Turbo Commander Engine Maintenance Information: Authorized Service Center

Turbo Commander
Engine Maintenance
Information
www.cdaviationservices.com
Authorized Service Center

CD Aviation Services is a Honeywell
Authorized repair facility specializing in the TPE
331 series engine. CDAS has been in business
for nearly 20 years and offers you the experience
that is required to cost effectively maintain your
turbine engine.
CDAS understands that important
maintenance decisions must be made with
knowledge and trust. Understanding your
operation and requirements is the key that
unlocks a wide array of CDAS value add
programs.
From on-site training to industry leading
customer support, CDAS offers reliable
maintenance solutions that will immediately
benefit the value of your aircraft.
• FAA, Transport Canada, EASA, and Argentine
DNA approved repair facilities
• Honeywell Authorized
• FAA Diamond Award Facility
• Repair through Overhaul Capability
• Multiple test sites
• Field Service
• EMT (Engine Maintenance Training)
Familiarization
Line Training
Custom
• Silver Sky
Superior Customer Support System
• Rental Engines
• Trouble Shooting
• LRU Support
Engine maintenance is the single largest

cost associated with your aircraft.
CD Aviation Services has compiled

this informational booklet as a quick
reference of the scheduled maintenance
and life limited components of your
Honeywell (Garrett) TPE 331 engine.
This is only a reference, the type certification as well as manufacturer’s

approved service bulletins should be referenced for all maintenance actions.
Definitions:
Cycle - Any operating sequence involving engine start, aircraft
takeoff and landing, engine shutdown.
Hour - Any time the engine is operated in flight. (Liftoff to touch-

down.)
TBO - Time Between Overhaul, the amount of time between

scheduled overhaul maintenance actions as recommended by
the manufacturer.
Hot Section Inspection (HSI) - The scheduled disassembly,

inspection and assembly of the turbine section as defined by the
applicable engine maintenance manual.
Gearbox Inspection (GBI) - The scheduled disassembly inspection

and assembly of the gearbox section as defined by the
applicable engine maintenance manual.
TPE 331-10 Engines
Please contact CD Aviation Services for any questions or
quotations regarding any engine related maintenance or
troubleshooting.
Maintenance Action 3600 5000 5400 7000
Hot (Turbine) Section Inspection 1800 2500 1800 3500
Gearbox Inspection 3600

3500
Overhaul and Functional Test Engine 3600 5000 5400 7000
Fuel Control Bendix 3600 5000 5400 5400
Fuel Control Woodward Pre 73-0254, 0262 3600 5000 5400 6000
Fuel Control Woodward Post 73-0254, 0262 3600 5000 5400 7000
Fuel Pump 3600 5000 5400 7000
Fuel Shutoff Valve 3600 5000 5400 7000
Propeller Governor 3600 5000 5400 7000
Propeller Pich Control 3600 5000 5400 7000
Torque/ Temperature Limiter Bypass Valve 3600 5000 5400 7000
Inlet Sensor - Bendix 3600 5000 5400 5400
Start Pressure Regulator - Bendix 3600 5000 5400 5400
Manufacturer recommend TBO and maintenance intervals and

cycle limits in accordance with Service Bulletin 72-0180 latest rev.
TBO and maintenance intervals specified in this service bulletin
are the manufacturer’s approved intervals. Individual commercial
operators may extend these intervals with the approval of their
local FAA or appropriate airworthiness regulating authority.
ALWAYS REFERENCE APPLICABLE HONEYWELL MAINTENANCE MANUAL
For Reference Only
TPE 331-10 Engines
troubleshooting.
Cycle Life Limit Items Cycle Limit
1st Stage Turbine Wheel - 3101520-1,-2 10000
1st Stage Turbine Wheel - 3101520-3, 3107079-1 20000
2nd Stage Turbine Wheel - 3102106-6 4800
2nd Stage Turbine Wheel - 3102106-9,-10 15000
3rd Stage Turbine Wheel - 3102655-1 4800
Seal Plate - 3102483-1, 3101515-4 20000
1st Stage Impeller - 3108182-2 30000
1st Stage Impeller - 896223-X (with known CSN) 25000
1st Stage Impeller - 896223-X (with unknown CSN)
Reference SB A72-0971 & SB A72-2083
2nd Stage Impeller 3108387-1 30000
2nd Stage Impeller 3107167-1,-2,-3,-4,-5 10500
Certain service bulletin and other conditions could apply. Please

contact CD Aviation Services for logbook review: 417-206-CDAS (2327)
For Reference Only
TPE 331-10 Engines
troubleshooting.
Daily/ Each Each Each Each Each Each Each
Pre- 100 150 200 300 400 800 900
Inspection Flight Hour Hour Hour Hour Hour Hour Hour
Air Inlet - Check for FOD X
Air lnlet & Exhaust, check for oil leak,

X
compressor and turbine air-oil seals
Oil level must be above add mark X
Starter Generator Spline - Inspect and

X
lube, pre SB72-0416, Initial inspection
Fuel Filter X
Input Gearbox Drain X
Compensating Resistor - Test temp

X
comp value
Oil Filter - Perform SOAP Except 7000

X
TBO
Oil Filter—Perform SOAP 7000 TBO X
First Stage Impeller - Inspect FOD X
Emergency Shutdown Systems -

Operate air-frame emergency feather/
fuel shutoff systems to determine if X
engine feathering valve and FSOV have
actuated.

X
lube, Pre SB72-0416
Fuel Control/Fuel Pump Integrity - (Pre

X
SB 73-0127 or 73-0131)
Overspeed Governor - Operational

X
Check, (TPE331-10-511K)
For Reference Only
TPE 331-10 Engines
troubleshooting.
Pre- 100 150 200 300 400 800 900
Overspeed Governor - Operational

X
Check, (TPE331-10-511K)
Fuel Manifold Purge System Filter -

X
Remove, clean
Plenum Drain Valves - Check operation

X
with-out removing from engine
Engine Oil, Type I only - Change X
Plumbing lines and connections X
Electrical Wiring and Connections X
Controls Linkage Assembly - Inspect,

X
lube rod end bearings if binding
Magnetic Drain Plug - Remove and

X
inspect
Igniter Plugs - Remove, clean, inspect X
Torque Limiter (Fuel Bypass) Valve Filter

X
- Remove and clean
Fuel Flow Divider Valve Filter - Remove,

X
clean, inspect
Starter Generator Drive Spline - Post

X
SB72-0416
Tachometer Generator Drive - Inspect

X
and lube (pre SB 72-0486)
Fuel Manifold and Nozzle Assembly -

X
Clean and Flow
Plenum Drain Valves - Remove and test

X
for closing and opening
Engine Oil, Type II Only - Change X
For Reference Only
TPE 331-5 Engines
Maintenance Action 3600 TBO 5400 TBO 6000 TBO
Hot (Turbine) Section Inspection 1800 1800 3000
Gearbox Inspection 3600 3000
Overhaul and Functional Test Engine 3600 5400 6000
Fuel Control Bendix 3600 5400 5000
Fuel Control Woodward 6000
Fuel Pump 3600 5400 6000
Fuel Shutoff Valve 3600 5400 6000
Propeller Governor 3600 5400 6000
Propeller Pitch Control 3600 5400 3000
Torque/ Temperature Limiter Bypass Valve 3600 5400 6000
Inlet Sensor - Bendix 3600 5400 5000
Start Pressure Regulator - Bendix 3600 5400 5000
SOAP 205 MAX
Functional test accessories and / or
electronic components IAW EMM 6000
Cycle Life Limit Items Cycle Limit
1st Stage Turbine Wheel - 867569-1,-7 5700
1st Stage Impeller - 896223-X
(with known CSN) 25000
1st Stage Impeller - 896223-X
(with unknown CSN)
Reference SB A72-0971 & SB A72-2083
Certain service bulletin and other conditions could apply. Please contact
CD Aviation Services for logbook review: 417-206-CDAS (2327)
Manufacturer recommend TBO and maintenance intervals in accordance

with Service Bulletin 72-0404 latest rev. and cycle life limits in accordance
with SB 72-0019 latest rev. TBO and maintenance intervals specified in
this service bulletin are the manufacturer’s approved intervals. Individual
commercial operators may extend these intervals with the approval of their
local FAA or appropriate airworthiness regulating authority.
TPE 331-5 Engines
troubleshooting.
Pre- 100 150 200 300 400 600 900
Air Inlet - Check for FOD X
Air lnlet & Exhaust, check for oil leak,

X
compres-sor and turbine air-oil seals
Oil level must be above add mark X
Fuel Control/Fuel Pump Integrity

X
Inspection, Verify P/N
Fuel Filter X
Oil Filter SOAP Sample X
Compensating Resistor - Test temp

X
comp value
Input Gearbox Drain X

X
lube, pre SB72-0416
First Stage Impeller - Inspect FOD X
Air Anti-Ice Valve (319980-5-1 only)

X
remove, disassemble, inspect
Emergency Shutdown Systems -

Operate air-frame emergency feather/
fuel shutoff systems to determine if X
engine feathering valve and FSOV have
actuated.
P3 Air Filter - Remove, clean, inspect

X
(Codes AA-CC)
For Reference Only
TPE 331-5 Engines
Pre- 100 150 200 300 400 600 900
Overspeed Governor Check X
Plumbing lines and connections X
Electrical Wiring and Connections X
Magnetic Drain Plug - Remove and
X
inspect
Igniter Plugs - Remove, clean, inspect X
Fuel Manifold Purge System Filter -
Remove, clean, inspect (Codes AB-GA, X
CB-FB)
Flow Divider and Drain Valve Filter -
X
Remove, clean, inspect
Controls Linkage Assembly - Inspect,
X
lube rod end bearings if binding
Plenum Drain Valves - Check operation
X
without removing from engine
Torque Limiter (Fuel Bypass) Valve Filter
X
- Re-move and clean
Fuel Manifold and Nozzle Assembly -
X
Clean and Flow
Fuel Pump Assembly Drive Coupling -
Inspect and lube, (Codes DA-FB, pre X
72-0104/73-0051)
Fuel Pump Assembly Drive Coupling -
Inspect and lube, (Codes AA-CC, pre X
72-0104/73-0054)
Pneumatic Tube Assembly Flares
and Sleeves - Inspect for cracks or X
corrosion.
Tachometer Generator Drive - Inspect
X
and lube (pre SB 72-0486)
Direct Drive Fuel Control Backlash
X
Inspection - (Codes AA, AB, CA)
Engine Oil, Type I only - Change X
Plenum Drain Valves - Remove and test
X
for closing and opening
Engine Oil, Type II Only - Change X
For Reference Only
Contacting CD Aviation Services
World Wide Support
CD Aviation Services
2707 East 32nd Street - Suite 2
Joplin, Missouri 64804
United States
Phone: 417-206-CDAS (2327)
990 McTavish Road N.E.
Calgary, Alberta T2E 7G6
Canada
Phone: 403-769-1550
Rodvingevagen 11
613 37 Oxelosund
Sweden
Phone: 46-8559255266

Turbo Commander Engine Maintenance Information: Authorized Service Center

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Turbo Commander Engine Maintenance Information: Authorized Service Center

Uploaded by

Copyright:

Available Formats

Turbo Commander

Authorized Service Center

Authorized Service Center

Authorized Service Center

Engine maintenance is the single largest

CD Aviation Services has compiled

This is only a reference, the type certification as well as manufacturer’s

Hour - Any time the engine is operated in flight. (Liftoff to touch-

TBO - Time Between Overhaul, the amount of time between

Hot Section Inspection (HSI) - The scheduled disassembly,

Gearbox Inspection (GBI) - The scheduled disassembly inspection

Hot (Turbine) Section Inspection 1800 2500 1800 3500

Gearbox Inspection 3600

Overhaul and Functional Test Engine 3600 5000 5400 7000

Fuel Control Bendix 3600 5000 5400 5400

Fuel Pump 3600 5000 5400 7000

Fuel Shutoff Valve 3600 5000 5400 7000

Propeller Governor 3600 5000 5400 7000

Propeller Pich Control 3600 5000 5400 7000

Torque/ Temperature Limiter Bypass Valve 3600 5000 5400 7000

Inlet Sensor - Bendix 3600 5000 5400 5400

Start Pressure Regulator - Bendix 3600 5000 5400 5400

Manufacturer recommend TBO and maintenance intervals and

1st Stage Turbine Wheel - 3101520-1,-2 10000

1st Stage Turbine Wheel - 3101520-3, 3107079-1 20000

2nd Stage Turbine Wheel - 3102106-6 4800

2nd Stage Turbine Wheel - 3102106-7 9600

2nd Stage Turbine Wheel - 3102106-9,-10 15000

3rd Stage Turbine Wheel - 3102655-1 4800

3rd Stage Turbine Wheel - 3102655-2 6000

Seal Plate - 3102483-1, 3101515-4 20000

1st Stage Impeller - 3108182-2 30000

1st Stage Impeller - 896223-X (with known CSN) 25000

1st Stage Impeller - 896223-X (with unknown CSN)

Reference SB A72-0971 & SB A72-2083

1st Stage Impeller - 3107110-2 9600

2nd Stage Impeller 3108387-1 30000

2nd Stage Impeller 3107167-1,-2,-3,-4,-5 10500

Certain service bulletin and other conditions could apply. Please

Air Inlet - Check for FOD X

Air lnlet & Exhaust, check for oil leak,

Oil level must be above add mark X

Starter Generator Spline - Inspect and

Input Gearbox Drain X

Compensating Resistor - Test temp

Oil Filter - Perform SOAP Except 7000

Oil Filter—Perform SOAP 7000 TBO X

First Stage Impeller - Inspect FOD X

Emergency Shutdown Systems -

Starter Generator Spline - Inspect and

Fuel Control/Fuel Pump Integrity - (Pre

Overspeed Governor - Operational

Overspeed Governor - Operational

Fuel Manifold Purge System Filter -

Plenum Drain Valves - Check operation

Engine Oil, Type I only - Change X

Plumbing lines and connections X

Electrical Wiring and Connections X

Controls Linkage Assembly - Inspect,

Magnetic Drain Plug - Remove and

Igniter Plugs - Remove, clean, inspect X

Torque Limiter (Fuel Bypass) Valve Filter

Fuel Flow Divider Valve Filter - Remove,
