Digital and Logic Design

Lab-8

Revision Lab

Faculty of Information Technology UCP Lahore Pakistan


Lab Tasks

Task#1

a) Draw the symbol Diagram of the following


i. AND
ii. NAND
iii. OR
iv. NOR
v. XOR
vi. XNOR
b) Complete the following Truth table for 2-input Gates. (Insert more rows in the
given table if needed.)

Ref# A B A.B A´. B A+B ´


A+B A B A´ B

c) Complete the following Truth table for 3-input Gates. (Insert more rows in the
given table if needed.)

Ref# A B C A.B.C A . B´ . C A+B+C ´


A+ B+C A B C ´
A BC

Task#2

a) Write down the names of all universal gates with their symbols and Boolean
expressions on paper ONLY.
b) Implement the two Input AND Gate using NOR Gate on circuit maker.
c) Implement the two Input OR Gate using NOR Gate on circuit maker.
Task#3
F(A,B,C) = ∑ (1,3,5,6,7)

a) Write down the standard SOP of given Function F(A,B,C).


b) By using k-map, write down the minimized SOP of given Function F(A,B,C).
c) Draw the Standard and minimized form on circuit maker.
Task#4
Consider the given table for the task.

Inputs Outputs
Ref # A B C X Y
0 0 0 0 0 1
1 0 0 1 1 0
2 0 1 0 1 1
3 0 1 1 0 0
4 1 0 0 1 1
5 1 0 1 0 0
6 1 1 0 1 0
7 1 1 1 0 1

a) Write down the canonical forms of both X and Y.


b) Express the Standard forms of both X and Y.
c) By using k-map, write down the minimized SOP of both X and Y.
d) Draw the Standard form and minimized forms on circuit maker. (For both X and Y)

Task#5

a) Draw a truth table for full adder. Clearly mention inputs and outputs.
b) Write the SOP and POS Expression.
c) Write the Minimized POS using K-Map grouping technique.
d) Using the above truth table design and implement full adder on Circuit Maker and
verify the results.

Task#6

a) Reduce the Boolean expression given below (on page)

F (A,B,C) = Á B́ Ć + Á B́ C + A B́ Ć + A B́ C+ A B Ć+ A B C

b) Create and fill the table for both expressions (given and reduced)

c) Implement both the expressions (given and reduced) in Circuit Maker with same inputs
(only three common inputs A, B and C) and verify your results

Task#7
a) Draw a truth table for full adder. Clearly mention inputs and outputs.
b) Write the SOP and POS Expression.
c) Write the Minimized SOP using K-Map using grouping technique.
d) By using standard SOP, implement full adder on Circuit Maker and verify the results.
e) By using minimized SOP, implement full adder on Circuit Maker and verify the results.
NOTE: Use single Circuit for both SUM and CARRY.
