Section 1 Uvisor™ Flame Scanners
Introduction Insert SF810i

here
All rights reserved. - 1 -
© Copyright ABB.
4/23/2008
Summary of Presentation
Introduction
Theory of Operation
Safe Flame Hardware
Installation and Tuning
© Copyright ABB - 2 -
Tangential Fired Boilers (T-Fired)
FS FS
Windbox Windbox FS FS
FS FS
FS FS
FS FS
FS FS
Top Plan View

Side Elevation View
Note: Four Scanners per elevation on either every elevation or every other
elevation depending on boiler operation. Fuel is injected from corners and the
entire fireball is considered one burner. Before “Fireball” is established (typically
above 30% of full load), individual burner discrimination is required.
Front and Rear Wall Fired Boilers
FS FS
FS FS FS FS
FS FS
FS FS FS FS
FS FS
FS FS
Top Plan View

Side Elevation View
Note: One scanner(minimum) per burner. Fuel is fired directly into boiler from
front and rear walls. Each burner is considered to be a unique ignition source.
Down Shot Fired Boilers
FS FS
FS FS
FS FS
FS FS
FS FS
Top Plan View Side Elevation View
Note: One scanner(minimum) per burner. Fuel is fired directly into boiler from top
down. Each burner is considered to be a unique ignition source.
What Is a Flame Scanner?
Coal Nozzle
Windbox Optical instrument that
senses:
Flame “ON”
Flame “OFF”
Fiber optic scanner
3”seal pipe 2-3” hole in spinner vane
2” Scanner guidepipe
Primary safety input
into BMS
One of most hated

instruments in plant!
ABB Flame Scanner History
40 years flame scanner

experience 1967 to present
Product Line :
UvisorTM
SafeFlameTM
Flame Explorer TM
SafeFlame was originally
part of Combustion
Engineering
Typical Flame Scanner Applications
Tangential Fired Utility

Boilers
Down Shot
Arc burners boilers
Front and Opposed Wall
Fired Boilers
Cyclone Fired Boilers
Gas Turbines
Oil / Gas Lighters
Duct burners and other small burners
Applications: Single vs. Dual Sensor
Possible sensor, scanner and signal processing unit combinations are shown below:
TM
The Uvisor SF810i integrated sensor & processing unit reduces overall hardware costs and is available either
with a single or dual sensor capability for sensing multiple fuels.
• Single scanner head (integrated) SINGLE sensor, targeting single burner flame (gaseous, liquid or
pulverized fuels)
SF810i
Flame Scanner & Signal processing
Single
• Single scanner head (integrated) DUEL sensor, targeting single burner flame (combination of gaseous,
liquid or pulverized fuels)
SF810i
Dual
Flame Scanner & Signal processing

Main Components of ABB Flame Scanner System
Integrated Integrated Flame
Scanner UvisorTM
SF810i
Through the windbox installation (F.O.C)

Connector/Cable to BMS
Main Components of ABB Flame Scanner System
Integrated
Integrated Flame
Scanner UvisorTM SF810i
Wall Mounted installation (L.O.S) Connector/Cable to BMS

Flame ExplorerTM Engineering Tool (Optional)
Window OS based
Trend and archive data

Save and reload parameters files
UvisorTM series, SafeFlameTM series, SF810i
Extended module diagnostic
UvisorTM SF810i Integrated Flame Scanner
Section 2 Uvisor™ Flame Scanners
Theory of Operation Insert SF810i
here
© Copyright ABB.
4/23/2008
General Terms/Understanding
Discrimination - Proving flame on a specific burner and

not from background radiation produced by adjacent or
opposing burners
Fireball - Single burner flame philosophy on former CE

tilting tangential burners
Photodiode Principle of Operation
Flame off Flame on
No light Current ~ Light intensity
Light from
flame
PHOTODIODE CURRENT *
+ -
Current
Flame Pulsation
0
0
TIME
* Simulated data for concept development only

Flame Scanner Principle of Operation
Light energy is converted to Electrical signal
Signal evaluated for frequency component and intensity
Three frequency based signal processing methods used
− Peak detection/counting
− Band pass filtering
− Flame “Signature” (FFT)
Measured values compared to programmed trip points
SCANNER HOUSING
CURRENT
SIGNAL TO
LOG
REMOTE CHASSIS
AMPLIFIER
CURRENT
AMPLIFIER
PHOTODIODE
FAULT PROTECTION
BURNER FLAME IMAGE

Flame Detection Parameters
Flicker Frequency = Slope Changes per second *
AC Amplitude
Detector raw signal output
Intensity
Time
Flame Detection Limits (Frequency Example)
Positive flame vote for
Frequency
frequency
Frequency
Pull-in Limit 12 Hz
Frequency 7 Hz
Trip Drop-out
Limit
Time in Seconds
milliamps
0.
00
0.000
0.200
0.400
0.600
0.800
1.000
1.200
1.400
1.600
1.800
2.000
0
0.
10
0
0.
20
0
0.
30
0
0.
40
0
0.
50
0
0.
60
Intensity
0
0.
70
0
0.
80
0
0.
90
0
Frequency
1.
00
0
1.
10
0
1.
20
0
Seconds
1.
30
0
1.
40
0
1.
50
0
1.
60
0
1.
Typical Scanner Output Signal
70
0
1.
80
Coal Flame
0
1.
90
0
2.
00
0
Scanner Head Electronics
Available in visible light, IR, or UV versions.

The dual sensor head IR/UV version.
Log amplifier for wide dynamic range
10E5 IR and Visible Light Scanners
10E2 UV Scanners
No local tuning
Fail safe surveillance over the whole flame signal path
Current output drives up to 5,000 ft. (2 - 0 ma)
Fiber Scanner Installation: Wall Burner
Coal Nozzle
Windbox
Fiber optic scanner

Section 3
Scanner head Uvisor™ Flame Scanners
selection and Insert SF810i
accessories image
here
© Copyright ABB.
4/23/2008
The Key to Successful Flame Scanning
Scanner head - Right scanner for

fuel(s) and burner type
Position – Scanner is only as good as
what it sees
Air – Sufficient, CLEAN, Cool
Scanner Head Selection based on boiler
Product Lines Scanner Heads Boiler Types Fuel Types
IR-LOS1 U/I Wall Fired Boiler HFO, PC
VL-LOS1 U/I Wall Fired Boiler HFO, PC
“UvisorTM UV-LOS1 U/I Wall Fired Boiler LFO, NG, BFG

SF810i”
or IR-FOC U/I Corner Fired Boiler HFO, PC
“UvisorTM
FAU810 VL-FOC U/I Corner Fired Boiler HFO, PC
+
SF810” UV-FOC U/I Corner Fired Boiler LFO, NG, BFG
UV-IR LOS1 U/I Wall Fired Boiler NG, HFO, PC
UV-IR FOC U/I Corner Fired Boiler NG, HFO, PC

U/I Utility (Steam Generators for Power Plants) and Industrial (Steam Generator for Industrial Process)
LFO Light Fuel Oil (Diesel)
HFO Heavy Fuel Oil
BFG Blast Furnace Gas
PC Pulverized Coal
NG Natural Gas
LOS Line of sight (Direct view from the burner plate)
FOC Fiber optic cable (Through the windbox)
IR Infrared
VL Visible Light
UV Ultraviolet
Notes 1) On large windbox utility boilers FOC installation is recommended
Flame Scanner Application Table
Abbreviations
Scanner Guide Pipe, T-Fired Furnaces
TILTING NOZZLE
TIP ASSEMBLY
IGNITOR
SCANNER AIR TURNING

GUIDE PIPE VANES
SCANNER
COOLING AIR
MANIFOLD
Gas/Oil burner displacement

on a corner fired boiler
OIL GUN
ASSEMBLY
FLAME DAMPER
SCANNER GAS CL
ASSEMBLY SUPPLY
Scanner Guide Pipe, T-Fired Furnaces
Blind flange
Purge/Cool air
provision
FOC Installation on Wall Burner
Coal Nozzle
Windbox
Fiber optic scanner

FOC Installation
LOS Installation on Wall Coal Burner
Coal Nozzle
Windbox
3”seal pipe 2-3” hole in spinner vane for existing

Sighting tube scanner mirror tube or sight glass

Wall Fired Installation
Recommended Cooling/Purge Air
Through the Windbox Fiber Optic Scanners

450 l/min (15 SCFM) @ 350 mm (13”) WC above
Windbox Pressure
Wall Fired LOS (Line of Sight) Scanners

6 to 10 SCFM
Section 4
Uvisor™ Flame Scanners
Flame Scanners Insert SF810i
Operation image
here
© Copyright ABB.
4/23/2008
Flame Scanner Electronics
UvisorTM SF810i
UvisorTM SF810i Wiring
Max 125 Profibus / Modbus nodes
T Bus termination
n Number of conductors
10 2 2 10 2 2 10 2 2
RS-485 network
RS-485 network
T
T
Local Junction Box Local Junction Box Local Junction Box
2 3 3 2
T
DI DO
T
24Vdc 24Vdc BMS
Flame ExplorerTM
Mains 4-20mA DCS Engineering Tool
Remote Tuning
Section 5
Uvisor™ Flame Scanners
Flame ExplorerTM Insert SF810i
here
© Copyright ABB.
4/23/2008
Flame ExplorerTM – Start-Up Display
Flame ExplorerTM – Configuration Display
Flame ExplorerTM – Parameter Display
Flame ExplorerTM – Parameter Display
Flame ExplorerTM – Single Trend Display
Flame ExplorerTM – Four Trend Display
Flame ExplorerTM – Overview Display
Flame ExplorerTM – Replay Mode
Note: Values at curser line shown in boxes

1” FOC Scanner Data on Oil Ignitor
Burner G7 - Visible Light 3 degree lens
F9 = 20, adjusting atomizing air pressure
Atomizing air pressure regulator

essentially at max pressure
Ignitor
Ignitor Increasing air Off
On pressure
Decreasing atomizing air

pressure using regulator
Note: Boiler at Full Load with coal elevation in service.

Wall Fired Burner

T-Fired Burner
Elevation F
Elevation E-F Oil
Elevation E
Elevation D
Elevation C-D Oil
Elevation C
Legend Elevation B
Elevation A-B Oil
Coal
Elevation A
Oil
Flame
Scanner
Down Shot Cyclone Burner
Industrial Boilers
UvisorTM SF810i - Features
Features
The UvisorTM SF810i system offers a wide range of signaling and communication
output possibilities.
Redundant Profibus DP-V1for high speed (up to 12 Mbit/sec) and safe data transfer, or
alternatively:
Redundant Modbus 255 nodes @ 115 Kbit/s
4-20mA optically isolated
1 (fuse protected) N.O main flame relay contact
1 (fuse protected) N.O fault relay contact, Configurable as secondary flame relay or
flame quality relay
2 Digital Inputs for external parameter file selection
Local tuning via a 4-push button digital display
ATEX II 2GD T6 IP66 (gas & dust) explosion proof enclosure designed for both LOS
(line of sight) and FOC (fiber optic cable) installations
70°C Max operating temperature
UvisorTM SF810i - Advantages
Wide range of combination fuel sensing.
Profibus capability
Modbus Capability.
Remote Tunable.
Explosion Proof system
Isolated 4-20 ma selectable into intensity, frequency, quality of fuel.
Flame out is configurable upto 4secs
No need of hand-held programming tool. Push-button for local tune and PC based
software for remote tuning. Upload , download, archiving and trending possible.
No mechanical shutters required, continuous self checking by the microprocessor.
70°C Max operating temperature

Section 1: Insert Image Here

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Section 1: Insert Image Here

Uploaded by

Copyright:

Available Formats

Section 1 Uvisor™ Flame Scanners

Introduction Insert SF810i

Top Plan View

Top Plan View

Top Plan View Side Elevation View

 One of most hated

 40 years flame scanner

 Tangential Fired Utility

Flame Scanner & Signal processing

Through the windbox installation (F.O.C)

Wall Mounted installation (L.O.S) Connector/Cable to BMS

 Trend and archive data

 Discrimination - Proving flame on a specific burner and

 Fireball - Single burner flame philosophy on former CE

* Simulated data for concept development only

BURNER FLAME IMAGE

Flicker Frequency = Slope Changes per second *

Positive flame vote for

 Available in visible light, IR, or UV versions.

Fiber optic scanner

 Scanner head - Right scanner for

IR-LOS1 U/I Wall Fired Boiler HFO, PC

VL-LOS1 U/I Wall Fired Boiler HFO, PC

“UvisorTM UV-LOS1 U/I Wall Fired Boiler LFO, NG, BFG

UV-IR LOS1 U/I Wall Fired Boiler NG, HFO, PC

UV-IR FOC U/I Corner Fired Boiler NG, HFO, PC

SCANNER AIR TURNING

Gas/Oil burner displacement

Fiber optic scanner

3”seal pipe 2-3” hole in spinner vane for existing

Sighting tube scanner mirror tube or sight glass

 Through the Windbox Fiber Optic Scanners

 Wall Fired LOS (Line of Sight) Scanners

Local Junction Box Local Junction Box Local Junction Box

Note: Values at curser line shown in boxes

Atomizing air pressure regulator

Decreasing atomizing air

Note: Boiler at Full Load with coal elevation in service.

Wall Fired Burner

You might also like

One of most hated

40 years flame scanner

Tangential Fired Utility

Trend and archive data

Discrimination - Proving flame on a specific burner and

Fireball - Single burner flame philosophy on former CE

Available in visible light, IR, or UV versions.

Scanner head - Right scanner for

Through the Windbox Fiber Optic Scanners

Wall Fired LOS (Line of Sight) Scanners
