 What I Need to Know

Good day, learner! This is another journey of fun, learning, and adventure.
While you are in the comforts of your home, you can still learn concepts that you can
apply in real-life situations. It takes courage, passion, dedication, and determination
to learn concepts and ideas in this new normal.

Are you ready to learn things anew? Very Good! Prepare yourself and enjoy
the knowledge and skills that you will be learning in this module. Let us start!

Have you already learned some of the electrical requirements and guidelines
on installation, maintenance, and different techniques on reading electrical
quantities which includes the Ohm’s Law, actual circuit testing, and color coding?

Remember, quantities matter. Reading and calculating them also matters, too.
Do you know how to read measurements, use measuring instruments and other
technique on reading electrical quantities? In this module, you will value electrical
interpretation and reading, the use of measuring, and testing instruments as per job
requirements.

This module contains a step-by-step procedure on how to calculate, read, and

recognize every quantity in the circuit relative to resistance. It also contains learning
activities to exercise and enhance your ability to read and calculate measurements.

After going through this module, you are expected to:

a. read measurement in terms of resistance using Ohm’s Law, color
coding, and volt-ohmmeter (TLE_IA EI 9-12 EP-Ia-j-1)

Are you now ready to activate your prior knowledge? Proceed to the next page
and answer the questions. Good luck!

1
 What I Know

Before we will start with our lesson, let us activate your prior knowledge on
some of the electrical terminologies needed in electrical reading or testing in wiring
installation by answering the following questions. Are you ready? Get your answer
sheet. Good luck!

Directions: Choose the letter of the correct answer and write your answer on your
activity notebook.

1. A circuit with 220v has bulbs are connected on it. However, the bulbs become
dim. How much resistance is opposing with in the bulbs with 2-amp current flow?
a. 110 Ω c. 210 Ω
b. 200 Ω d. 220 Ω

2. The ceiling fan has 15-amp current that flows in a 220v supply load. If you will
determine the resistance of the circuit, how much will you get?
a. 15 Ω c. 22 Ω
b. 20 Ω d. 220 Ω

3. In measuring resistance using 4 band-color-code, what is the reading of white,

black, brown, brown?
a. 90 Ω + 1% c. 900 Ω + 1%
b. 900 Ω + 5% d. 90 Ω + 5%

4. Which of these is the use of tolerance?

a. plus, minus 1% c. minimum to maximum
b. mathematical equation d. percentage

5. Which is used to measure the voltage, resistance, and current of a circuit which
is connected in parallel or series with the circuit depending on what to measure?
a. Ammeter c. Ohmmeter
b. Micrometer d. Volt-Ohmmeter

6. Which unit of measurement is used in measuring resistance?

a. amperes c. volts
b. ohms d. watts

7. In measuring resistance in a circuit, which should be your testing probe?

a. series to the load c. across the terminals
b. parallel to load d. series to the terminals

2
8. In reading measurements of ohms in volt-ohmmeter, the first to 20 is counted
by______.
a. 1 b. 2 c. 3 d. 4

9. In reading of resistance (ohms) in volt-ohmmeter, the measurement 100 to 200 is

counted by______.
a. 10 b. 20 c. 30 d. 40

10. In reading of ohms in volt-ohmmeter, the measurement 20 to 50 is counted

by______.
a. 1 b. 2 c. 3 d. 4

11. In reading of ohms in volt-ohmmeter, the measurement 50 to 100 is counted

by______.
a. 10 b. 20 c. 30 d. 40

12. Which instrument is used to measure the current opposition resistance in a

circuit?
a. ammeter c. ohmmeter
b. kilometer d. voltmeter

For items 13-15, write TRUE on the blank if the statement is correct and FALSE if it
is not.

____________________ 13. To find resistance, the formula to be used is R = E x I.

____________________ 14. The resistance of a simple circuit having a 0.20 ampere

current flow in a 220-power supply is 1, 000K Ω.

______________________ 15. The infinity symbol means shorted.

How was it? Did you get all the correct answers? If you got most of the answers
correctly, then you are ready for this module you are sure that you can do other
lessons and activities. Remember that before you comprehend, you will first know
how to read, know different approaches, and apply measurements and calculations
for the most competencies. You will learn more about these in this module. Let’s
start!

3
 Lesson Reading Measurements
1 in Terms of Resistance

Hey, you are pretty sure that your pair of shoes fits on you. Why? Because it
is your size. Therefore, size and measurements matter. They give critical information
for a purpose. In electricity, reading measurements of the three electrical quantities
matters a lot on electrical installation, maintenance, and the value of accurate
reading calculation on resistance.

What’s In

Each time, as we conduct various tasks on installation, maintenance, and

repair, we conduct the measurement or testing technique on reading the three
electrical quantities needed per job requirement.

Activity 1 - Hey Dude!

Directions: The illustration represents the functions of each electrical quantity -

voltage, current, and the resistance. Study the text below and write your answers in
your activity sheet.

inlet→

Assume that the pipeline is the electric current carrying wire. Look!
Somewhere near the entrance is a leak, and further ahead is a “U” trap. These two
conditions in the pipeline affects the water flow. These factors represent (1)
___________ . At a straight pipeline, water flows in a normal flow in the pipe, which
may represent the (2) _____________ while the water pressure pushed in the pipe
represents (3) ____________________.

4
 Notes to the Teacher
Being a facilitator to this module, you have to emphasize the
accuracy of reading or calculating electrical quantity such as
resistance. Remind your learners to focus on solving, calculating,
and remembering. Better encourage them to use calculators to be
more accurate.

What’s New

Your journey continues! Speaking of journey, have you felt a force against
your car or motorcycle? What is it all about? Do you have any idea? It is the
resistance from air.

On the other hand, resistance in electricity is the opposition of current flow.

The normal flow is current and the pressure of flow is called voltage. These three are
interrelated with one another.

Before learning the concepts relative to resistance and how to read its
measurement using Ohm’s Law, color coding, and volt-ohmmeter, answer first the
first activity.

5
Activity 2 - Threesome

Directions: Study the illustration below. Tell the equivalent in terms of R, resistance,
V, voltage and I, current for (1), (2), and (3). Write your answer in your test worksheet

The man
The direction 2. _______________?
1. _______________?

The load

3. __________________?

Did you like the activity? Did you analyze the illustration properly?

In what part of the illustration is resistance? When we say resistance, what

does it mean? To learn more about resistance, go to the next page.

6
 What is It

Electrical resistance represented by R is a measure of the opposition to

current flow in an electrical circuit. It is noted that different materials conduct
electricity differently. The unit of measurement for resistance (R) is ohms “Ω” named
after George Simon Ohms in 1827. An ohmmeter measures resistance.

Ohm’s Law expresses the relationship of current, voltage, and resistance

which is expressed in an equation R = V/R; where resistance is the quotient of the
voltage (V) over the current (I).

Methods of Reading Electrical Resistance

A. Ohm’s Law

Equation: E = I x R - equation in terms of voltage (E)

I = E / R - equation in terms of current (I)
R = E / I - equation in terms of resistance (R)
Where:

Unit of Unit
Quantity Symbol
Measurement Abbreviation

Current I Ampere (“Amp”) A

Voltage V Volt V

Resistance R Ohm Ω

Example:
In a simple circuit with 0.20 ampere current flow in a 220 volts power supply,
determine the resistance produced by temperature of light bulb.

Since: R = _________________?, based on given equation;

R=E/I
R = 220v/0.20amp. 1Ω = 1000kΩ
R = 1,100 Ω or 1.1k Ω

7
B. Ohmmeter Reading using Volt-ohmmeter.

Abstraction: Review from the reading measurement using Volt-ohmmeter.

To read the resistance, it is placed on the very top reading graduations, which is the
(0 to 20 counted by 1 per graduation), (20 to 50 counted by 2 per graduation), (50
to 100 counted by 10 per graduation), (100 to 200 counted by 20 per graduation),
(200 to 500 counted by 100 per graduation), (500 to 1k counted by 500 and 1k to

(δ)
3k counted 2k per graduation) and the infinity symbol means shorted.(graduation
may vary on brands and size of measuring tools, just see actual grading).

Ω Ω
Ω
Ω
Ω Ω
Ω

Multiplier

8
The Multiplier
Multiplier
Your
X1 X10 X100 X1K X10K X100K
answer
Example 1,000 Ω 10,000 Ω
(10 Ω) 10 Ω 100 Ω or 1KΩ or 10KΩ 100K Ω 1,000K Ω
1. 5 Ω 5Ω 50 Ω 500 Ω 5.0k Ω - -

2. 13 Ω 13 Ω 130 Ω 1.3k Ω 13k Ω - -

3. 26 Ω 26 Ω 260 Ω 2.6k Ω 26k Ω - -

4. 44 Ω 44 Ω 440 Ω 4.4k Ω 44k Ω - -

5. 70 Ω 70 Ω 700 Ω 7.0k Ω 70k Ω - -

C. Reading using Color Coding (resistor)

Note: Now you are doing right using volt-ohmmeter. But, there are rules on testing
resistor (an electronic component) as one medium component when you are in
troubleshooting and repair, later on. You are already knowledgeable on adjusting
selector knob into the Ohms multiplier. Today, we are going to perform reading the
resistance through resistor color code.

9
Example 1 LEGEND
BL = Black
From the example above,
BR = Brown
• First band (BR) brown= 1 O = Orange
• Second band (BL) black= 0 GR = Green
Equals to = 10 GY = Grey
GO = Gold
• Third band (O) Orange is multiplier = 10 x 1kΩ or 1,000Ω B =Blue
• Fourth band (BR) brown = + 1% S = Silver
Answer = 10kΩ+ 1% or 10,000 Ω+ 1% Y = Yellow
W = White
V = Violet

Example 2

From the example below,

• First band (BR) brown= 1

• Second band (BL) black= 0
• Third band (BL) black= 0
Equals to = 100

• Fourth band (O) Orange is multiplier = 100 x 1kΩ or 1,000Ω

• Fifth band (BR) brown = + 1%
Answer = 100kΩ+ 1% or 100,000 Ω+ 1% ,
,

10
The +% tolerance = reading of fourth/fifth band for tolerance.
Example 3

From the example 1 above,

10,000 Ω+ 1% = the tolerance is above 1% and under 1% representing (BR) brown

10,000Ω x 0.01 = 100 reading gap using volt-ohmmeter reading;

9,900Ω to 10,100 is considered as good reading;

Answer = minimum of 9,900Ω and maximum of 10,100Ω

so….it means plus with 100Ω and minus 100Ω

What’s More

Hey, nice to see you at this point of your lesson. In electrical installation and
maintenance, knowing one of the three is wholesome. The voltage, current, and
resistance. Their relationships make your knowledge complete. Let’s focus on
resistance!

Activity 3 - Solve Me!

Directions: Following the instructions on ohmmeter reading using volt-ohmmeter,
solve the given examples per graduation. Write your answer on your activity
notebook.

11
 What I Have Learned

After performing the activities on computing ohms reading, now let us

complete the mensuration and let’s determine how much you have learned.

Activity 4 - Go, Read, and Multiply!

Directions: Following the instructions you have learned, compute your previous
answer in activity 3 (What’s More) using multipliers. Write your answer on your
activity notebook.

Note: Using ohmmeter, your answer will be subjected to changes by adjusting

selector knob into the Ohms multiplier.

Multiplier
Your
X1 X10 X100 X1K X10K X100K
answer

Example 1,000 Ω 10,000 Ω

or 1KΩ
(10 Ω) 10 Ω 100 Ω or 10KΩ 100K Ω 1,000K Ω

1. - - -

2. - - -

3. - - -

4. - - -

5. - - -

6. - - -

7. - - -

8. - - -

9. - - -

10. - - -

Congratulations! You are doing a remarkable job. You want more? Go to the
next page.

12
 What I Can Do

What is your favorite color? Isn’t it nice to wear or see what you like, right?
Colors make our world beautiful. In reading resistance, color also matters. Now let’s
see what you’ve got.

Activity 5 - Color Me Crazy!

Directions: Read the following resistor by computing resistance using color code
formula. Write your answer on your activity notebook.

13
From the readings above, compute for the tolerance.

1.

2.

3.

4.

5.

Great! You’re improving. Congratulations!

14
 Assessment

How are you? Did you enjoy the varied techniques of reading
measurements in terms of resistance? Let us check your learning. Answer the
questions below on your test booklet.

1. Read the following reading measurements using ohmmeter. Write your answer
on your activity notebook.

2. Compute your previous answer using multiplier.

Multiplier
Your
X1 X10 X100 X1K X10K X100K
answer

Example 1,000 Ω 10,000 Ω

or 1KΩ
(10 Ω) 10 Ω 100 Ω or 10KΩ 100K Ω 1,000K Ω

1. - - -

2. - - -

3. - - -

15
 3. Compute for the tolerance and write your answer on your activity notebook.

1. 3 ohms + 5%

2. 66 ohms + 10%

3. 181 ohms + 50%

Additional Activities

Activity 6 - Make Your Own!

Directions: Make your own reading measurements and repeat the activities as you
want. Write your answer on the activity notebook. Apply what you have learned in
this module.

EXAMPLE With Reading No/Without Reading

(CONDUCTOR) (INSULATOR)

1.ballpen

2.paper

3.eraser

4.sleeper

5.plate

6.spoon

7.chair

8.table

9.glass

10.mirror

16
 17
Activity 3- Solve Activity 2 - Threesome!
Me! 1. Current
3. 28Ω 2. Voltage
3. Resistance
4. 65Ω
5. 2Ω
6. 7Ω
7. 11Ω
8. 17Ω
9. 85Ω
10.110Ω
11.160Ω
12.350Ω
Pre Test Activity 1- Hey Dude!
1. A 1. Resistance
2. A 2. Current
3. C
4. C
3. Voltage
5. D
6. B
7. C
8. A
9. B
10. A
11. A
12. C
13. FALSE
14. FALSE
15. TRUE
Answer Key
 18
Activity 5 – Color Me Assessment
Answers for Number 1
Crazy! 1. 180 Ω
2. 65 Ω
1. 910Ω + 5% 3. 2 Ω
2. 80Ω + 10% Answers for Number 3
3. 51Ω + 10% 1. 2.85 to 3.15
4. 7000Ω + 10% 2. 59.4 to 72.6
3. 9.5 to 271.5
5. 6000Ω + 0.055% Answers for Number 2
6. + 4.55
7. + 8
8. + 5.1
9. + 700
10. + 30
Activity 4 – Go, Read, and Multiply
 Activity 6 - Make Your Own!!

References

Blanco, Antonio Jr. and Roderick C. Verano, Technology and Livelihood Education-
module1 Learner Materials, IA-Carpentry. Meralco Avenue, Pasig City: Department of
Education, 2018, 37- 40.
en-us.fluk.com. How to Measure Resistance. Accessed August 2020. https://en-
us.fluk.com/training/training library/test-tools/digital-multimeters/ how-to-
measure-resistance.html.

sparkfun.com. How to Use a Multimeter. Accessed August 2020.

https://learn.sparkfun.com/tutorial/how-use-a-multimeter/measuring-resistance.

Vallarta, Hector M. and Roman A. Cabusora Jr. K To 12 Basic Education Curriculum

Technology and Livelihood Education Learning Module- Electrical Installation and
Maintenance Exploratory Course Grades 7 And Grade 8. Pasig City: Department of
Education, 2016, 59-76.

19
 DISCLAIMER
This Self-learning Module (SLM) was developed by DepEd
SOCCSKSARGEN with the primary objective of preparing for and addressing
the new normal. Contents of this module were based on DepEd’s Most
Essential Learning Competencies (MELC). This is a supplementary material
to be used by all learners of Region XII in all public schools beginning SY
2020-2021. The process of LR development was observed in the production of
this module. This is version 1.0. We highly encourage feedback, comments,
and recommendations.

For inquiries or feedback, please write or call:

Department of Education – SOCCSKSARGEN

Learning Resource Management System (LRMS)

Regional Center, Brgy. Carpenter Hill, City of Koronadal

Telefax No.: (083) 2288825/ (083) 2281893

Email Address: region12@deped.gov.ph
