outline Week1 Assignment
The due date for submitting this assignment has passed. Due on 2017-08-07, 23:59 IST.
How to access
the portal Submitted assignment

Week 1 1) What is the unit of shear stress? 1 point

Lecture 1: N/m3
Introduction N/m2
Lecture 2: N/m
Analysis of N.m
Stress- I
No, the answer is incorrect.
Lecture 3:
Score: 0
Analysis of
Stress- II Accepted Answers:
N/m2
Quiz : Week1
Assignment
2) What is the unit of shear strain? 1 point
Week 1:
Assignment No unit
Solution m
Feedback for m-1
week 1 m2
Week 2 No, the answer is incorrect.
Score: 0
Week 3
Accepted Answers:
No unit
Week 4
3) What is the unit of Young’s Modulus? 1 point
Week 5
N/mm2
Week 6 N/m2
Pa
Week 7
All of the above
Week 8 No, the answer is incorrect.
Score: 0
Week 9
Accepted Answers:
All of the above
Week 10
4) A uniform steel rod, 6mm in diameter and 0.5m long is subjected to a tensile force of 3kN. 1 point
Week 11 Find the stress in the bar and its elongation. (E=200 GPa)

Week 12 106.2 MPa ; 0.5 mm

106.2 MPa ; 0.265 mm
265 MPa ; 0.106 mm
265 MPa ; 0.5 mm
https://onlinecourses.nptel.ac.in/noc17_ce22/unit?unit=5&assessment=14 1/4
07/12/2017 Strength of Materials - - Unit 2 - Week 1
No, the answer is incorrect.
Score: 0
Accepted Answers:
106.2 MPa ; 0.265 mm
5) The length of an aluminium rod of 10 mm diameter and 400 mm length increases to 400.30 1 point
mm when subjected to a tensile force of 3 kN. Find the stress in the bar and the value of Young’s
modulus for the aluminium.

382 MPa ; 510 GPa

38.2 MPa ; 51 GPa
0.38 MPa ; 0.51 GPa
382 MPa ; 0.51 GPa
No, the answer is incorrect.
Score: 0
Accepted Answers:
38.2 MPa ; 51 GPa

6) Determine the maximum shear stress in rivets for the figure shown. P= 25 kN, diameter of 1 point
the rivet= 20 mm.

79.57 MPa
39.7 Pa
79.57 Pa
39.8 MPa

No, the answer is incorrect.

Score: 0
Accepted Answers:
39.8 MPa

7) Find the bearing stress between the bolts and the plates. The thickness of each plate is 10 1 point

mm. P= 25 kN, diameter of the rivets= 20 mm.

62.5 MPa
125 MPa
62500 Pa
125000 Pa
No, the answer is incorrect.
Score: 0
Accepted Answers:
62.5 MPa
8) Determine the resisting shear stress in the rivets. P= 30 kN, diameter of rivets = 1 point
20 mm.

https://onlinecourses.nptel.ac.in/noc17_ce22/unit?unit=5&assessment=14 2/4
07/12/2017 Strength of Materials - - Unit 2 - Week 1

190.9 MPa
47.7 MPa
95.5 MPa
23.8 MPa

No, the answer is incorrect.

Score: 0
Accepted Answers:
47.7 MPa

9) The state of stress at a given point is given as following. Calculate the principal stresses. 1 point

26.2, -2.37, -5.83

16.5, -1.8, 9.3
4.85, -6.31, 8.56
26.2, 4.23, 5.48

No, the answer is incorrect.

Score: 0
Accepted Answers:
26.2, -2.37, -5.83
10)Principal planes are those on which Normal stress is _______ . 1 point

Zero
Maximum
Minimum
Either maximum or minimum

No, the answer is incorrect.

Score: 0
Accepted Answers:
Either maximum or minimum
