2019/2020

Ring Main Unit (Authorized by ABB)

ABB SafeRing/SafePlus 12 kV/24 kV UniSec ABB 12 kV~24 kV air-insulated

switchgear and control gear

CL-SRM1 CL-SRM2
Gas-insulated Switchgear 12-24KV Air-insulated Switchgear 12-24KV

Recloser
CLW32 12-24KV CLW32 38KV

CLF3 12~24KV
Outdoor Vacuum Load Switch
Switchgear
GIS GZX Series Cubicle MV AIS KYN28 Series 12-24KV
Type N2 Gas Insulated Switchgear

MV AIS KYN61 Series 40.5KV MNS 2.0 Low Voltage Switchgear

CL-YBM1 Box-type Transformer Substation

Inverter Integrated Machine

12-35KV
ABB SafeRing/SafePlus 12 kV/24 kV

1. Overview
Authorized by ABB High Voltage Switchgear Co., Ltd., Beijing,
a full range of ABB Safe Ring/Safe Plus Seires 12-24 KV SF6
gas-insulated switchgear has been produced by Suzhou Clou-
MGE Electric Co., Ltd. from 1st January 2018, which is suitable
for distribution systems featuring AC 50-60HZ, 12-24KV. With
load switches and fuses or breaker units as its core
components, the product is widely utilized in substations of
load centers such as urban residential districts, large-scale
public buildings, factories and enterprises.

Executive standard:IEC 62271-1

2. Technical Parameters

3. Product Features
Fixed yet with flexible configuration. With flexible unit combination, multiple modular units can be configured
within the same SF6 insulating chamber, thus meeting complicated distribution schemes.
Fully insulated and fully sealed are realized given the high-voltage charged parts such as switches and busbars are
sealed in the stainless steel box and cables in silicon rubber cable accessories, which are free from environmental
impacts and able to be installed in humid, dusty and salty areas and mines.
With fully sealed structure and high level protection class, the product is free from environmental impacts,
cleaning, and maintenance.
With compacting structure and minimum unit width of 325mm, the product demands small floor space.

Ring Main Unit

4. Outline Structure Dimension Drawing

5. Typical Applications

P01/02
UniSec ABB 12 kV~24 kV air-insulated
switchgear and control gear
1. Overview

Authorized by ABB High Voltage Switchgear Co., Ltd., Beijing,

a full range of ABB UniSec Series 12-24 KV air-insulated
switchgear has been produced by Suzhou Clou-MGE Electric
Co., Ltd. from 1st January 2018, which is suitable for
distribution systems featuring AC 50-60 HZ, 12-24KV and plays
a role of accepting and distributing electricity. With load
switches and fuses or breaker units as its core components,
the product is widely utilized in substations of load centers such
as urban residential districts, large-scale public buildings,
factories, and enterprises.

Executive standard: IEC 62271-1

2. Technical Parameters

3. Product Features
All insulation is realized through the application of embedded poles technology, epoxy resin, and silicon
rubber and the protection class is Ip67.

Terminating the application of SF6 makes it environmental-friendly.

With the application of intelligent ring network switchgear, it is small in size, light in weight, safe, and reliable.
Fully insulated and fully sealed are realized given charged parts are sealed in epoxy resin switch socket and
silicon rubber enclosed busbars.

Applying phase separation design, phase insulator avoids the possibility of phase-to-phase discharge.
Featuring full modularization design, standardization, and assembly structure, modular units can be maintained
and replaced onsite in accordance with the demands of customers.

Equipped with various mechanical interlocking functions, five-prevention system is realized and switch working
positions in three phases are visible and independent from each other.

Ring Main Unit

4. Typical Applications

SDC-Unit with switch-disconnector SFC-Fused type of switch-disconnector unit

SBC – circuit-breaker with switch-disconnector SDV/BRV – PT unit

5. Structure Dimensions
The drawings merely show indicative dimensions of typical units but do not refer to specific configurations

Front view Side view

P03/04
CL-SRM1
Gas-insulated Switchgear 12-24KV
1. Overview

According to product features of ABB Safe Ring/Safe Plus

Seires 12-24 KV SF6 gas-insulated switchgear, utilizing its
core components, and combining China’s power supply
requirements, CL-SRM1, the new generation of small
scale MV Gas-insulated Switchgear has been designed
and developed, which is suitable for distribution systems
featuring AC 50-60HZ, 12-24KV. With load switches and
fuses or breaker units as its core components, the product
is widely utilized in substations of load centers such as
urban residential districts, large-scale public buildings,
factories, and enterprises.

Executive standard: IEC 62271-1

2. Technical Parameters

3. Product Features

With ABB’s chamber and operate machining as its core components and 90% of its parts provided by ABB’s supply channel,
the quality is guaranteed.

Fixed yet with flexible configuration. With flexible unit combination, multiple modular units can be configured within the same
SF6 insulating chamber, thus meeting complicated distribution schemes.

Fully insulated and fully sealed are realized given the high-voltage charged parts such as switches and busbars are sealed in
the stainless steel box and cables in silicon rubber cable accessories, which are free from environmental impacts
and are able to be installed in humid, dusty, and salty areas and mines.

With fully sealed structure and high level protection class, the product is free from environmental impacts, cleaning, and
maintenance.

With compacting structure and minimum unit width of 350mm, the product demands small floor s pace.
Ring Main Unit
4. Outline Structure Dimension Drawing

5. Typical Applications

P05/06
CL-SRM2
Air-insulated Switchgear 12-24KV

1. Overview
According to product features of ABB UniSec Series air-
insulated switchgear, utilizing its core components, and
combining China’s power supply requirements, CL-SRM2, the
new generation of small scale MV Gas-insulated Switchgear
has been designed and developed, which is suitable for
distribution systems featuring AC 50-60HZ, 12-24KV. With load
switches and fuses or breaker units as its core components,
the product is widely utilized in substations of load centers
such as urban residential districts, large-scale public buildings,
factories, and enterprises.
Executive standard: IEC 62271-1

2. Technical Parameters

3. Product Features
With ABB’s load switches, breakers, and operate machining as its core components and 90% of its parts provided by ABB’s
supply channels, the quality is guaranteed.

All insulation is realized through the application of embedded poles technology, epoxy resin, and silicon rubber and the
protection class is Ip67.

Reducing the application of SF6 makes it environmental-friendly.

With the application of intelligent ring network switchgear, it is small in size, light in weight, safe, and reliable.
Fully insulated and fully sealed are realized given charged parts are sealed in epoxy resin switch socket and silicon rubber
enclosed busbars.

Applying phase separation design, phase insulator avoids the possibility of phase-to-phase discharge.
Featuring full modularization design, standardization, and assembly structure, modular units can be maintained and replaced
onsite in accordance with the demands of customers.

Ring Main Unit

 Equipped with various mechanical interlocking functions, five-prevention system is realized and switch working
positions in three phases are visible and independent from each other.


4. Typical Applications

SDC-Unit with switch-disconnector SFC-Fused type of switch-disconnector unit

SBC – circuit-breaker with switch-disconnector SDV/BRV – PT unit

5. Structure Dimensions
The drawings merely show indicative dimensions of typical units but do not refer to specific configurations

Front view Side view

P07/08
CLW32 12-24KV

1. Overview

CLW32-12/24 series outdoor vacuum reclosers, as outdoor

high voltage switchgears for 3-phase AC 50HZ/60HZ, 12KV,
17.5KV, and 24KV, can be utilized in overhead distribution
lines or distribution substations. Playing a role of switching
on/off load current, overload current, and short-circuit current,
the product is equipped with various functions such as
protection, measuring, receiving and sending signals,
controlling, as well as adjustably automatic reclosing function
for three times at most.

The product complies with IEC62271-111:2012 and

2. Technical Parameters other relevant international standards.

2.1 outdoor vacuum breaker technical parameters

2.2 EMC Class of Controller

Recloser
3. Product Features and Characteristics

With three-phase column structure and small size, it is easy to install. Outdoor epoxy resin is utilized in column with
current transformer installed inside. One unit of potential transformer is installed inside each phase column and
another unit of external potential transformer is available. The partial discharge of the product is less than 10pc.

The vacuum arc-extinguishing chamber of longitudinal magnetic field is reliable with stable breaking performance.
Monostable permanent magnet operating mechanism is utilized to ensure as less moving parts as possible, thus
increasing product’s reliability and reducing maintenance.

Manual quick switch on operating machine is utilized to ensure switch on operation with load when power off.
Outdoor print is utilized in stainless steel to improve its corrosion resistance in harsh environment.
CLS51 is composed of three parts, which is power system, inputting 165-265VAC, 50/60HZ while supporting
battery charging function, core units, including human-computer interface, communication, sampling and
operation judgment, and driver unit, capable of drive switch on/off operating machine of CLW32-12/24M.

Protection function of CLS51 includes over current protection, zero sequence ground protection, directional
zero sequence grounding protection, low voltage/over voltage protection, and automatic reclosing function.

Backup battery is available for CLS51 controller, so as to support more than 300 times of switching on/off operations when power
off or 48 hours continuous operation. It is capable of event query, fault recording, measuring and remote communication.

4. Outline Structure Dimension

Structure Drawing of Breaker

1, Aerial socket; 2, Switch off handle; 3, Switch on handle; 4, Indicator; 5, Shell;

6, Embedded pole; 7, voltage transducer; 8, Current transformer; 9, Lower outlet; 10, Upper outlet; 11,
Hoisting ring

P09/10
4. Structure Dimensions

Outline dimensions of 12KV breaker

Outline Dimension of 17.5/24KV breaker

Recloser
5. Typical Applications

Single pole installation method Double pole installation method

1, Outdoor breaker; 2, Intelligent controller; 3, Potential Transformer

P11/12
CLW32 38KV

1. Overview

CLW32-38 series outdoor vacuum reclosers, as outdoor

high voltage switchgears for 3-phase AC 50HZ/60HZ,
38KV, can be utilized in overhead distribution lines or
distribution substations. Playing a role of switching on/off
load current, overload current, and short-circuit current,
the product is equipped with various functions such as
protection, measuring, receiving and sending signals,
controlling, as well as adjustably automatic reclosing
function for three times at most.

The product complies with IEC62271-111:2012 and other

relevant international standards.
2. Technical Parameters
2.1 outdoor vacuum breaker technical parameters

2.2 EMC Class of Controller

Recloser
3. Product Features and Characteristics

With three-phase column structure and small size, it is easy to install. Outdoor epoxy resin is utilized in column
with current transformer installed inside. One unit of potential transformer is installed in each phase column and
another unit of external potential transformer is available. The partial discharge of the product is less than 10pc.

The vacuum arc-extinguishing chamber of longitudinal magnetic field is reliable with stable breaking performance.
Three phase permanent magnetic operating machine synchronous breaking is utilized and three phase
independent breaking indication is set to ensure reliable breaking.

Outdoor print is utilized in stainless steel to improve its corrosion resistance in harsh environment.
CLS51 is composed of three parts, which is power system, inputting 165-265VAC, 50/60HZ while supporting
battery charging function, core units, including human-computer interface, communication, sampling and
operation judgment, and driver unit, capable of drive switch on/off operating machine of CLW32-38M.

Protection function of CLS51 includes over current protection, zero sequence ground protection, directional zero
sequence grounding protection, low voltage/over voltage protection, and automatic reclosing function, and is
equipped with four types of IEC curves and ten types of ANSI curves.

Backup battery is available for CLS51 controller, so as to support more than 300 times of switch on/off operations when power off
or 48 hours continuous operation. It is capable of event query, fault recording, measuring and remote communication.

4. Structure Dimensions

Outline dimension of 38KV breaker

5. Typical Applications

Single pole installation method Double pole installation method

1, Outdoor breaker; 2, Intelligent controller; 3, Potential Transformer

Recloser
CLF3 12~24KV Outdoor Vacuum Load Switch

1. Overview

Designed for distribution network featuring rated voltage

12/24, rated current 630A, 50/60HZ, CLF3-12/24 Outdoor
Vacuum Load Switch can be utilized to switch on/off load
current and over current in power systems, and to
automatically isolate faulty distribution line segments.
Equipped with the latest developed electronic controller, the
switch can be operated manually, electrically, and remotely.
Installed inside the stainless steel box, electronic controller
can be used in various climatic conditions.

2. Technical Parameters

P13/14
3. Product Features and Characteristics

SF6 insulation
Featuring non-toxic and non-flammable, SF6 is a kind of good dielectric gas with excellent arc extinguishing characteristics.
Various Bushing
In addition to standard ceramic bushing, various bushings can be provided, including rubber electrical insulator
used in epoxy equipment bushing.
Visible switching on/off condition
It is easy to observe the main contact location indicator (green—switching off; red—switching on) marked with color on
the ground, which is directly connected with main contact drive shaft to ensure accurate display of contact condition.
Quick operation
Operation machine of spring energy storage is utilized to ensure quick switch on/off operation (less than 100 millisecond).
Remote operation
Electronic controller is equipped to realize onsite operation and master station operation through FTU interface.
Firm and durable switches
Verified materials featuring firm, durable, and erosion-resistant (304L stainless steel plate specialized for warships) are utilized to
ensure long service life (30 years) and a series of operations, demonstrating excellent features of outdoor vacuum equipments.

4. Structure Dimensions

Recloser
5. Typical Applications

P15/16
GIS GZX Series
Cubicle Type N2 Gas Insulated Switchgear
1. Overview

As fixed switchgears featuring N2 insulation and mental

shell, GIS GZX0-12/GZX1-24/GZX2-40.5 AC Mental
Closed Switchgear (hereinafter referred to as C-GIS) is
indoor equipments for three phase AC 50/60HZ single
busbar and bus section, which is mainly utilized in
distribution systems such as auxiliary power in power
plants, small and medium sized generators, substations,
tall buildings, industrial and mining enterprises, metros and
electrified railways. It complies with IEC 62271.

2. Technical Parameters
2.1 GZX0 /GZX1/GZX2 rated technical parameters

Switchgear
2.2 VS1X0/VS1X1/VS1X2、DS0/DS1/DS2 rated technical parameters

3. Product Features

SF6 is replaced with low pressure N2 as the insulation medium of primary loop to realize vacuum arc suppressing
and to truly demonstrate environment-friendly features.

Modular design and various functions combination ensure flexible configuration. With standard width of
500mm and compacting structure, it demands small floor space.

PLC intelligent controlling system is utilized to integrate electric operation and display of breakers and three
position switches, sending signal of gas pressure fault and alarming, background monitoring, interlock function
together, and to realize complete background operation, and to satisfy distribution network automation.

P17/18
4. Product Structure

1.Low pressure chamber

2.Gas pressure gauge
3.Three position switches operating machine
4.DSO three position switches (working position)
5.Breaker operating machine
6.VS1X0 vacuum breaker
7.Arrestor
8.Cable terminal
9.Current transformer (core-piercing)
10.Shell
11.Cable chamber
12.Cable socket
13.Inflation compartment pressure relief equipment
14.Inflation compartment
15.Main busbar
16.Plug-and-play potential transformer Inflation (N2)
compartment

5. Typical Applications

12KV GZX0 630A/25KA

1.Instrument compartent
2.Gas density realay
3.Menchanism of 3-position switch
4.3-position switch
5.VCB
6.Mechanism of VCB
7.Arrester
8.Cable terminal
9.Cable compartment
10.PT
11.CT
12.Cable socket
13.Gas compartment
14.Pressare relief device of
gas compartment
15.Main busbar
16.Pressare relief duct
17.Insulation gas

GZX0 single gas compartment

Switchgear
12KV GZX0 1250A/25KA
24KV GZX1 1250A/25KA
1.Instrument compartent
2.Gas density realay
3.Menchanism of 3-position
switch
4.3-position switch
5.Mechanism of VCB
6.VCB
7.Arrester
8.Cable terminal
9.Pressare relief duct
10.CT
11.Cable compartment
12.Cable socket
13.Pressare relief device of gas
compartment
14.Gas compartment
15.Main busbar
16.Insulation gas
GZX0 double gas compartment

40.5KV GZX2 1250A/25KA 2500A/31.5KA

1.Instrument compartent
2.Gas density realay
3.VCB
4.Mechanism of VCB
5.3-position switch
6.Menchanism of 3-position switch
7.Main busbar
8.Gas compartment
9.Cable compartment
10.Pressare relief duct
11.CT
12.Arrester
13.Cable terminal
14.Cable socket
15.Pressare relief device of
gas compartment
16.PT
17.Insulation gas
GZX2 double gas compartment

P19/20
 40.5KV GZX2 1250A/25KA 2500A/31.5KA
1.Instrument compartent
2.Menchanism of 3-position switch
3.3-position switch
4.Gas density realay
5.VCB
6.Mechanism of VCB
7.Cable socket
8.Cable terminal
9.Cable compartment
10.PT
11.Gas compartment
12.Pressare relief device of gas
compartment
13.Pressare relief duct
14.CT
15.Main busbar
16.Insulation gas

GZX2 triad gas compartment

Switchgear
MV AIS KYN28 Series 12-24KV

1. Overview

As armored removable AC mental-enclosed switchgear

(hereinafter referred as switchgears), KYN28A is a whole
unit of distribution device for 3.6-24KV three phase AC
50/60HZ single busbar and single busbar segmented
system, which is mainly utilized in power plants, industrial
and mining enterprises distribution and large-scale high
voltage motor starting. The switchgear complies with IEC
62271 and is equipped with five-prevention interlocking
function. The switchgear can be used together with
imported vacuum breakers such as VD4, VEP, vacuum
breakers MEV9-12 produced by our company, and various
vacuum contactors, making it a power distribution device
with superior performance.

2. Technical Parameters
2.1 Technical data of switchgea

2.2 Technical data of VCB

P21/22
3. Product Features


Modular assembly structure is utilized in cabinet to make it beautiful in shape, small in size, and light in weight.


Operation power in secondary circuit can be selected flexibly in accordance with the demands of customers while
ensuring safe and convenient operation.


With great breaking capacity, vacuum breakers equipped are highly qualified, reliable, durable, and maintenance-free.


Advanced and reliable mechanical interlocks are equipped with a full range of operation functions and faulty
operations are effectively prevented with mechanical interlocks installed between neighboring switchgears’ handcarts.


Before cabinet and behind cabinet maintenance make it safer and more flexible.

4. Product Structure

A. Busbar
B. Circuit breaker cubicle
21
C. Cable cubicle
D 20
1 D. Relay instrument cubicle
19
1. Enclosure
2 18 2. Small branch bus
A 3. Bus bushing
3 17
4. Main busbar
4
16 5. Fixed contact device
6. Fixed contact box
5 7. Current transformer
B
2300

8. Earthing switch
6
15 9. Cable
10. Surge arrester
7 11. Main earthing busbar
1920

160

12. Base plate

0

8 14 13. Control mini busbar

9 14. Operating device of earthing switch
13 15. Withdrawable level board
C
10 16. Heating device
12 17. Circuit breaker dolly
11 18. Secondary plug
19. Shutter
20. Partition
21. Pressure release device

5. Typical Applications and Outline Dimensions

5.1 3.6/7.2/12kV switchgear

Incoming panel + PT unit

Switchgear
PT unit

Outgoing unit

P23/24
5.2 24 kV switchgear

Incoming panel + PT unit

PT unit

Outgoing unit

Switchgear
MV AIS KYN61 Series 40.5KV

1. Overview

As armored AC mental-enclosed switchgear (hereinafter

referred as switchgears), KYN61-40.5 is a whole unit of
distribution device for 40.5KV three phase AC 50/60HZ
single busbar and single busbar segmented system, which
is mainly utilized to receive and distribute electricity in
distribution room of power plants, substations and industrial
and mining enterprises, and is equipped with controlling,
protection, and monitoring function. The switchgear
complies with IEC 62271 and is equipped with five-
prevention interlocking function. It can be used together
with imported vacuum breakers such as VD4, VEP and
vacuum breakers MEV9-40.5 produced by our company.

2. Technical Parameters

3. Product Features

Modular assembly structure is utilized in cabinet to make it beautiful in shape, small in size, and light in weight.


Operation power in secondary circuit can be selected flexibly in accordance with the demands of customers while ensuring safe
and convenient operation.


With great breaking capacity, vacuum breakers equipped are highly qualified, reliable, durable, and maintenance free.


Advanced and reliable mechanical interlocks are equipped with a full range of operation functions and faulty operations are
effectively prevented with mechanical interlocks installed between neighboring switchgears’ handcarts.


Before cabinet and behind cabinet maintenance make it safer and more flexible.

P25/26
4. Product Structure

1-Instrument chamber

2-Switch chamber

3-Main switch

4-pressure relief channel

5-earthing operating machine

6-Busbar chamber

7-Current transformer

8-Earthing switch

9-Cable chamber

5. Typical Application And Product Dimension

Incoming panel + PT unit

Switchgear
PT unit

Outgoing unit

P27/28
MNS 2.0 Low Voltage Switchgear
1. Overview
Authorized by ABB (China) Co., Ltd., a whole set of
MNS2.0 Series low voltage withdrawable switchgear has
been produced by Suzhou Clou-MGE Electric Co., Ltd.
from 1st January 2018, which complies with IEC 60439.
The product can be utilized to receive, feed, and control
power in low voltage distribution systems such as power
plants, substations, tall buildings, theaters, hospitals,
stadiums, airports, ports, industrial and mining enterprises.

2. Technical Parameters

3. Product Features
As global-advanced low pressure withdrawable and fully enclosed metal AC switchgears, MNS2.0 adopts ABB original
device from low pressure components to accessories inside, thus ensuring stable operation and high reliability.

Switchgear
4. Typical Application

P29/30
P37/38
CL-YBM1 Box-type Transformer Substation

1. Overview
As a whole unit of compact distribution devices combining
high voltage electrical devices, transformers, and low voltage
electrical devices together, CL-YBM1-12, 24, 35 high
voltage/low voltage prefabricated substations can
independently realize voltage conversion, power protection,
controlling, and distribution power, which can be used in tall
buildings in cities, urban and rural architectures, squares and
parks, residential districts, medium-small sized factories, mine
and oil field and temporary power supply for construction
places to receive and distribute power in distribution systems.
It complies with IEC 1320 High Voltage/ Low Voltage
Prefabricated Substations.

2. Technical Parameters

3. Product Features
Adopting modular design, box type transformer substation installs multi-circuit high and low voltage switchgears, armored
busbars, automatic systems, communication, remote control, measuring, capacitor compensation, DC and other electric units
together inside a wholly enclosed box to ensure convenient onsite installation and shorten construction duration. Since the
whole unit is prefabricated and commissioned in the factory, it is highly safe and reliable.

Transformer
4. Product Structure and Foundation Drawing

P39/40
5. Typical Application

Transformer
Inverter Integrated Machine 12-35KV

1. Overview
Summarized from years of experience about energy-saving type
transformers and high and low voltage prefabricated substations
and combining characteristics of global cleaning energy
(photovoltaic power generation, wind power generation), box
type inverter integrated machine is a new type of energy saving
product specially designed and produced by Suzhou Clou-MGE
Electric Co., Ltd for photovoltaic power plants (wind power
plants). Adopting the structure of three-dimensional coil core
(special order) or plain laminated iron core, the transformers for
power generation are featuring three-phase balance, low loss,
strong short-circuit resistance, overload capacity, and small
magnetic field, making it more suitable for photovoltaic power
generation (wind power generation) and more superior
compared with other normal transformers for photovoltaic power
generation (wind power generation).

2. Technical Parameters

P41/42
3. Product Features

High integration and one-stop design: 1MW/2MW/2.5MW/5/1MW realizes one-stop photovoltaic system design for
unit integration design, internal integrated inverter, photovoltaic DC power distribution cabinet, communication
device, and distribution boxes for substations.

Professionalism and factory prefabrication: design is more professional and differentiated given its outdoor
integrated supply, factory prefabrication and fully combination of customers’ demands.

Safe and reliable with thorough protection measures: integrated access control monitoring and smoking alarm
system are utilized together with various protection measures to prevent fire, rain, dust, and small animals from
accessing the substation to ensure system security.

Unattended and highly intelligent: integrated SCADA monitoring system is completely compatible with smart grid
interface, thus ensuring a high degree of automation and unattended condition.

Adaptable to various environments: thanks to standardized container design with IP54, it can be utilized in high
altitude, strong wind and extreme temperature and other harsh environments.

4. Product Structure Dimension

Transformer
5. Typical Application

CLOU-MGE Electric Co., Ltd.

P43/44
Tel: +86 13713948167
Fax: +86-755-3690 1042 ext. 3853
Mail: henry@szcloudz.com
Web: www.szcloudz.com
