MileGate - your access to triple play

Engineering Bulletin

CIMT2
Installation Instruction

MileGate

EN/LZTBU 881 105 RA 1.0 / 11.2007

MileGate
CIMT2 Engineering Bulletin

Title MileGate CIMT2 Engineering Bulletin

Version 1.0 / 11.2007

Copyright and Confidentiality
Copyright in this document vests in KEYMILE GmbH. This document con-
tains confidential information which is the property of KEYMILE GmbH. It
must be held in confidence by the recipient and may not be used for any pur-
poses except those specifically authorised by contract or otherwise in writing
by KEYMILE GmbH. This document may not be copied in whole or in part, or
any of its contents disclosed by the recipient to any third party, without the
prior written agreement of KEYMILE GmbH.

Disclamer KEYMILE GmbH has taken reasonable care in compiling this document,
however KEYMILE GmbH accepts no liability whatsoever for any error or
omission in the information contained herein and gives no other warranty or
undertaking as to its accuracy.
KEYMILE GmbH reserves the right to amend this document at any time with-
out prior notice.

Document Number EN/LZTBU 881 105 RA

The product meets the rules of the conformity declaration at operational con-
ditions that can be considered as normal use.

Published by KEYMILE
Wohlenbergstr. 3
D-30179 Hanover
Tel. +49 (0)511 6747-0
customersupport.de@keymile.com
http://www.keymile.com

© 2.2008 KEYMILE GmbH

MileGate
CIMT2 Engineering Bulletin

Content
CIMT2 - Cable Impedance Matching Transformer 2-Pair 5

CIMT2 - Characteristics 5

Prerequisites 7

Installation 7

Warnings

Danger of electric shock.

The device can be connected to perilous voltages.

Caution £ Switch the device to power-off state before working on the device.

Danger of electrostatic discharge

Electronic components are sensitive to electrostatic discharges that might

Caution destroy the device.
£ Make sure to deviate electrostatic charges from your body; we recom-
mend that you were an electrostatic wristband.

Interruption of data transmission.

Data transmission will be interrupted during any workings at the transmis-

Caution sion line and/or deactivation of the power supply.
£ Make sure that that any workings will only be carried out on inactive
lines (without data transmission) or during quiet times to reduce interfe-
rences for the customers.

Danger of damage on the devices or service interruption.

Any access of unauthorized third persons may cause damaged devices

Caution and/or interrupted services.
£ Make sure that subracks are only installed in lockable loacations.

Danger by overvoltage.

During faults unprotected voltages may occur that are dangerous to per-
Caution sons.
£ Take care for sufficient grounding of the housings, i.e. by connecting
the grounding contact.

© 2.2008 KEYMILE GmbH

MileGate
CIMT2 Engineering Bulletin

© 2.2008 KEYMILE GmbH

 CIMT2 - Cable Impedance Matching Transformer 2-Pair © KEYMILE
CIMT2 - Characteristics

1 CIMT2 - Cable Impedance Matching Transformer

2-Pair

Fig. 1: CIMT2: Front and rear view

CIMT2 is a matching transformer that is employed for SHDSL transmission.

CIMT2 transforms the impedance for copper pairs by the factor 1.13.
The SHDSL transmission systems (e.g. STIM1, LineRunner LCM/DTM) are
optimised for lines as mentioned in the ITU-T Recommendation G.992.1
which suggests a line impedance of 135 Ohms.
If impedance is higher then transmission quality may deteriorate so that no
signal can be transmitted reliably.
In some cases CIMT2 may help as it transforms the impedance to fit the
standard even on non-standard cables.
Non-standard cables have been found at power suppliers and railway com-
panies.

1.1 CIMT2 - Characteristics

CIMT2 - Characteristics
Characteristics Remark
Installation on a top-hat rail
Article number of the device 37971506
Copper pairs 1 ... 2
Power supply none - passive component
Temperature range - 40 to +85 °C
Relative humidity 0 to 98% non-condensing
MTBF > 75 years
Impedance matching 1: 1.13 (e.g. 135 ohms to 174 ohms) (from in to out)

MileGate - CIMT2 Engineering Bulletin EN/LZTBU 881 105 RA | 2.2008 5

 CIMT2 - Cable Impedance Matching Transformer 2-Pair © KEYMILE
CIMT2 - Characteristics

CIMT2 - Characteristics
Characteristics Remark
Dimensions h * w * d (mm) 96 * 38 * 48
Voltage range 0 to 160 VDC
maximum wire diameter 2.26 mm (4 mm²)

First line

IN1 OUT1

IN2 OUT2

Second line
Fig. 2: Jacks to CIMT2 with first and second line pair.

Contacts
Jack Purpose
In 1 1. Copper pair for connection to the local terminal device - the impedance
of this wire is too low. This jack is connected to jack Out 1.
In 2 2. Copper pair for connection to the local terminal device - the impedance
of this wire is too low. This jack is connected to jack Out 2.
Out 1 1. Wire pair for connection to the remote terminal device on cables with high
impedance. This jack is connected to jack In 1.
Out 2 2. Wire pair for connection to the remote terminal device on cables with high
impedance. This jack is connected to jack In 2.

6
MileGate - CIMT2 Engineering Bulletin EN/LZTBU 881 105 RA | 2.2008
 CIMT2 - Cable Impedance Matching Transformer 2-Pair © KEYMILE
Prerequisites

1.2 Prerequisites

Devices of the type CIMT2 have to be installed at the end of the transmis-
sion line with high impedance - for this reason you need two devices for
point-to-point connections.
Devices of the type CIMT2 require a mounting rack with top-head rails or a
suitable mechanical adapter.
You need the following materials:
Required materials
Material Purpose
Top-hat rail CIMT2 can only be fixed reliably on top-hat rails. Other instal-
lation locations are not permitted
CIMT2 One unit of the type CIMT2 is required for each two copper
pairs.
It is allowed to connect only one copper pair.
If you connect only one copper pair the other pair of connec-
tors may be employed for the copper pair of a further device.
Transmission line to This transmission line can be maximum copper pair. The
the local terminal impedance of this line is nominal 135 ohms
device
Transmission line to This transmission line can be maximum one copper pair. The
the remote terminal impedance of this line is nominal 174 ohms
device
Slotted screwdriver To unfix and fix the screws in the screw terminals at the
3 mm device.
Stripper To skin the ends of the transmission lines if necessary.
Wire cutter To reduce the transmission line if necessary.
Planning documents Show the transmission lines affected and which copper pairs
belong to a transmission line.
Isolation material To insulate free cable ends during working steps in order to
prevent short voltages.

1.3 Installation

Proceed as follows:
1. Affix CIMT2 on hat rail.
2. Repeat for each of the connectors:
3. Remove isolation from transmission line.
4. Insert wire with low impedance into In 1 and the other in In 2.
5. Tighten screws.
6. Insert wire with high impedance into Out 1 and the other in Out 2.
7. Tighten screws.

Impedance adapter is installed.
