors
PNP NO Part number BMO A01-I-PU-C-02 BMO A01-J-PU-C-02 Optical ber
base units
NPN NO Part number BMO A01-I-NU-C-02 BMO A01-J-NU-C-02
Fiber optics
BMO A01-J-PU-C-S75* Contrast sensor
Analog output Luminescence
0...10 V DC Part number BMO A01-H-V1-C-02 sensor
4...20 mA Part number BMO A01-H-C1-C-02 Color sensors
Supply voltage UB 10...30 V DC 10...30 V DC 10...30 V DC Fork sensors
Output current 100 mA 100 mA Angle sensors
Dynamic optical
Analog Output type (voltage) 0...10 V (10 bit) windows
Analog Output type (current) 4...20 V (10 bit) Light grids
Analog Output load (voltage) min. 2k
Analog Output load (current) max. 300 <20 V DC or 600 <20 V DC Photoelectric
distance
Response time 100 s 1 ms 1 ms sensors
Switching frequency 5 kHz 500 Hz 500 Hz for analog
distance
Pulsed/Non-pulsed light source Non-pulsed Pulsed Pulsed measurement
Output function Light/Dark selectable Light/Dark selectable Light/Dark selectable
Operating temperature range 10 C to +55 C 10 C to +55 C 10 C to +55 C Special
Degree of protection per IEC 60529 IP 65 IP 65 IP 65 accessories for
photoelectric
Sensitivity/Range adjustment Teach-in and Manual Teach-in and Manual Teach-in and Manual sensors
Power/Stability indication Green LED Green LED Green LED
Alarm indication Red LED
Output LED Yellow LED Yellow LED 3 Yellow LEDs
Housing material ABS ABS ABS
Connection (to control system) 2 m PVC cable, 3x26 AWG 2 m PVC cable, 3x26 AWG 2 m PVC cable, 4x26 AWG
Recommended connector
*M8, 4-pin connector

15
15
15

Connector orientation 36 36 36
Suitable wired ber optics can

be found starting on page 313.
42.5
42.5
42.5
52
52
52
3.25 (x 2) 3.25 (x 2) 3.25 (x 2)
www.balluff.com 271
Photoelectric Special Sensors Plastic
Plastic ber optics BFO
Fiber Optics
Fiber optics are generally available in a diffuse sensor or through- Another plus
beam design. For complete exibility, there are also ber optics for user assembly;
The diffuse sensors have an integrated emitter and receiver ber at the length of the duplex cable can be trimmed as needed and can
the optical head; the through-beam sensors use two separate opti- be combined with various end ttings as desired.
cal bers.
It is easy to see why optical bers are so commonly used: The Applications
variety of end congurations, with straight or angled light exit, exible Small parts detection
optical head or coaxial ber arrangement, the various ber diameters For tight mounting conditions
and the ability to trim them to the desired length. Inspecting parts features
Counting (e.g. counting drops)
Precise parts positioning
Handling and assembly technology
Robotics

Product overview
Type Length Optical Light exit Fiber Core diameter Features Page
(meters) head arrangement
Bendable optical tip

Extended tempera-
Highly exible
Photoelectric
ture range
Light grid
0.25 mm
sensors
Standard
Ordering code
1.5 mm
1.0 mm
0.5 mm
Straight
Coaxial
Part number
90
Photoelectric
standard
sensors
Through-beam ber optics
BFO005M BFO D22-LA-KB-EAK-10-02 2 M4 274 Photoelectric
special
BFO005T BFO D22-LAH-KB-EAK-10-02 2 M4 274 sensors
BFO005W BFO D22-LAT-KB-EAK-10-02 2 M4 274 Optical ber
BFO005U BFO D22-LAP-KB-EAK-15-02 2 M4 275 base units
BFO0002 BFO D22-LA-TB-EAK-10-02 2 M4 275 Fiber optics
Contrast sensor
BFO005N BFO D22-LA-NB-PZK-10-02 2 M4 275
Luminescence
BFO00AW BFO D22-LAH-BK-EAK-10-02 2 M4 275 sensor
BFO005R BFO D22-LA-RB-EAK-10-02 2 M3 276 Color sensors
BFO000C BFO N22-LA-FB-EAK-05-01 1 M2 276 Fork sensors
BFO00AY BFO D22-LAT-YB-EAK-10-0,5 0.5 3 276 Angle sensors
BFO005P BFO D22-LA-QB-PAK-05-02 2 3 277 Dynamic optical
windows
BFO0056 BFO D13-LA-QB-EAK-05-02 2 3 277
Light grids
BFO0051 BFO D10-LA-CB-EAK-05-02 2 2 277
BFO0057 BFO D13-LA-WB-EAK-05-02 2 2 277 Photoelectric
BFO00AP BFO D22-LA-GD-EAK-52-02 2 1010 278 distance
BFO005H BFO D22-LA-AD-EAK-52-02 2 2010 278 sensors
for analog
BFO005K BFO D22-LA-BD-EAK-52-02 2 1515 278 distance
measurement
BFO0067 BFO D25-LA-CD-EAK-110-02 2 1925 279
BFO00C5 BFO D25-LA-ED-EAK-250-0,5 0.5 1938 279
Special
BFO0068 BFO D25-LA-ED-EAK-250-02 2 1938 279 accessories for
BFB00C8 BFO D25 LA-HD-EAK-465-02 2 2355 279 photoelectric
sensors
BFO0058 BFO D13-LG-05-EAK-30-02 2 1541 280
BFO0059 BFO D13-LG-10-EAK-30-02 2 2032 280
BFO000E BFO D22-LAH-ZB-EAK-10-02 2 54 280
BFO00C6 BFO D10-LAH-CK-EAK-05-02 2 116 281
BFO00C7 BFO D10-LAH-DK-EAK-05-02 2 137 281
Diffuse sensor ber optics

BFO0061 BFO D22-XA-LB-EAK-20-02 2 M6 282
BFO0063 BFO D22-XAH-LB-EAK-20-02 2 M6 282
BFO0065 BFO D22-XAT-LB-EAK-20-02 2 M6 282
BFO0064 BFO D22-XAP-LB-EAK-30-02 2 M6 283
BFO0066 BFO D22-XB-LB-EAK-15-02 2 M6 283
BFO0007 BFO D22-XBF-LB-EAK-15-02 2 M6 283
BFO0004 BFO D22-XA-SB-EAK-20-02 2 M6 283
BFO0005 BFO D22-XA-UB-EAK-20-02 2 M4 284
BFO0006 BFO D22-XB-UB-EAK-15-02 2 M4 284
BFO0055 BFO D10-XAH-KB-EAK-10-02 2 M4 284
BFO005C BFO D13-XB-KB-EAK-10-02 2 M4 285
BFO0053 BFO D10-XA-HB-EAK-10-02 2 M4 285
BFO0054 BFO D10-XA-RB-EAK-10-02 2 M3 285
BFO005E BFO D13-XB-RB-EAK-10-02 2 M3 285
BFO00C3 BFO D10-XA-VB-EAK-10-02 2 M3 285
BFO0052 BFO D10-XA-GB-EAK-10-02 2 M3 286
BFO005A BFO D13-XA-JB-EAK-20-02 2 3 286
BFO0062 BFO D22-XA-MB-PAK-10-02 2 3 286
BFO00AT BFO D13-XB-AB-EAK-10-01 1 2.5 287
BFO00AR BFO D13-XV-AK-EAK-50-02 2 1320 287
BFO005Z BFO D22-XA-CD-EAK-110-02 2 1925 287
BFO0060 BFO D22-XA-ED-EAK-250-02 2 1938 287
www.balluff.com 273
Through-beam Fiber Optics
Optical head M4 thread M4 thread M4 thread

Features Standard Highly exible Temperature rated
Straight light exit Part number BFO D22-LA-KB-EAK-10-02 BFO D22-LAH-KB-EAK-10-02 BFO D22-LAT-KB-EAK-10-02
90 light exit Part number
Sheathing 2.2 mm 2.2 mm 2.2 mm
Core 1 mm 1 mm 1 mm
Fiber length 2m 2m 2m
Fiber bending radius 25 mm 2 mm 25 mm
Head bending radius
Temperature range 55...+70 C 40...+70 C 55...+105 C
Range with BFB 75K-001 500 mm 300 mm 600 mm
with BFB 75K-002* 500 mm 300 mm 600 mm
with BFB 73K 500 mm 300 mm 500 mm
with BFB 18KF 120 mm 90 mm 120 mm
Packaging unit: 2
*Max. range in standard mode

3.5 3.5 3.5
Available lengths on page 273.

Through-beam
Photoelectric
sensors
Photoelectric
standard
M4 thread M4 thread M4 thread M4 thread sensors
Long range Bendable optical tip Bendable optical tip Highly exible
Photoelectric
BFO D22-LAP-KB-EAK-15-02 BFO D22-LA-TB-EAK-10-02 BFO D22-LA-NB-PZK-10-02 special
BFO D22-LAH-BK-EAK-10-02 sensors
2.2 mm 2.2 mm 2.2 mm 2.2 mm Optical ber
base units
1.5 mm 1 mm 1 mm 1 mm
Fiber optics
2m 2m 2m 2m Contrast sensor
40 mm 25 mm 25 mm 2 mm Luminescence
10 mm 10 mm sensor
55...+70 C 30...+60 C 55...+70 C 40...+70 C Color sensors
800 mm 450 mm 500 mm 250 mm Fork sensors
Angle sensors
800 mm 450 mm 500 mm 250 mm
Dynamic optical
800 mm 400 mm 500 mm 250 mm windows
500 mm 200 mm 250 mm 170 mm Light grids
250 mm 110 mm 120 mm 80 mm
Photoelectric
distance
4.1
sensors
7 3
for analog
M4
distance
measurement
8.1
2.6
7.3
M2.6
Special
accessories for
11
3 photoelectric
4
sensors
1.5
www.balluff.com 275
Optical head M3 thread M2 thread 3

Features Standard Precision Temperature rated
Straight light exit Part number BFO D22-LA-RB-EAK-10-02 BFO N22-LA-FB-EAK-05-01
90 light exit Part number BFO D22-LAT-YB-EAK-10-0,5
Sheathing 2.2 mm 1 mm 2.2 mm
Core 1 mm 0.5 mm 1 mm
Fiber length 2m 2m 0.5 m
Head bending radius
with BFB 75K-002* 500 mm 140 mm 600 mm
Packaging unit: 2 1.5

8
12
1
1.5
15
2.6
5
20
1
3
2.9

Through-beam
Photoelectric
sensors
Photoelectric
standard
3 1 mm 2 1.4 mm sensors
Light exit on side Light exit on side Precision Standard
Photoelectric
BFO D10-LA-CB-EAK-05-02 special
BFO D22-LA-QB-PAK-05-02 BFO D13-LA-QB-EAK-05-02 BFO D13-LA-WB-EAK-05-02 sensors
2.2 mm 1.3 mm 1 mm 1.3 mm Optical ber
base units
1 mm 0.5 mm 0.5 mm 1 mm
Fiber optics
2m 2m 2m 2m Contrast sensor
25 mm 15 mm 15 m 25 mm Luminescence
sensor
40...+70 C 35...+65 C 55...+70 C 40...+70 C Color sensors
Angle sensors
120 mm 110 mm 130 mm 75 mm
Dynamic optical
65 mm Light grids
35 mm 25 mm 20 mm
Photoelectric
distance
sensors
for analog
distance
15
measurement
1
0.6
Special
accessories for
photoelectric
sensors
www.balluff.com 277
Optical head 1010 mm 2010 mm 1515 mm

Features Light grid Light grid Light grid
Straight light exit Ordering code BFO D22-LA-GD-EAK-52-02 BFO D22-LA-AD-EAK-52-02
90 light exit Ordering code BFO D22-LA-BD-EAK-52-02
Core 160.25 mm 160.25 mm 160.25 mm
with BFB 75K-002* 600 mm 450 mm 400 mm

2
M
3.5

2.5
2.5
10
1
2.5
1
5
0.25(16x)
5.4
10

Through-beam
Photoelectric
sensors
Photoelectric
standard
Light grid Light grid Light grid Light grid
Photoelectric
BFO D25-LA-CD-EAK-110-02 special
BFO D25-LA-ED-EAK-250-0,5 BFO D25-LA-ED-EAK-250-02 BFO D25 LA-HD-EAK-465-02 sensors
base units
320.25 mm 320.25 mm 320.25 mm 320.25 mm
Fiber optics
2m 0.5 m 2m 2m Contrast sensor
10 mm 60 mm 60 mm 60 mm Luminescence
55...+70 C 55...+70 C 55...+70 C 55...+70 C sensor
600 mm 550 mm 550 mm 550 mm Color sensors
Angle sensors
600 mm 550 mm 550 mm 550 mm
Dynamic optical
230 mm 210 mm 210 mm 210 mm Light grids
Photoelectric
19 distance
12 5.1 5.1 5.1 sensors
for analog
distance
measurement
6
Special
accessories for
photoelectric
sensors
6.2
6.2
6.2
10
10
10
21
21
21
www.balluff.com 279
Optical head 1541 mm 2032 mm 54 mm

Features Fork Fork Highly exible
Straight light exit
90 light exit Part number BFO D13-LG-05-EAK-30-02 BFO D13-LG-10-EAK-30-02 BFO D22-LAH-ZB-EAK-10-02
Core 20.25 mm 20.25 mm 1 mm
with BFB 75K-002* 5 mm 10 mm 300 mm
Packaging unit: 2 5 4
3 2
2
2
15
5
3.5

Through-beam
Photoelectric
sensors
Photoelectric
standard
116 mm 137 mm sensors
Highly exible Highly exible
Photoelectric
special
BFO D10-LAH-CK-EAK-05-02 BFO D10-LAH-DK-EAK-05-02 sensors
1 mm 1 mm Optical ber
base units
0.5 mm 0.5 mm
Fiber optics
2m 2m Contrast sensor
1 mm 1 mm Luminescence
40...+70 C 40...+70 C sensor
55 mm 50 mm Color sensors
55 mm 50 mm Fork sensors
Angle sensors
45 mm 40 mm
Dynamic optical
windows
20 mm 20 mm Light grids
Photoelectric
2.5 6 13 distance
2 8 sensors
4.5
for analog
4
10.5
distance
4
5.5
measurement
7
2.1
2.1
3.6
3.6
Special
4 accessories for
photoelectric
25.5
4
2.2 sensors
15
25.5
2.2
15
www.balluff.com 281
Diffuse Fiber Optics

Features Standard Highly exible Temperature rated
Straight light exit Part number BFO D22-XA-LB-EAK-20-02 BFO D22-XAH-LB-EAK-20-02 BFO D22-XAT-LB-EAK-20-02
Core 21 mm 21 mm 21 mm
Head bending radius
with BFB 75K-002* 150 mm 120 mm 130 mm

Diffuse
Photoelectric
sensors
Photoelectric
standard
M6 thread M6 thread M6 thread M6 thread sensors
Long range Coaxial Coaxial, exible Bendable optical tip
Photoelectric
BFO D22-XAP-LB-EAK-30-02 BFO D22-XB-LB-EAK-15-02 BFO D22-XBF-LB-EAK-15-02 BFO D22-XA-SB-EAK-20-02 special
22.2 mm 22.2 mm 22.2 mm 22.2 mm sensors
21.5 mm 11 mm/160.25 mm 11 mm/160.25 mm 21 mm Optical ber
base units
40 mm 25 mm 5 mm 25 mm
Fiber optics
15 mm Contrast sensor
55...+70 C 55...+70 C 40...+60 C 35...+65 C Luminescence
180 mm 120 mm 110 mm 130 mm sensor
Angle sensors
130 mm 80 mm 70 mm 90 mm
Dynamic optical
Light grids
Photoelectric
distance
4.5 sensors
90
for analog
distance
18
113
measurement
6
23
Special
accessories for
photoelectric
sensors
www.balluff.com 283

Features Standard Coaxial Highly exible
Straight light exit Part number BFO D22-XA-UB-EAK-20-02 BFO D22-XB-UB-EAK-15-02 BFO D10-XAH-KB-EAK-10-02
Sheathing 22.2 mm 22.2 mm 21 mm
Core 21 mm 11 mm/160.25 mm 20.5 mm
Head bending radius
with BFB 75K-002* 120 mm 130 mm 40 mm
with BFB 6K 80 mm 90 mm

21
12
2.8

Diffuse
Photoelectric
sensors
Photoelectric
standard
M4 thread M4 thread M3 thread M3 thread M3 thread sensors
Coaxial Bendable optical tip Standard Coaxial Bendable optical tip
Photoelectric
BFO D13-XB-KB-EAK-10-02 BFO D10-XA-HB-EAK-10-02 BFO D10-XA-RB-EAK-10-02 BFO D13-XB-RB-EAK-10-02 BFO D10-XA-VB-EAK-10-02 special
21.25 mm 21 mm 21 mm 21.25 mm 21 mm sensors
10.5 mm/90.25 mm 20.5 mm 20.5 mm 10.5 mm/90.25 mm 20.5 mm Optical ber
base units
15 mm 15 mm 15 mm 15 mm 15 mm
Fiber optics
10 mm 10 mm Contrast sensor
55...+70 C 55...+70 C 55...+70 C 40...+60 C 55...+70 C Luminescence
60 mm 50 mm 50 mm 60 mm 50 mm sensor
60 mm 50 mm 50 mm 60 mm 50 mm Color sensors
Angle sensors

Dynamic optical
20 mm 10 mm 10 mm 20 mm 10 mm windows
Light grids
Photoelectric
1.5 distance
sensors
for analog
distance
18
measurement
15
2.8 3.8
Special
3.8 3.8
accessories for
photoelectric
sensors
www.balluff.com 285
Optical head M3 thread 3 mm 3 mm

Features Standard Standard Standard
Straight light exit Part number BFO D10-XA-GB-EAK-10-02 BFO D13-XA-JB-EAK-20-02
90 light exit Part number BFO D22-XA-MB-PAK-10-02
Sheathing 21 mm 21.3 mm 21 mm
Core 20.5 mm 21 mm 20.5 mm
Head bending radius 10 mm
with BFB 75K-002* 50 mm 130 mm 35 mm
with BFB 6K
with BFB 18KF 10 mm 50 mm

1.5
3.8

Diffuse
Photoelectric
sensors
Photoelectric
standard
2.5 mm 1320 mm 1925 mm 1938 mm sensors
Coaxial Standard Light grid Light grid
Photoelectric
BFO D13-XB-AB-EAK-10-01 BFO D22-XA-CD-EAK-110-02 special
BFO D13-XV-AK-EAK-50-02 BFO D22-XA-ED-EAK-250-02 sensors
base units
10.5 mm/90.25 mm 21 mm 320.25 mm 320.25 mm
Fiber optics
15 mm 25 mm 25 mm 25 mm Contrast sensor
Luminescence
55...+70 C 55...+70 C 55...+70 C 55...+70 C sensor
50 mm 1...6 mm 100 mm 90 mm Color sensors
50 mm 1...6 mm 100 mm 90 mm Fork sensors
Angle sensors
40 mm 1...6 mm 100 mm 90 mm
Dynamic optical
70 mm 60 mm windows
10 mm 40 mm 30 mm Light grids
Photoelectric
distance
sensors
for analog
distance
13 19 measurement
2.3
1.8 12 5.1
6
11 Special
2.5 accessories for
6
14
photoelectric
2.4
19.7
sensors
7
14
3.7
6.2

6. 3.6
2.6
5
1.3
10.5
4
90
10.5
4
15
2.2
15
0.25(9x)
0.5
2.2
www.balluff.com 287
For customized solutions Fiber Optics
Customized solutions with plastic ber optics for

user assembly
Optical bers can be user-cut to the desired length from a 20 m roll.
This way you only use as much plastic optical ber as you actually
need. Considerable savings, especially if multiple sensors are used.
For simple applications you may not need an end piece. A simple
clamp will sufce. Or for convenience and exibility, select from
among the available end pieces. The plastic optical ber is simply
crimped into the end piece. Tedious gluing is eliminated. The end
piece can be removed at any time. Size 2.24.4 mm duplex cable
Through-beam sensor range 150 mm
with L = 2 m
Cable length 20 m
Ordering code BFO005Y
Part number BFO D22-LD-EAK-10-20
Sheathing 21 mm
Core 2.2 mm
Tension on optical ber and 6N
connection parts at 20 C
Cutting tool BFO CT is included.
Size M4 M4 4 mm/M5 7 mm
Features End piece without lens End piece with lens 90 end piece Adapter lens
Used with BFO D22-LD-EAK-10-.. BFO D22-LD-EAK-10-.. BFO D22-LD-EAK-10-.. BFO D22-LA-BC-10
Range 150 mm 450 mm 150 mm 1500 mm
Ordering code BFO005J BFO005L BFO005F BAM 00NW
Part number BFO D22-LA-BC-10 BFO D22-LA-CC-30 BFO D22-LA-AC-20 BFO 04-PK-1
Material Optical surface Plastic (bers) Glass Glass Glass
Threaded tube Stainless steel Stainless steel Stainless steel Stainless steel
Packaging unit 1 pc. 1 pc. 1 pc. 1 pc.
Range when used

with 2 m plastic ber cable.

Accessories for Photoelectric Sensors
Adapter lens, deection head, focus lens,
adapter, cutting tool
Adapter lens, deection head, focus lens, Photoelectric

adapter and cutting tool are assigned to sensors
accessories, which we mark in gray.
Photoelectric
standard
Description Adapter lens 90 rotatable head Focusing lens Focusing lens sensors
Use For through-beam optical For through-beam optical For coaxial diffuse sensor For coaxial diffuse sensor
Photoelectric
bers M2.60.45 bers M2.60.45 optical bers M40.7 optical bers M40.7 special
Ordering code BAM00NN BAM00NP BAM00NR BAM00NT sensors
Part number BFO 02-PK-1 BFO 02-UK-1 BFO 04-FL-1 BFO 04-FL-2 Optical ber
base units
Sensing distance/range distance 10 0.7 19 mm2 mm 7 mm2 mm
Fiber optics
with corresponding ber optics
Contrast sensor
Packaging unit 2 pcs. 2 pcs. 1 pc. 1 pc. Luminescence
sensor
Color sensors
Fork sensors
Angle sensors
Dynamic optical
windows
Light grids
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Description Adapter Adapter Cutting Tool

Use For plastic ber optics For plastic ber optics For trimming
1 mm for connecting to ber 1.3 mm for connecting to plastic ber optics
optic base units ber optic base units 1 mm or 2.2 mm
Ordering code BAM000J BAM00P1 BAM000E

Part number BFO D10-LA-DC-10 BFO D13-LA-EC-10 BFO CT
Packaging unit 2 pcs. 2 pcs. 1 pc.
www.balluff.com 289
Photoelectric Special Sensors Glass
Glass ber optics BFO 18
Fiber Optics
The BFO 18 series of glass ber optics are designed for series
BOS 18M cylindrical sensors and are used wherever a high level of
function reserve or chemical resistance is required. Likewise, tem-
peratures over 200 C pose no problem.
Various straight or right-angle versions are available with a polyure-

thane jacket, corrugated metal armor or silicon protective jacket.
UZG type MZG type SMG type

Polyurethane jacket Corrugated metal armor Silicon protection jacket
Strain relief Strain relief Corrugated metal armor with
Glass optical ber bundle Glass optical ber bundle strain relief
Glass optical ber bundle
Flexible Resistant to high temperatures Extended temperature range
Excellent chemical 20...+170 C (up to +250 C 40...+150 C
resistance for a xed installation) Highly exible
Does not become brittle from Flexible Crush-resistant
oils and cooling emulsions Crush-resistant
Temperature resistance Resistant to hot swarf
20...+85 C

Product overview
Type Optical head Optical bundle diameter Page
Lenght (meters)
Ordering code
1.0 mm
1.5 mm
2.0 mm
3.0 mm
Straight
Part number Photoelectric
90
sensors
Through-beam ber optics Photoelectric

standard
BFO001Z BFO 18A-LGG-MZG-10-0,5 0.5 2 294 sensors
BFO0020 BFO 18A-LGG-MZG-10-1 1 2 294
BFO0023 BFO 18A-LGG-SMG-10-0,5 0.5 2 294 Photoelectric
special
BFO0024 BFO 18A-LGG-SMG-10-1 1 2 294 sensors
BFO0022 BFO 18A-LGG-MZG-10-2 2 2 294 Optical ber
BFO001P BFO 18A-LFF-MZG-10-0,5 0.5 2 294 base units
BFO001R BFO 18A-LFF-MZG-10-1 1 2 294 Fiber optics
BFO001U BFO 18A-LFF-SMG-10-0,5 0.5 2 294 Contrast sensor
Luminescence
BFO001W BFO 18A-LFF-SMG-10-1 1 2 294 sensor
BFO001Y BFO 18A-LFF-SMG-10-3 3 2 294 Color sensors
BFO000M BFO 18A-LAA-UZG-20-0,5 0.5 M5 295 Fork sensors
BFO000N BFO 18A-LAA-UZG-20-1 1 M5 295 Angle sensors
BFO000R BFO 18A-LAA-UZG-20-2 2 M5 295 Dynamic optical
windows
BFO000T BFO 18A-LAA-UZG-20-3 3 M5 295
Light grids
BFO000F BFO 18A-LAA-MZG-20-0,5 0.5 M5 295
BFO000H BFO 18A-LAA-MZG-20-1 1 M5 295 Photoelectric
BFO000J BFO 18A-LAA-MZG-20-1,5 1.5 M5 295 distance
BFO000L BFO 18A-LAA-MZG-20-3 3 M5 295 sensors
for analog
BFO000Z BFO 18A-LCC-UZG-20-1 1 6 295 distance
measurement
BFO0010 BFO 18A-LCC-UZG-20-1,5 1.5 6 295
BFO000U BFO 18A-LCC-SMG-20-0,5 0.5 6 295
Special
BFO000W BFO 18A-LCC-SMG-20-1 1 6 295 accessories for
BFO001F BFO 18A-LEE-UZG-20-0,5 0.5 6 295 photoelectric
sensors
BFO001H BFO 18A-LEE-UZG-20-1 1 6 295
BFO001K BFO 18A-LEE-UZG-20-2 2 6 295
BFO0013 BFO 18A-LEE-MZG-20-0,5 0.5 6 295
BFO0014 BFO 18A-LEE-MZG-20-1 1 6 295
BFO0016 BFO 18A-LEE-MZG-20-2 2 6 295
BFO0019 BFO 18A-LEE-SMG-20-0,5 0.5 6 295
BFO001C BFO 18A-LEE-SMG-20-1,5 1.5 6 295
BFO003Y BFO 18V-LCC-MZG-23-0,5 0.5 6 295
BFO003Z BFO 18V-LCC-MZG-23-0,75 0.75 6 295
BFO0040 BFO 18V-LCC-MZG-23-1,5 1.5 6 295
BFO0041 BFO 18V-LCC-MZG-23-2,0 2 6 295
BFO0042 BFO 18V-LCC-SMG-23-0,5 0.5 6 295
BFO0043 BFO 18V-LCC-SMG-23-0,75 0.75 6 295
BFO0044 BFO 18V-LCC-SMG-23-1,5 1.5 6 295
BFO0045 BFO 18V-LCC-SMG-23-2 2 6 295
BFO0046 BFO 18V-LCC-SMG-23-3 3 6 295
BFO0047 BFO 18V-LDD-MZG-23-0,75 0.75 6 295
BFO0048 BFO 18V-LDD-MZG-23-1,5 1.5 6 295
BFO0049 BFO 18V-LDD-MZG-23-2,0 2 6 295
BFO004A BFO 18V-LDD-MZG-23-3 3 6 295
BFO00C0 BFO 18V-LDD-MZG-23-5 5 6 295
BFO00C1 BFO 18V-LDD-MZG-23-8 8 6 295
BFO00C2 BFO 18V-LDD-MZG-23-13 13 6 295
BFO004C BFO 18V-LDD-SMG-23-0,5 0.5 6 295
BFO004E BFO 18V-LDD-SMG-23-0,75 0.75 6 295
BFO004F BFO 18V-LDD-SMG-23-1 1 6 295
BFO004H BFO 18V-LDD-SMG-23-1,5 1.5 6 295
BFO004J BFO 18V-LDD-SMG-23-2 2 6 295
BFO004K BFO 18V-LDD-SMG-23-3 3 6 295
www.balluff.com 291
Product overview
Type Optical head Optical bundle diameter
Length (meters)
Ordering code
1.0 mm
1.5 mm
2.0 mm
3.0 mm
Straight
Part number
90
BFO003R BFO 18A-XAG-MZG-15-0,5 0.5 2 296
BFO003T BFO 18A-XAG-MZG-15-1 1 2 296
BFO003U BFO 18A-XAG-MZG-15-1,5 1.5 2 296
BFO003W BFO 18A-XAG-MZG-15-2 2 2 296
BFO003H BFO 18A-XAF-MZG-15-0,5 0.5 2 296
BFO003J BFO 18A-XAF-MZG-15-1 1 2 296
BFO003K BFO 18A-XAF-MZG-15-1,5 1.5 2 296
BFO003L BFO 18A-XAF-MZG-15-2 2 2 296
BFO003M BFO 18A-XAF-SMG-15-0,5 0.5 2 296
BFO003N BFO 18A-XAF-SMG-15-1 1 2 296
BFO003P BFO 18A-XAF-SMG-15-3 3 2 296
BFO002M BFO 18A-XAA-UZG-30-0,5 0.5 M5 297
BFO002N BFO 18A-XAA-UZG-30-1 1 M5 297
BFO002P BFO 18A-XAA-UZG-30-1,5 1.5 M5 297
BFO002R BFO 18A-XAA-UZG-30-2 2 M5 297
BFO002T BFO 18A-XAA-UZG-30-3 3 M5 297
BFO0026 BFO 18A-XAA-MZG-30-0,5 0.5 M5 297
BFO0027 BFO 18A-XAA-MZG-30-1 1 M5 297
BFO0028 BFO 18A-XAA-MZG-30-1,5 1.5 M5 297
BFO002A BFO 18A-XAA-MZG-30-2 2 M5 297
BFO002C BFO 18A-XAA-MZG-30-2,5 2.5 M5 297
BFO002E BFO 18A-XAA-MZG-30-3 3 M5 297
BFO0029 BFO 18A-XAA-MZG-30-12 12 M5 297
BFO002F BFO 18A-XAA-SMG-30-0,5 0.5 M5 297
BFO002H BFO 18A-XAA-SMG-30-1 1 M5 297
BFO002J BFO 18A-XAA-SMG-30-1,5 1.5 M5 297
BFO002K BFO 18A-XAA-SMG-30-2 2 M5 297
BFO002L BFO 18A-XAA-SMG-30-3 3 M5 297
BFO002U BFO 18A-XAC-SMG-30-0,5 0.5 8 297
BFO002W BFO 18A-XAC-SMG-30-1 1 8 297
BFO002Y BFO 18A-XAC-SMG-30-1,5 1.5 8 297
BFO002Z BFO 18A-XAC-SMG-30-2,5 2.5 8 297
BFO0030 BFO 18A-XAC-SMG-30-3 3 8 297
BFO003C BFO 18A-XAE-UZG-30-0,5 0.5 8 297
BFO003E BFO 18A-XAE-UZG-30-1 1 8 297
BFO003F BFO 18A-XAE-UZG-30-2,5 2.5 8 297
BFO0031 BFO 18A-XAE-MZG-30-0,5 0.5 8 297
BFO0032 BFO 18A-XAE-MZG-30-1 1 8 297
BFO0033 BFO 18A-XAE-MZG-30-1,5 1.5 8 297
BFO0034 BFO 18A-XAE-MZG-30-2 2 8 297
BFO0035 BFO 18A-XAE-MZG-30-2,5 2.5 8 297
BFO0036 BFO 18A-XAE-MZG-30-3 3 8 297
BFO0037 BFO 18A-XAE-SMG-30-0,5 0.5 8 297
BFO0038 BFO 18A-XAE-SMG-30-1 1 8 297
BFO0039 BFO 18A-XAE-SMG-30-2 2 8 297
BFO003A BFO 18A-XAE-SMG-30-3 3 8 297
BFO004M BFO 18V-XAC-MZG-30-0,5 0.5 6 297
BFO004P BFO 18V-XAC-SMG-30-0,5 0.5 6 297
BFO004R BFO 18V-XAC-SMG-30-1 1 6 297
BFO004U BFO 18V-XAD-MZG-30-0,5 0.5 6 297
BFO004Y BFO 18V-XAD-SMG-30-0,5 0.5 6 297
BFO004Z BFO 18V-XAD-SMG-30-1 1 6 297

Photoelectric
sensors
Photoelectric
standard
sensors
Photoelectric
special
sensors
Optical ber
base units
Fiber optics
Contrast sensor
Luminescence
sensor
Color sensors
Fork sensors
Angle sensors
Dynamic optical
windows
Light grids
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 293
Through-beam sensor BOS 18M-...-PD-.. Range 100 mm 100 mm

with BOS 18M-...-1PF-... Range 400 mm 400 mm
BOS 30M-... Range
UZG type Part number
MZG type Part number BFO 18A-LGG-MZG-10-_ _ BFO 18A-LFF-MZG-10-_ _
SMG type Part number BFO 18A-LGG-SMG-10-_ _ BFO 18A-LFF-SMG-10-_ _
Glass optical ber bundle diameter 1 mm 1 mm
Max. tension on optical bers and connection parts 80 N 80 N
Min. bending radius 60 mm 60 mm
Can be used with BOS 18M-PA-1PD... Yes Yes
BOS 18M-PU-1PD-SA1.../-SA4.../-SA5... Yes (remove adapter Yes (remove adapter

disk) disk)
BOS 18M-GU-1PF-... Yes (remove adapter Yes (remove adapter
disk) disk)
BOS 18M-PA-1PF-... Yes Yes
BOS 30M-... No No
(use BFO 30-A1 adapter)

Additional lengths available (in 0.5 m increments)! Please submit an inquiry.
Please append the desired length L of the ber optics cable to the ordering code.
Adjustments from 0.5 m to max. 2 m possible.
Example:
BFO 18...-30-0,5 for 0.5 m ber length
BFO 18...-30-2 for 2 m ber length
Important!
With a ber optic through-beam sensor, the base unit's normally open signal
switches to a normally closed signal!
Mounting instruction Remove adapter disk

from ber optics!
BOS 30M with BFO 18V
Adapter BFO 30-A1

Through-beam
Photoelectric
sensors
Photoelectric
standard
200 mm 200 mm 200 mm 200 mm 200 mm sensors
700 mm 700 mm 700 mm
Photoelectric
2000 mm 2000 mm special
BFO 18A-LAA-UZG-20-_ _ BFO 18A-LEE-UZG-20-_ _ BFO 18A-LCC-UZG-20-_ _ sensors
BFO 18A-LAA-MZG-20-_ _ BFO 18A-LEE-MZG-20-_ _ BFO 18V-LCC-MZG-23-_ _ BFO 18V-LDD-MZG-23-_ _ Optical ber
base units
BFO 18A-LCC-SMG-20-_ _ BFO 18A-LEE-SMG-20-_ _ BFO 18V-LCC-SMG-23-_ _ BFO 18V-LDD-SMG-23-_ _
Fiber optics
2 mm 2 mm 2 mm 2 mm 2 mm Contrast sensor
80 N 80 N 80 N 80 N 80 N Luminescence
Yes Yes Yes No No Color sensors
Fork sensors
Angle sensors
Yes (remove adapter Yes (remove adapter Yes (remove adapter Yes (remove adapter Yes (remove adapter
Dynamic optical
disk) disk) disk) disk) disk) windows
Yes (remove adapter Yes (remove adapter Yes (remove adapter No No Light grids
disk) disk) disk)
Yes Yes Yes No No Photoelectric
distance
sensors
No No No Yes (remove adapter Yes (remove adapter for analog
distance
disk) disk) measurement
Special
accessories for
15 photoelectric
sensors
16.6
16.6
www.balluff.com 295
Diffuse sensor with BOS 18M-...-PD-.../BOS 18M-...-1PF-... 10 mm/50 mm 10 mm/50 mm

BOS 30M-...
Retroreective BOS 18M-...-PD-.../BOS 18M-...-1PF-... 300 mm/1000 mm 300 mm/1000 mm
sensor with BOS 30M-...
UZG type Part number
MZG type Part number BFO 18A-XAG-MZG-15-_ _ BFO 18A-XAF-MZG-15-_ _
SMG type Part number BFO 18A-XAF-SMG-15-_ _
Glass optical ber bundle diameter 1.5 mm 1.5 mm
Max. tension on optical bers and connection parts 80 N 80 N
Min. bending radius 60 mm 60 mm
Can be used with BOS 18M-PA-1PD... Yes Yes
BOS 18M-PU-1PD-SA1.../-SA4.../-SA5... Yes (remove adapter Yes (remove adapter

disk) disk)
BOS 18M-GU-1PF-... Yes (remove adapter Yes (remove adapter
disk) disk)
BOS 18M-PA-1PF-... Yes Yes
BOS 30M-... No No
Sensing distance with BOS 18M-PA-1PD... 10 mm 10 mm

BOS 18M-PU-1PD-SA1.../-SA4.../-SA5... 10 mm 10 mm
BOS 18M-...-1PF-... 50 mm 50 mm
BOS 30M-...
Range with BOS 18M-PA-1PD... 300 mm 300 mm
BOS 18M-PU-1PD-SA1.../-SA4.../-SA5... 300 mm 300 mm
BOS 18M-...-1PF-... 1000 mm 1000 mm
BOS 30M-...
Additional lengths available (in 0.5 m increments)!
Please submit an inquiry.
Remove adapter disk

from ber optics!
Mounting instruction
When using sensor BOS18M-GU-1PF-S4-Y or
BOS 18M-PU-1PD-SA..., please remove the adapter
disk from the ber optics.

Diffuse
Photoelectric
sensors
Photoelectric
standard
20 mm/100 mm 20 mm/100 mm 20 mm/100 mm 20 mm 20 mm sensors
200 mm 200 mm
Photoelectric
500 mm/1000 mm 500 mm/1000 mm 500 mm/1000 mm 500 mm 500 mm special
2000 mm 2000 mm sensors
BFO 18A-XAA-UZG-30-_ _ BFO 18A-XAE-UZG-30-_ _ Optical ber
base units
BFO 18A-XAA-MZG-30-_ _ BFO 18A-XAE-MZG-30-_ _ BFO 18V-XAC-MZG-30-_ _ BFO 18V-XAD-MZG-30-_ _
Fiber optics
BFO 18A-XAA-SMG-30-_ _ BFO 18A-XAC-SMG-30-_ _ BFO 18A-XAE-SMG-30-_ _ BFO 18V-XAC-SMG-30-_ _ BFO 18V-XAD-SMG-30-_ _ Contrast sensor
3 mm 3 mm 3 mm 3 mm 3 mm Luminescence
80 N 80 N 80 N 80 N 80 N sensor
Yes Yes Yes No No Fork sensors
Angle sensors
Dynamic optical
Yes (remove adapter Yes (remove adapter Yes (remove adapter Yes (remove adapter Yes (remove adapter windows
disk) disk) disk) disk) disk) Light grids
Yes (remove adapter Yes (remove adapter Yes (remove adapter No No
disk) disk) disk) Photoelectric
distance
Yes Yes Yes No No sensors
for analog
distance
No No No Yes (remove adapter Yes (remove adapter measurement
disk) disk)
20 mm 20 mm 20 mm Special
20 mm 20 mm 20 mm 20 mm 20 mm accessories for
photoelectric
100 mm 100 mm 100 mm sensors
200 mm 200 mm
500 mm 500 mm 500 mm
500 mm 500 mm 500 mm 500 mm 500 mm
1000 mm 1000 mm 1000 mm
2000 mm 2000 mm
M5
4
3
15
8
30
8
L
30
M18x1
20
Sensing distances referenced to a 90% reective Kodak gray card. When being used as a retroreective sensor, twice the switching
Diffuse sensor with glass ber optics as a retroreective sensor: distance must be used as the object dead zone.
Ranges are referenced to BOS R-1 reector.
www.balluff.com 297
Glass ber optics for 16K, 72K, 30M
Product overview Fiber Optics
Type Optical head Jacket Page

material
Lenght (meters)
Stainless steel
Light grid
1.6 mm
2.4 mm
3.2 mm
Straight
Ordering code
PVC
90
Part number

BFO00FH BFO N22-LA-01B-PAG-16-0,9 0.9 2.2 300
BFO00EJ BFO N22-LA-04B-MZG-16-0,9 0.9 5/16" -24 UNF 300
BFO00FW BFO N22-LA-04B-MZG-16-1,8 1.8 5/16 -24 UNF 300
BFO00EM BFO N22-LA-01B-MZG-16-0,9 0.9 2.2 300
BFO00EF BFO N22-LA-03K-MZG-16-0,9 0.9 2.1 301
BFO00EK BFO N22-LA-02K-MZG-16-0,9 0.9 5/16 -24 UNF 301
BFO00EL BFO N22-LA-02B-MZG-16-0,9 0.9 6.3 301
BFO00EN BFO N22-LA-01K-MZG-16-0,9 0.9 4.8 301
BFO00FL BFO N22-LA-02K-PAG-16-0,9 0.9 5/16 -24 UNF 301
BFO00FK BFO N22-LA-02B-PAG-16-0,9 0.9 6.3 302
BFO00FJ BFO N22-LA-01D-PAG-95-0,9 0.9 19.1x25.4 302
BFO00EU BFO N48-LA-02B-PAG-24-0,9 0.9 6.3 302
BFO00EY BFO N48-LA-04K-PAG-32-0,9 0.9 5/16 -24 UNF 303
BFO00EZ BFO N48-LA-03K-PAG-16-0,9 0.9 2.1 303
BFO00ET BFO N48-LA-04B-PAG-32-0,9 0.9 5/16 -24 UNF 303
BFO00FY BFO N48-LA-04B-PAG-32-1,8 1.8 5/16 -24 UNF 303
BFO00EW BFO N48-LA-02D-PAG-95-0,9 0.9 19.1x25.4 303
BFO00CN BFO N48-LA-06B-MZG-32-0,9 0.9 4.8 303
BFO00CZ BFO N48-LA-04B-MZG-32-0,9 0.9 5/16 -24 UNF 304
BFO00FR BFO N48-LA-04B-MZG-32-1,8 1.8 5/16 -24 UNF 304
BFO00CP BFO N48-LA-02B-MZG-24-0,9 0.9 6.3 304
BFO00CT BFO N48-LA-03K-MZG-16-0,9 0.9 2.1 304
BFO00CU BFO N48-LA-01K-MZG-32-0,9 0.9 4.8 305
BFO00CW BFO N48-LA-04K-MZG-32-0,9 0.9 5/16 -24 UNF 305
BFO00E1 BFO N48-LA-02K-MZG-32-0,9 0.9 5/16 -24 UNF 305
BFO00E0 BFO N48-LA-02K-MZG-32-3 3 5/16 -24 UNF 305
BFO00FT BFO N48-LA-02D-MZG-95-1,8 1.8 19.1x25.4 305

Product overview
Type Optical head Jacket Page

material
Lenght (meters)
Stainless steel
Light grid
Photoelectric
1.6 mm
2.4 mm
3.2 mm
Straight
sensors
Ordering code
PVC
90
Part number
Photoelectric
standard
Diffuse sensor ber optics sensors
BFO00EP BFO N22-XC-02B-PAG-16-0,9 0.9 6.3 306
Photoelectric
BFO00FA BFO N22-XC-04B-MZG-16-0,9 0.9 5/16 -24 UNF 306 special
BFO00F9 BFO N22-XC-02K-MZG-16-0,9 0.9 5/16 -24 UNF 306 sensors
BFO00F5 BFO N22-XC-04K-MZG-16-0,9 0.9 5/16 -24 UNF 307 Optical ber
base units
BFO00F8 BFO N22-XC-02B-MZG-16-0,9 0.9 6.3 307
Fiber optics
BFO00F7 BFO N22-XC-06B-MZG-16-0,9 0.9 4.8 307 Contrast sensor
BFO00CM BFO N22-XC-05B-MAK-08-0,9 0.9 M5 307 Luminescence
BFO00F6 BFO N22-XC-02B-MZG-95-0,9 0.9 19.1x25.4 307 sensor
BFO00FZ BFO N48-XC-06B-PAG-32-1,8 1.8 4.8 308 Color sensors
BFO00F4 BFO N48-XC-03K-PAG-16-0,9 0.9 2.1 308 Fork sensors
BFO00F1 BFO N48-XC-02B-PAG-24-0,9 0.9 6.3 308 Angle sensors
Dynamic optical
BFO00F0 BFO N48-XC-02K-PAG-32-0,9 0.9 5/16 -24 UNF 309 windows
BFO00FF BFO N48-XC-03D-PAG-381-0,9 0.9 50.8x38.1 309 Light grids
BFO00EE BFO N48-XC-06B-MZG-32-0,9 0.9 4.8 309
BFO00E6 BFO N48-XC-01B-MZG-16-0,9 0.9 2.1 309 Photoelectric
BFO00EA BFO N48-XC-02K-MZG-32-0,9 0.9 5/16 -24 UNF 309 distance
sensors
BFO00H0 BFO N48-XC-02K-MZG-32-1,8 1.8 5/16 -24 UNF 309 for analog
BFO00E2 BFO N48-XC-03K-MZG-16-0,9 0.9 2.1 310 distance
measurement
BFO00E3 BFO N48-XC-01K-MZG-32-0,9 0.9 4.8 310
BFO00E4 BFO N48-XC-04K-MZG-32-0,9 0.9 5/16 -24 UNF 310 Special
BFO00E9 BFO N48-XC-04B-MZG-32-0,9 0.9 5/16 -24 UNF 311 accessories for
photoelectric
BFO00FU BFO N48-XC-04B-MZG-32-1,8 1.8 5/16 -24 UNF 311 sensors
BFO00EC BFO N48-XC-02B-MZG-24-0,9 0.9 6.3 311
BFO00E7 BFO N48-XC-02D-MZG-95-0,9 0.9 19.1x25.4 311
BFO00FE BFO N48-XC-03D-MZG-381-0,9 0.9 50.8x38.1 311
www.balluff.com 299
Optical head 2.2

2 5/16"
5 -24 UNF 2.2
2
Straight light exit Part number BFO N22-LA-01B-PAG-16-_ _ BFO N22-LA-04B-MZG-16-_ _ BFO N22-LA-01B-MZG-16-_ _
Core 1.6 mm 1.6 mm 1.6 mm
Jacket material PVC Stainless steel Stainless steel
Range with BOS 72K 600 mm 600 mm 600 mm
with BOS 16K
Packaging unit: 2 2.2 2.2

5/16"-24 UNF
38.1 14.2
13
25.4 12.7 14.4
25.4 12.7
4.7 7.9 4.7
7.1 3.2 7.1
14.5
3.2
Available lengths on page 298. L L L
3.4
12.7 28.7
3.9
12.7 28.5
3.9 3.9
12.7 28.5
2.2
2.2 2.2

Through-beam
Photoelectric
sensors
Photoelectric
standard
2.1 5/16 -24 UNF 6.3 4.8 5/16 -24 UNF sensors
BFO N22-LA-03K-MZG-16-_ _ BFO N22-LA-02K-MZG-16-_ _ BFO N22-LA-02B-MZG-16-_ _
Photoelectric
BFO N22-LA-01K-MZG-16-_ _ BFO N22-LA-02K-PAG-16-_ _ special
3.2 mm 3.2 mm 3.2 mm 3.2 mm 3.4 mm sensors
1.6 mm 1.6 mm 1.6 mm 1.6 mm 1.6 mm Optical ber
base units
Stainless steel Stainless steel Stainless steel Stainless steel PVC
Fiber optics
Color sensors
Fork sensors
Angle sensors
7.1
58.9 58.9 Dynamic optical
4.8
2.1
12.7 20.3 38.1 windows

38.1
3.2
Light grids
35.0
20.3 15.2
26.5 12.7
27.9 15.2
20.315.2
6.3 16"-24 UNF 13 7.1 Photoelectric

4.7
5/16"-24 UNF 13 7.1 distance
7.1 7.1 3.4 sensors
3.2 for analog
14.5
L 3.2 L 3.2 L L L distance

3.2 measurement
3.9
12.7 28.7
Special
12.7 28.7
3.9
accessories for
12.7 28.6
3.9
12.7 28.7
3.9
photoelectric
12.7 28.6
3.9 2.2
sensors
2.2
2.20
2.2 2.2
www.balluff.com 301
Optical head 6.3 19.1x25.4 6.3

Straight light exit Part number
90 light exit Part number BFO N22-LA-02B-PAG-16-_ _ BFO N22-LA-01D-PAG-95-_ _ BFO N48-LA-02B-PAG-24-_ _
Sheathing 3.4 mm 3.4 mm 5 mm
Jacket material PVC PVC PVC
with BOS 16K
Packaging unit: 2 7.1 19.1 7.1
3.2
9.5 x 0.1
6.3 19.0
25.4
3.2
35.0
11.9
35.1
6.3
3.4 2-56 3/16" 5.0
L 6.3 L
12.7
3.4 L
3.9
12.7 28.6
3.9
12.7 28.6
15.2
7.1
2.2
2.2 4.8
12.7

Through-beam
Ph
Photoelectric
sensors
se
Photoelectric
Ph
standard
5/16 -24 UNF 2.1 5/16 -24 UNF 19.1x25.4 4.8 sensors
BFO N48-LA-04B-PAG-32-_ _ BFO N48-LA-02D-PAG-95-_ _ BFO N48-LA-06B-MZG-32-_ _
Photoelectric
BFO N48-LA-04K-PAG-32-_ _ BFO N48-LA-03K-PAG-16-_ _ special
base units
PVC PVC PVC PVC Stainless steel
Fiber optics
sensor
Fork sensors
Angle sensors
19.1
12.7
4.8 Dynamic optical
4.8
2.1
20.6 12.7
5/16"-24 UNF 13 windows
38.1 14.2
6.4
Light grids
12.7
9.7 x 0.8 7.1
25.4 12.7
26.9
8.4
19.1
25.4
11.6 6.0
4.7 2-56 x 3/16
Photoelectric
6.0
distance
38.1
7.1
sensors
6.4 for analog
14.4
13.2
6.0 distance
14.2
L L measurement
8.4 6.0
6.0 Special
L accessories for
L L
photoelectric
15.2
sensors
7.1
15.2
7.1
12.7
12.7
4.8 7.1 4.8

15.2
7.1
15.2
7.1
15.2
4.8
12.7
12.7
4.8
12.7
4.8
www.balluff.com 303
Optical head 5/16" -24 UNF 6.3 2.1

Straight light exit Part number BFO N48-LA-04B-MZG-32-_ _
90 light exit Part number BFO N48-LA-02B-MZG-24-_ _ BFO N48-LA-03K-MZG-16-_ _
Sheathing 6 mm 5 mm 6 mm
Jacket material Stainless steel Stainless steel Stainless steel
Range with BOS 72K
with BOS 16K 500 mm 350 mm 140 mm
3.2
2.1
38.1 14.2
5/16"-24 UNF
13
35.0
25.4 12.7
6.4
8.4 4.7
5.0 7.1
14.4
6.0
L L
L
15.2
7.1
7.1
15.2
12.7
4.8
15.2
7.1
12.7
4.8
12.7
4.8

Through-beam
Photoelectric
sensors
Photoelectric
standard
4.8 5/16" -24 UNF 5/16" -24 UNF 19.1x25.4 sensors
BFO N48-LA-02K-MZG-32-_ _
Photoelectric
BFO N48-LA-01K-MZG-32-_ _ BFO N48-LA-04K-MZG-32-_ _ BFO N48-LA-02D-MZG-95-_ _ special
3.2 mm 3.2 mm 3.2 mm Optical ber
base units
Stainless steel Stainless steel Stainless steel Stainless steel
Fiber optics
sensor
Fork sensors
Angle sensors
58.9
4.8
19.1
4.8
20.3 Dynamic optical

20.6 38.1 windows
6.4
Light grids
27.9 15.2
9.7 x 0.8
19.1
11.6
26.9
20.3
7.1 7.1 Photoelectric
25.4 12.7
5/16"-24 UNF 13 2-56 x 3/16
5/16"-24 UNF distance
38.1
14.2
13 6.0 6.3 sensors

6.0 for analog
8.4 6.0 distance
measurement
L
14.2
6.0 L
L L
Special
accessories for
photoelectric
sensors
7.1
15.2
15.2
7.10
7.1
15.2
7.1
15.2
4.8
12.7
4.8
12.7
12.7
4.8 4.8
12.7
www.balluff.com 305
Optical head 6.3 5/16" -24 UNF 5/16" -24 UNF

Straight light exit Part number BFO N22-XC-04B-MZG-16-_ _
90 light exit Part number BFO N22-XC-02B-PAG-16-_ _ BFO N22-XC-02K-MZG-16-_ _
Sheathing 5.0 mm 6 mm 6 mm
Jacket material PVC Stainless steel Stainless steel
with BOS 16K

3.2
7.1
38.1
16"-24 UNF 13 38.1
20.315.2
35.0
14.2
6.5 8.3 5/16"-24 UNF 13
6.0
6.0
L L L
3.4
3.2
3.2
12.7 28.5
4.0
12.7 28.5
4.0
12.7 28.5
4.0
2.2 2.2
2.2

Diffuse
Photoelectric
sensors
Photoelectric
standard
5/16" -24 UNF 6.3 4.8 M33 19.1x25.4 mm sensors
BFO N22-XC-06B-MZG-16-_ _ BFO N22-XC-05B-MAK-08-_ _ BFO N22-XC-02B-MZG-95-_ _
Photoelectric
BFO N22-XC-04K-MZG-16-_ _ BFO N22-XC-02B-MZG-16-_ _ special
6 mm 5 mm 6 mm 6.0 mm 6.0 mm sensors
base units
Stainless steel Stainless steel Stainless steel Stainless steel Stainless steel
Fiber optics
Color sensors
Fork sensors
Angle sensors
20.6
12.7
7.1 4.8 M3x0.5 M3x0.5 (2X) 19.1 Dynamic optical

windows
6.3
M3 (2X)
26.9
3.2
12.2
23.5
Light grids
35.0
12.7
4.8 7.1 4.8 9.7 X 0.8 11.6

6.5
19.1
6.0
25.4
38.1
5/16"-24 UNF 13 5.0 Photoelectric

distance
D 6.3 sensors
14.2
8.4 for analog

6.0 distance
50.8
measurement
2-56 x 3/16"
L L 6.0
L Special
accessories for
L photoelectric
L
sensors
152.4
3.2 4.0
3.2
42.0
29.5
4.0
12.7 28.6
12.7 28.6
4.0
2.1(2X) 3.2
3.2
12.7 28.5
4.0
12.7 28.6
4.0 2.1
2.2
2.1 2.2
www.balluff.com 307
Optical head 4.8 2.1 6.3

Straight light exit Part number BFO N48-XC-06B-PAG-32-_ _
90 light exit Part number BFO N48-XC-03K-PAG-16-_ _ BFO N48-XC-02B-PAG-24-_ _
Sheathing 6 mm 6 mm 5.0 mm
Jacket material PVC PVC PVC
Range with BOS 72K
2.1
4.8 12.7
3.2
12.7
26.5 12.7
*Max. range in standard mode 7.1
35.0
6.0
12.7
4.7 6.3
14.4
6.0
L
L L
6.0
5.0
15.2
7.1
6.0
15.2
7.1 15.2
12.7
4.8
7.1
12.7
4.8 4.8
12.7

Diffuse
Photoelectric
sensors
Photoelectric
standard
5/16" -24 UNF 50.8x38.1 mm 4.8 2.1
21 5/16 -24 UNF sensors
BFO N48-XC-03D-PAG-381-_ _ BFO N48-XC-06B-MZG-32-_ _ BFO N48-XC-01B-MZG-16-_ _
Photoelectric
BFO N48-XC-02K-PAG-32-_ _ BFO N48-XC-02K-MZG-32-_ _ special
6 mm 6.9 mm 6.0 mm 6 mm 6 mm sensors
base units
PVC PVC Stainless steel Stainless steel Stainless steel
Fiber optics
sensor
Fork sensors
Angle sensors
58.9 50.8 4.8 2.1 58.9 Dynamic optical
38.1 38.1 windows
9.5
12.7 12.7
25.4 12.7
25.4 7.1 Light grids
20.315.2
20.315.2
38.1 x .25
6.0 4.7
5/16"-24 UNF 13 7.1
7.10
31.8
5/16"-24 UNF 7.1 Photoelectric

38.1
13
distance
12.7
6.0 6.0 6.0
sensors
12.7
2-56 x 3/16 8.3 for analog

distance
6.9
measurement
L Special
accessories for
L L L photoelectric
sensors
6.0
15.2
6.0 7.1
6.0 6.0
6.0
15.2
7.1 7.1
15.2
15.2
12.7
7.0
4.8
12.7
15.2
7.1 4.8
12.7
4.8
12.7
4.8
4.8
12.7
www.balluff.com 309
Optical head 2.1 4.8 5/16" -24 UNF

Straight light exit Part number
90 light exit Part number BFO N48-XC-03K-MZG-16-_ _ BFO N48-XC-01K-MZG-32-_ _ BFO N48-XC-04K-MZG-32-_ _
Sheathing 6 mm 6 mm 6 mm
Jacket material Stainless steel Stainless steel Stainless steel
Range with BOS 72K

2.1
12.7
26.9
27.9 15.2
4.8
25.4 12.7
4.8
4.7
7.1
38.1
Ordering codes on page 299. 7.1 5/16"-24 UNF
12.7
6.0 13
14.2
6.0 8.4
6.0
L L L
6.0
6.0
6.0
15.2
7.1
15.2
7.1
7.1
15.2
4.8
12.7
12.7
4.8
4.8
12.7

Diffuse
Photoelectric
sensors
Photoelectric
standard
5/16" -24 UNF 6.3 19.1x25.4 mm 50.8x38.1 mm sensors
BFO N48-XC-02D-MZG-95-_ _ BFO N48-XC-03D-MZG-381-_ _
Photoelectric
BFO N48-XC-04B-MZG-32-_ _ BFO N48-XC-02B-MZG-24-_ _ special
6 mm 5 mm 6 mm 6.7 mm sensors
3.2 mm 2.4 mm Optical ber
base units
Stainless steel Stainless steel
Fiber optics
sensor
Fork sensors
Angle sensors
3.2
58.9 7.1 19.1 50.8 Dynamic optical

38.1 windows
6.4
9.5
9.7 x 0.8 11.6 Light grids
20.315.2
35.1
25.4
38.1X0.25
19.1
25.4 12.7
5/16"-24 UNF 13 7.1 2-56 x 3/16

Photoelectric
31.8
38.1
5.0 6.4 distance
6.0 sensors
6.0
for analog
12.7
2-56 X 3/16 8.4
distance
6.7 measurement
Special
accessories for
L L L L photoelectric
sensors
6.0 5.0
15.2
6.0
7.0
7.1
15.2
7.1
15.2
6.0
15.2
12.7
4.8 7.1
12.7
4.8
12.7
4.8
4.8
12.7
www.balluff.com 311
Photoelectric Special Sensors Wire
Fiber Optics

Wire ber optics for BMOA
Product overview
Type Sensing Range Optical Page

head
Cable length
BMO A01-J
Photoelectric
BMO A01-I
PUR cable
PVC cable
sensors
Red light
Ordering code
(meters)
Infrared
Part number
Photoelectric
standard
sensors
BOS005L BMOA 02SM-B200-1 200 mm 80 mm 2.0 1 314 Photoelectric
special
BOS005M BMOA 02SM-B200-F1 200 mm 80 mm 2.0 1 314 sensors
BOS005N BMOA 02SM-B200-R1 200 mm 80 mm 2.0 1 314 Optical ber
BOS0064 BMOA 04SM-B800-1 800 mm 250 mm 4.0 1 315 base units
BOS0065 BMOA 04SM-B800-2 800 mm 250 mm 4.0 2 315 Fiber optics
Contrast sensor
BOS0066 BMOA 04SM-B800-R1 800 mm 250 mm 4.0 1 315
Luminescence
BOS006C BMOA 05TM-B800-1 800 mm 250 mm M5 x 13 1 315 sensor
BOS006E BMOA 05TM-B800-3 800 mm 250 mm M5 x 13 3 315 Color sensors
BOS006F BMOA 05TM-B800-R1 800 mm 250 mm M5 x 13 1 315 Fork sensors
BOS005Y BMOA 03TM-B200-1 200 mm 80 mm M3 x 8 1 315 Angle sensors
BOS005U BMOA 03TM-B200-02 200 mm 80 mm M3 x 8 2 316 Dynamic optical
windows
BOS005W BMOA 03TM-B200-03 200 mm 80 mm M3 x 8 3 316
Light grids
BOS005Z BMOA 03TM-B200-F1 200 mm 80 mm M3 x 8 1 316
BOS0060 BMOA 03TM-B200-F3 200 mm 80 mm M3 x 8 3 316 Photoelectric
BOS0061 BMOA 03TM-B200-R1 200 mm 80 mm M3 x 8 1 316 distance
BOS006T BMOA 66RM-B800-1 800 mm 250 mm 6 x 6 x12 mm 1 317 sensors
for analog
BOS006W BMOA 66RM-B800-R1 800 mm 250 mm 6 x 6 x12 mm 1 317 distance
measurement

Special
BOS005P BMOA 02SM-X12-1 12 mm 3 mm 2.0 1 318 accessories for
BOS005R BMOA 02SM-X12-5 12 mm 3 mm 2.0 5 318 photoelectric
sensors
BOS005T BMOA 02SM-X12-F1 12 mm 3 mm 2.0 1 318
BOS0062 BMOA 03TM-X12-1 12 mm 3 mm M3 x 8 1 318
BOS0063 BMOA 03TM-X12-F1 12 mm 3 mm M3 x 8 1 319
BOS0069 BMOA 05SM-X63-1 63 mm 15 mm 5.0 1 319
BOS006A BMOA 05SM-X63-R1 63 mm 15 mm 5.0 1 319
BOS006K BMOA 06TM-X63-1 63 mm 15 mm M6 x 13 1 319
BOS006L BMOA 06TM-X63-3 63 mm 15 mm M6 x 13 3 319
BOS006M BMOA 06TM-X63-R1 63 mm 15 mm M6 x 13 1 319
BOS0071 BMOA 66RM-X63-R1 63 mm 15 mm 6 x 6 x12 mm 1 321
www.balluff.com 313
Photoelectric Special Sensors Miniature
Remote Sensors
Optical head 2.2 2.2 2.2

Straight light exit Part number BMOA 02SM-B200-1 BMOA 02SM-B200-F1 BMOA 02SM-B200-R1
Emitter light type Infrared Infrared Red light
Wave lenght 880 mm 880 mm 660 mm
Housing material Stainless steel Stainless steel Stainless steel
Sensing face material PMMA PMMA PMMA
Degree of protection IP 67 IP 67 IP 67
Temperature range -10...+55 C -10...+55 C -10...+55 C
Range BMO A01-J 200 mm 200 mm 200 mm
BMO A01-I 80 mm 80 mm 80 mm
Connection 1 m PUR 1 m PUR 1 m PUR
with M8 connector with M8 connector with M8 connector
2.0
2.0
Ordering codes on page 313. 8.0 8.0 12.0 8.0
2.0
2.0
8.0 8.0
2.0
2.0
31.0
31.0
31.0
M8x1 M8x1
M8x1
10.0 10.0
10.0

P
Photoelectric
ssensors
PPhotoelectric
standard
4.0 4.0 M5x13 M5x13 M3x8 sensors
BMOA 04SM-B800-_ BMOA 04SM-B800-R1 BMOA 05TM-B800-_ BMOA 05TM-B800-R1 BMOA 03TM-B200-_
Photoelectric
special
Infrared Red light Infrared Red light Infrared sensors
880 mm 660 mm 880 mm 660 mm 880mm Optical ber
base units
Stainless steel Stainless steel Nickel plated Nickel plated Nickel plated
Fiber optics
PMMA PMMA PMMA PMMA PMMA Contrast sensor
IP 67 IP 67 IP 67 IP 67 IP 67 Luminescence
-10...+55 C -10...+55 C -10...+55 C -10...+55 C -10...+55 C sensor
250 mm 250 mm 250 mm 250 mm 80 mm Fork sensors
Angle sensors
1 m PUR 1 m PUR 1 m PUR 1 m PUR 1 m PUR
Dynamic optical
with M8 connector with M8 connector with M8 connector with M8 connector with M8 connector windows
Light grids
11.0 11.0 11.0 11.0
M3x0.5
M3x0.5
M5x0.5
M5x0.5
M5x0.5
M5x0.5
4.0
4.0
4.0
4.0
8.0 8.0 Photoelectric

13.0 13.0 13.0 13.0 distance
sensors
for analog
distance
7 measurement
7 7
Special
accessories for
photoelectric
sensors
31.0
31.0
31.0
31.0
31.0
M8x1 M8x1 M8x1

10.0 M8x1 M8x1
10.0 10.0
10.0 10.0
www.balluff.com 315
Remote Sensors
Optical head M3x8 M3x8 M3x8

Straight light exit Part number BMOA 03TM-B200-0_ BMOA 03TM-B200-F_ BMOA 03TM-B200-R1
Emitter light type Infrared Infrared Red light
Wave lenght 880 mm 880 mm 660 mm
Housing material Nickel plated Nickel plated Nickel plated
Connection 2 m PUR PVC 1 m PUR
M3x0.5
M3x0.5
M3x0.5
M3x0.5
M3x0.5
M3x0.5
8.0 8.0 8.0 8.0 8.0 8.0
7 7 7
31.0
31.0
31.0
M8x1 M8x1 M8x1

10.0 10.0 10.0

Photoelectric
sensors
Photoelectric
standard
6x6x12 mm 6x6x12 mm sensors
BMOA 66RM-B800-1 BMOA 66RM-B800-R1
Photoelectric
special
Infrared Red light sensors
880 mm 660 mm Optical ber
base units
Nickel plated Nickel plated
Fiber optics
PMMA PMMA Contrast sensor
IP 67 IP 67 Luminescence
-10...+55 C -10...+55 C sensor
800 mm 800 mm Color sensors
250 mm 250 mm Fork sensors
Angle sensors
1 m PUR 1 m PUR
Dynamic optical
with M8 connector with M8 connector windows
Light grids
6.0 6.0
Photoelectric
1.5 6.0 6.0 1.5 6.0 6.0 distance
sensors
for analog
2.0 2.0
distance
2.0 2.0
12.0
12.0
measurement
Special
M2 (2X) M2 (2X) accessories for
2.0 2.0 photoelectric
sensors
31.0
31.0
M8x1 M8x1
10 10
www.balluff.com 317
Remote Sensors
Optical head 2.0 2.0 M3x8

Straight light exit Part number BMOA 02SM-X12-1_ BMOA 02SM-X12-F1 BMOA 03TM-X12-1
Emitter light type Infrared Infrared Infrared
Wave lenght 880 nm 880 nm 880 nm
Housing material Stainless steel Stainless steel Nickel plated
Connection PUR cable 1 m PVC 1 m PUR
Ordering codes on page 313. 2.0 2.0 M3X0.5

8.0
8.0
8.0
7
31.0
31.0
31.0
M8x1 M8x1
M8x1
10.0 10.0
10.0

Photoelectric
sensors
Photoelectric
standard
M3x8 5.0 5.0 M6x13 M6x13 sensors
BMOA 03TM-X12-F1 BMOA 05SM-X63-1 BMOA 05SM-X63-R1 BMOA 06TM-X63-_ BMOA 06TM-X63-R1
Photoelectric
special
Infrared Infrared Red light Infrared Red light sensors
880 nm 880 nm 660 nm 880 nm 660 nm Optical ber
base units
Nickel plated brass Stainless steel Stainless steel Nickel plated brass Nickel plated brass
Fiber optics
PMMA PMMA PMMA PMMA PMMA Contrast sensor
IP 67 IP 67 IP 67 IP 67 IP 67 Luminescence
-10...+55 C -10...+55 C -10...+55 C -10...+55 C -10...+55 C sensor
3 mm 15 mm 15 mm 15 mm 15 mm Fork sensors
Angle sensors
1 m PUR 1 m PUR 1 m PUR 1 m PUR 1 m PUR
Dynamic optical
with M8 connector with M8 connector with M8 connector with M8 connector with M8 connector windows
Light grids
M3X0.5 5.0 5.0 M6X0.5 M6X0.5

Photoelectric
distance
sensors
13.0
13.0
13.0
13.0
for analog
8.0
distance
7 8 measurement
8
Special
accessories for
photoelectric
sensors
31.0
31.0
31.0
31.0
31.0
M8x1
M8x1 M8x1 M8x1 M8x1
10.0
10.0 10.0 10.0 10.0
www.balluff.com 319
Remote Sensors
Optical head 6x6x12 mm

Straight light exit Part number BMOA 66RM-X63-1
Emitter light type Infrared
Wave lenght 880 nm
Housing material Nickel plated brass
Sensing face material PMMA
Degree of protection IP 67
Temperature range -10...+55 C
Range BMO A01-J 63 mm
BMO A01-I 15 mm
Connection 1 m PUR cable
with M8 connector
1.5 6.0
2.0
12.0
M2 (2X)
2.0
2.0
31.0
M8X1
10.0

Photoelectric
sensors
Photoelectric
standard
6x6x12 mm sensors
BMOA 66RM-X63-R1
Photoelectric
special
Red light sensors
660 nm Optical ber
base units
Nickel plated brass
Fiber optics
PMMA Contrast sensor
Luminescence
-10...+55 C sensor
63 mm Color sensors
15 mm Fork sensors
Angle sensors
1 m PUR cable
Dynamic optical
with M8 connector windows
Light grids
6.0
Photoelectric
1.5 6.0 distance
sensors
for analog
2.0
distance
12.0
measurement
M2 (2X)
2.0
Special
2.0 accessories for
photoelectric
sensors
31.0
M8X1
10.0
www.balluff.com 321
Photoelectric Special Sensors Contrast
Contrast sensors BKT
Sensor
Contrast sensors are high-resolution diffuse sensors that distinguish Applications

objects based on their gray values because of that color, brightness Sensing markings on packaging material
and reectivity have a strong effect on the measuring result. Synchronizing cutting or separating processes
The distance should be kept constant because gray values differ Checking for adhesive, ink and color
only slightly. The resolution of the sensor decreases with increasing Position checking of printing templates
sensing distance. Sensing objects based on contrast
Multiple series with various light types and functions are available for
the wide variety of uses for the sensors.

Contrast sensors BKT
Product overview
Type Sensing Light type Output Switch- Switch- US Connection Features Page
distance ing type ing fre-
quency
Red, green and blue light
for adapting ber optics

Photoelectric
sensors
M12 plug, 4-pin
M12 plug, 5-pin

Red, green light
Light switching
M8 plug, 4-pin
Dark switching
NPN transistor
PNP transistor
Analog output
10...30 V DC
Photoelectric
White light
Laser light
Part number sensors
Cable
Photoelectric
special
Contrast sensors sensors
BKT000A BKT 6K-001-P-S75 40...150 mm 1 kHz 325 Optical ber base
units
BKT0008 BKT 6K-001-N-S75 40...150 mm 1 kHz 325 Fiber optics
BKT0009 BKT 6K-001-P-02 40...150 mm 1 kHz 325 Contrast sensor
BKT0007 BKT 6K-001-N-02 40...150 mm 1 kHz 325 Luminescence
sensor
BKT000H BKT 18KF-001-P-S4 10 mm 5 kHz 327 Color sensors
Fork sensors
BKT000F BKT 18KF-001-P-02 10 mm 5 kHz 327
Angle sensors
Dynamic optical
BKT000Y BKT 21M-002-P-S4 19 mm 5 kHz 329 windows
BKT000W BKT 21M-002-N-S4 19 mm 5 kHz 329 Light grids
BKT0001 BKT 67M-001-U-S92 9 mm* 15 kHz 331 Photoelectric

distance
BKT0002 BKT 67M-002-U-S92 9 mm* 15 kHz 331 sensors
BKT0003 BKT 67M-003-U-S92 9 mm* 25 kHz 331 for analog
distance
BKT0004 BKT 67M-004-U-S92 9 mm* 25 kHz 331 measurement
BKT0005 BKT 67M-005-U-S92 9 mm* 30 kHz 331
BKT0006 BKT 67M-006-U-S92 9 mm* 30 kHz 331 Special
accessories for
photoelectric
BKT000N BKT M-15C-U-S4 6...12 mm* 20 kHz 335 sensors
BKT000R BKT M-45-U-S4 0...3 mm 20 kHz 335

BKT000U BKT M-71-U-03 9 mm 20 kHz 333
BKT000T BKT M-52-U-03 ** 20 kHz 333
*Longer sensing distances using interchangeable optics

** Fiber optic dependant
www.balluff.com 323
Photoelectric Special Sensors Laser
Laser contrast sensor BKT 6K
Contrast Sensor
The laser contrast sensor BKT 6K is designed to reliably detect

small areas of contrast variances. Even the narrowest lines can be
detected reliably in the optimum working range of 70...100 mm.
Larger areas are capable of being detected outside this range.
Programming the sensor is easy using a teach-in button or control

line.
Wiring diagrams
! @
# $


code material code
Mounting bracket BAM00UH M8, 4-pin Straight PUR Yellow 5m BCC053Z
You can nd special accessories for diffuse sensors, such as M8, 4-pin Angled PVC Yellow 2m BCC059W
this catalog starting on page 420. Connectors without LED are suitable for PNP and NPN sensors.


Laser contrast sensor BKT 6K
Photoelectric
sensors
Photoelectric
standard
Series BKT 6K BKT 6K sensors
Working distance 40...150 mm* 40...150 mm*
Photoelectric
PNP NC/NO Part number BKT 6K-001-P-S75 @ BKT 6K-001-P-02 ! special
NPN NC/NO Part number BKT 6K-001-N-S75 # BKT 6K-001-N-02 $ sensors
base units
Fiber optics
Contrast sensor
Settings Teach-in Teach-in Color sensors
Emitter, light type Laser, red light Laser, red light Fork sensors
Wavelength 650 nm 650 nm Angle sensors
Dynamic optical
Laser class 2 2 windows
Light spot diameter 0.7 mm at the focus 0.7 mm at the focus Light grids
(85 mm 15 mm) (85 mm 15 mm)
distance
Stability indicator Green LED Green LED sensors
Response time 0.5 ms 0.5 ms for analog
distance
Switching frequency 1 kHz 1 kHz measurement
Permissible ambient light EN 60947-5-2 EN 60947-5-2 accessories for
photoelectric
Material Housing Impact-resistant ABS Impact-resistant ABS sensors
*Optimum working range for small markings:

70...100 mm
3.2 12 3.2 12
4.2
4 4.2
24
32
24
32
8
42
17
9
9
5
10
4
3.8
2.6 2.6
10.7 M8x1 10.7
21 21
www.balluff.com 325
Photoelectric Special Sensors White Light
Contrast sensor BKT 18KF
Contrast Sensor
The contrast sensor BKT 18KF operates with white light and can
be congured simply at just the press of a button. It detects colored
markings as well as gray levels on various surfaces. In the standard
setting the sensor operates using dark switching.
Precise conguration is available for slight contrast differences. The
switching type can also be selected in this setting.
Wiring diagrams Function diagram
BKT 18KF...P...
! @ BN
+UB Relative sensitivity
BK
WH
BU
0V
Sensing
distance


code material code
1 2
1 Mounting bracket BAM00RY M12, 4-pin Straight PUR Yellow 5m BCC05FE
2 Mounting clamp BAM00T3 M12, 4-pin Straight PVC Yellow 2m BCC05FF
You can nd special accessories for diffuse sensors, such as Connectors without LED are suitable for PNP and NPN sensors.

Contrast sensor BKT 18KF
Photoelectric
sensors
Photoelectric
standard
Series BKT BKT sensors
Working distance 10 mm2 mm 10 mm2 mm
Photoelectric
PNP NC/NO Part number BKT 18KF-001-P-S4 ! BKT 18KF-001-P-02 @ special
Supply voltage UB 10...30 V DC 10...30 V DC sensors
No-load supply current I0 max. 25 mA 25 mA Optical ber
base units
Fiber optics
Switching type Light and dark switching Light and dark switching Contrast sensor
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes Luminescence
Settings Teach-in Teach-in sensor
Emitter, light type LED, white light LED, white light Color sensors
Wavelength 400...700 nm 400...700 nm Fork sensors
Angle sensors
Light spot diameter ca. 4.5 mm 10 mm ca. 4.5 mm 10 mm
Dynamic optical
Output function indicator Yellow LED Yellow LED windows
Power/error indicator Green/red LED Green/red LED Light grids
Switching frequency 5 kHz 5 kHz Photoelectric
distance
Degree of protection as per IEC 60529 IP 67 IP 67 sensors
Ambient temperature Ta 25...+55 C 25...+55 C for analog
distance
Permissible ambient light EN 60947-5-2 EN 60947-5-2 measurement
Optical surface PMMA PMMA Special
Connection M12 connector, 4-pin 2 m PVC cable, 26 AWG accessories for
photoelectric
sensors

M18x1 14 M18x1 14
2.5
10
34
34
45
45
81.5
24
77
24
25
25
3.8
3.8
10
LED
M12x1 LED
www.balluff.com 327
Contrast sensors BKT 21M
Contrast Sensor
The BKT 21M contrast sensor uses white light and can be pro-
grammed at the push of a button. It detects colored markings as
well as gray levels on various surfaces. In its standard setting the
sensor is dark switching (markings with less light intensity are de-
tected as the background).
Precise conguration is available for slight contrast differences. The
switching type can also be selected in this setting.

BKT 21M...P.. Relative sensitivity
!
BKT 21M...N..
@
Sensing
Indicators and operating elements distance
1 2 3
1 Output function indicator (yellow)

2 Power-/error indicator (green/red)
3 SET- button

1
code material code
1 Mounting bracket BAM00T9 M12, 4-pin Straight PUR Yellow 5m BCC05FE
2 Mounting bracket BAM00TA 2 M12, 4-pin Straight PVC Yellow 2m BCC05FF
4
4 Clamp holder BAM00TH M12, 4-pin Angled PVC Yellow 2m BCC05TF
reectors, apertures, lenses, lters and deection heads, in More electrical accessories: You can nd a large selection of plug con-
this catalog starting on page 420. lengths in our Industrial Networking and Connectivity catalog.

Photoelectric
sensors
Photoelectric
standard
Series BKT sensors
Working distance 19 mm2 mm
Photoelectric
PNP NC/NO Part number BKT 21M-002-P-S4 ! special
NPN NC/NO Part number BKT 21M-002-N-S4 @ sensors
Supply voltage UB 10...30 V DC Optical ber
base units
Fiber optics
Output current 100 mA Contrast sensor
Switching type Light/dark switching (adjustable in precise mode) Luminescence
Polarity reversal/short-circuit protected Yes/Yes sensor
Settings Teach-in Color sensors
Emitter, light type LED, white light Fork sensors
Angle sensors
Wavelength 400...700 nm
Dynamic optical
Light spot diameter ca. 3.5 mm 19 mm windows
Output function indicator Yellow LED Light grids
Power/error indicator Green/red LED
Response time 0.1 ms Photoelectric
distance
Switching frequency 5 kHz sensors
Time function 20 ms off-delay for analog
distance
Degree of protection as per IEC 60529 IP 67 measurement
Permissible ambient light EN 60947-5-2 Special
Material Housing GD-Zn/Al accessories for
photoelectric
Optical surface Glass sensors
www.balluff.com 329
Photoelectric Special Sensors R-G-B
Contrast Sensor
Wiring diagram
! 1
+US
2 Dark/Light
5 GY
Remote connection
4
NPN/PNP output
3 BU 0V

1. Output function indicator
2. Power indicator
287 5($'<
1 2 3. SET button
6(7
3 Series
Working distance
2 3 PNP and NPN transistor (selectable)
1. Output function indicator Vertical light spot Part number
2. Power indicator
287 5($'<
4 3. Time delay indicator PNP and NPN transistor (selectable)

1
5 4. Button status indicator Part number
Horizontal light spot
6(7 5. Switching threshold level indicator
6. + button Supply voltage UB
7. SET button
8. - button
Output current
8 7 6
Switching type
3
24 Analog output
1. Output function indicator Polarity reversal/short-circuit protected
2. Power indicator
5'<
3. Time delay indicator Settings
1 5 4. Button status indicator
SET 5. Scattered quantity of light indicator
Additional function
6. + button Emitter, light type
7. SET button
8. - button
Wavelength
Light spot diameter
8 7 6
Power/error indicator
Relative responsiveness based on object distance Time function display
Response time
With lens Switching frequency
BAM0121 or
standard lens BAM00P2 Time function
With lens Permissible ambient light
BAM0120
Material Housing
Optical surface
Connection
*Longer sensing distance using interchangeable

eable optics

40

Description Focal Ordering 1 2 Size Design Cable Color Length Ordering

length/focus code material code
1 Lens 18 mm BAM0120 M12, 5-pin Straight PUR Black 5m BCC098C
2 Lens 9 mm BAM0121 3 4 M12, 5-pin Angled PUR Black 5m BCC08FC
3 Lens 28 mm BAM0122
4 Lens 50 mm BAM00P3 5
5 Intermediate BAM00P2
ring
reectors, apertures, lenses, lters and deection heads, in More electrical accessories: You can nd a large selection of plug con-
this catalog starting on page 420. lengths in our Industrial Networking and Connectivity catalog.

Photoelectric
sensors
Photoelectric
standard
BKT BKT BKT sensors
9 mm* 3 mm 9 mm* 3 mm 9 mm* 3 mm
Photoelectric
special
BKT 67M-001-U-S92 ! BKT 67M-003-U-S92 ! BKT 67M-005-U-S92 ! sensors
Optical ber
base units
BKT 67M-002-U-S92 ! BKT 67M-004-U-S92 ! BKT 67M-006-U-S92 !
Fiber optics
10...30 V DC 10...30 V DC 10...30 V DC Contrast sensor
100 mA 100 mA 100 mA sensor
Light/Dark (automatic) Light/Dark (automatic) Light/Dark (automatic) Color sensors
1...3 V 1...3 V Fork sensors
Angle sensors
Dynamic optical
Teach-in button 3 teach-in buttons 3 teach-in buttons windows
Segment display 4-digit display Light grids
Red, green and blue light Red, green and blue light Red, green and blue light
630 nm/520 nm/465 nm 630 nm/520 nm/465 nm 630 nm/520 nm/465 nm Photoelectric
distance
1.55 mm 1.55 mm 1.55 mm sensors
distance
Green LED Green LED Green LED measurement
Orange LED
33 S 25 S 17 S Special
15 kHz 20 kHz 30 kHz accessories for
photoelectric
20 ms (can be activated) sensors
IP 67 IP 67 IP 67
10...+55 C 10...+55 C 10...+55 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Al Al Al
PMMA PMMA PMMA
28 43.4 28 43.4 28 43.4

M12x1
M12x1
M12x1
22
32
32
22
22
32
4x
4xM5
4xM5
5
5
M
5
16.5 28 38.6 32
16.5 28 38.6 32 16.5 28 38.6 32
3
15.8
3 3
60
2x
287 5($'<
M
40
15.8
15.8
25
5
6(7
2x
2x
60
60
287 5($'< 5'<

M
M
40
40
25
25
6(7
5
6(7
4.1
15.8
4.1
4.1
24.9 15.8 15.8

79
24.9 24.9
79 79
www.balluff.com 331
Contrast sensor BKT M
Contrast Sensor
The BKT M... series of contrast sensors are also available with
white light. Models with either a round light spot or an optical ber
connection are available.
Features
Round light spot
White light
Automatic setting of light/dark switching
Time delay and key lock
Interchangeable optics (straight and 90)
Analog output
Function diagrams
Standard lens
(9 mm)
With lens
BKT M-PK-1
(18 mm) Optical bers
Relative sensitivity (%)
40
Working distance (mm)
Wiring diagram
BKT M...
! @ %1
8%
PNP/NPN :+
313131
Analog output *<
9
%8
9
5'
5(027($
2*
5(027(%

Description Ordering Size

S Design Cable Color Length Ordering
1 Optical bers BFO0008 2 M12,
M 4-pin Straight PUR Yellow 5m BCC05FE
2 Lens BAM0120 M12,
M 4-pin Straight PVC Yellow 2m BCC05FF


Photoelectric
sensors
Photoelectric
standard
Working distance 9 mm 3 mm
Working distance with lens PK-1 18 mm 4 mm Photoelectric
special
Working distance with optical bers (diffuse) 0...3 mm sensors
PNP/NPN NC/NO Round spot Part number BKT M-71-U-03 @ Optical ber
base units
Fiber optics
PNP/NPN NC/NO for optical Part number BKT M-52-U-03 @ Contrast sensor
bers Luminescence
Supply voltage UB 10...30 V DC 10...30 V DC sensor
No-load supply current I0 max. 80 mA 80 mA Color sensors
Switching type Light/dark switching (selectable) Light/dark switching (selectable) Angle sensors
Dynamic optical
Analog output 0...5.5 V DC* 0...5.5 V DC* windows
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes Light grids
Additional function Disable buttons Disable buttons Photoelectric
distance
Emitter, light type LED, green light/red light LED, white light sensors
Wavelength 526...630 nm 400...700 nm for analog
distance
Ready indicator Green LED Green LED measurement
Response time 25s 25s Special
Switching frequency 20 kHz 20 kHz accessories for
photoelectric
Time function 20 ms off-delay selectable 20 ms off-delay selectable sensors

Material Housing GD-Zn GD-Zn
Connection 6x22 AWG 6x22 AWG
58.0 31.0
2.5 V DC with 90% reective Kodak gray card
4.3 42.2 25
5.9

14.1
36.6
27.5
82.8
28.0
28.0
M5
24.0
d=6
39.8
(4x
M5
8.5
)
d=6
21.0
(2x)
www.balluff.com 333
Contrast Sensor

Photoelectric
sensors
Photoelectric
standard
Working distance 9 mm 3 mm
Photoelectric
Working distance with lens PK-1 18 mm 4 mm special
Working distance with optical bers (diffuse) 0...3 mm sensors
PNP/NPN NC/NO Round spot Part number BKT M-15C-U-S4 ! Optical ber
base units
Fiber optics
PNP/NPN NC/NO for optical Part number BKT M-45-U-S4 ! Contrast sensor
bers Luminescence
Supply voltage UB 10...30 V DC 10...30 V DC sensor
No-load supply current I0 max. 80 mA 80 mA Color sensors
Angle sensors
Dynamic optical
Analog output 0...5.5 V DC* 0...5.5 V DC* windows
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes Light grids
Additional function Disable buttons Disable buttons Photoelectric
distance
Emitter, light type LED, green light/red light LED, white light sensors
Wavelength 526...630 nm 400...700 nm for analog
distance
Ready indicator Green LED Green LED measurement
Response time 25s 25s Special
accessories for
Switching frequency 20 kHz 20 kHz photoelectric
Time function 20 ms off-delay selectable 20 ms off-delay selectable sensors

Connection M12 4-pin M12 4-pin
2.5 V DC with 90% reective Kodak gray card
www.balluff.com 335
Photoelectric Special Sensors Luminescence
Luminescence sensors BLT
Sensors
Luminescence (UV) sensors can detect invisible marks that so not Applications
appear to the naked eye without a black light. They are used to Logistics (marking, selecting)
detect grease, glue on boxes, and luminescent plastic safety seals Assembly (guiding, monitoring, sorting)
on bottles. Packaging machines
(to monitor cutting, folding)
Ceramics industry (e.g. positioning parts)
Wood industry (e.g. checking the glue bead)
Pharmaceuticals (control tasks in the manufacturing process)
Textiles (e.g. guiding cuts)
Food industry

Luminescence sensors BLT
Product overview
Type Sensing Light type Output Switching Switching US Connec- Page

distance type frequency tion
Photoelectric
sensors
M12 plug, 4-pin

Light switching
Dark switching
NPN transistor
PNP transistor
Analog output
10...24 V DC
10...30 V DC
Photoelectric
UV light
Part number sensors
Cable
Photoelectric
special
Luminescence sensors sensors
BLT0004 BLT 18KF-001-P-S4 8...20 mm 1 kHz 339 Optical ber
base units
BLT0003 BLT 18KF-001-P-02 8...20 mm 1 kHz 339 Fiber optics
Contrast sensor
BLT0009 BLT 21M-001-P-S4 0...40 mm 2 kHz 341 Luminescence
BLT0008 BLT 21M-001-N-S4 0...40 mm 2 kHz 341 sensor
Color sensors
Fork sensors
Angle sensors
Dynamic optical
windows
Light grids
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 337
Luminescence sensors BLT 18KF
Sensors
The luminescence sensor BLT 18KF detects any type of lumines-

cent markings on any surface and automatically adjusts to ambient
conditions. The sensor is calibrated with the simple push of a button.
A precise setting is available for slightly luminescent markings. The
switching type can be freely selected in this case.
Function diagram
Relative sensitivity
Sensing
distance
Wiring diagrams
BLT 18KF...P...
BN
! @ BK
+UB
WH
BU
0V


1
1 Mounting bracket BAM00RY M12, 4-pin Straight PUR Yellow 5m BCC05FE
2 Mounting clamp BAM00T3 M12, 4-pin Straight PVC Yellow 2m BCC05FF

Luminescence sensors BLT 18KF
Photoelectric
sensors
Photoelectric
standard
Series BLT BLT sensors
Working range 8...20 mm 8...20 mm
Photoelectric
PNP NC/NO Part number BLT 18KF-001-P-S4 ! BLT 18KF-001-P-02 @ special
No-load supply current I0 max. 25 mA 25 mA Optical ber
base units
Fiber optics
Switching type Light and dark switching Light and dark switching Contrast sensor
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes Luminescence
Settings Teach-in Teach-in sensor
Emitter, light type LED, UV LED, UV Color sensors
Wavelength 370 nm 370 nm Fork sensors
Angle sensors
Dynamic optical
Output function indicator Yellow LED Yellow LED windows
Power/error indicator Green/red LED Green/red LED Light grids
Switching frequency 1 kHz 1 kHz Photoelectric
distance
Ambient temperature Ta 25...+55 C 25...+55 C for analog
distance
Permissible ambient light EN 60947-5-2 EN 60947-5-2 measurement
Optical surface PMMA PMMA Special
Connection M12 connector, 4-pin 2 m PVC cable, 26 AWG accessories for
photoelectric
sensors

M18x1 14 M18x1 14
2.5
10
34
34
45
45
81.5
24
77
24
25
25
3.8
3.8
10
LED
M12x1 LED
www.balluff.com 339
Luminescence sensors BLT 21M
Sensors
The luminescence sensor BLT 21M detects any type of luminescent

markings on any surface and automatically adjusts to ambient condi-
tions. The sensor is calibrated with the simple push of a button.
A precise setting is available for slightly luminescent markings. The
switching type can be freely selected in this case.
BLT 21M...P.. Relative sensitivity

!
BLT 21M...N..
@
Sensing
distance
1 2 3
1 Output function indicator (yellow)
2 Power-/error indicator (green/red)
3 SET- button

1
code material code
1 Mounting bracket BAM00T9 M8, 4-pin Straight PUR Yellow 5m BCC05FE
2 Mounting bracket BAM00TA M8, 4-pin Straight PVC Yellow 2m BCC05FF
2 4
4 Clamp holder BAM00TH M8, 4-pin Angled PVC Yellow 2m BCC05TF


Luminescence sensors BLT 21M
Photoelectric
sensors
Photoelectric
standard
Series BLT sensors
Working range 0...40 mm
Photoelectric
PNP NC/NO Part number BLT 21M-001-P-S4 ! special
NPN NC/NO Part number BLT 21M-001-N-S4 @ sensors
Supply voltage UB 10...30 V DC Optical ber
base units
Fiber optics
Output current 100 mA Contrast sensor
Switching type Light and dark switching (adjustable in precise mode) Luminescence
Polarity reversal/short-circuit protected Yes/Yes sensor
Settings Teach-in Color sensors
Emitter, light type LED, UV Fork sensors
Angle sensors
Wavelength 370 nm
Dynamic optical
Light spot diameter ca. 1.5 mm at 10 mm windows
Output function indicator Yellow LED Light grids
Power/error indicator Green/red LED
Response time 250 s Photoelectric
distance
Switching frequency 2 kHz sensors
Time function 20 ms off-delay for analog
distance
Degree of protection as per IEC 60529 IP 67 measurement
Permissible ambient light EN 60947-5-2 Special
accessories for
Material Housing GD-Zn/Al photoelectric
Optical surface Glass sensors
www.balluff.com 341
Photoelectric Special Sensors Color Sensors
Color sensors BFS
Applications
Color sensors open up a wide range of various applications, such as
in the packaging industry, robotics, automation, quality assurance or
in the process industry.
Versatile color sensors can be used to simplify and speed up auto-
mated processes, for detecting color nuance in rugs and textiles or
for color markings on packaging or labels.
The BFS 26K and BFS 27K series of color sensors operate using
pulsed white light, making them particularly insensitive to ambient
light. The light reected back from the object is received and pro-
cessed by three different receivers (red, green, blue).
The various light spot geometry congurations of the respective

sensors (round, rectangular or square) can reliably detect even the
smallest color markings.
Numerous special functions such as color scanning, pulse expan-
sion and blanking input provide additional application exibility.
Features
Microcontroller-based
Pulsed white light
Various light spot geometries
3 different colors can be identied at the same time
5-stage adjustable color tolerance

Color sensors BFS
Product overview
Type Sensing Light Output Switch- Switch- US Connection Special Page

distance/ type ing type ing fre- features
Range quency
Color intensity measurement

Photoelectric
sensors
3PNP transistor
RS 232 interface
RS485 interface
M12 plug, 8-pin

M12 plug, 5-pin
Light switching
Dark switching
10...30 V DC
12...28 V DC
18...30 V DC
3Push-pull
Photoelectric
White light
Color scan
Ordering code
True color
standard
Part number sensors
Cable
24 V
Photoelectric
special
Color sensors sensors
BFS0001 BFS 26K-PS-L01-S115 12...32 mm 500 Hz 345 Optical ber
base units
BFS0002 BFS 26K-PS-L02-S115-C 15...30 mm 500 Hz 345 Fiber optics
BFS0003 BFS 26K-PS-L03-S115-C 18...22 mm 500 Hz 345 Contrast sensor
BFS000F BFS 26K-GI-L04-S92 12...32 mm 500 Hz 345 Luminescence
sensor
BFS000L BFS 33M-GSS-F01-PU-02 400 mm 1.5 kHz 347 Color sensors
Fork sensors
Angle sensors
Dynamic optical
windows
Light grids
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 343
Color sensors BFS 26K

Power-on indicator
Channel indicator 1 2 34
Conf.
1. Power-on indicator
C S +/F
SET
2. Output function indicator/teach-in indicator
Tol.C
Tol.I ESC 3. Teach-in indicator (color range)

4. Teach-in indicator (special function)
Toggle button 5 6 7 5. Tolerance level/special function
SET button 6. Setting, teaching in
Tolerance level indicator
7. Advancing
Series
Wiring diagrams Working range
Diffuse mode working range
BFS 26K-PS...
Two modes are available.
Retroreective working range
1. Normal mode "factory setting" 3 PNP Ordering code
+US Part number
Scan input 1 Push-pull, IO-Link Ordering code
Part number
Supply voltage UB
0V
Output current
Switching type
2. External Teach-in
setting using "special functions" Polarity reversal/short-circuit protected
+US Settings
Scan input
Emitter, light type
External teach-in Light spot geometry
Conrm Light spot diameter
0V
Sensing distance tolerance
Color resolution tolerance
Disabling input:
> 12 V = Buttons locked, Ready indicator
< 3 V = Buttons not locked Output function indicator Ch. 1...Ch. 3
Output function indicator Tol. 1...Tol. 5
BFS 26K-GI...
1 +US
Ready delay
5 Trigger Response time
2 Teach
4 PNP-L/NPN-D, IO-Link
Switching frequency
3 0V Time function

Color resolution/sensing distance diagram Ambient temperature Ta
Color resolution
Material Housing
Optical surface
> 20% remission
Connection
BFS 26K...-L03... BFS 26K...-L01...

BFS 26K...-L02...
Sensing
distance

code material code
Mounting bracket BAM00TK M12, 8-pin Straight PUR Black 2m BCC06K1
M12, 8-pin Angled PUR Black 2m BCC06K4
M12, 5-pin Straight PUR Black 2m BCC08FE
M12, 5-pin Angled PUR Black 2m BCC09H7

Color Sensors BFS 26K
Photoelectric
sensors
Photoelectric
standard
BFS 26K BFS 26K BFS 26K BFS 26K sensors
Photoelectric
12...32 mm 15...30 mm 18...22 mm 12...32 mm special
50...200 mm sensors
BFS0001 BFS0002 BFS0003 Optical ber
base units
BFS 26K-PS-L01-S115 BFS 26K-PS-L02-S115-C BFS 26K-PS-L03-S115-C
Fiber optics
BFS000F Contrast sensor
BFS 26K-GI-L04-S92 Luminescence
12...28 V DC 12...28 V DC 12...28 V DC 18...30 V DC sensor
40 mA 40 mA 40 mA 40 mA Color sensors
100 mA 100 mA 100 mA 100 mA Fork sensors
Angle sensors
Light switching Light switching Light switching Light/dark switching (selectable)
Dynamic optical
Yes/Yes Yes/Yes Yes/Yes Yes/Yes windows
Teach-in Teach-in Teach-in Teach-in Light grids
Pulsed white light Pulsed white light Pulsed white light Pulsed white light
Round Square Rectangular Round Photoelectric
distance
4 mm at 22 mm sensing distance 22 mm at 22 mm sensing distance 51 mm at 22 mm sensing distance 4 mm at 22 mm sensing distance sensors
6 mm at Tol.3 5 mm at Tol.3 2 mm at Tol.3 6 mm at Tol C3 and Tol I2 for analog
distance
Adjustable in 5 levels Adjustable in 5 levels Adjustable in 5 levels measurement
3Yellow LED 3Yellow LED 3Yellow LED Special
accessories for
3Red LED 3Red LED 3Red LED photoelectric
300 ms 300 ms 300 ms 300 ms sensors
1 ms 1 ms 1 ms
500 Hz 500 Hz 500 Hz 500 Hz (SIO mode)
50 ms release delay 50 ms release delay 50 ms release delay 50 ms release delay
selectable selectable selectable selectable
IP 67 IP 67 IP 67 IP 67
10...+55 C 10...+55 C 10...+55 C 10...+55 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PMMA PMMA PMMA PMMA
Receiver Emitter
Receiver Emitter
14.2
14.2
Rotates 270 C S +/F

Conf.
Rotates 270
Tol.C SET
Tol.I ESC
www.balluff.com 345
True color sensor BFS 33M
For distinguishing between the smallest of color nuances at Features

the highest level Detection of and distinguishing between a random number of
The True Color sensor BFS 33M is in a completely different league to colors
conventional RGB sensors. Thanks to its high resolution, it not only Reliably distinguishes between the smallest of color nuances
detects colors but can also reliably distinguish between nuances. Large sensing distance up to 400 mm
The True Color sensor thus detects, for instance minimal color devi- Simple conguration and visualization using software
ations in injection molded parts. And it can also tell if a metal enters Robust metal housing
production polished or unpolished. Faded colors or poor print quality
are detected in an instant and separated. It thus opens up complete- Industries
ly new dimensions in quality control. The sensor uses three digital Automotive industry
outputs and a serial interface to perform evaluations. The lab color Plastics processing
space values are transmitted directly via this interface. Packaging industry
Printing industry
Wood processing
1
code
1 Optical ber M4 (coaxial), 2 m long BFO00C9
2 Optics (short-range), 7 mm, BAM00NT
screwed onto M4 2
optical ber
3 Optical ber M6 (coaxial), 1 m long BFO00FP
4 Optical ber M6 (coaxial), 2 m long BFO00C4 35
5 Optical ber M6 (coaxial), 5 m long BFO00FN
6 Optics (adjustable), BAM01U2 6
200 mm sensing distance, 7
screwed onto M6 optical ber
7 Optics (long-range), BAM01PA 8
400 mm sensing distance,
screwed onto M6 optical ber
8 Interface cable (shielded) BCC0ARP
9 RS232/USB interface converter BAE009A
9

True color sensor BFS 33M
Photoelectric
sensors
Photoelectric
standard
Series BFS 33M sensors
Working range up to 400 mm (with additional optics)
3 Push-pull Ordering code BFS000L Photoelectric
special
RS 232 interface Part number BFS 33M-GSS-F01-PU-02 sensors
Supply voltage UB 24 V DC 10% Optical ber
base units
Fiber optics
Contrast sensor
Polarity reversal/short-circuit protected Yes/Yes Luminescence
Settings via software sensor
Emitter, light type LED, white light Color sensors
Color space CIELab Fork sensors
Light spot diameter Depends on the ber optics Angle sensors
Dynamic optical
Color resolution tolerance Adjustable (software) windows
Resolution 8 amplier stages of 12 bits each Light grids
Color resolution < 0.5 dE
Repeat accuracy < 1 dE Photoelectric
distance
Ready indicator Green LED sensors
Output function indicator Ch. 1...Ch. 3 3 Yellow LED (binary encoding) for analog
distance
Response time 0.33 ms measurement
Switching frequency 1.5 kHz
Degree of protection as per IEC 60529 IP 54 Special
Ambient temperature Ta +10...+55 C accessories for
photoelectric
Permissible ambient light EN 60947-5-2 sensors
Housing material Al coated
Connection 2 m PUR cable, 524 AWG

7.5 58 7.5
Wiring diagram
BN +US
58.3
BK
Out 1
GY
Out 2
42
WH
26.5
Out 3
2
4.
23
BU
0V
17

11
M4
3.4
3 3
BCC M313-D259-B0-688-PS0334-02
BFO D22-XB-UB-EAK-15-SA1-02
BFO D22-XB-LB-EAK-15-SA1-01
BFS 33M-GSS-F01-PU-02
29
52
UC-232A USB/RS232
Convenience Kits
BCC0ARP
BFO00C4
BFO00C9
BFO00FN
BAE009A
BFO00FP
BFS000L
Ordering code
Part number
SET0149 BAV BP-PH-00090-01

SET014A BAV BP-PH-00090-02
SET014C BAV BP-PH-00090-03
SET014E BAV BP-PH-00091-01
www.balluff.com 347
Photoelectric Special Sensors Fork Sensors
Fork sensors BGL
Through-beam sensors are unsurpassed in their accuracy, their abil- Features

ity to distinguish small parts and ne detail and their operating reli- Integrated unit
ability. However, they do take some time to install and congure. This Rugged metal housing
does not apply to fork sensors, since the emitter and receiver are Glass optical surface
self-contained in one housing. Nevertheless, their accuracy, ability High resolution
to distinguish small parts and ne detail and their operating reliability Available in red light, laser light, IR or pin point
is outstanding. Laser fork sensors achieve the best results in these Identical housing dimensions for all light types
kinds of tasks. Balluff laser through-beam fork sensors are ideally 1010 mm fork arm, even for large fork openings
used for precisely positioning and reliably detecting fast-moving Stackable
processes and small parts. This opens a vast range of applications in Laser Class 1
robotics and automation. Applications
Parts sensing on conveyor and feed belts
Label sensing on transparent backing material
Part dimension checking
Counting parts in assembly lines
Tool break monitoring
Position checking
Feed control on automatic assembly equipment
Checking for completeness (e.g. connector pins)
Level monitoring of containers
Type Fork Resolu- Light type Output Switch- Switch- US Connec- Features Page
opening tion ing ing fre- tion
type quency
Transparency detection
Red and green light
Red light, pin point
Ordering code
Light switching
M8 plug, 3-pin
M8 plug, 4-pin
Dark switching
Fluid detection
10...30 V DC
Part number
Laser light
Red light
Infrared
NPN
PNP
Fork sensors
BGL001W BGL 5A-001-S49 5 mm 0.3 mm 3 kHz 350
BGL001Y BGL 5A-002-S49 5 mm 0.3 mm 3 kHz 350
BGL001Z BGL 5A-005-S49 5 mm 0.2 mm 5 kHz 354
BGL0020 BGL 5A-006-S49 5 mm 0.2 mm 5 kHz 354

BGL000R BGL 20A-001-S49 20 mm 0.3 mm 1.5 kHz 351

BGL000T BGL 20A-002-S49 20 mm 0.3 mm 1.5 kHz 351
BGL000U BGL 20A-005-S49 20 mm 0.2 mm 5 kHz 355
BGL000W BGL 20A-006-S49 20 mm 0.2 mm 5 kHz 355
BGL000Y BGL 20A-007-S49 20 mm 0.8 mm 2 kHz 359
BGL000Z BGL 20A-008-S49 20 mm 0.8 mm 2 kHz 359
BGL0016 BGL 30A-001-S49 30 mm 0.3 mm 1.5 kHz 351

BGL0019 BGL 30A-003-S49 30 mm 50 m 5 kHz 362
BGL001A BGL 30A-004-S49 30 mm 50 m 5 kHz 362
BGL001C BGL 30A-005-S49 30 mm 0.2 mm 5 kHz 355

Fork sensors BGL
Product overview
Type Fork Resolution Light type Output Switching Switching US Connection Features Page
opening type frequency
Transparency detection
Red and green light
Red light, pin point
Light switching
M8 plug, 3-pin
M8 plug, 4-pin
Dark switching
Fluid detection
10...30 V DC
Laser light
Ordering code
Red light
Infrared
Part number
NPN
PNP
Photoelectric
sensors
Fork sensors
BGL001E BGL 30A-006-S49 30 mm 0.2 mm 5 kHz 355 Photoelectric
standard
BGL001F BGL 30A-007-S49 30 mm 0.8 mm 2 kHz 359 sensors
BGL001H BGL 30A-008-S49 30 mm 0.8 mm 2 kHz 359
BGL003J BGL 30A-011-S49 30 mm 0.6 mm 2 kHz 364 Photoelectric
special
BGL003K BGL 30A-012-S49 30 mm 0.6 mm 2 kHz 364 sensors
Optical ber
BGL001J BGL 50A-001-S49 50 mm 0.4 mm 1.5 kHz 351 base units
BGL001L BGL 50A-002-S49 50 mm 0.4 mm 1.5 kHz 351 Fiber optics
BGL001M BGL 50A-003-S49 50 mm 80 m 5 kHz 363 Contrast sensor
BGL001N BGL 50A-004-S49 50 mm 80 m 5 kHz 363 Luminescence
sensor
BGL001P BGL 50A-005-S49 50 mm 0.3 mm 5 kHz 355 Color sensors
BGL001R BGL 50A-006-S49 50 mm 0.3 mm 5 kHz 355 Fork sensors
BGL001T BGL 50A-007-S49 50 mm 1.0 mm 2 kHz 359 Angle sensors
BGL001U BGL 50A-008-S49 50 mm 1.0 mm 2 kHz 359 Dynamic optical
windows
Light grids
Photoelectric
BGL0025 BGL 80A-003-S49 80 mm 0.1 mm 5 kHz 363 distance
BGL0026 BGL 80A-004-S49 80 mm 0.1 mm 5 kHz 363 sensors
for analog
BGL0027 BGL 80A-005-S49 80 mm 0.4 mm 5 kHz 356 distance
BGL0028 BGL 80A-006-S49 80 mm 0.4 mm 5 kHz 356 measurement
Special
BGL002A BGL 80A-008-S49 80 mm 1.2 mm 2 kHz 360 accessories for
BGL002T BGL 80A-009-S49 80 mm 50 m 5 kHz 365 photoelectric
sensors
BGL002U BGL 80A-010-S49 80 mm 50 m 5 kHz 365
BGL003L BGL 80A-011-S49 80 mm 0.8 mm 2 kHz 365
BGL003M BGL 80A-012-S49 80 mm 0.8 mm 2 kHz 365

BGL000A BGL 120A-004-S49 120 mm 0.15 mm 5 kHz 363
BGL000C BGL 120A-005-S49 120 mm 0.5 mm 5 kHz 356
BGL000E BGL 120A-006-S49 120 mm 0.5 mm 5 kHz 356
BGL000F BGL 120A-007-S49 120 mm 1.5 mm 1 kHz 360
BGL000H BGL 120A-008-S49 120 mm 1.5 mm 1 kHz 360
BGL000J BGL 180A-001-S49 180 mm 0.6 mm 1.5 kHz 353

BGL000K BGL 180A-002-S49 180 mm 0.6 mm 1.5 kHz 353
BGL000L BGL 180A-005-S49 180 mm 0.6 mm 5 kHz 357
BGL000M BGL 180A-006-S49 180 mm 0.6 mm 5 kHz 357
BGL000N BGL 180A-007-S49 180 mm 1.5 mm 2 kHz 361
BGL000P BGL 180A-008-S49 180 mm 1.5 mm 2 kHz 361

BGL002L BGL 21-IR 2 mm 0.25 mm 25 kHz 367

BGL002M BGL 21-RG 2 mm 0.25 mm 25 kHz 367
www.balluff.com 349
Fork sensors BGL
5A, 10A Red light
Series BGL BGL

Fork opening 5 mm 10 mm
Fork depth 17 mm 17 mm
PNP NO/NC Part number BGL 5A-001-S49 BGL 10A-001-S49
NPN NO/NC Part number BGL 5A-002-S49 BGL 10A-002-S49
Resolution (smallest discernible part) 0.3 mm 0.3 mm
Repeat accuracy 20 m 20 m
Switching hysteresis 0.1 mm 0.1 mm
Switching frequency 3 kHz 3 kHz
Ambient light limit according to EN 60947-5-2 EN 60947-5-2
Suitable connector
y)

material code
M8, 3-pin Straight PUR Yellow 5m BCC050P
M8, 3-pin Angled PUR Yellow 2m BCC055C
M8, 3-pin Angled PVC Yellow 2m BCC0558

Fork sensors BGL
20A, 30A, 50A
Photoelectric
sensors
Photoelectric
standard
BGL BGL BGL sensors
20 mm 30 mm 50 mm
Photoelectric
24 mm 34 mm 54 mm special
BGL 20A-001-S49 BGL 30A-001-S49 BGL 50A-001-S49 sensors
BGL 20A-002-S49 BGL 30A-002-S49 BGL 50A-002-S49 Optical ber
base units
10...30 V DC 10...30 V DC 10...30 V DC
Fiber optics
Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 Fork sensors
Angle sensors
Dynamic optical
0.3 mm 0.3 mm 0.4 mm Light grids
20 m 20 m 40 m
0.1 mm 0.1 mm 0.15 mm Photoelectric
distance
Yellow LED Yellow LED Yellow LED sensors
0.33 ms 0.33 ms 0.33 ms for analog
distance
1.5 kHz 1.5 kHz 1.5 kHz measurement
IP 67 IP 67 IP 67
10...+60 C 10...+60 C 10...+60 C Special
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 accessories for
photoelectric
GD-Zn GD-Zn GD-Zn sensors
Glass Glass Glass
10
Plug, LED output function indicator
Wiring diagram Potentiometer light/dark switching

PNP NPN
%:
8% Potentiometer, sensitivity
%.
%8
9
www.balluff.com 351
Fork sensors BGL
80A, 120A Red Light
Series BGL BGL

Switching frequency 1.5 kHz 1.5 kHz
Suitable connector
y)

material code

Fork sensors BGL
180A, 220A
Photoelectric
sensors
Photoelectric
standard
BGL BGL sensors
180 mm 220 mm
Photoelectric
BGL 180A-001-S49 BGL 220A-001-S49 sensors
BGL 180A-002-S49 BGL 220A-002-S49 Optical ber
base units
10...30 V DC 10...30 V DC
Fiber optics
200 mA 200 mA Luminescence
Light/dark switching (selectable) Light/dark switching (selectable) sensor
Yes/Yes Yes/Yes Color sensors
Potentiometer, 270 Potentiometer, 270 Fork sensors
Angle sensors
Dynamic optical
640 nm 640 nm windows
0.6 mm 0.6 mm Light grids
80 m 80 m
0.2 mm 0.2 mm Photoelectric
distance
0.33 ms 0.33 ms for analog
distance
1.5 kHz 1.5 kHz measurement
IP 67 IP 67
10...+60 C 10...+60 C Special
EN 60947-5-2 EN 60947-5-2 accessories for
photoelectric
GD-Zn GD-Zn sensors
Glass Glass
10
Potentiometer light/dark switching

Wiring diagram
PNP NPN Potentiometer, sensitivity
%:
8%
%.
%8
9
www.balluff.com 353
Fork sensors BGL
5A, 10A Pin Point
Series BGL BGL

Emitter, light type Red light, pin point Red light, pin point
Switching hysteresis 70 m 70 m
Suitable connector
y)

material code

Fork sensors BGL
20A, 30A, 50A
Photoelectric
sensors
Photoelectric
standard
BGL BGL BGL sensors
20 mm 30 mm 50 mm
Photoelectric
base units
10...30 V DC 10...30 V DC 10...30 V DC
Fiber optics
Angle sensors
Red light, pin point Red light, pin point Red light, pin point
Dynamic optical
20 m 20 m 30 m
70 m 70 m 0.1 mm Photoelectric
distance
distance
5 kHz 5 kHz 5 kHz measurement
IP 67 IP 67 IP 67
10...+60 C 10...+60 C 10...+60 C Special
photoelectric
Glass Glass Glass
10

Wiring diagram
%:
8%
%.
%8
9
www.balluff.com 355
Fork sensors BGL
80A, 120A Pin Point
Series BGL BGL

Suitable connector
y)

material code

Fork sensors BGL
180A, 220A
Photoelectric
sensors
Photoelectric
standard
BGL BGL sensors
180 mm 220 mm
Photoelectric
base units
10...30 V DC 10...30 V DC
Fiber optics
Angle sensors
Red light, pin point Red light, pin point
Dynamic optical
60 m 60 m
distance
0.1 ms 0.1 ms for analog
distance
5 kHz 5 kHz measurement
IP 67 IP 67
10...+60 C 10...+60 C Special
accessories for
EN 60947-5-2 EN 60947-5-2 photoelectric
GD-Zn GD-Zn sensors
Glass Glass
10

Wiring diagram
%:
8%
%.
%8
9
www.balluff.com 357
Fork sensors BGL
5A, 10A Infrared
Series BGL BGL

Emitter, light type Infrared Infrared
Repeat accuracy 0.1 mm 0.1 mm
Suitable connector
y)

material code

Fork sensors BGL
20A, 30A, 50A
Photoelectric
sensors
Photoelectric
standard
BGL BGL BGL sensors
20 mm 30 mm 50 mm
24 mm 34 mm 54 mm Photoelectric
special
base units
10...30 V DC 10...30 V DC 10...30 V DC
Fiber optics
35 mA 35 mA 35 mA
Contrast sensor
Infrared Infrared Infrared Angle sensors
Dynamic optical
0.8 mm 0.8 mm 1 mm Light grids
0.1 mm 0.1 mm 0.12 mm
0.3 mm 0.3 mm 0.3 mm Photoelectric
distance
Green LED Green LED Green LED sensors
distance
0.25 ms 0.25 ms 0.25 ms measurement
2 kHz 2 kHz 2 kHz
IP 67 IP 67 IP 67 Special
10...+60 C 10...+60 C 10...+60 C accessories for
photoelectric
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 sensors
GD-Zn GD-Zn GD-Zn
Glass Glass Glass
10

Wiring diagram
%:
8%
%.
%8
9
www.balluff.com 359
Fork sensors BGL
80A, 120A Infrared
Series BGL BGL

Suitable connector
y)

material code

Fork sensors BGL
180A, 220A
Photoelectric
sensors
Photoelectric
standard
BGL BGL sensors
180 mm 220 mm
Photoelectric
base units
10...30 V DC 10...30 V DC
Fiber optics
Angle sensors
Infrared Infrared
Dynamic optical
0.2 mm 0.2 mm
distance
Yellow LED Yellow LED for analog
distance
0.25 ms 0.25 ms measurement
2 kHz 2 kHz
IP 67 IP 67 Special
10...+60 C 10...+60 C accessories for
photoelectric
EN 60947-5-2 EN 60947-5-2 sensors
GD-Zn GD-Zn
Glass Glass
10

Wiring diagram
%:
8%
%.
%8
9
www.balluff.com 361
Fork sensors BGL
30A, 50A Laser
Series BGL
Fork opening 30 mm
Fork depth 34 mm
PNP NO/NC Part number BGL 30A-003-S49
NPN NO/NC Part number BGL 30A-004-S49
Wavelength 650 nm
Laser class 1
Resolution (smallest discernible part) 50 m
Repeat accuracy 10 m
Switching hysteresis 20 m
Switching frequency 5 kHz
Ambient light limit according to EN 60947-5-2
Material Housing GD-Zn
Suitable connector

material code

Fork sensors BGL
80A, 120A
Photoelectric
sensors
Photoelectric
standard
BGL BGL BGL sensors
50 mm 80 mm 120 mm
Photoelectric
base units
10...30 V DC 10...30 V DC 10...30 V DC
Fiber optics
Angle sensors
Dynamic optical
1 1 1 Light grids
80 m 0.1 mm 0.15 mm
10 m 10 m 10 m Photoelectric
distance
25 m 30 m 50 m sensors
distance
0.1 ms 0.1 ms 0.1 ms measurement
5 kHz 5 kHz 5 kHz
10...+60 C 10...+60 C 10...+60 C accessories for
photoelectric
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 sensors
GD-Zn GD-Zn GD-Zn
Glass Glass Glass
10

Wiring diagram Potentiometer light/dark switching
PNP NPN
%:
8% Potentiometer, sensitivity
%.
%8
9
www.balluff.com 363
Fork sensors BGL
30 A Special
Series BGL BGL

NPN NO/NC Transparency detection Part number
PNP NO/NC Part number BGL 30A-011-S49
NPN NO/NC Fluid detection Part number BGL 30A-012-S49
Switching frequency 2 kHz 200 Hz
Suitable connector

material code
Connectors without LED are suitable for PNP and NPN sensors. nectors and connector cables in a wide variety of cable materials, colors and

Fork sensors BGL
50A, 80A
Photoelectric
sensors
Photoelectric
standard
BGL BGL sensors
80 mm 80 mm
Photoelectric
54 mm 54 mm special
BGL 80A-009-S49 sensors
BGL 80A-010-S49 Optical ber
base units
BGL 80A-011-S49
Fiber optics
BGL 80A-012-S49 Contrast sensor
10...30 V DC 10...30 V DC Luminescence
35 mA 20 mA sensor
200 mA 200 mA Color sensors
Light/dark switching (selectable) Light/dark switching (selectable) Fork sensors
Angle sensors
Yes/Yes Yes/Yes
Dynamic optical
Potentiometer, 270 Potentiometer, 270 windows
Infrared Laser, red light Light grids
1480 nm 650 nm
0.8 mm 50 m Photoelectric
distance
0.1 mm 10 m sensors
0.2 mm 30 m for analog
distance
Green LED measurement
0.25 ms 0.1 ms Special
2 kHz 5 kHz accessories for
photoelectric
IP 67 IP 67 sensors
10...+60 C 10...+60 C
EN 60947-5-2 EN 60947-5-2
GD-Zn GD-Zn
Glass Glass
10

Wiring diagram
Potentiometer, sensitivity
PNP NPN
%:
8%
%.
%8
9
www.balluff.com 365
Fork sensors BGL 21
for Label Sensing
The fork sensor BGL 21 is a photoelectric sensor using a microcon- Features

troller for the setup process and function monitoring. All the user Fast, fully automatic sensor calibration
needs to do is press a button to access all the data needed for con- User interface has just one button and two LEDs
guring the sensor. An adjustment aid on the top and bottom of the Very short response time and high repeat accuracy
sensor species the object position during conguration. The internal Very resistant to optical interference and ambient light
microcontroller monitors all settings to ensure optimum switching NPN/PNP output on separate pins with overload protection
frequency, repeat accuracy and rejection of optical interference and M8 connector block can be rotated 90
ambient light. Metal housing
The BGL 21-RG has a red and green emitter diode, which is ideal
for detecting colored markings on transparent Applications
backing material. Which color of emitter light is more appropriate for Detecting markings on backing material
the particular task is automatically determined during setup. Label detection
The BGL 21-IR model with an infrared emitter makes it possible to Monitoring web tracking
scan labels or holes on backing material. Web break monitoring
Hole checking in thin materials (< 2 mm)
Wiring diagram
Suitable connector

material code
M8, 4-pin Angled PUR Yellow 2m BCC050P
M8, 4-pin Angled PVC Yellow 2m BCC050Y

Fork sensors BGL 21
Photoelectric
sensors
Photoelectric
standard
Series BGL BGL sensors
Photoelectric
Fork depth 50 mm 50 mm special
PNP/NPN NC/NO Part number BGL 21-IR BGL 21-RG sensors
base units
Fiber optics
Settings Teach-in Teach-in Color sensors
Emitter, light type Infrared Red and green light Fork sensors
Angle sensors
Wavelength 880 nm 636 nm/536 nm
Dynamic optical
Resolution (smallest discernible part) 1 mm 0.5 mm windows
Repeat accuracy 80 m 80 m Light grids
distance
Power/error indicator Green/red LED Green/red LED sensors
Response time 20 s 20 s for analog
distance
Switching frequency 25 kHz 25 kHz measurement
Ambient light limit according to EN 60947-5-2 EN 60947-5-2 accessories for
photoelectric
Material Housing Anodized aluminum Anodized aluminum sensors
www.balluff.com 367
Photoelectric Special Sensors Analog
Analog fork sensors BGL_C
Fork Sensors
In-process correction
Thanks to their band of light, analog fork sensors not only detect
objects with absolute reliability, they determine the positions of the
objects with extreme precision as well. This makes readjustment in Integral air rinsing nozzle to
an ongoing process a snap. Process reliability and product quality prevent dust from accumulat-
increase signicantly and more efciency is a welcome side effect. ing on the emitter and receiver
optics. Simple connection via
Technical highlights standard pneumatic system.
Analog signal proportional to the skin depth of the object
Constant value, even in the event of height variations
High degree of soiling resistance and compensation
Fieldbus connection with IO-Link
Ideal for web edge control

Product overview
Type Fork Resolu- Light Output Switch- Switch- US Connec- Page

opening tion type ing type ing fre- tion
quency
Photoelectric
sensors
M12 plug, 4-pin

Light switching
Dark switching
18...30 V DC
Photoelectric
4-20 mA
Red light
1 NPN
2 NPN
1 PNP
2 PNP
010 V
Part number sensors
Photoelectric
special
Fork sensors sensors
BGL002Z BGL 30C-001-S4 30 mm 80 m 500 Hz 370 Optical ber
base units
BGL0030 BGL 30C-002-S4 30 mm 80 m 500 Hz 370 Fiber optics
BGL0031 BGL 30C-003-S4 30 mm 80 m 500 Hz 370 Contrast sensor
BGL0032 BGL 30C-004-S4 30 mm 80 m 500 Hz 370 Luminescence
BGL0033 BGL 30C-005-S4 30 mm 80 m 500 Hz 371 sensor
BGL0034 BGL 30C-006-S4 30 mm 80 m 500 Hz 371 Color sensors
Fork sensors
Angle sensors
BGL0037 BGL 50C-001-S4 50 mm 80 m 500 Hz 371
Dynamic optical
BGL0038 BGL 50C-002-S4 50 mm 80 m 500 Hz 371 windows
BGL0039 BGL 50C-003-S4 50 mm 80 m 500 Hz 371 Light grids
BGL003A BGL 50C-004-S4 50 mm 80 m 500 Hz 371
BGL003C BGL 50C-005-S4 50 mm 80 m 500 Hz 371 Photoelectric
distance
BGL003E BGL 50C-006-S4 50 mm 80 m 500 Hz 371 sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 369
Photoelectric Special Sensors Analog
30C Fork Sensors
Series BGL BGL

PNP 2 switching outputs NC/NO Part number BGL 30C-001-S4
NPN Part number BGL 30C-002-S4
PNP 1 analog and NC/NO Part number BGL 30C-003-S4
NPN 1 switching/error output Part number BGL 30C-004-S4
Analog output 4...20 mA
Emitter, light type Red light Red light
Resolution (smallest discernible part) 80 m 80 m
Switching hysteresis < 0.4 mm < 0.4 mm
Output function indicator 2 Yellow LEDs 2 Yellow LEDs
Switching frequency 500 Hz 500 Hz
Measurement eld length 28 mm 28 mm
Material Housing Anodized aluminum Anodized aluminum
Ordering codes on page 369. 80 80
65 65
18
35 35
3.5
3.5
Output 1 LED output function indicator

28
28
54
54
Light/dark switching teach-in

80
93.5
93.5
Output 2 LED output function indicator

35 35
Sensitivity teach-in 17 .2 17 .2
5 5
5
M12x1
6 6
8.5
8.5
Suitable connector 17 10 17 10
(please order separately) 43 43

material code
M12, 4-pin Angled PVC Yellow 2m BCC05TF More electrical accessories: You can nd a large selection of plug con-

30C, 50C
Photoelectric
sensors
Photoelectric
standard
BGL BGL BGL BGL sensors
30 mm 50 mm 50 mm 50 mm
Photoelectric
54 mm 54 mm 54 mm 54 mm special
BGL 50C-001-S4 sensors
BGL 50C-002-S4 Optical ber
base units
BGL 30C-005-S4 BGL 50C-003-S4 BGL 50C-005-S4
Fiber optics
BGL 30C-006-S4 BGL 50C-004-S4 BGL 50C-006-S4 Contrast sensor
18...30 V DC 18...30 V DC 18...30 V DC 18...30 V DC Luminescence
20 mA 20 mA 20 mA 20 mA sensor
100 mA 100 mA 100 mA 100 mA Color sensors
0...10 V DC 4...20 mA 0...10 V DC Fork sensors
Angle sensors
Dynamic optical
Yes/Yes Yes/Yes Yes/Yes Yes/Yes windows
Teach-in Teach-in Teach-in Teach-in Light grids
Red light Red light Red light Red light
633 nm 633 nm 633 nm 633 nm Photoelectric
distance
80 m 80 m 80 m 80 m sensors
0.15 mm 0.15 mm 0.15 mm 0.15 mm for analog
distance
< 0.4 mm < 0.4 mm < 0.4 mm < 0.4 mm measurement
2 Yellow LEDs 2 Yellow LEDs 2 Yellow LEDs 2 Yellow LEDs
2 ms 2 ms 2 ms 2 ms Special
500 Hz 500 Hz 500 Hz 500 Hz accessories for
photoelectric
IP 65 IP 65 IP 65 IP 65
5...+55C 5...+55C 5...+55C 5...+55C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Anodized aluminum Anodized aluminum Anodized aluminum Anodized aluminum
PMMA PMMA PMMA PMMA
80 100 100 100
65 85 85 85
35 35 35 35
3.5
3,5
3,5
3,5
28
28
28
28
54
54
54
54
93.5
93.5
93.5
93.5
35
17 .2 17 17 17
5
5
5.2 5.2 5.2

5
6 6 6 6
8.5
8.5
8.5
8.5
17 10 17 10 17 10 17 10
43 35 35 35
63 63 63
Wiring diagrams
BGL... 002-S4 BGL... 004-S4
Out 1 Out/Error
Out 2 A
BGL... 009-S4 BGL... 006-S4
Out Out/Error
DSC V
www.balluff.com 371
Photoelectric Special Sensors Angle Sensors
Angle sensors BWL
BWL standard angle sensors are needed whenever space is too

tight for fork sensors. The design and beam geometry allow objects
to be approached and scanned from almost any direction, while red
light and laser variants ensure versatile use.
Applications
Assembly and handling technology
Robotic systems
Position and location control
Benets
High accuracy
Visible light spot for easy alignment
Can be installed even in tight mounting conditions
The Balluff angle sensor BWL Robust is a powerful photoelectric

sensor designed for harsh industrial use. Its housing is tough and
allows for variable mounting options.
Objects are reliably detected, even under extremely difcult condi-
tions.
A strong infrared emitter ensures a large function reserve and various
designs allow for exible use, allowing the creation of elegant solu-
tions for a vast number of applications.
Applications
Robotic systems
Position and location control
Type Optical axis Resolu- Light type Output Switching Switch- US Connec- Page
tion type ing fre- tion
quency
M12 connector,
Light switching
M8 plug, 3-pin
Dark switching
Red light, pin
10...30 V DC
Ordering code
Red light
Infrared
Laser
4-pin
Part number
point
NPN
PNP
Angle sensors
Standard
BWL000F BWL 4040D-R011-S49 40/40 mm 0.4 mm 1.5 kHz 374
BWL000H BWL 4040D-R012-S49 40/40 mm 0.4 mm 1.5 kHz 374
BWL000J BWL 4040D-R013-S49 40/40 mm 0.3 mm 5 kHz 376
BWL000K BWL 4040D-R014-S49 40/40 mm 0.3 mm 5 kHz 376
BWL0009 BWL 4040D-I011-S49 40/40 mm 1.0 mm 2 kHz 378
BWL000A BWL 4040D-I012-S49 40/40 mm 1.0 mm 2 kHz 378
BWL000C BWL 4040D-L011-S49 40/40 mm 80 m 5 kHz 380
BWL000E BWL 4040D-L012-S49 40/40 mm 80 m 5 kHz 380

Angle sensors BWL
Product overview
Type Optical axis Resolu- Light type Output Switching Switch- US Connec- Page
tion type ing fre- tion
quency
M12 connector,
Light switching
M8 plug, 3-pin
Dark switching
Red light, pin
10...30 V DC
Ordering code Photoelectric
Red light
sensors
Infrared
Part number
Laser
4-pin
point
NPN
PNP
Photoelectric
Angle sensors standard
sensors
Standard
BWL000R BWL 5454D-R011-S49 54/54 mm 0.4 mm 1.5 kHz 374 Photoelectric
BWL000T BWL 5454D-R012-S49 54/54 mm 0.4 mm 1.5 kHz 374 special
sensors
BWL000U BWL 5454D-R013-S49 54/54 mm 0.4 mm 5 kHz 376
Optical ber
BWL000W BWL 5454D-R014-S49 54/54 mm 0.4 mm 5 kHz 376 base units
BWL000L BWL 5454D-I011-S49 54/54 mm 1.2 mm 2 kHz 378 Fiber optics
BWL000M BWL 5454D-I012-S49 54/54 mm 1.2 mm 2 kHz 378 Contrast sensor
BWL000N BWL 5454D-L011-S49 54/54 mm 100 m 5 kHz 380 Luminescence
sensor
BWL000P BWL 5454D-L012-S49 54/54 mm 100 m 5 kHz 380
Color sensors
Fork sensors
BWL0012 BWL 6868D-R011-S49 68/68 mm 0.5 mm 1.5 kHz 375 Angle sensors
BWL0013 BWL 6868D-R012-S49 68/68 mm 0.5 mm 1.5 kHz 375 Dynamic optical
BWL001N BWL 6868D-R013-S49 68/68 mm 0.4 mm 5 kHz 377 windows
BWL0014 BWL 6868D-R014-S49 68/68 mm 0.4 mm 5 kHz 377 Light grids
BWL000Y BWL 6868D-I011-S49 68/68 mm 1.5 mm 2 kHz 379
Photoelectric
BWL00OZ BWL 6868D-I012-S49 68/68 mm 1.5 mm 2 kHz 379 distance
BWL0010 BWL 6868D-L011-S49 68/68 mm 120 m 5 kHz 381 sensors
for analog
BWL0011 BWL 6868D-L012-S49 68/68 mm 120 m 5 kHz 381 distance
measurement
BWL0019 BWL 9090D-R011-S49 90/90 mm 0.6 mm 1.5 kHz 375
Special
BWL001A BWL 9090D-R012-S49 90/90 mm 0.6 mm 1.5 kHz 375 accessories for
BWL001C BWL 9090D-R013-S49 90/90 mm 0.5 mm 5 kHz 377 photoelectric
sensors
BWL001E BWL 9090D-R014-S49 90/90 mm 0.5 mm 5 kHz 377
BWL0017 BWL 9090D-L011-S49 90/90 mm 150 m 5 kHz 381
BWL0018 BWL 9090D-L012-S49 90/90 mm 150 m 5 kHz 381

BWL0007 BWL 110110D-R013-S49 110/110 mm 0.6 mm 5 kHz 377
BWL0008 BWL 110110D-R014-S49 110/110 mm 0.6 mm 5 kHz 377
BWL0003 BWL 110110D-L011-S49 110/110 mm 0.2 mm 5 kHz 381
BWL0004 BWL 110110D-L012-S49 110/110 mm 0.2 mm 5 kHz 381
Angle sensors
Robust
BWL001F BWL 2222B-001-S4 22/22 mm 1 kHz 382
BWL001H BWL 2222C-001-S4 22/22 mm 1 kHz 382
BWL001J BWL 4241A-001-S4 43/43 mm 1 kHz 383

BWL001K BWL 4241A-001-S49 43/43 mm 1 kHz 383
BWL001L BWL 4260A-001-S4 42/62 mm 1 kHz 383

BWL001M BWL 4260A-001-S49 42/62 mm 1 kHz 383
www.balluff.com 373
Angle sensors BWL
40/40 mm, 54/54 mm Red light
Series BWL BWL

Optical axis 40/40 mm 54/54
PNP NO/NC Part number BWL 4040D-R011-S49 BWL 5454D-R011-S49
NPN NO/NC Part number BWL 4040D-R012-S49 BWL 5454D-R012-S49
Switching frequency 1.5 kHz 1.5 kHz
Suitable connector

material code

Angle sensors BWL
68/68 mm, 90/90 mm, 110/110 mm
Photoelectric
sensors
Photoelectric
standard
BWL BWL BWL sensors
68/68 mm 90/90 mm 110/110 mm
Photoelectric
BWL 6868D-R011-S49 BWL 9090D-R011-S49 BWL 110110D-R011-S49 special
BWL 6868D-R012-S49 BWL 9090D-R012-S49 BWL 110110D-R012-S49 sensors
base units
35 mA 35 mA 35 mA
Fiber optics
Light/dark switching (selectable) Light/dark switching (selectable) Light/dark switching (selectable) Luminescence
Potentiometer, 270 Potentiometer, 270 Potentiometer, 270 Color sensors
LED, red light LED, red light LED, red light Fork sensors
Angle sensors
640 nm 640 nm 640 nm
Dynamic optical
0.5 mm 0.6 mm 0.6 mm windows
80 m 80 m 80 m Light grids
0.2 mm 0.2 mm 0.2 mm
Yellow LED Yellow LED Yellow LED Photoelectric
distance
0.33 ms 0.33 ms 0.33 ms sensors
1.5 kHz 1.5 kHz 1.5 kHz for analog
distance
IP 67 IP 67 IP 67 measurement
10...+60 C 10...+60 C 10...+60 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 Special
GD-Zn GD-Zn GD-Zn accessories for
photoelectric
Glass Glass Glass sensors
10
Wiring diagram
PNP NPN
%: Potentiometer light/dark switching
8%
%. Plug, LED output function indicator
%8
9
www.balluff.com 375
Angle sensors BWL
40/40 mm, 54/54 mm Pin Point
Series BWL BWL

PNP NO/NC Part number BWL 4040D-R013-S49 BWL 5454D-R013-S49
NPN NO/NC Part number BWL 4040D-R014-S49 BWL 5454D-R014-S49
Suitable connector

material code

Angle sensors BWL
68/68 mm, 90/90 mm, 110/110 mm
Photoelectric
sensors
Photoelectric
standard
BWL BWL BWL sensors
68/68 mm 90/90 mm 110/110 mm
Photoelectric
BWL 6868D-R013-S49 BWL 9090D-R013-S49 BWL 110110D-R013-S49 special
BWL 6868D-R014-S49 BWL 9090D-R014-S49 BWL 110110D-R014-S49 sensors
base units
35 mA 35 mA 35 mA
Fiber optics
Red light, pin point Red light, pin point Red light, pin point Fork sensors
Angle sensors
640 nm 640 nm 640 nm
Dynamic optical
40 m 50 m 60 m Light grids
0.15 mm 0.15 mm 0.2 mm
distance
0.1 ms 0.1 ms 0.1 ms sensors
5 kHz 5 kHz 5 kHz for analog
distance
10...+60 C 10...+60 C 10...+60 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 Special
GD-Zn GD-Zn GD-Zn accessories for
photoelectric
Glass Glass Glass sensors
10
Wiring diagram
PNP NPN
8%
%8
9
www.balluff.com 377
Angle sensors BWL
40/40 mm, 54/54 mm Infrared
Series BWL BWL

PNP NO/NC Part number BWL 4040D-I011-S49 BWL 5454D-I011-S49
NPN NO/NC Part number BWL 4040D-I012-S49 BWL 5454D-I012-S49
Resolution (smallest discernible part) 1 mm 1.2 mm
Operating function indicator Green LED Green LED

2
.
+0
60
Suitable connector

material code

Angle sensors BWL
68/68 mm, 90/90 mm, 110/110 mm
Photoelectric
sensors
Photoelectric
standard
BWL BWL BWL sensors
68/68 mm 90/90 mm 110/110 mm
Photoelectric
BWL 6868D-I011-S49 BWL 9090D-I011-S49 BWL 110110D-I011-S49 special
BWL 6868D-I012-S49 BWL 9090D-I012-S49 BWL 110110D-I012-S49 sensors
base units
35 mA 35 mA 35 mA
Fiber optics
Infrared Infrared Infrared Fork sensors
Angle sensors
880 nm 880 nm 880 nm
Dynamic optical
0.5 mm 0.5 mm 0.5 mm
distance
distance
IP 67 IP 67 IP 67
10...+60 C 10...+60 C 10...+60 C Special
photoelectric
Glass Glass Glass
10
Wiring diagram
PNP NPN
8%
%8
9
www.balluff.com 379
Angle sensors BWL
40/40 mm, 54/54 mm Laser
Series BWL BWL

Optical axis 40/40 mm 54/54 mm
PNP NO/NC Part number BWL 4040D-L011-S49 BWL 5454D-L011-S49
NPN NO/NC Part number BWL 4040D-L012-S49 BWL 5454D-L012-S49
Emitter, light type Laser, red light Laser
Laser class 1 1
Resolution (smallest discernible part) 80 m 100 m
Switching hysteresis 25 m 35 m
Suitable connector

material code
Connectors without LED are suitable for PNP and NPN sensors. nectors and connector cables in a wide variety of cable materials, colors and

Angle sensors BWL
68/68 mm, 90/90 mm, 110/110 mm
Photoelectric
sensors
Photoelectric
standard
BWL BWL BWL sensors
68/68 mm 90/90 mm 110/110 mm
Photoelectric
BWL 6868D-L011-S49 BWL 9090D-L011-S49 BWL 110110D-L011-S49 special
BWL 6868D-L012-S49 BWL 9090D-L012-S49 BWL 110110D-L012-S49 sensors
base units
20 mA 20 mA 20 mA
Fiber optics
Laser Laser Laser Fork sensors
Angle sensors
640 nm 640 nm 640 nm
Dynamic optical
1 1 1 windows
120 m 150 m 0.2 mm Light grids
15 m 15 m 20 m
40 m 50 m 70 m Photoelectric
distance
distance
IP 67 IP 67 IP 67
10...+60 C 10...+60 C 10...+60 C Special
photoelectric
Glass Glass Glass
10
Wiring diagram
PNP NPN
8%
%8
9
www.balluff.com 381
Angle sensors BWL
22/22 mm Robust
Series BWL BWL

Optical axis 22/22 mm 22/22 mm
PNP NO/NC Part number BWL 2222B-001-S4 BWL 2222C-001-S4
NPN NO/NC Part number BWL 2222B-002-S4 BWL 2222C-002-S4
Switching type Dark switching Dark switching
Ready delay 100 ms 100 ms
Material Housing Corrosion-resistant steel Corrosion-resistant steel
Suitable connector
Suitable connector
Size Design Cable Color Length Ordering (please order separately)
material code
M8, 3-pin Straight PUR Yellow 2m BCC050P Size Design Cable Color Length Ordering
material code
M8, 3-pin Angled PUR Yellow 2m BCC0558 M12, 4-pin Straight PUR Yellow 5m BCC05FE
M8, 3-pin Angled PVC Yellow 2m BCC055C M12, 4-pin Straight PVC Yellow 2m BCC05FF
nectors and connector cables in a wide variety of cable materials, colors and Connectors without LED are suitable for PNP and NPN sensors.

Angle sensors BWL
43/43 mm, 42/62 mm
Photoelectric
sensors
Photoelectric
standard
BWL BWL BWL BWL sensors
43/43 mm 43/43 mm 42/62 mm 42/62 mm
Photoelectric
BWL 4241A-001-S4 BWL 4241A-001-S49 BWL 4260A-001-S4 BWL 4260A-001-S49 special
BWL 4241A-002-S4 BWL 4241A-002-S49 BWL 4260A-002-S4 BWL 4260A-002-S49 sensors
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC Optical ber
base units
35 mA 35 mA 35 mA 35 mA
Fiber optics
200 mA 200 mA 200 mA 200 mA Contrast sensor
Dark switching Dark switching Dark switching Dark switching Luminescence
Yes/Yes Yes/Yes Yes/Yes Yes/Yes sensor
Infrared Infrared Infrared Infrared Color sensors
880 nm 880 nm 880 nm 880 nm Fork sensors
Angle sensors
Dynamic optical
Yellow LED Yellow LED Yellow LED Yellow LED windows
100 ms 100 ms 100 ms 100 ms Light grids
0.5 ms 0.5 ms 0.5 ms 0.5 ms
1 kHz 1 kHz 1 kHz 1 kHz Photoelectric
distance
IP 67 IP 67 IP 67 IP 67 sensors
10...+60 C 10...+60 C 10...+60 C 10...+60 C for analog
distance
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 measurement
Corrosion-resistant steel Corrosion-resistant steel Corrosion-resistant steel Corrosion-resistant steel
PMMA PMMA PMMA PMMA Special
M12 connector, 4-pin M8 connector, 3-pin M12 connector, 4-pin M8 connector, 3-pin accessories for
photoelectric
sensors
,%$
,%$
Wiring diagrams
PNP NPN
%:
8%
%.
%8
9
www.balluff.com 383
Photoelectric Special Sensors Dynamic
Dynamic optical windows BOW
Optical Window
The ideal use for dynamic optical windows BOW is when objects Features
do not just have to be scanned in some places, but throughout an Constant, high resolution
entire area (window) instead. Thanks to their multitude of beams Dynamic operation
arranged in parallel, they can detect objects in a broad window. A Only moving objects are detected, so feed trays and the like
constant, high resolution is ensured at each location in the window do not affect the measurement
in the process. Detects small parts down to 1 mm
BOW sensors are dynamic, which means that parts are detected in Adjustable output signal length
the active area when they are moving. Adjustable sensitivity
Three window sizes
Standard M8 connector
Applications
Compressed air feeding of small parts
Thread break monitoring
Eject monitoring
Counting/separating parts

Product overview
Type Active Resolution Light type Output Switching Principle US Connec- Page
area type tion
Photoelectric
sensors
M8 plug, 3-pin
Dark switching
10...30 V DC
Photoelectric
Dynamic
Infrared
Part number sensors
NPN
PNP
Photoelectric
Dynamic special
optical windows sensors
BOW001A BOW A-0408-PS-C-S49 4080 mm 1 mm 386 Optical ber
base units
BOW001J BOW A-0808-PS-C-S49 8080 mm 1 mm 387 Fiber optics
BOW0012 BOW A-1208-PS-C-S49 12080 mm 1.2 mm 388 Contrast sensor
BOW0019 BOW A-0408-NS-C-S49 4080 mm 1 mm 386 Luminescence
BOW002E BOW A-0416-PS-C-S49 40160 mm 1 mm 387 sensor
BOW0027 BOW A-0416-NS-C-S49 40160 mm 1 mm 387 Color sensors
Fork sensors
BOW001H BOW A-0808-NS-C-S49 8080 mm 1 mm 387
Angle sensors
BOW002F BOW A-0816-PS-C-S49 80160 mm 1 mm 387
Dynamic optical
BOW0028 BOW A-0816-NS-C-S49 80160 mm 1 mm 387 windows
BOW001W BOW A-1208-NS-C-S49 12080 mm 1.2 mm 388 Light grids
BOW002H BOW A-1216-PS-C-S49 120160 mm 1.2 mm 389
BOW0029 BOW A-1216-NS-C-S49 120160 mm 1.2 mm 389 Photoelectric
distance
BOW002C BOW A-1608-PS-C-S49 16080 mm 1.5 mm 389 sensors
BOW0026 BOW A-1608-NS-C-S49 16080 mm 1.5 mm 389 for analog
distance
BOW002J BOW A-1616-PS-C-S49 160160 mm 1.5 mm 389 measurement
BOW002A BOW A-1616-NS-C-S49 160160 mm 1.5 mm 389
Special
accessories for
photoelectric
sensors
www.balluff.com 385
4080 mm, 40x160 mm Optical Window
Series BOW
Active area 4080 mm
PNP NC/NO Part number BOW A-0408-PS-C-S49
NPN NC/NO Part number BOW A-0408-NS-C-S49
Switching type Dark switching
Settings 2 Potentiometer, 270
Wavelength 880 nm
Resolution (smallest discernible part) 1.0 mm
Output function indicator Red LED
Turn-on delay 0.2 ms
Signal duration for pulse stretching 10...300 ms adjustable
Switching frequency 3...100 Hz dyn.
Material Housing Anodized aluminum
40
20
5.5
9
80
30
4x 4.3
6
8
10.5
17 M8x1
25
Suitable connector

material code

8080 mm, 80X160 mm, 12080 mm, 120x160 mm
Photoelectric
sensors
Photoelectric
standard
BOW BOW BOW sensors
40x160 mm 8080 mm 80x160 mm
Photoelectric
BOW A-0416-PS-C-S49 BOW A-0808-PS-C-S49 BOW A-0816-PS-C-S49 special
BOW A-0416-NS-C-S49 BOW A-0808-NS-C-S49 BOW A-0816-NS-C-S49 sensors
base units
65 mA 45 mA 75 mA
Fiber optics
Dark switching Dark switching Dark switching Luminescence
2 Potentiometer, 270 2 Potentiometer, 270 2 Potentiometer, 270 Color sensors
LED, infrared LED, infrared LED, infrared Fork sensors
Angle sensors
880 nm 880 nm 880 nm
Dynamic optical
Green LED Green LED Green LED Light grids
0.2 ms 0.2 ms 0.2 ms Photoelectric
distance
10...300 ms adjustable 10...300 ms adjustable 10...300 ms adjustable sensors
3...100 Hz dyn. 3...100 Hz dyn. 3...100 Hz dyn. for analog
distance
10...+55 C 10...+55 C 10...+55 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 Special
Anodized aluminum Anodized aluminum Anodized aluminum accessories for
photoelectric
PMMA PMMA PMMA sensors
20.0 80 20.0 30.0

30.0
8.0
8.0
25.0
18.0 10.0 18.0

17.0
6.0 60 2x M6x1 6.0

M8x1
17.0
9.0
25.0
33.0
2x M6x1 2x M6x1
53.0
10
2x M6x1 160.0
20
10.5
5.5
20.0
160.0
80.0
5.5
60.0
10.5 9
40.0
9.0
M8x1
5.5
40.0
25.0
17.0
80
8.0
4x 4.3
25.0
17.0
8.0
4x 4.3
30
6
8
10.5
M8x1 4x 4.3
17
25
18
Wiring diagram
Connector
Supply voltage LED

Output signal LED
NPN
Signal duration potentiometer %:
8%
Potentiometer, sensitivity %. Note when using for ambient light:
%8
9
The receiver is located on the connector side.
www.balluff.com 387
160x80 mm, 160x160 mm Optical Window
Series BOW
Active area 12080 mm
PNP NC/NO Part number BOW A-1208-PS-C-S49
NPN NC/NO Part number BOW A-1208-NS-C-S49
Switching type Dark switching
Settings 2 Potentiometer, 270
Wavelength 880 nm
Resolution (smallest discernible part) 1.2 mm
Output function indicator Red LED
Turn-on delay 0.2 ms
Signal duration for pulse stretching 10...300 ms adjustable
Switching frequency 3...100 Hz dyn
Material Housing Anodized aluminum

100 2x M6x1
10
20
5.5
9
80
4x 4.3
30
6
Suitable connector
8
10.5
(please order separately) 17

M8x1
25

material code


160x80 mm, 160x160 mm
Photoelectric
sensors
Photoelectric
standard
sensors
Photoelectric
BOW BOW BOW special
120x160 mm 16080 mm 160x160 mm sensors
BOW A-1216-PS-C-S49 BOW A-1608-PS-C-S49 BOW A-1616-PS-C-S49 Optical ber
base units
BOW A-1216-NS-C-S49 BOW A-1608-NS-C-S49 BOW A-1616-NS-C-S49 Fiber optics
10...30 V DC 10...30 V DC 10...30 V DC Contrast sensor
200 mA 200 mA 200 mA sensor
Dark switching Dark switching Dark switching Color sensors
Fork sensors
Angle sensors
2 Potentiometer, 270 2 Potentiometer, 270 2 Potentiometer, 270
Dynamic optical
LED, infrared LED, infrared LED, infrared windows
880 nm 880 nm 880 nm Light grids
1.2 mm 1.0 mm 1.0 mm
distance
Red LED Red LED Red LED sensors
distance
10...300 ms adjustable 10...300 ms adjustable 10...300 ms adjustable measurement
3...100 Hz dyn. 3...100 Hz dyn. 3...100 Hz dyn.
accessories for
10...+55 C 10...+55 C 10...+55 C photoelectric
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 sensors
Anodized aluminum Anodized aluminum Anodized aluminum
PMMA PMMA PMMA
20.0 30.0
8.0
17.0
25.0
20.0
8.0
30.0
8.0
17.0
18.0
25.0
18.0
25.0
17.0
10.0 6.0 20.0 30.0 10.0 6.0
10.0 6.0 18.0
2x M6x1 2x M6x1
2x M6x1
73.0
2x M6x1 2x M6x1
160.0
M8x1
160.0
93.0
2x M6x1
80.0
93.0
M8x1
5.5 5.5
5.5
100.0
M8x1
80.0
120.0
120.0
140.0
9.0
10.5
120.0
140.0
10.5
160.0
10.5
160.0
9.0
9.0
17.0
25.0
25.0
17.0
4x 4.3
8.0
25.0
17.0
4x 4.3
8.0
4x 4.3
8.0
18
Wiring diagram
Connector
Supply voltage LED

Output signal LED
NPN
Signal duration potentiometer %:
8%
Potentiometer, sensitivity %. Note when using for ambient light:
%8
9
The receiver is located on the connector side.
www.balluff.com 389
Photoelectric Special Sensors Light Grids
Light grids BLG
Light grids BGL are normally used for reliably detecting wide and Features
very large objects. BGL sensors are available in various measure- Easy to connect
ment eld heights of 100, 150 and 300 mm and allow both large and Easy to install
small ranges. Light grids with a measurement eld height of 100 and Ready for operation immediately
150 mm can be ordered with low or high resolution. No cumbersome conguration of parameters
The light grid can be simply and quickly installed using the supplied Ranges 150 mm...2.1 m
mounting bracket. Setup and installation are user friendly and easy Measurement eld heights 100, 150, 300 mm
to accomplish. Analog output
The system features an analog voltage output for outputting the
height or width of an object directly. An additional switching output Applications
indicates whether the object is within the monitored range. Counting parts
Height measurement and height checking
Presence verication
Slack and position checking
Pallet checking
Web monitoring
Position and material monitoring

Light grids BLG
Product overview
Type Measuring Range Resolution Light type Output Switching US Connec- Page
eld type tion
height
Photoelectric
sensors
Analog 0...10 V
Dark switching
PNP transistor
0.15...2.1 m
Photoelectric
Ordering code
M12 plug
standard
24 V DC
Infrared
Part number sensors
5 mm
7 mm
Photoelectric
special
Light grids sensors
BLG0001 BLG 1-010-210-050-PV01-SX 100 mm 393 Optical ber
base units
BLG0002 BLG 1-010-210-070-PV01-SX 100 mm 393 Fiber optics
Contrast sensor
BLG0003 BLG 1-015-210-050-PV01-SX 150 mm 393 Luminescence
BLG0004 BLG 1-015-210-070-PV01-SX 150 mm 393 sensor
Color sensors
Fork sensors
BLG0005 BLG 1-030-210-070-PV01-SX 300 mm 393
Angle sensors
Dynamic optical
windows
Light grids
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
www.balluff.com 391
Photoelectric Special Sensors Light Grids
Light grids BLG
Analog output
Series
Measurement eld height
PNP NO Resolution 5 mm Part number
NPN NO Resolution 7 mm Part number
Number of covered beams Supply voltage UB
No-load supply current I0 max. Emitter
Receiver
Resolution diagram Output current
Switching type
Range 0.15...2.1 m Short-circuit protected
Analog output
12 Settings
Standard resolution Emitter, light type
10 Wavelength
Power-on indicator Emitter/Receiver
Min. resolution (R) mm
8 Output function indicator

High resolution Degree of protection as per IEC 60529
6
Material Housing
4
Optical surface
Connection Emitter
2
Receiver
0
0 150 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100
Range (D) mm
Wiring diagrams Recommended accessories
Emitter Receiver
Mounting bracket
(included)


Light grids BLG
100 mm, 150 mm, 300 mm
Photoelectric
sensors
Photoelectric
standard
BLG BLG BLG sensors
100 mm 150 mm 300 mm
Photoelectric
BLG 1-010-210-050-PV01-SX BLG 1-015-210-050-PV01-SX special
BLG 1-010-210-070-PV01-SX BLG 1-015-210-070-PV01-SX BLG 1-030-210-070-PV01-SX sensors
24 V DC 24 V DC 24 V DC Optical ber
base units
150 mA 150 mA 150 mA
Fiber optics
50 mA no load 50 mA no load 50 mA no load Contrast sensor
Dark switching Dark switching Dark switching sensor
Yes Yes Yes Color sensors
0...10 V 0...10 V 0...10 V Fork sensors
Angle sensors
Fixed Fixed Fixed
Dynamic optical
LED, infrared LED, infrared LED, infrared windows
880 nm 880 nm 880 nm Light grids
distance
0...+55 C 0...+55 C 0...+55 C for analog
distance
Black anodized aluminum Black anodized aluminum Black anodized aluminum measurement
PMMA PMMA PMMA
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin Special
M12 connector, 5-pin M12 connector, 5-pin M12 connector, 5-pin accessories for
photoelectric
sensors
L1 L2
BLG 1-010 150 107
BLG 1-015 200 157
BLG 1-030 350 307
Suitable connector Suitable connector

Size Design Cable Color Length Ordering Size Design Cable Color Length Ordering
material code material code
M12, 5-pin Straight PUR Black 5m BCC098C M12, 4-pin Straight PUR Yellow 5m BCC05FE
M12, 5-pin Angled PUR Black 5m BCC08FC M12, 4-pin Straight PVC Yellow 2m BCC05FF
Connectors without LED are suitable for PNP and NPN sensors. M12, 4-pin Angled PVC Yellow 2m BCC05TF
nectors and connector cables in a wide variety of cable materials, colors and Use the plug connector without an LED!
www.balluff.com 393
Photoelectric
Sensors
Photoelectric distance sensors
for analog distance measurement
Photoelectric distance sensors are used when distances to objects
need to be measured or monitored or their precise position is to
determined. They support positioning tasks, material ow controls
and level detections in the most diverse of applications also across
large distances.
Users have a wide range of output signals available. Depending on

the type, these include analog current and voltage outputs or serial
interfaces. However, variants with IO-Link are available for a simple
and efcient connection to higher-level control systems.

Photoelectric Distance Sensors
Contents
Block designs
Product overview 396
BOD 6K 398
BOD 21M 400
BOD 26K 402
BOD 63M 410
BOD 66M 414
www.balluff.com 395
Photoelectric Distance Sensors Distance
Distance sensors BOD
Sensors
Optical distance sensors are used when distances of objects need Applications
to be measured or monitored with precise position determination. Control tasks
Distance measurement is based on either the triangulation principle Sensing
or time of ight. Object positioning
PSD elements or CCD arrays are used for the receiving elements, Level detection
with the emitter consisting of a red light or laser light source.
Analog current and voltage values, serial interfaces and digital out-
puts are available to the user.
Contour checking Blister packaging

Optical distance sensors continuously detect dimensions or contours Optical distance sensors monitor the packaging process, optimize
on tongue and groove boards. Analog sensing detects individual product lling and increase system productivity.
defects and gradual deviations directly for permanent monitoring of Before foil packaging is closed up, a BOD 21M checks the individual
the production process. compartments and detects missing or extra items.
Sag monitoring Adaptive feed

Film and web material has to be transported at a uniform speed in Multiple optical distance sensors measure components, assembled
order to be processed with precision. Tension-free material transport units and packages on a conveying line. BOD 21M sensors evaluate
succeeds using the BOD 21M, which dynamically detects the height the outer dimension and contour so that these various parts can be
of the sag section. transported to the next appropriate process steps. The rugged metal
housing guarantees long service life of the installation.

Distance sensors BOD
Product overview
Type Working Resolution Light Analog Output US Connection Page

range type output
Distance sensors are assigned the

linear position sensing and measurement
that we have marked in blue.

Photoelectric
M8 connector, 4-pin
sensors
2 PNP transistor
RS485 interface
PNP transistor
15...30 V DC
18...30 V DC
Alarm output
Photoelectric
Laser light
Ordering code
4...20 mA
standard
Red light
0...10 V
1...10 V
IO-Link
Part number sensors
Cable
Photoelectric
special
Distance sensor sensors
BOD000H BOD 6K-RA01-S75-C 20...80 mm n.a. 399 Photoelectric
BOD000F BOD 6K-RA01-C-02 20...80 mm n.a. 399 distance
sensors
for analog
BOD000L BOD 21M-LA01-S92 25...45 mm 30 m 400 distance
measurement
BOD000P BOD 21M-LB01-S92 25...45 mm 30 m 400
Block
BOD000M BOD 21M-LA02-S92 20...200 mm 100...200 m 401 designs
BOD000R BOD 21M-LB02-S92 20...200 mm 100...200 m 401
BOD000N BOD 21M-LA04-S92 20...500 mm 100...500 m 401 Special
accessories for
BOD000T BOD 21M-LB04-S92 20...500 mm 100...500 m 401 photoelectric
sensors
BOD0002 BOD 26K-LA01-S4-C 45...85 mm 80 m 403
BOD0001 BOD 26K-LA01-C-06 45...85 mm 80 m 403
BOD0004 BOD 26K-LA02-S4-C 45...85 mm 0.1% of Wh 403
BOD0003 BOD 26K-LA02-C-06 45...85 mm 0.1% of Wh 403
BOD0005 BOD 26K-LB04-S115-C 30...100 mm 0.1% of Wh 405

BOD000C BOD 26K-LBR04-S115-C 30...100 mm 0.1% of Wh 405

BOD000E BOD 26K-LBR05-S115-C 80...300 mm 0.1% of Wh 407
BOD000U BOD 63M-LA02-S115 200...2000 mm 1 mm 411

BOD0010 BOD 63M-LB02-S115 200...2000 mm 1 mm 411
BOD0012 BOD 63M-LI06-S4 200...6000 mm 1 mm 411
BOD000W BOD 63M-LA04-S115 200...6000 mm 1 mm 413
BOD0011 BOD 63M-LB04-S115 200...6000 mm 1 mm 413
BOD0015 BOD 66M-RA01-S92-C 100...600 mm 0.5 mm 415

BOD0016 BOD 66M-RB01-S92-C 100...600 mm 0.5 mm 415
BOD0013 BOD 66M-LA04-S92-C 200...2000 mm 5 mm 417

BOD0014 BOD 66M-LB04-S92-C 200...2000 mm 5 mm 417
www.balluff.com 397
Photoelectric Distance Sensors BOD 6K
BOD 6K distance sensors
The BOD 6K provides a distance-proportional analog output signal

with falling voltage over a xed measuring range of 20 to 80 mm.
With a switching output adjustable using teach-in, the sensor can
also be used as a sensing device with background suppression.
Features
Fixed measuring range between 20...80 mm
Analog output 0...10 V
Adjustable background suppression
PNP, NO/NC switching output
Teach-in
Disable buttons
Connector or cable version
20 mm
80 mm
Analog output BOD 6K-RA01 Wiring diagrams
analog
Output voltage
analog
Working distance


code material code
Mounting bracket BAM00UH M8, 4-pin Straight PUR Yellow 5m BCC02N5
M8, 4-pin Angled PUR Yellow 5m BCC02NH

BOD 6K distance sensors
[
linear position sensing and measure-
ment that we have marked in blue.
Photoelectric
sensors
Series BOD 6K BOD 6K

Photoelectric
Working range 20...80 mm 20...80 mm standard
Measuring range 60 mm 60 mm sensors
PNP NO/NC Ordering code BOD000H BOD000F
Photoelectric
Part number BOD 6K-RA01-S75-C BOD 6K-RA01-C-02 special
Analog output 0...10 V (max. 3 mA) 0...10 V (max. 3 mA)
Photoelectric
No-load supply current I0 max. 30 mA at 24 V DC 30 mA at 24 V DC distance
Output current 100 mA 100 mA sensors
for analog
Cutoff frequency 200 Hz 200 Hz distance
Switching type Light/dark switching (selectable) Light/dark switching (selectable) measurement
Block
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes designs
Emitter, light type LED, red light LED, red light Special
Wavelength 660 nm 660 nm accessories for
photoelectric
Light spot diameter 55 mm at 60 mm 55 mm at 60 mm sensors
Measurement values referenced to 100100 mm, 3.2 12 3.2 12

90% reective Kodak gray card.
4.2
4 4.2
24
32
24
32
8
42
17
9
9
5
10
4
3.8
2.6 2.6
10.7 M8x1 10.7
21 21
www.balluff.com 399
Photoelectric Distance Sensors BOD 21M
BOD 21M laser distance sensors
Laser
The BOD 21M is connected using a 5-pin M12 plug.

The connector orientation can be set over a range of 270,
allowing the BOD 21M to be attached in any position.
Distance sensors are assigned the linear position sensing

and measurement that we have marked in blue. [
Series BOD 21M BOD 21M
Working range 25...45 mm 25...45 mm
Measuring range 20 mm 20 mm
2 PNP NO/NC Ordering code BOD000L BOD000P
Part number BOD 21M-LA01-S92 BOD 21M-LB01-S92
Analog output 1...10 V (max. 3 mA) 4...20 mA
Settings Teach-in (rotary switch) Teach-in (rotary switch)
Switching type Light/dark switching Light/dark switching
Emitter, light type Laser, pulsed red light Laser, pulsed red light
Laser class 2 2
Light spot diameter 1 mm at 45 mm 1 mm at 45 mm
Temperature drift 0.2 %/K 0.2 %/K
Resolution 30 m 30 m
Linearity ~0.5% ~0.5%

On/off delay 7 ms 7 ms
Polarity reversal/short-circuit protected Yes Yes
Material Housing Gd-Zn Gd-Zn
Measured values referenced to Kodak gray card 90% reective.

Emitter
1 2
Receiver
code
1 Mounting bracket BAM00T9
2 Mounting bracket BAM00TA
0
27
You can nd special accessories for photoelectric

s
te
ta
sensors in this catalog on page 420.

Ro
Suitable connector
Size Design Cable Color Length Ordering Green LED

Yellow LED
material code
M12, 5-pin Straight PUR Black 5m BCC08KP

Photoelectric
sensors
BOD 21M BOD 21M BOD 21M BOD 21M

Photoelectric
BOD000M BOD000R BOD000N BOD000T
Photoelectric
BOD 21M-LA02-S92 BOD 21M-LB02-S92 BOD 21M-LA04-S92 BOD 21M-LB04-S92 special
1...10 V (max. 3 mA) 4...20 mA 1...10 V (max. 3 mA) 4...20 mA
Photoelectric
Teach-in (rotary switch) Teach-in (rotary switch) Teach-in (rotary switch) Teach-in (rotary switch) distance
Light/dark switching Light/dark switching Light/dark switching Light/dark switching sensors
for analog
Laser, pulsed red light Laser, pulsed red light Laser, pulsed red light Laser, pulsed red light distance
Block
2 2 2 2 designs
1 mm at 200 mm 1 mm at 200 mm 16 mm at 500 mm 16 mm at 500 mm
0.2 %/K 0.2 %/K 0.2 %/K 0.2 %/K Special
100...200 m 100...200 m 100...500 m 100...500 m accessories for
photoelectric
1% 1% 1% (to 200 mm) 1% (to 200 mm) sensors
3% (200...500 mm) 3% (200 to 500 mm)
300 ms 300 ms 300 ms 300 ms
7 ms 7 ms 7 ms 7 ms
70 Hz 70 Hz 70 Hz 70 Hz
IP 67 IP 67 IP 67 IP 67
Yes Yes Yes Yes
10...+50 C 10...+50 C 10...+50 C 10...+50 C
Gd-Zn Gd-Zn Gd-Zn Gd-Zn
Emitter
Emitter
Receiver
Receiver
0
0
27
27
s
s
te
te
ta
ta
Ro
Ro
Green LED Green LED

Wiring diagrams
BOS 21M-LA... BOS 21M-LB...
www.balluff.com 401
Photoelectric Distance Sensors BOD 26K-LA
Distance sensors BOD 26K-LA Laser
Laser
Features
Fixed measuring range between 45...85 mm
Analog output 0 to 10 V
20 m or 80 m resolution
Connector or cable version
Distance sensors are assigned the linear position sensing
and measurement that we have marked in blue. [
Series
Working range
Measuring range
Ordering code
Part number
Supply voltage UB
45 mm Analog output
85 mm No-load supply current I0 max.
Output current
Wiring diagrams Cutoff frequency
Settings
Emitter, light type
Wavelength
Shield Laser class
Light spot diameter
Temperature drift
Resolution
Linearity
Shield
Power-on indicator
Contamination indicator
Cutoff frequency
Analog output BOD 26K-LA0... Rise time (from 10% to 90%)
U
Fall-off time (from 90% to 10%)
10 V
Measuring range Material Housing
Optical surface
Connection
Output voltage
Measured values referenced to Kodak gray card 90 % reective.

0V
45 mm 85 mm


code material code
Mounting bracket BAM00TK M12, 4-pin Straight PUR Black 5m BCC032L
You can nd special accessories for photoelectric sensors, such
as reectors, apertures, lenses, lters and deection heads, More electrical accessories: You can nd a large selection of plug
in this catalog on page 420. connectors and connector cables in a wide variety of cable materials, colors,

BOD 26K-LA laser distance sensors
Photoelectric
sensors
BOD 26K BOD 26K BOD 26K BOD 26K

Photoelectric
BOD0002 BOD0004 BOD0001 BOD0003
Photoelectric
BOD 26K-LA01-S4-C BOD 26K-LA02-S4-C BOD 26K-LA01-C-06 BOD 26K-LA02-C-06 special
0...10 V (max. 3 mA) 0...10 V (max. 3 mA) 0...10 V (max. 3 mA) 0...10 V (max. 3 mA)
Photoelectric
35 mA 35 mA 35 mA 35 mA distance
for analog
200 Hz 200 Hz 200 Hz 200 Hz distance
Yes/Yes Yes/Yes Yes/Yes Yes/Yes measurement
Block
Fixed Fixed Fixed Fixed designs
Laser, red light Laser, red light Laser, red light Laser, red light
2 2 2 2 accessories for
photoelectric
0.8 mm at 65 mm 0.8 mm at 65 mm 55 mm at 60 mm 55 mm at 60 mm sensors
18 m/C 18 m/C 18 m/C 18 m/C
80 m 20 m 80 m 20 m
1% 1% 1% 1%
Red LED Red LED Red LED Red LED
400 Hz 400 Hz 40 Hz 40 Hz
3 ms 3 ms 30 ms 30 ms
2 ms 2 ms 20 ms 20 ms
IP 67 IP 67 IP 67 IP 67
0...+45 C 0...+45 C 0...+45 C 0...+45 C
EN 60947-5-2 EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
PMMA PMMA PMMA PMMA
M12 connector, 4-pin M12 connector, 4-pin 6 m PVC cable, 24 AWG 6 m PVC cable, 24 AWG
Emitter Receiver
Emitter Receiver
Rotates 270
www.balluff.com 403
Photoelectric Distance Sensors BOD 26K-LB
Distance sensors BOD 26K-LB Laser
Laser
Features
Adjustable measuring range between 30...100 mm
Analog output 4...20 mA adjustable: Rising or falling
Optional with RS485-interface (for master-slave-mode) and
for visualization using a computer (additional software required)
2 switching outputs with adjustable switching points
Teach-in
Adjustable averaging
Numerous additional functions 30 mm
100 mm
Analog output BOD 26K-LB(R)04... Connector diagram
I Measuring range (adjustable)
20 mA
Output current
Wiring diagram
+US
RS485 Y/A only type
RS485 Z/A BOD 26K-LBR...
4 mA
Ext. teach-in
0 mA 0V
30 100 mm


code material code
Mounting bracket BAM00TK M12, 8-pin straight PVC Gray 5m BCC0995
M12, 8-pin angled PVC Gray 5m BCC0998

More mechanical accessories: You can nd a large selection of mounting More electrical accessories: You can nd a large selection of plug
components of all types, such as clamping holders, mounting brackets and connectors and connector cables in a wide variety of cable materials, colors,
the Balluff mounting system BMS, in our Accessory Product Line catalog. and lengths in our Industrial Networking and Connectivity catalog.

BOD 26K-LB laser distance sensors
[
Photoelectric
sensors

Photoelectric
Measuring range adjustable max. 70 mm adjustable max. 70 mm sensors
2 PNP NO/NC Ordering code BOD0005 BOD000C

Photoelectric
Part number BOD 26K-LB04-S115-C BOD 26K-LBR04-S115-C special
Analog output 4...20 mA 4...20 mA
Photoelectric
No-load supply current I0 max. 40 mA 40 mA distance
for analog
Switching type Light/dark switching Light/dark switching distance
measurement
Interface RS485
Block
Additional function Master-slave mode Special
accessories for
Emitter, light type Laser, red light Laser, red light photoelectric
Wavelength 650 nm 650 nm sensors
Laser class 2 2
Light spot diameter 3.25 mm at 100 mm 3.25 mm at 100 mm
Linearity 175 m 175 m
Time function 50 ms pulse extension 50 ms pulse extension
Connection M12 connector,8-pin M12 connector,8-pin
Measured values referenced to Kodak

gray card 90% reective.
Emitter Receiver
Emitter Receiver
www.balluff.com 405
Laser
Features
Adjustable measuring range between 80...300 mm
Adjustable: Rising or falling
Optional with RS485-interface (for master-slave-mode) and
for visualization using a computer (additional software required)
2 switching outputs with adjustable switching points
Teach-in
Adjustable averaging
Numerous additional functions
80 mm
300 mm
Analog output BOD 26K-LB(R)05... Connector diagram
I Measuring range (adjustable)
20 mA
Output current
Wiring diagram
+US
RS485 Y/A only type
RS485 Z/A BOD 26K-LBR...
4 mA
Ext. teach-in
0 mA 0V
80 300 mm


code material code
Mounting bracket BAM00TK M12, 8-pin Straight PVC Black 5m BCC0995
M12, 8-pin Angled PVC Black 5m BCC0998
this catalog on page 420. More electrical accessories: You can nd a large selection of plug

[
Photoelectric
sensors

Photoelectric
2 PNP NO/NC Ordering code BOD0006 BOD000E
Photoelectric
Part number BOD 26K-LB05-S115-C BOD 26K-LBR05-S115-C special
Photoelectric
for analog
measurement
Interface RS485
Block
Additional function Master-slave mode Special
Emitter, light type Laser, red light Laser, red light accessories for
photoelectric
Wavelength 650 nm 650 nm sensors
Laser class 2 2
Light spot diameter 4.5 mm at 300 mm 4.5 mm at 300 mm

Emitter Receiver
Emitter Receiver
www.balluff.com 407
Laser
Features
Adjustable measuring range
Adjustable: Rising or falling
1 switching output with adjustable switching points
Teach-in
Laser beam can be turned off
30 mm
100 mm
Connector diagram
80 mm
300 mm
Analog output BOD 26K-LB06... Analog output BOD 26K-LB07...
I Measuring range (adjustable) Measuring range (adjustable)

I
20 mA 20 mA
Output current
Output current
4 mA 4 mA
0 mA 0 mA
30 100 mm 80 300 mm


Orde
code material code
Mounting bracket BAM00TK M12, 5-pin straight PUR black 5m BCC098C
M12, 5-pin angled PUR black 5m BCC08FC

[
Photoelectric
sensors

Photoelectric
PNP NO/NC Ordering code BOD0007 BOD0008
Photoelectric
Part number BOD 26K-LB06-S92-C BOD 26K-LB07-S92-C special
Photoelectric
for analog
measurement
Block
Settings Teach-in Teach-in designs
Wavelength 650 nm 650 nm Special
Laser class 2 2 accessories for
photoelectric
Light spot diameter 3.25 mm at 100 mm 4.5 mm at 300 mm sensors

Emitter Receiver
Emitter Receiver
Wiring diagram
*Laser shut-off (+US)

Key disable (0 V)
www.balluff.com 409
Distance sensors BOD 63M Laser
Laser
The BOD 63M in a robust metal housing has a working range of

200...2000/6000 mm. It has adjustable background suppression and an
analog output with 0...10 V or 4...20 mA. Time of ight measurement enables
longer ranges than using triangulation or energetic light scanners.
[
The switching outputs are set using a multi-turn-potentiometer. Distance sensors are assigned the
This innovative sensor technology is used in applications where traditional ment that we have marked in blue.
methods meet either technological or economical limits. Such applications
include detecting small objects at large distances and operating in difcult Series
conditions, such as if sensing must be performed "outside" of processes with Working range
high temperatures or in robotic cells. Measuring range
2 PNP NO Ordering code
Features Part number
Small laser spot for detecting small objects over large distances Supply voltage UB
Virtually independent of the reective properties of the target object within Analog output
a specic sensing distance No-load supply current I0 max.
Background suppression across the entire working range Switching type
Analog, switching and alarm output Polarity reversal/short-circuit protected
Laser beam can be turned off Settings
Emitter, light type
Applications Wavelength
Exact detection tasks over long distances (e.g. due to design limitations or Laser class
heat at the target location) Light spot diameter
Detecting objects with changing colors, shiny surfaces or
unfavorable angles to the light beam Resolution
Flexible solutions for position detection, level measurement and monitoring, Gray value shift
distance and height measurement, quality assurance applications Repeat accuracy per BWN
Temperature drift
Linearity
Recommended accessoriesssories Switching hysteresis
(please order separately)) Power-on indicator
Switching output
Description Ordering Stability indicator
code Ready delay
Mounting bracket BAM00P6 Response time
Switching frequency
Suitable connector Material Housing
(please order separately) Optical surface
Connection
Size Design Cable Color
lor Length Ordering
material code IO-Link
M12, 8-pin Straight PVC Gray 5m BCC0995 Mode
M12, 8-pin Angled PVC Gray 5m BCC0998 Transfer rate
Value range
Connectors without LED are suitable for PNP and NPN sensors. Diagnostics
Parameters
and lengths in our Industrial Networking and Connectivity catalog. Measured values referenced to Kodak
Wiring diagram Connector orientation

+US 1 +UB
Laser 4 Out 1/ IO-Link
+Analog 2 Out 2
Analog 3 0V
Out 1
Out 2
Error
0V
Shield

Photoelectric
sensors
BOD 63M BOD 63M BOD 63M

Photoelectric
200...6000 mm 200...2000 mm 200...2000 mm standard
5800 mm 1800 mm 1800 mm sensors
BOD0012 BOD000U BOD0010
Photoelectric
BOD 63M-LI06-S4 BOD 63M-LA02-S115 BOD 63M-LB02-S115 special
18...30 V DC 15...30 V DC 15...30 V DC sensors
0...10 V 4...20 mA
Photoelectric
90 mA 75 mA 75 mA distance
Light switching Light switching Light switching sensors
for analog
Yes/Yes Yes/Yes Yes/Yes distance
Teach-in Potentiometer, 4 revolutions Potentiometer, 4 revolutions measurement
Block
Laser, red light Laser, red light Laser, red light designs
660 nm 660 nm 660 nm
2 2 per EN 60825 2 per EN 60825 Special
5 mm at 3 m 10 mm 10 mm accessories for
photoelectric
10 mm at 6 m sensors
2 mm 1 mm 1 mm
1.5% 2% 2%
4 mm 3 mm 3 mm
2 mm/C 0.6 mm/C 0.6 mm/C
1% 2% 2 %
15 mm 10 mm 10 mm
Yellow LED 2 yellow LED 2 yellow LED
20ms 20ms 20ms
2 ms 2 ms
150 Hz 250 Hz 250 Hz
IP 65 IP 67 IP 67
10...+60 C 10...+60 C 10...+60 C
Anodized aluminum Anodized aluminum Anodized aluminum
Glass Glass Glass
M12 connector, 4-pin M12 connector,8-pin M12 connector,8-pin
COM 2
38.4 kbaud
Receiver
00C8 H...1770 H
Stability indicator
5
5.
Emitter
M
4
Switching points, laser on/off, button disable
Rotates 270
Laser class
The emitter corresponds to a class 2 laser
according to EN 60825-1:2001-11.
Thus no additional protective measures are
required for operation.
Install the device so that the laser warning
label is easily visible.
www.balluff.com 411
Laser
Analog output
Sensing distance Sensing distance
Sensing range
Sensing range
Switching output
Hysteresis
Switching distance
Measuring range BOD 63M-LA/LB02... Measuring range BOD 63M-LA/LB04...

depending on object reection depending on object reection
white
white
Gray
Gray
black
black
Indicators and operating elements Connector diagram
Pin-assignment Cable color

1 white Out 1
2 brown +US
3 Green Analog output
4 Yellow Out 2
1 Supply voltage (green)
5 Gray +Analog output
2 Switching output Out 1 (yellow)
3 Switching output Out 2 (yellow) 6 pink Stability indicator
4 Stability indicator (red) 7 Blue 0V
5 Potentiometer Out 1, 4 revolutions 8 Red Laser shut-off
6 Potentiometer Out 2, 4 revolutions Knurled nut Braided shield Shield

[
Photoelectric
sensors

Photoelectric
2 PNP NO Ordering code BOD000W BOD0011
Photoelectric
Part number BOD 63M-LA04-S115 BOD 63M-LB04-S115 special
Analog output 0...10 V 4...20 mA
Photoelectric
Output current Switching output 200 mA 200 mA sensors
for analog
Error output 200 mA 200 mA distance
Switching type Light switching Light switching measurement
Block
Settings Potentiometer, 4 revolutions Potentiometer, 4 revolutions
Emitter, light type Laser, red light Laser, red light Special
Wavelength 660 nm 660 nm accessories for
photoelectric
Laser class 2 per EN 60825 2 per EN 60825 sensors
Light spot diameter 10 mm 10 mm
Resolution 1 mm 1 mm
Gray value shift 1.5% 1.5%
Repeat accuracy per BWN 4 mm 4 mm
Temperature drift 1.5 mm/C 1.5 mm/C
Linearity 1% 1%
Switching hysteresis 15 mm 15 mm
Switching output 2 yellow LED 2 yellow LED
Stability indicator Red LED Red LED
Ready delay 20ms 20ms
Switching frequency 250 Hz 250 Hz

Receiver
5
5.
Emitter
M
4
Wiring diagram
+US
Laser
+Analog
Rotates 270
Analog
Out 1
Out 2
Error
0V
Shield
www.balluff.com 413
Photoelectric Distance Sensors BOD 66M-R
BOD 66M-R distance sensors
Distance measurements with high resolution are achieved using Analog output BOD 66M-R...
triangulation and modern CCD technology.
Measuring range
The BOD 66M-R_01 with analog voltage or current output and an
additional switching output can measure or monitor distance and, at
the same time, operate as a light scanner with background suppres-
sion for object detection.
The BOD 66M-R_01 uses red light over a measuring range of
Output voltage
100...600 mm at a resolution of 0.5 mm.
Features
Extremely color and ambient light insensitive
Working range 100...600 mm
Resolution 0.5 mm
Analog output with voltage (1...10 V) or current (4...20 mA)
PNP switching output teachable
Working distance
Scratch-resistant glass optics
Applications Connector diagram

Level monitoring
Positioning tasks
Winding diameter detection
Prole measurement
Sag control
Wiring diagram
Teach-in

Description Ordering Size Design Cable C

Color
l Length
L th Ordering
Od i
code material code
Mounting bracket BAM00P9 M12, 5-pin Straight PUR Black 5m BCC098C
M12, 5-pin Angled PUR Black 5m BCC08FC
this catalog on page 420.. connectors and connector cables in a wide variety of cable materials, colors,

BOD 66M-R distance sensors
[
Photoelectric
sensors

Photoelectric
PNP NO Ordering code BOD0015 BOD0016
Photoelectric
Part number BOD 66M-RA01-S92-C BOD 66M-RB01-S92-C special
Photoelectric
for analog
Switching type Light switching Light switching distance
Polarity reversal/short-circuit protected Yes/Yes Yes/Yes measurement
Block
Light spot diameter approx. 10 mm approx. 10 mm accessories for
photoelectric
Resolution 0.5 mm 0.5 mm sensors
Gray value shift (90 %/6 %) 1% 1%
Repeat accuracy per BWN 0.5% 0.5%
Absolute measuring accuracy** 2% (at the measuring distance) 2% (at the measuring distance)
Switching frequency 20...100 Hz* 20...100 Hz*
*depending on object reectivity

**Target 5050 mm2
www.balluff.com 415
Photoelectric Distance Sensors BOD 66M-L
Distance sensors BOD 66M-L Laser
Laser
The BOD 66M-L_04 features an analog as well as an additional Laser class

switching output. (see page 895)
It measures the object position across a range from 200...2000 mm. The emitter corresponds to a class 2 laser according to
In addition, it allows the switching output (background suppression) EN 60825-1:2001-11. Thus no additional protective measures are
to be congured in the same area using teach-in. Forward-looking required for operation.
laser- and CCD-technology ensure accuracy and reliability. Install the device so that the laser
warning label is easily visible.
Features
Laser class 2
Small light spot over the entire range
Extremely color and ambient light insensitive due to
CCD line receiver
Analog current or voltage output over 200...2000 mm
PNP switching output, teachable
Scratch-resistant glass optics
Applications
Background suppression up to 2 m
Analog measuring at up to 2 m target distance
Positioning tasks
Analog output BOD 66M-L... Connector diagram

Measuring range
Output voltage
Wiring diagram
Teach-in
Working distance


code material code
Mounting bracket BAM00P9 M12, 5-pin straight PUR Black 5m BCC098C
M12, 5-pin angled PUR Black 5m BCC08FC

Distance sensors BOD 66M-L Laser
[
Photoelectric
sensors

Photoelectric
PNP NO Ordering code BOD0013 BOD0014
Photoelectric
Part number BOD 66M-LA04-S92-C BOD 66M-LB04-S92-C special
Photoelectric
for analog
Switching type Light switching Light switching distance
measurement
Block
Laser class 2 2 accessories for
photoelectric
Light spot diameter 3 12 mm at 2 m 3 12 mm at 2 m sensors
Resolution 5 mm 5 mm
Gray value shift (90 %/6 %) 1% 1%
Repeat accuracy 0.5% 0.5%
Absolute measuring accuracy** 2% (at the measuring distance) 2% (at the measuring distance)
Switching frequency 10...100 Hz* 10...100 Hz*
*depending on object reectivity

**Target 5050 mm2
Green LED
Connector orientation Yellow LED
deep
Emitter deep
Receiver
www.balluff.com 417
Photoelectric
Sensors
Special accessories for photoelectric sensors
Complete optical accessories from mounting brackets, reectors,
lenses and holding systems etc. for standard applications and ap-
plications under more difcult ambient conditions.

Special Accessories for Photoelectric Sensors
Contents
Reectors
Round 420
Block-shaped 421
For special applications 423
For laser retroreective sensors 424
Reective foils 426
Fasteners
Mounting brackets 428
Mounting brackets for tubular sensors 437
Mounting nuts 439
Mounting brackets for 8x8 block sensors 440
Mounting cuff 441
Clamping blocks 441
Clamping holder 441
Adapter plate 441
BMS mounting systems 442
Holding system 450
Sensor accessories
Apertures 452
Weld protection 454
Planoconvex lens 456
Polarizing lters 456
Air tube 456
Lenses 457
Intermediate ring 457
Neutral density lters 458
Protective nuts 459
Deection heads 460
Angled mirrors 461
Accessories for ber optics

Adapters 462
Holders 462
Cutting tool 462
Optics 462
Adapter lens 463
Deection head 463
Focus lens 463
Metal helical tube 463
Optical ber 463
Lenses 464
www.balluff.com 419
Round reectors
Reectors are assigned to the

accessories that we mark in gray.
Size Reector 84 mm Reector 62 mm Reector 51 mm

Fasteners M4 screw Two M4 screws Rivet with mounting tabs
Ordering code BAM00UK BAM0126 BAM00UP
Part number BOS R-1 BOS R-10 BOS R-14
Material PMMA/ABS PMMA/ABS PC
Cube size 4 mm 4 mm 4 mm
Mounting accessories BOS 21-AD-1
Special features More chemical resistant
Reectivity rating 100% 60% 60%

Fasteners Glue Glue Glue
Ordering code BAM00UW BAM00W4 BAM00UR
Material PMMA/ABS PMMA/ABS PC
Cube size 2.5 mm 2 mm 2 mm
Special features More chemical resistant
Temperature range 20...+60 C 20...+60 C 20...+99C
Reectivity rating 60% 25% 25%

Block-shaped reectors
Photoelectric
sensors
Size Reector 100100 mm Reector 100100 mm Reector 8484 mm Reector 5172 mm Reector 6040 mm Photoelectric
Fasteners Two M3 screws Two M3 screws Two M3 screws Two M4 screws Two M3 screws standard
sensors
Ordering code BAM01CN BAM01JN BAM00UL BAM00UZ BAM01JP
Part number BOS R-37 BOS R-47 BOS R-11 BOS R-25 BOS R-46 Photoelectric
Material PC PMMA/ABS PMMA/ABS PMMA PMMA/ABS special
sensors
Cube size 4 mm 4 mm 4 mm 4 mm 4 mm
Temperature range 20...+100 C 20...+60 C 20...+60 C 0...+50 C 20...+60 C Photoelectric
Reectivity rating 125% distance
sensors
for analog
distance
9.0
40
7.5 34 measurement
9
2.50 Special
accessories for
photoelectric
52
60
sensors
100
92
Reectors
92.0
100.0
Fasteners
3.5
Sensor
accessories
92.0 92
Accessories for
ber optics
100.0 100
Size Reector 5161 mm Reector 3542 mm Reector 2380 mm Reector 18120 mm

Fasteners Two M4 screws Two M3 screws Two M4 screws Two M4 screws
Ordering code BAM00WL BAM00W0 BAM01LA BAM00WA
Part number BOS R-9 BOS R-26 BOS R-48 BOS R-5
Material PMMA/ABS PMMA PMMA/ABS PMMA/ABS
Cube size 4 mm 4 mm 4 mm 4 mm
Mounting accessories BOS 5-HW-5
Temperature range 20...+60 C 0...+50 C 20...+60 C 20...+60 C
Reectivity rating 100% 40%
7.5 23
4.5
71
59
80
www.balluff.com 421
Block-shaped reectors


Fasteners Side screws Rear and side screws Rear screws
Ordering code BAM00W3 BAM00W1 BAM00W2
Material PMMA PMMA PMMA
Cube size 2.3 mm 2.3 mm 2.3 mm
Mounting accessories BOS 5-HW-1/2 BOS 5-HW-1/2
Reectivity rating
Size Reector 1860 mm Reector 2340 mm

Fasteners Two M4 screws Two M4 screws
Ordering code BAM00W7 BAM01T3
Part number BOS R-33 BOS R-52
Material PMMA/ABS PMMA/ABS
Cube size 4 mm 0.9 mm
Mounting accessories
Temperature range 20...+60 C 20...+60 C
Reectivity rating
8.0
11.0
4.0
32.0
40.0
M4
23.0

Reectors for special applications
Photoelectric
sensors

Photoelectric
Fasteners Two M3 screws Two M3 screws Two M3 screws Two M1.5 screws standard
Ordering code BAM00W8 BAM01CM BAM01HE BAM01NH sensors
Photoelectric
Material Hot thermoplastic PMMA/ABS Solidchem Hot thermoplastic special
Cube size 4 mm 4 mm 4 mm 0.9 mm sensors
Special features Heat-resistant Anti-fogging Chemical-resistant Heat-resistant;
Photoelectric
For laser applications distance
Temperature range 20...+150C 20...+60 C 20...+140C 20...+110C sensors
for analog
Reectivity rating distance
measurement
40 40 40 1
Special
2
7.5 34 7.5 34 7.5 34
accessories for
photoelectric
sensors
23
19
Reectors
52
60
52
60
52
60
Fasteners
9.7 4.9
M3
M3
M3
Sensor
13.8 accessories
Accessories for
3.5 3.5 3.5 ber optics
Size Reector 52 mm Reector 10x62 mm

Fasteners Clamps
Ordering code BAM01H6 BAM01KU
Part number BOS R-31 BOS R-51
Material Borosilicate PMMA/ABS
Cube size 4 mm 3 mm
Special features Glass reector
Temperature range 20...+500C 20...+60C
Reectivity rating
18.0
9
8.0
5
9.0 3.0
3.0(X2)
39.9
60.0
50.0
5
52
www.balluff.com 423
Reectors for laser retroreective sensors


Fasteners Two M4 screws Two M3 screws Two M1.5 screws M3 screw
Ordering code BAM00UY BAM01H9 BAM00UM BAM01H8
Material PMMA/ABS PMMA/ABS PMMA/ABS PMMA/ABS
Cube size 1.2 mm 1.2 mm 0.9 mm 0.9 mm
Mounting accessories BOS 5-HW-6
Special features For laser retroreective
sensors
Reectivity rating 100%(Laser) 40%(Non-laser) 100%(Laser) 30%(Non-laser)
5.8
3.7
2
8
M3
M3
11
10
25 11
31
40

Reectors for laser retroreective sensors
Photoelectric
sensors
Reector 25 mm Reector 25 mm Reector 21 mm Reector 19 mm Reector 10 mm

Photoelectric
Glue M4 screw Glue M3 screw M3 screw standard
BAM00UN BAM01HC BAM00UT BAM01HA BAM01H7 sensors
BOS R-13 BOS R-43 BOS R-16 BOS R-42 BOS R-38
Photoelectric
PMMA/ABS PMMA/ABS PMMA/ABS PMMA/ABS PMMA/ABS special
1.2 mm 1.2 mm 1.2 mm 0.9 mm 0.9 mm sensors
Photoelectric
For laser retroreective distance
sensors sensors
for analog
20...+60 C 20...+60 C 20...+60 C 20...+60 C 20...+60 C distance
100%(Laser) 40%(Non-laser) 100%(Laser) 40%(Non-laser) measurement
Special
accessories for
5.6
7.5
4.4
photoelectric
sensors
8
9
8
Reectors
M4 M3 M3 Fasteners
Sensor
accessories
Accessories for
ber optics
19 10
25
www.balluff.com 425
Reective foils

Size Reective tape (standard) Reective tape (standard) Reective tape (standard)
(not for polarized light)
Fasteners Self-adhesive Self-adhesive Self-adhesive
100 Ordering code BAM01JM
100 mm Part number BOS R-50
50 mm Ordering code BAM00WC
25 cm Part number BOS R-6-0,25
50 mm Ordering code BAM00WE
45 m Part number BOS R-6-45
50 mm Ordering code BAM00WF
50 mm x Ordering code BAM019L BAM019J
1m Part number BOS R-7-1 BOS R-6-1
50 mm Ordering code BAM00WH
50 mm x Ordering code BAM019K BAM019H
100 m Part number BOS R-7-0,1 BOS R-6-0,1
25 mm Ordering code BAM00WJ
25 mm x Ordering code
1m Part number
25 mm Ordering code BAM00WK
25 mm x Ordering code BAM019M
100 mm Part number BOS R-8-0,1
Material PMMA PMMA PMMA
Special features Not for polarized light

Reectivity rating 40% 40%

Reective foils
Photoelectric
sensors
Reex foil Reex foil Reective tape Reective tape Reective tape
Photoelectric
4035 mm 10050 mm 300200 mm standard
Self-adhesive Self-adhesive Self-adhesive Self-adhesive Self-adhesive sensors
BAM00W9 BAM00W5 BAM01CF BAM01HF
Photoelectric
BOS R-35 BOS R-30 (standard) BOS R-40 BOS R-45 special
BAM019T sensors
BOS R-17-0,25
Photoelectric
distance
sensors
for analog
distance
measurement
BAM019P
Special
BOS R-171 accessories for
BAM00UU photoelectric
sensors
BOS R-17-22
Reectors
BAM019R Fasteners
BOS R-17-0,1 Sensor
accessories
Accessories for
ber optics
BAM019N
BOS R-8-1
Foil Foil PMMA PMMA PMMA

Micro glass balls Micro glass balls Special for laser sensors Standard and laser
non polarized non polarized sensors for large surfaces
20...+60 C 20...+60 C 20...+60 C 20...+60 C 20...+60 C
50% 40%
0.8
0.5
0.5
50.0
50.0
300
250.0 L
200
www.balluff.com 427
Mounting brackets

Description Mounting bracket Mounting bracket Mounting bracket Mounting bracket

Use For BOS 2K For BOS 2K For BOS 2K For BOS 5K
Ordering code BAM00T4 BAM00T6 BAM00T5 BAM00U5
Part number BOS 2-HW-1 BOS 2-HW-2 BOS 2-HW-3 BOS 5-HW-1
Description Mounting bracket Mounting bracket

Use For BOS 21K For BOS 21K
Ordering code BAM00T9 BAM00TA
Part number BOS 21-HW-1 BOS 21-HW-2

Mounting bracket
Photoelectric
sensors
Mounting bracket Mounting bracket Mounting bracket

Photoelectric
For BOS 5K For BOS 5K For BOS 6K and BOS 21M standard
BAM00U6 BAM00U7 BAM00UH sensors
BOS 5-HW-2 BOS 5-HW-3 BOS 6-HW-1
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories for
ber optics
Mounting bracket Mounting bracket Mounting bracket

For BOS 21K For BOS 21K For BOS 25K, BOS 26K, BOS 21M
BAM00TC BAM00TE BAM00TK
BOS 21-HW-3 BOS 21-HW-4 BOS 26-HW-1
www.balluff.com 429
Mounting brackets
Stainless Stainless
Reectors are assigned to the Steel Steel


Use For BOS 23K For BOS 23K
Ordering code BAM01FK BAM01FM
Part number BAM MB-X0-006-B05-4 BAM MB-X0-007-B05-4
Material Stainless steel Stainless steel
27 27
2 2
15.5 15.5
4.3
4.3
50
50
25
25
13.5
13.5
32
32 64.5
64.5 26.58
26.58
14.58
14.58
30
32
30
32
30
30
9.9
.9 R2
9
R2
R2
9.9
30
R2
9.9
30

Mounting bracket
Stainless
Steel
Photoelectric
sensors
Description Mounting bracket

Photoelectric
Use For BOS 50K/23K standard
Ordering code BAM01E8 sensors
Part number BAM MB-X0-005-B04-4
Photoelectric
Material Stainless steel special
sensors
46 Photoelectric
32 2 distance
4.
5 R5 sensors
R3
for analog
distance
measurement
R2
R6
R2
1
.7
Special
5
accessories for
98.5
93.5
86.5
photoelectric
5.5
77.2
75.7
sensors
65.7
Reectors
25.5
Fasteners
Sensor
23 32 accessories
29 Accessories for
54 ber optics
61.3
www.balluff.com 431
Mounting brackets

Description Mounting bracket Mounting bracket Mounting bracket

Use For BOS 18 For BOS 18F/BOS 18KW For BOS 18
Ordering code BAM00RY BAM00RZ BAM00T0
Part number BOS 18,0-HW-1 BOS 18,0-HW-2 BOS 18,0-HW-3
2 35 25 2
18.5
18.5
18.5 14.5 4 2
35
32
35
20
20
35
R12
28
20
43
4.4
17.5
12
20 12
25
35
12
43
25
12
12 R5
25 12 R5
35 R5 35 4

Use For BOS 18 For BOS 18 laser sensors
Ordering code BAM00T1 BAM00T2
Part number BOS 18,0-HW-4 BOS 18,0-HW-6
18.5 2 42
40
30
M181
30
40
50
140
125
50
100
6.5
10.8
10
8
4.25
25 4 6.5 3
35

Mounting brackets
Photoelectric
sensors
Description Mounting bracket Mounting bracket Mounting bracket

Photoelectric
Use For BOS 74K For BOS R-26 reectors standard
sensors
Ordering code BAM00UJ BAM00U8 BAM00U9
Photoelectric
Part number BOS 74-HW-1 BOS 5-HW-4 BOS 5-HW-5 special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories for
ber optics
Description Mounting bracket

Use For BOS R-9 and
BOS R-22
Ordering code BAM00UA
Part number BOS 5-HW-6
www.balluff.com 433
Mounting brackets
Deection heads and angled mirrors are

assigned to the accessories that we mark
in gray.
Description Dual axis adjustable Dual axis adjustable Dual axis adjustable
Use Small block Small block Small block
Ordering code BAM00UC BAM00UE BAM00UF
Part number BOS 5-HW-7 BOS 5-HW-8 BOS 5-HW-9
Suitable product BOS 5K BOS 5K BOS 5K
Material Stainless steel Zinc-plated steel Zinc-plated steel
6.5
14
14
6
24.2
1.51
21.3
5 3.4 x 6.35 3.2 TYP 4
21.5 R25.4
13
7.6
7
7 1.22 7 9.2 29
4.8
16.7
26.29
56 24.2
7
3.9
9
25.4
5.8
13.7
5.5
31.2
12
19
3.2
64
25.4 12.61
60.2
4.2
65
3.2 29.0
Typ 4 TYP 2
40.5
12
13
15
Description Protective mount Dual axis adjustable
Use Mid-size block Mid-size block
Ordering code BAM0155
Part number BOS 26-HW-7 BTL 31M-HW-1
Suitable product BOS 26K BLT 31M
Material Painted steel Anodized Aluminum
30
Rad 0.35
Rad 26.0
O .19
.40 .40
17.5
3.45
4.0
6.5 Typ 2 O .19 Typ.

2.50
4 places
2.0
9.25
.125
30.8
.75
61.58 .50
70 3.42
1.50 1.25
16.19
2.0
.25
42.08
7.2X15 .50 Typ

54.19
4.2 4 places
.50
70
7.2
HEX
4.2x11.7
16.19 26.5
42.08
54.19

Mounting brackets
Photoelectric
sensors
Description Adapter bracket
Use Mounting adapter Photoelectric
sensors
Part number BOS 18.0-BS-3
Suitable product BOS 18KF, BOS 18KW
Photoelectric
Material Durethan special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories for
ber optics
www.balluff.com 435
Mounting brackets
Description Swivel adjustable mounting bracket

Use 12 mm Tubular
Part number BOS 12.0-BS-1
Suitable product 12 mm tubular
Material ABS

Mounting brackets for tubular sensors
D
Clamp for tubular sensors 8 mm or M8
D
BES 08-KB-1 8
Material: PA6
Photoelectric
sensors
Photoelectric
standard
sensors
Photoelectric
Clamp for tubular sensors M12 and M18 (stackable) special
sensors
A B C D
BES 12-KB-2 16 40 25 12 Photoelectric
BES 18-KB-2 22 45 30 18 distance
sensors
Material: PA6 for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Clamping cuff Fasteners
A B C D E F G H I J Sensor
accessories
BES 08.0-BS-1 17 27 16 7.9 12 8 4.5 4.5 8 1
Accessories for
BES 12.0-BS-1 22 32 20 11.9 12 8 4.5 4.5 10 1 ber optics
BES 18.0-BS-1 26 36 26 17.9 12 8 4.5 4.5 13 1
Material: PA6
Snap clamp with positive stop

A B C D E F
BES 08.0-KB-5-F 12 20 15 8 7 22
BES 12.0-KB-5-F 16 24 18 12 8 30
BES 18.0-KB-5-F 21 29 24 18 14 30

Material: Plastic PC 33 41 34.5 30 24 35
Note: All units are in mm
www.balluff.com 437
SuperShorties "L" mounting bracket
BES 08-HW-4 12x17.5x16 mm

Material: Stainless steel
Universal "L" mounting bracket

A B C D E F G H
BES 516-MB-08 76 34 29 17 31 19 8 6
BES 516-MB-12 76 34 29 17 31 19 12 6
BES 516-MB-18 76 34 29 17 31 19 18 6
Material: Carbon steel
Slotted angle bracket (screws and washers included)

A B C D E F G H I
BES 08-HW-1 25 30 30 8.1 12 7 4 6 14
BES 12-HW-1 25 30 30 12.1 9 8.5 4 6 14
BES 16-HW-1 40 40 16.1 12 5 18
Material: Aluminum30 12 10
BES 18-HW-1 30 40 40 18.1 11 12 5 10 18
BES 24-HW-1 35 50 40 24.1 13 16 5 10 23
BES 30-HW-1 40 60 40 30.1 18 19 5 10 30
BES 36-HW-1 50 60 40 36.1 13 21 5 10 40

Mounting nuts
Description Mounting Nuts
Photoelectric
sensors
Photoelectric
standard
sensors
Photoelectric
special
sensors
Photoelectric
distance
sensors
metal nut plastic nut for analog
distance
measurement
Ordering Code Ordering code = Part no.
Special
accessories for
Metal nuts Part no. Material d wrench h photoelectric
Material sensors
M81 500557 steel galvanized 15 13 4 Reectors
M121 500462 Ms nickel plated 20 17 4 Fasteners
M181 500152 Ms nickel plated 28 24 4 Sensor
accessories
Stainless steel nuts Accessories for
ber optics
M121 636981 1.4305 (303) 20 17 4
M181 636982 1.4301 (304) 28 24 4
Plastic nuts
M121 507936 PA 6.6 19.7 17 6
M181 606841 PA 6.6 28 24 8
Spring type lockwasher for M5 sensors: part no. 710256

Toothed lockwasher for M8 sensors: part no. 500558
www.balluff.com 439
Mounting brackets for 8x8 block sensors
Description Compression Block Mount for Set Screw Block Mount for
8mm x 8mm Sensors 8mm x 8mm Sensors
Ordering Code BES Q08-KH-1 BES Q08-HW-4
Material Anodized Aluminum Anodized Aluminum
Description 8mm Channel Extruded Rail Mount for 10mm Channel Extruded Rail Mount for
8mm x 8mm Cable-out Sensors 8mm x 8mm Cable-out Sensors
59.8 60
42.5
42.5
M2 set screw
M2 set screw
12.1
12
M5 set screw
M5 set screw
7.9
10
Ordering Code BES Q08-KH-2 BES Q08-KH-3
Material Plated Copper Alloy Plated Copper Alloy

Mounting cuff, clamping blocks, clamping holder, adapter plate
Mounting cuffs, clamping blocks, clamping holder,

adapter plate and apertures are assigned Photoelectric
to the accessories that we have marked in gray. sensors
Description Mounting cuff Mounting clamp with ball joint Mounting clamp with ball joint Photoelectric
Use For cylindrical sensors For cylindrical sensors For cylindrical sensors standard
sensors
with M12 outside thread with M18 outside thread with M30 outside thread
Ordering code BAM01KM BAM00T3 BAM00TN
Photoelectric
Part number BOS 12,0-KB-1 BOS 18,0-KB-1 BOS 30,0-KB-1 special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories for
ber optics
Description Clamping holder Clamping holder Adapter plate

Use Sensors with dovetail for BOS Sensors with dovetail for BOS For BOS 21M, BOS 25K,
21M 21M BOS 26K and BOS R-1
Ordering code BAM00TF BAM00TH BAM00T7
Part number BOS 21-KH-1 BOS 21-KH-2 BOS 21-AD-1
www.balluff.com 441
BMS mounting systems
With the complete Balluff accessories line, you are well equipped Balluff accessories in use
for optimal integration of your sensors into your automation process. For adapting sensors to a specic application
This is because reliable products make assembly easier than you For simplifying work during installation and alignment
ever thought possible. Only at Balluff will you nd the eccentric For protecting the sensors
clamp which requires no tools and attaches the sensor with just a As an interface to the controller
click. Sensor integration has never been so easy.
Ease of handling comes standard with all our products.
The accessory line is designed specically for our sensors, and posi-
tions sensors quickly and precisely. It saves time, lowers your costs
and increases the machine availability.
Mounting system BMS

Designed for industrial automation
Sensors must be positioned inside plants, machines or conveyor
systems, usually during the setup process. Modular elements from
nce here. The
the Balluff mounting system provide valuable assistance
exible Balluff mounting system can be mounted on base plates and
king area can be
all standard proles. Almost every corner of the working
covered using the versatile range of accessories.

Sensor Holder Reector Holder Cross-Connector

for 1 rod 12 mm or 1010 mm for 1 rod 12 mm or 1010 mm for 2 rods 12 mm or 1010 mm
for cylindrical sensors for all reectors with 20 mm (glue) and connecting element for 2 rods
BOS R-14 51 mm (pluggable) 12 mm or 1010 mm
Photoelectric
sensors
Photoelectric
standard
sensors
Photoelectric
special
sensors
A
BMS CS-...08 8 Photoelectric
BMS CS-...12 12 distance
BMS CS-...8 18 sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
BMS CS-P-D12-AD08-00 for M8 sensors BMS CR-P-D12-AU-00 BMS CC-P-D12-A-00 Reectors
BMS CS-P-D12-AD12-00 for M12 sensors Fasteners
BMS CS-P-D12-AD18-00 for M18 sensors Sensor
accessories
POM plastic POM plastic POM plastic Accessories for
ber optics
www.balluff.com 443
Sensor Mount Sensor Mount Sensor Mount

for clamping cylinder for clamping cylinder for clamping cylinder
for cylindrical sensors M8, M12, M18 for cylindrical sensors M30 for use with prox mounts
.2
D
0
42
3
R1
4
8.5 3
1 C
47
A
34
26
20
3
3
B
33
28 34 33 28
19
A B C D
ID16 36.5 20 16.5 33
20
A
18
19
ID24 41.5 24 24.5 35
A ID36 54.0 30 36.5 48
BMS CS-...08 8.5
PX2349
PX2350
BMS CS-...12 12.5

R1
BMS CS-...18 18.5
0
4
2
BMS CS-M-D12-ID08-01 for M8 sensors BMS CS-M-D12-ID30-01 BMS CS-M-D12-ID16-01

BMS CS-M-D12-ID12-01 for M12 sensors BMS CS-M-D12-ID24-01
BMS CS-M-D12-ID18-01 for M18 sensors BMS CS-M-D12-ID36-01
V4A V4A V4A
Mounting Bracket Mounting Bracket

for clamping cylinder for clamping cylinder
for UniCompact sensors for UniCompact sensors
40 40
30 5 30
5
5
14.7
14.7
39.8
39.8
13 9.5
45
9.5 13
45
60
8(2x) 16 8(2x)
60
65
16
65
80
86
80
19.8
19.8
102
1.5
1.5
111
121
5.6(2x)
5.3(6X) 5.6(2x) 5.3(6X)
34
60 20
26
20
3
5.3(2X)
21
26
30
40
5(2X)
31
43
55
31 60
43
55
BMS CS-M-D12-IQ40-02 BMS-M-D12-IQ40-03
V4A V4A
Description Reector Mount Reector Mount Reector Mount

Type for BOS R1 + R2 + R3 for BOS R1 + R2 + R3 for BOS R11
Application for clamping cylinders for clamping cylinders for clamping cylinders
85
4 77
4
3
Photoelectric
8 3 sensors
92.5
5.3 4
77
85
3.5
50.5
Photoelectric
R1
standard
.5
sensors
20
3
27
36 28 Photoelectric
22 93 21 special
sensors
20
PX2352
Photoelectric
distance
sensors
for analog
distance
Ordering Code BMS CR-M-D12-IU-02 BMS CR-M-D12-IU-05 BMS CR-M-D12-IS-03 measurement
Material V4A V4A V4A Special

accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories for
ber optics
Description Sensor Adapter Plate Sensor Adapter Plate

Type for BOS 21/25/26 for BOS 21/25/26
Application for base holder with 40 mm hole spa- for base holder with 40 mm hole
cing or clamping cylinders spacing or clamping cylinders
114
105
99
110 65
50 5 54
46
41
6.6
.6 5.5
10
0 15
4
30
37
12.5
10
9
9
17.5
50
20
60
30
M5
30
37
M5
42.5
50
55
36.8
M4
20
35
60
6.6
20 3 M4
M4
45
M4
95
50
120
5
3
PX2363
Ordering Code BMS CS-M-D12-BX01-01 BMS CS-M-D12-BX05-02
Material Al anodized Al anodized
www.balluff.com 445
Reector mount Mounting Rod Mounting Rod

for BOS R9 for reectors R1, R9, R14, R22, R26 for BOS 2K, BOS 5K, BOS 6K, BES/BOS Q08
for clamping cylinders for base holder 12 mm for base holder 12 mm
11.95 11.95
150
200.5
4
250
250
2M3 4M3
2M4
6.5 4
15
25
49.6
11.2
10.5
40.5
34.3
20
3.8
4.5
25.3
21.5
15.3
16.5
10
PX2369
PX2368
M5 2.7
BMS CR-M-D12-IS-04 BMS BS-M-D12-0250-01 BMS BS-M-D12-0250-02
V4A Al anodized Al anodized
Mounting Rod Mounting Rod

for BGL 5A...80A for BGL 80A...220A
for base holder 12mm for base holder 12mm
11.95 11.95
120
120
M4 (8x) M4 (6x)
400
250
276
126
117.5
250
167
95.5
159
85.5
150
77.5
62.5
90
54.5
50
42.5
34.5
11.75 8 11.75 8
Mounting rods 12 mm, anodized Al

BMS BS-M-D12-0250-03 BMS BS-M-D12-0400-04 BMS RS-M-D12-0150-00 = 150 mm
BMS RS-M-D12-0250-00 = 250 mm
Al anodized Al anodized BMS RS-M-D12-1000-00 =1000 mm

Description Sensor adjustment tool Adapter bracket

Type for BGL for BGL
Application for ne positioning for ne positioning
9.52
12.7 10 9.5 8 8 4.5
25.6
45
(CX02)
Photoelectric
9.52
sensors
12.7 20 12.5 8 4.5
50
62.7
Photoelectric
(CX03) standard
sensors
44.7
20
Photoelectric
20
30
special
20 20 20 8 sensors
50 46.95
12.7 40 98 Photoelectric
distance
(CX04) sensors
Ordering Code for analog
distance
All BGLs BMS CS-M-D12-CZ measurement
BGL 5 - 20 mm BMS CS-M-D12-CX02-01
BGL 30 - 80 mm BMS CS-M-D12-CX03-01 Special
BGL 120 - 220 mm BMS CS-M-D12-CX04-01 accessories for
photoelectric
sensors
Reectors
Kits Available: Fasteners
BMS CS-M-D12-CX02-01-Z = BMS CS-M-D12-CZ and BMS CS-M-D12-CX02-01 Sensor
accessories
BMS CS-M-D12-CX03-01-Z = BMS CS-M-D12-CZ and BMS CS-M-D12-CX03-01 Accessories for
ber optics
BMS CS-M-D12-CX04-01-Z = BMS CS-M-D12-CZ and BMS CS-M-D12-CX04-01

BMS RS-M-D12-0150-00 = 150 mm
BMS RS-M-D12-0250-00 =250 mm
BMS RS-M-D12-1000-00 =1000 mm
www.balluff.com 447
NEW! BMS Mounting Kits
M10 x 40mm bolt and M10 nut

BMS CS-M-D12-ID08-01
BMS CS-M-IQ40-02
BMS CS-M-D12-IZ
Kit Number
BMS KIT-MTG-01-D08/40
BMS KIT-MTG-01-Q40/40
Kit Components Description
These kits provide BMS CS-M-D12-IZ Joint, Rotary Mounting type
you the convenience BMS CS-M-D12-ID08-01 Bracket, for standard M8 sensors
of all the parts you BMS CS-M-D12-ID12-01 Bracket, for M8 sensor prox mounts or standard M12 sensors
need in a single box. BMS CS-M-D12-ID16-01 Bracket, for M12 sensor prox mounts
BMS CS-M-D12-ID18-01 Bracket, for standard M18 sensors
BMS CS-M-D12-ID24-01 Bracket, for M18 sensor prox mounts
BMS CS-M-D12-ID30-01 Bracket, for standard M30 sensors
BMS CS-M-D12-ID36-01 Bracket, for M30 sensor prox mounts
BMS CS-M-IQ40-02 Bracket, 40x40mm Cube Sensor Mount
M10 x 40mm bolt and M10 nut M10 x 40mm bolt with M10 x 1.5 nut, black oxide
Tubular Sensors Only Tubular Sensors with Prox Mount Unicompact Sensor
Balluff Sensor BMS CS-D12-IZ Balluff Sensor Mounting screws BMS CS-M-IQ40-02
(Mounting Knuckle) (Mounting Bracket)
BMS CS-D12-IZ Q40 Sensor
Prox Mount (Mounting Knuckle)
BMS CS-D12-IZ
(Mounting Knuckle)
M10 bolt
BMS CS-M-D12-IDXX-01 BMS CS-M-D12-IDXX-01 M10 bolt
(Mounting Bracket) M10 bolt
(Mounting Bracket)
M10 nut Sensing
M10 nut surface
M10 nut

BMS Mounting Systems Description Base Holder Articulated Base Holder
Type for 1 rod 12 mm or 1010 mm for 1 rod 12 mm
Balluff offers high-quality Application for mounting on base plates or rails for mounting on base plates or rails
mounting accessories for opti-
mally positioning the sensors
in systems and machines. The
mounting system can be at-
tached to base plates or on all
common extrusion rails. The
kit design means that virtually Photoelectric
any required solid angle can sensors
be accommodated. Additional
Photoelectric
accessories such as reector standard
holders and adapter plates, sensors
usable for tubular and block-
style sensors, complete the Photoelectric
special
accessories kit. sensors
Photoelectric
distance
sensors
for analog
distance
Ordering Code BMS CU-P-D12-A040-00 BMS CUJ-P-D12-R040-00 measurement
Special
accessories for
photoelectric
sensors
Material POM plastic POM plastic
Reectors
Note: Stainless steel screws included. Fasteners
Sensor
accessories
Accessories for
ber optics

Description Rod Adapter
BMS RS-M-D12-0150-00 = 150 mm
Type for 1 rod 10 mm
BMS RS-M-D12-0250-00 = 250 mm
Application converts a 10 mm rod
BMS RS-M-D12-1000-00 = 1000 mm
to a 12 mm rod
27
The mounting rods are knurled over 12

the full length. This prevents slipping
10
and position shifting.
11.95
145 145
150 Ordering Code BMS AD-P-001-12/10
Material POM plastic

www.balluff.com 449
Holding system
Mounting rods are knurled all the way around.

This prevents any position change.
Holding systems are assigned to the

Description Holding system

Use For exible mounting; for all cylindrical sensors with M18 outside thread and 88 sensors.
May be combined with other Balluff accessories.
Ordering code BAM00R8
Part number BOS 18-HS-1

Holding system
Photoelectric
sensors
Photoelectric
standard
sensors
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories for
ber optics
Description Holding system

Use For sensors in series BOS 21M.
May be combined with other Balluff accessories.
Ordering code BAM00T8
Part number BOS 21-HS-1
View A
www.balluff.com 451
Apertures
Description Round aperture Double slit aperture Slit aperture

Use For BLE/BLS 18 For BLE/BLS 18 For BLE/BLS 12M
Ordering code BAM00R6 BAM00R7 BAM00PW
Part number BOS 18-BL-1 BOS 18-BL-2 BOS 12-BL-1
Aper- Aper- Range Aper- Aper- Range Slit Range Object
ture on ture on ture on ture on width size
emitter receiver emitter receiver
8 mm 3 mm 1 mm 0.5 mm > 1 mm
8 mm 2 mm 1.5 mm 1 mm > 1.5 mm
2 mm 2 mm 2 mm 2 mm > 2 mm
Advantages:
The round and slit apertures Small parts detection, i.e.
restrict the beam diameter. This 1 mm drill, aperture on emitter
allows you to detect small parts only
over a large range. The emitter Through-beams may be
and receiver must be exactly mounted close to one another
aligned with each other. Highly reective parts directly
next to the light path do not
interfere.

Apertures

accessories that we mark in gray. Photoelectric
sensors
Description Vertical slit aperture Vertical slit aperture Vertical slit aperture
Photoelectric
Use For BOS 5K For BOS 5K For BOS 5K standard
through-beam sensors through-beam sensors through-beam sensors sensors
Ordering code BAM00TU BAM00TW BAM00TY
Photoelectric
Part number BOS 5-BL-1 BOS 5-BL-2 BOS 5-BL-3 special
Aperture size 0.5 mm, vertical 1 mm, vertical 2 mm, vertical sensors
Range* 1.0 (2.5 m) 1.5 (3.5 m) 3.5 (6 m)
Photoelectric
Min. object* 0.5 (7 mm) 1.0 (7 mm) 2.0 (7 mm) distance
Packaging unit 2 pcs. 2 pcs. 2 pcs. sensors
for analog
distance
*Values in brackets apply to slit measurement
apertures on one side
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories for
ber optics
Description Horizontal slit aperture Horizontal slit aperture Horizontal slit aperture
Use For BOS 5K For BOS 5K For BOS 5K
through-beam sensors through-beam sensors through-beam sensors
Ordering code BAM00TZ BAM00U0 BAM00U1
Aperture size 0.5 mm horizontal 1 mm horizontal 2 mm horizontal
Range* 0.7 (2 m) 1.5 (3 m) 3.0 (5.5 m)
Min. object* 0.4 (7 mm) 0.7 (7 mm) 1.5 (7 mm)
Packaging unit 2 pcs. 2 pcs. 2 pcs.
*Values in brackets apply to slit

www.balluff.com 453
Apertures, weld protection
Description Round aperture Round aperture Round aperture

Use For BOS 5K For BOS 5K For BOS 5K
through-beam sensors through-beam sensors through-beam sensors
Ordering code BAM00U2 BAM00U3 BAM00U4
Aperture size 0.5 mm 1 mm 2 mm
Range* 0.08 (0.8 m) 0.3 (1.5 m) 1.2 (2.5 m)
Min. object* 0.3 (5 mm) 0.6 (5 mm) 1.5 (7 mm)
Packaging unit 2 pcs. 2 pcs. 2 pcs.
*Values in brackets apply to slit


Apertures, weld protection
Photoelectric
sensors
Photoelectric
standard
sensors
Sensor not Sensor not Photoelectric

included in the included in the special
standard scope standard scope sensors
of delivery! of delivery!
Photoelectric
Description Weld protection Weld protection distance
Use For BOS 23K For BOS 50K sensors
for analog
distance
Ordering code BAM01L8 BAM01U6 measurement
Part number BAM PC-XO-006-23K-1 BAM PC-XO-006-50K-1
Special
accessories for
30.8 30.8 photoelectric
sensors
Reectors
28.1
15.5
22.5
15.5
Fasteners
25.4
19.9 Sensor
accessories
Accessories for
ber optics
59.3
92.3
16.5
16.5
34.3
34.3
www.balluff.com 455
Planoconvex lens, polarizing lter, air tube
Description Planoconvex lens Polarizing lter Air shield Air shield

Use For all BOS 18 Only for For BOS 12 For BOS 18
diffuse sensors for BOS 18M-...-1RD... and tube with 4 mm and tube with 4 mm
background suppression inner diameter inner diameter
and small parts detection
Focal length/focus
Ordering code BAM00RF BAM00RE BAM00PY BAM00R9
Part number BOS 18-PK-1 BOS 18-PF-1 BOS 12-LT-1 BOS 18-LT-1
Material Housing: PA6 Housing: PA6
Planoconvex lens: glass Polarization lter:
IR polarization
Benets Polarizing lters are used The air tube with a The air tube with a
Sensing distance for reliably sensing highly compressed air source compressed air source
adjustable 0...40 mm reective objects. prevents premature prevents premature
Low switching point They prevent faulty contamination of the contamination of the
shift, e.g. for switching. optics. optics.
different colors or
surface properties Reecting or shiny parts
Background will then not cause faulty
suppression facilitates switching. The polarizing
detection of objects on lters guarantee that only
reective background the light reected back
Small parts detection by the reector is de-
down to 0.05 mm tected. They reduce the
through focusing sensing range by 50%.
planoconvex lens with
a working range of
approx. 0...13 mm

Lenses, intermediate ring
Photoelectric
sensors
Lens Lens Lens Lens Intermediate ring

Photoelectric
For BKT 67 For BKT 67 For BKT 67 For BKT 67 Intermediate ring with lens standard
for increasing the standard lenses for increasing the for increasing the for increased resolution sensors
sensing distance (light spot 1.54 mm) sensing distance sensing distance for BKT 67 in combination
Photoelectric
(light spot 27 mm) (light spot 28 mm) (light spot 2.511 mm) with M-PK-2. special
It is screwed in between sensors
the sensor and the 9 mm Photoelectric
lens. distance
for analog
BAM0120 BAM0121 BAM0122 BAM00P3 BAM00P2 distance
BKT M-PK-1 BKT M-PK-2 BKT M-PK-3 BKT M-PK-5 BKT M-PK-4 measurement
Lens: glass Lens: glass Lens: glass Lens: glass Lens: glass
Special
Version: aluminum Version: aluminum Version: aluminum Version: aluminum Version: aluminum accessories for
photoelectric
sensors
Reectors
33 33 25 Fasteners
20 20
Sensor
accessories
Accessories for
ber optics
4
15.5
11.5
25.5
21.5
48
32
6
www.balluff.com 457
Neutral density lters
Description Cover nut Cover nut

Use For BOS 08 For BOS 12
Transmission
Ordering code BAM01Y5 BAM01Y6
Part number BAM PC-X0-005-08M-4 BOS PC-XO-005-12M-4
12
M8x1
10
The protective end cap (cap nut) is made

with tempered glass and can be used with
all M12 photoelectric sensors.
The protective glass is used to protect the
optics from mechanical or thermal damage,
such as weld splatter.

Protective nuts
Photoelectric
sensors
Cover nut Cover nut

Photoelectric
For BOS 18 For BOS 18 with at front surface standard
sensors
BAM00RL BAM01NC
Photoelectric
BOS 18-SM-1 BAM PC-XO-005-18M-4 special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories for
ber optics
The protective end cap is made with The protective cap can be used in combina-
tempered glass and can be used with all tion with all BOS 18M and BOS 18K sensors.
M18 photoelectric sensors. It protects the sensor optics from external
The protective glass is used to protect the effects, such as welding splatter.
optics from mechanical or thermal damage, For increased protection, the BOS 18-SM-2
such as weld splatter. is made of metal, providing even better
protection for the sensor optics. The heat-
protecting glass closes off ush with the front
surface of the cover nut. This prevents dust
deposits from forming, which can impact the
range.
A ring between the sensor and protective
glass makes sure the system is sealed.
www.balluff.com 459
Deection heads
Description 90 deection head 90 deection head 90 deection head

Use For diffuse, retroreective For diffuse, retroreective For diffuse, retroreective
and through-beam sensors and through-beam sensors and through-beam sensors
BOS 18 (except laser) BOS 18 (except laser) BOS 18
Ordering code BAM00RP BAM00RT BAM00RR
Part number BOS 18-UK-1 BOS 18-UK-2 BOS 18-UK-10
BOS 18-UK-1 BOS 18-UK-2 BOS 18-UK-10

Diffuse sensor
BOS 18...-XA-...100 mm RF = 45 % RF = 50 %
BOS 18...-XB-...200 mm RF = 25 % RF = 50 %
BOS 18...-PB-...200 mm RF = 25 % RF = 50 %
BOS 18...-XD-...400 mm RF = 25 % RF = 30 %
BOS 18...-PD-...400 mm RF = 25 % RF = 30 %
BOS 18...-RB-...2 m RF = 20 % RF = 20 %
BOS 18...-RD-...4 m RF = 20 % RF = 20 %
Through-beam sensor
BLE 18...-P-...16 m RF = 15 % RF = 30 %
BLS 18...-XX-...16 m RF = 15 % RF = 30 %
Range 100%
Deection heads, suitable combinations
Emitter Receiver
All BOS 18 photoelectric sensors can be equipped with a 90
deection head. Emitter Receiver
The table shows the appropriate deection head for each switch
type and indicates the corresponding reduction factor (RF) to
apply to the range. With a through-beam sensor, the emitter and Emitter Receiver
the receiver can be equipped with a 90 deection head. Each
deection head reduces the range by approx. 15% ... 50%.
Emitter Receiver

Angled mirrors
Photoelectric
sensors
Angled mirror Angled mirror

Photoelectric
For diffuse and through-beam For laser through-beam standard
sensors BOS 12 sensors BOS 12 sensors
Photoelectric
BAM00R0 BAM00R1 special
BOS 12-WS-1 BOS 12-WS-2 sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories for
ber optics
When using the angled mirror, the sensing range is reduced by

30% for the M12 diffuse and M12 through-beam sensors. Not suit-
able for retroreective sensors.
www.balluff.com 461
Adapter, holder, cutting tool, optics
Description Adapter Holder Lens (Long Range) Optics (adjustable)

Use For BFO 18V glass ber For glass ber optics screwed to ber optics screwed to ber optics
optics for connecting to and sensors with a BFO00C4, BFO00C4,
BOS 30M M8 corresponding 400 mm 200 mm
diameter true-color sensor true-color sensor
Ordering code BAM00NM BAM00P0 BAM01PA BAM01U2
Part number BFO 30-A1 BFO 08,0-KB-1 BAM LS-FO-001-M6-L BAM LS-FO-002-F
19
3.4
25.1
20.1
18
32...38
M3 x 0.35
38.9
10
BFO D22...
13
M18x1
M6 x 0.75
24
Description Adapter Adapter Cutting tool
Use For plastic ber optics For plastic ber optics For trimming
1 mm for connecting to ber 1.3 mm for connecting to plastic ber optics
optic base units ber optic base units 1 mm or 2.2 mm
Ordering code BAM0003 BAM00P1 BAM000E

Part number BFO D10-LA-DC-10 BFO D13-LA-EC-10 BFO CT
Packaging unit 2 pcs. 2 pcs. 1 pc.

Adapter lens, deection head,
focus lens, metal helical tube, optical ber
Photoelectric
sensors
Description Adapter lens 90 deection head Focus lens Focus lens

Photoelectric
Use For through-beam optical For through-beam optical For coaxial diffuse sensor For coaxial diffuse sensor standard
bers M2.60.45 bers M2.60.45 optical bers M40.7 optical bers M40.7 sensors
Ordering code BAM00NN BAM00NP BAM00NR BAM00NT
Photoelectric
Part number BFO 02-PK-1 BFO 02-UK-1 BFO 04-FL-1 BFO 04-FL-2 special
Sensing distance/range with 10 0.7 19 mm2 mm 7 mm2 mm sensors
corresponding ber optics
Photoelectric
Packaging unit 2 pcs. 2 pcs. 1 pc. 1 pc. distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories
for ber optics
Description Optical ber M4 Optical ber M6 Metal corrugated tube Metal corrugated tube
with SMA connector with SMA connector (stainless steel) (stainless steel)
Use For BFS000L For BFS000L For ber optics M60.75 For ber optics M40.7
True color sensor True color sensor
Ordering code BFO00C9 BFO00C4 BAM00NY BAM00NU
Part number BFO D22-XB-UB-EAK-15-SA1-02 BFO D22-XB-LB-EAK-15-SA1-02 BFO 06-FS-1 BFO 04-FS-1
Sensing distance/range with 80 mm 80 mm
corresponding ber optics
www.balluff.com 463
Lenses
Neutral Filter Protective Lens Cap Protective Lens Cap

for BOS 18M for BOS 12M for BOS 18M
BOS 18-NF-_* BOS 12-SM-1 BOS 18-SM-2
* 1 = 50 % Transmission, 2 = 75 % Transmission
Neutral lters reduce the Protective cap with plastic Protective cap with glass lens
amount of light transmitted (or lens suitable for all BOS 12M suitable for all BOS 18M sen-
received) by a photoelectric sensors. Adds a layer of sors. Adds a layer of protec-
sensor. protection from mechanical tion from mechanical damage
The lens material is made damage as well as heat. as well as heat.
of a specialized glass that
works effectively with all wave-
lengths of light. Typical appli-
cations include sensor testing,
where a specic excess gain
level is required or specialized
congurations, where an emit-
ter needs to be dampened to
reduce the amount of light as
to not "burn-thru" an object.

Photoelectric
sensors
Photoelectric
standard
sensors
Photoelectric
special
sensors
Photoelectric
distance
sensors
for analog
distance
measurement
Special
accessories for
photoelectric
sensors
Reectors
Fasteners
Sensor
accessories
Accessories
for ber optics
www.balluff.com 465
Inductive
Sensors
Inductive sensors for object detection
Automation is almost inconceivable without inductive sensors.
Wherever processes are automated, non-contact position detection,
freedom from wear, and reliability are in demand. Whether in
machine building, automation technology, electronics manufacturing
or the plastics industry, in textile machines, wood processing or in the
automobile industry Balluff sensors monitor, control and automate
processes and states. Providing the highest quality and optimized
for any application. From standard to extended switching distance,
from temperature and high pressure rated to "Factor 1" from mini
to maxi: You too can take advantage of Balluff's versatility in your
applications. And prot from the reliability and quality of proven
products from your full-line provider.

Inductive Sensors
Contents
Inductive sensors Inductive sensors with special properties

Introduction 468 High-pressure sensors 643
Product overview 470 Strokemaster sensors 660
Steelface sensors 664
DC 3-wire inductive global sensors High temperature sensors 670
Tubular housings 476 Harsh environment sensors 674
Factor 1 sensors 684
DC 3-/4-wire inductive sensors Weld eld immune sensors 696
Tubular housings 493 Large designs 704
Block housings 552 Ring sensors 710
Tube sensors 714
DC 2-wire inductive sensors
Tubular housings 595 Inductive Sensors for analog distance measurement
Block housings 606 Tubular housings 720
Block housings 731
AC/DC 2-wire inductive sensors
Tubular housings 615 Accessories for inductive sensors
Block housings 623 Pulse stretching 736
Sensor tester, testing and setting device 741
AC 2-wire inductive sensors Analog switching devices 743
Tubular housings 634 Assembly aids for Uni and Unicompact sensors 744
Block housings 639 Protective coverings for Unicompact sensors 747
Protective nuts 748
Positive stop 750
Tube switch 752
Banking screw autuators 754
Cushioned Prox mounts 756
Mounting clamps for tubular sensors 758
Prox mounts for tubular sensors 761
Bunker Blocks 762
Weld Repel 763 Basic information
and denitions
Mounting brackets for 8x8 block sensors & seal nuts 764 can be found
on page 952.
Mounting brackets for block sensors 766
Sensor protection devices 767
www.balluff.com 467
Inductive Sensors
Introduction
3-/4-Wire

Inductive Sensors
Introduction
Inductive
Sensors
Introduction
Product
overview
Global
DC 3-wire
DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
AC 2-wire
Special
properties
Analog
distance
measurement
Accessories
www.balluff.com 469
Inductive Sensors
Product overview
Housing size 3 mm, M50.5 M81, M121 M161 M181

4 mm, 6.5 8 mm
M40.5
Inductive sensors
DC 3-wire Global page 476 page 481 page 484
DC 3-/4-wire page 492 page 498 page 512 page 530 page 538
page 503
DC 2-wire page 595 page 597 page 600
AC/DC 2-wire page 615 page 617
AC 2-wire page 634 page 636
Inductive Sensors with Special Properties

High pressure sensors page 643 page 651 page 643 page 648 page 650
page 651 page 645 page 659
page 590 page 653
Steelface sensors page 665 page 666 page 667
High temperature sensors page 670 page 670 page 670 page 671
page 673
Sensors for harsh environments page 674 page 676
Factor 1 sensors page 685 page 686 page 689
Weld eld immune sensors page 697 page 699
Large housing
Tube sensors
Ring sensors
Inductive distance sensors for analog distance measurement

Tubular-style housings page 721 page 722 page 725
Block housings
Ring sensors

Inductive Sensors
Product overview
M301.5 55 mm 88 mm 816 mm 1030 mm 16.530 mm 2032 mm 99x17.6 mm

R04 R03 R01
Inductive
page 487 Sensors
Introduction
page 547 page 553 page 556 page 562 page 566 page 568 page 569
Product
page 603 page 606 overview
Global
page 620 DC 3-wire
page 637 DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
AC 2-wire
Special
page 669 page 669 properties
Analog
page 671 distance
measurement
page 673
page 677 Accessories
page 692
page 701 page 702
page 728
page 731
www.balluff.com 471
Inductive Sensors
Product overview
Housing size 2550 mm 2626 mm 2640 mm 4248 mm 7460.5 mm 4040 mm
Inductive sensors
DC 3-wire Global
DC 3-/4-wire page 571 page 572 page 574 page 575 page 577
DC 2-wire page 607 page 608
AC/DC 2-wire page 623 page 625
AC 2-wire

High pressure sensors
Steelface sensors
High temperature sensors page 671
Sensors for harsh environments
Factor 1 sensors page 693
Weld eld immune sensors page 703
Large housing
Tube sensors
Ring sensors
Inductive distance sensors for analog distance measurement

Tubular-style housings
Block housings

Inductive Sensors
Product overview
40x40 mm 8080 mm 3535 mm 80x67 mm 110x110 mm Ring Tube

sensors sensors
Inductive
Sensors
Introduction
page 581 page 588
Product
page 609 page 610 overview
Global
page 627 page 631 DC 3-wire
page 639 DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
AC 2-wire
Special
properties
Analog
distance
measurement
Accessories
page 715
page 711
page 734
www.balluff.com 473
Inductive
Sensors
DC 3-wire inductive Global Sensors
DC 3-wire
3 wire inductive global sensors: Global sensors are
the most economical sensors from the Balluff group. These
standardized sensors are readily available and are ideal for
general-puropse applications

DC 3-wire Inductive Global Sensors
Contents
Tubular design
M81 476
M121 481
M181 484
M301.5 487
www.balluff.com 475
Tubular housing, M81
Global: Performance and value in inductive proximity sensors

Balluff Global sensors are proven performers that are globally
standarized with an optimum price point ratio.
Short and mid-size designs M8 to M301.5
Shielded and unshielded designs
Cable and connector versions
Standard and extended switching distance
Housing size M8 1 M8 1 M8 1
Installation type (observe instructions in Basic Information chapter) Flush Flush Flush
Rated switching distance sn 1.5 mm 1.5 mm 1.5 mm
Assured switching distance sa 0...1.2 mm 0...1.2 mm 0...1.2 mm
Sensing distance 1X 1X 1X
PNP, NO Ordering code BES00CJ BES00CH BES003C
Part number BES M08EE-PSC15B-S49G-003 BES M08EE-PSC15B-S04G-003 BES M08MI-PSC15B-S49G
PNP, NC Ordering code BES00CC BES00CA BES03P6
Part number BES M08EE-POC15B-S49G-003 BES M08EE-POC15B-S04G-003 BES M08MI-POC15B-S49G
NPN, NO Ordering code BES00C7 BES00C6 BES002K
Part number BES M08EE-NSC15B-S49G-003 BES M08EE-NSC15B-S04G-003 BES M08MI-NSC15B-S49G
NPN, NC Ordering code BES00C3 BES00C2 BES03PK
Part number BES M08EE-NOC15B-S49G-003 BES M08EE-NOC15B-S04G-003 BES M08MI-NOC15B-S49G
Voltage drop Ud at Ie max. 2.5 V 2.5 V 2V
Rated insulation voltage Ui (protection class) 250 V AC ([) 250 V AC ([) 75 V DC
Rated operating current Ie 200 mA 200 mA 200 mA
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes
Ambient temperature Ta 25...70 C 25...70 C 25...70 C
Switching frequency f max. 1 kHz 1 kHz 1 kHz
Approvals CE, cULus CE, cULus CE, cULus
Material Housing Stainless steel Stainless steel Brass-coated
Sensing surface PBT PBT PA 12
Suggested mating cable BCC M313-0000-10-001-VX43T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013 BCC M313-0000-10-001-VX43T2-020-C013
See technical section (page 963-966) M8x1 M8x1

for installation instructions.
13 13
For wiring diagram see page 958.
28.5
29.5
Additional cable lengths and PUR cable jacket material

40
43
available on request.
LED LED
M8x1
M12x1

Inductive
M8 1 M8 1 M8 1 M8 1 M8 1 sensors
Flush Flush Flush Flush Flush
Global
1.5 mm 1.5 mm 1.5 mm 2 mm 2 mm DC 3-wire
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.6 mm 0...1.6 mm Tubular
1X 1X 1X 2X 2X housings
BES0027 BES00CU BES0037 BES00CK BES00FC Block
housings
BES M08MH1-PSC15B-S04G BES M08EF-PSC15B-BP02-003 BES M08MI-PSC15B-BV02 BES M08EE-PSC20B-S49G-003 BES M08EE-PSC20B-S04G-003
BES0026 BES00CR BES0030 BES00CF BES00CE DC 3-/4-wire
BES M08MH1-POC15B-S04G BES M08EF-POC15B-BP02-003 BES M08MI-POC15B-BV02 BES M08EE-POC20B-S49G-003 BES M08EE-POC20B-S04G-003
DC 2-wire
BES0024 BES00CN BES002F BES00C9 BES00C8
BES M08MH1-NSC15B-S04G BES M08EF-NSC15B-BP02-003 BES M08MI-NSC15B-BV02 BES M08EE-NSC20B-S49G-003 BES M08EE-NSC20B-S04G-003 AC/DC 2-wire
BES0023 BES00CL BES03PJ BES00C5 BES00C4
AC 2-wire
BES M08MH1-NOC15B-S04G BES M08EF-NOC15B-BP02-003 BES M08MI-NOC15B-BV02 BES M08EE-NOC20B-S49G-003 BES M08EE-NOC20B-S04G-003
12...30 V DC 10...30 V DC 12...30 V DC 10...30 V DC 10...30 V DC Special
2V 2.5 V 2V 2.5 V 2.5 V properties
75 V DC 250 V AC ([) 75 V DC 250 V AC ([) 250 V AC ([) Analog
200 mA 200 mA 200 mA 200 mA 200 mA distance
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes measurement
25...70 C 25...70 C 25...70 C 25...70 C 25...70 C Accessories

1 kHz 1 kHz 1 kHz 700 Hz 700 Hz
IP 67 IP 67 IP 67 IP 67 IP 67
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus
Brass-coated Stainless steel Brass-coated Stainless steel Stainless steel
PA 12 PBT PA 12 PBT PBT
M12 connector, 4-pin 2 m PUR cable, 26 AWG 2 m PVC cable, 26 AWG M8 connector, 3-pin M12 connector, 4-pin
BCC M415-0000-1A-003-VX44T2-020-C013 BCC M313-0000-10-001-VX43T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013
M8x1 M8x1 M8x1
13 13
13
28.5
29.5
40
40
43
LED LED
LED M8x1
M12x1
www.balluff.com 477
Rated switching distance sn 2 mm 2 mm 2 mm
PNP, NO Ordering code BES003P BES0028
Part number BES M08MI-PSC20B-S49G BES M08MH1-PSC20B-S04G
PNP, NC Ordering code BES0033 BES03T5
Part number BES M08MI-POC20B-S49G BES M08MH1-POC20B-S04G
NPN, NO Ordering code BES002U BES0025 BES045P
Part number BES M08MI-NSC20B-S49G BES M08MH1-NSC20B-S04G BES M08EF-NSC20B-BP00,3-GS49
NPN, NC Ordering code BES03TJ BES03T6
Part number BES M08MI-NOC20B-S49G BES M08MH1-NOC20B-S04G
Voltage drop Ud at Ie max. 2.5 V 2.5 V 2.5 V
Rated insulation voltage Ui (protection class) 75 V DC 75 V DC 250 V AC ([)
Switching frequency f max. 700 Hz 700 Hz 700 Hz
Degree of protection as per IEC 60529 IP 67 IP 67 IP 68 per BWN Pr. 20
Material Housing Brass-coated Brass-coated Stainless steel
Sensing surface PA 12 PA 12 PBT
Connection M8 connector, 3-pin M12 connector, 4-pin 0.3 m PUR cable
with M8 connector, 3-pin
Suggested mating cable BCC M313-0000-10-001-VX43T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013 BCC M313-0000-10-001-VX43T2-020-C013
See technical section (page 963-966) M8x1

M8x1
For wiring diagram see page 958. 13

40
37
LED

M8 1 M8 1 M8 1 M8 1 M8 1
Flush Flush Flush Non-ush Non-ush
2 mm 2 mm 2 mm 4 mm 4 mm
0...1.6 mm 0...1.6 mm 0...1.6 mm 0...3.2 mm 0...3.2 mm
2X 2X 2X 2X 2X Inductive
BES003E BES00CW BES003K BES000M BES001J sensors
BES M08MI-PSC20B-BP00,2-GS04 BES M08EF-PSC20B-BP02-003 BES M08MI-PSC20B-BV02 BES M08EB-PSC40F-S49G BES M08EH-PSC40F-S49G Global
BES00CT BES03TH BES000L BES001F DC 3-wire
BES M08EF-POC20B-BP02-003 BES M08MI-POC20B-BV02 BES M08EB-POC40F-S49G BES M08EH-POC40F-S49G Tubular
housings
BES00CP BES002P BES000K BES001C
Block
BES M08EF-NSC20B-BP02-003 BES M08MI-NSC20B-BV02 BES M08EB-NSC40F-S49G BES M08EH-NSC40F-S49G housings
BES00CM BES03TF BES000J BES0019
DC 3-/4-wire
BES M08EF-NOC20B-BP02-003 BES M08MI-NOC20B-BV02 BES M08EB-NOC40F-S49G BES M08EH-NOC40F-S49G
12...30 V DC 10...30 V DC 12...30 V DC 10...30 V DC 10...30 V DC DC 2-wire
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
75 V DC 250 V AC ([) 75 V DC 250 V AC ([) 250 V AC ([) AC/DC 2-wire
200 mA 200 mA 200 mA 200 mA 200 mA AC 2-wire
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes
25...70 C 25...70 C 25...70 C 25...70 C 25...70 C Special
properties
700 Hz 700 Hz 700 Hz 1.5 kHz 1.5 kHz
Yellow LED Yellow LED Yellow LED Yellow LED Yellow LED Analog
IP 67 IP 67 IP 67 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 distance
measurement
Brass-coated Stainless steel Brass-coated Stainless steel Stainless steel Accessories
PA 12 PBT PA 12 PBT PBT
0.2 m PUR cable 2 m PUR cable, 2 m PVC cable, M8 connector, 3-pin M8 connector, 3-pin
with M12 connector, 4-pin 26 AWG 26 AWG
BCC M415-0000-1A-003-VX44T2-020-C013 BCC M313-0000-10-001-VX43T2-020-C013 BCC M313-0000-10-001-VX43T2-020-C013
M8x1 M8x1 M8x1
14.5 5
13 13
13 M12x1
40
50
49
60
46
LED
LED
LED
M8x1
www.balluff.com 479
Installation type (observe instructions in Basic Information chapter) Non-ush Non-ush Non-ush
PNP, NO Ordering code BES001H BES000Z BES0017
Part number BES M08EH-PSC40F-S04G BES M08ED-PSC40F-BV02 BES M08EG-PSC40F-BV02
PNP, NC Ordering code BES001E BES000W BES0015
Part number BES M08EH-POC40F-S04G BES M08ED-POC40F-BV02 BES M08EG-POC40F-BV02
NPN, NO Ordering code BES001A BES000T BES0013
Part number BES M08EH-NSC40F-S04G BES M08ED-NSC40F-BV02 BES M08EG-NSC40F-BV02
NPN, NC Ordering code BES0018 BES000P BES0011
Part number BES M08EH-NOC40F-S04G BES M08ED-NOC40F-BV02 BES M08EG-NOC40F-BV02
Rated insulation voltage Ui (protection class) 250 V AC ([) 250 V AC ([) 250 V AC ([)
Switching frequency f max. 1.5 kHz 1.5 kHz 1.5 kHz
Degree of protection as per IEC 60529 IP 67 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20
Material Housing Stainless steel Stainless steel Stainless steel
Sensing surface PBT PA 12 PBT
Connection M12 connector, 4-pin 2 m PVC cable, 26 AWG 2 m PVC cable, 26 AWG
Suggested mating cable BCC M415-0000-1A-003-VX44T2-020-C013

5

51
65.5
LED
M12x1

M121 M121 M121 M121 M121

0...1.6 mm 0...1.6 mm 0...1.6 mm 0...1.6 mm 0...3.2 mm
BES00EE BES0060 BES00E4 BES005U BES00EF sensors
BES M12ME-PSC20B-S04G-003 BES M12MI-PSC20B-S04G BES M12MD-PSC20B-BP02-003 BES M12MI-PSC20B-BV02 BES M12ME-PSC40B-S04G-003 Global
BES00EA BES005F BES00E2 BES00FP BES00EC DC 3-wire
BES M12ME-POC20B-S04G-003 BES M12MI-POC20B-S04G BES M12MD-POC20B-BP02-003 BES M12MI-POC20B-BV02 BES M12ME-POC40B-S04G-003 Tubular
housings
BES00E8 BES0054 BES00E0 BES00FL BES00E9
Block
BES M12ME-NSC20B-S04G-003 BES M12MI-NSC20B-S04G BES M12MD-NSC20B-BP02-003 BES M12MI-NSC20B-BV02 BES M12ME-NSC40B-S04G-003 housings
BES00E6 BES004Y BES00CY BES03PR BES00E7
DC 3-/4-wire
BES M12ME-NOC20B-S04G-003 BES M12MI-NOC20B-S04G BES M12MD-NOC20B-BP02-003 BES M12MI-NOC20B-BV02 BES M12ME-NOC40B-S04G-003
2V 2.5 V 2V 2.5 V 2.5 V
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) AC/DC 2-wire
25...70 C 25...70 C 25...70 C 25...70 C 25...70 C Special
1.2 kHz 1.2 kHz 1.2 kHz 1.2 kHz 300 Hz properties
IP 67 IP 68 per BWN Pr. 20 IP 67 IP 68 per BWN Pr. 20 IP 67 distance
measurement
Brass-coated Brass-coated Brass-coated Brass-coated Brass-coated Accessories
PBT PA 12 PBT PA 12 LCP
M12 connector, 4-pin M12 connector, 4-pin 2 m PUR cable, 22 AWG 2 m PVC cable, 22 AWG M12 connector, 4-pin
BCC M415-0000-1A-003-VX44T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013
M12x1 M12x1
17 17
30
30
33
45
LED
LED
M12x1
www.balluff.com 481
Housing size M121 M121 M121

PNP, NO Ordering code BES0068 BES00E5 BES0064
Part number BES M12MI-PSC40B-S04G BES M12MD-PSC40B-BP02-003 BES M12MI-PSC40B-BV02
PNP, NC Ordering code BES005N BES00E3 BES005L
Part number BES M12MI-POC40B-S04G BES M12MD-POC40B-BP02-003 BES M12MI-POC40B-BV02
NPN, NO Ordering code BES0059 BES00E1 BES00FM
Part number BES M12MI-NSC40B-S04G BES M12MD-NSC40B-BP02-003 BES M12MI-NSC40B-BV02
NPN, NC Ordering code BES004Z BES00CZ BES03PT
Part number BES M12MI-NOC40B-S04G BES M12MD-NOC40B-BP02-003 BES M12MI-NOC40B-BV02
Degree of protection as per IEC 60529 IP 68 per BWN Pr. 20 IP 67 IP 68 per BWN Pr. 20
Material Housing Brass-coated Brass-coated Brass-coated
Sensing surface PA 12 LCP PA 12
Connection M12 connector, 4-pin 2 m PUR cable, 22 AWG 2 m PVC cable, 22 AWG

17
30
33

LED

M121 M121 M121

Non-ush Non-ush Non-ush
8 mm 8 mm 8 mm
0...6.4 mm 0...6.4 mm 0...6.4 mm
2X 2X 2X Inductive
BES01PY BES004N BES004M sensors
BES M12MD-PSC80F-S04G BES M12MG-PSC80F-S04G BES M12MG-PSC80F-BV02 Global
BES01PU BES004K BES004J DC 3-wire
BES M12MD-POC80F-S04G BES M12MG-POC80F-S04G BES M12MG-POC80F-BV02 Tubular
housings
BES01PT BES004F BES004E
Block
BES M12MD-NSC80F-S04G BES M12MG-NSC80F-S04G BES M12MG-NSC80F-BV02 housings
BES01PR BES004A BES0049
DC 3-/4-wire
BES M12MD-NOC80F-S04G BES M12MG-NOC80F-S04G BES M12MG-NOC80F-BV02
10...30 V DC 10...30 V DC 10...30 V DC DC 2-wire
2.5 V 2.5 V 2.5 V
250 V AC ([) 250 V AC ([) 250 V AC ([) AC/DC 2-wire
200 mA 200 mA 200 mA AC 2-wire
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes
25...70 C 25...70 C 25...70 C Special
800 Hz 800 Hz 800 Hz properties
Yellow LED Yellow LED Yellow LED Analog
IP 68 per BWN Pr. 20 IP 67 IP 67 distance
measurement
CE, cULus CE, cULus CE, cULus
Brass-coated Brass-coated Brass-coated Accessories
PBT PBT PBT
M12 connector, 4-pin M12 connector, 4-pin 2 m PVC cable, 22 AWG
BCC M415-0000-1A-003-VX44T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013
www.balluff.com 483

Assured switching distance sa 0...4 mm 0...4 mm 0...4 mm
PNP, NO Ordering code BES00EY BES0086 BES00EN
Part number BES M18ME-PSC50B-S04G-003 BES M18MI-PSC50B-S04G BES M18MD-PSC50B-BP02-003
PNP, NC Ordering code BES00EU BES043J BES00EL
Part number BES M18ME-POC50B-S04G-003 BES M18MI-POC50B-S04G BES M18MD-POC50B-BP02-003
NPN, NO Ordering code BES00ER BES00EJ
Part number BES M18ME-NSC50B-S04G-003 BES M18MD-NSC50B-BP02-003
NPN, NC Ordering code BES03T7 BES03T8
Part number BES M18ME-NOC50B-S04G-003 BES M18MD-NOC50B-BP02-003
Voltage drop Ud at Ie max. 2V 2.5 V 2V
Rated insulation voltage Ui (protection class) 75 V DC 250 V AC ([) 75 V DC
Degree of protection as per IEC 60529 IP 67 IP 68 per BWN Pr. 20 IP 67
Sensing surface PA 12 PA 12 PA 12
Connection M12 connector, 4-pin M12 connector, 4-pin 2 m PUR cable, 22 AWG
Suggested mating cable BCC M415-0000-1A-003-VX44T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013

24
29.5

44.5
LED
M12x1

M181 M181 M181 M181 M181

0...4 mm 0...6.4 mm 0...6.4 mm 0...6.4 mm 0...6.4 mm
BES0082 BES00EZ BES008L BES00EP BES008E sensors
BES M18MI-PSC50B-BV02 BES M18ME-PSC80B-S04G-003 BES M18MI-PSC80B-S04G BES M18MD-PSC80B-BP02-003 BES M18MI-PSC80B-BV02 Global
BES007R BES00EW BES03RP BES00EM BES03PY DC 3-wire
BES M18MI-POC50B-BV02 BES M18ME-POC80B-S04G-003 BES M18MI-POC80B-S04G BES M18MD-POC80B-BP02-003 BES M18MI-POC80B-BV02 Tubular
housings
BES007A BES00ET BES007L BES00EK BES00FE
Block
BES M18MI-NSC50B-BV02 BES M18ME-NSC80B-S04G-003 BES M18MI-NSC80B-S04G BES M18MD-NSC80B-BP02-003 BES M18MI-NSC80B-BV02 housings
BES03RR BES03RN BES0077 BES00EH BES03T4
DC 3-/4-wire
BES M18MI-NOC50B-BV02 BES M18ME-NOC80B-S04G-003 BES M18MI-NOC80B-S04G BES M18MD-NOC80B-BP02-003 BES M18MI-NOC80B-BV02
2.5 V 3.5 V 2.5 V 3.5 V 2.5 V
250 V AC ([) 75 V DC 250 V AC ([) 75 V DC 250 V AC ([) AC/DC 2-wire
25...70 C 25...70 C 25...70 C 25...70 C 25...70 C Special
properties
700 Hz 150 Hz 1 kHz 150 Hz 150 Hz
IP 68 per BWN Pr. 20 IP 67 IP 67 IP 67 IP 68 per BWN Pr. 20 distance
measurement
PA 12 PBT PBT PBT PA 12
2 m PVC cable, 22 AWG M12 connector, 4-pin M12 connector, 4-pin 2 m PUR cable, 22 AWG 2 m PVC cable, 22 AWG
M18x1
24
29.5
44.5
LED
M12x1
www.balluff.com 485
Housing size M181 M181

Installation type (observe instructions in Basic Information chapter) Non-ush Non-ush
Rated switching distance sn 16 mm 16 mm
Assured switching distance sa 0...13 mm 0...13 mm
Sensing distance 2X 2X
PNP, NO Ordering code BES03RM BES006Z
Part number BES M18MG-PSC16F-S04G BES M18MG-PSC16F-BV02
PNP, NC Ordering code BES03RL BES006U
Part number BES M18MG-POC16F-S04G BES M18MG-POC16F-BV02
NPN, NO Ordering code BES006P
Part number BES M18MG-NSC16F-BV02
NPN, NC Ordering code BES006L
Part number BES M18MG-NOC16F-BV02
Voltage drop Ud at Ie max. 2.5 V 2.5 V
Rated insulation voltage Ui (protection class) 75 V DC ([) 250 V AC ([)
Rated operating current Ie 200 mA 200 mA
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes Yes/Yes/Yes
Ambient temperature Ta 25...70 C 25...70 C
Switching frequency f max. 800 Hz 800 Hz
Approvals CE, cULus CE, cULus
Material Housing Brass-coated Brass-coated
Sensing surface PBT PBT

10

24
50
65
LED
M12x1

Tubular housing, M301.5
M301.5 M301.5 M301.5 M301.5 M301.5

10 mm 10 mm 10 mm 10 mm 10 mm
0...8 mm 0...8.1 mm 0...8.1 mm 0...8.1 mm 0...8.1 mm
BES00F8 BES00A4 BES00A3 BES00F3 BES00A0 sensors
BES M30ME-PSC10B-S04G-003 BES M30MI-PSC10B-S04K BES M30MI-PSC10B-S04G BES M30MD-PSC10B-BP02-003 BES M30MI-PSC10B-BV02 Global
BES00F6 BES009P BES043H BES03TC BES009M DC 3-wire
BES M30ME-POC10B-S04G-003 BES M30MI-POC10B-S04K BES M30MI-POC10B-S04G BES M30MD-POC10B-BP02-003 BES M30MI-POC10B-BV02 Tubular
housings
BES00F5 BES009H BES00F0 BES009C
Block
BES M30ME-NSC10B-S04G-003 BES M30MI-NSC10B-S04K BES M30MD-NSC10B-BP02-003 BES M30MI-NSC10B-BV02 housings
BES03TA BES0097 BES03TE BES0096
DC 3-/4-wire
BES M30ME-NOC10B-S04G-003 BES M30MI-NOC10B-S04K BES M30MD-NOC10B-BP02-003 BES M30MI-NOC10B-BV02
3.5 V 2.5 V 2.5 V 3.5 V 2.5 V
75 V DC 250 V AC ([) 75 V DC 75 V DC 250 V AC ([) AC/DC 2-wire
25...70 C 25...70 C 25...70 C 25...70 C 25...70 C Special
properties
150 Hz 400 Hz 400 Hz 150 Hz 400 Hz
IP 67 IP 68 per BWN Pr. 20 IP 67 IP67 IP 68 per BWN Pr. 20 distance
measurement
PA 12 PA 12 PA 12 PA 12 PA 12
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin 2 m PUR cable, 22 AWG 2 m PVC cable, 22 AWG
BCC M415-0000-1A-003-VX44T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013
M30x1.5 M30x1.5 M30x1.5
36 36
30
30
36
36
44.5
50.5
65
LED LED
M12x1 LED
M12x1
www.balluff.com 487
Housing size M301.5 M301.5 M301.5

Assured switching distance sa 0...12 mm 0...12.2 mm 0...12.2 mm
PNP, NO Ordering code BES00F9 BES00AH BES00AF
Part number BES M30ME-PSC15B-S04G-003 BES M30MI-PSC15B-S04K BES M30MI-PSC15B-S04G
PNP, NC Ordering code BES00F7 BES009U BES03RK
Part number BES M30ME-POC15B-S04G-003 BES M30MI-POC15B-S04K BES M30MI-POC15B-S04G
NPN, NO Ordering code BES009J
Part number BES M30MI-NSC15B-S04K
NPN, NC Ordering code BES0098
Part number BES M30MI-NOC15B-S04K
Rated insulation voltage Ui (protection class) 75 DC 250 V AC ([) 250 V AC ([)
Suggested mating cables BCC M415-0000-1A-003-VX44T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013 BCC M415-0000-1A-003-VX44T2-020-C013
See technical section (page 963-966)

M30x1.5 M30x1.5

30
Additional cable lengths and PUR cable jacket material 36

44.5
50
available on request. 65
LED
M12x1
LED
M12x1

M301.5 M301.5 M301.5 M301.5 M301.5

Flush Flush Non-ush Non-ush Non-ush
15 mm 15 mm 30 mm 30 mm 30 mm
0...12 mm 0...12.2 mm 0...24 mm 0...24 mm 0...24 mm
BES00F4 BES00AA BES00AZ BES03RE BES00AY sensors
BES M30MD-PSC15B-BP02-003 BES M30MI-PSC15B-BV02 BES M30MM-PSC30F-S04K BES M30MM-PSC30F-S04G BES M30MM-PSC30F-BV02 Global
BES00F2 BES009T BES00AU BES03RC BES00AT DC 3-wire
BES M30MD-POC15B-BP02-003 BES M30MI-POC15B-BV02 BES M30MM-POC30F-S04K BES M30MM-POC30F-S04G BES M30MM-POC30F-BV02 Tubular
housings
BES00F1 BES03RH BES00AP BES00AN
Block
BES M30MD-NSC15B-BP02-003 BES M30MI-NSC15B-BV02 BES M30MM-NSC30F-S04K BES M30MM-NSC30F-BV02 housings
BES03RJ BES00AL BES00AK
DC 3-/4-wire
BES M30MI-NOC15B-BV02 BES M30MM-NOC30F-S04K BES M30MM-NOC30F-BV02
3.5 V 2.5 V 2.5 V 2.5 V 2.5 V
75 V DC 250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) AC/DC 2-wire
25...70 C 25...70 C 25...70 C 25...70 C 25...70 C Special
properties
75 Hz 100 Hz 300 Hz 300 Hz 300 Hz
IP 67 IP 67 IP 67 IP 67 IP 67 distance
measurement
PA 12 PA 12 PBT PBT PBT
2 m PUR cable, 22 AWG 2 m PVC cable, 22 AWG M12 connector, 4-pin M12 connector, 4-pin 2 m PVC cable, 22 AWG
M30x1.5 M30x1.5
36
13
36
30
36
67
83
LED
LED
M12x1
www.balluff.com 489
Inductive
Sensors
DC 3-/4-wire inductive tubular sensors
Balluff's largest and most popular sensor family DC 3 and 4 wire sensors
are used extensivily around the world. Available from 3 mm to 8080 mm
for practically every application in automation. These high-quality sensors are
designed and manufactured according to worldwide standards and the latest
technology. Our 100 % nal inspection of all products guarantees that only
carefully tested sensors leave our plants. Balluff DC 3 and 4 wire sensors are
available with PNP, NPN, and complementary outputs and come with Balluff's
lifetime warranty.

DC 3-/4-wire Inductive Tubular Sensors
3-/4-Wire Contents
Tubular housings
3 mm 493
4 mm 494
M40.5 497
M5x0.5 498
6.5 mm 502
8 mm 512
M81 513
M121 530
M181 538
M301.5 547
Block designs
55 mm 552
88 mm 556
8164 mm (R04) 562
10306 mm (R03) 566
302010 mm 567
163010 mm 568
20328 mm (R01) 569
205010 mm 571
264012 mm (R05) 572
424822 mm 574
7460.528 mm 575
4040 mm (Unicompact) 577
4040 mm (Unisensor) 581
8080 mm (Maxisensor) 588
www.balluff.com 491
Inductive mini-sensors
High-performance and
compact
Inductive mini-sensors are ideal
for position sensing in rough en-
vironments, and stand out due to
an optimum price/performance
ratio. They are easy to install and Housing size
can be fully integrated even in Installation type (observe instructions in the Basic Information chapter)
narrow assemblies such as linear Rated switching distance sn
units, valves and actuators. As Assured switching distance sa
a result, position sensing is now Sensing distance
possible where there was never PNP, NO Ordering code
space for a sensor before. Appli- Part number
cation tooling can be made even PNP, NC Ordering code
smaller. The low weight of the Part number
mini-sensors allows applications NPN, NO Ordering code
with extremely fast acceleration, Part number
so that pick-and-place is easy to Supply voltage UB
manage. Voltage drop Ud at Ie max.
Rated insulation voltage Ui
Rated operating current Ie
Polarity reversal protected/transposition protected/short-circuit protected
Switching frequency f max.
Approvals
Special properties
Material Housing
Sensing surface
Connection
Suggested mating cable


SuperShorties and slim designs

Inductive mini sensors are available with especially small diameter:
with 3 mm, 4 mm and 5 mm. They are also available as compact
short housings, with lengths of just 6 mm offering the shortest
inductive sensors on the market.
The most compact on the market: can be fully integrated

Unmatched in thinness and, as SuperShorty, unmatched in their
short length
Low weight (0.7 g) for extreme accelerations

3-/4-Wire Tubular housing, 3 mm
Flush Flush Flush Flush Non-ush
0...0.8 mm 0...0.8 mm 0...0.8 mm 0...0.8 mm 0...2.3 mm
BES0468 BES00M5 BES00M3 BES00MH sensors
BES 516-3044-G-E4-C-S26-00,3 BES 516-3044-G-E4-C-S49-00,3 BES 516-3044-G-E4-C-PU-02 BES 516-3048-G-E4-C-S26-00,3 Global
BES0415 BES00M7 DC 3-wire
BES G03ED-POC10B-EP00,3-GS49 BES 516-3045-G-E4-C-PU-02
DC 3-/4-wire
BES00M9
Tubular
BES 516-3046-G-E4-L-PU-02 housings
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 21.6...26.4 V DC Block
housings
2.5 V 2.5 V 2.5 V 1.5 V 2.5 V
75 V DC 75 V DC 75 V DC 75 V DC 75 V DC DC 2-wire
100 mA 100 mA 100 mA 100 mA 50 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/No Yes/Yes/Yes AC/DC 2-wire
25...+70C 25...+70C 25...+70C 0...+70 C 0...+70 C AC 2-wire
2 kHz 2 kHz 2 kHz 5 kHz 3 kHz
distance
IP 67 IP 67 IP 67 IP 67 IP 67 measurement
CE, cULus CE, cULus CE, cULus CE CE, cULus
Slim design Slim design Slim design Slim design Slim design Special
properties
POM POM POM POM PET-C Special
accessories
0.3 m PUR cable 0.3 m PUR cable 2 m PUR cable, 26 AWG 2 m PUR cable, 26 AWG 0.3 m PUR cable
with M5 connector, 4-pin with M8 connector, 3-pin with M5 connector, 4-pin
BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020 BKS-B 25-3-PU-03
23
23
www.balluff.com 493
Tubular housings, 3 mm, 4 mm
Housing size 3 mm 4 mm 4 mm
Installation type (observe instructions in the Basic Information chapter) Non-ush Flush Flush
Rated switching distance sn 3 mm 0.8 mm 0.8 mm
PNP, NO Ordering code BES00ME BES0122 BES00J5
Part number BES 516-3048-G-E4-C-PU-02 BES G04EC-PSC08B-S26G BES 516-3007-E5-C-S49
PNP, NC Ordering code BES00MJ BES0120 BES00K4
Part number BES 516-3049-G-E4-C-PU-02 BES G04EC-POC08B-S26G BES 516-3017-E5-C-S49
NPN, NO Ordering code BES011Y
Part number BES G04EC-NSC08B-S26G
NPN, NC Ordering code BES011W BES00KF
Part number BES G04EC-NOC08B-S26G BES 516-3018-E5-C-S49
Supply voltage UB 21.6...26.4 V DC 10...30 V DC 10...30 V DC
Voltage drop Ud at Ie max. 2.5 V 3V 3V
Rated insulation voltage Ui 75 V DC 75 V DC 75 V DC
Ambient temperature Ta 0...+70 C 25...+70C 25...+70C
Special properties Slim design, large Slim design Slim design
switching distance
Sensing surface PET-C PBT PBT
Connection 2 m PUR cable, M5 connector, 4-pin M8 connector, 3-pin
26 AWG
Suggested mating cable BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020



3-/4-Wire Tubular housing, 4 mm
0.8 mm 0.8 mm 0.8 mm 1.5 mm 1.5 mm
0...0.65 mm 0...0.65 mm 0...0.65 mm 0...1.2 mm 0...1.2 mm
BES00J3 BES00J0 BES00HW BES012F BES00JN sensors
BES 516-3007-E4-C-S49-00,3 BES 516-3007-E4-C-S4-00,3 BES 516-3007-E4-C-PU-02 BES G04ED-PSC15B-S26G BES 516-3007-G-E5-C-S49 Global
BES00K3 BES00K1 BES012A BES00KA DC 3-wire
BES 516-3017-E4-C-S49-00,3 BES 516-3017-E4-C-PU-02 BES G04ED-POC15B-S26G BES 516-3017-G-E5-C-S49
DC 3-/4-wire
BES00JP BES0126 BES00K0
Tubular
BES 516-3008-E4-C-PU-02 BES G04ED-NSC15B-S26G BES 516-3008-G-E5-C-S49 housings
BES00KC BES0123 BES00KK Block
housings
BES 516-3018-E4-C-PU-02 BES G04ED-NOC15B-S26G BES 516-3018-G-E5-C-S49
3V 3V 3V 3V 3V
75 V DC 75 V DC 75 V DC 75 V DC 75 V DC AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
3 kHz 3 kHz 3 kHz 3 kHz 3 kHz measurement
IP 67 IP 67 IP 67 IP 67 IP 67 Special
properties
accessories
PBT PBT PBT PBT PBT
0.3 m PUR cable 0.3 m PUR cable 2 m PUR cable, M5 connector, 4-pin M8 connector, 3-pin
with M8 connector, 3-pin with M12 connector, 4-pin 26 AWG
BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020
4
27
LED
50
M12x1
mini.s
Mini design
3 mm inductive sensors: Large switching distance with
the smallest installation space.
www.balluff.com 495
Tubular housing, 4 mm
Installation type (observe instructions in the Basic Information chapter) Flush Flush Flush
PNP, NO Ordering code BES00J8 BES00JJ
Part number BES 516-3007-G-E4-C-S26-00,2 BES 516-3007-G-E4-C-S49-00,3
PNP, NC Ordering code BES00K9
Part number BES 516-3017-G-E4-C-S49-00,3
NPN, NO Ordering code BES0156
Part number BES 516-3008-G-E4-C-S49-PU-00.3
NPN, NC Ordering code
Part number
Voltage drop Ud at Ie max. 3V 3V 3V
Ambient temperature Ta 25...+70C 25...+70C 25...+70C
Switching frequency f max. 3 kHz 3 kHz 1.8 kHz
Special properties Slim design Slim design Slim design

Sensing surface PBT PBT PBT
Connection 0.2 m PUR cable 0.3 m PUR cable 0.3 m PUR cable
Suggested mating cable BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
See technical section (page 963-966) 4


27

23
45
M8x1

3-/4-Wire Tubular housings, 4 mm, M40.5
4 mm 4 mm 4 mm 4 mm M40.5
Flush Flush Non-ush Non-ush Flush
1.5 mm 1.5 mm 5 mm 5 mm 0.6 mm
0...1.2 mm 0...1.2 mm 0...4 mm 0...4 mm 0...0.42 mm
BES00JA BES00J6 BES012K BES012H BES01P0 sensors
BES 516-3007-G-E4-C-S4-00,3 BES 516-3007-G-E4-C-PU-02 BES G04ED-PSC50F-S26G BES G04ED-PSC50F-EP02 BES M04EC-PSD06B-BP02 Global
BES00K5 BES012E BES0127 DC 3-wire
BES 516-3017-G-E4-C-PU-02 BES G04ED-POC50F-S26G BES G04ED-NSC50F-EP02
DC 3-/4-wire
BES00JW BES0129
Tubular
BES 516-3008-G-E4-C-PU-02 BES G04ED-NSC50F-S26G housings
BES00KH BES0125 Block
housings
BES 516-3018-G-E4-C-PU-02 BES G04ED-NOC50F-S26G
3V 3V 2.5 V 2.5 V 2.5 V
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
Yellow LED Yellow LED Yellow LED Yellow LED No
properties
Slim design Slim design Slim design, large Slim design, large Slim design Special
accessories
switching distance switching distance
PBT PBT PET-C PET-C POM
0.3 m PUR cable 2 m PUR cable, M5 connector, 4-pin 2 m PUR cable, 2 m PUR cable,
with M12 connector, 4-pin 26 AWG 26 AWG 26 AWG
BCC M415-0000-1A-003-EX44T2-020 BKS-B 25-3-PU-03
4 M4x0.5
6
22
27
LED
50
M12x1
www.balluff.com 497

PNP, NO Ordering code BES00HC BES00H7 BES00H3
Part number BES 516-3005-G-E4-C-S49-00,3 BES 516-3005-G-E4-C-S4-00,3 BES 516-3005-G-E4-C-PU-02
PNP, NC Ordering code BES00L4 BES00L2
Part number BES 516-3022-G-E4-C-S49-00,3 BES 516-3022-G-E4-C-PU-02
NPN, NO Ordering code BES00HM
Part number BES 516-3006-G-E4-C-PU-02
Part number

Connection 0.3 m PUR cable 0.3 m PUR cable 2 m PUR cable,
Suggested mating cable BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020


24
27

50

3-/4-Wire Tubular housing, M50.5
M50.5 M50.5 M50.5

5 mm 5 mm 5 mm
0...4 mm 0...4 mm 0...4 mm
3X 3X 3X Inductive
BES013H BES013C BES013E sensors
BES M05ED-PSC50F-S26G BES M05ED-PSC50F-EP00,3-GS04 BES M05ED-PSC50F-EP02 Global
BES0139 DC 3-wire
BES M05ED-POC50F-S26G
DC 3-/4-wire
BES0136 BES0134
Tubular
BES M05ED-NSC50F-S26G BES M05ED-NSC50F-EP02 housings
BES0132 Block
housings
BES M05ED-NOC50F-S26G
2.5 V 2.5 V 2.5 V
75 V DC 75 V DC 75 V DC AC/DC 2-wire
Yes/Yes/Yes No/Yes/Yes Yes/Yes/Yes
25...+70C 25...+70C 25...+70C Analog
distance
properties
Slim design, large Slim design, large Slim design, large Special
accessories
switching distance switching distance switching distance
Stainless steel Stainless steel Stainless steel
PET-C PET-C PET-C
M5 connector, 4-pin 0.3 m PUR cable 2 m PUR cable,
with M12 connector, 4-pin 26 AWG
BKS-B 25-3-PU-03 BCC M415-0000-1A-003-EX44T2-020
M5x0.5
7
35
LED
50
M12x1
www.balluff.com 499

PNP, NO Ordering code BES012Z BES00H2 BES00H1
Part number BES M05EC-PSC08B-S26G BES 516-3005-E5-C-S49 BES 516-3005-E4-C-S49-00,3
PNP, NC Ordering code BES012Y BES00L1
Part number BES M05EC-POC08B-S26G BES 516-3022-E5-C-S49
NPN, NO Ordering code BES012W BES00HL
Part number BES M05EC-NSC08B-S26G BES 516-3006-E5-C-S49
NPN, NC Ordering code BES012U BES00L8
Part number BES M05EC-NOC08B-S26G BES 516-3023-E5-C-S49
See technical section (page 963-966) M5x0.5


20
32

41
LED
M8x1

M50.5 M50.5 M50.5 M50.5 M50.5

0.8 mm 0.8 mm 1.5 mm 1.5 mm 1.5 mm
0...0.65 mm 0...0.65 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm
BES00FW BES00FT BES013A BES00HF BES00H5 sensors
BES 516-3005-E4-C-S4-00,3 BES 516-3005-E4-C-PU-02 BES M05ED-PSC15B-S26G BES 516-3005-G-E5-C-S49 BES 516-3005-G-E4-C-S26-00,3 Global
BES00KZ BES0137 DC 3-wire
BES 516-3022-E4-C-PU-02 BES M05ED-POC15B-S26G
DC 3-/4-wire
BES00HJ BES0133
Tubular
BES 516-3006-E4-C-PU-02 BES M05ED-NSC15B-S26G housings
BES00L6 BES0130 Block
housings
BES 516-3023-E4-C-PU-02 BES M05ED-NOC15B-S26G
3V 3V 3V 3V 3V
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
properties
accessories
PBT PBT PBT PBT PBT
0.3 m PUR cable 2 m PUR cable, M5 connector, 4-pin M8 connector, 3-pin 0.3 m PUR cable
with M12 connector, 4-pin 26 AWG with M5 connector, 4-pin
BCC M415-0000-1A-003-EX44T2-020 BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020 BKS-B 25-3-PU-03
24
M5x0.5
27
50
www.balluff.com 501
Tubular housing, 6.5 mm
Housing size
Installation type (observe instructions in Basic Information chapter)
Rated switching distance sn
Assured switching distance sa
Sensing distance
PNP, NO Ordering code
Part number
PNP, NC Ordering code
Part number
NPN, NO Ordering code
Part number
Part number
Supply voltage UB
Voltage drop Ud at Ie max.
Rated insulation voltage Ui (protection class)
Approvals
Material Housing
Sensing surface
Connection



3-/4-Wire Tubular housing, 6.5 mm
6.5 mm 6.5 mm 6.5 mm 6.5 mm 6.5 mm

0...1.6 mm 0...1.6 mm 0...3.2 mm 0...3.2 mm 0...3.2 mm
BES03R9 BES03P4 BES0005 BES03P5 BES000F sensors
BES G06EE-PSC20B-S49G-003 BES G06EH-PSC20B-S49G BES G06EB-PSC40F-S49G BES G06EH-PSC40F-S49G BES G06ED-PSC40F-BV02 Global
BES03RY BES03RT BES0004 BES03T1 BES000C DC 3-wire
BES G06EE-POC20B-S49G-003 BES G06EH-POC20B-S49G BES G06EB-POC40F-S49G BES G06EH-POC40F-S49G BES G06ED-POC40F-BV02
DC 3-/4-wire
BES03RZ BES0003 BES03T2 BES0009
Tubular
BES G06EE-NSC20B-S49G-003 BES G06EB-NSC40F-S49G BES G06EH-NSC40F-S49G BES G06ED-NSC40F-BV02 housings
BES03T0 BES0002 BES03T3 BES0007 Block
housings
BES G06EE-NOC20B-S49G-003 BES G06EB-NOC40F-S49G BES G06EH-NOC40F-S49G BES G06ED-NOC40F-BV02
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
75 V DC 75 V DC 75 V DC 75 V DC 250 V AC ([) AC/DC 2-wire
25...70 C 25...70 C 25...70 C 25...70 C 25...70 C Analog
distance
700 Hz 1.5 kHz 1.5 kHz 1.5 kHz 1.5 kHz measurement
IP 67 IP 67 IP 67 IP 67 IP 68 per BWN Pr. 20 Special
properties
Stainless steel Stainless steel Stainless steel Stainless steel Stainless steel Special
accessories
PBT PBT PA 12 PBT PBT
M8 connector, 3-pin M8 connector, 3-pin M8 connector, 3-pin M8 connector, 3-pin 2 m PVC cable, 26 AWG
BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
6.5 6.5 6.5 6.5 6.5

5
5
5
18
28
30
30
40
43
47
LED
55
60
LED
M8x1
LED
M8x1
LED LED
M8x1
M8x1
www.balluff.com 503
SUPERSHORTY
Housing size 6.5 mm 6.5 mm 6.5 mm
PNP, NO Ordering code BES025N BES00ZC BES01KJ
Part number BES G06EA-PSD15B-S49G BES 516-371-E5-C-S49 BES 516-371-S49-C
PNP, NC Ordering code BES025J
Part number BES G06EA-POD15B-S49G
NPN, NO Ordering code BES025F
Part number BES G06EA-NSD15B-S49G
NPN, NC Ordering code BES025A
Part number BES G06EA-NOD15B-S49G
Rated insulation voltage Ui (protection class) 75 V DC 75 V DC 75 V DC
Output function indicator No Yellow LED Yellow LED
Special properties Short design
Suggested mating cable BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
See technical section (page 963-966) 6.5 6.5

11.25

18

43
M8x1
55
LED
M8x1
Balluff's SuperShorty sensors monitor the

function of a pneumatic stepping motor.
504 For more info

information, visit us online!
SUPERSHORTY SUPERSHORTY SUPERSHORTY

6.5 mm 6.5 mm 6.5 mm 6.5 mm 6.5 mm
1.5 mm 1.5 mm 1.5 mm 1.5 mm 1.5 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm
BES0253 BES0254 BES00ZA BES00Z8 BES0256 sensors
BES G06E60-PSC15B-EP00,3-GS26 BES G06E60-PSC15B-EP00,3-GS49 BES 516-371-E4-C-S49-00,3 BES 516-371-E4-C-S4-00,3 BES G06E60-PSC15B-EP02 Global
BES0251 DC 3-wire
BES G06E60-POC15B-EP02
DC 3-/4-wire
BES024Y BES024Z
Tubular
BES G06E60-NSC15B-EP00,3-GS49 BES G06E60-NSC15B-EP02 housings
BES024W Block
housings
BES G06E60-NOC15B-EP02
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
75 V DC 75 V DC 250 V AC ([) 250 V AC ([) 75 V DC AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
IP 67 IP 67 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 Special
properties
Short design Short design Short design Special
accessories
PBT PBT PBT PBT PBT
0.3 m PUR cable 0.3 m PUR cable 0.3 m PUR cable 0.3 m PUR cable 2 m PUR cable,
with M5 connector, 4-pin with M8 connector, 3-pin with M8 connector, 3-pin with M12 connector, 4-pin 28 AWG
BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
6.5 6.5 6.5 6.5

0.35
0.35
6
6
LED
30
LED LED
LED
30
M5x0.5 M8x1
41.5
M12x1
www.balluff.com 505

PNP, NO Ordering code BES025M BES026F BES0269
Part number BES G06EA-PSC15B-EP02 BES K06K60-PSC15B-EP02 BES K06K40-PSC15B-FP02
PNP, NC Ordering code BES025H BES026E BES0262
Part number BES G06EA-POC15B-EP02 BES K06K60-POC15B-EP02 BES K06K40-POC15B-FP02
NPN, NO Ordering code BES025E BES026C BES0261
Part number BES G06EA-NSC15B-EP02 BES K06K60-NSC15B-EP02 BES K06K40-NSC15B-FP02
NPN, NC Ordering code BES0259 BES026A BES0260
Part number BES G06EA-NOC15B-EP02 BES K06K60-NOC15B-EP02 BES K06K40-NOC15B-FP02
Special properties Short design Short design Short design
Material Housing Stainless steel PBT PBT
Connection 2 m PUR cable, 28 AWG 2 m PUR cable, 28 AWG 2 m PUR cable, 28 AWG
See technical section (page 963-966) 6.5 6.5 6

6.5

6
10
LED
Additional cable lengths and PUR cable jacket material LED
available on request. LED
Features
Simple installation with glue-in sensor
Flexible use with optional radial cable outlet
Installation recommended
for 6.5 mm smooth sensor
Prepare and clean drill hole and sensor according to the
specications of the glue used. Coat hole and sensor
with adhesive and position sensor in hole. Allow to cure.
For additional instructions, see the data sheet.

SUPERSHORTY
6.5 mm 6.5 mm 6.5 mm 6.5 mm 6.5 mm
1.5 mm 1.5 mm 1.5 mm 2 mm 2 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.6 mm 0...1.6 mm
BES00Z2 BES00Z5 BES01K7 BES037K sensors
BES 516-371-E4-C-02 BES 516-371-E4-C-PU-02 BES 516-371-EO-C-02 BES 516-371-SA15-C-S49 Global
BES025K DC 3-wire
BES G06EA-POD20B-S49G
DC 3-/4-wire
BES00ZW BES0100 BES01L1
Tubular
BES 516-372-E4-C-02 BES 516-372-E4-C-PU-02 BES 516-372-EO-C-02 housings
BES025C Block
housings
BES G06EA-NOD20B-S49G
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
250 V AC ([) 250 V AC ([) 250 V AC ([) 75 V DC 75 V DC AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
3 kHz 3 kHz 3 kHz 3 kHz 1.5 kHz measurement
Yellow LED Yellow LED Yellow LED No Yellow LED
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 IP 67 Special
properties
Short design Special
accessories
PBT PBT PBT PBT PBT
2 m PVC cable, 26 AWG 2 m PUR cable, 26 AWG 2 m PVC cable, 26 AWG M8 connector, 3-pin M8 connector, 3-pin
BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
6.5
11.25
18
M8x1
SuperShorty sensors in electronics production: SMT placement equipment
www.balluff.com 507
SUPERSHORTY
PNP, NO Ordering code BES00ZU BES01KH BES0257
Part number BES 516-371-G-E5-C-S49 BES 516-371-G-S49-C BES G06E60-PSC20B-EP00,3-GS49
PNP, NC Ordering code BES00KY
Part number BES 516-3021-G-E5-C-S49
NPN, NO Ordering code BES0107 BES03RU
Part number BES 516-372-G-E5-C-S49 BES G06EH-NSC20B-S49G
NPN, NC Ordering code BES03RW
Part number BES G06EH-NOC20B-S49G
Switching frequency f max. 1.5 kHz 1.5 kHz 3 kHz
See technical section (page 963-966) 6.5 6.5

0.35
for installation instructions. 6
Additional cable lengths and PUR cable jacket material LED

43
55
LED
M8x1
M8x1

SUPERSHORTY SUPERSHORTY
6.5 mm 6.5 mm 6.5 mm 6.5 mm 6.5 mm
0...1.6 mm 0...1.6 mm 0...1.6 mm 0...1.6 mm 0...1.6 mm
BES00ZR BES00ZN BES0258 BES03ZA BES01KW sensors
BES 516-371-G-E4-C-S49-00,3 BES 516-371-G-E4-C-S4-00,2 BES G06E60-PSC20B-EP02 BES G06K40-PSC20B-FP02 BES 516-371-SA13-PU-02 Global
BES03F8 BES00KU DC 3-wire
BES 516-3021-G-E4-C-S49-00,3 BES 516-3021-G-E4-C-S4-00,2
DC 3-/4-wire
BES0106 BES0250
Tubular
BES 516-372-G-E4-C-S49-00,3 BES G06E60-NSC20B-EP02 housings
Block
housings

2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
250 V AC ([) 250 V AC ([) 75 V DC 75 V DC 75 V DC AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
1.5 kHz 1.5 kHz 3 kHz 1.5 kHz 2 kHz measurement
Yellow LED Yellow LED Yellow LED Yellow LED No
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 IP 65 IP 65 Special
properties
CE, cULus CE, cULus CE, cULus CE, cULus CE
Short design Short design Special
accessories
Stainless steel Stainless steel Stainless steel PBT Stainless steel
PBT PBT PBT PBT PBT
0.3 m PUR cable 0.2 m PUR cable 2 m PUR cable, 2 m PUR cable, 2 m PUR cable,
with M8 connector, 3-pin with M12 connector, 4-pin 28 AWG 28 AWG 26 AWG
BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
6.5 6.5 6
6.5
6
LED
30
LED
LED
Features
Simple installation with glue-in sensor
Flexible use with optional radial cable outlet
41.5
Installation recommended
for 6.5 mm smooth sensor
Drill hole and sensor according to the specications of
the glue used. Coat hole and sensor with adhesive and
M12x1
position sensor in hole. Allow to cure. For additional
instructions see data sheet.
www.balluff.com 509

Installation type (observe instructions in the Basic Information chapter) Flush Quasi-ush Quasi-ush
PNP, NO Ordering code BES00ZF BES02UY BES02UR
Part number BES 516-371-G-E4-C-02 BES G06MI-PSC30B-S49G BES G06MH1-PSC30B-S04G
PNP, NC Ordering code BES00KP BES02UW
Part number BES 516-3021-G-E4-C-02 BES G06MI-POC30B-S49G
NPN, NO Ordering code BES0102 BES02UU BES02UP
Part number BES 516-372-G-E4-C-02 BES G06MI-NSC30B-S49G BES G06MH1-NSC30B-S04G
NPN, NC Ordering code BES02UT
Part number BES G06MI-NOC30B-S49G
Rated insulation voltage Ui (protection class) 250 V AC ([) 75 V DC 75 V DC
Switching frequency f max. 1.5 kHz 1 kHz 1 kHz
Degree of protection as per IEC 60529 IP 68 per BWN Pr. 20 IP 67 IP 67
Approvals CE, cULus CE CE
Special properties Large switching distance Large switching distance
Material Housing Stainless steel Brass-coated Brass-coated
Connection 2 m PVC cable, 26 AWG M8 connector, 3-pin M12 connector, 4-pin



6.5 mm 6.5 mm 6.5 mm

Quasi-ush Non-ush Non-ush
4 mm 2.5 mm 4 mm
0...2.9 mm 0...2 mm 0...3.2 mm
4X 1X 2X Inductive
BES01NT BES00TZ BES01NP sensors
BES G06MI-PSC40B-S49G BES 516-349-E4-C-02 BES G06EF-PSC40F-S49G Global
DC 3-wire
DC 3-/4-wire
BES01NR BES00U6
Tubular
BES G06MI-NSC40B-S49G BES 516-350-E4-C-02 housings
Block
housings

2.8 V 2.5 V 2.5 V
75 V DC 250 V AC ([) 75 V DC AC/DC 2-wire
0...+60 C 25...+70C 25...+70C Analog
distance
700 Hz 2 kHz 1.5 kHz measurement
IP 65 IP 68 per BWN Pr. 20 IP 67 Special
properties
Large switching distance Special
accessories
Brass-coated Stainless steel Stainless steel
PBT PBT PBT
M8 connector, 3-pin 2 m PVC cable, 26 AWG M8 connector, 3-pin
BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
6.5 6.5
2.5
30
37.4
49.5
50
59
LED
LED
www.balluff.com 511
Tubular housing, 8 mm
Rated switching distance sn 1.5 mm 2 mm 2 mm
PNP, NO Ordering code BES01NY BES0379
Part number BES G08EG-PSC15B-BV02 BES 516-369-G-SA2-S49-C
PNP, NC Ordering code BES0349 BES0348
Part number BES 516-3013-G-SA2-S49-C BES 516-3013-G-SA2-S49-00,5
Part number
Switching frequency f max. 3 kHz 800 Hz 800 Hz
Approvals CE, cULus CE, cULus CE
Special properties
Sensing surface PBT PA 12 PA 12
Connection 2 m PVC cable, M8 connector, 3-pin 0.5 m PUR cable
26 AWG with M8 connector, 3-pin
Suggested mating cable BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
See technical section (page 963-966) 8 8


45
54.5
LED LED

3-/4-Wire Tubular housings, 8 mm, M81
SUPERSHORTY
8 mm 8 mm M8 1 M8 1 M8 1
2 mm 2 mm 0.5 mm 1 mm 1 mm
0...1.6 mm 0...1.6 mm 0...0.36 mm 0...0.8 mm 0...0.8 mm
BES0388 BES012N BES03P0 BES02HP sensors
BES G08EC-PSC20B-EP01-GS04-516 BES G08EE-PSC20B-BV02 BES M08EA-PSC05B-EP02 BES 516-324-SA8-02 Global
DC 3-wire
DC 3-/4-wire
BES0367
Tubular
BES 516-343-SA13-E5-C-S49 housings
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC Block
housings
2.5 V 2.5 V 2.5 V 2.5 V 1.5 V
75 V DC 250 V AC ([) 75 V DC 75 V DC 75 V DC DC 2-wire
200 mA 200 mA 150 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/No/No AC/DC 2-wire
25...+70C 25...+70C 25...85 C 25...+70C 25...+100 C AC 2-wire
2 kHz 1.5 kHz 2 kHz 3.5 kHz 2 kHz
Yellow LED Yellow LED Yellow LED Yellow LED No Analog
distance
IP 67 IP 68 per BWN Pr. 20 IP 67 IP 67 IP 67 measurement
CE CE, cULus CE, cULus CE, cULus CE
properties
Ceramic PBT PBT PBT PBT Special
accessories
1 m PUR cable 2 m PVC cable, 2 m PUR cable, M8 connector, 3-pin 2 m PVC cable,
with M12 connector, 4-pin 26 AWG 28 AWG 26 AWG
BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020
8 8-0.1 M8x1
6.5
30
20.5
35
13
44
LED
LED LED
41.5
24
M12x1
14.5
www.balluff.com 513
SUPERSHORTY
PNP, NO Ordering code BES0277 BES013N BES013M
Part number BES M08EA-PSD15B-S49G BES M08EC-PSC15B-S49G BES M08EC-PSC15B-S04G
PNP, NC Ordering code BES0270 BES013K
Part number BES M08EA-POD15B-S49G BES M08EC-POC15B-S49G
NPN, NO Ordering code BES026W BES013J
Part number BES M08EA-NSD15B-S49G BES M08EC-NSC15B-S49G
NPN, NC Ordering code BES026R
Part number BES M08EA-NOD15B-S49G
Rated insulation voltage Ui (protection class) 75 V DC 250 V AC ([) 250 V AC ([)
Suggested mating cable BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020

11.25

18

M8x1

3-/4-Wire Tubular housing, M81
M8 1 M8 1 M8 1 M8 1 M8 1
1.5 mm 1.5 mm 1.5 mm 1.5 mm 1.5 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm
BES0147 BES0146 BES01P7 BES01AW BES01PF sensors
BES M08EE-PSC15B-S49G BES M08EE-PSC15B-S04G BES M08EG-PSC15B-S49G BES 516-324-S49-C BES M08EH-PSC15B-S04G Global
BES0143 BES0142 BES01LR BES01PE DC 3-wire
BES M08EE-POC15B-S49G BES M08EE-POC15B-S04G BES 516-377-S49-C BES M08EH-POC15B-S04G
DC 3-/4-wire
BES013Z BES013Y BES01F5 BES01PC
Tubular
BES M08EE-NSC15B-S49G BES M08EE-NSC15B-S04G BES 516-343-S49-C BES M08EH-NSC15B-S04G housings
BES013T BES013R BES01LZ BES01PA Block
housings
BES M08EE-NOC15B-S49G BES M08EE-NOC15B-S04G BES 516-378-S49-C BES M08EH-NOC15B-S04G
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 Special
properties
Special
accessories
PBT PBT PBT PBT PBT
BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
M8x1 M8x1
13 13
28.5
29.5
40
43
LED LED
M8x1
M12x1
www.balluff.com 515
PNP, NO Ordering code BES0272 BES0273 BES034Y
Part number BES M08EA-PSC15B-EP00,3-GS26 BES M08EA-PSC15B-EP00,3-GS49 BES 516-324-SA44-C-S49-00,3
Part number
NPN, NO Ordering code BES026T
Part number BES M08EA-NSC15B-EP00,3-GS49
Special properties Short design Short design
Connection 0.3 m PUR cable 0.3 m PUR cable 0.3 m PUR cable
See technical section (page 963-966) M8x1 M8x1 M8x1

0.35
0.35

10
10
20
Additional cable lengths and PUR cable jacket material LED LED
13
LED
M5x0.5
M8x1

M8 1 M8 1 M8 1 M8 1 M8 1
1.5 mm 1.5 mm 1.5 mm 1.5 mm 1.5 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm
BES00NK BES00N9 BES00MU BES00MT BES01AL sensors
BES 516-324-E4-C-S49-00,3 BES 516-324-E4-C-S4-00,3 BES 516-324-E3-C-S49-00,3 BES 516-324-E3-C-S4-00,3 BES 516-324-EO-C-S49-00,3 Global
BES010N BES01LN DC 3-wire
BES 516-377-E3-C-S4-PU-00,3 BES 516-377-EO-C-S49-00,3
DC 3-/4-wire
BES01F4
Tubular
BES 516-343-EO-C-S49-00,3 housings
housings
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) DC 2-wire
200 mA 200 mA 200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C AC 2-wire
distance
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 measurement
Special
properties
PBT PBT PBT PBT PBT Special
accessories
0.3 m PUR cable 0.3 m PUR cable 0.3 m PUR cable 0.3 m PUR cable 0.3 m PUR cable
with M8 connector, 3-pin with M12 connector, 4-pin with M8 connector, 3-pin with M12 connector, 4-pin with M8 connector, 3-pin
BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020
www.balluff.com 517
PNP, NO Ordering code BES026M BES0275 BES034P
Part number BES M08E60-PSC15B-EP02 BES M08EA-PSC15B-EP02 BES 516-324-SA44-C-02
PNP, NC Ordering code BES026K BES026Y
Part number BES M08E60-POC15B-EP02 BES M08EA-POC15B-EP02
NPN, NO Ordering code BES026J BES026U
Part number BES M08E60-NSC15B-EP02 BES M08EA-NSC15B-EP02
NPN, NC Ordering code BES026H BES026N
Part number BES M08E60-NOC15B-EP02 BES M08EA-NOC15B-EP02
Connection 2 m PUR cable, 2 m PUR cable, 2 m PVC cable,
28 AWG 28 AWG 26 AWG

For wiring diagram see page 958. 6 20
Additional cable lengths and PUR cable jacket material LED 13

LED

M8 1 M8 1 M8 1 M8 1 M8 1
1.5 mm 1.5 mm 1.5 mm 1.5 mm 1.5 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm
BES00MY BES014K BES01A7 BES01AC sensors
BES 516-324-E4-C-02 BES M08EF-PSC15B-BP02 BES 516-324-EO-C-02 BES 516-324-EO-C-PU-02 Global
BES010T BES010K BES014H BES01LC BES01LH DC 3-wire
BES 516-377-E4-C-02 BES 516-377-E3-C-PU-02 BES M08EF-POC15B-BP02 BES 516-377-EO-C-02 BES 516-377-EO-C-PU-02
DC 3-/4-wire
BES00TL BES03J6 BES01EY BES01F1
Tubular
BES 516-343-E4-C-02 BES M08EF-NSC15B-BP02 BES 516-343-EO-C-02 BES 516-343-EO-C-PU-02 housings
BES014C BES01LT Block
housings
BES M08EF-NOC15B-BP02 BES 516-378-EO-C-02
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
properties
Special
accessories
PBT PBT PBT PBT PBT
2 m PVC cable, 2 m PUR cable, 2 m PUR cable, 2 m PVC cable, 2 m PUR cable,
26 AWG 26 AWG 26 AWG 26 AWG 26 AWG
M8x1 M8x1
13 13
35
40
LED
LED
www.balluff.com 519
SUPERSHORTY
PNP, NO Ordering code BES0278 BES013P BES014A
Part number BES M08EA-PSD20B-S49G BES M08EC-PSC20B-S49G BES M08EE-PSC20B-S49G
PNP, NC Ordering code BES013L BES0145
Part number BES M08EC-POC20B-S49G BES M08EE-POC20B-S49G
NPN, NO Ordering code BES01P1 BES0141
Part number BES M08EA-NSD20B-S49G BES M08EE-NSC20B-S49G
NPN, NC Ordering code BES013W
Part number BES M08EE-NOC20B-S49G
Rated insulation voltage Ui (protection class) 75 V DC 250 V AC ([) 250 V AC ([)
Switching frequency f max. 3 kHz 1.5 kHz 1.5 kHz


13
11.25

18
29.5

40
M8x1
LED
M8x1

M8 1 M8 1 M8 1 M8 1 M8 1
0...1.6 mm 0...1.4 mm 0...1.6 mm 0...1.4 mm 0...1.6 mm
BES0148 BES0149 BES00P7 BES02P0 BES01AU sensors
BES M08EE-PSC20B-S04G BES M08EE-PSC20B-S04G-101 BES 516-324-G-E5-C-S49 BES 516-324-SA96-G-E5-C-S49 BES 516-324-G-S49-C Global
BES0144 BES0113 BES01LP DC 3-wire
BES M08EE-POC20B-S04G BES 516-377-G-E5-C-S49 BES 516-377-G-S49-C
DC 3-/4-wire
BES0140 BES00TY BES02P1
Tubular
BES M08EE-NSC20B-S04G BES 516-343-G-E5-C-S49 BES 516-343-SA96-G-E5-C-S49 housings
BES013U BES0118 Block
housings
BES M08EE-NOC20B-S04G BES 516-378-G-E5-C-S49
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
1.5 kHz 1.5 kHz 1.5 kHz 1.5 kHz 1.5 kHz measurement
properties
Special
accessories
PBT With ceramic PBT with ceramic PBT
coating coating
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
M8x1 M8x1
13 13
28.5
28.5
43
43
LED LED
M12x1 M12x1
www.balluff.com 521
SUPERSHORTY
PNP, NO Ordering code BES01PH BES0276 BES00P4
Part number BES M08EH-PSC20B-S04G BES M08EA-PSC20B-EP00,3-GS49 BES 516-324-G-E4-C-S49-00,3
PNP, NC Ordering code BES0112
Part number BES 516-377-G-E4-C-S49-00,3
Part number
Rated insulation voltage Ui (protection class) 250 V AC ([) 75 V DC 250 V AC ([)
Switching frequency f max. 1.5 kHz 3 kHz 1.5 kHz
Connection M12 connector, 4-pin 0.3 m PUR cable 0.3 m PUR cable
with M8 connector, 3-pin with M8 connector, 3-pin
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020

0.35

10

LED
M8x1

SUPERSHORTY
M8 1 M8 1 M8 1 M8 1 M8 1
0...1.6 mm 0...1.4 mm 0...1.6 mm 0...1.6 mm 0...1.6 mm
BES00P2 BES02P5 BES03TU BES01AT sensors
BES 516-324-G-E4-C-S4-00,3 BES 516-324-SA96-G-E4-C-S4-00.3 BES M08EF-PSC20B-BP00,3-GS49 BES 516-324-G-EO-C-S49-01 Global
BES026Z DC 3-wire
BES M08EA-POC20B-EP02
DC 3-/4-wire
BES026P
Tubular
BES M08EA-NOC20B-EP02 housings
housings
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) 75 V DC DC 2-wire
200 mA 200 mA 200 mA 200 mA 150 mA
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C AC 2-wire
1.5 kHz 1.5 kHz 1.5 kHz 1.5 kHz 3 kHz
distance
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 measurement
properties
PBT with ceramic PBT PBT PBT Special
accessories
coating
0.3 m PUR cable 0.3 m PUR cable 0.3 m PUR cable 1 m PUR cable 2 m PUR cable,
with M12 connector, 4-pin with M12 connector, 4-pin with M8 connector, 3-pin with M8 connector, 3-pin 28 AWG
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
M8x1
M8x1
13
40
37
LED
www.balluff.com 523
PNP, NO Ordering code BES00NR BES00NY BES014L
Part number BES 516-324-G-E4-C-02 BES 516-324-G-E4-C-PU-02 BES M08EF-PSC20B-BP02
PNP, NC Ordering code BES010Y BES010Z BES014J
Part number BES 516-377-G-E4-C-02 BES 516-377-G-E4-C-PU-02 BES M08EF-POC20B-BP02
NPN, NO Ordering code BES00TT BES014F
Part number BES 516-343-G-E4-C-02 BES M08EF-NSC20B-BP02
NPN, NC Ordering code BES0116 BES014E
Part number BES 516-378-G-E4-C-02 BES M08EF-NOC20B-BP02
Switching frequency f max. 1.5 kHz 1.5 kHz 1.5 kHz
Degree of protection as per IEC 60529 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20
Special properties
Connection 2 m PVC cable, 26 AWG 2 m PUR cable, 26 AWG 2 m PUR cable, 26 AWG


40
LED

M8 1 M8 1 M8 1 M8 1 M8 1
Flush Flush Flush Quasi-ush Quasi-ush
2 mm 2 mm 2.5 mm 3 mm 3 mm
0...1.6 mm 0...1.6 mm 0...2 mm 0...2.4 mm 0...2.4 mm
BES01AM BES01AN BES0427 BES02WA BES02W9 sensors
BES 516-324-G-EO-C-02 BES 516-324-G-EO-C-PU-02 BES M08EE-PSC25B-S49G BES M08MH1-PSC30B-S49G BES M08MH1-PSC30B-S04G Global
BES0423 DC 3-wire
BES M08EE-POC25B-S49G
DC 3-/4-wire
BES02W8 BES02W7
Tubular
BES M08MH1-NSC30B-S49G BES M08MH1-NSC30B-S04G housings
Block
housings

2.5 V 2.5 V 2.5 V 2V 2V
250 V AC ([) 250 V AC ([) 250 V AC 75 V DC 75 V DC AC/DC 2-wire
25...+70C 25...+70C 0...+60 C 25...+70C 25...+70C Analog
distance
1.5 kHz 1.5 kHz 1 kHz 1 kHz 1 kHz measurement
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 IP 67 IP 67 Special
properties
CE, cULus CE, cULus CE, cULus CE CE
Large switching distance Large switching distance Special
accessories
Stainless steel Stainless steel Stainless steel Brass-coated Brass-coated
PBT PBT PBT PBT PBT
2 m PVC cable, 26 AWG 2 m PUR cable, 26 AWG M8 connector, 3-pin M8 connector, 3-pin M12 connector, 4-pin
BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
M8x1 M8x1
13
13
29.5
40
45.5
46
60
66
LED
M8x1 LED
www.balluff.com 525
Installation type (observe instructions in the Basic Information chapter) Quasi-ush Quasi-ush Quasi-ush
PNP, NO Ordering code BES02PW BES01ZW BES003R
Part number BES M08MH1-PSC30B-S04G-101 BES M08MI-PSC40B-S49G BES M08MI-PSC40B-BP00,3-GS49
Part number
NPN, NO Ordering code BES01ZT
Part number BES M08MI-NSC40B-S49G
Voltage drop Ud at Ie max. 2V 2.8 V 2.8 V
Ambient temperature Ta 25...+70C 0...+60 C 0...+60 C
Approvals CE CE, cULus CE, cULus
Special properties Large switching distance Large switching distance Large switching distance
Sensing surface with ceramic PBT PBT
coating
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020


M8x1
50.5
37

M8 1 M8 1 M8 1 M8 1 M8 1
Quasi-ush Non-ush Non-ush Non-ush Non-ush
4 mm 2.5 mm 2.5 mm 2.5 mm 2.5 mm
0...2.9 mm 0...2 mm 0...2 mm 0...2 mm 0...2 mm
BES01ZU BES01P3 BES01M6 BES01P8 sensors
BES M08MI-PSC40B-BP00,2-GS04 BES M08ED-PSC25F-S04G BES 516-383-S49-C BES M08EG-PSC25F-S04G Global
BES01P6 DC 3-wire
BES M08EG-POC25F-S04G
DC 3-/4-wire
BES01ZR BES01P2 BES01P5 BES011U
Tubular
BES M08MI-NSC40B-BP00,2-GS04 BES M08ED-NSC25F-S04G BES M08EG-NSC25F-S04G BES 516-384-E4-C-S49-00.2 housings
housings
2.8 V 2.5 V 2.5 V 2.5 V 2.5 V
75 V DC 250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) DC 2-wire
200 mA 200 mA 200 mA 200 mA 200 mA
0...+60 C 25...+70C 25...+70C 25...+70C 25...+70C AC 2-wire
800 Hz 2 kHz 2 kHz 2 kHz 2 kHz
distance
IP 67 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 measurement
properties
Brass-coated Stainless steel Stainless steel Stainless steel Stainless steel
PBT PBT PBT PBT PBT Special
accessories
0.2 m PUR cable M12 connector, 4-pin M8 connector, 3-pin M12 connector, 4-pin 0.2 m PVC cable
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020
M8x1
6.5
2.5
30
13
LED
37
M8x1
10
www.balluff.com 527
Installation type (observe instructions in the Basic Information chapter) Non-ush Non-ush Non-ush
PNP, NO Ordering code BES011A BES01M0
Part number BES 516-383-E4-C-02 BES 516-383-EO-C-02
Part number
NPN, NO Ordering code BES01MA BES011M BES01M7
Part number BES 516-384-EO-C-S49-00.2 BES 516-384-E4-C-02 BES 516-384-EO-C-02
Part number
Special properties
Connection 0.2 m PVC cable 2 m PVC cable, 2 m PVC cable,
Suggested mating cable BCC M313-0000-10-001-EX43T2-020

6.5

2.5
45
13
LED
37
M8x1
10

M8 1 M8 1 M8 1 M8 1
Non-ush Non-ush Non-ush Non-ush
4 mm 4 mm 6 mm 6 mm
0...3.2 mm 0...3.2 mm 0...4.8 mm 0...4.8 mm
2X 2X 3X 3X Inductive
BES014M BES01P9 BES02W4 BES02W3 sensors
BES M08EF-PSC40F-S49G BES M08EG1-PSC40F-S04G BES M08MG1-PSC60F-S49G BES M08MG1-PSC60F-S04G Global
BES02W2 DC 3-wire
BES M08MG1-POC60F-S49G
DC 3-/4-wire
BES02W0
Tubular
BES M08MG1-NSC60F-S04G housings
BES02UZ Block
housings
BES M08MG1-NOC60F-S49G
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC DC 2-wire
2.5 V 2.5 V 2V 2V
250 V AC ([) 250 V AC ([) 75 V DC 75 V DC AC/DC 2-wire
200 mA 200 mA 200 mA 200 mA AC 2-wire
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes
25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
1.5 kHz 5 kHz 500 Hz 500 Hz measurement
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 IP 67 Special
properties
CE, cULus CE, cULus CE CE
Large switching distance Large switching distance Special
accessories
Stainless steel Stainless steel Brass-coated Brass-coated
PBT PBT PBT PBT
BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
M8x1 M8x1 M8x1

4
5
4
5
13
13
39.1
13
49.5
41
42
60
64
66
LED LED
M8x1 LED
M12x1
www.balluff.com 529

PNP, NO Ordering code BES00PK BES02EL BES01C8
Part number BES 516-325-E5-C-S4 BES 515-325-S4-C BES 516-325-S4-C
PNP, NC Ordering code BES00YT BES01K6
Part number BES 516-370-E5-C-S4 BES 516-370-S4-C
PNP, complementary Ordering code BES0161
Part number BES 516-113-S4-C
NPN, NO Ordering code BES00T5 BES01EN
NPN, NC Ordering code BES010A BES01LA
NPN, complementary Ordering code BES016E
Ambient temperature Ta 25...+70C 25...+70C 40...+85 C
Material Housing Brass-coated Stainless steel Stainless steel
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020



M121 M121 M121 M121 M121

0...1.6 mm 0...1.6 mm 0...1.6 mm 0...3.2 mm 0...3.2 mm
BES00PH BES00P8 BES01AZ BES00PY BES014W sensors
BES 516-325-E4-C-S4-00,5 BES 516-325-E4-C-02 BES 516-325-BO-C-02 BES 516-325-G-E5-C-S4 BES M12EE-PSC40B-S04G Global
BES00YL BES01K2 BES00Z0 BES014U DC 3-wire
BES 516-370-E4-C-02 BES 516-370-BO-C-02 BES 516-370-G-E5-C-S4 BES M12EE-POC40B-S04G
DC 3-/4-wire
Tubular
housings
BES00T0 BES01EF BES00TC Block
housings
BES 516-329-E4-C-02 BES 516-329-BO-C-02 BES 516-329-G-E5-C-S4
BES0108 BES01L7 BES010H DC 2-wire
BES 516-375-E4-C-02 BES 516-375-BO-C-02 BES 516-375-G-E5-C-S4
AC/DC 2-wire
AC 2-wire
2V 2V 1.5 V 2.5 V 2V Analog
distance
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) measurement
200 mA 200 mA 200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Special
properties
25...+70C 25...+70C 40...+85 C 25...+70C 25...+85 C
5 kHz 5 kHz 3 kHz 2.5 kHz 2 kHz Special
accessories
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20
Brass-coated Brass-coated Stainless steel Brass-coated Stainless steel
PBT PBT PA 12 LCP LCP
0.5 m PUR cable 2 m PVC cable, 2 m PVC cable, M12 connector, 4-pin M12 connector, 4-pin
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020
M12x1 M12x1
17 17
30
30
33
45
LED
LED
M12x1
www.balluff.com 531

PNP, NO Ordering code BES00PZ BES02FU
Part number BES 516-325-G-E5-C-S49 BES M12EI-PSC40B-S04G
PNP, NC Ordering code BES00Z1 BES02FT
Part number BES 516-370-G-E5-C-S49 BES M12EI-POC40B-S04G
NPN, NO Ordering code BES03UP BES00TE BES02FR
Part number BES 516-329-SA96-G-E5-C-S4 BES 516-329-G-E5-C-S49 BES M12EI-NSC40B-S04G
NPN, NC Ordering code BES010J
Part number BES 516-375-G-E5-C-S49
Rated insulation voltage Ui (protection class) 250 V AC ([) 75 V DC 250 V AC ([)
Switching frequency f max. 2.5 kHz 2.5 kHz 1 kHz
Special properties
Sensing surface with ceramic LCP LCP
coating
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020

17
30

45
LED
M12x1

SUPERSHORTY
M121 M121 M121 M121 M121
0...3.2 mm 0...3.2 mm 0...3 mm 0...3.2 mm 0...3.2 mm
BES038C BES01C7 BES035R BES0464 BES00PW sensors
BES M12EI-PSC40B-S04G-009 BES 516-325-G-S4-C BES 516-325-SA96-G-S4-C BES M12EA-PSC40B-EP00,3-GS04 BES 516-325-G-E4-C-S4-00,5 Global
BES0465 DC 3-wire
BES M12EA-POC40B-EP00,3-GS04
DC 3-/4-wire
BES0467 BES03EK
Tubular
BES M12EA-NSC40B-EP00,3-GS04 BES 516-329-G-E4-C-S4-PU-00.5 housings
BES0466 Block
housings
BES M12EA-NOC40B-EP00,3-GS04
2.5 V 2.5 V 2.5 V 1.7 V 2.5 V
250 V AC ([) 250 V AC ([) 250 V AC ([) 75 V DC 250 V AC ([) AC/DC 2-wire
40...+85 C 25...+70C 25...+70C 40...+85 C 25...+70C Analog
distance
2 kHz 1 kHz 1 kHz 1 kHz 2.5 kHz measurement
IP 67 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 IP 68 per BWN Pr. 20 Special
properties
accessories
Stainless steel Brass-coated Brass-coated Stainless steel Brass-coated
LCP LCP with ceramic LCP LCP
coating
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin 0.3 m PUR cable 0.5 m PUR cable
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020
M12x1 M12x1
0.6
12
30
33
LED
17
LED
41.5
24
M12x1
M12x1
14.5
www.balluff.com 533

Installation type (observe instructions in the Basic Information chapter) Flush Flush Quasi-ush
PNP, NO Ordering code BES00PL BES00PP BES02WZ
Part number BES 516-325-G-E4-C-02 BES 516-325-G-E4-C-PU-02 BES M12MG1-PSC60B-S04G
PNP, NC Ordering code BES00YU BES00YW BES02WY
Part number BES 516-370-G-E4-C-02 BES 516-370-G-E4-C-PU-02 BES M12MG1-POC60B-S04G
PNP, complementary Ordering code
Part number
NPN, NO Ordering code BES00T6 BES00T9 BES02WW
Part number BES 516-329-G-E4-C-02 BES 516-329-G-E4-C-PU-02 BES M12MG1-NSC60B-S04G
NPN, NC Ordering code BES010C BES010E BES02WU
Part number BES 516-375-G-E4-C-02 BES 516-375-G-E4-C-PU-02 BES M12MG1-NOC60B-S04G
Switching frequency f max. 2.5 kHz 2.5 kHz 800 Hz
Degree of protection as per IEC 60529 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67
Special properties Large switching distance
Sensing surface LCP LCP PBT
Connection 2 m PVC cable, 22 AWG 2 m PUR cable, 22 AWG M12 connector, 4-pin
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020

17 17
30
30

33
33
LED LED

M121 M121 M121 M121 M121

Quasi-ush Non-ush Non-ush Non-ush Non-ush
0...5.8 mm 0...3.2 mm 0...3.2 mm 0...3.2 mm 0...3.2 mm
BES01ZN BES00UY BES02FC BES01H6 sensors
BES M12MI-PSH80B-S04G BES 516-356-E5-C-S4 BES 515-356-S4-C BES 516-356-S4-C Global
BES00KM BES018Y DC 3-wire
BES 516-3019-E5-C-S4 BES 516-3019-S4-C
DC 3-/4-wire
BES0178
Tubular
BES 516-131-S4-C housings
BES01ZY BES030Z BES01HE Block
housings
BES M12MI-NSH80B-S04G BES 516-357-E5-Y-S4 BES 516-357-S4-C
BES019E DC 2-wire
BES 516-3030-S4-C
10...55 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC AC/DC 2-wire
2.5 V 2V 3.5 V 1.5 V 1.5 V AC 2-wire
250 V AC ([) 250 V AC ([) 75 V DC 250 AC ([) 250 V AC ([)
200 mA 200 mA 130 mA 200 mA 200 mA Analog
distance
0...+60 C 25...+70C 25...+70C 40...+85 C 40...+85 C
300 Hz 2 kHz 400 Hz 1.5 kHz 1.5 kHz Special
properties
IP 67 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 Special
accessories
CE CE, cULus CE, cULus CE, cULus CE, cULus
Large switching distance
Brass-coated Brass-coated Brass-coated Stainless steel Stainless steel
LCP PBT PA 12 PA 12 PA 12
4.9
34.4
www.balluff.com 535

PNP, NO Ordering code BES00UT BES00UL BES01H1
Part number BES 516-356-E4-C-S4-00,3 BES 516-356-E4-C-02 BES 516-356-BO-C-02
PNP, NC Ordering code BES018P
Part number BES 516-3019-BO-C-02
NPN, NO Ordering code BES00W0 BES01H7
Part number BES 516-357-E4-C-02 BES 516-357-BO-C-02
NPN, NC Ordering code BES00M0 BES019A
Part number BES 516-3030-E4-C-02 BES 516-3030-BO-C-02
Voltage drop Ud at Ie max. 2V 2V 1.5 V
Special properties
Sensing surface PBT PBT PA 12
Connection 0.3 m PUR cable 2 m PVC cable, 2 m PVC cable,



SUPERSHORTY
M121 M121 M121 M121
6 mm 8 mm 10 mm 10 mm
0...4.8 mm 0...6.4 mm 0...8 mm 0...8 mm
BES047L BES01PN BES02WK BES02WR sensors
BES M12EA-PSC60F-EP00.3-GS04 BES M12EG-PSC80F-S04G BES M12MC1-PSC10F-S04G BES M12MF1-PSC10F-S04G Global
BES047M BES02WP DC 3-wire
BES M12EA-POC60F-EP00,3-GS04 BES M12MF1-POC10F-S04G
DC 3-/4-wire
BES047P BES02WJ BES02WN
Tubular
BES M12EA-NSC60F-EP00,3-GS04 BES M12MC1-NSC10F-S04G BES M12MF1-NSC10F-S04G housings
BES047N Block
housings
BES M12EA-NOC60F-EP00,3-GS04
2.5 V 2.5 V 2V 2V
75 V DC 250 V AC ([) 75 V DC 75 V DC AC/DC 2-wire
100 mA 200 mA 200 mA 200 mA AC 2-wire
40...+85 C 25...+70C 25...+70C 25...+70C Analog
distance
1 kHz 1.5 kHz 400 Hz 400 Hz measurement
IP 67 IP 68 per BWN Pr. 20 IP 67 IP 67 Special
properties
CE, cULus CE, cULus CE CE
Short design Large switching distance Large switching distance Special
accessories
Stainless steel Stainless steel Brass-coated Brass-coated
LCP PBT PBT PBT
0.3 m PUR cable M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020
M12x1
5.6
17
5.7
5.7
41
LED
M12x1
www.balluff.com 537

PNP, NO Ordering code BES00R6 BES02ET
Part number BES 516-326-E5-C-S4 BES 515-326-E5-T-S4
PNP, NC Ordering code BES00YC
Part number BES 516-367-E5-Y-S4
Part number
NPN, NO Ordering code BES00UC
Part number BES 516-355-E5-Y-S4
Part number
NPN, complementary Ordering code
Part number
Ambient temperature Ta 25...+70C 25...+70C 40...+105 C*
Output function indicator Yellow LED Yellow LED No
Degree of protection as per IEC 60529 IP 67 IP 67 IP 69K,
IP 68 as per BWN Pr. 27
Special properties Resistant to
high pressure cleaners

24 24
29.5
29.5

44.5
44.5
LED LED
M12x1 M12x1
*max. load current over temperature
130 mA
20 mA
40 C +70 C +85 C +105 C

M181 M181 M181 M181 M181

0...4 mm 0...4 mm 0...4 mm 0...4 mm 0...4 mm
BES01CW BES01CZ BES02EU BES00R5 BES00R0 sensors
BES 516-326-S4-C BES 516-326-S4-H BES 515-326-S4-C BES 516-326-E4-C-S4-00,2 BES 516-326-E4-C-02 Global
BES01JW DC 3-wire
BES 516-367-S4-C
DC 3-/4-wire
BES015N
Tubular
BES01H0 Block
housings
BES 516-355-S4-C
BES01JU DC 2-wire
BES 516-366-S4-C
BES015U AC/DC 2-wire
BES 516-111-S4-C AC 2-wire
2.5 V 1.5 V 1.5 V 2V 2V Analog
distance
250 V AC ([) 250 V AC ([) 250 V AC ([) 75 V DC 75 V DC measurement
200 mA 200 mA 200 mA 200 mA 200 mA
properties
25...+70C 25...+70C 40...+85 C 25...+70C 25...+70C
900 Hz 900 Hz 900 Hz 1 kHz 1 kHz Special
accessories
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 IP 67
CE, cULus CE CE, cULus CE, cULus CE, cULus
Brass-coated Brass-coated Stainless steel Brass-coated Brass-coated

PA 12 PA 12 PA 12 PA 12 PBT
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin 0.2 m PUR cable 2 m PVC cable,
M18x1
30
36
24
50
58
73
83
LED
41.5
24
M12x1
14.5
www.balluff.com 539

PNP, NO Ordering code BES01CE BES030R BES00RC
Part number BES 516-326-BO-C-02 BES 516-326-G-E5-Y-S49 BES 516-326-G-E5-C-S4
PNP, NC Ordering code BES00YK BES00YJ
Part number BES 516-367-G-E5-Y-S49 BES 516-367-G-E5-Y-S4
Part number
NPN, NO Ordering code BES01JP BES00UK BES00UJ
Part number BES 516-366-BO-C-02 BES 516-355-G-E5-Y-S49 BES 516-355-G-E5-Y-S4
Part number
Sensing surface PA 12 PBT PBT
Connection 2 m PVC cable, M8 connector, 3-pin M12 connector, 4-pin

22 AWG

for installation instructions. M18x1
24
29.5
30

44.5
24
44
LED
LED M8x1
M12x1

M181 M181 M181 M181 M181

0...6.3 mm 0...6.4 mm 0...6.4 mm 0...6.4 mm 0...6.4 mm
BES02P3 BES02H0 BES01CT BES01CU BES00RA sensors
BES 516-326-SA96-G-E5-Y-S4 BES M18EI-PSC80B-S04G BES 516-326-G-S4-C BES 516-326-G-S4-H BES 516-326-G-E4-C-S4-00,3 Global
BES02FZ DC 3-wire
BES M18EI-POC80B-S04G
DC 3-/4-wire
BES015M
Tubular
BES 516-105-G-S4-H housings
BES02P4 BES02FY Block
housings
BES 516-355-SA96-G-E5-Y-S4 BES M18EI-NSC80B-S04G
BES02FW DC 2-wire
BES M18EI-NOC80B-S04G
3.5 V 2.5 V 2.5 V 2.5 V 2.5 V AC 2-wire
75 V DC 250 V AC ([) 75 V DC ([) 75 V DC 75 V DC
distance
25...+70C 40...+85 C 0...70 C 0...+70 C 25...+70C
200 Hz 700 Hz 80 Hz 80 Hz 500 Hz Special
properties
Yellow LED Yellow LED Yes Yellow LED Yellow LED
IP 67 IP 68 per BWN Pr. 20 IP 67 IP 67 IP 67 Special
accessories
CE, cULus CE, cULus CE, cULus CE CE, cULus
Brass-coated Stainless steel Brass-coated Brass-coated Brass-coated
with ceramic PBT PBT PBT PBT
coating
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin 0.3 m PUR cable
M18x1 M18x1 M18x1
24
29.5
31
37
24
44.5
24
50
65
LED LED
M12x1
11
LED
M12x1
41.5
M12x1
www.balluff.com 541

Installation type (observe instructions in the Basic Information chapter) Flush Quasi-ush Quasi-ush
PNP, NO Ordering code BES01CN BES02Y5 BES02Y9
Part number BES 516-326-G-BO-C-PU-02 BES M18MD1-PSC12B-S04G BES M18MG1-PSC12B-S04G
Part number
NPN, NO Ordering code BES02Y4 BES02Y8
Part number BES M18MD1-NSC12B-S04G BES M18MG1-NSC12B-S04G
Ambient temperature Ta 0...+70 C 25...+70C 25...+70C


Special properties Large switching Large switching
distance distance
Sensing surface PA 12 PBT PBT
Connection 2 m PUR cable, 22 AWG M12 connector, 4-pin M12 connector, 4-pin
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020


50.5
76.5
LED

M181 M181 M181 M181 M181

Non-ush Non-ush Non-ush Non-ush Non-ush
0...6.5 mm 0...6.5 mm 0...6.5 mm 0...6.5 mm 0...6.5 mm
BES00WM BES02FK BES02FM BES03AW BES01HY sensors
BES 516-360-E5-Y-S4 BES 515-360-E5-T-S4 BES 515-360-SA12-S4-T BES 516-360-S4-L BES 516-360-S4-C Global
BES00LL BES0193 DC 3-wire
BES 516-3026-E5-Y-S4 BES 516-3026-S4-C
DC 3-/4-wire
BES00WT
Tubular
BES 516-361-E5-Y-S4 housings
housings
3.5 V 3.5 V 3.5 V 2.5 V 1.5 V
75 V DC 75 DC 75 V DC 250 V AC ([) 250 V AC ([) DC 2-wire
130 mA 130 mA 130 mA 400 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/No/No Yes/Yes/Yes AC/DC 2-wire
25...+70C 40...+105 C* 40...+85 C 40...+85 C 25...+70C AC 2-wire
(momentarily 105 C)
200 Hz 200 Hz 200 Hz 200 Hz 600 Hz Analog
distance
Yellow LED No No Yellow LED Yellow LED measurement
IP 67 IP 69K, IP 69K, IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20
IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 27 Special
properties
Resistant to Resistant to Special
accessories
high pressure cleaners high pressure cleaners
Brass-coated Stainless steel Stainless steel Brass-coated Brass-coated
PA 12 PA 12 PA 12 PA 12 PA 12
M12x1
*max. load current over temperature
130 mA
20 mA
40 C +70 C +85 C +105 C
www.balluff.com 543

PNP, NO Ordering code BES02FL
Part number
PNP, complementary Ordering code BES016Y
NPN, NO Ordering code BES01J5
NPN, NC Ordering code BES019H
NPN, complementary Ordering code BES0171
Ambient temperature Ta 40...+85 C 25...+70C 40...+85 C



M181 M181 M181 M181

8 mm 8 mm 8 mm 8 mm
0...6.5 mm 0...6.5 mm 0...6.5 mm 0...6.5 mm
BES00WH sensors
BES 516-360-E4-Y-02 Global
BES00LH BES018Z DC 3-wire
BES 516-3026-E4-Y-02 BES 516-3026-BO-C-02
DC 3-/4-wire
BES02E1
Tubular
BES00WN BES01HZ Block
housings
BES 516-361-E4-Y-02 BES 516-361-BO-C-02
BES019F DC 2-wire
BES 516-3031-BO-C-02
AC/DC 2-wire
AC 2-wire
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
2.5 V 3.5 V 2.5 V 1.5 V Analog
distance
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) measurement
200 mA 130 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Special
properties
40...+85 C 25...+70C 25...+70C 25...+70C
accessories
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 IP 68 per BWN Pr. 20
CE, cULus CE, cULus CE, cULus CE, cULus
Stainless steel Brass-coated Brass-coated Brass-coated
PA 12 PA 12 PA 12 PA 12
M12 connector, 4-pin 2 m PVC cable, 22 AWG 2 m PVC cable, 22 AWG 2 m PVC cable, 22 AWG
BCC M415-0000-1A-003-EX44T2-020
www.balluff.com 545

Installation type (observe instructions in the Basic Information chapter) Non-ush Non-ush
PNP, NO Ordering code BES016W BES02Y7
Part number BES 516-123-G-S4-H BES M18ME1-PSC20F-S04G
PNP, NC Ordering code BES01HW
Part number BES 516-360-G-S4-H
Part number
NPN, NO Ordering code BES02Y6
Part number BES M18ME1-NSC20F-S04G
Part number
Voltage drop Ud at Ie max. 2.5 V 2V
Rated insulation voltage Ui (protection class) 250 V AC ([) 75 V DC
Degree of protection as per IEC 60529 IP 68 per BWN Pr. 20 IP 67
Approvals CE CE
Special properties Large switching distance
Sensing surface PA 12 PBT


Monitor rotary speed

Two inductive sensors are used to protect rotary applications from
overspeed. Attached to a perforated disk, they determine rotary
speed and direction.
Extremely reliable (EMC, shock)
For extreme conditions (temperature uctuations)
Long service life
M301.5 M301.5 M301.5 M301.5 M301.5

10 mm 10 mm 10 mm 10 mm 10 mm
0...8 mm 0...8.1 mm 0...8.1 mm 0...8.1 mm 0...8.1 mm
BES00RP BES01EE BES02F1 BES00RF sensors
BES 516-327-E5-Y-S4 BES 516-327-S4-C BES 515-327-S4-C BES 516-327-E4-Y-02 Global
BES00LM BES0195 DC 3-wire
BES 516-3028-E5-Y-S4 BES 516-3028-S4-C
DC 3-/4-wire
BES0167 BES02E0
Tubular
BES 516-114-S4-C BES 515-114-S4-C housings
BES00W9 BES01HL BES00W5 Block
BES 516-359-E5-Y-S4 BES 516-359-S4-C BES 516-359-E4-Y-02 housings
BES016J DC 2-wire
BES 516-120-S4-C
3.5 V 2.5 V 2.5 V 2.5 V 3.5 V
AC 2-wire
75 V DC 250 V AC ([) 250 V AC ([) 250 V AC ([) 75 V DC
distance
25...+70C 25...+70C 25...+70C 40...+85 C 25...+70C
properties
IP 67 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 Special
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus accessories
Brass-coated Brass-coated Stainless steel Stainless steel Brass-coated

PA 12 PA 12 PA 12 PA 12 PA 12
M30x1.5 M30x1.5
36 36
30
30
36
44.5
LED LED
M12x1
www.balluff.com 547

Assured switching distance sa 0...8.1 mm 0...12 mm 0...12 mm
PNP, NO Ordering code BES01E3 BES00RY BES00RW
Part number BES 516-327-BO-C-02 BES 516-327-G-E5-Y-S49 BES 516-327-G-E5-Y-S4
PNP, NC Ordering code BES00LU
Part number BES 516-3028-G-E5-Y-S4
Part number
NPN, NO Ordering code BES01HF BES00WE
Part number BES 516-359-BO-C-02 BES 516-359-G-E5-Y-S49
Special properties
Connection 2 m PVC cable, 22 AWG M8 connector, 3-pin M12 connector, 4-pin

36
30
44.5
LED
M12x1

M301.5 M301.5 M301.5 M301.5 M301.5

Flush Flush Flush Quasi-ush Non-ush
15 mm 15 mm 15 mm 22 mm 15 mm
0...12 mm 0...12 mm 0...12 mm 0...17.6 mm 0...12.2 mm
BES01EA BES01EC BES00RR BES02YM BES00Y0 sensors
BES 516-327-G-S4-C BES 516-327-G-S4-H BES 516-327-G-E4-Y-02 BES M30MI1-PSC22B-S04G BES 516-362-E5-Y-S4 Global
BES00LN BES02YL BES00LZ DC 3-wire
BES 516-3028-G-E4-Y-02 BES M30MI1-POC22B-S04G BES 516-3029-E5-Y-S4
DC 3-/4-wire
BES0166 BES00Y4
Tubular
BES 516-114-G-S4-H BES 516-363-E5-Y-S4 housings
BES00WA BES02YK Block
housings
BES 516-359-G-E4-Y-02 BES M30MI1-NSC22B-S04G
2.5 V 2.5 V 3.5 V 2V 3.5 V
250 V AC ([) 250 V AC ([) 75 V DC 75 V DC 75 V DC AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Analog
distance
100 Hz 150 Hz 100 Hz 200 Hz 100 Hz measurement
IP 67 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 67 IP 67 Special
properties
CE, cULus CE CE, cULus CE CE, cULus
accessories
Brass-coated Brass-coated Brass-coated Brass-coated Brass-coated
PA 12 PA 12 PA 12 PBT PA 12
M12 connector, 4-pin M12 connector, 4-pin 2 m PVC cable, 22 AWG M12 connector, 4-pin M12 connector, 4-pin
M30x1.5
36
30
36
LED
www.balluff.com 549

PNP, NO Ordering code BES01JE BES03AL BES01JF
Part number BES 516-362-S4-C BES M30ML-PSC15F-S04G-002 BES 516-362-S4-H
NPN, NO Ordering code BES01JN BES03AT
Part number BES 516-363-S4-C BES M30ML-NSC15F-S04G-002
NPN, NC Ordering code BES019N
Special properties


M12x1 M12x1 M12x1

M301.5 M301.5 M301.5 M301.5 M301.5

Non-ush Non-ush Non-ush Non-ush Non-ush
15 mm 15 mm 15 mm 30 mm 40 mm
0...12.2 mm 0...12.2 mm 0...12.2 mm 0...24.00 mm 0...32 mm
BES02FN BES00WU BES01J6 BES01JC BES02YJ sensors
BES 515-362-S4-C BES 516-362-E4-Y-02 BES 516-362-BO-C-02 BES 516-362-G-S4-H BES M30MG1-PSC40F-S04G Global
BES00LW DC 3-wire
BES 516-3029-E4-Y-02
DC 3-/4-wire
BES01JJ
Tubular
BES 516-363-BO-C-02 housings
BES00Y1 BES019L BES02YH Block
housings
BES 516-363-E4-Y-02 BES 516-3033-BO-C-02 BES M30MG1-NSC40F-S04G
DC 2-wire

2.5 V 3.5 V 2.5 V 2.5 V 2V AC 2-wire
250 V AC ([) 75 V DC 250 V AC ([) 250 V AC 75 V DC
distance
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C
properties
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 54 Special
accessories
CE, cULus CE, cULus CE, cULus CE CE
Large switching distance
Stainless steel Brass-coated Brass-coated Brass-coated Brass-coated
PA 12 PA 12 PA 12 PA 12 PBT
M12 connector, 4-pin 2 m cable PVC, 22 AWG 2 m cable PVC, 22 AWG M12 connector, 4-pin M12 connector, 4-pin
M12x1 M12x1
www.balluff.com 551
DC 3-/4-wire Inductive Block Sensors
Block housing, 55 mm
Five good reasons for using inductive 5x5 sensors

Rugged, compact metal housing
Switching variants (can be installed ush): 0.8 mm for
high-precision applications, new 1.5 mm for extended range applications
Connections: Supply (+), Ground (-), Output. Easy to
integrate into standard and special controllers.
Interface variants: PNP or NPN, normally open or normally closed Housing size
Narrow installation design Installation type (observe instructions in the Basic Information chapter)
Sensing distance
Part number
Part number
Part number
Part number
Supply voltage UB
Electronics manufacturing: Applications require miniature sen-
sors. Balluff offers mini.s in the highest degree of precision. Rated insulation voltage Ui
Approvals
Special properties
Material Housing
Sensing surface
Robotics automation: The trend towards miniaturization contin- Connection
ues. Balluff is leading the way.


Punching/reshaping technology: Automated assemblies are

getting smaller and smaller. Balluff sensors adapt to this.
Linear technology: Position detection mini sensor designs

achieve precise position with maximum performance.

3-/4-Wire Block housing, 55 mm
55 mm 55 mm 55 mm 55 mm 55 mm
0.8 mm 0.8 mm 0.8 mm 0.8 mm 0.8 mm
0...0.65 mm 0...0.65 mm 0...0.65 mm 0...0.65 mm 0...0.65 mm
sensors
BES01RM BES01ZF BES019W BES019T BES019P
BES Q05AC-PSC08B-S26G BES 516-3040-I02-C-S49 BES 516-3040-I02-C-S49-00,3 BES 516-3040-I02-C-S4-00,3 BES 516-3040-I02-C-PU-02 Global
BES01RH BES01ZH BES01A1 DC 3-wire
BES Q05AC-POC08B-S26G BES 516-3042-I02-C-S49 BES 516-3042-I02-C-PU-02
DC 3-/4-wire
BES01RA BES01A0 BES019Y Tubular
BES Q05AC-NSC08B-S26G BES 516-3041-I02-C-S49 BES 516-3041-I02-C-PU-02 housings
BES01R6 BES01A5 BES01A3 Block
housings
BES Q05AC-NOC08B-S26G BES 516-3043-I02-C-S49 BES 516-3043-I02-C-PU-02
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
75 V DC 75 DC 75 V DC 75 V DC 75 V DC AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Special
properties
measurement
Slim design Slim design Slim design Slim design Slim design Accessories
Anodized aluminum Anodized aluminum Anodized aluminum Anodized aluminum Anodized aluminum
PBT PBT PBT PBT PBT
M5 connector, 3-pin M8 connector, 3-pin 0.3 m PUR cable 0.3 m PUR cable 2 m PUR cable,
BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
50
37
www.balluff.com 553
PNP, NO Ordering code BES01RP BES01RR BES03UW
Part number BES Q05AC-PSC15B-S26G BES Q05AC-PSC15B-S49G BES Q05AC-PSC15B-EP00,3-GS49
PNP, NC Ordering code BES01RK BES01RL
Part number BES Q05AC-POC15B-S26G BES Q05AC-POC15B-S49G
NPN, normally open Ordering code BES01RE BES01RF
Part number BES Q05AC-NSC15B-S26G BES Q05AC-NSC15B-S49G
NPN, NC Ordering code BES01R8 BES01R9
Part number BES Q05AC-NOC15B-S26G BES Q05AC-NOC15B-S49G
See technical section (page 963-966) 1.5 5x5

5.6

2.8
M1.6
14
25

46
LED
M8x1
37

55 mm
Flush
1.5 mm
0...1.2 mm
2X Inductive
sensors
BES01RN
BES Q05AC-PSC15B-EP02 Global
BES01RJ DC 3-wire
BES Q05AC-POC15B-EP02
DC 3-/4-wire
BES01RC Tubular
BES Q05AC-NSC15B-EP02 housings
BES01R7 Block
housings
BES Q05AC-NOC15B-EP02
10...30 V DC DC 2-wire
3V
75 V DC AC/DC 2-wire
100 mA AC 2-wire
Yes/Yes/Yes
25...+70C Special
properties
2 kHz
Yellow LED Analog
IP 67 distance
measurement
CE, cULus
Slim design Accessories
Stainless steel
PBT
2 m PUR cable,
26 AWG
1.5 5
5.6
LED
2.8
25
14
2xM1.6
www.balluff.com 555
PNP, NO Ordering code BES03U1 BES03Y6 BES0180
Part number BES Q08MEC-PSC15B-S26G BES Q08MEC-PSC15B-S49G BES 516-300-S166-S49
PNP, NC Ordering code BES03YE BES03U0 BES0187
Part number BES Q08MEC-POC15B-S26G BES Q08MEC-POC15B-S49G BES 516-300-S180-S49
NPN, NO Ordering code BES03Y7 BES03U8 BES0184
Part number BES Q08MEC-NSC15B-S26G BES Q08MEC-NSC15B-S49G BES 516-300-S170-S49
NPN, NC Ordering code BES03U9 BES03YC BES018H
Part number BES Q08MEC-NOC15B-S26G BES Q08MEC-NOC15B-S49G BES 516-300-S264-S49
Material Housing Brass-coated Brass-coated Cast zinc
See technical section (page 963-966) 3 8 3 8 8

3
5
5
5
10
10
10

24.2
20
20
26.7
LED LED
M3
M3

M3
20
50
M5x0.5
59
M81
LED
M8x1

SUPERSHORTY SUPERSHORTY SUPERSHORTY SUPERSHORTY

88 mm 88 mm 88 mm 88 mm 88 mm
1.5 mm 1.5 mm 1.5 mm 1.5 mm 2 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.6 mm
BES041J BES041C BES03TZ BES017R BES03U4 sensors
BES Q08MEC-PSC15B-EP00,3-GS26 BES Q08MEC-PSC15B-EP00,3-GS49 BES Q08MEC-PSC15B-EP02 BES 516-300-S166-02 BES Q08MEC-PSC20B-S26G Global
BES041K BES041E BES03Y5 BES03YH DC 3-wire
BES Q08MEC-POC15B-EP00,3-GS26 BES Q08MEC-POC15B-EP00,3-GS49 BES Q08MEC-POC15B-EP02 BES Q08MEC-POC20B-S26G
DC 3-/4-wire
BES041L BES041F BES03YA BES03Y9 Tubular
BES Q08MEC-NSC15B-EP00,3-GS26 BES Q08MEC-NSC15B-EP00,3-GS49 BES Q08MEC-NSC15B-EP02 BES Q08MEC-NSC20B-S26G housings
BES041M BES041H BES03U7 BES03UE Block
housings
BES Q08MEC-NOC15B-EP00,3-GS26 BES Q08MEC-NOC15B-EP00,3-GS49 BES Q08MEC-NOC15B-EP02 BES Q08MEC-NOC20B-S26G
2.8 V 2.8 V 2.8 V 2.5 V 2.8 V
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Special
properties
measurement
Short design Short design Short design Short design Accessories
Brass-coated Brass-coated Brass-coated Cast zinc Brass-coated
PBT PBT PBT PBT PBT
0.3 m PUR cable 0.3 m PUR cable 2 m PUR cable, 2 m PVC cable, M5 connector, 3-pin
with M5 connector, 3-pin with M8 connector, 3-pin 26 AWG 26 AWG
BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020 BKS-B 25-3-PU-03
3 8 3 8 3 8 3 8
5
5
5
5
10
10
10
10
24.2
20
20
20
20
LED LED LED

M3
M3
M3
LED
M3
M5x0.5
30.5
37
M5x0.5
M8x1
www.balluff.com 557
Supershorty inductive sensors

Thanks to the miniture housing size, position sensing is now also
possible when minimum space is required
Assemblies can be shrunk even futher, since the sensors require
less space
Ideal price/performance ratio
Robust due to high-quality metal housing Housing size
Installation type (observe instructions in the Basic Information chapter)
Common application examples Rated switching distance sn
Linear units Assured switching distance sa
Machine position Sensing distance
Part presence PNP, NO Ordering code
Robotics and automation Part number
Vibrating conveyor PNP, NC Ordering code
Error proong Part number
NPN, normally open Ordering code
Part number
Part number
Supply voltage UB
Approvals
Special properties
Material Housing
Sensing surface
Connection




88 mm 88 mm 88 mm 88 mm 88 mm
0...1.6 mm 0...1.6 mm 0...1.6 mm 0...1.6 mm 0...1.6 mm
sensors
BES03Y8 BES01U2 BES01UW BES041U BES041N
BES Q08MEC-PSC20B-S49G BES Q08ZC-PSC20B-S49G BES Q08ZE-PSC20B-S49G BES Q08MEC-PSC20B-EP00,3-GS26 BES Q08MEC-PSC20B-EP00,3-GS49 Global
BES03U3 BES01TF BES01UK BES041W BES041P DC 3-wire
BES Q08MEC-POC20B-S49G BES Q08ZC-POC20B-S49G BES Q08ZE-POC20B-S49G BES Q08MEC-POC20B-EP00,3-GS26 BES Q08MEC-POC20B-EP00,3-GS49
DC 3-/4-wire
BES03UC BES01T3 BES01UC BES041Y BES041R Tubular
BES Q08MEC-NSC20B-S49G BES Q08ZC-NSC20B-S49G BES Q08ZE-NSC20B-S49G BES Q08MEC-NSC20B-EP00,3-GS26 BES Q08MEC-NSC20B-EP00,3-GS49 housings
BES03YJ BES01RW BES01U6 BES041Z BES041T Block
housings
BES Q08MEC-NOC20B-S49G BES Q08ZC-NOC20B-S49G BES Q08ZE-NOC20B-S49G BES Q08MEC-NOC20B-EP00,3-GS26 BES Q08MEC-NOC20B-EP00,3-GS49
2.8 V 2.5 V 2.5 V 2.8 V 2.8 V
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Special
properties
measurement
Short design Short design Short design Accessories
Brass-coated Cast zinc Cast zinc Brass-coated Brass-coated
PBT PBT PBT PBT PBT
M8 connector, 3-pin M8 connector, 3-pin M8 connector, 3-pin 0.3 m PUR cable 0.3 m PUR cable
BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020
3 8 8 3 8 3 8
3
5
5
5
10
10
10
10
20
20
20
26.7
LED LED LED

M3
M3
M3
M3
20
50
59
M81
LED
30.5
37
M8x1
M5x0.5
M8x1
www.balluff.com 559
SUPERSHORTY
PNP, NO Ordering code BES03U2 BES01TZ BES01TN
Part number BES Q08MEC-PSC20B-EP02 BES Q08ZC-PSC20B-BV02 BES Q08ZC-PSC20B-BP02
PNP, NC Ordering code BES03YK BES01TA BES01T7
Part number BES Q08MEC-POC20B-EP02 BES Q08ZC-POC20B-BV02 BES Q08ZC-POC20B-BP02
NPN, NO Ordering code BES01T2 BES01RZ
Part number BES Q08ZC-NSC20B-BV02 BES Q08ZC-NSC20B-BP02
NPN, NC Ordering code BES03UA BES01RU BES01TL
Part number BES Q08MEC-NOC20B-EP02 BES Q08ZC-NOC20B-BV02 BES Q08ZC-NOC20B-BP02
Special properties
Material Housing Brass-coated Cast zinc Cast zinc
Connection 2 m PUR cable, 26 AWG 2 m PVC cable, 26 AWG 2 m PUR cable, 26 AWG

5

10
20
LED
M3


88 mm 88 mm 88 mm 88 mm 88 mm
Flush Flush Flush Flush Quasi-ush
2 mm 2 mm 2.5 mm 2.5 mm 3 mm
0...1.6 mm 0...1.6 mm 0...2 mm 0...2 mm 0...2.4 mm
sensors
BES01UR BES01UM BES01U3 BES01UY BES01U4
BES Q08ZE-PSC20B-BV02 BES Q08ZE-PSC20B-BP02 BES Q08ZC-PSC25B-S49G BES Q08ZE-PSC25B-S49G BES Q08ZC-PSC30B-S49G Global
BES01UH BES01UE DC 3-wire
BES Q08ZE-POC20B-BV02 BES Q08ZE-POC20B-BP02
DC 3-/4-wire
BES01UA BES01U7 Tubular
BES Q08ZE-NSC20B-BV02 BES Q08ZE-NSC20B-BP02 housings
Block
housings

2.5 V 2.5 V 2.5 V 2.5 V 2V
25...+70C 25...+70C 0...+70 C 0...+70 C 25...+70C Special
properties
measurement
CE, cULus CE, cULus CE, cULus CE, cULus CE
Long range Accessories
Cast zinc Cast zinc Cast zinc Cast zinc Brass-coated
PBT PBT PBT PBT PBT
2 m PVC cable, 26 AWG 2 m PUR cable, 26 AWG M8 connector, 3-pin M8 connector, 3-pin M8 connector, 3-pin
BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
8
3
5
10
M3
20
50
59
LED
M8x1
www.balluff.com 561
Block housings, 8164 mm R04
Housing size 8164.7 mm R04 8164.7 mm 8164.7 mm R04

PNP, NO Ordering code BES01YC BES01YE BES01YJ
Part number BES R04KC-PSC15B-EP00,2-GS26 BES R04KC-PSC15B-EP00,3-GS49 BES R04KC-PSC15B-EV02
PNP, NC Ordering code BES01Y7 BES01Y8 BES03J1
Part number BES R04KC-POC15B-EP00,2-GS26 BES R04KC-POC15B-EP00,3-GS49 BES R04KC-POC15B-EV02
NPN, normally open Ordering code BES01Y3
Part number BES R04KC-NSC15B-EV02
NPN, NC Ordering code BES01WY BES01WZ
Part number BES R04KC-NOC15B-EP00,2-GS26 BES R04KC-NOC15B-EV02
Switching frequency f max. 600 Hz 600 Hz 2.5 kHz
Material Housing PA 6 PA 6 PA 6
Sensing surface PA 6/GF 30 PA 6/GF 30 PA 6/GF 30
Connection 0.2 m PUR cable 0.3 m PUR cable 2 m PVC cable,
Suggested mating cable BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020
See technical section (page 963-966) 4.7

for installation instructions. 8 4
5.7

2.6
4
12
16

LED
30.5
M5x0.5

3-/4-Wire Block housings, 8164 mm R04
8164.7 mm R04 8164.7 mm R04 8164.7 mm R04 8164.7 mm R04 8164.7 mm R04
Flush Flush Flush Flush Non-ush
1.5 mm 2 mm 2 mm 2 mm 2.5 mm
0...1.2 mm 0...1.6 mm 0...1.6 mm 0...1.6 mm 0...2.2 mm
sensors
BES01YF BES03UN BES048E BES049E BES01YM
BES R04KC-PSC15B-EP02 BES RO4MC-PSC20B-EP02 BES RO4MC-PSC20B-EP00,2-GS49 BES RO4MC-PSC20B-EP00,2-GS49-107 BES R04KC-PSC25F-EP00,3-GS49 Global
BES0447 DC 3-wire
BES R04KC-POC25F-EP00,3-GS49
DC 3-/4-wire
Tubular
housings
Block
housings

2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
25...+70C 25...+70C 25...+70C 25...+70C 25...+70C Special
properties
2.5 kHz 5,000 Hz 5,000 Hz 5,000 Hz 3 kHz
measurement
PA 6 CuZn Ni-free coating CuZn Ni-free coating CuZn Ni-free coating PA 6 Accessories
PA 6/GF 30 PBT PBT Ceramic PA 6/GF 30
2 m PUR cable, 2 m PUR cable, 0.2 m PUR cable 0.2 mm silicon rubber 0.3 m PUR cable
26 AWG 26 AWG with M8 connector, 3-pin cable with M8 connector, 3-pin with M8 connector, 3-pin
BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
8.0 4.7
LED LED
LED
4.0
12.0
16.0
3.1
6.5
D
D D
www.balluff.com 563
Housing size 8164 mm R04

Installation type (observe instructions in the Basic Information chapter) Non-ush
Rated switching distance sn 2.5 mm
Assured switching distance sa 0...2 mm
Sensing distance 2X
PNP, NO Ordering code BES01YT
Part number BES R04KC-PSC25F-EV02
Part number
NPN, normally open Ordering code
Part number
Part number
Voltage drop Ud at Ie max. 2.5 V
Rated insulation voltage Ui 75 V DC
Rated operating current Ie 100 mA
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes
Switching frequency f max. 150 Hz
Approvals CE, cULus
Material Housing PA 6
Sensing surface PA 6/GF 30
Connection 2 m PVC cable,
28 AWG
See technical section (page 963-966) 4.7

5.7
2.6

4
12
16

LED

8164 mm R04
Non-ush
2.5 mm
0...2.2 mm
2X Inductive
sensors
BES01YN
BES R04KC-PSC25F-EP02 Global
DC 3-wire
DC 3-/4-wire
BES03R8 Tubular
BES R04KC-NSC25F-EP02 housings
Block
housings
10...30 V DC DC 2-wire
2.5 V
AC/DC 2-wire
75 V DC
100 mA AC 2-wire
Yes/Yes/Yes
25...+70C Special
properties
3 kHz
Yellow LED Analog
distance
IP 67 measurement
CE, cULus
PA 6 Accessories
PA 6/GF 30
2 m PUR cable,
26 AWG
4.7
8 4
5.7
2.6
4
12
16
LED
www.balluff.com 565
Housing size 10306 mm R03 10306 mm R03

Installation type (observe instructions in the Basic Information chapter) Flush Flush
Assured switching distance sa 0...2.4 mm 0...2.4 mm
PNP, NO Ordering code BES01WP BES01WR
Part number BES R03KC-PSC30B-BP00,3-GS49 BES R03KC-PSC30B-EP02
NPN, normally open Ordering code BES045C
Part number BES R03KC-NSC30B-BP00,3-GS49
Rated insulation voltage Ui 75 V DC 75 V DC
Switching frequency f max. 3 kHz 3 kHz
Material Housing PA 6 PA 6
Sensing surface PA 6 PA 6
Connection 0.3 m PUR cable 2 m cable TPU,

5
3.2
22
27
90
LED

3-/4-Wire Block housings, 10306 mm R03, 302010 mm
10306 mm R03 10306 mm R03 302010 mm

Non-ush Non-ush Flush
3 mm 3 mm 2 mm
0...2.4 mm 0...2.4 mm 0...1.6 mm
1X 1X 1X Inductive
sensors
BES02ZN BES0397 BES033J
BES R03KC-PSC30F-BV00.2-GS49 BES R03KC-PSC30F-BV00.3-GS04 BES 516-300-S279 Global
BES033H DC 3-wire
BES 516-300-S255
DC 3-/4-wire
10...30 V DC 10...30 V DC 10...30 V DC Tubular
1.5 V 1.5 V 0.5 V housings
75 V DC 75 V DC 75 V DC Block
housings
100 mA 100 mA 50 mA
No/No/Yes No/No/Yes Yes/No/No DC 2-wire
25...+70C 25...+70C 25...+70C
500 Hz 500 Hz 1.5 kHz AC/DC 2-wire
Yellow LED Yellow LED Yes/No AC 2-wire
IP 67 IP 67 IP 65
Special
properties
PA 6 PA 6 Anodized GD-Al
PA 6 PA 6 PBT Analog
0.2 m PVC cable 0.3 m PVC cable 5 m PVC cable, distance
measurement
BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 Accessories
10 6
17
30
90
8
3.2
LED
41.5
M12x1
www.balluff.com 567
Block housings, 163010 mm
Housing size 163010 mm 163010 mm

PNP, NO Ordering code BES01NA BES01N4
Part number BES 517-398-NO-C-S49-00,2 BES 517-398-NO-C-02
PNP, NC Ordering code BES01MT BES01ML
Part number BES 517-351-NO-C-S49-00.2 BES 517-351-NO-C-02
NPN, NO Ordering code BES01NM BES01NF
Part number BES 517-399-NO-C-S49-00,2 BES 517-399-NO-C-02
NPN, NC Ordering code BES01MY
Part number BES 517-352-NO-C-02
Part number
Voltage drop Ud at Ie max. 2V 2V
Switching frequency f max. 2.5 kHz 2.5 kHz
Approvals CE CE
Connection 0.2 m PUR cable 2 m PVC cable,



20328 mm R01 20328 mm R01

Flush Flush
7 mm 7 mm
0...5.6 mm 0...5.6 mm
1X 1X Inductive
sensors
BES01WF BES01WE
BES R01ZC-PSC70B-BP00.3-GS49 BES R01ZC-PSC70B-BP00.2-GS49 Global
DC 3-wire
DC 3-/4-wire
BES01W1 Tubular
BES R01ZC-NSC70B-BP00.2-GS49 housings
Block
housings
DC 2-wire
10...30 V DC 10...30 V DC AC/DC 2-wire

2.5 V 2.5 V AC 2-wire
75 V DC 75 V DC
200 mA 200 mA Special
properties
Yes/Yes/Yes Yes/Yes/Yes
25...+70C 25...+70C Analog
150 Hz 150 Hz distance
measurement
IP 67 IP 67 Accessories
CE, cULus CE, cULus
Cast zinc Cast zinc
PA 12 PA 12
0.3 m PUR cable 0.2 m PUR cable
BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
Note: R01 Steelface sensors are located on

page 669.
max. 39
max. 39
M8x1 M8x1
www.balluff.com 569
Housing size 20328 mm R01 20328 mm R01 20328 mm R01

PNP, NO Ordering code BES02PT
Part number BES R01ZC-PSC70B-BP00.2-GS04-101
PNP, complementary Ordering code BES01W2 BES0314
Part number BES R01ZC-PAC70B-BP00.2-GS04 BES R01ZC-PAC70B-BP00.2-GS04-107
NPN, complementary Ordering code BES01UZ
Part number BES R01ZC-NAC70B-BP00.2-GS04
Material Housing Cast zinc Cast zinc Cast zinc
Sensing surface With ceramic coating PA 12 With ceramic coating
Connection 0.2 m PUR cable 0.2 m PVC cable 0.2 m PUR cable


Note: R01 Steelface sensors are located on page 669.

3-/4-Wire Block housings 205010mm
205010 mm 205010 mm 205010 mm 205010 mm

Flush Flush Flush Flush
5 mm 5 mm 5 mm 5 mm
0...4.1 mm 0...4.1 mm 0...4.1 mm 0...4.1 mm
sensors
BES01FR BES01FT BES01FN BES01FH
BES 516-347-M0-C-S49 BES 516-347-M0-C-S49-00,2 BES 516-347-M0-C-S4-00,2 BES 516-347-M0-C-02 Global
BES0153 BES0179 DC 3-wire
BES 516-133-M0-C-S4-00,2 BES 516-133-M0-C-02 DC 3-/4-wire
Tubular
housings
housings
2.5 V 2.5 V 2.5 V 2.5 V
75 V DC 75 V DC 75 V DC 75 V DC DC 2-wire
200 mA 200 mA 200 mA 200 mA
AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C AC 2-wire
500 Hz 500 Hz 500 Hz 500 Hz
properties
IP 67 IP 67 IP 67 IP 67
CE, cULus CE, cULus CE, cULus CE, cULus Analog
distance
Cast aluminum Cast aluminum Cast aluminum Cast aluminum measurement
PBT PBT PBT PBT
M8 connector, 0.2 m PUR cable 0.2 m PUR cable 2 m PVC cable, Accessories
3-pin with M8 connector, 3-pin with M12 connector, 4-pin 22 AWG
BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
10
10
50
LED LED
50
8
8
M8x1
www.balluff.com 571

PNP, NO Ordering code BES01Z7 BES01Z3
Part number BES R05KB-PSC20B-S49A BES R05KB-PSC20B-BP00,3-GS49
Part number
Part number
Part number
Rated insulation voltage Ui (protection class) 75 V DC 75 V DC
Material Housing PA 12 PA 12
Connection M8 connector, 3-pin 0.3 m PUR cable with M8 connector, 3-pin
Suggested mating cable BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020
See technical section (page 963-966) Sensing surface Sensing surface


max. 40

264012 mm R05 264012 mm R05 264012 mm R05 264012 mm R05

2 mm 4 mm 4 mm 4 mm
0...1.6 mm 0...3.2 mm 0...3.2 mm 0...3.2 mm
sensors
BES01Z4 BES01ZE BES01Z8 BES01ZA
BES R05KB-PSC20B-EP02 BES R05KB-PSC40B-S49A BES R05KB-PSC40B-EP00,3-GS04 BES R05KB-PSC40B-EV02 Global
BES01Z2 DC 3-wire
BES R05KB-POC40B-S49A
DC 3-/4-wire
BES01Z1 Tubular
BES R05KB-NSC40B-S49A housings
BES01YW Block
housings
BES R05KB-NOC40B-EV02
2.5 V 2.5 V 2.5 V 2.5 V
75 V DC AC/DC 2-wire
250 V AC ([) 250 V AC ([) 250 V AC ([)
200 mA 200 mA 200 mA 200 mA AC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C Special
properties
400 Hz 400 Hz 400 Hz 400 Hz
Yellow LED Yellow LED Yellow LED Yellow LED Analog
IP 67 IP 67 IP 67 IP 67 distance
measurement
PA 12 PA 12 PA 12 PA 12 Accessories
PA 12 PA 12 PA 12 PA 12
2 m PUR cable, 22 AWG M8 connector, 3-pin 0.3 m PUR cable with M12 connector, 4-pin 2 m PVC cable, 22 AWG
BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
Sensing surface Sensing surface Sensing surface Sensing surface

max. 49
www.balluff.com 573

PNP, NO Ordering code BES01FC BES01FF
Part number BES 516-346-H2-Y BES 516-346-H2-Y-S49
PNP, NC Ordering code BES01EU
Part number BES 516-341-H2-Y
Part number
NPN, NO Ordering code BES01ZK
NPN, NC Ordering code BES01ET
Approvals CE CE
Material Housing Cast aluminum Cast aluminum
Connection Screw terminals up to 13 AWG M8 connector, 3-pin



3-/4-Wire Block housings, 424822 mm, 7460.528 mm
424822 mm 7460.528 mm
Flush Flush
5 mm 7 mm
0...4.1 mm 0...5.7 mm
1X 1X Inductive
BES01FE sensors
BES 516-346-H2-Y-S4 Global

BES01EW DC 3-wire
BES 516-341-H2-Y-S4
DC 3-/4-wire
BES017M Tubular
BES 516-161-H3-L housings
Block
housings
DC 2-wire
10...30 V DC 10...30 V DC AC/DC 2-wire

3.5 V 1.5 V AC 2-wire
75 V DC 75 V DC
130 mA 400 mA Special
properties
Yes/Yes/Yes Yes/No/No
25...+70C 25...+70C Analog
500 Hz 300 Hz distance
measurement
IP 67 IP 67 Accessories
CE CE
Cast aluminum Cast aluminum
PA 12 PA 12
M12 connector, 4-pin Screw terminals up to 13 AWG
BCC M415-0000-1A-003-EX44T2-020
www.balluff.com 575
Block housing, 4040 mm Unicompact
Unicompact Block Sensors

Balluff's 40 x 40 compact block sensor is a exible sensor for versatile
applications found in industrial automation processes.
The sensing surface and connection can be rotated to accomidate
application position.
Note permissible installation variants.

Compact sensor designs with large switching distances are required
in material handling technology.

3-/4-Wire Block housing, 4040 mm Unicompact
Housing size 4040 mm Unicompact

Installation type (observe instructions in the Basic Information chapter) Flush
Rated switching distance sn 20 mm
Sensing distance 1X Inductive
sensors
PNP, NO Ordering code BES021W
Part number BES Q40KFU-PSC20B-S04G Global
PNP, complementary Ordering code BES0217 DC 3-wire
Part number BES Q40KFU-PAC20B-S04G
DC 3-/4-wire
Supply voltage UB 10...30 V DC Tubular
Voltage drop Ud at Ie max. 2.5 V housings
Rated insulation voltage Ui (protection class) 250 V AC ([) Block
housings
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes DC 2-wire
Switching frequency f max. 50 Hz AC/DC 2-wire
Output function indicator Yellow LED AC 2-wire
Approvals CE, cULus Special
properties
Material Housing PBT
Sensing surface PBT Analog
Possible installation variations Fig. 1...8 distance
measurement
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 Accessories


Row mounting Permissible installation options

Flush 80 mm
120 mm non-ush
Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 Fig. 8
www.balluff.com 577
Block housing, 4040 mm Unicompact
Housing size 4040 mm Unicompact 4040 mm Unicompact

Assured switching distance sa 0...16 mm 0...16.2 mm
PNP, NO Ordering code BES0306
Part number BES Q40KFU-PSC20B-S04G-012
PNP, complementary Ordering code BES03PN
Part number BES Q40KHU-PAC20B-S04G
Part number
Rated insulation voltage Ui (protection class) 250 V AC ([) 250 V AC ([)
Material Housing PBT/Cast zinc PA
Sensing surface PBT PA
Possible installation variations Fig. 1...8 Fig. 1...8
See technical section (page 963-966) 40 LED 40 LED


40
30 40
46
54
62
65
66
25
20
5.5 M12x1

30
330
34
20
M12x1
Housing optimized for material handling technology

Highly visible corner LEDs
Sensor head can be mounted in ve positions
Connector outlet set to position within a 270 range

3-/4-Wire Block housing, 4040 mm Unicompact
4040 mm Unicompact 4040 mm Unicompact 4040 mm Unicompact 4040 mm Unicompact

25 mm 25 mm 30 mm 40 mm
0...20 mm 0...20 mm 0...24 mm 0...32.4 mm
sensors
BES021Z BES0308
BES Q40KFU-PSC30F-S04G BES Q40KFU-PSC40F-S04G-012 Global
BES0210 BES021E DC 3-wire
BES Q40KEU-PAH25F-S04G BES Q40KFU-PAC30F-S04G
DC 3-/4-wire
BES022J Tubular
BES Q40KFU-NAC25F-S04G housings
housings
2.5 V 2.5 V 2.5 V 2.5 V
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) DC 2-wire
200 mA 200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C AC 2-wire
50 Hz 50 Hz 50 Hz 60 Hz
properties
IP 67 IP 67 IP 67 IP 67
CE, cULus CE CE, cULus CE, cULus Analog
PBT PBT/Cast zinc PBT PA distance
measurement
PBT PBT PBT PA
Fig. 3...8 Fig. 3...8 Fig. 3...8 Fig. 3...8 Accessories
LED 40 LED
40
46
54
66
5.5 M12x1

30

Flush 80 mm
120 mm non-ush
www.balluff.com 579
Block housing, 4040 mm Unisensor
The Unisensor multiple uses

The Unisensor is made up of three modular components:
sensor head including sensor head base), sensor body and
sensor base.
Easily removable pin contacts join sensor head and sensor body,
e.g. easy interchange of the modules without wiring.
Sensor base with wiring terminals, self-lifting pressure plates and
ample wiring room.
Sensor head rotatable in ve different positions for
multipule application installations (see installation drawings).
PBT plastic housing.

Mounting dimensions and values are based on
DIN EN 60947-5-2
LED for supply voltage and output function indicator
Sensor body
Sensor head
Sensor head base

Sensor base

3-/4-Wire Block housing, 4040 mm Unisensor
Housing size 4040120 mm Unisensor 4040120 mm Unisensor

Sensing distance 1X 1X Inductive
sensors
PNP, complementary Ordering code BES0201 BES023F
Part number BES 517-132-M3-H BES 517-132-U3-H Global
Supply voltage UB 10...55 V DC 10...55 V DC DC 3-wire
DC 3-/4-wire
Rated insulation voltage Ui (protection class) 250 V AC ([) 250 V AC Tubular
Rated operating current Ie 200 mA 200 mA housings
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes Yes/Yes/Yes Block
housings
Switching frequency f max. 100 Hz 100 Hz DC 2-wire
Degree of protection as per IEC 60529 IP 67 IP 67 AC/DC 2-wire
Approvals CE CE AC 2-wire
Sensing surface PBT PBT Special
properties
Connection Screw terminal, M20x1.5 Screw terminal, 1/2" NPT Analog
distance
measurement
for installation instructions. Accessories

Screw terminal Screw terminal

M20x1.5 1/2" NPT
Row mounting Installation variations
Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5
www.balluff.com 581

PNP, complementary Ordering code BES0202 BES023J
Part number BES 517-132-M3-H-S4 BES 517-132-U3-H-S5
NPN, complementary Ordering code BES020H
Part number BES 517-134-M3-H-S4
Rated insulation voltage Ui (protection class) 250 V AC ([) 250 V AC
Approvals CE, cULus CE
Connection M12 connector, 4-pin 7/8" 16UN plug connector, 5-pin
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC A314-0000-10-003-EX44W6-020

40
46

7.3

120
5.3
available on request. LED
60
6.5
7.3
M12 x 1
7/8-16UN
30

4040120 mm Unisensor 4040120 mm Unisensor 4040120 mm Unisensor

Flush Flush Flush
20 mm 20 mm 20 mm
0...16 mm 0...16 mm 0...16 mm
1X 1X 1X Inductive
sensors
BES023L BES020A
BES 517-132-U6-H BES 517-132-M6-H-S4 Global
BES020N BES020P DC 3-wire
BES 517-134-M6-H-S4 BES 517-134-M6-H-S5
DC 3-/4-wire
10...55 V DC 10...55 V DC 10...55 V DC Tubular
2.5 V 2.5 V 2.5 V housings
250 V AC ([) 250 V AC ([) 250 V AC ([) Block
housings
200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes DC 2-wire
25...+70C 25...+70C 25...+70C
50 Hz 50 Hz 50 Hz AC/DC 2-wire
Yellow LED Yellow LED Yellow LED AC 2-wire
IP 67 IP 67 IP 67
CE CE CE Special
properties
PBT/aluminum PBT PBT
PBT PBT PBT Analog
Fig. 1...5 Fig. 1...5 Fig. 1...5 distance
measurement
Screw terminal, 1/2" NPT M12 connector, 4-pin 7/8" 16UN plug connector, 5-pin
BCC M415-0000-1A-003-EX44T2-020 BCC A314-0000-10-003-EX44W6-020 Accessories
40
46
7.3
120
5.3
LED
60
6.5
7.3
Screw terminal M12 x 1

1/2" NPT
7/8-16UN
30
www.balluff.com 583
Housing size 4040120 mm Unisensor

Sensing distance 1X
Part number
Part number BES 517-132-M4-H
NPN, complementary Ordering code BES020J
Supply voltage UBS 10...55 V DC
Rated insulation voltage Ui (protection class) 250 V AC ([)
Approvals CE
Sensing surface PBT
Possible installation variations Fig. 3...5
Connection Screw terminal, M20x1.5


Screw terminal
M20x1.5

4040120 mm Unisensor
Non-ush
20 mm
0...16 mm
1X Inductive
sensors
Global
BES0205 DC 3-wire
BES 517-132-M4-H-S4
DC 3-/4-wire
Tubular
housings
10...55 V DC Block
housings
2.5 V
250 V AC ([) DC 2-wire
200 mA
Yes/Yes/Yes AC/DC 2-wire
25...+70C AC 2-wire
100 Hz
Yellow LED Special
properties
IP 67
CE Analog
PBT distance
measurement
PBT
Fig. 3...5 Accessories
BCC M415-0000-1A-003-EX44T2-020
M12 x 1
www.balluff.com 585

PNP, NO Ordering code BES0206
Part number
NPN, complementary Ordering code BES020K BES023N
Part number BES 517-134-M5-H BES 517-134-U5-H
Approvals CE CE
Material Housing PBT PBT/aluminum
Connection Screw terminal, M20x1.5 Screw terminal, 1/2" NPT


Screw terminal Screw terminal

M20x1.5 1/2" NPT

4040120 mm Unisensor 4040120 mm Unisensor 4040120 mm Unisensor 4040120 mm Unisensor

30 mm 40 mm 40 mm 40 mm
0...24 mm 0...32 mm 0...32 mm 0...32 mm
sensors
Global
BES0207 BES020C BES023M BES020E DC 3-wire
BES 517-132-M5-H-S4 BES 517-132-M7-H BES 517-132-U7-H BES 517-132-M7-H-S4
DC 3-/4-wire
Tubular
housings
housings
2.5 V 2.5 V 2.5 V 2.5 V
200 mA 200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC/DC 2-wire
25...+70C 25...+70C 25...+70C 25...+70C AC 2-wire
60 Hz 50 Hz 50 Hz 50 Hz
properties
IP 67 IP 67 IP 67 IP 67
CE CE CE CE Analog
PBT PBT PBT/aluminum PBT distance
measurement
PBT PBT PBT PBT
Fig. 3...5 Fig. 3...5 Fig. 3...5 Fig. 3...5 Accessories
M12 connector, 4-pin Screw terminal, M20x1.5 Screw terminal, 1/2" NPT M12 connector, 4-pin
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020
M12 x 1 Screw terminal Screw terminal M12 x 1

M20x1.5 1/2" NPT
www.balluff.com 587
Block housing, 8080 mm Maxisensor
Flush mount
Housing size 808040 mm Maxisensor

Fig. 1
Sensing distance 1X
Non-ush mount Part number
PNP, complemen- Ordering code BES023P
tary Part number BES 517-139-M4-H
NPN, complemen- Ordering code
tary Part number
Fig. 2 Voltage drop Ud at Ie max. 2.5 V
Approvals CE
Fig. 3
Sensing surface PBT
Possible installation variations Fig. 5...8
Connection Screw terminal, M20x1.5
See technical section (page 963) for installation

notes on 2X, 3X, and 4X long range sensors.
Fig. 4
Minimum distances with steel Additional cable lengths and PUR cable
jacket material available on request.
h A B C
40 mm 70 mm 80 mm 90 mm
70 mm 80 mm 90 mm 100 mm
Minimum distances with aluminum

h A B C Screw terminal
40 mm 0 mm 10 mm 10 mm
70 mm 10 mm 20 mm 20 mm
The change of the real switching distance sr

is 10 % with these installation dimensions.
Mounting in steel Mounting in non- Mounting in steel/non- Mounting on steel/non-
ferrous metals ferrous metals ferrous metals
Fig. 5 Fig. 6 Fig. 7 Fig. 8

3-/4-Wire Block housing, 8080 mm Maxisensor
808040 mm Maxisensor 808440 mm Maxisensor 808040 mm Maxisensor

Flush Flush Flush
40 mm 40 mm 40 mm
0...32 mm 0...32 mm 0...32 mm
1X 1X 1X Inductive
sensors
BES0227
BES Q80KA-PSH40B-S04Q Global
BES0225 DC 3-wire
BES Q80KA-PAH40B-S04Q
DC 3-/4-wire
BES020R BES020T Tubular
BES 517-140-M4-H BES 517-140-M4-H-S4 housings
10...55 V DC 10...55 V DC 10...55 V DC Block
housings
2.5 V 2.5 V 2.5 V
250 V AC ([) 250 V AC ([) 250 V AC ([) DC 2-wire
200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC/DC 2-wire
25...+70C 25...70 C 25...+70C AC 2-wire
50 Hz 50 Hz 50 Hz
properties
IP 67 IP 67 IP 67
CE CE CE Analog
PBT PBT PBT distance
measurement
PBT PBT PBT
Fig. 5...8 Fig. 1 Fig. 5...8 Accessories
Screw terminal, M20x1.5 M12 connector, 4-pin M12 connector, 4-pin
Screw terminal
www.balluff.com 589
Block housing, 8080 mm Maxisensor
Housing size 809240 mm Maxisensor 808040 mm Maxisensor

Installation type (observe instructions in the Basic Information chapter) Flush Non-ush
Assured switching distance sa 0...40.5 mm 0...40 mm
Part number
PNP, complementary Ordering code BES030C BES023R
Part number BES Q80KA-PAC50B-S04Q-U BES 517-139-M5-H
NPN, complementary Ordering code BES020U
Ambient temperature Ta 25...70 C 25...70 C
Material Housing PPE PBT
Sensing surface PPE PBT
Possible installation variations Fig. 7, 8 (see page 588)
Connection M12 connector, 4-pin Screw terminal, M20x1.5
See technical section (page 963) for installation

notes on 2X, 3X, and 4X long range sensors.
Additional cable lengths and PUR cable

Screw terminal

3-/4-Wire Block housing, 8080 mm Maxisensor

50 mm 50 mm 50 mm
0...40 mm 0...40 mm 0...40 mm
1X 1X 1X Inductive
sensors
BES023W BES0228
BES 517-139-U5-H-S4 BES Q80KA-PSH50F-S04Q Global
BES0226 DC 3-wire
BES Q80KA-PAH50F-S04Q
DC 3-/4-wire
BES020W Tubular
BES 517-140-M5-H-S4 housings
10...55 V DC 10...55 V DC 10...55 V DC Block
housings
2.5 V 2.5 V 2.5 V
200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC/DC 2-wire
25...70 C 25...70 C 25...+70C AC 2-wire
100 Hz 100 Hz 50 Hz
properties
IP 67 IP 67 IP 67
CE CE, cULus CE Analog
PBT PBT PBT distance
measurement
PBT PBT PBT
Fig. 7, 8 (see page 588) Fig. 7, 8 (see page 588) Fig. 2...4 (see page 588) Accessories
www.balluff.com 591
Inductive
Sensors
DC 2-wire inductive sensors
This extensive line of DC 2-wire sensors are offered in tubular and
block housings to meet a wide variety of applications.

DC 2-wire Inductive Sensors
Contents
Tubular housing
M81 595
M121 597
M181 600
M301.5 603
Block housing
20328 mm (R01) 606
262626 mm (Z03) 607
809240 mm (maxi-sensor) 610
www.balluff.com 593
DC-2-wire Tubular Sensors
Popular in many "New Domestic" automotive plants and automotive tier

suppliers, Balluff's 2-wire DC tubular sensors are offered in Polarized
and Non-Polarized congurations, ush and non-ush mounting, in
standard and extended sensing ranges. Some models are also availiable
with PTFE-coated housings to help repel welding spatter. Housing size
Sensing distance
Polarized, NO Ordering code
Part number
Polarized, NC Ordering code
Part number
Non-polarized, NO Ordering code
Part number
Non-polarized, NC Ordering code
Part number
Supply voltage UB
Minimum operating current Im
Residual current Ir max.
Permissible load capacitance max.
Approvals
Material Housing
Sensing surface
Connection

For standard DC 2-wire connection information see page 958.

Recommendation for connection wiring for polarized

sensors on 3-wire controllers
PNP, NO NPN, NO
Controller input Controller input Controller input
Controller input
PNP, NC NPN, NC
Controller input Controller input

Controller input
Controller input

Tubular housings, M81
M81 M81 M81 M81

2 mm 2 mm 1.5 mm 2 mm
0 to 1.6 mm 0 to 1.4 mm 0 to 1.2 mm 0 to 1.6 mm
BES0022 BES00C0 BES001Z sensors
BES M08ME1-GSC20B-S04G BES M08ME1-GSC20B-S04G-101 BES M08MG-GSC20B-BP00,3-GS04 Global
BES024N BES03H8 DC 3-wire
BES M08ME1-GOC20B-S04G BES M08MG-GOC20B-BP00,3-GS04
DC 3-/4-wire
BES001Y
BES M08ME1-USC20B-S04G DC 2-wire
BES024P BES031N Tubular
housings
BES M08ME1-UOC20B-S04G BES 516-527-S4-H
Block
10...36 V DC 10...30 V DC 10...55 V DC 10...36 V DC housings
5V 5V 5V 5V
75 V DC 75 V DC 75 V DC 75 V DC AC/DC
2-wire
100 mA 100 mA 130 mA 100 mA
5 mA 5 mA 5 mA 5 mA AC 2-wire
600 A 600 A 500 A 600 A
Special
1 F 1 F 1 F 1 F properties
25...+70 C 25...+70 C 25...+70 C 25...+70 C Analog
distance
1.5 kHz 1.5 kHz 3 kHz 1.5 kHz measurement
Accessories
IP 67 IP 67 IP 67 IP 67
Brass-coated Brass-coated Stainless steel Brass-coated
PBT With ceramic PBT PBT
coating
M12 connector, M12 connector, M12 connector, 0.3 m PUR cable
4-pin 4-pin 4-pin with M12 connector, 4-pin
M8x1 M8x1
13 13
29.5
29.5
50
50
10.7 10.7
LED LED
M12x1 M12x1
www.balluff.com 595

Installation type (observe instructions in Basic Information chapter) Flush Flush
Assured switching distance sa 0 to 1.4 mm 0 to 1.6 mm
Polarized, NO Ordering code BES0324 BES001L
Part number BES M08MG-GSC20B-BP00,3-GS04-101 BES M08MG-GSC20B-BV02
Polarized, NC Ordering code BES024R
Part number BES M08MG-GOC20B-BV02
Non-polarized, NO Ordering code BES001T
Part number BES M08MG-USC20B-BV02
Non-polarized, NC Ordering code BES024T
Part number BES M08MG-UOC20B-BV02
Minimum operating current Im 5 mA 5 mA
Residual current Ir max. 600 A 600 A
Permissible load capacitance max. 1 F 1 F
Sensing surface With ceramic PBT
coating
Connection 0.3 m PUR cable 2 m PVC cable,



Tubular housings, M81, M121
M121 M121 M121

Flush Flush Flush
3 mm 3 mm 3 mm
0 to 2.4 mm 0 to 2.2 mm 0 to 2.4 mm
2X 2X 2X Inductive
BES003Z BES00C1 sensors
BES M12MF-GSC30B-S04G BES M12MF-GSC30B-S04G-101 Global
BES024J DC 3-wire
BES M12MF-GOC30B-S04G
DC 3-/4-wire
BES0041
BES M12MF-USC30B-S04G DC 2-wire
BES024K Tubular
housings
BES M12MF-UOC30B-S04G
Block
10...36 V DC 10...30 V DC 10...36 V DC housings
4V 5V 5V
75 V DC 75 V DC 75 V DC AC/DC
2-wire
100 mA 100 mA 100 mA
600 A 600 A 600 A
Special
1 F 1 F 1 F properties
25...+70 C 25...+70 C 25...+70 C Analog
distance
Accessories
IP 67 IP 67 IP 67
Brass-coated Brass-coated Brass-coated
PA 12 With ceramic PA 12
coating
M12x1 M12x1 M12x1
17 17 17
35.5
35.5
35.5
50
50
50
10.7 10.7 10.7
LED LED LED
M12x1 M12x1 M12x1
www.balluff.com 597

Polarized, NO Ordering code BES0042 BES0326
Part number BES M12MG-GSC30B-BP00,3-GS04 BES M12MG-GSC30B-BP00,3-GS04-101
Polarized, NC Ordering code BES03HK
Part number BES M12MG-GOC30B-BP00,3-GS04
Non-polarized, NO Ordering code
Part number
Non-polarized, NC Ordering code
Part number
Sensing surface PA 12 With ceramic
coating
Connection 0.3 m PUR cable 0.3 m PUR cable
M12x1 M12x1
M12x1 M12x1

40
40
43
43
46
46
LED LED

M121 M121 M121

Flush Flush Flush
3 mm 3 mm 3 mm
0...2.4 mm 0...2.4 mm 0...2.4 mm
2X 2X 2X Inductive
BES0045 sensors
BES M12MG-GSC30B-BV02 Global
BES024L DC 3-wire
BES M12MG-GOC30B-BV02
DC 3-/4-wire
BES004U
BES M12MG-USC30B-BV03 DC 2-wire
BES024M Tubular
housings
BES M12MG-UOC30B-BV02
Block
4V 5V 5V
2-wire
100 mA 100 mA 100 mA
600 A 600 A 600 A
Special
25...+70 C 25...+70 C 25...+70 C Analog
distance
Accessories
IP 67 IP 67 IP 67
CE, cULus CE, cULus CE
PA 12 PA 12 PA 12
2 m PVC cable, 2 m PVC cable, 2 m PVC cable,

22 AWG 22 AWG 22 AWG
www.balluff.com 599

Polarized, NO Ordering code BES0328
Part number BES M18MF-GSC70B-S04G
Polarized, NC Ordering code BES02NL
Part number BES M18MF-GOC70B-S04G
Non-polarized, NO Ordering code BES02NR
Part number BES M18MF-USC70B-S04G
Non-polarized, NC Ordering code BES02NN
Part number BES M18MF-UOC70B-S04G
M18x1 M18x1
24 24
35
35

51
51
LED LED
M12x1 M12x1

M181 M181 M181

Flush Flush Flush
7 mm 7 mm 7 mm
0...5.6 mm 0...5.5 mm 0...5.6 mm
2X 2X 2X Inductive
BES006C BES0329 BES00FA sensors
BES M18MG-GSC70B-BP00,3-GS04 BES M18MG-GSC70B-BP00,3-GS04-101 BES M18MG-GSC70B-BV02 Global
BES039L BES02NT DC 3-wire
BES M18MG-GOC70B-BP00,3-GS04 BES M18MG-GOC70B-BV02
DC 3-/4-wire
DC 2-wire
Tubular
housings
Block
4V 4V 4V
2-wire
100 mA 100 mA 100 mA
600 A 600 A 600 A
Special
25...+70 C 25...+70 C 25...+70 C Analog
distance
600 Hz 600 Hz 600 Hz measurement
Accessories
IP 67 IP 67 IP 67
PA 12 With ceramic PA 12
coating
0.3 m PUR cable 0.3 m PUR cable 2 m PVC cable,
M18x1 M18x1
24 24
M12x1 M12x1
40
40
46
46
46
46
LED LED
www.balluff.com 601

Installation type (observe instructions in Basic Information chapter) Flush Non-ush
Polarized, NO Ordering code
Part number
Part number
Non-polarized, NO Ordering code BES0073
Part number BES M18MG-USC70B-BV02
Non-polarized, NC Ordering code BES02NU BES0322
Part number BES M18MG-UOC70B-BV02 BES 516-547-S4-H
Rated insulation voltage Ui (protection class) 75 V DC 250 V AC ([)
Degree of protection as per IEC 60529 IP 67 IP 68 per BWN Pr. 20



M301.5 M301.5 M301.5 M301.5

10 mm 15 mm 15 mm 15 mm
0...8 mm 0...12 mm 0...12 mm 0...12 mm
BES027L BES008W sensors
BES M30MF-GSC15B-S04G BES M30MF-GSC15B-S04K Global
BES027C BES027J DC 3-wire
BES M30MF-GOC15B-S04G BES M30MF-GOC15B-S04K
DC 3-/4-wire
BES027E
BES M30MF-USC15B-S04G DC 2-wire
BES031T BES027F Tubular
housings
BES 516-541-S4-H BES M30MF-UOC15B-S04G
Block
5V 4V 5V 4V
250 V AC ([) 75 V DC 75 V DC 75 V DC AC/DC
2-wire
200 mA 100 mA 100 mA 100 mA
500 A 600 A 600 A 600 A
Special
25...+70 C 25...+70 C 25...+70 C 25...+70 C Analog
distance
150 Hz 400 Hz 400 Hz 400 Hz measurement
Accessories
IP 68 per BWN Pr. 20 IP 67 IP 67 IP 67
Brass-coated Brass-coated Brass-coated Brass-coated
PA 12 PA 12 PA 12 PA 12
M30x1.5 M30x1.5
36 36
35
35
51
51
LED LED
M12x1 M12x1
www.balluff.com 603
Housing size M301.5 M301.5

Polarized, NO Ordering code BES032A
Part number BES M30MF-GSC15B-BP00,3-GS04-101
Part number
Non-polarized, NO Ordering code BES0094
Part number BES M30MF-USC15B-S04K
Non-polarized, NC Ordering code BES027H
Part number BES M30MF-UOC15B-S04K
Sensing surface PA 12 With ceramic
coating
Connection M12 connector, 4-pin 0.3 m PUR cable
M30x1.5
for installation instructions. 36

M12x1
42.5
40

LED
46

M301.5 M301.5 M301.5 M301.5

Flush Flush Flush Non-ush
15 mm 15 mm 15 mm 15 mm
0...12 mm 0...12 mm 0...12 mm 0...12 mm
BES008Y BES008R sensors
BES M30MF-GSC15B-BP00,3-GS04 BES M30MF-GSC15B-BV02 Global
BES03H4 BES0279 DC 3-wire
BES M30MF-GOC15B-BP00,3-GS04 BES M30MF-GOC15B-BV02
DC 3-/4-wire
BES0091
BES M30MF-USC15B-BV02 DC 2-wire
BES027A BES0323 Tubular
housings
BES M30MF-UOC15B-BV02 BES 516-549-S4-H
Block
4V 4V 5V 5V
75 V DC 75 V DC 75 V DC 250 V AC ([) AC/DC
2-wire
100 mA 100 mA 100 mA 200 mA
600 A 600 A 600 A 500 A
Special
25...+70 C 25...+70 C 25...+70 C 25...+70 C Analog
distance
400 Hz 400 Hz 400 Hz 100 Hz measurement
Accessories
IP 67 IP 67 IP 67 IP 68 per BWN Pr. 20
PA 12 PA 12 PA 12 PA 12
0.3 m PUR cable 2 m PVC cable, 2 m PVC cable, M12 connector, 4-pin
M30x1.5 M30x1.5 M30x1.5

36
36 36
M12x1
42.5
42.5
42.5
40
40
40
LED LED LED

46
M12x1
www.balluff.com 605

Non-polarized, NO Ordering code BES032C BES03TM
Part number BES R01ZC-USC50B-BP00.2-GS04 BES R01ZC-USC50B-BP00.2-GS04-101
Material Housing Cast zinc Cast zinc
Sensing surface PA 12 With ceramic coating
Connection 0.2 m PUR cable with 0.2 m PUR cable with



Housing size 262626 mm Z03 262626 mm Z03

Polarized, NO Ordering code BES030H BES030E sensors
Part number BES Z03K-GSS10B-S04U-006 BES Z03K-GSS10B-EP00,15-GS04-006 Global
Supply voltage UB 10...36 V DC 10...36 V DC DC 3-wire
DC 3-/4-wire
Rated operating current Ie 100 mA 100 mA DC 2-wire
Minimum operating current Im 2 mA 2 mA Tubular
housings
Block
Permissible load capacitance max. 0.1 F 0.1 F housings
Ambient temperature Ta 25...+70 C 25...+70 C AC/DC
2-wire
Output function indicator Yellow LED Yellow LED AC 2-wire
Special
Approvals CE CE properties
Material Housing PA PA
Sensing surface PA PA Analog
distance
Connection M12 connector, 4-pin 0.15 m PUR cable with measurement
Accessories


Small, compact block sensor

Sensing surface
Sensing surface
with increased switching distance

for quick installation
The connector mount can be rotated
and the sensing face can be oriented in three
directions.
Simple replacement with no loss of position

thanks to the xed mounting plate:
Cost savings
No special tools necessary Mounting plate
Easy to install included with sensor.
www.balluff.com 607

Polarized, NO Ordering code BES0303 BES0302
Part number BES Q40KFU-GSH15B-S04G BES Q40KFU-GSH15B-EP00,8-GS04
Polarized, NC Ordering code BES0301
Part number BES Q40KFU-GOH15B-EP00,8-GS04
Approvals CE CE
Material Housing PPE, PPS PPE, PPS
Sensing surface PPE PPE
Connection M12 connector, 4-pin 0.8 m PUR cable with M12 connector, 4-pin


40 x 66 x 40
The exible sensor for mechanical engineering and equipment
manufacturing. The detection direction can be adjusted in 5 directions.
Long switching distance in compact package.
Permissible installation variations for 40 x 66 x 40 mm block housing

Block housings, 4012140 mm Unisensor
Housing size 4012140 mm Unisensor

Installation type (observe instructions in Basic Information chapter) Non-ush
Polarized, complementary Ordering code BES0309 sensors
Part number BES Q40KU-GPH20F-KM21 Global
Supply voltage UB 10...55 V DC DC 3-wire
DC 3-/4-wire
Rated operating current Ie 400 mA DC 2-wire
Minimum operating current Im 4 mA Tubular
housings
Residual current Ir max. 1 mA
Block
Permissible load capacitance max. 1 F housings
Ambient temperature Ta 25...+80 C AC/DC
2-wire
Output function indicator Red LED AC 2-wire
Special
Approvals CE properties
Material Housing PPE

Sensing surface PPE Analog
distance
Connection Screw terminal M20x1.5 measurement
Accessories
44.7
45.5

121
LED
60.5
5.3
10.4
Mounting options
30
40
40
16
M20x1.5
Row mounting
www.balluff.com 609
Housing size 809240 mm Maxisensor

Installation type (observe instructions in Basic Information chapter) Flush
Sensing distance 1X
Polarized, NO Ordering code BES030A
Part number BES Q80KA-GSH50B-S04Q
Minimum operating current Im 4 mA
Residual current Ir max. 600 A
Permissible load capacitance max. 1 F
Approvals CE
Material Housing PPE
Sensing surface PPE


Maxisensor
Long switching distance with low installation height in the detection
direction. Ideal for equipment manufacturing and conveyor technology.
Permissible Maxisensor installation options
Installation in steel or Installation on steel or

non-ferrous metals non-ferrous metals
The switching distance is reduced by

max. 5.5 mm when not installed ush.

Inductive
sensors
Global
DC 3-wire
DC 3-/4-wire
DC 2-wire
Tubular
housings
Block
housings
AC/DC
2-wire
AC 2-wire
Special
properties
Analog
distance
measurement
Accessories
www.balluff.com 611
Inductive
Sensors
AC/DC 2-wire inductive sensors
Balluff offers something for practically any application in automa-
tion with this comprehensive product line of sensors from M12 to
8080 mm. These high-quality sensors are designed and manufac-
tured according to worldwide standards and the latest technology.
We inspect absolutely every one of our products, providing you the
peace of mind that you are receiving the highest quality sensors.

AC/DC 2-wire Inductive Sensors
Contents
Tubular housings
M121 615
M181 617
M301.5 620
Block housings
264012 mm (R05) 623
www.balluff.com 613
Housing size
Sensing distance
NO Ordering code
Part number
NC Ordering code
Part number
Rated operating voltage Ue
Supply voltage UB
Current reduction as a function of Minimum operating current Im
ambient temperature range Residual current Ir max.
Short-term current carrying capacity Ic /time T
Short-circuit protected
130 mA
M12 Switching frequency f max.
Utilization category
100 mA Approvals
Material Housing
Sensing surface
25 C +25 C +70 C Connection

250 mA for installation instructions.
M18

150 mA
25 C +25 C +70 C
250 mA
M30
180 mA
25 C +25 C +70 C

M121 M121 M121

Flush Flush Non-ush
2 mm 2 mm 4 mm
0...1.6 mm 0...1.6 mm 0...3.2 mm
1X 1X 1X Inductive
BES02E3 BES027Y BES02E4 sensors
BES 515-207-S21-E BES 516-207-S5-E BES 515-209-S21-E Global
BES0284 DC 3-wire
BES 516-208-S5-E
DC 3-/4-wire
110 V AC 110 V AC 110 V AC
20...250 V AC/DC 20...250 V AC/DC 20...250 V AC/DC DC 2-wire
11 V 11 V 11 V
AC/DC
250 V AC 250 V AC 250 V AC 2-wire
130 mA 130 mA 130 mA Tubular
5 mA 5 mA 5 mA housing
1.7 mA 1.7 mA 1.7 mA Block
housings
0.7 A/20 ms 0.7 A/20 ms 0.7 A/20 ms
Yes Yes Yes AC 2-wire
25...+70 C 25...+70 C 25...+70 C
Special
1 kHz 1 kHz 600 Hz properties
AC 140/DC 13 AC 140/DC 13 AC 140/DC 13
Yellow LED Yellow LED Yellow LED Analog
distance
Accessories
PA 12 PA 12 PA 12
1/2" 20UNF-2A plug 7/8" 16UN plug 1/2-20UNF-2A plug
connector, 3-pin connector, 3-pin connector, 3-pin
C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020 C21 AE3-00-TY-060F
M12x1
50
17
85
7/8" - 16UN
www.balluff.com 615

NO Ordering code BES028E BES0289
Part number BES 516-209-S5-E BES 516-209-G-S21-E
NC Ordering code
Part number
Rated operating voltage Ue 110 V AC 110 V AC
Supply voltage UB 20...250 V AC/DC 20...250 V AC/DC
Voltage drop Ud at Ie max. 11 V 11 V
Rated insulation voltage Ui 250 V AC 250 V AC
Residual current Ir max. 1.7 mA 1.7 mA
Short-term current carrying capacity Ic /time T 0.7 A/20 ms 0.7 A/20 ms
Short-circuit protected Yes Yes
Utilization category AC 140/DC 13 AC 140/DC 13
Material Housing Stainless steel Stainless steel
Connection 7/8" 16UN plug 1/2-20UNF-2A plug
connector, 3-pin connector, 3-pin
Suggested mating cable BCC A313-0000-10-071-VX43W6-020 C21 AE3-00-TY-060F

5
5

40.5
50
17
70
85
1/2 - 20 UNF - 2A
7/8"-16UN

M181 M181 M181 M181

5 mm 5 mm 5 mm 8 mm
0...4 mm 0...4 mm 0...4 mm 0...6.4 mm
BES028P BES02E5 BES028T BES02ZE sensors
BES 516-211-E5-E-S21 BES 515-211-E5-E-S21 BES 516-211-E5-E-S5 BES M18MN-USU80B-S21G Global
BES028Z BES0291 DC 3-wire
BES 516-212-E5-E-S21 BES 516-212-E5-E-S5
DC 3-/4-wire
110 V AC 110 V AC 110 V AC 110 V AC
20...250 V AC/DC 20...250 V AC/DC 20...250 V AC/DC 20...300 V AC/DC DC 2-wire
11 V 11 V 11 V 8V
AC/DC
250 V AC 250 V AC 250 V AC 250 V AC 2-wire
250 mA 250 mA 250 mA 200 mA Tubular
5 mA 5 mA 5 mA 4 mA housings
1.7 mA 1.7 mA 1.7 mA 0.8 mA Block
housings
1.5 A/20 ms 1.5 A/20 ms 1.5 A/20 ms 1.5 A/20 ms
Yes Yes Yes Yes AC 2-wire
25...+70 C 25...+70 C 25...+70 C 25...+70 C
Special
400 Hz 400 Hz 400 Hz 30 Hz properties
AC 140/DC 13 AC 140/DC 13 AC 140/DC 13 AC 140/DC 13
Yellow LED Yellow LED Yellow LED Yellow LED Analog
distance
IP 67 IP 67 IP 67 IP 67 measurement
Accessories
Brass-coated Stainless steel Brass-coated Brass-coated
PA 12 PA 12 PA 12 PBT
1/2-20UNF-2A plug 1/2-20UNF-2A plug 7/8" 16UN plug 1/2-20UNF-2A plug
connector, 3-pin connector, 3-pin connector, 3-pin connector, 3-pin
C21 AE3-00-TY-060F C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020 C21 AE3-00-TY-060F
M18x1
50.5
24
80
19
7/8" - 16UN
www.balluff.com 617

NO Ordering code BES0296 BES02E7 BES0298
Part number BES 516-213-E5-E-S21 BES 515-213-E5-E-S21 BES 516-213-E5-E-S5
NC Ordering code BES029H
Part number BES 516-214-E5-E-S21
Rated operating voltage Ue 110 V AC 110 V AC 110 V AC
Supply voltage UB 20...250 V AC/DC 20...250 V AC/DC 20...250 V AC/DC
Voltage drop Ud at Ie max. 11 V 11 V 11 V
Rated insulation voltage Ui 250 V AC 250 V AC 250 V AC
Minimum operating current Im 5 mA 5 mA 5 mA
Residual current Ir max. 1.7 mA 1.7 mA 1.7 mA
Short-term current carrying capacity Ic /time T 1.5 A/20 ms 1.5 A/20 ms 1.5 A/20 ms
Short-circuit protected Yes Yes Yes
Utilization category AC 140/DC 13 AC 140/DC 13 AC 140/DC 13
Material Housing Brass-coated Stainless steel Brass-coated
Connection 1/2-20UNF-2A plug con- 1/2-20UNF-2A plug con- 7/8" 16UN plug
nector, 3-pin nector, 3-pin connector, 3-pin
Suggested mating cable C21 AE3-00-TY-060F C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020


10
10
10

50.5
50.5
50.5
24
70.5
70.5
80
24 24
1/2"-20UNF-2A 1/2"-20UNF-2A 19
7/8"-16UN

M181
Non-ush
16 mm
0...13 mm
2X Inductive
BES029A sensors
BES 516-213-G-E5-E-S21 Global
DC 3-wire
DC 3-/4-wire
110 V AC
20...250 V AC/DC DC 2-wire
11 V
AC/DC
250 V AC 2-wire
250 mA Tubular
5 mA housings
1.7 mA Block
housings
1.5 A/1 ms
Yes AC 2-wire
25...+70 C
Special
250 Hz properties
AC 140/DC 13
Yellow LED Analog
distance
IP 67 measurement
CE, cULus
Accessories
Brass-coated
PA 12
1/2-20UNF-2A plug
connector, 3-pin
C21 AE3-00-TY-060F
M18x1
10
50.5
70.5
24
1/2"-20UNF-2A
www.balluff.com 619

NO Ordering code BES029T BES02E9 BES029W
Part number BES 516-215-E5-E-S21 BES 515-215-E5-E-S21 BES 516-215-E5-E-S5
NC Ordering code BES02A2 BES02A4
Part number BES 516-216-E5-E-S21 BES 516-216-E5-E-S5
Rated operating voltage Ue 110 V AC 110 V AC 110 V AC
Voltage drop Ud at Ie max. 11 V 11 V 11 V
Rated insulation voltage Ui 250 V AC 250 V AC 250 V AC
Minimum operating current Im 5 mA 5 mA 5 mA
Residual current Ir max. 1.7 mA 1.7 mA 1.7 mA
Short-term current carrying capacity Ic /time T 3 A/20 ms 3 A/20 ms 3 A/20 ms
Short-circuit protected Yes Yes Yes
Utilization category AC 140/DC 13 AC 140/DC 13 AC 140/DC 13
Material Housing Brass-coated Stainless steel Brass-coated
Connection 1/2-20UNF-2A plug 1/2-20UNF-2A plug 7/8" 16UN plug
connector, 3-pin connector, 3-pin connector, 3-pin
Suggested mating cable C21 AE3-00-TY-060F C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020
See technical section (page 963-966) M30x1.5 M30x1.5 M30x1.5


50.5
50.5
50.5

70.5
70.5
80
36 36 36
1/2"-20UNF-2A 19
1/2"-20UNF-2A
7/8"-16UN

M301.5 M301.5
Non-ush Non-ush
15 mm 15 mm
0...12.1 mm 0...12.1 mm
1X 1X Inductive
BES02AA BES02AE sensors
BES 516-217-E5-E-S21 BES 516-217-E5-E-S5 Global
BES02AK BES02AM DC 3-wire
BES 516-218-E5-E-S21 BES 516-218-E5-E-S5
DC 3-/4-wire
110 V AC 110 V AC
20...250 V AC/DC 20...250 V AC/DC DC 2-wire
11 V 11 V
AC/DC
250 V AC 250 V AC 2-wire
250 mA 250 mA Tubular
5 mA 5 mA housings
1.7 mA 1.7 mA Block
housings
3 A/20 ms 3 A/20 ms
Yes Yes AC 2-wire
25...+70 C 25...+70 C
Special
100 Hz 100 Hz properties
AC 140/DC 13 AC 140/DC 13
Yellow LED Yellow LED Analog
distance
IP 67 IP 67 measurement
CE, cULus CE, cULus
Accessories
Brass-coated Brass-coated
PA 12 PA 12
1/2-20UNF-2A plug 7/8" 16UN plug
connector, 3-pin connector, 3-pin
C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020
M30x1.5 M30x1.5
13
13
50.5
50.5
70.5
36
80
36
1/2"- 20UNF- 2A
19
7/8"-16UN
www.balluff.com 621
Sensors in use
Position detection with Balluff inductive sensors: In foundry

work, exact position detection is absolutely essential for pouring
metal with exact precision. Balluff inductive sensors can be inte-
grated into the existing feed system and detect the stationary ladle
position right before pouring.
Assembly procedures require precise position of materials. Balluff

inductive sensors also identify metals over long distances and in
harsh environments.


NO Ordering code BES02CT BES02CY sensors
Part number BES R05KB-USU20B-EV02 BES R05KB-USU40B-EV02 Global
Rated operating voltage Ue 110 V AC 110 V AC DC 3-wire
DC 3-/4-wire
Voltage drop Ud at Ie max. 12 V 12 V
Rated insulation voltage Ui (protection class) 250 V AC ([) 250 V AC ([) DC 2-wire
AC/DC
Minimum operating current Im 5 mA 5 mA 2-wire
Residual current Ir max. 1.7 mA 1.7 mA Tubular
Short-term current carrying capacity Ic /time T 0.7 A/20 ms 0.7 A/20 ms housings
Short-circuit protected Yes Yes Block
housings
Switching frequency f max. 400 Hz 400 Hz AC 2-wire
Special
Output function indicator Yellow LED Yellow LED properties
Approvals CE CE Analog
distance
Material Housing PA 12 PA 12 measurement
Accessories
Connection 2 m PVC cable, 22 AWG 2 m PVC cable, 22 AWG
See technical section (page 963-966) Sensing surface Sensing surface


Row mounting
With plastics or no material present in the space:

Distance A = at least 5 mm
With metal in the space:
Distance A = at least 4 mm
www.balluff.com 623
Housing size
Sensing distance
NO Ordering code
Part number

NC Ordering code
Part number
Supply voltage UB
Approvals
Material Housing
Sensing surface
Possible installation variations
Connection
Current reduction as a function of See technical section (page 963-966)

ambient temperature range for installation instructions.
250 mA Additional cable lengths and PUR cable jacket material

180 mA
25 C +25 C +70 C
Row mounting
Flush 80 mm, Non-ush 120 mm
Mounting options
40
40
40
Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6

407340 mm Unicompact 407340 mm Unicompact

Flush Non-ush
15 mm 25 mm
0...12 mm 0...20.2 mm
1X 1X Inductive
BES022A BES022F sensors
BES Q40KEU-USU15B-S21G BES Q40KEU-USU25F-S21G Global
BES0211 BES0213 DC 3-wire
BES Q40KEU-UOU15B-S21G BES Q40KEU-UOU25F-S21G
DC 3-/4-wire
110 V AC 110 V AC
20...250 V AC/DC 20...250 V AC/DC DC 2-wire
11 V 11 V
AC/DC
250 V AC 250 V AC 2-wire
250 mA 250 mA Tubular
5 mA 5 mA housings
1.7 mA 1.7 mA Block
housings
2 A/20 ms 2 A/20 ms
Yes Yes AC 2-wire
25...+70 C 25...+70 C
Special
100 Hz 100 Hz properties
AC 140/DC 13 AC 140/DC 13
Yellow LED Yellow LED Analog
distance
CE CE
Accessories
PBT/Cast zinc PBT/Cast zinc
PBT PBT
Fig. 1...6 Fig. 3...6
1/2" 20UNF-2A plug connector, 3-pin 1/2" 20UNF-2A plug connector, 3-pin
C21 AE3-00-TY-060F C21 AE3-00-TY-060F
1/2"-20 UNF-2A 1/2"-20 UNF-2A
www.balluff.com 625
Programmable Unisensor
Unisensors can be switched between a normally open function-
and a normally closed function. A wire jumper is used to change the
setting.
sn 30/40 mm Housing size

sn 15/20 mm

Sensing distance
NO/NC Ordering code
programmable Part number

Supply voltage UB
UNISENSOR

Approvals
Material Housing
Sensing surface
Connection
Current reduction as a function of
ambient temperature range See technical section (page 963-966)

250 mA

180 mA
25 C +25 C +70 C
Row mounting Mounting options

Flush 80 mm,
Non-ush 120 mm


Flush Flush Flush
15 mm 15 mm 15 mm
0...12 mm 0...12 mm 0...12 mm
1X 1X 1X Inductive
BES020Y BES0242 BES0243 sensors
BES 517-223-M3-E BES 517-223-U3-E-S21 BES 517-223-U3-E-S5 Global
110 V AC 110 V AC 110 V AC DC 3-wire
20...250 V AC/DC 20...250 V AC/DC 20...250 V AC/DC
DC 3-/4-wire
10.5 V 10.5 V 10.5 V
250 V AC ([) 250 V AC 250 V AC DC 2-wire
250 mA 250 mA 250 mA
AC/DC
5 mA 5 mA 5 mA 2-wire
1.7 mA 1.7 mA 1.7 mA Tubular
1 A/20 ms 1 A/20 ms 1 A/20 ms housings
Yes Yes Yes Block
housings
25...+70 C 25...+70 C 25...+70 C
100 Hz 100 Hz 100 Hz AC 2-wire
AC 140/DC 13 AC 140/DC 13 AC 140/DC 13
Special
Yellow LED Yellow LED Yellow LED properties
IP 67 IP 67 IP 67
CE, cULus CE, cULus CE, cULus Analog
distance
PBT/aluminum PBT/aluminum PBT/aluminum measurement
PBT PBT PBT
Accessories
Fig. 1...5 Fig. 1...5 Fig. 1...5
Screw terminal M20x1.5 1/2" 20UNF-2A plug connector, 3-pin 7/8" 16UN plug connector, 3-pin
C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020
40
40
40
46
46
46
7.3
7.3
7.3
5.3
5.3
120
120
120
5.3
LED LED LED

60
60
60
6.5
7.3
7.3
6.5
6.5
7.3
30
40 7/8-16UN
1/2" 20UNF-2A
30
25.4
30
40
40
40
16
16
16
13
13
13
M201.5 40 40
www.balluff.com 627

Installation type (observe instructions in Basic Information chapter) Non-ush Non-ush
NO/NC Ordering code BES0245 BES0246
programmable Part number BES 517-223-U4-E-S21 BES 517-223-U4-E-S5
Rated operating voltage Ue 110 V AC 110 V AC
Residual current Ir max. 1.7 mA 1.7 mA
Short-term current carrying capacity Ic /time T 1 A/20 ms 1 A/20 ms
Short-circuit protected Yes Yes
Material Housing PBT/aluminum PBT/aluminum
Possible installation variations Fig. 4 and 5 (see page 626) Fig. 4 and 5 (see page 626)
Connection 1/2" 20UNF-2A plug connector, 3-pin 7/8" 16UN plug connector, 3-pin
Suggested mating cable C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020

40
40
46
46

7.3
7.3

5.3
120
120
5.3
LED LED
60
60
6.5
7.3
7.3
6.5
7/8-16UN
1/2" 20UNF-2A
30
25.4
30
40
40
16
16
13
13
40 40


30 mm 30 mm 40 mm
0...24 mm 0...24 mm 0...32 mm
1X 1X 1X Inductive
BES0248 BES0249 BES024C sensors
BES 517-223-U5-E-S21 BES 517-223-U5-E-S5 BES 517-223-U7-EL-S21 Global
20...250 V AC/DC 20...250 V AC/DC 20...250 V
DC 3-/4-wire
10.5 V 10.5 V 12.5 V
250 mA 250 mA 250 mA
AC/DC
1.7 mA 1.7 mA 1.7 mA Tubular
Yes Yes Yes Block
housings
25...+70 C 25...+70 C 25...+70 C
AC 140/DC 13 AC 140/DC 13 AC 140/DC 13
Special
IP 67 IP 67 IP 67
distance
PBT/aluminum PBT/aluminum PBT/aluminum measurement
PBT PBT PBT
Accessories
Fig. 4 and 5 (see page 626) Fig. 4 and 5 (see page 626) Fig. 4 and 5 (see page 626)
1/2" 20UNF-2A plug connector, 3-pin 7/8" 16UN plug connector, 3-pin 1/2" 20UNF-2A plug connector, 3-pin
C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020 C21 AE3-00-TY-060F
40
40
40
46
46
46
7.3
7.3
7.3
5.3
5.3
120
120
120
5.3
LED LED LED

60
60
60
6.5
7.3
7.3
7.3
6.5
6.5
7/8-16UN
1/2" 20UNF-2A 1/2" 20UNF-2A
30
25.4 25.4
30 30
40
40
40
16
16
16
13
13
13
40 40 40
www.balluff.com 629
Housing size
Sensing distance
NO/NC Ordering code
programmable Part number
Supply voltage UB
Approvals
Material Housing
Sensing surface
Connection
Precise pallet positioning using inductive sensors with long
switching distance See technical section (page 963-966)
Take advantage of the ability to position with precision and ensure a for installation instructions.
consistent production process. For wiring diagram see page 958.
Rugged Maxisensors can be sunk into a plant oor to provide stop-
ping points for vehicle assembly pallets. Additional cable lengths and PUR cable jacket material
Mounting in Mounting in
non-ferrous metals steel/non-ferrous metals
Fig. 1 Fig. 2


50 mm 50 mm 50 mm
0...40.5 mm 0...40.5 mm 0...40.5 mm
1X 1X 1X Inductive
BES024F BES023C BES01ZJ sensors
BES 517-224-M5-E BES 517-224-M5-E-S21 BES 517-224-U5-E-S5 Global
20...250 V AC/DC 20...250 V AC/DC 20...250 V AC/DC
DC 3-/4-wire
11 V 11 V 11 V
250 mA 250 mA 250 mA
AC/DC
1.7 mA 1700 A 1700 A Tubular
Yes Yes Yes Block
housings
25...+70 C 25...+70 C 25...+70 C
AC 140/DC 13 AC 140/DC 13 AC 140/DC 13
Special
IP 67 IP 67 IP 67
distance
PBT PBT PBT measurement
PBT PBT PBT
Accessories
Screw terminal M20x1.5 1/2" 20UNF-2A plug connector, 3-pin 7/8" 16UN plug connector, 3-pin
C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020
1/2"-20UNF-2A 7/8-16UN
www.balluff.com 631
Inductive
Sensors
AC 2-wire inductive sensors
Balluff AC 2-wire sensor technology:
Balluff offers AC-sensors in the M12, M18, M30,
and block housings to meet a wide variety of applications.
For more information, visit us online!

AC 2-wire Inductive Sensors
Contents
Tubular housings
M121 634
M181 636
M301.5 637
Block housings
www.balluff.com 633
AC-sensors are optimized for controllers with

alternating current inputs.
When maintaining the rated operating current, the
sensors can directly control fuses and relays.
Housing size M121

Installation type (observe instructions in Basic Information chapter) Flush
Assured operating distance sa 0...1.6 mm
Sensing distance 1X
NO Ordering code BES02CA
Part number BES 516-449-S21-L
Supply voltage UB 20...250 V AC
Voltage drop Ud at Ie max. 4V
Polarity reversal/short-circuit protected Yes/No
Ambient temperature range Ta 25...+70 C
Utilization category AC 140
Function indicator Yellow LED
Approvals CE, cULus
Material Housing Brass-coated
Sensing surface PA 12
Connection 1/2" 20UNF-2A plug
connector, 3-pin
Suggested mating cable C21 AE3-00-TY-060F

40.5
17
70
1/2"-20 UNF- 2A

M121 M121 M121 M121

Flush Flush Not ush Not ush
2 mm 2 mm 4 mm 4 mm
0...1.6 mm 0...1.6 mm 0...3.2 mm 0...3.2 mm
BES02FP BES02C8 BES02CF BES02CC sensors
BES 515-449-SA7-S21 BES 516-449-BO-L-02 BES 516-461-S21-L BES 516-461-BO-L-02 Global
35...250 V AC 20...250 V AC 20...250 V AC 20...250 V AC DC 3-wire
8.5 V 4V 4V 4V
DC 3-/4-wire
250 V AC 250 V AC ([) 250 V AC ([) 250 V AC ([)
150 mA 500 mA 500 mA 500 mA DC 2-wire
Yes/No Yes/No Yes/No Yes/No
AC/DC 2-wire
25...+70 C 25...+70 C 25...+70 C 25...+70 C
10 Hz 25 Hz 25 Hz 25 Hz AC 2-wire
AC 140 AC 140 AC 140 AC 140 Tubular
Yellow LED Yellow LED Yellow LED Yellow LED housings
Block
IP 67 IP 67 IP 67 IP 67 housings
Stainless steel Brass-coated Brass-coated Brass-coated Special
properties
PA 12 PA 12 PA 12 PA 12
1/2" 20UNF-2A plug 2 m PVC cable, 1/2" 20UNF-2A plug 2 m PVC cable, Analog
connector, 3-pin 22 AWG connector, 3-pin 22 AWG distance
measurement
C21 AE3-00-TY-060F C21 AE3-00-TY-060F
Accessories
M12x1
M12x1
5
40.5
50.5
17
17
70
70
1/2 - 20 UNF - 2A 1/2 - 20 UNF - 2A
www.balluff.com 635

NO Ordering code BES02AY BES02AU
Part number BES 516-420-E5-L-S21 BES 516-420-E4-L-02
Rated operating voltage Ue 110 V 110 V
Supply voltage UB 20...250 V AC 20...250 V AC
Polarity reversal/short-circuit protected Yes/No Yes/No
Ambient temperature range Ta 25...+70 C 25...+70 C
Utilization category AC 140 AC 140
Function indicator Yellow LED Yellow LED
Connection 1/2" 20UNF-2A plug 2 m PVC cable,
connector, 3-pin 22 AWG

51
49
56
65
24
1/2"-20 UNF-2A

Tubular housings, M181, M301.5
M181 M181 M301.5 M301.5

Not ush Not ush Flush Flush
8 mm 8 mm 10 mm 10 mm
0...6.4 mm 0...6.4 mm 0...8 mm 0...10 mm
BES02C7 BES02C5 BES02AT BES02AP sensors
BES 516-437-E5-L-S21 BES 516-437-E4-L-02 BES 516-418-E5-L-S21 BES 516-418-E4-L-02 Global
110 V 110 V 110 V 110 V DC 3-wire
20...250 V AC 20...250 V AC 20...250 V AC 20...250 V AC
DC 3-/4-wire
4V 4V 4V 4V
500 mA 500 mA 500 mA 500 mA
AC/DC 2-wire
Yes/No Yes/No Yes/No Yes/No
25...+70 C 25...+70 C 25...+70 C 25...+70 C AC 2-wire
25 Hz 25 Hz 25 Hz 10 Hz Tubular
AC 140 AC 140 AC 140 AC 140 housings
Yellow LED Yellow LED Yellow LED Yellow LED Block
housings
IP 67 IP 67 IP 67 IP 67
CE, cULus CE, cULus CE, cULus CE, cULus Special
properties
PA 12 PA 12 PA 12 PA 12 Analog
1/2" 20UNF-2A plug 2 m PVC cable, 1/2" 20UNF-2A plug 2 m PVC cable, distance
measurement
connector, 3-pin 22 AWG connector, 3-pin 22 AWG
C21 AE3-00-TY-060F C21 AE3-00-TY-060F Accessories
M18x1 M18x1
10
10
55.5
61.5
49
24
56
65
24
1/2-20 UNF-2A
LED
1/2"-20 UNF-2A
www.balluff.com 637
Tubular housings, M301.5
Housing size M301.5 M301.5

Installation type (observe instructions in Basic Information chapter) Not ush Not ush
NO Ordering code BES02C3 BES02C1
Part number BES 516-432-E5-L-S21 BES 516-432-E4-L-02
Supply voltage UB 20...250 V AC 20...250 V AC
Utilization category AC 140 AC 140
Function indicator Yellow LED Yellow LED
Connection 1/2" 20UNF-2A plug 2 m PVC cable,
connector, 3-pin 26 AWG
See technical section (page 963-966) M30x1.5 M30x1.5

13.5
13

36
50.5

50
56
70.5
36
LED
1/2"- 20UNF- 2A

Housing size 808040 mm Maxisensor 808040 mm Maxisensor

Installation type (observe instructions in Basic Information chapter) Not ush Not ush
NO/NC; Ordering code BES022T BES022U sensors
programmable Part number BES 517-460-U5-L-D-S21 BES 517-460-U5-L-D-S5 Global
Supply voltage UB 20...250 V AC 20...250 V AC DC 3-wire
DC 3-/4-wire
Rated operating current Ie 500 mA 500 mA DC 2-wire
AC/DC 2-wire
Switching frequency f max. 10 Hz 10 Hz AC 2-wire
Utilization category AC 140 AC 140 Tubular
Function indicator Yellow LED Yellow LED housings
Degree of protection as per IEC 60529 IP 67 IP 67 Block
housings
Material Housing PBT PBT Special
properties
Connection 1/2" 20UNF-2A plug connector, 3-pin 7/8" 16UN plug connector, 3-pin Analog
Suggested mating cable C21 AE3-00-TY-060F BCC A313-0000-10-071-VX43W6-020 distance
measurement
See technical section (page 963-966) Accessories

Additional cable lengths and PUR cable jacket

material available on request.
1/2"-20UNF-2A 7/8-16UN
Maxisensor Mounting in Mounting in

can be programmed non-ferrous metals steel/non-ferrous metals
Maxisensors can be set to have
a normally open- or normally
closed function using a switch.
Fig. 1 Fig. 2
www.balluff.com 639
Inductive
Sensors
Inductive sensors with special properties
Balluffs inductive sensors provide solutions for applications:
With increased requirements such as high pressure or Factor 1,
under rough conditions, in harsh environment applications.
The product line also includes special versions such as tube or ring
sensors for discharge and infeed and counting small parts and large
designs with large switching distance.

Contents
High-pressure sensors 642

Strokemaster sensors 660
Steelface sensors 664
High temperature sensors 670
Harsh environment sensors 674
Factor 1 sensors 684
Weld eld immune sensors 696
Large designs 704
Ring sensors 710
Tube sensors 714
www.balluff.com 641
Inductive Sensors with Special Properties up to 50 bar
High-pressure inductive cylinder sensors
In the wide range of hydraulic applications, high pressure

proximity switches are exposed to many aggressive media
and hostile environments.
Balluff offers a world-class line of pressure inductive cylinder sensors
to service high pressure applications. Designed to withstand severe
duty, Balluff high pressure sensors deliver reliable switching perfor-
mance under demanding industrial conditions. Housing size
Corrosion-resistant housing materials, high-strength ceramic sens- Rated switching distance sn
ing faces, and special sealing techniques allow dependable service Assured switching distance sa
up to 500 bar according to the sensor type. Pressure range
All Balluff high pressure sensors are rated for continuous operation Part number
in ambient temperatures up to 80 C, with some versions also high- PNP, NC Ordering code
temperature rated up to 120 C. Part number
Part number
Part number
Supply voltage UB
Output resistance Ra
Approvals
Material Housing
Sensing surface
Sealing ring material/size/replacement part number
Supporting ring material/size/replacement part number
Connection

Installation instruction for high pressure rated sensors
Additional cable lengths on request.
with O-ring
Assembly direction
Thread undercut D DIN 76
0.6O-Ring-Cord diameter
For example, for BES 516-300-S270-S4-D:

d1: of the positioning hole for the switch head 10H8 = 10+0.022
d2: Nominal thread diameter M121 6H
L: Recommended screw-in depth L 0.8d2 = 0.812 = 9.6

M50.5, M121
M50.5 M50.5 M50.5 M50.5 M121

0.8 mm 0.8 mm 0.8 mm 0.8 mm 1.5 mm
0...0.65 mm 0...0.65 mm 0...0.65 mm 0...0.65 mm 0...1.2 mm
Oil pressure resistant up to 10 bar Oil pressure resistant up to 20 bar Oil pressure resistant up to 20 bar Oil pressure resistant up to 20 bar Oil pressure resistant up to 50 bar Inductive
BES03H6 BES03JN BES03LT BES03K8 BHS003A sensors
BES M05EG-PSC08B-BP02 BES M05EC-PSC08B-S26G-R01 BES M05EC-PSC08B-S49G-R01 BES M05ED-PSC08B-BP00,3-GS49-R01 BES 516-300-S291-S4-D Global
BES03JP BES03K9 DC 3-wire
BES M05EC-POC08B-S26G-R01 BES M05ED-POC08B-BP00,3-GS49-R01
DC 3-/4-wire
BES03JP BES03KA
BES M05EC-NSC08B-S26G-R01 BES M05ED-NSC08B-BP00,3-GS49-R01 DC 2-wire
BES03JT BES03KC
BES M05EC-NOC08B-S26G-R01 BES M05ED-NOC08B-BP00,3-GS49-R01 AC/DC 2-wire
1030 V DC 1030 V DC 1030 V DC 1030 V DC 1030 V DC AC 2-wire
3V 3V 3V 3V 2V
75 V DC 75 V DC 75 V DC 75 V DC 75 V DC Special
properties
100 mA 100 mA 100 mA 100 mA 200 mA
High-pressure
Open collector Open collector Open collector Open collector 150 k sensors
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Strokemaster
sensors
25+70 C 25+70 C 25+70 C 25+70 C 25+80 C
Steelface
3 kHz 3 kHz 3 kHz 3 kHz 2 kHz sensors
Yellow LED Yellow LED Yellow LED Yellow LED no High
IP 67 IP 67 IP 67 IP 67 IP 68 per BWN Pr. 20 temperature
sensors
CE CE CE CE CE Harsh
Stainless steel Stainless steel Stainless steel Stainless steel Stainless steel environment
sensors
Ceramic PBT PBT PBT EP
PA/10.43.5/178173 PA/10.43.5/178173 PA/10.43.5/178173 N70B200V/5.32.4 NBR/631753 Factor 1
sensors
PTFE/5.32.4/705918
Weld eld
2 m PUR cable, M5 connector, 4-pin M8 connector, 3-pin 0.3 m PUR cable M12 connector, 3-pin immune
26 AWG with M8 connector, 3-pin sensors
BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 Large
designs
Ring sensors
M50.5 M5x0.5 M5x0.5 M5x05 Tube sensors
Analog
distance
15.4
15.4
measurement
20
27
29
7
41
42
7 LED LED Accessories

7
12
4
4 4
LED
LED
M8x1
M8x1
www.balluff.com 643
Housing size
Pressure range
Part number
Part number
Part number
Part number
Supply voltage UB
Approvals
Material Housing
Sensing surface
Sealing ring material/size/replacement part number
Supporting ring material/size/replacement part number
Connection

M50.5, M121
M50.5 M50.5 M121

Flush Flush Flush
0.8 mm 0.8 mm 1.5 mm
0...0.65 mm 0...0.65 mm 0...1.2 mm
Oil pressure resistant up to 100 bar Oil pressure resistant up to 100 bar Oil pressure resistant up to 100 bar Inductive
BES03LC BES03L7 BHS0035 sensors
BES M05ED-PSD08B-BP00,3-GS49-R03 BES M05ED-PSD08B-BP02-R03 BES 516-300-S270-S4-D Global
BES03LE BES03L8 DC 3-wire
BES M05ED-POD08B-BP00,3-GS49-R03 BES M05ED-POD08B-BP02-R03
DC 3-/4-wire
BES03LF BES03L9
BES M05ED-NSD08B-BP00,3-GS49-R03 BES M05ED-NSD08B-BP02-R03 DC 2-wire
BES03LH BES03LA
AC/DC 2-wire
BES M05ED-NOD08B-BP00,3-GS49-R03 BES M05ED-NOD08B-BP02-R03
1030 V DC 1030 V DC 1030 V DC AC 2-wire
3V 3V 2.5 V
75 V DC 75 V DC 75 V DC Special
properties
100 mA 100 mA 200 mA High-pressure
Open collector Open collector 150 k sensors
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Strokemaster
sensors
25+70 C 25+70 C 25+80 C
Steelface
3 kHz 3 kHz 2 kHz sensors
IP 67 IP 67 IP 68 per BWN Pr. 20 High
CE, cULus CE, cULus CE temperature
sensors
Stainless steel Stainless steel Stainless steel Harsh
Ceramic Ceramic EP environment
sensors
N70B200V/5.32.4/178173 N70B200V/5.32.4/178173 N70B200V/5.32.4/631753
PTFE/5.32.4 Factor 1
sensors
0.3 m PUR cable with M8 connector, 3-pin 2 m PUR cable, 26 AWG M12 connector, 3-pin
Weld eld
BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 immune
sensors
Large
M50.5 M50.5 10e7 designs
Ring sensors
Sealing disk Sealing disk
Washer Washer Tube sensors
12.9
Fastening nut Fastening nut

Analog
27
distance
27
measurement
2.1
2.1
17
40.6
7
69
7 Accessories
4 4
10
M121
M81
www.balluff.com 645
10 mm, M121
Housing size 10e7 M121 M121

Pressure range Oil pressure resistant up to 350 bar Oil pressure resistant up to 350 bar Oil pressure resistant up to 350 bar
PNP, NO Ordering code BHS0030 BHS007E BHS004T
Part number BES 516-300-S260-S4-D BES 516-300-S205-D-S4-00,3 BES 516-300-S324-S4-D
Supply voltage UB 1030 V DC 1030 V DC 1030 V DC
Output resistance Ra 150 k 150 k 150 k
Ambient temperature Ta 25+80 C 25+80 C 25+80 C
Approvals CE CE CE
Sensing surface EP EP EP
Sealing ring material/size/replacement part number FPM 70/5.852.4/636594 N70B200V/5.32.4/631753 FPM 70/5.852.4/636594
Supporting ring material/size/replacement part number PTFE/5.32.4/705918 PTFE/5.32.4/705918 PTFE/5.32.4/705918
Connection M12 connector, 3-pin 0.3 m PUR cable M12 connector, 4-pin
For wiring diagram see page 958. M12x1

18
300.1
37.3
13
max.49
M12x1

M121
M121 M121
Flush Flush
1.5 mm 1.5 mm
0...1.2 mm 0...1.2 mm
Oil pressure resistant up to 350 bar Oil pressure resistant up to 350 bar Inductive
BHS004P BHS004R sensors
BES 516-300-S322-S4-D BES 516-300-S323-S4-D Global
1030 V DC 1030 V DC DC 3-wire
2V 2V
DC 3-/4-wire
75 V DC 75 V DC
200 mA 200 mA DC 2-wire
150 k 150 k
AC/DC 2-wire
Yes/Yes/Yes Yes/Yes/Yes
25+80 C 25+80 C AC 2-wire
1 kHz 1 kHz
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 Special
properties
CE CE High-pressure
Stainless steel Stainless steel sensors
EP EP Strokemaster
sensors
FPM 70/5.852.4/636594 FPM 70/5.852.4/636594
Steelface
PTFE/5.32.4/705918 PTFE/5.32.4/705918 sensors
M12 connector, 4-pin M12 connector, 4-pin High
temperature
sensors
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 Harsh
environment
sensors
Factor 1
sensors
Weld eld
immune
sensors
Large
designs
Ring sensors
Tube sensors
Analog
distance
measurement
Accessories
www.balluff.com 647
M121, M161

Rated switching distance sn 1.5 mm 1.5 mm
Pressure range Oil pressure resistant up to 350 bar Oil pressure resistant up to 350 bar
PNP, NO Ordering code BHS004N BHS001T
Part number BES 516-300-S321-S4-D BES 516-300-S149-S4-D
Part number
Supply voltage UB 1030 V DC 1030 V DC
Output resistance Ra 33 k 33 k
Ambient temperature Ta 25+80 C 25+80 C
Degree of protection as per IEC 60529 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20
Approvals CE CE
Sensing surface EP EP
Sealing ring material/size/replacement part number FPM 70/5.852.4/636594 NBR 60-80/11.01.5/709137
Supporting ring material/size/replacement part number PTFE/5.32.4/705918 PTFE/1411.61.5/709136

10e7
7.4
17.9
3.7
61.5
17
78
10
M12x1

M161
M161 M161 M161 M161

1.5 mm 1.5 mm 1.5 mm 2.5 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...2 mm
Oil pressure resistant up to 350 bar Oil pressure resistant up to 350 bar Oil pressure resistant up to 350 bar Oil pressure resistant up to 350 bar Inductive
BHS001E BHS001C sensors
BES 516-300-S129-S4-D BES 516-300-S128-S4-D Global
BHS001Y BHS004U DC 3-wire
BES 516-300-S156-S4-D BES 516-300-S328-S4-D
DC 3-/4-wire
1030 V DC 1030 V DC 1030 V DC 1030 V DC
1.5 V 1.5 V 1.5 V 1.5 V DC 2-wire
75 V DC 75 V DC 75 V DC 75 V DC
AC/DC 2-wire
200 mA 200 mA 200 mA 200 mA
33 k 33 k 33 k 33 k AC 2-wire
25+80 C 25+80 C 25+80 C 10+80 C Special
properties
1 kHz 1 kHz 1 kHz 500 Hz High-pressure
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 sensors
CE CE CE CE Strokemaster
sensors
Steelface
EP EP EP EP sensors
NBR 60-80/11.01.5/709137 NBR 60-80/11.01.5/709137 NBR 60-80/11.01.5/709137 NBR 60-80/11.01.5/709137 High
temperature
PTFE/1411.10.7/505953 PTFE/1411.61.5/709136 PTFE/1411.10.7/505953 PTFE/1411.10.7/505953 sensors
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin Harsh
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 environment
sensors
Factor 1
sensors
Weld eld
immune
sensors
Large
designs
Ring sensors
Tube sensors
Analog
distance
measurement
Accessories
www.balluff.com 649
Inductive Sensors with Special Properties 350 bar
M181, M221.5, M50.5 up to 500 bar
Housing size M181 M50.5

Rated switching distance sn 1.5 mm 1 mm
Pressure range Oil pressure resistant up to 350 bar Oil pressure resistant up to 500 bar
PNP, NO Ordering code BHS001N BHS006U
Part number BES 516-300-S144-S4-D BHS G409N-PSD10-EP02
PNP, NC Ordering code BHS006W
Part number BHS G409N-POD10-EP02
NPN, NO Ordering code BHS006Y
Part number BHS G409N-NSD10-EP02
Output resistance Ra 33 k Open collector
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes Yes/No/Yes
Degree of protection as per IEC 60529 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20
Approvals CE CE
Sensing surface EP ZrO2
Sealing ring material/size/replacement part number NBR 60-80/11.01.5/709137 NBR 70/2.351/154783
Supporting ring material/size/replacement part number PTFE/1411.10.7/505953 PTFE/4.20.651/154782
Connection M12 connector, 4-pin 2 m PUR cable, 26 AWG
M5x0.5
4.2g6
8.6
28.1
32
7
4
8

M50.5, M81
M50.5 M50.5 M50.5 M8 1 M8 1

1 mm 1 mm 1 mm 1.5 mm 1.5 mm
0...0.8 mm 0...0.8 mm 0...0.8 mm 0...1.2 mm 0...1.2 mm
BHS007J BHS006N BHS005H BHS0054 BHS0050 sensors
BHS G409N-PSD10-EP00,3-GS49 BHS G403N-PSD10-S26 BHS G408N-PSC10-S49 BHS A404N-PSC15-S49 BHS A402N-PSC15-S49 Global
BHS006P BHS005F BHS0053 BHS004Z DC 3-wire
BHS G403N-POD10-S26 BHS G408N-POC10-S49 BHS A404N-POC15-S49 BHS A402N-POC15-S49
DC 3-/4-wire
BHS006R BHS005E BHS0052 BHS004Y
BHS G403N-NSD10-S26 BHS G408N-NSC10-S49 BHS A404N-NSC15-S49 BHS A402N-NSC15-S49 DC 2-wire
1030 V DC 1030 V DC 1030 V DC 1030 V DC 1030 V DC
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V AC/DC 2-wire
100 mA 100 mA 100 mA 100 mA 100 mA
Open collector Open collector Open collector Open collector Open collector Special
properties
Yes/No/Yes Yes/No/Yes Yes/No/Yes Yes/Yes/Yes Yes/Yes/Yes
High-pressure
25+80 C 25+80 C 25+80 C 0+80 C 25+80 C sensors
3 kHz 3 kHz 3 kHz 4 kHz 4 kHz Strokemaster
sensors
Steelface
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 sensors
CE CE CE CE CE High
Stainless steel Stainless steel Stainless steel Stainless steel Stainless steel temperature
sensors
ZrO2 ZrO2 ZrO2 ZrO2 ZrO2 Harsh
NBR 70/2.351/154783 NBR 70/2.351/154783 NBR 70/2.351/154783 NBR 70/41.5/154149 NBR 70/41.5/154149 environment
sensors
PTFE/4.20.651/154782 PTFE/4.20.651/154782 PTFE/4.20.651/154782 PTFE/5.32.4/154150 PTFE/5.32.4/154150
0.3 m PUR cable M5 connector, 3-pin M8 connector, 3-pin M8 connector, 3-pin M8 connector, 3-pin Factor 1
sensors
Weld eld
BCC M313-0000-10-001-EX43T2-020 BKS-B 25-3-PU-03 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M313-0000-10-001-EX43T2-020 immune
sensors
4.2 g6 M5x0.5 M5x0.5 M8x1 M8x1 Large
designs
M5x0.5 4.2g6 4.2g6 6.5g6 6.5g6
Ring sensors
Tube sensors
8.6
8.6
8.6
12
12
Analog
26.6
24
distance
32
32
7 7 13 13
19.5
40.1
40.6
6 measurement
42
45
4 4
47
55
LED 6 Accessories
25.4
24
13
7 LED
4 LED
24
M5x0.5
M8x1
M8x1
M8x1
M8x1
www.balluff.com 651
M121

PNP, NO Ordering code BHS0023 BHS0032
PNP, NC Ordering code BHS004F
Part number BES 516-300-S305-S4-D
Approvals CE CE CE
Sealing ring material/size/replacement part number N70B200V/5.32.4/631753 N70B200V/5.32.4/631753 N70B200V/5.32.4/631753

122.5
Simulation of sensor end cap and

housing under high-pressure stress.

High-pressure sensors
M121
M121 M121 M121 M121 M121

1.5 mm 1.5 mm 1.5 mm 1.5 mm 1.5 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm
BHS0033 BHS002Y BHS005Y BHS0063 BHS0061 sensors
BES 516-300-S265-S4-D BES 516-300-S249-S4-D BHS B249V-PSD15-S04 BHS B400V-PSD15-S04 BHS B265V-PSD15-S04 Global
DC 3-wire
DC 3-/4-wire
2V 2V 2.5 V 2.5 V 2.5 V DC 2-wire
AC/DC 2-wire
200 mA 200 mA 200 mA 200 mA 200 mA
150 k 150 k 33 k 33 k 33 k AC 2-wire
25+80 C 25+80 C 25+120 C* 25+120 C* 25+120 C* Special
properties
2 kHz 2 kHz 400 Hz 400 Hz 400 Hz High-pressure
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 sensors
CE CE CE CE CE Strokemaster
sensors
Steelface
EP EP Ceramic Ceramic Ceramic sensors
N70B200V/5.32.4/631753 N70B200V/5.32.4 NBR/631753 FPM 80/6.751.78/149621 FPM 80/6.751.78/149621 FPM 80/6.751.78/123170 High
temperature
PTFE/5.32.4/705918 PTFE/5.32.4/705918 PTFE/107.01.8/150229 PTFE/107.01.8/150229 PTFE/107.01.8/150229 sensors
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin Harsh
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 environment
sensors
M12x1 M12x1 Factor 1

10e7
sensors
10e7
Weld eld
immune
sensors
15
18
Large
17 17 designs
56 Ring sensors
56
Tube sensors
10 10
Analog
distance
16.5
16.5
measurement
Accessories
M12x1 M12x1
*Current reduction as a function of

ambient temperature range
200 mA
100 mA
25 C +75 C +120 C
www.balluff.com 653
M121

PNP, NO Ordering code BHS0021 BHS001L
Part number
NPN, NO Ordering code BHS0037
Part number BES 516-300-S281-S4-D
Degree of protection as per IEC 60529 IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20
Approvals CE CE CE
Sealing ring material/size/replacement part number N70B200V/5.32.4/631753 N70B200V/5.32.4/631753 FPM 70/5.852.4/636594
For wiring diagram see page 958. 10e7

7.4
17.9
3.7
61.5
17
78
10
M12x1

M121
With
temperature
output
M121 M121 M121 M121
1.5 mm 1.5 mm 1.5 mm 1.5 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...1.2 mm
BHS005R BHS005T BHS0049 sensors
BHS B135V-PSD15-S04 BHS B135V-PSD15-S04-T01 BES 516-300-S298-S4-D Global
BHS0002 DC 3-wire
BES 516-100-S46-S4-D
DC 3-/4-wire
DC 2-wire
1030 V DC 1030 V DC 1030 V DC 1030 V DC
2.5 V 2.5 V 1.5 V 1.5 V AC/DC 2-wire
75 V DC 75 V DC 75 V DC 75 V DC AC 2-wire
200 mA 200 mA 200 mA 200 mA
33 k 33 k 33 k 33 k Special
properties
Yes/Yes/Yes Yes/No/Yes Yes/Yes/Yes Yes/Yes/Yes
High-pressure
25+120 C* 25+120 C* 25+80 C 25+80 C sensors
400 Hz 400 Hz 1 kHz 1 kHz Strokemaster
sensors
IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20
Steelface
CE CE CE CE sensors
Stainless steel Stainless steel Stainless steel Stainless steel High
Ceramic Ceramic EP EP temperature
sensors
FPM 80/6.751.78/149621 FPM 80/6.751.78/123170 FPM 70/5.852.4/636594 FPM 70/5.852.4/636594 Harsh
PTFE/107.01.8/150229 PTFE/107.01.8/150229 PTFE/5.32.4/705918 PTFE/5.32.4/705918 environment
sensors
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 Factor 1
sensors
Weld eld
10e7 M12x1 10e7 10e7 immune
10e7 sensors
Large
7.4
7.4
7
designs
17.9
17.9
18
Ring sensors
4.1
18
3.7
3.7
17
Tube sensors
37
61.5
61.5
61.5
17 17 17 Analog
78
78
78
distance
78
measurement
10 Accessories
16.5
10 10 10
M12x1
M12x1 M12x1 M12x1
*Current reduction as a function of

ambient temperature range
200 mA
100 mA
25 C +75 C +120 C
www.balluff.com 655
M121

PNP, NO Ordering code BHS007H BHS0022
Part number BES 516-300-S135-E1-S4-D BES 516-300-S163-S4-D
PNP, complementary Ordering code BHS0076
Part number BHS B135V-PAD15-S04-007
Part number
Switching frequency f max. 1 kHz 1.5 kHz 1 kHz
Approvals CE CE CE
Sensing surface EP Ceramic EP
Sealing ring material/size/replacement part number FPM 70/5.852.4/636594 FPM 80/6.751.78/149621 N70B200V/5.32.4/631753

10e7 10e7
7.4
7
17.9
18
3.7
4.1
61.5
61.5
17 17
78
78
10 10
M12x1 M12x1
Simulation of sensor end cap

and housing under high-pressure
stress.

M121
M121 M121 M121 M121 M121

1.5 mm 1.5 mm 1.5 mm 2.5 mm 1.5 mm
0...1.2 mm 0...1.2 mm 0...1.2 mm 0...2 mm 0...2 mm
BES03PP BHS004C BHS0060 BHS0065 sensors
BES 516-300-S335-S4-D BES 516-300-S300-S4-D BHS B249V-PSD25-S04-003 BHS B400V-PSD25-S04-003 Global
DC 3-wire
DC 3-/4-wire
BHS002U
BES 516-300-S242-S4-D DC 2-wire
1.5 V 1.5 V 1.5 V 2.5 V 2.5 V AC/DC 2-wire
200 mA 200 mA 200 mA 200 mA 200 mA
33 k 33 k 33 k 33 k 33 k Special
properties
High-pressure
25+80 C 25+80 C 25+80 C 25+90 C 25+90 C sensors
1 kHz 1 kHz 1 kHz 400 Hz 400 Hz Strokemaster
sensors
IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20
Steelface
CE CE CE CE CE sensors
Stainless steel Stainless steel Stainless steel Stainless steel Stainless steel High
EP EP EP Ceramic Ceramic temperature
sensors
N70B200V/5.32.4/631753 N70B200V/5.32.4/631753 N70B200V/5.32.4/631753 FPM 80/6.751.78/149621 FPM 80/6.751.78/149621 Harsh
PTFE/5.32.4/705918 PTFE/5.32.4/705918 PTFE/5.32.4/705918 PTFE/107.01.8/150229 PTFE/107.01.8/150229 environment
sensors
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 Factor 1
sensors
Weld eld
M12x1 M12x1 immune
10e7 10e7 sensors
Large
designs
Ring sensors
18
20
17 Tube sensors
17 Analog
56
distance
76.5
10 measurement
16.5
Accessories
93
M12x1
10
www.balluff.com 657
M121

PNP, NO Ordering code BHS0062 BHS005U BHS005W
Part number BHS B265V-PSD25-S04-003 BHS B135V-PSD25-S04-003 BHS B163V-PSD25-S04-003
Approvals CE CE CE
Sensing surface Ceramic Ceramic Ceramic
Sealing ring material/size/replacement part number FPM 80/6.751.78/149621 FPM 80/6.751.78/149621 FPM 80/6.751.78/149621
For wiring diagram see page 958. M12x1 10e7 10e7

10e7
12.9
7
18
17
15
4.1
17
61.5
17
76.5
56
78
93
10
16.5
10
M12x1 10
M12x1
M12x1

High pressure sensors
M181
M181 M181 M181 M181

1.5 mm 1.5 mm 3 mm 3 mm
0...1.2 mm 0...1.2 mm 0...2.1 mm 0...2.1 mm
BHS004A BHS004J BHS0071 BHS0026 sensors
BES 516-300-S299-S4-D BES 516-300-S308-S4-D BES 516-300-S334-S4 BES 516-300-S190-S4 Global
2V 2V 3.5 V 3.5 V
DC 3-/4-wire
75 V DC 75 V DC 75 V DC 75 V DC
200 mA 200 mA 130 mA 130 mA DC 2-wire
150 k 150 k 2 k 2 k
AC/DC 2-wire
25+80 C 25+80 C 25+80 C 25+80 C AC 2-wire
2 kHz 2 kHz 400 Hz 400 Hz
IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20 IP 68 according to BWN PR. 20 Special
properties
CE CE CE CE High-pressure
Stainless steel Stainless steel Stainless steel Stainless steel sensors
EP EP PEEK PEEK Strokemaster
sensors
NBR 60-80/12.421.78/642828 NBR 60-80/12.421.78/642828 NBR 85/15.720.91.5/179002 NBR 90/13.01.5/619531
Steelface
PTFE/1512.20.7/642827 PTFE/1512.20.7/642827 PTFE/1613.80.5/635431 sensors
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin High
temperature
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 sensors
Harsh
M18x1 environment
15 f6 16 sensors
Factor 1
sensors
25.5 0.1
30.00.1
Weld eld
immune
sensors
45
58
19 Large
designs
Ring sensors
Tube sensors
Analog
M12x1 distance
measurement
Accessories
www.balluff.com 659
Inductive Sensors with Special Properties STROKEMASTER
Strokemaster sensors
Strokemaster Inductive Cylinder Sensors Strokemaster sensors are available in 3-wire DC and 2-wire AC/DC
Balluffs Strokemaster cylinder-position sensors provide precision versions, both with mini or micro connectors. Switching frequency
end-of-stroke sensing for hydraulic cylinders. The sensor body is 50 Hz for the AC/DC versions. All units are weld-eld immune,
allows 304 of rotation to eliminate the hassle of post-installation short-circuit, and reverse-polarity protected. They t popular cylinder
cable management, which in some competitive designs requires designs with standard available probe lengths of 0.912" - 4.560"
unbolting the ange and breaking the hydraulic seal. (23.165mm - 115.8mm). Custom probe lengths can be achieved
by using factory spacer kits. Probes are made of stainless steel with
A high-pressure, inductive proximity sensor, the Strokemaster a high-strength ceramic face. Both DC and AC/DC sensors have
provides a 2mm (0.08") sensing range to detect the spud of all-metal housings. The Strokemaster sensor is CE-certied, and its
hydraulic/pneumatic cylinders and indicate fully retracted or housing is sealed to IP67 requirements.
extended position. It mounts with two socket-head cap screws
and seals with a Viton O-ring. Withstanding cylinder pressures up
to 3000 PSI (207 bar), the embeddable design keeps most of the
switch protected within the cylinder, with only a 0.62" (16 mm) high
housing exposed outside.

Strokemaster DC sensors
Housing size
Assured switching distance sa 0...1.6 mm Inductive
PNP, NO Ordering code sensors
Part number BES 516-300-S 295/0.912"...4.560"-S4 Global

Rated operational voltage Ue 24 V DC DC 3-wire
DC 3-/4-wire
Rated insulation voltage Ui 75 V DC DC 2-wire
AC/DC 2-wire
No-load supply current I0 damped/undamped 18 mA/ 10 mA
Off-state current Ir 80 A AC 2-wire
Protected against polarity reversal Yes
Short circuit/overload protected Yes/Yes Special
properties
Load capacitance 1.0 F High-pressure
Repeat accuracy R 5% sensors
High pressure rated up to 207 bar (3000 PSI) Strokemaster
sensors
Ambient temperature Ta 25+70 C
Steelface
Operating frequency f 10 Hz sensors
Utilization categories DC 13 High
temperature
Function/Operating voltage indication Yes/Yes sensors
Degree of protection as per IEC 60529 IP 67 Harsh
Approvals cULus environment
sensors
Material Housing stainless steel/aluminum
Sensing surface ceramic Factor 1
sensors
Connection M12 connector 4-pin
Weld eld
BCC M415-0000-IA-003-EX44T2-020 immune
sensors
Large
For wiring diagram see page 958. designs
Ring sensors
Tube sensors
Analog
distance
measurement
Accessories
www.balluff.com 661
Inductive Sensors with Special Properties STROKEMASTER
Strokemaster AC/DC sensors
Housing size
Installation type Flush Flush
Part number BES 516-200-S 2/0.912"...4.560"-S 21 BES 516-200-S 2/0.912...4.560-S5
Rated operational voltage Ue 110 V AC 110 V AC
Supply voltage UB 20250 V AC/V DC 20250 V AC/V DC
Voltage drop Ud at Ie 6V 6V
Minimum operational current Im 5 mA 5 mA
Off-state current Ir 1.7 mA at 110 V AC 1.7 mA at 110 V AC
Inrush current Ik (t = 20 ms) 3 A max./1Hz 3 A max./1Hz
Protected against polarity reversal Yes Yes
Short circuit protected Yes Yes
Repeat accuracy R 5% 5%
High pressure rated up to 207 bar (3000 PSI) 207 bar (3000 PSI)
Operating frequency f 50 Hz 50 Hz
Utilization categories AC 140/DC 13 AC 140/DC 13
Function/Operating voltage indication Yes/Yes Yes/Yes
Approvals cULus cULus
Material Housing stainless steel/aluminum stainless steel/aluminum
Sensing surface ceramic ceramic
Connection 1/2" 20 UNF-2A plug connector, 3-pin 7/8" 16 UN plug connector, 5-pin
C21-AE3-00-TY-060F BCC A314-0000-IO-003-EX44W6-020
304
48
UNC 1/4-20x3/4 12.9 37 UNC 1/4-20x3/4 12.9 37
35
25
O-ring 17.13 X 2.62 O-ring 17.13 X 2.62

O12.7
O12.7
30
51
LED 1
LED 2
64.2
UNF-20-2A
7/8-16 UN 8 8
L L

Strokemaster installation and spacers
Inductive
sensors
Global
DC 3-wire
DC 3-/4-wire
Note: Spacer may be required to elevate cylinder sensor to position sensing face in optimal position. Balluff recommends the following
guidelines when mounting our Strokemaster sensors: DC 2-wire

Strokemaster Spacers AC/DC 2-wire
A - Recommended to allow for AC 2-wire

mechanical wear
(0.025" to 0.047") Special
properties
B - This dimension must be large High-pressure
enough to allow the sensor to sensors
turn off when the rod is present Strokemaster
sensors
(0.110" to 0.118")
Steelface
sensors
High
temperature
sensors
Below is a table to help you pick out a spacer for custom lengths needed with Strokemaster sensors: Harsh
environment
sensors
Z/Spacers (inches) Factor 1
sensors
0.180 0.188 0.225 0.307 0.372 0.375 0.500 0.562 0.600 0.684 0.712 0.810 0.937
Weld eld
immune
0.912 0.732 0.724 0.687 0.605 0.540 0.537 0.412 0.350 0.312 0.228 0.200 0.102 sensors
1.025 0.845 0.837 0.800 0.718 0.653 0.650 0.525 0.463 0.425 0.341 0.313 0.215 0.088 Large
1.25 1.07 1.062 1.025 0.943 0.878 0.875 0.750 0.688 0.650 0.566 0.538 0.440 0.313 designs
Probe length (inches)
Ring sensors
1.35 1.17 1.162 1.125 1.043 0.978 0.975 0.850 0.788 0.750 0.666 0.638 0.540 0.413
Tube sensors
1.5 1.32 1.312 1.275 1.193 1.128 1.125 1.000 0.938 0.900 0.816 0.788 0.690 0.563
1.75 1.57 1.562 1.525 1.443 1.378 1.375 1.250 1.188 1.150 1.066 1.038 0.940 0.813 Analog
1.875 1.695 1.687 1.650 1.568 1.503 1.500 1.375 1.313 1.275 1.191 1.163 1.065 0.938 distance
measurement
2.062 1.882 1.874 1.837 1.755 1.690 1.687 1.562 1.500 1.462 1.378 1.350 1.252 1.125
2.375 2.195 2.187 2.150 2.068 2.003 2.000 1.875 1.813 1.775 1.691 1.663 1.565 1.438 Accessories
2.775 2.595 2.587 2.550 2.468 2.403 2.400 2.275 2.213 2.175 2.091 2.063 1.965 1.838
2.875 2.695 2.687 2.650 2.568 2.503 2.500 2.375 2.313 2.275 2.191 2.163 2.065 1.938
3.775 3.595 3.587 3.550 3.468 3.403 3.400 3.275 3.213 3.175 3.091 3.063 2.965 2.838
4.56 4.38 4.372 4.335 4.253 4.188 4.185 4.060 3.998 3.960 3.876 3.848 3.750 3.623
Example: Need probe length of 1.125" combine sensor BES-516-200-S2-1.35-S21 with a 0.225" spacer.
(1.35" tube length - 0.225" spacer = 1.125" adjusted length)
Note: A difference of 0.005" will still have to be carefully considered when sizing a spacer and sensor to the cylinder.
- Spacer kits include a spacer, "O" ring, and appropriate mounting screws.
- Other spacer kits may be available: consult factory.
To order a spacer kit:

Use part number BESA-516-200-KIT-* (X.XXX) *measured in inches
(For both DC and AC/DC devices - there is no difference in ange dimensions)
www.balluff.com 663
Inductive Sensors with Special Properties STEELFACE
Steelface sensors
Todays inductive proximity sensors provide position/part conr- The extremely high-quailty coating has a PTFE and ceramic base. It
mation and error proong functions on a variety of machines and prevents the deposition of weld splatter, thereby increasing the pot life
assembly lines. When impact damages or destroys these vital of sensors.
feedback devices it can shut down your entire production process. Application areas
This leads to higher sensor costs, higher maintenance costs, loss of Welding equiptment
production and lower protability...bad news for any manufacturer. Lightweight construction
Balluffs SteelFace inductive sensors are affordable, rugged sensors Automotive industry
that are designed for impact-prone areas. Their stainless steel faces Conveyor technology
handle impacts and abuse multiple times longer than plastic faced Handling
sensors. They also provide up to twice the sensing range of standard Assembly
ush mount sensors. This feature allows the sensors to be mounted Special machine
farther away from their targets, reducing the chance of impact and construction
impact-related failures.

Steelface sensors
M81
Installation type (pay attention to the note in the Basic Information chapter) Flush Flush Flush
Sensing distance 1X 2X 2X Inductive
PNP, NO Ordering code BES02YZ BES02N5 BES02N6 sensors
Part number BES M08EG1-PSC15S-S04G-S BES M08EH1-PSC20B-S04G-S BES M08EH1-PSC20B-S04G-S01 Global
NPN, NO Ordering code BES02YY BES02N3 BES02N4 DC 3-wire
Part number BES M08EG1-NSC15S-S04G-S BES M08EH1-NSC20B-S04G-S BES M08EH1-NSC20B-S04G-S01
DC 3-/4-wire
Voltage drop Ud at Ie max. 2V 2.5 V 2.5 V DC 2-wire
AC/DC 2-wire
Polarity reversal protected/transposition protected/short-circuit protected Yes/No/Yes Yes/Yes/Yes Yes/Yes/Yes AC 2-wire
Switching frequency f max. 20 Hz 750 Hz 750 Hz Special
properties
Function indicator Yellow LED Yellow LED Yellow LED High-pressure
Degree of protection as per IEC 60529 IP 67 IP 67 IP 67 sensors
Approvals CE CE CE Strokemaster
sensors
Special properties Selective ferrous Pressure rated to 80 bar Pressure rated to 80 bar,
Steelface
weld spatter-resistant sensors
Material Housing Stainless steel 303 Stainless steel 316 L Stainless steel, High
temperature
PTFE coated sensors
Sensing surface Stainless steel 303 Stainless steel 316 L Stainless steel, Harsh
PTFE coated environment
sensors
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 Factor 1
sensors
M8x1 M8x1 M8x1 Weld eld
See technical section (page 963-966) immune
for installation instructions. sensors
Large
For wiring diagram see page 958. 13 13
13 designs
Ring sensors
44.5
44.5
Tube sensors
40
46
64.5
When using metal mounts, a reduction in the switching distance is Analog

65
65
to be expected. You should check whether the clamping holder can distance
be used in the application. LED measurement
10.7 Accessories
LED LED
M12x1 M12x1 M12x1
www.balluff.com 665
Steelface sensors
M121

Sensing distance marking 1X 1X 2X
PNP, NO Ordering code BES02Z2 BES02Z3 BES02NA
Part number BES M12EG1-PSC20N-S04G-S BES M12EG1-PSC20S-S04G-S BES M12EI-PSC40B-S04G-S
PNP, NC Ordering code BES02Z1
Part number BES M12EG1-POC20S-S04G-S
NPN, NO Ordering code BES02Z0 BES02N8
Part number BES M12EG1-NSC20S-S04G-S BES M12EI-NSC40B-S04G-S
Voltage drop Ud at Ie max. 2V 2V 2.5 V
Polarity reversal protected/transposition protected/short-circuit protected Yes/No/Yes Yes/No/Yes Yes/Yes/Yes
Function indicator Yellow LED Yellow LED Yellow LED
Degree of protection as per IEC 60529 IP 67/1200 psi washdown IP 67/1200 psi washdown IP 67
Approvals CE CE CE
Special properties Selective non-ferrous Selective ferrous Pressure rated to 60 bar
(870 psi)
Material Housing Stainless steel 303 Stainless steel 303 Stainless steel 316 L
Sensing surface Stainless steel 303 Stainless steel 303 Stainless steel 316 L


17 17
2

44
44
49.5
65
65
65
When using metal mounts, a reduction in the switching distance is

to be expected. You should check whether the clamping holder can
be used in the application.
LED LED LED
M12x1
M12x1 M12x1

Steelface sensors
M121, M181
M121 M121 M121 M181 M181

Flush Non-ush Quasi-ush Flush Flush
0...3.2 mm 0...8.1 mm 0...4.9 mm 0...4.1 mm 0...4.1 mm
BES02NC BES02WE BES02WH BES02Z8 BES02Z9 sensors
BES M12EI-PSC40B-S04G-S01 BES M12EF1-PSC10F-S04G-S BES M12EG1-PSC60Z-S04G-S11 BES M18EG1-PSC50N-S04G-S BES M18EG1-PSC50S-S04G-S Global
BES02Z7 DC 3-wire
BES M18EG1-POC50S-S04G-S
DC 3-/4-wire
BES02N9 BES02WC BES02WF BES02Z6
BES M12EI-NSC40B-S04G-S01 BES M12EF1-NSC10F-S04G-S BES M12EG1-NSC60Z-S04G-S11 BES M18EG1-NSC50S-S04G-S DC 2-wire
AC/DC 2-wire
2.5 V 2V 2V 2V 2V
200 mA 200 mA 200 mA 100 mA 100 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/No/Yes Yes/No/Yes Special
properties
25+70 C 25+70 C 25+70 C 25+70 C 25+70 C High-pressure
500 Hz 350 Hz 400 Hz 15 Hz 15 Hz sensors
Yellow LED Yellow LED Yellow LED Yellow LED Yellow LED Strokemaster
sensors
IP 67 IP 67 IP 67 IP 67/1200 psi washdown IP 67/1200 psi washdown
Steelface
Pressure rated to 60 bar, Pressure rated to 80 bar Pressure rated to 80 bar Selective non-ferrous Selective ferrous High
temperature
weld spatter-resistant (1,160 psi) (1,160 psi) sensors
Stainless steel, 316 L Stainless steel 303 Stainless steel 303 Stainless steel 303 Stainless steel 303 Harsh
PTFE coated environment
sensors
Stainless steel, 316 L Stainless steel 303 Stainless steel 303 Stainless steel 303 Stainless steel 303
PTFE coated Factor 1
sensors
Weld eld
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 immune
sensors
M12.1 M12x1 M12x1 M18x1 M18x1 Large
2.5
2.5
designs
Ring sensors
5
17 17 17 24 24 Tube sensors
Analog
42
42
41
41
50
50
49.5
distance
measurement
60
66
66
60
65
10.5 Accessories
LED LED
LED LED
LED
M12x1 M12x1 M12x1 M12x1
M12.1
www.balluff.com 667
Steelface sensors
M181

Rated switching distance sn 7.2 mm 7.2 mm 10 mm
PNP, NO Ordering code BES02NJ BES02NK BES02Y3
Part number BES M18EI-PSC72B-S04G-S BES M18EI-PSC72B-S04G-S01 BES M18EG1-PSC10Z-S04G-S11
NPN, NO Ordering code BES02NF BES02NH BES02Y2
Part number BES M18EI-NSC72B-S04G-S BES M18EI-NSC72B-S04G-S01 BES M18EG1-NSC10Z-S04G-S11
Approvals CE CE CE
Special properties Pressure rated to 40 bar Pressure rated to 40 bar, weld Pressure rated to 60 bar
(580 psi) spatter-resistant (580 psi) (870 psi)
Material Housing Stainless steel 316 L Stainless steel, 316 L Stainless steel 303
PTFE coated
Sensing surface Stainless steel 316 L Stainless steel, 316 L Stainless steel 303
PTFE coated


24 24
49
49
available on request. 63.5

65
65
When using metal mounts, a reduction in the switching distance is

to be expected. You should check whether the clamping holder can
be used in the application. LED LED LED
M12x1 M12x1 M12x1

Steelface sensors
M181, M301.5, Flat Pack
M181 M301.5 M301.5 20x32x8 mm 20x32x8 mm

Non-ush Flush Flush Flush Flush
0...16.2 mm 0...6.5 mm 0...6.5 mm
2X 1X 1X Inductive
sensors
BES02Y1 BES02ZH BES02ZJ BES04AH BES049Y
BES M18EF1-PSC20F-S04G-S BES M30EG1-PSC80N-S04G-S BES M30EG1-PSC80S-S04G-S BES R01EC-PSC50A-BP00,3-GS04-W50 BES R01EC-PSC50A-BP00,3-GS04-W51 Global
BES02ZF DC 3-wire
BES M30EG1-NSC80S-S04G-S
DC 3-/4-wire
2V 2V 2V DC 2-wire
75 V DC 75 V DC 75 V DC
AC/DC 2-wire
200 mA 100 mA 100 mA 200 mA 200 mA
Yes/Yes/Yes Yes/No/Yes Yes/No/Yes Yes/Yes/Yes Yes/Yes/Yes AC 2-wire
25+70 C 25+70 C 25+70 C 0+50 C 0+50 C
Special
200 Hz 15 Hz 15 Hz 20 Hz 20 Hz properties
Yellow LED Yellow LED Yellow LED High-pressure
IP 67 IP 67 IP 67 IP 65 IP 65 sensors
CE CE CE CE, cULus CE, cULus Strokemaster
sensors
Pressure rated to 60 bar Selective non-ferrous Selective ferrous Steelface
(870 psi) sensors
Stainless steel 303 Stainless steel 303 Stainless steel 303 Stainless steel 303 Stainless steel 303 High
temperature
sensors
Stainless steel 303 Stainless steel 303 Stainless steel 303 Stainless steel 303 Stainless steel with Harsh
W51 ceramic coating environment
sensors
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin 0.3 m PUR cable, 0.3 m PUR cable,
M12 connector, 3-pin LED M12 connector, 3-pin LED Factor 1
sensors
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 Weld eld
immune
8.0 8.0 sensors
M18x1 M30x1.5 M30x1.5 20.0 20.0
Large
2.5
2.5
designs
7
36 36 Ring sensors
32.0
32.0
3.0
3.0
3.3
3.3
24 Tube sensors
40
40
50
50
42
66
66
Analog
63.5
LED LED 13.0 13.0 distance

5
5
2.
2.
measurement
R
LED D D Accessories
M12x1 M12x1
M12x1
max. 49
max. 49
M12x1 M12x1
max. 15 max. 15
www.balluff.com 669
Inductive Sensors with Special Properties High temperature
High temperature sensors
M50.5, M81, M121 sensors
Housing size M50.5 M8 1 M8 1 M121

Installation type (observe instructions in the Basic Information chapter) Flush Flush Flush Flush
Rated switching distance sn 0.5 mm 1 mm 2 mm 2 mm
Assured switching distance sa 0...0.4 mm 0...0.8 mm 0...1.6 mm 0...1.6 mm
Sensing distance 1X 1X 2X 1X
PNP, Ordering code BES02J2 BES02HP BES02HK BES02HU
NO Part number BES M05ED-PSD05B-ES02-T01 BES 516-324-SA8-02 BES 516-324-SA26-02 BES 516-325-SA19-03
Part number BES 516-329-SA14-AO-X-03
NPN, com- Ordering code
plementary Part number
Supply voltage UB 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
Voltage drop Ud at Ie max. 1V 1.5 V 1.5 V PNP 1.8 V, NPN 1.5 V
Rated insulation voltage Ui 75 V DC 75 V DC 75 V DC 75 V DC
Rated operating current Ie 150 mA (g. 1) 200 mA (g. 2) 200 mA (g. 3) 200 mA (g. 3)
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes Yes/No/No Yes/No/No Yes/No/No
Ambient temperature Ta 25+120 C 25+100 C 25+120 C 25+120 C
Switching frequency f max. 1 kHz 2 kHz 1.5 kHz 1 kHz
Degree of protection as per IEC 60529 IP 67 IP 67 IP 67, IP 68 according to BWN Pr. 20,
IP 60 cable outlet IP 60 cable outlet
Approvals CE CE CE CE
Material Housing Stainless steel Stainless steel Stainless steel Brass-coated
Sensing surface PA 6 PBT PBT PEEK
Connection 2 m silicon cable, 2 m PVC cable, 2 m Teon cable, 3 m silicon cable,
26 AWG 26 AWG 26 AWG 20 AWG
Pressure rated to 3 bar

Additional cable lengths and PUR cable

Temperature rated sensors to +120 C

More and more industrial processes are running at higher
temperatures. This increases the demands on the sensors. BES 516-325-SA19-
Balluff high temperature sensors are ideal for your high
temperature application.
Applications BES 516-329-SA14-A0-X-

Steel production
Motor function monitoring
Glass manufacturing

M181, M301.5, 255010 mm
M181 M181 M301.5 M301.5 255010 mm

Flush Flush Flush Non-ush Flush
5 mm 5 mm 10 mm 15 mm 5 mm
0...4.1 mm 0...4.1 mm 0...8.1 mm 0...12.2 mm 0...4.1 mm
BES02H6 BES02H5 BES02H7 BES02HE BES02J0 sensors
BES 516-105-SA5 BES 516-105-SA2-05 BES 516-114-SA1-05 BES 516-125-SA1-05 BES 516-347-SA2-03 Global
DC 3-wire
DC 3-/4-wire
BES02HC
BES 516-120-SA2 DC 2-wire
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 24 V DC 10 %
AC/DC 2-wire
1.5 V 1.5 V 1.5 V 1.5 V 2.5 V
400 mA (g. 4) 400 mA (g. 4) 400 mA (g. 4) 400 mA (g. 4) 25 mA
Yes/No/No Yes/No/No Yes/No/No Yes/No/No Yes/Yes/Yes Special
properties
IP 67 IP 67, IP 67, IP 67, IP 67, Strokemaster
sensors
IP 60 cable outlet IP 60 cable outlet IP 60 cable outlet IP 60 cable outlet
Steelface
Brass-coated Brass-coated Brass-coated Brass-coated Cast aluminum High
PBT PBT PBT PA 12 PBT temperature
sensors
M12 plug connector, 5 m silicon cable, Silicon cable, 5 m silicon cable, 3 m silicon cable, Harsh
4-pin 19 AWG 19 AWG 19 AWG 19 AWG environment
sensors
BCC M415-0000-1A-003-EX44T2-020
Factor 1
sensors
Weld eld
immune
sensors
Large
designs
Ring sensors
Tube sensors
Analog
distance
measurement
Accessories
Current reduction as a function of ambient temperature range
150 mA Fig. 1 200 mA Fig. 2 200 mA Fig. 3 400 mA Fig. 4
45 mA 100 mA 100 mA 150 mA
25 C +50 C +120 C 25 C +70 C +100 C 25 C +70 C +120 C 25 C +70 C +120 C
www.balluff.com 671
Inductive Sensors with Special Properties High temperature
sensors
Balluffs ultra-high temperature inductive sensors can be used in

temperature ranges up to +160 C. These sensors are ideally suited
to harsh environments in the steel industry, in plastic injection mold-
ing machines and in forging and foundry processes.
Optimization of system availability

Reduction in maintenance costs Housing size
Increase in process quality Installation type (observe instructions in the Basic Information chapter)
Sensing distance
Part number
Supply voltage UB
Approvals
Material Housing
Sensing surface
Connection



M181, M301.5
160 C 160 C 160 C 160 C

High High High High
temperature temperature temperature temperature
range range range range
M181 M181 M301.5 M301.5
Flush Non-ush Flush Non-ush
5 mm 8 mm 10 mm 15 mm
0...4 mm 0...6.4 mm 0...8 mm 0...12 mm
BES043T BES043U BES043W BES043Y sensors
BES 515-326-SA49-D-TF-02 BES 515-360-SA13-D-TF-02 BES 515-327-SA22-D-TF-02 BES 515-362-SA4-D-TF-02 Global
2.5 V 2.5 V 2.5 V 2.5 V
DC 3-/4-wire
75 V DC 75 V DC 75 V DC 75 V DC
200 mA 200 mA 200 mA 200 mA DC 2-wire
Yes/No/No Yes/No/No Yes/No/No Yes/No/No
AC/DC 2-wire
25...+160 C 25...+160 C 25...+160 C 25...+160 C
200 Hz 200 Hz 200 Hz 200 Hz AC 2-wire
IP 69K IP 69K IP 69K IP 69K
CE CE CE CE Special
properties
Stainless steel Stainless steel Stainless steel Stainless steel High-pressure
PEEK PEEK PEEK PEEK sensors
2 m cable FEP, 22 AWG 2 m cable FEP, 22 AWG 2 m cable FEP, 22 AWG 2 m cable FEP, 22 AWG Strokemaster
sensors
Steelface
M18x1 M18x1 M30x1.5 M30x1.5
sensors
High
temperature
sensors
Harsh
environment
sensors
65
75
60
85
36 Factor 1
95
100
68
36 sensors
80
88
110
24 24
95
Weld eld
103
immune
sensors
Large
designs
Ring sensors
Tube sensors
Analog
distance
measurement
Accessories
Rated operating current
200
50
25 C +40 C +160 C
www.balluff.com 673
Inductive Sensors with Special Properties PROXINOX
Harsh environment sensors
M12x1 standard
Increased
temperature
range
PNP, NO Ordering code BES02EL BES02EH BES02FU
Part number BES 515-325-S4-C BES 515-325-BO-C-PU-03 BES M12EI-PSC40B-S04G
PNP, NC Ordering code BES02FT
Part number BES M12EI-POC40B-S04G
NPN, NO Ordering code BES02FR
Part number BES M12EI-NSC40B-S04G
Sensing surface PA 12 PA 12 LCP
Connection M12 connector, 4 pin 3 m PUR cable, 22 AWG M12 connector, 4-pin


Built tough stainless steel housing stops aggressive media

in its tracks. Inductive sensors are also used more and more in ag-
gressive environments: in machine tools, in the chemical industry, in
packaging machines- and the food industry. POXINOX sensors are
ideal for applications where aggressive cleaning agents, in connec-
tion with high-pressure cleaning devices are used.

M12x1 standard
Increased
temperature
range
M121 M121 M121 M121 M121
0...3.2 mm 0...3.2 mm 0...3.2 mm 0...3.2 mm 0...3.2 mm
BES038C BES014W BES02FC BES02F3 BES02F7 sensors
BES M12EI-PSC40B-S04G-009 BES M12EE-PSC40B-S04G BES 515-356-S4-C BES 515-356-BO-C-03 BES 515-356-E4-C-03 Global
BES014U DC 3-wire
BES M12EE-POC40B-S04G
DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
2.5 V 2V 1.5 V 1.5 V 2V
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) AC 2-wire
200 mA 200 mA 200 mA 200 mA 200 mA
properties
2 kHz 2 kHz 1.5 kHz 1.5 kHz 2 kHz sensors
Yellow LED Yellow LED Yellow LED Yellow LED Yellow LED Strokemaster
sensors
IP 67 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20
Steelface
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus sensors
Stainless steel Stainless steel Stainless steel Stainless steel Stainless steel High
LCP LCP PA 12 PA 12 PBT temperature
sensors
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin 3 m PVC cable, 22 AWG 3 m PVC cable, 22 AWG Harsh
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 environment
sensors
Factor 1
M12x1 sensors
Weld eld
immune
17 sensors
5
Large
34.5
37.5
designs
Ring sensors
Tube sensors
Analog
distance
LED measurement
Accessories
www.balluff.com 675
M18x1
Increased
temperature
range
PNP, NO Ordering code BES02EU BES02EN BES02H0
Part number BES 515-326-S4-C BES 515-326-BO-C-PU-03 BES M18EI-PSC80B-S04G
PNP, NC Ordering code BES02FZ
Part number BES M18EI-POC80B-S04G
Sensing surface PA 12 PA 12 PBT


50
50
58
65
73
83
11
LED
M12x1

M181, M301.5
Increased
temperature
range
M181 M181 M301.5 M301.5
Non-ush Non-ush Flush Non-ush
8 mm 8 mm 10 mm 15 mm
0...6.5 mm 0...6.5 mm 0...8.1 mm 0...12.2 mm
BES02FL BES02FH BES02F1 BES02FN sensors
BES 515-360-S4-C BES 515-360-BO-C-PU-03 BES 515-327-S4-C BES 515-362-S4-C Global
DC 3-wire
DC 3-/4-wire
1030 V DC 1030 V DC 1030 V DC 1030 V DC
1.5 V 1.5 V 2.5 V 2.5 V DC 2-wire
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([)
AC/DC 2-wire
200 mA 200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC 2-wire
40+85 C 25+70 C 25+70 C 25+70 C
properties
Yellow LED Yellow LED Yellow LED Yellow LED High-pressure
IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 IP 68 per BWN Pr. 20 sensors
CE, cULus CE, cULus CE, cULus CE, cULus Strokemaster
sensors
Steelface
PA 12 PA 12 PA 12 PA 12 sensors
M12 connector, 4-pin 3 m PUR cable, 22 AWG M12 connector, 4-pin M12 connector, 4-pin High
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 temperature
sensors
Harsh
environment
sensors
Factor 1
sensors
Weld eld
immune
sensors
Large
designs
Ring sensors
Tube sensors
Analog
distance
M12x1
measurement
Accessories
www.balluff.com 677
PROXINOX sensors withstand the harshest cleaning

processes
In the food- and beverage industry, the chemical industry, and even
conveying operations, inductive sensors are routinely cleaned with
more and more aggressive methods. Whether acids, bases, steam,
foaming cleaners or high-pressure cleaners PROXINOX-stainless
steel sensors fulll stringent requirements. Housing size
Features Rated switching distance sn
No function indicator directly on the sensor: The drill hole for the Assured switching distance sa
LED is a potential source of danger during cleaning processes Sensing distance
and a possible means of entry for bacteria. The function display is PNP, NO Ordering code
completely wrapped in the transparent plastic of the connector. Part number
Housing made of stainless steel (material 1.4571): This material is Supply voltage UR
common in the food and beverage- industry. The cable plug has Voltage drop Ud at Ie max.
to be adapted to different cleaning and- disinfection agents. Rated insulation voltage Ui (protection class)
Gold-coated contacts: The difcult installation relationships re- Rated operating current Ie
quire gold-coated contacts, so that plug corrosion is prevented. Polarity reversal protected/transposition protected/short-circuit protected
Lasered or etched part number: Cleaning- and disinfection pro- Ambient temperature Ta
cesses dissolve type plates. Lasered or etched part numbers are Ambient temperature Ta at load current 20 mA
there to stay. Ambient temperature range Ta short-time 30 min
Additional O-ring-seals for extreme requirements: temperature Switching frequency f max.
shocks triggered by cleaning and disinfection cause strong, Degree of protection as per IEC 60529
different residual stress on steel housings and casting resin.
Approvals
Material Housing
Sensing surface
Connection
Steam jet tested Suggested mating cable


Current reduction as a function

of ambient temperature range
130 mA
20 mA
40C +70 C +85 C +105 C

M121, M181, M301.5
M121 M121 M181 M181 M301.5

Flush Non-ush Flush Non-ush Flush
0...1.6 mm 0...3.2 mm 0...4.1 mm 0...6.5 mm 0...8.1 mm
BES02EK BES02FA BES02ET BES02FK BES02F0 sensors
BES 515-325-E5-T-S4 BES 515-356-E5-T-S4 BES 515-326-E5-T-S4 BES 515-360-E5-T-S4 BES 515-327-E5-T-S4 Global
3.5 V 3.5 V 3.5 V 3.5 V 3.5 V
DC 3-/4-wire
130 mA 130 mA 130 mA 130 mA 130 mA DC 2-wire
AC/DC 2-wire
40+70 C 40+70 C 40+70 C 40+70 C 40+70 C
40+85 C 40+85 C 40+85 C 40+85 C 40+85 C AC 2-wire
+105 C +105 C +105 C +105 C +105 C
properties
IP 69K and IP 69K and IP 69K and IP 69K and IP 69K and High-pressure
IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 27 sensors
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus Strokemaster
sensors
Stainless steel 1.4571 Stainless steel 1.4571 Stainless steel 1.4571 Stainless steel 1.4571 Stainless steel 1.4571
Steelface
PEEK PEEK PA 12 PA 12 PA 12 sensors
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin High
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 temperature
sensors
Harsh
environment
sensors
Factor 1
sensors
Weld eld
immune
sensors
Large
designs
Ring sensors
Tube sensors
Analog
distance
measurement
Accessories
www.balluff.com 679
In the food industry, medical and pharmaceutical technology, and

special requirements are placed on sensors: FDA conformity and
testing according to the Ecolab standard.
The sensors fulll the highest requirements:

Extended temperature range
Safe to clean according to Ecolab
FDA conformity
Resistant to high-pressure cleaners
Steam jet tested

IP 69K IP 68 Stainless
Hresistant
2O2
as per BWN
steel

12 mm, M121
Housing size 12 mm M121 M121

Assured switching distance sa 0...1.6 mm 0...1.6 mm 0...3.2 mm Inductive
Sensing distance 1X 1X 1X sensors
PNP, NO Ordering code BES0430 BES0444 BES0433 Global
Part number BES G12EE1-PSY20B-S04G-L02 BES M12EE1-PSY20B-S04G-L01 BES M12EE-PSC40B-S04G-L01 DC 3-wire
DC 3-/4-wire
Part number BES M12EE-POC40B-S04G-L01
Supply voltage UB 10...30 V DC 10...30 V DC 10...30 V DC DC 2-wire
AC/DC 2-wire
Rated operating current Ie 130 mA* 130 mA* 200 mA AC 2-wire
Ambient temperature Ta 40...+105 C 40...+105 C 25...+85 C Special
properties
Switching frequency f max. 800 Hz 800 Hz 2000 Hz High-pressure
Degree of protection as per IEC 60529 IP 69K and IP 69K and IP 69K and sensors
IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 20 Strokemaster
sensors
Approvals CE, cULus, Ecolab, CE, cULus, Ecolab, CE, cULus, Ecolab,
Steelface
FDA compliant FDA compliant FDA compliant sensors
Material Housing Stainless steel 1.4571 Stainless steel 1.4571 Stainless steel 1.4404 High
Sensing surface PEEK PEEK LCP temperature
sensors
Connection M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin Harsh
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 environment
sensors
See technical section (page 963-966) Factor 1
12h9 sensors
Weld eld
For wiring diagram see page 958. immune
sensors
Additional cable lengths and PUR cable jacket material avail- Large
able on request. designs
50
Ring sensors
Tube sensors
Analog
7
distance
measurement
M12x1
Accessories
* Current decrease curve
130 mA
20 mA
40 C +70 C +85 C +105 C
www.balluff.com 681
12 mm, M121
Housing size M121 12 mm M121

Installation type (observe instructions in the Basic Information chapter) Flush Non-ush Non-ush
PNP, NO Ordering code BES0435 BES0431 BES0443
Part number BES M12EI-PSC40B-S04G-L01 BES G12EE1-PSY40F-S04G-L02 BES G12EE1-PSY40F-S04G-L01
Part number BES M12EI-POC40B-S04G-L01
Part number BES M12EI-NSC40B-S04G-L01
Rated operating current Ie 200 mA 130 mA* 130 mA*
Degree of protection as per IEC 60529 IP 69K and IP 69K and IP 69K and
IP 68 as per BWN Pr. 20 IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 27
Approvals CE, cULus, Ecolab, CE, cULus, Ecolab, CE, cULus, Ecolab,
FDA compliant FDA compliant FDA compliant
Material Housing Stainless steel 1.4404 Stainless steel 1.4571 Stainless steel 1.4571
Sensing surface LCP PEEK PEEK
See technical section (page 963-966) 12h9

10.6

5

54.5
* Current decrease curve

7
M12x1
130 mA
20 mA
40 C +70 C +85 C +105 C
IP 69K IP 68 Stainless
Hresistant
2O2
as per BWN
steel

18 mm, M181
18 mm M181 M181 18 mm M18 mm

Flush Flush Flush Non-ush Non-ush
0...4 mm 0...4 mm 0...6.4 mm 0...6.4 mm 0...6.4 mm
BES0439 BES0441 BES0437 BES043A BES0442 sensors
BES G18EE1-PSY50B-S04G-L02 BES M18EE1-PSY50B-S04G-L01 BES M18EI-PSC80B-S04G-L01 BES G18EE1-PSY80F-S04G-L02 BES M18EE1-PSY80F-S04G-L01 Global
BES0438 DC 3-wire
BES M18EI-POC80B-S04G-L01
DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
3.5 V 3.5 V 2.5 V 3.5 V 3.5 V
75 V DC 75 V DC 250 V AC ([) 75 V DC 75 V DC AC 2-wire
130 mA* 130 mA* 200 mA 130 mA* 130 mA*
properties
40...+105 C 40...+105 C 40...+85 C 40...+105 C 40...+105 C High-pressure
IP 69K and IP 69K and IP 69K and IP 69K and IP 69K and Strokemaster
sensors
IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 20 IP 68 as per BWN Pr. 27 IP 68 as per BWN Pr. 27
Steelface
CE, cULus, Ecolab, CE, cULus, Ecolab, CE, cULus, Ecolab, CE, cULus, Ecolab, CE, cULus, Ecolab, sensors
FDA compliant FDA compliant FDA compliant FDA compliant FDA compliant High
temperature
Stainless steel 1.4571 Stainless steel 1.4571 Stainless steel 1.4404 Stainless steel 1.4571 Stainless steel 1.4571 sensors
PEEK PEEK PEEK PEEK PEEK Harsh
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin environment
sensors
Factor 1
sensors
18h9 M18x1 18h9 Weld eld
16.5 immune
sensors
Large
designs
10
30
24 Ring sensors
45
50
Tube sensors
65
29.5
54.5
Analog
distance
measurement
M12x1
11
LED
Accessories
M12x1 M12x1
www.balluff.com 683
Factor 1
Factor 1 sensors identify objects, such as those made of steel, alu-

minum or brass, with identical switching distances (without reduction
factor). These properties provide advantages in applications in which
the material of the objects to be detected can vary, or non-ferrous
metal can be detected with a high switching distance.
Moreover, all Factor 1-sensors are magnetic eld immune. Their
function is not impaired by strong electromagnetic elds (commonly
found in welding applications). Factor 1-sensors are not inuenced
in their switching behavior by welding currents up to 25 kA (at a
distance from the current conductor of approx. 5 cm).
Comparison of sensor types/switching distances
Switching distance
Aluminum
Brass
Copper
Nickel
Steel
Standard-sensor
Factor 1-sensor (F1)

Factor 1
M8 1
Rated switching distance sn 1.5 mm 1.5 mm 2 mm
PNP, NO Ordering code BES02YR BES02YT BES03YP sensors
Part number BES M08EG-PSC15A-S49G-W BES M08EG1-PSC15A-S04G-W BES M08MG1-PSC20A-S04G-W Global
Supply voltage UB 1030 V DC 1030 V DC 1030 V DC DC 3-wire
DC 3-/4-wire
Rated insulation voltage Ui (protection class) 75 V DC 250 V AC ([) 75 V DC
Rated operating current Ie 150 mA 150 mA 100 mA DC 2-wire
AC/DC 2-wire
Switching frequency f max. 2 kHz 2 kHz 1 kHz AC 2-wire
Degree of protection as per IEC 60529 IP 67 IP 67 IP 67 Special
properties
Approvals CE CE CE High-pressure
Special properties Interference-proof Interference-proof Interference-proof sensors
against magnetic against magnetic against magnetic Strokemaster
sensors
AC and DC elds AC and DC elds AC and DC elds
Steelface
Material Housing Stainless steel, Stainless steel, Brass sensors
PTFE coated PTFE coated PTFE coated High
Sensing surface PBT, PTFE coated PBT, PTFE coated LCP, PTFE coated temperature
sensors
Suggested mating cable BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 environment
sensors
M81 sensors
Weld eld
sensors
Additional cable lengths and PUR cable jacket material Large
37
designs
40
40
13
Ring sensors
49
65
Tube sensors
Analog
10.5
distance
measurement
10.5
LED
Accessories
M121
www.balluff.com 685
Factor 1
M121

PNP, NO Ordering code BES01PZ BES02JZ BES02K3
Part number BES M12MF-PSC30A-S04G BES M12MF1-PSC30A-S04G-W BES M12ML-PSC30A-S04G-W
Part number
Approvals CE CE CE
Special properties Interference-proof Interference-proof Interference-proof
against magnetic against magnetic against magnetic
Material Housing Brass, Brass, Brass,
coated PTFE coated PTFE coated
Sensing surface LCP, PTFE coated LCP, PTFE coated LCP, PTFE coated

M12x1

36
50+2
50
LED
M12x1

Factor 1
M121
M121 M121 M121 M121 M121

0...2.2 mm 0...3.2 mm 0...6.5 mm 0...6.5 mm 0...6.5 mm
BES02K4 BES0452 BES01PW BES02JW sensors
BES M12ML-PSC30A-S04G-W01 BES M12MG-PSC40A-S04G-W12 BES M12MD-PSC80E-S04G BES M12MD1-PSC80E-S04G-W Global
BES02YU DC 3-wire
BES M12MD1-NSC80E-S04G
DC 3-/4-wire
2.5 V 3V 2.5 V 2.5 V 2.5 V DC 2-wire
250 V AC ([) 60 V DC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([)
AC/DC 2-wire
200 mA 200 mA 200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC 2-wire
25+70 C 25+70 C 25+70 C 25+70 C 25+70 C
2 kHz 2 kHz 2 kHz 2 kHz 2 kHz Special
properties
Yellow LED Yellow LED Yellow LED Yellow LED Yellow LED High-pressure
CE CE CE CE CE Strokemaster
sensors
Interference-proof Interference-proof Interference-proof Interference-proof Interference-proof
Steelface
against magnetic against magnetic against magnetic against magnetic against magnetic sensors
AC and DC elds AC and DC elds AC and DC elds AC and DC elds AC and DC elds High
Brass, Brass, Brass, Brass, Brass, temperature
sensors
PTFE coated PTFE coated coated PTFE coated coated Harsh
Ceramic coating PPS LCP, PTFE coated LCP, PTFE coated PA 12 environment
sensors
Factor 1
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin sensors
immune
sensors
M121 M12x1 M12x1
Large
designs
Ring sensors
10
10
17 17 Tube sensors
36
36
17
39
Analog
50+2
50
distance
56
measurement
10.5 LED Accessories

LED
11.5
LED
M12x1 M12x1
M121
www.balluff.com 687
Factor 1
M121, M181

Installation type (observe instructions in the Basic Information chapter) Non-ush Non-ush Flush
Assured switching distance sa 0...6.5 mm 0...6.3 mm 0...4 mm
PNP, NO Ordering code BES02K5 BES02K6 BES01R3
Part number BES M12ML-PSC80E-S04G-W BES M12ML-PSC80E-S04G-W01 BES M18MF-PSC50A-S04G
Approvals CE CE CE
PTFE coated PTFE coated coated
Sensing surface LCP, PTFE coated Ceramic coating LCP, PTFE coated


24
35
50
LED
M12x1

Factor 1
M181
M181 M181 M181 M181 M181

0...4 mm 0...4 mm 0...3.9 mm 0...4 mm 0...6.4 mm
BES02K9 BES02KJ BES02KK BES01R1 BES03YT sensors
BES M18MF1-PSC50A-S04G-W BES M18ML-PSC50A-S04G-W BES M18ML-PSC50A-S04G-W01 BES M18EL-PSH50A-S04G BES M18MG-PSC80A-S04G-W Global
2.5 V 2.5 V 2.5 V 2V 3V
DC 3-/4-wire
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) 60 V DC ([)
AC/DC 2-wire
25+70 C 25+70 C 25+70 C 25+70 C 25+70 C
2.5 kHz 2.5 kHz 2.5 kHz 600 Hz 350 Hz AC 2-wire
properties
CE CE CE CE CE High-pressure
Interference-proof Interference-proof Interference-proof Interference-proof Interference-proof sensors
against magnetic against magnetic against magnetic against magnetic against magnetic Strokemaster
sensors
AC and DC elds AC and DC elds AC and DC elds AC and DC elds AC and DC elds
Steelface
Brass, Brass, Brass, Stainless steel Brass, sensors
PTFE coated PTFE coated PTFE coated PTFE coated High
LCP, PTFE coated LCP, PTFE coated Ceramic coating LCP PPS temperature
sensors
Harsh
sensors
Factor 1
sensors
M181 Weld eld
immune
sensors
Large
designs
35+1
24 Ring sensors
50+2
50
66
Tube sensors
Analog
distance
measurement
LED
11
7
Accessories
M121
www.balluff.com 689
Factor 1
M181

Installation type (observe instructions in the Basic Information chapter) Flush Non-ush Non-ush
PNP, NO Ordering code BES03YU BES01R2 BES02K7
Part number BES M18MI-PSC80A-S04G-W BES M18MD-PSC12E-S04G BES M18MD-PSC12E-S04G-W
Part number
Rated insulation voltage Ui (protection class) 60 V DC ([) 250 V AC ([) 250 V AC ([)
Switching frequency f max. 600 Hz 2.5 kHz 2.5 kHz
Approvals CE CE CE
PTFE coated coated PTFE coated
Sensing surface PPS LCP, PTFE coated LCP, PTFE coated


40
56
LED
11
M12x1

Factor 1
M181
M181 M181 M181 M181

Non-ush Non-ush Non-ush Quasi-ush
12 mm 12 mm 12 mm 12 mm
0...9.7 mm 0...9.5 mm 0...10.8 mm 0...9.7 mm
BES02KF BES02KH BES03YW sensors
BES M18ML-PSC12E-S04G-W BES M18ML-PSC12E-S04G-W01 BES M18MG-PSC12A-S04G-W Global
BES01R0 DC 3-wire
BES M18EL-POC12E-S04G
DC 3-/4-wire
1030 V DC 1030 V DC 1030 V DC 1030 V DC
2.5 V 2.5 V 2V 3V DC 2-wire
250 V AC ([) 250 V AC ([) 250 V AC ([) 60 V DC ([)
AC/DC 2-wire
200 mA 200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC 2-wire
25+70 C 25+70 C 25+70 C 25+70 C
2.5 kHz 2.5 kHz 300 Hz 600 Hz Special
properties
Yellow LED Yellow LED Yellow LED Yellow LED High-pressure
CE CE CE CE Strokemaster
sensors
Interference-proof Interference-proof Interference-proof Interference-proof
Steelface
against magnetic against magnetic against magnetic against magnetic sensors
AC and DC elds AC and DC elds AC and DC elds AC and DC elds High
temperature
Brass, Brass, Stainless steel Brass, sensors
PTFE coated PTFE coated PTFE coated Harsh
LCP, PTFE coated Ceramic coating LCP PPS environment
sensors
Factor 1
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin sensors
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 Weld eld
immune
sensors
M18x1
Large
designs
Ring sensors
Tube sensors
40
24
Analog
56
distance
measurement
LED Accessories
11
M12x1
www.balluff.com 691
Factor 1
M301.5

Installation type (observe instructions in the Basic Information chapter) Flush Flush Non-ush
Assured switching distance sa 0...8.1 mm 0...12.1 mm 0...16 mm
PNP, NO Ordering code BES02KM BES0454 BES02KP
Part number BES M30ML-PSC10A-S04G-W BES M30MI-PSC15A-S04G-W12 BES M30ML-PSC20E-S04G-W
Part number
Voltage drop Ud at Ie max. 2.5 V 3V 2.5 V
Rated insulation voltage Ui (protection class) 250 V AC ([) 60 V DC ([) 250 V AC ([)
Switching frequency f max. 600 Hz 250 Hz 1 kHz
Output function/power-on indicator Yellow LED/No Yellow LED/No Yellow LED/No
Approvals CE CE CE
PTFE coated PTFE coated PTFE coated
Sensing surface LCP, PTFE coated LCP, PTFE coated LCP, PTFE coated

Suggested maitng cable BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020

for installation instructions. M301.5

36 36
50.5

50.5
66.5
65
LED
11
LED
M12x1 M121

Flush 80 mm
120 mm non-ush

Factor 1
M301.5, 4040 mm Unicompact
M301.5 4040 mm 4040 mm

Non-ush Flush Flush
20 mm 15 mm 15 mm
0...16 mm 0...11.9 mm 0...11.9 mm
2X 1X 1X Inductive
BES03MZ BES021P BES021T sensors
BES M30ML-PSC20E-S04G-W01 BES Q40KFU-PSC15A-S04G BES Q40KFU-PSC15A-S04G-W01 Global
BES022K BES0214 DC 3-wire
BES Q40KFU-PAC15A-S04G BES Q40KFU-PAC15A-S04G-W01
DC 3-/4-wire
1030 V DC 1030 V DC 1030 V DC
2.5 V 2.5 V 2.5 V DC 2-wire
250 V AC ([) 250 V AC ([) 250 V AC ([)
AC/DC 2-wire
200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC 2-wire
25+70 C 25+70 C 25+70 C
1 kHz 400 Hz 400 Hz Special
properties
Yellow LED/No Green LED/Yellow LED Green LED/Yellow LED High-pressure
CE CE CE Strokemaster
sensors
Interference-proof Interference-proof against magnetic Interference-proof against magnetic
Steelface
against magnetic AC and DC elds AC and DC elds sensors
AC and DC elds High
temperature
Brass, PBT PBT, sensors
PTFE coated ceramic coating Harsh
Ceramic coating PBT PBT, environment
sensors
ceramic coating
Factor 1
Fig. 1...8 Fig. 1...8 sensors
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin Weld eld
immune
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 sensors
Large
designs
Ring sensors
Tube sensors
Analog
distance
measurement
Accessories
www.balluff.com 693
Factor 1
4040 mm Unicompact

Installation type (observe instructions in the Basic Information chapter) Flush Non-ush
PNP, NO Ordering code BES021U
Part number BES Q40KFU-PSC20A-S04G
PNP, complementary Ordering code BES0216 BES021A
Part number BES Q40KFU-PAC20A-S04G BES Q40KFU-PAC25E-S04G
Output function/power-on indicator Green LED/Yellow LED Green LED/Yellow LED
Approvals CE CE
Special properties Interference-proof against magnetic Interference-proof against magnetic
AC and DC elds AC and DC elds


Row mounting
Flush 80 mm
120 mm non-ush Permissible installation options

Factor 1
4040 mm Unicompact
4040 mm 4040 mm 4040 mm

35 mm 35 mm 40 mm
0...28.4 mm 0...28.1 mm 0...32.4 mm
1X 1X 2X Inductive
BES0220 BES0221 BES0223 sensors
BES Q40KFU-PSC35E-S04G BES Q40KFU-PSC35E-S04G-W01 BES Q40KFU-PSC40E-S04G Global
BES021H BES021K DC 3-wire
BES Q40KFU-PAC35E-S04G BES Q40KFU-PAC35E-S04G-W01
DC 3-/4-wire
1030 V DC 1030 V DC 1030 V DC
2.5 V 2.5 V 2.5 V DC 2-wire
250 V AC ([) 250 V AC ([) 250 V AC ([)
AC/DC 2-wire
200 mA 200 mA 200 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes AC 2-wire
10+70 C 10+70 C 10+70 C
250 Hz 250 Hz 100 Hz Special
properties
Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED High-pressure
CE CE CE Strokemaster
sensors
Interference-proof against magnetic Interference-proof against magnetic Interference-proof against magnetic
Steelface
AC and DC elds AC and DC elds AC and DC elds sensors
PBT PBT, ceramic coating PBT High
temperature
PBT PBT, ceramic coating PBT sensors
Fig. 3...8 Fig. 4...8 Fig. 4...8 Harsh
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin environment
sensors
Factor 1
sensors
Weld eld
immune
sensors
Large
designs
Ring sensors
Tube sensors
Analog
distance
measurement
Accessories
www.balluff.com 695
Inductive Sensors with Special Properties Weld eld
Weld eld immune sensors/Factor 1
immune/Factor 1
Weld-immune sensors
for rough industrial applications
Magnetic eld immune: Insensitive to magnetic elds which are

created from electrical weld currents up to 25 kA (at a distance
to the current conductor of approx. 5 cm).
Weld spatter-resistant: Resistant to weld slag which is created

during welding processes.
Factor 1: Identical switching distance with metals such as steel,

stainless steel, aluminum or brass.
Magnetic eld
Current - Magnetic eld immune

conductor sensor
Error-free function depends on the magnitude of the welding

current and the distance of the sensor from the current carrying
line. Through constructive and switching technological measures,
magnetic eld immune sensors are not inuenced by magnetic
elds.

Weld eld immune sensors
M121

Assured switching distance sa 1.6 mm 1.6 mm 1.6 mm
PNP, NO Ordering code BES02J6 BES02J5 BES02J7 sensors
Part number BES 516-325-S4-W BES 516-325-S4-CW BES 516-325-S4-WR Global
Supply voltage UB 1030 V DC 1030 V DC 1030 V DC DC 3-wire
DC 3-/4-wire
Rated operating current Ie 200 mA 200 mA 200 mA DC 2-wire
AC/DC 2-wire
Switching frequency f max. 1 kHz 1 kHz 1 kHz AC 2-wire
Degree of protection as per IEC 60529 IP 67 IP 67 IP 67 Special
properties
Approvals CE CE CE High-pressure
Special properties Interference-proof Interference-proof Interference-proof sensors
against magnetic against magnetic against magnetic Strokemaster
sensors
Steelface
Material Housing Brass, Stainless steel, Stainless steel sensors
PTFE coated PTFE coated High
temperature
Sensing surface LCP, PTFE coated PTFE Ceramic sensors
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 environment
sensors
M12x1 sensors
Weld eld
17 sensors
designs
40
Ring sensors
61
Tube sensors
Analog
distance
LED measurement
M12x1
Accessories
www.balluff.com 697
Weld eld immune sensors/ Factor 1
M121 immune/Factor 1
Housing size M121 M121 M121 M121

Installation type (observe instructions Flush Flush Flush Non-ush
in the Basic Information chapter)
Rated switching distance sn 3 mm 3 mm 3 mm 4 mm
Assured switching distance sa 2.2 mm 2.4 mm 2.2 mm 3.2 mm
Sensing distance 2X 2X 2X 1X
PNP, NO Ordering code BES02K0 BES02K1 BES02K2 BES02JN
Part number BES M12MF1-PSC30A-S04G-W01 BES M12MI-PSC30B-S04G-W BES M12MI-PSC30B-S04G-W01 BES 516-356-S4-W
Supply voltage UB 1030 V DC 1030 V DC 1030 V DC 1030 V DC
Voltage drop Ud at Ie max. 2.5 V 2.5 V 2.5 V 2.5 V
Rated insulation voltage Ui 250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([)
(protection class)
Rated operating current Ie 200 mA 200 mA 200 mA 200 mA
Polarity reversal protected/transposition Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes
protected/short-circuit protected
Ambient temperature Ta 25+70 C 5+60 C 5+60 C 25+70 C
Switching frequency f max. 2 kHz 300 Hz 300 Hz 1 kHz
Output function indicator Yellow LED Yellow LED Yellow LED Yellow LED
Degree of protection as per IEC 60529 IP 67 IP 67 IP 67 IP 67
Approvals CE CE CE CE
Special properties Interference-proof Interference-proof Interference-proof Interference-proof
against magnetic against magnetic against magnetic against magnetic
AC and DC elds AC and DC elds AC and DC elds AC and DC elds
Material Housing Brass, Brass, Brass, Stainless steel,
PTFE coated PTFE coated PTFE coated PTFE coated
Sensing surface Ceramic coating LCP, PTFE coated Ceramic coating PTFE
Connection M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020
See technical section

(page 963-966)
Additional cable lengths and

50+2
PUR cable jacket material


Weld eld immune sensors
M121, M181
M121 M181 M181 M181 M181

6.3 mm 3.2 mm 3.9 mm 4 mm 4 mm Inductive
2X 1X 1X 1X 1X sensors
BES02JY BES03MY BES02KA BES02JA BES02JC
Global
BES M12MD1-PSC80E-S04G-W01 BES M18MI-PSC40B-S04G-W03 BES M18MF1-PSC50A-S04G-W01 BES 516-326-S4-W BES 516-326-S4-WR DC 3-wire
DC 3-/4-wire
2.5 V 2.5 V 2.5 V 1.5 V 2.5 V
250 V AC ([) 75 V DC ([) 250 V AC ([) 250 V AC ([) 75 V DC DC 2-wire
200 mA 200 mA 200 mA 200 mA 200 mA AC/DC 2-wire

AC 2-wire
25+70 C 25+70 C 25+70 C 25+70 C 25+70 C Special

properties
2 kHz 50 Hz 2.5 kHz 500 Hz 100 Hz
High-pressure
Yellow LED Yellow LED Yellow LED Yellow LED Yellow LED sensors
IP 67 IP 67 IP 67 IP 67 IP 67 Strokemaster
Interference-proof Interference-proof Interference-proof Interference-proof Interference-proof Steelface
sensors
against magnetic against magnetic against magnetic against magnetic against magnetic High
AC and DC elds AC and DC elds AC and DC elds AC and DC elds AC and DC elds temperature
sensors
Brass, Brass, Brass, Brass, Brass,
Harsh
PTFE coated PTFE coated PTFE coated PTFE coated PTFE coated environment
Ceramic coating Ceramic coating Ceramic coating PTFE Ceramic sensors
Factor 1
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin sensors
immune
sensors
M18x1 Large
designs
Ring sensors
Tube sensors
35+1
Analog
50+2
24 distance
50
measurement
65
Accessories
11.8
LED
M12x1
M12x1
www.balluff.com 699
M181 immune/Factor 1

Installation type (observe instructions in the Basic Information chapter) Flush Flush Non-ush
Assured switching distance sa 5.6 mm 5.5 mm 6.4 mm
PNP, NO Ordering code BES02KC BES02KE BES02JR
Part number BES M18MI-PSC70B-S04G-W BES M18MI-PSC70B-S04G-W01 BES 516-360-S4-W
Approvals CE CE CE
PTFE coated PTFE coated PTFE coated
Sensing surface LCP, PTFE coated Ceramic coating PTFE



M181, M301.5
M181 M301.5 M301.5 M301.5 M301.5

12 mm 10 mm 10 mm 10 mm 13 mm
9.5 mm 8.1 mm 7.9 mm 8.1 mm 10.5 mm
BES02K8 BES02JJ BES02KN BES02JK BES02KL sensors
BES M18MD-PSC12E-S04G-W01 BES 516-327-S4-W BES M30ML-PSC10A-S04G-W01 BES 516-327-S4-WR BES M30MI-PSC13B-S04G-W Global
2.5 V 1.5 V 2.5 V 2.5 V 2.5 V
DC 3-/4-wire
250 V AC ([) 250 V AC ([) 250 V AC ([) 75 V DC 250 V AC ([)
AC/DC 2-wire
25+70 C 25+70 C 25+70 C 25+70 C 5+60 C
2.5 Hz 100 Hz 600 Hz 50 Hz 30 Hz AC 2-wire
properties
CE CE CE CE CE High-pressure
Interference-proof Interference-proof Interference-proof Interference-proof Interference-proof sensors
against magnetic against magnetic against magnetic against magnetic against magnetic Strokemaster
sensors
AC and DC elds AC and DC elds AC and DC elds AC and DC elds AC and DC elds
Steelface
Brass, Brass, Brass, Brass, Brass, sensors
PTFE coated PTFE coated PTFE coated PTFE coated PTFE coated High
temperature
Ceramic coating PTFE Ceramic coating Ceramic LCP, PTFE coated sensors
Harsh
sensors
Factor 1
sensors
M30x1.5 M30x1.5 Weld eld
immune
sensors
Large
36 36 designs
50.5
50.5
Ring sensors
65
65
Tube sensors
Analog
LED LED
distance
measurement
M12x1 M12x1
Accessories
M12x1
www.balluff.com 701
M301.5, 32208 mm R01 immune/Factor 1
Housing size M301.5 M301.5 32208 mm R01

Installation type (observe instructions in the Basic Information chapter) Flush Non-ush Flush
Assured switching distance sa 10.3 mm 12.2 mm 4 mm
PNP, NO Ordering code BES03F1 BES02JU BES02KW
Part number BES M30MI-PSC13B-S04G-W01 BES 516-362-S4-W BES R01ZC-PSC50B-BX05-W01
Output function/power-on indicator Yellow LED/No Yellow LED/No Green LED/Yellow LED
Approvals CE CE CE
Material Housing Brass, Brass, Cast zinc
PTFE coated PTFE coated
Sensing surface Ceramic coating PTFE Ceramic coating
Connection M12 connector, 4-pin M12 connector, 4-pin 5 m PUR cable

cross-linked, 24 AWG


36
50.5

65
LED
M12x1

4040 mm Unicompact
Housing size 404062 mm

Assured switching distance sa 32.4 mm
PNP, complementary Ordering code BES02JR sensors
Part number BES Q40KFU-PAC40E-S04G Global
Supply voltage UB 1030 V DC DC 3-wire

DC 3-/4-wire
Rated operating current Ie 200 mA DC 2-wire
AC/DC 2-wire
Switching frequency f max. 100 Hz AC 2-wire
Output function/power-on indicator Green LED/Yellow LED
Degree of protection as per IEC 60529 IP 67 Special
properties
Approvals CE High-pressure
Special properties Interference-proof sensors
against magnetic Strokemaster
sensors
AC and DC elds
Steelface
Material Housing PBT sensors
Sensing surface PBT High
temperature
Possible installation variations Fig. 3...8 sensors
Connection M12 connector, 4-pin Harsh
Suggested mating cable BCC M415-0000-1A-003-EX44T2-020 environment
sensors
sensors
Weld eld
sensors
available on request. designs
Ring sensors
Tube sensors
Analog
distance
measurement
Accessories

Flush 80 mm
120 mm non-ush
www.balluff.com 703
Large housing
Extended switching distance
Large Housing Sensors

Certain inductive sensor applications call for exceptionally long
sensing ranges. With their large-diameter sensing coils, Balluffs large
housing inductive sensors meet these requirements. Available in
round housing diameters from 80 mm to 163 mm and in rectangular
housing dimensions of 100x35X35 mm or 200x35x35 mm, with
sensing distances up to100 mm in some models. A choice of AC or
DC versions suit a wide range of control interface needs.
AC Long Range Pancake Style

DC Long Range Pancake Style
Bar Style

AC long range pancake style

Mounting non-ush non-ush
Rated operating distance Sn 35-105 mm 50-120 mm
AC Normally-open Ordering code BES02T0 BES02T5 Inductive
Part number BES IKN-S5-070-W-4-S BES IKO-S5-100-W-4-S sensors
AC Normally-closed Ordering code BES02T0 BES02T4 Global
Part number BES IKN-S5-070-W-4-O BES IKO-S5-100-W-4-O DC 3-wire
Nominal sensing distance Sn 70mm 100mm
DC 3-/4-wire
Adjustable range 35...105mm 50...120 mm
Supply voltage 15-350 Vdc, 20-260 Vac 85-140 Vac DC 2-wire
Supply frequency 45-65 Hz 45-65 Hz
AC/DC 2-wire
Target Steel, 1 mm thick Steel, 1 mm thick
Switching hysteresis 15% of Sn 15% of Sn AC 2-wire
Repeatability 5% of Sn 5% of Sn
Ambient temperature range -25 C...+70 C -25 C...+70 C Special
properties
Temperature drift 5% of Sn 10% of Sn High-pressure
Function display LED LED sensors
Current consumption minimum 5 mA 5 mA Strokemaster
sensors
Current consumption maximum 300 mA 500 mA
Steelface
Short-time load current maximum 1 A/100 msec 1 A/100 msec sensors
Short circuit protection yes yes High
temperature
Leakage current 1.5 ma @ 110 Vac 1.5 ma @ 110 Vac sensors
Voltage drop Vd 10 V at 5 mA load 10 V at 5 mA load Harsh
Overload protection yes yes environment
sensors
Housing material Makrolon Polyester Makrolon Polyester
Factor 1
Mounting type Surface mounting - 4 mounting holes Surface mounting - 4 mounting holes sensors
Protection class per DIN 40050 IP 67, NEMA 4, 4X, 6, 12, 13 IP 67, NEMA 4, 4X, 6, 12, 13 Weld eld
immune
Recommended connector BCC A313-0000-10-071-VX43W6-050 BCC A313-0000-10-071-VX43W6-050 sensors
Large
For wiring diagram see page 958. Pot LED designs
Ring sensors
68
4
These sensors are specically designed Tube sensors

for use in heavy industrial environments Analog
such as: 170 distance
measurement
Automotive Manufacturing 150
Steel Mills Accessories

Assembly and Fabrication Lines
Pipe and Rod Mills
150
170
Conveyors
Additional models may be available.

Refer to company website for details O5.3
www.balluff.com 705
Inductive Sensors with Special Properties Large Housing
DC long range pancake style
Extended switching distance
Housing size 100 mm 163 mm 120 x 80 x 30

Mounting non-ush non-ush non-ush
Rated operating distance Sn 70 mm 100 mm 50 mm
PNP Normally-open Ordering code BES02RW BES02T2 BES02T8
Part number BES IKN-K-070-P-1-S BES IKO-K-100-P-1-S BES IKRD-K-050-P-1-S
PNP Normally-closed Ordering code BES02T7
Part number BES IKRD-K-050-P-1-O
NPN Normally-open Ordering code BES02T1 BES02T6
Part number BES IKO-K-100-N-1-S BES IKRD-K-050-N-1-S
Rated operational voltage Ue 24 Vdc 24 Vdc 24 Vdc
Supply voltage UB 10...30 Vdc 10...30 Vdc 10...30 Vdc
Voltage drop Ud at le 2.5 V 2.5 V 2.5 V
Rated insulation voltage Ui 75 Vdc 75 Vdc 75 Vdc
Load current capacity 400 mA 500 mA 200 mA
Current consumption (closed/open) 25 mA / 12 mA 25 mA / 12 mA 25 mA / 12 mA
Protected against polarity reversal yes yes yes
Short circuit protected yes yes yes
Load capacitance 1 F 1 F 1 F
5% 5% 5%
Repeat accuracy R -25...+70C -25...+70C -25...+70C
Ambient temperature range Ta 80 Hz 100 Hz 100 Hz
Operating frequency f yes yes yes
Function indication IP 67* IP 67* IP 67*
Degree of protection per IEC 60529 plastic PBT plastic plastic
Housing material plastic PBT plastic plastic
Material of sensing face cable cable cable
Connection 3 x 22 AWG 3 x 22 AWG 3 x 22 AWG
* Meets IP67 when potentiometer Pot LED
30
cover screw is properly installed.
64

60
163
45
120
100
O9.7
LED Pot

3-wire DC, 2-wire AC
Long range bar style
Housing size 100 x 35 x 35 100 x 35 x 35 150 x 35 x 35 150 x 35 x 35

Mounting non-ush non-ush non-ush non-ush
Rated operating distance Sn 5...45 mm adjustable 30 mm factory set 5...45 mm adjustable 12 mm factory set
PNP Ordering code BES02TC BES02TE BES02TH BES02TK Inductive
sensors
Normally-open Part number BES IKU-011-P-1-S-S4-SA1 BES IKU-011.23-G-S4-SA2 BES IKU-015-23-G-S4 BES IKU-015.23-G-S4-SA1
Rated operational voltage 24 Vdc 24 Vdc 24 Vdc 24 Vdc Global
Supply voltage 10...30Vdc 10...30Vdc 10...30Vdc 10...30 Vdc DC 3-wire
Voltage drop at output 2.0 V 2.0 V 2.0 V 2.0 V
DC 3-/4-wire
Load current capacity 400 mA 400 mA 400 mA 400 mA
Reverse polarity protection yes yes yes yes DC 2-wire
Short circuit protected yes yes yes yes
AC/DC 2-wire
Ambient temperature range -25...+70C -25...+70C -25...+70C -25...+70C
Operating frequency (max.) 50 Hz 50 Hz 50 Hz 50 Hz AC 2-wire
Function indication yes yes yes yes
Degree of protection per IEC 60529 IP 65 IP 65 IP 65 IP 65 Special
properties
Housing material plastic plastic plastic plastic High-pressure
Sensing face material plastic plastic plastic plastic sensors
Connection connector connector connector connector Strokemaster
sensors
Recommended connector BCC M415-0000-1A-003-VX44T2-050 BCC M415-0000-1A-003-VX44T2-050
Steelface
sensors
For wiring diagram see page 958. 17.5 17.5 High
temperature
sensors
Harsh
environment
sensors
35
Factor 1
sensors
55
Weld eld
immune
sensors
Large
designs
Ring sensors
Tube sensors
45
Analog
distance
measurement
Accessories
15
35
35
www.balluff.com 707
Inductive Sensors with Special Properties Large
Large design
designs
Housing size 8067 mm

Assured switching distance sa 040.5 mm
Sensing distance 1X
PNP, NO Ordering code BES02RN
Part number BES IKJ-S-050-P-2-S-S4-C
Part number
Voltage drop Ud at Ie max. 2V
Output resistance Ra Open collector
Output function/power-on indicator Red LED/No
Approvals CE
Sensing surface PBT

Additional cable lengths and PUR cable jacket

material available on request.

Large designs
3535100 mm 3535300 mm 11011043 mm

30 mm (adjustable with teach-in key) 30 mm (adjustable) 70 mm (adjustable with teach-in key)
024.3 mm 024.3 mm 056.7 mm Inductive
sensors
1X 1X 1X
Global
DC 3-wire
BES02TF BES02TN BES02RU
DC 3-/4-wire
BES IKU-011T.28-G-S4 BES IKU-031.28-S4 BES IKN-070T.38-G-S4
1030 V DC 1030 V DC 1055 V DC DC 2-wire
2V 2V 2V
AC/DC 2-wire
75 V DC 75 V DC 75 V DC
Open collector Open collector Open collector
Yes/Yes/Yes Yes/Yes/No Yes/Yes/Yes Special
properties
25+70 C 25+70 C 0+70 C High-pressure
50 Hz 50 Hz 50 Hz sensors
Red LED/No Red LED/No Red LED/Green LED (1 LED with color change) Strokemaster
sensors
IP 65 IP 65 IP 67
Steelface
CE CE CE sensors
PVC PVC PBT High
temperature
PVC PVC PBT sensors
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin Harsh
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 environment
sensors
Factor 1
sensors
Sensing
surface
300 47 Weld eld

Sensing 290 35 LED
surface immune
sensors
Large
7
designs
35
7
Ring sensors
M12x1
25 4.2 Tube sensors

40
Analog
distance
measurement
Accessories
www.balluff.com 709
Inductive Sensors with Special Properties Ring sensors
Ring sensors
Housing size
Inside diameter dw
Minimum object size steel taper (St 37)
Target velocity max.
Part number
Supply voltage UB
Output function/power-on indicator
Approvals
Material Housing
Sensing surface
Connection

Pulse stretching
Installation in series: Installation in a stack:
Easy installation (since they can be mounted side-by-side and uni-

versally installed and can be stacked with a spacing of > 20 mm)
Very reliable (due to inductive sensor principle)
Optimal for detecting small parts (with integrated pulse extension,
permanently set)
Applications
Detection of nails, screws, welded studs, rivets, etc.
Eject monitoring
Part counting
Checking for wire breaks
Nail machines for creating pallets
Feed check in assembly technology
Blockage warning in feed hoses

Ring sensors, 356020 mm, 1158030 mm
356020 mm 356020 mm 356020 mm 1158030 mm

10.1 mm 15.1 mm 25.1 mm 45 mm
2 mm 3 mm 4 mm 9 mm
60 m/s 60 m/s 60 m/s 20 m/s Inductive
BES03JA BES03JC BES03JH BES02TJ sensors
BES IKVS-010.23-G-S4 BES IKVS-015.23-G-S4 BES IKVS-025.23-G-S4 BES IKV-045.23-G-Z-S4 Global
2V 2V 2V 2V
DC 3-/4-wire
75 V DC 75 V DC 75 V DC 75 V DC
400 mA 400 mA 400 mA 200 mA DC 2-wire
Open collector Open collector Open collector Open collector
AC/DC 2-wire
25+70 C 25+70 C 25+70 C 25+70 C AC 2-wire
16 Hz 16 Hz 16 Hz 16 Hz
Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Special
properties
IP 65 IP 65 IP 65 IP 65 High-pressure
CE CE CE CE sensors
PBT PBT PBT PBT Strokemaster
sensors
PVC PVC PVC PBT
Steelface
M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin sensors
High
temperature
BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 sensors
60 ms 60 ms 60 ms Can be set between 2.5250 ms Harsh
environment
35.0 35.0 35.0 sensors
10.1 15.1 25.1
Factor 1
sensors
Weld eld
immune
sensors
45
Large
designs
115
Ring sensors
60
60
60
65 Tube sensors
42.5
42.5
38
38
42.5
38
Analog
10
distance
measurement
.4
.4
.4
10
10
10
4
M121 Accessories
60
26.0 26.0 26.0
80
M121 M121 M121
6$
30
7,0(
20.0
20.0
20.0
16.0
16.0
16.0
11.0
11.0
11.0
LED
www.balluff.com 711
Inductive Sensors with Special Properties Ring Sensors
DC 3/4-wire ring sensors
Housing size 80 x 45 mm 80 x 45 mm
Mounting ush** ush
Rated operating distance Sn 10 mm 10 mm
PNP Normally-open Ordering code BES02U1
Part number BES IKV-K-010-PS-1-Y
PNP Normally-closed Ordering code BES02U0
Part number BES IKV-K-010-PO-1-Y
NPN Normally-open Ordering code BES02U8
Part number BES IKV-S4-010-NS-1-Y-TD
NPN Normally-closed Ordering code
Part number
Rated operational voltage Ue 24 Vdc 24 Vdc
Supply voltage UB 10...30 Vdc 10...30 Vdc
Voltage drop Ud at le 3.5 Vdc 2.0 Vdc
Load current capacity 200 mA 200 mA
Current consumption (closed/open) 12 mA 12 mA
Protected against polarity reversal yes yes
Short circuit protected yes yes
Repeat accuracy R 5% 5%
Ambient temperature range Ta -25... +70C -25... +70C
Operating frequency f 1000 Hz 4-400 Hz
Function indication yes yes
Degree of protection per IEC 60529 IP 65 IP 65
Housing material plastic plastic
Material of sensing face plastic plastic
Connection 3 x 20 AWG M12 connector, 4-pin
No. of wires x gauge
Recommended connector BCC M415-0000-1A-003-EX44T2-020

20
20
Standard cable length = 2 m PVC
Other cable lengths and jacket materials may be LED
available. Additional models may also exist. Refer to
45 45
company website for details.
** Flush mounting is possible when

adjusted for minimum sensing distance.
80
80
51.5
51.5
10 10
O4.5 33 O4.5 33
LED 6 Time Delay 6

Pot Adj. Pot

DC 3/4-wire ring sensors, 356020 mm, 1158030 mm
80 x 45 mm 80 x 45 mm 120 x 80 mm 115 x 80 mm
non-ush non-ush non-ush non-ush
25 mm 25 mm 45 mm 45 mm
BES02UY BES02TW BES02U7 BES02TY Inductive
BES IKV-K-025-PS-1-Y BES IKV-025.23-G-Z-S4 BES IKV-K-045-PS-1-Y BES IKV-045.23-G-Z-S4 sensors
BES02U3 BES02U6 Global
BES IKV-K-025-PO-1-Y BES IKV-K-045-PO-1-Y DC 3-wire
BES02UE BES02U5
DC 3-/4-wire
BES IKV-S4-025-NS-1-Y-TD BES IKV-K-045-NS-1-Y
BES02U2 DC 2-wire
BES IKV-K-025-NS-1-Y
AC/DC 2-wire
24 Vdc 24 Vdc 24 Vdc 24 Vdc
10...30 Vdc 10...30 Vdc 10...30 Vdc 18...30 Vdc AC 2-wire
3.5 Vdc 2.0 Vdc 3.5 Vdc 20 Vdc
200 mA 200 mA 400 mA 200 mA Special
properties
12 mA 12 mA 12 mA 12 mA High-pressure
yes yes yes yes sensors
yes yes yes yes Strokemaster
sensors
5% 5% 5% 5%
Steelface
-25... +70C -25... +70C -25... +70C -25... +70C sensors
1000 Hz 4-400 Hz 100 Hz yes High
temperature
yes yes yes IP 65 sensors
IP 65 IP 65 IP 65 plastic Harsh
plastic plastic plastic plastic environment
sensors
plastic plastic plastic M12 connector, 4-pin
Factor 1
3 x 20 AWG M12 connector, 4-pin 3 x 20 AWG sensors
BCC M415-0000-1A-003-EX44T2-020 Weld eld
immune
BCC M415-0000-1A-003-EX44T2-020 sensors
Large
designs
Sa LED
20
20
Ring sensors
Tube sensors
30
LED
45 Analog
45 Time distance
80 measurement
Accessories
80
80
4
51.5
25 5
51.5
25
33
115
33 O4.5
O4.5
65
Time Delay 6 60
LED 6 Pot
Pot Adj.
M12x1
10
7
M12x1
www.balluff.com 713
Inductive Sensors with Special Properties Tube sensors
Tube sensors, 1778.511.9 mm
Inductive tube sensors BES extend our line of ring sensors.

Optimized for tube infeeds in automated assembly, they detect small
parts easily and reliably.
Simple attachment to the infeed tube
Pulse extension of 150 ms results in a reliable detection of fast-
moving parts.
Object speed max. 20 m/s

Tube sensors, 1778.511.9 mm
Housing size 1778.511.9 mm 1778.511.9 mm

Minimum object size Screw M35 Screw M35
Assured switching distance sa 12.8 mm 12.8 mm Inductive
Sensing distance 1X 1X sensors
PNP, NO Ordering code BES0428 BES0429 Global
Part number BES Z06K-PSC16F-S49G BES Z06K-PSC16F-BP00,1-GS04 DC 3-wire
DC 3-/4-wire
Rated insulation voltage Ui 75 V DC 75 V DC DC 2-wire
AC/DC 2-wire
Output resistance Ra Open collector Open collector
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes Yes/Yes/Yes AC 2-wire
Switching frequency f max. 10 Hz 10 Hz Special
properties
Output function indicator Yellow LED Yellow LED High-pressure
Approvals CE CE Strokemaster
sensors
Material Housing PA 6.6 PA 6.6
Steelface
Sensing surface UN 3082 UN 3082 sensors
Connection M8 connector, 0.1 m PUR cable with High
temperature
3-pin M12 connector, 3-pin sensors
Suggested mating cable BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020 Harsh
Pulse stretching 150 ms 150 ms environment
sensors
For wiring diagram see page 958. 9.4 Factor 1
sensors
Rated switching distance sn relative to steel plate FE360 (18181 mm) Weld eld
immune
Sensing surface sensors
Sensing surface
Large
designs

87.5
78.5
Centerline spacing for side-by-side mounting Ring sensors

LED Tube sensors
,%$
Analog
distance
measurement
M81
11.9
Accessories
MAX
19
17
R2
0
-

2

www.balluff.com 715
Inductive
Sensors
Inductive sensors for analog distance measurement
Balluff inductive distance sensors BAW provide an absolute voltage-
or current signal that changes proportionally to the distance of a
metallic target. Objects of varying shape and size made of ferrous
or non-ferrous materials damp the sensor to different degrees. This
provides a simple way of detecting positions, distances and material
differences.

Inductive Sensors for
Analog Distance Measurement
Contents
Tubular-style housings
6.5 720
M81 720
M121 721
M181 725
M301.5 728
PG36 729
M12x1 high-pressure resistant 730
Block designs
10306 mm (R03) 731
20x30x8 mm (R06) 732
14x38.5x17 (Z05) 733
80x80x40 mm 734
www.balluff.com 717
Features, approach curve, processing programmable switch points
Features
Distance-proportional analog output signal
Contactless, absolute measuring principle
Wide variety of designs: cylindrical and cubical
Measuring ranges from 0.5...50 mm
High repeat accuracy
Optimal linearity
Low temperature drift
LED for setup aid
Compact, sealed, rugged and reliable
Output characteristics Evaluating programmed switching points (brake disk example)
Wear
Brake disk
Working-
range
Critical
area
LED off LED on
LED off LED on

Sensors in Use
Applications Axial approach Sensing a rotating object Lateral approach

Some of the numerous applica-
tions in measuring and controlling
include:
Distance measurement
Thickness measurement
Run-off measurement
Belt/band width measurement
Detection of surface waves
Counting
Positioning Inductive
Position monitoring sensors
Selection of parts of various Global
sizes and materials DC 3-wire
DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
Distance changes in the sensor axis Eccentrics, cams or unbalanced Detecting longer distances by AC 2-wire
result in output signals proportional motion result in a periodic change in sensing an inclined plane.
to distance. the output signal. Special
properties
Sensing Distance measurements Detecting
various materials at high object travel speeds installed seal rings Analog
distance
measurement
Tubular
Reslution Application Notes: housings
Block designs
BAW sensors are a pure Accessories
analog device with theoretically
innite resolution.
Application resolution depends
on ambient electrical noise
level.
Typical industrial application
noise level is 10-15mV.
If application level noise proves
troublesome, a connectorized
model and shielded cordset
are recommended.
When the distance is kept constant, Even at high traverse speeds dis- The seal ring effectively reduces
the output signal changes only when tances can be precisely measured. the distance between the nut/screw
the object material is different. and the sensor, thereby changing the
output signal.
Tie rod length change on an injection molding machine
Tie rod
In injection molding machines, the clamping force of the tool is built up through
a toggle joint and a hydraulic cylinder. The extension of the machine tie rods is
thereby directly proportional to the clamping force, and can be easily deter-
mined using an inductive distance sensor.
www.balluff.com 719
Tubular housings, 6.5 mm, M81
Temperature output
Series 6.5 mm 6.5 mm M8 1
Output signal Voltage, 0...10 V Voltage, 0...10 V Voltage, 0...10 V
Linear range sl 0.5...2 mm 0.5...2 mm 0.5...1.5 mm
Ordering code BAW000L BAW000J BAW000N
Part name BAW G06EF-UAC20B-S49G BAW G06EE-UAF20B-EP03-K BAW M08EI-UAD15B-BP00,2-GS04
Supply voltage UB 15...30 V DC 21.6...26.4 V DC 15...30 V DC
Effective distance se 1.25 mm 1.25 mm 1 mm
Load resistance RL min. 2 k 5 k 2 k
Load resistance RL max.
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes No/No/No Yes/Yes/Yes
Adjustment display (LED) Yes No No
Ambient temperature Ta +10...+60C* +10...+60C* 10...+70 C
Repeat accuracy RBWN 40.0 m 10.0 m 8.0 m
Non-linearity max. 45 m 45 m 30 m
Limit frequency (3 dB) 1 kHz 1 kHz 1 kHz
Response time 0.5 ms 1 ms 0.5 ms
Temperature coefcient, typically in range from +10...+50 C -0.6 m/K 1 m/K 1 m/K
Approvals CE, cULus CE CE, cULus
Connection M8 connector, 3-pin 3 m PUR cable, 0.2 m PUR cable
Suggested mating cable Unshielded BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
Shielded BCC M313-0000-10-036-VS8334-020 BCC M415-0000-1A-014-VS8434-020
* The function is assured over a range of 10...+70 C
Wiring diagrams
Connector, voltage output
Cable, voltage output
Temperature output
Connector, current output
Typical
Cable, current output
The temperature output (not short-

circuit protected) provides a signal
representing a precisely measured
temperature change.

M8 1 M8 1 M8 1 M8 1 M121
Flush Flush Flush Not ush Flush
Voltage, 0...10 V Voltage, 0...10 V Voltage, 0...10 V Voltage, 0...10 V Current, 4...20 mA
0.5...1.5 mm 0.5...1.5 mm 0.5...1.5 mm 0.5...2.5 mm 0.5...2 mm
BAW003R BAW000M BAW000T BAW000W BAW001F Inductive
BAW M08EH-UAD15B-S04G BAW M08EF-UAC15B-S49G BAW M08EI-UAD15B-BP03 BAW M08EI-UAD25F-BP03 BAW M12MG2-ICC20B-BP00,2-GS04 sensors
15...30 V DC 15...30 V DC 15...30 V DC 15...30 V DC 10...30 V DC Global
250 V AC 250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) DC 3-wire
1 mm 1 mm 1 mm 1.5 mm 1.25 mm
DC 3-/4-wire
2 k 2 k 2 k 2 k
500 DC 2-wire
AC/DC 2-wire
No Yes No No Yes
10...+70 C 10...+70 C 10...+70 C 10...+60 C* 10...+70 C AC 2-wire
40.0 m 40.0 m 8.0 m 10.0 m 5.0 m
30 m 30 m 30 m 60 m 45 m Special
properties
1 kHz 1 kHz 1 kHz 1 kHz 500 Hz
0.5 ms 0.5 ms 0.5 ms 1 ms 0.5 ms Analog
distance
0 m/K 0 m/K 1 m/K 1.5 m/K 0.5 m/K measurement
IP 67 IP 67 IP 67 IP 67 IP 67 Tubular
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus housings
Stainless steel Stainless steel Stainless steel Stainless steel Brass, coated Block designs
PBT PBT PBT PBT PBT Accessories
M12 connector, 3-pin M8 connector, 3-pin 3 m PUR cable, 3 m PUR cable, 0.2 m PUR cable
26 AWG 26 AWG with M12 connector, 3-pin
BCC M415-0000-1A-003-EX44T2-020 BCC M313-0000-10-001-EX43T2-020 BCC M415-0000-1A-003-EX44T2-020
BCC M415-0000-1A-014-VS8434-020 BCC M313-0000-10-036-VS8334-020 BCC M415-0000-1A-014-VS8434-020
M8x1
43.5
13
58
M12x1
www.balluff.com 721
Series M121 M121 M121

Output signal Current, 4...20 mA Voltage, 0...10 V Voltage, 0...10 V
Linear range sl 0.5...2 mm 0.5...2 mm 0.5...2 mm
Ordering code BAW001H BAW001J BAW001P
Part name BAW M12MG2-ICC20B-BP03 BAW M12MG2-UAC20B-BP00,2-GS04 BAW M12MI-UAC20B-S04G
Effective distance se 1.25 mm 1.25 mm 1.3 mm
Load resistance RL min. 2 k 2 k
Load resistance RL max. 500
Adjustment display (LED) Yes Yes Yes
Limit frequency (3 dB) 500 Hz 500 Hz 500 Hz
Temperature coefcient, typically in range from +10...+50 C 0.5 m/K 1 m/K 0.5 m/K
Material Housing Brass, coated Brass, coated Brass, coated
Connection 3 m PUR cable, 0.2 m PUR cable M12 connector, 3-pin
Suggested mating cable Unshielded BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020
Shielded BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020
Wiring diagrams

Temperature output
M121 M121 M121 M121 M121
Flush Flush Flush Flush Quasi-ush
Voltage, 0...10 V Voltage, 0...10 V Current, 0...20 mA Current, 0...20 mA Voltage, 0...10 V
0.5...2 mm 0.5...2 mm 0.5...2 mm 0.5...2 mm 1...5 mm
BAW0010 BAW001L BAW0019 BAW001C BAW0011 Inductive
BAW M12ME-UAC20B-S04G BAW M12MG2-UAC20B-BP03 BAW M12MG2-IAC20B-BP00,2-GS04 BAW M12MG2-IAC20B-BP03 BAW M12ME-UAD50B-BP01 sensors
250 V AC ([) 250 V AC ([) 250 V AC ([) 250 V AC ([) 75 V DC DC 3-wire
1.25 mm 1.25 mm 1.25 mm 1.25 mm 3 mm
DC 3-/4-wire
2 k 2 k 2 k
500 500 DC 2-wire
AC/DC 2-wire
Yes Yes Yes Yes No
10...+70 C 10...+70 C 10...+70 C 10...+70 C 0...+60 C AC 2-wire
20.0 m 8.0 m 5.0 m 5.0 m 10.0 m
45 m 45 m 45 m 45 m 160 m Special
properties
500 Hz 500 Hz 500 Hz 500 Hz 1 kHz
0.5 ms 0.5 ms 0.5 ms 0.5 ms 2 ms Analog
distance
0 m/K 1 m/K 1 m/K 1 m/K 1.5 m/K measurement
Brass, coated Brass, coated Brass, coated Brass, coated Brass, coated Block designs
PBT PBT PBT PBT PA 12 Accessories
M12 connector, 3-pin 3 m PUR cable, 0.2 m PUR cable 3 m PUR cable, 1 m PUR cable,
22 AWG with M12 connector, 3-pin 22 AWG 24 AWG
BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020
M12x1
26
17 30
Temperature output
Typical

temperature change.
www.balluff.com 723

Installation type (pay attention to the note in the Basic Information chapter) Not ush Not ush Not ush
Linear range sl 1...4 mm 1...4 mm 1...4 mm
Ordering code BAW0014 BAW000Z BAW0017
Part name BAW M12MF2-UAC40F-BP00,2-GS04 BAW M12MD-UAC40F-S04G BAW M12MF2-UAC40F-BP03
Effective distance se 2.5 mm 2.5 mm
Response time 1 ms 1 ms 1 ms
Temperature coefcient, typically in range from +10...+50 C 0 m/K 2 m/K 0 m/K
Connection 0.2 m PUR cable M12 connector, 3-pin 3 m PUR cable,
Suggested mating cable Unshielded BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020
Shielded BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020
Wiring diagrams

M12x1

Temperature output
M121 M181 M181 M181 M181
Not ush Flush Flush Flush Flush
Current, 4...20 mA Voltage, 0...10 V Voltage, 0...10 V Voltage, 0...10 V Voltage, 0...10 V
1...4 mm 1...5 mm 1...5 mm 1...5 mm 1...5 mm
BAW003N BAW001Z BAW002K BAW0026 BAW0025 Inductive
BAW M12MH1-ICC40F-S04G BAW M18ME-UAC50B-BP00,2-GS04 BAW M18MI-UAC50B-S04G BAW M18ME-UAE50B-S04G-K BAW M18ME-UAC50B-S04G sensors
10...30 V DC 15...30 V DC 15...30 V DC 21.6...26.4 V DC 15...30 V DC Global
250 V AC ([) 75 V DC 250 V AC ([) 75 V DC 75 V DC DC 3-wire
2.5 mm 3 mm 3 mm 3 mm
DC 3-/4-wire
2 k 2 k 2 k 2 k
500 ohms DC 2-wire
AC/DC 2-wire
Yes Yes Yes Yes Yes
10...+70 C 10...+70 C 10...+70 C 10...+70 C 10...+70 C AC 2-wire
8.0 m 8.0 m 8.0 m 8.0 m
120 m 120 m 120 m 120 m 120 m Special
properties
500 Hz 500 Hz 500 Hz 500 Hz 500 Hz
0.5 ms 1 ms 1 ms 1 ms 1 ms Analog
distance
1 m/K 2 m/K 1 m/K 2 m/K measurement
M12 connector, 3-pin 0.2 m PUR cable M12 connector, 3-pin M12 connector, 4-pin M12 connector, 3-pin
BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020
M12x1 M18x1
5
30
36
24
49.5
17
65
LED
LED
Temperature output
41.5
24
Typical
M12x1
14.5

temperature change.
www.balluff.com 725
With teach-in,
3 switching points With Teach-in
Ordering code BAW002M BAW002U BAW0022
Part name BAW M18MI2-UAC50B-BP05-002 BAW M18MM-UAZ50B-BP05-505 BAW M18ME-UAC50B-BP03
Supply voltage UB 15...30 V DC 21.6...26.4 V DC 15...30 V DC
Effective distance se 3 mm 3 mm 3 mm
Polarity reversal protected/transposition protected/short-circuit protected Yes/No/Yes Yes/No/Yes Yes/Yes/Yes
Adjustment display (LED) Yes No Yes
Response time 1 ms 1 ms 1 ms
Temperature coefcient, typically in range from +10...+50 C 1.5 m/K 0 m/K 1 m/K
Connection 5 m PUR cable, 24 AWG 5 m PUR cable, 24 AWG 5 m PUR cable, 22 AWG
Suggested mating cable Unshielded
Shielded
Wiring diagrams

M181 M181 M181 M181 M181

IO-Link, falling with rising proximity Current, 0...20 mA Current, 4...20 mA Current, 4...20 mA Current, 4...20 mA
1...5 mm 1...5 mm 1...5 mm 1...5 mm 1...5 mm
BAW002F BAW002H BAW002J BAW001U BAW001T Inductive
BAW M18MI-BLC50B-S04G BAW M18MI-IAC50B-S04G BAW M18MI-ICC50B-S04G BAW M18ME-ICC50B-S04G BAW M18ME-ICC50B-BP03 sensors
250 V AC ([) 250 V AC ([) 250 V AC ([) 75 V DC 75 V DC DC 3-wire
DC 3-/4-wire
500 500 500 500 DC 2-wire

AC/DC 2-wire
Yes Yes Yes Yes Yes
10...+70 C 10...+70 C 10...+70 C 10...+70 C 10...+70 C AC 2-wire
10.0 m 8.0 m 8.0 m 8.0 m 8.0 m
120 m 120 m 120 m 120 m 120 m Special
properties
500 Hz 500 Hz 500 Hz 500 Hz 500 Hz
2 ms 1 ms 1 ms 1 ms 1 ms Analog
distance
2 m/K 1 m/K -5 m/K 3 m/K 3 m/K measurement
BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020
www.balluff.com 727
Tubular housings, M181, M301.5
Temperature output
Series M181 M181 M301.5
Installation type (observe instructions in the Basic Information chapter) Not ush Not ush Flush
Ordering code BAW002C BAW0029 BAW002W
Part name BAW M18MG-UAC80F-S04G BAW M18MG-UAC16F-S04G-K BAW M30ME-UAC10B-S04G
Effective distance se 5 mm 10 mm 6 mm
Ambient temperature Ta 10...+70 C +10...+60C* 10...+70 C
Response time 1.5 ms 3 ms 1.5 ms
Temperature coefcient, typically in range from +10...+50 C 3 m/K 8 m/K 1.5 m/K
Suggested mating cable Unshielded BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020 BCC M415-0000-1A-003-EX44T2-020
Shielded BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020
* The function is guaranteed over a range of 10...+70 C

M30x1.5
Wiring diagram 36
30
44.5
LED
M12x1
Temperature output
Typical

temperature change.

Tubular housings, M301.5, PG36
M301.5 PG36
Not ush Flush
Voltage, 0...10 V Voltage, 0...10 V
3...15 mm 0...20 mm
BAW002Y BAW003M Inductive
BAW M30ME-UAC15F-S04G BAW MKZ-471.19-S4 sensors
15...30 V DC 20...30 V DC Global
250 V AC ([) 75 V DC DC 3-wire
9 mm 10 mm
DC 3-/4-wire
2 k 10 k
Yes/Yes/Yes Yes/Yes/Yes DC 2-wire
Yes Yes
AC/DC 2-wire
10...+70 C 10...+70 C
12.0 m 5.0 m AC 2-wire
360 m 600 m
350 Hz 20 Hz Special
properties
3 ms
1.5 m/K 1 m/K Analog
distance
CE, cULus CE Tubular
Brass, coated Brass, coated housings
PBT PBT Block designs
M12 connector, 3-pin M12 connector, 3-pin Accessories
BCC M415-0000-1A-014-VS8434-020 BCC M415-0000-1A-014-VS8434-020
M12x1
www.balluff.com 729
Tubular housings, high-pressure resistant M121
Analog for control of valves or

soft stop
Measurements of valves and
cylinders possible
Ceramic on medium side
robust
Oil pressure up to 500 bar Series M121
Installation (observe instructions in the Basic Information chapter) Flush
Application areas Output signal Voltage, 0...10 V
Control of valves Linear range sl 0.5...2 mm
Parked position of cranes Ordering code BAW0040
Final position of installation Part name BAW Z08EO-UAD20B-S04G-H11
supports Supply voltage UB 15...30 V DC
Service measurements of valves Rated insulation voltage Ui (protection class) 75 V DC
Position monitoring in mobile Effective distance se 1.25 mm
hydraulic systems Load resistance RL min. 2 k
Control of agricultural technol- Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes
ogy Adjustment display (LED) No
Repeat accuracy RBWN 8.0 m
Non-linearity max. 45 m
Limit frequency (3 dB) 1 kHz
Response time 1 ms
Temperature coefcient, typically in range from +10...+50 C 1 m/K
Approvals CE, cULus
Material Housing Stainless steel
Sensing surface Ceramic
Suggested mating cable Unshielded BCC M415-0000-1A-003-EX44T2-020
Shielded BCC M415-0000-1A-014-VS8434-020
Wiring diagram
-


500 bar


Block design, 10306 mm
Series 10306 mm R03 10306 mm R03

Installation (observe instructions in the Basic Information chapter) Flush Flush
Output signal Voltage, 0...10 V Voltage, 0...10 V
Linear range sl 1...4 mm 1...4 mm
Ordering code BAW0030 BAW0031 Inductive
Part name BAW R03KC-UAE40B-BP00,3-GS26 BAW R03KC-UAE40B-BP00,3-GS49 sensors
Supply voltage UB 21.6...26.4 V DC 21.6...26.4 V DC Global
Rated insulation voltage Ui (protection class) 75 V DC 75 V DC DC 3-wire
Effective distance se 2.5 mm
DC 3-/4-wire
Polarity reversal protected/transposition protected/short-circuit protected No/No/No No/No/No DC 2-wire
Adjustment display (LED) Yes Yes
AC/DC 2-wire
Repeat accuracy RBWN 35.0 m 35.0 m AC 2-wire
Non-linearity max. 150 m 150 m
Limit frequency (3 dB) 1 kHz 1 kHz Special
properties
Temperature coefcient, typically in range from +10...+50 C 4.7 m/K 4.7 m/K Analog
distance
Degree of protection as per IEC 60529 IP 67 IP 67 measurement
Approvals CE, cULus CE, cULus Tubular
Material Housing No/No/No PA6-FG30 housings
Sensing surface PA6-FG30 PA6-FG30 Block designs
Connection 0.3 m PUR cable with 0.3 m PUR cable with Accessories
Suggested mating cable Unshielded BKS-B-25-3-PU-03 BCC M313-0000-10-001-EX43T2-020
Shielded BCC M313-0000-10-036-VS8334-020
Installation note for BAW R03...
Material Installation dimensions x

Steel 0 mm
Brass 5 mm
Aluminum 5 mm
Stainless steel 5 mm
Wiring diagram
www.balluff.com 731
Block designs, 10306 mm, 20308 mm
Series 10306 mm R03 20308 mm R06

Output signal Voltage, 0...10 V Voltage, 0...10 V
Linear range sl 1...4 mm 0.5...2 mm
Ordering code BAW0032 BAW0034
Part name BAW R03KC-UAE40B-BP03 BAW R06AC-UAF20B-S49G
Supply voltage UB 21.6...26.4 V DC 21.6...26.4 V DC
Effective distance se 2.5 mm 1.3 mm
Polarity reversal protected/transposition protected/short-circuit protected No/No/No No/No/No
Adjustment display (LED) Yes No
Repeat accuracy RBWN 35.0 m 12.0 m
Non-linearity max. 150 m 45 m
Limit frequency (3 dB) 1 kHz 1 kHz
Temperature coefcient, typically in range from +10...+50 C 5 m/K 0.5 m/K
Material Housing PA6-FG30 Anodized aluminum
Sensing surface PA6-FG30 PBT
Connection 3 m PUR cable, 26 AWG M8 connector, 3-pin
Suggested mating cable Unshielded BCC M313-0000-10-001-EX43T2-020
Shielded BCC M313-0000-10-036-VS8334-020
* The function is guaranteed over a range of 10...+70 C
Wiring diagrams

Block designs 20308 mm, 1438.517 mm
45677_00
Temperature output Temperature output

20308 mm R06 1438.517 mm Z01 1438.517 mm Z01 1438.517 mm Z05
Flush
Voltage, 0...10 V Voltage, 0...10 V IO-Link, falling with rising proximity IO-Link, falling with rising proximity
0.5...2 mm 1...5 mm 1...5 mm 1...5 mm
BAW0033 BAW003E BAW003A BAW003W Inductive
BAW R06AC-UAF20B-EP03 BAW Z01AC-UAD50B-DP03-K BAW Z01AC-BLD50B-DP03 BAW Z05AC-BLD50B-BP00,75-GS04 sensors
21.6...26.4 V DC 15...30 V DC 18...30 V DC 18...30 V DC Global
1.25 mm 3 mm 3 mm 3 mm
DC 3-/4-wire
5 k 2 k
No/No/No Yes/No/Yes Yes/Yes/Yes Yes/Yes/Yes DC 2-wire
No No
AC/DC 2-wire
+10...+60C* 10...+60 C 10...+60 C 10...+60 C
12.0 m 10.0 m 10.0 m 10.0 m AC 2-wire
45 m 120 m 150 m 150 m
1 kHz 1 kHz 200 Hz 200 Hz Special
properties
0.5 ms 1 ms 5 ms 5 ms
0.5 m/K 3 m/K 3 m/K 3 m/K Analog
distance
IP 67 IP 67 IP 67 IP 67 measurement
CE CE, cULus CE, cULus CE, cULus Tubular
Anodized aluminum Anodized aluminum Anodized aluminum Anodized aluminum housings
PBT PA 12 LCP LCP Block designs
3 m PUR cable, 30.14 mm 3 m PUR cable, 40.14 mm 3 m PUR cable, 40.14 mm 0.75 m PUR cable with M12 connector, 3-pin Accessories
14 14 14
13
13
13
38.5
38.5
38.5
30.5
30.5
30.5
18.5
18.5
4
4
4 4
1.5
1.5
4
30 30 30
22 22 22
4.8 4.8 4.8
20
20
2
2
13.5
13.5
17
17
8.5
8.5
r
Temperature output Temperature output
Typical Typical
49
M12x1
The temperature output (not short- The temperature output (not short-
circuit protected) provides a signal circuit protected) provides a signal
representing a precisely measured representing a precisely measured
temperature change. temperature change.
www.balluff.com 733
Block designs, 808040 mm
Series 808040 mm Maxisensor

Installation type (observe instructions in the Basic Information chapter) Not ush
Output signal Voltage, 0...10 V
Linear range sl 0...50 mm
Ordering code BAW003K
Part name BAW MKK-050.19-S4
Effective distance se 25 mm
Load resistance RL min. 10 k
Adjustment display (LED) No
Repeat accuracy RBWN 12.0 m
Non-linearity max. 1500 m
Limit frequency (3 dB) 15 Hz
Temperature coefcient, typically in range from +10...+50 C 15 m/K
Approvals CE
Sensing surface PBT
Suggested mating cable Unshielded BCC M415-0000-1A-003-EX44T2-020
Shielded BCC M415-0000-1A-014-VS8434-020
Wiring diagram

Inductive
sensors
Global
DC 3-wire
DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
AC 2-wire
Special
properties
Analog
distance
measurement
Tubular
housings
Block designs
Accessories
www.balluff.com 735
Inductive
Sensors
Accessories for inductive sensors
We offer special accessories for our inductive sensors.
With products optimally suited to each other. Alongside switching
devices, there are also assembly aids and protective equipment for
the most varied inductive sensors.

Accessories for Inductive Sensors
Contents
Accessories for inductive sensors

Pulse stretching 739
Sensor tester, testing and setting device 741
Analog switching devices 743
Assembly aids for Uni and Unicompact sensors 744
Protective coverings for Unicompact sensors 747
Protective nuts 748
Positive stop 750
Tube switch 752
Banking screw actuators 754
Cushioned Prox mounts 756
Mounting clamps for tubular sensors 758
Prox mounts for tubular sensors 761
Bunker Blocks 762
Weld Repel 763
Mounting brackets for 8x8 block sensors & seal nuts 764
Mounting brackets for block sensors 766
Sensor protection devices 767
www.balluff.com 737
Pulse stretching
Detecting fast motion

Rapid motions on machines
mean that the sensors are only
actuated for a short time. There-
fore, the sensor pulse can be
too short to guarantee a secure
evaluation. Due to its cycle time,
the controller does not detect the
output signal, with the conse-
quence that important informa-
tion in the controller sequence is
lost. This can pose a risk
to your machine!
The solution is the Balluff pulse

extender BES 516-IV 2.
For controlling this device, the
rising or falling edge of the sen-
sor output signal is sufcient
to generate a pulse that your
controller can recognize. The
length is adjustable from 2 ms to
1 sec. Small and space-saving,
the device can be snapped
onto a rail in accordance with
EN 50022-35.

Pulse stretching
Description Pulse stretching

Use Ensures secure output signals from inductive,
capacitive or optoelectronic sensors to the controller
Ordering code BAE0073 Inductive
Part number BES 516-IV 2 sensors
Output (display by LEDs) Positive-switching (PNP), complementary Global
Adjustable pulse stretching 2 ms...1 s DC 3-wire
Set value 200 ms (+50 ms)
DC 3-/4-wire
Input 7/8 Referenced to the respective edge of the input signal
Input 5/6 Referenced to the pulse end of the input signal DC 2-wire
Repeatability < 10 %
AC/DC 2-wire
Input 1 PNP or 1 NPN - NO or NC
Min. input pulse length 1.5 ms AC 2-wire
Supply voltage US 10...30 V DC (input voltage = output voltage)
Residual ripple 15 % Special
properties
No-load current Approx. 20 mA
Output current 130 mA Analog
distance
Permissible load capacity 0.5 F/24 V measurement
Ambient temperature Ta 0...60 C
Housing attachment DIN rail EN 50022-35 Accessories
Max. conductor cross-section 22.5 mm Pulse
Extension
Polarity reversal protected Yes Sensor tester,
Short-circuit protected Yes testing and
setting device
Degree of protection as per IEC 60529 Housing IP 40/terminals IP 20
Analog
Output 3 Low-pulse, extended switching
4 High-pulse, extended device
Input 7 Falling edge Assembly aids
for Uni and
8 Rising edge Unicompact
5 Low pulse sensors
Protective
6 High pulse covering for
1 US Unicompact
sensors
2 +US
Protective nuts
Falling edge Output signal is triggered by rising edge
Positive stop
Rising edge Output signal is triggered by rising edge Tube switch
Low pulse PNP-NC/NPN-NO short damped Banking screw
PNP-NO/NPN-NC short undamped Cushioned
High pulse PNP-NC/NPN-NO short damped mounts
Clamping
PNP-NO/NPN-NC short undamped holder overview
www.balluff.com 739
Sensor tester, testing and setting device
Testers BES 576-3 Testing and setting device BES 516-4

Balluff sensor testers are at, handy, and visually appealing. The test- With this programming device, the following testing and setting
ing device is a simple manual testing device for PNP/NPN, normally functions can be carried out on the sensors:
open and normally closed sensors. Programming the switching distance of analog sensors.
Sensors with teachable switching points can also be
Benets programmed.
Integrated steel measuring plate for testing sensors Testing 3-wire sensors.
Automatic shut-off after 30 s of non-use Testing 2-wire sensors.
Power provided by a 9V battery
Visual and acoustic signal

Sensor tester, testing and setting device
Description Sensor tester High Sensor tester Sensor tester Testing and setting device
Use For DC PNP/NPN For DC PNP/NPN For DC PNP/NPN For DC PNP/NPN
3-wire sensors 3-wire sensors 3-wire sensors 2/3-wire sensorsand analog sensors
Ordering code BAE000M BAE002A BAE002C BAE0029 Inductive
Part number BES 516-3 BES 516-5 BES 516-7 BES 516-4 sensors
Output voltage 18 V DC 20-24 V DC 18 V DC 18 V DC Global
LED indicators 1 operating indicator 1 operating indicator 1 operating indicator 3 function indicators, 1 operating indicator DC 3-wire
Battery type 2 9 V battery 6 - 1.5 VAA (not included) 1 9 V battery 2 9 V batteries
DC 3-/4-wire
Sensor connection 3 spring-loaded terminals 3 spring-loaded terminals 3 spring-loaded terminals 7 spring-loaded terminals
Degree of protection IP 21 IP 21 IP 40 IP 40 DC 2-wire
as per IEC 60529
AC/DC 2-wire
Housing material Plastic Plastic Plastic Plastic
Acoustic and visual signal, AC 2-wire
built-in steel measuring plate Special

properties
Analog
distance
PWR LOW PNP NPN
measurement
BAT
LOW
BAT
Accessories
107
Pulse
HIGH POWER SENSOR TESTER Extension
BES 516-5
24VDC Output, 100mA Sensor tester,
Made in the UK testing and
setting device
34 mm deep
24 mm deep Analog
switching
device
Assembly aids
for Uni and
Unicompact
sensors
Protective
covering for
Unicompact
sensors
Protective nuts
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder overview
www.balluff.com 741
Analog switching device for onsite assembly
for inductive distance sensors BAW

This switching device allows you to easily program sensors which
have an analog output signal, such as the BOD family, with three
switching thresholds, onsite.
In this, the sensor connected to the switching device is brought into
the desired switching distance from the object. Then connecting the
control line to the (+) side of the supply voltage enables a "Teach-in"
mode; in other words, the set distance is assigned to the signal level
present and these values are stored in the evaluation device. This
procedure is supported with LEDs. During operation, these LEDs are
available as switching state indicators.
For sensors with a temperature output, the analog temperature
signal is made available in unchanged form on the device output.
Connection example
Analog sensors Analog switching

amplier
e.g. BOD... BES 516-615-PS-1-PU-05
Wiring diagrams
PNP analog and PNP normally open PNP analog and NPN normally open
Approach curve

for inductive distance sensors BAW
Size M181
Use For analog sensors
PNP analog and Ordering code BAE0070
PNP NO Part number BES 516-615-PS-1-PU-05 Inductive
PNP analog and Ordering code BAE006Z sensors
NPN NO Part number BES 516-615-NS-1-PU-05 Global

Rated operating voltage Ue 15...30 V DC DC 3-wire
Supply voltage US 15...30 V DC
DC 3-/4-wire
Residual ripple 15% of Ue
Rated insulation voltage Ui 75 V DC DC 2-wire
AC/DC 2-wire
per output
No-load supply current I0 max. 20 mA AC 2-wire
Residual current Ir 10 A
Polarity reversal protected Only against -reversal Special
properties
Short-circuit protected Yes
Ambient temperature Ta 10...+70 C Analog
distance
Switching frequency f 2 kHz measurement
Utilization category DC 13
Function indicator for each output Yes Accessories
Analog input Pulse
Extension
Input voltage Uin 0...10 V (implemented Sensor tester,
to output A) testing and
setting device
Input impedance 4.2 k
Analog
Switching outputs switching
Freely programmable 3 device
switching outputs Assembly aids
for Uni and
Hysteresis H 500 mV Unicompact
Temperature drift 2 % of Uin max. sensors
Protective
Degree of protection as per IEC 60529 IP 67 covering for
Housing material CuZn coated Unicompact
sensors
Connection Input M12 connector, 5-pin
Protective nuts
Output 5 m PUR cable, 70.25 mm
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder overview
www.balluff.com 743
Assembly aids for Unicompact sensors
Description Unicompact mounting bracket Unicompact mounting base Unicompact mounting base
Use for BES Q40KFU-... for BES Q40KFU-... for BES Q40KFU-...
Unicompact sensors (4040 mm) Unicompact sensors (4040 mm) Unicompact sensors (4040 mm)
Ordering code BAM00JW BAM00JY BAM00JZ
Part number BES Q40-HW-1 BES Q40-HW-2 BES Q40-HW-3
Material Anodized aluminum Anodized aluminum Anodized aluminum
Please note permissible installation options!
3 different mounting options

Assembly aids for Unicompact sensors
Description Unicompact holding system Unicompact holding system

Use Unicompact sensors for fastening Unicompact sensors for fastening
to prole rails (groove width: 8 mm) to prole rails (groove width: 16 mm)
Ordering code BAM00JU BAM00JT Inductive
sensors
Part number BES HS-01-P1-C8/Q40 BES HS-01-P1-C16/Q40
Material Al anodized, CuZn Al anodized, CuZn Global
DC 3-wire
DC 3-/4-wire
This holding system is used to
attach Unicompact sensors to DC 2-wire
extruded rails.
AC/DC 2-wire
The mounting set consists of:
1 mounting plate AC 2-wire
2 tenon blocks
2 M510 cheese head Special
properties
screws DIN 912 galvanized
2 washers 5.3 DIN 533 Analog
distance
2 M540 cheese head measurement
screws ISO 4762
Accessories
Pulse
Extension
Sensor tester,
testing and
setting device
Analog
switching
device
Assembly aids
for Uni and
Unicompact
sensors
Protective
covering for
Unicompact
sensors
Protective nuts
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder overview
www.balluff.com 745
Assembly aid for Uni sensors and Unicompact sensors
Description Mounting plate - Unisensor and Unicompact

Use For Unisensor and Unicompact sensors
(4040 mm)
Ordering code
Part number Montageplatte B 4 - 2057
Material Anodized aluminum
Unisensors can be adjusted up to 30 mm on this mounting plate

while wired.
Loosening the sensor mounting screws (M5x25; included in set) al-

lows the Unisensor to be easily repositioned to the desired location.
Then simply tighten the screws.

Protective coverings for Unicompact sensors
Description Protective cover - Unicompact Protective cap - Unicompact

Use For BES Q40KFU-... magnetic eld resistant for BES Q40KFU-...
Unicompact sensors (4040 mm) Unicompact sensors (4040 mm)
Ordering code BAM00K0 BAM00K1 Inductive
Part number BES Q40-SH-1 BES Q40-SH-2 sensors
Material Anodized aluminum PA 6 Global

DC 3-wire
DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
AC 2-wire
Special
properties
Analog
distance
measurement
Accessories
Pulse
Extension
Sensor tester,
testing and
setting device
The weld protection consists of a protective cover and a self-adher-
Analog
ing PTFE lm for protecting the active surface. If the sensor head is switching
replaced, the welding protection must not be removed. device
Assembly aids
for Uni and
Unicompact
Protective cover sensors
Protective
for use with BES 940 covering for
Material: Coated Brass Unicompact
sensors
Protective nuts
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder overview
www.balluff.com 747
Protective nuts
Description Cover nut Cover nut Cover nut Cover nut Cover nut
Use For M8 sensors For M8 sensors For M12 sensors For M16 sensors For M18 sensors
Ordering code BAM009Z BAM00A0 BAM00C2 BAM00EP BAM00EZ
Part number BES 08-SM-1 BES 08-SM-1F BES 12-SM-2 BES 16-SM-2 BES 18-SM-1
Reduction of the 1 mm 1 mm 1 mm 1.5 mm 1 mm
rated switching distance
Material PTFE PTFE POM PTFE PTFE
13 17 18.5
1.5
1
1
5
5
1
10
15
M8x1 M18x1
M8x1 M12x1
10 22
10 M16x1
16
20
Increase the life of a sensor with PTFE, Deirin

or ceramic screw on cap.
Increase life of the sensor by protecting sensor face

Withstands high temperatures
Used in welding applications
Easy installation
Material POM PTFE

Please note!
The rated switching distance of sensors is reduced to the wall
thickness of the nut when the protective nut is installed.

Protective nuts
Cover nut Cover nut Cover nut Cover nut Cover nut
For M18 sensors For M18 sensors For M30 sensors For M30 sensors For M36 sensors
BAM00F0 BAM00H8 BAM00HJ BAM00HK BAM00JL
BES 18-SM-2 BES 22-SM-2 BES 30-SM-1 BES 30-SM-2 BES 36-SM-2 Inductive
Global
POM PTFE POM POM POM DC 3-wire
DC 3-/4-wire
21.5 23 30.5 31 37
DC 2-wire
2
2
1
5
1
AC/DC 2-wire
9.5
15
15
15
M30x1.5
M18x1
AC 2-wire
34
M22x1,5 M30x1.5 M36x1,5
18.5
42 Special
28 35
properties
Analog
distance
measurement
Accessories
Pulse
Extension
Sensor tester,
testing and
setting device
Analog
switching
device
Description Cover nut Cover nut Cover nut
Assembly aids
Use For M18 sensors For M18 sensors for Uni and
Order code Unicompact
sensors
Part number BES 12-CERAMIC-CAP-1 BES 18-CERAMIC-CAP-1 BES 30-CERAMIC-CAP-1 Protective
Reduction of the 2 mm 2 mm 2 mm covering for
Unicompact
rated switching distance sensors
Material Ceramic Ceramic Ceramic Protective
nuts
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder overview
www.balluff.com 749
Positive stop
Positive stops for sensors with diameters of 4 mm or 8 mm

A positive stop that is combined with the corresponding mounting
cuff can be added to inductive sensors with housing 4 mm or
8 mm. The desired switching point between the proximity switch
and the trigger pin can be set wherever needed.
Prox Actuator Description Positive stop

To avoid sensor damage, Balluffs prox actuators isolate inductive
proximity sensors from mechanical contact with targets. They consist Use For inductive sensors for
of a mounting clamp and a detent holder and are used with either a mechanical protection
4mm or 8mm smooth bore sensor. Ordering code BAM009L
Part number BES 08-FA-49
When a target contacts the plunger, the rod moves the detent into Ordering code
the sensing range of the switch, thus activating its output. When the Part number
target is removed, the plunger springs back into place and the detent Temperature resistance 25...+100 C
is moved out of the sensing range. Spring force 3N
Impact force Fmax. (N) 100
Each prox actuator consists of a threaded barrel, a plunger and rod Spring deection 2 mm
with spring return and a detent, which is detected by the sensor. Permissible torque 15 Nm
The sensor is inserted into one end of the mounting clamp and the Material Stainless steel
detent holder is inserted into the other end. Mounting clamps are
available in four congurations:
M81
5.5
Straight and right angle for use with 4mm sensors
Straight and right angle for 8mm sensors
4
Detent holders come in three congurations:
M12 x 1, 70mm long
M08 x 1, 49mm long
M08 x 1, 89mm long 13
All have a 8mm smooth bore end for insertion into the clamp. Any
holder can be used with any clamp. Once the sensor and holder are
installed, two allen screws are tightened to hold them in place.
m
m
4

or
ns
Se
Positiv
e stop
BES 1
2-FA-7
0

Positive stop, mounting cuff for positive stop
Positive stop Positive stop Mounting cuff - Mounting cuff -

straight for positive stop angled for positive stop
For inductive sensors for For inductive sensors for For sensors with 4 mm For sensors with 4 mm
mechanical protection mechanical protection or 8 mm or 8 mm Inductive
sensors
BAM009M BAM00AZ BAM009N BAM009P
BES 08-FA-89 BES 12-FA-70 BES 08-FA-BS-4.0-G BES 08-FA-BS-4.0-W Global
BAM009R BAM009T DC 3-wire
BES 08-FA-BS-8.0-G BES 08-FA-BS-8.0-W
DC 3-/4-wire
25...+100 C 25...+100 C 25...+100 C 25...+100 C
3N 4N DC 2-wire
100 100
AC/DC 2-wire
2 mm 32 mm
15 Nm 25 Nm 15 Nm 15 Nm AC 2-wire
Stainless steel Stainless steel Anodized Al Anodized Al
Special
properties
M81 M121 Positive stop
Positive stop Analog
5.5 8 8 mm
8 mm distance
measurement
4
Accessories
4
Pulse
Extension
13 Sensor tester,
17 Sensor 4 mm Sensor 4 mm testing and
or 8 mm or 8 mm setting device
Analog
switching
device
Assembly aids
for Uni and
Unicompact
sensors
Protective
covering for
Unicompact
sensors
Protective nuts
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder overview
www.balluff.com 751
Tube switch
Mechanical actuation non-contact switching

Protects the sensor from mechanical damage
Plug and safe
Rapid application high reliability

The set includes a pre-assembled tube switch, which means
you only need to set up the sensor. The tube switch also combines
the advantages offered by mechanical and inductive switches. Description Tube switch
Manufactured from stainless steel, it is extremely robust and very Use For sensors dia. 4 mm for me-
reliable, even under difcult conditions. chanical protection
Ordering code BAM01C0
Part number BAM FS-XE-002-D4-4
Spring force F (N) 3
Impact force Fmax. (N) 400
Switching operations min. (with Fmax.) 500000
Housing material Stainless steel

Tube switch
Tube switch Tube switch Tube switch

For M5 sensors for For M5 sensors for For M8 sensors for
mechanical protection mechanical protection mechanical protection
BAM01AZ BAM019Y BAM019W Inductive
BAM FS-XE-001-M5-4 BAM FS-XE-003-M5-4 BAM FS-XE-004-M8-4 sensors
3 3 4 Global
400 400 400 DC 3-wire
500000 500000 500000
DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
AC 2-wire
Special
properties
Analog
distance
measurement
Accessories
Pulse
Extension
Sensor tester,
testing and
setting device
Analog
switching
device
Assembly aids
for Uni and
Unicompact
sensors
Protective
covering for
Unicompact
sensors
Protective nuts
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder overview
www.balluff.com 753
Banking screw actuators
Features:
Banking screw actuators are heat treated alloy steel that will accept any stan-
dard (1x) M8, M12 or M18 shielded sensor. Not intended for use with extended
range models.
Benets:
Solid state output with no mechanical contact with sensor.
Isolates sensor from impact.
Allows for positive mechanical contact to plunge without physical contact to
sensor. Banking screw used as
a rugged stop for a
linear slide.
Construction & Operation

Both the screw and piston are heat-treated to withstand heavy use. A con-
necting rod ties the spring-loaded piston to the target, which triggers the
sensor when the piston is displaced. The sensor is isolated from impact and
separated from the target with a plastic bushing.
Screw Jam Nut (2) Target
Stop Bushing
Piston

Banking screw actuators
31.8
B (1.25)
G C
E
F
A 16.7
(0.66)
Inductive
sensors
Global
DC 3-wire
Ordering Code A B C D E G
BESA 08-25-08-BANKING-SCREW M8 X 1 25 mm M8 X 1 3.16 mm 5.84 mm 11.0 mm DC 3-/4-wire
BESA 08-50-08-BANKING-SCREW M8 X 1 50 mm M8 X 1 3.16 mm 5.84 mm 11.0 mm
DC 2-wire
BESA 12-50-12-BANKING-SCREW M12 X 1 50 mm M12 X 1 4.32 mm 9.40 mm 15.7 mm AC/DC 2-wire
AC 2-wire
BESA 18-50-18-BANKING-SCREW M18 X 1 50 mm M18 X 1 4.32 mm 14.2 mm 22.1 mm Special
properties
BESA 18-100-18-BANKING-SCREW M18 X 1 100 mm M18 X 1 4.32 mm 14.2 mm 22.1 mm Analog
distance
measurement
Accessories
Pulse
Extension
Sensor tester,
Features: testing and
setting device
Banking screw actuators are heat treated alloy steel that will accept
Analog
any standard (1x) M8, M12 or M18 shielded sensor. Not intended for switching
use with extended range models. device
Assembly aids
for Uni and
Benets: Unicompact
Solid state output with no mechanical contact with sensor. sensors
Protective
Isolates sensor from impact. covering for
Allows for positive mechanical contact to plunge without physical Banking screw used as Unicompact
sensors
contact to sensor. a rugged stop for a
Protective nuts
linear slide.
Positive stop
Tube switch
Construction & Operation Banking
Both the screw and piston are heat-treated to withstand heavy screw
use. A connecting rod ties the spring-loaded piston to the Cushioned
mounts
target, which triggers the sensor when the piston is displaced.
Clamping
The sensor is isolated from impact and separated from the target holder overview
with a plastic bushing.
Screw Jam Nut (2) Target
Stop Bushing
Piston
www.balluff.com 755
Cushioned Prox mounts
Protects sensor face from welding spatter and abrasives

Minimal sensing distance affect (0.3-0.5 mm)
Held in place with epoxy*
Extends life of sensor
Provides physical and thermal protection to sensor face
Description Contact protector

Use For M8 sensors for
mechanical protection
Ordering code BAM015U
Part number BESA-08-CM
WAF 22
Ambient temperature 45...+85 C
Material Anodized Al, POM

Cushioned Prox mounts
Contact protector Contact protector Contact protector

For M12 sensors for For M18 sensors for For M30 sensors for
mechanical protection mechanical protection mechanical protection
BAM015W BAM015Y BAM015Z Inductive
BESA-12-CM BESA-18-CM BESA-30-CM sensors
29 35 51 Global
45...+85 C 45...+85 C 45...+85 C DC 3-wire
Anodized Al, POM Anodized Al, POM Anodized Al, POM
DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
AC 2-wire
Special
properties
Analog
distance
measurement
Accessories
Pulse
Extension
Sensor tester,
testing and
setting device
Analog
switching
device
Assembly aids
for Uni and
Unicompact
sensors
Protective
covering for
Unicompact
sensors
Protective nuts
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder overview
www.balluff.com 757
Mounting clamps for tubular sensors
Clamp for tubular sensors 4 mm and 5 mm

D
BES 04-KB-1 4
BES 05-KB-1 5
BES 06.5-KB-1 6.5
Material: PA6
Clamp for tubular sensors M12 and M18 (stackable)

A B C D
BES 12,0-KB-2 16 40 25 12
BES 18,0-KB-2 22 45 30 18
Material: PA6
Clamping cuff
A B C D E F G H I J
BES 06.5-BS-1 17 27 16 6.4 12 8 4.5 4.5 8 1
BES 08.0-BS-1 17 27 16 7.9 12 8 4.5 4.5 8 1
BES 12.0-BS-1 22 32 20 11.9 12 8 4.5 4.5 10 1
BES 14.5-BS-1 22 32 20 14.5 12 8 4.5 4.5 10 1
BES 16.0-BS-1 26 36 26 16 12 8 4.5 4.5 13 1
BES 18.0-BS-1 26 36 26 17.9 12 8 4.5 4.5 13 1
BES 20.0-BS-1 32 45 30 20 15 10 5.5 5.5 15 2
BES 22.0-BS-1 32 45 30 21.9 15 10 5.5 5.5 15 2
BES 30.0-BS-1 42 55 38 30 18 10 5.5 5.5 19 1.5
BES 36.0-BS-1 48 61 44 35.9 18 10 5.5 5.5 22 1.5
Material: PA6
Snap clamp with positive stop

A B C D E F
BES 08.0-KB-5-F 12 20 15 8 7 22
BES 12.0-KB-5-F 16 24 18 12 8 30
BES 18.0-KB-5-F 21 29 24 18 14 30
BES 30.0-KR-5-F 33 41 34.5 30 24 35

Material: Plastic PC

Mounting clamps for tubular sensors
Clamp without positive stop for sensors 3 mm to M8

D
BES 03.0-KB-3 3
BES 04.0-KB-3 4
BES 05.0-KB-3 5
BES 06.5-KB-3 6.5
BES 08.0-KB-3 8
Clamp with positive stop for sensors 3 mm to M8
BES 08.0-KB-3-F 8
Material: PA6
Inductive
sensors
Clamp without positive stop for sensors M12 or M18 non-ush
D A B C D E Global
BES 12.0-KB-3 12 18 9 9.7 28 40 DC 3-wire
BES 18.0-KB-3 18 24 12 13.5 28 40 DC 3-/4-wire
Clamp with positive stop for sensors M12, M18 or M30 ush
BES 12.0-KB-3-F 12 18 9 9.7 28 40 DC 2-wire
BES 18.0-KB-3-F 18 24 12 13.5 28 40
AC/DC 2-wire
BES 30.0-KB-3-F 30 36 18 19.5 42 54
Material: PA6 AC 2-wire
Special
properties
Clamp with positive stop for vertical insertion of sensors
for M12 or M18 ush, with mounting plate Analog
distance
D A B measurement
BES 12.0-KB-3-F-SA 1 12 30.5 21.5
Accessories
BES 18.0-KB-3-F-SA 1 18 36.5 24.5
Pulse
Material: PA6 Extension
Sensor tester,
12.5 deep testing and
setting device
Clamp with positive stop for horizontal insertion of sensors Analog
switching
for M12 or M18 ush, with mounting plate device
D A B Assembly aids
for Uni and
BES 12.0-KB-3-F-SA 2 12 79 55 Unicompact
BES 18.0-KB-3-F-SA 2 18 85 58 sensors
Protective
Material: PA6 covering for
Unicompact
sensors
Protective nuts
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder
overview
www.balluff.com 759
SuperShorties "L" mounting bracket
BES 08-HW-4 12x17.5x16 mm

SuperShorties offset mounting bracket

BES 08-HW-5 26.5x7x12 mm
Universal "L" mounting bracket

A B C D E F G H
BES 516-MB-08 76 34 29 17 31 19 8 6
BES 516-MB-12 76 34 29 17 31 19 12 6
BES 516-MB-18 76 34 29 17 31 19 18 6
BES 516-MB-30 108 55 45 25 51 29 30 7
Material: Carbon steel
Slotted angle bracket (screws and washers included)

A B C D E F G H I
BES 08-HW-1 25 30 30 8.1 12 7 4 6 14
BES 12-HW-1 25 30 30 12.1 9 8.5 4 6 14
BES 16-HW-1 30 40 40 16.1 12 12 5 10 18
BES 18-HW-1 30 40 40 18.1 11 12 5 10 18
BES 24-HW-1 35 50 40 24.1 13 16 5 10 23
BES 30-HW-1 40 60 40 30.1 18 19 5 10 30
BES 36-HW-1 50 60 40 36.1 13 21 5 10 40
Material: Aluminum

Prox mounts for tubular sensors
Balluff provides a range of mounting solutions to decrease the need to

adjust sensors for correct sensing range to reduce downtime and setup
costs when sensors are replaced.
Initial Sensor Installation

Sensor is assembled into the Prox Mount tube and locked into place with
a plastic compression ring and metal nut. The Prox Mount and sensor
assembly is then mounted and adjusted as with any tubular sensor, but the
Prox Mount will remain in place on future sensor replacement tasks.
Advantages
Reduced downtime Quick Sensor Replacement Inductive
Reduced setup costs Simply loosen the metal nut, allowing the sensor to be quickly removed. sensors
Secure and accurate Install the new sensor into the Prox Mount mounting tube and lock into Global
sensor fastening place with the compression ring and nut. A positive stop designed into the DC 3-wire
Prox Mount tube ensures effortless repeatable sensor positioning.
DC 3-/4-wire
DC 2-wire
Prox Mounts with positive stop for sensors with thread length 30 mm
A B C D max. E F G AC/DC 2-wire
BES 05.0-KH-2S* M5x0.5 5 13 11 13 13 4 AC 2-wire

BES 08.0-KH-2S* M121 8 17.5 14.5 17 17 4
BES 12.0-KH-2S* M161 12 19.5 14.5 22 22 4 Special
properties
BES 12.0-KH-2S-M18 M181 12 19.5 14.5 22 22 4
BES 18.0-KH-2S* M241.5 18 20.5 15.5 30 30 5 Analog
BES 30.0-KH-2S* M361.5 30 20.5 15.5 41 41 6 distance
measurement
Material: CuZn, nickel plated
* Also available for welding environments (PTFE coated). Add /W to ordering code. Accessories
Ordering example: BES 12.0-KH-2S/W or BES 12.0-KH-2S/W-M18 Pulse

Allows smaller diameter sensor to replace larger when installed in this prox mount. Extension
Sensor tester,
testing and
setting device
Prox Mounts with positive stop for sensors with thread length 30 mm
Analog
A B C D max. E F G switching
device
BES 08.0-KH-11S/W M12x1 8 17.5 15.5 17 17 4
Assembly aids
BES 12.0-KH-11S/W M16x1 12 21 15.5 22 22 4 for Uni and
BES 18.0-KH-11S/W M24x1.5 18 21.5 15.5 30 30 5 Unicompact
sensors
Material: Steel, black PTFE coated Protective
Allows smaller diameter sensor to replace larger when installed in this prox mount. covering for
Note: Used with 2X Steelface sensors. Unicompact
sensors
Protective nuts
Positive stop
Prox Mounts with positive stop for sensors with thread length 40 mm or longer Tube switch
Banking screw
A B C D max. E F G Cushioned
BES 08.0-KH-2L* M121 8 34 14.5 17 17 4 mounts
BES 12.0-KH-2L* M161 12 30 14.5 22 22 4 Clamping
holder
BES 18.0-KH-2L* M241.5 18 40 18 30 30 5 overview
BES 30.0-KH-2L* M361.5 30 40 18 41 41 6
Material: CuZn, nickel plated
* Also available for welding environments (PTFE coated). Add /W to end of ordering code.
Ordering example: BES 12.0-KH-2L/W
Prox Mounts with enclosed end for sensors in sealed installation

A B C D max. E F G H
BES 08.0-KH-3L M121 8 34 14.5 17 17 4 0.5
BES 12.0-KH-3L M161 12 30 14.5 22 22 4 1
BES 18.0-KH-3L M241.5 18 40 19.5 30 30 5 1
Material: PBT berglass reinforced
www.balluff.com 761
Bunker Blocks
6.50
Bunker Block
H
Bunker Block Prox Mount Required A B C D E F G H J

J
F G
E
BES 12.0-KB-9L BES 08,0-KH-2L/W 38.1 19.05 31.75 15.88 M12 6.55 25 34 17
BES 16.0-KB-9L BES 12,0-KH-2L/W 38.1 19.05 31.75 15.88 M16 6.55 25 30 15
BES 24.0-KB-9L BES 18,0-KH-2L/W 50.8 25.4 38.1 19.05 M24 7.9 35 40 20
C
BES 36.0-KB-9L BES 30,0-KH-2L/W 63.5 31.75 50.8 25.4 M36 7.75 48 40 20
D
BES 12.0-KB-9S BES 08,0-KH-2S/W 38.1 19.05 31.75 15.88 M12 6.55 25 17.5 8.75
B
BES 16.0-KB-9S BES 12,0-KH-2S/W 38.1 19.05 31.75 15.88 M16 6.55 25 19.5 9.75
A
BES 24.0-KB-9S BES 18,0-KH-2S/W 50.8 25.4 38.1 19.05 M24 7.9 35 20.5 10.25
BES 36.0-KB-9S BES 30,0-KH-2S/W 63.5 31.75 50.8 25.4 M36 7.75 48 20.5 10.25
Material: Aluminum
Sensor clamp with positive stop
A B C D E F G H I K L
BES 08.0-KB-4-F 28 30 12 20 4 5 6 8 3.4 6 3.4
BES 12.0-KB-4-F 28 35 16 17 5.5 6 8 12 4.3 8 4
BES 18.0-KB-4-F 28 40 22 17 5.5 6 11 18 4.3 8 4
BES 30.0-KB-4-F 34 56 34 22 6 7 17 30 6.4 10 6
Material: Aluminum
Note for aluminum clamps with positive stop:
The switching distance of the proximity sensor may be reduced by use of these clamps. Note
this when using this clamping system.
Slotted clamp mount without positive stop

A B C D E F G
BES 08.0-KB-6 8 16.0 19.2 25.4 18.4 3.5 4-40 SHCS
BES 12.0-KB-6 12 25.4 19.2 38.1 25.0 6.6 10-32 SHCS
BES 18.0-KB-6 18 31.8 25.4 38.1 30.7 3.7 8-32 SHCS
BES 30.0-KB-6 30 50.8 33.1 63.5 51.6 6.0 1/4 SHCS
Material: Aluminum
Bunker BlockII without positive stop

A B C D E F G H
A
BES 08.0-KB-10* 12.7 28.58 35 8 5.5 17 6.45 4.5

BES 12.0-KB-10* 19.05 34.92 38.1 12 5.5 22 7 4.5
B
BES 18.0-KB-10* 25.4 38.1 38.1 18 6.5 26 7 5.5
BES 30.0-KB-10* 38.1 60 44.45 30 8.5 42 6.45 6.5
H Material: Steel, black zinc chromate coated
* Also available for welding environments (copper plated steel). Add /W to end of ordering code.
C
Ordering example: BES 12.0-KB-10/W.

G 8.0
Note: No Prox Mount is required. Sensor mounts directly in Bunker BlockII.

F E
3.3x4 M3x0.5-6H Typ 2 14.5

Bunker Block for R01Z block sensors 3.3x4
(23.22)
(38.1)
BES R01-SH-4-A BES R01-SH-4-B

(23.22)
13
(38.1)
13
Material: Aluminum Material: Aluminum

6
Overtop for retro-t Socket-style for new

45.5 7.94
61.5 installations installations 45.5 9.52
6.0x4
61.5 6.0x4

Weld Repel
Weld Repel
Weld cells are a hot and abusive environment where sensor cable
failure can be a daily occurrence. Extend the life of your sensor Weld Repel Wrap
cables and other equipment by using Balluff's Weld Repel line of
accessories. Weld Repel Jacket, Wrap and Sheets will provide BKS PW-26/20-SI-TR-03,5 1" wide x 12 ft clear silicone wrap
comprehensive protection for your vulnerable weld cell components. BKS PW-51/30-SI-TR-11 2" wide x 36 ft clear silicone wrap
Inductive
sensors
Global
DC 3-wire
DC 3-/4-wire
Weld Repel Sheets Weld Repel Jacket (order by the meter) DC 2-wire
Part Number BKS-PS-914/16-SI BKS-PS-914/16-SI-00,91 ID ID Rollsize

AC/DC 2-wire
Length Info. 3 ft x custom length in ft 3 ft x ft sheet BKS-PT-7/16-SI 1/4" dia. 7 mm 15 m
Thickness 1.58 mm 1.58 mm BKS-PT-10/16-SI 3/8" dia. 10 mm 15 m AC 2-wire
Max. Length 165 ft per roll 165 ft per roll BKS-PT-13/16-SI 1/2"dia.* 13 mm,* 15 m,*
BKS-PT-16/16-SI 5/8" dia.** 16 mm** 15 m** Special
Elongation 600% 600% properties
Tear Strength 150 PSI 150 PSI BKS-PT-19/16-SI 3/4" dia. 19 mm 15 m
BKS-PT-38/16-SI 1.5" dia. 38 mm 7.5 m Analog
Temperature -65C to 233C -65C to 233C distance
(-80F to 450F) (-80F to 450F) BKS-PT-50/16-SI 2" dia. 50 mm 7.5 m measurement
* Recommended for use with M12 (micro) single ended cables
** Recommended for use with M12 (micro) double ended cables Accessories
Recommended for use with M8 (nano) single ended cables Pulse
Recommended for use with M8 (nano) double ended cables Extension
Specications Sensor tester,
testing and
Temperature Rating -85F to 500F setting device
Electrical Insulation 400 Volts/mil thickness (wrap Analog
switching
Rating only) device
Tensile Strength 700 PSI (wrap only) Assembly aids
Elongation 300% (wrap only) for Uni and
WELD Jacket Unicompact
Material Clear Silicone sensors
WELD-JACKET-1/2" Silicone & berglass 1/2" diameter (by the foot) Protective
WELD-JACKET-3/4" Silicone & berglass 3/4" diameter (by the foot) covering for
Unicompact
sensors
Protective nuts
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder
overview
Bunker Block Bunker
B
Bun ock II withoutt positive stop
nker Block sto
top
Machined AL Prox Mount Required Description Copper Plated Steel Description
BES 12.0-KB-9L BES 08,0-KH-2L/W M8 sensors (40 mm+) BES 08.0-KB-10/W M8 sensors
BES 12.0-KB-9S BES 08,0-KH-2S/W M8 sensors (short)
www.balluff.com 763
Mounting brackets for 8x8 block sensors & seal nuts
Compression Block Mount for Set Screw Block Mount for

Description 8mm x 8mm Sensors 8mm x 8mm Sensors
Ordering Code BES Q08-KH-1 BES Q08-HW-4
Material Anodized Aluminum Anodized Aluminum
Description Pressure Seal Nut
pressure
area
permissible
tightening
torque 5 Nm
sensor
Ordering Code BES 08-DM-1

Fig. 1
Material This is used to seal pressure rated proximity switches. It seals against both
liquids and gases, and can be removed and tightened again up to ve times.
For use with BES 516-300-S289-B0-D-PU-
See Fig. 1 for mounting guidelines.

Nuts
Mounting Nuts
Description
Inductive
sensors
Global
DC 3-wire
DC 3-/4-wire
DC 2-wire
metal nut plastic nut
AC/DC 2-wire
AC 2-wire
Ordering Code Ordering code = Part no.
Special
properties
Material Metal nuts Part no. Material d wrench h
M81 500557 steel galvanized 15 13 4 Analog
M121 500462 Ms nickel plated 20 17 4 distance
measurement
M181 500152 Ms nickel plated 28 24 4
M301.5 500252 Ms nickel plated 42 36 5 Accessories
Pulse
Stainless steel nuts Extension
Sensor tester,
M50.5 605313 1.4305 (303) 8.9 8 2.7 testing and
M121 636981 1.4305 (303) 20 17 4 setting device
M181 636982 1.4301 (304) 28 24 4 Analog
switching
M301.5 636983 1.4401 (304) 42 36 5 device
Assembly aids
Plastic nuts for Uni and
Unicompact
M121 507936 PA 6.6 19.7 17 6 sensors
M181 606841 PA 6.6 28 24 8 Protective
M301.5 covering for
610292 PA 6.6 40 36 8 Unicompact
sensors
Protective nuts
Spring type lockwasher for M5 sensors: part no. 710256
Positive stop
Tube switch
Banking screw
Cushioned
mounts
Clamping
holder
overview
www.balluff.com 765
Mounting brackets for block sensors
Description Q40 Optional Metal Mounting Bracket

Ordering Code BES Q40-HW-2
Slotted Mounting Bracket

BES Q40-HW-1*
Material: Aluminum
Protection Cap
BES Q40-SH-2*
Material: PA 6
Protective Cover
BES Q40-SH-1*
For use with
BES Q40KFU-...A-...
Material: Coated brass
*Consult factory for dimensions

Sensor protection devices
Ceramic Faces
Diameter (mm) Thickness (mm)
604094 M8x1 5.8 0.3
619341 M12x1 10.4 0.3
505933 M18x1 15.2 0.5
634036 M30x1.5 27.9 0.5
* An epoxy similar to Loctite 480-40 is recommended.
Ceramic face Protects sensor face from weld spatter and abrasives.
Minimal sensing distance affect (0.3-0.5 mm) Inductive
Held in place with epoxy* sensors
Extends life of sensor Global
Provides physical and thermal protection to sensor face DC 3-wire
DC 3-/4-wire
DC 2-wire
AC/DC 2-wire
AC 2-wire
Special
properties
Analog
distance
measurement
Cushioned Prox Mount Accessories

Nut Flats B C D E Pulse
Extension
BESA 08-CM* M8x1 22 M16x1.5 11 10 19
Sensor tester,
BESA 12-CM* M12x1 29 M22x1.5 15 10 19 testing and
BESA 18-CM* M18x1 35 M30x1.5 15 10 25 setting device
BESA 30-CM* M30x1.5 51 M47x1.5 25 15 25 Analog
switching
* Above part numbers are for shielded sensors. For unshielded sensors, alter part number in the device
following manner: BESA ...-N-CM. Assembly aids
for Uni and
Unicompact
sensors
Protective
covering for
Unicompact
sensors
For applications where impact to the sensor by
Protective nuts
the target is inevitable, cushioned Prox Mounts
Positive stop
extend the life of the sensor by allowing up to Tube switch
15mm of target overtravel. D = travel distance. Banking screw
Sensor returns to original location after intrusion Cushioned
is removed. mounts
Clamping
holder
overview
www.balluff.com 767
Capacitive
Sensors
Capacitive sensors for object detection
Balluff capacitive sensors are used for object and level detection.
They measure all materials even non-conductive ones such as
liquids, granules and powders in direct contact or through a
container wall. Difcult environments such as high temperature and
pressure, stainless steel and Teon housing or a wide supply voltage
are not a problem for the capacitive sensors. These sensors are
available in different designs, including particularly small versions and
adhesive sensors.
The SmartLevel is the ideal level sensor for water based conductive
media. This is because it compensates for humidity, foam and
deposits of any kind, even through thick glass and plastic walls.

Capacitive Sensors
Contents
Capacitive sensors
Introduction 770
Sensors in use 772

Mini-sensors 780
Cylinder design 781
Disk designs 784
Standard sensors 786
Cylinder designs 787
Disk designs 795
Block designs 797
Capacitive sensors for level detection

Standard sensors 803
SmartLevel sensors 814
Disk designs 822
Block designs 824
Capacitive sensors with special properties

High temperature rated sensors 828
High pressure rated sensor 830
Flexible adhesive sensor 831
AC/DC 2-wire sensors 832
Capacitive sensors for analog distance measurement

Standard sensor 837
Cylinder design 837
Basic
information
Special accessories for capacitive sensors and denitions
Sensor amplier 841 can be found
on page 952.
Adapters 848
Connection switching diagrams 849
www.balluff.com 769
Capacitive Sensors
It would be hard to imagine not having capacitive sensors in

industrial automation, because they bring reliability to object and
level detection. Balluff capacitive sensors show what they can do in
situations where other capacitive sensors reach their limit.
With extreme precision, BCS sensors check:

Stack height
Level
Presence
Volume
In doing so, they are not affected by dust, reection or object

properties and color. And they also measure objects with absolute
reliability through glass and plastic walls, without being impeded by
external factors.
Balluff capacitive sensors provide The ideal level sensor,

more solutions to solve SmartLevel not only sees
challenging applications. through thicker glass and plastic
walls, it also compensates for
moisture, foam and deposits.
SmartLevel is able to provide
solutions in applications that
would have been impossible
before.

Capacitive Sensors
Capacitive
sensors
Introduction
Sensors in use
Product
overview
Capacitive
sensors for
object detection
Capacitive
sensors for
level detection
SmartLevel sensors take off in the Airbus A380 Capacitive

Airbus is equipping the rest rooms in its 4-engine large-body A380 sensors
with special
with a mixer tap. The heart of this exclusive system in the elegant properties
Airbus design are compact SmartLevel capacitive sensors from
Balluff. These enable passengers to conveniently select the desired Capacitive
water temperatures with the assistance of an LED indicator. The sensors for
analog distance
show-stopper: sensing errors are impossible, since SmartLevel measurement
sensors ignore clinging dirt, liquid lms and soap foam. Touching
the faucet triggers a switching operation, even if a wet paper towel Accessories
for capacitive
covers it. sensors
SMARTLEVEL
www.balluff.com 771
Capacitive Sensors
Sensors in use
Capacitive sensors measure metallic or non-metallic objects, levels

of granular materials, powder, viscous or liquid media. The sensor
can be used in direct contact with the object to be measured, or as
a contactless sensors. This is because they work extremely reliable,
even through container walls.
Whether contacting or contactless, the capacitive sensors from
Balluff are suited for difcult applications.
Transfer lines: Determining Water tanks: Regulating

Packaging lines: Checking packaging and volume number of pieces inow and controlling pumps
Industries
Handling and automation
Specialty machine construction
Automotive industry
Semiconductor industry
Electronics industry (circuit boards, CD and DVD manufacturing, etc.)
Food industry
Bottling and packaging
Chemical industry
Industrial cleaning technology
Bottling plants: Checking ll level and
Pharmaceuticals and medical technology
controlling the ejector station
Plastic and rubber industry
Timber and furniture industry
Paper and printing industry
Energy generation

Capacitive Sensors
Sensors in use
Wood processing: Measuring wood and thickness
Packaging systems:
Checking completeness
Capacitive
sensors
Introduction
Sensors in use
Product
overview
Capacitive
sensors for
object detection
Capacitive
sensors for
level detection
Capacitive
sensors
with special
properties
Capacitive
sensors for
analog distance
measurement
Accessories
for capacitive
sensors
www.balluff.com 773
Capacitive Sensors
Product overview
4 mm M50.5 6.5 mm 6.5 mm M81 M81

ush ush ush non-ush ush non-ush
Power supply
DC
AC/DC
Housing materials
Stainless steel
Plastic
PTFE (Teon)
Connection
Connector
Cable with connector
Cable
Special properties
Global series
High temperature rated
Function diagnostics
SmartLevel
Compensate for moisture,
foam and deposits
Penetrate glass or plastic

walls over 10 mm thick
Detection of aqueous to
highly conductive media
Virtually no adjustment or
cleaning required
Areas of application
Object detection Page 781 Page 781 Page 781 Page 782 Page 782 Page 782
Direct sensing of bulk product

and powdery media
Sensing bulk product and

powdered media through a con-
tainer wall up to approx. 4mm
Direct sensing of non-conduc-
tive liquid and paste-like media
Sensing non-conductive
liquids and paste-like media
through a container wall
up to approx. 4mm
Direct sensing of conductive
liquids (SmartLevel technology)

Capacitive Sensors
Product overview
10 mm 10 mm M121 M121 M181 M181 22 mm 30 mm

ush non-ush ush non-ush ush non-ush ush ush

Capacitive
sensors
Introduction
Page 790...791 Page 803...805 Page 791 Page 805...807 Sensors in use
Product
Page 829 overview
Capacitive
Page 815 sensors for
object detection
Capacitive
sensors for
level detection
Page 815
Capacitive
sensors
Page 815 with special
properties
Capacitive
Page 783 Page 783 Page 783 Page 791 Page 792 Page 792 sensors for
analog distance
+ 789...791 measurement
Page Page
803...805 805...807 Accessories
for capacitive
sensors
Page Page
803...805 805...807
Page 815
www.balluff.com 775
Capacitive Sensors
Product overview
M301.5 M301.5 34 mm Disk designs Disc shapes Micro-Box

ush non-ush ush 18...30 mm 50 mm 16348 mm
Power supply
DC
AC/DC
Housing materials
Stainless steel
Plastic
PTFE (Teon)
Connection
Connectors
Cable with connector
Cable
Terminal housing
Special properties
Global series Page 792...793 Page 807...808 Page 793
High temperature rated Page 829
Pressure rated
Stick-on, exible
Degree of protection IP 68
SmartLevel
Compensate for moisture, Page 816 Page 823 Page 824
foam and deposits
Penetrate glass or plastic Page 816 Page 823 Page 824

walls over 10 mm thick (up to 8 mm)
Detection of aqueous to Page 816 Page 823 Page 824
highly conductive media
Virtually no adjustment or Page 816 Page 823 Page 824
cleaning required
Areas of application
Object detection Page 792...793 Page 793 Page 785+795 Page 796 Page 797
Direct sensing of bulk product Page 792...793 Page Page 793 Page 785+795 Page 796
and powder media (ush 807...808 (ush (ush (ush
installation) installation) installation) installation)
Sensing bulk product and Page 792...793 Page 793 Page 785+795 Page 796 Page 797
powdered media through a con-
tainer wall up to approx. 4 mm
Direct sensing of non-conduc- Page
tive liquid and paste-like media 807...808
Sensing non-conductive Page 792...793 Page 793 Page 785+795 Page 796 Page 797
liquids and paste-like media
through a container wall
up to approx. 4mm
Direct sensing of conductive Page 816
liquids (SmartLevel technology)
Detecting conductive liquids Page 816 Page 824

through a container wall even (up to 8 mm)
over 10 mm thick (SmartLevel
technology)

Capacitive Sensors
Product overview
Micro-Level M181, M181,

M121, R 3/8", R 3/8",
404010 mm 90164 mm 752 mm G 1/4", NPT 1/4" NPTF 3/8" NPTF 3/8"

Capacitive
sensors
Introduction
Sensors in use
Product
Page 799 overview
Page 815 Page 818...821 Page 813 Page 829
Page 810...812 Page 813 Page 829 Capacitive
Page 818...821 (10 bar) (6 bar) sensors for
object detection
Page 831
Page 813 Capacitive
sensors for
level detection
Page 825 Page 815 Page Capacitive

818...821 sensors
with special
properties
Page 825 Page 815
Capacitive
Page 825 Page 815 Page sensors for
analog distance
818...821 measurement
Page 825 Page 815 Page
818...821 Accessories
for capacitive
sensors
Page 799 Page 831
Page Page 813 Page 829
810...812
Page 799 Page 831
Page Page 813 Page 829

810...812
Page 799 Page 831
Page 815 Page

810...812
Page 825
www.balluff.com 777
Capacitive
Sensors
Industry standard capacitive sensors are M12 to M30 models.
For small parts detection or installation in tight mounting spaces,
however, smaller form factors are needed. The Balluff product line
therefore offers a large selection of sizes and form factors. The
small capacitive sensors can be calibrated remotely, simply using a
separate sensor amplier. And their rugged stainless steel housing
ensures reliability even under challenging conditions.
Capacitive sensors for object detection from Balluff employ a
straight-line electrical eld. These sensors detect solid bodies (e.g.
wafers, PCBs, cartons, paper stacks, bottles, plastic blocks and
plates) and sense liquids through walls made of glass and plastic
(thickness max. 4 mm). Advantage: The straight-line electrical eld
also enables media having a low dielectric constant to be detected.

Capacitive Sensors for Object Detection
Contents
Mini-sensors
Disk designs 784
Standard sensors
Disk designs 795
Block design housings 797
www.balluff.com 779
Mini-sensors
CD/DVD production: Checking stack height

During CD/DVD production, Capacitive sensors monitor the stacks of
CDs and DVDs on a spindle. As soon as the maximum stack height
is reached, the sensor sends a message that allows the nished
stack to be transported further to end packaging and the next empty
spindle to be prepared. And it does this with absolute reliability, with-
out allowing itself to be inuenced by the reective surface.

mini.s Capacitive Sensors for Object Detection
Mini-sensors, cylinder designs,
4 mm, M50.5, 6.5 mm
Size 4 mm M50.5 6.5 mm

Installation type Flush Flush Flush
Rated switching distance sn 0.11 mm 0.11 mm 0.11.5 mm
With sensor amplier Ordering code BCS0010 BCS0011 BCS0012
Part number BCS G04T4D-XXS10C-EP02-GZ01-002 BCS M05T4C-XXS10C-EP02-GZ01-002 BCS G06T4B-XXS15C-EP02-GZ01-002
Switching frequency f 100 Hz 100 Hz 100 Hz Capacitive
Sensing surface PTFE PTFE PTFE Capacitive
sensors for
Cover POM POM POM object detection
Connection 2 m PUR cable, 2 m PUR cable, 2 m PUR cable, Mini-sensors
30.14 mm 30.14 mm 30.14 mm Standard
sensors
Sensor ampliers for 4 M50.5 6.5

capacitive mini-sensors Capacitive
sensors for
can be found on page 841. level detection
18
3
29
29
Capacitive
8 sensors
5 with special
properties
Capacitive
18.6
sensors for
analog distance
18.6
18.6
measurement
8
8
8 Accessories
for capacitive
sensors
www.balluff.com 781
6.5 mm, M81
Size 6.5 mm M8 1 M8 1
Installation type Not ush Flush Not ush
Rated switching distance sn 0.13 mm 0.11.5 mm 0.13 mm
With sensor amplier Ordering code BCS0013 BCS0014 BCS0015
Part number BCS G06T4B-XXS30G-EP02-GZ01-002 BCS M08T4C-XXS15C-EP02-GZ01-002 BCS M08T4C1-XXS30G-EP02-GZ01-002
Sensing surface PTFE PTFE PTFE
Cover POM POM POM
Connection 2 m PUR cable, 2 m PUR cable, 2 m PUR cable,
30.14 mm 30.14 mm 30.14 mm
Sensor ampliers for 6.5 M81 M81

capacitive mini-sensors
3
can be found on page 841.
3
4
16
4
25
25
4
13
4
13
18.6
18.6
18.6
8
8
8

10 mm, M121
10 mm 10 mm M121 M121
Flush Not ush Flush Not ush
0.14 mm 18 mm 0.14 mm 18 mm
BCS0016 BCS0017 BCS0018 BCS0019
BCS G10T4B-XXS40C-EP02-GZ01-002 BCS G10T4C-XXS80G-EP02-GZ01-002 BCS M12T4D-XXS40C-EP02-GZ01-002 BCS M12T4D1-XXS80G-EP02-GZ01-002
48 V DC 48 V DC 48 V DC 48 V DC
75 V DC 75 V DC 75 V DC 75 V DC
30+80 C 30+80 C 30+80 C 30+80 C
100 Hz 100 Hz 100 Hz 100 Hz Capacitive
Capacitive
PTFE PTFE PTFE PTFE sensors for
POM POM POM POM object detection
2 m PUR cable, 2 m PUR cable, 2 m PUR cable, 2 m PUR cable, Mini-sensors
30.14 mm 30.14 mm 30.14 mm 30.14 mm Standard
sensors
10 10 M121 M121
Capacitive
sensors for
4
level detection
4
20
4
20
30
4
Capacitive
30
sensors
with special
5
17 17
properties
5
Capacitive
18.6
sensors for
18.6
analog distance
18.6
measurement
18.6
8
8
8 Accessories
8 for capacitive
sensors
m
m
www.balluff.com 783
Mini-sensors, disk designs,
18 mm
Size 182.5 mm 184 mm 1810 mm

With sensor amplier Ordering code BCS001A BCS001C BCS001E
Part number BCS D18T403-XXS30C-EP02-GZ01-002 BCS D18T404-XXS50C-EP02-GZ01-002 BCS D18T407-XXS50C-EP02-GZ01-002
Connection 2 m PVC cable, 2 m PUR cable, 2 m PUR cable,
30.09 mm 30.14 mm 30.14 mm
Sensor ampliers for 2.5 4 10 M35

capacitive mini-sensors
18
18
18
18.6
18.6
18.6
8
8
8
mm

Mini-sensors, disk designs,
22 mm, 30 mm
224 mm 2210 mm 304 mm 3010 mm

110 mm 110 mm 115 mm 1...15 mm
BCS001F BCS001H BCS001J BCS001K
BCS D22T405-XXS10C-EP02-GZ01-002 BCS D22T408-XXS10C-EP02-GZ01-002 BCS D30T406-XXS15C-EP02-GZ01-002 BCS D30T409-XXS15C-EP02-GZ01-002
48 V DC 48 V DC 4...8 V DC 48 V DC
75 V DC 75 V DC 75 V DC 75 V DC
30+80 C 30+80 C 30+80 C 30+80 C
100 Hz 100 Hz 100 Hz 100 Hz Capacitive
Capacitive
PTFE PTFE PTFE PTFE sensors for
2 m PUR cable, 2 m PUR cable, 2 m PUR cable, 2 m PUR cable, object detection
30.14 mm 30.14 mm 30.14 mm 30.14 mm Mini-sensors
Standard
sensors
4 10 M35 4 10 M35
Capacitive
sensors for
22
22
30
30
level detection
Capacitive
sensors
with special
properties
18.6
18.6
18.6
18.6
Capacitive
8 8 sensors for
8 8 analog distance
measurement
Accessories
for capacitive
sensors
www.balluff.com 785
Sensors in use
Paper and printing industry:

Stack height control in sheet-fed offset printing
Integrated in printing, folding and bookbinding machines, capacitive
sensors not only check stack height, but also provide for perfect
stacking of the papers, so that there is as little waste as possible
during further processing.
Despite a dirty environment (due to paper dust and anti-set-off spray
powder), the sensor works perfectly. Laterally or from above, it mea-
sures stack heights even in small increments, and raises and lowers
the stack as soon as it recognizes its height.
In the paper cutting machine, the capacitive sensor also measures
the width of the stack to be cut, so that the cutting pressure of the
cutting knife can be set in relation to it. In doing so, it proves to be
not only insensitive to dust, but also completely uninuenced by dif-
ferent colors of paper.

Standard sensors, cylinder designs, DC 3-wire,
6.5 mm
Size 6.5 mm 6.5 mm 6.5 mm

Installation type Flush Flush Not ush
Rated switching distance sn 0.11.5 mm 0.11.5 mm 0.13 mm
PNP, NO Ordering code BCS001R @ BCS001L ! BCS0022 @
Part number BCS G06T4D2-PSM15C-S49G BCS G06T4E1-PSM15C-EP02 BCS G06T4D2-PSM30G-S49G
PNP, NC Ordering code BCS001T & BCS001M % BCS0023 &
Part number BCS G06T4D2-POM15C-S49G BCS G06T4E1-POM15C-EP02 BCS G06T4D2-POM30G-S49G
NPN, NO Ordering code BCS001U $ BCS001N # BCS0024 $
Part number BCS G06T4D2-NSM15C-S49G BCS G06T4E1-NSM15C-EP02 BCS G06T4D2-NSM30G-S49G Capacitive
NPN, NC Ordering code BCS001W ) BCS001P * BCS0025 ) sensors
Part number BCS G06T4D2-NOM15C-S49G BCS G06T4E1-NOM15C-EP02 BCS G06T4D2-NOM30G-S49G
Supply voltage UB 1130 V DC 1130 V DC 1130 V DC Capacitive
sensors for
Voltage drop Ud at Ie 2V 2V 2V object detection
Rated insulation voltage Ui 75 V DC 75 V DC 75 V DC Mini-sensors
Output current max. 50 mA 50 mA 50 mA Standard
sensors
Polarity reversal protected/output miswiring protected/ Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes
Capacitive
short-circuit protected sensors for
Ambient temperature Ta 10+70 C 10+70 C 10+70 C level detection
Output function indicator Yellow LED Yellow LED Yellow LED Capacitive
sensors
Degree of protection as per IEC 60529 IP 65 IP 65 IP 65 with special
properties
Capacitive
Cover PA POM PA sensors for
Connection M8 connector, 3-pin 2 m PUR cable, 326 AWG M8 connector, 3-pin analog distance
measurement
Suggested mating cable BCC M313-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050
Accessories
for capacitive
! = Connection-Switching diagram, see page 849. 6.5 6.5 6.5
sensors
Additional cable lengths on request. 3
30.8
30.8
30.8
42
54
54
sn multi-turn/ sn multi-turn/
LED sn multi-turn/ LED
LED
www.balluff.com 787
6.5 mm, M81
Size 6.5 mm M81 M81

Installation type Not ush Flush Flush
Rated switching distance sn 0.13 mm 0.11.5 mm 0.11.5 mm
PNP, NO Ordering code BCS001Y ! BCS002A @ BCS0026 !
Part number BCS G06T4E1-PSM30G-EP02 BCS M08T4E2-PSM15C-S49G BCS M08T4E1-PSM15C-EP02
PNP, NC Ordering code BCS001Z % BCS002C & BCS0027 %
Part number BCS G06T4E1-POM30G-EP02 BCS M08T4E2-POM15C-S49G BCS M08T4E1-POM15C-EP02
NPN, NO Ordering code BCS0020 # BCS002E $ BCS0028 #
Part number BCS G06T4E1-NSM30G-EP02 BCS M08T4E2-NSM15C-S49G BCS M08T4E1-NSM15C-EP02
NPN, NC Ordering code BCS0021 * BCS002F ) BCS0029 *
Part number BCS G06T4E1-NOM30G-EP02 BCS M08T4E2-NOM15C-S49G BCS M08T4E1-NOM15C-EP02
Voltage drop Ud at Ie 2V 2V 2V
Output current max. 50 mA 50 mA 50 mA
short-circuit protected
Cover POM Stainless steel POM
Connection 2 m PUR cable, 326 AWG M8 connector, 3-pin 2 m PUR cable, 326 AWG
Suggested mating cable BCC M313-0000-10-001-PX43T2-050
! = Connection-Switching diagram, see page 849. 6.5 M81 M81

3
30.8
30.8
30.8
36
4
42
42
42
54
13
13
sn multi-turn/
LED sn multi-turn/ sn multi-turn/
LED LED

Standard sensors, cylinder designs, DC 3-wire, M81, 10
mm, M121
M81 M81 10 mm M121 M121

Not ush Not ush Flush Flush Flush
0.13 mm 0.13 mm 14 mm 14 mm 14 mm
BCS002M @ BCS002H ! BCS002T ! BCS0037 @ BCS002Z !
BCS M08T4E2-PSM30G-S49G BCS M08T4E1-PSM30G-EP02 BCS G10T4H-PSM40C-EP02 BCS M12T4D2-PSM40C-S04G BCS M12T4G1-PSM40C-EP02
BCS002N & BCS002J % BCS002U % BCS0038 & BCS0030 %
BCS M08T4E2-POM30G-S49G BCS M08T4E1-POM30G-EP02 BCS G10T4H-POM40C-EP02 BCS M12T4D2-POM40C-S04G BCS M12T4G1-POM40C-EP02
BCS002P $ BCS002K # BCS002W # BCS0039 $ BCS0031 #
BCS M08T4E2-NSM30G-S49G BCS M08T4E1-NSM30G-EP02 BCS G10T4H-NSM40C-EP02 BCS M12T4D2-NSM40C-S04G BCS M12T4G1-NSM40C-EP02 Capacitive
BCS002R ) BCS002L * BCS002Y * BCS00AC ) BCS0032 * sensors
BCS M08T4E2-NOM30G-S49G BCS M08T4E1-NOM30G-EP02 BCS G10T4H-NOM40C-EP02 BCS M12T4D2-NOM40C-S04G BCS M12T4G1-NOM40C-EP02
1130 V DC 1130 V DC 1235 V DC 1235 V DC 1235 V DC Capacitive
sensors for
2V 2V 0.8 V 1.5 V 0.8 V object detection
75 V DC 75 V DC 75 V DC 75 V DC 75 V DC Mini-sensors
50 mA 50 mA 200 mA 200 mA 200 mA Standard
sensors
10 mA 10 mA 10 mA 10 mA 10 mA
Capacitive
sensors for
10+70 C 10+70 C 30+70 C 30+70 C 30+70 C level detection
100 Hz 100 Hz 100 Hz 100 Hz 100 Hz
Yellow LED Yellow LED Yellow LED Yellow LED Yellow LED Capacitive
sensors
IP 65 IP 65 IP 65 IP 65 IP 65 with special
properties
PTFE PTFE PTFE PTFE PTFE
Capacitive
Stainless steel POM POM PA POM sensors for
M8 connector, 3-pin 2 m PUR cable, 326 AWG 2 m PUR cable, 326 AWG M12 connector, 4-pin 2 m PUR cable, 326 AWG analog distance
measurement
BCC M313-0000-10-001-PX43T2-050 BCC M415-0000-1A-003-PX44T2-050
Accessories
for capacitive
M81 M81 10 M121 M121 sensors
3
3
30.8
30.8
36
4
4
42
42
4
4
43
50
50
54
13
60
13 17 17
sn multi-turn/ sn multi-turn/ sn
10
LED
LED
LED
LED sn
sn LED
www.balluff.com 789
M12x1
Size M121 M121 M121

PNP, NO Ordering code BCS00P0 @ BCS00R4 ! BCS00PJ @
Part number BCS M12B4G2-PSC40D-S04K BCS M12B4I1-PSC40D-EP02 BCS M12BBG2-PSC40D-S04K
PNP, NC Ordering code BCS00P1 ^ BCS00P8 % BCS00PK ^
Part number BCS M12B4G2-POC40D-S04K BCS M12B4I1-POC40D-EP02 BCS M12BBG2-POC40D-S04K
NPN, NO Ordering code BCS00P2 $ BCS00P9 # BCS00PL $
Part number BCS M12B4G2-NSC40D-S04K BCS M12B4I1-NSaC40D-EP02 BCS M12BBG2-NSC40D-S04K
NPN, NC Ordering code BCS00P3 ( BCS00PA * BCS00PM (
Part number BCS M12B4G2-NOC40D-S04K BCS M12B4I1-NOC40D-EP02 BCS M12BBG2-NOC40D-S04K
Supply voltage UB 10... 30 V DC 10... 30 V DC 10... 30 V DC
Voltage drop Ud at Ie 1.5 V 1.5 V 1.5 V
Supply voltage/Output function indicator Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED
Material Housing Stainless steel Stainless steel PBT
Cover PA 12, PBT PA 12 PA 12, PBT
Suggested mating cable BCC M415-0000-1A-003-VX44T2-050-C013 BCC M415-0000-1A-003-VX44T2-050-C013
! = Connection-Switching diagram, see page 849. M121 M121 M121

41
39
49
61
17 17 17
75
75
LED LED
sn sn
LED
sn

Mx12, M18x1
M121 M181 M181 M181 M181

14 mm 28 mm 28 mm 28 mm 28 mm
BCS00PU ! BCS00MF @ BCS00LK ! BCS00M8 @ BCS00NZ !
BCS M12BBI1-PSC40D-EP02 BCS M18B4I3-PSC80D-S04K BCS M18B4N1-PSC80D-EP02 BCS M18BBI3-PSC80D-S04K BCS M18B4N1-PSC80D-EP02
BCS00PW % BCS00M4 ^ BCS00LR % BCS00MH ^ BCS00M1 %
BCS M12BBI1-POC40D-EP02 BCS M18B4I3-POC80D-S04K BCS M18B4N1-POC80D-EP02 BCS M18BBI3-POC80D-S04K BCS M18BBN1-POC80D-EP02
BCS00PY # BCS00M5 $ BCS00LN # BCS00MJ $ BCS00M2 #
BCS M12BBI1-NSC40D-EP02 BCS M18B4I3-NSC80D-S04K BCS M18B4N1-NSC80D-EP02 BCS M18BBI3-NSC80D-S04K BCS M18BBN1-NSC80D-EP02 Capacitive
BCS00PZ * BCS00M6 ( BCS00LP * BCS00MK ( BCS00M3 * sensors
BCS M12BBI1-NOC40D-EP02 BCS M18B4I3-NOC80D-S04K BCS M18B4N1-NOC80D-EP02 BCS M18BBI3-NOC80D-S04K BCS M18BBN1-NOC80D-EP02
10... 30 V DC 10... 30 V DC 10... 30 V DC 10... 30 V DC 10... 30 V DC Capacitive
sensors for
1.5 V 1.5 V 1.5 V 1.5 V 1.5 V object detection
75 V DC 75 V DC 75 V DC 75 V DC 75 V DC Mini-sensors
100 mA 100 mA 100 mA 100 mA 100 mA Standard
sensors
15 mA 15 mA 15 mA 15 mA 15 mA
Capacitive
sensors for
25+85 C 25+85 C 25+85 C 25+85 C 25+85 C level detection
100 Hz 100 Hz 100 Hz 100 Hz 100 Hz
Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Capacitive
sensors
IP 67 IP 67 IP 67 IP 67 IP 67 with special
properties
PBT Stainless steel Stainless steel PBT PBT
PBT PBT PBT PBT PBT
Capacitive
PA 12 PA 12, PBT PA 12 PA 12, PBT PA 12 sensors for
2 m PUR cable, 326 AWG M12 connector, 4-pin 2 m PUR cable, 322 AWG M12 connector, 4-pin 2 m PUR cable, 322 AWG analog distance
measurement
Accessories
M181
for capacitive
M121 M181 M181 M181
sensors
47
53
61
52
60
61
75
17
88.5
75.5
88.5
24 24 24 24
LED LED
sn sn
M121 M121
LED LED LED
sn sn sn
www.balluff.com 791
22 mm, 30 mm, M301.5
Size 22 mm 30 mm M301.5
PNP, NO Ordering code BCS0033 ! BCS00MR @
Part number BCS D22V4M1-PSC10C-EV02 BCS M30B4I2-PSC15D-S04K
PNP, NC Ordering code BCS0034 % BCS00MT ^
Part number BCS D22V4M1-POC10C-EV02 BCS M30B4I2-POC15D-S04K
PNP, NO/NC, Ordering code BCS004H !
switch selectable Part number BCS D30B4M3-PPC20C-EP02
NPN, NO Ordering code BCS0035 # BCS00MU $
Part number BCS D22V4M1-NSC10C-EV02 BCS M30B4I2-NSC15D-S04K
NPN, NC Ordering code BCS0036 * BCS00MW (
Part number BCS D22V4M1-NOC10C-EV02 BCS M30B4I2-NOC15D-S04K
NPN, NO/NC, Ordering code BCS004J #
switch selectable Part number BCS D30B4M3-NPC20C-EP02
Supply voltage UB 1035 V DC 1035 V DC 10...30 V DC
Supply voltage/Output function indicator No/Yellow LED Green LED/Yellow LED Green LED/Yellow LED
Sensing surface PVC PBT PBT
Cover PVC PBT, PE PA 12, PBT
Connection 2 m PVC cable, 324 AWG 2 m PUR cable, 322 AWG M12 connector, 4-pin
! = Connection-Switching diagram, see page 849. 22 30 M301.5

54
66.5
65
51
79
36
15.5
M121
NO/NC
sn
V 6 LED
sn LED LED sn

M301.5, 34 mm
M301.5 M301.5 M301.5 34 mm 34 mm

215 mm 215 mm 215 mm 125 mm 125 mm
BCS00N2 ! BCS00NA @ BCS00NM !
BCS M30B4I1-PSC15D-EP02 BCS M30BBI2-PSC15D-S04K BCS M30BBI1-PSC15D-EP02
BCS00N3 % BCS00NC ^ BCS00NN %
BCS M30B4I1-POC15D-EP02 BCS M30BBI2-POC15D-S04K BCS M30BBI1-POC15D-EP02
BCS004Z @ BCS004W !
BCS G34VVM2-PPM20C-S04G BCS G34VVM3-PPM20C-EP02 Capacitive
BCS00N4 # BCS00NE $ BCS00NP # sensors
BCS M30B4I1-NSC15D-EP02 BCS M30BBI2-NSC15D-S04K BCS M30BBI1-NSC15D-EP02
BCS00N5 * BCS00NF ( BCS00NR * Capacitive
sensors for
BCS M30B4I1-NOC15D-EP02 BCS M30BBI2-NOC15D-S04K BCS M30BBI1-NOC15D-EP02 object detection
BCS0050 $ BCS004Y # Mini-sensors
BCS G34VVM2-NPM20C-S04G BCS G34VVM3-NPM20C-EP02 Standard
sensors
10...30 V DC 10...30 V DC 10...30 V DC 1035 V DC 1035 V DC
1.5 V 1.5 V 1.5 V 1.8 V 1.8 V Capacitive
75 V DC 75 V DC 75 V DC 75 V DC 75 V DC sensors for
level detection
100 mA 100 mA 100 mA 300 mA 300 mA
15 mA 15 mA 15 mA 15 mA 15 mA
Capacitive
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes sensors
with special
properties
25+85 C 25+85 C 25+85 C 30+70 C 30+70 C
100 Hz 100 Hz 100 Hz 100 Hz 100 Hz
Capacitive
Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED sensors for
IP 67 IP 67 IP 67 IP 64 IP 64 analog distance
measurement
Stainless steel PBT PBT PVC PVC
PBT PBT PBT PVC PVC Accessories
PA 12, PBT PA 12, PBT PA 12, PBT PBT, PE PBT, PE for capacitive
sensors
2 m PUR cable, 322 AWG M12 connector, 4-pin 2 m PUR cable, 322 AWG M12 connector, 4-pin 2 m PUR cable, 322 AWG
BCC M415-0000-1A-003-VX44T2-050-C013 BCC M415-0000-1A-001-PX43T2-050
M301.5 M301.5 M301.5 34 34

56
51
50
50
56
66.5
66.5
66.5
66.5
36
79
36 36
20.5
15.5
NO/NC NO/NC
sn
sn
V 6
LED LED
6
LED
V
LED
sn sn sn LED
www.balluff.com 793
Standard sensors in use
Food and pharmaceutical industry:

presence check in the packaging process
If, for example, bottles in individual cartons are to be packaged
perfectly, capacitive sensors optimize the packaging process. In this
way, the BCS checks whether the bottle is present as desired after
packaging, without the carton wall being able to impede the pro-
cess. In doing so, it makes no difference whether the bottle is made
of glass or plastic. Capacitive sensors provide a quick, reliable result,
which is also more cost-effective than a weighing system.
Special machine construction:

Determining numbers of pieces
Whether screws, nuts or springs made of metallic or non-metallic
material, capacitive sensors check for completeness. To do so, they
accurately determine the exact number of pieces, without wear or
contact through container walls up to 4 mm thick. If the tube is even
thicker, there are other capacitive solutions available from us.

Standard sensors, disk designs, DC 3-wire,
22 mm, 30 mm
Size 224 mm 224 mm 304 mm

Rated switching distance sn 6 mm 10 % 6 mm 10 % 215 mm
PNP, NO Ordering code BCS003H ! BCS00HK ! BCS003A !
Part number BCS D22T403-PSM60C-EP02 BCS D22T402-PSM60C-EP02 BCS D30T401-PSC15C-EP02
PNP, NC Ordering code BCS003C %
Part number BCS D30T401-POC15C-EP02
NPN, NO Ordering code BCS003J # BCS003E #
Part number BCS D22T403-NSM60C-EP02 BCS D30T401-NSC15C-EP02 Capacitive
NPN, NC Ordering code BCS003F * sensors
Part number BCS D30T401-NOC15C-EP02
Supply voltage UB 1230 V DC 1230 V DC 1035 V DC Capacitive
sensors for
Voltage drop Ud at Ie 0.8 V 0.8 V 0.8 V object detection
Rated insulation voltage Ui 75 V DC 75 V DC 75 V DC Mini-sensors
Output current max. 300 mA 300 mA 300 mA Standard
sensors
short-circuit protected Capacitive
sensors for
Ambient temperature Ta 30+70 C 30+70 C 30+70 C level detection
Output function indicator Yellow LED Capacitive
sensors
Degree of protection as per IEC 60529 IP 64 IP 64 IP 67 with special
properties
Capacitive
Connection 2 m PUR cable, 326 AWG 2 m PUR cable, 326 AWG 2 m PUR cable, 326 AWG sensors for
Suggested mating cable analog distance
measurement
! = Connection-Switching diagram, see page 849. 4 16 4 Accessories

for capacitive
4
sensors
M5
22
30
22
LED sn multi-turn/
LED
www.balluff.com 795
Standard sensors, disk designs, DC 3-wire,
50 mm
Size 5010 mm 5010 mm

PNP/NPN and NO/NC, Ordering code BCS003L 1 BCS003K 1
wiring selected Part number BCS D50OO03-YPC25C-S49G BCS D50OO02-YPC25C-EV02
Output current max. 150 mA 150 mA
Polarity reversal protected/output miswiring protected/ Yes/Yes/Yes Yes/Yes/Yes
Material Housing POM POM
Sensing surface POM POM
Cover POM POM
! = Connection-Switching diagram, see page 849. 42 42

NO/ PNP/ NO/ PNP/
Additional cable lengths on request. NC NPN 50 NC NPN
50
5.5
5.5
LED
LED
10
10
sn

Standard sensors, block designs, DC 3-wire,
16348 mm MicroBox
Size 16348 mm MicroBox 16348 mm MicroBox

PNP, NO Ordering code BCS0055 @ BCS0051 !
Part number BCS R08RR01-PSM80C-EP00,2-GS49 BCS R08RR01-PSM80C-EP02
PNP, NC Ordering code BCS0056 & BCS0052 %
Part number BCS R08RR01-POM80C-EP00,2-GS49 BCS R08RR01-POM80C-EP02
NPN, NO Ordering code BCS0057 $ BCS0053 #
Part number BCS R08RR01-NSM80C-EP00,2-GS49 BCS R08RR01-NSM80C-EP02 Capacitive
NPN, NC Ordering code BCS0058 ) BCS0054 * sensors
Part number BCS R08RR01-NOM80C-EP00,2-GS49 BCS R08RR01-NOM80C-EP02
Supply voltage UB 1230 V DC 1230 V DC Capacitive
sensors for
Voltage drop Ud at Ie 1.5 V 1.5 V object detection
Rated insulation voltage Ui 75 V DC 75 V DC Mini-sensors
Output current max. 50 mA 50 mA Standard
sensors
Capacitive
Ambient temperature Ta 30+70 C 30+70 C level detection
Output function indicator Yellow LED Yellow LED Capacitive
sensors
Degree of protection as per IEC 60529 IP 67 IP 67 with special
properties
Material Housing PP PP
Sensing surface PP PP
Capacitive
Cover PP PP sensors for
Connection 0.2 m PUR cable with M8 3-pin connector 2 m PUR cable, 326 AWG analog distance
measurement
Accessories
for capacitive
! = Connection-Switching diagram, see page 849. 8 16 8 16 sensors
34
34
3.2
3.2
10 10
30
LED LED
sn sn
Mounting frame included in delivery Mounting frame included in delivery
www.balluff.com 797
404010 mm, Uniat
The cost-effective Global series now also provides Switching distance

capacitive sensors in a at design: in compact plastic housing in Switching distance can be set precisely from 1 to 20 mm, with a
40x40x10 mm. With cable or pigtail connection. And there is an LED 20-turn potentiometer.
display for supply voltage and switching status. The capacitive Q40 Uniat provides a PNP or NPN output, which is
available as either normally open or as normally closed.
Applications
The BCS capacitive sensors Q40 Uniat detect oil or granular Installation
material through non-metallic walls up to 6 mm thick. Through its The capacitive sensors BCS Q40 Uniat can be installed ush and
installation on the container bottom, it becomes the ideal leak can be secured in different ways with screws, cable ties or angle
detector. brackets. In addition, its universal 45 cable output provides for ad-
ditional exibility.
Application examples
Checking volume in infeed systems Mounting options
Checking content in transport packaging M4 through bolts
Detecting ll level through containers M3 with double-sided anti-rotation element for nuts
Detecting leaks Sunken M4 assembly with screw DIN 920
Angle brackets available for Balluff assembly system
Cable tie to secure on containers and pipes
The Uniat, which can be installed ush, has

a 45 cable outlet and LEDS visible from all
sides. Due to this, it can be integrated very
easily in every position.

404010 mm, Uniat
Size 404010 mm Uniat 404010 mm Uniat

Rated switching distance sn 1...20 mm 1...20 mm
PNP/NPN and NO/NC, Ordering code BCS00TR 1
wiring selected Part number BCS Q40BBAA-GPC20C-EP02
PNP, NO Ordering code BCS00U6 @
Part number BCS Q40BBAA-PSC20C-EP00,3-GS49
PNP, NC Ordering code BCS00U5 ^
Part number BCS Q40BBAA-POC20C-EP00,3-GS49 Capacitive
Supply voltage UB 10... 30 V DC 10... 30 V DC sensors
Voltage drop Ud at Ie 2.5 V 2.5 V
Rated insulation voltage Ui 75 V DC 75 V DC Capacitive
sensors for
Output current max. 100 mA 100 mA object detection
No-load supply current I0 max. 15 mA 15 mA Mini-sensors
Polarity reversal protected/output miswiring protected/ No/No/Yes Yes/Yes/Yes Standard
short-circuit protected sensors
Capacitive
Switching frequency f 100 Hz 100 Hz sensors for
Supply voltage/Output function indicator Green LED/Yellow LED Green LED/Yellow LED level detection
Material Housing PBT PBT Capacitive
sensors
Sensing surface PBT PBT with special
properties
Cover PBT PBT
Connection 2 m PUR cable, 326 AWG 0.3 m PUR cable with M8, 3-pin connector
Capacitive
Suggested mating cable BCC M313-0000-10-001-PX43T2-050 sensors for
analog distance
measurement
! = Connection-Switching diagram, see page 849. 40 40
32 10 32 10 Accessories
Additional cable lengths on request. for capacitive
3xM3 3xM3
sensors
32
32
40
40
.3
.3
45
45
LED LED
M8
www.balluff.com 799
Capacitive
Sensors
Capacitive sensors for level detection
Capacitive sensors for level detection use their sensing surface
to detect the product, bulk material or liquid (e.g. plastic granulate,
sugar, oil, aqueous media) directly or through a container wall.
Advantage: Their spherical electrical eld effectively compensates for
deposits on the sensing surface of the sensor.

Capacitive Sensors for Level Detection
Contents
Standard sensors
SmartLevel sensors
SmartLevel 500+ 817
Disk designs 822
Block designs 824
www.balluff.com 801
Sensors in use
Whether in coolant reservoir tanks or on glass bypass tubes, the capacitive

sensor reliably detects the level and thereby helps to prevent damage to the
machine from running it dry.

M12x1
Size M121 M121 M121

Installation type Not ush Not ush Not ush
PNP, NO Ordering code BCS00P4 @ BCS00PC ! BCS0062 @
Part number BCS M12B4E2-PSC80H-S04K BCS M12B4G1-PSC80H-EP02 BCS M12T4D2-PSM80G-S04G
PNP, NC Ordering code BCS00P5 ^ BCS00PE % BCS0063 &
Part number BCS M12B4E2-POC80H-S04K BCS M12B4G1-POC80H-EP02 BCS M12T4D2-POM80G-S04G
NPN, NO Ordering code BCS00P6 $ BCS00PF # BCS0064 $
Part number BCS M12B4E2-NSC80H-S04K BCS M12B4G1-NSC80H-EP02 BCS M12T4D2-NSM80G-S04G Capacitive
NPN, NC Ordering code BCS00P7 ( BCS00PH * BCS0065 ) sensors
Part number BCS M12B4E2-NOC80H-S04K BCS M12B4G1-NOC80H-EP02 BCS M12T4D2-NOM80G-S04G
Supply voltage UB 10...30 V DC 10...30 V DC 1235 V DC Capacitive
sensors for
Voltage drop Ud at Ie 1.5 V 1.5 V 1.5 V object detection
Output current max. 100 mA 100 mA 200 mA Capacitive
sensors for
No-load supply current I0 max. 15 mA 15 mA 10 mA level detection
Polarity reversal protected/output miswiring protected/ Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Standard
short-circuit protected sensors
Ambient temperature Ta 25+85 C 25+85 C 30+70 C SmartLevel
sensors
Output function indicator Yellow LED Yellow LED Yellow LED Capacitive
with special
Material Housing Stainless steel Stainless steel Stainless steel properties
Sensing surface PBT PBT PTFE
Cover PA 12, PBT PA 12 PA Capacitive
Connection M12 connector, 4-pin 2 m PUR cable, 326 AWG M12 connector, 4-pin sensors for
analog distance
Suggested mating cable BCC M415-0000-1A-003-VX44T2-050-C013 BCC M415-0000-1A-003-PX44T2-050 measurement
Accessories
for capacitive
sensors
10
10
10
43
4
31
39.5
60
17
61
17
75
17
LED
LED sn
sn
LED
sn
www.balluff.com 803
M12x1
Size M121 M121 M121

PNP, NO Ordering code BCS005F ! BCS00PN @ BCS00R0 !
Part number BCS M12T4G1-PSM80G-EP02 BCS M12BBE2-PSC80H-S04K BCS M12BBG1-PSC80H-EP02
PNP, NC Ordering code BCS005H % BCS00PP ^ BCS00R1 %
Part number BCS M12T4G1-POM80G-EP02 BCS M12BBE2-POC80H-S04K BCS M12BBG1-POC80H-EP02
NPN, NO Ordering code BCS005J # BCS00PR $ BCS00R2 #
Part number BCS M12T4G1-NSM80G-EP02 BCS M12BBE2-NSC80H-S04K BCS M12BBG1-NSC80H-EP02
NPN, NC Ordering code BCS005K * BCS00PT ( BCS00R3 *
Part number BCS M12T4G1-NOM80G-EP02 BCS M12BBE2-NOC80H-S04K BCS M12BBG1-NOC80H-EP02
Supply voltage UB 1235 V DC 10...30 V DC 10...30 V DC
Sensing surface PTFE PBT PBT
Cover POM PA 12, PBT PA 12
Connection 2 m PUR cable, 326 AWG M12 connector, 4-pin 2 m PUR cable, 326 AWG

10
10
10
49
50
31
4
39.5
61
17 17
75
17
LED
sn
LED
LED
sn sn

Mx12, M18x1
Particularly EMC-proof
of
M121 M121 M181 M181 M181
Not ush Not ush Not ush Not ush Not ush
18 mm 16 mm 2..15 mm 2..15 mm 215 mm
BCS006Z ! BCS009J ! BCS00ME @ BCS00M7 ! BCS006A @
BCS M12TTG1-PSM80G-ET02 BCS M12TTI1-PSM60G-ET02-E BCS M18B4G2-PSC15H-S04K BCS M18B4H1-PSC15H-EP02 BCS M18T4G2-PSC15G-S04G
BCS0070 % BCS009K % BCS00ML ^ BCS00M9 % BCS006C &
BCS M12TTG1-POM80G-ET02 BCS M12TTI1-POM60G-ET02-E BCS M18B4G2-POC15H-S04K BCS M18B4H1-POC15H-EP02 BCS M18T4G2-POC15G-S04G
BCS0071 # BCS009L # BCS00MM $ BCS00MA # BCS006E $
BCS M12TTG1-NSM80G-ET02 BCS M12TTI1-NSM60G-ET02-E BCS M18B4G2-NSC15H-S04K BCS M18B4H1-NSC15H-EP02 BCS M18T4G2-NSC15G-S04G Capacitive
BCS0072 * BCS009M * BCS00MN ( BCS00MC * BCS006F ) sensors
BCS M12TTG1-NOM80G-ET02 BCS M12TTI1-NOM60G-ET02-E BCS M18B4G2-NOC15H-S04K BCS M18B4H1-NOC15H-EP02 BCS M18T4G2-NOC15G-S04G
1235 V DC 1235 V DC 10...30 V DC 10...30 V DC 1035 V DC Capacitive
sensors for
0.8 V 0.8 V 1.5 V 1.5 V 1.5 V object detection
200 mA 200 mA 100 mA 100 mA 300 mA Capacitive
sensors for
10 mA 10 mA 15 mA 15 mA 10 mA level detection
Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes Standard
sensors
30+70 C 30+60 C 25+85 C 25+85 C 30+70 C SmartLevel
sensors
100 Hz 25 Hz 100 Hz 100 Hz 100 Hz
No/Red LED No/Red LED Green LED/Yellow LED Green LED/Yellow LED No/Yellow LED Capacitive
with special
PTFE PTFE Stainless steel Stainless steel Stainless steel properties
PTFE PTFE PBT PBT PTFE
PTFE PTFE PA 12, PBT PA 12 PA Capacitive
2 m PTFE cable, 326 AWG 2 m PTFE cable, 326 AWG M12 connector, 4-pin 2 m PUR cable, 322 AWG M12 connector, 4-pin sensors for
analog distance
BCC M415-0000-1A-003-VX44T2-050-C013 BCC M415-0000-1A-003-PX44T2-050 measurement
Accessories
M121 M121 M181 M181 M181 for capacitive
sensors
10
10
15
15
15
49
5
53
55
39
4
59
63
75.5
75
47
17 24
88.5
24 24
LED
LED
sn LED sn
LED
sn
M121
17 LED
sn 17
sn sn
www.balluff.com 805
M181
Size M181 M181 M181

Rated switching distance sn 215 mm 2..15 mm 2..15 mm
PNP, NO Ordering code BCS005R ! BCS00LM @ BCS00LL !
Part number BCS M18T4I1-PSC15G-DV02 BCS M18BBG2-PSC15H-S04K BCS M18BBH1-PSC15H-EP02
PNP, NC Ordering code BCS005T % BCS00LT ^ BCS00LY %
Part number BCS M18T4I1-POC15G-DV02 BCS M18BBG2-POC15H-S04K BCS M18BBH1-POC15H-EP02
PNP, NO/NC, Ordering code
switch selectable Part number
NPN, NO Ordering code BCS005U # BCS00LU $ BCS00LZ #
Part number BCS M18T4I1-NSC15G-DV02 BCS M18BBG2-NSC15H-S04K BCS M18BBH1-NSC15H-EP02
NPN, NC Ordering code BCS005W * BCS00LW ( BCS00M0 *
Part number BCS M18T4I1-NOC15G-DV02 BCS M18BBG2-NOC15H-S04K BCS M18BBH1-NOC15H-EP02
NPN, NO/NC, Ordering code
switch selectable Part number
Supply voltage UB 1035 V DC 10...30 V DC 10...30 V DC
Sensing surface PTFE PBT PBT
Cover POM PA 12, PBT PA 12
Connection 2 m PVC cable, 324 AWG M12 connector, 4-pin 2 m PUR cable, 322 AWG
! = Connection-Switching diagram, see page 849.

M181 M181 M181

15
15
15
4
39
64
65
75.5
47
24
88.5
24 24
LED
sn
M121
LED sn LED
sn

M181, M301.5
M181 M301.5 M301.5 M301.5 M301.5

215 mm 125 mm 125 mm 130 mm 230 mm
BCS0073 ! BCS00MY @ BCS00N6 !
BCS M18TTI2-PSC15G-AT02 BCS M30B4E2-PSC25H-S04K BCS M30B4E1-PSC25H-EP02
BCS0074 % BCS00MZ ^ BCS00N7 %
BCS M18TTI2-POC15G-AT02 BCS M30B4E2-POC25H-S04K BCS M30B4E1-POC25H-EP02
BCS007L @ BCS007J !
BCS M30T4M2-PPC30G-S04G BCS M30T4M3-PPC30G-EP02 Capacitive
BCS0075 # BCS00N0 $ BCS00N8 # sensors
BCS M18TTI2-NSC15G-AT02 BCS M30B4E2-NSC25H-S04K BCS M30B4E1-NSC25H-EP02
BCS0076 * BCS00N1 ( BCS00N9 * Capacitive
sensors for
BCS M18TTI2-NOC15G-AT02 BCS M30B4E2-NOC25H-S04K BCS M30B4E1-NOC25H-EP02 object detection
BCS007M $ BCS007K #
BCS M30T4M2-NPC30G-S04G BCS M30T4M3-NPC30G-EP02 Capacitive
sensors for
1035 V DC 10...30 V DC 10...30 V DC 1035 V DC 1035 V DC level detection
1.5 V 1.5 V 1.5 V 1.8 V 1.8 V Standard
75 V DC 75 V DC 75 V DC 75 V DC 75 V DC sensors
SmartLevel
10 mA 15 mA 15 mA 15 mA 15 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Capacitive
sensors
with special
30+70 C 25+85 C 25+85 C 30+70 C 30+70 C properties
100 Hz 100 Hz 100 Hz 100 Hz 100 Hz
No/Red LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Capacitive
IP 67 IP 67 IP 67 IP 64 IP 64 sensors for
analog distance
PTFE Stainless steel Stainless steel Stainless steel Stainless steel measurement
PTFE PBT PBT PTFE PTFE
PTFE PA 12, PBT PA 12, PBT PBT, PE PBT, PE Accessories
for capacitive
2 m PTFE cable, 324 AWG M12 connector, 4-pin 2 m PUR cable, 322 AWG M12 connector, 4-pin 2 m PUR cable, 322 AWG sensors
BCC M415-0000-1A-003-VX44T2-050-C013 BCC M415-0000-1A-003-PX44T2-050
M181 M301.5 M301.5 M301.5 M301.5

15
20
20
20
20
66.5
66.5
66.5
64
5
32.5
73
38
38
32
78.5
36 36 36 36
15.5
20.5
LED
sn
NO/NC NO/NC
sn sn
6 V 6
LED LED
24 LED
sn sn LED
www.balluff.com 807
M301.5
Size M301.5 M301.5 M301.5

PNP, NO Ordering code BCS00NH BCS00NT BCS0077
Part number BCS M30BBE2-PSC25H-S04K @ BCS M30BBE1-PSC25H-EP02 ! BCS M30TTH2-PSC30G-AT02 !
PNP, NC Ordering code BCS00NJ BCS00NU BCS0078
Part number BCS M30BBE2-POC25H-S04K ^ BCS M30BBE1-POC25H-EP02 % BCS M30TTH2-POC30G-AT02 %
NPN, NO Ordering code BCS00NK BCS00NW BCS0079
Part number BCS M30BBE2-NSC25H-S04K $ BCS M30BBE1-NSC25H-EP02 # BCS M30TTH2-NSC30G-AT02 #
NPN, NC Ordering code BCS00NL BCS00NY BCS007A
Part number BCS M30BBE2-NOC25H-S04K ( BCS M30BBE1-NOC25H-EP02 * BCS M30TTH2-NOC30G-AT02 *
Supply voltage UB 10...30 V DC 10...30 V DC 1035 V DC
Supply voltage/Output function indicator Green LED/Yellow LED Green LED/Yellow LED No/Red LED
Material Housing PBT PBT PTFE
Cover PA 12, PBT PA 12, PBT PTFE
Connection M12 connector, 4-pin 2 m PUR cable, 322 AWG 2 m PTFE cable, 326 AWG
! = Connection-Switching diagram, see page 849. M301.5 M301.5 M301.5
20
20
20
72
66.5
32.5
32
78.5
36 36 41
7.5
18
LED
sn
LED LED
sn sn

Sensors in use
Pharmaceutical industry:
Level detection in the packaging process
Whether tablets, capsules or powder whenever products
are to be packaged perfectly in the pharmaceutical industry,
capacitive sensors are used for level detection. Capacitive sensors
simply and reliably determine the ll level directly in containers
or contactlessly through glass or plastic walls. If the level drops,
additional parts are fed so that the optimal procedure in the
packaging process is guaranteed.
Capacitive sensors are insensitive to color, and in addition are
installed quickly and easily. Without wear they prevent production
stoppage and increase the cost-effectiveness of the system.
Capacitive
sensors
Capacitive
sensors for
object detection
Capacitive
sensors for
level detection
Standard
sensors
SmartLevel
sensors
Capacitive
sensors
with special
properties
Capacitive
sensors for
analog distance
measurement
Accessories
for capacitive
sensors
www.balluff.com 809
M121, G 1/4", NPT 1/4" MicroLevel
Size M121 MicroLevel

Installation type Not ush
Rated switching distance sn Level adjustable
PNP/NPN and NO/NC, Ordering code BCS009T 1
wiring selected Part number BCS S41SS01-GPCFNG-S49G
Voltage drop Ud at Ie 3V
Output current max. 50 mA
Polarity reversal protected/output miswiring protected/ No/No/Yes
Supply voltage/Output function indicator Green LED/Yellow LED
Degree of protection as per IEC 60529 IP 67 (sensing surface:
IP 68 at max. 10 bar)
Material Housing PSU
Sensing surface PSU
Cover PSU
Suggested mating cables BCC M313-0000-10-001-PX43T2-050
With level sensors in the MicroLevel housing, M121

an adjustment is only necessary in exceptional cases.
7
The potentiometer has a setting path of 270
and has to be carefully adjusted.
12
For the protective covering
15.5
(M18 or G 1/2") for
MicroLevel sensors, see
Section Accessories,
15.5
page 848.
14
270
6.8 16.5
The standard mounting uses through-holes with included nut.

This can be ignored when threaded holes are used or serve as
additional security. Sealing is accomplished using an O-ring or gasket.

G 1/4" MicroLevel NPT 1/4" MicroLevel M121 MicroLevel G 1/4" MicroLevel NPT 1/4" MicroLevel
Level adjustable Level adjustable Level adjustable Level adjustable Level adjustable
BCS009U 1 BCS009W 1 BCS009N 1 BCS009P 1 BCS009R 1
BCS S41SS02-GPCFNG-S49G BCS S41SS03-GPCFNG-S49G BCS S40SS01-GPCFNG-EP02 BCS S40SS02-GPCFNG-EP02 BCS S40SS03-GPCFNG-EP02
3V 3V 3V 3V 3V
50 mA 50 mA 50 mA 50 mA 50 mA Capacitive
No/No/Yes No/No/Yes No/No/Yes No/No/Yes No/No/Yes
Capacitive
sensors for
10+70 C 10+70 C 10+70 C 10+70 C 10+70 C object detection
5 Hz 5 Hz 5 Hz 5 Hz 5 Hz
Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Capacitive
IP 67 (sensing surface: IP 67 (sensing surface: IP 67 (sensing surface: IP 67 (sensing surface: IP 67 (sensing surface: IP sensors for
level detection
IP 68 at max. 10 bar) IP 68 at max. 10 bar) IP 68 at max. 10 bar) IP 68 at max. 10 bar) 68 at max. 10 bar) Standard
PSU PSU PSU PSU PSU sensors
PSU PSU PSU PSU PSU SmartLevel
sensors
PSU PSU PSU PSU PSU
M8 connector, 3-pin M8 connector, 3-pin 2 m PUR cable, 322 AWG 2 m PUR cable, 322 AWG 2 m PUR cable, 322 AWG Capacitive
BCC M313-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050 sensors
with special
properties
G 1/4 NPT 1/4 M121 G 1/4 NPT 1/4
7 7 7 7 7 Capacitive
sensors for
analog distance
measurement
12
12
12
12
12
15.5
15.5
15.5
15.5
15.5
Accessories
for capacitive
sensors
15.5
15.5
15.5
15.5
15.5
14 14
14 14 14
270 270
6.8 16.5
6.8 16.5
16.5
16.5
16.5
270 270 270
www.balluff.com 811
Reverse installation Reverse installation Reverse installation

Size M121 MicroLevel G 1/4" MicroLevel NPT 1/4" MicroLevel
Rated switching distance sn Level adjustable Level adjustable Level adjustable
Part number
Part number
Part number
Part number
PNP/NPN and NO/NC, Ordering code BCS009Y 1 BCS009Z 1 BCS00A0 1
wiring selected Part number BCS S42SS01-GPCFNG-S49G BCS S42SS02-GPCFNG-S49G BCS S42SS03-GPCFNG-S49G
Polarity reversal protected/output miswiring protected/ No/No/Yes No/No/Yes No/No/Yes
Degree of protection as per IEC 60529 IP 64 (sensing surface: IP 64 (sensing surface: IP 64 (sensing surface:
IP 68 at max. 10 bar) IP 68 at max. 10 bar) IP 68 at max. 10 bar)
Material Housing PSU PSU PSU
Sensing surface PSU PSU PSU
Cover PSU PSU PSU
Suggested mating cable BCC M313-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050
With level sensors in a MicroLevel housing, an adjustment

7 7 7
is only necessary in exceptional cases. The potentiometer
has a setting path of 270 for adjustment.
12
12
12

15.5
15.5
15.5

14 14 14
15.5
15.5
15.5
270 270 270

6.8 16.5
6.8 16.5
6.8 16.5
M121 G 1/4 NPT 1/4
The reverse mounting in a tube of any desired length

for fashioning "point-switching" rod sensors.
The sealing can be done with an O-ring or with a at seal.

M181, R 3/8", NPTF 3/8"
Pressure rated to 10 bar Pressure rated to 10 bar Pressure rated to 10 bar

M181 R 3/8" NPTF 3/8"
Not ush Not ush Not ush
Level adjustable Level adjustable Level adjustable
BCS006H ! BCS006M ! BCS00A6 !
BCS S01T401-PSCFNG-KM16-T02 BCS S02T401-PSCFNG-KM16-T02 BCS S03T401-PSCFNH-KM16-T02
BCS006J % BCS006N % BCS00A7 %
BCS S01T401-POCFNG-KM16-T02 BCS S02T401-POCFNG-KM16-T02 BCS S03T401-POCFNH-KM16-T02
BCS006K # BCS006P # BCS00A8 #
BCS S01T401-NSCFNG-KM16-T02 BCS S02T401-NSCFNG-KM16-T02 BCS S03T401-NSCFNH-KM16-T02 Capacitive
BCS006L * BCS006R * BCS00A9 * sensors
BCS S01T401-NOCFNG-KM16-T02 BCS S02T401-NOCFNG-KM16-T02 BCS S03T401-NOCFNH-KM16-T02
Capacitive
sensors for
object detection
1035 V DC 1035 V DC 1035 V DC
2.7 V 2.7 V 2.7 V Capacitive
sensors for
75 V DC 75 V DC 75 V DC level detection
100 mA 100 mA 100 mA Standard
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes SmartLevel
sensors
30+125 C 30+125 C 30+125 C Capacitive

5 Hz 5 Hz 5 Hz sensors
with special
No/Yellow LED No/Yellow LED No/Yellow LED properties
IP 67 (sensing surface: IP 67 (sensing surface: IP 67 (sensing surface:
IP 68 at max. 10 bar) IP 68 at max. 10 bar) IP 68 at max. 10 bar) Capacitive
Cast aluminum Cast aluminum Cast aluminum sensors for
analog distance
PTFE PTFE PTFE measurement
Cast aluminum Cast aluminum Cast aluminum
Screw terminals Screw terminals Screw terminals Accessories
for capacitive
sensors
54.8 48.5 54.8 48.5 54.8 48.5

50
50
50
PG9 PG9 PG9

106
106
106
10
10
10
12
12
27 27
12
27
24 R 3/8 R 3/8
35
35
35
M181 12 M181 12 M181 12
Gasket not included in the delivery. Gasket not included in the delivery. Gasket not included in the delivery.
Adjustment:
The adjustment is carried out with a potentiometer. The objective is to set a middle value between the turn-on and turn-off point
when the sensor is damped. In individual cases when temperature swings are great and very sticky media are used a slight
readjustment may be necessary. Otherwise, our adjustment instructions for non-ush mount sensor versions apply.
www.balluff.com 813
SMARTLEVEL
SMARTLEVEL
SmartLevel sensors exceed limits

Simply describing the output of SmartLevel sensors as level sensors for reliable sens-
ing of liquids and conductive media does not do its strengths justice. This is because
SmartLevel can do much more when all other capacitive sensors reach their limit.
SmartLevel sensors are
assigned to uid sensors,
SmartLevel which we label in orange.
Compensate for moisture, foam and deposits.
Penetrate wall thicknesses of glass and plastic even over 10 mm. Size
Detect aqueous to highly conductive media. Installation type
Have a chemically resistant housing made of PTFE. Rated switching distance sn
In short: SmartLevel sensors exceed limits. This is because they are the solution in PNP, NO Ordering code
applications that, until now, were extremely difcult. Part number
SmartLevel sensors also reduce costs, because they Part number
Provide freedom from cleaning in most applications NPN, NO Ordering code
Reduced use of materials Part number
Only require low construction effort (for example, bypass tubes are omitted) NPN, NC Ordering code
Part number
In this way, SmartLevel sensors optimize the production process and increase the Supply voltage UB
application security. Voltage drop Ud at Ie
Output current max.
Polarity reversal protected/output miswiring
protected/short-circuit protected
Material Housing
Sensing surface
Cover
Connection
SmartLevel sensors take off

Airbus is equipping the rest rooms in their 4-engine
large-body A380 with a mixer tap. The heart of this
exclusive system in the elegant Airbus design are
compact SmartLevel capacitive sensors. These
enable passengers to conveniently select the desired
water temperature with the assistance of an LED
indicator. The show-stopper: sensing errors are
impossible, since SmartLevel sensors ignore clinging
dirt, liquid lms and soap foam. Touching the faucet
triggers a switching operation, even if a wet paper
towel covers it.

SMARTLEVEL, cylinder design, DC 3-wire,
7 mm, M181
SMARTLEVEL 15 SMARTLEVEL 15 SMARTLEVEL 15 SMARTLEVEL 15

752 mm M181 M181 M181
Not ush Not ush Not ush Not ush
Fixed adjustment, media-dependent Media-dependent Media-dependent Media-dependent
BCS009C ! BCS008T @ BCS007N ! BCS008A !
BCS S20TT01-PSLFAG-ET02 BCS M18VVN-PSCFAG-S49G BCS M18VVI1-PSCFAG-DV02 BCS M18TTI2-PSCFAG-AT02
BCS009E % BCS008U & BCS007P % BCS008C %
BCS S20TT01-POLFAG-ET02 BCS M18VVN-POCFAG-S49G BCS M18VVI1-POCFAG-DV02 BCS M18TTI2-POCFAG-AT02
BCS0088 # BCS008W $ BCS007R # BCS008E #
BCS M30TTH2-NSCFAG-AT02 BCS M18VVN-NSCFAG-S49G BCS M18VVI1-NSCFAG-DV02 BCS M18TTI2-NSCFAG-AT02 Capacitive
BCS0089 * BCS008Y ) BCS007T * BCS008F * sensors
BCS M30TTH2-NOCFAG-AT02 BCS M18VVN-NOCFAG-S49G BCS M18VVI1-NOCFAG-DV02 BCS M18TTI2-NOCFAG-AT02
1030 V DC 1035 V DC 1035 V DC 1035 V DC Capacitive
sensors for
1.5 V 1.8 V 1.8 V 1.8 V object detection
75 V DC 75 V DC 75 V DC 75 V DC
50 mA 300 mA 300 mA 300 mA Capacitive
sensors for
20 mA 20 mA 20 mA 20 mA level detection
No/No/No Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Standard
sensors
+5+100 C 10+60 C 10+60 C 10+60 C SmartLevel
sensors
10 Hz 2 Hz 2 Hz 2 Hz
No Yellow LED Yellow LED Red LED Capacitive
with special
PTFE PVC PVC PTFE properties
PTFE PVC PVC PTFE
PTFE PVC PVC PTFE Capacitive
2 m PTFE cable, 326 AWG M8 connector, 3-pin 2 m PVC cable, 324 AWG 2 m PTFE cable, 326 AWG sensors for
analog distance
BCC M313-0000-10-001-VX43T2-050 measurement
7 M181 M181 M181 Accessories

for capacitive
sensors
15
15
15
30
64
64
70
70
73
4
4
5
21.5
24 24 24
6
LED
sn sn sn
For direct installation in containers:

The non-ush sensors for level
detection M12...M30 in plastic or PTFE
LED LED
housing provide IP 68 protection (at
approx. 5 bar) at the sensing surface.
Sensors in stainless steel housing meet
IP 67 at the sensing surface.
www.balluff.com 815
SMARTLEVEL
M301.5

which we label in orange.
SMARTLEVEL 15 SMARTLEVEL 15 SMARTLEVEL 15
Size M301.5 M301.5 M301.5
Rated switching distance sn Media-dependent Media-dependent Media-dependent
PNP, NO Ordering code BCS0086 !
Part number BCS M30TTH2-PSCFAG-AT02
PNP, NC Ordering code BCS0087 %
Part number BCS M30TTH2-POCFAG-AT02
PNP, NO/NC, Ordering code BCS007Y @ BCS007U !
switch selectable Part number BCS M30BBM2-PPCFAG-S04G BCS M30BBM3-PPCFAG-EP02
NPN, NO Ordering code BCS0088 #
Part number BCS M30TTH2-NSCFAG-AT02
NPN, NC Ordering code BCS0089 *
Part number BCS M30TTH2-NOCFAG-AT02
NPN, NO/NC, Ordering code BCS007Z ^ BCS007W #
switch selectable Part number BCS M30BBM2-NPCFAG-S04G BCS M30BBM3-NPCFAG-EP02
Supply voltage/Output function indicator Green LED/Yellow LED Green LED/Yellow LED No/Red LED
Material Housing PBT PBT PTFE
Cover PBT, PE PBT, PE PTFE
Connection M12 connector, 4-pin 2 m PUR cable, 322 AWG 2 m PTFE cable, 324 AWG
Suggested mating cable BCC M415-0000-1A-003-PX44T2-050

M301.5 M301.5 M301.5

20
20
20
58
66.5
66.5
72
38
36 36
41
7.5
15.5
20.5
18
LED
NO/NC NO/NC
sn 6 sn sn
V 6 V
LED LED

Capacitive Sensors with Special Properties
SMARTLEVEL 500+, cylinder designs, DC 3-wire,
M301.5, 30 mm
Detecting highly conductive

acids, such as sulphuric or
hydrochloric acid, through
plastic or glass containers that
are up to 10 mm thick SmartLevel sensors are
Reliable detection of levels which we label in orange.
in food items, such as ketchup SMARTLEVEL 500+
or mustard, despite heavy Size M301.5
deposits Installation type Not ush
Detecting concentrated Rated switching distance sn Media-dependent
cleaning agents in plastic PNP/NPN and NO/NC, Ordering code BCS00TZ 1
containers wiring selected Part number BCS M30TTH2-GPCFVG-AT02
Voltage drop Ud at Ie 2V
Industrial wastewater
Disinfection agent
Output current max. 100 mA Capacitive
No-load supply current I0 max. < 15 mA sensors
Table salt solution Polarity reversal protected/output miswiring No/No/Yes
protected/short-circuit protected Capacitive
sensors for
Ketchup/mustard Ambient temperature Ta 10+60 C object detection
Phosphoric acid (10 %)
Supply voltage/Output function indicator No/Red LED Capacitive
sensors for
Degree of protection as per IEC 60529 IP 67 level detection
Sulfuric acid (10 %)
Standard
Calcium chloride (30 %) Material Housing PTFE sensors
Sensing surface PTFE SmartLevel
sensors
Hydrochloric acid (40 %) Cover PTFE
Connection 2 m PTFE cable, Capacitive
Nitric acid (12 %)
30.2 mm sensors
with special
properties
SMARTLEVEL 500+
Approx. 50...500 mS and greater ! = Connection-Switching diagram, see page 849. M301.5
Additional cable lengths on request. Capacitive
sensors for
analog distance
20
measurement
Accessories
for capacitive
72
sensors
41
7.5
LED
18
sn
www.balluff.com 817

SMARTLEVEL 15 SMARTLEVEL 15 SMARTLEVEL 15
Size M121 MicroLevel G 1/4" MicroLevel NPT 1/4" MicroLevel
Rated switching distance sn Media-dependent Media-dependent Media-dependent
PNP/NPN and Ordering code BCS0095 1 BCS0096 1 BCS0097 1
NO/NC, wiring selected Part number BCS S41SS01-GPCFAG-S49G BCS S41SS02-GPCFAG-S49G BCS S41SS03-GPCFAG-S49G
Polarity reversal protected/output miswiring protected/ No/No/Yes No/No/Yes No/No/Yes
Degree of protection as per IEC 60529 IP 67 (sensing surface: IP 67 (sensing surface: IP 67 (sensing surface:
IP 68 at max. 10 bar) IP 68 at max. 10 bar) IP 68 at max. 10 bar)
Material Housing PSU PSU PSU
Sensing surface PSU PSU PSU
Cover PSU PSU PSU
Suggested mating cable BCC M313-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050
With level sensors in the MicroLevel housing, M121 G 1/4 NPT 1/4
an adjustment is only necessary in exceptional cases.
The potentiometer has a setting path of 270 7 7 7
12
12
12
(M18 or G 1/2") for
15.5
15.5
15.5
MicroLevel sensors,
see Section Accessories,
page 848.
15.5
15.5
14 14 14 15.5
270 270 270

6.8 16.5
6.8 16.5
6.8 16.5

Capacitive
sensors
Capacitive
sensors for
object detection
Capacitive
sensors for
level detection
Standard
sensors
SmartLevel
sensors
Capacitive
sensors
with special
properties
Capacitive
sensors for
analog distance
measurement
Accessories
for capacitive
sensors
www.balluff.com 819
SMARTLEVEL

SMARTLEVEL 15 SMARTLEVEL 15
Size M121 MicroLevel G 1/4" MicroLevel
Installation type Not ush Not ush
Rated switching distance sn Media-dependent Media-dependent
PNP/NPN and Ordering code BCS008Z 1 BCS0090 1
NO/NC, wiring selected Part number BCS S40SS01-GPCFAG-EP02 BCS S40SS02-GPCFAG-EP02
Polarity reversal protected/output miswiring protected/ No/No/Yes No/No/Yes
Supply voltage/Output function indicator Green LED/Yellow LED Green LED/Yellow LED
Degree of protection as per IEC 60529 IP 67 (sensing surface: IP 67 (sensing surface:
IP 68 at max. 10 bar) IP 68 at max. 10 bar)
Material Housing PSU PSU
Sensing surface PSU PSU
Cover PSU PSU
Connection 2 m PUR cable, 3x22 AWG 2 m PUR cable, 3x22 AWG
With level sensors in the MicroLevel housing, M121 G 1/4

an adjustment is only necessary in exceptional cases. 7 7
The potentiometer has a setting path of 270
12
12
15.5
15.5
(M18 or G 1/2") for
MicroLevel sensors,
see Section Accessories,
15.5
page 848. 15.5

14 14
16.5
16.5
270 270
The standard mounting uses through-holes with included nut.

This can be ignored when threaded holes are used or serve
as additional security. Sealing is done with an O-ring or gasket.

Reverse installation Reverse installation Reverse installation

NPT 1/4" MicroLevel M121 MicroLevel G 1/4" MicroLevel NPT 1/4" MicroLevel
Not ush Not ush Not ush Not ush
Media-dependent Media-dependent Media-dependent Media-dependent
BCS0091 1 BCS0098 1 BCS0099 1 BCS009A 1
BCS S40SS03-GPCFAG-EP02 BCS S42SS01-GPCFAG-S49G BCS S42SS02-GPCFAG-S49G BCS S42SS03-GPCFAG-S49G
1035 V DC 1035 V DC 1035 V DC 10...35 V DC
3V 3V 3V 3V
75 V DC 75 V DC 75 V DC 75 V DC
50 mA 50 mA 50 mA 50 mA Capacitive
No/No/Yes No/No/Yes No/No/Yes No/No/Yes
Capacitive
sensors for
10+105 C 10+105 C 10+105 C 10+105 C object detection
5 Hz 5 Hz 5 Hz 5 Hz
Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Green LED/Yellow LED Capacitive
IP 67 (sensing surface: IP 64 (sensing surface: IP 64 (sensing surface: IP 64 (sensing surface: sensors for
level detection
IP 68 at max. 10 bar) IP 68 at max. 10 bar) IP 68 at max. 10 bar) IP 68 at max. 10 bar) Standard
PSU PSU PSU PSU sensors
PSU PSU PSU PSU SmartLevel
sensors
PSU PSU PSU PSU
2 m PUR cable, 3x22 AWG M8 connector, 3-pin M8 connector, 3-pin M8 connector, 3-pin Capacitive
BCC M313-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050 sensors
with special
properties
NPT 1/4 7 7 7
7 Capacitive
sensors for
12
12
12
analog distance
measurement
12
15.5
15.5
15.5
Accessories
15.5
14 14 14 for capacitive
15.5
15.5
15.5
sensors
15.5
270 270 270

16.5
16.5
16.5
14
16.5
270
6.8
6.8
6.8
M121 G 1/4 NPT 1/4
Reverse mounting in a tube of any desired length for fashioning

"point-switching" rod sensors. The sealing can be done with an
O-ring or with a at seal.
www.balluff.com 821
SMARTLEVEL, disk designs, DC 3-wire,
SMARTLEVEL
50 mm
The SmartLevel capacitive sensor is always well put to use

if applications are difcult to nd solutions for, whether in the
semiconductor industry, in special machine design, in the food and
packaging segment or in industrial cleaning technology. For conductive
media, the SmartLevel 15 is recommended. And in highly conductive SmartLevel sensors are
media, SmartLevel 50 is best used. which we label in orange.
Wafer processing (semiconductor industry)
During wafer processing, SmartLevel monitors the overow of Size
hydrochloric acid through a container wall, so that it can come into Installation type
contact with condensate containing salt. The highly conductive deposit Rated switching distance sn
of the condensate does not, however, impede it. PNP, NO Ordering code
Cold deformation (oil spraying system in special machine Part number
design) PNP, NC Ordering code
Likewise, the SmartLevel ignores highly conductive graphite deposits Part number
when it reliably measures the level of an oil-graphite mixture through PNP, NO/NC, Ordering code
the wall of a plastic container in special machine construction. Through switch selectable Part number
this, it is ensured that the mixture can be continuously sprayed NPN, NO Ordering code
on metal plates, in order to better be able to bend it during cold Part number
deformation. NPN, NC Ordering code
Filling bottles of body lotion (packaging industry) Part number
The SmartLevel is suited for detecting conductive, paste-type media NPN, NO/NC, Ordering code
which can cause heavier deposits. Therefore, it is ideally used during switch selectable Part number
lling of bottles of body lotion. Through a 10 mm-thick inspection Supply voltage UB
glass, it monitors their ll level in stainless steel containers with Voltage drop Ud at Ie
absolute reliability and, through its external positioning, also reduces Rated insulation voltage Ui
the effort for cleaning. Output current max.
Brining pretzels (food industry) No-load supply current I0 max.
SmartLevel also nds use directly in foaming media. For example, in Polarity reversal protected/output miswiring protected/
the stainless steel container of a system in which pretzels are sprayed short-circuit protected
with caustic soda lye. In doing so, it controls the minimum-maximum ll Ambient temperature Ta
level of the caustic soda lye with absolute reliability. Switching frequency f
Cleaning metal parts (industrial cleaning technology) Output function indicator
SmartLevel controls the ll level of a supply tank for cleaning metal Degree of protection as per IEC 60529
parts, because it can compensate for foam, grease and lmimg. Water Material Housing
spray and temperatures up to 105 C do not impede it. In addition, its Sensing surface
PTFE sleeve protects it from aggressive media. Cover
Connection

SMARTLEVEL, disk designs, DC 3-wire,
50 mm

5010 mm 5010 mm 5010 mm 5010 mm
Media-dependent Media-dependent Media-dependent Media-dependent
BCS0080 ! BCS00CK ! BCS00UW !
BCS D50TT05-PSCFAC-ET02 BCS D50OO06-PSFSC-EV02 BCS D50TT06-PSCFSC-ET02
BCS0081 % BCS00CM % BCS00UY %
BCS D50TT05-POCFAC-ET02 BCS D50OO06-POFSC-EV02 BCS D50TT06-POCFSC-ET02
BCS0084 !
BCS D50OO04-PPCFAC-EV02 Capacitive
BCS0082 # BCS00HE # BCS00WO # sensors
BCS D50TT05-NSCFAC-ET02 BCS D50OO06-NSFSC-EV02 BCS D50TT06-NSCFSC-ET02
BCS0083 * BCS00C1 * BCS00UZ * Capacitive
sensors for
BCS D50TT05-NOCFAC-ET02 BCS D50OO06-NOFSC-EV02 BCS D50TT06-NOCFSC-ET02 object detection
BCS0085 #
BCS D50OO04-NPCFAC-EV02 Capacitive
sensors for
1035 V DC 1035 V DC 1030 V DC 1030 V DC level detection
1.8 V 1.8 V 1.8 V 1.8 V Standard
75 V DC 75 V DC 75 V DC 75 V DC sensors
SmartLevel
20 mA 20 mA 10 mA 10 mA
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Capacitive
sensors
with special
10+60 C 10+60 C 10+60 C 10+60 C properties
2 Hz 2 Hz 2 Hz 2 Hz
Yellow LED Red LED Yellow LED Red LED Capacitive
IP 67 IP 67 IP 67 IP 67 sensors for
analog distance
POM PTFE POM PTFE measurement
POM PTFE POM PTFE
POM PTFE POM PTFE Accessories
for capacitive
2 m PVC cable, 324 AWG 2 m PTFE cable, 326 AWG 2 m PVC cable, 324 AWG 2 m PTFE cable, 326 AWG sensors
42 42 42 42
4.2
4.2
50
50
50
50
5.5 5.5
LED LED
NO/NC NO/NC
LED sn LED sn
sn sn
10
10
10
10
www.balluff.com 823
SMARTLEVEL, block design, DC 3-wire,
SMARTLEVEL
16348 mm Micro-Box

which we label in orange. SMARTLEVEL 15 SMARTLEVEL 15
Size 16348 mm Micro-Box 16348 mm Micro-Box

PNP NO Ordering code BCS008M @ BCS008H !
Part number BCS R08RR01-PSMFAC-EP00,2-GS49 BCS R08RR01-PSMFAC-EP02
PNP NC Ordering code BCS008N & BCS008J %
Part number BCS R08RR01-POMFAC-EP00,2-GS49 BCS R08RR01-POMFAC-EP02
NPN NO Ordering code BCS008P $ BCS008K #
Part number BCS R08RR01-NSMFAC-EP00,2-GS49 BCS R08RR01-NSMFAC-EP02
NPN NC Ordering code BCS008R ) BCS008L *
Part number BCS R08RR01-NOMFAC-EP00,2-GS49 BCS R08RR01-NOMFAC-EP02
Supply voltage UB 1230 V DC 12...30 V DC
Material Housing PP PP
Sensing surface PP PP
Cover PP PP
Connection 0.2 m PUR cable, with M8 3-pin connector 2 m PUR cable, 326 AWG
Suggested mating cable BCC M313-0000-10-001-VX43T2-050
! = Connection-Switching diagram, see page 849. 8 16 8 16

34
34
3.2
3.2
10 10
30
LED LED
sn sn
Mounting frame included in delivery. Mounting frame included in delivery.

SMARTLEVEL, block design, DC 3-wire,
404010 mm Uniat

which we label in orange. SMARTLEVEL 15 SMARTLEVEL 15
Size 404010 mm Uniat 404010 mm Uniat

PNP/NPN and NO/NC, Ordering code BCS00TP 1
wiring selected Part number BCS Q40BBAA-GPCFAC-EP02
PNP NO Ordering code BCS00U8 @
Part number BCS Q40BBAA-PSCFAC-EP00,3-GS49
PNP NC Ordering code BCS00U7 ^
Part number BCS Q40BBAA-POCFAC-EP00,3-GS49 Capacitive
Rated insulation voltage Ui 75 V DC 75 V DC Capacitive
sensors for
Output current max. 100 mA 100 mA object detection
Polarity reversal protected/output miswiring protected/ No/No/Yes Yes/Yes/Yes Capacitive
level detection
Ambient temperature Ta 5...+85 C 5...+85 C Standard
Switching frequency f 10 Hz 10 Hz sensors
Supply voltage/Output function indicator Green LED/Yellow LED Green LED/Yellow LED SmartLevel
sensors
Material Housing PBT PBT Capacitive
Sensing surface PBT PBT sensors
with special
Cover PBT PBT properties
Connection 2 m PUR cable, 326 AWG 0.3 m PUR cable with M8 3-pin connector
Suggested mating cable BCC M313-0000-10-001-PX43T2-050 Capacitive
sensors for
analog distance
! = Connection-Switching diagram, see page 849. 40 40 measurement
32 10 32 10
3xM3 3xM3
Accessories
for capacitive
sensors
32
40
32
40
.3
45
.3
LED
45
LED
M8
The new capacitive SmartLevel sensors in the Uniat design detects

conductive media through non-metallic container walls with a thickness up
to 10 mm.
Installation is quick and easy. This is because they can be screwed on or
attached to bypass tubes with cable ties. The connection is made using a
2 m cable or a short pigtail line with an M8 plug.
The codable output function provides PNP or NPN and normally open or
normally closed functionality.
SmartLevel
Suppress foam and deposits
Easy to install on tubes with cable ties
Regular cleaning can be omitted
www.balluff.com 825
Capacitive
Sensors
Capacitive sensors
with special properties
Balluff capacitive sensors are available in high temperature and
pressure ratings, stainless steel and Teon housings for harsh
environments, a wide supply voltage range and especially compact
designs are all available in the BCS family. Capacitive adhesive
sensors adapt to the shape of the housing with great exibility.

Contents
Capacitive sensors with special properties

High temperature rated sensors 828
High pressure rated sensor 830
Flexible adhesive sensor 831
AC/DC 2-wire sensors 832
www.balluff.com 827
Capacitive Sensors with Special Properties +250 C
High temperature rated sensors, cylinder designs, DC 3-wire
Balluff high-temperature capacitive sensors can be used for level

detection of liquid, paste-like or powdery media at high temperatures
up to 250 C. To withstand such extreme conditions, the housing of
the high-temperature rated sensors is made of stainless steel and
the sensor heads of PTFE. The sensors are also used with a special
Triax sensor cable and a separate amplier.
Size
Installation type
With sensor amplier Ordering code
Part number
Supply voltage UB
Material Housing
Sensing surface
Cover
Connection
Sensor ampliers for

capacitive high pressure
rated sensors can
be found on page 841.
Description Connectors for high-temperature sensors
Ordering code BCC04JW

Part number BCC Z003-020
Ambient temperature Ta See drawing
Connection 2 m Triax FEP
POM 30...+70 C 90...+180 C MS-Cr 90...+180 C

9
Triax FEP 24.5

34 34.5

High temperature rated sensors, cylinder designs,
DC 3-wire, M18, M30, R 3/8", NPTF 3/8"
Temperature-resistant Temperature-resistant Temperature-resistant Temperature-resistant Temperature-resistant

up to +250 C up to +250 C up to +180 C up to +180 C up to +180 C
M181 M301.5 M181 R 3/8" NPTF 3/8"
110 mm 120 mm Level adjustable Level adjustable Level adjustable
BCS00A1 BCS00A2 BCS00A3 BCS00A4 BCS00A5
BCS M18T4H1-XXS10H-SZ02-T08 BCS M30T4G1-XXS20H-SZ02-T08 BCS S10T401-XXSFNC-SZ02-T07 BCS S10T402-XXSFNC-SZ02-T07 BCS S10T403-XXSFNC-SZ02-T07
180+250 C 180+250 C 10+180 C 10+180 C 10+180 C
IP 54 IP 54 IP 54 (sensing surface: IP 54 (sensing surface: IP 54 (sensing surface:
IP 68 at max. 6 bar) IP 68 at max. 6 bar) IP 68 at max. 6 bar) Capacitive
Stainless steel Stainless steel Stainless steel Stainless steel Stainless steel sensors
PTFE PTFE PTFE PTFE PTFE
PTFE, MS-Cr PTFE, MS-Cr PTFE, MS-Cr PTFE, MS-Cr PTFE, MS-Cr Capacitive
sensors for
Triax sensor cable Triax sensor cable Triax sensor cable Triax sensor cable Triax sensor cable object detection
Capacitive
14.5 26 M18x1 R 3/8 NPTF 3/8 sensors for
12 12 12 level detection
16
22
Capacitive
sensors
35 +1
35 +1
35 +1
with special
properties
65
65
4
High
37
45
27 temperature
rated sensors
12
12
12
24 36 High pressure-
resistant
3 10
3 10
3 10
sensors
M301.5 Adhesive
M181 sensors
AC/DC
2-wire
sensors
Capacitive
sensors for
analog distance
measurement
Accessories
for capacitive
sensors
www.balluff.com 829
Capacitive Sensors with Special Properties up to 150 bar
High pressure rated sensors, cylinder designs,
DC 3-wire, M12
Pressure rated to 150 bar

Size M121
Installation type Flush
With sensor amplier Ordering code BCS00CR
Part number BCS M12EG2-XXS10B-BT01-GZ01-501
Rated insulation voltage Ui (protection class) 75 V DC
Material Housing Stainless steel
Sensing surface PTFE
Cover POM
Connection Triax sensor cable
Sensor ampliers for M121

capacitive high pressure
rated sensors can
be found on page 841.
40
17
25

34

Flexible adhesive sensor, DC 3-wire,
90164 mm
Size 90164 mm
With sensor amplier Ordering code BCS000Y
Part number BCS F01CP01-XXS10C-EP02-GZ01-002
Switching frequency f 100 Hz Capacitive
Degree of protection as per IEC 60529 IP 60 sensors
Material Housing PC, PUR
Sensing surface PUR Capacitive
sensors for
Connection 2 m PUR cable, 26 AWG object detection
Sensor ampliers for 18.6 16 Capacitive

capacitive adhesive sensors sensors for
4.2 level detection
Capacitive
sensors
with special
properties
High
temperature
rated sensors
Additional cable lengths on request. High
83
90
41
pressure-
resistant
sensors
Adhesive
sensors
AC/DC
2-wire
sensors
5.5
Capacitive
sensors for
analog distance
measurement
Accessories
for capacitive
sensors
www.balluff.com 831
Capacitive Sensors with Special Properties AC/DC
AC/DC, cylinder designs, 2-wire,
M18, M30, 34 mm
Size M181 M301.5 34 mm

NO Ordering code BCS000K 2 BCS000W 2 BCS0007 2
Part number BCS M18KM3-UST80G-BV02 BCS M30KN2-UST15G-AV02 BCS G34KN2-UST20G-AV02
NC Ordering code BCS000J 3 BCS000U 3 BCS0006 3
Part number BCS M18KM3-UOT80G-BV02 BCS M30KN2-UOT15G-AV02 BCS G34KN2-UOT20G-AV02
Voltage drop Ud at Ie 6V 10 V 10 V
Output current max. 350 mA (AC)/100 mA (DC) 250 mA (AC)/100 mA (DC) 250 mA (AC)/100 mA (DC)
Short-circuit protected No No No
Switching frequency f 25 Hz (AC)/50 Hz (DC) 25 Hz (AC)/40 Hz (DC) 25 Hz (AC)/40 Hz (DC)
Material Housing PBT PBT PBT
Cover PBT PBT PBT
Connection 2 m PVC cable, 322 AWG 2 m PVC cable, 322 AWG 2 m PVC cable, 320 AWG
! = Connection-Switching diagram, see page 849. M181 M301.5 34
Additional cable lengths on request. 59

58
81
81
84
24
36
sn
LED
9 9
LED LED
sn sn
Mounting cuff included in delivery.

Capacitive
sensors
Capacitive
sensors for
object detection
Capacitive
sensors for
level detection
Capacitive
sensors
with special
properties
High
temperature
rated sensors
High pressure-
resistant
sensors
Adhesive
sensors
AC/DC
2-wire
sensors
Capacitive
sensors for
analog distance
measurement
Accessories
for capacitive
sensors
www.balluff.com 833
Capacitive
Sensors
Capacitive sensors for
analog distance measurement
Capacitive sensors for analog distance measurement have
a measuring range of 0 to 8 mm. Their current output signal is
4 to 20 mA. They are installed ush and are available in an M18
housing.

Capacitive Sensor for
Contents
Standard sensor
Cylinder design 837
www.balluff.com 835
Object color and surface properties do not inuence its measure-

ment results.
Technical details
Adjustable measuring range of 08 mm
Flush installation
Output signal, current 420 mA
Housing M18
Function
The capacitive distance sensor measures objects that are in its
response range without contact. As soon as the object enters it, the
electrical eld changes its sensing surface and, with it, the output
current. In this way, material composition, size and distance of the
object to the sensing surface can be determined.
The output signal (420 mA) can be adapted to the material using
the potentiometer (LED lights green). It is evaluated directly on the
analog output of the controller.
Polyester Melamine fabric-based laminate

IL / mA
thickness 2 mm thickness 2 mm
20
18 PVC
thickness
16 2 mm
14
12
10 Fe360
8
6
8 S / mm
Added plus: A blinking LED signals

to the user a high-impedance load.
OSC LIN A

Standard sensor, cylinder design, DC 3-wire,
M181

linear position sensing and measurement
that we have marked in blue.
Size M181
Measuring range 08 mm
PNP/NPN and Ordering code BCW0001
NO/NC, wiring selected Part number BCW M18B4M1-ICM80C-DV02
No-load supply current I0 max. < 17 mA Capacitive
Polarity reversal protected/output miswiring protected/short-circuit protected Yes/Yes/Yes, with load monitoring sensors
Ambient temperature Ta 10 to +55 C
Switching frequency f 100 Hz (3 dB limit frequency) Capacitive
sensors for
Supply voltage/Output function indicator Green LED/Red LED object detection
Material Housing Stainless steel Capacitive
sensors for
Sensing surface PBT level detection
Connection 2 m PVC cable, 3 x 24 AWG
Capacitive
M181 sensors
with special
properties
Capacitive
sensors for
analog distance
4
measurement
70
Cylinder
24 designs
Accessories
10
for capacitive
sensors
Applications
The capacitive analog sensor makes linear evaluation of a position
possible for the rst time; as soon as an object is located within the
sensor's measuring range, a precise output current is produced.
The uses shown represent only a fraction of the multifaceted
application options provided by the capacitive analog sensor.
Material selection Measuring nonmetallic coat- Product thickness Height measurement Determining diameters
ing thicknesses monitoring
Static/Dynamic movement Registering radial runout Concentricity and eccentricity Axial and radial Monitoring fit
concentricity deviation
www.balluff.com 837
Capacitive
Sensors
Special accessories for capacitive sensors
The numerous varieties of capacitive sensors for individual solutions
are enhanced by custom matched accessories. For example, there
are switching devices for particular exibility with varying voltage, in
order to be able to attach the sensors optimally.
Precisely matched mounting elements ensure exact positioning.

Accessories for Capacitive Sensors
Contents
Accessories for capacitive sensors

Sensor ampliers 841
Adapters 848
www.balluff.com 839
Accessories for capacitive sensors
Sensor amplier for capacitive sensors without
internal amplier
Size 453015 mm
PNP NO Ordering code BAE009E
Part number BAE SA-CS-001-PS
PNP NC Ordering code BAE009F
Part number BAE SA-CS-001-PO
NPN NO Ordering code BAE009H
Part number BAE SA-CS-001-NS
NPN NC Ordering code BAE009J
Part number BAE SA-CS-001-NO Capacitive
Supply voltage UB 1235 V DC sensors
Voltage drop Ud at Ie 0.8 V
Rated insulation voltage Ui 75 V DC Capacitive
sensors for
Output current max. 300 mA object detection
Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes Capacitive
sensors for
Ambient temperature Ta 30+70 C level detection
Supply voltage/Output function indicator Green LED/Yellow LED Capacitive
Degree of protection as per IEC 60529 IP 67 sensors
with special
Material Housing PC properties
Connection 2 m PUR cable 326 AWG
Capacitive
sensors for
Pin assignments 15 30 analog distance
M34
9 measurement
bn (1) +
bk (4) Accessories
PNP bu (3) -
for capacitive
5.5 sensors
LED1
35
45
30
Sensor
4.2
NPN
bn (1) + LED2
bk (4) ampliers
bu (3) - Adapters
sn
Function overview
9
LED 1: Switching state indicator
LED 2: Shows supply voltage
Item 1: Through-hole
4.2 mm, hexagonal on
both sides
for inserting an M3 nut
www.balluff.com 841
Sensor amplier for two capacitive sensors, without
internal amplier
Technical details
Two separate sensor
ampliers in one housing
Connection for two
capacitive sensors without
internal amplier
PNP and NPN transistor
output Size 98.57522.5 mm
Function normally open/ Installation type DIN rail (EN 60751)
normally closed can be PNP/NPN and NO/NC, Ordering code BAE009P
switched wiring selected Part number BAE SA-CS-002-YP
Actuation delay (normally open) Supply voltage UB 1035 V DC
selectable 10 ms/2 s Voltage drop Ud at Ie 0.8 V
Turn-off delay (normally closed) Rated insulation voltage Ui 75 V DC
selectable 10 ms/2s Output current max. 300 mA
Clamping terminal No-load supply current I0 max. 15 mA
Switching distance for sensors Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes
separately adjustable Ambient temperature Ta 30+70 C
Switching status indicated by Switching frequency f 100 Hz
two separate LEDs Output function indicator Yellow LED
Degree of protection as per IEC 60529 IP 40 (IP 20 at terminal box)
Material Housing PC
Connection max. 14 AWG
Pin assignments 7 8 9
+24 V 7
GND 10
10 11 12
bn 1 11 PNP
bk 3 10 ms
2s 0 0
10 ms
2s 12 NPN
bu 2
98.5
bn 4 8 PNP
bk 6 10 ms
2s 0 0
10 ms
2s 9 NPN
bu 5
Display
1 2 3
4 5 6
sn
20x
LED 2
10ms 2s
10ms 2s
35 (EN 60175)
LED 1
20x
7 8 9
22.5 75
sn LED 2 LED 1
10 11 12
3 6 9 12
2 5 8 11
1 4 7 10
sn 2 sn 1

Sensor amplier with logic for two capacitive sensors without
internal amplier
Sensor amplier with logic

Connection for two
capacitive sensors without
internal amplier
Two outputs each PNP/NPN
for Q and Q
Pick-up delay selectable
10 ms/2 s Size 98.57522.5 mm
Function OR, AND, RS-FF, Installation type DIN rail (EN 60751)
min/max selectable PNP/NPN and NO/NC, Ordering code BAE009R
Clamping terminal wiring selected Part number BAE SA-CS-003-YP
Switching distance for sensors Supply voltage UB 1035 V DC
separately adjustable Voltage drop Ud at Ie 0.8 V
Switching status indicated by Rated insulation voltage Ui 75 V DC
two separate LEDs Output current max. 300 mA
No-load supply current I0 max. 25 mA Capacitive
OR function Polarity reversal protected/transposition protected/short-circuit protected Yes/Yes/Yes sensors
Output Q active when one or Ambient temperature Ta 30+70 C
both sensors are damped. Switching frequency f 100 Hz Capacitive
sensors for
Output function indicator Yellow LED object detection
AND function Degree of protection as per IEC 60529 IP 40 (IP 20 at terminal box)
Output Q active only when both Material Housing PC Capacitive
sensors for
sensors are damped. Connection Max. 14 AWG level detection
RS-FF function Pin assignments 7 8 9

Capacitive
sensors
Output Q active when the sensor with special
+24V 7
is rst damped on the Set input. GND 10 properties
10 11 12
This status is retained until the bn 1 11 Q PNP

&
sensor is damped on the Reset
bk 3 12 Q NPN Capacitive
bu 2
>1 sensors for
input. R analog distance
98.5
bn 4 S 8 Q PNP
bk 6
measurement
Min/Max 9 Q NPN
bu 5
Function min/max
Accessories
Output Q active when both for capacitive
sensors are damped. The output Display sensors
is only reset when both sensors Sensor
+24V 7 ampliers
are undamped. GND 10
Adapters
bn 1 11 Q PNP
&
bk 3 12 Q NPN 35 (EN 60175)
bu 2
>1 22.5 75
R
bn 4 S 8 Q PNP LED 2 LED 1
bk 6 9 Q NPN
Min/Max 3 6 9 12
bu 5
2 5 8 11
1 4 7 10
sn 2 sn 1
www.balluff.com 843
Sensor amplier for one capacitive sensor without
internal amplier
Size 98.57522.5 mm 98.57522.5 mm

Installation type DIN rail (EN 60751) DIN rail (EN 60751)
PNP/NPN and NO/NC, Ordering code BAE009K BAE009L
wiring selected Part number BAE SA-CS-006-XR BAE SA-CS-007-XR
Supply voltage UB 230 V AC 115 V AC
Output current max. 8A 8A
Polarity reversal protected/transposition protected/short-circuit protected Floating relay Floating relay
Material Housing PC PC
Connection Max. 14 AWG Max. 14 AWG
7 8 9 7 8 9
Pin assignments
10 11 12 10 11 12
L1 11
N 12
bn 1 t1 t2
9
bk 3
8
98.5
98.5
bu 2
7
Display
1 2 3
4 5 6
sn
SNG-220AC-K
20x SK-Adj.
OUT
7 8 9
LED 35 (EN 60715) 35 (EN 60715)
10 11 12 22.5 75 22.5 75
3 6 9 12 3 6 9 12
2 5 8 11 2 5 8 11
1 4 7 10 1 4 7 10
sn LED sn LED

Sensor amplier with Min/Max level control for two
capacitive sensors without internal amplier
Size 98.57522.5 mm 98.57522.5 mm

PNP/NPN and NO/NC, Ordering code BAE009T BAE009U
wiring selected Part number BAE SA-CS-004-XR BAE SA-CS-005-XR
Polarity reversal protected/transposition protected/short-circuit protected Floating relay Floating relay Capacitive
Ambient temperature Ta 30+70 C 30+70 C sensors
Output function indicator Yellow LED Yellow LED Capacitive
sensors for
Degree of protection as per IEC 60529 IP 40 (IP 20 terminal enclosure) IP 40 (IP 20 terminal enclosure) object detection
Connection Max. 14 AWG Max. 14 AWG Capacitive
sensors for
level detection
Pin assignments
7 8 9 7 8 9
Capacitive
L1 11 sensors
N 12
10 11 12 10 11 12
with special
bn 1 properties
9
bk 3
8
2
bu Min/ 7
Max Capacitive
bn
98.5
98.5
4
t1 t2
sensors for
bk 5 analog distance
6
bu measurement
Accessories
Display for capacitive
sensors
1 2 3
sn
Sensor
4 5 6 ampliers
LED A
LED B 35 (EN 60715) 35 (EN 60715) Adapters
LED C 22.5 75 22.5 75
7 8 9 LED D LED A, B, C, D LED A, B, C, D
10 11 12
S1...S4
3 6 9 12 3 6 9 12
sn
2 5 8 11 2 5 8 11
1 4 7 10 1 4 7 10
1 2 1 2
Function Function indicators

When both sensors are undamped, the relay turns on - "LED" A Full
empty" lights up (contact 7/9 closed). If the Min sensor is damped, B Fill
"Fill LED" lights up. When both sensors are damped, the relay C Empty
turns off - "LED full" lights up (contact 7/9 open). If the Max sensor D Empty
is damped, "LED empty" lights up. The relay does not turn on until
both sensors are again undamped. Sensor adjustment
Other functions are selectable using the mini dip switches. Max sensor: Pot I
Min sensor: Pot II
Dip switch functions
S1 Time delay max-sensor (off: approx. 0.2 s; on: approx. 5 s) Applications
S2 Time delay min-sensor (off: approx. 0.2 s; on: approx. 5 s) Min and max level control
S3 Power-on setup (off: ll; on: empty) Input for connecting two capacitive sensors for level sensing,
S4 Output (relay inverse) adjustable separately using two potentiometers
Switch-on delay for min and max sensor can be selected
separately
www.balluff.com 845
Sensor ampliers with timer function and potential-free
changeover contact for one capacitive sensor
Size 98.57522.5 mm 98.57522.5 mm

Potential-free Ordering code BAE009W BAE009Y
changeover contact Part number BAE SA-XE-010-XR BAE SA-XE-011-XR
Pick-up delay 0.05...30 s 0.05...30 s
Release delay 0.05...30 s 0.05...30 s
Connection Screw terminals Screw terminals
Pin assignments 7 8 9 7 8 9
L1 11
N 12
10 11 12 10 11 12
bn
NPN NPN 1
bk 3 9
2 8
PNP PNP bu 4
t1 t2
7
6
98.5
98.5
-1
5
Display
1 2 3
4 5 6
LED
IN
0.5 2.5
sn
t/s
0.05 15
30
SNG-220AC/24DC-T
2.5
0.5
t/s
0.05 15
OUT
30
7 8 9 sn 35 (EN 60715) 35 (EN 60715)

10 11 12 LED 22.5 75 22.5 75
1 2 1 2
3 6 9 12 3 6 9 12
2 5 8 11 2 5 8 11
1 4 7 10 1 4 7 10
Not suitable for devices
with a output stage that can LED LED
be coded
(e.g. BCS S4...)

Sensor ampliers with Min/Max level control and potential-free
changeover contact for two capacitive sensors
Size 98.57522.5 mm 98.57522.5 mm

Potential-free Ordering code BAE009Z BAE00A0
changeover contact Part number BAE SA-XE-012-XR BAE SA-XE-013-XR
Ambient temperature Ta 30+70 C 30+70 C Capacitive
Switching frequency f 5 Hz 5 Hz sensors
Degree of protection as per IEC 60529 IP 20 IP 20 Capacitive
sensors for
Material Housing PC PC object detection
Connection Screw terminals Screw terminals
Capacitive
sensors for
Pin assignments level detection
7 8 9 7 8 9
L1 11
N 12 Capacitive
NPN
bn 1
10 11 12 10 11 12 sensors
bk 3
9 with special
8
bu
2
7
properties
PNP Min/
Max
bn
98.5
98.5
NPN 4
t1
bk 6
t2
Capacitive
bu
5 sensors for
PNP
analog distance
measurement
Display
Accessories
1 2 3
sn for capacitive
4 5 6
LED A sensors
LED B Sensor
35 (EN 60715) 35 (EN 60715)
LED C ampliers
7 8 9 LED D 22.5 75 22.5 75 Adapters
S1...S4
10 11 12 LED A, B, C, D LED A, B, C, D
sn
3 6 9 12 3 6 9 12
2 5 8 11 2 5 8 11
1 4 7 10 1 4 7 10
1 2 1 2
Not suitable for devices
with codable nal stage
(e.g. BCS S4...)
Function Function indicators

When both sensors are undamped, the relay turns on - "empty" LED A Full
lights up (contacts 7/9 are closed). If the Min sensor is damped, the B Fill
"ll" LED lights up. When both sensors are damped, the relay turns C Empty
off - "full" LED lights up (contacts 7/9 are open). If the Max sensor is D Empty
damped, the "empty" LED lights up. The relay does not turn on until
both sensors are again undamped. Applications
Other functions are selectable using the mini dip switches. Min and Max level control
Automatic PNP and NPN input voltage for connecting two
Dip switch functions normally open sensors
S1 Time delay max-sensor (off: approx. 0.2 s; on: approx. 5 s) DC short-circuit protected
S2 Time delay min-sensor (off: approx. 0.2 s; on: approx. 5 s) Turn-on delay for Min and Max sensor selectable independently
S3 Power-on setup (off: ll; on: empty)
S4 Output (inverse relay)
www.balluff.com 847
Adapters
Description Adapter Adapter Adapter Adapter

for Micro-Level for Micro-Level for BCS S01/2/3 for BCS S01/2/3
M12 to M18 M12 to G 1/2" M18 to M30 M18 to M32
Ordering code BAM018J BAM018K BAM018E BAM018F
Part number BAM AD-XA-002-M12/M18-4 BAM AD-XA-002-M12/G1/2"-4 BAM AD-XA-001-M18/M30-4 BAM AD-XA-001-M18/M32x1,5-4
Material Stainless steel Stainless steel Stainless steel Stainless steel
Connection
12.5 4
12.5 4
5
5
10
10
41 41
29.5
29.5
M181 M181
M301.5 M321.5
17 17
M181 G 1/2
27 27
M121 M121
Description Adapter Adapter Cable adapter Cable adapter Cable adapter

for BCS S01/2/3 for BCS S01/2/3 for capacitive for capacitive for capacitive
M18 to R 1" M16 to M12 mini-sensors mini-sensors mini-sensors
Ordering code BAM018H BCC04JT BCC04JU BCC04JY BCC04JZ
Part number BAM AD-XA-001-M18/R1"-4 BCC M454-0000-2A-RM004-020 BCC Z001-002 BCC Z002-030 BCC Z002-080
Material Stainless steel MS-Ni/PA
Connection 0.2 m PVC cable, 0.2 m PUR cable 3 m PUR cable 8 m PUR cable
30.25 mm
M121
19
5
8 8
10
10
41
9
17
M181
O-Ring
18.5
18.5
14.3
14.3
R 1
M161.5
0.2 m
13
13
19
19
8 8

Capacitive Sensors wiring diagrams
Connection-Switching diagrams
Wiring diagrams
NO
PNP cable PNP connector
BN 1
! @ +
BK 4
BU 3 -
NPN cable NPN connector

BN 1
# $ +
BK 4
BU 3 -
NC Capacitive
sensors
BN 1
% ^ +
Capacitive
BK 2 sensors for
object detection
BU 3 -
PNP connector NPN cable Capacitive

sensors for
& * level detection

Capacitive
sensors
NPN connector NPN connector with special
BN properties
1
( ) +
BK
4 Capacitive
BU sensors for
3 - analog distance
measurement
Accessories
PNP/NPN selectable for capacitive
BN
sensors
1
P
+ + Sensor
P P N N
BK ampliers
Adapters
N BU
- -
P-NO P-NC N-NC N-NO
2 BN
3 BN
BU
BU
www.balluff.com 849
Magnetic
Cylinder
Sensors
Magnetic cylinder sensors for object detection
The primary application for magnetic sensors is to provide end of
stroke and position detection on pneumatic cylinders.
Lifetime warranty
Low hysteresis, precise switch points
Long service life due to lack of contact and wear
Shock and vibration-resistant
Compact sizes; perfect for short stroke cylinders

Magnetic Cylinder Sensors
Contents
Magnetic cylinder sensors

Introduction 852
Magnetic cylinder sensors with mounting system

BMF 103 858
BMF 303 862
BMF 305 866
BMF 21 872
Magnetic cylinder sensors with a compact design

BMF 204 Global 876
BMF 214 Global 878
BMF 243 Global 880
BMF 235 Global 882
BMF 307 884
Magnetic cylinder sensors with special properties

Robust metal housings - BMF 32M 888
For the food industry - BMF 10E 891
Weld immune - BMF 32M, BMF 305M, BMF 305K, BMF 315M 892
High temperature up to 105 C - BMF 305M, BMF 315M 894
Radially magnetized magnets - BMF 103K, BMF 303K 895
Reed switches - BMF 305K 896
Magnetic sensors for object detection

6.5 mm, M8x1, M12x1 900
Magnets 902
Basic
Magneto-inductive displacement sensors for analog position information
measurement and denitions
can be found
Micro-BIL 906 on page 952.
Accessories for magnetic cylinder sensors

Cable clips 910
Tube cuffs 910
Tools 911
Know your cylinder? Find your sensor at www.balluff.us/bmfcenter 851

Reliable and wear-free position detection on all
pneumatic cylinders Improved sensor performance and
reliability results in less downtime and increased productivity.
Magnetic cylinder sensors are used on cylinders and grippers for
monitoring the piston position. The sensor detects the eld of the
magnet embedded in the piston through the actuator wall. Balluff
cylinder sensors provide reliable position detection, low hysteresis
and high noise immunity. The piston position is reliably detected even
at high speeds with no contact bounce, no moving parts or double
switch points.
Mini-sensors for mini-actuators Better integration options The right sensor for each cylinder Reduce costs with fewer
Balluff offers ideal solutions for short-stroke cylinders and mini-grip- sensors:
pers. The mini cylinder switches from Balluff are among the smallest Virtually any cylinder size and make can be covered with the small
on the market and have a precise switching point. number of designs as well as fastening and mounting materials. A
special sensor element enables Balluff sensors to be used on any
cylinder from virtually any manufacturer.

Sensors with mounting

system or compact sensors
Which sensor is
optimal for your application?
Sensors with Compact sensors

mounting system

Would you like to use just one sensor for Magnetic

Reduce the cylinder
a variety of cylinder types?
number of types sensors
sensors! Performance
spectrum

Do you need to change out sensors Switching point Product

overview
quickly and easily? remains the same
with stay put Magnetic
brackets cylinder

Do you always use the same sensors with

mounting
standard cylinder type (T- or C-slot)? Simple to install, system
compact
Magnetic
cylinder
sensors with
Our standard sensors have Compact sensors a compact
a perfect mounting system: with an integrated holding design
Know your cylinder? Find your sensor. Balluffs exclusive,
Magnetic cylinder sensors BMF element feature compact design
easy to use online Pneumatic Resourse Center is designed Magnetic
with our mounting system and ease of installation. cylinder
to help you select the best solution for specic cylinder
have a captive switching point sensors with
models. special
and can be used universally. properties
Magnetic
Visit: sensors for
object detection
www.balluff.us/bmfcenter on page 857 on page 875
Magneto-
inductive
displacement
sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors
Magnetic cylinder sensors with special properties on page 887
Magnetic sensors for object detection on page 899

Product overview
Magnetic cylinder sensors Magnetic cylinder sensors
with mounting system with a compact design
BMF series 103 303 305 21 32 204 214 243 235

Mini housing
Standard housing
Global
Properties
Integral connector page 867 page 872 page 888
Cable with connector page 859 page 863 page 867 page 876 page 878 page 880 page 882
Cable versions page 859 page 863 page 867 page 872 page 876 page 878 page 880 page 882
V-Twin page 859 page 863 page 867 page 876 page 878 page 880 page 882
Robust metal housing page 890 page 888
For the food industry
Weld-immune electronics page 892 page 892
High-temperature resistant up to 105 C page 894
For radially magnetized
magnets page 895 page 895
Reed switches page 896
Tubular housing with
a long range
For analog distance measurement
Cylinder prole
Size 10 slot Festo,
(C-slot) Sommer,
Bosch
Rounded groove SMC,
(C-slot) Bimba,
Schunk
T-slot General

Round cylinder General

Dovetail slot Bosch,

Parker,
Norgren
Trapezoidal guide Bosch

C-slot, large Numatics,

Norgren
with rail/SMC slot SMC

A and slot B
Prole cylinder General

and tie rod
5...11 mm
and tie rod
9...15 mm
and tie rod
14...20 mm
U-slot SMC CP95


Product overview
Magnetic sensors Magneto-inductive displacement sensors
for object detection for analog position measurement
307 315 10E 6.5 mm M81 M121 Micro-BIL
page 891 page 901

page 884 page 893 page 900 page 907
page 884 page 893 page 901 page 901
page 884 page 893
page 893
page 891
page 892
page 894
page 896
Magnetic
page 907 cylinder
sensors
Performance
spectrum
Product
overview
Magnetic
cylinder
sensors with
mounting
system

Magnetic
cylinder
sensors with
a compact
design
Magnetic
cylinder
sensors with
special
properties
Magnetic
sensors for
object detection
Magneto-
inductive
displacement
sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors

Magnetic
Cylinder
Sensors
With its standard sensors for grippers and pneumatic cylinders,
Balluff provides a exible solution for position detection with standard
sensors and the perfect mounting system. Magnetic cylinder sensors
with mounting system are suited for use on mini-grippers and in
short-stroke cylinders (BMF 103), for miniaturized (BMF 303) as well
as for larger actuators (BMF 305). The switching point is set just once
and remains intact, even when replacing the sensor. This way you
increase the functional reliability of your equipment. Replacement is
signicantly easier and more secure even at difcult-to-access
locations. By selecting the right mounting brackets you can adapt
these sensors to virtually all pneumatic cylinder types.

with Mounting System
Contents

BMF 103 858
BMF 103 mounting brackets 860
BMF 303 862
BMF 305 866
BMF 21 872

BMF 103
The sensor for positioning monitoring on miniature grippers and short

stroke cylinders. Precise switch point for monitoring even the smallest
piston movements.
Series
Properties

Part number
Part number
Part number
Supply voltage UB
Voltage drop Ud
Rated insulation voltage Ie
Rated switching eld strength I Hn I
Assured switching eld strength I Ha I
Temperature drift of switch-on point of I Hn I
On/off delay
Approval
Housing material
Cable
Suggested mounting cable
Basic information and denitions can be found on page 952,

associated mounting brackets for BMF 103 can be found on
page 860.
Additional cable lengths on request
Wiring diagrams
NO contact
PNP cable PNP connector NPN cable NPN connector V-Twin PNP connector
BN

BK
6

NC contact

PNP cable PNP connector WH
6
BU


BMF 103
BMF 103 BMF 103 BMF 103 BMF 103 BMF 103
Perpendicular cable exit Perpendicular cable exit Perpendicular cable exit Perpendicular cable exit Perpendicular cable exit
sensor with sensor with V-Twin with with sensor with
M5 connector M8 connector M8 connector M12 connector PUR cable
BMF001J BMF001L BMF001R BMF001K BMF001E
BMF 103K-PS-C-2A-S26-00,3 BMF 103K-PS-C-2A-SA2-S49-00,3 BMF 103K-PS-C-2A-SA95-S75-00,3 BMF 103K-PS-C-2A-S4-00,5 BMF 103K-PS-C-2A-PU-02
BMF0015 BMF0013
BMF 103K-PO-C-2A-SA2-S49-00,3 BMF 103K-PO-C-2A-PU-02
BMF0011 BMF000Y
BMF 103K-NS-C-2A-SA2-S49-00,3 BMF 103K-NS-C-2A-PU-02
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
100 mA 100 mA 100 mA 100 mA 100 mA
Magnetic
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes cylinder
1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) sensors
2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss)
Magnetic
0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C cylinder
25...+85 C 25...+85 C 25...+85 C 25...+85 C 25...+85 C sensors with
mounting
0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms system
IP 67 IP 67 IP 67 IP 67 IP 67 BMF 103
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus BMF 303
LCP LCP LCP LCP LCP BMF 305
0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 0.5 m PUR cable with 2 m PUR cable BMF 21
Total Productive
M8 connector, 3-pin M8 connector, 3-pin M8 connector, 4-pin M8 connector, 4-pin Maintenance
BKS-B 25-3-PU-05 BCC M313-0000-10-001-PX43T2-050 BCC M314-0000-10-003-PX43T2-050 BCC M415-0000-1A-003-PX44T2-050 28 AWG
Magnetic
cylinder
sensors with
2.75
2.75
4.8
4.8
a compact
M121 design
Magnetic
Sensing
surface
cylinder
Sensing
surface
max. 40
sensors with
max. 46
special
properties
Sensing surface Magnetic

sensors for
object detection
Sensing surface Sensing surface Magneto-

inductive
displacement
sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors
Suitable mounting brackets for BMF 103 can be found on page 860.

BMF 103 mounting bracket
Mounting bracket for BMF 103 BMF 103 BMF 103 BMF 103
Slot
C-slot C-slot Size 10 slot C-slot C-slot Size 10 slot
Ordering code BAM00K8 BAM00K9 BAM00KN BAM00KP
Part number BMF 103-HW-41 BMF 103-HW-42 BMF 103-HW-85 BMF 103-HW-87
Installation advantages
Cylinder type, for example SMC, Bimba, Schunk Festo, Sommer, Bosch SMC, Bimba, Schunk Festo, Sommer,
Bosch
Dimensions of
cylinder slot
Switching point adjusted

in seconds! Open screw with one
turn, adjust position, tighten.
Switching point cannot be lost.

Even if you replace the sensor,
the adjusted switching point is
permanently set by the mounting
bracket.
Can be inserted into slot from

above.
Slot
Bimba at1 Dovetail Dovetail Dovetail
Ordering code BAM00KC BAM00KJ BAM00KF BAM01ML
Cylinder type, for example Bimba Numatics Fabco Pancake Compact air
Dimensions of

cylinder slot

0[ 0[

r

0[$
0[$

r

BMF 10
103 BMF 10
103 BMF 103 BMF 103 BMF 103
C-slot C-slot Size 10 slot T-slot Round Cylinder Tie rod

BAM01K6 BAM01K7 BAM00KA BAM01E2 BAM00KH
BMF 103-HW-100 BMF 103-HW-102 BMF 103-HW-43 BMF 103-HW-93 BMF 103-HW-74
SMC, Bimba, Schunk Festo, Sommer, Bosch Festo, Bosch, SMC Without slot, round cylinder Phd
08...80 mm with tube cuff
0LQ
0D[
Magnetic
cylinder
sensors

Magnetic

0[[ 0[

cylinder
sensors with

mounting

5

system
BMF 103

BMF 303
BMF 305

BMF 21
Total Productive
Maintenance
Magnetic
cylinder
sensors with
a compact
design
Magnetic
cylinder
sensors with
special
properties
Magnetic
sensors for
object detection
Magneto-
inductive
displacement
Recommended accessories sensors for
(please order separately) analog position
measurement
Accessories
for magnetic
cylinder sensors
Special accessories for magnetic cylinder sensors, such as

installation tools, cable clips, or tube cuffs, can be found in

BMF 303
The universal sensor for position monitoring on small grippers

and cylinders. A variety of mounting brackets enables adapting
to virtually every miniaturized pneumatic actuator on the market.
Series
Properties

Part number
Part number
Part number
Part number
Supply voltage US
Voltage drop Ud
Hysteresis of I Hn I
On/off delay
Approval
Housing material
Cable

page 864.
Wiring diagrams
NO
BN

BK
6

NC
PNP cable PNP connector NPN cable NPN connector

WH
6
BU


BMF 303
Cylinder sensor for Cylinder sensor for V-Twin variant for V-Twin variant for Cylinder sensor for
all common cylinders all common cylinders all common cylinders all common cylinders all common cylinders
with M5 connector with M8 connector with M8 connector with M12 connector with direct PUR cable
BMF003Z BMF0043 BMF004F BMF004E BMF003U
BMF 303K-PS-C-2A-S26-00,3 BMF 303K-PS-C-2A-SA2-S49-00,3 BMF 303K-PS-C-2A-SA95-S75-00,3 BMF 303K-PS-C-2A-SA95-S4-00,3 BMF 303K-PS-C-2A-PU-02
BMF0039 BMF0036
BMF0033 BMF0034 BMF0031
BMF 303K-NS-C-2A-S26-00,3 BMF 303K-NS-C-2A-SA2-S49-00,3 BMF 303K-NS-C-2A-PU-02
BMF002Y BMF002U
BMF 303K-NO-C-2A-SA2-S49-00,3 BMF 303K-NO-C-2A-PU-02
2V 2V 2V 2V 2V Magnetic
75 V DC 75 V DC 75 V DC 75 V DC 75 V DC cylinder
sensors
100 mA 100 mA 100 mA 100 mA 100 mA
Magnetic
1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) cylinder
2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) sensors with
mounting
45% 45% 45% 45% 45% system
0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C BMF 103
0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms BMF 303
25...+85 C 25...+85 C 25...+85 C 25...+85 C 25...+85 C BMF 305
IP 67 IP 67 IP 67 IP 67 IP 67 BMF 21
Total Productive
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus Maintenance
LCP LCP LCP LCP LCP
0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 2 m PUR cable Magnetic
M5 connector, 3-pin M8 connector, 3-pin M8 connector, 4-pin M12 connector, 4-pin cylinder
sensors with
BKS-B 25-3-PU-05 BCC M313-0000-10-001-PX43T2-050 BCC M314-0000-10-003-PX43T2-050 BCC M415-0000-1A-003-PX44T2-050 28 AWG a compact
design
Magnetic
cylinder
sensors with
special
properties
Magnetic
sensors for
object detection
Magneto-
inductive
Sensing surface
Sensing surface
Sensing surface
Sensing surface
Sensing surface
displacement
sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors
Suitable mounting brackets for BMF 303 can be found on page 864

Slot
C-slot C-slot Size 10 slot C-slot C-slot Size 10 slot
Ordering code BAM00KZ BAM00L0 BAM01F0 BAM00L1
Cylinder type, SMC, Bimba, Schunk Festo, Sommer, Bosch SMC, Bimba, Schunk Festo, Sommer, Bosch
for example
Dimensions of
cylinder slot
Slot
Round Cylinder Round cylinder Dovetail Trapezoidal slot
Ordering code BAM00L3 BAM00L7 BAM01K9 BAM00LF
Cylinder type, Without slot, round Without slot, round Bosch, Parker, Norgren Bosch
for example cylinder 08...80 mm with cylinder 8...80 mm
tube cuff with tube cuff
Dimensions of 10.2...11.4
cylinder slot 60...90
min.11.4
8.9

0 1.5
M3
1.5
8

4.9

11.7


C-slot, large T-slot T-slot T-slot T-slot

BAM00LA BAM00L4 BAM00L2 BAM00L6 BAM00L8
Numatics, Norgren Festo, Bosch, SMC Festo, Bosch, SMC SMC Slot A, Slot B SMC Slot A and Slot B
for expanding the
BMF 303-HW-51
5.4...6
6.5...7.2 Type A Type B Type A Type B

Magnetic
cylinder
sensors
Expansion of the HW-51 with
12.5 Type A HW-60: for fastening the sensor Magnetic
M2 6.45 next to the slot. This lets you cylinder
attach two sensors to the cylinder sensors with
even when space is tight. mounting
5
For example, system

2 HW-51 + 2 HW-60 or
2 HW-51 + 1 HW-60 BMF 103
Type B BMF 303
BMF 305
BMF 21
Total Productive
Maintenance
BMF 303 BMF 303 BMF 303 Magnetic

cylinder
Sensor disappears in the slot. sensors with
Dovetail Dovetail U-slot a compact
BAM00L5 BAM00LE BAM01K4 design
BMF 303-HW-44 BMF 303-HW-69 BMF 303-HW-103 Switching point adjusted in seconds! Open screw with one Magnetic
turn, adjust position, tighten. cylinder
sensors with
special
Festo, Bosch, Numatics, Fabco pancake SMC CP95 properties
Hoerbiger - Origa Switching point cannot be lost. Even if you replace the
sensor, the adjusted switching point is permanently set by Magnetic
the mounting bracket. sensors for
object detection
7.4
105 Magneto-

Can be inserted into slot from above. inductive

6
displacement

6.3
r
sensors for
Recommended accessories analog position
measurement

Accessories
M2 1.5 for magnetic

cylinder sensors

8.6

r
2.8 6

7.3

r

r




BMF 305
The universal sensor for position monitoring on large actuators
Series
Properties

Part number
Part number
Part number
Part number
Supply voltage UB
Voltage drop Ud
Hysteresis of I Hn I
On/off delay
Temperature load curve Degree of protection as per IEC 60529
Approval
Material Housing
Cable

page 868.
Wiring diagrams
NO
BN

BK
6

NC
PNP cable PNP connector NPN cable NPN connector WH
6
BU


BMF 305
Universal Universal Universal Universal Universal
position monitoring with position monitoring with position monitoring with position monitoring with position monitoring with
M8 connector M8 connector M12 connector M12 connector PUR cable
BMF005L BMF0060 BMF0058 BMF005Z BMF0056
BMF 305K-PS-C-2-SA2-S49-00,3 BMF 305K-PS-C-2-SA95-S75-00,3 BMF 305K-PS-C-2-S4-00,2 BMF 305K-PS-C-2-SA95-S4-00,3 BMF 305K-PS-C-2-PU-02
BMF0055 BMF0052
BMF 305K-PO-C-2-SA2-S49-00,3 BMF 305K-PO-C-2-PU-02
BMF0050 BMF004W
BMF 305K-NS-C-2-SA2-S49-00,3 BMF 305K-NS-C-2-PU-02
BMF004U BMF004P
BMF 305K-NO-C-2-SA2-S49-00,3 BMF 305K-NO-C-2-PU-02
3.1 V 3.1 V 2V 3.1 V 3.1 V Magnetic
sensors
200 mA 200 mA 100 mA 200 mA 200 mA
30 mA 30 mA 5 mA 30 mA 30 mA
Magnetic
Yes/Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes cylinder
1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) sensors with
mounting
2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) system
45% 45% 45% 45% 45% BMF 103
0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C BMF 303
0.05 ms/ 0.05 ms 0.05 ms 0.07 ms 0.05 ms 0.05 ms BMF 305
25...+85 C 25...+85 C 25...+70 C 25...+85 C 25...+85 C BMF 21
Total Productive
IP 67 IP 67 IP 67 IP 67 IP 67 Maintenance
LCP LCP LCP LCP LCP Magnetic
0.3 m PUR cable with 0.3 m PUR cable with 0.2 m PUR cable with 0.3 m PUR cable with 2 m PUR cable cylinder
sensors with
M8 connector, 3-pin M8 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin a compact
design
BCC M313-0000-10-001-PX43T2-050 BCC M314-0000-10-003-PX43T2-050 BCC M415-0000-1A-003-PX44T2-050 BCC M415-0000-1A-003-PX44T2-050 26 AWG
Magnetic
cylinder
sensors with
special
properties
Magnetic
max. 40
sensors for
object detection
Magneto-
inductive
displacement
sensors for
analog position
measurement
Sensing Sensing Sensing Sensing Sensing
surface surface surface surface surface Accessories
for magnetic
cylinder sensors
Suitable mounting brackets for BMF 305 can be found on page 868

Slot
C-slot, large C-slot, large T-slot T-slot
Ordering code BAM00LW BAM01C4 BAM00LH BAM00LJ
Cylinder type, Norgren Numatics Festo, SMC, Bosch Festo, SMC, Bosch
for example
Dimensions of
cylinder slot
M3x5(2x)
6.9
2.5
8 4.8
13
Slot
T-slot T-slot T-slot T-slot
Ordering code BAM00M6 BAM00M7 BAM0017 BAM00LN
Cylinder type, SMC PHD Parker, 3MA, 4MA Festo, SMC, Bosch
for example
Dimensions of

cylinder slot

0[$ 0[$

0[


T-slot T-slot L-slot L-slot T-slot

BAM01EZ BAM00LM BAM00MO BAM00M9 BAM00M5
Festo, SMC, Bosch Festo, SMC, Bosch Parker, SST, ER Bosch
Magnetic
cylinder
sensors

Magnetic
cylinder

sensors with

mounting

system

BMF 103

0
BMF 303
BMF 305
BMF 21
Total Productive
Maintenance
Magnetic
cylinder
sensors with
BMF 305 BMF 305 BMF 305 BMF 305 BMF 305 a compact
design
T-slot T-slot Round cylinder Tie rod Tie rod
Magnetic
BAM00LT BAM01EY BAM00LP BAM00MC BAM00ME cylinder
BMF 305-HW-26 BMF 305-HW-99 BMF 305-HW-24 BMF 305-HW-70 BMF 305-HW-71 sensors with
special
properties
SMC SMC Round cylinder Magnetic

sensors for
8...80 mm object detection
0LQ 0LQ
0D[ 0D[
0LQ 0LQ Magneto-
0D[ 0D[
inductive
displacement
sensors for
Type A Type B Type A Type B analog position
measurement
M3x6-A2 M3x6-A2
Accessories
M3x10(2X) 9.0
8.0
for magnetic
Type A Type A cylinder sensors
20.0
20.0
18.2
13.5
8.5
17.5
8.5
4.6
15.7
4.0
4.8
2.2
2.4 20.2
6.3
18.4
29.7 M3x10 (2X)
28.0 4.8
Type B Type B

Slot
Tie rod Prole/tie rod Prole/tie rod Dovetail
Ordering code BAM00MF BAM00LL BAM00LL BAM00LY
Cylinder type, For prole/tie rod cylinders For prole/tie rod cylinders Tol-o-matic
for example 6.5 mm in conjunction 6.517 mm in conjunc-
with BAM00KY tion with BAM00KT
0LQ
Dimensions of 0D[

cylinder slot 0LQ
0D[

r

0[$ 0J

r

0[;

Mounting bracket for BMF 305 BMF 305 BMF 305

Slot
Dovetail Dovetail Trapezoidal guide
Ordering code BAM01K8 BAM00LR BAM00LU
Part number BMF 305-HW-106 BMF 305-HW-25 BMF 305-HW-27
T-slot
Cylinder type, Bosch
for example
Dimensions of
cylinder slot

8.9
M3 1.5
M3
6.70
11.7 4.9

r

4.90

Dovetail Dovetail Dovetail Dovetail Dovetail

BAM00LZ BAM00M1 BAM00M2 BAM00M3
Numatics De-Sta-Co Compact air Norgren 92000 Norgren 46000
r

5
5

Magnetic
cylinder
sensors
2.4
0 0 0
O11.6
4.8

r

Magnetic
O7

cylinder
0[$ sensors with
.30
r
6.7 mounting
system

0[
BMF 103

r

BMF 303
BMF 305
BMF 21
Total Productive
Maintenance
Magnetic
Can be inserted in slot from above. cylinder
Quick and time-saving. sensors with
a compact
design
Switching point adjusted in seconds! Open screw with one Magnetic

turn, adjust position, tighten. cylinder
sensors with
special
properties
Switching point cannot be lost. Even if you replace the
sensor, the adjusted switching point is permanently set by Magnetic
the mounting bracket. sensors for
object detection
Magneto-
inductive
displacement
sensors for
measurement
Accessories
for magnetic
cylinder sensors


BMF 21
Integral swinging bracket arm for

self adjustment across a wide
range of cylinder diameters.
Series BMF 21 BMF 21

Properties For cylinders For cylinders
with tie rod, DUO rail, round with tie rod, DUO rail, round
cylinder and prole cylinder cylinder and prole cylinder
with M8 connector with direct PUR cable
PNP, NO Ordering code BMF0029 BMF0026
Part number BMF 21K-PS-C-2-S49 BMF 21K-PS-C-2-PU-02
NPN, NO Ordering code BMF0025 BMF0023
Part number BMF 21K-NS-C-2-S49 BMF 21K-NS-C-2-PU-02
Voltage drop Ud 3.1 V 3.1 V
Rated switching eld strength I Hn I 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss)
Assured switching eld strength I Ha I 2 kA/m (25 Gauss) 2 kA/m (25 Gauss)
Hysteresis of I Hn I 45% 45%
Temperature drift of switch-on point of I Hn I 0.3 %/C 0.3 %/C
Turn-on delay 0.05 ms 0.05 ms
Turn-off delay 0.05 ms 0.05 ms
Approval CE, cULus CE
Housing material PBT (berglass reinforced) PBT (berglass reinforced)
Cable/suggested mating cable BCC M313-0000-10-001-PX43T2-050 26 AWG

page 873.
Additional cable lengths on request Sensing Sensing

surface surface
Temperature load curve
Wiring diagrams
NO

Stainless steel
Slot
Tie rod Prole/tie rod Prole/tie rod Round cylinder
Ordering code BAM00KY BAM00KT BAM00KU BAM00KW
Part number BMF 21-HW-8 BMF 21-HW-10 BMF 21-HW-10-E BMF 21-HW-11
Cylinder type For pneumatic cylinders For pneumatic cylinders For pneumatic cylinders For pneumatic cylinders
with tie rod. Any piston with tie rod. Any piston with tie rod. Any piston without tie rod/rail. Piston
diameter, tie rod diameter diameter, tie rod diameter diameter, tie rod diameter diameter 8...80 mm.
up to 6.5 mm. up to 17 mm. up to 17 mm. Mounting bracket usable
only with hose clamps.
Pneumatic cylinder with For pneumatic cylinder For pneumatic cylinder
DUO rail (Festo), with tie rod integrated in with tie rod integrated in
any piston diameter housing (prole). housing (prole).
Any piston diameter, Any piston diameter,
prole width prole width Magnetic
up to 17 mm. up to 17 mm. cylinder
sensors
303 Stainless steel Magnetic

cylinder
sensors with
mounting
Cylinder system
BMF 103
BMF 303
BMF 305
BMF 21
Total Productive
Maintenance
Magnetic
cylinder
sensors with
a compact
design
Magnetic
cylinder
sensors with
special
properties
Magnetic
sensors for
object detection
Magneto-
inductive
displacement
sensors for
measurement
Accessories
for magnetic
cylinder sensors


Magnetic
Cylinder
Sensors
Compact magnetic cylinder sensors are adapted to C-slot and T-slot
shapes and thus have a perfect hold. They can be installed ush in
the respective slot either by sliding in or dropping in from above.
Global: The complete series of standard sensors

Magnetic standard cylinder sensors are standard stock, can be
used around the world, and meet worldwide standards. They offer
an optimal price/performance ratio.
Compact designs for
Insertion from above or the side
Cable and connector versions
V-Twin variants available

with a Compact Design
Contents

BMF 204 Global 876
BMF 214 Global 878
BMF 243 Global 880
BMF 235 Global 882
BMF 307 884

Magnetic Cylinder Sensors C-slot (size 10 slot)
BMF 204 Global Slide-in
Installed and adjusted quickly and easily
The retaining element is integrated into the sensor.
Can also be used in space-critical applications

Flush-tting, the sensor "disappears" in the slot.
Optimum solution for every gripper and short-stroke cylinder

Miniature design, extremely short Series
Properties

Part number
Supply voltage UB
Voltage drop Ud
On/off delay
Approval
Housing material
Cable

Installation
Slot
Basic information and denitions can be found on page 952.
The BMF 204 and BMF 214 have

an impressive, extremely compact
design.
Wiring diagrams Slot dimension V-Twin PNP connector
BN
NO C-slot (size 10 slot)
BK
6
PNP cable PNP connector e.g. Festo

WH
6
BU


BMF 204 Global
Small housing Small housing V-Twin Small housing Small housing V-Twin Small housing
for the Festo C-slot for the Festo C-slot for the Festo C-slot for the Festo C-slot for the Festo C-slot
with M8 connector with M8 connector with M12 connector with M12 connector with PUR cable
BMF0002 BMF0006 BMF00A6 BMF0005 BMF0001
BMF 204K-PS-C-2A-SA2-S49-00,3 BMF 204K-PS-C-2A-SA95-S75-00,3 BMF 204K-PS-C-2A-SA2-S4-00,3 BMF 204K-PS-C-2A-SA95-S4-00,3 BMF 204K-PS-C-2A-PU-02
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
100 mA 100 mA 100 mA 100 mA 100 mA
8 mA 8 mA 8 mA 8 mA 8 mA
1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss)
2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) Magnetic
0.3%/C 0.3%/C 0.3%/C 0.3%/C 0.3%/C cylinder
sensors
0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms
25...+85 C 25...+85 C 25...+85 C 25...+85 C 25...+85 C
Magnetic
IP 67 IP 67 IP 67 IP 67 IP 67 cylinder
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus sensors with
mounting
25...+85 C 25...+85 C 25...+85 C 25...+85 C 25...+85 C system
0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 2 m PUR cable,
M8 connector, 3-pin M8 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin 28 AWG Magnetic
cylinder
BCC M313-0000-10-001-VX43T2-050-C013 BCC M314-0000-10-003-VX44T2-050-C013 BCC M415-0000-1A-003-VX44T2-050-C013 BCC M415-0000-1A-003-VX44T2-050-C013 sensors with
Slide-in Slide-in Slide-in Slide-in 28 AWG Slide-in a compact
design
C-slot (size 10 slot) C-slot (size 10 slot) C-slot (size 10 slot) C-slot (size 10 slot) C-slot (size 10 slot) BMF 204
Global
BMF 214
Global
BMF 243
Global
BMF 235
Global
BMF 307
Magnetic
Sensing cylinder
Sensing Sensing Sensing Sensing
surface sensors with
surface surface surface surface
special
properties
Magnetic
sensors for
object detection
Recommended accessories Magneto-

(please order separately) inductive
displacement
sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors


Magnetic Cylinder Sensors C-slot (rounded slot)
BMF 214 Global Slide-in
Installed and adjusted quickly and easily
The retaining element is integrated into the sensor.
Can also be used in space-critical applications

Flush-tting, the sensor "disappears" in the slot.
Optimum solution for every gripper and short-stroke cylinder

Miniature design, extremely short. Series
Properties

Part number
Supply voltage UB
Voltage drop Ud
On/off delay
Approval
Housing material
Cable
Suggested mounting cable

Installation
Slot

V-Twin two sensors, one connector
Less installation hardware
Less wiring
Less installation time
Less cost
Wiring diagrams Slot dimension V-Twin PNP connector

BN
NO contact C-slot (rounded slot)
BK
6
PNP cable PNP connector e.g. SMC

WH
6
BU


with a Compact
Com Design
BMF 214 Glo
Global
BMF 214 BMF 214 BMF 21 214 BMF 214 BMF 214
Small housing Small housing V-Twin Small housing Small housing V-Twin Small housing
for the SMC C-slot for the SMC C-slot for the SMC C-slot for the SMC C-slot for the SMC C-slot
with M8 connector with M8 connector with M12 connector with M12 connector with PUR cable
BMF00A2 BMF00A5 BMF00FC BMF00A4 BMF00A1
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V
100 mA 100 mA 100 mA 100 mA 100 mA
1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss)
2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) Magnetic
0.3%/C 0.3%/C 0.3%/C 0.3%/C 0.3%/C cylinder
sensors
25...+85 C 25...+85 C 25...+85 C 25...+85 C 25...+85 C
Magnetic
IP 67 IP 67 IP 67 IP 67 IP 67 cylinder
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus sensors with
mounting
25...+85 C 25...+85 C 25...+85 C 25...+85 C 25...+85 C system
0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 2 m PUR cable,
M8 connector, 3-pin M8 connector, 4-pin M12 connector, 4-pin M12 connector, 4-pin Magnetic
cylinder
BCC M313-0000-10-001-VX43T2-050-C013 BCC M314-0000-10-003-VX44T2-050-C013 BCC M415-0000-1A-003-VX44T2-050-C013 BCC M415-0000-1A-003-VX44T2-050-C013 28 AWG sensors with
Slide-in Slide-in Slide-in Slide-in Slide-in a compact
design
C-slot (rounded slot) C-slot (rounded slot) C-slot (size 10 slot) C-slot (rounded slot) C-slot (rounded slot)
BMF 204
Global
BMF 214
Global
BMF 243
Global
BMF 235
Global
BMF 307
Magnetic
cylinder
sensors with
special
Sensing Sensing Sensing Sensing properties
surface surface surface surface
Magnetic
sensors for
object detection
Magneto-
Recommended accessories inductive
displacement
(please order separately) sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors


Magnetic Cylinder Sensors C-slot (rounded
BMF 243 Global slot and size 10 slot)
Drop-in
New mounting concept
Solid hold in the slot, sensor
cannot be wrenched from the
slot.
Can be installed in
the slot from above
Can be installed even on Series
cylinders with an end plate. Properties

Compact design, i.e. Part number
can be mounted ush PNP, NC Ordering code
Can also be used in Part number
space-critical applications NPN, NO Ordering code
Part number
Short housing (24 mm) NPN, NC Ordering code
Can also be used in Part number
space-critical applications Supply voltage UB
Voltage drop Ud
On/off delay
Approval
Housing material
Cable

Installation
Slot
Wiring diagrams
NO
NC contact

BMF 243 Global
BMF 243 BMF 243 BMF 243 BMF 243

The new standard for The new standard for The new standard for The new standard for
every C-slot (rounded slot) with every C-slot (rounded slot) with every C-slot (rounded slot) with every C-slot (rounded slot) with
M8 connector M8 connector M12 connector direct PUR cable
BMF00EL BMF00ET BMF00ER BMF00EF
BMF 243K-PS-C-2A-SA2-S49-00,3 BMF 243K-PS-C-2A-SA95-S75-00,3 BMF 243K-PS-C-2A-SA2-S4-00,3 BMF 243K-PS-C-2A-PU-02
BMF00EM BMF00EH
BMF00EN BMF00EJ
BMF00EP BMF00EK
10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC
2.4 V 2.4 V 2.4 V 2.4 V Magnetic
75 V DC 75 V DC 75 V DC 75 V DC cylinder
sensors
100 mA 100 mA 100 mA 100 mA
7.5 mA 7.5 mA 7.5 mA 7.5 mA
Magnetic
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes cylinder
2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) 2 kA/m (25 Gauss) sensors with
mounting
2.4 kA/m (30 Gauss) 2.4 kA/m (30 Gauss) 2.4 kA/m (30 Gauss) 2.4 kA/m (30 Gauss) system
0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms 0.07 ms/ 0.07 ms
25...+85 C 25...+85 C 25...+85 C 25...+85 C Magnetic
cylinder
IP 67 IP 67 IP 67 IP 67 sensors with
CE, cULus CE, cULus CE, cULus CE, cULus a compact
design
PA 12 and A2 steel PA 12 and A2 steel PA 12 and A2 steel PA 12 and A2 steel
BMF 204
0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 2 m PUR cable Global
M8 connector, 3-pin M8 connector, 4-pin M12 connector, 4-pin BMF 214
Global
BCC M313-0000-10-001-VX43T2-050-C013 BCC M314-0000-10-003-VX43T2-050-C013 BCC M415-0000-1A-003-VX44T2-050-C013 28 AWG
BMF 243
Drop-in Drop-in Drop-in Drop-in Global
C-slot (rounded slot and size 10 slot) C-slot (rounded slot and size 10 slot) C-slot (rounded slot and size 10 slot) C-slot (rounded slot and size 10 slot) BMF 235
Global
BMF 307
3.0 3.8 max. 15 3 3.8
3.8 M121
Magnetic
5
cylinder
5
M2
sensors with
M2
3.8
5
24
24
max. 40
M2
special
24
LED LED properties

max. 46
5
LED
M2
24
Magnetic
LED sensors for
object detection
Magneto-
inductive
displacement
Recommended accessories sensors for
(please order separately) analog position
measurement
Accessories
M8x1 for magnetic
cylinder sensors


Magnetic Cylinder Sensors T-slot
BMF 235 Global Drop-in
Very bright LED
Reliable detection of switching
function from far away
(25 m in bright factory building).
New mounting concept

Solid hold in the slot, sensor
cannot be wrenched from the
Series
slot.
Properties
Knurled screw
Sensor screws in rmly, extreme-
ly secure hold in any slot (e.g.
Part number
Parker, Festo, SMC, Bosch).
Part number
Part number
Part number
Supply voltage UB
Voltage drop Ud
Can be installed from above. Assured switching eld strength I Ha I
Easy installation with Allen or slotted Temperature drift of switch-on point of I Hn I
screwdriver
On/off delay
Approval
Housing material
Cable

Installation
Slot
See page 884 for mounting brackets for tie-rod and round body
cylinders.
Wiring diagrams
NO
BN

BK
6

NC contact
6
BU


BMF 235 Global
The new standard for The new standard for The new standard for The new standard for The new standard for
every T-slot every T-slot V-Twin every T-slot every T-slot V-Twin every T-slot
with M8 connector with M8 connector with M12 connector with M12 connector with direct PUR cable
BMF00C4 BMF00CA BMF00C5 BMF00C9 BMF00AR
BMF00C6 BMF00AT
BMF00C2 BMF00AU
BMF00C3 BMF00AW
2.5 V 2.5 V 2.5 V 2.5 V 2.5 V Magnetic
sensors
100 mA 100 mA 100 mA 100 mA 100 mA
Magnetic
Yes/No/Yes Yes/No/Yes Yes/No/Yes Yes/No/Yes Yes/No/Yes cylinder
mounting
0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C
0.1 ms/ 0.1 ms 0.1 ms/ 0.1 ms 0.1 ms/ 0.1 ms 0.1 ms/ 0.1 ms 0.1 ms/ 0.1 ms Magnetic
cylinder
IP 67 IP 67 IP 67 IP 67 IP 67 a compact
design
BMF 204
PA12 PA12 PA12 PA12 PA12 Global
Global
BMF 243
BCC M313-0000-10-001-VX43T2-050-C013 BCC M314-0000-10-003-VX43T2-050-C013 BCC M415-0000-1A-003-VX44T2-050-C013 BCC M415-0000-1A-003-VX44T2-050-C013 28 AWG Global
Drop-in Drop-in Drop-in Drop-in Drop-in BMF 235
Global
T-slot T-slot T-slot T-slot T-slot
BMF 307
5.5 5.5 5.5
LED LED LED Magnetic
cylinder
5.5 sensors with
23.5
special
23.5
23.5
max. 40
LED
27
27
27
properties
5.5
LED
23.5
27
Magnetic
sensors for
23.5
27
object detection
Magneto-
inductive
max. 40
max. 46
displacement
sensors for
analog position
measurement
M8x1 M121
(please order separately) Accessories
max. 15
for magnetic
cylinder sensors

Magnetic Cylinder Sensors T-slot
BMF 307 Slide-in
The robust and compact sensor for the T-slot. The shape is adapted to
the slot and guarantees a strong hold. The sensor slides into the slot
from the end.
Series
Properties
Mounting BMF 235, BMF 235, BMF 235, BMF 235, PNP, NO Ordering code
bracket for 307, 315 307, 315 307, 315 307, 315 Part number
Slot PNP, NC Ordering code
Round body Prole/tie rod Prole/tie rod Prole/tie rod Part number
Ordering code BAM0149 BAM01M9 BAM01MA BAM01MC NPN, NO Ordering code
Part number BMF 307-HW-112 BMF 235-HW-109 BMF 235-HW-110 BMF 235-HW-111 Part number
Cylinder type, For round body For prole/tie For prole/tie For prole/tie NPN, NC Ordering code
for example cylinders re- rod cylinders rod cylinders rod cylinders Part number
quires tube cuff 5...11 mm 9...15 mm 14...20 mm Supply voltage UB
Voltage drop Ud

25 25 25 Rated insulation voltage Ui

22.8
25.9

31.1

11.3
15.3
M5 M5

30.2 34.2 M5 20.3

39.6



On/off delay
Approval
Housing material
Temperature load curve Cable

Installation
Slot
Wiring diagrams
NO
BN

BK
6

NC contact
6
BU


BMF 307
The compact sensor The compact sensor The compact sensor The compact sensor The compact sensor
for the T-slot with for the T-slot with V-Twin for the T-slot with for the T-slot with V-Twin for the T-slot with
M8 connector M8 connector M12 connector M12 connector direct PUR cable
BMF0072 BMF0077 BMF006Y BMF0076 BMF006U
BMF 307K-PS-C-2-SA2-S49-00,3 BMF 307K-PS-C-2-SA95-S75-00,3 BMF 307K-PS-C-2-S4-00,2 BMF 307K-PS-C-2-SA95-S4-00,3 BMF 307K-PS-C-2-PU-02
BMF006T BMF006M
BMF 307K-PO-C-2-SA2-S49-00,3 BMF 307K-PO-C-2-PU-02
BMF006L BMF006H
BMF307K-NS-C-2-SA2-S49-00,3 BMF 307K-NS-C-2-PU-02
BMF006E BMF0069
BMF 307K-NO-C-2-SA2-S49-00,3 BMF 307K-NO-C-2-PU-02
3.1 V 3.1 V 3.1 V 3.1 V 3.1 V Magnetic
sensors
200 mA 200 mA 200 mA 200 mA 200 mA
30 mA 30 mA 30 mA 30 mA 30 mA
Magnetic
Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes Yes/Yes/Yes cylinder
mounting
0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C
0.05 ms/ 0.05 ms 0.05 ms/ 0.05 ms 0.05 ms/ 0.05 ms 0.05 ms/ 0.05 ms 0.05 ms/ 0.05 ms Magnetic
cylinder
IP 67 IP 67 IP 67 IP 67 IP 67 a compact
design
BMF 204
LCP LCP LCP LCP LCP Global
Global
BMF 243
BCC M313-0000-10-001-PX43T2-050 BCC M314-0000-10-003-PX43T2-050 BCC M415-0000-1A-003-PX44T2-050 BCC M415-0000-1A-003-PX44T2-050 26 AWG Global
Slide-in Slide-in Slide-in Slide-in Slide-in BMF 235
Global
T-slot T-slot T-slot T-slot T-slot BMF 307
Magnetic
cylinder
sensors with
max. 40
special
properties
2.5
2.5
29
29
7.2
7.2
LED LED
Magnetic
sensors for
object detection
Sensing Sensing Sensing Sensing
Sensing
surface surface surface surface surface Magneto-
inductive
displacement
sensors for
measurement
Accessories
for magnetic
cylinder sensors

Magnetic
Cylinder
Sensors
Magnetic cylinder sensors with special
properties
Our magnetic cylinder sensors with special properties such as
stainless steel housing, high temperature and weld eld immune
come in many different varieties. By means of their broad spectrum,
the special features solve almost all applications even in demand-
ing environments.

with Special Properties
Contents
Magnetic cylinder sensors with special properties

For the food industry - BMF 10E 891
Weld-immune electronics -
BMF 32M, BMF 305M, BMF 305K, BMF 315M 892
Temperature-resistant up to 105 C - BMF 305M, BMF 315M 894
For radially magnetized magnets - BMF 103K, BMF 303K 895

Magnetic Cylinder Sensors Metal housing
Robust metal housing
BMF 32M
Series BMF 32M BMF 32M

Properties Robust metal housing with Robust metal housing with
M8 integral connector M12 integral connector
PNP, NO Ordering code BMF0088 BMF0087
Part number BMF 32M-PS-C-2-S49 BMF 32M-PS-C-2-S4
NPN, NO Ordering code BMF0086 BMF0085
Part number BMF 32M-NS-C-2-S49 BMF 32M-NS-C-2-S4
Rated switching eld strength I Hn I 1.2 kA/m 1.2 kA/m
Assured switching eld strength I Ha I 2 kA/m 2 kA/m
Temperature drift of switch-on point of I Hn I 0.3% 0.3%
On/off delay 0.05 ms/ 0.05 ms 0.05 ms/ 0.05 ms
Approval CE, cULus CE, cULus
Housing material Aluminum Aluminum
Suggested mating cable BCC M323-0000-10-001-PX43T2-050 BCC M425-0000-1A-003-PX44T2-050
Installation Can be installed on cylinder Can be installed on cylinder
with 60- or 90-trapezoidal slot with 60- or 90-trapezoidal slot
or with mounting bracket or with mounting bracket

associated mounting brackets for BMF 32M can be found on
page 891.
Sensing
surface
Temperature load curve Sensing
surface
Switching Switching
point point
Wiring diagrams
NO
PNP connector NPN connector
1 1
4 4
3 3

BMF 32M
Mounting bracket for BMF 32M BMF 32M BMF 32M BMF 32M BMF 32M
Slot
Ordering code BAM00MT BAM00MU BAM00MW BAM00MY BAM00MZ

Part number BMF 32-HW-13 BMF 32-HW-14 BMF 32-HW-15 BMF 32-HW-16 BMF 32-HW-49
Cylinder type For pneumatic For pneumatic For pneumatic For pneumatic Small tie rod cylin-
cylinders with cylinders with trap- cylinders with cylinders with ders
tie rod, any piston ezoidal rail (Bosch) tie rod, any piston tie rod, any piston 3/4 to 1-1/8 bore
diameter, tie rod type: diameter, diameter,
diameter 0 822... tie rod diameter tie rod diameter
max. 11 mm 350 up to 17 mm up to 6.5 mm
351
352 Pneumatic cylinder Pneumatic cylinder
353 with tie rod inte- with DUO rail (Festo),
354 grated in the housing any piston diameter Magnetic
355 (prole), cylinder
sensors
Any piston any piston diameter,
diameter prole width up to Magnetic
17 mm cylinder
sensors with
mounting
Cylinder system
Magnetic
cylinder
sensors with
a compact
design
Magnetic
cylinder
sensors with
special

properties
Robust metal
housing
For the food

5
industry

5
Weld-immune
electronics
Temperature-
5 resistant up to
105 C
For radially
magnetized
magnets
Reed switches
Magnetic
sensors for
Recommended accessories Hose clamp BMF size 10...18 object detection
(please order separately) Made of stainless steel for pneumatic cylinders
without tie rod/rail, piston diameter up to 80 mm Magneto-
inductive
displacement
Please order hose clamp separately. See page 910. sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors
this catalog on page 910. 10

Magnetic Cylinder Sensors Metal housing
BMF 305M
Series BMF 305M BMF 305M

Properties The robust universal sensor The robust universal sensor
made of metal for position made of metal for position moni-
monitoring with M8 connector toring with M12 connector
PNP, NO Ordering code BMF008F BMF008E
Part number BMF 305M-PS-C-2-S49 BMF 305M-PS-C-2-S4
NPN, NO Ordering code BMF008C
Part number BMF 305M-NS-C-2-S49
Rated switching eld strength I Hn I 1.2 kA/m (15 Gauss) 1.2 kA/m (15 Gauss)
Assured switching eld strength I Ha I 2 kA/m (25 Gauss) 2 kA/m (25 Gauss)
Temperature drift of switch-on point of I Hn I 0.3% 0.3%
On/off delay 0.05 ms/ 0.05 ms 0.05 ms/ 0.05 ms
Approval CE, cULus CE, cULus
Housing material Aluminum Aluminum
Suggested mating cable BCC M323-0000-10-001-PX43T2-050 BCC M425-0000-1A-003-PX44T2-050

associated mounting brackets for BMF 305M can be found on page 870.
Sensing
surface Sensing
surface
Wiring diagrams
NO
PNP connector NPN connector


Stainless Magnetic Cylinder Sensors
steel For the food industry
BMF 10E
BMF 10E developed for the

higher demands of the food
industry. Extremely robust due
to its one-piece, stainless steel
housing.
Series BMF 10E

Properties The stainless steel sen-
sor specially for the food
industry
PNP, NO Ordering code BMF001Z
Part number BMF 10E-PS-D-2-SA1-S49
Voltage drop Ud 3.1 V
Mounting bracket: Rated switching eld strength I Hn I 1.2 kA/m (15 Gauss)
BMF 10E-HW-19 made of stainless steel 1.4571 Assured switching eld strength I Ha I 2 kA/m (25 Gauss)
Ordering code: BAM00KR Hysteresis of I Hn I 45% Magnetic
(please order separately) Temperature drift of switch-on point of I Hn I 0.3% cylinder
sensors
On/off delay 0.05 ms/ 0.05 ms
Magnetic
Degree of protection as per IEC 60529 IP 69K cylinder
Approval CE sensors with
mounting
Housing material Stainless steel 1.4571 system
Suggested mating cable BCC S323-0000-10-
004-PX0334-050 Magnetic
Please order tube cuff separately. See page 910. cylinder
sensors with
Basic information and denitions can be found on page 952. a compact
design
Magnetic
cylinder
sensors with
Attach marking to
special
cylinder wall
properties
Robust metal
housing
For the food
Temperature load curve industry
Weld-immune
electronics
Temperature-
resistant up to
105 C
For radially
magnetized
magnets
Reed switches
Magnetic
sensors for
object detection
Magneto-
inductive
displacement
Wiring diagrams sensors for
analog position
measurement
NO
PNP connector Accessories
for magnetic
cylinder sensors

Magnetic Cylinder Sensors Weld-immune
With weld-immune electronics electronics
BMF 32M, BMF 305M, BMF 305K
Series BMF 32M BMF 305M BMF 305K

Properties Robust housing with Robust universal sensor Universal for
M12 integral connector made of metal for position monitoring with
position monitoring with M12 connector
M12 integral connector
PNP, NO Ordering code BMF008A BMF0067 BMF0061
Part number BMF 32M-PS-W-2-S4 BMF 305M-PS-W-2-S4 BMF 305K-PS-W-2-SA3-S4-00,8
Voltage drop Ud 4V 4V 4V
Rated switching eld strength I Hn I 1.2 kA/m 1.2 kA/m 1.2 kA/m
Assured switching eld strength I Ha I 2 kA/m 2 kA/m 2 kA/m
On/off delay 50 ms/ 50 ms 50 ms/ 50 ms 50 ms/ 50 ms
Approval CE CE, cULus CE, cULus
Material Housing Aluminum Aluminum LCP
Cable 0.8 m PUR cable
Suggested mating cable BCC M425-0000-1A-003-PX44T2-050 BCC M415-0000-1A-003-PX44T2-050 BCC M415-0000-1A-003-PX44T2-050
Installation Can be installed on cylinder Installation with mounting Installation with mounting
with 60 or 90-trapezoidal bracket bracket
slot or with mounting bracket

page 889; for BMF 305M and 305K see page 868.
Sensing
surface
Suitable for AC welding environments

The series BMF 3...-..-W-.. are suitable for
applications with extreme conditions. The metal
housings are resistant to weld splatter. Applications
with welding currents of over 25 kA do not impair the Sensing Sensing
Switching surface surface
functionality of the sensor. The output state of the point
sensor is stored during AC welding.
V-Twin PNP connector

Wiring diagrams BN

BK
6
NO

WH
6
BU

With weld-immune electronics
BMF 315M
With connector LED

BMF 315M BMF 315M BMF 315M BMF 315M BMF 315M
Metal drop-in compact Metal drop-in compact Metal drop-in compact Metal drop-in compact Metal drop-in compact
T-slot sensor for T-slot sensor for T-slot sensor for T-slot sensor for demand- T-slot sensor for
demanding applications demanding applications demanding applications ing applications with an demanding applications
with an M8 connector with an M12 connector with an M12 connector V-Twin M12 connector with a PUR cable
BMF0082 BMF0081 BMF00C1 BMF0084 BMF007Z
BMF 315M-PS-W-2-S49-00,3 BMF 315M-PS-W-2-S4-00,3 BMF 315M-PS-W-2-SA4-S4-00,3 BMF 315M-PS-W-2-SA95-S4-00,3 BMF 315M-PS-W-2-PU-02
4V 4V 4V 4V 4V
200 mA 200 mA 200 mA 200 mA 200 mA
20 mA 20 mA 20 mA 20 mA 20 mA
1.2 kA/m 1.2 kA/m 1.2 kA/m 1.2 kA/m 1.2 kA/m
2 kA/m 2 kA/m 2 kA/m 2 kA/m 2 kA/m Magnetic
50 ms/ 50 ms 50 ms/ 50 ms 50 ms/ 50 ms 50 ms/ 50 ms 50 ms/ 50 ms cylinder
sensors
25...+70 C 25...+70 C 25...+70 C 25...+85 C 25...+70 C
IP 67 IP 67 IP 67 IP 67 IP 67
Magnetic
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus cylinder
Aluminum Aluminum Aluminum Aluminum Aluminum sensors with
mounting
0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 0.3 m PUR cable with 2 m PUR cable system
BCC M313-0000-10-001-PX43T2-050 BCC M415-0000-1A-003-PX44T2-050 BCC M415-0000-1A-003-PX44T2-050 BCC M415-0000-1A-003-PX44T2-050 28 AWG Magnetic
cylinder
Drop-in T-slot Drop-in T-slot Drop-in T-slot Drop-in T-slot Drop-in T-slot sensors with
a compact
design
Magnetic
Refer to page 873 for brackets for tie rod and round body cylinders cylinder
sensors with
special
max. max. max. properties
0.35 Nm 0.35 Nm 0.35 Nm
Robust metal
max. housing
0.35 Nm
For the food
7.2 industry
Weld-immune
Sensing surface
electronics
33
Temperature-
resistant up to
105 C
For radially
magnetized
Sensing Sensing Sensing magnets
surface surface surface
Reed switches
Sensing
surface
Magnetic
sensors for
Recommended accessories object detection
Magneto-
inductive
displacement
sensors for
analog position
measurement
Accessories
for magnetic
Special accessories for magnetic cylinder sensors, such as cylinder sensors

Magnetic Cylinder Sensors 105 C
High-temperature resistant up to 105 C
BMF 305M, 315M
Series BMF 305M BMF 315M BMF 315M

Properties Universal for position For particularly demanding For particularly demanding
monitoring with integral applications with an applications with a
M8 connector M8 connector direct PUR cable
PNP, NO Ordering code BMF0066 BMF007Y BMF007U
Part number BMF 305M-PS-C-2-SA4-S49 BMF 315M-PS-D-2-SA3-S49-00,3 BMF 315M-PS-D-2-SA3-PU-02
Voltage drop Ud 3.1 V 3.1 V 3.1 V
Rated switching eld strength I Hn I 1.2 kA/m 1.2 kA/m 1.2 kA/m
Assured switching eld strength I Ha I 2 kA/m 2 kA/m 2 kA/m
On/off delay 0.05 ms/ 0.05 ms 0.05 ms/ 0.05 ms 0.05 ms/ 0.05 ms
Approval CE CE, cULus CE, cULus
Housing material Aluminum Aluminum Aluminum
Cable 0.3 m PUR cable with 2 m PUR cable
M8 conncetor, 3-pin
Suggested mating cable BCC M323-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050 28 AWG
Installation Installation with mounting Drop-in T-slot Drop-in T-slot
bracket

page 868.
max. max.
0.35 Nm 0.35 Nm
Sensing
surface Sensing Sensing
surface surface
Wiring diagrams
NO


Radially Magnetic Cylinder Sensors
magnetized For radially magnetized magnets
BMF 103K, BMF 303K
Series BMF 103K BMF 103K BMF 303K

Properties Perpendicular cable Perpendicular cable Cylinder sensor for
exit with exit with all common cylinders
M8 connector PUR cable with M8 connector
PNP, NO Ordering code BMF001P BMF001N BMF004C
Part number BMF 103K-PS-C-2A-SA7-S49-00,3 BMF 103K-PS-C-2A-SA7-PU-02 BMF 303K-PS-C-2A-SA7-S49-00,3
PNP, NC Ordering code BMF00AH
Part number BMF 303K-PO-C-2A-SA7-S49-00,3
Voltage drop Ud 2.5 V 2.5 V 2.5 V
Rated switching eld strength I Hn I 1.2 kA/m 1.2 kA/m 1.2 kA/m Magnetic
Assured switching eld strength I Ha I 2 kA/m 2 kA/m 2 kA/m cylinder
sensors
Magnetic
Degree of protection as per IEC 60529 IP 67 IP 67 IP 67 cylinder
Approval CE, cULus CE, cULus CE, cULus sensors with
mounting
Housing material LCP LCP LCP system
Cable 0.3 m PUR cable with 2 m PUR cable 0.3 m PUR cable with
M8 connector, 3-pin M8 connector, 3-pin Magnetic
cylinder
Suggested mating cable BCC M313-0000-10-001-PX43T2-050 BCC M313-0000-10-001-PX43T2-050 sensors with
Installation Installation with mounting bracket Installation with mounting bracket Installation with mounting bracket a compact
design
Basic information and denitions can be found on page 952, Magnetic

associated mounting brackets for BMF 103K can be found cylinder
on page 860; for BMF 303K see page 864. sensors with
special
properties
Robust metal
housing
For the food
industry
Weld-immune
Sensing electronics
surface Temperature-
resistant up to
Sensing 105 C
surface
Sensing For radially
surface magnetized
magnets
Reed switches
Wiring diagrams
Magnetic
sensors for
NO Recommended accessories object detection
PNP cable PNP connector (please order separately)
Magneto-
inductive
displacement
sensors for
analog position
measurement
NC contact
PNP cable PNP connector Accessories
for magnetic
Special accessories for magnetic cylinder sensors, such as cylinder sensors

Magnetic Cylinder Sensors Reed
Reed switch
BMF 305K
Series BMF 305K Reed BMF 305K Reed BMF 305K Reed
Properties Universal Universal Universal
position monitoring position monitoring position monitoring
reed switch reed switch reed switch
PNP, NO (DC) Ordering code BMF0063 BMF0062
Part number BMF 305K-R-PS-F-3-S49-00,2 BMF 305K-R-PS-F-3-03
NO (AC)/ Ordering code BMF0064
polarized, NO (DC) Part number BMF 305K-R-US-L-3-03
Sensed medium Magnetic eld Magnetic eld Magnetic eld
Supply voltage UB 10...30 V DC 10...30 V DC 6...240 V AC/DC
Switching capacity max. reed contact 10 W 10 W 10 W
Rated operating current Ie 500 mA 500 mA 128 mA at 24 V AC/DC
86 mA at 115 V AC/DC
43 mA at 230 V AC/DC
Minimum operational current Im 3 mA
Polarity reversal protected/transposition protected/short-circuit protected No/No/No No/No/No No/No/No
Approval CE CE CE
Housing material LCP LCP LCP
Cable 0.2 m PUR cable with 3 m PVC, 26 AWG 3 m PVC, 26 AWG
M8 connector, 3-pin
Installation Installation with mounting bracket Installation with mounting bracket Installation with mounting bracket

associated mounting brackets for BMF 305K can be found on
page 868.
Recommended short circuit protection equipment:

Miniature fuse in accordance with IEC60127-2 Sheet 1, 2 A
(fast-acting). The fuse has to lie in the load current line. The fuse
must not be routed into the output line.
The reed switches BMF 305K-R-... have an LED to

indicate function and act as an adjustment aid. The
recovery diode for switching an inductive load is already
integrated. For sensing the piston position in pneumatic
cylinders you can choose between electronic and Sensing Sensing Sensing
mechanical cylinder switches. Select whichever one ts surface surface surface
your application.
Fast and easy to install

Compatible with all common cylinder sizes using Recommended accessories
corresponding mounting brackets (please order separately)
No loss of the switching point when replacing a switch
Wiring diagrams
DC/cable AC/DC/cable
DC/connector Special accessories for magnetic cylinder sensors, such as


Reed switch
BMF 307K
Series BMF 307K Reed BMF 307K Reed BMF 307K Reed
Properties The compact sensor for The compact sensor for The compact sensor for
the T-slot slide-in the T-slot slide-in the T-slot slide-in
reed switch reed switch reed switch
PNP, NO (DC) Ordering code BMF00CP
Part number BMF 307K-R-PS-F-3-02,5
NO (AC)/ Ordering code BMF0078 BMF008P
polarized, NO (DC) Part number BMF 307K-R-AS-L-3-S49-00,2 BMF 307K-R-AS-L-3-03
Sensed medium Magnetic eld Magnetic eld Magnetic eld
Supply voltage UB 10...30 V DC 4...30 V AC/DC 4...30 V AC/DC
Switching capacity max. reed contact 10 W 10 W 10 W
Rated operating current Ie 500 mA 128 mA at 24 V DC 128 mA at 24 V DC
Minimum operational current Im 3 mA 3 mA
Polarity reversal protected/transposition protected/short-circuit protected No/No/No No/No/No No/No/No
On/off delay 0.7 ms/ 0.2 ms 0.7 ms/ 0.2 ms 0.7 ms/ 0.2 ms Magnetic
Ambient temperature Ta 20...+70 C 20...+70 C 20...+70 C cylinder
sensors
Approval CE, cULus CE CE
Magnetic
Housing material LCP LCP LCP cylinder
Cable 2.5 m PVC cable, 26 AWG 0.2 m PUR cable with M8 connector, 3-pin 3 m PVC cable, 26 AWG sensors with
mounting
Suggested mating cable BCC M313-0000-10-001-PX43T2-050 system
Installation Slide-in Slide-in Slide-in
Slot T-slot T-slot T-slot Magnetic
cylinder
sensors with
Refer to page 884 for mounting brackets for tie rod and round a compact
body cylinders. design
Basic information and denitions can be found on page 952. Magnetic

cylinder
Additional cable lengths on request sensors with
special
Recommended short circuit protection equipment: properties
Miniature fuse in accordance with IEC60127-2 Sheet 1, 2 A Robust metal
(fast-acting). The fuse has to lie in the load current line. The fuse housing
must not be routed into the output line. For the food
Sensing Sensing Sensing industry
surface surface surface
The reed switches BMF 307K-R-... have an LED to Weld-immune
electronics
indicate function and act as an adjustment aid. The
Temperature-
recovery diode for switching an inductive load is already resistant up to
integrated. For sensing the piston position in pneumatic 105 C
cylinders you can choose between electronic and For radially
magnetized
mechanical cylinder switches. Select whichever one ts magnets
your application. Reed switches
Refer to page 884 for mounting brackets for
Without mounting bracket for installation in cylinders the tie rod and round body cylinders. Magnetic
sensors for
with T-slot, e.g. Festo: ADVU, ADN, DRQ, DGP; SMC, object detection
Bosch. When using reed switches you should verify Recommended accessories
functionality on the pneumatic cylinder by means of (please order separately) Magneto-
inductive
pre-testing. displacement
sensors for
Wiring diagrams analog position
measurement
Example connectors Cable
Accessories
for magnetic
cylinder sensors

Connect to ground on controller side! this catalog on page 910.

Magnetic
Cylinder
Sensors
Magnetic sensors for object detection
Magnetic sensors for object detection in classic
cylindrical housings have several application benets:
Signicantly longer switching distances compared with inductive
sensors of the same size
Switch through walls of non-ferrous metal and aluminum without
reducing the switching distance
Activate from the front or side
Flush installation in steel
Respond to north and south pole
Wear-free
Vibration-resistant
Output protected against inductive spikes

Magnetic Sensors for Object Detection
Contents
Form factors
6.5 mm - BMF 07M 900
M81 - BMF 08M 901
M121 - BMF 12M 901
Magnets
4 mm 902
10 mm 902
15 mm 903
25 mm 903
22.1 mm 903
1612 mm 903

Designs, 6.5 mm
Magnetic sensors feature small, extremely compact

designs. Their magnets for position sensing offer
longer switching distances. This means that you can
detect positions up to 90 mm away using a single
sensor with a diameter of 6.5 mm. These sensors
are industrial grade. Positions can also be detected
through non-metalic containers or pipes. The Series BMF 07M
detection of codes using magnets is also possible. Maximum switching distance (with BAM01EL) 90 mm
PNP, NO Ordering code BMF000L
Non-contact position sensing up to a distance of Part number BMF 07M-PS-D-2-SA2-S49-00,3
90 mm NPN, NO Ordering code BMF000C
Object detection through non-magnetizable Part number BMF 07M-NS-D-2-SA2-S49-00,3
materials Supply voltage UB 10...30 V DC
Compact sensors and small magnets provide Voltage drop Ud 3.1 V
optimum installation conditions Rated insulation voltage Ui 75 V DC
Rated switching eld strength I Hn I 1.2 kA/m
Assured switching eld strength I Ha I 2 kA/m
Hysteresis of I Hn I 45%
Temperature drift of switch-on point of I Hn I 0.3 %/C
On/off delay 0.05 ms/ 0.05 ms
Function ready/error indicator
Approval CE, cULus
Housing material Brass-coated
Cable 0.3 m PUR cable with
M8 connector, 3-pin

magnets on page 904.
Wiring diagrams
NO

Designs, 6.5 mm, M81, M121
BMF 07M BMF 07M BMF 08M BMF 12M BMF 12M
90 mm 90 mm 90 mm 90 mm 90 mm
BMF000J BMF000E BMF000P BMF0022 BMF00C7
BMF 07M-PS-D-2-S4-00,6 BMF 07M-PS-C-2-KPU-02 BMF 08M-PS-C-2-KPU-02 BMF 12M-PS-D-2-S4 BMF 12M-PS-C-2-S4
BMF0008 BMF000M BMF0021
BMF 07M-NS-C-2-KPU-02 BMF 08M-NS-C-2-KPU-02 BMF 12M-NS-D-2-S4
3.1 V 3.1 V 3.1 V 3.1 V 3.1 V
200 mA 200 mA 200 mA 200 mA 200 mA
30 mA 30 mA 30 mA 30 mA 15 mA
1.2 kA/m 1.2 kA/m 1.2 kA/m 1.2 kA/m 1.2 kA/m
2 kA/m 2 kA/m 2 kA/m 2 kA/m 2 kA/m
45% 45% 45% 45% 45% Magnetic
0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C 0.3 %/C cylinder
sensors
25...+85 C 25...+85 C 25...+85 C 25...+85 C 25...+70 C
Magnetic
LED yellow LED yellow LED yellow cylinder
IP 67 IP 67 IP 67 IP 67 IP 67 sensors with
mounting
CE, cULus CE, cULus CE, cULus CE, cULus CE, cULus system
Brass-coated Brass-coated Brass-coated Brass-coated Brass-coated
0.6 m PUR cable with 2 m PUR cable 2 m PUR cable M12 connector, 4-pin M12 connector, 4-pin Magnetic
cylinder
M12 connector, 4-pin 26 AWG 26 AWG sensors with
BCC M415-0000-1A-003-PX44T2-050 BCC M415-0000-1A-003-PX44T2-050 BCC M415-0000-1A-003-PX44T2-050 a compact
design
Magnetic
cylinder
sensors with
special
properties
Magnetic
sensors for
object detection
Form factors
Magnets
Magneto-
inductive
displacement
sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors

Magnets
Size 4 mm 10 mm
Ordering code 709084 620961

Part number RUNDMAGNET 4.0X 5.0 RUNDMAGNET 10.0X10.0
Height 5 mm 10 mm
Maximum switching distance 5 mm 15 mm
Material Strontium ferrite Hard ferrite
Reliable switching is guaranteed

from 0 mm to the switching
distance indicated in the table.
The specied switching distances
are determined from series
measurements and should be
considered a starting point for
selecting a suitable magnet.

Magnets
15 mm 15 mm 25 mm with hole 22.1 mm with hole for 1612 mm

for M5 screw M5 screw
BAM01EJ BAM01EK BAM01EL BAM01EM 620260
BAM TG-MF-006 BAM TG-MF-007 BAM TG-MF-008 BAM TG-MF-009 MAGNETPLATTE 16X12X3
10 mm 15 mm 15 mm 10.5 mm 3 mm
40 mm 65 mm 90 mm 40 mm 28 mm
Neodymium iron boron Neodymium iron boron Neodymium iron boron Ferrite with Samarium cobalt
plastic encapsulation
Magnetic
cylinder
sensors
Magnetic
cylinder
sensors with
mounting
system
Magnetic
cylinder
sensors with
a compact
design
Magnetic
cylinder
sensors with
special
properties
Magnetic
sensors for
object detection
Form factors
Magnets
Magneto-
inductive
displacement
sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors

Magnetic
Cylinder
Sensors
Magneto-inductive displacement sensors
for analog position measurement
Magneto-inductive displacement sensors for analog position mea-
surement can be quickly and easily installed in T-slots. They detect
end positions and intermediate positions individually and exibly. The
magneto-inductive displacement sensor Micro-BIL provides non-
contact and absolute measurement on pneumatic miniature grippers
or compact cylinders with integrated permanent magnets.

Magneto-inductive Displacement Sensors
for Analog Position Measurement
Contents
Magneto-inductive displacement sensors

for analog position measurement
Micro-BIL 906

Magneto-inductive Distance Sensors
Micro-BIL
The Micro-BIL provides absolute measurement of the positions on

pneumatic miniature grippers or compact cylinders with integrated
permanent magnets. Moreover, the sensor element can be installed
in the T-slot very easily. The analog output signal enables individual
and exible detection of end positions and intermediate positions on
gripper jaws or pistons.
Features
Wear-free since the measuring position is detected without
contact
Insensitive to shock and vibration
Absolute output signal: Voltage or current
(cable break monitoring possible)
Adjustable measuring range / magnetic eld strength
Easiest installation in the T-slot
A button enables adjustment to various magnetic eld strengths.

The technical data refer to reference measurements. Different
grippers/cylinders having differing magnetic elds may affect the
technical data.
Original mounting brackets and screws are recommended for

attaching the Micro-BIL. Please order accessories separately.
Wiring diagram
Connect either the voltage or current output.

Magneto-inductive Distance Sensors
Micro-BIL
Displacement sensors are assigned to the

linear position sensing and measurement,
which we have marked in blue.
Series Micro-BIL
Output signal Uout/Iout Voltage 0...10 V / current 4...20 mA
Working range sw/linear range sl 0...10 mm
Ordering code BIL0002
Part number BIL ED0-B010P-02/30-S75
Supply voltage UB At voltage output Uout : US = 15...30 V DC,
at current output Iout : IS = 10...30 V DC
Field strength, axial Hn 10 kA/m typical
3dB width of the axial eld distribution, typical 2.5 mm
Residual ripple 10% of Ue
Effective distance se 5 mm
Load resistance RL At voltage output Uout : RL = 2 k,
at current output Iout : RL = 500 , Magnetic
No-load supply current I0 at Ue 30 mA cylinder
sensors
Magnetic
Repeat accuracy RBWN 30 m cylinder
Non-linearity max. 0.3 mm sensors with
mounting
Temperature coefcient TK, Typical +4 m/K system
in the optimum range from min. +2 m/K
+10...+50 C max. +10 m/K Magnetic
cylinder
Power-on/programming indicator Yes/Yes sensors with
Degree of protection as per IEC 60529 IP 67 a compact
design
Approvals CE, cULus
Material Housing PA (berglass reinforced) Magnetic
Sensing surface PBT cylinder
sensors with
Connection M8 connector, 4-pin special
Suggested mating cable BCC M314-0000-10-014-VS8434-020 properties
Basic information and denitions can be found on page 952. Magnetic

sensors for
Mounting bracket, stainless steel: object detection
BIL 01-HW-1 (BAM00K4)
Magneto-
inductive
displacement
sensors for
analog position
Sensing surface measurement
Micro-BIL
Accessories
for magnetic
BIL 01-HW-2 (BAM00K5) cylinder sensors
300 mm
Teach-in
BIL 01-HW-3 (BAM00K6)

Magnetic
Cylinder
Sensors
In order to be able to accurately mount and adjust sensors, you
need the right tools and accessories. We offer you practical cable
clips, tube cuffs, and tool sets designed for mounting Balluff
sensors.

Accessories for Magnetic Cylinder Sensors
Contents

Cable clips 910
Tube cuffs 910
Tools 911

Cable clips, tube cuffs
Part number Cable clip for T-slot Cable clip for C-slot
Type Packaging unit: 50 pieces Packaging unit: 50 pieces
Use For cable routing and strain relief For cable routing and strain relief
Ordering code BAM01EA BAM01EC
Part number BAM CC-XA-028-T05-P BAM CC-XA-025-C03-P
Material Plastic Plastic
Piston diameter BMF 303-HW-59 BMF 305-HW-24 BMF 21-HW-11 BMF 32 BMF 235-HW-112 BMF 10E-HW-19
with tube cuff with tube cuff with tube cuff with tube cuff with tube cuff with tube cuff
BMF size _ BMF size _ BMF size _ BMF size _ BMF size _ BMF size _
8 mm 0 BAM00N2 0 BAM00N2
8...10 mm 1 BAM00N3 1 BAM00N3 10 BAM001H 10 BAM001H 1 BAM00N3 2 BAM00N4
12 mm 2 BAM00N4 1 BAM00N3 10 BAM001H 10 BAM001H 1 BAM00N3 2 BAM00N4
16 mm 2 BAM00N4 1 BAM00N3 12 BAM001K 12 BAM001K 1 BAM00N3 3 BAM00N5
32 mm 3 BAM00N5 3 BAM00N5 13 BAM001L 13 BAM001L 3 BAM00N5 4 BAM00N6
40 mm 4 BAM00N6 4 BAM00N6 14 BAM001M 14 BAM001M 4 BAM00N6 5 BAM00N7
50 mm 5 BAM00N7 5 BAM00N7 15 BAM001N 15 BAM001N 5 BAM00N7 6 BAM00N8
63 mm 6 BAM00N8 6 BAM00N8 16 BAM001P 16 BAM001P 6 BAM00N8 8 BAM00NA
70 mm 8 BAM00NA 8 BAM00NA 18 BAM001T 18 BAM001T 8 BAM00NA 8 BAM00NA
80 mm 7 BAM00N9 7 BAM00N9 17 BAM001R 17 BAM001R 7 BAM00N9 10 BAM01TC
90 mm 10 BAM01TC 10 BAM01TC 10 BAM01TC 10 BAM01TC
100 mm 9 BAM01F4 9 BAM01F4 9 BAM01F4 9 BAM01F4

Tools
Part number BMF Hex Key Hex key set 0.7-2.0

Type Folding Allen key set,
with additional blades, 8-piece
Use Tool set for all BMF sensors and Tool set for BMF sensors and
BMF angle brackets as well as for sensors BMF angle brackets
having a potentiometer, e.g. BOS, BCS, BUS etc.
Material No. 139868 123264
Material Blade: chrome vanadium steel, fully hardened,
galvanically treated.
Grip: ergonomic, berglass reinforced housing,
55 mm long.
mm
0.7 0.71 Magnetic
cylinder
0.9 0.89 sensors
1.3 1.27
1.5 1.5 Magnetic cyl-
2.0 2.0 inder sensors
with mounting
2.5 system
3.0
PH00 Magnetic
cylinder sen-
sors with
a compact
Application design
Practical folding holder for Allen keys to prevent them
from getting lost. Especially good for turning very small Magnetic
cylinder
screws, for example, for tightening down or accurately sensors with
special
adjusting sensors. properties
Sturdy housing with release button for easily selecting
the right blade. Eyelet with matching carabiner hook. Magnetic
Self-service packaging for hanging with a Euro hole tab. sensors for
object detection
Magneto-
inductive
displacement
sensors for
analog position
measurement
Accessories
for magnetic
cylinder sensors
Cable clips
Hose clamps
Tools

Industrial
Networking
and
Connectivity
Cables, cordsets and connectors
From our extensive product line we have put together a selection for
you that covers the most important applications in object detection.

Cables, cordsets and connectors
Contents
Overview Quick Selector 914
Sensor Cable Part Number Builder 916
BCC Part Number Matrix 920
Technical Specications 925
Connectors
M5 926
M8 Nano 927
1/2" AC Micro 930
M12 Micro 931
M12 Shielded 937
Splitters 938
7/8" Mini 940
7/8" - M12 Adapters 941
Junction Blocks/Homerun Cables 942
Field Attachables 944
Wrenches 951
You will nd many additional products from our total product

line in Industrial networking and connectivity A guide to
industrial network architecture or online at: www.balluff.us.
Basic
information
and denitions
can be found
on page 952.
www.balluff.com 913
Connectivity Solutions
Overview quick selector
Sensor & Actuator Cables

Size M5 M8 M12
Congurations Single-Ended & Double-Ended Single-Ended, Double-Ended Single-Ended, Double-Ended
Conductors 3-wire, 4-wire 3-wire, 4-wire 3, 4, 4+PE, 5, 8, 12-wire

LED Versions No Yes Yes
Shielded Versions No Yes Yes
Page # 926 927 - 929 931 - 937
Mini Size Cables

Size 7/8" 1" 1 1/8"
Congurations Single-Ended, Double-Ended, Single-Ended, Double-Ended Single-Ended, Double-Ended
Tees, Bulkheads, Converters
Conductors US Color Code: 3 & 4-wire 6, 7, 8-wire 9, 10, 12, 19-wire
DC Color Code: 4 & 5-wire
Color Codes Available US AC, DC --- ---
Shielded Versions No No No
Page # 940 See Networking Catalog See Networking Catalog
Junction Blocks (MIBs)

Size M8 M12 M12, M16, M23
Congurations Quick Disconnect, Cable Out Quick Disconnect, Cable Out, Homerun Cables
Terminal Blocks
Conductors 4-port & 8-port, 3-wire & 4-wire 4-port & 8-port, 3+PE & 4+PE 8-wire, 12-wire, 19-wire
LED Versions Yes Yes No
Shielded Versions No No No
Page # 942 943 942 - 943

Overview quick selector
M8 and M12 Specialty Splitters 1/2" AC DIN A, DIN B, IND B, DIN C,

IND C
High Temp, Coil Cable, M8 & M12, V & U Styles Single-Ended, Double-Ended Single-Ended, Pigtail, V-Splitter
Stainless, IP69K, ECOLAB,
Global cable
3-wire, 4-wire, 4+PE 3-wire, 3+PE 3, 4, 5, 6-wire 2+PE
Yes Yes No Yes
No No Yes Yes
See Networking Catalog 938 - 939 930 See Networking Catalog
Cables,
cordsets and
Receptacles connectors
M8 M12 1/2" AC, 7/8", 1", " 1 1/8" M23 Overview
quick selector
M8x0.5 1/4"-18NPT, 1/2"-14NPT, 1/4"-18NPT, 1/2"-14NPT, M20x1.5
Sensor cable
M16x1.5 M16x1.5, M20x1.5 part number
3-wire, 4-wire 3, 4, 4+PE, 5, 8-wire 3, 4, 5, 6-wire, 7, 8, 9, 10-wire 12-wire, 19-wire builder
12, 19-wire BCC part
number matrix
DC DC US AC, DC ---
Technical
Metal Metal Metal Metal specications
See Networking Catalog See Networking Catalog See Networking Catalog See Networking Catalog Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
Field Attachables
M8 M12 1/2" AC, 7/8" M23
Piercon, Screw Terminal, Insulation Displacement, Screw Screw Terminal Solder Cup
Soldercup Terminal, Spring Clamp
3-wire, 4-wire 3, 4, 5, 8, 12-wire 3, 4, 5-wire 12, 19-wire
No No No No
No Yes No No
944 946-949 950 See Networking Catalog
www.balluff.com 915
Sensor cable part number builder
Balluffs new line of sensor cordsets offers many benets to the automation world. Balluff can globally offer cordsets that
t almost any standard sensor or actuator application. This offering includes features such as consistant and accurate IP
ratings, a wide range of cable jackets, a full range of overmold congurations, and high quality rugged materials.
Select your cordset in 4 easy steps:

1. Pick your connector types (single/double, right angle/straight)
2. Pick your electrical information and LEDs
3. Pick your jacket material and color
4. Pick your cordset length
Complete Part Number Example:
BCC M415-0000-1A-008-VX44T2-050

M12 single ended, straight female (M415-0000-1A)
4-wire, 2x PNP LED (008)
Yellow PVC, 4-wire (VX44T2)
5 m cable (050)
Step 1
BCC_ _ _ _-_ _ _ _-_ _ -_ _ _-_ _ _ _ _ _-_ _ _
Cordset Connector Selection

Single-ended and double-ended cordsets can be made using the chart below. Available in industry
standard M8 and M12 sizes, these cordsets come in a variety of head combinations; single-ended,
straight to straight, right angle to straight, and right angle to right angle. To select your cordset, start by
selecting the female connector that will match your sensor. Next, follow the row across until you nd
the required end that will go back to your controller, homerun cordset, MIB, etc.
Male (controller, homerun cable, MIB end)

Connector Types Single Ended 3-wire 3-wire 4-wire
Female (sensor end)
Female M8 Straight Male M8 Right Angle Male M8 Straight Male

Single-Ended Male M313-0000-20 M323-0000-20 M314-0000-20
M8 Straight Female 3-wire M313-0000-10 M313-M313-30 M313-M323-30
M8 Right Angle Female 3-wire M323-0000-10 M323-M313-30 M323-M323-30
M8 Straight Female 4-wire M314-0000-10 M314-M314-30
M8 Right Angle Female 4-wire M324-0000-10 M324-M314-30
M12 Straight Female M415-0000-1A M415-M313-3F M415--M323-3F M415-M314-3F
M12 Right Angle Female M425-0000-1A M425-M313-3F M425-M323-3F M425-M314-3F
Single Ended M8 Female M8 Female M8 Female M8 Female M8 Male M8 Male M8 Male

3-wire 3-wire 4-wire 4-wire 3-wire 3-wire 4-wire

Step 2
BCC_ _ _ _-_ _ _ _-_ _ -_ _ _-_ _ _ _ _ _-_ _ _
Cordset Wiring and LEDs
Both 3- and 4-wire cordsets are available in single- and double-ended cordsets, as well as two and
three LEDs. To select your cordset, start with Step 1 on previous page. Then decide if you need 3-
or 4-wire and whether or not you want an LED in the overmolded head.
Single Ended Cordsets

Head 1 and 2 3-wire N/O 3-wire N/C 4-wire
No LED 001 002 003
2x PNP LED 004 005 008
3x PNP LED** 010
2x NPN LED 006 007 009
No LED
Double Ended Cordsets
Head 1 Head 2 3-wire N/O 4-wire
No LED No LED 300 304
2x PNP LED No LED 602 606
3x PNP LED** No LED 650 Cables,
2x NPN LED No LED 603 607 cordsets and
connectors
2x PNP LED 2x PNP LED* 302 306 Overview
2x NPN LED 2x NPN LED* 303 307 quick selector
3x PNP LED** 2x PNP LED* 651 Sensor cable
2x LED 3x LED part number
builder
BCC part
number matrix
Technical
specications
2x = 1 power LED and 1 signal LED *M12 right angle male only Connectors
3x = 1 power LED and 2 signal LEDs **M12 right angle female only M5
M8 nano
Male (controller, homerun cable, MIB end) 1/2" AC micro
M12 micro
4-wire 3-wire 3-wire 4-wire 4-wire Splitters
M8 Right Angle Male M12 Straight Male M12 Right Angle Male M12 Straight Male M12 Right Angle Male 7/8" mini
7/8" to M12
adapters
M324-0000-20 M413-0000-2A M423-0000-2A M414-0000-2A M424-0000-2A
Junction
M313-M413-3E M313-M423-3E Blocks
M323-M413-3E M323-M423-3E /homerun
cables
M314-M324-30 M314-M414-3E M314-M424-3E
Field
M324-M324-30 M324-M414-3E M324-M424-3E attachables
M415-M324-3F M415-M413-3A M415-M423-3A M415-M414-3A M415-M424-3A Wrenches
M425-M324-3F M425-M413-3A M425-M423-3A M425-M414-3A M425-M424-3A
M8 Male M12 Female M12 Female M12 Male M12 Male M12 Male M12 Male
4-wire 3-wire 3-wire 4-wire 4-wire
www.balluff.com 917
Step 3
BCC_ _ _ _-_ _ _ _-_ _ -_ _ _-_ _ _ _ _ _-_ _ _
Raw Cable Type
To select your raw cable, rst decide on the correct jacket for the application and then on a jacket color.
PVC: For standard automation applications
PUR: For abrasion and extreme uid resistance
TPE: For High-ex and for use in heavy duty environments
Jacket Color and Material

Material Color Conductor 3-wire 4-wire
PVC Yellow 22 AWG VX43T2 VX44T2
PVC Gray 0.34 mm2 VX8334 VX8434
PUR Yellow 22 AWG PX43T2 PX44T2
PUR Black 0.34 mm2 PX0334 PX0434
TPE Yellow 22 AWG EX43T2 EX44T2
PVC, PUR, TPE PVC PUR

Step 4
BCC_ _ _ _-_ _ _ _-_ _ -_ _ _-_ _ _ _ _ _-_ _ _
Cordset Length
Select from our standard cordset lengths below. Contact the factory for custom cordset length selections.
Double Length Options Single Length Options

Length Ordering Information Length Ordering Information
0.3 m 003 2m 020
0.6 m 006 5m 050
1m 010 10 m 100
1.5 m 015
2m 020
3m 030
5m 050
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
Need help nding a cross?

Need help selecting a part?
Visit us online: www.balluff.us

Call or email our technical support group at:
1-800-543-8390
technical.support@balluff.com
www.balluff.com 919
BCC part number matrix
BCC M415 - M424 - 3A - 304 - VX44T2 - 020 - C008

Head 1 Head 2 Code Wiring Raw Cable Length Custom
Head 1 & Head 2 Conguration Raw Cable Conguration
Connector Size & Type: Jacket Material:

M3 M8 Nano DC - Ni Plated Brass V PVC
M4 M12 Micro DC - Ni Plated Brass P PUR
S3 M8 Nano DC - Stainless 1.4404 E TPE
S4 M12 Micro DC - Stainless 1.4404
0000 (Head 2) Single-Ended Cable Special Designator:
X Nothing
Connector Direction: C Coiled Cable
1 Straight Plastic Overmolded H High Temperature
2 Right Angle Plastic Overmolded S Shielded
W Weld Resistant / High Shore
Number of Visible Connections: M Solid Conductor, Unshielded
5 M12 Female
no. poles Any other conguration Jacket Color:
0 Black 2 Red (CC-Link)
3 Orange 4 Yellow (standard)
Code Conguration 5 Green (Pronet) 6 Blue (EtherNet/IP)
7 Violet (Probus) 8 Grey (standard/DeviceNet)
Gender Type:
1 Female Internal Threads Number of Poles
2 Male External Threads # 3-pole thru 9-poles
3 Female Int - Male Ext A 10-pole
5 Female Int - Female Int C 12-pole
6 Male Ext - Male Ext
Conductor Prole
Connector Coding T2 22 AWG W8 18 AWG
A M12 Sensor Cables (typical) (A-coded) 25 0.25mm2 34 0.34mm2
0 M8 Sensor Cables (typical) (No coding) 50 0.50mm2
B M12 Probus Cables (B-coded)
D M12 Ethernet Cables (D-coded)
(Pronet, EtherNet/IP)
E M8-M12 Double-Ended Cables
F M12-M8 Double-Ended Cables Length Conguration
Cable Length:
Wiring Congurations 003 0.3 meters
020 2.0 meters
See next page for congurations 100 10.0 meters
Special Lengths:
05/14 0.5m coiled, 1.4m stretch
2D5 2.5 decimeters (25cm)
10X 100 meters
Custom Congurations
Custom Values:
C002 Grey Overmold
Note: Part Number Matrix is designed for C008 WeldRepelTM Applied
information purposes only. Not all congurations are C013 GlobalLine, Black Overmold
possible. Consult factory for part number availability.

Standard Cordsets
Wiring Poles Shield Head 1 Head 2
001 3-wire --- N/O ---
002 3-wire --- N/C ---
003 4-wire --- Comp. ---
004 3-wire --- N/O PNP LED ---
005 3-wire --- N/C PNP LED ---
006 3-wire --- N/O NPN LED ---
007 3-wire --- N/C NPN LED ---
008 4-wire --- N/O PNP LED ---
009 4-wire --- N/O NPN LED (M12 Female Only) ---
010 4-wire --- Comp. PNP LED ---
300 3-wire --- N/O N/O
302 3-wire --- N/O PNP LED N/O PNP LED
304 4-wire --- Comp. Comp.
306 4-wire --- N/O PNP LED N/O PNP LED
313 5-wire --- Comp. and Gnd ---
602 3-wire --- N/O PNP LED N/O
603 3-wire --- N/O NPN LED N/O
606 4-wire --- N/O PNP LED Comp.
607 4-wire --- N/O NPN LED Comp.
650 4-wire --- Comp. PNP LED Comp.
651 4-wire --- Comp. PNP LED N/O PNP LED
Shielded Cordsets and High Conductor Counts
014 4-wire Nut BN,WH,BU,BK ---
016 5-wire Nut BN,WH,BU,BK,GY ---
017 5-wire --- BN,WH,BU,BK,GY --- Cables,
034 4-wire+PE --- BN,WH,BU,BK,GNYE --- cordsets and
connectors
036 3-wire Nut BN,BU,BK (N/O) ---
Overview
037 3-wire Nut BN,BU,BK (N/C) --- quick selector
039 5-wire --- Comp. PNP LED --- Sensor cable
040 4-wire+PE --- Comp. PNP LED --- part number
builder
043 4-wire+PE Nut BN,WH,BU,BK,GNYE --- BCC part
044 8-wire --- WH,GN,YE,GY,BN,PK,BU,RD --- number matrix
046 8-wire Nut WH,BN,GN,YE,GY,PK,BU,RD --- Technical
specications
049 12-wire --- BN,BU,WH,GN,PK,YE,BK,GY,RD,VI,GYPK,RDBU ---
Connectors
325 12-wire --- BN,BU,WH,GN,PK,YE,BK,GY,RD,VI,GYPK,RDBU --- M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8 to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
www.balluff.com 921
BCC M414 - M425 - M425 - U2010 - 003

Head 1 (Splitter) Head 2 (Head A) Head 3 (Head B) Splitter Code Length
Head 1 Conguration Head 2 & Head 3 Conguration
Connector Size & Type: Connector Size & Type:

M4 M12 Micro DC - Ni Plated Brass M3 M8 Nano DC - Ni Plated Brass
M4 M12 Micro DC - Ni Plated Brass
Connector Direction: 0000 (Head 2, Head 3) Open Splitter
1 Straight Plastic Overmolded
Connector Direction:
Number of Visible Connections: 1 Straight Plastic Overmolded
# 3-pole thru 8-poles 2 Right Angle Plastic Overmolded
Number of Visible Connections:

5 M12 Female
no. poles Any other conguration
Splitter Code
Code Type Wiring Head 1 Head 2 Head 3 Cable Body

U0003 U Splitter A00 M12 Male M12 Female M12 Female --- BK PVC
U0014 U Splitter A00 M12 Male M8 3-pole Female M8 3-pole Female --- BK PVC
U2002 V Splitter A00 M12 Male M12 Female M12 Female YE TPE YE TPU
U2009 V Splitter A13 M12 Male Leads Leads YE PVC YE TPU
U2010 V Splitter A00 M12 Male M12 Female M12 Female YE PVC YE TPU
U2011 V Splitter A07 M12 Male M12 Female M12 Female YE TPE YE TPU
U2012 V Splitter A00 M12 Male M8 Female M8 Female YE PVC YE TPU
Wiring Conguration
Wiring Head 1 Head 2 Head 3 Logic LED

A00 4-wire 3-wire N/O (H1=pin 4) 3-wire N/O (H1=pin 2) Splitter ---
A07 4-wire 3-wire N/O (H1=pin 4) 3-wire N/O (H1=pin 2) Splitter (H2&H3) PNP
A13 4-wire BN,BU,BK (H1=pin 4) BN,BU,BK (H1=pin 2) Splitter ---
Length Conguration
Cable Length:
003 0.3 meters
020 2.0 meters
100 10.0 meters
*Head 2 & Head 3 lengths are equal
Note: Part Number Matrix is designed for

information purposes only. Not all congurations are

BCC A315 - A325 - 30 - 335 - VX45W6 - 020

Head 1 Head 2 Code Wiring Raw Cable Length
Head 1 & Head 2 Conguration Raw Cable Conguration
Connector Size & Type: Jacket Material:

A3 7/8" MINI Size I V PVC
A4 1" MINI Size II P PUR
A5 1 1/8" MINI Size III E TPE
0000 (Head 2) Single-Ended Cable
Special Designator:
Connector Direction: X nothing
1 Straight Plastic Overmolded S Shielded
2 Right Angle Plastic Overmolded
Jacket Color:
Number of Visible Connections: 0 Black
# 3-pole thru 9-poles 4 Yellow (standard)
A 10-pole 8 Grey
C 12-pole
L 19-pole Number of Poles:
# 1-pole thru 9-poles
A 10-pole
Code Conguration C 12-pole Cables,
L 19-pole cordsets and
connectors
Gender Type: Overview
1 Female Internal Threads Conductor Prole: quick selector
2 Male External Threads W6 16 AWG Sensor cable
part number
3 Female Int - Male Ext W8 18 AWG builder
7 Female Int - Male Int A5 1.50mm2 BCC part
number matrix
C Male Internal Threads
Technical
D Female External Threads specications
Connectors
Connector Coding: M5
M8 nano
0 All congurations (typical) 1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
Wiring Congurations Length Conguration adapters
Junction
Single-Ended Double-Ended Poles Cable Length: Blocks
/homerun
003 304 4-wire DC 003 0.3 meters cables
063 335 5-wire DC 020 2.0 meters Field
100 10.0 meters attachables
071 345 3-wire AC
Wrenches
072 346 4-wire AC
085 357 6-wire
086 358 7-wire
087 359 8-wire
088 360 9-wire
089 355 10-wire
090 362 12-wire
091 363 19-wire

www.balluff.com 923
BCC M434 - 0000 - 2A - 000 - 55X450 - 000

Connector (Place Holder) Code (Place Holder) Conguration (Place Holder)
Field Attachable Connector Conguration Breakdown
Connector Size & Type: Cable Gland Minimum Diameter

M3 M8 Nano DC 1 min 2.5mm 2 min 3.0mm
M4 M12 Micro DC 3 min 3.5mm 4 min 4.0mm
S3 M8 Nano DC - Stainless 5 min 6.0mm 6 min 8.0mm
S4 M12 Micro DC - Stainless 7 min 10mm 8 min 12mm
A2 1/2" Micro AC 9 min 14mm 0 min 5.0mm
A3 7/8" MINI Size I A min 2.1mm or 4.0mm
Connector Direction: Connection Technology

3 Straight Plastic Field Attachable 1 Screw Terminals
4 Right Angle Plastic Field Attachable 2 PIERCECON Terminals
7 Straight Metal Field Attachable 3 Insulation Displacement Terminals
8 Right Angle Metal Field Attachable 4 Solder Cup Terminals
5 Spring Type Terminals
Number of Visible Connections:
5 M12 Female Cable Type
no. poles Any other conguration X no cable
Number of Poles
# 1-pole thru 9-poles
Code Conguration
A 10-pole
C 12-pole
Gender Type:
1 Female Internal Threads
Maximum Conductor Prole
2 Male External Threads
25 0.25mm2 34 0.34mm2
50 0.50mm2 75 0.75mm2
Connector Coding
A5 1.50mm2
A M12 Sensor Connectors (typical)
0 M8 & 7/8" (typical)
B M12 Probus Connectors
D M12 Ethernet Connectors
(Pronet, EtherNet/IP)


Technical specications
22AWG Bulk Cables

Jacket Material PVC PUR TPE
Application General Automation Cut & Fluid Resistant, Halogen Free High Flex, Weld Slag Resistant
Jacket Color Yellow Yellow Yellow
Conductor Gauge 22AWG 22AWG 22AWG
Ambient temp (moving) -5105C -2580C -40105C
Ambient temp (xed) -40105C -5080C -50105C
Bending Cycles > 2 Million > 2 Million > 10 Million
Rating PTLC tray rated
Bulk Cable (100 m) BCC0AE7 BCC0AE8 BCC0AE9 BCC0AEA BCC0AEC BCC0AEE
Number of Conductors 3 4 3 4 3 4
Cable Diameter (mm) 4.7 0.15 5.0 0.15 4.3 0.20 4.7 0.20 5.3 0.13 5.3 0.13
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
builder
M8 connectors, male straight and right-angle M8 connectors, female straight and right-angle
BCC part
number matrix
Technical
specications
Connectors
'
M5
M8 nano
1/2" AC micro
M12 micro

Splitters

'
7/8" mini
7/8" to M12
adapters
Junction
Blocks
M12 connectors, male straight and right-angle M12 connectors, female straight and right-angle /homerun
cables
Field

attachables

Wrenches
'
'

www.balluff.com 925
M5 single-ended cordsets
M5-M8 double-ended cordsets
M5 Single-Ended
Type M5 Female M5 Female
Conguration Straight Right Angle
Voltage Rating 30 VAC/VDC 30 VAC/VDC
Amperage 1A 1A
3-wire, non-LED BKS-B 25-1-PU-03 BKS-B 26-1-PU-03
4-wire, non-LED BKS-B 25-3-PU-03 BKS-B 26-3-PU-03
M5-M8 Double-Ended
Type M5 Female - M8 Male M5 Female - M8 Male
Conguration Straight - Straight Right Angle - Straight
Voltage Rating 30 VAC/VDC 30 VAC/VDC
Amperage 1A 1A
3-wire, non-LED BKS-B 25-1/GS49-PU-01 BKS-B 26-1/GS49-PU-01

M8 Nano single-ended cordsets
M8 Single-Ended Female
Voltage Rating 60 VAC/VDC (3-wire), 30 VAC/VDC (4-wire) 60 VAC/VDC (3-wire), 30 VAC/VDC (4-wire),
10-30 VDC (LED)
Amperage 4A 4A
3-wire, non-LED BCC M313-0000-10-001-EX43T2-_ _ _ BCC M323-0000-10-001- _ X43T2-_ _ _
3-wire, PNP-LED, N/O signal BCC M323-0000-10-004- _ X43T2-_ _ _
3-wire, NPN-LED, N/O signal BCC M323-0000-10-006- _ X43T2-_ _ _
4-wire, non-LED BCC M314-0000-10-003-EX44T2-_ _ _ BCC M324-0000-10-003- _ X44T2-_ _ _
Standard Cable Jackets: Standard Lengths Available:

V = PVC 020 = 2 m
P = PUR 050 = 5 m
E = TPE 100 = 10 m
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
M8 Single-Ended Shielded 7/8" to M12
Type M8 Female M8 Female adapters
Conguration Straight Right Angle Junction
Blocks
Voltage Rating 60 VAC/VDC (3-wire), 30 VAC/VDC (4-wire) 60 VAC/VDC (3-wire), 30 VAC/VDC (4-wire) /homerun
Amperage 4A 4A cables
Conductor Cross-Section 0.34 mm2 0.34 mm2 Field
attachables
3-wire, non-LED, shielded BCC M313-0000-10-036-_S_334-_ _ _ BCC M323-0000-10-036-_S_334-_ _ _ Wrenches
4-wire, non-LED, shielded BCC M314-0000-10-014-_S_434-_ _ _ BCC M324-0000-10-014-_S_434-_ _ _
Standard Cable Jackets:

VS8 = PVC (grey, 8)
PS0 = PUR (black, 0)
Standard Lengths Available:

020 = 2 meters
050 = 5 meters
100 = 100 meters
www.balluff.com 927
M8-M8 Double-Ended
10-30 VDC (LED)
Amperage 4A 4A
3-wire, non-LED BCC M313-M313-30-300-_X43T2-_ _ _ BCC M323-M313-30-300-_X43T2-_ _ _
3-wire, PNP-LED, N/O, Head 1 BCC M323-M313-30-602-_X43T2-_ _ _
3-wire, NPN-LED, N/O, Head 1 BCC M323-M313-30-603-_X43T2-_ _ _
4-wire, non-LED BCC M314-M314-30-304-_X44T2-_ _ _ BCC M324-M314-30-304-_X44T2-_ _ _
M8-M12 Double-Ended
10-30 VDC (LED)
Amperage 4A 4A
3-wire, non-LED BCC M313-M413-3E-300-_X43T2-_ _ _ BCC M323-M413-3E-300-_X43T2-_ _ _
3-wire, PNP-LED, N/O, Head 1 BCC M323-M413-3E-602-_X43T2-_ _ _
3-wire, NPN-LED, N/O, Head 1 BCC M323-M413-3E-603-_X43T2-_ _ _
4-wire, non-LED BCC M314-M414-3E-304-_X44T2-_ _ _ BCC M324-M414-3E-304-_X44T2-_ _ _

M8 Female - M8 Male M8 Female - M8 Male Standard Cable Jackets:

Straight - Right Angle Right Angle - Right Angle V = PVC
60 VAC/VDC (3-wire), 30 VAC/VDC (4-wire) 60 VAC/VDC (3-wire), 30 VAC/VDC (4-wire), P = PUR
10-30 VDC (LED) E = TPE
4A 4A
BCC M313-M323-30-300-_X43T2-_ _ _ BCC M323-M323-30-300-_X43T2-_ _ _
003 = 0.3 m
BCC M323-M323-30-602-_X43T2-_ _ _
006 = 0.6 m
BCC M323-M323-30-603-_X43T2-_ _ _
010 = 1.0 m
BCC M314-M324-30-304-_X44T2-_ _ _ BCC M324-M324-30-304-_X44T2-_ _ _
015 = 1.5 m
020 = 2 m
030 = 3 m
050 = 5 m
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
M8 Female - M12 Male M8 Female - M12 Male Standard Cable Jackets: adapters
Straight - Right Angle Right Angle - Right Angle V = PVC Junction
Blocks
60 VAC/VDC (3-wire), 30 VAC/VDC (4-wire) 60 VAC/VDC (3-wire), 30 VAC/VDC (4-wire), P = PUR /homerun
10-30 VDC (LED) cables
E = TPE
4A 4A Field
attachables
BCC M313-M423-3E-300-_X43T2-_ _ _ BCC M323-M423-3E-300-_X43T2-_ _ _ Standard Lengths Available: Wrenches
BCC M323-M423-3E-602-_X43T2-_ _ _ 003 = 0.3 m

BCC M323-M423-3E-603-_X43T2-_ _ _ 006 = 0.6 m
BCC M314-M424-3E-304-_X44T2-_ _ _ BCC M324-M424-3E-304-_X44T2-_ _ _ 010 = 1.0 m
015 = 1.5 m
020 = 2 m
030 = 3 m
050 = 5 m
www.balluff.com 929
1/2" Micro AC single-ended cordsets
1/2" Dual Keyway Single-Ended

Type 1/2" Dual Keyway Female 1/2" Dual Keyway Female
Voltage Rating 250 VAC / VDC 250 VAC / VDC
Amperage 4A 4A
3-wire, 22AWG C21 AE3-00-_Y-_ _ _F C21 BE3-00-_Y-_ _ _F
3-wire, 22 AWG, Stainless Steel Nut C21 AS3-00-_Y-_ _ _F C21 BS3-00-_Y-_ _ _F
3-wire, 18AWG C21 AE3-00-VY-_ _ _F-8 C21 BE3-00-VY-_ _ _F-8
4-wire, 18AWG C21 AE4-00-VY-_ _ _F-8 C21 BE4-00-VY-_ _ _F-8
4-wire, 22 AWG, Braided Shield C21 AE4-00-VY-_ _ _FB C21 BE4-00-VY-_ _ _FB
5-wire, 22 AWG, Braided Shield C21 AE5-00-VY-_ _ _FB
6-wire, 22 AWG, Braided Shield C21 AE6-00-VY-_ _ _FB C21 BE6-00-VY-_ _ _FB

V = PVC
T = TPE
Single-Ended Std Lengths:

060F = 6 feet
120F = 12 feet
150F = 15 feet
300F = 30 feet

M12 Micro DC single-ended cordsets
M12 Single-Ended
Voltage Rating 250 VAC/VDC (3&4-wire), 36 VDC (LED) 250 VAC/VDC (3&4-wire), 36 VDC (LED)
Amperage 4A 4A
3-wire, non-LED, N/O signal BCC M415-0000-1A-001-_X43T2-_ _ _ BCC M425-0000-1A-001-_X43T2-_ _ _
3-wire, non-LED, N/C signal BCC M415-0000-1A-002-_X43T2-_ _ _ BCC M425-0000-1A-002-_X43T2-_ _ _
3-wire, PNP-LED, N/O signal BCC M415-0000-1A-004-_X43T2-_ _ _ BCC M425-0000-1A-004-_X43T2-_ _ _
3-wire, PNP-LED, N/C signal BCC M415-0000-1A-005-_X43T2-_ _ _ BCC M425-0000-1A-005-_X43T2-_ _ _
3-wire, NPN-LED, N/O signal BCC M415-0000-1A-006-_X43T2-_ _ _ BCC M425-0000-1A-006-_X43T2-_ _ _
3-wire, NPN-LED, N/C signal BCC M415-0000-1A-007-_X43T2-_ _ _ BCC M425-0000-1A-007-_X43T2-_ _ _
4-wire, non-LED, N/O and N/C signal BCC M415-0000-1A-003-_X44T2-_ _ _ BCC M425-0000-1A-003-_X44T2-_ _ _
4-wire, PNP-LED, N/O signal BCC M415-0000-1A-008-_X44T2-_ _ _ BCC M425-0000-1A-008-_X44T2-_ _ _
4-wire, PNP-LED, N/O and N/C signal BCC M425-0000-1A-010-_X44T2-_ _ _
4-wire, NPN-LED, N/O signal BCC M415-0000-1A-009-_X44T2-_ _ _ BCC M425-0000-1A-009-_X44T2-_ _ _

V = PVC
P = PUR Cables,
E = TPE cordsets and
connectors
Overview
Standard Lengths Available: quick selector
Sensor cable
020 = 2 m part number
050 = 5 m builder
BCC part
100 = 10 m number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
www.balluff.com 931
M12-M12 Double-Ended
Type M12 Female - M12 Male
Conguration Straight - Straight
Voltage Rating 250 VAC / VDC (non-LED), 10-30 VDC (LED)
Amperage 4A
Female LED Male LED
3-wire, non-LED --- --- BCC M415-M413-3A-300-_X43T2-_ _ _
3-wire, PNP-LED, Head 1 N/O --- BCC M415-M413-3A-602-_X43T2-_ _ _
3-wire, PNP-LED, Head 1&2 N/O N/O
3-wire, NPN-LED, Head 1 N/O --- BCC M415-M413-3A-603-_X43T2-_ _ _
4-wire, non-LED --- --- BCC M415-M414-3A-304-_X44T2-_ _ _
4-wire, PNP-LED, Head 1 N/O --- BCC M415-M414-3A-606-_X44T2-_ _ _
4-wire, PNP-LED, Head 1 N/O and N/C ---
4-wire, PNP-LED, Head 1 & 2 N/O N/O
4-wire, PNP-LED, Head 1 & 2 N/O and N/C N/O
4-wire, NPN-LED, Head 1 N/O --- BCC M415-M414-3A-607-_X44T2-_ _ _

V = PVC
P = PUR
E = TPE

003 = 0.3 m
006 = 0.6 m
010 = 1.0 m
015 = 1.5 m
020 = 2 m
030 = 3 m
050 = 5 m

M12 Female - M12 Male M12 Female - M12 Male M12 Female - M12 Male
Right Angle - Straight Straight - Right Angle Right Angle - Right Angle
250 VAC / VDC (non-LED), 10-30 VDC (LED) 250 VAC / VDC (non-LED), 10-30 VDC (LED) 250 VAC / VDC (non-LED), 10-30 VDC (LED)
4A 4A 4A
BCC M425-M413-3A-300-_X43T2-_ _ _ BCC M415-M423-3A-300-_X43T2-_ _ _ BCC M425-M423-3A-300-_X43T2-_ _ _

BCC M415-M423-3A-302-_X43T2-_ _ _ BCC M425-M423-3A-302-_X43T2-_ _ _
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro-
Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
www.balluff.com 933
M12-M8 Double-Ended
Type M12 Female - M8 Male
Conguration Straight - Straight
Voltage Rating 60 VAC/VDC (3-wire)
30 VAC/VDC (4-wire)
10-30 VDC (LED)
Amperage 4A
Female LED Male LED
3-wire, non-LED --- --- BCC M415-M313-3F-300-_X43T2-_ _ _
3-wire, PNP-LED, Head 1 N/O --- BCC M415-M313-3F-602-_X43T2-_ _ _
3-wire, NPN-LED, Head 1 N/O --- BCC M415-M313-3F-603-_X43T2-_ _ _
4-wire, non-LED --- --- BCC M415-M314-3F-304-_X44T2-_ _ _
4-wire, PNP-LED, Head 1 N/O --- BCC M415-M314-3F-606-_X44T2-_ _ _
4-wire, PNP-LED, Head 1 N/O and N/C ---
4-wire, NPN-LED, Head 1 N/O --- BCC M415-M314-3F-607-_X44T2-_ _ _

V = PVC
P = PUR
E = TPE

003 = 0.3 m
006 = 0.6 m
010 = 1.0 m
015 = 1.5 m
020 = 2 m
030 = 3 m
050 = 5 m

M12 Female - M8 Male M12 Female - M8 Male M12 Female - M8 Male

Right Angle - Straight Straight - Right Angle Right Angle - Right Angle
60 VAC/VDC (3-wire) 60 VAC/VDC (3-wire) 60 VAC/VDC (3-wire)
30 VAC/VDC (4-wire) 30 VAC/VDC (4-wire) 30 VAC/VDC (4-wire)
10-30 VDC (LED) 10-30 VDC (LED) 10-30 VDC (LED)
4A 4A 4A
BCC M425-M313-3F-300-_X43T2-_ _ _ BCC M415-M323-3F-300-_X43T2-_ _ _ BCC M425-M323-3F-300-_X43T2-_ _ _

BCC M425-M314-3F-650-_X44T2-_ _ _ BCC M425-M324-3F-650-_X44T2-_ _ _
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
www.balluff.com 935
M12 4-wire+PE, 5-wire, 8-wire, 12-wire cordsets
M12 Single-Ended
Voltage Rating (4p+PE, 5p = 125 V), (8p = 60 V), (4p+PE, 5p = 125 V), (8p = 60 V),
(12p = 30 V) (12p = 30 V)
Amperage (4p+PE, 5p = 4 A), (8p = 2 A), (12p = 1 A) (4p+PE, 5p = 4 A), (8p = 2 A), (12p = 1 A)
Conductor Cross-Section (5p = 0.34 mm2), (8p, 12p = 0.25 mm2) (5p = 0.34 mm2), (8p, 12p = 0.25 mm2)
4-wire+PE, non-LED BCC M415-0000-1A-034-PX0534-_ _ _ BCC M425-0000-1A-034-PX0534-_ _ _
4-wire+PE, PNP-LED, N/O & N/C signals BCC M425-0000-1A-040-PX0534-_ _ _
5-wire, non-LED BCC M415-0000-1A-017-PX0534-_ _ _ BCC M425-0000-1A-017-PX0534-_ _ _
5-wire, PNP-LED, N/O & N/C signals BCC M425-0000-1A-039-PX0534-_ _ _
8-wire, non-LED BCC M418-0000-1A-044-PX0825-_ _ _ BCC M428-0000-1A-044-PX0825-_ _ _
12-wire, non-LED BCC M41C-0000-1A-049-_X_C25-_ _ _ BCC M42C-0000-1A-049-_X_C25-_ _ _

VX8= PVC (grey, 8)
PX0 = PUR (black, 0)

020 = 2 m
050 = 5 m
100 = 100 m
M12 Double-Ended
Voltage Rating 4p+PE & 5p = 125V, 8p=60V, 12p = 30V 125V
Amperage 4p+PE & 5p = 4A, 8p=2A, 12p = 1A 4A
Conductor Cross-Section 4p+PE & 5p = 0.34 mm2, 0.34 mm2
8p & 12p = 0.25 mm2, Yellow = 22 AWG
Cable Jacket Material Black PUR, Yellow TPE, Yellow PVC Black PUR
4-wire+PE, non-LED BCC M415-M415-3A-313-PX0534-_ _ _ BCC M425-M415-3A-313-PX0534-_ _ _
4-wire+PE, PNP-N/O & N/C signals BCC M425-M415-3A-661-PX0534-_ _ _
5-wire, non-LED BCC M415-M415-3A-312-PX0534-_ _ _ BCC M425-M415-3A-312-PX0534-_ _ _
5-wire, PNP-N/O & N/C signals BCC M425-M415-3A-660-PX0534-_ _ _
8-wire, non-LED BCC M418-M418-3A-342-PX0825-_ _ _
12-wire, non-LED BCC M41C-M41C-3A-325-PX0C25-_ _ _
Available Lengths:
003 = 0.3 m 020 = 2.0 m
006 = 0.6 m 030 = 3.0 m
010 = 1.0 m 050 = 5.0 m
015 = 1.5 m 100 = 10.0 m

M12 shielded cordsets
M12 Single-Ended Shielded

Voltage Rating (3p, 4p = 250 V), (3p, 4p = 250 V),
(4p+PE, 5p = 125 V), (8p = 60 V) (4p+PE, 5p = 125 V), (8p = 60 V)
Amperage (3p, 4p = 4 A), (5p = 4 A), (8p = 2 A) (3p, 4p = 4 A), (5p = 4 A), (8p = 2 A)
Conductor Cross-Section (3p, 4p, 5p = 0.34 mm2), (8p = 0.25 mm2) (3p, 4p, 5p = 0.34 mm2), (8p = 0.25 mm2)
3-wire, non-LED, N/O signal, shielded BCC M415-0000-1A-036-_S_334-_ _ _ BCC M425-0000-1A-036-_S_334-_ _ _
3-wire, non-LED, N/C signal, shielded BCC M415-0000-1A-037-_S_334-_ _ _ BCC M425-0000-1A-037-_S_334-_ _ _
4-wire, non-LED, shielded BCC M415-0000-1A-014-_S_434-_ _ _ BCC M425-0000-1A-014-_S_434-_ _ _
4-wire+PE, non-LED, shielded BCC M415-0000-1A-043-PS0534-_ _ _ BCC M425-0000-1A-043-PS0534-_ _ _
5-wire, non-LED, shielded BCC M415-0000-1A-016-PS0525-_ _ _
8-wire, non-LED, shielded BCC M418-0000-1A-046-PS0825-_ _ _ BCC M428-0000-1A-046-PS0825-_ _ _

VS8 = PVC (grey, 8)
PS0 = PUR (black, 0)
Standard Lengths Available: Cables,

cordsets and
020 = 2 meters connectors
050 = 5 meters Overview
quick selector
100 = 100 meters
Sensor cable
part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
www.balluff.com 937
M8 and M12 splitters
M8 Splitters
Type M8 Female (x2) - M12 Male M8 Female (x2) - M12 Male
Voltage Rating 60 VAC / 75 VDC 60 VAC / 75 VDC
Amperage 4A 4A
Wiring Jacket Mat.
3-wire, non-LED PVC BCC M414-M313-M313-U2012-_ _ _ BCC M414-M323-M323-U2012-_ _ _
3-wire, non-LED PUR (black)
3-wire, OR Logic PUR (black)
M12 Splitters
Type Flying Leads (x2) - M12 Male M12 Female (x2) - M12 Male
Conguration Open - Straight Straight - Straight
Voltage Rating 250 VAC/ VDC 250 VAC / VDC
Amperage 4A 4A
Wiring Jacket Mat.
3-wire, non-LED, N/O PVC BCC M414-0000-0000-U2009-_ _ _ BCC M414-M415-M415-U2010-_ _ _
3-wire, non-LED, N/O TPE BCC M414-M415-M415-U2002-_ _ _
3-wire, PNP-LED, N/O TPE BCC M414-M415-M415-U2011-_ _ _
3-wire+PE, non-LED, N/O PVC (black)
3-wire, AND Logic TPE C04 EEC-04-TY-002M-V-F039
4-wire+PE, OR Logic PVC (black)
4-wire, N/C or N/O, non-LED PUR (black) BCC M414-M415-M415-U2018-002

M8 and M12 splitters
M8 Female (x2) - M8 Male M8 Female (x2) - M12 Male Standard Lengths Available:
Straigt - Straight U-style 003 = 0.3 m
30 VAC / 30 VDC 60 VAC / 60 VDC 006 = 0.6 m
4A 4A 010 = 1.0 m
020 = 2 m
050 = 5 m
BCC M415-M313-M313-U0014-000
BCC M314-M313-M313-U2024-_ _ _
BCC M313-M313-M313-U2017-003
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M12 Female (x2) - M12 Male M12 Female (x2) - M12 Male Standard Lengths Available: M8 nano
1/2" AC micro
Right Angle - Straight U-style 003 = 0.3 m M12 micro
250 VAC / VDC 250 VAC / VDC 006 = 0.6 m Splitters
7/8" mini
4A 4A 010 = 1.0 m 7/8" to M12
adapters
020 = 2 m
Junction
BCC M414-M425-M425-U2010-_ _ _ 050 = 5 m Blocks
/homerun
BCC M414-M425-M425-U2002-_ _ _ cables
BCC M414-M425-M425-U2011-_ _ _ Flying Lead Standard Lengths: Field
020 = 2 m attachables
BCC M415-M415-M415-U0003-000
Wrenches
050 = 5 m
BCC M415-M415-M415-U0016-000
www.balluff.com 939
7/8" single-ended MINI cordset
7/8" Single-Ended
Type 7/8" Female (Int Threads) 7/8" Female (Int Threads)
Voltage Rating 300 V AC/DC 300 V AC/DC
Amperage 12 A (3-wire)/9 A (4- and 5-wire) 12 A (3-wire)/9 A (4- and 5-wire)
Conductor Cross-Section 16 AWG 16 AWG
3-wire US-Color Code BCC A313-0000-10-071-VX43W6-_ _ _ BCC A323-0000-10-071-VX43W6-_ _ _
4-wire US-Color Code BCC A314-0000-10-072-VX44W6-_ _ _ BCC A324-0000-10-072-VX44W6-_ _ _
4-wire DC-Color Code BCC A314-0000-10-003-_X44W6-_ _ _ BCC A324-0000-10-003-_X44W6-_ _ _
5-wire DC-Color Code BCC A315-0000-10-063-VX45W6-_ _ _ BCC A325-0000-10-063-VX45W6-_ _ _
Standard Cable Jackets: Standard Lengths Available:

V = PVC 020 = 2 meters
E = TPE 050 = 5 meters
100 = 10 meters
150 = 15 meters
200 = 20 meters
16 AWG Bulk Cables

Bulk Cable BCC0AEF BCC0AEH BCC0AEJ BCC0APC BCC0AEK
Jacket Material PVC PVC PVC TPE PVC
Length 100 m 100 m 100 m 100 m 100 m
Number of Conductors 3 4 4 4 5
Conductor Color Code US AC US AC DC DC DC
Jacket Color Yellow Yellow Yellow Yellow Yellow
Conductor Gauge 16 AWG 16 AWG 16 AWG 16 AWG 16 AWG
Cordsets Used 7/8" 7/8" 7/8" 7/8" 7/8"
Temperature Rating -40105C -40105C -40105C -40105C -40105C
Cable Diameter (mm) 10.24 0.20 mm 10.67 0.25 mm 10.67 0.25 mm 10.67 0.25 mm 12.57 0.25 mm

7/8" to M12 adapters
7/8" Double-Ended - Internal Threads to External Threads

Type 7/8" to M12 Converter M12 to 7/8" Converter
Conguration Female - Male Female - Male
Voltage Rating 300 V 300 V
Amperage 4A 4A
3-wire BCC0A7E BCC0A7J
BCC A313-M413-3E-RA031-000 BCC M415-A313-3F-RA023-000
4-wire BCC0A7F BCC0A7K
5-wire BCC0A7H BCC0A7L
7/8" connectors, male straight and right-angle 7/8" connectors, female straight and right-angle
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
37.5
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
You will nd many additional products in our total product

line, Industrial networking and connectivity A guide to
industrial network architecture or online at: www.balluff.us.
www.balluff.com 941
M8 junction blocks
M8 Junction Blocks (MIBs) - Quick Disconnect

Type M12 Quick Disconnect M12 Quick Disconnect
Conguration 4 port 8 port
Voltage Rating 10...30 VDC 10...30 VDC
Current Rating / Block 6A 6A
Current Rating / Contact 2A 2A
Suggested Homerun Cable BCC M4_8-0000-1A-044-PX0825-_ _ _ BCC M4_C-0000-1A-049-PX0C25-_ _ _
3-wire, PNP-LED BPI 4M303P-2K-00-SM48T BPI 8M303P-2K-00-SM4CT
M8 Junction Blocks (MIBs) - Cable Out

Type Cable Out Cable Out
Current Rating / Block 6A 6A
3-wire, PNP-LED BPI 4M303P-2K-00-KPX60-_ _ _ BPI 8M303P-2K-00-KPXA0-_ _ _

4-wire, PNP-LED BPI 4M304P-2K-00-KPXA0-_ _ _ BPI 8M304P-2K-00-KPXK0-_ _ _

030 = 3 meters
050 = 5 meters
100 = 10 meters
150 = 15 meters
M8 Blocks - M12 Homerun Cables

Voltage Rating (8p = 60 V), (12p = 30 V) (8p = 60 V), (12p = 30 V)
Amperage (8p = 2 A), (12p = 1A) (8p = 2 A), (12p = 1A)
8-wire BCC M418-0000-1A-044-PX0825-_ _ _ BCC M428-0000-1A-044-PX0825-_ _ _
12-wire BCC M41C-0000-1A-049-PX0C25-_ _ _ BCC M42C-0000-1A-049-PX0C25-_ _ _

020 = 2 meters
050 = 5 meters
100 = 10 meters
For more variations see

Networking Catalog

M12 junction blocks
M12 Junction Blocks (MIBs) - Quick Disconnect

Type M23 Quick Disconnect M23 Quick Disconnect
Current Rating / Block 6A 12 A
Suggested Homerun Cable (3-wire) BCC M6_C-0000-10-065-PX0BP4-_ _ _ BCC M6_C-0000-10-065-PX0BP4-_ _ _
Suggested Homerun Cable (4-wire) BCC M6_L-0000-10-022-PX0LP4-_ _ _ BCC M6_L-0000-10-022-PX0LP4-_ _ _
3-wire+PE, PNP-LED BPI 4M4A4P-2K-00-SM6CT BPI 8M4A4P-2K-00-SM6CT
4-wire+PE, PNP-LED BPI 4M4A5P-2K-00-SM6LT BPI 8M4A5P-2K-00-SM6LT
M12 Junction Blocks (MIBs) - Cable Out

Type Cable Out Cable Out
Cables,
Conguration 4 port 8 port cordsets and
Voltage Rating 10...30 VDC 10...30 VDC connectors
Current Rating / Block 6A 12 A Overview
quick selector
Current Rating / Contact 2A 2A Sensor cable
part number
3-wire+PE, PNP-LED BPI 4M4A4P-2K-00-KPX70-_ _ _ BPI 8M4A4P-2K-00-KPXB0-_ _ _ builder
4-wire+PE, PNP-LED BPI 4M4A5P-2K-00-KPXB0-_ _ _ BPI 8M4A5P-2K-00-KPXL0-_ _ _ BCC part
number matrix
Technical
Standard Lengths Available specications
030 = 3 meters Connectors
M5
050 = 5 meters M8 nano
100 = 10 meters 1/2" AC micro
M12 micro
150 = 15 meters Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
M12 Blocks - M23 Homerun Cables Field
Type M23 Female M23 Female attachables
Conguration Straight Right Angle Wrenches
Voltage Rating (12p = 250 VAC/VDC), (19p = 125 VAC/VDC) (12p = 250 VAC/VDC), (19p = 125 VAC/VDC)
Amperage (12p = 8 A), (19p = 3x8 A) (12p = 8 A), (19p = 3x8 A)
12-wire BCC M61C-0000-10-065-PX0BP4-_ _ _ BCC M62C-0000-10-065-PX0BP4-_ _ _
19-wire BCC M61L-0000-10-022-PX0LP4-_ _ _ BCC M62L-0000-10-022-PX0LP4-_ _ _

020 = 2 meters
050 = 5 meters
100 = 10 meters
For more variations see

Networking Catalog
www.balluff.com 943
M8 eld attachables
M8 Female Field Attachables

Conguration Straight Straight
Housing Plastic/Metal Plastic
Connection Piercon Terminals Screw Terminals
Conductor Maximum 0.14...0.38 mm (26...22 AWG) 0.14...0.50 mm (26...20 AWG)
No. of Conductors Cable Range Order Code
Part Number
3-wire 3...5 mm BCC09EU
BCC M333-0000-10-000-22X334-000
3.5...5 mm BCC06Z1
BCC M333-0000-10-000-31X350-000
4-wire 3...5 mm BCC09EY
BCC M334-0000-10-000-22X434-000
3.5...5 mm BCC06Z5
BCC M334-0000-10-000-31X450-000
M8 Male Field Attachables

Type M8 Male M8 Male
Housing Plastic/Metal Plastic
Connection Piercon Terminals Screw Terminals
No. of Conductors Cable Range Order Code
Part Number
3-wire 3...5 mm BCC09EW
BCC M333-0000-20-000-22X334-000
3.5...5 mm BCC0E7N
BCC M333-0000-20-000-31X350-000-C027
4-wire 3...5 mm BCC09EZ
BCC M334-0000-20-000-22X434-000
3.5...5 mm BCC06Z7
BCC M334-0000-20-000-31X450-000

M8 eld attachables
Standard Cable Information

M8 Female M8 Female Jacket Wires Conductors Diameter
Straight Right Angle Yellow PVC 3 22 AWG 4.7 0.15 mm
Plastic/Metal Plastic Yellow PVC 4 22 AWG 5.0 0.15 mm
Solder Cup Solder Cup Grey PVC 3 0.34 mm 4.5 0.15 mm
0.14...0.38 mm (26...22 AWG) 0.14...0.38 mm (26...22 AWG) Grey PVC 4 0.34 mm 4.8 0.15 mm
Yellow PUR 3 22 AWG 4.3 0.20 mm
Black PUR 3 0.34 mm 4.3 0.20 mm
Black PUR 4 0.34 mm 4.7 0.20 mm
BCC06YW BCC06YY Yellow TPE 3 22 AWG 5.3 0.13 mm
BCC M333-0000-10-000-34X325-000 BCC M343-0000-10-000-34X325-000 Yellow TPE 4 22 AWG 5.3 0.13 mm
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Standard Cable Information Splitters
7/8" mini
M8 Male M8 Male Jacket Wires Conductors Diameter 7/8" to M12
Straight Right Angle Yellow PVC 3 22 AWG 4.7 0.15 mm adapters
Junction
Plastic/Metal Plastic Yellow PVC 4 22 AWG 5.0 0.15 mm Blocks
Solder Cup Solder Cup Grey PVC 3 0.34 mm 4.5 0.15 mm /homerun
cables
0.14...0.38 mm (26...22 AWG) 0.14...0.38 mm (26...22 AWG) Grey PVC 4 0.34 mm 4.8 0.15 mm Field
Yellow PUR 3 22 AWG 4.3 0.20 mm attachables
Yellow PUR 4 22 AWG 4.7 0.20 mm Wrenches
Black PUR 3 0.34 mm 4.3 0.20 mm
Black PUR 4 0.34 mm 4.7 0.20 mm
Yellow TPE 3 22 AWG 5.3 0.13 mm
BCC06YZ BCC06Z0
BCC M333-0000-20-000-34X325-000 BCC M343-0000-20-000-34X325-000
www.balluff.com 945
M12 female eld attachables
M12 Female Field Attachables

Type M12 Female M12 Female M12 Female
Conguration Straight Straight Straight
Housing Plastic Plastic Plastic
Connection Screw Terminals Insulation Displacement Spring Clamp
Conductor Range 0.14...0.75 mm (26...18 AWG) 0.14...0.34 mm (26...22 AWG) 0.14...0.50 mm (26...20 AWG)
No. of Allowable Order Code
Conductors Cable Part Number
4-wire 4...6 mm BCC06Z9 BCC06ZY
BCC M435-0000-1A-000-41X475-000 BCC M435-0000-1A-000-43X434-000
5...8 mm
6...8 mm BCC06F6 BCC06Y6

BCC M435-0000-1A-000-51X475-000 BCC M435-0000-1A-000-55X450-000
5-wire 2.1...3 mm or BCC09JP
4...5 mm BCC M435-0000-1A-000-A1X575-000
4...6 mm BCC06ZF
BCC M435-0000-1A-000-41X575-000
5...8 mm
6...8 mm BCC06W9
BCC M435-0000-1A-000-51X575-000
8-wire 4...6 mm BCC04MC
(shielded) BCC M478-0000-1A-000-43X834-000
6...8 mm BCC0A03
(0.14...0.50 mm) BCC M438-0000-1A-000-51X850-000
12-wire 6...8 mm BCC0A05* (solder cup)
(0.14...0.25 mm) BCC M43C-0000-1A-000-54XC25-000
Jacket Wires Conductors Diameter *Consult factory for availability.

Yellow PVC 3 22 AWG 4.7 0.15 mm
Grey PVC 3 0.34 mm 4.5 0.15 mm
Grey PVC 4 0.34 mm 4.8 0.15 mm
Jacket Wires Conductors Diameter

Black PUR 3 0.34 mm 4.3 0.20 mm
Black PUR 4 0.34 mm 4.7 0.20 mm

M12 female eld attachables
M12 Female M12 Female M12 Female M12 Female

Right Angle Straight Straight Right Angle
Plastic Metal (shielded) Stainless Steel Stainless Steel
Screw Terminals Screw Terminals Screw Terminals Screw Terminals
0.14...0.75 mm (26...18 AWG) 0.14...0.75 mm (26...18 AWG) 0.14...0.75 mm (26...18 AWG) 0.14...0.75 mm (26...18 AWG)
BCC06ZA
BCC M445-0000-1A-000-41X475-000
BCC06ZM
BCC M475-0000-1A-000-01X475-000
BCC06Y8
BCC M445-0000-1A-000-51X475-000
BCC06ZH BCC097P BCC097T

BCC M445-0000-1A-000-41X575-000 BCC S435-0000-1A-000-41X575-000 BCC S445-0000-1A-000-41X575-000
BCC06ZN
Cables,
BCC M475-0000-1A-000-01X575-000 cordsets and
BCC06ZJ BCC097R BCC097U connectors
Overview
BCC M445-0000-1A-000-51X575-000 BCC S435-0000-1A-000-51X575-000 BCC S445-0000-1A-000-51X575-000 quick selector
BCC04ME (IDC) Sensor cable
BCC M488-0000-1A-000-43X834-000 part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
www.balluff.com 947
M12 male eld attachables
M12 Male Field Attachables

Type M12 Male M12 Male M12 Male
Conguration Straight Straight Straight
Housing Plastic Plastic Plastic
Connection Screw Terminals Insulation Displacement Spring Clamp
Conductor Maximum 0.14...0.75 mm (26...18 AWG) 0.14...0.34 mm (26...22 AWG) 0.14...0.50 mm (26...20 AWG)
No. of Allowable Order Code
Conductors Cable Part Number
4-wire 4...6 mm BCC06M4 BCC08C0
BCC M434-0000-2A-000-41X475-000 BCC M434-0000-2A-000-43X434-000
5...8 mm
6...8 mm BCC06F7 BCC06Y5

BCC M434-0000-2A-000-51X475-000 BCC M434-0000-2A-000-55X450-000
5-wire 2.1...3 mm or BCC09JW
4...5 mm BCC M435-0000-2A-000-A1X575-000
4...6 mm BCC06YA
BCC M435-0000-2A-000-41X575-000
5...8 mm
6...8 mm BCC06EY
BCC M435-0000-2A-000-51X575-000
8-wire 4...6 mm BCC01KR
C04 CNT-9
6...8 mm BCC0A04
(0.14...0.50 mm) BCC M438-0000-2A-000-51X850-000
12-wire 6...8 mm BCC0A06* (solder cup)
(0.14...0.25 mm) BCC M43C-0000-2A-000-54XC25-000
Jacket Wires Conductors Diameter *Consult factory for availability.

Grey PVC 3 0.34 mm 4.5 0.15 mm
Grey PVC 4 0.34 mm 4.8 0.15 mm
Jacket Wires Conductors Diameter

Black PUR 3 0.34 mm 4.3 0.20 mm
Black PUR 4 0.34 mm 4.7 0.20 mm

M12 male eld attachables
M12 Male M12 Male M12 Male M12 Male

Right Angle Straight Straight Right Angle
Plastic Metal (shielded) Stainless Steel Stainless Steel
Screw Terminals Screw Terminals Screw Terminals Screw Terminals
0.14...0.75 mm (26...18 AWG) 0.14...0.75 mm (26...18 AWG) 0.14...0.75 mm (26...18 AWG) 0.14...0.75 mm (26...18 AWG)
BCC06ZC
BCC M444-0000-2A-000-41X475-000
BCC0869
BCC M474-0000-2A-000-01X475-000
BCC06ZE
BCC M444-0000-2A-000-51X475-000
BCC06ZK BCC097K BCC097M

BCC M445-0000-2A-000-41X575-000 BCC S435-0000-2A-000-41X575-000 BCC S445-0000-2A-000-41X575-000
BCC086A
Cables,
BCC M475-0000-2A-000-01X575-000 cordsets and
connectors
BCC06ZL BCC097L BCC097N
Overview
BCC M445-0000-2A-000-51X575-000 BCC S435-0000-2A-000-51X575-000 BCC S445-0000-2A-000-51X575-000 quick selector
Sensor cable
part number
builder
BCC part
number matrix
Technical
specications
Connectors
M5
M8 nano
1/2" AC micro
M12 micro
Splitters
7/8" mini
7/8" to M12
adapters
Junction
Blocks
/homerun
cables
Field
attachables
Wrenches
www.balluff.com 949
1/2" Micro AC and 7/8" mini eld attachables
1/2" Field Attachables

Type 1/2" Female 1/2" Male
Housing Plastic Plastic
Connection Screw Terminals Screw Terminals
Cable Gland PG7 PG7
No. of Conductors Order Code
Part Number
Female BCC01ZL BCC08AU BCC0206 BCC08AW
C21 AN3-7 BCC A233-0000-10-000-41X3W8-000 C21 BN3-7 BCC A243-0000-10-000-41X3W8-000
Male BCC080J BCC08AY BCC020E BCC08AZ
C21 CN3-7 BCC A233-0000-20-000-41X3W8-000 C21 DN3-7 BCC A243-0000-20-000-41X3W8-000
7/8" Field Attachables

Type 7/8" Female 7/8" Male
Housing Plastic Plastic
Connection Screw Terminals Screw Terminals
No. of Conductors Allowable Order Code
Cable Part Number
3-wire 10...12 mm BCC0ATA BCC0ATE
BCC A333-0000-10-000-71X3A5-000 BCC A333-0000-20-000-71X3A5-000
4-wire 10...12 mm BCC0708 BCC070C
BCC A334-0000-10-000-71X4A5-000 BCC A334-0000-20-000-71X4A5-000
5-wire 12...14 mm BCC0ATH BCC0ATF
BCC A335-0000-10-000-81X5A5-000 BCC A335-0000-20-000-81X5A5-000
Jacket Material PVC PVC PVC PVC

Number of Conductors 3 4 4 5
Cable Diameter (mm) 10.24 0.20 mm 10.67 0.25 mm 10.67 0.25 mm 12.57 0.25 mm

Wrenches
IP67 Torque Wrenches
By using a calibrated IP67 torque wrench on the hex nut with every cordset,
you can ensure the IP67 rating at the sensor or at the MIB, which will protect
your sensor signals even in the wettest environments.
Description Order Code

Part Number
M8, 0.4 Nm torque rating BAM00ZL
BAM TO-CC-001-M3-0,4/8,0
M12, 0.6 Nm torque rating BAM00ZM
BAM TO-CC-001-M4-0,6/12,0
7/8", 1.5 Nm torque rating BAM00ZN
BAM TO-CC-001-A3-1,5/24,0
Cables,
cordsets and
connectors
Overview
quick selector
Sensor cable
part number
builder
BCC part
number matrix
Technical
Possible Wet/Oily Environment specications
Connectors
M5
In this scenario there is a connection between M8 nano
cordsets, with the nal connection to a sensor. This 1/2" AC micro
M12 micro
scenario is characteristic of homerun cables, patch Splitters
cables, and adapter cables. The connection between 7/8" mini
7/8" to M12
cordsets can sometimes lie in an unexpected, oily adapters
or wet environment at the bottom of a work cell. By Junction
Blocks
using a combination of a new Balluff cordset with /homerun
hexagonal coupling nut and a properly calibrated cables
torque wrench, the sensor connection is IP67 Field
attachables
guaranteed. By ratcheting when the connection is
Wrenches
properly sealed, it does not allow over-torque, which
can be just as bad as too little torque.
www.balluff.com 951
Basic
Information
and
Denitions

Basic Information and Denitions
Contents

Inductive Sensors 954
Photoelectric Sensors 968
Capacitive Sensors 983
Magnetic Cylinder Sensors 990
Cables 995
Materials 1000
IEC Standards 1002
Quality/Standards 1003
Conversion Tables 1006
www.balluff.com 953
Inductive sensors
Principle ... of inductive proximity sensors is based on the interaction

between metallic conductors and an electromagnetic alternating
eld. Eddy currents are induced in the metallic damping material,
which removes energy from the eld and reduces the height of
the oscillation amplitude. This change is processed in the induc-
tive sensor, which changes its output state accordingly.
Function groups ... of the Balluff proximity

switch are:
Sensor Oscillator Demodulator Trigger Output

eld, driver
Coil, Core
Sensing face ... is the area through which the high-frequency sensor eld
Sensor eld
enters the air space. It is determined primarily by the base of the
shell core and corresponds roughly to the surface area of the
shell core cap.
Sensing face
Standard target ... is a square plate of Fe 360 (ISO 630), used to dene sensing
distances per EN 60947-5-2. The thickness is d = 1 mm; and
Standard target
the side length a corresponds to
the diameter of the circle of the sensing face
or
3 x sn, if the value is greater than the given diameter.
Correction factor ... gives the reduction in sensing dis- Material Factor
tances for target materials which are steel 1.0
not made of Fe 360. Unless otherwise copper 0.25...0.45
noted. brass 0.35...0.50
aluminum 0.30...0.45
stainless steel 0.60...1.00
nickel 0.65...0.75
cast iron 0.93...1.05
Switching frequency f .. refers to the maximum number of

Pr wit
switching operations per second.

St
ox ch
s
an
im
d
ity
ar
d
Damping is per EN 60947-5-2 with

ta
rg
standard targets on a rotating, non-

et
conducting disk. The surface area

ratio of iron to non-conductor must
be 1 : 2.
The rated value of the switching

frequency is reached when
either the turn-on signal t1 = 50
s or the
turn-off signal t2 = 50 s
.

Inductive sensors
Delay Times
Start-up delay tv ... is the time from when the supply voltage is applied,
and the proximity switch assumes the ready state. This time
may not be longer than 300 ms. During this time there must be
no fault signal longer than 2 ms.
Temperature Effects and Limits
Temperature drift ... is the deviation of the effective operating distance with the
temperature range of 25 C d Ta d +70 C. Per EN 60947-5-2
it is: 'sr/sr d 10 %
Ambient temperature range Ta ... is the temperature range over which the function of the switch
is guaranteed.
Magnetic Field Immunity
Principle Error-free function depends on the magnitude of the welding

current and the distance of the sensor from the current carrying Basic
line. information
Inductive
sensors
Design and circuitry techniques ensure that magnetic eld im- Photoelectric
mune proximity switches remain unaffected by magnetic elds. sensors
Capacitive
sensors
Magnetic
cylinder
sensors
Cables
Magnetic eld Materials
IEC Standards
Quality/
Standards
Conversion
Tables
Current Sensor
conductor
www.balluff.com 955
Inductive sensors
Supply voltage UB ... is the permissible voltage range in which certain safe operation of the switch
is guaranteed (including ripple V.It is indicated in the catalog section for each
product.
Rated ... is the supply voltage UB used for testing without tolerances. To determine the
operating voltage Ue rated and limit values, the sensor must be operated using Ue. It is:
for DC switches for AC and

Ue = 24 VDC AC/DC switches
for AC and Ue = 110 VAC
AC/DC switches
Ue = 110 VAC
Voltage drop Ud ... is the voltage measured across the load of a closed (conducting) sensor at
load current Ie.
Rated insulation ... of a proximity switch is the voltage to which the isolation tests and the creep
voltage Ui distances are referenced. For proximity switches the highest rated operating volt-
age must be considered as the rated isolation voltage.
Rated supply frequency ... of the power supply for AC devices is 50 to 60 Hz.
Ripple V (%) ... is the AC voltage (peak-to-peak

of Ue) overlaid on the DC voltage
Ue given in percent. To operate DC
switches, a ltered DC voltage hav-
ing a ripple of max. 15 % (per DIN
41755) is required.
Ue = rated operational voltage
Uss = oscillation width
Uss
Ripple V = 100 [%]
Ue
Rated ... is the permissible constant output current that may ow through the load Rl.
operating current Ie
Off-state current Ir ... is the residual current owing through the load when a proximity switch is not
conducting (open).
Max. inrush Ik ... in the case of alternating current indicates the current Ik (Aeff) which is permitted
to ow during a given turn-on time tk (ms) and at a given frequency (Hz).
Short circuit current ... is 100 A, i. e., per EN 60947-5-2 the power supply during testing in short
circuit mode must be able to provide at least 100 A for a short duration. This cur-
rent is prescribed in the standard in order to test the short-circuit strength.
No-load supply current I0 ... is the current, which ows in the switch, without the need for a load to be
connected (only with 3- and 4-wire-switches).This current supplies the sensor
electronics.

Inductive sensors
Minimum ... is the smallest load current required for function of the switch when ON.
operating current Im
Output resistance Ra ... is the resistance between the output and the supply voltage which is built
into the switch; see Output circuits.
Load capacitance ... is the permissible total capacitance on the output of the switch, including line
capacitance.
Output Circuits
Driver stages
3-wire PNP, sourcing NPN, sinking

DC switches (current source) (current sink)
S = semiconductor switch
Ra = output resistance
Dz = Z-Diode, limiter
D1 = pol. rev. protect. diode
D2 = pol. rev. protect. diode
in load current circuit
(for short protection
types only)
LED = light emitting diode
Basic
information
Inductive
sensors
Photoelectric
sensors
2-wire Non-polarized Capacitive
sensors
DC switches
S = semiconductor switch Magnetic
Dz = Z-Diode, limiter cylinder
C = capacitor sensors
GI = bridge rectier Cables
LED = light emitting diode Materials
IEC Standards
Quality/
Standards
Conversion
Tables
2-wire
AC and AC/DC switches S = semiconductor switch
Dz = Z-Diode, limiter
(universal current switches) C = lter capacitor
RC = HF-Peak-limiter
ground connection for con- Gl = bridge rectier
nector version only LED = light emitting diode
VDR = voltage spike limiter
www.balluff.com 957
Inductive sensors
Wiring Diagrams
Cable/Terminals Connector Cable/Terminals Connector
DC 3/4-Wire NPN () sinking
PNP (+) sourcing
Normally open ! $
Normally closed @ %
NO/NC # ^
DC 2-Wire
Polarized Non-polarized
Normally open & (
Normally closed * )
AC-Sensors
*2 with protection ground
1
*
Normally open 1 3 2
3
3
2 1
Normally closed 2 4 2
3
3
AC/DC-Sensors
*
2
with protection ground
*
Normally open 5 7 1
2
3
3
2
Normally closed 6 8 1
2
3 3
Wire colors *Pin assignments shown are based on

Coding per DIN IEC 60757 BN brown the U.S. standard for cable connectors
BK black
BU blue
958 WH white For more information, visit us online!
Inductive sensors
Series connection ... can cause a time delay

(e. g. start-up delay). The number 3-wire DC switch 2-wire DC switch
of connected proximity switches (AC/DC)
is limited by the total voltage drop
(sum of all Ud).
In the case of 2-wire sensors it

is limited by the addition of the
minimum supply voltages. For
3-wire switches, the load capacity
of the output stage represents a
further limitation, since the current
consumption I0 of all switches is
added to the rated current Ie.
The ready delay time tv is the ready

delay of a sensor (number of
sensors n 1).
For parallel ... of proximity switches with LED

connection it is recommended that the out- 3-wire DC switch 2-wire DC switch
puts of the individual switches
be decoupled using diodes (as Parallel wiring of 2-wire
shown). proximity switches is Basic
not recommended, since information
This prevents all LEDs from missed pulses can be Inductive
sensors
lighting-up when the output state caused by the build-up of
Photoelectric
of one switch is turned on. oscillations. sensors
Capacitive
sensors
Magnetic
cylinder
sensors
Cables
Materials
IEC Standards
Quality/
Standards
Conversion
Tables
Utilization categories Category Typical load applications

per EN 60947-5-2/ AC 12 AC-switch Resistive and semiconductor loads, optocouplers
IEC 60947-5-2 AC 140 AC-switch Small electromagnetic load Ia d 0.2 A; e. g. contactor relay
DC 12 DC-switch Resistive and semiconductor loads, optocouplers
DC 13 DC-switch Electromagnets
www.balluff.com 959
Inductive sensors
Polarity reversal protected ... protected against any possible lead reversal for sensors with short circuit protec-
tion.
...protected against reversal of plus/minus leads for sensors without short circuit
protection.
Cable break protection ... in 3-wire sensors prevents improper function. A diode prevents the current from
owing via the output line A.
Short circuit protected ... is achieved in Balluff sensors using pulsing or thermal short circuit protection
(sensors with a maximum circuits. The output stage is thereby protected against overload and short circuit.
voltage of 60 V DC) The trigger current for the short circuit protection is higher than the rated operating
current Ie. Currents from switching and load capacitances are specied in the sensor
data and do not result in triggering, but rather are masked by a short delay in the
output circuit.
Short circuit/overload ... AC or AC/DC sensors are often operated with a relay or contactor as the load.
protected AC switching devices (contactors/relays) create a signicantly higher load (6...10
(universal AC/DC sensors) rated current) when they are rst energized as compared with their static operation
due to the fact that the core is still open.The static value of the load (current) is not
reached until several milliseconds later. Not until the magnetic eld is closed does the
max. permissible rated operating current Ie ow through the sensor.This means that
the threshold value for a short circuit condition in these sensors must lie signicantly
higher and would, if for example the contactor is prevented for mechanical or electri-
cal reasons from fully closing, result in an overload on the sensors.
This is where the overload protection comes into play. It is designed as slow-acting
(time-delayed). Its trigger threshold lies only slightly above the maximum permissible
Ie. A response (i. e. turn-off) is delayed, depending on the magnitude of the overload,
by more than 20 milliseconds. This ensures that properly working relays and contac-
tors can be switched normally, while defective devices will not destroy the Balluff
sensor. The short circuit/overload protection is generally of a bi-stable design, which
means that it must be reset by turning off the supply voltage to the sensor.

Inductive sensors response curves
Axial and radial damping

When damping in an axial direction the standard target is moved concentric to the system axis. The switchpoint is there-
by determined only by the distance s from the sensing face of the sensor. When damping in the radial direction, the
location of the switchpoint is additionally affected by the radial distance r of the target from the system axis.
The diagram shows the response curves, which indicate the dependency of the switchpoint on s and r.The primary
purpose of this drawing is to show the possibility of damping using a lateral approach and the difference compared with
axial approach
Application
Due in part to manufacturing tolerances within a production run, the exact switchpoint must in any case be established on
site.The solid lines represent the respective switchpoint (E), the dashed lines indicate the turn-off point (A). The red lines ap-
ply to switches with a clear zone, and the black lines for ush mount types. Since the switching operation can be induced
from either direction, the curves are shown mirrored from the system axis.
Examples
Passing objects on conveyor lines generate a signal change when their front edge crosses the turn-on curve on the entry
side. The signal reverses again when the back edge of the passing object crosses the (mirrored) turn-off curve on the op-
posite side. With reversing parts (e. g. limit of travel), the signal reversal occurs at the turn-off curve on the same side.
Typical approach curves

using the example of an M12 sensor with sn 2 mm
Standard target, axial approach
Basic
information
Inductive
sensors
Photoelectric
sensors
Standard target, radial approach Standard target, radial approach Capacitive
sensors
Magnetic
cylinder
sensors
Cables
Materials
IEC Standards
Quality/
Standards
Conversion
Tables
Sensor diameter (sensing face)
Sensor
The vertical axis in the diagram shows the distance of the switchpoint from the sensing face. It is referenced to the
nominal sensing distance sn. At a distance of 0.8 mm, a laterally approaching target reaches the solid line turn-on
curve at point E and leaves the turn-off curve at point A.
The horizontal axis in the diagram is referenced to the radius of the sensingface. The zero point of this axis lies in
the center of the shell core cap. In our example for the M12 switch, the radius is r = 6 mm. Example: The distance of
the turn-on and turn-off point (from the system axis) is typically E ~ 2.75 mm, A ~ 2.95 mm.
www.balluff.com 961
Inductive sensors
Switching Distances
Standard target
Switching distance s ... is the distance between the standard target and the sensing
face of the proximity switch at which a signal change is gener-
ated per EN 60947-5-2.For normally open this means from
OFF to ON and for normally closed from ON to OFF.
Rated operating ... is a theoretical value, which does not take into account manu-
distance sn facturing tolerances, operating temperatures, supply voltages,
etc. sn
Effective operating dis- ... is the switching distance of a single proximity switch mea-
tance sr sured under specied conditions, e.g. ush mountable, rated
Sensing face
operating voltage Ue, temperature Ta = +23 C r5 C (0.9 sn d
sr d 1.1 sn). sr
Useful operating ... is the switching distance of a single proximity switch under 110 % 90 %
distance su specied temperature and voltage conditions (0.81 sn d su d
1.21 sn). su
100 %
121 % 81 % 0%
Assured operating ... is any switching distance for which an operation of the prox-
distance sa imity switch within the permissible operating conditions (tem-
peratures, voltages) is guaranteed (0 d sa d 0.81 sn).
sa
Switching distance Housing Switching distance

identier none standard switching distance
per IEC 60947-5-2 3 mm* 1 mm ush
Switching distance 2x the switching distance 4 mm/M5* 1.5 mm ush
2X vs. standard 6.5 mm...M30 1.5...2x
3 mm* 3 mm non-ush
Switching distance 3x the switching distance 4 mm/M5* 5 mm non-ush
3X vs. standard 6.5 mm...M12 2.2...3x
M18...M30 depending on version
Switching distance 4x the switching distance
4X vs. standard
*Switching distance in mm. The switching distances for these sensors are not standardized.
Repeat accuracy R ... of sr is determined at rated operating voltage Ue under the following conditions: Tempera-
ture: T = +23 C r5 CRelative humidity: d 90 % Measuring duration: t = 8 h.
The permissible deviation per EN 60947-5-2 is R d 0.1 sr. Reference axis
Standard target
Hysteresis H ... is given as a percentage of the effective operating dis-

(switching hysteresis when tance sr. It is measured at an ambient temperature of +23
target is backed off) C r5 and at the rated operational voltage.
It must be less than 20% of the effective operating distance
(sr). H d 0.2 sr
Sensing face
Assured
switching
distance Proximity
switch
Inductive sensors
Installation in Metal
Sensors with standard switching distance
Sensing face
Flush mountable proximity ... can be installed with their sensing
switches faces ush to the metal. The distance
from opposing metal surfaces must be
t 3sn and the distance between two
proximity switches (side-by-side) t2d.
Sensing face
Non-ush mountable ... can be identied by their caps,
proximity switches since they have no metal housing sur-
rounding the area of the sensing face.
The sensing face must extend t 2sn
from the metallic installation medium.
The distance from opposing metal Clear zone
surfaces must be t 3sn and the dis-

tance between two adjacent proximity
switches t3d.
Basic
information
Inductive
sensors
Photoelectric
sensors
Capacitive
Opposing installation ... requires for all inductive proximity sensors
Magnetic
of 2 sensors switches a minimum distance of t 3d cylinder
between the sensing face. sensors
Cables
Materials
IEC Standards
Quality/
Standards
Conversion
Tables
Installation medium Ferromagnetic materials: Iron, steel or other mag-

netizable materials.
Alloys: Brass, aluminum or

other non-magnetizable
materials.
Other materials: Plastics, electrically non-

conducting materials.
www.balluff.com 963
Inductive sensors
Sensors with switching distance indicator 2X
Flush mountable proximity ... can be installed with

switches their sensing faces ush to the metal. Installation Sensing face
in alloy may result in a reduction of the switch-
ing distance. The distance to opposing switches
must be t 3sn, and the distance between adja-
cent switches (side-by-side) must be t 2d.
In order to install the sensor in ferromagnetic
materials, the following guidelines are used for
dimension .
3-wire DC
Housing Dimension For Factor 1 sensors the dimen-
size d sion is not needed for installa-
3 mm 1 mm tion in metal.
4 mm 1.5 mm
M5 1.5 mm
6.5 mm 0 mm Sensing face
M8 0 mm
M12 1.5 mm
M18 2.5 mm
M30 3.5 mm
2-wire DC
Housing Dimension
size d
M8 0 mm
M12 0 mm
M18 0.7 mm
M30 3.5 mm
Sensing face
Non-ush mountable ... can be identied by their caps, since they

proximity switches have no metal housing surrounding the area of Clear zone
the sensing face. The sensing face must extend
t 2sn from the metallic installation medium.
The distance from opposing metal surfaces
must be t 3sn and the distance between sen-
sors t3d.
Opposing installation ... requires for all inductive proximity switches a

of 2 sensors minimum distance of t 4d between the sensing
face.

Inductive sensors
Sensors with switching distance indicator 3X and 4X
Quasi-ush mountable ... require a space behind the sensing face which is free of conducting materials.
proximity switches Under this condition the specied switching distance is available without limitation.
Dimension (see g.) indicates the shortest distance between the sensing face and
the conductive material behind it.
Sensing
surface
Switching distance 3X Switching distance 4X
Housing Dimension Dimension
size d for installation in for installation in
ferromagnetic other ferromagnetic other
materials metals materials metals
6.5 mm,M8 2.0 mm 1.0 mm 3.0 mm 2.0 mm
M12 2.5 mm 2.0 mm 4.0 mm 3.0 mm
M18 4.0 mm 2.5 mm
M30 8.0 mm 4.0 mm
88 mm Clear zone
Non-ush mountable ... can be identied by their caps, since they have no metal housing surrounding the
proximity switches area of the sensing face. The distance from opposing metal surfaces must be t 3sn.
Installation conditions:
Basic
Housing size d Dimension b Dimension c Dimension e information
3 mm t 10 mm t t 30 mm t t 10 mm t Sensing face Inductive
M5 t 15 mm t 40 mm t 20 mm Photoelectric
sensors
6.5 mm t 8 mm t 32 mm t 8 mm Capacitive
M8 t 8 mm t 32 mm t 8 mm sensors
M12 t 10 mm t 48 mm t 12 mm Magnetic
cylinder
M18 t 20 mm t 72 mm t 18 mm Clear zone sensors
M30 t 35 mm t 120 mm t 30 mm Cables
in steel Materials
t 25 mm IEC Standards
in alloy Quality/
Standards
t 20 mm
Conversion
in stainless Tables
steel
Opposing installation ... requires for all inductive proximity switches a minimum distance of t 5d between
of 2 sensors the sensing faces. For exceptions see table.
Housing size Dimension a

3 mm 20 mm
4 mm 45 mm
M5 45 mm
www.balluff.com 965
Inductive sensors
SteelFace Sensors
Sensing face
To assure proper function, the values in the tabel below A
and the gure to the right should be observed. (Fig. 1)
A
Switching distance 2X t2d
Switching distance 3X t 4d
When installing in metals, the values for dimension x shown in

the following table must be observed. When these guidelines
are followed, the effective switching distance Sr will deviate Fig. 1
less than 10%. Values are in mm. (Fig. 2)
Sensor x x x x
2X Flush Mount Steel Aluminum Brass Stainless
Steel
Sensing face
M8 0mm 6mm 6mm 5mm
M12 0mm 8mm 8mm 7mm
M18 0mm 11mm 11mm 10mm
3X Quasi Flush Mount
M12 7mm 12mm 12mm 10mm

M18 14mm 12mm 14mm 16mm
M30 28mm 28mm 28mm 35mm
3X Non-Flush Mount Fig. 2
M12 25mm 15mm 17mm 25mm
M18 45mm 25mm 25mm 45mm
M30 70mm 40mm 40mm 70mm
Opposing Installation of Two Sensors

This conguration requires a minimum separation of
t3 Sn between the active surfaces for M8 thru M30,
2x and 3x sensors. (Fig. 3)
Reduction factors for target material Fig. 3

2X Flush Mount Steel Aluminum Brass Copper Stainless
Steel
M12 1.0mm 0.8...1mm 0.7...0.85mm 0.85...1.3mm 0.5...0.9mm
M18 1.0mm 0.8...1mm 0.7...0.85mm 0.85...1.3mm 0.5...0.8mm
M30 1.0mm 0.7...1mm 0.7...0.9mm 0.9...1.2mm 0.5...1mm
3X Quasi Flush Mount
M12 1.0mm 1.0mm 0.8mm 1.0mm 1.0mm

M18 1.0mm 0.7mm 0.7mm 0.7mm 1.0mm
M30 1.0mm 0.7mm 0.7mm 1.0mm 1.0mm
Ferrous Only
M8 1.0mm - - - 0.45mm
M12 1.0mm - - - 0.25mm
M18 1.0mm - - - 0.5mm
M30 1.0mm - - - 0.7mm
Non-Ferrous Only
M8 - - - - -
M12 - 1.0mm 1.1mm 0.9mm -
M18 - 1.0mm 1.1mm 0.9mm -
M30 - 1.0mm 1.1mm 0.9mm -

Inductive sensors
Mounting Guidelines for 40x40x62 Sensor with Bracket Variations
Original = Plastic
Optional BES Q40-HW-2 = Metal
Sensing distance Sn 15 mm 20 mm 35 mm 40 mm
Bracket Plastic Metal Plastic Metal Plastic Metal Plastic Metal
Yes Yes Yes Yes No No No No
Yes Yes Yes Yes Yes Yes Yes Yes
Basic
information
Yes Yes Yes Yes No No No No Inductive
sensors
Photoelectric
sensors
Capacitive
sensors
Magnetic
cylinder
sensors
Yes Yes Yes Yes No No No No Cables
Materials
IEC Standards
Quality/
Standards
Conversion
Tables
Yes Yes Yes Yes Yes No Yes No
www.balluff.com 967
Adjustable Sensitivity The ability of the sensor to discriminate between different levels of light incidence on the receiver.
Used primarily to black out background objects, discriminate between materials, or transparent objects.
Alarm output The alarm output at the receiver (PNP open collector 30mA) triggers a warning signal in the case
of functional interruptions, which can be caused by contamination or mechanical de-adjustment.
The alarm output is activated if the received signal lies in the alarm range for a dened amount of
time. Stability (green LED)
stable
Alarm
Switching
unstable threshold
stable
For series BOS 18M Teach-in, the entire product family, including diffuse and retrore-
ective sensors, is equipped with an alarm output.
Alignment Relation of the emitter and receiver. Proper alignment is necessary to achieve maximum
sensitivity to objects being sensed.
Ambient Light Light that is present in a given area; e.g., inside, outside, incandescent, or uorescent. In some
cases, ambient light may affect photoelectric controls.
Ambient Light Rejection There are basically 3 different ways for the receiver to differentiate the emitters signal from the ambi-
ent light. As a practical consideration in setting up a system, it is advised to direct the receiver away
from strong external light sources, such as the sun or industrial lighting.
1. Modulation - Pulsed light is different from continuous ambient light.
2. Filters - Filters block most of the visible light spectrum so that a modulated signal is more easily detected.
3. Focal Arrangement - Lenses are used at the emitter and receiver to focus the beam for optimum
signal transmission. This lens arrangement actually makes the image of the emitter focus on the
receiver just like a camera would focus an image on a sheet of lm.
Ambient temperature The ambient temperature is the temperature range in which the function of the photoelectric switch
is guaranteed. Balluff Standard: 15CTa+55C
Amplier A device that enables an input signal to control an output signal of that device.
Analog Sensors The output current or voltage is proportional to the target distance or surface.
Autocollimation Emitter and receiver use a common lens. The emitter light passes Beam splitter
through the beam splitter and the lens to the reector. The reector Emitter
Detection-
bounces the emitter light back to the lens. This gives retroreective area
sensors that work with autocollimation a small, round beam prole.
Lens
Additional benets: no dead zone for scanning and for the reector, Reector
Receiver
better small parts detection, and the switching characteristic is
independent of the approach direction.
Axial Approach When a target to be detected approaches the sensing face head on.
Background suppression (BGS) Through the background suppression, objects within a set switching distance are detected, without
being impeded by the reective background, and nearly independent of color and surface of the ob-
ject (object reection). Background suppression is achieved by cutting the beam from the emitter to
the receiver. To do so, it divides the visible eld into an active area and the background. In addition,
by dividing the receiver into at least two adjacent areas (e. g. by using a dual diode or a PSD- ele-
ment) and by means of a geometric arrangement (triangulation), the actual position of the
object within the sensing range can be determined. Through this, the object and the background
can be distinguished accurately. Diffuse sensors with background suppression are characterized by
low gray value shift and hysteresis.

Beam Pattern In the operation of thru-beam and retroreective sensors, a degree of deviation from absolute align
ment of the emitter and receiver (within which the beam intensity is sufcient to activate the receiver)
determines the beam pattern.
Color Mark Detector A sensor designed to differentiate between different colored marks, or between a color mark and the
background color it appears on. The contrast between the two marks, not the true color of the
mark, is used for this detection. The color mark detector is available with either Red or Green LED
emitters for this purpose.
Color Registration/Mark Detection Proximity (diffuse) sensing mode that detects the contrast between two colors on a surface.
Light Source Code:

G = Green
R = Red
RG = Red or Green
X = not possible
Color Registration Sensor The color registration sensor is a highly specialized diffuse proximity sensor that has the ability to
detect ne changes in contrast on a surface. But unlike the standard diffuse proximity sensor, this
type of unit uses a powerful lens system and must be positioned at a specic focal distance from the target.
Basic
information
Complementary Outputs Sensors with both N.O. and N.C. outputs that change state simultaneously. Inductive
sensors
Component System Separately mounted optical sensing head and amplier used for remote sensing applications. Photoelectric
sensors
Capacitive
Constant Current Source Source which provides constant current to the output of a sensing transistor, and allows the voltage at the sensors
output to vary from zero up to the supply voltage. Magnetic
cylinder
sensors
Contamination Contamination reduces the specied response range of sensors and ber optics compared to clean air, Cables
(inuence on the response range) because the dirt- and dust particles Materials
deposit on the lenses and IEC Standards
impair their light transmission, Quality/
Standards
and absorb and scatter light in the beam path.
Conversion
An oil-free source of compressed air can be used to prevent the effects of dirt and contamination due to impure air. Tables
Contamination indicator The contamination indicator (green) lights in the safe zone if the input energy exceeds the
threshold energy by at least 30%.
The threshold energy, at which a signal change affects the output, is dened at 100%.
From this, the safe zone results
if the input signal exceeds at least 130 % of the
threshold energy
if the input signal exceeds at least 70 % of the threshold energy.
www.balluff.com 969
Contamination indicator The contamination indicator (green) lights in the safe zone if the input energy exceeds the
threshold energy by at least 30%.
The threshold energy, at which a signal change affects the output, is dened at 100%.
From this, the safe zone results
if the input signal exceeds at least 130 % of the
threshold energy
if the input signal exceeds at least 70 % of the threshold energy.
Stability Output
(green LED) (red LED)
stable
Light-on
Dark-on
unstable Switching-
threshold
stable
Correction factors For objects with varying reection characteristics, the range can be determined by using the cor-
(for diffuse sensors) rection factors shown. See the adjacent table.
Correction factor Object, surface

1 Paper, white, matte 200 g/m
1.2...1.6 Metal, shiny
1.2...1.8 Aluminum, black anodized
1 Styrofoam, white
0.6 Cotton fabric, white
0.5 PVC, gray
0.4 Wood, rough
0.3 Cardboard, black, shiny
0.1 Cardboard, black, matte
Current Consumption Maximum amount of current required to properly operate a sensor.
Current Sinking NPN output - an output type such that when it is ON, current ow is from the load into the devices output,
then to ground. Output is normal high. The sensor sinks current from the load through the sensor to
ground. The load is connected between the positive lead of the supply and the output lead of the sensor.
Current Sourcing PNP output - an output type such that when it is ON, current ow is from the device into the load. Output
is normally low. The sensor sources current to the load. The load is connected between the output lead
and the negative ground lead of the supply. Considered safer than NPN outputs due to the way current
ows when wired up.
Dark Operation (Mode) Dark mode output is energized when the target is present (proximity output is energized when target is not detected).
Output mode that will result in an output from a device when light from the emitter is not being received upon the
receiver. The beam is being interrupted, thus creating an output.
Degree of contamination Pure air Ideal conditions

Trace contamination Relatively clean air in indoor rooms
Slight contamination Workshop- and storage rooms
Moderate contamination Dirty and dusty environments; switching distance is

reduced to s = 0.5 su
High contamination Heavy precipitation, whirled-up particles and
swarf: Functional failure of the photoelectric sensor is possible.
Highest contamination Coal dust precipitating on the lens.
Photoelectric sensor function may fail.
Detectable Object Refers to the requirements of an object size, reection qualities, light transmission properties, in order for that object
to be detected by the photoelectric sensor.

Differential The distance between the operating point and the release point as the target is moving away. It is expressed as ei-
ther a linear dimension or in number of degrees. The distance between the operating points where the target enters
the sensing eld (sensor energizes) to the release point (sensor re-energizes).
All discrete sensing technologies must have a differential. In some technologies, differential occurs as a by-product of
the basic laws of physics; however, in other technologies it must be manufactured through additional circuitry.
Photoelectrics - The distinctive property of a photoelectric sensor that results in the operation point being different
from the release point. This distance is expressed as a % of the total sensing distance of the photoelectric sensor. It
is the distance difference between the operating point when approaching the photoelectric and the release point
when moving away from the photoelectric.
Diffuse Where the unit senses the light directly from the target. The emitter and receiver are in the same housing, the same
as retroreective; however, the receiver is more sensitive to the weaker light that is diffused by the surface of the target.
Directional Angle The angular range within which an emitter, receiver, emitter/receiver pair or reector can be rotated
or shifted about on the optical axis and still have the photoelectric properly operate.
Double Pole Double Throw (DPDT) Sensors that make and break two separate circuits. This circuit provides a normally open and
normally closed contact for each pole.
Dynamic Optical Window Thru-beam sensors in an array used to detect moving parts in a conned operating space while
ignoring non-moving parts.
Effective Sensing Distance This is the actual sensing distance realized by the sensor installed in the actual application. The ef-
fective sensing distance will be no less than the usable sensing distance, and is usually closer to the
nominal in average circumstances.
Emitter A device that emits light when an electric current is passed through it. Emitters can give off visible
light (red, green, blue, white) but the majority used for industrial applications emits invisible electro-
magnetic waves (infrared).
Basic
information
Emitter light Photoelectric sensors use mainly the following transmission components: Inductive
Red light LED: Visible light, well-suited as an orientation aid and for sensor adjustment. sensors
Infrared LED (IR): Invisible beam with high energy. Photoelectric
sensors
Red light laser: Visible light, optimal for detecting small parts and high ranges due to the physical
Capacitive
properties of the laser. sensors
Magnetic
cylinder
sensors
Cables
Materials
IEC Standards
Quality/
Standards
Conversion
Tables
www.balluff.com 971
Excess Gain The measure of light energy striking the receiver above the threshold required to activate the reeiver.
Excess gain is used to predict the performance of optical sensors in various environments.
Excess Gain Ratio Maximum light available at a given distance. Level of light intensity needed to operate the photoelectric sensor.
Fiber Optic Cables Optical conductors are made of glass or plastic with a diameter of as little as 50 m and bunched
in bundles of several hundred individual bers to form so-called ber optics. The ber ends are
ground and polished to meet the quality criteria of the optical industry.
The individual bers are coated with a very thin layer of lubricant. This reduces friction against the
outer jacket and between the bers, so that broken bers are prevented even when the cable is
continuously exed. The transmission properties are guaranteed through this over a long span of
time.
The ends of the bundles are potted with the connection sleeve and the jacket. Balluff ber optics
thus have an IP 67 rating (IP 65 for metal jacket). Moisture and aggressive media cannot hurt either
the bers or the slide coating, so the optical properties remain unaffected.
This design distributes axial pull forces evenly over all the bers, and protects the individual bers
from excessive pull loads.
Polyurethane jacket Metal jacket

Temperature T=+85C Temperature T=+150C
Excellent chemical resistance Resistant to hot swarf
Flexible Flexible
No embrittlement from oils and cooling emulsions. Crush-resistant
Corrugated metal tube, silicon jacketed

Temperature T=+150C
Highly exible
Crush-resistant
Can be sterilized.

Fiber Optic Sensing The use of ber optic cables and a ber optic amplier to remotely sense in either a conned location or an
environment that a normal sensor will not function (High temperatures, chemicals).
Fixed Focus A diffuse reective photoelectric sensor that the optical axis of the emitter and receiver is adjusted to a focal
point or it utilizes an aperture to focus on an area in front of the sensor.
Focusable Diffuse A diffuse reective photoelectric sensor that either allows the optical axis of the emitter and receiver to be
adjusted to a focal point or it utilizes an aperture to focus on an area in front of the sensor.
Fork sensor Fork sensors are through-beam designs in which the emitter and receiver are arranged across from
each other in a U-shaped housing. Through the housing type, alignment and electrical connection
are simplied. Different ranges are available by selecting different housing congurations. Fork
openings of 5...220 mm are possible in various increments. The built-in potentiometer and apertures
allow you to adjust the fork sensors easily for detecting parts down to a diameter of 60 m.
Gray value shift Gray value shift is the switching distance difference when calibrating using different object
reectivities. The sensor is calibrated for a distance using a Kodak-gray card with 90 % reection.
With the Kodak-gray card with 18 % reection, the distance achieved with it is measured. The
difference between these two switchpoints in % is referred to as the gray value shift. The smaller the
gray value shift, the more color-independently the sensor operates.
Hysteresis The distance between the operating point and the release point as the target is moving away in order to make
a precise determination of target presence without factors of the environment intervening to create a noisy
output signal. (see Differential)
Interface Translates the presence of a target into an electrical signal.
Internal Reection Internal reection occurs whenever a light ray strikes the surface of a medium whose refractive index is less
than that of the medium in which the light is traveling. An example of this is a light source in water, where light
is internally reected from the surface of air. The amount of light that is reected depends upon the angle at
which it hits the surface. The critical angle is 49. At this angle the ray of light is completely contained within
the medium. Basic
information
Inductive
sensors
Lasers, laser class The purpose of laser protection classes is to protect persons from laser radiation by specifying limit Photoelectric
sensors
values. Based on this, the lasers used are classied according to a scale reecting the degree
Capacitive
of hazard. The calculations and associated limit values relevant for the classication are described in sensors
the standard EN60825-1:2001-11. The grouping is based on a combination of output power and Magnetic
wavelength, taking into account emission duration, number of pulses and angle extension. cylinder
sensors
Cables
Balluff sensors work in the following laser protection classes: Materials
Class 1: Not dangerous, no protective measures. IEC Standards
Class 2: Low output, lid-closing reex sufcient for protection. Quality/
Standards
With devices of protection class 2, the eye closes on its own due to
Conversion
the lid closing reex before it has been open to the beam for too long. Laser warning signs on the Tables
device and possibly also on the machine in which a laser is being used are sufcient. Additional
protective measures are not required. When using devices of protection classes 1 and 2, no laser
safety ofcer is necessary in the company.
Lateral Approach When the target to be detected approaches the sensing face from the side (slide by).
Leakage Current The amount of current that ows through, or leaks from, the output of an energized device when the device
is in the OFF state. Most common problem involves leakage current when a device is wired as an input to a
programmable logic controller. Leakage current should be less than 1.7mA.
LED (Light Emitting Diode) Solid state device that produces visible red, green or yellow light or invisible infrared light radiation. Indicator
on a sensor that emits visible light to show operation of the unit. Infrared types are used for emitters. Red or
green types are used also as emitters in special applications (polarized, plastic ber optics, etc.)
www.balluff.com 973
Light Incident The condition met when light from the emitter is reaching, or incident upon, the receiver.
Light Interrupted The condition met when light from the emitter is not reaching, or incident upon, the receiver.
Light Operation (Mode) Light mode output is energized when the target is not present (proximity output is energized when target is
detected).
Thru-beam & Diffuse sensor

retro sensor
Light-on Normally closed Normally open
Dark-on Normally open Normally closed
Output mode that will result in an output turning ON when light from the emitter is incident upon the receiver.
Light Refraction Light beams experience a change in direction (interruption) at the

border between two optical media with different optical
thicknesses(e.g. glass/air). The degree of interruption depends on
n
the quotients of the optical thicknesses of both media and on the reectio
Total
angle of incidence Hto the optical axis.
If a light beam travels from a dense medium, n, into a thinner one,

n, its course there will show a greater angle H. However, above
Hcrit. (boundary angle at which the broken beam runs parallel to the
boundary layer), it again enters the medium with the
thickness n; this means that a total reection is pending.
Light Source Type of light used in the emitter portion of the photoelectric. Most common, pulse modulated LED or
incandescent lamp.
Light transmission Without the total reection at boundary layers described above,
by total reection ber optics of todays quality would not be feasible. They consist of
a cylindrical, light-conducting core and a surrounding thin-wall
jacket. The optical density n of the core is greater than that of the
jacket. A light beam is always completely reected at the junction
between core and jacket, and can therefore never leave the core in
a radial direction. Theoretically, the light is not weakened by these
reections; however, contamination and small defects both in the
core material as well as the boundary layer do cause losses
(attenuation) and effectively limit the ber optic length over which
reliable information can be transmitted.
Line-Powered Sensor A sensor that draws its operating current directly from the line. Its operating current does not ow through
the load, and a minimum of three (3-wire) connections is required. A 4-wire has complimentary outputs and
requires four connections.
Loads There are basically two different kinds of loads:

Resistive - Lamps, heaters, solid state PLC input modules
Inductive - Relays and solenoid valves
Load-Powered A sensor that draws its operating current (leakage current) through the load. The sensor is always in series
with the load and only two connections are required.
Method of Detection Sensing technique used by the photoelectric sensor. Three types - Thru Beam, Retroreective, or Diffuse Reective.

Minimum Load Minimum current that the external load must draw to ensure proper operation of the photoelectric sensor. Most
often associated with standard AC 2-wire devices.
Luminescence To locate invisible marks on objects, so-called luminescent materials (contained in special chalks,
inks, paints etc.) are used which can only be made visible under ultraviolet (UV) light. The uorescent
materials convert the invisible UV light (short wavelength, here 380 nm) into visible light (between
blue 450 nm and dark red 780 nm). This effect is called photoluminescence. The visible light can
then be detected as usual by the receiver component of the sensor.
Maximum Load The most current that can ow through a device continually without damaging the device.
Method of Detection Sensing technique used by the photoelectric sensor. Three types - Thru Beam, Retroreective, or Diffuse Reective.
Minimum Load Minimum current that the external load must draw to ensure proper operation of the photoelectric sensor. Most
often associated with standard AC 2-wire devices.
Modulated LED Pulsations of light at a specic frequency reduce interference from ambient light and increase sensing distance.
Mutual Interference A feature in photoelectric sensors that eliminates false-signaling between similar protection sensors mounted next
to (or in close proximity to) each other.
N.C. (Normally Closed) Current ow through the sensing device is possible only when the device is in the off state or de-energized.
Contacts are closed when the sensor is not operated and when there is no external force on the actuator. The
sensor opens a circuit to the load when a target is detected or sensor is operated.
N.O. (Normally Open) Current ow through the device is not possible when the device is de-energized (turned OFF). Contacts are
open when the sensor is not operated and when there is not external force on the actuator. The sensor closes
a circuit to the load when a target is detected or sensor is operated.
Nominal Sensing Distance The rated operating distance for which the sensor is designed. This value should only be taken as a guide,
since no manufacturing tolerances or changes in external ope

Balluff Object Sensing

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Balluff Object Sensing

Uploaded by

Copyright:

Available Formats

Object Detection

Innovative sensor technology for all areas of automation

Balluff stands for comprehensive systems from a single source,

High-quality, innovative products tested in our own accredited

Whether electronic and mechanical sensors, rotary and linear

Balluff products increase performance, quality and productivity

2 For more information, visit us online!

Inductive sensors 466

Capacitive sensors 768

Magnetic cylinder sensors 850

Industrial networking and connectivity A selection 912

Basic information and denitions 952

4 For more information, visit us online!

8 For more information, visit us online!

News and events Company information

Service and support We are happy to help

Photoelectric Inductive Capacitive

Part recognition and counting Non-contact, wear-free, Non-contact, wear-free,

Page 14 Page 466 Page 768

Magnetic Industrial networking

Can be used universally All bus systems shock and

Page 850 Page 912

14 For more information, visit us online!

Photoelectric standard sensors

Photoelectric special sensors

Photoelectric distance sensors

Special accessories for photoelectric sensors

Checking stack height

Querying the size and content of containers

16 For more information, visit us online!

Checking drill breakage

Detecting a groove Detecting small parts

Querying packaging contents

Querying ll level in transparent containers

Recognizing different Checking sag

18 For more information, visit us online!

Detecting the bead of a camshaft

Checking the quality of workpieces

Counting transparent bottles Checking packaging

20 For more information, visit us online!

Final inspection of labels and caps Inspecting closing caps

Housing material Metal Metal Metal Metal Metal

Diffuse sensor 0...24 mm, 30...150 mm,

Output PNP PNP PNP PNP PNP

22 For more information, visit us online!

10...30 V DC 10...30 V DC, 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC

Housing material Plastic Plastic Metal Metal Metal Plastic

Output function PNP PNP PNP/NPN PNP PNP PNP

Degree of protection as per IEC 60529 IP 67 IP 67 IP 65 IP 67 IP 67 IP 67

24 For more information, visit us online!

Plastic Plastic Plastic Plastic Metal Metal Plastic Plastic Photoelectric

10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC 10...30 V DC,

Housing material Plastic Plastic Plastic Metal Plastic

26 For more information, visit us online!

Plastic Plastic Plastic Plastic Metal Photoelectric

10...30 V DC 11...26 V DC 10...30 V DC 10...30 V DC 10...30 V DC

PNP NPN PNP PNP NPN PNP NPN PNP NPN

Teach-in Teach-in Teach-in Potentiometer Potentiometer

Type BOS 16 K BOS 72 K BMOA BFO BMOA BKT 6K

Housing material Plastic Plastic Plastic Glass, plastic Metal Plastic

Diffuse sensor Depending on

28 For more information, visit us online!

Plastic Metal Metal Plastic Plastic Metal Photoelectric

PNP PNP/NPN PNP/NPN/ PNP/NPN PNP PNP Special
